TECHNICAL REVISION

Piping Valve Description Sample

se
U
al
ci
PIP PNSMV003

er
Carbon Steel Gate Valve Descriptions

m
m
Co
o
N
e-
pl
m
Sa
 PURPOSE AND USE OF PROCESS INDUSTRY PRACTICES

In an effort to minimize the cost of process industry facilities, this Practice has
been prepared from the technical requirements in the existing standards of major
industrial users, contractors, or standards organizations. By harmonizing these technical

se
requirements into a single set of Practices, administrative, application, and engineering
costs to both the purchaser and the manufacturer should be reduced. While this Practice
is expected to incorporate the majority of requirements of most users, individual

U
applications may involve requirements that will be appended to and take precedence
over this Practice. Determinations concerning fitness for purpose and particular matters
or application of the Practice to particular project or engineering situations should not

al
be made solely on information contained in these materials. The use of trade names
from time to time should not be viewed as an expression of preference but rather

ci
recognized as normal usage in the trade. Other brands having the same specifications
are equally correct and may be substituted for those named. All Practices or guidelines
are intended to be consistent with applicable laws and regulations including OSHA

er
requirements. To the extent these Practices or guidelines should conflict with OSHA or
other applicable laws or regulations, such laws or regulations must be followed.

m
Consult an appropriate professional before applying or acting on any material
contained in or suggested by the Practice.
m
This Practice is subject to revision at any time.
Co

© Process Industry Practices (PIP), Construction Industry Institute, The University of

Texas at Austin, 3925 West Braker Lane (R4500), Austin, Texas 78759. PIP Member
Companies and Subscribers may copy this Practice for their internal use. Changes or
o

modifications of any kind are not permitted within any PIP Practice without the express
N

written authorization of PIP. Authorized Users may attach addenda or overlays to clearly
indicate modifications or exceptions to specific sections of PIP Practices. Authorized
Users may provide their clients, suppliers and contractors with copies of the Practice
solely for Authorized Users’ purposes. These purposes include but are not limited to the
e-

procurement process (e.g., as attachments to requests for quotation/ purchase orders or

requests for proposals/contracts) and preparation and issue of design engineering
deliverables for use on a specific project by Authorized User’s client. PIP’s copyright
pl

notices must be clearly indicated and unequivocally incorporated in documents where an

Authorized User desires to provide any third party with copies of the Practice.
m
Sa

PRINTING HISTORY
October 1995 Issued May 2000 Revision June 2006 Technical Revision
February 1997 Revision April 2001 Revision March 2010 Complete Revision
June 1998 Revision November 2003 Technical Revision February 2015 Technical Revision
February 1999 Complete Revision November 2005 Technical Revision

Not printed with State funds

Process Industry Practices Page 2 of 34

 TECHNICAL REVISION
February 2015

Piping

se
U
al
ci
PIP PNSMV003

er
Carbon Steel Gate Valve Descriptions
Table of Contents
m
m
1. Introduction .................................2
1.1 Purpose ..............................................2
1.2 Scope .................................................2
Co

2. References ..................................2
2.1 Process Industry Practices ................2

3. Valve Designation System .........2

o

4. Notes ............................................2
N

5. Cross Reference .........................3

e-

6. Valve Descriptions ......................4

pl
m
Sa

Process Industry Practices Page 1 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

1. Introduction
1.1 Purpose
This Practice provides requirements for suppliers providing carbon steel gate valves
included in PIP Piping Line Class Material Specifications.

se
1.2 Scope
This Practice describes the requirements for carbon steel gate valves.

U
2. References
Applicable parts of the following Practices shall be considered an integral part of this Practice.

al
The edition in effect on the date of contract award shall be used, except as otherwise noted. Short
titles will be used herein where appropriate.

ci
2.1 Process Industry Practices (PIP)
– PIP PNCM0004 - Valve Commodity Codes Designator System

er
– PIP PNFJ8000 - Jacketed Piping Fabrication and Installation Details

m
3. Valve Designation System
3.1 For a full explanation of the format used to structure the valve numbers listed within this
m
Practice, refer to PIP PNCM0004.
3.2 This Practice provides descriptions for gate valves. Therefore, the first two characters in
Co
the valve numbers are GA.
3.3 The valves listed in Section 5 and Section 6 of this Practice are sorted by the unique
valve number designation in ascending alphanumeric sequence (e.g., GA01CA500,
GA01CA501, GA01CB500, GA01CB501, GA03CA500).
o

4. Notes
N

4.1 Occasionally, valve size ranges listed in this Practice are broader than the size ranges
shown for the same valves on a piping line class material specification. While the “most
e-

common practice” has been used to specify valve size ranges on line class specifications,
a purchaser may need to utilize a valve in a size outside this “common practice” choice.
Thus, for reference purposes, the full size range for which a given valve is typically
manufactured is shown in this Practice.
pl

4.2 Requirements for gear operators for gate valves are not specified in piping line class
specifications or valve specifications. Purchasers shall define the requirements for gear
m

operators in their specifications.

4.3 If fluids can be trapped (e.g., in double-seated valves) and subjected to heating and
Sa

subsequent expansion, means of pressure relief shall be considered to avoid excessive

pressure build-up.
4.4 See PIP PNFJ8000, detail PNFJ8750, for typical fabrication details for weld-on jacketed
valves.

Process Industry Practices Page 2 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

5. Cross Reference

Valve Number Applicable Line Classes

GA01CA500 1CA1S01
GA01CA501 1CA1S01
GA01CA502 1CA1S01

se
GA01CB500 1CB1S01, 1CB2S01, 1CB3S01, 1CS1B01, 1CS1B02, 1CS1S01, 1CS2S01,
1SA0B01
GA01CB501 1CB1S01, 1CB2S01, 1CB3S01, 1CS1B01, 1CS1B02, 1CS1S01, 1CS1S02,

U
1CS2S01, 1SA0B01
GA01CB502 1CB2S01, 1CS1B02, 1CS1S01, 1CS1S02, 1CS2S01, 1CB1S01
GA01CB503 1CS1S02

al
GA01CB550 1CS1J01
GA01CB551 1CS1J01

ci
GA03CA500 3CA1S01
GA03CA501 3CA1S01

er
GA03CA502 3CA1S01
GA03CB500 3CB1S01, 3CB2S01, 3CS1S01, 3CS1B01, 3CS2B01, 3CS2S01, 3SA0B01
GA03CB501 3CB1S01, 3CB2S01, 3CS1S01, 3CS1S02, 3CS1B01, 3CS2B01, 3CS2S01,

GA03CB502
3SA0B01

m
3CB1S01, 3CB2S01, 3CS1S01, 3CS1S02, 3CS1B01, 3CS2B01, 3CS2S01
m
GA03CB503 3CS1S02
GA03CB550 3CS1J01
Co
GA03CB551 3CS1J01
GA06CA500 6CA1S01
GA06CA501 6CA1S01
GA06CA502 6CA1S01
GA06CB500 6CB1S01, 6CB2S01, 6SA0B01
o

GA06CB501 6CB1S01, 6CB2S01, 6SA0B01

N

GA06CB502 6CS1S01
GA06CB503 6CB1S01, 6CB2S01
GA06CB504 6CS1S01
e-

GA06CB505 6CS1S01
GA06CB800 6CS1S01
GA06CB801 6CS1S01
pl

GA08CA200 1CA1S01, 3CA1S01, 6CA1S01

GA08CA300 1CA1S01, 3CA1S01, 6CA1S01
GA08CB200 1CB1S01, 1CB2S01, 1CB3S01, 1CS1J01, 1CS1S01, 1CS2S01, 1SA0J01,
m

1SA0J02, 1SD0J01, 1SD0J02, 3CB1S01, 3CB2S01, 3CS1J01, 3CS1S01,

3CS2S01, 3SA0J01, 3SA0J02, 3SD0J01, 3SD0J02, 6CB1S01, 6CB2S01
Sa

GA08CB201 6CS1S01
GA08CB202 1CS1S02, 3CS1S02
GA08CB203 1CB3S01
GA08CB300 1CB1S01, 1CB2S01, 1CB3S01, 1CS1S01, 1CS2S01, 3CS2S01, 3CB2S01,
3CS1S01, 3CB1S01, 6CB1S01, 6CB2S01
GA08CB301 6CS1S01
GA08CB302 1CS1S02, 3CS1S02

Process Industry Practices Page 3 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

GA09CB500 9CB1S01, 9CB2S01

GA09CB501 9CS1S01
GA09CB800 9CS1S01
GA15CB200 9CB1S01, 9CB2S01, 15CB1S01, 15CB2S01
GA15CB201 9CS1S01, 15CS1S01
GA15CB300 9CB1S01, 9CB2S01, 15CB1S01, 15CB2S01

se
GA15CB301 9CS1S01, 15CS1S01
GA15CB500 9CB1S01, 9CB2S01, 15CB1S01, 15CB2S01

U
GA15CB501 9CS1S01, 15CS1S01
GA15CB502 15CB1S01, 15CB2S01
GA15CB503 15CS1S01

al
GA15CB800 15CS1S01

6. Valve Descriptions

ci
Description of GATE Valve (GA01CA500):

er
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 150

m
Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Trim:............................. API 602 TRIM 12
m
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Co
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
The standards are:
o

DESIGN - API 602

ENDS - ASME B16.5
RATING - ASME B16.34
N

TESTING - API 598

DIMENSIONAL - ASME B16.10

Description of GATE Valve (GA01CA501):

e-

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 150
Ends:............................. FLANGED RF
pl

Body:............................. ITCS (ASTM A352 - LCB or A352 - LCC)

Bonnet:........................... ITCS (ASTM A352 - LCB or A352 - LCC)
Trim:............................. API 600 TRIM 12
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
m

Bonnet Type:...................... BOLTED

Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 4 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA01CA502):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 150
Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A352 - LCB or A352 - LCC)
Trim:............................. API 600 TRIM 12

se
Wedge Type:....................... FLEXIBLE
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD

al
NUTS: MFG STD
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.47 SERIES B

ci
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 36)

er
MFG STD (NPS 38 -to- NPS 48)

Description of GATE Valve (GA01CB500):

Type:............................. GATE

m
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 150
Ends:............................. FLANGED RF
m
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Co
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
o

NUTS: API 602

The standards are:
DESIGN - API 602
N

ENDS - ASME B16.5

RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10
e-

Description of GATE Valve (GA01CB501):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 150
Ends:............................. FLANGED RF
pl

Body:............................. CS (ASTM A105 or A216 - WCB)

Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 600 TRIM 8
m

Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 5 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA01CB502):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Class:............................ 150
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... FLEXIBLE

se
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600

al
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.47 SERIES B
RATING - ASME B16.34

ci
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 36)
MFG STD (NPS 38 -to- NPS 48)

er
Description of GATE Valve (GA01CB503):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2

m
Class:............................ 150
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A105)
m
Bonnet:........................... CS (ASTM A105)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Bonnet Type:...................... WELDED
Co
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
The standards are:
DESIGN - API 602
ENDS - ASME B16.5
o

RATING - ASME B16.34

TESTING - API 598
N

DIMENSIONAL - ASME B16.10

Description of GATE Valve (GA01CB550):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
e-

Class:............................ 150
Ends:............................. FLANGED RF and OVERSIZED REDUCING FLANGES
Body:............................. CS (ASTM A105)
Bonnet:........................... CS (ASTM A105)
Trim:............................. API 602 TRIM 8
pl

Wedge Type:....................... SOLID

Bonnet Type:...................... BOLTED
Jacket:........................... FULL JACKET - PIP PNFJ8750 and FNPT CONNECTIONS
m

Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Sa

Body-Bonnet Gaskets:.............. SS/GRAPHITE

Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 6 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA01CB551):

Type:............................. GATE
Valve Size:....................... NPS 3 -to- NPS 12
Class:............................ 150
Ends:............................. FLANGED RF and OVERSIZED REDUCING FLANGES
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)

se
Bonnet Type:...................... BOLTED
Jacket:........................... FULL JACKET - PIP PNFJ8750 and FNPT CONNECTIONS
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD

al
NUTS: MFG STD
The standards are:
DESIGN - ASME B16.34
ENDS - ASME B16.5

ci
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

er
Description of GATE Valve (GA03CA500):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2

m
Service: ......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 300
Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
m
Bonnet:........................... ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Trim:............................. API 602 TRIM 12
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Co
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
o

The standards are:

DESIGN - API 602
ENDS - ASME B16.5
N

RATING - ASME B16.34

TESTING - API 598
DIMENSIONAL - ASME B16.10

Description of GATE Valve (GA03CA501):

e-

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 300
Ends:............................. FLANGED RF
pl

Body:............................. ITCS (ASTM A352 - LCB or A352 - LCC)

Bonnet:........................... ITCS (ASTM A352 - LCB or A352 - LCC)
Trim:............................. API 600 TRIM 12
m

Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 7 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA03CA502):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 300
Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A352 - LCB or A352 - LCC)
Trim:............................. API 600 TRIM 12

se
Wedge Type:....................... FLEXIBLE
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD

al
NUTS: MFG STD
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.47 SERIES B

ci
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 36)

er
MFG STD (NPS 38 -to- NPS 48)

Description of GATE Valve (GA03CB500):

Type:............................. GATE

m
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 300
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A105 or A216 - WCB)
m
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Co
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
o

NUTS: API 602

The standards are:
N

DESIGN - API 602

ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10
e-

Description of GATE Valve (GA03CB501):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 300
pl

Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
m

Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 8 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA03CB502):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Class:............................ 300
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... FLEXIBLE

se
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600

al
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.47 SERIES B
RATING - ASME B16.34

ci
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 36)
MFG STD (NPS 38 -to- NPS 48)

er
Description of GATE Valve (GA03CB503):
Type:............................. GATE

m
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 300
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A105 or A216 - WCB)
m
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Bonnet Type:...................... WELDED
Co
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
The standards are:
DESIGN - API 602
o

ENDS - ASME B16.5

RATING - ASME B16.34
TESTING - API 598
N

DIMENSIONAL - ASME B16.10

Description of GATE Valve (GA03CB550):

Type:............................. GATE
e-

Valve Size:....................... NPS 1/2 -to- NPS 2

Class:............................ 300
Ends:............................. FLANGED RF and OVERSIZED REDUCING FLANGES
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
pl

Trim:............................. API 602 TRIM 8

Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
m

Jacket:........................... FULL JACKET - PIP PNFJ8750 and FNPT CONNECTIONS

Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Sa

Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 9 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA03CB551):

Type:............................. GATE
Valve Size:....................... NPS 3 -to- NPS 12
Class:............................ 300
Ends:............................. FLANGED RF and OVERSIZED REDUCING FLANGES
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)

se
Bonnet Type:...................... BOLTED
Jacket:........................... FULL JACKET - PIP PNFJ8750 and FNPT CONNECTIONS
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD

al
NUTS: MFG STD
The standards are:
DESIGN - ASME B16.34
ENDS - ASME B16.5

ci
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

er
Description of GATE Valve (GA06CA500):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2

m
Service: ......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 600
Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
m
Bonnet:........................... ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Trim:............................. API 602 TRIM 12
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Co
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
o

The standards are:

DESIGN - API 602
N

ENDS - ASME B16.5

RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10
e-

Description of GATE Valve (GA06CA501):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 600
pl

Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A352 - LCB or A352 - LCC)
Trim:............................. API 600 TRIM 12
m

Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 10 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA06CA502):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 600
Ends:............................. FLANGED RF
Body:............................. ITCS (ASTM A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A352 - LCB or A352 - LCC)
Trim:............................. API 600 TRIM 12

se
Wedge Type:....................... FLEXIBLE
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD

al
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.47 SERIES B
RATING - ASME B16.34

ci
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 30)
MFG STD (NPS 32 -to- NPS 48)

er
Description of GATE Valve (GA06CB500):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2

m
Class:............................ 600
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
m
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Co
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
o

The standards are:

DESIGN - API 602
ENDS - ASME B16.5
N

RATING - ASME B16.34

TESTING - API 598
DIMENSIONAL - ASME B16.10
e-

Description of GATE Valve (GA06CB501):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 600
Ends:............................. FLANGED RF
pl

Body:............................. CS (ASTM A216 - WCB)

Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
m

Bonnet Type:...................... BOLTED

Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 11 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA06CB502):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 600
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 5
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)

se
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600

al
The standards are:
DESIGN - API 600
ENDS - ASME B16.5
RATING - ASME B16.34

ci
TESTING - API 598
DIMENSIONAL - ASME B16.10

er
Description of GATE Valve (GA06CB503):
Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Class:............................ 600

m
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
m
Trim:............................. API 600 TRIM 8
Wedge Type:....................... FLEXIBLE
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Co
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
o

DESIGN - API 600, as applicable

ENDS - ASME B16.47 SERIES B
N

RATING - ASME B16.34

TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 30)
MFG STD (NPS 32 -to- NPS 48)
e-

Description of GATE Valve (GA06CB504):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 600
Ends:............................. FLANGED RF
pl

Body:............................. CS (ASTM A105 or A216 - WCB)

Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 5
m

Wedge Type:....................... SOLID

Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10

Process Industry Practices Page 12 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA06CB505):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Class:............................ 600
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 5

se
Wedge Type:....................... FLEXIBLE
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600

al
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.47 SERIES B

ci
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 30)
MFG STD (NPS 32 -to- NPS 48)

er
Description of GATE Valve (GA06CB800):
Type:............................. GATE

m
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 600
Ends:............................. BW
Body:............................. CS (ASTM A216 - WCB)
m
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 5
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
Bonnet Type:...................... BOLTED
Co
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
o

The standards are:

DESIGN - API 600
N

ENDS - ASME B16.25

RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10
e-

Description of GATE Valve (GA06CB801):

Type:............................. GATE
Valve Size:....................... NPS 26 -to- NPS 48
Class:............................ 600
Ends:............................. BW
pl

Body:............................. CS (ASTM A216 - WCB)

Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 5
Wedge Type:....................... FLEXIBLE
m

Bonnet Type:...................... BOLTED

Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Sa

Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
DESIGN - API 600, as applicable
ENDS - ASME B16.25
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 26 -to- NPS 30)
MFG STD (NPS 32 -to- NPS 48)

Process Industry Practices Page 13 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA08CA200):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 800
Ends:............................. T/SW
Body:............................. ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)

se
Trim:............................. API 602 TRIM 12
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD

U
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD

al
NUTS: MFG STD
The standards are:
DESIGN - API 602

ci
ENDS - SW: ASME B16.11, THD: ASME B1.20.1
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD

er
Description of GATE Valve (GA08CA300):
Type:............................. GATE

m
Valve Size:....................... NPS 1/2 -to- NPS 2
Service:.......................... -46 to 343 degC (-50 to 650 degF)
Class:............................ 800
Ends:............................. SW
m
Body:............................. ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Bonnet:........................... ITCS (ASTM A350 - LF2 CLASS 1 or A352 - LCB or A352 - LCC)
Trim:............................. API 602 TRIM 12
Wedge Type:....................... SOLID
Co
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: MFG STD
o

NUTS: MFG STD

The standards are:
N

DESIGN - API 602

ENDS - ASME B16.11
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD
e-

Description of GATE Valve (GA08CB000):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
pl

Ends:............................. THD
Body:............................. CS (ASTM A105)
Bonnet:........................... CS (ASTM A105)
Trim:............................. API 602 TRIM 8
m

Wedge Type:....................... SOLID

Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - ASME B1.20.1
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD

Process Industry Practices Page 14 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA08CB200):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
Ends:............................. T/SW
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8

se
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602

al
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - SW: ASME B16.11, THD: ASME B1.20.1

ci
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD

er
Description of GATE Valve (GA08CB201):
Type:............................. GATE

m
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
Ends:............................. T/SW
Body:............................. CS (ASTM A105 or A216 - WCB)
m
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 5
Wedge Type:....................... SOLID
Co
Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
The standards are:
o

DESIGN - API 602

ENDS - SW: ASME B16.11, THD: ASME B1.20.1
RATING - API 602
N

TESTING - API 598

DIMENSIONAL - MFG STD

Description of GATE Valve (GA08CB202):

e-

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
Ends:............................. T/SW
Body:............................. CS (ASTM A105 or A216 - WCB)
pl

Bonnet:........................... CS (ASTM A105 or A216 - WCB)

Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
m

Bonnet Type:...................... WELDED

Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Sa

Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

The standards are:
DESIGN - API 602
ENDS - SW: ASME B16.11, THD: ASME B1.20.1
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD

Process Industry Practices Page 15 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA08CB203):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
Ends:............................. PE x THD
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID

se
Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602

al
The standards are:
DESIGN - API 602
ENDS - SW: ASME B16.11, THD: ASME B1.20.1
RATING - API 602

ci
TESTING - API 598
DIMENSIONAL - MFG STD

er
Description of GATE Valve (GA08CB300):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800

m
Ends:............................. SW
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
m
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Co
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
o

DESIGN - API 602

ENDS - ASME B16.11
N

RATING - API 602

TESTING - API 598
DIMENSIONAL - MFG STD

Description of GATE Valve (GA08CB301):

e-

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
Ends:............................. SW
pl

Body:............................. CS (ASTM A105 or A216 - WCB)

Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 5
Wedge Type:....................... SOLID
m

Bonnet Type:...................... WELDED

Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Sa

Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - ASME B16.11
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD

Process Industry Practices Page 16 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA08CB302):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 800
Ends:............................. SW
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8

se
Wedge Type:....................... SOLID
Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
The standards are:
DESIGN - API 602

al
ENDS - ASME B16.11
RATING - API 602
TESTING - API 598
DIMENSIONAL - MFG STD

ci
Description of GATE Valve (GA09CB500):
Type:............................. GATE

er
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 900
Ends:............................. FLANGED RF

m
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
m
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Co
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
o

DESIGN - API 600

ENDS - ASME B16.5
RATING - ASME B16.34
N

TESTING - API 598

DIMENSIONAL - ASME B16.10

Description of GATE Valve (GA09CB501):

e-

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 900
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
pl

Bonnet:........................... CS (ASTM A216 - WCB)

Trim:............................. API 600 TRIM 5
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
m

Bonnet Type:...................... PRESSURE SEAL

Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Sa

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. MFG STD
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
The standards are:
DESIGN - ASME B16.34 and MSS SP-144
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 - LONG PATTERN

Process Industry Practices Page 17 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA09CB800):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 900
Ends:............................. BW
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 5
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)

se
Bonnet Type:...................... PRESSURE SEAL
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. MFG STD
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD

al
The standards are:
DESIGN - ASME B16.34 and MSS SP-144
ENDS - ASME B16.25
RATING - ASME B16.34

ci
TESTING - API 598
DIMENSIONAL - ASME B16.10 - SHORT PATTERN (NPS 2 -to- NPS 16)
ASME B16.10 - LONG PATTERN (NPS 18 -to- NPS 24)

er
Description of GATE Valve (GA15CB200):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2

m
Class:............................ 1500
Ends:............................. T/SW
Body:............................. CS (ASTM A105 or A216 - WCB)
m
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
Co
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
o

The standards are:

DESIGN - API 602
N

ENDS - SW: ASME B16.11, THD: ASME B1.20.1

RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - MFG STD
e-

Description of GATE Valve (GA15CB201):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 1500
pl

Ends:............................. T/SW
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 5
m

Wedge Type:....................... SOLID

Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Sa

Stem Design:...................... OS&Y

Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

The standards are:

DESIGN - API 602
ENDS - SW: ASME B16.11, THD: ASME B1.20.1
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - MFG STD

Process Industry Practices Page 18 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA15CB300):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 1500
Ends:............................. SW
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 8
Wedge Type:....................... SOLID

se
Bonnet Type:...................... BOLTED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602

al
The standards are:
DESIGN - API 602
ENDS - ASME B16.11
RATING - ASME B16.34

ci
TESTING - API 598
DIMENSIONAL - MFG STD

er
Description of GATE Valve (GA15CB301):
Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 1500

m
Ends:............................. SW
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
m
Trim:............................. API 602 TRIM 5
Wedge Type:....................... SOLID
Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Co
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

The standards are:

DESIGN - API 602
ENDS - ASME B16.11
o

RATING - ASME B16.34

TESTING - API 598
N

DIMENSIONAL - MFG STD

Description of GATE Valve (GA15CB500):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
e-

Class:............................ 1500
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
pl

Trim:............................. API 602 TRIM 8

Wedge Type:....................... SOLID
Bonnet Type:...................... BOLTED
m

Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Sa

Body-Bonnet Gaskets:.............. SS/GRAPHITE

Body-Bonnet Bolting:.............. BOLTS: API 602
NUTS: API 602
The standards are:
DESIGN - API 602
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 - GLOBE PATTERN (NPS 1/2 -to- NPS 3/4)
ASME B16.10 (NPS 1 -to- NPS 2)

Process Industry Practices Page 19 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA15CB501):

Type:............................. GATE
Valve Size:....................... NPS 1/2 -to- NPS 2
Class:............................ 1500
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A105 or A216 - WCB)
Bonnet:........................... CS (ASTM A105 or A216 - WCB)
Trim:............................. API 602 TRIM 5
Wedge Type:....................... SOLID

se
Bonnet Type:...................... WELDED
Bore-Port:........................ STANDARD
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL

U
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
The standards are:
DESIGN - API 602
ENDS - ASME B16.5

al
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 - GLOBE PATTERN (NPS 1/2 -to- NPS 3/4)
ASME B16.10 (NPS 1 -to- NPS 2)

ci
Description of GATE Valve (GA15CB502):
Type:............................. GATE

er
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 1500
Ends:............................. FLANGED RF

m
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 8
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
m
Bonnet Type:...................... BOLTED
Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Co
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. SS/GRAPHITE
Body-Bonnet Bolting:.............. BOLTS: API 600
NUTS: API 600
The standards are:
o

DESIGN - API 600

ENDS - ASME B16.5
RATING - ASME B16.34
N

TESTING - API 598

DIMENSIONAL - ASME B16.10

Description of GATE Valve (GA15CB503):

e-

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 1500
Ends:............................. FLANGED RF
Body:............................. CS (ASTM A216 - WCB)
pl

Bonnet:........................... CS (ASTM A216 - WCB)

Trim:............................. API 600 TRIM 5
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
m

Bonnet Type:...................... PRESSURE SEAL

Bore-Port:........................ FULL
Stem Design:...................... OS&Y
Operation:........................ HANDWHEEL
Sa

Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED

Body-Bonnet Gaskets:.............. MFG STD
Body-Bonnet Bolting:.............. BOLTS: MFG STD
NUTS: MFG STD
The standards are:
DESIGN - ASME B16.34 and MSS SP-144
ENDS - ASME B16.5
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 - LONG PATTERN

Process Industry Practices Page 20 of 21

 PIP PNSMV003 TECHNICAL REVISION
Carbon Steel Gate Valve Descriptions February 2015

Description of GATE Valve (GA15CB800):

Type:............................. GATE
Valve Size:....................... NPS 2 -to- NPS 24
Class:............................ 1500
Ends:............................. BW
Body:............................. CS (ASTM A216 - WCB)
Bonnet:........................... CS (ASTM A216 - WCB)
Trim:............................. API 600 TRIM 5

se
Wedge Type:....................... SOLID or FLEXIBLE (NPS 2 -to- NPS 4), FLEXIBLE (NPS 6 and greater)
Bonnet Type:...................... PRESSURE SEAL
Bore-Port:........................ FULL
Stem Design:...................... OS&Y

U
Operation:........................ HANDWHEEL
Stem-Packing:..................... FLEXIBLE GRAPHITE, ANTI-EXTRUSION RINGS and CORROSION INHIBITED
Body-Bonnet Gaskets:.............. MFG STD
Body-Bonnet Bolting:.............. BOLTS: MFG STD

al
NUTS: MFG STD
The standards are:
DESIGN - ASME B16.34 and MSS SP-144

ci
ENDS - ASME B16.25
RATING - ASME B16.34
TESTING - API 598
DIMENSIONAL - ASME B16.10 (NPS 2 -to- NPS 20)

er
MFG STD (NPS 24)

m
m
Co
o
N
e-
pl
m
Sa

Process Industry Practices Page 21 of 21
