OTH

BOOM

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0502 DMTAK 550 141 51gD 1/ 5

BOOM ASSEMBLY

550 141 51

7 5

15

Ref Part No. Description Standard designation Qty

7 325 132 48 HYDR.CYLINDER 125/50 SEP. PART LIST 1

8 550 110 18 HYDR.CYLINDER 125/50 SEP. PART LIST 1
9 239 017 98 HYDR.CYLINDER ASSY SEP. PART LIST 1

PARTS TO BE ORDERED SEPARATELY

5 550 108 68 CYLINDER SEP. PART LIST 1

6 325 135 28 HYDR.CYLINDER 125/80 SEP. PART LIST 1

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
 2/ 5 550 141 51gD 0502 DMTAK

15

10
15
4
22 23 40
30, 37
30, 37 16

22 23 32

25
26 21
24 21

46

28 16
100 28
14

3 36
45
12 34
103 35
102
17
20
19

18
20 102

39
15
47
100 13
23
27

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0502 DMTAK 550 141 51gD 3/ 5

BOOM ASSEMBLY

550 141 51
Ref Part No. Description Standard designation Qty

2 550 141 30 BOOM INCL. PARTS 49, 50, 51 1

3 550 141 28 SWING PIECE INCL. PARTS 48, 50, 51 1
4 550 131 25 CRADLE 1
10 138 357 98 BRACKET 1
12 550 140 63 SHAFT D=60, L=302 1

13 232 147 88 FLANGE 1

14 314 525 98 SPACER PLATE 1
15 263 781 08 TAPER PIN D50 L150 7
16 153 577 78 SLIDE PIECE 6
17 134 182 98 LOCK WASHER 3

18 550 017 99 WASHER d75,l=10 3

19 800 824 29 HEXAGON HEAD SCREW M121X25 m8.8 SFS 2064 6
20 851 068 09 DOUBLE LOCK WASHER M12 12
21 802 198 29 BOLT 16X70 m8.8 SFS 2063 23
22 811 259 69 LOCK NUT M16 m8 B--lock 23

23 850 687 49 DOUBLE LOCK WASHER M16 26

24 517 880 33 PILOT CONTROL NON--RETURN VALVE SEP. PART LIST 1
25 800 527 29 HEXAGON HEAD SCREW M10x50 m8.8 SFS 2064 2
26 851 282 09 DOUBLE LOCK WASHER M10 2
27 442 219 80 HEXAGON HEAD SCREW M 16X50 m8.8 SFS 2064 4

28 264 387 71 TAPER PIN D50 L156 2

29 814 387 99 RUBBER BUFFER 1
30 134 825 08 SUPPORT D=110 2
32 853 496 09 PIPE CLAMP 5
34 048 871 08 BRACKET 2

35 800 823 09 HEXAGON HEAD SCREW M10x20m8.8SFS 2064 2

36 851 282 09 DOUBLE LOCK WASHER M10 4
37 132 965 58 RUBBER PLATE 5
39 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 6
40 237 756 78 SUPPORT 1

42 550 143 27 SHAFT ASSEMBLY 1

45 814 579 99 CROSSOVER RELIEF VALVE SEP. PART LIST 1
46 550 170 85 RING RANGER 1
47 550 170 83 RING 1
48 550 205 36 SPACER S=1/D58 1

49 232 087 98 SHIM S=1,0 5

100 314 534 78 BEARING BUSHING D160 d140 L90 2
101 550 129 53 PLAIN BEARING 65/60 L=60 6
102 134 419 08 BEARING BUSHING D70 d60 L39 4
103 572 102 40 GREASE NIPPLE AR 1/8 7

PARTS TO BE ORDERED SEPARATELY

1 550 141 31 BOOM INCL. PARTS 49, 51 1

11 550 030 50 SHAFT D=60, L=407 1
31 135 059 38 SUPPORT 3
41 550 140 62 SHAFT D=60, L=397 1

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
 4/ 5 550 141 51gD 0502 DMTAK

29
31, 37 31, 37

20 18 31, 37
39
48
20 19
49 41 51
2

102

101 17

15 102

49
49 103 15 15
101
103 42

19 20 17 101
101
11 48 39
18 20

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0502 DMTAK 550 141 51gD 5/ 5

BOOM ASSEMBLY

550 141 51
Ref Part No. Description Standard designation Qty

2 550 141 30 BOOM INCL. PARTS 49, 50, 51 1

3 550 141 28 SWING PIECE INCL. PARTS 48, 50, 51 1
4 550 131 25 CRADLE 1
10 138 357 98 BRACKET 1
12 550 140 63 SHAFT D=60, L=302 1

13 232 147 88 FLANGE 1

14 314 525 98 SPACER PLATE 1
15 263 781 08 TAPER PIN D50 L150 7
16 153 577 78 SLIDE PIECE 6
17 134 182 98 LOCK WASHER 3

18 550 017 99 WASHER d75,l=10 3

19 800 824 29 HEXAGON HEAD SCREW M121X25 m8.8 SFS 2064 6
20 851 068 09 DOUBLE LOCK WASHER M12 12
21 802 198 29 BOLT 16X70 m8.8 SFS 2063 23
22 811 259 69 LOCK NUT M16 m8 B--lock 23

23 850 687 49 DOUBLE LOCK WASHER M16 26

24 517 880 33 PILOT CONTROL NON--RETURN VALVE SEP. PART LIST 1
25 800 527 29 HEXAGON HEAD SCREW M10x50 m8.8 SFS 2064 2
26 851 282 09 DOUBLE LOCK WASHER M10 2
27 442 219 80 HEXAGON HEAD SCREW M 16X50 m8.8 SFS 2064 4

28 264 387 71 TAPER PIN D50 L156 2

29 814 387 99 RUBBER BUFFER 1
30 134 825 08 SUPPORT D=110 2
32 853 496 09 PIPE CLAMP 5
34 048 871 08 BRACKET 2

35 800 823 09 HEXAGON HEAD SCREW M10x20m8.8SFS 2064 2

36 851 282 09 DOUBLE LOCK WASHER M10 4
37 132 965 58 RUBBER PLATE 5
39 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 6
40 237 756 78 SUPPORT 1

42 550 143 27 SHAFT ASSEMBLY 1

45 814 579 99 CROSSOVER RELIEF VALVE SEP. PART LIST 1
46 550 170 85 RING RANGER 1
47 550 170 83 RING 1
48 550 205 36 SPACER S=1/D58 1

49 232 087 98 SHIM S=1,0 5

100 314 534 78 BEARING BUSHING D160 d140 L90 2
101 550 129 53 PLAIN BEARING 65/60 L=60 6
102 134 419 08 BEARING BUSHING D70 d60 L39 4
103 572 102 40 GREASE NIPPLE AR 1/8 7

PARTS TO BE ORDERED SEPARATELY

1 550 141 31 BOOM INCL. PARTS 49, 51 1

11 550 030 50 SHAFT D=60, L=407 1
31 135 059 38 SUPPORT 3
41 550 140 62 SHAFT D=60, L=397 1

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0202 DMJAS 550 108 68b 1/ 1

HYDRAULIC CYLINDER

550 108 68

Ref Part No. Description Standard designation Qty

1 550 108 53 CYLINDER TUBE D 140 , L=754 1

2 550 108 83 PISTON ROD D 80, L=1144 1
3 550 033 82 CYLINDER COVER D 140/80 1
4 053 699 68 PISTON 1
5 816 976 39 PISTON SEAL M140/115x25W 1

6 807 250 49 U--SEAL U80--90--12 1

7 807 249 89 WIPER 80--90--7--10) 1
8 814 170 39 PISTON ROD GUIDE RING 1/PWR 80/86X13 3
9 817 053 09 O--RING 129,54X6,99--1 1
10 800 805 39 O--RING 69,5X3--1 1

11 871 693 09 OVERCENTER VALVE 270bar 2

12 871 374 39 LOCK NUT (M60X2) 1
13 856 040 09 STRAIGHT THREAD CONNECTOR F40X--S10--3/8 2
14 857 302 19 PLUG FNTX--S10 2
15 445 827 20 HEXAGON SOCKET HEAD SCREW M12x40 m8.8 SFS 2219 18

16 205 349 37 LIMIT BUSHING D95 d80 L100 1

17* 134 461 28 BEARING BUSHING D60 d50 L62 2
18* 422 292 00 CIRCLIP 90X3 DIN 472 4
19* 572 102 40 GREASE NIPPLE AR 1/8 3
20* 855 920 29 SPHERICAL PLAIN BEARING 2

550 035 73 SEAL KIT INCL.PARTS:5--9 AND SEALS FOR PART 11 1

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0598 VKV 325 135 28dB 1/1
HYDR.CYLINDER
125/80

325 135 28

















ÍÍ ÄÄ


ÍÍ
È Ä
Ä
ÄÄ
ÄÈ
È


ÍÍ
ÍÍ
Í
Ä







Ref Part No. Description Standard designation Qty

1 323 127 58 CYLINDER TUBE INCL. PARTS 15,16,18,19 1

2 320 426 88 PISTON ROD INCL. PARTS 15,16,18,19 1
3 155 004 08 PISTON 1
4 161 382 08 COVER 1
5 869 128 99 LOCK NUT (M40X1,5) 1

6 816 819 39 PISTON SEAL 125/100X25 (125–100–18,4/36,8) 1

7 882 281 79 SEAL 80X90X13 1
8 807 249 89 WIPER 80X90X10X7 1
9 885 070 09 GUIDE RING 80–86–13 3
10 522 300 00 O–RING 114,3X5,7–1 SMS 1586 1
11 428 702 10 O–RING 49,5X3–1 SMS 1586 1

12 871 693 09 OVERCENTER VALVE INCL. PART 19 ( 270bar) 2

13 856 040 09 STRAIGHT THREAD CONNECTOR F40X–S10–3/8”(9/16–18JIC) 2
14 134 461 28 BUSHING 2
15 263 497 08 PIPE 1
16 422 292 00 CIRCLIP 90X3 4

17 205 349 36 LIMIT BUSHING L=86 1

18 855 920 29 BEARING 2
19 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8” 2
20 871 694 39 SEAL KIT FOR VALVE PART 12 1
818 755 59 SEAL KIT INCL. PARTS 6–8, 10,11 1

1998 TAMROCK OY, SERVICE TAMPERE PLANT

P.O.Box 100
FIN–33311 TAMPERE, FINLAND
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0598 VKV 325 132 48cB 1/1
HYDR.CYLINDER
125/50
325 132 48












ÍÍÍ
ÄÄ

Í
ÈÈ
ÍÍÍ
ÄÄ
ÈÈ
ÈÈ
Ä



ÍÍÄ
Í







Ref Part No. Description Standard designation Qty

1 323 124 78 CYLINDER TUBE INCL. PARTS 16,17,18 1

2 320 427 08 PISTON ROD INCL. PARTS 16,17,18 1
3 155 004 08 PISTON 1
4 161 412 68 COVER 125/50 1
5 869 128 99 LOCK NUT (M40X1,5) 1

6 816 819 39 PISTON SEAL DBM 125/100X25 (SIMKO5 125–100–18,4/36,8) 1

7 803 135 09 U–SEAL BS 5006 P5008 (SIMRIT NI300) 1
8 807 823 69 WIPER AM 5006 Z5053 (SIMRIT AUAS 50–60–7–10) 1
9 814 797 09 GUIDE RING I/PWR 50/56X13 3
10 522 300 00 O–RING 114,3X5,7–1 SMS 1586 1

11 428 702 10 O–RING 49,5X3–1 SMS 1586 1

12 871 693 09 OVERCENTER VALVE ASSY INCL. PART 19 270bar 2
13 816 713 49 STRAIGHT THREAD ELBOW C40X–S10–3/8” (9/16–18JIC) 2
14 134 461 28 BUSHING L=62 2
15 857 302 19 FITTING CAP FNTX–S10 (9/16–18JIC) 1

16 422 292 00 CIRCLIP 90X3 4

17 855 920 29 BEARING 2
18 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8” 2
19 871 694 39 SEAL KIT FOR VALVE PART 12 1
855 777 09 SEAL KIT INCL. PARTS 6–11 1

1998 TAMROCK OY, SERVICE TAMPERE PLANT

P.O.Box 100
FIN–33311 TAMPERE, FINLAND
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0202 DMTAK 550 110 18 1/ 1

HYDR.CYLINDER 125/50

550 110 18

Ref Part No. Description Standard designation Qty

1 550 112 90 CYLINDER TUBE 1

2 550 110 17 PISTON ROD 1
3 155 004 08 PISTON 1
4 161 412 68 COVER 1
5 869 128 99 LOCK NUT M40X1,5 1

6 816 819 39 PISTON SEAL M125/100x25 W 1

7 803 135 09 U--SEAL U--seal 1
8 807 823 69 WIPER 50--60--7--10 1
9 814 797 09 PISTON ROD GUIDE RING Ring 3
10 522 300 00 O--RING 114,3x5,7--1 SMS 1586 1

11 428 702 10 O--RING 49,5x3--1 SMS 1586 1

12 871 693 09 OVERCENTER VALVE 2
13 816 713 49 STRAIGHT THREAD ELBOW 9/16/18 2
14 134 461 28 BEARING BUSHING D60 d50 L62 2
15 857 302 19 PLUG FNTX--S10 2

16 422 292 00 CIRCLIP 90X3 DIN 472 4

17 855 920 29 SPHERICAL PLAIN BEARING 2
18 572 102 40 GREASE NIPPLE AR 1/8 3
19 871 694 39 SEAL KIT INTEGRATED HYDR. 1
855 777 09 SEAL KIT FOR CYLINDER INCL. PART 8--11 1

E 2002 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0701 DMJAS 239 017 98A 1/ 1

HYDR.CYLINDER ASSY

239 017 98

23
22
21 13 24
9
14

8
23 11
3

24 25
10
16
4
2

7
5
1
25

Ref Part No. Description Standard designation Qty

1 138 280 08 CYLINDER TUBE D80 INCL. PARTS 23--25 1

2 138 281 28 PISTON ROD 1
3 155 044 48 PISTON 1
4 162 395 08 COVER 1
5 869 128 99 LOCK NUT M40X1,5 1

7 817 317 59 PISTON RING (5 80--60--15,4--33,8) 1

8 803 135 09 U--SEAL NI300 50X60X10 1
9 807 823 69 WIPER 50X60X10/7 1
10 522 271 70 O--RING 69,2X5,7--1 , NBR , 70 SHORE A 1
11 428 702 10 O--RING 49,5X3--1 SMS 1586 2

13 801 031 49 USIT--SEAL U 17,4X24X1,5 ,D2=19,1 2

14 800 118 39 O--RING 79,5X3--1 , NBR , 70 SHORE A 1
16 814 797 09 PISTON ROD GUIDE RING 3
21 856 040 09 STRAIGHT THREAD CONNECTOR 9/16--18JIC 2
22 857 302 19 PLUG 9/16--18JIC 2

23 800 110 19 CIRCLIP 4

24 800 127 19 BEARING 2
25 572 102 40 GREASE NIPPLE 2
100 801 802 69 BONDED SEAL 2

801* 856 700 69 SEAL KIT INCL. PARTS 7. 8. 9. 10. 11. 14. 16. 100 1

E 2001 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN-- 33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771
0300 DMPP 517 880 33cL





PILOT CONTROL NON–RETURN VALVE

517 880 33
















Ref Part No. Description Standard designation Qty

001 500 777 08 SPRING 2

004 048 286 88 PLUG 2
005 049 734 28 VALVE SEAT 2
006 453 787 68 SPINDLE 1
008 517 879 78 BODY 1

010 885 253 29 O–RING 11.3x2.4 1

011 522 067 70 O–RING 17,3X2,4–1 2
012 522 091 30 O–RING 22,2X3–1 2
013 049 735 58 TAPERED PIN 2
022 856 040 09 STRAIGHT THREAD CONNECTOR 9/16–18JIC 4

023 857 302 19 FITTING CAP 9/16–18JIC 4

PARTS TO BE ORDERED SEPARATELY

801* 882 630 09 REPAIR KIT 0

2000 SANDVIK TAMROCK CORP. TAMPERE PLANT

P.O.Box 100
FIN–33311 TAMPERE, FINLAND Trade Reg. No. 2.852
Tel. +358 205 44 121, Telex 22335 parts fi
Telefax +358 205 44 4771



 




DUAL RELIEF VALVE

814 579 99
















Ref Order No. Description Standard designation Qty

1 522 067 70 O–RING 17.3x2.4–1 2

2 802 437 29 O–RING 12.7x2.4–1 4
7 807 400 59 PILOT POPPET 2
8 807 401 89 BACK–UP RING 2
9 807 402 09 SEAL 2

13 514 912 20 BALL D=8 DIN 5401 2

814 586 19 REPAIR KIT INCL.PARTS 1,2,8,9 1

1993 TAMROCK OY PARTS

P.O.Box 100
SF–33311 TAMPERE, FINLAND
Tel. +358 31 241 4111, Telex 22335 parts sf
Telefax +358 31 241 4771
