Platinum User Prioritizing (RAN17.1 - 01)

WCDMA RAN
Platinum User Prioritizing Feature

Parameter Description
Issue 01
Date 2015-03-25
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or representations
of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: support@huawei.com
Issue 01 (2015-03-25) Huawei Proprietary and Confidential i

Copyright © Huawei Technologies Co., Ltd.
WCDMA RAN
Platinum User Prioritizing Feature Parameter Description Contents
Contents
1 About This Document..................................................................................................................1

1.1 Scope..............................................................................................................................................................................1
1.2 Intended Audience..........................................................................................................................................................1
1.3 Change History...............................................................................................................................................................1
1.4 Differences Between Base Station Types.......................................................................................................................3
2 Overview.........................................................................................................................................5
2.1 Introduction....................................................................................................................................................................5
2.2 Benefits...........................................................................................................................................................................5
2.3 Architecture....................................................................................................................................................................6
2.4 Classification of Users....................................................................................................................................................7
3 Identification and Maintenance of Platinum Users.............................................................11

4 Platinum User Paging Prioritizing During the Paging Phase.............................................15
5 Platinum User Prioritizing During the RRC Connection Setup Phase............................16
5.1 Flow Control.................................................................................................................................................................17
5.2 RRC Admission............................................................................................................................................................17
5.3 RRC Preemption...........................................................................................................................................................17
5.3.1 Preemption Triggered by RRC Connection Request Failures with the Cause Value "Originating Conversational Call"
or "Terminating Conversational Call"................................................................................................................................17
5.3.2 Preemption Triggered by RRC Connection Request Failures with a Cause Value Other Than "Originating
Conversational Call" and "Terminating Conversational Call"...........................................................................................18
6 Platinum User Prioritizing During the RAB Setup Phase...................................................19

6.1 RAB Admission............................................................................................................................................................20
6.2 RAB Preemption...........................................................................................................................................................20
7 Improvement of Platinum User Experience During the Service Processing Phase.......25

7.1 QoE Guarantee for Platinum Users..............................................................................................................................25
7.1.1 Basic QoE Guarantee for Platinum Users.................................................................................................................25
7.1.2 Enhanced QoE Guarantee for Platinum CS Users.....................................................................................................26
7.2 State Transition Policies for Platinum Users................................................................................................................28
8 Related Features...........................................................................................................................30
9 Network Impact...........................................................................................................................32
Issue 01 (2015-03-25) Huawei Proprietary and Confidential ii

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description Contents
10 Engineering Guidelines...........................................................................................................34
10.1 When to Use Platinum User Prioritizing....................................................................................................................34
10.2 Required Information.................................................................................................................................................34
10.3 Planning......................................................................................................................................................................35
10.4 Deployment................................................................................................................................................................35
10.4.1 Requirements...........................................................................................................................................................35
10.4.2 Data Preparation......................................................................................................................................................37
10.4.3 Activation................................................................................................................................................................49
10.4.4 Activation Observation............................................................................................................................................56
10.4.5 Deactivation.............................................................................................................................................................56
10.5 Performance Monitoring.............................................................................................................................................57
10.5.1 Increase in Connection Success Rates of Platinum Users.......................................................................................58
10.5.2 Voice Quality Improvement of Platinum Users......................................................................................................59
10.5.3 HSPA Throughput Improvement of Platinum Users...............................................................................................59
10.5.4 Increase in Call Drop Rate for Cell.........................................................................................................................60
10.6 Parameter Optimization..............................................................................................................................................60
10.7 Troubleshooting..........................................................................................................................................................60
11 Parameters...................................................................................................................................61
12 Counters....................................................................................................................................189
13 Glossary.....................................................................................................................................211
14 Reference Documents.............................................................................................................212
Issue 01 (2015-03-25) Huawei Proprietary and Confidential iii

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 1 About This Document
1 About This Document
1.1 Scope
This document describes the WRFD-150204 Platinum User Prioritizing, including its technical
principles, related features, network impact, and engineering guidelines.
This document applies to the following NE types.
NE Type NE Model
RNC BSC6900, BSC6910
NodeB Macro Not involved
Micro Not involved
LampSite Not involved
1.2 Intended Audience

This document is intended for personnel who:
l Need to understand the features described herein

l Work with Huawei products
1.3 Change History

This section provides information about the changes in different document versions. There are
two types of changes, which are defined as follows:
l Feature change
Changes in features of a specific product version
l Editorial change
Issue 01 (2015-03-25) Huawei Proprietary and Confidential 1

WCDMA RAN
Changes in wording or addition of information that was not described in the earlier version
RAN17.1 01 (2015-03-25)
This issue does not include any changes.
RAN17.1 Draft A (2015-01-15)

Compared with Issue 04 (2014-12-30) of RAN16.0, Draft A (2015-01-15) of RAN17.1 includes
the following changes.
Change Change Description Parameter Change

Type
Feature Added descriptions of the function of Added the following parameters:

change enhanced QoE guarantee for platinum l PtCSUserEnhSwitch
CS users. For details, see the following (BSC6900,BSC6910)
sections:
l ULActulLoadStaForPtPrior
l 7.1.2 Enhanced QoE Guarantee (BSC6900,BSC6910)
for Platinum CS Users
l DLPwrLoadStaForPtPrior
l 9 Network Impact (BSC6900,BSC6910)
l 10.1 When to Use Platinum User l DchUserLoadStaForPtPrior
Prioritizing (BSC6900,BSC6910)
l 10.2 Required Information l PsBlerTarDeltaForPtUser
l 10.4 Deployment (BSC6900,BSC6910)
l PsUlInitLimitRateForPt
(BSC6900,BSC6910)
l PsDlInitLimitRateForPt
(BSC6900,BSC6910)
l DlOtherThdForPt
(BSC6900,BSC6910)
Modified descriptions of impacted None

features in 8 Related Features.
Added the function of platinum user Added the following parameters:

paging prioritizing. For details, see the l PTCSPagingPreemptSwitch
following sections: (BSC6900,BSC6910)
l 4 Platinum User Paging l PTPSPagingPreemptSwitch
Prioritizing During the Paging (BSC6900,BSC6910)
Phase
l 10.4 Deployment

WCDMA RAN
Change Change Description Parameter Change

Type
Added descriptions of state transition Added the following parameter:

policies for platinum users. For details, PTUserStateTransStrategy
see the following sections: (BSC6900,BSC6910)
l 7.2 State Transition Policies for
Platinum Users
l 10.4 Deployment
Added descriptions of performance None

monitoring for platinum users in cells
enabled with the lightweight service
experience evaluation function. For
details, see section 10.5.3 HSPA
Throughput Improvement of
Platinum Users.
Modified descriptions of the impact of None

this feature on call-drop-rate-related
counters. For details, see section 10.5.4
Increase in Call Drop Rate for Cell.
Editorial None None

change
1.4 Differences Between Base Station Types

Feature Support by Macro, Micro, and LampSite Base Stations
Feature ID Descriptio Supported by Controller Supported Supported LampSite

n (Y/N/NA) by Macro by Micro
(Y/N/NA) (Y/N/NA)
BSC6900 BSC6910
WRFD-15 Platinum Y Y N/A N/A N/A

0204 User
Prioritizin
g
NOTE
Y indicates that a feature is supported; N indicates that a feature is not supported; NA indicates that an NE is
not involved, that is, a feature does not require the support of the NE.

WCDMA RAN
The features described in this document are implemented in the same way on macro, micro, and
LampSite base stations.The BTS3902E does not support any new and enhanced features or
functions in RAN17.1. For details, see1.3 Change History.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 2 Overview
2 Overview
2.1 Introduction
If network congestion occurs during, for example, large gatherings, sports events, or festivals,
it can become difficult for users to access the network. With the Platinum User Prioritizing
feature, the RNC preferentially improves experience of platinum users.
2.2 Benefits
This feature provides the following benefits:
l When network congestion occurs, platinum users preferentially access the network. This
enables platinum users to have a higher radio resource control (RRC) connection setup
success rate and radio access bearer (RAB) setup success rate than common users.
l This feature is applied when network access fails due to insufficiency of the following
resources:
– Power resources
– Credit resources
– Code resources
– Iub transmission resources
NOTE
This feature cannot increase the network access rate if the RRC connection setup and RAB setup
failures are caused by insufficient capacity licenses.
l When downlink coverage is weak, this feature allows NodeBs to increase the maximum
downlink transmit power for platinum users' conversational services, thereby increasing
their mean opinion scores (MOSs).
l When network congestion occurs, this feature restricts data transmission of common PS
users to reduce cell load and interference, thereby improving user experience and the call
drop rate of platinum users.
l Platinum users can have higher throughput than common users because the configured SPI
weight of platinum users is higher. For details about SPI weight, see Differentiated HSPA
Service Feature Parameter Description.

WCDMA RAN
2.3 Architecture
Figure 2-1 shows the service procedure with Platinum User Prioritizing enabled.
Figure 2-1 Service procedure with Platinum User Prioritizing enabled
The Platinum User Prioritizing feature works as follows during a service procedure:
1. The RNC identifies platinum users and maintains the IMSI-to-TMSI mapping table.
The operator configures platinum users' IMSIs by running the ADD UPLATINUMIMSI
command. The RNC maintains the IMSI-to-TMSI mapping table for platinum users based
on the RRC Connection Request, Common ID, and Non-Access Stratum (NAS) messages.
Upon receiving an RRC Connection Request message, if the message contains the IMSI
or TMSI, the RNC searches the IMSI-to-TMSI mapping table. If the RNC finds the IMSI
or TMSI in the table, it identifies the user as platinum. If the message contains the P-TMSI,
the RNC identifies the user as non-platinum.

WCDMA RAN
NOTE
IMSI stands for international mobile subscriber identity.

TMSI stands for temporary mobile subscriber identity.
P-TMSI stands for packet temporary mobile subscriber identity.
For details about how to identify platinum users, see 3 Identification and Maintenance of Platinum
Users.
2. Paging for platinum users is preferentially processed.
When paging channels are congested, paging messages for platinum users can preempt
paging channels, thereby improving the CS and PS paging success rate of platinum users.
3. The RNC allows platinum users to preferentially establish RRC connections during the
RRC connection setup phase.
During the flow control of RRC connection setup, the RNC raises all services for platinum
users to the same priority as conversational services, which have the highest priority among
all services except emergency calls. During the RRC connection setup phase, platinum
users can unconditionally preempt the resources for non-platinum users. The purpose is to
increase the RRC connection setup success rate of platinum users.
4. The RNC allows platinum users to preferentially establish RAB connections during the
RAB setup phase.
During the RAB setup phase, platinum users can unconditionally preempt the resources for
non-platinum users. The purpose is to increase the RAB setup success rate of platinum
users.
5. The Platinum User Prioritizing feature takes the following measures to improve the service
experience of platinum users during the service processing phase.
l QoE guarantee for platinum users
- Basic QoE guarantee for platinum users
NodeBs increase the maximum downlink transmit power for platinum users'
conversational services. This improves the voice quality of platinum users in weak
downlink coverage areas.
The initial SPI weight of platinum users is fixed to 100%. If different SPI weights are
configured, platinum users are preferentially scheduled so that they can obtain the
required resources. If the SPI weight of some non-platinum users (for example, gold
users) is also set to 100%, platinum and non-platinum users have the same scheduling
priority.
- Enhanced QoE guarantee for platinum CS users
This feature restricts data transmission of common PS users in platinum CS cells to
reduce cell load and interference, thereby improving experience of platinum users.
l State transition policies for platinum users
State transition policies can be specified for platinum users by the users' IMSIs to meet
different state transition requirements.
2.4 Classification of Users

In versions earlier than RAN15.0, users can be classified into gold, silver, and bronze to
implement service differentiation during the RAB setup phase and during later phases. With the
Platinum User Prioritizing feature, users can be classified into platinum and common during the

WCDMA RAN
RRC connection setup phase. In addition, the platinum user type is added to the RAB setup
phase.
The relationships between platinum users and the gold, silver, and bronze users are as follows:
Table 2-1 describes the differences between platinum users and the gold, silver, and bronze
users.
1. The operator runs the ADD UPLATINUMIMSI command to configure IMSIs for
platinum users. The RNC determines whether users are gold, silver, or bronze users based
on the ARP-to-user-type mapping in RAB Assignment Request messages.
2. The network access of platinum users can be guaranteed during paging, RRC connection
setup and RAB setup, whereas the network access of gold, silver, and bronze users can be
guaranteed only during the RAB setup phase.
3. A user can be a platinum user and at the same time a gold, silver, or bronze user. For such
a user, the initial SPI weight is 100%, and the maximum downlink transmit power for
conversational services is increased by PtUserRlMaxDlPwrDelta(BSC6900,BSC6910)
dB. Other processing mechanisms, such as the GBR and the mapping of SPI and rate range
to SPI weight, are the same as those for a gold, silver, or bronze user.
4. Whether platinum, gold, silver, and bronze users perform the LDR or OLC actions is as
follows:
l Platinum users are not selected to perform the LDR or OLC actions.
l Gold users can be selected to perform the LDR or OLC actions based on parameter
settings.
l Silver and bronze users are selected to perform the LDR or OLC actions by default.

WCDMA RAN
Table 2-1 Differences between platinum users and the gold, silver, and bronze users
User Identif Paging Phase RRC RAB Service

Type ication Connection Setup Processing
Metho Setup Phase Phase Phase
d
Platinu IMSI Improves the l Flow Control Supports l Load Control

m users paging priority Improves the preemptio Platinum users
of platinum priority of ns. are not selected
users platinum to perform the
users during LDR or OLC
flow control actions.
in the RRC l CS Service
connection Quality
setup phase. The maximum
l RRC downlink
Admission transmit power
and for
Preemption conversational
Supports services is
preemptions. increased by
PtUserRl-
MaxDlPwrDel
ta
(BSC6900,
BSC6910) dB.
l PS Service
Quality
Users are
differentiated
by setting SPI
Weight to
100%.

WCDMA RAN
User Identif Paging Phase RRC RAB Service

Type ication Connection Setup Processing
Metho Setup Phase Phase Phase
d
Gold, ARP No special No special Supports l Load Control

silver, attribute operation is operation is preemptio Gold users can
and performed for performed for ns. be selected to
bronze gold, silver, or gold, silver, or perform the
users bronze users. bronze users. LDR or OLC
actions based
on parameter
settings.
Silver and
bronze users
are selected to
perform the
LDR or OLC
actions by
default.
l CS Service
Quality
No special
operation is
performed for
gold, silver, or
bronze users.
l PS Service
Quality
Users are
differentiated
by flexibly
configuring
SPI Weight.
In this document, only two types of users are involved: platinum users and common users.
Common users refer to non-platinum users during the paging and RRC connection setup
phases and gold, silver, and bronze users during the RAB setup phase.
In this document, CS services refer to conversational services, PS services consist of streaming,

interactive, and background services, and PS best effort (BE) services consist of interactive and
background services.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 3 Identification and Maintenance of Platinum Users
3 Identification and Maintenance of Platinum

Users
The IMSIs of platinum users must be configured on the RNC so that the RNC can identify them.
To ensure information security of platinum users, only the administrator or a user who has been
granted rights by the administrator can run the commands for configuring the platinum users'
IMSIs. The RNC maintains the IMSI-to-TMSI mapping table of platinum users, identifies
platinum users based on the TMSI or IMSI information in RRC Connection Request, Common
ID, and NAS messages, and allows platinum users to preferentially access the network.
Figure 3-1 and Figure 3-2 show the procedure for identifying and maintaining platinum users
during location update and TMSI reallocation, respectively.

WCDMA RAN
Figure 3-1 Identifying and maintaining platinum users during location update

WCDMA RAN
Figure 3-2 Identifying and maintaining platinum users during TMSI reallocation
The procedure for identifying and maintaining platinum users is as follows:
1. The Platinum User Prioritizing feature is activated when the

PTUSER_IDENTIFY_SWITCH switch under the PROCESSSWITCH
(BSC6900,BSC6910) parameter is turned on. The operator can configure a maximum of
3000 platinum users by setting the PlatinumIMSI(BSC6900,BSC6910) parameter to
platinum users' IMSIs.
2. If the information element (IE) "Initial UE identity" in an RRC Connection Request
message is IMSI or TMSI, the RNC searches the IMSI-to-TMSI mapping table. If the RNC
finds the IMSI or TMSI in the table, it identifies the user as platinum. If the IE "Initial UE
identity" is P-TMSI, the RNC identifies the user as common.
NOTE
According to section 8.5.1 in 3GPP TS 25.331, the priority of reporting the ID of a UE in descending
order is TMSI, P-TMSI, IMSI, and IMEI. That is, a UE preferentially reports its TMSI to the RNC,
regardless of whether the UE initiates a CS or PS service.
3. When the RNC receives a Common ID message from the CN, the RNC identifies the user
as platinum if the IMSI in this message is among the list of platinum users' IMSIs. If the
RRC Connection Request message for the user contains the TMSI, the RNC updates the
TMSI information of the user. Otherwise, the RNC does not update the TMSI information.
4. If the Location Update Accept or TMSI Reallocation Command message for a platinum
user contains the TMSI, the RNC updates the TMSI information of the platinum user.

WCDMA RAN
NOTE
In cross-Iur handover, SRNS relocation, and Direct Signaling Connection Re-establishment (DSCR)
scenarios, the target RNC or DRNC can identify platinum users only when
PTUSER_IDENTIFY_ENH_SWITCH under the PROCESSSWITCH(BSC6900,BSC6910) parameter
in the SET URRCTRLSWITCH command is set to 1.
The identification of platinum users may be incorrect under the following conditions:
l After the IMSIs of platinum users are configured, a platinum user sends the first RRC
Connection Request message.
In such a scenario, the TMSI information has not been saved. The RNC cannot identify the
platinum user during the RRC connection setup phase. However, after receiving a Common
ID message, the RNC can identify this platinum user and maintain the TMSI information.
l After a platinum user leaves the RNC service area, the CN reallocates the TMSI of the
platinum user to a common user under the RNC.
Because the platinum user's TMSI is still contained in the IMSI-to-TMSI mapping table,
the RNC still identifies the user as platinum when receiving the first RRC Connection
Request message. After receiving a Common ID message, the RNC identifies this user as
common and deletes the TMSI from the IMSI-to-TMSI mapping table.
l When a platinum user powers off his or her UE for a long time, the CN reallocates its TMSI
to another user.
In such a scenario, the TMSI of the platinum user is no longer contained in the IMSI-to-
TMSI mapping table. When the platinum user powers on its UE again and sends an RRC
Connection Request message to the RNC, the RNC does not identify this user as platinum.
However, after receiving a Common ID message from the CN, the RNC then identifies this
user as platinum.
The preceding analysis shows that identification of platinum users may be incorrect only when
the RNC receives the first RRC Connection Request message. The incorrect identification is
rectified when the RNC receives a Common ID message from the CN. Therefore, the
identification of platinum users is rarely incorrect.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 4 Platinum User Paging Prioritizing During the Paging Phase
4 Platinum User Paging Prioritizing During

the Paging Phase
When paging channels are congested, platinum users can initiate paging preemption, which
improves the CS and PS paging success rates of platinum users.
l CS services
When the PTCSPagingPreemptSwitch(BSC6900,BSC6910) in the SET
UDPUCFGDATA command is set to on, the CS service paging priority of platinum users
in idle mode or in the CELL_PCH/URA_PCH state is higher than the priorities of common
users processing conversational, streaming, interactive, background, and SMS paging
services.
l PS services
When the PTPSPagingPreemptSwitch(BSC6900,BSC6910) in the SET
UDPUCFGDATA command is set to on, the PS service paging priority of platinum users
in idle mode or in the CELL_PCH/URA_PCH state is the same as the CS service paging
priority of common users but is higher than the priorities of common users processing PS
streaming, interactive, background, and SMS paging services.

WCDMA RAN 5 Platinum User Prioritizing During the RRC Connection
Platinum User Prioritizing Feature Parameter Description Setup Phase
5 Platinum User Prioritizing During the RRC

Connection Setup Phase
During the RRC connection setup phase, the RNC allows platinum users to preferentially
establish RRC connections. This increases the RRC connection setup success rate for platinum
users.
The RNC takes measures of flow control and preemption during the RRC connection setup phase
to preferentially process service requests from platinum users.

5.1 Flow Control

If resources on network elements (NEs) are overloaded, the flow control function rejects RRC
connection setup requests. RRC connection requests with different cause values have different
flow control priorities. Conversational services have the highest flow control priority among all
services except emergency calls. For emergency calls, the flow control priority of platinum users
is the same as that of common users.
For all other services, the flow control priority of platinum users is the same as that of
conversational services for common users.
A lot of flow control measures can be taken in the network. For details, see Flow Control Feature
Parameter Description and E2E Flow Control Feature Parameter Description.
5.2 RRC Admission

During RRC admission, platinum users have the same admission priority as common users.
5.3 RRC Preemption

If the RRC admission of a platinum user fails, the platinum user can preempt the resources
occupied by common users.
Regardless of whether the preemption is triggered during RRC connection or RAB setup, if a
RAB is to be preempted, the preemption priority depends on the user comprehensive priority.
The higher the user comprehensive priority, the less likely its resources to be preempted. The
user comprehensive priority is ranked, depending on the setting of the PriorityReference
(BSC6900,BSC6910) parameter:
l If the PriorityReference(BSC6900,BSC6910) parameter is set to ARP, the RNC first
considers allocation/retention priority (ARP) and ranks the user comprehensive priority in
descending order of platinum, gold, silver, and bronze users. For the users having the same
ARP, the RNC then considers TrafficClass and ranks the user comprehensive priority in
descending order of conversational, streaming, interactive, and background services.
l If the PriorityReference(BSC6900,BSC6910) parameter is set to TrafficClass, the RNC
first considers TrafficClass and ranks the user comprehensive priority in descending order
of conversational, streaming, interactive, and background services. For the users having
the same TrafficClass, the RNC then considers ARP and ranks the user comprehensive
priority in descending order of platinum, gold, silver, and bronze users.
5.3.1 Preemption Triggered by RRC Connection Request Failures

with the Cause Value "Originating Conversational Call" or
"Terminating Conversational Call"
If a platinum user's RRC connection request fails with the cause value "Originating
Conversational Call" or "Terminating Conversational Call", a RAB preemption is triggered.
l The platinum user's RRC connection request can preempt the RABs of all users, except the
RABs for platinum users' conversational services, regardless of the setting of the

RSVDBIT5 switch under the RsvdPara1(BSC6900,BSC6910) parameter in the SET

UCACALGOSWITCH command.
The priority of the user to be preempted is related to the setting of the PriorityReference
(BSC6900,BSC6910) parameter. For details, see section 5.3 RRC Preemption.
l The RRC resources for all PS BE services can be preempted, regardless of the setting of
the PsBERrcPreemptVulnerable(BSC6900,BSC6910) parameter.
Platinum users first preempt RABs and then RRC resources. The user preemption priority of PS
BE RRC connections for platinum users is higher than that for common users.
5.3.2 Preemption Triggered by RRC Connection Request Failures

with a Cause Value Other Than "Originating Conversational Call"
and "Terminating Conversational Call"
If a platinum user's RRC connection request fails with a cause value other than "Originating
Conversational Call" or "Terminating Conversational Call", then
l If the PriorityReference(BSC6900,BSC6910) parameter is set to ARP, the priority of all

services for platinum users is higher than the priority of common users, according to the
ranking of the user comprehensive priority described in section 5.3 RRC Preemption In
this case, platinum users can preempt all RABs (including the RABs for conversational
services) of common users. The RAB with the lowest user comprehensive priority is
preempted first. The PS BE RRC resources occupied by common users can also be
preempted. Platinum users first preempt RABs and then RRC resources.
l If the PriorityReference(BSC6900,BSC6910) parameter is set to TrafficClass, preemption
is related to the setting of the PtUserAbsolutePriority(BSC6900,BSC6910) parameter.
– If the PtUserAbsolutePriority(BSC6900,BSC6910) parameter is set to True, the RNC
preferentially processes PS service requests from platinum users. The platinum users
can preempt all RABs (including the RABs for conversational services) of common
users. The RAB with the lowest user comprehensive priority is preempted first. The PS
BE RRC resources occupied by common users can also be preempted. Platinum users
first preempt RABs and then RRC resources.
– If the PtUserAbsolutePriority(BSC6900,BSC6910) parameter is set to False, platinum
users can preempt the RABs (excluding the RABs for conversational services) of
common users. The RAB with the lowest user comprehensive priority is preempted
first. The PS BE RRC resources occupied by common users can also be preempted.
Platinum users first preempt RABs and then RRC resources.
NOTE
l The RNC allows a platinum user to preempt resources, regardless of whether the platinum user supports
preemption or whether the user to be preempted can be preempted.
For platinum users, the RABs for conversational services and the RABs for combined services
containing conversational services cannot be preempted.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 6 Platinum User Prioritizing During the RAB Setup Phase
6 Platinum User Prioritizing During the RAB

Setup Phase
During the RAB setup phase, the RNC allows platinum users to preferentially establish RABs.

WCDMA RAN
6.1 RAB Admission

During RAB admission, platinum users have the same priority as common users.
6.2 RAB Preemption

If the RAB admission of a platinum user fails, the platinum user can preempt the resources
occupied by common users or other platinum users.
Preemption occurs as follows:
l If RAB requests of conversational services for platinum users fail, preemption is triggered.
In this scenario, the RAB preemption of platinum users is the same as the preemption
triggered by RRC connection request failures of conversational services for platinum users.
For details about preemption, see section 5.3.1 Preemption Triggered by RRC
Connection Request Failures with the Cause Value "Originating Conversational
Call" or "Terminating Conversational Call".
l If RAB requests of non-conversational services for platinum users fail, preemption is as
follows:
– If the PriorityReference(BSC6900,BSC6910) parameter is set to ARP, the priority of
all services for platinum users is higher than the priority of common users, according
to the ranking of the user comprehensive priority described in section 5.3 RRC
Preemption In this case, platinum users preempt the RABs of common users. If the
preemption fails, preemption is then performed between platinum users. If the user
comprehensive priority of a platinum user is lower than that of the platinum user that
triggers the preemption, the RABs for the former can be preempted. In addition, PS BE
RRC resources occupied by common users can be preempted. Platinum users first
preempt RABs and then RRC resources.
– If the PriorityReference(BSC6900,BSC6910) parameter is set to TrafficClass,
preemption is related to the setting of the PtUserAbsolutePriority
(BSC6900,BSC6910) parameter.
1. If the PtUserAbsolutePriority(BSC6900,BSC6910) parameter is set to True, the RNC
preferentially processes PS service requests from platinum users. The priority of all
services for platinum users is higher than the priority of common users. Therefore, the
platinum users' PS services can preempt all RABs of common users. If the preemption
fails, preemption is then performed between platinum users. If the user comprehensive
priority of a platinum user is lower than that of the platinum user that triggers the
preemption, the RABs for the former can be preempted. In addition, PS BE RRC
resources occupied by common users can be preempted. Platinum users first preempt
RABs and then RRC resources.
The user comprehensive priority is ranked in descending order as follows:
{platinum user + conversational} > {platinum user + streaming} > {platinum +
interactive} > {platinum + background} > {gold user + conversational} > {silver user
+ conversational} > {bronze user + conversational} > {gold user + streaming} >
{silver user + streaming} > {bronze user + streaming} > {gold user + interactive} >
{silver user + interactive} > {bronze user + interactive} > {gold user + background}
> {silver user + background} > {bronze user + background}

WCDMA RAN
2. If the PtUserAbsolutePriority(BSC6900,BSC6910) parameter is set to False, the

RABs for the user whose user comprehensive priority is lower than that of the platinum
user that triggers the preemption can be preempted. The PS BE RRC resources
occupied by common users can also be preempted. The priority of PS BE RRC
resources is higher than the priority of all RABs.
NOTE
l When a platinum user triggers a preemption, the RNC does not consider whether the platinum
user supports preemption or whether the user to be preempted can be preempted.
l Whether platinum users can preempt resources or the resources for platinum users can be
preempted does not depend on the settings of the DemarcPreemptSwitch(BSC6900,BSC6910)
and PreemptEnhSwitch(BSC6900,BSC6910) parameters. In addition, preemption cannot be
performed on a per operator basis.
l When the MbmsPreemptAlgoSwitch(BSC6900,BSC6910) switch is turned off, Multimedia
Broadcast Multicast Services (MBMSs) of platinum users cannot trigger preemption.
l For platinum users, the RABs for conversational services and the RABs for combined services
containing conversational services cannot be preempted.
l Wireless Priority Service (WPS) users can preempt the resources for platinum users' non-
conversational services, whereas platinum users cannot preempt the resources for WPS users.
For details about WPS, see Intelligent Access Control Feature Parameter Description.
l When the WRFD-010505 Queuing and Pre-Emption feature is enabled and the
QueueAlgoSwitch(BSC6900,BSC6910) switch in the SET UQUEUEPREEMPT command is
turned on, platinum users can perform queuing. The queuing priority of platinum users is the
same as the preemption priority.
l If the PreemptEnhSwitch
(BSC6900,BSC6910):PREEMPT_ENH_NODEB_PREEMPT_CE_SWITCH is turned
off, NodeB CE insufficiency cannot trigger preemption for platinum users. It is
recommended this switch be turned on.
l When PREEMPT_ENH_PT_USER_PREEMPT_ENH_SWITCH under the
PreemptEnhSwitch(BSC6900,BSC6910) parameter is set to on, platinum users can
preempt resources of common users if cell admission fails during procedures such as DRD,
channel fallback, or rate re-negotiation during admission control. When this switch is set
to off, platinum users perform the same operations as common users. That is, DRD, channel
fallback, rate re-negotiation during admission control, and preemption are performed in
sequence. Figure 6-1 shows the DRD and channel fallback procedure performed when this
switch is set to off. Figure 6-2 shows the DRD and channel fallback procedure performed
when this switch is set to on. The rate re-negotiation during admission control procedure
is similar to the following procedures.

WCDMA RAN
Figure 6-1 DRD and channel fallback procedure performed when

PREEMPT_ENH_PT_USER_PREEMPT_ENH_SWITCH is set to off

WCDMA RAN
Figure 6-2 DRD and channel fallback procedure performed when

PREEMPT_ENH_PT_USER_PREEMPT_ENH_SWITCH is set to on

WCDMA RAN
NOTE
For details about the priority of the candidate DRD cells, see section "4.2.1 Inter-Frequency DRD" of the
Directed Retry Decision Feature Parameter Description.
l During soft handovers, neither platinum users nor common users can trigger preemption.

WCDMA RAN 7 Improvement of Platinum User Experience During the
Platinum User Prioritizing Feature Parameter Description Service Processing Phase
7 Improvement of Platinum User Experience

During the Service Processing Phase
7.1 QoE Guarantee for Platinum Users
7.1.1 Basic QoE Guarantee for Platinum Users

Basic QoE guarantee for platinum users provides the following functions:
l The maximum downlink transmit power for platinum users' conversational services is
increased by the value of PtUserRlMaxDlPwrDelta(BSC6900,BSC6910) compared with
that for common users.
l If a platinum user is using a weak reception UE to process 12.2 kbit/s adaptive multirate
(AMR) services, the maximum downlink transmit power for the platinum user's
conversational services is max(RlMaxDlPwr(BSC6900,BSC6910) +
PtUserRlMaxDlPwrDelta(BSC6900,BSC6910) dB, SpecUserRlMaxDlPwr
(BSC6900,BSC6910)).
NOTE
If a weak reception UE is used, the maximum transmit power for the UE is determined by the
SpecUserRlMaxDlPwr(BSC6900,BSC6910) parameter. Generally, the value of the
SpecUserRlMaxDlPwr(BSC6900,BSC6910) parameter is greater than the value of the RlMaxDlPwr
(BSC6900,BSC6910) parameter. For details, see Voice Service Experience Improvement for Weak
Reception UEs Feature Parameter Description.
l If a platinum user is processing combined services, the maximum downlink transmit power
for the platinum user's conversational services is calculated based on the maximum
downlink transmit power for each service, rate matching gain, and spectrum spreading gain.
The maximum downlink transmit power for the platinum user should meet the power
requirements of each service.
l The initial SPI weight of platinum users is set to the highest value, 100%. If the operator
wants to implement service differentiation between platinum users and common users
based on the SPI weight, then the SPI weights of common users must be set to values less
than 100%. In cross-Iur handover scenarios, to implement service differentiation between
platinum users and common users based on the SPI weight under the DRNC, set

IubCPPrivateInterfaceSwitch(BSC6900,BSC6910) to ON so that the SRNC will send the

SPI weights of platinum users to the DRNC.
The setting and processing mechanism of GBR for platinum users is the same as that for
common users.
l The following features are not applicable to platinum users:
– WRFD-020107 Overload Control
– WRFD-020106 Load Reshuffling
– WRFD-140217 Inter-Frequency Load Balance Based on Configurable Load Threshold
– WRFD-150233 Differentiated Service Based on Resource Reservation
NOTE
For details about WRFD-020107, WRFD-020106, and WRFD-140217, see Load Control
Feature Parameter Description.
For details about WRFD-150233, see Differentiated Service Based on Resource Reservation
Feature Parameter Description.
7.1.2 Enhanced QoE Guarantee for Platinum CS Users

In addition to basic QoE guarantee for platinum users, this feature provides enhanced QoE
guarantee for platinum CS users to further improve the QoE of platinum CS users. This function
can be enabled by running the RNC MML command SET ULDCALGOPARA with
PtCSUserEnhSwitch(BSC6900,BSC6910) set to ON.
This function includes the following sub-functions:
l Identifies platinum CS cells
The RNC identifies platinum CS users by IMSIs and service types, and sends the
identification results to the NodeB. The RNC and NodeB determine whether a cell has
platinum CS users in any of the following procedures: new service admission, state
transition, handover, and user release. When a cell has at least one platinum CS user, it is
considered to be a platinum CS cell. When a cell has no platinum CS user, it is not a platinum
CS cell.
l Makes decisions on cell congestion
– Makes decisions on cell uplink congestion
A cell is in the uplink congestion state when the following condition is met: The actual
uplink service load of the cell is greater than or equal to the value of
ULActulLoadStaForPtPrior(BSC6900,BSC6910), and the load of CELL_DCH users
in the cell is greater than or equal to the value of DchUserLoadStaForPtPrior
(BSC6900,BSC6910).
– Makes decisions on cell downlink congestion
A cell is in the downlink congestion state when the following condition is met: The non-
HSDPA service load of the cell is greater than or equal to the value of
DLPwrLoadStaForPtPrior(BSC6900,BSC6910), and the load of CELL_DCH users in
the cell is greater than or equal to the value of DchUserLoadStaForPtPrior
(BSC6900,BSC6910).
NOTE
The ULActulLoadStaForPtPrior(BSC6900,BSC6910), DLPwrLoadStaForPtPrior

(BSC6900,BSC6910), and DchUserLoadStaForPtPrior(BSC6900,BSC6910) parameters have the same
values: light, normal, loaded, heavy, and overloaded.

l Increases the BLER of a common PS BE user

When a platinum CS cell is congested in the uplink, the uplink target BLER of a common
PS BE user is increased by the value of min[(BLERQuality(BSC6900,BSC6910) +
PsBlerTarDeltaForPtUser(BSC6900,BSC6910)), -10]. When a platinum CS cell is not
congested in the uplink or a cell is not a platinum CS cell, the uplink target BLER of a
common PS BE user is not increased.
l Decreases the maximum downlink transmit power on the RL of a common PS BE user
When a platinum CS cell is congested in the downlink, the maximum downlink transmit
power on the RL of a common PS BE user is decreased by the value of RlMaxDlPwr
(BSC6900,BSC6910) - PsRlMaxDlPwrDeltaForPt(BSC6900,BSC6910) of the
corresponding service. When a platinum CS cell is not congested in the downlink or a cell
is not a platinum CS cell, the maximum downlink transmit power on the RL of a common
PS BE user is not decreased.
NOTE
In this document, a common PS BE user refers to a common user that performs only PS BE services.
l Restricts the uplink rate of a common PS BE user
When a platinum CS cell is congested in the uplink, newly admitted uplink PS BE services
of a common PS BE user can only be carried on the DCH, and the initial uplink rate is
restricted to the value of PsUlInitLimitRateForPt(BSC6900,BSC6910). In addition, the
rate cannot be increased and the (CELL_DCH-to-HSUPA) D2E state transition is not
allowed.
l Restricts the downlink rate of a common PS BE user
When a platinum CS cell is congested in the downlink, newly admitted PS BE services of
a common R99 user are restricted to an initial downlink rate of PsDlInitLimitRateForPt
(BSC6900,BSC6910). In addition, the rate cannot be increased and the (CELL_DCH-to-
HSDPA) D2H state transition is not allowed.
l Adjusts the reserved power margin on R99 channels of a cell and decreases the maximum
available transmit power on HSPA channels
For a platinum CS cell, the reserved power margin of R99 channels is specified by min
[100, PWRMGN + PWRMGNDELTAFORPT], thereby decreasing the maximum
available transmit power on HSPA channels to reduce cell load.
For a non-platinum CS cell, the reserved power margin of R99 channels is specified by
PWRMGN.
l Enhances admission control to decrease the number of admitted PS services common users
When the RNC MML command SET UCACALGOSWITCH is executed to set
PT_CSUSER_CAC_ENH_SWITCH under CacSwitch(BSC6900,BSC6910) to ON for
a platinum CS cell,
– If the uplink or downlink power admission algorithm is enabled, that is,
NBMUlCacAlgoSelSwitch(BSC6900,BSC6910) or NBMDlCacAlgoSelSwitch
(BSC6900,BSC6910) is set to a value other than ALGORITHM_OFF, the configured
admission algorithm takes effect. If the uplink or downlink power admission algorithm
is disabled,
When NBMUlCacAlgoSelSwitch(BSC6900,BSC6910) is set to
ALGORITHM_OFF, uplink power admission uses the equivalent UE quantity
algorithm.

When NBMDlCacAlgoSelSwitch(BSC6900,BSC6910) is set to

ALGORITHM_OFF, downlink power admission uses the load prediction algorithm.
– During downlink power admission, DlOtherThdForPt(BSC6900,BSC6910)
substitutes DlOtherThd(BSC6900,BSC6910) to serve as the downlink threshold for
other services.
– If the license of RB Parking is valid, the RB Parking function automatically takes effect
regardless of whether the RB Parking function switch is enabled
(CellConnAlgoSwitch1(BSC6900,BSC6910): RB_PARKING_SWITCH).
NOTE
It is recommended that the enhanced admission control function be used with WRFD-160206 RB Parking.
Otherwise, accessibility PKIs may deteriorate.
For details about RB Parking, see RB Parking Feature Parameter Description.
l When the AMRC function is enabled, max(GBR, IBRmax) is always used to calculate the
initial bit rate (IBR) for platinum CS users.
NOTE
When the AMRC function is enabled in a cell in the basic congestion state, the GBR is used to calculate
the IBR for common CS users. For details, see AMR Feature Parameter Description. The Platinum User
Prioritizing feature is optimized for platinum CS users.
7.2 State Transition Policies for Platinum Users

State transition policies can be specified for platinum users by the users' IMSIs to meet different
state transition requirements.
The PTUserStateTransStrategy(BSC6900,BSC6910) parameter in the ADD

UPLATINUMIMSI command controls state transition policies for platinum users.
l When the PTUserStateTransStrategy(BSC6900,BSC6910) parameter is set to

NORMALSTATETRANS, the same state transition policies apply to platinum users and
common users.
NOSTATETRANS, state transitions from CELL_DCH to CELL_FACH/CELL_PCH/
URA_PCH (including the state transitions triggered by the Enhanced Fast Dormancy and
State Transition features) cannot be triggered for platinum users.
SPECIALSTATETRANS, state transitions from CELL_DCH to CELL_FACH/
CELL_PCH/URA_PCH can be triggered for platinum users based on the setting of the low
activity timer (PlatinumCellDchlowActTmr(BSC6900,BSC6910)) configured for the
IMSIs. In addition, the following special operations are performed during the state
transition:
– After a platinum user transits to the CELL_FACH state, the platinum user shares the
same priority queue as PING services and can preferentially be scheduled for data
transmission.
– During a CELL_PCH-to-CELL_FACH (P2F) state transition, if the number of
CELL_FACH UEs does not reach the CELL_FACH user number limit or the FACH
Dedicated Traffic Channel (DTCH) is congested, the platinum user can perform a
CELL_PCH-to-CELL_DCH (P2D) state transition, regardless of the settings of the
P2D_SWITCH under the OptimizationSwitch(BSC6900,BSC6910) parameter and the

FACH_DTCH switch under the PROCESSSWITCH2(BSC6900,BSC6910)

parameter.
– During the CELL_FACH-to-CELL_FACH admission of platinum users, if the number
of remaining users is smaller than five, platinum users can randomly select Parking
users for resource preemption. If there are no Parking users, platinum users preempt the
resources for common users.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 8 Related Features
8 Related Features
Prerequisite Features
None
Mutually Exclusive Features

None
Impacted Features
The Platinum User Prioritizing feature affects other features as follows:
l The initial SPI weight of platinum users is set to the highest value, 100%, which cannot be
increased. Therefore, the performance of the following features related to SPI weight
adjustment may be affected: WRFD-020132 Web Browsing Acceleration, WRFD-020133
P2P Downloading Rate Control during Busy Hour, and WRFD-140221 HSDPA
Scheduling Based on UE Location.
l The initial SPI weight of platinum users is set to 100% regardless of whether the Scheduling
Based on UE Location function in the WRFD-01061209 HSUPA HARQ and Fast UL
Scheduling in NodeB feature is enabled.
l When WRFD-021103 Access Class Restriction, WRFD-020114 Domain Specific Access
Control (DSAC), or WRFD-140213 Intelligent Access Class Control is enabled, users of
access classes 0 through 9 are barred by turns and therefore cannot initiate services. If a
platinum user is of access class 0 to 9, user experience will deteriorate. However, during
the period when the access class of the platinum user is allowed to access the network, the
RNC preferentially processes service requests from the platinum user.
l WRFD-171210 Radio Aware Video Shaping
– If the WRFD-171210 Radio Aware Video Shaping feature preferentially schedules only
the video services of platinum users, after the Platinum User Prioritizing feature is
enabled, platinum user experience is not affected, and video services of platinum users
are better guaranteed.
– If the WRFD-171210 Radio Aware Video Shaping feature preferentially schedules the
video services of all video users, after the Platinum User Prioritizing feature is enabled,
the system preferentially schedules the video services of platinum and common users
and then schedules non-video services of platinum and common users based on SPI

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 8 Related Features
weights. In this case, the effects that all services of platinum users take priority over all
services of common users cannot be achieved.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 9 Network Impact
9 Network Impact
System Capacity
The maximum downlink transmit power for platinum users' conversational services is higher
than that for common users by the value of PtUserRlMaxDlPwrDelta(BSC6900,BSC6910).
When platinum users are located in weak coverage areas, the downlink load of the network
increases. As a result, the power available to other services, such as HSPA services, decreases.
This reduces cell throughput.
l If the proportion of platinum users is low in a cell, the impact on network capacity is very
small and can be hardly noticed.
l If the proportion of platinum users is high in a cell, RLC retransmission rates and service
establishment delay increase.
l When congestion occurs in a platinum CS cell activated with enhanced QoE guarantee for
platinum CS users, the RNC restricts the PS data transmission of common users. As a result,
the system capacity decreases.
Network Performance
l RRC Connection Setup Success Rate for Cell
After the Platinum User Prioritizing feature is enabled, the RRC connection setup success
rate in a cell may increase. This is because the RRC connection setup success rate of
platinum users increases. However, if platinum users account for only a small proportion
of the total users in a cell, this feature has only a small impact on the RRC connection setup
success rate.
l RAB Setup Success Rate for Cell
After the Platinum User Prioritizing feature is enabled, the RAB setup success rate in a cell
may increase. This is because the RAB setup success rate of platinum users increases.
However, if platinum users account for only a small proportion of the total users in a cell,
this feature has only a small impact on the RAB setup success rate.
After the function of enhanced QoE guarantee for platinum CS users is enabled, data
transmission of common PS users in platinum CS cells are restricted, and therefore cell
load and interference decrease. If there are many RAB setup failures caused by air interface
reasons before this function is enabled, the RAB setup success rate decreases after this
function is enabled.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 9 Network Impact
l CS call drop rate for Cell

Platinum users preempt the resources of common users, which increases the CS call drop
rate. However, if there are a large number of PS services in the cell, the probability that the
resources of CS services are preempted is low, and therefore the impact of this feature on
the CS call drop rate is small.
If downlink weak coverage is the major reason for call drops, the call drop rate of platinum
users decreases because NodeBs increase the maximum downlink transmit power for
platinum users' conversational services. Therefore, the CS call drop rate in the cell
decreases. If the proportion of platinum users is low and signal quality in the network is
good, the impact of this feature on the CS call drop rate is not obvious.
After enhanced QoE guarantee for platinum CS users is enabled, PS data transmission of
common users is limited in the cells where platinum CS users are located. As a result, cell
load and interference decrease, and the cell CS call drop rate decreases.
l PS call drop rate for Cell
When congestion occurs, platinum users preempt the resources of PS services, increasing
the PS call drop rate. The larger the proportion of platinum users and the severer the
congestion, the higher the PS call drop rate.
In addition, when congestion occurs in a platinum CS cell activated with enhanced QoE
guarantee for platinum CS users, the uplink target BLER is increased and the maximum
downlink transmit power on the RL is decreased for PS BE services of common users,
which also leads to a higher PS call drop rate.
After enhanced QoE guarantee for platinum CS users is enabled, PS data transmission of
common users is limited in the cells where platinum CS users are located. As a result, cell
load and interference decrease, and the cell PS call drop rate decreases.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 10 Engineering Guidelines
10 Engineering Guidelines
10.1 When to Use Platinum User Prioritizing

When the RRC connection setup success rate or the RAB setup success rate is low due to network
congestion but network access for a small number of users needs to be guaranteed, you are
advised to enable the Platinum User Prioritizing feature.
It is recommended that enhanced QoE guarantee for platinum CS users to further guarantee
platinum user experience over CS services under the premise that the PS capacity decrease and
KPI deterioration of common users are acceptable.
10.2 Required Information

Collect the following information required for enabling the Platinum User Prioritizing feature:
l Find the cells in which both the RRC connection setup and RAB setup success rates are
low and the network access failures are caused by network congestion. The following
counters define the network access failures caused by network congestion:
– The ratio of RRC connection failures due to network congestion to all RRC connection
failures, which is calculated by using the following formula:
Ratio of RRC connection failures due to network congestion to all RRC connection
failures = VS.RRC.FailConnEstab.Cong(BSC6900,BSC6910)/
(VS.RRC.AttConnEstab.Sum(BSC6900,BSC6910) – RRC.SuccConnEstab.sum
(BSC6900,BSC6910))
where
VS.RRC.FailConnEstab.Cong(BSC6900,BSC6910) provides the number of RRC
connection failures due to network congestion.
VS.RRC.AttConnEstab.Sum(BSC6900,BSC6910) provides the number of processed
RRC connection requests.
RRC.SuccConnEstab.sum(BSC6900,BSC6910) provides the number of successful
RRC connection setups.
– The rate of CS RAB setup rejection due to network congestion, which is calculated by
using the following formula:

WCDMA RAN
Rate of CS RAB setup rejection due to network congestion =

VS.RAB.FailEstabCS.Cong(BSC6900,BSC6910)/VS.RAB.FailEstabCS.RNL
(BSC6900,BSC6910)
where
VS.RAB.FailEstabCS.Cong(BSC6900,BSC6910) provides the number of CS RAB
setup failures due to network congestion.
VS.RAB.FailEstabCS.RNL(BSC6900,BSC6910) provides the number of CS RAB
setup failures due to radio network layer causes.
– The rate of PS RAB setup rejection due to network congestion, which is calculated by
using the following formula:
Rate of PS RAB setup rejection due to network congestion =
VS.RAB.FailEstabPS.Cong(BSC6900,BSC6910)/VS.RAB.FailEstabPS.RNL
(BSC6900,BSC6910)
where
VS.RAB.FailEstabPS.Cong(BSC6900,BSC6910) provides the number of PS RAB
setup failures due to network congestion.
VS.RAB.FailEstabPS.RNL(BSC6900,BSC6910) provides the number of PS RAB
setup failures due to radio network layer causes.
If network congestion occurs frequently or is predicted to occur and the congestion is
not severe, you are advised to enable this feature.
l Obtain the IMSIs of platinum users and configure a list.
l If both the Platinum User Prioritizing feature and preemption are enabled in a cell, collect
the following counters to evaluate the impact of this feature on the call drop rate:
– CS services: VS.RAB.AbnormRel.CS.Preempt(BSC6900,BSC6910),
VS.RAB.AbnormRel.CS(BSC6900,BSC6910), and VS.RAB.NormRel.CS
(BSC6900,BSC6910) for CS services
– PS services: VS.RAB.AbnormRel.PS.Preempt(BSC6900,BSC6910),
VS.RAB.AbnormRel.PS(BSC6900,BSC6910), and VS.RAB.NormRel.PS
(BSC6900,BSC6910)
l After enhanced QoE guarantee for platinum CS users is enabled, collect the following
counters related to the CS call drop rate of platinum users to evaluate feature gains:
– VS.RAB.NormRel.CS.Platinum(BSC6900,BSC6910)
– VS.RAB.AbnormRel.CS.Platinum(BSC6900,BSC6910)
10.3 Planning
None
10.4 Deployment
10.4.1 Requirements
l License

WCDMA RAN
For details about how to activate the license, see License Management Feature Parameter
Description.
Feature Feature License License NE License Sale

ID Name Control Control Allocatio s
Item Name n for Unit
Multiple
Operator
s
WRFD-15 Platinum LQW1PU Platinum BSC6900 Method 1 per

0204 User PRESE User BSC6910 Erl
Prioritizin Prioritizin
g g (per Erl)
WRFD-15 Platinum LQW1PU Platinum BSC6900 Method 2 per

0204 User PRESM User BSC6910 Mbps
Prioritizin Prioritizin
g g (per
Mbps)
If RAN Sharing or MOCN is enabled, the licensed value is allocated among the primary
and secondary operators according to the value of the "License Allocation for Multiple
Operators parameter".
Method 1: it is recommended that the license allocation proportion of a feature be consistent
with that of the capacity license item "Voice Erlang-Erlang". The licensed values can be
set by running the SET LICENSE command. If the FeatureResAssignMode parameter in
this command is set to AutoAssign, the licensed values are automatically allocated among
the primary and secondary operators. If the FeatureResAssignMode parameter in this
command is set to ManualAssign, you also need to specify the related license parameters
to implement manual license allocation.
Method 2: it is recommended that the license allocation proportion of a feature be consistent
with that of the capacity license item "PS throughput only-kbps". The licensed values can
be set by running the SET LICENSE command. If the FeatureResAssignMode parameter
in this command is set to AutoAssign, the licensed values are automatically allocated
among the primary and secondary operators. If the FeatureResAssignMode parameter in
this command is set to ManualAssign, you also need to specify the related license
parameters to implement manual license allocation.

WCDMA RAN
10.4.2 Data Preparation

Paramet Parameter Setting Notes Data
er Name ID Source
Platinum PlatinumUser When RAN Sharing or MOCN is enabled, you Radio

User PriErl need to configure Erlangs separately for the network
Prioritizi primary and secondary operators. plan
ng-Erlang The sum of the Erlangs configured for all the (internal)
operators cannot exceed the licensed Erlangs for
the Platinum User Prioritizing feature.
When RAN Sharing or MOCN is not enabled,
you do not need to configure this parameter.
Platinum PlatinumUser When RAN Sharing or MOCN is enabled, you Radio

User PriKbps need to configure PS throughput separately for network
Prioritizi the primary and secondary operators. plan
ng-kbps The sum of the PS throughput configured for all (internal)
the operators cannot exceed the licensed PS
throughput for the Platinum User Prioritizing
feature.
When RAN Sharing or MOCN is not enabled,
you do not need to configure this parameter.
Process PROCESSS This parameter specifies whether to enable the Default

switch WITCH Platinum User Prioritizing feature. value/
(BSC6900, Enable this feature when the application scenario Recomme
BSC6910): described in section 9.1 "When to Use Platinum nded value
PTUSER_ID User Prioritizing" is met.
ENTIFY_S
WITCH
Process PROCESSS To enable the target RNC or DRNC to identify Radio

switch WITCH platinum users in cross-Iur handover, SRNS network
(BSC6900, relocation, and DSCR scenarios, set plan
BSC6910): PTUSER_IDENTIFY_ENH_SWITCH to (internal)
PTUSER_ID ON.
ENTIFY_EN
H_SWITCH
Platinum PlatinumIMS If the Platinum User Prioritizing feature needs to Engineerin

IMSI I be enabled, configure this parameter based on the g design
(BSC6900, information collected about platinum users. A
BSC6910) maximum of 3000 platinum users can be
configured.
DL Max PtUserRl- This parameter specifies the maximum value of Radio

Power MaxDlPwrDe downlink transmit power on the RL increased for network
Delta for lta platinum CS users than common users. Its default plan
Platinum (BSC6900, value is 3 dB. (internal)
CS User BSC6910)

WCDMA RAN
Paramet Parameter Setting Notes Data

er Name ID Source
Integrate PriorityRefer- If the operator considers CS services more Radio

Priority ence important and determines that CS services should network
Configur (BSC6900, first preempt the resources for PS services and plan
ed BSC6910) then the resources for CS services, set this (internal)
Reference parameter to TrafficClass. In this case, if the
operator also wants to guarantee PS services for
Platinum PtUserAbsolu platinum users and enable platinum users' PS Engineerin
User tePriority services to preempt the resources occupied by g design
Prioritizi (BSC6900, common users' CS services, set the
ng BSC6910) PtUserAbsolutePriority(BSC6900,BSC6910)
parameter to True. If the PriorityReference
(BSC6900,BSC6910) parameter is set to ARP,
platinum users have the highest user
comprehensive priority regardless of whether the
PtUserAbsolutePriority(BSC6900,BSC6910)
parameter is set to True or False.
Preempti PreemptEnhS When this switch is set to on, platinum users can Engineerin
on witch preempt resources of common users if cell g design
Enhance (BSC6900, admission fails during procedures such as DRD,
ment BSC6910): channel fallback, or rate re-negotiation during
Switch PREEMPT_ admission control.
ENH_PT_US
ER_PREEM
PT_ENH_S
WITCH
To implement differentiated services based on scheduling priorities, the operator also needs to
purchase the WRFD-020806 Differentiated Service Based on SPI Weight feature or some
functions related to SPI weight adjustment. In this case, you need to collect the values of the
following parameters.

WCDMA RAN
Param Parameter ID Setting Notes Data Source

eter
Name
Process PROCESSSWI This parameter specifies whether the RNC Default value/
switch TCH sends NodeB private interface data to the Recommende
(BSC6900, NodeB through an Iub protocol message. d value
BSC6910): When the license for the WRFD-020806
NODEB_PRIV Differentiated Service Based on SPI Weight
ATE_INTERF feature is not activated, turn on the
ACE_SWITC NODEB_PRIVATE_INTERFACE_SWI
H TCH switch.
l When this switch is turned on, the RNC
sends NodeB private interface data to the
NodeB through an Iub protocol message.
l When this switch is turned off, the RNC
does not send NodeB private interface data
to the NodeB through an Iub protocol
message.
The setting of this parameter determines
whether the SPI weight of common users
is sent to the NodeB. If the SPI weight of
common users is not sent to the NodeB,
common users and platinum users have the
same SPI weight, 100%. In this case,
differentiated services based on SPI
weight cannot be implemented. Therefore,
you are advised to turn on this switch.
Default DefaultSPIWei This parameter specifies the SPI weight of Radio

SPI ght common users when the license for the network plan
Weight (BSC6900, WRFD-020806 Differentiated Service Based (internal)
BSC6910) on SPI Weight feature is not activated. The
SPI weight of platinum users is 100%. The
smaller the value of this parameter, the more
obvious the service differentiation between
platinum users and common users.
SPI SpiWeight This parameter specifies the SPI weight of Radio

Weight (BSC6900, corresponding specific scheduling priority network plan
BSC6910) when the license for the WRFD-020806 (internal)
Differentiated Service Based on SPI Weight
feature is activated. To preferentially
guarantee platinum user experience, set this
parameter to a value smaller than 100% for
common users.

WCDMA RAN
Param Parameter ID Setting Notes Data Source

eter
Name
Iub IubCPPrivateIn When Radio

Private terfaceSwitch PTUSER_IDENTIFY_ENH_SWITCH network plan
Interfac (BSC6900, under the PROCESSSWITCH (internal)
e BSC6910) (BSC6900,BSC6910) parameter is set to 1,
Switch set IubCPPrivateInterfaceSwitch
of (BSC6900,BSC6910) to ON so that the
Control DRNC can perform service differentiation
Plane between platinum users and common users
based on the SPI weight in cross-Iur handover
scenarios.
To activate enhanced QoE guarantee for platinum CS users, you need to configure the parameters
listed in the following table based on the actual situation.

WCDMA RAN
Parameter Name Parameter ID Setting Data Source

Notes
Platinum CS User PtCSUserEnhSwitch It is Radio network plan

Enhancement Switch (BSC6900,BSC6910) recomme (internal)
nded that
this
switch be
set to ON
to activate
enhanced
QoE
guarantee
for
platinum
CS users
to further
guarantee
platinum
user
experienc
e over CS
services
under the
premise
that the
PS
capacity
decrease
and KPI
deteriorat
ion of
common
users are
acceptabl
e.

WCDMA RAN

Notes
Platinum CS User CacSwitch You can Radio network plan

Admission Enhancement (BSC6900,BSC6910): set this (internal)
Switch PT_CSUSER_CAC_E switch to
NH_SWITCH ON to
restrict PS
service
admissio
n of
common
users to
decrease
the cell
load and
improve
the QoE
of
platinum
CS users.
NOTE
It is
recomme
nded that
this
function
be used
with RB
Parking
to
decrease
the
impact of
tightened
admissio
n on the
accessibi
lity
KPIs.

WCDMA RAN

Notes
DL Load Threshold for DlOtherThdForPt This Radio network plan

Other Services (BSC6900,BSC6910) parameter (internal)
specifies
the
downlink
power
admissio
n
threshold
for a
platinum
CS cell
when
PT_CSU
SER_CA
C_ENH_
SWITC
H under
CAC
algorith
m switch
is set to
ON, it is
recomme
nded that
this
parameter
be set to a
value less
than or
equal to
the value
of DL
threshol
d of other
services
and
greater
than or
equal to
the value
of DL
LDR
trigger
threshol
d.

WCDMA RAN

Notes
Platinum User Priority PS PsBlerTarDeltaForP- The Radio network plan

Target BLER Delta tUser recomme (internal)
(BSC6900,BSC6910) nded
value is
10 dB.
Platinum User Priority PS PsRlMaxDlPwrDelta- The Radio network plan

DL Max Power Delta ForPt recomme (internal)
(BSC6900,BSC6910) nded
value is 3
dB.
Platinum User Priority PS PsUlInitLimitRate- This Radio network plan

UL Initial Rate Limit ForPt parameter (internal)
(BSC6900,BSC6910) specifies
the
restricted
rate on the
DCH for
uplink PS
services
of
common
users
when a
platinum
CS cell is
congested
. The
recomme
nded
value is 8
kbit/s.
To
disable
this
function,
set this
parameter
to
NotLimit
ed.

WCDMA RAN

Notes
Platinum User Priority PS PsDlInitLimitRate- This Radio network plan

DL Initial Rate Limit ForPt parameter (internal)
the
restricted
rate on the
DCH for
downlink
PS
services
of
common
users
when a
platinum
CS cell is
congested
. The
recomme
nded
value is
16 kbit/s.
To
disable
this
function,
set this
parameter
to
NotLimit
ed.

WCDMA RAN

Notes
Platinum User Priority DL DLPwrLoadSta- This Radio network plan

Power Load State Thld ForPtPrior parameter (internal)
the initial
state of
the
downlink
power
load when
enhanced
QoE
guarantee
for
platinum
CS users
takes
effect.
The
recomme
nded
value is
DL_LO
ADED_S
TATE.

WCDMA RAN

Notes
UL Actual Service Load ULActulLoadSta- This Radio network plan

State Threshold ForPtPrior parameter (internal)
the initial
state of
the uplink
actual
service
load when
enhanced
QoE
guarantee
for
platinum
CS users
takes
effect.
The
recomme
nded
value is
UL_LO
ADED_S
TATE.

WCDMA RAN

Notes
DCH User Number Load DchUserLoadSta- This Radio network plan

State Threshold ForPtPrior parameter (internal)
the initial
load of
CELL_D
CH users
when
enhanced
QoE
guarantee
for
platinum
CS users
takes
effect.
The
recomme
nded
value is
DCHUS
ER_LO
ADED_S
TATE.
Power Margin Delta For PWRMGNDELTAFO This Radio network plan

Platinum User RPT parameter (internal)
specifies
the
increase
in the
reserved
power
margin of
R99
channels
when
Platinum
User
Prioritizi
ng is
enabled.
The
recomme
nded
value is
10%.

WCDMA RAN
10.4.3 Activation
Using MML Commands

Step 1 Obtain the IMSIs of platinum users and configure a list. Note that only the administrator or a
user who has been granted rights by the administrator can perform this step.
Run the RNC MML command ADD UPLATINUMIMSI with Platinum IMSI set to the IMSI
of a platinum user. In addition, set the state transition policies and low activity timer. You can
configure a maximum of 3000 platinum users.
NOTE
Run the ADD UPLATINUMIMSI command for each platinum user you want to add.
On the LMT, only the users who have the administrator's rights can run the following commands: ADD
UPLATINUMIMSI, LST UPLATINUMIMSI, and RMV UPLATINUMIMSI.
On the U2000, the administrator and the users who have been granted rights can perform IMSI-related
operations for platinum users. For details about user rights of the U2000, see User Management in the
U2000 product documentation.
On the CME, the administrator and the users who have been granted rights by the administrator can perform
IMSI-related operations for platinum users.
In operation logs, the IMSI information in these commands is anonymous.
Step 2 Run the RNC MML command SET UQUEUEPREEMPT to turn on the NodeB CE based
preemption. In this step, select PREEMPT_ENH_NODEB_PREEMPT_CE_SWITCH under
Preemption Enhancement Switch.
Step 3 (Optional) To enable the target RNC or DRNC to identify platinum users in cross-Iur handover,
SRNS relocation, and DSCR scenarios, run the RNC MML command SET
URRCTRLSWITCH with PTUSER_IDENTIFY_ENH_SWITCH under Process switch
parameter set to on. In addition, configure the IMSIs of platinum users on the target RNC and
DRNC by referring to Step 1.
Step 4 (Optional) Determine whether to modify the related parameter values based on operators'
requirements and the parameter setting notes provided in section 10.4.2 Data Preparation. To
modify the parameter values, perform the following sub-steps:
1. Run the RNC MML command SET UUSERPRIORITY to set the Integrate Priority
Configured Reference parameter.
2. If platinum users are required to have the highest preemption priority, run the RNC MML
command SET UQUEUEPREEMPT with Platinum User Prioritizing set to True.
Otherwise, set Platinum User Prioritizing to False.
NOTE
In most cases, the value of the Integrate Priority Configured Reference parameter does not need
to be modified.
When the Integrate Priority Configured Reference parameter is set to ARP, the Platinum User
Prioritizing parameter does not need to be configured.
When the Integrate Priority Configured Reference parameter is set to TrafficClass, the platinum
users' PS services can preempt the CS RABs of non-platinum users if the Platinum User Prioritizing
parameter is set to True; the platinum users' PS services cannot preempt the CS RABs of non-
platinum users if the Platinum User Prioritizing parameter is set to False.
3. To enable platinum users to preferentially access the first candidate cell for DRD, to
preferentially establish services on E-DCHs/HS-DSCHs during channel fallback, and to

WCDMA RAN
preferentially access the network at a data rate as high as possible during rate re-negotiation,
run the RNC MML command SET UQUEUEPREEMPT with
PREEMPT_ENH_PT_USER_PREEMPT_ENH_SWITCH under the Preemption
Enhancement Switch parameter set to on.
Step 5 (Optional) If the license for the WRFD-020806 Differentiated Service Based on SPI Weight
feature is not activated and the SPI weight for platinum users has been set to 100%, you are
advised to turn on the NODEB_PRIVATE_INTERFACE_SWITCH switch so that
differentiated services can be implemented between platinum users and common users based on
scheduling priorities.
1. Run the RNC MML command SET URRCTRLSWITCH. In this step, select the
NODEB_PRIVATE_INTERFACE_SWITCH switch under the Process switch
parameter.
2. Run the RNC MML command SET UFRC with Default SPI Weight set to a value smaller
than 100.
Step 6 (Optional) If the license for the WRFD-020806 Differentiated Service Based on SPI Weight
feature is activated and the SPI weight for platinum users has been set to 100%, perform the
following sub-step so that differentiated services can be implemented between platinum users
and common users based on scheduling priorities:
Run the RNC MML command SET USPIWEIGHT to with SPI Weight set to a value smaller
than 100.
NOTE
l Whether you need to modify other parameters related to the SPI weight depends on scenario
requirements. Generally, the SPI weights of gold, silver, and bronze users can be proportionally
reduced, for example, from 100:80:10 to 10:8:1.
l Modifying the SPI weight does not immediately take effect for online users.
l Whether you need to perform Step 3 or Step 4 above depends on whether the WRFD-020806
Differentiated Service Based on SPI Weight feature has been activated. If this feature has not been
activated, perform Step 3 to configure the SPI weight for common users. If this feature has been
activated, perform Step 4 to configure different SPI weights.
Step 7 (Optional) To enable the DRNC to perform service differentiation between platinum users and
common users based on the SPI weight in cross-Iur handover scenarios, run the RNC MML
command ADD UNRNC or MOD UNRNC with the Iub Private Interface Switch of Control
Plane parameter set to ON.
Step 8 Run the RNC MML command SET URRCTRLSWITCH. In this step, select
PTUSER_IDENTIFY_SWITCH under the Process switch parameter to enable the Platinum
User Prioritizing feature.
Step 9 (Optional) To activate enhanced QoE guarantee for platinum CS users in the live network,
perform the following operations to set the related parameters based on the setting notes in
section 10.4.2 Data Preparation and operators' requirements:
1. Run the RNC MML command SET ULDCALGOPARA with Platinum CS User
Enhancement Switch set to ON to activate enhanced QoE guarantee for platinum CS users.
2. Run the RNC MML command SET UCACALGOSWITCH. In this step, select
PT_CSUSER_CAC_ENH_SWITCH under the CAC algorithm switch parameter to
enable platinum CS user admission enhancement.

WCDMA RAN
3. Run the RNC MML command ADD UCELLCAC or MOD UCELLCAC with DL Load
Threshold for Other Services set to a proper value to adjust the service admission
threshold of common PS users for platinum CS users.
4. Run the RNC MML command SET UOLPC with Platinum User Priority PS Target
BLER Delta set to a proper value to activate uplink BLER adjustment for PS services of
platinum CS user guarantee.
5. Run the RNC MML command SET UOLPC with Platinum User Priority PS DL Max
Power Delta set to a proper value to activate maximum downlink transmit power
adjustment on the RL for PS services of platinum CS user guarantee.
6. Run the RNC MML command SET UFRC with Platinum User Priority PS UL Initial
Rate Limit set to a proper value to activate uplink rate limit for PS services of platinum
CS user guarantee.
7. Run the RNC MML command SET UFRC with Platinum User Priority PS DL Initial
Rate Limit set to a proper value to activate downlink rate limit for PS services for platinum
CS user guarantee.
8. Run the NodeB MML command SET ULOCELLMACHSPARA with Power Margin
Delta For Platinum User set to a proper value to adjust the reserved power margin of R99
channels for platinum CS users.
Step 10 Run the MML command SET UDPUCFGDATA, with CS Paging Preemption Switch for
Platinum Users and PS Paging Preemption Switch for Platinum Users set to ON to enable
CS and PS service paging preemption for platinum users.
----End
MML Command Examples

//Configuring a list of platinum users' IMSIs and setting state transition policies
for platinum users
ADD UPLATINUMIMSI: PlatinumIMSI=
"123456781234567",PTUserStateTransStrategy=SPECIALSTATETRANS,PlatinumCellDchlowAct
Tmr=10;
//(Optional) Enabling platinum users' PS services to preempt the CS RABs of non-
platinum users when the Integrate Priority Configured Reference parameter is set to
TrafficClass
SET UQUEUEPREEMPT:PtUserAbsolutePriority=True;
//Turning on the platinum user preemption enhance switch
SET UQUEUEPREEMPT:PreemptEnhSwitch=PREEMPT_ENH_PT_USER_PREEMPT_ENH_SWITCH-1;
//Enabling the target RNC and DRNC to identify platinum users
SET URRCTRLSWITCH: PROCESSSWITCH=PTUSER_IDENTIFY_ENH_SWITCH-1;
//(Optional) Setting the SPI weight of common users to a value smaller than 100%
when the operator does not purchase the WRFD-020806 Differentiated Service Based on
SPI Weight feature
SET URRCTRLSWITCH: PROCESSSWITCH=NODEB_PRIVATE_INTERFACE_SWITCH-1;
SET UFRC: DefaultSPIWeight=10;
//Enabling the DRNC to perform service differentiation between platinum users and
common users based on the SPI weight
MOD UNRNC: NRncId=1, IubCPPrivateInterfaceSwitch=ON;
//(Optional) Reducing the SPI weights of gold, silver, and bronze users
proportionally from 100:80:10 to 10:8:1 if the license for the WRFD-020806
Differentiated Service Based on SPI Weight feature is activated
SET USPIWEIGHT: SPI=1, SpiWeight=10;
//Activating the Platinum User Prioritizing feature
SET URRCTRLSWITCH:PROCESSSWITCH= PTUSER_IDENTIFY_SWITCH-1;
//(Optional) Setting the following parameters based on actual situations if
enhanced QoE guarantee for platinum CS users:

WCDMA RAN
SET ULDCALGOPARA: PtCSUserEnhSwitch=ON;

SET UCACALGOSWITCH: CacSwitch=PT_CSUSER_CAC_ENH_SWITCH-1;
MOD UCELLCAC: CellId=111, DlOtherThdForPt=70;
SET UOLPC: PsBlerTarDeltaForPtUser=10, PsRlMaxDlPwrDeltaForPt=30;
MOD UCELLFRC: CellId=111, DLPwrLoadStaForPtPrior=DL_LOADED_STATE,
ULActulLoadStaForPtPrior=UL_LOADED_STATE,
DchUserLoadStaForPtPrior=DCHUSER_LOADED_STATE;
SET ULOCELLMACHSPARA: ULOCELLID=111, PWRMGN=10;
//Enabling CS and PS service paging preemption for platinum users
SET UDPUCFGDATA:PTCSPagingPreemptSwitch=ON,PTPSPagingPreemptSwitch=ON;
Using the CME

NOTE
When configuring the Platinum User Prioritizing feature on the CME, perform a single configuration first,
and then perform a batch modification if required.
Configure the parameters of a single object before a batch modification. Perform a batch modification
before logging out of the parameter setting interface.
Step 1 Configure a single object (such as a cell) on the CME.
Set parameters on the CME according to the operation sequence in Table 10-1. For instructions
on how to perform the CME single configuration, see CME Single Configuration Operation
Guide.
Step 2 (Optional) Modify objects in batches on the CME. (CME batch modification center)
To modify objects in batches, click on the CME to start the batch modification wizard. For
instructions on how to perform a batch modification through the CME batch modification center,
press F1 on the wizard interface to obtain online help.
----End
NOTE
In operations 5 and 6, set the SPI weights for common users based on scenario requirements.
In operations 5 and 6, modifying the SPI weight does not immediately take effect for online users.
When RAN Sharing/MOCN is enabled, you need to run the RNC MML command SET LICENSE to set
the Platinum User Prioritizing (per Erl) or Platinum User Prioritizing (per Mbps) parameter on the
LMT because the CME does not support license operations. The Platinum User Prioritizing (per Erl)
and Platinum User Prioritizing (per Mbps) parameters specify the Erlangs and PS throughput,
respectively, that can be used by the primary and secondary operators.

WCDMA RAN
Table 10-1 Parameters on the CME
SN MO NE Parameter Name Parameter Configur

ID able in
CME
Batch
Modificat
ion
Center
1 UPL RNC Platinum IMSI PlatinumIMS No

ATIN NOTE I
UMI The administrator and the users (BSC6900,
MSI who have been granted rights by BSC6910)
the administrator can perform
IMSI-related operations for
platinum users.
2 UUS RNC Integrate Priority Configured PriorityRefer- Yes

(optional ERPR Reference ence
) IORI (BSC6900,
TY BSC6910)
3 UQU RNC Platinum User Prioritizing PtUserAbsolu Yes

(optional EUEP tePriority
) REE (BSC6900,
MPT BSC6910)
4 URR RNC Process switch PROCESSSW Yes

(optional CTR NOTE ITCH
) LSWI In cross-Iur handover, SRNS (BSC6900,
TCH relocation, and DSCR scenarios, BSC6910)
perform this step so that the target
RNC or DRNC can identify
platinum users.

(optional CTR Select ITCH
) LSWI NODEB_PRIVATE_INTE (BSC6900,
TCH RFACE_SWITCH under the BSC6910)
Process switch parameter.
NOTE
If the license for the
WRFD-020806 Differentiated
Service Based on SPI Weight
feature is not activated and the
SPI weight for platinum users has
been set to 100%, you are advised
to turn on the Iub private message
switch so that differentiated
services can be implemented
between platinum users and
common users based on

WCDMA RAN

ID able in
CME
Batch
Modificat
ion
Center
UFR RNC Default SPI Weight DefaultSPIW

C eight
(BSC6900,
BSC6910)
6 USPI RNC SPI Weight SpiWeight Yes

(optional WEI NOTE (BSC6900,
) GHT If the license for the BSC6910)
WRFD-020806 Differentiated
Service Based on SPI Weight
feature is activated and the SPI
weight for platinum users has
been set to 100%, perform this
step so that differentiated
services can be implemented
between platinum users and
common users based on

CTR Select ITCH
LSWI PTUSER_IDENTIFY_SWI (BSC6900,
TCH TCH under the Process BSC6910)
switch parameter.
8 UNR RNC Iub Private Interface Switch of IubCPPrivate Yes

(optional NC Control Plane InterfaceSwit
) NOTE ch
Perform this step so that the (BSC6900,
DRNC can perform service BSC6910)
differentiation between platinum
users and common users based on
the SPI weight in cross-Iur
handover scenarios.
9 ULD RNC Platinum CS User PtCSUserEnh Yes

CAL Enhancement Switch Switch
GOP (BSC6900,
ARA BSC6910)
10 UCA RNC Platinum CS User Admission CacSwitch Yes

CAL Enhancement Switch (BSC6900,
GOS BSC6910):
WIT PT_CSUSER_
CH CAC_ENH_S
WITCH

WCDMA RAN

ID able in
CME
Batch
Modificat
ion
Center
11 UCE RNC DL Load Threshold for Other DlOtherThdF Yes

LLC Services orPt
AC (BSC6900,
BSC6910)
12 UOL RNC Platinum User Priority PS PsBlerTarDel Yes

PC Target BLER Delta taForPtUser
(BSC6900,
BSC6910)
13 UOL RNC Platinum User Priority PS DL PsRlMaxDlP Yes

PC Max Power Delta wrDeltaForPt
(BSC6900,
BSC6910)
14 UFR RNC Platinum User Priority PS UL PsUlInitLimit Yes

C Initial Rate Limit RateForPt
(BSC6900,
BSC6910)
15 UFR RNC Platinum User Priority PS DL PsDlInitLimit Yes

C Initial Rate Limit RateForPt
(BSC6900,
BSC6910)
16 ULO RNC Power Margin Delta For PWRMGNDE Yes

CEL Platinum User LTAFORPT
LMA
CHS
PAR
A
17 UDP RNC CS Paging Preemption Switch PTCSPaging- Yes

UCF for Platinum Users PreemptSwitc
GDA h
TA (BSC6900,
BSC6910)
18 UDP RNC PS Paging Preemption Switch PTPSPaging- Yes

UCF for Platinum Users PreemptSwitc
GDA h
TA (BSC6900,
BSC6910)

WCDMA RAN

ID able in
CME
Batch
Modificat
ion
Center
19 PLA RNC State Transition Policy for PTUserState- No

TINU Platinum Users TransStrategy
MIM (BSC6900,
SI BSC6910)
20 UPL RNC Low Activity Timer for PlatinumCell No

ATIN CELL_DCH Platinum Users DchlowActTm
UMI r
MSI (BSC6900,
BSC6910)
10.4.4 Activation Observation

A period after the Platinum User Prioritizing feature is activated, check the value of the
RRC.AttConnEstab.Platinum(BSC6900,BSC6910) counter. If the value of this counter is not
0, this feature has been successfully activated.
10.4.5 Deactivation
Using MML Commands

1. Run the RNC MML command SET URRCTRLSWITCH. In this step, deselect the
PTUSER_IDENTIFY_SWITCH switch under the Process switch parameter to
deactivate the Platinum User Prioritizing feature.
2. Run the RNC MML command SET ULDCALGOPARA with Platinum CS User
Enhancement Switch set to OFF to deactivate enhanced QoE guarantee for platinum CS
users.
3. Run the MML command SET UDPUCFGDATA with both CS Paging Preemption
Switch for Platinum Users and PS Paging Preemption Switch for Platinum Users set
to OFF to disable CS and PS service paging preemption for platinum users.
NOTE
Deactivating the Platinum User Prioritizing feature does not immediately take effect for online users.
MML Command Examples

//Deactivating the Platinum User Prioritizing feature
SET URRCTRLSWITCH:PROCESSSWITCH=PTUSER_IDENTIFY_SWITCH-0;
//(Optional) Deactivating enhanced QoE guarantee for platinum CS users
SET ULDCALGOPARA: PtCSUserEnhSwitch=OFF;

WCDMA RAN
//Disabling CS and PS service paging preemption for platinum users

SET UDPUCFGDATA:PTCSPagingPreemptSwitch=OFF,PTPSPagingPreemptSwitch=OFF;
Using the CME

NOTE
When configuring the Platinum User Prioritizing feature on the CME, perform a single configuration first,
and then perform a batch modification if required.
Configure the parameters of a single object before a batch modification. Perform a batch modification
before logging out of the parameter setting interface.
Step 1 Configure a single object (such as a cell) on the CME.
Set parameters on the CME according to the operation sequence in Table 10-2. For instructions
on how to perform the CME single configuration, see CME Single Configuration Operation
Guide.
Step 2 (Optional) Modify objects in batches on the CME. (CME batch modification center)
----End
To modify objects in batches, click on the CME to start the batch modification wizard. For
instructions on how to perform a batch modification through the CME batch modification center,
press F1 on the wizard interface to obtain online help.
NOTE
Deactivating the Platinum User Prioritizing feature does not immediately take effect for online users.
Table 10-2 Parameters on the CME
SN MO NE Parameter Name Parameter ID Configur

able in
CME
Batch
Modifica
tion
Center
1 URRCTRLSWI RN Process switch Clear PROCESSSWI Yes

TCH C PTUSER_IDENTIFY_S TCH
WITCH under the (BSC6900,
Process switch parameter. BSC6910)
2 ULDCALGOP RN Platinum CS User PtCSUserEnhS Yes

ARA C Enhancement Switch witch
(BSC6900,
BSC6910)
10.5 Performance Monitoring

WCDMA RAN
10.5.1 Increase in Connection Success Rates of Platinum Users

When the RRC connection setup success rate or the RAB setup success rate is low due to network
congestion, the access key performance indicators (KPIs) of platinum users should be greater
than or equal to those of common users.
The RRC connection setup and the RAB setup success rates of platinum users are calculated by
using the following formulas:
l RRC connection setup success rate of platinum users' conversational services =

(RRC.SuccConnEstab.Conv.Platinum(BSC6900,BSC6910)/
RRC.AttConnEstab.Conv.Platinum(BSC6900,BSC6910)) x 100%
l RRC connection setup success rate of platinum users' non-conversational services =
(RRC.SuccConnEstab.Platinum(BSC6900,BSC6910) -
RRC.SuccConnEstab.Conv.Platinum(BSC6900,BSC6910))/
(RRC.AttConnEstab.Platinum(BSC6900,BSC6910) -
l RAB setup success rate of platinum users' conversational services =
(VS.RAB.SuccEstabCS.Conv.Platinum(BSC6900,BSC6910) +
VS.RAB.SuccEstabPS.Conv.Platinum(BSC6900,BSC6910))/
(VS.RAB.AttEstabCS.Conv.Platinum(BSC6900,BSC6910) +
VS.RAB.AttEstabPS.Conv.Platinum(BSC6900,BSC6910)) x 100%
l RAB setup success rate of platinum users' non-conversational services =
(VS.RAB.SuccEstabCS.Platinum(BSC6900,BSC6910) -
VS.RAB.SuccEstabCS.Conv.Platinum(BSC6900,BSC6910) +
VS.RAB.SuccEstabPS.Platinum(BSC6900,BSC6910) -
(VS.RAB.AttEstabCS.Platinum(BSC6900,BSC6910) -
VS.RAB.AttEstabCS.Conv.Platinum(BSC6900,BSC6910) +
VS.RAB.AttEstabPS.Platinum(BSC6900,BSC6910) -
The RRC connection setup and the RAB setup success rates of common users are calculated by
using the following formulas:
l RRC connection setup success rate of common users' conversational services =

(RRC.SuccConnEstab.OrgConvCall(BSC6900,BSC6910) +
RRC.SuccConnEstab.TmConvCall(BSC6900,BSC6910) -
RRC.SuccConnEstab.Conv.Platinum(BSC6900,BSC6910))/
(RRC.AttConnEstab.OrgConvCall(BSC6900,BSC6910) +
RRC.AttConnEstab.TmConvCall(BSC6900,BSC6910) -
l RRC connection setup success rate of common users' non-conversational services =
[RRC.SuccConnEstab.sum(BSC6900,BSC6910) -
RRC.SuccConnEstab.OrgConvCall(BSC6900,BSC6910) -
RRC.SuccConnEstab.TmConvCall(BSC6900,BSC6910) -
(RRC.SuccConnEstab.Platinum(BSC6900,BSC6910) -
RRC.SuccConnEstab.Conv.Platinum(BSC6900,BSC6910))]/
[VS.RRC.AttConnEstab.Sum(BSC6900,BSC6910) -
RRC.AttConnEstab.OrgConvCall(BSC6900,BSC6910) -
RRC.AttConnEstab.TmConvCall(BSC6900,BSC6910) -

WCDMA RAN
(RRC.AttConnEstab.Platinum(BSC6900,BSC6910) -
RRC.AttConnEstab.Conv.Platinum(BSC6900,BSC6910))] x 100%
l RAB setup success rate of common users' conversational services =
(VS.RAB.SuccEstabCS.Conv(BSC6900,BSC6910) + VS.RAB.SuccEstabPS.Conv
(BSC6900,BSC6910) - VS.RAB.SuccEstabCS.Conv.Platinum(BSC6900,BSC6910) -
(VS.RAB.AttEstabCS.Conv(BSC6900,BSC6910) + VS.RAB.AttEstabPS.Conv
(BSC6900,BSC6910) - VS.RAB.AttEstabCS.Conv.Platinum(BSC6900,BSC6910) -
l RAB setup success rate of common users' non-conversational services =
[VS.RAB.SuccEstabCS.Str(BSC6900,BSC6910) + VS.RAB.SuccEstabPS.Str
(BSC6900,BSC6910) + VS.RAB.SuccEstabPS.Int(BSC6900,BSC6910) +
VS.RAB.SuccEstabPS.Bkg(BSC6900,BSC6910) - (VS.RAB.SuccEstabCS.Platinum
(BSC6900,BSC6910) - VS.RAB.SuccEstabCS.Conv.Platinum(BSC6900,BSC6910) +
VS.RAB.SuccEstabPS.Platinum(BSC6900,BSC6910) -
VS.RAB.SuccEstabPS.Conv.Platinum(BSC6900,BSC6910))]/
[VS.RAB.AttEstabCS.Str(BSC6900,BSC6910) + VS.RAB.AttEstabPS.Str
(BSC6900,BSC6910) + VS.RAB.AttEstabPS.Int(BSC6900,BSC6910) +
VS.RAB.AttEstabPS.Bkg(BSC6900,BSC6910) - (VS.RAB.AttEstabCS.Platinum
(BSC6900,BSC6910) - VS.RAB.AttEstabCS.Conv.Platinum(BSC6900,BSC6910) +
VS.RAB.AttEstabPS.Platinum(BSC6900,BSC6910) -
VS.RAB.AttEstabPS.Conv.Platinum(BSC6900,BSC6910))] x 100%
You can obtain the KPIs for common users by subtracting the KPIs for platinum users from
the cell-level KPIs.
10.5.2 Voice Quality Improvement of Platinum Users

When platinum users are located in downlink weak coverage areas, their voice quality should
be improved. The actual gain in voice quality can be obtained by performing drive tests (DTs)
on the cell edge. You can also observe the MOSs of both platinum and common users. The MOSs
of platinum users should be higher than those of common users.
You can check whether the voice quality of platinum users has been improved based on the
uplink and downlink Enhanced Voice Quality Indicators (EVQIs):
l Downlink EVQI of platinum users = VS.EVQI.AMR.DL.TotalValue.Platinum
(BSC6900,BSC6910)/VS.EVQI.AMR.DL.TotalNum.Platinum(BSC6900,BSC6910)
l Uplink EVQI of platinum users = VS.EVQI.AMR.UL.TotalValue.Platinum
(BSC6900,BSC6910)/VS.EVQI.AMR.UL.TotalNum.Platinum(BSC6900,BSC6910)
10.5.3 HSPA Throughput Improvement of Platinum Users

If the SPI weight configured for common users is smaller than the SPI weight (100%) of platinum
users, the HSPA throughput of platinum users should increase compared with that of common
users. The actual gain in HSPA throughput of platinum users can be evaluated by performing
DTs. The DTs should be performed during busy hours when the traffic load is heavy and there
is a large amount of data to transmit. Then, based on the test results, you can compare the data
rates of platinum users and common users.
You can evaluate the improvement in HSPA throughput of platinum users by conducting a drive
test or using the Huawei iDart tool to conduct an offline analysis. For detailed operations, contact
Huawei technical support engineers.

WCDMA RAN
10.5.4 Increase in Call Drop Rate for Cell

Section 9 Network Impact describes how this feature affects the call drop rate in a cell.
The following describes how preemption affects the call drop rate in a cell.
l If preemption is triggered by platinum users, the increase in the number of abnormally

released CS and PS services caused by platinum users can be observed by using the
following counters:
– CS services: VS.RAB.AbnormRel.CS.Conv.PTPreempt(BSC6900,BSC6910) and
VS.RAB.AbnormRel.CS.Str.PTPreempt(BSC6900,BSC6910)
– PS services: VS.RAB.AbnormRel.PS.Conv.PTPreempt(BSC6900,BSC6910),
VS.RAB.AbnormRel.PS.Str.PTPreempt(BSC6900,BSC6910),
VS.RAB.AbnormRel.PS.Int.PTPreempt(BSC6900,BSC6910), and
VS.RAB.AbnormRel.PS.Bkg.PTPreempt(BSC6900,BSC6910)
l The VS.RAC.Platinum.Preempt.Cong(BSC6900,BSC6910) counter indicates the
number of preemptions performed during platinum user admission.
l Observe the value of the following formula to check whether the CS call drop rate of
platinum users decreases after enhanced QoE guarantee for platinum CS users is activated:
VS.RAB.AbnormRel.CS.Platinum(BSC6900,BSC6910)/
(VS.RAB.AbnormRel.CS.Platinum(BSC6900,BSC6910) +
VS.RAB.NormRel.CS.Platinum(BSC6900,BSC6910)) x 100%
10.6 Parameter Optimization

None
10.7 Troubleshooting
None

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 11 Parameters
11 Parameters
Table 11-1 Parameters
Parame NE MML Feature Feature Description

ter ID Comma ID Name
nd
PtCSUs BSC690 SET WRFD- Platinu Meaning: Whether to enable the platinum CS user
erEnhS 0 ULDCA 150204 m User enhancement function. This function guarantees the
witch LGOPA Prioritizi experience of platinum CS users by limiting the data
RA ng rate of common PS users, for example, increasing the
target uplink block error rate (BLER) for R99 PS users
and limiting the maximum transmit power of common
users. When this switch is set to on, the platinum CS
user enhancement function takes effect. When this
switch is set to off, the platinum CS user enhancement
function does not take effect.
GUI Value Range: OFF, ON
Unit: None
Actual Value Range: ON, OFF
Default Value: OFF

WCDMA RAN

nd
PtCSUs BSC691 SET WRFD- Platinu Meaning: Whether to enable the platinum CS user
erEnhS 0 ULDCA 150204 m User enhancement function. This function guarantees the
witch LGOPA Prioritizi experience of platinum CS users by limiting the data
RA ng rate of common PS users, for example, increasing the
target uplink block error rate (BLER) for R99 PS users
and limiting the maximum transmit power of common
users. When this switch is set to on, the platinum CS
user enhancement function takes effect. When this
switch is set to off, the platinum CS user enhancement
function does not take effect.
Unit: None
Actual Value Range: ON, OFF
Default Value: OFF
ULActul BSC690 ADD WRFD- Platinu Meaning: Threshold of the actual uplink service load for
LoadSta 0 UCELL 150204 m User the platinum CS user enhancement function to take
ForPtPri FRC Prioritizi effect. The uplink platinum CS user enhancement
or MOD ng algorithm takes effect only when the actual uplink
UCELL service load of the cell enters this state or enters a state
FRC where the congestion is more severe and the DCH user
number is congested (which is specified by the
"DchUserLoadStaForPtPrior" parameter).
GUI Value Range: UL_LIGHT_STATE,
UL_NORMAL_STATE, UL_LOADED_STATE,
UL_HEAVY_STATE, UL_OVERRLOAD_STATE
Unit: None
Actual Value Range: UL_LIGHT_STATE,
Default Value: UL_LOADED_STATE

WCDMA RAN

nd
ULActul BSC691 ADD WRFD- Platinu Meaning: Threshold of the actual uplink service load for
LoadSta 0 UCELL 150204 m User the platinum CS user enhancement function to take
ForPtPri FRC Prioritizi effect. The uplink platinum CS user enhancement
or MOD ng algorithm takes effect only when the actual uplink
UCELL service load of the cell enters this state or enters a state
GUI Value Range: UL_LIGHT_STATE,
Unit: None
Actual Value Range: UL_LIGHT_STATE,
Default Value: UL_LOADED_STATE
DLPwrL BSC690 ADD WRFD- Platinu Meaning: Threshold of downlink power congestion
oadStaF 0 UCELL 150204 m User state for the platinum CS user enhancement algorithm
orPtPrio FRC Prioritizi to take effect. The downlink platinum CS user
r MOD ng enhancement algorithm takes effect only when the non-
UCELL HSPA power of the cell enters this state or enters a state
GUI Value Range: DL_LIGHT_STATE,
DL_NORMAL_STATE, DL_LOADED_STATE,
DL_HEAVY_STATE, DL_OVERRLOAD_STATE
Unit: None
Actual Value Range: DL_LIGHT_STATE,
Default Value: DL_LOADED_STATE

WCDMA RAN

nd
DLPwrL BSC691 ADD WRFD- Platinu Meaning: Threshold of downlink power congestion
oadStaF 0 UCELL 150204 m User state for the platinum CS user enhancement algorithm
orPtPrio FRC Prioritizi to take effect. The downlink platinum CS user
r MOD ng enhancement algorithm takes effect only when the non-
UCELL HSPA power of the cell enters this state or enters a state
GUI Value Range: DL_LIGHT_STATE,
Unit: None
Actual Value Range: DL_LIGHT_STATE,
Default Value: DL_LOADED_STATE
DchUser BSC690 ADD WRFD- Platinu Meaning: Threshold of the DCH user number for the
LoadSta 0 UCELL 150204 m User platinum CS user enhancement function to take effect.
ForPtPri FRC Prioritizi The platinum CS user enhancement function takes
or MOD ng effect only when the DCH user number in the cell enters
UCELL this state or enters a state where the congestion is more
FRC severe.
GUI Value Range: DCHUSER_LIGHT_STATE,
DCHUSER_NORMAL_STATE,
DCHUSER_LOADED_STATE,
DCHUSER_HEAVY_STATE,
DCHUSER_OVERRLOAD_STATE
Unit: None
Actual Value Range: DCHUSER_LIGHT_STATE,
Default Value: DCHUSER_LOADED_STATE

WCDMA RAN

nd
DchUser BSC691 ADD WRFD- Platinu Meaning: Threshold of the DCH user number for the
LoadSta 0 UCELL 150204 m User platinum CS user enhancement function to take effect.
ForPtPri FRC Prioritizi The platinum CS user enhancement function takes
or MOD ng effect only when the DCH user number in the cell enters
UCELL this state or enters a state where the congestion is more
FRC severe.
GUI Value Range: DCHUSER_LIGHT_STATE,
Unit: None
Actual Value Range: DCHUSER_LIGHT_STATE,
Default Value: DCHUSER_LOADED_STATE
PsBlerT BSC690 SET WRFD- Platinu Meaning: Value of the target BLER increase for non-
arDeltaF 0 UOLPC 150204 m User platinum PS BE users in the Platinum User Prioritizing
orPtUser Prioritizi scenario. If cells of platinum CS users are congested,
ng the RNC adds the value of this parameter to the target
BLER of non-platinum PS BE users (specified by the
"BLERQuality" parameter in the "ADD
UTYPRABOLPC" command) and then uses Min
(Previously calculated value, -10) as the final target
BLER. This limits the load consumption of non-
platinum PS BE users and improves the experience of
platinum CS users. This parameter is an advanced
parameter. Therefore, modify the setting of this
parameter under the instruction of Huawei technical
support.
GUI Value Range: 0~40
Unit: None
Actual Value Range: 0~40
Default Value: 0

WCDMA RAN

nd
PsBlerT BSC691 SET WRFD- Platinu Meaning: Value of the target BLER increase for non-
arDeltaF 0 UOLPC 150204 m User platinum PS BE users in the Platinum User Prioritizing
orPtUser Prioritizi scenario. If cells of platinum CS users are congested,
ng the RNC adds the value of this parameter to the target
BLER of non-platinum PS BE users (specified by the
"BLERQuality" parameter in the "ADD
UTYPRABOLPC" command) and then uses Min
(Previously calculated value, -10) as the final target
BLER. This limits the load consumption of non-
platinum PS BE users and improves the experience of
platinum CS users. This parameter is an advanced
support.
Unit: None
Default Value: 0
PsUlInit BSC690 SET WRFD- Platinu Meaning: Limit of uplink initial access rate on DCH for
LimitRa 0 UFRC 150204 m User non-platinum PS BE users in the Platinum User
teForPt Prioritizi Prioritizing scenario. When this parameter is set to a
ng value other than NotLimited and cells of platinum CS
users are congested, the RNC limits the uplink initial
access rate of non-platinum PS BE users to a specific
DCH rate and prohibits rate increase and D2E attempts
for these users. When this parameter is set to
NotLimited, the RNC does not limit the uplink initial
access rate of non-platinum PS BE users. This
parameter is an advanced parameter. Therefore, modify
the setting of this parameter under the instruction of
Huawei technical support.
GUI Value Range: NotLimited, D8, D16, D32, D64,
D128, D144, D256, D384
Unit: kbit/s
Actual Value Range: NotLimited, 8, 16, 32, 64, 128,
144, 256, 384
Default Value: NotLimited

WCDMA RAN

nd
PsUlInit BSC691 SET WRFD- Platinu Meaning: Limit of uplink initial access rate on DCH for
LimitRa 0 UFRC 150204 m User non-platinum PS BE users in the Platinum User
users are congested, the RNC limits the uplink initial
access rate of non-platinum PS BE users to a specific
DCH rate and prohibits rate increase and D2E attempts
for these users. When this parameter is set to
NotLimited, the RNC does not limit the uplink initial
access rate of non-platinum PS BE users. This
D128, D144, D256, D384
Unit: kbit/s
144, 256, 384
PsDlInit BSC690 SET WRFD- Platinu Meaning: Limit of downlink initial access rate on DCH
LimitRa 0 UFRC 150204 m User for non-platinum R99 PS BE users in the Platinum User
users are congested, the RNC limits the downlink initial
access rate of non-platinum R99 PS BE users to a
specific DCH rate and prohibits rate increase and D2E
attempts for these users. When this parameter is set to
NotLimited, the RNC does not limit the downlink initial
access rate of non-platinum R99 PS BE users. This
D128, D144, D256, D384
Unit: kbit/s
144, 256, 384

WCDMA RAN

nd
PsDlInit BSC691 SET WRFD- Platinu Meaning: Limit of downlink initial access rate on DCH
LimitRa 0 UFRC 150204 m User for non-platinum R99 PS BE users in the Platinum User
users are congested, the RNC limits the downlink initial
access rate of non-platinum R99 PS BE users to a
specific DCH rate and prohibits rate increase and D2E
attempts for these users. When this parameter is set to
NotLimited, the RNC does not limit the downlink initial
access rate of non-platinum R99 PS BE users. This
D128, D144, D256, D384
Unit: kbit/s
144, 256, 384
DlOther BSC690 ADD WRFD- Platinu Meaning: Downlink load threshold for the admission of
ThdForP 0 UCELL 150204 m User other types of services in the Platinum User Prioritizing
t CAC Prioritizi scenario. Other types of services refer to services other
MOD ng than AMR conversational services, non-AMR
UCELL conversational services, and services in handover
CAC scenarios. During the admission of other types of
services, the RNC evaluates the downlink cell load after
the service admission. If the estimated downlink cell
load is higher this threshold, the RNC rejects the service
admission. If the estimated downlink cell load is lower
than or equal to this threshold, the RNC admits the
service admission. This parameter is an advanced
support.
Unit: %
Default Value: 70

WCDMA RAN

nd
DlOther BSC691 ADD WRFD- Platinu Meaning: Downlink load threshold for the admission of
ThdForP 0 UCELL 150204 m User other types of services in the Platinum User Prioritizing
t CAC Prioritizi scenario. Other types of services refer to services other
MOD ng than AMR conversational services, non-AMR
UCELL conversational services, and services in handover
CAC scenarios. During the admission of other types of
services, the RNC evaluates the downlink cell load after
the service admission. If the estimated downlink cell
load is higher this threshold, the RNC rejects the service
admission. If the estimated downlink cell load is lower
than or equal to this threshold, the RNC admits the
service admission. This parameter is an advanced
support.
Unit: %
Default Value: 70
PTCSPa BSC690 SET WRFD- Platinu Meaning: Whether the RNC preferentially sends the CS
gingPree 0 UDPUC 150204 m User conversational paging messages for platinum users.
mptSwit FGDAT Prioritizi When this switch is set to ON, the RNC preferentially
ch A ng sends CS conversational paging messages for platinum
users and holds back paging messages for
conversational, streaming, interactive, background, and
SMS services. When this switch is set to OFF, the RNC
sends paging messages according to the "first-come,
first-served" rule.
GUI Value Range: OFF(OFF), ON(ON)
Unit: None
Actual Value Range: OFF, ON
Default Value: OFF(OFF)

WCDMA RAN

nd
PTCSPa BSC691 SET WRFD- Platinu Meaning: Whether the RNC preferentially sends the CS
gingPree 0 UDPUC 150204 m User conversational paging messages for platinum users.
mptSwit FGDAT Prioritizi When this switch is set to ON, the RNC preferentially
ch A ng sends CS conversational paging messages for platinum
users and holds back paging messages for
conversational, streaming, interactive, background, and
first-served" rule.
Unit: None
PTPSPa BSC690 SET WRFD- Platinu Meaning: Whether the RNC preferentially sends the PS
gingPree 0 UDPUC 150204 m User paging messages for platinum users. When this switch
mptSwit FGDAT Prioritizi is set to ON, the RNC preferentially sends PS paging
ch A ng messages for platinum users and holds back paging
messages for streaming,interactive, background, and
first-served" rule.
Unit: None
PTPSPa BSC691 SET WRFD- Platinu Meaning: Whether the RNC preferentially sends the PS
gingPree 0 UDPUC 150204 m User paging messages for platinum users. When this switch
mptSwit FGDAT Prioritizi is set to ON, the RNC preferentially sends PS paging
ch A ng messages for platinum users and holds back paging
messages for streaming,interactive, background, and
first-served" rule.
Unit: None

WCDMA RAN

nd
PTUser BSC690 ADD WRFD- Platinu Meaning:

StateTra 0 UPLATI 150204 m User State transition policy for the specified platinum
nsStrate NUMIM Prioritizi subscribers.
gy SI ng
The value NORMALSTATETRANS indicates that the
MOD state transition policy for the specified platinum
UPLATI subscribers is the same as that for non-platinum
NUMIM subscribers.
SI
The value NOSTATETRANS indicates that the
specified platinum subscribers do not perform state
transitions.
The value SPECIALSTATETRANS indicates that the
specified platinum subscribers perform state transitions
only when a related timer expires.
GUI Value Range: NORMALSTATETRANS,
NOSTATETRANS, SPECIALSTATETRANS
Unit: None
Actual Value Range: NORMALSTATETRANS,
Default Value: NORMALSTATETRANS
PTUser BSC691 ADD WRFD- Platinu Meaning:

StateTra 0 UPLATI 150204 m User State transition policy for the specified platinum
nsStrate NUMIM Prioritizi subscribers.
gy SI ng
The value NORMALSTATETRANS indicates that the
MOD state transition policy for the specified platinum
UPLATI subscribers is the same as that for non-platinum
NUMIM subscribers.
SI
The value NOSTATETRANS indicates that the
specified platinum subscribers do not perform state
transitions.
The value SPECIALSTATETRANS indicates that the
specified platinum subscribers perform state transitions
only when a related timer expires.
GUI Value Range: NORMALSTATETRANS,
Unit: None
Actual Value Range: NORMALSTATETRANS,
Default Value: NORMALSTATETRANS

WCDMA RAN

nd
PtUserR BSC690 SET WRFD- Platinu Meaning: Maximum value of downlink transmit power
lMaxDl 0 UOLPC 150204 m User increase for platinum CS users. The RNC adds the value
PwrDelt Prioritizi of this parameter to the "RlMaxDlPwr" parameter in the
a ng "ADD UCELLRLPWR" command to obtain the final
maximum downlink transmit power for platinum CS
users.
Unit: 0.1dB
Default Value: 30
PtUserR BSC691 SET WRFD- Platinu Meaning: Maximum value of downlink transmit power
lMaxDl 0 UOLPC 150204 m User increase for platinum CS users. The RNC adds the value
PwrDelt Prioritizi of this parameter to the "RlMaxDlPwr" parameter in the
a ng "ADD UCELLRLPWR" command to obtain the final
maximum downlink transmit power for platinum CS
users.
Unit: 0.1dB
Default Value: 30

WCDMA RAN

nd
PROCE BSC690 SET WRFD- Cell Meaning:

SSSWIT 0 URRCT 021102 Barring 1)INVOKE_TRACE_SWITCH.
CH RLSWI WRFD- Layered 1: This switch is turned on. RNC will start Invoke Trace
TCH 150205 Paging procedure upon receiving INVOKE TRACE Message
WRFD- in Idle form CN.
150204 Mode
0: This switch is turned off. RNC will not start the
WRFD- Platinu Invoke Trace procedure though it receives the INVOKE
010101 m User TRACE message.
Prioritizi
WRFD- 2)SYS_INFO_UPDATE_FOR_IU_RST.
ng
150231 1: This switch is turned on. The SIB1 does not contain
3GPP broken-down CN information. In this case, the UE will
WRFD- R9
020500 not select broken-down network when Iu transmission
Specific failure occurs.
WRFD- ations
021303 0: This switch is turned off. The SIB1 contains the
RIM broken-down CN information. In this case, the UE will
WRFD- Based select broken-down network but the RNC will reject the
020132 UMTS request when Iu transmission failure occurs.
WRFD- Target
Cell 3)DRNC_DIRECT_DSCR.
020124
Selectio Whether the Directed Signaling Connection re-
WRFD- establishment (DSCR) procedure is triggered during a
n for
140206 cell update over the Iur interface for UEs that are not in
LTE
WRFD- the CELL_DCH state or for UEs that are in the
Enhance
020134 CELL_DCH state and do not have an Iur connection.
d Fast
WRFD- This switch is set on the drift radio network controller
Dorman
020128 (DRNC) side.
cy
WRFD- 1: This switch is turned on. DRNC will start DSCR
IMSI
0106121 procedure directly in RRC states other than
Based
2 CELL_DCH or CELL_DCH that do not have an Iur
Handov
connection.
WRFD- er
010641 0: This switch is turned off. DRNC will transfer RRC
Web
CELL UPDATE message to SRNC.
WRFD- browsin
g 4)PTUSER_IDENTIFY_ENH_SWITCH (Platinum
020806
accelerat user identify enhancement switch)
ion Whether platinum users are identified in DRNC or
Uplink relocation scenarios.
Flow 1: This switch is turned on. Platinum users are identified
Control and their services are guaranteed in DRNC or relocation
of User scenarios.
Plane 0: This switch is turned off. Platinum users are not
Layered identified in DRNC or relocation scenarios.
Paging 5)RNC_SHARE_SWITCH.
in
1: This switch is turned on. The traffic sharing function
is enabled.

WCDMA RAN

nd
URA_P 0: This switch is turned off. The traffic sharing function

CH is disabled, service access will be affected under heavy
Push to traffic.
Talk 6)RNCAP_IMSI_HO_SWITCH.
Quality 1: This switch is turned on. Imsi handover function will
Improve be used.
ment for
0: This switch is turned off. Imsi handover function will
Subscrib
not be used.
ed
Service 7)TERMINAL_VERSION_DEBASE_SWITCH.
HSUPA 1: This switch is turned on. Terminal version R4 will
Iub Flow debase to R99.
Control 0: This switch is turned off. Terminal version R4 will
in Case not debase to R99.
of Iub
8)SYS_HO_OUT_CIPHER_SWITCH.
Congesti
on 1: This switch is turned on. The RNC will add ciphering
byte at GSM HANDOVER COMMAND if the GSM
HSUPA
system do not add any cipher information at that
Adaptiv
message.
e
Transmi 0: This switch is turned off. The RNC will not add
ssion ciphering byte at GSM HANDOVER COMMAND if
the GSM system do not add any cipher information at
Differen
that message.
tiated
Service 9)SYS_HO_CIPHER_CONFIG.
Based 1: This switch is turned on. The cipher configuration in
on SPI the added cipher byte in GSM will be A5/1.
Weight
0: This switch is turned off. The cipher configuration is
A5/0.
10)BARRED_CELL_FOR_CSDOMAIN_RST.
1: This switch is turned on. Cell will be bared when CS
domain is invalid.
0: This switch is turned off. The CS domain will be
bared when CS domain is invalid.
It is invalid If SYS_INFO_UPDATE_FOR_IU_RST is
not checked.
11)CR2284R1_SWITCH.
1: This switch is turned on. The RNC performs the
processing based on CR2284R1, that is, based on the
description in section 8.6.6.28 of Release 5 TS 25.331.
In this section, it describes that the HFN is increased by
one when RB setup is accompanied by a Timing re-
initialized hard handover.

WCDMA RAN

nd
0: This switch is turned off. The HFN is not increased

by one when RB setup is accompanied by a Timing re-
12)CDT_MSG_FULL_TRACE.
1: This switch is turned on. CDT trace function starts
tracing from message RRC CONNECT REQUEST.
0: This switch is turned off. CDT trace function starts
tracing from message COMMON ID.
13)CR2284R1_COMPATIBLE_SWITCH.
CR2284R1 causes the compatible problem. if UE is not
consistent with RNC regarding whether accept the
CR2284R1 or not, it will cause the problem of streaming
when UEs are communicating with each other. So RNC
creates this switch. when it is checked, RNC is auto-
adaptive to accept the CR2284R1 according to UE
version information. The principles that RNC judges
UE whether to accept the CR2284R1 are as follows: R5
and above UE accepts the CR; R99/R4 UE, if it receives
the START LIST value from RB SETUP
COMPLETE,RNC figures that UE accepts the CR;
R99/R4 UE, if it only receives the START value from
RB SETUP COMPLETE,RNC figures that UE does not
accept the CR; when it is not checked, whether RNC
accept the CR or not is according to
CR2284R1_SWITCH. The relations between these two
switches CR2284R1_SWITCH and
CR2284R1_COMPATIBLE_SWITCH are as follows:
1: This switch is turned on. RNC is self-compatible, so
the CR2284R1_SWITCH is invalid;
0: This switch is turned off. The CR2284R1_SWITCH
is valid.
14)COMBINE_OPERATION_DRD_SWITCH.
1: This switch is turned on. RNC will not reject the
message RB SETUP CMP without the IE active time.
0: This switch is turned off. RNC will reject the message
RB SETUP CMP without the IE active time.
15)UL_INTER_PROTECT_SWITCH.
Although the configuration interface in this version
supports delivery and synchronization of the bit field
value, the bit field value is no longer internally used.
1: This switch is turned on. RNC will do integrity
protection check for uplink RRC messages.

WCDMA RAN

nd
0: This switch is turned off. RNC will not do integrity

16)FAST_DORMANCY_SWITCH.
1: This switch is turned on. RNC will apply FAST
DORMANCY function.
0: This switch is turned off. RNC will not apply FAST
DORMANCY function.
17)SYS_HO_IN_CIPHER_SWITCH.
During an incoming GSM-to-UMTS handover, if the
RNC cannot obtain a UE's encryption capability
information from the RELOC REQ message:
1: This switch is turned on. The encryption algorithm
that is configured for both the RNC and CN is used. For
example, if the CN is configured with the encryption
algorithm UEA1 and the RNC is configured with
encryption algorithms UEA0 and UEA1, then the RNC
uses the encryption algorithm UEA1.
0: This switch is turned off. Default configured of
encrypted parameter UIA1 and UEA0 is used.
18)PTT_EARLY_TRANS_SWITCH_OFF.
1: This switch is turned on. PTT user will not apply the
early transmission function.
0: This switch is turned off. PTT user will apply the early
transmission function.
19)UPLINK_MDC_ENHENCEMENT_SWITCH.
This switch has become invalid.
20)NODEB_PRIVATE_INTERFACE_SWITCH.
1: This switch is turned on. The NodeB private interface
data can be taken to the NodeB through the IUB protocol
message.
0: This switch is turned off. The NodeB private interface
data can not be taken to the NodeB through the IUB
protocol message.
21)PTT_SPEC_LI_SWITCH_OFF.
1: This switch is turned on. Special LI(Length Indicator)
will not be used for PTT user.
0: This switch is turned off. Special LI(Length
Indicator) will be used for PTT user.
22)RNC_DF_2_URA_PCH_SWITCH.
1: This switch is turned on. RNC will support
transferring Fast Dormancy UE from CELL_DCH or
CELL_FACH to URA_PCH.

WCDMA RAN

nd
0: This switch is turned off. RNC will not support

23)FD_TAC_MATCH_SWITCH.
1: This switch is turned on. The RNC uses TAC
matching to determine whether to apply the FAST
DORMANCY function for UEs.
0: This switch is turned off. The RNC applies the FAST
DORMANCY function for UEs of 3GPP Release 5 or
later.
24)NONPTT_L1_FAST_SYNC_SWITCH.
1: This switch is turned on. If a UE sets up a non-PTT
service on the DCH, the RNC includes the Post-
verification period information element (IE) in a Uu
message to instruct the UE to perform concurrent uplink
and downlink synchronization.
0: This switch is turned off. If a UE sets up a non-PTT
service on the DCH, the RNC does not include the Post-
verification period IE in a Uu message. The UE first
performs downlink synchronization and then uplink
synchronization.
25)URAPCH_LAYERED_PAGING_RT_SWITCH.
Whether the RNC allows Layered Paging in URA_PCH
for a UE processing real-time services.
1: This switch is turned on. The RNC sends paging
messages to the cell on which a UE processing real-time
services camped recently and to the neighboring cells
of this cell. The RNC pages the UE in the entire UTRAN
registration area (URA) only when it does not receive a
response from the UE. This significantly reduces the
number of paging messages on the Uu interface.
0: This switch is turned off. The RNC directly pages the
UE in the entire URA.
26)URAPCH_LAYERED_PAGING_NRT_SWITCH.
for a UE processing non-real-time services.
messages to the cell on which a UE processing non-real-
time services camped recently and to the neighboring
cells of this cell. The RNC pages the UE in the entire
URA only when the RNC does not receive a response
from the UE. This significantly reduces the number of
paging messages on the Uu interface.

WCDMA RAN

nd

27)IDLE_LAYERED_PAGING_NRT_SWITCH.
Whether to enable layered paging for UEs in the idle
state who will establish non-real-time service.
1: This switch is turned on. The first broadcasts a paging
message in the cell who has interacted with the UE for
the last time and its neighboring cells. If the UE cannot
be paged, the RNC then broadcasts a paging message in
the LAC or RAC area.
0: This switch is turned off. The RNC directly
broadcasts a paging message in the LAC or RAC area.
28)IDLE_LAYERED_PAGING_RT_SWITCH.
state who will establish real-time service.
1: This switch is turned on. First broadcasts a paging
29)INTELLIGENT_WIFI_DETECT_AND_SELEC-
TION.
Whether to enable intelligent Wi-Fi detection and
selection for the RNC.
1: This switch is turned on. The RNC supports
intelligent Wi-Fi detection and selection.
0: This switch is turned off. The RNC does not supports
30)
INTERRAT_LOAD_REPORT_FOR_LTE_SWITCH.
Whether to enable the RIM-based cell load sharing
function(Multiple Report).
1: This switch is turned on. RIM-based load sharing can
be achieved between UMTS and LTE cells. Upon
receiving a load sharing request from an LTE cell, a
UMTS cell responds with its own load information.
0: This switch is turned off. UMTS cells do not support
the RIM-based cell load sharing function. Therefore,
UMTS cells do not respond to load sharing requests
from LTE cells.

WCDMA RAN

nd
31)PTUSER_IDENTIFY_SWITCH.
Whether to preferentially guarantee platinum users in
terms of network access, voice quality, or PS service
rate.
1: This switch is turned on. The RNC recognizes
platinum users and preferentially guarantees their user
experience.
0: This switch is turned off. The RNC does not recognize
platinum users and does not preferentially guarantee
their user experience.
Disuse Statement:In future versions, the
RNC_SHARE_SWITCH,
TERMINAL_VERSION_DEBASE_SWITCH,
CR2284R1_SWITCH,
CR2284R1_COMPATIBLE_SWITCH,
COMBINE_OPERATION_DRD_SWITCH and
UPLINK_MDC_ENHENCEMENT_SWITCH bit
field value under the PROCESSSWITCH parameter
will be deleted. Although the configuration interface in
this version supports delivery and synchronization of
the bit field value, the bit field value is no longer
internally used.
Instead, the function of RNC_SHARE_SWITCH will
be controlled by the RncShareSwitch parameter in the
SET UCTRLPLNSHAREPARA command.
GUI Value Range: INVOKE_TRACE_SWITCH,
SYS_INFO_UPDATE_FOR_IU_RST,
DRNC_DIRECT_DSCR,
PTUSER_IDENTIFY_ENH_SWITCH,
RNC_SHARE_SWITCH,
RNCAP_IMSI_HO_SWITCH,
SYS_HO_OUT_CIPHER_SWITCH,
SYS_HO_CIPHER_CONFIG,
BARRED_CELL_FOR_CSDOMAIN_RST,
CR2284R1_SWITCH, CDT_MSG_FULL_TRACE,
COMBINE_OPERATION_DRD_SWITCH,
UL_INTER_PROTECT_SWITCH,
FAST_DORMANCY_SWITCH,
SYS_HO_IN_CIPHER_SWITCH,
PTT_EARLY_TRANS_SWITCH_OFF,
UPLINK_MDC_ENHENCEMENT_SWITCH,
NODEB_PRIVATE_INTERFACE_SWITCH,
PTT_SPEC_LI_SWITCH_OFF,

WCDMA RAN

nd
RNC_DF_2_URA_PCH_SWITCH,
FD_TAC_MATCH_SWITCH,
NONPTT_L1_FAST_SYNC_SWITCH,
URAPCH_LAYERED_PAGING_RT_SWITCH,
URAPCH_LAYERED_PAGING_NRT_SWITCH,
IDLE_LAYERED_PAGING_NRT_SWITCH,
IDLE_LAYERED_PAGING_RT_SWITCH,
INTELLIGENT_WIFI_DETECT_AND_SELEC-
TION,
INTERRAT_LOAD_REPORT_FOR_LTE_SWITCH,
PTUSER_IDENTIFY_SWITCH
Unit: None
Actual Value Range:
INVOKE_TRACE_SWITCH,
DRNC_DIRECT_DSCR,
RNC_SHARE_SWITCH,
TION,

WCDMA RAN

nd
Default Value: INVOKE_TRACE_SWITCH:
0,SYS_INFO_UPDATE_FOR_IU_RST:
0,DRNC_DIRECT_DSCR:
0,PTUSER_IDENTIFY_ENH_SWITCH:
0,RNC_SHARE_SWITCH:
1,RNCAP_IMSI_HO_SWITCH:
0,TERMINAL_VERSION_DEBASE_SWITCH:
0,SYS_HO_OUT_CIPHER_SWITCH:
0,SYS_HO_CIPHER_CONFIG:
1,BARRED_CELL_FOR_CSDOMAIN_RST:
0,CR2284R1_SWITCH:
0,CDT_MSG_FULL_TRACE:
0,CR2284R1_COMPATIBLE_SWITCH:
1,COMBINE_OPERATION_DRD_SWITCH:
1,UL_INTER_PROTECT_SWITCH:
0,FAST_DORMANCY_SWITCH:
0,SYS_HO_IN_CIPHER_SWITCH:
0,PTT_EARLY_TRANS_SWITCH_OFF:
0,UPLINK_MDC_ENHENCEMENT_SWITCH:
0,NODEB_PRIVATE_INTERFACE_SWITCH:
0,PTT_SPEC_LI_SWITCH_OFF:
0,RNC_DF_2_URA_PCH_SWITCH:
0,FD_TAC_MATCH_SWITCH:
0,NONPTT_L1_FAST_SYNC_SWITCH:
0,URAPCH_LAYERED_PAGING_RT_SWITCH:
0,URAPCH_LAYERED_PAGING_NRT_SWITCH:
0,IDLE_LAYERED_PAGING_NRT_SWITCH:
0,IDLE_LAYERED_PAGING_RT_SWITCH:
0,INTELLIGENT_WIFI_DETECT_AND_SELEC-
TION:
0,INTERRAT_LOAD_REPORT_FOR_LTE_SWITC
H:0,PTUSER_IDENTIFY_SWITCH:0

WCDMA RAN

nd
PROCE BSC691 SET WRFD- Cell Meaning:

SSSWIT 0 URRCT 021102 Barring 1)INVOKE_TRACE_SWITCH.
CH RLSWI WRFD- Layered 1: This switch is turned on. RNC will start Invoke Trace
TCH 150205 Paging procedure upon receiving INVOKE TRACE Message
WRFD- in Idle form CN.
150204 Mode
0: This switch is turned off. RNC will not start the
WRFD- Platinu Invoke Trace procedure though it receives the INVOKE
010101 m User TRACE message.
Prioritizi
WRFD- 2)SYS_INFO_UPDATE_FOR_IU_RST.
ng
150231 1: This switch is turned on. The SIB1 does not contain
3GPP broken-down CN information. In this case, the UE will
WRFD- R9
020500 not select broken-down network when Iu transmission
Specific failure occurs.
WRFD- ations
021303 0: This switch is turned off. The SIB1 contains the
RIM broken-down CN information. In this case, the UE will
WRFD- Based select broken-down network but the RNC will reject the
020132 UMTS request when Iu transmission failure occurs.
WRFD- Target
Cell 3)DRNC_DIRECT_DSCR.
020124
Selectio Whether the Directed Signaling Connection re-
WRFD- establishment (DSCR) procedure is triggered during a
n for
140206 cell update over the Iur interface for UEs that are not in
LTE
WRFD- the CELL_DCH state or for UEs that are in the
Enhance
020134 CELL_DCH state and do not have an Iur connection.
d Fast
WRFD- This switch is set on the drift radio network controller
Dorman
020128 (DRNC) side.
cy
WRFD- 1: This switch is turned on. DRNC will start DSCR
IMSI
0106121 procedure directly in RRC states other than
Based
2 CELL_DCH or CELL_DCH that do not have an Iur
Handov
connection.
WRFD- er
010641 0: This switch is turned off. DRNC will transfer RRC
Web
CELL UPDATE message to SRNC.
WRFD- browsin
g 4)PTUSER_IDENTIFY_ENH_SWITCH (Platinum
020806
accelerat user identify enhancement switch)
ion Whether platinum users are identified in DRNC or
Uplink relocation scenarios.
Flow 1: This switch is turned on. Platinum users are identified
Control and their services are guaranteed in DRNC or relocation
of User scenarios.
Plane 0: This switch is turned off. Platinum users are not
Layered identified in DRNC or relocation scenarios.
Paging 5)RNC_SHARE_SWITCH.
in
1: This switch is turned on. The traffic sharing function
is enabled.

WCDMA RAN

nd
URA_P 0: This switch is turned off. The traffic sharing function

CH is disabled, service access will be affected under heavy
Push to traffic.
Talk 6)RNCAP_IMSI_HO_SWITCH.
Quality 1: This switch is turned on. Imsi handover function will
Improve be used.
ment for
0: This switch is turned off. Imsi handover function will
Subscrib
not be used.
ed
Service 7)TERMINAL_VERSION_DEBASE_SWITCH.
HSUPA 1: This switch is turned on. Terminal version R4 will
Iub Flow debase to R99.
Control 0: This switch is turned off. Terminal version R4 will
in Case not debase to R99.
of Iub
8)SYS_HO_OUT_CIPHER_SWITCH.
Congesti
on 1: This switch is turned on. The RNC will add ciphering
byte at GSM HANDOVER COMMAND if the GSM
HSUPA
system do not add any cipher information at that
Adaptiv
message.
e
Transmi 0: This switch is turned off. The RNC will not add
ssion ciphering byte at GSM HANDOVER COMMAND if
the GSM system do not add any cipher information at
Differen
that message.
tiated
Service 9)SYS_HO_CIPHER_CONFIG.
Based 1: This switch is turned on. The cipher configuration in
on SPI the added cipher byte in GSM will be A5/1.
Weight
0: This switch is turned off. The cipher configuration is
A5/0.
10)BARRED_CELL_FOR_CSDOMAIN_RST.
1: This switch is turned on. Cell will be bared when CS
domain is invalid.
0: This switch is turned off. The CS domain will be
bared when CS domain is invalid.
It is invalid If SYS_INFO_UPDATE_FOR_IU_RST is
not checked.
11)CR2284R1_SWITCH.
1: This switch is turned on. The RNC performs the
processing based on CR2284R1, that is, based on the
description in section 8.6.6.28 of Release 5 TS 25.331.
In this section, it describes that the HFN is increased by
one when RB setup is accompanied by a Timing re-

WCDMA RAN

nd
0: This switch is turned off. The HFN is not increased

by one when RB setup is accompanied by a Timing re-
12)CDT_MSG_FULL_TRACE.
1: This switch is turned on. CDT trace function starts
tracing from message RRC CONNECT REQUEST.
0: This switch is turned off. CDT trace function starts
tracing from message COMMON ID.
13)CR2284R1_COMPATIBLE_SWITCH.
CR2284R1 causes the compatible problem. if UE is not
consistent with RNC regarding whether accept the
CR2284R1 or not, it will cause the problem of streaming
when UEs are communicating with each other. So RNC
creates this switch. when it is checked, RNC is auto-
adaptive to accept the CR2284R1 according to UE
version information. The principles that RNC judges
UE whether to accept the CR2284R1 are as follows: R5
and above UE accepts the CR; R99/R4 UE, if it receives
the START LIST value from RB SETUP
COMPLETE,RNC figures that UE accepts the CR;
R99/R4 UE, if it only receives the START value from
RB SETUP COMPLETE,RNC figures that UE does not
accept the CR; when it is not checked, whether RNC
accept the CR or not is according to
CR2284R1_SWITCH. The relations between these two
switches CR2284R1_SWITCH and
CR2284R1_COMPATIBLE_SWITCH are as follows:
1: This switch is turned on. RNC is self-compatible, so
the CR2284R1_SWITCH is invalid;
0: This switch is turned off. The CR2284R1_SWITCH
is valid.
14)COMBINE_OPERATION_DRD_SWITCH.
1: This switch is turned on. RNC will not reject the
message RB SETUP CMP without the IE active time.
0: This switch is turned off. RNC will reject the message
RB SETUP CMP without the IE active time.
15)UL_INTER_PROTECT_SWITCH.
Although the configuration interface in this version
supports delivery and synchronization of the bit field
value, the bit field value is no longer internally used.
1: This switch is turned on. RNC will do integrity

WCDMA RAN

nd
0: This switch is turned off. RNC will not do integrity

16)FAST_DORMANCY_SWITCH.
1: This switch is turned on. RNC will apply FAST
DORMANCY function.
0: This switch is turned off. RNC will not apply FAST
DORMANCY function.
17)SYS_HO_IN_CIPHER_SWITCH.
During an incoming GSM-to-UMTS handover, if the
RNC cannot obtain a UE's encryption capability
information from the RELOC REQ message:
1: This switch is turned on. The encryption algorithm
that is configured for both the RNC and CN is used. For
example, if the CN is configured with the encryption
algorithm UEA1 and the RNC is configured with
encryption algorithms UEA0 and UEA1, then the RNC
uses the encryption algorithm UEA1.
0: This switch is turned off. Default configured of
encrypted parameter UIA1 and UEA0 is used.
18)PTT_EARLY_TRANS_SWITCH_OFF.
1: This switch is turned on. PTT user will not apply the
early transmission function.
0: This switch is turned off. PTT user will apply the early
transmission function.
19)UPLINK_MDC_ENHENCEMENT_SWITCH.
This switch has become invalid.
20)NODEB_PRIVATE_INTERFACE_SWITCH.
1: This switch is turned on. The NodeB private interface
data can be taken to the NodeB through the IUB protocol
message.
0: This switch is turned off. The NodeB private interface
data can not be taken to the NodeB through the IUB
protocol message.
21)PTT_SPEC_LI_SWITCH_OFF.
1: This switch is turned on. Special LI(Length Indicator)
will not be used for PTT user.
0: This switch is turned off. Special LI(Length
Indicator) will be used for PTT user.
22)RNC_DF_2_URA_PCH_SWITCH.
1: This switch is turned on. RNC will support

WCDMA RAN

nd
0: This switch is turned off. RNC will not support

23)FD_TAC_MATCH_SWITCH.
1: This switch is turned on. The RNC uses TAC
matching to determine whether to apply the FAST
DORMANCY function for UEs.
0: This switch is turned off. The RNC applies the FAST
DORMANCY function for UEs of 3GPP Release 5 or
later.
24)NONPTT_L1_FAST_SYNC_SWITCH.
1: This switch is turned on. If a UE sets up a non-PTT
service on the DCH, the RNC includes the Post-
verification period information element (IE) in a Uu
message to instruct the UE to perform concurrent uplink
and downlink synchronization.
0: This switch is turned off. If a UE sets up a non-PTT
service on the DCH, the RNC does not include the Post-
verification period IE in a Uu message. The UE first
performs downlink synchronization and then uplink
synchronization.
25)URAPCH_LAYERED_PAGING_RT_SWITCH.
for a UE processing real-time services.
messages to the cell on which a UE processing real-time
services camped recently and to the neighboring cells
of this cell. The RNC pages the UE in the entire UTRAN
registration area (URA) only when it does not receive a
response from the UE. This significantly reduces the
number of paging messages on the Uu interface.
26)URAPCH_LAYERED_PAGING_NRT_SWITCH.
for a UE processing non-real-time services.
messages to the cell on which a UE processing non-real-
time services camped recently and to the neighboring
cells of this cell. The RNC pages the UE in the entire
URA only when the RNC does not receive a response
from the UE. This significantly reduces the number of
paging messages on the Uu interface.

WCDMA RAN

nd

27)IDLE_LAYERED_PAGING_NRT_SWITCH.
state who will establish non-real-time service.
1: This switch is turned on. The first broadcasts a paging
28)IDLE_LAYERED_PAGING_RT_SWITCH.
state who will establish real-time service.
1: This switch is turned on. First broadcasts a paging
29)INTELLIGENT_WIFI_DETECT_AND_SELEC-
TION.
Whether to enable intelligent Wi-Fi detection and
selection for the RNC.
1: This switch is turned on. The RNC supports
0: This switch is turned off. The RNC does not supports
30)
INTERRAT_LOAD_REPORT_FOR_LTE_SWITCH.
Whether to enable the RIM-based cell load sharing
function(Multiple Report).
1: This switch is turned on. RIM-based load sharing can
be achieved between UMTS and LTE cells. Upon
receiving a load sharing request from an LTE cell, a
UMTS cell responds with its own load information.
0: This switch is turned off. UMTS cells do not support
the RIM-based cell load sharing function. Therefore,
UMTS cells do not respond to load sharing requests
from LTE cells.

WCDMA RAN

nd
31)PTUSER_IDENTIFY_SWITCH.
Whether to preferentially guarantee platinum users in
terms of network access, voice quality, or PS service
rate.
1: This switch is turned on. The RNC recognizes
platinum users and preferentially guarantees their user
experience.
0: This switch is turned off. The RNC does not recognize
platinum users and does not preferentially guarantee
their user experience.
Disuse Statement:In future versions, the
RNC_SHARE_SWITCH,
CR2284R1_SWITCH,
COMBINE_OPERATION_DRD_SWITCH and
UPLINK_MDC_ENHENCEMENT_SWITCH bit
field value under the PROCESSSWITCH parameter
will be deleted. Although the configuration interface in
this version supports delivery and synchronization of
the bit field value, the bit field value is no longer
internally used.
Instead, the function of RNC_SHARE_SWITCH will
be controlled by the RncShareSwitch parameter in the
SET UCTRLPLNSHAREPARA command.
GUI Value Range: INVOKE_TRACE_SWITCH,
DRNC_DIRECT_DSCR,
RNC_SHARE_SWITCH,

WCDMA RAN

nd
TION,
Unit: None
Actual Value Range:
INVOKE_TRACE_SWITCH,
DRNC_DIRECT_DSCR,
RNC_SHARE_SWITCH,
TION,

WCDMA RAN

nd
Default Value: INVOKE_TRACE_SWITCH:
0,SYS_INFO_UPDATE_FOR_IU_RST:
0,DRNC_DIRECT_DSCR:
0,PTUSER_IDENTIFY_ENH_SWITCH:
0,RNC_SHARE_SWITCH:
1,RNCAP_IMSI_HO_SWITCH:
0,TERMINAL_VERSION_DEBASE_SWITCH:
0,SYS_HO_OUT_CIPHER_SWITCH:
0,SYS_HO_CIPHER_CONFIG:
1,BARRED_CELL_FOR_CSDOMAIN_RST:
0,CR2284R1_SWITCH:
0,CDT_MSG_FULL_TRACE:
0,CR2284R1_COMPATIBLE_SWITCH:
1,COMBINE_OPERATION_DRD_SWITCH:
1,UL_INTER_PROTECT_SWITCH:
0,FAST_DORMANCY_SWITCH:
0,SYS_HO_IN_CIPHER_SWITCH:
0,PTT_EARLY_TRANS_SWITCH_OFF:
0,UPLINK_MDC_ENHENCEMENT_SWITCH:
0,NODEB_PRIVATE_INTERFACE_SWITCH:
0,PTT_SPEC_LI_SWITCH_OFF:
0,RNC_DF_2_URA_PCH_SWITCH:
0,FD_TAC_MATCH_SWITCH:
0,NONPTT_L1_FAST_SYNC_SWITCH:
0,URAPCH_LAYERED_PAGING_RT_SWITCH:
0,URAPCH_LAYERED_PAGING_NRT_SWITCH:
0,IDLE_LAYERED_PAGING_NRT_SWITCH:
0,IDLE_LAYERED_PAGING_RT_SWITCH:
0,INTELLIGENT_WIFI_DETECT_AND_SELEC-
TION:
0,INTERRAT_LOAD_REPORT_FOR_LTE_SWITC
H:0,PTUSER_IDENTIFY_SWITCH:0
Platinu BSC690 ADD WRFD- Platinu Meaning: IMSI of a platinum user. RNC identifies a
mIMSI 0 UPLATI 150204 m User platinum user based on its IMSI.
NUMIM Prioritizi GUI Value Range: 6~15 digits
SI ng
Unit: None
MOD
UPLATI Actual Value Range: 6~15 digits
NUMIM Default Value: None
SI
RMV
UPLATI
NUMIM
SI

WCDMA RAN

nd
Platinu BSC691 ADD WRFD- Platinu Meaning: IMSI of a platinum user. RNC identifies a
mIMSI 0 UPLATI 150204 m User platinum user based on its IMSI.
NUMIM Prioritizi GUI Value Range: 6~15 digits
SI ng
Unit: None
MOD
UPLATI Actual Value Range: 6~15 digits
NUMIM Default Value: None
SI
RMV
UPLATI
NUMIM
SI
Priority BSC690 SET WRFD- Queuing Meaning:

Referen 0 UUSER 010505 and Pre- Reference used to determine which priority is arranged
ce PRIORI WRFD- Emption first in the priority sequence.
TY 150204 Platinu If the ARP is preferably used, the priority sequence is
WRFD- m User gold > silver > copper. If the ARPs are all the same, the
020106 Prioritizi TrafficClass is used and the priority sequence is
ng conversational > streaming > interactive > background.
WRFD-
020107 Load If the TrafficClass is preferably used, the priority
Reshuffl sequence is conversational > streaming > interactive >
WRFD- ing
020806 background. If the TrafficClass factors are all the same,
Overloa the ARP factor is used and the priority sequence is gold
d > silver > copper.
Control GUI Value Range: ARP, TrafficClass
Differen Unit: None
tiated
Service Actual Value Range: ARP, TrafficClass
Based Default Value: ARP
on SPI
Weight

WCDMA RAN

nd
Priority BSC691 SET WRFD- Queuing Meaning:

Referen 0 UUSER 010505 and Pre- Reference used to determine which priority is arranged
ce PRIORI WRFD- Emption first in the priority sequence.
TY 150204 Platinu If the ARP is preferably used, the priority sequence is
WRFD- m User gold > silver > copper. If the ARPs are all the same, the
020106 Prioritizi TrafficClass is used and the priority sequence is
ng conversational > streaming > interactive > background.
WRFD-
020107 Load If the TrafficClass is preferably used, the priority
Reshuffl sequence is conversational > streaming > interactive >
WRFD- ing
020806 background. If the TrafficClass factors are all the same,
Overloa the ARP factor is used and the priority sequence is gold
d > silver > copper.
Control GUI Value Range: ARP, TrafficClass
Differen Unit: None
tiated
Service Actual Value Range: ARP, TrafficClass
Based Default Value: ARP
on SPI
Weight

WCDMA RAN

nd
RsvdPar BSC690 SET WRFD- Admissi Meaning:

a1 0 UCACA 020101 on Reserved Parameter1.
LGOSW Control
ITCH Disuse statement: This parameter is used temporarily in
patch versions and will be replaced with a new
parameter in later versions. The new parameter ID
reflects the parameter function. Therefore, this
parameter is not recommended for the configuration
interface.
GUI Value Range: RSVDBIT1(Reserved Switch 1),
RSVDBIT2(Reserved Switch 2), RSVDBIT3
(Reserved Switch 3), RSVDBIT4(Reserved Switch 4),
(Reserved Switch 9), RSVDBIT10(Reserved Switch
10), RSVDBIT11(Reserved Switch 11), RSVDBIT12
16)
Unit: None
Actual Value Range: RSVDBIT1, RSVDBIT2,
RSVDBIT3, RSVDBIT4, RSVDBIT5, RSVDBIT6,
RSVDBIT11, RSVDBIT12, RSVDBIT13,
RSVDBIT14, RSVDBIT15, RSVDBIT16
Default Value:
RSVDBIT1:0,RSVDBIT2:0,RSVDBIT3:0,RSVDBIT
4:0,RSVDBIT5:0,RSVDBIT6:0,RSVDBIT7:0,RSVD
BIT8:0,RSVDBIT9:0,RSVDBIT10:0,RSVDBIT11:0,
RSVDBIT12:0,RSVDBIT13:0,RSVDBIT14:0,RSVD
BIT15:0,RSVDBIT16:0

WCDMA RAN

nd
RsvdPar BSC691 SET WRFD- Admissi Meaning:

a1 0 UCACA 020101 on Reserved Parameter1.
LGOSW Control
ITCH Disuse statement: This parameter is used temporarily in
patch versions and will be replaced with a new
parameter in later versions. The new parameter ID
reflects the parameter function. Therefore, this
parameter is not recommended for the configuration
interface.
GUI Value Range: RSVDBIT1(Reserved Switch 1),
16)
Unit: None
Actual Value Range: RSVDBIT1, RSVDBIT2,
RSVDBIT11, RSVDBIT12, RSVDBIT13,
RSVDBIT14, RSVDBIT15, RSVDBIT16
Default Value:
RSVDBIT1:0,RSVDBIT2:0,RSVDBIT3:0,RSVDBIT
4:0,RSVDBIT5:0,RSVDBIT6:0,RSVDBIT7:0,RSVD
BIT8:0,RSVDBIT9:0,RSVDBIT10:0,RSVDBIT11:0,
RSVDBIT12:0,RSVDBIT13:0,RSVDBIT14:0,RSVD
BIT15:0,RSVDBIT16:0

WCDMA RAN

nd
PsBERr BSC690 SET WRFD- Queuing Meaning: Whether to activate the PS BE RRC
cPreemp 0 UQUEU 010505 and Pre- preemption algorithm for a cell. When this switch is
tVulnera EPREE Emption turned on, if the conversational services (including the
ble MPT calling and called parties) fail to be allocated resources
at the RRC connection setup phase or RAB setup phase
and fail to preempt resources of other services (such as
PS RABs), the conversational services can preempt the
resources of PS BE services having only the RRC
connections.
Unit: None
Default Value: OFF
PsBERr BSC691 SET WRFD- Queuing Meaning: Whether to activate the PS BE RRC
cPreemp 0 UQUEU 010505 and Pre- preemption algorithm for a cell. When this switch is
tVulnera EPREE Emption turned on, if the conversational services (including the
ble MPT calling and called parties) fail to be allocated resources
at the RRC connection setup phase or RAB setup phase
and fail to preempt resources of other services (such as
PS RABs), the conversational services can preempt the
resources of PS BE services having only the RRC
connections.
Unit: None
Default Value: OFF
PtUserA BSC690 SET WRFD- Platinu Meaning: Whether the non-conversational services of
bsoluteP 0 UQUEU 150204 m User platinum users (including streaming, interactive, and
riority EPREE WRFD- Prioritizi background services) are absolutely guaranteed when
MPT 150206 ng "PriorityReference" in the "SET UUSERPRIORITY"
Turbo command is set to TrafficClass. When this parameter is
IC set to True, the non-conversational services of platinum
users preempt the non-conversational services first and
then the conversational services of common users.
When this parameter is set to False, the non-
conversational services of platinum users preempt only
the non-conversational services of common users.
GUI Value Range: False, True
Unit: None
Actual Value Range: False, True
Default Value: False

WCDMA RAN

nd
PtUserA BSC691 SET WRFD- Platinu Meaning: Whether the non-conversational services of
bsoluteP 0 UQUEU 150204 m User platinum users (including streaming, interactive, and
riority EPREE WRFD- Prioritizi background services) are absolutely guaranteed when
MPT 150206 ng "PriorityReference" in the "SET UUSERPRIORITY"
Turbo command is set to TrafficClass. When this parameter is
IC set to True, the non-conversational services of platinum
users preempt the non-conversational services first and
then the conversational services of common users.
When this parameter is set to False, the non-
conversational services of platinum users preempt only
the non-conversational services of common users.
GUI Value Range: False, True
Unit: None
Actual Value Range: False, True
Default Value: False

WCDMA RAN

nd
Demarc BSC690 SET WRFD- Queuing Meaning:

Preempt 0 UQUEU 010505 and Pre- Whether the demarcation preemption function takes
Switch EPREE Emption effect. Selecting a switch enables the corresponding
MPT algorithm and clearing a switch disables the
corresponding algorithm.
1. ICR_DEMARC_PREEMPT_SF: Whether to enable
preemption based on R99 spreading code ratio when the
demarcation function is enabled. This switch is set on
the RNC. When this switch is turned on and the cell-
level demarcation license is valid, users who fail in code
resource-based admission can preempt the power
resources of those from the operator that occupies the
most excess code resources.
2. ICR_DEMARC_PREEMPT_GBP: Whether to
enable preemption based on the ratio of available HS-
DSCH required power (also called GBP, indicating
power required for the guaranteed bit rate) between
operators when the demarcation function is enabled.
This switch is set on the RNC. When this switch is
turned on and the cell-level demarcation license is valid,
users who fail in power-based admission can preempt
the power resources of those from the operator that
occupies the most excess power.
GUI Value Range: ICR_DEMARC_PREEMPT_SF
(ICR Demarcation Preemption Based on Availability
Percent), ICR_DEMARC_PREEMPT_GBP(ICR
Demarcation Preemption Based on GBP)
Unit: None
Actual Value Range: ICR_DEMARC_PREEMPT_SF,
ICR_DEMARC_PREEMPT_GBP
Default Value: ICR_DEMARC_PREEMPT_SF:
0,ICR_DEMARC_PREEMPT_GBP:0

WCDMA RAN

nd
Demarc BSC691 SET WRFD- Queuing Meaning:

Preempt 0 UQUEU 010505 and Pre- Whether the demarcation preemption function takes
Switch EPREE Emption effect. Selecting a switch enables the corresponding
MPT algorithm and clearing a switch disables the
corresponding algorithm.
1. ICR_DEMARC_PREEMPT_SF: Whether to enable
preemption based on R99 spreading code ratio when the
demarcation function is enabled. This switch is set on
the RNC. When this switch is turned on and the cell-
level demarcation license is valid, users who fail in code
resource-based admission can preempt the power
resources of those from the operator that occupies the
most excess code resources.
2. ICR_DEMARC_PREEMPT_GBP: Whether to
enable preemption based on the ratio of available HS-
DSCH required power (also called GBP, indicating
power required for the guaranteed bit rate) between
operators when the demarcation function is enabled.
This switch is set on the RNC. When this switch is
turned on and the cell-level demarcation license is valid,
users who fail in power-based admission can preempt
the power resources of those from the operator that
occupies the most excess power.
GUI Value Range: ICR_DEMARC_PREEMPT_SF
(ICR Demarcation Preemption Based on Availability
Percent), ICR_DEMARC_PREEMPT_GBP(ICR
Demarcation Preemption Based on GBP)
Unit: None
Actual Value Range: ICR_DEMARC_PREEMPT_SF,
ICR_DEMARC_PREEMPT_GBP
Default Value: ICR_DEMARC_PREEMPT_SF:
0,ICR_DEMARC_PREEMPT_GBP:0

WCDMA RAN

nd
Preempt BSC690 SET WRFD- Queuing Meaning:

EnhSwit 0 UQUEU 010505 and Pre- 1.
ch EPREE WRFD- Emption PREEMPT_ENH_NODEB_PREEMPT_CE_SWITC
MPT 171201 Crystal H: Whether to activate CE-based user preemption on the
Voice in NodeB side. If this switch is turned on, the RNC sends
Deep the NodeB a user list containing users that can be
Coverag preempted. The NodeB selects users for preemption
e based on the consumed CEs.
2.
PREEMPT_ENH_HSSCCH_PREEMPT_SF_SWITC
H: Whether channel codes can be obtained by
preempting SF resources of R99 users when HS-SCCH
channels are being established.When this switch is
turned on, the RNC preempts SF resources occupied by
R99 users to set up HS-SCCHs.When the switch is
turned off, the RNC searches for vacant SF resources to
set up HS-SCCHs in scenarios where SF resources are
occupied by R99 users. Value of this bit field will be
removed from later versions. Although the
configuration interface in this version supports delivery
of the setting of this bit field, the system does not use
this bit field. Therefore, this bit field is not
recommended.
3.
PREEMPT_ENH_CSRRC_PREEMPT_PS_SWITCH
: Whether RRC connection requests for CS services
preempt resources for PS services when cell resources
are insufficient.When this switch is turned on, CS
services preempt resources occupied by PS services to
access the cell, if RRC connection requests for CS
services fail due to insufficient cell resources.When this
switch is turned off, RRC connection requests for CS
services cannot initiate a preemption for resources
occupied by PS services.
4.
PREEMPT_ENH_CSRAB_PREEMPT_PS_SWITCH
: Whether CS access requests preempt resources for PS
services when cell resources are insufficient.When this
switch is turned on, CS services preempt resources
occupied by PS services to access the cell, if CS access
requests fail due to insufficient cell resources.When this
switch is turned off, CS access requests cannot initiate
a preemption for resources occupied by PS services.
5.
PREEMPT_ENH_CPU_HIGHLOAD_CTRL_SWIT
CH: Whether preemption is allowed when the CPU load

WCDMA RAN

nd
is high. When this switch is turned on, a user checks the

CPU load when attempting to preempt other users'
resources due to insufficient cell resources and cannot
preempt other users' resources when the CPU usage is
higher than 70%. When this switch is turned off, the user
does not consider the CPU load when preempting other
users' resources.
6.
PREEMPT_ENH_RRC_RAB_COMBINE_SWITCH:
Whether to combine radio resources of UEs that have
RRC connections and UEs that are allocated RABs
when the preempting UE is allowed to preempt radio
resources of multiple UEs. If this switch is turned on,
the RNC combines radio resources of these two types
of UEs when preemption is required due to insufficient
radio resources. If this switch is turned off, the
preempting UE can preempt radio resources of only UEs
that have RRC connections or UEs that have been
allocated RABs.
7.
PREEMPT_ENH_PT_USER_PREEMPT_ENH_SWI
TCH: Whether to support the preemption enhancement
function for platinum users. When this switch is set to
on, platinum users can preempt resources of other users
if cell admission fails during the DRD, channel fallback,
or rate re-negotiation during admission control
procedure. When this switch is set to on, platinum users
perform the same actions as common users. That is,
DRD, channel fallback, rate re-negotiation during
admission control, and preemption are performed in
sequence.
8.
PREEMPT_ENH_DRNC_CS_RAB_PREEMPT_SW
ITCH: Whether to trigger the preemption function
during a CS RAB setup under the DRNC. When this
switch is set to on, preemption is triggered during a CS
RAB setup under the DRNC. When this switch is set to
off, preemption is not triggered during a CS RAB setup
under the DRNC.
9.PREEMPT_ENH_CS_PREEMPT_WHEN_OLC_S
WITCH: Whether users processing CS and push to talk
(PTT) services can preempt resources when a cell is in
the overload control (OLC) state. When this switch is
set to on for a cell in the OLC state, users processing CS
and PTT services can preempt resources if the CS
service or PTT service admission fails. When this

WCDMA RAN

nd
switch is set to off for a cell in the OLC state, only users
processing emergency calls and platinum users can
preempt resources. Users processing common CS
services and PTT services cannot preempt resources.
10.
PREEMPT_ENH_MULTIRAB_CS_INCR_PMT_S
WITCH: Whether to optimize the PS service bearing
policy and CS resource preemption when a UE that has
already had PS RABs attempts to set up a CS RAB but
the CS RAB setup fails and resource preemption is
triggered.When this switch is set to on, if a UE that has
already had PS RABs in the CELL_DCH state attempts
to set up a CS RAB but the CS RAB setup fails and
resource preemption is triggered, PS services can still
be carried on channels using more advanced
technologies and the UE preempts only the incremental
resources required for the CS RAB setup. When this
switch is set to off, PS services must be switched back
to R99 channels when resource preemption is triggered
and the UE preempts the resources required for
processing all the ongoing services.
11.PREEMPT_ENH_MULTIRAB_PRIO_OPT_SWI
TCH: Whether to prevent PS RABs from triggering
preemption if a UE that has already had a CS RAB
attempts to set up PS RABs when the forcible CS
preemption policy is used in combined service
scenarios.When the forcible CS preemption policy
(controlled by the
under the "PreemptEnhSwitch" parameter) is used and
this switch is set to on, if a UE that has already had a CS
RAB attempts to set up PS RABs, preemption cannot
be triggered for PS services if PS RAB admission fails.
When the forcible CS preemption policy is used and this
switch is set to off, preemption can be triggered for SP
services if PS RAB admission fails.
12. PREEMPT_ENH_PS_IU_CS_PMTED_SWITCH:
Whether resources of a PS user who has sent requests
of setting up CS connections but the CS RABs have not
been established can be preempted. When this switch is
turned on, resources of the PS user cannot be preempted
before the CS RABs are established. When this switch
is turned off, resources of the PS user can be preempted
before the CS RABs are established.
13.
PREEMPT_ENH_CS_PREEMPT_CELL_EXT_SWI

WCDMA RAN

nd
TCH: Whether CS services can perform preemption

attempts in another inter-RAT DRD neighboring cell if
their resource preemption fails in the current cell. When
this switch is turned on, CS services can perform
preemption attempts in another inter-RAT DRD
neighboring cell if their resource preemption fails in the
current cell. When this switch is turned off, CS services
can perform preemption attempts only in the current
cell.
14. PREEMPT_ENH_WPS_USER_SWITCH:
Whether UEs using the wireless priority service (WPS)
are allowed to initiate preemption during a soft
handover. When this switch is turned on, WPS UEs are
allowed to initiate preemption during a soft handover.
When this switch is turned off, WPS UEs are not
Disuse Statement:Value of bit field
"PREEMPT_ENH_HSSCCH_PREEMPT_SF_SWIT
CH" in the parameter PreemptEnhSwitch will be
recommended.
GUI Value Range:
PREEMPT_ENH_NODEB_PREEMPT_CE_SWITC
H,
H,
,
,
CH,
PREEMPT_ENH_RRC_RAB_COMBINE_SWITCH,
TCH,
ITCH,
PREEMPT_ENH_CS_PREEMPT_WHEN_OLC_SW
ITCH,
WITCH,
PREEMPT_ENH_MULTIRAB_PRIO_OPT_SWITC
H, PREEMPT_ENH_PS_IU_CS_PMTED_SWITCH,

WCDMA RAN

nd
TCH, PREEMPT_ENH_WPS_USER_SWITCH
Unit: None
Actual Value Range:
H,
H,
,
,
CH,
TCH,
ITCH,
ITCH,
WITCH,
Default Value:
H:
0,PREEMPT_ENH_HSSCCH_PREEMPT_SF_SWIT
CH:
1,PREEMPT_ENH_CSRRC_PREEMPT_PS_SWITC
H:
0,PREEMPT_ENH_CSRAB_PREEMPT_PS_SWITC
H:
0,PREEMPT_ENH_CPU_HIGHLOAD_CTRL_SWI
TCH:
1,PREEMPT_ENH_RRC_RAB_COMBINE_SWITC
H:
1,PREEMPT_ENH_PT_USER_PREEMPT_ENH_S
WITCH:
0,PREEMPT_ENH_DRNC_CS_RAB_PREEMPT_S
WITCH:
0,PREEMPT_ENH_CS_PREEMPT_WHEN_OLC_S
WITCH:

WCDMA RAN

nd
0,PREEMPT_ENH_MULTIRAB_CS_INCR_PMT_S
WITCH:
0,PREEMPT_ENH_MULTIRAB_PRIO_OPT_SWIT
CH:
0,PREEMPT_ENH_PS_IU_CS_PMTED_SWITCH:
0,PREEMPT_ENH_CS_PREEMPT_CELL_EXT_S
WITCH:0,PREEMPT_ENH_WPS_USER_SWITCH:
0

WCDMA RAN

nd
Preempt BSC691 SET WRFD- Queuing Meaning:

EnhSwit 0 UQUEU 010505 and Pre- 1.
ch EPREE WRFD- Emption PREEMPT_ENH_NODEB_PREEMPT_CE_SWITC
MPT 171201 Crystal H: Whether to activate CE-based user preemption on the
Voice in NodeB side. If this switch is turned on, the RNC sends
Deep the NodeB a user list containing users that can be
Coverag preempted. The NodeB selects users for preemption
e based on the consumed CEs.
2.
H: Whether channel codes can be obtained by
preempting SF resources of R99 users when HS-SCCH
channels are being established.When this switch is
turned on, the RNC preempts SF resources occupied by
R99 users to set up HS-SCCHs.When the switch is
turned off, the RNC searches for vacant SF resources to
set up HS-SCCHs in scenarios where SF resources are
occupied by R99 users. Value of this bit field will be
recommended.
3.
: Whether RRC connection requests for CS services
preempt resources for PS services when cell resources
are insufficient.When this switch is turned on, CS
services preempt resources occupied by PS services to
access the cell, if RRC connection requests for CS
services fail due to insufficient cell resources.When this
switch is turned off, RRC connection requests for CS
services cannot initiate a preemption for resources
occupied by PS services.
4.
: Whether CS access requests preempt resources for PS
services when cell resources are insufficient.When this
switch is turned on, CS services preempt resources
occupied by PS services to access the cell, if CS access
requests fail due to insufficient cell resources.When this
switch is turned off, CS access requests cannot initiate
a preemption for resources occupied by PS services.
5.
CH: Whether preemption is allowed when the CPU load

WCDMA RAN

nd
is high. When this switch is turned on, a user checks the

CPU load when attempting to preempt other users'
resources due to insufficient cell resources and cannot
preempt other users' resources when the CPU usage is
higher than 70%. When this switch is turned off, the user
does not consider the CPU load when preempting other
users' resources.
6.
PREEMPT_ENH_RRC_RAB_COMBINE_SWITCH:
Whether to combine radio resources of UEs that have
RRC connections and UEs that are allocated RABs
when the preempting UE is allowed to preempt radio
resources of multiple UEs. If this switch is turned on,
the RNC combines radio resources of these two types
of UEs when preemption is required due to insufficient
radio resources. If this switch is turned off, the
preempting UE can preempt radio resources of only UEs
that have RRC connections or UEs that have been
allocated RABs.
7.
TCH: Whether to support the preemption enhancement
function for platinum users. When this switch is set to
on, platinum users can preempt resources of other users
if cell admission fails during the DRD, channel fallback,
or rate re-negotiation during admission control
procedure. When this switch is set to on, platinum users
perform the same actions as common users. That is,
DRD, channel fallback, rate re-negotiation during
admission control, and preemption are performed in
sequence.
8.
ITCH: Whether to trigger the preemption function
during a CS RAB setup under the DRNC. When this
switch is set to on, preemption is triggered during a CS
RAB setup under the DRNC. When this switch is set to
off, preemption is not triggered during a CS RAB setup
under the DRNC.
9.PREEMPT_ENH_CS_PREEMPT_WHEN_OLC_S
WITCH: Whether users processing CS and push to talk
(PTT) services can preempt resources when a cell is in
the overload control (OLC) state. When this switch is
set to on for a cell in the OLC state, users processing CS
and PTT services can preempt resources if the CS
service or PTT service admission fails. When this

WCDMA RAN

nd
switch is set to off for a cell in the OLC state, only users
processing emergency calls and platinum users can
preempt resources. Users processing common CS
services and PTT services cannot preempt resources.
10.
WITCH: Whether to optimize the PS service bearing
policy and CS resource preemption when a UE that has
already had PS RABs attempts to set up a CS RAB but
the CS RAB setup fails and resource preemption is
triggered.When this switch is set to on, if a UE that has
already had PS RABs in the CELL_DCH state attempts
to set up a CS RAB but the CS RAB setup fails and
resource preemption is triggered, PS services can still
be carried on channels using more advanced
technologies and the UE preempts only the incremental
resources required for the CS RAB setup. When this
switch is set to off, PS services must be switched back
to R99 channels when resource preemption is triggered
and the UE preempts the resources required for
processing all the ongoing services.
11.PREEMPT_ENH_MULTIRAB_PRIO_OPT_SWI
TCH: Whether to prevent PS RABs from triggering
preemption if a UE that has already had a CS RAB
attempts to set up PS RABs when the forcible CS
preemption policy is used in combined service
scenarios.When the forcible CS preemption policy
(controlled by the
under the "PreemptEnhSwitch" parameter) is used and
this switch is set to on, if a UE that has already had a CS
RAB attempts to set up PS RABs, preemption cannot
be triggered for PS services if PS RAB admission fails.
When the forcible CS preemption policy is used and this
switch is set to off, preemption can be triggered for SP
services if PS RAB admission fails.
12. PREEMPT_ENH_PS_IU_CS_PMTED_SWITCH:
Whether resources of a PS user who has sent requests
of setting up CS connections but the CS RABs have not
been established can be preempted. When this switch is
turned on, resources of the PS user cannot be preempted
before the CS RABs are established. When this switch
is turned off, resources of the PS user can be preempted
before the CS RABs are established.
13.

WCDMA RAN

nd
TCH: Whether CS services can perform preemption

attempts in another inter-RAT DRD neighboring cell if
their resource preemption fails in the current cell. When
this switch is turned on, CS services can perform
preemption attempts in another inter-RAT DRD
neighboring cell if their resource preemption fails in the
current cell. When this switch is turned off, CS services
can perform preemption attempts only in the current
cell.
14. PREEMPT_ENH_WPS_USER_SWITCH:
Whether UEs using the wireless priority service (WPS)
are allowed to initiate preemption during a soft
handover. When this switch is turned on, WPS UEs are
When this switch is turned off, WPS UEs are not
Disuse Statement:Value of bit field
"PREEMPT_ENH_HSSCCH_PREEMPT_SF_SWIT
CH" in the parameter PreemptEnhSwitch will be
recommended.
GUI Value Range:
H,
H,
,
,
CH,
TCH,
ITCH,
ITCH,
WITCH,

WCDMA RAN

nd
Unit: None
Actual Value Range:
H,
H,
,
,
CH,
TCH,
ITCH,
ITCH,
WITCH,
Default Value:
H:
0,PREEMPT_ENH_HSSCCH_PREEMPT_SF_SWIT
CH:
1,PREEMPT_ENH_CSRRC_PREEMPT_PS_SWITC
H:
0,PREEMPT_ENH_CSRAB_PREEMPT_PS_SWITC
H:
0,PREEMPT_ENH_CPU_HIGHLOAD_CTRL_SWI
TCH:
1,PREEMPT_ENH_RRC_RAB_COMBINE_SWITC
H:
1,PREEMPT_ENH_PT_USER_PREEMPT_ENH_S
WITCH:
0,PREEMPT_ENH_DRNC_CS_RAB_PREEMPT_S
WITCH:
0,PREEMPT_ENH_CS_PREEMPT_WHEN_OLC_S
WITCH:

WCDMA RAN

nd
0,PREEMPT_ENH_MULTIRAB_CS_INCR_PMT_S
WITCH:
0,PREEMPT_ENH_MULTIRAB_PRIO_OPT_SWIT
CH:
0,PREEMPT_ENH_PS_IU_CS_PMTED_SWITCH:
0,PREEMPT_ENH_CS_PREEMPT_CELL_EXT_S
WITCH:0,PREEMPT_ENH_WPS_USER_SWITCH:
0

WCDMA RAN

nd
MbmsPr BSC690 SET WRFD- MBMS Meaning: Indicates whether the MBMS supports
eemptAl 0 UQUEU 010660 Phase 2 resource preemption. When the switch is enabled, the
goSwitc EPREE WRFD- MBMS RNC allows the preempting MBMS to preempt
h MPT 010661 over Iur resources from users or services with the preempted
attributes and lower priority in the case of cell resource
WRFD- Dynami insufficiency; the RNC also attempts to add the MBMS
010662 c Power with the preempted attributes to a candidate set. In this
WRFD- Estimati case, the cell resources assigned to the MBMS can be
010663 on for preempted by users or services with higher priority.
MTCH When the switch is disabled, the MBMS cannot preempt
WRFD-
010665 MSCH other users or services and cannot be preempted by other
Scheduli users or services.
WRFD- ng GUI Value Range: OFF, ON
010505
MBMS Unit: None
WRFD- Channel
0106600 Actual Value Range: OFF, ON
Audienc
4 e Rating Default Value: OFF
WRFD- Statistic
0106160 s
6 Queuing
WRFD- and Pre-
0106600 Emption
2 Inter-
WRFD- Frequen
0106600 cy
3 Neighbo
WRFD- ring Cell
0106600 Selectio
1 n for
MBMS
WRFD- PTP
0106160 Users
1
Streami
WRFD- ng
0106160 Service
3 on
WRFD- MBMS
0106160 MBMS
2 P2P over
WRFD- HSDPA
0106160 MBMS
5 Admissi
WRFD- on
0106160 Enhance
4 ment

WCDMA RAN

nd
WRFD- MBMS
010616 Enhance
WRFD- d
0106160 Broadca
8 st Mode
WRFD- MBMS
010626 Broadca
st Mode
WRFD-
010627 MBMS
Load
Control
MBMS
Admissi
on
Control
MBMS
Transpo
rt
Resourc
e
Manage
ment
MBMS
Soft/
Selectiv
e
Combini
ng
MBMS
Introduc
tion
Package
16/32/64
/
128Kbp
s
Channel
Rate on
MBMS
MBMS
FLC
(Freque
ncy
Layer
Converg

WCDMA RAN

nd
ence)/
FLD
(Freque
ncy
Layer
Dispersi
on)
FACH
Transmi
ssion
Sharing
for
MBMS

WCDMA RAN

nd
MbmsPr BSC691 SET WRFD- MBMS Meaning: Indicates whether the MBMS supports
eemptAl 0 UQUEU 010660 Phase 2 resource preemption. When the switch is enabled, the
goSwitc EPREE WRFD- MBMS RNC allows the preempting MBMS to preempt
h MPT 010661 over Iur resources from users or services with the preempted
attributes and lower priority in the case of cell resource
WRFD- Dynami insufficiency; the RNC also attempts to add the MBMS
010662 c Power with the preempted attributes to a candidate set. In this
WRFD- Estimati case, the cell resources assigned to the MBMS will be
010663 on for preempted by users or services with higher priority.
MTCH When the switch is disabled, the MBMS cannot preempt
WRFD-
010665 MSCH other users or services and cannot be preempted by other
Scheduli users or services.
WRFD- ng GUI Value Range: OFF, ON
010505
MBMS Unit: None
WRFD- Channel
0106600 Actual Value Range: OFF, ON
Audienc
4 e Rating Default Value: OFF
WRFD- Statistic
0106160 s
6 Queuing
WRFD- and Pre-
0106600 Emption
2 Inter-
WRFD- Frequen
0106600 cy
3 Neighbo
WRFD- ring Cell
0106600 Selectio
1 n for
MBMS
WRFD- PTP
0106160 Users
1
Streami
WRFD- ng
0106160 Service
3 on
WRFD- MBMS
0106160 MBMS
2 P2P over
WRFD- HSDPA
0106160 MBMS
5 Admissi
WRFD- on
0106160 Enhance
4 ment

WCDMA RAN

nd
WRFD- MBMS
010616 Enhance
WRFD- d
0106160 Broadca
8 st Mode
WRFD- MBMS
010626 Broadca
st Mode
WRFD-
010627 MBMS
Load
Control
MBMS
Admissi
on
Control
MBMS
Transpo
rt
Resourc
e
Manage
ment
MBMS
Soft/
Selectiv
e
Combini
ng
MBMS
Introduc
tion
Package
16/32/64
/
128Kbp
s
Channel
Rate on
MBMS
MBMS
FLC
(Freque
ncy
Layer
Converg

WCDMA RAN

nd
ence)/
FLD
(Freque
ncy
Layer
Dispersi
on)
FACH
Transmi
ssion
Sharing
for
MBMS
QueueA BSC690 SET WRFD- Queuing Meaning: Whether queuing is supported. When this
lgoSwitc 0 UQUEU 010505 and Pre- switch is turned on and a queuing-capable PS user
h EPREE Emption initiates a call, the RNC tries to enable this user to join
MPT the queue to increase the access success rate if cell
resources are insufficient and preemption fails. When
this switch is turned off, queuing is not supported if cell
resources are insufficient.
Unit: None
Default Value: OFF
QueueA BSC691 SET WRFD- Queuing Meaning: Whether queuing is supported. When this
lgoSwitc 0 UQUEU 010505 and Pre- switch is turned on and a queuing-capable PS user
h EPREE Emption initiates a call, the RNC tries to enable this user to join
MPT the queue to increase the access success rate if cell
resources are insufficient and preemption fails. When
this switch is turned off, queuing is not supported if cell
resources are insufficient.
Unit: None
Default Value: OFF

WCDMA RAN

nd
RlMaxD BSC690 ADD WRFD- Voice Meaning: Maximum transmit power of a downlink
lPwr 0 UCELL 140205 Service radio link. For details about this parameter, see 3GPP
RLPWR WRFD- Experie TS 25.433.
MOD 020501 nce GUI Value Range: -350~150
UCELL Improve
ment for Unit: 0.1dB
RLPWR
Weak Actual Value Range: -35~15
Receptio Default Value: None
n Ues
Open
Loop
Power
Control
RlMaxD BSC691 ADD WRFD- Voice Meaning: Maximum transmit power of a downlink
lPwr 0 UCELL 140205 Service radio link. For details about this parameter, see 3GPP
RLPWR WRFD- Experie TS 25.433.
MOD 020501 nce GUI Value Range: -350~150
UCELL Improve
ment for Unit: 0.1dB
RLPWR
Weak Actual Value Range: -35~15
Receptio Default Value: None
n Ues
Open
Loop
Power
Control
SpecUse BSC690 ADD WRFD- Voice Meaning: Maximum downlink power of the link
rRlMax 0 UCELL 140205 Service carrying 12.2kbit/s AMR services for special UEs. The
DlPwr RLPWR Experie maximum downlink power of this link is configured
MOD nce separately to improve the voice quality of the special
UCELL Improve UEs. A special UE can be added by running the "ADD
RLPWR ment for UIMEITAC" command.
Weak GUI Value Range: -350~150
Receptio
n Ues Unit: 0.1dB
Actual Value Range: -35~15
Default Value: 30

WCDMA RAN

nd
SpecUse BSC691 ADD WRFD- Voice Meaning: Maximum downlink power of the link
rRlMax 0 UCELL 140205 Service carrying 12.2kbit/s AMR services for special UEs. The
DlPwr RLPWR Experie maximum downlink power of this link is configured
MOD nce separately to improve the voice quality of the special
UCELL Improve UEs. A special UE can be added by running the "ADD
RLPWR ment for UIMEITAC" command.
Weak GUI Value Range: -350~150
Receptio
n Ues Unit: 0.1dB
Actual Value Range: -35~15
Default Value: 30
IubCPPr BSC690 ADD WRFD- 3GPP Meaning: Whether to include Iub control-plane
ivateInte 0 UNRNC 010101 R9 proprietary IE in Iur interface messages.
rfaceSwi MOD Specific GUI Value Range: OFF, ON
tch UNRNC ations
Unit: None
Default Value: OFF
IubCPPr BSC691 ADD WRFD- 3GPP Meaning: Whether to include Iub control-plane
ivateInte 0 UNRNC 010101 R9 proprietary IE in Iur interface messages.
rfaceSwi MOD Specific GUI Value Range: OFF, ON
tch UNRNC ations
Unit: None
Default Value: OFF

WCDMA RAN

nd
BLERQ BSC690 ADD WRFD- Outer Meaning:

uality 0 UTYPR 020503 Loop Actual value of the target BLER of DCH based on the
ABOLP Power GUI value of this parameter. The setting of the
C Control "SirAdjustStep" parameter is associated with this
MOD parameter. Assume that this parameter is changed from
UTYPR BLERQualityTarget1 to BLERQualityTarget2 and
ABOLP "SirAdjustStep" is changed from SirAdjustStep1 to
C SirAdjustStep2. Then, these values should fulfill the
following condition: (1 - BLERQualityTarget1) x
SirAdjustStep1/BLERQualityTarget1 = (1 -
BLERQualityTarget2) x SirAdjustStep2/
BLERQualityTarget2. For details about this parameter,
see 3GPP TS 25.331.
This parameter is an advanced parameter. To modify
this parameter, contact Huawei Customer Service
Center for technical support.
GUI Value Range: -63~0
Unit: None
Actual Value Range: 0.0000005~1(Actual Value = 10^
(GUI Value/10))
Default Value: None
BLERQ BSC691 ADD WRFD- Outer Meaning:

uality 0 UTYPR 020503 Loop Actual value of the target BLER of DCH based on the
ABOLP Power GUI value of this parameter. The setting of the
C Control "SirAdjustStep" parameter is associated with this
MOD parameter. Assume that this parameter is changed from
UTYPR BLERQualityTarget1 to BLERQualityTarget2 and
ABOLP "SirAdjustStep" is changed from SirAdjustStep1 to
C SirAdjustStep2. Then, these values should fulfill the
following condition: (1 - BLERQualityTarget1) x
SirAdjustStep1/BLERQualityTarget1 = (1 -
BLERQualityTarget2) x SirAdjustStep2/
BLERQualityTarget2. For details about this parameter,
see 3GPP TS 25.331.
This parameter is an advanced parameter. To modify
this parameter, contact Huawei Customer Service
Center for technical support.
GUI Value Range: -63~0
Unit: None
Actual Value Range: 0.0000005~1(Actual Value = 10^
(GUI Value/10))
Default Value: None

WCDMA RAN

nd
PsRlMa BSC690 SET WRFD- Platinu Meaning: Maximum value of downlink power decrease
xDlPwr 0 UOLPC 150204 m User for non-platinum PS BE users in the Platinum User
DeltaFor Prioritizi Prioritizing scenario. If cells of platinum CS users are
Pt ng congested, the RNC subtracts the value of this
parameter from the "RlMaxDlPwr" parameter in the
"ADD UCELLRLPWR" command to obtain the final
maximum downlink transmit power for non-platinum
PS BE users. This limits the downlink transmit power
of non-platinum PS BE users, thereby improving the
experience of platinum CS users. This parameter takes
effect for both HSPA and R99 users. This parameter is
an advanced parameter. Therefore, modify the setting
of this parameter under the instruction of Huawei
technical support.
Unit: 0.1dB
Default Value: 0
PsRlMa BSC691 SET WRFD- Platinu Meaning: Maximum value of downlink power decrease
xDlPwr 0 UOLPC 150204 m User for non-platinum PS BE users in the Platinum User
DeltaFor Prioritizi Prioritizing scenario. If cells of platinum CS users are
Pt ng congested, the RNC subtracts the value of this
parameter from the "RlMaxDlPwr" parameter in the
"ADD UCELLRLPWR" command to obtain the final
maximum downlink transmit power for non-platinum
PS BE users. This limits the downlink transmit power
of non-platinum PS BE users, thereby improving the
experience of platinum CS users. This parameter takes
effect for both HSPA and R99 users. This parameter is
an advanced parameter. Therefore, modify the setting
of this parameter under the instruction of Huawei
technical support.
Unit: 0.1dB
Default Value: 0

WCDMA RAN

nd
PWRM BTS390 SET WRFD- HSDPA Meaning: Indicates the power margin reserved for R99
GN 0, ULOCE 0106100 Power channels. It specifies the power percentage relative to
BTS390 LLMAC 4 Control the maximum cell transmit power.
0 HSPAR GUI Value Range: 0~100
WCDM A
A Unit: %
LST
ULOCE Actual Value Range: 0~100
LLMAC Default Value: 5
HSPAR
A
PWRM BTS390 SET WRFD- HSDPA Meaning: Indicates an adjustment to the reserved power
GNDEL 0, ULOCE 0106100 Power margin for R99 channels when the Platinum User
TAFOR BTS390 LLMAC 4 Control Prioritizing feature has been enabled. The reserved
PT 0 HSPAR WRFD- Platinu power margin for R99 channels of a cell serving
WCDM A 150204 m User platinum users in the CS domain equals the smaller
A LST Prioritizi value between 100 and the sum of PWRMGN and
ULOCE ng PWRMGNDELTAFORPT. The parameter value is a
LLMAC percentage relative to the maximum cell transmit power.
HSPAR GUI Value Range: 0~100
A Unit: %
Default Value: 10

WCDMA RAN

nd
CacSwit BSC690 SET WRFD- Admissi Meaning:

ch 0 UCACA 020101 on 1. NODEB_CREDIT_CAC_SWITCH(NodeB Credit
LGOSW WRFD- Control CAC Switch): Whether NodeB credit CAC is allowed.
ITCH 150204 Platinu When this switch is turned on, the system performs
m User CAC based on the usage state of NodeB credit. When
Prioritizi the NodeB's credit is not enough, the system rejects new
ng access requests.
2. FACH_60_USER_SWITCH (Switch for allowing a
Maximum of 60 UEs on the FACH): Maximum number
of UEs that use FACHs to transmit service data.When
this switch is turned on, a maximum of 60 UEs can be
carried on the FACH.If some UEs are processing
signaling messages, more than 60 UEs can be carried
on the FACH. When this switch is turned off, a
maximum of 30 UEs can be carried on the FACH. If
some UEs are processing signaling messages, more than
30 UEs can be carried on the FACH.
3. PT_CSUSER_CAC_ENH_SWITCH: Whether to
enable the admission control enhancement function in
the Platinum User Prioritizing scenario. When this
switch is set to on, if the uplink and downlink power
admission algorithms (controlled by "NBMUlCacAlgo-
SelSwitch" and "NBMDlCacAlgoSelSwitch",
respectively) are disabled for cells of platinum CS users,
the uplink admission algorithm 2 and downlink
admission algorithm 1 automatically take effect and the
downlink power admission threshold for PS services is
specified by the "DlOtherThdForPt" parameter. In
addition, if the RB Parking license is activated, the RB
Parking function automatically takes effect no matter
whether the RB Parking function switch is enabled. This
enhances admission control, thereby ensuring the
experience of platinum CS users. When this switch is
set to off, the admission control enhancement function
does not take effect and the RNC does not perform
special processing on cells of platinum CS users.
GUI Value Range: NODEB_CREDIT_CAC_SWITCH
(NodeB Credit CAC Switch),
FACH_60_USER_SWITCH(FACH Allowed Max 60
Users Switch), PT_CSUSER_CAC_ENH_SWITCH
(Platinum CS User Admission Enhancement Switch)
Unit: None
Actual Value Range:
NODEB_CREDIT_CAC_SWITCH,

WCDMA RAN

nd
FACH_60_USER_SWITCH,
PT_CSUSER_CAC_ENH_SWITCH
Default Value: NODEB_CREDIT_CAC_SWITCH:1,
FACH_60_USER_SWITCH:1,
PT_CSUSER_CAC_ENH_SWITCH:0

WCDMA RAN

nd
CacSwit BSC691 SET WRFD- Admissi Meaning:

ch 0 UCACA 020101 on 1. NODEB_CREDIT_CAC_SWITCH(NodeB Credit
LGOSW WRFD- Control CAC Switch): Whether NodeB credit CAC is allowed.
ITCH 150204 Platinu When this switch is turned on, the system performs
m User CAC based on the usage state of NodeB credit. When
Prioritizi the NodeB's credit is not enough, the system rejects new
ng access requests.
2. FACH_60_USER_SWITCH (Switch for allowing a
Maximum of 60 UEs on the FACH): Maximum number
of UEs that use FACHs to transmit service data.When
this switch is turned on, a maximum of 60 UEs can be
carried on the FACH.If some UEs are processing
signaling messages, more than 60 UEs can be carried
on the FACH. When this switch is turned off, a
maximum of 30 UEs can be carried on the FACH. If
some UEs are processing signaling messages, more than
30 UEs can be carried on the FACH.
3. PT_CSUSER_CAC_ENH_SWITCH: Whether to
enable the admission control enhancement function in
the Platinum User Prioritizing scenario. When this
switch is set to on, if the uplink and downlink power
admission algorithms (controlled by "NBMUlCacAlgo-
SelSwitch" and "NBMDlCacAlgoSelSwitch",
respectively) are disabled for cells of platinum CS users,
the uplink admission algorithm 2 and downlink
admission algorithm 1 automatically take effect and the
downlink power admission threshold for PS services is
specified by the "DlOtherThdForPt" parameter. In
addition, if the RB Parking license is activated, the RB
Parking function automatically takes effect no matter
whether the RB Parking function switch is enabled. This
enhances admission control, thereby ensuring the
experience of platinum CS users. When this switch is
set to off, the admission control enhancement function
does not take effect and the RNC does not perform
special processing on cells of platinum CS users.
GUI Value Range: NODEB_CREDIT_CAC_SWITCH
(NodeB Credit CAC Switch),
FACH_60_USER_SWITCH(FACH Allowed Max 60
Users Switch), PT_CSUSER_CAC_ENH_SWITCH
(Platinum CS User Admission Enhancement Switch)
Unit: None
Actual Value Range:
NODEB_CREDIT_CAC_SWITCH,

WCDMA RAN

nd
FACH_60_USER_SWITCH,
PT_CSUSER_CAC_ENH_SWITCH
Default Value: NODEB_CREDIT_CAC_SWITCH:1,
FACH_60_USER_SWITCH:1,
PT_CSUSER_CAC_ENH_SWITCH:0

WCDMA RAN

nd
NBMUl BSC690 ADD WRFD- Code Meaning:

CacAlgo 0 UCELL 020108 Resourc Selection of uplink power admission control algorithms
SelSwitc ALGOS WRFD- e
h WITCH Manage ALGORITHM_OFF: Uplink power admission control
010506 algorithm disabled.
MOD ment
WRFD- ALGORITHM_FIRST: Uplink admission control
UCELL 021104 RAB
ALGOS Quality algorithm based on the power load and the predicted
WITCH WRFD- of power load increment caused by admitting new UEs.
020102 Service ALGORITHM_SECOND: Uplink admission control
WRFD- Renegot algorithm based on the number of equivalent UEs and
010507 iation the predicted increment in the number of equivalent UEs
WRFD- over Iu to be admitted.
020101 Interface ALGORITHM_THIRD: Uplink admission control
WRFD- Emerge algorithm based on the power load in a cell.
020106 ncy Call ALGORITHM_FOURTH: Uplink admission control
WRFD- Load algorithm based on the actual service load and the
020107 Measure predicted service load increment.
ment GUI Value Range: ALGORITHM_OFF,
WRFD-
020104 Rate ALGORITHM_FIRST, ALGORITHM_SECOND,
Negotiat ALGORITHM_THIRD, ALGORITHM_FOURTH
WRFD-
ion at Unit: None
020105
Admissi
WRFD- Actual Value Range: ALGORITHM_OFF,
on
020120 ALGORITHM_FIRST, ALGORITHM_SECOND,
Control
ALGORITHM_THIRD, ALGORITHM_FOURTH
WRFD- Admissi
010505 Default Value: None
on
WRFD- Control
0204000 Load
3 Reshuffl
WRFD- ing
020401 Overloa
d
Control
Intra
Frequen
cy Load
Balance
Potential
User
Control
Service
Steering
and
Load

WCDMA RAN

nd
Sharing
in RRC
Connect
ion
Setup
Queuing
and Pre-
Emption
Inter
System
Redirect
Inter-
RAT
Redirect
ion
Based
on
Distance

WCDMA RAN

nd
NBMUl BSC691 ADD WRFD- Code Meaning:

CacAlgo 0 UCELL 020108 Resourc Selection of uplink power admission control algorithms
SelSwitc ALGOS WRFD- e
h WITCH Manage ALGORITHM_OFF: Uplink power admission control
010506 algorithm disabled.
MOD ment
WRFD- ALGORITHM_FIRST: Uplink admission control
UCELL 021104 RAB
ALGOS Quality algorithm based on the power load and the predicted
WITCH WRFD- of power load increment caused by admitting new UEs.
020102 Service ALGORITHM_SECOND: Uplink admission control
WRFD- Renegot algorithm based on the number of equivalent UEs and
010507 iation the predicted increment in the number of equivalent UEs
WRFD- over Iu to be admitted.
020101 Interface ALGORITHM_THIRD: Uplink admission control
WRFD- Emerge algorithm based on the power load in a cell.
020106 ncy Call ALGORITHM_FOURTH: Uplink admission control
WRFD- Load algorithm based on the actual service load and the
020107 Measure predicted service load increment.
ment GUI Value Range: ALGORITHM_OFF,
WRFD-
020104 Rate ALGORITHM_FIRST, ALGORITHM_SECOND,
Negotiat ALGORITHM_THIRD, ALGORITHM_FOURTH
WRFD-
ion at Unit: None
020105
Admissi
WRFD- Actual Value Range: ALGORITHM_OFF,
on
020120 ALGORITHM_FIRST, ALGORITHM_SECOND,
Control
ALGORITHM_THIRD, ALGORITHM_FOURTH
WRFD- Admissi
on
WRFD- Control
0204000 Load
3 Reshuffl
WRFD- ing
020401 Overloa
d
Control
Intra
Frequen
cy Load
Balance
Potential
User
Control
Service
Steering
and
Load

WCDMA RAN

nd
Sharing
in RRC
Connect
ion
Setup
Queuing
and Pre-
Emption
Inter
System
Redirect
Inter-
RAT
Redirect
ion
Based
on
Distance

WCDMA RAN

nd
NBMDl BSC690 ADD WRFD- MBMS Meaning:

CacAlgo 0 UCELL 010660 Phase 2 Selection of downlink admission control algorithm
SelSwitc ALGOS WRFD- MBMS
h WITCH ALGORITHM_OFF: Downlink power admission
010661 over Iur control algorithm disabled
MOD Dynami
WRFD- ALGORITHM_FIRST: Downlink admission control
UCELL c Power
010662 algorithm based on the power load and the predicted
ALGOS Estimati
WITCH WRFD- power load increment caused by admitting new UEs.
on for
010627 MTCH ALGORITHM_SECOND: Downlink admission
WRFD- control algorithm based on the number of downlink
FACH
010665 equivalent UEs and the predicted increment in the
Transmi
number of downlink equivalent UEs to be admitted.
WRFD- ssion
0106600 Sharing ALGORITHM_THIRD: Downlink admission control
4 for algorithm based on the power load in a cell.
MBMS GUI Value Range: ALGORITHM_OFF,
WRFD-
MBMS ALGORITHM_FIRST, ALGORITHM_SECOND,
020101
Channel ALGORITHM_THIRD
WRFD- Audienc Unit: None
0106600 e Rating
2 Actual Value Range: ALGORITHM_OFF,
Statistic
ALGORITHM_FIRST, ALGORITHM_SECOND,
WRFD- s
ALGORITHM_THIRD
0106600 Inter-
Frequen
WRFD- cy
010663 Neighbo
ring Cell
WRFD- Selectio
0106160 n for
6 MBMS
WRFD- PTP
0106160 Users
1 Admissi
WRFD- on
0106160 Control
3 MBMS
WRFD- P2P over
0106160 HSDPA
2 MBMS
Admissi
WRFD-
on
0106160
Enhance
5
ment
WRFD-
MSCH
0106160
Scheduli
4
ng

WCDMA RAN

nd
WRFD- Streami
010616 ng
WRFD- Service
0106160 on
8 MBMS
WRFD- MBMS
010626 Broadca
st Mode
WRFD-
0106600 MBMS
1 Load
Control
MBMS
Admissi
on
Control
MBMS
Transpo
rt
Resourc
e
Manage
ment
MBMS
Soft/
Selectiv
e
Combini
ng
MBMS
Introduc
tion
Package
16/32/64
/
128Kbp
s
Channel
Rate on
MBMS
MBMS
FLC
(Freque
ncy
Layer
Converg

WCDMA RAN

nd
ence)/
FLD
(Freque
ncy
Layer
Dispersi
on)
MBMS
Enhance
d
Broadca
st Mode

WCDMA RAN

nd
NBMDl BSC691 ADD WRFD- MBMS Meaning:

CacAlgo 0 UCELL 010660 Phase 2 Selection of downlink admission control algorithm
SelSwitc ALGOS WRFD- MBMS
h WITCH ALGORITHM_OFF: Downlink power admission
010661 over Iur control algorithm disabled
MOD Dynami
WRFD- ALGORITHM_FIRST: Downlink admission control
UCELL c Power
010662 algorithm based on the power load and the predicted
ALGOS Estimati
WITCH WRFD- power load increment caused by admitting new UEs.
on for
010627 MTCH ALGORITHM_SECOND: Downlink admission
WRFD- control algorithm based on the number of downlink
FACH
010665 equivalent UEs and the predicted increment in the
Transmi
number of downlink equivalent UEs to be admitted.
WRFD- ssion
0106600 Sharing ALGORITHM_THIRD: Downlink admission control
4 for algorithm based on the power load in a cell.
MBMS GUI Value Range: ALGORITHM_OFF,
WRFD-
MBMS ALGORITHM_FIRST, ALGORITHM_SECOND,
020101
Channel ALGORITHM_THIRD
WRFD- Audienc Unit: None
0106600 e Rating
2 Actual Value Range: ALGORITHM_OFF,
Statistic
ALGORITHM_FIRST, ALGORITHM_SECOND,
WRFD- s
ALGORITHM_THIRD
0106600 Inter-
Frequen
WRFD- cy
010663 Neighbo
ring Cell
WRFD- Selectio
0106160 n for
6 MBMS
WRFD- PTP
0106160 Users
1 Admissi
WRFD- on
0106160 Control
3 MBMS
WRFD- P2P over
0106160 HSDPA
2 MBMS
Admissi
WRFD-
on
0106160
Enhance
5
ment
WRFD-
MSCH
0106160
Scheduli
4
ng

WCDMA RAN

nd
WRFD- Streami
010616 ng
WRFD- Service
0106160 on
8 MBMS
WRFD- MBMS
010626 Broadca
st Mode
WRFD-
0106600 MBMS
1 Load
Control
MBMS
Admissi
on
Control
MBMS
Transpo
rt
Resourc
e
Manage
ment
MBMS
Soft/
Selectiv
e
Combini
ng
MBMS
Introduc
tion
Package
16/32/64
/
128Kbp
s
Channel
Rate on
MBMS
MBMS
FLC
(Freque
ncy
Layer
Converg

WCDMA RAN

nd
ence)/
FLD
(Freque
ncy
Layer
Dispersi
on)
MBMS
Enhance
d
Broadca
st Mode
DlOther BSC690 ADD WRFD- Admissi Meaning:

Thd 0 UCELL 020101 on Threshold for admitting a service other than
CAC Control conversational AMR services, conversational non-
MOD AMR services, and handover services.
UCELL When receiving a request for such as service, the RNC
CAC predicts the new downlink load after admitting the
service. If the predicted downlink load is less than or
equal to this threshold, the RNC admits the service.
Otherwise, the RNC rejects the service.
The threshold for admission based on downlink load can
be configured separately for the following four types of
services: handover services, conversational AMR
services, conversational non-AMR services, and other
services. Based on the parameter relationships between
"DlHOThd", "DlConvAMRThd",
"DlConvNonAMRThd", and "DlOtherThd", these
types of services are allocated different access priorities
in the following order: Handover services >
Conversational AMR services > Conversational non-
AMR services > Other services
Unit: %
Default Value: 75

WCDMA RAN

nd
DlOther BSC691 ADD WRFD- Admissi Meaning:

Thd 0 UCELL 020101 on Threshold for admitting a service other than
CAC Control conversational AMR services, conversational non-
MOD AMR services, and handover services.
UCELL When receiving a request for such as service, the RNC
CAC predicts the new downlink load after admitting the
service. If the predicted downlink load is less than or
equal to this threshold, the RNC admits the service.
Otherwise, the RNC rejects the service.
The threshold for admission based on downlink load can
be configured separately for the following four types of
services: handover services, conversational AMR
services, conversational non-AMR services, and other
services. Based on the parameter relationships between
"DlHOThd", "DlConvAMRThd",
"DlConvNonAMRThd", and "DlOtherThd", these
types of services are allocated different access priorities
in the following order: Handover services >
Conversational AMR services > Conversational non-
AMR services > Other services
Unit: %
Default Value: 75

WCDMA RAN

nd
CellCon BSC690 ADD WRFD- UE State Meaning:

nAlgoS 0 UCELL 010202 in Switch controlling certain cell-level connection-
witch1 CONNA WRFD- Connect oriented algorithms.
LGOPA 020605 ed Mode
RA (CELL- 1) RB_PARKING_SWITCH: When this switch is
WRFD- DCH, turned on, the RB Parking feature is available. This
MOD 160206 feature works as follows: When a UE fails to set up a
UCELL CELL-
WRFD- PCH, single PS BE service from the idle mode or fails to
CONNA perform a CELL_FACH-to-CELL_DCH (F2D) state
LGOPA 0204000 URA-
1 PCH, transition for a single PS BE service, this feature: 1)
RA Transits the UE to the RB Parking state (a special state
WRFD- CELL-
FACH) of the CELL_FACH state) to prevent the UE from
170204 repeatedly making RRC connection setup attempts. In
SRNS this way, this feature reduces the UE's signaling
Relocati resource consumption. 2) Prohibits the UE from
on reporting event 4A within a period of time specified by
Introduc the "ParkingF2DHTvmPTAT" parameter in the "SET
tion UUESTATETRANS" command. In this way, this
Package feature reduces the data transmission probability and
RB user-plane resource consumption for the UE. 3)
Parking Prohibits the UE from transmitting any data within a
Intra period of time specified by the "ParkingF2DHTvmTxI-
System AT" parameter in the "SET UUESTATETRANS"
Direct command. In this way, this feature reduces the data
Retry transmission probability and user-plane resource
consumption for the UE. When this switch is turned off,
Radio the RB Parking feature is unavailable. Refer to 3GPP
Aware TS 25.331 for details about the "pending time after
Video trigger" IE (corresponding to the
Shaping "ParkingF2DHTvmPTAT" parameter) and the "Tx
interruption after trigger" IE (corresponding to the
"ParkingF2DHTvmTxIAT" parameter).
2) PERFENH_SYSHO_IN_FAIL_RETRY_SWITCH:
Whether a UE processing only PS services is allowed
to perform a channel fallback or rate reduction to
attempt another incoming inter-RAT handover after the
UE fails to perform an incoming inter-RAT handover
procedure.When this switch is set to on, a UE processing
only PS services is allowed to perform a channel
fallback or rate reduction to attempt another incoming
inter-RAT handover after the UE fails to perform an
incoming inter-RAT handover procedure.When this
switch is set to off, a UE processing only PS services is
not allowed to perform a channel fallback or rate
reduction to attempt another incoming inter-RAT
handover after the UE fails to perform an incoming
inter-RAT handover procedure.

WCDMA RAN

nd
3) PREEMPTED_PS_BE_DO_PARKING_SWITCH:
Whether the RNC switches preempted UEs that process
only PS BE services to the RB Parking state. When this
switch and the RB_PARKING_SWITCH under the
"CellConnAlgoSwitch1" parameter and the
"PreemptAlgoSwitch" parameter in the "SET
UQUEUEPREEMPT" command are all set to on, the
RNC switches preempted UEs that process only PS BE
services to the RB Parking state. When this switch is set
to off, the RNC applies the original processing
mechanism to preempted UEs that process only PS BE
services; for example, the RNC directly releases the
RRC connections of these UEs. The RB Parking feature
works as follows: The RNC switches a UE to the
CELL_FACH state and stops user-plane data
transmission for the UE. For details about RB Parking,
see the meaning of the RB_PARKING_SWITCH under
the "CellConnAlgoSwitch1" parameter.
4) VIDEO_SHAPE_SWITCH: Whether to enable the
video shaping function for video services in a cell.When
this switch is set to on, video shaping is enabled for an
HSDPA UE in the cell if the RNC detects that the UE
is processing video services.When this switch is set to
off, video shaping is disabled for the cell.
5) IDLE_DRD_BASED_COVER_SWITCH: If this
switch is turned on, the RNC proactively obtains the
RSCP of a UE, which sends an RRC request in idle
mode to establish new services when the RNC enables
the blind-handover-based DRD algorithm, and then
determines the UE coverage condition based on the
measured RSCP and target cell RTWP so as to filter
target cells with poor coverage. If this switch is turned
off, the RNC does not proactively obtain the RSCP of a
UE, which sends an RRC request in idle mode to
establish new services when the RNC enables the blind-
handover-based DRD algorithm.
6) C2D_DRD_BASED_COVER_SWITCH: If this
RSCP of a UE, which send a request in the CELL_PCH
or CELL_FACH state to reconfigure services or
handover-based DRD algorithm, and then determines
the UE coverage condition based on the measured RSCP
and target cell RTWP to filter target cells with poor
coverage. If this switch is turned off, the RNC does not
proactively obtain the RSCP of a UE, which sends a

WCDMA RAN

nd
request in the CELL_PCH or CELL_FACH state to

reconfigure services or establish new services when the
RNC enables the blind-handover-based DRD
algorithm.
7) CONN_DRD_BASED_COVER_SWITCH: If this
RSCP of a UE in DCCC or periodic retry scenarios
when the RNC enables the blind-handover-based DRD
algorithm, and then determines the UE coverage
condition based on the measured RSCP and target cell
RTWP so as to filter target cells with poor coverage. If
this switch is turned off, the RNC does not proactively
obtain the RSCP of a UE in DCCC or periodic retry
scenarios when the RNC enables the blind-handover-
based DRD algorithm.
8)MOVE_USER_PS_LIMIT_IND: Whether moving
users can perform PS services in a cell. When this switch
is turned on, moving users are not allowed to perform
PS services in this cell.When this switch is turned off,
moving users are allowed to perform PS services in this
cell.
GUI Value Range: RB_PARKING_SWITCH,
PERFENH_SYSHO_IN_FAIL_RETRY_SWITCH,
PREEMPTED_PS_BE_DO_PARKING_SWITCH,
VIDEO_SHAPE_SWITCH,
IDLE_DRD_BASED_COVER_SWITCH,
C2D_DRD_BASED_COVER_SWITCH,
CONN_DRD_BASED_COVER_SWITCH,
MOVE_USER_PS_LIMIT_IND
Unit: None
Actual Value Range:
RB_PARKING_SWITCH,
VIDEO_SHAPE_SWITCH,
Default Value: RB_PARKING_SWITCH:0,
PERFENH_SYSHO_IN_FAIL_RETRY_SWITCH:0,
PREEMPTED_PS_BE_DO_PARKING_SWITCH:0,
VIDEO_SHAPE_SWITCH:
0,IDLE_DRD_BASED_COVER_SWITCH:0,

WCDMA RAN

nd
C2D_DRD_BASED_COVER_SWITCH:
0,CONN_DRD_BASED_COVER_SWITCH:
0,MOVE_USER_PS_LIMIT_IND:0

WCDMA RAN

nd
CellCon BSC691 ADD WRFD- UE State Meaning:

nAlgoS 0 UCELL 010202 in Switch controlling certain cell-level connection-
witch1 CONNA WRFD- Connect oriented algorithms.
LGOPA 020605 ed Mode
RA (CELL- 1) RB_PARKING_SWITCH: When this switch is
WRFD- DCH, turned on, the RB Parking feature is available. This
MOD 160206 feature works as follows: When a UE fails to set up a
UCELL CELL-
WRFD- PCH, single PS BE service from the idle mode or fails to
CONNA perform a CELL_FACH-to-CELL_DCH (F2D) state
LGOPA 0204000 URA-
1 PCH, transition for a single PS BE service, this feature: 1)
RA Transits the UE to the RB Parking state (a special state
WRFD- CELL-
FACH) of the CELL_FACH state) to prevent the UE from
170204 repeatedly making RRC connection setup attempts. In
SRNS this way, this feature reduces the UE's signaling
Relocati resource consumption. 2) Prohibits the UE from
on reporting event 4A within a period of time specified by
Introduc the "ParkingF2DHTvmPTAT" parameter in the "SET
tion UUESTATETRANS" command. In this way, this
Package feature reduces the data transmission probability and
RB user-plane resource consumption for the UE. 3)
Parking Prohibits the UE from transmitting any data within a
Intra period of time specified by the "ParkingF2DHTvmTxI-
System AT" parameter in the "SET UUESTATETRANS"
Direct command. In this way, this feature reduces the data
Retry transmission probability and user-plane resource
consumption for the UE. When this switch is turned off,
Radio the RB Parking feature is unavailable. Refer to 3GPP
Aware TS 25.331 for details about the "pending time after
Video trigger" IE (corresponding to the
Shaping "ParkingF2DHTvmPTAT" parameter) and the "Tx
interruption after trigger" IE (corresponding to the
"ParkingF2DHTvmTxIAT" parameter).
2) PERFENH_SYSHO_IN_FAIL_RETRY_SWITCH:
Whether a UE processing only PS services is allowed
to perform a channel fallback or rate reduction to
attempt another incoming inter-RAT handover after the
UE fails to perform an incoming inter-RAT handover
procedure.When this switch is set to on, a UE processing
only PS services is allowed to perform a channel
fallback or rate reduction to attempt another incoming
inter-RAT handover after the UE fails to perform an
incoming inter-RAT handover procedure.When this
switch is set to off, a UE processing only PS services is
not allowed to perform a channel fallback or rate
reduction to attempt another incoming inter-RAT
handover after the UE fails to perform an incoming
inter-RAT handover procedure.

WCDMA RAN

nd
3) PREEMPTED_PS_BE_DO_PARKING_SWITCH:
Whether the RNC switches preempted UEs that process
only PS BE services to the RB Parking state. When this
switch and the RB_PARKING_SWITCH under the
"CellConnAlgoSwitch1" parameter and the
"PreemptAlgoSwitch" parameter in the "SET
UQUEUEPREEMPT" command are all set to on, the
RNC switches preempted UEs that process only PS BE
services to the RB Parking state. When this switch is set
to off, the RNC applies the original processing
mechanism to preempted UEs that process only PS BE
services; for example, the RNC directly releases the
RRC connections of these UEs. The RB Parking feature
works as follows: The RNC switches a UE to the
CELL_FACH state and stops user-plane data
transmission for the UE. For details about RB Parking,
see the meaning of the RB_PARKING_SWITCH under
the "CellConnAlgoSwitch1" parameter.
4) VIDEO_SHAPE_SWITCH: Whether to enable the
video shaping function for video services in a cell.When
this switch is set to on, video shaping is enabled for an
HSDPA UE in the cell if the RNC detects that the UE
is processing video services.When this switch is set to
off, video shaping is disabled for the cell.
5) IDLE_DRD_BASED_COVER_SWITCH: If this
RSCP of a UE, which sends an RRC request in idle
mode to establish new services when the RNC enables
the blind-handover-based DRD algorithm, and then
determines the UE coverage condition based on the
measured RSCP and target cell RTWP so as to filter
target cells with poor coverage. If this switch is turned
off, the RNC does not proactively obtain the RSCP of a
UE, which sends an RRC request in idle mode to
handover-based DRD algorithm.
6) C2D_DRD_BASED_COVER_SWITCH: If this
RSCP of a UE, which send a request in the CELL_PCH
or CELL_FACH state to reconfigure services or
handover-based DRD algorithm, and then determines
the UE coverage condition based on the measured RSCP
and target cell RTWP to filter target cells with poor
coverage. If this switch is turned off, the RNC does not
proactively obtain the RSCP of a UE, which sends a

WCDMA RAN

nd
request in the CELL_PCH or CELL_FACH state to

reconfigure services or establish new services when the
RNC enables the blind-handover-based DRD
algorithm.
7) CONN_DRD_BASED_COVER_SWITCH: If this
RSCP of a UE in DCCC or periodic retry scenarios
when the RNC enables the blind-handover-based DRD
algorithm, and then determines the UE coverage
condition based on the measured RSCP and target cell
RTWP so as to filter target cells with poor coverage. If
this switch is turned off, the RNC does not proactively
obtain the RSCP of a UE in DCCC or periodic retry
scenarios when the RNC enables the blind-handover-
based DRD algorithm.
8)MOVE_USER_PS_LIMIT_IND: Whether moving
users can perform PS services in a cell. When this switch
is turned on, moving users are not allowed to perform
PS services in this cell.When this switch is turned off,
moving users are allowed to perform PS services in this
cell.
GUI Value Range: RB_PARKING_SWITCH,
VIDEO_SHAPE_SWITCH,
Unit: None
Actual Value Range:
RB_PARKING_SWITCH,
VIDEO_SHAPE_SWITCH,
Default Value: RB_PARKING_SWITCH:0,
PERFENH_SYSHO_IN_FAIL_RETRY_SWITCH:0,
PREEMPTED_PS_BE_DO_PARKING_SWITCH:0,
VIDEO_SHAPE_SWITCH:
0,IDLE_DRD_BASED_COVER_SWITCH:0,

WCDMA RAN

nd
C2D_DRD_BASED_COVER_SWITCH:
0,CONN_DRD_BASED_COVER_SWITCH:
0,MOVE_USER_PS_LIMIT_IND:0
Platinu BSC690 ADD WRFD- Platinu Meaning: Timer set for the state transitions of the
mCellD 0 UPLATI 150204 m User specified platinum subscribers from CELL_DCH to
chlowA NUMIM Prioritizi CELL_FACH, CELL_PCH, or URA_PCH.
ctTmr SI ng GUI Value Range: 1~65535
MOD Unit: s
UPLATI
NUMIM Actual Value Range: 1~65535
SI Default Value: 10
Platinu BSC691 ADD WRFD- Platinu Meaning: Timer set for the state transitions of the
mCellD 0 UPLATI 150204 m User specified platinum subscribers from CELL_DCH to
chlowA NUMIM Prioritizi CELL_FACH, CELL_PCH, or URA_PCH.
ctTmr SI ng GUI Value Range: 1~65535
MOD Unit: s
UPLATI
NUMIM Actual Value Range: 1~65535
SI Default Value: 10

WCDMA RAN

nd
Optimiz BSC690 SET WRFD- Dynami Meaning:

ationSwi 0 URRCT 021101 c 1. PAGGING_NUM_CTRL_SWITCH
tch RLSWI WRFD- Channel
TCH Configu Maximum number of paging attempts in the RAN
010510
ration network when no response is received after a paging
WRFD- Control message is sent.
010651 (DCCC) 1: This switch is turned on. The paging message is sent
WRFD- 3.4/6.8/1 for a maximum of 5 times.
140103 3.6/27.2 0: This switch is turned off. The paging message is sent
WRFD- Kbps for a maximum of 10 times.
040100 RRC
Connect 2. ASU_RL_RESET_SWITCH(Switch for RL
WRFD- Reestablishment During Soft Handover)
010507 ion and
Radio Whether to trigger radio link (RL) reestablishment
WRFD-
Access during a soft handover.
140226
Bearer
1: This switch is turned on. A UE sends a CELL
WRFD- Establis
UPDATE message to the RNC and subsequently the
020500 hment
RNC reestablishes the RL for the UE when both of the
WRFD- and
following conditions are met:
010301 Release
-The RNC is waiting for the UE's response to the
WRFD- HSDPA
ACTIVE SET UPDATE message.
0106150 over Iur
2 Call -The RNC detects that downlink transmission on
Reestabl signaling radio bearer (SRB2) is disconnected or the
WRFD- NodeB reports that all RLs for the UE are out of
010801 ishment
synchronization.
WRFD- Flow
Control 0: This switch is turned off. The RNC does not
010802
reestablish the RL for the UE when the preceding
WRFD- Rate
conditions are met.
011402 Negotiat
ion at 3. MC_RL_RESET_SWITCH(Switch for RL
WRFD- Admissi Reestablishment During Meas Control)
0106150 on
4 Whether to trigger RL reestablishment during
Control measurement control.
Fast 1: This switch is turned on. A UE sends a CELL
Return UPDATE message to the RNC and subsequently the
from RNC reestablishes the RL for the UE when both of the
UMTS following conditions are met:
to LTE
-The RNC has sent a MEASUREMENT CONTROL
Enhance
message to the UE.
d Fast
Dorman -The RNC detects that downlink transmission on SRB2
cy is disconnected when the UE state is stable.
Paging 0: This switch is turned off. The RNC does not
UE in reestablish the RL for the UE when the preceding
Idle, conditions are met.

WCDMA RAN

nd
CELL_P 4.
CH, FD_PCH_REENTERSA_FORCE_RRC_REL_SWIT
URA_P CH.
CH State Whether to enable the RNC to release the RRC
(Type 1) connection of an EFD-capable UE that received an
Combin SCRI message from the PS domain of the CN if the UE
ation of sends the RNC a CELL UPDATE message after
One CS reentering a service area. When this switch is turned on,
Service the RNC releases the RRC connection of such a UE in
and Two the preceding scenario. This solves the problem that a
PS network becomes inaccessible when such a UE reenters
Services a service area.
Intra 1: This switch is turned on. The RNC directly releases
RNC the RRC connection after receiving the CELL UPDATE
Cell message from the Enhanced Fast Dormancy-capable
Update that leaves and then reenters the service area.
Inter 0: This switch is turned off. The RNC processes the
RNC CELL UPDATE message received from the Enhanced
Cell Fast Dormancy-capable UE that leaves and then
Update reenters the service area.
Encrypti 5. UE_CRC_COMPATIBLE_SWITCH.
on Whether the RNC normally releases connections when
Combin it detects failed cyclic redundancy check (CRC) on RB
ation of SETUP COMPLETE or RB RECONFIGURATION
One CS COMPLETE messages received from HSDPA UEs.
Service 1: This switch is turned on. The RNC normally releases
and the connections when it detects the failed CRC.
Three
PS 0: This switch is turned off. The RNC abnormally
Services releases the connections when it detects the failed CRC.
6. RNC_P2D_DRD_SWITCH.
Whether the RNC performs the directed retry decision
(DRD) when it receives a CELL UPDATE message
with the cause value "uplink data transmission" or "
paging response" during UEs' state transition from
CELL_PCH or URA_PCH to CELL_DCH.
1: This switch is turned on. The RNC performs the DRD
in the preceding scenario.
0: This switch is turned off. The RNC does not perform
the DRD in the preceding scenario.
7. P2D_SWITCH
Whether the RNC switches a UE from the CELL_PCH
or URA_PCH state to the CELL_DCH state when the

WCDMA RAN

nd
The UE sends the RNC a CELL UPDATE message with

the cause value "uplink data transmission" or "paging
response."
The number of UEs on the FACH reaches the upper
limit or the UE is to set up a CS service but the common
channel is congested.
1: This switch is set to on. The RNC switches the UE
from the CELL_PCH or URA_PCH state to the
CELL_DCH state in the preceding scenario.
0: This switch is set to off. The RNC does not switch
the UE from the CELL_PCH or URA_PCH state to the
This parameter can be set in both the "SET
URRCTRLSWITCH" and "ADD
UCELLCONNALGOPARA" commands. The value of
this parameter in the "ADD UCELLCONNALGO-
PARA" command prevails.
8. AMR_F2D_OVERLAP_CELLUPT_SWITCH
Whether the RNC proceeds with CS service setups
involving state transitions from CELL_FACH to
CELL_DCH if the UEs in question report cell updates
during the setup procedure.
1: This switch is turned on. The RNC first processes the
CELL UPDATE message and then proceeds with the
CS service setup procedure.
0: This switch is turned off. The RNC processes the
CELL UPDATE message and does not proceed with the
CS service setup.
9. SRB_RESET_RL_SETUP_SWITCH
Whether the RNC reestablishes a radio link (RL) when
it detects an SRB reset reported on Layer 2 for
decreasing the number of UE call drops
1: This switch is turned on. The RNC reestablishes an
RL when it detects the SRB reset.
0: This switch is turned off. The RNC does not
reestablish an RL when it detects the SRB reset.
10. RLFAIL_RL_SETUP_SWITCH
Whether active link re-establishment is allowed after
the radio link fails
1: This switch is turned on. Active link re-establishment
is allowed after the RNC receives a RADIO LINK
FAILURE INDICATION message and the timer used

WCDMA RAN

nd
to wait for a RADIO LINK RESTORE INDICATION

message from the NodeB expires.
0: This switch is turned off. Active link re-establishment
is not allowed after the RNC receives a RADIO LINK
11. CS_RL_SETUP_SWITCH
SRBs of a CS service reset or all its RLs are out of
synchronization.
RL in the preceding scenario.
reestablish an RL in the preceding scenario.
12. PS_RL_SETUP_SWITCH
Whether PS services can trigger active link re-
establishment
1: This switch is turned on. PS services can trigger active
link re-establishment.
0: This switch is turned off. PS services cannot trigger
active link re-establishment.
13. UE_SRB_RESET_SWITCH
it receives a CELL UPDATE message carrying SRB
reset information.
1: This switch is turned on. The RNC does not release
the RRC connection and it reestablishes an RL.
0: This switch is turned off. The RNC releases the RRC
connection.
14. RL_RESTORE_SWITCH
Switch for the radio link restoration timer
1: This switch is turned on. If there are CS services and
the last radio link fails, the RNC waits for the radio link
to restore before the timer T313 expires.
0: This switch is turned off. If there are CS services and
to restore before the original timer expires.
15. RNC_EFD_D2F_SWITCH
Whether to enable RNC-level UE state transition from
CELL_DCH to CELL_FACH (D2F) for fast dormancy-
capable UEs.

WCDMA RAN

nd
1: This switch is turned on. The D2F state transition is

enabled for the fast dormancy-capable UEs..
0: This switch is turned off. The state transition from
CELL_DCH to CELL_PCH (D2P) is enabled for the
fast dormancy-capable UEs
16. RNC_RB_SCRI_NOT_DROP_SWITCH
Whether the RB release due to SCRI during RB
reconfiguration is calculated as a call drop
1: This switch is turned on. The RB release due to SCRI
during reconfiguration is not calculated as a call drop.
0: This switch is turned off. The RB release due to SCRI
during reconfiguration is calculated as a call drop.
17. RRC_RECONN_SWITCH
Switch for the RNC to process the RRC connection
setup requests from a UE.
1: This switch is turned on. The RNC releases the
established RRC connection when the UE retransmits
RRC connection setup requests.
0: This switch is turned off. When the UE retransmits
the RRC connection setup request to access the same
cell, the RNC rejects the new RRC connection setup
requests. When the UE retransmits the RRC connection
setup request to access different cells, the RNC releases
the established RRC connection.
It is recommended that this parameter be set to its
default value and the parameter value be not changed.
If you need to change the value of this parameter, ask
for assistance from Huawei technical support personnel.
18. RRC_REPEAT_PFM_SWITCH
Whether the RNC counts the number of retransmitted
RRC connection setup requests in the measurement of
the RRC.AttConnEstab.Reg and
RRC.AttConnEstab.Detac performance counters.
1: This switch is turned on. The RNC counts the number
of retransmitted RRC connection setup requests in the
measurement of the two preceding performance
counters.
0: This switch is turned off. The RNC does not count
the number of retransmitted RRC connection setup
requests in the measurement of the two preceding
performance counters.
19. F2D_NO_RSP_RRCREL_SWITCH

WCDMA RAN

nd
Whether the RNC releases the RRC connection of a UE

if the UE does not respond to the RNC after its three
failed attempts at the state transition from CELL_FACH
to CELL_DCH.
1: This switch is turned on. The RRC connection is
released with the cause "User Inactive" after the UE fails
in the state transition from CELL_FACH to
CELL_DCH for three times. The connection release is
measured in the VS.RAB.Rel.PS.F2DNoRsp counter.
0: This switch is turned off. The RRC connection is not
released after the UE fails in the state transition from
CELL_FACH to CELL_DCH three times, and the UE
remains in the CELL_FACH state.
20. CS_SETUP_P2D_SWITCH
Whether a UE in the CELL_PCH or URA_PCH state
preferentially performs a state transition from
CELL_PCH or URA_PCH to CELL_DCH or
CELL_FACH before initiating a CS service.
1: This switch is turned on. The RNC first performs a
state transition from CELL_PCH or URA_PCH to
CELL_DCH and then initiates the CS service.
0: This switch is turned off. The UE first performs a state
transition from CELL_PCH or URA_PCH to
CELL_FACH and then initiates the CS service.
21. SYSHO_CIPHER_IE_SWITCH
Whether the relocation command sent from a UMTS
network to an unencrypted GSM network carries the
UEA0 encryption information element (IE) when a UE
complying with 3GPP Release 6 or later is handed over
from the GSM network to the UMTS network.
1: This switch is turned on. The relocation command
does not carry any encryption IE.
0: This switch is turned off. The relocation command
carries the UEA0 encryption IE.
22. P2P_GTPU_NOT_CFG_SWITCH
Whether to reconfigure the GPRS Tunneling Protocol
User plane (GTP-U) when a UE in the CELL_PCH state
performs a cell update.
1: This switch is turned on. The GTP-U is not
reconfigured in the preceding scenario.
0: This switch is turned off. The GTP-U is reconfigured
23. RB_SETUP_CIPHER_TIME_ADJ_SWITCH

WCDMA RAN

nd
Whether the RNC adjusts the activation time for

encryption parameters based on an RB SETUP
COMPLETE message
1: This switch is turned on. The RNC does not adjust
the activation time for encryption parameters as long as
the difference between the activation times specified in
an RB SETUP COMPLETE message and in the
corresponding RB SETUP message is smaller than 200
connection frame numbers (CFNs).
0: This switch is turned off. The RNC always adjusts
the activation time for encryption parameters based on
an RB SETUP COMPLETE message, regardless of the
preceding difference.
24. CS_PRI_MOD_NOT_INT_SWITCH
Whether the RNC reinitiates CS services upon receiving
a RAB ASSIGNMENT REQUEST message in which
only the CS allocation/retention priority (CARP) is
changed.
1: This switch is turned on. The RNC does not reinitiate
CS services, which prevents CS call drops.
0: This switch is turned off. The RNC reinitiates CS
services, which results in CS call drops.
25. RAB_SETUP_TMSI_REALLOC_BUF_SWITCH
Whether the RNC buffers a TMSI REALLOCATION
COMMAND message received during an RAB setup.
1: This switch is turned on. The RNC buffers the TMSI
REALLOCATION COMMAND message received
during the RAB setup and then forwards the message to
a UE after the RAB setup.
0: This switch is turned off. The RNC does not buffer
the TMSI REALLOCATION COMMAND message
received during the RAB setup. The RNC directly
forwards the message to a UE.
26. IU_FAULT_REL_PS_RES_SWITCH
Whether an UCP subsystem sends a PS service release
message to an Iu-PS interface board in case of a faulty
IP path, a faulty Signaling Connection Control Part
(SCCP) link, or a reset on the Iu interface
1: This switch is turned on. The UCP subsystem sends
the PS service release message to the Iu-PS interface
board.

WCDMA RAN

nd
0: This switch is turned off. The UCP subsystem does

not send any PS service release message to the Iu-PS
interface board.
27. RB_RECFG_RL_REEST_SWITCH
Whether the RNC initiates radio link (RL)
reestablishment during a radio bearer (RB)
reconfiguration when the RNC detects that a signaling
radio bearer (SRB) is reset or all RLs for a UE are out
of synchronization
1: This switch is turned on. The RNC initiates RL
reestablishment during the RB reconfiguration.
0: This switch is turned off. The RNC does not initiate
RL reestablishment during the RB reconfiguration.
28. F2P_DT_MSG_BUFFER_SWITCH
Whether the RNC buffers a DIRECT TRANSFER
message received from the CN and sends a PAGING
message after the RNC receives a RADIO BEARER
RECONFIGURATION COMPLETE message from a
UE moving from the CELL_FACH to CELL_PCH state
(F2P for short)
1: This switch is turned on. The RNC buffers the
DIRECT TRANSFER message and sends the PAGING
message to the UE.
the DIRECT TRANSFER message.
29. SCRI_COMPATIBLE_SWITCH
Whether the RNC performs compatibility processing
upon receiving a Signalling Connection Release
Indication message with the cause value "UE Requested
PS Data Session End" when CS+PS combined services
are performed.
1: This switch is turned on. The RNC performs
compatibility processing. It sends an RB RELEASE
message containing the Signalling Connection Release
Indication information element (IE) to instruct a UE to
release the signaling connection in the corresponding
domain.
compatibility processing and it discards the SCRI
message.
30. GTPU_ERR_IND_DEF_SWITCH
Whether the RNC measures the number of call drops
when it receives a GTPU Error Indication message

WCDMA RAN

nd
pertaining to a UE from the CN and releases the RRC

connection.
1: This switch is turned on. The RNC does not measure
the number of call drops in the preceding scenario.
0: This switch is turned off. The RNC measures the
number of call drops when releasing PS services.
31.
IUR_SRV_CELL_CHG_MACHS_RESET_SWITCH
Whether the RNC contains the MAC-hs reset indicator
information element (IE) in the PHYSICAL
CHANNEL RECONFIGURATION and RADIO
BEARER RECONFIGURATION messages for a reset
of the MAC-hs entity. The two messages are sent to a
UE when a service link over the Iur interface changes.
1: This switch is turned on. The RNC contains the MAC-
hs reset indicator IE in the two preceding messages.
0: This switch is turned off. The RNC does not contain
the MAC-hs reset indicator IE in the two preceding
messages.
32. UL_INTEG_ALGO_COMPAT_SWITCH(UL
Integrity Compatibility Optimization Switch)
Reserved switch for security mode compatibility
handling. The bit field value is not internally used in this
version.
GUI Value Range:
PAGGING_NUM_CTRL_SWITCH
(PAGGING_NUM_CTRL_SWITCH),
ASU_RL_RESET_SWITCH
(ASU_RL_RESET_SWITCH),
MC_RL_RESET_SWITCH
(MC_RL_RESET_SWITCH),
FD_PCH_REENTERSA_FORCE_RRC_REL_SWIT
CH
(FD_PCH_REENTERSA_FORCE_RRC_REL_SWIT
CH), UE_CRC_COMPATIBLE_SWITCH
(UE_CRC_COMPATIBLE_SWITCH),
RNC_P2D_DRD_SWITCH
(RNC_P2D_DRD_SWITCH), P2D_SWITCH
(P2D_SWITCH),
AMR_F2D_OVERLAP_CELLUPT_SWITCH
(AMR_F2D_OVERLAP_CELLUPT_SWITCH),
SRB_RESET_RL_SETUP_SWITCH
(SRB_RESET_RL_SETUP_SWITCH),
RLFAIL_RL_SETUP_SWITCH

WCDMA RAN

nd
(RLFAIL_RL_SETUP_SWITCH),
CS_RL_SETUP_SWITCH
(CS_RL_SETUP_SWITCH),
PS_RL_SETUP_SWITCH
(PS_RL_SETUP_SWITCH),
UE_SRB_RESET_SWITCH
(UE_SRB_RESET_SWITCH),
RL_RESTORE_SWITCH
(RL_RESTORE_SWITCH),
RNC_EFD_D2F_SWITCH
(RNC_EFD_D2F_SWITCH),
RNC_RB_SCRI_NOT_DROP_SWITCH
(RNC_RB_SCRI_NOT_DROP_SWITCH),
RRC_RECONN_SWITCH
(RRC_RECONN_SWITCH),
RRC_REPEAT_PFM_SWITCH
(RRC_REPEAT_PFM_SWITCH),
F2D_NO_RSP_RRCREL_SWITCH
(F2D_NO_RSP_RRCREL_SWITCH),
CS_SETUP_P2D_SWITCH
(CS_SETUP_P2D_SWITCH),
SYSHO_CIPHER_IE_SWITCH
(SYSHO_CIPHER_IE_SWITCH),
P2P_GTPU_NOT_CFG_SWITCH
(P2P_GTPU_NOT_CFG_SWITCH),
RB_SETUP_CIPHER_TIME_ADJ_SWITCH
(RB_SETUP_CIPHER_TIME_ADJ_SWITCH),
CS_PRI_MOD_NOT_INT_SWITCH
(CS_PRI_MOD_NOT_INT_SWITCH),
RAB_SETUP_TMSI_REALLOC_BUF_SWITCH
(RAB_SETUP_TMSI_REALLOC_BUF_SWITCH),
IU_FAULT_REL_PS_RES_SWITCH
(IU_FAULT_REL_PS_RES_SWITCH),
RB_RECFG_RL_REEST_SWITCH
(RB_RECFG_RL_REEST_SWITCH),
F2P_DT_MSG_BUFFER_SWITCH
(F2P_DT_MSG_BUFFER_SWITCH),
SCRI_COMPATIBLE_SWITCH
(SCRI_COMPATIBLE_SWITCH),
GTPU_ERR_IND_DEF_SWITCH
(GTPU_ERR_IND_DEF_SWITCH),
(IUR_SRV_CELL_CHG_MACHS_RESET_SWITC
H), UL_INTEG_ALGO_COMPAT_SWITCH
(UL_INTEG_ALGO_COMPAT_SWITCH)
Unit: None

WCDMA RAN

nd
Actual Value Range:

PAGGING_NUM_CTRL_SWITCH,
ASU_RL_RESET_SWITCH,
MC_RL_RESET_SWITCH,
CH,
UE_CRC_COMPATIBLE_SWITCH,
RNC_P2D_DRD_SWITCH,
P2D_SWITCH,
AMR_F2D_OVERLAP_CELLUPT_SWITCH,
SRB_RESET_RL_SETUP_SWITCH,
RLFAIL_RL_SETUP_SWITCH,
CS_RL_SETUP_SWITCH,
PS_RL_SETUP_SWITCH,
UE_SRB_RESET_SWITCH,
RL_RESTORE_SWITCH,
RNC_EFD_D2F_SWITCH,
RNC_RB_SCRI_NOT_DROP_SWITCH,
RRC_RECONN_SWITCH,
RRC_REPEAT_PFM_SWITCH,
F2D_NO_RSP_RRCREL_SWITCH,
CS_SETUP_P2D_SWITCH,
SYSHO_CIPHER_IE_SWITCH,
P2P_GTPU_NOT_CFG_SWITCH,
RB_SETUP_CIPHER_TIME_ADJ_SWITCH,
CS_PRI_MOD_NOT_INT_SWITCH,
RAB_SETUP_TMSI_REALLOC_BUF_SWITCH,
IU_FAULT_REL_PS_RES_SWITCH,
RB_RECFG_RL_REEST_SWITCH,
F2P_DT_MSG_BUFFER_SWITCH,
SCRI_COMPATIBLE_SWITCH,
GTPU_ERR_IND_DEF_SWITCH,
,
UL_INTEG_ALGO_COMPAT_SWITCH
Default Value: PAGGING_NUM_CTRL_SWITCH:
0,ASU_RL_RESET_SWITCH:

WCDMA RAN

nd
0,MC_RL_RESET_SWITCH:
0,FD_PCH_REENTERSA_FORCE_RRC_REL_SWI
TCH:0,UE_CRC_COMPATIBLE_SWITCH:
0,RNC_P2D_DRD_SWITCH:0,P2D_SWITCH:
0,AMR_F2D_OVERLAP_CELLUPT_SWITCH:
0,SRB_RESET_RL_SETUP_SWITCH:
0,RLFAIL_RL_SETUP_SWITCH:
0,CS_RL_SETUP_SWITCH:
0,PS_RL_SETUP_SWITCH:
0,UE_SRB_RESET_SWITCH:
0,RL_RESTORE_SWITCH:
0,RNC_EFD_D2F_SWITCH:
1,RNC_RB_SCRI_NOT_DROP_SWITCH:
0,RRC_RECONN_SWITCH:
0,RRC_REPEAT_PFM_SWITCH:
1,F2D_NO_RSP_RRCREL_SWITCH:
0,CS_SETUP_P2D_SWITCH:
0,SYSHO_CIPHER_IE_SWITCH:
0,P2P_GTPU_NOT_CFG_SWITCH:
1,RB_SETUP_CIPHER_TIME_ADJ_SWITCH:
1,CS_PRI_MOD_NOT_INT_SWITCH:
0,RAB_SETUP_TMSI_REALLOC_BUF_SWITCH:
0,IU_FAULT_REL_PS_RES_SWITCH:
0,RB_RECFG_RL_REEST_SWITCH:
0,F2P_DT_MSG_BUFFER_SWITCH:
0,SCRI_COMPATIBLE_SWITCH:
0,GTPU_ERR_IND_DEF_SWITCH:
0,IUR_SRV_CELL_CHG_MACHS_RESET_SWITC
H:1,UL_INTEG_ALGO_COMPAT_SWITCH:0

WCDMA RAN

nd
Optimiz BSC691 SET WRFD- Dynami Meaning:

ationSwi 0 URRCT 021101 c 1. PAGGING_NUM_CTRL_SWITCH
tch RLSWI WRFD- Channel
TCH Configu Maximum number of paging attempts in the RAN
010510
ration network when no response is received after a paging
WRFD- Control message is sent.
010651 (DCCC) 1: This switch is turned on. The paging message is sent
WRFD- 3.4/6.8/1 for a maximum of 5 times.
140103 3.6/27.2 0: This switch is turned off. The paging message is sent
WRFD- Kbps for a maximum of 10 times.
040100 RRC
Connect 2. ASU_RL_RESET_SWITCH(Switch for RL
WRFD- Reestablishment During Soft Handover)
010507 ion and
Radio Whether to trigger radio link (RL) reestablishment
WRFD-
Access during a soft handover.
140226
Bearer
1: This switch is turned on. A UE sends a CELL
WRFD- Establis
UPDATE message to the RNC and subsequently the
020500 hment
RNC reestablishes the RL for the UE when both of the
WRFD- and
010301 Release
-The RNC is waiting for the UE's response to the
WRFD- HSDPA
ACTIVE SET UPDATE message.
0106150 over Iur
2 Call -The RNC detects that downlink transmission on
Reestabl signaling radio bearer (SRB2) is disconnected or the
WRFD- NodeB reports that all RLs for the UE are out of
010801 ishment
synchronization.
WRFD- Flow
Control 0: This switch is turned off. The RNC does not
010802
reestablish the RL for the UE when the preceding
WRFD- Rate
conditions are met.
011402 Negotiat
ion at 3. MC_RL_RESET_SWITCH(Switch for RL
WRFD- Admissi Reestablishment During Meas Control)
0106150 on
4 Whether to trigger RL reestablishment during
Control measurement control.
Fast 1: This switch is turned on. A UE sends a CELL
Return UPDATE message to the RNC and subsequently the
from RNC reestablishes the RL for the UE when both of the
UMTS following conditions are met:
to LTE
-The RNC has sent a MEASUREMENT CONTROL
Enhance
message to the UE.
d Fast
Dorman -The RNC detects that downlink transmission on SRB2
cy is disconnected when the UE state is stable.
Paging 0: This switch is turned off. The RNC does not
UE in reestablish the RL for the UE when the preceding
Idle, conditions are met.

WCDMA RAN

nd
CELL_P 4.
CH, FD_PCH_REENTERSA_FORCE_RRC_REL_SWIT
URA_P CH.
CH State Whether to enable the RNC to release the RRC
(Type 1) connection of an EFD-capable UE that received an
Combin SCRI message from the PS domain of the CN if the UE
ation of sends the RNC a CELL UPDATE message after
One CS reentering a service area. When this switch is turned on,
Service the RNC releases the RRC connection of such a UE in
and Two the preceding scenario. This solves the problem that a
PS network becomes inaccessible when such a UE reenters
Services a service area.
Intra 1: This switch is turned on. The RNC directly releases
RNC the RRC connection after receiving the CELL UPDATE
Cell message from the Enhanced Fast Dormancy-capable
Update that leaves and then reenters the service area.
Inter 0: This switch is turned off. The RNC processes the
RNC CELL UPDATE message received from the Enhanced
Cell Fast Dormancy-capable UE that leaves and then
Update reenters the service area.
Encrypti 5. UE_CRC_COMPATIBLE_SWITCH.
on Whether the RNC normally releases connections when
Combin it detects failed cyclic redundancy check (CRC) on RB
ation of SETUP COMPLETE or RB RECONFIGURATION
One CS COMPLETE messages received from HSDPA UEs.
Service 1: This switch is turned on. The RNC normally releases
and the connections when it detects the failed CRC.
Three
PS 0: This switch is turned off. The RNC abnormally
Services releases the connections when it detects the failed CRC.
6. RNC_P2D_DRD_SWITCH.
Whether the RNC performs the directed retry decision
(DRD) when it receives a CELL UPDATE message
with the cause value "uplink data transmission" or "
paging response" during UEs' state transition from
CELL_PCH or URA_PCH to CELL_DCH.
1: This switch is turned on. The RNC performs the DRD
the DRD in the preceding scenario.
7. P2D_SWITCH
Whether the RNC switches a UE from the CELL_PCH
or URA_PCH state to the CELL_DCH state when the

WCDMA RAN

nd
The UE sends the RNC a CELL UPDATE message with

the cause value "uplink data transmission" or "paging
response."
The number of UEs on the FACH reaches the upper
limit or the UE is to set up a CS service but the common
channel is congested.
1: This switch is set to on. The RNC switches the UE
from the CELL_PCH or URA_PCH state to the
0: This switch is set to off. The RNC does not switch
the UE from the CELL_PCH or URA_PCH state to the
This parameter can be set in both the "SET
URRCTRLSWITCH" and "ADD
UCELLCONNALGOPARA" commands. The value of
this parameter in the "ADD UCELLCONNALGO-
PARA" command prevails.
8. AMR_F2D_OVERLAP_CELLUPT_SWITCH
Whether the RNC proceeds with CS service setups
involving state transitions from CELL_FACH to
CELL_DCH if the UEs in question report cell updates
during the setup procedure.
1: This switch is turned on. The RNC first processes the
CELL UPDATE message and then proceeds with the
CS service setup procedure.
0: This switch is turned off. The RNC processes the
CELL UPDATE message and does not proceed with the
CS service setup.
9. SRB_RESET_RL_SETUP_SWITCH
it detects an SRB reset reported on Layer 2 for
decreasing the number of UE call drops
RL when it detects the SRB reset.
reestablish an RL when it detects the SRB reset.
10. RLFAIL_RL_SETUP_SWITCH
Whether active link re-establishment is allowed after
the radio link fails
1: This switch is turned on. Active link re-establishment
is allowed after the RNC receives a RADIO LINK

WCDMA RAN

nd

0: This switch is turned off. Active link re-establishment
is not allowed after the RNC receives a RADIO LINK
11. CS_RL_SETUP_SWITCH
SRBs of a CS service reset or all its RLs are out of
synchronization.
RL in the preceding scenario.
reestablish an RL in the preceding scenario.
12. PS_RL_SETUP_SWITCH
Whether PS services can trigger active link re-
establishment
1: This switch is turned on. PS services can trigger active
link re-establishment.
0: This switch is turned off. PS services cannot trigger
active link re-establishment.
13. UE_SRB_RESET_SWITCH
it receives a CELL UPDATE message carrying SRB
reset information.
1: This switch is turned on. The RNC does not release
the RRC connection and it reestablishes an RL.
0: This switch is turned off. The RNC releases the RRC
connection.
14. RL_RESTORE_SWITCH
Switch for the radio link restoration timer
1: This switch is turned on. If there are CS services and
to restore before the timer T313 expires.
0: This switch is turned off. If there are CS services and
to restore before the original timer expires.
15. RNC_EFD_D2F_SWITCH
Whether to enable RNC-level UE state transition from
CELL_DCH to CELL_FACH (D2F) for fast dormancy-
capable UEs.

WCDMA RAN

nd
1: This switch is turned on. The D2F state transition is

enabled for the fast dormancy-capable UEs..
0: This switch is turned off. The state transition from
CELL_DCH to CELL_PCH (D2P) is enabled for the
fast dormancy-capable UEs
16. RNC_RB_SCRI_NOT_DROP_SWITCH
Whether the RB release due to SCRI during RB
reconfiguration is calculated as a call drop
1: This switch is turned on. The RB release due to SCRI
during reconfiguration is not calculated as a call drop.
0: This switch is turned off. The RB release due to SCRI
during reconfiguration is calculated as a call drop.
17. RRC_RECONN_SWITCH
Switch for the RNC to process the RRC connection
setup requests from a UE.
1: This switch is turned on. The RNC releases the
established RRC connection when the UE retransmits
RRC connection setup requests.
0: This switch is turned off. When the UE retransmits
the RRC connection setup request to access the same
cell, the RNC rejects the new RRC connection setup
requests. When the UE retransmits the RRC connection
setup request to access different cells, the RNC releases
the established RRC connection.
It is recommended that this parameter be set to its
default value and the parameter value be not changed.
If you need to change the value of this parameter, ask
for assistance from Huawei technical support personnel.
18. RRC_REPEAT_PFM_SWITCH
Whether the RNC counts the number of retransmitted
RRC connection setup requests in the measurement of
the RRC.AttConnEstab.Reg and
RRC.AttConnEstab.Detac performance counters.
1: This switch is turned on. The RNC counts the number
of retransmitted RRC connection setup requests in the
measurement of the two preceding performance
counters.
0: This switch is turned off. The RNC does not count
the number of retransmitted RRC connection setup
requests in the measurement of the two preceding
performance counters.
19. F2D_NO_RSP_RRCREL_SWITCH

WCDMA RAN

nd
Whether the RNC releases the RRC connection of a UE

if the UE does not respond to the RNC after its three
failed attempts at the state transition from CELL_FACH
to CELL_DCH.
1: This switch is turned on. The RRC connection is
released with the cause "User Inactive" after the UE fails
in the state transition from CELL_FACH to
CELL_DCH for three times. The connection release is
measured in the VS.RAB.Rel.PS.F2DNoRsp counter.
0: This switch is turned off. The RRC connection is not
released after the UE fails in the state transition from
CELL_FACH to CELL_DCH three times, and the UE
remains in the CELL_FACH state.
20. CS_SETUP_P2D_SWITCH
Whether a UE in the CELL_PCH or URA_PCH state
preferentially performs a state transition from
CELL_PCH or URA_PCH to CELL_DCH or
CELL_FACH before initiating a CS service.
1: This switch is turned on. The RNC first performs a
state transition from CELL_PCH or URA_PCH to
CELL_DCH and then initiates the CS service.
0: This switch is turned off. The UE first performs a state
transition from CELL_PCH or URA_PCH to
CELL_FACH and then initiates the CS service.
21. SYSHO_CIPHER_IE_SWITCH
Whether the relocation command sent from a UMTS
network to an unencrypted GSM network carries the
UEA0 encryption information element (IE) when a UE
complying with 3GPP Release 6 or later is handed over
from the GSM network to the UMTS network.
1: This switch is turned on. The relocation command
does not carry any encryption IE.
0: This switch is turned off. The relocation command
carries the UEA0 encryption IE.
22. P2P_GTPU_NOT_CFG_SWITCH
Whether to reconfigure the GPRS Tunneling Protocol
User plane (GTP-U) when a UE in the CELL_PCH state
performs a cell update.
1: This switch is turned on. The GTP-U is not
reconfigured in the preceding scenario.
0: This switch is turned off. The GTP-U is reconfigured
23. RB_SETUP_CIPHER_TIME_ADJ_SWITCH

WCDMA RAN

nd
Whether the RNC adjusts the activation time for

encryption parameters based on an RB SETUP
COMPLETE message
1: This switch is turned on. The RNC does not adjust
the activation time for encryption parameters as long as
the difference between the activation times specified in
an RB SETUP COMPLETE message and in the
corresponding RB SETUP message is smaller than 200
connection frame numbers (CFNs).
0: This switch is turned off. The RNC always adjusts
the activation time for encryption parameters based on
an RB SETUP COMPLETE message, regardless of the
preceding difference.
24. CS_PRI_MOD_NOT_INT_SWITCH
Whether the RNC reinitiates CS services upon receiving
a RAB ASSIGNMENT REQUEST message in which
only the CS allocation/retention priority (CARP) is
changed.
1: This switch is turned on. The RNC does not reinitiate
CS services, which prevents CS call drops.
0: This switch is turned off. The RNC reinitiates CS
services, which results in CS call drops.
25. RAB_SETUP_TMSI_REALLOC_BUF_SWITCH
Whether the RNC buffers a TMSI REALLOCATION
COMMAND message received during an RAB setup.
1: This switch is turned on. The RNC buffers the TMSI
REALLOCATION COMMAND message received
during the RAB setup and then forwards the message to
a UE after the RAB setup.
the TMSI REALLOCATION COMMAND message
received during the RAB setup. The RNC directly
forwards the message to a UE.
26. IU_FAULT_REL_PS_RES_SWITCH
Whether an UCP subsystem sends a PS service release
message to an Iu-PS interface board in case of a faulty
IP path, a faulty Signaling Connection Control Part
(SCCP) link, or a reset on the Iu interface
1: This switch is turned on. The UCP subsystem sends
the PS service release message to the Iu-PS interface
board.

WCDMA RAN

nd
0: This switch is turned off. The UCP subsystem does

not send any PS service release message to the Iu-PS
interface board.
27. RB_RECFG_RL_REEST_SWITCH
Whether the RNC initiates radio link (RL)
reestablishment during a radio bearer (RB)
reconfiguration when the RNC detects that a signaling
radio bearer (SRB) is reset or all RLs for a UE are out
of synchronization
1: This switch is turned on. The RNC initiates RL
reestablishment during the RB reconfiguration.
0: This switch is turned off. The RNC does not initiate
RL reestablishment during the RB reconfiguration.
28. F2P_DT_MSG_BUFFER_SWITCH
Whether the RNC buffers a DIRECT TRANSFER
message received from the CN and sends a PAGING
message after the RNC receives a RADIO BEARER
RECONFIGURATION COMPLETE message from a
UE moving from the CELL_FACH to CELL_PCH state
(F2P for short)
1: This switch is turned on. The RNC buffers the
DIRECT TRANSFER message and sends the PAGING
message to the UE.
the DIRECT TRANSFER message.
29. SCRI_COMPATIBLE_SWITCH
Whether the RNC performs compatibility processing
upon receiving a Signalling Connection Release
Indication message with the cause value "UE Requested
PS Data Session End" when CS+PS combined services
are performed.
1: This switch is turned on. The RNC performs
compatibility processing. It sends an RB RELEASE
message containing the Signalling Connection Release
Indication information element (IE) to instruct a UE to
release the signaling connection in the corresponding
domain.
compatibility processing and it discards the SCRI
message.
30. GTPU_ERR_IND_DEF_SWITCH
Whether the RNC measures the number of call drops
when it receives a GTPU Error Indication message

WCDMA RAN

nd
pertaining to a UE from the CN and releases the RRC

connection.
1: This switch is turned on. The RNC does not measure
the number of call drops in the preceding scenario.
0: This switch is turned off. The RNC measures the
number of call drops when releasing PS services.
31.
Whether the RNC contains the MAC-hs reset indicator
information element (IE) in the PHYSICAL
CHANNEL RECONFIGURATION and RADIO
BEARER RECONFIGURATION messages for a reset
of the MAC-hs entity. The two messages are sent to a
UE when a service link over the Iur interface changes.
1: This switch is turned on. The RNC contains the MAC-
hs reset indicator IE in the two preceding messages.
0: This switch is turned off. The RNC does not contain
the MAC-hs reset indicator IE in the two preceding
messages.
32. UL_INTEG_ALGO_COMPAT_SWITCH(UL
Integrity Compatibility Optimization Switch)
Reserved switch for security mode compatibility
handling. The bit field value is not internally used in this
version.
GUI Value Range:
PAGGING_NUM_CTRL_SWITCH
(PAGGING_NUM_CTRL_SWITCH),
ASU_RL_RESET_SWITCH
(ASU_RL_RESET_SWITCH),
MC_RL_RESET_SWITCH
(MC_RL_RESET_SWITCH),
CH
(FD_PCH_REENTERSA_FORCE_RRC_REL_SWIT
CH), UE_CRC_COMPATIBLE_SWITCH
(UE_CRC_COMPATIBLE_SWITCH),
RNC_P2D_DRD_SWITCH
(RNC_P2D_DRD_SWITCH), P2D_SWITCH
(P2D_SWITCH),
AMR_F2D_OVERLAP_CELLUPT_SWITCH
(AMR_F2D_OVERLAP_CELLUPT_SWITCH),
SRB_RESET_RL_SETUP_SWITCH
(SRB_RESET_RL_SETUP_SWITCH),
RLFAIL_RL_SETUP_SWITCH

WCDMA RAN

nd
(RLFAIL_RL_SETUP_SWITCH),
CS_RL_SETUP_SWITCH
(CS_RL_SETUP_SWITCH),
PS_RL_SETUP_SWITCH
(PS_RL_SETUP_SWITCH),
UE_SRB_RESET_SWITCH
(UE_SRB_RESET_SWITCH),
RL_RESTORE_SWITCH
(RL_RESTORE_SWITCH),
RNC_EFD_D2F_SWITCH
(RNC_EFD_D2F_SWITCH),
RNC_RB_SCRI_NOT_DROP_SWITCH
(RNC_RB_SCRI_NOT_DROP_SWITCH),
RRC_RECONN_SWITCH
(RRC_RECONN_SWITCH),
RRC_REPEAT_PFM_SWITCH
(RRC_REPEAT_PFM_SWITCH),
F2D_NO_RSP_RRCREL_SWITCH
(F2D_NO_RSP_RRCREL_SWITCH),
CS_SETUP_P2D_SWITCH
(CS_SETUP_P2D_SWITCH),
SYSHO_CIPHER_IE_SWITCH
(SYSHO_CIPHER_IE_SWITCH),
P2P_GTPU_NOT_CFG_SWITCH
(P2P_GTPU_NOT_CFG_SWITCH),
RB_SETUP_CIPHER_TIME_ADJ_SWITCH
(RB_SETUP_CIPHER_TIME_ADJ_SWITCH),
CS_PRI_MOD_NOT_INT_SWITCH
(CS_PRI_MOD_NOT_INT_SWITCH),
RAB_SETUP_TMSI_REALLOC_BUF_SWITCH
(RAB_SETUP_TMSI_REALLOC_BUF_SWITCH),
IU_FAULT_REL_PS_RES_SWITCH
(IU_FAULT_REL_PS_RES_SWITCH),
RB_RECFG_RL_REEST_SWITCH
(RB_RECFG_RL_REEST_SWITCH),
F2P_DT_MSG_BUFFER_SWITCH
(F2P_DT_MSG_BUFFER_SWITCH),
SCRI_COMPATIBLE_SWITCH
(SCRI_COMPATIBLE_SWITCH),
GTPU_ERR_IND_DEF_SWITCH
(GTPU_ERR_IND_DEF_SWITCH),
(IUR_SRV_CELL_CHG_MACHS_RESET_SWITC
H), UL_INTEG_ALGO_COMPAT_SWITCH
(UL_INTEG_ALGO_COMPAT_SWITCH)
Unit: None

WCDMA RAN

nd
Actual Value Range:

PAGGING_NUM_CTRL_SWITCH,
ASU_RL_RESET_SWITCH,
MC_RL_RESET_SWITCH,
CH,
UE_CRC_COMPATIBLE_SWITCH,
RNC_P2D_DRD_SWITCH,
P2D_SWITCH,
AMR_F2D_OVERLAP_CELLUPT_SWITCH,
SRB_RESET_RL_SETUP_SWITCH,
RLFAIL_RL_SETUP_SWITCH,
CS_RL_SETUP_SWITCH,
PS_RL_SETUP_SWITCH,
UE_SRB_RESET_SWITCH,
RL_RESTORE_SWITCH,
RNC_EFD_D2F_SWITCH,
RNC_RB_SCRI_NOT_DROP_SWITCH,
RRC_RECONN_SWITCH,
RRC_REPEAT_PFM_SWITCH,
F2D_NO_RSP_RRCREL_SWITCH,
CS_SETUP_P2D_SWITCH,
SYSHO_CIPHER_IE_SWITCH,
P2P_GTPU_NOT_CFG_SWITCH,
RB_SETUP_CIPHER_TIME_ADJ_SWITCH,
CS_PRI_MOD_NOT_INT_SWITCH,
RAB_SETUP_TMSI_REALLOC_BUF_SWITCH,
IU_FAULT_REL_PS_RES_SWITCH,
RB_RECFG_RL_REEST_SWITCH,
F2P_DT_MSG_BUFFER_SWITCH,
SCRI_COMPATIBLE_SWITCH,
GTPU_ERR_IND_DEF_SWITCH,
,
UL_INTEG_ALGO_COMPAT_SWITCH
Default Value: PAGGING_NUM_CTRL_SWITCH:
0,ASU_RL_RESET_SWITCH:

WCDMA RAN

nd
0,MC_RL_RESET_SWITCH:
0,FD_PCH_REENTERSA_FORCE_RRC_REL_SWI
TCH:0,UE_CRC_COMPATIBLE_SWITCH:
0,RNC_P2D_DRD_SWITCH:0,P2D_SWITCH:
0,AMR_F2D_OVERLAP_CELLUPT_SWITCH:
0,SRB_RESET_RL_SETUP_SWITCH:
0,RLFAIL_RL_SETUP_SWITCH:
0,CS_RL_SETUP_SWITCH:
0,PS_RL_SETUP_SWITCH:
0,UE_SRB_RESET_SWITCH:
0,RL_RESTORE_SWITCH:
0,RNC_EFD_D2F_SWITCH:
1,RNC_RB_SCRI_NOT_DROP_SWITCH:
0,RRC_RECONN_SWITCH:
0,RRC_REPEAT_PFM_SWITCH:
1,F2D_NO_RSP_RRCREL_SWITCH:
0,CS_SETUP_P2D_SWITCH:
0,SYSHO_CIPHER_IE_SWITCH:
0,P2P_GTPU_NOT_CFG_SWITCH:
1,RB_SETUP_CIPHER_TIME_ADJ_SWITCH:
1,CS_PRI_MOD_NOT_INT_SWITCH:
0,RAB_SETUP_TMSI_REALLOC_BUF_SWITCH:
0,IU_FAULT_REL_PS_RES_SWITCH:
0,RB_RECFG_RL_REEST_SWITCH:
0,F2P_DT_MSG_BUFFER_SWITCH:
0,SCRI_COMPATIBLE_SWITCH:
0,GTPU_ERR_IND_DEF_SWITCH:
0,IUR_SRV_CELL_CHG_MACHS_RESET_SWITC
H:1,UL_INTEG_ALGO_COMPAT_SWITCH:0

WCDMA RAN

nd
PROCE BSC690 SET WRFD- SRVCC Meaning:

SSSWIT 0 URRCT 150215 from 1) LOAD_IRAT_HO_RNC_FILL_TL (Cell Load
CH2 RLSWI WRFD- LTE to Information TL Input Switch)
TCH 010101 UMTS
with PS During inter-RAT handovers from 3G cells to 2G cells,
WRFD- Handov the RNC can records information about load on 3G cells
160103 er in the RELOCATION REQUIRED container in the Tag
WRFD- Length Value (TLV) format.
3GPP
030011 R9 1: This switch is turned on. The RNC records the Tag
WRFD- Specific Length in the container.
020500 ations 0: This switch is turned off. The RNC does not record
WRFD- Termina the Tag Length.
140224 l Black 2) SEND_IDT_JUDGE_IU_RESET (Switch for
WRFD- List Transferring INITIAL UE Messages in the IU Reset
160271 MIMO State)
WRFD- Prime 1: This switch is turned on. The RNC discards the
020400 Enhance INITIAL UE message from a CN node if the Iu interface
d Fast is in the reset state.
WRFD-
140205 Dorman 0: This switch is turned off. The RNC handles the
cy INITIAL UE message from a CN node if the Iu interface
Fast CS is in the reset state.
Fallback 3)
Based RNC_RBRECFG_DRD_FAIL_ROLLBACK_SWIT
on RIM CH (RB Reconfiguration DRD Rollback Switch)
Ultra- 1: This switch is turned on. The RNC supports rollback
Flash caused by failed directed retry decisions (DRDs) of RB
CSFB reconfiguration.
DRD 0: This switch is turned off. The RNC does not support
Introduc rollback caused by failed DRDs of RB reconfiguration.
tion 4) RNC_CS_QUERY_UE_IMEI_SWITCH (CS IMEI
Package Request Switch)
Voice 1: This switch is turned on. The RNC rather than the CN
Service sends an IDENTITY REQUEST message to obtain the
Experie international mobile equipment identity (IMEI) of a UE.
nce Note: When the CN checks the serial number of direct
Improve transfer messages and the
ment for SEND_MSG_NULL_SWITCH switch is turned off,
Weak turning on this switch leads to inconsistency in the serial
Receptio number of direct transfer messages between the CN and
n Ues the UE. This causes CS service setup failures.
Therefore, you are not advised to turn on this switch.
Before turning on this switch, test the interworking
between the RNC and the CN. If the CN checks the
serial number of direct transfer messages, turn on

WCDMA RAN

nd
SEND_MSG_NULL_SWITCH under
"PROCESSSWITCH4" in the "SET
URRCTRLSWITCH" command.
0: This switch is turned off. The RNC does not send an
IDENTITY REQUEST message to obtain the IMEI of
a UE.
5) RNC_PS_QUERY_UE_IMEI_SWITCH (PS IMEI
Request Switch)
1: This switch is turned on. The RNC, rather than the
CN, sends an IDENTITY REQUEST message to obtain
the IMEI of a UE.
a UE.
6) FACH_DTCH_CONGEST_P2D (P2D Switch for
Congested FACH or DTCH)
1: This switch is turned on. The DCH resources may be
congested, thereby decreasing the access success rate.
0: This switch is turned off. UEs using PS services do
not trigger the P2D procedure on a congested FACH or
DTCH.
7)
RNC_RBSETUP_DRD_FAIL_ROLLBACK_SWITC
H (RB Establishment DRD Rollback Switch)
1: This switch is turned on. The RNC supports rollback
caused by failed DRDs of RB establishment.
0: This switch is turned off. The RNC does not support
rollback caused by failed DRDs of RB establishment.
However, the RNC cannot control the scenario where
the RB fast setup function is used for RB establishment
accompanied by DRDs.
8) PS_NOTIFYCN_NOTDOWNSIZE_SWITCH
(Switch for Not Triggering Rate Reduction Negotiation
Between the CN and the RNC After a PS Service Access
Failure)
1: This switch is turned on. The access rate is not
negotiated between the RNC and the CN if a PS service
fails to be admitted.
0: This switch is turned off. The access rate is negotiated
between the RNC and the CN if a PS service fails to be
admitted.

WCDMA RAN

nd
9) ASU_RSP_TIMEOUT_HANDLE_SWITCH
(Switch for Performing the Optimized Soft-Handover
Timeout Procedure)
1: This switch is turned on. The RNC considers that it
has received an ACTIVE SET UPDATE COMPLETE
message during soft handover procedure after the
message has expired.
0: This switch is turned off. RABs are directly released
during soft handover procedure after the ACTIVE SET
UPDATE COMPLETE message has expired.
10) RB_RECFG_USER_INACT_SWITCH (Switch
for Performing the Optimized RRC Connection Release
Procedure with No Data Transmitted on the UE upon
UE State Transition Timeout)
1: This switch is turned on. The RNC initiated the
release process with the cause of user inactive when the
UE have no data to transmit.
0: This switch is turned off. The RNC initiated the
release process with other causes when the UE have no
data to transmit.
11) RRC_SCRI_NORM_REL_SWITCH (Switch for
Performing the Optimized RRC Connection Release
Procedure on Receipt of a SIGNALLING
CONNECTION RELEASE INDICATION Message)
normal release process after receive SIGNALLING
CONNECTION RELEASE INDICATION message
from UE.
0: This switch is turned off. The RNC does not handle
SIGNALLING CONNECTION RELEASE
INDICATION message during the process.
12)
CELLUPT_RLFAILURE_SRBREESTAB_SWITCH
(Switch for SRB Reestablishment During a Cell Update
with the Cause Value of RL Failure)
1: This switch is turned on. SRBs are reestablished
during cell update procedure with the "RL Failure"
cause value.
0: This switch is turned off. SRBs are not reestablished
cause value.

WCDMA RAN

nd
13) CU_OVERLAP_DSCR_SWITCH (Switch for

Performing the Optimized Procedure for Concurrent
RB and Cell Update, Hard handover, or DRD)
1: This switch is turned on. The DSCR procedure is
performed if RNC can not handles different processes
performed simultaneously.
0: This switch is turned off. The DSCR procedure is not
performed in this scenes.
14) TRB_RST_DSCR_SWITCH (Switch for
Performing the Optimized TRB Reset Procedure for PS
BE Services)
performed if a Layer 2 data transmission error occurs.
15) RNC_FD_SCRI_FORCE_REL_SWITCH
(Signaling Connection Release Switch for UEs
Supporting Fast Dormancy)
1: This switch is turned on. If the RNC receives a
SIGNALING CONNECTION RELEASE
INDICATION from UE with the cause of "UE
Requested PS Data session end", the RNC triggers the
state transition for the UE. Otherwise, the RNC releases
the signaling connection.
0: This switch is turned off. If the RNC receives a
INDICATION from UE, the RNC triggers the state
transition for the UE.
16) FP_IUUP_TRACE_SWITCH (Switch for Tracing
UEs Failing in FP Synchronization)
1: This switch is turned on. UEs using FP can be traced
in terms of data streams.
0: This switch is turned off. UEs using FP cannot be
traced in terms of data streams.
17) RNC_PCHR_OUTPUT_CTRL_SWITCH (Switch
for Reducing PCHR Log Information for Normal
Procedure)
The switch RNC_PCHR_OUTPUT_CTRL_SWITCH
controls whether the RNC reduces information recorded
in a PCHR log for a normal procedure.
1: This switch is turned on. The RNC reduces
information in a performance call history record

WCDMA RAN

nd
(PCHR) log recorded during a normal procedure and

reports only the following information blocks:
-CONN_SETUP(Connection Block)
-RRC_RELEASE(RRC Release Block)
-CS_RAB_SETUP(CS RAB Setup Block)
-PS_RAB_SETUP(PS RAB Setup Block)
-CS_RAB_REL(CS RAB Release Block)
-PS_RAB_REL(PS RAB Release Block)
-SHO(Soft Handover Block)
-SYS_HO_OUT(Inter-RAT Handover Block)
-INTRA_FREQ_NET_OPT(Intra-Frequency Missing
Neighboring Cell Block)
-STAT(Statistical Block)
-CS_RAB_QUALITY_STAT(CS RAB Quality
Statistical Block)
-PS_RAB_QUALITY_STAT(PS RAB Quality
Statistical Block)
-CS_SETUP_DIRECT_STAT(CS Setup Direct
Transfer Message Statistical Block)
-PS_SETUP_DIRECT_STAT(PS Setup Direct
A procedure is abnormal only when either of the
following conditions is met:
-The RRC connection setup fails.
-The RAB setup fails.
-The RAB is abnormally released.
-The value of the information element (IE) NAS-PDU
contained in a DIRECT TRANSFER message is
ATTACH REJECT, RAU REJECT, or LAU REJECT.
0: This switch is turned off. The RNC does not reduce
information recorded in a PCHR log.
18) DTMF_SWITCH (DTMF Switch)
1: When this switch is turned on, the RNC triggers hyper
frame number (HFN) modification, noise pouring, and
Iu-UP loopback functions by direct transfer messages
from a UE.
0: When this switch is turned off, the RNC does not
trigger HFN modification, noise pouring, or Iu-UP
loopback functions by direct transfer messages from a
UE.

WCDMA RAN

nd
19) FAST_CS_FB_BASEDON_RIM_SWITCH
(Switch for fast CSFB based on RIM)
1: This switch is turned on. The RNC supports fast
CSFB(CS fallback) based on RIM.
fast CSFB(CS fallback) based on RIM.
20) L2U_SRVCC_WITH_PS_HO_SWITCH
Whether to support LTE-to-UMTS CS and PS
handovers simultaneously.
1: This switch is turned on. LTE-to-UMTS CS and PS
handovers can happen simultaneously.
0: This switch is turned off. LTE-to-UMTS CS and PS
handovers cannot happen simultaneously.
21)ULTRA_FLASH_CSFB_SWITCH(Ultra-Flash
CSFB Function Switch)
Whether the Ultra-Flash CSFB function takes effect.
1: This switch is turned on. The RNC supports the Ultra-
Flash CSFB function, and the delay of CSFB is reduced,
improving user experience.
the Ultra-Flash CSFB function, and the delay of CSFB
is long, affecting user experience.
22)RNC_PS_QUERY_UE_IMEISV_SWITCH
(Support RNC PS Querying UE IMEISV)
Whether the RNC sends an Identity Request message to
the UE, requesting the UE's international mobile station
equipment identity and software version (IMEISV).
1: This switch is set to on. The RNC sends an Identity
Request message to the UE, requesting the UE's
IMEISV.
0: This switch is set to off. The RNC does not send an
Identity Request message to the UE.
If this switch is enabled together with the
RNC_PS_QUERY_UE_IMEI_SWITCH, the RNC
queries the UE's IMEISV, not IMEI.
GUI Value Range:
LOAD_IRAT_HO_RNC_FILL_TL,
SEND_IDT_JUDGE_IU_RESET,
RNC_RBRECFG_DRD_FAIL_ROLLBACK_SWIT
CH, RNC_CS_QUERY_UE_IMEI_SWITCH,
RNC_PS_QUERY_UE_IMEI_SWITCH,
FACH_DTCH_CONGEST_P2D,

WCDMA RAN

nd
H, PS_NOTIFYCN_NOTDOWNSIZE_SWITCH,
ASU_RSP_TIMEOUT_HANDLE_SWITCH,
RB_RECFG_USER_INACT_SWITCH,
RRC_SCRI_NORM_REL_SWITCH,
CELLUPT_RLFAILURE_SRBREESTAB_SWITCH,
CU_OVERLAP_DSCR_SWITCH,
TRB_RST_DSCR_SWITCH,
RNC_FD_SCRI_FORCE_REL_SWITCH,
FP_IUUP_TRACE_SWITCH,
RNC_PCHR_OUTPUT_CTRL_SWITCH,
DTMF_SWITCH,
FAST_CS_FB_BASEDON_RIM_SWITCH,
L2U_SRVCC_WITH_PS_HO_SWITCH,
ULTRA_FLASH_CSFB_SWITCH,
RNC_PS_QUERY_UE_IMEISV_SWITCH
Unit: None
Actual Value Range:
DTMF_SWITCH,
Default Value: LOAD_IRAT_HO_RNC_FILL_TL:
0,SEND_IDT_JUDGE_IU_RESET:
0,RNC_RBRECFG_DRD_FAIL_ROLLBACK_SWI
TCH:1,RNC_CS_QUERY_UE_IMEI_SWITCH:
0,RNC_PS_QUERY_UE_IMEI_SWITCH:

WCDMA RAN

nd
0,FACH_DTCH_CONGEST_P2D:
0,RNC_RBSETUP_DRD_FAIL_ROLLBACK_SWIT
CH:0,PS_NOTIFYCN_NOTDOWNSIZE_SWITCH:
0,ASU_RSP_TIMEOUT_HANDLE_SWITCH:
0,RB_RECFG_USER_INACT_SWITCH:
0,RRC_SCRI_NORM_REL_SWITCH:
0,CELLUPT_RLFAILURE_SRBREESTAB_SWITC
H:0,CU_OVERLAP_DSCR_SWITCH:
0,TRB_RST_DSCR_SWITCH:
0,RNC_FD_SCRI_FORCE_REL_SWITCH:
0,FP_IUUP_TRACE_SWITCH:
1,RNC_PCHR_OUTPUT_CTRL_SWITCH:
1,DTMF_SWITCH:
1,FAST_CS_FB_BASEDON_RIM_SWITCH:
0,L2U_SRVCC_WITH_PS_HO_SWITCH:
0,ULTRA_FLASH_CSFB_SWITCH:
0,RNC_PS_QUERY_UE_IMEISV_SWITCH:0

WCDMA RAN

nd
PROCE BSC691 SET WRFD- SRVCC Meaning:

SSSWIT 0 URRCT 150215 from 1) LOAD_IRAT_HO_RNC_FILL_TL (Cell Load
CH2 RLSWI WRFD- LTE to Information TL Input Switch)
TCH 010101 UMTS
with PS During inter-RAT handovers from 3G cells to 2G cells,
WRFD- Handov the RNC can records information about load on 3G cells
160103 er in the RELOCATION REQUIRED container in the Tag
WRFD- Length Value (TLV) format.
3GPP
030011 R9 1: This switch is turned on. The RNC records the Tag
WRFD- Specific Length in the container.
020500 ations 0: This switch is turned off. The RNC does not record
WRFD- Termina the Tag Length.
140224 l Black 2) SEND_IDT_JUDGE_IU_RESET (Switch for
WRFD- List Transferring INITIAL UE Messages in the IU Reset
160271 MIMO State)
WRFD- Prime 1: This switch is turned on. The RNC discards the
020400 Enhance INITIAL UE message from a CN node if the Iu interface
d Fast is in the reset state.
WRFD-
140205 Dorman 0: This switch is turned off. The RNC handles the
cy INITIAL UE message from a CN node if the Iu interface
Fast CS is in the reset state.
Fallback 3)
Based RNC_RBRECFG_DRD_FAIL_ROLLBACK_SWIT
on RIM CH (RB Reconfiguration DRD Rollback Switch)
Ultra- 1: This switch is turned on. The RNC supports rollback
Flash caused by failed directed retry decisions (DRDs) of RB
CSFB reconfiguration.
DRD 0: This switch is turned off. The RNC does not support
Introduc rollback caused by failed DRDs of RB reconfiguration.
tion 4) RNC_CS_QUERY_UE_IMEI_SWITCH (CS IMEI
Package Request Switch)
Voice 1: This switch is turned on. The RNC rather than the CN
Service sends an IDENTITY REQUEST message to obtain the
Experie international mobile equipment identity (IMEI) of a UE.
nce Note: When the CN checks the serial number of direct
Improve transfer messages and the
ment for SEND_MSG_NULL_SWITCH switch is turned off,
Weak turning on this switch leads to inconsistency in the serial
Receptio number of direct transfer messages between the CN and
n Ues the UE. This causes CS service setup failures.
Therefore, you are not advised to turn on this switch.
Before turning on this switch, test the interworking
between the RNC and the CN. If the CN checks the
serial number of direct transfer messages, turn on

WCDMA RAN

nd
SEND_MSG_NULL_SWITCH under
"PROCESSSWITCH4" in the "SET
URRCTRLSWITCH" command.
a UE.
5) RNC_PS_QUERY_UE_IMEI_SWITCH (PS IMEI
Request Switch)
1: This switch is turned on. The RNC, rather than the
CN, sends an IDENTITY REQUEST message to obtain
the IMEI of a UE.
a UE.
6) FACH_DTCH_CONGEST_P2D (P2D Switch for
Congested FACH or DTCH)
1: This switch is turned on. The DCH resources may be
congested, thereby decreasing the access success rate.
0: This switch is turned off. UEs using PS services do
not trigger the P2D procedure on a congested FACH or
DTCH.
7)
H (RB Establishment DRD Rollback Switch)
1: This switch is turned on. The RNC supports rollback
caused by failed DRDs of RB establishment.
rollback caused by failed DRDs of RB establishment.
However, the RNC cannot control the scenario where
the RB fast setup function is used for RB establishment
accompanied by DRDs.
8) PS_NOTIFYCN_NOTDOWNSIZE_SWITCH
(Switch for Not Triggering Rate Reduction Negotiation
Between the CN and the RNC After a PS Service Access
Failure)
1: This switch is turned on. The access rate is not
negotiated between the RNC and the CN if a PS service
fails to be admitted.
0: This switch is turned off. The access rate is negotiated
between the RNC and the CN if a PS service fails to be
admitted.

WCDMA RAN

nd
9) ASU_RSP_TIMEOUT_HANDLE_SWITCH
(Switch for Performing the Optimized Soft-Handover
Timeout Procedure)
1: This switch is turned on. The RNC considers that it
has received an ACTIVE SET UPDATE COMPLETE
message during soft handover procedure after the
message has expired.
0: This switch is turned off. RABs are directly released
during soft handover procedure after the ACTIVE SET
UPDATE COMPLETE message has expired.
10) RB_RECFG_USER_INACT_SWITCH (Switch
for Performing the Optimized RRC Connection Release
Procedure with No Data Transmitted on the UE upon
UE State Transition Timeout)
release process with the cause of user inactive when the
UE have no data to transmit.
0: This switch is turned off. The RNC initiated the
release process with other causes when the UE have no
data to transmit.
11) RRC_SCRI_NORM_REL_SWITCH (Switch for
Performing the Optimized RRC Connection Release
Procedure on Receipt of a SIGNALLING
CONNECTION RELEASE INDICATION Message)
normal release process after receive SIGNALLING
CONNECTION RELEASE INDICATION message
from UE.
0: This switch is turned off. The RNC does not handle
SIGNALLING CONNECTION RELEASE
INDICATION message during the process.
12)
CELLUPT_RLFAILURE_SRBREESTAB_SWITCH
(Switch for SRB Reestablishment During a Cell Update
with the Cause Value of RL Failure)
1: This switch is turned on. SRBs are reestablished
cause value.
0: This switch is turned off. SRBs are not reestablished
cause value.

WCDMA RAN

nd
13) CU_OVERLAP_DSCR_SWITCH (Switch for

Performing the Optimized Procedure for Concurrent
RB and Cell Update, Hard handover, or DRD)
performed if RNC can not handles different processes
performed simultaneously.
performed in this scenes.
14) TRB_RST_DSCR_SWITCH (Switch for
Performing the Optimized TRB Reset Procedure for PS
BE Services)
15) RNC_FD_SCRI_FORCE_REL_SWITCH
(Signaling Connection Release Switch for UEs
Supporting Fast Dormancy)
1: This switch is turned on. If the RNC receives a
INDICATION from UE with the cause of "UE
Requested PS Data session end", the RNC triggers the
state transition for the UE. Otherwise, the RNC releases
the signaling connection.
0: This switch is turned off. If the RNC receives a
INDICATION from UE, the RNC triggers the state
transition for the UE.
16) FP_IUUP_TRACE_SWITCH (Switch for Tracing
UEs Failing in FP Synchronization)
1: This switch is turned on. UEs using FP can be traced
in terms of data streams.
0: This switch is turned off. UEs using FP cannot be
traced in terms of data streams.
17) RNC_PCHR_OUTPUT_CTRL_SWITCH (Switch
for Reducing PCHR Log Information for Normal
Procedure)
The switch RNC_PCHR_OUTPUT_CTRL_SWITCH
controls whether the RNC reduces information recorded
in a PCHR log for a normal procedure.
1: This switch is turned on. The RNC reduces
information in a performance call history record

WCDMA RAN

nd
(PCHR) log recorded during a normal procedure and

reports only the following information blocks:
-CONN_SETUP(Connection Block)
-RRC_RELEASE(RRC Release Block)
-CS_RAB_SETUP(CS RAB Setup Block)
-PS_RAB_SETUP(PS RAB Setup Block)
-CS_RAB_REL(CS RAB Release Block)
-PS_RAB_REL(PS RAB Release Block)
-SHO(Soft Handover Block)
-SYS_HO_OUT(Inter-RAT Handover Block)
-INTRA_FREQ_NET_OPT(Intra-Frequency Missing
Neighboring Cell Block)
-STAT(Statistical Block)
-CS_RAB_QUALITY_STAT(CS RAB Quality
Statistical Block)
-PS_RAB_QUALITY_STAT(PS RAB Quality
Statistical Block)
-CS_SETUP_DIRECT_STAT(CS Setup Direct
-PS_SETUP_DIRECT_STAT(PS Setup Direct
A procedure is abnormal only when either of the
following conditions is met:
-The RRC connection setup fails.
-The RAB setup fails.
-The RAB is abnormally released.
-The value of the information element (IE) NAS-PDU
contained in a DIRECT TRANSFER message is
ATTACH REJECT, RAU REJECT, or LAU REJECT.
0: This switch is turned off. The RNC does not reduce
information recorded in a PCHR log.
18) DTMF_SWITCH (DTMF Switch)
1: When this switch is turned on, the RNC triggers hyper
frame number (HFN) modification, noise pouring, and
Iu-UP loopback functions by direct transfer messages
from a UE.
0: When this switch is turned off, the RNC does not
trigger HFN modification, noise pouring, or Iu-UP
loopback functions by direct transfer messages from a
UE.

WCDMA RAN

nd
19) FAST_CS_FB_BASEDON_RIM_SWITCH
(Switch for fast CSFB based on RIM)
1: This switch is turned on. The RNC supports fast
CSFB(CS fallback) based on RIM.
fast CSFB(CS fallback) based on RIM.
20) L2U_SRVCC_WITH_PS_HO_SWITCH
Whether to support LTE-to-UMTS CS and PS
handovers simultaneously.
1: This switch is turned on. LTE-to-UMTS CS and PS
handovers can happen simultaneously.
0: This switch is turned off. LTE-to-UMTS CS and PS
handovers cannot happen simultaneously.
21)ULTRA_FLASH_CSFB_SWITCH(Ultra-Flash
CSFB Function Switch)
Whether the Ultra-Flash CSFB function takes effect.
1: This switch is turned on. The RNC supports the Ultra-
Flash CSFB function, and the delay of CSFB is reduced,
improving user experience.
the Ultra-Flash CSFB function, and the delay of CSFB
is long, affecting user experience.
22)RNC_PS_QUERY_UE_IMEISV_SWITCH
(Support RNC PS Querying UE IMEISV)
Whether the RNC sends an Identity Request message to
the UE, requesting the UE's international mobile station
equipment identity and software version (IMEISV).
1: This switch is set to on. The RNC sends an Identity
Request message to the UE, requesting the UE's
IMEISV.
0: This switch is set to off. The RNC does not send an
Identity Request message to the UE.
If this switch is enabled together with the
RNC_PS_QUERY_UE_IMEI_SWITCH, the RNC
queries the UE's IMEISV, not IMEI.
GUI Value Range:

WCDMA RAN

nd
DTMF_SWITCH,
Unit: None
Actual Value Range:
DTMF_SWITCH,
Default Value: LOAD_IRAT_HO_RNC_FILL_TL:
0,SEND_IDT_JUDGE_IU_RESET:
0,RNC_RBRECFG_DRD_FAIL_ROLLBACK_SWI
TCH:1,RNC_CS_QUERY_UE_IMEI_SWITCH:
0,RNC_PS_QUERY_UE_IMEI_SWITCH:

WCDMA RAN

nd
0,FACH_DTCH_CONGEST_P2D:
0,RNC_RBSETUP_DRD_FAIL_ROLLBACK_SWIT
CH:0,PS_NOTIFYCN_NOTDOWNSIZE_SWITCH:
0,ASU_RSP_TIMEOUT_HANDLE_SWITCH:
0,RB_RECFG_USER_INACT_SWITCH:
0,RRC_SCRI_NORM_REL_SWITCH:
0,CELLUPT_RLFAILURE_SRBREESTAB_SWITC
H:0,CU_OVERLAP_DSCR_SWITCH:
0,TRB_RST_DSCR_SWITCH:
0,RNC_FD_SCRI_FORCE_REL_SWITCH:
0,FP_IUUP_TRACE_SWITCH:
1,RNC_PCHR_OUTPUT_CTRL_SWITCH:
1,DTMF_SWITCH:
1,FAST_CS_FB_BASEDON_RIM_SWITCH:
0,L2U_SRVCC_WITH_PS_HO_SWITCH:
0,ULTRA_FLASH_CSFB_SWITCH:
0,RNC_PS_QUERY_UE_IMEISV_SWITCH:0
DlLdrTr BSC690 ADD WRFD- Load Meaning: Threshold for triggering downlink LDR. If
igThd 0 UCELL 020102 Measure the ratio of the downlink load to the downlink capacity
LDM WRFD- ment is higher than or equal to this threshold for a duration
MOD 020103 Inter longer than that specified by the "DlLdTrnsHysTime"
UCELL Frequen parameter, downlink LDR (preliminary congestion
WRFD- state) is triggered and LDR actions are performed to
LDM 020117 cy Load
Balance reduce the cell load. The recommended value difference
WRFD- between "DlLdrRelThd" and "DlLdrTrigThd" is higher
020106 Multi- than 10% because the load fluctuates. Otherwise, a cell
Carrier frequently enters and leaves the preliminary congestion
WRFD- Switch
020122 state.
off
Based GUI Value Range: 0~100
on Unit: %
Traffic Actual Value Range: 0~100
Load
Default Value: 70
Load
Reshuffl
ing
Multi-
Carrier
Switch
off
Based
on QoS

WCDMA RAN

nd
DlLdrTr BSC691 ADD WRFD- Load Meaning: Threshold for triggering downlink LDR. If
igThd 0 UCELL 020102 Measure the ratio of the downlink load to the downlink capacity
LDM WRFD- ment is higher than or equal to this threshold for a duration
MOD 020103 Inter longer than that specified by the "DlLdTrnsHysTime"
UCELL Frequen parameter, downlink LDR (preliminary congestion
WRFD- state) is triggered and LDR actions are performed to
LDM 020117 cy Load
Balance reduce the cell load. The recommended value difference
WRFD- between "DlLdrRelThd" and "DlLdrTrigThd" is higher
020106 Multi- than 10% because the load fluctuates. Otherwise, a cell
Carrier frequently enters and leaves the preliminary congestion
WRFD- Switch
020122 state.
off
on Unit: %
Traffic Actual Value Range: 0~100
Load
Default Value: 70
Load
Reshuffl
ing
Multi-
Carrier
Switch
off
Based
on QoS

WCDMA RAN

nd
DefaultS BSC690 SET WRFD- Quality Meaning: This parameter is used to specify SPI Weight
PIWeigh 0 UFRC 020128 Improve when the licence for SPI Weight-based differentiated
t WRFD- ment for services is disabled.
020133 Subscrib GUI Value Range: 1~100
ed
WRFD- Service Unit: %
020806 Actual Value Range: 1~100
P2P
WRFD- Downlo Default Value: 100
150204 ading
Rate
Control
during
Busy
Hour
Differen
tiated
Service
Based
on SPI
Weight
Platinu
m User
Prioritizi
ng

WCDMA RAN

nd
DefaultS BSC691 SET WRFD- Quality Meaning: This parameter is used to specify SPI Weight
PIWeigh 0 UFRC 020128 Improve when the licence for SPI Weight-based differentiated
t WRFD- ment for services is disabled.
020133 Subscrib GUI Value Range: 1~100
ed
WRFD- Service Unit: %
020806 Actual Value Range: 1~100
P2P
WRFD- Downlo Default Value: 100
150204 ading
Rate
Control
during
Busy
Hour
Differen
tiated
Service
Based
on SPI
Weight
Platinu
m User
Prioritizi
ng
SpiWeig BSC690 SET WRFD- Scheduli Meaning: Weight for service scheduling priority. This
ht 0 USPIW 0106110 ng based weight is used in two algorithms. In scheduling
EIGHT 3 on EPF algorithm, it is used to adjust the handling priority for
WRFD- and different services. In Iub congestion algorithm, it is used
020806 GBR to allocate bandwidth for different services. If the
Differen weight is higher, it is more possible to increase the
WRFD- handling priority of the user or get more Iub bandwidth,
150204 tiated
Service respectively.
on SPI Unit: %
Weight
Platinu
m User Default Value: 100
Prioritizi
ng

WCDMA RAN

nd
SpiWeig BSC691 SET WRFD- Scheduli Meaning: Weight for service scheduling priority. This
ht 0 USPIW 0106110 ng based weight is used in two algorithms. In scheduling
EIGHT 3 on EPF algorithm, it is used to adjust the handling priority for
WRFD- and different services. In Iub congestion algorithm, it is used
020806 GBR to allocate bandwidth for different services. If the
Differen weight is higher, it is more possible to increase the
WRFD- handling priority of the user or get more Iub bandwidth,
150204 tiated
Service respectively.
on SPI Unit: %
Weight
Platinu
m User Default Value: 100
Prioritizi
ng

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 12 Counters
12 Counters
Table 12-1 Counters
Counter ID Counter Name Counter NE Feature ID Feature Name

Description
67179299 RRC.SuccConn Number of BSC6900 WRFD-010510 3.4/6.8/13.6/27.

Estab.sum Successful RRC 2Kbps RRC
Connection Connection and
Setups for Cell Radio Access
Bearer
Establishment
and Release

Estab.sum Successful RRC 2Kbps RRC
Bearer
Establishment
and Release
67179329 RRC.AttConnE Number of RRC BSC6900 WRFD-010510 3.4/6.8/13.6/27.

stab.OrgConvC Connection WRFD-010501 2Kbps RRC
all Requests for Connection and
Cell Radio Access
(Originating Bearer
Conversational Establishment
Call) and Release
Conversational
QoS Class

WCDMA RAN

Description

stab.OrgConvC Connection WRFD-010501 2Kbps RRC
all Requests for Connection and
Cell Radio Access
(Originating Bearer
Call) and Release
Conversational
QoS Class

stab.TmConvCa Connection WRFD-010501 2Kbps RRC
ll Requests for Connection and
Cell Radio Access
(Terminating Bearer
Call) and Release
Conversational
QoS Class

stab.TmConvCa Connection WRFD-010501 2Kbps RRC
ll Requests for Connection and
Cell Radio Access
(Terminating Bearer
Call) and Release
Conversational
QoS Class

Estab.OrgConv- Successful RRC WRFD-010501 2Kbps RRC
Call Connection Connection and
(Originating Bearer
Call) and Release
Conversational
QoS Class

WCDMA RAN

Description

Estab.OrgConv- Successful RRC WRFD-010501 2Kbps RRC
(Originating Bearer
Call) and Release
Conversational
QoS Class

Estab.TmConv Successful RRC WRFD-010501 2Kbps RRC
(Terminating Bearer
Call) and Release
Conversational
QoS Class

Estab.TmConv Successful RRC WRFD-010501 2Kbps RRC
(Terminating Bearer
Call) and Release
Conversational
QoS Class
67179521 VS.RRC.FailCo Number of RRC BSC6900 WRFD-010510 3.4/6.8/13.6/27.

nnEstab.Cong Connection 2Kbps RRC
Rejects Due to Connection and
Network Radio Access
Congestion for Bearer
Cell Establishment
and Release
67179521 VS.RRC.FailCo Number of RRC BSC6910 WRFD-010510 3.4/6.8/13.6/27.

nnEstab.Cong Connection 2Kbps RRC
Rejects Due to Connection and
Network Radio Access
Congestion for Bearer
Cell Establishment
and Release

WCDMA RAN

Description
67179778 VS.RAB.Abnor Number of CS BSC6900 WRFD-010510 3.4/6.8/13.6/27.

mRel.CS RABs 2Kbps RRC
Abnormally Connection and
Released for Radio Access
Cell Bearer
Establishment
and Release

mRel.CS RABs 2Kbps RRC
Cell Bearer
Establishment
and Release
67179779 VS.RAB.Norm Number of CS BSC6900 WRFD-010510 3.4/6.8/13.6/27.

Rel.CS RABs Normally 2Kbps RRC
Released for Connection and
Cell Radio Access
Bearer
Establishment
and Release
67179779 VS.RAB.Norm Number of CS BSC6910 WRFD-010510 3.4/6.8/13.6/27.

Rel.CS RABs Normally 2Kbps RRC
Cell Radio Access
Bearer
Establishment
and Release
67179781 VS.RAB.Abnor Number of PS BSC6900 WRFD-010510 3.4/6.8/13.6/27.

mRel.PS RABs 2Kbps RRC
Cell Bearer
Establishment
and Release

mRel.PS RABs 2Kbps RRC
Cell Bearer
Establishment
and Release

WCDMA RAN

Description
67179782 VS.RAB.Norm Number of PS BSC6900 WRFD-010510 3.4/6.8/13.6/27.

Rel.PS RABs Normally 2Kbps RRC
Cell Radio Access
Bearer
Establishment
and Release
67179782 VS.RAB.Norm Number of PS BSC6910 WRFD-010510 3.4/6.8/13.6/27.

Rel.PS RABs Normally 2Kbps RRC
Cell Radio Access
Bearer
Establishment
and Release
67179825 VS.RAB.AttEst Number of CS BSC6900 WRFD-010501 Conversational

abCS.Conv Conversational QoS Class
RAB
Establishment
Requests for
Cell
67179825 VS.RAB.AttEst Number of CS BSC6910 WRFD-010501 Conversational

abCS.Conv Conversational QoS Class
RAB
Establishment
Requests for
Cell
67179826 VS.RAB.AttEst Number of CS BSC6900 WRFD-010502 Streaming QoS

abCS.Str Streaming RAB Class
Establishment
Requests for
Cell
67179826 VS.RAB.AttEst Number of CS BSC6910 WRFD-010502 Streaming QoS

abCS.Str Streaming RAB Class
Establishment
Requests for
Cell
67179827 VS.RAB.SuccE Number of BSC6900 WRFD-010501 Conversational

stabCS.Conv Successful CS WRFD-171202 QoS Class
Conversational Ultrafast CS
RAB Call Setup
Establishments
for Cell

WCDMA RAN

Description

stabCS.Conv Successful CS WRFD-171202 QoS Class
Conversational Ultrafast CS
RAB Call Setup
Establishments
for Cell
67179828 VS.RAB.SuccE Number of BSC6900 WRFD-010502 Streaming QoS

stabCS.Str Successful CS Class
Streaming RAB
Establishments
for Cell

stabCS.Str Successful CS Class
Streaming RAB
Establishments
for Cell
67179921 VS.RAB.AttEst Number of PS BSC6900 WRFD-010501 Conversational

abPS.Conv Conversational QoS Class
RAB
Establishment
Attempts for
Cell
67179921 VS.RAB.AttEst Number of PS BSC6910 WRFD-010501 Conversational

abPS.Conv Conversational QoS Class
RAB
Establishment
Attempts for
Cell
67179922 VS.RAB.AttEst Number of PS BSC6900 WRFD-010502 Streaming QoS

abPS.Str Streaming RAB Class
Establishment
Attempts for
Cell
67179922 VS.RAB.AttEst Number of PS BSC6910 WRFD-010502 Streaming QoS

abPS.Str Streaming RAB Class
Establishment
Attempts for
Cell
67179923 VS.RAB.AttEst Number of PS BSC6900 WRFD-010503 Interactive QoS

abPS.Int Interactive RAB Class
Establishment
Attempts for
Cell

WCDMA RAN

Description
67179923 VS.RAB.AttEst Number of PS BSC6910 WRFD-010503 Interactive QoS

abPS.Int Interactive RAB Class
Establishment
Attempts for
Cell
67179924 VS.RAB.AttEst Number of PS BSC6900 WRFD-010504 Background

abPS.Bkg Background QoS Class
RAB
Establishment
Attempts for
Cell
67179924 VS.RAB.AttEst Number of PS BSC6910 WRFD-010504 Background

abPS.Bkg Background QoS Class
RAB
Establishment
Attempts for
Cell

stabPS.Conv Successful PS QoS Class
Conversational
RAB
Establishments
for Cell

stabPS.Conv Successful PS QoS Class
Conversational
RAB
Establishments
for Cell

stabPS.Str Successful PS Class
Streaming RAB
Establishments
for Cell

stabPS.Str Successful PS Class
Streaming RAB
Establishments
for Cell

WCDMA RAN

Description
67179927 VS.RAB.SuccE Number of BSC6900 WRFD-010503 Interactive QoS

stabPS.Int Successful PS Class
Interactive RAB
Establishments
for Cell
67179927 VS.RAB.SuccE Number of BSC6910 WRFD-010503 Interactive QoS

stabPS.Int Successful PS Class
Interactive RAB
Establishments
for Cell
67179928 VS.RAB.SuccE Number of BSC6900 WRFD-010504 Background

stabPS.Bkg Successful PS QoS Class
Background
RAB
Establishments
for Cell
67179928 VS.RAB.SuccE Number of BSC6910 WRFD-010504 Background

stabPS.Bkg Successful PS QoS Class
Background
RAB
Establishments
for Cell

mRel.CS.Preem RAB Release WRFD-010505 2Kbps RRC
pt Attempts for Connection and
Cell (RAB Radio Access
Preemption) Bearer
Establishment
and Release
Queuing and
Pre-Emption

mRel.CS.Preem RAB Release WRFD-010505 2Kbps RRC
pt Attempts for Connection and
Cell (RAB Radio Access
Preemption) Bearer
Establishment
and Release
Queuing and
Pre-Emption

WCDMA RAN

Description

mRel.PS.Preem RAB Abnormal WRFD-010505 2Kbps RRC
pt Released Due to Connection and
RAB Radio Access
Preemption for Bearer
Cell Establishment
and Release
Queuing and
Pre-Emption

mRel.PS.Preem RAB Abnormal WRFD-010505 2Kbps RRC
pt Released Due to Connection and
RAB Radio Access
Preemption for Bearer
Cell Establishment
and Release
Queuing and
Pre-Emption
67189494 VS.RAB.FailEs Number of BSC6900 WRFD-010510 3.4/6.8/13.6/27.

tabCS.Cong Failed CS RAB 2Kbps RRC
Establishments Connection and
for Cell Radio Access
(Congestion) Bearer
Establishment
and Release

tabCS.Cong Failed CS RAB 2Kbps RRC
(Congestion) Bearer
Establishment
and Release

tabCS.RNL Failed CS RAB WRFD-171202 2Kbps RRC
for Cell (Radio Radio Access
Network Layer Bearer
Cause) Establishment
and Release
Ultrafast CS
Call Setup

WCDMA RAN

Description

tabCS.RNL Failed CS RAB WRFD-171202 2Kbps RRC
and Release
Ultrafast CS
Call Setup

tabPS.RNL Failed PS RAB 2Kbps RRC
and Release

tabPS.RNL Failed PS RAB 2Kbps RRC
and Release
67190586 VS.RRC.AttCo Number of BSC6900 WRFD-010510 3.4/6.8/13.6/27.

nnEstab.Sum Processed RRC 2Kbps RRC
Requests for Radio Access
Cell Bearer
Establishment
and Release
67190586 VS.RRC.AttCo Number of BSC6910 WRFD-010510 3.4/6.8/13.6/27.

nnEstab.Sum Processed RRC 2Kbps RRC
Requests for Radio Access
Cell Bearer
Establishment
and Release

tabPS.Cong Failed PS RAB 2Kbps RRC
(Congestion) Bearer
Establishment
and Release

WCDMA RAN

Description

tabPS.Cong Failed PS RAB 2Kbps RRC
(Congestion) Bearer
Establishment
and Release
73422072 VS.RRC.Paging Number of BSC6900 WRFD-010301 Paging UE in

1.PCHCong.CS Preemptions by Idle,
PreemptAtt CS Paging due CELL_PCH,
to PCH URA_PCH
Congestion per State (Type 1)
Cell

1.PCHCong.CS Preemptions by Idle,
PreemptAtt CS Paging due CELL_PCH,
to PCH URA_PCH
Congestion per State (Type 1)
Cell

1.PCHCong.CS Successful Idle,
PreemptSucc Preemptions by CELL_PCH,
CS Paging due URA_PCH
to PCH State (Type 1)
Congestion per
Cell

1.PCHCong.CS Successful Idle,
PreemptSucc Preemptions by CELL_PCH,
CS Paging due URA_PCH
Congestion per
Cell
73425914 RRC.AttConnE Number of RRC BSC6900 WRFD-150204 Platinum User

stab.Conv.Plati- Connection Prioritizing
num Setup Requests
for Platinum
UEs Performing
Conversational
Services for Cell

WCDMA RAN

Description

stab.Conv.Plati- Connection Prioritizing
num Setup Requests
for Platinum
UEs Performing
Conversational
Services for Cell

stab.Platinum Connection Prioritizing
Setup Requests
for Platinum
UEs Performing
Services for Cell

stab.Platinum Connection Prioritizing
Setup Requests
for Platinum
UEs Performing
Services for Cell
73425916 RRC.SuccConn Number of BSC6900 WRFD-150204 Platinum User

Estab.Conv.Plat Successful RRC Prioritizing
inum Connection
Setups for
Platinum UEs
Performing
Conversational
Services for Cell

Estab.Conv.Plat Successful RRC Prioritizing
inum Connection
Setups for
Platinum UEs
Performing
Conversational
Services for Cell

Estab.Platinum Successful RRC Prioritizing
Connection
Setups for
Platinum UEs
for Cell

WCDMA RAN

Description

Estab.Platinum Successful RRC Prioritizing
Connection
Setups for
Platinum UEs
for Cell
73425918 VS.RAB.AttEst Number of CS BSC6900 WRFD-150204 Platinum User

abCS.Platinum RAB Setup Prioritizing
Requests for
Platinum UEs
for Cell

abCS.Platinum RAB Setup Prioritizing
Requests for
Platinum UEs
for Cell
73425919 VS.RAB.SuccE Number of BSC6900 WRFD-150204 Platinum User

stabCS.Platinu Successful CS WRFD-171202 Prioritizing
m RAB Setups for Ultrafast CS
Platinum UEs Call Setup
for Cell

stabCS.Platinu Successful CS WRFD-171202 Prioritizing
m RAB Setups for Ultrafast CS
for Cell

abCS.Conv.Plat RAB Setup Prioritizing
inum Requests for
Platinum UEs
Performing
Conversational
Services for Cell

abCS.Conv.Plat RAB Setup Prioritizing
inum Requests for
Platinum UEs
Performing
Conversational
Services for Cell

WCDMA RAN

Description

stabCS.Conv.Pl Successful CS WRFD-171202 Prioritizing
atinum RAB Setups for Ultrafast CS
Performing
Conversational
Services for Cell

stabCS.Conv.Pl Successful CS WRFD-171202 Prioritizing
atinum RAB Setups for Ultrafast CS
Performing
Conversational
Services for Cell
73425922 VS.RAB.AttEst Number of PS BSC6900 WRFD-150204 Platinum User

abPS.Platinum RAB Setup Prioritizing
Requests for
Platinum UEs
for Cell

abPS.Platinum RAB Setup Prioritizing
Requests for
Platinum UEs
for Cell

stabPS.Platinum Successful PS Prioritizing
RAB Setups for
Platinum UEs
for Cell

stabPS.Platinum Successful PS Prioritizing
RAB Setups for
Platinum UEs
for Cell

abPS.Conv.Plati RAB Setup Prioritizing
num Requests for
Platinum UEs
Performing
Conversational
Services for Cell

WCDMA RAN

Description

abPS.Conv.Plati RAB Setup Prioritizing
num Requests for
Platinum UEs
Performing
Conversational
Services for Cell

stabPS.Conv.Pl Successful PS Prioritizing
atinum RAB Setups for
Platinum UEs
Performing
Conversational
Services for Cell

stabPS.Conv.Pl Successful PS Prioritizing
atinum RAB Setups for
Platinum UEs
Performing
Conversational
Services for Cell

1.PCHCong.SM Times a UE Idle,
SPreemptAtt Processing SMS CELL_PCH,
services URA_PCH
Attempts to State (Type 1)
Preempt
Resources to Be
Allocated to
Other UEs
When the PCH
Is Congested for
Cell

1.PCHCong.SM Times a UE Idle,
SPreemptAtt Processing SMS CELL_PCH,
services URA_PCH
Attempts to State (Type 1)
Preempt
Resources to Be
Allocated to
Other UEs
When the PCH
Is Congested for
Cell

WCDMA RAN

Description

1.PCHCong.SM Successful Idle,
SPreemptSucc Preemptions by CELL_PCH,
SMS Paging due URA_PCH
Congestion per
Cell

1.PCHCong.SM Successful Idle,
SPreemptSucc Preemptions by CELL_PCH,
SMS Paging due URA_PCH
Congestion per
Cell
73428759 VS.RAC.Platin Number of BSC6900 WRFD-010505 Queuing and

um.Preempt.Co Preemptions for WRFD-150204 Pre-Emption
ng Platinum User Platinum User
Prioritizing
73428759 VS.RAC.Platin Number of BSC6910 WRFD-010505 Queuing and

um.Preempt.Co Preemptions for WRFD-150204 Pre-Emption
ng Platinum User Platinum User
Prioritizing
73429470 VS.RAB.Norm Number of CS BSC6900 WRFD-150204 Platinum User

Rel.CS.Platinu RABs Normally Prioritizing
m Released for
Platinum UEs
for Cell
73429470 VS.RAB.Norm Number of CS BSC6910 WRFD-150204 Platinum User

Rel.CS.Platinu RABs Normally Prioritizing
m Released for
Platinum UEs
for Cell
73429471 VS.RAB.Abnor Number of CS BSC6900 WRFD-150204 Platinum User

mRel.CS.Platin RABs Prioritizing
um Abnormally
Released for
Platinum UEs
for Cell

WCDMA RAN

Description
73429471 VS.RAB.Abnor Number of CS BSC6910 WRFD-150204 Platinum User

mRel.CS.Platin RABs Prioritizing
um Abnormally
Released for
Platinum UEs
for Cell
73429472 VS.EVQI.AMR Total Downlink BSC6900 WRFD-150204 Platinum User

.DL.TotalValue. EVQI of AMR Prioritizing
Platinum Services for
Platinum Users
73429472 VS.EVQI.AMR Total Downlink BSC6910 WRFD-150204 Platinum User

.DL.TotalValue. EVQI of AMR Prioritizing
Platinum Users
73429473 VS.EVQI.AMR Total Uplink BSC6900 WRFD-150204 Platinum User

.UL.TotalValue. EVQI of AMR Prioritizing
Platinum Users
73429473 VS.EVQI.AMR Total Uplink BSC6910 WRFD-150204 Platinum User

.UL.TotalValue. EVQI of AMR Prioritizing
Platinum Users
73429474 VS.EVQI.AMR Number of BSC6900 WRFD-150204 Platinum User

.DL.TotalNum. Times Prioritizing
Platinum Downlink EVQI
of AMR
Services Is
Measured for
Platinum Users

.DL.TotalNum. Times Prioritizing
Platinum Downlink EVQI
of AMR
Services Is
Measured for
Platinum Users

.UL.TotalNum. Times Uplink Prioritizing
Platinum EVQI of AMR
Services Is
Measured for
Platinum Users

WCDMA RAN

Description

.UL.TotalNum. Times Uplink Prioritizing
Platinum EVQI of AMR
Services Is
Measured for
Platinum Users
73430425 VS.RRC.Paging Number of CS BSC6900 WRFD-010301 Paging UE in

1.PCHCong.CS Paging WRFD-150204 Idle,
PreemptAtt.Plat Preemption CELL_PCH,
inum Attempts URA_PCH
Initiated by State (Type 1)
Platinum Users Platinum User
upon PCH Prioritizing
Congestion for
Cell
73430425 VS.RRC.Paging Number of CS BSC6910 WRFD-010301 Paging UE in

1.PCHCong.CS Paging WRFD-150204 Idle,
Congestion for
Cell

1.PCHCong.CS Successful CS WRFD-150204 Idle,
PreemptSucc.Pl Paging CELL_PCH,
atinum Preemption URA_PCH
Attempts State (Type 1)
Initiated by Platinum User
Platinum Users Prioritizing
upon PCH
Congestion for
Cell

1.PCHCong.CS Successful CS WRFD-150204 Idle,
upon PCH
Congestion for
Cell

WCDMA RAN

Description
73430427 VS.RRC.Paging Number of PS BSC6900 WRFD-010301 Paging UE in

1.PCHCong.PS Paging WRFD-150204 Idle,
Congestion for
Cell
73430427 VS.RRC.Paging Number of PS BSC6910 WRFD-010301 Paging UE in

1.PCHCong.PS Paging WRFD-150204 Idle,
Congestion for
Cell

1.PCHCong.PS Successful PS WRFD-150204 Idle,
upon PCH
Congestion for
Cell

1.PCHCong.PS Successful PS WRFD-150204 Idle,
upon PCH
Congestion for
Cell

WCDMA RAN

Description
73430480 VS.RAB.Abnor Number of BSC6900 WRFD-150204 Platinum User

mRel.CS.Str.PT Abnormally Prioritizing
Preempt Released CS
RABs Carrying
Streaming
Services for Cell
(Platinum User
Preemption)

mRel.CS.Str.PT Abnormally Prioritizing
Preempt Released CS
RABs Carrying
Streaming
Services for Cell
(Platinum User
Preemption)

mRel.CS.Conv. Abnormally Prioritizing
PTPreempt Released CS
RABs Carrying
Conversational
Services for Cell
(Platinum User
Preemption)

mRel.CS.Conv. Abnormally Prioritizing
PTPreempt Released CS
RABs Carrying
Conversational
Services for Cell
(Platinum User
Preemption)

mRel.PS.Bkg.P Abnormally Prioritizing
TPreempt Released PS
RABs Carrying
Background
Services for Cell
(Platinum User
Preemption)

WCDMA RAN

Description

mRel.PS.Bkg.P Abnormally Prioritizing
TPreempt Released PS
RABs Carrying
Background
Services for Cell
(Platinum User
Preemption)

mRel.PS.Int.PT Abnormally Prioritizing
Preempt Released PS
RABs Carrying
Interactive
Services for Cell
(Platinum User
Preemption)

mRel.PS.Int.PT Abnormally Prioritizing
Preempt Released PS
RABs Carrying
Interactive
Services for Cell
(Platinum User
Preemption)

mRel.PS.Str.PT Abnormally Prioritizing
Preempt Released PS
RABs Carrying
Streaming
Services for Cell
(Platinum User
Preemption)

mRel.PS.Str.PT Abnormally Prioritizing
Preempt Released PS
RABs Carrying
Streaming
Services for Cell
(Platinum User
Preemption)

WCDMA RAN

Description

mRel.PS.Conv. Abnormally Prioritizing
PTPreempt Released PS
RABs for Cell
(Platinum User
Preemption)

mRel.PS.Conv. Abnormally Prioritizing
PTPreempt Released PS
RABs for Cell
(Platinum User
Preemption)

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 13 Glossary
13 Glossary
For the acronyms, abbreviations, terms, and definitions, see Glossary.

WCDMA RAN
Platinum User Prioritizing Feature Parameter Description 14 Reference Documents
14 Reference Documents
1. 3GPP TS 25.101, "User Equipment (UE) radio transmission and reception (FDD)"
2. 3GPP TS 25.211, "Physical channels and mapping of transport channels onto physical
channels (FDD)"
3. 3GPP TS 25.306, "UE Radio Access capabilities"
4. 3GPP TS 25.308, "UTRA High Speed Downlink Packet Access (HSPDA); Overall
description"
5. 3GPP TS 25.321, "Medium Access Control (MAC) protocol specification"
6. Flow Control Feature Parameter Description
7. E2E Flow Control Feature Parameter Description
8. Intelligent Access Control Feature Parameter Description
9. Directed Retry Decision Feature Parameter Description
10. Voice Service Experience Improvement for Weak Reception UEs Feature Parameter
Description
11. Load Control Feature Parameter Description
12. Differentiated Service Based on Resource Reservation Feature Parameter Description
13. Load Reshuffling Feature Parameter Description


Platinum User Prioritizing (RAN17.1 - 01)

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Platinum User Prioritizing (RAN17.1 - 01)

Uploaded by

Copyright:

Available Formats

WCDMA RAN

Platinum User Prioritizing Feature

HUAWEI TECHNOLOGIES CO., LTD.

Trademarks and Permissions

Huawei Technologies Co., Ltd.

Issue 01 (2015-03-25) Huawei Proprietary and Confidential i

1 About This Document..................................................................................................................1

3 Identification and Maintenance of Platinum Users.............................................................11

6 Platinum User Prioritizing During the RAB Setup Phase...................................................19

7 Improvement of Platinum User Experience During the Service Processing Phase.......25

Issue 01 (2015-03-25) Huawei Proprietary and Confidential ii

Issue 01 (2015-03-25) Huawei Proprietary and Confidential iii

1 About This Document

This document applies to the following NE types.

RNC BSC6900, BSC6910

NodeB Macro Not involved

Micro Not involved

LampSite Not involved

1.2 Intended Audience

l Need to understand the features described herein

1.3 Change History

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 1

RAN17.1 Draft A (2015-01-15)

Change Change Description Parameter Change

Feature Added descriptions of the function of Added the following parameters:

Modified descriptions of impacted None

Added the function of platinum user Added the following parameters:

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 2

Change Change Description Parameter Change

Added descriptions of state transition Added the following parameter:

Added descriptions of performance None

Modified descriptions of the impact of None

Editorial None None

1.4 Differences Between Base Station Types

Feature ID Descriptio Supported by Controller Supported Supported LampSite

WRFD-15 Platinum Y Y N/A N/A N/A

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 3

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 4

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 5

Figure 2-1 Service procedure with Platinum User Prioritizing enabled

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 6

IMSI stands for international mobile subscriber identity.

2.4 Classification of Users

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 7

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 8

User Identif Paging Phase RRC RAB Service

Platinu IMSI Improves the l Flow Control Supports l Load Control

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 9

User Identif Paging Phase RRC RAB Service

Gold, ARP No special No special Supports l Load Control

In this document, CS services refer to conversational services, PS services consist of streaming,

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 10

3 Identification and Maintenance of Platinum

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 11

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 12

The procedure for identifying and maintaining platinum users is as follows:

1. The Platinum User Prioritizing feature is activated when the

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 13

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 14

4 Platinum User Paging Prioritizing During

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 15

5 Platinum User Prioritizing During the RRC

Issue 01 (2015-03-25) Huawei Proprietary and Confidential 16
