VPL SW536

DATA PROJECTOR
VPL-SW536
VPL-SW526
VPL-SX536
REMOTE COMMANDER
RM-PJ8
SERVICE MANUAL
1st Edition (Revised 1)
!
! WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
! WARNUNG
Die Anleitung ist nur fr qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten drfen nur von qualifiziertem Fachpersonal ausgefhrt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten drfen nur von Personen ausgefhrt werden, die eine spezielle Befhigung
dazu besitzen.
! AVERTISSEMENT
Ce manual est destin uniquement aux personnes comptentes en charge de lentretien. Afin
de rduire les risques de dcharge lectrique, dincendie ou de blessure neffectuer que les
rparations indiques dans le mode demploi moins dtre qualifi pour en effectuer dautres.
Pour toute rparation faire appel une personne comptente uniquement.
: LAN

For safety, do not connect the connector for periph-

WARNING eral device wiring that might have excessive volt-
When installing the unit, incorporate a readily accessible age to the following port.
disconnect device in the fixed wiring, or connect the : LAN connector
power cord to a socket-outlet which must be provided Follow the instructions for the above port.
near the unit and easily accessible, so that the user can
turn off the power in case a fault should occur.
WARNUNG
Beim Einbau des Gerts ist daher im Festkabel For kundene i Norge
ein leicht zugnglicher Unterbrecher einzufgen,
oder das Netzkabel mu mit einer in der Nhe Dette utstyret kan kobles til et IT-strmfordelingssystem.
des Gerts befindlichen, leicht zugnglichen
Wandsteckdose verbunden werden, damit sich bei
einer Funktionsstrung die Stromversorgung zum Gert
jederzeit unterbrechen lt.
VPL-SW536
FRSIKTIGHET!
Fara fr explosion vid felaktigt placerat batteri.

Byt endast mot samma eller likvrdig typ av batteri,
enligt tillverkarens rekommendationer.

Nr du kasserar batteriet ska du flja rdande lagar
fr regionen eller landet.
CAUTION
PAS P
Danger of explosion if battery is incorrectly replaced.
Fare for eksplosion, hvis batteriet ikke udskiftes
Replace only with the same or equivalent type rec-
korrekt.
ommended by the manufacturer.
Udskift kun med et batteri af samme eller tilsvarende
When you dispose of the battery, you must obey the
type, som er anbefalet af fabrikanten.
law in the relative area or country.
Nr du bortskaffer batteriet, skal du flge
lovgivningen i det pgldende omrde eller land.
ATTENTION
HUOMIO
Il y a danger dexplosion sil y a remplacement incor-
rect de la batterie. Remplacer uniquement avec
Rjhdysvaara, jos akku vaihdetaan virheellisesti.
une batterie du mme type ou dun type quivalent
Vaihda vain samanlaiseen tai vastaavantyyppiseen,
recommand par le constructeur.
valmistajan suosittelemaan akkuun.
Lorsque vous mettez la batterie au rebut, vous devez
Noudata akun hvittmisess oman maasi tai
respecter la lgislation en vigueur dans le pays ou la
alueesi lakeja.
rgion o vous vous trouvez.
FORSIKTIG
VORSICHT
Eksplosjonsfare hvis feil type batteri settes i.
Explosionsgefahr bei Verwendung falscher Batterien. Bytt ut kun med samme type eller tilsvarende
Batterien nur durch den vom Hersteller empfohlenen anbefalt av produsenten.
oder einen gleichwertigen Typ ersetzen. Kasser batteriet i henhold til gjeldende avfallsregler.
Wenn Sie die Batterie entsorgen, mssen Sie die
Gesetze der jeweiligen Region und des jeweiligen
Landes befolgen.

VPL-SW536 1 (P)
Table of Contents
Manual Structure 2. Adjustments
Purpose of this manual ............................................................ 3 (E) 2-1. Notes on Servicing ....................................................2-1 (E)
Related manuals ...................................................................... 3 (E) 2-1-1. When the Prism Assembly is Replaced ...........2-1 (E)
Trademarks.............................................................................. 3 (E) 2-1-2. When the In-polarizer Assembly (G) is
Removed ..........................................................2-1 (E)
2-1-3. When Replacing the C Board ..........................2-1 (E)
1. Service Overview 2-2. Mechanical Adjustment .............................................2-2 (E)
2-2-1. Polarizer Adjustment........................................2-2 (E)
1-1. Appearance Figure/Board Location ..........................1-1 (E) 2-3. Electrical Adjustment ................................................2-4 (E)
1-2. Tighten Torque ..........................................................1-2 (E) 2-3-1. Required Equipment ........................................2-4 (E)
1-3. Disassembly ..............................................................1-3 (E) 2-3-2. How to Enter the Service Mode.......................2-4 (E)
1-3-1. Top Cover Assembly ........................................1-3 (E) 2-3-3. V COM Adjustment .........................................2-4 (E)
1-3-2. Filter .................................................................1-4 (E) 2-3-4. Angle Detect Sensor Adjustment .....................2-5 (E)
1-3-3. HA Board .........................................................1-5 (E) 2-3-5. White Balance Adjustment ..............................2-5 (E)
1-3-4. U Board ............................................................1-6 (E) 2-4. Software Update ........................................................2-8 (E)
1-3-5. HB Board .........................................................1-7 (E) 2-4-1. Preparation .......................................................2-8 (E)
1-3-6. Bottom Cover Assembly ..................................1-8 (E) 2-4-2. Main (Scan Converter).....................................2-9 (E)
1-3-7. Q Board ............................................................1-9 (E) 2-4-3. Sub .................................................................2-10 (E)
1-3-8. C Board ..........................................................1-10 (E) 2-5. Quick Access ........................................................... 2-11 (E)
1-3-9. Speaker Assembly .......................................... 1-11 (E) 2-5-1. Preparation ..................................................... 2-11 (E)
1-3-10. Power Unit .....................................................1-12 (E) 2-5-2. Acquisition of 3Dgamma/LookUpTable/
1-3-11. Power Unit (Ballast) ......................................1-13 (E) Main/Opt unit Data ........................................ 2-11 (E)
1-3-12. AC Inlet..........................................................1-14 (E) 2-5-3. Acquisition of NVM Data..............................2-12 (E)
1-3-13. DC Fan (80 Square) .......................................1-15 (E) 2-5-4. Writing of 3Dgamma/LookUpTable/
1-3-14. DC Fan (For Lamp) .......................................1-16 (E) Main/Opt unit Data ........................................2-13 (E)
1-3-15. TL Board ........................................................1-17 (E) 2-5-5. Writing of NVM Data ....................................2-14 (E)
1-3-16. Optical Block Assembly ................................1-18 (E) 2-6. Adjustment Item Initialize Data ..............................2-15 (E)
1-3-17. TA Board ........................................................1-19 (E)
1-3-18. V Board ..........................................................1-20 (E)
1-3-19. DC Fan (L) .....................................................1-21 (E) 3. Troubleshooting
1-3-20. DC Fan (R) ....................................................1-22 (E)
1-3-21. S Lens Assembly............................................1-22 (E) 3-1. Troubleshooting.........................................................3-1 (E)
1-3-22. S Prism Assembly ..........................................1-23 (E)
1-3-23. S In-polarizer Assembly (R)/(G)/(B) .............1-24 (E)
1-3-24. P/S Converter .................................................1-25 (E) 4. Spare Parts
1-4. Optional Fixtures .....................................................1-26 (E)
1-4-1. Extension Boards and Extension Cables .......1-26 (E) 4-1. Notes on Repair Parts ...................................................... 4-1
1-4-2. Connection .....................................................1-27 (E) 4-2. Exploded Views............................................................... 4-2
1-5. Service Mode (Network Volume)............................1-28 (E) 4-3. Packing Materials & Supplied Accessories................... 4-12
1-5-1. Outline ...........................................................1-28 (E)
1-5-2. Information Function .....................................1-29 (E)
1-5-3. Setup Function ...............................................1-29 (E)
1-6. Indicator Display .....................................................1-30 (E)
1-7. Lead-free Solder ......................................................1-31 (E)
VPL-SW536 1 (E)
5. Block Diagrams
Overall ............................................................................. 5-1
6. Frame Wiring
Frame Wiring................................................................... 6-1
2 (E) VPL-SW536
Manual Structure
Purpose of this manual

This manual is the Service Manual of the Data Projector VPL-SW536/SW526/
SX536.
This manual contains the service overview, adjustments, troubleshooting, spare
parts, block diagrams, and frame wiring.
The service of this unit is basically performed by the replacement of board.

Therefore, the schematic diagram, board layout and electrical parts list are not
contained.
Related manuals
In addition to this Service Manual, the following manuals are provided.
. Operating Instructions PDF (Supplied with unit)

This manual is necessary for application and operation of this unit.
. Quick Reference Manual (Supplied with unit)

This manual describes the notes for this unit, and using the CD-ROM of Operating
Instructions.
. Protocol Manual
This manual describes the protocol for controlling this unit.
Trademarks
Trademarks and registered trademarks used in this manual are as follows.
. Internet Explorer is a registered trademarks of Microsoft Corporation in the United

States and Other countries.
Other system names, product names, and company names appearing in this manual
are trademarks or registered trademarks of their respective holders.
VPL-SW536 3 (E)
Section 1
Service Overview
1-1. Appearance Figure/Board Location
Appearance Figure
RM-PJ8
Board Locations
TL
U
C
HA
TA
V
HB
VPL-SW536 1-1 (E)

1-2. Tighten Torque
Tighten the each screw with the torque below.
. B2 x 5: 0.19 ?0.03 N.m

. BVTP3 x 12: 0.55 ?0.06 N.m
. K3 x 10: 0.55 ?0.06 N.m
. PSW3 x 8 (except for speaker fixing screw/unit fixing screw): 0.55 ?0.06 N.m
. PSW3 x 8 (for speaker fixing screw/unit fixing screw): 0.125 ?0.025 N.m
. PSW3 x 10: 0.55 ?0.06 N.m
. PSW4 x 8: 1.00 ?0.08 N.m
. PWH3 x 10: 0.80 ?0.08 N.m
. Screw (with stopper): 0.55 ?0.06 N.m
. Tapping shaft: 0.65 ?0.05 N.m
. Connector screw: 0.55 ?0.06 N.m
. Screw special head: 0.20 ?0.06 N.m
1-2 (E) VPL-SW536

1-3. Disassembly
m . Remove the parts in the order of numbers shown in the figure, in this section.
. To assemble, reverse the removal procedure.
1-3-1. Top Cover Assembly
n When replacing the top cover assembly, replace the cushion and top cover cushion with new
one simultaneously.
HA board
CN21
5 Top cover assembly
4 Harness
2 Filter door
6 Cushion
7 Top cover cushion
1 Hook
Bottom of this unit
3 Nine screws
(BVTP3 x 12)
VPL-SW536 1-3 (E)

1-3-2. Filter
3 Two hooks
6 Filter B
4 Filter holder
5 Filter A
1 Hook
2 Filter door
1-4 (E) VPL-SW536

1-3-3. HA Board
. Remove the top cover assembly. (Refer to Section 1-3-1.)
1 Harness
5 HA board
6 Arrow button
CN22
7 Button
Top cover assembly
3 Hooks of the top cover assembly
2 Hooks of button
4 Hooks of the top cover assembly
VPL-SW536 1-5 (E)

1-3-4. U Board
2 Two screws
(BVTP3 x 12)
1 Harness
CN3
3 U board
Top cover assembly
1-6 (E) VPL-SW536

1-3-5. HB Board
CN31
1 Harness
3 HB board
4 LED guide
Top cover assembly
HB board 2 Two hooks
CN31
VPL-SW536 1-7 (E)

1-3-6. Bottom Cover Assembly
1 Three screws
(BVTP3 x 12)
2 Eight screws
(PSW3 x 8)
3 Bottom cover
assembly
1-8 (E) VPL-SW536

1-3-7. Q Board

. Remove the bottom cover assembly. (Refer to Section 1-3-6.)
C board (B side)
CN1602
CN1604
CN109
CN106 CN111
CN107
CN108
CN1603
CN500 CN104
2 Connector panel
CN1500 CN1601 CN1600
1 Eight connector screws
7 Four screws
(PSW3 x 8)
3 Five harnesses 9 Board bracket
8 Two screws
(PSW3 x 8)
C board 5 Three harnesses

4 Five harnesses
6 Three flexible flat cables
VPL-SW536 1-9 (E)

C board != Connector
(B to B)
CN100
0 Screw
(PSW3 x 8)
![ Sub board bracket

CN201
!- Two screws
(PSW3 x 8)
!\ Q board
!] Three screws
(PSW3 x 8)
1-3-8. C Board

. Remove the Q board. (Refer to Section 1-3-7.)
1 Two screws
(PSW3 x 8)
4 C board
3 Screw
(SCREW SPECIAL HEAD)
2 Screw
(PSW3 x 8)
1-10 (E) VPL-SW536

1-3-9. Speaker Assembly

. Remove the board bracket. (Refer to steps 1 to 9 in Section 1-3-7.)
1 Two screws
(PSW3 x 8)
n
Before tightening these screws,
apply the screw lock.
2 Speaker
3 Two cushion washers
VPL-SW536 1-11 (E)

1-3-10. Power Unit

5 Four screws 6 Screw

(PSW3 x 8) (PSW3 x 8)
7 Power unit cover
2 Two harnesses
8 Power unit
4 Two harnesses
CN101
CN202
CN201 CN102
3 Two screws 1 Harness

(PSW3 x 8)
C board
CN500
1-12 (E) VPL-SW536

1-3-11. Power Unit (Ballast)

. Remove the power unit. (Refer to Section 1-3-10.)
1 Screw
(PSW3 x 8)
2 Two screws
(PSW3 x 8)
3 Harness 7 Hook
5 Ballast case (upper)

X2
X3
4 Four hooks
X1
8 Power unit
(ballast) 6 Two harnesses
VPL-SW536 1-13 (E)

1-3-12. AC Inlet

. Remove the power unit. (Refer to Section 1-3-10.)
. Remove the power unit (ballast). (Refer to Section 1-3-11.)
5 Two screws
(K3 x 10)
6 AC inlet
2 Ground terminal
4 AC inlet
bracket 1 Screw
3 Three screws (PSW4 x 8)
(PSW3 x 8)
1-14 (E) VPL-SW536

1-3-13. DC Fan (80 Square)

3 Duct holder (Exhaust)

2 Three screws
(PSW3 x 8)
5 Two DC fans (80 square)
1 Two
harnesses
CN1603
C board
4 Eight tapping shafts
CN1602
VPL-SW536 1-15 (E)

1-3-14. DC Fan (For Lamp)

3 Two screws
(BVTP3 x 12)
4 Lamp fan case (upper)
2 Lamp fan case (lower)
6 DC fan (for lamp)
5 Two tapping shafts
1 Two screws
(PSW3 x 8)
1-16 (E) VPL-SW536

1-3-15. TL Board
2 Hook
3 TL board
CN5
1 Harness
VPL-SW536 1-17 (E)

1-3-16. Optical Block Assembly

. Remove the duct holder (Exhaust). (Refer to steps 1 to 3 in Section 1-3-13.)
3 Screw
(PWH3 x 10)
4 Lamp connector assembly
5 Fuse harness
6 Screw
(PSW3 x 8)
7 Lamp house 8 Two screws
(PSW3 x 8)
9 Screw (unit fixing screw)
(PSW3 x 8)
m
. Before tightening this screw,
apply the screw lock.
. Tightening torque: 0.125 ?0.025 N.m
0 Cushion washer
!- Optical block
assembly
2 Lamp assembly (SP)
1 Two screws
(with stoppers)
!= Screw
(PSW3 x 8)
m
Before tightening screws of steps
9 and 0, tighten this screw.
1-18 (E) VPL-SW536

1-3-17. TA Board

. Remove the filter. (Refer to Section 1-3-2.)
. Remove the AC inlet bracket. (Refer to steps 1 to 4 in Section 1-3-12.)
3 Two screws
(BVTP3 x 12)
CN1600
CN108
C board
1 Two harnesses
5 Harness
4 Prism duct
CN7
6 Screw
(BVTP3 x 12)
2 Seven screws
7 TA board (PSW3 x 8)
VPL-SW536 1-19 (E)

1-3-18. V Board

. Remove the prism duct. (Refer to steps 1 to 4 in Section 1-3-17.)
1 Harness
CN1
2 Two screws
(BVTP3 x 12)
3 V board
Prism duct
1-20 (E) VPL-SW536

1-3-19. DC Fan (L)
n
When replacing the DC fan (L), replace the sirocco cushion A with new one simultaneously.

1 Three screws
(BVTP3 x 12)
3 Prism duct (upper)
4 DC fan (L)
Label side
5 Sirocco cushion A
2 Screw
(BVTP3 x 12)
VPL-SW536 1-21 (E)

1-3-20. DC Fan (R)
n
When replacing the DC fan (R), replace the sirocco cushion A with new one simultaneously.

1 Harness
CN1603
C board
Label side
3 Sirocco cushion A
2 DC fan (R)
1-3-21. S Lens Assembly
. Remove the each part. (Refer to Sections 1-3-1 to 1-3-20.)
1 S lens assembly
1-22 (E) VPL-SW536

1-3-22. S Prism Assembly

. Remove the optical block assembly. (Refer to Section 1-3-16.)
2 S prism assembly
1 Four screws
(PSW3 x 10)
S prism assembly
The distance to the prism is long. The distance to the prism is short.
Metal plate
Prism Prism
VPL-SW536/SW526 VPL-SX536
VPL-SW536 1-23 (E)

1-3-23. S In-polarizer Assembly (R)/(G)/(B)

3 Screw
(B2 x 5)
5 Screw
(B2 x 5)
4 S in-polarizer
assembly (G)
1 Screw
6 S in-polarizer (B2 x 5)
assembly (B)
2 S in-polarizer
assembly (R)
Front side
VPL-SW536/SW526 VPL-SX536
Arrow A view Arrow A view
6 S in-polarizer assembly (B) 2 S in-polarizer assembly (R) 6 S in-polarizer assembly (B) 2 S in-polarizer assembly (R)
Front side Front side

Blue Blue
Red Red
Green Green
4 S in-polarizer assembly (G) 4 S in-polarizer assembly (G)
1-24 (E) VPL-SW536

1-3-24. P/S Converter

2 Cover FE
1 Two hooks
3 P/S converter
VPL-SW536 1-25 (E)

1-4. Optional Fixtures
1-4-1. Extension Boards and Extension Cables
. Polarizer Adjustment Kit (A-1893-442-A)
X board
A HM connector assembly 3P x5 C HR connector assembly 5P x3
B HR connector assembly 4P x2 E JST connector assembly 11P x1
. HR connector assembly 6P x1 (1-969-487-11): Not supplied with polarizer adjustment kit

3
4
1-26 (E) VPL-SW536

1-4-2. Connection
A HM connector assembly 3P x5
A C board B HR connector assembly 4P x2
B
A C HR connector assembly 5P x3
C D JST connector assembly 11P x1
A
*1 HR connector assembly 6P x1
D
A *1
C
B
C
A
Paper
X board
C board (B side) X board (B side)
CN001
CN1602 CN013
CN002
CN1604 CN014
CN109 CN021 CN022
CN106 CN111 CN023 CN024 CN029 CN030
CN107
CN108 CN027 CN028
CN003
CN1603 CN016
CN032
CN018 CN005 CN031
CN104 CN025 CN004 CN020
CN1500 CN1601
CN500 CN1600
VPL-SW536 1-27 (E)

1-5. Service Mode (Network Volume)
1-5-1. Outline
This unit is provided with a network terminal. Using a Web browser, it can check the state of a projector
and control and set the network blocks.
Additionally, this unit is able to check the information of the projector through a network as a service-
dedicated function.
1. Connection of projector and PC

. Set using a CAT5 cross cable so that the network setting of the projector and PC is the same in a
subnet when connecting a projector and PC directly.
. Connect PC to the LAN so as to adjust the network setting of PC to LAN operating environment
when a projector is connected to LAN.
2. IP address confirmation
Turn on the power of a projector and display a menu screen. On the [Connection/Power] screen of a
menu, confirm the IP address of the projector.
3. Entering the service mode

To use a service-dedicated function, enter the service mode. To enter the service mode, enter the
following in the address bar of a Web browser (Internet Explorer 6/7/8):
http:// (IP address of projector) /service/
You are prompted to enter a user name and password. Enter them as follows:
User name: service
Password: (Lower-case model name) Example: vpl-sw526, vpl-sw536, or vpl-sx526
n
When moving from the service mode to other pages and entering the service mode again, close a Web
browser once and start the Web browser again.
1-28 (E) VPL-SW536

1-5-2. Information Function
The information below can be confirmed as Information and Event Trace when you click the
[Information] tab on the Web page of service.
1. Information
The displayed items are described below.
PROJECTOR
. Model Name: Model name
. Serial No.: Serial number
. Location: Installation site (Blanked when Location is not set.)
ROM Ver.
. Main ROM Version: Version of Main ROM
. Sub ROM Version: Version of Sub ROM
1-5-3. Setup Function
When a user forgot a Web password, click the [Setup] tab and then [Password] button from the Web
page of service and set the Web password on the password setting screen again.
VPL-SW536 1-29 (E)

1-6. Indicator Display
In this unit, the error status is indicated by the blinking of the indicator. There are ON/STANDBY indica-
tor and LAMP/COVER indicator on the front panel. The error differs depending on which indicator
blinks.
For details of the blinking state of indicator and the error, refer to the list below.
ON/STANDBY indicator (Blinks in red)
Error Number of Details of the error status Remedy

blinking
Temperature error ON 2 The temperature inside of the unit exceeds Page 3-2
OFF
the tolerable range.
Fan error ON 4 Any of fan does not operate normally. Page 3-2
OFF
Power error ON 6 The power is not output normally. Page 3-2

OFF
System error-1 ON 10 The data cannot be normally acquired from _

OFF
the storage device (EEPROM) when the
power of sub-CPU is turned on.
System error-2 ON 11 The data cannot be normally acquired from _
OFF
the storage device (EEPROM) when the
power of main-CPU is turned on.
System error-3 ON 12 The main-CPU does not operate normally. _
OFF
System error-4 ON 13 The main-CPU does not operate normally. _

OFF
Assembly error ON 14 The connector of temperature sensor is Page 3-2

OFF
disconnected.
LAMP/COVER indicator (Blinks in red)
Error Number of Details of the error status Remedy

blinking
Cover error ON 2 The lamp cover is removed. Page 3-2
OFF
Lamp error ON 3 The lamp does not light normally. Page 3-2
OFF
1-30 (E) VPL-SW536

1-7. Lead-free Solder
Boards requiring use of lead-free solder are printed with a lead free mark (LF) indicating the solder
contains no lead.
(Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular
size.)
: LEAD FREE MARK
m
. Be sure to use the lead-free solder for the printed circuit board printed with the lead free mark.
. The lead-free solder melts at a temperature about 40 dC higher than the ordinary solder, therefore, it is
recommended to use the soldering iron having a temperature regulator.
. The ordinary soldering iron can be used but the iron tip has to be applied to the solder joint for a slightly
longer time. The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so
be careful.
VPL-SW536 1-31 (E)

Section 2
Adjustments
2-1. Notes on Servicing
2-1-1. When the Prism Assembly is Replaced
1. Perform the V COM adjustment. (Refer to Section 2-3-3.)

2. Write the Opt unit data in CD-ROM supplied with the prism assembly.
(Refer to Section 2-5-4.)
3. Check the white balance, then perform the white balance adjustment as needed.
2-1-2. When the In-polarizer Assembly (G) is Removed
Perform the polarizer adjustment. (Refer to Section 2-2-1.)
2-1-3. When Replacing the C Board
1. Save the Main data and NVM data before replacement. (Refer to Sections 2-5-2 and 2-5-3.)
2. Replace the C board. (Refer to Section 1-3-4.)
3. Write the Main and NVM data saved in step 1 to replaced C board.
4. Perform the V COM adjustment. (Refer to Section 2-3-3.)
5. Check the white balance, then perform the white balance adjustment as needed.
6. Perform the angle detect sensor adjustment. (Refer to Section 2-3-4.)
n
If any board other than the C board is replaced, there is not adjustment item.
VPL-SW536 2-1 (E)

2-2. Mechanical Adjustment
2-2-1. Polarizer Adjustment
n
Perform this adjustment in a dark place.
1. Remove the top cover assembly and bottom cover assembly. (Refer to Sections 1-3-1 and 1-3-6.)
2. Remove the board bracket. (Refer to steps 1 to 9 in Section 1-3-7.)
3. Connect the extension board, C board and extension cables. (Refer to Section 1-4-2.)
4. Place this unit on the edge of table and spread a white paper on the flour.
n
Be careful not to drop this unit.
5. Connect the power cord.
6. Turn on the power and project the image on the white paper on the flour.
White paper
2-2 (E) VPL-SW536

7. Loosen the screw of the S in-polarizer assembly (G).
8. Move the polarization panel holder from side to side, and then tighten the screw at the position where
the image on the screen becomes the darkest.
9. Turn off the power.
Screw (B2 x 5)
S in-polarizer assembly (G)
10. Assemble the unit in the reverse order of steps 1 to 3.
VPL-SW536 2-3 (E)

2-3. Electrical Adjustment
2-3-1. Required Equipment
. NTSC, PAL, SECAM component signal generator:

Tektronix TG2000 + AVG1 (option module) + AWVG1 (option module) or equivalent
. VG (programmable video signal generator): ASTRODESIGN VG-828 or equivalent
n
Allow the warm-up time of 5 minutes after the power is turned on before starting the adjustment.
2-3-2. How to Enter the Service Mode
1. Press the [MENU] key.

The menu appears.
2. Set the Status to On in the Operation menu.
3. Press the [MENU] key to close the MENU.
4. Press the keys in the following order:
[ENTER] [ENTER] [&] [ENTER]
The message Do you want to enter the Service Mode? [Yes] [No] appears.
Select [Yes] and press the [ENTER] key.
How to exit the service mode

Perform the key operations in accordance with step 4.
The message Do you want to return to the User Mode? [Yes] [No] appears.
Select [Yes] and press the [ENTER] key.
2-3-3. V COM Adjustment
1. Enter the service mode. (Refer to Section 2-3-2.)

2. Select the menus in the following order: Device Other 07 Other/Pattern Enb. Then, set the value
to 1.
3. Select the menus in the following order: Device Panel Driver 04 P.Drv/V Common R, and
adjust the value so that the flicker is the minimum.
4. In the same way of step 2, adjust the value for minimal flicker on the menu 05 P.Drv/V Common G
and 06 P.Drv/V Common B.
5. Select the menus in the following order: Device Save to memory. Select [Yes], and press the
[ENTER] key to save.
6. Select the menus in the following order: Installation Image Flip and set it to either V, H or
VHLR.
7. Perform the steps 2 to 4.
8. Select the menus in the following order: Installation Image Flip and set back to Off.
2-4 (E) VPL-SW536

2-3-4. Angle Detect Sensor Adjustment

2. Select the menus in the following order: Device Other 20 Other/X Tilt.
3. Place the unit on the table parallel to the top side of the unit.
4. Save the memory this value of the X TILT in 22 Other/X Tilt C0.
5. Tilt the unit to a 90-degree upward direction.
7. Tilt the unit to a 90-degree downward direction.
9. Select the menus in the following order: Device Save To Memory. Select [Yes], and press the
[ENTER] key.
2-3-5. White Balance Adjustment
Preparation before adjustment

1. Input the XGA 60 Hz 100% flat field signal to the INPUT A connector and allow the warm-up of ten
minutes aging at a minimum.
2. Enter the Service Mode. (Refer to Section 2-3-2.)
3. Enter the menu: Function Lamp Mode and set it to High.
4. Input the 10step computer signal to the INPUT A, then perform the visual check the chromaticity of
each step.
5. Input the 10step video signal to the VIDEO IN, then perform the visual check the chromaticity of
each step.
6. When the chromaticity varies widely, perform the adjustment below.
7. Enter the menu: Function Lamp Mode and set it to Standard.
8. Perform the steps 4 and 5 to check visually the chromaticity of each step.
9. When the chromaticity varies widely, perform the adjustment below.
n
Perform the white balance adjustment in sequence.
INPUT A color temperature: high

2. Select the menus: Device W/B High.
3. Input the 80% flat field computer signal to the INPUT A.
4. Adjust the GAIN R and GAIN G until the target chromaticity.
Target chromaticity (x, y): 0.284, 0.298
5. Change the input signal to the 20% flat field computer signal.
6. Adjust the BIAS R and BIAS G until the target chromaticity.
7. Repeat steps 3 to 6 until the chromaticity (x ?0.002, y ?0.002) with reference to the target chromaticity (x, y).
8. Select the menus: Device Save To Memory, then select [Yes] and press the [ENTER] key.
9. For each lamp mode High, Middle, Low, repeat the steps 3 to 8 and adjust.
VPL-SW536 2-5 (E)

INPUT A color temperature: middle
1. Select the menus in service mode: Device W/B Middle.

INPUT A color temperature: low
1. Select the menus in service mode: Device W/B Low.

3. Adjust the GAIN B and GAIN G until the target chromaticity.
5. Adjust the BIAS B and BIAS G until the target chromaticity.
VIDEO IN color temperature: high
1. Change the input channel to VIDEO, then input video signal to VIDEO IN.
2. Select the menus in service mode: Device W/B High.
3. Copy the adjusted values of GAIN R/B/G and BIAS R/B/G in INPUT A color temperature: high to
each item.
each step.
5. When the chromaticity varies widely, perform the adjustment below. If not, proceed to next section.
6. Change the input signal to the 80% flat field video signal.
8. Change the input signal to the20% flat field video signal.
2-6 (E) VPL-SW536

VIDEO IN color temperature: middle
1. Select the menus in service mode: Device W/B Middle.

2. Copy the adjusted values of GAIN R/B/G and BIAS R/B/G in INPUT A color temperature: middle
to each item.
each step.
4. When the chromaticity varies widely, perform the adjustment below. If not, proceed to next section.
VIDEO IN color temperature: low
1. Select the menus in service mode: Device W/B Low.

2. Copy the adjusted values of GAIN R/B/G and BIAS R/B/G in INPUT A color temperature: low to
each item.
each step.
4. When the chromaticity varies widely, perform the adjustment below. If not, finish the adjustment.
6. Adjust the GAIN B and GAIN G until the target chromaticity.
8. Adjust the BIAS B and BIAS G until the target chromaticity.
VPL-SW536 2-7 (E)

2-4. Software Update
2-4-1. Preparation
Required equipment/Tools
. Personal computer (PC)

. RS-232C cross cable
. Sub Flash upgrader for Sony Projector: Updater for Sub
. USB memory: USB2.0 supported, Free space more than 64 MB, FAT format-
ted (expect for exFAT)
n
For obtaining the each application and version upgrade file, contact your local Sony Sales Office/Service
Center.
Connection
RS-232C connector
PC
RS-232C cross cable
2-8 (E) VPL-SW536

Preparation
1. Set the Standby Mode to Standard in the Connection/Power menu.

(Refer to Operating Instructions.)
3. Select the menus in the following order: Device Other 232C (38.4 k = 0/19.2 k = 1/9.6 k = 2).
Then set the value to 0.
4. Install each application to PC.
5. Disconnect the power cord of this unit.
6. Connect this unit with PC referring to the connection figure.
2-4-2. Main (Scan Converter)
1. Copy the files to be written into the root folder of the USB memory.
The example for VPL-SW*** V1.00 1.01
sw*av1001a.bin, sw*av1001a.bin.sum,
sw*bv1001a.bin, sw*bv1001a.bin.sum,
sw*dv1001a.bin, sw*dv1001a.bin.sum,
sw*kv1001a.bin, sw*kv1001a.bin.sum,
update.inf
The example for VPL-SW*** V1.01 V1.02
sw*av1002a.bin, sw*av1002a.bin.sum,
update.inf
2. Connect the power cord to this unit and make it standby state, then wait about thirty seconds.
3. Connect the USB memory to the USB A connector on the rear side of this unit while holding down
the [INPUT] key.
4. After five seconds, the ON/STANDBY indicator blinks rapidly in green, then remove the finger from
the [INPUT] key.
The writing is executed. After completed, the ON/STANDBY indicator lights in red.
n
When the ON/STANDBY indicator blinks twenty times in red, the writing is failed. Repeat from step 3.
5. Disconnect the power cord.
VPL-SW536 2-9 (E)

2-4-3. Sub
1. Copy the three files ru2vXXXXX.dli, 5212.inf, and ru2vXXXXX.mot into the same folder of applica-
tion file Flash.exe.
n
XXXXX means version number.
2. Double-click Flash.exe to start the application.
Application name: Sub Flash Upgrader for Sony Projector
File name: Flash.exe
3. Check ru2vXXXXX.dli, 5212.inf, ru2vXXXXX.mot are selected in download information file, MCU
Type setting, and ROM File Name respectively.
4. Click the [Setting] button of Com.
The window for operation frequency and bit rate is displayed.
5. Set the following items.
Bit rate: 38,400 bit/s
Serial port: Serial port number/USB port number used for connecting PC
Time out: Arbitrary (Communication retrial time. default: 5 sec.)
6. Select UserProgram Mode.
7. Click the [Start] button.
The start window is displayed.
8. Click the [OK] button.
The Please AC Plug In window is displayed.
9. Connect the power cord.
The writing starts, and the write window is displayed.
11. The End window is displayed. (Upgrade completed)
2-10 (E) VPL-SW536

2-5. Quick Access
2-5-1. Preparation
Required equipment/Tools
. Personal computer (PC): RS-232C interface equipped

. RS-232C cross cable
. QuickAccess2: Executable: QuickAccess2.exe
n
For obtaining QuickAccess2, please contact your local Sony Sales Office/Service Center.
Preparation
1. Install the QuickAccess2 in PC.

2. Connect this unit with PC. (Refer to Section 2-4-1.)
2-5-2. Acquisition of 3Dgamma/LookUpTable/Main/Opt unit Data
1. Connect the power cord and set this unit to standby state.
2. Press the I/O button on this unit.
The lamp lights and the image is displayed.
3. Double-click QuickAccess2.exe to start the application.
4. Select a target model on the Model pull-down menu.
5. Select Save on the Load/Save pull-down menu.
6 Select the data type (3Dgamma/LookUpTable/Main/Opt unit) on the Data Type pull-down menu.
7. Click the [Next] button.
8 Click the [Browse...] button.
The file selection window is displayed.
9. Select the destination file for the obtained data.
11. Select the serial port used for connecting PC on the Serial Port pull-down menu.
Upper line: Serial port number used for connecting PC
Lower line: 38400
The window displaying the model name of this unit, serial number, and the file path of the destination
of the obtained data to save is displayed.
The saving starts. Completed is displayed after completed.
14. Press the I/O button and set this unit to standby state.
16. Click the [Complete] button.
VPL-SW536 2-11 (E)

2-5-3. Acquisition of NVM Data
4. Select Save on the Load/Save pull-down menu.
5. Select NVM on the Data Type pull-down menu.
Lower line: 38400
9. Select SAVE_ALL on the Save field.
10. Check the Verify check box.
12. Set the destination file for the obtained data.
The acquisition starts.
After completed, The massage Verify Success! Reading Model Name, Serial Number, NVM Map
Version and NVM Data Version is successful. is displayed.
Completed is displayed.
2-12 (E) VPL-SW536

2-5-4. Writing of 3Dgamma/LookUpTable/Main/Opt unit Data
2. Press the I/O button on this unit.
The lamp lights and the image is displayed.
5. Select Load on the Load/Save pull-down menu.
6 Select the data type (3Dgamma/LookUpTable/Main/Opt unit) on the Data Type pull-down menu.
8. Click the [Browse...] button.
9. Select the file to be written.
Lower line: 38400
The window displaying the file path, model name written in file, unit serial, serial number model
name of this unit, and serial number is displayed.
The writing starts. Completed is displayed after completed.
14. Press the I/O button and set this unit to standby state.
VPL-SW536 2-13 (E)

2-5-5. Writing of NVM Data
4. Select Load on the Load/Save pull-down menu.
5 Select NVM on the Data Type pull-down menu.
Lower line: 38400
9. Select ALL on the Load field.
10. Check the Verify check box.
12. Set the destination file for the writing data.
The writing starts.
After completed, The massage Turn Off and On the AC, and then Power On to enable the new
settings. is displayed.
Completed is displayed.
2-14 (E) VPL-SW536

2-6. Adjustment Item Initialize Data
Initialize data 1
Menu Title Item Name Memory Name
Set Sub Micro No Memory Status Eco Picture Memory
Memory Memory Memory Memory
All Channels
Dynamic Standard Presen Blackboard Game Cinema
Picture Picture Mode *1
Reset
Contrast 90 80 80 90 80 70
Brightness 50 50 50 50 70 50
Color 60 50 50 50 50 50
Hue 50 50 50 50 50 50
Color Temp. LOW LOW PRESENTATION PRESENTATION MIDDLE LOW
Custom1
Gain R 0
G 0
B 0
Bias R 0
G 0
B 0
Custom2
Gain R 0
G 0
B 0
Bias R 0
G 0
B 0
Custom3
Gain R 0
G 0
B 0
Bias R 0
G 0
B 0
Sharpness 7 5 5 7 5 4
Gamma Mode GRAPHICS1 GRAPHICS2 GRAPHICS1 BLACK_BOARD GRAPHICS2 GRAPHICS2
Screen Wide Mode(SD) 4_3

Wide Mode(HD) 16_9
Wide Mode(PC) FULL_1
Adjust Signal
APA
Dot Phase *1
Pitch *1
Shift *1
Function Volume 30
MIC Volume 0
Speaker ON
SmartAPA AUTO
CC Display OFF
Lamp timer setting
Operation Lauguage ENGLISH
Status ON
Security Lock OFF
Control Key Lock OFF
(Continue to Next page)
VPL-SW536 2-15 (E)

Menu Title Item Name Memory Name
Set Sub Micro No Memory Status Eco Picture Memory
Memory Memory Memory Memory
All Channels
Black-
Dynamic Standard Presen Game Cinema
board
Connection Power LAN Setting
IP Address Setup AUTO (DHCP)
IP Address
Subnet Mask
Default Gateway
Primary DNS
Secondary DNS
Apply
MAC Address
WLAN Setting ON
WLAN
SSID
IP Address
Encode system
Input-A Signal Sel. AUTO
ECO
Lamp Mode STANDARD
Auto Power Saving
With No Input STANDBY
With Static Signal LAMP_DIMMING
Lamp Dimming 10_MIN

Standby Mode LOW
Direct Power On OFF
Installation Image Flip OFF
Link to
Installation Attitude
Image Flip
High Altitude OFF
V Keystone AUTO
Information Model Name Display only
Serial Number Display only
fH Display only
fV Display only
signal info Display only
signal info Display only
Main ROM Version Display only
NVM Version Display only
Sub ROM Version Display only
Lamp Timer Display only
Operation Timer Display only
Prev. Lamp Timer Display only
*1: Dot Phase, Pitch, Shift in the Adjust Signal menu have the initial value respectively in accordance with the input signal (PRESET MEMORY No.).
n
There are nonadjustable items in accordance with the input signal.
2-16 (E) VPL-SW536

Initialize data 2
Device Name Item Name Memory Name
Set Sub Status Channel Memory No
Memory Micro Memory Memory
Memory Video S Video Input-A Input-B
A/D Converter ADC/ R Gain (Other) 227 279 391 391

R Gain (VideoGBR) 390
R Gain (Component 15k) 306
R Gain (Component 30k) 305
R Gain (Component HD) 303
G Gain (Other) 32 225 388 387
G Gain (VideoGBR) 385
G Gain (Component 15k) 283
G Gain (Component 30k) 283
G Gain (Component HD) 284
B Gain (Other) 275 32 388 390
B Gain (VideoGBR) 391
B Gain (Component 15k) 301
B Gain (Component 30k) 301
B Gain (Component HD) 302
Calibration 0
Panel Driver P.Drv V Common R 197
V Common G 188
V Common B 185
Gain 215
Display Engine DE/ LUT Enb 0
UF Enb 1
R SHP 351
G SHP 351
B SHP 351
DE/R REG H 0
DE/B REG H 0
DE/G PANEL LR 0
Other Other/ Pattern Enb 1
Pattern Type 0
Pattern R 1
Pattern G 1
Pattern B 1
X Tilt
X Tilt C0 0
X Tilt C1 4096
X Tilt C2 _4096
All Black Input Mode 0
DDC Wrte En 0
Dimming Thresh 3
RS232C bps 0
HDMI Range 0
Lamp Gain
n
There are nonadjustable items in accordance with the input signal.
VPL-SW536 2-17 (E)

Section 3
Troubleshooting
3-1. Troubleshooting
Connect the power cord to the unit.
Is the
ON/STANDBY No The power unit is No Connect the
indicator blinking connected to
CN500 on the harness securely.
in red ?
C board?
Yes Yes
Turn on the power.
Yes Replace the

Is the harness broken?
harness.
Replace the Is the
C board. No ON/STANDBY
(Refer to indicator blinking No
Section 1-3-8.) in green ?
Replace the power unit.

Yes (Refer to Section 1-3-10.)
No Does the projector

1 lamp illuminated ?
Yes
Is any image No Yes

projected ?
All black screen ? 4
Yes No
Replace the C board.

Yes Is the color
4 abnormal or all white
(all black)?
No Yes
Does the unit recover? End
3
No
Replace the optical block

assembly.
VPL-SW536 3-1 (E)

1
Does the
LAMP/COVER Yes
Check the lamp cover.
indicator blink
2 times ?
No
Does the
LAMP/COVER Yes
indicator blink 2
3 times ?
No
Does the
ON/STANDBY Yes 1. Check the fan rotation.
red indicator blink 2. Clean the filter.
2 times ?
No
Does the
ON/STANDBY Yes 1. Check the fan rotation.
red indicator blink 2. Check the fan connector.
4 times ?
No
Does the
ON/STANDBY Yes Replace the power unit.
red indicator blink (Refer to Section 1-3-10.)
6 times ?
No
Does the projector Yes

End
Does the illuminate ?
Yes Check the temperature
ON/STANDBY
sensor board.
red indicator blink
14 times ? (TL and TA boards).
No
No
3-2 (E) VPL-SW536

2
Is the
power unit
(ballast) connected to No
CN106 on the C board Connect the harness securely.
with the harness
normally ?
Yes
Is the
harness between No
the lamp and power Connect the harness securely.
unit (ballast)
is normal ?
Yes
Yes
Is the lamp broken ? Replace the lamp.
No
Does the
unit recover after Yes
the power unit End
(ballast)
replacement?
No

VPL-SW536 3-3 (E)

3
Yes
Is screen dark ? Replace the lamp.
No
Is screen Yes
bright normal ? End
Replace the S prism Yes
assembly. (Refer to Is the color abnormal?
Section 1-3-22.)
No
No Clean the lens and

the panel to remove dust.
Does the unit recover?

Yes Perform the V COM
Does screen flicker ? adjustment.
No
Replace the C board. No

(Refer to Section
1-3-8.)
Is there any trouble No Check the HB board and

in IR remote control? harness.
Yes
No problem. The set is normal.

Check another device and cable.
Check the LCD

connectors.
Does the
No Connect the flexible flat
flexible flat cable
connect securely? cable securely?
Yes
Replace the C board or

optical block assembly. No Yes
Does the unit recover? End
(Refer to Sections 1-3-8
and 1-3-16.)
3-4 (E) VPL-SW536

Section 4
Spare Parts
4-1. Notes on Repair Parts 4-1.
1. Safety Related Components Warning 1.

w !
Components marked ! are critical to safe operation. !
Therefore, specified parts should be used in the case of
replacement.
2. Standardization of Parts 2.
Some repair parts supplied by Sony differ from those
used for the unit. These are because of parts common-
ality and improvement.
3. Stock of Parts 3.
Parts marked with o at SP (Supply Code) column of SPSupply code o
the spare parts list may not be stocked. Therefore, the
delivery date will be delayed.
4. Harness 4.
Harnesses with no part number are not registered as
spare parts.
The components identified by mark contain confidential

information.
Strictly follow the instructions whenever the components
are repaired and/or replaced.
VPL-SW536 4-1
Top Cover Block
4-2. Exploded Views
BVTP3 x 12
13
18
BVTP
7
3 x 12
2 To C board
BVTP 6
3 x 12
1
9
20 12
3
A 11
19
16
17
10 15
17
8 14
A
4-2 VPL-SW536
Top Cover Block
No. Part No. SP Description

1 A-1914-406-A s MOUNTED CIRCUIT BOARD, HA
2 A-1914-407-A s MOUNTED CIRCUIT BOARD, HB
3 A-1914-409-A s MOUNTED CIRCUIT BOARD, U
4 X-2583-916-1 s ASSY, LAMP COVER
5 ! X-2586-092-1 s ASSY, TOP COVER
6 1-969-017-11 s SUB HARNESS (HA TO C)
7 1-969-018-11 s SUB HARNESS (HA TO HB/U)
8 4-172-393-01 s SCREW (M3), STOPPER
9 4-400-477-01 s GUIDE, LED
10 4-400-479-01 s IR WINDOW
11 ! 4-400-480-01 s BUTTON
12 ! 4-400-481-01 s ARROW KEY
13 ! 4-400-484-01 s DOOR, FILTER
14 ! 4-400-497-01 s DOOR, DIAL
15 ! 4-400-505-02 s COVER, ZOOM
16 4-409-076-51 s EMBLEM
(For VPL-SW536)
4-409-076-61 s EMBLEM
(For VPL-SX536)
4-409-076-71 s EMBLEM
(For VPL-SW526)
17 4-414-186-01 s HINGE, DOOR
18 4-417-067-01 s CUSHION
19 4-417-068-01 s CUSHION TOP COVER
20 4-420-084-01 s TAPE, SPEAKER
7-685-648-79 s SCREW +BVTP 3X12 TYPE2 IT-3
VPL-SW536 4-3
Bottom Cover Block
105
BVTP3 x 12
107
106
PSW3 x 8
111
101
110
111
109 111
BVTP
3 x 12
BVTP
3 x 12
108
104
113
102 103
112
4-4 VPL-SW536
Bottom Cover Block

101 ! X-2586-470-1 s ASSY, BOTTOM COVER
102 4-400-404-02 s HOLDER, FILTER
103 4-400-488-01 s FILTER A
104 4-400-490-01 s FILTER B
105 4-400-493-01 s FOOT, REAR
106 4-400-494-01 s ADJUSTER
107 4-400-495-01 s COVER ADJUSTER
108 4-408-045-01 s TAPE, COVER GLASS
109 4-410-404-01 s SHEET, BOTTOM
110 ! 4-413-327-01 s LABEL, CAUTION
111 4-420-084-01 s TAPE, SPEAKER
112 ! 4-447-820-01 s COVER, GLASS WINDOW
113 4-453-154-01 s GLASS, COVER (MC)
7-682-948-01 s SCREW +PSW 3X8

VPL-SW536 4-5
Board Block
To Lamp PSW3 x 8
203
PSW3 x 8
205 C
210
To TL board
To DC fan
To DC fan To DC fan
PSW
201 3x8
PSW PSW3 x 8
3x8
To HA board
To TA board/V board
A
To DC fan
213 212
To DC fan 211
205 To HA board 215
208 PSW3 x 8
PSW D
204 B 3x8
D
209
PSW
PSW 3x8
3x8 To Thermal fuse
PSW
3x8
202
C
PSW
3x8
PSW3 x 8
PSW A
3x8
207
214
B
K3 x 10
206
PSW3 x 8
PSW3 x 8
PSW4 x 8
4-6 VPL-SW536
Board Block

201 A-1914-404-A s MOUNTED CIRCUIT BOARD, C
(For VPL-SW536)
A-1914-412-A s MOUNTED CIRCUIT BOARD, C
(For VPL-SX536)
A-1914-413-A s MOUNTED CIRCUIT BOARD, C
(For VPL-SX526)
202 A-1914-405-A s MOUNTED CIRCUIT BOARD, Q
203 ! 1-474-253-22 s POWER UNIT
204 ! 1-474-375-12 s POWER UNIT
205 1-500-082-11 s CLAMP, SLEEVE FERRITE
206 ! 1-821-584-11 s INLET, AC (WITH NOISE FILTER)
207 ! 1-858-891-11 s SPEAKER(16W)
208 ! 1-968-122-11 s SUB HARNESS (PS 2P)
209 1-969-014-11 s SUB HARNESS (11P)
210 1-969-015-11 s SUB HARNESS (LPS 5P)
211 1-969-016-11 s SUB HARNESS (V/TA TO C)
212 4-400-487-31 s SHEET, CONNECTOR
213 ! 4-400-503-31 s PANEL, CONNECT
214 4-461-208-01 s CUSHION WASHER
215 4-673-018-02 s SCREW SPECIAL HEAD
7-682-249-09 s SCREW +K 3X10

7-682-948-01 s SCREW +PSW 3X8
7-682-961-01 s SCREW +PSW 4X8
VPL-SW536 4-7
DC Fan and Lamp Block
307 To C board
To C board
307
PSW
3x8
To Power unit (Ballast)
304
PWH To G board
3 x 10
To C board
301
302
305
BVTP
306
3 x 12
PSW3 x 8
303
307
To C board
PSW PSW
3x8 3x8

301 A-1914-410-A s MOUNTED CIRCUIT BOARD, TL
302 ! 1-839-597-11 s LAMP CONNECTOR ASSY
303 ! 1-855-143-11 s FAN, DC
304 ! 1-855-147-11 s FAN, DC (80 SQUARE)
305 1-966-013-11 s SUB HARNESS (TL TO C)
306 1-968-119-11 s SUB HARNESS (FUSE 3P)
307 4-408-035-01 s TAPPING SHAFT
7-682-948-01 s SCREW +PSW 3X8

7-685-903-31 s TAPPING +PWH 3X10 TYPE2 N-S
4-8 VPL-SW536
S Lens Block
PSW3 x 8
PSW3 x 8
407
401
To C board
BVTP
3 x 12
PSW
3x8
406 405 To C board
To C board
BVTP
3 x 12
BVTP
3 x 12
402 BVTP
3 x 12 VPL-SX536 only
BVTP3 x 12
403
404
406
401 A-1866-054-A s LENS ASSY, S
402 A-1914-408-A s MOUNTED CIRCUIT BOARD, V
403 A-1914-411-A s MOUNTED CIRCUIT BOARD, TA
404 ! 1-855-141-11 s FAN, DC (L) PSW3 x 8
405 ! 1-855-142-21 s FAN, DC (R)
BVTP3 x 12
406 4-400-491-01 s CUSHION SIROCCO A
407 4-461-208-01 s CUSHION WASHER
7-682-948-01 s SCREW +PSW 3X8
VPL-SW536 4-9
Optics Block
508
501
B2 x 5
B2 x 5
507
504
502
B2 x 5
506
503
509
505
The illustration indicates VPL-SX536.
4-10 VPL-SW536
Optics Block

501 A-1797-892-A s CONVERTER, P/S
502 A-1863-971-A s IN-POLARIZER ASSY (B), S
(For VPL-SX536)
A-1863-978-A s PANEL ASSY (B), POLARIZATION
(For VPL-SW536/SW526)
503 A-1866-055-A s IN-POLARIZER ASSY (R), S
A-1866-060-A s IN-POLARIZER ASSY (R), S
(For VPL-SX536)
504 A-1866-056-A s IN-POLARIZER ASSY (G), S
A-1866-061-A s IN-POLARIZER ASSY (G), S
(For VPL-SX536)
505 A-1930-578-A s PRISM ASSY(S075MC), S
(For VPL-SW536)
A-1930-579-A s PRISM ASSY(S063MC), S
(For VPL-SX536)
A-1930-580-A s PRISM ASSY(S075-25MC), S
(For VPL-SW526)
506 A-1866-058-A s UNIT ASSY(S075), S
(For VPL-SW536)
A-1866-063-A s UNIT ASSY(S063), S
(For VPL-SX536)
A-1887-606-A s UNIT ASSY(S075-25), S
(For VPL-SW526)
507 A-1930-581-A s OPTICS BLOCK ASSY(S075MC), S
(For VPL-SW536)
A-1930-582-A s OPTICS BLOCK ASSY(S063MC), S
(For VPL-SX536)
A-1930-583-A s OPTICS BLOCK ASSY(S075-25MC),S
(For VPL-SW526)
508 A-1900-580-A s COVER (FE)
509 4-382-854-11 s SCREW (M3X10), P, SW (+)
7-621-771-06 s SCREW +B 2X5
VPL-SW536 4-11
4-3. Packing Materials & Supplied
Accessories
----------------------------------------
PACKING MATERIALS & SUPPLIED ACCESSORIES
----------------------------------------
*1:[For SY]
*2:[For CN]
Ref. No.
or Q'ty Part No. SP Description
1pc *2 A-1933-696-A s WALL MOUNT BRACKET ASSY
1pc 1-490-463-11 s REMOTE COMMANDER (RM-PJ8)
1pc *2 ! 1-839-058-11 s AC POWER-SUPPLY CORD (For CN)
1pc *2 4-420-333-01 s COVER, WALL PLATE
1pc *2 4-420-334-01 s ACCESSORIES
1pc 4-437-934-03 s APPLICATION, CD-ROM
1pc *1 ! 4-453-100-01 s PACK, CD-ROM
OPERATING,INSTRUCTIONS
(JAPANESE, ENGLISH, FRENCH,
SPANISH, GERMAN, ITALIAN,
SIMPLIFIED CHINESE, RUSSIAN)
NOTICES FOR THE SOFTWARE LICEN
(JAPANESE, ENGLISH, FRENCH,
SPANISH, GERMAN, ITALIAN,
SIMPLIFIED CHINESE, RUSSIAN)
1pc *2 ! 4-461-020-11 s INSTALLATION INSTRUCTIONS
(SIMPLIFIED CHINESE)
1pc *2 ! 4-461-525-01 s OPERATING INSTRUCTIONS
(SIMPLIFIED CHINESE)
4-12 VPL-SW536
Overall Overall
Section 5
Block Diagrams
C
LVDS BUS
CVBS
VIDEO IN DISPLAY LVDS BUS LCD TG/ I2C BE PANEL 36 R_12Phase 12 PANEL R
PORT LU/WB/UF TG DRIVER
2 S-Y, S-C
S VIDEO IN
D-SUB1_R/G/B 3 ANALOG
INPUT A RGB/YPBPR D-SUB1_H/V 2 FRONT END
BUFF SPI_CLK, SW
SPI_TXD,
SPI_DE_CS
WP_DDC TG
DE_RESET
EEPROM
V_PANEL
SPI_RXD,
D-SUB2_R/G/B 3
SPI_CS0/1 5
G_12Phase 12 PANEL G
INPUT B RGB D-SUB2_H/V 2 SPI BUS
BUFF
WP_DDC RGB_30bit, HS,
EEPROM
VS, CLK, DE
INPUT C HDMI HDMI SPI FLASH_WP
WP_DDC FLASH
EEPROM
Q 3 VIDEO
B_12Phase 12 PANEL B
AMP
MON_OUT_R/G/B
OUTPUT MONITOR MON_OUT_H/V 2 SYNC
BUFF
SELECTOR
LAMP_CONTROL SUB
LAMP_UART POWER
SCI
CPU
LAMP_CONT, LAMP_COVER 2
UNIT
(BALLAST)
UART
VIDEO_L
L (MONO)
S VIDEO IN/ MAIN CPU
AUDIO VIDEO_R
VIDEO IN BUFF SW SUB 3.3V
R LAMP
D-SUB_L/R 2 SDATA, I2C BUS2 FAN
INPUT B AUDIO
SCLK, DRV
PRE RESET, DC FAN
MIC IN LRCK,
AMP MAIN NVM_WP 2 (INTAKE)
AUDIO MCLK 4 FAN
CODEC NVM FAN_PROT, DRV
D-SUB_L/R 2 FAN_DET_CONT,
INPUT A AUDIO
FAN_STOP_PW 3
SP_MUTE SLOW FAN
AUDIO FAN_CONT0/1/2/3/4 5
SPEAKER DAC BUFF DRV
AMP DC FAN
(EXHAUST)
BUFF FAN
OUTPUT AUDIO DRV
AMP
FAN DC FAN
DRV (LAMP)
RS-232C UART
RS-232C UART
DRIVER SW
ROBSTER GPIO
TOPAZ GPIO
USB
KEY 0
SLOW ADC
LAN PHY RMII
KEY 1
EXT_CHANGE_STATUS
CHANGE_STATUS,
SUB 3.3V PANEL

MON_OUT_EN,
232C_NWUSB
G SENSOR
DEVICE_SEL,
PROTECTOR TEMP
SP_MUTE
ACT SEL0
UART
WP_DDC
PHY_INT
I2C BUS1
TOPAZ GPIO
ROBSTER GPIO
POWER_ON
ECO_ON
V HB HA U TA TL
POWER THERMAL
FILTER POWER LAMP AMBIENT LAMP
COVER LED SIRCS
KEY
COVER TEMP TEMP
UNIT FUSE
Overall
VPL-SW536 5-1 5-1
Frame Wiring Frame Wiring
Section 6
Frame Wiring
CN201 1
CN1500 !
S VIDEO
S VIDEO IN/ SPEAKER
VIDEO IN J200
VIDEO
CN1400
FLEXIBLE
J1500 PANEL R
AUDIO
INPUT A
CN200
CN1401
RGB/YPBPR 2
FLEXIBLE
PANEL G
INPUT B RGB
C
CN400
CN1402
INPUT C HDMI
FLEXIBLE
CN801
PANEL B
Note: The components identified
CN802 by mark contain confidential
information.
Strictly follow the instructions
CN109 CN5
CN803 whenever the components are 3
LAN repaired and/or replaced. TL
J202
L (MONO) CN108 CN7

S VIDEO IN/
VIDEO IN
AUDIO R
TA
J201
INPUT B AUDIO
CN201 CN100
J200 CN1
AUDIO
Q V 4
OUTPUT CN202 CN111
MONITOR
CN104 CN21 CN22 CN31

J203
MIC IN HA HB
CN107
CN200
RS-232C
CN500 CN106 CN1600 CN1601 CN1602 CN1603 CN1604 CN33
U
! 5
AC IN
CN101
! CN202 X2
! !
! CN102 X1
POWER UNIT
X3
! DC FAN DC FAN DC FAN DC FAN DC FAN
POWER UNIT (INTAKE) (INTAKE) (EXHAUST) (EXHAUST) (LAMP)
CN201 (BALLAST) ! ! ! ! !
LAMP
THERMAL FUSE
Frame Wiring
VPL-SW536 6-1 6-1
A B C D E F G H
SAFETY CHECK-OUT
After correcting the original service problem,

perform the following safety checks before
releasing the set to the customer :
Check the metal trim, metallized knobs,

screws, and all other exposed metal parts for AC
leakage. Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part

to earth ground and from all exposed metal
parts to any exposed metal part having a return
to chassis, must not exceed 3.5 mA. Leakage
current can be measured by any one of three
methods.
1. A commercial leakage tester, such as the

Simpson 229 or RCA WT-540A. Follow the
manufacturers instructions to use these
instruments.
2. A battery-operated AC milliammeter. The
Data Precision 245 digital multimeter is
suitable for this job.
3. Measuring the voltage drop across a resistor
by means of a VOM or battery-operated AC
voltmeter. The limit indication is 5.25 V, so
analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa
SH-63Trd are examples of a passive VOM
that is suitable. Nearly all battery operated
digital multimeters that have a 20 V AC
range are suitable. (See Fig. A)
To Exposed Metal
Parts on Set
AC
0.15 F 1.5 kZ voltmeter
(5.25V)
Earth Ground
Fig A. Using an AC voltmeter to check AC leakage.
VPL-SW536
VPL-SW536 (CN)
VPL-SW536 (SY)
VPL-SW526 (SY)
VPL-SX536 (CN) Printed in Japan
VPL-SX536 (SY) J, E Sony Corporation 2012. 12 32
9-878-441-02 2012

VPL SW536

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

VPL SW536

Uploaded by

Copyright:

Available Formats

DATA PROJECTOR

For safety, do not connect the connector for periph-

Fara fr explosion vid felaktigt placerat batteri.

Manual Structure 2. Adjustments

Overall ............................................................................. 5-1

Frame Wiring................................................................... 6-1

Purpose of this manual

The service of this unit is basically performed by the replacement of board.

. Operating Instructions PDF (Supplied with unit)

. Quick Reference Manual (Supplied with unit)

. Internet Explorer is a registered trademarks of Microsoft Corporation in the United

1-1. Appearance Figure/Board Location

VPL-SW536 1-1 (E)

Tighten the each screw with the torque below.

. B2 x 5: 0.19 ?0.03 N.m

1-2 (E) VPL-SW536

1-3-1. Top Cover Assembly

7 Top cover cushion

Bottom of this unit

VPL-SW536 1-3 (E)

1-4 (E) VPL-SW536

. Remove the top cover assembly. (Refer to Section 1-3-1.)

Top cover assembly

3 Hooks of the top cover assembly

4 Hooks of the top cover assembly

VPL-SW536 1-5 (E)

. Remove the top cover assembly. (Refer to Section 1-3-1.)

Top cover assembly

1-6 (E) VPL-SW536

. Remove the top cover assembly. (Refer to Section 1-3-1.)

Top cover assembly

HB board 2 Two hooks

VPL-SW536 1-7 (E)

. Remove the top cover assembly. (Refer to Section 1-3-1.)

1-8 (E) VPL-SW536

. Remove the top cover assembly. (Refer to Section 1-3-1.)

3 Five harnesses 9 Board bracket

C board 5 Three harnesses

6 Three flexible flat cables

VPL-SW536 1-9 (E)

![ Sub board bracket

. Remove the top cover assembly. (Refer to Section 1-3-1.)

1-10 (E) VPL-SW536

. Remove the top cover assembly. (Refer to Section 1-3-1.)

3 Two cushion washers

VPL-SW536 1-11 (E)

. Remove the top cover assembly. (Refer to Section 1-3-1.)

5 Four screws 6 Screw

7 Power unit cover

3 Two screws 1 Harness

1-12 (E) VPL-SW536

. Remove the top cover assembly. (Refer to Section 1-3-1.)

5 Ballast case (upper)

VPL-SW536 1-13 (E)

. Remove the top cover assembly. (Refer to Section 1-3-1.)

1-14 (E) VPL-SW536

. Remove the top cover assembly. (Refer to Section 1-3-1.)

3 Duct holder (Exhaust)

VPL-SW536 1-15 (E)

. Remove the top cover assembly. (Refer to Section 1-3-1.)

4 Lamp fan case (upper)

2 Lamp fan case (lower)

6 DC fan (for lamp)
