ARDUINO FREQUENCY COUNTER

16,309 31 14 | Posted Nov. 17, 2016 in Technology > Arduino |

By Rajkumar2506
Twitter
More by
Follow
the author:

About: iam a B.E Electronics and Communication Engineer. I have great interest on electronics.I
love my college life.Even though there are many sadness in my life.I find joy in making
instructables. More About Rajkumar2506 »

To nd out the frequency of any signal we need to use CRO. We can

also use frequency meter.But both of them are costly.Using Arduino
Frequency Counter we can easily measure the frequency of various
signals.This Circuit can be easily made with very less cost when
compare to CRO and Frequency Meter.

 Add Tip V Ask Question | Comment Download

Step 1: Components Required

Arduino Uno.
3 Pin LCD Interface Board.
16 x 2 LCD
IC 74LS14

I have used 3 Pin LCD interface Board to Connect LCD easily with
3Pins. If you don't have 3 pin interface board you can easily make
it.Click on the bellow link to know how to make 3 pin interface board.

Interfacing LCD With Arduino Using Only 3 Pins

Step 2: Operation of IC 74LS14

IC74LS14 is a schmitt trigger.In order to convert any signal into square

wave schmitt trigger is used.

Advantages of Using this IC 74LS14

It is a 5volt IC
It's Output current is below 40mA
It converts any signal into square wave
The time period of output square wave is same as input signal,So the
frequency of input signal to be measured does not change when
converting it to square wave.
Arduino Digital and Analog Pins only withstand 5Volt and 40mA
current.Any thing out of this Range damage your Arduino. Since ic
74LS14 uses 5volt and gives the output current less than 40mA.It is
safe to use this IC74LS14.

Step 3: Schematic Diagram

You can use any Oscillator circuit to measure frequency.I have used
CD4047 which is a oscillator used for demo in this Schematic.

Step 4: Formula Used to Calculate Frequency

In CRO we use f=1/T formula to calculate frequency.Here also the same
concept is used to calculate frequency

where

T is the time period of one cycle of signal in microseconds(us)

In the program of Arduino Frequency counter we used

f=1000000/pulseTotal.

Where

pulse Total is nothing but, a Time period of Signal(T).

microseconds(us)=10^-6

See below how the formula is given asf=1000000/pulseTotal for

Arduino Frequency Counter

f=1/T in microseconds,so the formula is given as f=1/Tx(us)

microseconds(us)=10^-6,So the formula is written as f=1/Tx10^-6.

If we Take micro seconds(us) to numerator it becomes 10^6.It is equal

to the value that is 1000000

So nally the formula for arduino frequency counter is given as

f=1000000/T.

since we are converting signals into square wave.The square wave

contains Ton and Toff period,

So total time period of one cycle of signal is given as

pulseTotal=Ton+Toff

The below Code is used to calculate Ton and

Toff.Ton=pulseHigh.Toff=pulseLow

pulseHigh = pulseIn(pulsePin, HIGH);

pulseLow = pulseIn(pulsePin, LOW);

Step 5: Program Code(if You Use 3 Pin Interface

Board for LCD)
#include <Wire.h>

#include <LiquidCrystal_SR.h>

LiquidCrystal_SR lcd(6, 5, 9);

const int pulsePin = 12; // Input signal connected to Pin 12 of Arduino

int pulseHigh; // Integer variable to capture High time of the incoming

pulse

int pulseLow; // Integer variable to capture Low time of the incoming

pulse

oat pulseTotal; // Float variable to capture Total time of the incoming

pulse

oat frequency; // Calculated Frequency

void setup() {

pinMode(pulsePin, INPUT);

lcd.begin(16, 2);

lcd.setCursor(0, 0);

lcd.print("Instructables");

lcd.setCursor(0, 1);

lcd.print(" Freq Counter ");

delay(5000);

void loop() {

lcd.setCursor(0, 0);

lcd.print("Frequency is ");

lcd.setCursor(0, 1);

lcd.print(" ");

pulseHigh = pulseIn(pulsePin, HIGH);

pulseLow = pulseIn(pulsePin, LOW);

pulseTotal = pulseHigh + pulseLow; // Time period of the pulse in

microseconds

frequency = 1000000 / pulseTotal; // Frequency in Hertz (Hz)

lcd.setCursor(0, 1);

lcd.print(frequency);

lcd.print(" Hz");

delay(500);

Step 6: Program Code (if You Use LCD Without

3Pin Interface Board)
#include <LiquidCrystal.h>

LiquidCrystal lcd(11, 7, 5, 4, 3, 2);

const int pulsePin = 12; // Input signal connected to Pin 12 of Arduino

int pulseHigh; // Integer variable to capture High time of the incoming

pulse

int pulseLow; // Integer variable to capture Low time of the incoming

pulse

oat pulseTotal; // Float variable to capture Total time of the incoming

pulse

oat frequency; // Calculated Frequency

void setup() {

pinMode(pulsePin, INPUT);

lcd.begin(16, 2);

lcd.setCursor(0, 0);

lcd.print("Instructables");

lcd.setCursor(0, 1);

lcd.print(" Freq Counter ");

delay(5000);

void loop() {

lcd.setCursor(0, 0);

lcd.print("Frequency is ");

lcd.setCursor(0, 1);

lcd.print(" ");

pulseHigh = pulseIn(pulsePin, HIGH);

pulseLow = pulseIn(pulsePin, LOW);

pulseTotal = pulseHigh + pulseLow; // Time period of the pulse in

microseconds
frequency = 1000000/ pulseTotal; // Frequency in Hertz (Hz)

lcd.setCursor(0, 1);
lcd.print(frequency);

lcd.print(" Hz");

delay(500);
