< Advanced Graphs Graphical Parameters

You can customize many features of your graphs (fonts, colors, axes, titles) through
Graphical Parameters
graphic options.
Axes and Text
Combining Plots One way is to specify these options in through the par( ) function. If you set parameter
Lattice Graphs values here, the changes will be in effect for the rest of the session or until you change
ggplot2 Graphs them again. The format is par(optionname=value, optionname=value, ...)
Probability Plots

Mosaic Plots
# Set a graphical parameter using par()
Correlograms

Interactive Graphs
par()              # view current settings
opar <- par()      # make a copy of current settings
par(col.lab="red") # red x and y labels
hist(mtcars$mpg)   # create a plot with these new settings
par(opar)          # restore original settings

A second way to specify graphical parameters is by providing the optionname=value

pairs directly to a high level plotting function. In this case, the options are only in effect
for that specific graph.

R in Action

# Set a graphical parameter within the plotting function

hist(mtcars$mpg, col.lab="red")

R in Action (2nd ed)
significantly expands upon this
material. Use promo code ria38
for a 38% discount.
See the help for a specific high level plotting function (e.g. plot, hist, boxplot) to
determine which graphical parameters can be set this way.
The remainder of this section describes some of the more important graphical
parameters that you can set.

Text and Symbol Size

The following options can be used to control text and symbol size in graphs.

option description

cex number indicating the amount by which plotting text and

symbols should be scaled relative to the default. 1=default, 1.5
is 50% larger, 0.5 is 50% smaller, etc.

cex.axis magnification of axis annotation relative to cex

cex.lab magnification of x and y labels relative to cex

cex.main magnification of titles relative to cex

cex.sub magnification of subtitles relative to cex

Plotting Symbols
Use the pch= option to specify symbols to use when plotting points. For symbols 21
through 25, specify border color (col=) and fill color (bg=).

Lines
You can change lines using the following options. This is particularly useful for
reference lines, axes, and fit lines.

option description
lty line type. see the chart below.

lwd line width relative to the default (default=1). 2 is twice as wide.

Colors
Options that specify colors include the following.

option description

col Default plotting color. Some functions (e.g. lines) accept a

vector of values that are recycled.

col.axis color for axis annotation

col.lab color for x and y labels

col.main color for titles

col.sub color for subtitles

fg plot foreground color (axes, boxes - also sets col= to same)

bg plot background color

You can specify colors in R by index, name, hexadecimal, or RGB.

For example col=1, col="white", and col="#FFFFFF" are equivalent.
The following chart was produced with code developed by Earl F. Glynn. See his Color
Chart for all the details you would ever need about using colors in R.

You can also create a vector of n contiguous colors using the functions rainbow(n),
heat.colors(n), terrain.colors(n), topo.colors(n), and cm.colors(n).

colors() returns all available color names.

Fonts
You can easily set font size and style, but font family is a bit more complicated.

option description
font Integer specifying font to use for text.
1=plain, 2=bold, 3=italic, 4=bold italic, 5=symbol

font.axis font for axis annotation

font.lab font for x and y labels
font.main font for titles

font.sub font for subtitles

ps font point size (roughly 1/72 inch)

text size=ps*cex

family font family for drawing text. Standard values are "serif",
"sans", "mono", "symbol". Mapping is device dependent.

In windows, mono is mapped to "TT Courier New", serif is mapped to"TT Times New
Roman", sans is mapped to "TT Arial", mono is mapped to "TT Courier New", and
symbol is mapped to "TT Symbol" (TT=True Type). You can add your own mappings.

# Type family examples - creating new mappings

plot(1:10,1:10,type="n")
windowsFonts(
  A=windowsFont("Arial Black"),
  B=windowsFont("Bookman Old Style"),
  C=windowsFont("Comic Sans MS"),
  D=windowsFont("Symbol")
)
text(3,3,"Hello World Default")
 text(4,4,family="A","Hello World from Arial Black")
text(5,5,family="B","Hello World from Bookman Old Style")
text(6,6,family="C","Hello World from Comic Sans MS")
text(7,7,family="D", "Hello World from Symbol")

click to view

Margins and Graph Size

You can control the margin size using the following parameters.

option description

mar numerical vector indicating margin size c(bottom, left, top, right)
in lines. default = c(5, 4, 4, 2) + 0.1
mai numerical vector indicating margin size c(bottom, left, top, right)
in inches
pin plot dimensions (width, height) in inches

For complete information on margins, see Earl F. Glynn's margin tutorial.

Going Further
See help(par) for more information on graphical parameters. The customization of
plotting axes and text annotations are covered next section.

To Practice
Try this course on making graphs in R.
