Problem no 3:
Hysteretic Damping :
% Function to solve exact solution- hysteric%
function ydot=hyexact(t,y)
w= 20; % Excitation frequency
wn=6; % natural frequency
c=6;
ydot=[y(2);(wn^2*sin(w*t))-(c./w*y(2))-(wn*y(1))];
end
% Function to solve equivalent model- hysteric%
function ydot=equiv(t,y)
w= 20; % Excitation frequency
wn=6; % natural frequency
z=0.15;
ydot=[y(2);(wn^2*sin(w*t))-(z*y(2))-(wn*y(1))];
end
% Code to plot equivalent model- hysteric%
%Plotting of exact model%
syms x0 ts z
x0=[0.2 0.5];
ts=[0 20];
z=1;
[t,y]=ode45(@hyexact,ts,x0);
figure(1);
plot(t,y(:,1),'r');
grid on;
hold on;
%Plotting of equivalent model%
[t,y]=ode45(@equiv,ts,x0);
figure(1);
xlabel('time ');
ylabel('Displacement');
plot(t,y(:,1),'b');
xlim([0 10]);
ylim([-1 1.2]);
grid on;
hold off;
legend('Exact model','Equivalent model')

Structural Damping Case

% Function to solve exact solution- Structural damping %
function xdot=strucexact(t,y)
wn=6; % Excitation frequency
w=20; % natural frequency
c=6; % natural frequency
ydot=[x(2);(( wn^2.*(sin(w*t)))-wn^2.*y(1))-(c*abs(y(1)).*sign(y(2)))];
end

% Function to solve equivalent model- hysteric%

function ydot=equiv(t,y)
w= 20; % Excitation frequency
wn=6; % natural frequency
z=0.016; % equivalent damping ratio
ydot=[y(2);(wn^2*sin(w*t))-(2*z*wn*y(2))-(wn*y(1))];
end

%Plotting of exact model%

syms x0 ts z
x0=[0.2 0.5];
ts=[0 20];
z=1;
[t,y]=ode45(@strucexact,ts,x0);
figure(1);
plot(t,y(:,1),'r');
grid on;
hold on;

%Plotting of equivalent model%

[t,y]=ode45(@equiv,ts,x0);
figure(1);
xlabel('time ');
ylabel('Displacement');
plot(t,y(:,1),'b');
xlim([0 10]);
ylim([-1 1.2]);
grid on;
hold off;
legend('Exact model','Equivalent model')

Problem 7:
Code for the problem 7:
syms x y t T F
clear all
f1=10;
f2=11;
f3=9;
A1=10;
A2=4;
A3=4;
subplot(2,1,1);
t=linspace(1,4,1000)
y=(10+8*cos(2*pi*t-(pi/3))).*cos(20*pi*t);
plot(t,y);

xlabel('Time Axis \rightarrow');

ylabel('Amplitude \rightarrow');title('Plot of signal');
pause(2);
A=[A1 A2 A3];
% Amplitudes for one-sided spectrum
F=[f1 f2 f3];
% Frequencies for one-sided spectrum
b=[A A(end:-1:1)];
% Vector of amplitudes for two-sided spectrum
freq=[F -F(end:-1:1)];
% vector of frequencies for one-sided spectrum
Amp=b.^2/4;
% Amplitude
%% Plotting part
subplot(2,1,2);
stem(freq,Amp);
grid on;
xlabel('\itFrequency(Hz) \rightarrow');
ylabel('|Xsig(f)| \rightarrow');
