1. INTRODUCTION

This report represents the soil investigation works at Choa Chu Kang Drive.
The objective of the soil investigation is to obtain soil parameters for the foundation design.
Soil investigation at the site started on 20th December 2007 and finished by 27th January
2008.

2. SCOPE OF WORK

Soil investigation work included drilling, soil sampling, site testing and laboratory testing.

A total of five (5) nos. of boreholes were drilled. Site works included SPT test, collection of
SPT samples, disturb samples, and UD samples. Laboratory testing work included physical
properties of soil tests, Unconsolidated Undrained Triaxial Compression Strength Test and
Unconfined Compression Strength Test on rock samples.

SPT tests were carried out immediately after taking the undisturbed soil sample and
subsequently at an interval of 3m up to 100 blows/30cm were achieved. Generally,
boreholes were terminated after achieving SPT N values of 100 blows or upon
encountering rock. SPT samples were collected by split barrel sampler. Disturb samples
were also collected for soil type verification. At least 4 nos. of UD samples were collected
at each of the boreholes.
UD samples were tested for moisture content, bulk density and Unconsolidated Undrained
Triaxial Compression Strength Test and Mechanical Analysis for all the boreholes.

All UD samples were sent to Lab Services Private Limited.

3. METHOD STATEMENT

3.1 Site Investigation

Field works included Drilling, SPT test, Disturb and SPT samples sampling, and UD
samples sampling.

3.1.1 Drilling

Hydraulic feed rotary boring machine was used for drilling work. A cutting tool was
attached at the lower end of the drilling rod. Drilling was carried out by continuously
rotating the drilling rod and pumping mud water through hollow rods into the bottom of the
boreholes. The cutting was washed out to the ground surface by the water under circulation.

(1) KS07/URA-011
 KWANG SING ENGINEERING PTE LTD

3.1.2 Standard Penetration Test

SPT test was done in accordance with BS. 5930: 1999. SPT samples were collected for the
soil type identification.

Prepared the spilt barrel sampler, drive rod, and drive assembly. Clean out the borehole
carefully to the test elevation. Withdraw the drilling tools slowly. Lower the split barrel
assembly to the bottom of the borehole on the drive rods with the drive assembly on top.

Recorded the initial penetration under dead-weight and if penetration is over 450mm, record
the N value as zero. If less than 450mm, continue seating drive and test drive. The hammer
(63.5kg mass) was dropping free fall on to a drive head from a height of 760mm and
recorded the number of blows to achieve 150mm penetration or 25 blows whichever is first
reached as seating drive.

Count the number of blows required for a further penetration of 300mm and recorded as
penetration resistance (N) value. If the 300mm penetration could not be achieved in 100
blows, terminate the test drive and recorded the depth of penetration.

3.1.3 Undisturbed Sample Sampling

Undisturbed samples were collected by 75mm thin-wall sampler.

Borehole was flushed with water to remove the remnants left at the bottom of the borehole.
The depth of the borehole was measured. The sampling tube was lowered to the bottom of
the hole and jacked into the soil. After sampling tube was jacking into the soil of required
depth, sampler tube was taken out from the borehole, cleaned and sealed with wax at both
ends of the sampling tube. The sample identification was then labeled properly.

(2) KS07/URA-011
 KWANG SING ENGINEERING PTE LTD

3.2 Laboratory Testing

3.2.1 Moisture Content and Bulk Density Test

Moisture content and Bulk Density tests were tested in accordance with BS. 5930: 1999.

Initial weight of original sample was measured and dried in the oven under 105 to 1100C
until constant weight was achieved. The dry weight of sample was measured and the
moisture content was calculated.

(Weight of Wet Sample) (Weight of Dry Sample)

Moisture Content = Weight of Dry Sample

Bulk density is the ratio of mass over volume. Specimen was cut by the cutting ring and
the weight and volume was measured. Bulk density was calculated as follow:

Bulk Density = Weight of Sample

Volume

3.2.2 Unconsolidated-Undrained Shear Strength Test

Unconsolidated-undrained Shear Strength test was done in accordance with BS. 5930: 1999.

Soil samples were extruded from the UD sample tube into 38mm diameter sample tube.
Then, pushed out from the tube and cut top and bottom of the specimen to get 76mm length.
Lengths and weight of the specimens were measured.

Prepared specimens were set-up in the Triaxial cells. Placed the rubber membranes on the
specimens and sealed by the O-rings. Assembled the Triaxial cell, then fill up the cell with
water. Fit the proving ring and displacement transducer.

Three different cell pressures (0.5, , and 2 ) were chosen and applied the cell pressures
on the specimens with black pressure drainage lines were closed. Choose the strain rate that
failure stress achieved within a period of 5 to 15 min. Then started shearing on specimen at
constant strain rate up to deviator stress reached maximum or 20% axial strain was reached.

(3) KS07/URA-011
 KWANG SING ENGINEERING PTE LTD

After shearing, stop the test, taken out the specimens from the Triaxial Cells. Then,
recorded failure modes and measured the specimen moisture contents.

1) Axial Strain

= L
L0

L = Change in Height of Specimen

L0 = Initial Height of Specimen

2) Average Cross Sectional Area

A = Ao
1

Ao = Initial Average Cross-sectional Area of the specimen

3) Deviator Stress

1 - 3 = P
A

P = Measured Applied Axial Load

A= Average Cross-Sectional Area

4) Shear Strength

Cu = (1 - 3)

(4) KS07/URA-011
 KWANG SING ENGINEERING PTE LTD

4. RESULT OF SOIL INVESTIGATION

4.1 Sub-soil Condition

Six types of soil were encountered at this site. These were:-

1) sandy SILT
2) clayey SILT
3) silty CLAY
4) sandy CLAY
5) SILT
6) SILT with gravel

The top soil layers were mainly sandy SILT and clayey SILT.

The second soil layers were firm to very stiff sandy CLAY or sandy SILT.

Very stiff SILT with gravel was found only in BH4.

Bottom soil layers were very dense silty SAND.

Rock core of GRANITE was retrieved in BH1.

Details of soil layers can be seen in Borehole logs.
The borehole-logs and the Probable Soil Profile are attached in Appendix B.

4.2 Water Level Monitoring

No water standpipe was installed.

4.3 Laboratory Test Result

Laboratory tests were done on the undisturbed samples.

Based on the soil testing, moisture contents were found within the range of 273% to 60%,
and bulk densities were within 1.60Mg/m3 to 1.94Mg/m3. The cohesion values of the UU
tests vary from 19kN/m2 to 152kN/m2. The details were summarized in the laboratory test
result summary sheets.

Test results are attached in Appendix C.

(5) KS07/URA-011
 KWANG SING ENGINEERING PTE LTD

5. CONCLUSION

Seven types of soil and rock were encountered at this site. According to the Geological
Map of Singapore (PWD 1976) and the types of soil encountered, it may conclude that soils
of Bukit Timah Granite Formation were distributed in that area.

______________________________
Joseph C M Lee
BSc(Eng) C.E. MICE MIHE MHKIE
Managing Director

(6) KS07/URA-011
 APPENDIX A

LOCATION PLAN / BOREHOLE LOCATION PLAN

 APPENDIX B

PROBABLE SOIL PROFILE / BORELOG

 APPENDIX C

LABORATORY SOIL TEST REPORT
