Engineering Graphics Question Bank
Engineering Graphics Question Bank
F.E. All
Branches
2 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
Compiled By
ICEM
3 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
2009- 03
Day – Date- Dec. 2009
Engineering Graphics I
Time – 4 Hours Max. Marks: 100
1. Answer one question from each unit. Answers three questions from section-I and three questions from section- II.
2. Answer to the two sections should be drawn on separate drawing sheet.
3. Figures to the right indicate full mark.
4. Use of calculator is allowed.
5. Assume suitable data, if necessary.
6. Retain all the construction line.
SECTION I
UNIT-I: CURVES
Q.1) A The foci of an ellipse are 90 mm apart & the minor axis is 65mm long.
Determine the length of the major axis & draw half ellipse by concentric
7
circle method & other half by oblong method. Draw tangent & normal to the ellipse
at 25mm away from it.
B A circle of 40mm diameter rolls on a horizontal line. Draw the curve traced out by a
point capital R on the circumference for one half revolution of the circle. For the
8
remaining half revolution the circle rolls on a vertical line. The point R is vertically
above the center of the circle in the starting position.
OR
Q.2) A A jet of water is issuing through on orifice of 50 diameters, fitted To a vertical side of
a tank. The centre of the orifice is 1.5 m above the ground and centre of the jet
touches the ground at a distance of 2.5 m from the vertical orifice. Draw the locus of
the centre of the jet, which is just issuing from the orifice, till it reaches the ground. 7
Name the curve.
4 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
B An inelastic string 140 mm long has its one end attached to the circumference of a circular
disc of 35 mm diameter. Draw the curve traced out by the other end of the string, when it is 8
completely wound around the disc, keeping the string always tight.
Q.3) Figure 3 show the pictorial views of an objects. Using First Angle Projection Method draw (a)
Front View; (b) Top View; (c) Side View, by obtaining Front View in the direction of’ X ’, Also, 16+4
obtain the sectional views for the cutting plane shown in the figure.
(Fig.3 )
OR
Q.4) Fig. 4 show the isometric view of the machine component draw the following views i)
Elevation 16+4
ii) End View
5 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
(Fig. 4)
Q5) Fig.no.5 shows FV, incomplete TV & auxiliary view redraw the complete views and
complete TV.
13+2
(Fig.No.5)
OR
Q6) Fig. 6 shows the TV partially auxiliary FV & incomplete FV redraw the given views &
complete the FV
6 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
13+2
(Fig.NO.6)
SECTION – II
16+4
(Fig.7)
OR
Q8) Draw the Isometric view of the object show in Fig.8
7 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
16+4
(Fig.No.8)
Q9) Fig.9 shows FV & TV of machine part i) Redraw the FV ii) Draw the sectional LHS (A-
16+4
(Fig.9)
8 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
OR
Fig.10 shows FV & TV of an object i) draw the sectional FV ii) Draw the sectional TV
along B-B iii) LHSV
Q10)
16+4
(Fig.10
Unit-VI
a) Wing Nut
OR
Q12)
Draw to the proportion free hand sketches of any two:
b) Lock Nut
05+05
c) Single Riveted lap Joint
9 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
Q.3) Figure shows the pictorial views of an object. Using First Angle
Projection Method draw (a) Front View; (b) Top View; (c) Side
View, by obtaining Front View in the direction of’ X’, Also,
obtain the sectional views for the cutting plane shown in 20
the figure.
OR
i) Elevation
20
ii) End View
10 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
11 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
12 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
13 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
14 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
15 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
16 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
17 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
18 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
19 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
20 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
21 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
22 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
23 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
24 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
25 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
26 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
27 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
28 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
29 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
30 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
31 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
32 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
33 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
34 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
35 "I hear and I forget. I see and I remember. I do and I understand." -- Confucius
OR
Q8)
Draw the Isometric view of the object shown in figure 20
