SMD LED

Edition: V1.2 Date: Jun 2010

SMD LED 1608 SMD LED

Model: LED-0603 Color: Red/Yellow/Green/Blue/White. Select the products you need. Make sure the product Model in your orders are what you want.

Part Number LED-0603RVC LED-0603YVC LED-0603GVC LED-0603BVC LED-0603WVC

Material GaAllnP GaAllnP InGan InGan InGan

Chip Emitted Color Red Yellow Green Blue White

D(nm) 620-635 580-595 500-535 460-475 -

Lens Type

Vf(V) Typ. 1.8 1.8 3.0 3.0 3.0 Max. 2.4 2.4 3.6 3.6 3.6

Iv(mcd) Min 30 30 50 30 50 Typ 80 80 120 80 150

Water Clear

2012 SMD LED

Model: LED-0805 Color: Red/Yellow/Green/Blue/White. Select the products you need. Make sure the product Model in your orders are what you want.

Part Number LED-0805RVC LED-0805YVC LED-0805GVC LED-0805BVC LED-0805WVC

Material GaAllnP GaAllnP InGan InGan InGan

Chip Emitted Color Red Yellow Green Blue White

D(nm) 620-635 580-595 500-535 460-475 -

Lens Type

Vf(V) Typ. 1.8 1.8 3.0 3.0 3.0 Max. 2.4 2.4 3.6 3.6 3.6

Iv(mcd) Min 50 50 100 50 80 Typ 100 100 180 100 150

Water Clear

Wayjun Technology Co.,Ltd

-2-

www.wayjun.com

SMD LED 3216 SMD LED

Model: LED-1206 Color: Red/Yellow/Green/Blue/White. Select the products you need. Make sure the product Model in your orders are what you want.

Part Number LED-1206RVC LED-1206YVC LED-1206GVC LED-1206BVC LED-1206WVC

Material GaAllnP GaAllnP InGan InGan InGan

Chip Emitted Color Red Yellow Green Blue White

D(nm) 620-635 580-595 500-535 460-475 -

Lens Type

Vf(V) Typ. 1.8 1.8 3.0 3.0 3.0 Max. 2.4 2.4 3.6 3.6 3.6

Iv(mcd) Min 100 100 130 80 130 Typ 200 200 260 160 300

Water Clear

3528 SMD LED

Model: LED-1210 Color: Red/Yellow/Green/Blue/White. Select the products you need. Make sure the product Model in your orders are what you want.

Part Number LED-1210RVC LED-1210YVC LED-1210GVC LED-1210BVC LED-1210WVC

Material GaAllnP GaAllnP InGan InGan InGan

Chip Emitted Color Red Yellow Green Blue White

D(nm) 620-635 580-595 500-535 460-475 -

Lens Type

Vf(V) Typ. 1.8 1.8 3.0 3.0 3.0 Max. 2.4 2.4 3.6 3.6 3.6

Iv(mcd) Min Max

Water Clear

200 500 300 500 400 2000 300 600 4000 7000

Wayjun Technology Co.,Ltd

-3-

www.wayjun.com

SMD LED 2018 Double Color / Full Color SMD LED

Model: LED-0805-CA Select the Part Number of the products you need. Make sure the product Model in your orders are what you want.

Part Number

Material GaAllnP GaAllnP GaAllnP InGan InGan

LED-0805RGC

LED-0805RGBC

Chip Emitted Color Red Green Red Green Blue

D(nm) 620-635 570-580 620-635 500-530 460-475

Lens Type

Vf(V) Typ. 1.8 1.8 1.8 3.0 3.0

Iv(mcd)

Max. Min Typ 2.4 2.4 2.4 3.6 3.6 100 80 100 150 80 120 100 120 180 120

Water Clear

3216 Double Color / Full Color SMD LED

Model: LED-1206-CA Select the Part Number of the products you need. Make sure the product Model in your orders are what you want.

Part Number

Material GaAllnP GaAllnP GaAllnP InGan InGan

LED-1206RGC

LED-1206RGBC

Chip Emitted Color Red Green Red Green Blue

D(nm) 620-635 570-580 620-635 500-530 460-475

-4-

Lens Type

Vf(V) Typ. 1.8 1.8 1.8 3.0 3.0

Iv(mcd)

Max. Min Typ 2.4 2.4 2.4 3.6 3.6 120 120 120 180 100 150 150 150 220 120

Water Clear

Wayjun Technology Co.,Ltd

www.wayjun.com

SMD LED 3528 Double Color / Full Color SMD LED

Model: LED-1210-CA Select the Part Number of the products you need. Make sure the product Model in your orders are what you want.

Part Number

Material GaAllnP GaAllnP GaAllnP InGan InGan

LED-1210RGC

LED-1210RGBC

Chip Emitted Color Red Green Red Green Blue

D(nm) 620-635 570-580 620-635 500-530 460-475

Lens Type

Vf(V) Typ. 1.8 1.8 1.8 3.0 3.0

Iv(mcd)

Max. Min Typ 2.4 2.4 2.4 3.6 3.6 150 150 150 260 130 300 300 300 350 200

Water Clear

2810 Side Light SMD LED

Model: LED-2810 Color: Red/Yellow/Green/Blue/White. Select the products you need. Make sure the product Model in your orders are what you want.

Part Number LED-2810RVC LED-2810YVC LED-2810GVC LED-2810BVC LED-2810WVC

Wayjun Technology Co.,Ltd

Material GaAllnP GaAllnP InGan InGan InGan

Chip Emitted Color Red Yellow Green Blue White

D(nm) 620-635 580-595 500-535 460-475 -5-

Lens Type

Vf(V) Typ. 1.8 1.8 3.0 3.0 3.0 Max. 2.4 2.4 3.6 3.6 3.6

Iv(mcd) Min Typ 100 100 200 80 200 150 150 260 120 300

Water Clear

www.wayjun.com

SMD LED 5050 SMD LED

Model: LED-5050 Color: Red/Yellow/Green/Blue/White. Select the products you need. Make sure the product Model in your orders are what you want.

Part Number LED-5050RVC LED-5050YVC LED-5050GVC LED-5050BVC LED-5050WVC

Material GaAllnP GaAllnP InGan InGan InGan

Chip Emitted Color Red Yellow Green Blue White

D(nm) 620-635 580-595 500-535 460-475 -

Lens Type

Vf(V) Typ. 1.8 1.8 3.0 3.0 3.0 Max. 2.4 2.4 3.6 3.6 3.6

Iv(mcd) Min 1200 1200 2500 1000 14000 Typ 3500 3500 5500 3500 20000

Water Clear

Wayjun Technology Co.,Ltd

-6-

www.wayjun.com
