Power Distribution System
Power Distribution System
On
SUBMITTED BY
Arnab Nandi
Electrical Engineering
Academy of Technology
Roll No: 16901613025
Reg. No: 131690110525 of 2013-14
A. Chanda
Divisional Manager
Serampore Division (WBSEDCL)
Page | 1
STUDENT DECLARATION
This project has not been previously submitted to any other university /
institutions for any other examination and for any other purpose by any other
person. I will not use this project report in future to use as submission to any
other university, institutions or any publisher. I also promise not to allow /
permit any other persons to copy / publish any part /full material of this report
in any form.
ARNAB NANDI
Electrical Engineering,
Academy of Technology
Roll No: 16901613025
Reg. No: 131690110525 of 2013-14
Page | 2
PREFACE
The rationale behind the industrial training and preparing this report is to study
the working and steps involved in electrical power distribution system, the
equipments in an electrical sub-station, and the significance of each one of them
in distributing power to consumers.
I have tried my best to cover all the aspects of the electrical power distribution
system and their brief detailing in this project report.
Page | 3
ACKNOWLEDGEMENT
Page | 4
TABLE OF CONTENTS
Introduction................................................................................................................................. 6
Power System Components.......................................................................................................... 7
Distribution System...................................................................................................................... 8
Electrical Substation..................................................................................................................... 9
Transmission Substation .......................................................................................................10
Distribution Substation.........................................................................................................10
Substation Equipments ...............................................................................................................11
Transformers .......................................................................................................................11
Relays..................................................................................................................................17
Circuit Breakers....................................................................................................................18
Isolators ..............................................................................................................................20
Bus Bar ................................................................................................................................20
Distribution Feeder ..............................................................................................................21
Control Panel .......................................................................................................................21
Capacitor Bank.....................................................................................................................22
Lightning Arrestor ................................................................................................................22
Batteries..............................................................................................................................22
Secondary Distribution System....................................................................................................23
Overhead Distribution ..........................................................................................................25
Underground Distribution.....................................................................................................25
Commercial View........................................................................................................................26
Tariff ...................................................................................................................................26
Energy Meter.......................................................................................................................26
Load Curve ..........................................................................................................................27
Conclusion ..................................................................................................................................28
Bibliography ...............................................................................................................................29
Page | 5
INTRODUCTION
The electricity sector in India is predominantly controlled by Government of India's public
sector undertakings PSUs). Major PSUs involved in the generation of electricity include
National Thermal Power Corporation Ltd. (NTPC), National Hydroelectric Power
Corporation Ltd. (NHPC) and Nuclear Power Corporation of India (NPCI). Besides PSUs,
several state-level corporations, are also involved in the generation and intra-state distribution
of electricity. The Power Grid Corporation of India is responsible for the inter-state
transmission of electricity and the development of national grid.
India is world's 6th largest energy consumer, accounting for 3.4% of global energy
consumption. Due to India's economic rise, the demand of energy has grown at an average of
3.6% per annum over the past 30 years.
During the year 2014-15, the per capita electricity generation in India was 1,010 kWh with
total electricity consumption (utilities and non-utilities) of 938.823 billion or 746 kWh per
capita electricity consumption. Electric energy consumption in agriculture was recorded
highest (18.45%) in 2014-15 among all countries.
WBSETCL is responsible for transmitting power at 66 kV, 132kV, 220kV and 400kV in the
state of West Bengal.
WBSEDCL is responsible for distributing power at 33kV level and below. This state utility
at present has the consumer strength of over 68Lakhs. WBSEDCL provides power to
96% of West Bengal, catering to every sector — from ordinary villages to huge
industrial units. It serves a customer base of more than 1.65 crore across West
Bengal. The service network spans over 5 Zones, 18 Regional Offices, 70
Distribution Divisions and 501 Customer Care Centers.
Meeting 80% of the state’s peak power demand, WBSEDCL has achieved a profit of
Rs. 95.13 crore (PAT) in 2010-11. To mitigate short power supply and being an
environ- friendly corporate, WBSEDCL has set up Purulia Pumped Storage
Project with a capacity of 900MW hydel power.
Page | 6
POWER SYSTEM COMPONENTS
Electric power is generated at 11-25kV in a power station. To transmit over long distances, it
is then stepped-up to 400kV, 220kV or 132kV as necessary. Power is carried through a
transmission network of high voltage lines. Usually, these lines run into hundreds of
kilometers and deliver the power into a common power pool called the grid. The grid is
connected to load centers (cities) through a sub-transmission network of normally 33kV (or
sometimes 66kV) lines. These lines terminate into a 33kV (or 66kV) substation, where the
voltage is stepped-down to 11kV for power distribution to load points through a distribution
network of lines at 11kV and lower.
The power network, which generally concerns the common man, is the distribution network
of 11kV lines or feeders downstream of the 33kV substation. Each 11kV feeder which
emanates from the 33kV substation branches further into several subsidiary 11kV feeders to
carry power close
to the load points
(localities,
industrial areas,
villages, etc.,). At
these load points,
a transformer
further reduces
the voltage from
11kV to 415V or
220v to provide
the last-mile
connection
through feeders
(also called as
Low Tension LT
feeders) to
individual
customers, either
at 240V (single-Φ
) or at 415V
(three-Φ ).
Page | 7
DISTRIBUTION SYSTEM
The main function of an electrical power distribution system is to provide power to individual
consumer premises. Distribution of electric power to different consumers is done with much
low voltage level. Distribution of electric power is done by distribution networks.
Distribution networks consist of following main parts:
Feeder: It is a conductor which connects the substation to the area where power is to be
distributed.
Distributor: It is a conductor from which tapings are taken from pole mounted
transformer to the customer.
Service Mains: It is a small cable which connects the distributor to the customer’s meter.
Distribution System can be classified into the following types depending on the modes of
classifications:
Type of Voltage:
Primary Distribution System: 11kV, 6.6kV or 3.3kV
Secondary Distribution System: 415V or 220V.
Type of Construction:
Overhead System
Underground System
Number of Wires:
Two wire • Three wire • Four wire
Scheme of Connection:
Radial Distribution System
Ring or Loop Distribution System
Interconnected Distribution System
Page | 8
ELECTRICAL SUBSTATION
An electrical substation is a subsidiary station of an electricity generation, transmission and
distribution system where voltage is transformed from high to low or the reverse using
transformers. Electric power may flow through several substations between generating plant
and consumer, and may be changed in voltage in several steps.
A substation that has a step-up transformer increases the voltage while decreasing the current,
while a step-down transformer decreases the voltage while increasing the current for
domestic and commercial distribution.
Page | 9
There are several factors that need to be considered for deciding for a substation. Some
important primary factors in the design of substation are operational flexibility, supply
reliability, security and short circuit withstand capability etc.
One important factor to be considered first is the site selection. Substation design and some
equipment selection depends on site selection. Some factors which are considered during site
selection are:
The site should be near the load center keeping in view the future load growth.
Access road to the site for smooth movement of construction machines, equipment
and transformers.
Interference with communication signals. The construction company have to take
permission from the appropriate authority
Land should be fairly leveled to minimize development cost
The substation site should be as near to the town / city but should be clear of
public places, aerodromes, and military or police installations.
The land should not have water logging problem
The land should be far away from obstructions, to permit easy and safe approach
or termination of high voltage overhead transmission lines
Transmission Substations:
The three-Φ power leaves the generator and enters a transmission substation at the power
plant. This substation uses large transformers to convert or step up the generator's voltage
(11kV) to extremely high voltages (220kV) for long-distance transmission on the
transmission grid.
Distribution Substations:
A distribution substation transfers power from the transmission system to the distribution
system of an area. It is uneconomical to directly connect electricity consumers to the main
transmission network, unless they use large amounts of power, so the distribution station
reduces voltage to a level suitable for local distribution. The input for a distribution
substation is typically at least two transmission or sub transmission lines. The output is a
number of feeders. The feeders run along streets overhead (or underground, in some
cases) and power the distribution transformers at or near the customer premises. In
addition to transforming voltage, distribution substations also isolate faults in either the
transmission or distribution systems. Distribution substations are typically the points
of voltage regulation, although on long distribution circuits (of several miles/kilometers),
voltage regulation equipment may also be installed along the line.
SUBSTATION EQUIPMENTS
Page | 10
Figure 7: Arrangement of equipments in a substation
Transformers:
A Transformer is a static, alternating electromagnetic device that transfers electrica l
power between two or more circuits using electromagnetic induction. It is a constant power
device, constant flux device and a constant frequency device.
Since transformer is a constant power device: Vp Ip = Vs Is
As it is a constant flux device we get: IpNp= IsNs where,
Vp and Vs are voltage of the primary and secondary sides respectively
Ip and Is are currents of primary and secondary sides respectively
Np and N s are turns in the coils of primary and secondary sides respectively
𝐕𝐩 𝐈𝐬 𝐍𝐩
Equating the above two equations we get: = =
𝐕𝐬 𝐕𝐩 𝐍𝐩
Transformers are used to change the voltage level of the supply. While the transformers in
generating stations steps up the voltage to reduce the power losses (increasing voltage
Page | 11
reduces the current, thus reducing the I2 R losses), the transformers in transmission and
distribution systems gradually decreases the voltages in steps as required by the loads.
They are usually filled with oil and are cooled either by the surrounding atmosphere by air
blasts obtained from fans trained on them. Some also circulate the oil for additional cooling.
Because of the high voltages imposed on the incoming side, there is an elaborate electrical
connection going through the cover which is called as bushing. The supply circuits connected
to the terminals of the primary winding and the outgoing distribution feeders connected to the
terminals of the secondary winding.
Page | 13
Specifications of 33 kV CT: Specifications of 33 kV PT:
Rated Voltage: 33kV High Voltage Rating: 33/ √3 kV
Number of Cores: 3 Low Voltage Rating: 110/ √3 V
Rating: 20VA Φ:3
Ratio: 400-200A/5A Vector Group: YNyn
Figure 13: Circuit diagram showing connection of CT and PT for measuring high voltage and current
Distribution Transformers:
A distribution transformer or service transformer is a transformer that provides the
final voltage transformation in the electric power distribution system (415V line), stepping
down the voltage used in the distribution lines to the level used by the customer. If mounted
on a utility pole, they are called pole-mount transformers. If the distribution lines are located
at ground level or underground, distribution transformers are mounted on concrete pads and
locked in steel cases, thus known as pad-mount transformers.
Page | 14
Figure 14: Pole Mounted Distribution Transformer
Figure 15: Pad Mounted Distribution Transformer
Transformer Accessories:
Conservator: It consists of an airtight metal drum fixed above the level of the top of
the tank and connected with the tank is completely filled with oil. The conservator is
partially is filled with oil. The function of conservator is to take up construction and
expansion of oil without allowing it to come in contact with outside air. Transformer
oil will expand due to the heat generated because of losses.
Page | 15
Temperature Indicator: There are two temperature indicators on the transformer
tank one for oil temperature measurement and another for core temperature
measurement. In 31.5 MVA Transformers when oil temperature reaches 65o C cooling
fans starts automatically but when the oil temperature rises at 75o C or winding
temperature rises at 85o C the alarm circuit will be closed. Further increase in oil or
winding temp. The circuit will trip automatically. Cooling fans are placed beside the
radiator tube, which are used for oil cooling. Generally the cooling fans start
automatically but when needed it can be started manually.
Bushing: It is fixed on the transformer tank and these connections is made to the
external circuits. Ordinary porcelain insulators can be used as bushing up to voltage of
33 kV. Above 33 kV oil filled type bushings are used. In filled bushings, the
conductor is passed through the hollow porcelain insulator which is filled with oil.
Buchholz relay: It is a gas actuated relay installed in oil immersed transformers for
protection against overheating of the transformer windings. Overheating produces
heat and forces the evolution of H2 gas. It mainly consists of two float switches placed
in the connecting pipe between the main tank and conservator.
Page | 16
Relays:
A relay is a sensing element whose purpose is to sense the fault and generate a trip decision if
a fault within the relay’s jurisdiction is detected. The relay detects the abnormal condition in
the electrical circuit by constantly measuring the electrical quantities, which are different
under normal and fault condition. Relay itself is a low powered device. Hence the current and
voltage measured by the relay are stepped down using a CT or PT with a definite turns ratio.
The electrical quantities which may change under fault condition are voltage, current,
frequency and phase angle. Having detect the fault, the relay operate to close the trip circuit
of circuit breaker.
The following types of relays are generally used in electrical distribution system:
Figure 20: Circuit Diagram for Differential Protection Figure 21: Digital Differential Relay
Page | 17
Circuit Breakers:
A circuit breaker is an equipment, which can open or close a circuit under normal as well as
fault condition. These circuit breaker breaks for a fault which can damage other instrument in
the station. A circuit breaker consists of fixed and moving
contacts, which are touching each other under normal
condition i.e. when breaker is closed. Whenever a fault
occurs trip coil gets energized by the relay. The moving
contacts are pulled by some mechanism and therefore the
circuit is opened or circuit breaks. When circuit breaks an
arc is stack between contacts, the production of arc not
only interrupts the current but generates enormous amount
of heat which may cause damage to the system or the
breaker itself. Therefore the main problem in a circuit
breaker is to extinguish the arc within the shortest possible
time so that the heat generated by it may not reach a
dangerous value. The medium used for arc extinction is
usually oil, air, Sulfur Hexafluoride (SF6 ) or vacuum.
Figure 22: Operating Mechanism of Circuit Breaker
Page | 18
Air Blast Circuit Breaker:
The air blast circuit breakers employs compressed air (at a pressure of 20 k.g/c.m2 ) for arc
extinction and are finding their best application in systems operating 132 kV and above (up to
400kV)with breaking capacity up to 7,500 MVA (during short circuit fault)and above. These
breakers have the advantages of less burning of contacts because of less arc energy, little
maintenance, facility of high speed re closure, no risk of explosion and fire hazard and
suitability for duties requiring frequent operations. The drawbacks of such breakers are
additional need of compressor plant for supplying compressed air, current chopping,
sensitivity re-striking voltage and air leakage at the pipe line
fittings.
Figure 25: Operating Mechanism of SF6 Circuit Breaker Figure 26: SF6 Circuit Breaker
Page | 19
Isolators:
An isolator is used to ensure that an electrical circuit is completely de-energized for service
or maintenance. Unlike load switches and circuit breakers, isolators lack a mechanism for
suppression of electric arc. The main difference between a circuit breaker and isolator is that
a circuit breaker is on load device and is triggered by electromechanical mechanisms. An
isolator on the other hand is an off load device and is operated manually.
Bus Bar :
Bus bar is the main current carrying conductor in a power system. The bus is a line in which
the incoming feeders come into and get into the instruments for further step up or step down.
It is generally made of aluminum or copper bars.
There are many different electrical bus system schemes available but selection of a particular
scheme depends upon the system voltage, position of substation in electrical power system,
flexibility needed in system and cost to be expensed.
The most frequently used arrangement is Main Bus and Transfer Bus Arrangement. This
arrangement consists of two bus-bars, main bus and transfer bus. Each generator and feeder
can be connected to either bus bar with the help of Bus Coupler. Bus coupler allows change
from one bus to another under load conditions.
Page | 20
Distribution Feeder:
Distribution feeder circuits are the connections between the output terminals of a distribution
substation and the input terminals of primary circuits.
The distribution feeder circuit conductors leave the
substation from a circuit breaker or circuit reclose via
underground cables, called substation exit cables.
Several distribution feeder circuits can leave a
substation extending in different directions to serve
customers. The underground cables are connected to
the primary circuit via a nearby riser pole.
Distribution feeders emanating from a substation are
generally controlled by a circuit breaker which will
open when a fault is detected.
Control Panel:
Control and Relay panel is most important equipment of the substation as it work as shield
guard for all substation equipments and electrical network. Moreover, these panels are useful
to control the flow of electricity as per the load demand and detect the faults in power
systems. In this panel, varieties of numerical and electromechanical relays are installed to
provide damage protection to equipments. Meters, Control Switches, Indicating lamps, Push
Buttons, Annunciators and Relays are among of major equipments installed as per designing
requirements.
M etering
Instrument
s
Annunciator
Digital Hooter
Relay
Energy
M eter
Indicators
Page | 21
Capacitor Bank:
A capacitor bank is a grouping of several identical capacitors inter-connected in parallel or in
series with one another as required.
Since most of the loads are inductive, there is a net absorption of reactive power. The ratio of
active and reactive power is known as Power factor. Hence the power factor of the power
system reduces which is uneconomical. To compensate this reactive power, capacitor banks
are connected. The capacitors deliver the reactive power required by the inductive loads.
Lightning Arrester:
It is a device used in Electrical Power systems
to protect the insulation of the system from the
damaging effect of lightning. The typical
lightning arrestor is also known surge arrestor
has a high voltage terminal and a ground
terminal. When a lightning surge or switching
surge travels down the power system to the
arrestor, the current from the surge is diverted
around the protected insulation in most
cases to earth.
Lightning arrestors with earth switch are used
after the current transformers to protect it
from lightning i.e. from high voltage entering
into it. This lightning arrestor has an earth
switch that can directly earth the lightning.
The arrestor works at 30o to 45o angle of the
lightning making a cone. The earth switch
can be operated manually, by pulling
the switch towards the ground. This also helps
in breaking the line entering the station. By
doing so maintenance repair of any instrument
could be performed.
Batteries:
The operation of automatic control systems, protective relays and emergency lighting circuits
is supplied by station batteries. Lead-acid batteries are most commonly used in substations
because of their high cell voltage and low cost.
Page | 22
SECONDARY DISTRIBUTION SYSTEM
In secondary distribution system, electrical power is delivered to the consumers either at
415V (three Φ) or 220V (single Φ). Three Φ power at 415V is consumed for industrial use
where the machine loads are mostly three Φ induction motors. 220V single Φ power is
supplied to domestic consumers.
Each 11kV feeder which emanates from the 33kV substation branches further into
several subsidiary 11kV feeders to carry power close to the load points (localities,
industrial areas, villages, etc.,).
At these load points, a transformer further reduces the voltage from 11kV to 415V to
provide the last-mile connection through 415V feeders (also called as Low Tension
(LT) feeders) to individual customers, either at 240V (as single-Φ supply) or at 415V
(as three-Φ supply).
A feeder could be either an overhead line or an underground cable. In urban areas,
owing to the density of customers, the length of an 11kV feeder is generally up to 3
km. On the other hand, in rural areas, the feeder length is much larger (up to 20 km).
A 415V feeder should normally be restricted to about 0.5-1.0 km.
Page | 23
A 3 Φ 3 wire distribution system consists of three wires (R, Y, and B) whereas in 3 Φ 4 wire
system, an additional neutral wire is present.
When a 3 Φ 415V load is needed to be connected, three wires from three Φ s are
tapped in order to provide a 3 Φ supply to the load.
When a Single Φ 220V load is needed to be connected, we connect the load between
any of the Φ s and the neutral wire.
The wire connecting the single Φ load with any one of the Φ s of the three Φ supply (either R,
Y or B) is called Live wire. The Neutral wire is connected to the neutral of the three Φ
supply. The earth wire is connected to the earthing or gounding system at the consumer end.
This type of A.C distribution system is called Single Φ Three Wire Distribution.
Figure 34: 1Φ 3 Wire System showing Live, Neutral and Earth Connections
Page | 24
Overhead Distribution:
Overhead distribution system is much cheaper as compared to underground distribution as
insulator is not present throughout the entire length of the conductor. However it is more
prone to short circuit faults due to falling of tree branches.
Overhead lines are erected over utility poles made of reinforced concrete, steel or wood. The
distribution lines are connected to the poles using ceramic insulators to prevent conduction
with the metallic poles. Distribution transformers are mounted on utility poles which steps
down the voltage level to 415V or 220V.
Underground Distribution:
Underground distribution system is used in populated areas. Electrical power is distributed
using underground cables. This method is costly as insulator is present throughout the length
of conductor. Underground cables are less porn to short circuit faults, but more porn to open
circuit faults as heat dissipating ability is reduced under the
ground.
Page | 25
COMMERCIAL VIEW
The rate at which electrical energy is supplied to a consumer is known as tariff. Like other
commodities, electrical energy is also sold at such a rate so that it not only returns the cost
but also earns reasonable profit. Therefore, a tariff should include the following items:
Recovery of cost of producing electrical energy at the power station.
Recovery of cost on the capital investment in transmission and distribution systems.
Recovery of cost of operation and maintenance of supply of electrical energy e.g.,
metering equipment, billing etc.
Normally the tariff of electricity is mentioned in rate per kilowatt hour of power consumed or
rate per kWh. 1 kWh refers to the amount of electricity consumed when an appliance of one
kilowatt power rating runs for one full hour or sixty minutes. 1 kWh is also known as one
unit of electricity.
Types of Tariff:
Simple tariff: When there is a fixed rate per unit of energy consumed, it is called
simple tariff or uniform ate tariff. WBSEDCL doesn't provide this type of tariff.
Block Rate Tariff: When a given block of energy is charged at a specified rate and the
succeeding blocks of energy are changed at a progressively reduced rate.
Two Part Tariff: When the rate of electrical energy is charged on the basis of
maximum demand of the consumer and the units consumed.
Flat Rate Tariff: When different types of consumers are charged at different uniform
per unit rates
Energy Meter:
An energy meter or Watt-hour Meter is a device that measures the amount of electric energy
consumed by a residence, a business, or an electrically powered device. Electric utilities use
electric meters installed at customers' premises to measure electric energy delivered to their
customers for billing purposes. They are typically calibrated in billing units, the most
common one being the kilowatt hour (kWh). They are read once each billing period.
These may be single or three Φ meters depending on the supply utilized by domestic or
commercial installations. For small service measurements like domestic customers, these can
be directly connected between line and load. But for larger loads, step down current
transformers must be placed to isolate energy meters from higher currents.
Page | 26
Types of Energy Meters:
Electronic Type: These are of accurate, high procession and reliable types of
measuring instruments as compared to conventional mechanical meters. It consumes
less power and starts measuring instantaneously when connected to load. These
meters might be analog or digital. In analog meters, power is converted to
proportional frequency or pulse rate and it is integrated by counters placed inside it. In
digital electric meter power is directly measured by high end processor. The power
is integrated by logic circuits to get the energy
and also for testing and calibration purpose.
Load Curve:
A load curves is a chart showing the
amount of electrical energy customers'
use over the course of time. Power
producers use this information to plan
how much electricity they will need to
make available at any given time.
The vocational training had been conducted in a very efficient way. I have
acquired thorough knowledge about the power distribution system, the
equipment in an electrical sub-station and a proper knowledge about the
working and construction of each one of them.
Page | 28
BIBLIOGRAPHY
List of Websites:
www.wbsedcl.in
www.powermin.nic.in
www.iitk.ac.in
www.GEMultilin.com
www.electrical4u.com
www.wikipedia.org
List of Books:
Power System Engineering by Nagrath and Kothari
A Course in Power System by J.B Gupta
Electrical Machinery by Dr. P.S. Bimbhra
Electric Power Substations Engineering by John D. Mc Donald
Page | 29
