SCHOOL
Bharatpur (Rajasthan)
2019- 20
Physics Project
ELECTROSTATICS
It is further certified that this project is the individual work of the candidate.
Date: Principal:
External Examiner:
Acknowledgements
Secondly, I would also like to thank my parents and friends who helped me a
lot in finalizing this project within the limited time frame.
ACKNOWLEDGEMENT
S
ince classical physics, it has been known that some materials such
as amber attract lightweight particles after rubbing. The Greek word
for amber, ήλεκτρον, or electron, was the source of the word
'electricity'. Electrostatic phenomena arise from the forces that electric
charges exert on each other. Such forces are described by Coulomb's law.
Even though electrostatically induced forces seem to be rather weak, some
electrostatic forces such as the one between an electron and a proton, that
together make up a hydrogen atom, is about 36 orders of
magnitude stronger than the gravitational force acting between them.
There are many examples of electrostatic phenomena, from those as
simple as the attraction of the plastic wrap to one's hand after it is
removed from a package to the apparently spontaneous explosion of
grain silos, the damage of electronic components during manufacturing,
and photocopier & laser printer operation. Electrostatics involves the
buildup of charge on the surface of objects due to contact with other
surfaces.
Although charge exchange happens whenever any two surfaces contact
and separate, the effects of charge exchange are usually only noticed
when at least one of the surfaces has a high resistance to electrical flow.
This is because the charges that transferred are trapped there for a time
long enough for their effects to be observed. These charges then remain
on the object until they either bleed off to ground or are quickly
neutralized by a discharge: e.g., the familiar phenomenon of a static
'shock' is caused by the neutralization of charge built up in the body from
contact with insulated surfaces.
ELECTRIC CHARGE
Historically the credit of discovery of the fact that amber rubbed with
wool or silk cloth attracts light objects goes to Thales of Miletus,
Greece, around 600 BC. The name electricity is coined from the
Greek word elektron meaning amber. Many such pairs of materials
were known which on rubbing could attract light objects like straw, pith
balls and bits of papers. You can perform the following activity at
home to experience such an effect.
Cut out long thin strips of white paper and lightly iron them. Take
them near a TV screen or computer monitor. You will see that the
strips get attracted to the screen. In fact they remain stuck to the screen
for a while. It was observed that if two glass rods rubbed with wool or
silk cloth are brought close to each other, they repel each other The
two strands of wool or two pieces of silk cloth, with which the rods
were rubbed, also repel each other. However, the glass rod and wool
attracted each other. Similarly, two plastic rods rubbed with cat’s fur
repelled each other but attracted the fur. On the other hand, the
plastic rod attracts the glass rod and repel the silk or wool with which
the glass rod is rubbed. The glass rod repels the fur. If a plastic rod
rubbed with fur is made to touch two small pith balls (now-a-days we
can use polystyrene balls) suspended by silk or nylon thread, then the
balls repel each other and are also repelled by the rod. A similar effect
is found if the pith balls are touched with a glass rod rubbed with silk.
A dramatic observation is that a pith ball touched with glass rod
attracts another pith ball touched with plastic rod .These seemingly
simple facts were established from years of efforts and careful
experiments and their analyses. It was concluded, after many careful
studies by different scientists, that there were only two kinds of an
entity which is called the electric charge. We say that the bodies like
glass or plastic rods, silk, fur and pith balls are electrified.
They acquire an electric charge on rubbing. The experiments on pith balls
suggested that there are two kinds of electrification and we find that
(i) like charges repel and
(ii) (ii) unlike charges attract each other.
The experiments also demonstrated that the charges are transferred from
the rods to the pith balls on contact. It is said that the pith balls are
electrified or are charged by contact. The property which differentiates
the two kinds of charges is called the polarity of charge.
Physicists believe that charge is a fundamental quantity, and will have its
own unit. However, there is one interesting property of charge that mass,
length and time do not have:
charge is quantized in multiples of a basic charge. This means that the
charge on any particle or object is an integer multiple of a fundamental
charge unit called electron. Since all stable matter is made up of protons,
neutrons, and electrons, the net charge q of a material is (Np − Ne)e where
Np is the number of protons in the material and Ne is the number of
electrons. If there are an equal number of protons and electrons, the
material is neutral. If the material has an excess of electrons (protons), then
the material has a net negative (positive) charge. Thus, q = (Np − Ne)e is
quantized in multiples of e since Np and Ne are integers. This quantization
doesn’t only hold for stable mater, but for all subatomic particles that are
directly observed in the laboratory (quarks having a charge that is a fraction
of e).
Thus, one really doesn’t need a special unit to denote the charge on an
object. One only needs an integer denoting the number of fundamental
charges on the object. Whether e- itself has units is a question that is
considered in quantum mechanics. We will take the classical physics
approach and assign a unit to charge, that being the Coulomb.. In terms of
Coulombs, e ≈ 1.6×10−19 Coulombs. The charge on any material object is
equal to: q = (Np − Ne)1.6 × 10−19 Coulombs, and is consequently
quantized. When macroscopic objects are ”charged” large numbers of
electrons are transfered (around 1010 or more). Because of this, we are not
sensive to the quantization of charge and tend to think of charge as a
continuous quantity. Millikan (1909) was the first to demonstrate
experimentally that charge is quantized, and received a Nobel Prize for his
discovery.
Conductors and insulators
The behavior of an object that has been charged is dependent upon
whether the object is made of a conductive or a nonconductive
material. Conductors are materials that permit electrons to flow freely from
particle to particle. An object made of a conducting material will permit
charge to be transferred across the entire surface of the object. If charge is
transferred to the object at a given location, that charge is quickly distributed
across the entire surface of the object. The distribution of charge is the
result of electron movement. Since conductors allow for electrons to be
transported from particle to particle, a charged object will always distribute
its charge until the overall repulsive forces between excess electrons is
minimized. If a charged conductor is touched to another object, the
conductor can even transfer its charge to that object. The transfer of charge
between objects occurs more readily if the second object is made of a
conducting material. Conductors allow for charge transfer through the free
movement of electrons.
Insulators are materials that impede the free flow of electrons from atom to
atom and molecule to molecule. If charge is transferred to an insulator at a
given location, the excess charge will remain at the initial location of
charging. The particles of the insulator do not permit the free flow of
electrons; subsequently charge is seldom distributed evenly across the
surface of an insulator.
Applications
While insulators are not useful for transferring charge, they do serve a
critical role in electrostatic experiments and demonstrations. Conductive
objects are often mounted upon insulating objects. This arrangement of a
conductor on top of an insulator prevents charge from being transferred
from the conductive object to its surroundings. This arrangement also
allows for a student (or teacher) to manipulate a conducting object without
touching it. The insulator serves as a handle for moving the conductor
around on top of a lab table.
CHARGING BY INDUCTION
One common demonstration performed in a physics classroom involves the
induction charging of two metal spheres. The metal spheres are supported
by insulating stands so that any charge acquired by the spheres cannot travel
to the ground. The spheres are placed side by side (see diagram i. below) so
as to form a two-sphere system. Being made of metal (a conductor),
electrons are free to move between the spheres - from sphere A to sphere B
and vice versa.
If a rubber balloon is charged negatively (perhaps by rubbing it with animal
fur) and brought near the spheres, electrons within the two-sphere system
will be induced to move away from the balloon. This is simply the principle
that like charges repel. Being charged negatively, the electrons are repelled
by the negatively charged balloon. And being present in a conductor, they
are free to move about the surface of the conductor. Subsequently, there is
a mass migration of electrons from sphere A to sphere B. This electron
migration causes the two-sphere system to be polarized (see diagram ii.
below). Overall, the two-sphere system is electrically neutral. Yet the
movement of electrons out of sphere A and into sphere B separates the
negative charge from the positive charge.
Looking at the spheres individually, it would be accurate to say that sphere
A has an overall positive charge and sphere B has an overall negative
charge. Once the two-sphere system is polarized, sphere B is physically
separated from sphere A using the insulating stand. Having been pulled
further from the balloon, the negative charge likely redistributes itself
uniformly about sphere B (see diagram iii. below). Meanwhile, the excess
positive charge on sphere A remains located near the negatively charged
balloon, consistent with the principle that opposite charges attract. As the
balloon is pulled away, there is a uniform distribution of charge about the
surface of both spheres (see diagram iv. below).
This distribution occurs as the remaining electrons in sphere A move
across the surface of the sphere until the excess positive charge is uniformly
distributed.
PROPERTIES OF ELECTRIC CHARGE
1) Additive nature of charges
Charges are additive in nature means they’re like scalars and can be added
directly. For An Example consider a system which consists of two charges
namely q1 and q2. Now we wish to find the total charge of the system. The
total charge of the system will be the algebraic sum of q1 and q2 i.e.q1 + q2.
The same thing holds for a number of charges in a system. Let's say a
system contains q1,q2,q3,q4……….qn, then the net charge of the entire system
will be
= q1 + q2 + q3 + q4 + ………………………..+ qn
The charge is a scalar quantity as it has only magnitude and no direction.
The charge is just as other fundamental properties of the system like mass.
The only difference between mass and charge is that charge is both positive
and negative, while mass is always positive.
2) Charge is conserved
The charge is a conserved quantity which means charge can neither be
created nor be destroyed but can be transferred from one body to another
by certain methods like conduction and induction. As charging involves
rubbing two bodies, it is actually a transfer of electrons from one body to
another. We can’t create a charge in a body but eventually can transfer
them to another body with some convenient methods.
In a system when charges are distributed accordingly, by the principle of
conservation the net charge of the system remains constant. As an example
if 5 C is the total charge of the system, then it can be redistributed as 1C, 2C
and 2C or in any other possible permutation, but by conservation principle
the net charge of system will always be 5 C. Although the charge carriers
may be destroyed in a system but the net charge will remain conserved.
3) Quantization of charge
Charge only comes in countable numbers. The smallest amount of
charge that has ever been observed is the charge on the electron
and/or the charge on the proton (both the same amount, but
opposite type). Hence the term "quantization of charge." Quantum
or "quantized" means that it is numbered or integer-countable (can
come in -1, 0, 1, 2, 3, etc. but not 1.5 or pi, etc), and a quantum is
essentially one of those quantized objects. The total charge on a
charged object is therefore the number of individual charges, all of
which are either electrons or protons, multiplied by the charge on
one of them. This explains the existence of the following equation:
Q=n*e
Coulomb’s law is a quantitative statement about the force between
two point charges. When the linear size of charged bodies are much
smaller than the distance separating them, the size may be ignored
and the charged bodies are treated as point charges. Coulomb
measured the force between two point charges and found that it
varied inversely as the square of the distance between the charges
and was directly proportional to the product of the magnitude of the
two charges and acted along the line joining the two charges. Thus, if
two point charges q1 , q2 are separated by a distance r in vacuum,
the magnitude of the force (F) between them is given by ,
Principle of Superposition of Electrostatic Forces:- This principle states that
the net electric force experienced by a given charge particle q0 due to a
system of charged particles is equal to the vector sum of the forces exerted
on it due to all the other charged particles of the system.
Electrostatic Force due to Continuous Charge Distribution:-
The region in which charges are closely spaced is said to have continuous
distribution of charge. It is of three types given as below:
Electric Field Lines :-Electric field lines are a way of pictorially mapping
the electric field around a configuration of charge(s). These lines start on
positive charge and end on negative charge. The tangent on these lines at
any point gives the direction of field at that point.
Electric field lines due to positive and negative charge and their
combinations are shown as below:
Electric Field Intensity The electric field intensity at any point due to source charge is
defined as the force experienced per unit positive test charge placed at that point
without disturbing the source charge. It is expressed as
.
Electric Field Intensity (EFI) due to a Point Charge
APPLICATIONS
The value of dipole moment helps to predict the shape of the
molecule. For example, experiments show that the dipole moment of
BeF2 is zero. This is possible only if bond dipoles of two Be – F bonds
cancel each other.
GAUSS’S LAW
According to Gauss’s law, the total of the electric flux out of a closed surface
is equal to the charge enclosed divided by the permittivity. The total electric
flux through a closed surface is zero if no charge is enclosed by the surface.
o Gauss’s law is true for any closed surface, no matter what its shape or
size.
o The term q on the right side of Gauss’s law includes the sum of all
charges enclosed by the surface. The charges may be located anywhere
inside the surface.
o In the situation when the surface is so chosen that there are some
charges inside and some outside, the electric field [whose flux appears on
the left side of Eq. (1.31)] is due to all the charges, both inside and
outside S. The term q on the right side of Gauss’s law, however,
represents only the total charge inside S.
o The surface that we choose for the application of Gauss’s law is called
the Gaussian surface. The Gaussian surface can pass through a
continuous charge distribution.
o Gauss’s law is useful for the calculation of the electrostatic field for a
symmetric system.
o Gauss’s law is based on the inverse square dependence on distance
contained in the Coulomb’s law. Any violation of Gauss’s law will
indicate departure from the inverse square law.
The great significance of Gauss’s law is that it is true in general, and not only
for the simple cases we have considered above. Let us note some important
points regarding this law:
(i) Gauss’s law is true for any closed surface, no matter what its shape
or size.
(ii) The term q on the right side of Gauss’s law, includes the sum of all
charges enclosed by the surface. The charges may be located
anywhere inside the surface.
(iii) In the situation when the surface is so chosen that there are some
charges inside and some outside, the electric field [whose flux
appears on the left side of Eq. is due to all the charges, both inside
and outside S. The term q on the right side of Gauss’s law, however,
represents only the total charge inside S.
(iv) The surface that we choose for the application of Gauss’s law is
called the Gaussian surface. You may choose any Gaussian surface
and apply Gauss’s law. However, take care not to let the Gaussian
surface pass through any discrete charge. This is because electric
field due to a system of discrete charges is not well defined at the
location of any charge. (As you go close to the charge, the field
grows without any bound.) However, the Gaussian surface can pass
through a continuous charge distribution.
(v) Gauss’s law is often useful towards a much easier calculation of the
electrostatic field when the system has some symmetry. This is
facilitated by the choice of a suitable Gaussian surface.
(vi) Finally, Gauss’s law is based on the inverse square dependence on
distance contained in the Coulomb’s law. Any violation of Gauss’s
law will indicate departure from the inverse square law.
Let us draw a cylindrical gaussian surface, co-axial with the wire, of radius
and length --see Fig. 11. The above symmetry arguments imply that the
electric field generated by the wire is everywhere perpendicular to the
curved surface of the cylinder. Thus, according to Gauss' law,
(70)
(71)
The field points radially (in a cylindrical sense) away from the wire if ,
APPLICATIONS
Researchers use symmetry to find the electric field due to a charged virus
that is spherically symmetric, or a charged DNA that has some kind of
symmetry or charged symmetrical objects in nanotechnology. I am looking
for such specific applications.
As another example, we will calculate the field from a uniform plane sheet
of charge. Suppose that the sheet is infinite in extent and that the charge per
unit area is σ. We are going to take another guess. Considerations of
symmetry lead us to believe that the field direction is everywhere normal to
the plane, and if we have no field from any other charges in the world, the
fields must be the same (in magnitude) on each side. This time we choose
for our Gaussian surface a rectangular box that cuts through the sheet, as
shown in Fig. The two faces parallel to the sheet will have equal areas,
say A. The field is normal to these two faces, and parallel to the other four.
The total flux is E times the area of the first face, plus E times the area of
the opposite face—with no contribution from the other four faces. The total
charge enclosed in the box is σA. Equating the flux to the charge inside, we
have
EA+EA=σAϵ0,
EA+EA=σAϵ0,
from which E=σ2ϵ0,
E=σ2ϵ0,
a simple but important result.
www.google.in
pradeep publications
www.ncert.nic.in
learncbse.com
