Dayton Brake
Drums • Rotors • Trailer Hubs
Catalog PB-2006
M E R I T O R PA R T S . R I G H T F R O M T H E S TA R T.
CONTENTS
1
The SteelLite X30™ brake
drum sets a new standard in
advanced wheel-end design and
development. Feature for feature, our
SteelLite X30™ brake drum is a superior
alternative to any other brake drum
available.
Advanced
Fleets who specify the SteelLite X30™
brake drum for medium- and heavy-duty
trucks, tractors and trailers will enjoy its
considerable advantages, including
reliability, balance, weight reduction and
lifetime operating cost.
2
Exclusive One-Piece facility. This plant features the latest process
Steel Shell. technology and the most sophisticated
Provides exceptional statistical process controls to ensure optimum
strength, durability and quality.
concentricity, and reduces
No Weld Weights.
weight. One-piece design
Because of the forming process, SteelLite X30™
eliminates weld seams.
drums are inherently balanced. There is no need
Lighter Weight. for troublesome weld weights.
SteelLite X30™ brake drums are significantly
Exclusive SpinCast Casting Process.
lighter than standard full-cast drums (up to 200
Permanently fuses a gray iron liner to a one-
lbs. for a typical tandem axle tractor/trailer
piece steel outer shell. The result is a
combination).
superior braking surface that is much less
OEM or Retrofit. vulnerable to disintegration in the event of
SteelLite X30™ brake drums are available in breakage.
most popular axle configurations as original
equipment for your new tractors and trailers
and as retrofits for your
existing equipment.
State-Of-The-Art
Manufacturing.
All SteelLite X30™ brake
drums are built under one
roof in our Franklin,
Kentucky manufacturing
Balanced
Another advantage of our one-piece
steel shell design is that it produces
an inherently balanced drum. Since
Meritor’s SteelLite X30™ brake drums
require no weld weights, the result is a
The SteelLite X30™ brake drum is just
well-balanced, ready-to-mount drum.
one product within the Meritor family that
This design can also help reduce
demonstrates our dedication to
vibration-induced wear and tear on
addressing our customers’ true business
other wheel-end components.
needs. By combining innovation with
experience, we’ve become North
America’s first — and only — truck
component supplier to offer our customers
a complete family of braking components,
Complete
backed by top-notch service and support.
3
HOW TO USE THIS CATALOG
The Meritor part numbering system divides
as such; PREFIX DESCRIPTION
CODE
Example: 01 Rear Steel Wheel - No Longer Available
02 Front Brake Without Drum Assembly
03 - 122222 - 002
03 Brake Drums, Cast Non-Balanced
04 Hub Only - Rear Drive and Trailer
Prefix Base Number Suffix 05 Hub Only - Front
08 Rim, Studs, Misc., Etc.
• The prefix indicates the part type. The 03 in the
09 Hub / Wheel Parts
example indicates a cast non-balanced brake
drum. The 31 different prefix numbers are used 11 Rear Steel Wheel and Brake Drum Assembly
to categorize and describe the part. At present NLA / Replaced by 48-Series
not all of the prefix codes are currently being 12 Front Wheel with Brake Drum Assembly
used, but all are listed for your reference. (See
NLA / Replaced by 56-Series
attached Prefix Chart) This drum, rotor and
trailer hub catalog covers prefix codes 03, 04, 13 Brake Drums, Cast Weld-to-Balance
13, 14, 23, 53, 83, 85, 93, 95. 14 Hub and Drum Assembly - Rear Drive
and Trailer
• 122222 base number, when coupled with the 15 Hub and Drum Assembly Front
prefix, gives the part type and the part dimen-
sional specifications through the numerical part 16 Hub and Rotor Assembly Rear
number listing. The base numbers are not all 17 Hub and Rotor Assembly Front
available with all the prefix combinations. 19 Wheel and Rotor Assembly Front
NLA / Replaced by 57-Series
• The suffix, a three digit number, indicates the 21 Wheel and Rotor Assembly Rear
phase of manufacturing the part is in.
NLA / Replaced by 49-Series
For the current list of Meritor Brake Drum and 23 Rotor
Rotor part numbers, see the appropriate numerical 47 Nodular Iron Wheel Rear / Trailer
listing. If you have brake drum numbers not found 48 Wheel Drum Assembly Rear / Trailer
in the numerical listing, check the discontinued and
replaced by list in this catalog. Nodular Iron Wheel
53 X-30 Brake Drum
This catalog contains cross-reference 55 Nodular Iron Wheel Front
information for: 56 Wheel Drum Assembly Front Nodular Iron
• Gunite
Wheel
• Motor Wheel (centrifuse drums)
• Webb 57 Wheel Rotor Assembly Front
Nodular Iron Wheel
60 Calipers and Kits
63 Brake Drum, Non Balanced / With Tapped
Holes for Exciter Mounting NLA
69 Brake Supports - etc.
73 Brake Drum, Balanced / With Tapped Holes for
Exciter Mounting No Longer Available
83 X-10 Series Brake Drums / Non-Balanced
85 Brake Drums / Machined to Balance (MTB)
93 X-10 Series Brake Drums / Weld-to-Balance
(WTB)
95 X-10 Series Brake Drum / Machined to
Balance (MTB)
4
WHAT MAKES A GOOD BRAKE DRUM
There are a number of attributes that differentiate between mediocre and a good brake drum. The following highlights these
and what they mean to the end user.
5
WHAT MAKES A GOOD BRAKE DRUM (Cont’d.)
5. SUMMARY; THE BEST BRAKE DRUM FOR OVERALL PERFORMANCE
Is a relatively heavy brake drum
Is made from temperature and wear resistant high tensile iron
Is precisely machined
Is balanced by machining rather than adding weights
6
WHAT MAKES A GOOD BRAKE DRUM (Cont’d.)
WHEN SHOULD A BRAKE DRUM BE REPLACED?
The ability of a brake drum to perform safely is affected by a variety of factors. Conditions, which affect the life of
brake drums, are listed, although this list is not intended to be all-inclusive it should serve as a useful guide. The brake
drum should be replaced when any of these conditions appear.
When drums are forced to fit onto a hub, there is improper match of parts for installation. The cause must be
determined and corrected.
Wheel bearings should be properly adjusted to prevent the drum from picking up the load created by the
braking action
Drums and linings should be checked at periodic intervals to detect operational patterns. The use of non-asbestos
organic linings can cause linings to swell and drag resulting in hot spots and lower fuel economy.
Clearance between non-applied brake linings and the drum varies slightly. See the brake system manufacturer’s
recommendations for this adjustment. Proper clearance prevents excessively hot linings and drums and improves
fuel economy.
Parking brakes should not be set while the drums are hot. Allow them to cool, otherwise, drum cracking and failure
can result.
7
COMMON PROBLEMS
Cracked Drums
A drum which has cracked completely through a section of the braking surface must be replaced imme-
diately. A cracked drum is not repairable! Cracked drums are caused by one or more of the following:
1. Excessive heating and cooling
2. Excessive shoe pressure
Repeated cracking of this type may indicate one or more
of the following:
1. Dragging brakes
2. Inadequately designed drums for the application
3. Inadequately designed braking system for the
application
4. Incorrect brake balance of the vehicle
5. Driver abuse
The total braking system of the vehicle should be checked thoroughly, paying attention to the following:
1. Proper friction ratings
2. Proper valving and pluming
3. Proper brake balance
4. Missing linings and/or brake system components.
Heat Checking
A broken network of fine hairline cracks on the braking
surface of the drum, is a normal phenomenon of braking
surfaces. It is caused by regular heating and cooling of
the surface. Heat checking does not impair brake
performance; but you should examine heat checks
frequently to make sure they have not grown deep enough
to weaken the drum.
Oversized Drums
If the brake surface diameter is in excess of it’s specified
maximum diameter, replace the drum immediately. It
may be necessary to replace drums in pairs to assure
proper brake drum balance and braking efficiency. If the
linings show irregular wear replace them.
8
COMMON PROBLEMS (Cont’d.)
Scored Drums
Scored drums are signified by circumferential grooves on
the braking surface and excessive lining wear. If the
scoring is not deeper than the maximum rebore diameter,
the drum may be rebored and returned to service. The
linings should be replaced and the braking system should
be checked to make sure excessive amounts of abrasive
material are not entering into the lining-drum contact area.
If the scoring is deeper than the maximum rebore
diameter, replace the drum immediately.
Out-Of-Round Drums
Variations in drum diameter at different points on the braking
surface indicate out-of-round drums. The drum should be
machined within allowable rebore limits to restore concentric-
ity. Do not exceed the maximum rebore limit of turned drums,
and replace drums which are worn beyond their specified
maximum diameter. If you are unable to restore concentricity
by reboring the drum, replace it with a new one. It may be
necessary to replace drums in pairs to assure proper brake
drum balance and braking efficiency.
9
COMMON PROBLEMS (Cont’d.)
Blue Drums
A bluish disfiguration on the brake parts (shoes,
drums/rotors or bolts) indicates excessive heat.
The spots are caused by very light brake applications with non-
asbestos organic linings that are contacting the drum at a few
lining high spots. To avoid this problem, change braking tech-
nique to snubs rather than light dragging stops or ensure the
lining fits the drum contour uniformly when it is new.
Polished Drums
A polished brake drum/rotor is characterized by a mirror-like
finish on its braking surface. Correct this problem by
removing the gloss with 80 grit emery cloth. If the problem
recurs, check the linings to make sure they are the proper
friction rating. If the linings are glazed, consult the vehicle
manufacturer for the proper lining material.
10
NOTES
11
BRAKE DRUM TYPES
12
BRAKE DRUM TYPES
13
HOW TO MEASURE BRAKE DRUMS
IDENTIFY REQUIRED DRUM BY MEASURING:
Brake Surface Diameter Bolt Circle Diameter
14
NUMERICAL LISTING
CAST BRAKE DRUMS, CAST — NON-BALANCED
PART DRUM WHEEL BRAKE OVER- BRAKE PILOT BOLT BOLT HOLE DESCRIPTION/
NO. WEIGHT TYPE TYPE ALL SURFACE CIRCLE
SIZE DEPTH WIDTH DIA. NO. SIZE COMMENTS
03-012480-002 112 P Spoke 16.5 x 7 9.000 7.600 11.250 12.750 6 0.650
03-012582-002 118 R Disc 16.5 x 7 9.500 7.560 9.440 11.250 10 0.840
03-120149-002 110 T Disc 16.5 x 7 8.620 7.440 8.660 11.250 10 0.812
03-120376-002 131 AU Spoke/Disc 16.5 x 8.625 10.250 9.219 9.500 11.250 10 0.844
Replaces 03-120192,
03-120442-002 106 R Spoke 16.5 x 7 8.656 7.500 11.000 12.500 5 0.656
03-120435
03-120459-002 60 AH Spoke 15 x 3.5 5.310 4.190 10.000 11.250 5 0.531
03-120516-002 83 A Spoke 15 x 6 7.090 6.500 9.438 11.000 5 0.656 Replaces 03-122567
03-120517-002 76 S Spoke 15 x 5 6.590 5.560 9.438 11.000 5 0.656
03-120553-002 74 S Disc 15 x 5 7.220 5.500 6.250 8.750 6 0.844
03-120556-002 65 R Spoke 15 x 5 6.220 5.500 11.000 12.500 5 0.531
03-120574-002 103 R Spoke 16.5 x 7 8.720 7.560 11.250 12.750 5 0.781
Replaces 03-120664,
03-122103,
03-120586-002 116 R Spoke 16.5 x 7 8.750 7.500 9.500 11.250 5/6 .781/.656 03-122201,
03-122744,
03-023058
03-120705-002 37 P Spoke 15 x 3 4.130 3.560 10.000 11.000 5 0.531 Replaces 03-120375
03-120754-002 103 R Spoke 16.5 x 7 8.440 7.380 11.000 12.500 5/6 .656/.656 Replaces 03-120152
03-120855-002 92 A Spoke 16.5 x 5 6.120 5.370 9.250 11.250 6 0.781
03-120877-002 115 R Disc 16.5 x 7 10.690 7.530 9.438 11.250 10 0.843
03-120936-002 132 A Spoke 18 x 7 8.250 7.440 11.000 12.750 6 0.656
03-120981-002 76 R Disc 15 x 4 7.840 4.440 8.660 11.250 10 1.265 outboard mount
03-120988-002 86 AE Disc 16.5 x 5 8.580 5.480 8.660 11.250 10 1.265 outboard mount
03-122009-002 105 N Spoke 16.5 x 7 8.650 7.650 10.500 12.750 5 0.781
For Lucas Girling
03-122011-002 89 B Spoke 15 x 7 8.510 7.360 10.500 12.750 5 0.781
Rear Brake
03-122027-002 120 R Spoke 16.5 x 7 8.940 7.630 9.500 11.250 5 0.781
Replaces 03-122032,
03-122078-002 66 AI Spoke 15 x 4 5.260 4.310 9.500 11.250 6 0.781 13-122078,
03-122593
03-122104-002 64 R Spoke 15 x 4 5.840 4.540 9.250 11.250 6 0.781
03-122126-002 117 R Spoke/Disc 16.5 x 7 8.750 7.500 9.500 11.250 10 0.844
03-122222-002 108 Q Spoke 16.5 x 7 8.410 7.630 9.440 11.000 5/6 .781/.656
Notched for ABS
03-122239-002 119 O Disc 16.5 x 7 8.940 7.630 9.500 11.250 10 0.844 Replaces 03-122208,
13-122208
03-122290-002 119 O Spoke 16.5 x 7 8.940 7.630 9.500 11.250 6 0.781 Notched for ABS
03-122314-002 45 AL Spoke 15 x 3 4.690 3.500 6.445 8.000 5 0.656 Replaces 13-122314
03-122453-002 112 S Disc 16.5 x 7 10.380 7.440 8.530 11.250 10 0.812
03-122455-002 109 I Spoke 16.5 x 7 8.030 7.440 14.250 12.750 5/6 .656/.656 Peripheral Pilot
Replaces 03-012358,
03-122488-002 54 S Spoke 12.25 x 5.5 7.440 6.530 8.500 10.000 6/6 .656/.656 03-120947,
03-122322
03-122490-002 107 R Spoke 16.5 x 7 8.450 7.400 11.250 12.750 5/6 .781/.781
03-122513-002 127 R Disc 16.5 x 8.625 12.270 9.330 9.438 11.250 10 0.843 Outboard Mount
Standard Weight
03-122518-002 102 R Disc 16.5 x 7 8.750 7.500 9.500 11.250 10 0.813
03-122126
15
NUMERICAL LISTING
CAST BRAKE DRUMS, CAST — NON-BALANCED (Cont’d.)
OVER- BRAKE BOLT HOLE
PART DRUM WHEEL BRAKE PILOT BOLT DESCRIPTION/
WEIGHT ALL SURFACE
NO. TYPE TYPE SIZE DIA. CIRCLE NO. SIZE COMMENTS
DEPTH WIDTH
Outboard Mount
03-122529-002 88 S Disc 15 x 4 8.860 4.530 8.750 11.250 10 1.281
Replaces 13-122529
03-122550-002 106 AE Disc 16.5 x 7 10.590 7.750 9.000 11.250 10 0.812 Cast unbalanced
03-122561-002 73 S Disc 15 x 5 7.990 5.720 6.440 8.750 10 0.781
03-122562-002 72 S Disc 15 x 5 7.990 5.720 6.440 8.750 6 0.843 Replaces 03-120109
03-122575-002 60 S Spoke 15 x 4 5.540 4.440 9.188 11.250 5/6 .656/.656 Replaces 03-120980
03-122597-002 34 P Disc 14 x 2.5 4.030 3.000 4.600 6.000 6 0.531 Use 13-123057
03-122603-002 103 N Spoke 16.5 x 7 8.750 7.500 9.440 11.000 5 0.780
03-122607-002 117 R Disc 16.5 x 7 10.630 7.820 8.530 11.250 10 0.812
Replaces 03-012889,
03-122683-002 106 R Spoke 16.5 x 7 8.450 7.390 11.250 12.750 5/6 .781/.781 20025, 20451, 122079,
122083,122102
03-122921-002 84 AC Disc 15 x 4 8.980 5.090 8.750 11.250 10 0.812
03-122925-002 109 I Spoke 16.5 x 7 8.030 7.440 14.250 12.750 5 0.781 Peripheral Pilot
03-122947-002 61 A Spoke 15 x 4 5.600 4.680 11.000 12.750 6 0.781
03-122948-002 116 AD Disc 16.5 x 7 10.310 7.640 9.000 11.250 10 0.812
6 Holes Equally
03-122963-002 66 P Spoke 12.25 x 7.5 8.810 8.000 8.501 10.000 6/6 .656/.656 Spaced and 6 Paired
Holes Equally Spaced
03-122964-002 61 A Spoke 15 x 4 5.560 4.690 11.000 12.750 5 0.781
03-122966-002 96 AC Disc 16.5 x 5 9.630 5.740 8.750 11.250 10 0.812
Outboard Mount;
Hub Requires a
03-122978-002 112 R Disc 16.5 x 7 10.630 7.820 8.534 11.250 10 0.812 .25" x 450 chamfer -
do not subsitute
03-122607
Uni mount version
03-123020-002 69 S Disc 15 x 4 7.840 4.440 8.780 11.250 10 1.265
of 03-120981
335mm bolt circle -
03-123024-002 82 B Disc 15 x 4 8.870 4.530 11.252 13.189 10 0.937 for use with hub
piloted systems only
335mm bolt circle -
03-123025-002 114 S Disc 16.5 x 7 10.590 7.750 11.252 13.189 10 0.937 for use with hub
piloted systems only
03-123058-002 111 R Spoke 16.5 x 7 8.750 7.500 9.500 11.250 6 0.780 cast unbalanced
03-123200-002 109 N Spoke 16.5 x 7 8.650 7.650 10.501 12.750 6 0.781
03-123207-002 112 AD Disc 16.5 x 7 10.540 7.460 8.781 11.250 10 0.937 outboard mount
335mm bolt circle -
03-123219-002 90 P Disc 16.5 x 5 9.160 5.540 11.252 13.189 10 0.937 for use with hub
piloted systems only
03-123254-002 79 AD Disc 15 x 4 8.790 4.650 8.780 11.250 10 1.250
275mm bolt circle
03-123276-002 96 AD Disc 15 x 7 10.920 7.500 8.991 10.827 8 0.844 For Lucas Girling
Rear Brake
335mm bolt circle -
03-123302-002 109 R Disc 16.5 x 6 9.750 6.630 11.250 13.189 10 0.937 for use with hub
piloted systems only
16
NUMERICAL LISTING
CAST BRAKE DRUMS, CAST — NON-BALANCED (Cont’d.)
OVER- BRAKE BOLT HOLE
PART WEIGHT DRUM WHEEL BRAKE ALL SURFACE PILOT BOLT DESCRIPTION/
NO. TYPE TYPE SIZE DEPTH WIDTH DIA. CIRCLE NO. SIZE COMMENTS
03-123331-002 84 R Disc 15 x 6 8.790 6.750 8.992 10.827 8 0.844 275mm bolt circle
03-123365-002 122 AD Disc 16.5 x 7 10.590 7.750 8.780 11.250 10 0.937 285.75mm bolt circle
03-123366-002 70 AD Disc 15 x 4 8.850 4.560 8.780 11.250 10 0.937 285.75mm Bolt Circle
Heavy duty version of
03-123382-002 69 AD Disc 15 x 4 8.850 4.750 8.780 11.250 10 1.281
03-123420-002
03-123396-002 84 AD Disc 15 x 4 8.970 5.090 8.782 11.250 10 0.937
03-123397-002 117 AD Disc 16.5 x 7 10.310 7.640 8.780 11.250 10 0.937
03-123398-002 111 R Disc 16.5 x 7 9.500 7.560 8.440 11.250 10 0.843
Outboard Mount;
03-123406-002 142 R Disc 16.5x8.625 11.980 9.130 8.780 11.250 10 0.937 285.75mm Bolt
circle - heavy duty
03-122513
03-123409-002 123 AD Disc 16.5 x 7 10.590 7.750 9.000 10.827 8 0.937
03-123427-002 125 R Spoke 16.5 x 6 7.490 6.690 11.250 12.750 6 0.781
03-123428-002 142 R Disc 16.5x8.625 12.330 9.480 8.780 11.250 10 0.937 Use 83- or 93-120877
double drilled
03-123430-002 105 N Spoke 16.5 x 7 8.650 7.650 10.500 12.750 5/6 .781/.781 03-122009, 03-123200
similar to 03-122104
03-123431-002 65 R Spoke 15 x 4 5.840 4.750 9.251 11.250 6 0.781 except .25" deeper /
replaces 13-123431
03-123448-002 74 AD Disc 15 x 4 9.100 4.650 8.780 11.250 10 1.281
03-123466-002 121 Z Disc 15 x 8.625 12.200 8.830 8.780 11.250 10 1.000
285.75mm bolt
03-123493-002 90 AD Disc 15 x 6 8.810 6.750 8.782 11.250 10 0.937 circle / rated axle
cap. 15,000 lb
double drilled
03-123500-002 89 R Spoke/Disc 16.5 x 5 6.410 5.440 10.000 12.750 5/6/7 0.781 03-122266 &
03-122267
17
NUMERICAL LISTING
CAST BRAKE DRUMS, BALANCED — WELD-TO-BALANCE (Cont’d.)
PART DRUM WHEEL BRAKE OVER- BRAKE PILOT BOLT BOLT HOLE DESCRIPTION/
NO. WEIGHT TYPE TYPE SIZE ALL SURFACE DIA. CIRCLE COMMENTS
DEPTH WIDTH NO. SIZE
Balanced; Notched for
13-122027-002 120 R Spoke 16.5 x 7 8.940 7.630 9.500 11.250 5 0.781 ABS - Use 03-122027
less ABS / Balance
13-122038-002 88 R Spoke 16.5 x 5 6.690 5.410 10.000 12.750 6 0.781
13-122039-002 76 A Spoke 15 x 5 6.680 5.400 10.000 12.750 6 0.780
Ford Application,
13-122104-002 64 R Spoke 15 x 4 5.840 4.540 9.251 11.250 6 0.781 Rated Axle Capacity
12,000 Lbs.
13-122239-002 109 O Disc 16.5 x 7 8.940 7.620 9.500 11.250 10 0.810
13-122266-002 89 R Spoke 16.5 x 5 6.410 5.440 10.000 12.750 6 0.781
13-122290-002 120 O Spoke 16.5 x 7 8.940 7.630 9.500 11.250 6 0.781 Notched for ABS
13-122296-002 61 A Spoke 15 x 4 5.880 4.960 10.000 12.750 6 0.781 Replaces 03-122296
Balanced - Use
13-122314-002 45 Al Spoke/Disc 15x3 4.690 3.500 6.445 8.000 5 0.656 03-122314 less
balance
13-122328-002 108 R Spoke 16.5 x 7 8.440 7.380 11.000 12.500 5 0.656
13-122329-002 108 R Spoke 16.5 x 7 8.440 7.380 11.000 12.500 6 0.656
13-122453-002 112 S Disc 16.5 x 7 10.380 7.440 8.530 11.250 10 0.812
Balanced; Outboard
Mount - Use
13-122529-002 89 S Disc 15 x 4 8.860 4.530 8.750 11.250 10 1.281
03-122529 less
balance
Balanced -
13-122597-002 34 P Disc 14 x 2.5 4.030 3.000 4.600 6.000 6 0.531
Use 13-123057
13-122600-002 107 L Spoke 16.5 x 7 7.940 7.310 11.000 12.750 5/6 .656/.656
13-122607-002 117 R Disc 16.5 x 7 10.630 7.820 8.530 11.250 10 0.812
13-122683-002 106 R Spoke 16.5 x 7 8.450 7.390 11.250 12.750 5/6 .781/.781 Balanced
13-122806-002 105 AD Disc 15 x 7 10.930 7.500 6.440 8.750 6 0.812 Outboard mount
13-122990-002 119 N Spoke 16.5 x 7 8.750 7.500 9.500 11.250 5 0.781
335mm bolt circle -
13-123024-002 82 B Disc 15 x 4 8.870 4.530 11.252 13.189 10 0.937 for use with hub
piloted systems only
335mm bolt circle -
13-123025-002 114 S Disc 16.5 x 7 10.590 7.750 11.252 13.189 10 0.937 for use with hub
piloted systems only
335mm bolt circle -
13-123219-002 90 P Disc 16.5 x 5 9.160 5.540 11.252 13.189 10 0.937 for use with hub
piloted systems only
13-123383-002 96 AD Disc 16.5 x 5 9.140 5.500 8.780 11.250 10 1.281
13-123389-002 79 A Spoke 16.5 x 5 6.570 6.010 11.001 12.750 5 0.781
18
NUMERICAL LISTING
STEELLITE X30 BRAKE DRUMS
PART DRUM WHEEL OVER- BRAKE BOLT BOLT HOLE
BRAKE PILOT DESCRIPTION/
NO. WEIGHT TYPE TYPE ALL SURFACE CIRCLE
SIZE DEPTH WIDTH DIA. NO. SIZE COMMENTS
Axle Capacity
53-123512-002 66 AD Disc 16.5 x 7 8.600 4.860 8.780 285.75mm 10 1.250
13,200 lbs.
Axle Capacity
53-123519-002 88 AD Spoke 16.5 x 7 8.230 7.580 9.438 11.000 5/5 .781/.656
23,000 lbs.
Axle Capacity
53-123535-002 95 AD Disc 16.5 x 8 10.960 8.620 8.780 285.75mm 10 0.937
23,000 lbs.
Axle Capacity
53-123537-002 92 AD Disc 16.5 x 7 10.380 7.870 8.780 285.75mm 10 0.960
23,000 lbs.
Axle Capacity
53-123542-002 66 AD Disc 15 x 4 8.890 7.760 8.780 285.75mm 10 1.250
13,200 lbs.
Axle Capacity
53-123544-002 102 AD Disc 16.5x8.625 11.040 9.150 8.780 11.250 10 0.932
23,000 lbs.
Axle Capacity
53-123564-002 92 AD Disc 16.5 x 7 10.380 7.860 8.530 11.250 10 0.810
23,000 lbs.
Axle Capacity
53-123565-002 92 AD Disc 16.5 x7 10.380 7.860 9.000 11.250 10 0.810
23,000 lbs.
Axle Capacity
53-123566-002 92 AD Disc 16.5 x 7 10.380 7.860 9.000 275mm 8 0.920
23,000 lbs.
Axle Capacity
53-123567-002 66 AD Disc 15 x 4 8.640 5.110 8.780 285.75mm 10 0.960
13,200 lbs.
Axle Capacity
53-123568-002 66 AD Disc 15 x 4 8.890 4.760 8.780 285.75mm 10 0.960
13,200 lbs.
Axle Capacity
53-123575-002 64 AD Disc 15 x 4 8.890 4.760 9.000 10.827 8 0.937
23,000 lbs.
53-123579-002 106 AD Disc 16.5x8.625 12.150 9.38 9.000 275mm 8 0.937
53-123580-002 106 AD Disc 16.5x8.625 12.150 9.380 8.530 11.25 10 0.812
53-123581-002 106 AD Disc 16.5x8.625 12.150 9.380 8.780 285.75mm 10 0.937
53-123582-002 91 AD Disc 16.5 x 7 10.040 7.270 8.531 11.25 10 0.812
53-123583-002 90 AD Disc 16.5 x 7 10.040 7.270 8.783 285.75mm 10 0.937
53-123584-002 90 AD Disc 16.5 x 7 10.040 7.270 9.000 275mm 8 0.937
53-123588-002 79 AD Disc 16.5 x 5 9.220 5.820 9.000 275mm 8 0.937
53-123589-002 79 AD Disc 16.5 x 5 9.220 5.820 8.780 11.25 10 1.281
53-123590-002 79 AD Disc 16.5 x 5 9.220 5.820 8.530 11.25 10 1.281
53-123591-002 80 AD Disc 15 x 7 10.220 7.420 8.780 285.75mm 10 0.937
53-123592-002 80 AD Disc 15 x 7 10.220 7.420 8.530 11.25 10 0.812
53-123593-002 80 AD Disc 15 x 7 10.22 7.42 9.000 11.25 10 0.812
53-123594-002 80 AD Disc 15 x 7 10.220 7.420 9.000 275mm 8 0.937
53-123596-002 104 AD Disc 16.5x8.625 11.870 9.100 8.531 11.25 10 0.812
53-123597-002 103 AD Disc 16.5x8.625 11.870 9.100 8.783 285.75mm 10 0.937
53-123598-002 70 AD Disc 15 x 5 9.530 5.810 8.780 11.25 10 1.281
53-123599-002 70 AD Disc 15 x 5 9.530 5.810 9.000 275mm 8 0.937
53-123600-002 70 AD Disc 15 x 5 9.530 5.810 8.780 285.75mm 10 0.937
53-123601-002 90 AD Disc 15 x 8.625 11.440 9.110 8.780 285.75mm 10 0.937
53-123602-002 90 AD Disc 15 x 8.62 11.440 9.110 9.000 275mm 8 0.937
53-123605-002 77 AD Disc 16.5 x 5 8.590 5.870 8.530 11.25 10 1.281
53-123606-002 77 AD Disc 16.5 x 5 8.590 5.870 8.780 11.25 10 1.281
53-123607-002 87 AD Disc 16.5 x 6 9.620 6.680 8.780 285.75mm 10 0.937
53-123608-002 87 AD Disc 16.5 x 6 9.620 6.680 8.780 11.25 10 1.281
19
NUMERICAL LISTING
X - 10 SERIES CAST BRAKE DRUMS, NON-BALANCED
PART DRUM WHEEL BRAKE OVER- BRAKE PILOT BOLT BOLT HOLE DESCRIPTION/
NO. WEIGHT TYPE TYPE ALL SURFACE CIRCLE
SIZE DEPTH WIDTH DIA. NO. SIZE COMMENTS
83-012582-002 114 R Disc 16.5 x 7 9.500 7.500 9.438 11.250 10 0.843
83-120877-002 115 R Disc 16.5 x 7 10.690 7.530 9.438 11.250 10 0.843
83-122126-002 117 R Spoke/Disc 16.5 x 7 8.750 7.500 9.500 11.250 10 0.844
83-122222-002 108 Q Spoke 16.5 x 7 8.410 7.630 9.440 11.000 5/6 .781/.656
83-122550-002 106 AE Disc 16.5 x 7 10.590 7.750 9.000 11.250 10 0.812
83-122603-002 101 N Spoke 16.5 x 7 8.750 7.563 9.440 11.000 5 0.781
83-122607-002 117 R Disc 16.5 x 7 10.630 7.820 8.530 11.250 10 0.812 outboard mount
83-123200-002 109 N Spoke 16.5 x 7 8.650 7.650 10.502 12.750 6 0.781
83-123365-002 122 AD Disc 16.5 x 7 10.590 7.750 8.780 11.250 10 0.937 285.75mm bolt circle
83-123366-002 70 AD Disc 15 x 4 8.850 4.560 8.780 11.250 10 0.937 285.75mm bolt circle
83-123406-002 142 R Disc 16.5 x 8.625 11.980 9.130 8.780 11.250 10 0.937 outboard mount
285.75mm bolt circle
83-123409-002 123 AD Disc 16.5 x 7 10.590 7.750 8.780 10.827 8 0.937 275mm bolt circle
use 22mm bolt
83-123428-002 142 R Disc 16.5 x 8.625 12.330 9.480 8.780 11.250 10 0.937
20
NUMERICAL LISTING
CAST BRAKE DRUMS, “MACHINE-TO-BALANCE” (MTB) (Cont’d.)
PART DRUM WHEEL OVER- BRAKE BOLT BOLT HOLE
BRAKE ALL PILOT DESCRIPTION/
NO. WEIGHT TYPE TYPE SURFACE CIRCLE
SIZE DEPTH WIDTH DIA. NO. SIZE COMMENTS
85-123520-002 135 AD Disc 16.5 x 8 11.090 8.910 8.779 11.250 10 0.937 axle cap 23,000 lb
85-123548-002 110 G Disc 15 x 7 10.180 7.560 8.700 10.827 8 0.847 275mm bolt circle /
Ford no. 86HU-1126-CA
85-123553-002 90 A Disc 15 x 4 9.070 4.720 11.064 13.189 10 1.024 335mm bolt circle /
Ford no.
86UH-1125-BA
85-123561-002 115 Z Disc 16.5 x 6 9.832 6.820 11.712 13.729 10 .975 Meritor front drum
85-123569-002 85 Z Disc 16.5 x 6 9.906 6.880 9.139 11.250 10 1.334 285.75mm bolt
circle / front drum
85-123570-002 138 Z Disc 16.5 x 8.625 11.250 9.110 8.779 11.250 10 0.937
21
BRAKE DIAMETER CHART
OVERALL BRAKE BOLT BOLT HOLES MERITOR WHEEL
PILOT DRUM
SURFACE CIRCLE WEIGHT PART TYPE
DEPTH DIA. NO. SIZE NO. TYPE
WIDTH
22
BRAKE DIAMETER CHART
BRAKE BOLT HOLES MERITOR
OVERALL PILOT BOLT PART DRUM WHEEL
SURFACE WEIGHT
DEPTH WIDTH DIA. CIRCLE NO. SIZE NO. TYPE TYPE
23
BRAKE DIAMETER CHART
OVERALL BRAKE PILOT BOLT HOLES MERITOR DRUM
BOLT WEIGHT WHEEL
DEPTH SURFACE DIA. CIRCLE PART TYPE
NO. SIZE TYPE
WIDTH NO.
24
BRAKE DIAMETER CHART
BRAKE PILOT BOLT HOLES MERITOR DRUM
OVERALL BOLT WEIGHT WHEEL
SURFACE DIA. PART TYPE
DEPTH CIRCLE NO. SIZE TYPE
WIDTH NO.
25
BRAKE DIAMETER CHART
BRAKE PILOT BOLT HOLES MERITOR DRUM
OVERALL BOLT WEIGHT WHEEL
SURFACE DIA. CIRCLE PART TYPE TYPE
DEPTH WIDTH NO. SIZE NO.
9.940 9.060 9.438 11.000 5/6 .781 / .656 126 03-122284-002 R Spoke
10.250 9.219 9.500 11.250 10 0.844 131 03-120376-002 AU Spoke / Disc
11.040 9.150 8.779 11.250 10 0.932 102 53-123544-002 AD Disc
11.040 9.150 8.780 285.75mm 10 0.960 112 53-123554-002 AD Disc
11.250 9.110 8.779 11.250 10 0.937 138 85-123570-002 Z Disc
11.250 9.110 8.779 11.250 10 0.937 139 95-123570-002 Z Disc
11.760 9.580 9.000 10.930 8 0.937 135 85-123470-002 Z Disc
11.870 9.100 8.531 11.250 10 0.812 104 53-123596-002 AD Disc
11.870 9.100 8.783 285.75mm 10 0.937 103 53-123597-002 AD Disc
11.980 9.130 8.780 11.250 10 0.937 142 03-123406-002 R Disc
11.980 9.130 8.780 11.250 10 0.937 142 83-123406-002 R Disc
12.150 9.380 9.000 275mm 8 0.937 106 53-123579-002 AD Disc
12.150 9.380 8.530 11.250 10 0.812 106 53-123579-002 AD Disc
12.150 9.380 8.780 285.75mm 10 0.937 106 53-123581-002 AD Disc
12.270 9.330 9.438 11.250 10 0.843 127 03-122513-002 R Disc
12.330 9.480 8.780 11.250 10 0.937 142 03-123427-002 R Disc
12.330 9.480 8.780 11.250 10 0.937 142 03-123428-002 R Disc
12.330 9.480 8.780 11.250 10 0.937 142 83-123428-002 R Disc
12.330 9.480 8.780 11.250 10 0.937 140 95-123428-002 R Disc
26
NOTES
27
MEDIUM-DUTY TRUCK HYDRAULIC DISC BRAKE ROTORS
A — DISC D — BOLT
OUTSIDE CIRCLE
DIA.
E — DIA. &
B — NEW DISC NUMBER
F A
D THICKNESS* OF HOLES
23-123485-002 1 15.380 1.440 3.400 7.250 0.594 10 6.000 5 Tapped Holes For ABS Ring
Mounting (M8x1.25-6H 6.8" B.C.)
23-123486-002 1 14.750 1.350 3.810 6.750 0.656 5 5.400 5 Tapped Holes For ABS Ring
Mounting (Metric)
23-123487-002 1 14.750 1.350 3.810 6.750 0.656 5 5.400 5 Tapped Holes For ABS Ring
Mounting (1/4"-20 5.90 B.C.)
23-123489-002 1 15.380 1.540 3.400 7.250 0.594 10 6.000 5 Tapped Holes For ABS Ring
Mounting GMC Application
23-123494-002 1 14.750 1.350 3.810 7.250 0.781 6 5.760 New Holland 86514074
23-123495-002 1 14.750 1.350 3.810 7.250 0.594 10 6.000 5 Tapped Holes
For ABS Ring Mounting
23-123497-002 1 14.750 1.350 3.810 4.501
23-123498-002 1 15.380 1.540 3.410 7.250 0.656 10 5.964 5 Tapped Holes
For ABS Ring Mounting
23-123527-002 1 15.630 1.540 3.630 7.250 0.656 10 5.964 Ford YC3Z1125AA
23-123529-002 1 14.750 1.350 3.980 7.250 0.656 5 6.001 Casting Number23-122687-096
23-123532-002 1 15.169 1.440 2.895 6.750 0.656 5 5.400 GM Applications
23-123550-004 1 15.000 1.440 3.210 7.250 0.594 10 6.001 ITE 3531662C2 / ABS Exciter Teeth
In Casting (100)
23-123552-004 1 15.000 1.440 4.440 7.250 0.594 10 6.001 ITE 3531663C2 / ABS Exciter Teeth
In Casting (100)
23-123557-002 1 15.375 1.530 3.400 7.250 0.594 10 6.001 ABS Exciter Teeth In Casting (100)
23-123572-004 1 15.000 1.440 3.500 6.750 0.781 6 5.401 ABS Exciter Teeth In Casting (100)
23-123573-004 1 15.000 1.440 3.500 6.750 0.781 5 5.400 ITE 3531661C2 / ABS Exciter Teeth
In Casting (100)
29
MEDIUM-DUTY TRUCK HYDRAULIC DISC BRAKE ROTORS
MAJOR DIAMETER
MAJOR DIAMETER
30
DISC BRAKE ROTOR IDENTIFICATION CHART
SPOKE OR DISC WHEEL — (Primary Application)
MAJOR ROTOR MERITOR
DIA. TYPE NOTES PART NO.
31
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-09179-XXX Trailer Hub 10 hole
Inboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM518410 HM518445 11.25"
OUTER BEARING
CUP CONE
HM518410 HM518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 9.06"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 6.94"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter Drum Mount 9.5
G Hub Cap Mount 6.25"-8 TPI
FOR AXLE MODELS: DANA SPICER EATON: 225P, 230P, P-22 HENDRICKSON: HP
FRUEHAUF: PRO-PAR INGERSOLL: A24H, A24S, F24
MERITOR: TP
ABS
DESCRIPTION
RING NO.
N/A
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
32
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-14131-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM518410 HM518445 11.250"
OUTER BEARING
CUP CONE
HM518410 HM518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 9.06"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 6.94"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 9.47"
G Hub Cap Mount 6.25"-8 TPI
FOR AXLE MODELS: DANA SPICER EATON: 225P, 230P, P-22 HENDRICKSON: HP
FRUEHAUF: PRO-PAR INGERSOLL: A24H, A24S, F24
MERITOR: TP
ABS
DESCRIPTION
RING NO.
N/A
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum (03-120877-002)
14-14131-064 RH X Steel Cast Yes No No
14-14131-065 LH X Steel Cast Yes No No
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 8.62" Drum (03-122513-002)
14-14131-064 RH X Steel Cast Yes No No
14-14131-065 LH X Steel Cast Yes No No
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
33
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-14802-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM218210 HM218248 11.250"
OUTER BEARING
CUP CONE
HM212011 HM212049
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 6.93"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 4.74"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.53"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, JE, JH, 23L, 23R K-B: KBW-KBS
DEXTER: D200K, D2225K MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD
HENDRICKSON: HN STD. FORGE: A-22H, A-22S, A-22T
INGERSOLL: A22H, A22S, A22T, DC22H, F22 WESTPORT: F3W-1600, F3W-1800/2000,
F3W-1800D/2000D
STUDS USED WITH HUB IN ASSEMBLIES
THEAD TYPE
STUD NO. SIZE STYLE WHEEL TYPE USE WITH DRUM TYPE
09-853601 Serr. 3/4"-16 R Stud Piloted Steel Wheel Cast
09-853602 Serr. 3/4"-16 L Stud Piloted Steel Wheel Cast
09-861901 Serr. 3/4"-16 R Stud Piloted Steel Wheel Cast
09-861902 Serr. 3/4"-16 L Stud Piloted Steel Wheel Cast
ABS
DESCRIPTION
RING NO.
N/A —
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16" X 7" Drum (03-122607-002)
14-14802-100 RH X Steel or Aluminum Cast Yes Yes 10 cap No
14-14802-102 RH X Steel or Aluminum Cast Yes No No
14-14802-101 LH X Steel or Aluminum Cast Yes Yes 10 cap No
14-14802-103 LH X Steel or Aluminum Cast Yes No No
14-14802-108 RH X Steel or Aluminum Cast Yes Yes 10 cap No
14-14802-109 LH X Steel or Aluminum Cast Yes Yes 10 cap No
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
34 Not all of the numbers listed above are stocking items, some may have lead times involved.
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15479-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM218210 HM218248 13.189"
OUTER BEARING
CUP CONE
HM212011 HM212049
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 6.93"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 4.74"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 13.189"
E Wheel Stud Qty. 10"
F Pilot Diameter 11.252"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, DEXTER: D200K, D2225K
JE, JH, 23L, 23R INGERSOLL: A22H, A22S, A22T, DC22H, F22
HENDRICKSON: HN K-B: KBW-KBS
MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD STD. FORGE: A-22H, A-22S, A-22T
WESTPORT: F3W-1600, F3W-1800/2000,
F3W-1800D/2000D
ABS
DESCRIPTION
RING NO.
N/A —
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
HUB PILOTED — Hub And Drum Assemblies With 16.5" X 7" Drum (03-123025-002)
14-15479-1000 X Steel Cast Yes 10 Flg Yes
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
35
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15501-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM 218210 HM218245 11.250"
OUTER BEARING
CUP CONE
HM 212011 HM 212049
DRAWING
REFERENCE ITEM DIMENSION
A Over All Length 6.93"
B Outer Hub Cap Face To Inner
Brg. Cup Seat 4.74"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.75"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, JE, JH, 23L, 23R DEXTER: D200K, D2225K
HENDRICKSON: HN K-B: KBW-KBS
INGERSOLL: A22H, A22S, A22T, DC22H, F22, A-22S
MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD
STD. FORGE: A-22H, A-22S, A-22T
WESTPORT: F3W-1600, F3W-1800/2000, F3W-1800D/2000D
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
36
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
14-15501-377 RH X Steel or Aluminum Cast Yes No No
14-15501-505 RH X Steel or Aluminum Cast Yes No Yes
14-15501-378 LH X Steel or Aluminum Cast Yes No No
14-15501-506 LH X Steel or Aluminum Cast Yes No Yes
14-15501-668X30 RH X Steel or Aluminum X-30 Yes No No
14-15501-666X30 RH X Steel or Aluminum Cast Yes No Yes
14-15501-669X30 LH X Steel or Aluminum Cast Yes No No
14-15501-667X30 LH X Steel or Aluminum Cast Yes No Yes
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
14-15501-352 X Steel Cast Yes No No
14-15501-516 X Steel Cast Yes No Yes
14-15501-353 X Aluminum Cast Yes No No
14-15501-517 X Aluminum Cast Yes No Yes
14-15501-652X30 X Steel X-30 Yes No No
14-15501-656X30 X Steel X-30 Yes No Yes
14-15501-653X30 X Aluminum X-30 Yes No No
14-15501-657X30 X Aluminum X-30 Yes No Yes
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
37
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15502-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
OUTER BEARING
CUP CONE
HM 518410 HM 518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 9.06"
B Outer Hub Cap Face To Inner
Brg. Cup Seat 6.94"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.75"
G Hub Cap Mount 6.25"-8 TPI
FOR AXLE MODELS: DANA SPICER EATON: 225P, 230P, P-22 FRUEHAUF: PRO-PAR
MERITOR: TP HENDRICKSON: HP
INGERSOLL: A24H, A24S, F24
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
38
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
04-15502-021 X N/A N/A No N/A No
04-15502-022 X N/A N/A No N/A Yes
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
14-15502-509 RH X Steel or Aluminum Cast Yes No No
14-15502-511 RH X Steel or Aluminum Cast Yes No Yes
14-15502-510 LH X Steel or Aluminum Cast Yes No No
14-15502-512 LH X Steel or Aluminum Cast Yes No Yes
14-15502-625X30 RH X Aluminum Cast Yes No Yes
14-15502-626X30 LH X Aluminum Cast Yes No Yes
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 8.62" Drum (03-123406-002)
14-15502-304 RH X Steel or Aluminum Cast Yes No Yes
14-15502-305 LH X Steel or Aluminum Cast Yes No Yes
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
14-15502-352 X Steel Cast Yes No No
14-15502-503 X Steel Cast Yes No Yes
14-15502-502 X Aluminum Cast Yes No No
14-15502-504 X Aluminum Cast Yes No Yes
14-15502-600X30 X Steel X-30 Yes No No
14-15502-602X30 X Steel X-30 Yes No Yes
14-15502-601X30 X Aluminum X-30 Yes No No
14-15502-603X30 X Aluminum X-30 Yes No Yes
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum (03-123365-002)
14-15502-456 X Steel Cast Yes No No
14-15502-458 X Steel Cast Yes No Yes
14-15502-457 X Aluminum Cast Yes No No
14-15502-459 X Aluminum Cast Yes No Yes
HUB PILOTED— Hub and Drum Assemblies With 16.5" X 8.62" Drum (03-123406-002)
14-15502-191 X Steel Cast Yes No No
14-15502-193 X Steel Cast Yes No Yes
14-15502-192 X Aluminum Cast Yes No No
14-15502-194 X Aluminum Cast Yes No Yes
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 8.62" Drum (03-123520-002)
14-15502-552 X Steel Cast Yes No No
14-15502-553 X Steel Cast Yes No Yes
14-15502-554 X Aluminum Cast Yes No No
14-15502-555 X Aluminum Cast Yes No Yes
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
39
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15527-XXX Trailer Hub 10 hole
Inboard Drum Serrated Studs
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 8.62"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 6.06"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.75"
G Hub Cap Hole Pattern 6, 5/16"-18; 6" B.C.
ABS
DESCRIPTION
RING NO.
— —
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum (03-123398-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
40
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15537-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 9.06"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 6.94"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 10.827"
E Wheel Stud Qty. 8"
F Pilot Diameter 8.75"
G Hub Cap Mount 6.25"-8 TPI
FOR AXLE MODELS: DANA SPICER EATON: 225P, 230P, P-22 MERITOR: TP
FRUEHAUF: PRO-PAR HENDRICKSON: HP
INGERSOLL: A24H, A24S, F24
STUDS USED WITH HUB IN ASSEMBLIES
THEAD TYPE
STUD NO. SIZE STYLE WHEEL TYPE USE WITH DRUM TYPE
09-001989 Serr. M22 x 1.5 Hub Piloted Steel Wheel Cast
09-002003 Serr. M22 x 1.5 Hub Piloted Aluminum Wheel Cast
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
04-15537-016 X N/A N/A No N/A No
04-15537-017 X N/A N/A No N/A Yes
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123409-002 or 53-123566-002)
14-15537-080 X Steel Cast Yes No No
14-15537-081 X Steel Cast Yes No Yes
14-15537-078 X Aluminum Cast Yes No No
14-15537-079 X Aluminum Cast Yes No Yes
14-15537-300X30 X Steel X-30 Yes No No
14-15537-302X30 X Steel X-30 Yes No Yes
14-15537-301X30 X Aluminum X-30 Yes No No
14-15537-303X30 X Aluminum X-30 Yes No Yes
Note:Other Combinations are avaiable. For information please call the specifications department
Not All of the numbers listed above are stocking items, some may have lead times involved 41
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15541-XXX Trailer Nub 10 Hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM218210 HM218248 10.827"
275mm
OUTER BEARING
CUP CONE
HM212011 HM212049
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 6.93"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 4.74"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 10.827"
E Wheel Stud Qty. 8"
F Pilot Diameter 9.00"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, JE, JH, 23L, 23R
DEXTER: D200K, D2225K
HENDRICKSON: HN
INGERSOLL: A22H, A22S, A22T, DC22H, F22
K-B: KBW-KBS
MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD
STD. FORGE: A-22H, A-22S, A-22T
WESTPORT: F3W-1600, F3W-1800/2000, F3W-1800D/2000D
ABS
DESCRIPTION
RING NO.
— —
42
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
HUB PILOTED — Hub and Drum Assemblies With 16.5" x 7" Drum
(03-123207-002 or 53-123537-002
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
43
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15571-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM218210 HM218248 11.25"
OUTER BEARING
CUP CONE
HM212011 HM212049
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 6.93
B Outer Hub Cap Face To Inner Brg.
Cup Seat 4.74"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty 10"
F Pilot Diameter 8.78"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, JE, JH, 23L, 23R
DEXTER: D200K, D2225K
HENDRICKSON: HN
INGERSOLL: A22H, A22S, A22T, DC22H, F22
K-B: KBW-KBS
MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD
STD. FORGE: A-22H, A-22S, A-22T
WESTPORT: F3W-1600, F3W-1800/2000, F3W-1800D/2000D
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
44
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum (03-123207-002)
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum (03-123207-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
45
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15593-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM518410 HM518445 11.250"
OUTER BEARING
CUP CONE
HM518410 HM518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 9.06"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 6.94"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.78"
G Hub Cap Mount 6.5"-8 TPI
ABS
DESCRIPTION
RING NO.
09-001868 100 Tooth
46
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5” X 7” Drum (03-123207-002)
14-15593-275 RH X Steel or Aluminum Cast Yes No Yes
14-15593-276 LH X Steel or Aluminum Cast Yes No Yes
HUB PILOTED — Hub and Drum Assemblies With 16.5” X 7” Drum (03-123207-002)
14-15593-260 X Steel Cast Yes No Yes
14-15593-261 X Aluminum Cast Yes No Yes
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
47
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15656-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM518410 HM518445 11.250"
OUTER BEARING
CUP CONE
HM518410 HM518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 8.08"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 5.96"
C Distance Between Cups 4.5"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.78"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
48
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
49
TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15857-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM218210 HM218248 11.250"
OUTER BEARING
CUP CONE
HM212011 HM212049
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 6.93"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 4.74"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty 10"
F Pilot Diameter 8.75"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, JE, JH, 23L, 23R
DEXTER: D200K, D2225K
HENDRICKSON: HN
INGERSOLL: A22H, A22S, A22T, DC22H, F22
K-B: KBW-KBS
MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD
STD. FORGE: A-22H, A-22S, A-22T
WESTPORT: F3W-1600, F3W-1800/2000, F3W-1800D/2000D
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
50
TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16" X 7" Drum
(03-123207-002 or 53-123537-002)
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 8.62" Drum ( 53-123544-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
51
ULTRA LITE WEIGHT TP TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15944-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM518410 HM518445 11.250"
OUTER BEARING
CUP CONE
HM518410 HM518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 8.08"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 5.96"
C Distance Between Cups 4.500"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.77"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
52
ULTRA LITE WEIGHT TP TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
53
LITE WEIGHT TP TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15968-XXX Trailer Hub 10 hole
Outboard Drum Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM518410 HM518445 11.250"
OUTER BEARING
CUP CONE
HM518410 HM518445
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 8.08"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 5.96"
C Distance Between Cups 4.50"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.77"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
54
LITE WEIGHT TP TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
STUD PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum (03-123207-002)
HUB PILOTED — Hub and Drum Assemblies with 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
55
LITE WEIGHT TN TRAILER HUBS
DAYTON NO. DESCRIPTION TYPE
04-15984-XXX Trailer Hub 10 hole
Serrated Studs
INNER BEARING
CUP CONE BOLT CIRCLE
HM218210 HM218248 11.250"
OUTER BEARING
CUP CONE
HM212011 HM212049
DRAWING
REFERENCE ITEM DIMENSION
A Overall Length 6.93"
B Outer Hub Cap Face To Inner Brg.
Cup Seat 3.35"
C Distance Between Cups 3.34"
D Bolt Circle Diameter 11.25"
E Wheel Stud Qty. 10"
F Pilot Diameter 8.77"
G Hub Cap Hole Pattern 6, 5/16"-18; 5.5" B.C.
FOR AXLE MODELS: DANA SPICER EATON: D-22, K-22, J, JE, JH, 23L, 23R
DEXTER: D200K, D2225K
HENDRICKSON: HN
INGERSOLL: A22H, A22S, A22T, DC22H, F22 A-22S
K-B: KBW-KBS
MERITOR: RN, RQ, TKN, TN, TQ, TQC, TQD
STD. FORGE: A-22H, A-22S, A-22T
WESTPORT: F3W-1600, F3W-1800/2000, F3W-1800D/2000D
ABS
DESCRIPTION
RING NO.
09-001867 100 Tooth
56
LITE WEIGHT TN TRAILER HUBS
HUB PART HAND CUPS WHEEL DRUM STUDS INNER / OUTER ABS
NUMBER TYPE TYPE NUTS
HUB PILOTED — Hub and Drum Assemblies With 16.5" X 7" Drum
(03-123207-002 or 53-123537-002)
Note: Other combinations are available. For information please call the specifications department 1-888-725-9355.
Not all of the numbers listed above are stocking items, some may have lead times involved.
57
CROSS REFERENCE
GUNITE # MERITOR # COMMENTS GUNITE # MERITOR # COMMENTS
58
CROSS REFERENCE (Cont’d.)
GUNITE # MERITOR # COMMENTS WEBB # MERITOR # COMMENTS
TX802K 47-09715-002 61548 03-120933-002
TX877K 47-14018-007 61566 03-120516-002
TY454K 47-14938-001 61586 03-122806-002
TY745K 47-07841-008 61727 03-120442-002
TY746K 47-14068-007 61733 13-120142-002
61733 13-120140-002
61780 03-120754-002
WEBB # MERITOR # COMMENTS
61788 03-120936-002
1020 04-15571-004 61791 03-120149-002
1099 04-15571-004 62115B 13-122038-002
1320 04-15502-002 62117 03-122266-002
1391 04-15502-002 62200 03-012582-002
1521 05-15632-001 62240 03-120574-002
1528 05-15632-001 62358 03-122488-002
1622 04-15675-002 62997 03-122009-002
1623 04-15675-002 62997 03-123430-002
2023 04-15501-013 With Bearing 62998 03-123200-002
Cups NO ABS 63035 85-123203-002
2023 04-15501-014 With Bearing 63035 03-122011-002
Cups and ABS 63617 03-122963-002
2023 04-15571-004 Same As 04-15501 63647 03-122963-002
2091 04-15571-004 64018 03-120705-002
2323 04-15502-002 64404 03-122561-002
2523 05-15632-001 64405 03-122562-002
2643 04-15675-002 64406 03-120459-002
2653 04-15828-002 64408 03-120553-002
2656 04-15828-002 64414 03-122575-002
7015 47-14054-002 64420 03-120517-002
7315 47-14054-002 64425 03-122597-002
7520 47-14018-007 64428 03-120556-002
8320 47-07791-003 64453 03-122314-002
8520 47-07791-013 64478 03-122078-002
62117 03-123500-002 64481 03-120981-002
66864 03-123207-002 64489 03-123020-002
66884 03-123365-002 65266 03-123427-002
68931 03-120376-002 65514 03-122104-002
20231UH3 14-15501-050 65516 03-120855-002
20231UH3 14-15501-050 65545 03-123366-002
20231UH3T 14-15501-074 66250 03-123025-002
20231UH3T 14-15501-074 66366 03-123302-002
20231UQML 14-15501-378 66817 03-122513-002
20231UQML 14-15501-378 66864 03-123207-002
20231UQMLT 14-15501-506 66865 03-122948-002
20231UQMLT 14-15501-506 66865 85-123297-002
20231UQMR 14-15501-377 66873 03-123397-002
20231UQMR 14-15501-377 66875 03-123409-002
20231UQMRT 14-15501-505 66892 03-122453-002
20231UQMRT 14-15501-505 66893 03-122607-002
60876 03-120877-002 66893 03-122978-002
61529 03-122529-002 66895 03-122550-002
59
CROSS REFERENCE (Cont’d.)
WEBB # MERITOR # COMMENTS WEBB # MERITOR # COMMENTS
67101 03-122978-002 68897 03-120743-002
67518 03-122822-002 68903 03-012480-002
67518 03-122222-002 68921 03-122506-002
68012 03-122290-002 68927 03-120376-002
68012 03-122027-002 68942 03-122455-002
68013 03-122239-002 68946 03-122284-002
68730 03-122126-002 68958 03-122925-002
68730 03-122518-002 68981 03-122490-002
68732 03-123058-002 68981 03-122683-002
68733 03-122126-002 68988 03-120988-002
68760 03-122603-002 69877B 53-123583-002
68765 03-120586-002 69996B 53-123537-002
68765 03-120586-002 75209A 47-14018-013
68897 03-122600-002
60
CROSS REFERENCE (Cont’d.)
HAYES COMPONENTS HAYES CURRENTLY MERITOR
DRUM BACK NO. DRUM BAND NO. PART NUMBER AVAILABLE PART NO.
90175 87311 90176B X 53-123599-002
X 53-123600-002
91724 91480 91725B X 53-123601-002
91722 91480 91723B X 53-123602-002
91481 91480 91482B 53-123603-002
91439 91480 91438B 53-123604-002
88435 87369 88739B X 53-123605-002
91507 87369 90137B X 53-123606-002
91052 87298 91049B X 53-123607-002
91264 87298 91265B X 53-123608-002
91024 91028 87945B 53-123609-002
X 53-123627-002
61
CROSS REFERENCE (Cont’d.)
62
ROTOR CROSS REFERENCE
WEBB MERITOR PART NO. GUNITE MERITOR PART NO
54102 23-122687-002 R6115 23-122728-002
54102 23-123468-002 R6115A 23-122962-002
54103 23-122700-002 R6145 23-122945-002
54103 23-123434-002
54104 23-122688-002
BENDIX MERITOR PART NO.
54104 23-123459-002
54104 23-123486-002 141269 23-122700-002
54104 23-123487-002 141269 23-123434-002
54104 23-123495-002 141270 23-122691-002
54105 23-123480-002 141271 23-122687-002
54106 23-123296-002 141271 23-123468-002
54106 23-123495-002 141272 23-122729-002
54251 23-122527-002 141272 23-123440-002
54251 23-123458-002 141273 23-122527-002
54301 23-122729-002 141274 23-122701-002
54301 23-123440-002 141274 23-123460-002
54301 23-123443-002 141275 23-122703-002
54351 23-122691-002 141276 23-122743-002
54351 23-123439-002 141475 23-123572-004
54352 23-122743-002 141476 23-123573-004
54769 23-123573-004 141493 23-122920-002
54770 23-123572-004 141494 23-122897-002
54771 23-122897-002 141585 23-122688-002
54771 23-123552-004 141606 23-122693-002
141858 23-103887-002
141874 23-123296-002
GUNITE MERITOR PART NO.
141490 23-123046-002
D5054A 23-123495-002 141608 23-122945-002
D6052 23-122729-002 141627 23-122962-002
D6052 23-123440-002 141628 23-122728-002
D6054 23-122687-002
D6054 23-123468-002
D6054A 23-122688-002
D6054A 23-123459-002 GM MERITOR PART NO.
D6054A 23-123486-002 15514406 23-122729-002
D6054A 23-123487-002 15514492 23-122693-002
D6054C 23-122700-002 15515786 23-122687-002
D6054C 23-123434-002 15579020 23-123041-002
D6054C 23-123480-002 15611098 23-122688-002
D6059 23-122693-002 15661543 23-123296-002
D6128 23-122701-002 15579754 23-123046-002
D6128 23-123460-002
D6128A 23-122920-002
D6128A 23-123494-002
FORD MERITOR PART NO.
D6133 23-122897-002
D6151 23-123489-002 E3HZ1102A 23-122691-002
D6183 23-123552-004
R6054C 23-123443-002
63
NOTES
64
ARVINMERITOR AFTERMARKET PARTS WARRANTY
We warrant all new parts for one year from date of shipment to the buyer against defective material or
workmanship (but not against damage caused by accident, abuse or improper installation, maintenance
or repair) when such parts are used on vehicles the specifications of which have been approved by our
Engineering Department.
As the exclusive remedy under this warranty, we will, at our option, repair or replace such parts free of
charge, or take back the nonconforming parts and refund the monies paid by buyer for such parts, if found
on examination by us to be nonconforming and if any necessary return charges are prepaid.
If it is necessary to return any parts under this warranty, buyer agrees not to make any deduction on
account thereof from remittances on current accounts while claims are in the process of disposition. Any
expense incurred without our consent for repairs or replacement will not be allowed.
Only genuine ArvinMeritor replacement parts are covered by this aftermarket parts warranty.
Information contained in this publication was in effect at the time the publication was approved
for printing and is subject to change without notice or liability. ArvinMeritor, Inc. reserves the
right to revise the information presented or discontinue the production of parts at any time.
