    How To Read Simulation Code Forces

    In

    VHDL
    Practical Exam Guide

    force -freeze sim:/ram_128_8/clk 1 0, 0 {50 ns} -r 100


    force -freeze sim: Force Command ram_128_8 Program Name clk 1 0, 0 {50 ns} -r 100 Assign Clock with 100ns period to Signal clk

    Done By:
    View Signals Click on clk signal Edit Clock Ok

    force -freeze sim:/ram_128_8/wr 1 0


    force -freeze sim: Force Command ram_128_8 Program Name wr 1 0 Assign Value 1 to Signal wr with 0ns Delay

    Done By:
    View Signals Click on wr signal Edit Force Value = 1 , Delay = 0 Ok

    force -freeze sim:/ram_128_8/addr 0000000 100


    force -freeze sim: Force Command ram_128_8 Program Name addr 1 0 Assign Value 0000000 to Signal addr with 100ns Delay

    Done By:
    View Signals Click on addr signal Edit Force Value = 0000000 , Delay = 100 Ok

    force -freeze sim:/rom_128_8/addr 1111101 1400


    force -freeze sim: Force Command rom_128_8 Program Name addr 1111101 1400 Assign Value 1111101 to Signal addr with 1400ns Delay

    Done By:
    View Signals Click on addr signal Edit Force Value = 1111101 , Delay = 1400 Ok

    force -freeze sim:/tlc/start 1 300


    force -freeze sim: Force Command tlc Program Name start 1 300 Assign Value 1 to Signal start with 300ns Delay

    Done By:
    View Signals Click on start signal Edit Force Value = 1 , Delay = 300 Ok

    force -freeze sim:/suez/sensor_b 1 1600


    force -freeze sim: Force Command suez Program Name sensor_b 1 1600 Assign Value 1 to Signal sensor_b with 1600ns Delay

    Done By:
    View Signals Click on sensor_b signal Edit Force Value = 1 , Delay = 1600 Ok
