NAVIGATIONAL WATCH
ADVANTAGES
• Cheap, self-contained, simple, not easily damaged
• Does not need power source to operate
• Heading display is analog
• Can be compensated for magnetic deviation by the use of adjusting magnets
DISADVANTAGES
• Magnetic north is not fixed so compass requires regular adjustment.
• Must be corrected for magnetic variation
• Compass must be located at the steering station for reading by the helmsman.
GYRO COMPASS
• Always points to the true geographic north. Electro-mechanical device containing fast spinning
gyroscope
• Unaffected by earth’s magnetism and that of the Ship
2
Ratings Forming Part of a Navigational Watch
ADVANTAGES
• Acquire bearing data even when there exist a magnetic deviation.
• Can be located remotely or at the steering station.
• Can feed heading readings to one or more remote readouts.
DISADVANTAGE
• Loses orientation as earth rotates unless torque is applied to opposite direction.
• Far more expensive to install than magnetic compass.
• Repair requires expensive, sometimes not locally available professional help.
HELM ORDERS
• STANDARD WHEEL ORDERS
• Should be repeated by the helmsman and the officer of the watch should ensure that they are
carried out correctly and immediately
• Orders should be held until countermanded
• Helmsman should report immediately if the vessel does not answer the wheel
EXAMPLE
• COMMAND
o Midship
• REPEAT
o Midship
• EXECUTE
o Put the Ruddle to Midship
• REPORT
o Rudder Midship
• ACKNOWLEDGED
o Thank you
RUDDER MIDSHIP
ORDER MEANING
3
Ratings Forming Part of a Navigational Watch
PORT 1O°
ORDER MEANING
4
Ratings Forming Part of a Navigational Watch
STARBOARD 1O°
ORDER MEANING
Ease to Five Reduce amount of rudder to 5° and hold
Ease to Ten Reduce amount of rudder to 10° and hold
Ease to Fifteen Reduce amount of rudder to 15° and hold
Ease to Twenty Reduce amount of rudder to 20° and hold
ORDER MEANING
Keeping the vessel on its designate course or steer a steady course on the compass
heading indicated at the time of the order. The helmsman is to repeat the heading on
STEADY
receiving the order.
When the ship is steady on that heading, the helmsman is to call out: “Steady”
STEADY AS THE
To steer the ship on her designated course as ordered.
GOES
CONTINUATION
• Keep the buoy/mark/beacon on post/starboard. Report to the master or officer when the ship
does not respond
• Finished with the wheel – ordered after the maneuver given by the master
5
Ratings Forming Part of a Navigational Watch
“Very well”
“Steady!” Steady to course to 069o until further oder.
CHANGE OVER FROM AUTOMATIC PILOT TO HAND STEERING & VISE VERSA
Kinds of Steering
MANUAL STEERING
Required when the vessel enters or leaves a port, or navigates in narrow channel or congested areas
or in restricted visibility.
AUTOMATIC STEERING
Steering gear is switch over to the automatic position when ordered by the Master to the Officer of the
Watch when the vessel starts ocean transit or sails away from the coast
NON-FOLLOW UP
Steering is impossible in both automatic and manual modes, the control level (non-follow up steering) is
used
EMERGENCY STEERING
Steering control on the navigation bridge fails to operate, steering is still possible by operating the trick
wheel in the steering engine compartment.
LOOKOUT
• maintain a continuous state of vigilance by sight & hearing, as well as by all other all available
means, with regards to any significant changes in the operating environment.
• Fully appraising the situation & the risk of collision, standing & other dangers to navigation.
A lookout is a person at the ship’s bridge who maintains a continuous watch of the sea to report any
kind of hazard that can be an obstacle in the navigation & cause harm to the ship.
According to COLREG, a lookout is required to give his uninterrupted attention at all times to the ship’s
navigation in order to inform the officer on watch (OOW) about other ships, shipwrecks, debris, floating
objects etc.
6
Ratings Forming Part of a Navigational Watch
The lookout should remain at his position at all times until he is relieved from his duties.
On relieving, he should provide all the information to his reliever about things that he has reported.
Reporting of the navigational lights & shapes to determine another vessels course
7
Ratings Forming Part of a Navigational Watch
Report the approximate bearing of sound signals, lights and shapes or other objects using
degree or points
8
Ratings Forming Part of a Navigational Watch
IDENTIFY THE LIGHTS, SHAPES AND SOUND SIGNALS BY DIFFERENT TYPES OF VESSELS
AIR CUSHION means a craft capable of travelling over land, water, mud or ice and other surfaces.
9
Ratings Forming Part of a Navigational Watch
10
Ratings Forming Part of a Navigational Watch
11
Ratings Forming Part of a Navigational Watch
PILOT VESSEL
12
Ratings Forming Part of a Navigational Watch
MINESWEEPER
SOUND SIGNALS
WHISTLE - SHORT BLAST 1 SECOND
IN SIGHT VISUALLY
(maneuvering & warning signals)
RULE 34
A. Crossing or meeting head-on PDV, “ I am altering course to starboard” “I am altering course •
to port” “ I am operating astern propulsion” ••
•••
B. Overtaking (In narrow channel or “ I intend to overtake you on your starboard side” “ I intend to ––•
fairway) overtake you on your port side” “ I agree to be overtaken and ––•
shall take steps to permit safe passing” •
–•–
•
C. Obscured bend (clear visibility) Vessel nearing a blind bend in a channel (also the answering -
signal)
D. If in doubt or in danger I am in doubt about your intention or action •••••
13
Ratings Forming Part of a Navigational Watch
IN RESTRICTED VISIBILITY
(fog signal)
RULE 35
A. PDV, underway and making way Every 2 Minutes -
NOTE:
• The signal • •• ••• ••••• maybe supplemented by a corresponding light signal
• Whistle signal – every 2 minutes
• Bell and gong signal – every 1 minute
• 12m or more in length – whistle and bell
• 100m or more in length – whistle + bell +gong
• Less than 12m in length – any efficient sound signal
14
Ratings Forming Part of a Navigational Watch
2 Regions:
o Region A – Europe, Australia, New Zealand, Africa, the Gulf and some Asian country.
o Region B – North, Central & South America, Japan, North & South Korea & Philippines.
15
Ratings Forming Part of a Navigational Watch
5 TYPES OF MARKS
• Lateral Marks
• Cardinal Marks
• Quick & Very Quick Light Rhythms
• Isolated Danger Marks
• Safe Water Mark
LATERAL MARKS
• indicate the edge of the channel
• A channel & indicate the port & starboard sides of the navigation route to be followed into a
waterway such as a harbor, river or estuary from seaward. The vessel should keep port marks
to its left & keep starboard marks to its right.
16
Ratings Forming Part of a Navigational Watch
CARDINAL MARKS
• Indicate the position of a hazard & the direction of safe water.
• Indicates the direction of safety as a compass direction relative to the mark.
• It is named after the quadrant in which it is placed.
• Yellow & black markings and top marks
17
Ratings Forming Part of a Navigational Watch
18
Ratings Forming Part of a Navigational Watch
SPECIAL MARKS
Indicate an area or feature such as speed restrictions, recreation zones, mooring buoys or cable &
piping lines including outfall sewerage pipes.
19
Ratings Forming Part of a Navigational Watch
20
Ratings Forming Part of a Navigational Watch
REGION A
REGION B
21
Ratings Forming Part of a Navigational Watch
INTERNAL COMMUNICATIONS
• Communication in the ship, such as public address, telephone, engine order telegraph, and dial
or sound telephone system
• Essential in orderly performance of both emergency and routine shipboard practice
• Dial telephone
• Sound powered phone
system
• Public address system
GENERAL ALARM
• 7 short blast and 1 long blast
• The general alarm is sounded to make aware of the crew on board that an emergency has
occurred.
SHIP’S WHISTLE
A ship’s horn is known as whistle and it is generally provided in duplicate. One is driven by air and the
other is electrically operated.
VHF
• Use to transfer & receive message
• Helpful in sending distress signal
• Channel 16
FREQUENCIES OF VHF
• CHANNEL 6
• Internship Freq.
• CHANNEL 15
• Internship freq.
• CHANNEL 16
• Safety, Distress, Emergency freq.
• CHANNEL 17
• Internship freq.
• CHANNEL 67
• Search and Rescue Freq.
22
Ratings Forming Part of a Navigational Watch
- Not undertake any other duties that would interfere or compromise the keeping of a safe
navigational watch
ENVIRONMENTAL PROCEDURE
MARPOL
- Signed 17 February 1973
- Into force 02 October 1983
- It was designed to minimize pollution of the seas, including dumping, oil and exhaust pollution.
- Its stated object is to preserve the marine environment.
MARPOL Annexes
• Annex 1 – Oil
• Annex 2 – Noxious Liquid Substance
• Annex 3 – Harmful Substances Carried By Sea In Package Form
• Annex 4 – Sewage
• Annex 5 – Garbage
• Annex 6 – Air Pollution
Annex 1 – Oil
• Oil means petroleum in any form including crude oil, fuel oil, sludge, oil refuse and refined
products.
• Entered into force 2nd October 1983
• It contains regulations for the prevention of pollution by oil.
23
Ratings Forming Part of a Navigational Watch
Discharge of Oil – the regulation govern the discharges, except for clean or segregated ballast, from all
ship.
- Chemical tankers built after 01 July 1986 to comply with IBC (International Bulk Chemical
Code) code.
- Chemical tankers built before 01 July 1986 should comply with the requirements with BCH
(Code of Construction and Equipment of ships carrying Dangerous Chemical in Bulk) Code.
• CATEGORY X
• if discharged into the sea from tank cleaning or deballasting operations, are deemed to
present a major hazard to either marine resources or human health and, therefore,
justify the prohibition of the discharge into the marine environment
• CATEGORY Y
• if discharged into the sea from tank cleaning or deballasting operations, are deemed to
present a hazard to either marine resources or human health or cause harm to
amenities or other legitimate uses of the sea and therefore justify a limitation on the
quality and quantity of the discharge into the marine environment
• CATEGORY Z
• if discharged into the sea from tank cleaning or deballasting operations, are deemed to
present a minor hazard to either marine resources or human health and therefore
justify less stringent restrictions on the quality and quantity of the discharge into the
marine environment
24
Ratings Forming Part of a Navigational Watch
• CATEGORY OS
• substances which have been evaluated and found to fall outside Category X, Y or Z
because they are considered to present no harm to marine resources, human health,
amenities or other legitimate uses of the sea when discharged into the sea from tank
cleaning of deballasting operations.
- Part A of SOLAS Chapter VII - Carriage of dangerous goods, which includes provisions for the
classification, packing, marking, labeling and placarding, documentation and stowage of
dangerous goods.
- “harmful substances” are those identified as “marine pollutants” in the IMDG Code.
SEWAGE
- Drainage and other wastes from any form of toilets and urinals
- Drainage from medical premises (dispensary, sick bay, etc.) via wash basins, wash tubs and
scupper located in such premises;
- Drainage from spaces containing living animals
- Other waste water when mixed with the drainages defined above.
- Entered into force on 27 September 2003.
- Revised on 01 April 2004
- Revision entered into force on 01 August 2005.
- Revised annex applies to new ship engaged in international voyages of 400gt or more which
certifies to carry more than 15 persons.
- Existing ships shall comply after 5 years after the date of entry.
ANNEX V: GARBAGE
GARBAGE
All kinds of victual, domestic and operational waste excluding fresh fish and parts, generated during the
normal operation of the ship and liable to be disposed of continuously or periodically except those
substances which are defined or listed in other annexes to the present convention.
25
Ratings Forming Part of a Navigational Watch
GARBAGE CATEGORIES:
• Plastic – consist of plastic in any form, including synthetic ropes, synthetic fishing nets, plastic
garbage bags and incinerator ashes from plastic products.
• Foodwaste – spoiled or unspoiled food substance. Food wastes may be discharged at sea
under specific circumstances / requirements.
• Domestic waste – garbage generated mainly in the accommodation space on board the ship.
Garbage in this category is prohibited to be discharged at sea.
• Cooking oil – edible oil or animal fat used for the preparation or cooking of food.
Prohibited to be discharged at sea
• Incinerator ashes – ashes and clinkers resulting from shipboard incinerators used for the
incineration of garbage.
• prohibited to be discharged at sea.
• Operational waste – solid waste (including slurries) that are collected on board during normal
maintenance or operation of the ship, or used for cargo stowage and handling.
• prohibited to be discharged at sea.
• Cargo residues – remnants of any cargo which remain on the deck or in holds following
loading or unloading.
To be able to discharge at sea they should not be harmful to the marine environment.
• Animal carcasses – bodies of any animals that are carried on boars as cargo and that die or
are euthanized during voyage.
Discharge of such waste permitted at sea under specific circumstances/requirements.
• Fishing gear – physical device that may be placed on or in the water or on the sea-bed with the
intended purpose of capturing marine or fresh water organism.
Prohibited to be discharge at sea.
26
Ratings Forming Part of a Navigational Watch
27
Ratings Forming Part of a Navigational Watch
MUSTER LIST
A list which is displayed in prominent areas of the vessel so that every crew member onboard can read
it on a go.
28
Ratings Forming Part of a Navigational Watch
General Alarm
• 7 short and one long blast
LIFERAFT
Minimum capacity
• 6 or more but not more than 50 persons
29
Ratings Forming Part of a Navigational Watch
30
Ratings Forming Part of a Navigational Watch
LIFERAFT MARKINGS
- In English
- Must be on a plate or label sufficiently to withstand continuous exposure to environmental
conditions
- Manufacturer’s model identification
- Maximum capacity
RESCUE BOAT
- Rigid or inflatable
- Not less than 3.8m & not more than 8.5m length
- Speed at least 6 knots for a period of 4 hours
- Full complement speed of 2 knots.
31
Ratings Forming Part of a Navigational Watch
DISTRESS SIGNALS
- Radio
- Code flags
- Sound signal
- Flares
- Flashlights
- Arm signal
VHF
- Switch off the transmitter immediately
- Switch equipment on and set to channel 16
- Make broadcast to “all stations” giving the ship’s name, call sign and DSC number, and cancel
the false distress alert
VHF example:
- All stations, all stations, all stations
- This is MT Kenshin, call sign LAGC6
- DSC number, position
- Cancel my alert of 18 May 2015, 1432H
- Capt. Niriko Himura, call sign LAGC6
MF
- Switch off equipment immediately
- Switch equipment on and tune for radiotelephony transmission on 2,182khz
- Make broadcast to “all stations” giving the ship’s name, call sign and DSC number, and cancel
the false distress alert
INMARSAT C
- Notify the appropriate RCC to cancel the alert by sending a distress priority message via the
same CES through which the false distress alert was sent.
INMARSAT C example:
• MT Kenshin, LAGC6, IMO – 4457825,
• Lat 45º 42.5ºN Long 004º 21.4ºE,
• Cancel my Inmarsat-C distress
• alert of 20 May 2015, 1458H UTC
• = Capt. Nikita Himura
EPIRB
- The ship should contact the nearest coast station or an appropriate coast earth station or RCC
and cancel the distress alert.
32
Ratings Forming Part of a Navigational Watch
Course Compendium:
A1 Instructor’s Guide
A2 Handouts
Video Materials:
V1 How to use an EPIRB
V2 Radios, Flares, Phones & Signals – Boat Safety in NZ – Maritime New Zealand
V3 SART Course Maintenance Video Manual
Reference:
R1 International Maritime Organization (IMO). (2011). International convention on standards of
training, certification and watchkeeping for seafarers (STCW), as amended (3rd Ed). UK: IMO
R2 International Maritime Organization (IMO). (2003). Convention on the International Regulations
for Preventing Collisions at Sea, 1972 (4th ed.). London, UK: IMO.
R3 International Maritime Organization (IMO). (2011). MARPOL (5th ed.). London, UK: IMO.
R4 International Maritime Organization. (2002). IMO standard marine communication phrases. (1st
ed.). London, UK: IMO
R5 International Maritime Organization (IMO). (2009). SOLAS (5th ed.). London, UK: IMO.
R6 International Maritime Organization (IMO). (2010). Life saving appliances including LSA Code
(2nd ed.). London, UK: IMO.
R7 International Maritime Organization (IMO). (2011). General requirements and performance
standards for shipborne radio communications and navigational equipment. (6th ed.). London,
UK: IMO.
R8 International Maritime Organization (IMO). (2005). International code of signals. (4th ed.).
London, UK: IMO.
R9 International Maritime Organization (IMO). (2009). Global maritime distress and safety system
manual (5th ed.). London, UK: IMO.
R10 International Maritime Organization (1985). Standard marine navigational vocabulary.
Retrieved from
http://www.ctu.cz/cs/download/zkousky-prukaz/standard-marine-navigational-vocabulary_may-
1985.pdf
R11 International Maritime Organization (IMO) & International Civil Aviation Organization (ICAO).
(2008). IAMSAR manual: vol. I organization and management. (7th ed.). London, UK &
Montreal, Canada: IMO & ICAO.
R12 International Maritime Organization (IMO) & International Civil Aviation Organization (ICAO).
(2008). IAMSAR manual: vol. II mission co-ordination. (4th ed.). London, UK & Montreal,
Canada: IMO & ICAO.
R13 International Maritime Organization (IMO) & International Civil Aviation Organization (ICAO).
(2013). IAMSAR manual: vol. III mobile facilities. (9th ed.). London, UK & Montreal, Canada:
IMO & ICAO.
33
Ratings Forming Part of a Navigational Watch
Publications:
P1 Admiralty Charts & Publication. (2009). The mariner’s handbook (9th Ed.). UK: United Kingdom
Hydrographic Office.
P2 Bist, D. S. (2000). Safety and security at sea. A guide to safer voyages. (1st ed.). Oxford:
Butterworth-Heinemann.
P3 Bowditch, N. (2002). The American practical navigator. (2002 bicentennial ed.). Bethesda,
Maryland: National Imagery and Mapping Agency.
P4 Cockcroft, A. N. and Lameijer, J. N. F. (2004). A guide to collision avoidance rules.
Incorporates the 2009 amendments (7th Ed.). Oxford, UK: Butterworth-Heinemann.
P5 Cockcroft, A. N. Rev. ed. (2004). Nicholls’s seamanship and nautical knowledge. (28th Ed.).
Glasgow, Great Britain: Brown, Son & Ferguson, LTD.
P6 International Chamber of Shipping & International Shipping Federation. (2010). Guidelines on
the application of the IMO international safety management (ISM) code. (4th ed.). London, UK:
Marisec Publishing.
P7 International Chamber of Shipping & International Shipping Federation. (2011). Guidelines on
the IMO STCW convention including the 2010 Manila amendments. (3rd ed.). London, UK:
Marisec Publishing.
P8 International Chamber of Shipping. (2007). Bridge procedures guide. (4th ed.). London, UK:
Marisec Publications.
P9 Klinkert, J. (1976). Compass-wise or getting to know your compass. (1st ed.). Glasgow, Great
Britain: Brown, Son & Ferguson, LTD.
P10 Maritime and Coastguard Agency. (2010). Code of safe working practices for merchant
seamen. Consolidated ed. 2010. London, UK: TSO.
P11 Noel, J.V. Jr. (Ed.). (1989). Knight’s modern seamanship. (18th ed.). Canada: John Wiley and
Sons, Inc.
P12 Pursey, H. J. (2002). Merchant ship construction especially written for the merchant navy for
merchant seamen. (7th Ed.). Brown, Son & Ferguson, LTD.
Web References:
W1 http://www.marineinsight.com/tech/auxiliary-machinery/general-overview-of-types-of-pumps-on-
ship/
W2 http://www.brighthubengineering.com/marine-history/84795-types-of-shipboard-cranes/
W3 International Maritime Organization (1985). Standard marine navigational vocabulary.
Retrieved from
http://www.rtna.ac.th/article/Standard%20Marine%20Navigational%20Vocubulary.pdf.
W4 Surface Preparation. Retrieved from
http://www.osha.gov/SLTC/etools/shipyard/shiprepair/surfaceprep/index_sp.html
W5 International. Onboard Maintenance Painting Guide. Retrieved from
http://www.internationalmarine.com/Literature/Onboard%20Maintenance%20Painting%20Guid
e.pdf
34
Ratings Forming Part of a Navigational Watch
35
