Cabin Module

CABIN MODULE
119D59445-1
TABLE OF CONTENTS Sandvik DD321-40C 190701
12. CABIN MODULE

* BG 012 733 89 NSS MODULE, CABIN............................................................................................................................................. 2
** 551 683 73 NSS SCREW KIT......................................................................................................................................................... 5
** 551 613 90 CABIN........................................................................................................................................................................... 6
*** 550 520 17 NSS WINDOW KIT.................................................................................................................................................. 7
*** 551 888 97 DOOR ASSEMBLY.................................................................................................................................................. 10
*** 551 888 98 DOOR ASSEMBLY.................................................................................................................................................. 12
*** 551 824 86 NSS WASHING EQUIPMENT KIT........................................................................................................................... 14
**** 551 825 40 NSS WIPER......................................................................................................................................................... 15
**** 551 825 42 NSS WIPER......................................................................................................................................................... 16
**** 551 825 43 NSS WIPER......................................................................................................................................................... 17
**** 551 825 44 NSS WIPER......................................................................................................................................................... 18
**** 550 608 43 NSS WASHING EQUIPMENT KIT....................................................................................................................... 20
*** 551 712 60 NSS AIR CONDITIONING, CABIN.......................................................................................................................... 21
**** 550 517 38 FILTER UNIT........................................................................................................................................................ 22
*** 551 824 87 NSS INSULATION AND LINING.............................................................................................................................. 24
*** 551 888 96 UPHOLSTERY KIT.................................................................................................................................................. 25
*** 551 888 94 NSS ELECTRICS KIT.............................................................................................................................................. 26
**** 550 608 68 PANEL, INSTRUMENT........................................................................................................................................ 27
**** 550 608 70 CABLE SET.......................................................................................................................................................... 28
**** 550 613 58 ENCLOSURE....................................................................................................................................................... 30
**** 550 617 71 TERMINAL BOX................................................................................................................................................... 31
** 552 120 24 AIR CONDITIONER..................................................................................................................................................... 32
** 550 394 34 PEDAL, THROTTLE..................................................................................................................................................... 33
** 551 996 57 NSS PEDAL, BRAKE................................................................................................................................................... 36
*** 551 972 08 VALVE, BRAKE........................................................................................................................................................ 37
** BG 005 221 62 GAUGE ASSEMBLY.............................................................................................................................................. 38
** BG 005 235 91 GAUGE ASSEMBLY.............................................................................................................................................. 39
** 552 086 25 NSS STEERING UNIT................................................................................................................................................. 42
*** 550 515 63 NSS ASSEMBLY...................................................................................................................................................... 43
*** 551 644 14 ASSEMBLY.............................................................................................................................................................. 44
** 321 561 11 NSS GAUGE ASSEMBLY........................................................................................................................................... 46
** 550 752 86 NSS MESH, SAFETY.................................................................................................................................................. 47
** BG 004 925 17 NSS SEAT ASSEMBLY......................................................................................................................................... 50
*** 770 158 78 SEAT........................................................................................................................................................................ 51
*** BG 004 922 88 BRACKET.......................................................................................................................................................... 52
** 552 227 19 NSS HOSE SUPPORT ASSEMBLY............................................................................................................................ 54
** 552 157 21 ENCLOSURE, DOCUMENTS...................................................................................................................................... 55
** 552 056 29 NSS PANEL, CONTROL............................................................................................................................................. 58
*** 551 802 64 NSS CONTROL BOX ASSEMBLY.......................................................................................................................... 61
*** 551 686 62 NSS SYSTEM, CONTROL....................................................................................................................................... 64
**** 551 814 98 NSS VALVE ASSEMBLY..................................................................................................................................... 68
***** 551 752 40 VALVE ASSEMBLY.......................................................................................................................................... 70
****** BG 007 642 46 VALVE, PRESSURE RELIEF................................................................................................................ 73
****** 551 819 30 VALVE ASSEMBLY...................................................................................................................................... 75
******* 887 363 89 VALVE SECTION.................................................................................................................................................... 78
******* 882 204 89 MECHANICAL ACTIVATING MODULE................................................................................................................... 79
******* 882 883 99 CONTROL BLOCK ASSEMBLY.............................................................................................................................. 80
**** 550 570 69 NSS CONTROL BLOCK ASSEMBLY.................................................................................................................. 82
***** 888 012 39 CONTROL BLOCK ASSEMBLY...................................................................................................................... 83
**** 551 668 19 VALVE ASSEMBLY.............................................................................................................................................. 86
***** 864 257 79 VALVE, DIRECTIONAL.................................................................................................................................... 89
**** 552 121 04 CONTROL VALVE ASSEMBLY........................................................................................................................... 92
*** 552 056 57 CONTROL ASSEMBLY............................................................................................................................................ 98
**** 552 056 53 CONTROL ASSEMBLY........................................................................................................................................ 100
***** 550 554 81 CABLE ASSEMBLY......................................................................................................................................... 105
***** 551 672 63 CABLE ASSEMBLY......................................................................................................................................... 106
***** 551 672 61 CABLE ASSEMBLY......................................................................................................................................... 107
***** 551 901 65 JUNCTION BOX ASSEMBLY.......................................................................................................................... 110
Sandvik Mining and Construction Oy Drills Tampere © 2019

119D59445-1
**** 551 671 43 ELECTRIC COMPONENTS ASSEMBLY............................................................................................................. 112

***** 551 652 51 ASSEMBLY...................................................................................................................................................... 114
***** 106 148 51 JUNCTION BOX............................................................................................................................................... 115
****** 552 266 86 CABLE ASSEMBLY...................................................................................................................................... 116
**** 552 263 65 NSS ELECTRIC COMPONENTS ASSEMBLY.................................................................................................... 118
***** 552 266 87 CABLE ASSEMBLY......................................................................................................................................... 119
*** 552 017 67 CONSOLE ASSEMBLY, OPERATOR'S.................................................................................................................. 122
**** 551 752 05 NSS VALVE, PRESSURE RELIEF...................................................................................................................... 125
**** 550 015 57 NSS ADAPTER ASSEMBLY................................................................................................................................ 126
**** 551 663 36 NSS VALVE, DIRECTIONAL............................................................................................................................... 128
****** 551 985 09 COVER, END............................................................................................................................................... 139
****** 551 985 10 VALVE SECTION......................................................................................................................................... 140
****** 551 985 20 VALVE SECTION......................................................................................................................................... 141
****** 882 591 69 LEVER.......................................................................................................................................................... 142
**** 551 645 20 VALVE ASSEMBLY.............................................................................................................................................. 144
**** 551 752 11 CONTROL VALVE ASSEMBLY........................................................................................................................... 146
** 552 127 75 NSS MOUNTING......................................................................................................................................................... 147
** BG 004 855 58 NSS ALARM LIGHT, MOUNTING......................................................................................................................... 150
** BG 005 047 81 NSS LIGHT, WORK.............................................................................................................................................. 151
** 551 510 25 NSS MOUNTING......................................................................................................................................................... 154
** BG 005 039 86 NSS LIGHT, WORK.............................................................................................................................................. 156

119D59445-1

BG 012 733 89 bG NSS
1 (157) MODULE, CABIN 190701
21 21
122 701 703 122
708 707 30 173 552

552 173 18
551 506 144 7
551 506 144 8

50 174 508 552
60 146 506 551
71 205 553
706 145 506 551
3 1 14 171 552
68 173 562
22 23 25 28 122
262 265 550 555

BG 012 733 89 bG NSS
190701 MODULE, CABIN 2 (157)
Ref. Part no. Description EN Standard designation Qty

e
1 551 613 90 CABIN SECTION 12 PAGE 6 1
7 550 394 34 PEDAL, THROTTLE SECTION 12 PAGE 33 1
8 551 996 57 NSS PEDAL, BRAKE SECTION 12 PAGE 36 1
14 550 128 97 HANDLE 2
18 552 086 25 NSS STEERING UNIT SECTION 12 PAGE 42 1
. . . . .
21 321 561 11 NSS GAUGE ASSEMBLY SECTION 12 PAGE 46 2
22 550 184 91 SUPPORTING BLOCK Equipment platform 1
25 551 804 73 NSS EQUIPMENT PLATFORM 1
30 551 720 49 BRACKET Alarm light 1
. . . . .
68 551 827 28 BRACKET JB102, cabin 1
71 550 126 96 BRACKET Light bracket 2
703 552 127 75 NSS MOUNTING SECTION 12 PAGE 147 1
706 BG 005 047 81 NSS LIGHT, WORK SECTION 12 PAGE 151 1
707 551 510 25 NSS MOUNTING SECTION 12 PAGE 154 1
. . . . .

BG 012 733 89 bG NSS
3 (157) MODULE, CABIN 190701
551 610
507 145 2 311 555 518 265
553 205 24
60
144
506 64 110 112 571
551
11
76 75
63 110 571
550 122 61
551 145 82 563 562 203 173 101 17
552 173 58 59
99 10 9 122 550 262 555
22 23 25
102 86
75
80
15
85
173
16 111
552 563 562 203 173 102

BG 012 733 89 bG NSS
190701 MODULE, CABIN 4 (157)

e
2 552 120 24 AIR CONDITIONER SECTION 12 PAGE 32 1
11 551 679 89 CABLE ENTRY PLATE 1
15 550 429 80 NSS BRACKET DRIVING PANEL 1
15.1 550 433 67 HANDLE 2
16 BG 005 221 62 GAUGE ASSEMBLY SECTION 12 PAGE 38 1
. . . . .
17 BG 005 235 91 GAUGE ASSEMBLY SECTION 12 PAGE 39 1
24 550 752 86 NSS MESH, SAFETY SECTION 12 PAGE 47 1
25 551 804 73 NSS EQUIPMENT PLATFORM 1
. . . . .
58 BG 004 925 17 NSS SEAT ASSEMBLY SECTION 12 PAGE 50 1
61 552 227 19 NSS HOSE SUPPORT ASSEMBLY SECTION 12 PAGE 54 1
63 819 174 99 SOCKET 1
75 618 112 59 COVER, HOSE 1
76 618 800 00 GUARD 4
. . . . .
80 550 456 39 NSS PROTECTOR, CABLE ENTRY 1
82 552 157 21 ENCLOSURE, DOCUMENTS SECTION 12 PAGE 55 1
85 550 546 01 PROTECTIVE HOSE 1
86 550 556 31 BRACKET Glass holder 1
101 552 056 29 NSS PANEL, CONTROL SECTION 12 PAGE 58 1
. . . . .
102 552 056 29 NSS PANEL, CONTROL SECTION 12 PAGE 58 1
111 551 523 44 SUPPORT, HOSE 1
150 803 152 39 HOSE 12/18 reinforced transparent hose 14
705 BG 004 855 58 NSS ALARM LIGHT, MOUNTING SECTION 12 PAGE 150 1
710 BG 005 039 86 NSS LIGHT, WORK SECTION 12 PAGE 156 1
. . . . .
799 551 683 73 NSS SCREW KIT SECTION 12 PAGE 5 1

551 683 73 f NSS
5 (157) SCREW KIT / CABIN ASSEMBLY 190701

e
81 801 450 49 HEXAGON HEAD TAPPING SCREW M4,8x19 4
83 550 130 58 WASHER, LOCK, DOUBLE M10 8
122 802 421 59 HEXAGON HEAD SCREW M6x16m8.8 10
144 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 10
. . . . .
145 800 916 09 HEXAGON HEAD SCREW M8x25 2
146 442 535 70 HEXAGON HEAD SCREW M8X30-8.8 2
171 800 432 79 HEXAGON HEAD SCREW M10X16 4
. . . . .
203 800 465 89 HEXAGON HEAD BOLT M12X25 - 8.8 2
262 800 196 59 HEXAGON HEAD SCREW M16X30 - 8.8 4
. . . . .
506 801 779 99 NUT, LOCK M8 8
508 284 773 10 NUT, LOCK M10 - 8, Zn 10
518 811 259 69 NUT, LOCK M16 - 8 4
. . . . .
552 851 282 09 WASHER, LOCK, DOUBLEC M10 23
561 550 160 42 WASHER, LOCK, DOUBLE M8 sp 4
. . . . .
850 446 805 60 SLOTTED PAN HEAD SCREW M4x10 - 5.8 3

551 613 90 a
190701 CABIN / CABIN 7 (FOPS/ROPS) 6 (157)

e
*1 551 888 92 FRAME, CABIN 1
*2 550 520 17 NSS WINDOW KIT SECTION 12 PAGE 7 1
*3 551 888 97 DOOR ASSEMBLY SECTION 12 PAGE 10 1
*4 551 888 98 DOOR ASSEMBLY SECTION 12 PAGE 12 1
*5 551 824 86 NSS WASHING EQUIPMENT KIT SECTION 12 PAGE 14 1
. . . . .
*6 551 712 60 NSS AIR CONDITIONING, CABIN SECTION 12 PAGE 21 1
*7 551 824 87 NSS INSULATION AND LINING SECTION 12 PAGE 24 1
*8 551 888 96 UPHOLSTERY KIT SECTION 12 PAGE 25 1
*9 551 888 94 NSS ELECTRICS KIT SECTION 12 PAGE 26 1
*10 551 888 93 SCREW KIT Rivet nut kit 1
. . . . .

550 520 17 cB NSS
7 (157) WINDOW KIT 190701
17
12 3 17
5 10
16
17
13 2 8
4
14
15
18
11
13
1 6
2
9 16
16
7
5
17

e
*1 550 148 84 WINDOW, FRONT 1
*2 550 148 85 WINDOW, FRONT 2
*3 550 520 26 WINDOW 1
*4 550 520 30 WINDOW 1
*5 550 520 45 WINDOW 2
. . . . .
*6 550 520 46 FRAME, WINDOW 1
*7 550 148 87 FRAME, WINDOW Outer frame, right 1
*8 550 148 88 FRAME, WINDOW Outer frame, left 1
*9 550 520 47 FRAME, WINDOW 1
*10 550 520 48 FRAME, WINDOW Outer frame door left 1
. . . . .
*11 550 520 49 FRAME, WINDOW 1
*12 550 520 50 FRAME, WINDOW 1
*13 886 218 39 SCREW M5x20 132
*14 550 520 69 SEAL BAND 4x8 L=20400 21
*15 550 520 71 SEAL MATERIAL 1
. . . . .
*16 551 540 18 FITTING PIECE for front and front side windows 6
*17 551 540 20 FITTING PIECE for door, side and rear windows 11
*18 550 520 69 SEAL BAND 4x8 L=20400 21

551 888 97 b
9 (157) DOOR ASSEMBLY / RIGHT 190701
24 15 11 15 24
13
12
24 14
24 14
15 16
25 27
8 9
30
10
4 21 29
3 19
22 28
23 5
2 1
26 17
7
25
6
15
20 18
5 23

551 888 97 b
190701 DOOR ASSEMBLY / RIGHT 10 (157)

e
1 BG 003 240 29 LOCK Cabin Door 1
2 550 982 29 SCREW, CR, C-SUNK, FLAT HEAD M6x25, A4 2
3 AF0 190 0055 NUT, HEXAGON, PREVAILING TORQUE M6 2
4 550 522 14 HANDLE Door handle left 1
5 550 982 10 SCREW, CR, PAN HEAD M6x20, A4 12
. . . . .
6 550 522 20 LEVER Left 1
7 550 522 24 BAR 1
8 550 522 28 PIN Lock pin 1
9 550 522 50 GUARD Pin guard 1
10 550 522 52 BOSS, THREADED 1
. . . . .
11 551 588 88 SPRING, GAS 300N, L=650mm, S=250mm 1
12 886 528 29 JOINT, BALL M8 1
13 886 859 69 BRACKET 1
14 AF0 010 0406 SCREW, HEXAGON HEAD, FULL THREAD M8x20 3
. . . . .
16 550 522 63 BUFFER, RUBBER 1
17 551 889 00 PLATE, COVER Door, right - Cabin 7 1
18 551 889 01 HANDLE Door, right - Cabin 7 1
19 551 825 96 SEAL L=4290 1
20 550 522 71 SEAL L=550 1
. . . . .
21 550 608 45 PLATE, COVER For lock of door 1
22 886 218 39 SCREW M5x20 2
23 551 769 24 WASHER M6 (A4) 12
24 551 825 10 WASHER M8, A4, black 5
25 551 825 11 WASHER M10, A4, black 3
. . . . .
26 551 825 21 HEXAGON HEAD SCREW M10X20, A4, black 2
27 551 825 16 HEXAGON SOCKET HEAD SCREW M10X25, A4, black 1
28 551 888 99 HANDLE 1
29 551 825 23 HEXAGON HEAD SCREW M12X25, A4 2
30 AF0 230 0032 WASHER, PLAIN, NORMAL M12-200 HV-A4 2
. . . . .
31 BG 006 960 80 PLATE, LOCKING For Hinge 1

551 888 98 b
11 (157) DOOR ASSEMBLY / LEFT 190701
24 15
15 24
11
13
12
14 24
15
16
25
27
9 8
30 10
19
29 21
3
4
28
22
5 23
1
17 2
26
7
25
6
15
18 20
23 5

551 888 98 b
190701 DOOR ASSEMBLY / LEFT 12 (157)

e
1 BG 003 240 31 LOCK Cabin Door 1
2 550 982 29 SCREW, CR, C-SUNK, FLAT HEAD M6x25, A4 2
4 550 522 15 HANDLE Door handle 1
5 550 982 10 SCREW, CR, PAN HEAD M6x20, A4 12
. . . . .
6 550 522 21 LEVER Right 1
7 550 522 24 BAR 1
8 550 522 28 PIN Lock pin 1
9 550 522 50 GUARD Pin guard 1
10 550 522 52 BOSS, THREADED 1
. . . . .
11 551 588 88 SPRING, GAS 300N, L=650mm, S=250mm 1
12 886 528 29 JOINT, BALL M8 1
13 886 859 69 BRACKET 1
. . . . .
16 550 522 63 BUFFER, RUBBER 1
17 551 889 02 PLATE, COVER Door, left - Cabin 7 1
18 551 889 03 HANDLE Door, left - Cabin 7 1
19 551 825 96 SEAL L=4290 1
20 550 522 71 SEAL L=550 1
. . . . .
21 550 996 34 PLATE, COVER cover for lock of door 1
22 886 218 39 SCREW M5x20 2
23 551 769 24 WASHER M6 (A4) 12
24 551 825 10 WASHER M8, A4, black 5
25 551 825 11 WASHER M10, A4, black 3
. . . . .
26 551 825 21 HEXAGON HEAD SCREW M10X20, A4, black 2
27 551 825 16 HEXAGON SOCKET HEAD SCREW M10X25, A4, black 1
28 551 888 99 HANDLE 1
29 551 825 23 HEXAGON HEAD SCREW M12X25, A4 2
30 AF0 230 0032 WASHER, PLAIN, NORMAL M12-200 HV-A4 2
. . . . .
31 BG 006 960 80 PLATE, LOCKING For Hinge 1

551 824 86 NSS
13 (157) WASHING EQUIPMENT KIT 190701
13
12
14
16
4
10
15
3
11
11
10
5 7
11 8
11 10
6
2 10 1

551 824 86 NSS
190701 WASHING EQUIPMENT KIT 14 (157)

e
*1 551 825 40 NSS WIPER SECTION 12 PAGE 15 1
*5 550 608 43 NSS WASHING EQUIPMENT KIT SECTION 12 PAGE 20 1
. . . . .
*6 550 524 05 HOSE L=6500, Washing liquid hose windscreen 1
*7 550 524 06 HOSE Washing liquid hose, front side right, 1
L=7200
*8 550 524 07 HOSE Washing liquid hose, front side left, L=4700 1
*9 550 524 08 HOSE Washing liquid hose, rear window, L=5000 1
*10 550 524 13 SEAL, RUBBER Hose entry rubber 4
. . . . .
*11 550 524 15 VALVE, DIRECTIONAL 4
*12 551 825 45 EDGING PLATE Cabin, right 1
*13 551 825 46 EDGING PLATE Cabin, left 1
*14 551 825 47 EDGING PLATE Cabin, front 1
*15 550 982 18 HEXAGON HEAD SCREW M8X20, A4 14
. . . . .
*16 551 825 55 WASHER M8, A4 14

551 825 40 a NSS
15 (157) WIPER / WINDSCREEN 190701
4 2 8 9 1
3 7
1

e
*1 551 739 14 MOTOR, WIPER Cabin S, Wiper motor for front and rear 1
screen
*2 551 825 95 BRACKET, MOUNTING Wiper, front and rear window 1
*3 551 825 88 HEXAGON SOCKET COUNTERSUNK HEAD M8X40, A4 1
SCREW (FULL THREAD
*4 550 148 30 ARM Double arm L=700 1
*5 BG 002 026 41 BLADE, WIPER L=700, neoprene 1
. . . . .
*6 881 639 49 NOZZLE 1
SCREW (FULL THREAD
*8 551 825 93 WASHER M10, A4 2
*9 551 825 87 NUT, LOCK M10 2

551 825 42 NSS
190701 WIPER / FRONT SIDE WINDOW RIGHT 16 (157)
1 7
1 6
4 3 5

e
*1 551 741 96 MOTOR, WIPER Cabin S, Wiper motor for side screen, 1
RIGHT
*2 551 825 94 BRACKET, MOUNTING Wiper, front side window 1
*4 551 825 92 WASHER M6, A4 2
SCREW (FULL THREAD
. . . . .
*6 550 524 64 ARM, WIPER Cabin S, Front side right 1
*7 550 148 33 BLADE, WIPER Headlight 1
*8 881 645 49 NOZZLE 1

551 825 43 NSS
17 (157) WIPER / FRONT SIDE WINDOW LEFT 190701
3 4
2 1

e
*1 551 739 12 MOTOR, WIPER Cabin S, Wiper motor for side screen, LEFT 1
*2 551 825 94 BRACKET, MOUNTING Wiper, front side window 1
*4 551 825 92 WASHER M6, A4 2
SCREW (FULL THREAD
. . . . .
*6 550 524 65 ARM, WIPER Cabin S, Front side left 1
*7 550 148 33 BLADE, WIPER Headlight 1
*8 881 645 49 NOZZLE 1

551 825 44 a NSS
190701 WIPER / REAR WINDOW 18 (157)
1 7
2 1

e
*1 551 739 14 MOTOR, WIPER Cabin S, Wiper motor for front and rear 1
screen
*2 551 825 95 BRACKET, MOUNTING Wiper, front and rear window 1
SCREW (FULL THREAD
*4 852 791 39 DOUBLE ARM Double arm L=600 1
*5 BG 002 026 41 BLADE, WIPER L=700, neoprene 1
. . . . .
*6 881 639 49 NOZZLE 1
SCREW (FULL THREAD
*8 551 825 93 WASHER M10, A4 2
*9 551 825 87 NUT, LOCK M10 1

550 608 43 a NSS
19 (157) WASHING EQUIPMENT KIT 190701
13
8 10 12
12 11
12 10
4
3
14
15 17 16
1
1
18 1
2 10 12

550 608 43 a NSS
190701 WASHING EQUIPMENT KIT 20 (157)

e
*1 550 608 50 RESERVOIR Washing liquid receiver 1
*2 550 608 55 FIXING CLIP 1
*3 550 608 56 PLATE, MOUNTING 1
*4 550 608 57 PIPE, FILLING 1
*5 550 608 54 PIPE, FILLING 1
. . . . .
*6 550 608 51 PUMP UNIT 2
*7 550 608 53 CABLE ENTRY PLATE 2
*8 550 608 52 CAP, FILLING 1
*9 550 608 60 CLAMP, HOSE 58-75 1
*10 443 203 10 HEXAGON HEAD SCREW M10X20 , A4 1
. . . . .
*11 411 763 00 NUT, HEXAGON M10, A4 1
*12 551 825 93 WASHER M10, A4 8
*13 447 094 00 SLOTTED SCREW M5X10 - 5.8 6
*14 550 608 61 CLAMP 44-56 1
*15 551 825 84 PLATE, COVER Pump unit 1
. . . . .
*17 551 825 92 WASHER M6, A4 3
*18 551 825 85 SEAL L=260 1

551 712 60 a NSS
21 (157) AIR CONDITIONING, CABIN / CABIN - STEEL, WITHOUT A/C-UNIT 190701
8
4 17 2 3
10
15
10
16
5 1
7
13 12
14
19
18
16 6 11

e
*1 550 517 38 FILTER UNIT SECTION 12 PAGE 22 1
*2 AF0 230 0030 WASHER, PLAIN, NORMAL M8 4
*3 AF0 010 0406 SCREW, HEXAGON HEAD, FULL THREAD M8x20 8
*5 550 523 48 SEAL L=1200 1
*7 550 523 75 CLAMP, HOSE 15-24 1
. . . . .
*8 550 523 78 HOSE Front, Ø65 L=2000 1
*9 550 523 79 HOSE Back, Ø65 L=800 1
*10 550 134 68 CLAMP D=58-75 4
*11 550 148 65 PIPE, LUBRICANT Air channel 1
*12 881 616 49 AIRNOZZLE 5
. . . . .
*14 550 523 50 NOZZLE Heating nozzle 1
*15 552 090 31 PLATE, COVER A/C 1
*16 550 523 55 SCREW, CR, PAN HEAD M8x20-8.8, Black 8
*18 552 090 36 PLATE, COVER A/C bottom 1

550 517 38
190701 FILTER UNIT 22 (157)
2
3
4
5

e
*1 550 519 72 FRAME 1
*2 550 519 73 ELEMENT, FILTER 2
*4 550 519 75 SEPARATOR, COARSE 1
*5 550 519 76 COVER 1
. . . . .

551 824 87 NSS
23 (157) INSULATION AND LINING / CABIN 190701
13
12
10
25
7 11
9 20
17
8 18
1
16
23
15 3 14
19 2 5 24 21 22

551 824 87 NSS
190701 INSULATION AND LINING / CABIN 24 (157)

e
*1 551 657 68 CARPET Heavy Carpet, rear floor 1
*2 551 824 92 CARPET Heavy Carpet, middle floor 1
*3 551 824 93 CARPET Heavycarpet, front floor 1
*4 551 647 43 CARPET Carpet, rear floor 1
*5 551 824 94 CARPET Carpet, middle floor 1
. . . . .
*6 551 824 95 CARPET Carpet, middle floor 1
*7 551 657 80 UPHOLSTERY MATERIAL Upholstery plate, back wall, cabin 1
*8 551 657 82 UPHOLSTERY MATERIAL Upholstery plate, side wall R 1
*9 551 657 83 UPHOLSTERY MATERIAL Upholstery plate, side wall L 1
*10 551 657 86 UPHOLSTERY MATERIAL Upholstery material, back wall 1
. . . . .
*11 551 657 88 CARPET Heavy carpet, conditioning, lower 1
*12 551 657 90 UPHOLSTERY MATERIAL Upholstery plate, roof, front 1
*13 551 824 97 UPHOLSTERY MATERIAL Upholstery plate, roof, back 1
*14 551 824 98 CARPET Heavy carpet, fore 1
*15 551 658 05 CARPET Heavy carpet, front side R 1
. . . . .
*16 551 658 06 CARPET Heavy carpet, font side, L 1
*17 551 824 99 UPHOLSTERY MATERIAL Upholstery plate, fore 1
*18 551 658 12 UPHOLSTERY MATERIAL Upholstery plate, front 2
*19 551 825 00 UPHOLSTERY MATERIAL Upholstery plate, door R 1
*20 551 825 01 UPHOLSTERY MATERIAL Upholstery plate, door L 1
. . . . .
*21 551 658 19 UPHOLSTERY MATERIAL Upholstery plate, trap door 1
*22 551 825 02 UPHOLSTERY MATERIAL Upholstery plate, front recess 1
*23 551 658 22 UPHOLSTERY MATERIAL Upholstery plate, back recess 2
*24 551 825 03 UPHOLSTERY MATERIAL Upholstery plate, back recess 1
*25 551 658 24 CARPET Heavy carpet, conditioning channel 1
. . . . .

551 888 96 a
25 (157) UPHOLSTERY KIT / CABIN 190701
1
2
18
20
23

e
*1 550 608 62 PANEL, CEILING REAR 1
*2 550 608 63 PANEL, CEILING FRONT 1
*18 550 608 66 COVER, REAR 1
*20 550 608 65 CUP, BASE PLATE 2
*23 550 608 64 HOUSING 1
. . . . .
*33 BG 008 938 05 SEAL Cabin, L=1250 1
*34 BG 008 938 06 SEAL Cabin, L=1500 2

551 888 94 a NSS
190701 ELECTRICS KIT / CABIN 26 (157)
13
12
11 15
14
29
27 26
28
30 2
1

e
1 551 888 95 CABLE ENTRY PLATE Front part 1
2 550 104 98 CABLE ENTRY PLATE Front part 1
6 330 075 18 COVER Instrument panel 1
7 550 608 67 PANEL, INSTRUMENT 1
11 856 273 79 LIGHT 1
. . . . .
12 551 749 25 BULB 10 W Cabin S, Ceiling light 2
13 551 749 26 BULB 5W Cabin S, Ceiling light 1
14 551 749 30 LIGHT max 10W 'Spotlight', Cabin S 2
15 551 749 09 BULB 'Spotlight' Cabin S 2
26 550 608 68 PANEL, INSTRUMENT SECTION 12 PAGE 27 1
. . . . .
28 550 608 70 CABLE SET SECTION 12 PAGE 28 1
29 550 613 58 ENCLOSURE SECTION 12 PAGE 30 1
30 550 617 71 TERMINAL BOX SECTION 12 PAGE 31 1

550 608 68
27 (157) PANEL, INSTRUMENT 190701
15 1
14
8 7 13 9 6 10 8
SW --
X1
K 500
128A
210
209
208
207
206
204
203
127
126
125
124
123
122
121
120
11 9
11 8
11 7
11 6
11 5
11 4
11 3
11 2
111
107
106
106
106
106
106
105
104
103
103
103
103
102
101
101
19
18
17
16
15
14
13
12
11
10
24
23
22
21
20
1
9
8
7
6
5
4
3
2
128K
4 5 3 11 2
12

e
2 881 308 09 RELAY 24V 1
3 803 123 39 CONTACT RAIL 1
4 869 144 09 RACK, CABLE 60x60 1
5 855 016 39 TERMINAL STRIP 1
6 816 240 59 SEPARATION PLATE - 1
. . . . .
8 816 241 89 CLAMP, END E/NS 35N 1
9 806 768 09 BRIDGE, SWITCHING 1
14 856 471 79 ACCESSORIES, TERMINAL 1
. . . . .

550 608 70
190701 CABLE SET 28 (157)
E11
A500
E12 E9
E15
E17
P424
E18
X421
E10
E16
JB424
JB23
JB26

550 613 58
29 (157) ENCLOSURE / CABIN, SWITCH AND INDICATOR LIGHT PANEL 190701
8
7
1 6 2 3 4
8
7
6
S500 S501 S502 S510
8
OPTION
7
S505 S503 S504 S5 11
8 5 6
7 OPTION OPTION OPTION

15
S507 SH506 S508 S512
6
14
OPTION OPTION OPTION OPTION

12
8
7
S524 S525 S520 S521 S522 S523
6 16
9 14
12
17
OPTION
12
10
13
12
11

550 613 58
190701 ENCLOSURE / CABIN, SWITCH AND INDICATOR LIGHT PANEL 30 (157)

e
1 550 056 91 LABEL, PANEL SW-panel 1
2 550 476 59 SWITCH, SELECTOR Stay/Stay/Return, NC + NO 1
3 550 475 53 SWITCH, SELECTOR Selector switch assy (complete) 1
4 550 614 50 HOUSING 1
5 550 476 62 PUSH BUTTON, ILLUMINATED with blue indicator light (complete) 1
. . . . .
6 888 111 39 PLUG 1
9 868 964 29 MOUNTING FRAME 1
11 856 750 09 SWITCH, ROCKER 1
12 867 078 99 BODY, SWITCH 1
13 880 672 89 LABEL, PANEL 1
. . . . .
14 872 670 19 SWITCH, ROCKER 1
15 855 967 59 LABEL, PANEL 1
16 882 383 59 LABEL, PANEL 1

550 617 71
31 (157) TERMINAL BOX / JB26, JB23, JB424 190701
8
13
JB26 5
JB23--X1 JB424--X1
X1 12
2 10
101
101
10
106
205
205
206
207
205
201
201
202
202
203
204
205
205
205
205
1
1
2
2
3
1 2 3
4
5
13
3 4 6 5 11 12
6
9
7
13

e
4 816 241 89 CLAMP, END E/NS 35N 1
5 806 768 09 BRIDGE, SWITCHING 1
. . . . .
7 885 567 29 GLAND, CABLE, SHIELDED 1
9 817 862 09 TERMINAL, EARTHING 1

552 120 24
190701 AIR CONDITIONER 32 (157)
21 20 21 20
22
22
1.1 1
13
18
19
12 15
4
8 15
6
22.2
22.1

e
1 550 131 38 FAN 24 V 1
1.1 080 000 52 RESISTOR 1
4 550 131 51 CELL Vaporizer cell 1
5 550 131 53 FILTER 1
6 885 919 49 VALVE 1
. . . . .
8 857 030 09 THERMOSTAT 1
12 883 379 19 SWITCH 1
15 550 131 89 KNOB 2
18 BG 004 074 53 HOUSING AC unit 1
19 BG 004 074 57 COVER AC unit 1
. . . . .
20 550 131 70 NOZZLE 3
21 881 724 29 AIR HOSE FITTING D=63mm 2
22 BG 004 074 58 HOUSING ASSEMBLY Housing + Cover 1
22.1 BG 004 074 60 HOUSING For control panel 1
22.2 BG 004 074 76 PANEL For control panel 1
. . . . .
25 BG 004 578 27 HARNESS, WIRING AC unit 1

550 394 34 aA
33 (157) PEDAL, THROTTLE 190701
29
19
21 13 7 18
1 REPAIR KIT (INCL. PARTS 19, 21)
2 AXLES SET (INCL. PART 18)
3 SENSOR ASSEMBLY (INCL. PARTS 6, 7 ,13, 29)

e
1 550 613 74 WHEEL Repair kit (incl. parts 19,21) 1
2 550 613 86 AXLES SET Treadle pin kit (incl. parts 18) 1
3 550 613 87 SENSOR ASSEMBLY Sensor kit (incl. parts 6,7,13,29) 1

551 996 57 fF NSS
35 (157) PEDAL, BRAKE / BRAKE PEDAL VALVE 190701
2 5
6
2 5 6
6 6
6
2
16 9
15
3 11
6
18
2
17
9
6 2 16 10
18
11 10 15
17
MF2
F2
F1
T MF1
A1
LS
A2
P
B3
8
S MS MA

551 996 57 fF NSS
190701 PEDAL, BRAKE / BRAKE PEDAL VALVE 36 (157)

e
1 551 972 08 VALVE, BRAKE SECTION 12 PAGE 37 1
2 550 404 93 STRAIGHT THREAD ADAPTER M14x1,5 / JIC 3/4-16 5
3 866 769 99 STRAIGHT THREAD ADAPTER JIC 9/16-18 1
4 817 180 79 ELBOW, SWIVEL NUT 9/16-18JIC 1
. . . . .
6 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 7
9 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
10 817 165 99 REDUCER, TUBE END 3/4X7/16JIC 2
11 818 001 09 NUT JIC 3/4-16 2
. . . . .
15 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
17 853 780 09 REDUCER, TUBE END 9/16JIC, 3/4X 2
18 818 001 09 NUT JIC 3/4-16 2

551 972 08 bA
37 (157) VALVE, BRAKE 190701
7430
7400
7575

e
7400 550 698 92 REPAIR KIT Mechanical repair kit 1
7430 550 698 90 COVER, RUBBER 1
7575 551 974 18 COVER, RUBBER Cover rubber for brake valve 1

BG 005 221 62 aA
190701 GAUGE ASSEMBLY / RIGHT 38 (157)
14 15
13 7 6 5
12

e
1 818 163 49 GAUGE, PRESSURE 0-250 bar 3
5 BG 004 046 61 DECAL Percussion pressure, right boom 1
6 BG 004 046 64 DECAL Feed pressure, right boom 1
7 BG 004 046 68 DECAL Rotation pressure, right boom 1
12 455 332 90 SCREW 2X5 6
. . . . .
13 552 195 91 PANEL, INSTRUMENT Right 1
14 868 731 69 CONNECTOR, PRESSURE GAUGE 1/4 3
15 865 765 79 HOSE ASSEMBLY, HYDRAULIC Measuring hose, 630bar, L=4.5 m, M16x2 3

BG 005 235 91 bA
39 (157) GAUGE ASSEMBLY / LEFT 190701
2 16 3 10 1
14 15 14 15
13 8 9 7 6 5
12 12

e
1 818 163 49 GAUGE, PRESSURE 0-250 bar 3
2 853 251 79 GAUGE, PRESSURE 25bar 1
5 BG 004 046 77 DECAL Percussion pressure, left boom 1
6 BG 004 046 78 DECAL Feed pressure left boom 1
7 BG 004 046 80 DECAL Rotation pressure, left boom 1
. . . . .
8 390 051 58 SIGN Water pressure 1
9 390 039 58 SIGN Hydr. oil temperature 1
10 BG 004 138 79 THERMOMETER -40/+80deg 1
12 455 332 90 SCREW 2X5 12
13 552 192 27 PANEL, INSTRUMENT 1
. . . . .
14 868 731 69 CONNECTOR, PRESSURE GAUGE 1/4 4
15 865 765 79 HOSE ASSEMBLY, HYDRAULIC Measuring hose, 630bar, L=4.5 m, M16x2 4
*3 857 398 69 SWITCH, ROCKER 1
*16 856 759 59 LABEL, PANEL S14 1

552 086 25 aA NSS
41 (157) STEERING UNIT / ASSEMBLY 190701
6 5
11
8 574 3 224 551 553
722 10
7 9
172 552
12
2

552 086 25 aA NSS
190701 STEERING UNIT / ASSEMBLY 42 (157)

e
1 550 461 26 SHIFTER, GEAR F-N-R Shifter 1
2 550 515 63 NSS ASSEMBLY SECTION 12 PAGE 43 1
3 552 086 66 HANDLE 1
4 552 086 14 PLATE, COVER 1
5 551 612 60 WHEEL, STEERING D=250 1
. . . . .
6 551 612 61 CENTER 1
7 551 644 14 ASSEMBLY SECTION 12 PAGE 44 1
8 551 988 77 FRAME Steering device 1
9 551 988 75 HOUSING 1
10 551 988 76 PLATE, COVER - 1
. . . . .
11 552 089 52 PLATE, COVER - 1
12 551 979 93 SCREW M4x12 3
224 804 380 79 HEXAGON HEAD BOLT M12X130 m8.8 1
511 412 113 00 NUT, LOCK M12 - 8, Zn 1
. . . . .
574 421 181 30 WASHER 10,5 1
722 551 705 89 SCREW Rounded countersunk head screw 8

550 515 63 dD NSS
43 (157) ASSEMBLY / CONTROL ARM+ORBITROL 190701
8 5
4 6 9 552 510 615 1

e
1 550 433 81 ARM, CONTROL 1
2 614 814 69 VALVE, STEERING 1
2.1 615 095 23 SEAL KIT FOR STEERING VALVE 1
4 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 2
5 263 331 58 ADAPTER R1/2 in - 3/4 in -16 JIC, L=80 2
. . . . .
6 851 975 79 STRAIGHT THREAD ELBOW 7/16-20 JIC 1
9 807 180 49 USIT-SEAL 22,7X30X2 D2=24,4 2
510 AF0 140 0006 NUT, HEXAGON M10 4
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 4
. . . . .
615 AF0 310 0170 STUD, DOUBLE END M10x25-8.8 Zn 4

551 644 14 bB
190701 ASSEMBLY / STEERING DEVICE, HORIZONTAL ADJUSTMENT 44 (157)
2
144 551
1
4
6 121 504
5 574
504 550 755

e
1 551 644 03 BRACKET, MOUNTING Welding assembly 1
2 551 644 10 BRACKET, MOUNTING Welding assembly 1
3 551 643 73 RAIL BEAM L=220 1
4 551 643 74 CARRIAGE 1
5 552 086 66 HANDLE 1
. . . . .
6 551 644 16 PLATE 1
. . . . .
574 AF0 230 0006 WASHER, PLAIN, NORMAL M10 1
755 AF0 050 0227 SCREW, SOCKET HEAD, HEXAGON M6x30 4

321 561 11 eE NSS
45 (157) GAUGE ASSEMBLY 190701
3
1
2 10

321 561 11 eE NSS
190701 GAUGE ASSEMBLY 46 (157)

e
1 883 656 09 GAUGE Tilt gauge 1
2 208 429 78 PLATE 1
3 265 125 18 COVER 1

550 752 86 cC NSS
47 (157) MESH, SAFETY / CABIN 190701
25
551
551
10 504

e
1 550 740 82 GRILL, SAFETY 1
2 265 556 88 WATER NOZZLE 1
3 550 107 92 CYLINDER, SPRING Gas spring 500N L=205/330mm 2
4 885 790 19 BUFFER, RUBBER M10, D=40, L=20 2
10 446 866 40 SLOTTED PAN HEAD SCREW M6X40 - 5.8 2
. . . . .
25 572 102 40 NIPPLE, GREASE AR 1/8 2
504 801 774 59 NUT, LOCK M6 2

BG 004 925 17 aA NSS
49 (157) SEAT ASSEMBLY 190701
6 575
2
2
551 142 774
552 510 174

BG 004 925 17 aA NSS
190701 SEAT ASSEMBLY 50 (157)

e
1 770 158 78 SEAT SECTION 12 PAGE 51 1
2 552 130 95 ADAPTER 2
3 550 009 87 PEDESTAL, SWING 1
4 BG 004 922 88 BRACKET SECTION 12 PAGE 52 1
5 551 661 10 SEAT BELT 75mm 1
. . . . .
6 BG 001 980 57 SCREW 7/16-20 UNF x 3/4" SAE GRADE 5 2
510 800 820 19 NUT, HEXAGON M10 m8 4
. . . . .
575 421 189 50 WASHER M13 2
774 868 485 39 HEXAGON SOCKET COUNTERSUNK HEAD M8x20 m8.8 DIN 4
SCREW (FULL THREAD

770 158 78 bB
51 (157) SEAT 190701

e
1 BG 006 216 71 HANDLE Rear movement system 1
2 BG 007 083 54 KNOB Weight adjustment kit 1

BG 004 922 88 aA
190701 BRACKET / SEAT 52 (157)
5 2
6
6
7
9
10 6

e
1 552 158 98 BRACKET 1
2 BG 004 922 92 PEDESTAL 1
4 552 138 02 PIN 2
5 818 056 99 PIN, LINCH Shaft D30, pin D6 2
6 550 192 99 CRIMP For 2 mm Wire Rope 8
. . . . .
7 550 074 52 WIRE ROPE 2mm, 7X19, A4 0.23
8 550 074 52 WIRE ROPE 2mm, 7X19, A4 0.32
9 550 074 52 WIRE ROPE 2mm, 7X19, A4 0.23
10 550 074 52 WIRE ROPE 2mm, 7X19, A4 0.32

552 227 19 aA NSS
53 (157) HOSE SUPPORT ASSEMBLY / HOSE SUPPORT ASSEMBLY 190701
4 3 2
2
3
4
1

552 227 19 aA NSS
190701 HOSE SUPPORT ASSEMBLY / HOSE SUPPORT ASSEMBLY 54 (157)

e
1 885 051 19 STRAP L=600 Black 1
2 140 467 88 FASTENER, RING 2
3 802 421 59 HEXAGON HEAD SCREW M6x16m8.8 2
4 421 165 20 WASHER 6,4 2

552 157 21 aA
55 (157) ENCLOSURE, DOCUMENTS 190701
172

e
1 551 988 71 HOUSING 1
2 552 157 24 PLATE, MOUNTING 1
3 551 898 64 LINCH PIN D=6mm L=40mm 1

552 056 29 bA NSS
57 (157) PANEL, CONTROL / THC561 190701
4 21 123
131 21 3
2 21 504
6 153 163 551
5 21 123
10 158 551
721 570
12
1
22
571
551 160 9
550 130 11 23

552 056 29 bA NSS
190701 PANEL, CONTROL / THC561 58 (157)

e
1 551 802 64 NSS CONTROL BOX ASSEMBLY SECTION 12 PAGE 61 1

552 056 29 bA NSS
59 (157) PANEL, CONTROL / THC561 190701
8 21 123
15
14
24 25
COMPONENT LOCATION VARIES

7 DEPENDING ON THE MACHINE TYPE.
50
51
52
53
54

552 056 29 bA NSS
190701 PANEL, CONTROL / THC561 60 (157)

e
7 551 686 62 NSS SYSTEM, CONTROL SECTION 12 PAGE 64 1
8 552 056 57 CONTROL ASSEMBLY SECTION 12 PAGE 98 1
700 552 186 94 PLATE, COVER 1
700.1 551 806 82 DECAL 1
801 551 890 56 NSS HOSING SET SECTION 5 PAGE 72 1
. . . . .
900 552 017 67 CONSOLE ASSEMBLY, OPERATOR'S SECTION 12 PAGE 122 1

551 802 64 eE NSS
61 (157) CONTROL BOX ASSEMBLY / THC561 STEEL PARTS, CABIN 190701
122 572
574 173
122 572

e
1 551 807 15 BRACKET 1
2 551 802 67 FRAME ASSEMBLY 1
. . . . .

551 686 62 bB NSS
63 (157) SYSTEM, CONTROL / THC561, BOTTOM, WITHOUT STABILIZER 190701
504 131 21 2
6 153 163 551

123 21 4
5 21 123
131 21 3
10 21 135
721 570 JB23
551 160 9
11 130 550
12 22 571
1
23

551 686 62 bB NSS
190701 SYSTEM, CONTROL / THC561, BOTTOM, WITHOUT STABILIZER 64 (157)

e
50 551 814 98 NSS VALVE ASSEMBLY SECTION 12 PAGE 68 1
51 550 570 69 NSS CONTROL BLOCK ASSEMBLY SECTION 12 PAGE 82 1
52 551 668 19 VALVE ASSEMBLY SECTION 12 PAGE 86 1
53 552 121 04 CONTROL VALVE ASSEMBLY SECTION 12 PAGE 92 1

551 686 62 bB NSS
65 (157) SYSTEM, CONTROL / THC561, BOTTOM, WITHOUT STABILIZER 190701
50
53 COMPONENT
LOCATION
VARIES DEPENDING
52 ON THE MACHINE
51 TYPE.
54
19 19
18 17 8 122 550
14 15
24 25

551 686 62 bB NSS
190701 SYSTEM, CONTROL / THC561, BOTTOM, WITHOUT STABILIZER 66 (157)

e
50 551 814 98 NSS VALVE ASSEMBLY SECTION 12 PAGE 68 1
51 550 570 69 NSS CONTROL BLOCK ASSEMBLY SECTION 12 PAGE 82 1

551 814 98 fF NSS
67 (157) VALVE ASSEMBLY / CONTROL BLOCK OF DRILLING, THC561 190701
20 19 13 15 1
23
21 22 18 14 16
11
31
11
12
17
10
13
12
16
14
30 30

551 814 98 fF NSS
190701 VALVE ASSEMBLY / CONTROL BLOCK OF DRILLING, THC561 68 (157)

e
10 816 711 99 ADAPTER, ELBOW G1/4 x JIC 9/16-18 1
11 816 718 89 ADAPTER, TEE 1,5/16-12 JIC 2
12 816 725 09 CONNECTOR, PRESSURE GAUGE 1,5/16-12 JIC 2
13 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
. . . . .
16 818 001 09 NUT JIC 3/4-16 2
19 816 763 99 ADAPTER, TEE JIC 7/8-14 1
. . . . .
20 817 167 49 REDUCER, TUBE END 7/8x3/4JIC 1
22 816 740 99 NUT 7/8-14JIC 1
30 817 096 19 PLUG 7/16-20 JIC 2
. . . . .
31 857 302 19 PLUG 9/16-18 JIC 1

551 752 40 mG
34 2 10 7
4
8
12 15
18
42
20
53
52
1 16
37
33
6 9
44
35
13 14 19 5 11
9 15 42 5 12
17
X7
20 13
18
4 2
16 10 34
6 33 8 11
1 17 44 37 35 14 19

551 752 40 mG

e
2 BG 007 642 46 VALVE, PRESSURE RELIEF SECTION 12 PAGE 73 1
4 881 108 59 VALVE, PRESSURE RELIEF 1
4.1 882 534 99 SEAL KIT 1
5 885 584 69 VALVE, PRESSURE RELIEF MAX. 350bar, 30l/min 1
5.1 881 449 09 SEAL KIT 1
. . . . .
6 208 203 38 ORIFICE 1
7 551 755 49 CARTRIDGE 400bar on/off valve cartridge + plug 1
7.1 551 872 93 PLUG Plug R 1 1/4" 1
7.2 551 872 92 SEAL KIT Incl. 3pcs o-rings, 1pc backup ring 1
8 551 813 08 VALVE, DIRECTIONAL 3/2, hydraulic piloted 14bar 1
. . . . .
8.1 882 880 09 SEAL KIT 1
9 550 131 98 PLUG CAVITY PLUG 1
10 885 867 09 VALVE, DIRECTIONAL 9.1 Bar 1
10.1 882 880 09 SEAL KIT 1
11 881 106 09 VALVE, PRESSURE REDUCING 1
. . . . .
11.1 882 533 69 SEAL KIT 1
12 881 105 79 VALVE, SHUTTLE 1
12.1 882 532 39 SEAL KIT 1
13.1 882 532 39 SEAL KIT 1
. . . . .
14.1 882 532 39 SEAL KIT 1
17 551 755 50 COVER Compensator cover 1
. . . . .
18 BG 007 534 33 VALVE, PRESSURE RELIEF Pressure relief valve DB10P-01-C-N-500 1
19 BG 006 173 64 VALVE, PRESSURE REDUCING Pilot operated reducing valve, Qmax=80 l/ 1
min
20 881 291 79 VALVE, DIRECTIONAL 5 bar 1
20.1 882 880 09 SEAL KIT 1
21 AF1 014 0017 ADAPTER, MALE STUD CONNECTOR JIC 3/4 - BSPP 3/4 1
. . . . .
22 AF1 014 0033 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 1/4 3
25 AF1 015 0015 ADAPTER, MALE STUD ELBOW JIC 7/8 - BSPP 1/2 1
26 AF1 143 0005 ADAPTER, TEST POINT WITH THREADED G 1/4 9
CONNECTION M 16X
. . . . .
29 263 331 58 ADAPTER R1/2 in - 3/4 in -16 JIC, L=80 1
30 AF0 010 0438 SCREW, HEXAGON HEAD, PARTIAL M8x80 3
THREAD
. . . . .
33.1 882 534 99 SEAL KIT 1
34 551 813 08 VALVE, DIRECTIONAL 3/2, hydraulic piloted 14bar 1
34.1 882 880 09 SEAL KIT 1
35.1 882 532 39 SEAL KIT 1
. . . . .
37 344 380 38 ORIFICE M6X10 1
44 551 665 24 VALVE, PRESSURE COMPENSATOR pressure compensator cartridge 1
44.1 551 872 92 SEAL KIT Incl. 3pcs o-rings, 1pc backup ring 1

551 752 40 mG
26 37 9 5
33 30 31
27
35
26
13 54 6 14 19 17 44 26 11
34 2 10 59 60 7 42 15 26
12
25
26
29
20 16
26 4 18 8 23 26
27 27 27 27 27 21 24 22 27 27 27
26 27
27
27
27 27 26 22 58 22

551 752 40 mG

e
53 865 683 09 PLUG G1/8 40
54 AF1 172 0026 FITTING, BLANKING PLUG FOR PORTS BSPP 1/4 4
56 881 141 09 PLUG G3/4 in 3
57 881 142 29 PLUG G1 1
. . . . .
60 AF1 038 0003 ADAPTER, CAP JIC 7/16 1

BG 007 642 46 a
73 (157) VALVE, PRESSURE RELIEF / RATIO 1,5:1. 190701
2 (T)
40-120bar
4 (LS2) 3 (LS1)
1 (P)

e
1 BG 008 003 63 SEAL KIT - 1

551 819 30 b
75 (157) VALVE ASSEMBLY / PROP. FEED CONTROL VALVE 190701
22
23
21
24
25
24
3 1 23
26

e
1 887 363 89 VALVE SECTION SECTION 12 PAGE 78 1
2 882 200 79 PLATE, END 1
3 882 204 89 MECHANICAL ACTIVATING MODULE SECTION 12 PAGE 79 1
4 882 883 99 CONTROL BLOCK ASSEMBLY SECTION 12 PAGE 80 1
21 882 882 69 SPOOL INCL. PARTS 21-26 1
. . . . .

551 819 30 b
190701 VALVE ASSEMBLY / PROP. FEED CONTROL VALVE 76 (157)
6
7
210 bar
175 bar

e
1 887 363 89 VALVE SECTION SECTION 12 PAGE 78 1
5 551 823 22 VALVE, PRESSURE RELIEF Shock-/anti-cavitation valve, 175bar 1
6 882 191 59 O-RING 16,0X1,5 2
7 887 366 69 VALVE, SHOCK LOAD 1

551 819 30 b
77 (157) VALVE ASSEMBLY / PROP. FEED CONTROL VALVE 190701
11
12
13
14
15
16
16
14
13 14
17 14
50

e
50 882 193 09 ASSEMBLY KIT INCL. PARTS 11-17 1
51 882 202 29 SEAL KIT 1

887 363 89 a
190701 VALVE SECTION 78 (157)
NO ILLUSTRATION AVAILABLE

e
*4 887 365 39 VALVE, SHOCK LOAD 1
*5 882 191 59 O-RING 16,0X1,5 2
*6 887 366 69 VALVE, SHOCK LOAD 1

882 204 89 B
79 (157) MECHANICAL ACTIVATING MODULE 190701
4
5
6
2
1
9
3
10
11

e
*50 882 205 09 SEAL KIT 1

882 883 99
190701 CONTROL BLOCK ASSEMBLY 80 (157)
24
35
33
PVH
22
32

e
882 205 09 SEAL KIT

550 570 69 cC NSS
81 (157) CONTROL BLOCK ASSEMBLY / RETURN AUTOMATIC CONTROL BLOCK 190701
3 1 4

550 570 69 cC NSS
190701 CONTROL BLOCK ASSEMBLY / RETURN AUTOMATIC CONTROL BLOCK 82 (157)

e
1 888 012 39 CONTROL BLOCK ASSEMBLY SECTION 12 PAGE 83 1
CONNECTION M 16X
5 812 553 99 VALVE, SHUTTLE R1/4 INC 1
. . . . .
6 AF1 035 0005 ADAPTER, SWIVEL MALE STUD JIC 9/16 - BSPP 1/4 1

888 012 39 b
83 (157) CONTROL BLOCK ASSEMBLY 190701
16
12 13
14
16 14 13 14
16
12

e
*12 888 014 99 VALVE, PRESSURE REDUCING 1
*12.1 888 017 79 SEAL KIT 1
*13 888 015 19 VALVE, CHECK - 2
*14 888 011 09 VALVE, PRESSURE RELIEF - 2
*14.1 888 019 29 SEAL KIT SK10-2 1
. . . . .
*16 888 013 69 SWITCH, PRESSURE - 2
*16.1 814 036 39 O-RING 9,0x1,5 80SHORE A 2

551 668 19 dC
85 (157) VALVE ASSEMBLY / ANTI-JAMMING / RETURN AUTOMATICS 190701
10
14
15
13 9 11 12
18
7
16
19
21
17 2 1 20

551 668 19 dC
190701 VALVE ASSEMBLY / ANTI-JAMMING / RETURN AUTOMATICS 86 (157)

e
2 864 257 79 VALVE, DIRECTIONAL SECTION 12 PAGE 89 1
3 881 107 29 VALVE, DIRECTIONAL 1
3.1 882 532 39 SEAL KIT 1
3.2 882 535 19 COIL 1
. . . . .
4.1 882 532 39 SEAL KIT 1
4.2 882 535 19 COIL 1
5.1 882 532 39 SEAL KIT 1
5.2 882 535 19 COIL 1
. . . . .
6.1 882 532 39 SEAL KIT 1
7.1 882 532 39 SEAL KIT 1
. . . . .
8.1 882 532 39 SEAL KIT 1
9.1 882 532 39 SEAL KIT 1
10.1 882 532 39 SEAL KIT 1
. . . . .
11.1 882 532 39 SEAL KIT 1
12 344 380 38 ORIFICE M6X10 1
13.1 882 532 39 SEAL KIT 1
. . . . .
14.1 882 880 09 SEAL KIT 1
15 871 692 89 PLUG G1/4 1
16 865 683 09 PLUG G1/8 27
17 853 323 29 HEXAGON SOCKET HEAD SCREW M5X30 m12.9 4
. . . . .
18 816 885 99 FITTING, QUICK CONNECT 2
21 856 040 09 STRAIGHT THREAD ADAPTER G 3/8 in x JIC 9/16-18 1

551 668 19 dC
87 (157) VALVE ASSEMBLY / ANTI-JAMMING / RETURN AUTOMATICS 190701
14
10
8
12 7 13
5
9 11
4
2
3

551 668 19 dC
190701 VALVE ASSEMBLY / ANTI-JAMMING / RETURN AUTOMATICS 88 (157)

e
3.1 882 532 39 SEAL KIT 1
3.2 882 535 19 COIL 1
. . . . .
4.1 882 532 39 SEAL KIT 1
4.2 882 535 19 COIL 1
5.1 882 532 39 SEAL KIT 1
5.2 882 535 19 COIL 1
. . . . .
6.1 882 532 39 SEAL KIT 1
7.1 882 532 39 SEAL KIT 1
. . . . .
8.1 882 532 39 SEAL KIT 1
9.1 882 532 39 SEAL KIT 1
10.1 882 532 39 SEAL KIT 1
. . . . .
11.1 882 532 39 SEAL KIT 1
12 344 380 38 ORIFICE M6X10 1
13.1 882 532 39 SEAL KIT 1
. . . . .
14.1 882 880 09 SEAL KIT 1

864 257 79
89 (157) VALVE, DIRECTIONAL 190701
1.3 1.2
1.1

e
*1 883 000 29 SEAL KIT 1
*1.1 O-RING 4
*1.2 O-RING 1
*1.3 O-RING 2

552 121 04 eE
91 (157) CONTROL VALVE ASSEMBLY / ROTATION CONTROL VALVE ASSEMBLY 190701
30
23
2
11
13
12
23
14
32
25
10
23 27 26 15 18

552 121 04 eE
190701 CONTROL VALVE ASSEMBLY / ROTATION CONTROL VALVE ASSEMBLY 92 (157)

e
10 AF1 014 0032 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 3/4 2
CONNECTION M 16X
. . . . .
12 AF1 144 0003 ADAPTER, SWIVEL NUT BRANCH TEE JIC 9/16 1
13 AF1 174 0003 ADAPTER, TEST POINT CONNECTOR JIC 9/16 - BSPP 1/4 1
14 AF1 146 0004 ADAPTER, SWIVEL NUT ELBOW JIC 9/16 1
18 AF1 146 0009 ADAPTER, SWIVEL NUT ELBOW JIC 1 5/16 2
. . . . .
25 AF1 038 0003 ADAPTER, CAP JIC 7/16 2
26 AF1 035 0002 ADAPTER, SWIVEL MALE STUD JIC 7/16 - BSPP 1/4 1
27 808 226 99 VALVE, THROTTLE CHECK R1/4-R1/4 1
30 550 771 32 REDUCER, TUBE END JIC 1 1/16-12, JIC 1 5/16-12 2
. . . . .
32 AF1 147 0001 ADAPTER, SWIVEL NUT RUN TEE JIC 7/16 2

552 121 04 eE
93 (157) CONTROL VALVE ASSEMBLY / ROTATION CONTROL VALVE ASSEMBLY 190701
8 19
31
23
32
11
33

552 121 04 eE
190701 CONTROL VALVE ASSEMBLY / ROTATION CONTROL VALVE ASSEMBLY 94 (157)

e
3 AF1 040 0007 ADAPTER, NUT JIC 1 5/16 1
7 AF1 147 0008 ADAPTER, SWIVEL NUT RUN TEE JIC 1 5/16 1
CONNECTION M 16X
. . . . .
31 AF1 175 0002 ADAPTER, TEST POINT CONNECTOR JIC 1 5/16 - BSPP 1/4 1
33 505252 ADAPTER 1

550 485 56 dC
95 (157) VALVE, DIRECTIONAL / ROTATION CONTROL VALVE 190701
1 8 7 18
15
18
17
2
19
25 15 25 24 23
22 18
10
22 18 10 9
16 14 12 13 11

550 485 56 dC
190701 VALVE, DIRECTIONAL / ROTATION CONTROL VALVE 96 (157)

e
*3 550 497 59 REPAIR KIT Regulating kit 1
*4 550 497 72 SEAL KIT 1
*5 550 497 60 VALVE, PRESSURE RELIEF 1
*6 550 497 61 SEAL KIT 1
*7 550 497 64 VALVE, FLOW CONTROL Flow regulator 1
. . . . .
*8 550 497 65 SEAL KIT 2
*9 550 497 67 SEAL KIT 1
*12 550 497 70 CHECK VALVE ASSEMBLY Check valve kit 1
*13 550 497 71 COMPENSATOR, PRESSURE Pressure compensator kit 1
*25 550 497 69 FILTER 1
. . . . .
*90 550 497 73 REPAIR KIT Hydraulic operation kit 1

552 056 57 eF
97 (157) CONTROL ASSEMBLY / THC561 ELECTRICS 190701
1
2

552 056 57 eF
190701 CONTROL ASSEMBLY / THC561 ELECTRICS 98 (157)

e
1 552 056 53 CONTROL ASSEMBLY SECTION 12 PAGE 100 1
2 551 671 43 ELECTRIC COMPONENTS ASSEMBLY SECTION 12 PAGE 112 1
3 552 263 65 NSS ELECTRIC COMPONENTS ASSEMBLY SECTION 12 PAGE 118 1

552 056 53 nD
99 (157) CONTROL ASSEMBLY / JB102 + CABLES 190701

552 056 53 nD
190701 CONTROL ASSEMBLY / JB102 + CABLES 100 (157)

e
JB102 551 901 65 JUNCTION BOX ASSEMBLY SECTION 12 PAGE 110 1
S-CABLE 550 150 01 CABLE ASSEMBLY SECTION 6 PAGE 42 3
W115 551 672 63 CABLE ASSEMBLY SECTION 12 PAGE 106 1
. . . . .
WS80 887 291 29 CABLE, PRE-WIRED PLUG 24VDC, 5.0m PUR 1
WY127 879 369 39 CABLE, PRE-WIRED PLUG 24VDC, 5.0m PUR 1
. . . . .
WY460-461 551 639 64 CABLE, PRE-WIRED PLUG L1=0,2m, L2=5,0m, PUR 3x0.75mm2 1

552 056 53 nD

552 056 53 nD

e
. . . . .
. . . . .

552 056 53 nD

552 056 53 nD

e
. . . . .
. . . . .

550 554 81
105 (157) CABLE ASSEMBLY / 4-POLE FEMALE / 5M / PUR 5X1.5 190701
1 2 3 4 5

e
1 550 003 01 CONNECTOR 4-pole female + locking part 1
1.1 552 267 57 CONNECTOR Plug for sockets, 4-pole female, shrink boot 1
1.2 552 267 53 CONNECTOR ACCESSORIES LOCKING PART 1
2 550 148 83 CONNECTOR CONTACT Socket, Nickel 4
4 855 484 59 SHRINK WRAP d=20, 0.7 m 0.5
. . . . .
5 867 938 09 CABLE 5x1,5mm², 500V 5

551 672 63 cB
190701 CABLE ASSEMBLY / 5.0 M - PUR 24X1.5 / - (M) 106 (157)
3 2 1
4 5 11

e
1 550 554 43 CONNECTOR PLUG, CABLE 380V 16A 1
2 818 290 19 CONNECTOR, MULTIPOLE, FEMALE 380V 16A 1
4 550 038 19 GLAND, CABLE, METALLIC M25x1.5, 13-18mm 1
5 550 037 58 REDUCER M32x1.5 / M25x1.5 1
11 867 110 49 CABLE 24X1,5mm2 500V 5.2
. . . . .

551 672 61 bB
107 (157) CABLE ASSEMBLY / 5.0 M - PUR 18X1.5 / - (M) 190701
1 2 3
4 5 11

e
1 819 477 59 CONNECTOR, MULTIPOLE, FEMALE 380VAC 16A 1
2 550 078 77 CONNECTOR PLUG, CABLE M25 1
11 872 565 19 CABLE 18x1,5mm2 500V 5.2

551 901 65 sR
109 (157) JUNCTION BOX ASSEMBLY / JB102 190701
35,42
36,42
37,42
39,42
1,2,3,4 38,42
30,42 31,42 32,42 33,42 34,42
15
9 - 23
5,6,7

551 901 65 sR
190701 JUNCTION BOX ASSEMBLY / JB102 110 (157)

e
K127 888 152 09 RELAY 24VDC 1
K127 888 153 29 SOCKET, RELAY 1
K129 884 399 49 RELAY, TIME 0.1s...10h, 24-240V AC/DC 1
. . . . .
K71 888 152 09 RELAY 24VDC 1
K71 888 153 29 SOCKET, RELAY 1
K72 888 152 09 RELAY 24VDC 1
K73 888 152 09 RELAY 24VDC 1
. . . . .
K76 888 152 09 RELAY 24VDC 1
K77 550 879 19 RELAY 24VDC Double contact 1
. . . . .
1 551 666 28 ENCLOSURE, STAINLESS STEEL 360x230x120 + mounting plate 1
2 550 860 37 WASHER Washer d1=8.5, d2=21, s=3, Ms 4
3 550 860 31 WASHER Washer d1=17 d2=30 s=3, Ms, M16 4
. . . . .
5 850 546 59 RAIL, MOUNTING 0,1M 0.69
10 888 143 19 PLATE, END 1
12 551 612 77 TERMINAL STRIP ACCESSORY D-UTTB 2,5/4 Cover plate, gray 1
13 850 968 39 RECTIFIER DIODE 8
15 816 241 89 CLAMP, END E/NS 35N 4
. . . . .
15 BG 009 063 99 RAIL CLAMP DIN rail end piece, for DIN rail NS 35/7.5 4
22 BG 003 666 12 BRIDGING DEVICE Bridge, 10 pole 1
22 BG 003 960 77 BAR, JUMPER 2-5, Plug-in bridge 6
22 BG 004 881 68 BRIDGE, SWITCHING 3-5 Plug-in bridge 3
22 BG 004 881 71 BRIDGE, SWITCHING 5-5 Plug-in bridge 2
. . . . .
31 550 082 66 GLAND, CABLE, METALLIC M25x1,5, 11-20 mm 1
32 550 076 08 ENTRY, CABLE M25, 4x7mm² 1
33 550 076 08 ENTRY, CABLE M25, 4x7mm² 1
34 550 076 08 ENTRY, CABLE M25, 4x7mm² 1
. . . . .
35 550 076 08 ENTRY, CABLE M25, 4x7mm² 1
36 550 076 10 ENTRY, CABLE M25, 3x9mm² 1
37 550 076 08 ENTRY, CABLE M25, 4x7mm² 1
38 550 076 08 ENTRY, CABLE M25, 4x7mm² 1
39 550 024 04 PLUG, BLANKING, METALLIC M25x1.5 1
. . . . .
42 550 024 06 NUT, LOCKING, METAL M25 10
50 552 085 56 SWITCHING BRIDGE Jumper for bridging A2 or 11 -terminals 6

551 671 43 kJ
111 (157) ELECTRIC COMPONENTS ASSEMBLY / THC 561 AND JB93 190701
50 12 10 8 6 4 2
40
31 30 11 9 7 5 3 1
25 26 27 28 29
24 23 22 21 20

551 671 43 kJ
190701 ELECTRIC COMPONENTS ASSEMBLY / THC 561 AND JB93 112 (157)

e
1 551 650 52 SWITCH, SELECTOR Assembly stay/stay/return 1
2 550 471 82 BUTTON, EMERGENCY STOP Complete 1
3 551 649 82 SWITCH, SELECTOR Complete 1
4 550 475 51 LIGHT, SIGNAL Yellow pilot light assy (complete) 1
5 550 476 59 SWITCH, SELECTOR Stay/Stay/Return, NC + NO 1
. . . . .
6 550 486 19 SWITCH, SELECTOR Complete 1
7 811 694 79 PLUG, COVER Blanking plug, round style, black IP66 4
. . . . .
12 551 713 96 SWITCH, SELECTOR 4-pos., 60 deg, 2 contacts 1
20 421 155 10 WASHER 4,3 4
22 801 772 09 NUT, HEXAGON M4 - 8 4
23 818 288 29 CONNECTOR, MULTIPOLE, MALE 380V 16A 1
. . . . .
24 850 489 49 CASE, MULTIPOLAR CONNECTOR 380V 16A, Bottom part 1
25 421 155 10 WASHER 4,3 4
27 801 772 09 NUT, HEXAGON M4 - 8 4
28 850 485 39 CASE, MULTIPOLAR CONNECTOR bottom part 1
. . . . .
29 819 476 29 CONNECTOR, MULTIPOLE, MALE 16A 380VAC 1
30 551 652 51 ASSEMBLY SECTION 12 PAGE 114 1
40 106 148 51 JUNCTION BOX SECTION 12 PAGE 115 1
*31 551 656 76 DECAL Control system, main switches 1

551 652 51 dD
113 (157) ASSEMBLY / CONTROL PANEL, THC561 190701
571 4

551 652 51 dD
190701 ASSEMBLY / CONTROL PANEL, THC561 114 (157)

e
2 551 652 50 PLATE Control panel, THC561 1
3 551 656 76 DECAL Control system, main switches 1
4 886 174 59 SLOTTED RAISED HEAD WOOD SCREW M5X12 - 4.8 , Zn 6
571 AF0 250 0003 WASHER, PLAIN, LARGE M5-200 HV Zn 6

106 148 51 jB
115 (157) JUNCTION BOX / JB93 190701
11, 12
13
1
3, 4, 5
1
1
2
3
3
3
6,7,8,9,10
16
16
14, 15 17
20

e
3 850 546 59 RAIL, MOUNTING 0,1M 0.8
4 800 617 49 SLOTTED PAN HEAD SCREW M4X6 3
5 800 246 39 WASHER, STAR 4 IZ 2
6 850 547 89 STRIP, TERMINAL 6
7 850 595 79 TERMINAL STRIP ACCESSORY 1
. . . . .
8 850 549 39 CLAMP, END 3
9 806 768 09 BRIDGE, SWITCHING 0.5
13 550 038 02 NUT, LOCKING, METALLIC M20x1.5, H=3.0mm 1
14 550 038 16 GLAND, CABLE, METALLIC M16x1,5, 5-10mm 1
. . . . .
16 550 038 00 NUT, LOCKING, METALLIC M16x1.5, H=2.8mm 3
20 552 266 86 CABLE ASSEMBLY SECTION 12 PAGE 116 1

552 266 86
190701 CABLE ASSEMBLY / DT04 4P / 0,2M - PUR 5X1.5 / - 116 (157)
5
41, 2, 3

e
1 887 304 59 CONNECTOR 1
2 550 148 82 CONNECTOR CONTACT Pin, Nickel 4
4 855 484 59 SHRINK WRAP d=20, 0.7 m 0.5
5 867 938 09 CABLE 5x1,5mm², 500V 0.3

552 263 65 dD NSS
117 (157) ELECTRIC COMPONENTS ASSEMBLY / PRESSURE SWITCH ASSEMBLY 190701

552 263 65 dD NSS
190701 ELECTRIC COMPONENTS ASSEMBLY / PRESSURE SWITCH ASSEMBLY 118 (157)

e
Cable 552 266 87 CABLE ASSEMBLY SECTION 12 PAGE 119 3
S127 818 826 89 COLLAR, SLEEVE 1
S127 866 395 09 SWITCH, PRESSURE 2-20 bar 1
S127 885 564 49 GLAND, CABLE, SHIELDED 1
. . . . .
. . . . .

552 266 87 a
119 (157) CABLE ASSEMBLY / DT04 2P / 0,2M - PUR 2X1.5 190701
6,7,8
4

e
4 855 484 59 SHRINK WRAP d=20, 0.7 m 0.2
5 867 108 59 CABLE 2x1,5mm2 0.4
6 550 148 91 CONNECTOR 2-pole male 1
7 550 148 92 ACCESSORIES, CONNECTOR Locking part 1
8 886 820 99 CONNECTOR CONTACT Pin, Nickel 2
. . . . .

552 017 67 aA
121 (157) CONSOLE ASSEMBLY, OPERATOR'S / SAFETY CABIN 190701
4 21 123
131 21 3
2 21 504
6 153 163 551
5 21 123
10 158 551
721 570
12
1
22
571
551 160 9
550 130 11 23

552 017 67 aA
190701 CONSOLE ASSEMBLY, OPERATOR'S / SAFETY CABIN 122 (157)

e
2 551 752 05 NSS VALVE, PRESSURE RELIEF SECTION 12 PAGE 125 1
3 550 015 57 NSS ADAPTER ASSEMBLY SECTION 12 PAGE 126 1
4 551 663 36 NSS VALVE, DIRECTIONAL SECTION 12 PAGE 128 1
. . . . .
. . . . .
160 442 761 40 HEXAGON HEAD BOLT M8X80 2
163 802 488 09 HEXAGON HEAD BOLT M8x100 2

552 017 67 aA
123 (157) CONSOLE ASSEMBLY, OPERATOR'S / SAFETY CABIN 190701
8 21 123
15
14
24 25
COMPONENT LOCATION VARIES

7 DEPENDING ON THE MACHINE TYPE.
50
51
52
53
54

552 017 67 aA
190701 CONSOLE ASSEMBLY, OPERATOR'S / SAFETY CABIN 124 (157)

e
14 207 256 58 SIGN Type explanation, components 1
15 455 332 90 SCREW 2X5 4
24 551 934 67 PIN Limiter 1
25 551 934 70 PIN Limiter 1
. . . . .
135 810 913 49 HEXAGON HEAD BOLT M6X75 - 8.8 2

551 752 05 fF NSS
125 (157) VALVE, PRESSURE RELIEF / FEED PRESSURE CONTROL VALVE 190701
4 1
5
4 3

e
1 882 232 59 FRAME R1/2" 1
2 551 813 09 VALVE, PRESSURE RELIEF pilot operated 1
2.1 882 534 99 SEAL KIT 1
. . . . .
5 851 983 29 ADAPTER, TEE JIC 7/16-20 1
6 881 777 59 WHEEL, HAND 1
6.1 810 765 99 SCREW, RETAINER M6X8 3
6.2 813 719 89 O-RING 25X3,5 1

550 015 57 a NSS
190701 ADAPTER ASSEMBLY / OF ROTATION SPEED 126 (157)
11
1
7 10
9
3
5
1
8 3

e
1 325 499 78 BLOCK, CONNECTOR 1
2.1 882 534 99 SEAL KIT 1
3.1 882 532 39 SEAL KIT 1
. . . . .
4 881 777 59 WHEEL, HAND 1
4.2 813 719 89 O-RING 25X3,5 1
. . . . .
8 851 983 29 ADAPTER, TEE JIC 7/16-20 2
11 551 946 41 BUSHING L=13,9mm 1
. . . . .

551 663 36 bB NSS
127 (157) VALVE, DIRECTIONAL / ROTATION, PRESSURE, FEED 190701
1 7
15
2
14
11
12 2 13

551 663 36 bB NSS
190701 VALVE, DIRECTIONAL / ROTATION, PRESSURE, FEED 128 (157)

e
1.1 882 884 19 CAP, FILLING 3
1.2 882 885 49 SOLENOID 6
1.3 882 886 79 COVER, RUBBER 3
1.4 882 893 09 SEAL KIT 4
. . . . .
1.5 882 888 29 VALVE, STEERING 1
1.6 882 890 19 STEERING VALVE 1
. . . . .

551 663 36 bB NSS
129 (157) VALVE, DIRECTIONAL / ROTATION, PRESSURE, FEED 190701
10
2 6
2
10 8

551 663 36 bB NSS
190701 VALVE, DIRECTIONAL / ROTATION, PRESSURE, FEED 130 (157)

e
6 851 983 29 ADAPTER, TEE JIC 7/16-20 2
8 207 816 88 ADAPTER 2

551 670 62 NSS
131 (157) VALVE, DIRECTIONAL / FLUSHING AND RAPID MOVEMENT 190701
4 9 8
8
10
3
7
10
2

551 670 62 NSS
190701 VALVE, DIRECTIONAL / FLUSHING AND RAPID MOVEMENT 132 (157)

e
1.1 874 828 69 COVER, RUBBER 2
1.2 882 884 19 CAP, FILLING 2
1.3 882 893 09 SEAL KIT 2
. . . . .
1.5 882 895 59 STEERING VALVE 1
1.6 867 837 49 LEVER 2
2 812 553 99 VALVE, SHUTTLE R1/4 INC 2
. . . . .
5 851 983 29 ADAPTER, TEE JIC 7/16-20 1
6 816 719 09 ADAPTER, TEE 9/16-18 JIC 1
7 816 705 99 SWIVEL NUT MALE ADAPTER 1/4 in 2
. . . . .

551 684 97 hH NSS
133 (157) VALVE, DIRECTIONAL / BOOM CONTROL VALVE 190701
10 2
1
3
5
3 11
3 11
8 7
19
15 14 13 12

e
5 816 770 19 STRAIGHT THREAD ADAPTER G 1/2 in x JIC 1 1/16-12 1
. . . . .
11 865 488 99 SWIVEL NUT ELBOW 45 3/4-16 JIC 2
12 865 275 49 ADAPTER, TEE JIC 1,1/16-12 1
13 853 385 39 NUT JIC 1,1/16-12 1
. . . . .
14 851 977 29 REDUCER, TUBE END 1,1/16X7/16 JIC 1
15 817 096 19 PLUG 7/16-20 JIC 1
19 881 140 79 PLUG G1/2 1

551 684 24 bA
22
6
40
23 22 22
6
40
6
40
6
40

551 684 24 bA
190701 VALVE, DIRECTIONAL / BOOM CONTROL VALVE 136 (157)

e
*4 551 985 09 COVER, END SECTION 12 PAGE 139 1
*5 551 985 10 VALVE SECTION SECTION 12 PAGE 140 1
*40 882 591 69 LEVER SECTION 12 PAGE 142 4
*800 880 489 29 SEAL KIT Incl. parts 22-23 8
. . . . .

551 684 24 bA

551 684 24 bA
190701 VALVE, DIRECTIONAL / BOOM CONTROL VALVE 138 (157)

e
*4 551 985 09 COVER, END SECTION 12 PAGE 139 1
*40 882 591 69 LEVER SECTION 12 PAGE 142 4
*800 880 489 29 SEAL KIT Incl. parts 22-23 8
. . . . .

551 985 09 A
139 (157) COVER, END / INLET ELEMENT OF BOOM VALVE 190701
32

e
*32 879 105 19 LIMITER INCL. PARTS 20 1
*32.1 819 951 09 SEAL KIT For pressure valve 1

551 985 10 A
190701 VALVE SECTION / MIDDLE INLET ELEMENT OF BOOM VALVE 140 (157)

e
*5 817 806 59 VALVE, CARTRIDGE 1
*5.1 819 951 09 SEAL KIT For pressure valve 1

551 985 20 A
141 (157) VALVE SECTION / INCLUDING SPOOL COVER 190701
11 9
85
80

e
*9 550 656 55 COVER Piston centering kit 1
*11 551 985 30 VALVE, CHECK 1

882 591 69 d
190701 LEVER 142 (157)
2 1 3 4

e
*1 882 823 39 BELLOWS, RUBBER 1
*2 882 824 69 KNOB 1
*3 550 302 21 LEVER SPARE PART KIT OF SP08 CROSS 1
LEVER
*801 882 613 79 SEAL KIT Incl. parts 22, 23, 80 and 85 4
. . . . .

551 645 20 dD
143 (157) VALVE ASSEMBLY / HYDRAULIC ISOLATION VALVE 190701
2 3
8 7
10 11
17 16 18
15
9 11
8 7
5
17 16 13 12
2 3

551 645 20 dD
190701 VALVE ASSEMBLY / HYDRAULIC ISOLATION VALVE 144 (157)

e
2.1 882 532 39 SEAL KIT 1
2.2 552 086 65 COIL 1
3.1 550 411 56 COIL 24V, 33,6W 1
. . . . .
3.2 550 411 58 SEAL KIT 1
. . . . .
. . . . .
16 AF1 040 0006 ADAPTER, NUT JIC 1 1/16 2
17 AF1 150 0012 ADAPTER, TUBE END REDUCER FORM B JIC 3/4 - JIC 1 1/16 2
18 AF1 015 0018 ADAPTER, MALE STUD ELBOW JIC 1 1/16 - BSPP 3/4 1

551 752 11 cC
145 (157) CONTROL VALVE ASSEMBLY / FEED PRESSURE DEVIATION 190701
7 21
23
20 20
7
1
20 20
22 3
3 2

551 752 11 cC
190701 CONTROL VALVE ASSEMBLY / FEED PRESSURE DEVIATION 146 (157)

e
1 550 264 99 CONTROL VALVE BLOCK 1
2 551 796 62 VALVE, PRESSURE RELIEF pilot operated, 48bar/1turn 1
2.1 882 534 99 SEAL KIT 1
3.1 882 880 09 SEAL KIT 1
. . . . .
7 865 683 09 PLUG G1/8 5
8 881 777 59 WHEEL, HAND 1
8.2 813 719 89 O-RING 25X3,5 1
. . . . .

552 127 75 f NSS
147 (157) MOUNTING / POWER OUTLET 12V AND 24V 190701
850
105 41 107 108
106 42 108

e
41 885 298 09 DC/DC CONVERTER 20-32V DC/12VDC 12A 1
42 888 121 49 SOCKET 1
105 552 114 06 DECAL Decal for 24V outlet cabin 1
106 552 061 79 DECAL Decal for 12V outlet cabin 1
107 551 678 47 SOCKET Socket 24V 16A 1
. . . . .
108 888 122 79 CONNECTOR, PLUG Plug 6-50V, 16A 2
850 446 805 60 SLOTTED PAN HEAD SCREW M4x10 - 5.8 3

BG 004 855 58 aA NSS
149 (157) ALARM LIGHT, MOUNTING 190701
90 92 93
1 126 550 504

BG 004 855 58 aA NSS
190701 ALARM LIGHT, MOUNTING 150 (157)

e
1 550 293 55 GLAND, CABLE M12x1.5, IP68 1
90 BG 004 839 99 BEACON ASSEMBLY Blinking LED beacon and connector assy 1
92 560 148 97 ACCESSORIES, CONNECTOR Stainless steel mounting clip 1
93 560 148 97 ACCESSORIES, CONNECTOR Stainless steel mounting clip 1
. . . . .
504 801 774 59 NUT, LOCK M6 2

BG 005 047 81 aA NSS
151 (157) LIGHT, WORK / EXTRA WORKING LED LIGHTS, CABIN MODEL 190701
10 11 Optional extra light mounting
A B
C
174 508 552
C
2
174 205 3
508 553
552 1 11
DETAIL A DETAIL B
4 174 508 552
SECTION C - C
1 11

e
10 552 182 06 LIGHT, LED SECTION 10 PAGE 16 2
11 550 150 01 CABLE ASSEMBLY SECTION 6 PAGE 42 2

551 510 25 aA NSS
153 (157) MOUNTING / DOCUMENT BOX A4 ASSEMBLY, CABIN 190701
144 3
A3-BOX MOUNTING
A4-BOX MOUNTING
205 511 553

551 510 25 aA NSS
190701 MOUNTING / DOCUMENT BOX A4 ASSEMBLY, CABIN 154 (157)

e
3 551 001 61 ENCLOSURE, DOCUMENTS 1
144 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 4

BG 005 039 86 bB NSS
155 (157) LIGHT, WORK 190701
10
174 508 522
2
174 1
3
508 553
552 205
4 174 508 522

BG 005 039 86 bB NSS
190701 LIGHT, WORK 156 (157)

e
1 552 182 06 LIGHT, LED SECTION 10 PAGE 16 6
2 550 126 96 BRACKET Light bracket 2
3 551 607 24 BRACKET, LAMP N45 HID 4
. . . . .

Cabin Module - 12

Uploaded by

Copyright:

Available Formats

You might also like

Cabin Module - 12

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Cabin Module - 12

Uploaded by

Copyright:

Available Formats

12. CABIN MODULE

Sandvik Mining and Construction Oy Drills Tampere © 2019

**** 551 671 43 ELECTRIC COMPONENTS ASSEMBLY............................................................................................................. 112

Sandvik Mining and Construction Oy Drills Tampere © 2019

Sandvik Mining and Construction Oy Drills Tampere © 2019

708 707 30 173 552

551 506 144 7

551 506 144 8

706 145 506 551

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

506 64 110 112 571

551 145 82 563 562 203 173 101 17

99 10 9 122 550 262 555

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2019
