IBM Integration Bus Version 9 Beta Mapping Node

Andrew Coleman – IBM Integration Bus Development
June 2013
IBM Integration Bus Version 9 Beta

Mapping Node
© 2013 IBM Corporation

Disclaimer
Information regarding potential future products is intended to

outline our general product direction and it should not be relied
on in making a purchasing decision.
The information mentioned regarding potential future products is

not a commitment, promise, or legal obligation to deliver any
material, code or functionality.
Information about potential future products may not be

incorporated into any contract.
The development, release, and timing of any future features or

functionality described for our products remains at our sole
discretion
2 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Agenda
Mapping Node recap

Hints and Tips – Good map design
The power of XPath 2.0
Database mapping – Insert / Update / Delete
Invoking DB Stored Procedures
‘Assisted Convert’ of version 6.x / 7 maps
Other new features

Much Ado About Mapping
Improved usability
– Simple learning curve
– Simple transformations are simple to create
– Complex transformations build on concepts previously mastered
Improved capability
– Builds upon ‘best of breed’ mapping technologies in IBM products
– Full XPath 2.0 expression support
• Standards-based language designed for hierarchical data structures
Improved performance
– Dedicated runtime engine

The Mapping Editor

The Mapping Editor
Input / Source tree

The Mapping Editor
Output / Target tree

The Mapping Editor
Properties editor

The Mapping Editor
Transform

The Mapping Editor
Toolbar

The Mapping Editor
Name Type
+ Expand Occurrence
- Collapse
The Mapping Editor
Find elements
anywhere in the tree
Click <Show all>

To remove filter

The Mapping Editor
Help system

Transform types
Local Move
For each Assign
If / Else Convert
Submap XPath function - categorised
Create Custom XPath expression
Join Java – user defined
Append ESQL – user defined
Group

Transform properties
Each transform can be configured in the properties pane

Standard pages
– General – transform specific configuration
– Variables – customise variable names used in expressions
– Condition – XPath predicate determines if transform is performed
– Order – can re-order the input and output connections
– Documentation – freeform text
For repeating inputs
– Cardinality – specify which elements in array to transform
– Filter Inputs – only process elements according to XPath predicate
– Sort – re-order the input array

Properties? – What Properties?
When working in ‘full screen mode’ – the map takes the whole area
– Good for working with large, complex maps, but…
– How do I see the properties?
– Press ‘Alt-Enter’
Or click here

Map Navigation
Breadcrumb trail
Up one level
Down one level
Outline view
Linked to map

Map Design – Best Practices

Structured Mappings

What not to do

What not to do

What not to do

The nested approach

Controlling the output
Use ‘Local’ transform to map complex source to complex target

If elements are optional, set a condition property
– E.g. only create output if input exists

Map Refactoring
Insert new levels in the hierarchy

– E.g. Insert a ‘Local’ transform between
structures that are already mapped
– Error marker: Parent element already mapped!
– Quick fix: Nest transform within parent map
– Results in more structured mapping
Refactor to submap
– Convert a structural transform
to a submap
– Allows existing structural
transforms to be reusable

Message Assembly – Adding and Deleting Headers

Message Assembly – Adding and Deleting Headers
Selected headers are added into the

map editor.
Headers in the input message that
don’t appear in the target tree are
copied to the output message.
Headers not in the input message
can be added to the output message
by adding them to the target tree and
mapping to them.
Headers in the input message can be
deleted by adding them to the target
tree and not mapping to them.

Casting elements
xsd:any elements can be cast to

any simple or complex type
Other elements can be cast to a
derived type
Use to map variables in
LocalEnvironment
Use to map header and body in
SOAP message

Mapping a SOAP message
2) Right click -> Cast…

select required element
1) Create the map using the
built in SOAP schema.
3) Map the cast elements

Runtime trace
WMB ‘user trace’ will track the progress of the message though the map
Logs messages when
– individual transforms are entered and exited
– The input tree is navigated
– Output tree elements are created
– Values assigned to the output
– Variables are assigned/updated or go out of scope
– Functions are invoked, including user defined functions
…
2012-03-12 12:07:53.044555 96400 UserTrace BIP3962I: The Mapping node is assigning the value ''Twister'' to
the current output element.
2012-03-12 12:07:53.044647 96400 UserTrace BIP3956I: The Mapping node is exiting the transform ''Move''.
2012-03-12 12:07:53.044689 96400 UserTrace BIP3955I: The Mapping node is entering the transform ''Move''.
2012-03-12 12:07:53.044815 96400 UserTrace BIP3959I: The Mapping node is traversing the input tree by using
the nodetest ''element(Price)'' and the relationship ''child''. The number of matching elements is ''1''.
2012-03-12 12:07:53.044876 96400 UserTrace BIP3960I: The Mapping node is adding a new element with name
''out:Cost'' into the output tree.
…

XPath 2.0 – Quick Guide

XPath 2.0
The expression syntax used by properties in the mapping node

Specifies location paths for a tree structure
– E.g. $Order/Item[1]/Description
Type system based on XML Schema (and hence DFDL)

Rich function library
Expressive syntax supporting complex calculations with minimal code
Read-only ‘functional’ language – no side effects
‘Variables’ refer to elements in the input tree
High level programming constructs including ‘for’ loops, ‘if-then-else’
conditions
http://www.w3.org/TR/xpath20/
XPath 2.0 in the mapper
Much more than a ‘path’ syntax

– Path navigation using XPath is rarely done in the mapper
– Navigating the tree is done graphically
Most XPath expressions in the mapper are ‘predicates’
– Used within the ‘condition’ property of transforms
– If the expression evaluates to ‘true’, then the transform is evaluated and the
target is produced
Other common uses involve numeric calculation
– All the usual mathematical operators are built into the XPath syntax
– Numeric function library – e.g. sum, count, round, max, min, …
Strong support for string manipulation
– Extensive function library for string splitting, joining, comparing, etc.

Everything is a sequence… What is a sequence?
XPath 2.0 naturally handles repeating elements and values

A path expression can match multiple elements
– Returns a ‘sequence’ of elements (nodes)
It might only match one element
– It still returns a sequence, containing one element
Some expressions expect to work with data values, not elements
– E.g. sum($books/book/price)
– No problem, it will automatically extract the values from the elements
• This is called atomization and results in a sequence of values (e.g. decimals)
Some expressions expect a single value, not a sequence

– E.g. $quantity * 3
– A single value is equivalent to sequence containing one value
– If the expression is passed a sequence of more than one value, an error is thrown

(Sequences, Sequences, Sequences)
A sequence is an ordered collection of items

– An item is either a node (in the XML sense) or a value (of a schema type)
What if we have a path expression that matches nothing?
– Then it returns the ‘empty sequence’ – a sequence containing zero items
Sequences are returned by expressions and functions
– They can also be constructed as literals in an expression
– E.g. (1,2,3) produces a sequence containing the numbers ‘1’, ‘2’, and ‘3’
– (1 to 3) does the same
– () produces the empty sequence
Sequences can be constructed from other sequences

– E.g. ($var1,$var2,"str")
Sequences are always ‘flattened’

– i.e. (1,2,(3,4),(5),(),6) produces the sequence (1, 2, 3, 4, 5, 6)

Consequences of sequences
Sequences can be picked apart

– ("one", "two", "three")[2] → “two”
– subsequence((1 to 10), 3, 4)) → (3, 4, 5, 6)
Remember that sequences are always flattened

– ((), "two", "three")[2] → “three”
– ($var/missing, "default")[1] → “default”
• Assuming that <missing> doesn’t exist
• Just like the ESQL function coalesce()
A sequence can be assigned to a repeating output element

– Multiple elements created; each value in the sequence will be assigned to
each element

Predicates
A predicate is an expression that returns Boolean ‘true’ or ‘false’

In XPath, all values have an ‘Effective Boolean Value’ (EBV)
Therefore, all expressions can be used as predicates
The following values have EBV false
– The xs:boolean value false
– The numbers 0 and NaN
– The empty string ""
– The empty sequence ()
Everything else has EBV true
Booleans can be produced by comparison and logical operators
=, !=, <, >, <=, >=, eq, ne, lt, gt, le, ge
and, or, not

Number crunching
XPath syntax has numeric operators

+, -, *, div (can’t use / - path separator), idiv, mod
$book/price * 1.2
– The result of the path expression is atomized to extract the value as its xsd type
– Works provided the ‘price’ element is defined as a numeric type in the schema
– Otherwise it throws a ‘type error’ (XPTY0004)
– If it’s a xs:string, can explicitly cast it – xs:decimal($book/price) * 1.2
$books/book/price * 1.2
– Will throw a type error because ‘book’ is repeating
$books/book/(price * 1.2)
– Will work though – it returns a sequence of numbers
sum($books/book/(price * quantity))
– The sum() function takes a sequence of numbers as its parameter

String theory
Most transformations involve significant string

manipulation
XPath has a rich function library to support this
– Available in the transform ‘picker’
– Parameters automatically configured from wired inputs
– These parameters are themselves XPath expressions
that can invoke other string functions
– Usage documentation in property page
More complex combinations of functions and
expressions can be written in a custom XPath
transform
– Content assist and wizard based builder available

What’s new in v8.0.0.1, v8.0.0.2 and v9.0

Database Mapping
Mapper can work with data in a relational database

– Supports DB Select, Insert, Update, Delete & Stored Procedures
Can select fields from DB tables based on data in the input message
Can modify DB tables using values defined in the map
Graphical SQL ‘WHERE’ clause and ResultSet generator
– Can contain parameter placeholders to reference the input message tree
– Parameter values specified using XPath
ResultSets are presented as source trees in the map editor
Input parameters are presented as target trees

Database Mapping – JDBC configuration
Create JDBC Configurable Service

Set security credentials
– mqsisetdbparms
Toolkit and Runtime both connect to
the DB using JDBC
Now possible to specify a different
database schema at runtime from
the one specified in the map editor
JDBC Configurable service
– databaseSchemaNames property 8.0.0.1
– Specifies the database schema to
use at runtime for all DB operations
or a delimited list of table/schema
names
– If left unset, uses DB default schema
name (as for v8 GA mapper)

Database SELECT

Database SELECT
Source tree representing

The DB Select result set

8.0.0.1
Database Insert
Inserts a row into a Database table

Connects via JDBC
– WMB configurable service
DB table presented as target tree
– Transforms mapped to target tree specify
values to be inserted
Can also map to output message if DB
Insert succeeds
– Inside the ‘Return’ transform
– Can also do further DB operations here
Can map SQL error code to output
message if DB Insert fails

Database Insert

Database Insert

Database Insert

8.0.0.1
Database Update
Updates row(s) in a Database table

SQL ‘where’ clause edited in same way as ‘Select’ transform
DB table presented as target tree
– Transforms mapped to target tree specify values to be updated
Can also map to output message if DB Update succeeds
– ‘number of rows updated’ is available to be mapped
Can map SQL error code to output message if DB Update fails
Option to insert new row if no existing rows match the ‘where’ criterion

Database Update

8.0.0.1
Database Delete
Deletes row(s) from a Database table

SQL ‘where’ clause edited in same way as ‘Select / Update’ transform
DB table presented as target
– No field members are shown under the target
– Nothing to map – rows that match the where clause are deleted from the table
Can map to output message if DB Delete succeeds
– ‘number of rows deleted’ is available to be mapped
Can map SQL error code to output message if DB Delete fails

8.0.0.2
Database Policy – missing, empty & nil data

9.0
Database Stored Procedures
Invoke a database Stored Procedure

Presented as a ‘complex’ transform (function)
Tools to discover Stored Proc metadata
Presents ‘IN’ and INOUT’ parameters as target tree in nested map
– Wire inputs to stored procedure
‘INOUT’, ‘OUT’, ResultSet(s) & Return value as source tree in nested map
Supports DB2 (GA), Oracle (soon)


CREATE PROCEDURE ADD_CUSTOMER ( INOUT NAME VARCHAR(20),

IN ADDRESS VARCHAR(50),
OUT IDENT INTEGER )
P1: BEGIN
set ADD_CUSTOMER.IDENT = (
select id from new table (
insert into customers (name, address)
values (ADD_CUSTOMER.NAME,ADD_CUSTOMER.ADDRESS)
)
);
SET ADD_CUSTOMER.NAME = UPPER(ADD_CUSTOMER.NAME);
END P1



Stored Procedures – Returning ResultSet(s)

CREATE PROCEDURE ADDBOOK ( IN pISBN CHARACTER(32),
IN pTITLE CHARACTER(128),
INOUT pCOPIES INTEGER,
OUT pDUPLICATE BOOLEAN )
DYNAMIC RESULT SETS 2
P1: BEGIN
DECLARE cursor1 CURSOR WITH RETURN FOR
SELECT TITLE, ISBN, COPIES
FROM BOOKS2
WHERE ISBN = ADDBOOK.pISBN;
DECLARE cursor2 CURSOR WITH RETURN FOR

SELECT TITLE, ISBN, COPIES
FROM BOOKS2;
merge into BOOKS2 using

table (values (ADDBOOK.pISBN, ADDBOOK.pTITLE, ADDBOOK.pCOPIES))
as tBOOK (ISBN, TITLE, COPIES)
on BOOKS2.ISBN = tBOOK.ISBN
when matched then
update set COPIES = COPIES + tBOOK.COPIES
when not matched then
insert (ISBN, TITLE, COPIES)
values (tBOOK.ISBN, tBOOK.TITLE, tBOOK.COPIES);
select COPIES INTO pCOPIES from BOOKS2 WHERE ISBN = ADDBOOK.pISBN;

set pDUPLICATE = true;
OPEN cursor1;
OPEN cursor2;
END P1


8.0.0.1
Version 7 Maps
8.0.0.2
Version 7 maps can be viewed in Version 8/9 toolkit

– Read-only – cannot be edited
Version 7 maps can still be executed in Version 8/9 GA runtime
– Converted in the toolkit into an ESQL Compute node
– Executed in the ESQL runtime engine
Can ‘convert’ V7 maps to V8 maps (requires version 8.0.0.1)
– .msgmap -> .map file format conversion
– Can then be opened in V8 mapping editor and modified etc.
– Will then be executed in the V8 mapping runtime engine
‘Assisted Convert’
– Fundamentally different technologies
– Cannot guarantee 100% accurate ‘migration’
– Inserts annotations or ‘Task’ markers to prompt user review or fix up

Version 7 Maps

Assisted convert

Converted Map

Map annotations

8.0.0.1
Tasks

Repeating model groups

‘For each’ – Multiple outputs 8.0.0.2
<library>
<parameters>
<name>FRED BLOGS</name>
<value>16</value>
<name>JOE SMITH</name>
<value>17</value>
<name>MARY BERRY</name>
<value>18</value>
</parameters>
</library>

‘For each’ – Allow empty input 8.0.0.2
When checked
– If input array is empty
– or no inputs match filter condition
– Then the transform runs once
• Primary input in nested transform will be missing
• The index variable will be set to zero
Can be used to construct left, right and full outer joins

– Using nested ‘For each’ transforms with this option

‘Create’ Transform 8.0.0.2
Creates a new output element without any input

– Either simple element or complex structure
Used for creating empty or ‘nil’ elements
For simple elements can also assign ‘default’ or ‘fixed’ content based on
schema definition
– As opposed to ‘Assign’ transform which assigns a fixed value

‘Group’ Transform 9.0
Takes a repeating input structure produces multiple structures grouped by

distinct keys <countries>
<country name="France">
<city>Paris</city>
E.g <city>Nice</city>
<city>Lyon</city>
<cities> </country>
<city name="Paris" country="France"/> <country name="Italia">
<city name="Roma" country="Italia"/> <city>Roma</city>
<city name="Nice" country="France"/> <city>Milano</city>
<city name="Madrid" country="Espana"/> <city>Firenze</city>
<city name="Milano" country="Italia"/> <city>Napoli</city>
<city name="Firenze" country="Italia"/> </country>
<city name="Napoli" country="Italia"/> <country name="Espana">
<city name="Lyon" country="France"/> <city>Madrid</city>
<city name="Barcelona" country="Espana"/> <city>Barcelona</city>
</cities> </country>
</countries>

Other new features
Fewer restrictions on ‘head to head’ mappings

– Required to support v7 map conversion
Submap now supports multiple inputs
Added xs:<type> functions for casting values to
anySimpleType target
– Now available in transform picker
– Saves having to write custom XPath

Summary
New v8 Mapping Node

– Improved usability, capability and performance
Good Map Design
– Hierarchical mapping editor sub-divides complex transformations
– Remember to use ‘Local’ transform between structures
– Add conditions to control creation of target
– Use refactoring tools to restructure mappings
XPath 2.0 allows complex transformation logic
– Highly expressive syntax
– W3C open standard
Enhanced Database support
– Select, Update, Insert, Delete, Stored Procedures
Comprehensive ‘assisted convert’ tool

IBM Integration Bus Version 9 Beta Mapping Node

Uploaded by

Copyright:

Available Formats

You might also like

IBM Integration Bus Version 9 Beta Mapping Node

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

IBM Integration Bus Version 9 Beta Mapping Node

Uploaded by

Copyright:

Available Formats

Andrew Coleman – IBM Integration Bus Development

IBM Integration Bus Version 9 Beta

© 2013 IBM Corporation

Information regarding potential future products is intended to

The information mentioned regarding potential future products is

Information about potential future products may not be

The development, release, and timing of any future features or

2 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Mapping Node recap

3 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

4 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

5 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Input / Source tree

6 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Output / Target tree

7 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

8 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

9 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

10 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Click <Show all>

12 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

13 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

14 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Each transform can be configured in the properties pane

15 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

16 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Down one level

17 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

18 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

19 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

20 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

21 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

22 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

23 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Use ‘Local’ transform to map complex source to complex target

24 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Insert new levels in the hierarchy

25 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

26 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

Selected headers are added into the

27 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

xsd:any elements can be cast to

28 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

2) Right click -> Cast…

3) Map the cast elements

29 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

30 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

31 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

The expression syntax used by properties in the mapping node

Type system based on XML Schema (and hence DFDL)

Much more than a ‘path’ syntax

33 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

XPath 2.0 naturally handles repeating elements and values

Some expressions expect a single value, not a sequence

34 IBM Integration Bus V9 Beta Program © 2013 IBM Corporation

A sequence is an ordered collection of items

Sequences can be constructed from other sequences

Sequences are always ‘flattened’
