VOCATIONAL EDUCATION
REVITALISATION PROJECT-PHASE II
NATIONAL DIPLOMA IN
MECHANICAL ENGINEERING TECHNOLOGY
AUTOCAD 3
COURSE CODE: MEC 223
YEAR II- SEMESTER IV
THEORY/PRACTICAL
Version 1: December 2008
NATIONAL DIPLOMA IN
MECHANICAL ENGINEERING TECHNOLOGY
AUTOCAD 3
COURSE CODE: MEC 223
TABLE OF CO NTENT
COVER PAGE
WEEK 1
1.0
THREADS ON DRAWINGS
WEEK 2
1.1
1.2
Task 1
2.0
THREADS ON DRAWING II
WEEK 3
WEEK 4
WEEK 5
WEEK 6
2.1
3.0
3.1
3.2
3.3
3.4
3.5
Quiz 1
4.0
WORKING DRAWING
4.1
Introduction
4.2
4.3
Quiz 2
5.0
ASSEMBLY DRAWING
5.1
5.2
Task 2
6.0
DRAWING
6.1
Layout of Drawing
6.2
Part List
WEEK 7
WEEK 8
WEEK 9
WEEK 10
6.3
Dimensions
6.4
Task 3
7.0
ASSEMBLY DRAWING
7.1
8.0
ASSEMBLY DRAWING
8.1
9.0
ASSEMBLY DRAWING
9.1
WEEK 11
WEEK 12
WEEK 13
WEEK 14
WEEK 15
WEEK 1
1.0
Metric Fasteners made easier with AutoCAD, you have the access to unlimited numbers
of conventions and symbols for different types of industries. You can insert and edit the
convention symbols as much as you want to suite the drawing.
You can log to design center from "Design Center" Command available at standard
toolbar as shown below
.
Once you click the design center bottom a file search window like the one below will
open.
Try to double the scale before inserting the Hex Nut, remember that the Hex Nut will be
inserted as an object you can not modify it before you explode it's lines
Although the drawing will not be precise after scaling, however using design library will
save you time and effort (Fig. 1).
Fig. 1
1.1 Task 1
1- Using AutoCAD Design Center assemble the two plates shown in (Fig. 29) use
M20 for the Hex Nut & Bolt.
Fig. 1.1
2- Try to draw a 2D engineering drawing of your own and add to it as many standard
parts needed (use design center).
WEEK 2
2.0
2.0
Using AutoCAD design center assemble the two halves of coupling shown in (Fig. 2)
below, use M20 for the Hex Nut & bolt, also add suitable washers and spring washers. .
Fig. 2
WEEK 3
3.0
Different industries use different symbols and abbreviations in their drawings, this to
minimize time consumed in drawing and at the same time standardizes professional
dialog and communication.
3.1
Abbreviation
Across flats
AF
Assembly
Centers
Center line on a view in
a note
Cylinder or cylindrical
ASSY
CRS
C
CL
CYL
DIA
DIM.
DRG
Figure
FIG.
Long
Machine
LG
MC
Material
Maximum
MATL
MAX
Not to scale
NTS
Number
Radius (in a note)
NO.
RAD
R
STD
Table 3.1.1
Table 3.1.2
3.3
Table 3.1.3.
3.4
Table 3.1.4
3.5
Quiz Sheet 1
1- Select from the right table the correct names of the conventional representations
in the left table, the first row is given as an example.
2- Select from upper table the correct abbreviation and fill the lower table.
A
ACROSS
FLAT
RADIUS
SCRAPE
DIAMETER
(Preceding a
dimension)
CLEARENCE
SPHERICAL
LONG
DRAWING
ASSEMBLED
STATED
ACROSS FACES
RIGHT HAND
DIAMTER
(in a note)
STANDARD
ASSEMBLY
CHAMFER
PLACED
SPECIFICATIONS
PITCH
CIRCLE
DIAMETER
CENTER LINE
CHAMFERED
DRAWN
SCREWED
LIGHT GAUGE
Abbreviation
No.
1
2
3
4
5
6
7
8
Abbreviation
AF
ASSY
DIA
DRG
LG
R
RAD
WEEK 4
4.0
WORKING DRAWINGS
4.1
Introduction
A working drawing is the final constructed drawing produced in the design stage. After
that the drawing would be sent to the workshop floor for production. Thus, the drawing
should be precise and drawn to an appropriate scale and it usually includes a set of the
interrelated parts and details that are needed in production stage.
4.2
Working drawings can be divided into two main types, they are, Assembly drawings and
Detail drawings.
1) Assembly drawings
A complete assembly drawing is presentation of the product or structure put together,
showing all parts in their operational positions. The parts are logically connected
according to the designer specifications. (Fig. 4)
2) Detailed drawings
A detail drawing is used to magnify and focus on individual items in more details, this to
be helpful to the shop-floor personnel in producing each part precisely, and to be in
accordance with the designers requirements. (Fig.4.1)
5) Sub-Assembly
It is a drawing of a related group of parts and usually used to show the assembly of
complicated machinery for which it would be practically impossible to show all the
features on one drawing (Fig. 4.4)
4.3
QUIZ 2
..
..
..
2) Name the command that is available in CAD that allows you to see all the sides of
the component easily?
3) What is the main feature of an exploded drawing?
WEEK 5
5.0
ASSEMBLY DRAWINGS
5.1
To be able to draw a complete assembly drawing Fig. (5) you should follow carefully the
below steps:
1- Study the application of the machine or structure
2- Try to match the dimensions and understand the relationship between parts
3- Study carefully the assembly guide given to identify the relationship between
parts, in case no assembly guide is given try to draw one to help you in your
assembly.
5.2
Task 2
For the below drawing, Fig. (5.1), draw a free hand sketch of the assembly guide
Fig. 5.1
WEEK 6
6.0
It is important that you follow some simple rules when producing an engineering
drawing which although may not be useful now, will be useful when working in
industry
6.1 Lay-Out of Drawing
All assembly drawings should follow a standard layout therefore interpreting and analysis
will be easier
Make your own Template follow the steps below
1- Open AutoCAD New File
2- Draw a frame according to your limits (use the size of paper you are using
often)
3- Add Title Block and Parts List table, add the information shown below
4- Now save your template using save as command, change the file type to
AutoCAD Drawing Template and then name your file ASSEMBLY
TEMPLATE
PART
NO.
PART NAME
NO.
OFF
MATERIAL
6.3 Dimensions
Detailed dimensions required for manufacture are excluded from assembly drawings. But
overall dimensions of the assembled object are usually indicated
6.4
Task 3
Fig (35) illustrates the details of V BLOCK ASSEMBLY, using scale 1:1 and first angle
of projection draw the following:
1- An assembled sectional Front View
2- Add Title block and parts list
3- Add 8 main dimensions
Fig 6
WEEK 7
7.0
ASSEMBLY DRAWING
7.1
The drawing below (Fig. 7) shows the details of PIN JOINT ASSEMBLY, using scale
1:1 and first angle of projection draw the following:
4- Complete Sectional Front View with all parts correctly assembled
5- Add Title block and parts list
6- Add 8 main dimensions
Fig. 7
WEEK 8
8.0
ASSEMBLY DRAWING
8.1
The drawing below shows (Fig. 8) the details of SCREW JACK ASSEMBLY, using
scale 1:1 and first angle of projection draw the following
7- Complete Sectional Front View with all parts correctly assembled
8- Add Title block and parts list
9- Add 8 main dimensions
Fig.8
WEEK 9
9.0
ASSEMBLY DRAWING
9.1
The drawing below shows (Fig. 9) the details of PULLEY BRACKET ASSEMBLY,
using scale 1:1 and first angle of projection draw the following
10- Complete Sectional Front View with all parts correctly assembled
11- Use Design center library to obtain the required Hexagon Nut
12- Add Title block and parts list
13- Add 8 main dimensions
Fig. 9
WEEK 10
10.0 ASSEMBLY DRAWING
10.1
Clamp Assembly
The drawing below (Fig. 10) shows the parts of CLAMP, using scale 1:1 and first angle
of projection draw the following:
14- Complete Sectional Front View with all parts correctly assembled
15- Side View without hidden lines
16- Use Design center library to obtain the required Hexagon Nut
17- Add Title block and parts list
18- Add 8 main dimensions
Fig. 10
WEEK 11
11.0 ENGINEERING DRAWING ANALYSIS
The goal of engineering drawing is to identify the contents and elements and understand
the details of the parts and objects drawn, in addition to any suggestions and
modifications to be added.
11.1
The figure below (Fig. 11) shows the two views of a cylinder cover, study the drawing
carefully then answer the below questions.
Fig. 11
No
1
2
3
4
5
6
11.2
Questions
For what purpose this cover is used?
What is the pitch circle diameter of (p 10 mm,
8 holes?
What is the angle between any two adjacent
holes
What is the thickness of the cover?
What is the diameter of the dotted
lines.
Why are the holes located radially?
Answer
To close the cylinder
90 mm
45
10 mm ,8 mm
70 mm
Because the cover is circle
The figure below (Fig. 11.1) shows details of a screw jack, study the drawing carefully
then answer the below questions.
Fig. 11.1
Question
Answer
M: Metric thread
16: Nominal diameter
2: thread pitch
What is meant by M 16 x 2
50 mm
87 mm
Round bar 55 mm
11.3
What is meant by 2 / 45
QUIZ SHEET 3
1) The figure below Fig. (11.2) Shows the details of C-Clamp study the views
carefully and answers the questions below.
Fig. 11.2
Question
Answer
The figure below Fig. (11.3) shows the details of a screw jack, study the views carefully
and answer the questions below
Fig. 11.3
Question
1
WEEK 12
12.0 ASSEMBLY DRAWING
Answer
12.1
Figure 12
Figure 12, shows a pictorial view of a guide bracket, which incorporate inspection plate.
Draw full size and in correct orthographic projection the following views of the guide
bracket with the inspection plate fitted into its slot:
(a) An elevation in direction of arrow A
(b) A sectional elevation on plate PQ and in the direction of arrow B
(c) A plan in the direction of arrow C
Show in views (a) and (c) all hidden edges and includes on your drawing six
important dimensions.
Either first or third angle (but not both) methods of production may be used:
The method chosen must be stated on the drawing.
WEEK 13
13.0 ASSEMBLY DRAWING
13.1
Figure 13
Orthographic views of a sliding block are shown in figure 13. Do not copy the views as
shown but draw the following views:
(a)
In place of elevation F a sectional elevation, the plane of the section and
the direction of required view being indicated at XX.
(b)
A complete outside end elevation in the direction of arrow E.
(c)
A complete outside plan in the direction of arrow P and in projection with
view (a).
Hidden part lines are not required on any of the views. Insert on the drawing
six dimensions, the title and the scale.
WEEK 14
14.0 ASSEMBLY DRAWING
14.1
Figure 14
Figure 14 shows the details of small machine vice and a key to its assembly.
Draw, full size, in correct orthographic projection the following views of the completely
assembled vice, the sliding jaw being approximately 25mm from the fixed jaw.
(a)
A sectional elevation, in a vertical plane passing through the axis of the
square threaded screw, in the direction indicated by XX in the key.
(b)
A plan projected from the above.
Either first angle or third angle (but not both) methods of projection may be
used; the method chosen must be stated on the drawing.
WEEK 15
15.0 ASSEMBLY DRAWING
15.1
Figure 15
Figure 15 shows the details of the parts of a bracket and gland assembly.
Details drawings of the parts of a bracket and gland assembly are given in Figure 15.
The studs are fitted into the holes A. The packing is then inserted into the 38mm diameter
hole at D, following the gland, which is fitted so that the 11mm diameter holes pass over
the projecting studs. The washers and nuts are then fitted to the studs and the nuts
tightened. Do not draw the given views but make the following views, full size, of the
assembly, in first angle projection:
(a)
A sectional elevation, the plane of section and the direction of the required
view being indicated at BB.
(b)
Half of a sectional elevation, the plane of section and the direction of the
required view being indicated at CC. Draw that half which appears on the left of
the vertical centerline
(c)
A half plan. Draw that half which appears above the horizontal center line,
in plan.
