Copyright
Disclaimer
The contents of this document are subject to revision without notice due to
continued progress in methodology, design and manufacturing.
Ericsson shall have no liability for any error or damages of any kind resulting
from the use of this document.
Contents
1.1 Requirements
• The installation CDs for MINI-LINK MANAGER 6.1 and all third party
products:
• Software key; a device that is put on the parallel port of each server/client
• Power off the computer and all peripheral devices prior to installing the
software key; it is sensitive to static electricity.
• Secure the software key in the parallel port and tighten the screws.
• If you had any equipment connected to your parallel port, connect to the
back of the software key.
Warning!
Do not remove the software key from your node while MINI-LINK MANAGER
is running. If you do so, MINI-LINK MANAGER must be restarted and the
software key may be damaged.
Note: It is not recommended to attach any other device to the parallel port
that passes huge amounts of data (for example scanner, disc). A
printer though seems OK to attach to the parallel port.
1.2 Roadmap
The correct installation order for MINI-LINK MANAGER Server Application
is as follows:
4. Microsoft SQL Server 2000 and Service Pack 3 (required only if you want
to install a MINI-LINK Medium Capacity adaptation otherwise the MSDE
2000 will be installed as default)
The design of this roadmap is intended to show which installation steps you will
need to execute depending of the amount of features you want on the server. If
you have Windows 2000 Server already installed, go directly to the Windows
2000 Server configuration chapter. This chapter prepares the server computer
for a MINI-LINK MANAGER Server Application installation.
Look through the roadmap above of what components you need in your system.
Then look through the Adaptation requirements, the Interface requirements and
the Local Manager requirements to identify the options you need to add to the
basic MINI-LINK MANAGER Server Application installation.
Feel free to make notes of what chapters you will have to use to make the
custom installation desired. Then you should not have to refer to any other
installation sections in this manual.
Gather all the TCP/IP address information before you begin installation of 3rd
party software and MINI-LINK MANAGER itself. This should be inserted in the
host files of all connected computers on the network.
Note: All third party products must be installed before the installation of
MINI-LINK MANAGER; otherwise proper configuration will not be
possible.
If you are using MINI-LINK MANAGER with the default MSDE 2000 DB
and you want to install a MINI-LINK Medium Capacity Adaptation you
will need to run an upgrading procedure, from MSDE to Microsoft SQL
Server 2000 Standard Edition, as described in the appendix section.
In order to make the installation easy and smooth you have to make sure that
you have the right hardware as well as the right software installations, especially
WINDOWS 2000, see Windows 2000 Server installation instructions below.
Furthermore you should make sure to install all necessary 3rd party software
products before you start with the MINI-LINK MANAGER installation.
1.2.2 Mappings
When installing a MINI-LINK MANAGER Server Application use the above table
to find what additional installations of third party products you have to make
depending on your adaptation choices. Do likewise with the following sections
containing information for interfaces and local managers.
The time for installation of the required local manager software is after the
installation of MINI-LINK MANAGER Server . Check the overview above to see
when it will have to be done. You should have installed all needed 3rd party
software prior to MINI-LINK MANAGER installation according to this roadmap
otherwise you might face a reinstallation of MINI-LINK MANAGER and all 3rd
party software and / or local managers.
Make sure that you have the correct equipment run Windows 2000 Server and
the MINI-LINK MANAGER platform. See the following specifications for the
hardware requirements (Ericsson specifications):
Note: If parallel port is not present on motherboard and a separate PCI card
adapter is being used, execute the installation procedure described in
Section 1.2.9 on page 18 before continuing with normal installation
procedure.
Check the Windows 2000 installation package if it contains one CD-ROM disc
and one floppy disk.
• Most new servers that are recommended in the above documentation, have
the ability to boot on the installation CD for Windows 2000 directly.
• If this is the case, just power on the server and insert the CD in the
CD-ROM drive.
• If this does not happen, then the server does not have that ability, or it is
due to a setting in the server BIOS.
• If it still does not boot on the CD, you might have to boot on four floppy
disks, which should be included with Windows 2000.
• If the disks are not included, or if the floppy disks are missing, you have
to create them.
• The disks have to be created on a PC where you can use a CD-ROM drive.
• If you are accessing the CD from a character based interface (DOS) then
use the makeboot.exe program by entering makeboot a:.
• If you are accessing the CD from a Windows based computer, open a DOS
prompt window and enter: makeboot a:.
• You will be guided through the creation of the four floppy disks. Start the
installation by inserting the Windows 2000 Installation disk 1 and boot on it.
Note: You must install Windows 2000 on C partition and you do not change
the system directory WINNT. Check if the Regional Option is set
to English (United States) in the Regional Settings window during
Windows 2000 installation. If not, modify it with the Customize button
leaving the default date format: mm/dd/yyyy. During the Windows
2000 installation the Terminal Server must not be installed.
At first logon the "Windows 2000 Configure your Server" dialog appears.
Choose to configure your server later and uncheck the option "Show this
message at system start-up".
If the Windows 2000 system will not boot up because the boot files are corrupt
or missing, use the Windows 2000 Boot Disk. Insert the Boot Disk in drive A:\
and reboot your system. Make sure your computer BIOS is setup to read A: at
boot time. If and when the system has booted up and Windows 2000 is started,
copy the three files (BOOT.INI, NTDETECT.COM and NTLDR) back from A:\ to
C:\ by dragging and dropping the files with My Computer.
Begin installation of Microsoft Windows 2000 Server with the creation of the
partition(s). It is recommended to only have one partition on the server. Since
the recommendation is to have just one partition on the drive, that partition will
automatically become a boot partition.
If a RAID solution is to be used, with multiple hard drives in a RAID set, you will
have to configure and initialise the logical drive before you proceed. Instructions
on how to do this should be included in the shipment of the server.
Caution!
If you intend not to follow the recommendations about hard disk partitioning,
please note that MINI-LINK MANAGER can only be installed on the C:\ partition
or possibly the D:\ partition. You must not use partitions with drive letters E:\
to Z:\.
In order for MINI-LINK MANAGER to work properly, the computer name must
not consist of more than 8 characters. Otherwise the internal communication
will be corrupt.
Computer names and nodes aliases must contain only alphanumeric characters
(any special character is allowed).
An increase of the page file size is required. Go to Control Panel -> System ->
Performance and choose Page file size. Minimum should be as automatically
stated in the text input field (with 768 MB RAM in the server). Maximum should
be twice the size of physical RAM (with 768 MB RAM in the server, it should be
1536). Close all the windows. Windows 2000 might require a reboot after this
(if the page file is smaller than before).
1.2.3.7 DrWatson
˙ drwtsn32 -i
˙ drwtsn32
In the window that appears, tick the top three boxes under Options and leave
the rest. Set the log directory to C:\winnt (substitute c: for the appropriate
drive letter).
Before you continue the server configuration you should receive from the local
network administrator the following informations:
Note that both, a Domain Controller and a DNS server, must be present on the
network to ensure that MINI-LINK MANAGER Server works properly.
If a DNS server is not present, then the MINI-LINK MANAGER Server could be
configured to be a DNS server.
This can be done in two ways either you configure MINI-LINK MANAGER
Server as a DC and during the procedure described in the DC section you
promote it to be also a DNS server, or you must follow the procedure outlined
in the section "DNS".
If a Domain Controller does not exist on the network then the MINI-LINK
MANAGER Server could be configured as a Domain Controller. If this is the
case then the MINI-LINK MANAGER server IP address must be a static one.
Refer to "Domain Controller" section to configure MINI-LINK MANAGER Server
as a DC.
If the equipments are accessed through a router a Gateway IP, a DNS Host IP,
and a DNS IP are required. When Windows is installed and ready to use, test
the connection by using the PING command, and try to ping the equipment or
other computers.
3. The Wizard window then asks to install Active directory, just press Next.
4. In the next window choose "Domain controller for a new domain" and
press Next.
5. In the next window choose "Create a new domain tree" and press Next.
6. In the next window choose "Create a new forest for domain trees" and
press Next.
7. In the next window indicate "Full DNS name for new domain", insert the
name with a dot "name." and press Next.
8. In the next window indicate "Domain netbios name" leaving the default
name.
9. In the next two windows the location is showed. Leave the default value.
11. In "Active directory installation Wizard" select yes, install and configure
DNS on this computer (recommended).
12. In the next window choose "Permission compatible with pre W2K servers"
and press Next.
13. In the next window indicate the Administrator password for domain
management and press Next.
15. If the installation asks you to insert W2K disk please insert the 2000 Server
CD rom.
The installation will start and after the system reboot the machine is ready.
1.2.3.11 DNS
The PCs participating to the network of the DC PC, including the MINI-LINK
MANAGER Server PC, must be first configured as Member of WORKGROUP,
with static IP addresses and with DNS Server addresses the IP address of the
DC PC. Then they must join to the domain defined on the DC PC.
You will use Windows 2000 Service Pack 3 to update the system files on the
computer. Those can be found on the MINI-LINK MANAGER CD:
• To ensure that the system always has the latest system files installed, this
operation will have to be repeated several times.
• You will be prompted if you agree to the End User License Agreement.
When installation is done click Finish to reboot. The first time the computer has
rebooted after installation of IE5, some additional automatic configuration will
take place. Just wait for it to finish.
During the WIN2K operating system installation choose do not to install the IIS
(Internet Information Services). If these Windows Admin Services are already
installed, please de-install them from the Add-Remove Programs, checking in
Add/Remove Windows Components, Internet Information Services (IIS).
By now Windows will have rebooted (a couple of times) and you will have a
basic Windows 2000 Server up and running.
This software is needed for NERA NEW up to R7B (Server), so you can skip
this section if you do not use NERA equipment in your network.
In this chapter you will learn how to install NetOp, which is used for screen
integration of Windows NT2000 machines. NetOp Host is installed on a
machine you need to supervise via remote control, and NetOp Guest is installed
on a machine that you will use for surveillance.
• In the Registration window enter "Licensed to" and the "Serial number"
found on the NetOp license certificate. Then push the Next button.
• In the Communication Profile list box select TCP/IP by checking the box
beside it.
• Then push the Wait for Call button to enable NetOp guests to connect
to the host.
• Follow the same installation procedures (step 1 to 13) as for the installation
of NetOp 7.5 to create a Windows NTNT Host, see section above.
• Make sure that NetOp 7.5 Host software is installed and running on host
computer.
• In the Communication Profile Setup window check the TCP/IP check box
and then push the Close button.
• Make a connection to the remote NetOp host using the host IP-address
and the TCP/IP protocol.
• Push Ok in the Information window that pops up and then close the NetOp
Guest program.
This software is needed for NERA NEW Adaptation from R7C (Server).
3. If Internet Explorer 6.0 is not installed, the “Microsoft Internet Explorer 6.0
not found” appears. Then:
• After the PC restart and the installation completion redo the steps 1 and 2.
10. Click Finish button to complete installation and restart the PC.
Microsoft SQL Server 2000 Standard Edition and Service Pack 3 must be
installed before MINI-LINK MANAGER 6.1 if you want to install also a MINI-LINK
Medium Capacity Adaptation. If you are using MINI-LINK MANAGER with
the default MSDE 2000 DB and you want to install a MINI-LINK Medium
Capacity Adaptation you will need to run an upgrading procedure, from MSDE
to Microsoft SQL Server 2000 Standard Edition, as described in the appendix
section.
1. Insert the Microsoft SQL Server 2000 compact disk into the CD-ROM drive.
2. Click Run on the Start menu and browse the CD to find a file called
Autorun.exe. Double-click this file.
3. Click SQL Server 2000 Components.
7. Select Create a new instance of SQL Server, or install Client Tools in the
Installation Selection dialog box.
10. Select Server and Client Tools in the Installation Definition dialog box.
11. Click Next in the Instance Name dialog box to install a SQL 2000 Default
instance.
14. In the Services Accounts dialog box, select Use the same account for each
service. Auto Start SQL Server Service. Under Service Settings, select
Use the local system account.
15. In the Authentication Mode dialog box, select Mixed Mode (Windows
Authentication and SQL Server Authentication) and check Blank Password
for the sa login.
16. In the Collation Settings dialog box, select the Collation designator option
and select Latin1_General in the list. Under Sort Order, select Case
sensitive and Accent sensitive.
19. Select Per-Seat licensing mode in the Choose Licensing Mode dialog box
(with a devices number not equals to zero) and click Continue.
3. Copy the SQL2KSP3.exe file to the computer running SQL Server 2000.
5. The self-extraction program will prompt you for the name of the directory
in which you want the service pack files placed. For example, if you have
created a directory named C:\2000sp3, copy the file SQL2KSP3.exe
to your SQL Server computer, execute it, and provide the name of the
C:\2000sp3 directory when prompted.
6. Read the instructions in the readme.htm file that is located in the folder
where you extracted the service pack, then double-click the Setup.bat
file to start the installation.
10. In the Connect to Server dialog box, select Windows Authentication, then
click Next.
11. Select Ignore the security threat warning [...], then click OK.
14. In the Setup dialog box, click OK to confirm that you should do backups of
the master and msdb databases after installing of the service pack.
16. Restart your computer and make sure that SQL Server is running before
continuing with the rest of the installations.
Note: You must have local administrator privileges in the WINDOWS 2000
environment to be able to install MINI-LINK MANAGER Server
Application.
Before you begin installing MINI-LINK MANAGER make sure that all
third party products that are needed according to sections 6 to 13
have been installed.
The installation software makes it possible for the user to specify what different
options to install.
The set-up integration (that is, installing the Adapters together with MINI-LINK
MANAGER, see Section 1.2.10 on page 23) consists of launching the Adapters
installations in silent mode.
This is only needed where parallel port is not present on motherboard and a
separate PCI card adapter is being used.
Note: Sentinel System Driver can work with a PCI parallel port adapter under
the Windows 2000 operating system. The Sentinel System Driver
(SSD5.39.2-p01) can be configured to work with the following PCI
Parallel Port adapters:
http://www.siig.com/
Model TK9902
http://www.intek21.com
1. Copy all the files and folders from IMA/MINI-LINK Manager installation CD
to the new folder created (that is: C:\install).
2. Associate a new folder path with a drive letter "B:" running the command
below. The example refers "C:\install" folder. Please replace it with the
one you created.
subst b: C:\install
7. Perform the following steps to determine the resource used by the adapter:
a From the Control Panel, double-click the System icon to open the System
Properties page.
b Click the Hardware tab and then the Device Manager button to open the
Device Manager.
c Click the + sign next to Ports (COM & LPT) to expand the tree.
e Click on the Resources tab to see the resources used by the adapter.
f The value circled in red in the SIIG CyberParallel PCI Card properties page
above is the address of the parallel port.
8. Perform the following steps to configure the Sentinel System Driver to use
the port:
b Click the Configure Driver button as can be seen in the picture below:
d The following dialog will be displayed. Enter the I/O address of the PCI
parallel port adapter into the "Bus Address" field.
f Click the OK button and the following dialog appears. It shows that a User
Created port has been added at address 1088.
g Click the OK button to close the dialog, click the "Start NT parallel driver"
to start the driver and open the File menu and choose Exit to close the
Sentinel System Driver Configuration Utility.
11. Click Next button to install the iFix "Typical" setup type and wait for the
component installation.
13. Click Yes button on the question "Do you want Enable Scada Support?"
14. Click No button on the question "Would you like to register the product
online now?"
15. Select "Yes, I want to restart my computer now" and click finish button.
During the installation an information window warns the set-up will skip the
iFix application installation.
To start the MINI-LINK MANAGER INSTALL program follow the steps outlined
here:
3. If the installation program does not start automatically: from the Start
menu, select run.
5. From the Menu select MINI-LINK Manager 6.1 menu choice. This will start
MINI-LINK MANAGER setup.
11. If the Microsoft SQL Server 2000 Standard Edition has not been detected a
warning message will appear:
12. Now you can choose either the whole package of Adaptations and
Interfaces or click on the Change button to select parts of the packages.
19. Leave the default value of 1000 NEs unless your license states otherwise.
21. If MINI-LINK MANAGER is already installed, you will get a control question.
Choose Yes if you are upgrading. You will get this question only if you have
selected core components.
22. Push the Next button to start with the installation of the following software:
DAO, ADO and TCL 8.0.4, and MINI-LINK Adapters in silent mode if you
have choosen Medium Capacity Adp.
If MINI-LINK Adapters installation fails, a window will show the exit error
code, click Next to continue.
Caution!
Do not remove the MINI-LINK Manager Software user account
(IMA_USER/netman) or change its password while the MINI-LINK Manager
software is installed, or the MINI-LINK Manager software will not work properly.
In case this modification fails the line will contain default ip address (127.0.0.1).
Therefore the line will look as follows and the ip address has to be modified
manually:
....
Replace with:
....
To modify the file use Notepad or any other text editor be careful to drag the
file into an open editor instance since the default open command for this file
extension will not activate the "open with" dialog.
If it has been selected from the MINI-LINK MANAGER program main window,
MINI-LINK E Adapter, then E-Adapter Server will be installed, and no explicit
selection is needed during MINI-LINK MANAGER setup to install the MINI-LINK
E Client Adapter.
To start the MINI-LINK E Adapter installation program follow the steps outlined
here:
Caution!
You will not be able to supervise the network while the database log files (Alarm,
Performance, and AGC) are converted. This can take some time depending
on the amount of records in each log file. You are therefore recommended to
remove old log records so that only the most recent log records are converted.
On a 266 MHz computer with 128 MB RAM, the conversion of 200,000 records
takes about 8 minutes.
3. Welcome
This is the Welcome window for the Server Setup program. Click Next
to continue.
Caution!
Ericsson recommends to never change the proposed default directory.
Furthermore client installation drive must be the same as MINI-LINK
Manager one.
6. SNMP Configuration
Check all the parameters you have entered. If all settings are correct click
Next to start the installation. If something is wrong click Back until you
reach the correct window and change the information.
Choose yes I want to restart the computer now. Wait for the machine to
restart. If you are installing a IMA server after restart login again and
complete the installation with ML E Adapter Client setup.
After restart login again and complete the installation with the ImaPostInstall
procedure that automatically starts at the login.
To start the MINI-LINK E Client Adapter Client installation program insert the
MINI-LINK MANAGER installation CD in the CD-ROM drive and when it starts
(it is auto-running) select from the program main window to install MINI-LINK
E Adapter Client.
1. Welcome
This is the Welcome screen for the Client Setup program. Click Next
to continue.
Caution!
Ericsson recommends to never change the proposed default directory.
Furthermore client installation drive must be the same as MINI-LINK
Manager one.
If you want to change the directory click the Browse button. Click Next
to continue.
Check all the parameters you have entered. If all settings are correct click
Next to start the installation. If anything is wrong click Back until you reach
the correct window and change the information.
4. Setup Complete
Caution!
The MINI-LINK E Adapter Server must be running at all times. If not, the
entire MINI-LINK E Adapter system, including all connected clients, will be
shut down. Note that the traffic in the MINI-LINK network is not affected, only
the supervision.
Note: Shutting down the MINI-LINK E Adapter Server may take several
minutes if there are many terminals in the Network List and the Include
Start and Stop check box is selected in the Configure Data Collection
dialog box (see Configuration guide and MINI-LINK Medium Capacity
Adaptation Guide).
3. Click Stop.
4. Click OK.
5. Click Close.
Note: You must close the dialog box if you intend to remove the MINI-LINK E
Adapter Server from the system, for example, if you are upgrading to a
newer version of the MINI-LINK E Adapter Server.
If you start up the MINI-LINK E Adapter Server with the same, default network
file (for example Network.ids) that was loaded at the last MINI-LINK E
Adapter Server shut-down, then the following will happen:
1. The MINI-LINK E Adapter Server will get the last known severity for all
terminals in the network file.
Warning!
This section includes information about modifying your system registry. Using
the registry editors incorrectly may cause your system to become unbootable. It
is strongly recommended that you run RDISK /S to update Windows NT repair
information and create an emergency repair disk. RDISK is not a replacement
for a full back up. If you do not fully understand the instructions on editing
your systems registry we recommend that you consult your local systems
administrator for assistance.
4. If the user or group you want to login as is not in the Name list then you can
add them by clicking Add and selecting the username or groupname (notice
that you can select everyone instead, then this procedure will work for all
users defined on the domain) from the domain and clicking Add then OK.
5. You should now see your user or group (or everyone) in the Name list. Now
click Advanced, which will display the "Access Control Settings" dialog.
6. Select the user or group (or everyone) from the list and click View/Edit.
This will display the "Permission Entry" dialog, which shows the available
permissions.
7. Under the "Allow" column, put a check in the "Set Value" Permission. If
there is already a check, please double check that the correct user or group
has been selected in the Name box.
11. Now, by "My Computer", make sure the Dynamics directory (that is
C:\Dynamics) is selected.
12. Open the contextual menu with the right-click and select "Properties" and
then the tab "Security".
13. Click Advanced and in the "Access Control Settings" dialog, check "Reset
permission on all child objects and enable propagation of inheritable
permissions" and click OK.
15. Repeat the last four steps for Ericsson directory (that is C:\Ericsson).
Now you can log on as the user or group specified and access MINI-LINK
MANAGER.
Note: Each time a user with administrative rights creates maps, the steps
executed above for the security assignments in C:\Dynamics must be
performed also on the directory C:\Ericsson\IMA\pic, in order to allow
a user not in the administrator group to access those maps when he
logs onto the PC in a later session.
If the clients connected to the server are intended to use the pictures and the
maps that are stored on the server, it will be necessary to share the directory
that contains this information. Enable sharing on the C:\Ericsson\IMA folder
(substitute C: for the partition where you installed MINI-LINK MANAGER;
default name for the share will be IMA; replace IMA for <share> or any other
name you have chosen in what follows). Then you can map network drives on
the clients for <share>\pic accessing pictures and map information, and
<share>\local accessing security information.
1. Choose from the start menu: Programs > IMA > System Configuration.
2. Under Configure menu, select Local Startup. Check the boxes Continue
running after Logoff and Start FIX at system boot.
You need to configure some tasks that MINI-LINK MANAGER uses to start
the adaptations or interfaces.
Note: Options might be required before you proceed. Please refer to each
configuration guide for the various adaptations, interfaces for more
configurations required.
Caution!
Do not remove the first task already present into the task list and below
reported: %C:\DYNAMICS\SUMQDEL.EXE -F1:00:00
• Start the System Configuration program, which you will find in the
MINI-LINK MANAGER program group.
According to the export interfaces installed during the setup program, you need
also to configure the tasks:
• SNMP Interface
− c:\ericsson\IMA\snmp_proxy.exe
• TL-1 Interface
− c:\dynamics\AlarmUserQ.exe
− c:\ericsson\ima\TL1\tl1.exe
• BNSI interface
− c:\dynamics\AlarmUserQ.exe
− c:\ericsson\ima\bnsi\emm.exe
• c:\ericsson\IMA\RSU\Tools\MLEHC\TFTP.exe
AlarmWatchDog c:\ericsson\ima\bin\AlmPeak.exe
3. Choose from the start menu: Programs > IMA > Login.
5. Type admin for user and admin for password then click log in again.
6. Choose from the start menu: Programs > IMA > System Configuration.
Warning!
Never use the IMA Startup icon in Program > IMA > IMA Startup if you need to
make it run after logoff.
1 Open the System Configuration Utility program, which you will find in the
MINI-LINK MANAGER folder.
4 Push OK.
1.5.1 Configuration
Log in to the MINI-LINK HC terminal that you want to configure following the
procedure below:
• Start your browser and type in the Address bar, the IP Address of the
specific MINI-LINK HC terminal.
• When the applet is loaded into the browser, you can log in to the LCT from
the Login window using these values:
Password: Administrator
• In the Link Manager window displayed select Setup -> DCN -> Interfaces
and press the SNMPv3 tab.
• Under Registered Managers press the Add button to add the MINI-LINK
MANAGER Server to the list of the defined SNMPv3 Managers.
Group: V3Control
• Under Send traps, select yes to allow the equipment to send notifications
(trap messages) to the manager.
1.6.1 Installation
All external software associated with this adaptation should have been installed
according to the roadmap. To find out what external software to install please
check the roadmap.
1.6.3 Configuration
Log in to the MINI-LINK TN terminal that you want to configure following the
procedure below:
1. Start your browser and type in the Address bar, the IP Address of the
specific MINI-LINK TN terminal.
2. You can log in to the LCT from the Login window using these values:
Then click on the Apply button and press the Save button showed on
the top-right corner of the frame.
• Go to C:\Ericsson\IMA\SNMP.
• If you are a user that is going to configure the SNMP Manager, check under
Permissions… that the Type of access is set to Full Control.
• Press OK.
The SNMP Interface needs the Windows SNMP service installed. This should
have been done in the Windows 2000 configuration section in this manual,
according to the roadmap.
2 Select Services.
4 Push Stop in the Services window. The list should read Stopped for SNMP
after a few seconds. If not, consult the Windows NT documentation.
In order to configure the SNMP Export Interface to send traps to other systems
you must configure trap destinations as follow:
2 Select Services.
4 Select Traps. Use the dialog to specify the computers that will receive traps.
This is done in the following way:
5 Community Name is chosen from the list or written in the text field. This is
the SNMP "pass-word" used when the traps are sent, for example, public.
Note: The community name must match the community name specified
in the NE Properties window/Address tab.
7 Push Add next to Trap Destinations to specify host names for all servers
that correspond to the given Community Name give a host name (if it is
known in your network) or SNMP address, for example 150.132.152.21.
9 Push OK.
Caution!
If you have installed on MINI-LINK Manager Server also MINI-LINK E Adapter
Server set SNMP EMANATE Adapter for NT service to Manual.
Presets:
On the MINI-LINK MANAGER 6.1 Server SQL Server 2000 service has to be
started and MINI-LINK MANAGER 5.1 Applications must be closed.
1. From the start menu open SQL Server 2000 Enterprise Manager tool.
Under the Tree view right-click on the "SQL Server Group" and click on the
"New SQL Server Registration…" menu item.
2. Click Next on the "Welcome" window and then select the Server from the
list box that contains the MINI-LINK MANAGER 6.1 Server to uninstall. If
the name of the pc is not present, you can edit the name in the "Available
servers" edit box.
5. Insert the "sa" login and password (blank for default) and then click Next.
The last dialog appears to advise that the process is completed successfully.
Then, click Finish on the back dialog.
If the Server is registered, a new Server node is added under the "SQL Server
Group" node.
This chapter describes how to remove the replication from the server just
registered.
1. Select the Server node and open the Tools menu. Click, under the voice
"Replication", the "Disabling Publishing…" menu item.
2. Click the Next button in the "Welcome" dialog and select the Yes option on
the second wizard dialog. Then click the Next button.
If there is one publication on the server the last wizard dialog appears and then
you can click the Finish button. So the replication is removed.
If there is more than one publication, a tree view appears that shows all the
publications active (for IMA_INVENTORY or IMA_CONFIG database). Select
the publication and click Next until the wizard ends. Then click Finish.
1. Shutdown MINI-LINK MANAGER. Make sure that Clients are not accessed
to this server.
2. Go into the Control Panel and open the "Add/Remove Programs" window.
Click on the Change/Remove button of the IMA program.
4. A dialog with no title appears. With the message "You must restart your
computer before reinstalling iFIX ". Click OK.
5. If a dialog asks to you to remove the shared files, answer clicking on the
No to All button.
7. If you want to remove the programs Adobe, DAO or TCL 8.0.4 click on
their Change/Remove button.
Note: If the MINI-LINK E Adapter Server is not shut down, the installation
program cannot uninstall the program. See Section 1.2.11.3 on
page 30 for instructions on how to shut down the MINI-LINK E
Adapter Server.
This will remove all files that were added in the installation. Any files added to
the MINI-LINK E Adapter directories after installation will have to be removed
manually by deleting them in Windows NT Explorer.
• Stop the Netman Server service (stopping it, the MINI-LINK Netman Proxy
Agent service will be stopped automatically).
• From SQL Server Service Manager start-up icon stop the SQL Server
service then exit from it.
• Install the Service Pack 3 of Microsoft SQL Server 2000 Standard Edition.
• Stop the Netman Server service (stopping it, the MINI-LINK Netman Proxy
Agent service will be stopped automatically).
• From SQL Server Service Manager start-up icon stop the SQL Server
service then exit from it.
• Install the Service Pack 3 of Microsoft SQL Server 2000 Standard Edition.
• Start the E Adapter Server service (starting it, the MINI-LINK E Adapter
SNMP Proxy Agent service should be started automatically)
• If Microsoft SQL Server 2000 is installed, before the backup operation install
the Service Pack 3. If MSDE2000 is installed, upgrade MSDE to Microsoft
SQL Server 2000 (SP3) as described in Section 1.19.2 on page 47.
• Wait until the message "Backup completed" is displayed. Save and store
the backup directory in a different path from C:\Ericsson\ima.
• Replace the new backup directory with the previous saved directory.
1.19 Appendices
Complete the network configuration putting the new node name on the Domain
Controller and DNS server.
The updating procedure from MSDE (Microsoft SQL Server Desktop Engine) to
Microsoft SQL Server 2000 database server uses the Backup/Restore facilities
provided by MINI-LINK MANAGER. To do it follow these steps:
• Uninstall MSDE2000.
• From SQL Server Service Manager start-up icon stop both services: SQL
Server and SQL Server Agent, then exit from it.
The terminal server provides the connection between the serial interface of
a MINI-LINK network and the MINI-LINK E Adapter Server workstation. A
terminal server is only needed if more than one sub-network is present.
Ericsson recommends:
or
Both models can be equipped with LAN or WAN interfaces for most data
network standards, such as Ethernet, Token Ring, X.25, ISDN, and so on.
Note: You will find the configuration procedure for Cisco Access Server Model
2509 in Section 1.19.4.14 on page 57.
The maximum distance between the terminal server and the MINI-LINK network
is approximately 15 meters (see Section 1.19.4.3 on page 49). If longer, it can
be connected via a modem (see Section 1.19.4.4 on page 49).
The MINI-LINK network should be connected with a straight cable from the
MINI-LINK element cabling to the V.24 spider connection cabling connected
to the terminal server.
Note: The maximum distance between the terminal server and the MINI-LINK
network is approximately 15 meters.
1.19.4.4 Modem
The PC is connected to the modem via the serial communication port, and the
modem is connected to the MINI-LINK equipment according to Table 3 on page
51,Table 4 on page 51 and Table 5 on page 52.
M o d e m B P S T N M o d e m A
M IN I- L IN K e q u ip m e n t
The calling and modem configurations must be done outside the MINI-LINK E
Adapter Server, with terminal-emulation software such as Telnet.
• 1200 bits/s
• 8 data bits
• 1 stop bit
• no parity
• no flow control
The tables below give guiding information on how to connect the modem
to MINI-LINK equipment (cable to Modem A in Figure 3 on page 49). For
connection between PC and modem, use a standard RS 232C cable. Consult
the modem manual for detailed instructions.
The Patton Model 2120 Single Port Terminal Server (TS) is used for building a
communication channel between a MINI-LINK E sub-network and MINI-LINK E
Adapter via a TCP/IP network. The main function of the TS is to convert signals
between the V24/RS232 and TCP/IP standards.
For more information, see the User Guide included in the delivery.
Figure 4 Overview
Using the gender changer, connect the RS232 cable on the TS to an unused
serial port on the PC (typically COM1 or COM2).
Note: Your model of PC may need to be turned off before you connect the
PC cable to a serial port. If in doubt, turn off your PC while connecting
the PC cable to the serial port.
2. If the Connection Description dialog box does not open, click New
Connection on the File menu.
3. In the Name box, type a name for the new connection, for example TS.
4. Click OK.
5. In the Connect using list, select the serial port to use (typically COM1 or
COM2).
Figure 6 Connect
6. Click OK.
8. Click OK.
If no connection is established:
Figure 8 TS Properties
5. Click OK.
3. Set the period of time (in minutes) that the TS will close an inactive
connection to the serial interface:
Note: This time must be longer than the polling time set in MINI-LINK
E Adapter.
6. Disable char string for termination of the connection on the serial interface:
7. Disable DHCP:
Reboot [power cycle] the terminal server. The new configuration is now active.
Connect the RS232 cable on the TS to the O&M port on MINI-LINK equipment.
Connect the TS to the TCP/IP network using the 10BASE-T LAN interface.
Once the TS has been configured and installed the initial HyperTerminal speed
is no longer appropriate. It must be changed to 1200 bits/s if the serial interface
should be able to work. However, from now on it is more convenient to use a
Telnet session for configuration (if needed).
3. Click OK.
The PC and the TS must in this case be connected via a LAN connection.
1
0
A S Y N C 1 -8 A U I S E R IA L 0 S E R IA L 1 O n /o ff P o w e r
C O N S O L E A U X s w itc h
Figure 9 Cisco Access Server Model 2509
1.19.4.15 Connection
For connection to the ASYNC 1-8 port, use the octopus cable with a connector
for the ASYNC 1-8 port in one end and eight 8-pin RJ-45 connectors in the
other. The RJ-45 connectors can be connected to (up to) eight MINI-LINK
sub-networks. (The octopus cable is not included, and must be ordered
separately).
The AUX port on the Cisco terminal server can be used for a ninth MINI-LINK
sub-network.
Note: Cisco Access Server model 2511 has two identical ASYNC ports
(ASYNC 1-8 and ASYNC 9-16), and can be used for 16 MINI-LINK
sub-networks.
1.19.4.16 Configuration
Before the Cisco Access Server can be used, each port used must be
configured to provide the characteristics required by the MINI-LINK Networks.
The Cisco Access Server has to be installed and given a specific IP address
before the configuration can be done. You also have to know the two passwords
for the server. See the Cisco manuals for further instructions on these
procedures.
To configure the Cisco Access Server you have to log on to the server. This is
done by starting a Telnet session with the Access Server. The session can be
started from any workstation on the same LAN/WAN as the Access Server.
The actions below are performed from any workstation with access to the
Access Server (either via LAN, WAN or modem).
The password1 and password2 in Step 3 and Step 5 should be replaced with
valid passwords. See the Cisco Manuals. The cisco> prompt shows that a view
connection is established and the cisco# prompt shows that the configuration
mode is entered.
1. Start the application that provides a Telnet connection. The Telnet program
is easiest found on the Start menu:
Password: password1
cisco> enable
Password: password2
Repeat Step 7 to Step 9 for every port used for MINI-LINK connections.
cisco(config)# line 5
Line 5 represents Port 4005 for the Access Server. This port number
is entered in the MINI-LINK E Adapter Server installation program, see
Section 1.2.11 on page 26.
cisco(config-line)# stopbits 1
cisco(config-line)# databits 8
cisco(config-line)# no exec
cisco(config-line)# no exec-banner
cisco(config-line)# exit
Configure a Time-out
The Access Server needs to have a time-out if there is no traffic from the
MINI-LINK E Adapter Server. In this case all connections between the
MINI-LINK network and the MINI-LINK E Adapter Server are removed in the
Access Server. This ensures that the MINI-LINK E Adapter Server is able
to reconnect.
cisco(config-line)# session-timeout 1
12. Exit the configuration mode. Type and save the configuration in both the
running and boot memory:
cisco(config-line)# exit
cisco(config)# exit
cisco# exit
Here are a few more useful commands for the Cisco Access Server. They are
all used in the Telnet session window.
Caution!
You should not modify the communication parameters if you do not have good
knowledge about MINI-LINK networks.
Note: The values can be changed in run-time and have immediate impact.
Click Default to reset the network parameters to their default values.
-or-
-or-
Click Reset to reset all values to the settings they had when you opened
the application.
The Network.ids file holds information about all managed MINI-LINK terminals.
The .ids extension shows that the file is a MINI-LINK E Adapter Server Network
List.Example 1 on page 64 shows how the parameters are structured in each
record.
ID -> Type -> Sub-net ID -> Site ID -> Hop Side ID -> Hop ID -> Far Hop Side ID
-> Traffic Rate -> Description
The client Network List files hold information about MINI-LINK E Adapter Client
Network Lists. The .id extension shows that the file is a MINI-LINK E Adapter
Client Network List.
