TURBOEXPANDERS
1 Atlas Copco Group Presentation 2013
Turboexpander Training
Innovative Solutions
Products
Services
Knowledge
Section V:
Turboexpander Start-up And Operations
Gas processing is not inherently dangerous, but more so than skydiving, it is unforgiving of mistakes!
7 Atlas Copco Group Presentation 2013
SAFETY
9 Atlas Copco Group Presentation 2013
10
12
Its a machine used to produce refrigeration and recover otherwise wasted energy...
Atlas Copco Group Presentation 2013
14
LPG Absorber
Cold Separator
16
17
18
19
1. Purge housings and related piping following plant protocol 2. Pressurize machine housings out to the related block valves using seal gas
20
218 psig
218 psig
218 psig
23 Atlas Copco Group Presentation 2013
Proceed to Start-up:
24
X X X X
Cold Separator
Blocked In
To Re-compressor
25
Blocked In
To Re-compressor
26
27
Use seal gas PDCV bypass to pressurize all housings and piping out to the block valves...
28
218 psig
218 psig
218 psig
30 Atlas Copco Group Presentation 2013
31
When compressor housing pressure equals compressor suction pressure, open that block valve...
33 Atlas Copco Group Presentation 2013
X O Blocked In
Cold Separator
To Re-compressor
34
When expander housing pressure equals expander discharge, open that block valve...
35
Blocked In
To Re-compressor
36
Close Seal Gas Regulator By-pass; confirm seal gas ALARM is cleared.
37 Atlas Copco Group Presentation 2013
38
Drain Housings...
39 Atlas Copco Group Presentation 2013
Compressor Drains...
40 Atlas Copco Group Presentation 2013
41
LPG Absorber
42
In coordination with Control Room Personnel, start Turboexpander by pressing START at expander control screen...
43 Atlas Copco Group Presentation 2013
44
Turboexpander/Compressor Operation
TRIP
45
As IGVs open, J.T. Valve will close. As J.T. closes, switch DCS IGV controller to Remote
46 Atlas Copco Group Presentation 2013
16,500 RPM
300 psig
-110 F
What is Surge?
48
50
51
Monitor: 1. Seal Gas Pressure Diff. 2. Lube oil Pressure Diff. 3. Vibration Levels 4. Bearing Temperatures
53 Atlas Copco Group Presentation 2013
Reliability / Maintenance
Condition monitoring requires: Knowledge of parameters to be monitored Appropriate redundancy Trending of acquired data Adequate spare parts Pre-planning for corrective actions
54
55
Turboexpander Training
