Prisma P4000
Product knowledge
2. Overview
product description ............................................ 2
selling points ....................................................... 5
sales references .................................................. 6
Prisma P4000
3. Technical data
technical datasheet ............................................. 3
assembly manuals .............................................. 5
Prisma P4000
Contents
partial
■ IP 31 at most
■ form 1 (little maintenance is performed inside this cubicle,
normally locked) (other forms possible, to be produced by the
panel builder)
■ specific inside layout: NW40 mounting plate, 4000 A busbar
supports, etc.
Framework
The incoming cubicle is always made up of a Prisma P
framework, 700 mm wide and 600 mm deep.
Panels
The panels consist of a front plate support door or of front
plate support partial doors.
IP
This is limited to IP 31 to prevent temperature rise risks.
■ IP 20 with standard panels + ventilated roof and ventilated
front plate at the bottom of the cubicle in order to create
natural ventilation.
■ IP 31 with seal ref. 09372 + forced ventilation made up of:
❏ a fan installed at the bottom of the cubicle
❏ an output filter installed at the top of the cubicle
❏ partitioning between the incoming and outgoing cubicles.
Installation capacity
Generally speaking, the available installation height is
31 x 50 mm modules. In point of fact, the specific functional
uprights limit the height available to install switchgear.
Inside equipment
The outgoing cubicle receives all the standard Prisma P
equipment with no restrictions: upstream connections with
screen, cable connections on duct, flanging supports,
screens for form 2 or 3, etc.
Panels
Standard Prisma P, but limited to IP 31.
Incoming cubicle
This cubicle is fully studied to avoid all approximation in design
and production. Safety and reliability is dependent on this.
All aspects are taken into account:
■ mechanical mounting of Masterpact: specific mounting plate
■ temperature rise monitoring
■ control of prospective short-circuit currents
■ complete study of incoming connections and links up to the
main busbar.
Outgoing cubicles
Installation of the main busbar is fully studied to suit all cubicle
assembly configurations, in view of prospective short-circuit
currents.
Connection of the secondary busbar to the main busbar is
fully studied.
Installation and connection of outgoing units are exactly the
same as those of all Prisma P floor standing enclosures.
All standard components contributing to increased simplicity
and safety can be used:
■ Linergy busbar
■ upstream connections with form 2 screen
■ Polypact and Multiclip distribution blocks
■ cable connections on the duct
■ cable flanging support
■ form 3 screens
■ main and secondary busbar covers.
Outgoing cubicles
■ 07290
❏ set of functional uprights
Busbar
■ 07291
❏ set of 2 horizontal busbar fixing supports
■ 07292
❏ busbar support
■ 07293
❏ set of 5 125X5 mm sliding fishplates
■ 07294
❏ busbar flanging rod
■ 07295
❏ set of 4 vertical busbar fixing angle brackets
■ 07297
❏ horizontal busbar support
Prisma P4000
Contents
Technical datasheet
■ mechanical data ....................................................... 3
■ electrical data ........................................................... 3
■ conformity with standards .......................................... 3
Prisma P4000
Prisma P4000
Contents
056994
switchboard are standard Prisma offer
components.
However, some of them such as busbar
supports, the Masterpact mounting plate, etc.
are specific.
Only the specific components are described in
this section of the Prisma catalogue file.
Mechanical data
■ material: steel
■ surface treatment: Prisma beige polyester epoxy paint
■ degree of protection:
❏ standard: IP 20
❏ optional: IP 31.
Electrical data
■ rated operational voltage Ue up to 1000 V
■ rated insulation voltage Uimp up to 1000 V
■ nominal current In: 4000 A
■ permissible rated peak current Ipk up to 176 kÂ
■ permissible rated short-time current Icw up to 80 kA rms/1sec
■ frequency f : 50/60 Hz
E58394
busbar
support
07297
insulating
screen
busbar
support
07291
support
07292
flanging rod
07294 framework
09602
mounting
plate
07296
insulating
screen
busbar spacer
support 02407
07292
angle
busbar bracket
support 07295
07297
600
700
P4000 switchboard
056993
056995
056991
056997
056992
Vertical connection
056998
Enclosure The basic enclosure is made up of a 700 mm wide and 600 mm deep framework.
In case of connection to bar tails behind the cubicle, a P400 framework must be
combined with the P600 framework.
Panels are standard Prisma with compulsory front plate support door.
056990
600 mm deep
E58407
600
1000 mm deep
E58408
1000
E58395
07296
Upstream connection Upstream connection is on the bar tails fixed to one another by supports.
The supports are in turn fixed to the framework by means of support angle
brackets equipped with spacers.
056997
57072
E58396
07294
07292
02407
07292
07295
07297
07292
insulating
screen
E58397 07297
07291
insulating
screen
07292
07295
07294
3P device
07297
E58398
07291
insulating
screen
07292
07295
07294
4P device
Installing the switchgear The devices are installed on specific functional uprights with a capacity of 31
modules.
Description ref.
1 set of 2 P4000 functional uprights 07290
E58400
Installing the horizontal busbar The horizontal busbars are fixed to each other by means of horizontal supports,
in turn fixed to the framework by specific supports.
Description ref.
1 horizontal busbar support 07297
1 set of 2 specific supports for fixing the horizontal busbar supports 07291
1 set of sliding fishplates/phase 07293
E58399
E58409
E58401
outgoing cubicles 1 1
3 2
incoming cubicle 3 2
E58402
outgoing cubicles 4 2
incoming cubicle 3 2
E58403
outgoing cubicles 1 3 2
outgoing cubicles 2 5 3
incoming cubicle 3 2
E58404
outgoing cubicles 3 2
700 700
incoming cubicle 3 2
E58405
outgoing cubicles 4 2
incoming cubicle 3 2
E58406
outgoing cubicles 3 2
incoming cubicle 3 2
E58493
outgoing cubicles 3 1
700 600
Caption
busbar support
set of busbar support
E58412
busbar
support
07297
busbar
support
07292
insulating
wedge
busbar spacer H=30
support 02407
07292
Linergy busbar
Use the Prisma busbar supports.
sliding
fishplates
07293
special fishplates
E58489
insulating wedge
H= 30
