BASIC

BASIC INSPECTION
INSPECTION
&
&
ADJUSTMENT
ADJUSTMENT
 Compression Pressure Test
Ignition Timing
Idle Speed Adjustment
TP Sensor Adjustment
Fuel Pressure Test
Valve Clearance Adjustment(MLA)
Timing Belt Alignment
COMPRESSION PRESSURE TEST

PURPOSE

To check the condition of piston rings, cylinder head gasket, valve

seat, valves and valve springs.
COMPRESSION PRESSURE TEST
CHECK CONDITION
ENGINE OIL LEVEL, STARTER MOTOR AND BATTERY
ARE NORMAL

CHECK PROCEDURE
1. REMOVE THE SPARK PLUGS
2. ATTACH THE COMPRESSION
GAUGE TO THE SPARK PLUG
HOLE
COMPRESSION PRESSURE TEST

3. DEPRESS THE ACCELERATOR PEDAL TO FULLY

OPEN THE THROTTLE VALVE
4. CRANK THE ENGINE AND READ THE GAUGE
5. REPEAT STEP 2 THROUGH 4 ON ALL CYLINDERS
AND CHECK THE PRESSURE DIFFERENTIAL FOR
EACH CYLINDERS

LIMIT MAX. 1.0/ BETWEEN CYLINDERS

COMPRESSION PRESSURE TEST
PROCEDURE

6. IF A CYLINDER PRESSURE OR PRESSURE DIFFERENTIAL

IS BELOW SPECIFICATION, ADD A SMALL AMOUNT
ENGINE OIL THROUGH SPARK PLUG HOLE.

IF THE ADDITION OF OIL BRINGS THE COMPRESSION UP

SUSPECTED ITEMS : WORN CYLINDER AND PISTON RINGS, PISTON OR
RING BROKEN
IF SAME COMPRESSION PRESSURE AFTER ADDING OIL
SUSPECTED ITEMS : VALVE, VALVE SPRING, VALVE SEAT, CYLINDER
HEAD GASKET
IGNITION TIMING
PURPOSE

The fuel system and ignition system should be correctly

functioning for the engine to run smoothly. Hence,
proper operation of the fuel system and ignition system
must be determined prior to troubleshooting. Therefore,
the purpose of ignition timing is to check if the ignition
system is operating properly.
IGNITION TIMING
CHECK CONDITION
- WARMING UP TEMPERATURE
- ALL ELECTRICAL LOADS OFF
- A/T : "P" OR "N"
- IDLE RPM IS NORMAL

CHECK PROCEDURE
1. INSTALL A TIMING LIGHT
2. GROUND THE IGNITION
TIMING ADJUST TERMINAL
3. CHECK THE IGNITION
TIMING THROUGH TIMING
LIGHT
IGNITION TIMING

4. ADJUST THE IGNITION TIMING

IF THE IGNITION TIMING IS OUT
OF SPECIFICATION
5. IF THE TIMING CAN NOT BE
ADJUSTED(some of engine
ignition timing can not be adjusted),
PLEASE CHECK THE RELEVANT
COMPONENT
IGNITION TIMING

NOTICE !
z DO NOT USE THE SCAN TOOL TO CHECK THE
IGNITION TIMING . THE IGNITION TIMING SHOWN IN
CURRENT DATA ON THE SCAN TOOL IS NOT
ACTUAL IGNITION TIMING BUT IT IS ELECTRICAL
TIMING .
IDLE SPEED ADJUSTMENT
PURPOSE

The engine running condition must be checked at the initial

stage of troubleshooting. During idle state, the RPM and
torque is low and the reaction of the engine may be easily
seen. Also, basic idle RPM may be checked and adjusted
during idle and various information regarding the effects of
a problem can be obtained.
IDLE SPEED ADJUSTMENT
CHECK CONDITION

z WARMING UP TEMPERATURE
z ALL ELECTRICAL LOADS OFF
z A/T : "P" OR "N"
z IGNITION TIMING IS NORMAL

CHECK PROCEDURE
1. LOOSEN THE ACCELERATOR
CABLE
2. INSTALL THE SCAN TOOL TO
THE DATA LINK CONNECTOR
IDLE SPEED ADJUSTMENT

CHECK PROCEDURE CHECK PROCEDURE

** DC MOTOR TYPE ** ** STEP MOTOR TYPE **

3. TURN THE IGNITION

3. IF THE SCAN TOOL IS NOT
SWITCH ON(DO NOT START)
USED, CONNECT A
AND LEAVE IT IN THAT
TACHOMETER,
POSITION FOR 15 SECONDS
OR LONGER. 4. GROUND THE NO. 15 PIN
4. TURN THE IGNITION OF THE 16 PIN DATA LINK
SWITCH OFF AND CONNECTOR(NO. 10 PIN OF
DISCONNECT THE ISC THE 12 PIN CONNECTOR)
MOTOR CONNECTOR
 DATA LINK CONNECTOR

12 PIN 16 PIN
CONNECTOR CONNECTOR
5 4 3 2 1 1 2 3 4 5 6 7 8
12 11 10 9 8 7 6 9 10 11 1213 14 15 16
IDLE SPEED ADJUSTMENT
CHECK PROCEDURE

5. GROUND THE IGNITION

TIMING ADJUSTMENT
TERMINAL
6. START THE ENGINE
7. CHECK THE IDLE RPM
IDLE SPEED ADJUSTMENT
CHECK PROCEDURE
8. IF THE BASIC IDLE SPEED IS OUT OF SPECIFICATION,
ADJUST THE IDLE SPEED BY USING THE IDLE SPEED
ADJUSTING SCREW AFTER CHECK ING IGNITION TIMING
AND CARBON BUILD UP.

IDLE RPM CANNOT BE

ADJUSTED MANUALLY IN
THE SOME OF ENGINES.
THEREFORE, IF THERE IS
A PROBLEM IN RPM,
ACQUISITION
COMPONENTS SHOULD BE
CHECKED.
THROTTLE POSITION SENSOR
PURPOSE

The Throttle Position Sensor(TPS) senses the throttle

position and has a significant influence on the ignition timing
and RPM. The corresponding output voltage of the throttle
position must be checked and adjusted accordingly.
THROTTLE POSITION SENSOR
CHECK PROCEDURE-EXCEPT IDLE SWITCH INTEGRATED TYPE

APPLICABLE VEHICLE :
EXCEL, ELANTRA(95MY),
SONATA(EXCEPT V6)

1. CONNECT SCAN TOOL TO THE

DATA LINK CONNECTOR
2. TURN THE IGNITION SWITCH TO
THE ON POSITION (DO NOT
START) AND CHECK THAT THE
TP SENSOR OUTPUT VOLTAGE IS
480mV - 520mV
THROTTLE POSITION SENSOR
CHECK PROCEDURE-EXCEPT IDLE SWITCH INTEGRATED TYPE
3. IF IT IS OUT OF SPECIFICATION, MAKE CORRECT
ADJUSTMENT.
THROTTLE POSITION SENSOR
CHECK PROCEDURE-IDLE SWITCH INTEGRATED TYPE

1. CONNECT THE SCAN TOOL

2. CHECK CURRENT DATA WHILE THE THROTTLE LEVER
OPERATION
3. THE THROTTLE POSITION SENSOR DATA SHOULD BE
INSIDE OF SPECIFICATION WHEN THE IDLE SWITCH IS
ON
4. IF NOT, ADJUST IDLE SWITCH FIRST. CHECK THE
CURRENT DATA OF THROTTLE POSITION SENSOR
5. IF THE CURRENT DATA IN NOT WITHIN THE
SPECIFICATION AFTER ADJUSTMENT OF IDLE SWITCH.
REPLACE THROTTLE POSITION SENSOR
FUEL PRESSURE TEST

PURPOSE

A correctly functioning fuel system is essential for the engine

to run smoothly. The fuel pressure test may be used to
determine the conditions of fuel pipe, fuel hose, fuel filter,
fuel pressure regulator, fuel pump and return hose.
FUEL PRESSURE TEST
CHECK PROCEDURE
1. REDUCE THE INTERNAL PRESSURE OF THE FUEL
PIPES AND HOSES
(DISCONNECT THE FUEL PUMP CONNECTOR START THE
ENGINE AND TURN THE IGNITION SWITCH "OFF" AFTER IT
STOPS BY ITSELF CONNECT THE FUEL PUMP CONNECTOR)
2. INSTALL A FUEL PRESSURE GAUGE AND A FUEL
PRESSURE GAUGE ADAPTER
FUEL PRESSURE TEST
CHECK PROCEDURE
3. START THE ENGINE AND CHECK THAT THERE IS
NO FUEL LEAKAGE
4. DISCONNECT THE VACUUM HOSE FROM THE
PRESSURE REGULATOR AND PLUG THE HOSE
END. MEASURE THE FUEL PRESSURE
5. MEASURE THE FUEL PRESSURE WHEN THE
VACUUM HOSE IS CONNECTED TO THE PRESSURE
REGULATOR
FUEL PRESSURE TEST
SUSPECTED ITEMS
z FUEL PRESSURE TOO LOW -
FUEL FILTER, FUEL PRESSURE REGULATOR, FUEL PUMP
z FUEL PRESSURE TOO HIGH -
FUEL PRESSURE REGULATOR, RETURN HOSE OR PIPE
z FUEL PRESSURE DROPS SLOWLY AFTER ENGINE
HAS STOPPED -
INJECTOR LEAKAGE
z FUEL PRESSURE DROPS IMMEDIATELY AFTER ENGINE
HAS STOPPED -
CHECK VALVE OF THE FUEL PUMP
VALVE CLEARANCE ADJUSTMENT
MECHANICAL LASH ADJUSTER

Shim

Tappet
VALVE CLEARANCE ADJUSTMENT
VALVE CLEARANCE CAN BE ADJUSTED BY SHIM.
PROCEDURE
1. SET NO1 CYLINDER TO TDC COMPRESSION
2. CHECK TDC POSITION OF CAMSHAFT
3. MEASURE THE CLEARENCE FOR
#1 INTAKE VALVE, EXHAUST VALVE
#2 INTAKE VALVE,
#3 EXHAUST VALVE
4. TURN THE CRANK SHAFT ONE REVOLUTION
5. MEASURE THE CLEARENCE FOR
#2 EXHAUST VALVE,
#3 INTAKE VALVE
#4 INTAKE VALVE, EXHAUST VALVE
VALVE CLEARANCE ADJUSTMENT

6. IF THE VALVE CLEARENCE IS NOT WITHIN THE

SPECIFICATION, REPLACE THE ADJUSTING SHIM
SPECIFICATION (20C)
INTAKE 0.12 ~ 0.28mm
EXHAUST 0.2 ~ 0.36mm
USE SPECIAL TOOLS TO REPLACE ADJUSTING SHIM
7. SEE THE ADJUSTING SHIM SELECTION CHART
VALVE CLEARANCE ADJUSTMENT

SHIM
SHIM SELECTION
SELECTION CHART
CHART
FOR
FOR INTAKE
INTAKE VALVE
VALVE
SHIM
SHIM SELECTION
SELECTION CHART
CHART
FOR
FOR EXHAUST
EXHAUST VALVE
VALVE
TIMING BELT ALIGNMENT
PURPOSE

The function of the timing belt is to mechanically connect the

crankshaft and camshaft so the action of the valves(opening
and closing) becomes dictated by piston movement.

Note :
If the timing belt of SIRIUS DOHC becomes misaligned or cut,
damage may occur in the cylinder head or the valves.
TIMING BELT ALIGNMENT
PURPOSE

The function of the timing belt is to mechanically connect the

crankshaft and camshaft so the action of the valves(opening
and closing) becomes dictated by piston movement.

Note :
If the timing belt of SIRIUS DOHC becomes misaligned or cut,
damage may occur in the cylinder head or the valves.
TIMING BELT ALIGNMENT
EXCEL, ELANTRA 1.5L, SCOUPE, ACCENT 1.5L & 1.3L, ATOS

TENSION
TIMING BELT ALIGNMENT
ALPHA DOHC ENGINE - ACCENT 1.5 DOHC

CAMSHAFT
CAP MARK

CAMSHAFT
SPROCKET
TIMING BELT ALIGNMENT
BETA ENGINE - ELANTRA(96MY)

CAMSHAFT
CYL. CAP MARK
HEAD
CAMSHAFT
SPROCKET
TENTIONER

TIMING CHAIN
TIMING BELT ALIGNMENT
SONATA DOHC

Check the balance shaft position

TIMING BELT ALIGNMENT
SONATA SOHC

Check the balance shaft position

TIMING BELT ALIGNMENT
SONATA SOHC

Timing belt B
TIMING BELT ALIGNMENT
EF SONATA 2.5L

Tensioner
Pulley
Idler
Pulley
TIMING BELT ALIGNMENT
XG 3.0L
TIMING BELT ALIGNMENT
SONATA(Y-3) V6

260-380N(57-84lbs)
 TIMING BELT ALIGNMENT OMEGA 4.5
1. Align the camshaft timing mark on camshaft cap timing mark
TIMING BELT ALIGNMENT OMEGA 4.5

2. Align the sprocket timing mark and camshaft timing mark

... ...
TIMING BELT ALIGNMENT OMEGA 4.5
3. Align timing mark between sprocket and head(Left bank)

.
TIMING BELT ALIGNMENT OMEGA 4.5

4. Align timing mark between sprocket and head(Right bank)

TIMING BELT ALIGNMENT OMEGA 4.5
5. Align timing mark between crankshaft sprocket and front case
TIMING BELT ALIGNMENT OMEGA 4.5
6. Install the timing belt as following order
Check the timing mark after 8 rotation of crankshaft

TIMING BELT ALIGNMENT OMEGA 4.5

Checking the timing mark on the vehicle

TIMING BELT ALIGNMENT OMEGA 4.5

Checking the timing mark on the vehicle
