DIY Arduino based Color Sorter Machine using TCS3200 Color Sensor connectors for servers and storage devices.

As the name suggests, color sorting is simply to sort the things according to their color. It can be easily done
by seeing it but when there are too many things to be sorted and it is a repetitive task then automatic color
sorting machines are very useful.  These machines have color sensor to sense the color of any objects and
after detecting the color servo motor grab the thing and put it into respective box. They can be used in
different application areas where color identi cation, color distinction and color sorting is important. Some of
the application areas include Agriculture Industry (Grain Sorting on the basis of color), Food Industry, Diamond
and Mining Industry, Recycling etc. The applications are not limited to this and can be further applied to
different industries.

NEWS ARTICLES PROJECTS

Replacing Lithium in Rechargeable

Batteries with Potassium for
Sustainable Environment

Low Power SMD Proximity Sensor

from Vishay for Consumer and
Industrial Applications
Most popular sensor for detecting the colors is TCS3200 color sensor. We previously used TCS3200 sensor
with Arduino to get the RGB component (Red, Green, Blue) of any color and also interfaced it with Raspberry Pi Highly Robust and E cient IGBT Gate
for detecting the color of any object. Driver with Automotive Quali cation

Here in this tutorial we will make a color sorting machine using a color sensor TCS3200, some servo motors
Space-Quali ed COTS-Based
and Arduino board. This tutorial will include the sorting of colored balls and keeping them in the relevant Radiation-Tolerant Ethernet
Transceiver and Embedded
color box. The box will be in the xed position and the servo motor will be used to move the sorter hand to
Microcontroller
keep the ball in the relevant box.
Digi-Key Electronics Helps Companies
Innovate Faster at Embedded World
Components Required
2020

Arduino UNO
TCS3200 Color Sensor
Servo Motors
Jumpers
Breadboard

How to make the chassis for Color Sorting Robotic Arm

For making the complete setup including chassis, arm, roller, pad, we have used the white Sunboard of 2mm
thickness. It is easily available in the stationary stores. We have used paper cutter to cut the Sunboard Sheet
and FlexKwik or FeviKwik for joining the different parts.
Below are some steps build the Color sorting Arm:

1) Take the Sunboard Sheet.

DataSheet PDF Search Site. - Download

Datasheets for Free. OPEN

Offers you a great collection of semiconductor datasheet. datasheetspdf.com

2) Cut the sunboard sheet into pieces after measuring all sides with scale and marker as shown in the gure.

3) Now hold the two pieces of sunboard together and pour a drop of FeviKwik on it to stick the pieces
together. Keep joining the pieces by following the gure.

4) After joining all the pieces together, this color sorting machine will look something like this:

TCS3200 Color Sensor

TCS3200 is a color sensor which can detect any number of colors with right programming. TCS3200 contains
RGB (Red Green Blue) arrays. As shown in gure on microscopic level one can see the square boxes inside
the eye on sensor. These square boxes are arrays of RGB matrix. Each of these boxes contain three sensors,
One is for sensing RED light intensity, One is for sensing GREEN light intensity and the last in for sensing BLUE
light intensity.

Each of sensor arrays in these three arrays are selected separately depending on the requirement. Hence it is
known as programmable sensor. The module can be featured to sense the particular color and to leave the
others. It contains lters for that selection purpose. There is a forth mode called ‘no lter mode’ in which the
sensor detects white light.

Circuit Diagram

The circuit diagram for this Arduino Color Sorter is pretty easy to make and doesn’t require much
connections. The schematic is given below.

SPONSORED SEARCHES

Coding Software

Color Sorter Arduino Code

This is the circuitry behind the setup of color sorting machine:

Programming Arduino Uno for sorting colourful balls

Programing Arduino UNO is a pretty simple and requires a simple logic to simplify the steps involved in color
sorting. Complete program with a demonstration Video is given at the end.

Since the servo motor is used, so the servo library is essential part of the program. Here we are using two
servo motors. The rst servo will move the colored balls from initial position to TCS3200 detector position
and then move to the sorting position where the ball will be dropped. After moving to sorting position, the
second servo will drop the ball using its arm to the desired color bucket. See the complete working in the
Video given at the end.

The rst step will be all library inclusion and de ne the servo variables.

#include <Servo.h>
Servo pickServo;
Servo dropServo;

The TCS3200 color sensor can work without library as there is only need of reading frequency from sensor pin
to decide the color. So just de ne the pin numbers of TCS3200.

#define S0 4
#define S1 5
#define S2 7
#define S3 6
#define sensorOut 8
int frequency = 0;
int color=0;

Make the select pins as output as this will make the color photodiode high or low and take the Out pin of
TCS3200 as input. The OUT pin will provide frequency. Select the scaling of frequency as 20% initially.

pinMode(S0, OUTPUT);
pinMode(S1, OUTPUT);
pinMode(S2, OUTPUT);
pinMode(S3, OUTPUT);
pinMode(sensorOut, INPUT);
digitalWrite(S0, LOW);
digitalWrite(S1, HIGH);

The servo motors are connected at Pin 9 and 10 of Arduino. The pickup servo which will pickup the color balls
is connected at Pin 9 and the drop servo which will drop the color balls according to the color is connected at
Pin10.

pickServo.attach(9);
dropServo.attach(10);

Initially the pick servo motor is set in the initially position which in this case is 115 degrees. It may differ and
can be customized accordingly. The motor moves after some delay to the detector region and waits for the
detection.

pickServo.write(115);
delay(600);
for(int i = 115; i > 65; i--) {
pickServo.write(i);
delay(2);
}
delay(500);

The TCS 3200 reads the color and gives the frequency from the Out Pin.

color = detectColor();
delay(1000);

Depending Upon the color detected, the drop servo motor moves with particular angle and drops the color ball
to its respective box.

switch (color) {
case 1:
dropServo.write(50);
break;
case 2:
dropServo.write(80);
break;
case 3:
dropServo.write(110);
break;
case 4:
dropServo.write(140);
break;
case 5:
dropServo.write(170);
break;
case 0:
break;
}
delay(500);

The servo motor returns to the initial position for the next ball to pick.

for(int i = 65; i > 29; i--) {

pickServo.write(i);
delay(2);
}
delay(300);
for(int i = 29; i < 115; i++) {
pickServo.write(i);
delay(2);
}

The function detectColor() is used to measure frequency and compares the color frequency to make the
conclusion of color. The result is printed on the serial monitor. Then it returns the color value for cases to
move the drop servo motor angle.

int detectColor() {

Writing to S2 and S3 (LOW,LOW) activates the red photodiodes to take the readings for red color density.

digitalWrite(S2, LOW);
digitalWrite(S3, LOW);
frequency = pulseIn(sensorOut, LOW);
int R = frequency;
Serial.print("Red = ");
Serial.print(frequency);//printing RED color frequency
Serial.print(" ");
delay(50);

Writing to S2 and S3 (LOW,HIGH) activates the blue photodiodes to take the readings for blue color density.

digitalWrite(S2, LOW);
digitalWrite(S3, HIGH);
frequency = pulseIn(sensorOut, LOW);
int B = frequency;
Serial.print("Blue = ");
Serial.print(frequency);
Serial.println(" ");

Writing to S2 and S3 (HIGH,HIGH) activates the green photodiodes to take the readings for green color
density.

digitalWrite(S2, HIGH);
digitalWrite(S3, HIGH);

// Reading the output frequency

frequency = pulseIn(sensorOut, LOW);
int G = frequency;
Serial.print("Green = ");
Serial.print(frequency);
Serial.print(" ");
delay(50);

Then the values are compared to make the color decision. The readings are different for different
experimental setup as the detection distance varies for everyone when making the setup.

if(R<22 & R>20 & G<29 & G>27){

color = 1; // Red
Serial.print("Detected Color is = ");
Serial.println("RED");
}
if(G<25 & G>22 & B<22 &B>19){
color = 2; // Orange
Serial.println("Orange ");
}
if(R<21 & R>20 & G<28 & G>25){
color = 3; // Green
Serial.print("Detected Color is = ");
Serial.println("GREEN");
}
if(R<38 & R>24 & G<44 & G>30){
color = 4; // Yellow
Serial.print("Detected Color is = ");
Serial.println("YELLOW");
}
if (G<29 & G>27 & B<22 &B>19){
color = 5; // Blue
Serial.print("Detected Color is = ");
Serial.println("BLUE");
}
return color;
}

This nishes the color sorting machine using TCS3200 and Arduino UNO. You can also program it to detect
more colors if needed. If you have any doubt or have any suggestion then write to our forum or comment
below. Also check the video given below.

Code
#include <Servo.h>

Servo pickServo;

Servo dropServo;

#de ne S0 4

#de ne S1 5

#de ne S2 7

#de ne S3 6

#de ne sensorOut 8

int frequency = 0;

int color=0;

int detectColor() {

  // activating red photodiodes to read

  digitalWrite(S2, LOW);

  digitalWrite(S3, LOW);

  frequency = pulseIn(sensorOut, LOW);

  int R = frequency;

  Serial.print("Red = ");

  Serial.print(frequency);//printing RED color frequency

  Serial.print("   ");

  delay(50);

   // activating blue photodiodes to read

  digitalWrite(S2, LOW);

  digitalWrite(S3, HIGH);

  frequency = pulseIn(sensorOut, LOW);

  int B = frequency;

  Serial.print("Blue = ");

  Serial.print(frequency);

  Serial.println("   ");



  // activating green photodiodes to read

  digitalWrite(S2, HIGH);

  digitalWrite(S3, HIGH);

  // Reading the output frequency

  frequency = pulseIn(sensorOut, LOW);

  int G = frequency;

  Serial.print("Green = ");

  Serial.print(frequency);

  Serial.print("   ");

  delay(50);

  delay(50);

//Readings are different for different setup

//change the readings according your project and readings detected

  if(R<22 & R>20 & G<29 & G>27){

    color = 1; // Red

    Serial.print("Detected Color is = ");

    Serial.println("RED");

 }

  if(G<25 & G>22 & B<22 &B>19){

    color = 2; // Orange

      Serial.println("Orange  ");

 }

  if(R<21 & R>20 & G<28 & G>25){

    color = 3; // Green

      Serial.print("Detected Color is = ");

    Serial.println("GREEN");

 }

  if(R<38 & R>24 & G<44 & G>30){

    color = 4; // Yellow

       Serial.print("Detected Color is = ");

    Serial.println("YELLOW");

 }

  if (G<29 & G>27 & B<22 &B>19){

    color = 5; // Blue

     Serial.print("Detected Color is = ");

    Serial.println("BLUE");

 }

  return color;

void setup() {

  pinMode(S0, OUTPUT);

  pinMode(S1, OUTPUT);

  pinMode(S2, OUTPUT);

  pinMode(S3, OUTPUT);

  pinMode(sensorOut, INPUT);

  //frequency-scaling to 20% selected

  digitalWrite(S0, LOW);

  digitalWrite(S1, HIGH);

  pickServo.attach(9);

  dropServo.attach(10);

  Serial.begin(9600);

void loop() {

  //initial position of servo motor

  pickServo.write(115);

  delay(600);



  for(int i = 115; i > 65; i--) {

    pickServo.write(i);

    delay(2);

 }

  delay(500);

  //read color values by calling function. save the values for conclusion in variable

  color = detectColor();

  delay(1000);

  switch (color) {

    case 1:

    dropServo.write(50);



    break;

    case 2:

    dropServo.write(80);

    break;

    case 3:

    dropServo.write(110);

    break;

    case 4:

    dropServo.write(140);

    break;

    case 5:

    dropServo.write(170);

    break;



    case 0:

    break;

 }

  delay(500);



  for(int i = 65; i > 29; i--) {

    pickServo.write(i);

    delay(2);

  }

  delay(300);



  for(int i = 29; i < 115; i++) {

    pickServo.write(i);

    delay(2);

 }

  color=0;

Video

DIY Arduino based Color Sorting Machine Project

TAGS ARDUINO UNO ARDUINO COLOR SENSOR ROBOTICS ROBOTIC ARM SERVO MOTOR

RECOMMENDED POSTS

Dev Kit Weekly: Ayla Dev Kit Weekly: Industrial IoT Workloads The Engineer's Answer
Development Kit v2.0 BeagleBone AI Bene t from Edge to to Faster Sampling at
Cloud Intelligence Lower Power

Modem or Module? Enhancing Debug and How to Develop High- IoT Device Security
Answering a Key Trace Capabilities for Performance Object Conference 2020
Question for Cellular IoT System Developers Recognition on FPGA
Design Projects Edge Devices

Get Our Weekly Newsletter!

Subscribe below to receive most popular news, articles and DIY projects from Circuit Digest

Email Address *

Name

Country
United States of America

Subscribe

RELATED CONTENT

Interfacing ADXL345 Rain Detection System How to Interface Wireless Doorbell using
Accelerometer with using Arduino and Rain BMP280 Pressure Arduino and RF Module
Arduino UNO Sensor Sensor Module with
Arduino

LED Display Board using Automatic Bottle Filling Arduino Currency Login to Windows
P10 LED Matrix Display System using Arduino Counter using IR and Computers using RFID
and Arduino Color Sensor tag and Arduino

 PREVIOUS POST NEXT POST 

Interfacing OLED Display with NodeMCU Installing Machine Learning Software
ESP8266: Displaying Bitmap image on OLED TensorFlow on Raspberry Pi

COMMENTS

LOG IN OR REGISTER TO POST COMMENT

CATEGORIES POPULAR NEWSLETTER

Embedded Electronics ROBOTICS 555 CIRCUITS Sign Up for Latest News

Connect with us on social media and stay updated with Power Electronics
latest news, articles and projects! ARDUINO PROJECTS Enter your email
Analog Electronics
RASPBERRY PI PROJECTS
      Internet of Things
Subscribe
Audio Electronics ELECTRONICS NEWS

Electric Vehicles
ELECTRONICS FORUM
Events
CALCULATORS

Copyright © 2019 Circuit Digest. All rights reserved. Privacy Policy | Cookie Policy | Terms of Use | Contact Us | Advertise
