ISA–RP42.00.01–2001
Nomenclature for
Instrument Tube Fittings
NOTICE OF COPYRIGHT
This is a copyrighted document and may not be copied or distributed in any
form or manner without the permission of ISA. This copy of the document was
made for the sole use of the person to whom ISA provided it and is subject to
the restrictions stated in ISA’s license to that person. It may not be provided to
any other person in print, electronic, or any other form. Violations of ISA’s
copyright will be prosecuted to the fullest extent of the law and may result in
substantial civil and criminal penalties.
ISA–The Instrumentation,
Systems, and
Automation Society
ISA-RP42.00.01
Nomenclature for Instrument Tube Fittings
ISBN: 1-55617-784-4
Copyright © 2002 by the Instrumentation, Systems, and Automation Society. All rights reserved. Not for
resale. Printed in the United States of America. No part of this publication may be reproduced, stored in
a retrieval system, or transmitted in any form or by any means (electronic mechanical, photocopying,
recording, or otherwise), without the prior written permission of the Publisher.
ISA
67 Alexander Drive
P.O. Box 12277
Research Triangle Park, North Carolina 27709
USA
–3– ISA–RP42.00.01–2001
Preface
This preface, as well as all footnotes and annexes, is included for information purposes and is not part of
ISA-RP42.00.01-2001.
The standards referenced within this document may contain provisions which, through reference in this
text, constitute requirements of this document. At the time of publication, the editions indicated were
valid. All standards are subject to revision, and parties to agreements based on this document are
encouraged to investigate the possibility of applying the most recent editions of the standards indicated
within this document. Members of IEC and ISO maintain registers of currently valid International
Standards. ANSI maintain registers of currently valid U.S. National Standards.
This document has been prepared as part of the service of ISA–The Instrumentation, Systems, and
Automation Society, toward a goal of uniformity in the field of instrumentation. To be of real value, this
document should not be static but should be subject to periodic review. Toward this end, the Society
welcomes all comments and criticisms and asks that they be addressed to the Secretary, Standards and
Practices Board; ISA; 67 Alexander Drive; P. O. Box 12277; Research Triangle Park, NC 27709;
Telephone (919) 549-8411; Fax (919) 549-8288; E-mail: standards@isa.org.
The ISA Standards and Practices Department is aware of the growing need for attention to the metric
system of units in general, and the International System of Units (SI) in particular, in the preparation of
instrumentation standards. The Department is further aware of the benefits to USA users of ISA
standards of incorporating suitable references to the SI (and the metric system) in their business and
professional dealings with other countries. Toward this end, this Department will endeavor to introduce
SI-acceptable metric units in all new and revised standards, recommended practices, and technical
reports to the greatest extent possible. Standard for Use of the International System of Units (SI): The
Modern Metric System, published by the American Society for Testing & Materials as IEEE/ASTM SI 10-
97, and future revisions, will be the reference guide for definitions, symbols, abbreviations, and
conversion factors.
It is the policy of ISA to encourage and welcome the participation of all concerned individuals and
interests in the development of ISA standards, recommended practices, and technical reports.
Participation in the ISA standards-making process by an individual in no way constitutes endorsement by
the employer of that individual, of ISA, or of any of the standards, recommended practices, and technical
reports that ISA develops.
EVEN IF ISA IS UNAWARE OF ANY PATENT COVERING THIS STANDARD, THE USER IS
CAUTIONED THAT IMPLEMENTATION OF THE STANDARD MAY REQUIRE USE OF TECHNIQUES,
PROCESSES, OR MATERIALS COVERED BY PATENT RIGHTS. ISA TAKES NO POSITION ON THE
EXISTENCE OR VALIDITY OF ANY PATENT RIGHTS THAT MAY BE INVOLVED IN IMPLEMENTING
THE STANDARD. ISA IS NOT RESPONSIBLE FOR IDENTIFYING ALL PATENTS THAT MAY
REQUIRE A LICENSE BEFORE IMPLEMENTATION OF THE STANDARD OR FOR INVESTIGATING
THE VALIDITY OR SCOPE OF ANY PATENTS BROUGHT TO ITS ATTENTION. THE USER SHOULD
CAREFULLY INVESTIGATE RELEVANT PATENTS BEFORE USING THE STANDARD FOR THE
USER’S INTENDED APPLICATION.
ISA–RP42.00.01–2001 –4–
HOWEVER, ISA ASKS THAT ANYONE REVIEWING THIS STANDARD WHO IS AWARE OF ANY
PATENTS THAT MAY IMPACT IMPLEMENTATION OF THE STANDARD NOTIFY THE ISA
STANDARDS AND PRACTICES DEPARTMENT OF THE PATENT AND ITS OWNER.
The following individuals served as members of the SP42 Committee, who reaffirmed RP42.1 in 1992:
NAME COMPANY
The following individuals served as members of the SP42 Committee, who revised RP42.00.01 in 2001:
This published Recommended Practice was approved for publication by the ISA Standards and Practices
Board on 12 November 2001.
–5– ISA–RP42.00.01–2001
NAME COMPANY
______
* One vote per company.
Contents
1 Scope..................................................................................................................................................... 9
2 Purpose.................................................................................................................................................. 9
3 Definitions .............................................................................................................................................. 9
4 Specifications....................................................................................................................................... 10
5 Fittings ................................................................................................................................................. 12
1 Scope
This Recommended Practice defines nomenclature for tube fittings most commonly used in
instrumentation. It is not intended as a substitute for manufacturers' catalog numbers, nor does it apply to
special fittings. This Recommended Practice is intended to apply to mechanical flared and flareless tube
fittings as commonly used in instrument tubing systems.
2 Purpose
The purpose of this Recommended Practice is to aid in the proper specification and application of
instrument tube fittings by standardizing nomenclature. Proper use of this Recommended Practice
should result in data that
b) permits better communications between manufacturer, vendor, purchaser, and ultimate user;
c) provides standardized nomenclature to be used by drafting, billing, purchasing, and stores groups;
and
3 Definitions
3.2 branch:
the connection of a fitting tee that is in a 90° relation to the other two connections.
3.3 bulkhead:
a partition, panel, or bracket through which a fitting is installed.
3.5 ferrule:
a tube fitting component that provides the sealing and/or holding function of the flareless fitting on the
tubing.
3.8 port:
a fitting assembly connection.
3.9 run:
that portion of a fitting assembly having two ports on the same axis.
3.10 sleeve:
a flared fitting component that provides support from the nut shoulder to the flared tube end.
4 Specifications
CAUTION USER SHOULD APPLY FACTORY SPECIFICATION FOR THE PROPER APPLICATION
OF FITTINGS.
b) Fitting material
e) Flared or flareless
NOTE 2 — For SI letter symbols used on text, see ANSI/IEEE 260.1-1993 and ISO 1000; for drawings requiring capitalization, see
ASME Y14.38-1999.
EXCEPTION: Special tube fittings not covered by this Recommended Practice, including fittings with
coincident inch (customary U.S. units) and millimeter (SI units) connection sizes, should be specified as
provided in manufacturers’ pertinent data.
When (fractional) inch tubing sizes are in use, the specifications should use (fractional) inch dimensions.
NOTE 1 — For National Standard Pipe Taper (NPT) male or female threads, see ANSI/ASME B1.20.1-1983.
NOTE 2 —American National Standard Dryseal Pipe Threads (NPTF) male or female threads, see ANSI/ASME B1.20.3-1976.
– 11 – ISA–RP42.00.01–2001
EXAMPLES:
MALE CONNECTOR, STAINLESS STEEL, 1/4 IN. OD X 1/4 IN. NPT, FLARELESS (See 5.1) (As
used on drawing.)
FEMALE CONNECTOR, BRASS, 1/2 IN. OD X 1/2 IN. NPTF, FLARED (See 5.2) (As used on
drawing.)
When SI unit tubing sizes are used, the specifications should use SI unit dimensions.
NOTE 1 — For pressure tight joints SI unit pipe taper male or female threads, see ISO 7, Pt 1-94.
NOTE 2 — For non-pressure tight joints SI unit pipe parallel male or female parallel threads, see ISO 228, Pt 1-94.
EXAMPLES:
male connector, brass, 6 mm od x ISO 7-R 1/4 in., flareless (See 5.1) (As used in lower case text.)
male connector, brass, 12 mm od x ISO 7-R 1/2 in., flareless (See 5.1) (As used in lower case text.)
The ports for each tee or cross tube fitting (see 5.8 through 5.13) should be specified in the order
indicated by the port numbers as noted adjacent to the detailed symbol.
EXAMPLES:
male run tee, brass, 1/4 in. od x 1/4 in. npt x 1/4 in. od, flareless (See 5.9) (As used in lower case
text.)
4.5 Abbreviations
Abbreviations not appearing in ASME Y14.38-1999 should be defined in the document in which they
appear.
EXAMPLE:
MALE CONNECTOR, STAINLESS STEEL, 1/4 IN. OD X 1/4 NPT, FLARELESS, BORED THROUGH
(See 5.1) (As used on drawing.)
ISA–RP42.00.01–2001 – 12 –
5 Fittings
NOTE — Detailed symbols are shown to illustrate the common name tube fittings.
5.20 Plug
Annex A — References
This annex is included for information purposes and is not part of this recommended practice.
The following standards contain provisions that, through reference in this text, constitute provisions of this
ISA Recommended Practice. At the time of publication, the editions indicated were valid. All standards
are subject to revision, and parties to agreements based on this Recommended Practice are encouraged
to investigate the possibility of applying the most recent editions of the standards indicated below.
ANSI/IEEE 260.1-1993 American National Standard Letter Symbols for Units of Measurement
(SI Units, Customary Inch-Pound Units, and Certain Other Units)
IEEE/ASTM SI 10-1997 Standard for Use of the International System of Units (SI): The Modern
Metric System
ISO 7, Pt 1-94 Pipe Threads Where Pressure Tight Joints are Made on Threads -
Part 1: Dimensions, Tolerances and Designation (3rd ed.)
ISO 228, Pt 1-94 Pipe Threads Where Pressure Tight Joints are Not Made on Threads -
Part 1: Dimensions, Tolerances and Designation (3rd ed.)
ISA–RP42.00.01–2001 – 20 –
ISO 1000, 1992 SI Units and Recommendations for the Use of Their Multiples and of
rd
Amendment 1 - 1998 Certain Other Units (3 ed.)
ISA is an American National Standards Institute (ANSI) accredited organization. ISA administers United
States Technical Advisory Groups (USTAGs) and provides secretariat support for International
Electrotechnical Commission (IEC) and International Organization for Standardization (ISO) committees
that develop process measurement and control standards. To obtain additional information on the
Society’s standards program, please write:
ISA
Attn: Standards Department
67 Alexander Drive
P.O. Box 12277
Research Triangle Park, NC 27709
ISBN: 1-55617-784-4
