BA2M-DDT

Small size, long distance diffuse reflective type

▣Features
lCapability of detecting long distance(2m)
by special optical design.
lStable received light indicator built in.
lSensitivity adjustment function built in.
l2 color LED display.

Please read "Caution for your safety" in operation

! manual before using.

▣Specifications
Model BA2M-DDT
Type Diffuse reflective
Detecting distance 2m
Detecting target Transparent, Translucent, Opaque material
Hysteresis Max. 20% at rated setting distance
Response time Approx. 1ms
Power supply 12-24VDC ±10%(Ripple P-P : Max. 10%)
Current consumption Max. 15mA(Max. 30mA when the output is ON)
Light source Infrared LED(850nm modulated)
Sensitivity adjustment Adjustable VR
Operation mode Light ON(Dark ON mode is optional)

Control output NPN open collector output ☞ Load voltage : Max. 30VDC, Load current : Max. 100mA,
Residual voltage : Max. 1V
Protection circuit Reverse polarity protection, Output short-circuit protection
Receiver Photo diode(Built-in IC)
Indication 2 color LED [Operation : Red, Stability : Yellow(Red+Green)]
Insulation resistance Min. 20MΩ(at 500VDC)
Noise strength ±240V the square wave noise(pulse width:1㎲) by the noise simulator
Dielectric strength 1000VAC 50/60Hz for 1minute
Vibration 1.5mm amplitude at frequency of 10 ~ 55Hz in each of X, Y, Z directions for 2 hours
Shock 100m/s²(10G) in X, Y, Z directions for 3 times
Ambient illumination Sunlight : Max. 10,000 , Incandescent lamp : Max. 3,000
Ambient temperature -20 ~ +55℃(at non-freezing status), Storage : -25 ~ +70℃
Ambient humidity 35 ~ 85%RH
Protection IP50(IEC specification)
Material Case : PBT, Lens : PMMA
Cable 3P, ø3mm, Length : 2m
Accessory Sensitivity adjustment tool
Approval
Weight Approx. 50g

J-9
 DC Long Distance Diffuse Type

▣Characteristic
(A)
Detecting area Detecting distance against Detecting distance against Counter

Measuring method Data the target size the target color

2.2 2.2 (%) White Yellow Red Blue (B)

2.0 2.0 100 Timer
1.8 1.8
90
1.6 1.6
1.4 1.4 75
1.2 1.2 60
L 1.0 1.0 (C)
0.8 0.8 45 Temp.
0.6 0.6 controlle
30 Black
0.4 0.4
0.2 15
0.2
0 0 0
60 40 20 0 -20 -40 -60 50 80 100 150 200 (D)
Power
Left ← Center → Right Detecting target size(mm) Non-glossy white paper 100% controlle
Operation position (mm) (Standard targets : 200× 200mm)

(E)
Panel
▣Control output diagram ▣Operation mode meter

Photoelectric sensor circuit Connection (F)

Tacho/
(Brown)+V Stable Received Operat ion Speed/
light area level Pulse
Load meter

(Black)Output
+ (G)
12-24VDC Unst able Display
Max. 100mA - operating area unit
Over current
protection
3.3Ω
(Blue)0V
Stable interrupted (H)
ar ea Sensor
controlle
▣Connections
lLight ON Type Stability
ON (I)
indicator
12-24VDC OFF Proximit
(Red, Green) sensor
Brown
+V
Operation ON
Load indicator
Black (Red LED) OFF (J)
Light on Photo
100mA Max. operation electri c
TR ON sensor
Blue output 0FF
0V
※Dark ON Type is optional.
(K)
Pressur
sensor

▣Dimensions
(L)
5 Rotary
encoder
2color LE D
(OperationU stability indicator)
Adjusting VR (M)
18.5 5-Phase
stepping
motor &
Driver &
Controlle

19

M3 BOLT
ø3, Cable : 2m
10±0.2 Unit:mm
