LK2000 : Power Genset Data Acquisition [ Ref.

LK2000 ]
LK2000 : Power Genset Data Acquisition [ Ref. LK2000 ]

IMPORTANT SAFETY INSTRUCTIONS

When installing and using this electrical device, basic safety precautions MUST always
be followed very strictly, including the following: Failure to follow these instructions may
result in injury, damage and/or mal-functioning of the device. Prior to connecting the
device, read the user's manual completely for proper connection and operating
information. This manual provides safety, installation, and operating instructions. This
will help you to get the maximum performance and service life that the unit is designed
to offer. It includes all important instructions for the safe use of the device, and for
obtaining factory services if necessary. Future services and/or storage issues may arise
and require reference to this manual. Follow standard safety requirements when wiring
and connecting a power source and sensors or other accessories to the device. Failure
to do so could result in injury or damage to equipment. Make sure the proper input
voltage is applied to the controller. Improper voltage will result in damage to the unit.
Use caution when removing the controller from its case, there may be live voltage
present at the terminals. Always consult to qualified electronics engineer for
maintenance and repairing.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE OVER 80%RH.

All terminal screws must be tightened securely. Terminal screws not properly secured
can cause an electrical short and/or electrical spark that may damage the device.
Terminal screws improperly secured may fall into equipment causing possible damage
to device.

WARNING! High voltage is present inside the device with the AC Input power cord
connected. FOR OPERATOR & LK2000 Unit SAFETY, THIS EQUIPMENT MUST BE
PROPERLY GROUNDED. Observe safety precautions at all times. Do not touch
electronic circuits when power is applied. Do not disassemble the device. To reduce the
risk of electric shock, do not use extension cord to connect device to electric supply;
provide a properly located outlet.

Important: Firmware version of controller must match the version indicated on

the bottom front cover of the manual
LK2000 : Power Genset Data Acquisition [ Ref. LK2000 ]

LK2000 Introduction
Congratulations on your purchase of “Power Genset Data Acquisition, LK2000”
monitoring unit. The unit is specifically designed for unmanned and/or remote station for
round the clock environmental measurement and control.
Whenever round-the-clock, on 24x7x365 basis electrical operation is required, users
must arrange appropriate control unit. High Tech equipments are designed to operate
without any interruption; its supportive infrastructure usually doesn't enjoy such rigorous
dependability. Among other supporting equipments, “Electrical Power” Generators are
supposed to work on regular basis to provide un-interruptible electrical sources to keep
running all electrical appliances. Environmental conditions for a power generator must be
suitable to initiate a proper power up and transfer sequences. Among all these “Fuel”
remains the major and critical element for power generators. Fuel monitoring, and
predictive alerts for empty tank can reduce un-predictable power outages.
SOLUTION
What's needed is an intelligent approach to these environmental measurement and
control to improve the work flow and performance of the high tech equipment in building.

LK2000, is here to take control of Power Genset

LK2000 : Power Genset Data Acquisition [ Ref. LK2000 ]

LK2000 Features
Congratulations on your purchase of “Power Genset Data Acquisition, LK2000”,
monitoring unit. The unit is specifically designed for unmanned operations. The unit
measures predetermined electrical parameters, takes decision and raise local & remote
alarms. Additionally, provides several other facilities that helps site supervisor to take
care of power generations more efficiently and accurately.
Careful use of this device will provide years of reliable service.

LK2000 Salient Features

z Fuel Consumption Measurement
z KESC & Generator, Voltage/Current Measurement
z KESC & Generator, Run/Stop Hour Measurement
z Building Energy Measurement
z Local & Remote Alerts, Data Streaming and Logging
LK2000 Specification
z Microchip Fail-Safe Microcontroller
z Panel Display (20 by 4 Lines Alphanumeric LCD)
z Quad Band GSM Links (SMS, TCP/UDP, HTTP)
z Quad Power Sources Inlet (Twin 220AC, 24DC, 9DC)
z SSD Storage, Live Data Logging
LK2000 : Power Genset Data Acquisition [ Ref. LK2000 ]

LK2000 Specification
DATA ACQUISITION SPECIFICATION

Analog Measurement

KESC: 180~250VAC, 50/60Hz, 3-Phase, 600kVA

Power Genset: 180~250VAC, 50/60Hz, 3-Phase, 600kVA

FUEL: Capacitive Sensor, 0~5VDC (height 8”~24”)

Analog measurement are sampled at every second, while unit updates all alarm and
messages including any required control every one minute. LK2000 also performs unit
self-check to find any possible sensor failure before taking any electrical measurement.

High Current Measurement

AC Current measurement uses non-contact method. This ensure no wire-cut on high

tension wires, and thus safe to use.

Digital Measurement

There are four optional sensing port available on LK2000 to detect any ON/OFF state for
any electrical or mechanical changes. These ports are protected via opto isolators.
States of all four digital port are logged and transferred to central data server. User can
configure alarm levels to Hi or Lo for any digital source. The transition on that digital port
triggers the alarm.
LK2000 : Power Genset Data Acquisition [ Ref. LK2000 ]

LK2000 Specification
TECHNICAL SPECIFICATION

Power Voltages
™ Main Unit Supply, AC 220V @ 50Hz
™ Multiple AC Power IEC Sockets for redundancies
™ Main Unit Consumption 150mA to 3000mA approx.
™ Program retention upon power failure via non-volatile memory
™ Fuse Protection on all AC 220V terminals
™ Varistor Protected Main Supply
™ Internal rechargeable battery
note: Main Unit Supply can vary between 180 VAC to 250 VAC

Operating Environment
z 0 ºC to 80 ºC (32 ºF to 176 ºF)
z 0 to 90% RH non condensing

Mechanical
z Case: metallic body
z Overall dimension (not specified)

Central Controller
z Microchip microcontroller PIC18LFXXXX-E/ML
z Processing Speed 5 MIPS
z Watchdog Enabled
z Systems Processing Health Indicator

SSD Storage
z All non-embedded user and factory programs are stored in non-volatile memory.
z Data Logging on EEPROM, multiples of 128 kBytes

Sample/Update Rate
z AC Voltage & Current Measurement, 1 second
z Digital Inputs, 2 second
z Fuel Level Measurement, 2 second
z Alarms Update/Activation, instant (as it is detected)
z Data Logging, on every change of 10% with previous state
z Data Broadcast, programmable

Communication
z Remote Communication Modes are; SMS, HTTP, TCP, UDP
z Local Communication Modes are; RS232C, RS422, USB 2.0
z On-Site Panel Configuration Modes are; Protected PS/2
LK2000 : Power Genset Data Acquisition [ Ref. LK2000 ]

TECHNICAL SUPPORT
Thank you for selecting the GNoor PCtronics product “Power Genset Data
Acquisition, LK2000”. The unit provides maximum possible degree of alarm activation
and safe operation to monitor Power Genset. We strive to make our manuals easy-to-
understand and provide most accurate information. We rely on your feedback to let us
know if we are reaching our goal. If you cannot find the solution to your particular
application, or, if for any reason you need additional technical assistance, you are
requested to send emails to “support@GNoorPCtronics.com”. We also encourage you
to visit our website where you can find technical and non-technical information about our
products and our company. Visit us at http://www.GNoorPCtronics.com for additional
information and FAQs on LK2000 Unit.

WARRANTY
Power Genset Data Acquisition, LK2000, GNoor PCtronics is warranted free from
defects in materials and workmanship for the period specified at the time of sale, the
date of warranty starts from receipt date. This warranty is limited to repairing for any
mal-functioning, at GNoor PCtronics option, any defective component, circuit board, or
module contained within the product with an exception of any electrical burns only when
it is returned to GNoor PCtronics or to a GNoor PCtronics-designated repair facility. In
all cases, the customer is responsible for shipping charges to and from GNoor
PCtronics or the GNoor PCtronics-designated repair facility.

Limitations of Warranty
This limited warranty does not cover any losses or damages resulting from shipment to
or from the customer, or from improper installation, inappropriate environment, abuse,
modifications, adjustments, or unauthorized repair or any electrical burn.

Life support policy

As a general policy, GNoor PCtronics do NOT recommends the use of any of its
products in life support applications where failure or malfunction of the GNoor PCtronics
product can be reasonably expected to cause failure of the HUMAN LIFE supporting
devices or to significantly affect its safety or effectiveness. GNoor PCtronics DOES NOT
RECOMMENDS the use of any of its products in direct patient care. GNoor PCtronics
will not knowingly sell its products for use in such applications unless it receives in
writing assurances satisfactory to GNoor PCtronics that (a) the risks of injury or damage
have been minimized, (b) the customer assumes all such risks, and (c) the liability of
GNoor PCtronics is adequately protected under the circumstances.
