A604_40.

fm Page 13 Friday, October 10, 2008 10:59 AM

Front Suspension 40-13

Front Stabilizer Bar

Front suspension control arms

½ Suspension arms are available separately or as a kit. Included in kit
A60440008

are:
• Upper front control arms
• Upper rear control arms
• Stabilizer bar links
• Lower rear control arms
• Lower front control arms
• Mounting hardware

See Front suspension components diagrams in this repair group

for suspension arm locations and torque specifications.

Suspension arm components

A60440005
1. Lower front control arm (right)
2. Lower strut mount (right)
3. Stabilizer bar link (right)
4. Upper rear control arm (right)
5. Stabilizer bar mounting bracket
6. Upper rear control arm (left)
7. Stabilizer bar link (left)
8. Lower strut mount (left)
9. Lower front control arm (left)
10. Outer CV boot (right)
11. Lower rear control arm (right)
12. Axle flange (right)
13. Axle flange (left)
14. Lower rear control arm (left)
15. Outer CV boot (left)

FRONT STABILIZER BAR

Front stabilizer bar, removing and installing
– Raise car and support safely.
A60440020
WARNING —
• Make sure car is stable and well supported at all times. Use a
professional automotive lift or jack stands designed for the
purpose. A floor jack is not adequate support.

– Remove engine lower cover. See 03 Maintenance.

½ Remove stabilizer link nut (A).

– Remove stabilizer link from bar.
323
– Unscrew mounting bracket nuts (B) and remove stabilizer.
A604_40.fm Page 14 Friday, October 10, 2008 10:59 AM

40-14 Front Suspension

Front Stabilizer Bar

– Installation is reverse of removal. Remember to:

• Match stabilizer bar to suspension version.
• Mount bushing and stabilizer bar without grease.
• Attach stabilizer bar links. See Front stabilizer bar links in this
repair group.

Tightening torque
Stabilizer bar bracket to chassis (replace nuts) 25 Nm (18 ft-lb)

6 Front stabilizer bar links

A40-0266
From model year 1999, stabilizer bar link with bonded rubber
1 bushings replaces unit with ball joints.
5 4
Link with ball joint
3 1. Link with ball joint
2. Lower front control arm
3. Self-locking nut, 40 Nm (30 ft-lb) plus additional 90°
4. Clip
2 5. Self-locking nut, 100 Nm (74 ft-lb)
A40-0266
6. Stabilizer bar

Link with bonded rubber bushings

A40-0269 7 1
1. Link with rubber bushing (rubber bushing (A) with pressed-on
2 spacer is bolted to stabilizer)
2. Self-locking nut, 40 Nm (30 ft-lb) plus additional 90° turn
6 5 3. Bolt
A 4. Lower front control arm
3
5. Bolt
4
6. Self-locking nut, 60 Nm (44 ft-lb)
7. Stabilizer bar

A40-0269

A
½ Link (A) for left side of vehicle
A40-0268
– Link (B) for right side of vehicle

– Arrow on link points in direction of travel.

– Place fixed spacer (1) on stabilizer.

B CAUTION—
• To avoid damage, bonded rubber bushings may only be flexed
to a limited extent. Tighten suspension bushing bolts with
1 vehicle in curb weight position. See Curb weight position in
this repair group.
A40-0268
