WARNING -To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Do not allow to be used as a toy. Close attention is necessary when this appliance is used by or near
children.
2. Use this appliance only for its intended use as described in this manual. Use only the attachments
recommended by the manufacturer as contained in this manual.
3. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return the appliance to the nearest authorized dealer or
service center for examination, repair, electrical or mechanical adjustment.
4. Never operate the appliance with any air openings block. Keep ventilation openings of the sewing
machine and foot controller free from accumulation of lint, dust, and loose cloth.
5. Keep fingers away from all moving parts. Special care is required around the sewing machine needle.
6. Always use the proper needle plate, a wrong needle plate can cause the needle to break.
7. Do not use bent needles.
8. Do not pull or push fabric while stitching. It may deflect the needle causing it to break.
9. Switch the sewing machine off ("O") when making any adjustments in the needle area, such as
threading needle, changing needle, threading bobbin, or changing presser foot, and the light.
10. Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or when
making any other user servicing adjustments mentioned in the instruction manual.
11. Never drop or insert any object into any opening.
12. Do not use outdoors.
13. Do not operate where aerosol spray products are being used or where oxygen is being administered.
14. To disconnect, turn all controls to the off ("O") position, then remove plug from outlet.
15. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
16. The sound pressure level under normal operating conditions is 75dB(A).
17. Please turn off the machine or unplug when the machine is not operating properly.
18. Never place anything on the foot controller.
19. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
20. Children should be supervised to ensure that they do not play with the appliance.
Handle
Handwheel
Presser foot lifter
Power cord
Drop feed lever
1
Accessories
Standard
1 2 3 4
1. All purpose foot (T)
2. Zipper foot (I)
T I D E 3. Buttonhole foot (D)
006186008 006905008 006H1A0004 006907008 4. Overcasting foot (E)
5. Blind hem foot (F)
5 6 7 8 9 6. Satin stitch foot (A)
7. Button sewing foot
F A 8. Bobbin (3x)
006904008 006172008 006914008 006084009 R12373209 9. Spool holder (Large)
10 11 12 13 10. Spool holder (Small)
11. Spool pin felt
12. Second spool pin
TA10943209 006015009 006914008 006012008 13. Screwdriver (L & S)
14. Edge/quilting guide
14 15 16 15. Brush/ Seam ripper
16. Needle (3x)
006008001 006099008
Optional
17 18 19
17. Hemmer foot (K)
18. Cording foot (M)
K M P 19. Quilting foot (P)
006900008 006813008 006916008
20. Darning/ Embroidery foot
21. Gathering foot
20 21 22 22. Walking foot
23. Twin needle
24. Rigid cover
23 24 25
006020008
2
Connecting the machine to the power source
Caution: Always make sure that the machine is unplugged from power source and the main switch is
on ("O"). when the machine is not in use and before inserting or removing parts.
ON
OFF
To disconnect, turn the power switch to the off position, then remove plug from outlet.
3
Starting sewing
Start/stop button
The machine will start running when Start/stop
button is pressed and will stop when pressed the
second time.
The machine will rotate slowly at the beginning
of the sewing.
Foot control
With the sewing machine turned off, insert the
foot control plug into its connector on the sewing
machine.
Attention: Consult a qualified electrician if in doubt as how to connect the machine to the power
source. Unplug the power cord when the machine is not in use.
The appliance must be used with the foot controller C-9000 manufactured by CHIEN HUNG
TAIWAN., LTD.
4
Changing the presser foot
Attention: Turn power switch to off ("O") when carrying out any
of the below operations!
5
Type of presser foot chart
Darning/
Buttonhole foot (D) Embroidery foot
(Optional)
Note: The twin needle is optional. It is not include with the accessories.
When sewing with twin needle, the stitch width should be set at less than "5.0".
6
Replacing the needle
B Attention: Turn power switch to off ("O")
A when carrying out any of the above
operations!
9-11 (70-80) Lightweight fabrics-thin cottons, voile, serge, Light-duty thread in cotton, nylon,
silk, muslin, Qiana, interlocks, cotton knits, polyester or cotton wrapped polyester.
tricot, jerseys, crepes, woven polyester, shirt &
blouse fabrics.
11-14 (80-90) Medium weight fabrics-cotton, satin, Most threads sold are medium size
sailcloth, double knits, lightweight woollens. and suitable for these fabrics and
needle sizes.
14 (90) Medium weight fabrics-cotton duck, woolen,
heavier knits, terrycloth, denims. Use polyester threads on synthetic
materials and cotton on natural woven
16 (100) Heavyweight fabrics-canvas, woolens, outdoor fabrics for best results.
tent and quilted fabrics, denims, upholstery Always use the same thread on top
material (light to medium). and bottom.
18 (110) Heavy woollens, overcoat fabrics, upholstery Heavy duty thread, carpet thread.
fabrics, some leathers and vinyls.
Please Note:
- In general, fine threads and needles are used for sewing fine fabrics, and thicker threads are used
for sewing heavy fabrics.
- Always test thread and needle size on a small piece of fabric which will be used for actual sewing.
- Use the same thread for needle and bobbin.
7
Winding the bobbin
1. Place the thread and spool holder onto the spool pin.
For smaller spools of thread, place spool holder with the
small side next to the spool or use the small spool holder.
4. Place the thread end through one of the inner holes in the
bobbin as illustrated and place empty bobbin on the spindle.
8
Winding the bobbin
6. Hold the thread tail securely in one hand.
8. After the bobbin has wound a few turns stop the machine and
cut the thread near the hole of the bobbin. Continue filling
the bobbin until it is full. The motor stops automatically
when the bobbin is full. Stop the machine. Push the bobbin
winder spindle to left.
Please Note: When the bobbin winder switch is placed on the right, "bobbin winding position", the
machine will not sew and the handwheel will not turn. To start sewing, push the bobbin winder switch
to the left "sewing position".
9
Inserting the bobbin
Attention: Turn power switch to off ("O")
before inserting or removing the bobbin.
10
Threading the upper thread
5
7
8
Start by raising the needle to its highest point, and also raise
the presser foot to release the tension discs.
1. Lift up the spool pin. Place the spool of thread on the spool pin
so that the thread comes from the front of the spool, then place
the spool cap at the end of the spool pin.
2. Draw the thread from the spool through the upper thread
guide.
11
Threading the upper thread
3. Guide the thread around the thread guide pulling the thread
through the pre-tension spring as illustrated.
6. At the top of this movement, pass the thread from right to the
left through the slotted eye of the take-up lever and then
downwards again.
12
Using the needle threader
Attention: Turn power switch to the off
position ("O").
13
Thread tension
- Basic thread tension setting: "4"
- To increase the tension, turn the dial to the next number up. To
reduce the tension, turn the dial to the next number down.
- Proper setting of tension is important to good sewing.
- For all decorative sewing you will always obtain a nicer stitch
and less fabric puckering when the upper thread appears on the
bottom side of your fabric.
Upper thread
Bobbin thread
Reverse side
Thread tension is too loose for straight stitch sewing. Turn dial
to higher number.
Thread tension is too tight for straight stitch sewing. Turn dial to
lower number.
14
Raising up the lower thread
1. Hold the upper thread with the left hand. Turn
the handwheel towards you (counterclockwise)
lowering, then raising the needle.
15
Two-step presser foot lifter
The presser foot lifter raises and lowers your
presser foot.
Sliding the lever to the " " (b) will lower the
feed dog, for example during button sewing. If you
a
wish to continue sewing normally, slide the lever to
the " " (a) in order to raise the feed dogs.
The feed dog will not rise up if you do not turn the
b handwheel, even if the lever is slid to the right.
Make a complete turn to raise the feed dogs.
a
b
16
Function of machine
17
Function of machine
Needle up/ down position button (4)
With the Needle up/ down position button, you decide whether the
needle shall stop in the up position or in the material when you stop
sewing.
Please Note: During sewing, press the button will be no function.
Needle up/ down position button setting will only machine stop.
18
Function of machine
Stitch length adjustment lever (7)
When you select a stitch, the machine will automatically set the
recommended stitch length. The stitch length can be regulated by
sliding the stitch length adjustment lever.
Auto settings are easily determined by sliding the lever. The LED
indicator next to the lever will blink and beep 1 time to indicate the
setting is at the auto position.
When the setting is at the auto position, you can manually change the
length according to your preference. Starting at the auto position,
slide the lever to the left or right to locate each potential adjustment.
At each manual adjustment point, the LED will blink 3 times and
beep once.
To shorten the stitch length, slide the lever to left. For a longer stitch
length, slide the lever to right. The stitch length can be adjusted
between "0.0-4.5". Certain stitches have limited lengths.
19
Pattern chart
The portion marked in colored on the chart below shows the one unit of each pattern.
20
Useful skills
Sewing corners
1. Stop the sewing machine when you reach a
corner.
3 5 2. Lower the needle into the fabric manually or
2
by pressing the needle up/ down button once.
1 4 3. Raise the presser foot.
4. Use the needle as a pivot and turn the fabric.
5. Lower the presser foot and resume sewing.
Reverse
Reverse stitching is used to secure the threads at
the beginning and at the end of a seam.
Free arm
Free-arm sewing is convenient for sewing tubular
areas such as pant hems and cuffs.
21
Useful skills
Installing the extension table
* The Extension table accessory is optional. It is
not included with this machine.
Pull the sewing table and accessory box off by
sliding it to the left. (1)
B
A
3
22
Straight stitches and needle position
Zigzag stitches
23
Stretch stitch
Straight stitch
24
Overcasting stitches
Using the overcasting foot
5.0~7.0 2.0~3.0
T 2.5~4.5 2.0~3.0
25
Blind hem/ Lingerie stitch
11: Blind hem/lingerie for firm fabrics
12: Blind hem for stretch fabrics
2.5~4.0 1.0~2.0
26
Button sewing
2.5~4.5
27
Buttonhole stitching
17: For thin or medium fabric
5.5~7.0 0.3~1.0
Please Note: Before sewing a buttonhole on your project, practice on a scrap piece of the same type
of fabric.
Starting
point
28
Buttonhole stitching
Pull the buttonhole lever all the way down and
position it behind the bracket on the buttonhole
foot.
* Buttonholes are sewn from the front of the presser foot to the back, as shown.
17
18
19
29
Buttonhole stitching
Buttonholes are sewn from the front of the
presser foot to the back, as shown.
30
Darning stitch
20
D 3.5~7.0 1.0~2.0
31
Darning stitch
Pass the upper thread down through the
hole in the presser foot.
Pull down the buttonhole lever. The buttonhole
lever is positioned behind the bracket on the
buttonhole foot.
32
Zipper insertion
Attention: Zipper foot should be used for
sewing width center needle position straight
stitch only. It is possible that needle could
3.5 1.5~3.0 hit the presser foot and break when sewing
other patterns.
33
Zipper insertion
Inserting a side zipper
- Baste the zipper opening on the garment.
5mm
34
Narrow hemming
* The Hemmer foot accessory is optional. It is
not included with this machine.
3.5 1.5~3.0
35
Cording
Sew over one strand of cording to create a pretty swirled design on a jacket or vest or sew over three
strands of cording for border trims. Pearl cotton, knitting yarn, embroidery floss, lace thread, fine wool or
lily yarn can be used for cording.
* The Cording foot accessory is optional. It is not included with this machine.
Single cording
Triple cording
36
Satin stitch sewing
3.5~7.0 0.5~1.0
37
Quilting
3.5 1.0~3.0
Scallop stitch
T A
38
Gathering
Gathered fabric
Remove the presser foot holder and attach the
gathering foot, lowering the tension setting to
below 2.
Place fabric to be gathered under presser foot to
the right of the presser foot.
Sew a row of stitching, keeping the raw edge of
fabric aligned with the right edge of foot.
The stitches automatically cause the fabric to
gather. Suitable for light to medium weight
fabrics.
39
Smocking
40
Free motion darning, embroidery and monogramming
* The Darning/ Embroidery foot accessory is
optional. It is not included with this machine.
3.5~5.0
b
a
b
Darning
First sew around the edges of the hole (to secure
the threads). Working from left to right, sew over
the hole in a constant and continuous movement.
Turn the work by 1/4 and sew over the first
stitching moving the work slower over the hole
to separate the threads and not form big gaps
between the threads.
41
Free motion darning, embroidery and monogramming
Embroidery
Select zigzag stitch pattern and adjust the stitch
width as desired.
Stitch along the outline of the design by moving
the embroidery hoop. Make sure to maintain a
constant speed.
Monogramming
Select the zigzag stitch pattern and adjust the
stitch width as desired. Sew at a constant speed,
moving the hoop slowly along the lettering.
When the letter is finished. Secure with a
reinforcement stitches at the end by press Auto-
lock button.
42
Fagoting
Thin paper
Basting
Patchwork stitching
43
Twin needle
44
Walking foot
Always try to sew first without the walking foot accessory which should be used only when necessary.
It is easier to guide the fabric and you have a better view of the seam when using the standard, regular foot
on your machine.
Your sewing machine offers excellent stitch quality on a wide range of fabrics from delicate chiffons to
multiple layers of denim.
The Walking Foot accessory equalizes the feeding of the upper and lower layers of fabric and improves the
matching of plaids, stripes and patterns. It also helps to prevent uneven feeding of very difficult fabrics.
The Walking Foot accessory equalizes the feeding of the upper and lower layers of fabric and improves the
matching of plaids, stripes and patterns. It also helps to prevent uneven feeding of very difficult fabrics.
Lift the presser foot lifter to raise the presser foot bar.
Draw the bobbin thread up and place both the bobbin thread and
the needle thread behind the walking foot attachment.
45
Warning functions
Please Note: If the problem is still not solved, please contact your local dealer.
Attention: During the sewing, if the thread get jammed inside the hook stopping the needle from moving
and you continue pressing the foot control, the security switch will stop the machine completely. In order
to restart the sewing machine, you will have to turn the on/off switch to the OFF position and then ON
again.
Maintenance
Cleaning the sewing machine surface
If the surface of the sewing machine is dirty, lightly soak a cloth in mild detergent, squeeze it out firmly
and then wipe the surface. After cleaning it once in this way, wipe the surface again with a dry cloth.
Attention: This machine is equipped with a 100mW LED lamp. If lamp replacement is needed, please
contact nearest authorized retailer.
Attention: Disconnect the machine from the wall outlet before carrying out any maintenance.
46
Maintenance
Remove the needle plate cover and bobbin.
Clean the hook race, feed dog and bobbin case with a brush. Also
clean them, using a soft, dry cloth.
Replace the bobbin case into the hook race so that the tip (a) fits to
the stopper (b) as shown.
a b
47
Trouble shooting guide
Before calling for service, check the following items. If the problem still persists, contact the place of
purchase or your nearest authorized dealer.
Skipped 1. The needle is not inserted correctly. 1. Remove and reinsert needle(flat side Page 7
stitches towards the back).
2. The needle is damaged. 2. Insert a new needle. Page 7
3. The wrong size needle has been used. 3. Choose a needle to suit the thread. Page 7
4. The foot is not attached correctly. 4. Check and attach correctly. Page 5
5. The machine is not threaded correctly. 5. Rethread the machine. Page 11
Seam 1. The needle is too thick for the fabric. 1. Select a finer needle. Page 7
gather or
2. The stitch length is adjusted wrong. 2. Readjust the stitch length. Page 18
pucker
3. The thread tension is too tight. 3. Loosen the thread tension. Page 14
48
Trouble shooting guide
Patterns are 1. The correct presser foot is not used. 1. Select the correct foot. Page 20
distorted 2. The needle thread tension is too tight. 2. Loosen the thread tension . Page 14
The machine 1. Thread is caught in the hook. Remove the upper thread and bobbin case, turn Page 46
jams
the handwheel backwards and forwards by hand
2. The feed dogs are packed with lint. and remove the thread remands.
The 1. Fluff or oil have collected on the hook or 1. Clean the hook and feed dog as described. Page 46
machine is needle bar.
noisy
3. The needle is damaged. 3. Replace the needle. Page 7
4. Slight humming sound coming from 4. Normal. --
internal motor.
5. Thread is caught in the hook. Remove the upper thread and bobbin case, turn Page 46
the handwheel backwards and forwards by hand
6. The feed dogs are packed with lint. and remove the thread remands.
3. The machine is not plugged in. 3. Connect the power line plug to the electric Page 3
outlet.
49
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being.
When replacing old appliances with new once, the retailer is legally obligated to take back your old appliance
for disposal at least for free of charge.
!"#$% &'$()*#+
Bedienungsanleitung
Sehr geehrter Kunde!
WARNUNG - Zum Schutz vor Verbrennungen, Feuer, elektrischem Schlag oder Verletzungen
von Personen:
1. Verhindern, dass der Nhcomputer als Spielzeug verwendet wird. Erhhte Achtsamkeit ist geboten, wenn
der Nhcomputer von Kindern oder in der Nhe von Kindern benutzt wird.
2. Dieser Nhcomputer darf nur zu dem in der vorliegenden Bedienungsanleitung beschriebenen Zweck
benutzt werden. Es darf nur Zubehr wie in der vorliegenden Bedienungsanleitung beschrieben und vom
Hersteller empfohlen benutzt werden.
3. Den Nhcomputer nie benutzen, wenn ein Kabel oder Anschluss beschdigt ist, wenn er nicht richtig bzw.
strungsfrei funktioniert, nachdem er fallengelassen oder beschdigt worden oder mit Wasser in Kontakt
gekommen ist. Nhcomputer ins nchste autorisierte Fachgeschft oder Servicestelle zur berprfung,
Reparatur und zum Einstellen der elektrischen und/oder mechanischen Teile bringen.
4. Bei Gebrauch des Nhcomputers darauf achten, dass die Lftungsschlitze nicht blockiert sind.
Lftungsschlitze von Fusseln, Staub und Stoffrckstnden freihalten.
5. Finger von allen beweglichen Teilen fernhalten. Besondere Vorsicht ist im Bereich der Nhnadel geboten.
6. Immer eine korrekte zum Nhcomputer gehrende Stichplatte benutzen. Eine falsche Stichplatte kann zu
Nadelbruch fhren.
7. Keine krummen Nadeln verwenden.
8. Stoff beim Nhen weder ziehen noch stossen. Das kann die Nadel so weit biegen, dass sie bricht.
9. Nhcomputer ausschalten (Hauptschalter auf "O" stellen), wenn im Nadelbereich Ttigkeiten ausgefhrt werden,
zum Beispiel Einfdeln, Nadel wechseln, Greiferspule einsetzen oder Nhfuss wechseln und dergleichen.
10. Nhcomputer immer ausstecken (vom Stormnetz trennen), wenn Unterhaltsarbeiten wie in der
Bedienungsanleitung beschrieben, vorgenommen werden. Zum Beispiel, wenn Abdeckungen entfernt
werden, beim len oder Glhbirne wechseln usw.
11. Keine Gegenstnde in ffnungen am Nhcomputer stecken oder hineinfallenlassen.
12. Nhcomputer nicht im Freien benutzen.
13. Nhcomputer nicht benutzen, wo Treibgasprodukte (Sprays) oder Sauerstoff verwendet werden.
14. Zum Ausschalten alle Schalter auf ("O") stellen und Netzstecker herausziehen.
15. Kabel am Stecker herausziehen, nicht am Kabel ziehen. Beim Ausstecken immer am Stecker ziehen, nie am Kabel.
16. Der Schalldruckpegel unter normalen Betriebsbedingungen betrgt 75dB(A).
17. Bitte schalten Sie die Nhmaschine aus oder ziehen Sie den Stecker, wenn die Nhmaschine nicht
ordnungsgem funktioniert.
18. Platzieren Sie keine Gegenstnde auf dem Fuanlasser.
19. Dieses Gert ist nicht fr die Verwendung von Personen (einschlielich Kindern) mit reduzierten krperlichen,
sensorischen oder geistigen Fhigkeiten oder fehlender Erfahrung und Kenntnis vorgesehen, es sei denn, sie
werden beim Gebrauch des Gerts von einer fr ihre Sicherheit verantwortlichen Person beaufsichtigt oder
angeleitet.
20. Kinder sind zu beaufsichtigen, um sicherzustellen, dass sie nicht mit dem Gert spielen.
SICHERHEITSHINWEISE SORGFLTIG
AUFBEWAHREN
Dieser Nhcomputer ist nur den Haushaltgebrauch bestimmt.
Inhaltsverzeichnis
bersicht der wichtigsten teile am nhcomputer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Zubehr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Nhcomputer ans stromnetz anschliessen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Anfangen zu nhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ein/Aus Knopf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fuanlasser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Nhfuss auswechseln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Nhfusstabelle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Nadel wechseln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Passende nadel, faden und stoff whlen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Greiferspule fllen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Greiferspule einsetzen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Oberfaden einfdeln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Einfdler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Fadenspannung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Unterfaden heraufholen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Faden abschneiden . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2-stufen-nhfussanhebung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Transporteur heben und senken . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Funktionen der Maschine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-19
Ein/Aus Knopf (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Rcktransportknopf (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Automatisches Vernhen (3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Nadelstopp oben/unten (4). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Geschwindigkeitsregler (5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Stichbreitenregler (6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Stichlngenregler (7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Stichauswahlknpfe (8). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Stichbersicht . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Ntzliche anwendungen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21-22
Ecken nhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Rckwrts nhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Freiarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Tischverlngerung installieren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Auf dicken Stoffen nhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Geradstiche und nadelposition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Zickzackstiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Stretchstich . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Inhaltsverzeichnis
Kantenumnhstiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Kantenumnhfuss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Universalnhfuss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Blindsaum und lingeriestiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Knpfe annhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Knopflcher nhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-30
Knopflcher auf elastischen Stoffen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Stopfen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31-32
Reissverschluss einnhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33-34
Beidseitig verdeckt eingesetzter Reissverschluss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Einseitig verdeckt eingesetzter Reissverschluss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Schmalsumen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Schnuraufnhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Einzelschnur aufnhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Dreifachschnur aufnhen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Raupennhte . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Quilten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Muschelstich . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Kruseln. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Kruseln . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Kruseln und gleichzeitiges Annhen an ein glattes Stoffstck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Smoken. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Freihandstopfen, -sticken und -monogramme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41-42
Stopfen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Sticken. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Monogramme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Fagotten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Patchworkstich . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Zwillgsnadel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Obertransportfuss. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Warnfunktionen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Pieption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Spulerstift wieder nach links drcken . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Unterhalt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46-47
Oberflche des Nhcomputers reinigen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Greifer reinigen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Beheben von Strungen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48-49
bersicht der wichtigsten teile am nhcomputer
Fadenspanndrehknopf Greiferspulvorrichtung
Nadelstopp oben/unten
Geschwindigkeitsregler
Automatisches Vernhen
Rcktransport Stichbreitenregler
Stichlngenregler
Ein/Aus Knopf
Fadenabschneider Stichwahlknpfe
Knopflochhebel
Automatischer
Nadeleinfdler
Spulenabdeckung
Anschiebetisch Ausziehbare
und Zubehrbox Kurzanleitung
Griff
Handrad
Nhfusslifter
Hauptschalter
Netzkabel
Transporteur
Anschluss fr
Fussanlasser
1
Zubehr
Basiszubehr
1 2 3 4
1. Universalfuss (T)
2. Reissverschlussfuss (I)
T I D E 3. Knopflochfuss (D)
006186008 006905008 006H1A0004 006907008 4. Kantenumnhfuss (E)
5. Blindstichfuss (F)
5 6 7 8 9 6. Raupennahtfuss (A)
7. Knopfannhfuss
F A 8. Greiferspulen (3x)
006904008 006172008 006914008 006084009 R12373209 9. Garnrollenhalter (gross)
10 11 12 13 10. Garnrollenhalter (klein)
11. Filzkissen
12. Zweiten Garnrollenstift
TA10943209 006015009 006914008 006012008 13. Schraubenzieher (gross und
klein) (L & S)
14 15 16 14. Kantenlineal
15. Reinigunspinsel,
Pfeiltrenner
006008001 006099008
16. Paket Nadeln (3x)
Optional
17 18 19
17. Sumer (K)
18. Schnuraufnhfuss (M)
K M P 19. Quiltfuss (P)
006900008 006813008 006916008
20. Stopf-/Stickfuss
21. Krusler
20 21 22 22. Obertransportfuss
23. Zwillingsnadel
24. Abdeckung
23 24 25
006020008
2
Nhcomputer ans stromnetz anschliessen
Achtung: Immer sicherstellen, dass die Maschine vom Stromnetz getrennt und der Hauptschalter auf
("O") ist, wenn sie nicht im Gebrauch ist und bevor Sie Einzelteile einlegen oder entfernen.
EIN
AUS
3
Anfangen zu nhen
Ein/Aus Knopf
Die Maschine fngt an zu laufen, wenn die
Ein/Aus Knopf gedrckt ist und stoppt wenn Sie
sie noch einmal drcken.
Die Maschine rotiert am Anfang des Nhens ein
bisschen.
Fuanlasser
Fussanlasser bei ausgeschaltetem Nhcomputer
anschliessen.
Achtung: Falls Unsicherheiten bestehen betreffend Anschluss des Nhcomputers ans Stromnetz, bitte
qualifizierten Elektriker fragen. Nhcomputer bei Nichtgebrauch ausstecken.
Das Gert muss mit dem Fuanlasser C-9000 von der Firma CHIEN HUNG TAIWAN., LTD
betrieben werden.
4
Nhfuss auswechseln
Achtung: Hauptschalter ausschalten (auf OFF bzw. "O" stellen)
vor dem Ausfhren der oben genannten Operationen!
Nhfusshalter anbringen
a Nhfussstange hochstellen (a).
Nhfusshalter (b) wie abgebildet anbringen.
Nhfuss einsetzen
a Nhfusshalter (b) senken, bis die Aussparung (c) direkt ber dem Stift
(d) liegt.
e Befestigungshebel (e) nach oben drcken.
Nhfusshalter (b) senken und der Nhfuss (f) rastet automatisch ein.
c
b
d f
Nhfuss entfernen
Nhfuss hochstellen.
e Befestigungshebel (e) nach oben drcken und der Nhfuss lst sich.
Kantenlineal anbringen
Kantenlineal (g) wie agebildet durch die ffnung schieben. Je nach
g gewnschter Breite des Saums, der Falten usw. Einstellen.
5
Nhfusstabelle
Reissverschluss Schmalsumen
I
einnhen K
Knopfloch Stopfen
Freihandsticken
D Monogramme
Blindsaum Kruseln
Raupennaht
Obertransportfuss
A (Optional)
Raupennahtfuss (A)
Hinweis: Die Zwillingsnadel ist optional. Sie ist nicht im Lieferumfang enthalten.
Wenn Sie mit der Zwillingsnadel nhen, sollte die Stichbreite weniger als "5.0" sein.
6
Nadel wechseln
B Achtung: Hauptschalter ausschalten (auf
A OFF bzw. "O" stellen) vor dem Ausfhren
der folgenden Arbeiten.
11-14 (80-90) Mittelschwere Stoffe Baumwolle, Satin, Nessel, Die meist verkauften Fden sind von
Segeltuch, Doppelstrick, leichte Wollstoffe. mittlerer Strke und fr diese Stoffe
und Nadelstrken geeignet.
14 (90) Mittelschwere Stoffe Baumwollsegeltuch, Polyesterfaden fr synthetische und
Wollstoffe, dickerere Strickstoffe, Frott, Jeans. Mischmaterialien.
16 (100) Schwere Stoffe: Canvas, Wollstoffe, Zeltstoffe Baumwollfaden fr natrliche Gewebe.
und Quilts, Jeans, Polstermaterial (leicht bis Als Ober- und Unterfaden generell den
mittelschwer). gleichen Faden nehmen.
Hinweise :
- I.A., dnne Fden und Ndel fr dnne Geweben und dicke Fden und Ndel fr dickeGeweben.
- Immer Faden und Nadel auf einem kleinen Stck Gewebe probieren bzw. testen, das beim Nhen gebraucht
wird.
- Den gleichen Faden fr Nadel und Garnrolle benutzen.
7
Greiferspule fllen
8
Greiferspule fllen
6. Halten Sie das Fadenende mit der Hand fest.
Hinweis: Solange der Schalter des Garnrollenspulers auf linke Position steht "Garnrolle Wickelposition"
nht die Maschine nicht und dreht das Handrad auch nicht. Um nhen anzufangen, mu der Schalter
dann auf die rechte Position also "Nhposition" gestellt werden.
9
Greiferspule einsetzen
Achtung: Nhcomputer vor dem Einsetzen
oder Herausnehmen der Greiferspule
ausschalten (Hauptschalter auf OFF bzw.
"O" stellen).
10
Oberfaden einfdeln
5
7
8
11
Oberfaden einfdeln
3. Faden um die Fadenfhrung legen und durch die
Vorspannfeder ziehen, wie abgebildet.
12
Einfdler
Achtung: Nhcomputer ausschalten
(Hauptschalter auf OFF bzw. "O" stellen).
13
Fadenspannung
- Grundeinstellung Fadenspannung: "AUTO"
- Um die Spannung zu erhhen, Rad auf die nchst hhere Zahl
drehen.
- Um die Spannung zu reduzieren, Rad auf die nchst tiefere
Zahl drehen. Es ist wichtig, beim Nhen mit der richtigen
Fadenspannung zu arbeiten.
- Die Spannung muss je nach Stichart, Faden und Stoff angepasst
werden.
- 90 % aller Nharbeiten kann mit einer Spannung von zwischen
"3" und "5" ausgefhrt werden ("AUTO" ist die Grundeinstellung).
- Bei allen dekorativen Nharbeiten wird das Stichbild schner
und der Stoff fltelt weniger, wenn der Oberfaden leicht auf
die linke Stoffseite gezogen wird.
Oberfaden
Unterfaden
Stoffrckseite
14
Unterfaden heraufholen
Oberfaden mit der linken Hand festhalten.
Handrad gegen sich (im Gegenuhrzeigersinn)
drehen, Nadel senkt sich und hebt sich wieder.
Faden abschneiden
Nhfuss hochstellen. Stoff entfernen und die
Fden nach links zum Stnderkopf ziehen und
am Fadenabschneider abschneiden.
15
2-stufen-nhfussanhebung
Mit dem Nhfusslifter wird der Nhfuss gesenkt
und hochgestellt.
16
Funktionen der Maschine
Rcktransportknopf (2)
Wenn die Muster 01-16, 21-40 gewhlt sind, nht die Maschine
entgegengesetzt wenn der Rcktransportknopf bettigt ist. Sie nht
wieder vorwrts sobald der Knopf gelst worden ist.
17
Funktionen der Maschine
Nadelstopp oben/unten (4)
Mit der Nadelstopp oben/unten Knopf knnen Sie bestimmen, ob die
Nadel in der oberen Position oder im Stoff stoppt, wenn Sie das Nhen
beenden.
Bitte beachten: Whrend des Nhens ist diese Knopf auser Funktion.
Nadel hoch/runter Positions Knopf stoppt nur die Maschine.
Geschwindigkeitsregler (5)
Die Hchstgeschwindigkeit beim Nhen kann durch Verstellen des
Schiebereglers begrenzt werden. Die beim ganzen Durchtreten des
Fussanlassers erreichte Geschwindigkeit wird durch die Position des
Reglers bestimmt.
Langsam: nach links schieben
Schnell: nach rechts schieben
Beim Nhen mit der Ein/Aus Knopf wird mit der durch den Regler
festgelegten Geschwindigkeitsregler genht.
Stichbreitenregler (6)
Wenn Sie einen Stich auswhlen, stellt die Maschine automatisch die
empfohlene Stichbreite ein. Um die Stichbreite ein zu stellen,
knnen Sie den Stichbreitenregler verschieben.
Die Standardeinstellungen knnen einfach bestimmt werden durch
das Verschieben des Reglers. Die LED Anzeige neben dem Regler
blinkt und piept einmal um an zu zeigen, dass diese Einstellung die
Standardeinstellung ist.
Wenn die Standardeinstellung gewhlt ist, knnen Sie manuell die
Breite anpassen. Von der Standardeinstellung aus schieben Sie den
Regler nach links oder nach rechts um die gewnschte Anpassung
vor zu nehmen. Bei jeder Anpassungsstufe blinkt die LED Anzeige
drei Mal und piept ein Mal.
Fr einen schmaleren Stich schieben Sie den Regler nach links. Fr
einen breiteren Stich schieben Sie den Regler nach rechts. Die
Stichbreite kann zwischen "0.0 - 7.0" eingestellt werden. Einige
Stiche haben beschrnkte Stichbreiten.
18
Funktionen der Maschine
Stichlngenregler (7)
Wenn Sie einen Stich auswhlen, stellt die Maschine automatisch die
empfohlene Stichlnge ein. Um die Stichlnge ein zu stellen, knnen
Sie den Stichlngenregler verschieben.
Stichauswahlknpfe (8)
Stellen Sie das Gert ein und die LED Anzeige oberhalb des
Geradstiches leuchtet.
19
Stichbersicht
Der grn markierte Teil der unten abgebildeten Sticharten bezeichnet einen Rapport jeder Stichart.
20
Ntzliche anwendungen
Ecken nhen
1. Bei Erreichen einer Ecke anhalten.
2. Nadel senken in das Gewebe, entweder manuell
3 5 oder drcken Sie die Knopf von Nadel aufwrts/
2
abwrts einmal.
1 4 3. Nhfuss hochstellen.
4. Mit der Nadel als Angelpunkt Stoff drehen.
5. Nhfuss senken und weiternhen.
Rckwrts nhen
Rckwrtsnhen wird zum Vernhen zu
Nhbeginn und ende benutzt.
Freiarm
Freiarmnhen ist praktisch beim Nhen von
Rhrenware wie Hosensume und rmel.
21
Ntzliche anwendungen
Tischverlngerung installieren
* Der Tischverlngerung ist optionales Zubehr.
Er ist nicht im Lieferumfang enthalten.
B
A
3
Karton oder
dicker Stoff
22
Geradstiche und nadelposition
01 02 03 04 05
Nadelposition ndern
Diese Einstellungen knnen nur auf den Muster 01-05 anwenden.
Die Sticharten sind auf Nadelposition "3.5" voreingestellt.
Wenn Sie den Stichbreitenregler nach links schieben, bewegt
sich die Nadel nach links. Wenn Sie den Stichbreitenregler nach
rechts schieben, bewegt sich die Nadel nach rechts.
Stichlnge ndern
Um einen krzeren Stich zu nhen, schieben Sie den
Stichlngenregler nach links. Um einen lngeren Stich zu nhen,
schieben Sie den Stichlngenregler nach rechts.
Allgemein gesagt, je dicker das Gewebe, der Faden und die
Nadel ist, desto lnger mu der Stich sein.
Zickzackstiche
06 07 08 08
Stichbreite einstellen
Die maximale Stichbreite fr Zickzackstiche betrgt "7.0". Die
Stichbreite kann jedoch fr alle Sticharten schmler eingestellt
werden.
Die Stichbreite nimmt zu, wenn Sie den Stichbreitenregler von
"0.0 - 7.0" schieben.
Stichlnge einstellen
Die Stichdichte von Zickzackstichen nimmt zu, je nher die
Stichlnge zu "0.3" eingestellt wird.
Schne Zickzackstichbildungen erreicht man mit einer
Stichlnge im Bereich von "1.0 - 2.5".
Ganz dichten Zickzack (eng nebeneinander) nennt man
Raupennaht.
23
Stretchstich
03 04 08 08
T A
Geradstich
24
Kantenumnhstiche
06 09 Kantenumnhfuss
E
5.0~7.0 2.0~3.0
Kantenumnhfuss einsetzen.
07 10 Universalnhfuss
2.5~4.5 2.0~3.0
Universalnhfuss einsetzen.
Beim Kantennhen den Nhfuss so auf der
Stoffkante platzieren, dass die rechten
Nadeleinstiche knapp ber die Kante hinaus ins
Leere gehen.
25
Blindsaum und lingeriestiche
11 12 11: Blindsaum und Lingeriestiche auf festen
Stoffen.
12: Blindsaum auf Stretch-Stoffen.
F
2.5~4.0 1.0~2.0
Stoffrckseite Stoffrckseite
Kantenumnhstiche
Stoff umdrehen.
26
Knpfe annhen
06
2.5~4.5
Knopfannhfuss einsetzen.
a
Hebel zum Senken bzw. Heben des Transporteurs
auf " " (b) stellen, um den Transporteur zu
senken. (Hinweis: Die Stichlnge kann nicht
b verstellt werden, solange der Transporteur
versenkt ist.)
a
b
27
Knopflcher nhen
17 17: Fr leichte bis mittelschwere Stoffe
18: Fr leichte bis mittelschwere Stoffe
2.5~7.0 0.3~1.0
D
19: Fr Anzge, Mntel und Jacken
18
2.5~5.5 0.3~1.0
19
5.5~7.0 0.3~1.0
Hinweis: Vor dem Ausnhen des Knopflochs auf dem Nhgut, zuerst eine Probe auf einem Stoffrest
des gleichen Stoffs wie fr das Nhgut verwendet, nhen.
Anfangspunkt
28
Knopflcher nhen
Stoff so unter den Nhfuss legen, dass die Mitte-
Markierung auf dem Nhfuss mit der
eingezeichneten Knopflochlinie bereinstimmt.
Nhfuss senken.
* Knopflcher werden von der Vorderseite nach Hinterseite des Bglers genht, wie gezeigt.
17
18
19
29
Knopflcher nhen
Nhfuss hochstellen und Faden abschneiden. Um
ber das gleiche Knopfloch zu nhen, Nhfuss
hochstellen (kehrt in die ursprngliche Position
zurck).
Nach Beendigung Knopflochhebel heben, bis er
hlt.
30
Stopfen
20
D 3.5~7.0 1.0~2.0
31
Stopfen
Den Oberfaden durch das Loch in dem Nhfu
weitergeben. Den Knopflochhebel unterziehen
und dann zurckschieben. Der Knopflochhebel
ist am Knopflochfu hinter der Halterung. Das
Oberfadenende in der linken Hand vorsichtig
halten dann das Nhen beginnen.
32
Reissverschluss einnhen
01 Achtung: Reissverschlussfuss nur zum Nhen
mit der Nadel in der Mitte und Geradstich
verwenden! Bei Verwendung von anderen
I 3.5 1.5~3.0 Sticharten und mit anderen Nadelpositionen
als den empfohlenen kann es sein, dass die
Nadel auf den Nhfuss aufschlgt und bricht.
Nahtzugabe auseinanderbgeln.
Reissverschluss mit der Vorderseite so nach unten
auf die Nahtzugabe legen, dass die Zhnchen an
die Nahtlinie stossen. Reissverschlussband heften.
33
Reissverschluss einnhen
Einseitig verdeckt eingesetzter Reissverschluss
Reissverschlussschlitz auf dem Kleidungsstck
5mm heften.
34
Schmalsumen
01 * Der Sumer ist optional und nicht im
Lieferumfang dieser Maschine einbegriffen.
K
3.5 1.5~3.0
35
Schnuraufnhen
Eine oder drei Kordeln bernhen fr hbsche Strukturen auf Jacken oder Westen oder Bordren. Dazu
kann Perlgarn, Strickwolle, Stickgarn, Kordel, Hkelgarn usw. verwendet werden.
* Der Schnuraufnhfuss ist optional und nicht im Lieferumfang dieser Maschine einbegriffen.
06 Einzelschnur aufnhen
07 16 Dreifachschnur aufnhen
36
Raupennhte
06 21 22 23 24 25
A
3.5~7.0 0.5~1.0
37
Quilten
01 03
P 3.5 1.0~3.0
Muschelstich
34 22
T A
38
Kruseln
01 * Der Krusler ist ein optionales Zubehrteil.
Er ist in der Maschine enthalten.
3.5 4.5
Kruseln
Krusler einsetzen und die Fadenspannung auf
unter 2 stellen.
Den zu kruselnden Stoff rechts unter den
Nhfuss legen. Einmal durchsteppen, dabei die
Stoffkante parallel zur rechten Fusskante laufen
lassen.
Der Stoff wird nun automatisch gefltelt. Fr
leichte bis mittelschwere Stoffe geeignet.
Hinweis:
- Um die gewnschte Kruselstrke
herauszufinden, proben Sie am besten ber je
etwa 25cm Lnge am Stoff, Bordren oder
Gummiband. So knnen Einstellungen je nach
Wunsch einfacher vorgenommen werden.
Immer am gleichen Stoff und im gleichen
Fadenlauf wie nachher am Projekt proben.
Kruseln im Querfadenlauf ergibt hbschere
Falten als auf dem Lngsfaden.
- Nhen Sie langsam bis mittel schnell, um den
Stoff besser im Griff zu haben.
39
Smoken
15 16
T A
40
Freihandstopfen, -sticken und -monogramme
01 06 * Der Stopf-/Stickfuss ist optional und nicht im
Lieferumfang dieser Maschine einbegriffen.
3.5~5.0
b
a
b
Stopfen
Zuerst die Rissstelle einmal umnhen (um die
Gewebefden zu sichern): Von links nach rechts
mit bestndiger Geschwindigkeit und schn
regelmssig ber die Rissstelle nhen. Nhgut
um -Drehung drehen und die erste Stichlage
bernhen. Diesmal das Nhgut langsamer
bewegen, damit zwischen den Fden keine
grossen Lcken entstehen.
41
Freihandstopfen, -sticken und -monogramme
Sticken
Zickzackstich whlen und Stichbreite nach
Bedarf einstellen.
Dem Musterumriss entlang nhen, indem der
Stickrahmen entsprechend bewegt wird. Mit
gleichmssiger Geschwindigkeit arbeiten.
Monogramme
Zickzackstich whlen und Stichbreite nach
Bedarf einstellen.
Mit gleichmssiger Geschwindigkeit den
Buchstaben nach nhen.
Nhende nach einem Buchstaben mit
Vernhstichen fixieren durch Drcken der Auto-
Lock-Knopf.
42
Fagotten
14
Dnnes Papier
Heften
Patchworkstich
14 15 16 26
T A
43
Zwillgsnadel
* Der Zwillingsnadel ist optional und nicht im
Lieferumfang dieser Maschine einbegriffen.
T 2.0~5.0
Zwillingsnadel einsetzen.
Hinweis: Bei Verwendung von Zwillingsnadeln
sollte immer der universalfuss verwendet
werden, und zwar ungeachtet der Nhmethode.
Nur Zwillingsnadeln mit max. 2 mm
Zwischennadelabstand verwenden.
44
Obertransportfuss
01 * Der Obertransportfuss ist optional und nicht im Lieferumfang dieser
Maschine einbegriffen.
Generell zuerst ohne Obertransportfuss versuchen zu nhen. Er sollte erst eingesetzt werden, wenn
notwendig.
Mit blichen Nhfssen ist der Stoff leichter zu fhren und man hat eine bessere Sicht auf den Nhbereich.
Dieser Nhcomputer bietet hervorragende Stichqualitt auf sehr vielen Stoffen von zarten Chiffons bis
mehrlagigen Jeansstoffen.
Mit dem Obertransportfuss wird der Transport der oberen und unteren Stofflagen ausgeglichen und er hilft
beim exakten Zusammennhen von Karos, Streifen und Mustern. Er dient auch einem regelmssigen
Stofftransport auf sehr schwierigen Stoffen.
45
Warnfunktionen
Pieption
- Bei korrekter Anwendung: 1 Piep
- Bei falscher Anwendung: 3 Pieps
- Wenn die Nhmaschine ein Problem hat und nicht nhen kann: 3 Pieps
Es bedeutet, dass der Faden verdreht oder verklemmt ist und sich die Handradachse nicht bewegen kann.
Dann Seite 48/49 der Anleitung von Problembeseitigung bitte durchlesen um die Lsung dazu
herauszufinden. Sobald das Problem gelst worden ist, nht die Maschine weiter.
Hinweis: Sollte das Problem nicht gelst werden, wenden Sie sich bitte an Ihren Hndler.
Achtung: Whrend des Nhens, wenn der Faden in der Platine verklemmt wird und dadurch die Nadel
an Bewegung gehindert wird und Sie weiter die Fusteuerung drcken, schaltet der Sicherheitsschalter
die Maschine ganz aus. Um die Nhmaschine wieder zu starten, mssen Sie den Ein/Aus- Schalter aus
"Aus" und dann noch mal auf "Ein" drehen.
Unterhalt
Oberflche des Nhcomputers reinigen
Ist die Oberflche des Nhcomputers verschmutzt, weichen Lappen in Wasser mit wenig neutralem
Abwaschmittel tauchen, fest auswringen und damit die Oberflche reinigen. Anschliessend mit trockenem
Tuch ber die Oberflche wischen.
Achtung: Diese Maschine ist mit einer 100mW LED Lampe ausgestattet. Wenn Sie eine Lampe
auswechseln mssen, kontaktieren Sie bitte den nchsten authorisierten Riccar Hndler.
Greifer reinigen
Faden- und Stoffrckstnde im Greifer knnen dazu fhren, dass der Nhcomputer nicht mehr einwandfrei
funktioniert. Regelmssig nachsehen und bei Bedarf den Greiferbereich reinigen.
Achtung: Nhcomputer immer zuerst ausstecken (vom Stromnetz trennen), dann erst
Unterhaltsarbeiten daran ausfhren.
46
Unterhalt
Greiferdeckel entfernen und Spulenkapsel herausnehmen.
a b
47
Beheben von Strungen
Bevor die Nhmaschine wegen Strungen zur Reparatur gebracht wird, bitte Folgendes berprfen. Besteht das
Problem weiterhin, kontaktieren Sie die Verkaufsstelle des Gerts oder den nchsten autorisierten Fachhndler.
48
Beheben von Strungen
49
ENTSORGUNGSHINWEISE
Gebrauchte Elektro - und Elektronikgerte drfen gem europischer Vorgaben nicht mehr zum
unsortierten Siedlungsabfall gegeben werden.
In Deutschland sind Sie gesetzlich verpflichtet, ein Altgert einer vom unsortierten Siedlungsabfall
getrennten Erfassung zuzufhren. Die ffentlich-rechtlichen Entsorgungstrger (Kommunen) haben hierzu
Sammelstellen eingerichtet, an denen Altgerte aus privaten Haushalten ihres Gebietes fr Sie kostenfrei
entgegengenommen werden.
Bitte informieren Sie sich ber ihren lokalen Abfallkalender oder bei Ihrer Stadt - oder Ihrer
Gemeindeverwaltung ber die in Ihrem Gebiet zur Verfgung stehenden Mglichkeiten der Rckgabe oder
Sammlung von Altgerten.
ELEKTRISCHE KENNDATEN
Carina Comfort
100-240V 50/60Hz 70W
Schutzklasse II
Lampe
5V max. 100mW
!"#$#%!&!#'()' )*+,-.#!
/%01+%2/,34,56'$#!%)
