Bal Rotation

NetAct Optimizer 2.
2 CD2 for GSM

GSM Measurements for Optimizer
For public us e IPR applies

1
Noki a Si emens N etwor ks
Presentation / PLe / 20.4.2009
Nokia Siemens Networks

Academy
Legal notice
Intellectual Property Rights
All copyrights and intellectual property rights for Nokia Siemens Networks training
documentation, product documentation and slide presentation material, all of which are forthwith
known as Nokia Siemens Networks training material, are the exclusive property of Nokia
Siemens Networks. Nokia Siemens Networks owns the rights to copying, modification,
translation, adaptation or derivatives including any improvements or developments. Nokia
Siemens Networks has the sole right to copy, distribute, amend, modify, develop, license,
sublicense, sell, transfer and assign the Nokia Siemens Networks training material. Individuals
can use the Nokia Siemens Networks training material for their own personal self-development
only, those same individuals cannot subsequently pass on that same Intellectual Property to
others without the prior written agreement of Nokia Siemens Networks. The Nokia Siemens
Networks training material cannot be used outside of an agreed Nokia Siemens Networks
training session for development of groups without the prior written agreement of Nokia
Siemens Networks.

2
Presentation / PLe/ 20.4.2009
Data Flow Example

Measuring
PM database
BSC
DX2 0 0
P DE
MMR
every
480ms
CCMU
C
CCMU L
S
OMU
OMU
W
D
U
C
T
U
S TU
CHU
CM
S TU
CHU
CM
Optimizer
Radio Access
Configurator
Automatic
Automatic
Optimisation
Optimisation
Raw
data
Interference
matrix
Configuration
data
Algorithm
parameters
User input
New Plan

3
W
D
U
Module Objectives
At the end of this module the trainee should be able to:
Describe the measurements needed for Optimizer
Outline the measurement setup and collection process

4
Mobile Measurements
The measurements needed in Optimizer
How to manage BCCH Allocation List (BAL) changes?
CIP and ARP measurements if equal or less than 32

BCCH frequencies to be measured
CIP and ARP measurements if more than 32 BCCH

frequencies to be measured

5
The usage of mobile measurements in Optimizer

Mobile measurements are used in Optimizer
to generate Interference Matrix
to generate timing advance histogram
Interference matrix is used for
- automatic frequency optimisation
- automatic adjacency optimisation
Interference matrices are stored in Optimizer database and not
automatically cleaned.

6
Mobile Measurements in GSM

Defined Adjacent Cell (DAC) measurement collects data
from cells defined as adjacent cells
Channel Finder (CF) measurement collects data from nonadjacent cells
Traffic measurements are typically active by default
The cells that use the same BCCH channel as the serving
cell cannot be measured and are defined as Blind Spots

7
Mobile Measurement Report example

8
Mobile measurements
BSC
Def adj cell
measurements
MMR
Channel finder
measurements
OPT DB
PM DB
OPTDB_CIP
P_NBSC_CHANNEL_FINDER
OPTDB_ARP
P_NBSC_DEF_ADJ_CELL

9
Measurement Time
Minimum measurement period depends on the traffic but should
be at least 2-3 days
Less traffic => longer measurement period
More measurement rounds means longer measurement time
During the measurements and optimisation there must be
NO CHANGES to the NW

10
Preparations
During the measurements the BCCH Allocation Lists (BALs)
need to contain every BCCH frequency in the network
Maximum length (theoretical) of the BA list is 32
Common BCCH and WCDMA neighbors will reduce the
theoretical maximum BAL length by one each (down to 30)
If there are more than 32 (or 31, or 30) BCCH frequencies in
the network the measurements need to be run in several
cycles of equal length but with different BA lists

11
How to measure all BCCHs

10
20
25 neighbour cell BCCH frequencies

+ serving cell frequency
30
(max) 6 free
places
If the network has less than 32 BCCHs : create a double BAL

If the network has more than 32 BCCHs : rotate the BAL lists

12
How to get the measurements
Less than 32 BCCH

frequencies
More than 32 BCCH

frequencies
BSC older than S11

CD10
Double BAL
BAL rotation tool
BSC S11 CD10 or

newer
Double BAL for CIP, ARP BAL rotation tool for

CIP, ARP
MBAL for FEP
MBAL for FEP

13
Mobile Measurements



14
CIP and ARP measurements in short

Activate the feature Double BCCH
Allocation List in the BSC
This feature is by default active
Activate the measurement Channel

Finder
ZWOC,10,65,00FF;
Activate the measurement Defined

Adjacent Cell
ZWOA:2, 626,A;
Start the measurements Channel

Finder and Defined Adjacent Cell
Using Prepare GSM IM Creation

wizard
Retrieve the measurements from
Optimizer Tools Network

Statistics Manage Interference
Matrices
PM DB

15
Preparing Nokia GSM IM Creation for CIP and ARP (1/14)

Select BSCs from the Navigator

16

17

18

19

20

21

22

23

24

25

26

27

28

29
Mobile Measurements



30
CIP and ARP measurements in short

Activate the feature Double BCCH
Allocation List in the BSC
ZEQ
Activate the measurement Channel

Finder
ZWOC,10,65,00FF;
Activate the measurement Defined

Adjacent Cell
ZWOA:2, 626,A;
Start the measurements Channel

Finder and Defined Adjacent Cell
Using Prepare GSM IM Creation

wizard
Retrieve the measurements from
Optimizer Tools Network

Statistics Manage Interference
Matrices
PM DB

31
Using BAL Rotation (1/18)

Select BSCs from the Navigator

32

More than 32 BCCH frequencies to be measured

33

More than 32 BCCH frequencies to be measured

34

To measure more than 32 frequencies using CF and DAC
measurements BAL Rotation tool is needed
First you must remove old BAL objects if any exist.

35

36

Start the BAL Rotation tool to begin creating BALs

37

38
Settings are user specific

39
Settings are user specific

40

41

42

43

44

45

46

47

48
Using CM Operations Manager provision the backup plan that was created previously (in order to
bring back the original configuration in the network).

49
Exercise 1 (CIP, ARP)

1.
2.
3.
4.
5.
Check how many BCCHs are used in your optimization scope

Check the version (= release) of the BSCs in your optimization scope
Check if the needed features in the BSCs are activated
Use Optimizer wizard Prepare Nokia GSM IM Creation to set up and start the
measurements
In Optimizer, Retrieve the Interference matrix for your scope

50
Document change history

Date
20.4.2009
Version
Nam e
Change comment
1.0
PLe
First version for OPT 2.2 CD2
