Logging and reporting

in FortiOS 4.0 ™
Version 4.0 MR1
User Guide
Logging and reporting in FortiOS 4.0
Version 4.0 MR1
24 August 2009
01-410-82625-20090824

© Copyright 2009 Fortinet, Inc. All rights reserved. No part of this publication including text, examples,
diagrams or illustrations may be reproduced, transmitted, or translated in any form or by any means,
electronic, mechanical, manual, optical or otherwise, for any purpose, without prior written permission of
Fortinet, Inc.

Trademarks
Dynamic Threat Prevention System (DTPS), APSecure, FortiASIC, FortiBIOS, FortiBridge, FortiClient,
FortiGate®, FortiGate Unified Threat Management System, FortiGuard®, FortiGuard-Antispam,
FortiGuard-Antivirus, FortiGuard-Intrusion, FortiGuard-Web, FortiLog, FortiAnalyzer, FortiManager,
Fortinet®, FortiOS, FortiPartner, FortiProtect, FortiReporter, FortiResponse, FortiShield, FortiVoIP, and
FortiWiFi are trademarks of Fortinet, Inc. in the United States and/or other countries. The names of actual
companies and products mentioned herein may be the trademarks of their respective owners.
Contents

Contents
Introduction .............................................................................................. 7
Before you begin............................................................................................................. 7
How this guide is organized........................................................................................ 7
Document conventions .................................................................................................. 8
IP addresses............................................................................................................... 8
Cautions, Notes and Tips ........................................................................................... 8
Typographical conventions ......................................................................................... 8
CLI command syntax ................................................................................................ 10
Registering your Fortinet product............................................................................... 11
Fortinet products End User License Agreement ....................................................... 11
Customer service and technical support.................................................................... 11
Training .......................................................................................................................... 11
Fortinet documentation ............................................................................................... 12
Tools and Documentation CD................................................................................... 12
Fortinet Knowledge Base ......................................................................................... 12
Comments on Fortinet technical documentation ..................................................... 12

Logging practices in FortiOS 4.0.......................................................... 13


About logging................................................................................................................ 13
Logging FortiGate features .......................................................................................... 14
Log devices ................................................................................................................... 14
System memory........................................................................................................ 14
Local disk or AMC disks ........................................................................................... 15
Structured Query Language (SQL) database on a FortiGate unit’s hard disk ... 15
FortiAnalyzer unit...................................................................................................... 15
FortiGuard Analysis server ....................................................................................... 15
Syslog server ............................................................................................................ 16
NetIQ WebTrends server.......................................................................................... 16
Backup solutions for logging ...................................................................................... 16
FortiGate units with hard disks and AMC hard disks ......................................... 16
FortiAnalyzer unit ............................................................................................... 17
Syslog server ..................................................................................................... 17
NetIQ WebTrends server backup solution ......................................................... 17

Configuring log devices ........................................................................ 19


Logging to the FortiGate unit’s system memory ....................................................... 20
Logging to the FortiGate unit’s hard disk................................................................... 20
Logging to the FortiGate unit’s SQL database.......................................................... 21

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 3
http://docs.fortinet.com/ • Feedback
Contents

Logging to a FortiAnalyzer unit ................................................................................... 21


Testing the FortiAnalyzer configuration .................................................................... 22
Connecting to a FortiAnalyzer unit using Automatic Discovery ................................ 22
Logging to a FortiGuard Analysis server ................................................................... 22
Logging to a Syslog server .......................................................................................... 23
Logging to a WebTrends server .................................................................................. 23
Example ............................................................................................................. 24
Logging to multiple FortiAnalyzer units or Syslog servers ...................................... 24
Configuring multiple FortiAnalyzer units ................................................................... 24
Configuring multiple Syslog servers ......................................................................... 25

Logging in FortiOS 4.0........................................................................... 27


FortiGate log types and subtypes ............................................................................... 27
Log severity levels ........................................................................................................ 29
Enabling logging of FortiGate features....................................................................... 29
Firewall policy traffic logging..................................................................................... 30
Event logging ............................................................................................................ 30
Data Leak Prevention logging................................................................................... 31
Application control logging........................................................................................ 31
Antivirus logging ....................................................................................................... 32
Web Filter logging..................................................................................................... 32
Attack logging ........................................................................................................... 32
Spam filter logging .................................................................................................... 33
DLP archiving ........................................................................................................... 33
Configuring an alert email message ........................................................................... 34
Viewing quarantined files............................................................................................. 35

FortiGate log messages ........................................................................ 37


Explanation of log messages....................................................................................... 37
Traffic log messages .................................................................................................... 38
Event log messages...................................................................................................... 40
DLP Archive logs .......................................................................................................... 41
Antivirus log messages................................................................................................ 43
WebFilter log messages ............................................................................................... 45
Attack log messages .................................................................................................... 47
Antispam log messages ............................................................................................... 49
DLP log message .......................................................................................................... 51
Application control log message................................................................................. 53

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 4
http://docs.fortinet.com/ • Feedback
Contents

Configuring reports in FortiOS 4.0 ....................................................... 57


Configuring reports ...................................................................................................... 57
Configuring basic traffic reports (FortiGate system memory only)............................ 57
Configuring FortiAnalyzer reports ............................................................................. 60
Configuring SQL database reports ........................................................................... 62
Viewing FortiAnalyzer reports ..................................................................................... 63

Index........................................................................................................ 65

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 5
http://docs.fortinet.com/ • Feedback
Contents

Logging and reporting in FortiOS 4.0 User Guide


6 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Introduction Before you begin

Introduction
This guide provides detailed information that explains how to begin choosing a log device
for your logging requirements, the types of log files, how to configure your chosen log
device, including detailed explanations of each log type of log messages.
Logging is an integral component of the FortiGate system. Logging allows you to view the
activity and status of the traffic passing through your network, and monitor for anomalies.
This chapter includes the following topics:
• Before you begin
• Document conventions
• Registering your Fortinet product
• Fortinet products End User License Agreement
• Customer service and technical support
• Training
• Fortinet documentation

Before you begin


Before you begin using this guide, take a moment to note the following:
• The FortiGate unit is successfully installed and integrated into the network.
• The FortiGate unit is currently running FortiOS 4.0 or higher.
• This guide includes detailed log message examples of each log type. If you need more
information about specific log messages, such as the event-vipssl log messages, see
the FortiGate Log Message Reference.

How this guide is organized


This document contains information about how to find the right log device for you logging
requirements, how to enable and configure logging to that device, and a detailed
explanation of each log type log message.
This document contains the following chapters:
Logging practices in FortiOS 4.0 provides general information about logging. We
recommend that you begin with this chapter as it contains information for both beginners
and advanced users as well.
Configuring log devices provides information about how to configure your chosen log
device. Configuring multiple FortiAnalyzer units or Syslog servers is also included.
Logging in FortiOS 4.0 provides information about the different log types and subtypes,
and how to enable logging of FortiGate features.
FortiGate log messages provides general information about log messages, such as what
is a log header. Detailed examples of each log type are discussed as well. For additional
information about all log messages recorded by a FortiGate unit running FortiOS 4.0 and
higher, see the FortiGate Log Message Reference.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 7
http://docs.fortinet.com/ • Feedback
Document conventions Introduction

Configuring reports in FortiOS 4.0 provides information about how to configure reports if
you have logged to a FortiAnalyzer unit, FortiGate system memory, or the FortiGate unit’s
hard disk SQL database.

Document conventions
Fortinet technical documentation uses the conventions described below:

IP addresses
To avoid publication of public IP addresses that belong to Fortinet or any other
organization, the IP addresses used in Fortinet technical documentation are fictional and
follow the documentation guidelines specific to Fortinet. The addresses used are from the
private IP address ranges defined in RFC 1918: Address Allocation for Private Internets,
available at http://ietf.org/rfc/rfc1918.txt?number-1918.

Cautions, Notes and Tips


Fortinet technical documentation uses the following guidance and styles for cautions,
notes and tips.

Caution: Warns you about commands or procedures that could have unexpected or
undesirable results including loss of data or damage to equipment.

Note: Presents useful information, usually focused on an alternative, optional method, such
as a shortcut, to perform a step.

Tip: Highlights useful additional information, often tailored to your workplace activity.

Typographical conventions
Fortinet documentation uses the following typographical conventions:
Table 1: Typographical conventions in Fortinet technical documentation

Convention Example
Button, menu, text box, From Minimum log level, select Notification.
field, or check box label
CLI input config system dns
set primary <address_ipv4>
end
CLI output FGT-602803030703 # get system settings
comments : (null)
opmode : nat
Emphasis HTTP connections are not secure and can be intercepted by
a third party.
File content <HTML><HEAD><TITLE>Firewall
Authentication</TITLE></HEAD>
<BODY><H4>You must authenticate to use this
service.</H4>

Logging and reporting in FortiOS 4.0 User Guide


8 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Introduction Document conventions

Table 1: Typographical conventions in Fortinet technical documentation


Hyperlink Visit the Fortinet Technical Support web site,
https://support.fortinet.com.
Keyboard entry Type a name for the remote VPN peer or client, such as
Central_Office_1.
Navigation Go to VPN > IPSEC > Auto Key (IKE).
Publication For details, see the FortiGate Administration Guide.

* For conventions used to represent command syntax, see “CLI command syntax” on page 10

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 9
http://docs.fortinet.com/ • Feedback
Document conventions Introduction

CLI command syntax


This guide uses the following conventions to describe syntax to use when entering
commands in the Command Line Interface (CLI).
Brackets, braces, and pipes are used to denote valid permutations of the syntax.
Constraint notations, such as <address_ipv4>, indicate which data types or string
patterns are acceptable value input.
For more information, see the FortiGate CLI Reference.
Table 2: Command syntax

Convention Description
Square brackets [ ] A non-required word or series of words. For example:
[verbose {1 | 2 | 3}]
indicates that you may either omit or type both the verbose word and
its accompanying option, such as:
verbose 3
Angle brackets < > A word constrained by data type.
To define acceptable input, the angled brackets contain a descriptive
name followed by an underscore ( _ ) and suffix that indicates the
valid data type. For example:
<retries_int>
indicates that you should enter a number of retries, such as 5.
Data types include:
• <xxx_name>: A name referring to another part of the
configuration, such as policy_A.
• <xxx_index>: An index number referring to another part of the
configuration, such as 0 for the first static route.
• <xxx_pattern>: A regular expression or word with wild cards
that matches possible variations, such as *@example.com to
match all email addresses ending in @example.com.
• <xxx_fqdn>: A fully qualified domain name (FQDN), such as
mail.example.com.
• <xxx_email>: An email address, such as
admin@mail.example.com.
• <xxx_url>: A uniform resource locator (URL) and its associated
protocol and host name prefix, which together form a uniform
resource identifier (URI), such as
http://www.fortinet./com/.
• <xxx_ipv4>: An IPv4 address, such as 192.168.1.99.
• <xxx_v4mask>: A dotted decimal IPv4 netmask, such as
255.255.255.0.
• <xxx_ipv4mask>: A dotted decimal IPv4 address and netmask
separated by a space, such as
192.168.1.99 255.255.255.0.
• <xxx_ipv4/mask>: A dotted decimal IPv4 address and CIDR-
notation netmask separated by a slash, such as such as
192.168.1.99/24.
• <xxx_ipv6>: An IPv6 address.
• <xxx_v6mask>: A dotted decimal IPv6 netmask.
• <xxx_ipv6mask>: A dotted decimal IPv6 address and netmask
separated by a space.
• <xxx_str>: A string of characters that is not another data type,
such as P@ssw0rd. Strings containing spaces or special
characters must be surrounded in quotes or use escape
sequences
• <xxx_int>: An integer number that is not another data type,
such as 15 for the number of minutes.

Logging and reporting in FortiOS 4.0 User Guide


10 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Introduction Registering your Fortinet product

Table 2: Command syntax


Curly braces { } A word or series of words that is constrained to a set of options
delimited by either vertical bars or spaces.
You must enter at least one of the options, unless the set of options is
surrounded by square brackets [ ].
Options delimited Mutually exclusive options. For example:
by vertical bars | {enable | disable}
indicates that you must enter either enable or disable, but must
not enter both.
Options delimited Non-mutually exclusive options. For example:
by spaces {http https ping snmp ssh telnet}
indicates that you may enter all or a subset of those options, in any
order, in a space-delimited list, such as:
ping https ssh
Note: To change the options, you must re-type the entire list. For
example, to add snmp to the previous example, you would type:
ping https snmp ssh
If the option adds to or subtracts from the existing list of options,
instead of replacing it, or if the list is comma-delimited, the exception
will be noted.

Registering your Fortinet product


Before you begin, take a moment to register your Fortinet product at the Fortinet Technical
Support web site, https://support.fortinet.com.
Many Fortinet customer services, such as firmware updates, technical support, and
FortiGuard Antivirus and other FortiGuard services, require product registration.
For more information, see the Fortinet Knowledge Center article Registration Frequently
Asked Questions.

Fortinet products End User License Agreement


See the Fortinet products End User License Agreement.

Customer service and technical support


Fortinet Technical Support provides services designed to make sure that your Fortinet
products install quickly, configure easily, and operate reliably in your network.
To learn about the technical support services that Fortinet provides, visit the Fortinet
Technical Support web site at https://support.fortinet.com.
You can dramatically improve the time that it takes to resolve your technical support ticket
by providing your configuration file, a network diagram, and other specific information. For
a list of required information, see the Fortinet Knowledge Center article What does
Fortinet Technical Support require in order to best assist the customer?

Training
Fortinet Training Services provides a variety of training programs to serve the needs of our
customers and partners world-wide. Visit the Fortinet Training Services web site at
http://campus.training.fortinet.com, or email training@fortinet.com.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 11
http://docs.fortinet.com/ • Feedback
Fortinet documentation Introduction

Fortinet documentation
The Fortinet Technical Documentation web site, http://docs.fortinet.com, provides the
most up-to-date versions of Fortinet publications, as well as additional technical
documentation such as technical notes.
In addition to the Fortinet Technical Documentation web site, you can find Fortinet
technical documentation on the Fortinet Tools and Documentation CD, and on the Fortinet
Knowledge Base.

Tools and Documentation CD


The documentation for your product is available on the Fortinet Tools and Documentation
CD shipped with your product. The documents on this CD are current at shipping time. For
the most current versions of Fortinet documentation, visit the Fortinet Technical
Documentation web site, http://docs.fortinet.com.

Fortinet Knowledge Base


The Fortinet Knowledge Base provides additional Fortinet technical documentation, such
as troubleshooting and how-to articles, examples, FAQs, technical notes, a glossary, and
more. Visit the Fortinet Knowledge Base at http://kb.fortinet.com.

Comments on Fortinet technical documentation


Please send information about any errors or omissions in this or any Fortinet technical
document to techdoc@fortinet.com.

Logging and reporting in FortiOS 4.0 User Guide


12 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging practices in FortiOS 4.0 About logging

Logging practices in FortiOS 4.0


This chapter contains valuable information about logging practices and what you need to
consider before logging FortiGate features on your FortiGate unit. This chapter includes
how logging affects system performance, what logging devices are appropriate for your
logging setup, and solutions for ensuring that logs are not lost if a failure occurs with your
logging device.
Fortinet recommends reading this chapter when one or more of the following applies:
• You are new to logging in general or new to logging using a FortiGate unit and log
device.
• You are deciding on a log scenario for your network environment and need to know
what log devices are available for the FortiGate unit, including what FortiGate features
would be best suited for your network traffic.
• You want to upgrade your current log scenario which may mean a new log device
(such as a FortiGuard Analysis server)
• You need to create a new log scenario because the current one no longer meets your
network’s means.
This chapter contains the following sections:
• About logging
• Logging FortiGate features
• Log devices
• Backup solutions for logging

About logging
Logging is a valuable tool, providing insight into how to better protect the network traffic
against attacks, including misuse and abuse. This valuable tool requires a plan so that you
can properly configure logging for your particular network’s needs.
This plan should provide you with an outline of what log requirements your network needs.
You plan should cover:
• what FortiGate features you want logged
• the logging device best suited for your network
• if you want or are required to archive log files
• ensuring log files are not lost in the event a failure occurs (backup solution).
Your plan should also include the following:
• The FortiGate features you want to log. For more information, see “Logging FortiGate
features” on page 14.
• The amount of storage space required to log the chosen FortiGate features. For
example, traffic logs cannot be stored in the FortiGate system memory because they
are large files. For more information, see “Logging FortiGate features” on page 14.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 13
http://docs.fortinet.com/ • Feedback
Logging FortiGate features Logging practices in FortiOS 4.0

• The type of device appropriate for logging the chosen FortiGate features. If your
organization/company requires reports compiled from log data, a FortiAnalyzer unit
may be a better solution since it can create reports at scheduled times. For more
information, see “Log devices” on page 14.
• A backup solution in the event your logging device becomes unavailable. For more
information, see “Backup solutions for logging” on page 16.

Logging FortiGate features


When you are deciding which FortiGate features should be logged, it is important to know
what types of features are best suited for your logging requirements. For example, you
want to archive only spam email messages and log VoIP, IM/P2P, event, and traffic logs.
You also need to know if your logging device accepts the types of FortiGate features that
you want log. For example, a FortiGuard Analysis server accepts all DLP archive logs, but
a Syslog server does not. The backup solution must also fit with what you want to log. For
example, you have enabled traffic, event and DLP archiving to log to a FortiAnalyzer unit
with a Syslog server as a backup solution: a power failure occurs with the FortiAnalyzer
unit and only traffic and event logs are sent to the Syslog server because DLP archives
are not supported.
The FortiGate unit can log eleven types of features. These types are:
• traffic
• event
• Data Leak Prevention (DLP)
• application control
• antivirus
• web filtering
• attack (IPS)
• spam filtering
• DLP archiving (available only if connected to a FortiAnalyzer unit)
If you have enabled and configured VDOMs on your FortiGate unit, you can enable
logging of FortiGate features within each VDOM. The log message, whether recorded in a
VDOM or not, provides what VDOM that log message was recorded in. For example, an
event log recorded user_1 editing administrative profiles for user_23 in the vdom_hq. This
type of detail provides you with additional help in tracking down and taking action against
such things as misuse and abuse or attacks.

Log devices
Log devices provide a secure place to store and view generated log files; however, some
these devices can also provide much more. For example, a FortiAnalyzer unit provides
both archiving and reporting features.
The following explains each of the supported log devices, including why that logging
device may be a good idea for your network.

System memory
The system memory on the FortiGate unit logs the following features:
• Event log

Logging and reporting in FortiOS 4.0 User Guide


14 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging practices in FortiOS 4.0 Log devices

• Attack log
• Antivirus log
• Webfilter log
• Spam log
• Data Leak Prevention log
• Application Control log
• IM/P2P log
• VoIP log
System memory is limited; the system memory cannot log traffic or DLP archive logs
because of their file size and occurrence; however, if you have a local disk, it can log traffic
or DLP archive logs.
If you configured system memory logging, these logs display in Log&Report > Log Access
> Memory. System memory is a good log device when you only require logging a few
FortiGate features or for small networks, such as a home business.

Local disk or AMC disks


If you configured local disk logging, these logs display in Log&Report > Log Access >
Disk. This option is available only on FortiGate units with hard disks.
If you have an AMC disk, you can enable uploading of log files to a FortiAnalyzer unit
using the CLI.

Structured Query Language (SQL) database on a FortiGate unit’s hard


disk
You can store logs within an SQL database if your FortiGate unit has a hard disk. This
SQL database allows users to configure reports from the logs stored on the database. You
need to enable the database from the CLI.

FortiAnalyzer unit
The FortiAnalyzer unit logs all FortiGate features and can also archive logs. If you also
require creating reports from log data, the FortiAnalyzer unit provides a wide variety of
reports. Reports contain log information that is presented in both graphical and tabular
formats. Reports are a useful tool for reviewing what has occurred on your network in a
daily, weekly, or monthly time period.
Logs are accessed from either the web-based manager of the FortiAnalyzer unit or the
web-based manager of the FortiGate unit (Log&Report > Log Access > Remote).
You can configure up to three FortiAnalyzer units for logging FortiGate features; however,
this is more of a redundant option than a back up solution.
The FortiAnalyzer unit is perfect for large networks that require DLParchiving and reports.

FortiGuard Analysis server


You can also configure logging to a FortiGuard Analysis server. The FortiGuard Analysis
Service provides a server which you can configure a FortiGate unit to log FortiGate
features to. The FortiGuard Analysis Service is a subscription-based service that provides
logging and reporting capabilities previously only found on a FortiAnalyzer unit. You can
log to a FortiGuard Analysis server if your FortiGate unit is running FortiOS 4.0 and higher.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 15
http://docs.fortinet.com/ • Feedback
Backup solutions for logging Logging practices in FortiOS 4.0

The FortiGuard Analysis server can log all FortiGate features including traffic logs, as well
as full DLP archiving of all archival FortiGate features, such as email messages and FTP.
You can also generate reports from the log data stored on the FortiGuard Analysis server.
FortiGuard Analysis servers provide all the features of a FortiAnalyzer unit, but without
having an actual, physical FortiAnalyzer unit. This service provides an easy,
maintenance-free environment for logging and is best for those networks that are growing
or administrators who may not have a lot of experience with logging with a FortiGate unit.
The FortiGuard Analysis server can be used in all types of networks, large or small.

Note: If you have not already upgraded to FortiOS 4.0, you can still subscribe to the
FortiGuard Analysis and Management Service so that you can configure your FortiGate unit
to log to a FortiGuard Analysis server; however, certain FortiOS 3.0 maintenance releases
do not contain all the available features that the current FortiGuard Analysis and
Management Service version supports.

Syslog server
The Syslog server can log all FortiGate features, including content logs and VoIP logs.
You can also configure up to three Syslog servers to log all FortiGate features. Configuring
three Syslog servers is more of a redundant solution, than a back up solution.
Syslog servers are useful in any network setup, large or small.
If you require reports (which are generated from log data), you need to log to a
FortiAnalyzer unit or FortiGuard Analysis server.

NetIQ WebTrends server


The NetIQ WebTrends server logs all FortiGate features, except DLP archive. You can
configure only one NetIQ WebTrends server to log FortiGate features. A NetIQ
WebTrends server is useful in any network setup, large or small.

Backup solutions for logging


You need to have a backup solution, or backup plan, in the event the logging device
becomes unavailable. If you decide not to include a backup solution when you begin
logging, log files may be lost if the logging device becomes unavailable.
The following are backup solutions for various logging devices.
The FortiGuard Analysis Service has several secondary FortiGuard Analysis servers
configured as backup servers in the event the FortiGuard Analysis server that is storing
your log files becomes unavailable. The FortiGuard Analysis service does not require a
backup solution because the secondary servers provide the backup solution you may
need if the FortiGuard Analysis server your FortiGate unit is logging to becomes
unavailable.

FortiGate units with hard disks and AMC hard disks


You can use the hard disk, if available, to log to a FortiAnalyzer unit with buffering to the
hard disk by the configuring this in the CLI. For more information, see the FortiGate CLI
Reference.
You can configure the AMC hard disk on the FortiGate unit, if available, to store logs
including DLP archives and then upload these logs to a FortiAnalyzer unit on a daily basis.
You can also schedule when to upload these logs from the AMC disk to the FortiAnalyzer
unit.

Logging and reporting in FortiOS 4.0 User Guide


16 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging practices in FortiOS 4.0 Backup solutions for logging

FortiAnalyzer unit
A backup solution to a FortiAnalyzer unit may be a Syslog server or NetIQ WebTrends
server. You could use a FortiGuard Analysis server as a backup solution to a FortiAnalyzer
unit as well.

Syslog server
You can configure up to three Syslog servers for ensuring logs are not lost when a failure
occurs. When the FortiGate unit logs to all three Syslog servers, all three Syslog servers
receive the same logs. This ensures logs are available at all times.

NetIQ WebTrends server backup solution


You can log to the FortiGate system memory or hard disk, as a backup solution when
logging FortiGate features to a NetIQ WebTrends server.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 17
http://docs.fortinet.com/ • Feedback
Backup solutions for logging Logging practices in FortiOS 4.0

Logging and reporting in FortiOS 4.0 User Guide


18 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring log devices

Configuring log devices


In your log plan, you chose a log device to meet your log requirements. This section helps
you to configure the log device you chose, including how to configure multiple
FortiAnalyzer units or Syslog servers. This section also includes how to log to a
FortiGuard Analysis server, which is available if subscribed to the FortiGuard Analysis and
Management Service.
If you need to configure multiple FortiAnalyzer units or Syslog servers, see “Logging to
multiple FortiAnalyzer units or Syslog servers” on page 24 to configure these devices.
The FortiGate unit supports logging to a variety of log devices, including the FortiGuard
Analysis server. This provides greater flexibility when logging requirements change. The
log devices that the FortiGate unit supports are:
• FortiGate system memory
• Hard disk or AMC
• SQL database (for FortiGate units that have a hard disk)
• FortiAnalyzer unit
• FortiGuard Analysis server (part of the FortiGuard Analysis and Management Service)
• Syslog server
• NetIQ WebTrends server
This chapter contains the following sections:
• Logging to the FortiGate unit’s system memory
• Logging to the FortiGate unit’s hard disk
• Logging to a FortiAnalyzer unit
• Logging to a FortiGuard Analysis server
• Logging to a Syslog server
• Logging to a WebTrends server
• Logging to multiple FortiAnalyzer units or Syslog servers

Note: All log entries are cleared from the FortiGate unit system memory when the FortiGate
unit restarts.

In FortiOS 4.0 MR1, the size of a log file is reduced. This provides more room for storing
large amounts of log files on log devices as well as on the FortiGate unit. If you currently
have a scheduled uploading or rolling of log files, you may need to re-schedule because of
the reduced size. For example, logs rolled every two months, now need to be rolled every
four months.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 19
http://docs.fortinet.com/ • Feedback
Logging to the FortiGate unit’s system memory Configuring log devices

Logging to the FortiGate unit’s system memory


The FortiGate system memory has a limited capacity for log messages. The system
memory displays recent log entries and stores most log types except traffic and content
logs. The FortiGate system memory cannot store traffic and content logs because of their
size and frequency of log entries. When the system memory is full, the FortiGate unit
overwrites the oldest messages. All log entries stored in system memory are cleared when
the FortiGate unit restarts.

To configure the FortiGate unit to save logs in memory


1 Go to Log&Report > Log Config > Log Setting.
2 Expand Local Logging & Archiving.
3 Select the check box beside Memory.
4 Select a log level from the Minimum log level list.
5 Select Apply.
The FortiGate unit logs all messages at and above the logging severity level you
select. For more information on log severity levels, see “Log severity levels” on
page 29.

Logging to the FortiGate unit’s hard disk


If your FortiGate unit contains a hard disk, you can configure the FortiGate unit to store
logs on the disk. You can configure logging to the FortiGate unit’s hard disk from
Log&Report > Log Config > Log Settings. When you are configuring to log to a hard disk,
you can also configure a schedule to upload those logs to either a FortiAnalyzer unit, if the
hard disk is AMC.

Figure 1: Log configuration settings on a FortiGate unit with a hard disk

To log to the hard disk on a FortiGate unit


1 Go to Log&Report > Log Config > Log Settings.
2 Expand Remote Logging & Archiving to reveal the available options.
3 Select the check box beside for Buffer to hard disk and upload.
4 To log to an AMC hard disk, select the check box beside Log to AMC Hard Disk &
Upload to FortiAnalyzer.

Logging and reporting in FortiOS 4.0 User Guide


20 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring log devices Logging to a FortiAnalyzer unit

Logging to the FortiGate unit’s SQL database


If your FortiGate unit has a hard disk and is running FortiOS 4.0 MR1, then you can send
logs to the SQL database. You must first set up the SQL database before configuring the
FortiGate unit to log to it.
The following assumes that you have already logged in to the web-based manager. If you
want to configure logging to an SQL database using the CLI, see the FortiGate CLI
Reference.

To log to an SQL database


1 Go to Log&Report > Log Config > Log Settings.
2 Under Local Logging & Archiving, select the check box beside Disk.
3 Select a log level from the Minimum log level list.
4 Select one of the following in the When log disk is full list:

Overwrite old logs Deletes the oldest log entry and continues logging when the
maximum log disk space is reached.
Do not log Stops log messages going to the FortiGuard Analysis server when
the maximum log disk space is reached.

5 Enter a maximum number (in MB) that the log file should not exceed in the Log file
should not exceed field.
6 To roll log files on a daily basis, select Daily in the Log files should be rolled list, and
then specify a time.
7 To roll log files on a weekly basis, select Weekly in the Log files should be rolled list,
select a week day, and then enter the time when the log file will roll.
8 Select SQL as the log format you want for each of the available logs under Log Storage
Format.
9 Select Apply.

Logging to a FortiAnalyzer unit


A FortiAnalyzer unit can log all FortiGate features that are available for logging, including
DLP archiving. The following procedure assumes that you have only one FortiAnalyzer
unit to configure. If you are configuring more than one, you must configuring the other
FortiAnalyzer units in the CLI. Use the procedures in “Configuring multiple FortiAnalyzer
units” on page 24 to configure multiple FortiAnalyzer units.

To send logs to a FortiAnalyzer unit


1 Go to Log&Report > Log Config > Log Setting.
2 Expand Remote Logging & Archiving to reveal the available options.
3 Select FortiAnalyzer.
4 In the IP/FQDN field, enter either the IP address of FQDN of the FortiAnalyzer unit.
5 Select a log level from the Minimum log level list.
6 Select Apply.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 21
http://docs.fortinet.com/ • Feedback
Logging to a FortiGuard Analysis server Configuring log devices

Testing the FortiAnalyzer configuration


After configuring FortiAnalyzer settings, you can test the connection between the
FortiGate unit and the FortiAnalyzer unit to ensure the connection is working properly. This
enables you to view the connection settings between the FortiGate unit and the
FortiAnalyzer unit.
To test the connection between your FortiGate unit and the FortiAnalyzer unit, go to
Log&Report > Log Config > Log Settings, and under Remote Logging & Archiving select
Test Connectivity beside the IP/FQDN field.

Connecting to a FortiAnalyzer unit using Automatic Discovery


Automatic Discovery is a method of establishing a connection to a FortiAnalyzer unit by
using the FortiGate unit to find a FortiAnalyzer unit on the network. The Fortinet Discovery
Protocol (FDP) is used to locate the FortiAnalyzer unit. Both units must be on the same
subnet to use FDP, and they must also be able to connect using UDP.
When you select Automatic Discovery, the FortiGate unit uses HELLO packets to locate
any FortiAnalyzer units that are available on the network within the same subnet. When
the FortiGate unit discovers the FortiAnalyzer unit, the FortiGate unit automatically
enables logging to the FortiAnalyzer unit and begins sending log data.

To connect to a FortiAnalyzer unit using Automatic Discovery


1 Go to Log&Report > Log Config > Log Settings.
2 Under Remote Logging & Archiving, in FortiAnalyzer, select Automatic Discovery.
3 If in Transparent mode, select an interface from the Interface list.
4 If available, select a FortiAnalyzer unit from the Connect To list when a FortiAnalyzer
unit is discovered.
5 Select Discover.
6 When you select Discover in Transparent mode, a warning displays. Select OK to
continue.
If your FortiGate unit is in Transparent mode, the interface using the automatic discovery
feature will not carry traffic. For more information about how to enable the interface to also
carry traffic when using the automatic discovery feature, see the Fortinet Knowledge Base
article, Fortinet Discovery Protocol in Transparent mode.

Note: The FortiGate unit searches within the same subnet for a response from any
available FortiAnalyzer units.

Logging to a FortiGuard Analysis server


You can configure logging to a FortiGuard Analysis server after registering for the
FortiGuard Analysis and Management Service. The following procedure assumes that you
have already configured the service account ID in System > Maintenance > FortiGuard.

To log to a FortiGuard Analysis server


1 Go to Log&Report > Log Config > Log Settings.
2 Expand Remote Logging & Archiving to reveal the available options.
3 Select the check box beside FortiGuard.
4 Enter the account ID in the Account ID field.

Logging and reporting in FortiOS 4.0 User Guide


22 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring log devices Logging to a Syslog server

5 Select one of the following:


Overwrite oldest logs Deletes the oldest log entry and continues logging when the
maximum log disk space is reached.
Do not log Stops log messages going to the FortiGuard Analysis server when
the maximum log disk space is reached.

6 Select a severity level.


7 Select Apply.

Logging to a Syslog server


The Syslog server is a remote computer running syslog software. Syslog is a standard for
forwarding log messages in an IP network. Syslog servers capture log information
provided by network devices.
Use the procedure in “Configuring multiple Syslog servers” on page 25 to configure
multiple Syslog servers.

To send logs to a syslog server


1 Go to Log&Report > Log Config > Log Setting.
2 Select the check box beside Syslog.
After you select the check box, the Syslog options appear.
3 Enter the appropriate information for the following:
IP/FDQN Enter the domain name or IP address of the syslog server.
Port Enter the port number for communication with the syslog
server, usually port 514.
Minimum log level Select a log level the FortiGate unit will log all messages at and
above that logging severity level. For more information about
log severity levels, see “Log severity levels” on page 29.
Facility Facility indicates to the syslog server the source of a log
message. By default, the FortiGate reports facility as local7.
You can change the Facility if you want to distinguish log
messages from different Fortinet units.
Enable CSV Format Select to have logs formatted in CSV format. When you enable
CSV format, the FortiGate unit produces the log in Comma
Separated Value (CSV) format. If you do not enable CSV
format, the FortiGate unit produces plain text files.

4 Select Apply.

Logging to a WebTrends server


A WebTrends server is a remote computer, similar to a Syslog server, running NetIQ
WebTrends firewall reporting server. FortiGate log formats comply with WebTrends
Enhanced Log Format (WELF) and are compatible with NetIQ WebTrends Security
Reporting Center and Firewall Suite 4.1.
To send logs to a WebTrends server, log in to the CLI and enter the following commands:
config log webtrends setting
set server <address_ip4>
set status {disable | enable}
end

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 23
http://docs.fortinet.com/ • Feedback
Logging to multiple FortiAnalyzer units or Syslog servers Configuring log devices

Example
This example shows how to enable logging to and set an IP address for a remote NetIQ
WebTrends server.
config log webtrends settings
set status enable
set server 172.25.82.145
end

Logging to multiple FortiAnalyzer units or Syslog servers


FortiOS 4.0 allows you to configure multiple FortiAnalyzer units or multiple Syslog servers,
ensuring that all logs are not lost in the event one of them fails.
You can configure multiple FortiAnalyzer units or Syslog servers within the CLI. You
should review the FortiGate CLI Reference before proceeding because the reference
document provides detailed explanations on all the CLI commands used in the following
procedures.

Configuring multiple FortiAnalyzer units


Fortinet recommends that you contact a FortiAnalyzer administrator first, to verify that the
IP addresses of the FortiAnalyzer units you want to send logs to are correct and that all
FortiAnalyzer units are currently installed with FortiAnalyzer 4.0 firmware.
If VDOMs are enabled, you can configure multiple FortiAnalyzer units or Syslog servers
for each VDOM. For more information, see the FortiGate CLI Reference.
The following procedure does not contain how to enable logging of FortiGate features
within the CLI. Use the FortiGate CLI Reference (the config log section) to enable
which FortiGate features to log.

To enable logging to multiple FortiAnalyzer units


1 Log in to the CLI.
2 Enter the following commands:
config log fortianalyzer setting
set status enable
set server <faz_ip address>
set encrypt [disable | enable] (if encryption is required)
set psksecret <password> (if encryption is required)
set localid <identification_ipsectunnel> (if encryption is required)
set conn-timeout <value_seconds>
end
3 Enter the following commands for the second FortiAnalyzer unit:
config log fortianalyzer2 setting
set status {disable | enable}
set server <fortianalyzer_ipv4>
set encrypt [disable | enable] (if encryption is required)
set psksecret <password> (if encryption is required)
set localid <identification_ipsectunnel> (if encryption is required)
set ver-1 {disable | enable}
set conn-timeout <value_seconds>
end
4 Enter the following commands for the last FortiAnalyzer unit:

Logging and reporting in FortiOS 4.0 User Guide


24 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring log devices Logging to multiple FortiAnalyzer units or Syslog servers

config log fortianalyzer3 setting


set status enable
set server <faz_ip address>
set encrypt [disable | enable] (if encryption is required)
set psksecret <password> (if encryption is required)
set localid <identification_ipsectunnel> (if encryption is required)
set conn-timeout <value_seconds>
end

Configuring multiple Syslog servers


When configuring multiple Syslog servers (or one Syslog server), you can configure
reliable delivery of log messages from the Syslog server. Configuring of reliable delivery is
available only in the CLI.
If VDOMs are enabled, you can configure multiple FortiAnalyzer units or Syslog servers
for each VDOM. For more information, see the FortiGate CLI Reference.
The following procedure does not contain how to enable logging of FortiGate features
within the CLI. Use the FortiGate CLI Reference (the config log section) to enable
which FortiGate features to log.

To enable logging to multiple Syslog servers


1 Log in to the CLI.
2 Enter the following commands:
config log syslogd setting
set csv {disable | enable}
set facility <facility_name>
set port <port_integer>
set reliable {disable | enable}
set server <ip_address>
set status {disable | enable}
end
3 Enter the following commands to configure the second third Syslog server:
config log syslogd2 setting
set csv {disable | enable}
set facility <facility_name>
set port <port_integer>
set reliable {disable | enable}
set server <ip_address>
set status {disable | enable}
end
4 Enter the following commands to configure the third Syslog server:
config log syslogd3 setting
set csv {disable | enable}
set facility <facility_name>
set port <port_integer>
set reliable {disable | enable}
set server <ip_address>
set status {disable | enable}
end

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 25
http://docs.fortinet.com/ • Feedback
Logging to multiple FortiAnalyzer units or Syslog servers Configuring log devices

Logging and reporting in FortiOS 4.0 User Guide


26 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging in FortiOS 4.0 FortiGate log types and subtypes

Logging in FortiOS 4.0


This section introduces you to the types of logs the FortiGate unit records, log severity
levels, and where to enable logging of FortiGate features in FortiOS 4.0.
This chapter contains the following sections:
• FortiGate log types and subtypes
• Log severity levels
• Enabling logging of FortiGate features
• Configuring an alert email message
• Viewing quarantined files

FortiGate log types and subtypes


The FortiGate unit can record the following log types based on the network traffic.

Log Type File name Description


Traffic tlog.log The traffic log records all traffic to and through the FortiGate
interface.
Event elog.log The event log records management and activity events. For
example, when an administrator logs in or logs out of the
web-based manager.
Antivirus vlog.log The antivirus log records virus incidents in Web, FTP, and email
traffic.
Web wlog.log The web filter log records HTTP FortiGate log rating errors
including web content blocking actions that the FortiGate unit
performs.
Attack alog.log The attack log records attacks that are detected and prevented by
the FortiGate unit.
Spam Filter slog.log The spam filter log records blocking of email address patterns and
content in SMTP, IMAP, and POP3 traffic.
Data Leak dlog.log The Data Leak Prevention log records log data that is considered
Prevention sensitive and that should not be made public. This log also records
data that a company does not want entering their network.
Application rlog.log The application control log records data detected by the FortiGate
Control unit and the action taken against the network traffic depending on
the application that is generating the traffic, for example, instant
messaging software, such as MSN Messenger.
DLP archive clog.log The DLP archive log, or clog.log, records all log messages,
including most IM log messages as well as the following session
control protocols (VoIP protocols) log messages:
• SIP start and end call
• SCCP phone registration
• SCCP call info (end of call)
• SIMPLE log message

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 27
http://docs.fortinet.com/ • Feedback
FortiGate log types and subtypes Logging in FortiOS 4.0

FortiGate logs also include log subtypes, which are types of log messages that are within
the main log type. For example, in the event log type there are the subtype admin log
messages. FortiGate log types and subtypes are numbered, and these numbers appear
within the log identification field of the log message. For more information, see “FortiGate
log messages” on page 37.
Table 3: Log types and subtypes

Log Type Category Sub-Type Sub-Type


Number Number
traffic (Traffic allowed – Policy allowed traffic 21
Log) 00 violation – Policy violation traffic 22
Other 38
event 01 system – System activity event 00
(Event Log) ipsec – IPSec negotiation event 01
dhcp – DHCP service event 02
ppp – L2TP/PPTP/PPPoE service event 03
admin – admin event 04
ha – HA activity event 05
auth – Firewall authentication event 06
pattern – Pattern update event 07
alertemail – Alert email notifications 23
chassis – FortiGate-4000 and 29
FortiGate-5000 series chassis event
sslvpn-user – SSL VPN user event 32
sslvpn-admin – SSL VPN administration 33
event
sslvpn-session – SSL VPN session even 34
his-performance – performance statistics 43
vipssl – VIP SSL events 45
ldb-monitor – LDB monitor events 46
dlp 09 dlp – Data Leak Prevention 54
(Data Leak
Prevention)
app-crtl 10 app-crtl-all – All application control 59
(Application
Control Log)
DLP archive HTTP – Virus infected 24
(DLP Archive FTP – FTP content metadata 25
Log) 06 SMTP – SMTP content metadata 26
POP3 – POP3 content metadata 27
IMAP – IMAP content metadata 28
virus (Antivirus infected – Virus infected 11
Log) 02 filename – Filename blocked 12
oversize – File oversized 13
webfilter (Web 03 content – content block 14
Filter Log) urlfilter – URL filter 15
FortiGuard block 16
FortiGuard allowed 17
FortiGuard error 18
ActiveX script filter 35
Cookie script filter 36
Applet script filter 37

Logging and reporting in FortiOS 4.0 User Guide


28 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging in FortiOS 4.0 Log severity levels

Table 3: (Continued)Log types and subtypes


ids (Attack Log) 04 signature – Attack signature 19
anomaly – Attack anomaly 20
emailfilter SMTP 08
(Spam Filter 05 POP3 09
Log) IMAP 10

Log severity levels


You can define what severity level the FortiGate unit records logs at when configuring the
logging location. The FortiGate unit logs all message at and above the logging severity
level you select. For example, if you select Error, the unit logs Error, Critical, Alert, and
Emergency level messages.
Table 4: Log severity levels

Levels Description
0 - Emergency The system has become unstable.
1 - Alert Immediate action is required.
2 - Critical Functionality is affected.
3 - Error An error condition exists and functionality could be
affected.
4 - Warning Functionality could be affected.
5 - Notification Information about normal events.
6 - Information General information about system operations.

The Debug severity level, not shown in Table 4, is rarely used. It is the lowest log severity
level and usually contains some firmware status information that is useful when the
FortiGate unit is not functioning properly. Debug log messages are only generated if the
log severity level is set to Debug. Debug log messages are generated by all types of
FortiGate features.

Enabling logging of FortiGate features


Within FortiOS 4.0, there are many different logs you can enable. Depending on what you
choose to log, you need to enable them in various locations within the web-based
manager. This section describes where you enable logging for each log type.
This topic includes the following:
• Firewall policy traffic logging
• Event logging
• Data Leak Prevention logging
• Application control logging
• Antivirus logging
• Web Filter logging
• Attack logging
• Spam filter logging
• DLP archiving

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 29
http://docs.fortinet.com/ • Feedback
Enabling logging of FortiGate features Logging in FortiOS 4.0

Firewall policy traffic logging


Firewall policy traffic logging records the traffic, both permitted and denied by the firewall
policy, based on the protection profile. Firewall policy traffic logging records packets that
match the policy. This method of traffic logging is preferred because it reduces system
load on the FortiGate unit.

To enable firewall policy traffic logging


1 Go to Firewall > Policy.
2 Expand to reveal the policy list of a policy.
3 Select Edit beside the policy that you want.
If required, create a new firewall policy by selecting Create New. For more information
about firewall policies, see the FortiGate Administration Guide.
4 Select the check box beside Log Allowed Traffic.
5 Select OK.

Note: You need to set the logging severity level to Notification when configuring a logging
location to record traffic log messages.

Event logging
The event log records management and activity events, such as when a configuration has
changed, admin login, or high availability (HA) events occur.
When you are logged in to VDOMs, certain options may not be available, such as VIP ssl
event or CPU and memory usage events. You can enable event logs only when you are
logged in to a VDOM; you cannot enable event logs in the root VDOM.

To enable the event logs


1 Go to Log&Report > Log Config > Event Log.
2 Select the Enable check box.
3 Select one or more of the following logs:
System activity All system-related events, such as ping server failure and gateway
event status.
IPSec negotiation All IPSec negotiation events, such as process and error reports.
event
DHCP service event All DHCP-events, such as the request and response log.
L2TP/PPTP/PPPoE All protocol-related events, such as manager and socket create
service event processes.
Admin event All administrative events, such as user logins, resets, and
configuration updates.
HA activity event All high availability events, such as link, member, and stat
information.
Firewall All firewall-related events, such as user authentication.
authentication event
Pattern update event All pattern update events, such as antivirus and IPS pattern
updates and update failure.
SSL VPN user All administrator events related to SSL VPN, such as SSL
authentication event configuration and CA certificate loading and removal.

Logging and reporting in FortiOS 4.0 User Guide


30 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging in FortiOS 4.0 Enabling logging of FortiGate features

SSL VPN All administration events related to SSL VPN, such as SSL
administration event configuration and CA certificate loading and removal.
SSL VPN session All session activity such as application launches and blocks,
event timeouts, verifications and so on.
VIP ssl event All server-load balancing events that are happening during SSL
session, especially details about handshaking.
VIP server health All related VIP server health monitor events that occur when the
monitor event VIP health monitor is configured, such as an interface failure.
CPU & memory usage Real-time CPU and memory events only, at 5-minute intervals.
(every 5 min)
4 Select Apply.

Data Leak Prevention logging


Data Leak Prevention (DLP) provides additional information for administrators that can
better analyze and detect data leaks. You can enable logging of your configured settings
for DLP within the DLP sensor.
Before enabling logging of DLP events, verify that you have the correct DLP sensor for
what you want logged.

To enable logging of DLP events


1 Go to Firewall > Protection Profile.
2 Select Edit beside the policy that you want.
3 Expand Data Leak Prevention to reveal the available options.
4 Select the check box next to the sensor list.
5 Select a sensor from the list.
6 Expand Logging to reveal the available options.
7 Select the Data Leak Prevention Log DLP check box.

Application control logging


This log file includes IPS, IM/P2P and VoIP events that the FortiGate unit records. The
application control log also includes some IPS activities.
Before enabling logging of Application Control events, verify that the correct application
control list is available for what you want to log. An application control list is required for
logging application control events.

To enable logging of application control settings


1 Go to Firewall > Protection Profile.
2 Select Edit beside the protection profile that you want.
3 Expand Application Control to reveal the available options.
4 Select the check box beside the application control list to enable the option.
5 Select a list from the application control list.
6 Expand Logging to reveal the available options.
7 Select the Log Application Control check box.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 31
http://docs.fortinet.com/ • Feedback
Enabling logging of FortiGate features Logging in FortiOS 4.0

Antivirus logging
The Antivirus logs record virus incidents in Web, FTP and email traffic. For example, when
the FortiGate unit detects an infected file, blocks a file type, or blocks an oversized file or
email. You can also apply filters to customize what the FortiGate unit logs, which are:
• Viruses – The FortiGate unit logs all virus infections
• Blocked Files – The FortiGate unit logs all instances of blocked files.
• Oversized Files/Emails – The FortiGate unit logs all instances of files and email
messages exceeding defined thresholds.
• AV Monitor – The FortiGate unit logs all instances of viruses, blocked files, and
oversized files and email. This applies to HTTP, FTP, IMAP, POP3, SMTP, and IM
traffic.

To enable antivirus logs


1 Go to Firewall > Protection Profile.
2 Select the Edit icon beside the protection profile that you want.
3 Expand Logging to reveal the available options.
4 Under Antivirus, select what antivirus events you want logged.
5 Select OK.

Web Filter logging


Web Filter logs record HTTP, FortiGuard log rating errors including web content blocking
actions.

To enable web filter logs


1 Go to Firewall > Protection Profile.
2 Select the Edit icon beside the protection profile that you want.
3 Expand Logging to reveal the available options.
4 Under Web Filtering, select the web filtering events to log.
5 Select the FortiGuard Web Filtering Rating Errors (HTTP only) to log FortiGuard
filtering.
6 Select OK.

Attack logging
The Attack log records attacks detected and prevented by the FortiGate unit. The
FortiGate unit will log attack signatures and attack anomalies.

To enable the attack logs


1 Go to Firewall > Protection Profile.
2 Select Edit beside the protection profile that you want.
3 Expand Logging to reveal the available options.
4 Select the check box beside Log Intrusions.
5 Select OK.

Logging and reporting in FortiOS 4.0 User Guide


32 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging in FortiOS 4.0 Enabling logging of FortiGate features

Spam filter logging


Spam Filter logs record blocking of email address patterns and content in SMTP, IMAP,
and POP3 traffic.

To enable the spam log


1 Go to Firewall > Protection Profile.
2 Select Edit beside the protection profile that you want.
3 Expand Logging to reveal the available options.
4 Select Log Spam.
5 Select OK.

DLP archiving
You can archive FTP, Email, IM, and Web (including HTTPS and all other secure
protocols), using DLP rules and sensors. This is referred to as DLP archiving. For more
information about enabling and configuring DLP archiving, see the UTM User Guide.
You can use the default DLP sensors for archiving, which are Content_Archive and
Content_Summary, available in UTM > Data Leak Prevention > Sensor. These two default
DLP sensors are dedicated to content archiving. Content_Archive provides full content
archiving, while Content_Summary provides summary DLP archiving. For more
information, see the UTM User Guide.
Figure 2 helps to explain what can be seen when full DLP archiving is enabled, such as
from the Email tab. When full DLP archiving is enabled, you can view the email message
and any attachments, including HTML or XML pages.

Figure 2: An example of an archived email message as displayed in DLP Archive > Email

Note: When viewing web archives, the URL is usually saved as a PDF, except for XML
pages which are saved as XML.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 33
http://docs.fortinet.com/ • Feedback
Configuring an alert email message Logging in FortiOS 4.0

Configuring an alert email message


You can use the Alert Email feature to monitor logs for log messages, and to send email
notification about a specific activity or event logged. For example, if you require
notification about administrators logging in and out, you can configure an alert email that is
sent whenever an administrator logs in and out. You can also base alert email messages
on the severity levels of the logs.
Before configuring alert email, you must configure at least one DNS server if you are
configuring with an Fully Qualified Domain Server (FQDN). The FortiGate unit uses the
SMTP server name to connect to the mail server, and must look up this name on your
DNS server. You can also specify an IP address.
To configure an alert email message, go to Log&Report > Log Config > Alert E-mail, enter
the information for the SMTP server, and then select Apply. Choose one of the following:
• If you want an alert email message sent based on log severity, select Send alert email
for logs based on severity, and then select a minimum log level.
• If you want an alert email message sent based on specific activities, such as an
administrator logging in or out, select Send alert email for the following and then select
the check boxes beside the available options.
To verify the alert email message can be sent to the recipient, select Test Connectivity.
This test can be done at anytime after configuring the SMTP server information.

Figure 3: Alert Email options

SMTP Server The name/address of the SMTP email server.


Email from The SMTP user name.

Logging and reporting in FortiOS 4.0 User Guide


34 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Logging in FortiOS 4.0 Viewing quarantined files

Email to Enter up to three email address recipients for the alert email message.
Authentication Select the authentication Enable check box to enable SMTP
authentication.
SMTP user Enter the user name for logging on to the SMTP server to send alert
email messages. You need to do this only if you have enabled the
SMTP authentication.
Password Enter the password for logging on to the SMTP server to send alert
email. You need to do this only if you selected SMTP authentication.
Send alert email for the Select to have the alert email sent for one or multiple events that
following occur, such as an administrator logging in and out.
Interval Time Enter the minimum time interval between consecutive alert emails.
(1-9999 minutes) Use this to rate-limit the volume of alert emails.
Intrusion detected Select if you require an alert email message based on attempted
intrusion detection.
Virus detected Select if you require an alert email message based on virus detection.
Web access blocked Select if you require an alert email message based on blocked web
sites that were accessed.
HA status changes Select if you require an alert email message based on HA status
changes.
Violation traffic Select if you require an alert email message based on violated traffic
detected that is detected by the Fortinet unit.
Firewall authentication Select if you require an alert email message based on firewall
failure authentication failures.
SSL VPN login failure Select if you require an alert email message based on any SSL VPN
logins that failed.
Administrator Select if you require an alert email message based on whether
login/logout administrators log in or out.
IPSec tunnel errors Select if you require an alert email message based on whether there is
an error in the IPSec tunnel configuration.
L2TP/PPTP/PPPoE Select if you require an alert email message based on errors that
errors occurred in L2TP, PPTP, or PPPoE.
Configuration changes Select if you require an alert email message based on any changes
made to the FortiGate configuration.
FortiGuard license Enter the number of days before the FortiGuard license expiry time
expiry time (1-100 notification is sent.
days)
FortiGuard log quota Select if you require an alert email message based on the FortiGuard
usage Analysis server log disk quota getting full.
Send alert email for logs Select if you want to send an alert email that is based on a specified
based on severity log severity, such as warning.
Minimum log level Select a log severity from the list. For more information about log
severity levels, see “Log severity levels” on page 29.

Note: The default minimum log severity level is Alert. If the FortiGate unit collects more
than one log message before an interval is reached, the Fortinet unit combines the
messages and sends out one alert email.

Viewing quarantined files


You can view quarantined files from Log&Report > Quarantine Files. You can also search
through these files to find a specific quarantined file, or filter the information you are
currently viewing.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 35
http://docs.fortinet.com/ • Feedback
Viewing quarantined files Logging in FortiOS 4.0

For more information about quarantined files, see the UTM User Guide.

Logging and reporting in FortiOS 4.0 User Guide


36 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Explanation of log messages

FortiGate log messages


FortiGate log messages present detailed accounts of an event or activity that happened
on your network recorded by the FortiGate unit. These log messages provide valuable
information about your network that inform you about attacks, misuse and abuse, and
traffic activity.
The following information provides explanations for each type of log message in FortiOS
4.0 MR1.
If you require more information about FortiGate log messages than this technical note
provides, see the FortiGate Log Message Reference on the Technical Documentation web
site.
This chapter contains the following sections:
• Explanation of log messages
• Traffic log messages
• Event log messages
• DLP Archive logs
• Antivirus log messages
• WebFilter log messages
• Attack log messages
• Antispam log messages
• DLP log message
• Application control log message

Explanation of log messages


The following log messages are explained in detail and are all recorded in FortiOS
4.0 MR1. Each field of each log message is clearly outlined and explained. If you need
additional information about specific log messages, see the FortiGate Log Message
Reference.
Before proceeding, you should be aware of the two parts that make up a log message: the
header and the body. The header is the beginning part of a log message and includes key
information about that specific log message, such as the date and time of when it was
recorded.
The following is an example of a log header:
2009-07-10 12:55:06 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0021010001 type=traffic
subtype=allowed pri=notice vd=root fwver=041000
The rest of the log message is the log body, which includes the log message. The log
message body contains specific information for that specific log type and subtype.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 37
http://docs.fortinet.com/ • Feedback
Traffic log messages FortiGate log messages

Traffic log messages


The Traffic log message records all traffic to and through the interfaces on the FortiGate
unit. The following is an example of a traffic log message.
2009-06-22 09:24:55 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0021010001 type=traffic
subtype=allowed pri=notice vd=root fwver=041000 SN=613874
duration=120 carrier_ep=N/A user=admin1 group=admingroup
policyid=1 proto=6 service=80/tcp app_type=N/A status=accept
src=172.16.135.25 srcname=172.16.135.25 dst=172.16.25.125
dstname=172.16.25.125 src_int=”internal” dst_int=”wan1”
sent=825 rcvd=4451 sent_pkt=8 rcvd_pkt=6 src_port=2504
dst_port=80 vpn=”N/A” tran_ip=0.0.0.0 tran_port=0 dir_disp=org
tran_disp=noop
date=(2009-06-22) The year, month and day of when the event occurred in yyyy-mm-
dd format.
time=(09:24:55) The hour, minute and second of when the event occurred in the
format hh:mm:ss.
devname= The name of the FortiGate unit. The name is either the default
(FGT50B3G06500085) name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name that
appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(0021010001) A ten-digit number. The first two digits represent the log type and
the following two digits represent the log subtype. The last five
digits are the message id.
type=(traffic) The section of system where the event occurred.
subtype=(allowed) The subtype of the log message. This represents a policy applied
to the FortiGate feature in the firewall policy.
pri=(notice) The severity level of the event. There are six severity levels to
specify. For more information, see “Log severity levels” on
page 29.
vd=(root) The virtual domain where the traffic was logged. In this example, it
is the root virtual domain.
fwver=(041000) The firmware version that was running when the log message was
recorded.
SN=(613874) The session number of the log message.
duration=(120) This represents the value in seconds.
carrier_ep=(N/A) The FortiOS Carrier end-point identification. For example, it would
display the MSISDN of the phone that sent the MMS message. If
you do not have FortiOS Carrier, this field always displays N/A.
user=(admin1) The name of the user creating the traffic.
group=(admingroup) The name of the group creating the traffic.
policyid=(1) The ID number of the firewall policy that applies to the session or
packet.
Any policy that is automatically added by the FortiGate will have
an index number of zero. For more information, see the Fortinet
Knowledge Base article, Firewall policy=0.

Logging and reporting in FortiOS 4.0 User Guide


38 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Traffic log messages

proto=(6) The protocol that applies to the session or packet. The protocol
number in the packet header that identifies the next level protocol.
Protocol number’s are assigned by the Internet Assigned Number
Authority (IANA).
service=(80/tcp) The IP network service that applies to the session or packet. The
services displayed correspond to the services configured in the
firewall policy.
app_type=(N/A) The application or program used. If there was no program used to
create the traffic, then it is empty and displays N/A. The following
are application types:
• BitTorrent
• eDonkey
• Gnutella
• KaZaa
• Skype
• WinNY
• AIM
• ICQ
• MSN
• Yahoo!
status=(accept) The status can be either deny or accept depending on the
applicable firewall policy.
src=(172.16.135.25) The source IP address.
srcname= The source name or the IP address.
(172.16.135.25)
dst=(172.16.25.125) The destination IP address.
dstname= The destination name or IP address.
(172.16.25.125)
src_ int= (internal) The interface where the through traffic comes in. For outgoing
traffic originating from the firewall, it is “unknown”.
dst_ int=(wan1) The interface where the through traffic goes to the public or
Internet. For incoming traffic to the firewall, it is “unknown”.
sent=(825) The total number of bytes sent.
rcvd=(4451) The total number of bytes received.
sent_ pckt=(8) The total number of packets sent during the session.
rcvd_pckt=(6) The total number of packets received during the session.
src_ port=(2504) The source port of the TCP or UDP traffic. The source protocol is
zero for other types of traffic.
dst_ port=(80) The destination port number of the TCP or UDP traffic. The
destination port is zero for other types of traffic.
vpn=(N/A) The name of the VPN tunnel used by the traffic.
tran_ip=(0.0.0.0) The translated IP in NAT mode. For transparent mode, it is
“0.0.0.0”.
tran_port=(0) The translated port number in NAT mode. For transparent mode, it
is zero (0).
dir_disp=(org) The direction of the sessions. Org displays if a session is not a
child session or the child session originated in the same direction
as the master session. Reply displays if a different direction is
taken from the master session.
tran_disp=(noop) The packet is source NAT translated or destination NAT translated.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 39
http://docs.fortinet.com/ • Feedback
Event log messages FortiGate log messages

Event log messages


The Event log message records all event activity. The following is an example of an event
log message that recorded an admin user adding a firewall policy.
2009-06-30 04:15:22 devname=devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0104032120 type=event
subtype=admin pri=notice vd=root fwver=041000 user=admin
ui=GUI(172.16.24.144) name=”admin” msg=”Administrator admin
edited the settings of administrator admin from
GUI(172.16.24.144)”
date=(2009-06-30) The year, month and day of when the event occurred in yyyy-
mm-dd format.
time=(04:15:22) The hour, minute and second of when the event occurred in the
format hh:mm:ss.
devname= The name of the FortiGate unit. The name is either the default
(FGT50B3G06500085) name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name
that appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(0104032120) A ten-digit number. The first two digits represent the log type
and the following two digits represent the log subtype. The last
five digits are the message id.
type=(event) The section of system where the event occurred.
subtype=(admin) The subtype of the log message. This represents a policy
applied to the FortiGate feature in the firewall policy.
pri=(notice) The severity level of the event. There are six severity levels to
specify. For more information, see “Log severity levels” on
page 29.
vd=(root) The virtual domain where the traffic was logged.
fwver=(041000) The firmware version that was running when the log message
was recorded.
user=(“admin”) The user’s admin profile, usually an administration user. In this
example, the admin administrator changed the banned word.
ui=[GUI (172.16. 34.144)] The interface where this particular event occurred, along with
the IP address of that interface. The ui field includes GUI, CLI,
console, and LCD.
name=(“admin”) The user who created the traffic.
msg=(“Administrator admin Explains the activity or event that the FortiGate unit recorded.
edited the settings of In this example, an administrator edited the settings of the
administrator admin from GUI administrator admin from the web-based manager.
(172.16.24.144)”)

Logging and reporting in FortiOS 4.0 User Guide


40 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages DLP Archive logs

DLP Archive logs


The DLP Archive log message provides information concerning logs that are archived on
the FortiAnalyzer unit.
The following is an example of a DLP archive web log message:
2009-07-10 11:19:36 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0624000000 type=contentlog
subtype=HTTP pri=information vd=root fwver=041000 SN=613874
user=user1 group=usergroup carrier_ep=N/A cat=N/A cat_desc=N/A
3:240060590:0:172.16.25.142<->172.25.124.133:clean:401/4203:
GET 172.25.124.133/favicon.ico
date=(2009-07-10) The year, month and day of when the event occurred in yyyy-mm-
dd format.
time (11:19:36) The hour, minute and second of when the DLP archive logged the
email event.
devname= The name of the FortiGate unit. The name is either the default
(FGT50B3G06500085) name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name that
appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGTFGT50B3G06500085)
log_id= A number identifying the log message. In the above example, 06
(0624000000) identifies the log as the DLP archive log and 24 identifies the DLP
archive log as a web archive log message.
log_type= The type of log. The log types are traffic, event, attack, antivirus,
(contentlog) web filter, and spam filter.
subtype=(HTTP) The subtype of the DLP archive. In this example, it is web because
the subtype is HTTP.
pri=(information) The severity or priority level of the event. For more information, see
“Log severity levels” on page 29.
vd=(root) The virtual domain where the traffic was logged.
fwver=(041000) The firmware version that was running when the log message was
recorded.
SN=(613874) The session number of the log message.
user=(“user1”) The name of the user creating the traffic.
group=(“usergroup”) The name of the group creating the traffic.
carrier_ep=(N/A) The FortiOS Carrier end-point identification. For example, it
displays the MSISDN of the phone that sent the MMS message. If
you do not have FortiOS Carrier, this field always display N/A.
cat=(N/A) The FortiGuard web site category number.
cat_desc=(N/A) The name of the FortiGuard web site category.
content log version: (3) The content log version number.
timestamp: (240060590) The time of the recorded DLP archive log.
serial number: (0) The session number of the DLP archive log.
client IP:(172.16.25.142) The IP address of the client server.
server IP: The IP address of the server where the mail came from.
(172.25.124.133)

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 41
http://docs.fortinet.com/ • Feedback
DLP Archive logs FortiGate log messages

HTTP status: (clean) Indicates the status of the HTTP content. This can be any one of
the following:
• clean
• infected
• heuristic
• banned_word
• blocked
• exempt
• oversize
number of bytes from client: The number of bytes that were received from the client.
(401)
number of bytes from The number of bytes that were received from the server.
server: (4203)
HTTP command: (GET) The type of HTTP command used. In this example, it was the GET
command.
url= The URL address of the web site that was accessed.
(172.25.124.133/favicon.ico)

Logging and reporting in FortiOS 4.0 User Guide


42 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Antivirus log messages

Antivirus log messages


The Antivirus log records virus incidents in Web, FTP, and email traffic. The following is an
example of an antivirus log message.
2009-07-26 02:25:01 devname=FGT50B3G06500085
device_id=FGT50B06500085 log_id=0213066000 type=virus
subtype=oversize pri=notice vd=root fwver=041000 policyid=1
serial=110961 user=“user23” group=“admingroup”
src=172.16.22.122 sport=1254 src_int=“port1” dst=10.10.25.1
dport=80 dst_int=”wan1” profile=“Profile_Office” service=“http”
agent=“n/a” status=“passthrough”
url=“http://172.16.25.124/finance/finance_headquarters/headqua
rters_pic1.png” ref=“n/a” msg=“File exceeds size limit.”
date=(2009-07-26) The year, month and day of when the event occurred in yyyy-mm-
dd format.
time=(02:25:01) The hour, minute and second of when the event occurred in the
format hh:mm:ss.
devname= The name of the FortiGate unit. The name is either the default
(FGT50B3G06500085) name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name that
appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(0213066000) A ten-digit number. The first two digits represent the log type and
the following two digits represents the log subtype. The last five
digits are the message ID.
type=(virus) The section of system where the event occurred.
subtype=(oversize) The subtype of the log message. This represents a policy applied
to the FortiGate feature in the firewall policy.
pri=(notice) The severity level of the event. For more information, see “Log
severity levels” on page 29.
vd=(root) The virtual domain where the event originated from.
fwver=(041000) The firmware version that was running when the log message was
recorded.
policyid=(1) The firewall policy identification number.
serial=(110961) The serial number of the log.
user=(“user23”) The name of the user creating the traffic.
group=(“admingroup”) The name of the group creating the traffic.
src=(172.16.22.122) The source IP address.
sport=(1254) The source port of where the traffic is originating from.
src_int=(“port1”) The interface of the source. In this example, the source interface
is the internal interface of the FortiGate unit.
dst=(10.10.25.1) The destination IP address.
dport=(80) The destination port of where the traffic is going to.
dst_int=(“wan1”) The interface of the destination. In this example, the destination
interface is the external interface of the FortiGate unit.
profile=(“Profile_Office”) The protection profile associated with the firewall policy that traffic
used when the log message was recorded.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 43
http://docs.fortinet.com/ • Feedback
Antivirus log messages FortiGate log messages

service=(“http”) The service of where the activity or event occurred, whether it was
on a web page using HTTP or HTTPs. The service field can have
the protocols HTTP, FTP or SMTP.
agent=(“n/a”) This field is for FortiGate units running FortiOS Carrier. If you do
not have FortiOS Carrier running on your FortiGate unit, this field
always displays N/A.
status=(“passthrough”) The action the FortiGate unit took when the event occurred.
url= The URL address of where the file was acquired.
(“http://172.16.25.127/financ
e/finance_headquarters/
headquarters_pic1.png”)
ref=(“n/a”) The URL reference that gives more information about the virus. If
you enter the URL in your web browser’s address bar, the URL
directs you to the specific page that contains information about the
virus.
msg= Explains the activity or event that the FortiGate unit recorded. In
(“File exceeds size limit.”) this example, the file that was downloaded from the web site
exceeded the specified size limit.

Logging and reporting in FortiOS 4.0 User Guide


44 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages WebFilter log messages

WebFilter log messages


The Webfilter log messages record HTTP FortiGate log rating errors, including web
content blocking actions that the FortiGate unit performs. The following is an example of a
Web filter log message.
2009-07-15 11:56:04 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0315093003 type=webfilter
subtype=urlfilter pri=information vd=root fwver=041000
policyid=4 serial=613044 user=”user23” group=”admingroup”
src=172.16.22.122 sport=2364 src_int=”internal”
dst=”10.10.30.120” dport=80 dst_int=”wan2” service=”http”
hostname=”a.example.com” profile=”ProtectionProfile_1”
status=exempted req_type=”referral” url=”example1.example.com”
msg=”URL was exempted because it is in the URL filter list”
date=(2009-07-15) The year, month and day of when the event occurred in yyyy-
mm-dd format.
time=(11:56:04) The hour, minute and second of when the event occurred in the
format hh:mm:ss.
devname= The name of the FortiGate unit. The name is either the default
(FGT50B3G06500085) name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name
that appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(0315093003) A ten-digit number. The first two digits represent the log type
and the following two digits represent the log subtype. The last
five digits are the message ID.
type=(webfilter) The section of system where the event occurred.
subtype=(urlfilter) The subtype of the log message. This represents a policy
applied to the FortiGate feature in the firewall policy.
pri=(information) The severity level of the event. For more information, see “Log
severity levels” on page 29.
vd=(root) The virtual domain where the event was logged.
fwver=(041000) The firmware version that was running when the log message
was recorded.
policyid=(4) The firewall policy identification number.
serial=(613044) The serial number of the log ID.
user=(“user23”) The name of the user creating the traffic.
group=(“admingroup”) The group name of the user creating the traffic.
src=(172.16.22.122) The source IP address.
sport=(2364) The source port number.
src_int=(“internal”) The name of the source interface. In this example, the source
interface is the internal interface of the FortiGate unit.
dst=(10.10.30.120) The destination IP address.
dport=(80) The destination port number.
dst_int=(“wan2”) The name of the destination interface. In this example, the
destination interface is the external interface of the FortiGate
unit.
service=(“http”) The service of where the event or activity occurred.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 45
http://docs.fortinet.com/ • Feedback
WebFilter log messages FortiGate log messages

hostname= The name of the web site accessed.


(“a.example.com”)
profile= The protection profile that was used with the firewall policy.
(“ProtectionProfile_1”)
status=(exempted) The status of the action taken when the event occurred. In this
example, the URL was exempted.
req_type=(“referral”) The type of request, which can be one of the following:
• referral – If the HTTP transaction is requested from a parent
web site such as selecting a link on a web page.
• direct – a direct connection to a web page, such as typing in
the URL address manually.
url= The URL of the web site.
(“example1.example.com”)
msg=(“URL was exempted Explains the activity or event that the FortiGate unit recorded. In
because it is in the URL filter this example, the URL is exempted since that URL is specified
list.”) as exempt in the URL filter list.

Logging and reporting in FortiOS 4.0 User Guide


46 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Attack log messages

Attack log messages


The Attack log messages record all attacks that occur against your network. These log
messages also contain links to the Fortinet Vulnerability Encyclopedia where you can
better assess the attack. When viewing these log messages from Log&Report > Remote,
you can view the packet log that is associated with an attack log message.
The following is an example of an attack log message.
2009-07-22 19:02:11 dev_name=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=04190700000 type=ips
subtype=signature pri=alert vd=root fwver=041000 policyid=2
serial=581265 attack_id=13707 severity=high carrier_ep=N/A
profile=N/A sensor=”all_default_pass” src=172.16.22.122
dst=10.10.20.10 src_port=52903 dst_port=139 src_int=”wan1”
dst_int=”internal” status=detected proto=6 service=139/tcp
user=user55 group=usergroup_1
ref=”http://www.fortinet.com/ids/VID13707” count=1
incident_serialno=86324148 msg=”netbios:
MS.Network.Share.Provider.Unchecked.Buffer.DoS”
date=(2009-07-22) The year, month and day of when the event occurred in
yyyy-mm-dd format.
time=(19:02:11) The hour, minute and second of when the event occurred in
the format hh:mm:ss.
devname=(FGT50B3G06500085) The name of the FortiGate unit. The name is either the
default name (FGT<serial_number>) or the name given by
an administrator. The name that appears in this field is the
name that appears in Host Name in System > Status in the
System Information widget.
device_id=(FGT50B3G06500085) The serial number of the FortiGate unit.
log_id=(0419070000) A ten-digit number. The first two digits represent the log type
and the following two digits represent the log subtype. The
last five digits are the message ID.
type=(ips) The part of the system where the event occurred.
subtype=(signature) The subtype of the log message.
pri=(alert) The severity level of the event. For more information, see
“Log severity levels” on page 29.
vd=(root) The virtual domain where the event was logged.
fwver=(041000) The firmware version that was running when the log
message was recorded.
policyid=(2) The firewall policy identification number.
serial=(581265) The serial number of the log message.
attack_id=(12707) The identification number of the attack log message.
severity=(high) The specified severity level of the attack.
carrier_ep=(N/A) The FortiOS Carrier end-point identification. For example, it
would display the MSISDN of the phone that sent the MMS
message. If you do not have FortiOS Carrier, this field
always display N/A.
profile=(N/A) The protection profile associated with the firewall policy that
traffic used when the log message was recorded.
sensor=(“all_default_pass”) The DLP sensor that was used.
src=(172.16.22.122) The source IP address.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 47
http://docs.fortinet.com/ • Feedback
Attack log messages FortiGate log messages

dst=(10.10.20.10) The destination IP address.


src_port=(52903) The source port number.
dst_port=(139) The destination port number.
src_int=(“wan1”) The name of the source interface.
dst_int=("internal”) The name of the destination interface.
status=(detected) The status of the action the FortiGate unit took when the
event occurred. In this example, the FortiGate unit detected
an attack.
proto=(6) The protocol of the event.
service=(139/tcp) The service of where the event or activity occurred.
user=(user55) The name of the user creating the traffic.
group=(usergroup_1) The name of the group creating the traffic.
ref=(“http://www.fortinet.com/ids/ The reference URL of where to find more information about
VID13707”) the attack.
count=(1) The number of times that attack was detected within a short
period of time. This is useful when the attacks are DoS
attacks.
incident_serialno=(86324148) The unique ID for this attack. This number is used for cross-
referencing IPS packet logs.
msg= Explains the activity or event that the FortiGate unit
(“netbios:MS.Network.Share. recorded. In this example, an attack occurred that could
Provider.Unchecked.Buffer.DoS”) have caused a system crash.

Logging and reporting in FortiOS 4.0 User Guide


48 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Antispam log messages

Antispam log messages


The antispam log messages record blocking of email address patterns and content in
SMTP, IMAP and POP3 traffic. The following is an example of an antispam log message.
2009-06-20 10:19:04 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0509083003 type=emailfilter
subtype=pop3 pri=notice vd=root fwver=041000 policyid=1
serial=511989 user=”N/A” group=”N/A” src=172.16.130.25
sport=1874 src_int=”internal” dst=192.168.39.8 dport=110
dst_int=”wan2” service=”pop3” profile=“Profile_1”
status=”detected” from=”admin1@example.com”
to=”user23@example.com” msg=”from email address is in email
blacklist.(no.4 pattern matched)”
date=(2009-06-20) The year, month and day of when the event occurred in
yyyy-mm-dd format.
time=(10:19:04) The hour, minute and second of when the event occurred in the
format hh:mm:ss.
devname= The name of the FortiGate unit. The name is either the default
(FGT50B3G06500085) name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name
that appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(0509083003) A ten-digit number. The first two digits represent the log type
and the following two digits represent the log subtype. The last
five digits are the message id.
type=(emailfilter) The section of system where the event occurred.
subtype=(pop3) The subtype of the log message. This represents a policy
applied to the FortiGate feature in the firewall policy.
pri=(notice) The severity level of the event. For more information, see “Log
severity levels” on page 29.
vd=(root) The virtual domain where the event was logged.
fwver=(041000) The firmware version that was running when the log message
was recorded.
policyid=(1) The firewall policy identification number.
serial=(511989) The serial number of the log.
user=(“N/A”) The name of the user creating the traffic.
group=(“N/A”) The name of the group creating the traffic.
src=(172.16.130.25) The source IP address.
sport=(1874) The source port.
src_int=(“internal”) The name of the source interface.
dst=(192.168.39.8) The destination IP address.
dport=(“110”) The destination port.
dst_int=(“wan2”) The name of the destination interface.
service=(“pop3”) The service of where the event or activity occurred.
profile=(“Profile_1”) The protection profile associated with the firewall policy that
traffic used when the log message was recorded.
status=(“detected”) The action the FortiGate unit took when the attack occurred.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 49
http://docs.fortinet.com/ • Feedback
Antispam log messages FortiGate log messages

from= The sender’s email address.


(“admin1@example.com”)
to= The receiver’s email address.
(“user23@example.com”)
msg=[“from email address is in Explains the activity or event that the FortiGate unit recorded.
email blacklist. (no.4 pattern In this example, the sender’s email address is in the blacklist
matched”)] and matches the fourth email address in that list.

Logging and reporting in FortiOS 4.0 User Guide


50 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages DLP log message

DLP log message


The Data Leak Prevention log messages record events that may be either leaking out
from or entering your network.
The following is an example of a data leak prevention log message.
2009-07-15 12:22:36 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=0954110000 type=dlp
subtype=dlp pri=notice vd=root fwver=041000 policyid=1
serial=613874 user=”user1” group=”admingroup” src=172.16.20.144
sport=2504 src_int=”internal” dst=172.16.152.255 dport=80
dst_int=”wan2” service=”http” status=”detected”
hostname=”172.16.152.255” url=”example.com”
from=”user22@example.com” to=”user55@example.com” msg=”data
leak detected(Data Leak Prevention Rule matched)”
rulename=”All-HTTP” action=”log-only” severity=”1”
date=(2009-07-15) The year, month and day of when the event occurred in
yyyy-mm-dd format.
time=(12:22:36) The hour, minute and second of when the event occurred in
the format hh:mm:ss.
devname=(FGT50B3G06500085) The name of the FortiGate unit. The name is either the default
name (FGT<serial_number>) or the name given by an
administrator. The name that appears in this field is the name
that appears in Host Name in System > Status in the System
Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(095411000) A ten-digit number. The first two digits represent the log type
and the following two digits represent the log subtype. The last
five digits are the message id.
type=(dlp) The section of system where the event occurred.
subtype=(dlp) The subtype of the log message.
pri=(notice) The severity level of the event. For more information, see “Log
severity levels” on page 29.
vd=(root) The virtual domain where the event was logged.
fwver=(041000) The firmware version that was running when the log message
was recorded.
policyid=(1) The firewall policy identification number.
serial=(613874) The serial number of the log.
user=(“user1”) The name of the user creating the traffic.
group=(“admingroup”) The name of the user group creating the traffic.
src=(172.16.20.144) The source IP address.
sport=(2504) The source port.
src_int=(“internal”) The name of the source interface.
dst=(172.16.152.255) The destination IP address.
dport=(80) The destination port.
dst_int=(“wan2”) The name of the destination interface.
service=(“http”) The service of where the event or activity occurred.
status=(“detected”) The action the FortiGate unit took when the attack occurred.
hostname=(“172.16.152.255”) The host name. In this example it is an IP address.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 51
http://docs.fortinet.com/ • Feedback
DLP log message FortiGate log messages

url=(“example.com”) The URL address of the web site that was visited.
from= The sender’s email address.
(“user22@example.com”)
to= The receiver’s email address.
(“user55@example.com”)
msg=[“(data leak detected (Data Explains the activity or event that the FortiGate unit recorded.
Leak Prevention Rule In this example, the data leak that was detected match the
matched”)] rule, All-HTTP, in the DLP sensor.

rulename=(“All-HTTP”) The name of the rule within the DLP sensor.


action=(“log-only”) The action that was specified within the rule. In some rules
within sensors, you can specify content archiving. If no log
type is specified, this field displays log-only.
severity=(“1”) The level of severity for the specified rule.

Logging and reporting in FortiOS 4.0 User Guide


52 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Application control log message

Application control log message


The application control log messages records IM, P2P and VoIP activity. This log file also
records some IPS activities.
The following is an example of an application control log message.
2009-07-13 13:55:23 devname=FGT50B3G06500085
device_id=FGT50B3G06500085 log_id=1059116020 type=app-crtl
subtyp=app-crtl-all pri=notice vd=root fwver=041000
user=”user23” group=”admingroup” carrier_ep=”N/A” kind=N/A
profile=”N/A” dir=N/A src=172.16.23.99 src_port=443
src_int=”wan1” dst=10.10.20.1 dst_port=2524 dst_int=”internal”
src_name=”172.16.23.99” dst_name=”10.10.20.1” proto=6
service=”2524/tcp” policyid=1 serial=613935 app_list=”App_1”
app_type=”N/A” app=”Unknown Application” action=pass count=1
msg=”:Unknown Application”
date=(2009-07-13) The year, month and day of when the event occurred in
yyyy-mm-dd format.
time=(13:55:23) The hour, minute and second of when the event occurred in
the format hh:mm:ss.
devname= The name of the FortiGate unit. The name is either the
(FGT50B3G06500085) default name (FGT<serial_number>) or the name given by
an administrator. The name that appears in this field is the
name that appears in Host Name in System > Status in the
System Information widget.
device_id= The serial number of the FortiGate unit.
(FGT50B3G06500085)
log_id=(1059116020) A ten-digit number. The first two digits represent the log
type and the following two digits represent the log subtype.
The last five digits are the message id.
type=(app-crtl) The section of system where the event occurred.
subtype=(app-crtl-all) The subtype of the log message. This represents a policy
applied to the FortiGate feature in the firewall policy.
pri=(notice) The severity level of the event. For more information, see
“Log severity levels” on page 29.
vd=(root) The virtual domain where the event was logged.
fwver=(041000) The firmware version that was running when the log
message was recorded.
user=(“user23”) The name of the user creating the traffic.
group=(“admingroup”) The name of the group creating the traffic.
carrier_ep=(“N/A”) The FortiOS Carrier end-point identification. For example, it
would display the MSISDN of the phone that sent the MMS
message. If you do not have FortiOS Carrier, this field
always display N/A.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 53
http://docs.fortinet.com/ • Feedback
Application control log message FortiGate log messages

kind=(N/A) The type of operation which triggered the action. This can
be any one of the following:
• login
• chat
• file
• photo
• audio
• call
• regist
• unregister
• call-block
• request
• response
profile=(“N/A”) The protection profile associated with the firewall policy that
traffic used when the log message was recorded.
dir=(N/A) The direction of the traffic that triggered the action, which
can be incoming, outgoing, N/A, or unknown.
src=(172.16.23.99) The source IP address.
sport=(443) The source port.
src_int=(“wan1”) The name of the source interface.
dst=(10.10.20.1) The destination IP address.
dport=(2524) The destination port.
dst_int=(“internal”) The name of the destination interface.
src_name=(“172.16.23.99”) The name of the source.
dst_name=(“10.10.20.1”) The name of the destination.
proto=(6) The protocol that applies to the session or packet. The
protocol number in the packet header that identifies the
next level protocol. Protocol number’s are assigned by the
Internet Assigned Number Authority (IANA).
service=(“2524/tcp”) The service of where the event or activity occurred.
policyid=(1) The firewall policy identification number.
serial=(613935) The session number of the application control log
message. same as dlp
app_list=(“App_1”) The name of the application control list that triggered the
action.
app_type=(“N/A”) The type of application that triggered the action within the
control list.
app=(“Unknown Application”) The name of the application that triggered the action within
the control list.
action=(pass) The action that was taken by the application control engine.
This can be any one of the following:
• pass
• block
• monitor
• kickout
• encrypt-kickout
• reject
• unknown
count=(1) The number of times the same event was detected within a
short period of time.
msg=(:Unknown Application”) Explains the activity or event that the FortiGate unit
recorded. In this example, the application control list App_1
detected an unknown application.

Logging and reporting in FortiOS 4.0 User Guide


54 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
FortiGate log messages Application control log message

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 55
http://docs.fortinet.com/ • Feedback
Application control log message FortiGate log messages

Logging and reporting in FortiOS 4.0 User Guide


56 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring reports in FortiOS 4.0 Configuring reports

Configuring reports in FortiOS 4.0


You can configure a variety of reports in FortiOS 4.0 and higher. Reports help you to better
analyze the activity that is occurring on your network by using graphs or tables. In FortiOS
4.0 MR1, you can configure reports from logs stored on an SQL database.
This chapter contains the following sections:
• Configuring reports
• Viewing FortiAnalyzer reports

Note: You can configure reports from logs stored on a FortiAnalyzer unit, FortiGate system
memory, or an SQL database. Configuring reports from other log devices, such as a Syslog
server, are not supported.

Configuring reports
A report is a collection of log information, which is then displayed in the report in the form
of text, graphs and tables. This provides a clear, concise overview of the activities on your
network without manually going through large amounts of log messages.
If you have configured logging to a FortiAnalyzer unit, you will only be able to configure a
report schedule on the FortiGate side. You need to verify with the FortiAnalyzer
administrator that a report layout is available for you to use with the report schedule; a
report schedule requires a report layout.
If you have configured logging to an SQL database, you can configure report widgets
which are very similar to the Top Viruses or Traffic History widgets that display on System
> Dashboard. You cannot customize the type of graph or table that appears in the report
widget.

Configuring basic traffic reports (FortiGate system memory only)


If a FortiGate unit is collecting logs in its system memory, you can configure and then view
a basic traffic report in Log & Report > Report Access > Memory. These reports get log
information from various system memory logs, such as VoIP and accessed web sites.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 57
http://docs.fortinet.com/ • Feedback
Configuring reports Configuring reports in FortiOS 4.0

Figure 4: A basic traffic report displaying only Browsing, DNS and Email log information over
the last three days

When you go to the Memory page, there are two reports that appear on the page,
Bandwidth Protocols and Top Protocols Ordered by Total Volume. The first report,
Bandwidth Protocols, is the report that you can configure. The second report, Top
Protocols Ordered by Total Volume, displays traffic volume and does not update when you
configure Bandwidth Protocols report. When you go to another page in the web-based
manager, the settings on the Memory page go back to default; the basic traffic report that
you configured is not saved on the FortiGate unit’s system memory.
To configure a basic traffic report, go to Log&Report > Report Access > Memory, and
select a time period from the Time Period list. Select the check boxes beside the options
(such as Email) that you do not want included in the graph, and then select Apply.

Logging and reporting in FortiOS 4.0 User Guide


58 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring reports in FortiOS 4.0 Configuring reports

Figure 5: Default basic report on the Memory page

Time Period Select a time range to view for the graphical analysis. You can
choose from one day, three days, one week, or one month. The
default day is 1 day. When you refresh your browser or go to
different menu, the settings revert back to default.
Services By default all services are selected. When you refresh your
browser or go to a different menu, all services revert to default
settings. Clear the check boxes beside the services you do not
want to include in the graphical analysis:
• Browsing
• DNS
• Email
• FTP
• Gaming
• Instant Messaging
• Newsgroups
• P2P
• Streaming
• TFTP
• VoIP
• Generic TCP
• Generic UDP
• Generic ICMP
• Generic IP

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 59
http://docs.fortinet.com/ • Feedback
Configuring reports Configuring reports in FortiOS 4.0

Bandwidth Per This bar graph is based on what services you select, and is
Service updated when you select Apply. The graph is based on date and
time, which is the current date and time.
Top Protocols This bar graph displays the traffic volume for various protocols, in
Ordered by Total decreasing order of volume. The bar graph does not update when
Volume you select different Services and then select Apply.

Note: The date used to present the information for the basic traffic report is erased when
the FortiGate unit is reset or rebooted.

Configuring FortiAnalyzer reports


FortiAnalyzer reports are configured on a FortiAnalyzer unit; however, you can configure a
report schedule from the FortiGate unit in Log&Report > Report Config > Schedule. You
need to have a report layout when configuring a report schedule. Report layouts are
configured only on the FortiAnalyzer unit.
If you want to configure a report schedule based on another report schedule, you can
clone the report schedule. Cloning a report schedule produces a duplicate of the original
and then editing that duplicate to create a new schedule.
To configure a report schedule, go to Log&Report > Report Config > Schedule, select
Create New, and enter the information needed for that report schedule. The report
schedule may take some time, depending on the amount of log data needed and if there
are other reports being generated on the FortiAnalyzer unit.
To clone a report schedule, go to Log&Report > Report Config > Schedule, select Clone in
the same row of the report schedule that will be the basis of the new report schedule, and
then rename it. For example, CloneOfFGT_50B. Enter the information for that schedule
and then select OK.

Logging and reporting in FortiOS 4.0 User Guide


60 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring reports in FortiOS 4.0 Configuring reports

Figure 6: Configuring a report schedule

Delete
Edit
Clone

General report schedule settings


Create New Select to create a new report schedule.
Name The name of the report schedule.
Description A comment or note that describes that report schedule. This is optional.
Report Layout The report layout that will be used when the report is generated.
Schedule The time period specified for when the report is generated. For example, the
report schedule report_june will be generated only once.
Configuration settings for report schedule
Name Enter a name for the schedule.
Description Enter a description for the schedule. This is optional.
Report Layout Select a configured report layout from the list. You must apply a report layout
to a report schedule.
Language Select a language from the list.
Schedule Select one of the following to have the report generate only once, daily,
weekly, or monthly at a specified date or time period.
Once Select to have the report generated only once.
Daily Select to generate the report on every day of the week at the same time.
Select the time from the hour list and minute list in Time.
Weekly Select to generate the report on specified days of the week. Select the check
box beside each day of the week or a day of the week you want the report to
generate on. Select the time from the hour list and minute list in Time.
Monthly Select to generate the report on a monthly basis. Enter the date range in the
field provided; for example, if you wanted the report to generate on the 1st
day of the month and the 15th day of the month, enter 1, 15.

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 61
http://docs.fortinet.com/ • Feedback
Configuring reports Configuring reports in FortiOS 4.0

Log Data Filtering You can specify the variables that were selected in the charts when the
report layout (that you are using for this report schedule) was configured.
Virtual Domain Select to create a report based on virtual domains. Enter a specific virtual
domain to include in the report. If you want to include multiple virtual
domains, use a comma between each.
User Select to create a report based on a network user. Enter the user or users,
separated by a comma, in the field.
Group Select to create a report based on a group of network users, that are defined
locally. Enter the name of the group or groups, separated by a comma, in the
field.
Time Period The time period of what
• Relative to report run-time – select to specify the time period of the log
files that will be used for the report.
• Specify – specify the start and end dates (year, date, month and time
period) of the log files that will be used for the report.
Output Select the check box beside the type of file format that you want the report to
be in when it is generated. You can choose from PDF, MS Word, Text (TXT),
and MHT.

Configuring SQL database reports


If you have configured logging to a FortiGate unit’s SQL database, you can create reports
from those logs. SQL database reports appear on the Execute Summary page and are
represented as widgets. You cannot customize the type of chart, such as bar or pie, but
you can customize what column the widget displays in, such as the second column.

Figure 7: Adding a report widget to the Execute Summary page

+ Add Widget Select to add a report widget to the Execute Summary page. You can
only add one report widget at a time.
Widgets The list of available reports widgets.
Schedule The type of time period used.
• If you select Daily, you need to configure the hour that the report
widget will gather the information and generate the output on.
• If you select Weekly, you need to configure the day of the week
and the hour that the report widget will gather the information and
generate the output on.
Daily Select to configure the hour of when the report widget will generate
the output. Hours are in the 24-hour format.
Weekly Select to configure the day of the week and the hour of the day that
will generate output on. Hours are in the 24-hour format.
Display Column Select one of the following to customize which column contains the
information:

Logging and reporting in FortiOS 4.0 User Guide


62 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Configuring reports in FortiOS 4.0 Viewing FortiAnalyzer reports

First Column The widget will display in the first column, which is located on the left
side of the page beside the menus. By default, the first column is
selected.
Second Column Select to have the widget display in the second column, on the right
side of the page.

To configure an SQL database report


1 Go to Log&Report > Report Access > Execute Summary.
2 Select + Add Widget.
3 In Add New Widgets to Report Summary, select a report widget from the Widgets list.
Certain report widgets only display a table and others only display a graph. You cannot
customize the type of graph that displays.
4 Select OK.
The report widget appears on the Execute Summary page.
5 Repeat steps 2 to 4 until all of the report widgets that you need on the Executive
Summary page are configured.

Viewing FortiAnalyzer reports


After the FortiAnalyzer unit generates the report, it appears on the Report Access page.
All reports are listed on the page, including the rolled reports. A list displays the generated
report schedules as well as other reports that the FortiAnalyzer unit generated.
From the Report Access page, you can also print a generated FortiAnalyzer report. You
may want to print the report to have as hardcopy reference or for a presentation.
To view reports, go to Log&Report > Report Access and select a report name in the
Report Files column. You can also select the Expand Arrow to view the rolled reports
within the report. After viewing the report, select Historical Reports to return to the list.
To print off a report, go to Log&Report > Report Access, select the report you want printed
from the list and then select Print.

Figure 8: Browsing historical reports on the Report Access page

Logging and reporting in FortiOS 4.0 User Guide


01-410-82625-20090824 63
http://docs.fortinet.com/ • Feedback
Viewing FortiAnalyzer reports Configuring reports in FortiOS 4.0

Logging and reporting in FortiOS 4.0 User Guide


64 01-410-82625-20090824
http://docs.fortinet.com/ • Feedback
Index

Index
A documentation
commenting on, 12
adding configuring defining, 22 Fortinet, 12
alert email message, 34 dotted decimal, 10
antivirus logging, 32
application control, 31
attack logging, 32
F
basic traffic reports (system memory), 57 FortiAnalyzer unit, 15
CLI command syntax, 10 FortiGate documentation
connecting using automatic discovery, FortiAnalyzer, 22 commenting on, 12
data leak prevention logging, 31 FortiGate features, logging, 14
data types in angled brackets, 10 FortiGuard
dlp archiving, 33 Antivirus, 11
event logging, 30 services, 11
explanation of log messages, 37
FortiGuard Analysis server, 15, 22
firewall policy traffic logging, 30
FortiAnalyzer reports, 60 Fortinet
FortiAnalyzer unit, 21 Technical Support, 11
hard disk, 20 Fortinet documentation, 12
log messages, 37 Fortinet Knowledge Center, 12
log severity levels, 29 fully qualified domain name (FQDN), 10
log types and subtypes, 27
logging, 13 I
logging practices, 13
multiple FortiAnalyzer units, 24 introduction
multiple syslog servers, 25 Fortinet documentation, 12
spam filter logging, 33 IP address
sql database, 21 private network, 8
sql database reports, 62
syslog server, 23 L
system memory, 20
testing FortiAnalyzer configuration, 22 local disk, amc disks, 15
web filter logging, 32 log backup solutions
webtrends server, 23 FortiAnalyzer unit, 17
hard disks and amc disks, 16
netiq webtrends server, 17
C syslog server, 17
CIDR, 10 log devices
comments, documentation, 12 FortiAnalyzer unit, 15
configuring FortiGuard Analysis server, 15
alert email message, 34 local disk, amc disks, 15
basic traffic reports (system memory), 57 netiq webtrends server, 16
FortiAnalyzer reports, 60 sql database, 15
multiple FortiAnalyzer units, 24 syslog server, 16
multiple syslog servers, 25 system memory, 14
sql database reports, 62 log messages
connecting using automatic discovery, FortiAnalyzer, 22 antispam, 49
customer service, 11 antivirus, 43
application control, 53
attack, 47
D dlp, 51
devices dlp archive, 41
FortiAnalyzer unit, 15 event, 40
FortiGuard Analysis server, 15 traffic, 38
local disk, amc disks, 15 webfilter, 45
netiq webtrends, 16 log types and subtypes, 27
sql database, 15 logging features, 14
syslog server, 16
system memory, 14 N
netiq webtrends server, 16

Logging and reporting in FortiOS 4.0 Version 4.0 MR1 User Guide
01-410-82625-20090824 65
http://docs.fortinet.com/ • Feedback
Index

P sql databse, 15
string, 10
product registration, 11 syslog server, 16
system memory, 14
Q
quarantine files, 35 T
technical
R support, 11
regular expression, 10 testing FortiAnalyzer configuration, 22
reports (FortiAnalyzer), 60
reports (sql database), 62 V
RFC value parse error, 10
1918, 8 viewing quarantine files, 35
S W
severity levels (logs), 29 wild cards, 10

Logging and reporting in FortiOS 4.0 Version 4.0 MR1 User Guide
01-410-82625-20090824 66
http://docs.fortinet.com/ • Feedback
www.fortinet.com
www.fortinet.com

You might also like
