1998 Dodge Neon

SYSTEM WIRING DIAGRAMS

Fig. 8: 2.0L, Engine Performance Circuits (1 of 3)

Afinación de Motor y Diagnostico

OBDII, VW.
Tijuana B.C. México
Rubén Ayala L.
044 664 252 34 69
audirwbenz@yahoo.com.mx
Techbook de Rubén @ Facebook.

9:54:24 AM
Monday, September 25, 2017 9:54:20 Page 1 © 2011 Mitchell Repair Information Company, LLC.
 1998 Dodge Neon
SYSTEM WIRING DIAGRAMS
Fig. 9: 2.0L, Engine Performance Circuits (2 of 3)

Afinación de Motor y Diagnostico

OBDII, VW.
Tijuana B.C. México
Rubén Ayala L.
044 664 252 34 69
audirwbenz@yahoo.com.mx
Techbook de Rubén @ Facebook.

9:55:20 AM
Monday, September 25, 2017 9:55:17 Page 1 © 2011 Mitchell Repair Information Company, LLC.
 1998 Dodge Neon
SYSTEM WIRING DIAGRAMS
Fig. 10: 2.0L, Engine Performance Circuits (3 of 3)

Afinación de Motor y Diagnostico

OBDII, VW.
Tijuana B.C. México
Rubén Ayala L.
044 664 252 34 69
audirwbenz@yahoo.com.mx
Techbook de Rubén @ Facebook.

9:56:01 AM
Monday, September 25, 2017 9:55:57 Page 1 © 2011 Mitchell Repair Information Company, LLC.
