Lights//Camera//DJs

Sound Manual

Table of Contents
Equipment .1-14
Speaker Stand Setup.....15-18
Speaker Setup.19
Controller Setup.20-22
Microphone Setup..23-31
Mic Mixer Setup32-33

Equipment

Dark Knight Closed

Dark Knight Open

Whitey Closed

Whitey Open

Dark Knight Bag

Whitey Bag

S1 (Check top right corner for name)

SR (Check bottom middle for name)

SX (Check bottom middle for name)

Main microphone

Toast microphone

Airlift Speaker Stand

Telelock Speaker Stand

JBL PRX Front

JBL PRX Back

10

K12 Front

K12 Back

11

K10 Front

K10 Back

12

EV Front

EV Back

13

Subwoofer KW181 Front

14

Subwoofer KW181 Back

Locked Speaker Power Cord

15

Unlocked Speaker Power Cord

XLR (Female left, Male right)

16

Power Strip

Walkie Talkie

17

Speaker Stands Setup

To open the airlift speaker stands, twist the bottom knob displayed in the image below to
the left. When loosened enough, extend the legs by pushing down on them until reaching
a suitable width (ask DJ for confirmation that your width is good) and tighten the knob.

18

Once your speaker stands are placed correctly, pull the aluminum piece to the top by
pressing in on the side buttons and pulling up.

19

Place your speaker scrim onto the speaker stand and run your XLR and power cables
through the opening on the back. Attach two of the legs to the scrim leaving the third
open for you to have room to work with. Place your speaker onto the aluminum pole and
loosen the top knob (same way as bottom) to lift the speaker to the desired height. Once
the height is set correctly tighten the knob and attach the last leg of the speaker scrim.

20
For the TeleLock stands the only difference in setup will be how to open and close the
legs of the stands as well as raising the stands. Unlatch the gray curved bar to loosen the
legs then extend them to a suitable width and latch it to tighten the legs.

Turn the gray wheel to the raise section to raise the stand or lower section to lower the
stand and then turn it back to the lock position to lock the stand in place.

21

Speaker Setup
For the K12 and K10 speakers, plug the male XLR into Line A and plug the blue
locked power cord into the blue power slot on the back of the speaker.
For the EV speakers, plug the male XLR into input 1 (top input) and plug the
unlocked power cord into the power slot on the back of the speaker.
For the JBL PRX speakers, plug the male XLR into the only available input and
plug the unlocked power cord into the power slot on the back of the speaker.
The K12, K10, and EV speakers all have their power and XLR cords in their
respective cases. The JBL PRX speakers have their XLR and power cords in a bag with
multiple XLR and power cords.

IMPORTANT: Make sure all speaker gains are set to 0dB!

For the subwoofer KW181 take the XLR male to male cord and plug the XLR
male into Line A of the subwoofer and the male into the booth out section of the SX.

XLR Male to 1/4 Male

22

Controller Setup
SX:

Open the SX and pull the power cable (see image below) and plug it in.

23
Take the USB (located inside the controller case) and put it through the hole on the left
side (facing the SX as in the first image above).

Lastly, plug the other end of the XLR from the speaker into the back of the SX as shown
below.

24
SR:
Open the SR case and pull the USB tucked in the back through the left hole toward you.
Plugging in this USB to the laptop will power the SR. Pull the cables out as well and
leave them to the side. (Reference mic mixer on page 32 to see how to correctly
configure those.)

25

Microphone Setup
Main Microphone:
Pull the base out of the case and plug the XLR female into the back as well as the power
adapter. Be sure to loop the power adapter as seen below to prevent accidental
unplugging.

Plug the other end of the XLR (male) into the Mic 1 XLR input of the back of the SX.

26
Toast Microphone:
For the toast or backup microphone plug the male adapter into the Mic 2 input of
the SX and the XLR female into the base as seen above.

Main Microphone

27
To change the batteries on the main microphone, unscrew the bottom of the microphone
and lift the latch. Pull out the old batteries and replace with new batteries.

Unscrew bottom of microphone

Lift latch and remove old batteries

28

Open the third slot of the bookbag to find the battery packs and laptop power cord

Battery Packs

29

Toast Microphone

To change the batteries on the toast microphone, unscrew the bottom of the microphone
and remove the battery.

Unscrew the bottom to remove old batteries

30
Lapels:
For the lapels plug the power cord into the back of the receiver, plug the two
antennas into the back of the receiver, and plug the XLR female into the back of the
receiver with the male end into the mic mixer.

Lapel Receiver Back

If there is any interference you will need to change the frequencies by doing the
following:
On the receiver click the set button, then use the up/down arrows to find frequency
preset, change the 17-4 numbers to either lower or raise the frequency, then click set
again and finally navigate to the exit tab.

31

Click set

Scroll to frequency preset

Change channels to reduce or increase frequency

32

Click set to store the frequency

Navigate to exit

Next do the same thing on the lapel itself:

Turn on lapel and click set

33

Scroll to frequency preset

Make sure channel is set to the same as the receiver

Click set to save

34

Mic Mixer Setup

Mic Mixer

Plug the lapel microphones into XLR Lines 1 and 2, any handheld microphones into any
XLR Lines 3-8, and the controller into any Lines 9-12. Make sure when plugging in
the controller you set your gain fader to U (unity) as shown above in Line 11/12 and set
the main fader to -5dB as shown above.

35

Mic Mixer Back

Plug the power cord into the back of the mic mixer and use the two XLR outputs to plug
into the speakers.
