User Manual

DensityPRO+
Gamma Density System with Remote Transmitter

Installation Guide
P/N 717818
Revision F
Part of Thermo Fisher Scientific

DensityPRO+
Gamma Density System with Remote Transmitter
Installation Guide
P/N 717818
Revision F
© 2011 Thermo Fisher Scientific Inc. All rights reserved.
“Microsoft” and “Windows” are either trademarks or registered trademarks of Microsoft Corporation in
the United States and/or other countries.
“HART” is a registered trademark of the HART Communication Foundation.
All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
Thermo Fisher Scientific Inc. (Thermo Fisher) makes every effort to ensure the accuracy and completeness
of this manual. However, we cannot be responsible for errors, omissions, or any loss of data as the result of
errors or omissions. Thermo Fisher reserves the right to make changes to the manual or improvements to
the product at any time without notice.
The material in this manual is proprietary and cannot be reproduced in any form without expressed
written consent from Thermo Fisher.
This page intentionally left blank.
Revision History
Revision Level Date Comments
1.0 07-2001 Initial release.
A 03-2005 Name change.
B 07-2007 Per ECO 5804.
C 03-2008 Per ECO 5835.
D 12-2008 Per ECO 5930.
E 11-2009 Per ECO 7168.
F 06-2011 Per ECO 7705.
Thermo Fisher Scientific DensityPRO+ Installation Guide v

Contents
Safety Information & Guidelines ..................................................................... ix
Safety Considerations .............................................................................ix
Warnings, Cautions, & Notes ................................................................ix
Chapter 1 Introduction........................................................................................................ 1-1

Associated Documentation.................................................................. 1-1
Chapter 2 Handling & Storage .......................................................................................... 2-1

ESD Procedures .................................................................................. 2-1
Unpacking, Inspection, & Storage ...................................................... 2-2
Chapter 3 Installation ......................................................................................................... 3-1

General ............................................................................................... 3-1
Licensing............................................................................................. 3-2
Guidelines........................................................................................... 3-2
General ............................................................................................ 3-2
Power Options ................................................................................. 3-3
The Transmitter.................................................................................. 3-4
Installing Transmitter Boards........................................................... 3-5
AC Power Supply............................................................................. 3-6
The Gauge Head................................................................................. 3-7
Mounting Configurations ................................................................ 3-7
Mounting Instructions ..................................................................... 3-9
Dual Chain Mount ....................................................................... 3-9
Pipe Saddle (Cradle) Mount........................................................ 3-12
Pipe Spool Mount....................................................................... 3-14
Chapter 4 Wiring.................................................................................................................. 4-1

Preparation.......................................................................................... 4-1
General Wiring Procedures ................................................................. 4-2
For Scintillation Detectors ............................................................... 4-2
For Ion Chamber Detectors ............................................................. 4-4
For the Transmitter.......................................................................... 4-5
EMC Requirement for ATEX Version of 1400S Transmitters ...... 4-5
Procedure...................................................................................... 4-6
Detector Type Selection................................................................ 4-7
Power Supply Wiring .......................................................................... 4-7
Power to the Scintillation Detector .................................................. 4-7
Thermo Fisher Scientific DensityPRO+ Installation Guide vii

Contents
DC Power ..................................................................................... 4-7

AC Power...................................................................................... 4-8
Power to the Ion Chamber Detector ................................................ 4-9
Power to the Transmitter ............................................................... 4-10
AC Power.................................................................................... 4-10
DC Power ................................................................................... 4-10
Detector Signal Wiring ..................................................................... 4-11
Optional Wiring ............................................................................... 4-12
Relays............................................................................................. 4-12
Current Output ............................................................................. 4-12
Contact Closure (Switch) Inputs .................................................... 4-13
Temperature Compensation........................................................... 4-13
Flow Input ..................................................................................... 4-13
Serial Communications ..................................................................... 4-13
Optional RS485 Wiring................................................................. 4-14
RS485 Termination ....................................................................... 4-14
RS232 Wiring................................................................................ 4-14
HART Communications................................................................... 4-15
Chapter 5 Getting Help........................................................................................................5-1

Contact Information ........................................................................... 5-1
Returning Equipment for Service ........................................................ 5-1
Appendix A Ordering Information .......................................................................................A-1
Appendix B Specifications...................................................................................................B-1
Appendix C Drawings............................................................................................................ C-1
Appendix D Adding Ferrite Clamps to 1400S Transmitter ..............................................D-1

Procedure........................................................................................... D-1
Index ..........................................................................................................INDEX-1
viii DensityPRO+ Installation Guide Thermo Fisher Scientific

Safety Information & Guidelines
This section contains information that must be read and understood by all
persons installing, using, or maintaining this equipment.
Safety Failure to follow appropriate safety procedures or inappropriate use of the

equipment described in this manual can lead to equipment damage or
Considerations injury to personnel.
Any person working with or on the equipment described in this manual is
required to evaluate all functions and operations for potential safety hazards
before commencing work. Appropriate precautions must be taken as
necessary to prevent potential damage to equipment or injury to personnel.
The information in this manual is designed to aid personnel to correctly
and safely install, operate, and/or maintain the system described; however,
personnel are still responsible for considering all actions and procedures for
potential hazards or conditions that may not have been anticipated in the
written procedures. If a procedure cannot be performed safely, it must not
be performed until appropriate actions can be taken to ensure the safety
of the equipment and personnel. The procedures in this manual are not
designed to replace or supersede required or common sense safety practices.
All safety warnings listed in any documentation applicable to equipment
and parts used in or with the system described in this manual must be read
and understood prior to working on or with any part of the system.
Failure to correctly perform the instructions and procedures in this
manual or other documents pertaining to this system can result in
equipment malfunction, equipment damage, and/or injury to personnel.
Warnings,
arnings, Warnings, cautions, and notes are used throughout this manual to alert
users to potential hazards or important information. Failure to heed the
Cautions, & warnings and cautions in this manual can lead to injury or equipment
Notes damage.
Warning Warnings notify users of procedures, practices, conditions, etc.

which may result in injury or death if not carefully observed or followed.
The triangular icon displayed with a warning depends on the type of hazard
(general, electrical, radiation). ▲
Thermo Fisher Scientific DensityPRO+ Installation Guide ix

Safety Information & Guidelines
Warnings, Cautions, & Notes
Caution Cautions notify users of operating procedures, practices,

conditions, etc. which may result in equipment damage if not carefully
observed or followed. ▲
Note Notes emphasize important or essential information or a statement of

company policy regarding an operating procedure, practice, condition,
etc. ▲
Tip Tips may also be used in this manual. They are suggestions or things to
consider that will help you use the instrument or this manual. ▲
x DensityPRO+ Installation Guide Thermo Fisher Scientific

Chapter 1
Introduction
Refer to the Density PRO+ User Guide (p/n 717819) for a description of
instrument functions and features, ordering information, and product
specifications.
Associated In addition to this guide, the following documents must be read and
understood by all persons installing, using, or maintaining this equipment:
Documentation
● DensityPRO+ User Guide (p/n 717819)
● Gamma Radiation Safety (p/n 717904)
Thermo Fisher Scientific DensityPRO+ Installation Guide 1-1

Chapter 2
Handling & Storage
This chapter addresses procedures for handling electrostatic discharge
(ESD) sensitive equipment, as well as procedures for unpacking, inspecting,
and storing of the system.
Caution This system is an ESD sensitive instrument. Use proper ESD

protective equipment and procedures. Failure to comply with ESD
procedures can result in circuit damage. ▲
ESD
SD Procedures The instrument contains electronic components that can be damaged from
discharges of static electricity. Ordinarily, handling the circuit boards by
their edges will not damage the circuits.
Caution Do not touch the circuit board components. ▲
Observe the following when installing, setting up, servicing,

troubleshooting, or repairing the instrument:
1. Use an antistatic bag. Most instrument subassemblies are shipped in a

special antistatic bag. When not installed, keep the assembly in the bag
as often as possible.
2. Remove ESD sensitive subassemblies only under the following

conditions:
a. When at a designated static-free workstation or when the bag is
grounded at a field site.
b. After the conductive area of the container has been neutralized.
c. After making firm contact with an antistatic mat and / or firmly
gripping a grounded individual.
3. Personnel handling ESD sensitive devices should be neutralized to a

static-free workstation by means of a grounding wrist strap that is
connected to the station or to a good grounding point at the field site.

Handling & Storage
Unpacking, Inspection, & Storage
4. Do not allow clothing to make contact with ESD sensitive devices.
5. Avoid touching edge connectors and components.
6. Avoid partially connecting ESD sensitive devices. These devices,

especially the power supply connector, can be damaged by floating
leads.
7. Ground test equipment.
8. Avoid static charges during troubleshooting.
Unpacking, All personnel involved in the packing, shipping, or receiving of hazardous

material must be trained in accordance with the United States Department
Inspection, & of Transportation (DOT) and OSHA hazardous materials regulations or in
Storage accordance with the Canadian Nuclear Safety Commission (CNSC)
regulations.
Note Inspection, adjustment, installation, and maintenance of the

instrument must be performed by experienced personnel only. ▲
1. Upon receipt, inspect the instrument for damage that may have
occurred while in transit. If there is evidence of rough handling or
damage, file a damage claim with the transportation company
immediately. Notify Thermo Fisher and / or your sales representative as
soon as possible.
2. Carefully inspect the packing material prior to discarding it to ensure

that all equipment and instruction paperwork has been removed.
3. Use the original packing material and container for storage if necessary.
4. If storing the instrument, the storage environment should be protected,

free from extremes of temperatures and high humidity, and fall within
the environmental constraints listed in the specification appendix.
2-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Chapter 3
Installation
Read Gamma Radiation Safety (p/n 717904) prior to installing the
equipment.
Tip Copies of the drawings referenced in this manual are provided in

Appendix C. ▲
General
eneral The Thermo Scientific DensityPRO+ integrated gamma density system
consists of three components:
1. One of the following transmitter models:

Thermo Scientific 1400A transmitter with non-metallic enclosure
(NEMA 4X)
Thermo Scientific 1400A transmitter with cast aluminum enclosure
(NEMA 7/ NEMA 4)
Thermo Scientific 1400S transmitter with stainless steel enclosure
(NEMA 4X/IP65)
2. One of the following detector models:

Thermo Scientific 9701 or 9702 ion chamber detector
Thermo Scientific 9719B or 9720B scintillation detector
3. One of the following source head models:

Thermo Scientific 5190, 5191, 5176, 5200, 5201, 5202, 5203,
5204, or 5211
Note In this manual, the generic use of “transmitter” or “transmitters”

implies the 1400A and 1400S transmitters. The specific model name will
be used only when necessary. ▲
Note The combination of the detector and the source head is referred to as
the “gauge head”. ▲

Installation
Licensing
Licensing
Warning The instrument is a nuclear device regulated by federal and / or
state authorities. You are responsible for knowing and following the
pertinent safety and regulatory requirements. Refer to Gamma Radiation
Safety (p/n 717904) for a summary of these requirements. ▲
Warning Moving or removing an installed source housing or any assembly

that includes a source housing requires a person who is specifically licensed
to install and commission Thermo Scientific source heads. ▲
In the United States, your general license permits you to own and install all
of the instrument’s components, including the source head. However, you
may not commission the instrument (remove the lock and open the source
housing shutter for the first time) without a specific license authorizing
radiation commissioning of the instrument. In Canada, you are only
allowed to remove the instrument from the shipping container if your
CNSC license has a condition authorizing mounting / dismounting of
devices. For assistance obtaining a license or commissioning /
decommissioning the instrument, contact Thermo Fisher.
Guidelines
Warning Do not install the system in any hazardous area other than those
approved. Refer to the equipment tag for the specific approvals applicable
to the configuration of your instrument. ▲
Warning Do not apply power to the instrument in any hazardous area

unless the safety ground is properly wired inside the instrument and the
cover is properly installed. ▲
General
eneral Review the following guidelines when planning gauge installation. Also
refer to the installation layout drawing 868695 in the drawing appendix.
1. Correct power source is available. See “Power Options” later in this

chapter.
2. Operating temperature range:

a. Transmitter: -40°C to +60°C (-40°F to +140°F)
b. Scintillation or ion chamber detector: -30°C to +60°C (-20°F to
+140°F)

Installation
Guidelines
3. The transmitter should be mounted so that the display is easily seen

and the keypad on the transmitter (if applicable) is easily accessible.
4. The transmitter should not be mounted near high voltage, high

current, corrosive vapors, corrosive liquids, or corrosive esters.
5. There should be enough clearance to install and service the gauge head.
Refer to the appropriate drawings for your type of gauge and mount
(Appendix C).
6. The source housing should be positioned so that the radioactive source

identification tag is visible. The source housing tag should be upright.
7. The gauge should not be mounted where process overflow or other

material can collect in the beam path. The source shutter mechanism
must be kept free of debris.
8. The maximum cable length between the transmitter and the detector
varies with the gauge of the wire, but should not exceed 5000 feet
(1525 m) for an ion chamber detector or 1000 feet (300 m) for a
scintillation detector.
Power Options 1400A/1400S transmitters

● 115/230 Vac (100–240 Vac), 50/60 Hz, 12 VA
● 24 Vdc (20–28 Vdc), 12 VA
9701/9702 ion chamber detector
● 115/230 Vac ± 10%, 50/60 Hz, 500 VA
9719B/9720B scintillation detector
● 24 Vdc ± 20%, 12 VA, at detector input
● 115/230 Vac ± 15%, 50/60 Hz, 12 VA

Installation
The Transmitter
The Transmitter
Warning Do not install the unit in any hazardous area other than those
approved. Refer to the equipment tag for the specific approvals applicable
to the configuration of your instrument. Follow all instructions on the
installation drawings. ▲
Warning Do not apply power to the unit in any hazardous area unless the
safety ground is properly wired inside the unit and the cover is properly
installed. ▲
Warning Use proper lifting procedures during installation to avoid

injury. ▲
Refer to the proper dimensional drawing for the transmitter mounting

dimensions:
● 868212: 1400A transmitter with non-metallic enclosure (NEMA
4X)
● 868214: 1400A transmitter with cast aluminum enclosure (NEMA
7/ NEMA 4)
● 208-140002: 1400S transmitter with stainless steel enclosure
(NEMA 4X/IP65)
Mount the transmitter in one of the following two ways:
● With four screws: Place one screw through each of the four holes in
the transmitter enclosure’s flange and tighten.
● With four nuts, four bolts, and eight washers: Place one bolt
through each of the four holes in the transmitter enclosure’s flange,
with one washer on each side. Screw on the nuts, and tighten the
bolts.

Installation
The Transmitter
Installing
stalling
Transmitter Boards
Warning Remove all power from the unit prior to opening the transmitter
enclosure. Electrocution can result if power is present. ▲
The following procedure applies to all transmitter boards except for the AC
power supply. Refer to “AC Power Supply” later in this chapter.
1. Verify that power has been removed from the transmitter.
2. Remove the screws on the faceplate (cover) and open it.
3. If replacing a board, remove the board that is currently installed:

a. Unplug any screw-in terminal connectors that have been wired
from the board.
b. Remove the board retaining screw in the upper card guide.
c. Firmly but carefully push down on the top edge of the board to
disengage the board connector from the transmitter. Pull up and
out on the bottom edge of the board to remove it.
4. Align the board with the upper and lower card guide slots, and insert
the board into the slots.
5. Line up the 3-pin by 16-pin male connector on the board with the
corresponding connector on the back of the transmitter.
6. Firmly but carefully push on the board until the connector is fully
seated.
7. Insert and tighten the board retaining screw in the upper card guide.
8. Connect the screw-terminal connector(s) to the corresponding

replacement board connectors.
9. Refer to Chapter 4 for wiring procedures.
10. Close the transmitter and tighten the cover screws.

Installation
The Transmitter
AC
C Power Supply
Warning If a power supply fails, the input capacitor might still be charged
at a high voltage (up to 400 volts). ▲
Caution Do not remove the four screws that secure the power supply to
the mounting bracket. The power supply and mounting bracket are placed
as a single unit. ▲
Note The old power supply assembly is not field repairable. ▲
1. Follow the procedure in step 3 above to remove all other transmitter

boards (CPU, PCB 1, PCB 2, PCB 3, and PCB 4).
2. Remove the two hold-down screws from the base of the power supply
mounting bracket. These screws secure the power supply mounting
bracket to the main board.
3. Disconnect cables from the power supply (AC, DC, and Protective
Safety Ground). Cut the tie wrap that secures the toroid to the power
supply.
4. If replacing the power supply, remove the existing power supply and
mounting bracket assembly. Replace it with the new supply.
5. Connect the cables to the replacement power supply (see “Power to the
Transmitter” in Chapter 4 for wiring instructions).
6. Tighten the two hold-down screws to secure the power supply to the
main board. (A screw-holding screwdriver facilitates installation.)
7. Reinstall the transmitter boards.

Installation
The Gauge Head
The Gauge Head

Warning Installation must be in accordance with local and national
electric codes for the area classifications. ▲
Warning The source housing handle must be in the OFF position during
installation. ▲
Warning Do not reach inside the source housing at any time during
installation. ▲

injury. ▲
Mounting
unting The optimum gauge mounting configuration depends on the application;
Configurations however, the source head and the detector are typically mounted together
on the opposite sides of a pipe. The following mounting options are
supported for the gauge:
● Dual chain
● Pipe saddle (cradle) mount
● Pipe spool with gauge head pre-installed
The chain mount is the most frequently used mounting configuration, as it
allows the unit to be mounted on a range of pipe sizes using the same
mounting hardware.
Note Moving the gauge to a pipe with a different diameter may require
changing the radiation source size and/or reconfiguring the detector (ion
chamber) electronics. Contact Thermo Fisher for assistance. ▲
In addition to the guidelines listed earlier in this chapter, note the

following when planning gauge head installation.
● Whichever mounting configuration is used, it is important to align the
beam path (the centerline of the source housing) as closely as possible
with the centerline of the detector housing. Be sure to mount the gauge
head securely, since any movement or change in alignment can affect
the gauge’s calibration.

Installation
The Gauge Head
● For best performance the beam must pass through a representative

cross-section of the process material being measured. The gauge
measures only the material that passes through the beam. Prevent
suspended solids from settling out of the measured area by mounting
the gauge head on a vertical section of pipe.
● For mounting on a horizontal pipe:
● Position the beam path at a 30- to 45-degree angle from vertical.
This position tends to average density variations caused by settling,
while reducing the effect of any trapped gases or solids that
accumulate in the top or bottom of the pipe.
● If the process material is a solution, a light slurry, or a single-phase
liquid that will not separate, the gauge head can be mounted such
that the beam is horizontal.
● If the process material is a slurry, position the gauge head as far as
possible from any elbows, tees, or valves (these tend to separate
suspended solids). Position the beam path in the plane of the upstream
elbow so the measurement includes any uneven distribution caused by
the fitting.
Figure 3–1. Gauge installation examples

Installation
The Gauge Head
Mounting The following sections provide installation details for the various mounting
Instructions configurations. Refer to the following drawings for detector dimensions.
● 867468: 9719B scintillation detector, NEMA 4 housing
● 867469: 9720B scintillation detector, explosion proof housing
● 866778: 9701 ion chamber detector, NEMA 4 housing
● 866777: 9702 ion chamber detector, explosion proof housing

injury. ▲
Caution Do not over tighten the bolts. ▲
Dual
ual Chain Mount For the dual chain mount, two mounting chains are wrapped around the
pipe with their ends engaging keyhole-shaped openings in the source head
mounting plate. The detector housing is then clamped to the two chains’
center links (opposite the source mounting plate) by tensioning bolt
assemblies.
Details of the chain mount depend on the detector type, but the
installation is similar for both types. Refer to the following drawings for
mounting details.
● 867466: 9719B scintillation detector
● 867467: 9720B scintillation detector
● 867172: 9701/9702 ion chamber detector
Figure 3–2. Dual chain mount

Installation
The Gauge Head
1. Use the tables below to determine the number of chain links to thread
through the keyhole slots. Count the links and mark the ones that will
be engaged at each end of the two chains (four links in all).
For scintillation detectors, use chain p/n 867103. For ion chamber
detectors, use chain p/n 867104.
Table 3–1. Dual chain mounting for 9719B and 9720B scintillation detectors
Pipe Size Links from Links from Links from Links from
(inches) Center End Center End
2 7 23 6 24
2.5 7 23 6 24
3 8 22 7 23
3.5 8 22 7 23
4 9 21 8 22
5 10 20 9 21
6 12 18 11 19
8 14 16 13 17
10 17 13 16 14
12 20 10 19 11
14 21 9 20 10
16 24 6 23 7
18 25 5 24 6
Table 3–2. Dual chain mounting for 9701 and 9702 ion chamber detectors
Pipe Size Links from Links from Links from Links from
(inches) Center End Center End
2 29 25 28 26
2.5 32 22 31 23
3 34 20 33 21
3.5 37 17 36 18
4 40 14 39 15
5 42 12 41 13
6 45 9 44 10
8 47 7 46 8
10 50 4 49 5

Installation
The Gauge Head
2. For 9701/9702 ion chamber detectors, partially assemble the two

tensioning bolts (hardware kit 885825) in the following order:
a. 1 tensioning bolt (large)
b. 1 flat washer: Place onto bolt next to bolt head.
c. 1 spacer ring
d. 2 Belleville washers with concave sides together
e. 1 special nut: Thread nut securely onto the bolt end.
3. For 9719B/9720B scintillation detectors, partially assemble the two

tensioning bolts (hardware kit 885826) in the following order:
a. 1 tensioning bolt (large)
b. 1 chain: Place center ring of chain over the bolt head.
c. 1 bar nut: Position the guard tube towards the bolt head.
d. 1 special nut: Thread the nut securely onto the bolt end. After the
special nut is fully threaded, thread the bar nut back down the bolt
so that it rests against the special nut.
4. From the pipe side of the source mounting plate, thread one end of a
chain through the plate’s top keyhole opening until you reach one of
the four end links you marked in step 1. Engage this link by sliding it
into one of the keyhole slots.
5. Thread one end of the other chain through the bottom keyhole and
engage the marked link as you did with the top chain.
6. Position the source housing mounting plate on the pipe. If necessary,

use a lift, hoist, or other means to hold it in position.
7. Pass the center part of the upper and lower chains around the pipe and
thread their ends through the corresponding keyholes. Engage the
marked links in the empty slots.
Note All four chain ends must engage at the same link. If you make an
adjustment, adjust all four chain ends by the same amount. Also make sure
there are no twists in the chain as you wrap it around the pipe. Otherwise
the gauge head will not be aligned correctly. ▲

Installation
The Gauge Head
Note You may need to adjust chain links (thread more or fewer links
through each slot) to allow for pipe size tolerance, insulation, etc. Start with
approximately 10 cm (4 inches) of play. ▲
8. Position the detector on the pipe, opposite the source mounting plate.
If necessary, use a lift, hoist, or other means to hold it in position.
9. To secure the detector and the source head mounting plate on the pipe:
a. Position the upper chain, including the tensioning bolt assembled
earlier, over the detector’s top mounting arm.
b. Place a spacer ring and two Belleville washers with concave sides
together onto the pilot end of the special nut.
c. Insert the pilot end of the chain tensioning bolt into the hole in the
top detector mounting arm and tighten the chain tensioning bolt
finger-tight.
d. Repeat the previous three steps for the lower chain.
10. Alternately and uniformly tighten the chain tensioning bolts until the
spacers are just touching the mounting arms.
11. Place the loose ends of the upper chain over the top edge of the source
mounting plate so they will not interfere with the source housing
installation.
12. Position the source housing so its four mounting holes engage the four
studs on the mounting plate. If necessary, use a lift, hoist, or other
means to hold it in position.
13. Use the provided lock washers and nuts to secure the source housing.
Pipe Saddle (Cradle) A pipe saddle, or cradle, mount consists of two identical mounting plates
Mount that are bolted together on opposite sides of the process pipe.
Refer to drawing 85726N and follow the steps below to install a gauge
head with a pipe saddle mount.

Installation
The Gauge Head
Figure 3–3. Pipe saddle mount
1. Assemble the two halves of the saddle mount onto the process pipe
using the supplied nuts, bolts, and washers. Thread the nuts and bolts
together, but do not tighten them.
2. Adjust the saddle mount halves so the mounting plates are parallel and
even with each other. Then tighten the bolts evenly so the clamp ends
are the same distance apart on both sides of the pipe.
3. Bolt the detector and source housings to the mounting plates on either
side of the pipe saddle.
4. Tighten all bolts securely so the gauge head components cannot shift
positions.

Installation
The Gauge Head
Pipe
ipe Spool Mount A pipe spool is normally a 30-inch section of pipe with either mounting
plates or a complete gauge head already installed. Often, a length of the
required pipe is sent to Thermo Fisher to be converted into a pipe spool
mount.
Caution Use correct pipe fitting techniques suitable for the pipe being used
and the process material that the pipe will handle. ▲
1. Assemble the pipe spool into the existing pipe.
2. Position the source housing so its identification tag is upright.
3. If the detector and source housings are not already installed, bolt them
to the mounting plates on either side of the pipe saddle.
4. Tighten all bolts securely.

Chapter 4
Wiring
Wiring should be performed in the following order:
1. Power to the transmitter and detector
2. The detector to the transmitter
3. Optional wiring:
a. Relay contacts
b. 4–20 mA current output(s)
c. Contact closure inputs
d. Optional temperature compensation board to the transmitter
e. Serial communications
Preparation
reparation Review the following carefully prior to connecting any wiring.
Warning Remove all power from the unit before making any connections.
Electrocution can result if power is present. ▲
Warning All wiring must be done by qualified individuals in accordance

with applicable codes such as the NEC (National Electric Code)
ANSI/NFPA 70 specifications or the Canadian Electrical Code Part 1.
Only approved conduit, boxes, and fittings may be used. ▲
Warning Do not apply power to the unit in any hazardous area unless the
safety ground is properly wired inside the unit and the cover is properly
installed. ▲

Wiring
General Wiring Procedures
Warning For hazardous location installations, the cable entries must be

sealed per the installation layout drawing 868695. For non-hazardous
location installations, the cable entries into the enclosures must be sealed to
prevent passage of gas or vapors. The surrounding atmosphere or liquids
should not affect the sealing compound. The minimum thickness of the
sealing compound should be 16 mm (5/8”). ▲
Warning If metal conduit is used, the conduit must be grounded. ▲
Warning Before wiring, verify that the source shutter is in the closed
(OFF) position. ▲
The installation layout drawing 868695 provides general guidance for

routing the cables between the detector and the transmitter. The drawings
below provide instructions on wiring the detector and transmitter.
● 868680-2: Installation wiring, 1400A/1400S transmitter
● 868577: Installation wiring, 9719B/9720B scintillation detector
● 868697: Installation wiring, 9701/9702 ion chamber detector
General Wiring This section provides general instructions for detector and transmitter
wiring. Wiring details, such as power supply connections, are provided in
Procedures the remainder of this chapter.
Forr Scintillation Use the following procedure when wiring 9719B and 9720B scintillation
Detectors detectors:
1. Make sure all source shutters are in the “OFF” position.
2. Make sure all power to the gauge is turned off.
3. Remove the housing access cover:

For the 9719B detector, remove the bolts that secure the cover to
the housing.
For the 9720B detector, loosen the screw on the cover retaining
bracket and slide the bracket off of the housing cover. Unscrew the
housing access cover (two lugs are provided on the top of the cover
to aid in the removal of the cover).

Wiring
4. Remove the cable conduit plugs only from the hole(s) that will be used.
As shown in the installation layout drawing 868695, lay one conduit
for the signal cables (and DC power input, if applicable), and a second
conduit for the AC power input.
5. Pull each cable through the correct conduit fitting and into the
enclosure. Leave approximately 150 mm (six inches) for strain relief.
Secure the conduit, making sure it is completely sealed.
6. Connect the input power and the signal wires as follows. Reference the
installation wiring drawing 868577.
a. Remove the plug-in screw-terminal connector from the board
connector. The connector should be tightly seated. To remove the
connector, brace the board with your hand, being careful not to
touch any of the circuits or components.
b. Use a 1/8-inch screwdriver to loosen the screws on the plug-in
connector.
c. Insert the wires and make connections as shown in the installation
wiring drawing.
d. Tighten the screws in the connector to secure the wires and plug
the screw-terminal connector back into the corresponding onboard
connector.
e. The optional temperature compensation board uses a spring
terminal block connector. For each wire to be connected, use a flat
screwdriver to push and hold the appropriate tab down. Insert the
wire, and then release the tab to secure the wire.
7. When the detector wiring is complete, replace and secure the detector
housing cover.

Wiring
For Ion Chamber Use the following procedure when wiring 9701 and 9702 ion chamber
detectors. You will need a 1/8-inch bladed screwdriver.
Detectors
Note While wiring the ion chamber detector, locate the Hi-Meg label on
the detector circuit board. A large resistance value will be written on this
label (for example, 4.7 x 1011). Write down this value along with the
detector’s serial number. The Hi-Meg value will be needed during the
gauge setup to fine tune the gauge. ▲
1. Make sure all source shutters are in the “OFF” position.
2. Make sure all power to the gauge is turned off.
3. Remove the housing access cover:

For the 9701 detector, remove the bolts that secure the cover to the
housing.
For the 9702 detector, loosen the screw on the cover retaining
bracket and slide the bracket off of the housing cover. Unscrew the
housing access cover (two lugs are provided on the top of the cover
to aid in the removal of the cover).
4. Remove the foam insulator and the two brass-colored centering plates.
5. As shown in the installation layout drawing 868695, the AC power and

signal wiring should not be run in the same conduit for more than
three meters (ten feet). If required, use a conduit splitter and lay one
conduit for the signal cables and a second conduit for the AC power
wiring.
6. Pull each cable through the conduit and into the enclosure. Leave
approximately 150 mm (six inches) for strain relief. Secure the conduit,
making sure it is completely sealed.
7. Connect the input power, the ion chamber signal wires, and the
temperature compensation board wires, if applicable, as shown in the
installation wiring diagram 868697.

Wiring
Note Connect the AC wiring Earth ground to the internal safety ground
terminal (on the inside of the detector housing) as shown in the wiring
diagram. Do not connect the shield from the signal cable at the detector
end. ▲
8. Position the two brass-colored centering plates over the circuit board
with the smaller plate on top of the larger plate. Be careful to not pinch
any wiring. Thread in and finger-tighten the four screws that secure the
centering plates.
9. Insert a medium-sized flat blade screwdriver into the stepped (jagged)

opening in the larger centering plate. Twist the screwdriver to push the
two plates apart until the detector is locked in position. Tighten the
four screws to secure the centering plates and the detector.
10. When the wiring is complete, replace and secure the detector housing
cover.
For the Transmitter

EMC Requirement for In order for the 1400S transmitter to meet electromagnetic emission
ATEX Version of 1400S requirements for CE-EMC approvals, ferrite clamps must be installed
Transmitters within the transmitter enclosure on all power and signal wiring going into
and out of the transmitter housing.
One ferrite clamp is installed on the wires of the AC power supply input.
Five additional ferrite clamps are provided with the EMC ferrite clamps kit
(p/n 868773). The installation procedure accompanies the kit. It is also
provided in Appendix D.
Note The ferrite clamps are only used in the ATEX version of the 1400S
transmitter. They are not required for the CSA version or the plastic 1400A
transmitter. ▲

Wiring
Procedure The transmitter has slots for the following boards:

● Optional AC power supply
● CPU board
● PCB 1: Standard current I/O / DC power board
● PCB 2: Optional current I/O board with two contact inputs and two
optional relays
● PCB 3: Optional current I/O board with two contact inputs and two
optional relays
● PCB 4: Voltage/current pulse interface (VPI) board (p/n 868712), used
to interface with the detector
Follow this general procedure for wiring boards installed in the transmitter,
RS232 or RS485 serial ports, relay contacts, contact closure inputs, 4–20
mA current output(s), and detector signal cables to the transmitter. You
will need a 1/8-inch bladed screwdriver.
Note CSA certified fittings must be used to maintain CSA rating for the
enclosure. ▲
1. Ensure power is removed, and open the enclosure cover.
2. Remove the plugs only from the cable conduit holes you will use. The
holes are labeled on the transmitter enclosure.
3. Pull the cable through the fitting on the end of the enclosure. Leave
approximately 6 inches (150 mm) of stress relief. Secure the conduit,
ensuring it is completely sealed.
4. For ATEX versions of the 1400S: Install a ferrite clamp on all wiring.
You will need kit 868773. Refer to Appendix D.
5. Connect a cable to a PCB as follows:

a. Remove the plug-in screw terminal connector from the board
connector. If the connector is tight, brace the board with your hand
to remove the screw terminal connector, but be careful to not touch
any circuit components.
b. Loosen the terminal screws on the connector. Insert the wires into
the connector and make connections as shown in the appropriate
installation wiring drawing.

Wiring
Power Supply Wiring
c. Tighten the terminal screws to secure the wires.

d. Plug the screw-terminal connector back into the corresponding on-
board connector.
6. When all connections are complete, close and secure the transmitter
cover.
Detector Type Selection Three, two-pin headers (JP1, JP2, and JP3) are located along the edge of
the VPI board near the top of the board. A jumper should be installed on
one (and only one) of these headers to indicate the detector type as follows:
● JP1: Ion chamber detector
● JP2: Scintillation detector – SGD mode
● JP3: Scintillation detector – PRO mode
Caution Remove power from the transmitter before changing jumper

settings. Failure to do so may result in damage to the VPI board. ▲
Power Supply
Wiring
Power to the When connecting power to the 9719B/ 9720B scintillation detectors, refer
Scintillation to installation wiring diagram 868577.
Detector
Note To meet the requirements of CSA 1010.1, an external switch or
circuit breaker must be installed to allow the power source to be
disconnected from the gauge. In addition, protective bonding (grounding)
must always be provided, even if a DC power source is used. ▲
DC
C Power The 9719B/9720B scintillation detectors are designed to operate on 24
Vdc ± 20%. The input connector for the DC source voltage wiring is
located on the interface/ adapter board.
Note To meet the requirements of CSA 1010.1, the input DC terminals

shall be supplied from an SELV (Safety Extra Low Voltage) source. ▲
Connections are shown in the table below.

Wiring
Power Supply Wiring
Table 4–1. DC power wiring for 9719B/9720B scintillation detectors

User Power Supply (+24Vdc, 0.5 A) Detector
+ J1-2
- J1-1
AC
C Power With the AC power board installed, the scintillator detector may be
operated using either 115 or 230 Vac ± 15%. The AC supply voltage is set
by the 115/230 Vac selector switch. The selector switch is located on the
AC power board, below the connectors and just above the transformer. To
access the selector switch, it is necessary lift the detector chassis several
inches out of the housing.
If both AC and DC input power are supplied to the detector, the detector
will draw power from whichever source provides the higher DC voltage.
Caution Applying 230 Vac with the selector switch in the 115 Vac
position will damage the equipment. ▲
Caution For reliable operation and to maintain safety approval, the F1 fuse
on the AC power board must only be replaced with an approved fuse.
Reference installation wiring diagram 868577 ▲
Table 4–2. AC power wiring for 9719B/9720B scintillation detectors

AC Power Supply Detector
N J17-1
L J17-2
terminal as shown in the wiring diagram. ▲

Wiring
Power Supply Wiring
Power
wer to the Ion The 9701/9702 ion chamber detectors may be operated using either 115 or
230 Vac ± 10%. The maximum input power requirement is 500 VA.
Chamber Detector
When connecting power to the 9701/9702 detectors, refer to installation
wiring drawing 868697.
terminal provided on the inside of the detector housing as shown in the
wiring diagram. ▲
Caution Applying 230 Vac with the selector switch in the 115 Vac
position will damage the equipment. ▲
The ion chamber detector is shipped wired for either 115 or 230 Vac
operation. If necessary, the detector’s operating voltage can be changed by
following the procedure below.
1. The two red wires should be installed on the marked push-on tabs
(RED1 and RED2).
2. Install the four heater wires (two white wires and two black wires) on
the push-on tabs as follows:
a. One white wire on the Wh tab.
b. One black wire on the Bk tab.
c. For 115 Vac operation:
- One white wire on the Wh/115 tab.
- One black wire on the Bk/115 tab.
d. For 230 Vac operation:
- One white wire on the Wh/230 tab.
- One black wire on the tab Bk/230 tab.
3. Set the 115/230 Vac selection switch (located next to the transformer)
to the desired voltage.
Caution For reliable operation and to maintain safety approval, the F1 fuse
on the AC power board must only be replaced with an approved fuse.
Reference installation wiring diagram 868697. ▲

Wiring
Power Supply Wiring
Power to the When connecting power to the 1400A/1400S transmitters, refer to

Transmitter installation wiring drawing 868680-2.
Note To meet the requirements of CSA 1010.1, an external switch or

circuit breaker must be installed to allow the power source to be
disconnected from the gauge. In addition, protective bonding (grounding)
must always be provided even if a DC power source is used. ▲
AC Power With AC power, the 1400A and 1400S transmitters are designed to operate
on 100–240 Vac, at an input frequency of 50/60 Hz. The same system
configuration can be directly wired to either 115 or 230 Vac. The
maximum input power requirement is 12 VA when all options are present.
Table 4–3. AC power wiring for 1400A/1400S transmitters
AC Power Supply Transmitter
L J1-L
N J1-N
DC Power
Note To meet the requirements of CSA 1010.1, the input DC terminals
must be supplied from an SELV (Safety Extra Low Voltage) source. ▲
With 24 Vdc power, the 1400A and 1400S transmitters are designed to
operate on 20–28 Vdc. The maximum input power requirement is 12 VA
when all options are present.
Table 4–4. 24 Vdc power wiring for 1400A/1400S transmitters
+24Vdc Power Supply Transmitter
+24Vdc J5-8 (+24Vdc input)
+24Vdc return J5-9 (GND)

Wiring
Detector Signal Wiring
All signals from the detector are wired to the VPI board that is installed in
Detector
etector Signal the transmitter slot PCB 4. Refer to the appropriate installation wiring
Wiring drawings for the detailed requirements.
● 868680-2: Installation wiring, 1400A/1400S transmitter
● 868577: Installation wiring, 9719B/9720B scintillation detector
● 868697: Installation wiring, 9701/9702 ion chamber detector
Caution Remove power from the transmitter before changing jumper

settings. Failure to do so may result in damage to the VPI board. ▲
Signal wiring for the 9719B/9720B scintillation detectors are shown in the
tables below. Use 22–16 AWG individually shielded cable (1000 ft
maximum).
Table 4–5. Wiring for scintillation detector data and references pulses
Scintillation Adaptor Board VPI Board in 1400A/1400S Transmitter
J2-1 (DATA (H)) J1B-15 (+PULSE DATA)
J2-2 (SHIELD) J1B-21 (SHIELD)
J2-3 (DATA (L)) J1B-16 (-PULSE DATA)
J2-4 (REF (H)) J1B-17 (+PULSE REF)
J2-6 (REF (L)) J1B-18 (-PULSE REF)
Table 4–6. Wiring for scintillation detector HV pulses or duty cycle mode
Scintillation Adaptor Board VPI Board in 1400A/1400S Transmitter
J3-1 (INC (H)) J1B-19 (+HV INCREASE)
J3-3 (INC (L)) J1B-20 (-HV INCREASE)
J3-4 (DEC (H)) J1B-22 (+HV DECREASE)
J3-5 (SHIELD) J1B24 (SHIELD)
J3-6 (DEC (L)) J1B-23 (-HV DECREASE)

Wiring
Optional Wiring
Note The transmitter is used in duty cycle mode unless it is wired to a D

series scintillation detector. The duty cycle mode is set by connecting
jumper P3 pin 1 and 2 on the scintillation adapter board and shorting JP3
on the VPI board. ▲
Note Install two jumpers on P2. Jumper pin 1 to pin 3 and pin 2 to pin
4. ▲
Signal wiring for the 9701/9702 ion chamber detectors is shown below.
Table 4–7. Wiring for ion chamber detector signal
9701/9702 Ion Chamber VPI Board in 1400A/1400S Transmitter
J2-3 (+) J1A-8 (+ION CHAMBER)
J2-4 (-) J1A-0 (-ION CHAMBER)
Optional Wiring For optional wiring, refer to installation wiring drawing 868680-2.
Relays I/O boards installed in transmitter slots PCB 1 through PCB 3 can have
two relays each, allowing for a maximum of six relays. Connector J1 is for
relays and is only installed on the PCB if relays were specified in the order.
Relay contacts are Form C SPDT, isolated 8 A, 22 Vac. You can assign
process alarms to control the relays. Refer to the DensityPRO+ user guide
for details.
Current Output One current output (I/O) board is supplied as standard and installed in the
PCB 1 slot. Two additional I/O boards are optionally available are installed
the transmitter’s PCB 2 and PCB 3 slots.
The current output is normally shipped from the factory configured as an
isolated self-powered output. You can reconfigure the current output as
isolated loop-powered by removing the jumper from pins 3 and 4 of the J5
connector. In the loop-powered configuration, the user must supply +24
Vdc loop power to pin 3 of J5. Pin 2 of J5 is Iout+.
The current output is programmable between 3.8 and 20.5 mA. Refer to
the DensityPRO+ user guide for details. The minimum output in the self-
powered configurations is approximately 0.4 mA. The minimum output
current in the loop-powered configuration is approximately 3 mA.
Maximum load is 800 ohms.

Wiring
Serial Communications
Contact Closure Two contact closure inputs are included on each I/O board. They are dry
contact inputs between ground and switch 1 and ground and switch 2. The
(Switch) Inputs gauge can be configured to execute a command or other function upon a
user-provided contact opening or closing. Refer to the DensityPRO+ user
guide for details on assigning commands to the contact closure inputs.
Temperature Temperature compensation circuitry with 2-wire or 3-wire 100 ohm

Compensation platinum RTD is optionally available. For 9701/9702 scintillation
detectors, connections are made at J19. For 9719B/9720B ion chamber
detectors, connections are made from the temperature compensation board.
For the 1400A/1400S transmitter, connections are made at J1A of the VPI
board installed in the PCB 4 slot. Reference the appropriate installation
wiring diagrams for specific wiring information.
Flow Input There is a provision on the VPI board for a user-provided 4–20 mA flow
input (pins 6 and 7 of connector J1A). Refer to the DensityPRO+ user
guide for details on how to configure the gauge to use the flow input signal.
Serial The transmitter provides one RS232 single-drop serial interface. One
RS485 multi-drop serial interface is optionally available. Screw-terminal
Communications connectors for both ports are located on the CPU board.
The optional RS485 connector (J6) includes the +8 Vdc required to power
the Thermo Scientific HHT as well as the +DATA and –DATA
connections. An RJ-11 (phone jack) connector is also provided for the
RS485 port. The HHT can be connected directly to the RJ-11 connector.
Both the RS232 and optional RS485 ports are always active and provide
independent access to the measurement readings and software functions.
The setup menus, however, can only be accessed by one port at a time. For
information on configuring communications, refer to the DensityPRO+
user guide.

Wiring
Serial Communications
Optional RS485 Connecting a PC serial port (COM) to the optional RS485 port on the
gauge requires an RS485/RS232 converter (p/n 670045). The J6 connector
Wiring on the transmitter CPU is for the RS485 connections. Refer to installation
wiring drawing 868680-2 and make the RS485 connections as follows.
1. Connect +DATA and –DATA on the RS485 connector (J6) to the

corresponding connections on the RS485/RS232 converter.
2. Connect the RS485/RS232 converter to the PC using a standard DB9

serial cable.
RS485 Termination If you are having trouble using another device on the RS485 chain, verify
that it is properly terminated for its position on the chain. To terminate a
device, connect a 120  resistor between its RS485 +/– data terminals.
Never terminate more than the first and last device in the chain.
The transmitter includes a three-pin header (W4), located near the bottom-
front edge of the CPU board next to the RS485 connector (J6), to
terminate the RS485 connection.
For a single unit installation or for a multiple unit installation where the
transmitter is the last unit in line, the W4 jumper should be placed on pins
1 and 2 to terminate the RS485 line.
For a multiple unit installation where the transmitter is the not last unit in
line, the W4 jumper should be placed on pins 2 and 3 so that the RS485
line is not terminated at the transmitter.
RS232 Wiring COM1 or COM2 on a PC can be connected directly to the transmitter

RS232 port. This connection requires five wires: ground, TX, RX, RTS,
and CTS. The RS232 port connector (J8) is located on the transmitter
CPU board. Connections for standard DB9 and DB25 PC serial port
connectors are listed in the table below.
Table 4–8. RS232 connections
RS232 Connector (J8) on PC Serial Port DB9 PC Serial Port DB25
Transmitter CPU Connector Connector
J8-1 (RTS) Pin 8 Pin 5
J8-2 (TX) Pin 2 Pin 3
J8-3 (CTS) Pin 7 Pin 4
J8-4 (RX) Pin 3 Pin 2
J8-5 (GND) Pin 5 Pin 7

Wiring
HART Communications
HART The HART communication protocol is supported over the 4–20 mA

current output with an optional daughter board. You communicate with
Communications the gauge using the standard 275 or 375 Field Communicator. Refer to the
DensityPRO+ HART operation manual (p/n 717816).

Chapter 5
Getting Help
Contact The local representative is your first contact for support and is well
equipped to answer questions. You can also contact Thermo Fisher directly
Information for application assistance.
Process Instruments
1410 Gillingham Lane 14 Gormley Industrial Avenue Unit 702-715, 7/F Tower West
Sugar Land, TX Gormley, Ontario Yonghe Plaza No. 28
77478 USA L0H 1G0 Andingmen East Street, Beijing
CANADA 100007 CHINA
+1 (800) 437-7979
+1 (713) 272-0404 direct +1 (905) 888-8808 +86 (10) 8419-3588
+1 (713) 4573 fax +1 (905) 888-8828 fax +86 (10) 8419-3580 fax
A-101, 1CC Trade Tower Ion Path, Road Three
Senapati Bapat Road Winsford, Cheshire
Pune 411 016 CW7 3GA
Maharashtra, INDIA UNITED KINGDOM
+91 (20) 6626 7000

+44 (0) 1606 548700
+91 (20) 6626 7001 fax
+44 (0) 1606 548711 fax
www.thermoscientific.com
Contact Thermo Fisher for specific instructions. Please have the following
Returning available:
Equipment for ● Specific information about the problem.
Service ● A contact name and phone number, in case we need more
information.
● A purchase order authorizing repairs or a request for a quote.

Appendix A
Ordering Information
Table A–1. 9719B/9720B scintillation detectors
Part Number Description
886599 Scintillation adapter board (transmitter interface)
886568 AC power supply board
-- Fuse-F1, 250V, 0.125A (1/8A SB), 3AG
886609 Temperature compensation board
886592 Triangle board
Table A–2. 9701/9702 ion chamber detectors

P/N Description
885498-1 Preamp/power supply boards
-- Fuse-F1, 250V, 5A, Slo-Blow, 3AG
Table A–3. 1400A transmitter

P/N Description
886650 Power supply assembly
886765 CPU board
886675-1 I/O board, 24 Vdc input power, no relays
886675-2 I/O board, 24 Vdc input power, 2 relays
886675-5 I/O board, no DC input power, no relays
886675-6 I/O board, no DC input power, 2 relays
-- I/O board fuse-F1, 250V, 0.75A, Slo-Blow
886671-3 HART communication option
886712 VPI board
886723 RS485 board
Thermo Fisher Scientific DensityPRO+ Installation Guide A-1

Ordering Information
Table A–4. 1400S transmitter

P/N Description
HLT-MTXR-SS 1400S stainless steel transmitter
886765 Kit, NDM CPU board with EPROM for density
886712 VPI board
886650 AC power supply
OTO545B HART interface module
886675-1 I/O board, 24 Vdc input power, no relays
886675-2 I/O board, 24 Vdc input power, 2 relays
886675-5 I/O board, no DC input power, no relays
886675-6 I/O board, no DC input power, 2 relays
886723 RS485 board
868773 Kit, EMC ferrite clamps for 1400S transmitter (for ATEX units only)
A-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Appendix B
Specifications
Results may vary under different operating conditions.
Table B–1. Performance specifications
Operating Gamma radiation from the source passes through the process pipe and
principle material. The amount of radiation reaching the detector decreases as
the process level increases.
Accuracy ± 1% of span
Stability Drift less than 1.0% absolute radiation change per 6 months
Table B–2. 9701/9702 ion chamber detector specifications

Power supply 115/230 Vac ±10%, 50/60 Hz, 500 VA
Operating temperature range -30°C to +60°C (-20°F to +140°F)
Approvals Non-explosion proof (9701):
NEMA 4, Type 4
Explosion proof (9702):
Class I, Div. 1, Groups B, C, D
Class II, Div. 1, Groups E, F, G
Class III
NEMA 4, Type 4
Dimensions Non-explosion proof (9701):
~8 in diameter x 15.5 in tall
(200 mm diameter x 400 mm tall)
Explosion proof (9702):
~8 in diameter x 19.5 in tall
Weight Non-explosion proof (9701): 58 lb (26.3 kg)
Explosion proof (9702): 100 lb (45.4 kg)
Thermo Fisher Scientific DensityPRO+ Installation Guide B-1

Specifications
Table B–3. 9719B/9720B scintillation detector specifications

Power options 24 Vdc ± 20%, 12 VA, at detector input
115/230 Vac ±15%, 50/60 Hz, 12 VA
Operating temperature -30°C to +60°C (-20°F to +140°F)
range
Approvals Non-explosion proof (9719B):
Class III, Div. 1
NEMA 4, Type 4
Explosion proof (9720B):
Class I, Div. 1, Groups B, C, D
Class II, Div 1, Groups E, F, G
Class III
NEMA 4, Type 4
CE-ATEX
II 2 G Ex d IIC T5 Gb
CE-EMC compliance contingent upon installation of EMC
protection kit as illustrated on drawing 880100.
Dimensions Non-explosion proof (9719B):
~6.5 in diameter x 14 in tall
Explosion proof (9720B):
~6.5 in diameter x 15 in tall
Wiring entry (2) 3/4 NPT female conduit ports.
Use only suitably approved cable glands and blanking
plugs.
CE-EMC surge protection CE-ATEX
board junction box II 2 G Ex d IIC T6 Gb
-40°C<=Ta<=60°C
Warning: Do not open when an explosive
atmosphere may be present.
B-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Specifications
Table B–4. 1400A transmitter specifications

Power options 24 Vdc input (20–28 Vdc), 12 VA
115/230 Vac input (100–240 Vac), 50/60 Hz, 25 VA
Approvals Non-explosion proof (plastic enclosure):
Class I, Div. 2, Groups A, B, C, D
Class III
NEMA 4X, Type 4X
Explosion proof enclosure:
Class I, Div. 1, Groups C, D
Class III
NEMA 4 / 7, Type 4 / 7
Dimensions Non-explosion proof (plastic enclosure):
12 x 8.5 x 8.25 in
(305 x 216 x 210 mm)
Explosion proof enclosure:
14 x 15.5 x 10.5 in
(356 x 394 x 267 mm)
Weight Non-explosion proof (plastic enclosure): 7.5 lb (3.4 kg)
Explosion proof: 60 lb (27.2 kg)
Circuit protection Meets IEC 801-1, -2, and -3
Current outputs and relay outputs are isolated
Display Four-line backlit display; up to eight readouts displayed
simultaneously
Serial interface RS232, full duplex communication with remote terminal,
printer, PC, or host computer
Optional RS485, half-duplex party-line communication to
host computer or HHT
Current output One standard with two additional optionally available
Standard configuration: Isolated, self-powered, 700-ohm
maximum load
Alternate configuration: Isolated, loop-powered, 24 Vdc
nominal supply voltage, 800-ohm maximum load
Contact closure inputs Two per I/O board
Relays Two optional per I/O board; six maximum. Form C SPDT,
isolated 8 A, 220 Vac
Thermo Fisher Scientific DensityPRO+ Installation Guide B-3

Specifications
Table B–5. 1400S transmitter

Power options 24 Vdc (20–28 Vdc), 12 VA
115/230 Vac (100–240 Vac), 50/60 Hz, 12 VA
Approvals NEMA 4X / IP65
ATEX
II 3 G Ex nA IIC T6 (-40°C ≤ Ta ≤ 60°C) DC version,
EPSILON 08
ATEX 2387: II 3 G Ex nA nC IIC T4 (-20°C ≤ Ta ≤ 50°C)
AC version, EPSILON 08 ATEX 2387
CSA
Class I, Div. 2, Groups A, B, C, and D; Class II, Div. 2,
Groups F and G; Class III Enclosure type 4X,
Temperature code T3C / T4
CE compliant
Low Voltage Directive compliant
EMC Directive compliant
Dimensions See drawing 208-140002.
Display Four-line backlit display; up to eight readouts displayed
simultaneously
Serial outputs RS232 full duplex
RS485 half-duplex
Current output One standard with two additional optionally available
Standard configuration: Isolated, self-powered, 800-ohm
maximum load
Alternate configuration: Isolated, loop-powered, 24 Vdc
nominal supply voltage, 800-ohm maximum load
Contact closure inputs Two per I/O board
B-4 DensityPRO+ Installation Guide Thermo Fisher Scientific

Appendix C
Drawings
Note Information presented in this chapter has been regenerated from
original drawings. Every effort is made to maintain document accuracy.
However, in order to enhance legibility, the documents may have been
restructured, and some information may have been intentionally excluded.
Therefore, the drawings within this guide may not be an exact duplicate of
the original drawings. ▲
Note Drawings in this manual are included for reference only and may not
be the current version. Contact the factory if you need a copy of the latest
revision. ▲
Table C–1. Installation layout & wiring diagrams

Drawing # Rev. Description Page
868695 A Installation layout, 1400A transmitter to 9719B, 9720B, C–4
9701, 9702 detectors (2 sheets)
868577 D Installation wiring, 9719B/9720B scintillation detectors to C–6
1400A transmitter (3 sheets)
868680-2 B Installation wiring, 1400A/1400S transmitter (3 sheets) C–9
868697 A Installation wiring, 9701/9702 ion chamber detectors to C–12
1400A transmitter (1 sheet)
868519 B RS485 installation and wiring (1 sheet) C–13
Table C–2. Transmitter dimensional drawings

868212 F 1400A transmitter dimensional diagram, NEMA 4X C–14
enclosure (2 sheets)
868214 D 1400A transmitter dimensional diagram, NEMA 4/NEMA C–16
7 enclosure (1 sheet)
208-140002 A 1400S transmitter dimensional diagram (1 sheet) C–17
Thermo Fisher Scientific DensityPRO+ Installation Guide C-1

Drawings
Table C–3. Detector dimensional drawings

867468 B Installation drawing, detector assembly, flat mount, C–18
NEMA 4 housing (2 sheets)
867469 B Installation drawing, detector assembly, flat mount, C–20
explosion proof housing (2 sheets)
866777 -- Mounting dimensions, 9702 ion chamber detector, C–22
explosion proof housing (1 sheet)
866778 -- Mounting dimensions, 9701 ion chamber detector, NEMA C–23
4 housing (1 sheet)
Table C–4. Source housing dimensional drawings

864563 B Mounting dimensions – 5200 source housing, 100 mCi or C–24
less (1 sheet)
865453 C Mounting dimensions – 5201 source housing, 100 mCi or C–25
less (1 sheet)
865463 D Mounting dimensions – 5202 source housing, 500 mCi or C–26
less (1 sheet)
less (2 sheets)
less (2 sheets)
Table C–5. Gauge head installation drawings

867466 B Installation drawing, gauge head, two-chain mount, NEMA C–31
4 housing (3 sheets)
867467 B Installation drawing, gauge head, two-chain mount, C–34
explosion proof housing (3 sheets)
867172 A Installation drawing, gauge head, two-chain mount, C–37
9701/9702 ion chamber detector (1 sheet)
C-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Drawings
Table C–5. Gauge head installation drawings, cont.

85726N E Installation drawing, gauge head, pipe saddle mount (1 C–38
sheet)
861104 C Fabrication details, 1” to 3” Z-pipe section (2 sheets) C–39
866670 B Mounting dimensions, 1” to 3” Z-pipe mount (1 sheet) C–41
864163 A Fabrication details, 4” Z-pipe section (1 sheet) C–42
866705 A Mounting dimensions, 4” Z-pipe mount (1 sheet) C–43
Table C–6. Source housing options

866666 E Mounting instructions, remote manual actuator for 5201 – C–44
5204 source housings (2 sheets)

Drawings
Figure C–1. 868695: Installation layout, 1400A transmitter to 9719B, 9720B, 9701, 9702
detectors (sheet 1 of 2)

Drawings
Figure C–2. 868695: Installation layout, 1400A transmitter to 9719B, 9720B,

9701, 9702 detectors (sheet 2 of 2)

Drawings
Figure C–3. 868577: Installation wiring, 9719B/9720B scintillation detectors to 1400A transmitter
(sheet 1 of 3)

Drawings
Figure C–4. 868577: Installation wiring, 9719B/9720B scintillation detectors to 1400A transmitter
(sheet 2 of 3)

Drawings
Figure C–5. 868577: Installation wiring, 9719B/9720B scintillation detectors to

1400A transmitter (sheet 3 of 3)

Drawings
Figure C–6. 868680-2: Installation wiring, 1400A/1400S transmitter (sheet 1 of

3)

Drawings
Figure C–7. 868680-2: Installation wiring, 1400A/1400S transmitter (sheet 2 of 3)

Drawings
Figure C–8. 868680-2: Installation wiring, 1400A/1400S transmitter (sheet 3 of 3)

Drawings
Figure C–9. 868697: Installation wiring, 9701/9702 ion chamber detectors to

1400A transmitter (sheet 1 of 1)

Drawings
Figure C–10. 868519: Optional RS485 installation and wiring (sheet 1 of 1)

Drawings
Figure C–11. 868212: 1400A transmitter dimensional diagram, NEMA 4X enclosure (sheet 1 of 2)

Drawings
Figure C–12. 868212: 1400A transmitter dimensional diagram, NEMA 4X

enclosure

Drawings
Figure C–13. 868214: 1400A transmitter dimensional diagram, NEMA 4 /

NEMA 7 enclosure (sheet 1 of 1)

Drawings
Figure C–14. 208-140002: 1400S transmitter dimension diagram (sheet 1 of 1)

Drawings
Figure C–15. 867468: Installation drawing, detector assembly, flat mount, NEMA 4 housing
(sheet 1 of 2)

Drawings
Figure C–16. 867468: Installation drawing, detector assembly, flat mount, NEMA 4
housing (sheet 2 of 2)

Drawings
Figure C–17. 867469: Installation drawing, detector assembly, flat mount, explosion proof housing
(sheet 1 of 2)

Drawings
Figure C–18. 867469: Installation drawing, detector assembly, flat mount, explosion proof
housing (sheet 2 of 2)

Drawings
Figure C–19. 866777: Mounting dimensions, 9702 ion chamber detector, explosion proof housing
(sheet 1 of 1)

Drawings
Figure C–20. 866778: Mounting dimensions, 9701 ion chamber detector, NEMA 4 housing
(sheet 1 of 1)

Drawings
Figure C–21. 864563: Mounting dimensions – 5200 source housing, 100 mCi or less (sheet 1 of 1)

Drawings
Figure C–22. 865453: Mounting dimensions – Model 5201 source housing, 100 mCi or less (sheet 1 of 1)

Drawings
Figure C–23. 865463: Mounting dimensions – Model 5202 source housing, 500 mCi or less (sheet 1 of 1)

Drawings
Figure C–24. 865474: Mounting dimensions – Model 5203 source housing,

2000 mCi or less (sheet 1 of 2)

Drawings


Drawings


Drawings


Drawings
Figure C–28. 867466: Installation drawing, gauge head, single chain mount, explosion proof housing
(sheet 1 of 3)

Drawings
Figure C–29. 867466: Installation drawing, gauge head, single chain mount,
explosion proof housing (sheet 2 of 3)

Drawings
Figure C–30. 867466: Installation drawing, gauge head, single chain mount,

Drawings
Figure C–31. 867467: Installation drawing, gauge head, two-chain mount, explosion proof housing
(sheet 1 of 3)

Drawings
Figure C–32. 867467: Installation drawing, gauge head, two-chain mount,


Drawings


Drawings

9701/9702 ion chamber detector (sheet 1 of 1)

Drawings
Figure C–35. 85726N: Installation drawing, gauge head, pipe saddle mount (sheet 1 of 1)

Drawings
Figure C–36. 861104: Fabrication details, 1” to 3” Z-pipe section (sheet 1 of 2)

Drawings
Figure C–37. 861104: Fabrication details, 1” to 3” Z-pipe section (sheet 2 of 2)

Drawings
Figure C–38. 866670: Mounting dimensions, 1” to 3” Z-pipe mount (sheet 1 of 1)

Drawings
Figure C–39. 864163: Fabrication details, 4” Z-pipe section (sheet 1 of 1)

Drawings
Figure C–40. 866705: Mounting dimensions, 4” Z-pipe mount (sheet 1 of 1)

Drawings
Figure C–41. 866666: Mounting instructions, remote manual actuator for 5201 – 5204
source housings (sheet 1 of 2)

Drawings
Figure C–42. 866666: Mounting instructions, remote manual actuator for 5201 – 5204 source
housings (sheet 2 of 2)

Appendix D
Adding Ferrite Clamps to 1400S
Transmitter
Note The ferrite clamps are only used in the ATEX version of the 1400S
transmitter. They are not required for the CSA version or the plastic 1400A
transmitter. If needed, the ferrite clamps kit may be ordered separately. ▲
In order for the 1400S transmitter to meet electromagnetic emission

requirements for CE-EMC approvals, ferrite clamps must be installed
within the transmitter enclosure on all power and signal wiring going into
and out of the transmitter housing.
Procedure The ferrite clamp is part of the EMC ferrite clamps kit (p/n 868773). The
kit consists of the following:
● Five ferrite clamps (p/n 5-2720-007)
● At least one clamp “key”
● The procedure
The clamp key is used to remove the ferrite clamp from the wire during
wiring changes.
Figure D–1. Ferrite clamps

A ferrite clamp will need to be installed on all wiring that enters or exits the
transmitter enclosure. This may be a shielded twisted pair or a bundle of
individual wires. The limitation is that the wires through one clamp cannot
exceed 5 mm in diameter. Also, all of the clamps MUST be installed within
the enclosure.
Thermo Fisher Scientific DensityPRO+ Installation Guide D-1

Adding Ferrite Clamps to 1400S Transmitter
Procedure
Figure D–2. Ferrite clamps installed within enclosure

As shown in Figure D–2 the ferrite clamp can be placed around a shielded
twisted pair cable or a bundle of individual cables, as long as the diameter
of the bundle does not exceed 5 mm (a little over 3/16”).
The ferrite clamp kit (p/n 868773) contains five clamps. Depending on
your wiring scheme, you may need additional clamps. They can be ordered
using part number 5-2720-007.
For example, in a Thermo Scientific DensityPRO+ system with a
scintillation detector, flow input, and three outputs, there will be eight
shielded twisted pair cables and one power cable. This system would
require a total of nine ferrite clamps. So you would need either two kits or
one kit and four additional clamps to be EMC compliant.
Note All ATEX version 1400S transmitters shipped after August 2009 will
contain one ferrite clamp kit and will have one ferrite clamp installed on
the AC voltage input wiring. ▲
Note If the locking mechanism of the clamp should fail, a plastic wire tie
can be used to secure the clamp around the wire. ▲
D-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Index
ordering information, A-1
1 specifications, B-2
signal wiring, 4-11–4-12
1400A. See transmitter.
DOT. See Department of Transportion.
1400S. See transmitter.
C E
Canadian Nuclear Safety Commission (CNSC), 2-2, 3-2 electrostatic discharge (ESD), 2-1–2-2
Canadian Standards Association (CSA), 4-10 EMC requirement for ATEX 1400S transmitter, 4-5, D-1–D-2
CNSC. See Canadian Nuclear Safety Commission. ESD. See electrostatic discharge.
commissioning, 3-2
communications F
HART, 4-15 ferrite clamps
wiring EMC requirement for ATEX 1400S transmitter, 4-5, D-1–
optional RS485, 4-14 D-2
RS232, 4-14 flow input, 4-13
contact closure inputs, 4-6, 4-13, B-3, B-4
contact information, 5-1 G
CSA. See Canadian Standards Association. gauge head, 3-1, Also see detector., Also see source.
current outputs, 4-6, 4-12, B-3, B-4 mounting, 3-7
D H
Department of Transportation (DOT), 2-2 handling the instrument, 2-1–2-2
detector, 3-1 HART communications, 4-15
general wiring procedure
ion chamber detectors, 4-4–4-5 I
scintillation detectors, 4-2–4-3
installation
installation, 3-7–3-14
drawings, C-1–C-45
guidelines, 3-2–3-3
gauge head, 3-7–3-14
ion chamber
ordering information, A-1
in hazardous areas, 3-2, 3-4, 4-2
specifications, B-1
transmitter, 3-5–3-6
jumper setting for detector type selection, 4-7
installing
operating temperature range, 3-2
drawings for, C-1–C-45
power options, 3-3
guidelines for, 3-2–3-3
power supply wiring
in hazardous areas, 3-2, 3-4, 4-2
ion chamber detector, 4-9
the gauge head, 3-7–3-14
scintillation detector, 4-7–4-8
the transmitter, 3-5–3-6
scintillation
ion chamber detector. See detector.
Thermo Fisher Scientific DensityPRO+ Installation Guide INDEX-1

Index
J S
jumper settings safety, ix–x, 2-2, 3-2, 3-4, 3-7, 4-1
for detector type selection, 4-7 scintillation detector. See detector.
for duty cycle mode, 4-12 serial communications, 4-13–4-14
shipping the instrument, 2-2
L source, 3-1
installation, 3-7–3-14
licensing, 3-2
source head. See source.
M
source housing. See source.
mounting specifications, B-1–B-4
dual chain configuration, 3-9–3-12 storing the instrument, 2-2
gauge head, 3-7–3-14
pipe saddle configuration, 3-12
T
pipe spool configuration, 3-14
temperature compensation, 4-13
transmitter, 3-1
N
1400A ordering information, A-1
National Electric Code (NEC), 4-1, 4-2
1400A specifications, B-3
NEC. See National Electric Code., See National Electric Code.
1400S
EMC requirement for ATEX units, 4-5, D-1–D-2
O 1400S ordering information, A-2
ordering information 1400S specifications, B-4
1400A transmitter, A-1 AC power supply installation, 3-6
1400S transmitter, A-2 general wiring procedure, 4-6–4-7
ion chamber detector, A-1 installation, 3-5–3-6
scintillation detector, A-1 guidelines, 3-2–3-3
operating temperature range, 3-2
P PCB installation, 3-5
power power options, 3-3
options, 3-3 power supply wiring, 4-10
supply wiring
ion chamber detector, 4-9 W
scintillation detector, 4-7–4-8 wiring
transmitter, 4-10 detector signals, 4-11–4-12
EMC requirement for ATEX 1400S transmitter, 4-5, D-1–
R D-2
general procedure
receiving the instrument, 2-2
ion chamber detectors, 4-4–4-5
relay, 4-12
scintillation detectors, 4-2–4-3
relay contacts, 4-6
transmitters, 4-6–4-7
RS232 serial port, 4-6, 4-13
in hazardous areas, 4-1
RS485 serial port option, 4-6, 4-13
INDEX-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Index
options power
contact closure inputs, 4-13 to ion chamber detector, 4-9
current output, 4-12 to scintillation detector, 4-7–4-8
flow input, 4-13 to transmitter, 4-10
relay contacts, 4-12 preparation, 4-1–4-2
temperature compensation, 4-13 serial communications, 4-13–4-14
Thermo Fisher Scientific DensityPRO+ Installation Guide INDEX-3

Thermo Fisher Scientific
81 Wyman Street
P.O. Box 9046
Waltham, Massachusetts 02454-9046
United States
www.thermofisher.com

User Manual

Uploaded by

Copyright:

Available Formats

You might also like

User Manual

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

User Manual

Uploaded by

Copyright:

Available Formats

DensityPRO+

Gamma Density System with Remote Transmitter

Part of Thermo Fisher Scientific

Thermo Fisher Scientific DensityPRO+ Installation Guide v

Chapter 1 Introduction........................................................................................................ 1-1

Chapter 2 Handling & Storage .......................................................................................... 2-1

Chapter 3 Installation ......................................................................................................... 3-1

Chapter 4 Wiring.................................................................................................................. 4-1

Thermo Fisher Scientific DensityPRO+ Installation Guide vii

DC Power ..................................................................................... 4-7

Chapter 5 Getting Help........................................................................................................5-1

Appendix A Ordering Information .......................................................................................A-1

Appendix C Drawings............................................................................................................ C-1

Appendix D Adding Ferrite Clamps to 1400S Transmitter ..............................................D-1

viii DensityPRO+ Installation Guide Thermo Fisher Scientific

Safety Failure to follow appropriate safety procedures or inappropriate use of the

Warning Warnings notify users of procedures, practices, conditions, etc.

Thermo Fisher Scientific DensityPRO+ Installation Guide ix

Caution Cautions notify users of operating procedures, practices,

Note Notes emphasize important or essential information or a statement of

x DensityPRO+ Installation Guide Thermo Fisher Scientific

Thermo Fisher Scientific DensityPRO+ Installation Guide 1-1

Caution This system is an ESD sensitive instrument. Use proper ESD

Caution Do not touch the circuit board components. ▲

Observe the following when installing, setting up, servicing,

1. Use an antistatic bag. Most instrument subassemblies are shipped in a

2. Remove ESD sensitive subassemblies only under the following

3. Personnel handling ESD sensitive devices should be neutralized to a

Thermo Fisher Scientific DensityPRO+ Installation Guide 2-1

4. Do not allow clothing to make contact with ESD sensitive devices.

5. Avoid touching edge connectors and components.

6. Avoid partially connecting ESD sensitive devices. These devices,

7. Ground test equipment.

8. Avoid static charges during troubleshooting.

Unpacking, All personnel involved in the packing, shipping, or receiving of hazardous

Note Inspection, adjustment, installation, and maintenance of the

2. Carefully inspect the packing material prior to discarding it to ensure

4. If storing the instrument, the storage environment should be protected,

2-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Tip Copies of the drawings referenced in this manual are provided in

1. One of the following transmitter models:

2. One of the following detector models:

3. One of the following source head models:

Note In this manual, the generic use of “transmitter” or “transmitters”

Thermo Fisher Scientific DensityPRO+ Installation Guide 3-1

Warning Moving or removing an installed source housing or any assembly

Warning Do not apply power to the instrument in any hazardous area

1. Correct power source is available. See “Power Options” later in this

2. Operating temperature range:

3-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

3. The transmitter should be mounted so that the display is easily seen

4. The transmitter should not be mounted near high voltage, high

6. The source housing should be positioned so that the radioactive source

7. The gauge should not be mounted where process overflow or other

Power Options 1400A/1400S transmitters

Thermo Fisher Scientific DensityPRO+ Installation Guide 3-3

Warning Use proper lifting procedures during installation to avoid

Refer to the proper dimensional drawing for the transmitter mounting

3-4 DensityPRO+ Installation Guide Thermo Fisher Scientific
