Polyethylene Pipes & Fittings

‫مياه شرب‬ ‫ري‬ ‫مياه صرف‬ ‫غـــاز‬ ‫تغطية كوابل الكهرباء و اإلتصاالت‬
DRINKING WATER IRRIGATION DRAINAGE GAS ELECTRICAL & COMMUNICATION CONDUIT
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

Company profile Introduction

Polyethylene is a thermoplastic polyolefin material generated from the polymerization of ethylene.
It is manufactured on a petrochemical basis with petroleum as the raw material. Depending on the
polymerization process, different types of polyethylene materials can be produced. Low Density
JSPF is the trade name of Al-Jubail Sanitary Pipe Polyethylene (LDPE), has a density of 0.91-0.93 g\cm3, while High Density Polyethylene (HDPE) has a
Factory owned 100% by a Saudi individual.it was density of 0.94-0.96 g\cm3. In recent years extended development work has been undertaken by PE
established in 1985, then JSPF has become resin manufacturers, which has resulted in materials with better long-term strength and temperature
one of the largest manufacturer and supplier of resistance than the old generation grades.
Polyethylene (PE) pipes in the gulf region. The new classification is based on the minimum required strength (MRS), which has to be applied for
JSPF pipes are manufactured strictly in accordance designing long-term loaded PE pipes operating at a temperature of 20 C for a design life of at least
with standards DIN 8074\75 & ISO 4427 for 50 years. A «third generation» PE Grade was developed and recognized as PE 100 which has a MRS of
10MPa and a design tensile stress of 8 MPa. It is especially design for the production of larger diameter
HDPE, DIN 8072\73 & AS (2698.1) for LDPE,
and thick-walled pipe, but can be processed for the whole range of diameters. It also shows excellent
and comply with other relevant ISO standard resistance to rapid crack propagation and slow crack growth.
recommendations.
Apart from the factory and sales office in Jubail,
JSPF has sales branches and stocks depots
in Riyadh, Buraida, al-Jouf & Qariya Olayah.
Recognized sales distributors are available also
Application
in many local municipalities . big demands of JSPF HDPE pipes become widely adopted in a variety of piping systems and are rapidly replacing most
conventional pipes. HDPE pipes proved very successful in the main potable water supply and
PE pipes and fittings are also exported to GCC
distribution lines, plumbing, drainage & sewerage, sprinkler & drip irrigation systems, firefighting
countries, Middle East and some African countries. networks, underwater piping systems, relining of old pipelines, laboratories, electrical conduits &
To cope up with the increasing demand in fiber-optic ducts and gas distribution. It has a broad variety of industrial applications including the
comparison fittings and to cater customer›s urgent chemical industry, crude oil, mine slurry transportation and many other applications.
requirements, JSPF expanded its operation for the
production of injection Moulded Fittings. JSPF has
license to manufacture Geberit Drainage Pipes
according to Geberit, Switzerland specification in
the Kingdom of Saudi Arabia. JSPF established a
quality management system for manufacturing PE
pipes and fittings certified by TUV-gmbH according
to ISO 9001:2000 .
Here In the Kingdom of Saudi Arabia , JSPF
products are proved by many Government and
Private agencies like the Ministries of Health,
Housing, Agriculture, Defense, Naval and Aviation,
Ministry P.T.T, Saudi Electric Company (SEC),
Arabian American Oil Company (ARAMCO)
and Water & Sewage Departments of various
municipalities for their piping system projects.

2 3
Al Jubail ‫الجبيل‬
Quality control
Al-Jubail Sanitary Pipe Factory is an ISO 9001:2000 certified company and has been successfully
assessed by TUV-GmbH in this respect. The quality system imposes stringent standards of quality
control throughout the production and inspection processes. products are subjected to range of
periodic checks and tests like visual check, dimensional control, hydrostatic pressure test and heat
reversion test. Detailed records for dimensional and performance tests are kept and controlled for
inspection and traceability.
Quality Policy
"It is the policy of Al Jubail Sanitary Pipe Factory (JSPF) to provide its customers High Quality HDPE/
LDPE Pipes and Fittings as per DIN & ISO standard, On-time Delivery, and ever improving levels of
customer satisfaction. JSPF is dedicated to continual improvement of its products, services and the
factory itself, through process control, employee empowerment and management commitment, in
compliance with requirements of ISO 9001:2000."
4 5
Al Jubail ‫الجبيل‬
Properties of Polyethylene Pipe:
JSPF PE PIPES are flexible, lightweight, impact resistant and long lasting. The black color of the pipe
makes it resistant to UV-radiation. Abrasion resistance is better than any other rigid thermoplastics
and considerably better than steel and other metal pipes, concrete and asbestos cement. Corrosion
resistance of HDPE pipes is excellent and it's unharmed by all process chemicals.
Chemical Resistance:
Polyethylene material is renowned for its good resistance to chemical attack. It is chemically inert
within its normal temperature range of practical use. The degree of resistance to specific chemical will
depend on concentration, temperature and working pressure, each of which will affect the long term
life of any system. Polyethylene pipe does not rot, rust, pit, corrode, or lose wall thickness through
chemical reaction with the surrounding soul. It doesn't support the growth of, nor is affected by algae,
bacteria or fungi. Therefore it's a good choice for conveying drinking water and aqueous of foodstuffs.
Thermal Properties:
The water or any medium contained in PE pipe changes temperature more slowly than any other
conventional pipe, because the thermal conductivity of PE pipe is very low at 0.43W/mK. Changes
in length due to thermal action are generally much greater for plastic than for conventional pipe
materials such as steel and concrete. If the change in length is prevented, the stress in the material
will follow. It should be observed that, although the relative change in length maybe great, the stress
is not necessarily very large. This is due to the fact that the E-modulus usually decreases when the
coefficient of thermal expansion increases for plastics materials.
Color of Pipes:
JSPF pipes are normally supplied in black color to counter attack Ultra-violet radiation and to
suite extreme weathering conditions. Other colors also can be produced depending on customer
requirement. A co-extrusion system is responsible for producing pipe with color stripes depending
on pipe application. Blue stripe for potable water, Orange for conduit, and Yellow for gas application.
Pipe Length:
JSPF pipes in the range 16 mm OD to 160 mm OD are available in coils of 50 Meters and 100 Meter
length. Larger diameters are supplied in straight lengths of 6 Meter and 12 Meter. Other lengths can
also be supplied on request.
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

JOINTING METHODS OF HDPE PIPES AND FITTINGS INSTALLATION OF «PE» PIPELINE

Butt-fusion Jointing There are a number of methods for installing new PE pipelines using both excavation and trenchless
techniques. The techniques considered within this section are summarized as follows;
During recent years several different methods of welding PE
pipes have been developed. In the case of larger diameter
HDPE pipes, the most usual method is Butt Welding. The Excavation Trenchless
welding procedure involves accurate machine planning of
the pipe ends followed by heating to the melting point of the Open-cut trenching Impact moling
pipe ends which are then joined together under pressure. The Narrow trenching Directional drilling
heating time, temperature and pressure are adjusted so that Moleploughing Guided drilling
the physical properties of the original material are retained.
Both the temperature and pressure must be carefully checked The dimensions of the trenchline opening are normally governed by the pipe diameter, method of
and adapted to the actual raw material, pipe diameter and the
wall thickness. A good quality of a Butt Welded joint means jointing and site conditions. Normal minimum depth of cover for mains should be 900 mm from
that the strength of the joint should be about the same as valid ground level to the crown of the pipe. Trench width should be as narrow as possible but typically not
for the basic pipe material. This method of jointing requires an less than the outside diameter of the pipe plus 250 mm to allow for correct compaction of sidefill
electrically heated plate to raise the temperature of the pipe unless specialized narrow trenching techniques are used. The minimum lower bedding distance is
ends to the required fusion temperature and is used to weld PE 110 mm and the minimum initial cover above pipe crown is 100 mm. a compaction in layers of 250
pipes of the same Standard Dimension Ratio (SDR).
mm (max) backfill should be done till reaching the ground service. Other recommended installations
for in-house and drainage are shown as follows:
Electrofusion Jointing
Using electrofusion to join PE pipes enables a secure, systematic,
economical and efficient installation of PE piping system. One
advantage of this type of jointing is the capability to weld pipes
or fittings with different wall thicknesses (SDR s) using the same
welding conditions. The control unit is very portable and can be
used to weld pipes or fittings with ease even in narrow locations
and difficult installation condition. The inside bore in the joint
portion is very smooth since there will be no bead formation
which could contribute restriction of flow.

Compression (quick fix)

Jointing:
This type of mechanical jointing of PE pipes is done by the use
of PP compression fittings. This connection applies mostly in
the irrigation sector and in potable water system. The range
of compression fittings comprises a large number of items
suitable for meeting a wide range of installation requirements.
The dimensions of the fittings range from 16 MM up to 125 MM.
operating pressure at 20 C for sizes range from 16 MM to 36 MM
is 16 bar, while sizes range from 75 MM to 125 MM is 10 bar.

Flange Connections:
Polyethylene pipes can be jointed by butt fusion welding to
other pipes made of non-PE materials (eg. uPVC, asbestos, PP
etc.) wherever possible, flange joints should be made before
other joints are completed. Pipework configuration shall be such
that mating flanges are in true alignment and butted squarely
to each other with a maximum separation of 5MM between the
flange faces prior to bolting up. Only clean undamaged nuts
and bolts of the correct size should be used, with flat washers
of correct size at either end. Care must be taken to ensure that
the gasket is centered properly between the two flanges before
tightening commences. The nuts and bolts must be tightened
as uniformly as possible using a torque wrench, in diagonally
opposite sequence, progressively from a finger tight start till
the final torque.

6 7
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

Table 1 Material Properties of HDPE

Table 4 HDPE Pipe Dimension As Per Din 8074-1999E Specifications
Property Test Method Units PE 80 PE 100
Density (Compound) iso 1183 Kg/m3 956 959
Design Stress = 5.0 MPa
Melt Flow Rate (190oC/5kg) ISO 1133 g/10 min 0.3 0.25
S 12.5 S 8.3 S5 S 3.2
Tensile Stress at Yield (50mm/min) ISO 527-2 MPa 22 25
Elongation at break ISO 527-2 % > 600 > 600 SDR 26 SDR 17.6 SDR 11 SDR 7.4
O.D.
Charpy Impact Strength, notched ISO 179/1EA kJ/m 2
14 16 PN 4 PN 6 PN 10 PN 16
Carbon Black Content ASTM D 1603 % 2 2 W.T Weight W.T Weight W.T Weight W.T Weight
Vicat Softening Point ASTM D 1525 C
o
118 122 mm mm Kg/m mm Kg/m mm Kg/m mm Kg/m
Brittleness Temperature ASTM D 746 C
o
< -70 < -70
16 1.8 0.084 2.2 0.099
ESCR (10% Igepal), F50 ASTM D 1693A Hrs. >10,000 >10,000
20 1.9 0.112 2.8 0.158
Thermal Conductivity DIN 52612 W/moK 0.4 0.4
25 1.8 0.137 2.3 0.171 3.5 0.245
Dimensions 32 1.9 0.187 2.9 0.279 4.4 0.393
All dimensions are expressed in metric units. The diameters of pipes are measured in millimeters 40 1.8 0.228 2.3 0.285 3.7 0.430 5.5 0.617
(mm) and represent the outside diameter of the pipe. A table shown below facilitates comparison
50 2.0 0.314 2.9 0.440 4.6 0.666 6.9 0.936
of OD in metric and inch.
63 2.5 0.494 3.6 0.688 5.8 1.05 8.6 1.47
Table 2 75 2.9 0.675 4.3 0.976 6.8 1.47 10.3 2.14
MM 16 20 25 32 50 63 75 90 110 125 160 200 250 315 355 400 450 500 630 90 3.5 0.978 5.1 1.39 8.2 2.12 12.3 3.07
Inch 3/8 1/2 3/4 1 1 1/2 2 2 1/2 3 4 5 6 8 10 12 14 16 18 20 24 110 4.2 1.43 6.3 2.08 10.0 3.14 15.1 4.51

Pressure ratings of Polyethylene pipe at elevated temperatures. 125 4.8 1.84 7.1 2.66 11.4 4.08 17.1 5.83

140 5.4 2.32 8.0 3.34 12.7 5.08 19.2 7.40

The nominal working pressure has been calculated for operational conditions at 200 C. Since Polyethylene
pipe is a thermoplastic material, a loss in mechanical properties is to be expected as the temperature 160 6.2 3.04 9.1 4.35 14.6 6.67 21.9 9.52

rises. Where the system is to be operated at temperatures at above 200 C, then the allowable working 180 6.9 3.84 10.2 5.48 16.4 8.46 24.6 12.10
pressure and service life must be reduced. Details of which are shown in the following table. 200 7.7 4.69 11.4 6.79 18.2 10.4 27.4 14.90

Table 3 225 8.6 5.96 12.8 8.55 20.5 13.1 30.8 18.90

250 9.6 7.34 14.2 10.6 22.7 16.2 34.2 23.30

Years Of Allowable working pressure in bar, with a safety factory of 1.25
Temp C o
280 10.7 9.16 15.9 13.2 25.4 20.3 38.3 29.06
Service PE 80 PE 100 PE 80 PE 100 PE 80 PE 100 PE 80 PE 100
315 12.1 11.7 17.9 16.7 28.6 25.7 43.1 36.73
SDR 33 SDR 41 SDR 22 SDR 26 SDR 13.6 SDR 17 SDR 9 SDR 11
20 50 4 4 6 6.3 10 10 16 16 355 13.6 14.7 20.1 21.2 32.2 32.6 48.5 46.55
30 50 3.3 3.3 5 5.3 8.4 8.4 13.5 13.5 400 15.3 18.7 22.7 26.9 36.2 41.4 54.7 59.17
40 50 2.9 2.9 4.3 4.5 7.2 7.2 11.6 11.6 450 17.2 23.6 25.5 34.0 40.9 52.4 61.5 74.82
50 15 2.2 2.3 3.4 3.7 5.7 5.9 9.1 9.5
500 19.1 29.1 28.3 41.9 45.4 64.6 68.3 92.45
60 5 1.8 1.9 2.7 3.0 4.5 4.8 7.2 7.7
560 21.4 36.4 31.7 52.5 50.8 81.1
70 2 1.3 1.5 2 2.4 3.4 3.9 5.5 6.2
630 24.1 46.2 35.7 66.5 57.2 102.6
Years Of Allowable working pressure in bar, with a safety factory of 1.6
Temp oC
Service PE 80 PE 100 PE 80 PE 100 PE 80 PE 100 PE 80 PE 100
* 710 27.2 58.7 40.2 84.4 64.5 130.91

SDR 26 SDR 33 SDR 17.6 SDR 21 SDR 11 SDR 13.6 SDR 7.4 SDR 9 * 800 30.6 74.3 45.3 107.0
20 50 4 3.9 6 6.2 10 9.9 15.3 15.6 * 900 34.4 93.98 51.0 136.8
30 50 3.3 3.3 5 5.3 8.4 8.4 13.5 13.5
* 1000 38.2 115.7 56.7 168.52
40 50 2.9 2.9 4.3 4.5 7.2 7.2 11.6 11.6
50 15 2.3 2.3 3.4 3.7 5.7 5.9 9.1 9.5 * 1200 45.9 167.0 68.0 242.47
60 5 1.8 1.9 2.7 3.0 4.5 4.8 7.2 7.7
70 2 1.3 1.5 2 2.4 3.4 3.9 5.5 6.2
Note: * Can be supplied on special request; W.T – Wall thickness ; O.D – Outside Diameter ; SDR – Standard Dimension
Ratio ; S – Pipe Series #; PN – Nominal Pressure
for further information, contact technical support department

8 9
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

Table 5
HDPE PE 100 PIPE DIMENSION CONFORMING TO ISO 4427, DIN 8074 & EN 12201
Specifications Design Stress = 8 MPa

S 20 S 12.5 S 10 S8 S 6.3 S5 S4 S 3.2 S 2.5

SDR 41 SDR 26 SDR 21 SDR 17 SDR 13.6 SDR 11 SDR 9 SDR 7.4 SDR 6
O.D. O.D.
PN 4 PN 6.3 PN 8 PN 10 PN 12.5 PN 16 PN 20 PN 25 PN 32

W.T Weight W.T Weight W.T Weight W.T Weight W.T Weight W.T Weight W.T Weight W.T Weight W.T Weight

mm mm Kg/m mm Kg/m mm Kg/m mm Kg/m mm Kg/m mm Kg/m mm Kg/m mm Kg/m mm Kg/m mm

20 1.9 0.113 2.3 0.13 2.8 0.156 3.4 0.182 20

25 2.3 0.173 2.8 0.19 3.5 0.242 4.2 0.281 25

32 2.0 0.197 2.4 0.234 2.9 0.275 3.6 0.32 4.4 0.390 5.4 0.458 32

40 2.0 0.25 2.4 0.29 3.0 0.36 3.7 0.434 4.5 0.52 5.5 0.606 6.7 0.708 40

50 2.0 0.32 2.4 0.37 3.0 0.45 3.7 0.55 4.6 0.672 5.6 0.79 6.9 0.946 8.3 1.09 50

63 2.5 0.48 3.0 0.58 3.8 0.72 4.7 0.87 5.8 1.06 7.1 1.27 8.6 1.48 10.5 1.74 63

75 2.9 0.69 3.6 0.82 4.5 1.01 5.6 1.24 6.8 1.48 8.4 1.78 10.3 2.10 12.5 2.46 75

90 3.5 0.97 4.3 1.18 5.4 1.47 6.7 1.78 8.2 2.14 10.1 2.56 12.3 3.02 15.0 3.54 90

110 4.2 1.44 5.3 1.78 6.6 2.18 8.1 2.63 10.0 3.17 12.3 3.81 15.1 4.52 18.3 5.28 110

125 3.1 1.23 4.8 1.85 6.0 2.27 7.4 2.77 9.2 3.39 11.4 4.12 14.0 4.92 17.1 5.82 20.8 6.80 125

140 3.5 1.55 5.4 2.33 6.7 2.84 8.3 3.48 10.3 4.25 12.7 5.13 15.7 6.17 19.2 7.30 23.3 8.54 140

160 4.0 2.00 6.2 3.05 7.7 3.74 9.5 4.55 11.8 5.54 14.6 6.72 17.9 8.02 21.9 9.51 26.6 11.13 160

180 4.4 2.49 6.9 3.81 8.6 4.69 10.7 5.75 13.3 7.03 16.4 8.50 20.1 10.55 24.6 12.03 29.9 14.07 180

200 4.9 3.05 7.7 4.72 9.6 5.81 11.9 7.10 14.7 8.59 18.2 10.50 22.4 12.55 27.4 14.89 33.2 17.38 200

225 5.5 3.87 8.6 5.92 10.8 7.34 13.4 8.99 16.6 10.96 20.5 13.30 25.2 15.89 30.8 18.80 37.4 22.00 225

250 6.2 4.85 9.6 7.34 11.9 8.99 14.8 11.02 18.4 13.50 22.7 16.40 27.9 19.53 34.2 23.21 41.6 27.14 250

280 6.9 6.00 10.7 9.16 13.4 11.35 16.6 13.86 20.6 16.90 25.4 20.50 31.3 24.55 38.3 29.10 46.5 34.05 280

315 7.7 7.54 12.1 11.67 15.0 14.26 18.7 17.54 23.2 21.43 28.6 25.88 35.2 31.06 43.1 36.85 - - 315

355 8.7 9.60 13.6 14.92 16.9 18.11 21.1 22.33 26.1 27.16 32.2 32.83 39.7 39.44 48.5 46.71 - - 355

400 9.8 12.16 15.3 18.70 19.1 23.09 23.7 28.23 29.4 34.45 36.3 41.69 44.7 50.04 - - - - 400

450 11.0 15.33 17.2 23.64 21.5 29.19 26.7 35.76 33.1 43.68 40.9 52.80 50.3 62.7 - - - - 450

500 12.3 19.09 19.1 29.16 23.9 36.07 29.7 44.18 36.8 53.84 45.4 65.13 55.8 78.43 - - - - 500

560 13.7 23.78 21.4 36.55 26.7 45.08 23.2 55.34 41.2 67.55 50.8 81.80 62.5 98.37 - - - - 560

630 15.4 30.07 24.1 46.31 30.0 56.95 37.4 70.09 46.3 87.7 57.2 103.4 - - - - - - 630

* 710 17.4 38.28 27.2 58.87 33.9 72.5 42.1 89.28 52.2 108.90 64.5 131.87 710

* 800 19.6 48.54 30.6 74.56 38.1 91.9 47.4 113.24 58.8 138.19 - - - - - - - 800

* 900 22.0 61.23 34.4 94.68 42.9 116.82 53.3 143.23 66.10 174.75 - - - - - - - - 900

* 1000 24.5 75.80 38.2 116.4 47.7 144.28 59..30 177.02 - - - - - - - 1000

* 1200 29.4 109.12 45.9 167.6 57.2 207.57 70.6 252.97 - - - - - - - - 1200

Note: * Can be supplied on special request; W.T – Wall thicknes s ; O.D – Outside Diameter ; SDR – Standard Dimension Ratio;
S – Pipe Series #; PN – Nominal Pressure

10 11
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

Table 6 HDPE PE 80 Pipe Dimension Conforming To Iso 4427/Din 8074 Pipe for Drip and Irrigation Work
Design Stress = 6.3 MPa Application
S 10 S 6.3 S5 S4 LDPE pipe which is especially suited to the Saudi Arabian climate is intended for use in above or below
SDR 21 SDR 13.6 SDR 11 SDR 9 ground drip irrigation networks. This system optimizes the use of water in arid regions by supplying
O.D. water at low pressure, exactly where it is needed directly to the roots of the plant. Loss by evaporation
PN 6.3 PN 10 PN 12.5 PN 16
is minimized and water consumption is conserved.
W.T Weight W.T Weight W.T Weight W.T Weight

mm mm Kg/m mm Kg/m mm Kg/m mm Kg/m Table 7 LDPE Pipe Dimensions based on DIN 8072 from sizes 16 mm to 32 mm
16 1.8 0.085 OD with a working pressure of 4 bars at 20 C.
20 1.8 0.108 1.9 0.113 2.3 0.134
Outside Dimeter Wall Thickness
25 1.9 0.145 2.3 0.172 2.8 0.201 16 mm 1.2 mm / 1.5 mm
32 2.4 0.234 3.0 0.273 3.6 0.328 20 mm 1.5 mm
40 1.9 0.241 3.0 0.36 3.7 0.432 4.5 0.511 25 mm 1.5 mm / 2.0 mm
32 mm 2.0 mm
50 2.4 0.377 3.7 0.55 4.6 0.669 5.6 0.791

63 3.0 0.584 4.7 0.9 5.8 1.05 7.1 1.27 Table 8 LDPE Pipe Dimensions based on Australian Standard AS 2698.1 for drip
75 3.6 0.834 5.6 1.2 6.8 1.48 8.4 1.77 irrigation tubing (type 30), with a working pressure of 3 bars at 20 C.
90 4.3 1.2 6.7 1.8 8.2 2.13 10.1 2.55
Nominal Inside Diameter
110 5.3 1.8 8.1 2.6 10.0 3.15 12.3 3.80 Nominal Size ( MM) Wall Thickness (MM ) Nominal Weight ( kg / m)
( MM )
125 6.0 2.3 9.2 3.4 11.4 4.10 14.0 4.89 13 12.9 1.2 0.051
140 6.7 2.8 10.3 4.2 12.7 5.10 15.7 6.14 16 16.0 1.2 0.062

160 7.7 3.7 11.8 5.5 14.6 6.70 17.9 7.99 19 19.1 1.3 0.080
25 25.4 1.5 0.121
180 8.6 4.7 13.3 7.0 16.4 8.46 20.1 10.1
32 31.7 2.0 0.200
200 9.6 5.8 14.7 8.6 18.2 10.44 22.4 12.5

225 10.8 7.3 16.6 10.9 20.5 13.16 25.2 15.9 Table 9 GR Dripline, Lengths for 10% Flow Variation on Ground with Zero Slope.
250 11.9 9.0 18.4 13.5 22.7 16.27 27.9 19.5
Single Emitter Combination.
280 13.4 11.3 20.6 16.9 25.4 20.39 31.3 24.4
Code S Q Wt. Code S Q Wt. Code S Q Wt.
315 15.0 14.3 23.2 21.3 28.6 25.71 35.2 30.9 No cm LPH Kg. No cm LPH Kg. No cm LPH Kg.
355 16.9 18.1 26.1 27.0 32.2 32.64 39.7 39.3 GR 16433 33 4 22.95 GR 16250 40 2 22.00 GR 20440 40 4 31.00
GR 16440 40 4 22.45 GR 16250 50 2 21.45 GR 20450 50 4 30.00
400 19.1 23.0 29.4 34.2 36.2 41.47 44.7 49.8
GR 16450 50 4 21.70 GR 16260 60 2 21.00 GR 20460 60 4 29.35
450 21.5 29.0 33.1 43.4 40.9 52.52 50.3 63.0 GR 16460 60 4 21.25 GR 16275 75 2 20.75 GR 20475 75 4 28.00
500 23.9 35.9 36.8 53.5 45.4 64.77 55.8 77.6 GR 16475 75 4 20.75 ---- ---- ---- ---- ---- ---- ---- ----

560 26.7 44.9 41.2 67.2 50.8 81.14 61.5 98.06

Table 10 Physical Properties of LDPE
630 30.0 56.6 46.3 85.0 57.2 102.0

* 710 33.9 72.3 52.2 107.7 64.5 131.46 Property Value

Density @ 23oC 0.923 g/cm3
* 800 38.1 91.7 58.8 136.9
Melt Index ( 190oC/5 kg ) 1.0 gm / 10 min
* 900 42.9 115.7 66.1 174.21
Brittleness Temperature < - 70oC
* 1000 47.7 142.9
Tensile Strength 11.5 Mpa
* 1200 57.2 206.3 Elongation @ Break 800%
Flexural Modulus 220 Mpa
Note: * Can be supplied on special request; W.T – Wall thickness ; O.D – Outside Diameter ; SDR –
Melting Temperature 124oC
Standard Dimension Ratio ; S – Pipe Series #; PN – Nominal Pressure
Carbon Black Content 2%

12 13
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

JSPF Subduct & Miniduct HDPE Pipe for Electrical Conduit & Fiber Optic Cable Table 14 HDPE Perforated Pipes
Installation.
Table 11 HDPE Ducts as per DIN 8074 Underground Drainage System And Surface Freight
The factory manufacture polyethylene pipes to divert groundwater with different diameters
size wall thickness weigth / meter
25MM 1.5MM 0.1125 kg / m
S12.5 S 8.3
32 MM 2.0MM 0.196 kg / m
SDR 26 SDR 17.6
32 MM 3.0MM 0.279 kg /m. O.D.
40MM 3.7 MM 0.430 kg/ m PN 4 PN 6
SOMM 2.9MM 0.44 kg / m W.T Weight W.T Weight
SO MM 4.6 MM 0.666 kg / m 75 2.9 0.675 4.3 0.976
90 3.5 0.978 5.1 1.39

Standard Length : 300m to 500m. Other lengths are available on request. 110 4.2 1.43 6.3 2.08

The color of HDPE Duct is black. Other colors are available on request. 125 4.8 1.84 7.1 2.66
160 6.2 3.04 9.1 4.35
Table 12 HDPE Fiber Optic Ducts with orange stripe as per DIN 8074 / ISO 4427, 180 6.9 3.84 10.2 5.48
PE100 SDR11 200 7.7 4.69 11.4 6.79
size wall thickness weigth / meter 225 8.6 5.96 12.8 8.55
110 MM 10 MM 3.17 Kg / m
250 9.6 7.34 14.2 10.6
125MM 11.4 MM 4.12 Kg / m
280 10.7 9.16 15.9 13.2
Standard Length : 100 m to 200 m 315 12.1 11.7 17.9 16.7

Advantages of JSPF HDPE Duct

• Flexible & light weight which allows remarkable direction changes
without the use of joints.
• Smooth bore with very low friction for cable placement.
• Excellent shock resistant even at low temperature.
• Corrosion resistant & highly resistant to most chemical agents and micro-organisms.
• Good weathering resistant & the black color is effective protection against Ultra-violet radiation.
JSPF have license from Geberit International Switzerland to manufacture Geberit Pipes in
the Kingdom of Saudi Arabia from sizes 32 to 315 mm diameter.

Table 13 Geberit Drainage HDPE Pipes

outside Wall inside
Weight pressure Article
diameter Thickness Diameter
empty Kg /m Nominal PN Number
(mm) (mm) (mm)
32 3 26 0.28 13.0 379.000.16.0
Industrial specifications
40 3 34 0.37 10.5 360.00016.0 according to international standards, specialists working in the pipes industry examination of these
50 3 44 0.45 8.0 361.00016.0 pipes and borne pressure when backfilling with soil, Weight compressing Placed on the tubes for five
56 3 50 0.50 7.1 363.00016.0 to seven days, and the existence of timer machine refers to the change in diameter of the pipe And
63 3 57 0.60 6.3 364.00016.0 to see how carrying pipes for continuous pressure.
75 3 69 0.698 5.2 365.00016.0
90 3.5 83 0.978 5.1 366.00016.0
Usage
110 4.3 101.4 1.46 5.1 367.00016.0
125 4.9 115.2 1.88 5.1 368.00016.0 1. the excess surface water drainage to control the water level so as not to rise near the earth's surface
160 6.2 147.6 3.04 5.1 369.00016.0 for long periods of time and this process is called (surface drainage).
200 6.2 187.6 3.60 4.0 370.00016.0
250 7.8 234.4 5.99 4.0 371.00016.0 2. drainage the excess water from the plant need in the root zone so as to maintain the soil composition,
315 9.8 295.4 g_so 4.0 372.00016.0 ventilation, and this process is called internal drainage (underground drainage)

14 15
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

COMPRESSION FITTINGS
COMPRESSION FITTINGS Sizes Range : 20 mm up to 63 mm PN 16, 75 mm up to 125 mm PN 10
Sizes Range : 20 mm up to 63 mm PN 16, 75 mm up to 125 mm PN 10
Tee with BSP Thread (Male) Tee with BSP Thread (Female)

male adaptor with BSP thread mm x inch x mm mm x inch x mm

female adaptor 20 x 1/2” x 20
20 x 1/2” x 20
mm x inch
25 x 3/4” x 25 25 x 3/4” x 25
20 x 1/2” mm x inch
32 x 1” x 32 32 x 1” x 32
20 x 3/4” 20 x 1/2”
40 x 1 1/4” x 40 40 x 1 1/4” x 40
25 x 3/4” 20 x 3/4”
50 x 1 1/2” x 50 50 x 1 1/2” x 50
32 x 1/2” 32 x 1”
63 x 2” x 63 63 x 2” x 63
32 x 3/4” 40 x 1 1/4”
75 x 2 1/2” x 75 75 x 2 1/2” x 75
50 x 1 1/2”
32 x 1”
63 x 2”
90 x 3” x 90 149 90 x 3” x 90 179
40 x 1 1/4”
110 x 4” x 110 110 x 4” x 110
40 x 1 1/2” 75 x 2 1/2”

50 x 1 1/2” 90 x 3”
90 Elbow Coupling 90 Tee Coupling
50 x 2” 110 x 4”

63 x 2” mm x mm mm x mm x mm
75 x 2 1/2”
99 119 20 x 20 20 x 20 x 20
90 x 2” 25 x 25 25 x 25 x 25
90 x 2 1/2”
connector coupling 32 x 32 32 x 32 x 32
90 x 3” 40 x 40 40 x 40 x 40
mm x mm
90 x 4” 50 x 50 50 x 50 x 50
20 x 20
110 x 3” 63 x 63 63 x 63 x 63
25 x 25
110 x 4” 75 x 75 75 x 75 x 75
32 x 32
90 x 90 90 x 90 x 90
125 x 4”
40 x 40 159
125 x 5”
50 x 50
110 x 110 110 x 110 x 110
189
63 x 63
end cap 90 Elbow with BSP Thread (Male) 90 Elbow with BSP Thread (Female)
75 x 75

mm 90 x 90 mm x inch
mm x Inch
20 110 x 110
125 x 125
129 20 x 1/2” 20 x 1/2”
25 25 x 3/4” 25 x 3/4”
32 32 x 1” 32 x 1”
40 40 x 1 1/4” 40 x 1 1/4”
50 50 x 1 1/5” 50 x 1 1/5”
63 63 x 2” 63 x 2”
75
flange joint 75 x 2 1/2” 169 75 x 2 1/2” 199
90 90 x 3” Reducer Coupling 90 x 3” Reducer Coupling
110 109 mm x inch 110 x 4”
mm x mm
110 x 4”
mm x mm
125 125 x 5”
25 x 20 75 x 63
125 x 6” 90 x 50
32 x 25
160 x 6” 90 x 63
40 x 32
50 x 32 90 x 75

50 x 40 110 x 50

63 x 32 110 x 63

63 x 40 110 x 75

63 x 50 110 x 90

139 75 x 50 209 125 x 110

16 17
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

CLAMP SADDLE
Clamp Saddle with four Bolts BUTTWELDED MOULDED FITTINGS
mm x inch
63 x 1/2” Flange Adapter Tee Reducer 90O
63 x 3/4”
mm mm x mm x mm
32 x 1”
63 90 x 63 x 90
63 x 1 1/4” 75 111 x 63 x 110
63 x 1 1/2” 90 100 x 90 x 160
75 x 1/2” 110 160 x 110 x 160
125 225 x 110 x 225
75 x 3/4”
140 225 x 125 x 225
75 x 1”
75 x 1 1/4”
160
180
239 225 x 160 x 225
269
75 x 1 1/2” 200
75 x 2” 225
250
Reducer
90 x 1/2”
280
mm x mm
90 x 3/4”
219 315
63 x 50
mm x mm
200 x 160
90 x 1” 400
75 x 63 200 x 180
90 x 1 1/4” 450
500 90 x 63 225 x 110
90 x 1 1/2”
90 x 75 225 x 160
90 x 2”
110 x 63 225 x 200
90 x 2 1/2”
Tee 90O 110 x 75 250 x 160
110 x 1/2”
mm
110 x 90 279 250 x 225
110 x 3/4” 125 x 90 280 x 250
63
110 x 1” 75 125 x 110 315 x 200
110 x 1 1/4” 90 140 x 90 315 x 250
110 x 1 1/2” 110 140 x 110 315 x 280
125 140 x 125 355 x 250
110 x 2”
140 160 x 90 355 x 315
110 x 2 1/2”
110 x 3”
160 249 160 x 110 400 x 315
180 160 x 140 400 x 355
125 x 1/2” 200
180 x 90 450 x 400
125 x 3/4” 225
180 x 110 500 x 450
250
125 x 1” 180 x 160
280
125 x 1 1/4”
315
125 x 1 1/2” Clamp Saddle with two Bolts
125 x 2” Elbow 90 End Cap
125 x 2 1/2” mm x inch
25 x 1/2” mm mm
125 x 3”
63 50 x 57
125 x 4” 25 x 3/4”
75 63 x 65
160 x 1/2” 32 x 1/2”
90 75 x 72
160 x 3/4” 32 x 3/4” 110 90 x 81
160 x 1” 32 x 1” 125 110 x 86
40 x 1/2” 140 125 x 93
160 x 1 1/4”
160 x 1 1/2” 4 x 3/4”
160 259 140 x 97 280
180 160 x 103
160 x 2” 40 x 1”
200 180 x 110
160 x 2 1/2” 50 x 1/2” 225 200 x 117
160 x 3” 50 x 3/4” 250 225 x 125

160 x 4” 50 x 1” 229 280 250 x 136

315 280 x 145

18 19
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

BUTTWELDED FABRICATED FITTINGS BUTTWELDED FABRICATED FITTINGS

300 ELBOW - FABRICATED (30 E)
45 TEE Fabricated (45 T) 60 ELBOW – Fabricated (60 E)
OD (mm) CODE OD (mm) CODE OD (mm) CODE
90 JP-BWS-30E001 90 JP-BWS-45E001 90 JP-BWS-60E001
110 JP-BWS-30E002 110 JP-BWS-45E002 110 JP-BWS-60E002
125 JP-BWS-30E003 125 JP-BWS-45E003 125 JP-BWS-60E003
140 JP-BWS-30E004 140 JP-BWS-45E004 140 JP-BWS-60E004
160 JP-BWS-30E005 160 JP-BWS-45E005 160 JP-BWS-60E005
180 JP-BWS-30E006 180 JP-BWS-45E006 180 JP-BWS-60E006
200 JP-BWS-30E007 200 JP-BWS-45E007 200 JP-BWS-60E007
225 JP-BWS-30E008 225 JP-BWS-45E008 225 JP-BWS-60E008
250 JP-BWS-30E009 250 JP-BWS-45E009 250 JP-BWS-60E009
280 JP-BWS-30E010 280 JP-BWS-45E010 280 JP-BWS-60E010
315 JP-BWS-30E011 315 JP-BWS-45E011 315 JP-BWS-60E011
355 JP-BWS-30E012 355 JP-BWS-45E012 355 JP-BWS-60E012
PE 100 Available in PE 100 Available in
PE 100 Available in PN 4-5 , PN 400 JP-BWS-30E013 400 JP-BWS-45E013 PN 4-5 , PN 6.3, PN 400 JP-BWS-60E013 PN 4-5 , PN 6.3, PN
6.3 , PN 10 , PN 16 and PN 25 450 JP-BWS-30E014 450 JP-BWS-45E014 450 JP-BWS-60E014
10 , PN 16 and PN 25 10 , PN 16 and PN 25
500 JP-BWS-30E015 500 JP-BWS-45E015 500 JP-BWS-60E015
560 JP-BWS-30E016
289 630 JP-BWS-30E017
560
630
JP-BWS-45E016
JP-BWS-45E017
309 560
630
JP-BWS-60E016
JP-BWS-60E017
329
710 JP-BWS-30E018 710 JP-BWS-45E018 710 JP-BWS-60E018
800 JP-BWS-30E019 800 JP-BWS-45E019 800 JP-BWS-60E019
900 JP-BWS-30E020 900 JP-BWS-45E020 900 JP-BWS-60E020
1000 JP-BWS-30E021 1000 JP-BWS-45E021 1000 JP-BWS-60E021
1200 JP-BWS-30E022 1200 JP-BWS-45E022 1200 JP-BWS-60E022

450 ELBOW - FABRICATED (45 E)

90 ELBOW – Fabricated (90 E) 90 TEE Fabricated (90 T)
OD (mm) CODE
90 JP-BWS-45E001 OD (mm) CODE OD (mm) CODE
110 JP-BWS-45E002 90 JP-BWS-90E001 90 JP-BWS-90E001
125 JP-BWS-45E003 110 JP-BWS-90E002 110 JP-BWS-90E002
140 JP-BWS-45E004 125 JP-BWS-90E003 125 JP-BWS-90E003
160 JP-BWS-45E005 140 JP-BWS-90E004 140 JP-BWS-90E004
180 JP-BWS-45E006 160 JP-BWS-90E005 160 JP-BWS-90E005
200 JP-BWS-45E007 180 JP-BWS-90E006 180 JP-BWS-90E006
225 JP-BWS-45E008 200 JP-BWS-90E007 200 JP-BWS-90E007
250 JP-BWS-45E009 225 JP-BWS-90E008 225 JP-BWS-90E008
280 JP-BWS-45E010 250 JP-BWS-90E009 PE 100 Available in 250 JP-BWS-90E009
315 JP-BWS-45E011 280 JP-BWS-90E010 PN 4-5 , PN 6.3 , PN 280 JP-BWS-90E010
355 JP-BWS-45E012 315 JP-BWS-90E011 10 , PN 16 and PN 25 315 JP-BWS-90E011
400 JP-BWS-45E013 355 JP-BWS-90E012 355 JP-BWS-90E012
PE 100 Available in PN 4-5 , PN 6.3 ,
450
500
JP-BWS-45E014
JP-BWS-45E015 PN 10 , PN 16 and PN 25
400
450
JP-BWS-90E013
JP-BWS-90E014
319 400
450
JP-BWS-90E013
JP-BWS-90E014 PE 100 Available
560 JP-BWS-45E016 500 JP-BWS-90E015 500 JP-BWS-90E015 in PN 4-5 , PN
560 JP-BWS-90E016 6.3, PN 10 , PN
630
710
JP-BWS-45E017
JP-BWS-45E018
299 560
630
JP-BWS-90E016
JP-BWS-90E017 630 JP-BWS-90E017 16 and PN 25
800 JP-BWS-45E019 710 JP-BWS-90E018 710 JP-BWS-90E018
900
1000
JP-BWS-45E020
JP-BWS-45E021
800
900
JP-BWS-90E019
JP-BWS-90E020
800
900
JP-BWS-90E019
JP-BWS-90E020
339
1200 JP-BWS-45E022 1000 JP-BWS-90E021 1000 JP-BWS-90E021
1200 JP-BWS-90E022 1200 JP-BWS-90E022

20 21
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

ELECTROFUSION FITTINGS ELECTROFUSION FITTINGS

COUPLER
PE100 Black - Gas 10 Bar/Water PN16

FUSION COOLING
FITTING WEIGHT
L (MM) L 1(MM) D (MM) D1 (MM) TIME TIME
SIZE (Kg)
(SECS) (MINS)
20mm 77 37.5 29 20 35 3 0 033
25mm 77 3 7S 33,5 25 30 3 0.037
PRESSURE RATINGS 32mm 77 37.5 43 32 45 3 0.057
40mm 90 44 51.5 40 40 5 0.08
The maximum Pressure rating for each type of electrofusion fitting is in accordance with the table below: 50mm 91 44 61.5 50 90 5 0 096
63mm 102 49 77 63 35 3 0,148
Fitting Type Water cold GAS ** PN16 when PE100 resin / PN 12.5 when 75fnm 125 61 100 75 50 5 0.403
Pe80 resin 90mm 122 60 110 90 90 10 0.333
coupler PN16 6 Bar/10 Bar
110mm 144 70 133 110 160 10 0.52
elbow PN16 6 Bar/10 Bar 125mm 154 75 151 125 200 10 0.74
140mm 181 B9 176 140 200 10 145
equal tee PN16 6 Bar/10 Bar 160mm 175 86 195 160 300 20 1.409
reducer PN16 6 Bar/10 Bar 180mm 185 91 220 180 360 20 1.906
200mm 186 92 243 200 440 20 2.301
tapping tee** PN16/PN12.5 6 Bar/10 Bar 225mm 222 109 276 225 600 30 4.15
branche saddle** PN16/PN12.5 6 Bar 250mm 220 108 301 250 600 30 4.28
280mm(40V) 260 127 345 280 600 30 8.32
hydrant products PN12.5 n/a
355mm(40V) 261 128 386 315 900 30 10.1
transition fittings PN12.5 6 Bar 355mm(40V) 260 126 437 355 900 30 123
400mm(40V) 290 142 475 400 TSC TBC 14 S

SDR RATINGS END CAP /

The appropriate pipe SDR rating for electrofusion fittings is in accordance with tables below: PE 100 Black - Gas 10 Bar / Water PN16
FUSION COOLING
Fitting Size 63mm and below Fitting Size Above 63mm FITTING L D1 WEIGHT
L (MM) D (MM) TIME TIME
SIZE 1(MM) (MM) (Kg)
Fitting type pipe SDR Fitting type pipe SDR (SECS) (MINS)
20mm 82 37.5 29 20 35 3 0.041
coupler 11 coupler 11 to 17.6
25mm 82 373 33.5 25 30 3 0.048
elbow 11 elbow 11 to 17.6 32mm 84 37.5 46 32 45 3 0.073

reducer 40mm 97 44 51.5 40 40 5 0.102

11 reducer 11 to 17.6
50mm 101 44 61,5 50 90 5 0.15
equal tee 11 equal tee 11 to 17.6 63mm 115 49 77 63 35 5 0326
tapping tee 11 tapping tee 11 to 17.6 75 mm 125 61 100 75 50 5 0.553
90mm 138 60 110 90 90 10 0321
branch saddle 11 branch saddle 11 to 17.6 119mm 164 70 133 110 160 10 0.97
transition fittings 11 transition fittings 11 to 17.6 125mm 175 75 151 125 200 50 1.24
140mm 236 89 176 140 200 10 2.25
Hydrant products 11 to 17.6 160mm 202 85 196 160 300 20 221
180mm 214 91 220 180 360 20 2.32
testing can be carried out on 200mm 215 108 243 200 440 30 4.2
225mm 222 109 276 225 600 30 7
SDR rated pipe out of the stated ranges if required.
250mm 220 108 301 250 600 30 8.1

22 23
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

ELECTROFUSION FITTINGS ELECTROFUSION FITTINGS

REDUCER
PE100 Black - Gas 10 Bar /Water PN16 45° ELBOW
PE100 Black - Gas 10 Bar/Water PN16

FUSION COOLING
FITTING L L1 D D1 L2 D2 D3 WEIGHT
TIME TIME
SIZE (MM) (MM) (MM) (MM) (MM) (MM) (MM) (Kg)
(SECS) (MINS) FUSION COOLING
WEIGHT
25x20mm 77 38.5 34 25 36.5 29 20 35 3 0.035 FITTING SIZE L (MM) L1(MM) D(MM) D1(MM) TIME TIME
(Kg)
32x20mm 77 38.5 43 32 36.5 29 20 40 3 0.048 (SECS) (MINS)
32x25mm 77 38.5 43 32 36.5 34 25 30 3 0.052 32mm x 45deg 95 39 44 32 45 3 0.08
40 x 32 mm 84 41 52 40 41 43 32 50 5 0.104 40mm x 4Sdeg 108 41,5 53 40 50 5 0.1
50x32mm 91 46.5 62 50 41 44 32 60 S 0.087 50mm x 45deg 124 44,5 63.8 50 80 5 0.134
50x40mm 91 46.5 62 so 43 52 40 60 5 0.9?
63mm x 45deg 136.4 50 78.5 63 35 5 0.25
63x32mm 102 52 78 63 44 44 32 90 S 0,13
63x40mm 102 52.3 77 63 45 52 40 70 5 0.103 75mmx45deg 165 62 97 75 70 10 0.427
63 x 50mm 102 52 78 63 48 62 50 120 I0 0.138 90mm x 45deg 192 82 117 90 110 10 0.765
75 x 63mm 126 61 98 75 57 82 63 80 7 0.44 110mm x45deq 213 75 137 110 140 10 0,894
90x63nvn 122.5 61 109.5 90 55 79 63 80 5 0,3 125mmx45deg 240 81 154 125 140 10 1.22
110x63mm 158 80 140 110 58 98 63 70 10 0,62 160mm x45deg 320 105 217 160 240 10 4.5
110x90mm 1375 70 134 110 62 111 90 120 10 0.535 180mm x45deg 320 105 217 180 240 20 3.13
125x90mm 145 75 152 125 62.5 112 90 160 10 0.7
160 x 90mm 192 96 200 160 73 117 90 700 22 1.44
EQUAL TEE
160x110mm
180x125mm
193
221
96
101
200
216
160
180
80
83
140
157
110
125
200
220
22
10
1.52
2.09
PE100 Black - Gas 10 Bar/Water PN 16

90° ELBOW
PE100 Black - Gas 10 Bar/Water PN 16

FUSION COOLING
L L1 D D1 D2 A WEIGHT
FITTING SIZE TIME TIME
(MM) (MM) (MM) (MM) (MM) (MM) (Kg)
(SECS) (MINS)
FUSION COOLING 20 x 20 x 20mm 98 35 44 20 20 78 30 3 0.13
WEIGHT
FITTING SIZE L (MM) L1(MM) L2(MM) D(MM) D1(MM) TIME TIME
(Kg) 25 x 25 x 2Smm 98 3S 44 25 25 78 35 3 0.12
(SECS) (MINS)
20mmx90deg 82 44 64 36 20 3S 3 0,141 32 x 32 x 32mm 98 35 44 32 32 78 50 3 0.1
25mm x 90deg 72.4 37,5 55.4 33.85 25 30 3 0.062 40 x 40 x 40mm 131 44 52 40 40 91 80 5 0.163
32mm x 90deg 84 40 62 44 32 60 3 0.097 50 x 50 x 50mm 141 43 64 50 50 104 90 5 0.23
40mm x90deg 116 50 83 67 40 50 5 0.34 63 x 63 x 63mm 156 50 82 63 63 114 40 5 0.445
50mm x90deg 116 50 83 67 50 90 10 0.741 75 x 7S x 75mm 174 60 97 75 75 126 120 10 0.597
63mm x 90deg 123.3 50 84,1 80 63 35 5 0.294 90 x 90 x 90mm 201 55 115 90 90 143 110 8 0.97
110x 110 x 110mm 239 73 139 no . 110 167 140 10 1.67
75mm x 90deg 141 53 92 95 75 70 5 0.425
125 x 125 x 125mm 262 79 156 125 125 196 200 15 2.3
90mm x 90deg 165 59 106 113 90 90 10 0.685
160 x 160 x 160mm 313 89 200 160 160 211 360 20 4.06
110mmx90deg 205 71 135 137 110 160 15 1.12
180 x 180 x 180mm 330 89 224 180 180 231 360 19 5.3
125mmx90deg 228 72 152 154 125 200 15 1.57
160mm x 90deg m 104 211 213 160 200 10 5
180mm x90d eg 320 104 211 213 180 300 20 4.12

24 25
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

ELECTROFUSION FITTINGS ELECTROFUSION FITTINGS

MULTISEAL TAPPING TEE U/P MALE TRANSITION COUPLER
PEI 00 Black - Gas 10 Bar/Water PN16 PE100 Black - Gas 10 Bar /Water PN16

FUSION COOLING
WEIGHT
FITTING SIZE L (MM) H (MM) h (MM) W (MM) TIME TIME
(Kg)
(SECS) (MINS)
40 x 20mm 105 110 27 120 40 3 0.25
40 x25mm 105 110 27 120 40 3 0,25
40 x 32mm 105 110 27 120 40 3 0.25
SO x 20mm 105 110 27 120 40 3 0,26
50 x 25mm 105 110 27 120 40 3 0.26
L1 L2 FUSION COOLING WEIGHT
50 x 32mm 105 110 27 120 40 3 0.26 FITTING SIZE L (MM) D (MM)
(MM) (MM) TIME (SECS) TIME (MINS) (Kg)
63 x 20mm 105 119 62 120 70 10 0.6
25mm x 3/4 114 79 34 17 30 3 0.4
63 x 25mm 105 119 62 120 70 10 0.6
32mm x 1/2 114 79 34 23 45 3 0.425
63 x 32mm 105 119 62 120 70 10 0.6
32mm x 3/4 114 79 34 23 45 3 0.425
75 x 20mm 105 110 77 120 100 10 0.646
32mm x1" 114 79 34 23 45 3 0.426
75 x 2Smm 105 110 77 120 100 10 0.646
32mm x 11/4 114 79 34 23 45 3 0,431
75 x 32mm 105 110 77 120 100 10 0.646
32mm x11/2 114 79 34 23 45 3 0.431
90 x 20mm 105 110 77 120 100 10 0.646
40mm x 1" 126 81 34 29 40 5 0.468
90 x 25mm 105 110 77 120 100 10 0.646
40mm x 11/4 126 83 34 29 40 5 0.468
90 x 32mm 105 110 77 120 100 10 0.646
40mm x11/2 126 83 34 29 40 5 0,468
110 x20mm 105 117 87 120 80 10 0.682
110 x 25mm 105 117 87 120 80 10 0.682 40mm x 2" 126 88 34 29 40 5 0,471

110 x32mm 105 117 87 120 80 10 0.682 50mm x 1" 134 86 34 38 80 5 0.418

125x20mm 105 117 9S 120 80 10 Q.67 50mm x 11/4 136 88 36 38 80 5 0.548

125 x 25mm 105 117 95 120 80 10 0.67 50mm x11/4 136 88 36 38 80 5 0.548
125 x32mm 105 117 95 120 80 10 0.67 50mm x 2“ 141 93 41 38 80 5 0,569
160 x 20mm 105 122 112 120 100 10 0.69 63mm x11/4 154 97 36 48 35 3 0.704
160 x 25mm 105 122 112 120 100 10 0.69 63mm x 11/2 154 97 36 48 35 3 0.704
160 x32mm 105 122 112 120 100 10 0.69 63mm x 2" 159 102 41 48 35 3 0.894
180 x 20mm 105 122 122 120 100 10 0.68
180 x25mm 105 122 122 120 100 10 0.68
180 x32mm 105 122 122 120 100 10 0.68
200 x20mm 105 122 132 120 100 10 0.73
200 x25mm 105 122 132 120 100 10 8.73
200 x32mm 105 122 132 120 100 10 0.73
225 x 20mm 105 122 122 120 100 10 0.78
225 x 25mm 105 122 122 120 100 10 0.78
225 x 32mm 105 122 122 120 100 10 0.78

26 27
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

INTERNAL (BARBED) FITTINGS ON LINE DRIPPERS

TEE Equal TEE Reducer
mm x mm x mm mm x mm x mm JSPF Adjustable Flow Dripper
16 x 16 x 16 19 x 13 x 19
19 x 19 x 19 19 x 16 x 19 Advantages:

20 x 20 x 20 The dripper has the following advantages: CODE Discharge L/H

20 x 16 x 20
25 x 25 x 25 25 x 16 x 25 • No complicated channels or nozzles
which can be clogged. JP-ED-AD001 0 - 50
32 x 32 x 32 25 x 20 x 25
• Simple installation JP-ED-AD002 0 - 100
32 X 16 X 32
• Easy operation
32 X 20 X 32
400 440 • Efficient water distribution
Connector / Joint Reducer Nipple / Male JSPF adjustable dripper is ideal for flower

mm x mm inch x inch bed, shrubs, trees and plants.

4x4 3/4” x 1/2”

JSPF E2 – Emitter
16 x 16 1” x 1/2”
Application:
19 x 19 1” x 3/4”
20 x 20 1 1/2” x 1” A laminar flow emitter with precise and uniform flow characteristics.
25 x 25 2” x 1” • Ideal for irrigation fruit trees and vegetables.
32 X 32 2” x 1 1/2” • Easy to use in landscape irrigation applications due to the possibility of mounting
it on a 4mm I.D. spaghetti tube at its outlet.
410 450 3” x 2”
4” x 2”
Main Features:
• Main dripper is a simple to use on-line emitter.
4” x 3” • Removable cap for easy inspection and cleaning.
Elbow End Stop - Shape 8 • Features a lock that protects cap.
• Easy to install in the field.
mm x inch x mm mm
16 x 16 16
T.K Drip Emitters
19 x 19 20
20 x 20 25 Nominal Dis- Pressure ( Bar )
Code No.
charge 1.00 1.5 2.00
25 x 25
16 x 1/2,“3/4” JP-ED-TK001 4L / HR 4.00 4.80 5.40

19 x 1/2, “3/4”,1” JP-ED-TK002 8L / HR 9.00 9.00 10.50

20 x 1/2, “3/4”,1” JP-ED-TK003 2L / HR 2.05 2.10 2.10

420 25 x 1/2, “3/4”,1”
460 JP-ED-TK004 4L / HR 4.10 4.10 4.20
JP-ED-TK005 8L / HR 8.20 8.20 8.30
Male Adaptor with BSP thread TEE with Thread
mm x inch mm x inch x mm T.K Non Pressure Compensating Drip Emitter
16 x 1/2” 16 x 1/2” x 16 • Turbulant flow to resist blockage • Dripperline stability provided by logs in base • Clean easily due to its removable cap
16 x 3/4” 16 x 3/4” x 16 • 4mm Barbed inlet
19 x 1/2” 19 x 1/2” x 19
Applications: Landscaping, Orchards, Vineyards, Green Houses, Shrubs.
19 x 3/4” 19 x 3/4” x 19
20 x 1/2” 19 x 1” x 19
Bubbler Stake (16 x 1/2) Code mm x inch
20 x 3/4” 20 x 1/2” x 20
JSPF stake could be used for Bubblers, Pop- JP-ED-S001 16 x 1/2”
430 25 x 1/2”
25 x 1”
25 x 3/4” x 20
25 x 1/2” x 25
up Sprinklers etc.

which has female thread of 1/2 stake inlet 13

32 x 1” 25 x 3/4” x 25
mm outlet 1/2.
50 x 1 1/2” 25 x 1” x 25
63 x 2”
470 32 x 1” x 32

28 29
Al Jubail ‫الجبيل‬ Al Jubail ‫الجبيل‬

BUBBLERS JSPF VALVES

Single Union, B.S Parallel Male / Female Threaded
Code Description Type Discharge L / H
JP-ED-B001 Adjustable Bubbler RA 300 L / H
PN
JP-ED-B002 Adjustable Bubbler RB 0 - 650 L / H G“ DN mm“ Weight gr.
a 20˚ bar
JP-ED-B003 Adjustable Bubbler RC 0 - 650 L / H
3/4” 16 100
JP-ED-B004 Pressure Compensated Bubbler RBC 0.25, 0.5, 1.0, 2.0, G.P.M
1” 25 1” 16 200
1 1/2” 40 1 1/2” 16 480
Specification and Advantages: 2” 50 2” 16 832
• Water inlet to stake 13 mm
• Water outlet from stake to bubbler 1/2 outside
• No clogging is possible because of internal filter
• For RA and RC type bubblers, adjusting the inside, as for RB bubbler adjusting on the top of the bubbler
Applications:
Landscaping, flower beds, shrubs, trees, palm, orchards.
Single Union, B.S Parallel Female Threaded

Central Pivot Accessories

PN
G“ DN mm“ Weight gr.
a 20˚ bar
3/4” 16 100
Starter for Central Pivot Sprayer Central Pivot Sprayer 1” 25 1” 16 210
1 1/2” 40 1 1/2” 16 485
Code mm x inch 2” 50 2” 16 838
JP-IBF-MA008 19 x 3/4”

Butt Fusion Welding Machine Size 90 mm To 250 mm

JSPF VALVES
OD (mm)
CODE
mm x inch, mm
JP-VR001 16 x 16
JP-VR002 16 x 1/2”
JP-VR003 13 x 3/4”
JP-VR004 16 x 1”
JP-VR005 20 x 20
JP-VR006 20 x 1/2”
JP-VR007 30 x 3/4”
JP-VR008 20 x 1”
JP-VR009 25 x 25
JP-VR010 25 x 1/2”
JP-VR011 25 x 3/4”
JP-VR012 25 x 1”
JP-VR013 32 x 32
JP-VR014 32 x 1/2”
JP-VR015 32 x 3/4”
JP-VR016 32 x 1”

30 31
www.jubailpipes.com

JSPF Issue No. 4

Head Office
P.O. Box 10177, Madinat Al-Jubail Al-Sinayah 31961 Kingdom of Saudi Arabia
Tel: +966 3 3419822 to 25 • Fax: +966 3 3419826
E-mail: info@jubailpipes.com

Branches:
Riyadh: Tel: +966 1 4953317 • Fax: +966 1 4951588
Buraidah : Tel: +966 6 3810265 • Fax:9663826831
Jouf : Tel: +966 4 6254085 • Fax: +966 4 6254095
Qaria Olaya : Tel: +966 3 3862170 • Fax: +966 3 3862176
