Topic: Error Massages Iconos R 100 ( step by step ) (Read 3733 times)
- Watch HU display. The HU display should be increased. For getting a feeling, how kV and mAs influences the HU display,
look on this example:
Tube: OPTITOP
Max HU: 580 000 J (= 580 kWs)
Voltage: 125 kV
mAs 400 mAs
Energy of that exposure: 125kV x 0,4 As = 50kJ.
Amount %HU: 50kJ / 580 kJ = 8,6%.
As soon as either another organ program is selected, or SS is turned on or the Telephone button is pressed a second time,
the simulation is turned off.
Now it is possible to demonstrate the tube load calculator without stressing the tube.
Remark: It is not possible to reset the calculator. If it is one heated up no matter if by real exposures or by the simulation,
you must wait the amount of time that is
necessary to cool down the tube.
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
tplink11
Sr. Me m be r
P osts: 22
Logge d
This message is created, when during power on the XCU states that the time/date setting is obsolete. Another indicator is,
that in this case the date (to be checked by
calling the service SW and enter <System> <Realtime clock>) is set to 01-MAR-1999.
Reason
Battery on slot CPU = SX control unit (P/N 58 95 292 only, not CPU-HD unit) is empty, not completely inserted or missing.
Action
Remove cover of XCU. Search for slot CPU, which is located on the fourth (the utmost right) slot. Look for Battery which is
a inches by 1 inch integrated circuit having
four pins. The print on the cover shows <TIMEKEEPER> and <LITHIUM BATTERY>. It is located between the four red LEDs
and the plug from the power supply, having
lots of coloured wires.
- Is a battery inserted? --> if not, look for it in the housing of the XCU. If found, insert it. The marking (white dot on
cover of battery, located on the lower left, should point
in direction of HDD/Floppy cabling) and the battery is placed over an IC on the slot CPU.
if not found order a new one. (Battery type: M4T32-BR12SH1 from ST Microelectronics (www.st.com)).
The only restriction without battery is, that the time/date is wrong. All other functions should work properly.
-
remove battery
- check for PINs. Are all PINs OK or is one or more broken or bended?
- is voltage OK? The voltage should be measured between the PINs separated with a small black nose. Nominal voltage is
2.8 V, voltage of a new battery is app. 3.4 V.
Replace battery is voltage is below 2.0V, malfunctions (invalid date and time settings) apply below 1.0V.
XCU (AP-ID 240) error # 037
XCU - ARCNET TASK
---This message is equivalent to the display <74> on D320/D200 of XCU --Remote Login via Modem.
This message is only an indicator that someone has logged into XCU via a Modem. The status is detected by the D320 and
is logged even if an unsuitable Service SW is
used.
XCU - POWER ON
This message is always created when the High End XCU is turned on in order to find out, whether specific errors have been
occured once or many times before the system
has been turned off. The Power on message is created when all components are alive and the system is ready (first system
selection button on the control console lights
up) or if the system does not get ready in between this time-out - after 120 seconds. Any time an imaging system (RADIS
or FL TOP or FL Comp [with the exception of FL
H, which is fast enough]) is in the current site, the 120 sec timeout will hit.
the 43 (= 31 on display).
Missing terminal resistor or double terminal resistor
Any missing or double fitter termination resistior (120 Ohm) will cause an intermitting problem of error 43 (= 31 on D320). In
most cases the system will run. And
sometimes not. Check resistors carefully.
SX generator control consol is set to DUEP
The SX-desk may also be used in Polydoros SX 50 (RAS generator). If the switch setting is wrong, the 43 may be a followup error
Jumper X5 in Videomed SX D16 is in position END and termination resistor at XCS.X22 of Videomed SX is fitted
Unsuitable ARCNET chip
Check all listed High-Level-ARCNET-Controller (D100 in FL Comp, D100 in Optix, D16 in Vid SX, D320 in XCU, D200 in XCU,
D350 in FL TOP, D100 in FL H, D7
Sireskop SX und D100 in XCU of Iconos R200 and FD thorax/multix) that there is the correct ARCNET Chip Com20020 Typ
B. If Rev C is found replace immediately
the board
Com 20020 Rev C
Type C is a revision of Com 20020, that has been manufactured for 3 months until an error in the circuitry was reported by
the customer. The manufacturer SMC decided
to clear all stocks from Rev C and replace Rev B and the defective "no longer exisiting" Rev C by a Rev D. Rev D is not
released by MED. Although all stocks should
have been cleared from REV C, some distributors sold their samples as Rev B.
Identification of a Rev C Com20020
Rev C may be identified on the Chip manufactured by SMC, by a "C" in front of the lot-number. First line on the chip is
"SMC", second line is "Com 20020", third line is
"C" followed by a number identifying date code and lot number for instance "129020". Rev B will read in the third line "B" +
number - OR - number + "B" + number.
Examples: (the red one ist not OK!)
SMC
Com20020
C129020
SMC
SMC
Com20020 Com20020
B234190
3B24907
---This error is equivalent to the display <32> on D320/D200 of XCU --Duplicate node - ID
Two ARCNET partner do have the same physical board adress. This may be caused by jumper setting. Which Partner has
the wrong ID can be checked by the tool
usrshell.exe on this SSW.
XCU (AP-ID 240) error # 045
XCU - ARCNET TASK
---This error is equivalent to the display <33> on D320/D200 of XCU --Repeating transimission - parity error
An ARCNET package could not be sent in between the timeout given by the host program and has to be repeated. This
error can be ignored. It only indicates that the
transmission took more time, than estimated by the developper of the program. If the error occurs very often in a row it
might indicate, that the controller is too busy.
XCU (AP-ID 240) error # 046
ENTER REMOTE SERVICE MODE
This message is always created when the service PC logs in the XCU via Modem. So you may find out, if specific errors
occur only in service mode. No error, for
information only.
XCU (AP-ID 240) error # 047
TERMINATE REMOTE SERVICE MODE
This message is always created when the service PC logs OUT after a REMOTE session. So you may find out, if specific
errors occur only in service mode. No error, for
information only.
XCU (AP-ID 240) error # 050
XCU - FD-TASK
Internal SW problem: Systemcall returned illegal value, see error 000
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
XCU - FD-TASK
Internal SW problem: unable to delete alarm time
XCU (AP-ID 240) error # 060
XCU - FD-TASK
Internal SW problem: unable to delete alarm time
XCU (AP-ID 240) error # 070
XCU - FD-TASK
Acquisitions are blocked, because start up offset running. If the user tries to make an exposure during the offset
calibration this error is created and the exposure is denied.
XCU (AP-ID 240) error # 071
XCU - FD-TASK
Acq blocked, FD in transparent mode
Expsoure and calibration are locked, because the FD is in transparent mode. The transparent mode is a service setting,
where the detector can directly talk to RADIS and
bypasses the XCU.
XCU (AP-ID 240) error # 072
XCU - FD-TASK
File cannot be deleted. No further consequences.
Causes:
- disk of XCU defective --> replace XCU
- disk of XCU is cross-linked because power fail signal (D320/X1) is not working (see error 039) properly and disk is turned
off during write. You may insert a VGA
graphic card into XCU and try to perform per bootable floppy a DOS scandisk to repair. Also you should check the operation
of the power fail
- disk is full, which might be caused by starting a telegram trace via service PC, that has become too large, so that the
disk is full. Start another trace and terminate it
immediately, so that the new trace file is shorter.
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
User is gambling with the exposure release switch ---> stop him from doing that
Switch or cabeling of swich is defective ---> replace X-ray release switch
Logge d
tplink11
Sr. Me m be r
P osts: 22
If the user selects on the generator desk or on the Optix an organ program, which is empty in the FL H memory, this is
error is logged. If the service PC is connected to
XCU, it also will be displayed on the desk.
Reason:
The Fluorospot H cannot send exposure data, because there are no data programed.
Action:
2.Select the organ program, Press PAT DIR on FL H, F5 for tools, F1 for Organ Program, enter the specific data in the FL H
and store the program using F2.
2. Deinstall the after flash option in Configure Site Structure: In component selection click the Videomed DI, then click
OPTION and configure NO for the after flash
XCU (AP-ID 240) error # 106
XCU - BV-FS / VIDEO CONTROL TASK:
Internal SW problem: unable to create alarm time
XCU (AP-ID 240) error # 107
XCU - BV-FS / VIDEO CONTROL TASK:
Internal SW problem: unable to delete alarm time
XCU (AP-ID 240) error # 110
XCU - BV-FS / VIDEO CONTROL TASK:
Illegal Configuration. The Configuration of meas. fileds, TV Parameter oder LTI moder are inconsistent. This error is caused
for instance, if the configuration excludes image
freq. 7.5 i/s for pulse fluoro and FL TOP selects the frequency via Organ program.
XCU (AP-ID 240) error # 120
XCU - BV-FS / VIDEO CONTROL TASK:
Videomed does not confirm image flip command
The user has pressed the button for image flip and the camera does not confirm that it did flip the image. The error is
cleared automatically, if the error condition is
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
cleared.
Reason:
Software or timing error in the camera.
Action:
Check SW version of camera and the corresponding XCS-Interface
XCU (AP-ID 240) error # 121
XCU - BV-FS / VIDEO CONTROL TASK:
No confirmation of image flip command in between on second. (If the confirmation is received afterwards, the error is
deleted automatically.)
XCU (AP-ID 240) error # 122
XCU - BV-FS / VIDEO CONTROL TASK:
Horizontal image flip in progress. (If the confirmation is received , the error is deleted automatically.
XCU (AP-ID 240) error # 123
XCU - BV-FS / VIDEO CONTROL TASK:
Videomed does not confirm horizontal image flip command
The user has pressed the button for image flip and the camera does not confirm that it did flip the image.
Reason:
Software or timing error in the camera.
Action:
Check SW version of camera and the corresponding XCS-Interface
XCU (AP-ID 240) error # 124
XCU - BV-FS / VIDEO CONTROL TASK:
Videomed DI or DIC does not confirm AVR command
The generator has reached the maximum voltage output and wants the camera to take over the AVR. However the camera
does not reply. The error will interrupt fluoro.
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
As soon as the error has been confirmed by the user, fluoro is possible but only with 110 kV. The system must be switched
off and on to restore fluoro funtionality.
Reason:
Software or timing error in the camera.
Action:
Check SW version of camera and the corresponding XCS-Interface
Cycle power of system.
XCU (AP-ID 240) error # 150
XCU - GERTEGEOMETRIE/TABLE CONTROL TASK:
Internal SW problem: Systemcall returned illegal value, see error 000
XCU (AP-ID 240) error # 151
XCU - GERTEGEOMETRIE/TABLE CONTROL TASK:
Internal SW problem: error during initialize Task
XCU (AP-ID 240) error # 152
XCU - GERTEGEOMETRIE/TABLE CONTROL TASK:
Internal SW problem: error during receiving telegram. See error 002
XCU (AP-ID 240) error # 153
XCU - GERTEGEOMETRIE/TABLE CONTROL TASK:
Internal SW problem: error during sending telegram. See error 003
XCU (AP-ID 240) error # 154
XCU - GERTEGEOMETRIE/TABLE CONTROL TASK:
No function available for telegram received, see error 004
Logge d
tplink11
Sr. Me m be r
P osts: 22
Acquistion blocked due to limit. The Limit (exposure has been terminated by generator due exceeding value for max ms or
max mAs) condition is on and MUST be
confirmed by the user BEFORE continuing with an exposure.
XCU (AP-ID 240) error # 273
XCU - GENERATOR CONTROL TASK:
X-ray blocked
XCU (AP-ID 240) error # 274
XCU - GENERATOR CONTROL TASK:
Preparation of X-ray not possible
XCU (AP-ID 240) error # 275
XCU - GENERATOR CONTROL TASK:
Active tube is not the selected tube. Generator selects another tube than the desired one. Acq are disabled now.
XCU (AP-ID 240) error # 276
XCU - GENERATOR CONTROL TASK:
Internal SW problem with finding values in a table of the tube. When transforming normal value to BP there is the need of
tables. If a value outside a table has to be found,
this error is created. In most cases it is harmless and may be ignored.
XCU (AP-ID 240) error # 277
XCU - GENERATOR CONTROL TASK:
Internals SW error: wrong value in constant
XCU (AP-ID 240) error # 278
XCU - GENERATOR CONTROL TASK:
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
Internal SW error: exp. value (BP) < 0. May be ignored. No further consequences.
XCU (AP-ID 240) error # 279
XCU - GENERATOR CONTROL TASK:
Internal SW error: water equivale t value in BP is below 0. Probably the water equivalent calibtration has not been done
carefully.
XCU (AP-ID 240) error # 280
XCU - GENERATOR CONTROL TASK:
Internal SW error: water equivalent value in BP is above Maximum. Probably the water equivalent calibtration has not been
done carefully.
XCU (AP-ID 240) error # 281
XCU - GENERATOR CONTROL TASK:
No grid correction value for selected grid. This error is caused by a wrong configuration. Somebody removed the grids in
the site structure dialog but the grid is still in the
system. As soon as it selected by organ program or manually this error is created. The error is internally ignored and the
XCU assumes no grid.
The error is only a problem if the fluoro is done without and the exposure is done with grid. You may solve the problem in
the site structure by clicking on the stand (Polystar,
Iconos, Sireskop, Siregraph ...) and click edit and set the grid to <available>.
XCU (AP-ID 240) error # 282
XCU - GENERATOR CONTROL TASK:
No filter correction value for selected filter. This error is caused by a wrong configuration. Somebody removed the filters in
the site structure dialog but the filters are still in
the system. As soon as it is selected by organ program or manually this error is created. The error is internally ignored and
the XCU assumes no filter. You may solve the
problem in the site structure by clicking on the stand (polystar, siregraph, sireskop, iconos) and set the filters to
<available>.
XCU (AP-ID 240) error # 283
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
Logge d
tplink11
Sr. Me m be r
P osts: 22
IQAP or IMAC, if a system selection is done while IQAP is active and IQAP saves an OGP for DR although DR tomo is now
active.
XCU (AP-ID 240) error # 383
XCU - ORGAN PROGRAM SELECTION CONTROL TASK:
Organ programming is disabled because the system has been configured or a restore has been performed and since the
configuration the XCU has not been booted.
Boot the XCU by cycling power. OGP programming will then be allowed.
The reason for that behavior is, that the configuration is storing a new OGP structure to disk and the copy of the disk in
the RAM of the XCU is no longer a real copy. If
someone now store OGP Nr. 7 this OGP might be on location 5 on disk. And what would happen is, that the XCU places the
data for OGP 7 on the space of OGP 5 on
the disk. Because Nr. 5 can also be in another system (e.g. Cassette tomo instead of the DR standard) the consequences
would be fatal. Therefore storing OGP is not
allowed, if configuration has been made through.
Because IRIS adjust, IQAP and IMAC of FL TOP are doing also an OGP store, IQAP and IMAC are not possible, as soon as
the configuration has been entered.
If the XCU powers on, the OGP on disk are completely copied to the RAM and everything is fine again.
Logge d
tplink11
Sr. Me m be r
P osts: 22
Illegal configuration
XCU (AP-ID 240) error # 420
XCU - EXPOSURE TASK:
Acquisition not possible because a component is not ready: The system is not ready for exposure because one or more
components are no longer ready. This error is also
caused, if a spotfilm device is parked or a 3D stand is not in park position.
XCU (AP-ID 240) error # 421
XCU - EXPOSURE TASK:
Acquisition is prohibited by generator
May be caused by:
- a tube selection is in progress (up to 8 sec after a system selection) --> wait
- door contact is open (door is not closed) --> close door or shorten contact if no door is present
- generator is in service mode and an acquisition should be released at the console ---> leave service mode on service
PC)
- generator is in limit function (acquistion has been terminated due to exceeding max time or max mAs) ---> confirm limit
on console
- X-ray disable switch is activated ---> close x-ray disable switch or if no disable switch is present, make sure that D160
and D320 in generator do match (both new or
both old) and that the X-ray disable input is set to enable X-ray
- <emergency power> contact is closed ---> wait until emergency power is replaced by regular power or if no emergency
power is available, make sure that D160 and
D320 in generator do match (both new or both old) and that the emergency input is set to <enable X-ray>
- An error of the generator of the filament or of the iontomat (e.g. error 550of AP ID 80has been confirmed by the user
and the generator has reset filament or
iontomat which lasts up to 10 seconds. If an acquistion is requested in between this time, this error is displayed.
- In case of LX, that may mean that simple DR has been selected by switching to organ program #1 in region 1 but there
was no preceeding fluoro before invoking the
exposure.
XCU (AP-ID 240) error # 422
XCU - EXPOSURE TASK:
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
The cassette is not completely inserted --> remove cassette (might also happen in DR)
Cassette has no more free images ---> insert new cassette
Cassette is not inserted --> insert new cassette
Cassette has been in stand during power up ---> remove and re-insert cassette
First three possible error causes should be cleared automatically after 1 - 2 seconds. Last cause will not cure.
XCU (AP-ID 240) error # 424
XCU - EXPOSURE TASK:
Acquisition blocked by invalid device / Stand position. The device for Peri or Tomo is not in the correct position or the user
did not perform fluoro before starting peri.
XCU (AP-ID 240) error # 425
same as 420
XCU (AP-ID 240) error # 426
same as 421
XCU (AP-ID 240) error # 427
same as 422
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
same as 421
XCU (AP-ID 240) error # 447
same as 422
XCU (AP-ID 240) error # 448
same as 423
XCU (AP-ID 240) error # 449
same as 424
XCU (AP-ID 240) error # 450
same as 421
XCU (AP-ID 240) error # 451
same as 422
XCU (AP-ID 240) error # 452
same as 423
XCU (AP-ID 240) error # 453
same as 424
XCU (AP-ID 240) error # 454
same as 421
XCU (AP-ID 240) error # 455
Use our professional PDF creation service at http://www.htm2pdf.co.uk!
same as 422
XCU (AP-ID 240) error # 456
same as 423
XCU (AP-ID 240) error # 457
same as 424
XCU (AP-ID 240) error # 458
same as 421
XCU (AP-ID 240) error # 459
same as 422
XCU (AP-ID 240) error # 460
same as 423
XCU (AP-ID 240) error # 461
same as 424
XCU (AP-ID 240) error # 462
XCU - EXPOSURE TASK:
Acquisition blocked by DFR
This may be caused by conditions:
-
no patient selected
no more memory available on DFR
storing of images in progress
deleting of images in progress
imaging system is in error condition
background job is being prepared
the last acquitition has been terminated only 1.5 seconds before (recovery time)
tplink11
Sr. Me m be r
P osts: 22
Logge d
To get rid of this problem: configure the specific program with pulsed fluoro in CONFIGURE of the XCS SSW
XCU (AP-ID 240) error # 510
XCU - FLUORO CONTROL TASK:
illegal configuration. invalid fluoro curves etc.
door is open
X-ray disable swich is on
tube switching is in progress after a system selection (takes about 8 sec for heating up the tube)
problems with its hardware
limit is not confirmed by the user
door is open
X-ray disable swich is on
tube switching is in progress (takes about 10 sec for heating ab the tube)
problems with its hardware
Limit has not been confirmed
Logge d
tplink11
Sr. Me m be r
P osts: 22
Causes:
- disk of XCU defective --> replace XCU
- disk of XCU is cross-linked because power fail signal (D320/X1) is not working (see error 039) properly and disk is turned
off during write. You may insert a VGA
graphic card into XCU and try to perform per bootable floppy a DOS scandisk to repair. Also you should check the operation
of the power fail
- disk is full, which might be caused by starting a telegram trace via service PC, that has become too large, so that the
disk is full. Start another trace and terminate it
immediately, so that the new trace file is shorter.
-
- disk is full, which might be caused by starting a telegram trace via service PC, that has become too large, so that the
disk is full. Start another trace and terminate it
immediately, so that the new trace file is shorter.
-
Causes:
- disk of XCU defective --> replace XCU
- disk of XCU is cross-linked because power fail signal (D320/X1) is not working (see error 039) properly and disk is turned
off during write. You may insert a VGA
graphic card into XCU and try to perform per bootable floppy a DOS scandisk to repair. Also you should check the operation
of the power fail
- disk is full, which might be caused by starting a telegram trace via service PC, that has become too large, so that the
disk is full. Start another trace and terminate it
immediately, so that the new trace file is shorter.
-
Causes:
- disk of XCU defective --> replace XCU
- disk of XCU is cross-linked because power fail signal (D320/X1) is not working (see error 039) properly and disk is turned
off during write. You may insert a VGA
graphic card into XCU and try to perform per bootable floppy a DOS scandisk to repair. Also you should check the operation
of the power fail
- disk is full, which might be caused by starting a telegram trace via service PC, that has become too large, so that the
disk is full. Start another trace and terminate it
immediately, so that the new trace file is shorter.
-
tplink11
Sr. Me m be r
Logge d
P osts: 22
tplink11
Sr. Me m be r
P osts: 22
Logge d
Internal SW problem: System call returned illegal value, see error 000
Logge d
tplink11
Sr. Me m be r
P osts: 22
Logge d
Pages: [1]
previous next
Jum p to:
go
