S E R V I C E E Q U I P M E N T

FAST,

SAFE,

DEPENDABLE,

EFFICIENT,

SERVICE

EQUIPMENT

71
 Service Equipment Index

Service Equipment Index

Griffith • Vector Drilling Motor Test Stand ............................................. 73
Griffith • Vector Torquemaster Breakout Machine ....................... 74 – 75
Griffith • Vector Portable Service Centers ............................................... 76
Griffith • Vector Mini-Torque II Breakout Machine .............................. 77
Griffith • Vector Jar Testers ...................................................................... 77
Griffith • Vector Hydraulic Vises and Workshop Accessories .................. 78
Bowen Service Center for Downhole Tools .............................................. 79
Bowen Type D Jar Tester ........................................................................... 80
Bowen Peck-o-matic Coupling Bucking Units ....................................... 81
Bowen Peck-o-matic Soft Shoe Jaws ....................................................... 82
POWER EQUIPMENT INDEX

Bowen Peck-o-matic Makeup/Breakout Units ........................................ 82

Bowen Peck-o-matic Power Tongs ................................................. 83 – 84

72
 Griffith • Vector
Drilling Motor Test Stand

Drilling Motor Test Stand

The Griffith • Vector Testmaster and Hydramaster are drilling motor The Testmaster uses a caliper brake and disc to provide the braking torque,

TD350P PORTABLE TOP DRIVE DRILLING SYSTEM

dynamometer test benches designed to be operated safely and efficiently by one
person. Both units offer easy clamping and support systems for either straight or
bent motors; a fast and simple means to couple the motor to fluid supply, and
easy fixturing of the motor output shaft to the dynamometer. Floor to floor time
is therefore very short, so the units offer a rapid turnaround on any test using
only a series of simple procedures.
Both the Testmaster and the Hydramaster are operated from free standing
control consoles (combined if both units are at the same location) containing
the hydraulic power source, controls and instrumentation. The operator may set
combinations of flow and torque to evaluate motor performance and print the
results.
while the Hydramaster uses a positive displacement hydraulic brake, which
provides accurate and repeatable load application and the precise control
required to evaluate small diameter motors at low torque and slow speed. In
both cases, the load to the motor is applied by a single knob on the control
panel.
Griffith • Vector can assist the client with the specification or selection of the
engine, transmission, and pump required for the system. Griffith can also put
a complete package together including tanks, flow lines, etc. should that be
necessary.

Drilling Motor Test Stand Specifications

Testmaster Hydramaster
Imperial Metric Imperial Metric
Diameter range 4 3/4 to 11 1/4 in 121 to 286 mm 1 11/16 to 4 3/4 in 43 to 121 mm
Maximum torque capacity
Dynamic 19,400 lbf-ft 26 400 Nm 1500 lbf-ft 2040 Nm
Clamp
Maximum thrust force 50,000 lb 222 kN N/A N/A
Tool support
Maximum load 5,000 lb 2270 kg 2500 lb 1135 kg
Weight 6,100 lbs 2773 kg 1600 lbs 727 kg
Electrical requirements
Power unit 10hp 7.5 kW 10hp 7.5 kW
Customer to specify phase and voltage.

73
 Griffith • Vector
Torquemaster Breakout Machine

Push/Pull Cylinder Digital Torque Logger Hydraulic Console Spinner

Technical Specifications The Torquemaster Breakout Machine

Chucking Capacities: Headstock Tailstock The Torquemaster is a self-contained hydraulic makeup and breakout
inches (mm) inches (mm) machine designed for fast, safe, and dependable maintenance of tools and
Fixed Headstock motors in either workshop or drillsite locations.
Model 1689 3 1⁄ 2 – 14 90 – 355 3 1⁄ 2 – 14 90 – 355 The basic machine consists of a bed complete with a fixed headstock chuck,
Model 8025 3 1⁄ 2 – 18 90 – 457 3 1⁄ 2 – 14 90 – 355 a moveable tailstock chuck that applies the torque, and a hydraulic console unit.
Hinged Headstock
*Model 8026 3 1⁄ 2 – 18 90 – 457 3 1⁄ 2 – 14 90 – 355 Torque
*Model 8026 features a fully opening hinged headstock
The torque is produced by two hydraulic cylinders which rotate the tailstock
chuck through a 30 degree arc. Breakout torque is greater than makeup torque
Torque Capacity, All Models: at the same operating pressure due to the differential areas of the rod and head
Makeup: 4,000 – 150,000 lb-ft (5 400 – 203 000 Nm) sides of the pistons.
Breakout: 190,000 lb-ft maximum (257 000 Nm) The Torquemaster requires no anchors or special mounting facilities since
Overall length: 150" (3 800 mm) with a 12 ft bed the torsional reactions are resisted by the base frame.
Overall width: 52" (1 320 mm)
Overall height: 65" (1 650 mm) Synchronized Gripping Forces
Weight: 10,500 lbs (4 772 kg) approximate with console The headstock and tailstock each contain six radially arranged heavy duty
clamping cylinders. Each piston rod is fitted with a replaceable tong die. The
Electrical Requirements:
hydraulic system is designed to move the cylinders in unison to positively center
20 hp (15 kW) — customer to specify voltage and frequency.
the workpiece regardless of weight or diameter. The gripping force is in direct
The unit requires 3-phase power.
proportion to the applied torque, preventing damage to thin-walled components.

74

Power Traverse Tail Stock Support Jacks and Beam Extensions
Console
A freestanding console contains the hydraulic power unit, operating controls,
and torque gauges.
The console has enough hydraulic capacity for the functions of the basic
machine, plus a number of optional hydraulic accessories which make the
machine easier to use and extend its capabilities.
Powered Tailstock Traverse
The operator controls the movement of the tailstock from the console, which
allows the work to get done both faster and more safely. The tailstock is designed
to carry loads, i.e. a tool balanced in the tailstock can be shuttled along the bed
as required.
Torquemaster Optional Accessories
Bed Length: The standard machine is 12 ft. long, with 14 ft., 16 ft., and 18 ft.
available if required. As options, please inquire regarding any other length.
Specify as required.
Headstock and Tailstock Extension Beams, Complete With
Hydraulic Support Jacks: These extend the working length of the machine
and reduce the need for additional handling equipment once the tool is in
the machine. The operator controls the height of the jacks from the console.
Specific lengths are required for the beams and locations for the jacks (maxi-
mum 5 jacks).
Griffith • Vector
Torquemaster Breakout Machine
Hydraulic Push/Pull Cylinder: This is mounted on an extension beam
on either end of the Torquemaster and is used to insert or remove rotors from
stators, etc. Specific head or tailstock location. Standard cylinder produces
25,000 lbs force.
Hydraulic Spinner: Mounted on either the headstock or tailstock, the
spinner makes to “hand tight” or spins out broken connections. Specify
headstock or tailstock mount and model:
• 1397 medium torque to 1,500 lb-ft at 14" dia.
• 1375 high torque to 2,340 lb-ft at 14" dia.
Jar Tester: This can be controlled via the console as well, with no need to
have a separate hydraulic power unit. Specify the hose length needed to suit
your location.
Digital Torque Logger: This option provides a digital display of the torque
and a written record of torque values. The logger can be connected to local area
networks or function as a stand-alone unit to store and print data as required.
Logger software may be customized to suit specific requirements.
Hinged Headstock – Open Hinged Headstock –
Closed
Product Support
National Oilwell offers technical product support and service for the
Griffith • Vector Torquemaster and its accessories worldwide.
This includes:
Calibration: National Oilwell technicians can calibrate the Griffith • Vector
Torquemasters to trackable standards in your workshop.
Commissioning: Technicians will travel to the workshop site to set up a new
machine and train operators in its proper use and review general maintenance
and service procedures.
Repairs and Service: National Oilwell will provide the client with the
assistance needed to repair the equipment. This may be via communication
from our offices, advice regarding local agents who can assist with parts and
components, or by our technicians through a visit to the site.
Upgrades and Retrofits: National Oilwell can advise regarding the
installation of machine upgrades to boost productivity. We maintain records
for every machine and can provide designs that suit the specific features of
the machine.
Custom Applications: We invite your inquiries for developments specific
to your own needs. National Oilwell can design and manufacture any form
of hydraulic workshop equipment to suit a specific purpose.
75
 Griffith • Vector
Portable Service Centers

Portable Service Centers Technical Specifications

The Griffith • Vector Portable Service Center is a completely self- Per Container:
contained drilling tool service shop designed for use in remote locations. • Length: 35' 6" With Skid, Width: 8', Height: 9' 6" (8' Inside Door Frames)
The units are available in a single width using the Griffith • Vector Mini- • 3 Ton Overhead Craneway
Torque, or in double or triple width using the Griffith • Vector Torquemaster. • 3 Ton Exterior Jib Crane Mount
All units are skid mounted structures, complete with integral floor sumps, • Electrical: 3-Phase (customer to specify voltage and frequency)
overhead crane rails, ISO container mounts/lift points at the corners, insulated
Standard Equipment
and sheeted walls and roof, full height doors, and hinged/removable side panels
• Mini-Torque (single) wide center • Torquemaster (double) wide center
as necessary. They require an external power source (specified by the customer)
• Compressor • Sump pump – air lines and outlets
only, as all units are complete with a breaker panel and circuits for major
• Work bench, cabinets, shelving • Lights and receptacles
equipment and accessories.
• 3 ton overhead crane ways • 3 ton exterior jib crane mounts
Optional Equipment
• Jar tester • 3 ton overhead bridge cranes
• 3 ton exterior jib cranes • Complete hand tool packages
• Griffith service vise • Pulling post
• Pressure washer • A/C unit or heater
• Torquemaster accessories as required

76
 Griffith • Vector Mini-Torque II
Breakout Machine and Jar Testers

Griffith • Vector Mini-Torque II Griffith • Vector Jar Tester

The Griffith • Vector Mini-Torque II is a portable, hydraulic make up
and breakout unit requiring only an electrical power supply. It can be safely
and efficiently operated by one person and handles tools from 25⁄8" to 83⁄4"
diameter using standard tong dies without changing jaws or heads.
The Mini-Torque II consists of two components, a rotating head/ control
assembly and a self-contained hydraulic power unit/reservoir.
The rotating head assembly is suspended from a crane and positioned on the
workpiece to make or break the connections. This is a faster and more efficient
method than moving a cumbersome workpiece to a fixed breakout unit. The
Mini-Torque II may also be used while it stands on the floor to make or break
connections on kelly valves or other short components. The rotating head
consists of two clamp assemblies, each containing four radially mounted clamp
cylinders, that are synchronized and self-centering. These clamp assemblies
rotate relative to each other to apply the required torque. The clamping force
is proportional to the applied torque. The operating controls are located on the
fixed head assembly.
The Griffith • Vector Jar Tester is a rugged, self-contained unit designed
to test the proper operation of fishing jars, drilling jars and other downhole
drilling tools. The horizontal main frame and attached hydraulic cylinder
efficiently applies tension and compression forces in direct axial alignment
with the workpiece.
The Griffith • Vector Jar Tester is designed to stand alone or to be an acces-
sory to the Griffith • Vector Torquemaster. The auxiliary circuit on the Torque-
master console will provide the proper hydraulic power and control for effective
operation of the jar tester.
To test a tool in the jar tester, test nubbins are first threaded into the tool
connections. The tool can be placed into the jar tester frame after the tail
carriage and head carriage have been adjusted to accommodate tool length.
Tension or compression force can then be applied to the tool through the test
nubbins.
Customer should specify connections for test nubbins at time of order.

Griffith • Vector
GRIFFITH • VECTOR Mini-Torque
MINI TORQUE II Specifications
II SPECIFICATIONS

Diameter Range 2 5/8” to 8 3/4” Diameter 67 to 200 mm Diameter Hydraulic Unit:

Torque Capacity, Make Up to: 3,000-56,000 lbf-ft 4000-76000 N.m Length 34 in. 863 mm
Break Out from: 3,700-70,000 lbf-ft 5000-95200 N.m Width 18 in. 457 mm
Dimensions: Rotating Head: Length 24 in 610 mm Height 34 in. 863 mm
Width 37 in 940 mm Dry Weight 450 lbs 200 kg
Height 34 in 863 mm Capacity 20 US gal. 75 litres
Weight 1,800 lbs 816 kg Electrical Requirements:3 Phase, 10 H.P. (7.5kW) Customer to specify voltage and frequency

Griffith • Vector
GRIFFITH • VECTOR Jar Tester
JAR TESTER Specifications
SPECIFICATIONS
SERIES 1360 1361 1767 1786
Max Tension: 206000 lb - 916 kN 206000 lb - 916 kN 130000 lb - 578 kN 130000 lb - 578 kN
Max Compression: 2350000 lb - 1045 kN 235000 lb - 1045 kN 150000 lb - 667 kN 150000 lb - 667 kN
Stroke: 30” 30” 32” 32”
Operating Pressure: 3000 psi max. 3000 psi max. 3000 psi max. 3000 psi max.
Max Tool Length: 32’ 35’ 24’ 16’
Frame: Length: 39’ - 8” 43’ - 8” 31’ 22’ - 10”
Width: 4’ 4’ 3’ - 2” 2’ - 6”
Beams: W10 x 49 (4 Beams) W10 x 49 (4 Beams) W8 x 35 (2 Beams) 6” x 6” & 5 x 5 H.S.S.
Two Piece Frame Two Piece Frame Two Piece Frame Telescoping Frame
Weight: 6300 lbs 6000 lbs 4100 lbs 1700 lbs
Control Console: 1767-A-12 1767-A-12 1767-A-10 1767-A-10
or By Auxiliary Circuit or By Auxiliary Circuit or By Auxiliary Circuit or By Auxiliary Circuit

77
 Griffith • Vector Hydraulic Vises
and Workshop Accessories

GRIFFITH • VECTOR SERVICE “C” STYLE VISE GRIFFITH • VECTOR “HYDRO” STYLE VISE
Shown with the top jaw in the retracted position and also with the top jaw clamped on a tool.

SERVICE VISE (1609) SHOT PEENING CABINETS

The Griffith • Vector Service Vise (1609) is a floor-mounted unit This cabinet feastures a fully-opening front cover and
designed to hold a variety of tubular components while service a work area complete with rollers and ports in the side
work is carried out. panels to handle longer workpieces.

PORTABLE SERVICE SKIDS

For small diameter tools, this skid
includes:

• Skid with sump

• Service vise
• Rolling tool stand
• Jib crane and hoist

Griffith • Vector can configure service

skids to suit specific requirements.
GRIFFITH • VECTOR DIGITAL
STATOR MEASURING TOOL
Provides a direct measurement
of downhole motor stator size via
digital display. Two tools with
adapters cover stator sizes from
1.50 to 5.90 I.D. COMPLETE TOOL PACKAGES POLISHING STAND
For service work, including: Polish chrome, carbide, or other seal fit diameters
• Full handtool package with this machine. We supply diamond impregnated
• Wrenches and tongs straps to polish the workpiece.
• MPI equipment
• Pressure washing equipment
• Oil pumps to fill drilling tools
and motors

78
 Bowen Service Center
for Downhole Tools

Bowen Service Center

The Bowen Service Center for Downhole Tools is another innovation
by the company dedicated to furnishing quality tools in oilfields throughout the
world.
National Oilwell is the world’s leading manufacturer of oilfield tools and
equipment, and the hydraulically powered Bowen Service Center is designed to
allow the quick assembly and disassembly of all rotary tools.
The Bowen Service Center facilitates downhole tool repair work in both time
and convenience. The unique new concept incorporates five tools in one; and
one man can operate the entire unit. It is a must for any service company or
OEM involved in the servicing and repair of downhole tools. Other advantages
of the Service Center include the use of a proven makeup/breakout cam-action
system, push-pull assembly and a spinner assembly.
Components of the Service Center include the base unit which has the
following sub assemblies: the drive unit, traveling backup, spinner, push pull
assembly, three adjustable guide roller assemblies and the skid assembly.
Note: Bowen Jar Testers can be used to accompany the Bowen Service Center.

Bowen Service Center for Downhole Tools

Base Unit Power & Control Unit Push-Pull Unit*
Drive & Back-Up Units Spinner Guide Rollers Main Cylinder Clamp Cylinder
Torque Capacity (ft/lbs) 120,000** Makeup 1,500 @ 19 rpm
NA NA NA NA
150,000** Breakout 3,500 @ 8 rpm***
Size Range (inches) 31/8 to 17/8 O.D.
with double acting jaws 37/16 to 14" O.D.
27/8 to 13 NA NA 45/8 to 125/8
31/8 to 17 O.D. double acting jaws only
with single acting jaws
Cylinder Bore (inches) Hydraulic Cylinder 6
NA — NA 4 —
Air Cylinder 4
Cylinder Stroke (inches) Hydraulic Cylinder 20
NA 51/4 NA 48 4
Air Cylinder 141/2
Weight 8,000 lbs. 1,500 lbs. 500 lbs.
Dimension (inches) 42 x 68 x 160 26.5 x 51 x 18.5 76 x 32 x 36
* Optional item.
** Units with torque up to 200,000 (ft/lbs) are available.
*** High torque spinner available at extra cost.

Bowen Flawmaster
The Bowen Flawmaster is used for the detection of invisible defects in
ferrous metals through magnetic particle inspection. It is particularly suited for
“on location” detection of defects in tools, tool joints, subs, and fishing tools
to prevent downhole failures and to avoid fishing jobs caused by such failures.
The Bowen Flawmaster can also be used for the detection of flaws and invis-
ible defects in all ferrous metals during manufacturing. Raw materials, parts
in manufacture, final inspection parts, reworked or overhauled parts and tools
may all be inspected.
Magnetizing currents may be either low-voltage, high-current AC or DC. All
circuits are fused for the protection of electrical components against accidental
overload, with fuses easily replaceable from the front of the cabinet.
Either dry powder or liquid suspension particles may be used, depending
upon the size, type and finish of the article to be inspected.

Send for Bowen Technical Manual No. 7450

which completely describes the Bowen Flawmaster.

79
 Bowen Type D Jar Tester

Bowen Type D Jar Tester

The Bowen Type D Jar Tester is a versatile machine designed to exert
a tension or compression load which ranges from zero to 70 tons (140,000
pounds). It is engineered to accomplish this in a simple and controlled manner.
The Bowen Jar Tester will accept a tool up to 110" in length and 10" O.D. It
has a 20" stroke. A suitable, easy to read indicator is incorporated to show the
applied load in tons.

Uses
The Bowen Jar Tester provides an accurate and effective means of testing Bowen
Hydraulic Rotary Jars and Fluid Intensifiers and for setting Bowen Mechanical
Rotary Jars, Bowen Jar Safety Joints, Drilling Jars, (2 to 5 foot extensions
required for Drilling Jars), and Bowen Bumper Subs at any desired tripping
tonnage. This Jar Tester is especially useful in locations where proper main-
tenance of these tools must be conducted by the operator. It is also used for
checking other equipment, such as formation testing tools.
The Jar Tester can be used with Bowen Service Center and Rotary Tool Service
Type “D” Jar Tester
Units.

Construction
The Bowen Jar Tester consists of a long, sturdy horizontal frame, composed
of three main load members, and suitable positioning yokes. An adjustable
pull plate maintains one end of the tool being tested, while the other is held
by the crosshead. The crosshead is attached to a hydraulic actuated piston and
cylinder.
The hydraulic force required to operate the piston is provided by an electric
Box Sub
driven hydraulic pump.
Pin Sub
Operating controls are simple consisting primarily of a lever operated
direction control valve, and a simple load control valve. Jar Testing Subs Specifications
A frame extension is available as optional equipment. It will extend the T.J. Size (inches) 23/8 27/8 31/2 41/2 51/2 61/2 75/8
frame by a length of 36", 48", or 60". Pin Sub Part No. B-137-1 B-117-1 B-157-1 B-97-1 B-237-1 B-228-1 71754-1
Weight 24 27 322 61 73 102 120
RECOMMENDED SPARE PARTS: Box Sub Part No. B-173-2 B-117-2 B-157-2 B-97-2 B-237-2 B-228-2 71754-2
(1) 4 Packing Sets Weight 21 22 27 40 62 — 105
(2) 2 Cylinder Head Packings
(3) 4 Leather Cups
(4) 2 Bull Ring Seals Bowen Type “D” Jar Tester
(5) 2 Piston Head Seals 70 tons 100 tons
Capacity Stroke
(6) 1 Hydraulic Oil Filter 20 inches 20 inches
(7) 5 Complete Changes of Hydraulic Oil
Part No. 66760 207466
Complete Assembly Including Power Unit
Weight 2450 —
Send for Technical ManuaI No. 7500 which includes complete descriptions of
construction, operation, maintenance, and parts Iisting for the Bowen Jar Tester.

Bowen Standard 50,000 and 100,000 ft/lbs

Rotary Tool Service Unit
The Bowen Standard Rotary Tool Service Unit is a complete, portable,
skid-mounted workshop. It has all the necessary components to allow full
servicing of rotary oil field tools, including an electric motor and hydraulic
pump. The only supplementary requirements are hand tools, special purpose
tools, and an electric power source to power the unit.

80
 Bowen Peck-o-matic
Coupling Bucking Units

Coupling Bucking Units

Bowen/Peck-O-Matic offers the most complete line of Bucking Units when
you require absolute precision to achieve proper make-up in off-the-rig-floor
operations.
• Range 11/2" to 21" O.D.
• Torque to 75,000 ft/lbs
• Efficient, closed head design
• Contamination-free oil bath lubrication
• Precise torque control
• Optional computer control and data monitoring
• Soft-shoe, nonmarking, gripping system available for most units
• Optional electric or diesel power units Model 821 and accessories — a high speed
• Load cells/computer control available on all models computer and interface system to monitor, control, and
record spin-backup process for all types of threaded joints

Model 636/637 offers high speed/high torque capbilities Model 814 Bucking Unit, electric in-plant application,
torques up to 59,000 ft/lbs

Coupling Bucking Units Specifications

Model No. Description Capacities Torque Output Model Back-Up With Options Power Unit
High Gear Low Gear
636 Bucking Unit 15/16 to 75/8 1,250 @ 2,000 psi 6,000 @ 2,000 psi Rotary Load Cell (Optional) Electric or Diesel
637 Bucking Unit 15/16 to 75/8 1,250 @ 2,000 psi 9000/11,000 @ 2,500 psi Rotary Load Cell (Optional) Electric or Diesel 36 & 95 rpm @ 20 gpm
814 Bucking Unit 85/8 to 21 22,000 44,000 Floating Rotary Load Cell Electric or Diesel
31/8 to 21 Optional Optional (Optional) 48 & 24 rpm @ 55 gpm
w/Adapter 30,000 @ 6,000 psi 60,000 @ 6,000 psi (Optional) 48 & 24 rpm @ 55 gpm
821 Bucking Unit 33/8 to 17 18,000 36,000 Floating Rotary Load Cell Electric or Diesel
23/8 to 17 Optional Optional (Optional) 48 & 24 rpm @ 55 gpm
w/Adapter 24,000 @ 6,000 psi 48,000 @ 6000 psi (Optional) 40 & 20 rpm @ 55 gpm

81
 Bowen Peck-o-matic Soft Shoe Jaws
and Makeup/Breakout Units

Bowen Makeup/Breakout Units

Time-tested and field-proven, each Bowen unit (Models 624 and 824) makes
quick, easy work of servicing downhole tools from 25/16" to 17" O.D.
• Fast, precise makeup/breakout
• Safe operations by eliminating hazardous chains
• Double-acting jaws go from make to break
without changing jaws for most tool O.D. sizes
• Optional spinner to greatly reduce make/break time
• Simple, reliable operation
• Extremely economical
• Compact for complete portability
Bowen/Peck-O-Matic • Remote control
“Soft Shoe” Jaw Kit Configuration • Motorized back-up travel
• Optional push/pull hydraulic cylinder for servicing
Bowen/Peck-O-Matic “Soft Shoe” Jaws downhole motors or stroking tools
Soft Shoe Jaws are the answer to the problem of damage to pipe surfaces • Custom units available
caused by conventional tong dies during make-up and break-out operations.
This damage is particularly detrimental to premium pipe and undesirable on
any tubular.
The Bowen patented “soft shoe” design is the result of extensive testing and
employs a separate jaw insert for each diameter pipe. These inserts cover in
excess of 90% of the diameter where the pipe is gripped. Unlike other soft grip
devices, which merely wrap around the pipe, the Bowen design uses a rubber
cushion behind the insert which distributes the gripping and torsional forces
uniformly around the pipe. This feature eliminates the tendency to “bite” the
Makeup/Breakout Units
pipe with the leading edge of the insert as torque is applies. Instead, the flexible
gripping pads gently mold themselves to the various irregularities of the pipe. The Model 624 Makeup/Breakout Unit will make-up and break-out tools
Soft shoe inserts are available with special teeth which provide a soft grip from 25/16" to 85/8" O.D. Double-acting jaws available from 33/8" to 41/2".
with minor superficial indentations or as smooth aluminum shoes which are Maximum torque is 27,000 ft/lbs in breakout and 24,000 ft/lbs in makeup. This
completely nonmarking. Tooth type inserts are suitable for most applications unit is very economical and handles 80% of most downhole tool makeup and
with the aluminum inserts usually reserved for very special needs. breakout jobs. The unit’s compact size allows for complete portability. (Jaws
Bowen offers the soft shoe design as part of a complete tong/bucking unit or and inserts are optional.)
as a conversation kit for existing equipment. The conversation kits fit easily into The Model 824 Makeup/Breakout Unit will makeup and breakout
existing tongs or bucking units and offer an ease of operation never before tools from 31/8" to 17" O.D. Double-acting jaws are available from 31/8" to 101/
available with standard gripping systems. The soft shoe systems allow changing 8". Maximum torque is 150,000 ft/lbs in breakout and 124,000 ft/lbs in make-
from make-up to break-out without removing the pipe from the machine. up. Also available is an 824 high torque unit that has a maximum torque of
200,000 ft/lbs in breakout and 165,000 ft/lbs in makeup. (Jaws and inserts
Compu-Torque Computer Control are optional.)
and Monitoring System
The best in the business, Bowen’s Compu-Torque monitors, controls, and
records the spin-up/buck-up process with digital precision.
• Inputs joint data, make-up specs, and limits
• Monitors at continuous high speed
• Shuts down operations precisely
• Documents entire process
• Saves data on magnetic disk for rapid retrieval/recreation
• Custom programs available

Digital Torque Logger

82
 Bowen Peck-o-matic Power Tongs

Bowen Peck-O-Matic
The full line of Bowen Peck-O-Matic Bucking Units and Power Tongs
offer the most precise and efficient means of achieving proper make-up or
break-out either on or off the rig floor.
Standard models cover the entire range of pipe, couplings. tubing and
downhole tools with a selection of back up configurations and optional features
to suit the simplest or most exacting needs. And with its many years of
manufacturing experience, Bowen Peck-O-Matic is uniquely qualified to custom
manufacture units to whatever specifications required.
Bowen has added even more quality products to an already versatile line with
the acquisition of Peck-O-Matic, a leader in the manufacture of power tongs
and related equipment.
Backed by Bowen’s worldwide distribution, support, and 60 years’ experience,
the entire Bowen/Peck-O-Matic lineup of premium products establishes itself as
second-to-none.
Model 631-B Tubing Tong
• The most precise, efficient means of achieving proper make-up
Model 631-B Tubing Tong
in off-the-rig-floor operations The Model 631-B Tubing Tong is targeted for your jobs which require high
• The most experienced manufacturer of Bucking Units torque and speed, yet minimal maintenance and effort in operation.
• Uniquely qualified to custom-build as needed
• Unique two-motor design
Options tailor-made for your every requirement: • Faster trips
• Electric Elevator System to accommodate varying pipe diameters • Quick changes from make-up to break-out
• Hydraulic Load Cell Package to monitor torque accurately • Offers reduced drive stress and positive lubrication
• Adjustable Jacks to stabilize mobile units on uneven terrain
Model 631-B Specifications
• Strip Chart Recorder for a permanent record of each connection
Size Range 115/16” O.D. to 75/8” O.D.
• Compu-Torque System for precise monitoring, controlling,
Torque:
and recording of the spin-up/buck-up process for all types High Range (2,000 psi) 300 – 1,500 ft/lbs
of threaded joints Low Range (2,000 psi) to 6,000* ft/lbs
Rpm:
High Range 184 rpm
Low Range 45 rpm
Model 781 Sucker Rod Tong
Min. Hydraulic Requirement 20 gpm @ 2,000 psi
Bowen’s Model 781 Sucker Rod Tong offers all you need in a sucker rod
Length 563/4”
tongs — small, lightweight, and extremely simple to use. Space Requirement on Pipe 8”

• Simplicity of design means easy access to control handle from all Maximum Elevator Diameter 35”
C.L. of Pipe to C.L. of Anchor 43”
directions, fast conversions from make up to break out and reduced
Weight:
tong failure Tong 900 lbs
• Highly maneuverable (28" long, 175 lbs) to aid in crew’s control Back-Up Tool 95 lbs
when positioning Hydraulic Lift 180 lbs
• Higher rpm for faster trips and higher efficiency * High torque units to 9,000 ft/lbs available
• No daily maintenance required, only periodic cleaning and greasing

Model 781 Specifications

Size Range 5/8” to 11/8”

Torque 0 – 1100 ft/lbs

Rpm @ 35 gpm 80 rpm
Length 28”
Width 14”
Height 23”
Weight 175 lbs

Model 781 Sucker Rod Tong

83
 Bowen Peck-o-matic Power Tongs

Bowen Model 831 Tubing Tong

The Model 831 Tubing Tong — a powerful, compact tong designed for
rugged use — is also one of the most economical tongs built for well servicing/
workover rigs.
• High speed ratio (3.5:1) with two-speed vane type hydraulic motor
• Works without need for transmission or clutch
• High durability
• Minimal maintenance
Bowen Model 831 Specifications
Range Capacity .................................................................................................. 15/16" – 5" O.D.
Dimensions ............................................................................. 40" long x 121/2" wide x 18" high
Weight ............................................................................................................... Approx. 700 lbs
(includes the weight of tong assembly with oil and lift assembly)
Lift Assembly Stroke ............................................................................................................. 6 ft
Backup Assembly .................................................................................... Manual or air operated
Max. Stall Torque (at 2,000 psi):
Low Range .................................................................................................... 1,000 ft/lbs Bowen Model 831 Tubing Tong
High Range ................................................................................................... 3,500 ft/lbs
Max. Free Spin (with 32 gpm):
Low Range ......................................................................................................... 135 rpm
High Range .......................................................................................................... 40 rpm

Bowen Model 911 “Soft-Shoe” Tubing Tong

The Model 911 Tubing Tong utilizes Bowen’s patented soft shoe jaw system.
An open-faced, soft-shoe tong and floating rotary backup system, Model 911 is
designed especially for your premium tubing requirements.
By spreading its gripping force evenly over the tubing surface, the tong jaws
of the 911 gently mold themselves to the various irregularities of the tubing. The
result? Minimum marking and damage.
Model 911 also features a unique design that eliminates the side and bending
loads which other’ tong systems impose on the tubing connection. Plus, for
your most demanding applications, Model 911 can be configured either with
integrally-mounted electronic or hydraulic load cells to give precise readings.
• All the convenience and ease-of-use of an open face tong
• No special steps necessary to engage the tubing
• Precise readings, regardless of application
• Variable speed adjustments to 1 rpm
• Rugged design requires minimum maintenance,
regardless of surrounding environment
• Precise handling — time after time
• Designed to work with the Bowen Compu-Torque Computer System

Bowen Model 911 Specifications

Range Capacity ................................................................................................... 15/16" – 5" O.D.
Dimensions .............................................................................................. 54" long x 221/2" wide
Hydraulic Motors Available (all speeds listed are maximum):
2:1 Ratio Motor ....................................................................... Low Stage – 25 rpm/8,000 ft/lbs
(30 gpm/2,500 psi) ................................................................. High Stage – 50 rpm/4,000 ft/lbs
3:5:1 Ratio Motor .................................................................... Low Stage – 35 rpm/5,600 ft/lbs Bowen Model 911 “Soft-Shoe” Tubing Tong
(30 gpm/2,500 psi) ............................................................... High Stage – 123 rpm/1,600 ft/lbs

84
