&RPPHUFLDO)LUHDQG%XUJODU\
6HFXULW\6\VWHP
ZLWK6FKHGXOLQJ
,QVWDOODWLRQDQG6HWXS*XLGH
35(/,0,1$5<
-8/<
K3471-1V1 4/01
.
Differences Between the FOCUS 200 PLUS, and FOCUS 200 PLUS A Phase 1 Systems
Item FOCUS 200 PLUS (472462) FOCUS 200 PLUS (472462A) PHASE 1
Number of Groups 8 8
Number of 99 255
Operating Panel
Users
RS-485 Buses 2 2
Access Control Supports 8 Access Control Interface Units Supports 8 Access Control Interface Units
iii
Item FOCUS 200 PLUS (472462) FOCUS 200 PLUS (472462A) PHASE 1
ADT AC • Add-on module (472491) • Add-on module (472491 or 472491D)
Communicator
• Supports ADT SIA format only • Supports ADT SIA format only
Module
Service Telco Jack Located on the main PC board (Control Unit) Located on the main PC board (Control Unit)
Transformer Supports 18VAC and 16.5VAC transformers Supports 18VAC and 16.5VAC transformers
• 18VAC (50VA) transformer provides 1.5A • 18VAC (50VA) transformer provides 1.5A
max output current max output current
• 18VAC (72VA) transformer provides 2.3A • 18VAC (72VA) transformer provides 2.3A
max output current max output current
• 16.5VAC (50VA) transformer provides 1A • 16.5VAC (50VA) transformer provides 1A
max output current max output current
• 16.5VAC (82VA) transformer provides 1.8A • 16.5VAC (82VA) transformer provides 1.8A
max output current max output current
Use 18VAC transformer for all new installations. Use 18VAC transformer for all new installations.
Use 16.5VAC transformer for retrofit only. Use 16.5VAC transformer for retrofit only.
Use P4 Jumper to select current draw. Use P4 Jumper to select current draw.
Relay Outputs • 2 built-in bell outputs (bell 1 & bell 2) rated • 2 built-in bell outputs (bell 1 & bell 2) rated
at 12VDC, 1.7A. at 12VDC, 1.7A.
• Built-in auxiliary relay that may be set for • Built-in auxiliary relay that may be set for
Dry (28VAC/VDC, 2.0A) or Wet (12VDC, Dry (28VAC/VDC, 2.0A) or Wet (12VDC,
1.7A) operation. 1.7A) operation.
Built-in 4-Wire Uses the auxiliary relay Uses the auxiliary relay
Smoke Detector • Program the relay output point type for 4- • Program the relay output point type for 4-
Reset wire smoke detector reset (output point type wire smoke detector reset (output point type
23) 23)
• Set Jumper P3 for wet operation • Set Jumper P3 for wet operation
Wireless (RF) Supports all ADEMCO 5800 Series transmitters Supports all ADEMCO 5800 Series transmitters
Support except 5804BD, 5827BD, and 5827 except 5804BD, 5827BD, and 5827
Cabinet Back Supports back tamper for commercial burglary Supports back tamper for commercial burglary
Tamper applications applications
Cabinet Tamper Mounted on the side of the cabinet and Mounted on the side of the cabinet and
connects to the tamper input (J5 trigger 3) connects to the tamper input (J5 trigger 3)
Auto Cabinet Tamper is automatically bypassed when the Tamper is automatically bypassed when the
Tamper Bypass system goes into Service Mode system goes into Service Mode
Primary Phone Can be edited from either the downline loader or Can be edited from either the downline loader or
Number the operational panel the operational panel
Programming
Earth Ground Fault Is a built-in function and is mapped to point 245 Is a built-in function and is mapped to point 245
Detection
iv
The FOCUS 200 PLUS System Installation Vital Information
Use the following table to record the vital information for this installation. We recommend you leave
this table with the control unit.
Job Location
System Number (SS)
Group Number (GG)
Instrument Number (II)
ADEMCO Compass downloading
software Phone Number
CCC Phone Number
CCC Communication Type (check the
appropriate boxes) ADT SIA (FSK) CID AC Module
v
Fire Alarm Application Note
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Code Enforcement
Codes are enforced by the person who is designated by the state or local government as the
“Authority Having Jurisdiction,” also simply referred to as the “AHJ.” The AHJ has the
delegated power to review and interpret the code as it may pertain to a particular structure.
The AHJ must interpret codes because structures often are not uniform. Therefore, the AHJ
will review, for example, a fire alarm design for the correct number of smoke detectors and
their placement in relation to the structure’s layout.
vi
Table of Contents
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Fire Alarm Application Note .......................................................................................... vi
About Fire Alarm Codes.....................................................................................................................................................vi
Code Enforcement ..............................................................................................................................................................vi
vii
Table of Contents
viii
Table of Contents
ix
Table of Contents
Index......................................................................................................................... Index-1
x
List of Figures
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
xi
Figure 7-2: External Sounder Connections to the Auxiliary Relay.................................................................................. 7-6
Figure 8-1: Installing the 472402A Backup Dialer.......................................................................................................... 8-3
Figure 9-1: 472491 AC Communicator Module Wiring ................................................................................................... 9-3
Figure 9-2: 472491D AC Communicator Module Wiring ................................................................................................ 9-3
Figure 9-3: AC Communicator Module Wiring Using AC Telephone Lines.................................................................... 9-4
Figure 9-4: AC Communicator Module Wiring Using DVACS or RS232 Port ............................................................... 9-4
Figure 9-5: AC Communicator Module Wiring Using DC Telephone Lines ................................................................... 9-5
Figure 10-1: Configuration of the 7720P to the J5 Output Triggers ............................................................................... 10-5
Figure 10-2: Configuration of the 7830R to the J5 Output Triggers ............................................................................... 10-5
Figure 10-3: Configuration of the 7835C to the J5 Output Triggers ............................................................................... 10-5
Figure 10-4: Configuration of the 7920SE to the J5 Output Triggers............................................................................. 10-6
Figure 11-1: Access Control Interface Unit (ACIU).......................................................................................................... 11-3
Figure 11-2: Typical Installation Using Card Reader or Keyreader............................................................................. 11-10
Figure 11-3: Typical Installation Using a Keylok.......................................................................................................... 11-10
Figure 11-4: Modifying ACIU for Operation with Dorado 7401 or 7901 Card Reader ................................................ 11-11
Figure 11-5: Wiring Connections for a Manual Access Pushbutton or Exit Pushbutton.............................................. 11-12
Figure 12-1: Printer Interface Unit .................................................................................................................................. 12-2
Figure 13-1: Load Diagram for RS-485 Bus .................................................................................................................... 13-6
Figure 13-2: Load Diagram for RS-485 Bus with Power Supply .................................................................................... 13-7
Figure 13-3: Determining the Voltage Drop on the RS-485 Bus...................................................................................... 13-8
Figure 13-4: Determining Maximum Length of Quad Trunk for PID Gateway (no horn/strobes)................................ 13-9
Figure 13-5: Determining the Maximum Length of Quad Trunk for SIM/PID Gateway with Horn/Strobes............ 13-10
Figure 20-1: Operating Panel ........................................................................................................................................... 20-1
Summary of Connections .......................................................................................................Inside Back Cover
xii
Conventions Used in This Manual
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Before you begin using this manual, it is important that you understand the meaning of the following symbols (icons).
These notes include specific information that must be followed if you are installing this system for a UL
UL Listed application.
These notes include information that you should be aware of before continuing with the installation, and
which, if not observed, could result in operational difficulties.
This symbol indicates a critical note that could seriously affect the operation of the system, or could cause
damage to the system. Please read each warning carefully. This symbol also denotes warnings about
physical harm to the user.
Product model numbers (unless noted otherwise) represent ADT products. A 6-digit Stock Code Number replaces the 7-
digit type number used for ADT devices. For the convenience of the reader, when the 6-digit number is used for a given
item, the formerly used type number will be included in parenthesis. This type number is how the devices and systems
are referenced in UL reports and procedures.
xiii
xiv
S E C T I O N 1
General Description
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the FOCUS 200 PLUS System
♦ Prominent Features
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Prominent Features
Below is a list of the prominent features of the system. For a detailed explanation of any of the features, see the
appropriate section.
Point Characteristics
• Eight built-in points, including two 2-wire smoke • A Fixed BA point can be set for 24-hour type alarm.
detector loops. • Unique holdup alarm type that permits triggering
• Built-in programmable style "D" fire loop. an alarm as well as tripping a suspicion camera.
• Janitorial function that enables point-shunting of • Partial turn-off of vault sensors (vibration and/or
movable protection points in areas being cleaned audio sensors) to avoid nuisance alarms due to
during the closed period. construction or other noise/vibration occurring
• Provision for hostage signaling. during the premises’ open period.
• Ambush protection against hide-ins. • Detection of carbon monoxide.
1-1
FOCUS 200 PLUS Installation and Setup Guide
1-2
S E C T I O N 2
In This Section
♦ About the Control Unit ♦ Grade A Mercantile Premises Listing
♦ Before Installing the System ♦ Grade A Mercantile Safe and Vault Listing
♦ Mounting the Cabinet ♦ Installing the Control's Circuit Board
♦ Installing the Cabinet Lock
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
2-1
FOCUS 200 PLUS Installation and Setup Guide
Power Requirements
The FOCUS 200 PLUS System uses the control unit power supply as the primary power source.
Because the system power is distributed over the RS-485 buses, it is important to keep the voltage
drops along the buses to a minimum.
Good installation practices will go a long way toward minimizing both the effect of the voltage drops
and the need for adding an external power unit.
Where additional power is needed, a 472372 Power Supply Module (in a 472381 Power Unit Housing)
can be introduced at sections of the bus. The power supply will provide power for its associated device
and for additional sections of the RS-485 bus, as well. For more information regarding power
requirements, see the Power Requirements and the Specifications sections.
The control unit must be located in a protected area that is armed, unless occupied. If not occupied at any
time, the area must be under 24-hr. protection. This precaution does not apply to any control unit that is
protected against attack.
Be careful when removing knockouts to avoid damaging the control board. Remove the control board from
the control unit, if necessary. Do not drill mounting holes through the backshell. Place the backshell on the
wall, mark the locations of the holes, remove the backshell, and drill the holes.
RETAINER CLIP
1. Before mounting the circuit board, (NOTE POSITION)
the backshell.
Figure 2-1: Installing Cabinet Lock
For UL installations that are intended to provide certificated burglary service, the VISTA-ULAP UL Attack
UL Proof Kit must be used. Refer to Figure 2-2 Cabinet Attack Resistance Considerations for the requirements
and installation.
2-2
Section 2 – Installing the Control Unit
CLIP-ON DOOR
TAMPER SWITCH
CABINET
PC MOUNTING HOLE
BOARD (4 PLACES)
The cabinet tamper is automatically bypassed when the system is placed in Service mode and
automatically unbypassed when the system is taken out of Service mode.
2-3
FOCUS 200 PLUS Installation and Setup Guide
Make certain that the mounting screws are tight. This ensures a good ground connection between the PC
board and the cabinet. Also, dress field wiring away from the microprocessor (center) section of the PC
board. Use the 2 loops on the left and right side walls of the cabinet for anchoring field wiring using tie
wraps. These steps are important to minimize the risk of panel RF interference with television reception.
DETAIL A
SIDE VIEW OF
BOARD INSERTED
INTO SLOTS
DETAIL B
SIDE VIEW OF SHORT
MOUNTING CLIPS
(TYP.)
hi_end_mnt-PCB
2-4
S E C T I O N 3
In This Section
♦ About the Operating Panels ♦ Addressing the Operating Panels
♦ Installing the Operating Panels ♦ Operating Panel Programming Mode
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Operating Features
Help screens are available to assist the user in operating the system. The operating features of the
operating panel are as follows:
• Menus are employed to guide the user through the various operating procedures. Choices are
shown on the screen with an arrow (>) that lines up with buttons on the screen.
• The display screen and the numeric keypad become illuminated when any key is pressed.
• The customer can use the operating panel to change certain programming such as descriptors,
access codes, privilege levels, and permanent, temporary, and holiday schedules.
• The operating panel performs an automatic self-test whenever power is applied. If it passes the
power-on test, it emits a single beep, flashes the backlight, and displays the following message:
ADT INTERACTIVE KEYPAD WAITING FOR COMM.
3-1
FOCUS 200 PLUS Installation and Setup Guide
Do not locate the operating panel in any area where the temperature may drop below 32° F (0° C) or rise
above 122° F (50° C). At temperatures below 32° F, the display will fade and the glass may crack.
Temperatures above 122° F will affect the display output.
JUMPER E1
(REMOVE JUMPER TO
DISCONNECT BLACK WIRE 4 FLYING LEADS
TERMINATION RESISTOR) FOR FIELD WIRING
U4 U3 U2 U1
EXTERNAL TAMPER
CONNECTION
4 Remove the nylon screw on the bottom of the operating panel and separate the back plate
from the front of the unit.
3-2
Section 3 – Installing the Operating Panels
Step Action
5 Mount the back plate to the wall using any of the appropriate holes.
6 Connect the operating panel wires to the RS-485 cable matching color to color.
7 Each device that connects to the RS-485 bus has a terminating jumper designated E1 (see
Figure 3-1). Inserting the jumper connects a terminating resistor; removing the jumper
disconnects the resistor. Insert the jumper on the last device on each RS-485 bus. All other
devices on the RS-485 bus run must have the jumper removed.
8 Reconnect the front plate to the back plate and reinsert the nylon screw.
9 Install the instruction label at the rear of the operating panel in the slot provided.
10 Repeat the steps for each operating panel.
Addressing Considerations
Be aware of the following considerations when addressing the operating panels:
• One operating panel can control all BA groups.
• Regardless of whether communication group number 00 or 01 is used, all operating panels display
the same alarm and/or trouble information. If the sounder comes on for one panel (because of an
alarm, trouble, entry delay alert, etc.), it also comes on for the other panels.
• When there are several operating panels using the same communication group number, and one of
the operating panels is activated by touching a key or entering an ID code, the other panels are
locked out and display “Keypad In Use, Please Wait” until the first panel is deactivated. The active
period ends 60 seconds after the last key is pressed. Operating panels using a different
communication group number are not affected.
• Where there are two BA groups with the same communication group number and with similar
opening or closing schedules, it is possible to generate an Entry alarm unintentionally. For
example, one person enters the premises and triggers the entry delay for one BA group. When a
person enters the second BA group they cannot turn off the second BA group until the first entry
delay expires. An entry alarm may also be generated when an impatient person doesn’t wait for an
operating panel to clear before being able to close. To avoid such unintentional entry alarms,
assign one panel to communication group number 00 and assign the other panel communication
group number 01.
• When addressing operating panels, make sure that no two operating panels have the same address
(same group and unit number). Failure to do so may result in a communication clash.
• If you are pre-programming operating panels in the shop, DO NOT change the default communication
group number 31 at that time. Wait until the operating panel has been wired to the RS-485 bus in the
premises. Failure to do so results in a communication clash when the control unit is powered up, which
can be corrected only by powering down the control unit and then powering it back up again.
3-3
FOCUS 200 PLUS Installation and Setup Guide
Step Action
2 Wait for the operating panel to perform the power-on self-test. After this is completed, the
panel displays “ADT INTERACTIVE KEYPAD WAITING FOR COMM.”
3 Press the [1] and [8] keys simultaneously to enter the operating panel program mode.
4 Enter the default code 1 2 3 (or other number if you are not using 1 2 3).
5 Press Change.
6 Enter the new communication group and unit number for this operating panel.
7 Press Quit to exit the program mode. The control unit will recognize the operating panel if
it has been properly addressed.
NOTE: The firmware level is shown by characters in upper right-hand corner of the parameter display.
Where an operating panel is being used for access control with an ACIU, its communication Unit number
on the RS-485 bus must coincide with the communication Unit number of the ACIU. An operating panel
being used for access control (Communication Group 0) becomes locked out during the period that any
other operating panel at Communication Group 0 becomes activated, and vice versa.
Changing Parameters
To change any parameter, select the parameter to be changed, enter the new value at the keypad, and
then select ENTER. The following table explains the parameters and the values to be chosen:
Parameter Default Value Explanation of Value Required
Keycode 1,2,3 Any three digits, for entering the operating panel program
mode. Should not be changed unless there is a particular reason
for changing it, such as standardization within the area or
region served by a given ADT office.
Baud 9600 9600 baud is required; 4800 cannot be used at this time.
Group Number 31 Range is 0-31 (00 and 01 are reserved for the operating panels).
Unit Number 7 Range is 0-7.
Contrast Center Can be increased or decreased using the contrast screen. To call
up contrast screen without first entering Programming mode,
press [0] and [#] simultaneously.
If the AC and battery power are temporarily disconnected, the contrast setting that is adjusted by the
method described above will be overridden by the contrast setting established via the operating panel
parameter screen.
3-4
S E C T I O N 4
In This Section
♦ About the Hardwired Points ♦ Point 8 Bell Box Tamper Configuration
♦ Wiring the Hardwired Points
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
To disable a hardwired point, enter "00" for the point type (NZ) and enter zeroes (0) for the Hard ID.
4-1
FOCUS 200 PLUS Installation and Setup Guide
Wiring Burglary and Panic Devices to Points 1-8
To wire burglary and/or panic devices to points 1-8 (terminals 25 - 38), perform the following steps:
Step Action
1 Connect normally closed devices in series with the high (+) side of the loop.
Note: The 2K EOL resistor must be connected in series with the devices, following the last
device.
2 Connect normally open devices in parallel (across) the loop.
Note: The 2K EOL resistor must be connected across the loop wires at the last device.
The maximum loop resistance is 100 ohms for points 1 and 2, and 300 ohms for all other points (excluding
the 2K EOL resistor).
• 2K EOL resistors must be connected across the loop wires of each point at the last detector for fire
points.
• The alarm current provided by points 1 and 2 will support only one smoke detector each in the alarmed
state.
These smoke detectors are UL Listed for use with the FOCUS 200 PLUS, and are the only 2-wire smoke
UL detectors that may be used.
4-2
Section 4 – Basic Hardwired Points
Figure 4-1: 2-Wire Smoke Detector Connected to Point 1 (also Point 2, Terminals 27 and 28)
To wire 2-wire smoke detectors to points 1 and 2 (terminals 25 - 28), perform the following steps:
Step Action
1 Select from the list compatible 2-wire smoke detectors.
Note: These are the only 2-wire smoke detectors that may be used with the FOCUS 200
PLUS system.
2 Connect 2-wire smoke detectors across point 1 and/or point 2 terminals (25 through 28).
See Figure 4-1.
Note: Observe proper polarity when connecting the detectors.
3 If EOL resistors are presently connected across point 1 and point 2 terminals, remove
them. Connect the EOL resistors across the loop wires of each point at the last detector.
Power to 4-wire smoke detectors must be supervised with an EOL device (use a ADT 435243 or a System
UL Sensor A77-716B EOL Relay Module). See Figure 4-2.
Auxiliary power to 4-wire smoke detectors is not automatically reset after an alarm, and therefore must be
momentarily interrupted using the built-in auxiliary relay. This allows the detectors to be reset via the Alarm
Reset sequence.
Programming for the Alarm Reset sequence must be done via the ADEMCO Compass Downloader.
4-3
FOCUS 200 PLUS Installation and Setup Guide
N.C. 9
+
AUXILIARY
POLE 10
RELAY
CONTROL
PANEL 2000 •
OHM SHOWN POWERED.
EOLR • RELAY OPENS WHEN
POWER IS LOST.
+
POINT HEAT
TERMINALS DETECTOR
(25-38)
-
To wire 4-wire smoke detectors to points 1 - 8 (terminals 25-38), perform the following steps:
Step Action
1 Select compatible 4-wire smoke detectors. Some are listed on the previous page.
2 Connect 4-wire smoke detectors across points 1 through 8 (25 through 38). See Figure 4-2.
3 If EOL resistors are presently connected across the terminals, remove them.
4 Connect the EOL power supervision relay module (System Sensor A77-716B) and the 2k
EOL resistor at the last detector on each point. See Figure 4-2.
Note: Each point must have its own power supervision relay module.
5 Connect the power wires from the 4-wire smoke detectors and the EOL power supervision
relay module to the control unit. Connect the ground wire to terminal 12, and the positive
power to the normally closed side of the auxiliary relay (terminal 9). See Figure 4-2.
Note: Auxiliary power is not automatically reset after an alarm, and therefore must be
momentarily interrupted using the built-in auxiliary relay.
6 Move jumper P3 to short pins 1 and 2, making the auxiliary relay wet (12-volt output).
7 Program the Auxiliary Relay Output to 4-wire smoke detector reset.
+ 32
2k
POINT 4 EOLR C
- 31
Break #2
- 30
POINT 3
A B
+ 29
Break #1
4-4
Section 4 – Basic Hardwired Points
Referring to Figure 4-3, if Break #1 occurs, point 3 goes into a trouble condition, but will continue to
monitor device "A" for an alarm condition. Point 4 will continue to monitor devices "B" and "C" for
alarm conditions. If Break #2 occurs, point 3 goes into a trouble condition and will still monitor devices
"A", "B" and "C" for alarm conditions. The trouble and alarm messages will be sent to the CCC as point
3 trouble or alarm.
To wire points 3 and 4 for the Style “D” configuration, perform the following steps:
Step Action
1 Select UL Listed fire sensors (4-wire smoke detectors, sprinkler system supervisory devices,
etc.).
2 Run the wiring starting at point 3 terminals (29 and 30) through the facility and homerun
back to the control unit to the terminals for point 4 (31 and 32).
3 Connect the fire sensors in parallel along the wire run. See Figure 4-3.
4 If EOL resistors are presently connected across the terminals, remove them. Connect only
one 2k resistor directly across the terminals for point 4 inside the control cabinet. See Figure
4-3.
5 Connect the power wires from the fire sensors to the control unit. Connect the ground wire
to terminal 12, and the positive power to the normally closed side of the auxiliary relay
(terminal 9).
Note: Auxiliary power is not automatically reset after an alarm, and therefore must be
momentarily interrupted using the built-in auxiliary relay.
If you are using the bell box tamper, program the option via the ADEMCO Compass Downloader. Otherwise
the system will not detect a "short" on point 8.
4-5
FOCUS 200 PLUS Installation and Setup Guide
4-6
S E C T I O N 5
Gateways
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the Gateways ♦ Installing the RF Gateway
♦ PID Gateway ♦ Installing the RF Receiver
♦ Installing the PID Gateway ♦ 5800 Series Transmitters
♦ Installing Sensors to the PID ♦ Long Range Radio Gateway
♦ SIM Gateway ♦ Installing the LRR Gateway
♦ Installing the SIM Gateway ♦ Long Range Radio Trouble Conditions
♦ Installing SIM and SIM Sensors ♦ Gateway Off-Normal Conditions
♦ RF Gateway
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
RS-485 Buses
Each gateway connects to a port in the control unit via a cable known as an RS-485 bus. The control
unit can accommodate two independent RS-485 buses of 4000 feet each, permitting an end-to-end reach
of up to 8000 feet if using both buses. The total end-to-end reach can be extended to 16,000 feet by
using a 472430 RS-485 Repeater at the end of each bus. Current loading and voltage drop
considerations may limit the maximum allowable wire lengths on each RS-485 bus to less than 4000
feet. See the Power Requirements section for additional information.
5-1
FOCUS 200 PLUS Installation and Setup Guide
PID Gateway
The PID gateway utilizes the quad trunk monitoring (two wires for power and two for signaling) and
control circuitry of the FOCUS 200 PLUS system. It employs the same Point Interface Devices (PID's),
Commandable Output Point Interface Devices (COPID's), and other interface devices as used on
previous FOCUS Systems.
Each PID provides a point of protection and serves to interface a sensor into the system. Each COPID
occupies a point in the system, but the COPID is equipped with a pair of relays (form C, dry) that
operate in response to a predetermined function being monitored. A point of protection used in
conjunction with a PID is considered an input point, and one that is used with a COPID is considered
an output point.
A PID gateway:
• Connects to an RS-485 bus from the control unit and serves as a data gathering terminal for any
combination of up to 62 monitoring points.
• Interrogates its PID's and their sensors, issues commands from the control unit to its COPID's, and
reports the status of its connected devices to the FOCUS 200 PLUS control unit.
• May be used for retrofit applications.
• May be used for installations where the sensor or other device cannot be connected to the SIM
Gateway.
• Functions in a manner similar to the control unit circuitry used for interfacing the quad trunk on a
FOCUS 100 System.
• Operates with most presently used FOCUS System accessories (PIDs, COPIDs, etc.). A COPID is
not interrogated by its PID gateway and is therefore not supervised.
• Can be used for retrofitting previous FOCUS Systems (FOCUS 48, FOCUS 100B, C and D, FOCUS
256, and FOCUS 300 Systems).
5-2
Section 5 – Gateways
• Can be assigned to the same address as another COPID on the gateway trunk.
• Can be assigned to the same point as the sensor that it will follow, and its relay will then operate
when the point alarms, and will remain activated until the point restores.
• Is not supervised and cannot be used where point supervision is required.
Terminal Strip TB2 Used for connecting gateway quad Trunk 1A.
Terminal Strip TB3 Used for connecting gateway Trunk 1B. This second trunk is used in
instances where there would ordinarily be one long cable run that would
result in an excessive voltage drop on the power lines. By locating the
gateway near the center of this run and using two gateway trunks, the
voltage drop of each trunk can be kept to an acceptable level.
Jumpers E10 (for TB2) Used to accommodate an increase current level, with a rating greater than
and E11 (for TB3) 0.5A, when the gateway is connected to a separate power supply, Inserting
the jumpers serves to connect a larger internal fuse (1.6A per trunk).
Otherwise, remove jumpers if the gateway is not connected to a separate
power supply.
Jumpers E2 through E9 Used for setting the gateway communication address on the RS-485 bus.
Terminating jumper E1 Insert only if the gateway is located at one end of the RS-485 bus.
TXD and RXD LEDs Indicates the gateway communication status as follows:
• TXD LED - flashing when the gateway is transmitting
• RXD LED - flashing when the gateway is receiving.
Tamper Space is provided for adding a tamper switch, which must be ordered
separately as a 248116 Tamper Kit.
5-3
FOCUS 200 PLUS Installation and Setup Guide
RS-485 BUS LEDs TERMINAL STRIP TB1 JUMPER E1
TXD (YEL) RXD (RED) CONNECTIONS TO (REMOVE JUMPER TO
RS-485 BUS DISCONNECT RS-485
TERMINATING RESISTOR)
RS-485
DS1 DS2
TB1
GATEWAY TXD RXD
MICROPROCESSOR E2 (BLK) 1 GND
E3
(RED) 2 + 12V E1
E4
U6
E5 (YEL) 3 COM
RS-485 BUS E6
ADDRESS JUMPERS E7 (BLU) 4 COM +
E8
E9
FOR TAMPER
TERMINAL STRIP TERMINAL STRIP
(IF USED)
TB2 FOR TRUNK 1A TB3 FOR TRUNK 1B
SEE NOTE 2
0 1 2 3 4 5 6 7
UNIT NO. E2 UNIT NO.
E3
E4
E5
COMMUNICATION E6
GROUP NO. 3 E7
E8
E9
NOTES:
5-4
Section 5 – Gateways
Maximum RS-485 4000 feet. This distance may be less to comply with the minimum
Length from Control voltage to the PID gateway.
Unit to Gateway
Total Length of Must not exceed 1000 feet. This length may be less to comply with
Gateway Trunk Cable minimum voltage to farthest PID sensor. If using both gateway trunks,
limit applies to the sum of both runs.
Minimum Voltage to 12.1VDC with a fully charged battery and AC power applied to the
PID Gateway control unit, or to an external power supply, if used.
Minimum Voltage to 12.1VDC with a fully charged battery and AC power applied to the
Farthest PID Sensor control unit, or to an external power supply, if used.
Maximum Current The current on each gateway trunk must not exceed:
Draw from Gateway • 0.5A if the gateway is receiving power from the control unit power
Trunk supply (remove jumpers E10 and E11)
• 1.6A if gateway is receiving power from 472372 Power Supply
module (leave jumpers E10 and E11 on)
Gateway Log Form Complete the Gateway Log Form shown later in this section. When the
form has been completed, make a duplicate copy. Store one copy in the
control unit and file the other copy in the office.
Location Make sure the PID gateway is:
Considerations • Protected from physical damage.
• Not mounted on temporary walls or partitions.
• Mounted in an area free from excessive vibrations, corrosive
atmospheres, high temperatures.
• Mounted within the protected area.
• Never exposed to the outside elements.
PID Housing Unit The Housing provides combination cable entry ports with built-in strain
relief and a snap lock-hinged cover with a writing surface on its exterior
for the PID address. It can be mounted on walls, ceilings, and building
structures in any position. The PID modules snap into the housing unit
and are held in place with a locking catch. Modules are easily removed
by depressing the locking catch.
5-5
FOCUS 200 PLUS Installation and Setup Guide
6 Insert each branch receptacle onto the appropriate molex connector, observing the proper
positioning for the type of sensor connected.
• Powered sensors use Pins 1-2-3-4.
• Non-powered sensors use Pins 3-4-5-6.
7 Form the branch cable(s) around the strain relief posts and over the slotted branch cable
entry port(s), and depress so the cable is flush with the edge of the housing base.
5-6
Section 5 – Gateways
Do not connect more than 8 smoke detectors to a single PID, and make sure that all smoke detectors so
connected are physically located in the same fire point.
System-powered sensors cannot be adjusted or tested until the system power has been turned on, the
point data has been loaded into the control unit, and communication has been established between the
control unit and the gateway and between the gateway and its PID's.
5-7
FOCUS 200 PLUS Installation and Setup Guide
Remember that the Hard ID number is not the system point number, but is used for communication with the
PID gateway. The Hard ID will be linked to a system point number during the programming of the point. Also,
once the Hard ID is programmed, it is permanent.
A DIP shunt is used to set the PID or COPID’s Hard ID number, which serves to identify the PID or
COPID to its gateway. The DIP shunt consists of a series of six conductive straps. The straps come in a
closed circuit condition, and are “broken” to produce an open circuit. Once programmed, the Hard ID
number is permanent. To change a Hard ID number, the DIP shunt must be removed from the socket
and another DIP shunt with the new Hard ID number must be inserted.
When assigning the Hard ID numbers, always start with the number 1 and continue numbering
consecutively (2, 3, 4, and so on). This will provide a faster gateway interrogation process.
The straps in a DIP shunt are numbered 1 through 6, with number 1 designated by a hole next to it
through which the shunt strap material can be seen. As an aid to proper positioning of the DIP shunt in
the socket, the strap numbers are printed on the PID board next to the socket.
Program the Hard ID by breaking the straps to produce a sum equal to the desired PID address.
Example: Program address 16 by breaking straps 1 ,2, 3, 4, and 6. Strap 5 (16) would remain
unbroken.
Table of DIP Shunt Numbers
Hard ID# Break DIP Shunt Number(s) Indicated Hard ID# Break DIP Shunt Number(s) Indicated
00 NOT USED 32 1 2 3 4 5 —
01 — 2 3 4 5 6 33 — 2 3 4 5 —
02 1 — 3 4 5 6 34 1 — 3 4 5 —
03 — — 3 4 5 6 35 — — 3 4 5 —
04 1 2 — 4 5 6 36 1 2 — 4 5 —
05 — 2 — 4 5 6 37 — 2 — 4 5 —
06 1 — — 4 5 6 38 1 — — 4 5 —
07 — — — 4 5 6 39 — — — 4 5 —
08 1 2 3 — 5 6 40 1 2 3 — 5 —
09 — 2 3 — 5 6 41 — 2 3 — 5 —
10 1 — 3 — 5 6 42 1 — 3 — 5 —
11 — — 3 — 5 6 43 — — 3 — 5 —
12 1 2 — — 5 6 44 1 2 — — 5 —
13 — 2 — — 5 6 45 — 2 — — 5 —
14 1 — — — 5 6 46 1 — — — 5 —
15 — — — — 5 6 47 — — — — 5 —
16 1 2 3 4 — 6 48 1 2 3 4 — —
17 — 2 3 4 — 6 49 — 2 3 4 — —
18 1 — 3 4 — 6 50 1 — 3 4 — —
19 — — 3 4 — 6 51 — — 3 4 — —
20 1 2 — 4 — 6 52 1 2 — 4 — —
21 — 2 — 4 — 6 53 — 2 — 4 — —
22 1 — — 4 — 6 54 1 — — 4 — —
23 — — — 4 — 6 55 — — — 4 — —
24 1 2 3 — — 6 56 1 2 3 — — —
25 — 2 3 — — 6 57 — 2 3 — — —
26 1 — 3 — — 6 58 1 — 3 — — —
27 — — 3 — — 6 59 — — 3 — — —
28 1 2 — — — 6 60 1 2 — — — —
29 — 2 — — — 6 61 — 2 — — — —
30 1 — — — — 6 62 1 — — — — —
31 — — — — — 6 63 — — — — — —
Notes:
• Do not break DIP shunts indicated by dashes. Break only number(s) shown above. The Hard ID number of any
unused PID must be set to 63 (unbroken) DIP shunts.
• For identification, mark the hard ID number and the system point number on the Housing Unit cover on the
writing surface provided using an indelible marker.
5-8
Section 5 – Gateways
5-9
FOCUS 200 PLUS Installation and Setup Guide
PID BRANCH
CABLE CONNECTOR
HEADER RECEPTACLE
(NOTE 4)
BLK - 12VDC
1 1 1 TA TA
RED +12VDC 12VDC 12VDC SEE
2 2 (NOTE 1) (NOTE 1)
YEL LOW SIDE (NOTE 3)
3 3 EOLR EOLR
BLU HIGH SIDE NO
4 4 3K OHMS 3K OHMS
5 (NOTE 2) (NOTE 2)
NC
6 (NOTE 3)
NOTES:
5. CERTAIN FOCUS 7187 TYPE SENSORS MAY HAVE SOLID STATE ALARM
OUTPUTS, WHICH INCLUDE TAMPER, END-OF-LINE RESISTOR,
AND FOCUS CONNECTOR.
5-10
Section 5 – Gateways
PID CABLE BASIC BA - FIXED AND
CONNECTOR MOVABLE SENSORS
HEADER RECEPTACLE
BA NORMALLY-CLOSED
(BREAK-ONLY)
(NOTE 1) 1 (NOTE 2) CONTACT
TA
2 (NOTE 3) OR
BLK LOW SIDE FEED
3 1 OR BLK BLK
RED HIGH SIDE FEED
4 2 RED NO RED
YEL LOW SIDE RETURN
Notes for Figures 5-3a and 5-3b: 5 3
BLU HIGH SIDE RETURN NC
YEL NC
6 4 YEL BLU
BLU
1. Letter “G” on printed wiring EOL FIXED PROTECTION (NOTE 4) MOVABLE
board indicates pin 1 header. RESISTOR (SCREENS - FLOOR MOVABLE PROTECTION
MATS OR FOIL) PROTECTION
BLU
3. Electrical position of tamper,
WATER FLOW OR
where used. BASIC FA
SUPERVISORY DEVICE
(NOTE 5)
5
6. 494468 branch cable must be 6
494466 OR 494468 975306 RESISTOR
used in ceilings that are air- NOT USED BRANCH CABLE 3010 OHM, 1%, 1/2W
handling plenums. (NOTE 5)
7. Do not connect more than eight Figure 5-3a: Basic Sensor Connections to PID
4-wire smoke detectors to a PID CABLE COMBINATION OF SYSTEM-POWERED AND
CONNECTOR INDEPENDENTLY POWERED SENSORS ON SAME LOOP
single PID. Install supervisory
HEADER RECEPTACLE
relay and EOLR in same outlet
BLK - 12VDC
box used for electrically last (NOTE 1) 1 1
RED +12VDC
X X X
2 2 X X X
smoke detector. All smoke 3 3
YEL
BLU EOLR
detectors on the one PID must 4 4 (NOTE 9)
5
be located in the same fire 6
CONTACT CONTACT CONTACT
(NOTE 8) SYSTEM- (NOTE 8) (NOTE 8)
point. POWERED SYSTEM-
NOT USED (NOTE 2) SENSOR POWERED
SENSOR
8. Transfer contact of
independently powered sensor
is shown. Sensor is powered by
separate power supply (not
shown).
DOOR CONTACTS DOOR CONTACTS
RED
RED
YEL
BLK
YEL
BLK
(NOTE 11)
11. Make butt splices (X) of wires (NOTE 1) 1 (NOTE 2)
D6441-4B CABLE
5-11
FOCUS 200 PLUS Installation and Setup Guide
(NOTE 6)
TA AL
+
PID BRANCH
CABLE CONNECTOR
HEADER RECEPTACLE
(NOTE 1)
RESISTOR
(NOTE 5) 3010 OHM, 1%, 1/2 W
BLK - 12VDC
G 1 1 (SCN 975305) (NOTE 4)
2 RED +12VDC
2
YEL LOW SIDE
3 3
BLU HIGH SIDE
4 4
OR GRN
5
6 (NOTE 2)
D6441-4 CABLE OR 36468
EOL RESISTOR
BRANCH CABLE (NOTE 7)
IN PID (NOTE 3)
(NOTE 6)
TA AL
BA SENSOR +
TERMINALS
PID BRANCH
CABLE CONNECTOR
HEADER
(NOTE 1) G 1
RECEPTACLE TO SEPARATE
POWER SOURCE {
2 (NOTE 5)
3 1 BLK LOW SIDE FEED
4 2 RED HIGH SIDE FEED
YEL LOW SIDE RETURN
5 3
BLU HIGH SIDE RETURN
6 4
OR GRN
EOL RESISTOR
D6441-4 CABLE OR 36468
ON PID BOARD
BRANCH CABLE (NOTE 7)
NOTES:
PID CABLE
CONNECTOR
HEADER RECEPTACLE
( ) ( )
1 1
(+) (NOTE 1)
2 2 (+)
3 3
4 4
5 PA400W
SOUNDER
6
(INDOOR)
NOTES:
5-12
Section 5 - Gateways
SIM Gateway
The SIM gateway is used to interface SIM (Sensor Interface Module) sensors with the FOCUS 200
PLUS system. The SIM gateway can accommodate up to 72 points.
The sensor types employed on the SIM gateway can be divided into two categories:
• Sensors that have been uniquely manufactured with a built-in SIM.
• Standard sensors, which require connection to a separate SIM in order to be connected to the
gateway.
The SIM gateway quad trunk consists of four wires. Two wires are used for power (+ 12V and ground).
The other two wires are used in a multiplexed arrangement to serve a dual function. During one half-
cycle, the wires are used for communication with the gateway; during the next half-cycle, they provide
limited + 12V operating power.
5-13
FOCUS 200 PLUS Installation and Setup Guide
TAMPER SWITCH
OPERATOR
2
1
4
3
TAMPER SWITCH
TB2
GATEWAY TRUNK
TERMINAL STRIP
(RED)
(BLU)
(YEL)
(BLK)
GATEWAY
MICROPROCESSOR TERMINAL STRIP
TB1 CONNECTIONS TO
RS-485 BUS
1 (BLK) GND
2 (RED) +12V
TRANSMIT LED (YEL) E1 JUMPER E1
3 (YEL) COM (REMOVE JUMPER
RS-485 BUS ADDRESS TO DISCONNECT RS-485
4 (BLU) COM + TERMINATING RESISTOR)
DIP SWITCHES
4
5
UNIT COMMUNICATION
NUMBER GROUP 3
5-14
Section 5 - Gateways
Maximum RS-485 Bus 4000 feet. This distance may be less to comply with the minimum
Length from Control voltage to the SIM gateway.
Unit to Gateway
Total Length of Must not exceed 1000 feet. This length may be less to comply with
Gateway Trunk Cable minimum voltage to farthest SIM sensor. If using a dual trunk run, limit
applies to the sum of both runs.
Gateway Log Form As a part of the installation, complete the Gateway Trunk log Form
shown previously in this section. When the form has been completed,
make a duplicate copy. Store one copy in the control unit and file the
other copy in the office.
Maximum Current Black and Red wires: 1.0A; Blue and Yellow wires: 128mA.
Draw from Gateway
Trunk
5-15
FOCUS 200 PLUS Installation and Setup Guide
If system power calculations were required, make sure that the Gateway will be receiving at least 12.1 volts
(or 8.4V at end of standby time) and that the length of the Gateway trunk is within the maximum
permissible distance calculated in Power Requirements section.
5-16
Section 5 - Gateways
System-powered sensors cannot be adjusted or tested until the system power has been turned on, the point
data has been loaded into the control unit, and communication has been established between the control
unit and the gateway.
All SIM sensors are connected to the SIM gateway trunk cable via a 2-conductor branch cable. Two
types of branch cable are available for sensor connections. Each is a 2-conductor, 18-AWG cable,
differing only in type of insulation. The cables are:
• 493494 - Approved for FA, SUPV, HUA, and BA.
• 493493 - Approved for FA, SUPV, HUA, and BA where wire is being installed in air-handling
plenums (Teflon or equiv.).
5-17
FOCUS 200 PLUS Installation and Setup Guide
Step Action
5 Snap the Trunk Junction box SCN 148320 around the connections to enhance appearance.
6 Connect the branch cable to the SIM or SIM Sensor. SIM sensors that have screw
terminals include the smoke detector, the FA Pullbox, motion sensors, and glassbreaks.
Connect these directly to the branch cable.
7 Splice the SIM module to the branch cable. Use SCN 810953 connectors to splice to the
branch cable.
8 Collect the point description, gateway number, and Hard ID's of all installed SIMs so they
can be programmed into the control unit. Use the Gateway Trunk Log Form to record the
Gateway, Hard ID, BA Group, and point description. Once the data has been collected, it
must be entered into the control unit via the operating panel. See the Programming
section for the procedure. Once the data has been programmed, walk-tests LEDs will
function.
The Hard ID label: The top line is the barcode. The second line is in readable text. The
first eight digits are the Hard ID. The next six digits are the Stock Code Number (SCN #).
The next four digits are the manufacturing date codes ("year week"). The last two digits
are for the vendor codes like "P" for Pine Brook.
9 Mark the SIM Sensor point number stick-on labels SCN 146844. Peel off the number that
represents the point number and stick it on the outside of the sensor so it is clearly visible
and can be referred to later.
Sensors cannot be walk-tested unless the sensor's point type, group, gateway, and Hard ID are in the
control unit's database.
GND
ORG
IN 0
C5 AL-TBL
2.3 uf
25V
T
BLU-WHT
IN 2
TMPR
YEL
WHT
COM ( )
IN 0
MICROPROCESSOR CONDITION IN 0 IN 2 CONDITION IN 0 IN 2
INPUT NORMAL 6V GND NORMAL 6V GND
IN 2
ALARM GND GND ALARM 12V GND
MICROPROCESSOR TAMPER 6V 12V TAMPER 6V 12V
OUT 0
OUTPUT OPEN LOOP 12V 12V OPEN LOOP 12V 12V
5-18
Section 5 - Gateways
BLU
COM+
+12V LED
SEE SENSOR
POWER
NOTE 3 POWER +12V
NOTES:
1. POINT OPTION 3="Y".
RED OR
+12V +
TRANSISTOR
SWITCH 3K
EOLR HORN
BLACK
GND
BLK/W
OUT 0
+
RED/W
TRANSISTOR
SWITCH 3K
EOLR STROBE
BLK/W
BLU
COM+ POWER
SUPERVISION
33K
TRANSISTOR
SWITCH
IN 0
33K
YEL
COM-
5-19
FOCUS 200 PLUS Installation and Setup Guide
472366 SIM
OUT 0
SEE NOTE 1
RED RED/W
+12V
TRANSISTOR +
SWITCH
BLK BLK/W
GND
BLU
COM+
TAMPER
33K
NC
33K
33K
OR
IN 0
AL-TBL C
BLU/W
IN 2
TMPR
NO
YEL WHT
COM-
472366 SIM
OUT 0
FOCUS-VVS
ADT VAULT VIBRATION SENSOR
SEE NOTE
RED RED/W
+12V X
TRANSISTOR
SWITCH
BLK BLK/W
GND X
33K
33K
33K
OR
IN 0
AL-TBL
BLK
BLU/W
IN 2
TMPR
RED
YEL WHT
COM-
TEST
TRANSMITTER
5-20
Section 5 - Gateways
BLACK
X
RED
X
YELLOW
X
BLUE
X
869706 (10K 5% 1/2W)
X REMOVE
JUMPER J1
GRN YEL 10.2 - 13.8VDC
SUPERVISED
BLK 472366 BLU/GRN 247650 BLU/YEL 4Ma NORMAL STANDBY
SIM X
RED ORA WHT ORA 30Ma MAX WHEN ALL DEVICES IN ALARM
4W/2W
X ADAPTER
YEL BLU/WHT 10K 5% 1/2W
BOARD 244708
BLU WHT BLU/WHT 3K EOLR
X (8mA NORMAL
(INSIDE ELECTRICALLY
RED/WHT RED STANDBY)
X (35mA ALARM) LAST DEVICE IN LOOP)
BLK/WHT BLK BLU/ORA
X
When smoke and fire doors are held in the open position to allow free movement in corridors of
buildings, it is required that the doors be released when a fire alarm is activated. This requires a
472488 supervised SIM or 472366 SIM to release the Door Hold-Open device.
To install a 472488 supervised SIM or 472366 SIM to release the Door Hold-Open device, perform the
following steps:
Step Action
1 Mount and connect the SIM device. See Wiring a SIM or SIM Sensor shown previously in
this section.
Note: When 472366 SIM is used, the cable run between the SIM and Door Hold-Open
device can not exceed 3 feet.
2 Program it as FAC (21) point type.
For NFPA Life Safety applications, install a 472367 Door Contact to monitor the status of the door.
Program it as MID (5) point type.
5-21
FOCUS 200 PLUS Installation and Setup Guide
RF Gateway (472490)
The 5800ADT RF gateway provides additional RF points for the FOCUS 200 PLUS system, up to 72
points. The RF gateway is designed for use in conjunction with a 5881H/5881EH/5882H/5881ENHC RF
receiver only, and can support up to two receivers. It monitors individual 5800 series transmitters and
only reports changes in their status to the control panel. Only 1 RF gateway may be connected to the
RS-485 bus. It is automatically set for Communication Group 03, Unit 7 once the control unit is
powered-up with the gateway connected.
The Unit number for the RF gateway’s identification with the control unit is fixed at 7.
The RF gateway used only in conjunction with the 5881ENHC RF Receiver and the 5869 Holdup Switch
UL Transmitter are listed for UL Commercial Burglary applications. All other RF receivers and transmitters are
not listed for UL Commercial Burglary applications.
CONNECT TO
5881H/5881EH/5882H/5881ENHC
PANEL LED (RED) 5800ADT RF RECEIVER
RF LED (GREEN)
CONNECTOR
YELLOW
GREEN
BLACK
RED
ECP
DATA INPUT BUS
6
DATA OUTPUT
5
+ (+) 12VDC
4
( ) GND
3
+ 2 H BUS (+)
1 H BUS ( )
YELLOW
BLACK
BLUE
TB1
RED
RS485
BUS
(-) GND
P1
(+) 12V
5800ADT-002-V1
(+)
(-)
TO
5800ADT RF EXPANDER MODULE CONTROL PANEL
5-22
Section 5 - Gateways
7 Remove jumper P1 unless the RF gateway module is to be located at the end of the RS-485
bus; in that case, leave the jumper on.
5-23
FOCUS 200 PLUS Installation and Setup Guide
Note: The length of all wire runs combined must not exceed 500 feet when unshielded
quad conductor cable is used (250 feet if shielded cable is used).
2 If installing a 5881ENHC, install a flat-head screw (supplied) in the case tamper tab as
shown in Figure 5-15. When the receiver is pried from the wall, the tamper tab will break
off and remain on the wall. This will activate a tamper switch in the receiver and cause
generation of a tamper signal. Note that this signal will also be generated when the
receiver’s front cover is removed.
3 Connect the RF gateway to the RF receiver. See Figure 5-14 for wiring connections.
4 Install the two antennas into the right-hand terminals of the 2-terminal block in the
receiver (see receiver’s instructions). If you are using a second receiver, install the
antennas on that receiver.
SCREW
5881ENHC-001-V0
POSITION 5
IS PRESENT
4
ONLY ON
5881ENHC
3
(SEE
2
RECEIVER
INSTRUCTIONS
ON
ON
1
FOR USAGE).
RF_dip_sw-001-V0
5-24
Section 5 - Gateways
To address and program the RF receiver, perform the following steps:
Step Action
1 Set the RF receiver’s DIP switches as follows:
Set the first receiver’s device address to “1” (see Figure 5-16). If a second receiver is used,
set its device address to "2."
2 Program the number of RF receivers, set the RF Jam options (point 242), and set the
supervision interval via the ADEMCO Compass Downloader.
• Program the supervision of the receiver(s) (Receiver 1 = point 244 and Receiver 2 =
point 243) with input type 13 SPV.
• Program the supervision for RF Jam (point 242) with input type 13 SPV.
• Enable the tamper detection for the 5881ENHC RF receiver, if used, via the
ADEMCO Compass Downloader.
If an RF transmitter is used to arm or disarm the system, the point must be assigned to a user. Otherwise,
the system will show the arm/disarm prompts when the button is pressed, but the system will not change
state. We recommend using an outdoor annunciator for confirmation of arming.
Transmitter Supervision
Except for some transmitters that may be carried off premises (5804), each transmitter sends a
supervisory signal to the RF receiver every 70–90 minutes. If at least one signal is not received from
each supervised transmitter within a programmed check-in interval, the “missing” transmitter(s) will
display a trouble condition. For transmitters that may be carried off the premises (5802MN), turn off
the supervision by programming it as a “UR” (unsupervised RF) type.
The system is shipped with the transmitter check-in interval defaulted to (0) no supervision. Be sure to
program a check-in interval if you are using RF supervised transmitters. Otherwise, the system will not
annunciate a supervisory trouble condition from those transmitters.
Some 5800 Series transmitters have built-in tamper protection and will annunciate a trouble condition
if covers are removed.
5-25
FOCUS 200 PLUS Installation and Setup Guide
5-26
Section 5 - Gateways
TO 7845C LONG
RANGE RADIO
7800ADT TB2 TB1
PANEL LED (RED)
RF LED (GREEN)
DATA OUT
DATA IN
GND
V+
YELLOW
GREEN
BLACK
RED
ECP
DATA INPUT
BUS
6
DATA OUTPUT
5
+ (+) 12VDC
4
( ) GND
3
+ 2 H BUS (+)
1 H BUS ( )
YELLOW
BLACK
BLUE
TB1
RED
RS485
BUS
(-) GND
P1
(+) 12V
(+)
(-)
7800ADT LONG RANGE RADIO GATEWAY TO
CONTROL PANEL
7800ADT-002-V0
5-27
FOCUS 200 PLUS Installation and Setup Guide
7 Remove jumper P1 unless the LRR gateway module is to be located at the end of the RS-
485 bus; in that case, leave the jumper on.
Operation
The FOCUS 200 PLUS features Dynamic Signaling Delay and Dynamic Signaling Priority
message reporting when Long Range Radio is used. These message outputs are programmed only via
the ADT Compass Downloading software.. The Dynamic Signaling feature is designed to reduce the
number of redundant reports sent to the Customer Care Center.
The feature is described as follows:
• Dynamic Signaling Delay
Select the time the panel should wait for acknowledgment from the first reporting destination
before it attempts to send a message to the second destination. Delays can be selected from 0 to 225
seconds, in 15-second increments.
• Dynamic Signaling Priority
Select the initial reporting destination for messages, Primary Dialer (0) or Long Range Radio (1).
5-28
Section 5 - Gateways
• Without line security (Grade A), the maximum Dynamic Signaling Delay, is 15 seconds for Fire and
UL •
UL Burglary installations.
With line security (Grade AA), the Dynamic Signaling Delay must be 0 (no delay) for UL Burglary
installations. The reports will be sent to both the primary phone number and the LRR.
The chart below provides an explanation of how the Dynamic Signaling feature functions.
If the Priority is… And message is… Then…
Primary Phone Acknowledged before delay expires Message is removed from queue and no
Number message is sent to LRR.
Not acknowledged before delay Message is sent to both the Primary
expires Phone No. and LRR.
Long Range Radio Acknowledged before delay expires Message is removed from queue and no
message is sent to Primary Phone No.
Not acknowledged before delay Message is sent to both the Primary
expires Phone No. and LRR.
5-29
FOCUS 200 PLUS Installation and Setup Guide
Specific off-normal conditions monitored by the gateway and reported to the control unit are as follows:
PID Gateway
Off-Normal Condition Cause
Cross A short across the EOLR of the protection loop.
Open An open or ground in the protection loop and may include the sensor
tamper.
Comm Fail Failure to receive a response from a point when it is interrogated. PID
may be defective, or there may be a fault with the cable to the gateway
trunk, or PID has not been addressed correctly.
Point Tamper Activation of a tamper on a PID.
Multiple Conditions These are combinations of cross and open, cross and tamper, open and
tamper, and cross, open, and tamper.
PIDs addressed the same The gateway will interpret this as a tamper plus comm fail.
SIM Gateway
Off-Normal Condition Cause
Cross Indicates an alarm condition.
Open Indicates a trouble condition.
Comm Fail Failure to receive a response from a point when it is interrogated. SIM
may be defective, or there may be a fault with the cable to the gateway,
or the gateway has been addressed incorrectly.
Point Tamper Activation of a tamper on a sensor. If the BA group is Nite Set, this is
interpreted as an alarm.
Multiple Conditions These are combinations of cross and open (alarm and trouble), cross and
tamper (alarm and tamper), open, and tamper (trouble and tamper), and
cross, open, and tamper (alarm, trouble and tamper).
Diagnostics The false alarm immunity of the sensors is impaired. Examples: A Dual
motion detector with one of its technologies malfunctioning may increase
in sensitivity to motion. A smoke detector that is dirty may increase in
sensitivity to smoke.
RF Gateway
Off-Normal Condition Cause
Cross FA point: Alarm condition.
BA point: Normal condition.
Open FA point: Trouble condition.
BA point: Alarm condition.
Comm Fail 1. Failure to receive a response from a point when it is interrogated.
RF transmitter may be defective, or there may be a fault with the
cable to the gateway trunk, or the gateway has not been addressed
correctly.
2. Low battery condition in a RF transmitter.
Note: To determine which of these conditions the system is
annunciating, check the system's history log.
Point Tamper Activation of a tamper on an RF transmitter.
5-30
S E C T I O N 6
In This Section
♦ About the SIM Loop ♦ Installing SIM and SIM Sensors
♦ SIM Loop Supervision ♦ Installing a Keyswitch to the SIM Loop
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
6-1
FOCUS 200 PLUS Installation and Setup Guide
System-powered sensors cannot be adjusted or tested until the system power has been turned on, the
point data has been loaded into the control unit, and communication has been established between the
control unit and the SIM sensors.
All SIM sensors are connected to the SIM Loop via a 2-conductor cable. Two types of cables are
available for the connections. Each is a 2-conductor, 18-AWG cable, differing only in type of insulation.
The cables are:
• 493494 - Approved for FA, SUPV, HUA, and BA.
• 493493 - Approved for FA, SUPV, HUA, and BA where wire is being installed in air-handling
plenums (Teflon or equiv.).
6-2
Section 6 – SIM Loop
6-3
FOCUS 200 PLUS Installation and Setup Guide
When running SIM loop wires, they must not be run within 6" of AC power, telephone, or intercom wiring.
Because the SIM loop is carrying data between the control unit and the devices, interference on this loop
can cause an interruption of this communication. The SIM loop can also cause outgoing interference on
the intercom or phone lines. If this spacing cannot be achieved, shielded wire must be used. (Note that
the maximum total wire length supported is cut in half when shielded wire is used.)
6-4
Section 6 – SIM Loop
Install an SIM or SIM sensor by taking the following steps and referring to Figures 6-1 through 6-7.
Step Action
1 Run the cable no more than 100 feet long from the SIM Loop. Use cable SCN 493494 or
493493 for 2-wire connections. Use SCN 494465 or 494467 for 4-wire connections.
2 Cut the sheathing of the SIM Loop trunk to expose the four wires of the trunk.
3 Use Scotchlok SCN 809190 connectors (#558) to connect the branch cable to the SIM Loop
trunk, matching the colors of the wires on the trunk with the branch cable.
4 If the branch cable is subject to damage, splice in an SCN 248302 in-line fuse with holder
and place it close to the SIM Loop trunk.
5 Snap the Trunk Junction box SCN 148320 around the connections to enhance appearance.
6 Connect the branch cable to the SIM Sensor. Connect SIM sensors with screw terminals
(smoke detectors, FA Pullboxes, motion sensors, glassbreaks) directly to the branch cable.
7 Splice the SIM module to the branch cable using SCN 810953 connectors to splice it.
8 Collect the point description and Hard ID's of all installed SIMs so they can be
programmed into the control unit. Use gateway unit # 9 for the SIM Loop. Use the SIM
Loop Log Form to record the Hard ID, BA Group, and point description. Once the data has
been collected, it must be entered into the control unit via the operating panel. See the
Programming section for the procedure. Once the data has been programmed, walk-tests
LEDs on the units will function.
The Hard ID label: The top line is the barcode. The second line is in readable text. The first
eight digits are the Hard ID. The next six digits are the Stock Code Number (SCN #). The
next four digits are the manufacturing date codes ("year week"). The last two digits are for
the vendor codes like "P" for Pine Brook.
9 Mark the SIM Sensor point number stick-on labels SCN 146844. Peel off the number that
represents the point number and stick it on the sensor so it can be referred to later.
Sensors cannot be walk-tested unless the sensors' point type, group, gateway, and Hard ID are in the
control unit's database.
GND
ORG
IN 0
C5 AL-TBL
2.3 uf
25V
T
BLU-WHT
IN 2
TMPR
YEL WHT
40
COM ( )
IN 0
MICROPROCESSOR CONDITION IN 0 IN 2 CONDITION IN 0 IN 2
INPUT NORMAL 6V GND NORMAL 6V GND
IN 2
ALARM GND GND ALARM 12V GND
MICROPROCESSOR TAMPER 6V 12V TAMPER 6V 12V
OUT 0
OUTPUT OPEN LOOP 12V 12V OPEN LOOP 12V 12V
6-5
FOCUS 200 PLUS Installation and Setup Guide
BLU
39
COM+
+12V LED
SEE SENSOR
POWER
NOTE 3 POWER +12V
NOTES:
1. POINT OPTION 3="Y".
RED OR
19 +
+12V TRANSISTOR
SWITCH 3K
EOLR HORN
BLACK
20
GND BLK/W
OUT 0
+
RED/W
TRANSISTOR
SWITCH 3K
EOLR STROBE
BLK/W
BLU
39
COM+ POWER
SUPERVISION
33K
TRANSISTOR
SWITCH
IN 0
33K
YEL
40
COM-
6-6
Section 6 – SIM Loop
472380 HORN-STROBE
OUT 1
RED
19 +
+12V TRANSISTOR
SWITCH HORN
BLACK
20
GND
OUT 0
+
TRANSISTOR
SWITCH
STROBE
BLU
39
COM+ POWER
SUPERVISION
33K
TRANSISTOR
SWITCH
IN 0
33K
YEL
40
COM-
472366 SIM
OUT 0
SEE NOTE 1
19
RED RED/W
+12V TRANSISTOR +
SWITCH
BLK BLK/W
20
GND
BLU
39
COM+ TAMPER
33K
NC
33K
33K
OR
IN 0
AL-TBL C
BLU/W
IN 2
TMPR
NO
YEL WHT
40
COM-
6-7
FOCUS 200 PLUS Installation and Setup Guide
472366 SIM
OUT 0
FOCUS-VVS
ADT VAULT VIBRATION SENSOR
SEE NOTE
RED RED/W
19 X
+12V TRANSISTOR
SWITCH
BLK BLK/W
20
GND
X
33K
33K
33K
OR
IN 0
AL-TBL
BLK
BLU/W
IN 2
TMPR
RED
YEL WHT
40
COM-
TEST
TRANSMITTER
X REMOVE
JUMPER J1
GRN YEL 10.2 - 13.8VDC
SUPERVISED
BLK 472366 BLU/GRN BLU/YEL 4Ma NORMAL STANDBY
20
SIM X 247650
RED ORA WHT ORA 30Ma MAX WHEN ALL DEVICES IN ALARM
19 X 4W/2W
YEL BLU/WHT 10K 5% 1/2W ADAPTER
40 244708
BOARD
BLU WHT BLU/WHT 3K EOLR
39 X (INSIDE ELECTRICALLY
RED/WHT RED (8Ma NORMAL
X STANDBY) LAST DEVICE IN LOOP)
BLK/WHT BLK (35Ma ALARM) BLU/ORA
X
6-8
Section 6 – SIM Loop
For NFPA Life Safety applications, install a 472367 Door Contact to monitor the status of the door.
Program it as MID (5) point type.
The 4208U, 4209U and 4208SNF must be set for "Serial Number" mode. See the device's installation
instructions for the correct dip switch setting for this mode of operation. Each module must be set for a
different serial number.
4208U
1
OO
N
N
2
3
4
TB2
5
DIP Switches
6
5 NOT
7
USED
8
4 ( ) GROUND
3 (+) 12V
( )
REED (TAMPER) SWITCH
TB1
2
1 }
(+)
TO
SIM
LOOP
(USE
1 2 3 4 5 6 7 8 9 10 11 12 TWISTED
PAIR)
ON 4209U
POSITION 1: SELECT GROUP MODE
1
O
ON
N
TB1
1 ( )
(+) } TO
SIM
LOOP
(USE
1 2 3 4 5 6 7 8 TWISTED
PAIR)
(+) ( ) (+) ( ) (+) ( ) (+) ( )
LOOPS: A B C D
6-9
FOCUS 200 PLUS Installation and Setup Guide
DIP SWITCHES (TYPICAL SETTING; ALL TB2
SWITCHES SHIPPED IN ON POSITION)
POSITION 1: SELECT RESPONSE TIME FOR LOOPS A &B 6
(SHOWN ON = SLOW: 400 msec.) NOT USED
5
POSITIONS 2-5: SELECT SERIAL NUMBERS FOR MODULE LOOPS A - H EARTH GROUND (WHEN
FROM THE SERIAL NUMBER ASSIGNMENT TABLE 4 (–)
MOUNTED REMOTELY)
SELECTED VIA DIP SWITCH POSITIONS 6 & 7 (SHOWN
ON, ON, ON, OFF )
3 (+) 12 VDC
OPTIONAL
POSITIONS 6,7: SELECT THE SERIAL NUMBER ASSIGNMENT (–) GROUND
TABLE (SHOWN ON, ON = TABLE 1)
2
TO SIM LOOP
POSITION 8: SELECT TAMPER PROTECTION SETTING (–)
(USE TWISTED PAIR;
(SHOWN OFF = TAMPER ENABLED) (+) WIRING SUPERVISED BY
1
OFF ON CONTROL PANEL)
TB1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Figure 6-10: Wiring of the 4208SNF to the SIM Loop as a Point Expander
DIP SWITCHES (NOT USED) 4208SNF TB2
TO CONTROL
PANEL HARDWARE
6 LOOP H OUTPUT + POINTS
NOTE:
5 LOOP G OUTPUT + GROUND
RETURN IS
VIA TB2-2
4 (–) EARTH GROUND
(NOT REQUIRED)
3 (+) 12 VDC
TO CONTROL PANEL
AUXILIARY POWER
2 (–) GROUND (SUPERVISED)
1 NO CONNECTION
TB1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
NO CONNECTION
LOOPS G H
Figure 6-11: Wiring of the 4208SNF to the SIM Loop as a Class B to Class A Converter
6-10
Section 6 – SIM Loop
THE EOL RESISTOR MAX OF 100 ohms WIRING
MUST BE CONNECTED RESISTANCE AND 2k EOLR
ACROSS THE LOOP
2k EOLR 2k EOLR 2k EOLR 2k EOLR
WIRES AT THE LAST
UP TO 16 2-WIRE
BLU (+) DETECTOR
SMOKE DETECTORS
YEL (-)
TB1
8 7 6 5 4 3 2 1
RED (ORG)
19 1
+12V TRANSISTOR
EOLR
3K
SWITCH
REED (TAMPER) SWITCH
BLACK
20 (BRN)
2 ON
GND
OUT 1 POSITION 1: SELECT GROUP MODE
(SHOWN OFF = NON GROUPED).
POSITIONS 2-5: SELECT THE 2 (GROUPED) OR
(RED) 4 (NON GROUPED) SENSOR
3 }
TRANSISTOR DEVICE GROUP ADDRESS
EOLR
SWITCH (SHOWN ON, ON, ON,
3K
OFF = 2nd GROUP SELECTION).
POSITION 6: DEVICE TYPE (SHOWN
4 ON = “SERIAL NUMBER” MODE).
(BLK) POSITION 7: NOT USED. SET TO “OFF.”
OFF ON
BLU POSITION 8: SELECT TAMPER PROTECTION
39 COM+ POWER SETTING
SUPERVISION SIDEVIEW (SHOWN OFF = TAMPER ENABLED).
33K
NOTES:
TRANSISTOR
1. THE 472488 MUST BE PROGRAMMED
SWITCH
AS FA TYPE (09) WITH OPTION 1 SET.
IN 0
33K
2. DURING A RESET ALARM, THE 472488 WILL
REMOVE POWER FROM 4209U/4208U FOR
6 SECONDS.
YEL
40
COM
4209USIM-001-V0
Figure 6-12: Wiring a Horn/Strobe SIM to a 4209U for Resetting Glassbreak Detectors
6-11
FOCUS 200 PLUS Installation and Setup Guide
TAMPER SWITCH
OPERATOR
JUMPER J1
(REMOVE IF
USING TAMPER)
248116 TAMPER SWITCH
(ORDERED SEPARATELY) TB2 LOOP
(NOTE 1) CONNECTIONS
TA J1 1 2 3 4 5 6
1 (BLK)
SIM GATEWAY 2 (RED)
TRUNK CONNECTIONS
3 (YEL)
4 (BLU)
471943
HOUSING UNIT
SENSOR
TB1
TB2 1
12V @ 80mA (max.)
{
BLK
1 2 +
FROM SIM RED 3
GATEWAY 2 TA
TRUNK YEL 3 4
NO
BLU 4 5
C
6
JUMPER NC
3K EOL
RESISTOR
TB1
1
2
CONTACT
3 LOW SIDE FEED BLK
TB2
4 HIGH SIDE FEED RED C NO
20 BLK 1
2 5 LOW SIDE RETURN YEL
19 RED NC
3 6 HIGH SIDE RETURN BLU
40 YEL
BLU 4
39
Figure 6-15: Loop Interface Module Wiring to Lacing/Foil and Non-powered Sensor
6-12
Section 6 – SIM Loop
BRN/WHT
472488 SUPERVISED
HORN / STROBE SIM BLK/WHT
3k 3k
RED/WHT
BLU
ORG
BLK
RED
WHT
YEL 12VDC
472366 SIM DEVICE ORG BUZZER
RED/WHT
+
BLU/WHT
BLK/WHT
33k
JUMPER
EARTH
YEL RED ORG GRY VIO BLK GRN GROUND
2k 2k
6-13
FOCUS 200 PLUS Installation and Setup Guide
9 +
8 –
} EXTENSION
LOOP
7 –
+}
INPUT LOOP
6 (FROM CONTROL)
TB1
5 AC 16.5VAC, 25VA
4
} TRANSFORMER
AC No. 1321 (SEE NOTE 1)
3 Earth Ground
2 –
1 } 12VDC POWER INPUT OR
+ 12V LEAD ACID BATTERY
INPUT. 1.2 AH MIN/
2.6AH MAX. MAKE
J1 (BLUE) CONNECTIONS USING
CABLE SUPPLIED.
(SEE NOTE 1)
SHORT ISOLATION JUMPER: NOTES:
INTACT: EXTENSION LOOP SHORTS ARE 1. WHEN A SUPPLEMENTARY POWER SUPPLY IS USED,
ISOLATED FROM INPUT LOOP. CONNECT IT TO TERMINALS 1 & 2 AND MAKE NO
CUT: EXTENSION LOOP SHORTS ARE CONNECTIONS TO 4 & 5. USE A CLASS II (POWER LIMITED)
NOT ISOLATED FROM INPUT LOOP. SUPPLY.
WHEN A No. 1321 TRANSFORMER IS USED, CONNECT IT
TO TERMINALS 4 & 5.
2. ALL CIRCUITS ARE SUPERVISED EXCEPT CONNECTIONS
TO THE No. 1321 TRANSFORMER AND TO THE LEAD-ACID
BATTERY.
3. ALL OUTPUT CIRCUITS ARE POWER LIMITED.
CONTROL 4297
RPM - - - RPM RPM - - - RPM
PANEL MODULE
Figure 6-18: SIM Loop Connections Using One 4297 Extender Module
6-14
Section 6 – SIM Loop
Extension Loop #1
Input SIM 4297 RPM - - - RPM
Loop
Extension Loop #2
CONTROL
PANEL
4297 RPM - - - RPM
---
---
Extension Loop #8
RPM - - - RPM
4297
Note: The input loop limits stated in Figure 6-18 apply to Figure 6-19 as well. Devices labeled as
“RPM” may also be SIM devices.
6-15
FOCUS 200 PLUS Installation and Setup Guide
6-16
S E C T I O N 7
In This Section
♦ About the Bell Outputs and Auxiliary Relay ♦ Programming the Bell Outputs and Auxiliary
Relay
♦ Output Functions
♦ Installing the External Sounders
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
7-1
FOCUS 200 PLUS Installation and Setup Guide
Output Functions
• Commercial burglary alarm systems require bell circuits to be programmed for a minimum timeout of
16 minutes.
• Commercial fire alarm systems require bell or indicating circuits to be supervised. Polarized fire-
indicating devices must be used.
UL • Commercial fire alarm systems require bell or indicating circuits to be programmed for a minimum
timeout of 5 minutes.
• Residential fire alarm systems require bell or indicating circuits to be programmed for a minimum
timeout of 4 minutes.
7-2
Section 7 – Bell Outputs and Auxiliary Relay
Description Function
Telco This is a separate option associated with each of the three outputs, and is intended for
Backup systems that are connected to a CCC. It is used in conjunction with the selected function for
which the output is to operate. If this option is chosen, the output will operate for the
selected function only if there is a telco problem on the AC or FSK dialer line, in which case
the output can be used to trigger a direct-connect transmitter to a Police Headquarters or
other receiving station as a backup.
Light Output turns on when the protection of a pre-selected BA group is turned off, or the
entry/exit delay period is activated. The output turns off when the protection of a BA group
is turned on.
Note: If the Recycle Exit Delay is enabled, the output turns on whenever any key is pressed
on the operating panel.
Bell Note: The output is reset by entering a valid ID code at any operating panel, unless stated
otherwise.
Note: Programmed bell timeout is 0 to 255 minutes in 1-minute increments unless stated
otherwise.
The output activates when triggered by the following occurrences:
• Burglar Alarm: Alarm in any BA group will cause steady activation until valid ID code is
entered or bell timeout is reached. If the BA group has been programmed for a delay in
start of bell ringing, the start of the bell is delayed by the programmed delay time (up to
20 minutes in 1-minute increments).
• Fire Alarm: Bell rings for 10 minutes with the pattern 1-second-On/1-second-Off, with a
5-second pause every 10 seconds until silenced by entering a valid ID code, or until the
10 minutes expire. The bell can also be silenced using special Fire Marshall Code
(222222). (May also be set via option 3 for temporal pattern). See the Input and Output
Point Types section.
NOTE: The Fire Bell can be programmed for continuous operation (No Timeout) when a
fire alarm occurs. This option can only be programmed via the ADEMCO Compass
Downloader.
• BA Keyswitch Point: Output activates bell (∗) for an open, tamper, or comm fail condition
during Nite Set of the BA group. Bell will continue to ring until valid ID is entered or bell
timeout is reached.
• Remote Power Supply Point: Output activates bell (∗) for a tamper or comm fail condition
of remote power supply point. Bell will continue to ring until valid ID is entered or bell
timeout is reached.
• System Self-Supervision: Output activates bell (∗) for a cabinet tamper during Nite Set of
BA1.
• Janitor Keyswitch Point: Output activates bell for a tamper or comm fail condition
during Nite Set. Bell will continue to ring until valid ID is entered or bell timeout is
reached.
• Bell On No Close: Output activates bell for 10 minutes if system has not been closed at
scheduled closing time. Bell ringing starts either 5 or 15 minutes after scheduled closing
time, depending on the choice made for the No Close option (see the Scheduling section).
• Display and Bell Test: This is a 30-second test that is initiated from an operating panel
(see the Testing the System section). Output activates bell for the final 4 seconds of test.
• Auto Bell Test (programmable option): Bell will "bing" at the end of any BA group’s exit
delay for Local systems. Alternately, for CCC connected systems, bell will "bing" at end of
exit delay as an indication that closing has been acknowledged by the CCC.
• Closing Trouble Bell (programmable option): Bell will ring for 5 minutes if customer has
turned the BA group On and has exited, but has failed to close the exit door and exit
delay has expired. Used to remind customer to re-enter the premises and turn the BA
group off, and re-exit the premises properly. Failure to do so will result in an entry
alarm.
∗ Start of bell can be delayed up to 255 minutes (1-minute increments).
7-3
FOCUS 200 PLUS Installation and Setup Guide
UL The start of bell ringing delay may not be programmed for UL Burglary alarm systems.
Description Function
Access Used for controlling access to any selected BA group by having the output operate a door
Control strike. The output is normally locked. It operates for 10 seconds when valid ID is entered at
the operating panel if BA group is Off or when BA group is turned Off.
Access Used for controlling access to BA1 group by having an output operate a door strike. The
Control BA1 output is normally released. It operates for 10 seconds when a valid ID code is entered at
the operating panel if BA group is off or when BA group is turned off. Operating panel must
be assigned to Unit Number 0.
Access Same function as Access Control BA1 except it relates to BA2. Operating panel must be
Control BA2 assigned to Unit Number 1.
Access Same function as Access Control BA1 except it relates to BA3. Operating panel must be
Control BA3 assigned to Unit Number 2.
Access Same function as Access Control BA1 except it relates to BA4. Operating panel must be
Control BA4 assigned to Unit Number 3.
Access Same function as Access Control BA1 except it relates to BA5. Operating panel must be
Control BA5 assigned to Unit Number 4.
Access Same function as Access Control BA1 except it relates to BA6. Operating panel must be
Control BA6 assigned to Unit Number 5.
Access Same function as Access Control BA1 except it relates to BA7. Operating panel must be
Control BA7 assigned to Unit Number 6.
Access Same function as Access Control BA1 except it relates to BA8. Operating panel must be
Control BA8 assigned to Unit Number 7.
For the above Access Control functions the controlling operating panel must be located outside of the
entry door for the associated BA group. For information about installing and addressing, refer to the
Installing the Operating Panel and Access Control sections.
7-4
Section 7 – Bell Outputs and Auxiliary Relay
System Sensor MDL Synch Circuit Mod Red Wheelock MS1-12-VFR Strobe
System Sensor P1215 Horn/Strobe Red ADA Wheelock MT-12-LS-VFR Horn/Strobe
System Sensor P121575 Horn/Strobe Red ADA Wheelock MT4-12-LS-VFR Horn/Strobe
The 471956(7187-101) Alarm Housing and ADEMCO AB12 Bell are UL-approved exterior sounding
devices for local mercantile premises bell certification. For exterior auxiliary BA or FA bell applications,
UL other sounding devices such as the 471859 (7187-037) Bell Unit may be used, provided applicable UL
installation guidelines are followed.
7-5
FOCUS 200 PLUS Installation and Setup Guide
BURG FIRE
2k EOLR
TO POINT 8 + (TB38)
TO POINT 8 – (TB37)
(EG: BELL 2+; TB7)
TO PANEL'S BELL +
wired connection from its terminal #4 to
its outer box.
(Terminal 3 or 4)
• Assign point 8 to a BA Group. Program
it as a Supervisory (SPV) Point Type.
• All wiring from AB12M-ADT to panel
must be run in conduit.
2k EOLR
WIRING FOR 1 2 3 4 5 6
AB12M-ADT
COMMERCIAL AB12M-ADT OUTER BOX
BURGLARY TAMPER
GRADE A BELL SWITCHES
INNER LINER
BELL
If you are using the bell box tamper, program the option via the downline loader. Otherwise the system will
not detect a "short" on point 8.
7-6
S E C T I O N 8
System Communication
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the System Communication ♦ Paging Service
♦ Connecting the Telephone Lines ♦ Programming the System Communication
Options
♦ Description of ADEMCO Contact ID Format
♦ Types of Customer Care Center Service
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
For Listed fire central station (UL864/NFPA 72) applications, use either a LORRA alone, the main dialer
with the LORRA, or use the main dialer with the 472402A Backup Dialer. For Listed fire remote station
UL (UL864/NFPA72) applications, use the main dialer with the 472402A backup dialer. Telephone line
supervision is required for UL commercial fire alarm systems when a dual-line dialer is used for fire signal
transmission.
• The system supports the 472402A backup dialer. The older version 472402 cannot be used with the
FOCUS 200 PLUS system.
• The system supports either the AC Communicator or the backup dialer, not both.
• The system can uniquely identify troubles on the Telco lines.
A Successful Transmission
Below is the communication sequence whenever a signal is transmitted:
1. The control panel seizes the phone line and dials the Customer Care Center (CCC).
2. The control panel waits to hear a “handshake” frequency tone from the receiver to confirm that the
receiver is on-line and ready to receive its message.
3. After the panel hears the correct handshake, it transmits its message.
4. If the message is received and understood by the receiver, it transmits a “kissoff” frequency tone.
8-1
FOCUS 200 PLUS Installation and Setup Guide
The FOCUS 200 PLUS system will attempt, up to a programmed number of times, to transmit a signal
to the CCC using the built-in dialer. If, after the programmed number of attempts, the signal still has
not been properly accepted by the CCC, and the backup dialer is not enabled, a Comm Fail message
will be displayed on the operating panel. If the backup dialer is enabled, then, after additional
unsuccessful attempts using the backup dialer for a programmed number of times, the system will
display the Comm Fail message.
If the system detects low voltage on the main telephone lines, it will switch to the backup dialer, if
enabled.
• The number of dialing attempts is a programmable option. The system is shipped with 10 attempts as
the default.
• The system will switch to the backup dialer only when it detects a fault (low voltage) on the main
telephone line or when the maximum number of programmed attempts on the main telephone line is
reached.
• For information about how to program the CCC telco numbers, see the Programming section.
The number of dialing attempts must be programmed for a minimum of 5 and a maximum of 10 attempts
UL for Commercial fire and UL Burglary alarm systems.
If the communicator is connected to a telephone line inside a PABX, be sure the PABX has a backup
power supply that can support the PABX for 24 hours (central station usage) or 60 hours (remote station
usage). Many PABXs are not power-backed up, and connection to such a PABX will result in a
communication failure if power is lost.
To connect the telephone lines to the main and backup dialer, if used, perform the following steps:
Step Action
1 Conduct an electrical test of the line to the CCC or receiving station in accordance with the
requirements for the type of communication method to be employed.
Note: Any limitations or conditions that will affect satisfactory operation must be
immediately brought to the attention of the local telephone company for correction. Any
differences in operation that will affect programmable option selections must be brought to
the attention of the CCC data group for correction before the customized database is
downline-loaded.
8-2
Section 8 – System Communication
Step Action
2 Install an RJ31X jack within the proximity of the control unit. Install a second one if you
are using the backup dialer.
3 Run telephone company lines to the jack(s) and connect them to the red and green
terminals. Connect to the brown and gray terminals all premise phones that use the same
telephone line(s).
4 Connect the main dialer to the RJ31X jack using the RJ31X Cable supplied.
5 Mount the backup dialer to the main PCB as shown in Figure 8-1.
6 Connect the backup dialer to the main PCB J6 connector using a ribbon cable (supplied).
Do not run the ribbon cable underneath the backup dialer PC board.
The J6 header is static-sensitive. Make connections to the header with the power
to the control unit off and after grounding yourself.
7 Connect the backup dialer to the RJ31X jack, using the RJ31X Cable supplied.
8 Connect the earth ground screw on the backup dialer to the earth ground screw (terminal 3
or 4) on the main PCB using 16 AWG wire.
To prevent the risk of shock, disconnect phone lines at the RJ31X jack before servicing the panel.
MAIN
DIALER
LED
J6
1
2
3
4
5
6
7
8
9
CONTROL
PANEL
MAIN
SERVICE
RS-485 #1 RS-485 #2 POINT 1 POINT 2 POINT 3 POINT 4 POINT 5 POINT 6 POINT 7 POINT 8
RJ31X
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
• Do not run the ribbon cable underneath the backup dialer PC board.
• The J6 header is static-sensitive. Make connections to the header with the power off, and after
grounding yourself.
8-3
FOCUS 200 PLUS Installation and Setup Guide
Paging Service
The FOCUS 200 PLUS system can transmit messages to up to 8 paging services (typically one for each
group). The types of messages are divided into 4 categories as follows: System Troubles, Point Troubles,
Alarms and Open/Closes. Each category can be enabled or disabled individually. Additionally, the
system can be programmed to attempt to dial the paging service either once or twice (the default is
twice).
The format of the pager message is as follows:
EEE GGG UUUU
Where:
EEE = Event Code
GGG = Group Number (001-008)
UUUU = User Number (for open/closes) or Point Number.
The possible event codes are:
111 = Fire Alarm
222 = Hold-up or Hostage Alarm
333 = Burglary Alarm
400 = Group failed to Turn OFF
444 = Group was Turned OFF
500 = Group Failed to Turn ON
555 = Point or System Trouble
777 = Group was Turned ON
911 = Personal Emergency (Medical Alarm)
The following is an example of a pager message:
444 001 0025 − Group 1 was turned OFF by user 25.
8-4
Section 8 – System Communication
8-5
FOCUS 200 PLUS Installation and Setup Guide
8-6
Section 8 – System Communication
8-7
FOCUS 200 PLUS Installation and Setup Guide
8-8
Section 8 – System Communication
8-9
FOCUS 200 PLUS Installation and Setup Guide
8-10
Section 8 – System Communication
• NO for the general control unit option "PVF From Control." This inhibits an irregular opening
signal.
• YES for the SANS option for the BA group.
• Any or all ID codes associated with BA groups using this service as being changeable.
8-11
FOCUS 200 PLUS Installation and Setup Guide
8-12
S E C T I O N 9
AC Communicator Module
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the AC Communicator Module ♦ Using Multiple AC Communicator Modules
♦ Installing the AC Communicator Module ♦ Programming for the AC Communicator Module
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
The AC Communicator module must always be set up as the main communicator and any other type of
communication must be set up as the backup.
AC Communicator Supervision
Both the control unit and the module supervise the connections. The system polls the module every 45
seconds and provides a COMM FAIL indication if it does not get a response from the module.
The module transmits a COMM FAIL report (NYC) to the central station if it isn’t polled by the system
within a 45-second period, and sends a COMM FAIL RESTORE (NYO) when polling resumes. The
module may also be programmed to supervise its connection to the central station. A COMM FAIL is
indicated, if within a programmable time period, the module isn’t polled by the central station.
If the built-in dialer is not enabled as a backup, the system provides a COMM FAIL indication after the
module has failed to transmit a report to the central station. If the built-in dialer is enabled, the system
provides a COMM FAIL indication after both the module and built-in dialer fail to transmit the report.
9-1
FOCUS 200 PLUS Installation and Setup Guide
• The system supports either the AC Communicator or the backup dialer, not both.
• The module draws 250mA from the FOCUS 200 PLUS’ auxiliary power #2 output. Be sure to include
this current draw in the power calculations.
9-2
Section 9 – AC Communicator Module
9-PIN HEADER
CONNECTION TO J6.
SEE NOTE 2.
1 2 3 4 5 6 7 8 9 } 12
NOT USED
}
COM 2+
11 COM 2–
TO PAIR OF DC
10 COM 1+ TELEPHONE LINES
ACTIVITY LED
9 COM 1–
(GREEN)
(NOTE 3) 8
}
GROUND
7 TXD
6 TO DVACS TELEPHONE LINE
RXD
5 (OR RS232 PORT)
MOUNT MODULE
RTS
TO MAIN PCB
4
USING 3 CTS
STANDOFFS 3
EARTH GROUND (NOTE 4)
(SUPPLIED). 2
STANDOFFS
SNAP INTO 3
HOLES SHOWN.
472491 ADT AC COMMUNICATOR MODULE
1
RING
TIP } TO AC TELEPHONE LINE
1 2 3 4 5 6 7 8 9
12
}
COM 2+
11 COM 2– TO PAIR OF DC
10 COM 1+ TELEPHONE LINES
ACTIVITY LED 9
(GREEN) COM 1–
(NOTE 3) 8
}
GROUND
7 TO DVACS TELEPHONE LINE
TXD (OR RS232 PORT)
6
RXD
MOUNT MODULE 5
RTS
TO MAIN PCB
4
USING 3 T USED CTS
STANDOFFS 3
EARTH GROUND (NOTE 4)
(SUPPLIED). 2
STANDOFFS
SNAP INTO 3
HOLES SHOWN.
472491D AC COMMUNICATOR MODULE
1
RING
TIP } TO AC TELEPHONE LINE
9-3
FOCUS 200 PLUS Installation and Setup Guide
NO
CONNECTION } RED
GRY
12
11
BLK ORG
10
RJ31X TELCO JACK
9
8
7
6
5
4 TELCO
3
CORD
RING
2 TIP
1
(SEE NOTE 1)
4-PIN JL/JK
HEADER EARTH GROUND
BRN
GRN
RING
TO UCS
RED
TIP
GRY
BLK ORG
RJ31X TELCO JACK
Note 1: To install JL/JK header see text for multiple AC Communicator modules:
YEL BLU
GRY
12
11
BLK ORG
10
9
GND
8
TXD
7
RXD
6
RTS
5
CTS TELCO
4
3
CORD
2
1
(SEE NOTE 1)
4-PIN JL/JK
HEADER EARTH GROUND
YEL BLU
GND
BRN
GRN
RJ31X
TO UCS OR TELCO
EXTERNAL MODEM JACK
RED
TXD
RTS
GRY
BLK ORG
CTS
RXD
9-4
Section 9 – AC Communicator Module
YEL BLU
NO
CONNECTION } COM 2+
RED
GRY
12
COM 2-
11
COM 1+ BLK ORG
10
COM 1- RJ31X TELCO JACK
9
8
7
6
5
4 TELCO
3
CORD
2
1
(SEE NOTE 1)
4-PIN JL/JK
HEADER EARTH GROUND
TO UCS
RED
COM 1+
COM 2-
GRY
BLK ORG
RJ31X TELCO JACK
9-5
FOCUS 200 PLUS Installation and Setup Guide
9-6
S E C T I O N 1 0
J5 Output Triggers
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the J5 Output Triggers ♦ Auxiliary Alarm Signaling Equipment
♦ Types of Output Points ♦ Programming the Output Triggers
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Output Trigger 3 is normally configured as a tamper input to monitor the cabinet tamper(s).
The 4142TR cable is used to make connections to the J5 connector. The output triggers are primarily
intended to sink current, and are rated as follows:
Low Output: 0.7VDC through 100 ohm limiting resistor (can sink 33mA with a 4VDC drop).
High Output: 12VDC through 4k ohm limiting resistor.
These outputs can trigger low-current devices such as relays and sounders by wiring the device's (+)
terminal to one of the control unit's auxiliary power outputs and the device's (-) terminal to the desired
output trigger. A 12VDC relay with a 320 ohm coil and a 7.8VDC pull-in voltage is an example of a
device that may be used.
15 (SMC) Service Output turns on the first time a valid service ID code Complement
is entered at an operating panel (ADT on-premises),
and turns off when an ADT off- premises signal is
initiated by selecting RESET~ ADT OFF at the
operating panel.
16 (TFC) Telco Fault Output turns on if a telco fault condition occurs (low Complement
voltage or current, or loss of interrogation on AC telco
line). The output turns off when the telco line becomes
normal.
10-1
FOCUS 200 PLUS Installation and Setup Guide
10-2
Section 10 – J5 Output Triggers
10-3
FOCUS 200 PLUS Installation and Setup Guide
59 (ACD) Access This output point can be used to trigger a camera or Complement
Denied activate an annunciation device in the event that
someone uses a card/key having a code that either:
• Is not in the system.
• Does not have Irregular Open, Open or Close
access to all BA groups associated with that
ACIU.
• Does not have the Irregular Open or Open option
for any of the associated BA groups that may be
On.
• Has a Close option and the person attempts to
enter outside of the scheduled open period even
though the associated protection is Off.
When the point is triggered, the output stays on for 10
seconds and then goes Off.
68 (ABA) Alarm in any This point type is normally off and turns on when an Complement Comm
alarm occurs in any BA group that is armed. The Fail
BA Group
output returns to the off condition when the BA group
with the alarm condition is changed to Day Set.
When a Long Range Radio is installed, configure the sense select for zones 1 and 2 in the Long Range
Radio to activate on +5V (positive trigger). This is necessary to prevent false alarms from occurring. Refer to
the installation instructions provided with your radio for instructions on setting the zone 1 and 2 levels.
10-4
Section 10 – J5 Output Triggers
7720
FOCUS 200 PLUS SafetyNet Radio
AUX. Relay N.O. 11 Power
Ground 12 16.5VAC / 40VA
J5 Out 5 6
Output Yellow Ground
Out 6 7
Triggers Gray
Out 7 8
Violet Zone1
Out 8 9
FOCUS 200 PLUS Setup: Zone 2
J5 White
Trigger
Out 5 6
Output Yellow Ground
Out 6 7
Triggers Gray
Out 7 8
Violet Zone1
Out 8 9
FOCUS 200 PLUS Setup: Zone 2
ADEMCO 7835C
FOCUS 200 PLUS AC1
16.5
AUX. Relay N.O. 11 40VA
AC2
Ground 12
+ Trigger Voltage
J5
Output Out 6 7 - Trigger (GND)
Triggers Out 7 8
Out 8 9 Zone 1 (FA)
FOCUS 200 PLUS Setup:
Zone 2 (HU)
Set the P3 Jumper to 'WET'
Program the AUX. Relay to activate Zone 3 (BA)
on any BA [ABA]
Program Output 6 (Point 253) to
activate on Fire (type 21, FA)
Zone 4 (Telco Fault)
Program Output 7 (Point 254) to
activate on Holdup (type 23, HU) Zone 5
Program Output 8 (Point 255) to
activate on Telco Fault (type 16)
Zone 6 (Enable Radio)
New Programming
Options:
Q 27= Y
Q27a=Y
Q27b=Y
Q27c=Y
Q27d=N
Q27e=N
10-5
FOCUS 200 PLUS Installation and Setup Guide
7920SE
No. 1349
16.5VAC
40VA
879-126
FOCUS 200 PLUS Battery
TB1 1 2 3 4 5 6 7 8 9 10
J5 GND TEST GND Red Blk
Output Yellow XMFR
Out 6 7
Triggers Gray Imputs
Out 7 8 Tamper
Violet No. 112
Out 8 9
472366 SIM
Gnd Blk
ALTRONIX
RBTUL
10-6
S E C T I O N 1 1
Access Control
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About Access Control ♦ Access Control Options
♦ Installing the Access Control Interface Unit ♦ Maintenance of the Access Control System
♦ Using Readers, Keyloks, and Operating Panels
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
11-1
FOCUS 200 PLUS Installation and Setup Guide
• A user with janitor privilege may shunt alarms on Janitor points in all BA group(s) with card/key.
• The system can be programmed to release all access control doors when a fire alarm occurs. This
option can only be programmed via the ADEMCO Compass Downloader.
Battery Area and There is space for a separately ordered 12V 0.8 AH standby battery that
Connector connects to a polarized connector on the circuit board.
Terminating jumper E1 Insert only if the ACIU is located at the end of the RS-485 bus.
Jumpers E2 through E9 Used for setting the ACIU communication address on the RS-485 bus.
Jumper E11 Leave the jumper intact if it is powering a 12V device. Remove jumper if
it is powering a 5V device. Connect a standard 3k EOLR across TB3-1
and TB3-2 if it is not powering a door releasing mechanism.
11-2
Section 11 – Access Control
Part Purpose
TXD and RXD LEDs Indicates the ACIU communication status as follows:
• TXD LED - flashing when the ACIU is transmitting.
• RXD LED - flashing when the ACIU is receiving.
Tamper Space is provided for adding a tamper switch, which must be ordered
separately as a 248116 Tamper Kit.
RS-485
DS1 DS2
TXD RXD
BATTERY AREA
E2 12V, O.8AH
E3
RS-485 BUS E4
ADDRESS JUMPERS E5
(SEE DETAIL "A") E6
E7
E8
E9
TB1 TB2
JUMPER E10 1
(SEE NOTE 4) (BLK) 1 GND
BATTERY 2+
(RED) 2 + 12V
3 "0"
JUMPER E11 (YEL) 3 COM
(SEE NOTE 3) 4 "1"
TB3 1
(BLU) 4 COM + 5 "A"
2+
CONNECTION FOR E1 6 "B"
ON BOARD BATTERY
IF USED) FOR TAMPER
TERMINAL STRIP JUMPER E1 (REMOVE JUMPER (IF USED)
TB3 FOR POWERING STRIKE TO DISCONNECT RS-485 SEE NOTE 2
OR SOLENOID (NOTE 3) TERMINATING RESISTOR) TERMINAL STRIP
TB2 FOR READER
CONNECTIONS
0 1 2 3 4 5 6 7
UNIT NO. E2 UNIT NO.
E3
E4
E5
COMMUNICATION E6
GROUP NO. 4 E7
E8
E9
NOTES:
11-3
FOCUS 200 PLUS Installation and Setup Guide
Application Guidelines
Use the following guidelines when planning an installation:
• All access control applications require a separate ACIU for each door.
• All readers, except for the Marlok Keyreader and Keylok, can be used on both sides of a door, and
share the same ACIU.
• Reserve the first 255 user ID codes for people who must use an operating panel.
• When using an access-controlled perimeter front door, always make sure that there is another
perimeter door having a mechanical lock for gaining access. In this way, if there is a problem with
the door release mechanism or the ACIU, someone with the key can enter the other door and then
open the front door to let people in.
• Where general access to an unprotected lobby is required, and there is no concern for scheduling, a
card/key reader can be used with an ACIU that does not have any BA groups assigned to it. This
will allow access to the lobby for all persons with valid card/key codes, while requiring all others
(visitors, etc.) to be buzzed in.
If access to the lobby is to be limited to certain working hours, assign the lobby reader to a BA
group that does not have any BA points. Then assign a schedule to that BA group. All persons
having limited access must be programmed with a close only privilege. All persons requiring
round-the-clock access must be programmed with either open or irregular open privilege.
• Install a card/key reader near an operating panel to facilitate the enrolling of new cards/keys.
Installation Guidelines
Use the following guidelines when installing the ACIU:
• Do not use a mag stripe card on a Wiegand reader. It may corrupt the code on the mag stripe card.
• Each ACIU must receive a minimum of 12.5V from the RS-485 bus. Otherwise, the on-board
battery will not charge and there will not be any power for releasing the door strike. If necessary,
add a power supply to ensure that this voltage will be available.
• Maximum current for the electric door strike = 550mA.
• Make certain that the length of cable between the ACIU and its associated reader and door strike
does not exceed 150 feet.
• The ACIU must not be subjected to temperatures below 32°F (0°C) or above l20°F (49°C).
• Include each ACIU in the System Layout Diagram of the FOCUS 200 PLUS System, indicating the
BA group(s) that will be accessed via the ACIU.
• Each ACIU draws 60mA (including battery charge). Similarly, each card/key reader (or Keylok)
draws a current that is specified in the Equipment section. These current draws affect the overall
system power requirements; therefore, they must be incorporated into the power calculations in
the Power Requirements section.
When you are calculating power requirements, make sure that each ACIU will receive a minimum
of 8.5 volts (the same as the gateways and operating panels). This is based on 10.5 volts being
supplied by the control unit battery with all sensors in alarm, and is calculated based on voltage
drops on the RS-485 bus. The 8.5 volts cannot be measured; however, when the power transformer
is plugged in, the ACIU should be receiving 12.5 volts from the RS-485 bus in order to recharge the
on-board battery. This voltage can be measured.
11-4
Section 11 – Access Control
Note: The current for operating the door strike is furnished by the battery in the ACIU or by an
external power supply, and does not enter into these calculations.
• Where an operating panel is being used with an ACIU for access control, it must be assigned
communication Group # 0 on the RS-485 bus. All other operating panels that are not being used for
access control must be assigned to communication Group # 1. The purpose is to prevent access
control operating panels from being locked out if someone else is using a non-access control panel
for a period of time, and visa versa.
RS-485 Buses
Each ACIU connects to a port in the control unit via a cable known as an RS-485 bus. The control unit
can accommodate two independent RS-485 buses of 4000 feet each permitting an end-to-end reach of up
to 8000 feet if using both buses. The maximum bus distance can be extended to 16,000 feet by using a
472430 RS-485 Repeater at the end of each bus. Current loading and voltage drop considerations may
limit the maximum allowable wire lengths on each RS-485 bus to less than 4000 feet. See the Power
Requirements section for additional information.
11-5
FOCUS 200 PLUS Installation and Setup Guide
Wiring the Access Control Interface Unit
To wire the ACIU, perform the following steps:
Step Action
1 At the control unit, make sure the power switch is in the "OFF" position.
2 Run the buses as required and make sure to appropriately tag them. Limit each RS-485
bus to a single wire run.
Note: It is important to appropriately tag the cables so they can readily be identified. This
is especially important if troubleshooting becomes necessary at some future date.
3 Cut the trunk cable and remove enough sheathing and insulation from each wire to allow
fastening under the pressure plate of a terminal strip screw.
4 Measure the resistance between the black and red conductors (the (+) lead of the meter to
the red conductor and the (-) lead to the black conductor). A reading less than 12 ohms
indicates a short on the power conductors or an excess of protection points. Make the
necessary corrections before proceeding.
5 Connect the RS-485 cable to TB1 of the ACIU. Identify terminal wires so that the proper
wires can be connected to each terminal (see Figure 11-1).
6 Connect the battery leads to the connector on the circuit board.
7 Connect the RS-485 bus cable to the control unit (see table below).
Card Readers
The card readers:
• Are installed near the frame of the door.
• Read a coded card to determine whether a person will be permitted access.
• Are used with a separate electric door strike or other electrically controlled door- releasing device.
• Are categorized by the type of card that they read. Three basic types of cards are:
1. Magnetic stripe (mag stripe)
2. Wiegand
3. Proximity (prox)
Card readers are therefore generally known as mag stripe, Wiegand, or prox readers.
11-6
Section 11 – Access Control
• Are also categorized by the way the card must be presented for reading:
1. Card Swipe − The card is "swiped" across a slot in the reader.
2. Insert − The card is inserted fully into a narrow slot, and is read as it is withdrawn
3. Proximity − The card is passed in close proximity to the reader, which uses energy to
determine the code on the card.
• May come with a keypad for added security, so that a PIN number can be entered in addition to the
card code. For these applications, the ACIU can accommodate any PIN number of 1-8 digits along
with the associated card code.
• May feature an LED display to inform the user of the card-reading and access-control process.
Typically, a red-green LED lighting arrangement is used. Some readers use a bi-color LED and
others use two LED's. On most readers, the red LED is normally lit to indicate that the reader is
receiving power. When a card/key is being read, the red LED blinks off and, if access is granted, it
turns green.
Key Readers
The key readers:
• Read the code embedded in the shaft of a metal key.
• Utilize a reader that has been integrated into a lock cylinder.
• Are installed near the door frame.
• Are used with a separate electric door strike or other electrically controlled door-releasing device.
Keyloks
The keyloks:
• Are installed in the handle of a key-operated doorknob or other door-locking mechanism.
• Cylinder, which replaces the key cylinder of the lock, has both a key reader and a built-in electrical
releasing mechanism.
When a key with valid code is inserted, the ACIU provides the releasing voltage allowing the key to be
turned to unlock the door. When the key is turned, it operates a cam that can be linked to various types
of unlatching mechanisms.
Note: Because the Keylok is installed on the door rather than near the frame, wiring must be run from
the Keylok, through the door, to a flexible cord. The flexible cord carries the wires from the edge of the
door onto the door frame, so that a connection can be made to the ACIU.
11-7
FOCUS 200 PLUS Installation and Setup Guide
Summary of Access Control Card/Key Readers
Access Model Card/Key Application User Operation Card/Key Reader DIP ACIU
Control Type ∗∗ Programming Switch Strike
Device Settings Voltage
Settings
Sensor 3152540 Epic Three Wiegand Card Indoor/Outdoor Card swipe None—card comes None required 12-volt strike
Engineering LED pre-programmed
(E11 = IN on
Wiegand Card with site code and
ACIU)
Reader user code.
Motorola Slimline Proximity Proximity Indoor/Outdoor Card introduced within 4” of None—card comes None required 12-volt strike
Indala Card Reader 4” Card reader pre-programmed
(E11 = IN on
Proximity Card Range with site code and
or ACIU)
Reader user code.
WallSwitch
Proximity Key Key Tag introduced within
Proximity Card
Tag 2.5” of reader
Reader 4” Range
Dorado Pass- 3110-6440/6441 Magnetic Indoor Only with Any of the following: None—ADT- ABA card, 34 12-volt strike
Through Card Pass-Through Card stripe card Keypad ordered card comes bits Wiegand:
• Keypad PIN code only (1-8 (E11 = IN on
Reader ∗ Reader w/Keypad (high- pre-programmed Reader DIP
digits, then enter # key). ACIU)
coercivity with site code and switch
3110-7801 Pass-
Through Ruggedized
polyester) Indoor/Outdoor • Card swipe only. user code. settings.
with Keypad (Possibility of using
Card Reader • Card and keypad (enter credit cards and
A B C D
w/Keypad PIN of 1-8 digits, then driver’s license that on on on off
swipe card). is coded).
Dorado Pass- 3110-7401 Pass- Same as above Indoor/Outdoor Card swipe Same as above Same as above 12-volt strike
Through Card Through Ruggedized
(E11 = IN on
Reader ∗ Card Reader
ACIU)
w/Keypad
Dorado 3110-5849/5841 Same as above Indoor/Outdoor Any of the following: Same as above, but Same as above 12-volt strike
Insertion Card Insert Card Reader with Keypad cannot accept credit
• Keypad PIN code only (1-8 (E11 = IN on
Reader ∗ w/Keypad cards or driver’s
digits, then enter # key). ACIU)
license.
• Card insertion only
(extraction read).
• Card and keypad (insert
card, enter PIN of 1-8
digits, then remove card).
Marlok Keylok 072-101049/101051 Coded Key Indoor/Outdoor Coded key is inserted into None—key comes None required 5-volt solenoid
(cylinder w/key Keylok Mortise Marlok keyreader cylinder. If pre-coded. in Keylok
reader and key is OK, ACIU provides
072-101050 Rim (E11 = OUT on
integral voltage for integral solenoid,
Cylinder Keylok ACIU)
solenoid) permitting key to turn and
060-100997 Key In release mechanically-linked
Knob (D Knob) latch. (Keylok requires
running wires through door
and installation of a flexible
door cord between door and
its frame.)
Marlok 072-038110 Gang- Coded Key Indoor Only Coded key is inserted into None—key comes None required 12-volt strike
Keyreader Mount Keyreader Marlok keyreader cylinder. If pre-coded.
(E11 = IN on
key is OK, ACIU provides
072-038111 Mullion- ACIU and
voltage for operating a door
Mount Keyreader insert 330-ohm
strike.
dropping in
072-038112 Panel-
series with
Mount Keyreader
TB3-2)
Northern KP-11-8 BIT Numerical Indoor/Outdoor Keypad PIN code only (1-8 N.A. N.A. 12-volt strike
Computers Codes digits, then enter # key).
(E11 = IN on
Wiegand
ACIU)
Output
Weatherized
Keypad
FOCUS Indoor Only Enter 6-digit user ID code. N.A. N.A. 12-volt strike
Operating
(E11 = IN on
Panel
ACIU)
∗ Dorado and other mag stripe readers and cards may experience wear, necessitating periodic reader maintenance and eventual card replacement.
Consult vendor literature for details.
∗∗ Refer to vendor literature for environmental and other limitations.
11-8
Section 11 – Access Control
Installing and Wiring the Electric Door Strike and Card/Key Reader (or Keylok)
Wiring Connections Between ACIU and Readers/Strike
Reader and Strike Wire Connections (1)
ACIU Terminal Marlok Marlok Sensor Dorado (5) Motorola
Keylok (2) Keyreader Engineering Indala
(2) (Epic)
TB2-1 (-) (4) Brown Brown Black Black Black
TB2-2 (+) Green Green Red Red Red
TB2-3 (data “0”) Orange Orange Green Green Green
TB2-4 (data “1”) Black Black White White White
TB2-5 (LED “A”) Violet Brown Brown
TB2-6 (LED “B”) Brown
NOT USED Blue Yellow Blue
Orange Orange
Yellow
TB3-1 Strike (-) Red (2a) Red (2b) (3) Strike (-) (3) Strike (-) (3) Strike (-) (3)
Strike (-)
TB3-2 Strike (+) Yellow (2a) 330-ohm Strike (+) (3) Strike (+) (3) Strike (+) (3)
Yellow (2b) (3)
Strike (+)
(1) To extend reach of card/key readers for connection to ACIU, use manufacturer’s extension cable or use 494461 Cable as noted
below.
(2) For Marlok applications:
a. For a Marlok KEYLOK (comes with 5V internal solenoid), connect red and yellow keylok wires to TB3-1 and TB3-2,
respectively, and remove Jumper E11 in order to supply 5V to solenoid.
b. For Marlok KEYREADER (works with the 12V stand-alone strike):
1. Connect (+) and (-) terminals of strike to TB3-2 and TB3-1, respectively.
2. Insert a 330-ohm +/- 5%, 1-watt resistor in series with the yellow wire from Keyreader to TB3-2.
3. Connect red wire from Keyreader directly to TB3-1.
4. Insert Jumper E11 to supply 12V.
(3) Strike requires 12VDC (E11 = IN). If not using strike, connect a 3K resistor across TB3-1 and TB3-2.
(4) Connect TB2-1 to CWG so that wire from reader will be returned to CWG.
(5) Cut resistor R8 on the ACIU circuit board, if you are using Dorado 7401 or 7901 card readers. See Figure 11-4.
To install the electric door strike and card/key reader or Keylok, perform the following steps:
Step Action
1 Install the electric door strike and the card/key reader or Keylok in accordance with the
manufacturer's instructions.
2 Run the wiring in accordance with manufacturer's instructions, making sure that all
wiring to the ACIU does not exceed 150' (see Figures 11-2 and 11-3).
Where vendor extension cables are not available for the connections, use 494461 (6466-10)
Cable for the extension.
3 Set the DIP switch settings for the card reader, as required.
4 If not using a strike or a Keylok, install a standard 3K EOL resistor across TB3-1 and
TB3-2 on the ACIU to simulate the strike load for the strike supervisory circuit.
11-9
FOCUS 200 PLUS Installation and Setup Guide
ACIU TB1
494470 CABLE
(2-WIRE, #18 AWG)
494461 CABLE (6466-10)
(10-WIRE, #22 AWG)
1
CARD READER
KEY READER
ELECTRIC STRIKE
ACIU TB1
RS-485 BUS
TB3
TB2
MARLOK 011-037502
EXTENSION (15 FEET)
(SEE NOTE)
788-16 FLEXIBLE
ARMORED DOOR
MARLOK 1 CORD (16")
KEYLOCK
PULL
NOTE: MAXIMUM ALLOWABLE CABLE DISTANCE BETWEEN KEYLOCK AND ACIU IS 150 FEET
11-10
Section 11 – Access Control
TERMINAL STRIP TB1 JUMPER E1
FOR RS-485 BUS (REMOVE JUMPER TO
CONNECTIONS DISCONNECT RS-485
TERMINATING RESISTOR)
RS485
DS1 DS2
TXD RXD
BATTERY AREA
E2 12V, O.8AH
E3
E4
E5
E6
E7
E8
E9 TB1 D11 U1 U2
(BLK) 1
D1
GND TB2
C4
(RED) 2 R7 1
C3
+ 12V D4
E11 BATTERY R8 C6 2+
(YEL) 3 D5
E10 + COM D3 C7 3 "0"
(BLU) 4 D10 C5 4 "1" D6
1 D2
COM + 5 "A"
TB3 2+ D7
6 "B"
E1 D8
CUT R8
Figure 11-4: Modifying ACIU for Operation with Dorado 7401 or 7901 Card Reader
Where an operating panel is being used for access control with an ACIU, its communication Unit number on
the RS-485 bus must coincide with the communication Unit number of the ACIU. An operating panel being
used for access control (Communication Group 0) becomes locked out during the period that any other
operating panel at communication Group 0 becomes activated, and vice versa.
11-11
FOCUS 200 PLUS Installation and Setup Guide
Installing the RPX-264 Pushbutton
The RPX-264 Pushbutton may be used for manual buzz-in and egress (exit) applications (MAP/EXP
point types.
Where the RPX-264 Pushbutton is being used for manual buzz-in:
• Install it at the location specified by the customer.
• The associated SIM (Sensor Interface Module) connects to the trunk of any SIM (or PID) gateway
in the building. See Figure 11-5 for the wiring connections.
• Program the point as Manual Access Pushbutton Point.
Where an RPX-264 Pushbutton is being used for an egress (exit):
• Install it inside of the protected area close to the exit door along with its SIM (Sensor Interface
Module).
• The LED on the pushbutton serves to annunciate the status of the associated BA group(s).
Therefore, it must be visible from outside the door. If this is not possible, a separate series-
connected LED must be installed just outside of the exit door. See Figure 11-5 for the connections.
• Program the point as Exit Pushbutton Point.
For an explanation of these input point types, see Point Types Associated with Access Control later in
this section.
BLUE
X
YELLOW X
RED SIM QUAD TRUNK
X
BLACK
X
WHT
BLUE
X
YELLOW X
RED PID QUAD TRUNK
X
BLACK
X
Figure 11-5: Wiring Connections for a Manual Access Pushbutton or Exit Pushbutton
11-12
Section 11 – Access Control
11-13
FOCUS 200 PLUS Installation and Setup Guide
The strike being used for the CDR SCH option must be capable of continuous activation; otherwise it may
burn out. Also, the strike must be powered from a separate power supply in place of the ACIU battery.
Therefore:
• The battery must be removed from the ACIU.
• The red (12V) bus wire must be disconnected from TB1-2 of the ACIU.
• The 12 VDC power from the power supply must be connected to terminals TB 1-1 and TB1-2 (12V) of
the ACIU.
• Jumper E10 must be inserted on the ACIU board because the battery is not being used.
Where a Marlok Keylok is involved, DO NOT use the CDR SCH option because the Keylok will burn out if
its solenoid is continuously powered. Instead, the Keylok must be opened with the key and must not be
locked until the open period is terminated, typically by the last person leaving for the day.
11-14
Section 11 – Access Control
Entry
Description Function
Number
64 (EXP) Exit This point type uses a RPX-264 Pushbutton, installed inside of the
Pushbutton access-controlled area, to establish a 1-minute exiting-time window
for the last person leaving. This allows the person time to open the
door, exit, and use a coded key at a Keylok to lock the door, thereby
automatically tuning on the BA groups.
The pushbutton is ordinarily connected to a SIM. However, for
retrofit purposes, the pushbutton can also be connected to a 471999
Switch Interface Module.
When someone with a Janitor privilege uses the pushbutton for
exiting, then closes the door and uses the coded key to lock the
Keylok, the shunt is removed from all Janitor points that were alarm
shunted. Also, a Janitor Off Premises signal is sent to the CCC.
The LED option serves to annunciate the exit delay. See the tables
below for the status indications for a person with and without Janitor
privilege during entry and exit.
11-15
FOCUS 200 PLUS Installation and Setup Guide
Entering Point Data Via the Operating Panel
See the Types of Input and Output Points section for information about for point data options. See the
Programming section for instructions on entering the point data via the operating panel.
11-16
Section 11 – Access Control
Option Function
Cancel Date A date can be assigned for temporary users of the system, after which their
card/key or operating panel code will become invalid.
Note: If an RF button is linked to a user code, when the user code cancel date
expires the link is severed. Entering a new cancel date does not re-establish
the link to the RF button.
BA Group This serves to identify the number of each BA group within the access-
Control controlled area, and it is used in conjunction with the BA Group Level
(described above) that is assigned to each person who will have a coded
card/key. In this way, the control unit can determine whether a person's
card/key can be used to gain access to the BA group(s) associated with a given
card/key reader:
• If the associated BA groups are Off, any persons having a "C," "O," or "I"
level of access to these groups will be allowed to enter. All other persons
("-" level) will be locked out.
• If the associated BA groups are On, only persons with an "I" or "O" level
of access to these groups will be allowed to enter; persons with a "C" or "-"
level will be locked out.
Table of Privileges
The following table explains the 9 privilege levels available for each user. Privilege levels 1 through 5
apply to users with an operating panel code only.
Level Privilege
0 Ability to open and access all BA groups outside of the scheduled opening time without
initiating an irregular opening (open signal to CCC) or irregular access (no signal to CCC).
1 Ability to bypass and unbypass BA points, and ability to bypass VVS sensors.
2 Ability to change temporary schedules and change closing times, and ability to change real
time by up to 5 minutes per day.
3 Ability to change permanent schedules, make unlimited changes in real time, and to
conduct FA sensor test.
11-17
FOCUS 200 PLUS Installation and Setup Guide
Level Privilege
4 Ability to change person/point/BA group descriptions, and privilege level. Ability to change
ID code accessibility to BA group.
5 Ability to bypass fire, holdup, or supervisory points, and to conduct FA sensor test.
6 Service − ADT on-premises signal is transmitted to CCC when the ID code is entered and
will lock out all other ID codes. This privilege must be assigned to all Service ID codes, and
is not to be made available to the customer.
7 Operating panel code and/or card/key code is permitted to be changed by person having a
code with Level 4 privilege.
8 Janitor − Use of valid card/key will cause the alarm shunting of any Janitor BA points in
the associated BA group(s).
Note: Basic privilege assigned to each code allows user to turn BA protection On and Off for assigned
BA group(s), and to perform tests.
<? Code and card The Person’s Deletion Date Screen is displayed.
will be deleted Enter the digits for the month and day after which the person will
< on 08/21 be prevented from using the system.
< Quit Enter > Select Enter to register the date in the system.
<? Code and card After you press Enter, that button changes to None.
will be deleted Select None to delete the date and/or change it.
< on 08/21
< Quit None >
<? Code and card Select Quit to return to the Person Data Entry Screen.
will be deleted
< on 08/21
< Quit None >
11-18
Section 11 – Access Control
Construction Mode
The system is capable of operating in a Construction mode in which building contractors can be given a
special coded card or key for gaining access before the system is fully operational. This mode is in effect
if the ACIU is not communicating with the control unit.
Remember, to use the Construction key/card, the control unit must be powered down or the ACIU
communication wires must be disconnected from the RS-485 bus.
After making all required adjustments and powering up the system, you can enroll the Construction
key/card into the system and give it to construction people for use until the system is turned over. Then
the Construction key/card can be deleted.
Where a Keylok is involved, a small terminal is provided just above the LED to enable emergency
operation in the event that AC power is out or the control unit is down for an extended period. Applying
a + 12-volt potential to this terminal from a battery will power the ACIU and allow a Construction key
to be used to unlock the door.
Supervision of ACIU
The ACIU is supervised for three conditions:
• A low-battery condition − If the battery voltage falls below 12.0 volts, a low-battery supervisory
signal will be generated. The voltage is checked every time the door strike is powered.
• An open in the wiring between the electric strike or Keylok mechanism and the ACIU.
• A tamper condition − If the tamper is used and the cover is removed.
In either case, the operating panel will display a trouble message (shown below), that indicates the RS-
485 Communication Unit number of the ACIU.
In the event that a low battery or an open is detected, a DT (device trouble) signal will be sent to the
CCC. If a tamper is detected, a tamper signal will be sent. Both signals will include the number that
identifies the address of the associated ACIU.
11-19
FOCUS 200 PLUS Installation and Setup Guide
Identifying the ACIU in the CCC Transmission
The table below shows the information sent to the CCC for the various trouble conditions for each unit
number:
Unit Number CCC Transmission
0 DA32, DT32, or DR32
1 DA32, DT33, or DR33
2 DA34, DT34, or DR34
3 DASS, DT35, or DRSS
4 DA36, DT36, or DR36
5 DA37, DT37, or DR37
6 DA38, DT38, or DR33
7 DA39, DT39, or DR39
DA = Tamper, DT = Trouble (battery or strike wiring), DR = Restore
Super-Degraded Mode
If the control unit fails or the ACIU loses communication with the control unit, the ACIU goes into the
Super-Degraded mode, operating on its battery power. In this mode, the reader will recognize only the
last 63 different card/key codes that were granted access. This allows these people to continue to gain
access in the interim until normal operation is restored.
Attempts at access during the Super-Degraded mode, whether they are successful or not, will not be
logged in the History Log.
Troubleshooting
The following table describes access control troubleshooting procedures:
Symptom Probable Cause Corrective Action
Red LED on reader or 1 Battery is not fully charged 1 Make sure that battery is fully charged and is properly
keylok does not go on. or is not properly connected connected to ACIU.
to ACIU.
2 Insufficient power to 2 Check for 5VDC between TB2-1 (-) and TB2-2 (+). If
reader. you are using a Marlok Keylok or Keyreader, key must
be fully inserted in keyway for this measurement.
A. If reading is too low, either RS-485 bus voltage to
ACIU is too low or ACIU is defective.
B. If reading is OK, problem is in reader or wiring to
reader.
3 Insufficient voltage to 3 Check for at least 12.5VDC across TB1-1 (-) and TB1-2
ACIU. (+).
A. If reading is too low, add a local power supply.
B. If reading is zero or if polarity is reversed, check
wiring to TB1.
4 Defective ACIU. 4 Disconnect all wires from TB2. If voltage between TB2-
1 (-) and TB2-2 (+) is not 5VDC, replace ACIU.
5 Wrong reader. 5 Replace reader with one that is rated to operate
between 4.75 and 5.25VDC.
6 Defective reader. 6 Disconnect all reader wires on TB2, except wires TB2-1
(-) and TB2-2 (+). If reader had connection to TB2-6,
momentarily connect this wire to TB2-1. If red LED
does not light, replace reader.
11-20
Section 11 – Access Control
11-21
FOCUS 200 PLUS Installation and Setup Guide
11-22
Section 11 – Access Control
Successfully enrolled 1 Person does not have 1 Program person with access to ALL BA Groups
card/key does not activate access to all BA Groups associated with this reader.
green LED and strike or associated with this reader.
Keylok. Control unit
2 Time is outside of 2 Wait until time is inside of scheduled open period or
history and/or printer show
scheduled open period and reprogram person with irregular privilege.
“User XXX DENIED NA.”
person does not have
irregular privilege.
3 Time of day or date is 3 Correct time of day and/or date.
incorrectly set in control
unit.
4 “BA Off Disable” option has 4 Only person with an operating panel code (1-255) can
been selected for one of the turn off the BA Group. Change the “BA Off Disable “
BA Groups associated with option or assign an operating panel code to this person.
this reader.
5 BA Group associated with 5 Corrective actions are:
this reader is ON and
cannot be turned of
because:
a. Person has not been a. Re-program person with turn-off capability (“I” or
programmed with “O” level).
capability to turn off
the BA Group.
b. Schedule is locked. b. Wait until inside of schedule.
c. ATM interlock option c. Turn on other interlocked BA Group.
has been selected.
d. BA Group has 2-man d. BA Group must be turned off from operating panel.
rule.
Card code changes with 1 Card is not 100% 1 Use cards that are specified for the particular reader
each swipe when enrolling. compatible with reader. being used.
2 Incorrect reader 2 Use readers specified earlier in this section.
“I” level person does not 1 Control unit PVF is not 1 Program “PVF From Control” as (Y) Yes.
generate an Irregular selected.
Opening (PVF).
2 Time is inside of schedule. 2 Correct time, date, and/or schedule (Permanent or
temporary).
11-23
FOCUS 200 PLUS Installation and Setup Guide
11-24
S E C T I O N 1 2
History Log
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the History Log ♦ Displaying and Printing the History Log
♦ Installing the Printer Interface Unit
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
You must install a printer interface unit if you want to use a local printer.
12-1
FOCUS 200 PLUS Installation and Setup Guide
TB2
E2 GND 1
E3
USER BUS E4 + 12V 2
ADDRESS E5 SHIELD SHIELD
JUMPERS E6 COM 3 E1
(SEE DETAIL A) E7
E8 COM + 4
E9
RS485 IN
PRINTER HEADER
RS232 (J2)
JUMPER E1
(REMOVE JUMPER TO DISCONNECT
TERMINATING RESISTOR)
NOTES:
12-2
Section 12 – History Log
<? Enter choice: Enter the Service Code. Action Menu #1 is displayed.
< Lesson Turn on > Select More twice.
< See alarms Reset >
< Quit More >
12-3
FOCUS 200 PLUS Installation and Setup Guide
12-4
Section 12 – History Log
12-5
FOCUS 200 PLUS Installation and Setup Guide
Description Alpha
Open/Close (continued)
BA Auto Open AUTO OPEN
BA Irregular Opening IRR OPEN
BA Opening OPENING
BA No Close – scheduled close time expired NO CLOSE
BA Exit Fail – exit error (user) EXIT FAIL
BA Bypass Closing by User BYPASS USR
BA STAY (Local) Arming CLOSE STAY
Fire
Fire Alarm FIRE ALARM
Fire Trouble FIRE TBL
Fire Alarm Restore FIRE RST
Fire Alarm Silence FA SILENCE
Fire Point Bypass FA BYPASS
Fire Alarm Point Unbypass FA UNBYP
Supervisory Alarm CRIT ALARM
Supervisory Trouble CRIT TBL
Supervisory Restore CRITL RST
Supervisory Point Bypass CRIT BYP
Supervisory Point Unbypass CRIT UNBYP
Waterflow Alarm WF ALARM
Waterflow Bypass WF BYPASS
Waterflow Restore WF RST
Waterflow Trouble WF TBL
Waterflow Unbypass WF UNBYP
Panic
Holdup Alarm HOLDUP ALM
Holdup Point Trouble – sensor trouble HOLDUP TBL
Holdup Restore HOLDUP RST
Holdup Point Bypass HU BYPASS
Holdup Point Unbypass HU UNBYP
Hostage Alarm – Duress HHHHHHHHHH
Medical Alarm MED ALARM
Medical Alarm Restore MED RST
Medical Trouble MED TBL
Medical Bypass UT BYPASS
Medical Unbypass U UNBYPASS
Downloading
DLL Aborted DLL ABORT
Start DLL START DLL
DLL Interrupted DLL INTER
End DLL Altered END DLL AL
DLL Comm Fail DLL COMM F
End DLL Not Altered END DLL NA
Scheduling
BA Change Close Time (extend closing) CH CLOSE T
BA Change Open Time CH OPEN TM
12-6
Section 12 – History Log
Description Alpha
Scheduling (continued)
Change Close Time CH CLOSE T
Change Auto-On Level CH AUTO ON
Change Latest Close – sent only if closing schedule is altered CH LT CLOS
Change Open Time – schedule change CH OPEN TM
Change Time – time/date reset CH TIME
Other
Supervised Bell Alarm (remote bell) BELL ALARM
Supervised Bell Trouble (remote bell) BELL TBL
Supervised Bell Trouble Restore (remote bell) BELL RST
Remote Power Supply Alarm POWER ALM
Remote Power Supply Trouble POWER TBL
Remote Power Supply Trouble Restore POWER RST
Keyswitch Alarm KEY ALARM
Keyswitch Trouble KEY TBL
Keyswitch Restore KEY RST
Janitor Keyswitch Alarm JANITOR AL
Janitor Keyswitch Trouble JAN TBL
Janitor Keyswitch Alarm Restore JAN RST
Janitor On Premises – user on premises JANITOR ON
Janitor Off Premises – user on premises restore JAN OFF
ADT On-Premises SERVICE ON
ADT Off-Premises SER OFF
Tamper Alarm TAMPER ALM
Tamper Restore TAMPER RST
Tamper Bypass TMP BYPASS
Tamper Unbypass TMP UNBYP
VVS Bypass VVS BYPASS
VVS Unbypass (after 12 AM auto-off) VVS UNBYP
Bypass by User BYP USER
Keypad Active ACCESS
Audible Walk-Test AUDIBLE TS
Change Code CH CODE
Change Early Open CH ER OPEN
Change Holiday CH HOLIDAY
Carbon Monoxide Alarm CO ALARM
Carbon Monoxide Bypass CO BYPASS
Carbon Monoxide Restore CO RST
Carbon Monoxide Trouble CO TBL
Carbon Monoxide Unbypass CO UNBYP
Long Range Radio
DC Fault LR DC FLT
DC Fault Restore LR DC RST
Tamper Fault LR TMP FLT
Tamper Fault Restore LR TMP RST
Low Battery LR BAT FLT
Low Battery Restore LR BAT RST
VSR Fault (antenna) LR VSR FLT
12-7
FOCUS 200 PLUS Installation and Setup Guide
Description Alpha
Long Range Radio (continued)
VSR Fault Restore (antenna) LR VSR RST
ECP Fault LR ECP FLT
ECP Fault Restore LR ECP RST
Communication Fault LR COM FLT
Communication Fault Restore LR COM RST
System Test
Walk-Test WALK TEST
Bell Test BELL TEST
Holdup Test Alarm HU TEST AL
Holdup Test Restore HU TEST RS
Start Fire Alarm Test SRT FA TST
End Fire Alarm Test END FA TST
Start Burglary Alarm Test SRT BA TST
End Burglary Alarm Test END BA TST
Start Supervisory Test SRT SV TST
End Supervisory Test END SV TST
Start Holdup Alarm Test SRT HU TEST
End Holdup Alarm Test END HU TST
Long Print LONG PRINT
Short Print SHT PRINT
Supervisory Test Print – manual trigger test report CRIT TST A
Supervisory Test Restore CRIT TST R
Fire Alarm Test Print FIRE TST A
Fire Alarm Test Print Restore FIRE TST R
Burglary Alarm Test Print BA TST AL
Burglary Alarm Test Print Restore BA TST RST
Holdup Suspicion Print SUSPICION
Keypad No Access NO ACCESS
Untyped Bypass UT BYPASS
Untyped Unbypass U UNBYPASS
Burglary Alarm Diagnostics BA WAN
Fire Alarm Diagnostics FA WAN
Output Trouble OUTPUT TBL
Output Trouble Restore OUTPUT RST
Point Trouble POINT TBL
Point Alarm – general alarm POINT ALM
Point Alarm Restore – general alarm restore POINT RST
Untyped Diagnostics UA WAN
Burglary Alarm Weak Battery B WEAK BAT
Fire Alarm Weak Battery F WEAK BAT
Holdup Alarm Weak Battery H WEAK BAT
Supervisory Alarm Weak Battery S WEAK BAT
Untyped Alarm Weak Battery U WEAK BAT
Weak Battery Restore BAT RESTOR
Access
ND
2-Man 2 Person ACCESS 2ND
Keypad Lockout KEYPD LOCK
12-8
Section 12 – History Log
Description Alpha
Access (continued)
Cardreader Irregular Access IRR ACCESS
Manual Pushbutton Access – remote arm/disarm opening MAP ACCESS
Access Denied Code Known – access denied DENIED NA
Access Denied Code Unknown – access denied INVALID NA
Dialer Test
Dialer Test Report DLR TEST
Dialer Test Report with System Trouble Present TBL TEST
12-9
FOCUS 200 PLUS Installation and Setup Guide
12-10
S E C T I O N 1 3
Power Requirements
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About Powering the FOCUS 200 PLUS ♦ Installing a Power Supply
♦ Providing Adequate Voltage for Each Gateway, ♦ Connecting AC Power and Earth Ground to the
SIM Loop, and Operating Panel Control Unit
♦ Determining Maximum Length of Gateway ♦ Installing the Standby Battery
Trunk Cable ♦ Powering Up the Control Unit
♦ Determining the Control Unit Power Supply
Load
♦ Determining the Size of the Standby Battery
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
While wiring connections are being made or removed, make sure the POWER switch (on control unit circuit
board) is in the OFF position.
We recommend wiring all points and expansion modules according to each section's instructions before
powering up the system for programming and testing.
Providing Adequate Voltage for Each Gateway, SIM Loop, and Operating Panel
To determine that each gateway and each operating panel will have adequate voltage, the voltage drops
along the RS-485 bus must be calculated. Use the procedure below along with the tables and forms that
follow to determine whether an additional power supply is needed.
13-1
FOCUS 200 PLUS Installation and Setup Guide
A B AxB C AxC
Non-Powered
10 24
Sensors/COPIDS
System-Powered Sensors with PID
Motion Detector
45 54
Smoke Detectors
50 100
VVS
35 35
VAS
15 34
Teleproach Interface
15 39
Daytime Annunciator
100 100
Quad-Powered
20 20
Sounder PID Module
BA Supervised Bell
50 40
Control ∗
Sounder
45 45
PID Gateway 1 50 50 50 50
13-2
Section 13 – Power Requirements
A B AxB C AxC
Total Alarm Total Alarm
Standby
Device Quantity Standby Current Current
Current (mA)
Current (mA) (mA) (mA)
SIM Door Contact
1 1
SIM ∗
1 1
Horn/Strobe
∗∗ ∗∗
Sounder 472307
10 10
Powered Sensors
Relay
SIM Gateway 1 50 50 50 50
∗ SIM connected to external contact, powered sensor, self-powered sensor, output SIM, or horn/strobe
∗∗ 190mA for bell mode with strobe, 260mA for horn/strobe
13-3
FOCUS 200 PLUS Installation and Setup Guide
SIM ∗ 1 1
4208U
4209U
4208SNF
Horn/Strobe∗∗
Sounder PA400W
10 10
Powered Sensors
Relay
13-4
Section 13 – Power Requirements
To calculate the standby and alarm loads for each gateway, perform the following steps:
Step Action
1 Make a copy of each table for each gateway on the system.
2 Fill in Tables 1, 2, 3, and 4 to calculate the standby and alarm current loads for each
gateway. Use Table 1 for PID Gateways, Table 2 for SIM Gateways, Table 3 for RF
Gateways and Table 4 for the SIM Loop. These totals will be used to determine the
gateway trunk cable lengths and the size of the system’s backup battery.
13-5
13-6
NOTES:
1. TOTAL GATEWAY BUS LOAD = TABLE 1, 2 OR 3
2. l1 = GATEWAY 1 BUS LOAD + OPERATING PANEL 1 BUS LOAD + GATEWAY 2 BUS LOAD
l2 = OPERATING PANEL 1 BUS LOAD + GATEWAY 2 BUS LOAD
l3 = GATEWAY 2 BUS LOAD
POWER SUPPLY
V= (8.5V min.)
UNIT GATEWAY 2
l1 = GATEWAY 1 l2 = OPERATING
mA mA
PANEL 1
10.2V
FT. FT. BUS LOAD = 65mA
BUS LOAD = mA BUS LOAD = mA
V= (8.5V min.)
V= (8.5V min.)
GATEWAY 3
OPERATING l4 = 65mA l3 = mA
PANEL 2
1.3
1.2
1.1 .10A
1
0.9
0.8
0.7
0.6 .05A
0.5
0.4
0.3
0.2
0.1
0
0 200 400 600 800 1000 1200 1400
Length of RS-485 Bus Section (feet)
13-8
Section 13 – Power Requirements
1000
900
800
Gateway Load Current (ma)
700
600
500
10.2V
400 8.6V 8.8V 9.0V 9.2V 9.4V 9.6V 9.8V 10V
300
200
100
0
0 100 200 300 400 500 600 700 800 900 1000
Maximum Length of PID Gateway Trunk (feet)
Figure 13-4: Determining Maximum Length of Quad Trunk for PID Gateway (no
horn/strobes)
13-9
FOCUS 200 PLUS Installation and Setup Guide
1000
900
800
Horn/Strobe Load (ma)
700
600
10.2V
500
10.1V
400
10.0V
300
9.9V
200
9.8V
100
9.7V
0
0 100 200 300 400 500 600 700
Maximum Length of Gateway Trunk (feet)
Figure 13-5: Determining the Maximum Length of Quad Trunk for SIM/PID Gateway with
Horn/Strobes
13-10
Section 13 – Power Requirements
1. In table 5, enter devices used on the RS-485 Bus #1. Calculate standby and alarm currents, then
add to get RS-485 Bus #1 current subtotal.
Table 5: RS-485 BUS #1 CURRENT LOAD
Total Current
2. In table 6, enter devices used on the RS-485 Bus #2. Calculate standby and alarm currents, then
add to get RS-485 Bus #2 current subtotal.
Table 6: RS-485 BUS #2 CURRENT LOAD
Total Current
13-11
FOCUS 200 PLUS Installation and Setup Guide
3. In table 7, enter devices connected to Auxiliary Relay (if used for wet operation). Calculate standby
and alarm currents, then add to get Auxiliary Relay current subtotal.
Table 7: AUXILIARY RELAY CURRENT LOAD
Total Current
4. In table 8, enter devices connected to Bell 1 output. Calculate alarm currents, then add to get Bell
1 output current subtotal.
Table 8: BELL 1 OUTPUT CURRENT LOAD
Total Current
XXXXXX
XXXXXX
XXXXXX
XXXXXX
XXXXXX
XXXXXX
XXXXXX
13-12
Section 13 – Power Requirements
5. In table 9, enter devices connected to Bell 2 output. Calculate alarm currents, then add to get Bell
2 output current subtotal.
Table 9: BELL 2 OUTPUT CURRENT LOAD
Total Current
XXXXXX
XXXXXX
XXXXXX
XXXXXX
XXXXXX
XXXXXX
XXXXXX
6. In table 10, enter the total calculated subtotals of all listed outputs from Tables 5 through 9, then
add to get the combined current.
Table 10: TOTAL PERIPHERAL CURRENT LOAD
Standby Alarm
7. Compare the values calculated above with the values from the table in AC Transformer Alarm
Current and Battery Size Limits and Table 11. If the 50VA transformer limits are exceeded, then
use a 72VA transformer. If the 72VA transformer limits are exceeded, then use a supplementary
power supply to carry some of the current load.
13-13
FOCUS 200 PLUS Installation and Setup Guide
Total 11: STANDBY CURRENT LIMITS
8. After deciding which devices will be carried by the supplementary power supply, if used, revise the
Tables 5 through 10 in steps 1-6 to reflect the total control unit peripheral standby and alarm
currents.
Standby Alarm
5mA 15mA
*472402A Backup Dialer Module
(inactive) (active)
*472402A actually draws 55mA when active. However, because FOCUS 200 PLUS PCB current
includes the built-in main dialer, and because the main dialer is inactive when 472402A is active,
472402A imposes only 15mA added current on the FOCUS 200 PLUS power supply.
Enter the calculated combined current, then add to calculate total battery current.
Standby Alarm
13-14
Section 13 – Power Requirements
Calculated
Capacity Formula
Value
Standby Capacity For 4-hour standby time:
Total standby current X 4 hours X 1.4 contingency factor.
For 24-, 60-, or 72-hour standby time:
Total standby current X (24 hours) X 1.1 contingency factor.
(60 hours)
(72 hours)
Alarm Capacity For 4-, 5-, or 15-minute alarm time
Total alarm current X 0.067 (4 minutes)
0.083 hours (5 minutes)
0.250 hours (15 minutes)
13-15
FOCUS 200 PLUS Installation and Setup Guide
To install the power supply, perform the following steps:
Step Action
1 Cut the + 12V (red) wire of the incoming RS-485 bus, and insulate the end of this wire so it
will not short to any other component in the system.
2 Connect the + 12V output of the power supply to Terminals 1 (common ground) and 2 (+
12V) of the gateway and continue to the next device on the RS-485 bus (if necessary).
Note: Use terminal 1 to connect the two incoming common ground wires (one from
incoming bus and one from power supply) and to connect an outgoing common ground wire.
3 Connect the supervisory contacts of the power supply to the monitoring terminals of a SIM
(or PID) to provide supervision of the + 12V power.
Note: The power supply will provide power to the remaining section of the quad trunk and
also float-charge its standby battery.
4 Assemble the power supply according to the instructions accompanying the power supply.
The 120VAC circuit that the transformer is connected to should be dedicated to powering the control
unit, should provide power continuously for 24 hours, and should not be controlled by a wall switch.
Connecting the Transformer
To connect the transformer to the control unit, perform the following steps:
Step Action
1 Make sure the power switch on the control unit is in the OFF position.
2 Identify the circuit breaker or fuse controling the circuit furnishing power to the control
unit. Make sure it is in the OFF position. Use a 326670(2667) AC Power Switch Shielding
Kit to protect the circuit breaker from inadvertent operation. Where fuses are used, mark
the fuse label to indicate that it must not be removed except for replacement purposes.
3 If you are using the wired-in transformer, mount its enclosure to the wall near the
control unit, using the 4 mounting holes on the enclosure's rear surface.
4 Run 120VAC wire from the circuit breaker or fuse to the enclosure in conduit. Use wire
having insulation rated for at least 90°C operation. Use wire nuts to splice the 120VAC
wires to the transformer's white and black primary leads.
5 Run 16 AWG wire from the transformer's to the control unit. Use wire that has insulation
rated for at least 90°C operation and is suitable for non-power limited applications.
6 Route the wire through a knockout on the left-hand side of the control unit's enclosure. Tie-
wrap it to a tie-wrap loop near the knockout to separate it from other power-limited wiring.
7 Connect the wires to the transformer's blue secondary leads, using wire nuts. Connect the
other end of the wire run to the control unit's AC terminals 1 and 2.
8 If you are using the plug-in transformer, run 16 AWG wire from the transformer's
location to the control unit.
9 Connect the wire to the transformer and to the control unit's AC terminals 1 and 2.
13-16
Section 13 – Power Requirements
The control unit requires the earth ground connection in order for its lightning transient protection devices
and earth ground supervision to function properly.
13-17
FOCUS 200 PLUS Installation and Setup Guide
Battery Supervision
The FOCUS 200 PLUS System provides three supervisory functions associated with the control unit
battery:
• Process alarms with low battery option.
• Integral battery cutoff relay.
• Supervision of the battery leads.
Process Alarms with Low Battery Option is a battery check made under load in each of three instances:
• Every 24 hours.
• When any BA group is turned off.
• Any time that an AC Fail condition occurs.
The check consists of reducing the battery float charging voltage to cause the battery to power the load
for 1 minute. If, during this time, the battery drops below approximately 12.0 volts:
• A low-battery signal is sent to the CCC and a low-battery message is shown at the operating
panels.
• Ordinarily, system operation ceases at this time and there is no further signaling to the CCC.
However, if this option is selected, it allows the control unit to continue processing and sending
signals until the battery voltage drops to the point where the battery cut-off relay operates (next
item), thereby extending normal operation for several hours, depending on the size of the battery.
The low battery condition is stored in control unit memory for subsequent printout along with the
time and date. When AC power is restored (battery voltage rises above approximately 12.3 volts), a
battery restore signal is transmitted to the CCC.
NOTE: Normally the system cannot be turned on if a Low Battery condition is present. There is an
option to enable turning on the system (arming) with a Low Battery condition present. This option
can only be programmed via the ADEMCO Compass Downloader. Also, be sure to enable the
system to process alarms with a low battery present, if desired, via the downloader.
• There is a built-in battery cut-off relay that serves to protect the battery against deep discharge. If
the voltage drops to approximately 9.8 volts, the relay disconnects the battery from its load to
prevent deep discharge of the battery. At this point, all processing and transmission of signals
cease.
• There is an automatic check for the connection of the battery leads, which is required by FM and
with the latest revision of NFPA 72. The check involves momentarily turning off the battery charge
voltage and measuring the voltage where the leads are connected to the circuit board. If the check
shows that the battery is missing for 45 seconds, the operating panel will display:
Also, a battery-lead-disconnect signal is transmitted to the CCC. A battery restore signal is transmitted
when the leads are reconnected.
13-18
Section 13 – Power Requirements
13-19
FOCUS 200 PLUS Installation and Setup Guide
13-20
S E C T I O N 1 4
In This Section
♦ About the Input and Output Point Types ♦ Output Point Types
♦ Input Point Types
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
The built-in hardwire points (1-8) may only be programmed with an input point type.
The following table lists the program entry, explanation of the function of the input type points and the options
associated with each type. At the end of this list you will find an explanation of each of the options.
Entry Description Function Opt. 1 Opt. 2 Opt. 3
1 (FI) Fixed Assigned to points where alarms and troubles are to 24-Hour NC Self Test
Alarm Contact
(permanent) be monitored by the control unit at all times,
regardless of the Day/Nite-Set status of the system.
• During Day Set, a cross or open is processed as a
trouble condition.
• During Nite Set, any off-normal condition is
processed as an alarm.
The alarm or trouble condition is transmitted to the
CCC and causes local annunciation. Examples of
sensors employed are glassbreak detectors, foil, and
lacing (the latter two require a PID gateway).
2 (MI) Movable Assigned to points where alarms are processed only Janitor NC Self-Test
Contact
Instant during the Nite-Set period, such as door contacts and
infrared and photoelectric sensors.
• During Day Set, an open (if you are using transfer
contacts) is processed as a trouble condition and is
annunciated locally and transmitted to the CCC.
During Nite Set, a cross or open will result in an
alarm signal to the CCC.
14-1
FOCUS 200 PLUS Installation and Setup Guide
UL Entry delay must not exceed 45 seconds for all UL certified installations.
14-2
Section 14 – Input and Output Point Types
8 (MDC) Movable This type is similar to the movable instant chime, but Janitor NC Self-Test
Contact
Delayed it is used for a point in the entrance/exit path.
Chime
9 (FA) Fire Alarm The point type is monitored for an alarm and trouble Smoke Self-Test
Detector
at all times. An alarm or trouble condition is Reset
annunciated locally and a signal is sent to the CCC.
Note: Where a Style D (Class-A) loop is required use
points 3 and 4, or the 471881(7187-011) Retrofit Fire
Alarm PID Module.
The system can be programmed for fire with verification. An initial short on the point causes an 8-second
smoke detector power reset. A subsequent short on the point within 30 seconds of the reset causes a fire
alarm. When this option is enabled ALL fire points in the system will perform the verification. This option
can only be enabled via the ADEMCO Compass Downloader.
11 (HU) Holdup The point type is monitored for cross at all times, Suspicion NC Latch
Contact
permitting the use of devices with normally open
contacts. If the option for normally closed contacts is
selected, then break-only contacts may be used.
Operation of the holdup device results in a Holdup
Alarm, except upon the occurrence of an open when
the holdup suspicion option is selected.
12 (MED) Medical This point type is used for devices that trigger medical NC Self-Test
Contact
emergency situations. The point is monitored on a 24-
hour basis for an alarm or trouble condition.
14-3
FOCUS 200 PLUS Installation and Setup Guide
28 (JAN) Janitor This point type is used for controlling the bypassing of LED Buzzer
(Y/N) (Y/N)
Keyswitch those BA points that have been optionally selected as
janitor points, and requires the connection of a 471999
(7187-113) Janitor Keyswitch, via a Switch Interface
Module.
Operating the Janitor Keyswitch during the Nite Set
period causes the bypassing action, thereby
permitting cleaning personnel to move about and trip
movable protection devices without creating an alarm.
It also causes a Janitor On Premises signal to be sent
to the CCC. Restoring the keyswitch removes the
bypass and causes a Janitor Off Premises signal to be
sent to the CCC.
Note: This point must be assigned to the same BA
group having the entry/exit path so the Janitor
Keyswitch may be accessed. When the janitor turns
the key, in addition to the bypass action, it aborts the
entry delay for the assigned BA group. When the key
is removed, it starts the exit delay as well as removes
the shunting action.
29 (KEY) BA Keyswitch This point type is used for turning a BA group to Day LED Buzzer
(Y/N) (Y/N)
Set or Nite Set rather than using an operating panel.
It requires the connection of a 471998(7187-112)
Remote Keyswitch via a Switch Interface Module SCN
471999. Operating the keyswitch causes an open or
close signal along with the number of the BA group to
be sent to the CCC.
30 (RPS) Remote This point type is used for monitoring a remote power
Power Supply supply (e.g., 472381 Power Unit). A loss of AC power
to the power supply is annunciated locally at an
operating panel. If the loss of AC extends beyond 4
hours, it causes an AC Fail signal to be transmitted to
the CCC. However, a low-battery condition, operation
of a tamper, or a point comm fail causes a local trouble
annunciation and immediate transmission of a signal
to the CCC.
31 (END) BA End Delay This point type is intended primarily for European
applications and requires the use of a switch to
terminate any exit delay time that remains when the
customer closes the exit door. A 471997 Switch
Interface Module and appropriate controlling switch
are used for this purpose.
Note: Program a maximum exit delay (255 seconds)
for the associated BA group to ensure the customer
adequate time for exiting the premises. Additionally,
select the Auto Bell Test option to provide an audible
indication for the persons exiting the premises that
the exit delay has expired.
14-4
Section 14 – Input and Output Point Types
14-5
FOCUS 200 PLUS Installation and Setup Guide
14-6
Section 14 – Input and Output Point Types
Person With Janitor Privilege
User Action BA Groups LED Status Result
Status
On On Indicates BA groups are On.
Entry
Janitor uses the coded Normal Slow flashing (1-sec Indicates Janitor points in all BA
key/card and unlocks the door. On/2-sec Off). groups have become alarm shunted.
Exit
Janitor exits and presses the Normal Changes from slow to 1-minute window starts.
pushbutton. fast flashing (1-sec
On/1-sec Off).
Not Ready Remains slow Indicates BA groups are not normal.
flashing.
Janitor exits and presses the Normal Changes to On steady. Indicates alarm shunt has been
pushbutton, closes the door, removed from each Janitor point in
uses the coded key/card (or system and BA groups are On.
Janitor Keyswitch).
Note: The door must be closed and
locked before using the
passcode/keycode.
Janitor closes the door, but Normal At end of 1-minute Indicates BA groups are On, but
forgets to use the coded window goes to a slow Janitor points in each group are still
key/card (or Janitor flashing condition. alarm shunted.
Keyswitch).
14-7
FOCUS 200 PLUS Installation and Setup Guide
Point Link Select which point, if any the point is linked to.
14-8
Section 14 – Input and Output Point Types
Option 1 Function
Janitor Select whether the point automatically becomes alarm shunted during Nite Set if
a Janitor Keyswitch is operated.
Smoke Power Enabling this option causes the system to remove power from the smoke detector
Reset for 6 seconds when a Reset Alarm command is entered at an operating panel.
Holdup If you are using the holdup suspicion option, a separate device with normally-
Suspicion closed contacts can be installed in the holdup loop to open the loop to trigger a
Holdup Suspicion output point (SIM or COPID), thereby actuating a camera for a
few seconds without initiating a holdup alarm. If the suspicious switch is held
open for more than 1 minute, a trouble signal is initiated. A latch option (option
3) is available that permits the use of a device with momentary contacts to
initiate the alarm.
Log Whether an access control occurrence will be logged in the system’s history log.
24-Hour Alarm Selecting this option enables the point to cause an alarm even when the system is
turned off (Day set).
Option 2 Function
Normally Whether a sensor with a normally-closed contact is being used.
Closed An open in the wiring of a hardwired point or the SIM/PID loop will be ignored
Contact during Day Set, but interpreted as an alarm during Nite Set.
NOTE: If a point type normally produces a trouble during the Day Set, that
condition will not be ignored.
For ALL BA RF points, this option must be set for YES.
LED This is used exclusively for the Janitor or BA keyswitch. If the SIM device is
connected to the LED, enable this option.
Option 3 Function
Self-Test Whether self-testing will be used. This pertains to sensors with a built-in SIM
with self-test capability.
Selecting the bell and display test at the operating panel causes a 30-second +
12V signal to be sent to the sensor with this option. In response, the sensor
performs a self-test.
The results can be viewed on the operating panel screen (History). Selecting this
option is a trade-off for the ability to load shed and also for resetting a latching
sensor that requires the removal of power to reset.
Latch Whether a latching or momentary contact is used on the loop to initiate an alarm.
SIM Whether the pushbutton will be connected to a SIM Gateway. In that case, the
LED goes on when the pushbutton is pressed and remains on for the duration of
the unlock time. It also goes on whenever a card/key is used to gain access at this
door.
Buzzer This is used exclusively for the Janitor or BA keyswitch. If the SIM device is
connected to the buzzer, enable this option.
14-9
FOCUS 200 PLUS Installation and Setup Guide
15 (SMC) Service Output turns on the first time a valid service ID code Complement Comm
Fail
is entered at an operating panel (ADT on-premises),
and turns off when an ADT off- premises signal is
initiated by selecting RESET~ ADT OFF at the
operating panel.
16 (TFC) Telco Fault Output turns on if a telco fault condition occurs (low Complement Comm
Fail
voltage or current, or loss of interrogation on AC telco
line). The output turns off when the telco line becomes
normal.
17 (SCC) BA Schedule Output turns on at the start of the scheduled open Complement Comm
Fail
period for a designated BA group, and turns off when
the close schedule starts.
18 (LTC) BA Lights Output turns on when the protection of a pre-selected Complement Remain Comm
On Fail
BA group is turned off, or the entry/exit delay period
is activated. The output turns off when the protection
of a BA group is turned on.
Note: If the Recycle Exit Delay is enabled, the output
turns on whenever any key is pressed on the operating
panel.
19 (FXC) BA Fixed Output turns on when any BA Fixed or Fixed Local Complement Comm
Fail
type point goes into alarm or, during Day Set, an
Instant Daytime Annunciation type point goes into
alarm. Output turns off when a valid ID code is
entered at any operating panel.
20 (OFC) BA Off Output turns on when the protection of a selected BA Complement Comm
Fail
group is turned off, and turns off when the protection
is turned on.
21 (FAC) Fire Output turns on and latches when any fire type point Complement Silence
in the system goes into alarm. The output turns off
when the alarm condition has been cleared and the
fire alarm is reset.
22 (SPC) Supervisory Output turns on if any supervisory type point goes Complement Comm
Fail
into alarm, and turns off when the point restores.
14-10
Section 14 – Input and Output Point Types
14-11
FOCUS 200 PLUS Installation and Setup Guide
59 (ACD) Access This output point can be used to trigger a camera or Complement Comm
activate an annunciation device in the event that Fail
Denied
someone uses a card/key having a code that either:
• Is not in the system.
• Does not have Irregular Open, Open or Close
access to all BA groups associated with that
ACIU.
• Does not have the Irregular Open or Open option
for any of the associated BA groups that may be
On.
• Has a Close option and the person attempts to
enter outside of the scheduled open period even
though the associated protection is Off.
When the point is triggered, the output stays on for 10
seconds and then goes Off.
68 (ABA) Alarm in any This point type is normally off and turns on when an Complement Comm
alarm occurs in any BA group that is armed. The Fail
BA Group
output returns to the off condition when the BA group
with the alarm condition is changed to Day Set.
14-12
Section 14 – Input and Output Point Types
Output Point Options
The following table describes the output point options:
Options for
Function
All Types
BA Group The number of the BA group that the point will be assigned to.
Assignment
Bypass Whether bypassing will be permitted by persons with an ID code having a
bypassing privilege.
Point Link Select which point, if any the point is linked to.
Option 1 Function
Complement Selecting this option causes the turn-on and turn-off conditions of the output
point to be reversed. In other words, if the output is turned on upon detection of
the condition being monitored, it will instead be normally on, and turn off when
that condition is detected.
Strobe Select if a strobe will be used for the point in place of a bell, in which case the
strobe will flash continuously for an alarm.
Inhibit BA Selecting this option prevents the horn from annunciating a BA alarm.
Option 2 Function
Off Normal Enabling this option causes the output to turn on for any off normal condition on
Condition the system.
Output Link Select this option if the output will follow the status of a designated output point.
Common BA Select this option if the bell is turned on by an alarm in only one BA group, or an
alarm in any one of a series of BA groups.
If a series of BA groups is selected, then the BA group that is selected is the
starting point for the series. For example, if there are 8 BA groups and the
number 3 is selected, then an alarm in any BA group from BA3 through BA8 will
trigger the bell, but not an alarm in BA1 or BA2.
Remain On Select this option to keep the output on during a group entry or exit delay period.
Option 3 Function
Silence Ordinarily, the output does not unlatch unless the alarm-initiating sensor has
cleared and the alarm has been reset. If the Silence option is selected, the output
unlatches when a valid code (or Fire Marshall Code 2,2,2,2,2,2) is entered.
Code 3 The Horn/Strobe point is intended primarily to annunciate a fire alarm, but the
horn can also be used to sound for a burglar alarm.
If this option is selected, the horn sounds for an NFPA temporal pattern (¼-
second on, ¼-second off, for 3 seconds, followed by 1 second of silence).
Because these transmissions occupy a segment of the overall time allocated for
control unit interrogation and response messages, as well as other functions that
are performed by the control unit, the number of horn/strobes is limited to 5 per
SIM gateway and 20 per system. These numbers can be increased to 10 per SIM
gateway and 40 per system by selecting Option 1 (inhibit BA) for each
Horn/Strobe point, thereby preventing the horns from sounding for a BA alarm.
If this is done, the control unit will no longer generate the temporal pattern.
Instead, the DIP switches on each horn/strobe must be programmed to generate
the temporal pattern in accordance with the manufacturer’s instructions.
Comm Fail Selecting this option causes the output to activate only if a Communication
Failure on the dialer condition is present.
Activate When Selecting this option causes the output to activate only if the system is turned on.
Turned On
14-13
FOCUS 200 PLUS Installation and Setup Guide
Types of Input Points and Associated Options
Input Point Type Mnc∗ No. Link Group Bypass Option 1 Option 2 ∗∗∗∗ Option 3
BA Fixed FI 1 ∗∗ 1 thru 8 Y/N 24-Hour Alarm NC Contact (Y/N) Self Test
(Y/N)
BA Movable Instant MI 2 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
BA Movable Delayed MD 3 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
BA Fixed Local FL 4 ∗∗ 1 thru 8 Y/N — NC Contact (Y/N) Self Test
(Y/N)
BA Movable Instant MID 5 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
Daytime Annunciation (Y/N)
BA VVS VVS 6 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
BA Movable Instant MIC 7 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
Chime (Y/N)
BA Movable Delayed MDC 8 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
Chime (Y/N)
Fire FA 9 ∗∗ 1 ∗∗∗ Y/N Smoke Reset Self Test
(Y/N) (Y/N)
Holdup Special HUS 10 ∗∗ 1 ∗∗∗ Y/N Suspicion NC Contact (Y/N) Latch
(Y/N) (Y/N)
Holdup HU 11 ∗∗ 1 ∗∗∗ Y/N Suspicion NC Contact (Y/N) Latch
(Y/N) (Y/N)
Medical MED 12 ∗∗ 1 ∗∗∗ Y/N — NC Contact (Y/N) Self Test
(Y/N)
Supervisory SPV 13 ∗∗ 1 ∗∗∗ Y/N — NC Contact (Y/N) Self Test
(Y/N)
Janitor Keyswitch JAN 28 ∗∗ 1 thru 8 Y/N — LED (Y/N) Buzzer
(Y/N)
BA Keyswitch KEY 29 ∗∗ 1 thru 8 Y/N — LED (Y/N) Buzzer
(Y/N)
Remote Power Supply RPS 30 ∗∗ 1 thru 8 Y/N — — —
BA End Delay END 31 ∗∗ 1 thru 8 Y/N — — —
BA Blocklock-PID only BLK 32 ∗∗ 1 thru 8 Y/N — — —
Ambush Start ABS 35 ∗∗ 1 ∗∗∗ Y/N — NC Contact (Y/N) —
Ambush End ABE 36 ∗∗ 1 ∗∗∗ Y/N — — —
Waterflow WF 49 ∗∗ 1 ∗∗∗ Y/N — — —
Manual Access MAP 60 ∗∗ 1 thru 8 Y/N Log (Y/N) NC Contact (Y/N) SIM (Y/N)
Pushbutton
Exit Pushbutton EXP 64 ∗∗ 1 thru 8 Y/N — NC Contact (Y/N) SIM (Y/N)
Arming ARM 65 ∗∗ 1 thru 8 Y/N — NC Contact (Y/N) —
Disarm DAR 66 ∗∗ 1 thru 8 Y/N — NC Contact (Y/N) —
No Alarm Response NAR 67 ∗∗ 1 thru 8 Y/N — NC Contact (Y/N) SIM (Y/N)
Carbon Monoxide CO 69 ∗∗ 1 ∗∗∗ Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
Movable Instant Stay MIS 70 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
Movable Instant PIR MIP 71 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
Movable Delayed Stay MDS 72 ∗∗ 1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test
(Y/N)
∗ Mnemonic
∗∗ If using point-link function, enter the number of point that this point will be linked to.
∗∗∗ Point type must be assigned to a BA group (BA1), otherwise point will cause an FA fault annunciation.
∗∗∗∗ For RF Fire Points, this option must be set for NO. For RF Burglary Points, this option must be set for YES.
14-14
Section 14 – Input and Output Point Types
Types of Output Points and Associated Options
Output Point Type Mnc∗ No. Link Group Bypass Option 1 Option 2 Option 3
Central Station AC CSC 14 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
Service Mode SMC 15 — 1 ∗∗∗ Y/N Complement — COMM
(Y/N) Fail (Y/N)
Telco Fault TFC 16 — 1 ∗∗∗ Y/N Complement — COMM
(Y/N) Fail (Y/N)
BA Schedule SCC 17 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
BA Lights LTC 18 — 1 thru 8 Y/N Complement Remain On COMM
(Y/N) (Y/N) Fail (Y/N)
BA Fixed FXC 19 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
BA Off OFC 20 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
Fire FAC 21 — 1 ∗∗∗ Y/N Complement — Silence
(Y/N) (Y/N)
Supervisory SPC 22 — 1 ∗∗∗ Y/N Complement — COMM
(Y/N) Fail (Y/N)
Holdup HUC 23 — 1 ∗∗∗ Y/N Complement — COMM
(Y/N) Fail (Y/N)
Holdup Suspicion HSC 24 — 1 ∗∗∗ Y/N Complement — COMM
(Y/N) Fail (Y/N)
BA Remote Sonalert RSC 25 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
BA Bell and Vault Sensor TSC 26 — 1 thru 8 Y/N Complement — COMM
Test (Y/N) Fail (Y/N)
Remote Bell-PID only RBL 27 — 1 thru 8 Y/N Strobe (Y/N) Common BA —
(Y/N)
System Trouble STC 33 — 1 ∗∗∗ Y/N Complement Off Normal COMM
(Y/N) (Y/N) Fail (Y/N)
Point Link PLC 34 ∗∗ 1 ∗∗∗ Y/N Complement Output Link Activate
(Y/N) (Y/N) When On
BA Access ACC 37 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
Horn/Strobe-SIM only HST 38 — 1 thru 8 Y/N Inhibit BA Common BA Code
(Y/N) (Y/N) (Y/N)
AC Fail PRC 40 — 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
Access Denied ACD 59 ∗∗ 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
Alarm in any BA Group ABA 68 ∗∗ 1 thru 8 Y/N Complement — COMM
(Y/N) Fail (Y/N)
∗ Mnemonic
∗∗ If using point-link function, enter the number of point that this point will be linked to.
∗∗∗ Point type must be assigned to a BA group (BA1), otherwise point will cause an FA fault annunciation.
14-15
FOCUS 200 PLUS Installation and Setup Guide
14-16
S E C T I O N 1 5
Programming
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About Programming the System ♦ Programming the BA Groups’ Turn-Off Data
♦ Mechanics of Programming ♦ Programming the System Communication
Options
♦ Programming Names for the BA Groups
♦ Programming Point Data
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Point Data
Point data is the information associated with point of protection in the system. This data includes:
• The Hard ID Number
• The name of the point (descriptor)
• The point type
• The associated BA group
• Whether the point is linked to another point
• Whether the point can be bypassed
• The communication unit number
Descriptors
Descriptors are user-selected descriptive names. A user with a valid ID code and the appropriate
privilege level may at any time change the descriptors. Descriptors may be programmed for:
• Each BA group
• Each point of protection
• Each person assigned an ID code
• Each holiday in the holiday schedule
User ID Codes
The ID codes are user-selected, and are used to operate the system. See the ID Codes section for the
detailed programming procedure for entering the ID codes into the system.
15-1
FOCUS 200 PLUS Installation and Setup Guide
Mechanics of Programming
The operating panel provides an interactive display that operates in a manner similar to an automatic
teller machine (ATM). It employs a 19-character, four-line LCD display that shows menu selections,
message prompts, and help screens to guide you through the various operating procedures. Menu items
and other selectable choices are shown on the screen with an arrow (>) that lines up with one of the
four "Selector" buttons on each side of the screen. You make a choice by pressing the button alongside
the item shown on the screen.
Programming of the system is done by selecting a course of action from menu items that appear on a
series of screens known as Action Menus. Entering the valid Service Code will cause the first of four
Action Menus to be displayed. The Action Menus are the starting point for performing all programming
operations.
In order to access the Action Menus, the protection for the BA group associated with the operating panel
where the Service Code is entered must be Off.
<? GROUP #1 Group Info Screen is displayed. The default display shows the
Group 1 info for Group #1.
< Prev Change > The top line shows the current name. The second line shows the
< Quit Next > group to which this info pertains.
Select Next to display the info screen for Group #2. Select Next
again to display the info screen for Group #3, etc. Select Prev to
display the previous group’s info.
Select Change to move to the Character Entry Screen for the
group displayed.
<? GROUP #1 The cursor is under the first letter of the current name for the
Group 1 Done > group. Use the third key down on each side to move either Back or
< Back CHR Forward > Forward through the alphabet. Use the bottom key on each side to
move the cursor position either Left or Right through the name.
< Left POS Right >
Select Done to save the current name displayed. The system
displays the Group Info Screen.
Program all group names by selecting either Next or Prev to move
to another group.
Select Quit twice to exit the program mode.
15-2
Section 15 – Programming
15-3
FOCUS 200 PLUS Installation and Setup Guide
< ? FRONT DOOR 20 Select Enter to save this info and then select Continue to move to
Type MD Continue > the next screen.
Type – 0 3
< Previous Enter >
15-5
FOCUS 200 PLUS Installation and Setup Guide
< ? FRONT DOOR 20 Select Enter and then Continue to save this info and move to the
Gate 1 Continue > next screen.
POINT GATEWAY
< Previous Enter >
15-6
Section 15 – Programming
< ? BA GROUP #1 Group Info Screen. The system defaults to display the info for
Group #1. The top line shows the current name. The second line
Group 1
shows the group to which this info pertains.
< Previous Change >
< Quit Next > Select Next repeatedly until the info screen for Group #8 is shown.
Select Next once more to advance to the next screen.
< ? Grp0 Ut0 Keypad This screen shows which BA Groups will be automatically opened
(turned off) when a valid ID Code is entered at the operating panel
< BA-❙ ❙ ❙ ❙ ❙ ❙ ❙ ❙
indicated.
< Previous Change >
Select Change to edit the selections. Enter the number of each BA
< Quit Next > Group that will turn off. Entering the number again will erase the
selection.
Select Next to move to the operating panel at the next address on
the RS-485 bus.
Continue until all operating panels have been programmed.
< ? Grp4 Ut0 Cardrdr Selecting Next at the last operating panel will bring you to this
screen.
< BA-❙ ❙ ❙ ❙ ❙ ❙ ❙ ❙ Lg (N) >
This screen is same as the one for the operating panels, except this
< Previous Change >
is for BA Groups linked to card/key readers.
< Quit Next >
Select Change to edit the selections.
Select Next to move to the card/key reader at the next address on
the RS-485 bus.
Selecting Lg will toggle between Yes (Y) and No (N) to log
successful attempts, unsuccessful attempts, openings, and closings
at this card/key reader in the history log.
Selecting Next at the screen showing the last card/key reader will
bring you to the Point Data Info Screen.
Select Quit to return to Action Menu #4.
15-7
FOCUS 200 PLUS Installation and Setup Guide
15-8
Section 15 – Programming
15-9
FOCUS 200 PLUS Installation and Setup Guide
15-10
S E C T I O N 1 6
Scheduling
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About Scheduling ♦ Holiday Schedules
♦ Permanent Schedules ♦ Ambush Schedules
♦ Temporary Schedules ♦ Schedule Options
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
About Scheduling
Scheduling is used to:
• Automate openings and closings.
• Limit access to the system.
• Set the time limit for the Ambush Points.
• Automate the associated scheduling reports to the Customer Care Center (CCC).
The FOCUS 200 PLUS system utilizes permanent, temporary, and holiday schedules. Time windows
(time periods) are used to define the schedules. Each BA group can be assigned its own schedules.
UL Automatic openings and closings may not be used on UL Burglary alarm systems.
Opening/Closing Schedules
The opening and closing schedules define the time windows that a BA group will automatically turn on
and off, and when users may access the BA group. There are two permanent and two temporary
schedules that can be assigned to each BA group. The temporary schedule will override an existing
permanent schedule. Additionally, a holiday schedule can be assigned to the BA group and it will
override the permanent schedule, but not the temporary schedule.
Only users with the appropriate privilege levels can establish or change the permanent and temporary
schedules. The holiday schedule is typically established at the time of installation.
The ability to use any form of automatic opening or closing is controlled by a separate Automatic
Open/Close Enable option that may only be set via the downloader.
16-1
FOCUS 200 PLUS Installation and Setup Guide
Permanent Schedules
The permanent schedule has two open and close times that can be programmed for each day in the
week. The times can be changed only by someone who has an ID code with the privilege to change a
permanent schedule. This privilege also permits a person to make changes in real time.
Programming
Day of Schedule Result
Entry
Monday First 21:00 PM This starts the open period time window (9:00 PM) for
Opening Time Monday.
Monday First UUUU This inhibits "close reminder/warning" and "no close" from
Closing Time occurring because the premises will not close on Monday.
Tuesday First 12:00 AM This entry is needed because the open time period was
Opening Time started on Monday and allows any closing time to be entered
for Tuesday.
Tuesday First 01:00 AM This completes the time window that started at 9:00 PM on
Closing Time Monday.
Tuesday Second 21:00 PM This starts the open period time window (9:00 PM) for
Opening Time Tuesday.
Tuesday Second UUUU This inhibits "close reminder/warning" and "no close" from
Closing Time occurring because the premises will not close a second time
on Tuesday.
Wednesday First 12:00 AM This entry is needed because the open time period was
Opening Time started on Tuesday and allows any closing time to be entered
for Wednesday.
Wednesday First 01:00 AM This completes the time window that started at 9:00 PM on
Closing Time Tuesday.
16-2
Section 16 – Scheduling
Programming
Day of Schedule Result
Entry
Wednesday Second 21:00 PM This starts the open period time window (9:00 PM) for
Opening Time Wednesday.
Wednesday Second UUUU This inhibits "close reminder/warning" and "no close" from
Closing Time occurring because the premises will not close a second time
on Wednesday.
Repeat the same four entries for each day of the rest of
the week, up to and including Saturday.
Sunday First 12:00 AM This entry is needed because the open time period was
Opening Time started on Saturday and allows any closing time to be entered
for Sunday.
Sunday First Closing 01:00 AM This completes the time window that started at 9:00 PM on
Time Saturday.
Sunday Second UUUU There will not be an open time window because the premises
Opening Time will not open on Sunday.
Sunday Second UUUU This inhibits "close reminder/warning" and "no close" from
Closing Time occurring because the premises will not close on Sunday.
(This completes the schedule for the entire week).
Temporary Schedules
The temporary schedule is not ordinarily set up for a new installation. Instead, when needed, it is
usually entered at an operating panel or downline loaded upon customer request.
A temporary schedule:
• Has open and close times that can be assigned up to 6 days in advance.
• Will override any permanent schedule in effect at the time.
• Can be used for a BA group even if the group does not have a permanent schedule.
• Includes entry options that are the same as the Permanent Schedule, except for NNNN, which
cannot be used.
• Will be voided at midnight, at which time the permanent schedule will become active again.
For example, a temporary schedule is programmed for Thursday that has an opening time of 7:00
AM and a closing time of 10:30 PM. This schedule will be canceled on Thursday at midnight. The
automatic cancellation is a precaution against someone forgetting to cancel a temporary schedule.
• Can be downline loaded from the central station, or can be entered locally at any operating panel.
Any permanent or temporary schedule can be downline loaded, regardless of the earliest-open or latest-
close time that has been programmed in the control unit.
16-3
FOCUS 200 PLUS Installation and Setup Guide
Holiday Schedules
The holiday schedule:
• Specifies each day during the year that the premises will be closed for the observance of a holiday.
• Overrides the permanent schedule for that day.
• Accommodates l4 days that are designated as holidays.
• Requires the programming of the month, day of the month, and name of the holiday.
• Can be overridden by a temporary schedule, if a BA group needs to be opened during the holiday.
It is important to complete this schedule, if you are using a permanent schedule to perform Auto
On/Off. If an Auto Off function has been selected and the holiday falls on what would otherwise be a
normal workday, the protection is not automatically turned off at the normal opening time. When
someone arrives and enters, expecting the system to be off, a false alarm is generated.
Ambush Schedule
An ambush schedule:
• Is used for an Ambush-Start point and an Ambush-End point as protection against hide-ins.
• Provides for two permanent schedule openings and closings per day.
• Provides for two temporary schedule openings and closings per day.
• Is programmed in the same way as the permanent and temporary schedules for each BA group.
• Operates independently of other schedules.
Open and close times for a given day should form a time window spanning the permanent schedule
open time to permit the customer to enter to prepare for the opening of the bank without creating an
alarm.
For an explanation of how an ambush schedule works, see the Ambush Start and End Input Point
Types in the Input and Output Point Types section.
Scheduling Options
The options associated with scheduling are outlined in the following table:
Option Function
Auto On/Off Auto On/Off may be convenient to use for an area where people come and go as
they please, and no one is responsible for turning the protection on or off.
The burglar alarm protection associated with each schedule can be:
• Turned on and off manually. • Turned on and off automatically.
• Turned on automatically and • Turned on manually and turned
turned off manually. off automatically.
Example: If auto-on/auto-off is selected for a given BA group, it automatically
goes to Nite Set at the scheduled closing time, and automatically goes to Day Set
at the scheduled opening time without anyone having to go to an operating panel.
The closing time reminder and warning sounder operate as a reminder to exit
However, there is no warning sound during the entry delay because the opening
is being done automatically.
Notes:
• The system performs the auto-on at the end of the warning time.
• Auto-On/Off may not be used in UL burglary alarm systems.
• The auto-on will not occur if there are faults on any sensors in the group
unless Force Auto-arm is enabled.
Early Open/ This establishes the earliest opening and latest closing times that can be used
Late Close each day for the permanent and temporary schedules for a given BA group.
Schedule This is intended for use with areas involving safes, vaults, or other high-security
Lockout areas where the operating panel is located outside of the protected area. It is
used to prevent a BA group from being turned Off when the present time is
outside the scheduled open period.
16-4
Section 16 – Scheduling
16-5
FOCUS 200 PLUS Installation and Setup Guide
16-6
S E C T I O N 1 7
Downline Loading
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About Downline Loading ♦ Downline Loading the Customized Data
♦ Programming the Control Unit for Downline ♦ Verifying the Downline Loaded Data
Loading
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
17-1
FOCUS 200 PLUS Installation and Setup Guide
<? Ser Term Phn # The Service Terminal Phone Number Screen is displayed.
________________> Enter the phone number where the ADEMCO Compass
downloading software is located. Select Pause and select (wait for)
< Pause Dial Tone >
Dial Tone as needed. Each Pause entry is three seconds. Up to 32
< Quit Enter > digits may be entered.
Note: The display can only show 16 digits at a time. If you need to
th
enter more than 16 digits, when the 17 digit is entered the display
automatically advances to display digits 17 through 32.
The arrow (>) at the right-hand side indicates you are entering
digits 1 through 16. The arrow at the left-hand side indicates digits
17 through 32.
Select Enter when you are finished entering the phone number.
Any digits after the cursor will be erased.
The Enter key then changes to Delete. Select Delete to erase the
displayed phone number.
Select Quit to save the displayed phone number and return to the
Communication Screen.
17-2
Section 17 – Downline Loading
To downline load the system, proceed as follows:
Step Action
1 Call the ADEMCO Compass downloading software. This is to ensure that there is a "Read
customer unit into the database" job waiting in the queue for system being installed.
Note: If there isn't a job waiting in the queue for the system being installed, the system
will perform an Unsolicited Upload.
2 Inform the ADEMCO Compass downloading software of the area code and telephone
number of the telephone line connected to the Main Line of the control unit. This is the
telephone number that the ADEMCO Compass downloading software will use whenever it
contacts the control unit.
3 At any operating panel, enter the Service Code, More, More, More, Load, Remote
DLL. The control unit will call the ADEMCO Compass downloading software, and the
control unit database will be uploaded to the ADEMCO Compass downloading software.
During the upload, the operating panel will display the following message:
Calling ADT to initiate changes.
The following message will be displayed if there is no job in the queue:
DLL aborted.
Except where the DLL has been aborted, no further action is required by the installer. The control
unit's data will be uploaded and any additional data required for the installation will be downloaded
back to the control unit, as indicated in the following table.
Stage What Happens
1 The operator at the ADEMCO Compass downloading software examines the uploaded data
and modifies it, as is applicable. The finalized set of customer data is then used to create
(or verify) the customer's database for MAXimation SM.
2 Using the control unit telephone number provided by the Installer in Step 2, the operator
at the ADEMCO Compass downloading software downloads the finalized database to the
control unit. During the download, as during all forms of communication, the main dialer
red LED on the control unit goes on.
3 After completion of the download, the control unit waits 5 seconds, dials the CCC (via the
receiver), and sends a "Start DLL" transmission to verify that the control unit can
communicate with the CCC over the alarm channel.
4 When the control unit has received an acknowledgement that the CCC has received the
"Start DLL" message, the communicator hangs up and dials the ADEMCO Compass
downloading software, which, in turn, sets an "activation byte" at the control unit.
Note: With the setting of the activation byte, any off-normal events that occur from this
point on are transmitted to the CCC.
5 After a successful DLL (activation byte set), the control unit automatically checks the
various points in the system, including the hard IDs and the point number. If there are any
discrepancies, a trouble is annunciated at the operating panel(s) and the point is identified.
Note: From this point on, during normal operation (system out of service mode) any sensor
that is removed or added will generate a trouble until the sensor and hard ID have been
properly entered into the database via the operating panel, or via downline loading.
17-3
FOCUS 200 PLUS Installation and Setup Guide
17-4
S E C T I O N 1 8
Real-Time Clock
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the Real-Time Clock ♦ Setting Daylight Saving Time
♦ Setting the Time and Date
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• If the system loses all power or is powered down for any reason, the clock must be reset. The clock
does not advance during the time the system does not have power connected.
• The Time Change Menu screen will not display if any group is armed.
<? Time & date The Current Time and Date Screen is displayed.
11:15:28 AM Select Change to change the current settings.
09–28-98 Select Quit to move back to the Time Screen without making any
< Quit Change > changes.
18-1
FOCUS 200 PLUS Installation and Setup Guide
<? Enter new time: This is the Enter New Time Screen.
Curr: 11:15 AM Enter the new time for the system. Be sure to make the correct
New: _ _:_ _ AM > AM/PM selection.
< Quit PM > Select Quit to return to the Current Time and Date Screen.
<? Enter new date: This is the Enter New Date Screen.
Curr: 09–28-98 Enter the new date for the system.
New: _ _-_ _-_ _ Select Enter to save the date displayed and return to the Current
< Quit Enter > Time and Date Screen.
Select Quit to return to the Current Time and Date Screen without
saving the new date.
<? Delete > This is the Enter New Daylight Saving Screen.
Curr: 00-00 Enter the new date.
New: _ _-_ _ Select Delete to erase any incorrect entries and return to the
< Quit Enter > Current Daylight Saving Screen.
Select Enter to save the date displayed and return to the Current
Daylight Saving Screen.
Select Quit to return to the Current Daylight Saving Screen
without saving the new date.
18-2
S E C T I O N 1 9
ID Codes
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About the ID Codes ♦ Duress Signal
♦ Service Code ♦ ID Code Programming
♦ Fire Marshall Code ♦ Summary of ID Code Capabilities and Privileges
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
ID Code Makeup
ID codes are made up of six digits. All six digits of an ID code are needed to access the system. The first
two digits of the ID code:
• Serve as the user number, and are numbered 01, 02, 03, etc., up to 99. Users, such as 01, 101, and
201 all use the same first two digits 01.
• Are used as passcodes by the CCC when identifying the person performing a function.
The last four digits of the ID code:
• Serve as a PIN (Person Identification Number).
• Uniquely identify the user and his assigned privileges to the system.
• Serve to identify the level of access.
Users with the same user code (first two digits) cannot use the same PIN (last four digits). For example,
user 25's PIN may be 1234; user 125's PIN 3456; and user 225's 5678. User 25 would enter 251234 to
access the system. User 125 would enter 253456. User 225 would enter 255678.
Be careful that a duress code is not inadvertently created. See Duress Signal later in this section for a
detailed explanation for how to create a Duress signal.
19-1
FOCUS 200 PLUS Installation and Setup Guide
• Bypass VVS sensors.
• Establish or change temporary schedules.
• Establish or change closing times in the BA group(s).
• Change the real-time clock +/- 5 minutes maximum.
• Establish or change permanent schedules and make unlimited changes to real time.
• Bypass fire alarm, holdup alarm, and supervisory points.
• Establish or change descriptors for ID codes, points, and BA groups.
• Establish or change ID codes' accessibility to BA groups.
The Service Mode privilege is assigned to all service codes, and is not made available to the customer.
Service Code
The Service Code is an ID code for use by ADT personnel when installing or working on a system, and
must be assigned by the local office. As a minimum, the Service Code must be assigned the "Can enter
service mode" privilege. Any additional privileges may be assigned to that ADT service person, as
required.
Entry of this code at an operating panel will:
• Place the FOCUS 200 PLUS system in the Service Mode.
• Bypass the cabinet tamper when "Service On".
• Cause an ADT-on-premises signal to be transmitted to the Customer Care Center (CCC).
• Lock out all other ID codes so that the system can be worked on without any customer interference.
The cabinet tamper is automatically bypassed when the system is placed in Service mode and
automatically unbypassed when the system is taken out of Service mode.
The Service Code(s) must be downline loaded from the ADEMCO Compass downloading software. In
order to allow the service person to get into the system to initiate a downline load on a new installation,
a Temporary Service Code (8,8,8,8,8,8) becomes active for the first minute after power-up. After this
first minute, the Temporary Code becomes disabled, and the downline loaded Service Code must be
used. Temporary Service Code is active for 1 minute each time that the control unit is powered up.
During that first 1 minute after power-up, entering Reset, Memory, Yes will cause the temporary service
code [8,8,8,8,8,8] to remain active until the system is downline loaded.
19-2
Section – 19 – ID Codes
Duress Signal
A duress signal is a silent alarm transmitted in the form of a holdup alarm signal to the CCC. The
control unit duress option must be enabled for a duress signal to be activated. To activate a duress
signal, the user enters the first 5 digits of the ID code as usual, but adds a value of two to the normal
number of the last digit.
For example, if the ID code is 2-2-4-5-6-7, enter 2-2-4-5-6-9 to activate a duress signal. If the last digit
of the PIN is 8, enter 0; if the last digit is 9, enter 1; if the last digit is 0, enter 2. The duress signal
works with any valid ID code regardless of the privilege level.
Be careful that a duress code is not inadvertently created when entering new ID codes. As an example,
if user 22's PIN is 4567, then make sure user 122's or 222's PIN is not 4569.
Programming ID Codes
The deletion, addition, or alteration of the PIN (last four digits) of an ID code and associated user name
can be performed at any operating panel by a user with an ID code having this privilege, or the change
can be downline loaded from the central station. Where PCS (Passcode Schedule Supervision) service is
involved (see the System Communication section), instruct the customer that ID code changes must be
controlled from the CCC because the CCC monitors those who perform BA group openings. With this
type of service, the CCC can prevent the customer from changing an ID code.
ID Code Programming Options
Programming options associated with each ID code are as follows:
Option Function
Code These are the last four digits of the ID code. They are entered alongside the two
digits that serve as the user number in order to make up the 6-digit ID code.
Group The choice of BA groups that the ID code will have access to. The selection can
include any combination of groups, including all groups.
Cancellation Date A cancellation date can be assigned to any ID code up to 365 days in advance.
Notes: The privilege "Can enter service mode" is reserved for ADT personnel and must not be
assigned to any ID code being used by the customer.
If an RF button is linked to a user code, when the user code cancel date expires the link is
severed. Entering a new cancel date does not re-establish the link to the RF button.
Adding or Changing an ID Code
To add or change an ID code, enter a user ID code with the privilege to change ID codes or enter the
Service code at an operating panel and perform the following:
19-3
FOCUS 200 PLUS Installation and Setup Guide
< PERSON #1 If you selected Change, the Person’s Name Screen is displayed.
< Back CHR Forward > The cursor is at the first letter of the current name for the user.
< Left POS Right > Use the second key down on each side to move either Back or
Forward through the alphabet. Use the third key down on each
< Quit Continue >
side to move the cursor position either Left or Right through the
name or insert a space.
Select Continue to save the current name displayed and move to
the next screen.
<? PERSON #1 This brings you to the first in a series of nine Person Access
Access irr & open Screens.
Select Change to scroll through the following four choices of
< ** BA Group 1
access:
< Change Continue >
1. Can access & open
2. Can not access
3. Can access
4. Access irr (irregular) & open
Select Continue to save the displayed access capability, and
advance to the first access screen for BA groups 2-8.
** Pressing the BA Group button at any of the Person Access
Screens brings you to the previous screen.
<? PERSON #1 Selecting Continue at BA Group 8 brings you to the next in the
Can not open irregular series of access screens. The series of access screens progress as
follows:
< BA Group 8
Can (not) open irregular
< Change Continue >
Can (not) bypass BA
Can (not) change temp sched
Can (not) change perm sched
Can (not) change names
Can (not) bypass FA/HU/SPV
Can (not) enter service mode
Can (not) be changed
Note: The Janitor privileges may be set up only via downline
loading.
Select Change to toggle a privilege between Can and Can not.
If the last access screen displays “Can not be changed,” selecting
Continue advances you to the Enrolling Key or Card Screen. See
the Access Control section for the procedure for enrolling cards
and/or keys.
If you are adding a new ID Code or changing an existing ID code,
make sure the last access screen displays “Can be changed.” Select
Continue and the system advances to “ID Code May Be Changed”
screen. Select Change at this access screen to advance to the Type
New User Screen.
19-4
Section – 19 – ID Codes
Protection On/Off
• Turn the protection On for one or any combination of BA groups.
• Turn the protection Off for one or any combination of BA groups (turnoff is automatic upon entry of
a valid code if the BA group is in entry delay or alarm).
• Establish automatic On and/or automatic Off schedule (if system option has been enabled).
Alarms/Point Status
• View the points of protection that are off-normal.
• Reset sensors at the various points of protection (provided sensors have restored to normal).
• Silence BA/FA sounding devices and operating panel sounder (by entering valid code).
• View contents of alarm memories.
• Restore alarm memories.
• Initiate printout or view contents of alarm memory log.
Schedules/Time
• Close late by temporarily changing the close time schedule for any BA group (for up to 6
consecutive days from the current day).
• Establish or change permanent opening and closing schedules for each BA group.
• Establish or change earliest time for opening and latest time for closing each BA group.
• Establish temporary opening and closing schedules for each BA group for a maximum of six
consecutive days.
• Establish automatic On and/or automatic Off schedule (if system option has been enabled).
• Establish or change the holiday schedules (holiday name and date).
• Establish or change a hostage schedule.
• Set and adjust time and date.
Note: There are two different privileges for changing time:
1. Allowed to change time by plus or minus 5 minutes in any day, but allowed to make a full
change when the system is first powered up.
2. Always allowed unlimited time changes. Entered values of digits for hours must not be 00 and
must not be greater than 12.
Bypassing
• Bypass any point(s) in the system.
• View points that are bypassed.
Any BA point that has been bypassed will automatically become unbypassed when the system is turned
from On to Off at the operating panel.
Special bypass of vault vibration sensor points will automatically become unbypassed at BA1 Latest Close
Time, or at midnight if Latest Close Time is not set.
Resetting
• Reset alarms.
• Reset results of walk tests and other sensor tests.
• Reset Memory (SRAM).
19-5
FOCUS 200 PLUS Installation and Setup Guide
ID Codes
• Establish or change ID codes.
• Establish or change privilege levels for ID codes.
• Establish or change BA group(s) assigned to an ID code.
• View ID code privilege levels and name of person associated with each code.
Testing
• Test the operating panel display and sounder and local bell.
• Walk-test the areas protected by motion detectors, and test door and window contacts.
• Test security groups before closing, and see any points that may be abnormal.
• View points that have been bypassed for test purposes.
• Test holdup alarm, fire alarm, supervisory (CCM), and burglar alarm devices (and bell) without
initiating an alarm signal to the central station.
Printout
• Printout can be commanded for up to 60 of the most recent alarm messages that have been stored,
or up to 1000 of the most recent messages.
Naming
• Establish or change a name assigned to each BA group.
• Establish or change a name assigned to each point.
• Establish or change a person’s name to each user code number.
Viewing
• Point status.
• User name and privilege level.
• Time of day.
• Open and close schedules, both permanent and temporary.
• Contents of alarm memory.
• Contents of history log.
Downline Loading
• Reset Memory (SRAM).
• Start downline load.
• Enter, via operating panel, all basic data to get system installed and tested.
Note: All remaining data can be downline loaded or entered in hex via an operating panel.
19-6
S E C T I O N 2 0
System Operation
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ About Operating the System ♦ Control Unit and BA Group Options
♦ Action Menus ♦ Recycling Exit Delay
♦ Operating Panel Modes ♦ Alarm/Trouble Memory
♦ ID Codes
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
1 2 3
ABC DEF
4 5 6
GHI JKL MNO
7 8 9
PRS TUV WXY
20-1
FOCUS 200 PLUS Installation and Setup Guide
Action Menus
Operation of the system is based on selecting a course of action from menu items that appear on a
series of screens known as Action Menus. Provided the associated BA protection is off, entering a valid
ID code causes the first of four Action Menus to be displayed.
The Action Menus are the starting point for performing all operations other than turning the system
off. Selection of a menu item results in the display of another screen. Continue making selections until
the appropriate screen is displayed and the desired course of action has been completed.
The four Action Menus and the explanation for each of the keys at each menu follow on the next page.
20-2
Section 20 - System Operation
20-3
FOCUS 200 PLUS Installation and Setup Guide
12. Bypass: For performing the following d) Open and Close – for entering, checking, or
bypass functions in accordance with the user’s changing the following various schedules
privilege: associated with each BA group:
a) Bypass Points – for bypassing point(s). • Daily Schedules – choice of permanent or
b) See Limits – for determining the number temporary. Permanent schedules allow for
of points that can be bypassed in BA selection of automatic on/off control.
groups. • Schedule Limits – choice of earliest opening
c) VVS – for bypassing vault vibration sensor and latest closing times.
points. Note: Only users with an appropriate privilege
13. Status: For checking that AC power, the level can control scheduling functions.
standby battery, and the telephone lines are 16. Sysinfo: For identifying the firmware level of the
OK. control unit.
14. History: For viewing and/or printing up to 17. Name pnt/gps: For viewing, naming, or changing
500 of the most recent events (alarms, troubles, the name of a protection group or a point. Also for
openings, closings, bypassings, walk test entering complete point data.
results, etc.), including the date and time of the
18. ID codes: For entering, viewing, or changing user
event.
data:
15. Time: For entering, checking, or a) Name of user.
changing the following time-related functions
b) Assignment of user code ID.
for any BA group:
c) Assignment of user control of BA group(s).
a) Current – present time and date.
d) Assignment of user privilege level.
b) Daylight – date of Daylight Saving Time.
c) Holiday – for sequencing through name 19. Load: For ADT personnel.
and date of each holiday in the schedule. 20. First: For returning to Action Menu #1.
When the control unit power switch is turned Off, the time of day and the date, remain at the same settings
as when power was removed. Present time and date must be entered anew at the operating panel; these
values cannot be downline loaded.
20-4
Section 20 – System Operation
Correcting COMM FAIL Condition Due to Change of Panel Group Number
If the operating panel group number is changed, the control unit will detect a communications failure
on the old panel group number and a COMM FAIL message will occur. To clear the condition, proceed
as follows:
Step Action
1 Power down the system and then power it back up. The control unit will interrogate for the
new address and store it in memory.
2 Reset the COMM FAIL condition by using Reset, Alarms at the operating panel.
Service Mode
The Service mode is used when installing or working on the FOCUS 200 PLUS system and is initiated
by entering a Service Code. Operation in the Service mode is characterized by the following
occurrences:
• The operating panel becomes activated and remains activated for 4 minutes. All other operating
panels display ADT SERVICE PERSONNEL WORKING ON SYSTEM. (While in the Service
mode, pressing any operating panel key causes another 4-minute activation period.)
• An ADT-On-Premises signal is transmitted to the central station.
• Customer ID codes are locked out.
• The tamper on the control unit is bypassed.
• Any of the BA groups can be turned on with the cabinet tamper bypassed.
• The bell function is disabled except for BA alarms or test functions. Any point that is programmed
as a Remote Bell Point will not operate for a BA alarm or during testing.
• Any output point that has been programmed as a Service mode output point activates and will
remain activated for the duration of the Service mode.
• The Sonalert is disabled at all operating panels.
• A bypass signal is not transmitted to the CCC if a point is bypassed.
• The Recycling Exit Delay is disabled.
Notes:
• The Service Code has all of the basic user privileges plus those additional privileges that have
been allocated to the Service Code.
• Terminate the Service mode by selecting Reset, ADT Off at the operating panel. An ADT Off
Premises signal will be transmitted to the Customer Care Center, the cabinet tampers are
automatically unbypassed, and the system will be restored to normal operation.
20-5
FOCUS 200 PLUS Installation and Setup Guide
Training Mode
For training purposes, the selector buttons and keypad of one or more operating panels can be
temporarily deactivated for a trainee, while those on the instructor's panel remain active. The trainee
screens reflect the messages on the instructor’s operating panel, allowing the instructor to demonstrate
the usage of the operating panel to the person being trained, without the lessons being interrupted by
someone touching the selector buttons or the keypad.
The instructor's operating panel must have a valid communication address (group 0 or 1, and unit 0-7).
The trainee panels must have the same group number as the instructor's panel and a unit number of
"✴."
To activate the training mode, perform the following steps at the trainee operating panel:
Step Action
1 Press the [1] and [8] keys simultaneously.
2 Enter 1, 2, 3. The parameter screen will be displayed.
3 Press the change button and select the Unit/Mode option.
4 Enter [✴] as the new number in place of the existing unit number.
To exit the Training mode, select a valid unit number in place of the ✴. The operating panel will revert
to normal operation.
Annunciator Mode
The Annunciator mode is used when a facility is not ready to be occupied or the system is not totally
functional. This mode deactivates the selector buttons, and the screen displays only alarm and trouble
messages accompanied by the sounder. The keypad, however, will remain active locally without having
any interaction with the control unit.
To activate the Annunciator mode, perform the following steps:
Step Action
1 Press the [1] and [8] keys simultaneously.
2 Enter 1, 2, 3. The parameter screen is displayed.
3 Press the change button and select the Unit/Mode option.
4 Enter 8 as the new number in place of a unit number.
5 Power down and then power up the system again.
The operating panel may be programmed for normal operation at a future date by entering the
programming mode and entering a valid unit number.
ID Codes
ID codes are needed to turn the BA groups on and off and to perform most other functions. On a new
installation, the ID codes are entered into the control unit database along with the user name, the
privilege level, and the BA groups that the code can access. This can be done by downline loading the
data or by entering it via an operating panel with the system in the Service mode. Thereafter, any
additions or deletions can be made at any operating panel by someone having an ID code with the
privilege to do so.
There are 255 six-digit ID codes that can be assigned to any system, including Service codes. The first
two digits serve as a user number, and are numbered 01, 02, etc., up to 99.Users 01, 101, and 201 all
share the same user number 01. The last four digits (PIN) identify the access capabilities of the user.
Users with the same user code (first two digits) cannot use the same PIN (last four digits). For example,
user 25's PIN may be 1234; user 125's PIN 3456; and user 225's 5678. User 25 would enter 251234 to
access the system. User 125 would enter 253456. User 225 would enter 255678. Be careful that a
duress code is not inadvertently created. As an example, if user 25's PIN is 1234, then make sure user
125's or 225's is not 1236.
If you are entering a new ID code, the last four digits must be entered alongside the first two digits of
the user number. In the event that someone leaves the company, the last four digits should be erased to
invalidate the ID code.
20-6
Section 20 – System Operation
A new ID code can be assigned in either of two ways:
• By entering a new four-digit number alongside the two digits of the deleted code.
• By entering a four-digit number alongside any unused two-digit user number.
In addition, the following data must be entered for the new ID code:
• The BA group(s) to which the user will have access.
• Each of the eight possible privileges that the user will have.
Bypassing
Bypassing is a means of directing the control unit to ignore any point(s) in the system, and therefore
inhibit any output commands that would ordinarily be activated. Consequently, a bypassed input point
that goes into an alarm, trouble, tamper, or comm fail condition will not cause a signal to be sent to the
CCC, nor will it cause the local bell to ring or cause any output to activate.
One or more points can be bypassed by entering appropriate commands at the operating panel provided
that:
• The bypassing option has been activated for those points.
• The person(s) doing the bypass have been assigned an ID code with the privilege of bypassing that
particular type of point (BA, FA, SPV, HUA or special).
20-7
FOCUS 200 PLUS Installation and Setup Guide
Option Function
Turn On STAY The system provides an option to turn on the group(s) in the STAY mode.
Mode When the group is turned on in STAY mode:
• All Movable Instant PIR (MIP) points are bypassed.
• All Movable Instant Stay (MIS) and Movable Delay Stay (MDS) points
will not transmit messages to the central station.
NOTE: STAY mode is enabled via the ADEMCO Compass Downloader.
Bypass Point Ordinarily, if there is a closing of a BA group with one or more BA points
Reporting bypassed, a BA Group Bypass Closing message (BA1, BA2, BA3, etc.) is
transmitted to the CCC as part of the closing message (not for SANS).
Selecting this option activates a unique point bypass/unbypass reporting
scheme:
• For BA Points−Each BA point that has been bypassed is reported to the
CCC when the associated BA group is closed. When the BA group is
turned to Day Set, all of the points automatically become unbypassed,
and an unbypass message is transmitted for each point. (This
automatic unbypassing will not occur if a keyswitch is used or if Auto-
Off control is being used for the BA group; however, an unbypass signal
will be transmitted anyway.)
• For non-BA Points (FA, HUA, SUPV, output points, etc.) −A separate
bypass message is transmitted for each point at the time that the
bypass is made. The points remain bypassed until they are manually
unbypassed, and an unbypass message is transmitted to the CCC.
Note: These points will not automatically become unbypassed when any BA
group is opened.
Close Condition There are four choices for this option that determine whether the BA groups
can be closed when there is a Telco Fail or AC Fail condition:
Telco Fail and BA Group Closing
AC Fail Condition
AC Fail The BA groups can be turned to Nite Set during
AC Fail, but not during Telco Fail.
Telco Fail The BA groups can be turned to Nite Set during
Telco Fail, but not during AC Fail. Use this only
if backup signaling (e.g., bell, backup dialer, etc.)
is available in case a burglary occurs.
AC or Telco Fail The BA groups can be closed during AC Fail or
Telco Fail conditions.
AC or Telco Fail The BA groups cannot be closed during AC Fail
or Telco Fail conditions.
Force Auto-Arm This permits the system to perform an auto-arm of a BA Group when an off-
w/BA Off-normal normal condition is present on the system.
Condition NOTE: This feature can only programmed via the ADEMCO Compass
Downloading software.
No Close (15/15, As the scheduled closing time nears, the operating panel sounder beeps at a
30/5) rate of once per minute. This is the Close Time Reminder, and reminds the
user to get ready to close. If the BA group is not closed, the sounder changes
to a continuous tone and starts the Close Time Warning period. This alerts
the user that the closing time has passed and a No Close signal will be sent
to the CCC unless the BA group is closed before this time period ends. Two
choices are available for the reminder and warning periods:
• 15 minutes for the reminder and 15 minutes for the warning.
• 30 minutes for the reminder and 5 minutes for the warning.
20-8
Section 20 – System Operation
Option Function
Closing Trouble This causes the bell to ring for 5 minutes if the customer turns the system
Bell on and exits, but fails to close the exit door before the exit delay expires. It
is used to remind customer to re-enter the premises, turn the protection off,
then turn it on again, leave, and close the exit door. Failure to do so will
result in an entry alarm.
Audible on Exit This causes the operating panel sounder to beep once per second during the
exit delay period. This is helpful in reducing the number of false alarms
caused by someone exiting after the exit delay has expired.
Bypass Privilege This permits a user to bypass any BA points that are bypassable.
BA
Bypass Privilege, Similar to the option above, except that this pertains to the capability for
FA/SPV/HU/Special bypassing any non-BA point in the system.
Points Note: Special points are comprised of output points plus those input points
that do not fall into any of the following categories: BA, FA, HUA, or SPV.
Bypass FA/SPV/HU/ This is similar to the Bypass BA 2-man rule option; however, it applies to
Special the bypassing of non-BA points.
(2-Man Rule) Note: Both ID codes must be privileged to bypass these types of points.
Bypass BA This activates a requirement for the entry of two valid ID codes at the same
(2-Man Rule) operating panel within 45 seconds in order to bypass. Upon entry of the
second ID code, the bypass capability is enabled and the points can be
bypassed, provided that:
• Both ID codes are capable of bypassing the points.
• The points have been programmed as being bypassable.
Once exiting the bypass screen, both ID codes must be entered again. If only
one ID code is entered, a message appears that a second ID code be entered.
Bypass Limit This defines the number of BA points that may be bypassed within a BA
group. Any number of points can be specified. The BA group cannot be
armed if the number of programmed bypasses is exceeded.
Change Descriptor This is similar to the Bypass BA 2-Man Rule; however, it applies to
(2-Man Rule) changing the name of any BA group, a point of protection, or a person's
name.
Note: Both persons must have the privilege to change descriptors.
Permanent This is similar to the Bypass BA 2-Man Rule option; however, it applies to
Schedule changing the permanent schedule of any BA group.
(2-Man Rule) Note: Both persons must have the privilege to change permanent
schedules.
Temporary This is similar to the Bypass BA 2-Man Rule option; however, it applies to
Schedule changing the temporary schedule of any BA group.
(2-Man Rule) Note: Both persons must have the privilege to change temporary schedules.
Service To activate the Service mode, the entry of a Service Code must be followed
(2-Man Rule) by a valid customer code, at the same operating panel, within 45 seconds.
Latch Telco Fail This causes the Telco Fail display and the ongoing audible beeps (two beeps
followed by a 1-second pause) at all operating panels to latch until manually
reset. Otherwise, the display and audible will clear automatically when the
fault condition restores.
Sonalert on Open This causes the operating panel sounder to activate for 1 second of every
minute when any BA group is in a scheduled open period, and is used to
remind the user to turn the BA group off.
20-9
FOCUS 200 PLUS Installation and Setup Guide
Option Function
Passcode This is used in conjunction with access control, whereby the customer
Verification maintains the permanent open/close schedules. If an attempt is made to
Failure from turn a BA group off prior to the scheduled open period by someone who does
Control not have an irregular opening privilege, the control unit will send an
Irregular Opening signal to the CCC along with the user number. This
signal will cause a PVF alarm.
Auto On/Off Level This is used to determine if any form of automatic on/off will be permitted
Command Enable for the BA groups. If selected, the automatic on/off can be programmed, as
required, for each BA group as part of the permanent schedule.
Telco Fail Message This permits suppressing the Telco Fail signal. It is intended to avoid
Inhibit having Telco Fail signals from multiple control units sent in the event that
AC communications are interrupted.
AC Loss Delay This permits delaying the CCC transmission of an AC Fail condition. The
choices are from 0-255 hours in 1-hour increments.
Delayed This is intended to minimize the customer's security-related telephone bills
Open/Close and minimize nonessential CCC signaling. It delays the reporting of non-
Reporting alarm signals, such as openings and closings that occur within scheduled
time periods, until another transmission is made, at which time all
openings and closings occurring that day are included.
If there is no other transmission, the opening and closing information is
sent between midnight and 4:15 AM, with the time of transmission tied to
the customer's instrument number. For example, an instrument number of
62 corresponds to 62 minutes (1 hour and 2 minutes) past midnight. The
opening and closing data would be transmitted at 1:02 AM of the next day.
The delayed transmission replaces a daily test signal as a means of
ensuring that the telco line is intact.
Sensor Walk LED This is intended to prevent someone from learning the coverage pattern of a
Disable SIM sensor. The LED will only light when walk testing or when in the
Service mode.
Diagnostic Xmit This is intended for use with a sensor that has a self-diagnostic capability.
Enable If the sensor has a decrease in false alarm immunity, a transmission is
made to the CCC to signal this condition.
Group 0 Keypad BA Ordinarily, an operating panel displays the on/off status of the BA 1 group.
On/Off Display Anyone can walk over to any operating panel and keep pressing More to
Inhibit. view the on/off status of each of the remaining BA groups, without having to
enter a valid ID code.
Where, for purposes of security, the customer does not want the on/off
status of one or more BA groups to be displayed, this option allows the
selected BA group to be skipped and the display to show the status of the
next BA group not having a Display Inhibit. This option applies to all
panels that have been programmed for communication group 0 on the RS-
485 bus.
The status of each inhibited BA group can still be viewed at any operating
panel that has been programmed for communication group 1. This option
does not affect operation once a valid code has been entered.
Group 1 Keypad BA This differs from the previous option only in that it pertains to inhibiting
On/Off Display the display of BA group on/off status at operating panels programmed for
Inhibit communication group 1.
20-10
Section 20 – System Operation
Option Function
BA Group Off This option prevents the selected BA group from being turned off by a
Disable person with a coded card/key, and can only be set from an operating panel.
The operating panel can be used either in the normal manner for system
control or in conjunction with an ACIU or with a BA Access output point.
The primary purpose of this option is to prevent someone who finds a coded
card/key outside of an access-controlled area from using it to gain access
and thereby turn off this BA group. The operating panel used for turn-off
should be installed inside of the protected area.
This can also be used to isolate BA group(s) from those being used with
access control, such as when a second BA group is within the BA group
being accessed via a card/key reader.
Entry Delay This applies to installations where the operating panel for the BA group is
located inside of the protected area. The delay permits someone opening the
premises enough time to walk to the operating panel and turn the
protection to Day Set without creating an alarm. The delay starts when the
entrance door is opened and ends when the protection is turned off. The
sounder in the operating panel emits a steady tone during the delay period.
The delay time is selectable from 0 to 255 seconds, in 1-second increments.
Option Function
Exit Delay This applies to installations where the operating panel for the BA group is
located inside of the protected area. The delay permits someone leaving the
premises at closing enough time to turn the protection to Nite Set and walk
to the exit door and close it, without creating an alarm. The delay time is
selectable from 0 to 255 seconds, in 1-second increments.
Exit Fail This is used to make sure that someone exits the BA group after turning the
protection to Nite Set, and can only be used if the operating panel is located
inside of the protected area. An Exit Fail signal is transmitted to the CCC if
the customer turns the protection to Nite Set, but fails to trip a movable
delayed sensor in the exit path within the exit delay period.
One Exit This causes the exit delay period for the respective BA group to end when a
movable delayed sensor is restored or the exit door is closed, after the BA
group is changed to Nite Set. This option can only be used where:
• There is only one movable delayed sensor in the exit path, and the
customer will pass through that protection only once when exiting.
• The customer has specifically requested it, and fully understands the
operation and false alarm potential that exists if someone wants to go
back for something they forgot after exiting.
One Open Ordinarily, the BA group may be repeatedly turned on and off as long as it
is within the scheduled opening and closing time. This option permits only
one BA group on-to-off transition per schedule (maximum of 2 per day if two
schedules are used). This prevents someone from opening a BA group after
it has been closed until the next scheduled opening time is reached.
Off (2-Man Rule) This prevents the BA protection for the selected BA group from being
turned off unless two valid ID codes are entered on the same operating
panel within 45 seconds. Once the BA group is off, the entry of any valid ID
code for the group will activate the operating panel.
20-11
FOCUS 200 PLUS Installation and Setup Guide
Option Function
Irregular Off (2- This option prevents the turning off of the selected BA group outside the
Man Rule) scheduled open window (e.g., re-opening the same day after the scheduled
closing, opening earlier than the scheduled opening, or opening on a day
that the BA group is not scheduled to be opened) unless two valid ID codes
are entered at the same operating panel within 45 seconds. Only one ID
code is needed to open inside of a schedule window.
BA Shed This allows the control unit to shed BA protection for the BA group after 4
hours of AC power failure. This permits reserving the standby batteries for
FA devices to ensure 24 hours of FA standby time. The selective shedding
also allows preserving the BA protection for BA group with a vault or safe
by electing not to shed the protection for a power outage beyond 4 hours.
Bell Delay This is used to delay local annunciation of alarms for a BA group during
Nite Set for up to 20 minutes. It applies to both the operating panel sounder
and the local bell. Messages to the CCC, however, are sent without the
delay. The delay is automatically cancelled if a telco failure occurs.
Bell Cutoff This determines the length of time the local BA bell and operating panels
will annunciate. The cutoff time can be any number of whole minutes from
0 to 255.
Option Function
SANS This represents the type of CCC monitoring that will be provided for the BA
group. Refer to the System Communication section for an explanation of the
types of services that are available.
Interlock On This prevents the protection for a BA group being from being turned on
unless a specific combination of BA groups has been turned on. As an
example, it can be used to ensure that the vault protection has been turned
on before the bank perimeter protection can be turned on.
Schedule Lock This prevents the BA group from being turned off outside the scheduled
open time period. Use this option only on safes, vaults, or other high-
security areas where the operating panel is located outside the protected
area.
ATM Off This is primarily an Automatic Teller Machine (ATM) option. It prevents
the protection for a BA group from being turned off unless the protection is
on for specified BA group(s). Typically, it is used to prevent more than one
ATM from being turned off at any given time.
A Recycling Exit Delay has been incorporated into FOCUS 200 PLUS to minimize the possibility of
creating a false alarm when someone turns the protection On, exits, and then returns to get something
that was left behind.
20-12
Section 20 – System Operation
The Recycling Exit Delay operates as follows:
The BA group is turned on to start the programmed exit delay, and a 10-minute time window is
started. During this time window, an alarm from a movable instant or delayed point from any group in
exit delay automatically recycles all groups in exit delay back to their full exit delay time. This means
that the full exit delay is usually in effect when the person exits, and the delay is recycled to start anew
when that person returns and opens the door again. The exit delay also recycles for each movable point
that is tripped by the person returning.
The recycling of the exit delay can occur any number of times during the 10-minute time window. At
the end of the 10-minute time window, the exit delay will unconditionally start one last time. If the
door is not closed by the end of this last exit delay, a trouble-closing signal will be sent to the CCC.
If the "audible on exit" option was selected for the BA group being turned on, the operating panel (and
Remote Sonalert output point) beeps once per second to annunciate the exit delay period. This exit
delay annunciation is interrupted during the time that a movable delayed point in that BA group is in
alarm, and the sounder goes on steady during the time that a movable instant point of that BA group is
in alarm. In each case, the annunciation resumes when the point restores.
The Recycling Exit Delay is automatically disabled whenever the system is in Service Mode.
Alarm/Trouble Memory
There are 80 memories that serve to store off-normal conditions for each input point in the system, as
well as to store system trouble conditions. Once stored in memory, the contents remain stored until the
off-normal condition has been restored to normal and a RESET command has been entered at the
operating panel. The following is a listing of the memories and an explanation of the function:
Memory Type Function
BA Group There are 64 separate burglar alarm memories, eight for each BA group.
Memories Four memories of each BA group store the first four off-normal conditions
that are detected during Day Set, and the other four memories store the
first four off-normal conditions that occur during Nite Set. The off-normal
conditions include point in alarm as well as the occurrence of a trouble,
tamper, or comm-fail condition.
Holdup Memory Stores the first four holdup points for which an alarm is detected.
Fire Alarm Memory Stores the first four fire points for which an alarm is detected.
Supervisory Stores the first four supervisory points for which an alarm is detected.
Memory
Trouble Memory Stores the first four of the following events that occur:
• Holdup Point - comm fail, tamper, or open lasting more than 1 minute
if using holdup suspicion option.
• Fire Alarm Point - open, tamper, or comm fail condition.
• Supervisory Point - open, comm fail, or tamper.
• Operating Panel - comm fail.
• Janitor Keyswitch Point - open, tamper, or comm fail.
• BA Keyswitch Point - comm fail.
• Remote Bell Point - cross, open, or comm fail. Cross indicates AC fail for
4 hours; open indicates low battery.
• Remote Power Supply Point - cross, open, or comm fail. Cross indicates
AC fail; open indicates low battery.
If a given type of memory becomes filled, it will not store a new alarm unless one of the alarms being
stored is reset.
20-13
FOCUS 200 PLUS Installation and Setup Guide
Control Unit Interpretation of Input Point Status & SIM Output Point Status
Point NC Option = NO (1) Point NC
Input Point Option = YES (2) Point Bypass (4) Diagnostic
Point Comm. Point Tamper
Assignment Cross Open Cross or Open Failure (3) Test
NS DS NS DS NS DS NS DS NS DS Bypass Unbypass
Fire FA FA FT FT FT FT FT FT FB (5) FU (5) FW
Supervisory SS SS ST ST SS SS ST ST ST ST SB (5) SU (5)
Holdup HA HA HT (6) HT (6) HA HA HT HT HT HT HB (5) HU (5)
Holdup Special HT (7) HA (8) HT (6) HT (6) HT (7) HA (8) HT HT HT HT HB (5) HU (5)
Ambush Start HA (9) HA (9) HT HT HA (9) HA (9) HT HT HT HT UB (5) UU (5)
Ambush End HT HT HT HT HT HT UB (5) UU (5)
BA Fixed BA BT BA BT BA BT BA BT BA BT BB (17) UU (5)
BA Fixed Local (18) (18) BA BT (18) (18) BA BT BA BT BB (17) UU (5)
BA Movable Instant BA (11) BA BT BA (11) BA BT BA BT BB (17) UU (5) BW
BA Movable Instant BA (12) BA BT BA (12) BA BT BA BT BB (17) UU (5) BW
Day Annunciation
BA Movable Delayed BA (13) (11) BA BT BA (13) (11) BA BT BA BT BB (17) UU (5) BW
BA Movable Instant BA (11) BA BT BA (11) BA BT BA BT BB (17) UU (5) BW
Chime
BA Movable Delayed BA (13) (11) BA BT BA (11) BA BT BA BT BB (17) UU (5) BW
Chime
BA Vault Vibration BA (14) BT (11) BA BT BA (14) (11) BA BT BA BT BB (17) BU (10) BW
Sensor
BA Keyswitch OP CL UA UT UA UT UA UT UB (5) UU (5)
BA Janitor Keyswitch J1 (15) J1 (15) UA UT UA UT UA UT UB (5) UU (5)
BA End Delay UA UT UA UT UA UT UB (5) UU (5)
BA Blocklock OP UA UT UA UT UA UT UB (5) UU (5)
Remote Bell UT (16) UT (16) UT (16) UT (16) UA UT UA UT UB (5) UU (5)
Remote Power Supply UT (16) UT (16) UT (16) UT (16) UA UT UA UT UB (5) UU (5)
SIM Gateway Output UA UT UT UT UB (5) UU (5)
Point
BA Burglar Alarm FA Fire Alarm HU Holdup Alarm Unbypass SU Supervisory Unbypass
BB Burglar Alarm Bypass FB Fire Alarm Bypass JI Janitor In (key inserted) SW Supervisory Diagnostic
BT Burglar Alarm Trouble FT Fire Alarm Trouble JO Janitor Out (key removed) UA Untyped Alarm
BU Burglar Alarm Unbypass FU Fire Alarm Unbypass NS Nite Set UB Untyped Bypass
BW Burglar Alarm Diagnostic FW Fire Alarm Diagnostic OP Opening UT Untyped Trouble,
CL Closing HA Holdup Alarm SB Supervisory Bypass Tamper, or Comm Fail
DS Day Set HB Holdup Alarm Bypass SS Supervisory Alarm UU Untyped Unbypass
EA Entry Alarm HT Holdup Alarm Trouble ST Supervisory Trouble
Note: Each transmission to central station includes a tag that specifies cause of alarm or trouble (e.g., cause of trouble
as identified open, tamper, or comm fail).
NOTES:
1. Typically used for sensor with transfer contacts. 10. Transmitted automatically at opening if using bypass
2. Typically used for sensor with break-only contacts. point reporting.
3. Any SIM point with a tamper. 11. Condition is disregarded by control unit.
4. Only with bypass point reporting option. 12. Causes local audible only.
5. Bypass and unbypass signals transmitted as event occurs. 13. After entry delay.
6. Open must be more than 1 minute if using suspicion 14. Alarm only if BA1 is Nite Set.
option. 15. Becomes JO (Janitor Off} when key removed.
7. All BA groups (except BA1) are Nite Set, otherwise no 16. Cross = AC fail. Open = low battery.
transmission. 17. Transmitted automatically at closing if using bypass point
8. Any BA group (except BA1) is Day Set, otherwise no reporting.
transmission. 18. Local annunciation only; no CS transmission.
9. Alarm only after 4-1/4 minutes; inside of ambush schedule
and ambush end not activated.
20-14
S E C T I O N 2 1
In This Section
♦ About Testing the System ♦ Testing the Printer
♦ Operating Panel Tests ♦ Finishing the Installation
♦ Local Tests ♦ Instructing the Customer
♦ Transmission Tests
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
21-1
FOCUS 200 PLUS Installation and Setup Guide
Step Action
3 Press the Test LCD selector button. All the pixels on the display screen light up.
4 Press any key. The screen goes blank.
5 Press any key. All alphabetic characters and numbers are displayed.
6 Press any key. The keypad test screen is displayed.
7 Press Quit to return to the operating panel and system information screen.
8 Press Quit again to return the normal operation screen.
Local Tests
The local tests are typical of a local-only system because they do not involve the CCC. Perform a system
test by activating each sensor, in turn, and verifying that the alarm condition is properly displayed on
the operating panel(s), and that the panel sounder functions properly. Indicate the results on the
appropriate ADT form. Inspect the system performing the various tests and battery check. If problems
are encountered, troubleshoot and repair as needed.
Before performing the Burg pts audibly test (described in Additional Test Options), all points to be
tested in this mode must be bypassed.
When any of the Local Tests are selected, the sensitivity of the RF receiver is reduced by approximately
50%, if RF points are programmed in the system.
Burglary Groups
<? Test which grp: If test Burglary groups was selected, this screen is displayed.
BA Group 1 > Select the second key down on the right-hand side to initiate the
< Previous Next > test for the BA group displayed and to show the test results.
< Quit > Select Previous to select the previous BA group.
Select Next to select the next BA group.
Select Quit to return to the Test Screen.
21-2
Section 21 – Testing the System
Sensor Points
<? Sensor Type? If test Sensor points was selected, this screen is displayed.
Burglar > Select Burglar to test burglar points in a particular BA group.
< Supervisory Fire > Select Fire to test fire points in the system.
< Quit Holdup >
Select Supervisory to test supervisory points in the system.
Select Holdup to test holdup points in the system.
At the next prompt, select the BA group, if applicable.
At the next series of prompts, select More, More, More, Start
Test. Then activate all sensors that require testing (open/close
doors and windows, walk in front of motion detectors, etc). To see
the results, view the history log.
NOTE: The operating panel beeps once every minute until the test
is reset.
Select Quit to return to the Test Screen.
Transmission Tests
These tests are performed with the system in a normal mode of operation. That means that the system
produces alarm and trouble indications locally and also transmits the appropriate signal to the CCC.
Be sure the customer and the CCC are aware that these tests are being conducted so that the police or
fire department is not dispatched.
To perform the transmission tests, proceed as follows:
Step Action
1 Notify the CCC before starting the transmission tests.
2 Plug the modular telco line plugs into the respective RJ31X Jacks.
3 Cause an alarm condition from each point designated burglar, fire, supervisory, and holdup,
and restore each point.
4 Cause a trouble condition from each of the above points, and restore the trouble.
5 During the course of transmission, while performing either Step 3 or 4, lift the receiver of
any telephones connected on the same phone line to determine (by the absence of a dial
tone) that they have been disconnected from the line.
6 If you are using the backup dialer, temporarily disconnect the primary line and verify
signaling over the secondary line.
7 Verify that all signals have been received at the CCC.
8 Notify the CCC that the tests have been completed.
21-3
FOCUS 200 PLUS Installation and Setup Guide
21-4
S E C T I O N 2 2
Specifications
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ Electrical/Mechanical Specifications ♦ Approvals
♦ Installation Criteria
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Electrical/Mechanical Specifications
AC Transformer
For Secondary Wire Runs
Up to 10’ in Length 120V, 60 Hz (Primary)
18V, 60 Hz, 50VA, 72VA, or 75VA (Secondary)
Battery (standby)
Type 12VDC Sealed lead-acid battery
50VA Transformer 7AH min. - 24AH max.
72VA Transformer 7AH min. - 34.4AH max.
75VA Transformer 7AH min. - 34.4AH max.
Note: Use the 75VA transformer for installations in Canada.
22-1
FOCUS 200 PLUS Installation and Setup Guide
Installation Criteria
Control Unit
Current Draw
Standby 300mA
Alarm 440mA
Temperature Range 32°F (0°C) to 120°F (49°C)
Dimensions 18" H x 14-1/2" W x 4.3" D
Maximum Cable Runs
RS-485 Bus #1 4000 Feet
RS-485 Bus #2 4000 Feet
SIM Gateway Trunk 1000 Feet
PID Gateway Trunk (TB2 plus TB3) 1000 Feet
Branch Cable for PID and SIM Sensors 100 Feet
SIM Loop Trunk 2000 Feet
Note: RS-485 bus and gateway trunk cable lengths may be less, depending on current loading and
voltage drop considerations.
SIM Gateway
Dimensions with Micro PID Housing 3-1/2" H x 3-1/2" W x 1-5/8" D (8.6cm x 8.6cm x 4cm)
Temperature Range 32°F (0°C) to 120°F (49°C)
Length of SIM Gateway Trunk 1000 feet (max.)
Gateway Circuit Power Requirement 50ma
Worst Case Voltage @ SIM Gateway 12.lVDC
(End of Standby Period) (8.4VDC)
Worst Case Voltage @ SIM Sensor 12.0VDC
(End of Standby Period) (8.3VDC)
SIM Resistor 33k 5% 1/2w
PID Gateway
Dimensions with Standard PID Housing 9-1/4" H x 5" W x 1-5/8" D (23.5cm x l2.7cm x 4.1cm)
Temperature Range 32°F (0°C) to 120°F (49°C)
Length of PID Gateway Trunk (TB2 plus TB3) 1000 Feet (max.)
Gateway Circuit Power Requirement 50mA
Minimum Voltage to PID Gateway 12.lVDC
(End of Standby Period) 8.5VDC
Voltage to Farthest PID on Gateway Trunk 12.1VDC (minimum)
(End of Standby Period) 8.5VDC
Worst Case Voltage to Sensor 11.6VDC
(End of Standby Period) 8.0VDC
Sensor Current from PID Standard PID 85mA maximum (current limited)
Maximum PID Loop Resistance 900 ohms
PID Supervisory Current 3mA
PID End-of-Line Resistor 3,010 ohms, 1%, 1/2W
PID Loop Off-Normal Retard 500mSec.
Note: With AC power off and the battery fully charged the voltage to a sensor being powered by the
system must be greater than the rated minimal voltage of the sensor.
22-2
Section 22 – Specifications
RF Gateway
Dimensions 4.25” H x 6.44” W x 1.25” D
Temperature Range 32°F (0°C) to 120°F (49°C)
Gateway Circuit Power Requirement 50mA
Worst Case Voltage @ Gateway 12.1VDC
(End of Standby Period) 8.4VDC
Tamper
Control Unit Cover included (pry-off kit available for UL listing)
SIM Gateway Cover
PID Gateway Cover (ordered separately)
Operating Panel Cover and pry-off
Printer Interface Unit Cover and pry-off
Approvals
The FOCUS 200 PLUS System has been approved by the following agencies for listing:
• Underwriters Laboratories Inc. (UL)
• Federal Communications Commission (FCC)
• Factory Mutual (FM)
• California State Fire Marshall
• Underwriters Laboratories of Canada (ULC)
The FOCUS 200 PLUS System complies with UL609, UL611, UL864, UL985, UL1023, UL1610,
UL1635, NFPA71, and NFPA72, and will be submitted for approval to various European agencies.
22-3
FOCUS 200 PLUS Installation and Setup Guide
22-4
S E C T I O N 2 3
Equipment
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
In This Section
♦ Basic System Equipment
♦ SIM Sensors
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
The combined total number of operating panels, printers, ACIUs, and gateways must not exceed 31.
Control unit nominal output voltage on quad trunk is 12VDC. See the Power Requirements section to
determine the need for auxiliary power. AI=440mA, SI=300mA
472404 Transformer
18VAC/72VA wired-in transformer, which may be required for some commercial fire installations.
FTA7518ULC Transformer
18VAC/75VA plug-in transformer, which must be used for installations in Canada.
23-1
FOCUS 200 PLUS Installation and Setup Guide
VISTA-ULAP Attack Proof Kit
Hardware kit required for UL-certified burglary installations.
472490 RF Gateway
Consists of a 5800ADT RF Gateway Module and one (1) 5881H RF Receiver. One (1) additional 5881H
RF Receiver may be added to improve reception. RF Gateway - AI=SI=50mA
RF Receiver - AI=SI=60mA
23-2
Section 23 – Equipment
477967 Battery, 12-Volt, 7.0AH Sealed Lead-Acid
A 12V, 7.0AH rechargeable battery with male tab terminals. Connects to control or power supply via a
separately ordered 248222 Battery Wire Lead. Two to four batteries may be connected in parallel to
make up a 12V, 14, 21, or 28AH battery. Battery weighs 6.17 pounds (28kg). One 248222 Battery Wire
Lead is required to connect each battery. Refer to the installation section of control unit bulletin for
instruction in calculating battery standby requirements.
443241 Transformer
A 120/12V, 20VA, Class II transformer for supplying primary power to the 471715 Printer Interface
Unit.
23-3
FOCUS 200 PLUS Installation and Setup Guide
23-4
Section 23 – Equipment
809190 Connector
Scotchlok #558 electrical connector (T-tap type). Used for solid and stranded wires of 16 to 22 AWO. UL
approved. Supplied in a box of 100.
SIM Sensors
472370 FA Pull Station (w/SIM)
Manual FA Pull Box similar to a 455301(5060-S) except has a built-in SIM. It is a dual-action, single-
stage device with keyed reset. Semi-flush mounts in single-gang switchbox (purchased locally) or
surface mounts in 144910 Backbox. May also require 144917 Backplate or 146064 Break Rod, each of
which is listed in T-7 187 FOCUS System Common Equipment Technical Data sheet. Communicates
with the 472368 SIM gateway or built-in SIM loop via a two-wire connection. AI= SI=1mA
472374 Holdup Alarm Switch (W/SIM)
A finger-operated holdup device similar to a 441494 (6913-002) Holdup Alarm Switch, except it has a
built-in SIM. It is a dual-action latching device that requires user to insert a finger and then pull to
activate a holdup alarm. Includes 441495 Reset Tool, which must be used to restore switch to normal
condition. Also includes mounting hardware and a 11’ (3.4m) captive cable. Communicates with the
472368 SIM gateway or built-in SIM loop via a two-wire connection. Al= SI=1mA
472488 Supervised Horn/Strobe SIM
A stand-alone SIM for interfacing various types of horn/strobes (that are not already equipped with a
SIM) to the SIM Gateway. Current of horn or strobe must be less than 300mA each. Also used for
controlling an output function where the +12V output must be supervised. Comes with 6" flying leads
for making horn/strobe connections. Horn/Strobe SIM can be installed in the horn backbox or in a
separately ordered 370320 (7032) Junction Box. AI=SI=3mA
450SIM PIR (w/SIM')
A Sentrol model AP450 Passive Infrared Detector that includes a built-in SIM. It provides 9 curtains of
detection of motion in two jumper selectable ranges, 33 ft. and 50 ft. Recommended mounting height is
6 to 10 ft. Communicates with the 472368 SIM Gateway via a two-wire connection. Refer to the
manufacturer’s installation instructions for further details. AI=5mA, SI=1.78mA
663SIM PIR (w/472366SIM)
A Sentrol model AP633 Passive infrared Detector that includes a standalone SIM (472366) housed in
the same enclosure. When using this device Option 3 MUST be set to NO. It provides the detection of
motion in selectable ranges extending 40 ft.; 80 ft. (wide); and 200 ft. (long range) in 12 selectable
patterns. Features Step Focus Curtain technology. Communicates with the 472368 SIM Gateway via a
two-wire connection. Refer to the manufacturer’s installation instructions for further details.
AI=25mA, SI=13mA
669SIM Dual Optic Technology Ceiling Mount PIR (w/SIM)
A Sentrol model AP669 Passive Infrared Detector that includes a built-in SIM. The unit provides two
independent 180° fields of view, enabling the detector to cover a single 180° area or two 180° areas
(360°). Features 60 ft. diameter 360° coverage, 18 full curtains and can be mounted from a height of 8
to 16 ft. without changing lenses. Communicates with the 472368 SIM Gateway via a two-wire
connection. Refer to the manufacturer’s installation instructions for further details.
AI=11mA, SI=6mA
23-5
FOCUS 200 PLUS Installation and Setup Guide
23-6
Index
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
Index-2
Index
Holdup Suspicion ............................................. 10-2, 14-10
E Holiday Schedules....................................................... 16-4
Horn/Strobe...................................................... 10-4, 14-12
Early Open .................................................................. 16-5
Horn/Strobe (Code 3) ................................................ 14-13
Early Open/ Late Close ............................................... 16-4
Earth Ground Connections ........................................ 13-17
Earth Ground Fault.................................................... 13-17 I
Earth Ground to the Control Unit ............................... 13-16
Encrypted Communication ............................................ 9-1 ID Code Makeup ......................................................... 19-1
Enrolling Key or Card ................................................ 11-18 ID Code Privileges....................................................... 19-1
Entry Delay................................................................ 20-11 ID codes ...................................................................... 20-4
Event Code.................................................................... 8-4 ID Codes ................................................... 15-1, 19-1, 20-6
Exit Delay. ................................................................. 20-11 Independently powered sensor ............................ 5-17, 6-3
Exit Fail...................................................................... 20-11 Inhibit BA................................................................... 14-13
Exit Pushbutton ................................................ 11-15, 14-6 Initial Key Screen ........................................................ 15-9
Initial Vector Key ........................................................... 9-1
Input and Output Point Types...................................... 14-1
F Input Point Options...................................................... 14-8
Input Point Status ...................................................... 20-14
FCC Part 15 STATEMENT............................................ A-1 Input Point Types ........................................................ 14-1
FCC PART 68 NOTICE ................................................. A-1
Installing a Power Supply .......................................... 13-15
Features ........................................................................ 1-1
Installing Sensors to the PID ......................................... 5-7
Features of the ACIU................................................... 11-1
Installing SIM and SIM Sensors ........................... 5-17, 6-2
Fire ................................................................... 10-2, 14-10 Installing the Access Control Interface Unit................. 11-4
Fire Alarm............................................................. 7-2, 14-3
Installing the Control Unit .............................................. 2-1
Fire Alarm Application Note.............................................. vi
Installing the Control's Circuit Board ............................. 2-4
Fire Alarm Memory.................................................... 20-13
Installing the External Sounders.................................... 7-4
Fire Door Application..................................................... 6-8 Installing the Operating Panels ..................................... 3-1
Fire Marshall Code ...................................................... 19-2
Installing the PID Gateway ............................................ 5-5
fire with verification...................................................... 14-3
Installing the SIM Gateway.......................................... 5-15
First ............................................................................. 20-4
Installing the Standby Battery.................................... 13-17
Fixed............................................................................ 14-1
Interlock On............................................................... 20-12
Fixed Local .................................................................. 14-2
Irregular Off (2-Man Rule). ........................................ 20-12
G J
Gateway Log Form........................................................ 5-9
J5 Output Triggers....................................................... 10-1
Gateway Off Normal Conditions .................................. 5-29
Janitor Keyswitch ........................................................ 14-4
Gateway Screen.......................................................... 15-6
Janitor Point ................................................................ 14-9
Gateways ...................................................................... 5-1 Janitor Privilege................................................ 11-15, 14-6
General Description....................................................... 1-1
JL/JK Header ................................................................ 9-3
Grade A Mercantile Premises Listing ............................ 2-3
Grade A Mercantile Safe and Vault Listing.................... 2-4
Ground Clamp ............................................................. 23-5 K
Group 0 Keypad BA On/Off Display Inhibit................ 20-10
Group 1 Keypad BA On/Off Display Inhibit................ 20-10 Key Readers ............................................................... 11-7
Group Assignment Screen .......................................... 15-4 Keyloks............................................................... 11-6, 11-7
Group Info Screen .............................................. 15-2, 15-3 Keyswitch to the SIM Loop.......................................... 6-13
Group Number............................................................... 8-4 Kissoff ........................................................................... 8-1
Guidelines for Programming Schedules ...................... 16-3
L
H
Latch Telco Fail........................................................... 20-9
Handshake .................................................................... 8-1 Late Close ................................................................... 16-5
Hard ID Number ............................................................ 5-8 Lesson......................................................................... 20-3
Hard ID Screen............................................................ 15-6 LIM (Loop Interface Module) ....................................... 23-2
History ......................................................................... 20-4 LIMITATIONS OF THIS ALARM SYSTEM.................... A-3
History Log .................................................................. 12-1 List of Figures................................................................... xi
History Log Alpha and Event Codes............................ 12-5 Load ............................................................................ 20-4
History Log Entries ...................................................... 12-1 Load Diagrams for the RS-485 Buses......................... 13-5
Holdup..................................................... 10-2, 14-3, 14-10 Local Closing Supervision (LCS)................................. 8-10
Holdup Alarm................................................................. 7-2 Local Tests.................................................................. 21-2
Holdup Memory. ........................................................ 20-13 Lockout of Operating Panel................................ 20-4, 20-5
Holdup Special ............................................................ 14-3 Log Event .................................................................. 11-13
Index-3
Index
Long Range Radio Gateway ....................................... 5-26 Option 2 Screen .......................................................... 15-5
Long Range Radio Trouble Conditions ....................... 5-29 Option 3..................................................................... 14-13
Long Range Radios..................................................... 10-4 Option 3 Screen .......................................................... 15-5
Loop Interface Module........................................ 6-10, 6-11 Output Functions ........................................................... 7-2
LRR Gateway .............................................................. 5-27 Output Link (Option 2) ............................................... 14-13
Output Point Options ................................................. 14-13
Output Point Status ................................................... 20-14
M Output Point Types............................................. 10-1, 14-9
Main Telephone Line Supervision ................................. 8-2
Maintenance of the Access Control System .............. 11-19 P
Manual Access Pushbutton .............................. 11-14, 14-6
Marlok Keylok.............................................................. 11-8 pager message ............................................................. 8-4
Master Key ........................................................... 9-1, 15-9 Paging Service .............................................................. 8-4
Maximum Cable Runs ................................................. 22-2 Passcode No Schedule Supervision (PCNS) .............. 8-10
Maximum Length of Gateway Cable ........................... 13-9 Passcode Schedule Supervision (PCS) ........................ 8-9
Mnemonic....................................................... 14-14, 14-15 Passcode Verification Failure........................................ 8-9
More ............................................................................ 20-3 Passcode Verification Failure from Control ............... 20-10
Motorola ...................................................................... 11-8 PCB CURRENT ........................................................ 13-14
Mounting and Wiring the Operating Panel..................... 3-2 Permanent Schedule (2-Man Rule)............................. 20-9
Mounting and Wiring the Printer Interface Unit............ 12-3 Permanent Schedules ................................................. 16-2
Mounting and Wiring the RF Receiver......................... 5-24 Person Access Screens .............................................. 19-4
Mounting the AC Module............................................... 9-2 Person Data Entry Screen........................................... 19-3
Mounting the Access Control Interface Unit ................ 11-5 Person’s Name Screen ............................................... 19-4
Mounting the Cabinet .................................................... 2-2 Physical Description of ACIU ...................................... 11-2
Mounting the PID Gateway............................................ 5-6 Physical Description of the Printer Interface Unit ........ 12-2
Mounting the RF Gateway........................................... 5-23 PID Gateway ............................................... 5-2, 22-2, 23-2
Mounting the SIM Gateway ......................................... 5-15 PID Gateway Applications............................................. 5-4
Movable Delayed......................................................... 14-2 PID Gateway Physical Description................................ 5-3
Movable Delayed Chime ............................................. 14-3 PID Gateway Standby and Alarm Loads ..................... 13-2
Movable Delayed Stay................................................. 14-8 Point Data ................................................................... 15-1
Movable Instant ........................................................... 14-1 Point Info Screen......................................................... 15-3
Movable Instant Chime................................................ 14-3 Point Interface Devices (PIDs) ...................................... 5-2
Movable Instant Daytime Annunciation ....................... 14-2 Point Link ..................................... 10-3, 14-8, 14-12, 14-13
Movable Instant PIR .................................................... 14-8 Point Link Screen ........................................................ 15-4
Movable Instant Stay................................................... 14-7 Point Number ................................................................ 8-4
Multiple AC Communicator Modules ............................. 9-3 Point Type Screen....................................................... 15-3
Point Types Associated with Access Control ............ 11-14
Power Requirements............................................ 2-2, 13-1
N Power Supply module ................................................... 5-5
Power Supply Module ................................................. 23-6
Name pnt/gps .............................................................. 20-4 Power Unit Housing..................................................... 23-3
Naming BA Groups ..................................................... 15-2 Powering the FOCUS 200 PLUS ................................ 13-1
National Electric Code............................................... 13-17 Powering Up the Control Unit.................................... 13-19
New User Screen ........................................................ 19-4 Previous ...................................................................... 20-3
NFPA Life Safety applications .............................. 5-21, 6-9 Primary Phone Number Screen .................................. 15-8
No Alarm Response .................................................... 14-7 Printer Interface Unit .......................................... 12-1, 23-3
No Close...................................................................... 20-8 Printing the History Log ............................................... 12-3
Printout........................................................................ 19-6
O Printout of FOCUS 200 PLUS History Log .................. 12-4
Programming............................................................... 15-1
Programming for Downline Loading ............................ 17-1
Off Normal Condition................................................. 14-13
Programming for the AC Communicator Module........... 9-5
One Exit..................................................................... 20-11
Programming ID Codes............................................... 19-3
One Open.................................................................. 20-11
Programming Mechanics............................................. 15-2
Opening/Closing Schedules ........................................ 16-1
Programming Point Data ............................................. 15-3
Operating Panel ................................................. 20-1, 23-2
Programming the BA Groups Turn-Off Data ............... 15-7
Operating Panel Features ............................................. 3-1
Programming the Bell Outputs ...................................... 7-6
Operating Panel Modes............................................... 20-5
Programming the Output Triggers ............................... 10-6
Operating Panel Program Mode.................................... 3-4
Programming the System Communication
Operating Panel Sounder ............................................ 20-2
Options........................................................... 8-12, 15-7
Operating Panel Tests................................................. 21-1
Protection On/Off......................................................... 19-5
Operating Panels......................................................... 11-6
Option 1............................................................ 14-9, 14-13
Option 1 Screen .......................................................... 15-4
Option 2............................................................ 14-9, 14-13
Index-4
Index
SIM Sensors................................................ 5-17, 6-3, 23-5
Q Smoke Power Reset.................................................... 14-9
Sonalert on Open ........................................................ 20-9
Quit.............................................................................. 20-3
Specifications .............................................................. 22-1
Standby Battery Size................................................. 13-14
R Standby Current Limits.............................................. 13-14
Status .......................................................................... 20-4
Readers....................................................................... 11-6 STAY mode................................................................. 20-3
Real-Time Clock.......................................................... 18-1 Strobe........................................................................ 14-13
Recycling Exit Delay.................................................. 20-12 Style ‘D’ Configuration................................................... 4-4
Remote Bell...................................................... 10-3, 14-11 Successful Transmission............................................... 8-1
Remote Power Supply................................................. 14-4 Super-Degraded Mode.............................................. 11-20
Reporting Formats......................................................... 8-1 Supervised RF ............................................................ 5-25
Reset........................................................................... 20-3 Supervision of ACIU .................................................. 11-19
Resetting ..................................................................... 19-5 Supervision of the Printer Interface Units .................... 12-1
RF Gateway .............................................. 5-22, 22-3, 23-2 Supervisory .................................... 10-2, 14-3, 14-4, 14-10
RF Gateway & RF Receiver Standby and Alarm Supervisory Alarm ......................................................... 7-2
Loads....................................................................... 13-4 Supervisory Memory. ................................................ 20-13
RF Information Screen ................................................ 15-6 Sysinfo ........................................................................ 20-4
RF Programming Screen............................................. 15-6 System Communication ................................................ 8-1
RF Receiver ................................................................ 5-23 System Layout Diagram ................................................ 2-1
RPX-264 Pushbutton................................................. 11-12 System Number Screen .............................................. 17-2
RS-485 Bus #1 Current Load .................................... 13-11 System Operation........................................................ 20-1
RS-485 Bus #2 Current Load .................................... 13-11 System Self-Supervisory Signals ................................ 8-12
RS-485 Bus Load Current ........................................... 22-1 System Sensor.............................................................. 4-2
RS-485 Buses ...................................................... 5-1, 22-1 System Sensor EOL Relay Module............................... 4-3
RS-485 Cable Types ..................................................... 3-1 System Trouble ................................................ 10-3, 14-11
RS-485 Repeater ........................................................ 23-2 System-powered sensor....................................... 5-17, 6-3
S T
Index-5
Index
Wiring Bell Outputs........................................................ 7-6
U Wiring Burglary and Panic Devices to Points 1-8 .......... 4-2
Wiring the AC Module ................................................... 9-2
Unlock Time .............................................................. 11-13
Wiring the Access Control Interface Unit..................... 11-6
Unsolicited Upload ...................................................... 17-3
Wiring the Auxiliary Relay ............................................. 7-6
Unsupervised RF......................................................... 5-25
Wiring the Electric Door Strike .................................... 11-9
User Access Limitations .............................................. 16-1 Wiring the Hardwired Points.......................................... 4-1
User Number ................................................................. 8-4
Wiring the PID gateway................................................. 5-6
User Privileges .......................................................... 11-17
Wiring the RF Gateway ............................................... 5-23
Wiring the SIM Gateway.............................................. 5-16
V Working Encryption Key #1 Screen............................. 15-9
Working Encryption Key #2 Screen............................. 15-9
Vault Vibration Sensor........................................ 14-2, 14-3 Working Encryption Key #3 Screen........................... 15-10
Verifying the Downline Loaded Data ........................... 17-4 Working Encryption Key #4 Screen........................... 15-10
Viewing........................................................................ 19-6 Working Keys ................................................................ 9-1
VISTA-ULAP Attack Proof Kit...................................... 23-2 Worksheets to calculate the total current .................. 13-10
VISTA-ULAP UL Attack Proof Kit .................................. 2-2
Voltage Drops along the RS-485 Buses...................... 13-8 X
Voltage for Each Gateway and Operating Panel ......... 13-1
XMIT Denied ............................................................. 11-13
W XMIT Invalid .............................................................. 11-13
Index-6
FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IN THE EVENT OF TELEPHONE OPERATIONAL PROBLEMS
In the event of telephone operational problems, disconnect the control panel by removing the plug from the RJ31X (CA38A
in Canada) wall jack. We recommend that you demonstrate disconnecting the phones on installation of the system. Do not
disconnect the phone connection inside the Control Panel. Doing so will result in the loss of your phone lines. If the regular
phone works correctly after the Control Panel has been disconnected from the phone lines, the Control Panel has a problem
and should be returned for repair. If upon disconnection of the Control Panel, there is still a problem on the line, notify the
telephone company that they have a problem and request prompt repair service. The user may not under any circumstances
(in or out of warranty) attempt any service or repairs to the system. It must be returned to the factory or an authorized service
agency for all repairs.
FCC PART 68 NOTICE
This equipment complies with Part 68 of the FCC rules. On the front cover of this equipment is a label that contains, among
other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this
information must be provided to the telephone company.
This equipment uses the following jacks:
An RJ31X is used to connect this equipment to the telephone network.
The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the
telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the
RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined
by the total RENs, contact the telephone company to determine the maximum REN for the calling area.
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary
discontinuance of service may be required. If advance notice is not practical, the telephone company will notify the customer
as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the
operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the
necessary modifications in order to maintain uninterrupted service.
If trouble is experienced with this equipment, please contact the manufacturer for repair and warranty information. If the
trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the
network until the problem is resolved.
There are no user serviceable components in this product, and all necessary repairs must be made by the manufacturer. Other
repair methods may invalidate the FCC registration on this product.
This equipment cannot be used on telephone company-provided coin service. Connection to Party Line Service is subject to
state tariffs.
This equipment is hearing-aid compatible.
When programming or making test calls to an emergency number, briefly explain to the dispatcher the reason for the call.
Perform such activities in the off-peak hours; such as early morning or late evening.
A-1
CANADIAN EMISSIONS STATEMENTS
This Class B digital apparatus complies with Canadian ICES-003
NOTICE AVIS
The Industry Canada Label identifies certified equipment. L’étiquette d’Industrie Canada identifie le matériel
This certification means that the equipment meets homologué. Cette étiquette certifie que le matériel est
telecommunications network protective, operational and conforme aux normes de protection, d’exploitation et de
safety requirements as prescribed in the appropriate sécurité des réseaux de télécommunications, comme le
Terminal Equipment Technical Requirements prescrivent les documents concernant les exigences
document(s). The Department does not guarantee the techniques relatives au matériel terminal. Le Ministère
equipment will operate to the user’s satisfaction. n’assure toutefois pas que le matériel fonctionnera à la
satisfaction de l’utilisateur.
Before installing this equipment, users should ensure that
it is permissible to be connected to the facilities of the Avant d’installer ce matériel, l’utilisateur doit s’assurer
local telecommunications company. The equipment must qu’il est permis de le raccorder aux installations de
also be installed using an acceptable method of l’enterprise locale de télécommunication. Le matériel doit
connection. The customer should be aware that également être installé en suivant une méthode acceptée
compliance with the above conditions may not prevent da raccordement. L’abonné ne doit pas oublier qu’il est
degradation of service in some situations. possible que la conformité aux conditions énoncées ci-
dessus n’empêche pas la dégradation du service dans
Repairs to certified equipment should be coordinated by a
certaines situations.
representative designated by the supplier. Any repairs or
alterations made by the user to this equipment, or Les réparations de matériel nomologué doivent être
equipment malfunctions, may give the coordonnées par un représentant désigné par le
telecommunications company to request the user to fournisseur. L’entreprise de télécommunications peut
disconnect the equipment. demander à l’utilisateur da débrancher un appareil à la
suite de réparations ou de modifications effectuées par
Users should ensure for their own protection that the
l’utilisateur ou à cause de mauvais fonctionnement.
electrical ground connections of the power utility,
telephone lines and internal metallic water pipe system, if Pour sa propre protection, l’utilisateur doit s’assurer que
present, are connected together, This precaution may be tous les fils de mise à la terre de la source d’energie
particularly important in rural areas. électrique, de lignes téléphoniques et des canalisations
d’eau métalliques, s’il y en a, sont raccordés ensemble.
Caution: Users should not attempt to make such Cette précaution est particulièrement importante dans les
connections themselves but should contact appropriate régions rurales.
electric inspection authority, or electrician, as appropriate.
Avertissement : L’utilisateur ne doit pas tenter de faire
NOTICE: The Ringer Equivalence Number (REN) ces raccordements lui-même; il doit avoir racours à un
assigned to each terminal device provides an indication of service d’inspection des installations électriques, ou à un
the maximum number of terminals allowed to be électricien, selon le cas.
connected to a telephone interface. The termination on an
interface may consist of any combination of devices AVIS : L’indice d’équivalence de la sonnerie (IES)
subject only to the requirement that the sum of the Ringer assigné à chaque dispositif terminal indique le nombre
Equivalence Numbers of all the devices does not exceed maximal de terminaux qui peuvent être raccordés à une
5. interface. La terminaison d’une interface téléphonique
peut consister en une combinaison de quelques dispositifs,
à la seule condition que la somme d’indices d’équivalence
de la sonnerie de tous les dispositifs n’excède pas 5.
A-2
WARNING!
THE LIMITATIONS OF THIS ALARM SYSTEM
While this System is an advanced wireless security system, it does not offer guaranteed protection against burglary, fire
or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for
a variety of reasons. For example:
• Intruders may gain access through unprotected openings or have the technical sophistication to bypass an alarm
sensor or disconnect an alarm warning device.
• Intrusion detectors (e.g., passive infrared detectors), smoke detectors, and many other sensing devices will not work
without power. Battery-operated devices will not work without batteries, with dead batteries, or if the batteries are
not put in properly. Devices powered solely by AC will not work if their AC power supply is cut off for any reason,
however briefly.
• Signals sent by wireless transmitters may be blocked or reflected by metal before they reach the alarm receiver. Even
if the signal path has been recently checked during a weekly test, blockage can occur if a metal object is moved into
the path.
• A user may not be able to reach a panic or emergency button quickly enough.
• While smoke detectors have played a key role in reducing residential fire deaths in the United States, they may not
activate or provide early warning for a variety of reasons in as many as 35% of all fires, according to data published
by the Federal Emergency Management Agency. Some of the reasons smoke detectors used in conjunction with this
System may not work are as follows. Smoke detectors may have been improperly installed and positioned. Smoke
detectors may not sense fires that start where smoke cannot reach the detectors, such as in chimneys, in walls, or
roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on another level of a residence or
building. A second floor detector, for example, may not sense a first floor or basement fire. Finally, smoke detectors
have sensing limitations. No smoke detector can sense every kind of fire every time. In general, detectors may not
always warn about fires caused by carelessness and safety hazards like smoking in bed, violent explosions, escaping
gas, improper storage of flammable materials, overloaded electrical circuits, children playing with matches, or arson.
Depending on the nature of the fire and/or location of the smoke detectors, the detector, even if it operates as
anticipated, may not provide sufficient warning to allow all occupants to escape in time to prevent injury or death.
• Passive Infrared Motion Detectors can only detect intrusion within the designed ranges as diagrammed in their
installation manual. Passive Infrared Detectors do not provide volumetric area protection. They do create multiple
beams of protection, and intrusion can only be detected in unobstructed areas covered by those beams. They cannot
detect motion or intrusion that takes place behind walls, ceilings, floors, closed doors, glass partitions, glass doors, or
windows. Mechanical tampering, masking, painting or spraying of any material on the mirrors, windows or any part
of the optical system can reduce their detection ability. Passive Infrared Detectors sense changes in temperature;
however, as the ambient temperature of the protected area approaches the temperature range of 90° to 105°F (32° to
40°C), the detection performance can decrease.
• Alarm warning devices such as sirens, bells or horns may not alert people or wake up sleepers if they are located on
the other side of closed or partly open doors. If warning devices are located on a different level of the residence from
the bedrooms, then they are less likely to waken or alert people inside the bedrooms. Even persons who are awake
may not hear the warning if the alarm is muffled by noise from a stereo, radio, air conditioner or other appliance, or
by passing traffic. Finally, alarm warning devices, however loud, may not warn hearing-impaired people.
• Telephone lines needed to transmit alarm signals from a premises to a central monitoring station may be out of
service or temporarily out of service. Telephone lines are also subject to compromise by sophisticated intruders.
• Even if the system responds to the emergency as intended, however, occupants may have insufficient time to protect
themselves from the emergency situation. In the case of a monitored alarm system, authorities may not respond
appropriately.
• This equipment, like other electrical devices, is subject to component failure. Even though this equipment is
designed to last as long as 20 years, the electronic components could fail at any time.
The most common cause of an alarm system not functioning when an intrusion or fire occurs is inadequate maintenance.
This alarm system should be tested weekly to make sure all sensors and transmitters are working properly. The security
keypad (and remote keypad) should be tested as well.
Wireless transmitters (used in some systems) are designed to provide long battery life under normal operating conditions.
Longevity of batteries may be as much as 4 to 7 years, depending on the environment, usage, and the specific wireless
device being used. External factors such as humidity, high or low temperatures, as well as large swings in temperature,
may all reduce the actual battery life in a given installation. This wireless system, however, can identify a true low
battery situation, thus allowing time to arrange a change of battery to maintain protection for that given point within the
system.
Installing an alarm system may make the owner eligible for a lower insurance rate, but an alarm system is not a
substitute for insurance. Homeowners, property owners and renters should continue to act prudently in protecting
themselves and continue to insure their lives and property. We continue to develop new and improved protection devices.
Users of alarm systems owe it to themselves and their loved ones to learn about these developments.
A-3
A-4
WARNING: OWNER'S INSTRUCTION NOTICE NOT TO BE REMOVED AC TEST BURGLARY SYSTEM WEEKLY
NOTES LED
REFER TO INSTRUCTIONS K3471 FOR ADDITIONAL INFORMATION J5 VOLTAGE TRIGGERS J5
NOTE 1: TYPES OF FIRE SIGNALLING SERVICE: (not supervised) 1
WARNING:
The combined standby current THIS UNIT MAY BE PROGRAMMED TO Manual fire alarm, automatic fire alarm, sprinkler supervisory and waterflow alarm. See instructions for trigger use 2
BATTERY TABS and programming. 3
drawn from aux pwr #2, aux pwr #3 INCLUDE AN ALARM VERIFICATION UL Listed local control (non-coded). 1. GROUND (BLACK) 4
Make connections
and aux relay terminal 10 (when Connect to 12V, 7AH min/34.4AH max UL Listed central station, proprietary and Remote Station protected premises unit 2. OUT 1 (BLUE) 5 using 472412 cable
+ RED lead acid batteries using cables supplied. FEATURE THAT WILL RESULT IN A DELAY (not supplied)
wet) can not exceed 1.0A. The OF THE SYSTEM ALARM SIGNAL FROM when used with back-up dialer module. Installation limits under jurisdiction 3. OUT 2 (BROWN) 6
combined alarm current drawn See instructions for required capacity. of local authority.
4. OUT 3 (GREEN) 7
Float charging voltage: 13.7VDC. Battery THE INDICATED FIRE CIRCUITS. THE 5. OUT 4 (RED) 8
from aux pwr #2, aux pwr #3, aux - BLK normally need not be replaced for TOTAL DELAY (CONTROL UNIT PLUS 6. OUT 5 (WHITE) 9
relay terminal 10 (when wet), bell 1 SMOKE DETECTORS) SHALL NOT EXCEED The 472402A Dialer 7. OUT 6 (YELLOW)
and bell 2 cannot exceed 1.5A at least 3 yrs. Battery connection is Complies with FCC Rules, Part 68 8. OUT 7 (GRAY)
Cabinet
supervised. 60 SECONDS. NO OTHER INITIATING BACK-UP LINE SEIZE FCC Reg. No.: AC398U-68628-MO-N 9. OUT 8 (VIOLET)
when 443216 or N8167 transformer DEVICES SHALL BE CONNECTED TO LED (GREEN) Ringer Equivalence: 0.7B Ratings: Tamper
is used, and 2.3A when 472404 POWER SWITCH THESE CIRCUITS UNLESS APPROVED BY Low Output: 0.7V thru 100 ohm Input
transformer is used. THE LOCAL AUTHORITY HAVING BACK-UP
can sink 33mA with 4V drop
High Output: 12V thru 4k ohm
NOTE 2: P4 JURISDICTION. PHONE JACK MAIN DIALER
Use 472411 2k EOLR for listed fire SEE TELCO RJ31X
ON 1 CIRCUIT CONTROL UNIT SMOKE DETECTOR JACK SHOCK
LED
installations. (supplied) 2 (POINT) DELAY-SEC MODEL DELAY-SEC WARNING
OFF 3 Connect to main PCB
NOTE 3: header J6 using ribbon
BELOW
See instructions for max. # of JUMPER P4 cable (supplied) (connect using supplied cable)
keypads and wire run length ALARM CURRENT Supervision is programmable
restrictions. Attach 472402A BACK-UP TLM ON HOOK
Pins 1 & 2 shorted = 2.3A BACK-UP DIALER EARTH J6
module to main VOLTAGE THRESHOLD (BLUE) GROUND SCREW
Must use with 47204 transformer. INTACT: 25V 1
PCB using 3 (wire to main PCB,
Pins 2 & 3 shorted = 1.5A CUT: 13V terminal 3 or 4) 2
Must use with 443216/N8167 THE DELAY TIME MARKED ON THE INSTALLED standoffs 3
transformer. DETECTOR(S) IS TO BE USED (supplied) OPTIONAL 472402A BACK-UP DIALER MODULE 4 Backup Dial Header472402A
FTA7518ULC plug-in 5
or AC communication module
transformer (optional) 6
472491 Jack
7
INPUT: 120VAC, 8
0.59A, 60 Hz connect THIS EQUIPMENT SHOULD BE INSTALLED IN CONNECTION OF THE FIRE ALARM
to unswitched outlet The Focus Built-in Dialer 9
OUTPUT: 18VAC, 75VA ACCORDANCE WITH THE NATIONAL FIRE SIGNAL TO A FIRE ALARM HEAD- Complies with FCC Rules, Part 68
PROTECTION ASSOCIATION'S STANDARD 72, QUARTERS OR A CENTRAL STATION
472404 wired-in
SHALL BE PERMITTED ONLY WITH FCC Reg. No.: AC398R-68192-AL-E
transformer with CHAPTER 3 (NATIONAL FIRE PROTECTION Ringer Equivalence: 0.7B
enclosure THE APPROVAL OF THE LOCAL
INPUT: 120VAC, 1.0A,
ASSOC., BATTERYMARCH PARK, QUINCY, AUTHORITY HAVING JURISDICTION.
60Hz connect to a MA. 02269). PRINTED INFORMATION DESCRIBING P3 THE BURGLARY ALARM SIGNAL THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES.
443216 or N8167 plug-in dedicated circuit PROPER INSTALLATION, OPERATION, TESTING, 1 OPERATION IS SUBJECT TO THE FOLLOWING TWO
transformer (optional) SHALL NOT BE CONNECTED TO A
OUTPUT: 18VAC, 72VA MAINTENANCE, AND REPAIR SERVICE IS TO BE 2 POLICE EMERGENCY NUMBER. CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INPUT: 120VAC,
0.59A, 60 Hz connect OUTPUT PROVIDED WITH THIS EQUIPMENT. 3 INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
to unswitched outlet BL BL
JUMPER P3 Aux Relay Setting
OUTPUT: 18VAC, 50VA INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
Pins 1 & 2 shorted = wet THAT MAY CAUSE UNDESIRED OPERATION.
Pins 2 & 3 shorted = dry MAIN Connect
WH BK SERVICE RJ31X using
INPUT TRNSFMR GND BELL OUTPUTS AUX. RELAY RS-485 #1 RS-485 #2 POINT 1 POINT 2 POINT 3 POINT 4 POINT 5 POINT6 POINT 7 POINT 8 cable supplied.
1 2 3 4 5 6 7 8
RJ31X Supervision is
9 10 11 12 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
programmable.
JACK PHONE JACK
AC WIRING IS
SUPERVISED
)
RE
ND
RY
BELL 1 BELL 2
PA
OU
T/D
+ - + -
.
OOP
OOP
N.C
N.O
(S
OR LKE
Data
OR LKE
GR
Data
Data
Data
WE
EARTH GROUND
NOTE:
443216 may not be used for listed commercial fire + - + - WARNING: TO PREVENT
ECT
ECT
installations. Total alarm current is limited to 1.5A. AUX RELAY (FORM C) Blue Yel Red Blk Blue Yel Red Blk
RISK OF ELECTRICAL SHOCK,
2-W
2-W
Short pins 2 & 3 on P4. programmable response (not supervised)
472404 may be used for all listed commercial (burg,
HORN HORN
WHEN WET: 12V terminal 10,
+ - + - + - - + + -
DISCONNECT TELCO JACK
1.7A max., see note 1. AUXILIARY POWER #2 & #3
fire, burg/fire) installations. Total alarm current is
WHEN DRY: No voltage on terminal 10, (Not Supervised) - + BEFORE SERVICING THIS PANEL.
limited to 2.3A, see note 1. Short pins 1 & 2 on P4. SMOKE SMOKE - + + -
FTA7518ULC may be used for all listed commercial 2k (note 2) 2k Contact Rating: 28V, 2A max., Rating: 12VDC, 1.0A max.
(burg, fire, burg/fire) installations. Total alarm current resistive loads. See note 1.
ALARM POLARITY SHOWN POINT 1-8 NOTES N.C. N.C. N.C. N.C. N.C.
is limited to 2.3A, see note 1. Short pins 1 & 2 on P4. • All points provide Style B supervision N.C. N.C. N.C.
ALL CIRCUITS ARE POWER
• Point resistance (excluding EOLR): LIMITED EXCEPT THE OUTPUT
FIRE CKTS: Supervise using 2k EOLR. - Points 1, 2: 100 ohms max
Use polarized sounding devices. - Other points: 300 ohms max N.O. N.O. N.O. N.O. N.O. N.O. N.O. N.O. OF THE 472404 TRANSFORMER
BURG CKTS: Supervision not req'd. • Point response: 350 - 500mS (all points)
2k (note 2) 2k 2k 2k 2k 2k 2k 2k + -
EOLRs not req'd. May use non • Ratings for points 1, 2:
polarized devices. Ratings: 12VDC, 1.7A max. - 10 - 14VDC SIM Loop
See note 1. See instructions to enable/disable - 2mA max for smoke det. (up to 16 detectors Points 3 & 4 may Bell Box
supervision and for compatible devices. of the type specified in the instructions be set for a Style "D" Tamper
can be used) configuration.
• UL compatibility ID: A
Do not mix fire and burg. sensors on one loop.
N.C. contacts for burg. usage only.
Copyright 1999
¬.9Jl
K3471-1V1 4/01
