Solutions: Leading The Way

We can help design parts
for specific applications,

improve product performance,
reduce overall costs, AND
improve turn around time.
• EMI Shielding/Thermal Management

ENGINEERED PRODUCTS
solutions
• Cushioning/Surface Protection
• Noise and Vibration Control
Globally recognized
• Environmental Sealing
for innovation in
flexible OEM parts.
Leading the Way
global source rubber products
Downloaded from Arrow.com.

Why LVI
We are your full-service, one-stop

Door & Window Extrusions
Weather-stripping
Die-cut Gaskets
Molded Seals
Motor Mounts
Acoustical Foam
Edge Trims
Grommets
Rubber-to-Metal Bonded Parts
Die-cut Foam Pads with PSA
Bumpers
Conductive Extrusions
Conductive Sheet Products
Foam Insulation
EMI Shielding Products
Thermal Management Products
Gap Pads
shop for rubber products.
Environmental sealing, noise
reduction and vibration control,
cushioning and surface
protection, EMI shielding and
thermal management - the
products of Lakeview Industries
can be found where you work, in
your home and where you play.
Lakeview has over 30 years of
experience fabricating flexible
sheet, roll and extruded materials
for the OEM market. Founded in
1976, Lakeview has grown to
become the leading distributor
and manufacturer of fabricated
flexible components. Let
Lakeview Industries help you
develop creative and cost-
effective solutions for your
specific applications. Certified Woman-Owned Business

C O N T E N T S
ELASTOMERS 2
S TA N D A R D S 4
Molded Tolerances
Extruded Tolerances
GROMMETS 6
Symmetrical
Plug & Web
BUMPERS 14
Grommet Bumpers
Recess Bumpers
Recess Bumper Pads
Stem Bumpers
Plug Bumpers
MISC SHAPES 20
Tips & Caps
Stem Bushings
Suction Cups
RUBBER MOUNTS 24
Cylindrical Mounts
H Mounts & T Mounts
EXTRUDED PROFILES 30
Dual Durometer Clip Seals
Extruded Profiles
Extruded Profiles with Adhesive
C O M P R E S S I O N M O U N T S & PA D S 34
INDEX 36
For Engineering Design Assistance

or Order Placement:
Lakeview Industries
DISCLAIMER: Catalog diagrams are meant to provide a general
1225 Lakeview Drive
representation of parts only; actual parts may vary slightly in design
Chaska, MN 55318
from catalog diagrams. Tolerances given are nominal only, and will vary
Phone: 952.368.3500 within RMA commercial molded and/or extruded standards. If you have
Fax: 952.368.3599 any doubt regarding part suitability, please contact Lakeview Sales
Toll Free: 800.852.5384 department prior to order placement. Suitability of parts for specific
www.lakeviewindustries.com applications is the sole responsibility of the customer.
www.lakeviewindustries.com

NATURAL RUBBER/
EPDM/ETHELYNE
BUNA-NITRILE/
CHLOROPRENE
SBR/STYRENE
PROPYLENE
NEOPRENE/
BUTADIENE
ISOPRENE
BUNA-N
LAKEVIEW™ MAT’L CODE I B E C N
Durometer Range 25 - 90 30 - 90 25 - 90 25 - 90 25 - 90
(Shore “A”)
Low Temp Range (F) -60 to -40 -60 to - 55 -65 to -40 -65 to -30 -65 to 0
High Temp Range 180 - 220 210 - 250 220 - 300 250 - 275 250 - 275
E L A S T O M E R S
Max Tensile Strength (PSI) 3500 - 4000 2000 - 2500 2500 - 3000 2500 - 3000 1000 - 3000
Max Elongation % 500 - 600 450 - 500 500 - 600 600 - 700 400 - 600
Impact Strength Excellent Excellent Good Good Fair
Adhesion to Metal Excellent Excellent Good - Excellent Excellent Excellent
Vibration Damping Excellent Fair - Good Fair - Good Good - Excellent Fair - Good
Resiliency Excellent Fair - Excellent Good Fair - Good Good
Impermeability to Gas Good Fair Fair - Good Fair - Good Good

O F
Abrasion Good - Excellent Good - Excellent Good Good - Excellent Good - Excellent
Chemical/Fuel Poor Poor Fair - Good Good Excellent

P R O P E R T I E S
Flame Poor Poor Poor Good - Excellent Poor
Flex Cracking Excellent Good - Excellent Good Good Good
Heat Aging Fair - Good Fair - Good Good - Excellent Good - Excellent Good
Oil Poor Poor Poor Good Excellent
Oxidation Fair Fair Excellent Good - Excellent Fair - Good
Ozone Poor Poor Good - Excellent Good - Excellent Fair

P H Y S I C A L
Steam Fair - Good Fair - Good Excellent Fair Fair - Good
Sunlight Poor Poor Excellent Good - Excellent Poor - Good
Tearing Good - Excellent Fair - Good Fair - Good Good - Excellent Good
Water Swell Fair Excellent Excellent Good Excellent
Weather Aging Poor Fair - Good Excellent Good - Excellent Fair - Good
Note: Property values listed in this table are intended as general reference for typical applications only. Actual values will vary from compound
to compound. Final material selection should be arrived at only after taking all operating requirements and environmental factors into
consideration. If you are unsure as to what material best suits your application, contact Lakeview Sales Department for assistance.
2 800.8 LAKEVIEW (800.852.5384)

ELASTOMER
URETHANE
SILICONE
SILICONE
FLUORO-
FLUORO-
BUTYL
Y S V F U LAKEVIEW™ MAT’L CODE
30 - 80 20 - 90 50 - 95 35 - 80 20 - 95 Durometer Range
(Shore “A”)
-50 to -40 -85 -30 to 0 -85 -65 to -40 Low Temp Range (F)
250 - 300 400 - 500 400 350 180 - 220 High Temp Range (F)
E L A S T O M E R S
2000 600 - 1500 2000 1500 4000 - 8000 Max Tensile Strength (PSI)
600 - 800 100 - 1000 100 - 300 200 - 350 250 - 750 Max Elongation%
Good Poor - Good Poor - Good Poor - Good Excellent Impact Strength
Good Good - Excellent Good - Excellent Good - Excellent Excellent Adhesion to Metal
Excellent Fair - Excellent Fair - Good Good Good Vibration Damping
Poor - Fair Good - Excellent Fair - Excellent Fair - Excellent Poor - Good Resiliency
Good - Excellent Poor - Fair Good - Excellent Poor - Good Good Impermeability to Gas
O F
Fair - Good Poor - Good Good Poor Excellent Abrasion
Poor Poor Excellent Excellent Fair Chemical/Fuel
P R O P E R T I E S
Poor Fair - Excellent Good - Excellent Excellent Poor Flame
Good - Excellent Poor - Good Good Poor - Good Good - Excellent Flex Cracking
Good - Excellent Excellent Excellent Excellent Fair - Good Heat Aging
Poor Fair - Good Excellent Good Good Oil
Excellent Excellent Excellent Excellent Good - Excellent Oxidation
Excellent Excellent Excellent Excellent Excellent Ozone
P H Y S I C A L
Good - Excellent Fair - Good Fair - Good Fair Poor Steam
Excellent Excellent Good - Excellent Excellent Good - Excellent Sunlight
Good Poor - Good Fair - Good Poor Excellent Tearing
Excellent Good - Excellent Excellent Good Good Water Swell
Excellent Excellent Excellent Excellent Good - Excellent Weather Aging
technical data
3

STANDARD DIMENSIONAL TOLERANCE TABLE FOR MOLDED RUBBER PRODUCTS
TABLE 1 — “A1” HIGH PRECISION

Size (mm) ABOVE INCLUDING Fixed Closure Size (in) ABOVE INCLUDING Fixed Closure
0 - 10 ±.10 ±.13 .00 - .40 ±.004 ±.005
10 - 16 .13 .16 .40 - .63 .005 .006
16 - 25 .16 .20 .63 - 1.00 .006 .008
25 - 40 .20 .25 1.00 - 1.60 .008 .010
40 - 63 .25 .32 1.60 - 2.50 .010 .013
63 - 100 .32 .40 2.50 - 4.00 .013 .016
100 - 160 .40 .50 4.00 - 6.30 .016 .020
160 & over multiply by .004 .005 6.30 & over multiply by .004 .005
TABLE 2 — “A2” PRECISION

0 - 10 ±.16 ±.20 .00 - .40 ±.006 ±.008
10 - 16 .20 .25 .40 - .63 .008 .010
16 - 25 .25 .32 .63 - 1.00 .010 .013
25 - 40 .32 .40 1.00 - 1.60 .013 .016
40 - 63 .40 .50 1.60 - 2.50 .016 .020
63 - 100 .50 .63 2.50 - 4.00 .020 .025
100 - 160 .63 .80 4.00 - 6.30 .025 .032
TABLE 3 — “A3” COMMERCIAL

T O L E R A N C E S
0 - 10 ±.20 ±.32 .00 - .40 ±.008 ±.013
10 - 16 .25 .40 .40 - .63 .010 .016
16 - 25 .32 .50 .63 - 1.00 .013 .020
25 - 40 .40 .63 1.00 - 1.60 .016 .025
40 - 63 .50 .80 1.60 - 2.50 .020 .032
63 - 100 .63 1.00 2.50 - 4.00 .025 .040
100 - 160 .80 1.25 4.00 - 6.30 .032 .050
M O L D E D
TABLE 4 — “A4” BASIC

0 - 10 ±.32 ±.80 .00 - .40 ±.013 ±.032
10 - 16 .40 .90 .40 - .63 .016 .036
16 - 25 .50 1.00 .63 - 1.00 .020 .040
25 - 40 .63 1.12 1.00 - 1.60 .025 .045
40 - 63 .80 1.25 1.60 - 2.50 .032 .050
63 - 100 1.00 1.40 2.50 - 4.00 .040 .056
100 - 160 1.25 1.60 4.00 - 6.30 .050 .063
4 800.8 LAKEVIEW (800.852.5384)

STANDARD DIMENSIONAL TOLERANCE TABLE FOR EXTRUDED PRODUCTS
RMA Class High Precision Precision Commercial

Dimensions (mm) ABOVE UP TO E1 E2 E3
0.0 - 1.5 ±0.15 ±0.25 ±0.40
1.5 - 2.5 0.20 0.35 0.50
2.5 - 4.0 0.25 0.40 0.70
4.0 - 6.3 0.35 0.50 0.80
6.3 - 10.0 0.40 0.70 1.00
10.0 - 16.0 0.50 0.80 1.30
16.0 - 25.0 0.70 1.00 1.60
25.0 - 40.0 0.80 1.30 2.00
40.0 - 63.0 1.00 1.60 2.50
63.0 - 100.0 1.30 2.00 3.20
RMA Class High Precision Precision Commercial

Dimensions (in) ABOVE UP TO E1 E2 E3
0.00 - 0.06 ±0.006 ±0.010 ±0.015
0.06 - 0.10 0.008 0.014 0.020
0.10 - 0.16 0.010 0.016 0.027
0.16 - 0.25 0.014 0.020 0.031
0.25 - 0.39 0.016 0.027 0.039
0.39 - 0.63 0.020 0.031 0.051
T O L E R A N C E S
0.63 - 0.98 0.027 0.039 0.063
0.98 - 1.57 0.031 0.051 0.079
1.57 - 2.48 0.039 0.063 0.098
2.48 - 3.94 0.051 0.079 0.126
NOTE Tolerances on dimensions above 100mm (3.94”) should be agreed on by supplier and user. General cross sectional dimensions
below 1mm (0.04”) are impractical. In general, softer materials and those requiring a post cure need greater tolerances.
Material in these tables is extracted from the RMA Rubber Handbook, 1992 Edition, page 6 and 23. Reprinted with permission.
Tolerances for outside (O.D.) diameters, inside (I.D.) diameters, wall thickness, width, height, and general cross sectional dimensions
E X T R U D E D
or extrusions.
standards
5

SYMMETRICAL
GROMMETS
Symmetrical Grommets GD
are typically used for the ID Parts are indexed
GW smaller to larger by ID,
insulation and protection of OT then GW, then GD, then
wires and cables that are OD, then OT.
OD
run through a metal or
plastic panel. Select size
based on cable diameter
(Inner Diameter), panel ID Inner Diameter
GW Groove Width
thickness (Groove Width),
GD Groove Diameter
and hole diameter OD Outer Diameter
(Groove Diameter). OT Overall Thickness
G R O M M E T S
need custom solutions?

Lakeview Industries can help you develop creative and
cost-effective solutions for your specific applications.
800.8 LAKEVIEW (800.852.5384)

PLUG & WEB
GROMMETS
C 1
Plug and Web Grommets A 9/16 .484
P/N 19017B600
P/N 10155E700
are used to plug or mask 1/4 .188
holes in metal or plastic 5/8

1-1/6 .436
.184
.184
enclosures. They can also B E
.335
.400
be used as a protective F 3/4
D 13/16
boot. Select size based
on panel hole diameter
C
(“C” dimension) and panel F
thickness (“B” dimension).
E B
A
D
A
F
E B
C
D
G R O M M E T S
!
Grommet radius may vary.
Please check our website for
any changes or additions:
Please consult Lakeview Sales www.lakeviewindustries.com
Department if radius is critical
to your application.
grommets

SYMMETRICAL GROMMETS
GD
ID
GW
Lakeview P/N ID G.W. G.D. O.D. O.T. Compound Durometer
OT
OD 11026B600 1/8 1/16 1/4 11/32 3/16 SBR 60

11026N500 1/8 1/16 1/4 11/32 3/16 NITRILE 50
ID Inner Diameter 11046B600 1/8 3/16 9/16 3/4 5/16 SBR 60
GW Groove Width
11013E600 7/64 3/64 1/2 11/16 9/32 EPDM 60
GD Groove Diameter
OD Outer Diameter 11061B600 5/32 1/16 1/4 3/8 3/16 SBR 60
OT Overall Thickness 11084B600 3/16 1/16 9/32 7/16 7/32 SBR 60
11087B600 3/16 1/16 5/16 7/16 3/16 SBR 60
11090B600 3/16 1/16 5/16 1/2 1/4 SBR 60
11102B600 3/16 3/32 9/32 7/16 7/32 SBR 60
11106B600 3/16 3/32 11/32 5/8 3/8 SBR 60
11110B600 3/16 1/8 5/16 7/16 1/4 SBR 60
11112B600 3/16 1/8 1/2 11/16 3/8 SBR 60
11118N500 3/16 3/16 5/16 7/16 5/16 NITRILE 50
11146B600 7/32 1/16 5/16 7/16 3/16 SBR 60
11177B600 1/4 1/16 3/8 1/2 1/4 SBR 60
11178B600 1/4 1/16 3/8 9/16 1/4 SBR 60
11181B600 1/4 1/16 7/16 5/8 3/16 SBR 60
11196B600 1/4 3/32 3/8 1/2 1/4 SBR 60
11205B600 1/4 1/8 3/8 1/2 1/4 SBR 60
11209B600 1/4 1/8 7/16 5/8 1/4 SBR 60
11215C500 1/4 1/8 1 1-1/4 5/16 NEOPRENE 50
11219B600 1/4 3/16 7/16 5/8 5/16 SBR 60
NOTE Parts are 11220B600 1/4 3/16 1/2 5/8 7/16 SBR 60
indexed smaller to 11221B600 1/4 3/16 5/8 7/8 5/16 SBR 60
larger by ID, then
GW, then GD, then
11223B600 1/4 3/16 1 1-1/4 3/8 SBR 60
OD, then OT. 11251B600 9/32 1/16 3/8 9/16 1/4 SBR 60
11268C600 9/32 3/16 7/16 5/8 9/16 NEOPRENE 60
11270B600 9/32 1/4 15/32 11/16 7/16 SBR 60
11277B600 5/16 1/16 3/8 5/8 1/4 SBR 60
G R O M M E T S
11278B600 5/16 1/16 7/16 9/16 3/16 SBR 60

11280B600 5/16 1/16 7/16 5/8 9/32 SBR 60
11285B600 5/16 1/16 9/16 13/16 5/16 SBR 60
11285N500 5/16 1/16 9/16 13/16 5/16 NITRILE 50
11287B600 5/16 1/16 3/4 1 5/16 SBR 60
11293B600 5/16 3/32 7/16 5/8 5/16 SBR 60
11294B600 5/16 3/32 15/32 3/4 11/32 SBR 60
11304E600 5/16 1/8 1/2 3/4 3/8 EPDM 60
11305B600 5/16 1/8 9/16 13/16 3/8 SBR 60
11305N500 5/16 1/8 9/16 13/16 3/8 NITRILE 50
11307B600 5/16 1/8 3/4 1 3/8 SBR 60
11316B600 5/16 3/16 9/16 13/16 7/16 SBR 60
11317B600 5/16 3/16 3/4 1 7/16 SBR 60
11322B600 5/16 1/4 9/16 13/16 1/2 SBR 60
8 800.8 LAKEVIEW (800.852.5384)

SYMMETRICAL GROMMETS cont.
11323N500 5/16 1/4 3/4 1 1/2 NITRILE 50

11326B600 5/16 3/8 3/8 9/16 1/2 SBR 60
11333N500 11/32 1/16 15/32 5/8 5/16 NITRILE 50
11334B600 11/32 1/16 17/32 25/32 1/4 SBR 60
11344B600 3/8 1/16 1/2 5/8 1/4 SBR 60
11347B600 3/8 1/16 17/32 5/8 11/32 SBR 60
11346B600 3/8 1/16 1/2 11/16 9/32 SBR 60
11350C600 3/8 1/16 9/16 13/16 5/16 NEOPRENE 60
11351B600 3/8 1/16 5/8 7/8 5/16 SBR 60
11354B600 3/8 1/16 3/4 1 3/8 SBR 60
11357B600 3/8 1/16 1 1-1/4 1/4 SBR 60
11363B600 3/8 3/32 7/16 5/8 9/32 SBR 60
11374B600 3/8 1/8 1/2 5/8 13/32 SBR 60
11375B600 3/8 1/8 17/32 3/4 3/8 SBR 60
11378C500 3/8 1/8 5/8 25/32 3/8 NEOPRENE 50
11379N500 3/8 1/8 5/8 7/8 3/8 NITRILE 50
11379B600 3/8 1/8 5/8 7/8 3/8 SBR 60
11380E600 3/8 1/8 11/16 15/16 3/8 EPDM 60
11382N500 3/8 1/8 7/8 1-1/8 3/8 NITRILE 50
11392B600 3/8 3/16 9/16 13/16 3/8 SBR 60
11394B600 3/8 3/16 5/8 7/8 7/16 SBR 60
11395B500 3/8 3/16 13/16 1-1/16 7/16 SBR 50
11397N500 3/8 3/16 1 1-1/4 3/8 NITRILE 50
11399B600 3/8 1/4 1/2 3/4 1/2 SBR 60
11402B600 3/8 1/4 5/8 7/8 1/2 SBR 60
11408E600 3/8 3/8 9/16 3/4 3/4 EPDM 60
11411B600 3/8 1/2 9/16 3/4 3/4 SBR 60
11414B600 3/8 1/4 1 1-1/4 7/16 SBR 60
11424N500 13/32 3/16 5/8 1-3/32 7/16 NITRILE 50
G R O M M E T S
11430B600 7/16 1/16 9/16 3/4 1/4 SBR 60
11432B600 7/16 1/16 11/16 15/16 5/16 SBR 60
11440E600 7/16 1/8 9/16 3/4 3/8 EPDM 60
11441B600 7/16 1/8 11/16 15/16 3/8 SBR 60
11441C500 7/16 1/8 11/16 15/16 3/8 NEOPRENE 50
11446B600 7/16 3/16 11/16 15/16 7/16 SBR 60
11454B600 7/16 1/4 11/16 15/16 1/2 SBR 60
11466C500 1/2 1/16 11/16 15/16 3/8 NEOPRENE 50
11470B600 1/2 1/16 13/16 1-1/16 5/16 SBR 60
11472N500 1/2 1/16 7/8 1 1/8 5/16 NITRILE 50
11474N500 1/2 1/16 1 1-1/4 1/4 NITRILE 50
11475B600 1/2 1/16 1-1/4 1-1/2 1/4 SBR 60
11479B600 1/2 3/32 3/4 7/8 11/32 SBR 60
11480B600 1/2 3/32 3/4 31/32 9/32 SBR 60
9

GD
ID
GW
OT
OD 11482B600 1/2 3/32 25/32 1-1/16 11/32 SBR 60

11483B600 1/2 1/8 5/8 13/16 11/32 SBR 60
ID Inner Diameter 11485B600 1/2 1/8 3/4 1 1/2 SBR 60
GW Groove Width
11487B600 1/2 1/8 13/16 1-1/16 3/8 SBR 60
GD Groove Diameter
OD Outer Diameter 11490N500 1/2 1/8 1-1/4 1-1/2 5/16 NITRILE 50
OT Overall Thickness 11491B600 1/2 5/32 3/4 15/16 13/32 SBR 60
11495B600 1/2 3/16 13/16 1-1/16 7/16 SBR 60
11498B600 1/2 1/4 13/16 1-1/16 1/2 SBR 60
11498E600 1/2 1/4 13/16 1-1/16 1/2 EPDM 60
11499B600 1/2 1/4 1-1/4 1-1/2 7/16 SBR 60
11501B600 1/2 3/8 3/4 1 5/8 SBR 60
11520B600 9/16 1/16 3/4 7/8 15/64 SBR 60
11529B600 9/16 1/8 11/16 13/16 3/8 SBR 60
11530B600 9/16 1/8 3/4 1 3/8 SBR 60
10104B600 9/16 1/8 1-1/16 1-3/8 9/16 SBR 60
11532B600 9/16 3/16 13/16 1-1/16 7/16 SBR 60
11535B600 9/16 1/4 13/16 1-1/16 1/2 SBR 60
11537C700 9/16 3/8 7/8 1-1/16 5/8 NEOPRENE 70
11538B600 9/16 1 13/16 1-1/8 1-1/4 SBR 60
11550B600 5/8 1/16 7/8 1-1/8 5/16 SBR 60
11554B600 5/8 1/16 1-1/4 1-1/2 1/4 SBR 60
11557B600 5/8 3/32 7/8 1-1/8 5/16 SBR 60
NOTE Parts are 11560B600 5/8 3/32 31/32 1-1/4 7/16 SBR 60
indexed smaller to 11561B600 5/8 1/8 3/4 15/16 5/16 SBR 60
larger by ID, then
GW, then GD, then
11563B600 5/8 1/8 7/8 1-1/8 3/8 SBR 60
OD, then OT. 11563N500 5/8 1/8 7/8 1-1/8 3/8 NITRILE 50
11570B600 5/8 3/16 7/8 1-1/8 7/16 SBR 60
11572B600 5/8 3/16 1-1/4 1-1/2 3/8 SBR 60
11575I500 5/8 1/4 7/8 1-1/8 1/2 ISOPRENE 50
G R O M M E T S
11580B600 5/8 5/16 29/32 1-1/8 5/8 SBR 60

11585B600 41/64 3/16 31/32 1-3/16 7/16 SBR 60
11593B600 11/16 1/16 1 1-5/16 3/8 SBR 60
11595B600 11/16 1/8 1 1-5/16 7/16 SBR 60
11599B600 11/16 3/16 1 1-5/16 1/2 SBR 60
11600B600 11/16 1/4 1 1-5/16 9/16 SBR 60
11614B600 3/4 1/16 1-1/16 1-3/8 3/8 SBR 60
11615B600 3/4 1/16 1-1/8 1-1/2 3/8 SBR 60
11616B600 3/4 1/16 1-1/4 1-5/8 1/4 SBR 60
11626B600 3/4 3/32 1-1/2 1-3/4 11/32 SBR 60
11629B600 3/4 1/8 1-1/16 1-3/8 7/16 SBR 60
11631B600 3/4 1/8 1-7/16 1-13/16 7/16 SBR 60
11636B600 3/4 3/16 1-1/16 1-3/8 1/2 SBR 60
11643B600 3/4 1/4 1-1/16 1-3/8 9/16 SBR 60
10 800.8 LAKEVIEW (800.852.5384)

11644B600 3/4 1/4 1-1/4 1-5/8 7/16 SBR 60

11857C600 27/32 1 1-11/32 1-5/8 1-1/4 NEOPRENE 60
11657I500 13/16 9/16 15/16 1-1/4 7/8 ISOPRENE 50
11664B500 7/8 1/16 1-1/16 1-3/8 3/8 SBR 50
11666B600 7/8 1/16 1-1/4 1-5/8 7/16 SBR 60
11669N600 7/8 3/32 1 1/8 1-1/2 7/16 NITRILE 60
11670B600 7/8 1/8 1-1/4 1-5/8 1/2 SBR 60
11672B600 7/8 9/64 1-3/16 1-3/8 13/32 SBR 60
11676B600 7/8 3/16 1-1/4 1-5/8 9/16 SBR 60
11845B600 7/8 3/16 1-15/64 1-9/16 3/4 SBR 60
11681B600 7/8 1/4 1-1/4 1-5/8 5/8 SBR 60
11683N500 7/8 3/8 1-1/4 1-3/4 3/4 NITRILE 50
11691B500 1 1/16 1-1/4 1-1/2 5/16 SBR 50
11695B600 1 3/32 1-1/4 1-1/2 7/32 SBR 60
11692B600 1 1/16 1-3/8 1-3/4 7/16 SBR 60
11697B600 1 1/8 1-1/4 1-1/2 3/8 SBR 60
11698B600 1 1/8 1-3/8 1-3/4 1/2 SBR 60
10034N500 1 1/8 1-7/8 2-1/4 1/2 NITRILE 50
11700B600 1 3/16 1-1/4 1-1/2 7/16 SBR 60
11701B600 1 3/16 1-3/8 1-3/4 9/16 SBR 60
11702N500 1 3/16 1-7/8 2-1/4 9/16 NITRILE 50
11703C600 1 1/4 1-1/4 1-1/2 1/2 NEOPRENE 60
11704B600 1 1/4 1-3/8 1-3/4 5/8 SBR 60
11586B600 1 3/8 1-1/4 1-1/2 5/8 SBR 60
11707C550 1 3/8 1-3/8 1 -3/4 3/4 NEOPRENE 55
11720B600 1-1/8 1/16 1-3/8 1-3/4 7/16 SBR 60
10119B600 1-1/8 1/16 1-3/8 1-3/4 3/8 SBR 60
11721B600 1-1/8 1/16 1-1/2 1-7/8 3/8 SBR 60
11734B600 1-1/8 1/4 2-3/8 2-3/4 5/8 SBR 60
G R O M M E T S
11747B600 1-1/4 3/32 1-3/4 2-1/8 3/8 SBR 60
11749B600 1-1/4 1/8 1-1/2 1-7/8 13/32 SBR 60
11753B600 1-1/4 3/16 1-5/8 1-7/8 1/2 SBR 60
11756B600 1-1/4 1/4 1-1/2 2 33/64 SBR 60
11757B600 1-1/4 1/4 1-5/8 1-7/8 9/16 SBR 60
11764B600 1-5/16 1/16 1-5/8 2 3/8 SBR 60
11765B600 1-5/16 1/8 1-5/8 2 7/16 SBR 60
11768B600 1-3/8 1/32 1-1/2 1-13/16 9/32 SBR 60
11769C500 1-3/8 1/16 1-5/8 2 1/2 NEOPRENE 50
11770B600 1-3/8 1/16 1-3/4 2 5/16 SBR 60
11773B600 1-3/8 5/32 1-5/8 1-7/8 13/32 SBR 60
11778B600 1-1/2 1/16 1-3/4 2-1/8 7/16 SBR 60
11782B600 1-1/2 3/32 2 2-3/8 3/8 SBR 60
11783B600 1-1/2 1/8 1-3/4 2-1/8 1/2 SBR 60
11

GD
ID
GW
Lakeview P/N ID G.W. G.D. O.D. O.T. COMPOUND DUROMETER
OT
OD 10112N700 1-1/2 3/16 1-5/8 51/64 25/64 NITRILE 70

11785B600 1-1/2 3/16 1-3/4 2-1/8 9/16 SBR 60
ID Inner Diameter 11786N600 1-1/2 3/16 2 2-1/2 9/16 NITRILE 60
GW Groove Width
11788B600 1-1/2 1/4 1-3/4 2 1/2 SBR 60
GD Groove Diameter
OD Outer Diameter 11789B600 1-1/2 1/4 1-3/4 2-1/8 5/8 SBR 60
OT Overall Thickness 11793N500 1-5/8 1/16 2 2-1/4 5/16 NITRILE 50
10067B550 1-5/8 1/8 1-15/16 2-5/16 3/8 SBR 55
11796B600 1-45/64 1/8 2 2-1/2 3/8 SBR 60
11797B600 1-3/4 1/16 1-15/16 2-5/16 7/16 SBR 60
11856B600 1-3/4 1/4 2 2-1/2 17/32 SBR 60
11804C550 1-3/4 1/4 2-1/8 2-1/2 5/8 NEOPRENE 55
11812B600 2 1/16 2-1/4 2-5/8 7/16 SBR 60
11813B600 2 1/16 2-1/2 3 3/8 SBR 60
11848C500 2 1/8 2-1/4 2-5/8 3/8 NEOPRENE 50
11817B600 2 3/16 2-3/8 2-3/4 9/16 SBR 60
11819E600 2 1/4 3-1/2 4 11/16 EPDM 60
11821B600 2-1/8 1/16 2-1/2 2-7/8 7/16 SBR 60
11822B600 2-1/8 1/8 2-1/2 2-7/8 7/16 SBR 60
11823B600 2-1/8 3/16 2-1/2 2-7/8 9/16 SBR 60
11834N500 2-1/2 1/8 2-3/4 3-1/8 3/8 NITRILE 50
11858E600 2-1/2 1/8 3 3-1/2 3/8 EPDM 60
20025C600 2-19/32 5/32 2-29/32 3-5/32 3/8 NEOPRENE 60
NOTE Parts are 11840B600 3 1/8 3-1/4 3-5/8 3/8 SBR 60
indexed smaller to 11840N500 3 1/8 3-1/4 3-5/8 3/8 NITRILE 50
larger by ID, then
GW, then GD, then
11843N500 3 1/4 3-1/2 4 11/16 NITRILE 50
OD, then OT. 10141N500 4 1/4 4-3/8 5-1/4 1/2 NITRILE 50
NON SYMMETRICAL GROMMETS

G R O M M E T S
1
9/16
1/4 .484
.188
1-7/8 7/16
1-1/6
3/8 .184
.436
1/4 3/32 .184
3/4 .335
1-3/8
.400
1-5/8 13/16
19014B600 19017B600 10155E700

Grommet Bushing Grommet
12 800.8 LAKEVIEW (800.852.5384)

PLUG & WEB GROMMETS
C
Lakeview P/N Product A B C D E F Comp/Duro A
15006B600 Plug Grommet SOLID 1/16 1-3/4 2 1/2 1-7/8 SBR/60 B E
14006E600 Plug Grommet 3/4 1/16 1-9/32 2 11/32 3/16 EPDM/60 F

D
14021C500 Plug Grommet 11/16 1/4 1 1-5/16 9/16 5/32 NEOPRENE/50 BOOT
14022E600 Plug Grommet 1.22 .177 1.62 2.17 .729 .315 EPDM/60
C
17001B600 Web Grommet 3/4 1/16 15/16 1-1/8 1/4 1/16 SBR/60 F
17002B600 Web Grommet 1-1/2 1/16 1-3/4 2 1/4 1/16 SBR/60 E B
17007B600 Web Grommet 3/4 1/16 15/16 1-1/8 1/4 1/32 SBR/60 A
17008S606 Web Grommet 3/4 1/16 1-1/16 1-1/4 1/4 1/32 SILICONE/60 D
PLUG GROMMET
19036B400 Boot 1/4 1/16 27/32 1-1/16 5/16 5/8 SBR/40
A
F
E B
C
D
WEB GROMMET
G R O M M E T S
13

GROMMET RECESS RECESS
BUMPERS BUMPERS BUMPER PADS
Grommet Bumpers are D

E
used as a rubber foot and
Rounded Edges
C
Flat Base
C
B A F can be easily inserted into E
B
D
E
C
a pre-drilled hole. It is A
D A
INSERT best to drill the hole B
slightly smaller than the

“A” dimension. Select
D
E panel thickness using the
Round Shouldered
C
Pull Stem-Flat
“B” dimension. C
F E B
B A
D
A E
C B D A
E
Recess Bumpers and D C
Square Shouldered
Pull Stem-Round
Bumper Pads are rubber

C
B A F feet that must be E
B
D mechanically attached by A
E
C B
a screw or rivet. Both
D A
types of bumpers provide
product cushioning and
B U M P E R S
D
E give the product a non-skid
Tapered Shouldered
surface. Available with or

Round Base
B A F C
D without a metal washer. E
C A
INSERT B
800.8 LAKEVIEW (800.852.5384)
14

PLUG STEM
BUMPERS BUMPERS
C B
Flat Bumper
E C
D
D
A
A
B
Plug Bumpers can B

INSERT
be used as either a hole
Round Bumper
(OPT.)
plug or nipple. Select C

D
proper hole size based cost-effective solutions for your specific applications.
A
on dimension “A.”
E
INSERT
B
(OPT.)
Tapered Bumper
C
D
B U M P E R S
Stem Bumpers can B
Tapered Shouldered
be used as either a hole Please check our website for

C
plug or push-in bumper. D any changes or additions:
Select proper hole size www.lakeviewindustries.com
E
based on dimension “A.” A
bumpers
15

GROMMET BUMPERS
E
Lakeview P/N INS TYPE A B C D E F Comp/Duro
B A F
D
C
FB
12072B600 N FB 5/32 1/32 3/8 3/32 7/32 15/64 SBR/60
INSERT
12551B600 N FB 5/32 1/16 3/8 3/32 1/4 17/64 SBR/60
E 20372E700 N FB 11/64 5/64 15/32 1/8 15/64 15/32 EPDM/70
12142B600 N RB 3/16 1/32 3/8 1/8 1/4 3/8 SBR/60
F
B A
D 12152B600 N FB 3/16 3/64 5/16 1/8 1/4 17/64 SBR/60
C 12184B600 N FB 3/16 1/16 1/2 3/32 1/4 11/32 SBR/60
PSF
12186B600 N FB 3/16 1/16 1/2 5/32 1/4 13/32 SBR/60
E
12241B700 N PSR 7/32 3/16 5/8 7/32 5/16 7/8 SBR/70
F
12287B600 N FB 1/4 3/64 7/16 3/32 5/16 17/64 SBR/60
B A
D 12307B600 N RB 1/4 3/64 1/2 11/64 5/16 13/32 SBR/60
C
PSR
12340B400 N RB 1/4 1/16 1/2 5/32 5/16 11/32 SBR/40
12341B600 N FB 1/4 1/16 1/2 5/32 5/16 11/32 SBR/60
E
12372B600 N RB 1/4 3/32 1/2 3/16 5/16 15/32 SBR/60
B A
D
F 12396B600 N FB 1/4 1/8 3/8 1/16 5/16 1/4 SBR/60
C 12398B600 N FB 1/4 1/8 13/32 7/32 11/32 13/32 SBR/60
INSERT RB
12405B600 N PSF 1/4 1/8 1/2 5/16 3/8 61/64 SBR/60
12559B600 N FB 1/4 1/8 1/2 1/4 3/8 3/4 SBR/60
12409B600 N FB 1/4 1/8 17/32 1/8 11/32 13/32 SBR/60
24159B600 N PSR 1/4 .20 1/2 9/32 23/64 15/16 SBR/60
12412B600 N FB 1/4 1/8 9/16 1/8 11/32 17/32 SBR/60
12416B600 N FB 1/4 3/16 17/32 1/8 11/32 15/32 SBR/60
29017C500 N PSR 1/4 1/8 1/2 1/8 7/16 3/4 NEOPRENE/50
24097B500 N PSR 1/4 1/16 3/8 5/16 5/16 1-1/8 SBR/50
12451B600 N FB 9/32 1/8 5/8 11/32 7/16 41/64 SBR/60
12474B600 N FB 5/16 3/32 5/8 1/4 3/8 27/64 SBR/60
12483B600 N FB 11/32 1/16 9/16 5/32 13/32 5/16 SBR/60
12490B600 N FB 11/32 1/8 3/4 3/16 15/32 7/16 SBR/60
12513B600 Y FB 3/8 1/8 1 1/2 1/2 1 SBR/60
12527B600 N FB 31/64 1/16 3/4 7/64 37/64 9/16 SBR/60
12532B600 N RB 1/2 1/8 1 3/16 5/8 7/16 SBR/60
B U M P E R S
12534B600 N RB 1/2 3/16 1 3/16 5/8 1/2 SBR/60

12535B600 N FB 1/2 3/16 1 5/16 11/16 11/16 SBR/60
12543B600 N RB 1-1/32 3/64 1-1/2 1/8 1-5/16 5/16 SBR/60
NOTE Parts marked with a “Y” in the INS box have a center hole for easy insertion. Parts marked with an “N” are solid.
16 800.8 LAKEVIEW (800.852.5384)

RECESS BUMPERS
D
Lakeview P/N Type Washer A B C D E Comp/Duro
C
E
A
21020B600 RS Y 1/8 1/2 1/4 1/4 3/32 SBR/60 B
21036B600 SS Y 1/8 3/4 3/4 5/16 1/2 SBR/60 RE
21039B600 RS Y 1/8 1 13/16 1/4 3/8 SBR/60 D

22030B600 SS N 1/8 23/32 7/16 1/4 7/32 SBR/60
C
21046B600 SS Y 5/32 1/2 3/8 5/16 3/16 SBR/60 E
A
21054C700 SS Y 5/32 5/8 1/2 5/16 1/4 NEOPRENE/70 B
21061C404 RS Y 5/32 3/4 3/8 5/16 3/16 NEOPRENE/40 RS
21071B600 RS Y 5/32 1 1 5/16 3/8 SBR/60 D

22053B600 SS N 5/32 5/8 7/16 5/16 9/32 SBR/60
C
22071B600 RS N 5/32 1 1 5/16 3/8 SBR/60 E
A
21083B700 SS Y 11/64 3/4 25/32 11/32 17/32 SBR/70 B
21092B600 TS Y 3/16 3/4 1/2 3/8 1/4 SBR/60 SS
21094B609 TS Y 3/16 3/4 9/16 3/8 5/16 SBR/60 D

21100B600 RS Y 3/16 15/16 3/8 3/8 5/32 SBR/60
C
21102B750 SS Y 3/16 15/16 15/16 3/8 3/8 SBR/75 E
A
21104B600 RS Y 3/16 1 7/16 3/8 1/4 SBR/60 B
21108B600 SS Y 3/16 1-1/32 5/8 9/16 1/4 SBR/60 TS
21110B600 RS Y 3/16 1-3/32 5/8 7/16 7/32 SBR/60

21112B600 RS Y 3/16 1-1/2 5/8 1/2 9/32 SBR/60
22094B600 TS N 3/16 3/4 9/16 3/8 5/16 SBR/60
22112B600 RS N 3/16 1-1/2 5/8 1/2 9/32 SBR/60
21114B600 SS Y 7/32 13/16 23/32 3/8 1/2 SBR/60
21116B600 SS Y 7/32 1 1/2 1/2 1/4 SBR/60
21117E600 SS Y 7/32 1 1 3/8 7/16 EPDM/60
21119B600 SS Y 1/4 13/16 13/16 15/32 3/8 SBR/60
21122B600 SS Y 1/4 1-1/4 1-1/4 3/8 1/2 SBR/60
21124B600 SS Y 1/4 1-1/2 3/4 15/32 1/4 SBR/60
21125B600 SS Y 1/4 1-1/2 3/4 3/4 3/8 SBR/60
22145B600 SS N 17/64 1-1/4 1-1/2 11/16 1 SBR/60
21128B600 SS Y 9/32 1 9/16 17/32 1/4 SBR/60
B U M P E R S
21131B600 SS Y 5/16 1-1/2 5/8 3/4 9/32 SBR/60
21131B850 SS Y 5/16 1-1/2 5/8 3/4 9/32 SBR/85
21132B600 SS Y 11/32 2 1-3/4 5/8 1-3/4 SBR/60
22134B600 RE N 3/8 1-11/16 1-5/8 19/32 1-3/16 SBR/60
22133B600 RE N 3/8 2-1/2 1 1-1/8 1/2 SBR/60
NOTE Parts marked with an “N” in the WASHER box are not available with washer inserts. Parts marked with
“Y” in the WASHER box come with metal inserts as standard but may be available without a metal washer insert.
ALL PARTS containing washers have a 21- prefix; ALL PARTS not containing washers have a 22- prefix.
Therefore, the P/N for a size 21001 without a metal insert would be 22001.
17

RECESS BUMPER PADS
C
Lakeview P/N Type Washer A B C D E Comp/Duro
B
E
D A 21136B600 RS Y(2) 1/8 1-3/4 5/8 1/4 1/2 SBR/60
RS
21138B600 SS Y(2) 1/4 2 1 1/2 7/16 SBR/60
21139B600 SS Y(2) 1/4 2-3/4 1 7/16 1 SBR/60
C
21140C500 SS Y(2) 1/4 4 1-1/4 3/8 3/4 NEOPRENE/50
B
22150R700 DOCK N 1/2 6 3 1-1/2 3-1/4 SBR/NR
E
D A
SS
NOTE Parts marked with an “N” in the WASHER box are not available with washer inserts. Parts marked with “Y”
in the WASHER box come with metal inserts as standard but may be available without a metal washer insert. ALL PARTS
containing washers have a 21- prefix; ALL PARTS not containing washers have a 22- prefix. Therefore, the P/N for a size
C 21001 without a metal insert would be 22001.
D A
DOCK
B U M P E R S
18 800.8 LAKEVIEW (800.852.5384)

STEM BUMPERS
B
Lakeview P/N Product Type A B C D Comp/Duro C

D
29005B600 Stem Bumper FB 5/32 1/4 1/16 7/16 SBR/60 A

FB
24029B608 Stem Bumper FB 3/16 1/2 1/32 9/32 SBR/60
12332B600 Stem Bumper FB 1/4 1/16 3/8 1/2 SBR/60 B
INSERT
(OPT.)
C
D
24110B600 Stem Bumper RB 3/8 3/4 3/8 3/4 SBR/60 A
RB
24127B700 Stem Bumper FB 31/64 5/8 7/64 27/64 SBR/70 E INSERT
B (OPT.)
24133B600 Stem Bumper RB 1/2 7/8 3/16 9/16 SBR/60
C
24138B600 Stem Bumper RB 17/32 3/4 3/8 3/4 SBR/60 D
24150C700 Stem Bumper RB 5/8 1-3/16 11/16 1-7/16 NEOPRENE/70 A

TB
PLUG BUMPERS B
Lakeview P/N Product A B C D E F G Comp/Duro C

D
E
A
28542B600 Plug Bumper 3/8 3/4 7/32 5/16 1-1/8 5/32 SBR/60
TS
28530C600 Plug Bumper 11/32 5/8 3/16 1/4 1-1/8 13/16 NEOPRENE/60
F
28804I500 Plug Bumper 7/16 5/8 1/8 3/16 5/8 1/8 1/2 NR/50
C
28808I400 Plug Bumper 1-3/16 1-3/8 5/16 7/16 1-3/4 1/2 1-7/16 NR/40
E
28805R550 Plug Bumper 13/32 1/2 3/16 1/4 7/8 3/16 SBR/NR
D
A
B
B U M P E R S
19

TIPS AND CAPS STEM
BUSHINGS
Tips and Caps are sized CØ

Stem Bushings can
AØ
slightly smaller on the I.D. be used as an insulator
Stem Bushings
D
Crutch Tip
C E
D to fit snuggly on the end of or spacer.
a rod or tube. AØ
BØ BØ
AØ
Our factories are ISO & TS
Flat Base
C D certified. Can supply PPAP’s.

certified
BØ
P A R T S
AØ
Round Base
C
D
M O L D E D
BØ
EØ

AØ
Tapered Flat
C
D
M I S C

cost-effective solutions for your specific applications
BØ
800.8 LAKEVIEW (800.852.5384)
20

SUCTION CUPS BUMPERS/
FEET
Suction Cups are used Bumper Feet can be

THREAD
C as “pickers” to lift or hold used as door bumpers or
Rounded Male
D LENGTH
B
fast to a smooth surface. HEIGHT for feet on small pieces
A of equipment.
AØ
MS
C THREAD
Rounded Female
D
B HEIGHT
A AØ
SC
P A R T S
THREAD
LENGTH
Tapered Male
HEIGHT
We help Engineers
M O L D E D
solve problems.
BØ
AØ
We help Purchasing Agents
reduce overall costs.
Reverse Tapered Male
AØ
We help our Customers THREAD
LENGTH Please check our website for
meet their tight deadlines.
HEIGHT
M I S C
BØ
misc molded parts

21

TIPS & CAPS
AØ
Lakeview P/N Type A B C D E Comp/Duro
C
D
BØ
25002B500 RB 1/16 3/8 5/8 3/4 - SBR/50
CT 25167B600 TF 1/16 5/16 1/4 3/8 - SBR/60
25025B600 RB 5/32 23/64 7/16 17/32 - SBR/60
AØ
25185B600 FB 11/64 7/16 3/16 1/4 - SBR/60
C D
25066B600 TF 19/64 15/32 11/16 29/32 3/8 SBR/60
BØ 25118B600 CT 5/8 1-1/16 1-1/8 1-7/16 - SBR/60
FB
25140B600 CT 7/8 1-3/8 1-1/8 1-1/2 - SBR/60
AØ 25174B600 CT 3/4 1-3/8 1-1/8 1-1/2 - SBR/60
C
25171B600 Square Cap - FB 1 1-3/8 1 1-1/4 - SBR/60
D
25150B600 CT 1 1-1/2 1-3/16 1-9/16 - SBR/60
BØ 25177B600 CT 1-1/8 1-5/8 1-3/16 1-9/16 - SBR/60
RB
25178B600 CT 1-1/4 1-3/4 1-3/16 1-9/16 - SBR/60
EØ
AØ
C STEM BUSHINGS
D
BØ Lakeview P/N Product A B C D E Comp/Duro

TF
28013B600 Stem Bushing 1/8 1/4 3/8 7/64 3/8 SBR/60

28028C600 Stem Bushing 11/64 9/32 1/2 3/32 13/64 NEOPRENE/60
CØ 28041B600 Stem Bushing 3/16 1/2 5/8 1/8 9/16 SBR/60
D
E 28042C600 Stem Bushing 3/16 5/8 1 1/4 3/4 NEOPRENE/60
AØ
BØ 28080B600 Stem Bushing 5/16 1/2 3/4 1/8 13/32 SBR/60
28086B600 Stem Bushing 5/16 5/8 1 1/4 19/32 SBR/60
M I S C M O L D E D PA RT S

28098B700 Stem Bushing 3/8 21/32 1 3/32 5/16 SBR/70
28100B600 Stem Bushing 3/8 15/16 1-3/16 5/64 27/64 SBR/60
22 800.8 LAKEVIEW (800.852.5384)

SUCTION CUPS
C
D
Lakeview P/N Type A B C D Screw Comp/Duro B
A
MS
27041I303 SC 1 7/16 - 1/4 - ISOPRENE/30
27050I500 MS 1 7/16 1/4 - 8-32 ISOPRENE/50
C
27080B600 MS 1-1/2 1/2 3/8 - 8-32 SBR/60 D
B
27055C500 SC 1-1/2 3/4 - 17/32 - NEOPRENE/50 A
27031I500 MS 1-3/4 5/8 3/8 - 8-32 ISOPRENE/50 SC
BUMPERS / FEET
THREAD
Lakeview P/N Type A B Height Thread Length LENGTH
HEIGHT
AØ
38005 TM 1-1/2 1 1-1/4 5/16-18 5/8 RM
38008 TM 1-5/8 1-3/16 2 5/16-18 5/8
38028 RTM 1-3/8 1-5/8 1 5/16-18 5/8 THREAD
38029 RM 7/16 - 1/4 6-32 1/4 HEIGHT
AØ
38043 RM 1/2 - 1/4 6-32 1/4
RF
38030 RM 3/4 - 11/32 8-32 1/4
38032 RF 5/8 - 5/16 8-32 - THREAD
LENGTH
38027 RTM 1-3/16 1-5/8 1-1/2 5/16-18 5/8
HEIGHT
30141 RM 1 - 21/32 1/4-20 3/4
38054 TM 1-1/2 1 1-1/4 5/16-24 1-3/4 BØ
AØ
32083 RM 2-61/64 - 2-7/64 M10 X 1.5 27/32 TM
1-3/4 1-3/8
2.78 AØ
5/16 THREAD
LENGTH
1/2
5/8 1/8 HEIGHT
2-3/8 2.76
1/2
M I S C M O L D E D PA RT S
1.00 1/8 BØ
1/4
5/32
.25 RTM
5/8 1/4
7/32
1-7/8 1-5/8 1/8
.50
3.11 9/64
3/8
34020 20305 38041 23001B600 23010B600

Screw Bumper Knurled Bumper
23

CYLINDRICAL
MOUNTS
AØ
Mounts provide isolation THREAD

LENGTH
from noise and vibration.
Male Male
Product is typically B
HEIGHT
positioned between a motor LENGTH cost-effective solutions for your specific applications.
or fan and the mounting THREAD
MM
frame. The size and weight
of the equipment will
determine the size and THREAD AØ
Female Female
durometer of the mount. B

HEIGHT
THREAD
FF
AØ
THREAD
LENGTH
Male Female
B Additional mount specifications

HEIGHT
(including load ratings) available
upon request. Contact Lakeview
THREAD
MF
Sales Department for assistance.
THREAD
M O U N T S
Globally recognized
Female Bushing
Quality. Technology. People.

HEIGHT
for innovation in
flexible OEM parts. AØ
FB
800.8 LAKEVIEW (800.852.5384)
24

H MOUNTS T MOUNTS
H Mounts provide AØ T Mounts provide

AØ
E
isolation under more D
isolation and flexible F
BØ F
severe loads. Typical suspension for mobile and D BØ E
CØ
applications include E
portable equipment such
CØ
engines and tractor AØ
as cabs, engines and
cabs used on off-road compressors.
equipment.
M O U N T S
Parts may available in stud lengths (LENGTH) different than what is listed as standard. Please check our website for
Additional mount specifications (including load ratings) available upon request. Contact any changes or additions:
Lakeview Sales Department for assistance. www.lakeviewindustries.com
mounts
25

CYLINDRICAL MOUNTS
AØ
THREAD Lakeview P/N TYPE A B THREAD LENGTH
LENGTH
B
HEIGHT 31963 MM 3/8 1/2 10-32 3/8
LENGTH 31007 MM 9/16 1/2 8-32 3/8
THREAD
MM 31119 MM 5/8 5/8 1/4-20 5/8
31019 MM 3/4 3/8 1/4-20 1/2
THREAD AØ 31962 MM 3/4 5/8 1/4-20 1/2
31022 MM 3/4 1 5/16-18 5/8
B
HEIGHT
31031 MM 1 1/2 1/4-20 1/2
THREAD FF 31033 MM 1 17/32 1/4-20 1/2
31044 MM 1 3/4 1/4-20 3/8
AØ 31036 MM 1 3/4 1/4-20 1/2
THREAD
LENGTH 31041 MM 1 3/4 1/4-20 3/4
B 31097 MM 1 3/4 5/16-18 3/4
HEIGHT
31038 MM 1 25/32 1/4-20 3/4
THREAD MF
31040 MM 1 1 1/4-20 1/2
31116 MM 1 1 5/16-18 1/2
THREAD 31120 MM 1 1 5/16-18 7/8
31042 MM 1 1 5/16-18 5/8
B
HEIGHT 31049 MM 1-1/4 3/4 1/4-20 1/2
AØ 31052 MM 1-1/4 1 5/16-18 5/8
FB
31053 MM 1-1/4 1-1/4 5/16-18 5/8
31113 MM 1-1/4 3/4 5/16-18 3/4
31961 MM 1-3/8 1 5/16-18 9/16
31056 MM 1-3/8 1 5/16-18 3/4
31099 MM 1-3/8 1 5/16-18 1
31061 MM 1-1/2 1 3/8-16 3/4
31060 MM 1-1/2 1 5/16-18 5/8
31063 MM 1-1/2 1-1/4 3/8-16 5/8
31074 MM 2 3/4 3/8-16 1-1/8
31080 MM 2 1-5/8 3/8-16 5/8
32002 MF 3/8 1/2 8-32 1/2
32077 MF 3/8 1/2 8-32 3/8
M O U N T S
32005 MF 9/16 1/2 8-32 3/8

32006 MF 19/32 33/64 8-32 3/8
32053 MF 5/8 5/8 1/4-20 3/8
32017 MF 1 1/2 1/4-20 1/2
32019 MF 1 3/4 1/4-20 1/2
32054 MF 1 3/4 5/16-18 1/2
32008 MF 1 1 1/4-20 1/2
32023 MF 1 1 5/16-18 1/2
32045 MF 1-3/16 1 5/16-18 5/8
32028 MF 1-3/8 1 5/16-18 9/16
32029 MF 1-1/2 1 5/16-18 5/8
32031 MF 1-1/2 1 3/8-16 3/4
26 800.8 LAKEVIEW (800.852.5384)

CYLINDRICAL MOUNTS cont.
Lakeview P/N TYPE A B THREAD LENGTH
32041 MF 2 3/4 3/8-16 1-1/8

32044 MF 2 1-5/8 3/8-16 5/8
32047 MF 2 2 3/8-16 1-1/8
32057 MF 3-1/8 2-1/4 1/2-13 1-1/4
33009 FF 1 1/2 1/4-20 -
33013 FF 1 1 5/16-18 -
33017 FF 1-1/2 1 5/16-18 -
33031 FF 2 1-5/8 3/8-16 -
33032 FF 2 1-3/4 1/2-13 -
33018 FF 2 1-1/2 1/2-13 -
33039 FF 2 2-1/8 1/2-13 -
34004 MB 1-1/2 3/4 1/4-20 1/2
34007 MB 1 3/8 1/4-20 1-3/16
34008 MB 1 3/8 5/16-18 1-1/4
34009 MB 1 1/2 1/4-20 1/2
34012 MB 1 3/4 5/16-18 1/2
34015 MB 1 1 1/4-20 1/2
34016 MB 1 1 5/16-18 5/8
34018 MB 1-1/4 1 5/16-18 9/16
30143 MB 1-1/4 1-1/2 1/4-20 1/2
34002 MB 1-1/2 1 3/8-16 3/4
34005 MB 1-1/2 1 5/16-18 5/8
34028 MB 2 3/4 3/8-16 1-1/8
34031 MB 2 1-5/8 3/8-16 5/8
34032 MB 2 1-5/8 3/8-16 7/8
34035 MB 3.175 2-1/2 1/2-13 5/8
34033 MB 2 1-5/8 3/8-16 5/8
35003 FB 1 3/4 1/4-20 -
35006 FB 1-1/2 1-1/4 3/8-16 -
M O U N T S
27

H MOUNTS
AØ
E Lakeview P/N Type A B C D E F

D BØ F
CØ 36501 H 1.25 0.39 0.78 1.00 0.50 0.12

E 36502 H 1.31 0.39 0.79 1.25 0.49 0.38
AØ 36503 H 1.88 0.53 1.30 1.94 0.78 0.53
36511 H 2.00 0.56 1.30 1.00 0.50 0.20
36504 H 2.55 0.64 1.54 2.50 0.90 0.75
36506 H 3.50 0.94 2.30 2.90 1.00 1.00
36507 H 4.88 1.06 2.55 3.40 1.25 1.00
M O U N T S
28 800.8 LAKEVIEW (800.852.5384)

T MOUNTS
AØ
Lakeview P/N Type A B C D E F F
D BØ E
36003 T 1.09 0.400 0.81 1.020 0.62 0.220

CØ
36004 T 1.25 0.410 0.95 1.440 1.07 0.550
36007 T 1.75 0.520 1.24 1.250 1.00 0.410
39001 T 2.00 0.530 1.35 1.250 1.00 0.530
36011 T 2.00 0.530 1.38 2.000 1.45 0.750
36014 T 2.35 0.645 1.50 2.110 1.50 0.690
36080 T 2.50 0.640 1.50 2.187 1.71 0.650
36025 T 2.98 0.645 1.98 2.220 2.00 0.812
36030 T 3.68 0.770 2.20 2.500 2.12 0.940
M O U N T S
29

DUAL DUROMETER EXTRUDED
CLIP SEALS PROFILES
Dual Durometer Extruded Profiles are

A
Clip Seals have a wire continuous shapes of
Square Edge
0.76
carrier that allows easy 1.29

rubber that act as a seal or B
D
0.53
installation to a panel protective cover attached
C
0.39
edge as a door or weather to a panel edge or surface.
seal. All profiles have a
flexible wire carrier
encapsulated with 70 A
Rounded Edge
Durometer EPDM. All B
D
bulbs are medium density
EPDM Sponge except C
P/N 76115E700.
V E R S AT I L E
Extrusions can be
cut-to-length, mitered,
Lakeview Industries can help you develop creative and and spliced into
cost-effective solutions for your specific applications. complete gaskets.
E X T R U S I O N S
800.8 LAKEVIEW (800.852.5384)
30

EXTRUDED
PROFILES
WITH ADHESIVE
ENGINEERED
Extruded Profiles
SOLUTIONS
with Adhesive are either
PRODUCT
Ø0.25
0.5
sponge or dense rubber
0.047
profiles that can be 0.375
0.5
3/8" HATS
used in a wide variety

of sealing applications.
The pressure sensitive
tape allows for easy
installation.
E X T R U S I O N S
Lakeview utilizes the 3M Gasket Bonding Tape System for extruded profiles with adhesive. The tape is
heat fused directly to the extrusion for a powerful bond. The user side has acrylic adhesive which
bonds to multiple substrates. Other adhesives available upon request. The standard material for these
profiles, with the exception of 77004HATS and 73504HATS is medium density EPDM closed cell sponge.
extrusions
31

DUAL DUROMETER CLIP SEALS
.28
.39
0.214 .027 THK .5
EPDM
SPONGE 0.63
.82 .98 1.10 1.16
0.828 EPDM
0.530 .53 .445 DENSE 0.53
FLEX
.39 .39 .236 CARRIER
0.390 0.24
.394
0.39
76110DDUR 76115E700 77029DDUR 76010DDUR 76035DDUR

Dense Rubber
.72
0.76 .76
.89 .927
1.29 1.20
0.53 .53 .43 .53 .55 .53 .50 .454 .53
0.39 .39 .39 .39 .24

.06 .39
76031DDUR 77030DDUR 76131DDUR 76112DDUR 77025DDUR
1.29
1.019
1.09 0.89
1.156 .80 EPDM
NOTE 0.118 .67 0.70 DENSE
0.53 0.76
0.500
Profile drawings 0.715 .53 .453 .56 0.53
FLEX
CARRIER
.276 0.39
are not full scale. 0.090
0.329 0.07 TYP WALL
.231 0.39 .587
0.539
.39
76054DDUR 76113DDUR 77019DDUR 76124DDUR 77020DDUR
EXTRUDED PROFILES
.375
0.05
A 0.03
A .203 .250
.24 3/8"
E X T R U S I O N S
B .750
B D 0.23
D
.43 .53 9/32"
0.08
1/16"
C C .39 .094 1-1/8"
0.06
SE RE 0.16 .264
77022DDUR 71006E700 71105E700 78008E700

With Wire Carrier
Lakeview P/N Type A B C D Comp/Duro
71003E700 RE 3/64 19/64 13/64 3/8 EPDM/70

71011E700 RE 3/32 1/4 7/32 5/16 EPDM/70
71017E700 SE 1/8 1/4 1/4 5/16 EPDM/70
71021E700 RE 1/8 13/32 5/16 1/2 EPDM/70
71030E600 SE 1/4 1/8 3/8 3/16 EPDM/60
71009E700 RE 1/16 3/8 5/16 17/32 EPDM/70
71010E700 RE 5/64 5/16 13/64 3/8 EPDM/70
32 800.8 LAKEVIEW (800.852.5384)

EXTRUDED PROFILES WITH ADHESIVE
.562
Ø0.25
.32 0.5 .375

0.216 .25 .662
0.047 0.062 .09
0.047
0.25 1/4" HATS .375 0.375 3/8" HATS .09
0.354 0.5
73208HATS 73220HATS 73202HATS 78098HATS
.10
.65
.52
.375 0.5 0.375
.125 .17
0.047 .047
3/8" HATS 5/8" HATS .50
.50 0.375" 0.625
.625 0.625 0.75 .70
Ø0.3125
0.09
0.75 1.00
.358 0.562
0.12 1.40
0.047 0.047
5/8" HATS .484 0.625 5/8" HATS .875
0.625
0.75 .61 0.75

.25
60.00
Ø0.5 Ø0.312
1.00 1.125
.703
0.375
.25 .475
.047
0.047 0.07 0.625 5/8" HATS
.50 0.75
0.75 3/4" HATS 0.219
1.00 3/8" HATS .65
.578
E X T R U S I O N S
0.59
0.04
0.27
0.815
.30
0.217
0.047
3/8" HATS
1.0 1" HATS
.50 0.125 0.085
0.125
1.5
0.49
10.000 ∞
73515HATS 73504HATS 77004HATS

50 Durometer EPDM EPDM Sponge/
70 Durometer EPDM
33

Compression Mounts 5-3/8
17/32
4-1/8
and Pads are used to
P/N 39033C500
3-1/4
isolate medium to
large size engines,
1.66
P A D S
fans and pumps. 1/8

&
M O U N T S
We can help design parts
need custom solutions? for specific applications,

improve product performance,
C O M P R E S S I O N
cost-effective solutions for your specific applications. reduce overall costs, AND
improve turn around time.
Globally recognized
for innovation in
flexible OEM parts.
800.8 LAKEVIEW (800.852.5384)
34

4.00
• EMI Shielding/Thermal Management
P/N 39010C600
4.00
• Cushioning/Surface Protection
1/2
P A D S
• Noise and Vibration Control
5/8
• Environmental Sealing
18.00
&
P/N 0267
18.00 certified. Can supply PPAP’s.
certified
M O U N T S
.25
C O M P R E S S I O N
compression mounts & pads

35

PART PAGE PART PAGE PART PAGE PART PAGE PART PAGE
0267 35 32054 26 38029 23 11304E600 8 11479B600 9

30141 23 32057 27 38030 23 11305B600 8 11480B600 9
30143 27 32077 26 38032 23 11305N500 8 11482B600 10
31007 26 33009 27 38043 23 11307B600 8 11483B600 10
31019 26 33013 27 39001 29 11316B600 8 11485B600 10
31022 26 33017 27 10034N500 11 11317B600 8 11487B600 10
31031 26 33018 27 10067B550 12 11322B600 8 11490B600 10
31033 26 33031 27 10104B600 10 11323N500 9 11491B600 10
31036 26 33032 27 10112N700 12 11326B600 9 11495B600 10
31038 26 33039 27 10119B600 11 11333N500 9 11498B600 10
31040 26 34002 27 10141N500 12 11334B600 9 11498E600 10
31041 26 34003 27 10155E700 13 11344B600 9 11499B600 10
31042 26 34004 27 11013E600 8 11346B600 9 11501B600 10
31044 26 34005 27 11026B600 8 11347B600 9 11520B600 10
31049 26 34007 27 11026N500 8 11350C600 9 11529B600 10
31052 26 34008 27 11046B600 8 11351B600 9 11530B600 10
31053 26 34009 27 11061B600 8 11354B600 9 11532B600 10
31056 26 34012 27 11084B600 8 11357B600 9 11535B600 10
31060 26 34015 27 11087B600 8 11363B600 9 11537C700 10
31061 26 34016 27 11090B600 8 11374B600 9 11538B600 10
31063 26 34018 27 11102B600 8 11375B600 9 11550B600 10
31074 26 34020 23 11106B600 8 11378C500 9 11554B600 10
31080 26 34028 27 11110B600 8 11379B600 9 11557B600 10
31097 26 34031 27 11112B600 8 11379N500 9 11560B600 10
31099 26 34032 27 11118N500 8 11380E600 9 11561B600 10
31113 26 34033 27 11146B600 8 11382N500 9 11563B600 10
31116 26 34035 27 11177B600 8 11392B600 9 11563N500 10
31119 26 35003 27 11178B600 8 11394B600 9 11570B600 10
31120 26 35006 27 11181B600 8 11395B500 9 11572B600 10
31961 26 36003 29 11196B600 8 11397N500 9 11575I500 10
31962 26 36004 29 11205B600 8 11399B600 9 11580B600 10
31963 26 36007 29 11209B600 8 11402B600 9 11585B600 10
32002 26 36011 29 11215C500 8 11408E600 9 11586B600 11
32005 26 36014 29 11219B600 8 11411B600 9 11593B600 10
32006 26 36025 29 11220B600 8 11414B600 9 11595B600 10
32008 26 36030 29 11221B600 8 11424N500 9 11599B600 10
I N D E X
32017 26 36080 29 11223B600 8 11430B600 9 11600B600 10

32019 26 36501 28 11251B600 8 11432B600 9 11614B600 10
32023 26 36502 28 11268C600 8 11440E600 9 11615B600 10
32028 26 36503 28 11270B600 8 11441B600 9 11616B600 10
32029 26 36504 28 11277B600 8 11441C500 9 11626B600 10
32031 26 36506 28 11278B600 8 11446B600 9 11629B600 10
32034 27 36507 28 11280B600 8 11454B600 9 11631B600 10
32041 27 36511 28 11285B600 8 11466C500 9 11636B600 10
32044 27 38005 23 11285N500 8 11470B600 9 11643B600 10
32045 26 38008 23 11287B600 8 11472N500 9 11644B600 11
32047 27 38027 23 11293B600 8 11474N500 9 11657I500 11
32053 26 38028 23 11294B600 8 11475B600 9 11666B600 11
36 800.8 LAKEVIEW (800.852.5384)

PART PAGE PART PAGE PART PAGE PART PAGE PART PAGE
11669N600 11 11823B600 12 19014B600 12 24029B608 19 38054I400 23

11670B600 11 11834N500 12 19017B600 13 24057B600 19 39010C600 35
11672B600 11 11840B600 12 19036B400 13 24072B600 19 39033C500 34
11676B600 11 11840N500 12 20025C600 12 24097B500 16 71003E700 32
11681B600 11 11843N500 12 20305C600 23 24110B600 19 71006E700 32
11683N500 11 11845B600 11 20372E700 16 24125B600 19 71009E700 32
11691B500 11 11848C500 12 21020B600 17 24127B700 19 71010E700 32
11692B600 11 11856B600 12 21036B600 17 24133B600 19 71011E700 32
11695B600 11 11857C600 11 21039B600 17 24138B600 19 71017B700 32
11697B600 11 11858E600 12 21046B600 17 24150C700 19 71021E700 32
11698B600 11 12072B600 16 21054C700 17 24159B600 16 71030E600 32
11700B600 11 12142B600 16 21061C404 17 25002B500 22 71105E700 32
11701B600 11 12152B600 16 21071B600 17 25025B600 22 73071HATS 33
11702N500 11 12184B600 16 21083B700 17 25066B600 22 73103HATS 33
11703C600 11 12186B600 16 21092B600 17 25118B600 22 73202HATS 33
11704B600 11 12241B700 16 21094B609 17 25140B600 22 73203HATS 33
11707C550 11 12287B600 16 21100B600 17 25150B600 22 73204HATS 33
11720B600 11 12307B600 16 21102B750 17 25167B600 22 73205HATS 33
11721B600 11 12332B600 19 21104B600 17 25171B600 22 73206HATS 33
11734B600 11 12340B700 16 21108B600 17 25174B600 22 73208HATS 33
11747B600 11 12341B600 16 21110B600 17 25177B600 22 73210HATS 33
11749B600 11 12372B600 16 21112B600 17 25178B600 22 73211HATS 33
11753B600 11 12396B600 16 21114B600 17 25185B600 22 73215HATS 33
11756B600 11 12398B600 16 21116B600 17 28530B600 19 73220HATS 33
11757B600 11 12405B600 16 21117E600 17 27031I500 23 73504HATS 33
11764B600 11 12409B600 16 21119B600 17 27041I303 23 73510HATS 33
11765B600 11 12412B600 16 21122B600 17 27050I500 23 73511HATS 33
11768B600 11 12416B600 16 21124B600 17 27055C500 23 76010DDUR 32
11769C500 11 12451B600 16 21125B600 17 27080B600 23 76031DDUR 32
11770B600 11 12474B600 16 21128B600 17 28013B600 22 76035DDUR 32
11773B600 11 12483B600 16 21131B600 17 28028C600 22 76054DDUR 32
11778B600 11 12490B600 16 21131B850 17 28041B600 22 76110DDUR 32
11782B600 11 12513B600 16 21132B600 17 28042C600 22 76112DDUR 32
11783B600 11 12527B600 16 21136B600 18 28058B600 22 76113DDUR 32
11785B600 12 12532B600 16 21138B600 18 28080B600 22 76115SE700 32
11786N600 12 12534B600 16 21139B600 18 28086B600 22 76124DDUR 32
I N D E X
11788B600 12 12535B600 16 21140C500 18 28097B600 22 76131DDUR 32
11789B600 12 12543B600 16 22030B600 17 28098B700 22 77004HATS 33
11793N500 12 12551B600 16 22053B600 17 28100B600 22 77019DDUR 32
11796B600 12 12559B600 16 22071B600 17 28110B600 22 77020DDUR 32
11797B600 12 14006E600 13 22094B600 17 28542B600 19 77022DDUR 32
11804C550 12 14021C500 13 22112B600 17 28804I500 19 78008E700 32
11812B600 12 14022E600 13 22133B600 17 28805R550 19 78097HATS 33
11813B600 12 15006B600 13 22134B600 17 28808I400 19 78098HATS 33
11817B600 12 17001B600 13 22145B600 17 29005B600 19
11819E600 12 17002B600 13 22150R700 18 29017C500 16
11821B600 12 17007B600 13 23001B600 23 32083C800 23
11822B600 12 17008S606 13 23010B600 23 38041C500 23
37

manufacturing facility.
has a knowledgeable
expertise in offshore
Lakeview Industries
engineering staff,
sourcing and a
state-of-the-art
Quality. Technology. People.

certified. Can supply PPAP’s.
certified
die cut gaskets

molded rubber components
value added extrusions
1225 Lakeview Drive

Chaska, Minnesota
55318-9506
1-800-852-5384

Solutions: Leading The Way

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Solutions: Leading The Way

Uploaded by

Copyright:

Available Formats

We can help design parts

for specific applications,

• EMI Shielding/Thermal Management

Leading the Way

global source rubber products

Downloaded from Arrow.com.

We are your full-service, one-stop

Rubber-to-Metal Bonded Parts

Die-cut Foam Pads with PSA

Conductive Sheet Products

EMI Shielding Products

Thermal Management Products

Downloaded from Arrow.com.

For Engineering Design Assistance

Downloaded from Arrow.com.

Impact Strength Excellent Excellent Good Good Fair

Adhesion to Metal Excellent Excellent Good - Excellent Excellent Excellent

Resiliency Excellent Fair - Excellent Good Fair - Good Good

Impermeability to Gas Good Fair Fair - Good Fair - Good Good

Chemical/Fuel Poor Poor Fair - Good Good Excellent

Flame Poor Poor Poor Good - Excellent Poor

Flex Cracking Excellent Good - Excellent Good Good Good

Oil Poor Poor Poor Good Excellent

Oxidation Fair Fair Excellent Good - Excellent Fair - Good

Ozone Poor Poor Good - Excellent Good - Excellent Fair

Steam Fair - Good Fair - Good Excellent Fair Fair - Good

Sunlight Poor Poor Excellent Good - Excellent Poor - Good

Water Swell Fair Excellent Excellent Good Excellent

2 800.8 LAKEVIEW (800.852.5384)

Downloaded from Arrow.com.

Excellent Fair - Excellent Fair - Good Good Good Vibration Damping

Poor Poor Excellent Excellent Fair Chemical/Fuel

Good - Excellent Excellent Excellent Excellent Fair - Good Heat Aging

Poor Fair - Good Excellent Good Good Oil

Excellent Excellent Excellent Excellent Good - Excellent Oxidation

Excellent Excellent Excellent Excellent Excellent Ozone

Excellent Excellent Good - Excellent Excellent Good - Excellent Sunlight

Good Poor - Good Fair - Good Poor Excellent Tearing

Excellent Good - Excellent Excellent Good Good Water Swell

Excellent Excellent Excellent Excellent Good - Excellent Weather Aging

Downloaded from Arrow.com.

TABLE 1 — “A1” HIGH PRECISION

TABLE 2 — “A2” PRECISION

TABLE 3 — “A3” COMMERCIAL

TABLE 4 — “A4” BASIC

4 800.8 LAKEVIEW (800.852.5384)

Downloaded from Arrow.com.

RMA Class High Precision Precision Commercial

RMA Class High Precision Precision Commercial

Downloaded from Arrow.com.

need custom solutions?

800.8 LAKEVIEW (800.852.5384)

Downloaded from Arrow.com.

holes in metal or plastic 5/8

Downloaded from Arrow.com.

OD 11026B600 1/8 1/16 1/4 11/32 3/16 SBR 60

11278B600 5/16 1/16 7/16 9/16 3/16 SBR 60

8 800.8 LAKEVIEW (800.852.5384)

Downloaded from Arrow.com.

Lakeview P/N ID G.W. G.D. O.D. O.T. Compound Durometer

11323N500 5/16 1/4 3/4 1 1/2 NITRILE 50

Downloaded from Arrow.com.

OD 11482B600 1/2 3/32 25/32 1-1/16 11/32 SBR 60
