07QJ78XX-E02-D785-00007

Page
Marathon Petroleum Co. PROJECT SPECIFIC 2 of 3
ADDENDUM
Relief Systems Improvement TO
ADDENDUM
Project – 2021 TAR Revision: A - IFA Date: 10/15/19
LINE CLASS
Site / Jacobs Job Number SPECIFICATION SUPERCEDES
Catlettsburg, KY / 07-QJ78-XX SP-50-03-N2 Revision: Date:

Issuing Department: Prepared By: Checked By:

Piping Engineering Y. Massey M. Miller
Reviewed By: Project Approval: Client Approval:
N. Parker C. Andre

5 FITTINGS:

5.1 Revise fittings as follows:

FITTINGS
SIZE DESCRIPTION LARGE END SIZE NOTES
½ Sockolet - CL 6000, CS (A105), MSS SP-97 & B16.11 ¾ - 24 NC1
¾-2 Sockolet - CL 3000, CS (A105), MSS SP-97 & B16.11 1 - 24 NC1

5.2 Add note FL4 to NPS ½ -1 nipolets.

6 FLANGES:

6.1 Add note FL4 to NPS ½ -1, Sch. 160, SW flanges.

6.2 Remove slip-on flanges from the pipe spec.

7 ORIFICE FLANGES:

8 GASKETS:

9 BOLTING:

9.1 Default to using stud bolts. Use of cap screws requires MPC approval.

9.2 Flanges that require a "controlled tightening" method shall require ASTM F436
(Type 1) through-hardened or carburized Carbon Steel flat washers (2 per stud).
Joints being "tensioned" do not require washers. Piping and fixed equipment
flanges with stud size ≥ 1¼" and < 2" is one example of studs requiring "controlled
tightening" and washers. See section 4.1 and 4.6 of SP-50-16 for other cases
requiring "controlled tightening" or "tensioning."

9.3 All refinery piping and fixed equipment bolted joints with stud size 2" or larger
shall be hydraulically tensioned. Washers are not required for these studs.

10 LINE BLANKS:

10.1 Remove all paddle blanks and paddle spacers from the pipe spec. They shall be
ordered as Piping Specialty Items.
 07QJ78XX-E02-D785-00007
Page
Marathon Petroleum Co. PROJECT SPECIFIC 3 of 3
ADDENDUM
Relief Systems Improvement TO
ADDENDUM
Project – 2021 TAR Revision: A - IFA Date: 10/15/19
LINE CLASS
Site / Jacobs Job Number SPECIFICATION SUPERCEDES
Catlettsburg, KY / 07-QJ78-XX SP-50-03-N2 Revision: Date:

Issuing Department: Prepared By: Checked By:

Piping Engineering Y. Massey M. Miller
Reviewed By: Project Approval: Client Approval:
N. Parker C. Andre

11 SPECIALTY COMPONENTS:

11.1 Remove all strainers and steam traps. They shall be ordered as Piping Specialty
Items.

12 PIPING INSTRUMENT CONNECTIONS:

12.1 O’lets with WN flanges are preferred over Flanged Pipets® for flanged PI, TI, TE
and TW instrument connections.

13 EQUIPMENT INSTRUMENT CONNECTIONS:

14 BRANCHES:

15 NOTES:

REVISION HISTORY

Rev. A dtd 10/15/19 – Pipe spec addendum created for project use. Issued for Approval.
 MARATHON PETROLEUM COMPANY LP SHEET 1 of 10

LINE CLASS SPECIFICATION N2

SERVICE: STEAM, CONDENSATE, BOILER FEEDWATER DOC. NO.: SP-50-03-N2

DESIGN BASIS: ASME B16.5 MG 1.1 (SEE PRESSURE/TEMPERATUE CURVE) REV.: 15

CODE: ASME B31.3; CATEGORY D & NORMAL FLUID SERVICES DATE: 12/21/2018
CORROSION ALLOWANCE MATERIAL FLANGE RATING TEMP. RATING
0.125 IN CARBON STEEL CL 150 RF -20/800°F
SIZE REFERENCE CODE /
NOTE NO. DESCRIPTION
MIN MAX LARGE END SIZE
SPECIAL PROVISIONS
SP-50-03-DS1A PIPE WELD DATA SHEET #1A..........SEE SP-50-03, SECTION 10
PIPE WELD DATA SHEET #1I..........SEE SP-50-03, SECTION 10, FOR CATEGORY D
SP-50-03-DS1I
SERVICES ONLY
SP-50-03-ZT 316/316L SS INSTRUMENT TUBING SPECIFICATION
NS2 MULTI-PASS WELD REQUIRED FOR ALL SOCKET WELDS
FL4 ½ 2 SOCKETWELD
3 AND LARGER - BUTTWELD

VV1, VV2 VALVES (SEE NOTES VV1, VV2)

FOR STEAM SERVICE, GLOBE AND TRIPLE OFFSET ARE PREFERRED VALVES FOR
POSITIVE SHUTOFF.
GATE - API 602 LATEST ED., CL 800, EXTENDED BODY, MSW/FPT, CS (A105), API TRIM
VG6, VG7 ½ 1½ 8 (F6/HF), BB, OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH VGA82-EB-MST
PACKING
GATE - API 602 LATEST ED., CL 800, EXTENDED BODY, INTEGRALLY REINFORCED
VALVOLET END BY FPT, CS (A105), API TRIM 8 (F6/HF), BB, OS&Y, MFG STD GRPH
VG7, VG8 ½ 1½ BONNET GSKT & API 622 APPROVED GRPH PACKING; CONTOUR OF WELD TO BE VGA82-EB-BWT
SPECIFIED FOR VALVOLET END
GATE - API 602 LATEST ED., CL 800, SW, CS (A105), API TRIM 8 (F6/HF), BB, OS&Y,
½ 2 MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGA82-SW

GATE - API 602 LATEST ED., CL 800, SW, CS (A105), API TRIM 8 (F6/HF), FP, BB, OS&Y,
VV4 ½ 2 MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGA82-SW-FP

GATE - API 602 LATEST ED., CL 800, SW, CS (A105), API TRIM 5 (F6/FHF), WELDED IN
½ 2 BODY SEATS, WB, BELLOWS SEAL, OS&Y, & MFG STANDARD GRPH PACKING [e.g., VGA81-SW-BSB
DIXON EAGLE]
GATE - API 602 LATEST ED., CL 800, SW/T, CS (A105), API TRIM 8 (F6/HF), BB, OS&Y,
VV3 ½ 1½ MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGA82-ST

GATE - API 602 LATEST ED., CL 150, RF, CS (A105), API TRIM 8 (F6/HF), BB, OS&Y, MFG
VUN ½ 2 STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGAA2-C

GATE - API 602 LATEST ED., CL 150, RF, CS (A105), API TRIM 8 (F6/HF), FP, BB, OS&Y,
VV4, VUN ½ 2 MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGAA2-C-FP

GATE - API 602 LATEST ED., CL 300, RF, CS (A105), API TRIM 8 (F6/HF), BB, OS&Y, MFG
VR1 ½ 2 STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGAC2-C

GATE - API 602 LATEST ED., CL 300, RF, CS (A105), API TRIM 8 (F6/HF), FP, BB, OS&Y,
VV4, VR1 ½ 2 MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGAC2-C-FP

GATE - API 600 LATEST ED., CL 150, RF, CS (A216-WCB), API TRIM 8 (F6/HF), BB,
3 12 OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING VGAA2

GATE - API 600 LATEST ED., CL 150, RF, CS (A216-WCB), API TRIM 8 (F6/HF), BB,
14 24 OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH PACKING, GO VGAA2-GO

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 2 of 10

LINE CLASS SPECIFICATION N2

SERVICE: STEAM, CONDENSATE, BOILER FEEDWATER DOC. NO.: SP-50-03-N2

DESIGN BASIS: ASME B16.5 MG 1.1 (SEE PRESSURE/TEMPERATUE CURVE) REV.: 15

CODE: ASME B31.3; CATEGORY D & NORMAL FLUID SERVICES DATE: 12/21/2018
CORROSION ALLOWANCE MATERIAL FLANGE RATING TEMP. RATING
0.125 IN CARBON STEEL CL 150 RF -20/800°F
SIZE REFERENCE CODE /
NOTE NO. DESCRIPTION
MIN MAX LARGE END SIZE
VV1, VV2 VALVES (SEE NOTES VV1, VV2), continued
GLOBE - API 602 LATEST ED., T OR Y-PATTERN, CL 800, SW, CS (A105), API TRIM 8
½ 2 (F6/HF), BB, OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH VLA82-SW
PACKING
GLOBE - API 602 LATEST ED., T OR Y-PATTERN, CL 150, RF, CS (A105), API TRIM 8
VUN ½ 2 (F6/HF), BB, OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH VLAA2-C
PACKING
GLOBE - API 602 LATEST ED., T OR Y-PATTERN, CL 800, SW, CS (A105), API TRIM 8
½ 2 (F6/HF), WELDED IN BODY SEATS, BB, OS&Y, MFG STD GRPH BONNET GSKT & API VLA82-SW-WS
622 APPROVED GRPH PACKING (FOR STEAM SYSTEMS)
GLOBE - API 602 LATEST ED., T OR Y-PATTERN, CL 150, RF, CS (A105), API TRIM 8
VUN ½ 2 (F6/HF), WELDED IN BODY SEATS, BB, OS&Y, MFG STD GRPH BONNET GSKT & API VLAA2-C-WS
622 APPROVED GRPH PACKING (FOR STEAM SYSTEMS)
GLOBE - API 623 LATEST ED., T OR Y-PATTERN, CL 150, RF, CS (A216-WCB), API TRIM
3 12 8 (F6/HF), BB, OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH VLAA2
PACKING
GLOBE - API 623 LATEST ED., T OR Y-PATTERN, CL 150, RF, CS (A216-WCB), API TRIM
14 24 8 (F6/HF), BB, OS&Y, MFG STD GRPH BONNET GSKT & API 622 APPROVED GRPH VLAA2-GO
PACKING, GO

CHECK - API 602 LATEST ED., PISTON TYPE, CL 800, SW, CS (A105), API TRIM 8
VC2 ½ 2 (F6/HF), BB, SS SPRING, MFG STD GRPH BONNET GSKT (HORIZONTAL ONLY) VCA82-SW-P-HORZ

CHECK - API 602 LATEST ED., SWING TYPE, CL 800, SW, CS (A105), API TRIM 8
VC4 ½ 2 (F6/HF), BB, MFG STD GRPH BONNET GSKT VCA82-SW

CHECK - API 602 LATEST ED., PISTON TYPE, CL 150, RF, CS (A105), API TRIM 8
VC2, VUN ½ 2 (F6/HF), BB, SS SPRING, MFG STD GRPH BONNET GSKT (HORIZONTAL ONLY) VCAA2-C-P-HORZ

CHECK - API 602 LATEST ED., SWING TYPE, CL 150, RF, CS (A105), API TRIM 8 (F6/HF),
VC4, VUN ½ 2 BB, MFG STD GRPH BONNET GSKT VCAA2-C

CHECK - API 594 LATEST ED., EXTENDED BODY, DUAL DOOR, DOUBLE FLGD, CL 150,
VC5 2 6 RF, CS (A216-WCB), API TRIM 8 (F6/HF), INCONEL X-750 SPRING, BONNETLESS [e.g. VWAA2-EB
Goodwin, Advance]
CHECK - API 594 LATEST ED., SWING TYPE, CL 150, RF, CS (A216-WCB), API TRIM 8
VC4 3 24 (F6/HF), BB, MFG STD GRPH BONNET GSKT VCAA2

CHECK - API 594 LATEST ED., DUAL DOOR, DOUBLE FLGD, CL 150, RF, CS (A216-
VC5 8 24 WCB), API TRIM 8 (F6/HF), INCONEL X-750 SPRING, BONNETLESS VWAA2

BUTTERFLY - API 609 LATEST ED., TRIPLE OFFSET, CL 150, RF, CS (A216-WCB),
STELLITE® WELD OVERLAY ON SEAT AND DUPLEX SS (UNS S31803) SEAL RING,
VBL 3 6 VFAA2-DF-TO
DOUBLE FLG (SHORT OR LONG F2F PATTERN PER API 609), API 622 APPROVED
GRPH PACKING
BUTTERFLY - API 609 LATEST ED., TRIPLE OFFSET, CL 150, RF, CS (A216-WCB),
STELLITE® WELD OVERLAY ON SEAT AND DUPLEX SS (UNS S31803) SEAL RING,
VBL 8 24 DOUBLE FLG (SHORT OR LONG F2F PATTERN PER API 609), API 622 APPROVED VFAA2-DF-TO-GO
GRPH PACKING, GO

PIPE
NC4 ½ 1 PIPE - SCH 160, SMLS, CS (A106-B)
¾ 2 PIPE - SCH 80 (XS), SMLS, CS (A106-B)
3 24 PIPE - STD WT, SMLS, CS (A106-B)

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 3 of 10

LINE CLASS SPECIFICATION N2

SERVICE: STEAM, CONDENSATE, BOILER FEEDWATER DOC. NO.: SP-50-03-N2

DESIGN BASIS: ASME B16.5 MG 1.1 (SEE PRESSURE/TEMPERATUE CURVE) REV.: 15

CODE: ASME B31.3; CATEGORY D & NORMAL FLUID SERVICES DATE: 12/21/2018
CORROSION ALLOWANCE MATERIAL FLANGE RATING TEMP. RATING
0.125 IN CARBON STEEL CL 150 RF -20/800°F
SIZE REFERENCE CODE /
NOTE NO. DESCRIPTION
MIN MAX LARGE END SIZE
FL4 FITTINGS (SEE NOTE FL4)
LOKRING FITTINGS ARE ACCEPTABLE FOR USE IN CATEGORY D FLUID SERVICES.
THEIR USE IN SERVICES OTHER THAN CATEGORY D WILL REQUIRE A SPEC
½ ½ ELL - 90 DEG, CL 6000, SW, CS (A105), B16.11
½ ½ ELL - 45 DEG, CL 6000, SW, CS (A105), B16.11
NC1 ½ ½ TEE - CL 6000, SW, CS (A105), B16.11
NC1 ½ ½ REDUCING TEE - CL 6000, SW, CS (A105), B16.11 ¾-2
NC1 ½ ½ COUPLING - CL 6000, SW, CS (A105), B16.11

½ 2 PLUG - ROUND HEAD SOLID, SW, CS (A105), B16.11

PLG ½ 1½ PLUG - ROUND HEAD SOLID, THRD, CS (A105), B16.11 & B1.20.1

¾ 2 ELL - 90 DEG, CL 3000, SW, CS (A105), B16.11

¾ 2 ELL - 45 DEG, CL 3000, SW, CS (A105), B16.11
NC1 ¾ 2 TEE - CL 3000, SW, CS (A105), B16.11
NC1 ¾ 1½ REDUCING TEE - CL 3000, SW, CS (A105), B16.11 1-2
NC1 ¾ 2 COUPLING - CL 3000, SW, CS (A105), B16.11

YMD, YMU, UN1 ¾ 1½ UNION - CL 3000, SW, CS (A105), STANDARD OR UNIFLEX, B16.11 & MSS SP-83

3 24 ELL - 90 DEG, LR, STD WT, SMLS, CS (A234-WPB), B16.9

3 24 ELL - 45 DEG, STD WT, SMLS, CS (A234-WPB), B16.9
3 24 TEE - STD WT, SMLS, CS (A234-WPB), B16.9
3 20 REDUCING TEE - STD WT, SMLS, CS (A234-WPB), B16.9 4 - 24
3 24 CAP - STD WT, SMLS, CS (A234-WPB), B16.9
3 20 REDUCER - CONC, STD WT, SMLS, CS (A234-WPB), B16.9 4 - 24
3 20 REDUCER - ECC, STD WT, SMLS, CS (A234-WPB), B16.9 4 - 24
3 18 WELDOLET - STD WT, SMLS, CS (A105), MSS SP-97 & B16.9 6 - 24

OLET FITTINGS
NC1 ½ ½ SOCKOLET - CL 6000, CS (A105), MSS SP-97 & B16.11 3 - 24
½ ½ FLAT SOCKOLET - CL 6000, CS (A105), MSS SP-97 & B16.11 3 - 24
½ ½ ELBOLET - CL 6000, SW, CS (A105), B16.11 3 - 24
½ ½ LATROLET - CL 6000, SW, CS (A105), MSS SP-97 & B16.11 3 - 24

NC4 ½ 1 NIPOLET - SCH 160, BEVELED END OR EQUAL, CS (A105), B16.9 & B16.25 3 - 24

NC1 ¾ 2 SOCKOLET - CL 3000, CS (A105), MSS SP-97 & B16.11 3 - 24

¾ 2 FLAT SOCKOLET - CL 3000, CS (A105), MSS SP-97 & B16.11 3 - 24
¾ 2 ELBOLET - CL 3000, SW, CS (A105), B16.11 3 - 24
¾ 2 LATROLET - CL 3000, SW, CS (A105), MSS SP-97 & B16.11 3 - 24

FL4 1½ 2 NIPOLET - SCH 80 (XS), BEVELED END OR EQUAL, CS (A105), B16.9 & B16.25 3 - 24

UD7 ¾ 1½ THREDOLET - CL 6000, CS (A105), MSS SP-97 & B1.20.1 3 - 24

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 4 of 10

LINE CLASS SPECIFICATION N2

SERVICE: STEAM, CONDENSATE, BOILER FEEDWATER DOC. NO.: SP-50-03-N2

DESIGN BASIS: ASME B16.5 MG 1.1 (SEE PRESSURE/TEMPERATUE CURVE) REV.: 15

CODE: ASME B31.3; CATEGORY D & NORMAL FLUID SERVICES DATE: 12/21/2018
CORROSION ALLOWANCE MATERIAL FLANGE RATING TEMP. RATING
0.125 IN CARBON STEEL CL 150 RF -20/800°F
SIZE REFERENCE CODE /
NOTE NO. DESCRIPTION
MIN MAX LARGE END SIZE
FITTINGS - INSTRUMENT CONNECTIONS
UI8 1 1 COUPLING - CL 6000, THRD, CS (A105), B16.11 & B1.20.1

UP1 ¾ ¾ SOCKOLET - CL 6000, CS (A105), MSS SP-97 & B16.11 3 - 24

UI8 1 1 ELBOLET - CL 6000, THRD, CS (A105), B16.11 & B1.20.1 3 - 24
UI8 1 1 THREDOLET - CL 6000, CS (A105), MSS SP-97 & B1.20.1 3 - 24

YMD, YMU, UN1 ¾ 1½ UNION - CL 3000, SW, CS (A105), STANDARD OR UNIFLEX, B16.11 & MSS SP-83

UI9 2 2 WELDOLET - STD WT (RUN) x SCH 80 (BRANCH), BW, CS (A105), MSS SP-97 & B16.9 3 - 24

UI9 2 2 ELBOLET - STD WT (RUN) x SCH 80 (BRANCH), BW, CS (A105), B16.9 & B16.25 3 - 24

PIPE FLANGES
SLIP-ON - ONLY FOR CATEGORY D FLUID SERVICE; OTHERWISE, USE WELD NECK
FLANGES (REFER TO SP-50-34, SECTION 2.6)

NC4 ½ 1 FLG - SW, CL 150, RF, CS (A105), SCH 160 BORE, B16.5
FL4 ¾ 2 FLG - SW, CL 150, RF, CS (A105), SCH 80 (XS) BORE, B16.5
TFR, UI9 2 2 FLG - WN, CL 150, RF, CS (A105), SCH 80 BORE, B16.5
FLANGED PIPET® - CL 150, RF, CS (A105), MATCH PIPE THICKNESS (RUN) X SCH 80
TFR, UI9 2 2 (BRANCH), BW, B16.5
3 24 FLG - WN, CL 150, RF, CS (A105), STD BORE, B16.5
3 24 FLG - SO, CL 150, RF, CS (A105), STD BORE, B16.5

½ 24 FLG - BLIND, CL 150, RF, CS (A105), B16.5

VR1, NC4 ½ 1 FLG - SW, CL 300, RF, CS (A105), SCH 160 BORE, B16.5
VR1, FL4 ¾ 2 FLG - SW, CL 300, RF, CS (A105), SCH 80 (XS) BORE, B16.5
VR1, TFR, UI9 2 2 FLG - WN, CL 300, RF, CS (A105), SCH 80 BORE, B16.5
FLANGED PIPET® - CL 300, RF, CS (A105), MATCH PIPE THICKNESS (RUN) X SCH 80
VR1, TFR, UI9 2 2 (BRANCH), BW, B16.5
VR1 3 24 FLG - WN, CL 300, RF, CS (A105), STD BORE, B16.5
VR1 3 24 FLG - SO, CL 300, RF, CS (A105), STD BORE, B16.5

VR1 ½ 24 FLG - BLIND, CL 300, RF, CS (A105), B16.5

FO1 ORIFICE FLANGES (SEE NOTE FO1)

ORIFICE FLG SET - WN, CL 300, RF, CS (A105), SCH 80 (XS) BORE, W/ NPS ½
2 2
SOCKETWELD TAPS, B16.36
ORIFICE FLG SET - WN, CL 300, RF, CS (A105), STD BORE, W/ NPS ½ SOCKETWELD
3 24
TAPS, B16.36

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 5 of 10

LINE CLASS SPECIFICATION N2

SERVICE: STEAM, CONDENSATE, BOILER FEEDWATER DOC. NO.: SP-50-03-N2

DESIGN BASIS: ASME B16.5 MG 1.1 (SEE PRESSURE/TEMPERATUE CURVE) REV.: 15

CODE: ASME B31.3; CATEGORY D & NORMAL FLUID SERVICES DATE: 12/21/2018
CORROSION ALLOWANCE MATERIAL FLANGE RATING TEMP. RATING
0.125 IN CARBON STEEL CL 150 RF -20/800°F
SIZE REFERENCE CODE /
NOTE NO. DESCRIPTION
MIN MAX LARGE END SIZE
NR4 PIPE NIPPLES (SEE NOTE NR4)
½ ½ NIPPLE - XXS, SMLS, CS (A106-B), TBE, 3-INCH LONG, B1.20.1
½ ½ NIPPLE - XXS, SMLS, CS (A106-B), TBE, 4-INCH LONG, B1.20.1
½ ½ NIPPLE - XXS, SMLS, CS (A106-B), TBE, 6-INCH LONG, B1.20.1

¾ 1½ NIPPLE - SCH 160, SMLS, CS (A106-B), TBE, 3-INCH LONG, B1.20.1

¾ 1½ NIPPLE - SCH 160, SMLS, CS (A106-B), TBE, 4-INCH LONG, B1.20.1
¾ 1½ NIPPLE - SCH 160, SMLS, CS (A106-B), TBE, 6-INCH LONG, B1.20.1

NC4 ½ 1 NIPPLE - SCH 160, SMLS, CS (A106-B), PBE, 3-INCH LONG, B36.10M
NC4 ½ 1 NIPPLE - SCH 160, SMLS, CS (A106-B), PBE, 4-INCH LONG, B36.10M
NC4 ½ 1 NIPPLE - SCH 160, SMLS, CS (A106-B), PBE, 6-INCH LONG, B36.10M

1½ 2 NIPPLE - SCH 80, SMLS, CS (A106-B), PBE, 3-INCH LONG, B36.10M

1½ 2 NIPPLE - SCH 80, SMLS, CS (A106-B), PBE, 4-INCH LONG, B36.10M
1½ 2 NIPPLE - SCH 80, SMLS, CS (A106-B), PBE, 6-INCH LONG, B36.10M

NR4 SWAGE NIPPLES (SEE NOTE NR4)

THREADED ENDS SHALL NOT BE LARGER THAN NPS 1½. SWAGE NIPPLES IN THIS
SPECIFICATION MUST MEET THE FOLLOWING THICKNESS REQUIREMENTS:
THREADED ENDS SHALL BE NPS ½ = XXS, NPS ¾ - 1½ = SCH 160. PLAIN OR
BEVELED ENDS SHALL MATCH PIPE THICKNESS.
ONLY A FEW OF THE MANY COMBINATIONS FOR SWAGE NIPPLES ARE SHOWN
BELOW. FOLLOW MSS SP-95 AND NOTE NR4 FOR ALL OTHER POSSIBLE
COMBINATIONS.
SWAGE - CONC, XXS SMALL END, SCH 160 LARGE END, CS (A234-WPB), TBE, MSS SP-
½ ½ 95 ¾ - 1½
¾ 1 SWAGE - CONC, SCH 160, CS (A234-WPB), TBE, MSS SP-95 1 - 1½

NC4 ½ 1½ SWAGE - CONC, THICKNESS TO MATCH PIPE, CS (A234-WPB), PBE, MSS SP-95 ¾-2
NC4 ½ 2 SWAGE - CONC, THICKNESS TO MATCH PIPE, CS (A234-WPB), BLE x PSE, MSS SP-95 3-4

SWAGE - ECC, XXS SMALL END, SCH 160 LARGE END, CS (A234-WPB), TBE, MSS SP-
½ ½ 95 ¾ - 1½
¾ 1 SWAGE - ECC, SCH 160, CS (A234-WPB), TBE, MSS SP-95 1 - 1½

NC4 ½ 1½ SWAGE - ECC, THICKNESS TO MATCH PIPE, CS (A234-WPB), PBE, MSS SP-95 ¾-2
NC4 ½ 2 SWAGE - ECC, THICKNESS TO MATCH PIPE, CS (A234-WPB), BLE x PSE, MSS SP-95 3-4

GASKETS (REFERENCE SP-50-34)

GASKET - CL 150, 304 SS, SPW, INHIBITED GRADE FLEXIBLE GRPH (e.g., BP, GTB, OR
½ 24 EQUAL), 0.175-INCH THK, W/ 304 SS INNER RING & CS OUTER RING, B16.20

GASKET - CL 300, 304 SS, SPW, INHIBITED GRADE FLEXIBLE GRPH (e.g., BP, GTB, OR
VR1 ½ 24 EQUAL), 0.175-INCH THK, W/ 304 SS INNER RING & CS OUTER RING, B16.20

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 6 of 10

LINE CLASS SPECIFICATION N2

SERVICE: STEAM, CONDENSATE, BOILER FEEDWATER DOC. NO.: SP-50-03-N2

DESIGN BASIS: ASME B16.5 MG 1.1 (SEE PRESSURE/TEMPERATUE CURVE) REV.: 15

CODE: ASME B31.3; CATEGORY D & NORMAL FLUID SERVICES DATE: 12/21/2018
CORROSION ALLOWANCE MATERIAL FLANGE RATING TEMP. RATING
0.125 IN CARBON STEEL CL 150 RF -20/800°F
SIZE REFERENCE CODE /
NOTE NO. DESCRIPTION
MIN MAX LARGE END SIZE
BL2 BOLTING (SEE NOTE BL2 & REFERENCE SP-50-34)
½ 99 STUD BOLT - CR-MO (A193 GR B7) W/ CS (A194 GR 2H) HEAVY HEX NUTS
½ 99 CAP SCREW - HEAVY HEX HEAD, CR-MO (A193 GR B7), UNC

WASHER - CS, THROUGH-HARDENED PER ASTM F436 (TYPE 1). ONLY USE PER SP-
½ 99 50-16, SECTION 2.5

STRAINERS
Y-STRAINER - CL 600, SW, CS, 304 SS SCREEN W/ 0.033-INCH PERFORATIONS,
½ 2
MUELLER 862-BC OR EQUAL
TEMPORARY STRAINER - CL 150, RF/FF, CS, BASKET, 1/8-INCH PERFORATIONS,
3 24 ROYAL GUARD 51-P, MAC IRON M/N 150# RF PBS OR EQUAL

LINE BLANKS
CORROSION ALLOWANCE OF ZERO IS USED FOR SS MATERIAL
½ 12 FIGURE 8 BLANK - CL 150, A240-TP304/304L SS, B16.48
14 24 PADDLE BLANK - CL 150, A240-TP304/304L SS, B16.48 (CALCULATE THICKNESS)
14 24 PADDLE SPACER - CL 150, A240-TP304/304L SS, B16.48

VR1 ½ 10 FIGURE 8 BLANK - CL 300, A240-TP304/304L SS, B16.48

VR1 12 24 PADDLE BLANK - CL 300, A240-TP304/304L SS, B16.48 (CALCULATE THICKNESS)
VR1 12 24 PADDLE SPACER - CL 300, A240-TP304/304L SS, B16.48

STEAM TRAP
½ 1 STEAM TRAP - INV BUCKET, CL 400, SW, UNIV, 304/304L SS
UN1, YM8, YMU ½ 2 UNION - CL 3000, SW, CS (A105), UNIFLEX (SPENCE), MSS SP-83
UN2, YM8, YMU ½ 2 UNION - CL 3000, THRD, CS (A105), UNIFLEX (SPENCE), MSS SP-83

STEAM TRACER TRAPS

YMB ¾ ¾ STEAM TRAP - THERMOSTATIC, THRD, SS W/ BLOW OFF VALVE

BRANCHES
SEE BRANCH TABLE ATTACHED

CONSTRUCTION DETAILS
PIPE BENDS.....................................SEE SP-50-03, SECTION 10
THREAD SEALANT............................SEE SP-50-03, SECTION 10
INSTRUMENTATION SPEC.................SEE SP-75-01

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 7 of 10

LINE CLASS SPECIFICATION N2

BB-Bolted Bonnet, BBE-Beveled Both Ends, BLE-Beveled Large End, BSB-Bellows Seal Bonnet, BW-Buttweld, CA-Corrosion Allowance, CL-Class,
CS-Carbon Steel, CWP-Cold Working Pressure, DSAW-Double Submerged Arc Welded, EFW-Electric Fusion Welded, F2F-Face to Face, FLG-Flange,
FP-Full Port, FPT-Female Pipe Thread, FS-Fire Safe, GO-Gear Operator, GR-Grade, GRPH-Graphite, GSKT-Gasket, HB-Brinell Hardness, LR-Long Radius,
Abbreviations LWN-Long Weldneck, M/N-Model Number, MSW-Male Socket Weld, OS&Y-Outside Screw & Yoke, PBE-Plain Both Ends, PE-Plain End,
PSE-Plain Small End, PTFE-Teflon, PWHT-Post Weld Heat Treatment, RF-Raised Face, RPTFE-Reinforced Teflon, SAW-Submerged Arc Welded,
SCH-Schedule, SMLS-Seamless, SPW-Spiral Wound, STD-Standard, STL-Steel, SW-Socket Weld, SW/T-Socket Weld/Threaded,
TBE-Threaded Both Ends, THK-Thick, TLE-Threaded Large End, TOE-Threaded One End, TSE-Threaded Small End, WN-Weldneck

NOTE NO. NOTE

BOLT LENGTH SPECIFIED IS THE EFFECTIVE THREAD LENGTH. ROUNDED OR CHAMFERED END POINTS SHALL NOT BE INCLUDED
WHEN MEASURING LENGTH OF BOLTS. BOLT LENGTHS SHALL BE IN ACCORDANCE WITH TABLES 7, 10, 15, 17, 19, AND 21 OF ASME
BL2
B16.5 FOR STANDARD FLANGED JOINTS. FOR NONSTANDARD FLANGED JOINTS, THE METHOD SHOWN IN APPENDIX C OF ASME B16.5
SHALL BE USED TO CALCULATE THE BOLT LENGTH.
FL4 WELDING NECK FLANGES AND BUTTWELDING FITTINGS MAY BE USED IN NPS ½ THROUGH 2.
ORIFICE FLANGES SHALL BE FURNISHED IN PAIRS, SUPPLIED WITH JACKSCREWS, AND SHALL BE FURNISHED WITH SOLID FORGED
FO1
PLUGS (NOT WELDED-IN) WITH THE SAME BASIC METALLURGY AS THE FLANGES.
USE SOCKETWELD FULL COUPLING FOR LINE COUPLING ONLY. USE SOCKOLET OR SOCKETWELD TEE FOR SOCKETWELD BRANCH
NC1
CONNECTIONS. SEE BRANCH CHART IN THIS LINE CLASS SPECIFICATION.
DESIGN OF THE PIPING SYSTEM MUST ADDRESS SMALL BORE BRANCH PIPING CONNECTIONS SUCH AS PIPING TREES USED IN
CONNECTIONS WITH EQUIPMENT, INSTRUMENTATION, AS WELL AS PIPING. HEAVIER WALL PIPE SHALL BE USED ON SMALL BORE
BRANCH CONNECTIONS FOR MECHANICAL STRENGTH; THEREFORE, ALL BRANCH CONNECTIONS NPS 1 OR SMALLER SHALL BE A
NC4 MINIMUM OF SCHEDULE 160 UP TO THE FIRST BLOCK VALVE OR FITTING. FOR EXAMPLE, ALL NPS ¾ BLEEDERS AND VENTS SHALL BE
INSTALLED WITH SCH 160 MINIMUM PIPE NIPPLES. (THIS DOES NOT INCLUDE BRANCHES THAT ARE CONNECTED TO ANOTHER
PROPERLY SUPPORTED CONTINUOUS PIPING RUN.) FOR STAINLESS STEEL OR NICKEL-ALLOY MATERIALS, BRANCH CONNECTIONS
MAY BE SCHEDULE 80S WHERE SCHEDULE 160 IS SPECIFIED ABOVE.
THREADED ENDS MAY ONLY BE USED DOWNSTREAM OF FIRST WELDED BLOCK VALVE. USE SWAGES WHERE SMALL END IS NPS 2 OR
NR4 SMALLER AND LARGE END IS NPS 4 OR SMALLER. USE REDUCERS FOR SMALL END LARGER THAN NPS 2. A NPS 3 OR 4 LARGE END
WILL NORMALLY BE BEVELED FOR BUTT-WELDING.
WHERE SOCKETWELD (SW) CONNECTIONS ARE USED, A MULTI-PASS WELD TECHNIQUE IS REQUIRED. WHERE SW CONNECTIONS ARE
NS2
USED ON RELIEF VALVE INLET LINES, THEY SHALL REQUIRE DYE PENETRANT OR MAGNETIC PARTICLE TESTING BE PERFORMED.
USE FOR UNVALVED HYDROTEST VENTS AND DRAINS; SEALWELD THE PLUG AFTER HYDROTESTING FOR ALL HYDROCARBON AND
PLG STEAM SERVICES. DO NOT USE THREAD COMPOUND ON JOINT TO BE SEALWELDED. "OPERATIONAL" PLUGS ARE ADDRESSED IN SP-
50-34.
TFR THERMOWELL FLANGE RATING SHALL BE THE SAME AS THE PIPING LINE CLASS SPECIFICATION.
USE THREDOLET AND SCREWED PLUG FOR HIGH POINT, HYDROSTATIC TEST VENT PURPOSES ONLY. SEAL WELD PLUG IMMEDIATELY
UD7
AFTER HYDROSTATIC TEST. IF REQUIRED, LOCALLY PWHT AFTER WELDING.
USE FOR PI, TI, TE AND TW INSTRUMENT CONNECTIONS, HOSE CONNECTIONS, & PSV CONNECTIONS FOR LIQUIDS - TEMPERATURES
UI8
UP TO 400°F.
USE FOR PI, TI, TE AND TW INSTRUMENT CONNECTIONS, ALL HYDROGEN SERVICE LINES, AND CLASS 600 PIPING AND ABOVE. THE
UI9
THICKNESS OF ANY “FLANGED PIPET®”, WELDOLET, OR ELBOLET SHOULD MATCH OR EXCEED THE PIPING REQUIRED THICKNESS.
UN1 UNIFLEX PIPE COUPLING (SUA-SW) IS A MODIFIED STEEL PIPE UNION WITH A SPIRAL-WOUND GASKET.
UN2 UNIFLEX (SUA-T) PIPE COUPLING IS A MODIFIED STEEL PIPE UNION WITH A SPIRAL-WOUND GASKET.
UP1 USE FOR PI CONNECTIONS.
USE WHERE POSITIVE SHUTOFF AND RELIABILITY ARE REQUIRED. PATTERN IS DOUBLE FLANGED. THE STELLITE® WELD OVERLAY ON
VBL SEAT AND DUPLEX SS (UNS S31803) SEAL RING COMBINATION OFFERS THE GREATEST DEGREE OF THERMAL COMPATIBILITY IN ORDER
TO AVOID THE POTENTIAL PROBLEM OF THE VALVE STICKING IN THE SEAT DUE TO HIGHER OPERATING TEMPERATURES.
VC2 INSTALL THESE CHECK VALVES IN HORIZONTAL POSITION ONLY.
VC4 INSTALL THESE CHECK VALVES IN HORIZONTAL POSITION WITH COVER UP OR IN VERTICAL POSITION WITH UPWARD FLOW.
INSTALL IN HORIZONTAL POSITION WITH HINGE PIN VERTICAL OR IN VERTICAL POSITON WITH UPWARD FLOW. FOR VERTICAL FLOW
VC5 APPLICATIONS, SEVERE PUMP APPLICATIONS, OR APPLICATIONS WITH PRESSURE SURGE OR WATER HAMMER ISSUES, CONTACT THE
MANUFACTURER/FACTORY WITH PROCESS CONDITIONS.
EXTENDED BODY, ONE-PIECE FORGING, BOLTED BONNET, MSW (MALE SOCKET WELD) X FPT (FEMALE PIPE THREADS). THE MSW X FPT
WILL NORMALLY BE USED WITH A SOCKOLET OR SOCKET WELD FITTING. THE BONNEY FORGE VALVE FIGURE NUMBER IS FIG. ML-10
VG6
(800#) OR 9ML-10 (1500#) WHICH COVERS AN EXTENDED BODY, SOCKET WELDED-PLAIN END, BOLTED BONNET VALVE. ALSO REFER TO
SMITH FIG. 0812 (800#). AN "OR EQUAL" MAY BE PROVIDED WITH ENGINEERING APPROVAL.
VG7 EXTENDED BODY GATE VALVES MAY BE USED FOR VENTS, DRAINS, AND INSTRUMENT CONNECTIONS.
EXTENDED BODY, ONE-PIECE FORGING, BOLTED BONNET, INTEGRALLY REINFORCED VALVOLET END X FPT. THE CONTOUR OF
VG8 "VALVOLET" EXTENSION IS TO MATCH THE OD OF [SPECIFY] NPS RUN PIPE OR THE VALVOLET END MAY HAVE A LIP END. UTILIZE
BONNEY FORGE FIG. VLL-10 (800#) OR 9VLL-10 (1500#), SMITH FIG. 0874 (800#), OR EQUAL.
VR1 TO BE USED WHEN MATING WITH CLASS 300 RATED EQUIPMENT NOZZLE OR FLANGE.
VUN USE THESE FLANGED VALVES AT EQUIPMENT NOZZLES AND WHERE ISOLATION BLINDING MAY BE REQUIRED.
VV1 ALL API 602 VALVES ARE STANDARD PORT UNLESS INDICATED OTHERWISE. ALL API 600 & 603 VALVES ARE FULL PORT.
OTHER VALVES, INCLUDING "HOT TAP" VALVES AND SPECIAL DISSIMILAR TYPE CHECK VALVES THAT DO NOT APPEAR ON THIS
SPECIFICATION, SHALL BECOME SPECIALTY ITEMS / ENGINEERED ITEMS PER SP-50-03. THEY SHALL MEET ALL THE DESIGN
VV2
REQUIREMENTS OF THIS SPECIFICATION AND BE PURCHASED FROM THE PIPE, VALVE AND FITTINGS AML (RSP-1565-000-PVFAML).
THEY WILL NOT REQUIRE A SPEC. WAIVER.
VV3 ONLY USE THIS VALVE FOR VENTS, DRAINS AND INSTRUMENT CONNECTIONS.
USE ONLY WHERE SPECIFICALLY INDICATED ON P&ID FOR LOCATIONS REQUIRING FULL PORT VALVE SUCH AS INSTRUMENTS, HOT
VV4
TAPS, INLETS TO PUMPS, INLET/OUTLET ON PSV'S, ETC.
TO BE USED ONLY ON STEAM AND CONDENSATE MANIFOLDS FOR TRACERS. NOT TO BE USED ABOVE 300 PSIG AT 450°F. REFERENCE
YM8
STANDARD REFINERY DRAWING SD-4-572.
YMB TO BE USED ONLY ON STEAM AND CONDENSATE MANIFOLDS FOR TRACERS. NOT TO BE USED ABOVE 300 PSIG AT 450°F.
YMD THESE UNIONS ARE ONLY TO BE USED FOR CATEGORY D FLUID SERVICE PER THE LATEST EDITION OF ASME B31.3.
ALL UNIONS SHALL BE PER MSS SP-83. UNION PARTS FROM DIFFERENT MANUFACTURERS ARE NOT FUNCTIONALLY INTERCHANGABLE
YMU
AND COMBINING PARTS FROM DIFFERENT MANUFACTURERS IS NOT RECOMMENDED.

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 8 of 10

LINE CLASS SPECIFICATION N2

BRANCH TABLE - N2
90 Degree Branch Connection Table. Branch Connections shall be in accordance with ASME B31.3.

½ T
¾ T Legend:
SOL = Sockolet
1 T
TOL = Thredolet
1½ RTs, Note 7 T WOL = Weldolet (Note 5)
2 T T = Straight Tee
HEADER SIZE (NPS)

3 T RT = Reducing Tee
4 RT T RTs = SW Reducing Tee
6 RT, Note 4 RT T
8 RT, Note 4 RT T
10 RT, Note 4 RT T
12 RT, Note 4 RT T
14 RT, Note 4 RT T
16 SOL, Note 2 WOL, Notes 1, 3 RT, Note 4 RT T
18 RT, Note 4 RT T
20 RT, Note 4 RT T
24 RT, Note 4 RT T
½ ¾ 1 1½ 2 3 4 6 8 10 12 14 16 18 20 24
BRANCH SIZE (NPS)

Branch Table Notes

1. WOL covers a number of fittings including the weldolet, an insert weldolet (Bonney Forge Insert Weldolet or WFI SRV
Vesselet) and a contoured fitting (Bonney Forge Sweepolet or WFI Vesselet). The weldolet, manufactured to MSS SP-97,
is an ASME B31.3 listed component. The insert weldolet and the contoured fittings are not listed, but have been qualified in
accordance with the code. The qualified fittings should be used in vibrating or cyclic service or where radiographic
examination of the weld is required; they may be preferred in larger branch sizes because of the smaller weld size
requirement. Engineering shall specify which fitting to use.
2. Sockolet is the default branch fitting.
3. Weldolet is the default branch fitting; a Reducing Tee may be used if available.
4. Reducing Tee is the default branch fitting; a Weldolet is acceptable where a Reducing Tee cannot be used.
5. Integrally reinforced branch connections are permitted outside the sizes shown in the branch connection tables. Designer
shall check weld thickness of integrally reinforced branch connections to determine if PWHT is required.
6. This table does not apply to hot taps, thermowells, pipe made of concrete, cement-lined steel, ductile iron pipe, or services
defined by ASME B31.3 as Category M, High Pressure, or Severe Cyclic.
7. SW Reducing Tee (RTs) is the default branch fitting; a Sockolet may be used where a RTs cannot be used.

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 9 of 10

LINE CLASS SPECIFICATION N2

PRESSURE/TEMPERATURE LIMITS (FLANGE RATED PER ASME B16.5, MG 1.1, CLASS 150)

Size (NPS) Deg F -20 100 200 300 350 390 400 500 600 650 700 750 800
½ - 24 Psig 285 285 260 230 215 204 200 170 140 125 110 95 80
Saturated Steam Psig 0.0 53 120 204
Category D Fluid Psig 150 150 150 150 150

LINE CLASS N2 FLANGE RATING PER ASME B16.5, MG 1.1, CL 150

300 Notes:
285 285
1. Do not use above pressure and
260 temperature limits shown.
250
ASME B16.5, MG 1.1, CL 150
230
SATURATED STEAM CURVE
PRESSURE (PSIG)

215 204
Category D Fluid
200 200

170

150
140
125
110
100 95
SUPERHEATED 80
STEAM
50

0
-50 50 150 250 350 450 550 650 750 850

TEMPERATURE oF

Printed: 2/25/2019
 MARATHON PETROLEUM COMPANY LP SHEET 10 of 10

LINE CLASS SPECIFICATION N2

CHANGE LOG
REVISION
REV. NO. DESCRIPTION OF CHANGE AUTHOR APPROVED BY DATE
0-3 No record. -- -- --
Spec was converted to new format; Added note UN1 and reference "UNIFLEX (SPENCE)" to 1/2 - 2
4 UNION - CL 3000, SW, STL, A105; and added fitting 1/2 - 2 CL 3000, THRD, STL, A105 M.A. Garlinger -- 11/10/2009

Added Thermostatic per Don Akers and deleted manufacturer. Combined 3 - 10 Sch 40 pipe and
12 - 24 Std Wt pipe since they are the same. Added SPECIAL PROVISIONS at top and added
5 D.H. Akers -- 8/6/2010
LARGE END SIZES to the REFERENCE column. Moved note TS0 from 1/2 - 2 Y-Strainer to the 3 -
24 Strainer.
Added Pipe Weld Data Sheet reference, dual door check valves, and updated gasket information
6 M.I. Etter -- 4/23/2013
and line blank designations.
Consolidated Core, GME and DHOUP's SP-50-03, rev. 7 line class into this one line class. Engineering and
Pipe Spec
7 Increased Corrosion Allowance to 0.125, added Boiler Feedwater, and changed number from N1 to Maintenance 2/20/2014
Advisory Group
N2. Managers
8 Revised Olet Section size range from ½" - 2" to ¾" - 2". M.D. Bush M.I. Etter 6/10/2014
9 Added valve codes. Deleted API 600 Gate Valves with FP (Full Port) in description. M.D. Bush M.I. Etter 8/29/2014
Added a new instrument tubing spec & link, added code references, revised valve bonnet gasket
description, added packing info, added API 602 CL 300 standard port gate valve, added new notes
YMD & YMU for UNION in FITTINGS section, added SLIP-ON note & Slip-On Flanges in FLANGE
section, added tap size in ORIFICE section, added note NR4 to PIPE NIPPLES section, added
10 notes DL4 & NR4 and revised BBE to PBE and added THICKNESS TO MATCH PIPE in SWAGE M.D. Bush M.I. Etter 9/10/2014
NIPPLES section, added gasket & bolting reference, added Heavy Hex to nut description, added
manufacturer reference for temporary strainer, added corrosion allowance to LINE BLANK section,
revised notes NR4, VV1, & YM8, deleted notes VGO & VOR, and revised branch chart.

Revised CODE description to include both Category D & Normal Fluid Services, added instrument
11 tubing material, added valve bonnet gasket material, revised SWAGE NIPPLES section, specified M.D. Bush M.I. Etter 9/24/2014
zero corrosion allowance for SS Line Blank material, and deleted note DL4.
Added NPS 2-10 extended body dual-door check valves, revised max size of SW/T Gate Valve from
NPS 2 to 1½, clarified Inconel X spring to read Inconel X-750, updated the trim for the Butterfly
Valves, revised max size of Cap & Plug from NPS 2 to 1½, added reducing tees in Fittings Section,
added Note UD7 on Thredolet in OLET FITTINGS section, added Thredolets to Olet Fittings
12 Section, added SMLS requirement to fittings and pipe nipples, added notations limiting max M.D. Bush M.I. Etter 12/28/2015
threaded size to NPS 1½ for pipe nipples & swage nipples, updated description for flexible graphite
in gaskets, added through-hardened washers, revised Y-Strainer screen size from 0.062" to 0.033",
removed "RF" in Line Blank section, deleted row for Seal Welding under Construction Details,
added new Note UD7, and revised Notes VBL & VC5.
GBR Consolidation: Changed Max Temp to 800F, added note to Special Provisions in regards to
multi-pass welds on SW connections, added CL 800 extended body gate valves, updated packing
info, changed Inconel X-750 requirement for piston check valves springs to Stainless Steel (SS),
added CL 800 Swing Check valves, removed the 316 SS Trim requirement on butterfly valves,
added SCH 160 option for NPS 3/4 - 1 piping for "special" branch connections, deleted THRD & SW Engineering and
13 Caps from Fittings Section, added Nipolet to OLET FITTINGS section, revised Swage Nipple M.D. Bush Maintenance 12/22/2016
section, deleted Kammprofile gaskets, updated gasket description & revised size range of SPW Managers
Gaskets to include down to NPS 1/2, added notes FL4, NC4, NS2, VC7, VG6 & VG7, revised notes
PLG, UI8, VC5 & VV1, deleted note UD6, updated Abbreviations on Notes Page, updated Branch
Table notes, and revised P/T chart to reflect new max temperature of 800F.

14 Removed the size overlap for the CL 6000 fittings and revised note NC4. M.D. Bush M.I. Etter 2/22/2017
Removed Low Pressure designation from service description, added steam service valve
preferences, added LATEST ED. & API 622 APPROVED to valve descriptions, updated description
for extended bonnet gate valve w/ Valvolet end, added NPS ½ - 2 API 602 bellows seal gate valve,
updated globe valve size range to NPS 24 & added option for Y-pattern globe, added small bore
globe valves with weld in seats, revised EB dual door check valve, removed "preferred" from dbl.
flgd. dual door check valve, revised Butterfly Valves F2F pattern per API 609, added LokRing
fittings for use in Category D Fluids, revised max size of unions from NPS 2 to NPS 1½ to be
A.L. Knipp &
15 consistent on threaded fittings, revised size range of SCH 160 nipolets to go up to NPS 1 and added M.I. Etter 12/21/2018
M.D. Bush
note NC4, revised size range of SCH 80 nipolet to begin with NPS 1½, changed Instrument
Connection fittings from SCH 160 to SCH 80, revised SCH 160 SW flange range up to NPS 1 &
added Note NC4 to those rows, changed NPS 2 WN flange from SCH 160 bore to SCH 80 bore,
added Flanged Pipet to Pipe Flange section, revised small end size range for all Sch 80 nipples to
begin with NPS 1½, corrected CL 300 Line Blank size ranges, added Notes BL2, TFR, & VG8,
revised Notes NC4, UI9, VG6, & VV2, deleted Note VC7, and added "Category D Fluids" to P/T
Chart.

Printed: 2/25/2019
