This document summarizes a paper that proposes a new method for designing observers for singular systems. The method is based on concepts of generalized inverses and does not presuppose an observer structure like Luenberger observer theory. It shows that under certain conditions, namely if the system is generalized observable and the matrix F is not the identity matrix, it is possible to directly design a minimal-order observer of dimension n-p, where n is the state dimension and p is the output dimension. The paper provides background on generalized inverses and observability of singular systems to develop this direct method of observer design.
This document summarizes a paper that proposes a new method for designing observers for singular systems. The method is based on concepts of generalized inverses and does not presuppose an observer structure like Luenberger observer theory. It shows that under certain conditions, namely if the system is generalized observable and the matrix F is not the identity matrix, it is possible to directly design a minimal-order observer of dimension n-p, where n is the state dimension and p is the output dimension. The paper provides background on generalized inverses and observability of singular systems to develop this direct method of observer design.
This document summarizes a paper that proposes a new method for designing observers for singular systems. The method is based on concepts of generalized inverses and does not presuppose an observer structure like Luenberger observer theory. It shows that under certain conditions, namely if the system is generalized observable and the matrix F is not the identity matrix, it is possible to directly design a minimal-order observer of dimension n-p, where n is the state dimension and p is the output dimension. The paper provides background on generalized inverses and observability of singular systems to develop this direct method of observer design.
SINGULAR SYSTEMS R. L. Carroll Dept. of Electrical and Computer Engineering Northeastern University Boston, MA 02115 ABSTRACT This paper considers the design of observer for generalized state space systems. The design ap- nroach is based on the concepts of the MIoore- Penrose matrix generalized inverse and the Drazin inverse. In contrast to the Luenberger observer theory, a new method is proposed which does not oresuppose the observer structure. A further dis- cussion on alternative design approaches is pro- vided and it is shown that under certain conditions a direct method for the design of full and minimal- order observer is nossible. Illustrative examples are included. INTRODUCTION The state observer problem for regular system is solved completely by Luenberger [ Il [ 2] and [ 3] and since then a considerable amount of research has been devoted to both state and functional ob- server problems. Commonly, all the methods of de- riving observer equations presuppose the observer structure. Das and Goshal [ 4 ] derived the observer equations for the state observer problem without such assumption by utilizing the generalized matrix inverse. Based on alternative models for singular sys- tems we use the same concept and give condition under which an observer can be constructed for this general class of systems. Consider the linear, time-invariant, multi- variable singular svstem described in state-space as follows: M x( t) = A x( t) + B u( t) y( t) = C x( t) ( 1) ( 2) where ME:RnX n is a singular matrix, xR is the state vector, uE Rm is the input vector, ye Rp is the output vector, and without loss of generality it is assumed that the system is generalized state observalbe, generalized state controllable and the rank of matrix C is full. Singular systems have received considerable attention during recent years. We refer to the works of Verghese et al. [ 5] , Cobb [ 6 ] , [ 7 ] and[ 8 ] ,, Campbell et al. [ 9 ] , [ 10] and [ 11] , Luenberger[ 12] , [ 13] , Yip et al. [ 14 ] , Newcomb [ 151 and Saidahmed[ 16 ] . The present paper is the first attempt towards designing a reduced order observer of minimal di- mension n-p for such control systems. PRELIMINARIES In this section we give a brief overview of some Dertinent results which are essential in the Dept. of Electrical Engineering and Computer Science George Washington University Washington D. C. 20052 development to be presented in the next section. For a unified treatment of the matrix generalized inverses and the Drazin inverse, the interested readers should refer to Ben-Israel and Greville [ 17 ] , Lovass-Nagy et al. [ 18 ] and Campbell et al. [ 9 ] - [ 11] . Definition 1 If C is a pxn matrix and Cg is an nxp matrix satisfying CX C = C X CX = X Ca = ( a) ' X C = ( X C) ' then Cg is called the Moore-Penrose generalized matrix inverse of C. In most of the cases the first condition is sufficient to construct a generalized inverse for a given matrix C. In this case we refer to X as a ( l) -inverse of C and denote it byC( l) . If the first two equations hold, then X is said to be a ( 1,2) -inverse of C, etc. For notational simplicity let superscript g be used instead of ( 1) . Definition 2 If E is an nxn matrix of real or complex num- bers then the Drazin inverse of E, denoted by ED, is the unique solution of the following three equations EX = X E X EX = X Ek 1 X = Ek, where k - Ind ( E) the last equation may be replaced by Er+ X =E, r> n k Note that the index of E, Ind ( E) , is the smallest non-negative integer k such that rank ( Ek) = rank ( Ek+l) . Furthermore, it should be pointed out that the Drazin inverse of a square matrix always exists and is unique. D=-1 If E is nonsingular then Ind( E) = 0 and E while if E is nilpotent of Index k ( Ek=O) then D E = 0. Solvability A singular system given by ( 1) , ( 2) is solv- able if and only if ( A+ X M) 1 exists for some X EcC. Theorem 1 Let the singular system ( 1) , ( 2) be solvable, then there exists a set of alternative models for the system of the form x( t) = x( t) + B u( t) + Fx ( 3) y( t) = C x( t) ( 4 ) 207 7 B. Shaf ai Proof -1 Multiplying ( 1) from the left by ( A + AM) we obtain M i = A x + B u, where M = ( A+X M) " 1M, A = ( A +X M) A and B = ( A + AM) Y1B. Now RM can be written as N = I-F and ( 3) , ( 4 ) follows immediately with A = A, B = B. Q . E. D. Remark 1 There are other possibilities to construct ( 3) , ( 4 ) . One such possibility is to substitute for N in ( 1) , M = I-F, and then ( 3) , ( 4 ) follows with A = A, = B. There is still another possibility which was proposed by Saidahmed ( 19 8 3) and the matrices A B, F are specified as i = ( i 1K -F) , =l ( Rj D_ F -I -D D. B - ( iiD-Fi) B and F = ( I_ MRD) ( I-MA ) We close this section by a brief discussion of the concept of generalized observability of the system ( 1) , ( 2) . Several attempts have already been made in this direction. One could consider the references cited in section 1. Perhaps the simplest and most intuitively appealing possibility for defining generalized observability ( controlla- bility) has been introduced by Cobb [ 19 ] and it is our intent to follow his results. Theorem 2 The singular system ( 1) , ( 2) is generalized observable if and only if K er M n K er C = O ( 5) K er ( A+X M) nK erC =0 for every AEC ( 6 ) Theorem 3 The singular system ( 1) , ( 2) is generalized observable if and only if the alternative model ( 3) , ( 4 ) is generalized observable. Proof If ( 1) , ( 2) is generalized observable then K er M n K er C = K er ( A+X M) -lM nK erC=K erflnK erC =0 and K er ( A+X M) nrK erC = K er[ ( A+X oM) -l( A+X M) ] rK erC = K er ( A+X M) nK erC =0, which implies that ( 3) ,( 4 ) is generalized observable. A similar argu- ment can be used to show that the converse is also true. Q . E. D. DEVELOPMENT OF TH E METH OD The design method which will follow is appli- cable to any alternative model of ( 1) , ( 2) repre- sented in the form ( 3) , ( 4 ) . Now the general solution of equation ( 4 ) is obtained as x( t) = C5 y( t) + ( I - CgC) v( t) ( 7 ) where v( t) is an arbitrary vector having the same dimension as x( t) . For simplicity choose a matrix L E RnX ( n-P) of full rank such that { L} = { I-CC} , where { X } denotes a linear space spanned by the columns of X . Then L Lg = I - C5 C ( 8 ) and ( 7 ) reduces to x( t) = C# y( t) + L h( t) where h( t) = Lg v( t) ( 10) and x( t) is unique for a given y( t) and for a cho- sen L, provided that h( t) is unique. For notational simplicity we drop the indepen- dent variable t in the following discussion. By substituting ( 9 ) into ( 3) we get Cy+ Lh = Ax + Bu + F C + FL; ( 11) Premultiplying ( 11) once by Lg alone, another time by C alone and considering the relations ( 8 ) and ( 9 ) along with CL=0, CC =I, L9 C9 =O, L? L=1 we obtain ( I-LgFL) = LgX h + LgACgy + LgB^ u + LgFCg ( 12) y = CAL h + CACU y + CBu + CFCgy + CFL ( 13) Lemma 1 rxr For any matrix S C R ,the matrix I-S is sin- gular if and only if X i[ S] = 1 for some i= 1,2,. . . . r. In the above lemma the matrix S plays the role of matrix L& TL in ( 12) . Theorem 4 If the singular system ( 1) , ( 2) represented by the alternative model ( 3) , ( 4 ) is generalized ob- servable with FeCRnxn, F # I and C C Rpxn then there exists a matrix Le Rnxr with CL=Q and a matrix Lg with LgL= I such that ( i) B* [ lOF L] # 1 for all i = 1,2,. . . ,r ( ii) I-L9 F L nonsingular where r= n-p. Proof Consider C: Rn + RP and the obvious relation dim ( K er C) + dim ( Im C) = n. Then it is clear that Im C = Rp which implies that dim ( ImC) = p and dim ( K er C) =n-p. Now, let { v1,. . . ,v np} be a set of linearly independent vectors of K er C. Then from K er MnK er C = 0, where M: R , follows that the set of n-p vectors X i = M( v) : i= 1,. . . ,n-p are linearly independent. Next, define WA span { v1,. . vn-p} and W span { vi,. . . ,n- } to be subspaces of Rn with equal dimension n-p. It is not difficult to show that there exist WCRn 3 Wew = Wc3;f = R. Let us construct L and Lg as follows: Pick { el,. . . en p} linearly independent vectors in Rn-P Then n-pAg L: Rn-P Rn is defined by L( ei) v iand L Rn +Rn P is defined by Lg( vi) = ei and L9 iv ) =O where vi's span the subspace W, j =l,. . . ,p. Note CL=0 and LgL= I. Finally, Cg can be obtained from CCg=I and L9 C9 =O. Now we show that I-L9 FL= LgML is invertible. The invertibility of LgM is equivalent to saying that LgMLx # 0 for all nonzero vector x n P Let x = laciei. ai not all zero. Then. LgfLx = LgML ( hiei) = LH M( Z aiLei) = LgM( J aiV) =L ( ivi ' i are linearly independent vectors in i and thus aivi is also a nonzero vector in > . Since from construction ker Lg = W and W n f -O it follows that Lg( yatSi) AO, which proves the conj ecture ( ii) . The conj ecture ( i) follows directly from Thma 1. Q . E. ED. Let us go back to equations ( 12) , ( 13) . Ob- viously F # I, otherwise ( 3) reduces to an algebraic equation. Then, as long as I- FL is inevitable, X can be solved from ( 12) and by sub- stituting in ( 13) we obtain h=F 1LgLA Lh +F -L AC + ti + F -LgFC9 ; ( 14 ) 207 8 and h is uniquely obtainable ( see the comment fol- lowing ( 10) ) , where F=I - Lg FL ( 16 ) L = I + FLFl Lg ( 17 ) w = [ I - C L FC ] y - CL AC y - C L B u ( 18 ) The derivative of v in equation ( 14 ) can be elimi- nated by defining a new variable as h = h- Ry ( 19 ) with _ F- L Fg ( 20) Upon substituting h from ( 19 ) into ( 14 ) , ( 15) we obtain two new sets of equations as h=FlLg ALh +( F-lE? kCg+ F-1LgLR) y -F-1I,g% 9 21) +F L Bu ( 21) - _ ru - w = CLALh ( 22) where w = - ( CLAC + CLALR) y - CLtu ( 23) with S = I - CL F Cg ( 24 ) The equations ( 21) , ( 22) can be interpreted as a dynamical system where h is the state vector and w represents the output vector. The input vector can be identified from ( 21) . An observer of dimension r= n- p can be writ- ten for the above system as h-= ( F LAL - K CL AL) h + K w + AC + F1 LgALR) y + F 1L Bu ( 25) where K is a gain matrix, yet to be determined. The derivative of y is present in the above expres- sion for w. H owever, this difficulty can easily be avoided by introducing a new variable z as z =h-K Sy ( 26 ) After some straightforward manipulations the final observer equation is given by z Fz + Gy + H u ( 27 ) where F =IF1 g L C F =- F L AL- K CTLIL ( 28 ) G = F LA ( C + LK S) - K CLA ( C +LK S) + ( F L K CL) ALR ( 2 H = F-1L B-K C LB ( 3C Then using ( 9 ) , ( 19 ) and ( 26 ) the estimated state is given by x = Mz + Ny ( 31 where M = L ( 32 N = Cg + L( R + K S) ( 3 We summarize the preceding results as a theorem. Theorem 5 Let a singular system, described by ( 1) , ( 2) or correspondingly ( 3) , ( 4 ) be generalized state observable, controllable and solvable, then an ob- server defined by ( 27 ) - ( 33) , with any desired eignevalues can be constructed for the system iff the pair ( F 1Lg AuL, CLIL) is observable. It is easy to show that once the above pair is observable, then any standard pole placement tech- nique suffices to determine a stable F and the ob- server is completely specified. It is also inter- esting to note that if the pair ( W, C) is observable in the usual sense, then the pair ( Lg iL) , CiIl) is also observable. Now, if in addition the system is generalized observable, then we might expect that ( F CL L) consitutes an observable pair. But this point must be investigated more carefully. Remark 2 It should be pointed out that if the system is regular, then F= 0, which implies that F=I, L=I, R= 0, S = I and the observer reduces to the one de- rived by Das and Goshal [ 4 ] 7 . FURTH ER DISCUSSIONS AND DESIGN TECH NIQ UES In this paper, the minimal dimension of the observer for singular systems is defined in the sense of Luenberger observer theory, as for regular systems. It is understood that the minimal order of observer for singular systems depends highly on the structure of the given system. To clarify this point, consider the system ( 1) , ( 2) with p[ M] = r'< n -p, then by decomposing the system into a dynamical system of order r' and an algebraic equa- tion of order n- r', it is Dossible, under certain circumstances, to construct observer of order r'. Sometimes, it is even possible to design observer of order less than r' ( see example 3) . The following discussion is devoted to the design of observer for a special case of the model ( 3) , ( 4 ) . It can be shown that if certain con- ditions on model structure are satisfied then a parallel procedure, as the one given by Luenberger for regular systems, is possible for singular systems. Theorem 6 Consider the singular sytem of the form ( 3) , ( 4 ) and let ( A, C) be observable, then a full- and a reduced- order observer in the sense of Luenberger can be designed for the system if F can be factor- ized as F = FC ( 34 ) Proof 9 ) Full-order observer: In this case ( 34 ) is substi- tuted for F in the equation ( 3) as 0) x+Ax + Bu +iCx ( 35) Now, taking the derivative of the output equation ( 4 ) and substituting in ( 35) yields 1) X = X X + Wu +} ( 36 ) A full- order observer can ge given for ( 36 ) as x= L - LC) xi + Ly + wu + i'9 ( 37 ) 3) y can be eliminated by defining a new variable as z = x - Fy ( 38 ) Then ( 37 ) reduces to z= ( A-LC) z+[ ( A-LC) F+ L] y+Bu ( 39 ) Any standard pole placement technique can be used to obtain an L which makes - L C stable with arbitrary eigenvalues. Reduced-order Observer: In this case ( 36 ) and ( 4 ) are assumed to be in the form; 207 9 x = Ax + Bc uc ( 4 0) y = [ I O] x [ ( 4 1) where Bc = [ ? ] , u = YI The partitioned equations yield 2 =A22 x2 + X 21Y + BC2 uc ( 4 3) 12 X 2 ( 4 4 ) where . wy-A y -Bc u 11 Y cl uc ( 4 5) an observer can be constructed for ( 4 3) , ( 4 4 ) by inspection as K 2= 2( 2 - L 12 ) 2 +LW+A21y+ c2u+B22y ( 4 6 ) The derivative of y is present in ( 4 6 ) . This can be avoided by defining a new variable as z = x2 - [ L ( I - Wc12) + Wc22] Y ( 4 7 ) and the final observer is given by Z = a22 LA12) z [ ( k22 LA12) cx LAll 21] Y + ( Bc2- LB cl) u ( 4 8 ) Any standard pole placement techn4 que can be used to obtain an L which makes 22-LA12 stable. Therefore, the observer design is completed. Q . E. D. Remark 3 Although condition ( 34 ) is quite restrictive, sometimes it is possible to construct an alterna- tive model such that this factorization is possible. EX AMPLES Example 1 Consider the following single-outout singular system V1 J ] -1 -1 +[ j y = 2] x Since ( A + X M) 1 exists for all choices of X I the system is solvable. Obviously, the system is also generalized observable and an observer can be constructed. Let X 0= and premultinly the state equation of the svstem by A1, we get Mx = Ax + bu where Mi is niloot possible cI F = see proof c M = , AX =I, b =[ ] L-1 O, -l tent, thus ii=O and AD= I. Next, one loice for ( 3) , ( 4 ) is obtained as 2 3 ) , I = -F, b = [ : ) f theorem 1 and remark 1. Now we construct an observer of minimal-order with the specified eigenvalue-2. Following the construction procedure outlined in the proof of theorem 4 , we choose the parameters as L L = [ 1 ] , L :1 From ( 16 ) , F=2 and it is easy to check that the pair defined in theorem 5 is observable. A simple pole placement technique applied to ( 28 ) yields K = -5/ 4 The matrices L, R and S are obtained from ( 17 ) ,( 20) and ( 24 ) as '2 1 L= [ R- l/ 2, 5=0 l-3/ 2 -1/ 2 and the observer parameter can be determined from ( 28 ) -( 33) as F=-2, G = 1/ 4 , H =3/ 4 M = [ -2 1] , N =[ 0 1/ 2] Note that if we choose Cg = [ -3 2] then S=-2 and a different set of parameters could be obtained. Example 2 Consider the following multi-output singular system -1 0 -2- . -0 -1 -2- 1 -1 o 2 c = 27 22 17 x + 2 u L 2 3 2j [ -18 -14 -2 L 0J -1 -10 y= x O O 1' The solvability of the above system was investiga- ted by Campbell. Let the a ternative model f,r this example be defined by A- A, F=I- M and b= b. Then following the construction procedure outlined in the oroof of theorem 4 , one may choose the par- ameters L, Lg and C0 as [ O] I = [ l 0 o] , C =[ 1 O] It is also easy to obtain F, L, R and S from ( 16 ) , ( 17 ) , ( 20) and ( 24 ) as F=l , r=Fl 1 0 R 2] , S[ 3 6 -2 0 1j L. Now, let the observer eigenvalue be specified by -3. Then ( 28 ) trivially yields K = [ 1/ 3 1/ 3] and the remaining parameters can be evaluated from ( 28 ) - ( 33) as A A A F =-3. ,G = [ -7 -17 ] , H = 2/ 3 I =[ J - 208 0 Examle 3 Let a singular system be described by 0 0 0 1 1 1 0 01 0001 10-2 01 0 O O 1: O x= 0 0 -2 0 x + O u O O O 1 [ 00 2 -o 1 y [ O 0 0 1] x Obviously an observer of order 3 cannot be constructed for the above system by using the nor- mal procedure presented in section 3. H owever, it is clear that p[ M] = 2 and therefore an observer of order 2 may exist by decomposing the above system as as [ x4 j L2 -1 J x4 1 1J u X I =0 xl - 2x3 = 0 y = X 4 Considering the first and last equation, it is easy to construct an observer of order 2. Furthermore, since y= x , an observer of order 1 can also be constructed. The estimate of the states x1, x2 can be determined once X 3 is obtained. Example 4 Consider the singular system of example 1 with y = [ O 1] x. Note that by using the theorem 1 an equivalent model can be given by I1 -1] t2 -1 l] x [ t fx+ tu[ Y =[ 0 1] x an alternative and simpler equivalent model can also be given, by defining first M = I-F O O 'F= O 1_ and thus F 4 r Y = [ 0 l ] x For the first model the condition of theorem 6 is not satisfied. H owever, for the second model F can be factorized as in ( 34 ) with F=K [ o 1] , P=[ Now by applying the simple procedures given in theorem 6 a full- and a reduced- order observer can be constructed for the above singular system. CONCLUS ION A design method for constructing minimal or- der observer for singular systems has been proposed by using the concept of matrix generalized inverse. We showed that, if the given singular system is solvable and if a certain observability con- dition is satisfied, then a minimal-order observer can be constructed for such systems. For a special type of generalized state-space representation a full-order and a minimal-order ob- server are also provided. Although this paper accomplished a possible design approach, the problem of designing observers for singular systems is one that needs further in- vestigation. We hope that in the future new re- sults and other extensions can be achieved towards this goal. REFERENCES [ 1] D. G. Luenberger, " Observing the State of a Linear System," IEEE Trans. Mil. Electron, ME-8 , 19 6 4 , pp. 7 4 -8 0. [ 2) D. G. Luenberger, " Observers for Multivariable Systems," IEEE Trans. Automat. Contr. , AC-11, 19 6 6 , pp. 19 0-19 7 . [ 3] D. G. Luenberger, " An Introduction to Observers," IEEE Trans. Automat. Contr. , AC-16 , 19 7 1, pp. 59 6 -6 02. [ 4 ] G. Das and T. K . Goshal, " Reduced-Order Obser- ver Construction by GeneralizedMatrix TiverseV Int. J . Contr. , Vol. 33, 19 8 1, pp. 37 1-37 8 . [ 5] G. C. Verghese, B. C. Levy, and T. K ailatti, " A Generalized State Space for Singular Systems," IEEE Trans. Automat. Contr. , AC-26 ,19 8 1. [ 6 ] D. Cobb, " Description Variable and Generalized Singularly Perturbed Systems: A Geometric Approach, Ph. D. Dissertation, Dept. Electrical Eng. , Univ. Of Illinois, Urbana, 19 8 0. [ 7 ] D. Cobb, " Feedback and Pole Placement in Descriptor Variable Systems, Int. J . Contr. , Vol. AC-28 , 19 8 3. [ 8 ] D. Cobb, " Descriptor Variable Systems and Optimal State Regulation," IEEE Trans. Automat. , Contr. , Vol. AC-28 , 19 8 3. [ 9 1 S. L. Campbell, C. D. Meyer, and N. J . Rose, " Application of the Drazin Inverse to Linear Systems of Differential Equations," SIAM J . Appl. Matr. , Vol. 31, pp. 4 11-4 25, 19 7 6 . [ 10] S. L. Campbell and C. D. Meyer, Generalized Inverses of Linear Transformations, Pitman Publishing Co. , 19 7 9 . [ 11] S. L. Campbell, Singular Systems of Differen- tial Equations, Pitman Publishing Co. , 19 8 0. [ 12] D. G. Luenberger, " Dynamic Equations in De- scriptor Form," IEEE Trans. Automat. Contr. , AC-22, p. 312, 19 7 7 . [ 13] D. G. Luenberger, " Time-Invariance Descriptor Systems," IFAC J . Automatica, Vol. 14 , pp. 4 7 3-4 8 0, 19 7 8 [ 14 ] E. Yip and R. F. Sincovec, " Solvability, Con- trollability and Observability of Continuous Descriptor Systems, IEEE Trans. Automat. Contr. , AC-26 , 19 8 1 [ 15] R. W. Newcomb, " The Semistate Description of Non-Linear Time-Variable Circuits," IEEE Trans. Circuits and Systems, Vol CAS-28 , pp. 6 2-7 1, 19 8 1. 208 1 [ 16 ] M. T. Saidahmed, " Analysis of Generalized State-Space for Singular Systems," D. S. C. Dissertation, The George Washington Univ. [ 17 ] A. Ben-Israel and T. N. E. Greville, Generalized Inverses, Theory and Applica- tions, Wiley [ 18 ] V. Lovass-Nagy, R. J . Miller and D. G. Power, " An Introduction to the Application of the Simplest Matrix-Generalized Inverse in System Science," IEEE Trans. Circuits and Systems, CAS-25, p. 7 6 6 , 19 7 8 . [ 19 ] D. Cobb, " Controllability, Observability, and Duality in Singular Systems," IEEE Trans. Automat. Contr. AC-29 , p. 19 7 6 , 19 8 4 . 208 2
