Ace 2014

Premium Quality - Value Price
ACE Enclosures
A
ACE Enclosures
Product overview
A Industrial steel enclosures
A-1 Junction boxes 1
A-2 Terminal boxes 3
A-3 Bus enclosures 5
A-4 Wall-mounting enclosures VS 9000 7
A-5 Compact free-standing enclosures VS 5000 13
A-6 Panel system enclosures VS8000 19
A-7 Extendable enclosures EP8000 27
A-8 Outdoor enclosures 65
A-9 One-piece consoles 67
A-10 Substation Kiosk enclosures 69
A-11 Customised enclosures 73
A-12 Certificates - enclosures 75
B Electrical distribution boards

B-1 SPN Consumer units 77
B-2 DIN Rail Distribution Boards 79
B-3 Circuit Breaker Enclosures 81
B-4 Busbar Enclosures 83
B-5 Combination Distribution Boards 85
B-6 Load Centres Distribution Boards IEC Type “B” - DIN mount models 87
B-7 Load Centres Distribution Boards NEMA Type “A” - Plug-in models 91
B-8 Sub Main Distribution Boards 93
B-9 Busbars 99
B-10 Certificates - Type tests. 101
C IT enclosures
C-1 FlatBox wall-mounted and floor-standing enclosure 103
C-2 Wall mount 19” rack, model E1 104
C-3 Two-section wall mount 19” enclosure, model E11 105
C-4 IP65 wall mount 19” enclosures, model E19 106
C-5 IT server flexi Rack, model E7 107
C-6 Network enclosures and boxes, based on VS7000 108
C-7 Network enclosures, based on EP8000 109
C-8 Klasik rack, model E37 113
C-9 Network Enclosures, based on VS8000 115
D Industrial Storage Equipment

D-1 Heavy duty drawer cabinets 121
D-2 Mobile cabinets 123
D-3 Heavy duty work benches 125
D-4 Tooling maintenance trolley 129
D-5 Heavy duty steel cupboards 131
D-6 Panel trolley 133
D-7 Perforated tool panel system 135
As part of our on-going product improvement , ACE Enclosures reserves the right to modify the
characteristics or the products described in this document without prior notice and assumes no
responsibility for any error which may appear in this publication.
The information given is not- contractual. For further details please contact
ACE Enclosures, Malaysia.
www.ace.net.my
A. Industrial Steel Enclosures
A-1 Junction Boxes
• Screw fixed cover boxes, without gland plate

• Cover gasketed with all-round foamed-in PU seal.
• Material: Electro galvanised steel, 1.20 mm
• Surface finish: epoxy powder-coated
RAL 7035 texture.
• Protection category: IP66 to EN 60 529/09.2000
complies with NEMA 4.
Premium Quality - Value Price 1

A
Selection
External dimensions, mm OrderCode Nr.

Height Width Depth Empty Come with M. Plate Come with Din Rail
80 80 45 J89.808045 - -
100 100 55 J89.101055 - -
130 130 60 J89.131360 - -
160 160 65 J89.161665 - -
160 120 65 J89.161265 J89.161265.P -
200 200 90 J89.202090 J89.202090.P -
250 250 100 J89.252510 J89.252510.P -
300 200 110 - - J89.302011.R
300 300 100 J89.303010 J89.303010.P -
400 200 110 - - J89.402011.R
400 400 110 J89.404011 J89.404011.P -
500 200 110 - - J89.502011.R
500 300 110 - - J89.503011.R
600 200 110 - - J89.602011.R
600 300 110 - - J89.603011.R
Junction boxes - J89
2
A-2 Terminal Boxes
• Screw fixed cover boxes,

Cover gasketed with all-round foamed-in PU seal.
• Material: Electro galvanised steel, 1.20 mm.
Optional: stainless steel
• Surface finish: epoxy powder-coated RAL 7035
texture.

A Industrial Steel Enclosures
1. Electro galvanised sheet steel

Height Width Depth With gland plate Without gland plate
150 80 - E89.151580
150 120 - E89.151512
200 80 - E89.152080
150 200 120 - E89.152012
300 80 - E89.153080
300 120 E89.153012.GP E89.153012
400 120 - E89.154012
200 80 - E89.202080
200 120 - E89.202012
300 80 - E89.203080
300 120 E89.203012.GP E89.203012
200 400 80 - E89.204080
400 120 E89.204012.GP E89.204012
500 120 E89.205012.GP E89.205012
600 80 - E89.206080
600 120 E89.206012.GP E89.206012
800 120 E89.208012.GP E89.208012
300 120 E89.303012.GP E89.303012
300 400 120 E89.304012.GP E89.304012
500 120 E89.305012.GP E89.305012 Terminal Box E89
600 120 E89.306012.GP E89.306012
400 120 E89.404012.GP E89.404012
400 600 120 E89.406012.GP E89.406012
800 120 E89.408012.GP E89.408012
2. Stainless steel - without gland plate

Height Width Depth steel AISI 304 steel ASIS 316L
150 80 E89.151580.304 E89.151580.316
150
300 80 E89.153080.304 E89.153080.316
200 80 E89.202080.304 E89.202080.316
200 300 80 E89.203080.304 E89.203080.316
400 120 E89.204012.304 E89.204012.316
300 300 120 E89.303012.304 E89.303012.316
4
A-3 Bus Enclosures
Enclosures have been designed and

manufactured with enhanced reliability and
quality.
• Enclosures with viewing window made from

polycarbonate/ tempered safety glass , 4 mm.
• Cover gasketed with all-round foamed-in PU seal.
• Material: Electro galvanised steel, 1.20 mm.
• Surface finish: powder-coated in texture RAL 7035.
• Supply includes: Door with left/right hinges,
1 cam lock with PA double-bit insert,
2 DIN rail TS 35/7.5

A
1. Without gland plate
External dimensions, mm
Height Width Depth OrderCode Nr.
200 80 E16.302080
300 80 E16.303080
400 80 E16.304080
500 80 E16.305080
300 200 120 E16.302012
400 120 E16.304012
400 150 E16.304015
600 150 E16.306015
800 150 E16.308015
2. With gland plate
External dimensions, mm
Height Width Depth OrderCode Nr.
200 400 125 E16.204012.GP
600 125 E16.206012.GP
300 500 125 E16.305012.GP
600 125 E16.306012.GP
500 400 160 E16.504016.GP
E16 with gland plate
6
A-4 Wall-mounting enclosures
VS 9000
A. Electro galvanised steel
• Door hinge on the right , may be swapped to opposite side.

• Door gasketed with all-round foamed-in PU seal
and PA double bit insert locks.
• Material: Electro galvanised steel.
• Mounting plate: Zinc plated.
• Surface finish: powder-coated RAL 7035 texture.
Optional RAL 7032 texture.

A
1. Single leaf door enclosures
Enclosure nominal dimensions, mm OrderCode Nr.

Height Width Depth Plain door with Plain door without Glazed door with
GI mounting plate mounting plate GI mounting plate
200 200 150 E9.202015 E9.202015.LP -
200 300 150 E9.203015 E9.203015.LP -
250 200 150 E9.252015 E9.252015.LP -
300 200 150 E9.302015 E9.302015.LP -
300 250 150 E9.302515 E9.302515.LP E19.302515
300 250 200 E9.302520 E9.302520.LP E19.302520
300 300 150 E9.303015 E9.303015.LP E19.303015
300 300 200 E9.303020 E9.303020.LP E19.303020
300 400 200 E9.304020 E9.304020.LP E19.304020
300 450 150 E9.304515 E9.304515.LP E19.304515
400 300 150 E9.403015 E9.403015.LP E19.403015
400 300 200 E9.403020 E9.403020.LP E19.403020
400 400 150 E9.404015 E9.404015.LP E19.404015
400 400 200 E9.404020 E9.404020.LP E19.404020
400 600 250 E9.406025 E9.406025.LP E19.406025
400 600 300 E9.406030 E9.406030.LP E19.406030
500 400 150 E9.504015 E9.504015.LP E19.504015
500 400 200 E9.504020 E9.504020.LP E19.504020
500 400 250 E9.504025 E9.504025.LP E19.504025 E9 Single leaf door enclosure
600 400 150 E9.604015 E9.604015.LP E19.604015
600 400 200 E9.604020 E9.604020.LP E19.604020
600 400 250 E9.604025 E9.604025.LP E19.604025
600 500 150 E9.605015 E9.605015.LP E19.605015
600 500 200 E9.605020 E9.605020.LP E19.605020
600 500 250 E9.605025 E9.605025.LP E19.605025
600 600 200 E9.606020 E9.606020.LP E19.606020
600 600 250 E9.606025 E9.606025.LP E19.606025
600 600 300 E9.606030 E9.606030.LP E19.606030
600 800 300 E9.608030 E9.608030.LP E19.608030
700 500 200 E9.705020 E9.705020.LP E19.705020
700 500 250 E9.705025 E9.705025.LP E19.705025
800 600 200 E9.806020 E9.806020.LP E19.806020
800 600 250 E9.806025 E9.806025.LP E19.806025
800 600 300 E9.806030 E9.806030.LP E19.806030
800 800 200 E9.808020 E9.808020.LP E19.808020
800 800 250 E9.808025 E9.808025.LP E19.808025
800 800 300 E9.808030 E9.808030.LP E19.808030
1000 600 200 E9.106020 E9.106020.LP E19.106020
1000 600 250 E9.106025 E9.106025.LP E19.106025
1000 600 300 E9.106030 E9.106030.LP E19.106030
1000 800 200 E9.108020 E9.108020.LP E19.108020
1000 800 250 E9.108025 E9.108025.LP E19.108025
1000 800 300 E9.108030 E9.108030.LP E19.108030
1200 800 200 E9.128020 E9.128020.LP E19.128020
1200 800 250 E9.128025 E9.128025.LP E19.128025
1200 800 300 E9.128030 E9.128030.LP E19.128030
1200 1000 250 E9.121025 E9.121025.LP E19.121025
1200 1000 300 E9.121030 E9.121030.LP E19.121030
1400 600 150 E9.146015 E9.146015.LP -
1400 600 200 E9.146020 E9.146020.LP -
1400 600 250 E9.146025 E9.146025.LP -
1400 600 300 E9.146030 E9.146030.LP -
1400 600 350 E9.146035 E9.146035.LP -
1400 600 400 E9.146040 E9.146040.LP -
1400 800 150 E9.148015 E9.148015.LP -
1400 800 200 E9.148020 E9.148020.LP -
1400 800 250 E9.148025 E9.148025.LP -
1400 800 300 E9.148030 E9.148030.LP -
1400 800 350 E9.148035 E9.148035.LP -
1400 800 400 E9.148040 E9.148040.LP -
1400 1000 350 E9.141035 E9.141035.LP -
1400 1000 400 E9.141040 E9.141040.LP -
8
A4 - Wall-mounting enclosures VS 9000
cont...Single leaf door enclosures

Height Width Depth Plain door with Plain door without Glazed door with
GI mounting plate mounting plate GI mounting plate
1600 600 150 E9.166015 E9.166015.LP -
1600 600 200 E9.166020 E9.166020.LP -
1600 600 250 E9.166025 E9.166025.LP -
1600 600 300 E9.166030 E9.166030.LP -
1600 600 350 E9.166035 E9.166035.LP -
1600 600 400 E9.166040 E9.166040.LP -
1600 800 150 E9.168015 E9.168015.LP -
1600 800 200 E9.168020 E9.168020.LP -
1600 800 250 E9.168025 E9.168025.LP -
1600 800 300 E9.168030 E9.168030.LP -
1600 800 350 E9.168035 E9.168035.LP -
1600 800 400 E9.168040 E9.168040.LP -
1600 1000 350 E9.161035 E9.161035.LP -
1600 1000 400 E9.161040 E9.161040.LP -
1800 600 150 E9.186015 E9.186015.LP -
1800 600 200 E9.186020 E9.186020.LP -
E9 Glazed door enclosure
1800 600 250 E9.186025 E9.186025.LP -
1800 600 300 E9.186030 E9.186030.LP -
1800 600 350 E9.186035 E9.186035.LP -
1800 600 400 E9.186040 E9.186040.LP -
1800 800 150 E9.188015 E9.188015.LP -
1800 800 200 E9.188020 E9.188020.LP -
1800 800 250 E9.188025 E9.188025.LP -
1800 800 300 E9.188030 E9.188030.LP -
1800 800 350 E9.188035 E9.188035.LP -
1800 800 400 E9.188040 E9.188040.LP -
1800 1000 350 E9.181035 E9.181035.LP -
1800 1000 400 E9.181040 E9.181040.LP -
2000 800 300 E9.208030 E9.208030.LP -
2000 800 350 E9.208035 E9.208035.LP -
2000 800 400 E9.208040 E9.208040.LP -
2000 1000 350 E9.201035 E9.201035.LP -
2000 1000 400 E9.201040 E9.201040.LP -
9
A
2. Overlapping-door enclosures
Enclosure dimensions, mm OrderCode Nr.

Height Width Depth Plain door with Plain door without
GI mounting plate mounting plate
1200 1000 250 E29.121025 E29.121025.LP
1200 1000 300 E29.121030 E29.121030.LP
1200 1000 350 E29.121035 E29.121035.LP
1200 1000 400 E29.121040 E29.121040.LP
1200 1200 250 E29.121225 E29.121225.LP
1200 1200 300 E29.121230 E29.121230.LP
1200 1200 350 E29.121235 E29.121235.LP
1200 1200 400 E29.121240 E29.121240.LP
1400 1000 250 E29.141025 E29.141025.LP
1400 1000 300 E29.141030 E29.141030.LP
1400 1000 350 E29.141035 E29.141035.LP
1400 1000 400 E29.141040 E29.141040.LP
1400 1200 250 E29.141225 E29.141225.LP
1400 1200 300 E29.141230 E29.141230.LP
1400 1200 350 E29.141235 E29.141235.LP
1400 1200 400 E29.141240 E29.141240.LP
1600 1000 250 E29.161025 E29.161025.LP
1600 1000 300 E29.161030 E29.161030.LP Overlapping door enclosures
1600 1000 350 E29.161035 E29.161035.LP
1600 1000 400 E29.161040 E29.161040.LP
1600 1200 250 E29.161225 E29.161225.LP
1600 1200 300 E29.161230 E29.161230.LP
1600 1200 350 E29.161235 E29.161235.LP
1600 1200 400 E29.161240 E29.161240.LP
1800 1000 250 E29.181025 E29.181025.LP
1800 1000 300 E29.181030 E29.181030.LP
1800 1000 350 E29.181035 E29.181035.LP
1800 1000 400 E29.181040 E29.181040.LP
1800 1200 250 E29.181225 E29.181225.LP
1800 1200 300 E29.181230 E29.181230.LP
1800 1200 350 E29.181235 E29.181235.LP
1800 1200 400 E29.181240 E29.181240.LP
2000 1000 350 E29.201035 E29.201035.LP
2000 1000 400 E29.201040 E29.201040.LP
2000 1200 350 E29.201235 E29.201235.LP
2000 1200 400 E29.201240 E29.201240.LP
Enclosures of height 1000mm and above are provided with
four floor mounting holes.
Accessories
3 Plinths
Material: Electro galvanised steel.
Surface finish: powder-coated in texture
RAL 9002. Optional RAL 7035 texture.

Width Depth height H100mm height H200mm
300 E9.12.153 E9.12.253
500
400 E9.12.154 E9.12.254
300 E9.12.163 E9.12.263
600 350 E9.12.163V E9.12.263V
400 E9.12.164 E9.12.264
300 E9.12.183 E9.12.283
800 350 E9.12.183V E9.12.283V
400 E9.12.184 E9.12.284
300 E9.12.103 E9.12.203
1000 350 E9.12.103V E9.12.203V
400 E9.12.104 E9.12.204
300 E9.12.123 E9.12.223
1200 350 E9.12.123V E9.12.223V
400 E9.12.124 E9.12.224
Plinth E9.12
10
A4 - Wall-mounting enclosures VS 9000
4. Rain canopy
Surface finish: powder-coated in texture RAL 7035.

Width Depth
200 150 E9.11.2015
150 E9.11.2515
250
200 E9.11.2520
150 E9.11.3015
300
200 E9.11.3020
150 E9.11.4015
400 200 E9.11.4020
250 E9.11.4025
150 E9.11.4515 Rain canopy
450
200 E9.11.4520
150 E9.11.5015
200 E9.11.5020
500
250 E9.11.5025
300 E9.11.5030
150 E9.11.6015
200 E9.11.6020
250 E9.11.6025
600
300 E9.11.6030
350 E9.11.6035
400 E9.11.6040
150 E9.11.8015
200 E9.11.8020
800 250 E9.11.8025
300 E9.11.8030
400 E9.11.8040
250 E9.11.1025
1000 300 E9.11.1030
350 E9.11.1035
400 E9.11.1040
250 E9.11.1225
1200 300 E9.11.1230
350 E9.11.1235
400 E9.11.1240
5. Inner door
Material: electro galvanised steel.
Optional RAL 7032 texture..
Height Width
400 300 E9.04.4030
300 E9.04.5030
500
400 E9.04.5040
400 E9.04.6040
600
500 E9.04.6050
700 500 E9.04.7050
600 E9.04.8060 Inner door
800
800 E9.04.8080
600 E9.04.1060
1000
800 E9.04.1080
800 E9.04.1280
1200
1000 E9.04.1210
6. Wall mounting brackets

Packs of 4.
Material Steel OrderCode Nr.

Zinc passivized E9.10.12
AISI 304 E39.10.12
Wall mounting brackets
11
A
B Stainless steel
1 Enclosures
Enclosure without gland plate in the base.
Door hinge on the right, may be swapped to opposite side.
Door gasketed with all-round foamed-in PU seal.
Cam lock:
Die-cast nickel chrome plated/sus.
Material: stainless steel.
Mounting plate: Zinc plated.
Surface finish: Brushed, grain size 240.
Protection category: IP65 to EN 60 529/09.2000 complies with NEMA 4x.
Enclosure nominal dimensions, mm OrderCode Nr. Number

Height Width Depth AISI 304 AISI 316L of Locks
300 200 150 E39.302015 E39.302015H 1
300 250 150 E39.302515 E39.302515H 1
300 300 150 E39.303015 E39.303015H 1
400 300 150 E39.403015 E39.403015H 1
400 300 200 E39.403020 E39.403020H 1
400 400 200 E39.404020 E39.404020H 1
400 600 200 E39.406020 E39.406020H 1
500 400 200 E39.504020 E39.504020H 2
600 400 200 E39.604020 E39.604020H 2
600 500 200 E39.605020 E39.605020H 2
600 600 250 E39.606025 E39.606025H 2
700 500 250 E39.705025 E39.705025H 2
800 600 200 E39.806020 E39.806020H 2
800 600 250 E39.806025 E39.806025H 2
800 800 300 E39.808030 E39.808030H 2
1000 800 300 E39.108030 E39.108030H 2
1200 800 300 E39.128030 E39.128030H 2
1000 1000 300 E39.101030-2D E39.101030H-2D 3-point
closure
1200 1000 300 E39.121030-2D E39.121030H-2D system
E39 - Stainless steel Enclosures
2. Rain canopy
Material: stainless steel.
Surface finish: Brushed, grain size 240

Width Depth AISI 304 AISI 316L
200 150 E39.11.2015 E39.11.2015H
150 E39.11.2515 E39.11.2515H
250
200 E39.11.2520 E39.11.2520H
150 E39.11.3015 E39.11.3015H
300
200 E39.11.3020 E39.11.3020H
150 E39.11.4015 E39.11.4015H
400 200 3E9.11.4020 3E9.11.4020H
250 E39.11.4025 E39.11.4025H
150 E39.11.4515 E39.11.4515H
450
200 E39.11.4520 E39.11.4520H
150 E39.11.5015 E39.11.5015H Rain Canopy
200 E39.11.5020 E39.11.5020H
500
250 E39.11.5025 E39.11.5025H
300 E39.11.5030 E39.11.5030H
150 E39.11.6015 E39.11.6015H
200 E39.11.6020 E39.11.6020H
600 250 E39.11.6025 E39.11.6025H
300 E39.11.6030 E39.11.6030H
350 E39.11.6035 E39.11.6035H
150 E39.11.8015 E39.11.8015H
200 E39.11.8020 E39.11.8020H
800
250 E39.11.8025 E39.11.8025H
300 E39.11.8030 E39.11.8030H
250 E39.11.1025 E39.11.1025H
1000
300 E39.11.1030 E39.11.1030H
VS9000 Certificate
12
A-5 Compact free-standing enclosures
VS 5000
• Enclosure with gland plate in the base.
• Door hinge on the right, may be swapped to opposite side.
• Door gasketed all-round foamed-in PU seal and mounted with
double bit PA insert lock.
• Surface finish: powder-coated in texture RAL 7035. Optional
RAL 7032 texture.
• Protection category: IP55 to EN 60 529/09.2000 complies
with NEMA 12.

A

Height Width Depth Plain door with Plain door without Glazed door without
GI mounting plate mounting plate mounting plate
600 300 E5.106030P E5.106030 -
600 400 E5.106040P E5.106040 -
1000
800 300 E5.108030P E5.108030 -
800 400 E5.108040P E5.108040 -
600 300 E5.126030P E5.126030 -
600 400 E5.126040P E5.126040 -
1200 800 300 E5.128030P E5.128030 -
800 400 E5.128040P E5.128040 -
1000 400 E5.121040P E5.121040 -
600 300 E5.146030P E5.146030 -
600 400 E5.146040P E5.146040 -
1400 800 300 E5.148030P E5.148030 -
800 400 E5.148040P E5.148040 E15.148040
1000 400 E5.141040P E5.141040 -
600 300 E5.166030P E5.166030 -
600 400 E5.166040P E5.166040 E15.166040
600 500 E5.166050P E5.166050 -
1600 800 300 E5.168030P E5.168030 E15.168030
800 400 E5.168040P E5.168040 E15.168040
800 500 E5.168050P E5.168050 -
1000 400 E5.161040P E5.161040 -
600 300 E5.186030P E5.186030 -
600 400 E5.186040P E5.186040 E15.186040
600 500 E5.186050P E5.186050 -
800 300 E5.188030P E5.188030 E15.188030
1800
800 400 E5.188040P E5.188040 E15.188040
800 500 E5.188050P E5.188050 E15.188050 Single leaf door enclosures
800 600 E5.188060P E5.188060 -
1000 400 E5.181040P E5.181040 -
600 300 E5.206030P E5.206030 -
600 400 E5.206040P E5.206040 E15.206040
600 500 E5.206050P E5.206050 -
800 300 E5.208030P E5.208030 E15.208030
2000 800 400 E5.208040P E5.208040 E15.208040
800 500 E5.208050P E5.208050 E15.208050
800 600 E5.208060P E5.208060 E15.208060
1000 400 E5.201040P E5.201040 -
1000 500 E5.201050P E5.201050 -
2. Overlapping door enclosures

Height Width Depth Plain door with Plain door without
GI mounting plate mounting plate
1000 300 E5.121030P-2D E5.121030-2D
1200
1200 400 E5.121040P-2D E5.121040-2D
1000 400 E5.141040P-2D E5.141040-2D
1400
1200 400 E5.141240P-2D E5.141240-2D
1000 300 E5.161030P-2D E5.161030-2D
1000 400 E5.161040P-2D E5.161040-2D
1600
1200 300 E5.161230P-2D E5.161230-2D
1200 400 E5.161240P-2D E5.161240-2D
1000 400 E5.181040P-2D E5.181040-2D
1000 500 E5.181050P-2D E5.181050-2D
1200 400 E5.181240P-2D E5.181240-2D
1800
1200 500 E5.181250P-2D E5.181250-2D
1600 400 E5.181640P-2D E5.181640-2D
1600 500 E5.181650P-2D E5.181650-2D
1000 400 E5.201040P-2D E5.201040-2D
1000 500 E5.201050P-2D E5.201050-2D
1200 400 E5.201240P-2D E5.201240-2D
1200 500 E5.201250P-2D E5.201250-2D
2000
1200 600 E5.201260P-2D E5.201260-2D
1600 400 E5.201640P-2D E5.201640-2D
1600 500 E5.201650P-2D E5.201650-2D
1600 600 E5.201660P-2D E5.201660-2D
Overlapping door enclosures

14
A5 - Compact free-standing enclosures VS 5000
Accessories
3. Rain canopy
Enclosure dimensions, mm
OrderCode Nr.
Width Depth
300 E5.25.063
600 400 E5.25.064
500 E5.25.065
300 E5.25.083
800 400 E5.25.084
500 E5.25.085
300 E5.25.103
1000 400 E5.25.104
500 E5.25.105
300 E5.25.123
1200 400 E5.25.124
500 E5.25.125
Rain canopy
4. Plinths

300 E5.04.1063 E5.04.2063
600 400 E5.04.1064 E5.04.2064
500 E5.04.1065 E5.04.2065
300 E5.04.1083 E5.04.2083
800 400 E5.04.1084 E5.04.2084
500 E5.04.1085 E5.04.2085
300 E5.04.1103 E5.04.2103
1000 400 E5.04.1104 E5.04.2104 Plinths
500 E5.04.1105 E5.04.2105
300 E5.04.1123 E5.04.2123
1200 400 E5.04.1124 E5.04.2124
500 E5.04.1125 E5.04.2125
400 E5.04.1164 E5.04.2164
1600 500 E5.04.1165 E5.04.2165
600 E5.04.1166 E5.04.2166
5. GI mounting plate
Supplies include mounting brackets.
Enclosure dimensions, mm
OrderCode Nr.
Height Width
600 E5.36.1006
1000
800 E5.36.1008
600 E5.36.1206
1200 800 E5.36.1208
1000 E5.36.1210
600 E5.36.1406
1400 800 E5.36.1408
1000 E5.36.1410
600 E5.36.1606
800 E5.36.1608
1600
1000 E5.36.1610
1200 E5.36.1612
600 E5.36.1806
800 E5.36.1808
1800
1000 E5.36.1810
1200 E5.36.1812
600 E5.36.2006
800 E5.36.2008
2000
1000 E5.36.2010
1200 E5.36.2012
GI mounting plate
15
A
6. Vertical uprights
Material: zinc passivated steel.
Packs of 2.
Enclosure Height, mm OrderCode Nr.
1000 E5.43.1000
1200 E5.43.1200
1400 E5.43.1400
1600 E5.43.1600
1800 E5.43.1800
2000 E5.43.2000
Vertical uprights
7. 19” swing frame


Height Width Off-centre Centred
1200 800 E5.76.1281 E5.76.1282
1400 800 E5.76.1481 E5.76.1482
1600 800 E5.76.1681 E5.76.1682
1800 800 E5.76.1881 E5.76.1882
2000 800 E5.76.2081 E5.76.2082
2200 800 E5.76.2281 E5.76.2282
19” swing frame
16
A5 - Compact free-standing enclosures VS 5000
8. 19” fixed frame


Height Width
600 E5.66.1260
1200
800 E5.66.1280
600 E5.66.1460
1400
800 E5.66.1480
600 E5.66.1660
1600
800 E5.66.1680
600 E5.66.1860
1800
800 E5.66.1880
600 E5.66.2060
2000
800 E5.66.2080
19” fixed frame
9. Inner door
Optional RAL 7032 texture..

Height Width
600 E5.08.1206
1200
800 E5.08.1208
600 E5.08.1406
1400 800 E5.08.1408
1000 E5.08.1410
600 E5.08.1606
1600 800 E5.08.1608
1000 E5.08.1610
600 E5.08.1806
1800 800 E5.08.1808
1000 E5.08.1810
600 E5.08.2006
2000 800 E5.08.2008
1000 E5.08.2010
Inner door
17
A
10. Door retainer

Holds the door open at 120 degree to avoid accidental closing.
Supplied with fasteners
Packs of 1 set.
OrderCode Nr. E8.35.0
Door retainer
View of Door retainer in use.
18
A6 - Panel System Enclosures VS 8000
A-6 Panel system enclosures VS8000
• Every enclosure is accessible from all sides.

• When used in conjunction with the system accessories, it offers endless possibilities.
• Enclosure welded frame sections are slotted on a 25mm pitch pattern.
• Door and panels are gasketed with all-round foamed-in PU seal.
• Surface finish: powder-coated in texture RAL 7035. Optional RAL 7032 texture.
• Protection category: IP55 to EN 60 529/09.2000 complies with NEMA 12.
• Supply includes: Enclosure welded frame with depth profiles, doors/rear panel,
mounting plate ( optional ), gland plates and roof panel.

A

supply excludes GIP mounting plate
Height Width Depth Plain front door and Plain front and
rear panel enclosure rear doors enclosure
600 400 E8.1264 E8.1264-RD
600 500 E8.1265 E8.1265-RD
1200
800 400 E8.1284 E8.1284-RD
800 500 E8.1285 E8.1285-RD
600 400 E8.1464 E8.1464-RD
1400 600 500 E8.1465 E8.1465-RD
800 500 E8.1485 E8.1485-RD
600 500 E8.1665 E8.1665-RD
600 600 E8.1666 E8.1666-RD
600 800 E8.1668 E8.1668-RD
1600
800 500 E8.1685 E8.1685-RD
800 600 E8.1686 E8.1686-RD
800 800 E8.1688 E8.1688-RD
400 400 E8.1844 E8.1844-RD
400 500 E8.1845 E8.1845-RD
400 600 E8.1846 E8.1846-RD
600 400 E8.1864 E8.1864-RD
600 500 E8.1865 E8.1865-RD
600 600 E8.1866 E8.1866-RD
600 800 E8.1868 E8.1868-RD
1800
800 400 E8.1884 E8.1884-RD
800 500 E8.1885 E8.1885-RD
800 600 E8.1886 E8.1886-RD
1000 400 E8.1804 E8.1804-RD
1000 500 E8.1805 E8.1805-RD
1000 600 E8.1806 E8.1806-RD
600 400 E8.2064 E8.2064-RD
600 500 E8.2065 E8.2065-RD
600 600 E8.2066 E8.2066-RD
600 800 E8.2068 E8.2068-RD Single leaf door enclosures
800 400 E8.2084 E8.2084-RD
800 500 E8.2085 E8.2085-RD
2000
800 600 E8.2086 E8.2086-RD
800 800 E8.2088 E8.2088-RD
1000 400 E8.2004 E8.2004-RD
1000 500 E8.2005 E8.2005-RD
1000 600 E8.2006 E8.2006-RD
1000 800 E8.2008 E8.2008-RD
600 600 E8.2266 E8.2266-RD
600 800 E8.2268 E8.2268-RD
2200 800 600 E8.2286 E8.2286-RD
800 800 E8.2288 E8.2288-RD
1000 600 E8.2206 E8.2206-RD
Transparent Door enclosures
20
2. Overlapping door enclosures

Height Width Depth Plain front door and Plain front and
rear panel enclosure rear doors enclosure
1600 1200 500 E8.1625-2D E8.1625-2DRD
800 500 E8.1885-2D E8.1885-2DRD
800 600 E8.1886-2D E8.1886-2DRD
1000 400 E8.1804-2D E8.1804-2DRD
1000 500 E8.1805-2D E8.1805-2DRD
1800
1000 600 E8.1806-2D E8.1806-2DRD
1200 400 E8.1824-2D E8.1824-2DRD
1200 500 E8.1825-2D E8.1825-2DRD
1200 600 E8.1826-2D E8.1826-2DRD
800 600 E8.2086-2D E8.2086-2DRD
1000 400 E8.2004-2D E8.2004-2DRD
1000 500 E8.2005-2D E8.2005-2DRD
1000 600 E8.2006-2D E8.2006-2DRD
1000 800 E8.2008-2D E8.2008-2DRD
1200 400 E8.2024-2D E8.2024-2DRD
2000
1200 500 E8.2025-2D E8.2025-2DRD
1200 600 E8.2026-2D E8.2026-2DRD
1200 800 E8.2028-2D E8.2028-2DRD
1600 400 E8.20164P-2D E8.20164-2DRD
1600 500 E8.20165-2D E8.20165-2DRD
1600 600 E8.20166-2D E8.20166-2DRD
1000 600 E8.2206-2D E8.2206-2DRD
1000 800 E8.2208-2D E8.2208-2DRD
2200
1200 600 E8.2226-2D E8.2226-2DRD
1200 800 E8.2228-2D E8.2228-2DRD
Overlapping door enclosures
3. Transparent Door enclosures

Supply includes: Enclosure welded frame with depth profiles,
transparent front door, gland plates, rear plain door / panel and
roof panel.

Height Width Depth centre cut-out offset cut-out centre cut-out offset cut-out
transparent front door transparent front door transparent front door & transparent front door &
& rear panel enclosure & rear panel enclosure rear plain door enclosure rear plain door enclosure
600 400 E78.1864 - E78.1864-RD -
600 500 E78.1865 - E78.1865-RD -
600 600 E78.1866 - E78.1866-RD -
1800 600 800 E78.1868 - E78.1868-RD -
800 400 E78.1884 E78.1884.S E78.1884-RD E78.1884.S-RD
800 500 E78.1885 E78.1885.S E78.1885-RD E78.1885.S-RD
800 600 E78.1886 E78.1886.S E78.1886-RD E78.1886.S-RD
800 400 E78.2084 E78.2084.S E78.2084-RD E78.2084.S-RD
800 500 E78.2085 E78.2085.S E78.2085-RD E78.2085.S-RD
800 600 E78.2086 E78.2086.S E78.2086-RD E78.2086.S-RD
2000 800 800 E78.2088 E78.2088.S E78.2088-RD E78.2088.S-RD
600 600 E78.2266 - E78.2066-RD -
600 800 E78.2268 - E78.2068-RD -
800 600 E78.2286 E78.2286.S E78.2086-RD E78.2086.S-RD
800 800 E78.2288 E78.2288.S E78.2088-RD E78.2088.S-RD
600 600 E78.2266 - E78.2266-RD -
2200 600 800 E78.2268 - E78.2268-RD -
800 600 E78.2286 E78.2286.S E78.2286-RD E78.2286.S-RD
800 800 E78.2288 E78.2288.S E78.2288-RD E78.2288.S-RD
21
A
B. Accessories
4. Side panels
Surface finish: powder-coated in texture RAL
7035. Optional RAL 7032 texture.
Packs of 2.
Height Depth
1200 400 E8.01.124

500 E8.01.125
1400 400 E8.01.144
500 E8.01.145
500 E8.01.165
1600 600 E8.01.166
800 E8.01.168
400 E8.01.184
1800 500 E8.01.185
600 E8.01.186
800 E8.01.188
400 E8.01.204
2000 500 E8.01.205
600 E8.01.206
800 E8.01.208
2200 600 E8.01.226
800 E8.01.228
Side panels
5. Lifting Eyebolt -M12

Packs of 4.
6. Lifting angle brackets

Packs of 4. Lifting Eyebolt -M12
7. Plinths

400 E8.04.1064 E8.04.2064
Lifting angle brackets
500 E8.04.1065 E8.04.2065
600
600 E8.04.1066 E8.04.2066
800 E8.04.1068 E8.04.2068
500 E8.04.1085 E8.04.2085
800 600 E8.04.1086 E8.04.2086
800 E8.04.1088 E8.04.2088
400 E8.04.1104 E8.04.2104
500 E8.04.1105 E8.04.2105
1000
600 E8.04.1106 E8.04.2106
800 E8.04.1108 E8.04.2108
400 E8.04.1124 E8.04.2124
500 E8.04.1125 E8.04.2125
1200
600 E8.04.1126 E8.04.2126
800 E8.04.1128 E8.04.2128
Plinths
22
8. GI mounting plate
including mounting brackets
Packs of 1.

Height Width
600 E8.36.1206
1200
800 E8.36.1208
600 E8.36.1406
1400
800 E8.36.1408
600 E8.36.1606
800 E8.36.1608
1600
1000 E8.36.1610
1200 E8.36.1612
600 E8.36.1806
800 E8.36.1808
1800
1000 E8.36.1810
1200 E8.36.1812
600 E8.36.2006
800 E8.36.2008
2000
1000 E8.36.2010
1200 E8.36.2012
600 E8.36.2206
2200 800 E8.36.2208
1000 E8.36.2210
1200 E8.36.2212
GI mounting plate
9. 19” swing frames

Supplied with fixing accessories.
Packs of 1 set.
For enclosure OrderCode Nr.

Height, mm Width, mm installed centre installed offset
1600 E8.76.1682 E8.76.1681
1800 800 E8.76.1882 E8.76.1881
2000 E8.76.2082 E8.76.2081
2200 E8.76.2282 E8.76.2281
10. 19” fixed frames

Packs of 1 set.
Height, mm Width, mm Installed centre
600 E8.38.1660
1600
800 E8.38.1680
600 E8.38.1860
1800
800 E8.38.1880
600 E8.38.2060
2000
800 E8.38.2080
600 E8.38.2260
2200
800 E8.38.2280
19” swing frames 19” fixed frames

23
A
11. 19” panels

Packs of 4..
Panel OrderCode Nr.

U height Plain Vented
1 E4.910.0 E4.910.1
1.5 E4.915.0 E4.915.1
2 E4.920.0 E4.920.1
3 E4.930.0 E4.930.1
4 E4.940.0 E4.940.1
5 E4.950.0 E4.950.1
19” panels
12. Internal door

Packs of 1 set.
Height, mm Width, mm
600 E8.08.1606
1600
800 E8.08.1608
600 E8.08.1806
1800
800 E8.08.1808
600 E8.08.2006
2000
800 E8.08.2008
600 E8.08.2206
2200
800 E8.08.2208
Internal door
13. Side divider panels- plain

Material: zincpassivated steel.
Packs of 1.

Height, mm Depth, mm
500 E8.34.165
1600 600 E8.34.166
800 E8.34.168
500 E8.34.185
1800 600 E8.34.186
800 E8.34.188
500 E8.34.205
2000 600 E8.34.206
800 E8.34.208
500 E8.34.225
2200 600 E8.34.226
800 E8.34.228
Side divider panels- plain
24
14. Enclosure baying kits

Material: zinc passivated steel.
Packs of 1 set.
Enclosure baying kits
15. Metal document pockets, mount to the door stiffeners

Packs of 1 set.
For enclosure door OrderCode Nr.
Width, mm
500 E8.34.500
600 E8.34.600
700 E8.34.700 Metal document pockets , mount to the door stiffeners
800 E8.34.800
16. Door retainer

Holds the door open at 120 degree to avoid accidental closing.
Packs of 1 set.
Door retainer
17. Door switch

c/w mounting brackets
Packs of 1 set.
OrderCode Nr. DS-230V
Door switch
18. Compact fluorescent lamp, 220V/50Hz,60W

c/w switch and mounting brackets
Packs of 1 set.
OrderCode Nr. LAMP 68
Compact fluorescent lamp, 220V/50Hz,60W
19. Spray touch-up paint

Aerosol can
Colour OrderCode Nr.

RAL 7032 SC-7032
RAL 7035 SC-7035
Spray touch-up paint
25
A
20. Punched section 25x75 mm with mounting flanges

Packs of 4.

Width/Depth, mm Width, mm Depth, mm
500 - E8.65.05
600 E8.64.06 E8.65.06
800 E8.64.08 E8.65.08
1000 E8.64.10 E8.64.10
1200 E8.64.12 -
21 Punched section 25x75 mm without mounting flange

Packs of 4, with support brackets.

Height / Width / Depth, mm Height, mm Width, mm Depth, mm
400 - - E8.62.7504
500 - - E8.62.7505
600 - E8.61.7506 E8.62.7506
800 - E8.61.7508 E8.62.7508
1000 - E8.61.7510 -
1200 E8.63.7512 E8.61.7512 -
1400 E8.63.7514 - -
1600 E8.63.7516 - - Punched section 25x75 mm without mounting flange
1800 E8.63.7518 - -
2000 E8.63.7520 - -
2200 E8.63.7522 - -
22 Punched section 25x25 mm without mounting flange

Packs of 4, with support brackets

Height / Width / Depth, mm Height, mm Width, mm Depth, mm
400 - - E8.62.2504
500 - - E8.62.2505
600 - E8.61.2506 E8.62.2506
800 - E8.61.2508 E8.62.2508
1000 E8.63.2510 E8.61.2510 -
1200 E8.63.2512 E8.61.2512 -
1400 E8.63.2514 - - Punched section 25x25 mm without mounting flange
1600 E8.63.2516 - -
1800 E8.63.2518 - -
2000 E8.63.2520 - -
2200 E8.63.2522 - -
26
A-7 Extendable Enclosures EP 8000
Enclosures have been designed and

manufactured with enhanced reliability and
quality.
• kit set assembly modular design

• the eight folds profiles of the frame
elements provide substantial torque resistance
• complies with international standards
• tested according to these standards
• manufactured in ISO certified facilities
• guaranteed flexibility and quick assembly
• guaranteed by a world-class enclosure manufacturer
• offer an appropriate solution for the central link
represented by the low voltage switchgear application
and installation
Characteristics - Mechanical ;
The enclosure range may be used to build switchboards of

various depths and widths by combining basic frames and
extensions.
• Forms: 1 - 2b - 3b - 4b
• Degree of protection: IP55
• Dimensions:
Overall height - 2200, 2000, 1800 and 1600 mm
Width - 300, 400, 500, 600, 700, 800, 900, 1000,
1100,1200,1300 and 1400 mm.
Depth - 400, 500, 600, 700, 800, 900 and 1000 mm
• Functional height / width / depth - modules of 50 mm
• Material: Electro galvanised and zincpassivated
steel sheets
• Finish: Painted with epoxy-polyester resin,
textured RAL 7035. Optional - RAL 7032 textured
Basic frame :
The basic frame of the enclosure unit is an assembly of
prefabricated elements.
These elements are available in a number of sizes and may be
assembled to form columns of different volumes.
Each column is made up of four distinct zones :

1. Busbars.
2. Switchgear components.
3. Cable connections.
4. Auxiliaries.

A
Layout of the columns:
The modular design makes it possible to match the

switchboard layout to the configuration of the electrical
room.
• columns may be positioned side-by-side or back-

to-back or cornered.
• access to connection zones is possible through
the front or back of each column.
• if the connection terminals are located behind
switchgear components, access is through the
rear of column.
• incoming or outgoing cables may enter through
the top or bottom of columns.
• the switchboard may also be supplied by bus
ways through the top of the column.
The arrangement is of Endless Possibilities.
28
A7 - Extendable Enclosures EP 8000
29
A
30
Flat pack component kits
31
A
1. Selection : Flat pack component kits

Height Width Depth Number Vertical Vertical Top and bottom Top and bottom Roof panel Plain door and Side panels Mounting plate
of doors uprights-standard uprights- extended frame-standard frame-extended rear panel set (pack of 2) and brackets
400 1 6.01.1200 6.01.1200E 6.02.6040 6.02.6040E 6.04.6040 6.05.1260 6.11.1240 6.31.1260

500 1 6.01.1200 6.01.1200E 6.02.6050 6.02.6050E 6.04.6050 6.05.1260 6.11.1250 6.31.1260
600
600 1 6.01.1200 6.01.1200E 6.02.6060 6.02.6060E 6.04.6060 6.05.1260 6.11.1260 6.31.1260
800 1 6.01.1200 6.01.1200E 6.02.6080 6.02.6080E 6.04.6080 6.05.1260 6.11.1280 6.31.1260
1200
400 1 6.01.1200 6.01.1200E 6.02.8040 6.02.8040E 6.04.8040 6.05.1280 6.11.1240 6.31.1280
500 1 6.01.1200 6.01.1200E 6.02.8050 6.02.8050E 6.04.8050 6.05.1280 6.11.1250 6.31.1280
800
600 1 6.01.1200 6.01.1200E 6.02.8060 6.02.8060E 6.04.8060 6.05.1280 6.11.1260 6.31.1280
800 1 6.01.1200 6.01.1200E 6.02.8080 6.02.8080E 6.04.8080 6.05.1280 6.11.1280 6.31.1280
400 1 6.01.1400 6.01.1400E 6.02.6040 6.02.8040E 6.04.6040 6.05.1460 6.11.1440 6.31.1460
500 1 6.01.1400 6.01.1400E 6.02.6050 6.02.8040E 6.04.6050 6.05.1460 6.11.1450 6.31.1460
600
600 1 6.01.1400 6.01.1400E 6.02.6060 6.02.8040E 6.04.6060 6.05.1460 6.11.1460 6.31.1460
800 1 6.01.1400 6.01.1400E 6.02.6080 6.02.8040E 6.04.6080 6.05.1460 6.11.1480 6.31.1460
1400
400 1 6.01.1400 6.01.1400E 6.02.8040 6.02.8040E 6.04.8040 6.05.1480 6.11.1440 6.31.1480
500 1 6.01.1400 6.01.1400E 6.02.8050 6.02.8050E 6.04.8050 6.05.1480 6.11.1450 6.31.1480
800
600 1 6.01.1400 6.01.1400E 6.02.8060 6.02.8060E 6.04.8060 6.05.1480 6.11.1460 6.31.1480
800 1 6.01.1400 6.01.1400E 6.02.8080 6.02.8080E 6.04.8080 6.05.1480 6.11.1480 6.31.1480
400 1 6.01.1600 6.01.1600E 6.02.6040 6.02.6040E 6.04.6040 6.05.1660 6.11.1640 6.31.1660
500 1 6.01.1600 6.01.1600E 6.02.6050 6.02.6050E 6.04.6050 6.05.1660 6.11.1650 6.31.1660
600
600 1 6.01.1600 6.01.1600E 6.02.6060 6.02.6060E 6.04.6060 6.05.1660 6.11.1660 6.31.1660
800 1 6.01.1600 6.01.1600E 6.02.6080 6.02.6080E 6.04.6080 6.05.1660 6.11.1680 6.31.1660
1600
400 1 6.01.1600 6.01.1600E 6.02.8040 6.02.8040E 6.04.8040 6.05.1680 6.11.1640 6.31.1680
500 1 6.01.1600 6.01.1600E 6.02.8050 6.02.8050E 6.04.8050 6.05.1680 6.11.1650 6.31.1680
800
600 1 6.01.1600 6.01.1600E 6.02.8060 6.02.8060E 6.04.8060 6.05.1680 6.11.1660 6.31.1680
800 1 6.01.1600 6.01.1600E 6.02.8080 6.02.8080E 6.04.8080 6.05.1680 6.11.1680 6.31.1680
400 1 6.01.1800 6.01.1800E 6.02.4040 6.02.4040E 6.04.4040 6.05.1840 6.11.1840 -
500 1 6.01.1800 6.01.1800E 6.02.4050 6.02.4050E 6.04.4050 6.05.1840 6.11.1850 -
400
600 1 6.01.1800 6.01.1800E 6.02.4060 6.02.4060E 6.04.4060 6.05.1840 6.11.1860 -
800 1 6.01.1800 6.01.1800E 6.02.4080 6.02.4080E 6.04.4080 6.05.1840 6.11.1880 -
400 1 6.01.1800 6.01.1800E 6.02.6040 6.02.6040E 6.04.6040 6.05.1860 6.11.1840 6.31.1860
500 1 6.01.1800 6.01.1800E 6.02.6050 6.02.6050E 6.04.6050 6.05.1860 6.11.1850 6.31.1860
600
600 1 6.01.1800 6.01.1800E 6.02.6060 6.02.6060E 6.04.6060 6.05.1860 6.11.1860 6.31.1860
800 1 6.01.1800 6.01.1800E 6.02.6080 6.02.6080E 6.04.6080 6.05.1860 6.11.1880 6.31.1860
400 1 6.01.1800 6.01.1800E 6.02.8040 6.02.8040E 6.04.8040 6.05.1880 6.11.1840 6.31.1880
500 1 6.01.1800 6.01.1800E 6.02.8050 6.02.8050E 6.04.8050 6.05.1880 6.11.1850 6.31.1880
800 600 2 6.01.1800 6.01.1800E 6.02.8060 6.02.8060E 6.04.8060 6.05.1880-2D 6.11.1860 6.31.1880
800 1 6.01.1800 6.01.1800E 6.02.8080 6.02.8080E 6.04.8080 6.05.1880 6.11.1880 6.31.1880
1800
800 2 6.01.1800 6.01.1800E 6.02.8080 6.02.8080E 6.04.8080 6.05.1880-2D 6.11.1880 6.31.1880
400 1 6.01.1800 6.01.1800E 6.02.1040 6.02.1040E 6.04.1040 6.05.1810 6.11.1840 6.31.1810
400 2 6.01.1800 6.01.1800E 6.02.1040 6.02.1040E 6.04.1040 6.05.1810-2D 6.11.1840 6.31.1810
500 1 6.01.1800 6.01.1800E 6.02.1050 6.02.1050E 6.04.1050 6.05.1810 6.11.1850 6.31.1810
1000 600 1 6.01.1800 6.01.1800E 6.02.1060 6.02.1060E 6.04.1060 6.05.1810 6.11.1860 6.31.1810
600 2 6.01.1800 6.01.1800E 6.02.1060 6.02.1060E 6.04.1060 6.05.1810-2D 6.11.1860 6.31.1810
800 1 6.01.1800 6.01.1800E 6.02.1080 6.02.1080E 6.04.1080 6.05.1810 6.11.1880 6.31.1810
800 2 6.01.1800 6.01.1800E 6.02.1080 6.02.1080E 6.04.1080 6.05.1810-2D 6.11.1880 6.31.1810
400 2 6.01.1800 6.01.1800E 6.02.1240 6.02.1240E 6.04.1240 6.05.1812-2D 6.11.1840 6.31.1812
500 2 6.01.1800 6.01.1800E 6.02.1250 6.02.1250E 6.04.1250 6.05.1812-2D 6.11.1850 6.31.1812
1200
600 2 6.01.1800 6.01.1800E 6.02.1260 6.02.1260E 6.04.1260 6.05.1812-2D 6.11.1860 6.31.1812
800 2 6.01.1800 6.01.1800E 6.02.1280 6.02.1280E 6.04.1280 6.05.1812-2D 6.11.1880 6.31.1812
500 1 6.01.2000 6.01.2000E 6.02.3050 6.02.3050E 6.04.3050 6.05.2030 6.11.2050 -
300
600 1 6.01.2000 6.01.2000E 6.02.3060 6.02.3060E 6.04.3060 6.05.2030 6.11.2060 -
400 1 6.01.2000 6.01.2000E 6.02.4040 6.02.4040E 6.04.4040 6.05.2040 6.11.2040 -
500 1 6.01.2000 6.01.2000E 6.02.4050 6.02.4050E 6.04.4050 6.05.2040 6.11.2050 -
400
600 1 6.01.2000 6.01.2000E 6.02.4060 6.02.4060E 6.04.4060 6.05.2040 6.11.2060 -
800 1 6.01.2000 6.01.2000E 6.02.4080 6.02.4080E 6.04.4080 6.05.2040 6.11.2080 -
400 1 6.01.2000 6.01.2000E 6.02.6040 6.02.6040E 6.04.6040 6.05.2060 6.11.2040 6.31.2060
500 1 6.01.2000 6.01.2000E 6.02.6050 6.02.6050E 6.04.6050 6.05.2060 6.11.2050 6.31.2060
600
600 1 6.01.2000 6.01.2000E 6.02.6060 6.02.6060E 6.04.6060 6.05.2060 6.11.2060 6.31.2060
800 1 6.01.2000 6.01.2000E 6.02.6080 6.02.6080E 6.04.6080 6.05.2060 6.11.2080 6.31.2060
400 1 6.01.2000 6.01.2000E 6.02.8040 6.02.8040E 6.04.8040 6.05.2080 6.11.2040 6.31.2080
500 1 6.01.2000 6.01.2000E 6.02.8050 6.02.8050E 6.04.8050 6.05.2080 6.11.2050 6.31.2080
2000
600 1 6.01.2000 6.01.2000E 6.02.8060 6.02.8060E 6.04.8060 6.05.2080 6.11.2060 6.31.2080
800
600 2 6.01.2000 6.01.2000E 6.02.8060 6.02.8060E 6.04.8060 6.05.2080-2D 6.11.2060 6.31.2080
800 1 6.01.2000 6.01.2000E 6.02.8080 6.02.8080E 6.04.8080 6.05.2080 6.11.2080 6.31.2080
800 2 6.01.2000 6.01.2000E 6.02.8080 6.02.8080E 6.04.8080 6.05.2080-2D 6.11.2080 6.31.2080
400 1 6.01.2000 6.01.2000E 6.02.1040 6.02.1040E 6.04.1040 6.05.2010 6.11.2040 6.31.2010
400 2 6.01.2000 6.01.2000E 6.02.1040 6.02.1040E 6.04.1040 6.05.2010-2D 6.11.2040 6.31.2010
500 1 6.01.2000 6.01.2000E 6.02.1050 6.02.1050E 6.04.1050 6.05.2010 6.11.2050 6.31.2010
500 2 6.01.2000 6.01.2000E 6.02.1050 6.02.1050E 6.04.1050 6.05.2010-2D 6.11.2050 6.31.2010
1000
600 1 6.01.2000 6.01.2000E 6.02.1060 6.02.1060E 6.04.1060 6.05.2010 6.11.2060 6.31.2010
600 2 6.01.2000 6.01.2000E 6.02.1060 6.02.1060E 6.04.1060 6.05.2010-2D 6.11.2060 6.31.2010
800 1 6.01.2000 6.01.2000E 6.02.1080 6.02.1080E 6.04.1080 6.05.2010 6.11.2080 6.31.2010
800 2 6.01.2000 6.01.2000E 6.02.1080 6.02.1080E 6.04.1080 6.05.2010-2D 6.11.2080 6.31.2010
32
A7 - Flat pack component kits
Selection : continuation.....

Height Width Depth Number Vertical Vertical Top and bottom Top and bottom Roof panel Plain door and Side panels Mounting plate
of doors uprights-standard uprights- extended frame-standard frame-extended rear panel set (pack of 2) and brackets
400 2 6.01.2000 6.01.2000E 6.02.1240 6.02.1240E 6.04.1240 6.05.2012-2D 6.11.2040 6.31.2012

1200 500 2 6.01.2000 6.01.2000E 6.02.1250 6.02.1250E 6.04.1250 6.05.2012-2D 6.11.2050 6.31.2012
600 2 6.01.2000 6.01.2000E 6.02.1260 6.02.1260E 6.04.1260 6.05.2012-2D 6.11.2060 6.31.2012
2000 800 2 6.01.2000 6.01.2000E 6.02.1280 6.02.1280E 6.04.1280 6.05.2012-2D 6.11.2080 6.31.2012
400 2 6.01.2000 6.01.2000E 6.02.1640 6.02.1640E 6.04.1640 6.05.2016-2D 6.11.2040 6.31.2016
1600 500 2 6.01.2000 6.01.2000E 6.02.1650 6.02.1650E 6.04.1650 6.05.2016-2D 6.11.2050 6.31.2016
600 2 6.01.2000 6.01.2000E 6.02.1660 6.02.1660E 6.04.1660 6.05.2016-2D 6.11.2060 6.31.2016
400 1 6.01.2200 6.01.2200E 6.02.4040 6.02.4040E 6.04.4040 6.05.2240 6.11.2240 -
400 500 1 6.01.2200 6.01.2200E 6.02.4050 6.02.4050E 6.04.4050 6.05.2240 6.11.2250 -
600 1 6.01.2200 6.01.2200E 6.02.4060 6.02.4060E 6.04.4060 6.05.2240 6.11.2260 -
800 1 6.01.2200 6.01.2200E 6.02.4080 6.02.4080E 6.04.4080 6.05.2240 6.11.2280 -
400 1 6.01.2200 6.01.2200E 6.02.6040 6.02.6040E 6.04.6040 6.05.2260 6.11.2240 6.31.2260
600 500 1 6.01.2200 6.01.2200E 6.02.6050 6.02.6050E 6.04.6050 6.05.2260 6.11.2250 6.31.2260
600 1 6.01.2200 6.01.2200E 6.02.6060 6.02.6060E 6.04.6060 6.05.2260 6.11.2260 6.31.2260
800 1 6.01.2200 6.01.2200E 6.02.6080 6.02.6080E 6.04.6080 6.05.2260 6.11.2280 6.31.2260
400 1 6.01.2200 6.01.2200E 6.02.8040 6.02.8040E 6.04.8040 6.05.2280 6.11.2240 6.31.2280
2200 800 500 1 6.01.2200 6.01.2200E 6.02.8050 6.02.8050E 6.04.8050 6.05.2280 6.11.2250 6.31.2280
600 1 6.01.2200 6.01.2200E 6.02.8060 6.02.8060E 6.04.8060 6.05.2280 6.11.2260 6.31.2280
800 1 6.01.2200 6.01.2200E 6.02.8080 6.02.8080E 6.04.8080 6.05.2280 6.11.2280 6.31.2280
400 1 6.01.2200 6.01.2200E 6.02.1040 6.02.1040E 6.04.1040 6.05.2210 6.11.2240 6.31.2210
1000 500 1 6.01.2200 6.01.2200E 6.02.1050 6.02.1050E 6.04.1050 6.05.2210 6.11.2250 6.31.2210
600 1 6.01.2200 6.01.2200E 6.02.1060 6.02.1060E 6.04.1060 6.05.2210 6.11.2260 6.31.2210
800 1 6.01.2200 6.01.2200E 6.02.1080 6.02.1080E 6.04.1080 6.05.2210 6.11.2280 6.31.2210
400 2 6.01.2200 6.01.2200E 6.02.1240 6.02.1240E 6.04.1240 6.05.2212-2D 6.11.2240 6.31.2212
1200 500 2 6.01.2200 6.01.2200E 6.02.1250 6.02.1250E 6.04.1250 6.05.2212-2D 6.11.2250 6.31.2212
600 2 6.01.2200 6.01.2200E 6.02.1260 6.02.1260E 6.04.1260 6.05.2212-2D 6.11.2260 6.31.2212
800 2 6.01.2200 6.01.2200E 6.02.1280 6.02.1280E 6.04.1280 6.05.2212-2D 6.11.2280 6.31.2212
Note : extended vertical uprights and extended top and bottom frames are required when two columns are joined back-to back
33
A
2. Welded frames
Consisting of vertical uprights , top and bottom frames welded together to form a cubicle
Enclosure dimensions, mm OrderCode Nr. Enclosure dimensions, mm OrderCode Nr.
Height Width Depth Frames extendable Frames extendable Height Width Depth Frames extendable Frames extendable
side-by-side front-to-rear side-by-side front-to-rear
400 6.126040S 6.126040E 300 500 6.203050S 6.203050E

500 6.126050S 6.126050E 600 6.203060S 6.203060E
600 400 6.204040S 6.204040E
600 6.126060S 6.126060E
800 6.126080S 6.126080E 400 500 6.204050S 6.204050E
1200
400 6.128040S 6.128040E 600 6.204060S 6.204060E
500 6.128050S 6.128050E 800 6.204080S 6.204080E
800 400 6.206040S 6.206040E
600 6.128060S 6.128060E
800 6.128080S 6.128080E 600 500 6.206050S 6.206050E
400 6.146040S 6.146040E 600 6.206060S 6.206060E
500 6.146050S 6.146050E 800 6.206080S 6.206080E
600 400 6.208040S 6.208040E
600 6.146060S 6.146060E
800 6.146080S 6.146080E 2000 800 500 6.208050S 6.208050E
1400
400 6.148040S 6.148040E 600 6.208060S 6.208060E
500 6.148050S 6.148050E 800 6.208080S 6.208080E
800 400 6.201040S 6.201040E
600 6.148060S 6.148060E
800 6.148080S 6.148080E 1000 500 6.201050S 6.201050E
400 6.166040S 6.166040E 600 6.201060S 6.201060E
500 6.166050S 6.166050E 800 6.201080S 6.201080E
600 400 6.201240S 6.201240E
600 6.166060S 6.166060E
800 6.166080S 6.166080E 1200 500 6.201250S 6.201250E
1600
400 6.168040S 6.168040E 600 6.201260S 6.201260E
500 6.168050S 6.168050E 800 6.201280S 6.201280E
800 400 6.201640S 6.201640E
600 6.168060S 6.168060E
800 6.168080S 6.168080E 1600 500 6.201650S 6.201650E
400 6.184040S 6.184040E 600 6.201660S 6.201660E
500 6.184050S 6.184050E 400 6.224040S 6.224040E
400 400 500 6.224050S 6.224050E
600 6.184060S 6.184060E
800 6.184080S 6.184080E 600 6.224060S 6.224060E
400 6.186040S 6.186040E 800 6.224080S 6.224080E
500 6.186050S 6.186050E 400 6.226040S 6.226040E
600 500 6.226050S 6.226050E
600 6.186060S 6.186060E
800 6.186080S 6.186080E 600 600 6.226060S 6.226060E
400 6.188040S 6.188040E 800 6.226080S 6.226080E
500 6.188050S 6.188050E 2200 400 6.228040S 6.228040E
1800 800
600 6.188060S 6.188060E 800 500 6.228050S 6.228050E
800 6.188080S 6.188080E 600 6.228060S 6.228060E
400 6.181040S 6.181040E 800 6.228080S 6.228080E
500 6.181050S 6.181050E 400 6.221040S 6.221040E
1000 500 6.221050S 6.221050E
600 6.181060S 6.181060E 1000
800 6.181080S 6.181080E 600 6.221060S 6.221060E
400 6.181240S 6.181240E 800 6.221080S 6.221080E
500 6.181250S 6.181250E 400 6.221240S 6.221240E
1200 500 6.221250S 6.221250E
600 6.181260S 6.181260E 1200
800 6.181280S 6.181280E 600 6.221260S 6.221260E
800 6.221280S 6.221280E
Packed and ready for delivery.

34
Frames, door, panels and plinths
35
A
1 Vertical uprights
Packs of 4.
Height Standard version Extended version
1600 6.01.1600 6.01.1600E
1800 6.01.1800 6.01.1800E
2000 6.01.2000 6.01.2000E
2200 6.01.2200 6.01.2200E
2. Centre bar upright

Packs of 1.
Height
1600 6.01.1600C
1800 6.01.1800C
2000 6.01.2000C
2200 6.01.2200C
3. Top and bottom frames

Packs of 1 pair set.

Width Depth Standard version Extended version
400 6.02.4040 6.02.4040E
500 6.02.4050 6.02.4050E Vertical uprights Centre bar uprights
400
600 6.02.4060 6.02.4060E
800 6.02.4080 6.02.4080E
400 6.02.6040 6.02.6040E
500 6.02.6050 6.02.6050E
600
600 6.02.6060 6.02.6060E
800 6.02.6080 6.02.6080E
400 6.02.7040 6.02.7040E
500 6.02.7050 6.02.7050E
700
600 6.02.7060 6.02.7060E
800 6.02.7080 6.02.7080E
400 6.02.8040 6.02.8040E
500 6.02.8050 6.02.8050E
800
600 6.02.8060 6.02.8060E
800 6.02.8080 6.02.8080E
400 6.02.9040 6.02.9040E
500 6.02.9050 6.02.9050E
900
600 6.02.9060 6.02.9060E
800 6.02.9080 6.02.9080E
400 6.02.1040 6.02.1040E
500 6.02.1050 6.02.1050E
1000
600 6.02.1060 6.02.1060E
800 6.02.1080 6.02.1080E
400 6.02.1240 6.02.1240E
500 6.02.1250 6.02.1250E
1200
600 6.02.1260 6.02.1260E
800 6.02.1280 6.02.1280E
Top and bottom frame

36
A7 - Frames, door, panels and plinths
4. Single leaf doors - plain

Mounted with door stiffeners, swing handle key alike
locking system.
Packs of 1.
Height Width Plain Standard Version Plain - Centre Bar Version
300 6.06.1630 6.06.1630.CB
400 6.06.1640 6.06.1640.CB
600 6.06.1660 6.06.1660.CB
1600 700 6.06.1670 6.06.1670.CB
800 6.06.1680 6.06.1680.CB
900 6.06.1690 6.06.1690.CB
1000 6.06.1610 6.06.1610.CB
300 6.06.1830 6.06.1830.CB
400 6.06.1840 6.06.1840.CB
600 6.06.1860 6.06.1860.CB
1800 700 6.06.1870 6.06.1870.CB
800 6.06.1880 6.06.1880.CB
900 6.06.1890 6.06.1890.CB
1000 6.06.1810 6.06.1810.CB
300 6.06.2030 6.06.2030.CB
400 6.06.2040 6.06.2040.CB
600 6.06.2060 6.06.2060.CB
2000 700 6.06.2070 6.06.2070.CB
800 6.06.2080 6.06.2080.CB
900 6.06.2090 6.06.2090.CB
1000 6.06.2010 6.06.2010.CB
300 6.06.2230 6.06.2230.CB
400 6.06.2240 6.06.2240.CB
600 6.06.2260 6.06.2260.CB
2200 700 6.06.2270 6.06.2270.CB
800 6.06.2280 6.06.2280.CB
900 6.06.2290 6.06.2290.CB
1000 6.06.2210 6.06.2210.CB
Single leaf doors - plain
5 Single leaf doors - transparent - packs of 1

Mounted with door stiffeners, swing handle key alike locking system.
4
Transparent door, it is mounted with 4mm e
safety tempered glass.

Height Width Cut-out centred Cut-out offset to lock Cut-out offset to hinge
400 6.06.1640C - -
600 6.06.1660C - -
1600 700 6.06.1670C - -
800 6.06.1680C 6.06.1680L 6.06.1680H
900 6.06.1690C 6.06.1690L 6.06.1690H
1000 6.06.1610C 6.06.1610L 6.06.1610H
400 6.06.1840C - -
600 6.06.1860C - -
1800 700 6.06.1870C - -
800 6.06.1880C 6.06.1880L 6.06.1880H
900 6.06.1890C 6.06.1890L 6.06.1890H
1000 6.06.1810C 6.06.1810L 6.06.1810H
400 6.06.2040C - -
600 6.06.2060C - -
2000 700 6.06.2070C - -
800 6.06.2080C 6.06.2080L 6.06.2080H
900 6.06.2090C 6.06.2090L 6.06.2090H
1000 6.06.2010C 6.06.2010L 6.06.2010H
400 6.06.2240C - -
600 6.06.2260C - -
2200 700 6.06.2270C - -
800 6.06.2280C 6.06.2280L 6.06.2280H
900 6.06.2290C 6.06.2290L 6.06.2290H
1000 6.06.2210C 6.06.2210L 6.06.2210H
Note : for door cut-out with radius -add “R” to the OrderCode Nr. For example : 6.06.2060C-R Single leaf doors - transparent
37
A
6. Overlapping doors - equal width

Mounted with door stiffeners, swing handle key alike
locking system.
Height Width Plain Standard Version Removable Centre Bar Version
1600 1000 6.07.1610 6.07.1610B
1200 6.07.1612 6.07.1612B
1800 1000 6.07.1810 6.07.1810B
1200 6.07.1812 6.07.1812B
2000 1000 6.07.2010 6.07.2010B
1200 6.07.2012 6.07.2012B
2200 1000 6.07.2210 6.07.2210B
1200 6.07.2212 6.07.2212B
7. Roof panels - packs of 1 Overlapping doors - equal width

Width Depth Plain version
400 6.04.4040
400 500 6.04.4050
600 6.04.4060
800 6.04.4080
400 6.04.6040
600 500 6.04.6050
600 6.04.6060
800 6.04.6080
400 6.04.7040
700 500 6.04.7050
600 6.04.7060
800 6.04.7080
400 6.04.8040 Roof panel
800 500 6.04.8050
600 6.04.8060
800 6.04.8080
400 6.04.9040
500 6.04.9050
8. Rear panels - packs of 1
900
600 6.04.9060
800 6.04.9080 Enclosure nominal dimensions, mm OrderCode Nr.
400 6.04.1040 Height Width Plain version
1000 500 6.04.1050 400 6.09.1640
600 6.04.1060 600 6.09.1660
800 6.04.1080 700 6.09.1670
400 6.04.1240 1600 800 6.09.1680
1200 500 6.04.1250 900 6.09.1690
600 6.04.1260 1000 6.09.1610
800 6.04.1280 1200 6.09.1612
400 6.09.1840
Note: Part of OrderCodeNrs 6.04.6080 and 600 6.09.1860
6.04.8060 are identical 700 6.09.1870
1800 800 6.09.1880
900 6.09.1890
1000 6.09.1810
1200 6.09.1812
400 6.09.2040
600 6.09.2060
700 6.09.2070
2000 800 6.09.2080
900 6.09.2090
1000 6.09.2010
1200 6.09.2012
400 6.09.2240
600 6.09.2260
700 6.09.2270
2200 800 6.09.2280
900 6.09.2290
1000 6.09.2210
1200 6.09.2212
Rear panels - packs of 1
38
9. Side panels - packs of 2

Height Width Depth Plain version Extended Version
- 400 6.11.1640 6.11.1640E
- 500 6.11.1650 6.11.1650E
1600
- 600 6.11.1660 6.11.1660E
- 800 6.11.1680 6.11.1680E
- 400 6.11.1840 6.11.1840E
- 500 6.11.1850 6.11.1850E
1800
- 600 6.11.1860 6.11.1860E
- 800 6.11.1880 6.11.1880E
- 400 6.11.2040 6.11.2040E
- 500 6.11.2050 6.11.2050E
2000
- 600 6.11.2060 6.11.2060E
- 800 6.11.2080 6.11.2080E
- 400 6.11.2240 6.11.2240E
- 500 6.11.2250 6.11.2250E
2200
- 600 6.11.2260 6.11.2260E
- 800 6.11.2280 6.11.2280E
Side panels - packs of 2
10. Roof panel infill

To close the gap when roof panels are bayed side-to-side or
front to rear.
Packs of 4.
width / depth, mm
300 6.17.0300
400 6.17.0400
500 6.17.0500
600 6.17.0600
Roof panel infill
700 6.17.0700
800 6.17.0800
900 6.17.0900
1000 6.17.1000
11. Cable entry module - side opening

To be positioned at the end of a enclosure suite.
For protecting cable / busbar and connector systems.
Supply includes: basic frame column, side and roof panels,
gasketed door mounted with stiffeners and swing handle key
alike locking system.
Packs of 1 set.

Height Width Depth Plain version
500 6.14.1650
1600 600 6.14.1660
800 6.14.1680
500 6.14.1850
1800 600 6.14.1860
800 300 6.14.1880
500 6.14.2050
2000 600 6.14.2060
800 6.14.2080
500 6.14.2250
2200 600 6.14.2260
800 6.14.2280
Cable entry module - side opening
39
A
12. Cable entry module - front opening

To be used as an end or an intermediate element in a suite
of enclosures.
Front and/or rear access.
Supply includes: basic frame, top and rear panels, gasket-
ed door mounted with swing handle key alike locking system.
Packs of 1 set.
Height Width Depth Plain version
400 6.15.1640
1600 500 6.15.1650
600 6.15.1660
800 6.15.1680
400 6.15.1840
1800 500 6.15.1850
600 6.15.1860
300 800 6.15.1880
400 6.15.2040
2000 500 6.15.2050
600 6.15.2060
800 6.15.2080
400 6.15.2240
2200 500 6.15.2250
600 6.15.2260
800 6.15.2280
Cable entry module - front opening
13. Plinth/base components, front and rear.

Supply includes: 4 corners and 2 cross channels.
Enclosure OrderCode Nr.
width, mm 100 mm high 200 mm high
300 6.20.1030 6.20.2030
400 6.20.1040 6.20.2040
500 6.20.1050 6.20.2050
600 6.20.1060 6.20.2060
700 6.20.1070 6.20.2070
800 6.20.1080 6.20.2080
900 6.20.1090 6.20.2090
1000 6.20.1100 6.20.2100 Plinth/base components, front and rear
1100 6.20.1110 6.20.2110
1200 6.20.1120 6.20.2120
1300 6.20.1130 6.20.2130
1400 6.20.1140 6.20.2140
14. Plinth/base - side trim

Supply includes: 2 trim channels (4 trim channels in
case of 200mm high plinth)

depth, mm 100 mm high 200 mm high Plinth/base - side trim
300 6.21.1030 6.21.2030
400 6.21.1040 6.21.2040
600 6.21.1060 6.21.2060
800 6.21.1080 6.21.2080
1000 6.21.1100 6.21.2100
15. Lifting Eyebolts, M12

Packs of 4.
16. Lifting brackets

Packs of 4.
OrderCode Nr. 6.00.0002
Lifting Eyebolts, M12 Lifting brackets

40
17. Baying / joining set - cubicle suite

Use to grant more rigidity to enclosures joined in a suite.
Baying / joining set - cubicle suite
18. Door retainer

Holds the door open at 120 degree to avoid accidental
closing.
Door retainer
19 Document pockets
Mount to the door stiffeners.
For door OrderCode Nr.
width, mm
400 6.19.0400
500 6.19.0500
600 6.19.0600
700 6.19.0700
800 6.19.0800
Document pockets
20. Door switch c/w mounting brackets
Door switch c/w mounting brackets

OrderCode Nr. LAMP 68
Compact fluorescent lamp

22. Spray touch-up paint - aerosol can

RAL 7032 SC-7032
RAL 7035 SC-7035
Spray touch-up paint.

41
A
23. Mounting brackets

Material: Zinc passivated steel
Packs of 4.
Mounting brackets
24. Spacers - for roof panel

To raise the roof for ventilation purposes, in three different
heights.
Packs of 4.
Height, mm OrderCode Nr.
10 6.00.0006
20 6.00.0007
50 6.00.0008
Spacers - for roof panel
25. Levelling feet

To compensate for height differences with floor irregularities.
Packs of 4.
Levelling feet
26. Cage nuts

Install on enclosures, punched sections and rails with
rectangular system punching 12.5 x 10.5 mm
Packs of 50.
OrderCode Nr. Thread
CN-M6-50 M6
CN-M8-50 M8
Cage nuts
27. Self- tapping screws

For the round holes 4.5 mm diameter in the enclosure section,
punched sections and punched rails
Packs of 500 pcs.
OrderCode Nr. Dimensions, mm Type of Screw

HHST-M5x10-500 M5 x 10 Hex flanged head
HHST-M5x12-500 M5 x 12 Hex flanged head
PHST-M5x12-500 M5 x 12 Philip head
Self-tapping screws
42
Gland plates, mounting plates, side dividers and 19” frames.
43
A
1. Bottom gland plates - one piece type

Packs of 1.

width, mm depth, mm Plain type
400 6.25.3040
500 6.25.3050
300 600 6.25.3060
800 6.25.3080
400 6.25.4040
500 6.25.4050
400 600 6.25.4060
800 6.25.4080
400 6.25.5040
500 6.25.5050
500 600 6.25.5060
800 6.25.5080
400 6.25.6040
500 6.25.6050
600 600 6.25.6060
800 6.25.6080
400 6.25.7040
500 6.25.7050 Bottom gland plate
700 600 6.25.7060
800 6.25.7080
400 6.25.8040
500 6.25.8050
800 600 6.25.8060
800 6.25.8080
2. Bottom gland plates - 3 piece type

Packs of 1 set.
width, mm depth, mm Plain type
400 6.26.4040
500 6.26.4050
400 600 6.26.4060
800 6.26.4080
400 6.26.5040
500 6.26.5050
500 600 6.26.5060
800 6.26.5080
400 6.26.6040
500 6.26.6050
600 600 6.26.6060
800 6.26.6080
400 6.26.7040
500 6.26.7050
700 600 6.26.7060
800 6.26.7080
400 6.26.8040
500 6.26.8050
800 600 6.26.8060
800 6.26.8080 Bottom gland plate - 3 piece type
3. Bottom brackets - for mounting gland plates

Packs of 2.
depth, mm
400 6.29.0400
500 6.29.0500
600 6.29.0600
800 6.29.0800
Bottom brackets - for mounting gland plates

44
A7 - Gland plates, mounting plates, side dividers and 19” frames
4 Full height mounting plates

Packs of 1, come with mounting brackets.

height, mm width, mm Plain type
400 6.31.1640
500 6.31.1650
600 6.31.1660
700 6.31.1670
1600
800 6.31.1680
900 6.31.1690
1000 6.31.1610
1200 6.31.1612
400 6.31.1840
500 6.31.1850
600 6.31.1860
700 6.31.1870
1800
800 6.31.1880
900 6.31.1890
1000 6.31.1810
1200 6.31.1812
400 6.31.2040
500 6.31.2050
600 6.31.2060
700 6.31.2070
2000
800 6.31.2080
900 6.31.2090
1000 6.31.2010
1200 6.31.2012
400 6.31.2240
500 6.31.2250
600 6.31.2260
700 6.31.2270
2200
800 6.31.2280
900 6.31.2290
1000 6.31.2210
1200 6.31.2212
5. Intermediate mounting plates Full height mounting plates Intermediate mounting plates
Packs of 1.
height, mm
1600 6.32.1600
1800 6.32.1800
2000 6.32.2000
2200 6.32.2200
6. Depth profiles
RAL 7035
Packs of 4.

depth, mm
400 6.59.0400
500 6.59.0500
600 6.59.0600
800 6.59.0800
Depth profiles
45
A
7 Partial mounting plates

Packs of 1,
For compartment For enclosures OrderCode Nr.

height, mm width / depth, mm Plain type
600 6.33.6060
800 6.33.8060
600
1000 6.33.1060
1200 6.33.1260
600 6.33.6070
800 6.33.8070
700
1000 6.33.1070
1200 6.33.1270
600 6.33.6080
800 6.33.8080
800
1000 6.33.1080
1200 6.33.1280 Partial mounting plates - rear view

Packs of 1 set.
For enclosure For enclosure For compartment OrderCode Nr.
height, mm width, mm width, mm Installed centre Installed offset
700 600 6.37.1670C 6.37.1670S
1600
800 700 6.37.1680C 6.37.1680S
700 600 6.37.1870C 6.37.1870S
1800
800 700 6.37.1880C 6.37.1880S
700 600 6.37.2070C 6.37.2070S
2000
800 700 6.37.2080C 6.37.2080S
700 600 6.37.2270C 6.37.2270S
2200
800 700 6.37.2280C 6.37.2280S
19” swing frames

46
A7 - Gland plates, mounting plates, side dividers and 19” frames

Packs of 1 set.
For enclosure For enclosure For compartment OrderCode Nr.

height, mm width, mm width, mm Installed centre
600 500 6.38.1660
1600 700 600 6.38.1670
800 700 6.38.1680
600 500 6.38.1860
1800 700 600 6.38.1870
800 700 6.38.1880
600 500 6.38.2060
2000 700 600 6.38.2070
800 700 6.38.2080
600 500 6.38.2260
2200 700 600 6.38.2270
800 700 6.38.2280
19” Fixed frames
10. Inter-cubicle partitions

Metal partition, used to separate two adjacent cubicles.
It is made up of two panels, each half the height of the
enclosures.
The top and bottom ends have knock-outs for busbars and
conductors.
The partition is mounted on the framework and does not hinder
installation of the
functional mounting plates.
Packs of 2 pieces.
For enclosure Compartment

OrderCode Nr.
height, mm depth, mm depth, mm
400 6.16.1640 300
500 6.16.1650 400
1600
600 6.16.1660 500
800 6.16.1680 700
400 6.16.1840 300
500 6.16.1850 400
1800
600 6.16.1860 500
800 6.16.1880 700
400 6.16.2040 300
500 6.16.2050 400
2000
600 6.16.2060 500
800 6.16.2080 700
400 6.16.2240 300
500 6.16.2250 400
2200
600 6.16.2260 500
800 6.16.2280 700
Inter-cubicle partitions
47
A
11. Front cover panels

Packs of 1.
For enclosure For compartment

OrderCode Nr.
height, mm width, mm
150 6.12.1615
1600
250 6.12.1625
150 6.12.1815
1800
250 6.12.1825
150 6.12.2015
2000
250 6.12.2025
150 6.12.2215
2200
250 6.12.2225
Front cover panel (front & back view)
12. Horizontal mounting plate - plain

Packs of 1.
OrderCode Nr.
Mounting plate for enclosure width, mm
depth mm
400 500 600 700 800
200 6.78.4020 6.78.5020 6.78.6020 6.78.7020 6.78.8020
250 6.78.4025 6.78.5025 6.78.6025 6.78.7025 6.78.8025
300 6.78.4030 6.78.5030 6.78.6030 6.78.7030 6.78.8030
400 6.78.4040 6.78.5040 6.78.6040 6.78.7040 6.78.8040
500 6.78.4050 6.78.5050 6.78.6050 6.78.7050 6.78.8050
Horizontal mounting plate - plain (front & back view)
13. Depth rails for horizontal mounting plate

Packs of 2.
For compartment Component

OrderCode Nr.
depth, mm length, mm
200 6.49.0200 200
250 6.49.0250 250
300 6.49.0300 300
400 6.49.0400 400
500 6.49.0500 500
Depth rails
48
Form 2 - 4 structures
49
A
1. Functional space side panels - closed and open

Packs of 2
For enclosure Space side panel OrderCode Nr.

Height, mm Depth, mm Closed Panel Open Panel
200 6.70.1620 6.71.1620
225 6.70.1622 6.71.1622
1600 250 6.70.1625 6.71.1625
300 6.70.1630 6.71.1630
400 6.70.1640 6.71.1640
200 6.70.1820 6.71.1820
225 6.70.1822 6.71.1822
1800 250 6.70.1825 6.71.1825
300 6.70.1830 6.71.1830
400 6.70.1840 6.71.1840
200 6.70.2020 6.71.2020
225 6.70.2022 6.71.2022
2000 250 6.70.2025 6.71.2025
300 6.70.2030 6.71.2030
400 6.70.2040 6.71.2040
200 6.70.2220 6.71.2220
225 6.70.2222 6.71.2222
2200 250 6.70.2225 6.71.2225
300 6.70.2230 6.71.2230
400 6.70.2240 6.71.2240
2 Partial doors - plain

Material: electro galvanised steel. RAL7035.
Packs of 1, comes with hinges and quarter turn 5mm double bit insert lock
and assembly accessories
Functional space side panels - closed and open
For Number of OrderCode Nr.
partial door quarter turn for enclosure width, mm (View as when fixed)
height, mm locks 300 400 500 600 700 800
200 1 - 6.73.0240 6.73.0250 6.73.0260 6.73.0270 6.73.0280
250 1 - 6.73.2540 6.73.2550 6.73.2560 6.73.2570 6.73.2580
300 1 - 6.73.3040 6.73.3050 6.73.3060 6.73.3070 6.73.3080
400 1 - 6.73.4040 6.73.4050 6.73.4060 6.73.4070 6.73.4080
500 2 - 6.73.5040 6.73.5050 6.73.5060 6.73.5070 6.73.5080
600 2 - 6.73.6040 6.73.6050 6.73.6060 6.73.6070 6.73.6080
800 2 - 6.73.8040 6.73.8050 6.73.8060 6.73.8070 6.73.8080
1000 2 - 6.73.1040 6.73.1050 6.73.1060 6.73.1070 6.73.1080
1400 3 - 6.73.1440 6.73.1450 6.73.1460 6.73.1470 6.73.1480
1600 3 6.73.1630 6.73.1640 6.73.1650 6.73.1660 6.73.1670 6.73.1680
1800 3 6.73.1830 6.73.1840 6.73.1850 6.73.1860 6.73.1870 6.73.1880
2000 3 6.73.2030 6.73.2040 6.73.2050 6.73.2060 6.73.2070 6.73.2080
Partial doors - plain

50
A7 - Form 2 - 4 structures
3 Partial doors - Full height type - plain

Packs of 1, comes with hinges and quarter turn 5 mm double bit insert lock
and assembly accessories
For enclosure Number of OrderCode Nr.

height, mm quarter turn locks for enclosure width, mm
300 400 500 600 700
1600 3 6.73.1630.FH 6.73.1640.FH 6.73.1650.FH 6.73.1660.FH 6.73.1670.FH
1800 3 6.73.1830.FH 6.73.1840.FH 6.73.1850.FH 6.73.1860.FH 6.73.1870.FH
2000 3 6.73.2030.FH 6.73.2040.FH 6.73.2050.FH 6.73.2060.FH 6.73.2070.FH
2200 3 6.73.2230.FH 6.73.2240.FH 6.73.2250.FH 6.73.2260.FH 6.73.2270.FH
4. Partial doors - Customised

RAL7035.
Packs of 1, comes with hinges and quarter turn 5mm
double bit insert lock and assembly accessories
Cut-out dimensions ( Height x Width mm ) and location on
the door panel shall base on buyer’s request.
Providing additional information such as Breaker Brand and
Model would be most useful. Partial doors - Full height type - plain
For Number of OrderCode Nr.

partial door quarter turn for enclosure width, mm
height, mm locks 400 500 600 700 800
200 1 6.80.0240(H..xD..) 6.80.0250(H..xD..) 6.80.0260(H..xD..) 6.80.0270(H..xD..) 6.80.0280(H..xD..)
5. Door cross tie Partial doors - Customised

For use as sealing member between partial doors and trim panels.
Packs of 6, come with assembly accessories
For enclosure width, mm Component length, mm OrderCode Nr.

400 300 6.72.0400
500 400 6.72.0500
600 500 6.72.0600
700 600 6.72.0700
800 700 6.72.0800
Door cross tie

51
A
6. Intermediate Uprights, 50x50 mm and 50x25 mm.

Finish: RAL7035.
Packs of 2
For enclosure Component OrderCode Nr.

height, mm length, mm 50x50 mm 50x25 mm
1600 1500 6.44.1600 6.43.1600
1800 1700 6.44.1800 6.43.1800
2000 1900 6.44.2000 6.43.2000
2200 2100 6.44.2200 6.43.2200
7. Intermediate Uprights, 50x100mm.

RAL7035.
Packs of 2
height, mm length, mm
1600 1500 6.63.1600
1800 1700 6.63.1800
2000 1900 6.63.2000
2200 2100 6.63.2200
Intermediate Uprights
8 Punched sections 50x50 mm and 50x25 mm

Packs of 2 including support brackets

width/depth, mm length, mm 50x50 mm 50x25 mm
300 200 6.60.0300 6.61.0300
400 300 6.60.0400 6.61.0400
500 400 6.60.0500 6.61.0500
600 500 6.60.0600 6.61.0600
700 600 6.60.0700 6.61.0700
800 700 6.60.0800 6.61.0800
900 800 6.60.0900 6.61.0900
1000 900 6.60.1000 6.61.1000
1100 1000 6.60.1100 6.61.1100
1200 1100 6.60.1200 6.61.1200
Punched sections 50x50 mm and 50x25 mm
52
9. Front trim panels, Height: 100 mm.

Required as upper and lower height filler when partial doors are
used.
Packs of 1 set, combination of top and bottom 100mm high
trim panels including assembly accessories.
OrderCode Nr.
Design Packs of For enclosure width, mm
400 500 600 700 800
IP 55 sealed 1 set 6.81.0400 6.81.0500 6.81.0600 6.81.0700 6.81.0800 Front trim panel
IP2X ventilated 1 set 6.82.0400 6.82.0500 6.82.0600 6.82.0700 6.82.0800
10. Front trim panels for busbar compartment

To conceal a 300mm high busbar compartment. RAL7035.
Packs of 1 set, combination of 300mm and 100mm front trim panel
and assembly parts.
For enclosure Height of front trim panels OrderCode Nr

width, mm Top, mm Bottom, mm IP 55 Sealed IP 2X Vented
400 300 100 6.83.0400 6.84.0400
500 300 100 6.83.0500 6.84.0500
600 300 100 6.83.0600 6.84.0600
700 300 100 6.83.0700 6.84.0700
800 300 100 6.83.0800 6.84.0800
400 100 300 6.83.0400.B 6.84.0400.B
500 100 300 6.83.0500.B 6.84.0500.B
600 100 300 6.83.0600.B 6.84.0600.B
700 100 300 6.83.0700.B 6.84.0700.B
800 100 300 6.83.0800.B 6.84.0800.B
Front trim panels for busbar compartment
11. Modular panels - plain

Packs of 2
OrderCode Nr.
For panel for enclosure width, mm
height mm
400 500 600 700 800
100 6.92.1040 6.92.1050 6.92.1060 6.92.1070 6.92.1080
150 6.92.1540 6.92.1550 6.92.1560 6.92.1570 6.92.1580
200 6.92.2040 6.92.2050 6.92.2060 6.92.2070 6.92.2080
300 6.92.3040 6.92.3050 6.92.3060 6.92.3070 6.92.3080
400 6.92.4040 6.92.4050 6.92.4060 6.92.4070 6.92.4080
500 6.92.5040 6.92.5050 6.92.5060 6.92.5070 6.92.5080
600 6.92.6040 6.92.6050 6.92.6060 6.92.6070 6.92.6080
700 6.92.7040 6.92.7050 6.92.7060 6.92.7070 6.92.7080
Modular panel - plain
12. Modular panels - Customised

Cut-out dimensions ( Height x Width mm ) and location on the panel
shall base on buyer’s request.
Providing additional information such as Breaker Brand and Model
would be most useful.
Packs of 1.
For Panel OrderCode Nr.

Height,
g for enclosure width, mm
mm 400 500 600 700 800
200 6.90.2040(H..xD..) 6.90.2050(H..xD..) 6.90.2060(H..xD..) 6.90.2070(H..xD..) 6.90.2080(H..xD..)
Modular panel - customised

53
A
13. Modular panels - Vented

RAL7035.
Packs of 2
OrderCode Nr.
For panel for enclosure width, mm
height, mm
400 500 600 700 800
100 6.91.1040 6.91.1050 6.91.1060 6.91.1070 6.91.1080
150 6.91.1540 6.91.1550 6.91.1560 6.91.1570 6.91.1580
200 6.91.2040 6.91.2050 6.91.2060 6.91.2070 6.91.2080
300 6.91.3040 6.91.3050 6.91.3060 6.91.3070 6.91.3080
400 6.91.4040 6.91.4050 6.91.4060 6.91.4070 6.91.4080
500 6.91.5040 6.91.5050 6.91.5060 6.91.5070 6.91.5080
600 6.91.6040 6.91.6050 6.91.6060 6.91.6070 6.91.6080
700 6.91.7040 6.91.7050 6.91.7060 6.91.7070 6.91.7080
Modular panels - Vented
14. Modular panels - DIN cut-out

Packs of 2
Modular panel - Din cut-outs

OrderCode Nr.
For panel Cut-out
height, with for enclosure width, mm
mm DIN row 400[12DIN module] 500 [16 DIN module] 600 [24 DIN module] 700 [30 DIN module] 800 [36DIN module]
150 1 row 6.95.1540 6.95.1550 6.95.1560 6.95.1570 6.95.1580
200 1 row 6.95.2040 6.95.2050 6.95.2060 6.95.2070 6.95.2080
300 2 rows 6.95.3040 6.95.3050 6.95.3060 6.95.3070 6.95.3080
600 3 rows 6.95.6040 6.95.6050 6.95.6060 6.95.6070 6.95.6080
15. Modular panels - meter device 72x72 and 96x96 mm cut-outs

Packs of 2.
Modular panelW - meter device cut-outs
OrderCode Nr.
For panel Cut-out for
for enclosure width, mm
height, mm meter device
400 500 600 700 800
150 72x72 mm 6.94.1472 6.94.1572 6.94.1672 6.94.1772 6.94.1872
150 96x96 mm 6.94.1496 6.94.1596 6.94.1696 6.94.1796 6.94.1896
200 72x72 mm 6.94.2472 6.94.2572 6.94.2672 6.94.2772 6.94.2872
200 96x96 mm 6.94.2496 6.94.2596 6.94.2696 6.94.2796 6.94.2896
16. Support rails DIN 35 / 7.5

Packs of 6.
OrderCode Nr. for enclosure width, mm
400 500 600 700 800
6.93.0400 6.93.0500 6.93.0600 6.93.0700 6.93.0800
Support rails DIN 35 / 7.5

54
17. Support rails DIN 35 / 15

Packs of 6.

400 500 600 700 800
6.96.0400 6.96.0500 6.96.0600 6.96.0700 6.96.0800
Support rails DIN 35 / 15
18. Slide rails with flanges

Packs of 10, including angle brackets
For compartment OrderCode Nr. Component
200 6.54.0200 200
225 6.54.0225 225
250 6.54.0250 250
300 6.54.0300 300
350 6.54.0350 350
400 6.54.0400 400
500 6.54.0500 500
Slide rails with flanges
19. Slide rails without flanges

Packs of 10, including angle brackets
For compartment OrderCode Nr. Component

200 6.53.0200 200
225 6.53.0225 225
250 6.53.0250 250
300 6.53.0300 300
350 6.53.0350 350
400 6.53.0400 400
500 6.53.0500 500
Slide rails without flanges
20. Slide rails - come with one flange

Packs of 10, including angle brackets.
Component OrderCode Nr.
length, mm
150 6.56.0150
100 6.56.0100
Slide rails with one flange

21. Back mounting plate - plain
For direct fixing to the angle brackets of the slide rails.
Material : zincpassivated steel.
Packs of 4,
For Mounting OrderCode Nr. for enclosure width, mm
compartment plate
height, mm height, mm 400 500 600 700 800
200 190 6.79.2040 6.79.2050 6.79.2060 6.79.2070 6.79.2080
250 240 6.79.2540 6.79.2550 6.79.2560 6.79.2570 6.79.2580
300 290 6.79.3040 6.79.3050 6.79.3060 6.79.3070 6.79.3080
400 390 6.79.4040 6.79.4050 6.79.4060 6.79.4070 6.79.4080
600 590 6.79.6040 6.79.6050 6.79.6060 6.79.6070 6.79.6080
700 690 6.79.7040 6.79.7050 6.79.7060 6.79.7070 6.79.7080
Back mounting plate - plain

55
A
22. Vertical brackets - Back Mounting Plate

For installing the Back Mounting Plates to the functional
space side panels
Packs of 4.
For compartment Mounting plate OrderCode Nr.

height, mm height, mm
200 190 6.85.0200
250 240 6.85.0250
300 290 6.85.0300
400 390 6.85.0400
500 490 6.85.0500
600 590 6.85.0600
700 690 6.85.0700
23. Feedback rails

Packs of 10, including assembly accessories Vertical brackets - Back mounting plate

400 500 600 700 800
6.86.0400 6.86.0500 6.86.0600 6.86.0700 6.86.0800
24 Feedback mounting plate - plain

Packs of 4, including assembly fasteners
Feedback rails
OrderCode Nr.
For compartment
height, mm feedback mounting plate width, mm
200 250 300 350 400
200 6.87.2020 6.87.2025 6.87.2030 - -
300 6.87.3020 6.87.3025 6.87.3030 - -
400 - 6.87.4025 6.87.4030 6.87.4035 -
500 - - 6.87.5030 6.87.5035 6.87.5040
600 - - 6.87.6030 6.87.6035 6.87.6040
700 - - 6.87.7035 6.87.7040
25 Horizontal functional space divider

For horizontal separation of compartments.
Packs of 4
For enclosure For Compartment OrderCode Nr.

Feedback mounting plate
width, mm depth, mm Vented Plain
200 6.74.4020 6.75.4020
225 6.74.4022 6.75.4022
400
250 6.74.4025 6.75.4025
300 6.74.4030 6.75.4030
200 6.74.5020 6.75.5020
225 6.74.5022 6.75.5022
500
250 6.74.5025 6.75.5025
300 6.74.5030 6.75.5030
200 6.74.6020 6.75.6020
225 6.74.6022 6.75.6022
600
250 6.74.6025 6.75.6025
300 6.74.6030 6.75.6030
200 6.74.7020 6.75.7020
225 6.74.7022 6.74.7022
700
250 6.74.7025 6.75.7025
300 6.74.7030 6.75.7030
200 6.74.8020 6.75.8020
225 6.74.8022 6.75.8022
800
250 6.74.8025 6.75.8025
300 6.74.8030 6.75.8030 Horizontal functional space divider
56
26 Side functional space divider

For vertical separation of compartments.
Packs of 2
For enclosure For Compartment OrderCode Nr.

height, mm depth, mm Vented Plain
200 6.68.2020V 6.68.2020
250 6.68.2025V 6.68.2025
200
300 6.68.2030V 6.68.2030
400 6.68.2040V 6.68.2040
200 6.68.3020V 6.68.3020
250 6.68.3025V 6.68.3025
300
300 6.68.3030V 6.68.3030
400 6.68.3040V 6.68.3040
200 6.68.4020V 6.68.4020
250 6.68.4025V 6.68.4025
400
300 6.68.4030V 6.68.4030
400 6.68.4040V 6.68.4040
200 6.68.5020V 6.68.5020
250 6.68.5025V 6.68.5025
500
300 6.68.5030V 6.68.5030
400 6.68.5040V 6.68.5040
200 6.68.6020V 6.68.6020
250 6.68.6025V 6.68.6025
600
300 6.68.6030V 6.68.6030
400 6.68.6040V 6.68.6040
Side functional space divider
27. Segregation panels - Plain

Packs of 4
Panel OrderCode Nr.

height, Compartment width / depth, mm
mm 300 400 500 600 700 800
200 6.77.2030 6.77.2040 6.77.2050 6.77.2060 6.77.2070 6.77.2080
250 6.77.2530 6.77.2540 6.77.2550 6.77.2560 6.77.2570 6.77.2580
300 6.77.3030 6.77.3040 6.77.3050 6.77.3060 6.77.3070 6.77.3080
400 6.77.4030 6.77.4040 6.77.4050 6.77.4060 6.77.4070 6.77.4080
500 6.77.5030 6.77.5040 6.77.5050 6.77.5060 6.77.5070 6.77.5080
600 6.77.6030 6.77.6040 6.77.6050 6.77.6060 6.77.6070 6.77.6080
700 6.77.7030 6.77.7040 6.77.7050 6.77.7060 6.77.7070 6.77.7080
800 6.77.8030 6.77.8040 6.77.8050 6.77.8060 6.77.8070 6.77.8080
Segregation panels - Plain
28. Segregation panels - Vented

Packs of 4
Panel OrderCode Nr.

height, Compartment width / depth, mm
mm 300 400 500 600 700 800
200 6.76.2030 6.76.2040 6.76.2050 6.76.2060 6.76.2070 6.76.2080
250 6.76.2530 6.76.2540 6.76.2550 6.76.2560 6.76.2570 6.76.2580
300 6.76.3030 6.76.3040 6.76.3050 6.76.3060 6.76.3070 6.76.3080
400 6.76.4030 6.76.4040 6.76.4050 6.76.4060 6.76.4070 6.76.4080
500 6.76.5030 6.76.5040 6.76.5050 6.76.5060 6.76.5070 6.76.5080
600 6.76.6030 6.76.6040 6.76.6050 6.76.6060 6.76.6070 6.76.6080
700 6.76.7030 6.76.7040 6.76.7050 6.76.7060 6.76.7070 6.76.7080
800 6.76.8030 6.76.8040 6.76.8050 6.76.8060 6.76.8070 6.76.8080
Segregation panels - vented
57
A
29. Terminal box Form 4b

For modular outgoing section.
Mount on the side.
To shield the connections (terminals)of the functional space,
busbar chamber and cable chamber to Form 4b.
The terminal boxes are externally mounted on the functional
space side panel modules in the cable chamber, to match the
heights of the compartments.
Material: EG steel, RAL 7035 epoxy painted.
Supply includes: assembly parts
Packs of 1 set.
Terminal box OrderCode Nr. for Terminal box height, mm

Width Depth 150 200 250 300 400 600
250 6.88.1512 6.88.2012 6.88.2512 6.88.3012 6.88.4012 6.88.6012
150 300 6.88.1513 6.88.2013 6.88.2513 6.88.3013 6.88.4013 6.88.6013 Side functional space divider
400 6.88.1514 6.88.2014 6.88.2514 6.88.3014 6.88.4014 6.88.6014
250 6.88.1522 6.88.2022 6.88.2522 6.88.3022 6.88.4022 6.88.6022
200 300 6.88.1523 6.88.2023 6.88.2523 6.88.3023 6.88.4023 6.88.6023
400 6.88.1524 6.88.2024 6.88.2524 6.88.3024 6.88.4024 6.88.6024
58
Punched sections, rails and profiles.
59
A
1. Punched section 25x75 mm with mounting flanges,

Packs of 4,

height/width/depth, mm
300 6.40.0300
400 6.40.0400
500 6.40.0500
600 6.40.0600
700 6.40.0700
800 6.40.0800
900 6.40.0900
1000 6.40.1000
1100 6.40.1100
1200 6.40.1200
Punched section 25x75 mm with mounting flanges,
1600 6.40.1600
1800 6.40.1800
2000 6.40.2000
2200 6.40.2200
2. Punched section 25x75 mm without mounting flange

Packs of 4, including support brackets.
For enclosure OrderCode Nr. Component
height/width/depth, mm length, mm
300 6.41.0300 200
400 6.41.0400 300
500 6.41.0500 400
600 6.41.0600 500
700 6.41.0700 600
800 6.41.0800 700
900 6.41.0900 800
1000 6.41.1000 900
1100 6.41.1100 1000
1200 6.41.1200 1100
Punched section 25x75 mm without mounting flange
1600 6.41.1600 1500
1800 6.41.1800 1700
2000 6.41.2000 1900
2200 6.41.2200 2100


300 6.42.0300 200
400 6.42.0400 300
500 6.42.0500 400
600 6.42.0600 500
700 6.42.0700 600
800 6.42.0800 700
900 6.42.0900 800
1000 6.42.1000 900 Punched section 25x25 mm without mounting flange
1100 6.42.1100 1000
1200 6.42.1200 1100
1600 6.42.1600 1500
1800 6.42.1800 1700
2000 6.42.2000 1900
2200 6.42.2200 2100
60
A7 - Punched sections, rails and profiles.


400 6.45.0400 300
500 6.45.0500 400
600 6.45.0600 500
700 6.45.0700 600
800 6.45.0800 700
Punched section 50x100 mm without mounting flange
5. Intermediate Uprights, 50x50 mm and 50x25 mm.
Packs of 2 including support brackets.
For enclosure Compartment / Component OrderCode Nr.

height, mm length, mm 50x50 mm 50x25 mm
1600 1500 6.44.1600 6.43.1600
1800 1700 6.44.1800 6.43.1800
2000 1900 6.44.2000 6.43.2000
2200 2100 6.44.2200 6.43.2200
6. Punched sections 50x50 mm and 50x25 mm Intermediate Uprights

Material: zincpassivated steel. RAL7035.
For enclosure Compartment / Component OrderCode Nr.

width/depth, mm length, mm 50x50 mm 50x25 mm
300 200 6.60.0300 6.61.0300
400 300 6.60.0400 6.61.0400
500 400 6.60.0500 6.61.0500
600 500 6.60.0600 6.61.0600
700 600 6.60.0700 6.61.0700
800 700 6.60.0800 6.61.0800
900 800 6.60.0900 6.61.0900
1000 900 6.60.1000 6.61.1000
1100 1000 6.60.1100 6.61.1100
1200 1100 6.60.1200 6.61.1200
Punched sections 50x50 mm and 50x25 mm
7. Busbar supports, 25x40 mm

Packs of 4.
For compartment Component OrderCode Nr.

width/depth, mm length, mm
300 300 6.55.0300
350 350 6.55.0350
400 400 6.55.0400
450 450 6.55.0450
500 500 6.55.0500
550 550 6.55.0550
600 600 6.55.0600
700 700 6.55.0700
Busbar supports, 25x40 mm
8. Crosspiece, 18x40 mm
Packs of 4.
For compartment Component OrderCode Nr.
width/depth, mm length, mm
300 300 6.57.0300
350 350 6.57.0350
400 400 6.57.0400
450 450 6.57.0450
500 500 6.57.0500
550 550 6.57.0550
600 600 6.57.0600
700 700 6.57.0700
Crosspiece, 18x40 mm
61
A
9. RMS - busbar Supports

Packs of 4 sets.
System Bar OrderCode Nr.
Assembly centre distance, Enclosures width/ depth
mm 600 700 800
3-pole 100 6.58.3106 6.58.3107 6.58.3108
4-pole 100 6.58.4106 6.58.4107 6.58.4108
3-pole 120 6.58.3126 6.58.3127 6.58.3128
4-pole 120 6.58.4126 6.58.4127 6.58.4128
RMS - busbar Supports
3-pole 165 6.58.3166 6.58.3167 6.58.3168
4-pole 165 6.58.4166 6.58.4167 6.58.4168
10. Cable-tie support - external

Packs of 10.
OrderCode Nr.
For compartment width/depth, mm
200 250 300 400 500 600
6.46.0200 6.46.0250 6.46.0300 6.46.0400 6.46.0500 6.46.0600
Cable-tie support - external
11. Cable-tie support - internal

Packs of 10.
OrderCode Nr.
For compartment width/depth, mm
200 250 300 400 500 600
6.48.0200 6.48.0250 6.48.0300 6.48.0400 6.48.0500 6.48.0600
Cable-tie support - internal
12. Cable guide profiles - mounting on door stiffeners

Packs of 2.
For door width, Component length, OrderCode Nr.

mm mm
400 275 6.47.0400
500 375 6.47.0500
600 475 6.47.0600
700 575 6.47.0700
800 675 6.47.0800
900 775 6.47.0900
Cable guide profiles - mounting on door stiffeners

13. System support rails.
For heavy installed equipment such as transformers.
T-head screws slot into the support rail for any mounting position.
Packs of 2.
For enclosure width/depth mm OrderCode Nr.

500 6.51.0500
600 6.51.0600
700 6.51.0700
800 6.51.0800
900 6.51.0900
1000 6.51.1000
System support rails.

62
A7 - Punched sections, rails and profiles.
14. Support rails, 32x75 mm.

For heavy installations.
Packs of 4.
For enclosure width/depth mm OrderCode Nr.

400 6.50.0400
500 6.50.0500
600 6.50.0600
700 6.50.0700
800 6.50.0800
Support rails, 32x75 mm.
15. Support rails DIN 35/7.5

Packs of 6.
OrderCode Nr.
For enclosure width, mm
400 500 600 700 800
6.93.0400 6.93.0500 6.93.0600 6.93.0700 6.93.0800
Support rails DIN 35/7.5
16. Support rails DIN 35/15

Packs of 6.
OrderCode Nr.
400 500 600 700 800
6.96.0400 6.96.0500 6.96.0600 6.96.0700 6.96.0800
Support rails DIN 35/15
17 C- rails TS 30/15
Packs of 6
OrderCode Nr.
400 500 600 700 800
6.97.0400 6.97.0500 6.97.0600 6.97.0700 6.97.0800
C- rails TS 30/15
63
A
18. Mounting brackets

Packs of 4
Mounting brackets
19 Depth profiles
RAL7035.
Packs of 2.
For enclosure depth, mm OrderCode Nr.

500 6.59.0500
400 6.59.0400
500 6.59.0500
600 6.59.0600
800 6.59.0800
Depth profiles
64
A-8 Outdoor Enclosures

A
1. Outdoor single-walled enclosures

Single-walled enclosure of all-round solid construction, open
base,
bottom gland plate, swing handle locking system, plinth and rain
canopy.
Finish: Painted with epoxy-polyester resin, textured RAL 7035.
Optional - RAL 7032 textured
Protection category: IP 55 to EN 60 529/09.2000
Enclosure dimension, mm OrderCode Nr. Number of doors

height width depth
600 400 E3.806040 1
800 800 400 E3.808040 1
1200 400 E3.801240-2D 2
600 400 E3.126050 1
600 500 E3.126050 1
1200 800 400 E3.128040 1
1200 400 E3.121250-2D 2
1200 500 E3.121250-2D 2
600 400 E3.146040 1
1400 800 400 E3.148040 1
1200 400 E3.141240-2D 2
Outdoor single-walled enclosures
2 Outdoor modular double-walled enclosures

Double-walled, fully assembled enclosure.
Consisting of welded frame, roof canopy 75 mm high, side panels
and base/plinth 100mm high and gland plates

height width depth
1000 600 500 E88.106050 1

800 500 E88.108050 1
600 600 E88.126060 1
1200 800 500 E88.128050 1
800 600 E88.128060 1
1200 600 E88.121260-2D 2
1600 800 600 E88.168060 1
3 Outdoor modular single-walled enclosures Outdoor modular double-walled enclosures

Single-walled, fully assembled enclosure.
Consisting of welded frame, roof canopy 75 mm high, side panels
and base / plinth 100mm high and gland plates

height width depth
1000 600 500 E88.106050.SW 1

800 500 E88.108050.SW 1
600 600 E88.126060.SW 1
1200 800 500 E88.128050.SW 1
800 600 E88.128060.SW 1
1200 600 E88.121260.SW-2D 2
1600 800 600 E88.168060.SW 1
66
A-9 One-piece Consoles

A
1. Enclosure closed at the rear and sides,

door or double door at the front, console lid with stay, bottom gland
plate and mounting plate.
Protection category: IP 55 to EN 60 529 complies with NEMA 12

height width depth
960 600 400/480 E63.0600 1
960 800 400/480 E63.0800 1
960 1000 400/480 E63.1000 2
960 1200 400/480 E63.1200 2
E63
Accessories
2. Plinths
Plinth dimensions, mm OrderCode Nr.

height width depth
600 E63.04.1064
800 E63.04.1084
100 400
1000 E63.04.1104
1200 E63.04.1264
Plinths
3. Upper SPA
SPA dimensions, mm OrderCode Nr.

height width depth
250 600 130/180 E63.01.0600
250 800 130/180 E63.01.0800
250 1000 130/180 E63.01.1000
250 1200 130/180 E63.01.1200
Upper SPA
68
A-10 Substation Kiosk Enclosure
A-10 Substation Kiosk Enclosure
These Substation Kiosk Enclosures are available in a wide range of sizes.

The Substation Kiosk is assembled as an integrated unit from specially designed
and manufactured component parts.
The base is built on components laser cut from heavy steel sheets. Other component
parts are made from electrogalvanised steel sheet and finished with epoxy powder paint.
The Kiosk enclosure is divided into three compartments.
A. Medium Voltage Compartment

B. Transformer Compartment
C. Low Voltage Compartment.

A
70
A10 - Substation Kiosk Enclosure
71
A
A10 - Substation Kiosk Enclosure (Rear View)
72
A-11 Customised Enclosures

A
74
A-12 Certificates

A
76
B. Electrical Distribution Boards
B-1 SPN Consumer units
• Single row type A distribution boards.

• Designed for safety and reliability in electrical building
installation.
• Available in flush and surface mounting.
• Available in plain and transparent doors.
• Supplied without incoming device or outgoing protection
device.
• Enclosure material: Electro galvanised steel.
• Finishing: Epoxy powder coated, RAL 7035 texture.
• Degree of protection: IP 41
• Complies with: IEC 439-3 & BS 60439 part 1 & 3.

1. Comby - steel flap version

Base dimensions, mm OrderCode Nr.
No. of Rows No. of Modules
height width depth Surface mounting Flush mounting
1 6 230 213 95 E50.106.0S E50.106.0F
1 8 230 249 95 E50.108.0S E50.108.0F
1 10 230 285 95 E50.110.0S E50.110.0F
1 12 230 321 95 E50.112.0S E50.112.0F
1 14 230 357 95 E50.114.0S E50.114.0F
1 16 230 393 95 E50.116.0S E50.116.0F
1 18 230 429 95 E50.118.0S E50.118.0F
1 20 230 465 95 E50.120.0S E50.120.0F
E50 - SPN Consumer Units - Steel Flap Version
2. Steel door version

No. of Rows No. of Modules Surface mounting Flush mounting
height width depth
Plain door Transparent door Plain door Transparent door
1 6 250 252 90 E51.106.0S E51.106.0GS E51.106.0F E51.106.0GF
1 8 250 288 90 E51.108.0S E51.108.0GS E51.108.0F E51.108.0GF
1 10 250 324 90 E51.110.0S E51.110.0GS E51.110.0F E51.110.0GF
1 12 250 360 90 E51.112.0S E51.112.0GS E51.112.0F E51.112.0GF
1 14 250 396 90 E51.114.0S E51.114.0GS E51.114.0F E51.114.0GF
1 16 250 432 90 E51.116.0S E51.116.0GS E51.116.0F E51.116.0GF
1 18 250 468 90 E51.118.0S E51.118.0GS E51.118.0F E51.118.0GF
1 20 250 504 90 E51.120.0S E51.120.0GS E51.120.0F E51.120.0GF
E51 - SPN Consumer Units - Steel Door Version
78
B-2 DIN Rail Distribution Boards
• Multi row type A distribution boards.

• Distance between rows is 150 mm.
installation.
• Available in plain and transparent doors.
• Supplied without incoming device or outgoing protec-
tion device.
• Degree of protection: IP 41
• Complies with: IEC 439-3 & BS 60439 part 1 & 3

Selection
No. of Rows No. of Modules Surface mounting Flush mounting
height width depth
Plain door Transparent door Plain door Transparent door
1 1 x 16 300 440 115 E52.116S E52.116GS E52.116F E52.116GF
2 2 x 16 450 440 115 E52.216S E52.216GS E52.216F E52.216GF
3 3 x 16 600 440 115 E52.316S E52.316GS E52.316F E52.316GF
4 4 x 16 750 440 115 E52.416S E52.416GS E52.416F E52.416GF
5 5 x 16 900 440 115 E52.516S E52.516GS E52.516F E52.516GF
6 6 x 16 1050 440 115 E52.616S E52.616GS E52.616F E52.616GF
E52 DIN Rail (Internal Arrangement) E52.XXX.F DIN Rail Distribution Board
E52.XXX.GS DIN Rail Distribution Board - Transparent Door
80
B-3 Circuit Breaker Enclosures

installation.
• Supplied without incoming device.
• Degree of protection: IP 54 ( outdoor version ),
IP 41 ( indoor version ).
• Supply includes: Earth and Neutral terminals.

1. Indoor version

Rating Incomer
height width depth Surface mounting Flush Mounting
30-100A MCB 350 200 80 E53.100.MS E53.100.MF
100-125A MCCB 380 200 80 E53.125.S E53.125.F
200-250A MCCB 440 280 110 E53.250.S E53.250.F
400A MCCB 600 350 170 E53.400.S E53.400.F
Indoor Version E53 - surface mounting
Indoor Version E53 - flush mounting
2. Outdoor version

Rating Incomer
height width depth Surface mounting
30-100A MCB 350 200 80 E83.100.MS
100-125A MCCB 380 200 80 E83.125.S
200-250A MCCB 440 280 110 E83.250.S
400A MCCB 600 350 170 E83.400.S
Outdoor Version E83
82
B-4 Busbar Enclosures

installation.
• Steel enclosures mounted with 5mm double bit PA
locks and gland plate.
Option - RAL 7032
• Degree of protection: IP 55, NEMA 4
• Supply includes: Tin plated conductors, Earth and
Neutral terminals and Zinc passivized mounting plate

Selection

Rating Incomer
height width depth Surface mounting
100-125A MCCB 600 400 150 E36.125
200-250A MCCB 700 500 200 E36.250
400A MCCB 800 600 200 E36.400
630A MCCB 1000 600 250 E36.630
Note : when ordering, please state the Brand and model of breaker you intend to
install in these enclosures.
Busbar Enclosure E36
84
B-5 Combination Distribution Boards

installation.
locks and gland plate.
Option - RAL 7032
• Degree of protection: IP 41, NEMA -1
• Complies with IEC 439-1 & BS 60439-1
• Supply includes: Tin plated Busbar Assembly and
rails chassis, Earth and Neutral terminals and Zinc
passivated mounting plate

Selection
DIN Busbar Assembly Row chassis OrderCode Nr.
Amps Way Incomer No. of Row No. of module Surface mounting Flush mounting
6 E62.125A.6W.116.IS.S E62.125A.6W.116.IS.F
8 E62.125A.8W.116.IS.S E62.125A.8W.116.IS.F
125A Iso/ELCB 1 1 x 16
10 E62.125A.10W.116.IS.S E62.125A.10W.116.IS.F
12 E62.125A.12W.116.IS.S E62.125A.12W.116.IS.F
8 E62.225A.8W.216.IS.S E62.225A.8W.216.IS.F
225A 10 Iso/ELCB 2 2 X 16 E62.225A.10W.216.IS.S E62.225A.10W.216.IS.F
12 E62.225A.12W.216.IS.S E62.225A.12W.216.IS.F
Note : when ordering, please state the Brand and model of breaker you intend to install in these enclosures.
E62.125A.6W.116.IS.S E62.125A.6W.216.IS.S
86
B-6 Load Centre Distribution Boards
IEC Type “B” - DIN mount models
• Designed for safety and reliability in electrical building installation.
• Complies with IEC 61 439-2: 2009
• KEMA Type tested rated short circuit withstand 20kA-0.25 sec.
• Maximum Busbar load: 250 amps.
• Steel enclosures mounted with 5mm double bit PA locks and
gland plate.
Option: Die cast push lock.
• Supplied without incoming and outgoing device.
Option - RAL 7032
• Supply includes: Tin plated Busbar Assembly, Earth and Neutral
terminals and Zinc passivized mounting plate

1. 125A TPN Load Centre matching Isolator/ELCB Incomer
No. of ways Base dimensions, mm OrderCode Nr.

1-pole 3-pole Height Width Depth Flush mounting Surface mounting
12 4 500 E56.IS.125A.4W-F E56.IS.125A.4W-S
18 6 550 E56.IS.125A.6W-F E56.IS.125A.6W-S
24 8 600 385 105 E56.IS.125A.8W-F E56.IS.125A.8W-S
30 10 650 E56.IS.125A.10W-F E56.IS.125A.10W-S
36 12 700 E56.IS.125A.12W-F E56.IS.125A.12W-S
42 14 750 E56.IS.125A.14W-F E56.IS.125A.14W-S
48 16 800 E56.IS.125A.16W-F E56.IS.125A.16W-S
2. 125A TPN Load Centre matching MCCB Incomer

12 4 550 E56.MCCB.125A.4W-F E56.MCCB.125A.4W-S
24 8 650 385 105 E56.MCCB.125A.8W-F E56.MCCB.125A.8W-S
E56 - TPN Load Centre -MCCB Incomer
3. 250A TPN Load Centre matching MCCB Incomer

30 10 700 385 105 E56.MCCB.225A.10W-F E56.MCCB.225A.10W-S
E56 - TPN Load Centre -ISO/ELCB Incomer
88
B6 - Load Centres Distribution Boards
4. Split Load Centre matching Isolator/ELCB Incomer - 125A
No. of ways OrderCode Nr.

3-pole 3-pole Flush mounting Surface mounting
2 2 E56.IS.125A.2+2W-F E56.IS.125A.2+2W-S
2 4 E56.IS.125A.2+4W-F E56.IS.125A.2+4W-S
4 4 E56.IS.125A.4+4W-F E56.IS.125A.4+4W-S
2 6 E56.IS.125A.2+6W-F E56.IS.125A.2+6W-S
4 6 E56.IS.125A.4+6W-F E56.IS.125A.4+6W-S
6 6 E56.IS.125A.6+6W-F E56.IS.125A.6+6W-S
4 8 E56.IS.125A.4+8W-F E56.IS.125A.4+8W-S
6 8 E56.IS.125A.6+8W-F E56.IS.125A.6+8W-S
8 8 E56.IS.125A.8+8W-F E56.IS.125A.8+8W-S
4 12 E56.IS.125A.4+12W-F E56.IS.125A.4+12W-S
Note : when ordering, please state the Brand and model of breaker you intend to
install in these enclosures. In case you wish to have the door to be installed with
a keyed metal lock, add “ PKL “ to your OrderCode Nr.
E56 - Split Load Centre matching Isolator/ELCB Incomer - 125A
5. IP 65 Outdoor Load Centre

Enclosure with gland plate in the base. Door hinge on the
right , may be swapped to opposite side.
Protection category: IP65 to EN 60 529/09.2000 com-
plies with NEMA 4.
Surface mounting only.
IP65 Outdoor load centre

1-pole 3-pole Height Width Depth Main isolator incomer 125A MCCB incomer 250A MCCB incomer
12 4 550 E56.IS.125A.4W-IP E56.MCCB.125A.4W-IP E56.MCCB.225A.4W-IP
30 10 700 400 150 E56.IS.125A.10W-IP E56.MCCB.125A.10W-IP E56.MCCB.225A.10W-IP
89
6 Mini Centre compact Distribution Boards

Designed for safety and reliability in electrical building
installation.
Complies with IEC 61 439-2 :2009
KEMA Type tested rated short circuit withstand 20kA-
0.25 sec.
Maximum Busbar load: 250 amps.
Steel enclosures mounted with die cast key lock(s).
Supplied without incoming and outgoing device.
Enclosure material: Electro galvanised steel.
Finishing: Epoxy powder coated, RAL 7035 texture.
Option - RAL 7032
Degree of protection: IP 42, NEMA -1
Supply includes: Tin plated Busbar Assembly, Earth and
Neutral terminals and Zinc passivized mounting plate
Surface mounting only. Flush on request.
Mini Centre compact Distribution Boards

1-pole 3-pole Height Width Depth Isolator/ELCB incomer 125A MCCB incomer 250A MCCB incomer
12 4 502 E86.IS.125A.4W E86.MCCB.125A.4W E86.MCCB.225A.4W
36 12 718 400 125 E86.IS.125A.12W E86.MCCB.125A.12W E86.MCCB.225A.12W
90
B-7 Load Centres Distribution Boards
NEMA Type “A” - Plug-in models

installation.
• Complies with NEMA UL 50 & 67 & IEC 60529: 1989-11
• Maximum Busbar load: 250 amps.
locks and gland plate. Option : Die cast push lock.
Option - RAL 7032
• Supply includes: Tin plated Busbar Assembly, Earth
and Neutral terminals and Zinc passivized mounting
plate

1. 125A TPN Load Centre matching Isolator/ELCB Incomer
No. of ways Base dimensions, mm OrderCode Nr. (Surface Mounting)

1-pole 3-pole Height Width Depth WIWO incomer 125A MCCB incomer 250A MCCB incomer
12 4 591 E57-12100W.S E57-L12100.S E57-L12225.S
18 6 667 E57-18100W.S E57-L18100.S E57-L18225.S
24 8 743 E57-24100W.S E57-L24100.S E57-L24225.S
30 10 848 343 105 E57-30100W.S E57-L30100.S E57-L30225.S
36 12 930 E57-36100W.S E57-L36100.S E57-L36225.S
42 14 1010 E57-42100W.S E57-L42100.S E57-L42225.S
48 16 1090 E57-48100W.S E57-L48100.S E57-L48225.S
No. of ways Base dimensions, mm OrderCode Nr. (Flush Mounting)

12 4 591 E57-12100W.F E57-L12100.F E57-L12225.F
18 6 667 E57-18100W.F E57-L18100.F E57-L18225.F
24 8 743 E57-24100W.F E57-L24100.F E57-L24225.F
30 10 848 343 105 E57-30100W.F E57-L30100.F E57-L30225.F
36 12 930 E57-36100W.F E57-L36100.F E57-L36225.F
42 14 1010 E57-42100W.F E57-L42100.F E57-L42225.F
48 16 1090 E57-48100W.F E57-L48100.F E57-L48225.F
TPN Load Centre
2. Outdoor version
Enclosure with gland plate in the base. Door hinge on the right , may
be swapped to opposite side.
Surface finish: powder-coated in texture RAL 7035. Optional RAL
7032 texture.
Protection category: IP65 to EN 60 529/09.2000 complies with
NEMA 4.
Surface mounting only.
Outdoor version
No. of ways Base dimensions, mm OrderCode Nr. (Surface Mounting)

12 4 550 E75-12100.IP E75-L12100.IP E75-L12225.IP
18 6 600 E75-18100.IP E75-L18100.IP E75-L18225.IP
24 8 650 E75-24100.IP E75-L24100.IP E75-L24225.IP
30 10 700 400 150 E75-30100.IP E75-L30100.IP E75-L30225.IP
36 12 750 E75-36100.IP E75-L36100.IP E75-L36225.IP
42 14 800 E75-42100.IP E75-L42100.IP E75-L42225.IP
48 16 850 E75-48100.IP E75-L48100.IP E75-L48225.IP
92
B-8 Sub Main Distribution Boards
• Complies with IEC 61 439-1 : 1999 + A1 : 2004

• KEMA Type Tested rated short circuit withstand 35kA
( 73kA peak ) for 1.0 second.
installation.
Option - RAL 7032
• Supply includes: Tin plated Busbar Assembly, Earth
and Neutral terminals and Zinc passivized mounting
plate
• Available in surface mounting.

1. Version A
a. 250A panel boards : Maximum outgoing 160A
Outgoing OrderCode Nr. Dimensions, mm

Ways, TP MCCB frame width Height Width Depth
4 V55.250MD-04-125MD-P25 808
6 V55.250MD-06-125MD-P25 903
8 75 mm V55.250MD-08-125MD-P25 980 800 190
10 V55.250MD-10-125MD-P25 1057
12 V55.250MD-12-125MD-P25 1134
b. 400A panel boards : Maximum outgoing 160A

4 V55.400MD-04-125MD-P25 1000
6 V55.400MD-06-125MD-P25 1077
8 V55.400MD-08-125MD-P25 1154
10 75 mm V55.400MD-10-125MD-P25 1231 800 190
12 V55.400MD-12-125MD-P25 1308
14 V55.400MD-14-125MD-P25 1383
16 V55.400MD-16-125MD-P25 1458
V55 - Panel Boards Version A

C. 630A panel boards : Maximum outgoing 160A

6 V55.630MD-06-125MD-P25 1317
8 V55.630MD-08-125MD-P25 1392
10 V55.630MD-10-125MD-P25 1467
75 mm 800 190
12 V55.630MD-12-125MD-P25 1542
14 V55.630MD-14-125MD-P25 1617
16 V55.630MD-16-125MD-P25 1692
d. 400A panel boards : Maximum outgoing 250A

4 V55.400MD-04-225MD-P35 1115
6 V55.400MD-06-225MD-P35 1210
8 V55.400MD-08-225MD-P35 1315
10 105 mm V55.400MD-10-225MD-P35 1420 800 190
12 V55.400MD-12-225MD-P35 1525
14 V55.400MD-14-225MD-P35 1630
16 V55.400MD-16-225MD-P35 1735
V55 - Panel Boards Version A
e. 630A panel boards : Maximum outgoing 250A

6 V55.630MD-06-225MD-P35 1335
8 V55.630MD-08-225MD-P35 1440
10 V55.630MD-10-225MD-P35 1545
105 mm 800 190
12 V55.630MD-12-225MD-P35 1650
14 V55.630MD-14-225MD-P35 1755
16 V55.630MD-16-225MD-P35 1860
Note : when ordering, please state the Brand and model of breakers you intend to install in these enclosures.
94
B8 - Sub Main Distribution Boards
Accessories
f. Top /Bottom extension box
OrderCode Nr. Box dimensions, mm

Plain cover type Meter cut-out cover type Height Width Depth
V55.208019 V55.208019.M 200 800 190
g. Side extension box : V55 - Top / Bottom extension box

designed suitable to be mounted on the left side as well as
on the right side of the enclosure.
When ordering, please indicate height of the box required.
Box is of standard width of 200 mm and depth of 190 mm.
V55 - Panel Boards Version A with side mounting
2. Version B
a. 250A panel boards : Maximum outgoing 160A

4 E55.250MD-04-125MD-P25 808
6 E55.250MD-06-125MD-P25 903
8 75 mm E55.250MD-08-125MD-P25 980 750 160
10 E55.250MD-10-125MD-P25 1057
12 E55.250MD-12-125MD-P25 1134
b. 400A panel boards : Maximum outgoing 160A

4 E55.400MD-04-125MD-P25 1000
6 E55.400MD-06-125MD-P25 1077
8 E55.400MD-08-125MD-P25 1154
10 75mm E55.400MD-10-125MD-P25 1231 750 160
12 E55.400MD-12-125MD-P25 1308
14 E55.400MD-14-125MD-P25 1383
16 E55.400MD-16-125MD-P25 1458
E55 - Panel Boards Version B

95
C. 630A panel boards : Maximum outgoing 160A

6 E55.630MD-06-125MD-P25 1317
8 E55.630MD-08-125MD-P25 1392
10 E55.630MD-10-125MD-P25 1467
75 mm 750 160
12 E55.630MD-12-125MD-P25 1542
14 E55.630MD-14-125MD-P25 1617
16 E55.630MD-16-125MD-P25 1692
d. 400A panel boards : Maximum outgoing 250A

4 E55.400MD-04-225MD-P35 1115
6 E55.400MD-06-225MD-P35 1210
8 E55.400MD-08-225MD-P35 1315
10 105 mm E55.400MD-10-225MD-P35 1420 750 160
12 E55.400MD-12-225MD-P35 1525
14 E55.400MD-14-225MD-P35 1630
16 E55.400MD-16-225MD-P35 1735
e. 630A panel boards : Maximum outgoing 250A

6 E55.630MD-06-225MD-P35 1335
8 E55.630MD-08-225MD-P35 1440
10 E55.630MD-10-225MD-P35 1545
105 mm 750 160
12 E55.630MD-12-225MD-P35 1650
14 E55.630MD-14-225MD-P35 1755
16 E55.630MD-16-225MD-P35 1860 E55 - View without front panel
Note : when ordering, please state the Brand and model of breakers you intend to install in these enclosures.
Accessories
f. Front meter panel
OrderCode Nr. E55.1275.M
E55 - Front meter panel
96
B8 - Sub Main Distribution Boards
3. Version C
a. 250A panel boards: Maximum outgoing 160A
4 E85.250MD-04-125MD-P25 700
6 E85.250MD-06-125MD-P25 800
8 75 mm E85.250MD-08-125MD-P25 900 750 210
12 E85.250MD-12-125MD-P25 1100
16 E85.250MD-16-125MD-P25 1300
b. 400A panel boards: Maximum outgoing 160A

4 E85.400MD-04-125MD-P25 900
6 E85.400MD-06-125MD-P25 1000
8 75 mm E85.400MD-08-125MD-P25 1100 750 210
12 E85.400MD-12-125MD-P25 1300
16 E85.400MD-16-125MD-P25 1500
C. 630A panel boards: Maximum outgoing 160A

4 E85.630MD-04-125MD-P25 900
6 E85.630MD-06-125MD-P25 1000
E85 - MCCB panel boards
8 75 mm E85.630MD-08-125MD-P25 1100 750 210
12 E85.630MD-12-125MD-P25 1300
16 E85.630MD-16-125MD-P25 1500
d. 630A panel boards: Maximum outgoing 160A

4 E85.400MD-04-225MD-P35 1115
6 E85.400MD-06-225MD-P35 1210
8 105 mm E85.400MD-08-225MD-P35 1315 800 210
12 E85.400MD-12-225MD-P35 1525
16 E85.400MD-16-225MD-P35 1735
e. 630A panel boards: Maximum outgoing 250A

6 E85.630MD-06-225MD-P35 1210
8 105 mm E85.630MD-08-225MD-P35 1440 800 210
12 E85.630MD-12-225MD-P35 1650
16 E85.630MD-16-225MD-P35 1860
Note : when ordering, please state the Brand and model of breakers you intend to install in
these enclosures.
97
Accessories
OrderCode Nr. Dimensions, mm

Type
Top extension box Bottom extension box Height Width Depth
E85.15.750.0 E85.04.750.0 750
Plain
E85.15.800.0 E85.04.800.0 800
200 210
E85.15.750.M - 750
Meter cut-outs
E85.15.800.M - 800
Note : supply does not include meters and lamps.
E85 - Top Bottom extension box
98
B-9 Busbars
1. Three-pole Final Distribution Board

Busbar Assembly - Type B.
Complies with IEC 61 439-2 :2009
KEMA Type tested rated short circuit withstand 20kA - 0.25 sec.
Tin plated 99.99% copper busbar shrouded in heavy duty high
temperature engineering plastics.
Supply does not include GI tray nor copper link.
Number of way OrderCode Nr.

125A Type 250A Type
2 BBA.125.2W.DIN BBA.225.2W.DIN
10 BBA.125.10W.DIN BBA.225.10W.DIN E56 -Three-pole Final Distribution Board Busbar Assembly -
12 BBA.125.12W.DIN BBA.225.12W.DIN Type B
2. Sub Main Busbar Assembly

Complies with IEC 61 439-1 : 1999 + A1 : 2004
KEMA Type Tested rated short circuit withstand 35kA ( 73kA peak ) for
1.0 second.
Tin plated 99.99% copper busbar shrouded in heavy duty high
temperature engineering plastics.
Supply does not include mounting brackets, spreader nor copper link.
a. Main busbar assembly

Outgoing MCCB frame of 75 mm
250A 400A 630A
4 E55.250W04.P25 E55.400W04.P25 E55.630W04.P25
6 E55.250W06.P25 E55.400W06.P25 E55.630W06.P25
8 E55.250W08.P25 E55.400W08.P25 E55.630W08.P25
10 E55.250W10.P25 E55.400W10.P25 E55.630W10.P25
12 E55.250W12.P25 E55.400W12.P25 E55.630W12.P25
Main Terminal Copper Section 6.0 x 25.0 mm 10.0 x 25.0 mm 12.7 x 32.0 mm

250A 400A 630A
4 E55.250W04.P30 E55.400W04.P30 E55.630W04.P30
6 E55.250W06.P30 E55.400W06.P30 E55.630W06.P30
8 E55.250W08.P30 E55.400W08.P30 E55.630W08.P30
10 E55.250W10.P30 E55.400W10.P30 E55.630W10.P30
12 E55.250W12.P30 E55.400W12.P30 E55.630W12.P30
E55 - Main busbar assembly


250A 400A 630A
4 E55.250W04.P35 E55.400W04.P35 E55.630W04.P35
6 E55.250W06.P35 E55.400W06.P35 E55.630W06.P35
8 E55.250W08.P35 E55.400W08.P35 E55.630W08.P35
10 E55.250W10.P35 E55.400W10.P35 E55.630W10.P35
12 E55.250W12.P35 E55.400W12.P35 E55.630W12.P35
Note : when ordering please indicate the Brand and model of the breakers you intend to install in
the Busabar Assembly.
b. Extension busbar assembly

250A 400A 630A
4 E55E.250W04.P25 E55E.400W04.P25 E55E.630W04.P25
6 E55E.250W06.P25 E55E.400W06.P25 E55E.630W06.P25
8 E55E.250W08.P25 E55E.400W08.P25 E55E.630W08.P25
10 E55E.250W10.P25 E55E.400W10.P25 E55E.630W10.P25
12 E55E.250W12.P25 E55E.400W12.P25 E55E.630W12.P25

250A 400A 630A
4 E55E.250W04.P30 E55E.400W04.P30 E55E.630W04.P30
6 E55E.250W06.P30 E55E.400W06.P30 E55E.630W06.P30
8 E55E.250W08.P30 E55E.400W08.P30 E55E.630W08.P30
10 E55E.250W10.P30 E55E.400W10.P30 E55E.630W10.P30
12 E55E.250W12.P30 E55E.400W12.P30 E55E.630W12.P30

E55 - Extension busbar assembly
250A 400A 630A
4 E55E.250W04.P35 E55E.400W04.P35 E55E.630W04.P35
6 E55E.250W06.P35 E55E.400W06.P35 E55E.630W06.P35
8 E55E.250W08.P35 E55E.400W08.P35 E55E.630W08.P35
10 E55E.250W10.P35 E55E.400W10.P35 E55E.630W10.P35
12 E55E.250W12.P35 E55E.400W12.P35 E55E.630W12.P35
Note : when ordering please indicate the Brand and model of the breakers you intend to install in
the Busabar Assembly.
100
B-10 Certificates - Type tests

102
C. IT Enclosures
C-1 FlatBox wall-mounted and

floor-standing enclosure
• Flat-packed enclosure
• Supply includes:
wall section, basic supports, roof/base plates with
cut-outs for cable entry,
19” mounting angles,
levelling feet ( from 12U ),
side panels,
glazed door,
lockable,
hinges and assembly fasteners.
• Material: Electro-galvanised steel.
• Finish: Epoxy powder coated RAL 9002 texture.
Option: RAL 7035.
Selection
U 6 9 6 9 12 15 12 15 18 21
Height, mm 360 500 360 500 630 760 630 760 900 1030
Width, mm 600 600 600 600 600 600 600 700 700 700
Depth, mm 400 400 600 600 400 400 600 700 700 700
OrderCode Nr. E70.066040 E70.096040 E70.066060 E70.096060 E70.126040 E70.156040 E70.126060 E70.157070 E70.187070 E70.217070

C - IT Enclosures
C-2 Wall Mount 19” Rack, Model E1
• Developed specially for small networks, secondary

distributions and floor standing.
• Side panels and door are detachable. Equipment are
accessible from three sides.
• Cut-outs at top and bottom surface.
• Glazed door with security lock, 19” mounting angles,
infinitely depth-variable.
Option: RAL 7035.
Selection
U 6 9 6 9 12 12 15 15 15 18 18 21 21
Height, mm 360 500 360 500 630 630 760 760 760 900 900 1030 1030
Width, mm 600 600 600 600 600 600 600 600 600 600 600 600 600
Depth, mm 400 400 500 500 400 500 400 500 600 400 600 400 600
OrderCode Nr. E1.065040 E1.096040 E1.066050 E1.096050 E1.126040 E1.126050 E1.156040 E1.156050 E1.156060 E1.186040 E1.186060 E1.216040 E1.216060
104 Premium Quality - Value Price

C - IT Enclosures
C-3 Two-section Wall Mount

19” Enclosure, model E11
• Wall section with punched rails and C rail mounted

horizontally for cable clamping.
• Bottom provided with cut-out for cable entry.
• Hinged part provided with 25 mm hole patterns in the
front and rear frame.
• 19” mounting angles mounted on C rails, infinitely depth
variable.
Option: RAL 7035.
• Protection category: IP 43 to EN 60 529 when unit is
mounted with solid gland plate.
Selection
U 6 9 12 15 18 21
Height, mm 350 500 620 750 880 1015
Width, mm 600 600 600 600 600 600
Depth, mm 475 475 475 475 475 475
OrderCode Nr. E11.06.475 E11.09.475 E11.12.475 E11.15.475 E11.18.475 E11.21.475

C - IT Enclosures
C-4 IP65 Wall Mount 19” Enclosures,

model E19
• Based on the VS9000 enclosures.

• Unit can be fitted with 19” mounting angles, infinitely
depth-variable or
fitted with 19” swing frame.
Option: RAL 7032.
• Protection category: IP 65 to EN 60 529.
Selection
Fixed 19” frame 19” swing frame

U 8 12 16 6 11 14
Height, mm 400 600 800 400 600 800
Width, mm 600 600 600 600 600 600
Depth, mm 350 350 350 400 400 400
OrderCode Nr. E19.0835.FF E19.1235.FF E19.1635.FF E19.0640.SF E19.1140.SF E19.1440.SF

C - IT Enclosures
C-5 IT server flexiRack, model E7
• Welded frame punched with 25mm hole pattern.

• Top and bottom frame surfaces come with cut-outs.
• Frames are bay able side-to- side.
Option: RAL 9002.
Glazed front door, electro galvanised steel rear door, levelling
feet, swing handle key alike lock on the front and swivel keyed
lock at the perforated rear door.
• Detachable side panels, 19” mounting angles and depth stays.
Selection
U 24 24 38 42 42 47
Height, mm 1200 1200 1800 2000 2000 2200
Width, mm 600 600 600 600 600 600
Depth, mm 600 1000 600 600 1000 1000
OrderCode Nr. E7.1266 E7.1260 E7.1866 E7.2066 E7.2060 E7.2260
U 24 38 42 42 47 47
Height, mm 1200 1800 2000 2000 2200 2200
Width, mm 800 800 800 800 800 800
Depth, mm 800 800 800 1000 800 1000

C - IT Enclosures
C-6 Network Enclosures,

based on VS7000
• A pair of self-supporting 19” frame structure,

Glazed door at the front come with swing
handle key alike lock, two-point locking rod.
• Plug-in side panels with lock- optional
• Base frame with cut-outs.
• Roof plate for cable entry cut-out.
• Perforated rear door.
• Levelling feet.
• Finish: Epoxy powder coated RAL 7035
texture. Option: RAL 9005.
1 Without side panel including baying kit,
U 24 24 42 42 47 47
Height, mm 1200 1200 2000 2000 2200 2200
Width, mm 600 600 600 600 600 600
Depth, mm 600 800 600 800 600 800
OrderCode Nr. E70.2466.0 E70.2468.0 E70.4266.0 E70.4268.0 E70.4766.0 E70.4768.0
U 24 24 42 42 47 47
Height, mm 1200 1200 2000 2000 2200 2200
Width, mm 800 800 800 800 800 800
Depth, mm 600 800 600 800 600 800
OrderCode Nr. E70.2486.0 E70.2488.0 E70.4286 E70.4288.0 E70.4786.0 E70.4788.0
2. Including side panels
U 24 24 42 42 47 47
Height, mm 1200 1200 2000 2000 2200 2200
Width, mm 600 600 600 600 600 600
Depth, mm 600 800 600 800 600 800
U 24 24 42 42 47 47
Height, mm 1200 1200 2000 2000 2200 2200
Width, mm 800 800 800 800 800 800
Depth, mm 600 800 600 800 600 800

C-7 Network enclosures,
based on EP8000
• Welded frame. Option: Flat pack version.

• Frame bay able on all sides,
Enclosure frame with front glazed door
and rear plain door, roof panel with cut-
out,
L 19” mounting angles at the front and
rear, 19” depth stay punched profiles,
one-piece gland plate.
• Finish: Epoxy powder coated RAL 7035
texture. Option: RAL 9005.
• Protection category: IP 55 to EN 60 529.

C - IT Enclosures
1 Welded frame version.

Without side panel, including rear door and swing handle key alike lock.
U 24 38 42 47
Height, mm 1200 1800 2000 2200
Width, mm 600 800 800 800
Depth, mm 600 800 800 800
OrderCode Nr. 6.126060.V3 6.188080.V3 6.208080.V3 6.228080.V3
U 24 42 42 47 47
Height, mm 1200 2000 2000 2200 2200
Width, mm 800 800 800 800 800
Depth, mm 900 900 1000 900 1000
OrderCode Nr. 6.128090.V3 6.208090.V3 6.208010.V3 6.228090.V3 6.228010.V3
2 Flat pack version.

Without side panel, including rear door and swing handle key alike
lock.
U 24 38 42 47 Welded frame version.

Height, mm 1200 1800 2000 2200
Width, mm 600 800 800 800
Depth, mm 600 800 800 800
OrderCode Nr. 6.126060.FP 6.188080.FP 6.208080.FP 6.228080.FP
U 24 42 42 47 47
Height, mm 1200 2000 2000 2200 2200
Width, mm 800 800 800 800 800
Depth, mm 900 900 1000 900 1000
OrderCode Nr. 6.128090.FP 6.208090.FP 6.208010.FP 6.228090.FP 6.228010.FP
110
C7 - Network Enclosures, based on EP8000
Accessories :
2. Levelling feet
To compensate for height differences with floor iregularities.
Packs of 4.
Levelling feet
3. Plinth/base components, vented front and rear.

Supply includes: 4 corners and 2 cross channels.

width, mm 100 mm high
600 6.20.1060V
800 6.20.1080V
Plinth/base components, vented front and rear.
4. Plinth/base - side trim

Surface finish: powder-coated in texture RAL 9002. Optional
RAL 7035 texture.
Supply includes: 2 trim channels
( 4 trim channels in case of 200mm high plinth )
Depth, mm 100 mm high
600 6.21.1060
800 6.21.1080
900 6.21.1090
1000 6.21.1010 Plinth/base - side trim
5. Side panels.
Packs of 2.

height depth Plain version
1200 600 6.11.1260
900 6.11.1290
1800 800 6.11.1880
800 6.11.2080
2000 900 6.11.2090
1000 6.11.2010
800 6.11.2280
2200 900 6.11.2290
1000 6.11.2210
Side panels.
111
C - IT Enclosures
6. Spacers
For roof panel.
heights.
Packs of 4.
10 6.00.0006
20 6.00.0007
50 6.00.0008
Spacers

Packs of 1 set.
For enclosure For enclosure For Compartment OrderCode Nr

Height, mm Width, mm Width, mm Installed centre Installed offset
700 600 6.37.1270C 6.37.1270S
1200
800 700 6.37.1280C 6.37.1280S
700 600 6.37.1870C 6.37.1870S
1800
800 700 6.37.1880C 6.37.1880S
700 600 6.37.2070C 6.37.2070S
2000
800 700 6.37.2080C 6.37.2080S
700 600 6.37.2270C 6.37.2270S
2200
800 700 6.37.2280C 6.37.2280S
19” swing frames
112
C-8 Klasik Rack
model E37
• Welded rack frame with 25 mm system increments. Side panels manufactured from 1.2 mm electro-
• Top and bottom frame are passively ventilated. galvanised sheet steel.
• Perforated rear door with security lock. • Finish: Epoxy polyester textured powder paint,
• Tripartite front with security locking. RAL7035.
• Monitor bay mounted with fixed shelf depth 500 mm. • Supply includes:
• Monitor door installed with 4 mm safety glass. x1 Welded frame.
• Keyboard pull-out tray, 400 mm deep. x1 Fixed shelf 400/500 mm deep
• Side panels with security lock. installed in the monitor bay.
• Material: Basic welded frame & doors manufactured x2 Side panels.
from 1.5 mm electro-galvanised sheet steel. x1 Keyboard pull-out tray, 400 mm deep.
Top and bottom frame manufactured from, 2.0 mm x4 Adjusting leveling feet.
electro-galvanised sheet steel.

C - IT Enclosures
Selection
Rack Dimension, mm OrderCode Nr.

Height Width Depth U height
1600 600 33U E37.1666
600 800 E37.1668
1800 600 38U E37.1866
800 E37.1868
114
C-9 Network Enclosures,
based on VS8000
Side panels manufactured from 1.2 mm electro-

galvanised sheet steel.
• Finish: Epoxy polyester textured powder paint,
RAL7035.
x1 Welded frame.
x1 Fixed shelf 400/500 mm deep
installed in the monitor bay.
x2 Side panels.
x1 Keyboard pull-out tray, 400 mm deep.
x4 Adjusting leveling feet.

C - IT Enclosures
1. Welded frame
Frame bay able side-to-side.
Supply includes:
Enclosure frame with front glazed door and rear plain panel,
roof panel with cut-out.
3-pc gland plates, depth profiles.
Material: Electro-galvanized steel.
Finish: Epoxy powder coated RAL 7035 texture
Option: RAL 9005
Protection category: IP 55 to EN 60 529
U 24 38 42 47
Height, mm 1200 1800 2000 2200
Width, mm 600 800 800 800
Depth, mm 600 800 800 800
OrderCode Nr. E78.1266 E78.1888 E78.2080 E78.2288
U 24 42 42 47 47
Height, mm 1200 2000 2000 2200 2200
Width, mm 800 800 800 800 800
Depth, mm 900 900 1000 900 1000
OrderCode Nr. E78.1289 E78.2089 E78.2080 E78.2289 E78.2280
2. Welded frame
Frame bay able side-to-side.
Supply includes:
Enclosure frame with front glazed door and rear plain door,
roof panel with cut-out.
3-pc gland plates, depth profiles.
Finish: Epoxy powder coated RAL 7035 texture
Option: RAL 9005
Protection category: IP 55 to EN 60 529
U 24 38 42 47
Height, mm 1200 1800 2000 2200
Width, mm 600 800 800 800
Depth, mm 600 800 800 800
OrderCode Nr. E78.1266-RD E78.1888-RD E78.2080-RD E78.2288-RD Welded frame
U 24 42 42 47 47
Height, mm 1200 2000 2000 2200 2200
Width, mm 800 800 800 800 800
Depth, mm 900 900 1000 900 1000
OrderCode Nr. E78.1289-RD E78.2089-RD E78.2080-RD E78.2289-RD E78.2280-RD
116
C9 - Network Enclosures, based on VS8000
Accessories:
3. Side Panels
Surface finish: powder coated in texture RAL
Packs of 2.

height depth Plain version
1200 600 E8.01.126
900 E8.01.129
1800 800 E8.01.188
800 E8.01.208
2000 900 E8.01.209
1000 E8.01.200
800 E8.01.228
2200 900 E8.01.228
1000 E8.01.220
4. Rear doors Side Panels

Mounted with door stiffeners, swing handle key alike locking
system.
Packs of 1.
Door OrderCode Nr
Height, mm Width, mm Plain door Vented door
600 E8.06.126 E8.06.126.V
1200
800 E8.06.128 E8.06.128.V
600 E8.06.186 E8.06.186.V
1800
800 E8.06.188 E8.06.188.V
600 E8.06.206 E8.06.206.V
2000
800 E8.06.208 E8.06.208.V
600 E8.06.226 E8.06.226.V
2200
800 E8.06.228 E8.06.228.V
Rear doors
117
C - IT Enclosures

Packs of 1 set.
For enclosure OrderCode Nr

Height, mm Width, mm Installed centre Installed offset
1200 E8.76.122 E8.76.121
1800 E8.76.182 E8.76.181
800
2000 E8.76.202 E8.76.201
2200 E8.76.222 E8.76.221
19” swing frames

Packs of 1 set.
For enclosure OrderCode Nr

Height, mm Width, mm Installed centre
600 E8.38.1260
1200
800 E8.38.1280
600 E8.38.1860
1800
800 E8.38.1880
600 E8.38.2060
2000
800 E8.38.2080
600 E8.38.2260
2200
800 E8.38.2280
9” fixed frames
118
C9 - Network Enclosures, based on VS8000
7. 19” Panels
Packs of 4.
Panel OrderCode Nr
U Height Plain Vented
1 E4.910.0 E4.910.1
1.5 E4.915.0 E4.915.1
2 E4.920.0 E4.920.1
3 E4.930.0 E4.930.1
4 E4.940.0 E4.940.1
5 E4.950.0 E4.950.1
19” Panels
8. Spacers
For roof panel.
heights.
Packs of 4.

10 6.00.0006
20 6.00.0007
50 6.00.0008
Spacers - for roof panel
9. Lifting Eyebolts, M12

Packs of 4.
Lifting Eyebolts, M12
10. Lifting angle brackets

Packs of 4.
Lifting angle brackets
11. Plinths, height 100mm

Surface finish: powder coated in texture RAL 9002.
Optional RAL 7035 textured.
Enclosure dimension, mm OrderCode Nr

Height Width Plain Vented (front & rear panels)
600 600 E8.04.1066 E8.04.1066V
800 E8.04.1088 E8.04.1088V
800 900 E8.04.1089 E8.04.1089V
1000 E8.04.1080 E8.04.1080V
Plinths, height 100mm
119
C - IT Enclosures
12. Door retainer

Holds the door open at 120 degree to avoid accidental
closing.
Packs of 1 set.
Door retainer
13. Door switch c/w mounting brackets

Packs of 1 set.
Door switch c/w mounting brackets

Packs of 1 set.
OrderCode Nr. LAMP 68 Levelling feet
Compact fluorescent lamp
15. Spray touch-up paint - aerosol can

RAL 7032 SC-7032
RAL 7035 SC-7035
Spray touch-up paint.
16. Levelling feet

To compensate for height differences with floor irregularities.
Packs of 4.
Levelling feet
120
D. Industrial Storage Equipment
D-1 Heavy Duty Drawer Cabinets
• Made from steel and suitable for arduous workshop conditions.

Features:
• Cabinet housings are made of electrogalvanised steel sheets
and fully welded to ensure integrity of shape and high loading
capacity.
• Epoxy powder coated in modern dual colors, gray RAL 7001 for
housings and blue RAL 5015 for fronts.
• All drawers are fixed with individual safety trigger.
• Central locking of all drawer stacks.
• Full width handles.
• Drawers glide easily on steel bearings even when loaded to 100
kg UDL capacity.
• Drawer space utilisation is greatly enhanced by the use of
metal partitions and dividers
• Universal in application : for storing tools and machines;
components and materials
Selection
Dimensions, mm Cabinet Drawer Combination, Height and Units

OrderCode Nr. Width Depth Height H75mm H100mm H125mm H150mm H200mm H400mm H575mm
A62.875.4 500 500 875 x1 - - x2 - x1 -

A62.225.1 500 500 225 - - - x1 - - -
A62.425.3 500 500 425 - x2 - x1 - - -
A62.650.1 500 500 650 - - - - - - x1
A62.650.2 500 500 650 - - - x1 - x1 -
A62.650.3 500 500 650 x2 - - - - x1 -
A62.650.5 500 500 650 x2 x1 - x2 - - -
A62.650.6 500 500 650 x2 x4 - - - - -
A62.800.4 500 500 800 x2 - - x1 - x1 -
A62.800.5 500 500 800 x4 - - - - x1 -
A62.800.6 500 500 800 - x4 - x2 - - -
A62.800.7 500 500 800 x4 x1 - x2 - - -
A62.800.8 500 500 800 x4 x4 - - - - -

Selection..... continuation
Dimensions, mm Cabinet Drawer Combination, Height and Units
OrderCode Nr. Width Depth Height H75mm H100mm H125mm H150mm H200mm H400mm H575mm
A62.875.4 500 500 875 x1 - - x2 - x1 -
A62.875.5 500 500 875 x1 x3 - - - x1 -
A62.875.7 500 500 875 x1 x4 - x2 - - -
A62.875.8 500 500 875 x5 x1 - x2 - - -
A62.875.9 500 500 875 x5 x4 - - - - -
A63.650.2 750 500 650 - - - x1 - x1
A63.650.3 750 500 650 x2 - - x1 - - -
A63.650.5 750 500 650 x2 x1 - x2 - - -
A63.650.6 750 500 650 x2 x4 - - - - -
A63.650.7 750 500 650 x6 x1 - - - - -
A63.800.4 750 500 800 x2 - - x1 - x1 -
A63.800.5 750 500 800 x4 - - - - x1 -
A63.800.6 750 500 800 - x4 - x2 - - -
A63.800.7 750 500 800 x4 x1 - x2 - - -
A63.800.8 750 500 800 x4 x4 - - - - -
A63.875.4 750 500 875 x1 - - x2 - x1 -
A63.875.5 750 500 875 x1 x3 - - - x1 -
A63.875.7 750 500 875 x1 x4 - x2 - - -
A63.875.8 750 500 875 x1 x7 - - - - -
A63.875.9 750 500 875 x5 x4 - - - - -
A64.800.4 600 600 800 x2 x1 - - - x1 -
A64.800.5 600 600 800 - x2 - x2 x1 - -
A64.800.6 600 600 800 x2 x2 - x1 x2 - -
A64.800.7 600 600 800 x2 x4 - x1 - - -
A64.800.8 600 600 800 x4 x4 - - - - -
A64.900.4 600 600 900 - x2 - x1 - x1 -
A64.900.6 600 600 900 - x3 - x2 x1 - -
A64.900.7 600 600 900 x2 x3 - x1 x1 - -
A64.900.8 600 600 900 x3 x3 x1 x1 - - -
A64.900.9 600 600 900 x4 x5 - - - - -
A65.800.4 750 600 800 - - x2 x2 - -
A65.800.5 750 600 800 - x2 - x2 x1 - -
A65.800.6 750 600 800 x2 x2 - x1 x1 - -
A65.800.7 750 600 800 x2 x4 - x1 - - -
A65.800.8 750 600 800 x4 x4 - - - - -
A65.900.5 750 600 900 - x2 - - x3 - -
A65.900.6 750 600 900 - x3 - x2 x1 - -
A65.900.7 750 600 900 x2 x3 - x1 x1 - -
A65.900.8 750 600 900 x3 x3 x1 x1 - - -
A65.900.9 750 600 900 x4 x5 - - - - -
A66.800.4 750 750 800 - - - x2 x2 - -
A66.800.5 750 750 800 x2 - x2 x1 - -
A66.800.6 750 750 800 x2 x2 - x1 x1 - -
A66.800.7 750 750 800 x2 x4 - x1 - - -
A66.800.8 750 750 800 x4 x4 - - - - -
A66.900.5 750 750 900 - x2 - - x3 - -
A66.900.6 750 750 900 - x3 - x2 x1 - -
A66.900.7 750 750 900 x2 x3 - x1 x1 - -
A66.900.8 750 750 900 x3 x3 x1 x1 - - -
A66.900.9 750 750 900 x4 x5 - - - - -
A67.800.4 1125 750 800 - - - x2 x2 - -
A67.800.5 1125 750 800 - x2 - x2 x1 - -
A67.800.6 1125 750 800 x2 x2 - x1 x1 - -
A67.800.7 1125 750 800 x2 x4 - x1 - - -
A67.800.8 1125 750 800 x4 x4 - - - - -
A67.900.5 1125 750 900 - x2 - - x3 -
A67.900.6 1125 750 900 - x3 - x2 x1 - -
A67.900.7 1125 750 900 x2 x3 - x1 x1 - -
A67.900.8 1125 750 900 x3 x3 x1 x1 - - -
A67.900.9 1125 750 900 x4 x5 - - - - -
A67.800.8 1125 750 800 x4 x4 - - - - -
A67.900.5 1125 750 900 - x2 - - x3 - -
A67.900.6 1125 750 900 - x3 - x2 x1 - -
A67.900.7 1125 750 900 x2 x3 - x1 x1 - -
A67.900.8 1125 750 900 x3 x3 x1 x1 - - -
A67.900.9 1125 750 900 x4 x5 - - - - -
122
D-2 Mobile Cabinets
• H952 x W750 x D650mm

• 100 kg per drawer capacity
• 6 drawers c/w roller bearings
• Single key lock design
• x1 tray c/w rubber protective cover
• x2 fixed & x2 swivel brake 125mm diameter caster wheels
• Material: Electrogalvanised steel
• Finish: Epoxy powder painted
M63.800.6
Cabinet Drawer
A62
OrderCode Nr. M63.800.6

M62,M63,M64 and M65

Mobile drawer cabinet.
• Ideal for mechanics,fitters and
maintenance technicians.
• Equipped with push/pull handles.
• Top quality rubber castor and tyred
wheels to ensure easy roll even when
heavily loaded.
• External height:
Model M62 : 725 mm

Model M63 : 775,925 and 1000 mm
Model M64 : 775,925 and 1025 mm.
Model M65 : 1050 mm.
Series M62 M63 M64 M65

mm mm mm mm mm
Width 500 750 600 750
Depth 500 500 600 600
725 775 775 1050
Height 925 925
1000 1025
124
D-3 Heavy Duty Work Benches
• Made from heavy gauge channel frameworks backed with

full width bracing to provide high stability.
• Epoxy powder coated.
Wooden top 40 mm thick.
• Workbench combination /configuration tailored to your
specific requirements.
• Optional test bench are comprehensively equipped with
integral power sockets, service rack, power duct and extra
lighting unit.

1 Work Benches
A21 Modular Frame Work Bench
Epoxy powder coated tough steel section framework.
Frames are fully braced to ensure stability.
Optional workbench combinations can be made up from
any workbench and installing A62 and A63 cabinets
below the wooden top.
Optional bench panels are supplied complete with rear

supports to allow fitting to the workbench.
• Bench panel available:
Height 457 x width 1500 mm.
(OrderCode Nr :A25.54.031)
Height 457 x width 2000 mm.
(OrderCode Nr :A25.54.041) A21 Modular Frame Work Bench
A22 Heavy Duty Work Bench

Made from heavy gauge channel frameworks backed
with full width bracing to provide high stability.
Epoxy powder coated.
Wooden top 40 mm thick.
Workbench combination /configuration tailored to your
specific requirements.
Optional test bench are comprehensively equipped with
integral power sockets, service rack, power duct and
extra lighting unit.
Dimensions, mm
OrderCode Nr. Height Width Depth Timber Top Thickness
A21.156.00 830 1500 600 30mm A22 Heavy Duty Work Bench
A21.206.00 830 2000 600 30mm
A22.159.00 830 1500 900 30mm
A22.209.00 830 2000 900 30mm
2. Work Bench System B62, B63 and B64

Combining A62,A63 and A64 cabinets with a
wooden top will give you a workbench of your
choice.
Wooden top size available:
width 1500 and 2000 mm.
Depth 700 mm and
Thickness 30 mm.
Height of workbench available :
830, 905 and 930 mm.
B62, B63 and B64 Workbench System
B62, B63 and B64 Workbench System - in different combinations.
126
D3 - Heavy Duty Work Benches
3. Hexagon work bench A29

Modular frame type.
Made from electro-galvanised steel .
Optional feature enable A62 cabinets to be selectively
mounted under the wooden top.
A62 cabinet support type.
The wooden top is mounted on the top of six units of
A62 cabinets.
Size :
2600 x 2252 x front width 1300 mm.
Height 830 mm.
• Accessories available:
Central perforated tool panel kits A29 Hexagon Work Bench
Hexagon central utility box.
A29 Hexagon Work Bench
4. High Capacity DRAWER COUNTER SYSTEM

A622, A623, A633 Series
Combining A62 and A63 cabinets with a wooden top will
give you a serving counter of your choice.
Wooden top size available:
Width 1000,1500 and 2000 mm.
Depth 600 mm, and
Thickness 30 mm.
Height of counter available :
830 and 903 mm.
A622, A623, A633 Series
Drawers - showing dividers
127
5. Heavy Duty Work Bench

1000 Kg Load capacity
H830xW1500xD550 mm
30 mm timber top
Screw out adjustable feet.
Material: Electrogalvanised steel.
Finish: Epoxy powder painted
Table A23
Table + A62.225.1
Table + A62.425.3
Table + A62.425.3 + A62.225.1
128
D-4 Tooling Maintenance Trolley
• 1000 mm wide x 550 mm deep x 955 mm high.

• Spacious cupboard section come with rear louvred panel for
plastic bins and adjustable shelf.
• Door inner and side walls are perforated for tool storage.
• Center locking for drawer stacks.
• Total safety individual trigger locks on all drawers to prevent
accidental opening in motion even when central locking is not
in operation.
• Stability and manoeuvrability ensured by quality rubber tyred
castor set.
• Choice of work top is available. Wooden top 30mm thick or
metal tray with rubber mat.
• Standard end mounted document pocket.
• Attractive durable epoxy powder paint finish in dual colours,
blue RAL 5015 and gray RAL 7001.

Heavy Duty Maintenace Tool Trolley

• H952 x W1000 x D550 mm
• 100 kg per drawer capacity
• x2 keys, 12 drawers c/w roller bearings
• x1 tray c/w rubber protective cover
• x2 fixed & x2 swivel brake 125mm diameter caster wheels
• Material: Electrogalvanised steel
• Finish: Epoxy powder painted
Selection
OrderCode Nr. A28.66.02
A28.66.02 + A62.425.1 A28 HD Maintenance Tool Trolley
A28.66.02 + A62.225.3
130
D-5 Heavy Duty Steel Cupboards
• Cupboard housings are made of electrogalvanised steel

sheets and fully welded to ensure integrity of shape and high
loading capacity.
• Epoxy powder coated in modern dual colors, gray RAL 7001
for housings and blue RAL 5015 for fronts.
• Doors come complete with swing locking mechanism.
• Drawers glide easily on steel bearings even when loaded to
100 kg UDL capacity.
• Drawer space utilisation is greatly enhanced by the use of
metal partitions and dividers
• Universal in application: for storing tools and machines;
components and materials.
High Capacity Cupboards A24

1. High Capacity Cupboards Housing and Doors: HC Series

Standard cupboard size is
1000 mm wide
590 mm deep
1900 mm high
Complete with swing locking mechanism, epoxy painted in
Grey (RAL 7001) housing and Blue (RAL 5015) doors.
Four types of inner-door panels are available, perforated,
louvred, plain or glazed (2.0mm thick acrylic sheet).
Versatile Combination: This high capacity cupboard HC
Series, is designed and engineered specifically for use in an
industrial workshop or store environment.
The system comprises of accessories such as drawers,
partitions, shelves, tooling panels and wooden top
which enables the creation of units tailored to your exact
requirements.
High Capacity Cupboards A24
Model Doors Shelves Drawers Perforated Louvred Wooden Top OrderCode Nr.
Perforated Louvred Plain Glazed Tooling Panel Tooling Panel
A 2 - - - - - - - - 24.11
B - 2 - - - - - - - 24.12
C - - 2 - - - - - - 24.13
D - - - 2 - - - - - 24.14
E 2 - - - - 4 1 1 1 24.15
F 2 - - - 3 4 - - - 24.16
G 2 - - - 3 9 - - - 24.17
H - 2 - - - - - 2 - 24.18
I - 2 - - 3 - - - - 24.19
2. Series SC Cupboard Housing and Doors

Standard cupboard size is
1000 mm, width
425 mm, depth
1900 mm, height
Model Doors Shelves OrderCode Nr.

Perforated Louvred Plain Glazed
A 2 - - - - 38.11
B - 2 - - - 38.12
C - - 2 - - 38.13
D - - - 2 - 38.14
E - - - 2 3 38.15
F - 2 - - 3 38.16
G - - 2 - 3 38.17
Accessory
Shelf
Supplied with support brackets and fittings.
Grey epoxy p;ainted
Shelf adjusted in 25 mm vertical increments.
Load capacity 100kg
Dimensins, mm OrderCode Nr.

width x depth x height Standard Capacity Cupboards A38
915 x 370 x 35 38.03.00
132
D-6 Panel Trolley
• Made from steel and suitable for arduous workshop

conditions.
• Epoxy powder coated RAL 7001.
• Push-pull handle.
• Large diameter rubber tyred castor wheels ensure smooth
mobility.

1. Mobile Tool Trolley

Dimensions:
H1300 x W1000 x D600mm
This double sided trolley is extremely sturdy and easy to
manoeuvre.
The inclined panels ensure that tool are safely secured
when the unit is in motion.
Base tray with raised edges provide useful space.
Supplied flat packed with full assembly kits and detailed
instruction or fully factory assembled.
Hook kits is optional.
OrderCode Nr. A27.61
Mobile Tool Trolley - A27
2. Louvred Trolley - A27

Sizes available:
H1300 x W1000 x D600mm
H1300 x W600 x D600mm
Louvred tool panels mounted on two side over a base tray.
OrderCode Nr. Dimensions, mm Tool Block mounting capacity

Height Width Depth
A27.10 1300 600 600 x16 (Supplied without tool block)
A27.11 1300 1000 600 x24 (Supplied without tool block)
Mobile Louvred Trolley - A27
3. Tool Block Trolley - A27

Dimensions:
H1100 x W780 x D600mm
Mounted with rails for bins #2 and #3 on both sides
Made from electro-galvanised steel sheet.
Standard feature of all trolleys: Both ends are fixed with
push-pull handles and 100mm castor wheels.
OrderCode Nr. A27.40
Tool Blocks Trolley - A27
134
D-7 Perforated Tool Panel System
A 25 Wall mounting perforated tool panel system and accessories
Option available
• Perfo workshop kits: OrderCode Nr.A25.67.420
• Kits comes with 4 pcs of panel:
Height 1000mm x Width 457mm
& 54 assorted accessories.
• A selection of perfo tool panel board of various sizes is also
available:
500 x 457mm
1000 x 457mm
1500 x 457mm
2000 x 457mm

1. Free Stand Rack System

The rack system uses standard perfo panels 1000 mm x
457 mm.
Three heights are available, made by either, two, three or
four panels high, mounted on sturdy upright sections.
Racks can be single or double sided.
Single sided racks can be converted to double sided by
simply adding panels to the opposite side when required.
Adjustable feet to compensate for uneven floors.
A. Single Sided Racks
OrderCode Nr Height mm Type

A72.67.12 1080 2 panels high
A72.67.13 1540 3 panels high
A72.67.14 2000 4 panels high
B. Double Sided Racks

OrderCode Nr Height mm Type
A72.67.22 1080 2 panels high
A72.67.23 1540 3 panels high Free Stand Rack System
A72.67.24 2000 4 panels high
2. Rack Storage
Single and double side free standing racks for use in
conjunction with tool blocks. Available in three colours.
A. Single Sided Racks
OrderCode Nr Height mm Tool Block Capacity

A72.67.11 1080 16
A72.67.12 1540 24
A72.67.13 2000 32
B. Double Sided Racks

OrderCode Nr Height mm Tool Block Capacity
A72.67.21 1080 32
A72.67.22 1540 48
A72.67.23 2000 64
Rack Storage
3. Bench Panels
Bench panels are supplied complete with rear supports to
allow fitting to almost any workshop.
Two lengths, 1600 mm and 2000 mm to work in conjunction
with ACE A21 framework bench system
OrderCode Nr Dimensions, mm
A25.54.031 1500 X 457
A25.54.032 2000 xX457
Bench Panels
136

Ace 2014

Uploaded by

Document Information

Original Description:

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Ace 2014

Uploaded by

Copyright:

Available Formats

Premium Quality - Value Price

B Electrical distribution boards

D Industrial Storage Equipment

A-1 Junction Boxes

• Screw fixed cover boxes, without gland plate

Premium Quality - Value Price 1

External dimensions, mm OrderCode Nr.

Junction boxes - J89

• Screw fixed cover boxes,

Premium Quality - Value Price 3

1. Electro galvanised sheet steel

External dimensions, mm OrderCode Nr.

2. Stainless steel - without gland plate

External dimensions, mm OrderCode Nr.

Enclosures have been designed and

• Enclosures with viewing window made from

Premium Quality - Value Price 5

1. Without gland plate

2. With gland plate

E16 with gland plate

• Door hinge on the right , may be swapped to opposite side.

Premium Quality - Value Price 7

1. Single leaf door enclosures

Enclosure nominal dimensions, mm OrderCode Nr.

cont...Single leaf door enclosures

Enclosure nominal dimensions, mm OrderCode Nr.

Enclosure dimensions, mm OrderCode Nr.

External dimensions, mm OrderCode Nr.

External dimensions, mm OrderCode Nr.

6. Wall mounting brackets

Material Steel OrderCode Nr.

Wall mounting brackets

Enclosure nominal dimensions, mm OrderCode Nr. Number

E39 - Stainless steel Enclosures

External dimensions, mm OrderCode Nr.

Premium Quality - Value Price 13

1. Single leaf door enclosures

Enclosure dimensions, mm OrderCode Nr.

2. Overlapping door enclosures

Enclosure dimensions, mm OrderCode Nr.

Overlapping door enclosures

Enclosure dimensions, mm OrderCode Nr.

7. 19” swing frame

Enclosure dimensions, mm OrderCode Nr.

19” swing frame

8. 19” fixed frame

Enclosure dimensions, mm OrderCode Nr.

19” fixed frame

Enclosure dimensions, mm OrderCode Nr.

10. Door retainer

OrderCode Nr. E8.35.0

View of Door retainer in use.

A-6 Panel system enclosures VS8000

• Every enclosure is accessible from all sides.

Premium Quality - Value Price 19

1. Single leaf door enclosures

Enclosure dimensions, mm OrderCode Nr.

Transparent Door enclosures

2. Overlapping door enclosures

Enclosure dimensions, mm OrderCode Nr.

Overlapping door enclosures

3. Transparent Door enclosures

Enclosure dimensions, mm OrderCode Nr.
