TURNTABLE
instruction manual
CONTENTS
I. GENERAL DESCRITION
SPECIFICATIONS
ACCESSORIES
II. UNPACKING
III. ASSEMBLY
Mounting tonearm
IV. ADJUSTMENT
2. Levelling of turntable
V. USE OF CLAMP
10
11
1. Immobile subchassis
11
11
3. Slow start
11
12
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
I. GENERAL DESCRITION
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
SPECIFICATIONS
mass
external dimensions
weight of platter
resonance ob subchassis
speeds
mat
motor
mains supply (non selectable)
40 kgs
500x400x200 mm
8 kgs
2 Hz (damped)
33,45 RPM
textile&rubber
2 pcs 24 poles
110 V, 240 V, 50, 60 Hz
ACCESSORIES
The following are supplied with the turntable and will be found in the accessories box:
1. Clamp with washer (plate)
2. Alan key 4 mm for tonearm board
3. Small plastic bottle with oil for bearing
4. belt
5. subplatter
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
II. UNPACKING
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
III. ASSEMBLY
1. Open box C and remove baseplate taking care not to knock motor pulleys. Place
in intended location for use.
2. Open box B, remove subchassis and lower gently into position on top of base plate.
Remove protection tape from shaft and check that the small ruby ball is in a central
position on top of the shaft.
3. From box A remove subplatter, belt and small oil bottle. Remove protection tape
from theunderneath of the subplatter.
4. From small oil bottle squeeze 35 drops of oil onto the top of the shaft. Oil will run
from top to fill lower well.
5. Gently lower subplatter onto shaft (NOTE: if at anytime it is necessary to remove
subplatter, be aware that a certain amount of oil will adhere to it). Airpressure will
slow motion ob subp.
6. Carefully put belt around both motor pulleys and subplatter to make a diamond
shape.
7. Remove platter from box D and place carefully on top of subplatter, mat uppermost.
8. Turning the adjustment knobs anticlockwise cause the subchassis to rise. If you
look
from the side between baseplate and subchassis you can see a line marked on each
suspension towers which is 7 mm above the baseplate. Adjust height of subchassis
by turning all 4 adjustment knobs so thar lowr edge of subchassis is level with
markings on all towers.
9. The cable for connecting power supply and turntable has five pin plugs which
should
be inserted and locked into connectors at rear of power supply and turntable.
10. Connect mains cable into mains and then switch on power supply at the rear of PS.
Red light should appear on front panel.
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
Mounting tonearm
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
IV. ADJUSTMENT
REFERENCE T U R N T A B L E
KUZMA
V. USE OF CLAMP
The function of the clamp is to press the record close to the platter mat, thus
minimising vibration between record and platter and decreasing warps of record itself.
1. position metal disc over spindle on top of mat.
2. place record on spindle.
3. gently screw clamp onto spindle while steadying platter and edge of record with
fingers.
4. clamp should be tightened so that rim of record touches mat. Continue tightening
until rim of record starts to rise, at which point release clamp slightly.
5. with very bent records pay particular attention to highest point of rim.
With a little practise use of clamp soon becomes second nature.
Note: If clamp is inadequately tightened, inner grooves are out of contact with mat
and if overtightened outer grooves are visibly raised. Slight cracks on the
middle of record (around the hole) might occur.
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
KUZMA
1. Dust with a soft cloth and any oil stains can be removed with detergent or alcohol.
2. Cleaning pulleys and belt:
This should be done occasionally (3 to 6 months) according to regularity of use.
a. remove platter to gain access to belt and pulleys. Remove belt. Switch on motors,
clean surfaces of pulleys and subplatter with cotton bud moistened with alcohol.
By hand rotate subplatter and clean it.
b. moisten cloth with alcohol and pull belt throught cloth to clean (ensure that
hands
are clean and grease free.
3. Cleaning of mat:
a. remove platter from turntable
b. squeeze alcohol onto mat until whole surface is wet.
c. with a toothbrush brush out from centre until alcohol evaporates.
4. Check oil in bearing:
The level of oil is not so critical due the use of metal versus non metal sliding
materials. However, the level of oil should be just under the height of ruby ball
and cca 2 mm height in the middle of lower bath.
_________________________________________________________________
STABI
REFERENCE T U R N T A B L E
10
KUZMA
If any problem occur with your turntable do not hesitate to contact your dealer. It
may, however, he convenient to be able to make a few checks and adjustments
yourself.
1. Immobile subchassis
- check turntable has been unpacked correclty,
- check tension of tonearm cable
- check clearance between subchassis and baseplate
- check that nothing else is touching subchassis
3. Slow start
- clean belt and check oil in bearing. If there is a fault in power supply consult
your dealer. Check cable conection.
