Systemic Project Management

How to Master
Complex Projects
Systemic Project Management

with KNOW-WHY
and the MODELER / PROCESS MODELER
Kai Neumann
Kai Neumann: How to Master Complex Projects

please think for the environment before printing this e-book
Note: this e-book needs to be revised by a native speaker - we will send you the latest version automatically
Content:
What causes projects to fail?

3
Established project management methods

7
KNOW-WHY-thinking: what are the crucial factors ?

8
Qualitative Modeling using the KNOW-WHY-method

11
Quick-start: thinking creatively about a project

12
Insight Matrix: insights through rough assumptions

18
Quantitative Modeling: possible developments of the project in scenarios

21
Complex challenges - example 1: resource outages

27
Complex challenges - example 2: the learning curve and quality issues

29
Complex challenges - example 3: the impact of specification changes

30
Worst, best and most likely scenarios due to complex challenges

32
So it just takes the MODELER and KNOW-WHY ?

35
Further informationen
37
Consideo GmbH

Maria-Goeppert-Str. 1 23562 Luebeck, Germany

Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32

info@consideo.com www.consideo.com

Kai Neumann: How to master complex projects

How to master complex projects

Projects fail because the crucial interrelationships where not taken into consideration
Most projects fail because the crucial interrelationships that exist in a given project are
either not taken into consideration or their possible effects are grossly underestimated.
But even if we have the necessary insights regarding these connections, successful
project management still depends on our being able to clearly communicate our
insights to others and also on our acting according to them.
When we use cause and effect models we can foresee most of the possible effects that
these interrelationships will have. If we do not model, we will come up against our
mental limits, and we will negligently rely on our limited gut feelings.
By applying KNOW WHY Thinking, we can identify the crucial factors that exist in a
complex situation. This also means that we can systemically predict the success of a
given project.
With the help of the CONSIDEO PROCESS MODELER, we can run scenarios to
determine the effects that complex interrelationships in a project might have.
KNOW WHY Thinking, modeling and the project teams awareness of all dynamics at
hand result in systemic project management.
What causes projects to fail?

According to studies1 between 50 and 87 percent of all projects do not come in on
time, on budget, and on quality. This is the reason that project management has been such
a booming topic during the last few years, and also why there are so many new tools,
methods and training courses on offer. However, recent studies show no signs of
improvementdespite all of these measures.
The reason that so many projects still fail is due to the fact that these tools and methods
do not
help to identify the various events and dynamics that may arise during the course of a
project on account of the complex interrelationships at hand.
You will certainly agree that in almost all cases the reason that projects fail is due to the
fact that effects have been underestimated or because crucial factors have been
overlooked.
A systemic approach to management, however, holds the promise of helping executives to

manage in complex environments. Nevertheless, even after more than 50 years of
systems theory and systems thinking, only a handful of managers know aboutand speak
ofsystems thinking. And only a few actually apply it. This is most likely due to its rather
1 http://spatialnews.geocomm.com/features/mesa1/
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


3 / 38

complicated theories and the need for sophisticated computer software to foresee
complex developments.
Together with Consideo, I have simplified systems thinking and developed a software tool
that can be used on a daily basis. My concept of KNOW WHY Thinking, the software
CONSIDEO MODELER, as well as the CONSIDEO PROCESS MODELER are so easy to
use that hundreds of schools and universities around the world use it today to teach
systems thinking to our future decision makers.
KNOW WHY Thinking asks that you determine which crucial factors exist within a
complex challenge, e.g. in a project. Such factors include all kinds of different incidents,
which can trigger dynamics that may at some point become decisive. If we visualize the
interrelationships that exist between the factors in a computer model using the
CONSIDEO MODELER, we can analyze their effects. We can either model them very
quicklyqualitativelyusing rough assumptions, or quantitatively using both
mathematical descriptions of the intercorrelations and concrete data to run scenarios on
a given projects possible developments.
The following illustrations2 demonstrate the principle behind systemic project

management:
Think first - then act!
The extra effort you invest in visualizing and analyzing the various interrelationships that
exist in your project before you actually begin with it will minimize the likelihood of
encountering problems and delays as your project progresses.3
2 These illustrations stem from my experiences while coaching the state governments of Hamburg and Schleswig Holstein in Germany as they
planned a multimillion euro project that would introduce a new IT solution. Before the project began, we built a model of the requirements, the
dynamics that the use of the new software would create and of both the hard and soft factors of its implementation, as well as the
organizational changes that would ensue.
3 Thinkingabout all of the various factors that exist in a creative and systemic wayby using KNOW WHY Thinkingcan be described as taking
a holonic or holarchic approach, which is a combination of holistic thinking and reductionist modeling of cause and effect structures. I provide
an in-depth explanation of this approach in my book entitled KNOW WHY: gain insight - get success (2010).
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


4 / 38

Pic 1: The longer a project takes to complete, the more unwanted incidents may occur,
which will result in higher costs.
Pic. 2: Although the start of a project will initially be delayed due to applying KNOW
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


5 / 38

WHY Thinking and cause and effect modeling, it will be completed earlier and risks will be
minimized.
The project that I use as an example in this e-book could just as well have been undertaken by
a company in the service, software or machine tool industry. In this case, the company in
question is an automotive supplier of illumination components. The company is considering
getting involved in an additional project to utilize the resources that were set free by the crisis
in the automotive sector. It was offered the opportunity to produce a new gadget for a supplier
of fitness devices called a Squeeze Pear. This item is the size of a pear and customers squeeze
it to alleviate their frustration or anger. The force of their squeeze is indicated on a nanometer
display or by a different number of lights turning on.4
Here are some examples of complex challenges that may arise from various
interrelationships that exist in a given project:
The aim of the project and its benefits have been misinterpreted. It turns out
that even doing the project makes little sense. During the course of the
projectoften without the continued support of managementemployee
motivation will decrease significantly, and not just for this one individual project.
(Example: a renowned oil company invests roughly one million dollars a day over
an 18-month period to implement a major ERP software solution before
everyone realizes that they have chosen the wrong tool).
Making specification changesregardless of whether these changes could have

been prevented or notmay lead to expensive stockpiles of unusable unfinished
products. The change will, of course, cause employee frustration, and in many
cases employees may even have to undergo time-intensive retraining.
Wrong and/or late deliveries from suppliers teach us important lessons on how
to prevent this from happening in the future. However, it is important to note
that it is seldom simply the delay of a delivery that creates a problem, but rather
the resulting chain reaction. E.g. follow-up processes must be postponed to a
time when the resources are actually needed for other processes, which means
that the overall delay will exceed that of the original delay caused by the late
delivery. (Example: when Terminal 5 at the London Heathrow Airport opened,
personnel training had started too late, and this had disastrous consequences on
baggage handling).
Possible resource outages require that we calculate buffer times. The challenge is
to identify both the reasons for the resource outage and have countermeasures
ready for such a situation. Otherwise, for example, we risk buffers that are too
short to lead to a lucrative project or too long to remain competitive in a
bidding process.
4 the idea for this and similar products I have first published in my German book Modelst du schon - oder tappst du noch im Dunkeln?
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


6 / 38

Loss of competence if employees leave the team. The challenge here, too, is to
identify the reasons that have made employees decide to leave and have
countermeasures ready for such a situation.
The trap of multitasking: parallel to the current project at hand, resources are
also needed for other projects and tasks as well. The challenge is to minimize
multitaskingor to at least make sure to consider its effects during the planning
of a new project.
Another classic challenge: bottlenecksor constraints, as E. M. Goldratt refers to

them in his theory of constraints (ToC). In any project or process there are
resources that are constantly in use, so called constraints, that limit the overall
throughput. We can quicken a process or project only by identifying the
constraints and by removing them if possible. Another challenge that results from
bottlenecks is minimizing stockpiles resulting from resources that have not been
fully utilized: the non-constraints.
Insufficient quality checks that result in rising follow-up costs. It is, of course,
necessary to differentiate between errors that do not cause any additional costs
and errors that result in the need for repeating process stepswhich is both
time and cost-intensive as it will probably also block running processes.
Decreased employee motivation that lowers performance. The challenge is not

only to know what motivates your team but also how to detect any diminishing
motivation. This is important because less motivated employees have a negative
influence on other members and actually serve to lower motivation within the
entire team.
Underestimating the complexity of a projects environment. (e.g. the escalating

development costs at Boing and Airbus)
Please take a minute to think about some publicly known or smaller projects that did not
come in on time, on budget, and on quality. What were the reasons for this? I am pretty
certain that the causes somehow can be explained with underestimating the complexity
of the project, with one or more unforeseen developments and with the fact that certain
factors had been left unconsidered. You will probably agree with me when I suggest that
itat least in theorywould have been possible to devote some attention to all of these
causes before embarking on the projectat least before they began playing a role in it.
The standard methods and tools used within project management only implicitly address
these causes.
Established project management methods

The following measures and methodsat least in theoryare widespread within
management:
Improving project preparation
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


7 / 38

Improving communication
Improving the planning of project step sequence (critical path or critical chain)
Improving the allocation of resources
Making quality controls mandatory
Applying knowledge management to secure and share competencies
Applying methods, such as the water fall, the V-model, the agile, the scrum and
the XP method, etc.
Applying the theory of constraints (ToC)
Etc.
I imagine that neither being faced with complex challenges nor applying the
aforementioned measures are new to you. However, neither one of these lists is
exhaustive. It is also important to note that not every point will be applicable to every
project. Furthermore, the measures that are adopted strongly depend on the mentality of
the project team at hand.5
The challenge, therefore, is to identify all of the challenges that exist in a given project
case-by-case, as well as any further project risks at hand, and also to develop concrete
measures that the project team is able to execute. Recognizing the unique
interrelationships that exist in each and every complex project will result in systemic
project management. But yet another challenge still remains: finding a way to not just think
and speak about systemic project management, but to actually establish it as a new culture
of thinking, working and communicating in your project team.
In order to help you to identify both potential risks and successful countermeasures, I will
now explain the method of KNOW WHY Thinking. I will then present you with cause and
effect modeling that uses the CONSIDEO MODELER and the CONSIDEO PROCESS
MODELER. These tools can be used to foresee both the impact of project risks and the
effectiveness of various measures. Finally, I will give you some advice on how to motivate
your team to adopt systemic project management.
KNOW-WHY-thinking: what are the crucial factors ?

Allow me to now give you a brief overview of KNOW WHY Thinking and the KNOW
WHY Method.
To begin with, I developed both because I concluded that in most cases the existing
systems theories do not explain why somethingbe that an enterprise, a product, a
project, a communication strategy, or a policy, etc.is successful or unsuccessful. In my
mind, these theories only provide descriptions of a given systems behavior, but do not
5 P. Hamilton describes in Dynaxity how the application of scrum and other agile project management methods depend on a teams mentality.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


8 / 38

give explanations as to WHY. Apart from this, for most managers they remain much too
complicated to establish in actual planning and decision-making processes. And although
many claim to be systems thinkers, frankly only a handful actually do more than simply
announce that it is necessary to see interconnections and that hierarchies within
organizations need to be flattened so that they function like self-organizing, living
organisms, as defined by cybernetics.
KNOW WHY Thinking also follows cybernetics, but it does not seek to determine fixed
structures, but rather to find a general pattern of success:
According to KNOW WHY, success depends on two things: integration and

development. This is to say that any given thing must be able to both become integrated
into the environment that it is in and also to develop as the environment that it is in
changes or in order to remain competitive.
Integration and development - both are needed to avoid failure
This meta-systemic principle and pattern of evolution can be applied to explain the
success of everything from enterprises to politics, strategies, products, human relationships
and even texts (such as this one), etc Although this may sound a bit trivial to you,
believe me when I say that this simple fact can be extremely powerful when reflected
upon on a daily basis.
We can easily think about our challenges and the environment that we are in with the
help of the so-called KNOW WHY Wave:
Pic 3: The KNOW WHY Wave is an iconographical depiction of the surrounding

environment of a given thingwhere it lives or has been placed into. The higher
something is positioned on the wave, the more successful it is. Of course, the wave is
constantly in motion. Any given thing is therefore required to continue developing in order
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


9 / 38

to ascend on the waveensuring that it gains more success or that it just keeps up with
the waves movement. However, if a given thing develops without at the same time also
integrating into its environment it may suddenly slide off the wave. The end result: no
success at all.
Human behavior, too, can be directly linked to this pattern. We are motivated by our
feelings, and every feeling we have causes us to either integrate or to develop. Allow me
to give you an example: every gadget we buy gives us a sense of development. Being a fan
of something, or being a part of a group or something larger than ourselves gives us a
feeling of integration. Interesting is also that there is no emotion in our lives that cannot be
explained without referring to either integration or development.
It is amazing how we can improve our planning, our decision-making and even our view of
the world if we just become conscious of exactly where something is located on the
KNOW WHY Wave. Coming back to the example I used before, the automotive
suppliers project in relation to the wave might look something like this:
First off, it is a given that the project is positioned somewhere on the wave. One
important question that needs to be asked right off is what the economic goal of
the project is. If the project is able to attain this goaland remain profitable both
today and tomorrowit will stay on top of the wave. If the project does not
hope to earn a profit until the distant future, its position on the wave will be well
beyond the top of itwith the very good possibility of sliding away from it. Such
a project may end up quickly losing the support of the team involved, because
the members will not feel any success in the present. This means that the project
lacks integration. However, if the long-term goal of the project is integrated into
the overall company strategyand this strategy is made known to the project
teamboth the project and the strategy will be positioned together (integrated)
at the top of the wave.
Another question that needs to be asked is what the economic, technological

and organizational conditions are? Is the project integrated by the capacities or
the company?
On the other hand crucial questions to ask are the following: does this project
mean that we will develop? Will it help us to grow? Or might it possibly be an
area we do not really want to be involved in anymore?
Are the resources integrated? Might the project cause too much development
for the resources overextending them? The employees, of course, need to feel
integrated into the team and believe that the project makes sense.6
How are the milestones integrated into the overall project? And how do they
develop? Have the milestones been chosen arbitrarily? Can they change based
on how the project develops?
6 I describe the need to feel integratedand all that it entailsin detail in my book entitled KNOW WHY: gain insight - get success.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


10 / 38

You might also think that the following aspect is trivial, but truly it is not. Please think of a
problem that you have experienced while working on a project in the past. You can even
think of a project that failed entirely. I am certain that it is possible for you to describe the
problem or the failure of the project using KNOW WHY Thinking, i.e. the project either
lacked integration or it lacked development. If you do not think it is possible to think
about a cer tain project in these ter ms, please send me an email at
neumann@consideo.com describing your specific example and I will analyze it for you
using KNOW WHY.
Qualitative Modeling using the KNOW-WHY-method

If you tell me that applying KNOW WHY Thinking to projects needs to be done in a
more precise and sophisticated way, I agree with you completely. In fact, it is for this very
reason that we should always apply KNOW WHY Thinking in combination with the
MODELER 7aka the KNOW WHY Method.
On the one hand, the KNOW WHY Method helps us to think creatively about the crucial
factors involved in a given project and also to systematically build a model. On the other
hand, it gives us the chance to interpret a model that shows us both the integration and
the development of a given factor.
The KNOW WHY Method is fairly simple. All you have to do is place a factor in your
model and then list which factors either cause or hinder the integration of this factor to
the left of it, and which factors either cause or hinder the development of that factor to
the right of it. In the center, right above the factor, you should place those factors that
cause both integration and development. I will illustrate how this is done in the following
section.
Once you have done this for one factor, you should place more factors in your model and
continue as I described abovein most cases using submodels to ensure that even very
large models always offer a clear overview.
For some factors it is also often helpful to place a picture of the KNOW WHY Wave in
the background.
The automotive supplier from the previous example has a difficult decision to make
regarding the complex project the company is contemplating to take on. Will it be a
successful endeavor? How will the project influence core business? Does the company
have the technical and engineering expertise to do the job successfully? What are the risks
involved?
It is common practice for many companies to make these kinds of decisions by simply
asking their engineers if they feel up to the task. This is, of course, after the economic
7Every year the Verein Deutscher Ingenieure (Association of German Engineers) publishes a list of world champions from Germany. In 2009
and also in 2010, the MODELER was named the leading tool for visualizing and analyzing complex situations.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


11 / 38

aspects of a given project are taken into consideration. What will the project cost? At what
volume will it become profitable?
As far as the automotive supplier is concerned, the companys capacities had not been
fully utilized during the crisis, so the decision is made to go ahead with the project.
We will take a look at where this will lead them.
Please note: there will not be one correct way to model a given scenario. This is because
there are so many different ways to reflect on a situation. But never forget, every model
you create will take you further than if you had not modeled at all.
Quick-start: thinking creatively about a project

And now back to the automotive company. It has determined that the total benefits of
the project Squeeze Pears is a main factor and places this as the first factor in the model.
The company team then brainstorms what factors influence both the integration and
development of this factor. The first answers that they come up with are, of course,
factors that describe whether or not the product can be developed and manufactured by
them, and also if it will be profitable.
Especially when you beginning to model, it is important to think of as many factors as

possiblenot only considering the most common ones, which are hardly ever the
underlying reasons that a project will fail. Using KNOW WHY means asking what factors
will influence a project in the near future, and what the affects of those factors might be.
This method ensures that not only profitability will be considered, but also strategic
benefits and the possibility that capacity will be limited when the core business rebounds.
The company members continue to brainstormlooking for everything that might

influence both the integration and development of the factors. What is the manufacture of
the Squeeze Pears dependent on? Will this change over time? What things influence both
short-term and long-term profitability? And so forth
To then clearly show what the positive and negative effects on the project are, they place
the factor Manufacture of Squeeze Pears at the top of the model, showing the effects it
has on the factor Total benefits of the Squeeze Pears project.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


12 / 38

Pic. 4: An example of the first level of a qualitative model for the automotive company. It
applies the KNOW WHY Method and shows the interrelationships that exist in the
project.
Since some members in your team might find the terms integration and development
too abstract, you should consider asking the questions differently as well:
What causes something to integrate and what hinders it?
What is something dependent on and what needs to be eliminated?
What are the conditions like today? What obstacles are there?
What will conditions be like tomorrow? What risks are there?
How will something develop? Can it develop? Is it required to develop?
What will be different tomorrow?
Already at this first level of modeling, the automotive supplier can develop a gut feeling
about whether or not the project is integrated, whether it will help the development of
the company and if there are any imbalances at hand that may lead to failure:
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


13 / 38

As far as development potential is concerned, the company is positioned beyond

the crest of the wave. This means that the engineers will probably need
additional training. The project asks for too much development.
Regarding the ability to manufacture the product, the company is positioned

right at the top of the wave. Some minor adaptations need to be made, but
there is no reason that they could not easily be able to produce it on their
assembly lines.
The profitability of the project is positioned far away from the top of the wave.
This is on account of the fact that this job is just too small to be called a major
development.
As far as the companys strategy with regard to this project is concerned, it is

positioned beyond the crest of the wave. This is due to the fact that the project
is not integrated into their current business strategywhich is to be the leading
supplier of illumination technology for the automotive industry.
The company can continue to reflect on the project in this mannerapplying a

combination of gut feeling and KNOW WHY Thinking. However, it is important to note
that for a project of this size it would be grossly negligent to rely on gut feelings.
Therefore, it is pertinent that the company continue to model the interrelationships that
exist in the project using submodels:
Pic.5: Submodels are used to add even hundreds of factors for a more detailed model. The
Model Explorer on the left shows you the structure of the submodels.
The example I show here is a submodel that shows the reflection on the factor Ability to
develop. Of course such a model depends on the knowledge of the engineers. It is also
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


14 / 38

necessary to find a manufacturer for the prototype. Alternatively, the development of the
product could be arranged via a supplier or an external engineering service.
The following submodel shows that it is not all too important if you place a factor to the
left or to right of the KNOW WHY Wave to indicate the effect it has on development or
integration in a given model. The factor Contracting a university or engineering service
has in this submodel been placed to the right of the wave, but it could just as well have
been placed to the left of it as an alternative to the factor Engineers expertise. During
the reflection process, the company members asked themselves what would happen if
they were not able to develop the product, and in order to show the development of
their cability to do so, they placed this factor to the right of the wave.
Pic. 6: Submodel for the integration and development of the factor Capability to develop.
One vital factor that must be considered has been disregarded in this submodel: the use
of the product. The deficiencies that a product have are often not discovered until after
the first generation or the first production batch. The engineers are also usually forced to
admit that these deficiencies could have been avoided had they paid more attention to
these aspects of the product before it was manufactured. When you apply KNOW WHY,
it will help you to think of a whole host of factors, e.g. the different ways that a given
product can be used, the parts that are susceptible to damage, possible material abrasion,
safety issues, etc.
Although I do not address the subject of Idealized Systems Design in his e-book, I would
like to briefly mention that it also uses KNOW WHY Thinking and facilitates reflection on
the use of a product. Applying Idealized Systems Design means that we do not simply go
ahead and develop products, but rather begin by thinking what some ideal science
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


15 / 38

fiction solutions might be. We take these unrealistic solutions and successively modify
them using KNOW WHY until we come up with a feasible solution.8
Let us now take a look at some other submodels for the factors Ability to manufacture
and Strategic benefits:
Pic. 7: The submodel of Capability to produce
8 See KNOW WHY: gain insight, get success.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


16 / 38

Pic. 8: The submodel of the effects that the project will have on the business strategy.
I will not present any further submodels here. You can show cause and use trees for any
factor to see the interrelationships that exist across submodels:
Pic. 9: The cause tree of the factor quality problems
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


17 / 38

The cause and effect model contains a number of feedback-loops: reinforcing feedback-
loops (R-loops) have an increasing impact and balancing feedback-loops have a decreasing
impact.
Pic. 10: Feedback-loops cause the dynamic of the interrelationships
Reflecting on a project in the way that I describe here already serves to improve many
projects. This is because one is made aware of more aspects involved in the project and
these can then be communicated. The MODELER not only allows you to visualize the
interrelationships, but also to analyze their implications as well.
Insight Matrix: insights through rough assumptions

To identify short- and long-term measures or potential risks we can roughly weight the To
identify both short-term and long-term business measures or potential risks, we can
roughly weight the effects that the factors will have on each other. Already these rough
assumptions will lead to concrete insights that most likely go way beyond any gut feelings.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


18 / 38

Pic. 11: The weighting of the effects
When we roughly weight interrelationships using the attributes strong, middle and
weak, or any percentage value, we refer to this as qualitative modeling. This is opposed
to quantitative modeling, where we are required to describe all effects using data and
formulas.
The project I have described here is but one example of a possible business scenario.
Nevertheless, please take a minute and use your gut feeling to think of what the crucial
factors involved in the success of this project might be.
After you have done this, we can qualitatively analyze any factor in the model using the so-
called Insight Matrix. On the x-axis we see the short-term impact that the other factors
will have on the factor we have selected to analyze. On the y-axis we see the possible
change in impact that the factors may have over the long-term due to feedback loops. If
these factors are on the upper right, their impact might be increasingly positive, and if they
are on the lower right, they might be decreasingly positive. If they are on the upper left,
they might be decreasingly negative and if they are on the lower left, they might be
increasingly negative.
The ability to do qualitative modeling and to use the Insight Matrix are unique selling
points of the MODELER. Doing both is extremely powerful not only because they give
you very quick results, but also because it is simply fascinating how the rather fuzzy
qualitative weighting of effects leads to a robust analysis of a complex situation. This
method is also very useful because even opposing parties can easily agree on rough
weightings, while the analysis of concrete figures and data might end up causing long and
tedious discussions. If participants of a group modeling agree on a common model is also
called mental modeling.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


19 / 38

Pic. 12: The Insight Matrix for the factor Total benefit of Squeeze Pears project (without
and with zoom)
The Insight Matrix shows that the blue factor number 20 is slightly positive on the x-axis
and considerably positive on the y-axis, which means that manufacturing the Squeeze
Pears will only have slight short-term benefits for the company, but that the potential does
exist that the benefits will increase in the long run. The positions of the other factors in
the Insight Matrix indicate whether they contribute to the success of the project or
appear to put it at risk.
The matrix also makes clear, for example, that team motivation plays a decisive role. To
many members of your team and/or the management this may sound trivial, but now you
can prove to them just how important it is by showing them the use tree of the factor
motivation or the cause trees of other factors.
It is also apparent that factor number 23Quality problemshas a negative impact on

the overall success of the project. If you then switch to the Insight Matrix of Quality
problems, you will see that Team motivation has a negative impact on Quality problems
and therefore a positive impact on the overall project. Please refer to Pic. 13.
The example that I provide here may sound trivial to you, but using the Insight Matrix will
help you to both determine and communicate the role that many crucial factors play in
your projects. It also helps you to decide which measures you need to take to either make
your project a success (positive impact), or which scenarios you must avoid (negative
impact).
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


20 / 38

In many projects, especially the soft factors, such as motivation, communication and
learning curves, etc. are left ignored, despite the fact that they are often decisive to the
overall success of the projects.
Pic. 13: Insight-Matrix of the factor Quality problems
Quantitative Modeling: possible developments of the project in scenarios

Qualitative modeling showed the company what the decisive factors of the project were
and also made clear that the project would have some short-term success, but that the
long-term benefits looked more promising. The company therefore decides to model the
project quantitatively as well. They opt to model the actual costs of the project and the
price they need to ask from the supplier of fitness devices for the project to be profitable.
They start by modeling the processes using just the information they would use within the
application of MS-Excel or an MS-Project. The PROCESS MODELER, by the way, also
allows you to import MS-Project files.
It is advisable to use submodels for all models that have more than 20 factors. For
processes and projects, it has also been proven valuable to use a submodel for each
project (or process) step, as well as for each resource. Factors used in other submodels
will in these cases become so-called external factor copies. They are indicated by a
frame. When you use submodels, you can even create models that have thousands of
factors.
And the resources can be used to model several steps involved in a project or in the
different processes of a project. If you look at the submodel of the resource itself, you can
see where it has been used by its connections to external copies of process steps. You can
compare this view to that of swim lane diagrams.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


21 / 38

Pic. 14: Submodels for the process/project steps
Pic. 16: Example of a submodel of a resource
Compared to the MODELER, the PROCESS MODELER also features some additional
types of factors. You can connect processes, resources and milestones and spare yourself
the use of sophisticated formulas. The process factors have their own dialogue window to
set the parameters for the need and duration that each of the connected resources
needs in order to process one unit of the process step.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


22 / 38

Pic. 15: Resource- and process-factors and the parameters of a process step
The PROCESS MODELER takes this information and calculates the shortest possible
duration of a project depending on the availability of the resources that are needed. This is
the so-called critical chain,9 implying that the buffer-times for the individual steps are
removed from them and added to the end of the project instead. This also means that
each project step starts as early as possible, even if it is not a critical one.
Even more settings can be selected:
The sequence of process steps follows the list of priorities, but if a process step
cannot start because a resource is not available, the next step in the list will try
to start.
It is also possible to define whether it is a project with a one-time run or a

process that starts and stops at certain numbers of accumulated items.
Finally, we can combine resources by using AND and OR. If we use OR, the
program will try to use the resource on the left first.
Since the PROCESS MODELER features the same functionality as the MODELER, we can
combine process and resource factors with ordinary factors. This makes it possible to
describe the dynamics at hand, e.g. of learning curves or project costs.
9 E. M. Goldratt, Critical Chain.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


23 / 38

The following illustration shows the formula editor for ordinary factors. Using the formulas
is just as easy (or difficult) as with Excel. You can use if-then-else formulas, as well as
calculate the mean, the max, the min and random, etc.:
Pic. 18: An example of a formula
To run simulations, you can set up any number of cockpits using tables, diagrams and
manipulators. This enables you, for example, to see the utilization of resources, the levels
of finished or semi-finished products, or the dynamics of costs, quality, etc.
Following the principles of the Theory of Constraints (ToC),10 you want to reduce the
strain placed on the fully utilized resourcesonly by improving this will there be an overall
improvementand minimize stockpile levels along the process chains. These levelswith
the exception of those found at the end of a project, of coursealways indicate
suboptimal processesas they imply storage costs, tied up capital, and the risk of losing
capital in the event that they have to be discarded due to one or more specification
changes.
As the following illustrations of cockpits show, the automotive supplier should easily be
able to manufacture Squeeze Pears on an ongoing basis. The core business would remain
a priority, but the project would serve to optimize the utilization of the companys
resources.
10 E. M. Goldratt, The Goal.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


24 / 38

Illustration 22 shows the profitability and the early break-even the project can achieve if
the actual costs of the project are taken into considerationcompared to the break-even
the project will reach at a later time if the market prices for the use of the resources is
taken into consideration. To clarify the break-even or the reach of the targeted profit, a
comparison value can be added to the diagram (the red and the green base line in Pic.
22).
Pic. 19: The project processes
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


25 / 38

Pic. 20: The amounts of semi-finished and finished products
Pic. 21: The utilization of resources
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


26 / 38

Pic. 22: The profitability of the project under ideal circumstances
It is clear to see that the project becomes lucrative at a price of 15,000 EUR for each
production batch. This price can be changed using the slide manipulator (see Pic. 22) to
compare different scenarios.
Complex challenges - example 1: resource outages

It is fairly simple to calculate the resource outage caused by employee vacations. But it can
be quite a challenge to take possible sick days or other reasons for outages into
consideration without using a simulation model.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


27 / 38

Abb. 23: Submodel for production workers
With the MODELER, you can easily run Monte Carlo simulations on the likelihood of e.g.
sick days. If the likelihood that one employee will stay home from work due to illness is 5
percent, then the likelihood that one out of 4 employees will stay home on any given day
goes up to 20 percent. And the likelihood that 2, 3 or even 4 employees will stay home
on the same day steadily decreases. Illustration 24 shows you one way how to model this.
The MODELER not only gives you the possibility of calculating likelihoodswhich you
could also do with Excelbut also the chain reactions caused by outages in a complex
project. If you face outages of your constraints then the whole process will be delayed. But
also non-constraints can turn into constraints if they remain unavailable long enough. In
many cases the sequence of project steps will be disrupted and the resources needed at a
certain time may be tied up elsewhere. In such a case, the entire project will be delayed
for much longer than just the outage time(s) caused by one resource.
And this does not even take into account that employee outages have an effect on both
the workload and the motivation of the other employees, which causes reinforcing
feedback loops.11
11Consideo was hired by the Munich airport for a fairly large project. We modeled the soft factors, such as motivation, communication, etc. and
then their reinforcing feedback loops. As a result of this, we then developed a kind of dynamic balanced scorecard and identified the successful
countermeasures to lower the number of sick days. A report of this project (in German) can be found at: http://www.consideo-modeler.de/
papers.html.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


28 / 38

Pic. 24: The likelihood of sick days: there is a likelihood of 80 percent that there will be no
outage(s), but there is a 20 percent likelihood that one to four employees will take sick
leave.
Complex challenges - example 2: the learning curve and quality issues

Looking at the famous recalls in the automotive industry or the quality issues we
experience when we purchase cheap products, it seems only logical that the company I
have been using as an example must calculate a buffer for possible quality issues and
product returns. This, of course, also applies to companies that offer services and/or
manufacture high-quality products as well.
It is wrong to simply accept inferior quality or ignore quality issues. However, there are
many things to consider since the cost calculation of your offer could end up being too
high to win a contract, or the actual project costs might cause the project to fail overall.
Also the loss of reputation caused by an inferior product or service might serve to hurt
your company more. Therefore, you should use KNOW WHY to come up with measures
that will keep quality issues to a minimum.
It is always cheaper to think before going into production than fixing what went wrong
afterward!
Aside from quality controls and integrating ones suppliers into manufacturing processes,
motivation, as well as learning curves and/or the fatigue curve, too, play a crucial role in
the quality of a product or service. The following illustrations will show you the basic way
of modeling this.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


29 / 38

Picture 14 already demonstrated that product returns add to the pre-assembly of the
production process. The pre-assembly of incoming orders is delayed and the final assembly
and delivery costs arise a second time.
Pic. 25: A freehand sketch of a learning-curve that decreases from 20 to 0 percent.
The simulation will show that theres a big difference whether I assume just an average
error rate or a decreasing one. The higher returns at the beginning have a major impact
on the running processes!
In this case the error rate is given. We can also model the likelihood of errors and their
normal distribution using Monte Carlo simulation, which allows you to see the best, the
worst and the most likely case scenarios.
Complex challenges - example 3: the impact of specification changes

Although systemic reflection on the possible use(s) of a product or the possible problems
that might occur during production, etc. should minimize the likelihood of needing any
specification changes (see Ill. 2), we should know what the implications will be if it does
happen anyway.
Let us assume that a specification change means that an assembly line has to be
reorganized and that we have to exchange vendor parts, too. In real life, this situation
would have to be scrutinized more closely. In this illustration, the specification change
causes the milestones Completed product development, Complete assembly line and
Complete organization of parts from suppliers to go to 50, 60 and 70 percent, which
means that all production will stop until the milestones reach 100 percent again. A
specification change in and of itself is defined by an if-then-else function that is dependent
on the number of finished production batches.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


30 / 38

Pic. 26: A specification change as a submodel of product development.
Pic. 27: A decreasing likelihood of the need for a specification change for the first 10
production batches.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


31 / 38

Worst, best and most likely scenarios due to complex challenges

I have not modeled all possible complex challenges of this project, but rather shown you different ways of how
it can easily be done.12
Now, after we have included the complex challenges in our model, it should not come as a surprise that the
15,000 EUR per production batch we calculated earlier will not result in a profit for the company. Before we
look at what amount would, Id like for you to contemplate which amount would lead to a profitfollow your
gut feeling or base your answer on your best practice experiences.
Unfortunately, both globalization and growing competition keep us from being able to add a fixed surcharge to
our calculations. If we were to add one, our competitors might either have made an offer that is much lower,
meaning that we will not win the contract, or that our surcharges to buffer the risks are low enough to win the
contract, but our competitors anticipated the risks and we still not make a profit.
It is no wonder that it has become crucial for project-orientated enterprises to have tools and methods that
can calculate the risks of their projects in an appropriate way. However, most of the tools on the market that I
know of that can do this do not take the complexity and the dynamics of individual projects into consideration.
So what scenarios do our automotive supplier face?
Pic. 28: A Monte Carlo simulation of the profitability of the project. The spaghetti plot
shows that with 15,000 EUR per production batch no curve reaches a positive value. The
histogram shows a most likely loss of 250,000 EUR by the end of the next year.
12 If you have some concrete examples in mind that you do not know how to model, please post your questions in our MODELER forum.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


32 / 38

The Monte Carlo simulations in this example ran 100 times to combine the different
likelihoods of any quality issues, specification changes or employee outages. To see what
problems led to each of the individual spaghetti curves all you have to do is select the
simulation that you wish to inspect from their context menu. It becomes easy to see that
the reason for the losses is not just the utilization of resources or the fact that we have
constraints due to outages:
Pic. 29: This cockpit shows bad case scenarios of the utilization of resources and is taken
from the Monte Carlo simulation. The employees are a constraint some of the time.
It is rather the combination of quality issues, resource outages and specification changes
that has led to the negative scenarios for the project.
15,000 EUR per batch will guarantee financial loss for the company, but if the price is
increased incrementally, the risks of loss can be decreasedand even eliminated.
Another option for the company is to increase the number of resources, but not even this
can guarantee a break even.
A more promising option is to minimize the likelihood of quality issues and specification
changes from cropping up.
The next illustrations show that an increase to 25,000 EUR per batch promises a profit.
However, the company will still not be able to deliver the number of Squeeze Pears
agreed upon.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


33 / 38

Pic. 30: Scenarios for a selling price of 25,000 EUR
Pic. 31: Example of a simulation run chosen for a very positive Monte Carlo curve. More
than a third of the delivered parts from suppliers remain unused as the number of
delivered Squeeze Pears rises only slightly.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


34 / 38

There are many more scenarios imaginable. For our automotive supplier, gaining insight
into the complexity of the project and seeing the possible outcomes is extremely
beneficial. The regular use of KNOW WHY Thinking and the MODELER facilitates
organizational learning13 and even improves the accuracy of gut feelings.14
So it just takes the MODELER and KNOW-WHY ?

So far I have shown you that it is possible to identify the crucial factors of a given project
using KNOW WHY Thinking, and also that it is quite easy to overcome the complexities
at hand with qualitative modeling. It is also even fairly easy to run scenarios on the
likelihoods of the possible developments of a project.
The insights that are gained are your key to success. But it takes more than just a single
project manager to gain these insights. Project teams need to adopt an entirely new
culture of working, thinking and communicating. The collective intelligence of a team
contributes with crucial factors while applying KNOW WHY Thinkingwhich, by the way,
makes the team members feel integrated and causes project integration as well. Without
good communication within a teamespecially regarding insights that go beyond gut
feelingsno one would be able to implement the decisions made by the project
manager. The project would have development without integration!
It is not advisable that you try to model a quantitative model in a large group. It is better if
one or two people take on the task of gathering data and parameters, and then later the
other team members join in to run the scenarios on the model. A qualitative model, in
turn, can be easily modeled with a large group. However, the first time the group models
together, it might be challenging to handle notorious objection raiserspeople who have
a dislike for applying methods, especially new ones. I suggest that you ignore any
discussions of the tool itself and/or the method, and simply focus on the factors that
should be considered, as well as discuss what would serve to both benefit and hinder the
positive outcome of a project. In doing so, you should only use KNOW WHY Thinking
implicitly. As a moderator, you should ask your team to contribute their ideas and you will
see just how enthusiastic they will become once they see these ideas in a cause and effect
model.
Nonetheless, you may come up against team members who still dislike the extra effort
that has to be made when consciously reflecting on a projects complexity. You should tell
them about Ashbys law of variety15 which states that the number of possible conditions
a project can have has to be met by an appropriate number of possible states a project
team can have, if the project is to be a success. This includes mental states, too. Therefore,
13 P. Senge, The fifth discipline: the art & practice of the learning organization.
14 G. Gigerenzer, Bauchentscheidungen, M.Gladwell, Blink and K. Neumann, KNOW WHY: gain insight - get success. Most of our gut feelings
come from the experiences we have had with cause and effect phenomena. Therefore, modeling cause and effect structures increases our
intuitive intelligence.
15 I also explain this law in KNOW WHY: gain insight - get success.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


35 / 38

scenarios on possible developments are crucial to complex project management. This also
explains why it is so important that an organization have flat (or at least multidimensional)
hierarchies. It facilitates good communication and ensures that even minor factors are
addressed during the planning and decision-making process.
However, flat hierarchies and a high degree of freedom have been known to be successful
measures for decades. Nevertheless, in many organizations these measuresas well as
agile project management methods seem impracticable. It is also the case that many
strictly managed organizations with rigidly structured project plans can work effectively,
too.
If I have successfully explained KNOW WHY Thinking, you will now fully understand that
two things are needed: a certain degree of structure to ensure integration and a high
degree of freedom to ensure development! Complex projects and enterprises will fail if
either integration or development is lacking for a longer period of time.
This rather abstract principle must be implemented by the management in real life
situations:
Team members that tend to merely integratemeaning that they are positioned
very low on the KNOW WHY Wave and simply wait for directions to be given
to themmust be motivated in such a way that they begin contributing to
development. If you get your entire teams to sit down in front of a model you
can ask them what factors they feel need to be included. If some members still
insist on staying quiet in the background, you should ask them directly if they
agree or disagree with a specific cause and effect structure in order to make
them feel that they too are responsible for the model. You should also praise
everyone who contributes, regardless of how short-sighted you might think that
their idea is. It gives you the opportunity to make the complexity of a project
clearer and also to teach your team members how to think ahead.
There are also team members who like to develop without becoming
integratedwhich means that they repeatedly go beyond the crest of the
KNOW WHY Wave and make changes that no one can really follow. These
individuals must be forced to justify their actions using the cause and effect
model.
In conclusion, those team members who have ideas that they can explain using a
modeleven if they do not know if these ideas could work and therefore they
are asking the team to comment on themare right on top of the wave, and
will not move beyond it because they are integrated in the team.
According to KNOW WHY Thinking, a project (as well as a project team and every
member of that team) is most successful when the team is integrated and developing.
If our automotive supplier did not integrate the engineers and the production workers
into the project team, the employees would probably become fearful that the company
was following some nonsensical or even nonexistent strategy and that it was in some sort
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


36 / 38

of crisis. The project would extend beyond the crest of the KNOW WHY Wave. But even
if a the decision and most of the planning has been made by management, it is still
possible to ask employees for their opinions and advice, which makes them feel
integrated.
Last but not least, you should use the features that the MODELER offers to document
your project, e.g. by including links to documents, description texts and even annotations
to track discussions. The model can tell you what changes have taken place in the project
environment.
Of course, it is not necessary to model extremely small projects, but it is easier to reflect
on a project using a qualitative model than it is to use conventional project management
software. It is definitely beneficial to think about where on the KNOW WHY Wave
different aspects of a project would be positioned.
However, if your qualitative model shows you that a project is only slightly beneficial to
the companyas was the case in the example I used with the Squeeze Pearsyou
should definitely take the time to model it quantitatively!
I hope I have shown you just how easy it is to reflect on the complexity of a project.
Nonetheless, it takes some effort and even quite a few soft skills to work and
communicate effectively within a team. This is the reason that many companiesand most
project managersfind it easier to rely on fixed schemes that can be followed as if
according to a book. Lists are made and principles taken from the past are followed,
without taking responsibility for the very specific complexity of the project at handnor
finding it necessary to communicate this to the team. Unfortunately, as long as KNOW
WHY Thinking and modeling are not commonly known, it will remain widely acceptable
to simply say that a project was too complex to be planned in advance.
To model and to reflect using KNOW WHY Thinking can be referred to as systemic
project management. Many systemic approaches to management regrettably remain nice
theories, but with systemic project management, you can start reflecting on any given
project as mentioned in this e-book immediately. Within only a few hours, you will be a
practitioner of systemic project management.
Further informationen
In the MODELER forum, you will find further examples and/or you can ask for help on
how to model some concrete challenges that you are faced with.
Well documented models are also available as templates in the MODELER-SHOP.
Books on Systemic Project Management:
Edward Yourdon: Death March
Kai Neumann: KNOW-WHY: gain insight - get success
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


37 / 38

Patrick Hamilton: Dynaxity
Books on systems theory and thinking:
M. C. Jackson: Systems Approaches To Management
D. Drner: Die Logik des Milingens
F. Vester: Die Kunst vernetzt zu denken
Books on modeling:
Kai Neumann CONSIDEO MODELER: Beyond Mind Mapping - systems

thinking and simulation for everyone
J. D. Sterman: Business Dynamics
For more information, please visit www.consideo.com.
Consideo GmbH


Tel.: +49(0)451-50 270 30 Fax: +49(0)451-50 270 32


38 / 38

Systemic Project Management

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Systemic Project Management

Uploaded by

Copyright:

Available Formats

How to Master

Systemic Project Management

please think for the environment before printing this e-book

What causes projects to fail?

Established project management methods

KNOW-WHY-thinking: what are the crucial factors ?

Qualitative Modeling using the KNOW-WHY-method

Quick-start: thinking creatively about a project

Insight Matrix: insights through rough assumptions

Quantitative Modeling: possible developments of the project in scenarios

Complex challenges - example 1: resource outages

Complex challenges - example 2: the learning curve and quality issues

Complex challenges - example 3: the impact of specification changes

Worst, best and most likely scenarios due to complex challenges

So it just takes the MODELER and KNOW-WHY ?

How to master complex projects

What causes projects to fail?

A systemic approach to management, however, holds the promise of helping executives to

The following illustrations2 demonstrate the principle behind systemic project

Think first - then act!

Making specification changesregardless of whether these changes could have

Another classic challenge: bottlenecksor constraints, as E. M. Goldratt refers to

Decreased employee motivation that lowers performance. The challenge is not

Underestimating the complexity of a projects environment. (e.g. the escalating

Established project management methods

Improving project preparation

Improving the allocation of resources

Making quality controls mandatory

Applying knowledge management to secure and share competencies

Applying the theory of constraints (ToC)

KNOW-WHY-thinking: what are the crucial factors ?

According to KNOW WHY, success depends on two things: integration and

Integration and development - both are needed to avoid failure

Pic 3: The KNOW WHY Wave is an iconographical depiction of the surrounding

Another question that needs to be asked is what the economic, technological

Qualitative Modeling using the KNOW-WHY-method

We will take a look at where this will lead them.

Quick-start: thinking creatively about a project

Especially when you beginning to model, it is important to think of as many factors as

The company members continue to brainstormlooking for everything that might

What causes something to integrate and what hinders it?

What is something dependent on and what needs to be eliminated?

What will conditions be like tomorrow? What risks are there?

How will something develop? Can it develop? Is it required to develop?

What will be different tomorrow?

As far as development potential is concerned, the company is positioned beyond

Regarding the ability to manufacture the product, the company is positioned

As far as the companys strategy with regard to this project is concerned, it is

The company can continue to reflect on the project in this mannerapplying a

Pic. 7: The submodel of Capability to produce

8 See KNOW WHY: gain insight, get success.

Pic. 9: The cause tree of the factor quality problems

Pic. 10: Feedback-loops cause the dynamic of the interrelationships

Insight Matrix: insights through rough assumptions

Pic. 11: The weighting of the effects

It is also apparent that factor number 23Quality problemshas a negative impact on

Pic. 13: Insight-Matrix of the factor Quality problems

Quantitative Modeling: possible developments of the project in scenarios

Pic. 14: Submodels for the process/project steps

Pic. 16: Example of a submodel of a resource

Even more settings can be selected:

It is also possible to define whether it is a project with a one-time run or a

9 E. M. Goldratt, Critical Chain.

Pic. 18: An example of a formula
