Overcurrent Curves List

ASPEN
Overcurrent
Relay Library
List of Devices
Advanced Systems for Power Engineering, Inc.

NOTICE
The information in this document is subject to change without notice. Advanced Systems for Power Engineering, Inc.
(ASPEN) assumes no responsibility for any errors that may appear in this document.
Copyright  1988-2010 Advanced Systems for Power Engineering, Inc. All right reserved.
HOW TO ORDER MORE MANUALS
This Manual may be duplicated by the Licensee for its own use. You can order a new copy by writing to the address
below. Please refer to document OCL-UM-2007.
HOW TO REACH ASPEN
Mailing address: ASPEN

49 N. San Mateo Drive
San Mateo, CA 94401
U.S.A.
Telephone: (650)347-3997
Fax: (650)347-0233
eMail (English): support@aspeninc.com
eMail (Spanish/Portuguese): suporte@aspeninc.com
WEB Page: www.aspeninc.com
Our office hours are from 8:00 a.m. to 5:00 p.m. Pacific time (GMT-8 in the winter; GMT-7 in the summer), Monday
through Friday.
____________________________________________________________________________________
ASPEN OneLiner™, ASPEN Breaker Rating Module™, ASPEN Power Flow™, ASPEN DistriView™,
PowerScript™, ASPEN Relay Database™, ASPEN Line Constants Program™, and ASPEN Line Database™ are
trademarks of Advanced Systems for Power Engineering, Inc.
Contents
INTRODUCTION......................................................................................................................................................... 4
Relay Library Files ......................................................................................................... 4
LIST OF OVERCURRENT DEVICES ........................................................................................................................ 5
ABB.RLY ....................................................................................................................... 5
AREAVA.RLY............................................................................................................. 28
BASLER.RLY .............................................................................................................. 31
BECKWITH.RLY ........................................................................................................ 37
BUSSMANN.RLY ....................................................................................................... 38
CALOR_EMAG.RLY .................................................................................................. 47
CHANCE.RLY ............................................................................................................. 48
COMBINED_TECH.RLY............................................................................................ 53
COOPER.RLY.............................................................................................................. 54
CUTLER_HAMMER.RLY ........................................................................................ 113
ELASTIMOLD.RLY .................................................................................................. 125
ELECTROFUSI.RLY................................................................................................. 142
FEDERAL_PIONEER.RLY....................................................................................... 145
FUJI.RLY.................................................................................................................... 146
G&W_ELECTRIC.RLY............................................................................................. 147
GE.RLY: GE FUSES.................................................................................................. 189
HITACHI.RLY ........................................................................................................... 216
HITECH.RLY............................................................................................................. 217
HUBBELL.RLY ......................................................................................................... 224
JOSLYN.RLY............................................................................................................. 230
KEARNEY.RLY ........................................................................................................ 241
MERLIN_GERIN.RLY .............................................................................................. 245
MISUBISHI.RLY ....................................................................................................... 246
MULTILIN.RLY ........................................................................................................ 248
NU-LEC.RLY............................................................................................................. 254
NXTPHASE.RLY....................................................................................................... 257
OMRON.RLY............................................................................................................. 258
REYROLLE.RLY....................................................................................................... 259
RTE.RLY .................................................................................................................... 260
S&C.RLY.................................................................................................................... 262
SCHNEIDER_ELECTRIC.RLY ................................................................................ 291
SEL.RLY .................................................................................................................... 294
SHAWMUT.RLY....................................................................................................... 301
SIBA.RLY .................................................................................................................. 305
SIEMENS.RLY .......................................................................................................... 307
SOUTHERN_STATES.RLY...................................................................................... 313
STANDARD.RLY...................................................................................................... 321
TOSHIBA.RLY .......................................................................................................... 323
ZIV.RLY..................................................................................................................... 325
INTRODUCTION
Relay Library Files

The curve coordinates for a large number of relays, fuses, reclosers and other protective devices are
stored in binary files called “relay library files”. These files are inputs to ASPEN programs, including
ASPEN OneLiner, ASPEN DistriView, ASPEN Overcurrent Curve Editor™ and ASPEN Time Dial
Calculator™.
The curves are grouped by manufacturer: Each library files generally contains the curves from a single
manufacturer. The only exception is the file ASPEN_Taps.RLY, which contains a list of discrete tap
units, for backward compatibility. This document lists all the curves and their annotation.
LIST OF OVERCURRENT DEVICES
ABB.RLY
This file contains ABB, ASEA and Westinghouse relay, fuse and recloser curves.
670-ANSI-EI
ABB 670 Series ANSI Extremely Inverse no 1
Ref. 1MRK511187-UUS rev. A
Created 12/08/2009
670-ANSI-I
ABB 670 Series ANSI Normal Inverse no 3
Created 12/08/2009
670-ANSI-LEI
ABB 670 Series ANSI Long Time Extremely Inverse no 6
Created 12/08/2009
670-ANSI-LI
ABB 670 Series ANSI Long Time Inverse no 8
Created 12/08/2009
670-ANSI-LVI
ABB 670 Series ANSI Long Time Very Inverse no 7
Created 12/08/2009
670-ANSI-MI
ABB 670 Series ANSI Moderately Inverse no 4
Created 12/08/2009
670-ANSI-VI
ABB 670 Series ANSI Very Inverse no 2
Created 12/08/2009
670-IEC-EI
ABB 670 Series IEC Extremly Inverse no 12
Created 12/08/2009
670-IEC-I
ABB 670 Series IEC Inverse no 11
Created 12/08/2009
670-IEC-LTI
ABB 670 Series IEC Long-time Inverse no 14
Created 12/08/2009
670-IEC-NI
ABB 670 Series IEC Normal Inverse no 9
Created 12/08/2009
670-IEC-RI
ABB 670 Series IEC RI Inverse no 18
T=TD/(0.339-0.236/I)
Created 12/08/2009
670-IEC-VI
ABB 670 Series IEC Very Inverse no 10
Created 12/08/2009
ASPEN Overcurrent Relay Library Page 5

A-60
BBC Brown Boveri Overcurrent Relay: Type A,Inverse, 60cycles.
Created 5/22/95.
ABB-PCD-11
ABB PCD Recloser curve 11(141)
T=D*(21.6149/(M^2.69489-1)+10.6768)
Created 05/08/2003
ABB-PCD-2
T=D*(11.4161/(M^1.84911-1)+0.488986)
Created 05/08/2003
ABB-PCD-3
T=D*(13.5457/(M^1.76391-1)+0.992904)
Created 05/08/2003
ABB-PCD-8
T=D*(1.68546/(M^1.78873-1)+0.158114)
Created 05/08/2003
ABB-PCD-9
T=D*(2.75978/(M^1.0353-1)+5.10647)
Created 05/08/2003
AH-60
BBC Brown Boveri Overcurrent Relay: Type AH, Very Inverse, 60cycles.
Created 5/22/95.
AMPTECTOR-GH
Westinghouse Amptector I-A
Ground curve – upper limit
Created 10/16/2008
AMPTECTOR-GL
Ground curve – lower limit
Created 10/16/2008
AMPTECTOR-LH
Long delay curve – upper limit
Created 10/16/2008
AMPTECTOR-LL
Long delay curve – lower limit
Created 10/16/2008
AMPTECTOR-SH
Short time delay curve – upper limit
Created 10/16/2008
AMPTECTOR-SL
Short time delay curve – upper limit
Created 10/16/2008
ASEA-EI
ASEA RXIDE Relay. Extremely Inverse time-lag characteristic acc. to
BS 142, 1966. RFR 1083. Created 8/28/98.
NOTE: The curves for time dial settings 0.05, 0.1 and 0.2 are
approximated in the region less than 0.1 seconds.
ASEA-NI
ASEA RXIDE Relay. Normal Inverse time-lag characteristic acc. to
BS 142, 1966. RFR 1081. Created 8/28/98.
ASEA-VI
ASEA RXIDE Realy. Very Inverse time-lag characteristic acc. to
BS 142, 1966. RFR 1082. Created 8/28/98.
NOTE: The curve for time dial setting 0.05 is approximated
in the region less than 0.1 seconds.
CLE1-15-030
Westinghouse Type CLE-1, -2 and -3 Fuses. 15.5kV. 30E.
Ref. No. 598783, 598784, 622124, 622129. Created 11/4/96.

CLE1-15-040
Westinghouse Type CLE-1, -2 and -3 Current Limiting Power Fuses.
15.5Kv, 40E.
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-050
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-065
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-080
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-100
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-125
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-150
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-15-175
Westinghouse Type CLE-1, -2 and -3 Fuses. 15.5kV. 175E/200X.
Ref. No. 598783, 598784, 622124, 622129. Created 11/5/96.
CLE1-5-010
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 10E. Ref. No.
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/6/96.
CLE1-5-025
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-030
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-040
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-050
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-065
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-080
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 80E. Ref. No. 5
36900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089. C
reated 11/7/96.
CLE1-5-100
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-1200
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV.
2*600E in parallel. Ref. No. 666905. Created 11/4/96.
CLE1-5-125
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-150

536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-1500
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV.
2*750E in parallel. Ref. No. 666905. Created 11/4/96.
CLE1-5-200
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-225
536900, 536901, 536861, 536862, 536903, 536904, 598839, and 629089.
Created 11/7/96.
CLE1-5-250
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 250/280X.
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-300
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 300E/325X
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-350
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 350X
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-365X
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-400
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-450
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-600
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 600E
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-5-750
Westinghouse Type CLE-1 and -2 Fuses. 2.75 - 5.5kV. 750E
Ref. No. 536900, 536901, 536861, 536862, 536903, 536904, 598839,
and 629089. Created 11/7/96.
CLE1-8-030
Westinghouse Type CLE-1 and -2 Fuses. 8.25 kV. 30E.
Ref. No. 536010-A and 536911-A. Created 11/5/96.
CLE1-8-040
CLE1-8-050
CLE1-8-065
CLE1-8-080
CLE1-8-100
CLE1-8-125

CLE1-8-150
CLE1-8-200
CLS-A30
Westinghouse CLS-12,-14,-22,-24,-700, HCLS-12,-22 Motor Starter Fuses.
Curve A, 30 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-B70-2R
Curve B, 70 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-C100-3R
Curve C, 100 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-D130-4R
Curve D, 130 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-E150-5R
Curve E, 150 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-F170-6R
Curve F, 170 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-G200-9R
Curve G, 200 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-H230-12R
Curve H, 230 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-J390-18R
Curve J, 390 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-K450-24R
Curve K, 450 A. 2.0 to 5.5kV. Created 1/9/96.
CLS-L480-26R
Curve L, 480A. 2.0 to 5.5kV. Created 1/9/96.
CLS-M600-32R
Curve M, 600A. 2.0 to 5.5kV. Created 1/9/96.
CLS-N650-36R
Curve N, 650A. 2.0 to 5.5kV. Created 1/9/96.
CO-10
Updated 1/29/92.
CO-11
Westinghouse CO-11 relay, extremely inverse. Curve #418267.
Modeled by 40 points. Updated 9/25/95.
CO-2
Westinghouse CO-2 relay, short time, Curve #471044.
Updated 10/11/94.
CO-5
Westinghouse CO-5 relay, long time, Curve #471045.
Updated 10/11/94.
CO-6
Westinghouse CO-6 relay, definite time, Curve #418263.
Updated 10/11/94.
CO-7
Westinghouse CO-7 relay, moderate inverse, Curve #418264.
Updated 10/11/94.
CO-8
Westinghouse CO-8 relay, inverse, Curve #418265. Modeled by 40 points.

Updated 9/25/95.
CO-9
Westinghouse CO-9 relay, very inverse. Curve #418266.
CO-AI
Type CO Adjustable Inverse time over current relay.
Inverse calibration 60 cycles.
Created 11/30/92.
CO-AVI
Tpye CO Adjustable Inverse time over cuurent relay.
Very inverse calibration 60 cycles.
Created 11/30/92.
CO-DTS
Type CO Relay.
Definite Time Standard energy.60 cycles.
Created 12/1/92.
CO-DTS1
CO relay.
Definite time standard Energy.60 cycles.
Updated 8/26/95.
CO-DTSE
Type CP relay.
Definite Time Standard Energy.60 cycles.
Updated 8/25/95.
CO-ILE
Type CO Relay.
Inverse time Low Energy.60 cycles.
created 11/30/92.
CO-LTS
Type CO Relay.
Long Time Standard Energy.60 cycles.
Created 12/1/92.
CO-VIL
Type CO Relay.
Very Inverse Low energy.60 cycles.
Created 12/1/92.
COH
Type COH Relay.60 cycles.
Created 12/1/92.
CO-SE
Westinghouse CO standard energy 2 sec. definite time.
Created 11/06/2006
CR-10
Updated 1/29/92.
CR-11
Westinghouse CR-11 relay, extremely inverse. Copied from CO-11, Curve #
418267. Modeled by 40 points. Updated 9/25/95.
CR-2
Westinghouse CR-2 relay, short time, Copied from CO-2, Curve #471044.
Updated 2/7/95.
CR-5
Westinghouse CR-5 relay, long time. Copied from CO-5, Curve #471045.
Updated 2/7/95.
CR-6
Westinghouse CR-6 relay, definite time. Copied from CO-6,Curve #418263.
Updated 2/7/95.
CR-7
Westinghouse CR-7 relay, moderate inverse. Copied from CO-7,
Curve #418264. Updated 2/7/95.
CR-8
Westinghouse CR-8 relay, inverse. Copied from CO-8, Curve #418265.
CR-9
Westinghouse CR-9 relay, very inverse. Copied from CO-9, Curve #418266.

CSFULINK-006
ABB DO-III (FAULT) Sensing (143G) fuse link in transformer oil.
Fuse Link NOS. G4, 6 AMPS
Curve number 1C11103
Created 02/24/2005
CSFULINK-010
Curve number 1C11103, 1C11102
Created 02/24/2005
CSFULINK-015
Created 02/24/2005
CSFULINK-025
Created 02/24/2005
CSFULINK-040
Created 02/24/2005
CSFULINK-065
Created 02/24/2005
CSFULINK-100
Created 02/24/2005
CSFULINK-140
Created 02/24/2005
CU150/26
ABB CAPACITOR BANK FUSE. CU150/26 Internal Element Fuses.
Ref. No. KK93006(930524/EE). Created 7/8/95.
CU150/31
CU150/36
CU150/41
CU150/46
CWC
ABBTypical Time curves of the CWC Relay - Current coils in series
Time dial 0.5 to 11
Inst. leaflet: I.L.41-242.4F
Ref. no.: 9, 629A272
Created 12/13/2009.
CWP
ABB typical time curves for CWP Replay at maximum torque angle
Time dial 0.5 to 11
Inst leaflet: I.L.41-242.4F
Ref. No.: 629A273
Created 12/13/2009.

CXP-010
ABB Capacitors Expulsion Fuses type CXP
Fuse link type K
Curve: 10K
Drawing No.: KK99003a, 99-04-07/EE
Reference No.: 51184-A
Created 07/09/2009
DBA-125L-015
Westinghouse DBA-1, -2 and -5 dropout power fuses. time lag fuse
elements, 15E. 34.5 to 69kV. Curve No. 14 and 16. Created 6/24/96.
DBA-125L-020
DBA-125L-025
DBA-125L-030
DBA-125L-040
DBA-125L-050
DBA-125L-065
DBA-125L-080
DBA-125L-100
DBA-125L-125
DBA-125L-150
DBA-125L-200
DBA-125S-0.5
Westinghouse DBA-1, -2 and -5 dropout power fuses. standard speed fuse
elements, 1/2E. 34.5 to 69kV. Curve No. 10 and 12. Created 6/21/96.
DBA-125S-003
DBA-125S-005
DBA-125S-007
DBA-125S-010
DBA-125S-015
DBA-125S-020

DBA-125S-025
Westinghouse DBA-1,-2 and -5 dropout power fuses. standard speed fuse
DBA-125S-030
DBA-125S-040
DBA-125S-050
elements, 50E. 34.5to 69kV. Curve No. 10 and 12. Created 6/24/96.
DBA-125S-065
DBA-125S-080
DBA-125S-100
DBA-125S-125
DBA-125S-150
elements, 150E. 34.5 to 69kV. Curve No.10 and 12. Created 6/24/96.
DBA-125S-200
elements, 200E. 34.5 to 69kV. Curve No.10 and 12. Created 6/24/96.
DBA-1L-015
Westinghouse DBA-1, dropout power fuses. time lag fuse elements,
15E. 2.4 to 23kV. Curve No. 14 and 15. Created 6/24/96.
DBA-1L-020
DBA-1L-025
DBA-1L-030
DBA-1L-040
DBA-1L-050
DBA-1L-065
DBA-1L-080
DBA-1L-100
DBA-1L-125
DBA-1L-150
DBA-1L-200

DBA-1S-0.5
Westinghouse DBA-1, dropout power fuses. standard speed fuse elements,
1/2E. 2.4 to 23kV. Curve No. 10 and 11. Created 6/21/96.
DBA-1S-003
DBA-1S-005
DBA-1S-007
DBA-1S-010
DBA-1S-015
DBA-1S-020
DBA-1S-025
DBA-1S-030
DBA-1S-040
DBA-1S-050
DBA-1S-065
DBA-1S-080
DBA-1S-100
DBA-1S-125
DBA-1S-150
150E. 2.4 to 23kV. Curve No.10 and 11. Created 6/21/96.
DBA-1S-200
200E. 2.4 to 23kV. Curve No.10 and 11. Created 6/21/96.
DBA-2L-015
15E. 92 to 138kV. Curve No. 14 and 17. Created 6/24/96.
DBA-2L-020
DBA-2L-025
DBA-2L-030

DBA-2L-040
DBA-2L-050
DBA-2L-065
DBA-2L-080
80E. 92 to138kV. Curve No. 14 and 17. Created 6/24/96.
DBA-2L-100
DBA-2L-125
DBA-2L-150
DBA-2L-200
DBA-2S-005
DBA-2S-007
7E. 92 to 138 kV. Curve No. 10 and 13. Created 6/24/96.
DBA-2S-010
DBA-2S-015
DBA-2S-020
DBA-2S-025
DBA-2S-030
DBA-2S-040
DBA-2S-050
DBA-2S-065
DBA-2S-080
DBA-2S-100
DBA-2S-125
DBA-2S-150

150E. 92 to 138kV. Curve No.10 and 13. Created 6/24/96.
DBA-2S-200
200E. 92 to 138kV. Curve No.10 and 13. Created 6/24/96.
DEFULINK-005
ABB DO-III Dual Element (145G) fuse links in transformer oil.
Created 02/24/2005
DEFULINK-006
Created 02/24/2005
DEFULINK-008
Created 02/24/2005
DEFULINK-012
Created 02/24/2005
DEFULINK-015
Created 02/24/2005
DEFULINK-025
Created 02/24/2005
DEFULINK-040
Created 02/24/2005
DEFULINK-050
Created 02/24/2005
DPU_#8
ABB DPU Relay: Recloser Curve #8. DWG No: 605856.
T=(4.211/(M^1.8-0.35)+0.013)*(14*n-5)/9; Updated 8/8/96.
DPU_EI
ABB DPU Relay: Extremely Inverse Curve. DWG No: 605842
T=(2.855/(M*M-1)+.0112)*2.244*(14*n-5)/9; Created 8/8/96.
DPU_EI**
ABB DPU Relay: Extremely Inverse Curve.
Original series circa 1986. Catalog series 245D, 445H, 445V.
T=(2.93/(M*M-1.026)+.0112)*2.244* (14*n -5)/9; Created 4/1/94.
DPU_I
ABB DPU relay: inverse curve
T = [.6814*ln(M/(M-1)) + .1282]*(14*n-5)/9]
Created 19/02/2003
DPU_LEI
ABB DPU Relay: Long Time Extremely Inverse Curve.
DWG No: 605842, Rev 2.
T=(64.07/(M*M-1)+0.25)*(14*n-5)/9;
Created 8/8/96.
DPU_LTI
ABB DPU relay: long time inverse curve
T = 10 * Inverse time
Created 11/02/2000

DPU_LVI
ABB DPU Relay: Long Time Very Inverse Curve.
DWG No: 605841, Rev 2
T=(28.55/(M*M-1)+0.712)*(14*n-5)/9; Created 8/8/96.
DPU_LVI**
ABB DPU Relay: Long Time Very Inverse Curve. Original series circa 1886
. Catalog series 245D, 445H, 445V.
T=(29.3/(M*M-1.026)+0.712)(14*n-5)/9
Created 4/1/94.
DPU_STI
ABB DPU relay: Short time inverse curve.
T = 0.2 * Inverse time
Created 19/02/2003
DPU_VI
ABB DPU Relay: Very Inverse Curve.
T=(2.855/(M*M-1)+.0712)(14*n-5)/9. Created 8/8/96.
DPU_VI**
ABB DPU Relay: Very Inverse Curve. Original series circa 1986. Catalog
series 245D, 445H, 445V.
T=(2.93/(M*M-1.026)+.0712)(14*n-5)/9. Created 4/1/94.
DPU2000-#8
ABB DPU-2000 Relay: Curve #8. DWG No: 605856, Rev 0.
T=(4.211/(M^1.8-0.35)+0.013)*(14*n-5)/9; Created 8/8/96.
DPU2000_EI
ABB DPU-2000 Relay: Extremely Inverse Curve. DWG No: 605842, Rev 2.
T=(6.407(M*M-1)+0.025)*(14*n-5)/9; Created 6/15/2004.
DPU2000_I
ABB DPU-2000 Relay: Inverse. DWG No: 605854, Rev 0.
T=(0.0086/(M^0.02-1)+0.0185)*(14*n-5)/9;
Created 6/15/2004.
DPU2000_LEI
ABB DPU Relay: Long Time Extremely Inverse Curve.
DWG No: 605842, Rev 2.
T=(64.07/(M*M-1)+0.25)*(14*n-5)/9;
Created 6/15/2004.
DPU2000_LI
ABB DPU Relay: Long Time Inverse Curve.
T=(0.086/(M^0.02)-1)+0.185)*(14*n-5)/9;
Created 6/15/2004
DPU2000_LVI
ABB DPU-2000 Relay: Long Time Very Inverse Curve.
DWG No: 605841, Rev 2
T=(28.55/(M*M-1)+0.712)*(14*n-5)/9; Created 6/15/2004.
DPU2000_SEI
ABB DPU Relay: Short Time Extremely Inverse Curve.
T=(1.281/(M^2)-1)+0.005)*(14*n-5)/9;
Created 6/15/2004
DPU2000_SI
ABB DPU-2000 Relay: Short Time Inverse. DWG No: 605855, Rev 0.
T=(0.00172/(M^.02-1)+0.0037)*(14*n-5)/9; Created 6/15/2004
DPU2000_VI
ABB DPU-2000 Relay: Very Inverse Curve. DWG No: 605841
T=(2.855/(M*M-1)+0.0712)*(14*n-5)/9; Created 6/15/2004
DPU2000R_II
ABB DPU2000R Relay: Inverse Instantaneous curve
DWG. NO. 604916 Rev. 0
Created 2/08/2006
DPU2000R_IS
ABB DPU2000R Relay: Standard Instantaneous curve
DWG. NO. 605845 Rev. 2
Created 2/22/2006
DSFULINK-003
ABB DO-III Dual Sensing (144G) fuse links in transformer oil.
Created 02/24/2005

DSFULINK-008
Created 02/24/2005
DSFULINK-015
Created 02/24/2005
DSFULINK-025
Created 02/24/2005
DSFULINK-050
Created 02/24/2005
DSFULINK-065
Created 02/24/2005
ICM2
BBC Brown Boveri Overcurrent Relay:
Type ICM2, Inverse, 60cycles,
T=0.0014*D/( I**0.002 -1)
Created 5/22/95.
ICM22
Type ICM22,Very Inverse time, 60cycles,
Created 4/08/2003.
IKC_EI
ABB Overcurrent Relay:
Type IKC, Extremely Inverse (British Standard 142).
T = 80.0*D / (M**2 - 1).
Created 7/9/97.
IKC_LTEF
Type IKC, Long Time Earth Fault (British Standard 142).
T = 120.0*D / ((M) - 1).
Created 7/9/97.
IKC_NI
Type IKC, Normally Inverse (British Standard 142).
T = 0.14*D / (M**0.02 - 1).
Created 7/9/97.
IKC_VI
Type IKC, Very Inverse (British Standard 142).
T = 13.5*D / ((M) - 1).
Created 7/9/97.
IMPRS-EI
ABB IMPRS and IMPRS Motor Relay: Extremely Inverse.
T=(2.855/(M*M-1)+0.0112)*(14*n-5)/9;
DWG No 605850 Rev 2. Updated 8/8/96.
IMPRS_I
ABB IMPRS and IMPRS Motor Relay: Inverse.
DWG No: 605852 Rev 2. Updated 11/22/93.
IMPRS_SI
ABB IMPRS and IMPRS Motor Relay: Short Time Inverse. DWG No: 605853
Rev 2. T=0.2*(0.6814*ln(M/(M-1))+0.1282)*(14*n-5)/9);
Updated 8/9/96.
IMPRS_VI
ABB IMPRS and IMPRS Motor relay: Very Inverse.

DWD No: 605851 Rev 2. Created 11/22/93.
IMPRSm_LEI
ABB IMPRS and IMPRS Motor relay: Long Time Extremely Inverse.
DWD No: 605870 Rev 0
Created 11/22/93.
IMPRSm_LI
ABB IMPRS and IMPRS Motor relay: Long Time Inverse.
DWG No: 605872 Rev 2
Created 11/22/93.
IMPRSm_LVI
ABB IMPRS and IMPRS Motor relay: Long Time Very Inverse.
DWD No: 605871 Rev 2
Created 11/22/93.
IMPRSm_OL
ABB IMPRS Motor Relay: Thermal Overload. DWG No: 605875.
Created 7/17/96.
IRD-10
Updated 1/29/92.
IRD-11
Westinghouse IRD-11 relay, extremely inverse. Copied from CO-11, Curve
#418267. Modeled by 40 points. Updated 9/25/95.
IRD-2
Westinghouse IRD-2 relay, short time. Copied from CO-2, Curve #471044.
Updated 2/7/95.
IRD-5
Westinghouse IRD-5 relay, long time. Copied from CO-5, Curve #471045.
Updated 2/7/95.
IRD-6
Westinghouse IRD-6 relay, definite time. Copied from CO-6, Curve #418263.
Updated 2/7/95.
IRD-7
Westinghouse IRD-7 relay, moderate inverse. Copied from CO-7, Curve #418264.
Updated 2/7/95.
IRD-8
Westinghouse IRD-8 relay, inverse, Copied from CO-8, Curve #418265.
IRD-9
Westinghouse IRD-9 relay, very inverse. Copied from CO-9, Curve #418266
ITE-51D
Type ITE-51D Definite Time.
Drawing No: TCC605806
Created: 11/30/93.
ITE-51E
Type ITE-51E Extremely Inverse.
Created: 11/30/93.
ITE-51I
BBC Brown Boveri Overcurrent Relay: Type ITE-51I Inverse.
Drawing No: TTC605801.
Created 11/30/93.
ITE-51IM
BBC Brown Boveri Overcurrent Relay: Type ITE-51IM Long Time Inverse.
Created 11/30/93.
ITE-51L
Type ITE-51L Long Time, Extremely Inverse.
Created: 11/30/93.
ITE-51S
BBC Brown Boveri Overcurrent Relay: Type ITE-51S Short Time.
Created 11/30/93.

ITE-51S(SP)
BBC Brown Boveri Overcurrent Relay: Type ITE-51S (SP) Short Time (SP).
Created 11/30/93.
ITE-51Y
Type ITE-51Y Very Inverse.
Created: 11/30/93.
ITE-51YM
Type ITE-51YM Long Time, Very Inverse.
Created: 11/30/93.
KRD4-A
Westinghouse Electric KRD-4 Relay
Typical operating times
Directional unit closing times
Curve A: Current, Voltage, or dual polarized
Created 04/24/2007
KRD4-B
Directional unit closing times
Curve B: 5 Volt Voltage polarized
Created 04/24/2007
KRD4-INST
Instantaneous overcurrent unit closing times
Created 04/24/2007
KRD4-OPEN
Directional unit opening times
Current, Voltage, or dual polarized
Created 04/24/2007
MCO-CV1
Westinghouse or ABB MCO relay, Curve 1, Similar to CO-2.
T = [112+735/(I -0.675)]*D/24000
Created 3/1/95.
MCO-CV2
T = [8197+13769/(I -1.130)]*D/24000
Created 3/1/95.
MCO-CV3
T = [785+671/(I -1.19)]*D/24000
Created 3/1/95.
MCO-CV4
T = [525+3121/(I -0.8)]*D/24000
Created 3/1/95.
MCO-CV5
T = [478+4122/(I -1.27)]*D/24000
Created 3/1/95.
MCO-CV6
T = [310+2756/(I -1.335)]*D/24000
Created 3/1/95.
MCO-CV7
T = [110+17640/(I -0.5)**2]*D/24000
Created 3/1/95.
MDAR-CO2
ABB MDAR relay, Similar to CO-2 Relay.

Short time inverse
T = 0.030625 *D/( M - 0.675 ) + 0.00466*D
Created 10/09/2008.
MDAR-CO5
Long time inverse
T = 0.5737 *D/( M - 1.13 ) + 0.341527*D
Created 10/09/2008.
MDAR-C06
T = 0.02796*D/( M - 1.19 ) + 0.03268*D
Created 10/09/2008.
MDAR-CO7
Moderate inverse
T = 0.13 *D/( M - 0.8 ) + 0.021868*D
Created 10/09/2008.
MDAR-CO8
T = 0.171753 *D/( M - 1.27 ) + 0.01991*D
Created 9/19/96.
MDAR-CO9
Very inverse
T = 0.11483 *D/( M - 1.35 ) + 0.012917*D
Created 10/09/2008.
MDAR-CO11
Extremely inverse
T = 0.735 *D/( M - 0.5 )^2 + 0.00458*D
Created 10/09/2008.
MICRO-51-EI
ABB Microshield Relay: Extremely Inverse Curve. DWG No: 605842
T=(2.855/(M*M-1)+.0112)*2.244*(14*n-5)/9; Created 8/8/96.
MICRO-51-LEI
ABB Microshield relay: Long Time Extremely Inverse Curve.
DWG No: 605842, Rev 2.
T=(64.07/(M*M-1)+0.25)*(14*n-5)/9;
Created 8/8/96.
MICRO-51_EI*
ABB MICRO-51 Relay: Extremely Inverse. DWG No 605850 Rev 2.
T=(2.855/(M*M-1)+0.0112)*(14*n-5)/9; Created 8/8/96.
MICRO-51_I
ABB MICRO-51 Relay: Inverse. DWG No: 605854, Rev 0.
T=(0.0086/(M**0.002-1)+0.0186)*(14*n-5)/9; Created 8/8/96.
MICRO-51_LI
ABB MICRO-51 Relay: Long time Inverse. DWG No: 605854, Rev 0.
T=10*(0.00855/(M**0.02-1)+0.0186)*(14*n-5)/9; Created 8/20/96.
MICRO-51_LVI
ABB MICRO-51 Relay: Long Time Very Inverse. DWG No: 605851, Rev 2.
T=10*(2.855/(M**2-1)+0.0712)*(14*n-5)/9; Created 8/20/96.
MICRO-51_SI
ABB MICRO-51 Relay: Short Time Inverse. DWG No: 605855, Rev 0.
T=0.2*(0.0086/(M**0.02-1)+0.0186)*(14*n-5)/9; Created 8/8/96.
MICRO-51_VI
ABB MICRO-51 Relay: Inverse. DWG No: 605851, Rev 2.
T=(2.855/(M*M-1)+0.0712)*(14*n-5)/9; Created 8/8/96.
MICRO51_LEI*
ABB MICRO-51 Relay: Long time Extremely Inverse. DWG No: 605850, Rev 2.
T=10*(2.855/(M**2-1)+0.0112)*(14*n-5)/9; Created 8/20/96.
MMCO-CV1
Westinghouse or ABB MMCO relay, Curve 1, Similar to CO-2.
T = [112+735/(I -0.675)]*D/24000
Created 3/1/95.
MMCO-CV2

T = [8197+13769/(I -1.130)]*D/24000
Created 3/1/95.
MMCO-CV3
T = [785+671/(I -1.19)]*D/24000
Created 3/1/95.
MMCO-CV4
T = [525+3121/(I -0.8)]*D/24000
Created 3/1/95.
MMCO-CV5
T = [478+4122/(I -1.27)]*D/24000
Created 3/1/95.
MMCO-CV6
T = [310+2756/(I -1.335)]*D/24000
Created 3/1/95.
MMCO-CV7
T = [110+17640/(I -0.5)**2]*D/24000
Time Dial from 3 to 63. Created 3/1/95.
MMCO-CV7a
T = [110+17640/(I-0.5)**2]*D/24000
Time Dial from 1 to 63. Created 7/15/96.
MPSC2000GHI
MPSC2000 Trip device
Ground time delay band upper limit
TD=1: Min; 2: Interm; 3: Max
ABB Drawing TD-9652
Created 08/30/2006
MPSC2000GLO
Ground time delay band lower limit
ABB Drawing TD-9652
Created 08/30/2006
MPSC2000INST
Instantaneous curve
TD=1
ABB Drawing TD-9651
Created 08/30/2006
MPSC2000LTHI
Long time delay band upper limit
ABB Drawing TD-9651
Created 08/30/2006
MPSC2000LTLO
Long time delay band lower limit
ABB Drawing TD-9651
Created 08/30/2006
MPSC2000STHI
Short time delay band upper limit
ABB Drawing TD-9651
Created 09/21/2006
MPSC2000STLO
Short time delay band lower limit
ABB Drawing TD-9651
Created 09/21/2006

MTR-INST
Westinghouse MTR static controlled 400-Pr, 560-PR and 560-ORM recloser
Curve: Instantaneous
Created: 04/12/2009
MTR-INST1
Curve: Instantaneous 1
Created: 04/14/2009
MTR-INST2
Created: 04/14/2009
MTR-INST3
Created: 04/14/2009
MTR-TD
Curve: Time Delay
Created: 04/12/2009
MTR-TD1
Curve: Time Delay 1
Created: 04/14/2009
MTR-TD2
Curve: Time Delay 2
Created: 04/14/2009
PCD2000-8
ABB PCD2000 Recloser
Curve 8.
T=((1.68546/(M^1.78873-0.436253))+0.158114)*((14*n-5)/9)
n=time dial
Created 07/22/2005
PCD2000-C
Curve C.
T=((8.76047/(M^1.80788-0.380004))+0.029977)*((14*n-5)/9).
n = Time Dial.
M = Multiples of pickup current
Created 07/22/2005
PCD2000-E
Curve E.
T=((10.7656/(M^2.18261-0.249969))+0.004284)*(14*n-5)/9
n = Time Dial.
M = Multiples of pickup current
Created 07/22/2005Created 07/22/2005
PCD2000-EI
ANSI Extremely Inverse curve
T=((6.407/(M^2 - 1) + 0.025 )*((14n-5)/9)
Created 02/27/2006
PCD2000-I
ANSI Inverse curve
T=((0.086/(M^0.02 - 1) + 0.0185 )*((14n-5)/9)
Created 02/27/2006
PCD2000-LEI
ANSI Long Time Extremely Inverse curve
T=((64.07/(M^2 - 1) + 0.25 )*((14n-5)/9)
Created 02/27/2006
PCD2000-LI
ANSI Long Time Inverse curve
T=((0.086/(M^0.02 - 1) + 0.185 )*((14n-5)/9)

Created 02/27/2006
PCD2000-LVI
ANSI Long Time Very Inverse curve
T=((28.55/(M^2 - 1) + 0.712 )*((14n-5)/9)
Created 02/27/2006
PCD2000-SEI
ANSI Short Time Extremely Inverse curve
T=((1.281/(M^2 - 1) + 0.005 )*((14n-5)/9)
Created 02/27/2006
PCD2000-SI
ANSI Short Time Inverse curve
T=((0.00172/(M^0.02 - 1) + 0.037 )*((14n-5)/9)
Created 02/27/2006
PCD2000-VI
ANSI Very Inverse curve
T=((2.855/(M^2 - 1) + 0.0712 )*((14n-5)/9)
Created 02/27/2006
PR
Westinghouse type PR static controlled recloser. Model 560-PR and 560-P
RM. Application Data 38-726-A.
Curve PR
Created 07/25/2005
PR-1
Westinghouse static controller 400-Pr, 560-Pr and 560-PRM recloser
Time delay curve #1
Created 06/21/2004
PR-2
Time delay curve #2
Created 06/21/2004
PR-I
Westinghouse type PR static controlled recloser. Model 560-PR and 560-P
RM. Application Data 38-726-A.
Curve PR-I.
Created 07/25/2005
PR-I1
Instantaneous curve #1
Created 06/21/2004
PR-I2
Created 06/21/2004
PR-I3
Created 06/21/2004
PROLINK-10
ABB Protective Links #10
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-11
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-12
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-13
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002

PROLINK-2
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-3
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-3A
ABB Protective Links #3A
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-4
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-5
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-5A
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-6
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-7
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-7A
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-8
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
PROLINK-9
Curve No 697700 & 735701 Rev. 1
Created 11/05/2002
RBA-RDB-0.5E
Westinghouse Type RBA-RDB-400 Refill Power Fuse, Standard Speed.
2.4 to 34.5kV. 0.5A.
Ref No. 628862, Curve No. 5 and 6.
Created 12/23/94
RBA-RDB-003E
2.4 to 34.5kV. 3A.
Created 12/23/94
RBA-RDB-005E
2.4 to 34.5kV. 5A.
Created 12/23/94
RBA-RDB-007E
2.4 to 34.5kV. 7A.
Created 12/23/94
RBA-RDB-010E
2.4 to 34.5kV. 10A.

Created 12/23/94
RBA-RDB-015E
2.4 to 34.5kV. 15A.
Created 12/23/94
RBA-RDB-020E
2.4 to 34.5kV. 20A.
Created 12/23/94
RBA-RDB-025E
2.4 to 34.5kV. 25A.
Created 12/23/94
RBA-RDB-030E
2.4 to 34.5kV. 30A.
Created 12/23/94
RBA-RDB-040E
2.4 to 34.5kV. 40A.
Created 12/23/94
RBA-RDB-050E
2.4 to 34.5kV. 50A.
Created 12/23/94
RBA-RDB-065E
2.4 to 34.5kV. 65A.
Created 12/23/94
RBA-RDB-080E
2.4 to 34.5kV. 80A.
Created 12/23/94
RBA-RDB-100E
2.4 to 34.5kV. 100A.
Created 12/23/94
RBA-RDB-125E
2.4 to 34.5kV. 125A.
Created 12/23/94
RBA-RDB-150E
2.4 to 34.5kV. 150A.
Created 12/23/94
RBA-RDB-200E
2.4 to 34.5kV. 200A.
Created 12/23/94
RBA-RDB-250E
2.4 to 34.5kV. 250A.
Created 12/23/94

RBA-RDB-300E
2.4 to 34.5kV. 300A.
Created 12/23/94
RBA-RDB-400E
2.4 to 34.5kV. 400A.
Created 12/23/94
REL301_CO11
ABB REL 301/302 CO11 curve. Create 3/16/2001.
REL301_CO2
REL301_CO5
REL301_CO6
REL301_CO7
REL301_CO8
REL301_CO9
REL512 -CO6
ABB REL 512 Definity Time Over Current Characteristics
T=[0.3164*D/(M**1.4-1)] + 0.1934*D
REL512-CO11
ABB REL 512 Extremely Inverse Time Over Current Characteristics
T=[5.57*D/(M**2.0-1)] + 0.028*D
Created 2003/02/03
REL512-CO2
ABB REL 512 Short Time Over Current Characteristics
T=[0.1052*D/(M**0.8-1)] + 0.0262*D
REL512-CO5
ABB REL 512 Long Time Over Current Characteristics
T=[4.842*D/(M**1.1-1)] + 1.9662*D
REL512-CO7
ABB REL 512 Moderately inverse Over Current Characteristics
T=[0.0094*D/(M**0.02-1)] + 0.0366*D
Modified 02/08/2006
REL512-CO8
ABB REL 512 Inverse Time Over Current Characteristics
T=[5.8478*D/(M**2.0-1)] + 0.1654*D
Created 2003/02/03
REL512-CO9
ABB REL 512 Very Inverse Time Over Current Characteristics
T=[4.1204*D/(M**2.0-1)] + 0.0958*D
Modified 02/08/2006
RXIDF-2H-EI
ASEA AC time-overcurrent rely, Type RXIDF 2H, Extremely inverse.
Ref No. RK473-006AA. Created 7/3/96.
RXIDF-2H-I
ASEA AC time-overcurrent relay, Type RXIDF 2H, Normal inverse.
RXIDF-2H-RII
ASEA AC time-overcurrent relay, Type RXIDF 2H, RI inverse.
RXIDF-2H-VI
ASEA AC time-overcurrent relay, Type RXIDF 2H, Very Inverse.

AREAVA.RLY
This file contains AREAVA, ALSTOM and GEC relay curves.
ALST-IEC-EI
ALSTOM IEC Extremely Inverse curves
TMS: 0.025 to 1.2
t= TMS*(80/(M^2 -1))
Created 2003-10-07
ALST-IEC-SI
ALSTOM IEC Standard Inverse curves
TMS: 0.025 to 1.2
t= TMS*(0.14/(M^0.02 -1))
Created 2003-10-07
ALST-IEC-VI
ALSTOM IEC Very Inverse curves
TMS: 0.025 to 1.2
t= TMS*(13.5/(M -1))
Created 2003-10-07
ALST-IEEE-EI
ALSTOM IEEE Extremely Inverse curves
TD: 0.5 to 15
t= (TD/7)*(28.2/(M^2 -1) + 0.1217)
Created 2003-10-07
ALST-IEEE-MI
ALSTOM IEEE Moderately Inverse curves
TD: 0.5 to 15
t= (TD/7)*(0.0515/(M^0.02 -1) + 0.114)
Created 2003-10-07
ALST-IEEE-VI
ALSTOM IEEE Very Inverse curves
TD: 0.5 to 15
t= (TD/7)*(19.61/(M^2 -1) + 0.491)
Created 2003-10-07
ALSTIEEE-EI*
ALSTOM IEEE Extremely Inverse curves version 2.08 or later
TD: 0.5 to 15
t= (TD)*(28.2/(M^2 -1) + 0.1217)
This curve is the newer version of ALST-IEEE-EI in which TD/7 was replaced by TD in
the curve equation.
Created 06/28/2007
ALSTIEEE-MI*
ALSTOM IEEE Moderately Inverse curves version 2.08 or late
TD: 0.5 to 15
t= (TD)*(0.0515/(M^0.02 -1) + 0.114)
This curve is the newer version of ALST-IEEE-MI in which TD/7 was replaced by TD in
the curve equation.
Created 06/28/2007
ALSTIEEE-VI*
ALSTOM IEEE Very Inverse curves version 2.08 or later
TD: 0.5 to 15
t= (TD)*(19.61/(M^2 -1) + 0.491)
This curve is the newer version of ALST-IEEE-VI in which TD/7 was replaced by TD in
the curve equation.
Created 06/28/2007
ALST-UK-LTI
ALSTOM UK Long time Inverse curves
TMS: 0.025 to 1.2
t= TMS*(120/(M -1))
Created 10/07/2003
ALST-USCO2-S
ALSTOM US CO2 Short time curves
TD: 0.5 to 15
t= (TD/7)*(0.02394/(M^0.02 -1) + 0.01694)
Created 10/07/2003

ALST-USCO8-I
ALSTOM US CO8 Inverse curves
TD: 0.5 to 15
t= (TD/7)*(5.95/(M^2 -1) + 0.18)
Created 10/07/2003
ALST-USCO2*
ALSTOM US CO2 Short time curves
TD: 0.5 to 15 version 2.08
t= (TD)*(0.16758/(M^0.02 -1) + 0.11858)
This curve is the newer version of ALST-USCO2-S in which TD/7 was repla
ced by TD in the equation.
Created 06/28/2007
ALST-USCO8*
ALSTOM US CO8 Inverse curves
TD: 0.5 to 15
t= (TD)*(5.95/(M^2 -1) + 0.18)
This curve is the newer version of ALST-USCO8-I in which TD/7 was repla
ced by TD in the equation.
Created 06/28/2007
CDG-11_NI
GEC Relay: CDG 11, 21, 31, 41, 51, 61. Normal Inverse, 3.0s @ 10*Is.
Drawing No. 398.23.96. Updated 7/9/97.
CDG-11_SI
GEC Relay: CDG 11, 21, 31, 41, 51, 61. Short time normal inverse.
1.3s at 10*Is. Drawing No: 398.23.95. Created 8/9/96.
CDG-12
GEC relay: CDG 12. Long time: 30s at 5*Is. Drawing No: 398.23.101.
Created 8/9/96.
CDG-13_VI
GEC Relay: CDG 13, 23, 33, 43, 53, 63. Very inverse: 1.5s at 10*Is.
Drawing No: 398.23.98. Created 8/9/96.
CDG-14_EI
GEC Relay: CDG14. Extremely Inverse.
Drawing No: 398.S23.37. Created 7/9/97.
EIX10DT
GEC EIX10DT Extremely Inverse Curve. Definite time above 10xIs.
EIX20DT
GEC EIX20DT Extremely Inverse Curve. Definite time above 20xIs.
EPAC-EI ANSI
EPAC-2000 Relay: Extremely Inverse ANSI Characteristics. Created 10/3/98
EPAC-EI IEC
EPAC-2000 Relay: Extremely Inverse IEC Characteristics. Created 10/3/98
EPAC-MI ANSI
EPAC-2000 Relay: Moderately Inverse ANSI Characteristics. Created 10/3/98
EPAC-SI ANSI
EPAC-2000 Relay: Standard Inverse ANSI Characteristics. Created 10/3/98
EPAC-SI IEC
EPAC-2000 Relay: Standard Inverse IEC Characteristics. Created 10/3/98
EPAC-VI ANSI
EPAC-2000 Relay: Very Inverse ANSI Characteristics. Created 10/3/98
EPAC-VI IEC
EPAC-2000 Relay: Very Inverse IEC Characteristics. Created 10/3/98
INX30DT
GEC STX30DT Inverse Curve.
K142-EI ANSI
KCGG142/KCEG142 relays: Extremely Inverse ANSI Characteristics. Created 10/3/98
K142-MI ANSI
KCGG142/KCEG142 relays: Moderately Inverse ANSI Characteristics. Created 10/3/98
K142-VI ANSI
KCGG142/KCEG142 relays: Very Inverse ANSI Characteristics. Created 10/3/98
LTX30DT
GEC LTX30DT Long Time Inverse Curve.
MCGG-EI
GEC MCGG Overcurrent relay.
Extremely Inverse.

T = 80*D/(I**2 -1)
Created 3/1/95.
MCGG-LTI
Longtime earth fault.
T = 120*D/(I -1)
Created 3/1/95.
MCGG-SI
Standard Inverse.
T = 0.14*D/(I**0.02 -1)
Created 3/1/95.
MCGG-VI
Very Inverse.
T = 13.5*D/(I -1)
Created 3/1/95.
MCGGDT2
2s definite time. Updated 1/23/92.
MCGGDT4
4s definite time. Updated 1/23/92.
MCGGDT8
8s definite time. Update 1/23/92.
OPTIMHO-1ST
GEC OPTIMHO Static Distance relay.
Curve 1: Standard Inverse.
T = 0.14*D/(I**0.02 -1)
Created 3/1/95.
OPTIMHO-2VI
Curve 2: Very Inverse.
T = 13.5*D/(I -1)
Created 3/1/95.
OPTIMHO-3EI
GEC OPTIMHO Static Distance Relay.
Curve 3: Extremely Inverse.
T = 80*D/(I**2 -1)
Created 3/1/95.
OPTIMHO-4LTS
Curve 4: Longtime standby earth fault.
T = 120*D/(I -1)
Created 3/1/95.
OPTIMHO-5MI
OPTIMHO Static Distance Protection Relay, DEF Protection time delay trip times.
Curve 5: US moderate inverse.
Created 9/14/93.
OPTIMHO-6SI
Curve 6: US standard inverse.
Created 9/14/93.
OPTIMHO-7VI
Curve 7: US very inverse.
Created 9/14/93.
OPTIMHO-8EI
Curve 8: US extremely inverse.
Created 9/14/93.
SIX30DT
GEC SIX30DT Standard Inverse (Moderately Inverse) curve. 10/92.
STX30DT
GEC STX30DT Short Time Inverse Curve.
VIX30DT
GEC VIX30DT Very Inverse Curve.

BASLER.RLY
This file contains Basler Electric relay curves.
BE1-1051_46
Basler Electric BE1-1051 inverse time-overcurrent relay. 51P, 51Q, 51N
Curve 46 Negative sequence overcurrent
T=0.028
Created 2003-04-01
BE1-1051_A
Curve A Standard inverse
Drawing 99-1621
T=0.01414*D/(M-1) + 0.028
Created 2003-04-01
BE1-1051_B
Curve B (for both SW3-3 open and closed )very inverse (I^2t)
Drawing 99-1376
T=1.4636*D/(M^1.0469-1) + 0.028
Created 2003-04-01
BE1-1051_C
Curve C (for both SW3-3 open and closed ) extremely inverse (I^2t)
Drawing 99-1377
T=8.2506*D/(M^2.0469-1)+0.028
Created 2003-04-01
BE1-1051_D
Curve D D( for both SW3-3 open and closed ), Definite time
Drawing 99-1371
T=0.4797*D/(M^1.5625-1)+0.21359*D+0.028
Created 2003-04-01
BE1-1051_E1
Curve E1 (SW3-3 open) Extremely Inverse
Drawing 99-1375
T=7.7624*D/(M^2.0938-1)+0.02758*D+0.028
Created 2003-04-01
BE1-1051_E2
Curve E2 (SW3-3 closed) E2,Extremely Inverse
Drawing 99-1598
T=4.9883*D/(M^2.0469-1)+0.0129*D+0.028
Created 2003-04-01
BE1-1051_F
Curve F(for both SW3-3 open and closed ) fixed time
T= 1*D+0.028
Created 2003-04-01
BE1-1051_G
Curve G long time inverse (I^2t)
Drawing 99-1622
T=12.1212*D/(M-1)+0.028
Created 2003-04-01
BE1-1051_I1
Curve I1 (SW3-3 open) I, Inverse time
Drawing 99-1373
T=8.9341*D/(M^20938-1)+0.17966D+0.028
Created 2003-04-01
BE1-1051_I2
Curve I2 (SW3-3 closed) Inverse time
Drawing 99-1597

T=0.2747D/(M^0.4375-1)+0.10426*D+0.028
Created 2003-04-01
BE1-1051_L1
Curve L1 L1( SW3-3 open ), Long inverse
Drawing 99-1370
T=5.6143*D/(M-1)+2.18592*D+0.028
Created 2003-04-01
BE1-1051_L2
Curve L2 L2( SW3-3 closed ), Long inverse
Drawing 99-1594
T=2.3955*D/(M^0.3125-1)+0.028
Created 2003-04-01
BE1-1051_M
Curve M (for both SW3-3 open and closed ) Moderately inverse
Drawing 99-1372
0.3022*D/(M^0.5-1)+0.1284*D+0.028
Created 2003-04-01
BE1-1051_S1
Basler Electric BE1-1051 inverse time-overcurrent relay. 51P, 51Q, 51N.
Curve S1 S( SW3-3 open ), Short inverse
Drawing 99-99-1369
T=0.2663*D/(M^1.2969-1)+0.03393*D+0.028
Created on 2003-04-01
BE1-1051_S2
Curve S2 S2( SW3-3 closed ), Short inverse
Drawing 99-1595
0.0286*D/(M^0.9844-1)+0.0208*D+0.028
BE1-1051_V1
Curve V1 (SW3-3 open) V, Very Inverse
Drawing 99-1374
5.4678*D/(M^2.0469-1)+0.10814*D+0.028
Created 2003-04-01
BE1-1051_V2
Curve V2 (SW3-3 closed) V2, Very Inverse
Drawing 99-1596
T=4.4309*D/(M^1.9531-1)+0.0901*D+0.028
Created 2003-04-01
BE1-50/51B_B
Basler BE1-50/51B Time Overcurrent Relay.
Curve Type B: BS142 Very Inverse.
T = 1.4636*D/(M**1.0469 -1) +0.028
Created 3/1/95.
BE1-50/51B_C
Basler BE1-50/51C Time Overcurrent Relay.
Curve Type C: BS142 Extremely Inverse.
T = 8.2506*D/(M**2.0469 -1) +0.028
Created 3/1/95.
BE1-50/51B_D
Curve Type D: Definite Time.
T = 0.4797*D/(M**1.5625 -1) +0.21359*D +0.028
Created 3/1/95.
BE1-50/51B_E
Curve Type E: Extremely Inverse.
T = 7.7624*D/(M**2.0938 -1) +0.02758*D +0.028
Created 3/1/95.
BE1-50/51B_F
Curve Type F: Fixed Time.
T = D

Created 3/1/95.
BE1-50/51B_I
Curve Type I: Inverse.
T = 8.9341*D/(M**2.0938 -1) +0.17966*D +0.028
Created 3/1/95.
BE1-50/51B_L
Curve Type L: Long Inverse.
T = 5.6143*D/(M -1) +2.18592*D +0.028
Created 3/1/95.
BE1-50/51B_M
Curve Type M: Moderately Inverse.
T = 0.3022*D/(M**0.5 -1) +0.1284*D +0.028
Created 3/1/95.
BE1-50/51B_S
Curve Type S: Short Inverse.
T = 0.2663*D/(M**1.2969 -1) +0.03393*D +0.028
Created 3/1/95.
BE1-50/51B_V
Curve Type V: Very Inverse.
T = 5.4678*D/(M**2.0469 -1) +0.10814*D +0.028
Created 3/1/95.
BE1-50/51E1
Basler inverse time over current relays
Curve E1: Extremly inverse
T = 7.7624*D/(M^2.0938-1) + .02758*D + .028
03/15/2001
BE1-50/51E2
Basler inverse time over current relays
Curve E2: Extremly inverse
T = 4.9883*D/(M^2.0496-1) + .0129*D + .028
03/15/2001
BE1-51_B1
Basler BE1-51 Timing Type B1 Short Inverse. Created 2/92.
BE1-51_B1E
Basler BE1-51 Timing Type B1 Extented: Short Inverse. Create 2/92.
BE1-51_B2
Basler BE1-51 Timing Type B2. Long Inverse. Create 2/92.
BE1-51_B2E
Basler BE1-51 Timing Type B2 Extended: Long Inverse. Create 2/92.
BE1-51_B3
Basler BE1-51 Timing Type B3 Definite Time. Created 2/92.
BE1-51_B3E
Basler BE1-51 Timing Type B3 Extended: Definite Time. Create 2/92.
BE1-51_B4
Basler BE1-15 Timing Type B4: Moderately Inverse. Created 2/92.
BE1-51_B4E
Basler BE1-51 Timing Type B4 Extended: Moderately Inverse. Create 2/92
.
BE1-51_B5
Basler BE1-51 Timing Type B5: Inverse. Create 2/92.
BE1-51_B5E
Basler BE1-51 Timing Type B5 Extended: Inverse. Create 2/92.
BE1-51_B6
Basler BE1-51 Timing Type B6: Very Inverse. Create 2/92.
BE1-51_B6E
BE1-51 Timing Type B6 Extended: Very Inverse. Created 2/92.
BE1-51_B7
Basler BE1-51 Timing Type B7: Extremely Inverse. Create 2/92.
BE1-51_B7E
Basler BE1-51 Timing Type B7 Extended: Extremely Inverse. Create 2/92.

BE1-51_B8
Basler BE1-51, BE1-51/27C, BE1-51/27R Time Overcurrent Relay. Timing Ty
pe: B8
Switch Position: 0
DWG No: 99-0926 Rev A
Created 12/3/93
BE1-51_C1
Bastler BE1-51, BE1-51/27C, BE1-51/27R Time Overcurrent Relays.
Timing Type: C1
Switch Position: 8
Created 12/3/93
BE1-51_C2
Timing Type: C2
Switch Position: 9
Created 12/3/93
BE1-51_C3
Timing Type: C3
Switch Position: A
Created 12/3/93
BE1-51_C4
Timing Type: C4
Switch Position: B
Created 12/3/93
BE1-51_C5
Timing Type: C5
Switch Position: C
Created 12/3/93
BE1-51_C6
Timing Type: C6
Switch Oosition: D
DWG No: 99-0961
Created 12/3/93
BE1-51_C7
Timing Type: C7
Switch Position: E
Created 12/3/93
BE1-51_C8
Timing Type: C8
Switch Position: F
Created 12/3/93
BE1-51_E7
Basler BE1-51, BE1-51/27C, BE1-51/27R. Timing Type E7: BS 142 Extremely
Inverse. Drawing No.99-1097. Created 11/14/95.
BE1-51A_W1
Basler BE1-51A Timing Option W1: Short Inverse
BE1-51A_W2
Basler BE1-51 Timing Option W2: Long Inverse. Created 2/92.
BE1-51A_W3
Basler BE1-51A Timing Option W3: Definite. Create 2/92.
BE1-51A_W4
Basler BE1-51 Timing Option W4: Moderately Inverse. Created 2/92.
BE1-51A_W5
Basler BE1-51A Timing Option W5: Inverse. Created 2/92.

BE1-51A_W6
Basler BE1-51A Timing Option W6: Very Inverse. Create 2/92.
BE1-51A_W7
Basler BE1-51A Time Overcurrent Relay.
Timing Option W7: Extremely Inverse.
Created 2/19/93.
BE1-A
Basler Electric BE1-851, -951, -1051, -CDS, -IPS, -GPS inverse time-overcurrent
relay.
Curve A Standard inverse
Drawing 99-1621
T=0.01414*D/(M-1) + 0.028
Created 09/02/2003
BE1-B
relay. 51P, 51Q, 51N
Curve B very inverse (I^2t)
Drawing 99-1376
T=1.4636*D/(M^1.0469-1) + 0.028
Created 09/02/2003
BE1-C
Basler Electric BE1-851, -951, -1051, -CDS, -IPS, -GPS inverse-overcurr
ent relay. 51P, 51Q, 51N
Curve C extremely inverse (I^2t)
Drawing 99-1377
T=8.2506*D/(M^2.0469-1)+0.028
Created 09/02/2003
BE1-D
Curve D, Definite time
Drawing 99-1371
T=0.4797*D/(M^1.5625-1)+0.21359*D+0.028
Created 09/02/2003
BE1-E1
Curve E1 Extremely Inverse
Drawing 99-1375
T=7.7624*D/(M^2.0938-1)+0.02758*D+0.028
Created 2003-04-01
BE1-E2
Curve E2 E2,Extremely Inverse
Drawing 99-1598
T=4.9883*D/(M^2.0469-1)+0.0129*D+0.028
Created 09/02/2003
BE1-F
Curve 46 Negative sequence overcurrent
T=0.028
Created 2003-04-01
BE1-G
Curve G long time inverse (I^2t)
Drawing 99-1622
T=12.1212*D/(M-1)+0.028
Created 09/02/2003
BE1-I1
Curve I1 I, Inverse time
Drawing 99-1373
T=8.9341*D/(M^20938-1)+0.17966D+0.028
Created 09/02/2003

BE1-I2
Curve I2 Inverse time
Drawing 99-1597
T=0.2747D/(M^0.4375-1)+0.10426*D+0.028
Created 2002-04-02
BE1-L1
Curve L1 L1, Long inverse
Drawing 99-1370
T=5.6143*D/(M-1)+2.18592*D+0.028
Created 09/02/2003
BE1-L2
Curve L2, Long inverse
Drawing 99-1594
T=2.3955*D/(M^0.3125-1)+0.028
Created 09/02/2003
BE1-M
Curve M Moderately inverse
Drawing 99-1372
0.3022*D/(M^0.5-1)+0.1284*D+0.028
Created 09/02/2003
BE1-S1
Curve S1 S, Short inverse
Drawing 99-99-1369
T=0.2663*D/(M^1.2969-1)+0.03393*D+0.028
Created on 09/02/2003
BE1-S2
Curve S2 S2, Short inverse
Drawing 99-1595
0.0286*D/(M^0.9844-1)+0.0208*D+0.028
BE1-V1
Curve V1 V, Very Inverse
Drawing 99-1374
5.4678*D/(M^2.0469-1)+0.10814*D+0.028
Created 09/02/2003
BE1-V2
Curve V2 V2, Very Inverse
Drawing 99-1596
T=4.4309*D/(M^1.9531-1)+0.0901*D+0.028
Created 09/02/2003
BE1_1051_L1
Curve L1 L1, Long inverse

BECKWITH.RLY
This file contains Beckwith relay curves.
M-3420-D
Instruction book M-3420, Definite time
Created 6/22/2001
M-3420-EI
Instruction book M-3420, Extremly Inverse.
Created 6/22/2001
M-3420-I
Instruction book M-3420, Inverse.
Created 6/22/2001
M-3420-VI
Instruction book M-3420, Very Inverse.
Created 6/22/2001

BUSSMANN.RLY
This file contains Bussmann fuse curves.
DLS-R-0.1
BUSSMANN DIVISION, COOPER INDUSTRIES. DLS-R(600V)
DUAL ELEMENT-TIME DELAY CONSTRUCTION GRADE FUSES. CLASS RK5 - 600V
Curve 0.1A.
Ref. SB99006.
Created 4/03/09.
DLS-R-0.2
Curve 0.2A.
Ref. SB99006.
Created 4/03/09.
DLS-R-0.3
Curve 0.3A.
Ref. SB99006.
Created 4/03/09.
DLS-R-0.4
Curve 0.4A.
Ref. SB99006.
Created 4/03/09.
DLS-R-0.5
Curve 0.5A.
Ref. SB99006.
Created 4/03/09.
DLS-R-0.6
Curve 0.6A.
Ref. SB99006.
Created 4/03/09.
DLS-R-0.8
Curve 0.8A.
Ref. SB99006.
Created 4/03/09.
DLS-R-001
Curve 1A.
Ref. SB99006.
Created 4/03/09.
DLS-R-001.25
Curve 1.25A.
Ref. SB99006.
Created 4/03/09.
DLS-R-001.6
Curve 1.6A.
Ref. SB99006.
Created 4/03/09.
DLS-R-002

Curve 2A.
Ref. SB99006.
Created 4/03/09.
DLS-R-002.5
Curve 2.5A.
Ref. SB99006.
Created 4/03/09.
DLS-R-003.2
Curve 3.2A.
Ref. SB99006.
Created 4/03/09.
DLS-R-004
Curve 4A.
Ref. SB99006.
Created 4/03/09.
DLS-R-005
Curve 5A.
Ref. SB99006.
Created 4/03/09.
DLS-R-006.25
Curve 6.25A.
Ref. SB99006.
Created 4/03/09.
DLS-R-008
Curve 8A.
Ref. SB99006.
Created 4/03/09.
DLS-R-010
Curve 10A.
Ref. SB99006.
Created 4/03/09.
DLS-R-012
Curve 12A.
Ref. SB99006.
Created 4/03/09.
DLS-R-015
Curve 15A.
Ref. SB99006.
Created 4/03/09.
DLS-R-030
Curve 30A.
Ref. SB99006.
Created 4/03/09.
DLS-R-060
Curve 60A.

Ref. SB99006.
Created 4/03/09.
DLS-R-100
Curve 100A.
Ref. SB99006.
Created 4/03/09.
DLS-R-200
Curve 200A.
Ref. SB99006.
Created 4/03/09.
DLS-R-400
Curve 400A.
Ref. SB99006.
Created 4/03/09.
DLS-R-600
Curve 600A.
Ref. SB99006.
Created 4/03/09.
FRN-R-007
Cooper FRN-R FUSETRON (250V) Fuses.
7A. Reference No. 235(236).Created 6/5/96
FRN-R-008
FRN-R-010
FRN-R-012
FRN-R-015
FRN-R-030
FRN-R-060
FRN-R-100
FRN-R-200
FRN-R-400
FRN-R-600
FRS-R-015
Cooper FRS-R FUSETRON Fuses (600V). 15A. Reference No. 233(234).
Created 6/3/96
FRS-R-030
Created 6/3/96

FRS-R-060
Created 6/3/96
FRS-R-100
Created 6/3/96
FRS-R-200
Created 6/3/96
FRS-R-400
Created 6/3/96.
FRS-R-600
Created 6/3/96.
JCX-0.5
McGraw-Edison Co. BUSSMANN MFG. DIVISION. BUSS HIGH VOLTAGE FUSES Type
JCX and JCY 1/2E
Ref. 171(172). Created 6/14/96.
JCX-001
JCX and JCY 1E
Ref. 171(172). Created 6/14/96.
JCX-002
JCX and JCY 2E
Ref. 171(172). Created 6/14/96.
JCX-003
JCX and JCY 3E
Ref. 171(172). Created 6/14/96.
JCX-005
JCX and JCY 5E
Ref. 171(172). Created 6/14/96.
JCX-007
JCX and JCY 7E
Ref. 171(172). Created 6/14/96.
JCX-010
JCX and JCY 10E
Ref. 171(172). Created 6/14/96.
JCX-015
JCX and JCY 15E
Ref. 171(172). Created 6/14/96.
JCX-020
JCX and JCY 20E
Ref. 171(172). Created 6/14/96.
JCX-025
JCX and JCY 25E
Ref. 171(172). Created 6/14/96.
JCX-030
JCX and JCY 30E
Ref. 171(172). Created 6/14/96.
JCX-040
JCX and JCY 40E
Ref. 171(172). Created 6/14/96.
JCX-050
JCX and JCY 50E

Ref. 171(172). Created 6/14/96.
JCX-065
JCX and JCY 65E
Ref. 171(172). Created 6/14/96.
JCX-080
JCX and JCY 80E
Ref. 171(172). Created 6/14/96.
JCX-100
JCX and JCY 100E
Ref. 171(172). Created 6/14/96.
JCX-125
JCX and JCY 125E
Ref. 171(172). Created 6/14/96.
JCX-150
JCX and JCY 150E
Ref. 171(172). Created 6/14/96.
JCX-200
JCX and JCY 200E
Ref. 171(172). Created 6/14/96.
JJN-001
Cooper JJN TRON Quick-Acting 1A. Reference No. 283(284).Created 6/5/96
JJN-003
JJN-006
JJN-010
JJN-015
JJN-030
JJN-060
JJN-100
Cooper JJN TRON Quick-Acting 100A. Reference No. 283(284).
Created 6/5/96
JJN-200
Created 6/5/96
JJN-400
Created 6/5/96
JJN-600
Created 6/5/96
JKS-030
Cooper JKS LIMITRON 30A. Reference No. 197-1(197-2).Created 6/14/96
JKS-060
JKS-100
JKS-200
JKS-400
JKS-600
KRP-C-0800
Cooper KRP-C_SP Low-Peak Yellow Fuses.

KRP-C-1200
KRP-C-1600
KTN-R-030
Cooper KTN-R and KTS-R LIMITRON Fuses.
KTN-R-060
KTN-R-100
KTN-R-200
KTN-R-400
KTN-R-600
LPJ-001
Cooper LPJ 1-12 AMP UL CLASS J TIME DELAY.
LPJ-002
LPJ-003
LPJ-005
LPJ-006
LPJ-008
LPJ-010
LPJ-012
LPJ-015
15A. Reference No. 363(364)-1.Created 6/3/96
LPJ-020
LPJ-030
LPJ-040
LPJ-050

LPJ-060
LPJ-070
LPJ-100
LPJ-150
LPJ-200
LPJ-300
LPJ-400
LPJ-600
LPN-RK-015
Cooper LPN-RK(RK1) LOW-PEAK Dual-Element Fuses(250V).
15A. Reference No. 305-1(305-2).Created 6/5/96
LPN-RK-020
LPN-RK-030
LPN-RK-060
LPN-RK-100
LPN-RK-200
LPN-RK-400
LPN-RK-600
LPS-RK-020
Bussmann Dual-Elements time-Delay fuse LPS-RK20
Rated voltage: 600V
Curve: 20 Amps
Created 08/11/2006
LPS-RK-025
Rated voltage: 600V
Curve: 25 Amps
Created 08/11/2006
LPS-RK-030
Rated voltage: 600V
Curve: 30 Amps
Created 08/11/2006
LPS-RK-035
Rated voltage: 600V

Curve: 35 Amps
Created 08/11/2006
LPS-RK-040
Rated voltage: 600V
Curve: 40 Amps
Created 08/11/2006
LPS-RK-045
Rated voltage: 600V
Curve: 45 Amps
Created 08/11/2006
LPS-RK-050
Rated voltage: 600V
Curve: 50 Amps
Created 08/11/2006
LPS-RK-060
Rated voltage: 600V
Curve: 60Amps
Created 08/11/2006
LPS-RK-070
Rated voltage: 600V
Curve: 70 Amps
Created 08/11/2006
LPS-RK-080
Rated voltage: 600V
Curve: 80 Amps
Created 08/11/2006
LPS-RK-090
Rated voltage: 600V
Curve: 90 Amps
Created 08/11/2006
LPS-RK-100
Rated voltage: 600V
Curve: 100 Amps
Created 08/11/2006
LPS-RK-200
Rated voltage: 600V
Curve: 200 Amps
Created 06/26/2007
LPS-RK-400
Rated voltage: 600V
Curve: 400 Amps
Created 06/26/2007
LPS-RK-600
Rated voltage: 600V
Curve: 600 Amps
Created 06/26/2007
NOS-015
BUSSMANN DIVISION, COOPER INDUSTRIES. NOS(600V) BUSS ONE-TIME FUSE.
15A. Ref. 152-1(152-2). Created 6/17/96.
NOS-020
20A. Ref. 152-1(152-2). Created 6/17/96.
NOS-030
30A. Ref. 152-1(152-2). Created 6/17/96.

NOS-035
35A. Ref. 152-1(152-2). Created 6/17/96.
NOS-060
60A. Ref. 152-1(152-2). Created 6/17/96.
NOS-100
100A. Ref. 152-1(152-2). Created 6/17/96.
NOS-200
200A. Ref. 152-1(152-2). Created 6/17/96.
NOS-400
400A. Ref. 152-1(152-2). Created 6/17/96.
NOS-600
600A. Ref. 152-1(152-2). Created 6/17/96.

CALOR_EMAG.RLY
This file contains Calor Emac fuse curves.
HHC-006
Calor Emag HRC High Voltage Fuses Type HHC. 6A. Ref. No. EDS 79-1.
Created 7/8/96.
HHC-010
Created 7/8/96.
HHC-016
Created 7/8/96.
HHC-020
Created 7/8/96.
HHC-025
Created 7/8/96.
HHC-030
Created 7/8/96.
HHC-040
Created 7/8/96.
HHC-063
Created 7/8/96.
HHC-080
Created 7/8/96.
HHC-100
Created 7/8/96.
HHC-125
Created 7/8/96.
HHC-160
Created 7/8/96.
HHC-200
Created 7/8/96.

CHANCE.RLY
This file contains A. B. Chance fuse curves.
CHANCE-H001
Chance Type H fuse 1 Amps. in cutouts.
CHANCE-H002
CHANCE-H003
CHANCE-H005
CHANCE-H008
CHANCE-H010
CHANCE-H015
CHANCE-H020
CHANCE-H025
Chance Type H 25 Amps. in cutouts.
CHANCE-H030
CHANCE-H040
CHANCE-H045
CHANCE-H050
CHANCE-H060
CHANCE-H075
CHANCE-H085
CHANCE-H095
CHANCE-H100
CHANCE-K001
Chance Type "K" (FAST) 1 amp fuse link in cutout.
Catalog #: M1K. Dwg. #: 30002, 30003. Created 12/15/97.
CHANCE-K002
CHANCE-K003
Catalog #: M3K. Dwg. #:30002, 30003. Created 121/15/97.
CHANCE-K006
CHANCE-K008
CHANCE-K010
CHANCE-K012

CHANCE-K015
CHANCE-K020
CHANCE-K025
CHANCE-K030
Catalog 3: M30K. Dwg. #: 30002, 30003. Created 12/16/97.
CHANCE-K040
CHANCE-K050
CHANCE-K065
CHANCE-K080
CHANCE-K100
CHANCE-K140
CHANCE-K200
CHANCE-MS003
Chance Type MS fuse 3 Amps. in cutouts.
CHANCE-MS005
CHANCE-MS007
CHANCE-MS010
CHANCE-MS015
CHANCE-MS020
CHANCE-MS025
CHANCE-MS030
CHANCE-MS040
CHANCE-MS050
CHANCE-MS065
CHANCE-MS080
CHANCE-MS100
CHANCE-MS125
Chance Type Ms fuse 125 Amps. in cutouts.
CHANCE-MS150

CHANCE-MS200
CHANCE-SF0.2
Chance Type SloFast fuse 0.2 Amps. in cutouts.
CHANCE-SF0.3
CHANCE-SF0.4
CHANCE-SF0.6
CHANCE-SF0.7
CHANCE-SF1.0
CHANCE-SF1.3
CHANCE-SF1.4
CHANCE-SF1.6
CHANCE-SF14
Chance Type SloFast fuse 14 Amps. in cutouts.
CHANCE-SF2.1
CHANCE-SF21
CHANCE-SF3.1
CHANCE-SF3.5
CHANCE-SF32
CHANCE-SF4.2
CHANCE-SF46
CHANCE-SF5.2
CHANCE-SF6.3
CHANCE-SF7.0
CHANCE-SF7.8
CHANCE-T001
Chance Type "T" (SLOW) 1 amp fuse link in cutout.
Catalog #: M1T. Dwg. #: 30005, 30006. Created 12/15/97.
CHANCE-T002
CHANCE-T003
CHANCE-T006
CHANCE-T008
CHANCE-T010

CHANCE-T012
CHANCE-T015
CHANCE-T020
CHANCE-T025
CHANCE-T030
CHANCE-T040
CHANCE-T050
CHANCE-T065
CHANCE-T080
CHANCE-T100
CHANCE-T140
CHANCE-T200
CHANCEcts005
Chance Type CTS fuse 5 Amps. in cutouts.
CHANCEcts008
CHANCEcts010
CHANCEcts015
CHANCEcts020
CHANCEcts025
CHANCEcts030
CHANCEcts040
CHANCEcts050
CHANCEcts060
CHANCEcts075
CHANCEcts100
CHANCEcts125
CHANCEcts150

CHANCEcts175
CHANCEcts200
Chance Type CTS fuse 200 Amps. in cutouts
CHANCEsf10.4
K-MATEclf12
Chance K-MATE CLF FUSE 8.3-15.5-22KV. K-MATE12. No. 18-7601-1(2).
Point model. Created 5/31/96.
K-MATEclf25
Chance K-MATE CLF FUSE 8.3-15.5-22KV. K-MATE25. NO. 18-7601-1(2).
K-MATEclf40
Chance K-MATE CLF FUSE 8.3-15.5-22kV. K-MATE40. No. 18-7601-1(2).
K-MATEclf80
Chance K-MATE CLF Fuse 8.3-15.5-22KV. K-MATE80. No. 18-7601-1(2).
K125
A.B. Chance Type "K" Fast. 125A.
K175
A.B. Chance Type "K" Fast. 175A.

COMBINED_TECH.RLY
This file contains Combined Tech. Inc. SX-Limiter and Fuse curves.
EJO-065E
Combined Tech Inc. 8.3, 15.5, 23.0kV EJO fuse. Size C,D, DD. TCC-319-M.
65A. Created 1/19/96.
EJO-080E
80A. Created 1/23/96.
EJO-100E
100A. Created 1/23/96.
EJO-150E
150A. Created 1/23/96.
SX-020
Combined Tech Inc. 8.3 & 15.5kV SX-Limiter. 20A. TCC-100.
Created 5/30/95.
SX-030
Created 5/30/95.
SX-050
Created 5/30/95.
SX-080
Created 5/30/95.
SX-100
Created 5/30/95.
SX-150
Created 5/30/95.
SX-200
Created 5/30/95.

COOPER.RLY
This file contains Cooper and McGraw relay, recloser and fault interrupter curves.
240-91-10910
Cooper 8.3,15.5,23 kV (10 amp) X-Limiter Full Range Fuse.
Ref. No.: TCC-301-M, TCC-301-C. Created 3/23/98.
240-91-10912
240-91-10918
240-91-10920
240-91-10925
240-91-10930
240-91-10940
240-91-10950
240-91-10965
240-91-10980
240-91-125
Cooper ELSP Backup Type oil immersible current limiting fuse.
8.3kV,125A. Version 2003
Ref. 240-91-71.
Created 8/03/2004.
240-91-150
Ref. 240-91-72.
Created 8/03/2004.
240-91-15003
M-E fuse links: TYPE S.
3S, Ref. R240-91-15. Created 8/23/96.
240-91-15005
5S, Ref. R240-91-15. Created 8/23/96.
240-91-15007
7S, Ref. R240-91-15. Created 8/23/96.
240-91-15010
10S, Ref. R240-91-15. Created 8/23/96.
240-91-15015
15S, Ref. R240-91-15. Created 8/23/96.
240-91-15020
20S, Ref. R240-91-15. Created 8/23/96.
240-91-15025
25S, Ref. R240-91-15. Created 8/23/96.

240-91-15030
30S, Ref. R240-91-15. Created 8/23/96.
240-91-15040
40S, Ref. R240-91-15. Created 8/23/96.
240-91-15050
50S, Ref. R240-91-15. Created 8/23/96.
240-91-15065
65S, Ref. R240-91-15. Created 8/23/96.
240-91-15080
80S, Ref. R240-91-15. Created 8/23/96.
240-91-15100
100S, Ref. R240-91-15. Created 8/23/96.
240-91-15125
125S, Ref. R240-91-15. Created 8/23/96.
240-91-15150
150S, Ref. R240-91-15. Created 8/23/96.
240-91-15200
200S, Ref. R240-91-15. Created 8/23/96.
240-91-19065
Cooper ELG power fuse 23.0/25/8kV
Curve: 65A
TCC: R240-91-91
Updated 04/01/2010
240-91-2_001
M-E fuse links: EEI-NEMA TYPE T-TIN.
1T, Ref. R240-91-2. Created 8/21/96.
240-91-2_002
2T, Ref. R240-91-2. Created 8/21/96.
240-91-2_003
3T, Ref. R240-91-2. Created 8/21/96.
240-91-2_005
5T, Ref. R240-91-2. Created 8/21/96.
240-91-2_006
6T, Ref. R240-91-2. Created 8/21/96.
240-91-2_008
8T, Ref. R240-91-2. Created 8/21/96.
240-91-2_010
10T, Ref. R240-91-2. Created 8/21/96.
240-91-2_012
12T, Ref. R240-91-2. Created 8/21/96.
240-91-2_015
15T, Ref. R240-91-2. Created 8/21/96.
240-91-2_020
20T, Ref. R240-91-2. Created 8/21/96.
240-91-2_025
25T, Ref. R240-91-2. Created 8/21/96.

240-91-2_030
30T, Ref. R240-91-2. Created 8/21/96.
240-91-2_040
40T, Ref. R240-91-2. Created 8/21/96.
240-91-2_050
50T, Ref. R240-91-2. Created 8/21/96.
240-91-2_065
65T, Ref. R240-91-2. Created 8/21/96.
240-91-2_080
80T, Ref. R240-91-2. Created 8/21/96.
240-91-2_100
100T, Ref. R240-91-2. Created 8/21/96.
240-91-2_140
140T, Ref. R240-91-2. Created 8/21/96.
240-91-2_200
200T, Ref. R240-91-2. Created 8/21/96.
240-91-37_10
Cooper 8.3 kV (10 amp) NXC (Capacitor) Fuse.
DWG. No. 4239247B00 (Page 1 & 2). Created 3/20/98.
240-91-37_18
240-91-37_25
240-91-37_30
240-91-37_40
240-91-37_45
240-91-37_65
240-91-39-12
Copper 23 kV NXC ( Capacitor) fuse.
Reference R240-91-39. 12A.
Created 8/23/2005
240-91-39-18
Created 8/23/2005
240-91-39-25
Created 8/23/2005
240-91-3_001
M-E fuse links: HIGH SURGE TYPE H.
1H, Ref. R240-91-3. Created 8/22/96.
240-91-3_002
2H, Ref. R240-91-3. Created 8/22/96.
240-91-3_003

3H, Ref. R240-91-3. Created 8/22/96.
240-91-3_005
5H, Ref. R240-91-3. Created 8/22/96.
240-91-3_008
M-E fuse links: HIGH SURG TYPE H.
8H, Ref. R240-91-3. Created 8/22/96.
240-91-41-12
Cooper 8.3,15.5, 23.0 kV companion II Fuse. 12K curve
Ref. No.: R240-91-41.
Created 01/14/2005.
240-91-41-25
Cooper 8.3,15.5, 23.0 kV companion II Fuse. 25K curve
Ref. No.: R240-91-41.
Created 01/14/2005.
240-91-41-40
Cooper 8.3,15.5, 23.0 kV companion II Fuse.40K curve
Ref. No.: R240-91-41.
Created 01/14/2005.
240-91-42_06
Cooper 8.3 kV (6 amp) ELF Dropout Fuse.
DWG No.: 4239106B00 (Page 1 & 2). Created 3/24/98.
240-91-42_08
DWG. No.: 4239106B00 (Page 1 & 2). Created 3/24/98.
240-91-42_12
240-91-42_18
240-91-42_20
240-91-42_25
240-91-42_30
240-91-42_40
240-91-42_50
Cooper 8.3 kV (2-25 amp in parallel) ELF Dropout Fuse.
240-91-42_65
Cooper 8.3 kV (2-32.5 amp in parallel) ELF Dropout Fuse.
240-91-42_80
Cooper 8.3 kV (2-40 amp in parallel) ELF Dropout Fuse.
240-91-43_12
DWG. No. 4239213B00, 4239311B00. Created 10/3/97.
240-91-43_18
DWG. NO. 4239211B00, 4239213B00. Created 10/3/97.
240-91-43_20
DWG. No. 4239213B00, 4239211B00. Created 10/3/97.
240-91-43_25
DWG. NO. 4239211B00, 4239213B00. Created 10/3/97.

240-91-43_30
DWG. NO. 4239213B00, 4239211B00. Created 10/3/97.
240-91-43_40
Parallel fuses, 2-20 amp.
DWG. NO. 4239213B00, 4239211B00. Created 10/3/97.
240-91-43_50
Parallel fuses, 2-25 amp.
DWG. NO. 4239213B00, 4239311B00. Created 10/3/97.
240-91-47_06
Cooper Power ELS-LR 23kV Fuse
Curve 6 Amps,
Ref. 240-91-47
Created 02/01/2006
240-91-47_08
Curve 8 Amps,
Ref. 240-91-47
Created 02/01/2006
240-91-47_12
Curve 12 Amps,
Ref. 240-91-47
Created 02/01/2006
240-91-47_18
Curve 18 Amps,
Ref. 240-91-47
Created 02/01/2006
240-91-47_20
Curve 20 Amps,
Ref. 240-91-47
Created 02/01/2006
240-91-4_006
M-E fuse links: EEI-NEMA TYPE K-SILVER.
6K, Ref. R240-91-4. Created 8/22/96.
240-91-4_008
8K, Ref. R240-91-4. Created 8/22/96.
240-91-4_010
10K, Ref. R240-91-4. Created 8/22/96.
240-91-4_012
12K, Ref. R240-91-4. Created 8/22/96.
240-91-4_015
15K, Ref. R240-91-4. Created 8/22/96.
240-91-4_020
20K, Ref. R240-91-4. Created 8/22/96.
240-91-4_025
25K, Ref. R240-91-4. Created 8/22/96.
240-91-4_030
30K, Ref. R240-91-4. Created 8/22/96.
240-91-4_040
40K, Ref. R240-91-4. Created 8/22/96.
240-91-4_050
50K, Ref. R240-91-4. Created 8/22/96.

240-91-4_065
65K, Ref. R240-91-4. Created 8/22/96.
240-91-4_080
80K, Ref. R240-91-4. Created 8/22/96.
240-91-4_100
100K, Ref. R240-91-4. Created 8/22/96.
240-91-53065
Cooper high amp transformer overload link (65A)
TCC-R240-91-53
240-91-53100
TCC-R240-91-53
240-91-53125
TCC-R240-91-53
240-91-56-01
Cooper Isolation link minimum melt time.
Reference R240-91-56.
Catalog No. 3637803B and 3001861A. Curve # 1.
Created 5/14/2007.
240-91-56-02
Created 5/14/2007.
240-91-56-03
Created 5/14/2007.
240-91-56-05
Created 5/14/2007.
240-91-56-06
Created 5/14/2007.
240-91-56-07
Created 5/14/2007.
240-91-56-08
Created 5/14/2007.
240-91-56-09
Catalog No. 3637803B and 3001861A. Curve # 9
Created 5/14/2007.
240-91-56-10
Created 5/14/2007.

240-91-5_006
M-E fuse links: EEI-NEMA TYPE EK-TIN.
6EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_008
8EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_010
10EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_012
12EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_015
15EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_020
20EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_025
25EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_030
30EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_040
40EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_050
50EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_065
65EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_080
80EK, Ref. R240-91-5. Created 8/22/96.
240-91-5_100
100EK, Ref. R240-91-5. Created 8/22/96.
240-91-6_006
M-E fuse links: EEI-NEMA TYPE ET-TIN.
6ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_008
8ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_010
10ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_012
12ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_015
15ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_020
20ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_025
25ET, Ref. R240-91-6. Created 8/22/96.
240-91-6_030
30ET, Ref. R240-91-6. Created 8/23/96.
240-91-6_040

40ET, Ref. R240-91-6. Created 8/23/96.
240-91-6_050
50ET, Ref. R240-91-6. Created 8/23/96.
240-91-6_065
65ET, Ref. R240-91-6. Created 8/23/96.
240-91-6_080
80ET, Ref. R240-91-6. Created 8/23/96.
240-91-6_100
100ET, Ref. R240-91-6. Created 8/23/96.
240-91-70100
Cooper (8.3 & 15.5 kv only) ELX Full Range Fuse (100 amp, 2-50 amp
fuses in parallel). Reference R240-91-70. Created 11/18/97.
240-91-70_03
Cooper (8.3,15.5 & 23 kV) ELX Full Range Fuse (3 amp).
Reference R240-91-70. Created 11/17/97.
240-91-70_06
240-91-70_08
240-91-70_12
240-91-70_18
240-91-70_20
240-91-70_25
240-91-70_30
240-91-70_40
240-91-70_50
Copper (23 kV only) ELX Full Range Fuse (50 amp, 2-25 amp
240-91-70_60
Cooper (8.3,15.5 & 23 kV) ELX Full Range Fuse (60 amp, 2-30 amp
240-91-70_80
Cooper (8.3,15.5 & 23 kV) ELX Full Range Fuse (80 amp, 2-40 amp
fuses in parallel). Reference R240-91-70. Crreated 11/18/97.
240-91-71-40
Ref. 240-91-71.
Created 8/03/2004.
240-91-71100
Ref. 240-91-71.
Created 8/03/2004.
240-91-71150
Ref. 240-91-71.

Created 8/03/2004.
240-91-71165
Ref. 240-91-71.
Created 8/03/2004.
240-91-71250
Ref. 240-91-71.
Created 8/03/2004.
240-91-7130
Ref. 240-91-71.
Created 8/03/2004.
240-91-71300
Ref. 240-91-71.
Created 8/03/2004.
240-91-71330
Ref. 240-91-71.
Created 8/03/2004.
240-91-7150
Ref. 240-91-71.
Created 8/03/2004.
240-91-7165
Ref. 240-91-71.
Created 8/03/2004.
240-91-7180
Ref. 240-91-71.
Created 8/03/2004.
240-91-72100
15kV,100A. Version 2003
Ref. 240-91-72.
Created 8/03/2004.
240-91-72125
Ref. 240-91-72.
Created 8/03/2004.
240-91-72250
Ref. 240-91-72.
Created 8/03/2004.
240-91-7230
Ref. 240-91-72.
Created 8/03/2004.
240-91-72300
Ref. 240-91-72.
Created 8/03/2004.

240-91-7240
Ref. 240-91-72.
Created 8/03/2004.
240-91-7250
Ref. 240-91-72.
Created 8/03/2004.
240-91-7265
Ref. 240-91-72.
Created 8/03/2004.
240-91-7280
Ref. 240-91-72.
Created 8/03/2004.
240-91-73100
Ref. 240-91-73.
Created 8/03/2004.
240-91-73125
Ref. 240-91-73.
Created 8/03/2004.
240-91-73150
Ref. 240-91-73.
Created 8/03/2004.
240-91-73165
Ref. 240-91-73.
Created 8/03/2004.
240-91-73250
Ref. 240-91-73.
Created 8/03/2004.
240-91-7330
Ref. 240-91-73.
Created 8/03/2004.
240-91-73300
Ref. 240-91-73.
Created 8/03/2004.
240-91-73330
Ref. 240-91-73.
Created 8/03/2004.
240-91-7340
Ref. 240-91-73.
Created 8/03/2004.
240-91-7350

Ref. 240-91-73.
Created 8/03/2004.
240-91-7365
Ref. 240-91-73.
Updated 4/1/2010
240-91-7380
Ref. 240-91-73.
Created 8/03/2004.
240-91-7_001
M-E fuse links: HIGH SURGE TYPE EH.
1EH, Ref. R240-91-7. Created 8/23/96.
240-91-7_002
2EH, Ref. R240-91-7. Created 8/23/96.
240-91-7_003
3EH, Ref. R240-91-7. Created 8/23/96.
240-91-7_005
5EH, Ref. R240-91-7. Created 8/23/96.
240-91-85004
Cooper Power System 8.3 & 15.5kV ELSG full range oil immersible fuse 2.
0 DIA.
Curve 4.
Refferencedata: R240-91-85
Created 2005.04.25
240-91-85008
0 DIA.
Curve 8.
Created 2005.04.25
240-91-85012
0 DIA.
Curve 12.
Created 2005.04.25
240-91-85015
0 DIA.
Curve 15.
Created 2005.04.25
240-91-85020
0 DIA.
Curve 20.
Created 2005.04.25
240-91-85025
0 DIA.
Curve 25.
Created 2005.04.25
240-91-85030
0 DIA.
Curve 30.
Created 2005.04.25

240-91-85040
0 DIA.
Curve 40.
Created 2005.04.25
240-91-85050
0 DIA.
Curve 50.
Created 2005.04.25
240-91-85060
0 DIA.
Curve 60.
Created 2005.04.25
240-91-85065
0 DIA.
Curve 65.
Created 2005.04.25
240-91-85080
0 DIA.
Curve 80.
Created 2005.04.25
240-91-85100
0 DIA.
Curve 100.
Created 2005.04.25
240-91-85120
0 DIA.
Curve 120.
Created 2005.04.25
240-91-85150
0 DIA.
Curve 150.
Created 2005.04.25
240-91-86065
0 DIA.
Curve 65.
Created 2005.04.25
240-91-86080
0 DIA.
Curve 80.
Created 2005.04.25
240-91-86100
0 DIA.
Curve 100.
Created 2005.04.25
240-91-86125

0 DIA.
Curve 125.
Created 2005.04.25
240-91-87050
Cooper Power System 23kV ELSG under-oil power fuse.
Curve 65.
Created 2005.04.25
240-91-87080
Curve 80.
Refference data: R240-91-87
Created 2005.04.25
240-91-87100
Curve 100.
Created 2005.04.25
240-91-87125
Curve 125.
Created 2005.04.25
240-91-88050
Cooper Power System 8.3, 15.5 & 23kV ELSG full range under-oil current
limit fuse
Curve 50.
Created 2005.04.25
240-91-88090
Cooper Power System 8.3, 15.5 & 23kV ELSG full range under-oil current
limit fuse
Curve 90.
Created 2005.04.25
240-91-88135
Cooper Power System 23kV ELSG full range under-oil current limit fuse
Curve 135.
Created 2005.04.25
240-91-8_101
M-E fuse links: TYPE C-TIN.
101C, Ref. R240-91-8. Created 8/23/96.
240-91-8_102
M-E fuse links: TYPE C-TIN.
102C, Ref. R240-91-8. Created 8/23/96.
240-91-91040
Curve: 40A
TCC: R240-91-91
Updated 04/01/2010
240-91-91050
Curve: 50A
TCC: R240-91-91
Updated 04/01/2010
240-91-91080
Curve: 80A
TCC: R240-91-91
Updated 04/01/2010
240-91-91100
Curve: 100A
TCC: R240-91-91
Updated 04/01/2010

240-91-91120
Curve: 120A
TCC: R240-91-91
Updated 04/01/2010
240-91109100
240-91109125
Cooper 8.3,15.5 kV (125 amp) X-Limiter Full Range Fuse.
240-91109140
Cooper 8.3 kV (140 amp) X-Limiter Full Range Fuse.
2409111-050
Cooper 8.3,15.5,23 kV (50 amp) X-Limiter "DW" Fuse.
24091111-100
Cooper 8.3,15.5,23 kV (100 amp) X-Limiter "DW" Fuse.
24091113-050
Cooper 8.3,15.5 kV K-Limiter backup Fuse. K50 curve
Ref. No.: R240-91-113.
Created 01/14/2005.
24091113-065
Ref. No.: R240-91-113.
Created 01/14/2005.
24091113-080
Ref. No.: R240-91-113.
Created 01/14/2005.
24091113-100
Ref. No.: R240-91-113.
Created 01/14/2005.
24091113-140
Ref. No.: R240-91-113.
Created 01/14/2005.
24091155-005
Cooper CMU612XXXX, CMU613XXXX, CMU614XXXX fuses
Curve: 005 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-007
Curve: 007 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-010
Curve: 010 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-013
Curve: 013 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-015
Curve: 015 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010

24091155-020
Curve: 020 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-025
Curve: 025 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-030
Curve: 030 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-040
Curve: 040 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-050
Curve: 050 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-065
Curve: 065 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-080
Curve: 080 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-100
Curve: 100 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-125
Curve: 125 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-150
Curve: 150 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-175
Curve: 175 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
24091155-200
Curve: 200 E
Reference: R240-91-152, R240-91-155
Updated 4/1/2010
285-91-3-EFC
Cooper Padmounted Switchgear Tri-Phase Control.
TCC-643
R285-91-3, Clearing curve FF
Created 11/06/2006
285-91-3-EFR

TCC-643
R285-91-3, Response curve EF
Created 11/06/2006
285-91-3-FC
TCC-649
R285-91-3, Clearing curve F
Created 11/06/2006
285-91-3-FR
TCC-649
R285-91-3, Response curve F
Created 11/06/2006
285-91-3-HC
TCC-650
R285-91-3, Clearing curve H
Created 11/06/2006
285-91-3-HR
TCC-650
R285-91-3, Response curve H
Created 11/06/2006
285-91-3-KFC
TCC-648
R285-91-3, Clearing curve KF
Created 11/06/2006
285-91-3-KFR
TCC-648
R285-91-3, Response curve KF
Created 11/06/2006
285-91-3-TFC
TCC-647
R285-91-3, Clearing curve TF
Created 11/06/2006
285-91-3-TFR
TCC-647
R285-91-3, Response curve TF
Created 11/06/2006
BAY-353C-006
Cooper Bay-O-Net 353C fuse link, 6A. Fuse Link Nos. C4.
Ref. 240-91-50. Created 5/22/96.
BAY-353C-010
Ref. 240-91-50. Created 5/22/96.
BAY-353C-015
Ref. 240-91-50. Created 5/22/96.
BAY-353C-025
Ref. 240-91-50. Created 5/22/96.
BAY-353C-040
Ref. 240-91-50. Created 5/22/96.
BAY-353C-065
Ref. 240-91-50. Created 5/22/96.
BAY-353C-100
Ref. 240-91-50. Created 5/22/96.
BAY-353C-140
Ref. 240-91-50. Created 5/22/96.

Cooper-643
Cooper Pad-Mounted Switchgear Tri-Phase Control. TCC-643 and TCC-643
R. Reference R285-91-3.
Cooper-647
Cooper Fault Interrupter TCC-647R and 647. Type SEC-101-TF.
Cooper-648
Cooper Fault Interrupter TCC-648. Type SEC-101-KF.
Cooper-649
Cooper Fault Interrupter TCC-649. Type SEC-101-F.
Cooper-650
Cooper Fault Interrupter TCC-650. Type SEC-101-H.
Updated 4/2/2010
D-E-BAY05
Cooper Dual Element Bay-O-Net fuse link, 5A. Fuse Link Nos. C3.
Ref. 240-91-57. Created 6/5/95.
D-E-BAY06
Ref. 240-91-57. Created 6/5/95.
D-E-BAY08
Ref. 240-91-57. Created 6/5/95.
D-E-BAY12
Ref. 240-91-57. Created 6/5/95.
D-E-BAY15
Ref. 240-91-57. Created 6/5/95.
D-E-BAY25
Ref. 240-91-57. Created 6/5/95.
D-E-BAY40
Ref. 240-91-57. Created 6/5/95.
D-E-BAY50
Ref. 240-91-57. Created 6/5/95.
D-S-BAY003
Cooper Dual Sensing Bay-O-Net Primary fuse, 3A. Fuse Link Nos. C3.
Ref. 240-91-51. Catalog No. 4000358C. Created 5/30/95.
D-S-BAY008
D-S-BAY015
D-S-BAY025
D-S-BAY050
D-S-BAY065
D-S-BAY100
Ref. 240-91-51. Created 1/19/96.
D-S-BAY140
ELRP8.3-150
Cooper ELPR Full range outdoor fuse
8.3kV 150A.
Standards uses as basic data: ANSI C37.47-1981(A1992)
Created 06/21/2006

ELSP15-065
15.5kV, 65A. Ref. 240-91-64. Created 6/5/95.
ELSP15-080
15.5kV, 80A. Ref. 240-91-64. Created 6/5/95.
ELSP15-100
15.5kV, 100A. Ref. 240-91-64. Created 6/5/95.
ELSP15-130
15.5kV, 130A (Parallel 2-65). Ref. 240-91-64. Created 6/5/95.
ELSP15-150
15.5kV, 150A. Ref. 240-91-65. Created 6/5/95.
ELSP15-160
ELSP15-175
15.5kV, 175A. Ref. 240-91-65. Created 6/5/95.
ELSP15-200
ELSP15-300
ELSP15-350
ELSP23-065
23kV, 65A. Ref. 240-91-67. Created 1/12/00.
ELSP23-080
23kV, 80A. Ref. 240-91-67. Created 1/12/00.
ELSP23-125
23kV, 125A. Ref. 240-91-84. Created 1/12/00.
ELSP8.3-065
8.3kV, 65A. Ref. 240-91-61. Created 6/5/95.
ELSP8.3-080
8.3kV, 80A. Ref. 240-91-61. Created 6/5/95.
ELSP8.3-100
8.3kV, 100A. Ref. 240-91-61. Created 6/5/95.
ELSP8.3-130
ELSP8.3-150
8.3kV, 150A. Ref. 240-91-62. Created 6/5/95.
ELSP8.3-160
ELSP8.3-175
8.3kV, 175A. Ref. 240-91-62. Created 6/5/95.
ELSP8.3-200
8.3kV, 200A. Ref. 240-91-62. Created 6/5/95.
ELSP8.3-200*

ELSP8.3-300
ELSP8.3-350
ELSP8.3-400
K-TIN-001K
M-E fuse links: EEI-NEMA TYPE K-TIN.
1K, Ref. R240-91-1. Created 8/28/95.
K-TIN-002K
2K, Ref. R240-91-1. Created 8/28/95.
K-TIN-003K
3K, Ref. R240-91-1. Created 8/28/95.
K-TIN-005K
5K, Ref. R240-91-1. Created 8/28/95.
K-TIN-006K
6K, Ref. R240-91-1. Created 8/28/95.
K-TIN-008K
8K, Ref. R240-91-1. Created 8/28/95.
K-TIN-010K
10K, Ref. R240-91-1. Created 8/28/95.
K-TIN-012K
12K, Ref. R240-91-1. Created 8/28/95.
K-TIN-015K
15K, Ref. R240-91-1. Created 8/28/95.
K-TIN-020K
20K, Ref. R240-91-1. Created 8/28/95.
K-TIN-025K
25K, Ref. R240-91-1. Created 8/28/95.
K-TIN-030K
30K, Ref. R240-91-1. Created 8/28/95.
K-TIN-040K
40K, Ref. R240-91-1. Created 8/28/95.
K-TIN-050K
50K, Ref. R240-91-1. Created 8/28/95.
K-TIN-065K
65K, Ref. R240-91-1. Created 8/28/95.
K-TIN-080K
80K, Ref. R240-91-1. Created 8/28/95.
K-TIN-100K
100K, Ref. R240-91-1. Created 8/28/95.
K-TIN-140K
140K, Ref. R240-91-1. Created 8/28/95.

K-TIN-200K
200K, Ref. R240-91-1. Created 8/28/95.
KEARNEY 1
KEARNEY TYPE X 1A FUSE LINKS IN KEARNEY CUTOUTS
REF. NO. K-41000 A/B. CREATED 3/6/2001
KEARNEY 1.25
KEARNEY TYPE X 1.25A FUSE LINKS IN KEARNEY CUTOUTS
KEARNEY 1.5
KEARNEY 1/2
KEARNEY TYPE X 1/2A FUSE LINKS IN KEARNEY CUTOUTS
KEARNEY 1/3
KEARNEY TYPE X 1/3A FUSE LINK IN KEARNEY CUTOUTS
RATING 1/3 AMP
KEARNEY 10
KEARNEY 15
KEARNEY 2
KEARNEY 2.5
KEARNEY 2.75
KEARNEY 3.5
KEARNEY 3/4
KEARNEY 4
KEARNEY 5.5
KEARNEY 7
Kyle-102
Cooper FXB Kyle-102 Recloser
Created 2003/03/19
Kyle-133
Cooper FX Kyle-102 recloser
Created 2004/10/22
Kyle-ANSI-EI
Cooper Kyle Recloser
ANSI Extremely Inverse curve
T=D*(A/(M**p - 1) + B)
A=28.2, B=0.1217, p=2.0
Created 03/20/2006
Kyle-ANSI-MI
ANSI Moderate Inverse curve
T=D*(A/(M**p - 1) + B)
A=0.0515, B=0.114, p=0.02

Created 03/20/2006
Kyle-ANSI-VI
ANSI Very Inverse curve
T=D*(A/(M**p - 1) + B)
A=19.61, B=0.491, p=2.0
Created 03/20/2006
ME-215-A
McGraw-Edison recloser type L. Reference R280-91-3. TCC-215-A 25 A
Created 2005/07/21
ME-215-B
McGraw-Edison recloser type L. Reference R280-91-3. TCC-215-B. 25A.
ME-215-C
McGraw-Edison recloser type L. Reference R280-91-3. TCC-215-C. 25A.
ME-215-D
McGraw-Edison recloser type L. Reference R280-91-3. TCC-215-D. 25A.
ME-216-A
McGraw-Edison recloser type L. Reference R280-91-3. TCC-216-A. 35A.
ME-216-B
ME-216-C
ME-216-D
ME-217-A
ME-217-B
ME-217-C
ME-217-D
ME-218-A
ME-218-B
ME-218-C
ME-218-D
ME-219-A
ME-219-B
ME-219-C
ME-219-D
ME-220-A
ME-220-B
ME-220-C
ME-220-D
ME-221-A
ME-221-B
ME-221-C

ME-221-D
ME-247-A
McGraw recloser type H, 3H. R280-91-1, TCC-247-A, 5A, 9/15/94.
ME-247-B
McGraw recloser type H, 3H. R280-91-1, TCC-247-B, 5A, 9/15/94.
ME-247-C
McGraw recloser type H, 3H. R280-91-1, TCC-247-C, 5A, 9/15/94.
ME-248-A
ME-248-B
ME-248-C
ME-249-A
ME-249-B
ME-249-C
ME-250-A
ME-250-B
ME-250-C
ME-251-A
ME-251-B
ME-251-C
ME-252-A
ME-252-B
ME-252-C
ME-282-A
ME-282-B
ME-282-C
ME-282-D
ME-298-A
McGraw-Edison recloser types 4H, VH, PV4H ( Single Phase ); 6H, V6H (T
hree Phase ) 5A. Reference R280-91-2. TCC-298-A.
ME-298-B
McGraw-Edison recloser types 4H, V4H, PV4H ( Single Phase ); 6H, V6H (
Three Phase ) 5A. Reference R280-91-2. TCC-298-B.
ME-298-C
Three Phase ) 5A. Reference R280-91-2. TCC-298-C.
ME-299-A
Three Phase ) 10A. Reference R280-91-2. TCC-299-A.
ME-299-B
ME-299-C

ME-300-A
ME-300-B
ME-300-C
McGraw-Edison recloser type 4H, V4H, PV4H ( Single Phase ); 6H, V6H ( T
hree Phase ) 15A. Reference R280-91-2. TCC-300-C.
ME-301-A
ME-301-B
ME-301-C
ME-302-A
ME-302-B
ME-302-C
ME-303-A
ME-303-B
McGraw-Edison recloser types 4H, V4H, PV4H ( Single Phase ); 6H, V6H
( Three Phase ) 50A. Reference R280-91-2. TCC-303-B.
ME-303-C
McGraw-Edison recloser types 4H, V4H, PV4H ( Single Phase ); 6H, V6H
( Three Phase ) 50A. Reference R280-91-2. TCC-303-C.
ME-304-A
McGraw-Edison recloser types 4H, 4H, PV4H ( Single Phase ); 6H, V6H ( T
ME-304-B
ME-304-C
ME-305-A
McGraw-Edison recloser types 4H, 4H, PV4H ( Single Phase ); 6H, V6H ( t
ME-305-B
ME-305-C
ME-341-A1
McGraw recloser type PWH, PWVH, SW, SWV, VW, VWV, W, WV.
R280-91-6. TCC-341-A1. 7/13/94.
ME-341-A2
McGraw recloser type R, RV, RX. 280-91-6. TCC-341-A2. 7/13/94.
ME-341-B
McGraw recloser type PWH, PWVH, R, RV, RX, SW, SWV, VW, VWV, W, WV.
R280-91-6. TCC-341-B. 7/13/94.
ME-341-C

R280-91-6. TCC-341-C. 7/13/94.
ME-341-D
R280-91-6. TCC-341-D. 7/13/94.
ME-341-E
R280-91-6. TCC-341-E. 7/13/94.
ME-342-A
McGraw recloser type PWH, PWVH, R, RV, RX, SW, SWV, VW, VWS, VWV, W, WV
R280-91-6. TCC-342-A. 7/13/94.
ME-342-B
R280-91-6. TCC-342-B. 7/13/94.
ME-342-C
R280-91-6. TCC-342-C. 7/13/94.
ME-342-D
R280-91-6. TCC-342-D. 7/13/94.
ME-342-E
R280-91-6. TCC-342-E. 7/13/94.
ME-356-A
McGraw recloser type E, S/N < 52000. R280-91-5, TCC-356-A, 5A, 9/15/94.
ME-356-B
McGraw recloser type E, S/N < 52000. R280-91-5, TCC-356-B, 5A, 9/15/94.
ME-356-C
McGraw recloser type E, S/N < 52000. R280-91-5, TCC-356-C, 5A, 9/15/94.
ME-357-A
McGraw recloser type E, S/N < 52000. R280-91-5, TCC-357-A, 10A, 9/15/94
.
ME-357-B
McGraw recloser type E, S/N < 52000. R280-91-5, TCC-357-B, 10A, 9/15/94
.
ME-357-C
McGraw recloser type E, S/N < 52000. R280-91-5, TCC-357-C, 10A, 9/15/94
.
ME-358-A
.
ME-358-B
.
ME-358-C
.
ME-359-A
.
ME-359-B
.
ME-359-C
.
ME-360-A
.
ME-360-B
.
ME-360-C
.

ME-361-A
.
ME-361-B
.
ME-361-C
.
ME-362-A
McGraw recloser type E. R280-91-5, TCC-362-A, 75A, 9/14/94.
ME-362-B
.
ME-362-C
.
ME-363-A
4.
ME-363-B
4.
ME-363-C
4.
ME-417-A
McGraw recloser type R, RV, RX. R280-91-6, TCC-417-A, 1500A. 7/13/94.
ME-417-B
McGraw recloser type R, RV, RX. R280-91-6, TCC-417-B, 1500A. 7/13/94.
ME-417-C
McGraw recloser type R, RV, RX. R280-91-6, TCC-417-C, 1500A. 7/13/94.
ME-417-D
McGraw recloser type R, RV, RX. R280-91-6, TCC-417-D, 1500A. 7/13/94.
ME-417-E
McGraw recloser type R, RV, RX. R280-91-6, TCC-417-E, 1500A. 7/13/94.
ME-418-A
McGraw recloser type R, RV, RX. R280-91-6, TCC-418-A. 2100A, 7/13/94.
ME-418-B
McGraw recloser type R, RV, RX. R280-91-6, TCC-418-B. 2100A, 7/13/94.
ME-418-C
McGraw recloser type R, RV, RX. R280-91-6, TCC-418-C. 2100A, 7/13/94.
ME-418-D
McGraw recloser type R, RV, RX. R280-91-6, TCC-418-D. 2100A, 7/13/94.
ME-418-E
McGraw recloser type R, RV, RX. R280-91-6, TCC-418-E. 2100A, 7/13/94.
ME-419-A1
McGraw recloser Type PWH, PWVH, SW, SWV, VW, VWV.
R280-91-6. TCC-419-A1. 3000A. 7/13/94.
ME-419-A2
McGraw recloser Type R, RV, RX. R280-91-6. TCC-419-A2. 3000A. 7/13/94.
ME-419-B
McGraw recloser Type PWH, PWVH, R, RV, RX, SW, SWV, VW, VWV.
R280-91-6. TCC-419-B. 3000A. 7/13/94.
ME-419-C
R280-91-6. TCC-419-C. 3000A. 7/13/94.
ME-419-D
R280-91-6. TCC-419-D. 3000A. 7/13/94.
ME-419-E
R280-91-6. TCC-419-E. 3000A. 7/13/94.

ME-420-A1
McGraw recloser type PWH, PWVH, SW, SWV, VW, VWV.
R280-91-6. TCC-420-A1. 4200A. 7/13/94.
ME-420-A2
McGraw recloser type R, RV,RX. R280-91-6. TCC-420-A2. 4200A. 7/13/94.
ME-420-B
McGraw recloser type PWH, PWVH, R, RV, RX, SW, SWV, VW, VWV.
R280-91-6. TCC-420-B. 4200A. 7/13/94.
ME-420-C
R280-91-6. TCC-420-C. 4200A. 7/13/94.
ME-420-D
R280-91-6. TCC-420-D. 4200A. 7/13/94.
ME-421-A1
McGraw recloser type PWH, PWVH, SW, SWV, VW, VWS, VWV, W, WV.
R280-91-6. TCC-421-A1. 7/13/94.
ME-421-A2
McGraw recloser type R, RV, RX
R280-91-6. TCC-421-A2. 7/13/94.
ME-421-B
R280-91-6. TCC-421-B. 7/13/94.
ME-421-C
R280-91-6. TCC-421-C. 7/13/94.
ME-421-D
R280-91-6. TCC-421-D. 7/13/94.
ME-421-E
R280-91-6. TCC-421-E. 7/13/94.
ME-422-A1
R280-91-6. TCC-422-A1. 7/14/94.
ME-422-A2
McGraw recloser type R, RV, RX. R280-91-6. TCC-422-A2. 7/14/94.
ME-422-B
R280-91-6. TCC-422-B. 7/14/94.
ME-422-C
R280-91-6. TCC-422-C. 7/14/94.
ME-422-D
R280-91-6. TCC-422-D. 7/14/94.
ME-422-E
R280-91-6. TCC-422-E. 7/14/94.
ME-423-A1
R280-91-6. TCC-423-A1. 7/14/94.
ME-423-A2
McGraw recloser type R, RV, RX, R280-91-6. TCC-423-A2. 7/14/94.
ME-423-B
R280-91-6. TCC-423-B. 7/14/94.
ME-423-C
R280-91-6. TCC-423-C. 7/14/94.
ME-423-D
R280-91-6. TCC-423-D. 7/14/94.
ME-423-E

R280-91-6. TCC-423-E. 7/14/94.
ME-424-A1
McGraw recloser type PWH, PWVH, SW, SWV, VW, VWS, VWV, W, WV
R280-91-6. TCC-424-A1. 7/14/94.
ME-424-A2
McGraw recloser type R, RV, RX.
R280-91-6. TCC-424-A2. 7/14/94.
ME-424-B
R280-91-6. TCC-424-B. 7/14/94.
ME-424-C
R280-91-6. TCC-424-C. 7/14/94.
ME-424-D
R280-91-6. TCC-424-D. 7/14/94.
ME-424-E
R280-91-6. TCC-424-E. 7/14/94.
ME-425-A1
R280-91-6. TCC-425-A1. 7/14/94.
ME-425-A2
R280-91-6. TCC-425-A2. 7/14/94.
ME-425-B
R280-91-6. TCC-425-B. 7/14/94.
ME-425-C
R280-91-6. TCC-425-C. 7/14/94.
ME-425-D
R280-91-6. TCC-425-D. 7/14/94.
ME-425-E
R280-91-6. TCC-425-E. 7/14/94.
ME-426-A1
R280-91-6. TCC-426-A1. 7/14/94.
ME-426-A2
McGraw recloser type R, RV, RX. R280-91-6. TCC-426-A2. 7/14/94.
ME-426-B
R280-91-6. TCC-426-B. 7/14/94.
ME-426-C
R280-91-6. TCC-426-C. 7/14/94.
ME-426-D
R280-91-6. TCC-426-D. 7/14/94.
ME-426-E
R280-91-6. TCC-426-E. 7/14/94.
ME-427-A1
R280-91-6. TCC-427-A1. 7/14/94.
ME-427-A2
R280-91-6. TCC-427-A2. 7/14/94.
ME-427-B
R280-91-6. TCC-427-B. 7/14/94.
ME-427-C

R280-91-6. TCC-427-C. 7/14/94.
ME-427-D
R280-91-6. TCC-427-D. 7/14/94.
ME-427-E
R280-91-6. TCC-427-E. 7/14/94.
ME-428-A
McGraw recloser type PWH, PWVH, R, RV, RX, SW, SWV, VM, VWS, W, WV
R280-91-6. TCC-428-A. 7/14/94.
ME-428-B
R280-91-6. TCC-428-B. 7/14/94.
ME-428-C
R280-91-6. TCC-428-C. 7/14/94.
ME-428-D
R280-91-6. TCC-428-D. 7/14/94.
ME-428-E
R280-91-6. TCC-428-E. 7/14/94.
ME-429-1
McGraw recloser types RE, RVE, RXE, SWE, SWVE, VWE, VWVE, WE, WVE.
Ground trip-Socket No.1 plugs. Reference R280-91-26. TCC-429-1
ME-429-2
ME-429-3
ME-429R-1
McGraw recloser type Electronic Control. Ground trip-Socket No. 1 plugs
. R280-91-25. TCC-429R-1
ME-429R-2
. R280-91-25. TCC-429R-2
ME-429R-3
. R280-91-25. TCC-429R-3
ME-430-A
Phase trip-Socket No.1 plugs. Reference R280-91-26. TCC-430-A
ME-430-B
McGraw recloser types SWE, SWVE, VWE, VWVE, WE, WVE.
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-430-B
ME-430-C
McGraw Recloser types SWE, SWVE, VWE, VWVE, WE, WVE.
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-430-C
ME-430-D
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-430-D
ME-430-E
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-430-E
ME-431-A*
McGraw recloser types RE, RVE, RXE.
Phase trip-Socket No.1 plugs.
Reference R280-91-26. TCC-431-AP
ME-431-B
McGraw recloser types RE, RVE, RXE. Phase trip-Socket No.1 plugs. Ref
erence R280-91-26. TCC-431-B
ME-431-C
McGraw recloser types RE, RVE, RXE. Phase trip-Socket No. 2 plugs. Re
ference R280-91-26. TCC-431-C

ME-431-D
ference R280-91-26. TCC-431-D
ME-431-E
ference R280-91-26. TCC-431-E
ME-431R-A
McGraw recloser type Electronic Control. Phase trip-Socket No.1 plugs.
R280-91-25. TCC_431R-A
ME-431R-B
McGraw recloser type Electronic Control. Phase trip-Socket No. 2 plugs.
R280-91-25. TCC-431R-B
ME-431R-C
McGraw recloser type Electronic Control. Phase trip-Socket No. 2 plugs
. R280-91-25. TCC-431R-C
ME-431R-D
R280-91-25. TCC-431R-D
ME-431R-E
R280-91-25. TCC-431R-E
ME-440_1-2
McGraw recloser type R, RV, RX, VW, VWV, W, WV
Refference Data: R280-91-7, TCC-440
Curve 1-2
Group trip-Inverse time
KA510R2 accessory. Parallel connection, bushing
CT all Ratios
Created 06/20/2003
ME-440_1-3
Curve 1-3
Group trip-Inverse time
CT all Ratios
Created 06/20/2003
ME-440_2
Curve 2
Group trip-Inverse time. Average clearing time for one operation.
CT all Ratios
Created 06/20/2003
ME-440_3
Curve 3
Group trip-Inverse time. Average clearing time for one operation.
CT all Ratios
Created 06/20/2003
ME-451-Y
McGraw recloser types RE, RVE, RXE, SWE, SWVE, VWE, VWVE, WE, WVE. Phas
e trip-Socket No. 2 plugs. Reference R280-91-26. TCC-451-Y
ME-451-Z
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-451-Z
ME-470-A
McGraw recloser types D, DV. Reference R280-91-4. TCC-470-A. 100A.
ME-470-B
McGraw recloser type D, DV. Reference R280-91-4. TCC-470-B. 100A.
ME-470-C
McGraw recloser type D, DV. Reference R280-91-4. TCC-470-C. 100A.

ME-470-D
McGraw recloser types D, DV. Reference R280-91-4. TCC-470-D. 100A.
ME-470-E
McGraw recloser types D, DV. Reference R280-91-4. TCC-470-E. 100A.
ME-471-A
McGraw recloser type D, DV. R280-91-4, TCC-471-A, 140A, 9/16/94.
ME-471-B
McGraw recloser type D, DV. R280-91-4, TCC-471-B, 140A, 9/16/94.
ME-471-C
McGraw recloser type D, DV. R280-91-4, TCC-471-C, 140A, 9/16/94.
ME-471-D
McGraw recloser type D, DV. R280-91-4, TCC-471-D, 140A, 9/16/94.
ME-471-E
McGraw recloser type D, DV. R280-91-4, TCC-471-E, 140A, 9/16/94.
ME-472-A
ME-472-B
ME-472-C
ME-472-D
ME-472-E
ME-473-A
ME-473-B
ME-473-C
ME-473-D
ME-473-E
ME-474-A
ME-474-B
ME-474-C
ME-474-D
ME-474-E
ME-475-A
ME-475-B
ME-475-C
ME-475-D
ME-475-E
ME-476-A
ME-476-B
ME-476-C
ME-476-D

ME-476-E
ME-477-A
ME-477-B
ME-477-C
ME-477-D
ME-477-E
ME-478-A
McGraw-Edison recloser types CXE, CVE, CZE. Phase Trip - Socket No. 1.
Reference R280-91-29. TCC-478-A.
Created 04/08/2003
ME-478-B
Reference R280-91-29. TCC-478-B.
Created 04/08/2003
ME-478-C
R eference R280-91-29. TCC-478-C.
Created 04/08/2003
ME-478-D
Reference R280-91-29. TCC-478-D.
Created 04/08/2003
ME-478-E
Reference R280-91-29. TCC-478-E.
Created 04/08/2003
ME-479-1
McGraw-Edison recloser type CXE, CVE, CZE. Ground trip - Socket No 1. Reference
R280-91-29. TCC-479-1.
ME-479-2
McGraw-Edison recloser types CXE, CVE, CZE. Ground trip - Socket No.2.
Reference R280-91-29. TCC-479-2.
ME-479-3
McGraw-Edison recloser types CXE, CVE, CZE. Ground trip - Socket No.2.
Reference R280-91-29. TCC-479-3.
ME-480-1
McGraw recloser type ME, MLE, MVE. R280-91-28, TCC-480-1, socket No.1,
9/16/94.
ME-480-2
9/16/94.
ME-480-3
9/16/94.
ME-481-A
McGraw recloser type ME, MLE, MVE. R280-91-28, TCC-481-A, socket No.1,
9/16/94.
ME-481-B
McGraw recloser type ME, MLE, MVE. R280-91-28, TCC-481-B, socket No.2,
9/16/94.
ME-481-C
McGraw recloser type ME, MLE, MVE. R280-91-28, TCC-481-C, socket No.2,
9/16/94.
ME-481-D
McGraw recloser type ME, MLE, MVE. R280-91-28, TCC-481-D, socket No.2,
9/16/94.
ME-481-E
McGraw recloser type ME, MLE, MVE. R280-91-28, TCC-481-E, socket No.2,

9/16/94.
ME-482-A
ME-482-B
ME-482-C
ME-482-D
ME-482-E
ME-483-A
ME-483-B
ME-483-C
ME-483-D
ME-483-E
ME-486-13
Ground trip-Socket No. 2 plugs. Reference R280-91-26. TCC-486-13
ME-486-5
ME-486-6
Ground trip-Socket no. 2 plugs. Reference R280-91-26. TCC-486-6
ME-486R-13
. R280-91-25. TCC-486R-13
ME-486R-5
. R280-91-25. TCC-486R-5
ME-486R-6
. R280-91-25. TCC-486R-6
ME-487-11
ME-487-7
McGraw recloser types RE, RVE, RXE, SWE, SWVE, VWE, VWVE, WE,WVE.
ME-487-9
McGraw recloser types RE, RVE, RXE. SWE, SWVE, VWE, VWVE, WE, WVE.
ME-487R-11
. R280-91-25. TCC-487R-11
ME-487R-7
. R280-91-25. TCC-487R-7
ME-487R-9
. R280-91-25. TCC-487R-9
ME-488-14
ME-488-4

ME-488-8
McGraw recloser types RE,RVE, RXE, SWE, SWVE, VWE, VWVE, WE, WVE.
ME-488R-14
McGraw recloser type Electronic Control. Ground trip-Socket No. 2 Plugs
. R280-91-25. TCC-488R-14
ME-488R-4
McGraw recloser type Electronic Control. Ground trip-Socket No.1 plugs.
R280-91-25. TCC-488R-4
ME-488R-8
. R280-91-25. TCC-488R-W
ME-488R-81
McGraw recloser type Electronic Control. Ground trip-Socket No.1 Plugs.
TCC-488R, Curve 81. Created 5/23/95.
ME-488R-82
ME-488R-83
ME-488R-84
ME-488R-85
ME-489-K
Ground trip-Socket No. 2 plugs. Reference R280-91-26. TCC-489-K
ME-489R-K
. R280-91-25. TCC-489R-K
ME-490-8
ME-490-8*
McGraw recloser types RE,RVE,RXE, SWE, SWVE, VWE, VWVE, WE, WVE. Ground
trip-Socket No.1 plugs. Reference R280-91-26. TCC-490-8S
ME-490-8+
Ground trip-Socket No.1 plugs. Reference R280-91-26. TCC_490-8P
ME-490R-8
R280-91-25. TCC-490R-8
ME-490R-8*
R280-91-25. TCC-494R-8S
ME-490R-8+
R280-91-25. TCC-490R-8P
ME-491-H
McGraw recloser types RE, RVE,RXE, SWE, SWVE, VWE, VWVE, WE, WVE.
Phase trip-Socket No.1 plugs. Reference R280-91-26. TCC-491-H
ME-491-V
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-491-V
ME-491R-H
R280-91-25. TCC-491R-H
ME-491R-V
MCGraw recloser type Electronic Control. Phase trip-Socket No. 2 plugs.
R280-91-25. TCC-491R-V
ME-492-M

Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-492-M
ME-492-N
Phase trip-Socket No.1 plugs. Reference R280-91-26. TCC-492-N
ME-492-P
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-492-P
ME-492-T
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-492-T
ME-492R-M
R280-91-25. TCC-492R-M
ME-492R-N
R280-91-25. TCC-492R-N
ME-492R-P
MCGraw recloser type Electronic Control. Phase trip-Socket No. 2 plugs.
R280-91-25. TTC-492R-P
ME-492R-T
R280-91-25. TCC-492R-T
ME-493-G
Phase trip-Socket No.1 plugs. Reference R280-91-26. TCC-493-G
ME-493-W
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-493-W
ME-493R-G
R280-91-25. TCC-493R-G
ME-493R-W
McGraw recloser type Electronic COntrol. Phase trip-Socket No. 2 plugs.
R280-91-25. TCC-493R-W
ME-494-K
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-494-K
ME-494-L
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-494-L
ME-494R-K
R280-91-25. TCC-494R-K
ME-494R-L
R280-91-25. TCC-494R
ME-495-F
Phase trip-Socket no. 2 plugs. Reference R280-91-26. TCC-495-F
ME-495-J
Phase trip-Socket No. 2 plugs. Reference R280-91-26. TCC-495-J
ME-495-R
Phase trip-Socket No.1 plugs. Reference R280-91-26. TCC-495-R
ME-495R-F
R280-91-25. TCC-495R-F
ME-495R-J
R280-91-25. TCC-495R-J
ME-495R-R
R280-91-25. TCC-495R-R

ME-498-A
McGraw recloser types VSA, VSAT, VSML, VSMT, VSO.
Form 2, 3, 3A controller.
Phase trip-Socket No.1 plugs. Reference R280-91-27. TCC-498-A.
Created 12/6/94.
ME-498-B
Phase trip-Socket No.2 plugs. Reference R280-91-27. TCC-498-B.
Created 12/6/94.
ME-498-C
Phase trip-Socket No.2 plugs. Reference R280-91-27. TCC-498-C.
Created 12/6/94.
ME-498-D
Phase trip-Socket No.2 plugs. Reference R280-91-27. TCC-498-D.
Created 12/6/94.
ME-498-E
Phase trip-Socket No.2 plugs. Reference R280-91-27. TCC-498-E.
Created 12/6/94.
ME-499-1
Ground trip-Socket No.1 plugs. Reference R280-91-27, TCC-499-1.
Created 12/6/94.
ME-499-2
Created 12/6/94.
ME-499-3
Created 12/6/94.
ME-500-15
ME-500-17
ME-500R-15
. R280-91-25. TCC-500R-15
ME-500R-17
R280-91-25. TCC-500R-17
ME-503-A
McGraw-edison recloser types 4H, V4H, PV4H ( Single Phase );
6H, V6H ( Three Phase ) 140A. Reference R280-91-2. TCC-503-A.
ME-503-B
McGraw-Edison recloser types 4H, V4H, PV4H ( Single Phase );
6H, V6H ( Three Phase ), 140A. Reference R280-91-2. TCC-503-B.
ME-503-C
6H, V6H ( Three Phase ). 40A. Reference R280-91-2. TCC-503-C.
ME-504-A
6H, V6H ( Three Phase ). 200A. Reference R280-91-2. TCC-504-A.
ME-504-B

6H, V6H ( Three Phase ). 200A. Reference R280-91-2. TCC-504-B.
ME-504-C
6H, V6H ( Three Phase ). 200A. Reference R280-91-2. TCC-504-C.
ME-507-16
ME-507-18
ME-507R-16
. R280-91-25. TCC-507R-16
ME-507R-18
. R280-91-25. 507R-18
ME-508-A
McGraw recloser type 4E. R280-91-8, TCC-508-A, 50A, 9/16/94.
ME-508-B
McGraw recloser type 4E. R280-91-8, TCC-508-B, 50A, 9/16/94.
ME-508-C
McGraw recloser type 4E. R280-91-8, TCC-508-C, 50A, 9/16/94.
ME-508-D
McGraw recloser type 4E. R280-91-8, TCC-508-D, 50A, 9/16/94.
ME-508V4-A
Cooper Recloser Type V4L & V4E.
Reference R-280-91-15, TCC-508-A, 50amp.
Created 12/06/2009.
ME-508V4-B
Reference R-280-91-15, TCC-508-B, 50amp.
Created 12/06/2009.
ME-508V4-C
Reference R-280-91-15, TCC-508-C, 50amp.
Created 12/06/2009.
ME-508V4-D
Reference R-280-91-15, TCC-508-D, 50amp.
Created 12/06/2009.
ME-509-A
ME-509-B
ME-509-C
ME-509-D
ME-509V4-A
Created 12/06/2009.
ME-509V4-B
Created 12/06/2009.
ME-509V4-C
Created 12/06/2009.
ME-509V4-D
Created 12/06/2009.

ME-510-A
ME-510-B
ME-510-C
ME-510-D
ME-510V4-A
Created 12/06/2009.
ME-510V4-B
Created 12/06/2009.
ME-510V4-C
Created 12/06/2009.
ME-510V4-D
Created 12/06/2009.
ME-511-A
ME-511-B
ME-511-C
ME-511-D
ME-511V4-A
Created 12/06/2009.
ME-511V4-B
Created 12/06/2009.
ME-511V4-C
Created 12/06/2009.
ME-511V4-D
Created 12/06/2009.
ME-512-A
ME-512-B
ME-512-C
ME-512-D
ME-512V4-A
Created 12/06/2009.
ME-512V4-B
Created 12/06/2009.

ME-512V4-C
Created 12/06/2009.
ME-512V4-D
Created 12/06/2009.
ME-513-A
ME-513-B
ME-513-C
ME-513-D
ME-513V4-A
Created 12/06/2009.
ME-513V4-B
Created 12/06/2009.
ME-513V4-C
Created 12/06/2009.
ME-513V4-D
Created 12/06/2009.
ME-529-KF-A
McGraw Recloser Type KF. Bullentin 73003, TCC-529 Curve A
Created 4/17/2003.
ME-529-KF-B
McGraw Recloser Type KF. Bullentin 73003, TCC-529 Curve B
Created 4/17/2003.
ME-529-KF-C
McGraw Recloser Type KF. Bullentin 73003, TCC-529 Curve C
Created 4/17/2003.
ME-541R-Y
R280-91-25. TCC-541R-Y
ME-541R-Z
R280-91-25. TCC-541R-Z
ME-549-1
McGraw recloser type R, RX, RV, W, WV, VW, VWV. R280-91-9, TCC-549-1, 9
/19/94.
ME-549-6
/19/94.
ME-550-2
/19/94.
ME-550-7
/19/94.
ME-551-3
/19/94.
ME-551-8
/19/94.

ME-552-4
/19/94.
ME-552-9
/19/94.
ME-553-5
/19/94.
ME-555-B
McGraw fault interrupter, Electronic trip control. Phase & ground trip,
50A, R280-91-31, TCC-555(556, 557)-B, 9/19/94.
ME-555-C
50A, R280-91-31, TCC-555(556, 557)-C, 9/19/94.
ME-555-D
50A, R280-91-31, TCC-555(556, 557)-D, 9/19/94.
ME-555-E
50A, R280-91-31, TCC-555(556, 557)-E, 9/19/94.
ME-555-F
50A, R280-91-31, TCC-555(556, 557)-F, 9/19/94.
ME-555-G
50A, R280-91-31, TCC-555(556, 557)-G, 9/19/94.
ME-555-H
50A, R280-91-31, TCC-555(556, 557)-H, 9/19/94.
ME-555-J
50A, R280-91-31, TCC-555(556, 557)-J, 9/19/94.
ME-555-N
50A, R280-91-31, TCC-555(556, 557)-N, 9/19/94.
ME-555R-B
50A, R280-91-31, TCC-555R(556R, 557R)-B, 9/19/94.
ME-555R-C
50A, R280-91-31, TCC-555R(556R, 557R)-C , 9/19/94.
ME-555R-D
McGraw fualt interrupter, Electronic trip control. Phase & ground trip,
50A, R280-91-31, TCC-555R(556R, 557R)-D, 9/19/94.
ME-555R-E
50A, R280-91-31, TCC-555R(556R, 557R)-E, 9/19/94.
ME-555R-F
50A, R280-91-31, TCC-555R(556R, 557R)-F, 9/19/94.
ME-555R-G
50A, R280-91-31, TCC-555R(556R, 557R)-G, 9/19/94.
ME-555R-H
50A, R280-91-31, TCC-555R(556R, 557R)-H, 9/19/94.
ME-555R-J
50A, R280-91-31, TCC-555R(556R, 557R)-J, 9/19/94.
ME-555R-N
50A, R280-91-31, TCC-555R(556R, 557R)-N, 9/19/94.
ME-562-11
McGraw recloser type 3H, 6H, V6H. R280-91-11, TCC-562-11, 9/19/94.

ME-562-3
ME-562-7
ME-563-5
ME-563-9
ME-564
McGraw fault interrupter, Electronic trip control. R280-91-31, TCC-564,
9/19/94.
ME-565-1
McGraw fault interrupter, Electronic trip control. R280-91-31, TCC-565-
1, 9/19/94.
ME-565-10
10, 9/19/94.
ME-565-11
11, 9/19/94.
ME-565-12
12, 9/19/94.
ME-565-13
13, 9/19/94.
ME-565-2
2, 9/19/94.
ME-565-3
3, 9/19/94.
ME-565-4
4, 9/19/94.
ME-565-5
5, 9/19/94.
ME-565-6
6, 9/19/94.
ME-565-7
7, 9/19/94.
ME-565-8
8, 9/19/94.
ME-565-9
9, 9/19/94.
ME-566-A
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-566-A, 5A, 9/17/94
.
ME-566-B
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-566-B, 5A, 9/17/94
.
ME-566-C
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-566-C, 5A, 9/17/94
.
ME-566-D
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-566-D, 5A, 9/17/94
.
ME-567-A
4.

ME-567-B
4.
ME-567-C
4.
ME-567-D
4.
ME-568-A
4.
ME-568-B
4.
ME-568-C
4.
ME-568-D
4.
ME-569-A
4.
ME-569-B
4.
ME-569-C
4.
ME-569-D
4.
ME-570-A
4.
ME-570-B
4.
ME-570-C
4.
ME-570-D
McGraw recloser type E. R280-91-10, TCC-570-D, 35A, 9/17/94.
ME-571-A
4.
ME-571-B
4.
ME-571-C
4.
ME-571-D
4.
ME-572-A
4.
ME-572-B
4.
ME-572-C
4.

ME-572-D
4.
ME-573-A
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-573-A, 100A, 9/17/
94.
ME-573-B
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-573-B, 100A, 9/17/
94.
ME-573-C
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-573-C, 100A, 9/17/
94.
ME-573-D
McGraw recloser type E, S/N > 52000. R280-91-10, TCC-573-D, 100A, 9/17/
94.
ME-629-F
McGraw fault interrupter, Electronic trip control. R280-91-31, TCC-629(
630)-F, 5/22/96.
ME-629-G
630)-G, 5/22/96.
ME-629-H
630)-H, 5/22/96.
ME-629-J
630)-J, 5/22/96.
ME-631-2
Cooper Reclosers
Type RX, RV, W, WV, VW, VWV
Reference R-280-91-12, TCC-631.
Curve No. 2.
Created 5/17/2009.
ME-631-4
Cooper Reclosers
Curve No. 4.
Created 5/17/2009.
ME-631-6
Cooper Reclosers
Curve No. 6.
Created 5/17/2009.
ME-631R-2R
Cooper Reclosers
Reference R-280-91-12, TCC-631R.
Curve No. 2R.
Created 5/17/2009.
ME-631R-4R
Cooper Reclosers
Curve No. 4R.
Created 5/17/2009.
ME-631R-6R
Cooper Reclosers
Curve No. 6R.
Created 5/17/2009.
ME-632-1
Cooper Reclosers

Curve No. 1.
Created 5/17/2009.
ME-632-3
Cooper Reclosers
Curve No. 3.
Created 5/17/2009.
ME-632-5
Cooper Reclosers
Curve No. 5.
Created 5/17/2009.
ME-632R-1R
Cooper Recloser
Curve No. 1R.
Created 5/17/2009.
ME-632R-3R
Cooper Reclosers
Curve No. 3R.
Created 5/17/2009.
ME-632R-5R
Cooper Reclosers
Curve No. 5R.
Created 5/17/2009.
ME-633-B&C
Cooper Recloser
Curve No. CURRENT IN PHASE BOTH B&C.
Created 5/18/2009.
ME-633-BORC
Cooper Recloser
Curve No. CURRENT IN PHASE B or C.
Created 5/18/2009.
ME-634R-101
Recloser Form 4A and 4C,
Type Microprocessor-Based.
Reference R280-91-34, TCC-634R.
Curve No. 101.
Created 9/27/93.
ME-634R-102
Curve No. 102.
Created 9/27/93.
ME-634R-103
Curve No. 103.
Created 9/27/93.
ME-634R-104
Curve No. 104.
Created 9/27/93.

ME-634R-105
Curve No. 105.
Created 9/27/93.
ME-634R-106
Curve No. 106.
Created 9/27/93.
ME-634R-107
Curve No. 107.
Created 9/27/93.
ME-634R-111
Curve No. 111.
Created 9/27/93.
ME-634R-112
Curve No. 112.
Created 9/27/93.
ME-634R-113
Curve No. 113.
Created 9/27/93.
ME-634R-114
Curve No. 114.
Created 9/27/93.
ME-634R-115
Curve No. 115.
Created 9/27/93.
ME-634R-116
Curve No. 116.
Created 9/27/93.
ME-634R-117
Curve No. 117.
Created 9/27/93.
ME-634R-118
Curve No. 118.
Created 9/27/93.
ME-634R-119

Curve No. 119.
Created 9/27/93.
ME-634R-120
Curve No. 120.
Created 9/27/93.
ME-634R-121
Curve No. 121.
Created 9/27/93.
ME-634R-122
Curve No. 122.
Created 9/27/93.
ME-634R-131
Type MicroProcessor-Based.
Curve No. 131.
Created 9/27/93.
ME-634R-132
Curve No. 132.
Created 9/27/93.
ME-634R-133
Curve No. 133.
Created 9/27/93.
ME-634R-134
Curve No. 134.
Created 9/27/93.
ME-634R-135
Curve No. 135.
Created 9/27/93.
ME-634R-136
Curve No. 136.
Created 9/27/93.
ME-634R-137
Curve No. 137.
Created 9/27/93.
ME-634R-138

Curve No. 138.
Created 9/27/93.
ME-634R-139
Curve No. 139.
Created 9/27/93.
ME-634R-140
Curve No. 140.
Created 9/27/93.
ME-634R-141
Curve No. 141.
Created 9/27/93.
ME-634R-142
Curve No. 142.
Created 9/27/93.
ME-634R-151
Curve No. 151.
Created 9/27/93.
ME-634R-152
Curve No. 152.
Created 9/27/93.
ME-634R-161
Curve No. 161.
Created 9/27/93.
ME-634R-162
Curve No. 162.
Created 9/27/93.
ME-634R-163
Curve No. 163.
Created 9/27/93.
ME-634R-164
Curve No. 164.
Created 9/27/93.
ME-634R-165
Curve No. 165.
Created 9/27/93.

ME-634R-200
Curve No. 200.
Created 9/27/93.
ME-634R-201
Curve No. 201.
Created 9/27/93.
ME-634R-202
Curve No. 202.
Created 9/27/93.
ME-637-A
Cooper Recloser Type V4L & V4E. R280-91-15, TCC-637-A, 15 amp,11/18/97.
ME-637-B
Cooper Recloser Type V4L & V4E. R280-91-15, TCC-637-B, 15 amp,11/18/97.
ME-637-C
Cooper Recloser Type V4L & V4E. R280-91-15, TCC-637-C, 15 amp,11/18/97.
ME-637-D
Cooper Recloser Type V4L & V4E. R280-91-15, TCC-637-D, 15 amp,11/18/97.
ME-638-A
Cooper Recloser Type V4L & V4E. R280-91-15, TCC-638-A, 25 amp,11/18/97
ME-638-B
ME-638-C
ME-638-D
ME-639-A
Cooper Recloser Type V4L & V4E. R280-91-15, TCC-639-A, 35 amp,11/18/97.
ME-639-B
ME-639-C
ME-639-D
ME-640-B
630)-B. 5/22/96.
ME-640-C
630)-C, 5/22/96.
ME-640-D
McGraw fault interrupter, Electronic trip control. R280-91-31, TCC-640R
(641R)-D, 5/22/96.
ME-640-E
630)-E. 5/22/96.
ME-640-N
McGraw fault interrupter, Electronic trip control. R280-91-31, TCC-640R
(641R)-N, 5/22/96.
ME-651-A
Cooper Recloser Type VXE. R280-91-16, TCC-651-A, 10/1/98.
ME-651-AMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-651-A-MOD1, 10/1/98.
ME-651-AMOD2
ME-651-AMOD3

ME-651R-A
Cooper Recloser Type VXE. R280-91-16, TCC-651R-A, 10/1/98.
ME-651RAMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-651R-A-MOD1, 10/1/98.
ME-651RAMOD2
ME-651REMOD3
ME-652-B
Cooper Recloser Type VXE. R280-91-16, TCC-652-B, 10/1/98.
ME-652-BMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-652-B-MOD1, 10/1/98.
ME-652-BMOD2
ME-652-BMOD3
ME-652R-B
Cooper Recloser Type VXE. R280-91-16, TCC-652R-B, 10/1/98.
ME-652RBMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-652R-B-MOD1, 10/1/98.
ME-652RBMOD2
ME-652RBMOD3
ME-653-C
Cooper Recloser Type VXE. R280-91-16, TCC-653-C, 8/11/99.
ME-653-CMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-653-C-MOD1, 8/11/99.
ME-653-CMOD2
ME-653-CMOD3
ME-653R-C
Cooper Recloser Type VXE. R280-91-16, TCC-653R-C, 8/11/99.
ME-653RCMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-653R-C-MOD1, 8/11/99.
ME-653RCMOD2
ME-653RCMOD3
ME-654-D
Cooper Recloser Type VXE. R280-91-16, TCC-654-D, 10/1/98.
ME-654-DMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-654-D-MOD1, 10/1/98.
ME-654-DMOD2
ME-654-DMOD3
ME-654R-D
Cooper Recloser Type VXE. R280-91-16, TCC-654R-D, 10/1/98.
ME-654RDMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-654R-D-MOD1, 10/1/98.
ME-654RDMOD2
ME-654RDMOD3
ME-655-E
Cooper Recloser Type VXE. R280-91-16, TCC-655-E.
Created 4/7/2003.
ME-655-EM1
Recloser VXE,

Curve No. EM1.
Created 3/5/02.
ME-655-EM2
Recloser VXE,
Curve No. EM2.
Created 3/5/02.
ME-655-EM3
Recloser VXE,
Curve No. EM3.
Created 3/5/02.
ME-655-EMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-655-E-MOD1.
Created 4/7/2003.
ME-655-EMOD2
Created 4/7/2003.
ME-655-EMOD3
Created 4/7/2003.
ME-655R-E
Cooper Recloser Type VXE. R280-91-16, TCC-655R-E.
Created 4/7/2003.
ME-655R-EM1
Recloser VXE,
Curve No. EM1.
Created 3/5/02.
ME-655R-EM2
Recloser VXE,
Curve No. EM2.
Created 3/5/02.
ME-655R-EM3
Recloser VXE,
Curve No. EM3.
Created 3/5/02.
ME-655R-EMO1
Cooper Recloser Type VXE. R280-91-16, TCC-655R-E-MOD1.
Created 4/7/2003.
ME-655R-EMO2
Created 4/7/2003.
ME-655R-EMO3
Created 4/7/2003.
ME-656-F
Cooper Recloser Type VXE. R280-91-16, TCC-656-F.
Created 4/7/2003.
ME-656-FM1
Recloser VXE,
Curve No. FM1.
Created 3/5/02.
ME-656-FM2
Recloser VXE,
Curve No. FM2.

Created 3/5/02.
ME-656-FM3
Recloser VXE,
Curve No. FM3.
Created 3/5/02.
ME-656-FMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-656-F-MOD1.
Created 4/7/2003.
ME-656-FMOD2
Created 4/7/2003.
ME-656-FMOD3
Created 4/7/2003.
ME-656R-F
Cooper Recloser Type VXE. R280-91-16, TCC-656R-F.
Created 4/7/2003.
ME-656R-FM1
Recloser VXE,
Curve No. FM1.
Created 3/5/02.
ME-656R-FM2
Recloser VXE,
Curve No. FM2.
Created 3/5/02.
ME-656R-FM3
Recloser VXE,
Curve No. FM3.
Created 3/5/02.
ME-656R-FMO1
Cooper Recloser Type VXE. R280-91-16, TCC-656R-F-MOD1.
Created 4/7/2003.
ME-656R-FMO2
Created 4/7/2003.
ME-656R-FMO3
Created 4/7/2003.
ME-659-N
Cooper Recloser Type VXE. R280-91-16, TCC-659-N, 8/11/99.
ME-659-NMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-659-N-MOD1, 8/11/99.
ME-659-NMOD2
ME-659-NMOD3
ME-659R-N
Cooper Recloser Type VXE. R280-91-16, TCC-659R-N, 8/11/99.
ME-659RNMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-659R-N-MOD1, 8/11/99.
ME-659RNMOD2
ME-659RNMOD3
ME-660-R
Cooper Recloser Type VXE. R280-91-16, TCC-660-R, 8/11/99.

ME-660-RMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-660-R-MOD1, 8/11/99.
ME-660-RMOD2
ME-660-RMOD3
ME-660R-R
Cooper Recloser Type VXE. R280-91-16, TCC-660R-R, 8/11/99.
ME-660RRMOD1
Cooper Recloser Type VXE. R280-91-16, TCC-660R-R-MOD1, 8/11/99.
ME-660RRMOD2
ME-660RRMOD3
ME-668-TF
Cooper Recloser Type VXE. R280-91-16, TCC-668-TF.
Created 4/7/2003.
ME-668-TFM1
Recloser VXE,
Curve No. TFM1.
Created 3/5/02.
ME-668-TFM2
Recloser VXE,
Curve No. TFM2.
Created 3/5/02.
ME-668-TFM3
Recloser VXE,
Curve No. TFM3.
Created 3/5/02.
ME-668-TFMO1
Cooper Recloser Type VXE. R280-91-16, TCC-668-TF-MOD1.
Created 4/7/2003.
ME-668-TFMO2
Created 4/7/2003.
ME-668-TFMO3
Created 4/7/2003.
ME-668R-TF
Cooper Recloser Type VXE. R280-91-16, TCC-668r-TF.
Created 4/7/2003.
ME-668R-TFM1
Recloser VXE,
Curve No. TFM1.
Created 3/5/02.
ME-668R-TFM2
Recloser VXE,
Curve No. TFM2.
Created 3/5/02.
ME-668R-TFM3
Recloser VXE,
Curve No. TFM3.
Created 3/5/02.

ME-668RTFMO1
Cooper Recloser Type VXE. R280-91-16, TCC-668R-TF-MOD1.
Created 4/7/2003.
ME-668RTFMO2
Created 4/7/2003.
ME-668RTFMO3
Created 4/7/2003.
ME-669-EF
Cooper Recloser Type VXE. R280-91-16, TCC-669-EF.
Created 4/7/2003.
ME-669-EFM1
Recloser VXE,
Curve No. EFM1.
Created 3/5/02.
ME-669-EFM2
Recloser VXE,
Curve No. EFM2.
Created 3/5/02.
ME-669-EFM3
Recloser VXE,
Curve No. EFM3.
Created 3/5/02.
ME-669-EFMO1
Cooper Recloser Type VXE. R280-91-16, TCC-669-EF-MOD1.
Created 4/7/2003.
ME-669-EFMO2
Created 4/7/2003.
ME-669-EFMO3
Created 4/7/2003.
ME-669R-EF
Cooper Recloser Type VXE. R280-91-16, TCC-669R-EF.
Created 4/7/2003.
ME-669R-EFM1
Recloser VXE,
Curve No. EFM1.
Created 3/5/02.
ME-669R-EFM2
Recloser VXE,
Curve No. EFM2.
Created 3/5/02.
ME-669R-EFM3
Recloser VXE,
Curve No. EFM3.
Created 3/5/02.
ME-669REFMO1
Cooper Recloser Type VXE. R280-91-16, TCC-669R-EF-MOD1.
Created 4/7/2003.
ME-669REFMO2
Created 4/7/2003.

ME-669REFMO3
Created 4/7/2003.
ME-670-KF
Cooper Recloser Type VXE. R280-91-16, TCC-670-KF.
Created 4/7/2003.
ME-670-KFM1
Recloser VXE,
Curve No. KFM1.
Created 3/6/02.
ME-670-KFM2
Recloser VXE,
Curve No. KFM2.
Created 3/6/02.
ME-670-KFM3
Recloser VXE,
Curve No. KFM3.
Created 3/6/02.
ME-670-KFMO1
Cooper Recloser Type VXE. R280-91-16, TCC-670-KF-MOD1.
Created 4/7/2003.
ME-670-KFMO2
Created 4/7/2003.
ME-670-KFMO3
Created 4/7/2003.
ME-670R-KF
Cooper Recloser Type VXE. R280-91-16, TCC-670R-KF.
Created 4/7/2003.
ME-670R-KFM1
Recloser VXE,
Curve No. KFM1.
Created 3/6/02.
ME-670R-KFM2
Recloser VXE,
Curve No. KFM2.
Created 3/6/02.
ME-670R-KFM3
Recloser VXE,
Curve No. KFM3.
Created 3/6/02.
ME-670RKFMO1
Cooper Recloser Type VXE. R280-91-16, TCC-670R-KF-MOD1.
Created 4/7/2003.
ME-670RKFMO2
Created 4/7/2003.
ME-670RKFMO3
Created 4/7/2003.
MELSP-030
Cooper Mini-ELSP Backup Type oil immersible current limiting fuse.
8.3 & 15.5kV, 30A. Ref. 240-91-60 & 240-91-63. Created 5/30/95.

MELSP-040
8.3 & 15.5kV, 40A. Ref. 240-91-60 & 240-91-63. Created 5/30/95.
MELSP-050
8.3 & 15.5kV, 50A. Ref. 240-91-60 & 240-91-63. Created 5/30/95.
MELSP-060
8.3 & 15.5kV, 60A (Parallel 2-30). Ref. 240-91-60 & 240-91-63. Created
5/30/95.
MELSP-080
8.3 & 15.5kV, 80A (Paraallel 2-40). Ref. 240-91-60 & 240-91-63. Created
5/30/95.
MELSP-100
8.3 & 15.5kV, 100A (Parallel 2-50). Ref. 240-91-60 & 240-91-63. Created
5/30/95.
MELSP15-125
Cooper Mid-Range ELSP Backup Type oil immersible current limiting fuse.
15.5kV, 125A. Ref. 240-91-83. Created 6/6/95.
MELSP15-250
MELSP8-125
8.3kV, 125A. Ref. 240-91-82. Created 10/4/99.
MV-155-65
Cooper E-Rated Medium Voltage Fuses
For Transformer and Feeder Protection
15.5kV - MV155F1DB & MV155F1DC Serires.
Curve 65A.
Created 12/19/2005
N-TIN-005N
M-E fuse links: TYPE N-TIN. 005N, Ref. R240-91-9. Created 7/24/96.
N-TIN-008N
N-TIN-010N
N-TIN-015N
N-TIN-020N
N-TIN-025N
N-TIN-030N
N-TIN-040N
N-TIN-050N
N-TIN-060N
N-TIN-075N
N-TIN-085N
N-TIN-100N
N-TIN-125N
N-TIN-150N

N-TIN-200N
NX04.3-018
McGraw-Edison NX type power fuse. 18A 4.3kV. Reference R240-91-30.
NX04.3-025
NX04.3-035
NX04.3-045
NX04.3-050
NX04.3-065
NX04.3-075
NX04.3-100
NX04.3-130
McGraw-Edison NX type power fuse. Two 65A - 4.3kV power fuses mounted i
n parallel. Reference R240-91-30.
NX04.3-150
NX04.3-200
McGraw-Edison NX type power fuse. Two 100A - 4.3kV power fuses mounted
in parallel. Reference R240-91-30.
NX05.5-006
McGraw-Edison NX type power fuse. 6A 5.5kV . Reference R240-91-31.
Updated 4/2/2010
NX05.5-008
NX05.5-010
Updated 4/2/2010
NX05.5-012
NX05.5-018
NX05.5-020
NX05.5-025
NX05.5-030
NX05.5-040
NX05.5-050
NX05.5-065
NX05.5-075
NX05.5-100
n parallel. Reference R240-91-31
NX05.5-130
McGraw-edison NX type power fuse. Two 65A - 5.5kV power fuses mounted i
NX05.5-150
McGraw-Edison NX type power fuse. Two 75A - 5.5kV fuses mounted in para
llel. Reference R240-91-31.

NX08.3-004.5
McGraw-Edison NX type fuse. 4.5A 8.3KV. Reference R240-91-32.
NX08.3-006
McGraw-Edison NX type fuse. 6A 8.3KV. Reference R240-91-32.
NX08.3-008
McGraw-Edison NX type power fuse. 8A 8.3KV. Reference R240-91-32.
NX08.3-010
NX08.3-012
NX08.3-018
NX08.3-020
NX08.3-025
NX08.3-030
NX08.3-040
NX08.3-050
NX08.3-065
NX08.3-080
NX08.3-100
NX08.3-130
McGraw-Edison NX type fuse. Two 65A - 8.3kV power fuses moun
ted in parallel. Reference R240-91-32.
NX08.3-160
McGraw-Edison NX type fuse. Two 80A - 8.3kV power fuses mo
unted in parallel. Reference R240-91-32.
NX08.3-200
McGraw-Edison NX type fuse. Two 100A - 8.3kV power fuses mou
nted in parallel. Reference R240-91-32.
NX08.3-2x100
McGraw-Edison NX type power fuse. Two 100A 8.3kV power fuses mounted in
parallel. Reference R240-91-32.
NX08.3-2x25
NX08.3-2x30
NX08.3-2x40
NX08.3-2x50
NX08.3-2x65
McGraw-edison NX type power fuse. Two 65A 8.3kV power fuses mounted in
parallel. reference R240-91-32.
NX08.3-2x80
NX15.5-004.5
McGraw-Edison NX type fuse. 4.5A 15.5KV. Reference R240-91-33.
NX15.5-006
NX15.5-008

NX15.5-010
NX15.5-012
NX15.5-018
NX15.5-020
NX15.5-025
NX15.5-030
NX15.5-040
NX15.5-050
NX15.5-065
NX15.5-080
NX15.5-100
NX15.5-130
NX15.5-160
McGraw-Edison NX type power fuse. Two 80A - 15.5kV power fuses mounte
d in parallel. Reference R240-91-33.
NX15.5-200
McGraw-Edison NX type power fuse. Two 100A -15.5kV power fusesmounted i
NX15.5-2x100
McGraw-Edison NX type power fuse. Two 100A 15.5kV fuses mounted in para
llel. Reference R240-91-33.
NX15.5-2x25
McGraw-Edison NX type power fuse. Two 25A-15.5kV power fuses mounted in
NX15.5-2x30
NX15.5-2x40
NX15.5-2x50
NX15.5-2x65
NX15.5-2x80
NX27.0-006
McGraw-Edison NX type power fuse. 6A 27kV. Reference R240-91-35.
NX27.0-008
NX27.0-010
NX27.0-012
NX27.0-015
NX27.0-018

NX27.0-020
NX27.0-025
NX27.0-030
NX27.0-040
NX27.0-050
NX27.0-060
McGraw-Edison NX type power fuse. Two 30A - 27kV power fuses mounted in
NX27.0-080
NX27.0-100
NXC15.5-010
McGraw-Edison NXC (Capacitor) fuse. 10A 15.5kV. Reference R240-91-38.
Created 5/30/95.
NXC15.5-012
Created 5/30/95.
NXC15.5-018
Created 5/30/95.
NXC15.5-025
Created 5/30/95.
NXC15.5-030
Created 5/30/95.
NXC15.5-035
Created 5/30/95.
NXII15.5-003
Cooper NXII (non-gassing) fuse. 3A 15.5 kV.Reference R240-91-72.
Created 11/17/97.
NXII15.5-006
McGraw-Edison NXII (non-gassing) fuse. 6A 15.5kV.Reference R240-91-72.
Created 5/23/96.
NXII15.5-008
Created 5/23/96.
NXII15.5-012
Created 5/23/96.
NXII15.5-018
Created 5/23/96.
NXII15.5-020
Created 5/23/96.
NXII15.5-025
Created 5/23/96.
NXII15.5-030
Created 5/23/96.
NXII15.5-040
Created 5/23/96.

NXII15.5-050
Created 5/23/96.
NXII15.5-065
McGraw Edison NXII (non-gassing) fuse. 65A 15.5kV.Reference R240-91-72.
Created 11/17/97.
RTE_719C_006
RTE 719C Fuse Link (6 amp). Fuse Link Nos: C4.
Ref. No.: 1551B and 1552B. Created 8/12/98.
RTE_719C_010
RTE_719C_015
RTE_719C_025
RTE_719C_040
RTE_719C_065
RTE_719C_140
TR-OLINK-065
Copper Power System Division Component & Protective Equipment. High AMP
Transformer Overload Link(65A). Reference R240-91-53.
Created 5/24/96.
TR-OLINK-100
Created 5/24/96.
TR-OLINK-125
Created 5/24/96.

CUTLER_HAMMER.RLY
This file contains Cutler-Hammer relay and fuse curves.
5CLE-030
Cuttler-Hammer Eaton CLE, HLE and HCL fuses
Type CLE general purpose current limiting fuses 5.5 to 15.5kV
Curve 30E
Reference # 563532, 563533
Created 12/2/2008
5CLE-125
Type CLE general purpose current limiting fuses 5.5 kV
Curve 125E
Reference # 705458, 705459
Created 12/2/2008
5CLE-250
Curve 250E
Reference # 705458, 705459
Created 12/2/2008
5CLE-350
Curve 350E
Reference # 705460,705461
Created 12/2/2008
5CLE-600
Type 5CLE-600E and 5CLS70-600E general purpose current limiting fuses
5.5 kV
Curve 600E
Reference # 629089,
Created 12/2/2008
CLE-R-015
Cutler-Hammer Eaton CLE-R General purpose current limiting fuses
5.5 - 15.5 kV
Curve 15E,
Reference No. 563532, 563533
Created 10/09/2007
CLE-R-020
5.5 - 15.5 kV
Curve 20E,
Reference No. 563532, 563533
Created 10/09/2007
CLE-R-025
5.5 - 15.5 kV
Curve 25E,
Reference No. 563532, 563533
Created 10/09/2007
CLE15-030
Cutler-Hammer Eaton CLE General purpose current limiting fuses
15.5 kV
Curve 30E,
Reference No. 70548601, 70548501
Created 08/11/2008
CLE15-100
15.5 kV
Curve 100E,
Reference No. 70546801, 70546901
Created 08/18/2008
CLE15-125
15.5 kV

Curve 125E,
Reference No. 70546801, 70546901
Created 08/18/2008
CLE15-150
15.5 kV
Curve 150E,
Reference No. 70546801, 70546901
Created 08/18/2008
CLE15-175
15 kV
Curve 175E,
Reference No. 705471, 705470
Created 10/09/2007
CLE15-200
15 kV
Curve 200E,
Reference No. 705471, 705470
Created 10/09/2007
CLE15-250
15 kV
Curve 250E,
Reference No. 705471, 705470
Created 10/09/2007
CLE15-300
15 kV
Curve 300E,
Reference No. 705471, 705470
Created 10/09/2007
CLE8-200
8.3 kV
Curve 200E,
Reference No. 705464, 705465
Created 10/09/2007
CLE8-250
8.3 kV
Curve 250E,
Reference No. 705464, 705465
Created 10/09/2007
CLE8-300
8.3 kV
Curve 300E,
Reference No. 705464, 705465
Created 10/09/2007
CLE8-350
8.3 kV
Curve 350E,
Reference No. 705464, 705465
Created 10/09/2007
CLS-030
Cutler-Hammer CLS5[4]-30A through 44R Motor Start current limiting fuses
Curve 30A
Created 04/24/2008
CLS-070
Curve 2R[70A]
Created 04/24/2008
CLS-100
Curve 3R[100A]

Created 04/24/2008
CLS-130
Curve 4R[130A]
Created 04/24/2008
CLS-150
Curve 5R[150A]
Created 04/24/2008
CLS-170
Curve 6R[170A]
Created 04/24/2008
CLS-210
Curve 9R[210A]
Created 04/24/2008
CLS-230
Cutler-Hammer CLS5[4]-30A through 44R Motor Start current limiting fuse
Curve 12R[230A]
Created 04/24/2008
CLS-390
Curve 18R[390A]
Created 04/24/2008
CLS-450
Curve 24R[450A]
Created 04/24/2008
CLS-480
Curve 26R[480A]
Created 04/24/2008
CLS-600
Curve 32R[600A]
Created 04/24/2008
CLS-650
Curve 36R[650A]
Created 04/24/2008
CLS-700
Curve 44R[700A]
Created 04/24/2008
CXF-003
Cutler-Hammer Type[8/15/23]CXF Full Range Limiting Fuse 3A
Curve 70541802, Reference#705318.
Created 01/18/2005
CXF-006
Created 01/18/2005
CXF-008
Created 01/18/2005
CXF-010
Created 01/18/2005
CXF-012
Created 01/18/2005

CXF-018
Created 01/18/2005
CXF-020
Created 01/18/2005
CXF-025
Created 01/18/2005
CXF-030
Created 01/18/2005
CXF-040
Created 01/18/2005
CXF-050
Created 01/18/2005
CXF-060
Cutler-Hammer Type[8/15/23]CXF Full Range Limiting Fuse 60A (two parall
el 30A fuses)
Created 01/18/2005
CXF-080
Cutler-Hammer Type[8/15/23]CXF Full Range Limiting Fuse 80A (two parall
el 40A fuses)
Created 01/18/2005
CXF-100
Cutler-Hammer Type[8/15/23]CXF Full Range Limiting Fuse 100A (two paral
lel 50A fuses)
Curve 70541802, Reference# 705318.
Created 01/18/2005
D3000-ANSI-M
Cutler-Hammer Digitrip 3000
ANSI Moderate curve
T=D*(0.0515/((I/Ipu)^.0.02-1) + 0.014)
Created 04/08/2003
D3000-ANSI-V
ANSI Very Inverse
T=D*(19.61/((I/Ipu)^2-1) + 0.491)
Created 04/08/2003
D3000-ANSI-X
ANSI Extremely Inverse
T=D*(28.2/((I/Ipu)^2-1) + 0.1217)
Created 04/08/2003
D3000-IECA-I
IEC curve A Normal Inverse
T=D*0.14/((I/Ipu)^0.02-1)
Created 04/08/2003
D3000-IECB-V
IEC curve B Very Inverse
T=D*13.5/((I/Ipu)-1)
Created 04/08/2003
D3000-IECC-X
IEC curve C Extremely Inverse

T=D*80/((I/Ipu)^2-1)
Created 04/08/2003
D3000-IECD-D
IEC curve D Definete time
T=D*4
Created 04/08/2003
DBU-E-005
Cutler-Hammer Type DBU Standard E fuses
17.1 to 38kV
Curve: 005 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-007
17.1 to 38kV
Curve: 007 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-010
17.1 to 38kV
Curve: 010 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-013
17.1 to 38kV
Curve: 013 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-015
17.1 to 38kV
Curve: 015 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-020
17.1 to 38kV
Curve: 020 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-025
17.1 to 38kV
Curve: 025 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-030
17.1 to 38kV
Curve: 030 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-040
17.1 to 38kV
Curve: 040 E
Curve #: 36-643

Reference: 667027
Created: 03/01/2006
DBU-E-050
17.1 to 38kV
Curve: 050 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-065
17.1 to 38kV
Curve: 065 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-080
17.1 to 38kV
Curve: 080 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-100
17.1 to 38kV
Curve: 100 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-125
17.1 to 38kV
Curve: 125 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-150
17.1 to 38kV
Curve: 150 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-175
17.1 to 38kV
Curve: 175 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-E-200
17.1 to 38kV
Curve: 200 E
Curve #: 36-643
Reference: 667027
Created: 03/01/2006
DBU-SE-015
Cutler-Hammer Type DBU Slow E Speed Fuses
17.1 to 38kV
Curve: 015 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-020
17.1 to 38kV

Curve: 020 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-025
17.1 to 38kV
Curve: 025 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-030
17.1 to 38kV
Curve: 030 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-040
17.1 to 38kV
Curve: 040 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-050
17.1 to 38kV
Curve: 050 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-065
17.1 to 38kV
Curve: 065 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-080
17.1 to 38kV
Curve: 080 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-100
17.1 to 38kV
Curve: 100 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-125
17.1 to 38kV
Curve: 125 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-150
17.1 to 38kV
Curve: 150 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009

DBU-SE-175
17.1 to 38kV
Curve: 175 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
DBU-SE-200
17.1 to 38kV
Curve: 200 SE
Curve #: 36-643
Reference: 667029; 667026
Created: 12/16/2009
FP5000-GFLAT
Cutler-Hammer FP-5000 Relay
Thermal Ground Flat curve
A1=5, A2=0, A3=0
B1=0, B2=0, B3=0
Created 09/30/2005
FP5000-GI2T
Thermal Ground I2T curve
A1=5, A2=0, A3=0
B1=0, B2=2, B3=0
Created 09/30/2005
FP5000-GI4T
Thermal Ground I4T curve
A1=5, A2=0, A3=0
B1=0, B2=4, B3=0
Created 09/30/2005
FP5000-GIT
Thermal Ground IT curve
A1=5, A2=0, A3=0
B1=0, B2=1, B3=0
Created 09/30/2005
FP5000-PFLAT
Thermal Phase FLAT curve
A1=5, A2=0, A3=0
B1=0, B2=0, B3=0
Created 09/30/2005
FP5000-PI2T
Thermal Phase I2T curve
A1=45, A2=0, A3=0
B1=0, B2=2, B3=0
Created 09/30/2005
FP5000-PI4T
Thermal Phase I4T curve
A1=405, A2=0, A3=0
B1=0, B2=4, B3=0
Created 09/30/2005
FP5000-PIT
Thermal Phase IT curve
A1=15, A2=0, A3=0
B1=0, B2=1, B3=0
Created 09/30/2005
FP5000ANS-EI
ANSI Extremely Inverse curves
A1=28.2, A2=0.1217, A3=0
B1=0, B2=2, B3=-1
Created 09/30/2005

FP5000ANS-MI
ANSI Moderate Inverse curves
A1=0.0515, A2=0.114, A3=0
B1=0, B2=0.02, B3=-1
Created 09/30/2005
FP5000ANS-VI
ANSI Very Inverse curves
A1=19.61, A2=0.491, A3=0
B1=0, B2=2, B3=-1
Created 09/30/2005
FP5000IEC-A
IEC-A curves
A1=0.14, A2=0, A3=0
B1=0, B2=0.02, B3=-1
Created 09/30/2005
FP5000IEC-B
IEC-A curves
A1=13.5, A2=0, A3=0
B1=0, B2=1, B3=-1
Created 09/30/2005
FP5000IEC-C
IEC-C curves
A1=80, A2=0, A3=0
B1=0, B2=2, B3=-1
Created 09/30/2005
RBA400-200E
Cutler-Hammer Type RBA-RDB-400 refill Power Fuse. Standard speed refill
s 2.4 to 34.5 kV.
Curver 200E, drawing 36-365 #5 and #6
Created 2004-09-08
RBA400-250E
s 2.4 to 34.5 kV.
Created 2004-09-08
RBA400-300
s 2.4 to 34.5 kV.
Created 2004-09-08
RBA400-400E
s 2.4 to 34.5 kV.
Created 2004-09-08
RBA400-250L
Cutler-Hammer Type RBA-RDB-400 refill Power Fuse. Time Lag refills 2.4
to 34.5 kV.
Created 2004-09-08
RBA400-300L
to 34.5 kV.
Created 2004-09-08
RBA400-400L
to 34.5 kV.
Created 2004-09-08
RBA4S-100E
Cuttler-Hammer RBA-RDB-400 Refill Power Fuses 2.4 to 34.5kV
Curve 36-635#6

Reference #628861, April 1999
Curve 100E
Created 12-08-2003
RBA4S-10E
Curve 10E
Created 12-08-2003
RBA4S-125E
Curve 36-635#6
Curve 125E
Created 12-08-2003
RBA4S-150E
Curve 36-635#6
Curve 150E
Created 12-08-2003
RBA4S-15E
Curve 36-635#6
Curve 15E
Created 12-08-2003
RBA4S-200E
Curve 36-635#6
Curve 200E
Created 12-08-2003
RBA4S-20E
Curve 36-635#6
Curve 20E
Created 12-08-2003
RBA4S-250E
Curve 36-635#6
Curve 250E
Created 12-08-2003
RBA4S-25E
Curve 36-635#6
Curve 25E
Created 12-08-2003
RBA4S-300E
Curve 36-635#6
Curve 300E
Created 12-08-2003
RBA4S-30E
Curve 36-635#6
Curve 30E
Created 12-08-2003
RBA4S-3E
Curve 36-635#6
Curve 3E
Created 12-08-2003

RBA4S-400E
Curve 36-635#6
Curve 400E
Created 12-08-2003
RBA4S-40E
Curve 36-635#6
Curve 40E
Created 12-08-2003
RBA4S-50E
Curve 36-635#6
Curve 50E
Created 12-08-2003
RBA4S-5E
Curve 36-635#6
Curve 5E
Created 12-08-2003
RBA4S-65E
Curve 36-635#6
Curve 65E
Created 12-08-2003
RBA4S-7E
Curve 36-635#6
Curve 7E
Created 12-08-2003
RBA4S-80E
Curve 36-635#6
Curve 80E
Created 12-08-2003
RBA800-250E
s 2.4 to 34.5 kV.
Created 9/8/2004
RBA800-300E
s 2.4 to 34.5 kV.
Created 9/8/2004
RBA800-400E
s 2.4 to 34.5 kV.
Created 9/8/2004
RBA800L-400
Cutler-Hammer Type RBA-RDB-800 refill Power Fuse. Time-lag refills 2.4 to 34.5 kV.
Curver 2x400E.
Refference#: 667009
Created 5/14/2007
SC-6912_MAX
Series C Molded case circuit breakers. M-Frame 300-800 Apms.
Types MDL, HMDL, MDLB & HMDLB
Maximum curve.
Ref. curve #: SC-6912-98

SC-6912_MIN
Series C Molded case circuit breakers. M-Frame 300-800 Apms.
Types MDL, HMDL, MDLB & HMDLB
Ref. curve #: SC-6912-98
Created 12/06/2005
SC4423-100MA
Cuttler-Hammer AB DE-ION Circuit Breaker
Types EHD, FDB, FD 100 Apms
Curve 100A Max
Create 09/15/2008
SC4423-100MI
Curve 100A Min
Create 09/15/2008
SC4423-15MAX
Types EHD, FDB, FD 15Apms
Curve 15A Max
Create 09/15/2008
SC4423-25MAX
Curve 25A Max
Create 09/15/2008
SC4423-25MIN
Types EHD, FDB, FD 25Apms
Curve 25A min
Create 09/15/2008
SC4423-30MAX
Curve 30A Max
Create 09/15/2008
SC4423-30MIN
Curve 30A Min
Create 09/15/2008
SC4423-40MAX
Curve 40A Max
Create 09/15/2008
SC4423-60MAX
Curve 60A Max
Create 09/15/2008
SC4423-60MIN
Curve 60A Min
Create 09/15/2008
SC4423-A5MIN
Curve 15A Min
Create 09/15/2008
SC5390-92B
Cutler-Hammer Eaton
Inverse Time over current phase, I4T curves (SC-5390-92B)
For DT 3100 & DT 3101
Created 03/20/2009

ELASTIMOLD.RLY
This file contains Elastimold fuse curves.
280ARX-120
Elastimold Cooper 280ARX Relay, 30-600A
Curve 120, draw number: MVI-TCC-13
Created 03/26/2009
280ARX-150
Created 03/26/2009
280ARX-200
Created 03/26/2009
280ARX-250
Created 03/26/2009
280ARX-30
Created 03/26/2009
280ARX-350
Created 03/26/2009
280ARX-40
Created 03/26/2009
280ARX-450
Created 03/26/2009
280ARX-50
Created 03/26/2009
280ARX-600
Created 03/26/2009
280ARX-70
Created 03/26/2009
280ARX-90
Created 03/26/2009
CooperEF-120
Elastimold Cooper EF Relay, 30-600A
Created 2003-10-29
CooperEF-150
Created 2003-10-29
CooperEF-200
Created 2003-10-29

CooperEF-250
Created 2003-10-29
CooperEF-350
Created 2003-10-29
CooperEF-40
Elastimond Cooper EF Relay, 30-600A
Created 2003-10-29
CooperEF-450
Created 2003-10-29
CooperEF-50
Created 2003-10-29
CooperEF-600
Created 2003-10-29
CooperEF-70
Created 2003-10-29
CooperEF-90
Created 2003-10-29
CooperEF_30
Created 2003-10-29
CO-11-1-120
Elastimold CO-11-1 Relay, 30-600A
Created 03/26/2009
CO-11-1-150
Created 03/26/2009
CO-11-1-200
Created 03/26/2009
CO-11-1-250
Created 03/26/2009
CO-11-1-30
Created 03/26/2009
CO-11-1-350
Created 03/26/2009
CO-11-1-40
Created 03/26/2009
CO-11-1-450

Created 03/26/2009
CO-11-1-50
Created 03/26/2009
CO-11-1-600
Created 03/26/2009
CO-11-1-70
Created 03/26/2009
CO-11-1-90
Created 03/26/2009
CO-11-2-120
Created 03/26/2009
CO-11-2-150
Created 03/26/2009
CO-11-2-200
Created 03/26/2009
CO-11-2-250
Created 03/26/2009
CO-11-2-30
Created 03/26/2009
CO-11-2-350
Created 03/26/2009
CO-11-2-40
Created 03/26/2009
CO-11-2-450
Created 03/26/2009
CO-11-2-50
Created 03/26/2009
CO-11-2-600
Created 03/26/2009
CO-11-2-70
Created 03/26/2009
CO-11-2-90
Created 03/26/2009

CO-9-1-120
Created 03/26/2009
CO-9-1-150
Created 03/26/2009
CO-9-1-200
Created 03/26/2009
CO-9-1-250
Created 03/26/2009
CO-9-1-30
Created 03/26/2009
CO-9-1-350
Created 03/26/2009
CO-9-1-40
Created 03/26/2009
CO-9-1-450
Created 03/26/2009
CO-9-1-50
Created 03/26/2009
CO-9-1-600
Created 03/26/2009
CO-9-1-70
Created 03/26/2009
CO-9-1-90
Created 03/26/2009
CO-9-2-120
Created 03/26/2009
CO-9-2-150
Created 03/26/2009
CO-9-2-200
Created 03/26/2009
CO-9-2-250
Created 03/26/2009
CO-9-2-30

Created 03/26/2009
CO-9-2-350
Created 03/26/2009
CO-9-2-40
Created 03/26/2009
CO-9-2-450
Created 03/26/2009
CO-9-2-50
Created 03/26/2009
CO-9-2-600
Created 03/26/2009
CO-9-2-70
Created 03/26/2009
CO-9-2-90
Created 03/26/2009
E_Std-120
Elastimold E standard Relay, 30-600A
Created 2003-10-29
E_Std-150
Created 2003-10-29
E_Std-200
Created 2003-10-29
E_Std-250
Created 2003-10-29
E_Std-30
Created 2003-10-29
E_Std-350
Created 2003-10-29
E_Std-40
Created 2003-10-29
E_Std-450
Created 2003-10-29
E_Std-50
Created 2003-10-29

E_Std-600
Created 2003-10-29
E_Std-70
Created 2003-10-29
E_Std-90
Created 2003-10-29
EFX-006
Elastimold Fused Elbow, Current-
Limiting Fuse, Type EFX.
6 Amps
Model Numbers: EFX08306-E & EFX17206-E
Drawing No. FC-084
Created 2005/05/17
EFX-008
8 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-010
10 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-012
12 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-018
18 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-020
20 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-025
25 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-030
30 Amps
Drawing No. FC-084
Created 2005/05/17

EFX-040
40 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-045
45 Amps
Drawing No. FC-084
Created 2005/05/17
EFX-065
65 Amps
Created 2008/02/28
EFX-080
80 Amps
Created 2008/02/28
ESLOW-010
Elastimold E Slow Fuse, 10-200A
Created 03/26/2009
ESLOW-020
Created 03/26/2009
ESLOW-030
Created 03/26/2009
ESLOW-040
Created 03/26/2009
ESLOW-050
Created 03/26/2009
ESLOW-065
Created 03/26/2009
ESLOW-080
Created 03/26/2009
ESLOW-100
Created 03/26/2009
ESLOW-125
Created 03/26/2009
ESLOW-150
Created 03/26/2009

ESLOW-175
Created 03/26/2009
ESLOW-200
Created 03/26/2009
F-120
Elastimold F Relay, 30-600A
Created 03/26/2009
F-150
Created 03/26/2009
F-200
Created 03/26/2009
F-250
Created 03/26/2009
F-30
Created 03/26/2009
F-350
Created 03/26/2009
F-40
Created 03/26/2009
F-450
Created 03/26/2009
F-50
Created 03/26/2009
F-600
Created 03/26/2009
F-70
Created 03/26/2009
F-90
Created 03/26/2009
GE-120
Elastimold GE Relay, 30-600A
Created 03/26/2009
GE-150
Created 03/26/2009
GE-200

Created 03/26/2009
GE-250
Created 03/26/2009
GE-30
Created 03/26/2009
GE-350
Created 03/26/2009
GE-40
Created 03/26/2009
GE-450
Created 03/26/2009
GE-50
Created 03/26/2009
GE-600
Created 03/26/2009
GE-70
Created 03/26/2009
GE-90
Created 03/26/2009
K_Fuse-10
Elastimold K-Fuse, 10-200A
Created 2004-5-17
K_Fuse-100
Created 2004-5-17
K_Fuse-125
Created 2004-5-17
K_Fuse-150
Created 2004-5-17
K_Fuse-20
Created 2004-5-17
K_Fuse-200
Created 2004-5-17
K_Fuse-30
Created 2004-5-17

K_Fuse-40
Created 2004-5-17
K_Fuse-50
Created 2004-5-17
K_Fuse-65
Created 2004-5-17
K_Fuse-80
Created 2004-5-17
K_Relay-030
Elastimold MVI Fault Interrupter K-Relay 30-600 Amps.
Curve 30 Amps
Ref. Number: MVI-TCC-04
Created 12/07/2006
K_Relay-040
Curve 40 Amps
Created 12/07/2006
K_Relay-050
Curve 50 Amps
Created 12/07/2006
K_Relay-070
Curve 70 Amps
Created 12/07/2006
K_Relay-090
Curve 90 Amps
Created 12/07/2006
K_Relay-120
Curve 1200 Amps
Created 12/07/2006
K_Relay-150
Curve 150 Amps
Created 12/07/2006
K_Relay-200
Curve 200 Amps
Created 12/07/2006
K_Relay-250
Curve 250 Amps
Created 12/07/2006
K_Relay-350
Curve 350 Amps
Created 12/07/2006

K_Relay-450
Curve 450 Amps
Created 12/07/2006
K_Relay-600
Curve 600 Amps
Created 12/07/2006
KQA-Fuse-20
Elastimold Kearney QA Fuse, 10-200A
Created 2003-10-29
KQA_Fuse-10
Created 2003-10-29
KQA_Fuse-100
Created 2003-10-29
KQA_Fuse-125
Created 2003-10-29
KQA_Fuse-150
Created 2003-10-29
KQA_Fuse-175
Created 2003-10-29
KQA_Fuse-200
Created 2003-10-29
KQA_Fuse-30
Created 2003-10-29
KQA_Fuse-40
Created 2003-10-29
KQA_Fuse-50
Created 2003-10-29
KQA_Fuse-65
Created 2003-10-29
KQA_Fuse-80
Created 2003-10-29
KS-120
Elastimold Kearney KS Relay, 30-600A
Updated 4/1/2010
KS-150
Updated 4/1/2010

KS-200
Updated 4/1/2010
KS-250
Updated 4/1/2010
KS-30
Updated 4/1/2010
KS-350
Updated 4/1/2010
KS-40
Updated 4/1/2010
KS-450
Updated 4/1/2010
KS-50
Updated 4/1/2010
KS-600
Updated 4/1/2010
KS-70
Updated 4/1/2010
KS-90
Updated 4/1/2010
MVI_DW-010
Custom curve for Elastimold D&W for DMI
10Amps
Created 02/29/2008
MVI_DW-015
Custom curve for Elastimold D&W for DMI
15Amps
Created 02/29/2008
MVI_DW-020
Custom curve for Elastimold D&W for MVI
20Amps
Created 02/29/2008
MVI_DW-025
25 Amps
Created 02/29/2008
MVI_DW-030
30 Amps
Created 02/29/2008
MVI_DW-040
40 Amps
Created 02/29/2008
MVI_DW-050

50 Amps
Created 02/29/2008
MVI_DW-065
65 Amps
Created 02/29/2008
MVI_DW-075
75 Amps
Created 02/29/2008
MVI_DW-100
100 Amps
Created 02/29/2008
MVI_DW-125
125 Amps
Created 02/29/2008
MVI_DW-150
150 Amps
Created 02/29/2008
OILFUSE-010
Elastimold Oil Fuse Cut Out, 10-200A
Created 03/26/2009
OILFUSE-020
Created 03/26/2009
OILFUSE-030
Created 03/26/2009
OILFUSE-040
Created 03/26/2009
OILFUSE-050
Created 03/26/2009
OILFUSE-065
Created 03/26/2009
OILFUSE-080
Created 03/26/2009
OILFUSE-100
Created 03/26/2009
OILFUSE-125
Created 03/26/2009
OILFUSE-150
Created 03/26/2009
OILFUSE-175
Created 03/26/2009

OILFUSE-200
Created 03/26/2009
OILRELAY-120
Elastimold Oil Fuse Cutout Relay, 30-600A
Created 2009-03-27
OILRELAY-150
Created 2009-03-27
OILRELAY-200
Created 2009-03-27
OILRELAY-250
Created 2009-03-27
OILRELAY-30
Created 2009-03-27
OILRELAY-350
Created 2009-03-27
OILRELAY-40
Created 2009-03-27
OILRELAY-450
Created 2009-03-27
OILRELAY-50
Created 2009-03-27
OILRELAY-600
Created 2009-03-27
OILRELAY-70
Created 2009-03-27
OILRELAY-90
Created 2009-03-27
RLYESLOW-120
Elastimold E Slow Relay, 30-600A
Created 2009-03-27
RLYESLOW-150
Created 2009-03-27
RLYESLOW-200
Created 2009-03-27
RLYESLOW-250

Created 2009-03-27
RLYESLOW-30
Created 2009-03-27
RLYESLOW-350
Created 2009-03-27
RLYESLOW-40
Created 2009-03-27
RLYESLOW-450
Created 2009-03-27
RLYESLOW-50
Created 2009-03-27
RLYESLOW-600
Created 2009-03-27
RLYESLOW-70
Created 2009-03-27
RLYESLOW-90
Created 2009-03-27
Std_Fuse-10
Elastimold E Standard Fuse, 10-200A
Created 2003-10-29
Std_Fuse-100
Created 2003-10-29
Std_Fuse-125
Created 2003-10-29
Std_Fuse-175
Created 2003-10-29
Std_Fuse-20
Created 2003-10-29
Std_Fuse-200
Created 2003-10-29
Std_Fuse-30
Created 2003-10-29
Std_Fuse-40
Created 2003-10-29

Std_Fuse-50
Created 2003-10-29
Std_Fuse-65
Created 2003-10-29
Std_Fuse-80
Created 2003-10-29
Std_Fuse150
Created 2003-10-29
T_RLY-120
Elastimold T Relay, 30-600A
Created 2009-03-27
T_RLY-150
Created 2009-03-27
T_RLY-200
Created 2009-03-27
T_RLY-250
Created 2009-03-27
T_RLY-30
Created 2009-03-27
T_RLY-350
Created 2009-03-27
T_RLY-40
Created 2009-03-27
T_RLY-450
Created 2009-03-27
T_RLY-50
Created 2009-03-27
T_RLY-600
Created 2009-03-27
T_RLY-70
Created 2009-03-27
T_RLY-90
Created 2009-03-27
TFUSE-010
Elastimold T Fuse, 10-200A

Created 03/26/2009
TFUSE-020
Created 03/26/2009
TFUSE-030
Created 03/26/2009
TFUSE-040
Created 03/26/2009
TFUSE-050
Created 03/26/2009
TFUSE-065
Created 03/26/2009
TFUSE-080
Created 03/26/2009
TFUSE-100
Created 03/26/2009
TFUSE-125
Created 03/26/2009
TFUSE-150
Created 03/26/2009
TFUSE-175
Created 03/26/2009
TFUSE-200
Created 03/26/2009

ELECTROFUSI.RLY
This file contains ELECTROFUSI fuse curves.
EF-H-1
ElectroFusi High Surge Type H
Curve 1H, TCC28-01, August 1996
Created 12/16/2002
EF-H-1_2
Curve 1/2H, TCC28-01, August 1996
Created 12/16/2002
EF-H-2
Curve2H, TCC28-01, August 1996
Created 12/16/2002
EF-H-3
Created 12/16/2002
EF-H-5
Created 12/16/2002
EF-K-1-2
ElectroFusi High Surge Type K
Curve 1K, TCC28-01, August 1996
Created 12/16/2002
EF-K-10
Created 12/16/2002
EF-K-100
Created 12/16/2002
EF-K-12
Created 12/16/2002
EF-K-140
Created 12/16/2002
EF-K-15
Created 12/16/2002
EF-K-2
Created 12/16/2002
EF-K-20
Created 12/16/2002
EF-K-200
Created 12/16/2002
EF-K-25
Created 12/16/2002

EF-K-30
Created 12/16/2002
EF-K-40
Created 12/16/2002
EF-K-5
Created 12/16/2002
EF-K-50
Created 12/16/2002
EF-K-6
Created 12/16/2002
EF-K-65
Created 12/16/2002
EF-K-8
Created 12/16/2002
EF-K-80
Created 12/16/2002
EF-T-1
ElectroFusi High Surge Type T
Curve 1T, TCC28-03, August 1996
Created 12/16/2002
EF-T-10
Created 12/16/2002
EF-T-100
Created 12/16/2002
EF-T-12
Created 12/16/2002
EF-T-140
Created 12/16/2002
EF-T-15
Created 12/16/2002
EF-T-2
Created 12/16/2002
EF-T-20
Created 12/16/2002
EF-T-200

Created 12/16/2002
EF-T-25
Created 12/16/2002
EF-T-3
Created 12/16/2002
EF-T-30
Created 12/16/2002
EF-T-40
Created 12/16/2002
EF-T-5
Created 12/16/2002
EF-T-50
Created 12/16/2002
EF-T-6
Created 12/16/2002
EF-T-65
Created 12/16/2002
EF-T-8
Created 12/16/2002
EF-T-80
Created 12/16/2002
FE-K-3
Created 12/16/2002

FEDERAL_PIONEER.RLY
This file contains Federal Pioneer Ltd. relay curves.
MGFR-20
Federal Pioneer Limited Microprocessor Ground Fault Relay: MGFR-20.
T = 91.2011*D/M**1.96 1.2<M<10
Created 11/28/95.
MGFR-200
Federal Pioneer Limited Microprocessor Ground Fault Relay: MGFR-200.
T = 91.2011*D/M**1.96 1.2<M<10
Created 11/28/95.
SD-GF
Federal Pioneer Limited SD relay, Ground fault curves, C-3-286.
Created 10/25/94.
SD-LT
Federal Pioneer Limited SD relay, Long time curves, C-3-286,
Created 10/25/94.
SD-ST
Federal Pioneer Limited SD relay, Short time curves, C-3-286,
Created 10/25/94.
USD-20-GF
Federal Pioneer Solid State Relay USD-20
Ground fault curves. 132-054B Rev. 1
IMPORTANT: X axis has been shifted by factor of 10.
Created 01/21/2003
USD-20-LT
Long time curves
132-054B Rev. 1
Created 01/21/2003
USD-20-ST
Short time curves
132-054B Rev. 1
Created 01/21/2003

FUJI.RLY
This file contains Fuji curves.
AI8R
Fuji Over-Current Relay AI8R-01
Time dial: 0.5 - 10.0
Created 07/07/2008
CH1-53A
Fuji Over-Current Relay CH1-53a, CH2-53a
Time dial: 0.5 - 10
Created 07/07/2008
CH2-63A
Fuji Over-Current Relay CH2-63a, CH2-53a
Time dial: 0.5 - 10
Created 07/07/2008
CO3-53A
Fuji Over-Current Relay CO3-53a, CO3-63a
Time dial: 0.5 - 10
Created 07/07/2008
DQAJB1HC
Fuji Over-Current Relay DQAJB1HC, DQAJB1HJ
Time dial: 0.5 - 10
Created 07/07/2008
DQASD4MH
Fuji Over-Current Relay DQASD4MH
Time dial: 0.5 - 10
Created 07/07/2008
FRAS1
Fuji Over-Current Relay FRAS1
Time dial: 0.5 - 10.0
Created 07/07/2008
QH-OC1
Fuji Over-Current Relay QH-OC1, QH-OC2
Time dial: 0.5 - 10
Created 07/07/2008

G&W_ELECTRIC.RLY
This file contains G&W Electric interrupter curves.
15-300.5_100
G&W Electric Co. CO-8 Relay Curve
Time dial: .5; Setting: 15-300A; Curve: 100
Created: 03/21/2005
15-300.5_125
Created: 03/21/2005
15-300.5_15
Created: 03/21/2005
15-300.5_175
Created: 03/21/2005
15-300.5_20
Created: 03/21/2005
15-300.5_225
Created: 03/21/2005
15-300.5_25
Created: 03/21/2005
15-300.5_300
Created: 03/21/2005
15-300.5_35
Created: 03/21/2005
15-300.5_45
Created: 03/21/2005
15-300.5_60
Created: 03/21/2005
15-300.5_75
Created: 03/21/2005
15-3001_100
Time dial: 1; Setting: 15-300A; Curve: 100
Created: 03/21/2005
15-3001_125
Created: 03/21/2005
15-3001_15
Created: 03/21/2005

15-3001_175
Created: 03/21/2005
15-3001_20
Created: 03/21/2005
15-3001_225
Created: 03/21/2005
15-3001_25
Created: 03/21/2005
15-3001_300
Created: 03/21/2005
15-3001_35
Created: 03/21/2005
15-3001_45
Created: 03/21/2005
15-3001_60
Created: 03/21/2005
15-3001_75
Created: 03/21/2005
15-30010_100
Created: 03/21/2005
15-30010_125
Created: 03/21/2005
15-30010_15
Created: 03/21/2005
15-30010_175
Created: 03/21/2005
15-30010_20
Created: 03/21/2005
15-30010_225
Created: 03/21/2005
15-30010_25
Created: 03/21/2005
15-30010_300

Created: 03/21/2005
15-30010_35
Created: 03/21/2005
15-30010_45
Created: 03/21/2005
15-30010_60
Created: 03/21/2005
15-30010_75
Created: 03/21/2005
15-30011_100
Created: 03/21/2005
15-30011_125
Created: 03/21/2005
15-30011_15
Created: 03/21/2005
15-30011_175
Created: 03/21/2005
15-30011_20
Created: 03/21/2005
15-30011_225
Created: 03/21/2005
15-30011_25
Created: 03/21/2005
15-30011_300
Created: 03/21/2005
15-30011_35
Created: 03/21/2005
15-30011_45
Created: 03/21/2005
15-30011_60
Created: 03/21/2005
15-30011_75
Created: 03/21/2005

15-3002_100
Created: 03/21/2005
15-3002_125
Created: 03/21/2005
15-3002_15
Created: 03/21/2005
15-3002_175
Created: 03/21/2005
15-3002_20
Created: 03/21/2005
15-3002_225
Created: 03/21/2005
15-3002_25
Created: 03/21/2005
15-3002_300
Created: 03/21/2005
15-3002_35
Created: 03/21/2005
15-3002_45
Created: 03/21/2005
15-3002_60
Created: 03/21/2005
15-3002_75
Created: 03/21/2005
15-3003_100
Created: 03/21/2005
15-3003_125
Created: 03/21/2005
15-3003_15
Created: 03/21/2005
15-3003_175
Created: 03/21/2005
15-3003_20

Created: 03/21/2005
15-3003_225
Created: 03/21/2005
15-3003_25
Created: 03/21/2005
15-3003_300
Created: 03/21/2005
15-3003_35
Created: 03/21/2005
15-3003_45
Created: 03/21/2005
15-3003_60
Created: 03/21/2005
15-3003_75
Created: 03/21/2005
15-3004_100
Created: 03/21/2005
15-3004_125
Created: 03/21/2005
15-3004_15
Created: 03/21/2005
15-3004_175
Created: 03/21/2005
15-3004_20
Created: 03/21/2005
15-3004_225
Created: 03/21/2005
15-3004_25
Created: 03/21/2005
15-3004_300
Created: 03/21/2005
15-3004_35
Created: 03/21/2005

15-3004_45
Created: 03/21/2005
15-3004_60
Created: 03/21/2005
15-3004_75
Created: 03/21/2005
15-3005_100
Created: 03/21/2005
15-3005_125
Created: 03/21/2005
15-3005_15
Created: 03/21/2005
15-3005_175
Created: 03/21/2005
15-3005_20
Created: 03/21/2005
15-3005_225
Created: 03/21/2005
15-3005_25
Created: 03/21/2005
15-3005_300
Created: 03/21/2005
15-3005_35
Created: 03/21/2005
15-3005_45
Created: 03/21/2005
15-3005_60
Created: 03/21/2005
15-3005_75
Created: 03/21/2005
15-3006_100
Created: 03/21/2005
15-3006_125

Created: 03/21/2005
15-3006_15
Created: 03/21/2005
15-3006_175
Created: 03/21/2005
15-3006_20
Created: 03/21/2005
15-3006_225
Created: 03/21/2005
15-3006_25
Created: 03/21/2005
15-3006_300
Created: 03/21/2005
15-3006_35
Created: 03/21/2005
15-3006_45
Created: 03/21/2005
15-3006_60
Created: 03/21/2005
15-3006_75
Created: 03/21/2005
15-3007_100
Created: 03/21/2005
15-3007_125
Created: 03/21/2005
15-3007_15
Created: 03/21/2005
15-3007_175
Created: 03/21/2005
15-3007_20
Created: 03/21/2005
15-3007_225
Created: 03/21/2005

15-3007_25
Created: 03/21/2005
15-3007_300
Created: 03/21/2005
15-3007_35
Created: 03/21/2005
15-3007_45
Created: 03/21/2005
15-3007_60
Created: 03/21/2005
15-3007_75
Created: 03/21/2005
15-3008_100
Created: 03/21/2005
15-3008_125
Created: 03/21/2005
15-3008_15
Created: 03/21/2005
15-3008_175
Created: 03/21/2005
15-3008_20
Created: 03/21/2005
15-3008_225
Created: 03/21/2005
15-3008_25
Created: 03/21/2005
15-3008_300
Created: 03/21/2005
15-3008_35
Created: 03/21/2005
15-3008_45
Created: 03/21/2005
15-3008_60

Created: 03/21/2005
15-3008_75
Created: 03/21/2005
15-3009_100
Created: 03/21/2005
15-3009_125
Created: 03/21/2005
15-3009_15
Created: 03/21/2005
15-3009_175
Created: 03/21/2005
15-3009_20
Created: 03/21/2005
15-3009_225
Created: 03/21/2005
15-3009_25
Created: 03/21/2005
15-3009_300
Created: 03/21/2005
15-3009_35
Created: 03/21/2005
15-3009_45
Created: 03/21/2005
15-3009_60
Created: 03/21/2005
15-3009_75
Created: 03/21/2005
280ARX-015
G&W Electric Co. Vacuum Interrupter 280ARX setting 15-300A.
Curve 15
Created 02/17/2009
280ARX-020
Curve 20
Created 02/17/2009
280ARX-030
Curve 30
Created 02/16/2009

280ARX-035
Curve 35
Created 02/17/2009
280ARX-040
Curve 40
Created 02/16/2009
280ARX-045
Curve 45
Created 02/17/2009
280ARX-050
Curve 50
Created 02/16/2009
280ARX-060
Curve 60
Created 02/17/2009
280ARX-070
Curve 70
Created 02/16/2009
280ARX-075
Curve 75
Created 02/17/2009
280ARX-090
Curve 90
Created 02/16/2009
280ARX-100
Curve 100
Created 02/17/2009
280ARX-120
Curve 120
Created 02/16/2009
280ARX-125
Curve 125
Created 02/17/2009
280ARX-150
Curve 150
Created 02/16/2009
280ARX-175
Curve 175
Created 02/17/2009
280ARX-200
Curve 200
Created 02/16/2009
280ARX-225
Curve 225
Created 02/17/2009
280ARX-300
Curve 300
Created 02/17/2009
280ARX-025

Curve 25
Created 02/17/2009
280ARX-250
Curve 250
Created 02/16/2009
280ARX-350
Curve 350
Created 02/16/2009
280ARX-450
Curve 450
Created 02/16/2009
280ARX-600
Curve 600
Created 02/16/2009
30-600.5_120
Created: 03/21/2005
30-600.5_150
Created: 03/21/2005
30-600.5_200
Created: 03/21/2005
30-600.5_250
Created: 03/21/2005
30-600.5_30
Created: 03/21/2005
30-600.5_350
Created: 03/21/2005
30-600.5_40
Created: 03/21/2005
30-600.5_450
Created: 03/21/2005
30-600.5_50
Created: 03/21/2005
30-600.5_600
Created: 03/21/2005
30-600.5_70
Created: 03/21/2005
30-600.5_90
Created: 03/21/2005

30-6001_120
Created: 03/21/2005
30-6001_150
Created: 03/21/2005
30-6001_200
Created: 03/21/2005
30-6001_250
Created: 03/21/2005
30-6001_30
Created: 03/21/2005
30-6001_350
Created: 03/21/2005
30-6001_40
Created: 03/21/2005
30-6001_450
Created: 03/21/2005
30-6001_50
Created: 03/21/2005
30-6001_600
Created: 03/21/2005
30-6001_70
Created: 03/21/2005
30-6001_90
Created: 03/21/2005
30-60010_120
Created: 03/21/2005
30-60010_150
Created: 03/21/2005
30-60010_200
Created: 03/21/2005
30-60010_250
Created: 03/21/2005
30-60010_30

Created: 03/21/2005
30-60010_350
Created: 03/21/2005
30-60010_40
Created: 03/21/2005
30-60010_450
Created: 03/21/2005
30-60010_50
Created: 03/21/2005
30-60010_600
Created: 03/21/2005
30-60010_70
Created: 03/21/2005
30-60010_90
Created: 03/21/2005
30-60011_120
Created: 03/21/2005
30-60011_150
Created: 03/21/2005
30-60011_200
Created: 03/21/2005
30-60011_250
Created: 03/21/2005
30-60011_30
Created: 03/21/2005
30-60011_350
Created: 03/21/2005
30-60011_40
Created: 03/21/2005
30-60011_450
Created: 03/21/2005
30-60011_50
Created: 03/21/2005

30-60011_600
Created: 03/21/2005
30-60011_70
Created: 03/21/2005
30-60011_90
Created: 03/21/2005
30-6002_120
Created: 03/21/2005
30-6002_150
Created: 03/21/2005
30-6002_200
Created: 03/21/2005
30-6002_250
Created: 03/21/2005
30-6002_30
Created: 03/21/2005
30-6002_350
Created: 03/21/2005
30-6002_40
Created: 03/21/2005
30-6002_450
Created: 03/21/2005
30-6002_50
Created: 03/21/2005
30-6002_600
Created: 03/21/2005
30-6002_70
Created: 03/21/2005
30-6002_90
Created: 03/21/2005
30-6003_120
Created: 03/21/2005
30-6003_150

Created: 03/21/2005
30-6003_200
Created: 03/21/2005
30-6003_250
Created: 03/21/2005
30-6003_30
Created: 03/21/2005
30-6003_350
Created: 03/21/2005
30-6003_40
Created: 03/21/2005
30-6003_450
Created: 03/21/2005
30-6003_50
Created: 03/21/2005
30-6003_600
Created: 03/21/2005
30-6003_70
Created: 03/21/2005
30-6003_90
Created: 03/21/2005
30-6004_120
Created: 03/21/2005
30-6004_150
Created: 03/21/2005
30-6004_200
Created: 03/21/2005
30-6004_250
Created: 03/21/2005
30-6004_30
Created: 03/21/2005
30-6004_350
Created: 03/21/2005

30-6004_40
Created: 03/21/2005
30-6004_450
Created: 03/21/2005
30-6004_50
Created: 03/21/2005
30-6004_600
Created: 03/21/2005
30-6004_70
Created: 03/21/2005
30-6004_90
Created: 03/21/2005
30-6005_120
Created: 03/21/2005
30-6005_150
Created: 03/21/2005
30-6005_200
Created: 03/21/2005
30-6005_250
Created: 03/21/2005
30-6005_30
Created: 03/21/2005
30-6005_350
Created: 03/21/2005
30-6005_40
Created: 03/21/2005
30-6005_450
Created: 03/21/2005
30-6005_50
Created: 03/21/2005
30-6005_600
Created: 03/21/2005
30-6005_70

Created: 03/21/2005
30-6005_90
Created: 03/21/2005
30-6006_120
Created: 03/21/2005
30-6006_150
Created: 03/21/2005
30-6006_200
Created: 03/21/2005
30-6006_250
Created: 03/21/2005
30-6006_30
Created: 03/21/2005
30-6006_350
Created: 03/21/2005
30-6006_40
Created: 03/21/2005
30-6006_450
Created: 03/21/2005
30-6006_50
Created: 03/21/2005
30-6006_600
Created: 03/21/2005
30-6006_70
Created: 03/21/2005
30-6006_90
Created: 03/21/2005
30-6007_120
Created: 03/21/2005
30-6007_150
Created: 03/21/2005
30-6007_200
Created: 03/21/2005

30-6007_250
Created: 03/21/2005
30-6007_30
Created: 03/21/2005
30-6007_350
Created: 03/21/2005
30-6007_40
Created: 03/21/2005
30-6007_450
Created: 03/21/2005
30-6007_50
Created: 03/21/2005
30-6007_600
Created: 03/21/2005
30-6007_70
Created: 03/21/2005
30-6007_90
Created: 03/21/2005
30-6008_120
Created: 03/21/2005
30-6008_150
Created: 03/21/2005
30-6008_200
Created: 03/21/2005
30-6008_250
Created: 03/21/2005
30-6008_30
Created: 03/21/2005
30-6008_350
Created: 03/21/2005
30-6008_40
Created: 03/21/2005
30-6008_450

Created: 03/21/2005
30-6008_50
Created: 03/21/2005
30-6008_600
Created: 03/21/2005
30-6008_70
Created: 03/21/2005
30-6008_90
Created: 03/21/2005
30-6009_120
Created: 03/21/2005
30-6009_150
Created: 03/21/2005
30-6009_200
Created: 03/21/2005
30-6009_250
Created: 03/21/2005
30-6009_30
Created: 03/21/2005
30-6009_350
Created: 03/21/2005
30-6009_40
Created: 03/21/2005
30-6009_450
Created: 03/21/2005
30-6009_50
Created: 03/21/2005
30-6009_600
Created: 03/21/2005
30-6009_70
Created: 03/21/2005
30-6009_90
Created: 03/21/2005

CENT_A-030
G&W Electric Co. Vacuum Interrupter CENTERIOR A setting 30-600A.
Curve 30
Created 02/18/2009
CENT_A-040
Curve 40
Created 02/18/2009
CENT_A-050
Curve 50
Created 02/18/2009
CENT_A-070
Curve 70
Created 02/18/2009
CENT_A-090
Curve 90
Created 02/18/2009
CENT_A-120
Curve 120
Created 02/18/2009
CENT_A-150
Curve 150
Created 02/18/2009
CENT_A-200
Curve 200
Created 02/18/2009
CENT_A-250
Curve 250
Created 02/18/2009
CENT_A-350
Curve 350
Created 02/18/2009
CENT_A-450
Curve 450
Created 02/18/2009
CENT_A-600
Curve 600
Created 02/18/2009
CO11_TD2_600
CO-11 Relay Curve Time Dial 2 Setting 600A.
CO9_TD2_200
G&W SF6 Vacuum Interrupter.
C0-9, Time Dial #2, 200 amps.
DWG. #: FC15. Created 1/15/99.
CO9_TD2_250
CO9_TD2_350
E-Slow_100
G&W Electric Co. Vacuum Interrupter E-Speed slow setting 15-300A.
Curve 100
Created 2003-09-04

E-Slow_125
Curve 125
Created 2003-09-04
E-Slow_175
Curve 175
Created 2003-09-04
E-Slow_225
Curve 225
Created 2003-09-04
E-Slow_25
G&W Electric Co. Vacuum Interrupter E-Speed slow setting 15-300A. Curve
25
Created 2003-09-04
E-Slow_40
Curve 40
Created 2003-09-04
E-Slow_75
Curve 75
Created 2003-09-04
E_Slow_120
Curve 120
Created 2003-09-04
E_Slow_15
15
Created 2003-09-04
E_Slow_150
Curve 150
Created 2003-09-04
E_Slow_20
20
Created 2003-09-04
E_Slow_200
Curve 200
Created 2003-09-04
E_Slow_250
Curve 250
Created 2003-09-04
E_Slow_30
Curve 30
Created 2003-09-04
E_Slow_300
Curve 300
Created 2003-09-04
E_Slow_35
35
Created 2003-09-04
E_Slow_350
Curve 350
Created 2003-09-04
E_Slow_45

45
Created 2003-09-04
E_Slow_450
Curve 450
Created 2003-09-04
E_Slow_50
Curve 50
Created 2003-09-04
E_Slow_60
Curve 60
Created 2003-09-04
E_Slow_600
Curve 600
Created 2003-09-04
E_Slow_70
Curve 70
Created 2003-09-04
E_Slow_90
Curve 90
Created 2003-09-04
E_Std175
E Standard Speed 175A for SF6 Vacuum Interruptors
E_Std200
E Speed Standard 200A for SF6 Vacuum Interruptors.
ES15-300_100
G&W Electric Co. E Speed Standard
E Speed Standard 15-300A; Curve: 100
Created: 03/21/2005
ES15-300_125
Created: 03/21/2005
ES15-300_15
Created: 03/21/2005
ES15-300_175
Created: 03/21/2005
ES15-300_20
Created: 03/21/2005
ES15-300_225
Created: 03/21/2005
ES15-300_25
Created: 03/21/2005
ES15-300_300
Created: 03/21/2005
ES15-300_35
Created: 03/21/2005

ES15-300_45
Created: 03/21/2005
ES15-300_60
Created: 03/21/2005
ES15-300_75
Created: 03/21/2005
ES30-600_120
Created: 03/21/2005
ES30-600_150
Created: 03/21/2005
ES30-600_200
Created: 03/21/2005
ES30-600_250
Created: 03/21/2005
ES30-600_30
Created: 03/21/2005
ES30-600_350
Created: 03/21/2005
ES30-600_40
Created: 03/21/2005
ES30-600_450
Created: 03/21/2005
ES30-600_50
Created: 03/21/2005
ES30-600_600
Created: 03/21/2005
ES30-600_70
Created: 03/21/2005
ES30-600_90
Created: 03/21/2005

CENT-A-015
Curve 15
Created 02/17/2009
CENT-A-020
Curve 20
Created 02/17/2009
CENT-A-025
Curve 25
Created 02/17/2009
CENT-A-030
Curve 30
Created 02/18/2009
CENT-A-035
Curve 35
Created 02/17/2009
CENT-A-040
Curve 40
Created 02/18/2009
CENT-A-045
Curve 45
Created 02/17/2009
CENT-A-050
Curve 50
Created 02/18/2009
CENT-A-060
Curve 60
Created 02/17/2009
CENT-A-070
Curve 70
Created 02/18/2009
CENT-A-075
Curve 75
Created 02/17/2009
CENT-A-090
Curve 90
Created 02/18/2009
CENT-A-100
Curve 100
Created 02/17/2009
CENT-A-120
Curve 120
Created 02/18/2009
CENT-A-125
Curve 125
Created 02/17/2009
CENT-A-150
Curve 150
Created 02/18/2009

CENT-A-175
Curve 175
Created 02/17/2009
CENT-A-200
Curve 200
Created 02/18/2009
CENT-A-225
Curve 225
Created 02/17/2009
CENT-A-250
Curve 250
Created 02/18/2009
CENT-A-300
Curve 300
Created 02/17/2009
CENT-A-350
Curve 350
Created 02/18/2009
CENT-A-450
Curve 450
Created 02/18/2009
CENT-A-600
Curve 600
Created 02/18/2009
CO11-015
Created 02/20/2009
CO11-020
Created 02/20/2009
CO11-025
Created 02/20/2009
CO11-030
Created 02/20/2009
CO11-035
Created 02/20/2009
CO11-040
Created 02/20/2009
CO11-045
Created 02/20/2009
CO11-050
Created 02/20/2009
CO11-060

Created 02/20/2009
CO11-070
Created 02/20/2009
CO11-075
Created 02/20/2009
CO11-090
Created 02/20/2009
CO11-100
Created 02/20/2009
CO11-120
Created 02/20/2009
CO11-125
Created 02/20/2009
CO11-150
Created 02/20/2009
CO11-175
Created 02/20/2009
CO11-200
Created 02/20/2009
CO11-225
Created 02/20/2009
CO11-250
Created 02/20/2009
CO11-300
Created 02/20/2009
CO11-350
Created 02/20/2009
CO11-450
Created 02/20/2009
CO11-600
Created 02/20/2009
CO11-TD2-015
Created 02/20/2009

CO11-TD2-020
Created 02/20/2009
CO11-TD2-025
Created 02/20/2009
CO11-TD2-030
Created: 20/02/2009
CO11-TD2-035
Created 02/20/2009
CO11-TD2-040
Created 02/20/2009
CO11-TD2-045
Created 02/20/2009
CO11-TD2-050
Created 02/20/2009
CO11-TD2-060
Created 02/20/2009
CO11-TD2-070
Created 02/20/2009
CO11-TD2-075
Created 02/20/2009
CO11-TD2-100
Created 02/20/2009
CO11-TD2-120
Created 02/20/2009
CO11-TD2-125
Created 02/20/2009
CO11-TD2-150
Created 02/20/2009
CO11-TD2-175
Created 02/20/2009
CO11-TD2-200
Created 02/20/2009
CO11-TD2-225

Created 02/20/2009
CO11-TD2-250
Created 02/20/2009
CO11-TD2-300
Created 02/20/2009
CO11-TD2-350
Created 02/20/2009
CO11-TD2-450
Created 02/20/2009
CO11-TD2-600
Created 02/20/2009
CO11-TD2-90
Created 02/20/2009
CO9-TD2-015
Created 03/01/2009
CO9-TD2-020
Created 03/01/2009
CO9-TD2-025
Created 03/01/2009
CO9-TD2-030
Created 03/01/2009
CO9-TD2-035
Created 03/01/2009
CO9-TD2-040
Created 03/01/2009
CO9-TD2-045
Created 03/01/2009
CO9-TD2-050
Created 03/01/2009
CO9-TD2-060
Created 03/01/2009
CO9-TD2-070
Created 03/01/2009

CO9-TD2-075
Created 03/01/2009
CO9-TD2-090
Created 03/01/2009
CO9-TD2-100
Created 03/01/2009
CO9-TD2-120
Created 03/01/2009
CO9-TD2-125
Created 03/01/2009
CO9-TD2-150
Created 03/01/2009
CO9-TD2-175
Created 03/01/2009
CO9-TD2-200
Created 03/01/2009
CO9-TD2-225
Created 03/01/2009
CO9-TD2-250
Created 03/01/2009
CO9-TD2-300
Created 03/01/2009
CO9-TD2-350
Created 03/01/2009
CO9-TD2-450
Created 03/01/2009
CO9-TD2-600
Created 03/01/2009
CO9_TD2_200
CO9_TD2_250
CO9_TD2_350

CO9TD4.5-015
Time dial: 4.5; Setting: 15-300A; Curve: 15
Created 03/02/2009
CO9TD4.5-020
Created 03/02/2009
CO9TD4.5-025
Created 03/02/2009
CO9TD4.5-030
Created 03/02/2009
CO9TD4.5-035
Created 03/02/2009
CO9TD4.5-040
Created 03/02/2009
CO9TD4.5-045
Created 03/02/2009
CO9TD4.5-050
Created 03/02/2009
CO9TD4.5-060
Created 03/02/2009
CO9TD4.5-070
Created 03/02/2009
CO9TD4.5-075
Created 03/02/2009
CO9TD4.5-090
Created 03/02/2009
CO9TD4.5-100
Created 03/02/2009
CO9TD4.5-120
Created 03/02/2009
CO9TD4.5-125
Created 03/02/2009
CO9TD4.5-150
Created 03/02/2009

CO9TD4.5-175
Created 03/02/2009
CO9TD4.5-200
Created 03/02/2009
CO9TD4.5-225
Created 03/02/2009
CO9TD4.5-250
Created 03/02/2009
CO9TD4.5-300
Created 03/02/2009
CO9TD4.5-350
Created 03/02/2009
CO9TD4.5-450
Created 03/02/2009
CO9TD4.5-600
Created 03/02/2009
EF-015
G&W Electric Co. Vacuum Interrupter EF SPEED setting 15-300A.
Curve 15
Created 03/02/2009
EF-020
Curve 20
Created 03/02/2009
EF-025
Curve 25
Created 03/02/2009
EF-035
Curve 35
Created 03/02/2009
EF-045
Curve 45
Created 03/02/2009
EF-060
Curve 60
Created 03/02/2009
EF-075
Curve 75
Created 03/02/2009
EF-100
Curve 100
Created 03/02/2009
EF-125

Curve 125
Created 03/02/2009
EF-175
Curve 175
Created 03/02/2009
EF-225
Curve 225
Created 03/02/2009
EF-300
Curve 300
Created 03/02/2009
EFUSE-006
G&W Electric Co. Vacuum Interrupter Electronic Oil Fuse Cutout Replacement.
Curve 6
Created 03/10/2009
EFUSE-008
Curve 8
Created 03/10/2009
EFUSE-010
Curve 10
Created 03/10/2009
EFUSE-012
Curve 12
Created 03/10/2009
EFUSE-015
Curve 15
Created 03/10/2009
EFUSE-020
Curve 20
Created 03/10/2009
EFUSE-025
Curve 25
Created 03/10/2009
EFUSE-030
Curve 30
Created 03/10/2009
EFUSE-040
Curve 40
Created 03/10/2009
EFUSE-050
Curve 50
Created 03/10/2009
EFUSE-065
Curve 65
Created 03/10/2009
EFUSE-100
Curve 100
Created 03/10/2009
EFUSE-140
Curve 140
Created 03/10/2009

EFUSE-200
Curve 200
Created 03/10/2009
F-015
G&W Electric Co. Vacuum Interrupter F SPEED setting 15-300A.
Curve 15
Created 03/02/2009
F-020
Curve 20
Created 03/02/2009
F-025
Curve 25
Created 03/02/2009
F-030
Curve 30
Created 03/02/2009
F-035
Curve 35
Created 03/02/2009
F-040
Curve 40
Created 03/02/2009
F-045
Curve 45
Created 03/02/2009
F-050
Curve 50
Created 03/02/2009
F-060
Curve 60
Created 03/02/2009
F-070
Curve 70
Created 03/02/2009
F-075
Curve 75
Created 03/02/2009
F-090
Curve 90
Created 03/02/2009
F-100
Curve 100
Created 03/02/2009
F-120
Curve 120
Created 03/02/2009
F-125
Curve 125
Created 03/02/2009
F-150

Curve 150
Created 03/02/2009
F-175
Curve 175
Created 03/02/2009
F-200
Curve 200
Created 03/02/2009
F-225
Curve 225
Created 03/02/2009
F-250
Curve 250
Created 03/02/2009
F-300
Curve 300
Created 03/02/2009
F-350
Curve 350
Created 03/02/2009
F-450
Curve 450
Created 03/02/2009
F-600
Curve 600
Created 03/02/2009
GE-IAC53-015
G&W Electric Co. Vacuum Interrupter GE-IAC53 setting 15-300A.
Curve 15
Created 03/02/2009
GE-IAC53-020
Curve 20
Created 03/02/2009
GE-IAC53-025
Curve 25
Created 03/02/2009
GE-IAC53-030
Curve 30
Created 03/02/2009
GE-IAC53-035
Curve 35
Created 03/02/2009
GE-IAC53-040
Curve 40
Created 03/02/2009
GE-IAC53-045
Curve 45
Created 03/02/2009
GE-IAC53-050
Curve 50
Created 03/02/2009

GE-IAC53-060
Curve 60
Created 03/02/2009
GE-IAC53-070
Curve 70
Created 03/02/2009
GE-IAC53-075
Curve 75
Created 03/02/2009
GE-IAC53-090
Curve 90
Created 03/02/2009
GE-IAC53-100
Curve 100
Created 03/02/2009
GE-IAC53-120
Curve 120
Created 03/02/2009
GE-IAC53-125
Curve 125
Created 03/02/2009
GE-IAC53-150
Curve 150
Created 03/02/2009
GE-IAC53-175
Curve 175
Created 03/02/2009
GE-IAC53-200
Curve 200
Created 03/02/2009
GE-IAC53-225
Curve 225
Created 03/02/2009
GE-IAC53-250
Curve 250
Created 03/02/2009
GE-IAC53-300
Curve 300
Created 03/02/2009
GE-IAC53-350
Curve 350
Created 03/02/2009
GE-IAC53-450
Curve 450
Created 03/02/2009
GE-IAC53-600
Curve 600
Created 03/02/2009
K-SPEED-015
G&W Electric Co. Vacuum Interrupter K SPEED setting 15-300A.

Curve 15
Created 03/03/2009
K-SPEED-020
Curve 20
Created 03/03/2009
K-SPEED-025
Curve 25
Created 03/03/2009
K-SPEED-030
Curve 30
Created 03/03/2009
K-SPEED-035
Curve 35
Created 03/03/2009
K-SPEED-040
Curve 40
Created 03/03/2009
K-SPEED-045
Curve 45
Created 03/03/2009
K-SPEED-050
Curve 50
Created 03/03/2009
K-SPEED-060
Curve 60
Created 03/03/2009
K-SPEED-070
Curve 70
Created 03/03/2009
K-SPEED-075
Curve 75
Created 03/03/2009
K-SPEED-090
Curve 90
Created 03/03/2009
K-SPEED-100
Curve 100
Created 03/03/2009
K-SPEED-120
Curve 120
Created 03/03/2009
K-SPEED-125
Curve 125
Created 03/03/2009
K-SPEED-150
Curve 150
Created 03/03/2009
K-SPEED-175
Curve 175
Created 03/03/2009

K-SPEED-200
Curve 200
Created 03/03/2009
K-SPEED-225
Curve 225
Created 03/03/2009
K-SPEED-250
Curve 250
Created 03/03/2009
K-SPEED-300
Curve 300
Created 03/03/2009
K-SPEED-350
Curve 350
Created 03/03/2009
K-SPEED-450
Curve 450
Created 03/03/2009
K-SPEED-600
Curve 600
Created 03/03/2009
NX-35C-015
G&W Electric Co. Vacuum Interrupter NX 35-C setting 15-300A.
Curve 15
Created 03/05/2009
NX-35C-020
Curve 20
Created 03/05/2009
NX-35C-025
Curve 25
Created 03/05/2009
NX-35C-035
Curve 35
Created 03/05/2009
NX-35C-045
Curve 45
Created 03/05/2009
NX-35C-060
Curve 60
Created 03/05/2009
NX-35C-075
Curve 75
Created 03/05/2009
NX-35C-100
Curve 100
Created 03/05/2009
NX-35C-125
Curve 125
Created 03/05/2009
NX-35C-175

Curve 175
Created 03/05/2009
NX-35C-225
Curve 225
Created 03/05/2009
NX-35C-300
Curve 300
Created 03/05/2009
NX-35C-030
Curve 30
Created 03/05/2009
NX-35C-040
Curve 40
Created 03/05/2009
NX-35C-050
Curve 50
Created 03/05/2009
NX-35C-070
Curve 70
Created 03/05/2009
NX-35C-090
Curve 90
Created 03/05/2009
NX-35C-120
Curve 120
Created 03/05/2009
NX-35C-150
Curve 150
Created 03/05/2009
NX-35C-200
Curve 200
Created 03/05/2009
NX-35C-250
Curve 250
Created 03/05/2009
NX-35C-350
Curve 350
Created 03/05/2009
NX-35C-450
Curve 450
Created 03/05/2009
NX-35C-600
Curve 600
Created 03/05/2009
OILFUSE-020
G&W Electric Co. Vacuum Interrupter Oil Fuse Cutout setting 15-300A.
Curve 20
Created 03/09/2009
OILFUSE-025
Curve 25
Created 03/09/2009

OILFUSE-035
Curve 35
Created 03/09/2009
OILFUSE-045
Curve 45
Created 03/09/2009
OILFUSE-060
Curve 60
Created 03/09/2009
OILFUSE-075
Curve 75
Created 03/09/2009
OILFUSE-100
Curve 100
Created 03/09/2009
OILFUSE-125
Curve 125
Created 03/09/2009
OILFUSE-15
Curve 15
Created 03/09/2009
OILFUSE-175
Curve 175
Created 03/09/2009
OILFUSE-225
Curve 225
Created 03/09/2009
OILFUSE-300
Curve 300
Created 03/09/2009
OILFUSE-030
Curve 30
Created 03/08/2009
OILFUSE-040
Curve 40
Created 03/08/2009
OILFUSE-050
Curve 50
Created 03/08/2009
OILFUSE-070
Curve 70
Created 03/08/2009
OILFUSE-090
Curve 90
Created 03/08/2009
OILFUSE-120
Curve 120
Created 03/08/2009

OILFUSE-150
Curve 150
Created 03/08/2009
OILFUSE-200
Curve 200
Created 03/08/2009
OILFUSE-250
Curve 250
Created 03/08/2009
OILFUSE-350
Curve 350
Created 03/08/2009
OILFUSE-450
Curve 450
Created 03/08/2009
OILFUSE-600
Curve 600
Created 03/08/2009
QA-015
G&W Electric Co. Vacuum Interrupter QA Speed setting 15-300A.
Curve 15
Created 03/09/2009
QA-020
Curve 20
Created 03/09/2009
QA-025
Curve 25
Created 03/09/2009
QA-035
Curve 35
Created 03/09/2009
QA-045
Curve 45
Created 03/09/2009
QA-060
Curve 60
Created 03/09/2009
QA-075
Curve 75
Created 03/09/2009
QA-100
Curve 100
Created 03/09/2009
QA-125
Curve 125
Created 03/09/2009
QA-175
Curve 175
Created 03/09/2009
QA-225

Curve 225
Created 03/09/2009
QA-300
Curve 300
Created 03/09/2009
T-015
G&W Electric Co. Vacuum Interrupter T Speed Slow setting 15-300A.
Curve 15
Created 03/10/2009
T-020
Curve 20
Created 03/10/2009
T-025
Curve 25
Created 03/10/2009
T-030
Curve 30
Created 03/09/2009
T-035
Curve 35
Created 03/10/2009
T-040
Curve 40
Created 03/09/2009
T-045
Curve 45
Created 03/10/2009
T-050
Curve 50
Created 03/09/2009
T-060
Curve 60
Created 03/10/2009
T-070
Curve 70
Created 03/09/2009
T-075
Curve 75
Created 03/10/2009
T-090
Curve 90
Created 03/09/2009
T-100
Curve 100
Created 03/10/2009
T-120
Curve 120
Created 03/09/2009
T-125
Curve 125
Created 03/10/2009

T-150
Curve 150
Created 03/09/2009
T-175
Curve 175
Created 03/10/2009
T-200
Curve 200
Created 03/09/2009
T-225
Curve 225
Created 03/10/2009
T-250
Curve 250
Created 03/09/2009
T-300
Curve 300
Created 03/10/2009
T-350
Curve 350
Created 03/09/2009
T-450
Curve 450
Created 03/09/2009
T-600
Curve 600
Created 03/09/2009

GE.RLY: GE FUSES
This file contains GE relay, fuse, recloser and capacitor bank case rupture curves.
Among these are 110 fuses from manufacturer's drawings GET-1857,GET-1858, GET-2760, GET-2761,
GET-2762, GET-2763, GET-2764, GET-2765, GET-2766 and GET-2767. The drawings GET-1857 and
GET-1858 are the minimum-melt curves for the standard EG-1 and the fast operating EG-1 and EG-1B
fuses, respectively.The rest are total-clear curves.
The naming convention follows the drawing number for the total-clear curve.For example, all fuses in the
relay library whose total-clear curves come from the drawing GET-2760 have names that begin with GET-
2760.The current rating of the individual fuse is appended to the reference number.The fuse GET-2760-
100, for example, is a 100E fuse.(The character 'E' is omitted in the fuse name because all fuses starting
with the number GET-2760 are 'E' fuses.)
The table below lists all the fuses in the library.
Type kV Nom. Rating Ampere Rating ASPEN Relay Name

Standard EG-1
7.2 0.5E through 125E GET-2760-1/2 through GET-2760-125
14.4 and 23 0.5E through 125E GET-2761-1/2 through GET-2761-125
34.5, 46 and 69 0.5E through 125E GET-2762-1/2 through GET-2762-125
92, 115, and 138 0.5E through 125E GET-2763-1/2 through GET-2763-125
Fast-Operating EG-1 & EG-1B
7.2 20E through 200E GET-2764-20 through GET-2764-200
14.4 and 23 20E through 200E GET-2765-20 through GET-2765-200
34.5, 46 and 69 20E through 200E GET-2766-20 through GET-2766-200
Fast-Operating EG-1
92, 115, and 138 20E through 125E GET-2767-20 through GET-2767-125
DDP-EI
GE DDP relay, extreme inverse curves. Similar to IAC-51.
DDP-I
GE DDP relay, inverse curves. Similar to IAC-51.
DDP-VI
GE DDP relay, very inverse curves. Similar to IFC-53.
DFP100-EI
GE DFP100 relay, extremely inverse curves. t=TD*[5.64/(M^2-1)+0.02434].
t=time in seconds; TD=Time Dial; M=multiples of pickup.
Created 8/21/96.
DFP100-I
GE DFP100 relay, inverse curves. t=TD*[0.0103/(M^0.02-1)+0.0228];
Created 8/21/96.
DFP100-VI
GE DFP100 relay, very inverse curves. t=TD*[3.922/(M^2-1)+0.0982];
Created 8/21/96.
DIAC-12t
GE DIAC, DIFC, & DSFC Overcurrent relays. 12t Time Curve.

Ref. No: 0358A1119. Created 8/20/96.
DIAC-51
GE DIAC, DIFC, & DSFC Overcurrent relays. IAC51 curves.
Ref. No: 0358A1104. Created 8/20/96.
DIAC-53
GE DIAC, DIFC, & DSFC Overcurrent relays. IAC53 curves.
Ref No: 0358A1105. Created 8/20/96.
DIAC-55
GE DIAC, DIFC, & DSFC Overcurrent relays. 55 Short Time Curve.
Ref. No: 0358A1106. Created 8/20/96.
DIAC-57
GE DIAC, DIFC, & DSFC Overcurrent relays. 57 Medium Time Curve.
Ref. No: 0358A1104. Created 8/20/96.
DIAC-66
GE DIAC, DIFC, & DSFC Overcurrent relays. 66 Long Time Curve.
Ref. No: 0358A1108. reated 8/20/96.
DIAC-75
Ref. No: 0358A1109. Created 8/20/96.
DIAC-77
GE DIAC, DIFC, & DSFC Overcurrent relays. IAC-77 Time Curves.
Ref. No: 0358A1110. Created 9/25/95.
DIAC-95
Ref. No: 0358A1111. Created 8/20/96.
DIAC-IEC-VI
GE DIAC, DIFC, & DSFC overcurrent relay. IEC Very Inverse.
T=13.5/(M^1.-1). Ref No. 0358A1113. Created 8/20/96.
DIAC-IEC_EI
GE DIAC, DIFC, & DSFC overcurrent relay. IEC Extremely Inverse.
T=80./(M^2.-1). Ref No. 0358A1114. Created 8/20/96.
DIAC-IEC_I
GE DIAC, DIFC, & DSFC overcurrent relay. IEC Inverse.
T=0.14/(M^0.02-1). Ref No. 0358A1112. Created 8/20/96.
DIAC-IEEE-VI
GE DIAC, DIFC, & DSFC overcurrent relay. IEEE Very Inverse.
T=0.2*D*[19.61/(M^2-1)+0.491]. Ref No. 0358A1116. Created 8/20/96.
DIAC-IEEE_EI
GE DIAC, DIFC, & DSFC overcurrent relay. IEEE Extremely Inverse.
T=0.2*D*[28.2/(M^2-1)+0.1217]. Ref No. 0358A1117. Created 8/20/96.
DIAC-IEEE_I
GE DIAC, DIFC, & DSFC overcurrent relay. IEEE Inverse.
T=0.2*D*[0.0515/(M^.02-1)+0.114]. Ref No. 0358A1115. Created 8/20/96.
DLP
GE DLP relay. Similar to, but not the same as, IAC53.
DLP-OV
GE DLP Relay, original version. GEK-99300. 1/7/93.
DLP_B-I
GE DLP Relay, inverse curves. GES-9850, Rev. B. 1/7/93.
DLP_C-EI
GE DLP relay, extremely inverse curves. GES-9859.
Rev. C and later. 6/6/94.
DLP_C-I
GE DLP Relay, inverse curves. GES-9857,
DLP_C-VI
GE DLP relay, very inverse curves. GES-9858.
F60_IEEE-EI
GE Multilin F60 feeder management relay
IEEE Extremely Inverse curves
T=D*[28.2/(M^2 - 1) + 0.1217]
Created 06/13/2006
F60_IEEE-MI

IEEE ModeratelyInverse curves
T=D*[0.0515/(M^0.02 - 1) + 0.114]
Created 06/13/2006
F60_IEEE-VI
IEEE Very Inverse curves
T=D*[19.61/(M^2 - 1) + 0.491]
Created 06/13/2006
GES-6407-B
TYPE VIR AUTOMATIC CIRCUIT RECLOSER
REFERENCE GES-6407
CURVE: PHASE TRIP 'B', TIME DELAY
CREATED 6/2/97
GES-6407-B1
TYPE VIR AUTOMATIC RECLOSER
REFERENCE GES-6407
CURVE: PHASE TRIP 'B1'. INSTANTANEUOUS
CREATED 6/2/97
GES-6407-B2
REFERENCE GES-6407
CURVE: PHASE TRIP 'B2', INSTANTANEOUS
CREATED 6/2/97
GES-6407-B3
REFERENCE GES-6407
CURVE: PHASE TRIP 'B3', INSTANTANEOUS
CREATED 6/2/97
GES-6408-C
REFERENCE GES-6408
CURVE:PHASE TRIP 'C', TIME DELAY
CREATED 6/2/97
GES-6408-C1
REFERENCE GES-6408
CURVE: PHASE TRIP 'C1', INSTANTANEOUS
CREATED 6/2/97
GES-6408-C2
REFERENCE GES-6408
CREATED 6/2/97
GES-6408-C3
REFERENCE GES-6408
CREATED 6/2/97
GES-6409-D
REFERENCE GES-6409
CURVE: PHASE TRIP 'D', TIME DELAY
CREATED 6/2/97
GES-6409-D1
REFERENCE GES-6409
CURVE: PHASE TRIP 'D1', INSTANTANEOUS
CREATED 6/2/97
GES-6409-D2
REFERENCE GES-6409
CREATED 6/2/97
GES-6409-D3
REFERENCE GES-6409
CREATED 6/2/97

GES-6410-BG
REFERENCE GES-6410
CURVE: GROUND TRIP 'BG', TIME DELAY
CREATED 6/2/97
GES-6410-BG1
REFERENECE GES-6410
CURVE: GROUND TRIP 'BG', INSTANTANEOUS
CREATED 6/2/97
GES-6410-BG2
REFERENCE GES-6410
CREATED 6/2/97
GES-6410-BG3
REFERENCE GES-6410
CREATED 6/2/97
GES-6411-CG
REFERENCE GES-6411
CURVE: GROUND TRIP 'CG', TIME DELAY
CREATED 6/2/97
GES-6411-CG1
REFERENCE GES-6411
CURVE: GROUND TRIP 'CG', INSTANTANEOUS
CREATED 6/2/97
GES-6411-CG2
REFERENCE GES-6411
CURVE GROUND TRIP 'CG', INSTANTANEOUS
CREATED 6/2/97
GES-6411-CG3
REFERENCE GES-6411
CURVE: GROUND TRIP 'CG', INSTANTANEOUS
CREATED 6/2/97
GES-6412-DG
REFERENCE GES-6412
CURVE: GOUND TRIP 'DG', TIME DELAY
CREATED 6/2/97
GES-6412-DG1
REFERENCE GES-6412
CURVE: GROUND TRIP 'DG1', INSTANTANEOUS
CREATED 6/2/97
GES-6412-DG2
REFERENCE GES-6412
CURVE: GROUND TRIP 'DG', INSTANTANEOUS
CREATED 6/2/97
GES-6412-DG3
REFERENCE GES-6412
CURVE: GROUND TRIP 'DG', INSTANTANEOUS
CREATED 6/2/97
GES-6422-E
REFERENCE GES-6422
CURVE: PHASE TRIP 'E', TIME DELAY
CREATED 6/2/97
GES-6422-E1

REFERENCE GES-6422
CURVE: PHASE TRIP 'E1', INSTANTANEOUS
CREATED 6/2/97
GES-6422-E2
REFERENCE GES-6422
CREATED 6/2/97
GES-6422-E3
REFERENCE GES-6422
CREATED 6/2/97
GES-6423-EG
REFERENCE GES-6423
CURVE: GROUND TRIP 'EG', TIME DELAY
CREATED 6/2/97
GES-6423-EG1
REFERENCE GES-6423
CURVE: GROUND TRIP 'EG1', INSTANTANEOUS
CREATED 6/2/97
GES-6423-EG2
TYPE VIR AUTOMATIC CIRCUIT RELCOSER
REFERENCE GES-6423
CREATED 6/2/97
GES-6423-EG3
REFERENCE GES-6423
CREATED 6/2/97
GES-6424-F
REFERENCE GES-6424
CURVE: PHASE TRIP 'F', TIME DELAY
CREATED 67/2/97
GES-6424-F1
REFERENCE GES-6424
CURVE: PHASE TRIP 'F1', INSTANTANEOUS
CREATED 6/2/97
GES-6424-F2
REFERENCE GES-6424
CREATED 6/2/97
GES-6424-F3
REFERENCE GES-6424
CREATED 6/2/97
GES-6425-FG
REFERENCE GES-6425
CURVE: GROUND TRIP 'FG', TIME DELAY
CREATED 6/2/97
GES-6425-FG1
REFERENCE GES-6425
CURVE: GROUND TRIP 'FG1', INSTANTANEOUS
CREATED 6/3/97
GES-6425-FG2
REFERENCE GES-6425
CREATED 6/2/97

GES-6425-FG3
REFERENCE GES-6425
CREATED 6/3/97
GES-6426-H
REFERENCE GES-6426
CURVE: PHASE TRIP 'H', TIME DELAY
CREATED 6/5/97
GES-6426-H1
REFERENCE GES-6426
CURVE: PHASE TRIP 'H1', INSTANTANEOUS
CREATED 6/5/97
GES-6426-H2
REFERENCE GES-6426
CREATED: 6/5/97
GES-6426-H3
REFERENECE GES-6426
CREATED: 6/5/97
GES-6427-HG
REFERENCE GES-6427
CRUVE: GROUND TRIP 'HG', TIME DELAY
CREATED 6/5/97
GES-6427-HG1
TYPE VIR AUTOMATIC CIRCUIT RECLOSR
REFERENCE GES-6427
CURVE: GROUND TRIP 'HG1', INSTANTANEOUS
CREATED 6/5/97
GES-6427-HG2
REFERENCE GES-6427
CREATED 6/5/97
GES-6427-HG3
REFERENCE GES-6427
CREATED 6/5/97
GES-8102-250
GE Fuse: EJ-1, 2.4 or 4.16 & 4.8 KV. Size DD, Current Rating(A) : 250E.
Reference No: GES-8102, GES-8103.
Created 5/4/94.
GES-8102-300
GE Fuse: EJ-1, 2.4 or 4.16 & 4.8 KV. Size DD, Current Rating(A) : 300E.
Created 5/4/94.
GES-8102-325
GE Fuse: EJ-1, 2.4 or 4.16 & 4.8 KV. Size DD, Current Rating(A) : 325.
Created 5/4/94.
GES-8102-375
Created 5/4/94.
GES-8102-400
Created 5/4/94.
GES-8102-450

Created 5/4/94.
GES-8104-0.5
GE Fuse: EJ-1 & EJ0-1, 14.4 KV. Size C, Current Rating(A) : 0.5E.
Created 3/6/95.
GES-8104-001
GE Fuse: EJ-1 & EJ0-1, 14.4 KV. Size C, Current Rating(A) : 1E.
Created 3/6/95.
GES-8104-002
Reference No: GES-8104, GES-8105. Created 3/6/95.
GES-8104-003
GES-8104-005
GES-8104-007
GES-8104-010
GES-8104-015
GE Fuse: EJ-1 & EJ0-1, 14.4 kV. Size D, Current Rating(A): 15E.
GES-8104-020
GES-8104-025
GES-8104-030
GES-8104-040
GE Fuse: EJ-1 & EJ0-1, 14.4 kV. Size D, Current Rating(A) : 40E.
GES-8104-050
GE Fuse: EJ-1 & EJ0-1, 14.4 kV. Size D, Current Rating(A) : 50E.
GES-8104-065
GE Fuse: EJ-1 & EJ0-1, 14.4 kV. Size DD, Current Rating(A) : 65E.
GES-8104-080
GES-8104-100
GES-8104-125
GE Fuse: EJ-1 & EJ0-1, 14.4 kV. Size EE, Current Rating(A) : 125E.
GES-8104-150
GES-8104-175
GES-8106-0.5
GE Fuse: EJ-1 & EJ0-1, 2.4 & 4.8 KV. Size C, Current Rating(A) : 0.5E.
Created 5/5/94.

GES-8106-001
GE Fuse: EJ-1 & EJ0-1, 2.4 & 4.8 KV. Size C, Current Rating(A) : 1E.
Created 5/5/94.
GES-8106-002
Created 5/5/94.
GES-8106-003
GES-8106-005
GES-8106-007
Created 5/5/94.
GES-8106-010
Created 5/5/94.
GES-8106-015
GE Fuse: EJ0-1, 7.2 KV. Size C, Current Rating(A) : 15E.
Created 1/23/96.
GES-8106-020
GE Fuse: EJ-1 & EJ0-1, 2.4, &4.8 kV. Size C, Current Rating(A): 20E.
GES-8106-025
GE Fuse: EJ-1 & EJ0-1, 2.4 & 4.8 KV. Size C, D, Current Rating(A): 25E.
GES-8106-030
GE Fuse: EJ-1 & EJ0-1, 2.4 & 4.8 KV. Size D, Current Rating(A) : 30E.
Created 5/5/94.
GES-8106-040
GE Fuse: EJ-1 & EJ0-1, 2.4 & 4.8 KV. Size D, Current Rating(A): 40E.
GES-8106-050
Created 5/5/94.
GES-8106-065
Created 5/5/94.
GES-8106-080
Created 5/5/94.
GES-8106-100
Created 5/5/94.
GES-8106-125
GE Fuse: EJ-1 & EJ0-1, 2.4 & 4.8 KV. Size DD, Current Rating(A) : 125E.
Created 5/5/94.
GES-8106-150
Created 5/5/94.
GES-8106-200

Created 5/5/94.
GES-8108-001
GE Fuse: EJ-1 2.4 KV. Size A, Current Rating(A) : 1E.
Created 5/9/94.
GES-8108-002
GE Fuse: EJ-1 2.4 KV. Size A, Current Rating(A) : 2E.
GES-8112-0.5
GE Fuse: EJ0-1, 7.2 KV. Size C. Current Rating(A) : 0.5E.
GES-8112-001
GE Fuse: EJ0-1, 7.2KV. Size C, Current Rating(A) : 1E.
GES-8112-002
GE Fuse: EJ0-1, 7.2KV. Size C, Current Rating(A) : 2E.
GES-8112-003
GES-8112-005
GES-8112-007
GES-8112-010
GES-8112-015
GES-8112-020
GE Fuse: EJ0-1, 7.2 kV. Size D, Current Rating(A): 20E.
GES-8112-025
GE Fuse: EJ0-1, 7.2 KV. Size D, Current Rating(A): 25E.
GES-8112-030
GE Fuse: EJ0-1,7.2 KV. Size D, Current Rating(A) : 30E.
GES-8112-040
GE Fuse: EJ0-1, 7.2 KV. Size D, Current Rating(A): 40E.
GES-8112-050
GE Fuse: EJ0-1, 7.2 KV. Size D, Current Rating(A) : 50E.
GES-8112-065
GES-8112-080
GES-8112-100
GES-8112-125
GE Fuse: EJ0-1, 7.2 KV. Size DD, Current Rating(A) : 125E.
GES-8112-150
GES-8112-200

GES-8138-020
GE Fuse: EJ0-1, Type 9F62, 15.5 kV. Size C, Current Rating(A): 20E.
GES-8138-025
GES-8138-030
GES-8138-050
GE Fuse: EJ0-1, Type 9F62, 15.5 kV. Size D, Current Rating(A): 50E.
GES-8138-065
GES-8138-080
GES-8138-100
GES-8138-125
GE Fuse: EJ0-1, Type 9F62, 15.5 kV. Size DD, Current Rating(A): 125E.
GES-8138-150
GES-8138-175
GES-8138-200
GES-8224-010
GE Fuse: Model 9F54MFC Fault-Sensing Bayonet Fuse, 8.3, 15.5 and 23 kV.
10 amp, Fuse Link No. C6. Reference No: GES-8224 and GES-8225.
Created 6/24/98.
GES-8224-015
Created 6/25/98.
GES-8224-025
GE Fuse: Model 9F54MFC Fault Sensing Bayonet Fuse, 8.3, 15.5 and 23 kV.
Created 6/25/98.
GES-8224-040
GE Fuse: Model 9F54MFC Fault Sensing Bayonet Fuse, 8.3, 15.5 and 23 kV.
Created 6/25/98.
GES-8224-065
Created 6/25/98.
GES-8224-100
Created 6/25/98.
GES-8224-140
Created 6/25/98.
GES-8301A-30
GE Fuse Fuse.
Fuse Desig. No: 30.
Reference No: GES-8301A.
Created 04/16/2002.

GES-8301A-31
GE Fuse Fuse.
Fuse Desig. No: 31.
Created 04/16/2002.
GES-8301A-32
GE Fuse Fuse.
Fuse Desig. No: 32.
Created 04/16/2002.
GES-8301A-33
GE Fuse Fuse.
Fuse Desig. No: 33.
Created 04/16/2002.
GES-8301A-34
GE Fuse Fuse.
Fuse Desig. No: 34.
Created 04/16/2002.
GES-8301A-35
GE Fuse Fuse.
Fuse Desig. No: 35.
Created 04/16/2002.
GES-8301A-36
GE Fuse Fuse.
Fuse Desig. No: 36.
Created 04/16/2002.
GES-8307-B1
GE Fuse: 9F54DB Connection Board Fuse, 8.4 kV. Fuse Desig. No: B1.
Reference No: GES-8307 and GES-8317. Created 6/26/98.
GES-8307-B10
GES-8307-B11
GES-8307-B12
GES-8307-B13
GES-8307-B14
GES-8307-B2
GES-8307-B3
GES-8307-B4
GES-8307-B5
GES-8307-B6
GES-8307-B7

GES-8307-B8
GES-8307-B9
GES-8311-30
GE Fuse.
Fuse Desig. No: 30.
Reference No: GES-8311.
Created 04/16/2002.
GES-8311-31
GE Fuse.
Fuse Desig. No: 31.
Created 04/16/2002.
GES-8311-32
GE Fuse.
Fuse Desig. No: 32.
Created 04/16/2002.
GES-8311-33
GE Fuse.
Fuse Desig. No: 33.
Created 04/16/2002.
GES-8311-34
GE Fuse.
Fuse Desig. No: 34.
Created 04/16/2002.
GES-8311-35
GE Fuse.
Fuse Desig. No: 35.
Created 04/16/2002.
GES-8311-36
GE Fuse.
Fuse Desig. No: 36.
Created 04/16/2002.
GES-8500-10
GE Oil fuse cutout fuse link type 9F57B&C
Curve 10.
Reference #: GES-8500/8501.
Created 2004-05-17
GES-8500-100
Curve 100.
Created 2004-05-17
GES-8500-125
Curve 125.
Created 2004-05-17
GES-8500-140
Curve 140.
Created 2004-05-17
GES-8500-15
Curve 15.
Created 2004-05-17

GES-8500-150
Curve 150.
Created 2004-05-17
GES-8500-20
Curve 20.
Created 2004-05-17
GES-8500-200
Curve 200.
Created 2004-05-17
GES-8500-250
Curve 250.
Created 2004-05-17
GES-8500-30
Curve 30.
Created 2004-05-17
GES-8500-300
Curve 300.
Created 2004-05-17
GES-8500-301
Curve 301.
Created 2004-05-17
GES-8500-40
Curve 40.
Created 2004-05-17
GES-8500-50
Curve 50.
Created 2004-05-17
GES-8500-6
GE Oil fuse cutout fuse link type 9F57B & C
Curve 6.
Created 2004-05-17
GES-8500-65
Curve 65.
Referance #: GES-8500.
Created 2004-05-17
GES-8500-75
Curve 75.
Created 2004-05-17
GES-8500_25
Curve 25.
Created 2004-05-17
GES_8308_C1
GE Fuse: 9F54DC Connection Board Fuse, 23 kV. Fuse Desig. No: C1.

Reference No: GES-8308 and GES-8318A. Created 8/12/98.
GES_8308_C10
GES_8308_C11
GES_8308_C2
GES_8308_C3
GES_8308_C4
GES_8308_C5
GES_8308_C6
GES_8308_C7
GES_8308_C8
GES_8308_C9
GES6111C01MA
GE GES--6111C
Molded-case circuit breaker K-1200 Line. Type TKMA and THKMA 300 - 600
Amps.
Maximum curve.
Created 12/06/2005
GES6111C01MI
GE GES--6111C
Amps.
Minimum curve.
Created 12/06/2005
GES6111C02MA
GE GES--6111C
Amps.
Maximum curve.
Created 12/06/2005
GES6111C02MI
GE GES--6111C
Amps.
Minimum curve.
Created 12/06/2005
GES6111C03MA
GE GES--6111C
0 Amps.
Maximum curve.
Created 12/06/2005
GES6111C03MI
GE GES--6111C
0 Amps.
Minimum curve.
Created 12/06/2005

GET-2760-001
GE Fuse: Standard EG-1, 7.2kV, Current Rating: 1A,
Reference No: GET-1857, GET-2760. Created 11/3/93.
GET-2760-002
GE Fuse: Standard EG-1, 7.2kV. Current Rating: 2A.
GET-2760-003
GET-2760-005
GET-2760-007
GET-2760-010
GET-2760-015
GET-2760-020
GET-2760-025
GET-2760-030
GET-2760-040
GET-2760-050
GET-2760-065
GET-2760-080
GET-2760-1/2
GE Fuse: Standard EG-1, 7.2kV, Current Rating: 0.5A,
GET-2760-100
GET-2760-125
GE Fuse: Standard EG-1, 7.2kV. Current Rating: 125 A.
GET-2761-001
GE Fuse: Standard EG-1, 14.4kV and 23kV, Current Rating: 1A,
GET-2761-002
GE Fuse: Standard EG-1, 14.4kV, and 23kV. Current Rating: 2A.
GET-2761-003
GE Fuse: Standard EG-1, 14.4kV and 23kV. Current Rating: 3A.
GET-2761-005
GET-2761-007

GET-2761-010
GET-2761-015
GET-2761-020
GE Fuse: Standard EG-1, 14.4 kV and 23kV. Current Rating: 20A.
GET-2761-025
GET-2761-030
GET-2761-040
GET-2761-050
GET-2761-065
GET-2761-080
GET-2761-1/2
GE Fuse: Standard EG-1, 14.3 and 23kV, Current Rating: 0.5A,
GET-2761-100
GET-2761-125
GE Fuse: Standard EG-1, 14.4kV and 23kV. Current Rating: 125 A.
GET-2762-001
GE Fuse: Standard EG-1, 34.5, 46, and 69kV, Current Rating: 1A,
GET-2762-002
GE Fuse: Standard EG-1, 34.5, 46, and 69kV. Current Rating: 2A.
GET-2762-003
GE Fuse: Standard EG-1, 34.5, 46 , and 69kV. Current Rating: 3A.
GET-2762-005
GET-2762-007
GET-2762-010
GET-2762-015
GET-2762-020
GET-2762-025

GET-2762-030
GET-2762-040
GE Fuse: Standard EG-1, 34.5, 46, 69kV. Current Rating: 40A.
GET-2762-050
GET-2762-065
GET-2762-080
GET-2762-1/2
GE Fuse: Standard EG-1, 34.5, 46, and 69kV, Current Rating: 0.5A,
GET-2762-100
GET-2762-125
GE Fuse: Standard EG-1, 34.5, 46, and 69kV. Current Rating: 125 A.
GET-2763-001
GE Fuse: Standard EG-1, 92, 115, and 138kV, Current Rating: 1A,
Reference No: GET-1857, GET-2763.
Created 11/4/93.
GET-2763-002
GE Fuse: Standard EG-1, 92, 115, and 138kV. Current Rating: 2A.
Created 11/4/93.
GET-2763-003
Created 11/4/93.
GET-2763-005
Created 11/4/93.
GET-2763-007
Created 11/4/93.
GET-2763-010
GE Fuse: Standard EG-1, 92, a115, and 138kV. Current Rating: 10A.
Created 11/4/93.
GET-2763-015
Created 11/4/93.
GET-2763-020
Created 11/4/93.
GET-2763-025
Created 11/4/93.
GET-2763-030
Created 11/4/93.
GET-2763-040

Created 11/4/93.
GET-2763-050
GE Fuse: Standard EG-1, 92, 115, AND 138kV. Current Rating: 50A.
Created 11/3/93.
GET-2763-065
Created 11/8/93.
GET-2763-080
Created 11/8/93.
GET-2763-1/2
GE Fuse: Standard EG-1, 92, 115, and 138kV, Current Rating: 0.5A,
Created 11/4/93.
GET-2763-100
Created 11/8/93.
GET-2763-125
GE Fuse: Standard EG-1, 92, 115, and 138kV. Current Rating: 125 A.
Created 11/8/93.
GET-2764-020
GE Fuse: Fast-operating EG-1 & EG-1B, 7.2kV. Current Rating: 20A.
Created 11/8/93.
GET-2764-025
Created 11/8/93.
GET-2764-030
Created 11/8/93.
GET-2764-040
Created 11/8/93.
GET-2764-050
Created 11/8/93.
GET-2764-065
Created 11/8/93.
GET-2764-080
Created 11/8/93.
GET-2764-100
Created 11/8/93.
GET-2764-125
Created 11/8/93.
GET-2764-150
Created 11/8/93.

GET-2764-200
Created 11/8/93.
GET-2765-020
GE Fuse: Fast-operating EG-1& EG-1B, 14.4 and 23kV. Current Rating: 20A
GET-2765-025
GET-2765-030
GET-2765-040
GET-2765-050
GET-2765-065
GET-2765-080
GET-2765-100
GE Fuse: Fast-operating EG-1& EG-1B, 14.4 and 23kV. Current Rating:100A
GET-2765-125
GE Fuse: Fast-operating EG-1 & EG-1B
14.4 and 23kV. Current Rating: 125A.
Created 11/8/93.
GET-2765-150
Reference No: GET-1858, GET-2765
Created 11/8/93.
GET-2765-200
Created 11/8/93.
GET-2766-020
34.5, 46, and 69kV. Current Rating: 20A.
Created 11/8/93.
GET-2766-025
Created 11/8/93.
GET-2766-030
Created 11/8/93.
GET-2766-040
Created 11/8/93.
GET-2766-050

Created 11/8/93.
GET-2766-065
Created 11/8/93.
GET-2766-080
Created 11/8/93.
GET-2766-100
Created 11/8/93.
GET-2766-125
Created 11/8/93.
GET-2766-150
Created 11/8/93.
GET-2766-200
GE Fuse: Fast-operating EG-1 & EG-1B, 34.5, 46, and 69kV.
Current Rating: 200A.
Created 11/8/93.
GET-2767-020
GE Fuse: Fast-operating EG-1, 92, 115, and 138kV. Current Rating: 20A.
Created 11/8/93.
GET-2767-025
Created 11/8/93.
GET-2767-030
Created 11/8/93.
GET-2767-040
Created 11/8/93.
GET-2767-050
Created 11/8/93.
GET-2767-065
Created 11/8/93.
GET-2767-080
Created 11/8/93.
GET-2767-100
Created 11/8/93.
GET-2767-125

Created 11/8/93.
IA-201
GE IA-201 overcurrent relay. Created 9/13/94.
IAC-11
GE IAC-11 overcurrent relay, GEH-846B, Created 1/8/95.
IAC-15/17
Very-inverse curves for GE IAC15A, IAC15E, IAC15J, IAC15M,
IAC17A and IAC17D relays. Print K-6209200B. Created 6/19/96.
IAC-51
GE IAC-51 Relay, Inverse curves. Updated 10/25/94.
IAC-52
Same as GE IAC-51 Relay, Inverse curves. Updated 7/17/96.
IAC-53
GE IAC-53 relay, very inverse standard time, GES-7002B.
IAC-54
Same as GE IAC-53 relay, very inverse standard time, GES-7002B.
IAC-55
1. 11/01/91 RJA
IAC-56
1. 11/01/91 RJA
IAC-60
IAC-66
GE IAC-66 relay, Inverse long time, GES-7004B. Created 10/11/94.
IAC-75F
GE IAC-75F relay, Inverse medium short time. GES-7006.
Created 10/11/94.
IAC-77
GE IAC-77 relay, extremely inverse standard time, GES-7005B.
IAC-80
IAC-81
IAC-90
Same as GE IAC-77 relay, extremely inverse standard time, GES-7005B.
IAC-95F
GE IAC-95F relay, Inverse moderate short time, GES-7008.
Created 10/11/94.
IBC-33
GE IAC-33 Relay, very inverse curves. GEH-1159C. 1/7/93.
IBC-3x-I
Inverse Time
Types: IBC31A, 32A, 35A, 36A, 37A & 38A
Instruction book: GEH-1159
Updated: 10/10/02
IBC-3x-VI
Very Inverse Time
Type IBC31A, 32A, 35A, 37A, 38A
Instruction book: GEH-1159
Updated: 10/10/02
IBC-3xA-I
Inverse Time
Type ICB31A, 32A, 35A, 36A, 37A, 38A
Instruction book: GEH-1159A
Updated: 10/10/02
IBC-3xA-VI
Very Inverse Time
Type ICB31A, 32A, 35A, 36A, 37A, 38A

Updated: 10/10/02
IBC-51
IBC-52
IBC-53
IBC-54
IBC-77
IBC-78
IBCG-51
IBCG-52
IBCG-53
IBCG-54
IBCG-77
IBCG-78
IBCV-51
IBCV-52
IBCV-53
IBCV-54
IBCV-77
IBCV-78
IBCx-3xA-VI
Very Inverse Time
Type IBC33A(-)Y1, IBC34A(-)Y1, IBCC33A(-)Y1, IBCC34A(-)Y1, IBCP33A(-)Y1
, IBCP34A(-)Y1
ICC-11A-13A
Time-current curves of
GE ICC11A and ICC13A Relays
Update on 02/21/2003
ICP-11A-14A
Time-current curves of
GE ICP11A and ICP14A Relays
Update on 02/21/2003
IFC-51
IFC-53
GE IFC-53 relay.

IFC-57
GE IFC-57 relay.
IFC-66
GE IFC-66 relay.
IFC-77
GE IFC-77 relay.
IFC-95
GE IFC-95 relay.
IJCV-51_0%
GE Time Overcurrent Relay with Voltage Restraint.
Type: IJCV51 Relays with 0% of Rated Restraint Voltage and
Current Pickup equal to 25% Tap Setting.
Drawing No.:459A228, Sheet 1-0. Created 7/9/97.
IJCV-51_100%
Type: IJCV51 Relays with 100% of Rated Restraint Voltage,
Unity Power Factor and Current Pickup Equal to 100% Tap Setting.
IJCV-51_48%
Unity Power Factor and Current Pickup equal to 52% Tap Setting.
IJCV-51_78%
Unity Power Factor and Current Pickup Equal to 78% Tap Setting.
JBC-51
JBC-52
JBC-53
JBC-54
JBC-77
JBC-78
JBCG-51
JBCG-52
JBCG-53
JBCG-54
JBCG-77
JBCG-78
JBCV-51
JBCV-52

JBCV-53
JBCV-54
JBCV-77
JBCV-78
LPS-EI
GE LPS Extremely Inverse curves.
T=5.64./(M^2.-1) + 0.02434
Created 05/17/2010.
LPS-I
GE LPS Inverse curves.
T=0.0103./(M^0.02.-1) + 0.0228
Created 05/17/2010.
LPS-VI
GE LPS Extremely Inverse curves.
T=3.922./(M^2.-1) + 0.0982
Created 05/18/2010.
MDP_2SD
GE MDP digital, nondirectional relay.
Constant operating time: 2 Second Definite. Created 4/18/94.
MDP_4SD
MDP_6SD
MDP_8SD
MDP_EI
GE MDP digital nondirectional relay. Extremely inverse time curves.
GES-9872. Created 4/24/94.
MDP_I
GE MDP digital nondirectional relay. Inverse time curves.
GES-9869. Created 4/17/94.
MDP_LI
GE MDP digital, nondirectional relay. Long time inverse curves.
GES-9870. Created 4/17/94.
MDP_VI
GE MDP digital nondirectional relay. Very inverse time curves.
GES-9871. Created 4/17/94.
R745-ANSI-EI
GE SR745 Relay, The ANSI TOC shapes. Extremely Inverse
T=M * (A + B/(I/Ipu-C) + D/(I/Ipu-C)^2 + E/(I/Ipu-C)^3)
M=Multipier Setpoint
I=Input Current, Ipu=Pickup Current setpoint
A=0.0399, B=0.2294, C=0.5, D=3.0094, D=0.7222
Created 2003/03/05
R745-ANSI-I
GE SR745 Relay, The ANSI TOC shapes. Normally Inverse
A=0.0274, B=2.2614, C=0.3, D=-4.1899, E=9.1217
R745-ANSI-MI
GE SR745 Relay, The ANSI TOC shapes. Modetately Inverse

A=0.1735, B=0.6791, C=0.8, D=-0.08, E=0.1271
Created 2003/03/05
R745-ANSI-VI
GE SR745 Relay, The ANSI TOC shapes. Very Inverse
A=0.0615, B=0.7989, C=0.34, D=-0.2840, E=4.0505
Created 2003/03/05
R745-IEC-A
GE SR745 Relay, The IEC Curve A
T=M * (K/((I/Ipu)Ê-1) ))
K=0.140, E=0.020
Created 2003/03/11
R745-IEC-B
GE SR745 Relay, The IEC Curve B
T=M * (K/((I/Ipu)Ê-1) ))
K=13.50, E=1.0
Created 2003/03/11
R745-IEC-C
GE SR745 Relay, The IEC Curve C
T=M * (K/((I/Ipu)Ê-1) ))
K=80.0, E=2.0
Created 2003/03/11
R745-IEC-SI
GE SR745 Relay, The IEC Short Inverse Curve
T=M * (K/((I/Ipu)Ê-1) ))
K=0.050, E=0.040
Created 2003/03/11
SFC-EI
GE SFC time-overcurrent relay, extremely inverse, 7/9/93.
SFC-I
GE SFC time-overcurrent relay, inverse, 7/9/93.
SFC-VI
GE SFC time-overcurrent relay, very inverse, 7/9/93.
SFC151
Same as GE SFC time-overcurrent relay, inverse, Updated 7/17/96.
SFC152
Same as GE SFC time-overcurrent relay, inverse, Updated 7/17/96.
SFC153
Same as GE SFC time-overcurrent relay, very inverse, Updated 7/17/96.
SFC154
Same as GE SFC time-overcurrent relay, very inverse, Updated 7/17/96.
SFC177
Same as GE SFC time-overcurrent relay, extremely inverse.
Dwg. No: GEK-36807. Updated 6/2/99.
SFC178
Same as GE SFC time-overcurrent relay, extremely inverse.
Dwg. No: GEK-36807. Updated 6/2/99.
SR469
GE Multilin SR469 Moto Management Relay
Standard Overload Curve
Time dial 1 to 15
Formular: TD*2.2116623/(0.02530337*(Pickup-1)^2 + 0.05054758*(Pickup - 1) )
Created 09/28/2009
TYS
GE standard TYS Relay. GEK-90653. 1/7/93.

UR-IAC-EI
GE Universal Relay.
IAC Extremely Inverse Curve.
UR-IAC-I
GE Universal Relay.
IAC Inverse Curve.
UR-IAC-SI
GE Universal Relay.
IAC Short Inverse curve.
UR-IAC-VI
GE Universal Relay.
IAC Very Inverse Curve.
UR-IEC-A
GE Universal Relay.
IEC Curve A, as defined in IEC255-4 and British standard BS142.
UR-IEC-B
GE Universal Relay.
IEC Curve B, as defined in IEC255-4 and British standard BS142.
UR-IEC-C
GE Universal Relay.
IEC Curve C, as defined in IEC255-4 and British standard BS142.
UR-IEC-SI
GE Universal Relay.
IEC Short Inverse, as defined in IEC255-4 and British standard BS142.
UR-IEEE-EI
GE Universal Relay.
IEEE Extremly Inverse Curve
T=28.2/(M^2-1)+0.1217. Revised 8/19/2004.
UR-IEEE-MI
GE Universal Relay.
IEEE Extremly Inverse Curve
T=0.0515/(M^0.02-1)+0.114 Revised 8/19/2004.
UR-IEEE-VI
GE Universal Relay.
IEEE Very Inverse Curve
T=19.61/(M^2-1)+0.491 Revised 8/19/2004.
VIR-C
GE VIR type C-phase recloser, Curve C, GES-6408. Created 12/6/94.
VIR-C1
GE VIR type C-phase recloser, Curve C1, GES-6408. Created 12/6/94.
VIR-C2
VIR-C3
VIR-CG
GE VIR type ground recloser, Curve CG, GES-6411. Created 12/6/94.
VIR-CG1
GE VIR type ground recloser, Curve CG1, GES-6411. Created 12/6/94.
VIR-CG2
GE VIR type ground recloser, Curve CG2, GES-6411. Created 12/6/94.
VIR-CG3
GE VIR type ground recloser, Curve G3, GES-6411. Created 12/6/94.
Damage curves:
GE_RUPT_100
GE Capacitor Bank Case-Rupture curve, size B 100kVA
Created 11/10/2004
GE_RUPT_150
Created 11/10/2004
GE_RUPT_200
Created 11/10/2004

GE_RUPT_300

HITACHI.RLY
This file contains Hitachi relay curves.
IO-C
Hitachi Over-Current Relay IO-C, IO-O
Time dial: 0.5 - 10
Created 07/07/2008
IO-C-R
Hitachi Over-Current Relay IO-C-R, IO-O-R
Time dial: 0.5 - 10
Created 07/07/2008
IO-CI
Hitachi Over-Current Relay IO-C-B1, IO-CI-B1, IO-C-3R, IO-CI-3R
Time dial: 0.5 - 10
Created 07/07/2008
IO-CIJ
Hitachi Over-Current Relay IO-CIJ-R, IO-OJ-R, IO-OIJ-R
Time dial: 0.5 - 10
Created 07/07/2008
IO-L3R
Hitachi Over-Current Relay IO-L3R
Time dial: 0.5 - 10
Created 07/07/2008
IOM-C-B1
Hitachi Over-Current Relay IOM-C-B1
Time dial: 0.5 - 10
Created 07/07/2008

HITECH.RLY
This file contains Hitech fuse curves.
EXT-HTDE-012
Hi-Tech Trans-guard Fuse, Type EXT, Model HTDS. Curve 12K
No. FC-010; FC-060.
Voltage Rating 8.3kV, 15.5kV.
Created 01/14/2005
EXT-HTDE-025
No. FC-010; FC-060.
Created 01/14/2005
EXT-HTDE-040
No. FC-010; FC-060.
Created 01/14/2005
EXT-HTDE-050
No. FC-010; FC-060.
Created 01/14/2005
EXT-HTDE-065
No. FC-010; FC-060.
Created 01/14/2005
EXT-HTDE-080
No. FC-010; FC-060.
Created 01/14/2005
EXT-HTDE-100
Hi-Tech Trans-guard Fuse, Type EXT, Model HTDS23E100. Curve 100K
Voltage Rating 8.3kV.
Created 02/03/2005
Relays in library J:\ASPEN\CURVES~1\Hi_Tech.rly
FX-HTFX2-003
Hi-Tech Fuse, Type FX, model HTFX2.
No FX-035, FC-081. 8.3kV, 15.5kV, 23kV norminal.
Curve 3 Amp
Created 09/11/2006
FX-HTFX2-006
Curve 6 Amp
Created 09/11/2006
FX-HTFX2-008
Curve 8 Amp
Created 09/11/2006
FX-HTFX2-010
Curve 10 Amp
Created 09/11/2006
FX-HTFX2-012
Curve 12 Amp
Created 09/11/2006
FX-HTFX2-018

Curve 18 Amp
Created 09/11/2006
FX-HTFX2-020
Curve 20 Amp
Created 09/11/2006
FX-HTFX2-025
Curve 25 Amp
Created 09/11/2006
FX-HTFX2-030
Curve 30 Amp
Created 09/11/2006
FX-HTFX2-040
Curve 40 Amp
Created 09/11/2006
FX-HTFX2-050
Curve 50 Amp
Created 09/11/2006
FX-HTFX2-060
Curve 60 Amp
Created 09/11/2006
FX-HTFX2-080
Curve 80 Amp
Created 09/11/2006
FX-HTFX2-100
Curve 100 Amp
Created 09/11/2006
HTSS242--150
Trans-Guard OS Shorty
15.5kV/17.5kV Norminal
Publication: #FC 037/083
Catalog Numbers: HTSS242
Curve: 150A
Created: 02/21/2009
HTSS242--165
Curve: 165A
Created: 02/21/2009
HTSS242--250
Curve: 250A
Created: 02/21/2009

HTSS242--300
Curve: 300A
Created: 02/21/2009
HTSS242-125
Curve: 125A
Created: 02/21/2009
HTSS242-330
Curve: 330A
Created: 02/21/2009
OS-23-030
23.0kV Norminal
Curve: 30A
Created: 12/11/2007
OS-23-040
23.0kV Norminal
Curve: 40A
Created: 12/11/2007
OS-23-050
23.0kV Norminal
Curve: 50A
Created: 12/11/2007
OS-23-065
23.0kV Norminal
Curve: 65A
Created: 12/11/2007
OS-23-080
23.0kV Norminal
Curve: 80A
Created: 12/11/2007
OS-23-100
23.0kV Norminal
Curve: 100A
Created: 12/11/2007
OS-23-130
23.0kV Norminal
Curve: 130A
Created: 12/11/2007
OS-23-160
23.0kV Norminal
Curve: 160A

Created: 12/11/2007
OS-23-200
23.0kV Norminal
Curve: 200A
Created: 12/11/2007
OS-15.3-035
Hi-Tech Fuse, Type OS, Model HTDS. No. FC-005; FC-0051A.
Fuse Rating 35A, 15.5kV. Minimum I/C 380A.
Created 1/19/96.
OS-15.5-040
Hi-Tech Fuse, Type OS, Model HTDS. No. FC-003A; FC-051A.
Created 1/19/96.
OS-15.5-045
Hi-Tech Fuse, Type OS, Model HTDS. No. FC-005; FC-051A.
Created 1/19/96.
OS-15.5-050
Created 1/19/96.
OS-15.5-065
Created 1/19/96.
OS-15.5-080
Created 1/19/96.
OS-15.5-100
Created 1/19/96.
OS-15.5-125
Created 1/19/96.
OS-15.5-150
Created 1/19/96.
OS-15.5-165
Created 1/19/96.
OS-15.5-200
Created 1/19/96.
OS-15.5-250
Created 1/19/96.
OS-15.5-300
Created 1/19/96.
OS-8.3-040
Created 1/19/96.
OS-8.3-050
Created 1/19/96.

OS-8.3-065
Created 1/19/96.
OS-8.3-080
Created 1/19/96.
OS-8.3-100
Created 1/19/96.
OS-8.3-125
Created 1/19/96.
OS-8.3-150
Created 1/19/96.
OS-8.3-165
Created 1/19/96.
OS-8.3-200
Created 1/19/96.
OS-8.3-250
Created 1/19/96.
OS-8.3-300
Created 1/19/96.
OS-HTDS-040C
Fuse Rating 40A, 23.0kV. Minimum Interrupting Current 280A.
Created 2/27/95.
OS-HTDS-150C
Created 2/27/95.
OS-HTDS-175C
Created 2/27/95.
OS-HTSD-050C
Created 2/27/95.
OS-HTSD-065C
Created 2/27/95.
OS-HTSD-100C
Created 2/27/95.
OS-HTSD-125C
Hi-Tech Fuse, Type OS, Model HTDS. No. FC-008A; FC-056A
Created 2/27/95.
SX-HTSX2-005
Hi-Tech Trans-Guard SX full-range current-limiting Fuse, Type SX, Model

HTSX2. No. FC-023, FC-070.
Fuse Rating 5A, 8.3kV, 15.5kV, 23.0kV.
Created 12/13/2004.
SX-HTSX2-010
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-012
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-015
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-020
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-025
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-030
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-040
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-050
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-065
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SX-HTSX2-075
HTSX2. No. FC-023, FC-070.
Created 12/13/2004.
SXHTSX33-090
HTSX33. No. FC-025.
Fuse Rating 90A, 8.3kV.
Created 12/13/2004.
SXHTSX33-100
HTSX33. No. FC-025.
Created 12/13/2004.
SXHTSX33-150
HTSX33. No. FC-025.
Created 12/13/2004.

SXHTSX33-160
HTSX33. No. FC-025.
Created 12/13/2004.
SXHTSX34-090
HTSX34. No. FC-024, FC-071.
Created 12/13/2004.
SXHTSX34-100
HTSX34. No. FC-024, FC-071.
Created 12/13/2004.
SXHTSX34-150
HTSX34. No. FC-024, FC-071.
Created 12/13/2004.

HUBBELL.RLY
This file contains Hubbell Power Systems relay and recloser curves.
VERSA_CLR-D
Hubbell power Systems Versa-Tech recloser clearing TCC
Curve D
Created 03/03/2008
VERSA_CLR-D1
Curve D-MOD1
Created 03/03/2008
VERSA_CLR-D2
Curve D-MOD2
Created 03/03/2008
VERSA_CLR-D3
Curve D-MOD3
Created 03/03/2008
VERSA_CTR-D
Hubbell power Systems Versa-Tech recloser control response TCC
Curve D
Created 03/03/2008
VERSA_CTR-D1
Curve D-MOD1
Created 03/03/2008
VERSA_CTR-D2
Curve D-MOD2
Created 03/03/2008
VERSA_CTR-D3
Curve D-MOD3
Created 03/03/2008
VERSA_CLR-A
Hubbell Power System Versa-Tech recloser clearing TCC
Curve A
Created 2/2/2009
VERSA_CLR-A1
Curve A-MOD1
Created 2/2/2009
VERSA_CLR-A2
Curve A-MOD2
Created 2/2/2009
VERSA_CLR-A3
Curve A-MOD3
Created 2/2/2009
VERSA_CLR-C
Curve C
Created 1/21/2009
VERSA_CLR-C1
Curve C-MOD1
Created 1/21/2009
VERSA_CLR-C2
Curve C-MOD2
Created 1/21/2009

VERSA_CLR-C3
Curve C-MOD3
Created 1/21/2009
VERSA_CTR-A
Hubbell Power System Versa-Tech recloser control TCC
Curve A
Created 2/2/2009
VERSA_CTR-A1
Curve A-MOD1
Created 2/2/2009
VERSA_CTR-A2
Curve A-MOD2
Created 2/2/2009
VERSA_CTR-A3
Curve A-MOD3
Created 2/2/2009
VERSA_CTR-C
Curve C
Created 1/21/2009
VERSA_CTR-C1
Curve C-MOD1
Created 1/21/2009
VERSA_CTR-C2
Curve C-MOD2
Created 1/21/2009
VERSA_CTR-C3
Curve C-MOD3
Created 1/21/2009
VERSA_CL_EF
Curve EF
Created 02/04/2009
VERSA_CL_EF1
Curve EF-MOD1
Created 02/04/2009
VERSA_CL_EF2
Curve EF-MOD2
Created 02/04/2009
VERSA_CL_EF3
Curve EF-MOD3
Created 02/04/2009
VERSA_CL_F
Curve F
Created 02/04/2009
VERSA_CL_F1
Curve F-MOD1
Created 02/04/2009
VERSA_CL_F2
Curve F-MOD2
Created 02/04/2009
VERSA_CL_F3

Curve F-MOD3
Created 02/04/2009
VERSA_CL_KF
Curve KF
Created 02/04/2009
VERSA_CL_KF1
Curve KF-MOD1
Created 02/04/2009
VERSA_CL_KF2
Curve KF-MOD2
Created 02/04/2009
VERSA_CL_KF3
Curve KF-MOD3
Created 02/04/2009
VERSA_CL_N
Curve N
Created 02/04/2009
VERSA_CL_N1
Curve N-MOD1
Created 02/04/2009
VERSA_CL_N2
Curve N-MOD2
Created 02/04/2009
VERSA_CL_N3
Curve N-MOD3
Created 02/04/2009
VERSA_CL_R
Curve R
Created 02/04/2009
VERSA_CL_R1
Curve R-MOD1
Created 02/04/2009
VERSA_CL_R2
Curve R-MOD2
Created 02/04/2009
VERSA_CL_R3
Curve R-MOD3
Created 02/04/2009
VERSA_CL_TF
Curve TF
Created 02/04/2009
VERSA_CL_TF1
Curve TF-MOD1
Created 02/04/2009
VERSA_CL_TF2
Curve TF-MOD2
Created 02/04/2009
VERSA_CL_TF3
Curve TF-MOD3
Created 02/04/2009

VERSA_CLR_B
Curve B
Created 02/04/2009
VERSA_CLR_B1
Curve B-MOD1
Created 02/04/2009
VERSA_CLR_B2
Curve B-MOD2
Created 02/04/2009
VERSA_CLR_B3
Curve B-MOD3
Created 02/04/2009
VERSA_CLR_E
Curve E
Created 02/04/2009
VERSA_CLR_E1
Curve E-MOD1
Created 02/04/2009
VERSA_CLR_E2
Curve E-MOD2
Created 02/04/2009
VERSA_CLR_E3
Curve E-MOD3
Created 02/04/2009
VERSA_CT_EF
Curve EF
Created 02/04/2009
VERSA_CT_EF1
Curve EF-MOD1
Created 02/04/2009
VERSA_CT_EF2
Curve EF-MOD2
Created 02/04/2009
VERSA_CT_EF3
Curve EF-MOD3
Created 02/04/2009
VERSA_CT_F
Curve F
Created 02/04/2009
VERSA_CT_F1
Curve F-MOD1
Created 02/04/2009
VERSA_CT_F2
Curve F-MOD2
Created 02/04/2009
VERSA_CT_F3
Curve F-MOD3
Created 02/04/2009
VERSA_CT_KF

Curve KF
Created 02/04/2009
VERSA_CT_KF1
Curve KF-MOD1
Created 02/04/2009
VERSA_CT_KF2
Curve KF-MOD2
Created 02/04/2009
VERSA_CT_KF3
Curve KF-MOD3
Created 02/04/2009
VERSA_CT_N
Curve N
Created 02/04/2009
VERSA_CT_N1
Curve N-MOD1
Created 02/04/2009
VERSA_CT_N2
Curve N-MOD2
Created 02/04/2009
VERSA_CT_N3
Curve N-MOD3
Created 02/04/2009
VERSA_CT_R
Curve R
Created 02/04/2009
VERSA_CT_R1
Curve R-MOD1
Created 02/04/2009
VERSA_CT_R2
Curve R-MOD2
Created 02/04/2009
VERSA_CT_R3
Curve R-MOD3
Created 02/04/2009
VERSA_CT_TF
Curve TF
Created 02/04/2009
VERSA_CT_TF1
Curve TF-MOD1
Created 02/04/2009
VERSA_CT_TF2
Curve TF-MOD2
Created 02/04/2009
VERSA_CT_TF3
Curve TF-MOD3
Created 02/04/2009
VERSA_CTR_B
Curve B
Created 02/04/2009

VERSA_CTR_B1
Curve B-MOD1
Created 02/04/2009
VERSA_CTR_B2
Curve B-MOD2
Created 02/04/2009
VERSA_CTR_B3
Curve B-MOD3
Created 02/04/2009
VERSA_CTR_E
Curve E
Created 02/04/2009
VERSA_CTR_E1
Curve E-MOD1
Created 02/04/2009
VERSA_CTR_E2
Curve E-MOD2
Created 02/04/2009
VERSA_CTR_E3
Curve E-MOD3
Created 02/04/2009

JOSLYN.RLY
This file contains Joslyn relay and recloser curves.
FM 2000 EI
Joslyn Faultmaster 2000 Time Overcurrent Curves: Extremely Inverse.
Created 3/19/97.
FM 2000 MI
Joslyn Faultmaster 2000 Time Overcurrent Curves: Moderately Inverse.
Created 3/19/97.
FM 2000 NI
Joslyn Faultmaster 2000 Time Overcurrent Curves: Normally Inverse.
Ceated 3/19/97.
FM 2000 VI
Joslyn Faultmaster 2000 Time Overcurrent Curves: Very Inverse.
Created 3/19/97.
Trimod_A
Joslyn TriMod recloser
Curve A
Created 06/10/2004
Trimod_A_M1
Curve A MOD1
Created 06/10/2004
Trimod_A_M2
Curve A MOD2
Created 06/10/2004
Trimod_A_M3
Curve A MOD3
Created 06/10/2004
Trimod_B
Curve B
Created 06/10/2004
Trimod_B_M1
Curve B MOD1
Created 06/10/2004
Trimod_B_M2
Curve B MOD2
Created 06/10/2004
Trimod_B_M3
Curve B MOD3
Created 06/10/2004
Trimod_C
Curve C
Created 06/10/2004
Trimod_C_M1
Curve C MOD1
Created 06/10/2004
Trimod_C_M2
Curve C MOD2
Created 06/10/2004
Trimod_C_M3
Curve C MOD3
Created 06/10/2004

Trimod_D
Curve D
Created 06/10/2004
Trimod_D_M1
Curve D MOD1
Created 06/10/2004
Trimod_D_M2
Curve D MOD2
Created 06/10/2004
Trimod_D_M3
Curve D MOD3
Created 06/10/2004
Trimod_E
Curve E
Created 06/10/2004
Trimod_E_M1
Curve E MOD1
Created 06/10/2004
Trimod_E_M2
Curve E MOD2
Created 06/10/2004
Trimod_E_M3
Curve E MOD3
Created 06/10/2004
Trimod_EF
Curve EF
Created 06/10/2004
Trimod_EF_M1
Curve EF MOD1
Created 06/10/2004
Trimod_EF_M2
Curve EF MOD2
Created 06/10/2004
Trimod_EF_M3
Curve EF MOD3
Created 06/10/2004
Trimod_EI_01
Extremely inverse curve, time dial=1
Created 06/10/2004
Trimod_EI_02
Created 06/10/2004
Trimod_EI_03
Created 06/10/2004
Trimod_EI_04
Created 06/10/2004
Trimod_EI_05

Created 06/10/2004
Trimod_EI_06
Created 06/10/2004
Trimod_EI_07
Created 06/10/2004
Trimod_EI_08
Created 06/10/2004
Trimod_EI_09
Created 06/10/2004
Trimod_EI_10
Created 06/10/2004
Trimod_EI_11
Created 06/10/2004
Trimod_EI_12
Created 06/10/2004
Trimod_EI_13
Created 06/10/2004
Trimod_EI_14
Created 06/10/2004
Trimod_EI_15
Created 06/10/2004
Trimod_EI_16
Created 06/10/2004
Trimod_EI_17
Created 06/10/2004
Trimod_EI_18
Created 06/10/2004
Trimod_EI_19
Created 06/10/2004
Trimod_EI_20
Created 06/10/2004
Trimod_EI_21
Created 06/10/2004

Trimod_EI_22
Created 06/10/2004
Trimod_EI_23
Created 06/10/2004
Trimod_EI_24
Created 06/10/2004
Trimod_EI_25
Created 06/10/2004
Trimod_EI_26
Created 06/10/2004
Trimod_EI_27
Created 06/10/2004
Trimod_EI_28
Created 06/10/2004
Trimod_EI_29
Created 06/10/2004
Trimod_EI_30
Created 06/10/2004
Trimod_EI_31
Created 06/10/2004
Trimod_EI_32
Created 06/10/2004
Trimod_F
Curve F
Created 06/10/2004
Trimod_F_M1
Curve F MOD1
Created 06/10/2004
Trimod_F_M2
Curve F MOD2
Created 06/10/2004
Trimod_F_M3
Curve F MOD3
Created 06/10/2004
Trimod_I_01
Inverse curve, time dial=1
Created 06/10/2004
Trimod_I_02

Created 06/10/2004
Trimod_I_03
Created 06/10/2004
Trimod_I_04
Created 06/10/2004
Trimod_I_05
Created 06/10/2004
Trimod_I_06
Created 06/10/2004
Trimod_I_07
Created 06/10/2004
Trimod_I_08
Created 06/10/2004
Trimod_I_09
Created 06/10/2004
Trimod_I_10
Created 06/10/2004
Trimod_I_11
Created 06/10/2004
Trimod_I_12
Created 06/10/2004
Trimod_I_13
Created 06/10/2004
Trimod_I_14
Created 06/10/2004
Trimod_I_15
Created 06/10/2004
Trimod_I_16
Created 06/10/2004
Trimod_I_17
Created 06/10/2004
Trimod_I_18
Created 06/10/2004

Trimod_I_19
Created 06/10/2004
Trimod_I_20
Created 06/10/2004
Trimod_I_21
Created 06/10/2004
Trimod_I_22
Created 06/10/2004
Trimod_I_23
Created 06/10/2004
Trimod_I_24
Created 06/10/2004
Trimod_I_25
Created 06/10/2004
Trimod_I_26
Created 06/10/2004
Trimod_I_27
Created 06/10/2004
Trimod_I_28
Created 06/10/2004
Trimod_I_29
Created 06/10/2004
Trimod_I_30
Created 06/10/2004
Trimod_I_31
Created 06/10/2004
Trimod_I_32
Created 06/10/2004
Trimod_KF
Curve KF
Created 06/10/2004
Trimod_KF_M1
Curve KF MOD1
Created 06/10/2004
Trimod_KF_M2

Curve KF MOD2
Created 06/10/2004
Trimod_KF_M3
Curve KF MOD3
Created 06/10/2004
Trimod_MI_01
Moderate inverse curve, time dial=1
Created 06/10/2004
Trimod_MI_02
Created 06/10/2004
Trimod_MI_03
Created 06/10/2004
Trimod_MI_04
Created 06/10/2004
Trimod_MI_05
Created 06/10/2004
Trimod_MI_06
Created 06/10/2004
Trimod_MI_07
Created 06/10/2004
Trimod_MI_08
Created 06/10/2004
Trimod_MI_09
Created 06/10/2004
Trimod_MI_10
Created 06/10/2004
Trimod_MI_11
Created 06/10/2004
Trimod_MI_12
Created 06/10/2004
Trimod_MI_13
Created 06/10/2004
Trimod_MI_14
Created 06/10/2004
Trimod_MI_15
Created 06/10/2004

Trimod_MI_16
Created 06/10/2004
Trimod_MI_17
Created 06/10/2004
Trimod_MI_18
Created 06/10/2004
Trimod_MI_19
Created 06/10/2004
Trimod_MI_20
Created 06/10/2004
Trimod_MI_21
Created 06/10/2004
Trimod_MI_22
Created 06/10/2004
Trimod_MI_23
Created 06/10/2004
Trimod_MI_24
Created 06/10/2004
Trimod_MI_25
Created 06/10/2004
Trimod_MI_26
Created 06/10/2004
Trimod_MI_27
Created 06/10/2004
Trimod_MI_28
Created 06/10/2004
Trimod_MI_29
Created 06/10/2004
Trimod_MI_30
Created 06/10/2004
Trimod_MI_31
Created 06/10/2004
Trimod_MI_32

Created 06/10/2004
Trimod_N
Curve N
Created 06/10/2004
Trimod_N_M1
Curve N MOD1
Created 06/10/2004
Trimod_N_M2
Curve N MOD2
Created 06/10/2004
Trimod_N_M3
Curve N MOD3
Created 06/10/2004
Trimod_R
Curve R
Created 06/10/2004
Trimod_R_M1
Curve R MOD1
Created 06/10/2004
Trimod_R_M2
Curve R MOD2
Created 06/10/2004
Trimod_R_M3
Curve R MOD3
Created 06/10/2004
Trimod_TF
Curve TF
Created 06/10/2004
Trimod_TF_M1
Curve TF MOD1
Created 06/10/2004
Trimod_TF_M2
Curve TF MOD2
Created 06/10/2004
Trimod_TF_M3
Curve TF MOD3
Created 06/10/2004
Trimod_VI_01
Very inverse curve, time dial=1
Created 06/10/2004
Trimod_VI_02
Created 06/10/2004
Trimod_VI_03
Created 06/10/2004
Trimod_VI_04
Created 06/10/2004

Trimod_VI_05
Created 06/10/2004
Trimod_VI_06
Created 06/10/2004
Trimod_VI_07
Created 06/10/2004
Trimod_VI_08
Created 06/10/2004
Trimod_VI_09
Created 06/10/2004
Trimod_VI_10
Created 06/10/2004
Trimod_VI_11
Created 06/10/2004
Trimod_VI_12
Created 06/10/2004
Trimod_VI_13
Created 06/10/2004
Trimod_VI_14
Created 06/10/2004
Trimod_VI_15
Created 06/10/2004
Trimod_VI_16
Created 06/10/2004
Trimod_VI_17
Created 06/10/2004
Trimod_VI_18
Created 06/10/2004
Trimod_VI_19
Created 06/10/2004
Trimod_VI_20
Created 06/10/2004
Trimod_VI_21

Created 06/10/2004
Trimod_VI_22
Created 06/10/2004
Trimod_VI_23
Created 06/10/2004
Trimod_VI_24
Created 06/10/2004
Trimod_VI_25
Created 06/10/2004
Trimod_VI_26
Created 06/10/2004
Trimod_VI_27
Created 06/10/2004
Trimod_VI_28
Created 06/10/2004
Trimod_VI_29
Created 06/10/2004
Trimod_VI_30
Created 06/10/2004
Trimod_VI_31
Created 06/10/2004
Trimod_VI_32
Created 06/10/2004

KEARNEY.RLY
This file contains Kearney fuse curves.
124080DUAL05
Kearney Type 124080 Dual Element Fuse Link (5 amp).
Drawing No.: 124080 A and 124080 B. Created 6/15/98.
124080DUAL06
124080DUAL08
124080DUAL12
124080DUAL15
124080DUAL25
124080DUAL30
124080DUAL35
KRNY-K006
Kearney "K" type fuse 6 Amps
KRNY-K008
KRNY-K010
KRNY-K012
KRNY-K015
KRNY-K020
KRNY-K025
KRNY-K030
KRNY-K040
KRNY-K050
KRNY-K065
KRNY-K080
KRNY-K100
KRNY-K140
KRNY-K200
KRNY-KS005
Kearney type KS fuse link 5 Amps
KRNY-KS007
Kearney KS type fuse 7 Amps

KRNY-KS010
KRNY-KS015
Kearney KS type fuse 15A
KRNY-KS020
KRNY-KS025
Kearney KS type fuse 25A
KRNY-KS030
KRNY-KS040
KRNY-KS050
Kearney type KS fuse 50 Amps
KRNY-KS065
KRNY-KS080
KRNY-KS100
Kearny KS type fuse 100 Amps
KRNY-KS125
Kearny KS type fuse 125 Amps
KRNY-KS150
KRNY-KS200
KRNY-N007
Kearney N200-7A
KRNY-N010
Kearney N200-10A
KRNY-N015
Kearney N200-15A
KRNY-N020
Kearney N200-20A
KRNY-N025
Kearney N200-25A
KRNY-N030
Kearney N200-30A
KRNY-N040
Kearney fuse, type N200-40A. No 11000B.
Modified 3/5/96.
KRNY-N050
Kearney N200-50A
KRNY-N065
Kearney type N (200) fuse: 65 A.
KRNY-N080
Kearney type N(200) fuse: 80A
KRNY-N100
KRNY-N125
KRNY-N150
Kearney type N(200) fuse:150A
KRNY-N175
Kearney N200-175A
KRNY-N200
Kearney type N(200) fuse:200A
KRNY-QA005
Kearney "QA" type fuse 5 Amps
KRNY-QA007
KRNY-QA010

KRNY-QA015
KRNY-QA020
KRNY-QA025
KRNY-QA030
KRNY-QA040
KRNY-QA050
KRNY-QA060
KRNY-QA075
KRNY-QA100
KRNY-QA125
KRNY-QA150
KRNY-QA175
KRNY-QA200
KRNY-T006
Kearney "T" type fuse 6 Amps
KRNY-T008
KRNY-T010
KRNY-T012
KRNY-T015
KRNY-T020
KRNY-T025
Kearney type "T" fuse 25 Amps
KRNY-T030
KRNY-T040
KRNY-T050
KRNY-T065
KRNY-T080
KRNY-T100
KRNY-T140
KRNY-T200
KRNY-X01
KRNY_X0.33
KEARNEY TYPE X 1/3A FUSE LINK IN KEARNEY CUTOUTS
RATING 1/3 AMP

KRNY_X0.5
KRNY_X0.75
KRNY_X01.25
KRNY_X01.5
KRNY_X02
KRNY_X02.5
KRNY_X02.75
KRNY_X03.5
KRNY_X04
KRNY_X07
KRNY_X10
KRNY_X15
KRNY_X5.5

MERLIN_GERIN.RLY
This file contains Merlin-Gerin relay curves.
DIT5-250-1
MERLIN GERIN TRIP CURVES WITH DIT 5. Current Transformer Ie=250A.
SETTING RANGE 0.65 TO 1*Ie. Curve 1: Max Cold. Ref. No. C49757100.
Created 7/8/96.
DIT5-250-2
SETTING RANGE 0.65 TO 1*Ie. Curve 2: Min Cold. Ref. No. C49757100.
Created 7/8/96.
DIT5-250-3
SETTING RANGE 0.65 TO 1*Ie. Curve 3: Min with I=0.8 rated
before overload. Ref. No. C49757100. Created 7/8/96.
DIT5-250-4
SETTING RANGE 0.65 TO 1*Ie. Curve 4: Min with I=1 rated
before overload. Ref. No. C49757100. Created 7/8/96.
DIT5-630-1
MERLIN GERIN TRIP CURVES WITH DIT 5. CURRENT TRANSFORMER Ie=630A.
SETTING RANGE 0.65 TO 1*Ie. Curve 1: Max Cold. Ref No. C49757100.
Created 7/8/96.
DIT5-630-2
SETTING RANGE 0.65 TO 1*Ie. Curve 2: Min Cold. Ref No. C49757100.
Created 7/8/96.
DIT5-630-3
SETTING RANGE 0.65 TO 1*Ie. Curve 3: Min with I=0.8 rated
before overload. Ref No. C49757100. Created 7/8/96.
DIT5-630-4
SETTING RANGE 0.65 TO 1*Ie. Curve 4: Min with I=1 rated
before overload. Ref No. C49757100. Created 7/8/96.

MISUBISHI.RLY
This file contains Misubishi relay curves.
CGP2-10-M3
Misubishi Over-Current Relay CGP2-10-M3, CGP3-10-M3, CGP4-10-M3
Time dial: 0.5-10
Created 07/07/2008
CO
Mitsubishi Over-Current Relay CO
Time dial: 0.5 - 10
Created 07/07/2008
CO-16
Misubishi Over-Current Relay CO-16, CO-16I-D
Time dial: 0.5-10
Created 07/07/2008
CO-18-D
Misubishi Over-Current Relay CO-18-D, CO-18I-D
Time dial: 0.5-10
Created 07/07/2008
CO-1I
Misubishi Over-Current Relay CO-1I
Time dial: 0.5-10
Created 07/07/2008
CO-4
Misubishi Over-Current Relay CO-4, CO-4I
Time dial: 0.5-10
Created 07/07/2008
CO-5I
Misubishi Over-Current Relay CO-5I
Time dial: 0.5-10
Created 07/07/2008
CO-H
Misubishi Over-Current Relay CO-H
Time dial: 0.5-10
Created 07/07/2008
CO-T
Misubishi Over-Current Relay CO-T
Time dial: 0.5-10
Created 07/07/2008
COA-4I
Misubishi Over-Current Relay COA-4I
Time dial: 0.5-10
Created 07/07/2008
COC1-11-M1
Misubishi Over-Current Relay COC1-11-M1, COC2-11-M1, COC3-11-M1 ( NI )
Time dial: 0.5 - 10
Created 07/07/2008
COC3-21-M1
Misubishi Over-Current Relay CO3-21-M1 ( NI )
Time dial: 0.5-10
Created 07/07/2008
COT-4
Misubishi Over-Current Relay COT-4, COT-4I
Time dial: 0.5-10
Created 07/07/2008
MOC-1-R
Misubishi Over-Current Relay MOC-1-R, MOC-1A-R, MOC-1T-R, MOC-1N-R, MOC-1I-R
Time dial: 0.5-10
Created 07/07/2008
MOC-1AI-R
Misubishi Over-Current Relay MOC-1AI-R, MOC-1NI-R, MOC-1TI-R
Time dial: 0.5-10
Created 07/07/2008
MOC-1I-D
Misubishi Over-Current Relay MOC-1I-D
Time dial: 0.5-10

Created 07/07/2008
MOC-2-R
Misubishi Over-Current Relay MOC-2-R, MOC-2I-R, MOC-2TI-R, MOC-2B-R, MOC-2IB-R
Time dial: 0.5-10
Created 07/07/2008
MOC-A1V-R-EI
Misubishi Over-Current Relay MOC-A1V-R (EI)
Time dial: 0.5-10
Created 07/07/2008
MOC-A1V-R-NI
Misubishi Over-Current Relay MOC-A1V-R (NI)
Time dial: 0.5-10
Created 07/07/2008
MOC-E1V-R
Misubishi Over-Current Relay MOC-E1V-R, MOC-E1T-R
Time dial: 0.5-10
Created 07/07/2008

MULTILIN.RLY
This file contains Multilin relay curves.
269/169-C1
MULTILIN 269/169 Relay,
Standard Overload Curve 1. Created 2/28/95.
269/169-C2
Standard Overload Curve 2. Created 2/28/95.
269/169-C3
Standard overload Curve 3. Created 2/28/95.
269/169-C4
269/169-C5
269/169-C6
269/169-C7
269/169-C8
MTLN_F60-EI
Multilin F60 feeder management relay
Extreme Inverse curves
T=D*[a+b/(M-c)+d/(M-c)^2+e/(M-c)^3].
a=0.004, b=0.6379, c=0.620, d=1.7872, e=0.2461
Created 2003-07-15
MTLN_F60-I
Inverse curve
T=D*[a+b/(M-c)+d/(M-c)^2+e/(M-c)^3].
a=0.2078, b=0.863, c=0.800, d=-0.418, e=0.1947
Created 2003-07-15
MTLN_F60-VI
Very Inverse curves
T=D*[a+b/(M-c)+d/(M-c)^2+e/(M-c)^3].
a=0.090, b=0.7955, c=0.100, d=-1.2885, e=7.9586
Created 2003-07-15
MTLN_MIF-EI
Multilin MIF digital feeder protection relay
Extreme Inverse curves
T=D*[a+b/(M-c)+d/(M-c)^2+e/(M-c)^3].
a=0.0399, b=0.2294, c=0.500, d=3.0094, e=0.7222
Created 2003-07-15
MTLN_MIF-I
Inverse curves
T=D*[a+b/(M-c)+d/(M-c)^2+e/(M-c)^3].
a=0.0274, b=2.2614, c=0.300, d=--4.1899, e=9.1272
Created 2003-07-15
MTLN_MIF-VI
Very Inverse curves
T=D*[a+b/(M-c)+d/(M-c)^2+e/(M-c)^3].
a=0.0615, b=0.7989, c=0.3400, d=-0.2840, e=4.0505
Updated 2004-04-16
MTLN565-EI-G
Multilin 565 Feeder Relay, Extremely Inverse Time/Ground Overcurrent

Curves. Created 6/19/96.
MTLN565-EI-P
Multilin 565 Feeder relay, Extremely Inverse Time/Phase Overcurrent
MTLN565-MI-G
Multilin 565 feeder relay, Moderately Inverse Time/Ground Overcurrent
MTLN565-MI-P
Multilin 565 feeder relay, Moderately inverse Time/Phase Overcurrent
curves. Created 6/19/96.
MTLN565-NI-G
Multilin 565 feeder relay, Normal Inverse Time/Ground Overcurrent
MTLN565-NI-P
Multilin 565 feeder relay, Normal Inverse Time/Phase Overcurrent
MTLN565-VI-G
Multilin 565 feeder relay, Very Inverse Time/Ground Overcurrent
MTLN565-VI-P
Multilin 565 feeder relay, Very Inverse Time/Phase Overcurrent
MTLN565IEC-A
Multilin 565/575 Feeder relay.
IEC-A (normal Inverse) Curves. T=0.14*D/(M**0.02-1)/20
Creadted 9/20/96.
MTLN565IEC-B
IEC-B Curves. T=13.5*D/(M-1)/20
Creadted 9/20/96.
MTLN565IEC-C
IEC-C Curves. T=80*D/(M**2-1)/20
Creadted 9/20/96.
SR735-DT-0.5
ANSI DEFINITE TIME, for Multilin SR735/SR737 Feeder Relay. T=S*M*0.1;
S=0.5; Created 7/17/96.
SR735-DT-0.8
S=0.8; Created 7/17/96.
SR735-DT-1.1
S=1.1; Created 7/17/96.
SR735-EI-0.5
ANSI EXTREMELY INVERSE, for Multilin SR735/SR737 Feeder Relay.
T=S*M*(A+B/(I/Ipu+C)+D/(I/Ipu)^2+E/(I/Ipu)^3); S=0.5; A=0.0399;
B=0.2294; C=0.500; D=3.0094; E=0.7222; Created 7/9/96.
SR735-EI-0.8
B=0.2294; C=0.500; D=3.0094; E=0.7222; Created 7/9/96.
SR735-EI-1.1
B=0.2294; C=0.500; D=3.0094; E=0.7222; Created 7/9/96.
SR735-MI-0.5
ANSI MODERATELY INVERSE, for Multilin SR735/SR737 Feeder Relays.
B=0.6791; C=0.8000; D=-0.0800; E=0.1271; Created 7/9/96.
SR735-MI-0.8
ANSI MODERATELY INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=0.6791; C=0.8000; D=-0.0800; E=0.1271; Created 7/9/96.
SR735-MI-1.1
ANSI MODERATELY INVERSE, for Multilin SR735/SR737Feeder Relay.

B=0.6791; C=0.8000; D=-0.0800; E=0.1271; Created 7/9/96.
SR735-NI-0.5
ANSI NORMAL INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=2.2614; C=0.3000; D=-4.1899; E=9.1272; Created 7/9/96.
SR735-NI-0.8
ANSI NORMAL INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=2.2614; C=0.3000; D=-4.1899; E=9.1272; Created 7/9/96.
SR735-NI-1.1
ANSI NORMAL INVERSE, for Multilin SR735/SR737 Feeder Relays.
B=2.2614; C=0.3000; D=-4.1899; E=9.1272; Created 7/9/96.
SR735-VI-0.5
ANSI VERY INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=0.7989; C=0.3400; D=-0.2840; E=4.0505; Created 7/9/96.
SR735-VI-0.8
B=0.7989; C=0.3400; D=-0.2840; E=4.0505; Created 7/9/96.
SR735-VI-1.1
B=0.7989; C=0.3400; D=-0.2840; E=4.0505; Created 7/9/96.
SR735/737-DT
Multilin SR735/SR737 Feeder Relays, ANSI Definite time:
T=S*M*0.1; S=1.0; Updated 7/17/96.
SR735/737-EI
Multilin SR735/SR737 Feeder Relays, ANSI Extremely Inverse:
T=S*M*(A+B/(I/Ipu+C)+D/(I/Ipu)^2+E/(I/Ipu)^3); S=1.0;
A=0.0399; B=0.2294; C=0.500; D=3.0094; E=0.7222; Updated 7/9/96.
SR735/737-I
Multilin SR735/SR737 Feeder Relays, ANSI normal inverse:
B=2.2614; C=0.3000; D=-4.1899; E=9.1272; Updated 7/9/96.
SR735/737-MI
Multilin SR735/SR737 Feeder Relay, ANSI Moderately Inverse.
B=0.6791; C=0.8000; D=-0.0800; E=0.1271; Updated 7/11/96.
SR735/737-VI
Multilin SR735/SR737 Feeder Relays, ANSI Very Inverse:
B=0.7989; C=0.3400; D=-0.2840; E=4.0505; Updated 7/9/96.
SR735IAC-EI
IAC EXTREMELY INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=0.638; C=0.620; D=1.787; E=0.246; Created 7/11/96.
SR735IAC-I
IAC INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=0.863; C=0.8 D=-0.418; E=0.1947; Created 7/11/96.
SR735IAC-SI
IAC SHORT INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=0.061; C=0.620; D=-0.001; E=0.022; Created 7/9/96.
SR735IAC-VI
IAC VERY INVERSE, for Multilin SR735/SR737 Feeder Relay.
B=0.796; C=0.100; D=-1.289; E=7.959; Created 7/11/96.
SR735IACE0.5
B=0.638; C=0.620; D=1.787; E=0.246; Created 7/11/96.
SR735IACE0.8

B=0.638; C=0.620; D=1.787; E=0.246; Created 7/11/96.
SR735IACE1.1
B=0.638; C=0.620; D=1.787; E=0.246; Created 7/11/96.
SR735IACI0.5
B=0.863; C=0.8; D=-0.418; E=0.1947; Created 7/9/96.
SR735IACI0.8
B=0.863; C=0.8; D=-0.418; E=0.1947; Created 7/11/96.
SR735IACI1.1
B=0.863; C=0.8; D=-0.418; E=0.1947; Created 7/11/96.
SR735IACS0.5
B=0.061; C=0.620; D=-0.001; E=0.022; Created 7/9/96.
SR735IACS0.8
B=0.061; C=0.620; D=-0.001; E=0.022; Created 7/9/96.
SR735IACS1.1
B=0.061; C=0.620; D=-0.001; E=0.022; Created 7/9/96.
SR735IACV0.5
B=0.796; C=0.100; D=-1.289; E=7.959; Created 7/11/96.
SR735IACV0.8
B=0.796; C=0.100; D=-1.289; Created 7/11/96.
SR735IACV1.1
B=0.796; C=0.100; D=-1.289; E=7.959; Created 7/11/96.
SR735IEC-A
IEC-A(NORMAL INVERSE) Curves for MULTILIN Feeder Relays: SR735/SR737.
T=S*M*K/((I/IO)**E-1); S=1.0, K=0.14, E=0.020. Created 7/11/96.
SR735IEC-B
IEC-B(VERY INVERSE) Curves for MULTILIN Feeder Relays: SR735/SR737.
SR735IEC-C
IEC-C(EXTREMELY INVERSE) Curves for MULTILIN Feeder Relays:
SR735/SR737.
SR735IEC-ST
IEC Short Time Curves for MULTILIN Feeder Relays: SR735/SR737.
SR735IECA0.5
SR735IECA0.8
SR735IECA1.1
SR735IECB0.5

SR735IECB0.8
SR735IECB1.1
SR735IECC0.5
SR735/SR737.
SR735IECC0.8
SR735/SR737.
SR735IECC1.1
SR735/SR737.
SR735IECS0.5
SR735IECS0.8
SR735IECS1.1
SR750-IAC-EI
Multilin SR750/SR760 Feeder Relay, IAC Extreme Inverse.
T=M*(A+B/(I/Ipu-C)+D/(I/Ipu-C)**2+E/(I/Ipu-C)**3); A=0.0040; B=0.6379;
C=0.6200; D=1.7872; E=0.2461; Created 7/12/96.
SR750-IAC-I
Multilin SR750/SR760 Feeder Relay, IAC Inverse.
C=0.8000; D=-0.4180; E=0.1947; Created 7/12/96.
SR750-IAC-SI
Multilin SR750/SR760 Feeder Relay, IAC short inverse.
C=0.6200; D=-0.0010; E=0.0221; Created 7/12/96.
SR750-IAC-VI
Multilin SR750/SR760 Feeder Relay, IAC Very Inverse.
C=0.1000; D=-1.2885; E=7.9586; Created 7/12/96.
SR750-IEC-A
Multilin SR750/SR760 Feeder Relay.
IEC Curve A: T=0.14*D/(M**0.02-1); Created 7/12/96.
SR750-IEC-B
IEC Curve B: T= 13.5*D/(M-1); Created 7/12/96.
SR750-IEC-C
IEC Curve C: T=80*D/(M**2-1); Created 7/12/96.
SR750ANSI-DT
Multilin SR750/SR760 Feeder Relay, ANSI Definite Time.
T=M**0.1; Created 7/12/96.
SR750ANSI-EI
Multilin SR750/SR760 Feeder Relay, ANSI Extremely Inverse.
C=0.5000; D=3.0094; E=0.7222; Created 7/12/96.
SR750ANSI-MI
Multilin SR750/SR760 Feeder Relay, ANSI Moderate Inverse.
C=0.8000; D=-0.0800; E=0.1271; Created 7/12/96.
SR750ANSI-NI
Multilin SR750/SR760 Feeder Relay, ANSI Normal Inverse.

C=0.3000; D=-4.1899; E=9.1272; Created 7/12/96.
SR750ANSI-VI
Multilin SR750/SR760 Feeder Relay, ANSI Very Inverse.
C=0.3400; D=-0.2840; E=4.0505; Created 7/12/96.

NU-LEC.RLY
This file contains NU-LEC Industries relay curves.
NULEC-N-010
Nu-Lec N series non-standard Inverse Time Protection.
Curve TCC 010
NULEC-N-101
Curve TCC 101
NULEC-N-102
Curve TCC 102
NULEC-N-103
Curve TCC 103
NULEC-N-104
Curve TCC 104
NULEC-N-105
Curve TCC 105
NULEC-N-106
Curve TCC 106
NULEC-N-107
Curve TCC 107
NULEC-N-111
Curve TCC 111
NULEC-N-112
Curve TCC 112
NULEC-N-113
Curve TCC 113
NULEC-N-114
Curve TCC 114
NULEC-N-115
Curve TCC 115
NULEC-N-116
Curve TCC 116
NULEC-N-117
Curve TCC 117

NULEC-N-118
Curve TCC 118
NULEC-N-119
Curve TCC 119
NULEC-N-120
Curve TCC 120
NULEC-N-121
Curve TCC 121
NULEC-N-122
Curve TCC 122
NULEC-N-131
Curve TCC 131
NULEC-N-132
Curve TCC 132
NULEC-N-133
Curve TCC 133
NULEC-N-134
Curve TCC 143
NULEC-N-135
Curve TCC 135
NULEC-N-136
Curve TCC 136
NULEC-N-137
Curve TCC 137
NULEC-N-138
Curve TCC 138
NULEC-N-139
Curve TCC 139
NULEC-N-140
Curve TCC 140
NULEC-N-141
Curve TCC 141
NULEC-N-142

Curve TCC 142
NULEC-N-151
Curve TCC 151
NULEC-N-152
Curve TCC 152
NULEC-N-161
Curve TCC 161
NULEC-N-162
Curve TCC 162
NULEC-N-163
Curve TCC 163
NULEC-N-164
Curve TCC 164
NULEC-N-165
Curve TCC 165
NULEC-N-200
Curve TCC 200
NULEC-N-201
Curve TCC 201
NULEC-N-202
Curve TCC 202

NXTPHASE.RLY
This file contains NxtPhase relay curves.
8700-IEC-EI
NxtPhase T-PRO 8700 relay
IEC extremely inverse curve
T=D*[80/(M^2-1)]
Created 2003/04/21
8700-IEC-I
IEC standard inverse curve
T=D*[0.14/(M^0.02-1)]
Created 2003/04/21
8700-IEC-VI
IEC very inverse curve
T=D*[13.5/(M^1-1)]
Created 2003/04/21
8700-IEEE-EI
IEEE extremely inverse curve
T=D*[5.64/(M^2-1) + 0.0243)
Created 2003/04/21
8700-IEEE-I
IEEE standard inverse curve
T=D*[5.95/(M^2-1) + 0.18)
Created 2003/04/21
8700-IEEE-MI
IEEE moderately inverse curve
T=D*[.0103/(M^0.02-1) + 0.0228)
Created 2003/04/21
8700-IEEE-VI
IEEE very inverse curve
T=D*[3.922/(M^2-1) + 0.0982)
Created 2003/04/21

OMRON.RLY
This file contains Omron relay curves.
CHS-CH
OMRON (TATEISHI) Over-Current Relay COS-CH
Time dial: 0.5 - 10
Created 07/07/2008
CO-C
OMRON (TATEISHI) Over-Current Relay CO-C
Time dial: 0.5 - 10
Created 07/07/2008
CO-C3HT
OMRON (TATEISHI) Over-Current Relay CO-C3HT
Time dial: 0.5 - 10
Created 07/07/2008
CO-CHT
OMRON (TATEISHI) Over-Current Relay CO-CHT
Time dial: 0.5 - 10
Created 07/07/2008
CO-CHT-R1
OMRON (TATEISHI) Over-Current Relay CO-CHT-R1, CO-CHT-R2, CO-CHT-D2
Time dial: 0.5 - 10
Created 07/07/2008
CO-LAH
OMRON (TATEISHI) Over-Current Relay COS-LAH, CO-LA3
Time dial: 0.5 - 10
Created 07/07/2008
CO-OHT
OMRON (TATEISHI) Over-Current Relay CO-OHT
Time dial: 0.5 - 10
Created 07/07/2008
COS-C
OMRON (TATEISHI) Over-Current Relay COS-C, COS-CH, COS-CHT
Time dial: 0.5 - 10
Created 07/07/2008
COS-CHT-R2
OMRON (TATEISHI) Over-Current Relay COS-CHT-R2, COS-C3HT-R2
Time dial: 0.5 - 10
Created 07/07/2008
COS-O
OMRON (TATEISHI) Over-Current Relay COS-O, COS-OH
Time dial: 0.5 - 10
Created 07/07/2008
COS-O-F4
OMRON (TATEISHI) Over-Current Relay COS-O-F4, COS-O-R2
Time dial: 0.5 - 10
Created 07/07/2008
COS-OHT-F4
OMRON (TATEISHI) Over-Current Relay COS-OHT-F4, COS-OHT-R2
Time dial: 0.5 - 10
Created 07/07/2008
K2CA-DO-F4
OMRON (TATEISHI) Over-Current Relay K2CA-D0-F4
Time dial: 0.25 - 10
Created 07/07/2008
K2CA-DO3-R2
OMRON (TATEISHI) Over-Current Relay K2CA-DO3-R2
Time dial: 0.5 - 10
Created 07/07/2008
TO-O
OMRON (TATEISHI) Over-Current Relay TO-O
Time dial: 0.5 - 10
Created 07/07/2008

REYROLLE.RLY
This file contains Reyrolle relay curves.
IDMT
IDMT: IDMT Normal Inverse Relay. 2TJM10 Series. Created 7/8/97.

RTE.RLY
This file contains RTE fuse link curves.
1559B-A1
RTE Isolation Fuse Link: 15559B-A1. Catalog No.: 3001861A.
Created 11/4/99.
1559B-A2
Created 11/4/99.
1559B-A3
Created 11/4/99.
1559B-A5
Created 11/4/99.
1559B-A6
Created 11/4/99.
1559B-A7
Created 11/4/99.
BAY-0-NET003
RTE Components, BAY-O-NET Dual Sensing Fuse 358C Fuse Links.
In transformer oil. 3A.
Fuse Link Nos. C3, Catalog No. 4000358C M. Created 6/17/96.
BAY-0-NET008
BAY-0-NET015
BAY-0-NET025
BAY-0-NET050
BAY-0-NET065
BAY-0-NET140
C-S-BAY006
RTE Components, BAY-O-NET Current (Fault) Sensing 353C Fuse Links. 6A.
Fuse Link Nos. C4, Catalog No. 4000353C-M. Created 5/30/96.
C-S-BAY010
C-S-BAY015
C-S-BAY025
C-S-BAY040

C-S-BAY065
C-S-BAY100
RTE Components, BAY-O-NET Current(Fault) Sensing 353C Fuse Links. 100A.
C-S-BAY140
RTE Components, BAY-O-NET Current(Fault) Sensing 353C Fuse Links. 140A.

S&C.RLY
This file contains S&C fuse curves and Vista underground distribution switchgear curves.
The naming convention follows S&C's TCC number designation for the total-clear curve. The TCC number
of a fuse is in the form of WWW-X-Y-Z, where each letter represent a digit between 0 and 9. Here is how
you can decipher a TCC number:
WWW=Speed Characteristics:
111 Standard (Liquid)
115 Standard (Liquid, SMD, SM, SMU — VTs)
119 Slow (Liquid, SMD, SMU, SM)
123 Standard (Fuse Links)
129 Slow (Liquid)
153 Standard (SMD, SMU, SM)
156 Slow (Liquid — VTs)
161 Time Lag (Liquid)
165 K (SMU, Fuse Links)
166 QR (Fuse Links)
167 N (Fuse Links)
170 T (Fuse Links)
172 Coordinating (Fuse Links)
173 Coordinating (SM)
176 Very Slow (SMD, SMU)
179 Coordinating (SM)
400 Instantaneous Curve (Fault Fiter)
410 Inverse Curve (Fault Fiter)
420 Compound Curve (Fault Fiter)
421 Time-Delayed Compound Curve (Fault Fiter)
422 Underground Subloop Curve (Fault Fiter)
450 Fault Tamer Fuse Limiters
680 S&C Overcurrent Control (Vista) — “E” Standard
685 S&C Overcurrent Control (Vista) — Tap Interrupter
690 S&C Overcurrent Control (Vista) — Main Interrupter
695 S&C Overcurrent Control (Vista) — Instantaneous
696 S&C Overcurrent Control (Vista) — Definite Time
697 S&C Overcurrent Control (Vista) — Instant. and Definite Time
X=Fuse type
1 SMD
2 SMU
3 HSO
4 SM
5 Liquid
6 Fuse Links
7 Fault Fiter
8 Fault Tamer
9 S&C Overcurrent Control (Vista)
Y=Voltage rating
1 7.2 kV and below
2* 14.4 kV
3 23 kV, 25 kV
4 34.5 kV
5 46 kV
6 69 kV

7 (Unassigned)
8 (Unassigned)
9 115/138 kv
(Note): Fuse links, Fault Fiter, and S&C Overcurrent Control are voltage independent. The '2' simply
means total-clear curve.
Z=Fuse type (for SMD and SMU only)

1 SMD-1A
2 SMD-2C
3 (Unassigned)
4 SMU-40
5 SMD-50
The fuse names in this file are in the form of WWW-XYZ-R, where R is the rating in amperes. (We
omitted the dashes between X, Y and Z for brevity.)
For fuses that are made up of two fuse links in parallel, the last part of the fuse name is based on the
combined
current rating, instead of the 2X designation used by S&C. For example, the name 153-214-600 is for the
2x300E fuse pair whose total-clear curve comes from TCC 153-2-1-4.
111-5-003
S&C Liquid Power Fuses - Standard Speed - Size 3,4 and 5
TCC No. 111-5
Curve 3E
Created 07/06/2006
111-5-005
TCC No. 111-5
Curve 5E
Created 07/06/2006
111-5-007
TCC No. 111-5
Curve 7E
Created 07/06/2006
111-5-010
TCC No. 111-5
Curve 10E
Created 07/06/2006
111-5-013
TCC No. 111-5
Curve 13E
Created 07/06/2006
111-5-015
TCC No. 111-5
Curve 15E
Created 07/06/2006
111-5-020
TCC No. 111-5
Curve 20E
Created 07/06/2006
111-5-025
TCC No. 111-5
Curve 25E
Created 07/06/2006
111-5-030

TCC No. 111-5
Curve 30E
Created 07/06/2006
111-5-040
TCC No. 111-5
Curve 40E
Created 07/06/2006
111-5-050
TCC No. 111-5
Curve 50E
Created 07/06/2006
111-5-065
TCC No. 111-5
Curve 65E
Created 07/06/2006
111-5-080
TCC No. 111-5
Curve 80E
Created 07/06/2006
111-5-100
TCC No. 111-5
Curve 100E
Created 07/06/2006
111-5-125
TCC No. 111-5
Curve 125E
Created 07/06/2006
111-5-150
TCC No. 111-5
Curve 150E
Created 07/06/2006
111-5-175
TCC No. 111-5
Curve 175E
Created 07/06/2006
111-5-200
TCC No. 111-5
Curve 200E
Created 07/06/2006
111-5-250
TCC No. 111-5
Curve 250E
Created 07/06/2006
115-151-001
S&C Power Fuses - Type SMD-1A (34.5 and 46 kV) 1Amp.
Standard Speed (TCC 115-1-5-1)
Created 2005/05/12
119-151-015
Slow speed fuse unit SMD-1A 34.5kV and 46 kV.

119-151-020
119-151-025
119-151-030
119-151-040
119-151-050
119-151-065
119-151-080
119-151-100
119-151-125
119-151-150
119-151-175
119-151-200
119-152-015
Slow speed fuse unit SMD-2C 34.5kV and 46 kV.
119-152-020
119-152-025
119-152-030
119-152-040
119-152-050
119-152-065
119-152-080
119-152-100
119-152-125
119-152-150
119-152-175
119-152-200
119-152-250
119-152-300
119-152-400
119-152-500
119-152-600
119-155-015
Slow speed fuse unit SMD-50 34.5kV and 46 kV.
119-155-020
119-155-025
119-155-030
119-155-040
119-155-050
119-155-065
119-155-080
119-155-100
119-16-015
Slow speed fuse unit SMD-2B and SMD-3 69 kV. Also for previous design
SMD-2 and SMD-2A rated 34.5-69 kV.

119-16-020
119-16-025
119-16-030
119-16-040
119-16-050
119-16-065
119-16-080
119-16-100
119-16-125
119-16-150
119-16-175
119-16-200
119-16-250
119-16-300
119-16-400
119-16-500
119-16-600
119-161-015
Slow speed fuse unit SMD-1A 69 kV.
119-161-020
119-161-025
119-161-030
119-161-040
119-161-050
119-161-065
119-161-080
119-161-100
119-161-125
119-161-150
119-161-175
119-161-200
119-165-015
Slow speed fuse unit SMD-50 69 kV.
119-165-020
119-165-025
119-165-030
119-165-040
119-165-050
119-165-065
119-165-080
119-165-100
119-19-015
Slow speed fuse unit SMD-1A and SMD-2B rated 115kV and 138 kV. Also for
previous design SMD-2

119-19-020
119-19-025
119-19-030
119-19-040
119-19-050
119-19-065
119-19-080
119-19-100
119-19-125
119-19-150
119-19-175
119-19-200
119-19-250
119-214-015
Slow speed fuse unit SMU-20 (14.4-34.5 kV) and SMD-40 (4.8-25 kV). Also
for previous design SMD-20
119-214-020
119-214-025
119-214-030
119-214-040
119-214-050
119-214-065
119-214-080
119-214-100
119-214-125
119-214-150
119-214-175
119-214-200
119-214-250
119-214-300
119-214-400
119-214-500
119-214-600
119-214-800
119-22-015
Slow speed fuse unit SMU-20 14.4kV
119-22-020
119-22-025
119-22-030
119-22-040
119-22-050
119-22-065
119-22-080
119-22-100
119-22-125
119-22-150
119-22-175
119-22-200
119-234-015
Slow speed fuse unit SMU-40 14.4kV and 25 kV.

119-234-020
119-234-025
119-234-030
119-234-040
119-234-050
119-234-065
119-234-080
119-234-100
119-234-125
119-234-150
119-234-175
119-234-200
119-234-250
119-234-300
119-234-400
119-234-500
119-234-600
119-234-800
119-24-015
Slow speed fuse unit SMU-20 25kV and 34.5kV.
119-24-020
119-24-025
119-24-030
119-24-040
119-24-050
119-24-065
119-24-080
119-24-100
119-24-125
119-24-150
119-24-175
119-24-200
119-42-015
Slow speed refill unit SM-4 (7.2kV and 14.4kV) and SM-5 (4.16-14.4kV)
119-42-020
119-42-025
119-42-030
119-42-040
119-42-050
119-42-065
119-42-080
119-42-100
119-42-125
119-42-150
119-42-175
119-42-200
119-42-250
119-42-300
119-42-400
119-42-500
119-42-600
119-42-800
119-44-015
Slow speed refill unit SM-4 and SM-5 25kV and 34.5kV.

119-44-020
119-44-025
119-44-030
119-44-040
119-44-050
119-44-065
119-44-080
119-44-100
119-44-125
119-44-150
119-44-175
119-44-200
119-44-250
119-44-300
119-5-3-100E
S&C Liquid Power Fuse 100E
Slow speed, size 3,4,5 7.5kV and 23kV
119-5-3-125E
119-5-3-150E
119-5-3-15E
119-5-3-200E
119-5-3-20E
119-5-3-250E
119-5-3-25E
119-5-3-30E
119-5-3-40E
119-5-3-50E
119-5-3-65E
119-5-3-80E

119-5-6-100e
119-5-6-125e
119-5-6-150E
119-5-6-15E
119-5-6-200E
119-5-6-20E
119-5-6-250E
119-5-6-25E
119-5-6-30E
119-5-6-40E
119-5-6-50E
119-5-6-65E
119-5-6-80e
119-5-9-100E
Slow speed, size 3,4,5 115kV and 138kV
119-5-9-125E
119-5-9-150E

119-5-9-15E
119-5-9-200E
119-5-9-20E
119-5-9-250E
119-5-9-25E
119-5-9-30E
S&C Liquid Power Fuse30E
119-5-9-40E
119-5-9-50E
119-5-9-65E
119-5-9-80E
123-8-001
S&C Fault Tamer Fuse limiters -S&C Standard Speed
TCC 123-8-3 and TCC 123-8
Curve 1 Amp
Created 11/23/2009
123-8-002
TCC 123-8-3 and TCC 123-8
Curve 2 Amps
Created 11/23/2009
123-8-003
TCC 123-8-3 and TCC 123-8
Curve 3 Amps
Created 11/23/2009
123-8-005
TCC 123-8-3 and TCC 123-8
Curve 5 Amps
Created 11/23/2009
123-8-007
TCC 123-8-3 and TCC 123-8
Curve 7 Amps
Created 11/23/2009
123-8-010

TCC 123-8-3 and TCC 123-8
Curve 10 Amps
Created 11/23/2009
123-8-015
TCC 123-8-3 and TCC 123-8
Curve 15 Amps
Created 11/23/2009
123-8-020
TCC 123-8-3 and TCC 123-8
Curve 20 Amps
Created 11/23/2009
123-62-1
Standard speed fuse link 1A
123-62-10
123-62-100
123-62-125
123-62-15
123-62-150
123-62-2
123-62-20
123-62-200
123-62-25
123-62-3
123-62-30
123-62-40
123-62-5
123-62-50
123-62-65
123-62-7
123-62-80
153-151-003
Standard speed fuse unit SMD-1A 34.5kV and 46kV. Created 3/20/2001

153-151-005
153-151-007
153-151-010
153-151-013
153-151-015
153-151-020
153-151-025
153-151-030
153-151-040
153-151-050
153-151-065
153-151-080
153-151-100
153-151-125
153-151-150
153-151-175
153-151-200
153-152-003
Standard speed fuse unit SMD-2C 34.5kV and 46kV. Created 3/20/2001
153-152-005
153-152-007
153-152-010
153-152-013
153-152-015
153-152-020
153-152-025
153-152-030
153-152-040
153-152-050
153-152-065
153-152-080
153-152-100
153-152-125
153-152-150
153-152-175
153-152-200
153-152-250
153-152-300
153-152-400
153-152-500
153-152-600
153-155-015
Standard speed fuse unit SMD-50 34.5kV and 46kV.
153-155-020
153-155-025
153-155-030
153-155-040
153-155-050
153-155-065
153-155-080
153-155-100
153-16-015
Standard speed fuse unit SMD-2B and SMD-4 69kV. Also for previous desig
n SMD-2 and SMD-2A, 34.5KV-69kV.

153-16-020
153-16-025
153-16-030
153-16-040
153-16-050
153-16-065
153-16-080
153-16-100
153-16-125
153-16-150
153-16-175
153-16-200
153-16-250
153-16-300
153-16-400
153-16-500
153-16-600
153-161-015
Standard speed fuse unit SMD-1A 69kV.
153-161-020
153-161-025
153-161-030
153-161-040
153-161-050
153-161-065
153-161-080
153-161-100
153-161-125
153-161-150
153-161-175
153-161-200
153-165-015
Standard speed fuse unit SMD-50 69kV.
153-165-020
153-165-025
153-165-030
153-165-040
153-165-050
153-165-065
153-165-080
153-165-100
153-19-015
Standard speed fuse unit SMD-1A and SMD-2B, 115kV and 138kV. Also for p
revious design SMD-2.

153-19-020
153-19-025
153-19-030
153-19-040
153-19-050
153-19-065
153-19-080
153-19-100
153-19-125
153-19-150
153-19-175
153-19-200
153-19-250
153-2-005
Standard speed fuse unit SMU-20 (14.4-34.5kV) and SMU-40 (4.8-25kV)
153-2-007
153-2-010
153-2-013
153-2-015
153-2-020
153-2-025
153-2-030
153-2-040
153-2-050
153-2-065
153-2-080
153-2-100
153-2-125
153-2-150
153-2-175
153-2-200
153-214-015
Standard speed fuse unit SMU-40 4.8kV.
153-214-020
153-214-025
153-214-030
153-214-040
153-214-050
153-214-065
153-214-080
153-214-100
153-214-125
153-214-150
153-214-175
153-214-200
153-214-250
153-214-300
153-214-400
153-214-500
153-214-600
153-214-800
153-22-015
Standard speed fuse unit SMU-20 14.4kV.

153-22-020
153-22-025
153-22-030
153-22-040
153-22-050
153-22-065
153-22-080
153-22-100
153-22-125
153-22-150
153-22-175
153-22-200
153-234-015
Standard speed fuse unit SMU-40 14.4kV and 25kV.
153-234-020
153-234-025
153-234-030
153-234-040
153-234-050
153-234-065
153-234-080
153-234-100
153-234-125
153-234-150
153-234-175
153-234-200
153-234-250
153-234-300
153-234-400
153-234-500
153-234-600
153-234-800
153-24-015
Standard speed fuse unit SMU-20 25kV and 34.5kV.
153-24-020
153-24-025
153-24-030
153-24-040
153-24-050
153-24-065
153-24-080
153-24-100
153-24-125
153-24-150
153-24-175
153-24-200
153-42-003
Standard speed refill unit SM-4 (7.2kV and 14.4kV) and SM-5 (4.16-14.4k
V)

153-42-005
153-42-007
153-42-010
153-42-013
153-42-015
153-42-020
153-42-025
153-42-030
153-42-040
153-42-050
153-42-065
153-42-080
153-42-100
153-42-125
153-42-150
153-42-175
153-42-200
153-42-250
153-42-300
153-42-400
153-42-500
153-42-600
153-42-800
153-44-003
Standard speed refill unit SM-4 and SM-5 25kV and 34.5kV.
153-44-005
153-44-007
153-44-010
153-44-013
153-44-015
153-44-020
153-44-025
153-44-030
153-44-040
153-44-050
153-44-065
153-44-080
153-44-100
153-44-125
153-44-150
153-44-175
153-44-200
153-44-250
153-44-300
165-10-030M
S&C Tripsaver Dropout Recloser
Curve minimum tripping delayed 30K
TCC 165-10
Created 11/23/2009
165-10-030MF
Curve minimum tripping Fast 30K
TCC 165-10
Created 11/23/2009
165-10-030T
Curve total clearing 30K
TCC 165-10-2
Created 11/23/2009

165-10-030TF
Curve total clearing Fast 030K
TCC 165-10-2
Created 11/23/2009
165-10-050M
S&C Tripsaver dropout recloser
TCC-165-10
Curve Minimum Tripping 50K
Created 09/28/2006
165-10-050MF
TCC-165-10
Curve Minimum Tripping Fast 50K
Created 09/28/2006
165-10-050T
TCC-165-10-2
Curve Total Clearing 50K
Created 09/28/2006
165-10-050TF
TCC-165-10-2
Curve Total Clearing Fast 50K
Created 09/28/2006
165-10-100M
TCC-165-10
Curve Minimum Tripping 100K
Created 09/28/2006
165-10-100MF
TCC-165-10
Curve Minimum Tripping Fast 100K
Created 09/28/2006
165-10-100T
TCC-165-10-2
Curve Total Clearing 100K
Created 09/28/2006
165-10-100TF
TCC-165-10-2
Curve Total Clearing Fast 100K
Created 09/28/2006
165-22-003
"K" speed fuse unit SMU-20. 14.4kV.
165-22-006
165-22-008
165-22-010
165-22-012
165-22-015
165-22-020
165-22-025
165-22-030
165-22-040
165-22-050
165-22-065
165-22-080
165-22-100
165-22-140
165-22-200
165-24-003
"K" speed fuse unit SMU-20 25kV and 34.5kV.

165-24-006
165-24-008
165-24-010
165-24-012
165-24-015
165-24-020
165-24-025
165-24-030
165-24-040
165-24-050
165-24-065
165-24-080
165-24-100
165-24-140
165-24-200
165-62-10
S&C positrol fuse link "K" speed 10A
165-62-100
165-62-12
165-62-140
165-62-15
165-62-20
165-62-200
165-62-25
165-62-30
165-62-40
165-62-50
165-62-6
165-62-65
165-62-8
165-62-80
166-62-1
S&C positrol fuse link "QR" speed 1A
166-62-10
166-62-100
S&C positrol fuse link "QR" speed 100 Amps
166-62-125
166-62-15
166-62-150
166-62-175
166-62-2

166-62-20
166-62-200
S&C positrol fuse link "QR" speed200 Amps
166-62-25
166-62-3
166-62-30
166-62-40
166-62-5
166-62-50
166-62-60
166-62-7
166-62-75
167-62-10
S&C positrol fuse link "N" speed 10A
167-62-100
167-62-125
167-62-15
167-62-150
167-62-20
167-62-200
167-62-25
167-62-30
167-62-40
167-62-45
167-62-5
167-62-50
167-62-65
167-62-75
167-62-8
167-62-85
167-62-95
Relays in library J:\ASPEN\Curves library\S&C.rly
170-10-020M
Curve minimum tripping delayed 20T
TCC 170-10

Created 11/23/2009
170-10-020MF
Curve minimum tripping Fast 20T
TCC 170-10
Created 11/23/2009
170-10-020T
Curve total clearing delayed 20T
TCC 170-10
Created 11/23/2009
170-10-020TF
Curve total clearing Fast 20T
TCC 170-10-2
Created 11/23/2009
170-10-030M
TCC 170-10
Created 11/23/2009
170-10-030MF
TCC 170-10
Created 11/23/2009
170-10-030T
TCC 170-10
Created 11/23/2009
170-10-030TF
TCC 170-10-2
Created 11/23/2009
170-10-065M
TCC 170-10
Created 11/23/2009
170-10-065MF
TCC 170-10
Created 11/23/2009
170-10-065T
TCC 170-10
Created 11/23/2009
170-10-065TF
TCC 170-10-2
Created 11/23/2009
170-10-230T
TCC-170-10-2
Curve Total Clearing 30 T delayed
Created 05/30/2008
170-10-230TF
TCC-170-10-2
Curve Total Clearing 30T Fast
Created 05/30/2008

170-10-265T
TCC-170-10-2
Curve Total Clearing 65T delayed
Created 05/30/2008
170-10-265TF
TCC-170-10-2
Curve Total Clearing 65 T Fast
Created 05/30/2008
170-10-30MF
TCC-170-10
Curve Minimum tripping30T Fast
Created 05/30/2008
170-10-35M
TCC-170-10
Curve Minimum tripping30T delayed
Created 05/30/2008
170-10-65M
TCC-170-10
Curve Minimum tripping65T delayed
Created 05/30/2008
170-10-65MF
TCC-170-10
Curve Minimum tripping65T fast
Created 05/30/2008
170-62-10
S&C positrol fuse link "T" speed 10A
170-62-100
170-62-12
170-62-140
170-62-15
170-62-20
170-62-200
170-62-25
170-62-30
170-62-40
170-62-50
170-62-6
170-62-65
170-62-8
170-62-80
172-62-101
S&C positrol fuse link coordinating speed 101A
172-62-102

172-62-103
173-42-410
Coordinating speed refill unit SM-5 7.2kV and 14.4kV.
173-42-420
175-6-10DR
S&C Positrol Fuse Links
Universal and Extra Performance Styles
"DR" Speed (TCC 175-6)
Curver 10DR
Created 2005/12/07
175-6-15DR
Curver 15DR
Created 2005/12/07
175-6-20DR
Curver 20DR
Created 2005/12/07
175-6-3DR
Curver 3DR
Created 2005/12/07
175-6-4DR
Curver 4DR
Created 2005/12/07
175-6-5RD
Curver 5DR
Created 2005/12/07
175-6-7DR
Curver 7DR
Created 2005/12/07
176-151-050
Very slow speed fuse unit SMD-1A 34.5kV and 46kV.
176-151-065
176-151-080
176-151-100
176-151-125
176-151-150
176-151-175
176-151-200
176-152-050
Very slow speed fuse unit SMD-2C 34.5kV and 69kV.

176-152-065
176-152-080
176-152-100
176-152-125
176-152-150
176-152-175
176-152-200
176-152-250
176-152-350
176-152-400
176-152-500
176-16-050
Very slow speed fuse unit SMD-2B and SMD-3 69kV.
176-16-065
176-16-080
176-16-100
176-16-125
176-16-150
176-16-175
176-16-200
176-16-250
176-16-350
176-16-400
176-16-500
176-161-050
Very slow speed fuse unit SMD-1A 69kV.
176-161-065
176-161-080
176-161-100
176-161-125
176-161-150
176-161-175
176-161-200
176-19-050
Very slow speed fuse unit SMD-1A and SMD-2B 115kV and 138kV.
176-19-065
176-19-080
176-19-100
176-19-125
176-19-150
176-19-175
176-19-200
176-19-250
176-22-050
Very slow speed fuse unit SMU-20 14.4kV.
176-22-065
176-22-080
176-22-100
176-22-125
176-22-150
176-22-175
176-22-200
176-24-050
Very slow speed fuse unit SMU-20 25kV and 34.5kV.

176-24-065
176-24-080
176-24-100
176-24-125
176-24-150
176-24-175
176-24-200
179-42-210
410-72-0400
S&C Fault Fiter Electronic Fuse: Inverse-curve-type Control Module.
Minimum Pickup: 400A.
TCC No: 410-7-2.
Catalog No: 814040.
Created 4/14/93.
410-72-0500
S&C Fault Fiter Electronic Fuse:
Inverse-curve-type Control Module.
TCC No: 410-7-2.
Catalog No: 814050.
Created 4/14/93.
410-72-0600
TCC No: 410-7-2.
Catalog No: 814060.
Created 4/14/93.
410-72-0700
TCC No: 410-7-2.
Catalog No: 814070.
Created 4/14/93.
410-72-0800
TCC No:410-7-2.
Catalog No: 814080.
Created 4/14/93.
410-72-1000
TCC No: 410-7-2.
Catalog No: 814100.
Created 4/14/93.
410-72-1250
TCC No: 410-7-2.
Catalog No: 814125.
Created 4/14/93.
410-72-1500
TCC No: 410-7-2.
Catalog No: 814150.
Created 4/14/93.
421-7-104003
S&C Fault Fiter Electronic Power Fuse.
Time-Delayed Compound-Curve-Type Control Module( TCC-421-7)

Short time delay band 1. Min PU=400A. High I PU: 3kA.
Created 11/19/2004
421-7-104006
Created 11/19/2004
421-7-106003
Created 11/19/2004
421-7-106006
Created 11/19/2004
421-7-108003
Created 11/19/2004
421-7-108006
Created 11/19/2004
421-7-111003
Created 11/19/2004
421-7-111006
Created 11/19/2004
421-7-204003
Created 11/19/2004
421-7-204006
Created 11/19/2004
421-7-206003
Created 11/19/2004
421-7-206006
Created 11/19/2004
421-7-208003
Created 11/19/2004
421-7-208006
Created 11/19/2004

421-7-211003
Created 11/19/2004
421-7-211006
Created 11/19/2004
421-7-304003
Created 11/19/2004
421-7-304006
Created 11/19/2004
421-7-306003
Created 11/19/2004
421-7-306006
Created 11/19/2004
421-7-308003
Created 11/19/2004
421-7-308006
Created 11/19/2004
421-7-311003
Created 11/19/2004
421-7-311006
Created 11/19/2004
421-7-404003
Created 11/19/2004
421-7-404006
Created 11/19/2004
421-7-406003
Created 11/19/2004
421-7-406006

Created 11/19/2004
421-7-408003
Created 11/19/2004
421-7-408006
Created 11/19/2004
421-7-411003
Created 11/19/2004
421-7-411006
Created 11/19/2004
450-8-003
S&C Fault Tamer Fuse limiters
TCC 450-8-3 and TCC 450-8
Curve 3 Amps
Created 11/23/2009
450-8-005
TCC 450-8-3 and TCC 450-8
Curve 5 Amps
Created 11/23/2009
450-8-007
TCC 450-8-3 and TCC 450-8
Curve 7 Amps
Created 11/23/2009
450-8-010
TCC 450-8-3 and TCC 450-8
Curve 10 Amps
Created 11/23/2009
450-8-015
TCC 450-8-3 and TCC 450-8
Curve 15 Amps
Created 11/23/2009
450-8-020
TCC 450-8-3 and TCC 450-8
Curve 20 Amps
Created 11/23/2009
680-9_100E
S&C Tap Fault Interrupter 100E.
TCC Number 680-9 and 680-9-2. Created 1/4/2000.
680-9_125E
680-9_150E
680-9_175E
680-9_200E

680-9_25E
680-9_30E
680-9_40E
680-9_50E
680-9_65E
680-9_80E
685-9_100A
S&C Tap Fault Interrupter 100A.
685-9_150A
685-9_200A
685-9_250A
685-9_300A
685-9_350A
685-9_400A
685-9_50A
685-9_65A
685-9_80A
690-9_100A
S&C Main Fault Interrupter 100A.
690-9_150A
690-9_200A
690-9_250A
690-9_300A

690-9_350A
690-9_400A
690-9_450A
690-9_500A
690-9_600A
690-9_700A
690-9_800A
C40S1T1-S105
S&C Fault Fiter.
Catalog No: 7010-C40S1T1-S105.
Created 1/10/94.
SMU-20-10E
Same as curve 153-2-010.
SMU-20_100E
SMU-20_125E
SMU-20_13E
SMU-20_150E
SMU-20_15E
SMU-20_175E
SSame as curve 153-2-175.
SMU-20_200e
SMU-20_20E
SMU-20_25E
SMU-20_30E
SMU-20_40E
SMU-20_50E
SMU-20_5E
SMU-20_65E
SMU-20_7E
SMU-20_80E

SCHNEIDER_ELECTRIC.RLY
This file contains Schneider Electric fuse curves.
S20-I
Schneider Electric Sepam Series 20 digital relay.
Standard inverse curve.
t=(k/(D^p - 1))*T/b
k=0.14, p=0.02, b=2.97
Time dial range= 0.04 to 4.2
Created 04/24/2008
S20-LI
Long time inverse curve.
t=(k/(D^p - 1))*T/b
k=120, p=1, b=13.33
Created 04/24/2008
S20-UI
Ultra-inverse curve.
t=(k/(D^p - 1))*T/b
k=315.2, p=2.5, b=1
Created 04/24/2008
S20-VI
Very inverse curve.
t=(k/(D^p - 1))*T/b
k=13.5, p=1, b=1.5
Created 04/24/2008
S20-IAC-EI
IAC inverse curve.
t=(A+B/(I/Is - C)+D/(I/Is - C)^2 +E/(I/Is - C)^3)*T/b
A=0.004, B=0.638, C=0.62,D=1.787,E=0.246,b=0.092
Created 11/06/2006
S20-IAC-I
IAC inverse curve.
A=0.208, B=0.863, C=0.8,D=-0.418,E=0.195,b=0.297
Created 11/06/2006
S20-IAC-VI
IAC Very inverse curve.
A=0.09, B=0.795, C=0.1,D=-1.288,E=7.958,b=0.165
Created 11/06/2006
S20-IEC-EI
IEC Standard inverse curve.
t=(k/(D^p - 1))*T/b
k=80, p=2, b=0.808
Created 11/06/2006
S20-IEC-I
IEC Standard inverse curve.
t=(k/(D^p - 1))*T/b
k=0.14, p=0.02, b=2.97
Created 11/06/2006

S20-IEC-LI
IEC long time inverse curve.
t=(k/(D^p - 1))*T/b
k=120, p=1, b=13.33
Created 11/06/2006
S20-IEC-UI
IEC Ultra-inverse curve.
t=(k/(D^p - 1))*T/b
k=315.2, p=2.5, b=1
Created 11/06/2006
S20-IEC-VI
IEC Very inverse curve.
t=(k/(D^p - 1))*T/b
k=13.5, p=1, b=1.5
Created 11/06/2006
S20-IEEE-EI
IEEE Extremely inverse curve.
t=(A/(D^p - 1)+ B)*T/b
A=5.64, B=0.0243, p=2, b=0.081
Created 11/06/2006
S20-IEEE-MI
IEEE Moderately inverse curve.
t=(A/(D^p - 1)+ B)*T/b
A=0.01, B=0.023, p=0.02, b=0.241
Created 11/06/2006
S20-IEEE-VI
IEEE Very inverse curve.
t=(A/(D^p - 1)+ B)*T/b
A=3.922, B=0.098, p=2, b=0.138
Created 11/06/2006
SDFuse_100e
Schneider Electric Square D Fuse
Type DIN/E Fuses in Parallel
15.5 kV Fuse Catalog Type 155GXQSJD
17.5 kV Fuse Catalog Types 175GXQSJD, 175GXMSJD, 175GFMSJD, 175GDMSJD
Curve 100E
Created 2003-06-02
SDFuse_125E
Curve 125E
Created 2003-06-02
SDFuse_150E
Curve 150E
Created 2003-06-02
SDFuse_15E

Curve 15E
Created 2003-06-02
SDFuse_175E
Curve 175E
Created 2003-06-02
SDFuse_200E
Curve 200E
Created 2003-06-02
SDFuse_20E
Curve 20E
Created 2003-06-02
SDFuse_25E
Curve 25E
Created 2003-06-02
SDFuse_30E
Curve30E
Created 2003-06-02
SDFuse_40
Curve 40E
Created 2003-06-02
SDFuse_50E
Curve 50E
Created 2003-06-02
SDFuse_65E
Curve65E
Created 2003-06-02
SDFuse_80E
Curve80E
Created 2003-06-02

SEL.RLY
This file contains Schweitzer Engineering Laboratory (SEL) relay and recloser curves.
351J-1006_2
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1006, Curve # 2.
Created 1/14/2000.
351J-1006_3
Created 1/14/2000.
351J-1006_B
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1006, Curve # B.
Created 1/14/2000.
351J-1006_R
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1006, Curve # R.
Created 1/14/2000.
351J-1007_16
Created 1/14/2000.
351J-1007_8+
Schwitzer 351J Electronic Recloser. DWG. NO.:TOC1007, Curve # 8 PLUS.
Created 1/14/2000.
351J-1007_D
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1007, Curve # D.
Created 1/14/2000.
351J-1008_1
Created 1/14/2000.
351J-1008_F
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1008, Curve # F.
Created 1/14/2000.
351J-1008_H
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1008, Curve # H.
Created 1/14/2000.
351J-1008_J
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1008, Curve # J.
Created 1/14/2000.
351J-1009_13
Created 1/14/2000.
351J-1009_6
Created 1/14/2000.
351J-1009_G
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1009, Curve # G.
Created 1/14/2000.
351J-1009_V
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1009, Curve # V.
Created 1/14/2000.
351J-1010_18
Created 1/14/2000.
351J-1010_E
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1010, Curve # E.
Created 1/14/2000.
351J-1010_P
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1010, Curve # P.
Created 1/14/2000.
351J-1011_5
Created 1/14/2000.
351J-1011_KG
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1011, Curve # KG.
Created 1/14/2000.

351J-1011_Y
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1011, Curve # Y.
Created 1/14/2000.
351J-1011_Z
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1011, Curve # Z.
Created 1/14/2000.
351J-1012_17
Created 1/14/2000.
351J-1012_KP
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1012, Curve # KP.
Created 1/14/2000.
351J-1012_M
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1012, Curve # M.
Created 1/14/2000.
351J-1012_T
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1012, Curve # T.
Created 1/14/2000.
351J-1013_11
Schwitzer 351J Electronic Recloser. DWG. NO.: TOC1013, Curve #11.
Created 1/13/2000.
351J-1013_14
Created 1/13/2000.
351J-1013_4
Created 1/13/2000.
351J-1013_9
Created 1/13/2000.
351R-1005_A
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1005, Curve A
Created 4/01/2003
351R-1005_C
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1005, Curve C
Created 4/01/2003
351R-1005_N
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1005, Curve N
Created 4/01/2003
351R-1005_W
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1005, Curve W
Created 4/01/2003
351R-1006_2
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1006, Curve 2
Created 4/1/2003
351R-1006_3
Created 4/1/2003
351R-1006_B
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1006, Curve B
Created 4/1/2003
351R-1006_R
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1006, Curve R
Created 4/1/2003
351R-1007_16
Created 4/1/2003
351R-1007_8+
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1007, Curve 8 plus
Created 4/1/2003
351R-1007_D
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1007, Curve D
Created 4/1/2003
351R-1008_1

Created 4/1/2003
351R-1008_F
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1008, Curve F
Created 4/1/2003
351R-1008_H
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1008, Curve H
Created 4/1/2003
351R-1008_J
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1008, Curve J
Created 4/1/2003
351R-1009_13
Created 4/1/2003
351R-1009_6
Created 4/1/2003
351R-1009_G
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1009, Curve G
Created 4/1/2003
351R-1009_V
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1009, Curve V
Created 4/1/2003
351R-1010_18
Created 4/1/2003
351R-1010_E
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1010, Curve E
Created 4/1/2003
351R-1010_P
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1010, Curve P
Created 4/1/2003
351R-1011_5
Created 4/1/2003
351R-1011_KG
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1011, Curve KG
Created 4/1/2003
351R-1011_Y
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1011, Curve Y
Created 4/1/2003
351R-1011_Z
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1011, Curve Z
Created 4/1/2003
351R-1012-KP
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1012, Curve KP
Created 4/1/2003
351R-1012_17
Created 4/1/2003
351R-1012_M
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1012, Curve M
Created 4/1/2003
351R-1012_T
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1012, Curve T
Created 4/1/2003
351R-1013_11
Created 4/1/2003
351R-1013_14
Created 4/1/2003
351R-1013_4
Created 4/1/2003

351R-1013_9
Created 4/1/2003
351R-1014_15
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1014, Curve #15
Created 4/01/2003
351R-1014_7
Created 1/27/2003
351R-1014_8
Created 4/01/2003
351R-1014_L
Schwitzer 351R Electronic recloser. DWG. NO.: TOC1014, Curve L
Created 4/1/2003
351R-C1
Schwitzer 351R Electronic recloser. I.E.C Class A curve (very inverse)
curve C2
T=0.14*D/(M^0.02-1)
Created 08/25/2006
351R-C2
Schwitzer 351R Electronic recloser. I.E.C Class B curve (very inverse)
curve C2
T=13.5*D/(M-1)
Created 08/25/2006
351R-C3
Schwitzer 351R Electronic recloser. I.E.C Class C curve extremely inve
rse) curve C3
T=80.0*D/(M^2-1)
Created 08/25/2006
351R-C4
Schwitzer 351R Electronic recloser. I.E.C Long time inverse curve C4
T=120.0*D/(M-1)
Created 08/25/2006
351R-C5
Schwitzer 351R Electronic recloser. I.E.C Short-time inverse curve C5
T=0.05*D/(M^0.04-1)
Created 08/25/2006
351R-U1
Schwitzer 351R Electronic recloser. U.S. Moderately inverse Curve U1
T=0.0104*D/(M^0.02-1) + 0.0226*D
Created 4/01/2003
351R-U2
Schwitzer 351R Electronic recloser. U.S. inverse Curve U2
T=5.95*D/(M^2-1) + 0.18*D
Created 4/01/2003
351R-U3
Schwitzer 351R Electronic recloser. U.S. Very inverse Curve U2
T=3.88*D/(M^2-1) + 0.0963*D
Created 4/01/2003
351R-U4
Schwitzer 351R Electronic recloser. U.S. Extremely inverse Curve U4
T=5.67*D/(M^2-1) + 0.0352*D
Created 4/01/2003
351R-U5
Schwitzer 351R Electronic recloser. U.S. Short-time inverse Curve U5
T=0.00342*D/(M^0.02-1) + 0.00262*D
Created 4/01/2003
421-C1
Schwitzer 421 Electronic recloser. I.E.C. Standard inverse Curve C1
T=0.14*D/(M^0.02-1)
Created 5/15/2006
421-C2
Schwitzer 421 Electronic recloser. I.E.C. Very inverse Curve C2
T=13.5*D/(M-1)
Created 5/15/2006

421-C3
Schwitzer 421 Electronic recloser. I.E.C. Extremely inverse Curve C3
T=80*D/(M^2-1)
Created 5/15/2006
421-C4
Schwitzer 421 Electronic recloser. I.E.C. Long-time inverse Curve C4
T=120*D/(M-1)
Created 5/15/2006
421-C5
Schwitzer 421 Electronic recloser. I.E.C. Short-Time inverse Curve C5
T=0.05*D/(M^0.04-1)
Created 5/15/2006
421-U1
Schwitzer 421 Electronic recloser. U.S. Moderate inverse Curve U1
T=0.0104*D/(M^0.02-1) + 0.0226*D
Created 5/15/2006
421-U2
Schwitzer 421 Electronic recloser. U.S. Inverse Curve U2
T=5.95*D/(M^2-1) + 0.18*D
Created 5/15/2006
421-U3
Schwitzer 421 Electronic recloser. U.S. Very inverse Curve U3
T=3.88*D/(M^2-1) + 0.0963*D
Created 5/15/2006
421-U4
Schwitzer 421 Electronic recloser. U.S. Extremely inverse Curve U4
T=5.64*D/(M^2-1) + 0.02434*D
Created 5/15/2006
421-U5
Schwitzer 421 Electronic recloser. U.S. Short-Time inverse Curve U5
T=0.00342*D/(M^0.02-1) + 0.0262*D
Created 5/15/2006
SEL-2xx-MI
SEL MI- Schweitzer Moderate Inverse relay.
T = 0.668*D/(M -1) +0.157*D
Created 3/1/95. Same as SEL-MI.
SEL-701_1
SEL-701 Motor Protection Relay
Curve 1
Created 2003-06-06
SEL-701_10
Curve 10
Created 2003-06-06
SEL-701_15
Curve 15
Created 2003-06-06
SEL-701_2
Curve 2
Created 2003-06-06
SEL-701_20
Curve 20
Created 2003-06-06
SEL-701_25
Curve 25
Created 2003-06-06
SEL-701_3
Curve 3
Created 2003-06-06
SEL-701_30

Curve 30
Created 2003-06-06
SEL-701_35
Curve 35
Created 2003-06-06
SEL-701_4
Curve 4
Created 2003-06-06
SEL-701_40
Curve 40
Created 2003-06-06
SEL-701_45
Curve 45
Created 2003-06-06
SEL-701_5
Curve 5
Created 2003-06-06
SEL-701_6
Curve 6
Created 2003-06-06
SEL-701_7
Curve 7
Created 2003-06-06
SEL-701_8
Curve 8
Created 2003-06-06
SEL-701_9
Curve 9
Created 2003-06-06
SEL-EI
SEL-EI - SEL U4: U.S. Extremely Inverse curve
T = 5.67*D/(M**2 -1) +0.0352*D
Created 04/14/2005.
SEL-I
SEL-I - SEL U2: U.S. Inverse curve
T = 5.95*D/(M**2 -1) +0.180*D
Created 04/14/2005.
SEL-IEC-EI
SEL-IEC-EI - SEL C3: I.E.C. Class C curve (Extremely Inverse).
T = 80*D/(M**2 - 1)
Created 04/14/2005
SEL-IEC-LTI
SEL-IEC-LTI - SEL C4: I.E.C. Long-Time Inverse curve
T = 120*D/(M - 1)
Created 04/14/2005.
SEL-IEC-SI
SEL-IEC-SI - SEL C1: I.E.C. Class A curve (Standard Inverse).
T = D*0.14/(M**0.02 - 1)
Created 04/14/2005
SEL-IEC-STI
SEL-IEC-STI - SEL C5: I.E.C. Short-Time Inverse curve.
T = 0.05*D/(M**0.04 - 1)
Created 04/14/2005
SEL-IEC-VI
SEL-IEC-VI - SEL C2: I.E.C. Class B curve (Very Inverse).
T = 13.5*D/(M-1)
Created 04/14/2005

SEL-STI
SEL-STI - SEL U5: US Short-Time Inverse curve.
T = 0.00342*D/(M**0.02 - 1) + 0.00262*D
Created 04/14/2005
SEL-VI
SEL-VI- SEL U3: U.S. Very Inverse curve.
T = 3.88*D/(M**2 -1) +0.0963*D
Created 04/14/2005
SEL3xx/5xxMI
SEL3xx/5xxMI - SEL U1: U.S. Moderate Inverse curve for model SEL 3xx or later.
T = 0.0104*D/(M**0.02 - 1) + 0.0226*D
Created 04/14/2005.

SHAWMUT.RLY
This file contains Gould Shwmut fuse curves.
A480R-02R
Ferraz Shawmut AMP TRAP A480R, medium voltage fuses/R-rated
A480A-1, A480R-1HE, 4800 Volts
Curve 2R
Created 07/01/2008
A480R-03R
A480A-1, A480R-1HE, 4800 Volts
Curve 3R
Created 07/01/2008
A480R-04R
A480A-1, A480R-1HE, 4800 Volts
Curve 4R
Created 07/01/2008
A480R-05R
A480A-1, A480R-1HE, 4800 Volts
Curve 5R
Created 07/01/2008
A480R-06R
A480A-1, A480R-1HE, 4800 Volts
Curve 6R
Created 07/01/2008
A480R-09R
A480A-1, A480R-1HE, 4800 Volts
Curve 9R
Created 07/01/2008
A480R-12R
A480A-1, A480R-1HE, 4800 Volts
Curve 12R
Created 07/01/2008
A480R-18R
A480A-1, A480R-1HE, 4800 Volts
Curve 18R
Created 07/01/2008
A480R-24R
A480A-1, A480R-1HE, 4800 Volts
Curve 24R
Created 07/01/2008
A480R-36R
A480A-1, A480R-1HE, 4800 Volts
Curve 36R
Created 07/01/2008
BOLT-750E5kV
BOLT-750E5kV: Shawmut 5.5 kV Medium Voltage Bolt-In Amp-Trap Fuse.
Cat. No.: AO55B3DORO, Ref.: 24445, 24447. Created 4/21/99.
BOLT-900E5kV
BOLT-900E5kV: Shawmut 5.5 kV Medium Voltage Bolt-In Amp-Trap Fuse.
Cat. No.: AO55B3DORO, Ref.: 24445, 24447. Created 4/21/99.
CL14-100E15k
CL-14-100E: Shawmut 15.5 kV Medium Voltage Amp-Trap Fuse.
Cat. No.: A155C1DORO, Ref. 24449, 24450. Created 7/2/97.
CL14-100E5KV
Cat. No.: AO55C1DORO, Ref.: 24439, 24440. Created 7/2/97.

CL14-125E15k
Cat. No.: A155C2DORO, Ref.: 24449, 24450. Created 7/2/97.
CL14-125E5kV
CL14-150E15k
CL14-150E5kV
CL14-200E15k
CL14-200E5kV
CL14-250E15k
CL14-250E5kV
CL14-300E15k
CL14-300E5kV
CL14-400E5kV
CL14-450E5kV
CL14-500E5kV
CL14-50E15kV
CL14-50E5kV
CL14-600E5kV
CL14-65E15kV
CL14-65E5kV
CL14-80E15kV
CL14-80E5kV
CS3-100E*15k
CS-3-100E: Shawmut 15.5 kV Medium Voltage Amp-Trap Fuse.
Cat. No.: A155F1DORO, Ref.: 24434, 24432. Created 9/29/97.
CS3-100E15kV
CS-3-100E 15.5 kV: Shawmut 15.5 kV Medium Voltage Amp-Trap Fuse.

CS3-100E5kV
CS-3-100E: Shawmut 5.5 kV Medium voltage Amp-Trap Fuse.
CS3-125E15kV
CS3-125E5kV
CS-3-125E: Shawmut Medium Voltage Amp-Trap Fuse.
CS3-150E15kV
CS3-150E5kV
Cat. No.: AO55F1DORO, Ref.: 24443, 24442. Created 9/29/97.
CS3-175E15kV
CS3-175E5kV
CS3-200E15kV
CS3-200E5kV
CS3-250E5kV
CS3-300E5kV
CS3-350E5kV
CS3-400E5kV
CS3-450E5kV
CS3-50E*5kV
Cat. No.: A055F1CORO, Ref.: 24437, 24436. Created 9/30/97.
CS3-50E15kV
Cat. No. A155F1DORO, Ref.: 24468, 24469. Created 9/24/97.
CS3-50E5kV
CS3-65E*15kV
CS3-65E*5kV
CS-3-65E: Shawmut 5.5 kV Medium Voltage Amp Trap Fuse.
Cat. No.: A055F1CORO, Ref.: 24436, 24437. Created 9/30/97.
CS3-65E15kV
CS3-65E5kV

CS3-80E*15kV
CS3-80E15kV
CS3-80E5kV
CS-3-80E: Shwamut 5.5 kV Medium Voltage Amp-Trap Fuse.

SIBA.RLY
This file contains Siba fuse curves.
FH-006.3
Siba High Voltage fuse-links German DIN standard
Class: back-up; Related Voltage: AC 10/17.5kV;
DIN E= 292mm
Curve: 6.3 Amps
Created 09/30/2009
FH-010
DIN E= 292mm
Curve: 10 Amps
Created 09/30/2009
FH-016
DIN E= 292mm
Curve: 16 Amps
Created 09/30/2009
FH-020
DIN E= 292mm
Curve: 20 Amps
Created 09/30/2009
FH-025
DIN E= 292mm
Curve: 25 Amps
Created 09/30/2009
FH-031.5
DIN E= 292mm
Curve: 31.5 Amps
Created 09/30/2009
FH-040
DIN E= 292mm
Curve: 40 Amps
Created 09/30/2009
FH-050
DIN E= 292mm
Curve: 50 Amps
Created 09/30/2009
FH-063
DIN E= 292mm
Curve: 63 Amps
Created 09/30/2009
FH-080
DIN E= 292mm
Curve: 80 Amps
Created 09/30/2009
FH-100

DIN E= 292mm
Curve: 100 Amps
Created 09/30/2009
FH-125
DIN E= 292mm
Curve: 125 Amps
Created 09/30/2009
FH-160
DIN E= 292mm
Curve: 160 Amps
Created 09/30/2009

SIEMENS.RLY
This file contains Siemens relay curves.
7SA522-DI
7SA522 Version 4 Definite Inverse. 3/1/2001.
7SA522-EI
7SA522 Version 4 Extreme Inverse. 3/1/2001.
7SA522-I
7SA522 Version 4 Inverse. March 2001
7SA522-LI
7SA522 Version 4 Long Inverse. March 2001
7SA522-MI
7SA522 Version 4 Moderate Inverse. March 2001
7SA522-SI
7SA522 Version 4 Short Inverse. 3/1/2001.
7SA522-VI
7SA522 Version 4 Very Inverse. March 2001.
7SJ512-DI
7SJ512 Version 3.6 Definite Inverse. 3/1/2001.
7SJ512-EI
7SJ512 Version 3.6 Extreme Inverse. 3/1/2001.
7SJ512-I
7SJ512 Version 3.6 Inverse. March 2001
7SJ512-LI
7SJ512 Version 3.6 Long Inverse. March 2001
7SJ512-MI
7SJ512 Version 3.6 Moderate Inverse. March 2001
7SJ512-SI
7SI512 Version 3.6 Short Inverse. 3/1/2001.
7SJ512-VI
7SJ512 Version 3.6 Very Inverse. March 2001.
7SJ600-DI
7SJ600-EI
7SJ600-I
7SJ600-LI
7SJ600-MI
7SJ600-SI
7SJ600 Version 2.1 Short Inverse. 3/1/2001.
7SJ600-VI
7SJ602-DI
7SJ602-EI
7SJ602-I
7SJ602-LI
7SJ602-MI
7SJ602-SI
7SJ602 Version 3.0 Short Inverse. 3/1/2001.
7SJ602-VI
7SJ61-DI
7SJ61/62/63 Version 4 Definite Inverse. March 2001

7SJ61-EI
7SJ61/62/63 Version 4 Extreme Inverse. 3/1/2001.
7SJ61-I
7SJ61/62/63 Version 4 Inverse. March 2001
7SJ61-LI
7SJ61/62/63 Version 4 Long Inverse. March 2001
7SJ61-MI
7SJ61/62/63 Version 4 Moderately Inverse. March 2001
7SJ61-SI
7SJ61/62/63 Version 4 Short Inverse. 3/1/2001.
7SJ61-VI
7SJ61/62/63 Version 4 Very Inverse. March 2001
7UT51-EI
7UT51 version 3.0 Extremely inverse
Created 7/12/2001
7UT51-MI
7UT51 version 3.0 Moderately inverse
Created 7/12/2001
7UT51-VI
7UT51 version 3.0 Very inverse
Created 7/12/2001
Relays in library J:\ASPEN\Curves library\SIEMENS.RLY
CENT-IEC-EI
Siemens Centurion recloser IEC255 Inverser Time protection curve.
Type C, Extremely Inverse curve
Created 01/06/2009
CENT-IEC-I
Type A, Inverse curve
Created 01/06/2009
CENT-IEC-VI
Type B, Very Inverse curve
Created 01/06/2009
CENT-IEEE-IE
Siemens Centurion recloser IEEE Inverser Time protection curve.
Standard Extremely inverse curve
Created 01/06/2009
CENT-IEEE-MI
Standard moderate inverse curve
Created 01/06/2009
CENT-IEEE-VI
Standard very inverse curve
Created 01/06/2009
CENTURION010
Siemens Centurion breaker
Microprocessor control type TCC 010
Electronic control type: NA
Create 01/06/2009
CENTURION015
Electronic control type R
Create 01/06/2009
CENTURION101
Electronic control type A
Create 01/06/2009
CENTURION102
Electronic control type 1
Create 01/06/2009

CENTURION103
Create 01/06/2009
CENTURION104
Electronic control type N
Create 01/06/2009
CENTURION105
Electronic control type R
Create 01/06/2009
CENTURION106
Create 01/06/2009
CENTURION107
Electronic control type L
Create 01/06/2009
CENTURION111
Electronic control type 8-Special
Create 01/06/2009
CENTURION112
Create 01/06/2009
CENTURION113
Create 01/06/2009
CENTURION114
Create 01/06/2009
CENTURION115
Electronic control type P
Create 01/06/2009
CENTURION116
Electronic control type D
Create 01/06/2009
CENTURION117
Electronic control type B
Create 01/06/2009
CENTURION118
Electronic control type M
Create 01/06/2009
CENTURION119

Create 01/06/2009
CENTURION120
Electronic control type Y
Create 01/06/2009
CENTURION121
Electronic control type G
Create 01/06/2009
CENTURION122
Electronic control type H
Create 01/06/2009
CENTURION131
Create 01/06/2009
CENTURION132
Electronic control type E
Create 01/06/2009
CENTURION133
Electronic control type C
Create 01/06/2009
CENTURION134
Electronic control type Z
Create 01/06/2009
CENTURION135
Create 01/06/2009
CENTURION136
Create 01/06/2009
CENTURION137
Electronic control type V
Create 01/06/2009
CENTURION138
Electronic control type W
Create 01/06/2009
CENTURION139
Create 01/06/2009
CENTURION140
Create 01/06/2009

CENTURION141
Create 01/06/2009
CENTURION142
Create 01/06/2009
CENTURION151
Create 01/06/2009
CENTURION152
Create 01/06/2009
CENTURION161
Electronic control type T
Create 01/06/2009
CENTURION162
Electronic control type K-Ph
Create 01/06/2009
CENTURION163
Electronic control type F
Create 01/06/2009
CENTURION164
Electronic control type J
Create 01/06/2009
CENTURION165
Electronic control type K-Gnd
Create 01/06/2009
CENTURION200
Electronic control type NA
Create 01/06/2009
CENTURION201
Create 01/06/2009
CENTURION202
Create 01/06/2009
ISGS-EI
ISGS Version 3.0 Extremely Inverse. March 2001.
ISGS-LI
ISGS Version 3.0 Long Inverse. March 2001
ISGS_DI
ISGS Version 3.0 Definite Inverse. March 2001.

ISGS_I
ISGS Version 3.0 Inverse. March 2001.
ISGS_I2T
ISGS Version 3.0 I2T. March 2001.
ISGS_MI
ISGS Version 3.0 Moderately Inverse. March 2001
ISGS_SI
ISGS Version 3.0 Short Inverse. March 2001.
ISGS_SLI
ISGS Version 3.0 Slightly Inverse. March 2001.
ISGS_VI
ISGS Version 3.0 Very Inverse. March 2001.
Relays in library J:\ASPEN\CURVES~1\SIEMENS.RLY
MD6-240MAX
I-T-E Sentron Circuit Breaker.
MD-Frame, Types MD6, MXD6, HMD6, HMX6, CMD6.
240V Maximum clearing time curve
Reference No.: TD-7108
Created 09/08/2006
MD6-480MAX
Created 09/08/2006
MD6-600MAX
Created 09/08/2006
MD6-MAX
Maximum curve
Created 09/08/2006
MD6-MIN
Minimum curve
Created 09/08/2006

SOUTHERN_STATES.RLY
This file contains Southern States fuse curves..
SS-PE23-001
Southern States PE type power fuse 23kV and below, 1A
SS-PE23-002
SS-PE23-003
SS-PE23-005
SS-PE23-007
SS-PE23-010
SS-PE23-015
SS-PE23-020
SS-PE23-025
SS-PE23-030
SS-PE23-040
SS-PE23-050
SS-PE23-065
SS-PE23-080
SS-PE23-100
SS-PE23-125
SS-PE23-150
SS-PE23-200
SS-PE34-001
Southern States PE type power fuse 34.5kV - 69kV, 1A
Created 6/29/2001
SS-PE34-002
Southern States PE type power fuse 34.5 - 69kV, 2A
Created 6/29/2001
SS-PE34-003
Southern States PE type power fuse 34.5 - 69kV, 3A
Created 6/29/2001
SS-PE34-005
Southern States PE type power fuse 34.5 - 69kV 5A
SS-PE34-007
SS-PE34-010
SS-PE34-015
SS-PE34-020
SS-PE34-025

SS-PE34-030
SS-PE34-040
SS-PE34-050
SS-PE34-065
SS-PE34-080
SS-PE34-100
SS-PE34-125
SS-PE34-150
SS-PE34-200
SS-PE88-001
Southern States PE type power fuse 88kV and above, 1A
SS-PE88-002
SS-PE88-003
SS-PE88-005
SS-PE88-007
SS-PE88-010
SS-PE88-015
SS-PE88-020
SS-PE88-025
SS-PE88-030
SS-PE88-040
SS-PE88-050
SS-PE88-065
Southern States PE power type fuse 88kV and above, 65A
SS-PE88-080
SS-PE88-100
SS-PE88-125
SS-PE88-150
SS-PE88-200
SS-PF23-002
Southern States PF type power fuse 23kV and below, 2A
Created 6/29/2001
SS-PF23-003
Created 6/29/2001
SS-PF23-005
Southern States PF type power fuse 23kV 5A

SS-PF23-010
SS-PF23-015
SS-PF23-020
SS-PF23-030
SS-PF23-040
SS-PF23-050
SS-PF23-060
SS-PF23-075
Sounthern States PF type power fuse 23kV 75A
SS-PF23-100
SS-PF23-125
SS-PF23-150
SS-PF23-200
SS-PF23-250
SS-PF23-300
SS-PF34-002
Southern States PF type power fuse 34.5 - 69kV, 2A
Created 6/29/2001
SS-PF34-003
Southern States PF type power fuse 34.5 - 69kV, 3A
Created 6/29/2001
SS-PF34-005
Southern States PF type power fuse 34.5 - 69kV 5A
SS-PF34-010
SS-PF34-015
SS-PF34-020
SS-PF34-030
SS-PF34-040
SS-PF34-050
SS-PF34-060
SS-PF34-075
SS-PF34-100
SS-PF34-125
SS-PF34-150
SS-PF34-200
SS-PF34-250

SS-PF34-300
SS-PF88-002
Southern States PF type power fuse 88kV and above, 2A
Created 6/29/2001
SS-PF88-003
Created 6/29/2001
SS-PF88-005
Southern States PF type power fuse 88 kV and above, 5A
SS-PF88-010
SS-PF88-015
SS-PF88-020
SS-PF88-030
SS-PF88-040
SS-PF88-050
SS-PF88-060
SS-PF88-075
SS-PF88-100
SS-PF88-125
SS-PF88-150
SS-PF88-200
SS-PM23-005
Southern States PM type power fuse 23kV 5A
SS-PM23-008
Southern States PM type power fuse 23kV and below 8A
SS-PM23-010
Southern States PM type power fuse 23kV and below 10A
SS-PM23-0125
Southern States PM type power fuse 23kV and below, 12.5A
SS-PM23-015
Southern States PM type power fuse 23kV and below, 15A
SS-PM23-020
SS-PM23-025
SS-PM23-030
SS-PM23-040
SS-PM23-050
SS-PM23-060
SS-PM23-075
SS-PM23-100
SS-PM23-125

SS-PM23-150
SS-PM23-200
SS-PM23-250
SS-PM23-300
SS-PM23-350
SS-PM23-400
SS-PM34-005
Southern States PM type power fuse 34.5 - 69kV 5A
SS-PM34-008
SS-PM34-010
SS-PM34-0125
Southern States PM type power fuse 34.5 - 69kV 12.5A
SS-PM34-015
Southern States PM type power fuse 34.5 - 69KV 15A
SS-PM34-020
SS-PM34-025
SS-PM34-030
SS-PM34-040
SS-PM34-050
SS-PM34-060
SS-PM34-075
SS-PM34-100
SS-PM34-125
SS-PM34-150
SS-PM34-200
SS-PM34-250
SS-PM34-300
SS-PM34-350
SS-PM34-400
SS-PM88-005
Southern States PM type power fuse 88kV and above, 5A
SS-PM88-008
SS-PM88-010
SS-PM88-0125
Southern States PM type power fuse 88kV and above, 12.5A
SS-PM88-015

SS-PM88-020
SS-PM88-025
SS-PM88-030
SS-PM88-040
SS-PM88-050
SS-PM88-060
SS-PM88-075
SS-PM88-100
SS-PM88-125
SS-PM88-150
SS-PM88-200
SS-PX23-005
Southern State PX type power fuse23kV and below, 5A
SS-PX23-008
Southern States PX type power fuse 23kV and below, 8A
SS-PX23-010
SS-PX23-0125
Southern States PX type power fuse 23kV and below, 12.5A
SS-PX23-015
SS-PX23-020
SS-PX23-025
SS-PX23-030
SS-PX23-040
SS-PX23-050
SS-PX23-060
SS-PX23-075
SS-PX23-100
SS-PX23-125
SS-PX23-150
SS-PX23-200
SS-PX23-250
SS-PX23-300
SS-PX34-005
Southern States type PX fuse 34.5 KV - 69 KV
5 Amps
SS-PX34-008
Southern States PX type power fuse 34.5 KV - 69 KV- 69 KV

8 Amps
SS-PX34-010
Southern States PX type power fuse 34.5 KV - 69 KV
10 Amps
SS-PX34-0125
12.5 Amps
SS-PX34-015
15 Amps
SS-PX34-020
20 Amps
SS-PX34-025
25 Amps
SS-PX34-030
30 Amps
SS-PX34-040
40 Amps
SS-PX34-050
50 Amps
SS-PX34-060
60 Amps
SS-PX34-075
75 Amps
SS-PX34-100
100 Amps
SS-PX34-125
125 Amps
SS-PX34-150
150 Amps
SS-PX34-200
200 Amps
SS-PX34-250
250 Amps
SS-PX34-300
300 Amps
SS-PX88-005
Southern States PX type power fuse 88kV and above, 5A
SS-PX88-008
SS-PX88-010
SS-PX88-0125
Southern States PX type power fuse 88kV and above, 12.5A
SS-PX88-015
SS-PX88-020
SS-PX88-025
SS-PX88-030

SS-PX88-040
SS-PX88-050
SS-PX88-060
SS-PX88-075
SS-PX88-100
SS-PX88-125
SS-PX88-150
SS-PX88-200

STANDARD.RLY
This file contains ANSI, IEEE, IEC and IAC standard curves.
ANSI_EI
ANSI Curve: Extremely Inverse.
T=(6.407(M*M-1)+0.025)*(14*n-5)/9;
Created 1/8/2002.
ANSI_I
ANSI Curve: Inverse.
T=(0.0086/(M^0.02-1)+0.0185)*(14*n-5)/9;
Created 1/8/2002
ANSI_LEI
ANSI Curve: Long Time Extremely Inverse.
T=(64.07/(M*M-1)+0.25)*(14*n-5)/9;
Created 1/8/2002
ANSI_LI
ANSI Curve: Long Time Inverse.
T=(0.086/(M^0.02)-1)+0.185)*(14*n-5)/9;
Created 1/8/2002.
ANSI_LVI
ANSI Curve: Long Time Very Inverse
T=(28.55/(M*M-1)+0.712)*(14*n-5)/9;
Created 1/8/2002.
ANSI_SEI
ANSI Curve: Short Time Extremely Inverse
T=(1.281/(M^2)-1)+0.005)*(14*n-5)/9;
Created 1/8/2002
ANSI_SI
ANSI Curve: Short Time Inverse.
T=(0.00172/(M^.02-1)+0.0037)*(14*n-5)/9;
Created 1/8/2002
ANSI_VI
ANSI Curve: Very Inverse
T=(2.855/(M*M-1)+0.0712)*(14*n-5)/9;
Created 1/8/2002
IAC_EI
IAC Curve: Extremely Inverse.
IAC_I
IAC Curve: Inverse
IAC_SI
IAC Curve: Short Inverse
IAC_VI
IAC Curve: Very Inverse
IEC_EI
IEC Curve C: Extremely Inverse
As defined in IEC255-4 and British standard BS142.
T=80*D/(M**2-1).
Revised 04/16/2002.
IEC_I
IEC Curve A: Standard Inverse
T=0.14*D/(M**0.02-1).
Revised 04/16/2002.
IEC_LTI
UK Curve: Long Time Inverse
T=120*D/(M-1).
Revised 04/16/2002.
IEC_VI
IEC Curve B: Very Inverse
T=13.5*D/(M-1).
Revised 04/16/2002.

IEEE-EI*
IEEE Curve: Extremely Inverse
T=D*[28.2/(M^2-1)+0.1217]
Created 04/21/2003
IEEE-MI*
IEEE Curve: Moderately Inverse
T=D*[0.0515/(M^0.02-1)+0.114]
Created 04/21/2003
IEEE-VI*
IEEE Curve: Very Inverse
T=D*[19.61/(M^2-1)+0.491
Created 04/21/2003.
IEEE_EI
IEEE Curve: Extremely Inverse
T=D/7*[28.2/(M^2-1)+0.1217]
Revised 04/16/2002.
IEEE_MI
IEEE Curve: Moderately Inverse
T=D/7*[0.0515/(M^0.02-1)+0.114]
Revised 04/16/2002.
IEEE_VI
IEEE Curve: Very Inverse
T=D/7*[19.61/(M^2-1)+0.491]
Revised 04/16/2002.
US_CO2_STI
US_CO2 Curve: Short Time Inverse
T=D/7*[0.02394/(M^0.02-1)+0.01694]
Created 04/16/2002.
US_CO8_I
US_CO8 Curve: Inverse
T=D/7*[5.95/(M^2-1)+0.18]
Created 04/16/2002.

TOSHIBA.RLY
This file contains Toshiba relay curves.
DCO53H-6A02
Toshiba Over-Current Relay DCO-53H-6A02
Time dial: 0.5 - 5
Created 07/07/2007
ICO1D-AT1
Toshiba Over-Current Relay ICO1D-AT1
Time dial: 10 - 0.5
Created 07/07/2007
ICO1D-AT2H
Toshiba Over-Current Relay ICO1D-AT2H
Time dial: 10 - 0.5
Created 07/07/2007
ICO1E-AT1
Toshiba Over-Current Relay ICO1E-AT1
Time dial: 10 - 0.5
Created 07/07/2007
ICO1E-AT2H
Toshiba Over-Current Relay ICO1E-AT2H
Time dial: 10 - 0.5
Created 07/07/2007
ICO1G-AT1
Toshiba Over-Current Relay ICO1G-AT1
Time dial: 10 - 0.5
Created 07/07/2007
ICO5G-AT2H
Toshiba Over-Current Relay ICO5G-AT2H
Time dial: 10 - 0.5
Created 07/07/2007
IOD1-AT1
Toshiba Over-Current Relay IOD1-AT1
Time dial: 10 - 0.5
Created 07/07/2007
IOD1-PHA
Toshiba Over-Current Relay IOD1-PHA
Time dial: 10 - 0.5
Created 07/07/2007
IOD1G-AT2H
Toshiba Over-Current Relay ICO1G-AT2H
Time dial: 10 - 0.5
Created 07/07/2007
NCO11P02A51E
Toshiba Over-Current Relay NCO11P-02A51, NCO12P-02A51 [E]
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A51S
Toshiba Over-Current Relay NCO11P-02A51, NCO12P-02A51 [S]
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A51V
Toshiba Over-Current Relay NCO11P-02A51, NCO12P-02A51 [V]
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A52E
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A52S
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A52V
Time dial: 0.05 - 1

Created 07/07/2007
NCO11P02A62E
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A62S
Time dial: 0.05 - 1
Created 07/07/2007
NCO11P02A62V
Time dial: 0.05 - 1
Created 07/07/2007
TCO21B-E
Toshiba Over-Current Relay TCO21B-DU11Q, DU12Q[E]
Time dial: 0.05 - 1
Created 07/07/2007
TCO21B-S
Toshiba Over-Current Relay TCO21B-DU11Q[S]
Time dial: 0.05 - 1
Created 07/07/2007
TCO22B-E
Toshiba Over-Current Relay TCO22B-DU11Q[E]
Time dial: 0.05 - 1
Created 07/07/2007
TCO22B-S
Toshiba Over-Current Relay TCO22B-DU11Q[S]
Time dial: 0.05 - 1
Created 07/07/2007
TCO22B-V
Toshiba Over-Current Relay TCO22B-DU11Q[V]
Time dial: 0.05 - 1
Created 07/07/2007

ZIV.RLY
This file contains ZIV relay curves.
ZIV-8BCD EI
ZIV 8BCD Extremely Inverse Time/Current characteristics.
ZIV-8BCD Inv
ZIV 8BCD Inverse Time/Current characteristics.
ZIV-8BCD VI
ZIV 8BCD Very InverseTime/Current characteristics.

Overcurrent Curves List

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Overcurrent Curves List

Uploaded by

Copyright:

Available Formats

ASPEN

Advanced Systems for Power Engineering, Inc.

HOW TO ORDER MORE MANUALS

HOW TO REACH ASPEN

Mailing address: ASPEN

Relay Library Files

ASPEN Overcurrent Relay Library Page 5

ASPEN Overcurrent Relay Library Page 6

ASPEN Overcurrent Relay Library Page 7

ASPEN Overcurrent Relay Library Page 8

ASPEN Overcurrent Relay Library Page 9

ASPEN Overcurrent Relay Library Page 10

ASPEN Overcurrent Relay Library Page 11

ASPEN Overcurrent Relay Library Page 12

ASPEN Overcurrent Relay Library Page 13

ASPEN Overcurrent Relay Library Page 14

ASPEN Overcurrent Relay Library Page 15

ASPEN Overcurrent Relay Library Page 16

ASPEN Overcurrent Relay Library Page 17

ASPEN Overcurrent Relay Library Page 18

ASPEN Overcurrent Relay Library Page 19

ASPEN Overcurrent Relay Library Page 20

ASPEN Overcurrent Relay Library Page 21

ASPEN Overcurrent Relay Library Page 22

ASPEN Overcurrent Relay Library Page 23

ASPEN Overcurrent Relay Library Page 24

ASPEN Overcurrent Relay Library Page 25

ASPEN Overcurrent Relay Library Page 26

ASPEN Overcurrent Relay Library Page 27

ASPEN Overcurrent Relay Library Page 28

ASPEN Overcurrent Relay Library Page 29

ASPEN Overcurrent Relay Library Page 30

ASPEN Overcurrent Relay Library Page 31

ASPEN Overcurrent Relay Library Page 32

ASPEN Overcurrent Relay Library Page 33

ASPEN Overcurrent Relay Library Page 34

ASPEN Overcurrent Relay Library Page 35

ASPEN Overcurrent Relay Library Page 36

ASPEN Overcurrent Relay Library Page 37

ASPEN Overcurrent Relay Library Page 38

ASPEN Overcurrent Relay Library Page 39

ASPEN Overcurrent Relay Library Page 40

ASPEN Overcurrent Relay Library Page 41

ASPEN Overcurrent Relay Library Page 42

ASPEN Overcurrent Relay Library Page 43

ASPEN Overcurrent Relay Library Page 44

ASPEN Overcurrent Relay Library Page 45

ASPEN Overcurrent Relay Library Page 46

ASPEN Overcurrent Relay Library Page 47

ASPEN Overcurrent Relay Library Page 48

ASPEN Overcurrent Relay Library Page 49

ASPEN Overcurrent Relay Library Page 50

ASPEN Overcurrent Relay Library Page 51

ASPEN Overcurrent Relay Library Page 52

ASPEN Overcurrent Relay Library Page 53

ASPEN Overcurrent Relay Library Page 54

ASPEN Overcurrent Relay Library Page 55

ASPEN Overcurrent Relay Library Page 56

ASPEN Overcurrent Relay Library Page 57

ASPEN Overcurrent Relay Library Page 58

ASPEN Overcurrent Relay Library Page 59

ASPEN Overcurrent Relay Library Page 60

ASPEN Overcurrent Relay Library Page 61
