INTRODUCTION

This book was written for industrial managers and others, military
or commercial, who know very little about Configuration Man-
agement (CM) but still have to deal with it. CM is usually learned
in a haze of hair-splitting jargon, confusing regulations, obscure
specifications, and endless confrontations none of which are easy.
Too often the result is frustration, misunderstanding, and anger.

In this book, small as it is, I have tried to provide a straightforward

explanation of what CM is, what it does, how it works, and why. I
have avoided the “Army Way” or the “Navy Way” in favor of the
generic way. It’s candid, unorthodox, based on solid experience1,
and most likely politically incorrect. It’s written in common Eng-
lish however it does presume a reasonable understanding of engi-
neering, manufacturing, procurement, deployment, and their rela-
tionships.

A number of side issues were left out of the basic text in favor of
brevity. However, they are covered in the separately downloadable
Appendix. This material is not essential to understanding generic
CM. However, much of it is helpful in understanding people’s be-
havior.

This book is neither a commercial venture nor the prelude to one. I

am fully retired and intend to remain so. However, I will try to an-
swer genuine questions about the content as time and energy allow.
I can be reached at cmg@netlink.net

If you find that this effort helps your understanding of CM please

tell others. No other advertising campaign is planned. If the book
has merit word of mouth will do the job.

1
Detailed in the Appendix for those who care about such things.

5
Generic CM Rev. 1

1. VIEW FROM THE TOP

CM is a discipline that keeps an evolving product

aligned with the need for it.

The Discipline
Locate applicable engineering requirements.
Perform work in accord with those requirements.
Document the work.
Identify the work.
Verify compliance with the requirements.
Release the documents.
Change Control the documents

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product M ajor Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product

Fig. 1 Generic CM

If you can understand the elements and relationships in Figure 1, you will understand CM. It’s
not that hard. But before we look at its pieces let’s consider why we have it at all.

CM exists to prevent design drift. It may seem odd, but during the life of a program (5 – 15
years) it was quite possible for say a fighter design to morph into an unintended fighter-bomber
before responsible people realized that the design was drifting. There were other similar diver-
sions. Ignorance or innocence, poor instruction, human error, misguided engineers, and deliber-
ate misuse of government resources are among the causes. During the 50’s and 60’s the problem
became intolerable and the Air Force took the lead in finding a solution. Configuration Manage-
ment, System Engineering, and Weapon System Management were among the corrective actions.
If all of this seems farfetched it’s a matter of record and there are still a number of us able to at-
test to its reality.

Now, let’s consider the pieces.

***

6
Rev. 1 Generic CM

2. WHAT IS IT?

CM is a discipline that keeps an evolving product

aligned with the need for it.

Fig. 2 Definition

A discipline is specialized know-how; in this case how to establish and maintain

alignment of the product with the need for it.

An evolving product is one undergoing design, development, or modification.

The product is kept in alignment during its evolution because it’s much less ex-
pensive than realignment afterward.

A product is aligned with need when it does (or will in the case of an evolving
product) meet the need for it.

There are other far more official definitions than this one. However, the reader must know CM
before they are understandable. Though sometimes useful in bureaucratic infighting, for us it’s
self-defeating.

Some may find the use of the term ”alignment” unusual. However, it replaces convoluted com-
mentary on the reason for CM with a simple idea. CM exists to see that a product meets the spe-
cific need for it.

CM is always a means and never an end in itself!

***

7
Generic CM Rev. 1

3. THE DISCIPLINE

Locate applicable engineering requirements.

Perform work in accord with those requirements.
Document the work.
Identify the work.
Verify compliance with the requirements.
Release the documents.
Change Control the documents

Fig. 3 The Discipline

It’s important to recognize that every one of the elements listed above was in use long before
CM came along. The Air Force simply borrowed them when it created the Discipline. However,
the view that CM is nothing more than a new name for old practices is incorrect. The point to the
Discipline is not the elements it applies but the way that it applies them. However, before going
there let’s be sure we have a common understanding of these elements.

Requirements
Engineering Requirements are usually things that must be done to complete the design, turn it
into working hardware, or maintain and repair the product. They also include the physical and
functional interfaces that the item must meet along with test, safety, shipping, maintenance, and
repair provisions.

Work
Work produces the item(s) called for by the requirements. It may be hardware, further detailed
design, or maintenance and repair instructions.

Documentation
Documentation communicates information generated by the work to people or to machines, near
or far, now or in the future.

Identification
Identification distinguishes one thing from another precisely by using a unique identifier.

Verification
Verification proves that documentation or hardware complies with the requirements for it.

8
Rev. 1 Generic CM

Release
Release makes verified documentation available to down-stream functions and maintains an ac-
curate record of it.

Change Control
Change Control maintains the integrity of released (verified) items by approving or disapproving
changes to them.
***

9
Generic CM Rev. 1

4. PHASES & BASELINES

A phase is a block of time and a package of work with a discrete beginning and end. Phasing is a
program planning practice intended to make programs more manageable. CM depends upon and
influences phases but defining them is a program-planning task.

The best phasing is compatible with the product, the program, the industry, and the buyer. Most
industries have evolved patterns that work for their products. However, in every case, phasing
should be carefully tailored to fit the specific product and program. There is no standard formula!
It’s a matter of informed judgment.

Figure 4 displays a common model of program phases before CM while Figure 5 shows common
program phases after CM was created

Design Build/Test Build/Test Deploy

Prototype Refine Deliver Maintain
Prototype Product Repair
Product

Fig. 4 Phases Pre CM

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product Major Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product

Fig. 5 Phases Post CM

Phases 1 & 2 were forced into being by the CM requirement to have a full and formal functional
definition of the product before detail design begins; a requirement discussed in the next section.

In a different situation some of these phases might be combined or eliminated while others might
be divided. The names would no doubt differ but the concept would remain the same. Phase the
program to fit the product and the need.

Baselines: A baseline is a line serving as a basis, e.g. for measurement, calculation, or location.
Since the authors of CM expected all three, they required several baselines and permitted others.
In fact it is both possible and desirable to end Phases 1 through 4 with a baseline as shown in
Figure 6. (Phases 5 & 6 produce changes to the Product Baseline but do not generate a new one.)

10
Rev. 1 Generic CM

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product Major Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product
Functional Allocated Prototype Product
Baseline Baseline Baseline Baseline

Underlined Baselines are required; the others are optional.

Fig. 6 Baselines

• Functional Baseline = documents containing the functions of the system

• Allocated Baseline = documents containing system functions allocated to major compo-
nents.
• Prototype Baseline = documents containing the detailed design from which the Prototype
is built.
• Product Baseline = documents containing the detailed design from which the product is
built, maintained, and repaired.

We often make a buzzword out of baseline and attribute all kinds of powers to it. It’s important
to remember that there is no magic there. It is simply a symbol that stands for (1) a particular set
of documents and (2) the point at which Change Control of those documents begins. There are
other ways to do it but the baseline concept is a very useful convenience.

Baselines are established for each Phase by Release as shown in the boxed text below.

The Discipline
Locate applicable engineering requirements.
Perform work in accord with those requirements.
Document the work.
Identify the work.
Verify compliance with the requirements.
Release the documents. Establish Baseline
Change Control the documents

Fig. 7 Establishing Baselines

***

11
Generic CM Rev. 1

5. HOW IT WORKS

The Discipline is applied to each phase of the program.

The Discipline
Locate applicable engineering requirements.
Perform work in accord with those requirements.
Document the work.
Identify the work.
Verify compliance with the requirements.
Release the documents.
Change Control the documents

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product M ajor Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product

Fig. 8 Applying the Discipline

Phase 1. Define the Product

Locate Requirements: In the beginning the applicable engineering requirements for Phase 1 must
be derived from the need for the product.

Need
Strategists and tacticians derive need from threat analysis. They may describe it in detail
or as the concept for a product to be developed. CM does not define or evaluate need. It
cannot distinguish a genuine need from a phony one. It will foster either one with equal
vigor.

Establishing need is a difficult job. Elements of Congress or the White House may be in-
volved. Budgets will be impacted. Doubtful approaches may require feasibility studies.
Contractors may or not participate but they don’t make the decisions. All of this work and
more is repeatedly reviewed, critiqued, and revised. The process is quite formal and pro-

12
Rev. 1 Generic CM

ceeds through stages. It may take weeks, months, or years. When the time comes, the re-
sponsible authority makes the critical decision and “need” is established or the effort is
shelved.

For the military, law, regulation, or directive defines the “responsible authority”. In the
commercial world need is better known as opportunity and is identified by the upper
management of the company. With need established, a program can be defined (phased)
and CM begins.

The Work: A product can be defined in terms of what it is (physically), what it does (function-
ally), or both. At this stage of development, it’s necessary to define the product functionally; that
is, by stating the functions it must perform to satisfy the established need. However, if a major
component such as an aircraft engine already exists it will be described by its top-level identifi-
cation and that includes its physical characteristics.

System Engineers define the product by translating the functions it must perform into engineer-
ing terms suitable as requirements to be met by detail design engineers. The job is difficult. It
must do enough but not too much.

Over Specification
Over-specifying is the practice of defining unnecessarily stringent requirements in the
hope that the extra effort needed to achieve them will assure that the real requirements
are met. This practice can turn up at almost any point during a program but when it oc-
curs at the beginning the consequences are more severe and longer lasting. Every engi-
neering decision becomes more difficult to make and to implement until the truth sur-
faces. The consequence is usually greater cost, wasted time, and increased change vol-
ume. Over-specifying seldom achieves its goal. Those who define need or convert it into
engineering requirements have a heavy obligation. Meeting it is both art and science.

Document & Identify: The requirements are documented, usually in a specification often called
the System Specification, and identified with a specification number.

Verify: The finished specification is evaluated by another set of experts. Their job is to determine
that it does or does not meet the established “need”. If it does we go forward. If it doesn’t, it is
corrected.

Release & Change Control: The verified System Specification is released which establishes the
System Baseline and places its content under Change Control.

As we leave Phase 1 please note that each element of the Discipline has been applied in the se-
quence specified in Figure 8. These elements in this sequence will be applied to each phase of
the program.
__________

13
Generic CM Rev. 1

Phase 2. Define Major Components

Originally, a separate specification was to be written for each major component of the product.
Each specification was assigned to a group of design engineers who designed the physical com-
ponent accordingly. Initially, this approach worked but not well.

The System Engineers who write the component specifications were given to over speci-
fying which was deeply resented by the Design Engineers who had to meet unrealistic re-
quirements.

In most cases Design Engineers were quite capable of working with the System Specifi-
cation. Further definition was seldom necessary. So the whole Component Specification
notion was seen as overkill.

Much hemming and hawing resulted in the phase being made optional and it was oftentimes
abandoned. But this action ignores at least two situations. When a component is to be designed
by a subcontractor a separate specification for the design of that component is necessary for
clarity and reference in the subcontract. When a component is to be supplied by the government
a separate specification of exactly what is to be supplied will prevent major misunderstanding.

In multi-division corporations it is not uncommon to have the basic program under the control of
one division while another division designs a major component of the product. It is usually wise
to have a component specification or equivalent to control the design work to be done by the
other division. It’s easy to get into trouble without one.

Now, it’s altogether practical to combine Phases 1 & 2 by having necessary component specifi-
cations prepared as a second task in Phase 1. On the other hand there is a great advantage to
having the product requirements thoroughly settled in Phase 1 before becoming involved with
the snarls of major components. A Phase 2 also provides an additional checkpoint for the pro-
gram.

The Program Manager designates the components that will be subject to separate specification.
Generally they will be subcontracted or government furnished items but they can be other items
that he feels require special treatment. It is not uncommon for the customer to require special
treatment for one or more items for his own purposes.

Locate Requirements: The requirements to be allocated (assigned) to major components are lo-
cated in the System Specification.

The Work: System Engineers allocate (assign) requirements from the System Specification to
each major component.

Document & Identify: The requirements are usually documented in a specification for each ma-
jor component and identified with a specification number. (These specifications are referred to in
this book as Component Specifications.)

14
Rev. 1 Generic CM

Verify: Each Component Specification is evaluated by another set of experts. Their job is to de-
termine that it does or does not meet the requirements of the System Specification. If it does,
things go forward. If it doesn’t, it is corrected.

Release & Change Control: Verified Component Specifications are released which establishes
the Allocated Baseline and places its content under Change Control.
__________

Phase 3. Design Prototype.

Locate Requirements: The requirements for this phase are in the System Specification (from
Phase 1) and the Component Specifications (from Phase 2).

Subcontract: Issue subcontracts as appropriate referencing the applicable Component Specifica-

tion from Phase 2.

The Work (for both Sub and Prime Contractors): Detail Designers meet Phase 1 & 2 require-
ments by selecting and arranging parts and materials to perform the functions required. Test En-
gineers develop methods (usually demonstrations) to prove that the functional requirements have
been met.

Document & Identify: The detail design requirements and tests are usually documented in
drawings, specifications, and text procedures identified with document numbers.

Verify: Other experts, most often checkers and editors, examine each document. Their job is to
determine that it does or does not meet the requirements of its next assembly. If it does, things go
forward. If it doesn’t, it is corrected.

Release & Change Control: Verified drawings, specifications, and test procedures are released
which establishes the Prototype Baseline and places its content under Change Control.
__________

Phase 4. Build, Test, & Refine Prototype.

Locate Requirements: The requirements for this phase are found in the drawings, specifications,
and test procedures created during Phase 3.

The Work (Task 1 - Build): Technicians and mechanics fabricate and assemble parts and materi-
als into one or more prototypes.

Verify: Their work is inspected to assure compliance with requirements.

15
Generic CM Rev. 1

The Work (Task 2 - Test): Technicians run the test (demonstrate) the prototype(s) and record the
results.

Document & Identify: The results are documented in a test report identified with a document
number.

Verify: The report is evaluated to assure compliance with the requirements. This is the acid test
for a program. The test procedures are designed to show that the prototype does or does not meet
the requirements defined in the Phase 1 & 2 specifications (which contain the need in engineer-
ing terms). Every reasonable effort is made to conduct such tests under conditions as close to
those in actual deployment as possible. If the prototype fails these tests, corrective action is re-
quired. If it passes, a suitable celebration follows and the work goes forward.

The Work (Task 3 - Refine): Oftentimes the techniques used to produce the prototype are unsuit-
able for volume production. So production specialists review the prototype design for produci-
bility and recommend refinements (changes) to enhance production. Acceptance test methods are
defined to prove that production hardware meets its requirements.

Document and Identify: The proposed changes are documented in Change Proposals and identi-
fied with Change Proposal Numbers. Acceptance tests are documented in procedures and identi-
fied with document numbers.

Verify: Proposed changes are evaluated to assure that they will not degrade hardware perform-
ance. Acceptance tests are evaluated for adequacy.

Release & Change Control: The Prototype drawings, specifications, and test procedures along
with verified changes to them are released which establishes the Product Baseline and places its
content under Change Control.

_________

Phase 5. Build/Test Deliver Product.

Locate Requirements: The requirements for this phase are found in the Product Baseline; the
drawings, specifications, and test procedures released at the end of Phase 4.

The Work: Technicians and mechanics fabricate and assemble parts and materials into products.
Maintenance Engineers prepare such instructions and manuals as may be required to maintain
and repair the product in the field.

Document & Identify: Proposed changes if any to Product Baseline Documents are documented
in Change Proposals and identified with Change Proposal Numbers. Maintenance and repair in-
structions are documented, usually as Manuals, and identified with manual numbers.

16
Rev. 1 Generic CM

Verify: The hardware is subject to acceptance inspection (examination and test) to assure that it
conforms to the Product Baseline. Proposed changes if any are evaluated to assure that they will
not degrade hardware performance. Manuals are evaluated to assure that they comply with the
Product Baseline.

Release & Change Control: Verified changes if any are released as changes to the Product Base-
line and placed under Change Control. Verified manuals are released and placed under Change
Control.

Delivery: The completed product is delivered.

__________

Phase 6. Deploy, Maintain, Repair

Locate Requirements: The requirements for this phase are found in the Product Baseline; the
drawings, specifications, and test procedures released at the end of Phase 4 and any maintenance
and repair instructions or manuals released during Phase 5.

The Work: Technicians and mechanics perform routine maintenance and repair of the product as
necessary

Document & Identify: Generally this work is recorded in logbooks. Changes to the Product
Baseline are documented in Change Proposals and identified with Change Proposal Numbers.

Verify: The maintained or repaired product is subject to Acceptance Inspection (examination and
test) to assure that it continues to conform to the product Baseline. Proposed changes if any are
evaluated to assure that they will not degrade hardware performance.

Release & Change Control: Verified changes if any are released as changes to the Product Base-
line and placed under Change Control.
__________

Change Control
The product is built, maintained, repaired, or modified only in accordance with released docu-
mentation. Once something has been released it can’t be changed without going through the pro-
cedure shown in Figure 9.

Desirable
Release Implement
Propose Evaluate Approve
a the IF
Change Proposal Undesirable
Archive
Reject

Fig. 9 Change Control

17
Generic CM Rev. 1

An approved Change Proposal becomes a Change Order that is implemented by releasing it. In
due course, released changes are incorporated into the documents they change. Those changed
documents are reviewed for continuing compliance and re-released to replace the old documents
plus changes.

There is much more to be said about Change Control but this is not the place to say it. Those
with a special interest in the subject (and it is a fascinating one) should download the Appendix
where they will find it discussed at length.
***

18
Rev. 1 Generic CM

6. CHAIN OF VERIFICATION

The Chain of Verification shown in Figure 10 is the crux of CM.

1 2 3 4 5 6
Need System Detailed Prototype
Components Design Product Maintain
Repair
Product

Fig. 10 Verification
The logic is simple.

If the Product complies with the Detailed Design,

The Product meets the need,

Because the Detailed Design complies with

the Component and System Specifications,

And they specify the need in engineering terms.

Such alignment is accomplished by applying the CM Discipline:

• Identify requirements to know what needs to be done.

• Do the work.
• Document the work result to communicate it.
• Identify the work (documents or hardware) to distinguish it.
• Verify compliance with the requirements.
• Release the documents to establish a record.
• Change Control the documents to preserve their integrity.

To each phase of the program:

• Define Product
• Define Major Components
• Design Prototype
• Build/Demonstrate Prototype
• Build Product
• Maintain Product

19
Generic CM Rev. 1

At this point it’s tempting to write those fatal words, “That’s all there is to it!” because in one
sense they’re true. Yet, there is more to be touched on and we will do so. However, if you under-
stand the preceding page you understand the essence of CM.

A great deal has been said about the importance of staying aligned with need. What happens if
the need is no longer valid or there was a mistake in the definition in the first place? The answer
is move to change it! Now!

Propose a formal change to the System Specification that will correct the deficiency. If it’s ap-
proved, implement the change. This can be a major undertaking if the program is well along be-
cause changes must be made at every level of detail. Still, it must be done.

***

20
Rev. 1 Generic CM

7. SOFTWARE

Originally, enthusiasts attempted to force fit Software to CM or CM to Software. It didn’t work.

CM imposes structure and constraints. Typically Software, as an emerging technology, vigor-
ously fought any structure or constraint from any quarter, including its own.

Perspective
Initially, no one really knew what software was. Anyone who could make it work was seen as a
black art practitioner. Eventually, these practitioners evolved their own jargon, methods, and
rituals. They could do no wrong until they became exuberantly optimistic, enormously expen-
sive, and exceedingly unpredictable. This evolutionary pattern is relatively standard for any new
technology.

Emerging technologies are properly developed in feasibility programs designed to accommodate

their idiosyncrasies and develop their promise by pushing the state of the art. They do not belong
in design and development programs destined for production until they are mature enough to
withstand the rigors of need, predictability, cost, and schedule.

However, there is no formula that determines maturity and there are always those who push the
state of their art into collision with the realities of industrial practice. The result is a clash of lan-
guages, methods, and rituals. Only time, patience, and experience produce the mutual under-
standing necessary for successful integration. All new technologies pass through this trial by fire.
If they are viable, they eventually become commonplace.

Software is now commonplace. But remnants of its evolution linger and there is still much po-
tential to be developed. It’s wise to remember those facts.

As A Product Component
Software is developed by programmers to run in a hardware device developed by hardware engi-
neers. It’s easier to think of the software and hardware together as a single component that per-
forms a function. This component is often called a computer system, Figure 11, even though the
hardware may be a simple microprocessor and the software no more than a few lines of code.

Fig. 11 Simple Computer System

21
Generic CM Rev. 1

When a computer system is a component of the product, CM applies in the same way that it ap-
plies to hardware regardless of the differences in jargon. However, adjustments similar to those
required for any specific technology must be made. For instance, undimensioned drawings were
developed to accommodate the photo-etching technology. The documentation of Software may
look odd and may be recorded on a disk rather than paper but it’s still Documentation. Generic
CM does not change.

The derivation of technical requirements for Software is sometimes debated as a chicken or egg
problem. Are requirements derived from a computer that needs Software or from Software that
needs a computer? The answer is neither. They are properly derived from a function of the prod-
uct that is best performed by a computer system. Both the software and the computer must be
designed (or selected) to operate as compatible components of that computer system to perform
that function. Of course, that function has its origin in “need” passed down through the phases.
It may be identifiable in Phase 2 as a major component or not until Phase 3 as an element of the
design.

High-risk takers, hoping to achieve phenomenal breakthroughs, often use immature technology.
The consequence is really a feasibility effort embedded in a development program. It’s very
high-risk but sometimes it works. However, be mindful that the objective of a development pro-
gram is to “Do this”. For feasibility the objective is, “Can this be done”? These are not compati-
ble goals! The usual development program techniques will not work in the feasibility effort. It
should be encapsulated as a side-program until it is successful. While some elements of CM can
be helpful within the capsule, the full spectrum is seldom advisable. Participants won’t be tied
down and risk-takers exhibit effervescent certainty instead of acknowledging risk. Usually, en-
capsulation is not achieved and the development effort suffers accordingly.

The fact remains that CM is applicable to Software, as a product component, with little more ac-
commodation than that required for other evolving technologies.

As The End Product

Software is the end product for many companies. They do nothing else. However, they program
it to work in a computer or it’s useless.

The “need” in this case is derived from the computer system being developed or used by some
other organization. That system is expected to perform a specific function(s). That function must
be specified in enough detail to allow the development of software. These activities must be dis-
ciplined enough to produce a computer system that performs the specific function(s) required.
CM can and should be applied.

Commercial Market
A wide variety of computers already exist in the commercial market. Now comes a company
dreaming of a killer application. What must they do to achieve their dream?

They must know or gather the significant attributes of every existing computer model that is ex-
pected to host their application. Those attributes are one part of the “need”. The other part is the

22
Rev. 1 Generic CM

attributes of the application they expect to develop. However, this kind of “need” is soft - and
fickle.

The difficulties of development and the limitations of finance will cause computer models or
software attributes to be added or deleted. These changes can be made with relative impunity.
The only limitations are future market share, competition, and cost. These circumstances usually
turn “need” into a mush that defeats the effective application of CM. However, if the “need” is
stable, CM can be successful.

Some of these companies use one or more of the CM elements and call it CM. They are incorrect
but no great harm is done unless someone else is depending on them to use the real thing. In that
case, things come unglued.

There are many companies now offering to help others implement CM. The offer is usually
based on software products that they sell. They are likely dealing in good but mistaken faith.
Generally, these folks are offering various combinations of bundled computerized practices that
they believe constitute CM. These programs may or not integrate with various existing manage-
ment systems. The day may come when the entirety of CM is fully automated but it’s not here
yet! If you decide to consider such a product:

• Examine it against your well-defined need.

• Try before you buy!
• If it meets your need, buy it, however --
• If it’s a first generation program that will operate or impact critical activities re-
quire indemnification against consequential damages or take other protective
steps. It’s almost certain that you will need them.

***

23
Generic CM Rev. 1

8. GOVERNMENT CONTROL

Background
Commercial firms may use or not use CM in any way they like unless they choose to do business
with the government. Generally firms doing business with the military and some other agencies
are required to use CM but only as specified in their contracts. Some of what’s specified will re-
late to government control – that is, approval of original documents and subsequent changes to
them by the government customer.

Generally, controllers want more and the controlled want less. This is more than a contest of ego
and power. No control is chaotic. Complete control is paralyzing. The goal is to eliminate chaos
without paralyzing anything. Even so, there is always someone demanding more so that achiev-
ing a reasonable balance is exceptionally difficult.

The military customer will insist on control of performance, outside interfaces, supportability,
safety, and security requirements. These elements are usually stated in the System Specification.
In addition, he will want control of Demonstration Test Procedures and Acceptance Test Proce-
dures. Figure 12 displays this approach.

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product Major Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product

Approve Approve Ov ersee

System Demo Demo
Spec Tests Tests

Approve Ov ersee
Accept. Accept.
Tests Tests

Fig. 12 Government Control

The System Specification defines the functions that must be performed. The Demonstration
Tests prove that the design complies with the specification. The Acceptance Tests prove that the
manufactured product complies with the design. These elements may be difficult but they are
manageable and certainly reasonable for any prudent customer. However, they are not always
enough to warn that a program is troubled in time to prevent failure. So more controls are ap-
plied.

24
Rev. 1 Generic CM

The military buyer has legitimate reason for concern. The stakes are high. The obligations are
great. They extend from the need to adequately equip fighting forces to the control of a large part
of the pubic purse. Regrettably, unscrupulous or incompetent contractors do exist. There is a se-
rious need to find them out before they ruin a program. Even so, excessive control does more to
punish the ethical, raise the costs, and obscure the unscrupulous than it does to catch anyone. Pe-
riodic technical and management progress reviews by knowledgeable reviewers are far more ef-
fective.

Nonetheless, the government has extended its control over contractors by citing military
standards in contracts. These standards take various forms and cover most conceivable
conditions. The contractors’ plea to “tell us what you want, not how to do it” fell on deaf
ears. At the same time, contractors caused much of this excess with “can’t-be-done”
challenges that provoked “then-we’ll-tell-you-how” responses.

Acquisition Reform2
A few years ago the military became earnest about Acquisition Reform. (“Acquisition” means
procure, purchase, or buy.) In brief, the reform would:

• Stop imposing CM requirements by citing military standards. Instead, ask the

contractor how he applies CM. Evaluate his method against industry standards
and accept it if appropriate.

The military has been moving to replace the old standards with more generalized
provisions and greater reliance on CM Plans. This method will promote commu-
nication and likely result in more useful CM Plans written by the contractor,
evaluated (approved) by the government, and cited in the contract.

• Require government configuration control of performance requirements rather

than the detail design in most cases.

In simplest terms, Figure 12 presents one form of this approach. Overall, it should
provide adequate government control while removing many lower level compli-
cations.

• Base government control on adequacy of process rather than inspection of prod-

uct.

This is an established verification method often used for manufacturing processes.

In essence, if the process yields a good product use the process inspection for ac-
ceptance of the hardware produced by the process. Wider use would greatly sim-
plify many operations. It would not reduce government control but it would re-
duce the idiosyncrasies of individual reviewers and inspectors.

2
MIL-HDBK-61A
25
Generic CM Rev. 1

• Replacing military standards with industry standards whenever possible.

This approach is very helpful to firms with both commercial and defense products
because they can base their operations on one set of standards instead of two. It
also encourages the use of existing off-the-shelf commercial items that can greatly
reduce cost to the government.

There is an additional item that is related to this strategy.

• Development of a government-industry database that includes all CM information

necessary to support and maintain products (including software) during the life
cycle of the product. It may be extended to re-procurement of entire systems.

This is a laudable but formidable goal fraught with difficulty. It should have no
effect on Generic CM. However, it will require large amounts of detail managed
with exquisite precision. If implemented wisely and slowly it has the potential of
becoming a very effective tool. However, it also has the potential of smothering
CM with the effort to improve the process.

The brevity of the foregoing descriptions and comments does not demean the importance of the
effort. It is significant. Many believe that the contactors’ plea has finally been heard. However,
implementation will not alter Generic CM.

Ultimately, successful implementation depends upon competent professionals of good faith and
good sense. But, it won’t be fast. Existing programs operating under the old rules will likely
continue in that fashion. The difficulty of changing in midstream is greater than the benefit to be
realized. Changes that appear to be simple as policies are much more complicated in practice.
Both the old and the new will co-exist for some time. Therefore, both are covered in the follow-
ing sections as appropriate.

***

26
Rev. 1 Generic CM

9. CONTRACTS

If it isn’t in the contract, it doesn’t have to be done.

If it is in the contract, do it or change the contract!

For most people, contracts are part of the world’s dullest reading so they don’t read them! Most
organizations maintain a Contracts Department responsible for getting the contract right in the
first place and then telling others what it means. Unfortunately, these departments seldom in-
clude anyone who is CM sensitive let alone knowledgeable. The result is trouble for both gov-
ernment and company. The solution is to have a CM Specialist review the contract and explain
the CM Requirements.

CM Requirements
Government contracts call for CM in a wide variety of ways. It would be nice to find the re-
quirements in one place but that seldom happens. They pop up in various sections of the contract
in specifications and in other documents referenced in the contract including requirements for
technical data.

Although Acquisition Reform, discussed above, promises considerable improvement it will take
a while. Until that time comes, and most likely afterwards, it is wise to search the entire contract
for CM requirements

CM Plans - Old
CM Plans came into being in an effort to consolidate and clarify CM requirements. As with so
many things, they became additive rather than consolidating. However, they never gained high
standing as requirements. Various sections of the contract document continued to overshadow
them.

Generally a CM Plan, prepared in accordance with specified format and content, was called for
in the Request for Proposal. The Plan was expected to detail the way in which CM would be ap-
plied to the program and to some extent it did. However, for the most part, the Plans became
sales documents hyping the contractor’s CM capability.

The Plan was submitted as part of the contractor’s proposal and, after being picked at, became a
part of the contract. Thereafter, it was put on a shelf and never seen again unless a dispute devel-
oped. In that case, the parties miraculously rediscovered the Plan and began finger pointing. It
was an ignoble end for a noble effort.

Even so, it was unwise to treat the CM Plan as nothing more than a sales document. When it was
part of the contract, it could be enforced! So both parties were well advised to prune the hype.
Unfortunately, this happy outcome seldom occurred because most of the innocents assigned
couldn’t distinguish hype from reality. They were as likely to cut a necessity and expand the fluff
as not.

27
Generic CM Rev. 1

CM Plans - New
Acquisition Reform promises a major change in this situation. First the military intends to detail
its requirements and expectations in its own CM plan made available to contractors before the
first Request for Proposal is written. It expects the contractor to participate in such planning.
Second, the Contractor will produce his own CM plan that details his response to the military
plan. Both plans would likely be referenced in the contract.

This approach has an enormous potential provided that: (1) the innocents on both sides are re-
placed by competent knowledgeable people and (2) the powers-that-be pay attention to the re-
sults. Otherwise, the probable course is degeneration into a greater display of the same old sales
hype.

Requirement Development
Specific CM Requirements usually begin in a Request for Proposal. It’s hard dull work but it‘s
necessary to read the whole thing at least once, highlighting CM Requirements as you go, in or-
der to find all of them. Yes, that reading includes the boilerplate, most of the referenced docu-
ments, and most certainly any CM Plan.

Once the requirements are identified, they should be placed in a framework that displays the re-
lationship of one to another and to the basic work of the program. It’s important to understand
the consequences and then decide how the requirements will or will not be met.

Compliance considerations usually get short shrift because the emphasis at this point is on win-
ning the contract. A good CM proposal will not win and a poor one will seldom lose a contract.
Few organizations will admit to themselves that they cannot or should not meet a given CM re-
quirement. So they accept it and sometimes add embroidery.

The contractor’s proposal is submitted, reviewed, and negotiated. This is the time and place to
adjust CM Requirements if it couldn’t be done before. However, it’s awkward because the nego-
tiators really have other matters on their minds. Unfortunately, both the customer and the con-
tractor seldom have people at the table who really understand the fundamentals. So the debate
turns upon individual elements such as Documentation. They tend to overwhelm.

Again, hard dull work is necessary when the Contract is issued. It must be read again at least
once to find all of the requirements. Yes, requirements can and do change between submittal of
the proposal and issuance of the contract.

Contracting Patterns
Figure 13 displays one relatively common pattern of contracting. It is important to see that the
CM approach for the program is consulted and applied correctly each time a new contract is cre-
ated. Otherwise, the requirements in the next contract can easily become incompatible with those
in the last one. This result is particularly likely if either contractor or government personnel are
changed along with the contract. Each new person brings his perception with him. Unless it is

28
Rev. 1 Generic CM

conformed to the approach for the program it will result in new interpretations which can easily
be incompatible with all that has gone before.

This concern is even more important if the Contractor (the company) is also changed or a second
Contractor is awarded a contract pursuant to competition.

Development Production Support

Contract Contract Contract

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product Major Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product
Functional Allocated Prototype Product Product Product
Baseline Baseline Baseline Baseline Baseline Baseline
(Revised) (Revised)

Fig. 13 Typical Contracting Pattern

Subcontracting
Most major contractors engage one or more subcontractors to design certain components of the
system. In such cases, CM applies to the subcontracted components. Figure 14 illustrates such a
situation.

When verification to establish a baseline is conducted the subcontractor’s work is part of it.
When demonstration of the system is required, the subcontractor’s component is installed and
demonstrated as part of the system. All of the comments about contracting apply to subcon-
tracting as well.

29
Generic CM Rev. 1

Development Production Support

Contract Contract Contract

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product Major Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product
Functional Allocated Prototype Product Product Product
Baseline Baseline Baseline Baseline Baseline Baseline
(Revised) (Revised)

Development Production
Subcontract Subcontract

Design Build/Test Build/Test

Components Refine Deliver
Components Components

Fig. 14 Subcontracting

Competition
From time to time, the powers-that-be rediscover competition and demand greater use of it in
government procurement as a cure-all for most ills. Sometimes it lowers costs and sometimes it
doesn’t but it always complicates the management of a program. In theory, it requires a competi-
tive documentation package suitable for manufacture by any competent manufacturer. In prac-
tice, it requires enormous care and immense patience.

When the competition is for first production, the design contractor must produce the documenta-
tion package without the benefit of production proofing. This practice almost guaranties vocifer-
ous complaints from the competitor about the inadequacies of the package. Endless wrangling
and high change rates follow.

No documentation package can be considered suitable for competition until it has been through
Pilot Line and Initial Production proofing regardless of what they are called or how they are
merged. Identical performance by two contractors is impossible without, and difficult with,
enormous and expensive coordination between them. That coordination cannot take place during
a competition.

30
Rev. 1 Generic CM

When competition is required, a high change rate for one to two years should be expected and
planned for. Unfortunately, high rates usually occur but the planning does not.

Competition does appear to lower unit cost in follow-on production. Whether this happy state is
an overall cost saving depends on the cost of getting there and the duration of production. The
answer is a good subject for an MBA thesis but not for this book.

Competition does not alter Generic CM but it complicates its application and coordination be-
cause two contractors must be synchronized. The same condition applies when another contrac-
tor is introduced, without competition, to achieve the required production volumes.

***

31
Generic CM Rev. 1

10. CM ORGANIZATION

There is no optimum organizational pattern or location for CM. It’s not naturally an organization.
It’s a discipline. In the beginning, everyone was expected to learn enough CM to perform his part
of the job just like everyone must learn enough mathematics to do his job. Of course, that didn’t
happen. Conventional wisdom took hold, “If everyone is in charge, no one is in charge, so put
someone in charge.” They did but it wasn’t as effective as it sounds.

Tasks
The “Primary Tasks” in Table 1 are required to accomplish CM. The “Personnel Required” is
based upon the skills needed to perform the tasks.

Primary Tasks Personnel Required

Establish Need Strategists & Tacticians
Establish Phases Program Planners
Establish Contract Contract Analysts & Lawyers
Define CM Requirements CM Specialist

Define Product System Engineers

Define Major Components System Engineers
Subcontract, if necessary Buyers (Purchasing Agents)
Design Prototype Design Engineers & Programmers
Build Prototype Manufacturing Engineers, Mechanics, & Technicians
Test Prototype Test Engineers & Technicians
Refine Prototype Producibility & Design Engineers
Build Product Manufacturing Engineers, Mechanics, & Technicians
Test Product Inspectors & Technicians
Deliver Product Production Personnel
Maintain Product Maintenance Engineers & Technicians
Repair Product Maintenance Technicians

Document & Identify Draftsmen, Checkers, Analysts, Writers, & Editors

Verify Selected Technical Specialists, Engineers,
&Technicians
Release Release Clerks
Change Control Selected agents of all elements of the organization.
Table 1 Who Does What
Generally, the personnel required by Table 1 existed and had an organizational home before CM
was created. The only exception was the CM Specialist regardless of what we call him. Of
course, it was different for each organization but generally here’s what happened.

32
Rev. 1 Generic CM

Someone was picked to figure it out, be in charge, take responsibility, do something, etc. Of
course, he needed someone to be in charge of. So bits and pieces were taken from what once was
called Documentation and they were re-named CM. And, there had to be a place to report so he
was assigned to Administrative, Design or System Engineering, Quality Assurance, Logistics,
Contracts, etc. The ingenuity displayed was not only ingenious but also disingenuous and almost
entirely useless. The new CM organizations were without power while the organizations that had
power remained uninhibited.

Organization
A quick review of Table 1 will convince most people that there is no way to gather all of those
tasks into one organization for direction by one individual. So what’s the alternative?

When things function adequately, leave them alone. If they are not functioning, take the
corrective action that you should take without any special regard for CM.

Acquire a CM Specialist and task him with (1) defining CM Requirements for inclusion
in the contract and (2) for interpreting those requirements, as needed, for members of the
organization.

Will it work? That depends upon the contract compliance attitude and function of the organiza-
tion. If it’s weak, CM will fail because people will ignore the contract. If it’s strong, CM will
likely succeed.

Of course this approach is too simple and direct to be acceptable in most places and many twists
and turns have been and will be tried. Even so, please consider the following before you abandon
the notion altogether.

The unique element that CM brings to any program is the assurance that the evolving product
remains aligned with the need for it. It accomplishes that job through requirements specified in
the contract. The result sometimes produces new uses for old methods but it does not produce
new methods. For instance:

• Phases 1 & 2 were new but the use of Phases was not.

• Specifications to document the results of Phases 1 & 2 were new but specifications as
such were not.

Consequently, people familiar with phasing or specifications, etc are called upon to modify past
practice to fit new conditions. While adjustment is sometimes difficult, the people who can do it
already exist in the established organization. There is no need to reorganize and every reason not
to!

CM Specialist
On the other hand, someone who understands most of the complications and consequences of
CM requirements is generally rare. Whether he’s called specialist, guru, expert, or manager he
must be found or created. The desirable qualifications are:

33
Generic CM Rev. 1

• A thorough understanding of the operation of an engineering-manufacturing organization.

• A thorough understanding of CM and its impact upon such an organization.

• The ability to negotiate with customer or contractor and define clear CM requirements for
inclusion in contracts.

• The ability to interpret contract CM provisions.

The foregoing is a tall order and there are few ready-made candidates. If you grow your own, the
person selected must be able to acknowledge the deficiencies in his own knowledge and be
willing to correct them as rapidly as he can even though this task is never-ending.

Where should he report? Wherever he can function effectively, reasonably free of backstabbing.
The Contracts Dept. is one possibility because he deals with contracts. Engineering is another
because he deals with engineering requirements. Program Management is a third because his
work influences the program. However, Contracts Departments are often weak. Engineering is
often disinterested. And, Program Managers are sometimes given to stifling CM when it threat-
ens their ability to ignore inconvenient requirements. The final choice depends entirely on the
makeup of the organization in which the Specialist is to function.

CM Organization
The organization shown in Figure 15 is for those who can’t accept the CM Specialist as a stand-
alone position. The functions appear to be compatible. The Manager’s time splits into 80% as
specialist for Requirements and 20% as a supervisor for Release and Change Control.

Fig. 15 CM Organization

However, the Achilles Heel is Change Control. It’s almost certain that Change Control will swell
to dwarf all else. The organization will morph into one where Change Control demands 100% of
the time and the rest goes begging.

34
Rev. 1 Generic CM

Summary
The organizational necessities for CM are:

• A reasonably competent engineering-manufacturing organization

• A reasonably effective means of assuring contract compliance.

• A competent CM Specialist

The Specialist will negotiate effective requirements for inclusion in the contract. The contract
compliance method will see that the requirements are not ignored. The organization will perform
in accord with the requirements.

The question of a reporting home for the CM Specialist will continue to bedevil because there is
no really good answer. Therefore, he should report wherever he can function effectively, rea-
sonably free of backstabbing. That location will differ from one organization to another and is
best left to those who know something about the specifics.

***

35
Generic CM Rev. 1

11. IS IT REALLY NECESSARY?

Design Drift
Unless you can tolerate design drift, CM is a necessity. If you haven’t experienced design drift
it’s hard to believe that all of this fuss is really necessary. So let’s understand it. A cork will float
aimlessly pushed hither and yon by currents of wind and water or a good shove. Odd as it may
sound designs behave in the same way.

Programs take 5-15 years or more to complete and they take place inside of very large compli-
cated organizations. Control of the design passes through many hands as people quit, retire, die,
transfer etc. in both the contractor and customer organizations. This churning of personnel is am-
plified by the military practice of rotating assignments every three years. Most people are not
fond of “writing it down” so they rely on memory which can be tricky. All of this flux makes it
easier for zealots to substitute their own judgment to “make it better”. All it takes is a few new
people plus a foggy collective memory to cause or permit a change in direction. Let that happen
several times over the years and a fighter aircraft easily morphs into a fighter-bomber.

Unfortunately, people of uncertain scruples have been known to collude in using an existing pro-
gram as a test bed for a wholly new product without any authorization but their own. An excess
of patriotism has motivated some, others are victims of raw ambition or plain greed, and believe
it or not some are real innocents.

None of this is theory. The procurement literature of the 50’s and 60’s is full of examples and it’s
still available for review. It convinced the Congress and the military that corrective action was
necessary. CM was one of the results.

Decision Criteria
If a specific device must be designed and manufactured to satisfy a particular need, CM or its
equivalent is necessary! Many have tried but all have failed to find an equivalent. At best they
have reinvented the wheel and given it a different name.

If the device to be designed and manufactured is not dedicated to satisfying a particular need,
CM is really not necessary. Precise alignment has little to no significance but some of the ele-
ments shown in Figure 1 will still be required to a greater or lesser degree.

***

36
Rev. 1 Generic CM

AFTERWORD

If you understand the elements and relationships in Figure 1, you understand Generic CM. Add
the fact that existing personnel, with one exception, can perform all of the tasks required and CM
is not so hard after all. The one exception is a CM Specialist needed to define and interpret CM
Requirements and he isn’t necessary if enough of the existing personnel really understand CM
Requirements.

If you don’t understand it, review the previous text with some care and thought. Take a look at
the separately downloadable Appendix. A number of side issues are covered. This material is not
essential to understanding generic CM. However, it is useful background and helps explain peo-
ple’s behavior.

If you still have a problem, I will try to answer genuine questions about the content as time and
energy allow but I intend to remain fully retired. I can be reached at cmg@citlink.net

On the other hand, if this effort has helped your understanding of CM please tell others. No ad-
vertising campaign is planned. If the book has merit word of mouth will do the job.

***

37
 GENERIC CM
C O N F I G U R A T I O N M A N A G E M E N T
E X P L A I N E D

A P P E N D I X
Revision 1

By Rich a r d L . Ru m a g e

Copyright © 2005 by Richard L. Rumage

May be reproduced and distributed
for educational purposes
but not for profit.
Appendix - Generic CM Rev. 1

CONTENTS
CONTENTS.............................................................................................................................................. 2
FIGURES.................................................................................................................................................. 5
TABLES.................................................................................................................................................... 5
INTRODUCTION .................................................................................................................................... 7
PREREQUISITE ........................................................................................................................................ 7
EXPERIENCE ........................................................................................................................................... 7
1. VIEW FROM THE TOP...................................................................................................................... 9
SCANDAL ............................................................................................................................................... 9
CONTENTION ........................................................................................................................................ 10
IGNORANCE .......................................................................................................................................... 11
2. WHAT IS IT? ..................................................................................................................................... 13
3. THE DISCIPLINE ............................................................................................................................. 16
REQUIREMENTS .................................................................................................................................... 16
WORK .................................................................................................................................................. 17
DOCUMENTATION................................................................................................................................. 17
Technical Data Management (TDM) .............................................................................................. 18
Technical Manuals .......................................................................................................................... 19
IDENTIFICATION ................................................................................................................................... 20
Reidentification & Interchangeability.............................................................................................. 22
Part Numbering .............................................................................................................................. 22
Version............................................................................................................................................ 22
Reidentification ............................................................................................................................... 23
Model.............................................................................................................................................. 25
Part Marking .................................................................................................................................. 25
Serialization.................................................................................................................................... 26
Alternate Parts ................................................................................................................................ 26
Configuration Item (CI)................................................................................................................... 26
VERIFICATION ...................................................................................................................................... 26
Proof............................................................................................................................................... 27
Technical Compliance Review......................................................................................................... 28
Documentation Standards ............................................................................................................... 28
Configuration Audit ........................................................................................................................ 29
RELEASE .............................................................................................................................................. 29
Approval ......................................................................................................................................... 30
Recording........................................................................................................................................ 30
Where-Used (Next Assembly) .......................................................................................................... 31
Effectivity ........................................................................................................................................ 31
Bonding........................................................................................................................................... 32
Distribution..................................................................................................................................... 32
Pre-release...................................................................................................................................... 33
Configuration Accounting ............................................................................................................... 33
Traceability..................................................................................................................................... 34
Lot Control ..................................................................................................................................... 35
CHANGE CONTROL ............................................................................................................................... 36
Hard Facts ...................................................................................................................................... 36
Proposing Changes ......................................................................................................................... 37
Evaluating Changes ........................................................................................................................ 38
Approving Changes......................................................................................................................... 39

2
Rev. 1 Appendix - Generic CM

After the Decision............................................................................................................................ 40

Incorporation .................................................................................................................................. 40
Change Classification ..................................................................................................................... 40
Change Status Reporting................................................................................................................. 40
Customer Change Control............................................................................................................... 41
Field Modification........................................................................................................................... 43
Retrofit & Refurbishment ................................................................................................................ 43
Fixing Change Control.................................................................................................................... 43
Warning .......................................................................................................................................... 44
THE NEVER-AGAIN SYNDROME ............................................................................................................ 44
4. PHASES & BASELINES ................................................................................................................... 46
TAILORING ........................................................................................................................................... 46
ALLOCATED BASELINE ......................................................................................................................... 46
System............................................................................................................................................. 46
Interfaces ........................................................................................................................................ 47
Allocation........................................................................................................................................ 48
Cookie Cutter.................................................................................................................................. 48
One-For-One .................................................................................................................................. 49
Turf Wars........................................................................................................................................ 49
The Upshot...................................................................................................................................... 50
A TAILORED ALLOCATED BASELINE..................................................................................................... 50
Customer Directed Items................................................................................................................. 50
Subcontracted New Design.............................................................................................................. 51
Contractor Designed Items.............................................................................................................. 51
The Lesson ...................................................................................................................................... 52
THE AS-BUILT BASELINE ..................................................................................................................... 52
5. HOW IT WORKS .............................................................................................................................. 54
PHASE 1. DEFINE THE PRODUCT............................................................................................................ 54
Correcting Need.............................................................................................................................. 54
PHASE 2. DEFINE MAJOR COMPONENTS ................................................................................................ 54
PHASE 3. DESIGN PROTOTYPE............................................................................................................... 55
Demonstration Plan ........................................................................................................................ 55
PHASE 4. BUILD, TEST, AND REFINE PROTOTYPE .................................................................................. 56
Refinement for Producibility............................................................................................................ 56
PHASE 5. BUILD/TEST DELIVER PRODUCT............................................................................................. 56
Pilot Lines....................................................................................................................................... 56
Maintenance Manuals ..................................................................................................................... 58
PHASE 6. DEPLOY, MAINTAIN, REPAIR ................................................................................................. 58
6. CHAIN OF VERIFICATION ............................................................................................................ 59
7. SOFTWARE ....................................................................................................................................... 60
MODERN TRIAL AND ERROR ................................................................................................................ 60
8. GOVERNMENT CONTROL ............................................................................................................ 62
METHODS............................................................................................................................................. 62
DUPLICITOUS CONTRACTORS ................................................................................................................ 62
TESTING ............................................................................................................................................... 63
PRODUCT BASELINE CUSTOMER CONTROL ........................................................................................... 63
ACQUISITION REFORM .......................................................................................................................... 64
9. CONTRACTS..................................................................................................................................... 65
CONTRACTING................................................................................................................................. 65
TECHNICAL DATA REQUIREMENTS ....................................................................................................... 65

3
Appendix - Generic CM Rev. 1

CM PLANS ........................................................................................................................................... 65
SPECIAL PROVISION .............................................................................................................................. 66
INSERTION ............................................................................................................................................ 66
THE CONTRACTING CYCLE ................................................................................................................... 66
CONTRACT KINDS ................................................................................................................................ 67
CHAIN OF REFERENCE .......................................................................................................................... 67
10. CM ORGANIZATION..................................................................................................................... 69
THE PRIMARY ACTORS ......................................................................................................................... 69
Customer......................................................................................................................................... 69
Contractor ...................................................................................................................................... 70
Subcontractor.................................................................................................................................. 70
Vendor ............................................................................................................................................ 70
11. IS IT REALLY NECESSARY? ....................................................................................................... 72
12. A TALE OF TWO PROGRAMS..................................................................................................... 73
12A. THE STANDARD MISSILE (SM) PROGRAM .......................................................................... 73
THE PROBLEMS .................................................................................................................................... 73
Compression ................................................................................................................................... 73
Change Control............................................................................................................................... 74
Competitive Data Package .............................................................................................................. 75
Technical Data Management........................................................................................................... 75
Fixed-Price ..................................................................................................................................... 75
Change............................................................................................................................................ 75
NEGOTIATION....................................................................................................................................... 76
DEVELOPMENT ..................................................................................................................................... 76
INITIAL PRODUCTION............................................................................................................................ 77
FOLLOW-ON PRODUCTION.................................................................................................................... 78
THE CLAIM........................................................................................................................................... 78
FIXING CHANGE CONTROL ................................................................................................................... 79
12B. THE STANDARD ARM PROGRAM (ANTI-RADIATION MISSILE)..................................... 80
NO GOOD DEED …............................................................................................................................... 82
12C. LESSONS ....................................................................................................................................... 82
Compression ................................................................................................................................... 82
Competitive Data Package .............................................................................................................. 83
Bonus .............................................................................................................................................. 84
Fixing Change Control.................................................................................................................... 84
CM.................................................................................................................................................. 84
AFTERWORD ....................................................................................................................................... 86

4
Rev. 1 Appendix - Generic CM

FIGURES
FIG. 1 THE GAP ........................................................................................................................................... 9
FIG. 2 THE FIX .......................................................................................................................................... 10
FIG. 3 THE ELEMENTS ............................................................................................................................... 16
FIG. 4 TYPICAL TYPES OF DOCUMENTATION ............................................................................................. 18
FIG. 5 SAMPLE IDENTIFICATION NUMBER .................................................................................................. 21
FIG. 6 REIDENTIFICATION.......................................................................................................................... 24
FIG. 7 COMMON VERIFICATION METHODS ................................................................................................. 28
FIG. 8 EFFECTIVITY................................................................................................................................... 32
FIG. 9 CHANGE CONTROL PROCESS ........................................................................................................... 37
FIG. 10 THE ORIGINAL ALLOCATION CONCEPT.......................................................................................... 48
FIG. 11 A TYPICAL ALLOCATION OUTCOME .............................................................................................. 49
FIG. 12 A TAILORED APPROACH ............................................................................................................... 52
FIG. 13 TRADITIONAL VS. STANDARD MISSILE .......................................................................................... 74
FIG. 14 CM ON STANDARD ARM.............................................................................................................. 81

TABLES
TABLE 1 COMMON IDENTIFICATION METHODS .......................................................................................... 21
TABLE 2 CHANGE BOARD DECISIONS ........................................................................................................ 39

5
Appendix - Generic CM Rev. 1

REVISIONS
Rev. 1, 6/2/06: Inserts “Competitive Data Package” subtitle on page 75. Adds “Revi-
sions” page and renumbers subsequent pages appropriately. Adjusts Tables of Contents
accordingly. Adds “Revision” number to headers. Corrects figure captions. Cleans up
Table 1.

6
Rev. 1 Appendix - Generic CM

INTRODUCTION

This Appendix covers a number of side issues. They are not essential to an
understanding of Generic CM. However, they are helpful in explaining
why things are the way they are. The following sections parallel the sec-
tions of the basic text and usually amplify, clarify, or detail that material.

Prerequisite
CM is bounded on one side by the need for a product and on the other by
retirement of the product from service. The upper boundary is the highest
level of functional requirement. At the bottom, it’s the piece part, material,
or process. Given this scope I press, once again, the importance of having
or acquiring a reasonable understanding of engineering, manufacturing,
procurement, deployment, and their relationships. The lack of such knowl-
edge is the most common cause of major CM failures.

Experience
The following details the experience upon which this book is based.

I worked at the Pomona Division of the General Dynamics Corporation

for 31 years. In the first 4 years I was exposed to every major department
in the Division as a Management Systems Analyst. Then I was asked to
move to Engineering Management Systems, which eventually merged
with Documentation where I was assigned the task of figuring out this
thing called Technical Data Management. Having done so, I was assigned
the management of that activity.

When CM came along it seemed to be very much like Technical Data so

they asked me to figure that out too. The result was appointment to the po-
sition of Configuration and Technical Data Manager where I remained
until retirement.

There was considerable inter-action between the Pomona Division and

other divisions of General Dynamics as well as other companies. There
were other temporary assignments but only two have significance in this
context. I directed a division-wide study on Design to Production Transi-
tion and another one on the probable impact of the future upon the Divi-
sion’s systems.
__________

The Pomona Division came into being as part of Consolidated Vultee

(Convair) to develop and produce a defense against the Japanese kamikaze
(suicide) bombers of WW II. Among its accomplishments are the Terrier,
Tartar, and Standard Anti-Aircraft Missiles for the Navy; the shoulder-

7
Appendix - Generic CM Rev. 1

fired Redeye and Stinger Anti-Aircraft Missiles for the Army; the ARM
Anti-Radiation Missile for the Air Force and Navy; the Phalanx Gun
(Anti-Aircraft) System for the Navy; and many less spectacular items for
one or another of the services.

As part of the great reshaping of aerospace during the 1990’s, General

Dynamics sold Pomona’s product lines and closed the Division. However,
most of the products mentioned above remain actively deployed and are
supported by other manufacturers.

***

8
Rev. 1 Appendix - Generic CM

1. VIEW FROM THE TOP

Configuration Management (or CM as we call it) was conceived in scandal, nourished on

contention, and matured in ignorance. Nonetheless, done right, it works.

Scandal
Of course scandals are always with us but those of the 1950’s and 60’s were exceptional.
They caught the attention of the media and the people. They rattled the Congress, which
took deadly aim at the Military. The Brass, threatened with meltdown, was desperate for
a solution. The Air Force led the way and discovered a real oddity. Bad products were
seldom the result of conventional skullduggery. Instead they were usually caused by mis-
understanding, miscommunication, or similar misadventure.

How could anyone start out to develop one weapon and end up with another? Even so,
they did! Obviously, instructions were unclear, misunderstood, or someone was doing his
own thing. As it turned out all three were at work.

It’s important to know that long established documentation, identification, verification,

release, and change control practices were in place. They had been developed by industry
years before and they had worked well. They still did but something was clearly wrong.
Where was the flaw?

By and large, prior to World War II, inventors created a device and
Ideas Create Need then tried to convince the defense establishment that it was needed.
If agreement was reached, the inventor financed further design, test,
WORLD WAR II and production sometimes at his own expense and sometimes
backed by others or a procurement guarantee. World War II con-
vinced everyone that this scheme no longer worked. So a need-
Need Creates Ideas creates-ideas approach was adopted. The Department of Defense
decided what it needed and then sought a contractor willing and
able to design and produce it’s fulfillment. Figure 1 displays the way it was.

Fig. 1 The Gap

The weapon needed was selected from a group of ideas and passed on for design, test,
production, and deployment. The practices began at the mid-point of design and contin-
ued throughout the life of the product. Changes, adjustments, corrections, etc. were made
using design as the point of reference. This self-referencing approach allowed the design
to drift or be pushed away from the need. The fix is displayed in Figure 2.

9
Appendix - Generic CM Rev. 1

Need Ideas Design Test Produce Deploy Retire

| Practices |

V
V
V
V

Fig. 2 The Fix

The practices start at the end of need. All subsequent changes, adjustments, corrections,
etc. are made using need as the point of reference. This approach closes the gap and
keeps the design aligned with need. To keep the gap closed, several verification points
are imposed. At each point, the current work is examined to assure that it is still aligned
with need. If it isn’t, corrective action is taken or the program is cancelled. They called
this approach Configuration Management or CM for short.

Of course there was more to it. There always is. System Engineering was elevated to a
dominant position. The whole effort was wrapped in a scheme called Weapon System
Management and there was more.

Contention
However, the proverbial “they” had invaded the provincial halls of Engineering and
started internecine war. Design engineers maintained that System Engineering couldn’t
work and would lead to failure. System engineers swore that it worked marvelously well
by keeping the designers in line. Both were ingenious in proving their contentions in
practice. It was awkward and it took years to reach an uneasy accommodation.

Simply put the System Engineering task is to translate the need defined by strategists and
tacticians into engineering terms suitable as (1) requirements to be met by detail design
engineers, and (2) a frame of reference for determining that the design is aligned with
need at various points throughout the program. It’s a delicate task. Specifying too much
hamstrings the detail designers and increases costs. Specifying too little fails as a point of
reference and enables design drift. To add spice to the mix, millions of dollars are usually
at risk.

To aid this task, the Military spawned dozens of requirements for specifications and
wrapped them in complex procedures. It took a specialist to decipher them and all but an
Act of Congress to change them. Of course, they were resented and the contention was
vociferous.

The second affront was Weapon System Management. It was created to define an or-
derly, phased process beginning with the strategic and tactical studies that define need
and ending when the product was retired from service. Generally, this period lasts 5-15
years or more during which people and conditions change. So another load of procedures

10
Rev. 1 Appendix - Generic CM

was developed to cover most contingencies. To be fair, many of them were adequate and
helpful when used properly. But some folks prefer contention to compliance so contend
they did.

These conditions were further complicated by the implementation of Program Manage-

ment and Fixed-Price Contracting.

Generally, defense contractors were organized by department; one for procurement, an-
other for engineering, another for manufacturing, and so on. When more than one product
was in work, coordinators, expediters, and project managers were assigned to specific
products. Their job was to shepherd their products through the various departments to
completion on time and within budget. As the number of products and degree of com-
plexity increased, their job became all but impossible. The Military cure was Program
Management. In this scheme, a Program Manager was made fully responsible for a prod-
uct. He was given rank equal to that of the department heads plus control of the budget.
His real power often exceeded that of a General Manager. In too many cases department
heads and program managers mounted an offensive against each other. After all, careers
were at stake! It was contentious and a number of years passed before an uneasy truce
was achieved.

Cost-plus was a primary form of financing during WW II. Keeping it simple, cost-plus
meant spend what you must to get the job done but your profit is limited. Fixed-price
means that a specified amount of work must be done for a predetermined price including
both cost and profit. The objective is to save tax dollars. Most likely it does. However, its
impact on organizations was to shrink the money supply. Competition for funding be-
came intense.

Then, as if all that was not enough, the computer revolution arrived. In the beginning it
was used more often to demonstrate its wonders than to enhance the thing computerized.
If something could be done, it was done, regardless of good sense. Systems blossomed.
Applications flourished. New organizations burgeoned. And, they contended.

Ignorance
Ignorance isn’t stupidity. Let’s not cross those wires. It’s a state of not knowing; an often
ignored condition common in humans. The defense establishment is not immune.

CM must operate across an enormous spectrum of activity extending from product need
to product obsolescence. The WW II Generation of managers rose through the ranks over
many years. They learned the detailed activities of their departments intimately and came
to understand the spectrum in which they lived. Unfortunately, as CM came into being,
the WW II Generation was retiring. A new generation was taking its place.

Many of the New Generation came to power as college graduates in business and finan-
cial management imbued with “maximizing the bottom line”. There was a notion at the
time that “if he can manage one thing he can manage anything”. So they gained manage-

11
Appendix - Generic CM Rev. 1

ment positions early in their careers without knowing the detailed activities of their de-
partments. Of course, many of them had been exposed to the industrial spectrum in
school but few of them had hands-on experience with it. They tended to view the details
of plant operation as the responsibility of someone else. As a result, they were often un-
aware of the widespread consequences of their decisions.

The focus of the WW II Generation was the product. Of course, a

profit had to be made but it did not dominate every waking mo-
ment. Ultimately, the focus of the New Generation was profit. Of
course, there had to be a product but profit was the dominant
force. Although this distinction may appear to be an insignificant
subtlety, it is not! When profit overwhelms product, the ambiance
of the plant changes! There are significant consequences not the
least of which is corner cutting.

Specialists have a similar problem. Most people in the defense establishment are accom-
plished specialists of one kind or another. Generally, they are fascinated with their spe-
cialty and tend to be parochial. Even so, the WW II Generation Specialists had at least a
passing appreciation of the industrial spectrum in which they operated. The New Genera-
tion Specialists did not. Things like CM or industrial spectrums were simply too intangi-
ble, even too ethereal, to warrant serious attention. However, successful CM is dependent
upon their willing cooperation.
_______________________________

Of course all of these conditions didn’t occur at once. However, they appeared, one hard
upon the heels of another, and lasted until many of them co-existed. It is important to
note and to remember that the people involved were not bad people. Each one came at
these problems from his perspective and acted according to his perception. However,
their perspectives were limited and the problems were vast. Limited perspective contin-
ues to be the most common obstacle to understanding CM.

The resulting turbulence engulfed CM. From time to time it became the prisoner of war-
ring engineers, competing empires, shrinking budgets, or careerist power plays. Its devel-
opment was warped, stunted in some cases and overblown in others. Ultimately, it sur-
vived only because of the intransigent demands of the Military Brass. Design drift had to
go! Real need had to be met!

***

12
Rev. 1 Appendix - Generic CM

2. WHAT IS IT?

Give or take a tweak, the following definition of CM has appeared in many places for
many years.

A discipline applying technical and administrative direction and surveil-

lance to (1) identify and document the functional and physical characteris-
tics of a configuration item, (2) control changes to those characteristics,
and (3) record and report change processing and implementation.1

A more modern version follows.

A process that establishes and maintains consistency of a product’s attrib-

utes with its requirements and product configuration information through-
out the product’s life cycle, 2

Neither definition is really satisfactory. If the user has the knowledge necessary to under-
stand them he doesn’t need them. On the other hand, if the user lacks that knowledge they
are of little help.

CM is difficult to define because it borrows from many preexisting fields and applies the
borrowings purposefully across an enormous spectrum of activity. The most common
definitions focus on Documentation and Change Control because they are tangible and
most people are already aware of them. In fact, the association is so close that many peo-
ple come to believe that CM is just another name for Documentation or Change Control.

Another approach to definition is based on a simple question. What’s different? What do

we do now that we didn’t do before CM was established?

We had documentation, identification, verification, release, and change control before

CM was ever heard of. They were loosely collected under the rubric of Documentation.
We have them now under the rubric of CM and we use them to define, direct, control,
and record. So what is really different?

Before CM they were used to stay in line with the design. After CM, they are used to stay
in line with the need. Thus, ---

1
Army AR 70-37, Navy NAVMATINST 4130.1A, Marine Corps MCO 4130.1A, Air
Force AFR 65-3, Defense Supply Agency DSAR 8250.4, National Security Agency
NSA/CSS 80-14, Defense Communications Agency DCAC 100-50-2, and Defense Nu-
clear Agency DNA INST 5010.18; issued 1 July 1974 by the Joint DOD Serv-
ices/Agency.
2
EIA-649-A, 2004, by the Government Electronics and Information Technology Asso-
ciation.

13
Appendix - Generic CM Rev. 1

CM is a discipline that keeps an evolving product aligned with the need

for it.

Most people can readily understand that definition. If not it can be explained quickly and
simply. (See: Section 2, Basic Text).
__________

Originally, CM was presented in three parts (a fourth was added later), which are often
included in definitions. They are academic in style, jargonistic in language, dependent on
prior knowledge, and hard to understand. However, they should be acknowledged and
correlated with appropriate parts of this book.

Configuration Identification: The Documentation of product characteristics or the

process of developing such documentation. Correlates with: Documentation,
Identification, and Verification.

Configuration Control: Evaluation, coordination, approval, or disapproval of

changes, deviations, and waivers of product characteristics. Correlates with:
Change Control and Verification.

Configuration Status Accounting: Appropriate records of the Configuration Iden-

tification, the status of proposed changes, deviations, or waivers, and their imple-
mentation. Correlates with: Release and Change Control.

Configuration Audit: Verification of compliance with the Configuration Identifi-

cation. Correlates with: Verification.
__________

It would not be surprising to see a new definition before long; something like the fol-
lowing:

Configuration Management is the collective name for the following prac-

tices: Documentation, Identification, Verification, Release, and Change
Control.

Note that alignment has disappeared. The argument for omission is that, by now, every-
one knows that alignment is necessary so there is no longer any reason to emphasize that
fact. In common usage the term “CM” is a collective name for the listed practices. It is
better to conform to current usage than it is to press an esoteric approach that we don’t
need.

Regrettably, this was the state of things in the 60’s and 70’s when CM was born. We used
all of the practices and we knew that alignment was necessary but, too often, it did not
happen! Why not?

14
Rev. 1 Appendix - Generic CM

Until the cause is identified, understood, and eliminated it is imprudent at best and absurd
at worst to discard the safeguards established with such difficulty.
***

15
Appendix - Generic CM Rev. 1

3. THE DISCIPLINE

Locate applicable engineering requirements.

Perform work in accord with those requirements.
Document the work.
Identify the work.
Verify compliance with the requirements.
Release the documents.
Change Control the documents

Fig. 3 The Elements

The elements of CM have different names in different places but the point is not what
they’re called but what they do. Each one has its own standards and purposes. They were
well established by commercial industry years before the advent of CM because they are
necessary for the success of any sizeable industrial project. They were adopted by the
military for its industrial projects for the same reason. When the Air Force created CM in
the ‘60s and ‘70s, it relied on these existing practices for the same reason. Over time,
they have become so closely associated with CM that many regard them as “CM Prac-
tices”. The term implies ownership however CM does not own them! It borrowed them
and it shares them with many other activities.

One can go on at great length about each one of them. But it is best to start with simple
straightforward definitions based on what they do.

• Requirements specify what has to be accomplished.

• Work accomplishes the things specified.
• Documentation communicates to people and/or machines now or in the future.
• Identification (numbering) distinguishes precisely between one thing and another,
• Verification proves that a documented design meets its requirements.
• Release, records verified items and makes them available for use.
• Change Control maintains the integrity of released items.
Although these practices, individually and collectively, are not CM they are essential to
its successful operation.

Requirements
The concept of requirements befuddles some people although it’s really not that compli-
cated. A requirement is neither more nor less than the statement of something that must
be done. There are many kinds of requirements: Engineering, Manufacturing, Procure-

16
Rev. 1 Appendix - Generic CM

ment, Customer, Contractor, Financial, Schedule, and more. The number and variety may
be the source of confusion. Most of them of them have some administrative impact upon
CM and that fact may cause the confusion.

The requirements for which CM was created are the Engineering Requirements for a
product. The initial set is derived from the work of strategists and tacticians. They are
usually documented in a System Specification. All subsequent Engineering Requirements
are derived from the initial set and become more detailed as the program proceeds. Ulti-
mately they become the details in Engineering Drawings from which the product can be
manufactured.

Work
There are many kinds of work but the work that CM is concerned with is that which is
necessary to fulfill the requirements.

Documentation
The purpose of documentation is to communicate information to people or to machines,
near or far, now or in the future. The form it takes should be the one that best communi-
cates information to the intended user. Usually it will be text, a list, graphics, a combina-
tion, or computer code. The medium used should be accessible, legible, reproducible, and
durable. Common mediums include paper, vellum, glass, computer tape, disk, and chip
among others.

Documentation has been around since the pyramids. It evolved over time to include for-
mats, conventions, customs, and traditions thought to improve communication. Each cur-
rently used method has a vociferous constituency devoted to it along with clamorous
critics intent on changing it. And, they fight – until an agreement is forged – whereupon
they fight about the meaning of the agreement.

Even after the most meticulous efforts to be clear, accurate, and adequate some user
somewhere will misinterpret and worse have a logical reason for doing so. No, computers
won’t solve it. They do eliminate some problems as they create others. The reason for the
hullabaloo is not arrowheads or paragraph headings. It’s the human problem of clear
communication; a puzzle of perspective and perception not easily solved.

The kinds of documentation are almost limitless. Figure 4 displays the types most often
produced during each Phase of a program.

17
Appendix - Generic CM Rev. 1

1 2 3 4 5 6
Define Define Design Build/Test Build/Test Deploy
Product M ajor Prototype Refine Deliver Maintain
Components Prototype Product Repair
Product
Drawings,
Operation &
Lists, Standards,
Specifications Maintainance
Specifications,
Manuals
Procedures

Test Plan

Test Procedures

Change Proposals, Orders. & Deviations

Fig. 4 Typical Types of Documentation

Generally, it is wise to follow the customs and traditions prevalent in the industry in-
volved unless there is a compelling reason to do otherwise. Change in this field comes
slowly and at significant cost.

The information to be conveyed is the province of various kinds of engineers and techni-
cal specialists. Form and format is the job of draftsmen, checkers, technical writers, edi-
tors, and now-a-days computer programmers.

Technical Data Management (TDM)

When CM borrowed Documentation as a tool it accepted the rubrics of Technical Data
Management (TDM).

Technical data became a discipline because contractors raised unmitigated hell about two
things. First, too much very expensive and often useless data was being ordered. Second,
the Military was acquiring and compromising contractor proprietary data that it had no
right to. Investigations revealed enough truth in the charges to require significant
changes. The interesting and complicated subject of proprietary data is best left for an-
other time and place. It is primarily a legal problem. The kind and amount of data ordered
is another matter.

The Military adopted a Form (DD 1423, Contract Data Requirements List) upon which
all data ordered was to be listed and priced. The Form was made part of the contract. If
data wasn’t listed on the form, the contractor didn’t have to produce it. These changes
required people to manage and enforce them and TDM was born. To “simplify” matters,
TDM prepared Data Item Description sheets specifying content and format requirements
for each kind of data ordered. These sheets soon became the acceptance criteria for data
being delivered and a whole new order of complexity blossomed.

18
Rev. 1 Appendix - Generic CM

There are few jobs harder than writing an adequate Data Item Description. Each item has
its own vocal constituency within the Military and in each major contractor’s organiza-
tion. None of them see things the same way. Nonetheless, the sheets get written and is-
sued.

Clearly, the Military needs data that (1) details the progress of a program, (2) permits ac-
ceptance, reprocurement, competition, operation, and maintenance of the product, and (3)
prevents trouble from developing. All of these are difficult, but preventing trouble is a
lollapalooza. The scenario works like this.

Something goes wrong! An investigation assigns the cause to the fact that this, that, or
the other was not documented. The corrective action requires such documentation in the
future and a new Data Item Description is added to the book. When the next contract
comes along, the item is sitting there just waiting to be ordered, so someone does.
__________

Software came along just in time to be entrapped. It was new and evolving. Too many
people knew too little about it. They made mistakes. Corrective Data Item Descriptions
flowed like water in the tropics. Many of them dealt with programming control. Soon
there were so many that something was needed to manage them and there sat CM. To the
inexperienced, it looked like the perfect tool and to many it still does.

However, when CM is used properly it applies a requirement and verification methods

but not how-to achieve it. The how-to belongs to others. Too often software applies a re-
quirement, verification, and how to achieve it in an attempt to control the programmers.
Thus, the mangled mess that commingles CM, programmer control, and excessively spe-
cific Technical Data Requirements was created and remains to be untangled.
__________

Technical Data Management and CM have much in common. Nonetheless they are sepa-
rate disciplines. For TDM, the overall objective is effective communication. For CM, it is
direct alignment with need. CM uses only some of the documents subject to TDM while
TDM relies on CM to help produce only some of the documents it oversees.

Technical Manuals
Technical Manuals deserve special mention because they seldom get adequate attention.
Historically, designers designed the product. Then Maintenance Engineers figured out
how to maintain and repair it. They documented their conclusions in Operations and
Maintenance Manuals intended for use by field personnel.

Weapon System Management seeks to integrate maintainability with the design process.
It’s difficult! Maintenance Engineers are generally turned off by the theoretics in the
early phases. Typically, designers have little patience with maintenance issues. The trade-
offs between Reliability and Maintainability are complicated and unglamorous. Typi-
cally, most designers are convinced that their design will not break and do not become

19
Appendix - Generic CM Rev. 1

fully engaged until it does. Of course, that’s too late. Repair in the field can be impossi-
ble. Redesign for maintainability is enormously expensive.

The solution of course is a broader understanding of the whole enterprise by more people.
This is unlikely in an age when specialization is king and broad but shallow knowledge is
dismissed as useless. CM can do little about the situation but cope with its consequences.

Operation and maintenance requirements, including reliability and maintainability, can be

specified in the System Specification (Phase 1) and Component Specifications (Phase 2),
accomplished by designers (Phase 3 & 4), documented in manuals (Phase 5), for field use
(Phase 6). However, it’s very difficult to verify compliance with the requirements in any
objective way until some years of field use have past. The most effective method so far
has been high-powered technical review by people with enormous field experience.

Technical Manuals are seldom included in the regular release record so it is easy to omit
them in the Change Control process. However, if an adequate, accessible release record is
otherwise available and if Maintainability is a real requirement in Change Control, it’s
quite possible to keep them integrated with the rest of the documentation. It is not un-
usual for the actual release to be made by the organization that prepares the manuals,
usually technical writers.

Changes to the product can impact maintenance of the product. Therefore, it is important
that they be examined for Maintainability during the Change Control process to assure
that Manuals are revised if necessary.

Pure Manual errors can be corrected without any impact on the product. However, error
may have occurred because of unclear product documentation. If so, it is appropriate for
technical writers to propose clarification changes to the product documentation to correct
the condition.

Identification
The purpose of identification is to distinguish one thing from another precisely. It can
take the form of a name, number, letter, symbol, mark, or some combination of these
provided that it is unique. Uniqueness is essential to prevent confusion with similar items.
Use of the wrong thing is expensive and sometimes dangerous.

There is always some ingenious fellow out there inventing a new “Significant Numbering
System”. Each digit stands for something such as plant, company, date, product, etc.
They can tell you more than you ever wanted to know about the component if you know
the code. They also require a special assignment and cataloguing system, which can be
both cumbersome and costly. The alternative is a “Non-significant Numbering System”
in which each digit means nothing but sequence. Assignment and use are easy.

The military assigns a numerical prefix (Code Ident, CAGE Code) to each agency and
contractor. It is used to keep their numbers from duplicating each other. Commercial

20
Rev. 1 Appendix - Generic CM

ßcompanies often rely on the company name or trademark as a prefix for the same pur-
pose.

As with documentation, there are endless identification schemes and advocates. Simple
but adequate is best. A non-significant sequential document number and revision letter or
number has had the best long-term result. However, the wise course is to follow the cus-
toms and traditions prevalent in the industry involved unless there is a compelling reason
to do otherwise. Change in this field is also slow, confusing, complicated, and costly.

The more common identification methods are noted in Table 1.

Companies and Agencies Code Ident. or CAGE Code 12345

Commercial Organizations Company Name or Logo BVD
Documents Numeric or Alphanumeric 34567825
Drawing Revisions Revision Letter A
Other Document Revisions Revision Number Rev. 1
Change Proposal Numeric or Alphanumeric C34681
Deviation Numeric or Alphanumeric D2124
Hardware or Software • Document Number & Revision 34567825A
Letter of the document used to
create it
or

Part Number referenced to the DQ 219890

Document Number.

• Serial Number if applicable. S/N1111

(Alternatively a manufacturing lot
number may be used.)

• Deviation Number if applicable. D2124

Table 1 Common Identification Methods

Figure 5 displays one possible hardware identifier from Table 1.

Fig. 5 Sample Identification Number

One of the obvious problems is identifying microminiaturized parts with this amount of
data. New methods are constantly being developed. Meanwhile, the most common
method is to keep the part in a container marked with the identifier until it is placed in its
next assembly. Afterwards deduction from the next assembly drawing is the practical
method of identifying an item.

21
Appendix - Generic CM Rev. 1

The identification system in use is usually defined in a standard applied by the originator
of the document and audited as part of release. The manufacturer marks the identification
on the part. Regardless of method, the system must be able to distinguish precisely one
thing from another. And that brings us to “reidentification” and “interchangeability”.

Reidentification & Interchangeability

The decision to reidentify or revise is an integral part of Change Control but the form that
it takes is part of Identification

When a changed item will not work in all of its next assemblies as well as
an unchanged item of the same number, the changed item is not inter-
changeable and must be reidentified. The Basic Document Number must
be changed.

When a changed item will work in all of its next assemblies as well as the
unchanged item of the same number, the changed item is interchangeable
and must not be reidentified. Only the Revision Letter is changed. These
changes are often called revisions or versions.

Excruciatingly complex definitions of “will work” and “will not work” are
available and sometimes helpful. However, the only thing that really
works is the informed judgment of knowledgeable people able and willing
to understand the use and user of the item.

Wouldn’t it be simpler to change the Basic Document Number on everything and

avoid the fuss about what does or not constitute a revision or version? Yes, it
would on one end of things but not so for the user. In the field, revisions are inter-
changeable. Reidentifications are not. This information is vital in keeping weap-
ons working. It could be conveyed in other ways however the fuss about what
does or not constitute a version would remain. This identification problem backs
up throughout the whole system of ordering and stocking spare parts. In that
world they don’t track versions because any one will work. But they keep careful
track of reidentifications because just anyone will not work!

There’s a lot more to it. However, for our purposes, the key elements are uniqueness and
preciseness. One thing must be distinguishable from another — precisely.

Part Numbering
Some companies follow a tradition of identifying documents and the items they describe
separately. Thus, they have Document Numbers and Part Numbers. The Part Numbers
are cross-referenced in the document. Other companies use the same number on the
document and on the part.

Version
In common English, a version is a slight variation from an original. The term includes
alteration, modification, variant, issue, edition, revision, letter change, and anything else

22
Rev. 1 Appendix - Generic CM

that can be considered a slight variation. For CM, slight variation means interchangeable;
a version is an interchangeable variation of an original.

Determining interchangeability, particularly functional interchangeability, is an engi-

neering task! The function of upper level assemblies is usually stated in the documenta-
tion that defines them. The function of lower level assemblies and parts is inherent in
their design and often must be deduced from it.

Unfortunately, there are many ways to identify versions. Generally, versions of drawings
are identified with letters of the alphabet. Versions of specifications are identified with
Arabic numerals. Versions of software are identified with a variant of the Dewey Deci-
mal system. Versions of other documents may be identified differently but similarly.
Once again tradition confronts us. Each identification method was developed by those
who controlled the documents affected; separate communities of specialists working in
splendid isolation. It is tempting but unwise to call for standardization. The legacy is too
broad and too deep to be abandoned easily. The cost exceeds the benefit. So, if you must
work with the detail, either rely on a specialist or learn the local conventions.

Version identifiers are recorded in the revised document along with some indication of
what has been revised. For drawings, a simple description of the change is recorded in the
drawing revision block. For text documents, it’s often shown on a “revisions page”. Gen-
erally, version identifiers are marked on the part.

References in a document to another document do not include version numbers in order

to reduce changes and in accord with the general working rule, “Always use the latest
version”. (After all, they are interchangeable, aren’t they?) .

As to drawings and the items they define, if there is an original plus two approved ver-
sions of Item 840, the identifiers will be 840, 840A, and 840B. If another interchangeable
version comes along, the new identifier will be 840C. However, if that version is not in-
terchangeable, it must be reidentified; that is given a new and unique number.

Reidentification
If the version that would have become 840C is not interchangeable with all other versions
of 840, it must be reidentified; given a new unique number AND it is no longer a version.
It is a new item! The new number will be the next one in order from a log of unused
numbers. (A number once used is never reused! Even if the document it identifies is can-
celled, the number remains to identify the cancelled document.)

Reidentification is required not only for Item 840 but for every item above it until the
level of interchangeability is reached.

23
Appendix - Generic CM Rev. 1

BEFORE AFTER

123 123
4
Level of
890 Interchangability 981

3
840 980
840A
2
840B

840C
1
1

Fig. 6 Reidentification

1. 840C is not interchangeable with the other versions of 840, so -

2. 840C is reidentified to new part 980.
3. Obviously, 840 and 980 are not interchangeable, which forces the
creation of 981.
4. Fortunately, 890 and 981 are interchangeable so 123 is not affected.

Changes like this cause delay and expense. A product can have 16 or more levels. Rei-
dentification can ripple upwards from bottom to top and affect every one of them. When
it does it can impact at every level in almost every department of the plant. Thus, people
turn themselves into pretzels to avoid it.

They have developed a whole folklore of excruciatingly complicated refinements, such as

one-way interchangeability, of these fundamentals. This doctrine holds that you need not
reidentify a version when it is interchangeable forward (in new units of product) but not
backward (for repair of old units); provided that there are no old units to be repaired. The
theoretical logic is impeccable. However, the Devil pays no homage to theory. He will
find old units, somewhere, that must be repaired and you will be out of luck!

These so-called refinements produce almost endless controversy and occasionally real
danger. Thus, if you don’t know each and every circumstance thoroughly, don’t fool with
the fundamental. Each component, and its defining document, must have a unique intelli-
gible identifier! If non-interchangeable components have the same number, reidentify one
of them! Reidentification must continue upward until the level of interchangeability is
reached!

The people who usually make reidentification decisions are the members of the Change
Control Board heavily influenced by engineers. Unfortunately, many engineers are very

24
Rev. 1 Appendix - Generic CM

narrowly focused specialists. They know little or nothing of the consequences in manu-
facturing or the field that can result from lack of reidentification. The solution is to edu-
cate engineers about the real and far-flung consequences of their decisions.

Model
Model names or numbers are an old form of identification. It’s still widely used. How-
ever, there is very little that is uniform about it. Every company and agency that uses
Models seems to have a different set of rules for them. So, CM does not use them al-
though there have been exceptions.

As a practical matter, Model identifiers have become the property of marketers both in
and out of the Military. Most organizations see little benefit in marketing the same old
model year after year so they change it with much “new and improved” hoopla. Con-
versely, deep within the Congress there are plenty of fixed attitudes. When they do not
favor something new, Model numbers don’t change. Interchangeability has very little if
anything to do with it.

Therefore, model numbers should not be used as CM identifiers. A product may bear
both model number and part number. The model number may be used effectively for
some inventory control purposes in some systems but the part number is the only positive
identification.

Part Marking
Instructions for placing the identifier on the item to be identified are stated in the docu-
ment that defines that part. They include the actual number to be used, the specific loca-
tion on the part where it is to be marked, and the method to be used such as stamping,
etching, non-conductive ink, etc. Common practice requires version identifiers to be
marked on the item.

The miniaturization of parts has created parts too small to mark by conventional methods.
The first recourse is “bag & tag”. The part number is written on a bag, which contains the
part, or the part number is written on a tag, which is tied to the part. Obviously, when the
part is next assembled the bag or tag is removed and the identification is lost.

The second recourse is microscopic marking methods. This is an expensive process prac-
tical in only the most critical cases. Therefore, it is seldom used.

The third recourse calls for other techniques. For assemblers, a tightly controlled assem-
bly line is employed. The parts are placed in individual bins at each assembly station. The
part number is marked on the bin. The assembler is responsible for getting the right part
in the right place. Assembly testing is often used to assure that the right part was assem-
bled.

Generally, repair of microminiaturized assemblies is not economical so the whole assem-

bly is replaced. In those rare cases where repair is required, the technician compares the
part in question with the assembly drawing to determine its identity.

25
Appendix - Generic CM Rev. 1

None of this is picayunish. Getting the right part in the right place is essential! However,
it does bring another principle to the fore. Don’t spend to prevent that which is cheaper to
correct. Just don’t forget that the cost of correction includes, time lost, damage to reputa-
tions, and above all else – human safety!

Serialization
A serial number is an additional identifier used to identify each individual unit of an item
(part). Example: Part 123, S/N 29 means the 29th unit of item 123. It can be applied to a
product or any part of a product subject to the Part Marking constraints discussed above.
Serial numbering should not be used simply because it can be done. It is one more cost
and delay in production. However, if there is a real need to distinguish one unit of a part
from another unit of the same part, serial number is the best method known.

Alternate Parts
Just as more than one kind of light bulb may fit a socket, more than one part may work in
an assembly. A part shortage in Manufacturing or Maintenance can spark a hunt for al-
ternate parts that may be available from more than one vendor or from other products. An
alternate part, if interchangeable, can be added to the released documentation through an
approved change or deviation. The specific method of documentation and release of al-
ternate parts depends upon the local practices of contractors, industries, and buying agen-
cies.

Configuration Item (CI)

The CI originated as part of the allocation process but soon mutated into an “acceptable”
technique for moderating Military control. It is defined as “an aggregation of hardware or
software, designated by the government for Configuration Management”. Translation: a
part of the product that the Military really wants to control. (By inference all other parts
are free of military control.)

A CI has its own CI Identifier (number) in addition to document and part number. It is
designed in accord with a Military controlled specification, which means initial approval
of the specification and change control thereafter.

The CI is best understood as a technique, useful to some and overdone for others, de-
pending upon the parochial practices of the contractor and the buying agency. Where it
works, use it. Where it doesn’t, avoid it. Either way, it does not alter the basics of CM!

Verification
The purpose of verification is to prove that an item complies with the requirements for it.
That item may be documentation or hardware. Documentation includes software docu-
mentation. Hardware includes the software used in it or with it.

26
Rev. 1 Appendix - Generic CM

Proof
The only certain Verification is use of the actual product to satisfy the specified need. For
a weapon, that means use of the weapon in war. For a commercial product, it means use
of the product by a large number of consumers. Thankfully, wars are not always available
to verify weapons. Obviously, it is imprudent to wait for a commercial product to be
marketed. So, the next best thing is devised to prove the work at various stages of the
program.

Proof is that which convinces the mind. So it is not surprising that there are almost as
many methods of proofing, as there are items to be verified. Most commonly, Technical
Compliance Review, Checking, or Editing are used to verify design. Inspection (Exami-
nation or Test) is used to verify hardware. However, the acid test is to actually build
hardware from the documentation and then demonstrate that the hardware meets the
need.

A Technical Compliance Review consists of competent people, familiar with the technol-
ogy involved, but not part of the design team. They examine the item against its require-
ments and reach a conclusion that the item does or does not meet them.

Checking and editing are age-old methods dealing as much with communication as con-
tent. However, they do examine technical coherence and compatibility.

Inspection (Examination or Test) is a well-established Quality Assurance method of long

standing.

A successful demonstration, conducted near the end of Phase 4, is the crowning achieve-
ment of most development programs. The intent is to demonstrate satisfactory perform-
ance of one or more prototypes in the field. Every reasonable effort is made to duplicate
the operating conditions that the product was designed to meet. Verification is usually
performed by a wide variety of technical types selected for their knowledge of the tech-
nology involved or the verification method used.

Figure 7 displays the most common methods in relation to program phase.

27
Appendix - Generic CM Rev. 1

Fig. 7 Common Verification Methods

Technical Compliance Review

Of all the verification methods available the Technical Compliance Review is the most
difficult to conduct successfully. It would seem to be simple. Gather a group of techni-
cally competent people. Give them a copy of the applicable requirement. Make the cur-
rent work available to them. Ask the question, “Does this work comply with these re-
quirement?” However, unless they have a chairman with iron control they will never get
to the compliance question. Instead they will come up with every possible change that in
their opinion will improve the product. Many of these ideas will be practical and attrac-
tive but they are diversions!

Product Improvement Reviews, also called Design Reviews or Technical Reviews, are
good and useful techniques for getting the best possible product from the engineering ef-
fort. Compliance Reviews are not. They are conducted not to improve the product but to
see if the product in its current state complies with the requirements for it. These are very
different activities. However the same people perform them. Their usual work is creation
or improvement of product design and they will revert to that mode of behavior whenever
they have the chance without even being aware of it. Only a strong Chairman can keep
them focused on compliance long enough to get an answer.

Do not take this matter lightly. It is one of the primary causes for the failure of Technical
Compliance Reviews to detect errors that must be corrected.

Documentation Standards
Compliance with documentation standards imposed by Technical Data Management is
not part of CM Verification. Thus, “verified document” is a shop term (slang), which re-
fers to the content of the document rather than to its form and format. Draftsmen, check-
ers, technical writers or editors determine compliance with form and format standards as
the documents are created.

However, these same people examine the documents for errors and inconsistencies. This
part of their work is considered to be an adequate CM verification for Prototype docu-

28
Rev. 1 Appendix - Generic CM

mentation primarily because there is no other practical method available at that point in a
program.

Even so, grizzled gray-heads usually say that the only way to prove a documentation
package is to build it and do so more than once. In my opinion they are right particularly
if the documentation package is intended for use in competitive reprocurement.

Configuration Audit
Of the verification methods available, Configuration Audit became the most expensive
for the least value added. In simple terms, it is a customer-imposed practice that dupli-
cates verifications already completed. This consequence had two causes. First, formal
CM definitions were ambiguous enough to permit it. Second, the performance of verifi-
cation, conducted by both military and contractor personnel, was poor enough to require
it.

Unfortunately, large organizations are prone to add another unit of people or duty rather
than correct those that are failing. Thus, instead of audit being treated as a synonym for
verification, it became a cause célèbre with a life of its own.

In very simple terms, a Functional Configuration Audit verifies that finished hardware
complies with the applicable Functional or Allocated Baseline; that is, it functions, as it
should. A Physical Configuration Audit verifies that finished hardware complies with the
applicable Product Baseline; that is, it was built correctly.

Generally, Configuration Audits are conducted on the first unit of production hardware
but some other unit may be selected. Functional Audits became unpopular quickly be-
cause they require examination of lots of test data and that gets dull fast. They usually get
short shrift. Conversely, Physical Audits became quite popular because they capture lots
of attention and can be dramatic.

A physical audit consists of disassembling a finished product piece by piece until the
limits of non-destructive disassembly are reached. Each part is examined against its
documentation to determine conformance. Discrepancies require correction of the docu-
ments or rework of the hardware. All well and good except that it should have been done
through verification much earlier in the program. Further, much of the hardware can’t be
checked because disassembly destroys it.

Thus, Configuration Audit is not a technique to be used routinely on every program. The
better practice is to see that Verification is properly conducted in the first place. If that
effort fails, use audit to recover.

Release
The purpose of Release is to make verified documentation available to down-stream
functions and maintain an accurate record of it. Before Release, a document is deemed to
be a working draft, error prone, incomplete, and changeable without notice. After Release
the document is deemed to be authentic, error free, and changeable only with notice. Re-

29
Appendix - Generic CM Rev. 1

lease stands between Engineering and Manufacturing, Procurement, and other major
functions. It protects downstream users from investing time and money based on invalid
information. However, schedule pressure causes most organizations to permit some form
of “Advance Release” (sometimes called “Pre-release”) which means, subject to change -
use at your own risk! An Advance Release takes place before the documentation has been
verified.

The release act consists of (1) placing a release symbol on the master of the document (so
that all copies will show it) or making a “released” entry in a widely accessible record
and (2) making the document and record available for distribution. Masters of Advance
Release documents are marked or the record shows “Advance Release”. They are re-
placed by the verified documentation release as soon as it is available.

A record of the document is made before it is released. Generally, the document identifi-
cation, date, author, verifier, and where and when the document is to be used are suffi-
cient. However, the advent of computers has greatly complicated the process. Release is
now expected to record many kinds of information for dissemination through integrated
systems to widely dispersed users. So a release is not made until all of that data is avail-
able. The process needs careful management to avoid creating an enormous choke point.

The master (or an equivalent) of a released document is placed in bond and jealously
guarded thereafter to prevent any unauthorized change.

Release is really quite deceptive. The act itself is exceedingly simple however the record
generated is an enormously complicated database widely used throughout the organiza-
tion. The need for information is usually acute and the pressure for timeliness and accu-
racy is remorseless.

Release clerks usually perform the release task, which consists of the following parts:

Approval
Originally the only approval required for release came from the engineer who created the
document. As complexity increased mistakes became more costly so management added
specialized approvals such as reliability, materials, etc. to prevent error. These approvals
can easily grow to 10 or more and degenerate into last minute signature collection and
wrangling that has almost no value. It is also an oft-cited bottleneck. Such approvals
should be integrated either with the work of the phase or with Verification. The only ap-
proval required by the CM Discipline is Verification. However, it is common to also re-
quire Technical Data Management clearance as to form and format to assure usability.

Recording
Originally, the name and number of the document, the name of the engineer approving it,
and the date was the only record made. With the advent of computers it became possible
to construct databases containing much more. Release was the obvious spot to capture the
data. Thus, the release record has become a critical central source of information for most

30
Rev. 1 Appendix - Generic CM

functions in the plant and for many in the Military. However, such added data is ancillary
to the CM Discipline.

In addition to verification, the Release Record data required by the CM Discipline is the
identification of documents released (including the version), where they are used (next
assembly), and the effectivity of the release. Identification was discussed above. Where-
used and Effectivity are summarized below.

Where-Used (Next Assembly)

“Where-used” is slang for “The assembly(s) in which the item is used”.

Normally, parts are assembled into assemblies and assemblies are assembled into other
assemblies and so on until the top assembly is reached and the product is completed.
Each assembly is considered to be the “next assembly” of the parts, materials, and as-
semblies it contains.

For instance, a doorknob is a part, which next assembles into a doorknob

assembly, which next assembles into a door, which next assembles into a
house. Thus, the house is the next assembly of the door. The door is the
next assembly of the doorknob assembly. The doorknob assembly is the
next assembly of the doorknob.

Of course, it’s often not that simple. Parts and assemblies can be used in many different
next assemblies. Thus, the “where-used” data for doorknob #4040 could be doorknob as-
semblies #9122, #8043, #3060, and #9203. But it doesn’t stop there. Next assemblies
#9122 and #8042 are used in House #50126, while #3060 and #9203 are used in House
#60131.

These data and their relationships are recorded in the Release Record for later use in
Change Control. If a change is proposed to the doorknob the change must be acceptable
for all four next assemblies or it must be reidentified.

Effectivity

“Effectivity” is “when the item is to be used”. Effectivity can be expressed as a calendar

date, an event, a quantity of hardware, a lot number, or as a unit serial number. The most
common manner is unit serial number. But most next assemblies are not serialized. What
then? For this purpose, they are treated “as if” they are serialized.

A new version of #4040 is to be introduced as 4040A. Effectivity has to be estab-

lished for each usage (next assembly). However, in this case it will be used in
only one next assembly until its desirability is established.

Figure 8 shows that ten units of 8043 are on order in the factory. Two of them are
complete and two of them are in work so it is most economic to set the effectivity

31
Appendix - Generic CM Rev. 1

of 4040A at 5 and-on for 8043. Factory systems will pick up this information and
translate it into whatever system they are currently using. Most likely they will
call for a quantity of 4 containing 4040 and a quantity of 6 containing 4040A,

Ef fectivity
5 and on .

Un its of 8043 1 2 3 4 5 6 7 8 9 10
Com plete
Pen ding
or in w or k.

Contain Will Contain

4040 4040A

Fig. 8 Effectivity
The phrase “and-on” means “every unit that follows until otherwise directed”.

If all of this seems somewhat confusing rest assured that it is but, happily, we don’t have
to cope with it. Manufacturing Control calculates effectivity and they are quite good at it.
Effectivity, however expressed, is recorded in the Release Record.

Bonding
Formerly, the original of the recorded document was placed “in bond”; that is locked up.
Copies were made available to users and authors. The objective was to prevent unau-
thorized change to the original. However, modern reproduction can produce a duplicate
original indistinguishable from the real thing. Therefore, “bonding the original” is an ob-
solete practice.

Still, unauthorized change to the released document must be prevented. Any legible, re-
producible, bonded copy can serve the purpose including digital media provided that hu-
mans can easily read it. This bonded copy becomes the “master”.

Note: Technical Data Management may impose archival requirements for durability and
reproducibility of masters. However, though important, they are ancillary to CM.

Distribution
Any economic, efficient method that makes true copies of the “master” available to users
is acceptable. However, it is important that timely notice of a release reaches actual users.
Such notice is doubly important when releasing a change. Notice may be accomplished
by distributing the released documents or by any other timely means that alerts users.

The release record is also made available, usually via an automated system. Sometimes
such systems stand alone. More often they are integrated with, or at least connected to,
various management systems such as inventory or material control.

32
Rev. 1 Appendix - Generic CM

Pre-release
Originally, the use of a document prior to release was cause for dismissal. Compressed
schedules have eliminated the rule. Many companies allow the use of clearly marked
“pre-release” copies at the risk of the user. The risk is change of the pre-released docu-
ments without notice to the user. Pre-release documents may also contain substantial er-
ror. Thus, limited planning is a reasonable risk. Large quantity purchase orders are not.

Some companies have installed separate “pre-release control systems”, an utterly foolish,
deceptive, and expensive practice. A document is either released or it is not! If it is not,
all of the safeguards imposed between the creator and the user are absent. If you really
don’t need those safeguards, abandoning them is safer than going around them. Yes,
change orders can be pre-released but with even greater caution. It is a dangerous practice
because people cannot seem to resist the urge to implement them at once.

If the receivers of pre-released documents are mature, experienced, and well supervised
the practice works rather well for advance planning. However, if their attitudes are ado-
lescent and their supervisors are gung-ho they are better off without the temptation to
damn the risk and proceed at full speed ahead.

Configuration Accounting
The Release Record is sometimes referred to as Configuration Accounting, a formal term
from original CM definitions. Technically speaking Configuration Accounting includes
the information called for in the release record plus the status of proposed changes, and
sometimes more. However, the specific elements vary from time to time and place to
place.

Efforts have been made to specify and standardize the elements to be required. Standardi-
zation eases automated transfer of such data between contractors and agencies. However,
the ease of transfer must be weighed against the colossal disruption caused by imposing
such a standard on contractors and agencies of every hue and stripe. Contractors, indus-
tries, and products cannot be standardized routinely! The elements required for an effec-
tive record will continue to vary.

Therefore, standardize where and when practical but do not let the compromises essential
for standardization distort the elements needed by the particular contractor, industry, or
product. The price of doing otherwise exceeds the benefit to be achieved. The objective is
effective CM not standardization. Again, one size does not fit all.

The following cautions apply to any Release Record or Configuration Accounting Sys-
tem.

• Don’t assume a need to know everything about everything. Record the elements
that will most likely be needed and used during the life of the product.

33
Appendix - Generic CM Rev. 1

• Enforce existing basic systems; don’t reinvent them.

• Use proven rather than leading edge automation technology and equipment.

• Discard “nice-to-haves” when requirements, costs, or schedules are impacted.

• Watch out for “just-might-as-well” features. They always cost more than pre-
dicted and often are never used.

• Keep it simple. Complex systems require costly maintenance and sophisticated

operators. They are hard to modify. Automation is an aid not an objective or a re-
ligion.

• Keep the system user friendly or it won’t be used!

Traceability
Despite best efforts, bad parts occasionally get into good hardware. Once known, the
problem is to find them. For most commercial items, that task is left to the customer. Re-
placement is covered by a wide variety of warranties. However, given product liability
developments, that course is not always wise. For military items, the task is a joint effort
of the contractor and the military custodian of the delivered products. Usually, the task is
urgent because bad parts cause malfunctions which can generate a disaster overnight. So,
there is always pressure for “a better system”.

Beware! Better systems generally require serialization of everything and retained assem-
bly records stating which serially numbered part went into which serially numbered next
assembly all the way up to the serially numbered top assembly of the product. It sounds
easy, fast, and cheap? It’s not! Furthermore, miniaturization prevents serialization of
many parts.

A decision to adopt such an approach rests upon the probability of having bad parts as-
sembled, plus the current ability to find them, plus cost – versus – the efficiency and cost
of the more elaborate method. The manned space program of NASA is a good example of
the need for a very elaborate traceability system. The cost is justified by the need to pro-
tect human life.

The first defense against bad parts is a well-run, intelligently self-disciplined organiza-
tion. Every executive, manager, supervisor, and employee needs to appreciate and guard
against the consequences of bad parts. The reason for this seemingly platitudinous state-
ment is that bad parts seldom result from deliberate wrongdoing or even simple neglect.
They most often develop subtly from ignorance.

The second defense is good, not excessive, common records well kept in every major de-
partment.

34
Rev. 1 Appendix - Generic CM

Keeping it simple, a search starts with the Release Record. When were the governing
documents released? Where are they used? What is their effectivity (how many and
when)? The next step is Procurement. When did the parts arrive in-plant? When and how
many were released to Manufacturing? Then in Manufacturing, when were the parts next
assembled? How many were scrapped? Which end-product units were in line to receive
the assembled parts and when did they ship? Then in the field, where are the end products
now? Find, test, fix, and keep track of the bad parts until all of them are accounted for.

It sounds forbidding, and it is. However, most experience indicates that this loosely orga-
nized but existing capability is the preferable method. It will be available because its re-
cords exist for other real needs. The more elaborate approaches fall into disrepair because
their maintenance and costs are resented!

Traceability is an excellent illustration of the fact that CM is a discipline applied by

many, not an organization. Please note that no one but the General Manager controls all
the departments involved in a bad parts problem. Only those departments can and will
maintain records for their own reasons which can also support a search. Any “CM Man-
ager” confronted with a traceability problem is completely dependant upon the active
support of people he cannot control.

Lot Control
A manufacturing lot is a number of units of the same item to be created at the same time
through a series of manufacturing operations. The number of units is based on economic
lot size. The contract quantity of simple parts, such as stampings, usually constitutes one
lot because it costs more and takes longer to setup the machine than it does to make the
parts. The lot size for intermediate assemblies will have more to do with efficient move-
ment from one manufacturing operation to another. The top assembly (product) is often
made in lots of one. However, economic lot size is almost totally dependent upon the
kind of product and type of manufacturing operation.

The existence of manufacturing lots is an almost irresistible temptation for the advocates
of traceability. The associated data, captured in an automated system as part of an as-
built baseline, could be of tremendous help in tracing bad parts. It could help in diagnos-
ing failures and a lot of other things. It could also bankrupt the company.

The key word is could. The cost of having the data must be weighed against the conse-
quences of not having the data. So far, not having has won. As the kinds of interrelated
data increase, the system becomes more complex and costly to design, maintain, and op-
erate. Eventually, more will be possible but eventually isn’t now! Because something can
be done does not mean that it should be done!

As noted earlier under Traceability, lot data is usually available as a normal part of manu-
facturing records. It’s just awkward to use in that form.

35
Appendix - Generic CM Rev. 1

Change Control
Change Control maintains the integrity of released (verified) items by approving or dis-
approving changes to them before the changes are made.

Hard Facts
We start with some hard facts of life.

• Engineering is an iterative process; that is something is done from which some-

thing is learned which causes something more to be done from which something
more is learned and so on until the boss says “good enough” – or they run out of
money.

• Manufacturing is an iterative process until it stabilizes. Then it becomes repeti-

tive.

• Suppliers discontinue some items, initiate new ones, go out of business, or fail to
deliver as promised. Replacements are necessary.

• Given these conditions, change is inevitable! But, if it flows without restraint

chaos and bankruptcy loom. Release was developed to bring order and Change
Control was instituted to maintain it.

• Change Control was not designed to reduce the number of changes! Although it
has some impact on volume the result is relatively slight. The volume of change is
driven by the difficulty of the technical work, the experience of the personnel do-
ing it, and the schedule!

We can accommodate these facts or we can ignore them and suffer the consequences.
They will not evaporate.

The Change Control Process -

• Determines the desirability or undesirability of each proposed change.

• Facilitates the implementation of desirable changes.

• Prevents the implementation of undesirable changes.

Figure 9 shows the primary elements of the process

36
Rev. 1 Appendix - Generic CM

Desirable
Release Implement
Propose Evaluate Approve
a the IF
Change Proposal Undesirable
Archive
Reject
.
Fig. 9 Change Control Process
The hang-up of course is the definition and interpretation of “desirable”. There is no gen-
eral or lasting solution to that quandary. Numerous categories, definitions, and guidelines
exist but none of them, none of them, are adequate over time. The hard fact is that the
desirability of change varies from industry to industry, product to product, time to time,
place to place, and situation to situation.

Obviously, any change necessary to align the product to need is desirable. Any change
that lowers cost is desirable – unless it wrecks the schedule. Any change that increases
cost is undesirable – or is it? There simply are no good generalizations. The harder we try
to define, refine, and apply them the more muscle-bound we become. At some point, we
must rely on informed judgment!

Change Control applies to all released documents and all completed hardware. Changes
are proposed at any time during any phase for any number of reasons. Usually, a Change
Control Board is responsible for evaluating them. The board members represent all ele-
ments of the organization that have direct responsibility for the product. They determine
desirability or undesirability in accordance with criteria supplied by management, the
buyer, the situation, and their own good sense difficult though that may be. Desirable
changes are approved, released, and implemented. Later they are incorporated into the
documents that they change. The revised documents are subject to re-release.

The Change Board’s task is further complicated by the fact that the desirability of a par-
ticular change is not always clear. It is often a matter of technical judgment subject to
vigorous debate.

Proposing Changes

The process starts with a written Change Request. So who can write one? At first blush
you might think that any employee qualifies but that’s not necessarily so. Some organi-
zations limit the kinds of personnel authorized to write a change proposal in the hope that
this filter will keep foolish or unnecessary changes out of the system. It may have been
decreed that only a supervisor or manager can submit a change. Perhaps only Manufac-
turing Engineering can propose factory changes or maybe there’s a group of change en-
gineers who do all the proposing. Whatever, these schemes always add cost and time to
the system without significant benefit.

First, it is deceptive to think of all this activity as happening outside the change system.
In reality it is part of the system whether it’s recognized as such or not. Second, it is a

37
Appendix - Generic CM Rev. 1

major error to think of most changes as unnecessary or frivolous. To prove this fact you
need only setup an anti-frivolous filter and see what’s caught in the net. Significant
frivolous change is an industrial myth, good for emoting but little else. Third, these su-
pervisors, managers, or special engineers are removed from the situation by one-degree
or more. That means that they must take the time to gather facts and make a decision.

Generally organizations with great concern for quality will permit any employee to pro-
pose a change because they are concerned with getting all of the kinks, quirks, and errors
out of their products. In my opinion any employee of the organization should be allowed
to propose a change. At most I would insist that he get the approval or acknowledgement
of his own supervisor to gain a little more maturity in the decision. However, I stress the
fact that the system must fit the organization it serves or it will be destroyed. If that re-
quires special filters or writers, so be it.

Regardless of who prepares it, the proposal must state what is to be changed, how it is to
be changed, and why it is to be changed. It should be as clear, complete, and accurate as
possible to communicate adequately.

Where-used (next assembly) data for the item to be changed must be gathered from the
Release System and included in the proposal. It is unwise to think of most items as hav-
ing a single usage. Use of an item in more than one next assembly or product is quite
common and all uses must be considered in evaluating the change.

Evaluating Changes

Generally changes are evaluated by a Change Control Board, which consists of a member
from each element of the organization that has responsibility for the product. A so-called
“neutral party” chairs it. The members must be quite adept at recognizing the limits of
their own competence. They apply some version of the following questions to each usage
(next assembly) of each change and they answer for their organizations if they can.

Technical
• Will the product function if the change (a) is made, and (b) is not made?
• Is reidentification required?
• Should the change (a) be made, and (b) why?

Financial
• What is the cost to your organization of (a) making the change and (b) of
not making the change?

Schedule
• Upon approval, how long will it take your organization to implement the
change?
• What effectivity should be assigned?

38
Rev. 1 Appendix - Generic CM

If board members cannot answer these questions, they get the answers from their organi-
zations. When conflict or ambiguity arises, they pull the right people together and seek
resolution. Regardless of the method used, the questions must be answered for each us-
age (next assembly) of the item being changed. Based on the circumstances, the decision
is documented in one or more of the following forms. These decisions also verify the
content of the document and authorize its release.

Document What When

Stop Order A written order to stop work
until further notice.
Deviation Written authorization, be-
fore an item is manufac-
tured, to vary from released
documents for a specific
number of units or period of
time.
Waiver Written authorization, after
an item(s) is manufactured
to vary from released docu-
ments.
Change A written order to change a
Order released document, as speci-
fied in the order, at a speci-
fied effectivity.
Rejection Written notice of the reason
for rejection.
Table 2 Change Board Decisions
Continued work or pro-
curement will result in ex-
pensive rework or replace-
ment.
Permanent change to the
design is inappropriate but
a temporary deviation is
necessary.
Such units are suitable for
use “as is”,
A permanent change to the
design is required.
The Change Request is not
acceptable.

Approving Changes
Change decisions can be made by a Change Control Board or by a number of other meth-
ods. Frankly, no one method is clearly better than another as long as it (1) reaches every
affected element of the organization not for political reasons but because that’s where the
knowledge is, (2) is able to force timely trade-offs and final decisions when necessary,
and (3) fits the organization it serves. The personality of the organization, most of its
customs and traditions, and the powers that be, must be accommodated! And that means
that very few of these methods transplant from one organization to another without sig-
nificant modification. One size does not fit all!

If the Board is unable to reach a decision the proposed change is presented to the Pro-
gram Manager(s) for decision.

39
Appendix - Generic CM Rev. 1

After the Decision

Each Stop Order, Deviation, Waiver, and Change Order has its own Identification. When
approved, they are promptly released which places them under Change Control. The rest
of the organization responds by implementing these released documents at the effectivity
specified. Rejection Notices are sent to the originator and Change Requests are filed.

Incorporation
In due course, the content of Change Orders is incorporated into the documents that they
change, the identification of changed documents is adjusted, and the revised documents
are released as replacements for the previously released Change Orders. Most organiza-
tions limit the number of Change Orders that can be outstanding (unincorporated) at any
one time in order to reduce confusion.

Stop Orders, Deviations, and Waivers are never incorporated but remain a permanent part
of the Release Record. Hardware subject to Deviations and Waivers is marked with the
Deviation or Waiver Identifier.

Change Classification
Some organizations use elaborate systems of classification to route changes through
variations of processing. Class I vs. Class II, mandatory vs. non-mandatory, major vs.
minor, supplier vs. contractor, customer vs. contractor are examples. For instance, a Class
I change alters contract cost and generally goes to a headquarters command for review
and approval (slow) while Class II changes do not alter contract cost and are reviewed
and approved by a local customer representative (faster).

Generally, classifications emerge as compromises in a constant struggle to make Change

Control simpler and faster. However, they soon become parochial in nature, barnacled
with local practices bordering on superstition, and have far more to do with power than
efficiency. The fundamental questions will always be who has the power to say, “Yes”
and who has a veto.

As for the CM Discipline, there are only two logical questions to be answered. Do we
know enough about the change and its ramifications to make a decision? Should we make
the change in spite of (or because of) the ramifications? Yes or No! Whatever method
produces these answers, completely and accurately, is adequate!

Change Status Reporting

An automated Change Status System is a necessity. The data recorded must include iden-
tification of Change Requests, the documents or items they would change, the classifica-
tion of the change, location of the Change Request in the processing cycle, the final dis-
position of the Request, and the date of everything. The primary capabilities of the sys-
tem should include random access, sorting by any of the elements recorded, counting
everything sorted, and time span calculation.

The kind and volume of data available in the Change Control process is almost infinite.
The demand for it is sporadic and usually capricious. The effective use of it is very un-

40
Rev. 1 Appendix - Generic CM

even. The cost of recording, processing, and preserving it is relatively high. Even so,
some amount of it must be available! The problem is simple. The solution is not.

Normally, no one except Change Control Administrators and Processors has much inter-
est in Change Control data until something goes wrong. Thereupon, the wronged-ones
demand information for defense and counter-attack. The problem can be about anything
from any level in any department. Unless satisfied, it can swell until it involves many
levels and many departments.

If data is available, it will be beaten to death by the wronged-ones until they exhaust
themselves. If data is not available, Change Control will likely be “reorganized”. There-
upon, in either case, all will return to business-as-usual until the next time.

The key factor in all this is easy to spot but hard to deal with. By the time that a change
has a status to report, the problem that generated it exists. The need is to solve that
problem not to status the change. However, the change is the presumed solution. Every-
one concerned wants to know where it is in the process and how soon it will be approved.
Usually, the location is known and processing time can be estimated. However, that in-
formation is seldom enough.

So the Change System itself becomes the culprit. Why is it so slow? What is being done
to expedite? The answers to these questions and a dozen others are seldom acceptable so
the emoting goes on and another log is tossed on the fire of controversy.

In the broader sense, the study of change statistics can produce a number of insights into
plant operation. The problem is that almost no one is prepared to do anything construc-
tive about them. It’s not hard to find that most changes are coming from a particular de-
partment. It’s very hard for that department head to do something timely about it. It’s not
hard to see that span time is expanding and to locate the delays. It can be almost impossi-
ble for the delayer to do anything timely about it.

It is difficult for most people to recognize that the causes of Change Control problems are
rarely found in the system or the processors. The causes lie deep within the operating
philosophy of the enterprise. By the time they are recognized, the fat is in the fire and it’s
too late for prevention. The obvious time to correct such problems is in the calm between
programs when managers have more time. However, the incentive is usually obscure
during such lulls. When the incentive becomes obvious, the lull has passed and there is
no time to make general improvements.

One more time – there is simply no substitute for a thorough understanding of the indus-
trial process and the way that it functions in your workplace. Change Control is difficult
with it and nearly impossible without it!

Customer Change Control

Customer Change Control is always controversial.

41
Appendix - Generic CM Rev. 1

First, it takes time, a lot of time. The customer is cautious because he doesn’t know what
he’s getting into. The contractor is impatient because he’s anxious to implement his deci-
sion. Second, many contracts have compressed, even incentivized, schedules which are
often impossible of performance on their face. They also include Customer Change Con-
trol with no time limit on that process. Thus, the contractor strives to meet schedules,
which the Customer thwarts with untimely Change Control. Third, in adversarial settings
professional conceit swells, “professional differences of opinion” proliferate. They take
time and cost money. Fourth, anyone with the right or obligation to intervene is clearly
culpable for the consequences. “You approved (or disapproved) so it’s your fault!”

Therefore, customers are well advised to be very selective about imposing controls on
contractors. Even so, common sense dictates customer control of any change that would
alter the following basic parameters of the contract.

• Contract cost, schedule, terms, and conditions.

• Requirements that the finished product must meet. (Functional Baseline)

• Verification methods used to assure that the finished product actually

complies with its requirements. (Demonstration & Product Baseline)

Military customers have paid dearly for their unwillingness to accept these limits. With-
out deep and detailed control, they fear that poor contractor judgment or chicanery will
leave them holding the bag. So they tend to require review and approval of every change
to make sure it’s OK. The irony is that the Military is no more adept than the contractor
at making sure. Having spent much time and money on prevention they are still left
holding the bag – but – they tried. This is a real problem. Every attempt to solve it pro-
duces new manifestations because it is inherent in the government-contractor relation-
ship!

This problem won’t go away. It’s too subtle to solve. But it could be eased if Customer
Change Control applied only to the basic parameters of the contract as stated above.

As a safeguard, the customer can require information copies of all Change Control deci-
sions. If the contractor’s independent judgment is unwise, it can be suspended or reversed
through various contract provisions. This approach allows the contractor to be a contrac-
tor instead of an employee and reduces the customer’s culpability. It also provides the
Military with a brake to apply when necessary and it will reduce overall cost.

Perhaps the most important factor is that a contract is supposed to be a voluntary agree-
ment to cooperate. When it becomes an adversarial invitation to combat, the product suf-
fers! Customer Change Control should be defined and exercised in that light.

42
Rev. 1 Appendix - Generic CM

Field Modification
Generally, modifications developed and implemented by field personnel are unwise. It is
almost impossible for them to know all the ramifications of their actions which may come
back to bite.

However, it is not uncommon for field personnel do develop a modification as an im-

provement. Such modifications are treated as changes and are Identified, Documented,
Verified, and Released into the Product Baseline. They are fabricated as kits and shipped
to the field for installation. They are installed, verified, and recorded in the Product Log.

Retrofit & Refurbishment

A retrofit usually involves major modifications. Normally, these will be Identified,
Documented, Verified, Released, and Change Controlled either as a major change or as a
different product. A refurbishment usually replaces old or worn parts. It makes no change
in the design or performance of the product. In both cases, implementation is usually
done in a factory.

Fixing Change Control

Every so often a novice, with the power to impose, declares that he “is going to fix
Change Control”. Life becomes quite difficult until he learns that neither he nor anyone
else can “fix” that which is intrinsic. The best he can do is to improve administration that
seldom betters overall performance by more than 10 percent, if at all.

The intrinsic factors are the volume of changes which should be lower, the number of
people involved which should be fewer, the behavior displayed which should be better,
the span time which should be shorter, the cost which should be lower, and the complex-
ity which should be simpler. You, like hundreds before you, will wonder why these goals
cannot be achieved once and for all. The answer follows.

Far too many people think that the responses to a Change Request can be routine, timely,
and clear; with trade-offs made promptly; and decisions made quickly. Most of the time
they’re wrong. Information is often late, ambiguous, and conflicting. A change, needed in
one usage, can be acceptable in another, and be a disaster for a third yet reidentification is
opposed. The manufacturing costs could be lowered but the hardware will have been
completed before the change can be implemented. Engineers are irked because their work
has been challenged. Change requestors are irritated because their work is delayed. Man-
agers are harried because their work is increased. And, each one wants his problem
solved his way!

Before Release, relatively few people are affected. After Release, hoards of people base
their work on it. As the program progresses, other designers, test engineers, manufactur-
ing and inspection planners, tool engineers, buyers, suppliers, vendors, budget managers,
etc. become dependant on it. If that release is changed, at least some of their work is lost
and must be redone. Frustration and stress are abundant. Only the most sophisticated
handle it well.

43
Appendix - Generic CM Rev. 1

Another problem is the “no change” syndrome! Unfortunately, neophytes sometimes gain
the power to issue no-change policies that inevitably embarrass them and everyone else.
Change is inherent to engineering, manufacturing, and procurement. If nothing else hap-
pens (and it will), vendors go out of business resulting in a necessary change of parts.

In the engineering world, there is almost no such thing as “doing it right the first time” no
matter how good they are or how hard they try. Engineering is an iterative process. Each
iteration produces new knowledge that quite often exposes both new and old errors and
possibilities. Similarly, Manufacturing produces new knowledge that poses problems
even though it was “done right the first time”. Yes, these circumstances can be used to
mask incompetence and that’s a significant problem for supervisors. Nonetheless, these
circumstances are real and they do produce changes that have to be handled!

There are as many schemes to manage Change Control, as there are people involved in it.
None of them really alleviate the frustration because the intrinsic elements remain intrin-
sic. There is no sweeping panacea awaiting discovery. Some things in life are simply hard
work. Coping with the intrinsic elements of Change Control is one of them. However the
following can help.

Competent personnel, deeper understanding of industrial practice, minimum Customer

Change Control, realistic expectations, sound program planning, and adequate time (be-
ware of compressed schedules) are the elements most apt to improve performance. Even
so, don’t expect to “fix” Change Control. Learn to cope with it.

Warning
Hopefully the foregoing discussion of Change Control has explained at least a few of the
most significant reasons why it is so often controversial. Not so clear is a common conse-
quence. Problems pile up and emotions run riot. The attention they demand swells
Change Control until it displaces CM. In fact there are many managers today who think
that CM is no more than a fancy name for Change Control. They are wrong! Essential
though it is, Change Control cannot keep “an evolving product in alignment with the
specified need for it” unless the CM Process was properly applied.

If all you want is Change Control, call it that and do it. If you want to keep your product
aligned with need, apply the CM Process and all of its tools.

The Never-Again Syndrome

Like many other things all of these elements of CM are subject to the “never-again” syn-
drome. A mishap occurs. A task force is formed to see that it never happens again! A
check, balance, procedure, audit, or the like is added to the practice and the mishap does
not recur. However, years later the safeguard appears to be useless. No one remembers its
purpose. Indeed the original purpose may no longer exist.

44
Rev. 1 Appendix - Generic CM

Such accretions are hard to remove. What appears to be useless may really be needed
somewhere deep in the organization. No one knows all the nooks, crannies, and conse-
quences. So it’s easier to leave them than to run the risk of removal.

Contrary to popular belief, this condition is not peculiar to government. It is a malady of

large organizations, public and private. It is more prevalent in government because al-
most anyone from a crank to the press can criticize governmental mishaps making over-
correction probable. Generally, there is no cure but knowledgeable people can manage
the condition.

There is no doubt that the CM practices should be reconditioned periodically. Their es-
sential elements may be rearranged or updated to accommodate new proven technology.
However, any greater effort is likely to reinvent the wheel under a different name. It’s
wise to remember – a wheel by any other name is still a wheel.

***

45
Appendix - Generic CM Rev. 1

4. PHASES & BASELINES

Tailoring
Originally, the Military thought that one size would fit all. They persisted primarily be-
cause they had few who really understood the fundamentals of an industrial plant. As a
result, they got an inadequate system, muddled allocations, and a product developed in-
dependently of both. So they came up with the idea of “tailoring” which allows substan-
tial adjustment and selective application. It also allows the less scrupulous to duck and
avoid. However, the objective is still to keep the product directly aligned with the speci-
fied need throughout the program, no more and no less!

Allocated Baseline
The Allocated Baseline seldom worked well in its original form. The primary cause is the
disparate methods used by various industries, contractors, and subcontractors to get re-
quirements from the Functional Baseline into their design organizations. Their methods
are as varied as the people using them and it is wise to use those methods unless a com-
pelling reason dictates otherwise. Consequently, the Allocated Baseline finally became
optional.

This decision put the power to require an Allocated Baseline into the hands of various
buying commands. They have used it for a wide variety of purposes or not at all. The
problem is complicated because it’s rooted in the subtleties of engineering practice, poli-
tics, and technology. Even so, variations of the Allocated Baseline are easier to under-
stand if you know a bit about the forces that shape them.

When the Military decided to define need first and then design a product to meet it, the
first large scale use of System Engineering (a more or less new engineering discipline)
came into being. This discipline brought at least two new concepts into play, system and
allocation.

System
The definition of system will remain forever controversial. There have been conferences,
symposiums, and powwows convened to define the term. They have come up with such
things as a self-sufficient entity including hardware, facilities, techniques, and personnel.
Few are satisfied and the debate continues.

Further examination will reveal that these efforts have little to do with the realities of a
system and much to do with protecting the interests of powerful factions. As one wag put
it, “He who defines system, controls the (engineering) world”, an exaggeration but not
without merit. So, what can be done with the problem?

46
Rev. 1 Appendix - Generic CM

Simply put, stay out of it. Use a working definition. For CM purposes, a system is all of
functions, including outside interfaces, necessary to meet the specified need. If it finally
turns out to be a subsystem, component, or something else, rename it. A system in one
use becomes a subsystem in another and a mere assembly in a third. All of these terms
are relative to the context in which they are used.

Regardless of what it’s called, the idea of treating the end-item to be developed as a
functioning whole rather than a patched together collection has great merit. The emphasis
on interfaces has even more merit. You may well ask, “Wasn’t this always necessary?”
And, I must answer, “Yes, it was.” but it was often haphazard. Elements such as main-
tainability, training, and even interfaces were often overlooked or left for later in the pro-
gram. Such practice always produces problems, sometimes very serious ones.

The critical concern is to define an entity that includes all of the functions and outside
interfaces necessary to meet the specified need. In most cases, that entity will be a sys-
tem.

Interfaces
An interface is the point, line, or plain where two items meet or interact. It may be
electrical, mechanical, or functional. It may even be specified empty space be-
tween items.

• Outside Interface: An interface between a product and an item outside of

it. Example: an aircraft radio receiver and a control tower transmitter or an
automobile gas tank and a gas pump nozzle.

• Inside Interface: An interface between components of the product. Exam-

ple: An aircraft wing and the gas tank inside that wing.

Outside interface characteristics can be documented in the product specification,

in a referenced interface drawing, or in a referenced interface specification. Such
characteristics are subject to Verification, Release, and Change Control as part of
the Functional Baseline.

Inside interfaces can be documented with interface drawings. However, they are
more commonly recorded in the documentation of each interfacing item. Thus, a
comparison of documents is required to see both sides of the interface. The man-
agement of interfaces is an engineering task that should not be left to novices!

47
Appendix - Generic CM Rev. 1

Allocation
Once the functions of the system have been defined and verified they are allocated (as-
signed) to sub-systems. Each sub-system is evaluated as a separate functioning entity and
then verified. The sum of the sub-systems equals the system.

There are two advantages to this approach. (1) Developing and verifying sub-systems is
another way to examine the system as a whole, another chance to find and correct errors.
(2) Sub-systems divide the System into more visible and manageable work packages at
least in theory.

The work of system definition and allocation is done by System Engineers. It is then
handed to Design Engineers who are expected to design physical items that perform the
functions of the sub-systems. Theoretically this scheme produces the neat result depicted
in Figure 10. Please note the Baselines are provided for reference.

Need

System System
Functions Baseline

Subsystem 1 Subsystem 2 Subsystem 3 Subsystem 4 Allocated

Functions Functions Functions Functions Baseline

Subsystem 1 Subsystem 2 Subsystem 3 Subsystem 4 Product

Physical Physical Physical Physical Baseline

Design Design Design Design

Fig. 10 The Original Allocation Concept

However, this scheme seldom produces the neat result shown. Some of the more signifi-
cant reasons are noted below.

Cookie Cutter
The approach in Figure 10 was designed for new products and applied as a cookie cutter.
However, one size does not fit all. It doesn’t even fit most.

In reality, there are very few totally new products. Most of them are modifications of ex-
isting items or technology to produce a new result. It’s logical to ask why functional sub-
systems should be developed for existing physical items whose functions are already es-
tablished. There are some theoretical reasons but they fade rapidly when cost versus
value is examined.

48
Rev. 1 Appendix - Generic CM

Figure 10 implies that there is a one-for-one relationship between sub-systems and physi-
cal items. Sometimes that’s true as when a propulsion sub-system becomes a rocket mo-
tor. More often it’s not true as when an automobile electrical sub-system becomes head-
lights, taillights, and many things in-between. Figure 11 presents a more likely outcome.

Need

System System
Functions Baseline

Subsystem 1 Subsystem 2 Subsystem 3 Subsystem 4 Allocated

Functions Functions Functions Functions Baseline

Item 1 Item 2 Item 4 Product

Physical Physical Physical Baseline
Design Design Design

Item 3 Item 5
Physical Physical
Design Design

Fig. 11 A Typical Allocation Outcome

One-For-One
The desire for a one-to-one relationship between the functional and physical is more than
compulsive symmetry. It does make tracking the functional to the physical and back
much easier. This notion played a major role in the genesis of “Two Part Specifications”
to document a single item. Part 1 was Functional and Part 2 was Physical. However, the
practice requires that physical items be known before the functional allocation is made.
This is quite a compromise of the original idea and an invasion of Design Engineering
Territory.

Turf Wars
The allocation concept implies that function is the province of System Engineering while
physical design belongs to Design Engineering. Even though Figure 11 shows only two
levels of functional design, there is nothing to prevent allocation to several additional
levels. Such action tends to dictate physical design. It wasn’t long before over enthusias-
tic System Engineers found themselves in small enclaves surrounded by a much larger
group of hostile Design Engineers (with the power to disable) who felt that they had been
invaded and trashed by a foreign force. Turf wars, neither hot nor cold, but uncomforta-
bly warm, developed and continue in some quarters to this day.

49
Appendix - Generic CM Rev. 1

In reality, while the focus of Systems Engineering is functional and the focus of Design
Engineering is physical, both must deal effectively with both functional and physical as-
pects of the product. Turf wars simply complicate an already complex problem and con-
tribute little to its solution.

The Upshot
Having lost sight of the objective, they redoubled their efforts. Prime Items, Critical
Items, two-part specifications, and Configuration Items, are among the compromises that
still litter the landscape. The uproar finally became so debilitating, that the Military made
the Allocated Baseline optional. Of course, this action questions the need for allocation to
sub-systems in the first place. In fact, it has been used to avoid the sub-system level alto-
gether by cramming such detail into the definition of the System. Although that approach
can work, it can also produce 3 or more inches of inordinately complicated system speci-
fication.

Please remember that the cause of controversy is rooted in the subtleties of engineering
practice. Resolution depends upon (1) the practices of the buying agencies and their con-
tractors, (2) the attitudes and competence of the engineering organizations involved, and
(3) the maturity of the technology needed for the product. Given the number of variables,
resolution must be found System-by-System, one at a time. The resolution for one seldom
transplants to another without major tinkering.

The engineers of the buying agency and the contractor must reach such resolutions. Oth-
erwise, it fails! CM has no contribution to make to such resolutions. However, there is
another way to approach the problem.

A Tailored Allocated Baseline

Sooner or later systems must be divided according to the organizations that will have de-
tail design responsibility for the physical items in the system. Usually that division pro-
duces the following.

• Customer Directed Items

• Subcontracted Design Items
• Contractor Designed Items

Customer Directed Items

Customer Directed Items usually fall into one of two categories: (1) Customer Supplied
Items such as warheads or (2) Existing Items from specific contractors such as rocket
motors. There are all kinds of reasons, usually economic, why a customer decides to fol-
low this route but regardless of reason he has the right to do so. However, he remains re-
sponsible for the detail design of the item!

As a minimum, the interfaces between these items and the product of this program must
be documented, verified and released as a part of this program’s product! And, the Cus-

50
Rev. 1 Appendix - Generic CM

tomer must agree not to permit change to these interfaces without the prior agreement of
the contractor for this program!

Usually Customer Directed Items are identified in the System Specification (System
Baseline). However, if such identification is missing or inadequate it can be added to the
Allocated Baseline. If the Items exist the existing documentation is usually adequate. If
they do not yet exist original documentation must be created.

People often overlook the fact that the interfaces of such Customer Directed Items be-
come design constraints on the product of this program. That is everything else must be
designed to be compatible with them. If those interfaces are not imposed upon this pro-
gram they will be ignored and significant trouble will follow.

Subcontracted New Design

A contractor subcontracts design because he doesn’t have (1) the capability in terms of
personnel or facilities who can do it as well or (2) the capacity in terms of enough per-
sonnel, space, or equipment. Obviously, he has to tell the subcontractor what he wants
done. This task is usually accomplished through a functional procurement specification
that states the functions the item must perform, and the functional and physical interfaces
that the item must meet. (It also includes verification methods and handling require-
ments.) The proper place for this sort of item is the Allocated Baseline.

Contractor Designed Items

This category includes everything required by the System other than Customer Directed
Items and Subcontracted New Design.

Every contractor has evolved a way in which to divide and assign Design Engineering
tasks. It is based on powerful personalities, organization, tradition, experience, and myr-
iad other elements. No two are the same. Tamper with it at your peril.

The Military has never learned this lesson and they pay dearly because of it. The result is
that the contractor pursues his own method and converts the results into the form the
Military prefers. The Military reviews, comments, amends, and approves these results.
Thereupon the contractor reverts to his own method. This means that parallel methods are
operating at the same time. They are the cause of much expense and no little confusion.

A far more practical approach is to let the contractor proceed in his established manner.
He may divide the work into recognizable subsystems and verify and release them into an
Allocated Baseline. He may divide the work into dozens of work assignments and control
them through some variation of a release system. He may choose some other device. In
any case, he is allocating functions from the System Specification to Design Engineering.

For CM purposes, the System Specification is lurking in the background as the source of
functional requirements to be met by Contractor Designed Items. Technically speaking
this means that the source of requirements for Contractor Design is really the Functional

51
Appendix - Generic CM Rev. 1

Baseline. For coherency, you may think of the System Specification as if it had been re-
leased into the Allocated Baseline (for reference) even though such a release is rare.

Figure 12 displays the foregoing approach to an Allocated Baseline.

Need

System System
Functions Baseline

Sub Customer Allocated

Baseline
Contract Directed
Item Item

Contractor Contractor Sub Product

Customer
Des ign Des ign Contract Baseline
Supplied
Item Item Desig n
Hardware
Item

Con tr acto r Con tr acto r

Desig n Desig n
Item Item

Fig. 12 A Tailored Approach

The Lesson
There is no virtue in an Allocated Baseline as such. It must contribute to keeping the
evolving product in direct alignment with the specified need or it is superfluous. When
the real effort is to impose or avoid an Allocated Baseline the result will be useless and
often harmful. Real-life solutions depend upon the product to be developed, the maturity
of the technology, the experience and maturity of the personnel, and prevailing practice
in the industry and agency. Once again, one size does not fit all.

The As-Built Baseline

The notion of an As-Built Baseline arises from the fact that there can be permissible un-
certainties between the Product Baseline and the hardware built from it.

Alternate or substitute parts are one obvious example. Perhaps the Baseline calls for Part
902 or Part 888 in an assembly. The factory installs first one and then the other depend-
ing on availability. No special record is made. Later in production or in the field it is dif-
ficult to tell which part was installed. It can be impossible if the part is miniaturized.
Doesn’t it just make good sense to keep a record of the part actually used?

52
Rev. 1 Appendix - Generic CM

Not necessarily. If we insured against all possible perils we would be insurance paupers.
So we insure against the most probable worst perils. Simple prudence demands that the
cost of a probable consequence be weighed against the cost of preventing it.

When the perils of manned space flight are considered, the consequences of not doing
something can be catastrophic. Consequently, NASA is much more concerned with the
as-built problem. The concern drops when most defense systems are examined and drops
again for most commercial products.

There is no decision formula for this problem. Solution depends entirely upon specific
situations, probabilities, and experience. So far, in most situations there is little justifica-
tion for an as-built baseline.

***

53
Appendix - Generic CM Rev. 1

5. HOW IT WORKS

Phase 1. Define the Product

Correcting Need
What do you do when you discover that the specified need is really and truly wrong?
Fix it! Change it! Now! And, accept the consequences. They don’t get better with age.

That last statement is not always true. If the Congress has set the need in stone or if the
Brass is career dependent upon a particular need, changing it can be career limiting for
them and for you! Programs can be cancelled and people can be fired! Sometimes waiting
removes the obstacle through retirement or reassignment and the consequences look bet-
ter. However, those are political decisions! The CM Disciple can only contribute facts,
which are often unwelcome. It has no part in making the decision itself.

This Devil’s Brew is real! It’s often the root cause of CM controversy. After all, without
the surveillance made possible by CM there would be no unavoidable facts to disturb
minds already made up. I have no easy solution. It is one of life’s conundrums to be
solved by each of us in his own way. It is also the reason why integrity is often prized in
theory and demeaned in practice.

If the need is no longer legitimate, fix it. Doing otherwise can cost lives. But understand
that CM cannot make the decision for you.

Generally, need is altered by submitting a Change Request to modify the System Specifi-
cation. It is assumed that the customer will examine that change against need and alter
need or reject the change. This is a weak spot in the system for there is nothing that
forces the customer to do that job. If it isn’t done the gap between need and design reap-
pears and design drift sets in.

Phase 2. Define Major Components

One could go on for some time about major components to no particular benefit. How-
ever, it is quite important to understand the material presented under “Allocated Base-
line” in Section 4 above. It applies.

Of course care should be taken to see that all specifications are adequate and accurate.
But those dealing with Subcontracted or Customer Directed Items need special attention
precisely because people are apt to give them short shrift. After all subcontractors are
very knowledgeable and should need little direction. Customer Directed Items already
exist and should be quite easy to define.

However, a mistake under the control of the prime contractor is relatively easy to correct.
But one that crosses a contract line is subject to correction by at least two parties. That

54
Rev. 1 Appendix - Generic CM

makes it difficult. It also opens subcontracts to some degree of renegotiation that can lead
to price increases. It’s wise to put a little extra effort into Verification for this phase.

Phase 3. Design Prototype

The work of design is the selection of characteristics in the form of raw material, detail
parts, subassemblies, and assemblies, up to the top of the product. It includes the integra-
tion of Customer Directed Items, Subcontractor Design Items, and Vendor supplied mate-
rials, parts, and supplies. Hundreds of people are involved. Thousands of documents re-
sult.

Verification of this design really takes place in Phase 4 when the Demonstration Tests are
conducted. Even so, checkers and editors perform an analysis almost as complete as a
Compliance Review even though it is done piecemeal, document by document, over a
longer time period. This verification is essential to reduce the manufacturing costs in
Phase 4.

Demonstration Plan
The Demonstration Plan is critical because it will be used in Phase 4 to prove that the
Prototype Design meets the Need.

The Plan is derived from the verification requirements of the System Specification
(Functional Baseline), Component Specifications (including the Allocated Baseline) and
the detailed design of the Prototype. It will demonstrate one or more manufactured units
of the Prototype under field conditions as close as possible to those for which it was de-
signed. Contractor and customer test engineers working in close cooperation usually de-
velop the plan. A Compliance Review verifies it.

Most often the detailed plan for Prototype demonstration is released and controlled by the
organization that develops it. The obvious question is why. They had it under control
long before the advent of CM. At that time Release and Change Control were seen as
support to production rather than control systems for the enterprise and Test Engineers
were isolated in their own little world. They had to do everything for themselves. Thus,
tradition, organizational power, and rivalry played a part in both customer and contractor
organizations.

The Demonstration Plan is used by relatively few people and there is no CM reason to
change the method of control. In fact, it is a good example of CM being performed by the
people doing the technical work. As long as good performance is maintained the only
reason to change this approach is a centralized system argument.

The best arguments for centralized systems are economics and discipline. Complexity
and inflexibility are the best arguments against it. The deciding factors are found in the
personality and operation of the enterprise. If the CM Discipline can be maintained with-
out centralization, there is no good CM argument to centralize. In most cases a hybrid
approach develops and works.

55
Appendix - Generic CM Rev. 1

Phase 4. Build, Test, and Refine Prototype

Refinement for Producibility

Many of the standard techniques of manufacturing are uneconomic when only one or a
few units are to be manufactured. So, they are truncated or modified during the manu-
facture of Prototypes. Manufacturing planning and routing, inspection planning, tooling,
castings, and test equipment are examples. Some parts and assemblies are fabricated or
tweaked under laboratory conditions. The completed Prototype Baseline contains these
abbreviated methods.

However, these cost saving abbreviations are not economic when production quantities
are required. So, the Prototype Documentation is examined for producibility and various
refinements are made through Change Control to assure that it will be producible. Pro-
ducibility has two elements of concern. (1) Can the item be produced in production
quantities and (2) can it be produced economically?

Some companies release these changes into the Prototype Baseline and then simply call it
the Product Baseline. While this method is slightly less expensive, it also destroys the
record of the Prototype Configuration that was demonstrated. During production, trouble
may require a comparison of the current production configuration with the configuration
that was demonstrated (the Prototype). Of course, that can’t be done without recon-
structing it; an added cost in time and money. Maintaining the Prototype Baseline is not
that expensive and it can avoid a good deal of effort later on.

Copying the Prototype Documentation and calling it the “intended” Product Baseline ac-
complishes this result; usually a simple automated process. Producibility changes are re-
leased into this intended baseline. When the upgrade is complete, the “intended” desig-
nation is removed. The fully released Product Baseline becomes available and the Proto-
type Baseline record remains intact.

Remember, Murphy’s Law is still alive and well. To deal with its mischief, it’s wise to
keep the Prototype Baseline record complete and accessible. There is nothing like know-
ing what worked when you need to do it again.

Phase 5. Build/Test Deliver Product

Pilot Lines
Once upon a time, production began with a Pilot Line, followed by Initial Production,
and then annual Follow-on Production Contracts that could continue for years.

• The purpose of a Pilot Line is to debug manufacturing methods. When these

methods are used for the first time, some elements don’t work. Tools and test
equipment fail. Processes are awkward. People are inexperienced. Product de-
sign is misinterpreted. So a limited number of production units are used to
flush out problems for correction. A high change rate is expected. (Pilot Line
Units are ultimately delivered and function as well as subsequent ones.)

56
Rev. 1 Appendix - Generic CM

• Initial Production proves that the Technical Data Package (Product Baseline
Documentation) is adequate to support follow-on production including com-
petitive or multi-source procurement if required. Initial Production yields the
first hardware produced with debugged manufacturing methods. A moderate
change rate is expected.

• Follow-on production provides more production units. The Technical Data

Package has been stabilized so a low change rate is expected. A full-fledged
competition for continuing production can be conducted. If a second source is
introduced, operating differences between contractors will cause the change
rate to rise and then stabilize.

However, competition suddenly became the source of all good things (according to Con-
gressional mythology). The Military was directed to reduce unit prices by getting to com-
petition faster. The objections of prime contractors were summarily dismissed as obvi-
ously self-serving. Something of a contest developed between program managers to see
who could get there fastest. Things changed!

The need to debug manufacturing methods (Pilot Line) or prove the Technical Data
Package (Initial Production) was deemed to be little more than prattle designed to ob-
scure the benefits of competition. So, a slogan, “Do it right the first time!”, replaced ex-
perience and the Pilot Line and Initial Production were combined. And –– since it is now
being done right the first time, we might as well conduct competitive biding for follow-
on production right away. Various combinations and permutations followed along with a
few problems.

The unproved Technical Data Package provoked all kinds of dirty pool complaints from
competing contractors because it was unstable. It really wasn’t pool but it certainly was
dirty. The Package kept changing while they were bidding and it continued to change af-
terwards. However, any experienced contractor should have expected it.

The second difficulty appeared when the change rate soared. Of course, the glow of early
competition faded. However, it was summarily decided that the change control system or
the people running it must be the culprits. The critics conducted the usual witch-hunt un-
til they wore themselves out.

We should note that second source and competition is not necessarily the same thing.
Second sources are added (by competition or otherwise) when the original contractor
cannot supply the volume of product units wanted. Competition is conducted to drive the
production unit price down. However, the impact of bug-filled manufacturing methods
and unstable Technical Data Packages will raise change rates in either case.

CM has no part in the decision that competition or a second source is necessary sooner,
later, or at all. At the higher levels of government, where charts and graphs are often the
basis for decisions, early competition looks good but there is a price to be paid.

57
Appendix - Generic CM Rev. 1

Compressed schedules, buggy manufacturing methods, unproven Technical Data Pack-

ages, competition, and second sources inevitably raise change rates, which cost money
and delay schedules!

Although “do it right the first time” is a laudable goal to be pursued vigorously, no expe-
rienced manager believes that it is a practical solution to real engineering or manufactur-
ing problems! Either take time to debug production methods and prove the Technical
Data Package or plan for a high change rate. Neither practice will please speeders.

Maintenance Manuals
Most often Maintenance Manuals are released and controlled by the organization that de-
veloped them. The reasons are the same as those given for the Demonstration plan – es-
sentially tradition, organizational power, and rivalry in both customer and contractor or-
ganizations. There is no CM reason to change the method of control. In fact, it is another
good example of CM being performed by the people doing the technical work. As long as
good performance is maintained the only reason to change this approach is to achieve a
centralized system, not always a desirable goal.

Phase 6. Deploy, Maintain, Repair

Significant experience accumulates in the field. Unfortunately it is too often ignored.
Most designers have little interest in design performance once the customer has accepted
it. After all, they are submerged in new assignments. Field personnel are soon discour-
aged by this attitude and communication simply dries up.

Many companies try to correct this situation by creating a group of liaison engineers to
deal with the field. Another approach is the assignment of designers to the field for a pe-
riod of time as part of their training. However, almost any approach is nearly impossible
to fund unless the customer issues a support contract. In the absence of funding it’s im-
possible to staff the operation.

CM can help this situation, at least a little bit, by keeping the Change Control System
easily accessible and responsive to field personnel.

***

58
Rev. 1 Appendix - Generic CM

6. CHAIN OF VERIFICATION

See Section 6 of the basic text.

***

59
Appendix - Generic CM Rev. 1

7. SOFTWARE
Modern Trial And Error
The Electronic Battlefield is a good example of an area in which Software is essential
although the requirements for it vacillate endlessly. This battlefield concept is new and
evolving rapidly. Need can change almost faster than it can be defined. It is an unstable
base from which to derive requirements. Situations like this have spawned a so-called
“new approach”. Why not send programmers into the field? Let them work with the
computer operator and develop the programming needed on the spot. Well, why not?

There is no good reason not to do so, if ----

• Requirements really cannot be stabilized,

• Need is genuine and compelling,

• Success is both possible and probable, and

• You can afford to finance the effort.

However, this is not a “new approach”! It’s a return to the venerable “educated trial, er-
ror, discovery, and invention” approach. Some of its advantages and limitations are noted
below.

• Enthusiasm or desperation for what might be tends to override the probability of

what will be.

• Realistic cost and schedule limits are unlikely. Arbitrary limits must be set and
will become culprits if the venture fails.

• The computer operator is unlikely to know his real interface limitations. The re-
sult is apt to be scads of function that can’t be used and loads of data that simply
confuse.

• Necessary changes to interfacing elements of the system must be made in the

field. On-the-spot changes are notoriously fickle.

• Documentation of the result will be slovenly to the point of uselessness unless

mayhem has been threatened repeatedly.

• Ultimately, a successful result must be integrated with the formal program for
future use. This is a significant added expense usually ignored until it has to be
paid.

60
Rev. 1 Appendix - Generic CM

• Necessary changes can be made, tested, and revised on the spot. This is a huge
advantage when time is really of the essence. But remember on-the-spot
changes are notoriously fickle.

There are conditions in this world that compel radical, risky action. When a sober analy-
sis of risk and probability shows that success is possible, perhaps probable, and appropri-
ate disaster safeguards are in place, variations of this approach can be used successfully.
However, it indicates an effort to push the state of the art, an effort more suitable for fea-
sibility than design development destined for production.

Software is by no means the only area with problems amenable to this approach. How-
ever, the use of the CM Discipline is not practical in these situations even though appro-
priate use of some CM elements will be helpful.

***

61
Appendix - Generic CM Rev. 1

8. GOVERNMENT CONTROL

Methods
Most contract changes are accomplished by mutual agreement of the parties. However,
the government, as Customer and a party, usually retains the right to direct unilateral
changes “for the convenience of the government” subject to “an equitable adjustment of
cost and schedule”. The Contractor has the right to appeal. The process is generally ac-
cepted as fair. However, such unilateral changes are relatively rare.

Customer Approval is a more common form of Customer Control. Normally, Customer

Approval of certain items is required before further work can proceed. Once approved,
the item is subject to Customer Change Control.

Those new to the scene often wonder why the Contractor can’t be given a contract and
left alone to design, produce, and deliver the product. From the Customer’s point of view
the history of this approach is too grim, the risk is too great, and penalty is too severe.

From the Contractor’s point of view Customer Approval may be appropriate but it can
present some serious difficulty. Generally, if a change meets requirements it should be
approved without comment. However, many reviewers try to improve the change; normal
behavior for most engineers. Thus, Change Control becomes a contest rather than a proc-
ess.

Both views are correct! But take note. The more the Customer fiddles the less stringent
the Contractor becomes. Disgruntled employees are inclined to “let the government do
it”. And, the more the Customer does it the more culpable he becomes. The best resolu-
tion for both parties is to limit Customer Approval and Control to minimum essentials
and make them as efficient as possible.

Duplicitous Contractors
The image of the nefarious, duplicitous, thieving contractor is greatly over done but it
persists for good reasons. First, there always are some. Second, the buying command, as
the agent of others, doesn’t want to be snookered.

However, no amount of “Customer Control” will eliminate the deliberate malefactor. In-
creasing the stringency of CM is also a near useless response. CM was designed to help
knowledgeable cooperative people perform a complex job. When it is used for gotcha
purposes it seldom gets anything but more expensive and less effective.

The best course is common sense before the fact and severe penalties afterwards. When
they claim that they will do a better job for half the money in half the time you are deal-
ing with genius or fraud. Find out which! When everything said is what you want to hear,
beware. Life seldom works that way. Be prudent! When you are conned in spite of pru-

62
Rev. 1 Appendix - Generic CM

dence, sock them with a penalty, a severe penalty. That action will do more for the in-
dustry, decent contractors, and good products than anything else.

With that said, take note: the deliberate malefactor is seldom the problem. Most of the
time it is customer and contractor untutored hypesters and imprudent risk takers. They
unwittingly lure the naïve and themselves into non-performable commitments. Such is
not their intent. It is their destiny. Do not make it yours!

Stringent Customer Control is not an antidote to this witches brew. The best defense is
prudence; a thorough understanding of the industrial process, practical skepticism, realis-
tic risk evaluation, and a healthy respect for Murphy’s Law.

Testing
Extensive testing or examination (inspection) is often seen as protection from duplicitous
contractors. Most of the time it is. But there are limits.

Testing is enormously expensive. It is impractical to test or examine every characteristic

of any product. So, the dependent characteristic approach is used. To check an electric
circuit in an ordinary residence, we turn on the light. We do not examine the power
source, wiring, switch, socket, and bulb unless the bulb doesn’t light. A lit bulb is the de-
pendent characteristic because it depends upon the other characteristics of the circuit. If
they are absent the bulb won’t light. Another cost saving approach is to test for the most
probable and serious failures. After all if a loose screw has no impact, there is little point
in testing for it. However, neither of these methods takes durability, longevity, corrosion,
etc. into account.

Almost everyone can understand these humble examples and think of dozens of others to
illustrate the dilemma. Actual performance over time is the only real proof of perform-
ance but it is not a practical testing method.

Product Baseline Customer Control

Given the foregoing problems, most military customers will take the belt and suspenders
approach. They will require an extensive test program plus control of the Product Base-
line.

The most common objection to the Baseline approach is cost. But the cost is trivial when
compared to the cost of a major failure. The root problem is time. Customer personnel
must approve hundreds of initial documents and thousands of subsequent changes. Usu-
ally the customer will locate an office in or near the contractor’s plant to facilitate the
process. However, local offices are limited in the type of change they can approve. Major
changes will be forwarded to the buying command for approval. If the project is a joint
procurement it’s possible to have two buying commands, two change boards, and all of
the confusion and contention one would expect.

In this situation, both the customer and the contractor will be urged to buy the latest
transmission and reproduction technologies to reduce time and cost. Obviously, Xerox is

63
Appendix - Generic CM Rev. 1

better than blue line and computers can be better than Xerox. However, the saving in time
and cost, in relation to the total, is miniscule. The time-eater is personnel. The solution is
enough really competent people to do the job. The Military seldom has the resources. The
result is delayed schedules, increased cost, and an indictment of Change Control.

Acquisition Reform
One of the proposed improvements is:

Stop imposing CM requirements by citing military standards. Instead, ask

the contractor how he applies CM. Evaluate his method against industry
standards and accept it if appropriate.

It sounds good but it contains the seeds of its own destruction. It assumes that “industry
standards” exist. They don’t! Therefore, the approach fails. Of course, there is an effort to
develop such standards. The Government Electronics and Information Technology Asso-
ciation (GEIA) has issued the “National Consensus Standard for Configuration Manage-
ment”, EIA-649-A, The concept needs further development and they intend to do it.
There is a good chance that this approach will be successful in the short term. Long-term
survival is dubious.

Industry writes and maintains only those standards that it finds necessary for its purposes.
Right now it finds that CM standards are necessary to get the government out of its hair.
Once that objective has been accomplished, it is likely that the standard will become ob-
solete because industry will no longer see it as necessary.

It is true that industry was the original developer of documentation, identification, verifi-
cation, release, and change control but not as elements of CM. It is true that each com-
pany developed its own standards for verification, release, and change control because
the company needed them. The companies did join to develop common standards for
documentation and identification because they needed them.

However, industry has not developed standards to “keep an evolving design aligned with
the need for it” (the essence of CM) because industry doesn’t need them. Industry’s obli-
gation is to fulfill the contracts it signs. It is the buyer’s responsibility to decide if the
contract product meets his need.

Over the years many have tried and all have failed to convince industry that it has more
than a marketing stake in the customer’s need. There would have been no CM at all if
government had not written the standard and imposed it with implacable intensity. I see
nothing in the future to mitigate these conditions.

***

64
Rev. 1 Appendix - Generic CM

9. CONTRACTS
CONTRACTING
Department of Defense instructions require the Military to apply CM under various cir-
cumstances. However, nothing but a contract requires any contractor to comply with
those instructions. Once upon a time, Procurement Commands handled the problem by
contractually imposing a top CM military instruction that, in turn, invoked almost every-
thing ever written on the subject and had nothing to do with the program as such.

Things have improved though they are still difficult. There are many ways to call for the
use of CM in a contract including Addenda, Supplements, Attachments, and Annexes.
The following four are the most common.

• Technical Data Requirements

• A CM Plan

• A Special Provision; a section of customized text.

• Insertion into text on some other subject.

Technical Data Requirements

Many of the CM Requirements, both explicit and implicit, are contained in Technical
Data Requirements for specifications, engineering drawings, and other documents. CM
and TDM are tied very closely together. However, they are not the same thing. Therefore,
it’s wise to pay close attention to the Technical Data Requirements when determining the
CM imposed by contract.

CM Plans
A CM Plan is usually called for as a Technical Data Requirement. The Plan is supposed
to detail the CM to be applied during the contract. The prime contractor and each sub-
contractor submit CM Plans as part of their proposals. Unfortunately, many CM Plans
tend to be sales documents; compendiums of commonly accepted CM hype. They are
often written and reviewed by the equivalent of interns. If the boilerplate and buzz are
right, the plan is approved and made a part of the contract. Thereafter, it usually gathers
dust unless a dispute develops.

Some people believe that vague and indefinite language will help them prevail in a dis-
pute. However, “the government” will prevail unless the Contractor’s negotiators are ex-
ceptional! That lightly considered boilerplate and buzz could turn out to have sharp teeth.

To avoid this unhappy result, the CM Plan should be a realistic statement of requirements
that fit the product, program, contract, and customer. Do not overstate them in the sales
mode and expect to avoid them later.

65
Appendix - Generic CM Rev. 1

Special Provision
A Special Provision is simply one or more contract paragraphs setting forth requirements
that are usually out of the ordinary. For instance, a complicated test requirement might be
spelled out in a Special Provision. In a similar fashion, CM Requirement additions, ex-
tensions, modifications, or exceptions can appear in Special Provisions.

Insertion
One might be reading about prototypes and see “… which shall be made part of the Prod-
uct Baseline.” If it makes sense, so be it. If it doesn’t, get it fixed as early as possible in
the contracting cycle.

The Contracting Cycle

The contracting cycle consists of the Customer’s Request for Proposal; the Contractor’s
response (a work statement, cost estimate, and schedule); negotiation; a Contract docu-
ment; Contract interpretation or modification; and Contract closeout.

If competition is intended the Customer’s Request will go to several Contractors. The

Customer will award a contract to one or more Contractors based on their proposals
rather than negotiation. It is also possible for a Contractor to begin the cycle by offering
an unsolicited proposal for which there was no Customer Request. In most cases a con-
tracting cycle between the Contractor and his Subcontractors parallels the cycle between
Customer and Prime Contractor.

CM Requirements first appear in the Customer’s Request for Proposal. The Contractor’s
response may accept them “as is” or include a counterproposal. Differences should be
resolved and a better understanding achieved during negotiations. The results of negotia-
tions are documented in the Contract Document.

Understandably, CM Requirements are not the primary objective of the Customer or the
Contractor. Unfortunately, CM is often left to the last minute and then jammed into place
by exhausted participants. Obviously, this is bad practice and often produces mangled
requirements best suited for the trashcan. When this practice cannot be avoided, under-
take clarification as soon as practical! Many will object but it is better to deal with it early
and avoid the almost impossible snarls that are certain to develop later in the program.
Clarification can be accomplished through Contract modification or interpretation.

A modification is a rewrite of parts of the existing contract, an addition to it, or deletion

from it. Normally, customer personnel resist modification because it opens the contract to
cost (usually higher) and schedule (usually longer) adjustments. Assessing the risk is a
matter of judgment. There is no formula. Unfortunately, most CM problems are usually
regarded as low risk until the Contractor or the Customer is in deep trouble. It’s wise to
avoid this consequence.

An interpretation is easier to accomplish. A simple letter agreement can state that para-
graphs x through z really mean the following. However, any such agreement must with-
stand scrutiny if a dispute develops during contract performance or closeout. To survive,

66
Rev. 1 Appendix - Generic CM

it must be a reasonable interpretation that does not strain credulity. To avoid disallow-
ance by the Contracting Officer, make him a party to the letter agreement.

Contract Kinds
The CM Discipline has been presented as a smooth-flowing, uninterrupted continuum
covering the life cycle of the product and that is the way it should operate. However, if
care is not taken to preserve that continuum, disconnects will develop as the program
moves from one kind of contract to another.

A program can be covered by a single all-in-one contract but this method appears to have
been unsatisfactory for both Customers and Contractors. Many kinds of contracts are
available but the following ones are most often used. Purchase Orders usually apply to
Vendors. The others are used between Customers and Contractors and between Contrac-
tors and Subcontractors.

Feasibility Contract. Covers all kinds of efforts too immature for use in full-scale
development and production programs. The CM Discipline should not be imposed
but tailored elements of CM may be helpful.

Development Contract. Usually covers design, prototype manufacture, and test.

The CM Discipline applies. In a competitive effort, a separate Development Con-
tract for each winning Contractor will be awarded.

Production Contract. Usually covers the manufacture of hardware designed under

a Development Contract. Operating and Maintenance Methods and the Mainte-
nance Document Package are often made a requirement of the Production Con-
tract. The CM Discipline applies. Over time, there may be many Production Con-
tracts, one per year for instance. In a competitive effort, a separate Production
Contract for each winning Contractor will be awarded.

Support Contract. Covers all sorts of ancillary tasks such as maintenance, retrofit,
field service, spare parts, etc. The CM Discipline may apply. The number of Sup-
port Contracts depends upon the practices of the Procuring Command and the
kind of product supported.

Purchase Order. Covers the procurement of ready-made (off-the-shelf) parts or

materials from Vendors. The CM Discipline applies but in a reversed sort of way.
In simple terms, Vendors have already defined and identified the characteristics of
their own products in their own documentation. New design is not involved. Con-
tractors use the Vendor’s documentation or a Specification Control Drawing to
order items from the Vendor. Contractors may impose additional examinations or
tests to Confirm Compliance.

Chain of Reference
Documents call for (invoke, reference) the use of other documents in whole or part. To
the extent that they are referenced, such ‘other documents’ are just as binding as if they

67
Appendix - Generic CM Rev. 1

had been incorporated, word for word, into the referencing document. Drawings refer-
ence parts lists, which reference specifications and other drawings, which reference stan-
dards, which may reference other standards, which in turn may reference … etc. This
condition is called a “chain of reference” and may extend through 16 or more levels of
referencing.

This method of referencing is used because it eliminates the need to repeat the same text
(describing for instance a common method such as welding) in document after document.
Instead, the common method is simply referenced. There are many cost and management
advantages.

However, sloppy referencing can produce serious conflicts. It is not uncommon for a
lower tier of reference to invoke a document that is a useless, even damaging, application
for the product being developed. Knowledgeable, intelligent interpretation is the best (but
seldom used) solution. More often harried functionaries pursue their own agendas and
each other.

Referencing a document without knowing the applicability of its chain of reference (rote
referencing) should be stopped but that is unlikely. However, a special contract provision
can be helpful. It can limit applicability of a document’s chain of reference to the first
two or three tiers unless that document was specifically prepared for the product being
developed. Regrettably, this is an expedient that won’t help future users because they
won’t have the same contract. The elimination of rote referencing coupled with knowl-
edgeable interpretation is still the best solution.

It is always possible to give a document a new identity by attaching a cover sheet that
specifies which parts of that document are to be applied. This Technical Data Manage-
ment technique can change the Chain of Reference to eliminate inappropriate lower tier
references while retaining the applicable information without an expensive rewrite.
***

68
Rev. 1 Appendix - Generic CM

10. CM ORGANIZATION
The Primary Actors
The primary actors are:

• The Customer as Buyer from the Contractor.

• The Contractor as Seller to the customer, and
As buyer from Subcontractors and Vendors.
• Subcontractors as Sellers to the Contractor, and
As buyers from Vendors.
• Vendors as Sellers to Contractors and Subcontractors.
The term “supplier” can apply to any seller.

Customer
The Customer’s role is to specify when and what he needs, to negotiate an agreement
with a company capable of supplying it, to assure that the product delivered is the product
that was ordered, and to pay for it.

Technically, the military Customer is “the government”. Its agent is a Contracting Offi-
cer, the only person who can legally commit the government to an agreement.

Practically, the military Customer is an Armed Service Procurement Command consist-

ing of a Commanding Officer and staff including Program Managers and technical spe-
cialists. The procuring command is almost never the using command. The relationship
between these military commands is significant although it is seldom readily visible to
the seller.

Although a military officer is in charge, other personnel may be military or civilian.

Typically, the Program Manager is the primary spokesman for the Customer. However,
technical specialists usually handle the details of the program. All personnel are “guided”
by extensive and cumbersome regulations imposed by the Congress, the Administration,
the Department of Defense, or one of the armed services.

Non-military customers may be commercial companies, non-profit organizations, or

other government agencies. Their duties are the same but their organizations are more
like those of a contractor.

69
Appendix - Generic CM Rev. 1

Contractor
The Contractor’s role is to supply the product ordered and collect a reasonable price for
it.

Typically, the Contractor is a company. Its agent is one or more officers of the company
supported by a contracting staff. The agent is usually the only person who can legally
commit the company to an agreement but a corporate staff of some size almost always
oversees his actions.

Practically, the Contractor takes the form of a Program Manager, technical staff, and liai-
son with many other functions scattered throughout the company. The Program Manager
is usually the primary spokesman for the Contractor. However, his technical specialists
usually handle the details of the program. All personnel are “guided” by practices im-
posed by the company’s hierarchy.

“Prime Contractor” is the term most often used to identify the Contractor who deals di-
rectly with the Customer.

Subcontractor
The Subcontractor’s role is to supply the Prime Contractor with custom designed compo-
nents such as rocket motors, aircraft engines, generators, radar units, etc. He may be a
designer, manufacturer, or both.

Typically, a Subcontractor is organized and operates like any other contractor. However,
his products are for use in a Prime Contractor’s product.

Vendor
The Vendor’s role is to supply Sub or Prime Contractors with ready-made (off-the-shelf)
parts or materials such as nuts, bolts, screws, solder, electronic parts, raw materials, adhe-
sives, lubricants, etc. He is usually a manufacturer or broker.

Typically, a Vendor is organized and operates like any other contractor. However, he
makes or distributes standardized ready-made parts or materials for wide markets, both
military and commercial. Generally, he does not customize anything for a special use.
__________________________________________________

Customer and Contractor specialists, interacting with one another, make most of the de-
tail program decisions. The same is true of Contractors and Subcontractors. These people
develop necessary, reliable, personal, business relationships that lead to agreements be-
tween organizations.

In daily practice, the primary actors can appear to be individual people but they are not!
The primary actors are organizations represented by people who may or not remain in
place. Transfers, promotions, resignations, death, etc. can destroy the most carefully de-
veloped unwritten agreement at the most inopportune time. Consequently, the only reli-
able way to maintain agreements between organizations is by written contract.

70
Rev. 1 Appendix - Generic CM

The representatives of each organization are responsible for maintaining a clear contract
record for their successors. When enthusiasm obscures that responsibility, the contract
becomes uncertain and the organizations are subject to arbitrary or capricious interpreta-
tions by uninformed successors. CM is unusually vulnerable to this unfortunate conse-
quence.

***

71
Appendix - Generic CM Rev. 1

11. IS IT REALLY NECESSARY?

If anyone has done a real cost-effectiveness (or similar) study of CM, I have not seen it. I
suspect that the complexity and cost of doing such a study would discourage any but the
most determined and naïve MBA candidate.

Even so, I remain convinced after all these years that CM, properly applied, and in spite
of its many annoyances and confusions, does save money. However, my proof is anec-
dotal and the savings are almost impossible to isolate because they occur in such diffuse
areas as design time or procurement and manufacturing error reduction. So the cost-
effectiveness debate will likely continue inconclusively.

***

72
Rev. 1 Appendix - Generic CM

12. A TALE OF TWO PROGRAMS

This story is true - as far as I know it. The actual happenings were so many and so com-
plicated, strewn across a wide swath through time, that it is doubtful that anyone knows
“the whole truth”. Still, it’s useful to us because it contains real life examples of errors
and their consequences, as part of actual happenings.

Our tale begins with the Applied Physics Lab (APL) at Johns Hopkins University. They
had come up with a promising concept for a sea-to-air missile that would foil future Ka-
mikaze-like attacks, the Japanese suicide missions of WW II. The Navy built a Naval Re-
serve Industrial Plant at Pomona, California to develop the idea and engaged the Consoli-
dated Vultee Aircraft Corporation (Convair) to operate it. The result was the Pomona Di-
vision, first of Convair and then of General Dynamics when it acquired Convair.

12A. The Standard Missile (SM) Program

Terrier and Tartar were among the early manifestations of the APL concept. Several ver-
sions of those missiles followed during the late 1950’s. In the early 60’s a standardization
effort gave birth to the notion of a Standard Missile. Of course, the Pomona Division
wanted that business.

Meanwhile other developments were converging on this project. The consequences will
be easier to understand if Figure 13 is consulted as we go along. The upper panel displays
a relatively common program plan in use at the time. The lower panel displays the con-
troversial plan for Standard Missile (SM). I can no longer vouch for the exactness of the
numbers but they are accurate enough to illustrate events.

The Problems

Compression
Every so often the Congress rediscovers competition and behaves like it’s a cure for all
the ills that beset the Nation. This was one of those times. Defense Industry scandals
were abnormally prevalent and severe. The Congress was plaguing the Military, which
was doing everything possible to placate it. Thus, the heat was on to reach competition as
soon as possible.

The SM Plan got to competition 1.5 years faster than the old plan. This feat was accom-
plished by shortening Development to 18 months and omitting the 12-month Pilot Line
altogether. Never mind that there were half again as many prototypes to be manufactured
in 75% of the time normally allowed. “Just eliminate the waste and you’ll be fine”.

Nominally, it took 36 months to reach bug-free, economic, volume production. Regard-

less of what the bits and pieces were called the amount of work was the same. But a dif-
ferent idea had taken hold. The contractors’ recommendation for a Pilot Line was seen as
a ruse to delay competition for as long as possible. So the SM Plan eliminated it.

73
Appendix - Generic CM Rev. 1

Customer Change
Control Starts Competition, if any.

Development Non
Pilot Initial Follow-on &
Competitive
10 Prototypes Line Prod. Prod. On
Drawing
5.0 Years Annual Package

3.5 Year s Annual

Development Initial Follow-on &

15 Prototypes Prod. Prod. On

Customer Competitive Competition

Change Drawing
Control Package
Starts $500,000

Fig. 13 Traditional vs. Standard Missile

Change Control
Normally, Customer Change Control was imposed at the end of development. The SM
Plan imposed it during the last third of Development, specifically on the last half of the
Prototypes. This scheme was curious for it was a much-debated compromise without
clear intent. The first 8 prototypes, as I recall, were left under contractor Change Control.
The last 7 were under customer Change Control. Most likely the intent was to bolster the
effort to reach early competition by limiting changes. This mistaken notion prevails in
spite of experience.

The signification of this action to the SM Program was a built-in conflict between Cus-
tomer Change Control, which takes time, and a schedule already compressed beyond rea-
son.

Competition
For a time there was a debate about competing the Development Phase of the program.
Fortunately the Navy found that it didn’t have the money to fully fund two major con-
tractors during Development. The next effort was to introduce competition at the end of
Development.

This approach was resisted on the grounds that a fully proven data package was necessary
for competition and a competitive package was impossible without production experi-
ence. So it was finally agreed that it wouldn’t be imposed until the end of Initial Produc-
tion.

74
Rev. 1 Appendix - Generic CM

Competitive Data Package

However, a full-fledged competition takes about 12 months. That means that the data
package must be available at the end of Development. A $500,000 bonus was the incen-
tive to produce the package on time.

Basically, a competitive data package is a set of drawings and other documents that can
be used by any competent manufacturer to produce the item depicted. However, it is
practically impossible to know that a package is suitable for competition until it has been
used to produce the item depicted in significant quantities.

Technical Data Management

The concept of a Form (DD-1423) defining all of the data that had to be produced under a
contract was introduced for the first time. While there had been much debate no one had
elected to put the policy into practice prior to this time.

Fixed-Price
The fixed price concept was applied to this program. It means that for a stated number of
dollars (covering all costs and profit) the contractor will perform all of the work listed.
This was a revolutionary idea for Development Contracts that had been cost-plus in the
past.

Change
The Pomona Division of General Dynamics was a large organization. So was the U.S.
Navy. It takes large organizations a lot of time to change. This is not a question of resis-
tance although that counts. It is far more about people perceiving – correctly – what’s
wanted, figuring out how to do it, and cooperating with each other to get it done. That
takes time! The sheer number of major changes listed above was more than enough to
guarantee failure when a compressed schedule was one of them!
____________________

Why would an experienced contractor agree to a program that requires early Change
Control, early competition, and a new approach to Technical Data inside of a compressed
schedule for a fixed-price? And, for that matter, why would any seasoned Customer want
to deal with a Contractor who would agree to such a thing?

The Navy’s motive was fairly clear and they made no secret of it. They had to placate the
Congress. The planners simply over reached by gathering the new ideas under considera-
tion and, ready or not, slapping them on this program. Wisdom played no role.

Hubris played a major role in the Pomona Division’s decision; “We can do anything!”, so
to speak. However, there was another far more significant reason. Without the Ter-
rier/Tartar program there would be no Pomona Division. Terrier/Tartar was certain to end
when the Standard Missile went on line. More bluntly, the Division had to go where the
money was and the Navy had it. The Navy had to go where the skill was and the Pomona
Division had it.

75
Appendix - Generic CM Rev. 1

But there was one more thing that had a heavy influence on both parties. The idea that
“they don’t really mean it” had been around for several years and experience indicated
that it was true. Many excessive contract provisions were simply window dressing, ig-
nored once the contract was signed. There was nothing but prudence and great unrest in
the defense industry to indicate that it would change.
_____________________

Negotiation
The die was cast when the Division elected to bid on the SM Development Contract. The
negotiation was bumpy but made progress until the very end. It broke down over two
points. The Contractor wanted $5 Million more and the Navy claimed not to have it. The
Navy wanted data in accord with a DD-1423 that the Contractor couldn’t fathom.

Time was short so the Division put together a special team to seek resolution. The Con-
tract Manager, the Program Planner, the Chief Estimator, and I were directed to go to
Washington and get it settled. My responsibility was the DD-1423 since I seemed to be
the only person in the Division who understood it.

It had been priced at $1.2 Million provided that the Navy dropped its demand for Tooling
and Test Equipment drawings and Manufacturing Planning. The Navy negotiators were
convinced that these items contained the secrets of successful manufacturing. The price
for them was huge because of the sheer volume of such data.

This issue was in an unseemly snarl because a number of Navy people were convinced
that we were suppressing this data to gain an advantage. This belief was embedded even
though their own procurement regulations counseled against the procurement of such
data. The Navy had found it to be useless in the past. Ultimately, I must have been con-
vincing enough because the requirement finally disappeared from the DD-1423.

I was not so persuasive with the $500,000 bonus for timely delivery of a competitive data
package. I was not surprised because I had been the only voice, Navy or Contractor, in
opposition to this item. I took that position because there was no mutually agreeable ac-
ceptance inspection method for something so nebulous. I foresaw a major conflict when
the Navy refused the package as inadequate while the Contractor insisted that it was.

We had struggled in Washington for 10 days when our Corporate Office told us to go
home. They had settled. No one ever did fess up but it was rumored that the Corporate
CEO and the Admiral in charge of procurement met and agreed to split the $5 Million
difference 50-50. The final figures supported that view.

Development
We had entered into a fixed-price contract for $2.5 Million less than our bid and it wasn’t
padded! Internally, that difference had to be absorbed and much of it came out of the
funding for the DD-1423.

76
Rev. 1 Appendix - Generic CM

Development proceeded remarkably well until we reached the point of applying Cus-
tomer Change Control to the last of the Prototypes. A frustrated company accused the
Navy of dragging its feet so that we would miss the due date for the procurement package
and the $500,000 bonus that went with it. Of course, the Navy disagreed. The truth was
not in foot dragging. It was in the time it takes to process changes but the atmosphere had
been poisoned.

Those involved with Documentation had pretty good proof that we could not meet the
date for a competitive data package. It was suggested that the company announce that
fact and give up the bonus. Upper management went ballistic! We were told to make that
date or get out.

The Manager of Documentation was replaced with a company hatchet man. He started by
rearranging the supervisory structure and moving the physical location of the group. Then
he let it be known that we would make the date and earn the bonus or else. Generally he
was merciless on the working level personnel.

It wasn’t long before everyone got the message and began presenting drawings to the
Navy for review and acceptance. The Navy personnel had never conducted such a review
and had little idea of how to do it. But do it they did and ownership of the drawings
passed to them, something they had coveted from the beginning but would live to regret.
Ultimately we met the delivery date, earned the bonus and the SM passed its demonstra-
tion tests with flying colors. Management was thrilled as we had proved that “We could
do anything!” But had we? Several million dollars of overrun was hardly offset by the
$500,000 bonus.

Initial Production
Initial Production did not proceed as easily as development had. The Navy had officially
delivered copies of its Competitive Data Package to us and to the company that would
bid against us. Our factory was getting tooling and testing stabilized along with all the
other things usually done during a Pilot Line. But an unusual volume of changes to the
data package kept the effort in flux. These were changes that were skipped during Devel-
opment in order to make the delivery date and earn the bonus.

They were also disrupting the competitor’s effort to put his bid together. It wasn’t long
before he complained that a constantly changing data package was not suitable for com-
petition. Of course, the Navy insisted that it was and the wrangling went on for some time
before the Navy came up with a solution.

We would simply freeze the data package for bidding purposes. That way both contrac-
tors would be bidding on a stable package. Meanwhile, the Pomona Division would con-
tinue with the Initial Production program. That meant that there were two data packages
in play, never a good idea, one for Initial Production and the other for bidding purposes.

As the high change rate continued the two packages diverged. The Navy accused us of
having hoodwinked them into accepting an inadequate Competitive Data Package. Our

77
Appendix - Generic CM Rev. 1

answer was that, in spite of our protests, “You reviewed it and you approved it as ade-
quate. You wanted to own it and now you do. It’s your package that’s causing trouble.”
Thus it was that we wrangled our way to the end of Initial Production.

The SM was produced and it worked. The competition was conducted. The Navy split the
first year’s follow-on production awarding one-half to the Pomona Division and the other
half to the competitor and the troubles began again.

Follow-On Production
The Navy had to increase the money award to cover integration of the changes made
during Initial Production but not incorporated into the frozen Competitive Data Package.
The competitor had to absorb all of those changes before he could start Follow-On Pro-
duction, a very awkward situation.

Following this contract, Follow-on Production contracts were awarded on a competitive

basis year after year. The total number of missiles was split in various quantities between
the Pomona Division and its competitor. As far as I know that practice continued until
General Dynamics sold its interests and closed the plant. The missile did work and be-
came the primary anti-aircraft defense for the fleets of most countries in what was then
known as the free world. However, there are two more bits to this tale before we close.

The Claim
At the end of Initial Production the company filed a claim against the Navy to recover its
costs for correcting “the Navy’s inadequate Data Package”. The General Manager of the
Pomona Division retired unexpectedly and without explanation.

The claim provoked a gasp heard throughout the plant and all the way to Washington and
back. After all, we had produced the package. It was undeniably inadequate. We had
some responsibility. However, we had protested and argued for the time to do it right.
The Navy had denied our plea. It was convinced that we were resisting competition by
deliberately delaying. (Yes, we resisted competition quite openly but not by delay.)

We were told to present the drawings so that Navy personnel could decide whether they
were competitive or not. We warned that neither our people nor theirs could make that
determination accurately. When we were told to do it anyway we elected to earn the bo-
nus and let the Devil take the hindmost and he did.

The claim went forward. It was based on the fact that the Navy’s Data Package, furnished
to us for Initial Production, was inadequate. The Navy had admitted that fact (1) by tak-
ing “ownership” of the package at the end of Development and (2) by approving all of the
changes that had been made in order to correct it. We were entitled to reimbursement for
the costs of those changes. The claim was quite large for its time – rumored to be some-
where between $20 and $40 Million. The exact figures were withheld from most of us.
The company recovered most of what it claimed.

78
Rev. 1 Appendix - Generic CM

Thus, the feeling of mutual betrayal that had infected both parties was set in concrete. It
was never resolved and the Pomona Division’s reputation never fully recovered.

Fixing Change Control

Some months after the claim had been settled I was summoned by the Vice President and
General Counsel, sworn to secrecy, and told that the Corporate Office would not let the
Division accept the next SM Production Contract unless and until Change Control was
fixed. The question was what should we do? I assured him that Change Control was not
out of control. It was not the cause of the SM change rate problem. He made clear to me
that, true or not, such an answer was unacceptable to the corporate office and would re-
sult in no contract! Something more had to be done! I was given the task of figuring out
what to do and getting it done promptly.

The corrective action that should have been taken was the adjustment of contract provi-
sions to accommodate a compressed schedule, or rejection of the contract, or knowledge-
able acceptance of the consequences. It would also have been wise to tone down the no-
tion that ”we can do anything” because we couldn’t. But it was quite clear that we would
get nowhere with that kind of an answer. There were several things about our approach to
Change Control that could be improved so I set about getting that done.

We were a multi-program Division. Each program had developed its own approach to
Change Control. The differences often caused confusion and delay in change processing
so we made the system uniform division-wide. The only differences retained were those
required by the various customers, Army, Navy, etc., and they were few.

The other major modification was the elimination of a formal Change Board. The logic
was that most of the time the members of the Board had to consult with the departments
they represented before they could act. So we decided to forward changes directly to
those departments for action without the middlemen.

Engineering and program personnel went berserk more over rumor than fact. Several
Vice Presidents met with them and read the riot act so to speak. Accept the modifications
or do without a contract. Most accepted it but many continued a subversive resistance
that caused constant local criticism. Management had an article published in the corpo-
rate-wide newspaper advising the world of the wonderful improvements that we had
made in Change Control. I resisted publishing this stuff because what we had done was
not that great. Hubris won the day. The Corporate Office lifted its restrictions and I got to
host delegations from our other Divisions. They wanted to know what was so great about
Pomona’s Change Control.

And, the beat went on. Several Program Managers authorized individuals to examine the
Change System independently and thoroughly and prove that it wasn’t working. Gener-
ally, these individuals were quite competent and I instructed all personnel to cooperate
with them in every way. They all reported that there was no correctable problem with
Change Control. However the carping continued. The primary complaint became span

79
Appendix - Generic CM Rev. 1

time. It took too long to process a change. Allegedly, the lack of a Change Board was at
fault.

So, I took advantage of a situation to establish a Change Board for a particular Army
Program. I chaired that Board personally. An influential Design Manager was assigned to
the Board to oversee the engineers. Generally, the other departments assigned top-notch
people to represent them. A room was dedicated and several phones were installed for
rapid communication. This Board met everyday from 1:00 P. M. until every open change
for that program had been reviewed. Any delay by any department was pounced upon
and pursued. At the end of ninety days we had improved the span time for the average
change by about 1.5 days, a little less than 4%.

No company or agency can afford to devote that amount and quality of effort to its
Change Board routinely for a 4% improvement in span time. The volume and quality of
change reflects the operation of the entire organization. If big money is to be spent on it,
a greater gain will be realized by improving performance in each part of the organization.
Too much pressure on reducing change span time acts exactly like a compressed sched-
ule. Any number of ills develop not the least of which is personnel burnout.

This became obvious when most members of management were incentivized to fix the
Change Control Problem. Each one had a high old time fixing the problem at the expense
of everyone else. And, then there was the period when the Chief Engineer decided to re-
view each change before it entered the Change System. He intended to fix the problem by
keeping unnecessary changes out of the system. It took him six weeks to discover that the
vast majority of changes are necessary. He gave up.

So it was that we arrived in the 1990’s still wrangling over a change problem that had
started in the 1960’s. There were several other convulsive efforts to fix things including
the transfer of Change Control to another Branch of the Engineering Department where it
remained for a couple of years (without significant modification) before being returned to
its former home. Shortly after that it became evident that the Division would close so the
critics had more significant things to worry about.

12B. The Standard ARM Program (Anti-Radiation Missile)

In the mid 1960’s the Vietnamese were destroying our aircraft and pilots at a catastrophic
rate. They had gained the ability to have a missile ride up our radar beam to destroy our
aircraft with uncanny accuracy.

The Navy teamed with the Air Force to develop a counter-measure. They came to the
Pomona Division with a proposal. They wanted us to modify the Standard Missile so that
it could ride down the Vietnamese radar beam and destroy their ground station and its
missiles before they could be launched. Essentially this action would convert a sea-to-air
missile into an air-to-ground missile. We agreed.

80
Rev. 1 Appendix - Generic CM

The Navy and Air Force set up a joint Program Office. We agreed to bend every con-
straint as far as we could to get this weapon into the field at the earliest possible date and
they agreed to help. Cost was not to be a constraint.

By this time CM had come into being and was being pressed by all customers on all pro-
grams. Our tailored approach for this program is displayed in Figure 14.

System Demonstration Plan,

Spec. Procedures, & Test
Customer
Acceptance Tests
Control
Development Produce

Prototypes Deploy
Deployment
11
Mons.

Contractor
Change Non-Competitive
Control
Control Drawing Package
Starts

Fig. 14 CM on Standard ARM

Of course it was not as neat as the diagram implies. But it’s accurate enough to illustrate
the approach.

The System Specification defined the performance required. The Demonstration Plan,
Procedures, and Tests proved that the required performance had been achieved in the
hardware. (These tests were completed in the actual theater of war.) Some of these tests
evolved into simpler Acceptance Tests for follow-on missiles. All of these items were
placed under Customer Change Control, which gave it the control of performance that it
needed. The Contractor was obligated to comply.

Contractor Change Control started with Prototypes destined for the field and continued
with the following missiles. The drawing package was to be no more than what was nec-
essary to allow us to produce the hardware in the labs and the Experimental Factory. This
approach gave us the flexibility that we needed to meet the “as soon as possible” sched-
ule. The Customer was obligated to comply.

While Technical Reviews were conducted almost monthly their purpose was perfection
of the design rather than compliance assurance. We believed that the risk of drift was low
because Development was short, the objective was clear, and scrutiny was constant and
intense. However, the door to cost increase was open because cost was not a constraint.
Higher cost often makes up for lack of time.

81
Appendix - Generic CM Rev. 1

The missile was wildly successful. From program initiation to first working hardware
took eleven months, an almost unheard of accomplishment. It was very costly but it saved
lives and won battles. Basically, the Vietnamese gave up this fight by shutting off their
ground radar to prevent its total destruction. The slaughter of our pilots stopped.

No Good Deed …
The Navy decided that it wanted more missiles but at a substantially lower unit cost.
They established a new Program Office that became intent on lowering the cost by intro-
ducing competition. The outrage was palpable when they realized that the Standard ARM
Drawing Package was not suitable for competition. Worse, it was not even suitable for
production in our own Production Factory. We were still producing units for the field in
our Experimental Factory supported by our Labs.

We were flabbergasted because the quality of the drawing package had been carefully
defined to avoid this specific complaint. We explained that we would need at least a
Mini-Development Program to make the drawings suitable for quantity production. Pilot
Line and Initial Production would be necessary to assure that the package was suitable for
competition. The more that we explained the madder they got.

It became evident that the two Navy Program Offices were not speaking and nothing we
could do would get the Production Program people to talk to the Development people.
So, we remained the unscrupulous scoundrels that had hoodwinked the Navy into ac-
cepting a defective data package. There is little doubt that the quarrels about the Standard
Missile were heavily influencing Navy thinking on Standard ARM. They took excep-
tional steps to see that the Navy was not “fooled again” which did nothing but delay the
effort.

A Mini-Development contract was awarded and the drawing package was improved for
production and eventual competition. Once again time for Pilot Line and Initial Produc-
tion was not available but the program continued until later designs by other companies
replaced the Standard ARM completely.

12C. Lessons
This Tale is well worth reviewing more than once. It contains many subtle lessons not so
much about CM as about the impact of program planning and management. It’s tempting
to call them “lessons learned” but it’s more likely that they were merely lessons endured.
Perhaps the best description is “lessons to be learned”. Some of them are highlighted be-
low.

Compression
It’s true that things can become so sloppy over time that they need to be wrung out every
now and then. In these circumstances compressed schedules become popular. They can
be useful but they are always dangerous and often produce unintended consequences. The
compressed schedule for SM Development did not allow enough time to complete the
producibility effort, abandoned a Pilot Line, and distorted Initial Production. Design de-

82
Rev. 1 Appendix - Generic CM

velopment had to be completed during Initial Production under Change Control. All of
this made preparation of a Competitive Data Package in the time allowed impossible.

The compressed schedule created a pent up demand for changes that was not satisfied
during Development or Initial Production. It fed upon itself until it became a long-term
plague, cost an enormous sum unnecessarily, and damaged the reputations of everyone
associated with it.

Competitive Data Package

We need a series of seminars on Competitive Data Packages. It was originally thought
that “suitable for manufacturing by any competent manufacturer” was an adequate defi-
nition. In theory, it was accomplished by:

• Strict adherence to Military Specifications,

• The elimination of proprietary restrictions, and

• The removal of manufacturing methods (“how-to” data) from the package.

Military Specifications put everything in a common language understood by most estab-

lished manufacturers. The elimination of proprietary restrictions removed legal con-
straints. The removal of manufacturing methods gave the competitor freedom to apply his
methods, which is necessary and does reduce cost. These efforts would have allowed any
competent manufacturer to produce the item but not in a smooth operation within a
month or two after start-up. Yet smooth operation is what the military customer de-
manded.

This viewpoint is wholly unrealistic even between two identical plants operated by the
same company; even between an Engineering Department and a Manufacturing Depart-
ment operated by the same company at the same location. No matter how much effort has
gone into making documentation clear, precise, and accurate some mechanic (or engi-
neer) will point to something and ask, “What do you think they meant by that?”

By direction, methods are not included. There are always elements, sometimes called
“know-how”, that cannot be documented adequately. One contractor’s methods will not
necessarily work in another contractor’s plant! They have to be developed through prac-
tice. As a minimum the new Contractor needs a real Pilot Line during which he learns to
accommodate the design in his plant.

The ability to increase production by quick start-up of another plant has been a pie-in-the-
sky dream of military procurement for years. It was tried through the creation of identical
plants during WWII. It fails because the people in the two plants cannot be made identi-
cal!

83
Appendix - Generic CM Rev. 1

Bonus
Bonuses are useful incentives particularly when they are awarded after the fact for out-
standing work accomplished. They are more complicated when they are promised in ad-
vance for future performance unless that performance is defined objectively. They are
plain dangerous when the work to be rewarded cannot be measured objectively.

A Competitive Data Package is all but impossible to measure objectively. After one or
two years of smooth production the package is probably competitive. After a year or two
of smooth production by the second contractor the package is competitive. To expect
more is to believe in fairy dust.

The bonus for the SM Data Package distorted the program. The Contractor focused on
getting the money. The Navy focused on timely delivery. Unfortunately, no one focused
on the content of the package.

Fixing Change Control

It is impossible to fix Change Control when the elements to be fixed are intrinsic to it.
Volume will always be too high and span time will always be too long. Sometimes they
can be improved through administrative adjustments but it will seldom gain more than
10% if that. More often efforts to fix intrinsic problems complicate the process, increase
the cost, extend the time, and fail! Using the Change Control System to control volume is
akin to tying-down the safety valve on a steam boiler. Sooner or later it blows up!

Volume, span time, and most other elements are driven by the operation of the plant and
the conduct of the program. By the time they are evident as problems it’s too late to cor-
rect them for the impacted program. If volume and span time are nominal, leave them
alone! They are a normal part of any program. If they are excessive, look for the cause in
(1) the conduct of the program, (2) the operation of the plant, and lastly (3) the Change
Control System.

If a program contains requirements that will increase changes, such as compressed

scheduling, either modify the requirements or accept the fact and plan on it. Don’t deny it
or hide from it. It will not go away. Nine times out of ten it is not fixable! Most people
will not accept this fact so it cannot be taught. They simply have to live with it long
enough to realize that it is real and unavoidable.

CM
As for CM, the Standard Missile Program was under way before CM was created. Even
so, most of the elements of CM were used and the program illustrates many of the ways
that management decisions impact Change Control.

“Alignment with need” was simply assumed as it always had been. There will be those
who say that this proves that CM is unnecessary but that’s too great a leap. The pro-
gram’s “need” was to stop the Kamikaze by making the APL concept work. It was clearly
defined and widely known and there was no time for drift.

84
Rev. 1 Appendix - Generic CM

Does this mean that a clear need and a compressed schedule makes CM unnecessary?
It’s possible but unlikely. A clear need really means that CM is possible. A compressed
schedule means trouble aplenty. Don’t forget the overruns and the Claim!

CM program planning could have made the inherent complications more obvious. How-
ever, it’s unlikely that they would have been accommodated. The Navy was fixated on
achieving early competition no matter what. They got it but at an enormous cost in
money, stress, and reputation.

CM was very much in being when the Standard ARM came along. Once again time was a
major constraint. A compressed schedule was unavoidable. But this time the Navy’s pri-
mary goal was an effective solution to a raging problem. They cooperated to develop ap-
propriate accommodations, the greatest of which was high cost.

It may sound odd but it is often possible to substitute higher cost for time. Higher cost
makes possible the assignment of more people and people of greater capability (higher
paid) to the problem. The search for lowest cost parts and materials is dropped in favor of
availability of those that work. Greater risks are taken. If they turn to junk they are simply
scrapped and something else is tried. Economy of operation is subordinate to effective
operation. These things, skillfully managed, do save time. The change rate will be high
but expected. Little time is lost in emoting about it.

The Standard ARM program illustrates that CM can be effectively tailored to fit almost
any set of conditions if the tailors know what they are doing and work at it in good faith.

Competition wasn’t a consideration until the design problem was solved. However, when
it appeared it became an almost insane fixation all over again. Nothing had been learned
from the Standard Missile’s problems. After the storm had abated somewhat, we set
about solving the problem but the amiable relationship that existed during the Develop-
ment Program was gone forever.

***

85
Appendix - Generic CM Rev. 1

Afterword

Be mindful of the fact that perception depends upon perspective. The Tale of Two Pro-
grams has been told from my perspective. There are others. Many of the decisions that
appear to have been irresponsible may be justified if seen from the perspective of upper
management. Even so, decisions have consequences. They must be accommodated or
suffered.

The Standard Missile program suffered them in ignorance for almost 30 years. The Stan-
dard ARM Development Program accommodated them and produced amazing results.
The Standard ARM Production Program tried to suppress them and suffered accordingly.

Perhaps the most important lesson to be learned is that CM is not a task for novices. It
requires a thorough understanding of the industrial plant and the way it operates. Without
that understanding it provides little more than expensive window dressing, comforting to
some but of little other benefit.
***

86
