3UF5 SIMOCODE-DP System Motor

Protection and Control Device

Contents

Page

The 3UF5 SIMOCODE-DP System

Thermistor-Type Motor Protection

Without Compromise

Wide Scope of Control Functions

Extensive Diagnostics

Communication PROFIBUS-DP

Exchange of Data

10

Simple Start-Up

12

Price Advantage with SIMOCODE-DP

14

Modular Device Configuration

16

SIVACON
The Communications-Capable
Low-Voltage Switchgear

18

Technical Specifications

19

The 3UF5 SIMOCODE-DP System

There is less and less time in between ordering and the start-up of
a system however, the requirements made on motor feeders are
increasing. A system should, for
example, be compact, intelligent
and powerful. Every motor has
optimum protection, the scope of
wiring is as small as possible and
spares must not mean high storage
costs.
To meet all these requirements, the
system designer has to have extensive
knowledge of the complete range of
low-voltage switchgear. The new
communications-capable
SIMOCODE-DP 3UF50 Siemens
Motor Protection and Control Device Decentralised Peripherals makes life
easier for the system designer.

SIMOCODE-DP is a tried and

tested system
SIMOCODE 3UF10/20 devices have
been in use all over the world for more
than five years. They protect and
control motors for the chemical, oil and
gas industry. Motors with heavy
starting duty as used in paper, cement
and metal production for example are
no problem for SIMOCODE.
SIMOCODE also helps ensure that
high-availability systems such as coal,
gas and hydro electric plants run
around the clock. SIMOCODE provides
the communication between the
master level and the automation level
via the PROFIBUS-FMS /SINEC-L2bus.
The new SIMOCODE-DP 3UF50 with
integrated PROFIBUS-DP interface has
established itself worldwide in a short
time span. It protects and controls for
example Cement and Petrochemical

Supervisory level

industries in Malaysia; Paper,

Chemical, Textile, Steel, Gas and
Waterwork plants in Europe; Chemical
plants in South Africa; Food and
Consumergoods industries in South
America and like the Steel industry in
North America will soon be installed in
a Steel plant in Australia.
The new SIMOCODE-DP 3UF50 is
based on the tried and tested
SIMOCODE 3UF10/20. In addition to
the existing control functions, such as
direct-, reversing-, star-delta starters,
there is now the possibilty to
implement user-specific controls by
using the freely assignable inputs and
outputs and the built-in truth tables,
timers and counters.
The existing motor protection
functions (overload, phase failure and
current imbalance detection) have
been supplemented by thermistor
motor protection and earth-fault
monitoring.

Master computer

Control level
ETHERNET

PLC e.g.
SIMATIC

Automation level
PROFIBUS-DP

K1

Motor

Fans
Field level

K2

Motor

Conveyor
belt

K3

K4

Communicationscapable low-voltage
switchgear
SIMOCODE-DP

Motor

Fans

Thermistor-Type Motor Protection

Without Compromise

Earth fault monitoring

always available
This protective function is also offered
by the SIMOCODE-DP communications-capable motor protection and
control device. The internal earth fault
detection can be activated in addition
to the thermistor evaluation.

Reduction of variants by large

setting ranges: 0.25 A 820 A
A current window from 0.25 A to
820 A is covered using only six units.
This reduces product selection and
saves on spares costs.

Tripping characteristics for 3-pole load

Protection of motors in the EExe range

The SIMOCODE-DP system complies
to the regulations for overload
protection of explosion-protected
motors of the increased safety type
EExe DIN EN 50019/ DIN VDE0165,
DIN VDE 0170/0171 and to the test
regulations of the Federal Institute for
Physics and Technology and the test
requirements of the Federal Institute
for Physics and Technology No. 3.5314605/96.

Tripping characteristics for 2-pole load

120
100

120
100

50

50

20

20

10

Class 30
25
20

5
2
1
50
20
10
5

15
10
Class 5

2
0.6

Easy through feed connection

Feeder cables up to 100 A rating can be
easily connected to the 3UF50. The
cables are not terminated to the device,
but are fed through 3 integral conduits
in the device housing
a major saving in installation time.

min

For motors with a thermally critical

rotor, e.g. slipring and squirrel-cage
motors with increased power, the combination of thermistor-type motor protection and electronically delayed overload
relay offers full thermal protection
thermistor-type motor protection.

Resettable everywhere manual,

remote and automatic reset
A reset at the device is implemented
with the Test/Reset button. By connecting a pushbutton to the inputs, via
PROFIBUS-DP or via the Test/Reset
button at the operating module, a
remote reset can be implemented. An
automatic reset can also be
configured.

Cost reduction by built-in current

transformers
Current detection is archieved via three
current transformers which are
integrated in the device. This means that
savings are made three ways i.e.
space, wiring and additional device
requirements.

Tripping time

Apart from binary thermistor detectors,

SIMOCODE-DP also evaluates
analogous (KTY) thermistor detectors.
KTY detectors incorporate a resistance
curve which rises linearly with the
temperature. Therefore, a warning and
a tripping threshold can be set in the
SIMOCODE-DP.
A considerable advantage.

Protection against stalled rotors

Protection against the stalling of
motors during normal operation is
achieved by a comparison of a settable
current limit.

Tolerance < 10%

With a tolerance of less than 10%,
SIMOCODE-DP has an accurate
tripping curve which guarantees an
optimum utilisation of motors.
Long-term stability also contributes to
the high degree of accuracy.

10
Class 30
25
20

5
2
1
50
20

Built-in thermistor motor protection

Thermistor motor protection is used for
the thermal protection of motors. The
temperature is measured directly at
the motor windings via a PTC or NTC
thermistor detector and is evaluated by
SIMOCODE-DP. No additional
evaluation devices are required, thus
saving space in the switchboard.

An additional evaluation device is not

required, and the space requirement in
the cubicle is further reduced.

min

Finely adjustable adaptation to

start-up conditions
It is possible to select a tripping class
in six steps from CLASS 5 to CLASS
30. The tripping time can be finely
adjusted to the start-up conditions
and the utilisation of the motors can
be optimised.

The SIMOCODE-DP system is also

suitable for a precise earth fault
detection. A version is available with
external earth fault detection. By
connecting an external summation
current transformer, fault currents of
0.3 A, 0.5 A and 1 A can be detected
for both 3 and 4-wire motors.

Tripping time

Overload protection
SIMOCODE-DP protects the load,
independent of the automation level,
against overload, phase failure and
current imbalance. The 3UF50 basic
unit can also be used as an
autonomous, solid-state overload relay
for motor protection.

For motors with 3-wire connection,

fault currents which exceed the
current setting Ie (during nominal
operation) by 30% can be detected
with the internal earth fault detection.

Electrical equipment such as AC

motors and transformers need
protection against excessive heating.
Unbalanced current consumption,
phase failure or a stalled rotor are
some of the possible causes of
overloading.

10
5

15
10
Class 5

2
5
1
10x I e
2
Tripping current (Mean values)

0.6

5
1
2
10x I e
Tripping current (Mean values)

Wide Scope of Control Functions

With the SIMOCODE-DP system nine

different control functions can be
implemented:

Cost reduction by pre-defined

control functions

In addition, run time checks can be set

for the start or stop of motors and for
the slide valve control functions in
between the limits.

In the SIMOCODE-DP, all necessary

interlocking requirements for the
relevant control function (e.g. with
encoders the undelayed deactivation
of the motor in case of an operation of
the limit or torque switch) are implemented. This offers major advantages:

Overload relay
Direct starter
Reversing starter
Star-delta starter
Dahlander
Pole-changing switch
Slide valve (Encoder)
Solenoid valve
SIKOSTART 3RW22
(Soft starter)

Safety by operator enable and

manual/automatic switch-over
In the automatic mode, control
commands (e.g. ON, OFF) are transmitted to SIMOCODE-DP via the bus.
Control commands from the switchgear cubicle (e.g. of the operating
module) or from the local control
station are only possible in this
operating mode if the corresponding
operator enable commands have been
set.

Reducing the demands put on the

user program in the programmable
controller, i.e. fast planning, fewer
possibilities for errors, shorter
program cycle times
Time-critical functions of the
motor feeder are independent of
the signal process time in the
automation level and on the
communication system.

In addition, permanent or nonmaintained command mode can be

set. All control functions can be
implemented using the 3UF50 basic
unit. If more than four inputs and four
outputs are required, an additional
eight inputs and four outputs can be
fitted by using an extension module.

0 Hz
~ 50/6
3/N/PE

0V
400/23

L1
L2
L3
N
PE

2L1
2N
1L1
1N

F11

Q1

l>

Q1
RMT
2
3

-K3

Ready ault
Gen. F

-K2
-K1
ad
Overlo
n ce
t imbala
Curren ure
il
fa
e
s
Pha
tor
Thermis
ult
Earth fa rotection
gp
on
Blockin
detecti
t value
Curren

T1 T2
A1 A2
C
230 V A

-K1
1W
1U 1V

2
3

ON 1
OFF
Local

M
3~

6 7

8 9

-K2

1 2

3UF50
10

ON

4 5

US-DP
PROFIB
PE/PE
S
A
11 B

Test/
Reset

OFF

e
ing at th
Switch door via
le
ic
b
cu
F52
the 3U ng module
ti
ra
e
op

-K3

2W
2U
2V

If the automatic level switches to

manual operation, or if local control is
activated by means of a local manual/
automatic key switch, the bus control
commands are ignored and the feeder
can now be exclusively controlled via
the operating module or using the local
control station.
Reduction of failure times by
autonomous operation
In case of system failures on the
communication system, SIMOCODEDP automatically switches to manual
mode.
When this occurs, the load is either
switched OFF or the operating state is
maintained. Further control is possible
using the manual mode.
Downtimes in case of failures in the
automation and communication level
are considerably reduced: The process
can still be safely continued locally due
to the autonomous structure of the
SIMOCODE-DP.
The process can be resumed however
surely by the self-sufficient structure of
the system SIMOCODE-DP locally.
It means self-sufficient that all
protective relay for motor and control
functions are processed independently
of the automation level in the
SIMOCODE-DP.

Flexibility due to decentralised

signal logic-, delays- and
conditioning
The great flexibility of the SIMOCODEDP system is especially characterised
by the integrated:

Selective start of the system

After a mains failure, the motor feeders
can be restarted using time-grading.
This makes a fast and selective start of
the system possible.

3 truth tables
(3 inputs with 1 output each)
1 truth table
(5 inputs with 2 outputs)
2 timers
(0.5 s...60 min; output behavior:
ON delay, OFF delay, fleeting
NO contact)
2 counters
(0...65535)
4 elements of signal processing
Inverted level without memory
Rising edge with memory
Falling edge with memory
Signal conditioning
3 flashing modules
3 flickering modules.
2 elements of non-resetting
onvoltage failure
The inputs and outputs of the system
can be assigned to predefined control
functions as well as to the truth tables,
timers and counters. Thus, a flexible
use of the predefined control functions
is possible.
The make/break contact behavior of
the outputs is set by the signal
processing modules.

Control and Signalling

Extensive Diagnostics

SIMOCODE-DP offers a large amount

of operational and statistical data on
the feeder, which is available to the
user for visualisation and diagnostic
purposes.
This data can be accessed:
directly at the switchboard via the
LED display of the hand-held-unit
plugged into the basic unit or
operator panel, or via a PC with
Win-SIMOCODE-DP/Smart.
via PROFIBUS-DP. The data can be
read by the user program and it can
be transferred to a corresponding
operator communication and
monitoring system. Thus, the various
operational and statistical information
can be displayed in the control room
over PROFIBUS-DPV1 with a
communications processor which
were in the PC/PU and the software
Win-SIMOCODE-DP/Professional

Always informed as to the current

operating state

Display of other critical operating

states:

SIMOCODE-DP continuously informs

the process engineer about the current
operating state:

Current imbalance
Overload warning/trip
Thermistor motor protection
warning/trip
Earth fault warning/trip
Locked rotor protection
Warning/trip upper/lower current
limit response.

actual phase current in %

ON/OFF
Anti-clockwise, clockwise LEFT/
RIGHT
Fast, slow
Slide open, closed, moving
Warning
Fault.
Reduction of failures by the
signalling of critical operating
states
The settable current limits inform the
process engineer about critical states
in the system. For example, a current
which is below the lower current limit
setting could mean a broken conveyor
belt for example. The overloading of a
mixing machine for example can be
quickly detected by the display of
upper current limit exceeded. To avoid
an overload trip of the machine, the
process engineer can take precise
steps to change the working process,
such as reducing the amount of
material in the mixer.

Reduction of maintenance times

Maintenance intervals can be
increased, as all statistical data relating
to the condition of a particular feeder is
transmitted from the SIMOCODE-DP to
the PLC. SIMOCODE-DP registers the
number of starts and the number of
overload trips, counts the operating
hours and calculates the current in %
of the last trip. All data is stored in a
non-volatile memory in SIMOCODE-DP.
Analogue Current display
For display of analogue current value
through a display device on the panel
door; the SIMOCODE-DP system is
provided with an external current
transformer (range 0.25 A-820 A/1A).
With this it is also possible for the
systemselector to inform about the
actual current flowing in the motor
feeder.
Self-monitoring
The correct function of the
SIMOCODE-DP processor is
permanently monitored. If there is a
fault, SIMOCODE-DP switches the
load to the adjustement, safe state
(OFF, or maintain operating state monostable or bistable behavior).
Also testable in action
This function gives SIMOCODE-DP
additional safety and better monitoring
features.
The operation of SIMOCODE-DP can
be checked during running without
switching off of the motor. This saves
time and avoids unnecessary
interruptions of the operation.

Display and Diagnoses with Win-SIMOCODE-DP software

Communication
PROFIBUS-DP

PC or PU with
Win-SIMOCODE-DP/
Professional

PROFIBUS-DPV1
Online parametrization,
diagnostics, control
and test via acyclical
reading and writing
of data

PLC

Programmable
Logic Controller

MMI

Man-Machine
Interface

PU/PC Programming Unit/

Personal Computer

PC or PU
PLC
MMI
with PROFIBUS-DPcommunicationprocessor

PROFIBUS-DP
Cyclical exchange of data of control-, and
signal data. Moreover exchange of diagnostics
by changing and parameterization at communication
processor running-up

SIMOCODE-DP

SIMOCODE-DP

SIMOCODE-DP

PC or PU with
Win-SIMOCODE-DP/Smart
or Hand-Held-Unit

From point to point,

parametrization, diagnostics,
control SIMOCODE-DP and
test via RS-232-Interface

3UF50 SIMOCODE-DP

PROFIBUS-DP (Process Fieldbus Decentralised Peripherals) provides

high-performance communication
between the SIMOCODE-DP and the
automation level. Control commands,
operational data, statistical data and
parameter data are transmitted via the
two-wire bus cable. There is also the
possibility to use optical link modules
so that the data transmission would be
effected via plastic or glass fibre optic
cables.
Here, the communications processor
(CP/IM) plugged into the programmable logic controller (PLC) provides the
management of the SIMOCODE-DP

devices connected to the bus and

forms the interface to the user
program. Further processing of the
SIMOCODE-DP data, i.e. the integration into the supervisory control
system and any subsequent
processing is handled by the user
program.
Short transmission times
To achieve short transmission times,
PROFIBUS-DP features several data
channels. Up to 12 bytes can be sent
cyclically from SIMOCODE-DP
to the automation level and up to 4
bytes can be returned.

Technical specifications PROFIBUS-DP

Total stations

30 SIMOCODE-DP per segment;

with RS485 repeaters 122 SIMOCODE-DP

Transmission medium

shielded, twisted, pair cable or plastic fibre

glass fibre optic cable

max. distance

9.6 km for two-wire, 100 km for glass fibre

optic cable, 425 m for plastic fibre optic cable

Transmission medium

PROFIBUS-DP (EN 50170), PROFIBUS-DPV1

Transmission speed

9.6, 45.45, 93.75, 187.5, 500, 1500 kBit/s

The diagnostic data of 20 bytes is

only sent to the automation level of
SIMOCODE-DP in case of a change,
i.e. the diagnostic channel is eventcontrolled. 213 bytes of parameter
data are only sent to the SIMOCODEDP during the start-up of the
automation system.

Communication
PROFIBUS-DPV1
The PROFIBUS-DP standard has been
extended around acyclic reading and
writing from data and with PROFIBUSDPV1 this can be achieved. Acyclic
reading and writing means for
SIMOCODE-DP, that from a central
workstation over PROFIBUS-DPV1
with a PC or PU fitted with
communicatios processor and the
software Win-SIMOCODE-DP/
Professional all control, diagnosis,
test and parameter data can be
read and written. The PROFIBUS-DPV1
is a secondary protocol for the
PROFIBUS-DP, and it does not
require additional lines or interfaces.

OUT without
PROFIBUS-DP.

The communication processors

SIMOCODE-DP can work with any
standard DP master which is able to
read GSD files and which is capable
of processing the following amounts
of data:
Control data 1 or 4 byte cyclic from
the DP master to SIMOCODE-DP
Signalling data 1/4/12 byte cyclic
from SIMOCODE-DP to the DP
master
Diagnosis data 20 byte acyclic from
SIMOCODE-DP to the DP master
Parameter data 213 byte.

Siemens and 400 other

manufacturers and users
of communications-capable
devices fully support the
EN 50170 PROFIBUS
standard. All are members
of the PROFIBUS user
organisation.

Today, there are more

than 700 PROFIBUS-related
products.

For acyclic reading and writing from

data the communication processor
must be able the standard extension
PROFIBUS-DPV1.
Bus system expandable
If no bus system is applicable at the
todays point in time, then can be
easily re-tooled this later. Because
SIMOCODE-DP processes all
protective relay for motor and control
functions independently of the
automation level.
Naturally also SIMOCODE-DP is
applicable as self-sufficient protective
realy for motor and controller without
PROFIBUS-DP genereally.

See for yourself. You can

get information on the highperformance PROFIBUS
simply by requesting the
information diskette of the
PROFIBUS user
organisation or via the
Internet. This will give you
an immediate overview of
all relevant products.

Simple Start-Up

PC or PU with
Win-SIMOCODE-DP/
Professional

PLC
MMI
with PROFIBUS-DPCommunication
Processor

PROFIBUS-DP
Parameter data is written
on every starting cycle of
the communication processor

PROFIBUS-DPV1
Online Parameterization

SIMOCODE-DP

SIMOCODE-DP

PC or PU with
Win-SIMOCODE-DP/Smart
or hand-held-unit

SIMOCODE-DP

Point to point parameterization

over SIMOCODE-DP system
interface

Mglichkeiten der Parametrierung

Integrating many slaves using only

one software
The integration of SIMOCODE-DP into
a PROFIBUS-DP network is easily
achieved via the parameterising and
service programme of COM
PROFIBUS Windows 3.1 or of
SIMATIC S7: Step 7 Windows 95.
Call up the parameterisation and
service program COM PROFIBUS open the master system under File
New and add the individual slaves
e.g. the SIMOCODE-DP, the
PROFIBUS-DP interface for the circuitbreaker or the micro master everything with just one software.
Double-click on the SIMOCODE-DP
icon and now the required parameters
for the motor feeder can be set.
SIMOCODE-DP Online
Parametrization
Now the user can parameterize
SIMOCODE-DP Online from a
central workstation through
PROFIBUS-DP.
So, what is meant by Online?
Previously it was possible to transfer

10

the slave parameters through

PROFIBUS-DP only in the start-up
phase of the communication processor.
But now exists the possibility that
besides normal cyclic data exchange,
acyclic reading and writing of
parameters is also possible. This
means now SIMOCODE-DP can be
parameterized, controlled, observed
and tested from a central project
engineering workstation by using WinSIMOCODE-DP/Professional software.
This central project engineering
workstation should be equipped with a
personnel computer (PC) or a
programming unit (PU) with integrated
PROFIBUS-DP communication
processor. Another possibility is to use
a Siemens PU, with integrated MPI
interface and access the PROFIBUSDP directly.
Reduced comissioning time
Now its not required to run around
from switch room and parametrize the
motor feeders. All SIMOCODE-DP
connected to PROFIBUS-DP can be
parametrized from a central place.
Moreover all parameters can also be
read and written by that.

Increased system availability

In the past changing of parameters
meant system deadlock. With WinSIMOCODE-DP/Professional the
parameters in SIMOCODE-DP can be
modified Online through PROFIBUSDP wihtout bringing the system to a
halt.

Totally Integrated in SIMATIC S7,

C7, M7, PCS7 OM-SIMOCODE-DP
Win-SIMOCODE-DP/Professional is
Totally Integrated in SIMATIC S7/C7/
M7 as well as PCS7. The call is made
by STEP 7 from HW-Config. The OMSIMOCODE-DP therby implements
the data interface.
This results in a unique possibility; that
only with one software package one
can write the PLC user programme,
configure PROFIBUS-DP and
parameterize SIMOCODE-DP 3UF5
the communication capable motor
protection and control device. Use of
different complex software packages is
omitted thereby.

Totally Integrated in SIMATIC S7/M7/C7/PCS7

A plus for commisioning

Another advantage of the SIMOCODEDP system is that a motor feeder can
be tested during the commisioning
stage with the Win-SIMOCODE-DP/
Professional software. This means,
there lies a possibility, that one can
switch on and off from a central
workstation and also set the Testbits
and enquire about the device state.

Interconnectivity from SIMOCODE-DP to a PROFIBUS-DP network

Parameterization with Win-SIMOCODE-DP/Professional

11

Price Advantage with SIMOCODE-DP

Figure 1 shows the configuration of a

typical communications-capable motor
feeder with overload relay, thermistor
motor protection device, earth fault
detection, current value transmission
via A/D converters and a decentralised
peripheral system for the bus
connection.
Figures 2 and Figure 3 show the motor
branch of the future.

is normally implemented via coupling

devices and point-to-point connections
to input and output modules of the
PLC or DCS. With the application of
SIMOCODE-DP, the scope of wiring is
reduced to a minimum - A two-wire
PROFIBUS-DP cable for up to 100
motor feeder; Coupling devices and
input/output modules, cable gallery are
not required.
Reduction in wiring costs in
the field level

Reduced number of products

cover the entire range
For the complete control and
monitoring including connection to the
PROFIBUS-DP, only SIMOCODE-DP is
required. This means that no additional
overload relays, thermistor evaluation
devices etc. need to be installed.
Reduction of the scope of wiring
between field and control level

In the case of the reverser starter

(figure 3) no electrical interlocking is
required, and no time-delay relay which
prevents a direct switch-over from
clockwise to anti-clockwise rotation is
necessary. Everything is implemented
with SIMOCODE-DP. The only thing
required is to set the desired switchover delay time

Communication between the field

level and the higher automation level
(PLC or process control system DCS)

3UF5
With

Without 3UF5

-Q1

-Q1
-K1

-K1

-K2

-K2

Earth fault
detection
3UL22

ce
load
Over t imbalan
n
e
r
Cur
ure
n
e fail
ectio
Phas ault prot
f
Earth istor
tion
m
Ther
rotec
ion
ing p e detect
k
c
lo
B
lu
a
v
nt
Curre

3UL21
Current value
transmission

4...20 mA

Overload relay
3RU50

3UN21

PROFIBUS-DP
M
3~

Thermistor
motor protection

Figure 1: Well-tried technology

12

DI

AI

M
3~

DO

Decentralized peripherals

e 2:
Figur

f
nch o
r bra
o
t
o
M

uture
the f

3/N/PE~ 50/60 Hz

L1
L2
L3
N
PE

400/230 V

1L1
1N

Q1

2L1
2N
F11
Q1
RMT

l>

-K1

-K2

Overload
Current unbalance
Phase failure
Thermistor
Earth fault
Blocking protection
Current value detection

A1 A2 T1 T2 1 2
230 V AC

4 5

Ready
Gen. Fault

Anti-clockwise

3UF50
6 7

8 9

PROFIBUS-DP
10 11 B A SPE/PE

Clockwise

Test/
Reset

Off

4
Local

M
3~

-1

-K1

-K2

Figure 3: Reversing starter with SIMOCODE-DP

As all functions are integrated into one

device, the following savings are
possible.

Savings possible:
device variants in
the motor feeders
space requirement
in the cubicle
the wiring cost
between control level
and field level
scope of wiring
in the unit control
level
start-up
times
spares
costs
13

Modular Device Configuration

The modular configuration of the

SIMOCODE-DP system means that it
can be used as a protection and
control device for feeders. The system
consists of the following components:

3UF50 basic unit

The basic unit with four inputs and
four outputs implements all protection
and control functions autonomously,
and provides connection to the
PROFIBUS-DP. The four inputs are fed
by the internal 24 V DC power supply.
The extension module, the operating
module, the manual operating device
or the PC can be connected via the
system interface. The basic unit is
produced with three different control
supply voltage
(24 V DC, 115 V AC, 230 V AC).

3UF51 extension module

Win-SIMOCODE-DP
Runs on any AT-compatible PC under
Windows 95 or Windows NT. For startup, diagnostics and maintenance.
Manual control (ON, OFF, ...)
Diagnostics (current display, fault, ...)
Parameterization (address, baud rate,
set current, control function, ...)
Includes Online Help and parameter
data examples.

The extension module additionally

provides eight inputs and four outputs
to the system. The device itself is fed
by the basic unit. The eight inputs
must be connected to an external
voltage supply. Here, there are three
different voltage versions (24 V DC,
115 V AC, 230 V AC). The connection to
the basic unit and the connection to
the operating module, to the manual
operating device or to the PC is via the
system interface.

3UF52 operating module

For manual control of a drive in the
cubicle. Can be connected to the basic
unit and to the extension module.
Power supply from the basic unit.
Connection possibilities for the manual
operating device or PC. Installation in
the front panel or in the IP 54 cubicle
door.
Three buttons can be freely
parameterised. Six signalling LEDs
can be freely parameterised.

14

3WX36 manual operating device

Connection of a thermistor sensor circuit
for optional thermistor-type motor
Connection of a summation current
transformer for earth fault monitoring

A1

A2

T1

T2

AC 230V

Connection of control
supply voltage
- 24 V DC
- 115 V AC
- 230 V AC

I1

I2

I4

I3

24VDC

Ready
Bus
Sys.
3UFS

Gen. Fault

System interface
- Connection of extension
module, operating module,
manual operating device or PC

25...100A

3 LED displays
Device test, manual reset
- Automatic reset parameterisable
- Remote reset via bus or input

4 optocoupled inputs:
- 24 V DC, internally supplied
- Function assignment
parameterisable

Test/
Reset

PROFIBUS-DP
3UF5021-3AJ00-1

G/9520

01

3 + 1 relay outputs:
- Function assignment
parameterizable

02

This can be connected to the basic

unit, to the extension module or to the
operating module. For commisioning,
diagnostics and maintenance. Manual
control (ON, OFF, ...) Diagnosis
(Current display, fault, ...)
Parameterisation (address,
baud rate, set current, control
function, ...)

03

03

10

PROFIBUS-DP

11

A SPE/PE

OM-SIMOCODE-DP
PROFIBUS-DP bus connection
- Standard 9-pole SUB-D socket
- Terminals, e.g. for drawout unit
design

STEP 7-Object-Manager to call WinSIMOCODE-DP/Professional in STEP 7

Connection cables with plugs
Connection between basic unit,
extension module or operating
module.

20

15

System interface
- Connection to basic unit
- Power supply from basic unit

21

16

22

17

23

24

18

25

19

10

Sys.
3UFS

11

28

12

3UF5100-0XX00-0AA0

05

30

27

Sys.
3UFS

G/9520

3 + 1 outputs:
- Function assignment
parameterisable

26

31

06

32

07

8 optocupled inputs:
- 24 V DC, 115 V AC
230 V AC, externally supplied
- Function assignment
parameterisable

System interface
- Connection of
operating module,
manual operating device
or PC

08

33

34

35

PE

Bus terminal/bus termination

modules
If the PROFIBUS-DP is connected to
the basic unit, the standard 9-pole SubD plugs with built-in bus terminating
resistor can be used. Especially for the
application of SIMOCODE-DP in Motor
Control Centers (MCC drawout unit
design) there is a bus termination
module with built-in power supply. This
guarantees that even the last unit in
the bus can be removed without any
impairment of the data flow.
Operating manual

2 status LEDs

Ready
Gen. Fault

3 LED displays
Function assignment
parameterisable
Device test
Manual reset

Test/
Reset

3 buttons,
function assignment
parameterisable
3 LED displays
function assignment
parameterisable
9-pole SUB-D socket
for the connection of the
manual operating device
or PC

A manual for the SIMOCODE-DP

system is available which describes
each detail of the functionality of
SIMOCODE-DP. It is intended as an aid
for project planning and system startup and it features a comprehensive
description of the PROFIBUS-DP
communications interface and project
examples.

15

SIVACON The Communications-Capable

Low-Voltage Switchgear

As well as the communicationscapable 3WN6 circuit-breakers and

AS-Interface modules, SIMOCODE-DP
now provides another communications
module for low-voltage switchgear.
SIMOCODE-DP can be used in
SIVACON for the control of all
feeders in both fixed and drawout
design.
High availability - no problem with
SIVACON drawout design
SIVACON drawout design enables the
system operator to adapt quickly to
changing system requirements.
With the integration of SIMOCODE-DP
directly into the drawout units, a clear
connection to the feeder and the
corresponding SIMOCODE-DP is
reached. A replacement of drawout
units is possible without interruption of
the bus connection.
Technical configuration of the
SIVACON switchgear with
SIMOCODE-DP
The 3UF52 operating module is always
accessible from the front and is
situated in the front panel of the
relevant drawout unit.
The 3UF50 basic unit with the integrated current transformers is built into
the inside of the drawout units.
Each feeder can be adjusted and
controlled autonomously at the
switchboard by connecting the manual
operating device or a PC with the WINSIMOCODE-DP software to the
operating module integrated into the
front panel. In addition, all operation,
diagnostic and statistical data
determined by SIMOCODE-DP can be
read.

16

Technical Specification

3UF50 basic unit, 3UF51 extansion module, 3UF52 operator panel, 3WX3G hand-held-unit
Permiss. ambient/storage temperature

-25 C to +60 C/ -40 C to +80 C

Site altitude

up to 2000 m above sea level

Degree of protection (in acc. IEC 529)

IP 20 max. setting curent Ie w 100 A; IP 00 max. setting current Ie > 100 A;

Shock resistance (sinewave)

10 g /5 ms

Mounting position

free choice

Mounting

max. setting current Ie w 100 A: snap-on mounting onto 35 mm top-hat rail or screw fixing
with insertion clip
max. setting current Ie > 100 A: screw fixing directly to contactor of srewfiring

EMC interference immunity

Conducted interference, burst in acc. with IEC 61000-4-4: 2 kV (corr. to severity 3)

Conducted interference, surge in acc. with IEC 61000-4-5: 2 kV (corr. to severity 3)
Electrostatic discharge in acc. with IEC 61000-4-2: 8 kV (corr. to severity 3)
Field-related interference in acc. with IEC 61000-4-3: 3 V/m (corr. to severity 2)
(see special notes in the manual)

EMC emitted interference

Limit value class A in acc. with EN 55011 1991

3UF50 basic unit

Display
green LED Ready

Permanent light Ready

Off no control supply voltage or function test negative, device blocked

green LED Bus

Permanent light Bus operation

red LED General Fault

Permanent light/flashing light Branch fault, e.g. overload tripping

Buttons
Test/Reset

By pressing the Test/Reset button the device can be reset after a tripping or it can be
tested as to its functionality

System interface

RS232 for connection of extension module, operating module, manual operating device or PC

PROFIBUS-DP interface

RS485 for connection of the PROFIBUS-DP line via terminals (connection cross-section
as with auxiliary contactors or via 9-pole SUB-D socket)

Main circuit

Rated insulation voltage U I

690 V for blank/uninsulated conductor (3UF5001 - 3UF5021)

for pollution degree 3
1000 V for insulated conductor 3UF5031 - 3UF5051
1000 V for blank/uninsulated conductor (3UF5031 and 3UF5051)

Rated impulse strength Uimp

6 kV 3UF5001 - 3UF5021
8 kV 3UF5031 - 3UF5051

Rated frequency and current type

50 Hz/60 Hz; three-phase AC

Diameter of push-through openings

(max. Ie w 100 A)

10 mm (devices with max. setting current Ie w 25 A)

15 mm (devices with max. setting current Ie 100 A)
for devices with setting current Ie >100 A: mounting with connection bars

Busbar connection (Current range)

Torque

50 to 205 A
M8: 10 to 14 Nm

125 to 500 A
M10: 14 to 24 Nm

Flexible with cable lug

Stranded with cable lug

35 to 95 mm2
50 to 120 mm2

50 to 240 mm2
70 to 240 mm2

200 to 820 A
M10: 14 to 24 Nm
M12: 20 to 35 Nm
50 to 240 mm2
70 to 240 mm2

Auxiliary circuit/control circuit

Rated control supply voltage Ue

AC 50/60 Hz, 115 V and 230 V

DC 24 V

Working range

AC 50/60 Hz, 0.85 to 1.1 Us

DC 24 V, 0.85 to 1.2 Us (DIN 19240)

Power consumption

AC 50/60 Hz, 5 VA

DC 24 V, 5 W

Mains buffering time

200 ms

Rated insulation voltage U I

300 V (for pollution degree 3)

Rated impulse strength Uimp

4 kV

Outputs
Auxiliary contacts of outputs
Upstream short-circuit protection for
auxiliary contacts (outputs)

4 mono-/bistable outputs depending on the variant

3 outputs thereof are connected to a common potential and 1 is connected separately; can be freely assigned to the
control functions (e.g. for activation of mains and star-delta contactor as well as signalling of the operating state)
Fuse-links utilization category gL/gA 6 A, fast 10 A
Circuit-breaker 1.6 A, C characteristic

Rated continuous current

5A

17

Rated operating current

(Switching capacity)

AC-15; 6 A/24 V; 6 A/120 V; 3 A/230 V

DC-13; 2 A/24 V; 0.55 A/60 V; 0.25 A/125 A

Inputs

4, own power supply due to device electronics (24 V DC); inputs connected to a common potential for the coupling
of process signals such as e.g. local control station, key-operated switches or limit switches

Thermistor motor protection

(PTC thermistor detector)

Total cold resistance: 1.5 kO

Operating value: 2.7... 3.1 kO; release value: 1.5...1.65 kO

Connection cross-section
Torque
single-core and stranded
flexible with/without conductor barrel

0.8 to 1.2 Nm
1 x (0.5 to 4.0) mm2; 2 x (0.5 to 2.5) mm2
1 x (0.5 to 2.5) mm2; 2 x (0.5 to 1.5) mm2

3UF51 extension module

System interface

RS232 as connection to the basic unit and

for connection of operating module, manual operating device or PC

Auxiliary circuit/control circuit

Rated insulation voltage U I

300 V (for pollution degree 3)

Rated impulse strength Uimp

4 kV

Outputs
Auxiliary contacts of outputs
Upstream short-circuit protection for
auxiliary contacts (outputs)

4 bistable outputs
3 outputs thereof are connected to a common potential and 1 is connected separately;
can be freely assigned to the control functions (e.g. for activation of mains and star-delta contactor as well as
signalling of the operating state)
Fuse-links utilization category gL/gA 6 A, fast 10 A
Circuit-breaker 1.6 A, C characteristic

Rated continuous current

5A

Rated operating current

(Switching capacity)

AC-15; 6 A/24 V; 6 A/120 V; 3 A/230 V

DC-13; 2 A/24 V; 0.55 A/60 V; 0.25 A/125 A

Inputs

8 externally supplied 24 V DC, 115 V AC, 230 V AC depending on the variant, inputs connected to a common potential
for the coupling of process signals such as e.g. local control station, key-operated switches or limit switches

Connection cross-section
Torque
single-core and stranded
flexible with/without conductor barrel

0.8 to 1.2 Nm
1 x (0.5 to 4.0) mm2; 2 x (0.5 to 2.5) mm2
1 x (0.5 to 2.5) mm2; 2 x (0,5 to 1.5) mm2

3UF52 operating module

Displays
green LED Ready

Permanent light Ready

OFF no control supply voltage or function test negative, device blocked

red LED General Fault

Permanent light/flashing light Branch fault, e.g. overload tripping

3 green und 3 yellow LEDs

Feeder-specific displays can be freely assigned, e.g. manual/automatic mode,

tripping, thermistor motor protection, clockwise/anti-clockwise rotation etc.

Operating buttons

For controlling the motor feeder, freely programmable

Keys
Test/Reset
System interface

By pressing the Test/Reset button the device can be reset after a trip
or it can be tested as to its functionality
RS232 for connection of manual operating device or PC

3WX36 manual operating device

Displays

2 lines, 16 letters.

Keys

3 function keys, 4 cursor keys, 1 acknowledgement key

Power supply

4 batteries, type 1.5 V round cell

18

Win-SIMOCODE-DP/Professional 3UF5710
Parameterization, Operate, Observe, Testing
Parameterization, Operate, Observe, Testing

over DPV1
over RS-232

Target system
Automation System

SIMATIC S5
SIMATIC S7/M7/C7/PCS7
foreign system

PC/PU requirements
sea PC-/PU requirements
free capacity harddisk

Windows 95 or Windows NT 4.0

minimum 10 MB

STEP 7 requirements

STEP 7 is not an absolute necessity. But when it is already installed it is necessary

to have a Version 4.0. (These version contain the compatible support software for DPV1
otherwise it will be directly loaded through Win-SIMOCODE-DP/Professional)

PC/PU interface requirements

PU integrated with MPI-SS or MPI-Board

CP 5411, CP 5412 (A2), CP 5511 or CP 5611
RS-232 with compatible interface cable 3RW29 20-1DA00

SIMOCODE-DP requirements

DPV1-delivery date E10 (from June 98)

Win-SIMOCODE-DP/Smart 3UF5711
PC/PU requirements
sea PC-/PU preconditions
free capacity harddisc

Windows 95 or Windows NT 4.0

minimum 10 MB

PC/PU interface requirements

RS-232 with compatible interface cable 3RW29 20-1DA00

OM-SIMOCODE-DP 3UF5712
SIMATIC requirements

SIMATIC S7/M7/C7/PCS7

STEP 7 requirements

Version 4.0

PC/PU requirements

Software STEP 7

SIMOCODE-DP requirements

DPV1 delivery date E10 (from June 98)

19

www.ad.siemens.de
Automation and Drives Group
Low Voltage Controls and Distribution Division
P.O. Box 32 40, D-91050 Erlangen
Siemens Aktiengesellschaft

Subject to change without prior notice 4/98

Order No. E20001-A230-P302-X-7600
Printed in Germany
Dispostelle 27615/SEK 30197
21C7128 CPSM.52.1.03 PS 07013.0
