GETTINGTOGRIPSWITHFANS
GETTINGTOGRIPSWITHFANS
FOREWORD
The purpose of this brochure is to provide AIRBUS aircraft operators with an
overview of the CNS/ATM concept, more specifically on data link communication
matters (i.e. FANS operations), and with operational details regarding AIRBUS
FANS A and FANS B systems. This brochure is split into three parts :
The present brochure is the follow-up of the former brochure entitled “Getting to
grips with FANS, issue II – September 2003”. It introduces some updates on
operational procedures, the A380 interfaces related to data link communications
(Part II), and the brand new AIRBUS FANS B system for A320 family aircraft with
the related operational procedures (Part III).
Part I – Getting to grips with CNS/ATM introduces the CNS/ATM concept and the
AIRBUS products (i.e. FANS A and FANS B) derived from this concept.
Part II – Getting to grips with FANS A and Part III – Getting to grips with FANS B
are two separate parts, respectively dedicated to FANS A system (FANS A+
included) and FANS B system. They are organized exactly in the same way. To
ease the reader’s understanding, chapter and page numberings are preceded by A
(for FANS A) in Part II and B (for FANS B) in Part III.
It has to be noticed that the present brochure deals with ATC data link
communications. The reader is invited to refer to Getting to grips with data link –
April 2004 for details about AOC data link communications.
The contents of this Getting to Grips Brochure are not subject to Airworthiness
Authority approval. Therefore, this brochure neither supersedes the requirements
mandated by the State in which the operator's aircraft is registered, nor does it
supersede the contents of other approved documentation (e.g. AFM, FCOM, MEL,
etc). If any contradiction exists between this brochure and local/national
authorities regulations (or other approved documentation), the latter
applies.
Any questions with respect to information contained herein should be directed to:
AIRBUS SAS
Flight Operations Support & Services
Customer Services Directorate
1, Rond Point Maurice Bellonte, BP 33
31707 BLAGNAC Cedex – FRANCE
Fax: 33 5 61 93 29 68 or 33 5 61 93 44 65
E-mail: fltops.ops@airbus.com
Getting to grips with FANS – Part I – Issue III Table of contents
Abbreviations....................................................................................................................... 4
1. CNS/ATM concept.......................................................................................... 17
1.5. Surveillance.........................................................................................20
2. CNS/ATM implementation.......................................................................... 23
2.2. FANS 1/A standards for oceanic and remote areas .............................26
-1-
Table of contents Getting to grips with FANS – Part I – Issue III
-2-
Getting to grips with FANS – Part I – Issue III Table of contents
-3-
Abbreviations Getting to grips with FANS – Part I – Issue III
ABBREVIATIONS
-4-
Getting to grips with FANS – Part I – Issue III Abbreviations
-5-
Abbreviations Getting to grips with FANS – Part I – Issue III
-6-
Getting to grips with FANS – Part I – Issue III Abbreviations
-7-
Executive Summary Getting to grips with FANS – Part I – Issue III
1. CNS/ATM CONCEPT
Communication
o Operationally speaking, the biggest change provided by FANS is the way pilot
and controllers communicate. In addition to the classical VHF and HF voice,
and to the more recent satellite voice, digital CPDLC (Controller Pilot Data Link
Communications) expands the set of communication means between pilots and
controllers.
o CPDLC is a powerful tool to sustain ATC communications in oceanic or remote
areas as a primary means, and it became, by the end of 2006, a
supplementary communication means to overcome VHF congestion in some
dense continental airspaces (where voice VHF media remains the primary
communication means).
1
FANS A+ package is an enhancement of FANS A package with additional features. For more details,
please refer to chapter A6 – FANS A evolutions of Part II – Getting to grips with FANS A.
-8-
Getting to grips with FANS – Part I – Issue III Executive Summary
Navigation
o FANS routes or air spaces are associated with a given RNP (Required
Navigation Performance) value. This RNP is a statement on the navigation
performance accuracy necessary for operation in this air space.
Surveillance
o Under this term is grouped a large set of methods to improve the management
of all the parts of the air traffic, e.g. traffic flow management, strategic (long
term) and tactical (short term) control or air traffic services. New methods are
developed and progressively implemented to provide greater airspace capacity
to cope with the large increase of air traffic demand.
2. CNS/ATM IMPLEMENTATION
This is for a worldwide network. Historically, data link has been operational in
oceanic and remote areas first with FANS 1/A 2 standards through the existing
ACARS network. FANS 1/A standards are highly inspired from ICAO concept but
do not comply with the entire ICAO specifications. Indeed, FANS 1/A standards
utilise ACARS network that is less efficient than the new ATN. Therefore, in order
to offset ACARS weaknesses, a specific communication protocol called ARINC 622
has been implemented.
The entry in operation of the ATN all over the world is planned in successive
steps. The initial step consists in trials in some areas. The following steps will
intent to deploy FANS operations based on ATN on other areas.
For oceanic and remote areas, a dedicated technology has been developed to
insure communication, navigation and surveillance according to ICAO CNS/ATM
concept. The characteristics of these regions do not allow VHF and Radar
antennas to cover air-controlled areas entirely. Therefore, the FANS 1/A packages
2
FANS 1 was developed by Boeing, and FANS A by AIRBUS. The two systems have been harmonized
under FANS 1/A standards.
-9-
Executive Summary Getting to grips with FANS – Part I – Issue III
are well-adapted systems to insure the three CNS functions with an accurate
constellation of satellites.
Notice that in some areas where data link communications have reached a good
reliability, data link communication is considered as the primary means of
communication and voice communication is used as back up.
The ATN Baseline 1 standards have been developed to aim the same objectives
set by the ICAO CNS/ATM concept. However, because of environment
discrepancies (traffic density, procedures, etc), ATN Baseline 1 standards have
been settled in a slightly different way. Differences with FANS 1/A standards
mainly deal with data link protocols (communication and surveillance), whereas
airborne/ground architectures and applications are almost identical.
The operational benefits from data link operations in high-density continental
airspaces are a significant alleviation of congested voice channels and increased
airspace capacity.
For the deployment of the full ICAO CNS/ATM concept, the FAA CPDLC
programme is divided into three main steps : Build I, II and III. The initial
implementation of ATN Baseline 1 standards over USA is framed in a preliminary
step called CPDLC Build 1A. The CPDLC Build 1A programme is focused on Miami
area.
Unfortunately, since 2001, due to budget reallocation, the FAA CPDLC programme
has been frozen.
- 10 -
Getting to grips with FANS – Part I – Issue III Executive Summary
Accommodation of standards
In order not to loose the investments made on systems compliant with FANS 1/A
standards while ATN is deploying, studies to adapt one standard (e.g. FANS 1/A)
to another (e.g. ATN Baseline 1) are in progress. Such adaptations are called
accommodation.
AIRBUS products
* In the rest of the document, the term A320 will be used to designate the A320
family.
- 11 -
Executive Summary Getting to grips with FANS – Part I – Issue III
FANS A architecture
FANS A applications
CPDLC is a powerful tool to sustain data link communications between a pilot and
the controller of the relevant flight region.
- 12 -
Getting to grips with FANS – Part I – Issue III Executive Summary
FANS B architecture
o The airborne part, with the ATSU, which is a modular hosting platform that
centralises all data communications (ATC and AOC) and manages the
dedicated Human Machine Interface (HMI).
o The air/ground data link :
- VDL modeA/2, SATCOM or HFDL are used to transmit AOC data to the
ground as per FANS A architecture. SATCOM and HFDL for AOC purposes
are optional,
- Only VDL mode 2 is used to transmit ATC data to the ground for
communication purposes.
o The ground/ground data link, which is the same as per FANS A
architecture. Nevertheless, two types of network have to be considered :
ACARS for AOC and ATN for ATC.
o In the same way as in FANS A architecture, DSPs are interconnected to ensure
the interoperability of ATS data link applications.
FANS B applications
This application provides the Data Link Initiation Capability (DLIC) service, which
is similar to the FANS A AFN application and remains mandatory prior to any
CPDLC connection from an operational point of view.
Even if ACARS and ATN environments provide similar services, some discrepancies
exist. Pilots who operate both FANS A and FANS B package should master these
discrepancies in order to properly operate any FANS systems with their distinctive
features.
- 13 -
Executive Summary Getting to grips with FANS – Part I – Issue III
Accommodation
For the time being, data link operations are possible in many parts of the world,
mainly over the ACARS network. Consequently, different combinations of aircraft
types with data link networks can be imagined. The following table presents the
different combinations offered by AIRBUS.
… on which aircraft …
A320 A330/A340 A380
environment?
… for which
FANS B Continental
- 14 -
Getting to grips with FANS – Part I – Issue III Executive Summary
The AEEC623 specification defines the application text formats for character-
oriented Air Traffic Services messages (called ATS 623 applications for departure
or oceanic clearances and Digital ATIS) that can be transmitted over the ACARS
data link.
With its NPA-OPS 48, the European JAA proposes to postpone the mandate dates
due to the short lead-times (i.e. postponement of 3 years).
If your airline is not submitted to European regulations, please refer to your local
authority.
Performance requirements
The transition to CNS/ATM requires both flexibility and growth capability. For the
airplane, flexibility is the essential requirement, but requires computer power.
This was tackled right from the beginning with the AIRBUS FANS avionics
package: the power and flexibility of a dedicated communications unit (the
ATSU, respectively the ATC applications) combined with the power of a new FMS.
A320/A330/A340 aircraft
o This avionics unit (ATSU) has been developed to cope with data link
communications. Its functions are:
- To manage the HMI, the display and warning systems,
- To enable the access to all available communications media,
- To sustain the communications tasks.
o The FMS is a key element of the AIRBUS FANS A system for which :
- It provides data to the ATSU
- It monitors the ATC messages and their subsequent implications
- It handles and processes some of the ATC messages
- 15 -
Executive Summary Getting to grips with FANS – Part I – Issue III
o The main crew interface used for the FANS applications is based on the two
DCDUs. All ATC messages, clearances (uplink message), requests or answers
(downlink messages) are displayed on the DCDU.
o In addition to the DCDU, the MCDU is mainly used to prepare a request.
A380 aircraft
The A380 introduces new technologies. As such, its architecture is different from
the ones on A320 and A330/A340 aircraft. However, the basic operational
principles remain exactly the same.
A380 cockpit benefits from a new design where the Control and Display System
(CDS) is the key element. However, A380 FANS interfaces had been designed in
order to keep the same operational principles as on A320/A330/A340 aircraft.
- Uplink messages (i.e. clearances or instructions) and downlink messages
(i.e. requests or responses) are received on or sent from the ATC
mailbox located on the central screen C2 of CDS.
- Downlink messages are prepared from the Multi Function Display (MFD –
ATC COM pages) located on either side of the ATC mailbox (i.e. L3 and
R3 CDS screens).
- 16 -
Getting to grips with FANS – Part I – Issue III 1 – CNS/ATM concept
1. CNS/ATM CONCEPT
- 17 -
1 – CNS/ATM concept Getting to grips with FANS – Part I – Issue III
Airlines rapidly acknowledged benefits from such a concept and requested for an
operational system without waiting for all the required components of the concept
(i.e. new ATN network). Consequently, based on the existing ACARS network,
aircraft manufacturers proposed first FANS capable aircraft in mid 1990’s.
FANS operations in oceanic and remote areas are intended to cope with poor
reliability of HF communications and with shortage of radar coverage. FANS
operations in high density airspaces aim at reducing congestion encountered in
voice channels for routine ATC communications. Nevertheless, FANS operations
aim at making communication safer in both environments.
Numerous actors play in this global end-to-end concept, which can be seen as a
chain linking a pilot and a controller. Although most of these actors are
independent entities (e.g. Air Traffic Services organisations, communication
service providers or ATC) the proper interoperability of all of them is the key
factor for the right operation of the system.
3
Wherever mentioned, A320 refers to the A320 family.
- 18 -
Getting to grips with FANS – Part I – Issue III 1 – CNS/ATM concept
Navigation Space
Communication
satellites (GNSS)
satellites (SATCOM)
Air
Ground-based Radio
(VHF & HF) Ground
SATCOM Transponder
Ground Network for
Data Communications
Differential
GNSS
1.3. COMMUNICATION
Operationally speaking, the biggest change provided by FANS is the way pilot and
controllers communicate. In addition to the classical VHF and HF voice, and to the
more recent satellite voice, digital CPDLC (Controller Pilot Data Link
Communications) expands the set the communication means between pilots and
controllers.
Ground-ground communications are also part of the concept. They serve to link
and to co-ordinate in between different ATC service organisations (or services of
the same ATC) and AOC (Airline Operational Centre). AFTN, voice or AIDC (ATS
Interfacility Data Communications) ensure these communications.
Under commercial and financial pressures, the airlines have asked for FANS
benefits without waiting for complete availability of all the appropriate tools (such
- 19 -
1 – CNS/ATM concept Getting to grips with FANS – Part I – Issue III
1.4. NAVIGATION
To fully benefit from the CNS/ATM concept, aircraft will need to attain a certain
level of navigation performance in terms of accuracy, availability, integrity and
service continuity. Required Navigation Performance (RNP) is a navigation
element, which is expected to affect currently existing airspace structures and
lead to a whole new concept in air navigation. Another modern navigation trend
involves the development of instrument procedures that are not based on
conventional radio Navaids. This type of navigation is called Area Navigation or
RNAV. It can be used En-route, in association with the RNP concept, but also for
terminal area navigation and instrument approach procedures.
Refer to the “Getting to grips with modern navigation” document for detailed
explanations.
1.5. SURVEILLANCE
Different types of surveillance may be found. Wherever radar coverage is
possible, SSR modes A and C are still used. Mode S is used in such areas where
traffic densities are high enough to warrant it.
- 20 -
Getting to grips with FANS – Part I – Issue III 1 – CNS/ATM concept
- 21 -
Getting to grips with FANS – Part I – Issue III
- 22 -
Getting to grips with FANS – Part I – Issue III 2 – CNS/ATM implementation
2. CNS/ATM IMPLEMENTATION
2.1 Introduction 24
2.2 FANS 1/A standards for oceanic and remote areas 26
2.3 ATN Baseline 1 standards for continental areas 26
2.3.1 Eurocontrol Link 2000+ program 26
2.3.2 FAA CPDLC Build 1A program 27
2.4 Accommodation of standards 27
2.5 AIRBUS products 28
- 23 -
2 – CNS/ATM implementation Getting to grips with FANS – Part I – Issue III
2.1. INTRODUCTION
The standards for the first implementation of the ICAO CNS/ATM concept are
known as ICAO CNS/ATM Package 1. The first step is known as ATN Baseline 1,
which has been operational since the end of 2006. The objectives of this concept
are an airspace capacity increase coupled with an operational efficiency
enhancement. Naturally, the continued air traffic safety has to be maintained. To
these ends, the implementation of the ICAO CNS/ATM concept will affect the Air
Traffic Control procedures by improving voice communications and generalizing
data communications and satellite-based navigation.
This is for a worldwide network. Historically, data link has been operational in
oceanic and remote areas first with FANS 1/A 4 standards through the existing
ACARS network. FANS 1/A standards are highly inspired from ICAO concept but
does not comply the entire ICAO specifications. Indeed, FANS 1/A standards
utilise ACARS network that is less efficient than the new ATN. Therefore, in order
to offset ACARS weaknesses, a specific communication protocol called ARINC 622
has been implemented.
The entry in operation of the ATN all over the world is planned in successive
steps. The initial step consists in trials in some areas. The following steps will
intent to deploy FANS operations based on ATN on other areas.
FANS operations started first in oceanic and remote areas as the FANS technology
based on satellites enabled to cope with the drawbacks of HF communications and
position reports. At that time, only the ACARS network was able to fulfil the FANS
requirements; ACARS weaknesses were accommodated thanks to ARINC 622
protocol. Feasibility studies on FANS operations over ATN are now completed. The
saturation of high-density airspaces led to the implementation of FANS technology
over ATN in these airspaces to augment their capacity. Therefore, FANS
operations over ACARS network are performed in oceanic and remote areas (FANS
1/A standards), and FANS operations over ATN in high-density continental areas
(ATN Baseline 1 standards). The following sections provide some details about
each type of standards.
The following figures identify the FIRs where data link is operated for ATC
purposes.
4
FANS 1 was developed by Boeing and FANS A by AIRBUS. The two systems have been harmonised
under FANS 1/A standards.
- 24 -
Getting to grips with FANS – Part I – Issue III 2 – CNS/ATM implementation
Figure 2-1
FIRs using FANS in the world as of April 2005
Figure 2-2
ATN area in Europe as in 2006 (left) and in 2011 (right)
After a phased implementation, the ATN area as in 2011 should cover the
European airspace (in green). Traffic forecasts are in red.
- 25 -
2 – CNS/ATM implementation Getting to grips with FANS – Part I – Issue III
At the beginning, the FANS 1/A was incomplete until the GPS became a certified
primary navigation mean. Indeed, only communication and surveillance functions
were granted via the CPDLC and ADS applications.
Since late 2004, initial trials have been conducted in high-density continental
airspaces for first FANS operations based on ATN. FANS operations are supposed
to alleviate congested voice channels in these airspaces. These trials have been
performed in Maastricht (The Netherlands) within the LINK 2000+ programme
and in Miami (USA) within the CPDLC Build 1A programme. By the beginning of
2007, first airlines are expected to fly routinely over Maastricht with ATN.
For a harmonized entry into services of both ATC centres and aircraft, a
progressive roadmap split into three phases has been drawn.
- 26 -
Getting to grips with FANS – Part I – Issue III 2 – CNS/ATM implementation
Please refer to Chapter B7 of Part III for more details. Also refer to
http://www.eurocontrol.int/link2000/public/subsite_homepage/homepage.html.
Unfortunately, since 2001, due to budget reallocation, the FAA CPDLC programme
has been frozen.
The most probable scenario is a long haul aircraft, equipped with FANS 1/A
package, coming from a FANS 1/A airspace and entering an ATN airspace. The
accommodation will allow such an aircraft to continue data link operations until
the reversion to voice communications for the termination of the flight.
- 27 -
2 – CNS/ATM implementation Getting to grips with FANS – Part I – Issue III
Please refer to chapter 7 of Part II or Part III for the use of FANS A and
respectively FANS B in the world.
Figure 2-3
AIRBUS FANS packages by environment
- 28 -
Getting to grips with FANS – Part I – Issue III 2 – CNS/ATM implementation
Historically, data link has been operational in oceanic and remote areas first with
FANS 1/A standards through the existing ACARS network. FANS 1/A standards are
highly inspired from ICAO concept but does not comply the entire ICAO
specifications. Indeed, FANS 1/A standards utilise ACARS network that is less
efficient than the new ATN.
The entry in operation of the ATN all over the world is planned in successive
steps. The initial step consists in trials in some areas. The following steps will
intent to deploy FANS operations based on ATN on other areas.
- 29 -
2 – CNS/ATM implementation Getting to grips with FANS – Part I – Issue III
Accommodation of standards
In order not to loose investments made on systems compliant with FANS 1/A
standards while ATN is deploying, studies to adapt one standard (i.e. FANS 1/A or
ATN Baseline 1) to another (i.e. ATN Baseline 1 or FANS 1/A) are in progress.
Such adaptations are called accommodation.
Definition of accommodation principles is in progress. However, until a complete
definition of accommodation principles, the accommodation of standards will not
be detailed further in the present document.
AIRBUS products
• In oceanic and remote areas : FANS A package over ACARS network
(FANS 1/A standards) for A320, A330/A340 and A380 aircraft.
• In high density continental areas : FANS B package over ATN (ATN
Baseline 1 standards) for A320 aircraft.
- 30 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
- 31 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
- 32 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
The FANS A data link architecture on A330/A340 aircraft is given in Figure 3-1
(except the ATSU component, this architecture is fully applicable to the A380) It is
made of the following components:
• The airborne part, with the ATSU for A320 and A330/A340 aircraft, which
is a modular hosting platform that centralises all data communications (ATC
and AOC) and manages the dedicated Human Machine Interface (HMI). For
A380 aircraft, the airborne part is composed of the ATC applications for the
management of ATC data link functions, and of the Avionics Communication
Router (ACR) for the management of data communications.
• The air/ground data link (VDL modeA/2, SATCOM or HFDL) is used to
transmit AOC or ATC data to the ground.
• The ground/ground data link, which ensure the connection to the ground
part through either :
- Satellite Ground Earth Stations (GES) whenever VHF coverage is not
available
- VHF and HF Remote Ground Stations (RGS) if within the line of sight of
the aircraft
- Air-Ground processors, which route and handle the messages
- 33 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
ATSU
ACARS networks
Airline Air
Operations Traffic
Control Control
Figure 3-1
FANS A architecture
AOC (optional)
ATSU
ATC
SATCOM
ground station
VDL Mode A VDL Mode 2 HFDL VDL Mode 2
ground station ground station ground station ground station
Airline Air
Operations Traffic
Control Control
Figure 3-2
FANS B architecture
- 34 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
The aircraft’s ATSU still manages the data communications for either ATC or AOC,
as per FANS A architecture. However, only VDL mode 2 is used to transmit ATC
data to the ground through ATN.
- 35 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
This solution is known as the VDL-2/AOA (AOA: ACARS over AVLC: Aviation VHF
Link Control). It is intended to cover the gap between the current ACARS system
and the ATN capabilities.
Compared to the ATSU data link capabilities through the ACARS networks with
VDL mode A, the VDL-2 increases the rate of data transmission from 2.4Kbits per
second to 31.5Kbits per second.
3.3.1.2. SATCOM
Until SATCOM, radio-communications suffered from VHF line-of-sight limitations
along with the unreliability and variable quality of HF. Satellite links overcome
these weaknesses, being unaffected by distance or ionospheric conditions.
SATCOM are thus playing a major role in the implementation of ICAO’s CNS/ATM
concept for Air Traffic Control in the 21st century, supporting both ADS and
CPDLC applications over the oceanic and remote areas.
- 36 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
"Supplementary" means that the certification process authorises the use of HFDL
provided that VDL and SATCOM are installed. During the certification process, the
demonstration of data link performances including HFDL (measurement of
message transit time between end users) was not performed for environments
such as polar areas. Nevertheless, in an inbound flight from the North Pole to
Edmonton for instance, the use of HFDL for data link operations is possible. In
such a case, the operator should notice that HFDL performances, even better than
HF voice ones, are not as good as VDL or SATCOM data link ones. Thus, messages
transmitted by HFDL may take much more time to reach the addressee than via
VDL or SATCOM. Some messages may even be lost.
If the airline elects to use HFDL outside SATCOM coverage, the airline
operates outside the approved certification framework of FANS A+. The
airline shall submit its choice to its approval authority.
HFDL allows data transmission at a rate of 1.8 Kbits per second. Today, ARINC is
the only DSP providing HFDL. The proposed coverage is worldwide (Refer to
Appendix C of Part II).
Both ARINC and SITA networks operate with national service providers and are
currently interconnected to provide a global interoperability of ATS data link
applications. This means for instance, that an aircraft using a VHF data link under
a SITA agreement can nevertheless operate in a FANS ATC area using an ARINC
contract (refer to 3.3.2.2 – The interoperability of the networks).
- 37 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
Whenever there is a switching for instance from VHF to SATCOM (or vice versa,
ACARS environments only), the ATSU sends a Medium Advisory (MA) message to
the DSP indicating the status of the communications with each medium. Such an
automatic function is needed to fulfil the logic that determines the routing of any
uplink message. It is transparent to both the pilot and the controller and ensures
that uplink messages can be sent to the aircraft irrespective of the medium or
communications service providers used.
Network
Interoperability
ATC 1 ATC 2
ARINC communication domain SITA communication domain
Figure 3-3
ACARS network interoperability
- 38 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
• ATN network
The same kind of feature is provided for ATN in order to ensure a seamless data
link connection with the ground. However, in the LINK 2000+ airspaces, VDL
mode 2 is the unique medium used for ATC data link purposes. ARINC and SITA
are the main DSPs.
At the time of writing the document, UAC Maastricht is the single ATC centre
providing data link ATS services. UAC Maastricht contracted ARINC to provide VLD
mode 2 links with aircraft. Aircraft of airlines, which contracted SITA as their DSP,
will be available to connect to UAC Maastricht thanks to the inter-connection
between ARINC and SITA. The following figure illustrates a possible extension
model of the network.
Network
Interoperability
- 39 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
same purposes, LINK 2000+ areas implement a variant of AIDC called the On-
Line Data Interchange (OLDI). This is not an aircraft issue.
To that end, AIRBUS has proposeds the FANS B package since the end of 2006.
- 40 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
FANS A data link is provided by three main applications (AFN, CPDLC and ADS).
For FANS B data link, the notion of service is introduced. A service is intended to
fulfil an operational need (ATC or flight crew) and is based on several applications.
For the first implementation of ATN (ATN Baseline 1), two applications (CM and
CPDLC) are used and support four services (DLIC, ACL, ACM and AMC).
The following sections describe applications and services (if applicable) related to
each environment.
The flight crew initiates an AFN notification to make the aircraft data link
capability and characteristics to the ATC. Whenever there is no automatic transfer
of control from one ATC centre to another, the active ATC centre may request the
flight crew to perform a notification procedure to the next ATC centre.
- 41 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
part of the world), and became very convenient to alleviate congested VHF of
some dense continental airspaces when utilised for routine dialogue (e.g.
frequency transfer).
CPDLC allows flight crew and controllers to communicate via data link thanks to
written messages composed of one or several elements chosen in a set of
internationally agreed preformatted elements. Those elements are in line with the
existing ICAO voice phraseology and can be used for clearances, requests,
reports, negotiations and other kinds of dialog with ATC (e.g. emergency
messages, ATC transfer, frequency changes...).
Appendix A of Part II lists all the messages (around 180) that are supported by
FANS A and FANS A+ airborne and ground systems.
The following points however must be well understood and will have to be
underlined in training:
• Handling of CPDLC messages requires time:
- Reading and interpreting a written clearance was found to be less
immediate than hearing the same one
- Preparing and sending a request through the combination of the MCDU
and DCDU is longer than directly using the microphone.
• The party line is lost (the pilot can no longer listen to the surrounding
transmissions).
- 42 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
The present document only deals with ADS-Contract as part of data link
applications. A new brochure dedicated to surveillance aspects of the CNS/ATM
concept will be released soon. More details on ADS-Broadcast will be provided in
this brochure. The goal of this section is to help the reader in differentiating ADS-
Contract and ADS-Broadcast.
The reader may found the term Centralized ADS (CADS). It is a service
provided by ARINC or SITA for ATS providers or airlines that wish to benefit from
ADS-C application without investing in ADS-C equipment. ADS-C connections are
ensured via a CADS server. This server translates any received ADS-C reports in
standard text format and relays them to ATS centres via AFTN. ADS-C reports can
also be forwarded to airline servers via a specific ARINC service.
Considering the range of ADS-C and ADS-B, they are expected to complement
each other for a complete coverage during a transoceanic flight for instance.
When the aircraft is out of VHF coverage, ADS-C makes the link between the
aircraft and the ATC centre. When in VHF coverage, ADS-B makes the link with
any ATC centres or aircraft in the vicinity, equipped with an ADS-B receiver.
Except when explicitly specified, ADS stands for ADS-Contract for the rest
of the document.
5
ADS-C is part of AIRBUS FANS A and FANS A+ packages on A320/A330/A340/A380 aircraft.
- 43 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
This is done automatically and remains transparent to the crew. These are air-
ground downlink messages.
In the FANS A system, the ADS is based on these contracts, which are set by the
ATC centres to satisfy their operational needs for surveillance, as dictated by
circumstances (e.g. traffic density). The crew cannot modify these contracts, but
the controller can. And so can he specify the parameters of the contract. Optional
data groups may thus be added in the contract request. Obviously, at any ATC
centre, only one contract may exist at any time, and whenever the controller
makes a modification, a new contract is set, which cancels the previous one.
Another type of contract may be found: the emergency mode. When the crew
activates this mode, an emergency report is sent to any ATC centre which has an
ADS contract with the aircraft. The emergency report is sent at the same rate of
the current active periodic contract if any, otherwise it is sent every 64 seconds.
Appendix B of Part II lists the various elements and groups of data of the ADS-C
reports, and provides some details on the different contracts.
Based on these contracts, directly addressed between an ATC centre and a given
aircraft, ADS is then usually called ADS-C (where C stands for Contract), or ADS-A
(where A stands for Addressed). Both these designations are equivalent.
ADS-B enables pilots and air traffic controllers to get a more precise image of the
traffic thanks to enriched data compared to SSR data. Once the broadcasted data
are collected, they are displayed in the cockpit on the Cockpit Display of Traffic
Information (CDTI). On AIRBUS aircraft, CDTI information is displayed on ND.
Unlike SSR, ADS-B works also at low altitudes and on ground. In addition, any
vehicle equipped with a Mode S emitter can be “seen” by any vehicle equipped
with a Mode S receiver, provided the emitter is in the range of the receiver.
For safety reasons, ADS-B can be used on ground only if the Airport Navigation
application is available on board. Indeed, the position and the heading of a
surrounding aircraft are rightly interpreted only if they are related to the map of
the airport (e.g. runways, taxiways).
- 44 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
Figure 3-5
CDTI information displayed on ND
- 45 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
The CM Application supports the DLIC (Data-Link Initiation Capability) Air Traffic
Service.
- 46 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
- 47 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
Primary if aircraft
CPDLC Supplementary
equipped
- 48 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
AFN CM
CPDLC CPDLC
ADS-C No equivalence
These constitute a major difference between ATN Baseline 1 and FANS 1/A.
Indeed, these acknowledgements do not address to the same recipient. Besides,
the MAS function is required whereas LACK function is not. European airspaces
implement the LACK function whereas US airspaces seem not (since the FAA
CPDLC Build 1A programme is frozen at the time of writing the present document,
the final implementation is not known).
In FANS 1/A environment, the MAS is the notification by the Data link Service
Provider (DSP) to the ATC centre that the uplink message has been acknowledged
or not by the airborne system. The MAS function is provided for uplink messages
only. Refer to Figure 3-6.
6
One ‘E’ is omitted due to space restrictions imposed by the interface.
- 49 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
ATSU
ATC HMI
Uplink message
ACK
MAS
Downlink message
ACK
ACARS Network
Airborne
ATC centre
HMI
Figure 3-6
Technical acknowledgement in ACARS environment
ATSU
ATC HMI
Uplink message
LACK
Downlink message
LACK
ATN network
Airborne
ATC centre
HMI
Figure 3-7
Technical acknowledgement in ATN environment
- 50 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
At the time when FANS A and FANS A+ systems were certified on A330/A340
aircraft, FANS 1/A standards did not require ATC centres to provide the time
stamp in message header. Actually, a very few ATC centres do not provide the
time stamp.
However, it has been observed that more and more ATC centres are equipped
with systems able to provide the time stamp, and do provide the time stamp in
uplink messages.
For ATN Baseline 1 ATC centres, time stamp is mandatory. Consequently, FANS B
interface on A320 aircraft displays permanently the time stamp for uplink
messages.
3.6.5. TIMERS
In ATN environment, to avoid any everlasting data link dialogue, timers are
implemented. That is why time stamps are required in such environment.
7
This value is valid for the LINK 2000+ Pioneer phase. For post Pioneer phase, this value may change.
Hence, the timer will be accordingly updated in a subsequent FANS B package.
- 51 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
Besides, the operational response referencing the message that has been sent is
also discarded. It means that if the flight crew sends a message to the ATC and if
the LACK is not received within 20 seconds, the ATC response, if any, to the
message will not be displayed to the flight crew.
As per ATN Baseline 1 standards, the value of the message latency timer should
vary according to various connection conditions. Under certain circumstances, the
timer value should be 21.6 seconds.
On one hand, the LINK 2000+ programme elected to a fixed value of 21.6
seconds for its Pioneer phase. On the other hand, AIRBUS elected to a fixed value
of 60 seconds for the FANS B package. This FANS B deviation is known and
accepted by Certification authorities. The AIRBUS policy was to avoid too many
messages to be rejected due to a too much restrictive timer.
In FANS B package, if the receipt time of a message reveals a difference with its
timestamp greater than the message latency timer, the message is discarded (i.e.
not displayed on DCDU).
As a data link dialogue involves two end users, two operational timers are
defined:
• Operational timer – Sender,
• Operational timer – Responder.
- 52 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
According to whether the air traffic controller or the flight crew sends the
message, operational timer values vary.
If STAND BY is answered, all the operational timers (Sender and Responder) are
reset.
Message
TLACK = 20 s
LACK
TSENDER = 270 s TRESP = 250 s
Response
TLACK = 20 s
LACK
Figure 3-8
Operational timer values – Dialogue initiated by the flight crew
If STAND BY is answered, then all operational timers (Sender and Responder) are
reset. The STAND BY function can be triggered only once.
- 53 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
Message
TLACK = 20 s
LACK
TRESP = 100 s TSENDER = 120 s
Response
TLACK = 20 s
LACK
Figure 3-9
Operational timer values – Dialogue initiated by the ATC
Notice that 100 seconds are quite a short period of time to read the
message, to interpret it, to check the aircraft parameters and to prepare
the response, especially if a voice read-back has to be performed.
3.7. ACCOMMODATION
In order not to loose investments made on systems compliant with FANS 1/A
standards while ATN is deploying, studies to adapt one standard (i.e. FANS 1/A or
ATN Baseline 1) to another (i.e. ATN Baseline 1 or FANS 1/A) are in progress.
Such adaptations are called accommodation.
- 54 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
The FANS A+ system is able to discard any uplink messages received after the
operational timer – Sender times out. For instance, an A330/A340 aircraft
equipped with a FANS A+ system flying over an ATN airspace, will discard a uplink
message received more than 120 seconds after its sending. For more details, refer
to the description of Max Uplink Delay in Chapter A6 of Part II.
- 55 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
… on which aircraft …
A320 A330/A340 A380
environment?
… for which
Oceanic and Oceanic and
FANS A+ * Oceanic and remote
remote remote
FANS B Continental
Note 1 : Combination of FANS A and FANS B packages on the same aircraft is not
available.
Note 2 : FANS A was the first package proposed in oceanic and remote areas
since July 2000. Since the FANS A+ package was certified in April 2004, the
FANS A package is not proposed anymore on brand new AIRBUS aircraft.
Through these applications, oceanic and departure clearances and ATIS report,
which are usually received via voice channel (either from ATC or broadcasted),
are received in a text format.
- 56 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
6.3.1.5.1 From 1 January 2007, all aeroplanes which utilize data link
communications and are required to carry a CVR shall record on a flight
recorder, all data link communications to and from the aeroplane. The
minimum recording duration shall be equal to the duration of the CVR, and
shall be correlated to the recorded cockpit audio.
Note.— Data link communications include, but are not limited to, automatic
dependent surveillance (ADS), controller-pilot data link communications
(CPDLC), data linkflight information services (D-FIS) and aeronautical
operational control (AOC) messages.
As to comply with the constraints imposed by the JAA rulemaking process and by
the industry, the European JAA proposed :
• To delay the introduction of the data link requirements for new aeroplanes
to at least 1 January 2008.
• To delay the introduction of the data link requirements for aeroplanes first
type certificated before 1 January 2008 and first issued with an individual
certificate of airworthiness on or after 1 January 2010, to at least 1 January
2010.
The goal is to postpone the applicability dates for the forward fit and to evaluate
later the retrofit impact considering the high costs implied by retrofits.
Therefore, the NPA-OPS 48 is split into two parts : NPA-OPS 48A (release date :
01 June 06) for forward fit and Advance-NPA-OPS 48B for retrofit. The
harmonisation of the NAP-OPS 48A with the FAA NPRM on FDR requirements is in
progress.
- 57 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
If your airline is not submitted to European regulations, please refer to your local
authority.
They all address the functionality and performance of the system for their relevant
aspect and may be defined in terms of availability, accuracy and integrity. Each of
these three performance requirements is independent of the technologies used to
ensure either of the three Navigation, Communications or Surveillance functions.
It is now commonly agreed upon that the prime parameter in assessing the
technical performance of the communications, is the delay experienced by the
exchange of data between the end users (e.g. pilot / controller).
According to the latest work of the RTCA/EUROCAE groups, the following terms
have been defined to characterise the RCP statement:
• Delay : is a measure of the time required for an information element to
transit between two identifiable points.
• Integrity : is expressed as the probability of an undetected system-
induced failure of message transmission (i.e. undetected message error,
wrong address, lost message transmission).
• Availability : is the ratio of actual operating time to specified operating
time.
- 58 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
Each aircraft operating in RNP airspace shall have a total system navigation
position error equal to, or less than, the RNP value for 95 % of the flight
time.
The RNP concept together with the FANS A navigation capabilities of the AIRBUS
aircraft are fully described in the "Getting to grips with modern navigation"
brochure.
Remark : Over North Atlantic, MNPS airspace has been defined before the RNP
concept. It is assumed that MNPS is equivalent to RNP11.
Containment
2X
Accuracy limit
X (RNP value)
Desired Flight Path
X
Accuracy limit
2X
Containment
Figure 3-10
RNP concept
- 59 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
FANS A applications
• ATS Facility Notification (AFN)
Through this application, an ATC knows whether an aircraft is capable of using
data link communications. This exchange of the data link context is needed prior
to any CPDLC or ADS-C connection.
• Controller Pilot Data Link Communications (CPDLC)
CPDLC is a powerful tool to sustain data link communications between a pilot and
the controller of the relevant flight region.
It is particularly adapted to such areas where voice communications are difficult
(e.g. HF voice over oceans or remote part of the world), and is expected to
become very convenient to alleviate congested VHF of some busy TMAs when
utilised for routine dialogue (e.g. frequency transfer).
• Automatic Dependent Surveillance (ADS)
ADS-Contract is an end-to-end application that uses data link as CPDLC. ADS-C
application is hosted by ATSU.
Through the ADS-C application, the ATSU automatically sends aircraft surveillance
data to the connected ATC centres (up to 4). This is done automatically and
remains transparent to the crew.
Different types of ADS "contracts" exist: periodic, on demand and on event.
- 60 -
Getting to grips with FANS – Part I – Issue III 3 – CNS/ATM component description
FANS B applications
• Context Management (CM)
This application provides the Data Link Initiation Capability (DLIC) service,
which is similar to the FANS A AFN application and remains mandatory prior to
any CPDLC connection.
• Controller Pilot Data Link Communications (CPDLC)
It is an application similar to the FANS A CPDLC application and is restricted to
non-time critical situations.
Three services are provided : the ATC Clearance (ACL) to communicate, the
ATC Communication Management (ACM) service to manage the centre
transfers, and the ATC Microphone Check (AMC) to check that the voice
frequency is not blocked.
Thanks to the LACK, the end user (pilot or controller) knows when the message is
displayed on the recipient’s screen. In addition, the introduction of operational
timers imposes to answer a message in a timely manner.
Accommodation
The accommodation allows a seamless transition between ACARS and ATN
environments with potential savings on equipment. At the time of writing the
document, the accommodation principles were not clearly defined. However, the
FANS A+ package anticipates the accommodation by taking into account the early
assumptions (i.e. max uplink delay).
- 61 -
3 – CNS/ATM component description Getting to grips with FANS – Part I – Issue III
FANS B Continental
Performance Requirements
The three concepts of Required Navigation Performance (RNP), Required
Communications Performance (RCP) and Required Surveillance Performance (RSP)
are all parts of a general CNS/ATM performance concept and independent of the
technologies used.
- 62 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
- 63 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
- 64 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
Implementing the latest technologies, which are now available to support these
awaited changes, cannot be done without the involvement of numerous parties.
States, ATS, communications service providers are affected in the same way as
airlines, aircraft manufacturers or avionics equipment manufacturers.
That is why the CNS-ATM concept can only be developed regionally or even on a
route-by-route basis. FANS A routes have been regionally opened in the Pacific
area, in the North Atlantic, in the Bay of Bengal and so on.
The AIRBUS forecast for future CNS-ATM implementation envisions two main
phases :
• On a short term basis (2007- 2011), ICAO SARPS 8 compliant ATN
development should allow FANS B to regionally, thus enabling a full-
performance data link. The potential economic benefits however, lie mainly
in the high traffic density areas for which FANS B is designed. The ADS-B is
expected to come into service during this period.
• On a long term basis (starting around 2015), a generalisation of FANS B
is expected, since the search for the best economic benefits and the
tremendous increase of traffic should then lead to a world-wide
generalisation of this concept.
8
The SARPs are international “Standards And Recommended Practices” published by ICAO. National
aeronautical regulations of countries member of ICAO shall comply with the content of these SARPS.
- 65 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
2015
FANS B
High density
2007
airspace
FANS B C & S: Over ATN and
High Density airspaces ADS-B
2000 C: Over ATN N: Extended Satellite.
FANS A S: Over ADS-B Nav.-based
Oceanic/Remote N: GNSS/RNP (GNSS)/RNP
airspaces - Low density ATM: Air Traffic Control ATM: Air Traffic
1998 C & S: ATC/AOC First implementation of Management using
Pre-FANS data link over ACARS FANS B ICAO standards
Airline Data link N: GPS-based
C: AOC by ACARS ATM: Air Traffic
N: Classical means Control Procedures Extension of FANSB
S: Transponder enhancement to other high density areas
ATM: Air Traffic
Control procedures Ground accommodation of FANS A legacy
Figure 4-1
AIRBUS view of CNS/ATM implementation
It is considered that FANS A, FANS B and non-FANS environments will co-exist for
many years. The aircraft's ability to go seamlessly from one environment to
another is a fundamental asset, which was one of the prime design objectives of
the AIRBUS architecture.
Longer term philosophy aiming at defining whether or not and to which extent,
the crew will be responsible for their own separation is beyond the scope of the
aircraft manufacturers alone.
But flexibility requires computer power. This was tackled right from the beginning
with the AIRBUS FANS avionics package (for either A320/A330/A340 aircraft or
A380) : the power and flexibility of a dedicated communications unit (the ATSU
for A320/A330/A340 aircraft, and ATC applications for A380) combined with the
power of a new FMS.
- 66 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
Figure 4-2
A320/A330/A340 FANS architecture
- 67 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
Part of this, is the management of all the messages (up/down link) whatever their
types (ATC clearance, ADS, pilot requests, AOC, flight information). Today's
ACARS functions are included in the ATSU. There is no longer a need for an
ACARS management unit.
In the frame of FANS A and B, only one ATSU is used. But for later steps, two
ATSUs can be installed, dealing with all the expected evolutions, as aircraft
operation and safety become more dependent on data link communications.
The ATSU is a hosting platform, which has been designed so as to take provision
of all foreseen evolutions. This modularity concept for both software and hardware
permits to ease a quick and dependable introduction of all the ATC data link
capability during the transition to the ultimate full FANS.
Figure 4-3
ATSU architecture for FANS A package
- 68 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
Figure 4-4
ATSU architecture for FANS B package
The FMS 9 is a key element of the AIRBUS FANS system for which it ensures three
main functions:
• It provides data to the ATSU.
• It monitors the ATC messages and their subsequent implications.
• It handles and processes some of the ATC messages.
The FMS can first be seen as a data provider for both ADS and CPDLC messages.
As such, it periodically sends all the ADS parameters, whether for the basic group
(position, altitude, cross track...), the predicted route frame or the intent group.
The predicted position, altitude, speed or sequencing time for up to the next 2
waypoints of the flight plan are thus sent by the FMS to the ADS application of the
ATSU.
Position reports messages whether for manual CPDLC messages or for automatic
ADS are processed by the FMS.
9
In the frame of the first release of the FANS B package, the interface between ATSU anf FMS is
limited. The FMS only provides the ATSU with the flight number, the departure and destination airports,
and the aircraft position.
- 69 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
The FMS monitors the ATC conditional or deferred clearances that are linked to
the navigation (e.g. "AT ALCOA CLIMB TO AND MAINTAIN FL 350"). It triggers the
signal to warn the pilot of the completion of the clearance.
Route requests or route clearances are processed by the FMS. Once prepared in
the secondary F-PLN, a route request is sent by the FMS to the ATSU/DCDU prior
to being sent. Similarly, once a route clearance (or a re-route proposed by the
AOC) is received, it is loaded into the FMS, which acknowledges or rejects this
new routing. The reasons for a rejection (for instance proposed waypoint not in
database) are indicated to the pilots so that they can solve the issue. Co-
ordination and exchange of F-PLN between ATC, AOC and the aircraft is processed
with the FMS.
The two DCDUs are located in the main deck, just above each MCDU. The retained
principles for an operational use of the DCDU are described in the following
chapter.
In addition to the DCDU, the MCDU is mainly used to prepare a request. Once
ready, the request is transferred to the DCDU for sending.
Any ATC message can also be printed on the printer, at any time.
The Human Factors considerations were particularly addressed all along the
development of this interface. From the initial capture of the operational needs at
the very beginning of the design phase, to the operational flight test evaluation
and certification, numerous pilots from various origins such as flight test, training
instructors and airline pilots, were involved in the definition of this interface. The
whole Human Factors plan, as defined and presented to the airworthiness
authorities, was also applied.
- 70 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
Figure 4-5
A320/A330/A340 FANS Human Machine Interfaces
The retained interface, with the two DCDUs in the core part of the cockpit,
provides for a minimum perturbation of the existing procedures. This allows for a
simple reversion to backup voice-based procedures when needed.
Colour coding and/or reverse video on the DCDU have been used to differentiate
between titles, text, main parameters in the text, uplink or downlink messages.
- 71 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
The DCDU provides for full time accessibility and readability for both crew, which
requires only limited head-down time.
Current
Brightness message
key Print key
Message Page
Slew key Slew key
Information
Field
Function Function
keys keys
Figure 4-6
Data link Control and Display Unit (DCDU)
Note: The audio sound is similar to an old telephone sound. It was elected by a
great majority of the consulted pilots.
To reply to a message, the flight crew either uses the standard replies on the
DCDU or composes a reply on a menu-page from the MCDU. After composing the
message on the MCDU it is transferred to the DCDU for sending (refer to
operational scenarios in appendices of Part II or III).
- 72 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
4.3.2.1. DCDU
• The two DCDUs are the compulsory data link communications focal point
for either type of messages (up or down link).
• Both DCDUs are identical and synchronised. Any operation on either DCDU
is valid for both of them, and both DCDUs show the same display.
4.3.2.2. MCDU
• The MCDUs are also part of the ATS data link system. They are used to
prepare downlink messages such as requests or free texts. They also
provide for an access to the file of the stored messages.
• The "ATC COMM" key of the MCDU gives access to the various pages of the
ATS data link system (this key is optional while retrofitting FANS B on A320
aircraft equipped with Legacy FMS).
4.3.2.3. ALERT
• The alert function is triggered each time a new uplink message arrives or
whenever a deferred report or clearance expires.
• Both ATC MSG pushbuttons on the glare shield flash until a positive action
of the crew (either by pressing one of the pushbuttons or by answering the
uplinked message on the DCDU) is done to stop the alert.
• The specific ATC audio sound may also be activated (5 sec or 15 sec delay
according to the urgency of the message).
4.3.2.4. MESSAGES
• As soon as the alert is triggered, the associated ATC message may be
accessed and viewed on both DCDUs. It is automatically displayed (whether
the screens of the DCDUs are free or not) if it is an urgent or distress
message.
• Request messages can be brought to the DCDU as soon as the crew has
activated the corresponding command (ATC REQ DISPL on FANS A, or ATC
MSG DISPL on FANS A+, improved as XFR TO DCDU on FANS B).
- 73 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
• Pending messages can be brought (one at a time) to the DCDU by the crew
who can review them in the order they want.
• The crew can (and is recommended to do so) clean up the DCDU through
the CLOSE key once the displayed message has been entirely treated.
4.3.2.5. PRINTER
• A print function is available on the DCDU to print the currently displayed
message in whole. This can be done at any time.
• The printer is not a certified system as ATSU is. Consequently, the crew
should check that printed messages are consistent with messages displayed
on the screens.
- 74 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
interface will be enriched. Therefore, for the first release of the FANS B
package, there is no interaction between the FMS and DCDUs.
• However, the FMS provides the ATSU with the following parameters for
ATSU initialisation purposes :
- The flight number,
- The departure and destination airports,
- The aircraft position.
• Uplink messages are displayed with the text in WHITE and the main
parameters are highlighted in CYAN.
4.3.2.10. MISCELLANEOUS
• A star. “ * ” in front of a LSK means the key is available. Pressing a LSK
without a star displayed next to it will have no effect.
• New messages coming from the controller are displayed immediately if they
are of the following type ‘Distress’ or ‘Emergency’ or if the message file is
empty. Else they are queued and can be accessed through the ‘MSG+’ and
‘MSG-’ keys on DCDUs).
The flight crew can process (i.e. answer or send) the queued messages in
any order.
- 75 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
MSG 1/4
MSG 2/4
MSG 3/4
MSG 4/4
PGE 1/3
PGE 2/3
PGE 3/3
MSG- PGE-
MSG+ PGE+
Figure 4-7
Management of messages and pages
Any next or previous page of the currently displayed message can be accessed
through the DCDU keys ‘PGE+’ and ‘PGE-’ respectively.
Any next or previous message of the message stack can be accessed through the
DCDU keys ‘MSG+’ and ‘MSG-’ respectively.
Note: Several scenarios are provided in appendices of Part II and III to develop
the handling of both DCDU and MCDU.
- 76 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
The transition to CNS/ATM requires both flexibility and growth capability. For the
airplane, flexibility is the essential requirement, but requires computer power.
This was tackled right from the beginning with the AIRBUS FANS avionics
package: the power and flexibility of a dedicated communications unit (the ATSU,
respectively ATC applications) combined with the power of a new FMS.
- 77 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
The following figure shows a simplified view of the A380 architecture. For a clear
and rapid overview, not all the links are represented. In the same way, not all the
components are represented.
Figure 4-8
A380 FANS architecture
* The clock feeds ATC applications via IOM. Besides, as a back-up, ADIRS
modules directly feed ATC applications if the clock fails to provide time
information. ADIRS modules are also used as back-up if FMS fails to provide flight
parameters.
- 78 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
Onboard the A380, instead of an ATSU, the ATC data link communications are
ensured by the ATC data link applications 10. Considering ATC data link
communications, the ATC data link applications provides the same functions as
the ATSU does :
· To manage the HMI, the display and warnings. It warns the crew of any up-
coming message, displays it, and also sends the appropriate data to the
peripherals
· To sustain the communications tasks (e.g. selection of the appropriate ATC
centre for data link all along the flight).
The routing function has been granted to a dedicated system, as many other
applications require a connection to the ACARS network (e.g. AOC FMS, AOC OIS,
Refuel, E-logbook, etc).
Whenever mentioned in the three parts of this document and except when
specified, the term “ATC applications” refers to the on-board system in
charge of ATC data links as described in this section.
The ATC mailbox is located in the main deck, just below the permanent data. The
retained principles for an operational use of the mailbox are described in the
following chapter.
In addition to the ATC mailbox, the MFD ATC pages isare mainly used to prepare a
request. Once ready, the request is transferred to the mailbox for sending. Pages
related to FANS functions on MFD can be directly displayed thanks to the ATC
COM shortcut located on KCCU.
Any ATC message can also be printed on the printer, at any time.
10
The AOC communications managed by ATSU on A320/A330/A340 aircraft are shifted to the Avionics
domain of the NSS/OIS.
- 79 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
Figure 4-9
A380 FANS Human Machine Interfaces
The figure above gives an overview of the A380 cockpit with the main elements of
the FANS interfaces.
As for A320/A330/A340 interfaces, a Human Factor process had been applied all
along the design. The centralized mailbox ensures that both pilots read the same
thing, and as DCDU the mailbox is permanently visible and then the same
- 80 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
To receive or to send
a message.
To edit a message.
or
or
- 81 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
Message Slew
buttons Function
keys
Page
Information Fields Slew buttons
Figure 4-10
ATC mailbox
* The message time refers to :
• If the ATC centre provides the time stamp, the time when the message had been sent from
the ground.
• If not, a blank field. In this case, an explicit indication is inserted at the end of the message
(e.g. RECEIVED AT 1105Z).
Refer to Chapter A6 of Part II for more details.
- 82 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
4.5.2.2. MFD
• ATC COM pages on MFDs on either side on the ATC mailbox are used to
prepare downlink messages such as requests or free texts. They also
provide for an access to the file of the stored messages.
• The ATC COMM key of the MCDU gives access to the various pages of the
ATS data link system.
4.5.2.3. ALERT
• The alert function is triggered each time a new uplink message arrives or
whenever a deferred report or clearance expires.
• Both ATC MSG pushbuttons on the glare shield flash until a positive action
of the crew (either by pressing one of the pushbuttons or by answering the
uplinked message on the DCDU) is done to stop the alert.
• The specific ATC audio sound may also be activated (5 sec or 15 sec delay
according to the urgency of the message).
4.5.2.4. MESSAGES
• As soon as the alert is triggered, the associated ATC message may be
accessed and viewed on the ATC mailbox. It is automatically displayed
(whether the screen of the ATC mailbox is free or not) if it is a "urgent" or
"distress" message.
• Request messages can be brought to the ATC mailbox as soon as the crew
has activated the corresponding command "XFR TO MAILBOX”.
• The crew can (and is recommended to do so) clean up the ATC mailbox
through a specific function ("CLOSE") once the displayed message has been
entirely treated.
4.5.2.5. PRINTER
• A print function is available on the ATC mailbox to print the currently
displayed message in whole. This can be done at any time.
- 83 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
• Uplink messages are displayed with the text in WHITE and the main
parameters are highlighted in CYAN.
- 84 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
4.5.2.9. MISCELLANEOUS
• New messages coming from the controller are displayed immediately if they
are of the following type ‘Distress’ or ‘Emergency’ or if the message file is
empty. Else they are queued and can be accessed through the message
slew buttons on the ATC mailbox).
The flight crew can process (i.e. answer or send) the queued messages in
any order.
MSG 1/4
MSG 2/4
MSG 3/4
MSG 4/4
PGE 1/3
PGE 2/3
PGE 3/3
MSG
PGE
Figure 4-11
Management of messages and pages
The slew buttons either for messages or pages are displayed only when
necessary.
- 85 -
4 – AIRBUS FANS description Getting to grips with FANS – Part I – Issue III
Any next or previous page for a currently displayed message can be accessed
through the page slew buttons (double arrows on the right side of the ATC
mailbox).
Any next or previous message of the file can be accessed though the message
slew buttons (single arrows on the left side of the ATC mailbox).
- 86 -
Getting to grips with FANS – Part I – Issue III 4 – AIRBUS FANS description
The A380 introduces new technologies. As such, its architecture is different from
the ones on A320 and A330/A340 aircraft. However, the basic operational
principles remain exactly the same.
- 87 -
Getting to grips with FANS – Part I – Issue III
- 88 -
Getting to grips with FANS – Part II – Issue III Table of contents
Abbreviations....................................................................................................................... 5
-A1-
Table of contents Getting to grips with FANS – Part II – Issue III
-A2-
Getting to grips with FANS – Part II – Issue III Table of contents
A8.1. General................................................................................................97
-A3-
Table of contents Getting to grips with FANS – Part II – Issue III
-A4-
Getting to grips with FANS – Part II – Issue III Abbreviations
ABBREVIATIONS
-A5-
Abbreviations Getting to grips with FANS – Part II – Issue III
-A6-
Getting to grips with FANS – Part II – Issue III Abbreviations
-A7-
Abbreviations Getting to grips with FANS – Part II – Issue III
-A8-
Getting to grips with FANS – Part II – Issue III Executive Summary
Pre-flight phase
The CNS/ATM capabilities of the aircraft will be notified when filling in the ICAO
flight plan.
o The data link capability is notified by a letter J to be entered in the field 10.
o The letter D is also entered in the surveillance part of that field, if ADS 1 is
available.
o The other capabilities are given in the field 18 (Other Information) under the
DAT/ information. The following code is used:
- S (Satellite data link), H (HFDL), V (VHF data link), M (SSR Mode S data
link)
Pre-flight checks
Prior to departing for a FANS flight, the crew will check that the required
equipment is operative. The following items are recommended to be included in
those checks :
- GPS availability,
- UTC time settings,
- RNP capability,
- Data link communications availability,
- The initialization of data link systems :
• On the MCDU COMM INIT page for A320 & A330/A340 FANS A
package,
• On the RMP MENU>DATALINK INIT page for A380 FANS A package.
- Airline priority list of contracted DSP for FANS operations with this
aircraft.
When no other CPDLC or ADS connections have been established with a previous
ATC centre, the flight crew must perform an AFN (e.g. prior to departure, between
15 to 45 minutes prior to entering a data link airspace).
1
Whenever mentioned in this part, ADS refers to ADS-Contract. Please refer to Part I for
more details.
-A9-
Executive Summary Getting to grips with FANS – Part II – Issue III
The AFN must be successfully completed prior to any connection (CPDLC or ADS)
is being established.
CPDLC procedures
CPDLC connection
o Once the AFN has been successfully done, the ATC centre can initiate a CPDLC
connection (no flight crew action required).
o Checks are automatically done by the ATSU (respectively ATC applications) to
validate or reject the connection:
- Connection is accepted if no previous connection already exists or, it is
relative to the next data link ATC to control the aircraft.
- Connection is rejected in all other cases.
o Once connection is established, the active connected ATC centre is then
displayed on the DCDU (respectively ATC mailbox), and on the CONNECTION
STATUS page of the MCDU (respectively MFD ATC COM pages).
- A 10 -
Getting to grips with FANS – Part II – Issue III Executive Summary
ADS procedures
ADS connections
o An ATC centre can establish ADS contracts once the AFN has been performed
(AFN required for an initial connection).
o FANS A equipped aircraft can have up to five ADS connections.
o The aircraft has the capability to report to all connected ATC centres
simultaneously using ADS.
o Different types of ADS "contracts" exist:
- Periodic: the data are sent at periodic time intervals.
- On demand : the data are sent only when asked for.
- On event : the data are sent whenever a specified event occurs.
o ADS is transparent to the crew. In particular, contracts can not be modified
from the aircraft. An individual ADS connection may be stopped from the
ground or manually by the crew (FANS A+ only) through the ADS DETAIL page
of the MCDU ATC menu (respectively MFD CONNECTION STATUS page).
o The ADS should not be set to off unless instructed to do so by ATC. If
the ADS is set to off, the ATC centre can no longer be provided with ADS
reports.
o ADS contracts and connections should normally be terminated by the ground
system when the:
- Aircraft has crossed a FIR boundary, or
- Aircraft's flight plan has been cancelled or has finished, or
- Connected ATCs have no further surveillance requirements for the flight.
o A Waypoint will not be sequenced if the position is offset by more than 7NM
on Honeywell FMS2 and 5NM on Thalès FMS2 aside from this point. When
an offset is flown, it is recommended that the crew keeps updated his FMS
flight plan, and that he uses the FMS Offset function.
ADS shutdown
When a shutdown within the ground system occurs, the ATC controller will advise
the crew of the requirements for the position reports (by voice or CPDLC).
ADS emergency
o The emergency mode can be activated either by the pilot or the controller, and
is normally cancelled by the pilot. When selected on the MCDU ATC page
(respectively MFD), the ATSU (respectively ATC applications) immediately
sends a report to all ATC centres that currently have contracts established with
the aircraft.
o The controller in charge of the flight shall acknowledge any ADS emergency
message.
- A 11 -
Executive Summary Getting to grips with FANS – Part II – Issue III
A320/A330/A340 aircraft
Enhance ADS
Current FANS A ADS system can be enhanced through the updates of the ATSU
software (CLR3.6b) and FMS Pegasus 2 software (as detailed in Appendix K).
FANS A+ standard
To improve the current FANS A package and extend the use of data link services,
a new standard, called FANS A+, has been developed.
- A 12 -
Getting to grips with FANS – Part II – Issue III Executive Summary
FANS A+ retrofits
A380 aircraft
o The basic definition of the A380 encompasses the A320/A330/A340 FANS A+
package and the ATS 623 applications. The A380 FANS A+ package resumes
all the functions provided within the A320/A330/A340 FANS A+ package.
Some novelties are also introduced considering the regulation evolutions and
the new A380 technology.
Timestamp
o On the operational side, in order to improve dialogues between flight crews
and air traffic controllers, the timestamp is adopted as the time reference for
uplink messages. If ground ATC applications do not provide the timestamp
(applicable to few ATCs), the time indication refers to the reception time and is
displayed differently from the timestamp.
- A 13 -
Executive Summary Getting to grips with FANS – Part II – Issue III
o All FIRs, which are FANS equipped, do not provide the same services. These
FIRs may provide the following FANS functions
- Both ADS and CPDLC.
- ADS only
- CPDLC only
o FANS B is only deployed in European airspaces (CPDLC only) since FAA CPDLC
programme (deployment from Miami) had been frozen.
- A 14 -
Getting to grips with FANS – Part II – Issue III Executive Summary
o It is the airline’s responsibility to get its own customised database from the
database supplier (namely Rockwell-Collins France). AIRBUS suggests that the
airline has issued a RFC to upload their ACR customization databases before
the aircraft delivery. If no customised database is provided, the aircraft is
fitted with a default database. Note the time schedule for the ACR
customisation process :
- Several months (6 months or less depending on the customisation level)
are necessary to Rockwell-Collins France for generating the database,
- The availability of the databases is required no later than one month
before aircraft delivery for their uploading by AIRBUS.
Operational approval
Rules are not yet fully available and individual operational authority may choose
the means of compliance stating what the applicant airline may have to
demonstrate. However, the following items will have to be complied with:
- Aircraft configuration
The aircraft should be configured in accordance with the approved
certification configuration for FANS A operations
- Flight crew training/qualification
Operating an aircraft in a FANS type environment requires from the crew
understanding, knowledge and operational use of the three C, N and S
dimensions of the CNS/ATM concept.
- Maintenance training
An appropriate maintenance training program relative to the digital
communications, must be given to maintenance people
- Approved operational documentation
The applicant airline should present to its relevant authority the FANS A
Airworthiness Approval Summary, the MEL and the AFM to be
approved.
- A 15 -
Getting to grips with FANS – Part II – Issue III
- A 16 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
A5.1 Introduction 19
A5.2 Pre-flight phase 19
A5.2.1 ICAO flight plan filling 19
A5.2.2 Pre-flight checks 20
A5.3 ATS Facilities Notification (AFN) 21
A5.3.1 Why such a function? 21
A5.3.2 Manual AFN 21
A5.4 CPDLC procedures 25
A5.4.1 CPDLC connection 25
A5.4.2 CPDLC connection transfer 27
A5.4.2.1 Notification of transfer to the next ATC 27
A5.4.2.2 Transfer to the next ATC 28
A5.4.3 Abnormal cases at the time of transfer of connection 33
A5.4.3.1 Non-delivery of the NDA 33
A5.4.3.2 Non-delivery of the END SERVICE 33
A5.4.3.3 Automatic connection transfer not successful 34
A5.4.4 End of service 34
A5.4.5 Failures of the CPDLC connection 35
A5.4.5.1 Failure detected by the controller 35
A5.4.5.2 Failure detected by the aircraft or the flight crew 35
A5.4.6 CPDLC shutdown 35
A5.4.6.1 Planned shutdown 35
A5.4.6.2 Unexpected ground shutdown 36
A5.4.6.3 Unexpected avionics shutdown 36
- A 17 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
- A 18 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
A5.1. INTRODUCTION
The following chapter depicts some important and general procedures for an
operational use of CNS/ATM systems. These procedures are applicable to FANS A
and FANS A+ systems.
As already explained FANS routes are, and will be, regionally opened, based on
the availability of ground equipment and technologies. At the beginning of FANS
operations, operational procedures were defined for each region (e.g. Pacific area,
Indian Ocean and Bay of Bengal). Since early 2004, operational procedures have
been standardized thanks to the gained experience in the Pacific region.
Therefore, most of the FANS 1/A regions worldwide joined the standardization
movement to publish the FANS 1/A Operations Manual (FOM), which is based on
the Pacific Operations Manual (POM). For the NAT airspace, operational
procedures are still described in the Guidance Material for ATS Data Link Services
in North Atlantic Airspace.
For more details, please refer to Chapter A7 – FANS A world status and Appendix E
– FANS operational procedures in oceanic and remote areas.
Procedures described in the following sections are common to FANS A and FANS
A+ package disregarding the aircraft models (A320, A330/A340 or A380). In
order to keep the educational side of this brochure, illustrations are repeated for
each type of interfaces (i.e. DCDU and MCDU on A320/A330/A340 aircraft, and
ATC mailbox and MFD on A380). However, keep in mind that procedures and
functions are identical whatever the aircraft model.
- A 19 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
In this example, the data link is ensured by both Satellite and VHF, and ADS is
available.
The following code is used:
- S...........Satellite data link
- H...........HF data link
- V...........VHF data link
- M...........SSR Mode S data link
The aircraft registration is also to be notified in the Field 18. This will be
used for correlation purposes by the ATC through a comparison of it with the one
contained in the AFN logon (see hereafter).
If the data link is to be used a short time after the departure, the ATS Facilities
Notification (AFN) function (described here after) will have to be completed prior
to take off. As a general rule, it is worth noting that the AFN should be
completed 15 to 45 minutes before entering the CPDLC/ADS air space.
- A 20 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
The table below emphasises the ways to initiate an AFN depending on the services
provided by the Current Data Authority (FROM) and the Next Data Authority (TO).
TO
CPDLC only ADS only CPDLC & ADS
FROM
CPDLC only Automatically Automatically Automatically
ADS only Manually Manually Manually
CPDLC & ADS Automatically Automatically Automatically
To this end, the pilot sends a first AFN CONTACT message (FN_CON). This is done
through the NOTIFICATION page of the ATC pages on the MCDU (respectively
MFD ATC COM pages), when the crew enters the ICAO 4 letter code of the ATC
centre and the automatic exchange of messages between the ground and the
aircraft is correctly done. The ATC centre replies to the FN_CON by an AFN
ACKNOWLEDGE (FN_ACK).
This AFN procedure is more or less transparent to the crew, but must be
understood.
- A 21 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
Note :
Until the appropriate FANS stations installation in both Nav Canada (Gander
Oceanic) and UK NATS (Shanwick Oceanic), ADS was not true ADS. The
connection was NOT directly done with any of these centres, but to the ARINC
Centralized ADS (CADS) computer in Annapolis, which then transformed the
received ADS reports into position reports as if received by the AERADIO
operators and then transmitted to the controllers via AFTN (Aero Fixed Telecom
Network).
The true ADS has been announced to replace CADS in the NAT airspace since May
31st 2005. Actually, some FIRs still conduct some tests until the integrated ADS
installation has been completely validated. For instances, at the time of writing
the document, Reykjavik still uses CADS, Shanwick and Gander should switch to
integrated ADS by April 2007.
MCDU
AFN Contact
AFN Acknowledgement
2
3
MCDU
Figure 5-1
Manual notification with A320/A330/A340 interfaces
- A 22 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
MFD
AFN Contact
AFN Acknowledgement
MFD
2
3
Figure 5-2
Manual notification with A380 interfaces
- A 23 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
- A 24 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
For the connection establishment, the ground system and the aircraft exchange
two messages : CONNECTION REQUEST and CONNECTION CONFIRM. During this
exchange, no flight crew action is required.
2
Connection Request
Connection Confirm
DCDU
1
MCD
Figure 5-3
CPDLC connection with A320/A330/A340 interfaces
- A 25 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
2
Connection Request
Connection Confirm
ATC mailbox
MFD
Figure 5-4
CPDLC connection with A380 interfaces
Note: The ACTIVE ATC line on the MCDU (respectively MFD) is dedicated to
CPDLC connection status. When CPDLC connection has been established, the
active ATC is indicated on both DCDU and MCDU (respectively ATC mailbox and
MFD).
- A 26 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
The active data link ATC is usually called the Current Data Authority.
The next data link ATC is usually called the Next Data Authority (NDA).
To inform the aircraft avionics (i.e. ATSU or ATC applications) that a transfer of
control will be done, the current active ATC sends a so-called NDA message to the
aircraft. This is the only way for the ATSU (respectively ATC applications) to be
aware of and to accept the connection with the next ATC centre.
Once a NDA message has been received, the aircraft is waiting for the connection
with the next ATC centre.
DCDU
MCDU
ATC 2 ATC 1
Figure 5-5
Notification of transfer to the next ATC with A320/A330/A340 interfaces
- A 27 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
ATC mailbox
MFD
ATC 2 ATC 1
Figure 5-6
Notification of transfer to the next ATC with A380 interfaces
The automatic transfer to the next ATC is made through a so-called Address
Forwarding Process. The aim of the address forwarding is to forward the
address of the next ATC to the aircraft avionics.
- A 28 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
The following sequence of message exchange should be initiated by the first ATC
around 30 minutes prior to the estimated time at the FIR boundary. The crew is
unaware of this exchange.
- The first ATC sends an AFN Contact Advisory message to the aircraft.
- The aircraft acknowledges this message and sends an AFN contact
message to the next ATC.
- This second ATC acknowledges the demand through an FN_ ACK
message.
- The aircraft sends an AFN Complete (FN_COMP) message to the first
ATC, to inform it of the completion of the AFN.
- At this stage, the second ATC initiates a CPDLC connection as described
in A5.4.1 – CPDLC connection.
For the termination of a connection, the END SERVICE message is used (refer to
A5.4.4 – End of service). Until the END SERVICE message is received from the
first ATC, the ATSU (respectively ATC applications) supports two CPDLC
connections : one active connection with the Current Data Authority and one
passive connection with the Next Data Authority.
The process of the CPDLC connection transfer is completed with the MONITOR (OR
CONTACT) [icaounitname] [frequency] and END SERVICE message elements.
These message elements should be sent after the receipt of the last position
report before crossing the FIR boundary; but not less than 5 minutes before the
FIR boundary. This will allow the next ATC connection to become active when the
aircraft crosses the FIR boundary. If the next ATC centre has not been connected
to the aircraft at the time the "END SERVICE" message is received, the aircraft is
left without any connection.
At the receipt of the END SERVICE message, the ATSU (respectively ATC
applications) disconnects the Current Data Authority. The Next Data Authority
CPDLC connection becomes then active.
Method 1 : The current ATC centre sends to the flight crew MONITOR (OR
CONTACT) [icaounitname] [frequency] and END SERVICE message
elements in one single uplink message.
When the flight crew sends WILCO as a response to the multi-element message,
the ATSU (respectively ATC applications) disconnects the connection with the
- A 29 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
current ATC centre. Therefore, the multi-element message should be received on-
board not more than 10 minutes before the frequency transfer point. Refer to
Figure 5-7 or Figure 5-8.
Method 2 : The current ATC centre sends to the flight crew MONITOR (OR
CONTACT) [icaounitname] [frequency] and END SERVICE message
elements in separate uplink messages.
- A 30 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
CDU
NDA
1
NEXT ATC : NFFF CTL
AFN Contact Advisory
2
AFN Response
3
AFN Contact
4
AFN Acknowledgement
5
AFN Complete
6
Connection Request
7
Connection Confirm
DCDU 8
MONITOR / CONTACT
+ END SERVICE
9
WILCO
10
Disconnection Request
MCDU
ATC 2 ATC 1
Figure 5-7
Transfer to the next ATC with A320/A330/A340 interfaces
- A 31 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
ATC mailbox
NDA
1
MONITOR / CONTACT
+ END SERVICE
9
WILCO
10 Disconnection Request
Figure 5.8
MFD Transfer to the next ATC as on A380
ATC 2 ATC 1
Figure 5-8
Transfer to the next ATC with A380 interfaces
- A 32 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
Either voice or CPDLC can be used for this instruction. The following phraseology
is recommended :
To select ATC Com off, select the DISCONNECT function from the CONNECTION
STATUS page on MCDU (respectively MFD).
• Selecting ATC Com off will disconnect the transferring ATC.
• Logging on to the designated ATC will allow the designated ATC to perform
a CPDLC connection.
Such a procedure is initiated by the transferring ATC while approaching the FIR
boundary.
- A 33 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
Controller : Select ATC Com Off then Logon to [ATC ICAO 4 letter code].
Pilot : Roger
If the CPDLC connection with the current ATC is not terminated at the expected
time (i.e. before the position or time indicated in the CONTACT/MONITOR
message), the flight crew shall send the CPDLC position report to the current ATC.
This CPDLC position report should prompt the ATC controller to terminate the
connection.
If the END SERVICE message is not received within three minutes after the CPDLC
position report has been sent, the flight crew should manually disconnect the
current ATC and should notify the next ATC.
For the following cases, the avionics will terminate established connections. In
both cases, an error message is sent to both ATC centres and a disconnection with
both ATC centres occurs :
• When any uplink messages remain open and the aircraft receives an END
SERVICE message,
• When the END SERVICE element is part of an uplink multi-element
message where none of the elements requires a WILCO response.
If any downlink message remains open when the aircraft receives an END
SERVICE message, the avionics will close the message and terminate the CPDLC
connection with the current ATC. This will not affect the CPDLC connection with
the next ATC.
- A 34 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
As soon as a failure of the CPDLC connection is noticed by either the flight crew or
ground controller, voice will be used to inform the other part of the failure and to
co-ordinate further actions. The voice coordination will be done before any
disconnection.
- A 35 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
• The flight crew shall terminate the data link (i.e. DISCONNECT function in
the CONNECTION STATUS page on MCDU or MFD) and continue on voice.
- A 36 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
A list of all the up and down link messages supported by the CPDLC system is
given in Appendix A.
A5.4.7.1. TO BE KNOWN
In ACARS environments, both pilot and controllers cannot know whether a
message has been delivered to their right counterpart.
Should any doubt or problem occur when dialoguing through CPDLC, voice should
be resumed.
Most of the clearances can be directly answered through appropriate answer keys
on the DCDU (respectively ATC mailbox). According to the recommended
international rules, the 5 following closure responses may be used as appropriate:
WILCO, ROGER, AFFIRM, UNABLE, NEGATIVE.
It is then important that the crew is fully aware of the right meaning and
implications of these answers. The following lists the recognised statements for
these response elements:
- A 37 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
- WILCO : This downlink message tells the controller that the pilot will
comply fully with the clearance/instruction contained in the associated
uplink message.
- ROGER : Through this either uplink or downlink message the pilot or the
controller informs/is informed that the content of the associated message
has been received and understood. ROGER is the only correct response
to any uplink free text message. ROGER shall not be used instead of
AFFIRM.
- DISREGARD : This uplink link message means that the previous uplink
link shall be ignored. DISREGARD should not refer to an instruction or
clearance. Another element shall be added to clarify which message is to
be disregarded.
- A 38 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
- Uplink : A 120 second round trip delay on 95%. Round trip being
obtained by comparing the time the up link is sent from the controller
system against the time the message assurance (indicating successful
delivery) was received back to the ground controller station.
As an order of magnitude both controller and pilot should consider that it takes up
to one minute for a message to be received, around 30 seconds for the pilot or
controller to take action and respond and up to one other minute for the reply to
be received.
• Uplink STANDBY : If the ATC controller does not respond within this time,
the pilot shall send an inquiry (e.g. WHEN CAN WE EXPECT CRUISE CLIMB
TO FL360). In no case, should a duplicate message be sent to avoid any
confusion. Refer to A5.4.7.6 – Duplicate messages.
- A 39 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
• General
“Position” and “Next Position” shall only contain compulsory reporting points
unless requested otherwise by ATC. This recommendation allows to receive
consistent position reports by either voice or data.
In data link airspaces where only CPDLC is available (no ADS-C service provided),
the flight crew shall ensure that a CPDLC position report is sent whenever an ATC
waypoint is passed over (or passed abeam if the aircraft flies an offset). The
preformatted POSITION REPORT message has to be used.
The use of this function should be preferred to manual position report where
CPDLC position reporting is needed.
AUTO POS REPORT function and access to MANUAL POS REPORT on MCDU
- A 40 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
- A 41 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
This first position report is required whether the flown FIR is ADS capable or not.
The first position report confirms that the receiving ATC centre is the Current Data
Authority (CDA).
It is the flight crew’s responsibility to ensure that position reports are only sent at
ATC waypoints. Other waypoints are of no interest to ATC.
If a waypoint ETA has to be updated, a free text shall be sent using the following
wording : REVISED ETA [position] [time].
If the ATC controller does not receive an expected CPDLC position report, the ATC
controller may explicitly request a position report with the uplink message
REQUEST POSITION REPORT.
When this message is received on-board, the ATSU automatically collects the
required information from the FMS to fill in the response. The flight crew may
modify the response prepared by the ATSU if it is not satisfactory.
The FMS does not sequence the active waypoint when the aircraft is abeam this
point by more than 7 NM on Honeywell FMS2 and 5NM on Thalès FMS2. In this
case, the waypoint is not sequenced on the CPDLC report message. It is thus
recommended to use the offset function of the FMS so as to send true position
reports. Once again, and specially in RNP or FANS route, updating the flight plan
is highly recommended.
- A 42 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
- A 43 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
The issue is limited to ATC communication (CPDLC) for reporting Ident Waypoint
coded in Arinc424. ADS does not use identifiers, but reports all lat./long
waypoints, including the Reported Waypoint (in the Basic group) or a Waypoint
Change Event report, Next and Next+1 waypoints (in the Predicted Route Group),
as well as all those that force track, speed or altitude changes and are reported as
“ADS Intent points”.
Many ATC centres cannot accept position reports containing latitude and longitude
(Lat./Long) in ARINC 424 format (e.g. 4050N). Position reports containing
Lat./Long waypoints within these areas will be accepted in whole latitude and
longitude format only. Flights unable to send position reports in whole latitude and
longitude format must accomplish position reporting via HF voice.
• Re-sending of a message
After a reasonable period without answer to its request, the flight crew may elect
to re-send a message. In that case, he should do this in the form of a query, not a
duplicate of the first request. In the case for instance where the initial request
was REQUEST CLIMB TO FL 350, the second attempt should be WHEN CAN WE
EXPECT FL 350.
- A 44 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
Note : "Standardised free text" messages have been developed and agreed upon
by the main FANS actors of the South Pacific area, to cope with the lack of pre-
formatted functions.
Pilots should be prompt to answer the received messages and to clean up their
DCDU (respectively ATC mailbox) with the CLOSE prompt.
Free text message received on board gets closed once ROGER has been
answered. ROGER is the sole response to any up linked free text.
- A 45 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
When a message is sent (i.e. SENT indication is displayed), always close the
message via the CLOSE soft key to clear DCDUs (respectively ATC mailbox). The
RECALL soft key displays the last closed message.
All exchanged messages are stored in the MSG RECORD page on MCDU
(respectively MFD ATC COM pages) when they are answered (uplink messages) or
sent (downlink messages).
- A 46 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
To be noticed
In ACARS environments (contrary to ATN), both pilots and ATC controllers cannot
know whether a message has been delivered to their right counterpart.
- A 47 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
The ATC centre will establish ADS contracts once the AFN has been done either
manually via the MCDU (respectively the MFD ATC COM page for A380) or
automatically through a transfer from a previous ATC centre (refer to A5.4.2.2 –
Transfer to the next ATC).
As soon as the ATSU (respectively the ATC applications for A380) is initialised, the
ADS application is armed, waiting for a possible connection.
In the FANS A+ package on A320/A330/A340 aircraft, the initial FANS A HMI (as
described above) has been modified to improve the awareness about ADS
connections.
- When ADS is activated and no ADS connections have been established,
ADS is in the ARMED mode. ARMED is indicated on the MCDU
CONNECTION STATUS page.
- When ADS is activated and at least one ADS connection has been
established, ADS is in the CONNECTED mode. CONNECTED is indicated
on the MCDU CONNECTION STATUS page, and the number of
connections is indicated on DCDU (e.g. ADS CONNECTED (2)). The
identifications of connected units are available in the MCDU ADS DETAILS
page.
The awareness of ADS connections has been improved even more on A380
interfaces.
- When ADS is deactivated, ADS is in the OFF mode. It is indicated both
on MFD CONNECTION STATUS page and on ATC mailbox (i.e. white ADS
OFF indication).
- A 48 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
ADS Connection
FANS A FANS A+
Status
OFF OFF
On MCDU ON ARMED
ON CONNECTED
OFF
On MFD ARMED
CONNECTED
On DCDU No information ADS CONNECTED (X)
On ATC mailbox X ADS CONNECTIONS
Note 2 : The ADS system must be set to ARMED (or ON for A330/A340 aircraft
equipped with FANS A package), prior to perform an AFN notification. This
setting is the default status.
- A 49 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
On the MCDU page, ADS status is ON. On the MCDU page, ADS status is
But it does not mean that ADS contracts ARMED. The ADS status is given without
have been set up. Actually, here ADS is ambiguity.
just armed, waiting for contracts.
On the MCDU page, ADS status is still ADS status is now CONNECTED. It is
ON. But is this example, contract(s) has explicitly indicated that the ADS
(have) been set up. application is sending reports to at least
one ATC.
- A 50 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
Even if there are no connections, the CPDLC When there are no connections, the default
connection status is displayed. screen is blank.
There is no CPDLC connection, but 2 ADS contracts have been set up.
In case of ADS-only, the information given by There is no ambiguity regarding the ADS
the DCDU screen can be misleading. Even if status on the DCDU screen.
NO ACTIVE ATC is displayed, ADS contract
could have been set up.
DCDU is devoted to CPDLC application. No The default screen of the ATC mailbox
information relative to ADS contracts is provides information about CPDLC and ADS
available. connections.
A CPDLC connection exists, but no ADS contract has been set up.
There is no cue on actual ADS contracts (ADS No ADS contracts have been set-up. (ADS is
is either ON or OFF). either OFF or ARMED).
- A 51 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
The principles used for A320/A330/A340 FANS A+ HMI apply for the A380 FANS
A+ HMI.
The notification has been done. The ADS At the first ADS connection, the ADS
application is ready (i.e. ARMED) to status becomes CONNECTED. For each
connect. connected ATC centre, the time at which
the ATC centre connected is provided.
- A 52 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
There is no CPDLC connection, but 2 ADS contracts have been set up.
A CPDLC connection exists, but no ADS contracts have been set up.
- A 53 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
The FANS A system does not assign technical priority to ADS connections;
therefore, the controlling ATC may not be aware of other connections established
with the aircraft. In order to manage these connections, a procedural hierarchy
controlled by the Address Forwarding process (refer to A5.4.2.2 – Transfer to the
next ATC) has been established.
- A 54 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
Note :
In the example given through this figure, four centres have set up ADS contracts.
Pressing the appropriate LSK cancels the ADS contract established by the
corresponding ATC centre.
In the A380 FANS A+ package, the same kind of feature is provided in the
CONNECTION STATUS page. Just uncheck the ATC centres with which the ADS
connection should be terminated.
- A 55 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
Note : The ADS should not be set to off, unless instructed to do so by ATC.
If the ADS is set to off, the ATC centre can no longer be provided with ADS
reports.
If an offset is manually flown, in a Heading Select mode for instance, both the
intent and predictions as sent by the FMS for ADS purpose, may be incorrect. A
Waypoint will not be sequenced if the position is beyond 7NM on Honeywell
FMS2 and 5NM on Thalès FMS2 aside from this point.
It is then recommended that the crew keeps updated its FMS flight plan, and that
it uses the FMS Offset function. When an Offset is flown with the FMS, the intent
and predicted route information will be provided along the offset route.
Controller : ADS not available revert to ATC data link position reports.
Pilot : Roger
- A 56 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
In that case, the ATC may request the status of the on-board ADS application with
the following the phraseology :
When only ADS is operating, the ADS EMERGENCY mode can be activated :
• For A320/A330/A340 aircraft, through the EMERG ADS function from MCDU
EMERGENCY page,
• For A380 aircraft, through the ADS EMERGENCY function from MFD
EMERGENCY page or from MFD CONNECTION STATUS page.
- A 57 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
When the ADS emergency mode is set, the aircraft immediately sends an ADS
report containing an emergency flag that is interpreted by all ground systems that
currently have periodic or event contracts established with that aircraft.
When the pilot cancels the emergency mode, the aircraft will send an emergency
mode cancellation message to each ground station receiving the emergency mode
reports. The cancellation message will remove the emergency flag from the
periodic contract, but the data contents will remain the same as per the
emergency contract. Any previously existing data groups requested by the ground
system will not be restored unless the ground system re-negotiates the periodic
contract following receipt of the emergency cancellation message. Existing event
contracts are unaffected by the emergency cancellation.
- A 58 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
Operating these applications is done with both the DCDU and the MCDU
(respectively ATC mailbox and MFD). Although very similar to the current FANS A
functions, differences exist and must be kept in mind :
• ATS623 exchanges do not require a preliminary notification process
(AFN) contrary to CPDLC and ADS applications.
• ATS623 exchanges have been built upon voice exchanges: crew request,
ground clearance, crew read-back and ground confirmation. This was a
requirement from the Airworthiness Authorities.
• As per AEEC 623 specifications, it is not possible to refuse an ATS 623
clearance by data link. The refusal, if any, shall be done via voice.
• No Time stamp information are available for ATS623 exchanges.
Note 1 : In case similar applications have been customised through AOC (ACARS)
contracts, these will no longer be available should the ATS623 package be chosen.
- A 59 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
This means that AOC DCL or OCL will no longer be sent from a customised AOC
page. However, customised AOC functions such as Pre-Departure Clearance
(PDC), which is not compliant with the AEEC 623 specifications, will remain
possible through the ACARS.
Note 2 : ATS623 applications are not FANS applications, but are considered as
such because using the DCDU/MCDU (respectively ATC mailbox and MFD) to
exchange messages.
• Usual answers
The following figure provides a typical scenario for a departure clearance using the
ATS623 application. The introduction of new interfaces with the A380 does not
modify the communication protocol. Therefore, this figure applies to the A380
with ATC mailbox and MFD instead of DCDU and MCDU.
- A 60 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
Ground DSP
1- M CDU +
DCDU Request DCL
‘ sending ’
NAT ACK DSP
‘ sent ’
Clearance
2- ATC
MSG + DCDU
NAT = Network Acknowledgement Timer
AUCT = ATC Uplink Confirmation Timer
3-
DCDU Answer (ACK)
‘ sending ’
NAT ACK DSP
‘ sent ’
AUCT
Confirmed
4-
ATC
MSG +
DCDU
Figure 5-9
Departure Clearance scenario
If the crew prefers to REFUSE the received clearance (step 3), then no downlink
message is sent to the ground and this must be done by voice contact: this is
indicated on the DCDU when REFUSE is selected.
- A 61 -
A5 – FANS A operational procedures Getting to grips with FANS – Part II – Issue III
ADS connections
• An ATC will establish ADS contracts once the AFN has been performed.
• FANS A equipped aircraft can have up to five ADS connections.
• The aircraft has the capability to report to all connected ATC centres
simultaneously using ADS.
• Different types of ADS "contracts" exist:
- Periodic : the data are sent at periodic time intervals.
- On demand : the data are sent only when asked for.
- On event : the data are sent whenever a specified event occurs.
• ADS is transparent to the crew. In particular, contracts cannot be modified
from the aircraft. An individual ADS connection may be stopped from the
ground or manually by the crew (FANS A+ only) through the ADS DETAIL
page of the MCDU ATC menu (respectively MFD CONNECTION STATUS
page).
• The ADS should not be set to off unless instructed to do so by ATC.
If the ADS is set to off, the ATC centre can no longer be provided with ADS
reports.
• ADS contracts and connections should normally be terminated by the
ground system when the:
- Aircraft has crossed a FIR boundary, or
- Aircraft's flight plan has been cancelled or has finished, or
- Connected ATCs have no further surveillance requirements for the
flight.
• A Waypoint will not be sequenced if the position is offset by more than
7NM on Honeywell FMS2 and 5NM on Thalès FMS2 aside from this
point. When an offset is flown, it is recommended that the crew keeps
updating its FMS flight plan, and that it uses the FMS Offset function.
ADS shutdown
• When a shutdown occurs the ATC controller will advise the crew of the
requirements for the position reports (by voice or CPDLC).
ADS Emergency
• The emergency mode can be activated either by the pilot or the controller,
and is normally cancelled by the pilot. When selected on the MCDU ATC
page (respectively MFD ATC COM pages), the TSU (respectively ATC
applications) immediately sends a report to all ATC centres that currently
have contracts established with that aircraft.
• The controller in charge of the flight shall acknowledge any ADS emergency
report.
- A 62 -
Getting to grips with FANS – Part II – Issue III A5 – FANS A operational procedures
ATS623
• Pending for a greater maturity of standardised services, AIRBUS has
decided to implement only three ATS 623 applications:
- Departure Clearance (DCL)
- Oceanic Clearance (OCL)
- Digital – Automatic Terminal Information Service (D-ATIS)
• These ATS 623 applications do not require a preliminary AFN procedure
compared to CPDLC and ADS applications.
• In case similar applications have been customised through AOC (ACARS)
contracts, these will no longer be available should the ATS623 package be
chosen (e.g. AOC DCL or OCL will no longer be sent from a customised AOC
page). However, customised AOC functions such as Pre-Departure
Clearance (PDC), which is not compliant with the AEEC 623 specifications,
will remain possible via ACARS.
- A 63 -
Getting to grips with FANS – Part II – Issue III
- A 64 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
- A 65 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
Note 1 : Whenever used, the term A320 designates the A320 family.
Note 2 : The A380 FANS A+ package and the ATS 623 applications are included
in the basic definition of the A380 aircraft.
A320/A330/A340 aircraft
- A 66 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
Improvements address points coming from feedback from operators (e.g. ADS
information on DCDU), interoperability and standardisation objectives (e.g.
addition of CPDLC elements to clarify some messages) or have been dictated by
improvement of Human Machine Interface (HMI) or by functional evolutions (e.g.
availability of the "LOAD" command on the DCDU).
New data link services have also been added with the introduction of :
• VDL mode 2, so as to increase the capacity for ATC communications,
• HFDL capability for ATC (once this service is approved),
• ATS623 applications : Departure & Oceanic clearances and Digital-ATIS,
• High-speed data loading capability (AEEC 615A).
These services are optional and may be chosen separately according to the
airlines needs and types of operations.
Note : The following evolutions are independent of the software update providing
an enhanced ADS (refer to A6.2 – FANS A enhanced ADS) and have been basic for
the A330/A340 at the entry into service since January 2004.
- A 67 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
In case of connection loss, the pilot (through voice) must notify the current ATC of
the problem and restart the CPDLC connection through the complete AFN
procedure from the MCDU NOTIFICATION pages (refer to A5.3 – ATS Facilities
Notification (AFN)).
- A 68 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
They are part of the Report messages, and are proposed wherever appropriate by
the FMS.
- A 69 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
This request, done via CPDLC the message: SET MAX UPLINK DELAY VALUE TO
xxx SEC, will be displayed on the DCDU. The crew will set the value on the
CONNECTION STATUS page in the MAX UPLINK DELAY field.
The MAX UPLINK DELAY value shall be inserted into MCDU on ATC request only.
Messages received beyond this maximum elapsed time will be discarded (not
displayed on the DCDU). An error message will be sent to the ground indicating
that the related delayed message has been discarded by the airborne system.
- A 70 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
The system capacity to auto-diagnose its failures (or those of its peripherals) has
been improved to limit the number of inopportune messages, which harm the
correct breakdown service of the system.
- A 71 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
When HFDL is used, the aircraft may be emitting for slots of 2.5 seconds every 32
seconds.
The figure given in Appendix C gives the current deployment of VDL mode 2
ground stations.
- A 72 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
A6.3.2.3.2. Benefits
A joint utilisation of a high-speed-data loading ATSU and of a SDL/PDL provides
the following benefits :
• Reduced data loading time with a factor of five at a minimum,
• Compatible with AEEC 615-3 and AEEC 615A,
• Facilitated maintenance operation :
- Reduce manual intervention between loads,
- Capacity to load customised airline configuration,
- User-friendly data loader design,
- Trouble shooting aids in case of loading issue.
- A 73 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
The most important point is that DCL and OCL are not true FANS A services, and
as such, cannot be processed by the system in the same way as CPDLC for
instance. The associated HMI (DCDU mainly) is thus slightly different, and has
been adapted to take account of these differences.
It has to be noticed that D-ATIS reports are not parts of a direct dialogue between
the flight crew and the ATC controller. As a consequence, D-ATIS reports are
directly received into the MCDU.
For operators wishing to modify their aircraft configuration, an RFC (Request For
Change) must be issued for the basic functions package (see A6.3.1 – A330/A340
FANS A+ basics) and a specific RFC for capabilities to be activated separately
(options).
- A 74 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
A320/A330/A340 aircraft
Enhanced ADS
Current FANS A ADS system can be enhanced through the updates of the ATSU
software (CLR3.6b) and FMS Pegasus 2 software (as detailed in Appendix K).
FANS A+ Standard
To improve the current FANS A package and extend the use of data link services,
a new standard, called FANS A+, has been developed.
• Improvements address points coming from:
- Operational / in service feedback from operators,
- Interoperability and standardisation objectives,
- Improvement of Human Machine Interface (HMI),
- Functional evolutions.
• New data link services have also been added with the introduction of :
- VDL mode 2, so as to increase the capacity for ATC communications,
- HFDL capability for ATC (once this service is approved),
- ATS623 (Departure & Oceanic clearances, Digital-ATIS applications),
- High-speed data loading capability (AEEC 615a).
FANS A+ retrofits
To upgrade aircraft systems from FANS A to FANS A+ standards, only a software
update is necessary (no hardware components need to be changed).
- A 75 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
A380 aircraft
When an ATC instruction to modify the value of the maximum uplink delay is
received, select the SET MAX UPLINK DELAY option and copy the value mentioned
in the ATC instruction.
The MAX UPLINK DELAY value shall be inserted into MCDU on ATC request only.
- A 76 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
Taking into account the statement on the timestamp provided by most ATC
centres, the FANS A+ package on A380 aircraft offered an opportunity to manage
the timestamp while displaying the uplink message on ATC mailbox. The
management of the timestamp is described below.
Besides, it has been observed that most pilots considered the time provided at the
top left corner of DCDU as the time at which the message has been sent
(timestamp). The management introduced by the A380 ATC mailbox allows
getting rid of this confusion.
- A 77 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
- A 78 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
A380 aircraft are basically fitted with such flight data recorders.
- A 79 -
A6 – FANS A evolutions Getting to grips with FANS – Part II – Issue III
The ACR PRODB is comparable to the Media configuration table (MCT) part of the
DSP world map file of the ATSU Router Parameter Database (ATSU RPDB) except
that it does not contain the VHF frequencies.
The ACR CSTDB is comparable to the ARF customisation file and the DSP world
map file except the MCT but with the VHF frequencies.
In a dual ACR configuration, if ACR 1 fails, ACR 2 becomes active. This ACR
reconfiguration has no impact on ATC connections with the ground. Only
messages queued in ACR 1 at the time of the failure are lost. Mechanisms have
been implemented inside ATC applications to get aware of the message loss.
- A 80 -
Getting to grips with FANS – Part II – Issue III A6 – FANS A evolutions
A380 aircraft
The basic definition of the A380 encompasses the FANS A+ package and the ATS
623 applications. The A380 FANS A+ package resumes all the functions provided
within the A320/A330/A340 FANS A+ package. Some novelties are also
introduced considering the regulation evolutions and the new A380 technology.
Timestamp
On the operational side, in order to improve dialogues between flight crews and
air traffic controllers, the timestamp is adopted as the time reference for uplink
messages. If ground ATC applications do not provide the timestamp (applicable to
few ATCs), the time indication refers to the reception time and is displayed
differently from the timestamp.
- A 81 -
Getting to grips with FANS – Part II – Issue III
- A 82 -
Getting to grips with FANS – Part II – Issue III A7 – FANS A world status
- A 83 -
A7 – FANS A world status Getting to grips with FANS – Part II – Issue III
All FIRs, which are FANS equipped, do not provide the same services.
These FANS capabilities are represented on the following chart (based on data
available in April 2005).
Figure 7-1
FANS equipped FIRs as of April 2005
- A 84 -
Getting to grips with FANS – Part II – Issue III A7 – FANS A world status
CPDLC service will utilize the message sets contained in sections 7 and 8 of the
Guidance Material for ATS Data Link Services in North Atlantic Airspace.
Operators should note that other NAT areas do not support all of the message
elements contained in this section 8. In the New York Data Link service area, first
preference for position reports is ADS WPR, followed by CPDLC (ensuring that
geographic coordinates are not encoded as per ARINC specification 424), followed
by HF voice. Operators should note that voice reports are required unless
otherwise advised.
Unless otherwise advised, additional AFN Notification to initiate ADS services with
other NAT OCAs is not required, once an Active CPDLC connection is established
with KZWY.
Flights entering the New York Data Link service area should be especially aware of
the guidance related to transfer to another ATC while crossing the FIR boundary
because automatic CPDLC transfers from other FIRs to KZWY may not be enabled
during the initial New York CPDLC implementation.
2
FMC WPR is out of the scope of Getting to Grips with FANS brochure. For more details,
please refer to Getting to Grips with Data Link brochure.
- A 85 -
A7 – FANS A world status Getting to grips with FANS – Part II – Issue III
Note 1 : The Gander OCA encompasses the Gander Oceanic FIR and that part of
the Sondrestrom FIR south of 63°30' North and above FL195.
Note 2 : The Reykjavik OCA encompasses the Reykjavik FIR and that part of the
Sondrestrom FIR north of 63°30' North and above FL195.
For deeper interest, the main NAT operational procedures are given in Appendix E.
A7.2.4. CONTACTS
Contacts Company Phone Fax E-mail
Tom Cole Nav (613) 248- (613) 248- fcma@navcanada.ca
FANS Central Canada 7158 6802
Monitoring
Agency
Carole Stewart Nav (613) 563- (613) 563- stewacg@navcanada.ca
Manager, Canada 5674 7987
enroute and
Oceanic
Procedures
Operators using ARINC as their DSP
Pete Grogan (410) 266- PGROGAN@arinc.com
2344
Operators using SITA as their DSP
Karen 61 29240 61 2 9247 karen.stephenson@sita.int
Stephenson 1427 9330
- A 86 -
Getting to grips with FANS – Part II – Issue III A7 – FANS A world status
For deeper interest, the main operational procedures are given in Appendix E.
- A 87 -
A7 – FANS A world status Getting to grips with FANS – Part II – Issue III
A7.3.4. CONTACTS
Contacts Company Phone Fax E-mail
John Fekkes Nav 1 613 248 1 613 248 fekkesj@navcanada.ca
Canada 6930 6802
Norm Dimock Nav 1 613 248 1 613 248 dimockn@navcanada.ca
Canada 6859 6802
• ADS : It is used by all the ATCs within the Pacific areas (except Oakland
and Anchorage, which should be equipped in 2004).
This type of operation has been specifically developed to take full advantage of
the weather conditions as they appeared along the average 14 hours flight in the
SOPAC. It consists in allowing an in-flight dynamic re-routing once better wind
- A 88 -
Getting to grips with FANS – Part II – Issue III A7 – FANS A world status
conditions are known. Once primarily negotiated with the concerned ATCs, a new
flight plan is sent by AOC to the aircraft via ACARS into the FMS secondary flight
plan. It is then up to the crew to decide and negotiate for the new route. All this
transaction with ATC is done through CPDLC. Now, DARP is used on some User
Preferred Route (detailed below).
Although promising, this procedure (detailed in Appendix F) has not been used
very much for the time being, because it happens that the current wind models,
as used by the airlines, are precise enough within the frame of the flight.
Activating the DARP procedure requires a good co-ordination between all involved
actors (Aircraft, AOC, ATC). The User Preferred Route procedure (UPR) is by far
preferred by the airlines. In addition, DARP cannot be generalised because it
needs AIDC between the various ground ATC, which is not available in all ATC
centres.
The wind models used by the airlines are not the same than those used by the
ATC when the daily PACOTS routes are defined. Differences of up to around 15
minutes of flight time are claimed by the operators. These have been asking for
the possibility to define their own routes according to the daily conditions. They
file their UPR Flight Plan. These UPR procedures are generalised throughout South
Pacific.
The end-to-end data link system is now sufficiently reliable to support 50NM
lateral spacing in the South Pacific.
Weather deviations occur frequently in the South Pacific but application of RVSM
provides an opportunity for more flexibility and for added contingency procedures
that pilots can use if a weather deviation clearance cannot be provided (refer to
http://www.faa.gov/ats/ato/rvsm_documentation.htm - areas_specific).
- A 89 -
A7 – FANS A world status Getting to grips with FANS – Part II – Issue III
For deeper interest, the main operational procedures are given in Appendix E.
A7.4.4. CONTACTS
Contacts Company Phone Fax E-mail
Pacific Ocean – Oakland
Robert FAA 510-745- 510-745- Bob.hansen@faa.gov
Hansen 3836 3826
Pacific Ocean – Tahiti
Jean-Michel VIVO Tahiti PROST-BOUCLE_Jean-
Prost-Boucle Michel@seac.pf
Pacific Ocean – Fiji
J. Seetom SASL-Fiji 679- 679-724- Seetomj@afl.com.fj
725110 525
Pacific Ocean – Auckland
Paul Radford ACNZ 64-9- 64-9- Radfordp@airways.co.nz
2568077 275-3106
Pacific Ocean – Brisbane
Adam Watkin Air Services 61-7-3866- 61-7- Adam.watkin@airservices.gov.au
Australia 3421 3866-
3257
Pacific Ocean – Japan
Hideo JCAB hideo-
Watanabe watanabe@so.motnet.go.jp
Yoshiro ATCA Japan +81 3 crasa@cra-japan.org
Nakatsuji 3747 1231 naka@atcaj.or.jp
Indian Ocean – South Africa
Peter Marais ATNS +2711 961 peterm@atns.co.za
0100
Indian Ocean – Australia
Adam Watkin Air Services 61-7-3866- 61-7- Adam.watkin@airservices.gov.au
Australia 3421 3866-
3257
Singapore
Soo Kiat Goh CAAS/OP Soo_Kiat_Goh@caas.gov.sg
Bay of Bengal
Nanang Indonesia cns_atm@telkom.net
- A 90 -
Getting to grips with FANS – Part II – Issue III A7 – FANS A world status
A7.5. CHINA
A7.5.1. AREA OF APPLICATION
A specific FANS route (L888) has been opened along Western China over Tibetan
plateau.
Four FANS equipped stations ensure CPDLC and ADS services along this route :
• Kunming (ZPPP), • Lanzhou (ZLLL),
• Chengdu (ZUUU), • Urumqi (ZWWW).
An AIP has been published to describe the data link capabilities supported by the
China Air Traffic services on this Chinese western route.
Both CPDLC and ADS operations are carried out through Satellite data link in a
first step.
- A 91 -
A7 – FANS A world status Getting to grips with FANS – Part II – Issue III
A7.5.4. CONTACTS
Contacts Company Phone Fax E-mail
Aeronautical Information 86-10- aip@aischina.com
Service Center 67347230
Air Traffic Management
Bureau
General Administration of
Civil Aviation of China
P.O.Box 2272, Shilihe,
Chaoyang District
Beijing 100021, People's
Republic of China
The table below is reproduced with the courtesy of SITA. This table is protected by
copyright SITA 2006. It provides the list of all FIRs ensuring data link services as of
June 2006.
CAUTION: While SITA and AIRBUS SAS have taken every precaution to
avoid any errors or omissions that may inadvertently be contained in this
document, SITA and AIRBUS SAS do not accept any liability for the
accuracy of information contained herein. Please refer to the relevant ATS
Provider publications such as AIPs, AIC, NOTAMs, etc. to verify information
and to find out the specific participation requirements.
- A 92 -
Getting to grips with FANS – Part II – Issue III A7 – FANS A world status
- A 93 -
A7 – FANS A world status Getting to grips with FANS – Part II – Issue III
- A 94 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
A8.1 General 97
A8.2 Data link : contracts and declarations 97
A8.2.1 Contracts with Data link Service Providers (DSP) 97
A8.2.2 Aircraft declaration to data link service providers and 98
ATC centres
A8.2.3 Recommendations 98
A8.3 Impacts on A320/A330/A340 aircraft configuration 98
A8.3.1 ATSU SCAN MASK 98
A8.3.2 SATCOM user ORT 99
A8.3.3 AMI database of the FMS 99
A8.4 Impacts on A380 aircraft configuration 99
A8.4.1 Customised ACR database 100
A8.4.2 A380 SATCOM user ORT 100
A8.4.3 OPC database of the A380 FMS 101
A8.4.4 AMI database of the A380 FMS 101
A8.5 Get the operational approval 101
A8.5.1 General requirements 101
A8.5.2 A320/A330/A340 aircraft configuration 102
A8.5.3 A380 aircraft configuration 102
A8.5.4 Flight crew training/qualification 102
A8.5.4.1 General recommendations 102
A8.5.4.2 Proposed qualification means 103
A8.5.4.3 Academic training 103
A8.5.4.4 Operational training 105
- A 95 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
- A 96 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
A8.1. GENERAL
This chapter aims at providing airlines with administrative and technical guidelines
so as to ensure proper operations of FANS A aircraft on FANS routes.
For these reasons the operator needs to ensure the following before starting FANS
Operations :
As of today, VHF, SATCOM and HFDL are certified by AIRBUS to sustain both ATC
and AOC data link. However, it is to be noticed that HFDL is certified :
• As a primary means for AOC purposes,
• As a supplementary means for ATC purposes.
- A 97 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
If an airline wishes to use more than one service provider, then two solutions may
be considered :
• Place contracts directly with each service provider, or
• Place a contract with a unique service provider who will subcontract data
handling to other service providers.
In addition, the SATCOM AES (Aircraft Earth Station) identification, i.e. the aircraft
ICAO address, must be declared to the GES (Ground Earth Station) the aircraft
will operate with. This is achieved through registering with INMARSAT using the
Registration for service activation of Aircraft Earth Station (AES) form.
The airline should make sure that all service providers to be potentially contacted
by a given aircraft have been advised of its FANS capability and identification.
Each new FANS aircraft entry into service must be declared to the service
providers selected by the airline and to the ATC centres the aircraft will
communicate with.
A8.2.3. RECOMMENDATIONS
- A 98 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
be applied on each FANS aircraft. If the scan mask is not set properly, FANS
operation will be impacted, and this may result in ATC data link message losses.
The Initialisation procedure of the ATSU router (airline identification and scan
mask) is provided through AMM 46-21-00-860-801.
The Appendix D gives the GES code and associated Satellite code that are used by
Airborne SATCOM systems for both voice and data link communications. Pairs of
selected Satellite/GES should be entered in the ORT with a priority order.
The ORT cannot be modified via MCDU, thus is less prone to programming errors
than the ATSU scan mask.
The FMS database called AMI (Airline Modifiable Information) allows activating the
FMS/ATSU interface. FMS data are required by the ATSU to operate in ADS, AFN
and CPDLC. A wrong AMI definition can cause these FANS applications to be
inoperative on a FANS aircraft.
Airlines are required, by their FMS supplier, to fill-in a form called AMI worksheet,
where they must specify the FMS optional functions they wish to use. In order to
have FANS functions activated, it is necessary to have the data link function
enabled (§2.5.1 of Honeywell AMI worksheet). Airlines should advise their FMS
supplier, that the aircraft on which the AMI will be loaded have the FANS function
activated, so that a particular attention will be paid at AMI settings.
- A 99 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
The routing policy defines in which order the available media (VHF, HF, SATCOM)
have to be used considering performances and costs of the media, and with which
DSPs according to the contracts the airline has made.
It is the airline’s responsibility to get its own customised database from the
database supplier (namely Rockwell-Collins France). AIRBUS proposes for the
airline having issued a RFC to upload their ACR customization databases before the
aircraft delivery. If no customised database is provided, the aircraft is fitted with a
default database.
Didier VIVIER
Program Manager – Commercial Avionics
Rockwell Collins France
6, avenue Didier Daurat – BP 20008 – 31701 Blagnac – France
Phone : +33 (0) 5 34 61 86 14 Mobile : +33 (0) 6 87 76 71 55
Fax : +33 (0) 5 61 71 51 69
Email: dvivier@rockwellcollins.com
- A 100 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
Nevertheless, if the airline elects for a second ACR to be installed, the OPC
database of the FMS has to be configured accordingly.
Data link operations over oceanic and remote areas are not mandatory. Therefore,
there are no requirements that define the operational approval process. However,
airlines that elect to use data link systems are required to get an operational
approval for their local authority. To that end, some materials are available (such
as FAA AC 120-70A available at http://www.faa.gov/ats/ato/data_link.htm),
stating what the applicant airline may have to demonstrate.
It is however expected that the following items will have to be complied with, by
the applicant airline :
• Aircraft configuration,
• Flight crew training/qualification,
• Maintenance training,
• Approved operational documentation and procedures.
Based on this document, which lists the assumptions on the ground environment
and gives a synthesis of the tests carried out for certification, the scope of
additional tests may be defined :
• Interoperability test scenarios,
• Verification of the safety and performance criteria with regards to the
considered environment.
- A 101 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
The list of the approved FANS aircraft configuration will be kept updated by
AIRBUS. Compliance to this list will have to be ensured.
The Navigation aspects are addressed in the “Getting to grips with modern
navigation” brochure.
- A 102 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
To this end, the following points will be emphasised in preparing the flight crew
training programs :
• Basic knowledge of the overall CNS/ATM environment for which, the various
concepts and interacting elements, the involved aircraft systems and
relevant operating procedures to be applied should be covered in a
dedicated academic training.
• Operational use of data link communications (e.g. handling of up and down
link ATC messages or ATC operating procedures) should be taught so as to
develop skills and practices for the considered FANS environment.
• Initial evaluation and recurrent training have to be part of the approved
syllabi.
• Specific Human Factors points pertaining to the data link communications
should be carefully addressed (refer to A8.5.4.3 – Academic training).
It is AIRBUS opinion that the initial qualification should be made of the following
components :
• Half a day familiarisation course, to address the academic training, and
emphasise the main operational critical points.
• "Home work" training for each pilot, through the interactive Computerized
Based Training (CBT) developed by AIRBUS.
• One operational flight conducted with an airline check pilot.
Such an initial training may be based on the CBT developed by AIRBUS or given
as a first step.
Note : To obtain a copy of the AIRBUS training course, a CBT license is needed.
For further information, contact your AIRBUS Resident Customer Service Manager
(RCSM) or Customer Service Director (CSD).
Once completed, this program needs not to be repeated. Only the new, modified
or specific points will be addressed during further programs.
- A 103 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
Flight crews should be made aware of the nominal systems operations and
performance parameters, normal and abnormal use together with the limitations
of the systems.
- A 104 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
• The pilot responsible for the communications ensures that the situation
awareness, as entailed by the ATC data link messages, is fully shared by
the other pilot. To this end, any message transiting through the DCDU
respectively ATC mailbox (whether received or to be sent) will be read in a
loud voice so as to ensure a common understanding and allow for a good
cross checking between the two pilots.
• Crew co-ordination should be completed before any action ensuing a
received message is done or before any message or answer is sent to the
ground.
• Emphasis will be done on the crew work sharing, so as to avoid
simultaneous head down attention by both pilots, while handling of the
messages is done.
The AIRBUS CBT training device, through its interactive operational scenarios,
mostly covers this training syllabus. It may be presented by the airline to the
airworthiness authorities as a stand-alone computer-based instruction. It covers
the data link communications items of the global FANS, and comes in complement
to the RNP/RVSM operational training (as described in the Getting to grips with
modern navigation brochure).
The following lists the items to be tackled in a training course. All but the "Special
Recommendations" paragraph are addressed in the AIRBUS CBT :
• Message handling
The pilots should be trained on how to receive and interpret ATC messages.
Understanding the CPDLC / ADS phraseology is to be acquired.
- A 105 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
Will also be practised the operations that require simultaneous work on both the
DCDU and the MCDU (respectively ATC mailbox and MF). In particular, loading
route clearance messages in the FMS, or preparing requests on the ATC pages of
the MCDU (respectively MFD) should be covered.
The automatism, as provided by the FMS, for monitoring and answering to some
specific messages (e.g. differed clearances) should be known from the flight
crews. Handling of automatically FMS proposed answers should be mastered.
The global use of the communications systems, whether they are traditional voice
or new data link communications will have to be acquired.
Establishing and terminating CPDLC, activating and deactivating ADS, switching
from traditional voice based to digital communications control and coping with
failures of these systems should be practised.
All the available controls and indicators of the AIRBUS FANS system should be
known and used (e.g. the meaning of the various displays, advisories, available
functions).
Knowledge of the ATS procedures for the considered FANS area (e.g. timely,
relevant and appropriate responses to communications and surveillance failures)
is of prime importance.
In addition, crews should be able to recognise "usual" failures and be fully aware
of the tricks pertaining to the sensitivity of the end-to-end data link
communications (Refer to the following recommendations).
• Special recommendations
Derived from the lessons learned during FANS operations in the South Pacific
area, the following list gives the main points to be underlined in the operational
training:
- A 106 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
- Flight identification
Pilots should be fully aware that the flight identification of both the filed F-PLN and
the one used for data link communications must be identical. It is the pilot's
responsibility to ensure that correct flight identification and registration number
are used.
In particular, the operator ICAO 3-letter code is to be used (e.g. ICAO ATC filed F-
PLN, FMS, data link). Attempting a connection with AI 123 identification for
instance, whereas AIB123 has been filed, will cause the ground system to reject
the connection.
Pilots shall be aware when the data link shall be established at the latest.
- Communication means
When the dialogue is initiated via CPDLC, the response shall be via CPDLC. When
the dialogue is initiated via voice, the response shall be via voice.
When CPDLC fails and communications revert to voice, all outstanding CPDLC
messages should be considered not delivered and the entire dialogue involving the
outstanding messages should be recommenced by voice.
Limit the use of free text message to exceptional cases. Pilots should be made
aware that free text messages cannot be treated by the automated station of the
controller as a standard ATC message. As such, no correlation between the free
text and its answer can be provided.
Avoid abbreviations and acronyms since they may have different meanings to
different operators.
- A 107 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
ROGER is the sole answer for an up linked free text message. Any other answer
will keep the received message open.
In particular, pilots should verify that the expected ICAO 4 letter code for the
region is displayed on the DCDU (respectively ATC mailbox), and should not
send any message before this check has been done.
o Disconnection may also occur during FIR transfers due to pending uplink
messages and this, although the recommended procedures specify that the
END SERVICE message is not transmitted while there are open messages.
Pilots should be aware of such occurrences.
o During a transfer, if the END SERVICE message is not received on-board, the
flight crew shall apply the appropriate procedure :
Manual disconnection with the current ATC followed by an AFN notification
to the next ATC as per section 4.7.2.1 of FANS 1/A Operations Manual, or
Voice contact with the current ATC followed by manual disconnection with
the current ATC and a logon to the next ATC as per section 5.8 of Guidance
Material for ATS Data Link Services in North Atlantic Airspace.
- Open message
- Delays in responding
Both pilots and ATC answers to messages should be done as soon as possible. In
case a STANDBY response has been received from the ATC, the flight crew should
expect a further answer within 10 minutes. Waiting for it, the message remains
open. If no answer comes on time, and to avoid a duplicate message, it is then
recommended that the next message of the crew is based on an inquiry (e.g.
WHEN CAN WE EXPECT)
- A 108 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
- Multi-element messages
- Waypoint sequencing
When an aircraft is laterally displaced by more than a set distance (7NM for
AIRBUS models) from the track defined by an active flight plan, waypoints cease
to be sequenced. This affects the data transmitted in CPDLC position reports and
prevents ADS waypoint events from triggering reports.
Monitoring the correct sequencing of the waypoints together with the updating of
the F-PLN is thus to be recommended, especially in those areas of flight where
ADS (or CPDLC) position reporting is done.
Pilots should be well aware of the consequences on CPDLC and ADS applications
when flying an offset in Heading Selected mode.
- Position reporting
Pilots should be aware that there is no ATC response to their CPDLC position
report. As such, they must not re-send their message.
- Weather deviation
- A 109 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
- Message printing
- Abnormal configurations
The following lists the expected pilot's behaviour for an efficient use of the data
communications systems, whether this is used as either a primary or a secondary
means :
- Prompt and appropriate answer to up linked messages
- Appropriate emission of down linked messages
- Nominal crew work share for an efficient handling of the messages
- Compensation of system failures through prompt back up voice
- Compliance with the voice clearance whenever this contradicts the data
link one
- Use of data link only within approved area and configuration
• Operator responsibilities :
Operators have the following responsibilities regarding the use of digital
communications :
- Signing contract with DSP and declaring aircraft to DSP and ATC centres
of operated routes
- Configuring adequately the aircraft avionics,
- Verifying digital communications functionality for each environment to be
used and when new or modified components or software are introduced,
- Assuring follow up and evaluation of exceptional data link events;
- Periodically assessing digital communication training, checking and
maintenance programs to ensure their correctness, pertinence, timeless
and effectiveness.
Data link anomalies (failures, loss of messages, unanswered messages, very long
response time, disconnection...), procedural difficulties, human factors issues
- A 110 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
Installation, modification and use of testing tools are some of the points to be
trained. The maintenance people should also be aware of the MEL items
associated to the relief of FANS equipment.
Based on this document, the operational and technical context may be evaluated
and additional demonstration activities be asked by the authority.
- A 111 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
The MEL items for data link communications may depend on the considered FANS
route (oceanic, continental, remote areas). The airline should thus take provisions
for some specific operating systems at dispatch, and consider the consequences of
their loss on the data link communications.
FANS operations are related to operational aspects, and therefore AIRBUS current
policy is not to include FANS considerations in the MMEL. Therefore it remains up
to the operators to amend their own MEL for FANS operations.
Note : 2 HF are required for remote area further than VHF line-of-sight with or
without FANS capability. Although the availability and the reliability of the
SATCOM have proven to be good enough in South Pacific area, dispatch with one
HF only is still not granted for such area.
Note : Second FMGC or its Nav Backup function may be required in function of
the RNP of the planned route.
- A 112 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
- A 113 -
A8 – Starting FANS A operations Getting to grips with FANS – Part II – Issue III
- A 114 -
Getting to grips with FANS – Part II – Issue III A8 – Starting FANS A operations
Operational approval
Rules are not yet fully available and individual operational authority may choose
the "means of compliance" stating what the applicant airline may have to
demonstrate. However, the following items will have to be complied with:
• Aircraft configuration
The aircraft should be configured in accordance with the approved certification
configuration for FANS A operations.
• Flight crew training/qualification
Operating an aircraft in a FANS type environment requires from the crew
understanding, knowledge and operational use of the three C, N and S dimensions
of the CNS/ATM concept.
• Maintenance training
An appropriate maintenance training program relative to the digital
communications, must be given to maintenance people.
• Approved operational documentation
The applicant airline should present to its relevant authority the FANS A
Airworthiness Approval Summary, the MEL and the AFM to be approved.
- A 115 -
Getting to grips with FANS – Part II – Issue III
- A 116 -
Getting to grips with FANS – Part II – Issue III APPENDICES
APPENDICES
- A 117 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
Listed in this appendix are all the FANS A and FANS A+ messages supported by
the CPDLC, as defined by the EUROCAE ED-100 and endorsed by the ICAO ADS
panel. Additional comments provided by the ISPACG user forum are displayed in
italics.
All up and down messages have been classified into operational groups. The
reference number is that of the initial ED-100.
The abbreviations used for classification purpose are defined here below.
- A 118 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
UPLINK MESSAGES
- A 119 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 120 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 121 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 122 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 123 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 124 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 125 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 126 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 127 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 128 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 129 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 130 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 131 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 132 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 133 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
DOWNLINK MESSAGES
DOWNLINK – RESPONSES
DL MESSAGE ELEMENT MESSAGE INTENT RESPONSE
0 WILCO The instruction is understood and N
will be complied with.
1 UNABLE The instruction cannot be complied N
with.
2 STANDBY Wait for a reply. N
The controller is informed that the
request is being assessed and there
will be a short term delay (within 10
minutes). The exchange is not
closed and the request will be
responded to when conditions allow.
3 ROGER Message received and understood. N
ROGER is the only correct response
to an uplink free text message.
Under no circumstances will ROGER
be used instead of AFFIRM.
4 AFFIRM Yes N
AFFIRM is an appropriate response to
an uplinked negotiation request
message (e.g. CAN YOU ACCEPT
[altitude] AT [time]).
5 NEGATIVE No N
NEGATIVE is an appropriate response
to an uplinked negotiation request
message (e.g. CAN YOU ACCEPT
[altitude] AT [time]).
- A 134 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 135 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
DOWNLINK – REPORTS
DL MESSAGE ELEMENT MESSAGE INTENT RESPONSE
28 LEAVING [altitude] Notification of leaving the specified N
level.
29 CLIMBING TO [altitude] Notification of climbing to the N
specified level.
30 DESCENDING TO [altitude] Notification of descending to the N
specified level.
31 PASSING [position] Notification of passing the specified N
position.
78 AT [time] [distance] At the specified time, the aircraft's N
[to/from] [position] position was as specified.
32 PRESENT ALTITUDE [altitude] Notification of the present level. N
33 PRESENT POSITION Notification of the present position. N
[position]
34 PRESENT SPEED [speed] Notification of the present speed. N
35 PRESENT HEADING [degrees] Notification of the present heading in N
degrees.
36 PRESENT GROUND TRACK Notification of the present ground N
[degrees] track in degrees.
37 LEVEL [altitude] Notification that the aircraft is N
- A 136 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 137 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 138 -
Getting to grips with FANS – Part II – Issue III APPENDIX A
- A 139 -
APPENDIX A Getting to grips with FANS – Part II – Issue III
- A 140 -
Getting to grips with FANS – Part II – Issue III APPENDIX B
- A 141 -
APPENDIX B Getting to grips with FANS – Part II – Issue III
NOTES:
1. When no value is available or the value available to the ADS is invalid, a default value
shall be inserted in the field. The values shown here reflect a coding of all "ones".
2. The value of the Most Significant Bit (MSB) is accurate by definition. The value of the
Least Significant Bit (LSB) is an approximation.
3. When either the latitude or the longitude for a position is invalid, both shall be set to –
180° In the Basic ADS Group, the FOM shall also be set to 0.
4. When the Flight Identification is invalid, all characters shall be encoded as spaces.
When the Flight Identification is less than eight characters, the Flight Identification
shall be encoded left justified and the unused characters shall be encoded as spaces.
5. The character set for the Flight Identification Group shall be ISO 5, without the most
significant bit. This allows the characters to be encoded using only six bits. Valid
characters are contained in the following sets: (A..Z), (0..9) and ( ).
6. The validation of the direction parameter shall be indicated by the immediately
preceding bit, where 0 = valid and 1 = invalid.
7. Signed numerical values shall be represented in two's complement notation.
8. The time stamp shall be expressed as the time elapsed since the most recent hour.
Time shall be rounded, not truncated, to accurately yield the value loaded into the
time stamp field.
- A 142 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
1. INMARSAT
• Aeronautical global coverage and spot beams
Contact : customer_care@inmarsat.com
2. MTSAT
• SATCOM coverage over Asia-Pacific region
Contact : aircom.customer.support@sita.aero
SITA ensures the customer support as it is the exclusive service provider for
MTSAT communications.
3. ARINC
• VHF world coverage
• VDL mode 2 coverage
Contact : http://www.arinc.com/contact/index.html
4. SITA
• VDL mode A and mode 2 world coverage
• VDL regional coverage
Contact : http://www.sita.aero/News_Centre/Contact_SITA/default.htm
The following maps are provided with the courtesy of INMARSAT, MTSAT, ARINC
and SITA.
- A 143 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
- A 144 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
- A 145 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
- A 146 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
- A 147 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
- A 148 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
- A 149 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
- A 150 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
- A 151 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
SITA – EUROPE, AFRICA AND MIDDLE EAST – VDL MODE A (MARCH 2006)
Altitude 30 000 ft – On line RGS are in red, planned are in blue.
- A 152 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
- A 153 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
- A 154 -
Getting to grips with FANS – Part II – Issue III APPENDIX C
- A 155 -
APPENDIX C Getting to grips with FANS – Part II – Issue III
- A 156 -
GES INMARSAT Satellite
Telecom Providers
Service provider for
for voice/fax
Code SATCOM data link
Country Location Name Code communications
(octal)
SKYPHONE CONSORTIUM
101 AOR/E 01
UK Goonhilly Stratos ARINC, SITA
AOR/W 00
SATELLITE AIRCOM CONSORTIUM
Getting to grips with FANS – Part II – Issue III
305 IOR 03
Australia Perth Stratos SITA
205 POR 02
103 AOR/E 01
- A 157 -
France Aussaguel France Telecom SITA
005 AOR/W 00
GLOBAL LINK
104 AOR/E 01
Norway Eil Telenor ARINC
301 IOR 03
Southbury 002 AOR/W 00
USA Telenor ARINC
APPENDIX D – SATCOM OPERATORS
The following sections are extracted from the mentioned manuals. They are
consistent with those manuals at the time of their effectiveness. They are intended
to illustrate FANS operations in the mentioned regions. It is strongly
recommended to refer to the manuals available at the mentioned website
address as they may be updated without prior notice.
At any time, the following sections shall not be used for operations.
AIRBUS SAS shall not be liable for any direct, indirect, or consequential damages
that results from the use or inability to use the extracts, in particular for, but not
limited to, errors, or omissions in the contents of the following sections or the
consequences of its use, nor for inaccurate transmission or misdirection, even if
AIRBUS SAS has been advised of the possibility of such damage. This limitation
applies whether the alleged liability is based on contract, tort, or any other basis. It
is the user’s responsibility to make sure that she or he is using the most up-to-date
information available.
- A 158 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
- A 159 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
Antananarivo
(Madagascar)
Auckland Oceanic MONITOR NZZOCENTER [frequency]
Clearances/instructions relating to cruise climb are not issued within the Fukuoka
FIR. Therefore, downlink request DM#8 “REQUEST CRUISE CLIMB TO [ level ]”
should not be used.
- A 160 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
129 UM Report The United States has not used this message, but
level[altitude] will be phasing it in during the 2003-4 time period.
- A 161 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
- A 162 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
- A 163 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
Flight crews should continue to use the data link term until either the SELCAL
check has been completed or the frequency assignment has been received.
• If the flight will exit the CTA into oceanic airspace, on initial contact with
the CTA the pilot shall:
1. Not include a position report;
2. Use the appropriate data link term after the aircraft call sign (i.e. A-D-S,
F-M-C or C-P-D-L-C);
3. State the name of the next OCA/FIR to be entered; and
4. Request the SELCAL check.
- A 164 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
Example 3 (initial contact from an eastbound CPDLC flight about to enter the
New York Data Link service area):
NEW YORK ARINC, AIRLINE 123 C-P-D-L-C, GANDER NEXT, REQUEST SELCAL
CHECK CKFM.
• If the flight will exit the CTA into domestic airspace, on initial contact with
the CTA, the pilot shall:
1. Not include a position report;
2. Use the appropriate data link term after the aircraft call sign (i.e. A-D-S,
F-M-C or C-P-D-L-C);
3. State the track letter if operating on the Organized Track System (OTS);
4. State the last two fixes in the cleared route of flight if operating outside
the OTS; and
5. Request the SELCAL check.
Example 2 (initial contact from a westbound CPDLC flight about to enter the
Gander OCA):
GANDER RADIO, AIRLINE 123 C-P-D-L-C, SCROD VALIE, REQUEST SELCAL
CHECK DMCS.
Example 3 (initial contact from an eastbound FMC flight about to enter the
Shanwick OCA):
SHANWICK RADIO, AIRLINE 123 F-M-C, TRACK BRAVO, REQUEST SELCAL
CHECK CDAB.
• Depending on which data link services are offered in the CTA and the
operational status of those services, the AERADIO operator will provide
appropriate information and instructions to the flight crew (refer to
Guidance Material for ATS Data Link Services in North Atlantic Airspace for
details).
- A 165 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
• In the event an onboard systems failure prevents CPDLC, ADS WPR or FMC
WPR or if any of these services is terminated:
a. If the failure/termination occurs prior to initial contact with the
AERADIO station, do not use the phrase “A-D-S”, “C-P-D-L-C” or
“F-M-C” after the aircraft call sign;
b. Resume normal voice communications, including providing all
subsequent position reports via voice;
c. Do not inform AERADIO that the service has been terminated;
and
d. Inform Company Operations Department in accordance with
established problem reporting procedures.
• Flight crews are required to submit position reports via voice unless
otherwise advised by the AERADIO operator. To reduce frequency
congestion, when instructed “VOICE REPORTS NOT REQUIRED IN
(nominated OCA/FIR)” flight crews should not send position reports via
voice.
• ADS WPR flights, which have been instructed “VOICE REPORTS NOT
REQUIRED”, are exempt from all routine voice meteorological reporting,
however reports of unusual meteorological conditions such as severe
turbulence should be made by voice to the AERADIO station. CPDLC should
not be used for meteorological reports unless voice contact cannot be
established.
• Flight crews should not ask AERADIO questions regarding the status of the
ADS or CPDLC connections or whether an ADS WPR or an FMC WPR has
been received. Should ATC fail to receive an expected ADS WPR or FMC
WPR, they will request a voice report.
• When leaving NAT airspace, flight crews should comply with all
communication requirements applicable to the airspace being entered.
• If no domestic frequency assignment has been received by 10 minutes prior
to the flight’s entry into domestic airspace, the flight crew should contact
AERADIO and request the frequency, stating the oceanic exit fix.
- A 166 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
• The crew may assume that the estimate for the next waypoint, shown on
the FMS at the time a waypoint is crossed, is the estimate transmitted to
ATC in the ADS report. If that estimate subsequently changes by three
minutes or more, a revised estimate shall be transmitted via voice to the
ATS unit concerned as soon as possible.
• Flight crews should avoid inserting non-ATC waypoints (e.g. mid-points) in
cleared oceanic flight legs, as non-ATC waypoints may prevent the
provision of proper ETA data in the FMC reports required for ATC purposes.
If the flight number contains an alphabetic character (such as ABC132A or
ABC324W) the flight cannot participate in FMC WPR and the flight crew should not
use the term “F-M-C” during contact with AERADIO (refer to Guidance Material for
ATS Data Link Services in North Atlantic Airspace for details). Flight crews should
not use the initial contact procedures AERADIO, but should revert to normal voice
procedures.
- A 167 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
- A 168 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
Note: Use the ICAO four-character code when identifying the ATC.
Note: Use this phraseology when the NDA message delivery or address
forwarding is unsuccessful or when the END SERVICE message does not terminate
the CPDLC connection.
• To inform aircraft that the FANS 1/A data link has failed:
DATA LINK FAILED. SELECT ATC COM OFF. CONTINUE ON VOICE.
Note: This phraseology should only be included with the first transmission made
for this reason.
- A 169 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
Note: The pilot may use the ICAO four-character codes or plain language at
his/her discretion.
Note: This phraseology should only be included with the first transmission made
for this reason.
- A 170 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
- A 171 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
- A 172 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
- A 173 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
Flights entering Edmonton ADS airspace from airspace where FANS 1/A ATS data
link services are being received do not need to perform another AFN logon to
continue participating in ADS WPR. Flights entering Edmonton ADS airspace from
airspace where FANS 1/A ATS data link services are not being received should
ensure their ADS function is turned on and perform an AFN logon
• 15 to 45 min prior to entering the airspace; or
• prior to departure, for flights departing airports adjacent to or underlying
the airspace.
Flights exiting Edmonton ADS airspace into adjacent airspace where ADS and
controller-pilot data link communications (CPDLC) services are offered do not
need to perform another AFN logon to continue participating in ADS or to initiate a
CPDLC connection. Note: Currently, CPDLC services are not available in the
Edmonton FIR. Until CPDLC services are available, flights identifying themselves
as CPDLC will be advised “CPDLC SERVICE NOT AVAILABLE IN THE EDMONTON
FIR”.
3.2. FLIGHT CREW INITIAL CONTACT WITH EDMONTON CENTRE (PHASE 2, FLIGHT
IS RADAR IDENTIFIED)
Flights that have been radar identified by a previous unit and that will transit the
Edmonton FIR south of NCA 24 prior to entering the Edmonton ADS airspace
should not identify themselves as ADS (or CPDLC) on initial radio contact with
Edmonton Centre. Prior to each flight leaving radar coverage and thereby
approaching the Edmonton ADS airspace, Edmonton Centre will advise the flight
that radar service is terminated. At that time, participating flights should use the
term “A–D–S” (or “C–P–D–L–C”) after the aircraft call sign to indicate their
capability.
The following are sample exchanges with Edmonton Centre (Phase 2):
- A 174 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
3.3. FLIGHT CREW INITIAL CONTACT WITH EDMONTON CENTRE (PHASE 2, FLIGHT
IS NOT RADAR IDENTIFIED)
Flights that are not radar identified when making initial contact with Edmonton
Centre should:
1. Not include a voice position report; and
2. Use the term “A–D–S” (or “C–P–D–L–C”) after the aircraft call sign.
Flight crews can expect the reply from Edmonton Centre to include:
1. Acknowledgement that the flight is ADS (or CPDLC);
2. For Phase 2, the advisory VOICE REPORTS NOT REQUIRED; and
3. The assigned frequency for the next station en route.
The following is a sample exchange with Edmonton Centre (Phase 2):
EDMONTON CENTRE, AIRLINE EIGHT FIVE ONE A-D-S, FLIGHT LEVEL 350
AIRLINE EIGHT FIVE ONE A-D-S, EDMONTON CENTRE, VOICE REPORTS NOT
REQUIRED, CONTACT EDMONTON CENTRE AT INUVIK ON 134.47
- A 175 -
APPENDIX E Getting to grips with FANS – Part II – Issue III
Flight crews can expect the reply from Arctic Radio to include:
1. Acknowledgement that the flight is ADS (or CPDLC);
2. For Phase 2, the advisory “VOICE REPORTS NOT REQUIRED”;
3. An Arctic Radio frequency to monitor; and
4. The assigned frequency for the next station en route.
The following are sample exchanges with Arctic Radio, using four scenarios:
- A 176 -
Getting to grips with FANS – Part II – Issue III APPENDIX E
exact extent and effect of the shadow depends on atmospheric conditions, aircraft
antenna placement and direction of flight.
- A 177 -
APPENDIX F Getting to grips with FANS – Part II – Issue III
The dynamic re-routing procedure has been developed by the ISPACG forum to
provide FANS equipped aircraft with the possibility of a complete F-PLN change
once airborne. On the typical Los Angeles/Sydney or Los Angeles/Auckland routes,
the wind updates after the first hours of flight may happen to show that a better
F-PLN could be considered.
Procedures, based on an extensive use of the data link capabilities of the three
AOC, ATC and aircraft, have thus been developed to allow for the crew to get an
in-flight route re-clearance. The DARP scenario is described in the AIRBUS FANS A
CBT. The following describes the SPOM procedures, for a single re-route per flight,
as currently in use.
PREREQUISITES
• The airline shall have an AOC data link capability to communicate with both
the aircraft and the ATC with data link.
• The airline must be able to sustain CPDLC with the appropriate ATC, and
data link AOC with its operations centre.
• The ATC centres providing the control of the FIR where the re-routing will
be done must have CPDLC capability.
DESCRIPTIVE DRAWING
The following sequence is applied:
OAKLAND
• Oakland (ZOA) receives new weather forecast and loads it in its system
• ZOA Traffic Management Unit defines the DARP entry point on the original
track, at least 90 minutes ahead of the aircraft.
• ZOA TMU (Traffic Management Unit) defines a new track based on the old
route until the DARP entry point.
• ZOA TMU sends a new TDM (Track Definition Message) to all concerned
ATCs
- A 178 -
Getting to grips with FANS – Part II – Issue III APPENDIX F
• Once cleared, the crew activates the re-route and notifies it to its AOC
• The AOC transmits a Change message to the all concerned ATC (until AIDC
exists)
The following drawing gives a general view of all the co-ordinated sequences that
occur in a DARP phase.
2 – New Track
Definition
Meteo Centre
5 – Cleared 6 – Re-route
Route Notification
4 – Route Clearance
Request 3 – Revised
F-PLN
Although promising this procedure has not been used very much for the time
being, because it happens that the current wind models, as used by the airlines,
are precise enough within the frame of the flight. Activating the DARP procedure
requires a good co-ordination between all involved actors (Aircraft, AOC, ATC) .
The User Preferred Route procedure (UPR) is by far preferred by the airlines.
- A 179 -
APPENDIX G Getting to grips with FANS – Part II – Issue III
1. INITIAL NOTIFICATION
First, select the ATC Menu page on the MCDU (by pressing on the ATC COMM
function key), and then select the NOTIFICATION page.
FM 1 IN D RDY FM 2 FM 1 IN D RDY FM 2
AT SU DAT A L I N K AT C MENU
<WH E N C A N WE OT H E R R E Q>
T E XT>
- A 180 -
Getting to grips with FANS – Part II – Issue III APPENDIX G
FM 1 IN D RDY FM 2
The ATC FLT NBR is provided by the
FMGEC (set on the INIT page). The
N OT I F I C A T I ON
system has stored the last active ATC
A T C F L T N B R
A F 8 0 0
centre of the previous flight, here KZAK.
A T C C E N T E R In our example, this is the first ATC for
K Z A K – – – – – – – – – – – – – NOT I F Y * your flight.
A T C ME N U CON N E CT I ON
<R E T U RN ST AT U S>
BRT
FM 1 IN D RDY FM 2
KZAK NOTIFIED is displayed in green. It
means that the ATC has been notified of
N OT I F I C A T I ON the aircraft data link capability. It does
A T C F L T N B R
not mean that the connection has been
A F 8 0 0
A T C C E N T E R
performed.
– – – – – – – – – – – – – N O T I F Y
– – – – – K Z A K : N OT I F I E D – – – – –
A T C ME N U CON N E CT I ON
<R E T U RN ST AT U S>
BRT
DIM
NO A C T I V E A T C PRINT Once notified, the connection operation
is initialised by the ATC at their
MSG - PGE -
discretion.
MSG + PGE +
- A 181 -
APPENDIX G Getting to grips with FANS – Part II – Issue III
2. CPDLC CONNECTION
When the ATC centre initialises the
CPDLC connection, the display on the
BRT DCDU changes, and the active ATC is
DIM
ACT I VE AT C : KZAK CT L PRINT displayed on the DCDU. The ATC centre
has performed the connection operation
MSG - PGE -
and the communication is established.
MSG + PGE +
FM 1 IN D RDY FM 2
The aircraft is now able to exchange
data link messages. Here is how to
N OT I F I C A T I ON
check the connection status:
A T C F L T N B R
A F 8 0 0
Select the Connection Status page.
A T C C E N T E R
– – – – – – – – – – – – – N O T I F Y
A T C ME N U CON N E CT I ON
<R E T U RN ST AT U S>
BRT
- A 182 -
Getting to grips with FANS – Part II – Issue III APPENDIX G
MSG - PGE -
MSG + PGE +
RECAL L*
On the connection status page, KZAK is the active ATC. There is no NEXT ATC.
FM 1 IN D RDY FM 2 FM 1 IN D RDY FM 2
AT C MENU C ON N E C T I ON ST AT U S
A CT I V E A T C
< L AT REQ V E RT R E Q> K Z A K ––––––– D I S CONN E CT *
N E X T A T C
<WH E N C A N WE OT H E R R E Q> – – – –
T E XT>
–––––––– ADS : ON –––––––
<M S G L OG R E P ORT S > *S ET OF F
CON N E CT I ON
<N OT I F I C A T I ON ST AT U S>
A T S U D L K A T C ME N U
<R E T U RN EM E RG E N CY > <R E T U RN NOT I F I C AT I ON>
BRT BRT
Upon reception by the aircraft of an ATC message, both ATC MSG lights flash and
as it is a normal message, the first telephone ring is delayed by 15 s, then it will
be repeated every 15 s until the message is acknowledged (i.e. ATC MSG push-
button pressed or a key to treat the message is pressed).
- A 183 -
APPENDIX G Getting to grips with FANS – Part II – Issue III
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
FM 1 IN D RDY FM 2
C ON N E C T I ON ST AT U S
A CT I V E A T C
K Z A K ––––––– D I S CONN E CT *
N E X T A T C
K OA K
BRT
ACT I VE AT C : KZAK CT L PRINT
DIM
The message can be recalled by pressing
the RECALL soft key on the DCDU or MSG - PGE -
MCDU.
RECAL L*
- A 184 -
Getting to grips with FANS – Part II – Issue III APPENDIX G
An uplink ATC message is received: both ATC MSG lights flash and as it is a
normal message, the first telephone ring is delayed by 15 s, then it will be
repeated every 15 s until the message is acknowledged (i.e. ATC MSG push-
button pressed or a key to treat the message is pressed).
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
BRT
A C T I V E A T C : KOA K C T L PRINT
DIM
RECAL L*
4. CLEARANCE
In this scenario the aircraft receives the answer to its previous request.
An uplink ATC message is received: both ATC MSG lights flash and as it is a
normal message, the first telephone ring is delayed by 15 s, then it will be
repeated every 15 s until the message is acknowledged (i.e. ATC MSG push-
button pressed or a key to treat the message is pressed).
- A 185 -
APPENDIX G Getting to grips with FANS – Part II – Issue III
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
MSG + PGE +
On the second line, in white, the reply
indication, including the sending time of
* U N AB L E ST BY* the aircraft's request.
<OT HER W I L CO *
On the remaining lines, the ATC answer.
To ease the reading, uplink messages
are in white with the main parameters
highlighted in cyan.
- A 186 -
Getting to grips with FANS – Part II – Issue III APPENDIX G
MSG + PGE +
the FMS will recall the message to
MO N I T O R I N G remind the crew about this clearance.
* C AN C E L
SENT
During CPDLC exchanges, the FMS processes the ATC conditional or deferred
clearances that are linked to navigation. Then, when approaching a clearance
condition, the FMS is able to recall messages to alert the pilots.
About 30 s before the clearance condition, the FMS automatically displays the
deferred clearance text on the DCDU. This is indicated by the REMINDER
information and the visual and aural alerts.
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
- A 187 -
APPENDIX G Getting to grips with FANS – Part II – Issue III
MSG - PGE -
The time and active ATC fields at the top MSG + PGE +
of the screen are no longer displayed.
REM I NDER
MSG + PGE +
The CAN and CANNOT softkeys are
available.
* C AN NO T
C AN *
Press the CAN soft key. The response
message is automatically created.
the reply is displayed with the data field MSG - –––––––––––––––––––––––– PGE -
to fill in by means of the MCDU. MSG +
WE C A N A C C E P T F L 3 7 0 B Y [
PGE +
]
- A 188 -
Getting to grips with FANS – Part II – Issue III APPENDIX G
SEND
ADD T E XT
P A G E A T C
* C AN C E L MOD I F DI SPL
12H30
BRT
FM 1 IN D RDY FM 2
The time (foreseen to reach the flight
level 370) is displayed on the MCDU.
ME S S AG E MOD I F Y
T O K Z A K CT L
It is possible to add free text to the reply
by selecting ADD TEXT. This leads to the
WE CAN ACCEPT F L370 MCDU TEXT page:
B Y
12H30
ADD T E XT>
P A G E A T C
* C AN C E L MOD I F D I SP L*
BRT
- A 189 -
APPENDIX G Getting to grips with FANS – Part II – Issue III
FM 1 IN D RDY FM 2
It is possible to enter up to 4 lines of
free text, or to chose one of the
T E XT 1 / 2 ÅÆ
proposed reasons. For this example,
DU E T O DU E T O
ÅA / C P E R F O RM . M E D I C A LÆ chose the DUE TO A/C PERFORM. key.
DU E T O DU E T O The selected text is displayed in cyan.
ÅWE A T H E R T E CHN I C A LÆ
DU E T O A T P I L OT S
ÅT U R B U L E N C E D I S C R E T I ONÆ
– – – – – – F R E E T E X T – – – – – – –
[ ]
I N P U T S
*ERASE
A T C ME N U A T C
<R E T U RN MOD I F D I SP L*
BRT
FM 1 IN D RDY FM 2
Press the line key adjacent to the ATC
MSG DISPL* command on the MCDU.
T E XT 1 / 2 ÅÆ
This displays the prepared message on
DU E T O DU E T O
A/ C P E R F O RM . M E D I C A LÆ the DCDU.
DU E T O DU E T O
ÅWE A T H E R T E CHN I C A LÆ The MCDU page is refreshed, with the
DU E T O A T P I L OT S
default "ATC TEXT DISPL" text in line
ÅT U R B U L E N C E D I S C R E T I ONÆ
– – – – – – F R E E T E X T – – – – – – –
6R, but unavailable (no star). Options
[ ] are all available again to allow for
I N P U T S further message completion if required.
*ERASE
A T C ME N U A T C
<R E T U RN MOD I F D I SP L*
BRT
- A 190 -
Getting to grips with FANS – Part II – Issue III APPENDIX G
CAN
BRT
1 2H3 0 PRINT
DIM
D U E T O A / C P E R F O RM A N C E
* C AN C E L MO D I F Y *
PGE
2/ 2 SEND*
- A 191 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
1. INITIAL NOTIFICATION
The aircraft is flying from Los Angeles (KLAX) to Auckland (NZAA). The first ATC
for this flight is KZAK control and the crew wants to logon to it. The first step is to
notify the ATC centre of the aircraft data link capability.
AT SU D AT A L I N K
To display ATC pages, the hard key ATC COM can also be used either on MCDU for
A320/A330/A340 aircraft, or on KCCU for A380 aircraft.
- A 192 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
AT C MENU 1 / 2 ÅÆ
<WH E N C A N WE OT H E R R E Q>
T E XT >
The ATC FLT NBR is provided by the FMS (set on the INIT page). The system has
stored the last active ATC centre of the previous flight, here KZAK.
In our example, this is the first ATC for your flight. Select NOTIFY* in order to
notify the KZAK ATC centre.
- A 193 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
KZAK is displayed in green. It means that the ATC has been notified of the aircraft
data link capability. It does not mean that the connection has been performed.
The connection is confirmed on DCDU by the default message ACTIVE ATC.
Once notified, the connection operation is initialised by the ATC at its discretion.
Notes :
• The last 6 notified centres can be displayed on MCDU (respectively MFD).
• All the notification history will be deleted after each flight, 2 minutes after
the engine shut down.
• The notification time is provided on A380 MFD ATC COM pages only.
- A 194 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
2. CPDLC CONNECTION
When the ATC centre initialises the CPDLC connection, the DCDU display
(respectively ATC mailbox) changes, and the active ATC is displayed on DCDU
(respectively ATC mailbox). The ATC centre has performed the connection
operation and the communication is established.
A C T I V E A T C : K ZA K C T L
The aircraft is now able to exchange data link messages. Here is how to check the
connection status. Select the Connection Status page.
- A 195 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
Notice also the default status of the ADS function, set to “ARMED”. This means
that ADS is ready to work (ARMED : ready to accept contract with ground ATC
centres).
- A 196 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
A C T I V E A T C : K ZA K C T L
R E CA L L *
AT C MENU 1 / 2 ÅÆ
<WH E N C A N WE OT H E R R E Q>
T E XT >
On the connection status page, KZAK is the active ATC. There is no NEXT ATC.
- A 197 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
Upon reception by the aircraft of an ATC message, both ATC MSG lights flash and
as it is a normal message, the first telephone ring is delayed by 15 s, then it will
be repeated every 15 s until the message is acknowledged (i.e. ATC MSG push-
button pressed or a key to treat the message is pressed).
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
- A 198 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
1 1 0 7 Z F ROM K Z A K CT L
N EX T A T C : KOA K C T L
C L O S E
When the connection is established with the next ATC centre, the name of the
next ATC centre is displayed in the MCDU CONNECTION STATUS page
(respectively MFD) in the NEXT ATC field.
C ON N E CT I ON ST AT U S
A CT I V E A T C
K Z A K ––––––– D I S CONN E CT *
N E X T A T C MS G L A T E N C Y
K OA K N ON E
– – – – – – – – – ADS : A RM E D – – – – –
*S ET OF F
ADS DET A I L
A T C ME N U
<R E T U RN N OT I F I C AT I ON >
Once the message is closed,: the DCDU screen (respectively ATC mailbox) is
cleared. The active ATC is still KZAK and will change only when KZAK terminates
the connection.
The message (as a general rule, the last processed message) can be recalled by
pressing the RECALL soft key on the DCDU (respectively ATC mailbox) or
displayed in the MSG RECORD page on MCDU (respectively MFD).
- A 199 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
A C T I V E A T C : K ZA K C T L
R E C A L L *
An uplink ATC message is received: both ATC MSG lights flash and as it is a
normal message, the first telephone ring is delayed by 15 s, then it will be
repeated every 15 s until the message is acknowledged (i.e. ATC MSG push-
button pressed or a key to treat the message is pressed).
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
The message CONTACT coupled with the message SERVICE TERMINATED are
received from KZAK and displayed on DCDU (respectively ATC mailbox). These
messages mean that KZAK instructs t contact the next ATC centre on the given
frequency and ends the data link connection when the flight crew answers the
message. The NDA, which was connected in a passive mode becomes active at
this time.
Press the CLOSE soft key to clear the DCDU screen (respectively ATC mailbox)
and to store the message in the MSG RECORD.
- A 200 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
Once the message is closed, the DCDU screen (respectively ATC mailbox) is
cleared. The new active ATC (KOAK) is displayed on DCDU (respectively ATC
mailbox). The flight crew shall contact KOAK via voice on the given frequency.
4. CLEARANCE
The exchange of messages described in this scenario and the DCDU associated
HMI are the same for FANS A and FANS A+.
Both ATC MSG lights flash and as it is a message of normal priority, the first
telephone ring is delayed by 15 s, then it will be repeated every 15 s until the
message is acknowledged (i.e. ATC MSG push-button pressed or a key to treat
the message is pressed).
Press on the ATC MSG pushbutton to extinguish the lights and stop the aural
signal.
ATC ATC
MSG MSG
- A 201 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
If the clearance cannot be complied with, select UNABLE. You are able to insert text
to justify the refusal.
AT C MENU 1 / 2 ÅÆ
<WH E N C A N WE OT H E R R E Q>
T E XT >
- A 202 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
Select the DUE TO A/C PERFORM prompt Select the DUE TO button and select the
for instance and transfer the text to the A/C PERF option.
DCDU.
- A 203 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
By selecting CANCEL, the ATC mailbox display returns to the initial state.
- A 204 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
About 30 seconds before the monitoring condition is met, the visual and aural
alerts are triggered. In addition, a reminder pops up on the DCDU (respectively
ATC mailbox). The reminder includes the clearance and the operational response
made by the flight crew.
ATC ATC
MSG MSG
Press the CANNOT soft key. The response message is automatically created. If
required, the response can be modified on MCDU (respectively MFD) through the
MODIFY soft key.
- A 205 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
1 5 4 9 Z F ROM K Z A K CT L O P EN
WH E N C A N YOU A C C E P T
F L 3 7 0
– – – – – – – – – – – – – – – – – – – – – – – –
WE C A N A C C E P T F L 3 7 0 NOW
[ 1 5 4 9 Z ]
* CA NN OT MOD I F Y *
<OT H E R S E N D*
1 5 4 9 Z F ROM K Z A K CT L O P EN
WH E N C A N YOU A C C E P T
F L 3 7 0
– – – – – – – – – – – – – – – – – – – – – – – –
WE C A NNOT A C C E P T F L 3 7 0
* CA N C E L MOD I F Y *
<OT H E R S E N D*
Under the reply, the MCDU FOR MODIF (respectively MFD FOR MODIF)
information is displayed.
1 5 4 9 Z F ROM K Z A K CT L O P EN
WH E N C A N YOU A C C E P T
F L 3 7 0
– – – – – – – – – – – – – – – – – – – – – – – –
WE C A NNOT A C C E P T F L 3 7 0
<OT H E R S E ND *
- A 206 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
Select the positive response (e.g. CAN FL370 for A320/A330/A340 aircraft or WE
CAN ACCEPT for A380 aircraft). Once selected, time may be modified.
ME S S AGE MOD I F Y
ÅC AN F L370
C ANNOT F L370
P A G E
* C AN C E L ADD T E XT>
A T C R E P O RT S A T C
<R E T U RN MOD I F D I SP L*
ME S S AGE MOD I F Y
CA N F L 3 7 0 A T
1549Z
ÅC AN N OT F L370
P A G E
* C AN C E L ADD T E XT>
A T C R E P O RT S A T C
<R E T U RN MOD I F D I SP L*
- A 207 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
ME S S AGE MOD I F Y
CA N F L 3 7 0 A T
1549Z
ÅC AN N OT F L370
P A G E
* C AN C E L ADD T E XT>
A T C R E P O RT S A T C
<R E T U RN MOD I F D I SP L*
1555Z
By pressing ATC MODIF DISPL, the From the MFD, the transfer to the ATC
modification can be transferred to mailbox is controlled with the XFR TO
DCDU. MAILBOX button.
ME S S AGE MOD I F Y
CA N F L 3 7 0 A T
1555Z
ÅC AN N OT F L370
P A G E
* C AN C E L ADD T E XT>
A T C R E P O RT S A T C
<R E T U RN MOD I F D I SP L*
- A 208 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
If you wish to append a text to the response, press MODIFY to call the MESSAGE
MODIFY page on MCDU (respectively MFD). From this page, select ADD FREE TEXT.
1 5 4 9 Z F ROM K Z A K CT L O P EN
WH E N C A N YOU A C C E PT
F L 3 7 0
– – – – – – – – – – – – – – – – – – – – – – – –
WE C A N A C C E PT F L 3 7 0 A T
1 5 5 5 Z
* CA N NOT MOD I F Y *
<OT H E R S E N D*
ME S S AGE MOD I F Y
CA N F L 3 7 0 A T
1555Z
ÅC AN N OT F L370
P A G E
* C AN C E L ADD T E XT>
A T C R E P O RT S A T C
<R E T U RN MOD I F D I SP L*
- A 209 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
T E XT 1 / 2 ÅÆ
DU E T O DU E T O
ÅA / C P E R F O RM . M E D I C A LÆ
DU E T O DU E T O
ÅWE A T H E R T E CHN I C A LÆ
DU E T O A T P I L OT S
ÅT U R B U L E N C E D I S C R E T I ONÆ
– – – – – – F R E E T E X T – – – – – – –
[ ]
A L L F I E L D S
ERASE
A T C ME N U A T C
<R E T U RN T E XT DI SPL
T E XT 1 / 2 ÅÆ
DU E T O DU E T O
A/ C P E R F O RM . M E D I C A LÆ
DU E T O DU E T O
ÅWE A T H E R T E CHN I C A LÆ
DU E T O A T P I L OT S
ÅT U R B U L E N C E D I S C R E T I ONÆ
– – – – – – F R E E T E X T – – – – – – –
[ ]
I N P U T S
*ERASE
A T C ME N U A T C
<R E T U RN MOD I F D I S P L*
- A 210 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
In this case, the addition of a free text requires a second page on DCDU
(respectively ATC mailbox) as the five lines of the screen are already filled in.
Before sending a message displayed on several pages, it has to be entirely
review. Scroll the message down until the last page. The SEND soft key becomes
available. Press the SEND soft key.
1 5 5 5 Z
DU E TO A / C P ER FORMA NC E
* CA N C E L MOD I F Y *
P G E
2 / 2 S E N D*
1 1 5 4 Z F ROM K Z A K CT L
WH E N C A N YOU A C C E PT
F L 3 7 0
– – – – – – – – – – – – – – – – – – – – – – – –
WE C A N A C C E PT F L 3 7 0 A T
1 5 5 5 Z
S E N T
P G E
1 / 2 C L O S E *
Under the reply, the SENDING information is displayed until the acknowledgement
from the ground network is received. The message body turns into green once
SEND is selected.
6. MSG RECORD
Once a message is closed on DCDU (respectively ATC mailbox), it is stored in the
MSG RECORD. The storage capacity is up to 99 messages. When this limit is
reached, the oldest message is deleted to store the most recent one.
Messages in the MSG RECORD are sorted in the chronological order (i.e. from the
most recent message to the oldest one).
- A 211 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
Up to four messages per page are The same kinds of features as on MCDU
displayed on MCDU. The time, the are provided on MFD.
addressee/addresser, the first line of the
message and the associated response if
any are provided.
- A 212 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
To display the entire message on MCDU, To display the entire message on MFD,
select the prompt at the left side of the select the triple rightward arrow at the
chosen message. right side of the chosen message.
- A 213 -
APPENDIX H Getting to grips with FANS – Part II – Issue III
Select MSG RECORD ERASE function to Select ERASE ALL button to erase the
erase the MSG RECORD on MCDU. MSG RECORD on MFD.
- A 214 -
Getting to grips with FANS – Part II – Issue III APPENDIX H
- A 215 -
APPENDIX I Getting to grips with FANS – Part II – Issue III
M C DU ME N U
<F M1
<AT S U
- A 216 -
Getting to grips with FANS – Part II – Issue III APPENDIX I
AT C MENU 2 / 2 ÅÆ
– – – – – A T S 6 2 3 P A G E – – – – – –
<D E P A R T REQ AT I S>
<O C E A N I C REQ
A T S U D L K
<R E T U RN
- A 217 -
APPENDIX I Getting to grips with FANS – Part II – Issue III
As all mandatory fields are completed, REQ DISPL (respectively XFR TO MAILBOX)
function becomes available. A free text may be also appended to the request.
- A 218 -
Getting to grips with FANS – Part II – Issue III APPENDIX I
- A 219 -
APPENDIX I Getting to grips with FANS – Part II – Issue III
MO R E F REE T E XT
CH A RT E R E D F L I GHT
[ ]
[ ]
[ ]
D E P A RT R E Q A T C D E P A RT
<R ET U RN REQ D I S P L*
175 PAX ON BOA RD
The request is now completed and may be transferred to DCDU (respectively ATC
mailbox).
- A 220 -
Getting to grips with FANS – Part II – Issue III APPENDIX I
MO R E F REE T E XT
CH A RT E R E D F L I GHT
[ ]
[ ]
D E P A RT R E Q A T C D E P A RT
<R ET U RN REQ D I S P L*
The Departure request on DCDU (respectively ATC mailbox) lies on two pages.
The request cannot be sent until it has been entirely reviewed.
To review a message on several pages, scroll down with PGE+ key (respectively
button with double downward arrows).
Page 2/2 is displayed and it is now possible to send the message: select SEND.
- A 221 -
APPENDIX I Getting to grips with FANS – Part II – Issue III
O P EN
A / C T Y P E : A 3 2 0
C HA R T ER ED F L I GHT
1 7 5 P A X ON BOA R D
* CA N C E L
PG E
2 / 2
S E N D*
The message switches to green inverse video, indicating that is being sent. The
first page is displayed, with the SENDING indication.
The SENT information indicates that the message has been received by the
ground network. It is now possible to close the message. Closing the message
stores it in the message log. Select CLOSE.
The default screen is displayed, and the previous message can be recalled if
required.
- A 222 -
Getting to grips with FANS – Part II – Issue III APPENDIX I
R E CA L L *
The flashing ATC MSG pushbuttons and the aural warning (telephone ring)
indicate that a message from the ATC has been received: extinguish the alert by
pushing a pushbutton.
ATC ATC
MSG MSG
The received message is the departure clearance. Its status for the moment is
OPEN because no answer has been prepared yet.
The REFUSE and ACK answers are now selectable. For this example, select
REFUSE.
- A 223 -
APPENDIX I Getting to grips with FANS – Part II – Issue III
O P EN
C L R D TO : K J F K
RWY : 0 9 S I D : B N E 8 A
SQK : 5 0 2 3 S LOT : 1 1 3 5 Z
F R EQ : 1 2 4 . 2 5 A T I S : H
HA V E A N I C E F L I GHT
* R E F U S E
P G E
<OT H E R 2 / 2 A C K*
According to AEEC 623 protocol, the refusal is not supported by data link.
Consequently, on DCDU (respectively ATC mailbox), a reminder is inserted before
the clearance. The received clearance is repeated on the following pages, in
green: select PGE+ (respectively button with double downward arrows) to see the
clearance.
1 0 5 9 Z F ROM L F P G CT L R E F U S E
CONT A C T A T C B Y VO I C E
R E F U S E NOT SU P POR T ED
B Y DA T A L I NK
– – – – – – – – – – – – – – – – – – – – – – – –
DE P A R T C L EA R A NC E NO 1 4 6
* CA N C E L
P G E
<OT H E R 1 / 3 C L O S E *
On each page of the refused clearance, the status "REFUSE" is displayed. However
it is displayed in white, meaning that no downlink message has been sent.
For training purposes, cancel the refusal. As no message has been sent to the
controller, the refusal is transparent to the ground. Select CANCEL.
- A 224 -
Getting to grips with FANS – Part II – Issue III APPENDIX I
R E F U S E
C L RD TO : K J F K
RWY : 0 9 S I D : B N E 8 A
SQK : 5 0 2 3 S LOT : 1 1 3 5 Z
F R EQ : 1 2 4 . 2 5 A T I S : H
HA V E A N I C E F L I GHT
* CA N C E L
P G E
<OT H E R 3 / 3 C L O S E *
The clearance is displayed with the 'open' status, and the ACK and REFUSE
functions are proposed. To accept the clearance, select ACK.
The message is displayed in the 'ACK' status. To send the Departure clearance
read back, select SEND.
- A 225 -
APPENDIX I Getting to grips with FANS – Part II – Issue III
When the ground service provider acknowledges reception of the message, the
information 'sent' is displayed. At that time, the indication that the flight crew will
receive a confirmation of its read back is displayed. Before the confirmation is
received, it is highly recommended to close the message as usual.
1 0 5 9 Z F ROM L F P G CT L A C K
P G E
<OT H E R 1 / 2 C L O S E *
When the confirmation of the read back arrives, it is indicated to the crew with the
visual and aural alerts: extinguish the alerts by pressing the ATC MSG
pushbutton.
ATC ATC
MSG MSG
The departure clearance is confirmed. Close the message to clear the DCDU,
respectively ATC mailbox.
- A 226 -
Getting to grips with FANS – Part II – Issue III APPENDIX I
From an operational point of view, the flight crew shall execute the clearance
(departure or oceanic) only once the confirmation is received on-board.
- A 227 -
APPENDIX J Getting to grips with FANS – Part II – Issue III
1. A320/A330/A340 AIRCRAFT
ATSU FAILURE
The ATSU is not working anymore. Data
link communications between the
aircraft and the ground are not
available.
The ATSU failure affects both ATC and
AOC applications. The flight crew shall
contact ATC by voice if any ATC was
connected.
The DATALINK ATSU FAULT caution is
displayed on EWD.
The flight crew should wait for 5 minutes before contacting ATC by voice. After 5
minutes, the loss may be considered as stable. At the time of writing the
document, the 5-minute period was being discussed within FANS interoperability
meetings and may change. In any cases, the National regulations apply.
- A 228 -
Getting to grips with FANS – Part II – Issue III APPENDIX J
- A 229 -
APPENDIX J Getting to grips with FANS – Part II – Issue III
- A 230 -
Getting to grips with FANS – Part II – Issue III APPENDIX J
2. A380 AIRCRAFT
ACR FAILURE
The ACR1 (and ACR2 if installed) is (are)
not working anymore. Data link
communications between the aircraft
and the ground are not available.
The ACR failure affects all applications
using data link (i.e. ATC, AOC, AAC).
The flight crew shall contact ATC by
voice if any ATC was connected.
The COM DATALINK FAULT caution is
displayed on EWD.
Thanks to the A380 architecture, the ACR manages the communication means
and the ATC applications manage the ATC communications, contrary to the ATSU
that manage both communication means and ATC communications.
If the ACR is not recovered within the first 16 minutes, the consequences
on ATC mailbox are the ones described for the definitive loss of ATC
communications.
The flight crew should wait for 5 minutes before contacting ATC by voice. After 5
minutes, the loss may be considered as stable. At the time of writing the
document, the 5-minute period was being discussed within FANS interoperability
meetings and may change. In any cases, the National regulations apply.
- A 231 -
APPENDIX J Getting to grips with FANS – Part II – Issue III
If the ACR fails to recover the data link communications within 16 minutes, an
abnormal ATC data link disconnection occurs. Refer to description below.
- A 232 -
Getting to grips with FANS – Part II – Issue III APPENDIX J
ATC mailbox
- A 233 -
APPENDIX K Getting to grips with FANS – Part II – Issue III
I/ VALIDITY:
ALL A330 AND A340 AIRCRAFT EQUIPPED WITH FANS A
- FORWARD FIT: MODIFICATION 48227 EMBODIED
- RETROFIT: AIRBUS SB A330-46-3006/A340-46-4010.
A340-600 AND A340-500 ARE NOT CONCERNED BY THIS OIT/FOT SINCE THE
SUBJECT CONFIGURATION IS BASIC AT THE ENTRY INTO SERVICE.
II/ REASON
III/ DESCRIPTION
IIIA) ATSU
- A 234 -
Getting to grips with FANS – Part II – Issue III APPENDIX K
IIIB) FMS
- A 235 -
APPENDIX K Getting to grips with FANS – Part II – Issue III
ON BOTH FMS ON THE AIRCRAFT VIA THE MDDU. INDEED, USE OF THE
CROSSLOADING FUNCTION FOR FM OPERATIONAL SOFTWARE (FIN 1CA0M3)
UPGRADE ON SECOND FMS IS FORBIDDEN DUE TO A P1 SOFTWARE UPLOAD
LIMITATION, ADDRESSED THROUGH P2 UPGRADE.
BUT FMS CROSSLOADING CAN BE USED FOR SECOND FMS UPLOADING WITH
FM
PERFORMANCE DATABASE (FIN 1CA0M2), OPERATIONAL PROGRAM
CONFIGURATION (OPC), AIRLINE MODIFIABLE INFORMATION (AMI) AND
NAVDATABASE.
2/ A340
FMS P2A10 UPGRADE FROM P1A9 FOR CFMI ENGINES CONSISTS IN:
- FMGEC HARDWARE CHANGE TO PN C12858AA03 FROM PN C12858AA02 VIA
FG
OBRM REPLACEMENT
- ABOVE MENTIONED FM PERFORMANCE DATABASE (FIN 1CA0M2) AND FM
OPERATIONAL SOFTWARE (FIN 1CA0M3) UPGRADES, APPLY ALSO TO THE A340
(SAME SOFTWARE PN) AND ARE ALSO TO BE DONE ON AIRCRAFT. THE SAME
CROSSLOADING LIMITATIONS OF ABOVE CAUTION PARAGRAPH APPLY TO
P2A10
UPGRADE ON A340.
IV) RECOMMENDATION
IN ORDER TO EASE ATSU CLR3.6B AND FMS P2 RETROFIT ON ALL AIRCRAFT
TYPES, CORRESPONDING AIRBUS SB'S WILL NOT BE PHYSICALLY LINKED.
THIS WILL ALLOW PROCEEDING SEPARATELY WITH ATSU THEN FMS RETROFIT.
- A 236 -
Getting to grips with FANS – Part II – Issue III APPENDIX K
V) RETROFIT
ATSU CLR3.6B/FMS P2 RETROFIT, MONITORED BY AIRBUS (SET4), WILL
START SOON AFTER SB ISSUE AND WILL BE ANNOUNCED BY A RETROFIT
INFORMATION LETTER.
EACH OPERATOR WILL THEN BE CONTACTED INDIVIDUALLY BY AIRBUS
FRANCE
AND THALES AVIONICS, THROUGH A CUSTOMIZED RETROFIT PLANNING
LETTER
(RPL), IN ORDER TO FORMALIZE THE LOGISTICAL ASPECTS OF THE
RETROFIT CAMPAIGN.
QUOTE
- DURING FLIGHTS ON NORTH ATLANTIC ROUTES, IT HAS BEEN REPORTED
THAT, SOMETIMES, ADS REPORTS ARE NOT TRIGGERED WHEN OVERFLYING A
WAYPOINT. WHEN THE FMS2 IS THE MASTER, AND SEQUENCES A WAYPOINT
BEFORE FMS1, IT MAY OCCUR THAT THE ATSU DOES NOT DETECT THE
WAYPOINT CHANGE EVENT.
TO AVOID MISSING ADS REPORTS, WHEN OVERFLYING A WAYPOINT, DO NOT
USE AP2 DURING ADS OPERATIONS.
UNQUOTE
- A 237 -
APPENDIX K Getting to grips with FANS – Part II – Issue III
BEST REGARDS.
P. GLAPA C. MONTEIL
VICE PRESIDENT, SYSTEMS & POWERPLANT VICE PRESIDENT
ENGINEERING SERVICES FLIGHT OPERATIONS
CUSTOMER SERVICES DIRECTORATE SUPPORT AND LINE
ASSISTANCE
- A 238 -
Getting to grips with FANS – Part II – Issue III APPENDIX L
TO: A300/A300-600/A310/A318/A319/A320/A321/A330/A340/A340-500/A340-
600
OPERATORS.
1/ PURPOSE
The purpose of this OIT is to:
- Advise Airbus customers that the new INMARSAT 4 Satellite will start broadcast
with an extended number of spot-beams. This can affect the users of Rockwell-
Collins and Honeywell Aero I and Aero H-PLUS SATCOM systems,
2/ BACKGROUND
Airbus has been informed by Rockwell-Collins and Honeywell that the entry into
service of the extended spot-beam map on INMARSAT 4 constellation scheduled
on 31st Oct 2006 with the Atlantic Ocean Region West satellite (AOR-W), can lead
to disruptions on SATCOM systems, depending on the geographical position of the
aircraft.
- A 239 -
APPENDIX L Getting to grips with FANS – Part II – Issue III
The full broadcast with the 19 spot-beams will be activated with the AOR-W
Satellite on 31st Oct. 2006. This activation was initially scheduled for 01 Jul 2006.
It has recently been reported by IMMARSAT in order to leave more time to the
Operators to perform the SATCOM upgrades as necessary.
3/ CAUSES/CONSEQUENCES
3.1/ EFFECT ON ROCKWELL-COLLINS SATCOM SYSTEMS
For Rockwell-Collins systems, the Vendor has identified that Aero I and Aero H-
PLUS systems can present resets when trying to logon to the requested Ground
Earth Station.
This results in logon/reset cycles that can repeat several times as long as the
aircraft is flying in the new INMARSAT Satellite spot-beam. Then, the SDU
(Satellite Data Unit) will eventually recover its normal operation after having
acquired the new INMARSAT 4 system tables broadcast by the Satellite (AOR-W).
In the mean time, Voice or Data communications using SATCOM will be
interrupted during these repeated logon/reset cycles with affected units.
This disruption can already occur when connecting to the AOR-W satellite. The
transition to the broadcast with 19 spot-beams to come with the AOR-W satellite
(from 31 Oct 2006 on) will not have any additional effect on these avionics.
The affected SDU Part Numbers from Aero H-PLUS Rockwell-Collins SAT-906
family, currently certified by Airbus on A330/A340 family that have the potential
to reset, are listed here below.
- PN 822-0314-303, installed through MOD 49352,
- PN 822-0314-350, installed through MOD 52730.
The affected SDU Part Numbers from Aero I Rockwell-Collins SRT-2000 family,
currently certified by Airbus on A318/A319/A320/A321 that have the potential to
reset, are listed here below:
- PN 822-1348-401, installed through MOD 28137,
- PN 822-1349-401, installed through MOD 28138,
- PN 822-1405-401, installed through MOD 28208.
- A 240 -
Getting to grips with FANS – Part II – Issue III APPENDIX L
Since the next coming extension of broadcast from 14 to 19 spot-beams for the
AOR-W satellite does not change anything for the Rockwell-Collins avionics, and
since such an avionic can already be affected by the issue if flying in the AOR-W
zone, it is recommended to perform this software upgrade at the soonest
opportunity (without consideration of the 31st Oct 2006 date).
- A 241 -
APPENDIX L Getting to grips with FANS – Part II – Issue III
For more information on these SDU software modifications, Honeywell has also
issued the Technical Newsletter A23-5111-008 "Software Modification to SD-600/-
700 Satellite Data Unit."
5/ FOLLOW-UP PLAN
No specific follow-up of this OIT is planned.
Questions about the technical content of this OIT are to be addressed to:
Mr G. Martins, Dept SEE44,
Phone: +33/(0)5 67 19 03 74,
Fax: +33/(0)5 61 93 44 25
E-mail: georges.martins@airbus.com
Best Regards,
P. GLAPA
VICE PRESIDENT ENGINEERING SUPPORT
CUSTOMER SERVICES
- A 242 -
Getting to grips with FANS – Part II – Issue III APPENDIX M
This document is primarily intended for Operators, ATC Service Providers and
National Aviation Authorities.
- A 243 -
APPENDIX M Getting to grips with FANS – Part II – Issue III
A certification process was performed for each FANS configuration on any Airbus
aircraft model. As a consequence, an Airworthiness Approval Summary is
applicable to a given FANS configuration and a given aircraft model.
To a get a copy of the appropriate Airworthiness Approval Summary, please
mention to the AIRBUS engineering support one of the following references :
- A 244 -
Getting to grips with FANS – Part II – Issue III APPENDIX N
In order to modify data contained in PRODB and CSTDB for ACR (and RPDB for
ATSU) when ATC are installed, a safety analysis has been conducted on all
parameters to classify the potential failures caused by an erroneous parameter in
database. The main outcome of this analysis leads to a Major safety impact. That
means that a modification of a parameter may "alter" the DAL C of ACR (ATSU).
Conclusion: in order to modify data contained in PRODB and CSTDB for ACR (and
RPDB for ATSU) when ATC are installed, a specific process has to be put in place
in order to guarantee that there is no corruption or error in the format or content
of database, or no incompatibility between databases and aircraft systems.
- A 245 -
APPENDIX N Getting to grips with FANS – Part II – Issue III
Limitations:
• The Standard VHF World Map is defined 1 or 2 years before the EASA
Certification Approval. VHF World Map is not necessarily the last update
VHF World Map when EASA Certification Approval is obtained.
• Errors may occur during the selection of VHF Scan Mask or during the input
of A/L ID by the airline. For instance unsubscribed DSP selected in VHF
Scan Mask may lead to undetected loss of communication, with a potential
Major Safety impact for ATC applications.
- A 246 -
Getting to grips with FANS – Part II – Issue III APPENDIX N
Why the choice of a database and why the database shall be defined by each
airline before delivery?
• Configuration of ACR will not be easy to define manually with HMI due to
new ACR mechanisms (for instance: routing policy for each area...).
• Moreover provisions for ATN and security will also make more complex the
configuration of ACR. It has been anticipated that the future introduction of
an ATN stack or Security for the data link in the ACR will make more
complex the customization, and would hence have become impractical via
an avionics HMI.
• ACR HMI has been minimized to fit on the RMP and should be minimalist.
Developing the ACR HMI on CDS would have increased the ACR cost and
complexity.
• On ATSU, some airlines have asked Airbus to protect the VHF Scan Mask
MCDU access by a password or other solutions. Airbus has chosen the
database to answer to this airline need.
• For ACR configuration, it is faster to load a database than to enter manually
all parameters.
• Tools will be proposed to airlines to customize their own database after EIS.
- A 247 -
Getting to grips with FANS – Part II – Issue III
- A 248 -
Getting to grips with FANS – Part III – Issue III Table of contents
Abbreviations....................................................................................................................... 3
-B1-
Table of contents Getting to grips with FANS – Part III – Issue III
-B2-
Getting to grips with FANS – Part III – Issue III Abbreviations
ABBREVIATIONS
-B3-
Abbreviations Getting to grips with FANS – Part III – Issue III
-B4-
Getting to grips with FANS – Part III – Issue III Abbreviations
-B5-
Abbreviations Getting to grips with FANS – Part III – Issue III
-B6-
Getting to grips with FANS – Part III – Issue III Executive Summary
Pre-flight phase
Pre-flight checks
Prior to departing for a FANS flight, the crew will check that the required
equipment is operative. The following items are recommended to be included in
those checks :
- GPS availability
- UTC time settings
- RNP capability
- Data link communications availability
- The initialization of data link systems :
• On MCDU>ATSU MENU>COMM MENU>COMM CONFIG page for the
Aircraft Registration Number,
• On MCDU>ATSU MENU>ATC MENU>NOTIFICATION page for the flight
number.
- Airlines’ priority list of contracted DSP for FANS operations with this
aircraft
Notification procedures
The aim of the notification is to :
- Notify the appropriate ATC centre of the capabilities and specifics of the
aircraft data link communication applications,
- Give the flight identification, the aircraft address, and the departure and
destination airports.
When no other CPDLC connections have been established with a previous ATC
centre, the flight crew must perform a DLIC notification (e.g. prior to departure,
prior to entering a data link airspace).
-B7-
Executive Summary Getting to grips with FANS – Part III – Issue III
CPDLC procedures
CPDLC connection
o Once the DLIC notification has been successfully done, the ATC centre will
initiate a CPDLC connection (no action required from the flight crew). CPDLC
messages shall only be sent when the aircraft is assumed by the ATC (i.e.
reception of the uplink message indicating the name of the ATC).
o Checks are automatically done by the ATSU to validate or reject the
connection:
- Connection is accepted if no previous connection already exists or, it is
relative to the next data link ATC to control the aircraft
- Connection is rejected in all other cases
o Once connection is established:
- For the technical connection, the active connected ATC centre is then
displayed on the DCDU, and on the CONNECTION STATUS page of the
MCDU.
- For the operational connection, a uplink message indicating the name of
the current ATC (e.g. EDYY, MAASTRICHT, CENTER) is received.
o Any received message shall be promptly answered (100-second timer)
and shall be closed once the response has been sent.
o A Voice read-back is required for any messages related to any changes of
the aircraft trajectory in the framework of the FANS B system.
-B8-
Getting to grips with FANS – Part III – Issue III Executive Summary
DCDU management
When a message is received by the ATC ground system (i.e. RECEIVD BY ATC
indication is displayed on DCDU), always close the message via the CLOSE soft
key to clear DCDUs. Once closed, the message can be recalled via the RECALL soft
key.
FANS B retrofit
To install the FANS B package on a A320 aircraft, the following equipment is
required :
- 1 ATSU CSB5,
- 2 DCDUs;
- 2 ATC message push-buttons,
- 1 VHF Data Radio (VDR) for data and voice communications capable of
VDL mode 2.
o For the time being only remote areas such as oceanic or desert areas are
implemented with FANS over ACARS network, and European airspaces with
FANS over ATN. The deployment over FAA airspaces is frozen.
o In European airspaces, VHF channels are congested and CPDLC is expected to
alleviate these congested channels. Surveillance is still performed via SSR.
o FANS operations over ATN will be deployed over the European airspaces on a
step-by-step basis until 2011.
-B9-
Executive Summary Getting to grips with FANS – Part III – Issue III
Operational approval
Individual operational authority may choose the "means of compliance" stating
what the applicant airline may have to demonstrate. However, the following items
will have to be complied with :
- Aircraft configuration
The aircraft should be configured in accordance with the approved
certification configuration for FANS B operations
- Flight crew training/qualification
Operating an aircraft in a FANS type environment requires from the crew
understanding, knowledge and operational use of the three C, N and S
dimensions of the CNS/ATM concept.
- Maintenance training
An appropriate maintenance training program relative to the digital
communications, must be given to maintenance people
- Approved operational documentation
The applicant airline should present to its relevant authority the FANS B
Airworthiness Approval Summary, the MEL and the AFM to be
approved.
- B 10 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
B5.1 Introduction 13
B5.2 Pre-flight phase 13
B5.2.1 ICAO flight plan filling 13
B5.2.2 Pre-flight checks 14
B5.3 Notification procedures 16
B5.3.1 Data Link Initiation Capability (DLIC) service 16
B5.3.1.1 Manual notification with logon function 16
B5.3.1.2 Automatic notification with Contact function 17
B5.4 CPDLC procedures 19
B5.4.1 Initial CPDLC connection 19
B5.4.2 CPDLC connection transfer 22
B5.4.2.1 Transfer between ATC centres 22
B5.4.2.2 Abnormal cases at the time of the transfer of connection 26
B5.4.3 CPDLC termination 26
B5.4.3.1 During a transfer from one ATC centre to another, both using 26
CPDLC
B5.4.3.2 During a transfer from one ATC centre using CPDLC to 26
another using CPDLC
B5.4.3.3 Open dialogue during CPDLC termination 28
B5.4.4 Inhibition of CPDLC application 28
B5.4.5 Failures of the CPDLC connection 28
B5.4.6 Intentional CPDLC shutdown 28
B5.4.7 Loss of communication means 29
B5.4.8 Use of CPDLC in the event of voice radio 29
communication failure
- B 11 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
- B 12 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
B5.1. INTRODUCTION
The following chapter depicts some important and general procedures for an
operational use of CNS/ATM systems.
As already explained FANS operations are and will regionally started, based on the
availability of ground equipment and technologies. Operational procedures are
defined and published in Flight Crew Data Link Guidance for Link 2000+ Services.
The following procedures are based on this document as per 15 JAN 07 (available
at http://www.eurocontrol.int/link2000/public/standard_page/specific_docs.html).
In ATN environment for Pioneer and Incentive phases of the Link 2000+
programme, voice communications remain the primary means of
communication. If the flight crew experiences any difficulty to maintain data link
communications, the flight crew shall revert to voice.
- B 13 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
The A/C ICAO CODE is also to be notified in the field 18 preceded by CODE/.
This will be used for correlation purposes by the ATC through a comparison of it
with the one contained in the notification. Refer to B5.2.2 – Pre-flight checks.
• GPS availability
• UTC time settings
• RNP capability
• Data link communications availability (e.g. VHF3 set to DATA)
• The initialization of data link systems :
- On MCDU>ATSU MENU>COMM MENU>COMM CONFIG page for the A/C
ICAO Code.
- On MCDU>ATSU MENU>ATC MENU>NOTIFICATION page for the flight
number.
• Airlines’ priority list of contracted DSP for FANS operations with this aircraft
(refer to B8.3.1 – ATSU SCAN MASK).
If the data link is to be used a short time after the departure, the notification
(described here after) will have to be completed prior to take off. As a general
rule, it is worth noting that the notification should be completed 15 to 45 minutes
before entering the CPDLC airspace.
Note 1 : Some figures in the following sections illustrate some exchanges via data
link between the aircraft and the ATC centre. In order to ease the understanding
of these figures, the LACK is not illustrated even if the use of LACK is required for
some regions.
Note 2 : The Context Management (CM) and Controller Pilot Data Link
Communication (CPDLC) applications and their related services are described in
details in part I.
- B 14 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
- B 15 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
The Logon function is used for transmitting the necessary information required for
flight plan association and CPDLC information required for connection
establishment. The Logon function is manually triggered in case of initial
notification, or is automatically triggered in case of transfer from one ATC centre
to another.
The Contact function provides the Current Data Authority (CDA) with a means to
transfer an aircraft to the Next Data Authority (NDA). This function is transparent
to the flight crew.
As a response, the notified ATC centre sends a Logon response to the aircraft.
On the NOTIFICATION page, the ATC centre is then declared as notified with the
corresponding time.
- B 16 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
MCDU
F R O M / T
EFHF/LFP
EDYY
Logon request
Logon response
MCDU
F R O M / T
EFHF/LFP
Figure 5-1
Manual notification
The Next Data Authority (NDA) sends a Logon response to the aircraft while
receiving the Logon request. To close the Contact process, the aircraft sends a
Contact response to the CDA on reception of the Logon response. Refer to
B5.4.2.1 – Transfer between ATC centres.
- B 17 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
Pre-flight phase
• ICAO F-PLN filling
The CNS/ATM capabilities of the aircraft will be notified when filling in the ICAO
flight plan.
- The data link capability is notified by a letter J to be entered in the
field 10.
- The other capabilities are given in the field 18 (Other Information).
The following codes have to be used :
o Following DAT/ information : V (VHF data link), M (SSR Mode S
data link),
o For aircraft having CPDLC capability, the flight crew shall insert
COM/CPDLC.
• Pre-flight checks
Prior to departing for a FANS flight, the crew will check that the required
equipment is operative. The following items are recommended to be included in
those checks :
- GPS availability - RNP capability
- UTC time settings - Data link communications availability
- The initialization of data link systems :
o The Aircraft Registration Number on the MCDU>ATSU
MENU>COMM MENU>COMM CONFIG page,
o The flight number on the MCDU>ATSU MENU>ATC
MENU>NOTIFICATION page.
- Airlines’ priority list of contracted DSP for FANS operations with this
aircraft
Notification procedures
• The aim of the notification is to :
- Notify the appropriate ATC centre of the capabilities and specifics of
the aircraft data link communication applications,
- Give the flight identification and the aircraft registration number.
• When no other CPDLC connection has been established with a previous ATC
centre, the DLIC notification must be exercised (e.g. prior to departure,
prior to entering a data link airspace).
• The DLIC notification can be initiated:
- Manually by the pilot, or
- Automatically by the ATSU using the Contact function.
The DLIC notification must be successfully completed 15 to 45 minutes
prior to entering the airspace and prior to any connection is being
established.
- B 18 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
The time at which the ATC centre will attempt a CPDLC connexion varies according
to the ATC centres. For Maastricht, the CPDLC start request is sent approximately
10 minutes before entering the airspace.
The flight crew shall only initiate CPDLC messages when the ATC centre has
enabled CPDLC. The flight crew shall not send CPDLC messages before CPDLC is
enabled. Any attempt to send CPDLC messages before CPDLC is enabled results in
uplink error message TRANSFER NOT COMPLETED – REPEAT REQUEST 1 displayed
on DCDU.
The flight crew knows that the ATC centre has enabled CPDLC when :
• The flight crew have made an initial voice contact,
• A uplink message indicating the name of the ATC centre is displayed on the
DCDU. For Maastricht, the message is EDYY, MAASTRICHT, CENTER.
Checks are automatically done by the ATSU to validate or reject the connection :
• Connection is accepted if no previous connection already exists,
• Connection is accepted if it is relative to the next data link ATC to control
the aircraft,
• Connection is rejected in all other cases.
1
This is a standardised message. This message will be uplinked even if the early CPDLC
attempt precedes an initial CPDLC connection.
- B 19 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
1. The flight crew sends a logon request to the Receiving ATC (R-ATC) as
already described in B5.3.1.1 – Manual notification with logon function.
2. As a response, the R-ATC sends a logon response to the aircraft.
3. On one hand, the Transmitting ATC (T-ATC) instructs via voice the flight
crew to contact or to monitor the R-ATC on a given frequency.
4. The flight crew copies the T-ATC instruction via voice while tuning the
instructed frequency on the RMP.
5. On the other hand, the R-ATC initiates the CPDLC connection through a CPDLC
start request.
6. The airborne system confirms the receipt of the CPDLC start request. The name
of the active ATC is displayed in green on DCDU (e.g. ACTIVE ATC : EDYY
CTR).
7. The flight crew contacts by voice (or monitor as appropriate) the R-ATC,
whereas the airborne system notifies the R-ATC that it becomes the CDA. The
technical connection is established. However, the operation connection is not yet
completed. Refer to the following step.
8. The R-ATC sends a uplink message identifying the R-ATC to the flight
crew (e.g. “EDYY, MAASTRICHT, CENTER”). This message confirms that
CPDLC is well established from an operational point of view. The ATC assumes
the aircraft.
The flight crew should not send any downlink message to the R-ATC until the R-ATC
has identified himself by sending its designation (e.g. EDYY, MAASTRICHT,
CENTER). Early sending of downlink messages may results in rejection of these
messages by the ground. The ground will send to the airborne system an error
message CPDLC TRANSFER NOT COMPLETED – REPEAT REQUEST displayed on
DCDU.
- B 20 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
MCDU
F R O M / T
EFHF/LFP
CDA 7
R-ATC T-ATC
Figure 5-2
Initial CPDLC connection
When the CPDLC connection has been established, the active ATC is indicated on
both DCDU and MCDU.
----
- B 21 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
• The ATC unit that initiates the transfer is called the Transferring ATC
(T-ATC),
• The ATC unit that receives the aircraft is called the Receiving ATC
(R-ATC),
• The ATC unit that uses data link and is currently responsible of the aircraft
is usually called the Current Data Authority (CDA).
• The ATC unit that uses data link and is designated by the CDA for an
onward transfer is usually called the Next Data Authority (NDA).
Voice and data link communications relative to these scenarios are detailed in the
following section.
B5.4.2.1.1. Transfer from T-ATC not using CPDLC to R-ATC using CPDLC
For this scenario, two cases may occur :
• A transfer from the departure control to an en-route control, or
• A transfer between two en-route ATC centres, the first one does not use
data link.
- B 22 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
1. The T-ATC sends a data link Voice Contact Instruction (VCI) to the
flight crew to be transferred (e.g. CONTACT EDYY 127.13).
2. The flight crew answers WILCO on the DCDU. At this stage, no CPDLC
messages can be sent to the T-ATC anymore. The transfer of data link is
fully managed by the ground and is transparent to the flight crew.
3. While sending the WILCO response, the flight crew tunes the assigned
frequency on the RMP and contacts the R-ATC.
4. The R-ATC sends a data link message containing its name (e.g. EDYY,
MAASTRICHT, CENTER) and becomes the Current Data Authority.
DCDU DCDU
3 2
4 1
R-ATC T-ATC
Figure 5-3
Transfer between ATC sectors – No change of CPDLC connection
- B 23 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
Both methods are transparent to the flight crew. Hereinafter is described the
transfer process based on DLIC Contact function. Refer to Figure 5-4.
1. The T-ATC sends a Contact request to the airborne system and subsequently
notifies the NDA to the airborne system. A message indicating the name of
the R-ATC is displayed on DCDU.
2. While receiving the Contact request from the T-ATC, the airborne system sends
a Logon request to the R-ATC.
3. The R-ATC replies the airborne system with a Logon response.
4. This Logon response allows the airborne system to send a Contact response to
the T-ATC.
5. On one hand, after sending the logon response to the airborne system, the R-
ATC initiates the CPDLC connection by sending a CPDLC start request.
6. The airborne system confirms the reception of the CPDLC start request. The
name of the R-ATC is displayed in white on DCDU (e;g. NEXT ATC : LFFF
CTR) underneath the ACTIVE ATC indication, and in green in the MCDU
CONNECTION STATUS page.
7. On the other hand, the T-ATC sends a Voice Contact Instruction (VCI)
coupled with an instruction to end the CPDLC connection.
When the flight crew replies WILCO to the VCI, a CPDLC end confirmation is
appended to this response. At that stage, the CPDLC connection with the T-ATC
is ended.
8. The flight crew contacts by voice the R-ATC, whereas the airborne system
notifies the R-ATC that it becomes the CDA.
9. The R-ATC sends a uplink message identifying the R-ATC to the flight
crew (e.g. EDYY, MAASTRICHT, CENTER). This message confirms that
CPDLC is well established from an operational point of view. The ATC assumes
the aircraft.
- B 24 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
DCDU
1556Z
1556Z FROMFROM EDYY
EDYY CTL WILCWILCO
WILCO
CONTACT
CONTACTLFFF
LFFF128.275
128.275
7 CPDLC end confirmation
Contact / Monitor DCDU
by voice
CDA 8
ACTIVE ATC : LFFF
ACTIVE ATC :CTR
LFFF CTL
ATC unit name
9
1559Z 1559Z
FROMFROM
LFFF LFFF CTL
CURRENTLFFF,
ATCPARIS,
UNIT CENTER
LFFF, PARIS, CTR
R-ATC T-ATC
Figure 5-4
Transfer between ATC centres – Use of DLIC Contact function
- B 25 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
The flight crew should not send any downlink message to the R-ATC until the R-ATC
has identified himself by sending its designation (e.g. EDYY, MAASTRICHT,
CENTER). Early sending of downlink messages may results in rejection of these
messages by the ground. The ground will send to the airborne system an error
message CPDLC TRANSFER NOT COMPLETED – REPEAT REQUEST displayed on
DCDU.
B5.4.2.1.3. Transfer from T-ATC using CPDLC to R-ATC not using CPDLC
For this scenario, two cases may occur :
• A transfer from the en-route control to an approach control, or
• A transfer between two en-route ATC centres, the second one does not use
data link.
- B 26 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
VCI
DCDU 1
CPDLC end request
WILCO
2 CPDLC end confirmation
Contact by voice
3
R-ATC T-ATC
Figure 5-5
CPDLC termination
- B 27 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
If the ATC controller decides to transfer the aircraft without waiting for the
responses to any open dialogues, before initiating the transfer, the ATC controller
should revert to voice in order to avoid any ambiguity implied by the open
dialogues.
The system resumes the CPDLC application when the flight crew initiates a
manual notification (whatever the result of the notification).
When the CPDLC application is inhibited, any valid CPDLC connection request is
rejected by the system (transparent for the flight crew). The system justifies the
connection rejection with an error downlink message followed by a free text
AIRCREW HAS INHIBITED CPDLC.
At that time, pending CPDLC messages should be considered as not delivered and
the entire dialogue related to these messages should be restarted on voice.
- B 28 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
Consequently, even if a CPDLC connection exists, the flight crew shall apply all the
procedures provisioned in the event of radio communication loss.
- B 29 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
Lists of all the up and down link messages supported by the CPDLC system are
given in Appendix A.
B5.4.9.1. TO BE KNOWN
B5.4.9.1.1. Technical acknowledgement
Thanks to the ATN protocol, either the flight crew or the ATC controller gets the
assurance that the sent message is displayed on the recipient’s HMI. This is valid
only in areas where the LACK is used.
Indeed, when the WILCO response is sent, the ATSU appends a disconnection
request to this response. Then the T-ATC is no more connected to the aircraft.
2
One ‘E’ is omitted due to space restrictions imposed by the interface.
- B 30 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
For downlink messages, the same principle may apply according to the local
implementation of the ATC ground systems. If the ground systems discard
delayed downlink messages, the ATC controller will not see the downlink message
and the flight crew will receive the error message DOWNLINK DELAYED – USE
VOICE. The flight crew shall revert to voice.
All these messages are listed in Appendix B with the appropriate procedure.
When the air traffic controller or the flight crew communicates via voice, the
response should be via voice.
- B 31 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
Pilots should answer any received messages within 100 seconds (refer to
the description of operational timers in Part I).
Free text message received on board will be closed once ROGER has been
answered. ROGER is the sole response to any up linked free text.
- B 32 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
ATC indication displayed on DCDU), always close the message via the
CLOSE soft key to clear DCDUs. Once closed, the message can be recalled via
the RECALL soft key.
In those cases, the air traffic control or the flight crew shall preface their
transmission with the following sentence DISREGARD CPDLC (message content or
type) MESSAGE, BREAK followed by the correction.
- B 33 -
B5 – FANS B operational procedures Getting to grips with FANS – Part III – Issue III
CPDLC Connection
• Once the DLIC notification has been successfully done, the ATC centre
can initiate a CPDLC connection (no action required from the flight crew).
CPDLC messages shall only be sent when the aircraft is assumed by the
ATC (i.e. reception of the uplink message indicating the name of the ATC).
• Checks are automatically done by the ATSU to validate or reject the
connection :
- Connection is accepted if no previous connection already exists or, it
is relative to the next data link ATC to control the aircraft,
- Connection is rejected in all other cases.
• Once connection is established :
- For the technical connection, the active connected ATC centre is then
displayed on the DCDU, and on the CONNECTION STATUS page of the
MCDU.
- For the operational connection, a uplink message indicating the name
of the current ATC (e.g. EDYY, MAASTRICHT, CENTER) is received.
• Pilots should answer any received messages within 100 seconds.
• It is strongly recommended to close with the CLOSE soft key any
messages on DCDUs once they are sent.
• A Voice read-back is required for any messages related to any changes of
the aircraft trajectory in the framework of FANS B system.
- B 34 -
Getting to grips with FANS – Part III – Issue III B5 – FANS B operational procedures
Under normal circumstances the CPDLC connection should be established with the
Next Data Authority prior to the connection between the aircraft and the current
data authority being terminated.
DCDU management
When a message is received by the ATC ground system (i.e. RECEIVD BY ATC
indication is displayed on DCDU), always close the message via the CLOSE soft
key to clear DCDUs. Once closed, the message can be recalled via the RECALL soft
key.
- B 35 -
Getting to grips with FANS – Part III – Issue III
- B 36 -
Getting to grips with FANS – Part III – Issue III B6 – FANS B integration
- B 37 -
B6 – FANS B integration Getting to grips with FANS – Part III – Issue III
For aircraft not equipped of MMR (if the CLOCK is not synchronised with GPS), a
direct link has to be installed between GPS and ATSU.
For FANS B, the ATSU CSB 5 has been developed. The following configurations are
inherited from the ATSU CSB 4 (ATSU CSB 4 has been certified for FANS A+
function on Single Aisle) :
• Host platform,
• Hardware inherited of HW70 (with Ethernet capability),
• ACARS router (with VDL mode 2 function),
• Capability to host AOC applications (either AOC customized by the airlines
or standard AOC provided by AIRBUS),
• Capability to customize the router, with customization in 2 steps :
- Customization step 1 allows the ATSU supplier to modify the
AIRLINE ID and the SCAN MASK parameters upon customer request.
- Customization step 2 allows ATSU supplier to modify a defined set of
parameters contained in the DSP World map file.
- B 38 -
Getting to grips with FANS – Part III – Issue III B6 – FANS B integration
- B 39 -
B6 – FANS B integration Getting to grips with FANS – Part III – Issue III
- B 40 -
Getting to grips with FANS – Part III – Issue III B6 – FANS B integration
FANS B options
Wired high speed data loading capability (AEEC 615A)
This feature reduces software data loading duration with a factor of 5 at a
minimum and introduces also a full ATSU software configuration management
(including the AOC) to ease maintenance operations.
FANS B retrofits
To install the FANS B package on a A320 aircraft, the following equipment is
required :
• 1 ATSU CSB5,
• 2 DCDUs,
• 2 ATC message push-buttons,
• 1 VHF Data Radio (VDR) for data and voice communications capable of VDL
mode 2.
- B 41 -
Getting to grips with FANS – Part III – Issue III
- B 42 -
Getting to grips with FANS – Part III – Issue III B7 – FANS B world status
- B 43 -
A7 – FANS B world status Getting to grips with FANS – Part III – Issue III
In the framework of FANS B system, a voice read-back is required for any ATC
instruction affecting the flight profile.
ICAO Facility
FIR/UIR Responsible ACC Notes
Designator
Hannover UIR Maastricht UAC EDYY Operational April 2004
Amsterdam FIR Maastricht UAC EDYY Operational April 2004
Brussels UIR Maastricht UAC EDYY Operational April 2004
Wien FIR Wien ACC LOVV Operational TBD
France UIR Brest UAC LFRR Operational 2011
Reims UAC LFEE Operational 2009
Paris UAC LFFF Operational 2011
Marseille UAC LFMM Operational 2011
Bordeaux UAC LFBB Operational 2011
Rhein UIR Rhein UAC EDUU Operational 2008
Milano UIR Roma ACC LIRR Operational 2008
Brindisi UIR Brindisi ACC LIBB Operational 2008
Roma UIR Roma ACC LIRR Operational 2008
Canarias UIR Canary ACC GCCC Operational 2011
- B 44 -
Getting to grips with FANS – Part III – Issue III B7 – FANS B world status
ICAO Facility
FIR/UIR Responsible ACC Notes
Designator
Barcelona UIR Barcelona ACC LECB Operational 2011
Palma ACC LECP Operational 2011
Madrid UIR Madrid ACC LECM Operational 2011
Sevilla ACC LECS Operational 2011
Swiss UIR Geneva ACC LSAG Operational 2008
Zurich ACC LSAZ Operational 2008
Lisboa UIR Lisboa ACC LPPC Operational 2011
Shannon UIR Shannon UAC EISN Operational TBD
Here below, are provided the ATN airspace deployment and the traffic growth
forecast.
2005 2011
Figure 7-1
ATN airspaces (green) and traffic forecasts (red)
- B 45 -
A7 – FANS B world status Getting to grips with FANS – Part III – Issue III
B7.1.4. CONTACTS
For general information on Link 2000+ programme, please refer to :
http://www.eurocontrol.int/link2000.
- B 46 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
B8.1 General 48
B8.2 Data link : contracts and declarations 48
B8.2.1 Contracts with Data link Service Providers (DSP) 48
B8.2.2 Aircraft declaration to data link service providers and 48
ATC centres
B8.2.3 Recommendations 49
B8.3 Impacts on aircraft configuration 49
B8.3.1 ATSU SCAN MASK 49
B8.3.2 CMA address database 49
B8.4 Get the operational approval 50
B8.4.1 General requirements 50
B8.4.2 Aircraft configuration 51
B8.4.3 Flight crew training/qualification 51
B8.4.3.1 General recommendations 51
B8.4.3.2 Proposed qualification means 52
B8.4.3.3 Academic training 52
B8.4.3.4 Operational training 54
B8.4.4 Maintenance personnel training 58
B8.4.5 Approved documentation 59
B8.4.5.1 FANS B Airworthiness Approval Summary 59
B8.4.5.2 Minimum Equipment List 59
B8.4.5.3 Aeroplane Flight Manual 60
- B 47 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
B8.1. GENERAL
This chapter aims at providing airlines with administrative and technical guidelines
so as to ensure proper operations of FANS B aircraft in ATN-based FANS
airspaces.
For these reasons the operator needs to ensure the following before starting FANS
Operations :
ATSU is certified to sustain ATC data link communications via VHF in ATN
environments, and certified for AOC communications via VHF, SATCOM and HFDL.
If an airline wishes to use more than one service provider, then two solutions may
be considered :
• Place contracts directly with each service provider, or
• Place a contract with a unique service provider who will subcontract data
handling to other service providers.
- B 48 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
condition to allow exchanges of ATC data link messages between an aircraft and
the ATC centre.
The airline should make sure that all service providers to be potentially contacted
by a given aircraft have been advised of its FANS capability and identification.
Each new FANS aircraft entry into service must be declared to the service
providers selected by the airline and to the ATC centres the aircraft will
communicate with.
B8.2.3. RECOMMENDATIONS
The Initialisation procedure of the ATSU router (airline identification and scan
mask) is provided through AMM 46-21-00-860-801.
- B 49 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
Operational approval rules are not yet fully available and individual operational
authority may choose the "means of compliance" (such as ACJ-20X10 3 available
at http://www.eurocontrol.int/link2000/public/standard_page/bsl_docs.html),
stating what the applicant airline may have to demonstrate.
It is however expected that the following items will have to be complied with, by
the applicant airline :
• Aircraft configuration,
• Flight crew training/qualification,
• Maintenance training,
• Approved operational documentation and procedures.
3
At the time of writing the document, ACJ-20X10 entitled “Advisory Material for the
Approval of use of Initial Services for Air-Ground Data Link in Continental Airspace” was
still a NPA referenced as NPA 20-11c.
- B 50 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
Based on this document, which lists the assumptions on the ground environment
and gives a synthesis of the tests carried out for certification, the scope of
additional tests may be defined :
• Interoperability test scenarios,
• Verification of the safety and performance criteria with regards to the
considered environment.
The list of the approved FANS aircraft configuration will be kept updated by
AIRBUS. Compliance to this list will have to be ensured.
The Navigation aspects are addressed in the “Getting to grips with modern
navigation” brochure.
To this end, the following points will be emphasised in preparing the flight crew
training programmes :
• Basic knowledge of the overall CNS/ATM environment for which, the various
concepts and interacting elements, the involved aircraft systems and
relevant operating procedures to be applied should be covered in a
dedicated academic training.
- B 51 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
It is AIRBUS opinion that the initial qualification should be made of the following
components :
• Half-a-day familiarisation course to address the academic training and to
emphasise the main operational critical points,
• Home work training for each pilot through the interactive Computerized
Based Training (CBT) developed by AIRBUS,
• One operational flight conducted with an airline check pilot.
Note : To obtain a copy of the AIRBUS training course, a CBT license is needed.
For further information, contact your AIRBUS Resident Customer Service Manager
(RCSM) or Customer Service Director (CSD).
Flight crews should be made aware of the nominal systems operations and
performance parameters, normal and abnormal use together with the limitations
of the systems.
- B 52 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
- B 53 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
The AIRBUS CBT training device, through its interactive operational scenarios,
mostly covers this training syllabus. It may be presented by the airline to the
airworthiness authorities as a stand-alone computer-based instruction. It covers
the data link communications items of the global FANS, and comes in complement
to the RNP/RVSM operational training (as described in the “Getting to grips with
modern navigation” brochure).
The following lists the items to be tackled in a training course. All but the "Special
Recommendations" paragraph are addressed in the AIRBUS CBT :
• Message handling
The pilots should be trained on how to receive and interpret ATC messages.
Understanding the CPDLC phraseology is to be acquired.
Appropriate use of the pre-formatted answers of the DCDU (e.g. WILCO, ROGER,
UNABLE, CANCEL...) together with the knowledge for storing and retrieving
messages from the ATC messages logbook will be addressed.
Will also be practised the operations that require simultaneous work on both the
DCDU and the MCDU. In particular, the preparation of requests and the edition of
responses on the MCDU ATC pages should be covered.
The global use of the communications systems, whether they are traditional voice
or new data link communications will have to be acquired.
All the available controls and indicators of the AIRBUS FANS system should be
known and used (e.g. the meaning of the various displays, advisories, available
functions).
Whenever a CPDLC failure occurs or whenever a doubt while using CPDLC raises,
procedures to revert to voice have to be mastered.
- B 54 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
Knowledge of the ATS procedures for the considered FANS area (e.g. timely,
relevant and appropriate responses to communication failures) is of prime
importance.
In addition, crews should be able to recognise "usual" failures and be fully aware
of the tricks pertaining to the sensitivity of the end-to-end data link
communications (Refer to the following recommendations).
• Special recommendations
Derived from the lessons learned during FANS operations in FANS 1/A areas, the
following list gives the main points to be underlined in the operational training:
- Flight identification
Pilots should be fully aware that the flight identification of both the filed F-PLN and
the one used for data link communications must be identical. It is the pilot's
responsibility to ensure that correct flight identification and registration number
are used.
In particular, the operator ICAO 3-letter code is to be used (e.g. ICAO ATC filed F-
PLN, FMS, data link). Attempting a connection with AI 123 identification for
instance, whereas AIB123 has been filed, will cause the ground system to reject
the connection.
- Communication means
When the dialogue is initiated via CPDLC, the response shall be via CPDLC. When
the dialogue is initiated via voice, the response shall be via voice.
- B 55 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
When CPDLC fails and communications revert to voice, all outstanding CPDLC
messages should be considered not delivered and the entire dialogue involving the
outstanding messages should be recommenced by voice.
ROGER is the sole answer for an up linked free text message. Any other answer
will keep the received message open.
In particular, pilots should verify that the expected ICAO 4 letter code for the
region is displayed on the DCDU. , Pilots should also verify that a uplink
message indicating the name of the ATC centre is well received and should not
send any message before this uplink message is received. Any downlink
messages sent before the reception of this uplink message will be discarded
by the ground.
o Disconnection may also occur during FIR transfers due to pending uplink
messages and this, although the recommended procedures specify that the
"END SERVICE" message is not transmitted while there are open messages.
Pilots should be aware of such occurrences.
- Open message
- Delays in responding
For ATC responses to downlink messages, the flight crew should expect an ATC
response within 250 seconds. if a STANDBY response has been received from
ATC, the flight crew should expect a further answer within further 250 seconds
(Refer to the description of operational timers in Part I). At the timer expiration, a
- B 56 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
system message is sent to the aircraft and closes the dialogue. ATC TIME OUT –
REPEAT REQUEST is displayed on DCDU. Reversion to voice is let at discretion of
the flight crew.
For flight crew responses to uplink messages, the flight crew should respond
within 100 seconds after the message has been received (refer to the description
of operational timer in Part I). If the flight crew answers STANDBY, the timer is
reset. The flight crew should be aware that a 100-second period is all the more
short because a voice read back has to be done for some messages.
- Multi-element messages
- Abnormal configurations
The following lists the expected pilot's behaviour for an efficient use of the data
communications systems :
- Prompt and appropriate answer to up linked messages,
- Appropriate emission of down linked messages,
- Nominal crew work share for an efficient handling of the messages,
- Compensation of system failures through prompt reversion to voice,
- Compliance with the voice clearance whenever this contradicts the
data link one.
• Operator responsibilities :
- B 57 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
Data link anomalies (failures, loss of messages, unanswered messages, very long
response time, disconnection...), procedural difficulties, human factors issues
should be reported through any appropriate devices according to the airline
policies.
Significant incidents associated with an ATC message transmitted by data link that
affects or could affect the safe operation of the aircraft will need to be reported in
accordance with JAR-OPS 1.420 (or national regulations, as applicable), and to
the air traffic services provider and its responsible authority.
- B 58 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
Based on this document, the operational and technical context may be evaluated
and additional demonstration activities be asked by the authority.
The MEL items for data link communications may depend on the considered FANS
route (oceanic, continental, remote areas). The airline should thus take provisions
for some specific operating systems at dispatch, and consider the consequences of
their loss on the data link communications.
For Master MEL (MMEL) considerations, the following pieces of equipment may be
inoperative. The following list is provided for information only. Refer to the MMEL
for the official dispatch conditions.
- B 59 -
B8 – Starting FANS B operations Getting to grips with FANS – Part III – Issue III
- B 60 -
Getting to grips with FANS – Part III – Issue III B8 – Starting FANS B operations
Operational approval
Individual operational authority may choose the "means of compliance" stating
what the applicant airline may have to demonstrate. However, the following items
will have to be complied with:
• Aircraft configuration
The aircraft should be configured in accordance with the approved certification
configuration for FANS A operations.
• Flight crew training/qualification
Operating an aircraft in a FANS type environment requires from the crew
understanding, knowledge and operational use of the three C, N and S dimensions
of the CNS/ATM concept.
• Maintenance training
An appropriate maintenance training program relative to the digital
communications, must be given to maintenance people
• Approved operational documentation
The applicant airline should present to its relevant authority the FANS A
Airworthiness Approval Summary, the MEL and the AFM to be approved.
It is strongly recommended not to make spontaneous FANS testing with
ATC centres when they have not been previously made aware of a given
aircraft intention to operate in FANS mode.
- B 61 -
Getting to grips with FANS – Part III – Issue III
- B 62 -
Getting to grips with FANS – Part II – Issue III APPENDICES
APPENDICES
- B 63 -
APPENDIX A Getting to grips with FANS – Part III – Issue III
UPLINK MESSAGES
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
CONFIRM UM133 REPORT PRESENT Instruction to report the present
REQUEST LEVEL level.
OPEN UM148 WHEN CAN YOU Request for the earliest time at
NEGOTIATION ACCEPT [level] which the specified level can be
accepted
- B 64 -
Getting to grips with FANS – Part III – Issue III APPENDIX A
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
- B 65 -
APPENDIX A Getting to grips with FANS – Part III – Issue III
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
- B 66 -
Getting to grips with FANS – Part III – Issue III APPENDIX A
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
- B 67 -
APPENDIX A Getting to grips with FANS – Part III – Issue III
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
- B 68 -
Getting to grips with FANS – Part III – Issue III APPENDIX A
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
VOICE CONTACT UM117 CONTACT [unitname] Instruction that the ATS unit
INSTRUCTION [frequency] with the specified ATS unit
name is to be contacted on the
specified frequency.
- B 69 -
APPENDIX A Getting to grips with FANS – Part III – Issue III
FANS B
UM MESSAGES DESCRIPTION
CATEGORY
UM183 [free text]
DOWNLINK MESSAGES
FANS B
DM MESSAGES DESCRIPTION
CATEGORY
REQUEST DM6 REQUEST [level] Request to fly at the specified
level
DM18 REQUEST [speed] Request to fly at the specified
speed.
- B 70 -
Getting to grips with FANS – Part III – Issue III APPENDIX A
- B 71 -
APPENDIX B Getting to grips with FANS – Part III – Issue III
Extracts from the Flight Crew Data Link Guidance for Link 2000+ Services v3.0
(as of 15 JAN 2007).
Available at :
http://www.eurocontrol.int/link2000/public/standard_page/specific_docs.html
The following sections are copied from the above website with the courtesy of the
EUROCONTROL Agency. They are reproduced for information only. It is a faithful
copy as of 15 JAN 2007. It is strongly recommended to check the accuracy of these
sections at the mentioned website address.
Use of the below extracts from the Flight Crew Data Link Guidance for Link 2000+
Services as of 15 JAN 2007 and such as may be updated from time to tome by the
EUROCONTROL Agency (called “the extracts”) is subject to the following conditions:
• The use of the extracts in this brochure is under the sole responsibility of the
user of such material;
• AIRBUS SAS and the EUROCONTROL Agency shall not be liable for any direct,
indirect, or consequential damages that results from the use or inability to
use the extracts, in particular for, but not limited to, errors, or omissions in
the contents of the http://www.eurocontrol.int website or the consequences
of its use, nor for inaccurate transmission or misdirection, even if AIRBUS
SAS and/or the EUROCONTROL Agency have been advised of the possibility
of such damage. This limitation applies whether the alleged liability is based
on contract, tort, or any other basis. It is the user responsibility to make sure
that she or he is using the most up to date information available.
The messages below are standard messages that the flight crew may receive in
case an error occurs. For each message, the appropriate procedure is provided.
Procedure:
The flight crew should communicate with ATC via voice alone, until the CPDLC
connection has been properly established.
- B 72 -
Getting to grips with FANS – Part III – Issue III APPENDIX B
Procedure:
The flight crew may resend the request in the form of separate messages, or
make the request/s by voice.
Procedure:
The flight crew should make the request by voice.
Procedure:
The flight crew may resend the message/request in the form of separate
messages, or make the request/s by voice
- B 73 -
APPENDIX B Getting to grips with FANS – Part III – Issue III
Procedure:
The flight crew should be aware that only one downlink request for a single type
will be presented to the controller, and that this open dialogue must be closed
before a second request of that type may be treated.
Note: Ground systems only accept one data link exchange of a given type at the
same moment. This means that if e.g. a CLIMB TO [level] clearance has been
sent, a REQUEST DESCEND TO [level] request will be rejected until the flight crew
has responded to the clearance.
Procedure:
The flight crew must respond to the uplink before being able to send a downlink
request of this type. For example, if CLIMB TO [altitude] has been received, the
flight crew must answer WILCO or UNABLE before being able to send REQUEST
CLIMB TO [altitude].
Note: The total number of data link exchanges with an aircraft may be limited by
some ground systems. This means that further requests will be rejected. If there
are only downlink requests, the flight crew cannot do anything about it. If there is
at least one uplink expecting a response, the flight crew can respond to that
clearance first to enable reception of a downlink request.
Procedure:
The flight crew should make the request/s by voice
- B 74 -
Getting to grips with FANS – Part III – Issue III APPENDIX B
When the conditions to enable CPDLC have been met, the ground system will
accept the CPDLC messages received from the aircraft.
Procedure:
The flight crew cannot use data link now, but when CPDLC is enabled, a CPDLC
message is uplinked and displayed to the flight crew, indicating the name and
function of the current ATC unit.
Procedure:
The flight crew should repeat the request/s by voice
Procedure:
The flight crew should revert to voice.
- B 75 -
APPENDIX B Getting to grips with FANS – Part III – Issue III
Procedure:
The flight crew should revert to voice.
Procedure:
The light crew should revert to voice.
Procedure:
The flight crew should revert to voice.
Note1: The flight crew should not use “Free text” if a relevant CPDLC message
already exists for the situation.
Note2: Ground systems may not accept downlinked free text messages, or may
not display them to the controller.
Procedure:
The flight crew should revert to voice.
- B 76 -
Getting to grips with FANS – Part III – Issue III APPENDIX B
Procedure:
The flight crew should revert to voice.
Procedure:
The flight crew should revert to voice.
Procedure:
The flight crew should revert to voice.
Procedure:
The flight crew should revert to voice.
- B 77 -
APPENDIX D Getting to grips with FANS – Part III – Issue III
The following maps are provided with the courtesy of SITA and ARINC.
- B 78 -
Getting to grips with FANS – Part III – Issue III APPENDIX D
- B 79 -
APPENDIX D Getting to grips with FANS – Part III – Issue III
As of 18 JAN 2007
The following sections are copied from the above website with the courtesy of the
Air Traffic Control The Netherlands. They are reproduced for information only. It is
a faithful copy as of 13 APR 06. It is strongly recommended to check the accuracy
of these sections at the mentioned website address.
Use of the below extracts from the The Netherlands AIP as of 18 JAN 2007 and
such as may be updated from time to tome by the Air Traffic Control The
Netherlands (called “the extracts”) is subject to the following conditions:
• The user accepts all the conditions and disclaimers applying to the use of the
information contained in the http://www.ais-netherlands.nl website;
• The use of the extracts in this brochure and/or via the http://www.ais-
netherlands.nl website is under the sole responsibility of the user of such
material;
• AIRBUS SAS and the Air Traffic Control The Netherlands shall not be liable for
any direct, indirect, or consequential damages that results from the use or
inability to use the extracts, in particular for, but not limited to, errors, or
omissions in the contents of the http://www.ais-netherlands.nl website or
the consequences of its use, nor for inaccurate transmission or misdirection,
even if AIRBUS SAS and/or the Air Traffic Control The Netherlands have been
advised of the possibility of such damage. This limitation applies whether the
alleged liability is based on contract, tort, or any other basis. It is the user
responsibility to make sure that she or he is using the most up to date
information available. The Air Traffic Control The Netherlands may change
materials on the website without prior notice.
- B 80 -
Getting to grips with FANS – Part III – Issue III APPENDIX D
3.6.1. GENERAL
Data link services are available for aircraft operating within the upper airspace
(above FL 245) of the Amsterdam FIR, under the responsibility of Maastricht UAC.
- B 81 -
APPENDIX D Getting to grips with FANS – Part III – Issue III
The data link messages concerning changes to aircraft profile require voice
readback by the crew on reception.
Example – “Callsign – Confirming datalink climb FL 370”.
Data link messages concerning SQUAWK, SQUAWK IDENT and CONTACT do not
require voice readback prior to execution. Clearances shall be executed when the
WILCO message is sent.
If a downlink request receives a timeout aircrew should make the request again
by voice.
Log-on shall be initiated by the aircrew. Aircrew shall log-on using their ICAO
callsign as filed in their flight plan. Aircrews shall not use a two-letter IATA flight
ID, or insert a leading zero (0) into a callsign, as these actions will result in a
failed log-on.
Log-on should be initiated 30 minutes prior to entry into Maastricht UAC airspace.
For aircraft departing from an aerodrome in close proximity to Maastricht UAC
airspace, log-on can be initiated when the aircraft is on the ground.
Irrespective of the number of Maastricht sectors entered during their flight only
one log-on per flight is required.
3.6.6.2. ACM
When an aircraft is transferred by data link to an adjacent sector/ATSU, aircrew
shall acknowledge the instruction by WILCO, and shall then contact the next
sector/ATSU by voice communication on the frequency given.
- B 82 -
Getting to grips with FANS – Part III – Issue III APPENDIX D
3.6.6.3. AMC
A ‘Check Stuck Microphone’ instruction may be sent by ATC in circumstances
where an aircraft is inadvertently blocking a voice communication frequency. For
FANS aircraft a ROGER response is expected to this instruction.
If the ‘Check Stuck Microphone’ instruction relates to the R/T frequency being
used, then the aircrew shall check that their radio equipment is not causing the
blockage. If the ‘Check Stuck Microphone’ instruction does not relate to the R/T
frequency being used then no further aircrew action is required.
3.6.8. LOG-OFF
Log-off is automatic on exiting Maastricht UAC airspace. No aircrew action is
required.
In the event of airborne CPDLC failure, the aircrew shall revert to voice
communication and inform ATC.
3.6.10. MESSAGES
The following uplink clearances and instructions may be expected by aircrew using
CPDLC with Maastricht UAC.
- B 83 -
APPENDIX D Getting to grips with FANS – Part III – Issue III
The following downlink requests may be sent by aircrew using CPDLC with
Maastricht UAC.
Aircrew Requests
Request direct to
Request Climb to [level]
Request Level
Request Descent to [level]
If a downlink request receives a timeout aircrew should make the request again
by voice.
- B 84 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
To enable the ACARS router, the aircraft registration number and the ACARS
airline identification are necessary. In addition, to enable the use of VDL mode 2,
the aircraft ICAO code must be set.
From the ATSU DATALINK page, select Select the COMM CONFIG prompt in the
the COMM MENU prompt. COMM MENU page.
- B 85 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
If the ATSU is correctly initialised, the If not, the parameters shall be entered
COMM CONFIG page shall appear as manually.
follows.
2. INITIAL NOTIFICATION
The aircraft is flying from Helsinki – Malmi, Finland (EFHF) to Paris – Charles De
Gaulles, France (LFPG). The first ATC using data link for this flight is Maastricht
UAC, The Netherlands (EDYY) and the flight crew wants to notify it.
The notification shall be done 15 to 45 minutes before entering the airspace. Refer
to AIP. For Maastricht, it should be done 30 minutes prior to entering.
- B 86 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
Select the ATC MENU prompt on MCDU. Then, select the CONNECTION prompt.
- B 87 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
Notify the ATC centre by selecting the 2R key. Once the ATC centre has been
notified, the notification time is indicated underneath. At this stage, the
connection is initialised at ATC controller’s discretion.
Note : Once the CPDLC connection is established, the notification indication (e.g.
EDYY NOTIFIED 1233Z) disappears.
3. CPDLC CONNECTION
Once the notification is completed, the ATC will establish a CPDLC connection. The
time at which it will be established varies according to the airspace. For
Maastricht, the CPDLC connection should be established 10 minutes prior to
entering.
- B 88 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
Note : For regular (respectively urgent) messages, the aural signal is delayed by
15 seconds (respectively 5 seconds) and then repeated every 15 seconds
(respectively 5 seconds) until the receipt of the message is acknowledged (i.e.
ATC MSG push-button is switched off or a key to treat the message is pressed).
The following figures provide the method to check the connection status.
From the ATC MENU page on MCDU, go On ATC request, you can disconnect the
to the CONNECTION page, and then connected ATC centres (here the
select the CONNECTION STATUS ACTIVE ATC) with the 3R key of the
prompt. CONNECTION STATUS page.
- B 89 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
ATC
MSG
- B 90 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
Remember that 100 seconds are quite a short period of time to read the message,
to interpret it, to check the aircraft parameter and to prepare the response,
especially if a voice read-back has to be performed.
The ATN Baseline 1 standards define a 100-second timer assuming that no voice
read-back is required.
- B 91 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
The flight crew knows that the transfer procedure starts when the Voice Contact
Instruction and the uplink message identifying the NDA are received.
For the following figures, it is assumed that the aircraft is about to transit from
the EDYY airspace to the LFFF airspace.
Note : At the time of writing the document, LFFF is not data link equipped. For
training purposes, the transfer illustrated below assumes that the NDA is data link
equipped.
ATC
MSG
The ATC sent an uplink message. Press
the ATC MSG push-button to switch the
light off and to stop the aural signal.
ATC
MSG
- B 92 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
When LFFF starts the connection process (i.e. CPDLC start request), the default
DCDU screen appears as follows. You are still under the authority of EDYY. LFFF
will take over soon.
On MCDU CONNECTION STATUS page, you can also check that LFFF is the NEXT
ATC.
ATC
MSG
Select SEND.
- B 93 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
The aircraft is now disconnected from EDYY. The establishment of the CPDLC
connection with LFFF is almost completed.
As soon as you have replied WILCO to the Voice Contact Instruction, contact LFFF
by voice on the instructed frequency.
The new ATC, LFFF, sent an initial ATC
uplink message that clearly identifies MSG
the ATC centre to which the aircraft is
connected.
- B 94 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
7. OPEN NEGOTIATION
ATC
You are now under the authority of
MSG
LFFF. The ATC sent an uplink message.
- B 95 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
- B 96 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
- B 97 -
APPENDIX E Getting to grips with FANS – Part III – Issue III
9. MSG RECORD
The ATSU records up to 99 CPDLC messages (either uplink or downlink). When
this limit is reached, the latest message overwrites the oldest message.
Note : the time-out advisory received from the ground is not store in the MSG
RECORD as it is just a means to properly close the CPDLC dialogue, without any
particular operational interest.
- B 98 -
Getting to grips with FANS – Part III – Issue III APPENDIX E
- B 99 -
APPENDIX F Getting to grips with FANS – Part II – Issue III
This document is primarily intended for operators, ATC service providers and
national aviation authorities.
- B 100 -
