FLUID MECHANICS

For Mechanical, Production, Chemical, Civil, Electrical,

Marine, Aeronautics & Instrumentaion Engineering

TM

B.S.PYROMATIC INDIA (P) LTD.,

AN ISO 9001 - 2000 CERTIFIED COMPANY
 TM

META CENTRIC HEIGHT APPARATUS BSPIL-FML-L-20000

Specification:
wCopper Sheet Vessel 350x350mm is provided with device for loading on different
points corresponding to the keel. The bridge is graduated in degree is provided for
measuring the angle of inclination the unit is complete with clamping screw and two
sets of brass slotted weights of 10gms.
wSump tank for the above apparatus a 40 Liter capacity steel tank is provided with
drain cock and is transparent window marked in cms.
wTotal Weight: 20 Kg.
wDimension: 40 x 40 cm sump tank.
FLOW THROUGH NOTCHES - BSPIL-FML-L-20001

Specification:

 M.S. Notch tank capacity of 40 Liters. having steadying arrangement with

baffle and provision for fixing interchangeable notch plates. A set of different sharp
edged notches
 Rectangular notch 100mmPipe system with 2 G.I. Pipe lines of size 15mm
and
 Triangular notch 60mm
 Hook gauge with provision for mounting.
 M.S. measuring and collecting tank of size 40Lts. Capacity provided with
gauge glass scale arrangement and drain valve.
 Total weight: 75 kg Approximately.
 Space needed: 3 x .3 x 3 Ms

FLOW THROUGH ORIFICE AND MOUTH PIECES CV,CD,CC,OF ORIFICE

& CD OF MOUTHPIECE - BSPIL-FML-L-20002
PURPOSE: This equipment is designed for determination of co-efficient of discharge of
orifice & mouthpiece.
DESCRIPTION: This is recirculation type equipment and is complete by itself. It
consists of a Sump tank, Collecting Tank, Measuring Tank and Monoblock Pump
etc., suitably mounted on a sturdy base frame. Necessary instruments for
measuring X-Y co-ordinates, stop clock etc. are provided. In order to prevent rusting
of the tanks, we have provided Sump Tank and Measuring Tank made up of
M.S.Sheet lined with Fibreglass. The Set-Up is very compact and can be easily
moved around the lab. And also the space required is very less as compared to
conventional setups.
Specification:
1. Set of Orifice : 10mm & 15mm (Acrylic)
2. Set of Mouth piece : Dia. 10mm, L/D 2.5 & 4 (Brass)
FLUID MECHANICS

3. Sump Tank : Capacity 150 ltrs. Material M.S.Sheet with F.R.P. lining
from inside for prevention of rusting.
4. Collecting Tank : Capacity 100 ltrs. Material M.S.Sheet with F.R.P. lining from
inside for preventing of rusting. Stand for mounting the
collecting tank.
5. Measuring Tank : Capacity 40 ltrs Material M.S.Sheet with F.R.P. lining from inside
for prevention of rusting. Piezometric Glass Tube for flow
measurement.
6. Monoblock Pump : Capacity 0.5 HP, Single Phase, 230 V. with required
bye-pass valve and suction piping.
7. Flexible Hose Pipe for connecting the basic unit to the Sump Tank.
8. Control valve for controlling the flow rate.
9. Stop clock.
10.Scale X-Y co-ordinate measuring arrangement.
11. A base frame made up of sturdy M.S. Angles.
12.Weights : 80 Kg (Approximately)
13.Dimension : 4 x .4 x 3 m.

FLOW THROUGH PIPES, MINOR LOSSES DUE TO SUDDEN

EXPANSION, SUDDEN CONTRACTION,BENDS AND ELBOWS 15 & 20
MM PIPES. - BSPIL-FML-L-20003
a. Piping system with 2 G.I. Pipe line 15mm and 20mm dia, fitted with a device for quick
and easy change over and a pressure tappings to any points through separate lines
 TM
having isolating valves and flow control valves. One pipe line consisting of pipes and one
bend, one elbow, and one sudden contraction and one sudden enlargement
arrangement.
b. Differential manometer 1m length for the measurement of loss in head, supplied with
mercury.
c. Fibre glass line M.S. Measuring tank of size 300x300x500mm height to measure the
discharge water from the unit, provided with a gauge glass, scale arrangement and a drain
valve.
d. Fibre glass line M.S.Sump 2000x300x300mm height to store sufficient water for
independent circulation through the unit for experimentation and arranged within the floor
space of the main unit.
e. Supply pump set of 0.5HP capacity to pump water from the sump to store the unit through
proper piping system with a gate valve to control the rate of flow, and connected with a DP
switch.
f. Rigid M.S.Frame work compactly fitted with all the above items as self sufficient package
unit, suitable for operation without any foundation.
g. Space needed: 4 x .3 x 3 M
h. Total weight: 75 kg Approximately.

PIPE FRICTION APPARATUS WITH 15 AND 20 MM PIECE -

BSPIL-FML-L-20004
Specification:
 Pipe system consisting of 3 GI pipe Lines of size 15mm, 20mm
and 25mm dia fitted with a device for quick and easy change over for a
pressure tapings to any through separate lines having isolating valves and
flow control valves.Each pipe line with tapings 3 meters discharge to
determine the pipe friction loss through Darcy's Co-efficiency.
 Differential manometer 1000 mm length for the measurement of
loss in head, supplied with mercury. Fiber Glass lined M.S. Measuring
tank of size 150 Liters Capacity to measure the discharge water from the
unit, provided with a gauge glass, scale arrangement and drain valve.
 Fiber glass lined M.S sump 2000x300x300mm height to store
sufficient water for independent circulation through the unit for
experimentation and arranged within the floor space of the main unit.
 Supply of pump set of Capacity 0.5 HP capacity to pump water
from the sump to store the unit through proper system with a gate valve to
control the rate of flow, and connected to with a DP Switch.
 Rigid MS frame work compactly fitted with all the above items as
self sufficient package unit, suitable for operation without any foundation
[Closed Circuit]
 Stop Watch
 Alternatively the above said test rig with open circuit
(Conventional Model) without
 Heavy duty polymer trolley wheels (4Nos) with screw jack
arrangement for shifting
FLUID MECHANICS

 Space Needs: 3.5m x 0.5 m x 2 m height

 Weights: 75 kg.

COMBINED UNIT OF PIPE FRICTION IN 15MM & 20MM PIPE AND MINOR
LOSSES IN 15 MM PIPE - BSPIL-FML-M-20005
CALIBRATION TEST RIG FOR VENTURIMETER 25MM & 40 MM - BSPIL-
FML-L-20006
Specification:
a . A venturimeter of size 25mm inlet dial fitted on a pipeline control valve with a sturdy iron
stand for mounting the unit.
b. Differential Manometer 1m length for the measurement of differential head, supplied with
` mercury
c. M.S. collecting tank of size 0.3x0.3x0.5m height provided with a gauge glass, scale
arrangement and a drain valve.
d. Total weight: 75 kg approximately
e. Over All dimension: 4 x .3 x 3 M

CALIBRATION TEST RIG FOR ORIFICE METER 25MM & 40 MM

- BSPIL-FML-L-20007

Specification:
Orifice meter made of gunmetal inlet dia fitted on a pipeline and control valve.
a. Differential manometer 1 m length for the measurement of differential head, supplied with
mercury
 TM
b. Fiber Glass lined M.S measuring tank to measure the discharge water from the unit
provided with a gauge glass scale arrangement and a drain valve
c. Fiberglass lined M.S sump to store sufficient water for independent circulation through the
unit for experimentation and arranged with in the floor space of the main unit.
Water Over Flow Provision to Maintain Standard Head is provided with the system Piezo
Meter tube is provided along with the system
d. Supply of pump set of 0.5 HP to pump water from the sump to store the unit through proper
piping system with a gate valve to control the rate of flow, and connected with a DP switch.
e. Rigid M.S Frame work compactly fitted with all the above items as self-sufficient package
unit, suitable for operation without any foundation.
f. Total dimension: 5 x .4 x 4 M
g. Weights: 70 kg approximately .
COMBINED UNIT OF VENTURIMETER 40 MM AND ORIFICEMETER-25MM
CODE BSPIL-FML-L-20008-CODE BSPIL-FML-M-20008

Specification:
Venturimeter of size 25mm made of gunmetal inlet dia fitted on a pipeline and control
valve.
a. Differential manometer 1 m length for the measurement of differential head, supplied with
mercury
b. Fiber Glass lined M.S measuring tank to measure the discharge water from the unit
provided with a gauge glass scale arrangement and a drain valve
c. Fiberglass lined M.S sump of to store sufficient water for independent circulation through
the unit for experimentation and arranged with in the floor space of the main unit.
d. Supply of pump set of 0.5 HP 25mm size to pump water from the sump to store the unit
through proper piping system with a gate valve to control the rate of flow, and connected
with a DP switch.
e. Rigid M.S Frame work compactly fitted with all the above items as self-sufficient package
unit, suitable for operation without any foundation.
f. Space needed : 4 x .3 x 3 M
g. Total weight : 65 kg .

BERNOULLI'S THEOREM - BSPIL-FML-L-20009

Specification:
 Supply and receiving chamber with scale and glass tube Fittings for the
measurement of total potential head, an Interlinking duct and made of the thick
transparence Perspex sheet and of smooth variable cross section glass tubes to measure
the pressure head along the duct, and a control valve.
 Strong iron stands for supporting the equipments.
 M.S. Collecting tank of size 0.03x0.3x0.6m gauge glass and scale fitting and a
drain valve.
 Dimension: 3 x .5 x 3 M
 Weight : 70 kg approximately.
FLUID MECHANICS

REYNOLDS'S APPARATUS- BSPIL-FML-L-20010

Specification:
 Supply tank of size 0.3x0.3x0.6m height with a small tank for supply of colored
liquid a transparent pipe of suitable length for flow observation with control valve.
 M.S. collecting tank of size 0.2x0.2x0.5M with a drain valve glass tube and scale
fitting.
 Total weight: 30 kg
 Dimension: .7 x .7 x 2 M

CALIBRATION TEST RIG FOR ROTA METER

CODE BSPIL-FML-L-20011-CODE BSPIL-FML-M-20011

Specification:
This equipment consist with 2 graduated tanks and a motor to pump the water from
bottom tank to the top tank which is totally housed in a column stand which will enable
the student to study the flow rate of given liquid and the quantity of the liquid pumped in
the top tank and reduction of quantity from the bottom tank and see the actual flow
through the Rotometer and compare the quantity of the flow in the top tank which is
graduated and check the timing with the digital timer and the timer also facilitate auto
shut-off of motor which will avoid air block to conduct the subsequent tests also a valve is
provided to drain the pumped water to bring back
 TM
to the bottom tank through gravity force which will enable the student to have the second test
cycle and so on.

CALIBRATION TEST RIG FOR PITOT TUBE - BSPIL-FML-M-20012

Specification:

 A 25mm dia pipe with prandle pitot tube arrangement with strong iron stand for
mounting a unit.
 A differential mercury manometer of suitable 1-meter range.
 Measuring tank made of mild steel of size 0.3x0.3x0.5m.
 Total weights: 45 kg.
 Dimension :2.5 x .7 x 3 M

CENTRIFUGAL BLOWER - BSPIL-FML-L-20013

Specification:
Suitable for experiments of interchangeable impellers of backward, radial and forward curved vanes so
that the effect of different type of blading could be well demonstration. The
approximate discharge of air is 20-m3 meter per minute at a pressure of 20cm of
water column. One orifice meter and a differential manometer of 0.5m heights to
measure the discharge.
a. A differential manometer 0.5m height with connecting plastic tubes to
determine the total pressure developed.
b, 2 numbers of pitot tubes mounted at the inlet duct and outlet
c. 2 numbers of differential manometers of 0.5m height
d. 2 thermometers fitted at the inlet and outlet
e. The blower is directly coupled to an induction motor of 3 HP speed 2880 RPM.
To determine the
f. input power by energy meter.
g. Outlet pipe of 3m total lengths. A sluice valve with flanges to control the discharge. Suitable
stands to hold the pipe.

EXPERIMENTAL BLOWER TEST RIG - BSPIL-FML-M-20013

Specification:

 Centrifugal Single Stage Blower Supported by a raised base Plate. 7.5 HP, 3 Phase
motor running at approximately 2800 RPM with starter switch.
3
 Approximately discharge of 50 m per minute.
 Discharge measured using veturimeter of suitable range, pressure and velocity
traverse using Pitot tube (2 Nos.). Power input to the blower measured using energy
meter and calibration chart. Pressure difference across blower measured by water
manometer. Temperature rise across the blower measured by mercury in glass
precision thermometer or temperature indicator.
 Space needed: 3 x .5 x 3 M
FLUID MECHANICS

TWO STAGE TWIN CYLINDER AIR COMPRESSOR TEST RIG (SWING

FIELD DYNAMOMETER)- BSPIL-FML-L-20014
Specification:
 Two stage twin cylinder air compressor with a displacement of about 300 LPM and to
work against a maximum pressure of 12kg/sq.cm with a large capacity storage tank.
 MOTOR: 3 HP 3 phase 440 V motor (ISI) converted a trunion mounted.
 Electrical dynamometer with a torque arm, spring balance and a dash pot.
 The unit is supplied with pressure switch, safety valve, pressure gauge, shut of valve,
pressure release valve, water drain valve etc.,
 To determine the input power an energy meter is supplied.
 A large capacity MS air tank an orifice plate with a U tube manometer is used to flow
measurement of air with sturdy iron stand.
 CONTROLS; A receiver fitted with a drain cock and an automatic pressure switch,
suction filter, pressure safety valve non return valve.
 DIGITAL TEMPERATURE INDICATOR: Multi channel temperature indicator with
thermocouples are provided to measure the temperatures of air at various points of the
test rigs.
 TEMPERATURE MEASUREMENT: To measure suction and delivery side temperature
of the compressor
 ELECTRICALS: ISI starter and NON ISI main switch.
 Total weights: 240 Kg approximately.
 Foundation dimension: 4 x 1 M
 TM

TWO STAGE TWIN CYLINDER AIR COMPRESSOR TEST RIG

- BSPIL-FML-M-20014
Specification:

 Two Stage Single acting reciprocating Air Compressor, Twin Cylinder

with inter cooler air-Cooled type, approximate maximum working
pressure 14 Kgf/cm2 with storage tank of approximate capacity 175 Liters.

 Induction motor of 5 HP running at approximately 1400 RPM with electric

dynamometer (fitted with torque arm and Spring Balance), energy meter,
starter switch, pressure relief valve, air deliver valve, intake air filter,
incoming air flow measuring arrangement by orifice meter and differential
manometer, digital temperature indicator and pressure gauges for
measuring pressure at each stage.

TO DETERMINE THE METACENTRIC HEIGHT OF A FLOATING VESSEL

UNDER LOADED AND UNLOADED CONDITIONS. - BSPIL-FML-M-20015

Specification:

 This system is designed to find out the met centric height of the given float.
 A tank of size 300x 300 x 400mm comes with float of 0.5 kg (approximate) is used for
experimentation. Very simple and easy procedure is used to measure the fluid
displacement, the float is designed to accept variable weights to conduct test.

TO DETERMINE THE CO EFFICIENT OF DISCHARGE FOR AN

OBSTRUCTION FLOW METER (VENTURI METER/ ORIFICE METER)
VENTURIMETER TEST RIG CLOSED CIRCUIT- BSPIL-FML-M-20016

Specification:

 A venturimeter of size 25mm inlet dial fitted on a pipeline control valve with a sturdy iron
stand for mounting the unit.
 Differential Manometer 1m length for the measurement of differential head, supplied with
mercury.
 M.S. collecting tank of size 0.3x0.3x0.5m height provided with a gauge glass, scale
` arrangement and a drain valve.
FLUID MECHANICS

We do manufacture and deal other mechanical labs such as : Imaging, Metallurgy, Dynamics, Metrology,
Thermal, Biotechnology, Refrigeration & Air Condition, Heat Transfer, Foundry,Non Destructive Testing,
Strength Of Materials, Workshop.
Above Specifications are indicative and may have variations as per Current R&D
Marketed by
TM B.S.PYROMATIC INDIA (P) LTD.,

P.B.No.6033,27/1,XII Avenue,
Ashok Nagar,Chennai-600 083.INDIA.
Phone : 091-44-24890009 / 24890710. Fax: 091-44-24897880
E-Mail: pyromat@satyam.net.in. Websites : www.bspyromatic.com.
