Applications

On-Road
OEM
Applications
Quick Reference Guide High Volume PARTS list Quick Reference Guide
Ford / Sterling
Red Dot Part No. Factory No. OEM No. ClimaTech No. International No. Alliance No. Volvo No. Mack No.
Accumulator 74R5095 RD-5-11546-0P 4C4H-19C808-AA / F6HZ-19C836A N/A N/A ABP N83 319309 RDHRD5115460P 4379-RD5115460
Blower Motor 73R3072 RD-5-11579-0P XC4H-19805-AA N/A N/A ABP N83 301020 RDHRD5115790P 4379-RD5115790
Blower Motor 73R3092 RD-5-11843-0P F1HZ-19805 N/A N/A ABP N83 301276 RDHRD5118430P 4379-RD5118430
Clutch 75R0452 RD-5-4967-0P D2AZ-2884-A, D4AZ-2884-A KA1410 N/A ABP N83 303252 RDHRD549670P, 176470 4379-RD549670
Clutch 75R1202 RD-5-4972-0P C7AZ-2884-B N/A N/A ABP N83 303082 RDHRD549720P, 3949292 4379-RD549720
Clutch 75R3002 RD-5-4984-0P C5TZ-2884-C, E5LZ-19D784-A KA1045 1676660-C91 ABP N83 303011 RDHRD549840P, V8889022 4379-RD549840
Clutch 75R3452 RD-5-4987-0P C5UZ-2884-A, C KA1035 1669746C91 ABP N83 303102 RDHRD549870P, 176330 4379-RD549870, IMX246
Clutch 75R4502 RD-5-4994-0P D2NN-19D649-A KA1090 N/A ABP N83 303012 RDHRD549940P, 176455 4379-RD549940
Clutch 75R4742 RD-5-10357-0P F20H-19D786-AA KA1655 N/A ABP N83 303717 RDHRD5103570P 4379-RD5103570
Compressor 75R84152 RD-5-10303-0P F4HT-19D629-CA N/A N/A ABP N83 304053 RDHRD5103030P, 85100868 4379-RD5103030
Condenser 77R6807 RD-4-5696-0P F6HT-19710-BA N/A N/A ABP N83 306880 RDHRD456960P 4379-RD456960
Switch 75R89334 RD-5-10888-0P D0HZ-19986-A N/A N/A ABP N83 304582 RDHRD5108880P 4379-RD5108880
Freightliner
Blower Motor 73R3002 RD-5-11466-0P BOA 85 440 50 009 HB1880 ZGG19230 ABP N83 301017, RDHRD5114660P, 4379-RD5114660
ABP N83 301317 176140
Blower Motor 73R3062 RD-5-11489-0P BOA 85 415 00 789 N/A N/A ABP N83 301317 RDHRD5114890P 4379-RD5114890
Blower Motor 73R3052 RD-5-11488-0P BOA 85 462 5000 900 N/A N/A ABP N83 301308, RDHRD5114880P 4379-RD5114880
ABP N83 301327
Clutch 75R0302 RD-5-4966-0P ABP N83 303051 KA1095 481800C91 ABP N83 303051 RDHRD549660P, 4379-RD549660,
3949313 1MX41281
Clutch 75R1202 RD-5-4972-0P ABP N83 303252 KA1040 1647566C91 ABP N83 303252 RDHRD549720P, 3949292 4379-RD549720
Clutch 75R3452 RD-5-4987-0P A22-22498-000 KA1090 481806C91 ABP N83 303102 RDHRD549870P, 4379-RD549870,
176330, 31160-7760 IMX246
Compressor 75R7280 RD-5-8637-0P CFC ET210L 25147R, 25149S LC2000 N/A ABP N83 304081 3949851 4379-RD586370
Compressor 75R7290 RD-5-8638-0P CFC ET210L 25150 LC2100 417888C91/167683C92 ABP N83 304031, 1119561, 3949850 4379-RD586380
ABP N83 304061
Compressor 75R81212 RD-5-11243-0P 4429 N/A N/A ABP N83 304803 RDHRD5112430P 4379-RD5112430
Compressor 75R81282 RD-5-11249-0P SKI4421 N/A N/A ABP N83 304793 RDHRD5112490P 4379-RD5112490
Compressor 75R81352 RD-5-11254-0P 22-48437-000 N/A 3541235C91 ABP N83 304893 RDHRD5112540P 4379-RD5112540
Compressor 75R81382 RD-5-11258-0P 22-59342-000 N/A N/A ABP N83 304833 RDHRD5112580P 4379-RD5112580
Compressor 75R81472 RD-5-11316-0P 22-41179-000/ 22-59344-000 N/A N/A ABP N83 304853 RDHRD5113160P 4379-RD5113160
Compressor 75R81512 RD-5-11328-0P 22-43374-000, F69-6001-215 N/A N/A ABP N83 304873 RDHRD5113280P 4379-RD5113280
Compressor 75R84152 RD-5-10303-0P 22-44462-000 N/A N/A ABP N83 304053 85100868 4379-RD5103030
Compressor 75R84232 RD-5-10267-0P SKI4776 N/A N/A ABP N83 304113 85100876 4379-RD5102670
Compressor 75R8432 RD-5-7522-0P SKI4626, F69-6001-153 LE1140 N/A ABP N83 304095 8022507 4379-RD575220
Compressor 75R8512 RD-5-5876-0P 488-25011 N/A N/A ABP N83 304019 RDHRD558760P 4379-RD558760
Expansion Valve 71R8301 RD-5-6868-1P S10 329 440 EA1065 1676649C1 ABP N83 308011 3916657 4379-RD568681
Expansion Valve N/A RD-5-10179-0P A22-45432-000 EA1365 ZGG19226 ABP N83 308211 3949281 4379-RD5101790
Expansion Valve 71R8370 RD-5-7567-0P BOA-80-321-00-169 EA1365 ZGG19226 ABP N83 308009, ABP N83 308211 3916182 4379-RD575670
Expansion Valve, Stat Seal 71R8451 RD-5-10903-0P ABP N83 308231 N/A N/A ABP N83 308231 RDHRD5109030P 4379-RD5109030
Expansion Valve, Stat Seal 71R8453 RD-5-12520-0P BOA-80-321-00-269 N/A N/A ABP N83 308241 RDHRD5125200P 4379-RD5125200
Expansion Valve, Stat Seal 71R8455 RD-5-12521-0P 327302, A4965 N/A N/A ABP N83 308107 RDHRD5125210P 4379-RD5125210
Expansion Valve, Stat Seal 71R8457 RD-5-12522-0P BOA-A93674 N/A N/A ABP N83 308117 RDHRD5125220P 4379-RD5125220
Filter 78R5430 RD-5-11836-0P 22-46891-000, VCC36000006 N/A N/A ABP N83 328375 RDHRD5118360P 4379-RD5118360
PAGE 80 PAGE 81
Freightliner
Pressure Switch(Binary) 71R7075 RD-5-8433-0P A22-43249-000 N/A N/A ABP N83 318229 RDHRD584330P 4379-RD584330
Receiver Drier 74R2608 RD-5-11192-0P 088193-00 N/A N/A ABP N83 319685 RDHRD5111920P 4379-RD5111920
Receiver Drier 74R3129 RD-5-11522-0P 088538-00 N/A ZGG712010 ABP N83 319584 RDHRD5115220 4379-RD5115220
Receiver Drier 74R3321 RD-5-10941-0P 088536-00 JA2020 ZGG19139 ABP N83 319624 3934718 4379-RD5109410
Receiver Drier 74R3327 RD-5-10944-0P 088397-01 JA1885 ZGG19138 ABP N83 319614 3949278 4379-RD5109440
Receiver Drier 74R3331 RD-5-11196-0P 088337-00 JA1740 ZGG19135 ABP N83 319735 RDHRD5111960P 4379-RD5111960
Receiver Drier 74R3377 RD-5-11186-0P 088343-00 JA2055 N/A ABP N83 319315 RDHRD5111860P 4379-RD5111860
Relay (Actuator) 71R3577 RD-5-11862-0P VCC32000022 ABP N83 301459 RDHRD5118620P 4379-RD5118620
International / Navistar
Blower Motor 73R0512 RD-5-5120-0P 2500485C1 / 3949261 HA1090 2500485C1 ABP N83 301421 3949261 4379-RD551200
Blower Motor 73R2102 RD-5-4937-0P 1669786C1 / 85100164 HA1090 1669786C1 /1699291C1 ABP N83 301025 85100164 4379-RD549370
Blower Motor 73R2232 RD-5-8805-0P 1699291C1 / 3093425 N/A 1699291C1 / 3093425 ABP N83 301781 RDHRD588050P 4379-RD588050
Clutch 75R0302 RD-5-4966-0P 481800C91 KA1095 481800C91 ABP N83 303051 3949313 4379-RD549660
Clutch 75R0612 RD-5-8009-0P 1687780C92 / 3949295 KA1480 1687780C92 ABP N83 303007 3949295 4379-RD580090
Clutch 75R1202 RD-5-4972-0P 1647566C91 / 3949292 KA1040 1647566C91 ABP N83 303252 3949292 4379-RD549720
Clutch 75R3452 RD-5-4987-0P A22-22498-000 / 31160-7760 KA1090 481806C91 ABP N83 303102 31160-7760 4379-RD549870
Compressor 75R7290 RD-5-8638-0P 200820C91 / 3949479/417888C91/167683C92 LC2100 200820C91 / 417888C91 / 167683C92 ABP N83 304031 1119561/3949479 4379-RD586380
Compressor 75R81452 RD-5-11313-0P 2003413C91 LE1150, F69-6002-243 2003413C91 ABP N83 304953 RDHRD5113130P 4379-RD5113130
Compressor 75R81472 RD-5-11316-0P 2032287C91 LE1135, F69-6001-253 2032287C91 ABP N83 304853 RDHRD5113160P 4379-RD5113160
Compressor 75R81502 RD-5-11326-0P 3579878C1 LE1085,K318-103, F69-6002-114 3579878C1 ABP N83 304973 RDHRD5113260P 4379-RD5113260
Compressor 75R81732 RD-5-11350-0P 3541235C91 3541235C91 ABP N83 304983 RDHRD5113500P 4379-RD5113500
Expansion Valve 71R8301 RD-5-6868-1P 1696846-C2 / 3916657 EA1065 1676649C2 ABP N83 308011 3916657 4379-RD568681
Expansion Valve 71R8310 RD-3-7822-0P 1696846-C3 EA1305 1696846-C3 RDH RD3 7822 0 N/A 4379-RD378220
Expansion Valve 71R8430 RD-5-8936-0P 1699955-C1 / 3949398 EA1310 1699955-C1 ABP N83 308141 3949398 4379-RD589360
Filter 78R5236 RD-5-10077-0P ZGG720002 N/A ZGG720002 ABP N83 328194 RDHRD5100770P 4379-RD5100770
Filter 78R5302 RD-5-10774-0P 481813C1 N/A 481813C1 ABP N83 328265 RDHRD5107740P 4379-RD5107740
Filter 78R5306 RD-5-10773-0P 498144C1, ZGG14263, ZGG720007 GD1020 498144C1 / ZGG14263 / ABP N83 328285 RDHRD5107730P 4379-RD5107730
ZGG720007
Filter 78R5308 RD-5-10775-0P 1699956C1 N/A 1699956C1 ABP N83 328295 RDHRD5107750P 4379-RD5107750
Receiver Drier 74R1706 RD-5-3593-1P 1676651C1 N/A 1676651C1 ABP N83 319010 RDHRD535931P 4379-RD535931
Receiver Drier 74R1756 RD-5-3593-0P 1676653C1 JA1085 1676653C1 ABP N83 319514 61510-001 4379-RD535930
Receiver Drier 74R3450 RD-5-4959-0P 1693117C1 / 3949280/454613-C1 JA1325, JA1960 1693117C1 ABP N83 319910 3949280 4379-RD549590
Kenworth
Blower Motor 73R0222 RD-5-8212-0P 203139BSM N/A N/A ABP N83 301461 RDHRD582120P 4379-RD582120
Blower Motor 73R0412 RD-5-10337-0P HB1610 HB1610 ZGG701019 ABP N83 301004 85101275 4379-RD5103370
Blower Motor 73R0612 RD-5-8922-0P 203142BSM HB1935 N/A ABP N83 301073 RDHRD589220P 4379-RD589220
Blower Motor 73R4182 RD-5-6801-0P 20578P HB1050 1691733C91, 1691704C91 ABP N83 301072 3949266 4379-RD568010
Clutch 75R0302 RD-5-4966-0P K332-62-2, 024 21942 KA1095 481800C91 ABP N83 303051 3949313 4379-RD549660, 1MX41281
Clutch 75R0452 RD-5-4967-0P KA1360 KA1360 165338C91 ABP N83 303252 176470 4379-RD549670
Clutch 75R1202 RD-5-4972-1P KA1040 KA1040 1647566C91 ABP N83 303252 3949292 4379-RD549721
Compressor 75R7280 RD-5-8637-0P ER210L-25149, LC1000, LC2000 LC2000 ZGG15701 ABP N83 304081 3949851 4379-RD586370
PAGE 82 PAGE 83
Kenworth
Compressor 75R7290 RD-5-8638-0P ER210L-25150, LC2100 LC2100 2502459C91, 417888C91 / ABP N83 304061 1119561, 3949850 4379-RD586380
167683C92
Compressor 75R81472 RD-5-11316-0P 4647, F69-6001-253 LE1135 2032287C91 ABP N83 304853 RDHRD5113160P 4379-RD5113160
Compressor 75R81482 RD-5-11322-0P 4660 ZGG705006 ABP N83 304344 RDHRD5113220P 4379-RD5113220
Compressor 75R81502 RD-5-11326-0P K318-103 LE1085, F69-6002-114 3579878C1 ABP N83 304973 RDHRD5113260P 4379-RD5113260
Compressor 75R81512 RD-5-11328-0P F69-6001-215 F69-6001-215 ZGG705009 ABP N83 304873 RDHRD5113280P 4379-RD5113280
Compressor 75R81562 RD-5-11334-0P F69-6002-214, 18-04291 F69-6002-214 N/A ABP N83 304394 RDHRD5113340P 4379-RD5113340
Compressor 75R81632 RD-5-12332-0P Sanden #4425, 4792 F69-6000, F69-6002-122 N/A ABP N83 304481 RDHRD5123320P 4379-RD5123320
for Cat 3406 engine
for Detroit S60 series engine
Compressor 75R8422 RD-5-7120-0P 4627, LE1145 LE1145 ZGG19296 ABP N83 304125 8164872 4379-RD575220
Compressor 75R8432 RD-5-7522-0P 4626, F69-6001-153 LE1140,F69-6001-153 ZGG19316 ABP N83 304095 8022507 4379-RD575220
Compressor 75R8432 RD-5-7522-0P F69-1002, F69-6002-133 F69-1002, F69-6002-133 ZGG19316 ABP N83 304095 RDHRD575220P 4379-RD575220
Compressor 75R84612 RD-5-10297-0P 4664 LE1035 ZGG19370 ABP N83 304363 3916160 4379-RD5102970, 206RD413M
Compressor 75R8742 RD-5-10495-0P F69-1000, 18-04154 F69-1000 ZGG705129 ABP N83 304659 RDHRD5104950P 4379-RD5104950
Expansion Valve 71R8301 RD-5-6868-1P EA1065 EA1065 1676649C1 ABP N83 308011 3916657 4379-RD568681
Expansion Valve 71R8400 RD-5-7155-0P EA1090 EA1090 1676665C1 ABP N83 308191 3919114, 3949396 4379-RD571550
Expansion Valve 71R8430 RD-5-8936-0P 540057BSM 540057BSM 1699955C1 ABP N83 308141 3949398 4379-RD589360
Filter 78R5420 RD-5-10745-0P 525507BSM, 94735015-A/M 525507BSM N/A ABP N83 328225 RDHRD5107450P 4379-RD5107450
Grill Condenser 77R6920 RD-4-3727-2P K122-64 K122-64 N/A ABP N83 306535 RDHRD437272P 4379-RD437272
Grill Condenser 77R6957 RD-5-12488-0P K122-125 K122-125 N/A ABP N83 306575 RDHRD5124880P 4379-RD5124880P
Grill Condenser 77R6960 RD-4-4403-1P K122-121, RD4 4403 1 K122-121 N/A ABP N83 306260 RDHRD444031P 4379-RD444031
Grill Condenser 77R6970 RD-4-5190-0P K137-299-1 K137-299-1 N/A ABP N83 306580 RDHRD451900P 4379-RD451900
Grill Condenser 77R6980 RD-4-3901-1P K100 Series K100 Series N/A ABP N83 306615 RDHRD439011P 4379-RD439011
Receiver Drier 74R2001 RD-5-10434-0P 088439-01, F37-6000 F37-6000 ZGG712051 ABP N83 319574 RDHRD5104340P 4379-RD5104340
Receiver Drier 74R3356 RD-5-8254-0P 088324-01, 02, K251-571, GD1135 GD1135 ZGG19141 ABP N83 319028 3949310 4379-RD582540
Toggle Switch 71R0453 RD-5-10056-0P BA1005 BA1005 N/A ABP N83 322003 RDHRD5100560P 4379-RD5100560
Mack
Blower Motor 73R0412 RD-5-10337-0P 4379-RD5103370 HA1180, HB1610 ZGG701019 ABP N83 301004 85101275 4379-RD5103370
Blower Motor 73R0922 RD-5-5634-1P 4379-RD556341 HA1175 ZGG19262 ABP N83 301097 RDHRD56341P 4379-RD556341
Clutch 75R0202 RD-5-5486-0P 4379-RD554860 KA1345 ZGG11207 ABP N83 303282 176314 4379-RD554860
Compressor 75R8382 RD-5-7088-0P 4379-RD570880 LE1260 ZGG13503 ABP N83 304102 RDHRD70880P 4379-RD570880
Compressor 75R81622 RD-5-12330-0P 206RD51M, 20514024, Sanden 4883 ABP N83 304241 RDHRD123300P 4379-RD512230
Compressor 75R84612 RD-5-10297-0P 206RD413M LE1035, LE1135 ZGG19370 ABP N83 304933 3916160 4379-RD5102970, 206RD413M
Condenser 77R7717 RD-4-6415-0P 210RD428 N/A N/A ABP N83 306907 RDHRD464150P 4379-RD464150
Control Cable 72R8180 RD-5-10588-0P 7787-530244 N/A N/A ABP N83 327376 RDHRD5105880P 4379-RD5105880
Expansion Valve 71R8301 RD-5-6868-1P 4379-RD568680 EA1065 1676649C1 ABP N83 308011 3916657 4379-RD568681
Expansion Valve 71R8321 RD-5-7015-1P 4379-RD570150 EA1075 1676665C1 ABP N83 308071 RDHRD70150P 4379-RD570150
Expansion Valve 71R8385 RD-5-10546-0P 7787-869221, 329-488 N/A N/A ABP N83 308125 RDHRD5105460P 4379-RD5105460, 7787-869221
Filter 78R5235 RD-5-10593-0P 7787-525784 N/A N/A ABP N83 328135 RDHRD5105930P 4379-RD5105930, 7787-525784
Receiver Drier 74R3076 RD-5-8241-0P 088294-01, 02, 221RD335 JA1980 ZGG19145 ABP N83 319504 3949131 4379-RD-582410, 221RD335
Receiver Drier 74R3322 RD-5-6768-1P 088268-01, 221RD334 JA1975 ZGG19144 ABP N83 319554 176240 4379-RD-567681, 221RD334
Peterbilt
Accumulator 74R5050 RD-5-4961-0P 849748, 18-03837, JC1080 JC1080 ZGG19786 ABP N83 319029 176565 4379-RD549610
Blower Motor 73R0042 RD-5-10336-0P P93CAA-0301-01S / HA1825 HA1825 ZGG701017 ABP N83 301981 3949265 4379-RD5103360
Blower Motor 73R0222 RD-5-8212-0P 203139BSM 203139BSM N/A ABP N83 301461 RDHRD582120P 4379-RD582120
Blower Motor 73R0422 RD-5-6526-0P RD-5-6526-0, HA1070 HA1070 117283C91, ZGG19269, 1676648C1 ABP N83 301001 3949262 4379-RD565260
PAGE 84 PAGE 85
Peterbilt
Compressor 75R81452 RD-5-11313-0P 4645 LE1150, F69-6002-243 2003413C91 ABP N83 304953 RDHRD5113130P 4379-RD5113130
Compressor 75R81472 RD-5-11316-0P 4647, 4713, 18-04088, F69-6001-253 LE1135, LE1620 2032287C91 ABP N83 304853 RDHRD5113160P 4379-RD5113160
Compressor 75R81482 RD-5-11322-0P 4660 N/A ZGG705006 ABP N83 304344 RDHRD5113220P 4379-RD5113220
Compressor 75R81502 RD-5-11326-0P 4667, F69-6002-114, K318-103 LE1085 3579878C1 ABP N83 304973 RDHRD5113260P 4379-RD5113260
Compressor 75R81512 RD-5-11328-0P 4672, F69-6001-215 N/A ZGG705009 ABP N83 304873 RDHRD5113280P 4379-RD5113280
Compressor 75R81562 RD-5-11334-0P 4739, F69-6002-214, 18-04291 F69-6002-214 N/A ABP N83 304394 RDHRD5113340P 4379-RD5113340
for Cat 3406 engine
for Detroit S60 series engine
Compressor 75R8512 RD-5-5876-0P 488-25011, 18-03536 LE1000 1691725-C92 ABP N83 304019 3918277 4379-RD558760
Compressor 75R8292 RD-5-5575-0P 9285 LE1015 ZGG11065 ABP N83 304222 3916160 4379-RD555750
Compressor 75R84292 RD-5-10273-0P 4731, F69-6001-121, 122 F69-6001-121,122 N/A ABP N83 304163 RDHRD5102730P 4379-RD5102730
Compressor 75R84312 RD-5-10274-0P 4484, 18-04373 F69-6002-233 N/A ABP N83 304173 RDHRD5102740P 4379-RD5102740
Compressor 75R8432 RD-5-7522-0P F69-1002, F69-6001-153, F69-6002-133 LE1140 ZGG19316 ABP N83 304095 8022507 4379-RD575220
Compressor 75R84572 RD-5-10295-0P 4665, 18-03788 LE1150 ZGG19297 ABP N83 304333 85100887 4379-RD5102950
Compressor 75R84612 RD-5-10297-0P 18-03787, 4639SAN LE1035 ZGG19370 ABP N83 304363 3916160 4379-RD5102970, 206RD413M
Compressor 75R84612 RD-5-10297-0P 18-04088, 4713SAN LE1620 ZGG705007 ABP N83 304363 RDHRD5102970P 4379-RD5102970, 206RD413M
Compressor 75R8742 RD-5-10495-0P 4696, 18-04154, F69-1000 F69-1000 ZGG705129 ABP N83 304659 RDHRD5104950P 4379-RD5104950
Condenser 77R6950 RD-4-5658-0P 18-03809 18-03809 N/A ABP N83 306420 RDHRD456580P 4379-RD456580
Condenser 77R7717 RD-4-6415-0P 210RD428 210RD428 N/A ABP N83 306907 RDHRD464150P 4379-RD464150
Condenser 77R7900 RD-4-3683-2P PA1200 PA1200 N/A ABP N83 306120 RDHRD436832P 4379-RD436832
Expansion Valve 71R8301 RD-5-6868-1P RD-5-6868-0, EA1065 EA1065 1676649C1 ABP N83 308011 3916657 4379-RD568681
Expansion Valve 71R8430 RD-5-8936-0P 540057BSM EA1310 1699955C1 ABP N83 308141 3949398 4379-RD589360
Orfice Tube 71R8505 RD-5-9082-0P P93CAB2500-01S, EC1015 EC1015 ZGG16244 ABP N83 308017 3093407 4379-RD590820
Receiver Drier 74R1756 RD-5-3593-0P 402529 / JA1085 JA1085 1676653C1 ABP N83 319514 61510-001 4379-RD535930
Receiver Drier 74R2001 RD-5-10434-0P F37-6000 F37-6000 ZGG7102051 ABP N83 319574 RDHRD5104340P 4379-RD5104340
Receiver Drier 74R2706 RD-5-4955-0P 18-01800 / JA1240 JA1240 1676663C1 ABP N83 319110 RDHRD549550P 4379-RD549550
Thomas Built
Air Filter 78R5236 RD-5-10077-0P 8566-0439 N/A ZGG720002 ABP N83 328194 RDHRD5100770P 4379-RD5100770
Air Filter 78R5244 RD-5-10076-0P 8566-0237 N/A N/A ABP N83 328223 RDHRD5100760P 4379-RD5100760
Air Filter 78R5254 RD-5-10079-0P N/A N/A N/A ABP N83 328204 RDHRD5100790P 4379-RD5100790
Air Filter 78R5256 RD-5-10075-0P 8566-0237 N/A ZGG720006 ABP N83 328214 RDHRD5100750P 4379-RD5100750
Air Filter 78R5258 RD-5-10074-0P N/A N/A N/A ABP N83 328213 RDHRD5100740P 4379-RD5100740
Blower Motor 73R0012 RD-5-10379-0P 8566-0226 N/A 2503277C1 ABP N83 301921 RDHRD5103790P 4379-RD5103790
Blower Motor 73R0022 RD-5-5909-0P 8566-0130, 73069008 N/A 411876C1 ABP N83 301161 RDHRD559090P 4379-RD559090
Blower Motor 73R0082 RD-5-10071-0P N/A N/A N/A ABP N83 301901 RDHRD5100710P 4379-RD5100710
Blower Motor 73R0142 RD-5-10070-0P 2503279C1 N/A 2503279C1 ABP N83 301881 RDHRD5100700P 4379-RD5100700
Blower Motor 73R0632 RD-5-10069-0P 6500-0439, 8566-0378 N/A ZGG11643, ZGG19343 ABP N83 301871 RDHRD5100690P 4379-RD5100690
Blower Motor 73R0642 RD-5-10072-0P 4316246 N/A ZGG701089 ABP N83 301911 RDHRD5100720P 4379-RD5100720
Defrost Fan 73R9062 RD-5-5796-0P 5200-3268 N/A 221099C1, 4507329R1 ABP N83 309141 61103-0024 4379-RD557960
Defrost Fan 73R9082 RD-5-10490-0P 783966C93 N/A 783966C93 ABP N83 309311 RDHRD5104900P 4379-RD5104900
Volvo
APADS Press. Switch 71R6418 RD-5-10778-0P 3966805 N/A N/A ABP N83 318828 RDHRD5107780P 4379-RD5107780
APADS Press. Switch 71R6420 RD-5-10470-0P 8040202 N/A N/A ABP N83 318138 RDHRD5104700P 4379-RD5104700
APADS Press. Switch 71R6422 RD-5-10779-0P 3939317 N/A N/A ABP N83 318848 3939317 4379-RD5107790
Blower Motor 73R3002 RD-5-11466-0P BOA 85 440 50 009 / 176140 HB1880 ZGG19230 ABP N83 301307 176140 4379-RD5114660
Blower Motor Kit 73R4532 RD-3-10538-0P 3945237 HB1660 ZGG13501 ABP N83 301362 3945237 4379-RD3105380
PAGE 86 PAGE 87
Volvo
Compressor 75R81372 RD-5-11257-0P 8088112, 20501069 N/A N/A ABP N83 304624 20501069 4379-RD112570
Compressor 75R81482 RD-5-11322-0P 8177089 N/A N/A ABP N83 304344 8177089 4379-RD5113220
Compressor 75R81532 RD-5-11330-0P 20501069, 8080059, 8088112 N/A N/A ABP N83 304524 8080059 4379-RD5113300
Compressor 75R81702 RD-5-11348-0P N/A N/A N/A ABP N83 304684 RDHRD5113480P 4379-RD5113480 Z
Compressor 75R8422 RD-5-7120-0P 20370291, 8164872 LE1145 ZGG19296 ABP N83 304125 20370291, 8164872 4379-RD571200
Compressor 75R84382 RD-5-10278-0P 8082269, 85104593 N/A N/A ABP N83 304213 8082269, 85104593 4379-RD5102780
Expansion Valve 71R8301 RD-5-6868-1P 3916657 EA1065 1676649C1 ABP N83 308011 3916657 4379-RD568681
Expansion Valve 71R8370 RD-5-7567-0P BOA-80-321-00-169 / 3949281 EA1365 ZGG19226 ABP N83 308009 3949281 4379-RD575670
Receiver Drier 74R1406 RD-5-10742-0P 20407205 N/A N/A ABP N83 319660 RDHRD5107420P 4379-RD5107420
Receiver Drier 74R1426 RD-5-10743-0P 20447319 N/A N/A ABP N83 319258 20447319 4379-RD5107430
Receiver Drier 74R3106 RD-5-9789-0P 3934718 / 61510-0008 JA1280 ZGG19150 ABP N83 319394 3934718 4379-RD597890
Receiver Drier 74R3450 RD-5-4959-0P 3949280, 8086753 JA1325, JA1960 1693117C1 ABP N83 319910 3949280, 8086753 4379-RD549590
Resistor 71R1457 RD-5-10341-0P 3949112 CA1035 1696836C1 ABP N83 321300 3949112 4379-RD5103410
Water Valve 72R6530 RD-5-10345-0P 1118413 N/A N/A ABP N83 324145 1118413 4379-RD5103450
Western Star
Blower Motor-Main 73R1002 RD-3-8657-0P RD-3-8657-0 ABP N83 301771 RDHRD386570P 4379-RD386570
Blower Motor-Sleeper 73R0422 RD-5-6526-0P 60009-5003, 5009 HA1070 117283-C91 ABP N83 301001 60009-5003, 5009 4379-RD565260
Compressor 75R8432 RD-5-7522-0P 61104-3420 LE1140 ZGG19316 ABP N83 304095 8022507 4379-RD575220
Expansion Valve 71R8300 RD-5-6868-0P 60012-5001 EA1065 1676649-C1 ABP N83 308011 3916657 4379-RD568680
Pressure Switch 71R7650 RD-5-4625-0P RD-5-4625-0 ABP N83 322200 RDHRD546250P 4379-RD546250
Receiver Drier 74R3136 RD-5-7517-0P 61506-3404 ABP N83 319048 RDHRD575170P 4379-RD575170
Receiver Drier 74R3376 RD-5-7517-1P 61506-3406 ABP N83 319314 176248 4379-RD575171
Thermostat 71R3200 RD-5-4531-24P 60054-4421 ABP N83 323010 RDHRD5453124P 4379-RD5453124
All Makes Products

Defrost Fan 73R9082 RD-5-10490-0P 783966C93 N/A 783966C93 ABP N83 309015 3916157, RDHRD5104900P 4379-RD5104900
Electrical Connector Kit 79R3532 RD-5-11966-0P N/A N/A ABP N83 322842 RDHRD5119660P 4379-RD5119660
Filter, Hi Efficiency Gideon 78R5260 RD-5-12533-0P FEFF003 N/A N/A N/A RDHRD5125330P 4379-RD5125330
Filter, Hi Efficiency Gideon 78R5261 RD-5-12534-0P FEFF004 N/A N/A N/A RDHRD5125340P 4379-RD5125340
Filter, RESPA Gideon Precleaner 78R5622 RD-5-12531-0P N/A N/A N/A N/A RDHRD5125310P 4379-RD5125310
Filter, RESPA Gideon Precleaner 78R5624 RD-5-12532-0P N/A N/A N/A N/A RDHRD5125320P 4379RD5125320
Filter, Gideon Precleaner 78R5632 RD-5-11859-0P N/A N/A N/A N/A RDHRD5118590P 4379-RD5118590
Filter, Gideon Precleaner 78R5634 RD-5-11860-0P N/A N/A N/A N/A RDHRD5118600P 4379-RD5118600
Flush 1 GAL. 79R4650 RD-5-10206-0P VA1070 ZGG725011 ABP N83 326025 RDHRD5102060P 4379-RD5102060
#6 Goodyear Hose 50ft 78R0456 RD-5-5006-600P D1037-3023 AA1045 ZGG16971 ABP N83 313106 3949322 4379-RD55006600
#6 Parker P80 Hose 100ft 78R8806 RD-5-9820-0P P80-6 N/A N/A ABP N83 313120 176556 4379-RD598200
#8 Goodyear Hose 50ft 78R0458 RD-5-5008-600P D1037-3037 N/A ZGG16972 ABP N83 313118 3949323 4379-RD55008600
#10 Goodyear Hose 50ft 78R0451 RD-5-5010-600P D1037-3058 AA1055 ZGG16973 ABP N83 313100 3949324 4379-RD55010600
#12 Goodyear Hose 50ft 78R0452 RD-5-5012-600P D1037-3064 D1037-3064 ZGG16974 ABP N83 313102 3949325 4379-RD55012600
Per-Job O-Ring Kit 70R5020 RD-5-9987-0P VH1160 ZGG12033, 12034, 19129 ABP N83 312125 176566, 3949461 4379-RD599870
Slimline Seal, #6, 9⁄16" O.D. x 5⁄16" I.D. 70R5022 RD-5-10200-0M ABP N83 312076 RDHRD5102000M 4379-RD5102000
Mini Stat-O-Seal, #6, 5⁄8" O.D. x 5⁄16" I.D. 70R5031 RD-5-11527-0M 336565, 23-13201-000 ABP N83 312366 RDHRD5115270M 4379-RD5115270
PAGE 88 PAGE 89
All Makes Products

Mini Stat-O-Seal, #12, 1 1⁄8" O.D. x 11⁄16" I.D. 70R5034 RD-5-11530-0M 720565, 23-13205-000 ABP N83 312372 RDHRD5115300M 4379-RD5115300
Slimline Seal, 17mm, 1" O.D. x 5⁄8" I.D. 70R5035 RD-5-12675-0M 23-13204-000 ABP N83 312222 RDHRD5126750M 4379-RD5126750
Retro Fit Kit - CCI/Tecumeseh 79R4600 RD-5-8958-0P VC2000 ZGGH550432 ABP N83 325010 3949456 4379-RD589580
Retro Fit Kit - GM 79R4615 RD-5-8961-0P VC2015 ZGGH725016 ABP N83 325513 176377, 3949459 4379-RD589610
Retro Fit Kit - Sanden/Seltec 79R4605 RD-5-8960-0P VC2005 ZGGH550433 ABP N83 325511 3949457, 8 4379-RD589600
Sanden PAG Oil 79R4580 RD-5-7103-0P LM1035 NA ABP N83 326013 RDHRD571030P 4379-RD571030
Seltec PAG Oil 79R4585 RD-5-7166-0P LM1070 ZGGR6822 ABP N83 326056 RDHRD571660P 4379-RD571660
Slim Line/Stat-O-Seal Service Kit 79R8950 RD-5-12676-0P NA NA NA ABP N83 322860 RDHRD5126760P 4379-RD5126760
EZ Clip Fittings
Quick Disconnect, #8 male to #6 quick disconnect 70R3908 RD-2-4844-1P NA NA NA ABP N83 311454 RDHRD248441P 4379-RD248441
Quick Disconnect, #12 male to #10 quick disconnect 70R3912 RD-2-4845-1P NA NA NA ABP N83 311464 RDHRD248451P 4379-RD248451
Straight Splicer with R-12 Charge Port - #10 70R8061 RD-5-10572-1P NA NA NA ABP N83 311220 RDHRD5105721P 4379-RD5105721
90° Bulkhead - #10 70R8071 RD-5-10562-1P NA NA NA ABP N83 311941 RDHRD5105621P 4379-RD5105621
Straight Female O-ring with Low side charge port # 10 70R8201 RD-5-10564-1P NA NA NA ABP N83 311951 RDHRD5105641P 4379-RD5105641
Straight Female O-ring with High side charge port #8 70R8208 RD-5-10566-1P NA NA NA ABP N83 311958 RDHRD5105661P 4379-RD5105661
90° Splicer - #10 70R8291 RD-5-10580-1P NA NA NA ABP N83 311961 RDHRD5105801P 4379-RD5105801
Straight Male O-ring with High side charge port - # 8 70R8688 RD-5-10575-1P NA NA NA ABP N83 311978 RDHRD5105751P 4379-RD5105751
45° Male O-ring - #10 70R8341 RD-5-10556-1P NA NA NA ABP N83 311971 RDHRD5105561P 4379-RD5105561
90° Male O-ring with High side charge port - #8 70R8398 RD-5-10576-1P NA NA NA ABP N83 311998 RDHRD5105761P 4379-RD5105761
O-Ring - FNBR #6 70R8506 RD-5-11015-0M NA NA NA ABP N83 312346 RDHRD5110150M 4379-RD5110150
90° Bulkhead - #10 to #12 70R8591 RD-5-10563-1P NA NA NA ABP N83 310360 RDHRD5105631P 4379-RD5105631
90° Male O-ring with Low side charge port - #10 to #12 70R8598 RD-5-10577-1P NA NA NA ABP N83 310320 RDHRD5105771P 4379-RD5105771
Straight Female O-ring with Low side charge port # 10 to #12 70R8621 RD-5-10565-1P NA NA NA ABP N83 310300 RDHRD5105651P 4379-RD5105651
Straight Male O-ring with Low side charge port - # 10 to #12 70R8681 RD-5-10574-1P NA NA NA ABP N83 310310 RDHRD5105741P 4379-RD5105741
Straight Bulkhead Fitting - #10 70R8881 RD-5-10559-1P NA NA NA ABP N83 310340 RDHRD5105591P 4379-RD5105591
90° Female O-ring with 7⁄16” Switch Port - #10 to #12 70R8891 RD-5-10569-1P NA NA NA ABP N83 310350 RDHRD5105691P 4379-RD5105691
90° Female O-ring with 7⁄16” Switch Port - #6 70R8996 RD-5-10567-1P NA NA NA ABP N83 310356 RDHRD5105671P 4379-RD5105671
90° Female O-ring with 7⁄16” Switch Port - #8 70R8998 RD-5-10568-1P NA NA NA ABP N83 310358 RDHRD5105681P 4379-RD5105681
EZ CLIP TOOL KIT 79R8915 RD-5-10718-0P NA NA NA ABP N83 327980 85100261 4379-RD5107180
#6 EZ Clip Hose 78R8456 RD-5-10504-600P NA NA NA ABP N83 313406 85100278 4379-RD510504600
#8 EZ Clip Hose 78R8458 RD-5-10505-600P NA NA NA ABP N83 313408 RDHRD510505600P 4379-RD510505600
PAGE 96 PAGE 97
ON-ROAD APPLICATIONS
Model Year Description OEM Part No. Factory No. Part No.
CHEVROLET/GMC
BLOWER MOTOR
Astro, Titan (Cab Over) 1983-88 Bunk Unit - Kysor, double shaft motor, 1 speed, 4 3⁄4” length 275152 RD-5-8032-0P 73R4122
Sleeper Unit - Red Dot R-4013, R-4060, R-9711, single shaft,
Bison, General (Conventional) 1979-84 RDH RD3106 13 RD-3106-13P 73R0602
4 1⁄4” length
Brigadier, Bruin (Conventional) 1983-88 Bunk Unit - Kysor, double shaft motor, 1 speed, 4 3⁄4” length 275152 RD-5-8032-0P 73R4122
3028652, 3031995, 303196,
C, K Series, 6 & 8 cylinder 4.3, 5.0, 5.7L 1986-2000 Rear Roof Unit A/C, double shaft motor, 1 speed, 4 3⁄4” length RD-5-6801-0P 73R4182
3034845, 4961626
Front and Auxiliary Rear with or without A/C, plate mounted,
G 10 -35 Series 1992-2001 52461561, 52468300 RD-5-11466-0P 73R3002
7” diameter, CW, 1 speed, 4 3⁄4” length
Front, with or without A/C, plate mounted, 7” diameter, CW, 52461377, 52469795,
G 10 -35 Series 1985-95 RD-5-11466-0P 73R3002
1 speed, 4 3⁄4” length 5246079
Double shaft motor, single speed, 4 3⁄4” x 4” x 3”, shaft 2 1⁄2”
G 10 -35 Series 1971-84 3031995 RD-5-5190-0P 73R4162
length
w Aux Heater, 1 speed, 3 1⁄4” diameter blower motor, CW or
G 10 -35 Series 1971-79 4999707 RD-5-10390-0P 73R0212
CCW
52461377, 52469795,
P Series 1993-95 w A/C, plate mounted, 7” diameter, CW, 1 speed, 4 3⁄4” length RD-5-11466-0P 73R3002
5246079
Hupp heater, Kysor heater A/C, single shaft motor, 1 speed,
P Series 1960-95 1099001, 274248 RD-5-10389-0P 73R0372
CCW, 4 5⁄8” length
Hupp heater, Main unit, double shaft motor, 1 speed, 4 3⁄4” 3028652, 3031995, 303196,
P Series 1960-89 RD-5-6801-0P 73R4182
length 3034845, 4961626
Motor between seat (double shaft motor), single speed, 4 3⁄4”
Topkick/Kodiak 40-95 Series 1982-88 4999706 RD-5-5190-0P 73R4162
x 4” x 3”, shaft 2 1⁄2” length
BLOWER RELAY
C, K, Suburban 1992-97 Blower A/C and 12V motor relay (Auxiliary), SPST, 5 terminal 15591178 RD-5-7232-0P 71R1912
C, K Series, 6 & 8 cylinder 4.3, 5.0, 5.7L 1988-97 Blower A/C and 12V motor relay (Auxiliary), SPST, 5 terminal 15591178 RD-5-7232-0P 71R1912
Topkick/Kodiak C40-75 Series 1970-1978 Blower relay (30 amp), SPST, 5 terminals 1115858 RD-5-10154-0P 71R1922
Motor relay (glovebox), Bosch type (40 amp) with diode, 14100455, 25520198,
Topkick/Kodiak C40-95 Series 1990-2000 RD-5-9915-0P 71R1722
SPST, 5 terminals 3949297
Forward, Tiltmaster - mini relay (Kysor) (30 amp), SPST, 5
Topkick/Kodiak C40-95 Series 1985-93 221655 RD-5-4408-0P 71R1702
terminals
GMC General, Bison, control lock, relay (30 amp), SPST, 5
Topkick/Kodiak C40-95 Series 1981-82 3989214 RD-5-10154-0P 71R1922
terminals
Mini relay (accessory), Bosch type (40 amp) with diode, SPST,
Topkick/Kodiak C50-75, 80-95 Series 1990-95 14100455, 3949297 RD-5-9915-0P 71R1722
5 terminals
Mini relay (accessory), Bosch type (40 amp) with diode, SPST,
Topkick/Kodiak C60-75 Series 1983-85 14100455, 3949297 RD-5-9915-0P 71R1722
5 terminals
Topkick/Kodiak C60-75 Series 1983-85 Mini relay (accessory), Bosch type (30 amp), SPST, 5 terminals 2098912 RD-5-4408-0P 71R1702
BLOWER WHEEL
C, G, K Series, 6 & 8 cylinder 4.3, 5.0,
1986-2000 Main standard heater motor and rear roof (steel) 3027031, 3094157, 3905776 RD-3106-38P 73R6101
5.7L, 6.2L Diesel
C, G 50-75 Series 1983-91 Heater only, 5 5⁄8” single entry wheel, 3 7⁄16” width, CW 3027437, 3094157, 3949391 RD-5-10753-0P 73R6253
G 10 -35 Series 1974-91 Heater only, 5 5⁄8” single entry wheel, 3 7⁄16” width, CW 3027437, 3094157, 3949391 RD-5-10753-0P 73R6253
COMPRESSOR ASSEMBLY
C50 - C95 Conventional, all 6.0L, 7.0L
Sanden compressor 7H15FLX, GV head, ear mount, 2 groove,
engines with Sanden compressor 7H15 1994-2000 15680077, 15020478 RD-5-10283-0P 75R83112
4.9” (125mm)
#4860
All with Sanden compressor 5H14 #7803, 2 groove, 125mm,
P10-35, P600 Series, 454 ci, 7.4L 1993-95 15680077, 15020478 RD-5-10283-0P 75R83112
QD head
ELECTRICAL SWITCH
Brigadier/Bruin 80-95 Series 1980-87 Blower speed control resistor, 3 terminal, 3 speed 8865281 RD-5-3647-0P 71R1450
EXPANSION VALVE / BLOCK
Main unit (Kysor), block valve, female O-Ring, 50 psig@85°F,
Astro, Titan (Cab Over) 1980-89 02-7086617 RD-5-6780-0P 71R8410
superheat 5°F
PAGE 99
CHEVROLET/GMC
COMPRESSOR ASSEMBLY
Bison, General (Conventional) 1980-90 02-7086617 RD-5-6780-0P 71R8410
superheat 5°F
Brigadier, Bruin (Conventional) 1980-90 02-7086617 RD-5-6780-0P 71R8410
superheat 5°F
Topkick/Kodiak 40-95 Series 1978-92 02-7086617 RD-5-6780-0P 71R8410
superheat 5°F
EXPANSION VALVE / ORIFICE TUBE
GM type, CCOT (White) Orifice Tube with accumulator system,
Astro, Titan (Cab Over) 1999-05 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
Main unit
Bison, General (Conventional) 1980-90 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
Main unit
Brigadier, Bruin (Conventional) 1980-90 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
Main unit
C, K, Blazer, RV, Suburban, all engines 1990-2009 CCOT Orifice Tube (Black/White) in condenser, Main unit 3093576, 3096068 RD-5-10012-0P 71R8501
C, K, Blazer, RV, S-10 (86-99), Suburban, GM type, CCOT (White) Orifice Tube with accumulator system,
1976-2000 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
all engines Main unit
G 10 -35 Series Van 1976-97 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
Main unit
G 10 -35 Series Van 1991-97 CCOT Orifice Tube (Black/White) in condenser, Main unit 3093576, 3096068 RD-5-10012-0P 71R8501
P10-35, P600 Series, 454 ci, 7.4L 1976-97 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
Main unit
Topkick/Kodiak 40-95 Series 1999-2010 15-5151, 3033879, 3033919 RD-5-4919-0P 71R8500
Main unit
PRESSURE SWITCH
C, K 10-35 Series all engines 1994-00 Compressor Low Pressure NC cycling switch 15966454 RD-5-6397-0P 71R6020
RECEIVER DRIER
Astro, Titan (Cab Over) 1980-90 Accumulator tube for universal accumulator, RD-5-4961-0P RD-5-4962-0 RD-5-4962-0P 74R5600
15-1641, 15505227,
Astro, Titan (Cab Over) 1980-89 In-line Drier, 2 1⁄2” X 6 9⁄16”, #6 to #8 male O-Ring RD-5-4947-0P 74R0450
2724475, 3949269
15-1641, 15505227,
Bison, General (Conventional) 1978-89 In-line Drier, 2 1⁄2” X 6 9⁄16”, #6 to #8 male O-Ring RD-5-4947-0P 74R0450
2724475, 3949269
All (Kysor) receiver drier, 3” x 10 1⁄4”, hi cap, pressure relief,
Brigadier, Bruin (Conventional) 1983-89 1999003 RD-5-11535-0P 74R3324
moisture indicator
15-1641, 15505227,
Brigadier, Bruin (Conventional) 1981-89 In-line Drier, 2 1⁄2” X 6 9⁄16”, #6 to #8 male O-Ring RD-5-4947-0P 74R0450
2724475, 3949269
15-1641, 15505227,
Topkick/Kodiak C50-75, 80-95 Series 1980-93 In-line Drier, 2 1⁄2” X 6 9⁄16”, #6 to #8 male O-Ring RD-5-4947-0P 74R0450
2724475, 3949269
RECEIVER DRIER / ACCUMULATOR
Astro, Titan (Cab Over) 1980-81 Universal Accumulator, #12 female O-Ring, 3 1⁄2” x 8” 15-1274, 849748, 3012944 RD-5-4961-0P 74R5050
Brigadier, Bruin (Conventional) 1981-89 Universal Accumulator, #12 female O-Ring, 3 1⁄2” x 8” 15-1274, 849748, 3012944 RD-5-4961-0P 74R5050
G 10 -35 Series Van 1980-85 Universal Accumulator, #12 female O-Ring, 3 1⁄2” x 8” 15-1274, 849748, 3012944 RD-5-4961-0P 74R5050
Topkick/Kodiak 40-95 Series 1980-85 Universal Accumulator, #12 female O-Ring, 3 1⁄2” x 8” 15-1274, 849748, 3012944 RD-5-4961-0P 74R5050
RELAY (ACTUATOR)
Topkick/Kodiak C50-75, 80-95 Series 1992-01 Actuator (Mode Valve), 126° maximum travel 16141802 RD-5-13605-0P 71R3571
THERMOSTATIC SWITCH
Fixed Setting thermostat with 24” capillary tube, flange/side
All series with OE # 3949291 1985-95 3949291 RD-5-4531-24P 71R3200
mount
Fixed Setting thermostat with 24” capillary tube, flange
All series with OE # 3093422 1985-95 3093422 RD-4427-24P 71R3100
mount
All series with OE # RD-4125-36 1985-95 Rotary thermostat with 36” capillary tube RD-4125-36 RD-4125-36P 71R2250
Fixed Setting thermostat with 24” capillary tube, flange/side
C Series, Tiltmaster with Kysor unit 1983-93 3949291 RD-5-4531-24P 71R3200
mount
WATER VALVE
Topkick/Kodiak C50-75, 80-95 Series 1984-89 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose 3857131 RD-5-4257-0P 72R5050
PAGE 100
FORD
BLOWER MOTOR
All series with Main unit, OE # XC4H- A/C and heater 7 7⁄8” flange motor, CW, vented, shaft length
1998-00 XC4H-19805-AA RD-5-11579-0P 73R3072
19805-AA 1 1⁄2”
OE style single shaft blower motor (only), 3 3⁄4” length,
C/CL/CLT/CT 1978-90 E1FZ-19805A RD-5-10391-0P 73R0092
non-vented
C, CT 600-900 1979-90 A/C & Heater with single shaft, 2 speed, CW, 4 1⁄4” length B7A-18527-B RD-3106-12P 73R0552
CF 600-800 Cargo series 1987-93 Kysor A/C, double shaft motor, 1 speed, 4” length RD-5-5614-0P 73R4062
CF 600-800 Cargo series with factory
1989-91 Single speed, 4 3⁄4” x 4” x 3”, shaft 2 1⁄2” length E9TF-19805BC RD-5-5190-0P 73R4162
A/C, F.N.H. Engine
Main unit (with white blower wheels), double shaft, vented,
CF Cargo series 1986-92 E6HZ-19805A RD-5-5049-1P 73R4422
5 1⁄4” x 4 1⁄2” x 3”
Main unit (with white blower wheels), double shaft, vented,
CF Cargo series 1986-92 E9HZ-19805A RD-5-10068-0P 73R4322
4 7⁄8” x 4 1⁄2” x 3”
Rear unit, flange/plate mounted motor, 1 speed, 4 3⁄4” length, F0ZZ-19805B, F4SZ-19805A,
E Series, all engines 1992-2000 RD-5-4937-0P 73R2102
CW GA
A/C and heater flange motor, single speed, vented, shaft
E 150-350, all engines exc 7.3L diesel 1992-00 F0ZZ-19805C RD-5-10382-0P 73R2242
length 1 1⁄16”
E150-350 all models with Main unit with All models with Main unit with flange motor, vented, shaft
1995-96 F3UZ-19805A RD-5-10388-0P 73R2152
flange motor, 7.3L diesel length 1 1⁄16”
E150-350 A/C and heater flange motor, F58H-19805FA, F58Z-
1995-96 A/C and heater flange motor, CW, vented, shaft length 1 1⁄16” RD-5-10383-0P 73R2112
7.3L diesel 19805B
All models with flange/plate mounted, CW, vented, shaft
E150-350, Main unit 1992-96 F2UZ-19805A RD-5-10387-0P 73R2142
length 1 5⁄8”
E150-350, Integral heater 1988-91 All models with Integral Heater A/C (flange Motor only) E8UF-19805A RD-5-10386-0P 73R2132
E150-350 1969-88 A/C flange motor, single speed, vented, shaft length 1 1⁄16” C9UZ-19805A RD-5-10382-0P 73R2242
All models heater only (motor only), single speed, 4” x 3 1⁄2”
E150-350 1969-81 D5UZ-18527A, E3PZ-18527A RD-5-10379-0P 73R0012
x 3”
Main unit, OE style single shaft blower motor (only), 3 3⁄4”
Expedition , all engines 1998-2002 F7SZ-19805DA, EA, FA RD-5-10391-0P 73R0092
length, non-vented
F150-350, Bronco 1990-96 All models with Integral Heater A/C (flange Motor only) E7TZ18527A, F2TZ-18527A RD-5-10385-0P 73R2122
F150-350, Bronco 1988-91 All models with Integral A/C (flange Motor only) E8UZ-18527A RD-5-10385-0P 73R2122
F150-350, Bronco 1988-91 All models with Integral Heater A/C (flange Motor only) E8UF-19805A RD-5-10386-0P 73R2132
All models heater only, flange motor, single speed, shaft E2TZ-18527A, E3TZ-18527A,
F150-350, Bronco 1982-91 RD-5-10380-0P 73R2202
length 1 7⁄16” F47Z-19805A
All models with Integral A/C, flange motor, CW, vented, shaft
F150-350, Bronco 1980-87 E0TY-19805A, E0VY-19805A RD-5-10383-0P 73R2112
length 1 1⁄16”
All models with Integral A/C, flange motor, CW, vented, shaft
F150-350, Bronco 1980-86 D9AZ-19805A RD-5-10383-0P 73R2112
length 1 1⁄16”
F150-350, Bronco 1973-81 E3PZ18527A RD-5-10379-0P 73R0012
x 3”
F100-350, Bronco 1973-79 A/C Motor (late), single speed, vented, shaft length 1 1⁄16” D7TZ-19805A RD-5-10382-0P 73R2242
All models heater only, 1 speed, 3 1⁄4” diameter blower motor,
F100-350 1965-81 D3TZ-18527A RD-5-10390-0P 73R0212
CW or CCW
A/C Motor (early) with flange motor, 4 7⁄8” diameter,CW,
F100-350 1968-73 D3TZ-19805A RD-5-10381-0P 73R2222
single speed
F500-1000 1965-75 All models heater only with 4 3⁄4” diameter, CCW, single speed C5TZ-18527A RD-5-10746-0P 73R1012
All models heater only, flange motor, single speed, shaft
F600-800 1990-98 F47Z-19805A RD-5-10380-0P 73R2202
length 1 7⁄16”
All models, 2 speed vent, A/C and heater flange motor, CW,
F600-900 1983-89 F4VZ-19805BD RD-5-10383-0P 73R2112
shaft length 1 1⁄16”
All models heater only, flange motor, single speed, shaft E2TZ-18527-A, E3TZ-
F600-900 1982-89 RD-5-10380-0P 73R2202
length 1 7⁄16” 18527-A, F47Z-19805-A
All models, 2 speed vent, A/C and heater flange motor, CW,
F600-900 1980-91 E0TY-19805A, E0VY-19805A RD-5-10383-0P 73R2112
shaft length 1 1⁄16”
PAGE 101
Ford
BLOWER MOTOR
F600-900 1980-81 E3PZ-18527A RD-5-10379-0P 73R0012
x 3”
F6UZ-19805BA, F8HH-
Main unit with flange/plate mounted, CW, vented, shaft
L Series 1996-99 19805AA, F8HZ-19805AA, RD-5-10387-0P 73R2142
length 1 5⁄8”
BA, X4CZ-19805BA
Main unit, flange motor, single speed, CCW, vented, shaft
L Series Main unit 1991-96 F1HZ-19805-A RD-5-8029-0P 73R2212
length 1”
L Series, all models with or without
1991-95 Flange motor, single speed, CCW, vented, shaft length 1” F1HZ-19805-A RD-5-8029-0P 73R2212
integral A/C
L Series with Red Dot R8720 Unit 1987-91 Main unit (Red Dot) with single shaft, 4 3⁄4” length D8HZ-18527A RD-5-6526-0P 73R0422
All models with Standard Heater, OE style single shaft blower
L Series 1973-94 E1FZ-19805A RD-5-10391-0P 73R0092
motor (only), 3 3⁄4” length, non-vented
C8TZ-18527A, E0HZ-
High Output Heater - A/C, flange motor, 4 7⁄8” diameter,CW,
L, LN, LNT, LT, LTS 600-900 1980-91 18527B, E8HF-19805A, RD-5-10381-0P 73R2222
single speed
E9HT-19805A
Economy Heater, single shaft blower motor, 1 speed, CW, 4”
L, LN, LNT, LT, LTS 600-900 1973-80 RD-5-5634-0P 73R0922
length
L, LN, LNT, LT, LTS 600-900 1973-80 Economy Heater (motor only), single speed, 4” x 3 1⁄2” x 3” D1AZ-18527A RD-5-10379-0P 73R0012
BLOWER RELAY
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1993-98 All, Blower Relay, Bosch type (30 amp), SPST, 5 terminals RD-5-4408-0P 71R1702
BLOWER RESISTOR
CF 600-800 Cargo series models with Resistor for all Cargo series models with Kysor A/C units, 3
1987-91 220990 RD-5-10441-0P 71R1463
Kysor A/C terminal, 3 speed
BLOWER SWITCH
CF 600-800 Cargo series models with All models with Kysor A/C, Auxiliary fan rotary switch, DP3T, 3
1987-97 N/A RD-5-3646-0P 71R1150
Kysor A/C speed, long shaft thread
E150-350 1997-2011 All models, Front Control blower switch E6DZ-19986A RD-5-10438-0P 71R6249
E150-350 1992-00 All models, Front Control Auxiliary Fan Switch F2UZ-19986C RD-5-10439-0P 71R6251
E150-350 1992-00 All models, Rear Control Aux Fan Switch F2UZ-19986B RD-5-10440-0P 71R6253
E150-350 1992-96 All models, Front Main Control F4UZ-19986A RD-5-10437-0P 71R6247
All models, Main Control, lever switch, all models, 4 position,
E150-350 1980-91 D5AZ-19986A RD-5-10196-0P 71R0487
4 terminal
F100-350 1980-91 All models with lever switch, 4 position, 4 terminal D5AZ-19986A RD-5-10196-0P 71R0487
F600-900 1997 All models with lever switch, 4 position, 4 terminal D5AZ-19986A RD-5-10196-0P 71R0487
All models with gas engine, blower lever switch, 4 position,
L Series, all models with gas engine 1990-92 F0HZ-19986A RD-5-10192-0P 71R0475
4 terminal
All models with manual A/C with lever switch, 4 position, 4
L, LN, LNT, LL, LTL Series 1991-93 F1HZ-19986A RD-5-10196-0P 71R0487
terminal
D0HZ-19986A, E7HT-
L, LN, LNT, LL, LTL Series 1978-91 Blower lever switch, single pole, 4 position, 5 terminals RD-5-10188-0P 71R0485
18C5345AA
BLOWER WHEEL
Main unit (with White Plastic Blower Wheels), double entry,
CF Cargo series 1986-92 D8AZ-19834-A RD-5-8092-0P 73R7200
CW, 5” diameter x 3 7⁄8” width
Main unit (with Black Blower Wheels), double entry, CCW, 5”
CF Cargo series 1986-92 E9HZ-19834-A RD-5-8092-1P 73R7210
diameter x 3 7⁄8” width
Kysor Class Six A/C, double entry, 3 3⁄16” diameter x 3 3⁄16”
CF Cargo series 1987-91 D2AZ-19834-A RD-5-5656-0P 73R7000
width
Red Dot A/C, double entry, dual rotation, 5 1⁄4” diameter x 3
L Series with Red Dot A/C unit R-8720 1987-91 RDH RD3 2557 2 RD-3-2557-2P 73R7151
3⁄4” width
Kysor KA700 Unit (backwall unit), dual rotation, 4 1⁄2”
L Series with Kysor KA700 backwall unit 1980-96 360480 RD-5-10346-0P 73R7130
diameter, 3 3⁄8” width
PAGE 102
Ford
BLOWER WHEEL
L Series with Kysor Class Six A/C 1980-91 260680 RD-5-5656-0P 73R7000
width
CLUTCH ASSEMBLY
Aerostar, 3.0L, 4.0L with Nippondenso
1992-95 Nippondenso, FX15 compressor, poly 7 groove, 4 1⁄2” diameter RD-5-10359-0P 75R4762
FX15 compressor
1991-93 Nippondenso FX15 compressor, poly 6 groove, 5” diameter RD-5-10357-0P 75R4742
FX15 compressor
1986-90 Nippondenso FS6 compressor, 6 groove, 4 7⁄8” diameter RD-5-10401-0P 75R4702
FS6 compressor
B Series, 5.9L engine with Sanden 7H15
1992-96 Sanden 7H15 compressor, Poly 8 groove, 4.9” (125mm) RD-5-10361-0P 75R1432
compressor
B Series, 7.0-7.8L engine with Sanden
1992-96 Sanden 7H15 compressor, 2 groove, 1⁄2” width, 5 1⁄4” (132mm) RD-5-10761-0P 75R1852
7H15 compressor
B600-700 Series with Sanden SD510
1991-93 Sanden SD510 compressor, 2 groove, 1⁄2” width, 4.9” (125mm) RD-5-10362-0P 75R1522
compressor, 2 groove
B600-700 Series with Nippondenso FS6 Nippondenso FS6 compressor, 2 groove, 7⁄16” width, 6”
1986-88 RD-5-10354-0P 75R4712
compressor diameter
Bronco II, Ranger with Nippondenso Nippondenso FS10-FX15 compressor, poly 6 groove, 5 9⁄16”
1992-96 RD-5-10358-0P 75R4752
FS10-FX15 compressor with 2.3L engine diameter
Bronco II, Ranger with FX15 compressor
1992-96 Nippondenso FX15 compressor, poly 6 groove, 5” diameter RD-5-10357-0P 75R4742
with 3.0L, 4.0L engines
Bronco II, Ranger with Nippondenso FS6 Nippondenso FS6, 6E171, 6P148 compressor, poly 6 groove, 4
1984-86 RD-5-10401-0P 75R4702
compressor with 2.3L engine 7⁄8” diameter
Bronco II, Ranger with Nippondenso FS6
1983-86 Nippondenso FS6 compressor, poly 6 groove, 5 7⁄8” diameter RD-5-9657-0P 75R4732
compressor with 2.9L engine
C, CL, CLT, CT with Sanden SD5 Sanden SD5 compressor with 2 groove, 1⁄2” width, 5 1⁄4”
1989-93 RD-5-5486-0P 75R0202
compressor (132mm)
C, CL, CLT 9000 with Sanden SD5
1989-93 Sanden SD510 compressor, 2 groove, 1⁄2” width, 4.9” (125mm) RD-5-10362-0P 75R1522
compressor
C, CL, CLT, CT 9000, 4.9L engines with Nippondenso FS6 compressor, 2 groove, 7⁄16” width, 6”
1984-90 RD-5-10354-0P 75R4712
Nippondenso FS-6 compressor diameter
CF Cargo series, 5.9L engines with
1992-96 Sanden 7H15 compressor, poly 8 groove, 4.9” (125mm) F4HZ-19D786A RD-5-10361-0P 75R1432
Sanden 7H15 compressor
CF Cargo series, 7.0L, 7.8L engines with
1992-96 Sanden 7H15 compressor, 2 groove, 1⁄2” width, 132mm F4HZ-19D786C RD-5-10761-0P 75R1852
Sanden 7H15 compressor
CF Cargo series 1986-92 All with Ford Engine & Sanden compressor F1HZ-19D786 RD-5-10355-0P 75R4722
CF Cargo series 1986-88 All with Ford Nippondenso FS-6 compressor E3LY-19D786 RD-5-4966-0P 75R0302
CF 600-800 Cargo series with FNH
1989-91 All models with Sanden compressor (SD510) 2 groove RD-5-5486-0P 75R0202
engine
CF 600-800 Cargo series, 6.9L, 7.3L 1988-91 All models with FS6 Nippondenso compressor with 1 groove RD-5-10355-0P 75R4722
CF 600-800 Cargo series 1986-87 All with FS6 Nippondenso compressor with Ford add-on A/C RD-5-10354-0P 75R4712
E150-350, 4.9L, 5.0L, 5.8L, 7.5L engines 1987-93 FS6 Nippondenso compressor, poly 6 RD-5-10401-0P 75R4702
E150-350, 4.9L, 5.0L, 5.8L, 7.5L engines 1983-86 FS6 Nippondenso compressor, 1 groove RD-5-10355-0P 75R4722
E150-350, 5.0L, 5.8L, 6.9L 1983-87 FS6 Nippondenso compressor, 1 groove RD-5-10356-0P 75R4732
E150-350, 6.9L, 7.5L 1983-85 FS6 Nippondenso compressor RD-5-10355-0P 75R4722
E150-350, 7.3L engines 1991-94 FS6 Nippondenso compressor, 1 groove RD-5-10356-0P 75R4732
F150-350, 2.0L, 2.3L diesel 1983-86 FS6 Nippondenso compressor RD-5-10401-0P 75R4702
F150-350, 2.8L, 4.9L , 5.0L, 5.8L 1984-87 FS6 Nippondenso compressor RD-5-10356-0P 75R4732
F150-350, 3.8L 1982-83 FS6 Nippondenso compressor RD-5-10401-0P 75R4702
F150-350, 4.2L, 4.6L, 5.4L 1997-99 FX15 Nippondenso compressor with 21S RD-5-10357-0P 75R4742
F150-350, 4.9L 1996-97 FX15 Nippondenso compressor with 21S RD-5-10357-0P 75R4742
F150-350, 4.9L 1982-88 FS6 Nippondenso compressor with single groove RD-5-10355-0P 75R4722
F150-350, 4.9L , 5.8L 1990-92 FX15 Nippondenso compressor with 21S RD-5-10358-0P 75R4752
PAGE 103
Ford
CLUTCH ASSEMBLY
F150-350, 4.9L, 7.5L 1989-96 FX15 Nippondenso compressor with 21S RD-5-10358-0P 75R4752
F150-350, 5.0L 1987-88 FS6 Nippondenso compressor with poly groove RD-5-10401-0P 75R4702
F150-350, 5.0L, 5.8L 1982-86 FS6 Nippondenso compressor RD-5-9657-0P 75R4732
F150-350, 5.8L 1989 FX15 Nippondenso compressor with 21S RD-5-10357-0P 75R4742
F150-350, 5.8L 1988 FS6 Nippondenso compressor with poly groove RD-5-10401-0P 75R4702
F150-350, 6.9L, 7.3L 1983-87 FS6 Nippondenso compressor RD-5-10355-0P 75R4722
F150-350, 6.9L, 7.5L 1982-87 FS6 Nippondenso compressor with single groove RD-5-10355-0P 75R4722
F150-500, 4.9L, 5.0L, 5.8L, 7.5L 1988-89 FS6 Nippondenso compressor with poly groove RD-5-10401-0P 75R4702
All with Nippondenso FS6 compressor with Cat 6 cylinder 8
F, FT600-1100 1984-87 RD-5-10354-0P 75R4712
cyl 3208 with tilt nose
F600-1100 1980-85 All with CCI, Tecumseh compressor 515528, MA-N06D RD-5-10397-0P 75R1342
Sanden SD7H15 compressor with Poly 8 Clutch, Ford
L Series 1996-00 RD-5-10361-0P 75R1432
Conventional
L Series 1996-00 RD-5-10360-0P 75R1512
Conventional
L Series 1996-00 N/A RD-5-10379-0P 75R1542
Conventional
Sanden SD508 compressor with Poly 8 Clutch, Ford
L Series 1991-95 N/A RD-5-10362-0P 75R1522
Conventional
L Series 1988-95 Sanden SD5 compressor, factory A/C F0HZ-19D786A RD-5-10368-0P 75R1532
L Series, C, CL, CLT, CT 1984-91 All models with FS6 Nippondenso compressor RD-5-10354-0P 75R4712
All with FS6 Nippondenso compressor with CAT, L10,
L Series 1984-91 RD-5-10354-0P 75R4712
CUMMINS with 2 groove
L, LN, LNT, LT Series, 7.0L-14.6L 1994-96 Sanden SD7H15 compressor, 2 groove, F4HZ-19D786C RD-5-10761-0P 75R1852
L, LN Series 1992-93 Sanden SD7H15 compressor, poly 8 F4HZ-19D786A RD-5-10361-0P 75R1432
L, LN, LNT, LT, LTS 800 Series, 5.9L 1974-85 Tecumseh compressor with Caterpillar diesel RD-5-9798-0P 75R1222
L, LN, LNT, LT, LTS 800-900 Series 1973-85 Tecumseh compressor with Cummins diesel 515528, MA-N06D RD-5-10397-0P 75R1342
L, LN, LNT, LT, LTS 800-900 Series 1970-85 Tecumseh compressor with 8 cyl gas engines RD-5-9798-0P 75R1222
COMPRESSOR - CCI / YORK / TECUMSEH
All models with Rotolock Head without
Rotolock Head, LH Suction without clutch, (universal - new) 99242-5 RD-5-8637-1P 75R7280
clutch, OE# 99242-5
All models with Tube O-Ring
compressors without clutch, OE# Tube O-Ring type head without clutch, (universal - new) 99244-5 RD-5-8638-1P 75R7290
99244-5
compressors without clutch, OE# Rotolock Head, LH Suction without clutch, (universal - new) ER210L-25149 RD-5-8637-1P 75R7280
ER210L-25149
compressors without clutch, OE# CCI Super Heavy Duty with Tube-O fittings (#10 O-Ring) ET210L-25150 RD-5-8061-1P 75R7295
ET210L-25150
E150-350 with Tube O-Ring compressors
1969-85 CCI Super Heavy Duty with Tube-O fittings (#10 O-Ring) D4FZ-19703B RD-5-8061-1P 75R7295
without clutch, OE# D4FZ-19703B
Explorer with FX15 compressor, OE#
1991-98 FX15 Nippondenso compressor without clutch, 21 spline F6DZ-19703AA RD-5-10372-0P 75R8916
F6DZ-19703AA
PAGE 104
Ford
F150-350 with Rotolock Head without Universal-new CCI/York Rotolock LH Suction, (repl ER-
1963-79 C9AZ-19703B RD-5-8637-1P 75R7280
clutch, OE# C9AZ-19703B 210L-25149)
F150-500 with Tube O LH suction,
1970-84 Tube O-Ring type head without clutch, (universal - new) D4FZ-19703B RD-5-8638-1P 75R7290
without clutch, OE# D4FZ-19703B
F600-900 York Tube O LH suction,
1971-84 CCI Super Heavty Duty with Tube-O fittings (#10 O-Ring) D4FZ19703B RD-5-8061-1P 75R7295
without clutch, OE# D4FZ19703B
School bus Chassis, Tecumseh Tube-O ET210L-21160, 25061,
1980-85 Tube O-Ring type head without clutch, (universal - new) RD-5-8638-1P 75R7290
compressor 25150C
COMPRESSOR - GM
C/CL/CLT/CT 9000 with A6 compressor,
1978-85 GM A6, 1 groove, 1⁄2” width, 4 7⁄8” diameter (124mm), generic D8HZ-19703B RD-5-5000-0P 75R8102
OE# D8HZ-19703B
COMPRESSOR - NIPPONDENSO
All models with FS6 compressor, OE#
Ford Nippondenso FS6 ear mount compressor without clutch E7TZ-19703B RD-5-10371-0P 75R8906
E7TZ-19703B
All models with FS6 compressor, OE#
FS6 Nippondenso direct mount compressor without clutch E7VY-19703A RD-5-10373-0P 75R8918
E7VY-19703A
All models with FX15 compressor, OE#
FX15 Nippondenso compressor without clutch, 21 spline F6DZ-19703AA RD-5-10372-0P 75R8916
F6DZ-19703AA
Aerostar with FX15 compressor, OE#
F6DZ-19703AA
Aerostar, 3.0L FS6 compressor, OE#
1986-87 FS6 Nippondenso ear mount, poly 6, 4 7⁄8” (123.8mm) E45Z-19V703K RD-5-10312-0P 75R8907
E45Z-19V703K
Aerostar, 3.0L with FS6 compressor, OE#
1986-87 Ford Nippondenso FS6 ear mount compressor without clutch E7TZ-19703B RD-5-10371-0P 75R8906
E7TZ-19703B
1986-90 FS6 Nippondenso direct mount compressor without clutch E7VY-19703A RD-5-10373-0P 75R8918
E7VY-19703A
1986-90 FS6 Nippondenso direct mount, poly 6, 4 7⁄8” (123.8mm) E8DZ-19V703N RD-5-10316-0P 75R8917
E8DZ-19V703N
B Series with FX15 compressor, OE#
F1SZ-19703B, F3SZ-19703A,
F1SZ-19703B, F3SZ-19703A, F77Z- 1989 FX15 Nippondenso compressor without clutch, 21 spline RD-5-10372-0P 75R8916
F77Z-19703AB
19703AB
B Series, 3.0L with FS6 compressor, OE#
1986-88 Ford Nippondenso FS6 ear mount compressor without clutch E6VY-19703A RD-5-10371-0P 75R8906
E6VY-19703A
6 cyl appl., FS6 Nippondenso compressor assembly 5 7⁄8”, 1
Bronco II with FS6 compressor 1983-88 RD-5-10315-0P 75R8910
groove
4 cyl appl., FS6 Nippondenso ear mount compressor assembly
Bronco II with FS6 compressor 1986-87 RD-5-10312-0P 75R8907
poly 6
Bronco II with FS6 compressor, OE# 4 cyl appl., FS6 Nippondenso ear mount compressor without
1983-92 E7TZ-19703B RD-5-10371-0P 75R8906
E7TZ-19703B clutch
Bronco II, 2.3L with FX15 compressor,
OE# F6DZ-19703AA
Bronco II, 2.9L with FS6 compressor 1989-92 FS6 Nippondenso compressor assembly 5 7⁄8”, 1 groove RD-5-10315-0P 75R8910
C/CL/CLT 9000 with FS6 compressor, OE#
1985-88 FS6 Nippondenso ear mount compressor without clutch E6VY-19703A RD-5-10371-0P 75R8906
E6VY-19703A
CF 600-800 with FS6 compressor, OE#
1985-88 FS6 Nippondenso ear mount compressor without clutch E7GZ-19703B RD-5-10371-0P 75R8906
E7GZ-19703B
E150-350 with FS6 compressor, OE#
1982-87 FS6 Nippondenso ear mount compressor without clutch E2LY-19703A RD-5-10371-0P 75R8906
E2LY-19703A
1982-87 FS6 Nippondenso ear mount compressor without clutch E2LY-19703A RD-5-10371-0P 75R8906
E2LY-19703A
1987-93 FS6 Nippondenso direct mount compressor without clutch E7VY-19703A RD-5-10373-0P 75R8918
E7VY-19703A
1987-93 FS6 direct mount compressor without clutch E7VY-19703A RD-5-10373-0P 75R8918
E7VY-19703A
PAGE 105
Ford
COMPRESSOR - NIPPONDENSO
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L with FS6 Nippondenso direct mount, 6 groove, 4 7⁄8” (124mm)
1987-93 E8DZ-19V703N RD-5-10316-0P 75R8917
FS6 compressor, OE# E8DZ-19V703N compressor assy
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L
with FX15 compressor, OE# F1SZ-19703B, 1989-99 FX15 Nippondenso compressor without clutch, 21 spline F1SZ-19703B, F3SZ19703A RD-5-10372-0P 75R8916
F3SZ19703A
E150-350, 4.9L, 6.9L, 7.5L with FS6 FS6 Nippondenso ear mount compressor assembly 5 7⁄8”, 1
1983-86 RD-5-10314-0P 75R8909
compressor groove, 7⁄8” gauge line
E150-350, 5.0L, 5.8L, 6.9L with FS6 FS6 Nippondenso compressor assembly 5 7⁄8”, 1 groove, 1 3⁄8”
1983-87 RD-5-10315-0P 75R8910
compressor gauge line
E150-350, 5.0L, 5.8L, 7.5L with FS6
1987-88 FS6 ear mount compressor RD-5-10312-0P 75R8907
compressor
FS6 Nippondenso ear mount compressor assembly 5 7⁄8”, 1
E150-350, 7.3L with FS6 compressor 1988-92 RD-5-10314-0P 75R8909
groove, 7⁄8” gauge line
F, FT600-800 Tilt with FS6 compressor,
1986-88 FS6 Nippondenso ear mount compressor without clutch E4VY-19703A, E6VY-19703A RD-5-10371-0P 75R8906
OE# E4VY-19703A, E6VY-19703A
FS6 Nippondenso ear mount compressor, poly 6 clutch-
F150-350, 3.8L with FS6 compressor 1982-83 RD-5-10312-0P 75R8907
serpentine belt
F150-350, 4.9L, 5.0L, 5.8L, 6.9L, 7.3L Grooved belt, 7.5L with FS6 Nippondenso ear mount
1983-91 RD-5-10314-0P 75R8909
with FS6 compressor compressor
F150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L with FS6 Nippondenso ear mount compressor, poly 6 clutch-
1988-91 RD-5-10312-0P 75R8907
FS6 compressor serpentine belt
F150-350, 4.9L, 5.0L, 5.8L, 7.5L with
FX15 compressor, OE# F1SZ-19703B, 1989-96 FX15 Nippondenso compressor without clutch, 21 spline F1SZ-19703B, F3SZ-19703A RD-5-10372-0P 75R8916
F3SZ-19703A
F150-500, 4.9L, 5.8L with FS6
1984-87 FS6 Nippondenso compressor assembly 5 7⁄8”, 1 groove RD-5-10315-0P 75R8910
compressor
FS6 Nippondenso ear mount compressor assembly 5 7⁄8”, 1
F150-500, 7.3L with FS6 compressor 1988-91 RD-5-10314-0P 75R8909
groove, 7⁄8” gauge line
Ranger, 2.3L with FX15 compressor, OE#
F6DZ-19703AA
Ranger, 2.9L with FS6 compressor. 1989-92 FS6 Nippondenso compressor assembly 5 7⁄8”, 1 groove RD-5-10315-0P 75R8910
Ranger, 4 cylinder with FS6 compressor 1986-87 FS6 Nippondenso ear mount compressor assembly poly 6 RD-5-10312-0P 75R8907
Ranger, 4 cylinder with FS6 compressor,
1983-92 FS6 Nippondenso ear mount compressor without clutch E7TZ-19703B RD-5-10371-0P 75R8906
OE# E7TZ-19703B
Ranger, 6 cylinder with FS6 compressor 1983-88 FS6 Nippondenso compressor assembly 5 7⁄8”, 1 groove RD-5-10315-0P 75R8910
Windstar, Villager with FX15
compressor, OE# F6DZ-19703AA
COMPRESSOR - SANDEN
B Series with Sanden 7H15, # 4474, Sanden SD7H15, WH head, direct mount, poly 8, 4.7”
1992-96 F2HZ-19703A RD-5-11245-0P 75R81252
7804. OE# F2HZ-19703A (119mm)
B Series, 5.9L with Sanden 7H15, # 7804. Sanden 7H15 WH head, direct mount, poly 8 groove, 4.7”
1992-96 F4HT-19D629AA RD-5-11245-0P 75R81252
OE# F4HT-19D629AA (119mm)
B Series, 5.9L, 8.3L with Sanden 7H15, # Sanden 7H15 WH head, direct mount, 1A groove, 6
1992-96 F4HT-19D629BA RD-5-11242-0P 75R81202
4602. OE# F4HT-19D629BA 1⁄2”(169mm)
B Series, 8.3L with Sanden 7H15, #
1992-96 Sanden 7H15, WJ head, ear mount, 2A groove, 5 1⁄4” (132mm) F4HT-19D629CA RD-5-11241-0P 75R81192
4603. OE# F4HT-19D629CA
CF 600-800, 5.9L, 8.3L with Sanden
1992-96 Sanden 7H15 compressor (7804), Poly 8 Clutch F4HT-19D629AA RD-5-11245-0P 75R81252
7H15, # 7804. OE# F4HT-19D629AA
CF 600-800, 5.9L, 8.3L with Sanden
1992-96 Sanden 7H15 compressor (4602), 1 groove, clutch F4HT-19D629BA RD-5-11242-0P 75R81202
7H15, # 4602. OE# F4HT-19D629BA
CF 600-800, 8.3L with Sanden 7H15, #
1992-96 Sanden 7H15, WJ head, ear mount, 2A groove, 5 1⁄4” (132mm) F4HT-19D629CA RD-5-11241-0P 75R81192
4603. OE# F4HT-19D629CA
CF 600-800, FNH engine Sanden 510 Sanden 510 R-12 compressor , FG head, ear mount, 2 groove,
1989-93 9120 RD-5-5443-0P 75R8212
R-12 compressor, Sanden OE# 9120 clutch
PAGE 106
Ford
COMPRESSOR - SANDEN
CF 600-800, FNH engine, Sanden 510, Sanden 510, 709 R-12 compressor , FC head, ear mount, 2
1989-93 E93Z-19703B RD-5-6625-0P 75R8412
709 R-12 compressor, OE# E93Z-19703B groove, 4.9” (125mm)
F, FT600-800 with Sanden 7H15, Sanden
1992-96 Sanden 7H15 compressor (4602), 1 groove, clutch F4HT-19D629BA, 4602 RD-5-11242-0P 75R81202
# 4602, OE# F4HT-19D629BA
F, FT600-800 with Sanden 7H15, Sanden
1994-96 Sanden 7H15, WH head, direct mount poly 8, 4.7” (119mm) F4HT-19D629AA, 7804 RD-5-11245-0P 75R81252
# 7804, OE# F4HT-19D629AA
F, FT600-800. Sanden 510, 709 R-12 Sanden 510, 709 R-12 compressor , FC head, ear mount, 2
1989 E7GZ-19703B, 7409 RD-5-6625-0P 75R8412
compressor, #7409, OE# E93Z-19703B groove, 4.9” (125mm)
F, FT600-900 with FNH engine, Sanden Sanden 508, FG head, ear mount, 1 goove overhang clutch,
1989-90 E9HZ-19703A, 9514 RD-5-5684-0P 75R8342
508, Sanden #9514, OE#E9HZ-19703A 4 3⁄4”
F150-350 with Sanden 7H15, Sanden #
1999-02 Sanden 4704, SJ head, ear mt, 2 groove, (132mm) XC3H-19D629AB RD-5-10261-0P 75R84132
4704, OE# XC3H-19D629AB
F150-350 with Sanden 7H15, Sanden
1999-02 Sanden 7H15, MJA head, direct mount poly 8, 4.7” (119mm) 4885 RD-5-11249-0P 75R81282
OE# 4885
F350-800 with Sanden 508, Sanden
1988-90 Sanden 508 compressor (5415) with 10 gr clutch (FLX-7 repl) 5415 RD-5-11004-0P 75R89332
OE# 5415
F600-900 with Sanden 7H15, Sanden
1999-2003 Sanden 7H15, MJA head, direct mount poly 8, 4.7” (119mm) 4885 RD-5-11249-0P 75R81282
# 4885
L Series with Sanden 5H14, Sanden #
1993-94 Sanden 5H14HD, with 2 goove clutch 4510 RD-5-7088-0P 75R8382
4510
L Series with Sanden 7H15SHD, Sanden
1993-94 Sanden 7H15SHD, ear mt . with 2 goove clutch 4617 RD-5-10291-0P 75R84532
# 4617
L Series with Sanden 7H15SHD, Sanden All models with Sanden 7H15SHD (4637) compressor with8
1993-95 4637 RD-5-10446-0P 75R84712
# 4637 groove, Clutch
L, LA 800, LL, LS, LT, LTL, LTS, LN, LNT
with FNH engine, Sanden 508, #9514, 1989-91 Sanden 508, with 1 goove overhang clutch, FNH engine, E9HZ-19703A, 9514 RD-5-5684-0P 75R8342
OE# E9HZ-19703A
COMPRESSOR, HEAD ADAPTER
F350-800 1988-90 Sanden 508 compressor (5415) with 10 gr clutch (FLX-7 repl) RD-5-10881-0P 75R89310
CONDENSER
AEROSTAR 1996-97 All models F69Z-19712AA RD-4-5685-0P 77R1403
AEROSTAR 1990-95 All models F49Z-19712A RD-4-5684-0P 77R1401
CF Cargo series 1988 Rear Facing Inlet Fitting & 6 Holes in Mounting Plate E8HZ-19712-A RD-4-5146-1P 77R0570
C/CL/CLT/CT 1990-93 All models with Factory Air E0HZ19712D RD-4-5681-0P 77R5240
E150-350 1997-99 All models withFactory Air withR134A F7UZ-19712A RD-4-5686-0P 77R1405
F150-350 1997-00 All F150⁄250 under 8500 GVW, Models with factory air F65Z-19712AB RD-4-5688-0P 77R1409
F150-350 1997-98 All F250 with 8500 GVW, F350 F6TZ-19712BA RD-4-5687-0P 77R1407
F150-350 1994-96 Models with factory air (inlet #8, outlet #6) F4TZ-19712D RD-4-5687-0P 77R1407
F600-900 1999 All F800 with FNH Diesel with fixed hood F5HZ-19712CA RD-4-5689-0P 77R1411
F600-900, 5.9L 1999 All F800 with 5.9L (160, 175 & 190 hp) withTilt Hood F5HZ-19712B RD-4-5692-0P 77R1417
F600-900 1997-98 All F700⁄800, FT900 withFNH Diesel with fixed hood F5HZ-19712CA RD-4-5689-0P 77R1411
F600-900, FT900 1995-1999 All F700⁄800, FT900 with gas engine F5HZ-19712C RD-4-5693-0P 77R1419
F600-900, 5.9L, 8.3L engines 1995-1999 5.9L (210, 230 hp), 8.3L with tilt hood F5HZ-19712E RD-4-5684-0P 77R1421
F600-900 1995-98 All F700⁄800, FT900 with diesel engine & conventional hood F5HZ-19712A RD-4-6591-0P 77R1415
F600-900 1995-99 All F700⁄800, FT900 with5.9L (160, 175, & 190 HP) with tilt hood F5HZ-19712B RD-4-5696-0P 77R6807
F600-900 1993-94 All F600⁄800 with FD1460 diesel with tilt hood F0HZ-19712A RD-4-5680-0P 77R0850
F600-900 1992-94 All F600⁄800 withFNH Diesel withFD1060 Diesel with tilt hood F0HZ-19712A RD-4-5680-0P 77R0850
F600-900 1992-94 All F600⁄800 withFNH Diesel with fixed hood F5HZ-19712CA RD-4-5689-0P 77R1411
F600-900 1990-94 FNH Engine with tilt front end F0HZ-19712A RD-4-5680-0P 77R0850
F600-900 1990-94 All F600⁄800, FT900 with gas engine F0HZ-19712E RD-4-5682-0P 77R0860
F5HZ-19712DA, F0HZ-
F, FT600-900 1990-92 All with fixed front end RD-4-5680-0P 77R0850
19712B
PAGE 107
Ford
CONDENSER
F, FT600-800 1980-86 All without tilt front end E0HZ-19712A RD-4-5680-0P 77R0850
L, LT, LLT Series 1996-2000 All with factory air F6HZ-19712A RD-4-5696-0P 77R6807
L, LN, LNT, LT, LTS Series 1994-97 All models with factory air without E# (Exc. Below) F4HZ-19712A RD-4-5695-0P 77R6805
L Series 1991-96 All L Series Models except Aeromax RD-4-3372-3P 77R6800
LL, LLS, LTL, LTLS with Cummins L10,
1991-92 All with diesel engines F2HZ--19712A RD-4-5683-0P 77R5245
N14, NTC and Ford FNH
L, LN Series, Cat engine, 3306, 3406,
1991-93 All models withSpringlock Fitting F1HZ-19712A RD-4-5683-0P 77R5245
3176
ELECTRICAL SWITCH
Lever switch, all models with LH Control, 4 position, 4
C/CL/CLT/CT 1987-90 D5AZ-19986A RD-5-10196-0P 71R0487
terminal
Lever Control Switch, main control, left side (4 position lever
CL, CLT 9000 1978-90 D5AZ-19986A RD-5-10443-0P 71R0487
switch)
E, F150-350 1968-72 Blower lever switch, single pole, 4 position, 5 terminals D0HZ-19986A RD-5-10188-0P 71R0485
L Series 1978-91 Blower lever switch, single pole, 4 position, 5 terminals D0HZ-19986A RD-5-10188-0P 71R0485
EVAPORATOR
CF Cargo series 1986-92 Main unit assembly R-9715 E6HZ-19860-A RD-2-2928-0P 76R6040
F150-350 1987-93 All models with Factory Air E7TZ-19860A RD-2-3828-0P 77R7507
F600-900 1987-93 All F600⁄800, FT900 Models withFactory Air E7TZ-19860A RD-2-3828-0P 77R7507
L/LN/LNT/LT 1994-97 All models with Factory Air, Red Dot Models R-8725 F4HZ-19860A RD-5-7847-0P 76R7505
L Series 1987-90 All models with Red Dot Air RD215550 RD-2-1555-0P 76R7500
ALL 1970-93 Block expansion valve, 1 1⁄2 Ton E1HZ-19849-A RD-5-6868-0P 71R8301
CF 600-800 Cargo series 1989-91 Factory A/C, F.N.H. Engine E1HZ-19849-A RD-5-6868-0P 71R8301
CF 600-800 Cargo series 1986-88 Add-On A/C, Ford aftermarket E1HZ-19849-A RD-5-6868-0P 71R8301
CF Cargo series 1992-94 Main unit, Block valve, 1 1⁄2 Ton, plate mounted F3HZ-19849-A RD-5-7179-0P 71R8420
CF Cargo series 1986-91 Main unit, block valve with schrader port, 2 Ton E6HZ-19849-A RD-5-8936-0P 71R8430
CL/CLT/CLT 9000/CT 1978-87 All models withSleeper, Block valve (9000) C80Z19849A RD-5-6868-0P 71R8301
L, LL, LLS, LN, LNT, LT, LTL, LTLS, LTS C80Z-19849A, E1HZ-
1970-93 Main unit, Block valve, 1 1⁄2 ton, female O-Ring RD-5-6868-0P 71R8301
Series 19849-A
EXPANSION VALVE / INTERNAL EQUALIZER
E150-350 1971-99 All models with Aux A/C-Rear, internal equilized Exp Valve D5UZ-19949A RD-5-10445-0P 71R8220
F2DZ-19D990A, F5DZ-
Aerostar 1990-97 Main unit, Orange tube, blue orifice with green HBNR RD-5-10011-0P 71R8504
19D990AA, AB
Aerostar 1986-97 Auxiliary unit, Brown orifice F39Z-19D990A RD-5-10013-0P 71R8506
E0VY-19D990A, E1FZ-
Bronco II 1994-2001 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3XY-19D990A
E69Z-19D990A, F54Z-
Bronco II 1987-2011 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990AB
E0VY-19D990A, E1FZ-
Bronco II 1982-86 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3XY-19D990A
E0VY-19D990A, E1FZ-
CF Cargo series 1991-93 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3XY-19D990A
E69Z-19D990A, F4UZ-
CF Cargo series 1987-90 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990A, F54Z-19D990AB
E0VY-19D990A, E1FZ-
CF Cargo series 1980-86 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3SY-19D990A
D8TZ-19D990A, E59H-
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1992-2006 Main unit, Red orifice tube 19D990AA, E69Z-19D990A, RD-5-9564-0P 71R8505
F54Z-19D990AB
PAGE 108
Ford
E8TZ, E8UZ-19D990A, F2DZ-
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1988-91 Main unit, Orange tube, blue orifice with green HBNR 19D990A, F5DZ-19D990AA, RD-5-10011-0P 71R8504
AB, E92H-19D990A
E69Z-19D990A, F4UZ-
Expedition, Explorer, Excursion 1997-2005 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990A, F54Z-19D990AB
E0VY-19D990A, E1FZ-
Explorer 1994-95 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3XY-19D990A
E69Z-19D990A, F4UZ-
Explorer 1990-93 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990A, F54Z-19D990AB
E69Z-19D990A, F4UZ-
F150-900, Super Duty 5.8L, 7.3L, 7.5L 1994-2010 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990A, F54Z-19D990AB
1997-2005; E0VY-19D990A, E1FZ-
F150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
1991-93 19D990A, F3XY-19D990A
E69Z-19D990A, F4UZ-
F150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1986-97 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990A, F54Z-19D990AB
E0VY-19D990A, E1FZ-
F150-800, 5.0L, 5.8L, 6.9L, 7.3L, 7.5L 1980-92 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3XY-19D990A
L, LL, LLS, LN, LNT, LT, LTL, LTLS, LTS 1999; 1994- E69Z-19D990A, F4UZ-
Main unit, Red orifice tube RD-5-9564-0P 71R8505
Series 95 19D990A, F54Z-19D990AB
L, LL, LLS, LN, LNT, LT, LTL, LTLS, LTS E0VY-19D990A, E1FZ-
1988-97 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
Series 19D990A, F3XY-19D990A
E69Z-19D990A, F4UZ-
Villager, Windstar 1994-2000 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19D990A, F54Z-19D990AB
E8TZ, E8UZ-19D990-A,
F2DZ-19D990A, F5DZ-
Villager, Windstar 1994-1999 Main unit, Orange tube, blue orifice with green HBNR RD-5-10011-0P 71R8504
19D990AA, AB, E92H-
19D990A
E0VY-19D990A, E1FZ-
Villager, Windstar 1993-1999 Main unit, Blue orifice tube with green HBNR RD-5-9807-0P 71R8503
19D990A, F3XY-19D990A
HEATER CORE
L Series 1987-91 All models with R8720 Red Dot A/C Unit RD106800 RD-1-0680-0P 76R3900
PRESSURE SWITCH
F3AH-19E561AA, F3AZ-
Aerostar 1994-97 Accumulator Cycling R-134A Switch, opens 46psi RD-5-10442-0P 71R6093
19E561A
E0VY19E561A, E1FZ-A,
E1VY-A, E2DZ-A, B, E2FZ-A,
Aerostar 1983-93 Accumulator Cycling R-12 Switch, closes 46 psi RD-5-8026-0P 71R6095
E2TZ-B, E1VY-19618-B,
E3DY-A, E35Y19E561A
Bronco II 1997-2000 Accumulator Cycling R-134A Switch F5VY-19E561A RD-5-10443-0P 71R6255
F3AH--19E561AA, F3AZ--
Bronco II 1994-96 Accumulator Cycling R-134A Switch, opens 46psi RD-5-10442-0P 71R6093
19E561A
E0VY-19E561A, E1FZ-A,
Bronco II 1983-93 Accumulator Cycling R-12 Switch, closes 46 psi RD-5-8026-0P 71R6095
E2TZ-B, E1VY--19618-B,
E3DY-A, E35Y-19E561A
CF Cargo series 1992-99 Low Pressure Cut-Out (withR134a System) F4HZ-19E561 RD-5-8219-0P 71R6170
CF Cargo series 1986-92 Low Pressure Cut-Out (withR12 System) E7D7-19E561 RD-5-8026-0P 71R6095
F5VY19E561A, F6RZ-
E150-350 1997-2010 All models OVER 8500 GVW 19E561AA, 95BW- RD-5-10443-0P 71R6255
19E561AA
E150-350 1986-97 All models with Accumulator cycling switch. (M12 THREAD) F3AZ-19E561A RD-5-10442-0P 71R6093
E0VY19E561A, E1FZ-A,
E150-350 1980-93 All models with Accumulator cycling switch. RD-5-8026-0P 71R6095
E2TZ-B, E1VY-19618-B,
E3DY-A
PAGE 109
Ford
PRESSURE SWITCH
F150-350 1997-00 All models OVER 8500 GVW F5VY-19E561A RD-5-10443-0P 71R6255
F150-350 1997-94 All F250/350 OVER 8500 GVW; F53 Stripped Chassis F3AZ-19E561A RD-5-10442-0P 71R6093
F150-350 1986-93 All models with Accumulator cycling switch. RD-5-8026-0P 71R6095
E2TZ-B, E1VY--19618-B,
F150-800 1986-96 All models with Accumulator cycling switch. (M12 THREAD) F3AZ-19E561A RD-5-10442-0P 71R6093
E2TZ-B, E1VY--19618-B,
F150-550SD 1999-2011 All F250, 350, 450, 550 Super Duty F6RZ-19E561AA RD-5-10444-0P 71R6257
F600-900 1999-00 All F800 Models with Accumulator cycling switch. F3AZ-19E561A RD-5-10442-0P 71R6093
F600-900 1995-98 All F700/800, FT 900 Models withACC. Cycling SW. F3AZ-19E561A RD-5-10442-0P 71R6093
E2TZ-B, E1VY--19618-B,
L Series 1994-97 Accumulator Cycling R-134A Switch, opens 46psi RD-5-10442-0P 71R6093
19E561A
E2HT14806A, E0VY-
19E561A, E1FZ-A, E1VY-A,
L Series 1980-93 All models with Accumulator cycling switch. E2DZ-A, B, E2FZ-A, E2TZ-B, RD-5-8026-0P 71R6095
E1VY--19618-B, E3DY-A,
E35Y-19E561A
Windstar, Villager 1994-97 Accumulator Cycling R-134A Switch, opens 46psi RD-5-10442-0P 71R6093
19E561A
Windstar, Villager 1983-93 Accumulator Cycling R-12 Switch, closes 46 psi RD-5-8026-0P 71R6095
E2TZ-B, E1VY--19618-B,
RECEIVER DRIER
C/CL/CLT/CT 1990-94 All models with Drier F0HZ-19959BA RD-5-10450-0P 74R3140
CF 600-800 Cargo series 1989-91 All with drier and factory air, F.N.H. engine E7HT-19959CA RD-5-6422-0P 74R3316
L Series 1988-91 Models with Receiver Drier, Caterpillar 3406 engine EDE8HT-19959CA RD-5-6422-0P 74R3316
L Series 1988-91 Models with Receiver Drier, Cummins L-10 engine E8HZ-19959B RD-5-6422-0P 74R3316
L Series 1988-91 Models with Receiver Drier, Cummins NTC 444 engine F0HZ-19959A RD-5-6422-0P 74R3316
L Series 1991-93 All models with Receiver Drier E7HZ-19959C RD-5-6422-0P 74R3316
L Series 1984-92 All models with Receiver Drier, Male #6 O Ring with bracket F2HZ-19959A, F4HZ-19959G RD-5-6422-0P 74R3316
L Series, LTS 800-900 1987-90 All models with Receiver Drier, FTO Diesel E7HZ-19959A RD-5-10450-0P 74R3140
L Series, LTS 800-900 1973-82 Models with Receiver Drier and roof mounted condenser D3HZ-19959A RD-5-3843-0P 74R2556
Aerostar 1994-97 All Front A/C with Accumulator without Auxiliary Unit F49Z-19C836C RD-5-10458-0P 74R5073
Aerostar 1994-97 All with Accumulator with Auxiliary Unit F49Z-19C836D RD-5-10453-0P 74R5063
Aerostar 1994-97 All with Accumulator with Auxiliary Unit F39Z-19C836A RD-5-10451-0P 74R5055
Aerostar 1986-93 All with Accumulator without Auxiliary Unit E69Z-19C836A RD-5-10452-0P 74R5057
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1997-00 All models with out Auxiliary Unit F7UZ--19C836AB RD-5-10459-0P 74R5075
2C2Z-19C836BA, F7UZ-
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1997-99 All models with Auxiliary Unit RD-5-10461-0P 74R5079
19C836BB
F4UZ-19C836A, F6UZ-
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1994-96 Models with Accumulator with R134A, #10 springlock RD-5-10455-0P 74R5067
19C836AA
F2UZ-19C836A, F3DZ-
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1992-93 Models with Accumulator with R12 Port, #10 springlock RD-5-10454-0P 74R5065
19C836A
PAGE 110
Ford
Explorer, Expedition 1997 All models under 8500 GVW with Accumulator F75Z-19C836BA RD-5-10462-0P 74R5081
F150-350, 4.2L 2000-03 All F150 Models with4.2L with Accumulator XL3Z-19C836AA RD-5-10463-0P 74R5083
F150-350, 4.2, 5.4L 1999 All F150/250 Models Under 8500 GVW with Accumulator XL3Z-19C836BA RD-5-10465-0P 74R5087
XL3Z-19C836BA, F75Z-
F150-350, 4.6L, 5.4L 2000-2003 All F150/250 Models Under 8500 GVW with Accumulator RD-5-10462-0P 74R5081
19C836BA
F150-350, 4.6L, 5.4L 1998 All F150/250 Models Under 8500 GVW with Accumulator F85Z-19C836AB RD-5-10467-0P 74R5091
F150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1997-98 All models with Accumulator without Auxiliary A/C Unit F7UZ-19C836AB RD-5-10459-0P 74R5075
All Super Duty Models with Auxiliary A/C Unit with
F150-350 1997 F7UZ-19C836BB RD-5-10461-0P 74R5079
Accumulator
All F150/250 Models under 8500 GVW, FROM 3/17/97 with
F150-350 1997 F75Z-19C836AA RD-5-10460-0P 74R5077
Accumulator
All F150/250 Models under 8500 GVW, up to 3/17/97 with
F150-350 1997 F75Z-19C836BA RD-5-10462-0P 74R5081
Accumulator
F150-350 1997 All includes F250 with 8500 GVW & F350 Models with Accumulator
F6TZ-19C836AA RD-5-10464-0P 74R5085
F150-350 1994-95 All models with Accumulator F0TZ-19C836A RD-5-10464-0P 74R5085
E3TZ-19C836B, E7TZ-
F150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1983-94 All models with Accumulator RD-5-10453-0P 74R5063
19C836A
F250-550 1999-2006 All F250,350,450 & 550 Super Duty Models F81Z-19C836AA RD-5-10466-0P 74R5089
F0TZ-19C836A, F6HZ-
F700-900, FT900 1995-99 All models with Accumulator , male insert o- rings RD-5-10464-0P 74R5085
19C836BA
Accumulator with 134A charge port and pressure switch port, F6HH-19E647AA, F6HZ-
FT600-800 Diesel 1995-96 RD-5-11546-0P 74R5095
inlet 5⁄8” (#10), outlet 3⁄4” (#12) 19C836A
F600-900 1983-94 All models with Accumulator E7TZ-19C836A RD-5-10453-0P 74R5063
L Series 1998-01 All models with Accumulator XL3Z-19C836AA RD-5-10463-0P 74R5083
XL3Z-19C836BA, F75Z-
L Series 1998-99 All models with Accumulator RD-5-10462-0P 74R5081
19C836BA
Accumulator with 134A charge port and pressure switch port,
L Series 1996-99 F7HH-19E647AB RD-5-11546-0P 74R5095
inlet 5⁄8” (#10), outlet 3⁄4” (#12)
RELAY
All with Auxillary Heater, Compressor Relay, Bosch type (30
E150-350, 4.9L, 5.0L, 5.8L, 7.3L, 7.5L 1992-98 RD-5-4408-0P 71R1702
amp), SPST, 5 terminals
RESISTOR
CF Cargo series 1986-92 Blower Speed (with White Blower Wheels) E6HZ-19A706 RD-5-9916-0P 71R1460
CARGO 1987-97 Blower Resistor (with Kysor A/C), 3 terminal, 3 speed 220990 RD-5-10441-0P 71R1463
THERMOSTATIC SWITCH
CARGO 1989-93 All models with Factory Air with cable operated thermostat E7HZ-19618AA RD-4226-0P 71R2700
CARGO 1987-93 All models with Kysor A/C with preset thermostat D3DZ-19681-A RD-5-4531-24 71R3200
CF 600-800 Cargo series 1989-91 Ford A/C, F.N.H. engine E7HZ-19618AA RD-4226-0P 71R2700
CF 600-800 Cargo series 1987-91 Kysor A/C D3DZ-19681-A RD-5-4531-24P 71R3200
CL, CLT 9000 1978-89 All with factory A/C 9533N508 RD-4125-66P 71R2400
L Series 1970-91 All models with KA700 wall mount unit with Rotary SW. 404028 RD-4125-36 71R2250
L Series 1970-97 All models DOHZ-19618A RD-4226-0P 71R2700
F150-550 1968-72 All models with factory air with rotary switch DOTZ-19618A RD-5-4909-0P 71R2100
C8TZ-19618-A, DOHZ-
F150-550 1968-72 All models with factory air with cable RD-4226-0P 71R2700
19618A
WATER VALVE
All models with cable operated valve, straight (pull to open),
F150-350 1973-79 C3UZ-18495A RD-5-4923-0P 72R5040
5⁄8” to 5⁄8” hose
PAGE 111
FREIGHTLINER
AIR VALVES, SWITCH
All with Red Dot air cylinder valve Single action air cylinder 3⁄4” diameter, 3 1⁄4” length RDH RD3267 1 RD-3267-1P 72R1100
All with Red Dot air operated control
Toggle switch with 90 degree air fitting, 1⁄4” in, 1⁄8” out RDH RD5 4721 0 RD-5-4721-0P 72R0610
switch
All with Red Dot air operated control
Toggle switch with nickel plated toggle RDH RD5 3827 2 RD-5-3827-2P 72R0220
switch
BLOWER MOTOR
A/C and heater 7 7⁄8” flange motor, CW, vented, shaft length ABP N83 301020, XC4H-
All, Main unit 1998-00 RD-5-11579-0P 73R3072
1 1⁄2” 19805-AA
BOA 85-462-50-009
Century Class C112, C120, Columbia 2002-06 Auxillary Unit (front with blend air), plate mount, 7” diameter RD-5-10393-0P 73R3022
2809-841-036
BOA-85-462-5000-900
Century Class C112, C120, Columbia 2002-05 Main unit with blower assembly, plate mount, 7 3⁄16” diameter RD-5-11488-0P 73R3052
2809-850-053
Behr Sleeper unit, blower assembly, single speed, 13 3⁄4” x 5 BOA-80-414-00-149, 2809-
Century Class C112, C120, Columbia 1996-99 RD-5-8948-0P 73R5562
1⁄8” 820-016
Century Class C112, C120, Columbia 1994-04 Main unit (Assembly), plate mount, 7 3⁄16” diameter BOA 80 415 00 789 RD-5-10501-0P 73R3062
ABP N83 301137
Main unit (Assembly), plate mounted, 7” diameter, CW, 1
Century Class C112, C120, Columbia 1994 -01 BOA85-440-50-009 RD-5-11466-0P 73R3002
speed, 4 3⁄4” length
HA1870
Blower motor with Red Dot unit R-3911-H, 1 speed, 3 1⁄4”
Century, Columbia Sleeper Unit 1975-82 - RD-5-10390-0P 73R0212
diameter blower motor, CW or CCW
Blower motor with Red Dot units, 1 speed, 3 1⁄4” diameter
Century, Columbia Sleeper Unit 1975-88 HA1035 RD-5-10390-0P 73R0212
blower motor, CW or CCW
Classic XL, (FLD) Conventional with
2006-07 Sleeper cab motor, single shaft with brackets 2808-841-036M RD-5-8255-0P 73R0982
Sleeper Cab
FL50, FL60, FL70, FL80, FL106, FL112 1994-01 Main unit (Assembly), plate mount, 7” diameter - RD-5-10393-0P 73R3022
FL50, FL60, FL70, FLB, FLL 1994-04 BOA-85-440-50-009 RD-5-11466-0P 73R3002
FLA 1989-93 BOA-85-440-50-009 RD-5-11466-0P 73R3002
ABP N83 301057, BOA-85-
FLA 1989-93 Main unit (Red Dot Assembly R-4290) RD-3-5182-0P RD-3-5182-0P
415-00-429
FLA, FLC, FLD 1989-93 BOA-85-440-50-009 RD-5-11466-0P 73R3002
FLB, FLL 1994-99 Main unit (Assembly), plate mount, 7” diameter - RD-5-10393-0P 73R3022
FLC, FLD 1978-88 Main unit, single shaft, 4 11⁄16”, CW, shaft length 1 9⁄16” A22-21403-001 RD-5-10392-0P 73R0232
A22-29923-000
FLC, FLD, FLT 1989-93 Main unit, single shaft, 4 7⁄8”, CCW, shaft length 1 1⁄2” PF2666Q RD-5-8016-0P 73R0662
A22-29923-000
Main unit (Red Dot), single shaft, CCW, 12V, 5” length, 3⁄4” A22-21403-001
FLC, FLD, FLT 1978-88 RD-5-6526-2P 73R0352
shaft HA1060
FLC, FLT 1989-93 Main unit, single shaft, CCW, 12V, 5” length, 3⁄4” shaft A22-21403-001 RD-5-6526-2P 73R0352
FLD 1978-86 Main unit (Assembly), motor only - single shaft, 4 1⁄2” length - RD-5-6531-0P 73R0322
FLD 112, FLD 120, Classic XL 1991-01 BOA-85-440-50-009 RD-5-11466-0P 73R3002
Auxillary Unit (water valve control), single shaft, plate mount,
FLD 112, FLD 120, Coronado 2002-2010 BOA-85-462-50-009 RD-5-10393-0P 73R3022
7” diameter
FLD Classic XL, Conventional with
2006-07 Sleeper cab motor, single shaft with brackets 2808-841-036M RD-5-8255-0P 73R0982
Sleeper Cab
with Behr Sleeper Unit, single shaft, plate mount, 7”
FLN, FLT 1991-99 BOA 85-462-50-009 RD-5-10393-0P 73R3022
diameter
A22-21016, A22-29923-
FLP, FLT 1989-92 Main unit, single shaft , CCW, 12V, 4 7⁄8”, shaft length 1 1⁄2” RD-5-8016-0P 73R0662
000, PF2666Q
ABP N83 301057, BOA-85-
FLS 1989-97 Main unit (Red Dot Assembly R-4290) RD-3-5182-0P RD-3-5182-0P
415-00-429
PAGE 112
FREIGHTLINER
BLOWER MOTOR
Main unit (Auxiliary Heater), 12V, 2 speed single shaft, 3 5⁄8”
FLT 1976-88 RDH RD5 6440 0 RD-5-6440-0P 73R0062
length
Main unit (Auxiliary Heater), 24V, 2 speed single shaft, 3 5⁄8”
2807-406-048
FLT 1976-88 RD-5-10491-24P 73R0034
length HA1715
BOA94350
Sleeper Unit 2002-10 Front and Aux w/Blend air system RD-5-13067-0P 73R3122
BOAD8587
Auxillary Unit (front with blend air), plate mounted 7” BOA 85-462-50-009
Sleeper Unit 2002-06 RD-5-10393-0P 73R3022
diameter, CCW 2809-841-036
Behr Auxillary Unit (with water valve), plate mount, 7 3⁄16” ABP N83 301327, 2809-
diameter 841-036
Behr Sleeper Unit, blower assembly, single speed, 13 3⁄4” x BOA-80-414-00-179, RDH
5 1⁄8” RD5 8948 0
Sleeper Unit 1989-97 Red Dot Sleeper Unit R-4190, single shaft, CCW, 4 3⁄4” length RDH RD5 8204 0 RD-5-8204-0P 73R0432
RDH RD5 6531 0
Sleeper Unit 1989-97 Red Dot Sleeper Unit R-4290, single shaft, CCW, 4 1⁄2” length 289-540-022 RD-5-6531-0P 73R0322
HA1050
Sleeper Unit 1989-96 Sleeper with Booster Fan - RD-5-10378-0P 73R5582
Sleeper Unit 1975-82 Blower motor, single speed, CCW, NV, Sleeper Unit - RD-5-10394-0P 73R0002
Sleeper Unit 1975-80 Blower motor, single speed, CCW, NV, Sleeper Unit RDH RD3106 18 RD-3106-18P 73R0202
HA1120
MVA1-3291
WFC, WFT Conventional 1974-80 Main unit (with Single Shaft), single shaft, 4 1⁄4” length RD-3106-13P 73R0602
2807-517-019
A22-18014
XL, FLD Conventional with Sleeper Cab 2006-07 Sleeper cab motor, single shaft with brackets 2808-841-036M RD-5-8255-0P 73R0982
BLOWER RELAY
All 1974-00 Bosch type (30 amp), SPST, 5 terminals A22-011101-022 RD-5-4408-0P 71R1702
All 1974-00 Bosch type (40 amp) with diode, SPST, 5 terminals RD-5-9915-0P 71R1722
BLOWER RESISTOR
RDH RD5 3647 0,
All 1990-06 Red Dot speed control resistor, 3 terminal, 3 speed RD-5-3647-0P 71R1450
ABP N83 321060
RDH RD6 4797 0,
All 1990-06 Red Dot 12V CTC circuit control blower speed thermistor kit. RD-6-4797-0P 71R3502
ABP N83 322925
C Series, Century Class C112, C120, BOA-80-926-00-079,
1996-00 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
Columbia ABP N83 321350
FL50, FL60, FL70, FL80, FL106, FL112, BOA-80-926-00-079,
1994-01 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
FFL, FLB ABP N83 321350
BOA-80-926-00-079,
FLD112, FLD120, Classic XL 1991-02 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
ABP N83 321350
BOA-80-926-00-079,
FLP Series 1989-92 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
ABP N83 321350
BOA-80-926-00-079,
Sleeper Units (Behr) 1999-02 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
ABP N83 321350
BOA-80-926-00-079,
W Series 1988-96 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
ABP N83 321350
BLOWER SWITCH
All with rotary switch All Rotary switch, 3 speed, DP3T, 4 position, 5 terminal INM2G754A RD-5-5194-0P 71R1210
All with toggle switch All Toggle switch, SPST, 2 terminal RD-5-3748-0P 71R0010
All with toggle switch All Toggle switch, SPDT, 3 terminal, On-off-on A06-11454-001 RD-4123-1P 71R0100
FL50, FL60, FL70, FL80, FL106, FL112 1994-01 Toggle switch, DP3T, 4 position, 4 terminal BOA-80-926-00-059 RD-5-3779-0P 71R1165
FLB, FLL, FLD112, FLD120, Classic XL 1991-99 Micro Switch, DPDT A06-14889-001 RD-5-10590-0P 71R1620
FLB, FLL 1991-99 Auxiliary fan toggle switch, SPDT, 3 terminal, On-off-on A06-11454-001 RD-4123-1P 71R0100
FLB, FLL, FLD112, FLD120, FL50 - FL112,
1993-00 Rotary switch, DP3T, 3 speed, short shaft thread BOA-80-926-00-059 RD-5-9833-0P 71R1160
Classic XL
PAGE 113
FREIGHTLINER
BLOWER SWITCH
FLB, FLL, FLD112, FLD120, Classic XL 1991-99 Auxiliary fan rotary switch, DP3T, 3 speed, long shaft thread MVA1-9253 RD-5-3646-0P 71R1150
FLD112, FLD120, Classic XL 1999-01 Rotary switch, DP3T, 3 speed, long shaft thread BOA-80-926-00-109 RD-5-3646-0P 71R1150
FLD112, FLD120, Classic XL 1991-99 Toggle switch, DP3T, 4 position, 5 terminal A06-14889-001 RD-5-3646-0P 71R1150
FLD112, FLD120, Classic XL 1991-99 Micro Switch, DPDT, 8 amp A06-14889-001 RD-5-10590-0P 71R1620
BOA-80-908-00-219,
FLD112, FLD120, Classic XL 1991-93 Micro Switch, SPDT, 15 amp RD-5-8490-0P 71R1610
ABP N83 322020
BLOWER WHEEL
All incl. Red Dot sleeper Unit (R4190-0) 1989-97 Single entry wheel(plastic), CCW, 5 3⁄4” diameter RDH RD5 5601 0 RD-5-5601-0P 73R6370
All incl. Red Dot sleeper Unit (R4290-0) 1975-97 Single entry wheel (steel), CCW, 5 1⁄4” diameter RDH RD3106 14 RD-3106-39P 73R6151
All with Red Dot sleeper Unit 1975-88 Single entry wheel (steel), CCW, 5 1⁄4” diameter RDH RD3106 14 RD-3106-39P 73R6151
FLC, FLT, WFC, FLC 1989-93 Main unit A22-14366-000 RD-5-3933-1P 73R7101
Red Dot A/C Unit 1974-78 Main unit, Single entry wheel (steel), CCW, 5 1⁄4” diameter RD-5-8618-0P 73R6051
CLUTCH ASSEMBLY
Fits CCI/York - R12/134A compressors 1 groove, 6 3⁄4” dia pulley, 1⁄2” width, weatherpak plug 024 21942, ABP N83 303051 RD-5-4966-0P 75R0302
1 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 3 1⁄8” gauge line, 03-1104968, 03-1104978,
Fits CCI/York - R12/134A compressors RD-5-4980-0P 75R2402
bullet plug 502740
1 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 1 3⁄4” gauge line, A22-22499, L50-2731,
bullet plug ABP N83 303071
1 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 2 3⁄4” gauge line,
Fits CCI/York - R12/134A compressors A22-11671-000, 502393 RD-5-4984-0P 75R3002
bullet plug
Fits CCI/York - R12/134A compressors A22-11669, 502736 RD-5-4981-0P 75R2552
bullet plug
1 groove, 6 3⁄4” diameter pulley, 3⁄4” width, 2 3⁄4” gauge line, 03-1105003, 502745,
bullet plug L50-2745
1 groove, 7 1⁄4” diameter pulley, 3⁄4” width, 2” gauge line, A22-10761, 502400,
bullet plug L50-2400
2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line, 024 25238,
metripak plug ABP N83 303063T
2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line, 03-1104973, 501215,
bullet plug 518521
2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line, 024 25190, 03-1104973,
weatherpak plug 501939
2 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 2 1⁄4” gauge line, A22-10795, A22-22498,
FitsCCI/York - R12/134A compressors RD-5-10370-0P 75R3502
IHC plug MA N01
2 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line, A22-22498-000,
bullet plug ABP N83 303102
2 groove, 7” diameter pulley, 12V, 1⁄2” width, 2” gauge line, ABP N83 303012, 332334,
bullet plug MA 7A
2 groove, 7” diameter pulley, 24V, 1⁄2” width, 2” gauge line,
FitsCCI/York - R12/134A compressors ABP N83 303342, 501075 RD-5-8382-0P 75R4534
bullet plug
024 25144,
Fits CCI/York - R12/134A compressors Poly 6 groove, 5 3⁄4” dia groove, far forward, metripak plug RD-5-10364-0P 75R0512
ABP N83 303287
FitsCCI/York - R12/134A compressors Poly 6 groove, 5 7⁄8” dia groove, far forward, metripak plug 024 25244 RD-5-10363-0P 75R0502
024 25241, MAE MG07,
FitsCCI/York - R12/134A compressors Poly 6 groove, 5 7⁄8” diameter pulley, metripak plug RD-5-10366-0P 75R0522
ABP N83 303187
024 25078,
Fits CCI/York - R12/134A compressors Poly 6 groove, 6 1⁄8” diameter pulley, IHC plug RD-5-8009-0P 75R0612
ABP N83 303007, 513352
ABP N83 303307,
Fits CCI/York - R12/134A compressors Poly 8 groove, 5 3⁄8” diameter pulley, IHC plug RD-5-9802-0P 75R0662
ABP N83 303017
024 25247,
Fits CCI/York - R12/134A compressors Poly 8 groove, 6 1⁄8” diameter pulley, metripak plug RD-5-10365-0P 75R0682
ABP N83 303123T
Fits Sanden SD508, 510, 514 R-12 1 groove, 6 1⁄4” 158mm diameter pulley, variable width, bullet
6521-6010, 6565-6210 RD-5-5489-0P 75R1402
compressors plug
PAGE 114
FREIGHTLINER
CLUTCH ASSEMBLY
2 groove, 4.9” 125mm diameter pulley, 1⁄2” width, metripak
Fits Sanden 7H15HD compressors 4740-9931, 6593-6010 RD-5-10368-0P 75R1532
plug
Fits Sanden SD508, 510, 514 R-12 6514-6210, 6519-6010,
2 groove, 5 1⁄4” (132mm) diameter pulley, 1⁄2” width, 1 wire RD-5-5486-0P 75R0202
compressors 6575-6310
Fits Sanden 709, 7H15HD compressors Poly 6 groove, 4.7” 119mm diameter pulley, bullet plug 6524-6010 RD-5-10398-0P 75R0032
Fits Sanden 7H15HD compressors Poly 8 groove, 4.9” 125mm dia groove 6593-6010 RD-5-10361-0P 75R1432
Fits Seltec CH, Diesel Kiki, Zexel TM15 2 groove, 5 21⁄64” 135mm diameter pulley, 1⁄2” width, bullet
A22-19726-001 RD-5-6996-0P 75R0222
compressors plug
1 groove, 4.9” 125mm dia groove, overhang, 1⁄2” width, bullet
Fits Seltec CH, TM15 compressors 511869, ABP N83 303261 RD-5-6646-0P 75R0182
plug
2 groove, 5 21⁄64” 135mm diameter pulley, 1⁄2” width, bullet
Fits Seltec CH, TM15 compressors 2570151, 624-19724 RD-5-11025-0P 75R0172
plug
CCI/York - C112 Century with DDAD 55 (OE new replacement) Tube O-Ring with LH suction, 8 groove,
1999-00 ET210L-25246C RD-5-11219-0P 75R7332
series (12.0L eng, ) Tube O-Ring 6 1⁄8” diameter, 2 wire clutch
CCI/York - C112 Century with DDAD 55 (OE new replacement) Tube O-Ring head with LH suction, 2
1997-98 ET210L-25237C RD-5-11218-0P 75R7322
series (12.0L eng, ) Tube O-Ring groove, 2 wire clutch
CCI/York - C120 Century with Cat C12 (OE new replacement) Tube O-Ring with LH suction, 8 groove,
1999-00 ET210L-25246C RD-5-11219-0P 75R7332
eng, Tube O-Ring 6 1⁄8” diameter, 2 wire clutch
CCI/York - C120 Century, Classic XL, FLD
Tube O-Ring type head with 2 groove, 1 wire clutch (OE
120 with DDAD 60 series and 12.7L eng, 1996-98 ET210L-25073C RD-5-11217-0P 75R7312
replacement - new)
Tube O-Ring with LH suction
CCI/York - FL60CFE with Cummins 5.9L Tube O-Ring type head with LH suction, 2 groove, 1 wire
1997-99 ET210L-25073C RD-5-11217-0P 75R7312
eng, Tube O-Ring clutch (OE replacement - new)
CCI/York - FLD 120, Classic XL with Cat Tube O-Ring with LH suction, 8 groove, 6 1⁄8” diameter, 2 wire
1996-98 ET210L-25246C RD-5-11219-0P 75R7332
3406E eng, Tube O-Ring clutch
CCI/York - FLD 120SD, Classic XL with
M 11 Cummins series eng, Tube O-Ring 1997-98 ET210L-25073C RD-5-11217-0P 75R7312
replacement - new)
with LH suction
CCI/York - Rotolock Head, R12/134A
Rotolock Head, LH Suction without clutch, (universal - new) ER210L-25149 RD-5-8637-1P 75R7280
without clutch
CCI/York - Slimline head compressor Slimline head with flange fitting without charge ports with
2001-03 ES210L-25334C RD-5-10029-0P 75R7300
without clutch ester oil
CCI/York - Tube O-Ring compressors,
Tube O-Ring type head without clutch, (universal - new) ET210L-25150 RD-5-8638-1P 75R7290
R12/134A without clutch
COMPRESSOR - SANDEN
Sanden 7H15, #4417 fits M2 Daycab 7H15, GH head, direct mount, poly 8 groove, 4.7”(119mm)
2006-07 4417, ABP N83 304783 RD-5-11251-0P 75R81302
business class, model MM106042S diameter
Sanden 7H15, #4417 fits Mer 906LA/ 7H15, GH head, direct mount, poly 8 groove, 4.7”(119mm)
4417, ABP N83 304783 RD-5-11251-0P 75R81302
Series 60 Century class diameter
Sanden 7H15, #4421 fits Mer 906LA/ 7H15, MJA head, ear mount, poly 8 groove, 4.7”(119mm)
4421, ABP N83 304793 RD-5-11249-0P 75R81282
Series 60 Century class diameter
Sanden 7H15, #4428 fits Cummins appl. 7H15, KCA head, direct Mount, 2 groove, 5 1⁄4” (132mm)
4428, ABP N83 304503 RD-5-10737-0P 75R84632
with Dual Compressor diameter
Sanden 7H15, #4429 fits ISB, ISC, N14
7H15, GH head, ear mount, 2 groove, 5 1⁄4”(132mm) diameter 4429, ABP N83 304803 RD-5-11243-0P 75R81212
with R134a compressor with PAG oil
Sanden 7H15, #4430 fits C10/12 ISM, ISX
7H15, GH head, direct mount, poly 6 4.9”(125mm) diameter 4430, ABP N38 304813 RD-5-11244-0P 75R81232
with 3406E Cat engine
Sanden 7H15, #4431 fits Cat 3126, Mer 7H15, MJA head, ear mount, poly 8 groove, 4.7”(119mm)
4431, 22-47692-000 RD-5-11247-0P 75R81262
366 with R134a compressor diameter
Sanden 7H15, #4453, 4495 fits Mer366, 7H15, GV head, ear mount, poly 8 groove, 4.7”(119mm)
22-59342-000 RD-5-11258-0P 75R81382
Cum C - R134a compressor with PAG oil diameter
Sanden 7H15, #4471, fits Mer 366, IHC 7H15, MJA head, ear mount, 2 groove, 5 1⁄4”(132mm) diameter 4471, 22-47691-000 RD-5-10263-0P 75R84172
Sanden 7H15, #4475 fits S55 with R134a
7H15, CBA head, direct mt, poly 6, 4.9”(125mm) diameter 4475, 22-47693-000 RD-5-10266-0P 75R84212
compressor with PAG oil
PAGE 115
FREIGHTLINER
COMPRESSOR - SANDEN
Sanden 7H15, #4485 fits ISB, ISC, Mer
7H15, GH head, direct mt, poly 6, 4.7”(119mm) diameter 4485, ABP N83 304903 RD-5-11251-0P 75R81302
906LA/Ser 60 Cent class, N14 engine
Sanden 7H15, #4488 C 8.3, M11, S60
7H15, JDA head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4488, 22-47690-000 RD-5-10264-0P 75R84182
Sanden 7H15, #4491 fits S60, R134a
7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter 4491, 22-47694-000 RD-5-10265-0P 75R84192
Sanden 7H15, #4492 fits ISX, Argosy
7H15, MDA head, direct mt, poly 6, 4.9”(125mm) diameter 4492, 22-48437-000 RD-5-11254-0P 75R81352
R134a compressor with PAG oil
Sanden 7H15HD, #4617 fits S-60 series 7H15HD, MD head, ear mount, 2 groove, 5 1⁄4”(132mm)
4617, ABP N83 304303 RD-5-10291-0P 75R84532
with R134a compressor with PAG oil diameter
Sanden 7H15, #4626 fits S-60, Cum ISC -
7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter 4626, ABP N83 304095 RD-5-7522-0P 75R8432
Sanden 7H15, #4644 R134a compressor
7H15, JD head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4644, ABP N83 304363 RD-5-10297-0P 75R84612
with PAG oil
Sanden 7H15, #4646 fits Cummins C
7H15, MJA head, ear mount, 2 groove, 5 1⁄4”(132mm) diameter 4646, 22-41180-000 RD-5-11315-0P 75R81462
series eng, Mer 366
Sanden 7H15, #4647 Mtr Home, C 8.3
4647, 22-41179-000, 22-
engines with R134a compressor with 7H15, JDA head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter RD-5-11316-0P 75R81472
59344-000
PAG oil
Sanden 7H15, #4672 fits Cat C3126, Mer 7H15, MJA head, ear mount, poly 8 groove, 4.7”(119mm)
4672, 22-43374-000 RD-5-11328-0P 75R81512
336 engines diameter
Sanden 7H15, #4687 fits S55 with R134a 7H15HD, CBA head, direct mt, poly 6, 4.9”(125mm) diameter,
4687, 22-44462-000 RD-5-10303-0P 75R84152
compressor with PAG oil S55.
Sanden 7H15 #4709, fits Motor Home -
7H15, KG head, ear mount, 2A groove, 4.9”(125mm) diameter 4709, 22-59343-000 RD-5-11331-0P 75R81552
Sanden 7H15, #4734 fits Cat 3126 7H15, MJA head, ear mount, poly 8 groove, 4.7”(119mm)
4734, 22-47692-000 RD-5-10262-0P 75R84162
Engine, Mer 366 engines diameter
Sanden 7H15, #4735 fits Mer 366, IHC 7H15, MJA head, ear mount, 2 groove, 5 1⁄4”(132mm) diameter 4735, 22-47691-000 RD-5-10263-0P 75R84172
Sanden 7H15, #4736 C 8.3, M11, S60
7H15, JDA head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4736, 22-47690-000 RD-5-10264-0P 75R84182
Sanden 7H15, #4752 fits S60, R134a
7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter 4752, 22-47694-000 RD-5-10265-0P 75R84192
Sanden 7H15, #4756 fits S55 with R134a
7H15, CBA head, direct mt, poly 6, 4.9”(125mm) diameter 4756, 22-47693-000 RD-5-10266-0P 75R84212
Sanden 7H15, #4761 fits ISX, Argosy
7H15, MDA head, direct mt, poly 6, 4.9”(125mm) diameter 4761, 22-48437-000 RD-5-11254-0P 75R81352
Sanden 7H15, #4776 fits Mer 906LA/Ser 7H15, MJA head, direct mt, poly 8 groove, 4.7”(119mm)
4776, ABP N83 304113 RD-5-10267-0P 75R84232
60 Cent class diameter
Sanden 7H15, #4818 fits Century S/T
Sleeper, ISB, ISC with Detroit S-60 2000-08 709, GH head, direct mt, poly 8, 4.7”(119mm) diameter 4818, ABP N83 304903 RD-5-11251-0P 75R81302
engine
Sanden 7H15, #4818 fits ISB, ISC, Mer
709, GH head, direct mt, poly 8, 4.7”(119mm) diameter 4818, ABP N83 304903 RD-5-11251-0P 75R81302
906LA/Ser 60 Century class, N14 engine
Sanden 7H15, #4819 fits Century,
Columbia C10, 12, ISM, ISX Cummins, Cat 2000-2004 709, GH head, direct mt, poly 6, 4.9”(125mm) diameter 4819, ABP N83 304903 RD-5-11339-0P 75R81602
3406E engine
Sanden 7H15, #4820 fits S 60, Cum ISC, 7H15, GH head, ear mount, poly 8 groove, 4.7”(119mm)
4820, ABP N83 304913 RD-5-11340-0P 75R81612
Cat 3126 engine - R134a compressor diameter
Sanden 7H15, #4821 fits S 60, Cum ISC -
7H15, GH head, ear mount, 2 groove, 5 1⁄4”(132mm) diameter 4821, ABP N83 304133 RD-5-10269-0P 75R84262
Sanden 7H15, #7822 fits Cat 210-250 - 7H15, MD head, ear mount, poly 8 groove, 4.7”(119mm)
7822, ABP N83 304343 RD-5-10296-0P 75R84582
R134a compressor with PAG oil diameter
Sanden SD510, #9120 R-12 Compressor
SD510, FG head, ear mount, 2 groove, 5 1⁄4” (132mm) diameter 9120, ABP N83 304272 RD-5-5443-0P 75R8212
with mineral oil and charge port
PAGE 116
FREIGHTLINER
COMPRESSOR - SANDEN
RD-5-11012-0P 74R89292
Sanden 508, #9285 R-12 compressor with with
FLX replacement, 2 groove, 5 1⁄4”(132mm) diameter 9285
with charge ports, mineral oil RD-5-10881-0P 75R89310
adapter adapter
Sanden 508, #9514 R-12 compressor
with charge ports, mineral oil
COMPRESSOR - ICE SELTEC
ICE/Seltec / Diesel Kiki #488-25011 - R12
TM15CH, F head, ear mount, 2 groove, 5 1⁄4” (135mm) 488-25011,
Compressor with mineral oil/ with RD-5-5876-1P 75R8512Q
diameter with ports ABP N83 304019
charge ports
ICE/Seltec / Diesel Kiki #488-25063 -
TM15CH, F head, ear mount, 1 groove, 5” (125mm) diameter 488-25063,
R12 Compressor with mineral oil/ with RD-5-5875-1P 75R8502Q
without ports ABP N83 304029
charging ports
ICE/Seltec TM15 # 488-45011 - R134a
TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) without 488-45011,
Compressor with PAG OIL, no charge RD-5-7145-1P 75R8612Q
ports ABP N83 304025
ports
ICE/Seltec TM15 # 488-45063 - R134a TM15CH, D head, ear mount, 1 groove, 5” (125mm) diameter 488-45063,
RD-5-8944-1P 75R8532Q
Compressor with PAG OIL without ports ABP N83 304039
ICE/Seltec TM15 # 488-45065 - R134a TM15CH, D head, ear mount, 1 groove, 6 1⁄4” (159mm) 488-45065,
RD-5-7164-1P 75R8632Q
Compressor with PAG OIL diameter without ports ABP N83 304015
ICE/Seltec TM15 # 488-45077 - R134a
TM15BH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) without 488-45077,
ports ABP N83 304059
ports
CONDENSER
Century, Columbia Class S/T- Sleeper 1E 6068, BHT 92710, BHT
2000-08 Tube & Fin with slim line fittings RD-4-6432-0P 77R6977
Series with Detroit S-60 series engine 73002
Century, Columbia Class - Sleeper Series 1E 6068, BHT 92710, BHT
2000-04 Tube & Fin with slim line fittings RD-4-6432-0P 77R6977
with Cummins ISX 450 engine 73002
1E 6068, BHT 92710, BHT
C112, C120, Century, Columbia, Coronado 2000-05 Tube & Fin with slim line fittings RD-4-6432-0P 77R6977
73002
FLD Series, Classic XL, Coronado 2004 Radiator mount, tube & fin style with slim line fittings 1E6854, BHT79465 RD-4-6432-0P 77R6977
WFC, WFT Series 1970-85 Radiator Mount, Red Dot unit RDH RD4 3874 1 RD-4-3874-1P 77R0500
WFC, WFT Series All Radiator Mount, Red Dot unit RDH RD4 3724 0 RD-4-3724-0P 77R0650
ELECTRICAL SWITCH
All with rotary switch All Rotary switch, 3 speed, DP3T, 4 position, 5 terminal INM2G754A RD-5-5194-0P 71R1210
All with toggle switch All Toggle switch, SPST, 2 terminal A06-11454-001 RD-5-3748-0P 71R0010
FLD112, FLD120, Classic XL 1991-99 Blower, Micro Switch A06-14889-001 RD-5-10590-0P 71R1620
BOA-80-908-00-219,
FLD112, FLD120, Classic XL 1991-93 Blower, Micro Switch RD-5-8490-0P 71R1610
ABP N83 322020
Auxiliary blower fan rotary switch, DP3T, 3 speed, long shaft
FLD120, FLD112, CLASSIC XL 1991-2010 A06-14889-001 RD-5-3646-0P 71R1150
threaded
FLD120, FLD112, CLASSIC XL 1991-99 Heater Sleeper Switch INM 6G754A RD-5-9833-0P 71R1160
FL50, FL60, FL70, FL80, FL106, FL112 1994-01 Blower Switch BOA-80-926-00-059 RD-5-3779-0P 71R1165
FL50, FL60, FL70, FL80, FL106, FL112 1993-00 Clutch, Micro Switch BOA-80-908-00-219 RD-5-8490-0P 71R1610
Auxiliary blower fan rotary switch, DP3T, 3 speed, long shaft
FLB, FLL 1994-99 A06-14889-001 RD-5-3646-0P 71R1150
thread
FLB, FLL 1994-99 Aux Heater Switch INM 6G754A RD-5-9833-0P 71R1160
FL50, FL60, FL70, FL80, FL106, FL112 1994-99 Micro Switch BOA-80-908-00-219
Century Class C120, C112 1997-99 Aux Fan Switch INM-6G754A RD-5-9833-0P 71R1160
EVAPORATOR
All with Red Dot sleeper unit (R-4190-0) 1989-97 Sleeper Unit (R4190-0) RDH RD2 1402 0 RD-2-1402-0P 76R6150
All with Red Dot sleeper Unit (R-4290-
1989-97 Sleeper Unit (R4290-0) RDH RD2 1660 0 RD-2-1660-0P 76R6120
0)
PAGE 117
FREIGHTLINER
Evaporator
All with Red Dot sleeper units (R-3911,
1975-87 Sleeper Unit (R3911, R4060) RDH RD2 1137 5 RD-2-1137-5P 76R6110
R-4060)
FLD112, FLD120 1994-04 Main unit with Red Dot evaporator RDH RD2 1402 0, NA1040 RD-2-1402-0P 76R6150
BOA-80-375-00-569,
FLD112, FLD120, CLASSIC XL 1989-01 Main unit with Behr evaporator RD-2-4074-0P 76R7515
MVA1-9248
FLB, FLL, FL50, FL60, FL70, FL80, FL106,
1994-01 Main unit with Behr evaporator BOA-80-374-00-439 RD-2-4054-0P 76R7040
FL112
FLB, FLL 1989-01 Main unit BOA-80-375-00-569 RD-2-4074-0P 76R7515
C112, C120, Century, Century ST,
2000-08 Auxiliary Unit (Mini Stat O Seal), gold color BOA 80 321 00 269 RD-5-12520-0P 71R8453
Columbia, Coronado
C112, C120, Century, Century ST,
2000-04 Main Unit (Mini Stat O Seal), gold color BOA 80 321 00 269 RD-5-12520-0P 71R8453
Columbia, Coronado
C112, C120, Century, Columbia, Coronado 2001-07 Main unit, (Stat Seal), Behr valve BOA 4965 RD-5-12521-0P 71R8455
C112, C120, Century, Columbia, Coronado 2000-06 Main unit, (Slim line seal), gold color ABP N83 308231 RD-5-10903-0P 71R8451
C112, C120, Century, Columbia, Coronado 2002-07 Auxiliary Unit, (Stat Seal), Behr valve, burgundy color BOA 93674 RD-5-12522-0P 71R8457
A22-45432-000,
C112, C120 1996-00 Main unit, Hi - capacity (2 ton) RD-5-7015-0P 71R8321
ABP N83 308071
C112, C120, Century Class 1996-00 Main unit A22-45432-000 RD-5-7567-0P 71R8370
Century;Columbia; Coronodo 2001-07 Main unit, (Stat Seal), Behr valve BOA 4965 RD-5-12521-0P 71R8455
Century;Columbia; Coronodo 2002-07 Sleeper Unit (Mini Stat O Seal), Behr valve, burgundy color BOA 93674 RD-5-12522-0P 71R8457
9/2000-
Century;Columbia; Coronodo Auxilliary Unit BOA 803210026900 RD-5-10903-0P 71R8451
6/2002
A22-45432-001,
FL50, FL60, FL70, FL80, FL106, FL112 2000-02 Main unit, Hi - capacity RD-5-10546-0P 71R8385
ABP N83 308070
A22-45432-000,
FL50, FL60, FL70, FL80, FL106, FL112 1994-00 Main unit RD-5-7015-0P 71R8321
ABP N83 308071
A22-45432-000,
FLB, FLC, FLL 1989-02 Main unit RD-5-7015-0P 71R8321
ABP N83 308071
FLB, FLL, FL50, FL60, FL70, FL80, FL106,
1994-00 Main unit A22-45432-000 RD-5-7567-0P 71R8370
FL112
A22-18591-000, RDH RD5
FL Series, FLC (1974-88), FLD (1992-96) 1974-97 Main unit, Hi - capacity RD-5-6868-0P 71R8301
6868 0
FLC Series 1989-93 Main unit A22-45432-000 RD-5-7567-0P 71R8370
A22-18591-000, RDH RD5
FLC Series 1974-88 Main unit RD-5-7015-0P 71R8321
6868 0
FLC (1974-91), FLD, FLP, FLT (1981-93) 1974-93 Main unit 681 830 00 84 RD-5-6868-0P 71R8301
FLD112, FLD120, CLASSIC XL, Coronado 2001-07 Main unit, (Stat Seal), Behr valve BOA A4965 RD-5-12521-0P 71R8455
FLD112, FLD120, CLASSIC XL, Coronado 1991-00 Main unit BOA 80-321-00-129 RD-5-7015-0P 71R8321
FLD112, FLD120, CLASSIC XL 1991-02 Main unit A22-45432-000 RD-5-7567-0P 71R8370
M2 2003-07 Main unit (Mini Stat O Seal) VCC 88000030 RD-5-10902-0P 71R8425
Sleeper Models with Red Dot units (R- A22-18591-000, RDH RD5
1974-97 Main unit, Hi - capacity RD-5-6868-0P 71R8301
4060, 4190, 4290) 6868 0
A22-45432-000,
Sleeper Models with Behr unit 1997-02 Main unit RD-5-7015-0P 71R8321
ABP N83 308211
A22-45432-000, BOA 80-
Sleeper Models with Behr unit 1998-01 Main unit RD-5-7567-0P 71R8370
321-00-129
A22-45432-000,
WFC, WFT 1989-96 Main unit RD-5-7015-0P 71R8321
ABP N83 308071
WFC, WFT 1989-93 Main unit A22-45432-000 RD-5-7567-0P 71R8370
WFC, WFT 1974-92 Main unit, Hi - capacity RDH RD5 6868 0 RD-5-6868-0P 71R8301
PAGE 118
FREIGHTLINER
COMPRESSOR
EXPANSION - SANDEN
VALVE / INTERNAL EQUALIZER
WFC, WFT 1973-84 Main unit with internal equalized Exp Valve BOA 80-321-00-049 RD-5-10445-0P 71R8220
FILTER
All 1995-06 Main unit, 8 1⁄4”x8 1⁄2”x3⁄4” pleated filter 22-46891-000 RD-5-11836-0P 78R5430
C, C112, C120, Century, F Class 1997-06 Main unit, 10 1⁄2”x10 1⁄2”x3⁄4” filter 22-44665-000 RD-5-11224-0P 78R5239
C, C112, C120, Columbia, Coronado 2002-07 Main unit, 10 5⁄8”x10 5⁄8”x1” pleated filter BOA 91559, FR0202P RD-5-11841-0P 78R5237
Columbia, Coronado 2003-10 Main unit, 10 5⁄8”x10 5⁄8”x1” pleated filter BOA 91621 RD-5-11841-0P 78R5237
M2, M2 Daycab business class, model
2003-10 Main unit, 8 1⁄4”x8 1⁄2”x3⁄4” pleated filter 22-46891-000 RD-5-11836-0P 78R5430
MM
HEATER CORE
FLB, FLL 1991-99 Main unit BOA 80 373 00 109 RD-1-2557-0P 76R2155
FLD120, FLD112, CLASSIC XL 1991-99 Main unit BOA 80 373 00 109 RD-1-2557-0P 76R2155
Sleeper units, Red Dot (R4190 Only CTC) 1989-97 Sleeper Unit (R4190 Combo & Heater, Only CTC) MC1150, RDH RD1 0563 0 RD-1-0563-0P 76R2400
Sleeper units, Red Dot (R4190 Only non
1989-96 Red Dot Sleeper Unit (R4190 Combo & Heater, Only non CTC) RDH RD1 0752 1 RD-1-0752-1P 76R2340
CTC)
Sleeper units, Red Dot (R4290 Only CTC) 1989-97 Red Dot Sleeper Unit (R4290 Combo & Heater Only CTC) MC1255, RDH RD1 0755 0 RD-1-0755-0P 76R2320
Sleeper units, Red Dot (R4290 Only non
1989-97 Sleeper Unit (R4290 Combo & heater only NON-CTC) RDH RD1 0752 0 RD-1-0752-0P 76R2330
CTC)
Sleeper units, (R4060) 1982-88 Red Dot Sleeper Unit (R4060) RDH RD1 0434 0 RD-1-0434-0P 76R2220
O-RINGS / SEALS
#6 Mini Stat -O - Seal, metal washer with red rubber insert,
All with Mini Stat O Seal 23-13201-000 RD-5-11527-0M 70R5031
5⁄8” O.D., 5⁄16” I.D.
#8 Mini Stat -O - Seal, metal washer with red rubber insert,
All with Mini Stat O Seal 23-13202-000 RD-5-11528-0M 70R5032
3⁄4” O.D., 7⁄16” I.D.
All with Mini Stat O Seal #10 Mini Stat -O - Seal , Red, 15⁄16” O.D., 9⁄16” I.D. ABP N83 312361 RD-5-11529-0M 70R5033
All with Mini Stat O Seal #12 Mini Stat -O - Seal , Red, 1” O.D., 11⁄16” I.D. PH720565 RD-5-11530-0M 70R5034
All with Mini Stat O Seal for Evaporator #10 Mini Stat -O - Seal , Red, 15⁄16” O.D., 9⁄16” I.D. ABP N83 312361 RD-5-11529-0M 70R5033
All with Mini Stat O Seal for Sanden
#12 Mini Stat -O - Seal , Red, 1” O.D., 11⁄16” I.D. ABP N83 312372 RD-5-11530-0M 70R5034
compressor, (GH) head
All with slimline seal #6 Slimline seal, metal washer (black), 9⁄16” O.D., 5⁄16” I.D. ABP N83 312076 RD-5-10200-0M 70R5022
All with standard sized Stat O Seal #6 Standard Stat - O - Seal ABP N83 312206 RD-5-10338-0P 70R5028
PRESSURE SWITCH
All C, Century, Classic, Coronado, FL, W Dual Function switch, M10 x 1.25 Low: open 455 psi, closed
1994-03 22-43249 RD-5-11169-0P 71R7077
series 30psi. High: open 28psi, closed 370
All C, Century, Classic, Coronado, FL, W Dual Function switch, 7⁄16” - 20 Low: open 28 psi, closed 30psi.
1991-98 22-36474 RD-5-9620-1P 71R7076
series High: open 384psi, closed 57-114psi
All C, Century, Classic, Coronado, FL Business Class, Trinary switch, with male 3⁄8-24, normally
1989-04 ABP N83 322175 RD-5-4620-0P 71R7600
series closed fan switch
Low pressure cut out switch, 3⁄8”-24, norm. open, closes 27
All C, F series 1994-03 085108-00 RD-4191-0P 71R6050
psig
Century Class C112, C120 1997-07 High Pressure Fan switch with M10 threads A22-45194-001 RD-5-8287-0P 71R6210
Century Class C112, C120 1997-04 All with APAds pressure switch 8040279P, 8040135 RD-5-9990-0P 71R6400
3966805, 8040136,
Century Class C112, C120 1997-04 All with APAds low pressure switch with M12 threads RD-5-9991-0P 71R6405
8040152, 8040161P
FL50, FL60, FL70, M2 100-112 series 1994-03 Business Class, Trinary switch, with female 7⁄16-20, 4 term. A06-18015-000 RD-5-4583-0P 71R7550
FL50, FL60, FL70, M2 100-112 series 1994-03 High Pressure Fan switch, normally open, 2 pin BOA 80 941 00 063 RD-5-6394-0P 71R6080
FL50, FL60, FL70, M2 100-112 series 1974-03 Business Class, Trinary switch, with male 3⁄8-24, 4 term. RDH RD5 4585 0 RD-5-4585-0P 71R7500
FL50, FL60, FL70, FL80, FL106, FL112 1994-03 All with Fujikoki binary sw with M10 threads, 4 term. A22-43249-000 RD-5-11169-0P 71R7077
PAGE 119
FREIGHTLINER
PRESSURE SWITCH
FL50, FL60, FL70, FL80, FL106, FL112 1994-03 High pressure switch, normally open A22-30930-000 RD-5-8288-0P 71R6220
FL50, FL60, FL70, FL80, FL106, FL112 1990-93 High Pressure Fan switch, normally open BOA 80 926 00 091 RD-5-6430-0P 71R6110
FLA, FLB, FLD 1991-98 All with Fujikoki binary sw with 7⁄16-20, 4 term. A22-36474-000 RD-5-8433-0P 71R7075
FLA, FLD 1990-93 High Pressure Fan switch, normally open BOA 80 926 00 091 RD-5-6430-0P 71R6110
FLA, FLD, FL50, FL60, FL70, M2 100-112
1994-03 High Pressure Fan switch with M10 threads A22-45194-001 RD-5-8287-0P 71R6210
series
FLD112, FLD120, CLASSIC XL 1994-03 All with Fujikoki binary sw with M10 threads, 4 term. A22-43249-000 RD-5-11169-0P 71R7077
FLD112, FLD 120, CLASSIC XL 1991-99 Low pressure switch, normally open ABP N83 318104 RD-5-5877-0P 71R6060
FLD112, FLD 120, CLASSIC XL 1991-99 Low pressure switch, NO, closes 42 psi, opens 32 psi ABP N83 318064 RD-5-4833-0P 71R6030
FLD112, FLD 120, CLASSIC XL 1991-98 All with Fujikoki binary sw with 7⁄16-20, 4 term. A22-36474-000 RD-5-8433-0P 71R7075
FLD112, FLD120, CLASSIC XL 1991-97 High Pressure Fan switch A22-30930-000 RD-5-8288-0P 71R6220
A22-30930-000, BOA 80
FLD112, FLD 120, CLASSIC XL 1991-92 High Pressure Fan switch, normally open RD-5-6430-0P 71R6110
926 00 091
Low pressure cut out switch, 3⁄8”-24, norm. open, closes 27
WFC, WFT Series 1982-88 085108-00 RD-4191-0P 71R6050
psig
WFT 320 1973-79 Heat sensing (overheat, safety) switch, opens 200°F ABP N83 322270 RD-4527-0P 71R6300
RECEIVER DRIER
All model series with Red Dot A/C, OE#
1995-00 Male inlet and Female Outlet 134a only ABP N83 319734 RD-5-10586-0P 74R3330
RD-5-10586-0
C series with OE# A22-14425-001 1981-91 Male O-Ring with fuse plug, side port, top glass A22-14425-001 RD-5-4950-0P 74R0906
C112, C120 2000-03 Quick Disconnect, side mount fittings ABP N83 319524, 319510 RD-5-11190-0P 74R3317
C112, C120 1996-01 Drier with slim-line Stato Seal with side mounting 088502-00 RD-5-11522-0P 74R3129
C112, C120, Century Class 1996-01 Male & Female O-Ring with HPRV, MI, 2 M10 switch ports ABP N83 319510, 615 RD-5-11188-0P 74R3328
C112, C120, Columbia Class 1996-01 Male O-Ring with fuse plug, side port, top glass A22-14425-001 RD-5-4950-0P 74R0906
Century, Classic, Coronado series 1981-91 Male O-Ring with fuse plug, side port, top glass A22-14425-001 RD-5-4950-0P 74R0906
Century, Columbia series 2002-07 Slim-Line seal top mt with opposing #6 male O-Ring PH088518-00 RD-5-10589-0P 74R3120
Century S/T Class Sleeper with Detroit
2000-07 Drier with slim-line Stato Seal with side mounting PH088446-00 RD-5-10939-0P 74R3127
S-60 engine
Century, Columbia Class - Sleeper Series
2000-04 Drier with slim-line Stato Seal with side mounting PH088538-00 RD-5-10939-0P 74R3127
with Cummins ISX 450 engine
Century, Columbia Class 2000-03 Drier with slim-line Stato Seal with side mounting PH088446-00 RD-5-10939-0P 74R3127
Century, Columbia, Coronado Class 2000-03 Quick disconnect ABP N83 319664 RD-5-10940-0P 74R3315
C.O.E., Conventional 1981-91 Male & Male O-Ring with Fuse Plug, low pressure switch A22-14425-002 RD-5-4950-0P 74R0906
C.O.E., Conventional 1981-85 Male & Male O-Ring with Fuse Plug, low pressure switch A22-14425-003 RD-4160-1P 74R2106
C.O.E., Conventional 1989-92 Male & Male O-Ring with switch port, HPRV, MI A22-32150 RD-5-11193-0P 74R2668
FL Series 1994-02 Male & Female O-Ring with HPRV, MI, 2 M10 switch ports ABP N83 319510, 615 RD-5-11188-0P 74R3328
FL series 1981-91 Male O-Ring with fuse plug, side port, top glass A22-14425-001 RD-5-4950-0P 74R0906
FLB, FLL 1994-99 Male & Female O-Ring withMI, 2 Male Ports, Spring Loaded RDH RD5 10944 0 RD-5-11188-0P 74R3328
FLC, FLD, FLP 1988-96 Male & Male O-Ring with2 Gage Ports, MI IN Cap, HPRV A22-37199-000 RD-5-11193-0P 74R2668
FLC, FLD, FLT 1986-89 Male & Male O-Ring HPRV, MI IN CAP PH 088193-00 RD-5-11192-0P 74R2608
FLC, FLD, FLT 1986-89 Male & Male O-Ring HPRV, MI IN CAP A22-28796-000 RD-5-5583-0P 74R2606
FLC, FLP, FLT 1978-88 Male & Male O-Ring HPRV, MI IN CAP A22-14425-003 RD-5-9455-0P 75R1836
FLC, FLT 1989-91 Male & Male O-Ring HPRV, MI IN CAP A22-28796-000 RD-5-5583-0P 74R2606
FLC, FLT 1978-88 Male O-Ring with fuse plug, side port, top glass A22-14425-002 RD-5-4950-0P 74R0906
FLC, FLT 1978-88 Male & Male O-Ring with Fuse Plug, low pressure switch A22-14425-003 RD-4160-1P 74R2106
FL50, FL60, FL70, FL80, FL106, FL112 1994-01 Male O-Ring with fuse plug, side port, top glass A22-14425-002 RD-5-4950-0P 74R0906
FL50, FL60, FL70, FL80, FL106, FL112 1994-99 Male & Female O-Ring with,MI, 2 Male Ports, Spring Loaded RDH RD5 10944 0 RD-5-11188-0P 74R3328
FLB, FLD112, FLD120, FLL, CLASSIC XL 1994-02 Male O-Ring with fuse plug, side port, top glass A22-14425-002 RD-5-4950-0P 74R0906
FLD112, FLD120, CLASSIC XL 1994-01 Male & Male O-Ring with Fuse Plug, low pressure switch A22-14425-003 RD-4160-1P 74R2106
PAGE 120
FREIGHTLINER
RECEIVER DRIER
FLD112, FLD120, CLASSIC XL 1994-99 Male & Female O-Ring withMI, 2 Male Ports, Spring Loaded RDH RD5 10944 0 RD-5-11188-0P 74R3328
FLD112, FLD120, CLASSIC XL 1994-99 Quick disconnect RDH RD5 10941 0 RD-5-10941-0P 74R3321
FLD112, FLD120, CLASSIC XL 1993-94 Quick disconnect PH 088293-00 RD-5-10585-0P 74R3311
FLD112, FLD120, CLASSIC XL 1993-94 Quick disconnect PH 088293-00 RD-5-11195-0P 74R3309
FLD112, FLD120, CLASSIC XL 1993-94 Quick disconnect & HPRV RDH RD5 9791 0 RD-5-9791-0P 74R3314
FLD112, FLD120, CLASSIC XL 1991-94 Male & Female O-Ring withHPRV, MI, 2 7⁄16-20 Gage Ports RDH RD5 10584 0 RD-5-10584-0P 74R3147
FLD112, FLD120, CLASSIC XL 1991-94 Male & Female O-Ring withHPRV, MI, 2 7⁄16-20 Gage Ports RDH RD5 11194 0 RD-5-11194-0P 74R3148
FLD112, FLD120, CLASSIC XL 1991-92 Male & Male O-Ring with2 Gage Ports, MI IN Cap, HPRV A22-37199-000 RD-5-11193-0P 74R2668
M2 Business class - Daycab series with
2006-08 Drier with slim-line seal with top mounting PH088539-00 RD-5-10589-0P 74R3120
MB engine #MBE-900-210 (6.4L)
M2 Series 2002-07 Drier with slim-line seal with top mounting PH088518-00 RD-5-10589-0P 74R3120
WFC Series 1978-91 Male O-Ring with fuse plug, side port, top glass A22-14425-002 RD-5-4950-0P 74R0906
WFC, WFT 1988-96 Male & Male O-Ring with2 Gage Ports, MI IN Cap, HPRV A22-37199-000 RD-5-11193-0P 74R2668
RELAY
Compressor Clutch Relay, Bosch type (30 amp), SPST, 5
ALL 1974-00 ABP N83 320140 RD-5-4408-0P 71R1702
terminals
Compressor Clutch Relay, Bosch type (40 amp) with diode,
ALL 1974-00 POTVF415F11 RD-5-9915-0P 71R1722
SPST, 5 terminals
RELAY (ACTUATOR)
M2 100 - 112V Series 2002-07 Water Valve Actuator, universal VCC32000022 RD-5-11862-0P 71R3577
RESISTOR
Century Class C120, C112 1997-2010 Blower Resistor RDH RD5 6450 0 RD-5-6450-0P 71R1455
FLD120, FLD112 CLASSIC XL 1991-99 Blower Resistor RDH RD5 6450 0 RD-5-6450-0P 71R1455
BOA-80-926-00-079,
FLP Series 1989-92 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
ABP N83 321350
BOA-80-926-00-079,
W Series 1988-92 Blower resistor, 4 speed, 4 terminal RD-5-6450-0P 71R1455
ABP N83 321350
SOLENOID VALVE
ALL 1972-00 Freon refrigerant Solenoid valve for Sleeper unit 207583, LA1225 RD-4188-0P 71R9002
ALL 1978-98 Air Solenoid - Fan Clutch RDH RD5 0060 0 RD-5-0060-0P 72R1502
THERMOSTATIC SWITCH
All C, Century, Century ST series 1990-10 Main & Sleeper unit with fixed setting thermostat BOA-80-946-00-109 RD-5-6429-0P 71R3150
All C, Century, Classic, Coronado, FL
1989-04 Cable controlled thermostat, 30” cap tube 02-7010174 RD-4226-0P 71R2700
series
All C, Century, Classic, Coronado, FL
1989-04 All models with bunk style thermostat, bimetal RDH RD 4430 0 RD-4430-0P 71R2500
series
All C, C112, C120, Century, Columbia A630-008-00, BOA-80-
1998-10 Main unit with fixed setting thermostat RD-5-6429-0P 71R3150
series 946-00-079
FL50, FL60, FL70, FL80, FL106, FL112,
1994-01 Main unit with fixed setting thermostat BOA-80-946-00-079 RD-5-6429-0P 71R3150
FLB, FLL
FLA, FLC, FLT 1989-04 Main unit with fixed setting thermostat BOA-80-946-00-079 RD-5-6429-0P 71R3150
A22-15817-A, BD1035,
FLC, FLP, FLT 1976-80 Rotary thermostat with 48” capillary tube, 34 - 52°F RD-4125-48P 71R2300
MVA1-4185
FLD, FLD120, FLT 1981-88 Main unit with fixed setting thermostat A22-23640-000 RD-5-4531-24P 71R3200
FLD112, FLD120, CLASSIC XL 1998-10 Main unit with fixed setting thermostat BOA-80-946-00-079 RD-5-6429-0P 71R3150
A22-15817A-001,
FLP, FLT, WFT 1976-80 Rotary thermostat, 36” cap tube RD-4125-36P 71R2250
9533N178, MVA1-1048
A22-15817-A, BD1035,
WFT Series 1976-80 Rotary thermostat with 48” capillary tube, 34 - 52°F RD-4125-48P 71R2300
MVA1-4185
WATER VALVE
All C, C.O.E., Conventional, FL series 1975-85 Cable operated, Red Dot 173119 RD-5-8943-0P 72R6515
PAGE 121
FREIGHTLINER
WATER VALVE
A22-44463-001, A22-
C112, C120, Century, Columbia 1996-02 Cable operated, Red Dot RD-5-8943-0P 72R6515
44553-000, MVA1-6296
RDH RD5 8859 0, RDH RD5
C.O.E., Conventional 1975-86 Air Operated with Red Dot unit (3⁄4” to 3⁄4”) RD-5-8859-0P 72R6410
4797 0
C.O.E., Conventional 1975-86 Air Operated with Red Dot unit (5⁄8” to 1⁄2”NPT) RD-5-8856-0P 72R6430
3654 0
C.O.E., Conventional 1975-86 Cable Operated, Red Dot (5⁄8” to 5⁄8”), pull to open RDH RD5 5300 1 RD-5-5300-1P 72R5210
C.O.E., Conventional 1975-86 Cable Operated, Red Dot (5⁄8” to 5⁄8”), pull to open, 90° RDH RD5 5495 1 RD-5-5495-1P 72R5260
F Series 1982-92 Cable operated, (3⁄4” to 3⁄4”) RDH RD5 5191 0 RD-5-5191-0P 72R5070
FL50 - FL112, FL106 - 112, FLB, FLL, MB70 1992-01 Cable operated (Kysor) 5⁄8” x 5⁄8”, pull to close KYS 173144, MA1425 RD-5-10344-0P 72R6520
FLB, FLD (91-95), FLL, FL50 - FL112 1992-01 Cable operated, Red Dot RDH RD5 8935 0 RD-5-8935-0P 72R6510
FLD, FLD112, FLD120 1986-94 Air Operated with Red Dot unit (3⁄4” to 3⁄4”) RD-5-8859-0P 72R6410
4797 0
A22-44553-000, MVA1-
FLD112, FLD120 1991-10 Cable operated, Red Dot, Main unit RD-5-8943-0P 72R6515
6296
RDH RD5 8804 0-1, MVA1-
FLD112, FLD120, CLASSIC XL 1986-94 Air Operated with Red Dot unit (5⁄8” to 5⁄8”) RD-5-8804-0P 72R6400
9251
FLD112, FLD120 1986-94 Air Operated 5⁄8” to 5⁄8” with 90 deg elbow RD-5-8857-0P 72R6420
FLB, FLD112, FLD120, FLL(94-99),
1991-00 Cable Operated (Bergstrom), mounts to core MA1365 RD-5-11319-0P 72R6533
CLASSIC XL,
W Series 1982-92 Cable operated, (3⁄4” to 3⁄4”) RDH RD5 5191 0 RD-5-5191-0P 72R5070
WATER VALVE (ACTUATOR)
M2 100 - 112V Series 2002-07 Water Valve Actuator, universal VCC32000022 RD-5-11862-0P 71R3577
IHC - NAVISTAR
BLOWER MOTOR
117238-C91,1691702-C91,
All models 1969-75 1 speed, 3 1⁄4” diameter blower motor, CW or CCW RD-5-10390-0P 73R0212
238748R91, 346931-C91
All models 1969-75 All with 3”diameter blower motor, 2 speed, CCW direction 419993-C91 RD-5-6526-1P 73R0402
1076362R91, 1691719-C91,
All models 1969-75 All with 3”diameter blower motor, 1 speed, CW direction RD-5-9100-0P 73R0462
419992-C91
All models 1972-73 All with 4 3⁄4” diameter, CCW, single speed 1676648-C1, 1691721-C91 RD-5-10746-0P 73R1012
All models 1972-73 All with flange motor, 4 7⁄8” diameter,CW, single speed 1676657-C1 RD-5-10381-0P 73R2222
All models 1972-73 All with 3”diameter blower motor, 2 speed, CCW direction 0680952R93 RD-5-6526-1P 73R0402
All models Double Shaft motor, 1 speed, 4 3⁄4” length 1691704-C91, 1691733-C91 RD-5-6801-0P 73R4182
All models Double Shaft motor, 1 speed, 4 3⁄4” length 1691705-C91 RD-5-8032-0P 73R4122
All models Single shaft motor, 1 speed, CCW, 4 5⁄8” length 1691708-C91, 498554-C92 RD-5-10389-0P 73R0372
All models Single shaft motor, 1 speed, CCW, 5” length 1691717-C91 RD-5-6526-1P 73R0402
All models OE style blower motor (only), 3 3⁄4” length, non-vented 411876-C91, 442987-C1 RD-5-10391-0P 73R0092
CXT/MXT/RXT Truck, Lonestar ALL Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
Fleetstar Models 2010, 2011A, 2050, OE style single shaft blower motor (only), 3 3⁄4” length,
1977-86 442987-C1 RD-5-10391-0P 73R0092
2070A non-vented
Fleetstar Models 2010, 2050 1974-81 OE style blower motor (only) 345511-C92 RD-5-9100-0P 73R0462
Heater/AC Motor (floor mt), single shaft motor, 1 speed, CCW,
Paystar 5000, 5360 Series 1978-84 488842-C91 RD-5-10389-0P 73R0372
4 5⁄8” length
ProStar Conventional, ProStar
Conventional Limited, ProStar ALL Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
Conventional Premium
S Series, 9671 1977-94 All models with flange style motor, 1 speed, 4 3⁄4” length, CW 1669786-C1 RD-5-4937-0P 73R2102
Kysor S combo unit with flange style motor, 1 speed, 4 3⁄4”
S Series 1977-93 274243 RD-5-4937-0P 73R2102
length, CW
PAGE 122
IHC - NAVISTAR
BLOWER MOTOR
A/C Motor, Heater Motor (CW), 1977-84, flange style motor, 1
S Series 1977-89 469455-C1 RD-5-4937-0P 73R2102
speed, 4 3⁄4” length, CW
A/C motor, main unit with flange style motor, 1 speed, 4 3⁄4”
S Series, 9670 1982-90 1676650-C1 RD-5-4937-0P 73R2102
length, CW
Transtar 4070A & B with Blend Air Unit 1978-82 Side mounted motors (CCW), after 10/31/77 488831-C1 RD-5-4927-0P 73R0702
Transtar 4070A & B with Blend Air Unit 1978-82 Floor (After 10/31/77) (CW) 488832-C1 RD-5-10392-0P 73R0232
Transtar II, 4070A, 4070B with side Side mounted motors (CCW), single shaft motor, 1 speed,
1986-93 421843-C1 RD-5-10389-0P 73R0372
mount CCW, 4 5⁄8” length
Floor mounted Motor, 3-1⁄2 diameter, (CW or CCW), single
Transtar II, 4070A, 4070B, 4200 1978-85 HA1135 RD-5-10389-0P 73R0372
shaft motor, 1 speed, 4 5⁄8” length
Transtar 4070B 1974-89 Kysor Rooftop Unit 1099013 RD-5-10379-0P 73R0012
All Transtar II with floor mount, single shaft motor, 1 speed,
Transtar 4200 1978-85 HA1135 RD-5-10389-0P 73R0372
Transtar II 1978-81 CW Motor, single shaft, CCW, 12V, 5” length, 3⁄4” shaft 421844-C1 RD-5-6526-2P 73R0352
Transtar II, 4200 & 4300, 4070B, Paystar
1978-85 Heater & A/C (Floor)(CW) includes Blend Air Units 488832-C1 RD-5-10392-0P 73R0232
53
Transtar II, 4200 & 4300, 4070A, B,
1978-85 Heater & A/C (Side)(CCW) includes Blend Air Units 488831-C1 RD-5-4927-0P 73R0702
Paystar 53
1669779-C1, 1669786-C1,
1400, 1600 1987-97 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
1699291-C1
1700/1800 Bus Flat Back Cowls,
1700/1800 Medium Truck, 1900, 2100, 1981-88 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
2200, 2300, 2500/2600 Medium Truck
Main unit (motor kit) with flange style motor, 1 speed, 4 3⁄4”
2000 1988-01 1699291--C1 RD-5-4937-0P 73R2102
length, CW
2000 1988-01 All with flange style motor (heavy duty) 2500485-C1 RD-5-11526-0P 73R3082
2000; 4000; 8000 Series 1982-96 Main unit with flange style motor, 1 speed, 4 3⁄4” length, CW 1669786-C1 RD-5-4937-0P 73R2102
1669779-C1, 1669786-C1,
2500, 2600, 8200, 8300 1989-98 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
1699291-C1
Fleetstar models with OE style single shaft blower motor
2010, 2050, 2070A, 2011A 1977-86 442987-C1 RD-5-10391-0P 73R0092
(only), 3 3⁄4” length, non-vented
2010, 2050 1974-81 All Fleetstar models with OE blower motor 345511-C92 RD-5-9100-0P 73R0462
2500/2600 Heavy Truck 4/1/1981-88 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
2500/2600 Heavy Service Truck, 8100 After 1/16/98 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
2500/2600 Heavy Truck, 2500/2600
1989-1/16/98 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
Medium Truck, 8200, 8300
3000 Bus, 4700/4800/4900 Medium
After 5/23/97 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
Truck
3200 Commercial Bus, Cutaway
ALL Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
Commercial Bus
3400/3600/3700/3800 Bus Flat Back Before
Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
Cowls, 3900 FC Bus 5/23/97
4000, 5000, 8000, 9000 1988-07 All with flange style motor (heavy duty) 2500485-C1 RD-5-11526-0P 73R3082
4070A 1974-89 All models with Kysor rooftop style motor HA1010 RD-5-5230-0P 73R0522
All Transtar II with side mount, single shaft motor, 1 speed,
4070A, 4070B with side mount 1986-93 421843-C1 RD-5-10389-0P 73R0372
4100/4200/4300/4400 Medium Truck ALL Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
4500/4600/4700/4800/4900/7100 Before
Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
Medium Truck, 1650 UPS 5/23/97
Before 1669779-C1, 1669786-C1,
4500, 4600, 4700, 4800, 4900, 7100 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
5/23/1997 1699291-C1
PAGE 123
IHC - NAVISTAR
BLOWER MOTOR
4600, 4900, 8000, 8100, 8200, 8300 1988-92 Main unit with flange style motor, 1 speed, 4 3⁄4” length, CW 474086-C1 RD-5-4937-0P 73R2102
1669779-C1, 1669786-C1,
5000 Series 1992-3/96 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
1699291-C1
5000 Series 1982-93 Heater Motor with I.H. Heater Model No. 488891- C97 Floor 421844-C1 RD-5-10392-0P 73R0232
Heater Motor with I.H. Heater Model No. 488891- C97 side
5000 Series 1982-93 488843-C91 RD-5-4927-0P 73R0702
mt
5000 Series with I.H. Heater Model No. Heater motor (floor mt), single shaft motor, 1 speed, CCW, 4
1982-91 488842-C91 RD-5-10389-0P 73R0372
488891-C97 floor mt 5⁄8” length
5000 Series 1981-3/14/96 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
Heater/AC motor (floor mt), single shaft motor, 1 speed, CCW,
5000 Series 1978-84 488842-C91 RD-5-10389-0P 73R0372
4 5⁄8” length
5000, 7000 Series 1998-99 All with flange style motor (heavy duty) 2500485-C1 RD-5-11526-0P 73R3082
5000, 7100, 8000, 9000, 9200, 9300,
1988-99 Main unit (motor kit) 2500485-C1 RD-5-4937-0P 73R2102
9400, 9600, 9700, 9800
5000, 7100, 9200, 9300, 9400, 9600,
1982-96 Main unit with flange style motor 1669786-C1 RD-5-4937-0P 73R2102
9700
5000i, 9100i, 9200i, 9400i, 9900i 2000-10 Main unit 1699949-C1 RD-5-11526-0P 73R3082
Before
5870 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
3/15/96
7300 Severe Service After 10/1/01 Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
7400/7500 Severe Service After 7/1/01 Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
7600 Severe Service After 4/1/02 Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
After
7700 Severe Service Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
12/15/03
Before 1669779-C1, 1669786-C1,
8100 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
1/16/1998 1699291-C1
8300 Series 1989-93 Sleeper Motor with 4 3⁄4” diameter, CCW, single speed 1669342-C1 RD-5-10746-0P 73R1012
8300 Series 1989-93 Sleeper unit (Red Dot) with single shaft, 4 3⁄4” length 1669342-C1 RD-5-6526-0P 73R0422
Before
8300 Series Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
1/1/89
8500/8600 Heavy Tractors ALL Blower Assembly, Single Shaft, Flange Mount, 3542611-C2 RD-5-13068-0P 73R3132
Before 1669779-C1, 1669786-C1,
9200, 9300, 9400 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
5/23/1996 1699291-C1
9200, 9300, 9400, 9800, 9900 1997-99 Main unit & Bunk Booster Blower 1699949-C1 RD-5-11526-0P 73R3082
9300 Premium Cabover, 5000 Severe
After 3/15/96 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
Service
9600/9700 Premium Cabover After 1/1/91 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
After 1669779-C1, 1669786-C1,
9600, 9700 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW RD-5-11526-0P 73R3082
1/1/1991 1699291-C1
Before
9800 Premium Cabover, 8100 Motor, Flange Mount, 1 speed, 4 3⁄4” length, CW, No Wire 1669786-C1 RD-5-4937-0P 73R2102
1/16/98
BLOWER RELAY
All Models withKysor A/C (mini relay) 1986-93 Bosch type (30 amp), SPST, 5 terminals A22-011101-022 RD-5-4408-0P 71R1702
S Series 1977-91 IHC Relay (30 amp), SPST, 5 terminals 447186-C1 RD-5-10154-0P 71R1922
5000 - 9700 Series 1982-96 IHC Relay (30 amp), SPST, 5 terminals 447186-C1 RD-5-10154-0P 71R1922
BLOWER RESISTOR
All models 1977-00 Sleeper units with3 terminal, 4 speed resistor 469458-C1 RD-5-9916-0P 71R1460
All models 1977-96 Sleeper units with3 terminal, 3 speed resistor 1669332-C1 RD-5-3647-0P 71R1450
2000, 4600, 4700, 4900, 8100, 8200,
1991-02 IHC Resistor, 3 terminal, 3 speed 1696836-C1, 650179 RD-5-10341-0P 71R1457
8300
506552C1, BSM321010,
2000, 4000, 8000 (1977-93) Series 1977-01 IHC Resistor, 4 terminal, 4 speed RD-5-9916-0P 71R1460
ZGG14512
PAGE 124
IHC - NAVISTAR
BLOWER RESISTOR
506552C1, BSM321010,
4070, 4200, 4300 1974-01 IHC Resistor, 4 terminal, 4 speed RD-5-9916-0P 71R1460
ZGG14512
5000 Series (1983-93), 7100, 9200, 9300,
1983-96 IHC Resistor, 4 terminal, 4 speed 506552C1, ZGG14512 RD-5-9916-0P 71R1460
9400, 9600, 9700, 9800
8300 Series 1977-93 Sleeper units with3 terminal, 3 speed resistor 1669332-C1 RD-5-3647-0P 71R1450
9200, 9300, 9400, 9600, 9700, 9800 506552C1, BSM321010,
1982-00 IHC Resistor, 4 terminal, 4 speed RD-5-9916-0P 71R1460
Series ZGG14512
S Series 1977-93 IHC Resistor, 4 terminal, 4 speed 506552C1, ZGG14512 RD-5-9916-0P 71R1460
S Series 1977-92 IHC Resistor, 4 terminal, 4 speed 506552C1, ZGG14512 RD-5-9916-0P 71R1460
Transtar 4070A & B, 4200/4300 Fleetstar 1974-91 IHC Resistor, 4 terminal, 4 speed 506552C1, ZGG14512 RD-5-9916-0P 71R1460
BLOWER SWITCH
All Models 2001-08 Blower rotary switch, DP3T 25 amp, 12V or 24V. 1661420-C1 RD-5-9833-0P 71R1160
All Models 1976-93 Blower (heater) toggle switch, 5 terminal, OFF-ON-ON-ON ZGG16523 RD-5-6804-0P 71R0460
All Models 1976-03 Blower rotary switch, DP3T 25 amp, 12V or 24V. INM2G754A RD-5-3646-0P 71R1150
8000 Series 1976-94 Blower rotary switch, DP3T 25 amp, 12V or 24V. 1661420-C1 RD-5-9833-0P 71R1160
8300 Series 1989-93 Sleeper A/C Htr. toggle switch, DPDT, ON-ON-ON 1669348-C1, RD-5-0071-0 RD-5-0071-0P 71R0400
9300, 9400, 9600, 9700 Series 1981-01 Blower (fan) toggle switch, 10 terminal, OFF-ON-ON-ON 501087-C1, C3, ZGG14469 RD-5-8256-0P 71R0480
S Series 1984-94 Blower toggle switch, SPST, 3 terminal, ON - OFF 221005, ZGG11601 RD-5-3923-0P 71R0050
S Series 1976-94 Blower rotary switch, DP3T 25 amp, 12V or 24V. 1661420-C1 RD-5-9833-0P 71R1160
S Series with Kysor A/C Unit 1984-94 Red Dot speed control resistor, 3 terminal, 3 speed ZGG16665 RD-5-3647-0P 71R1450
S Series, Sleeper unit 1989-94 Sleeper A/C Htr. toggle switch, DPDT, ON-ON-ON 1669348-C1, RD-5-0071-0 RD-5-0071-0P 71R0400
S Series, Sleeper unit 1989-94 Sleeper A/C Htr. toggle switch, DPDT, ON-OFF-ON ZGG16663 RD-5-3599-0P 71R0250
BLOWER WHEEL
All models 2001-2009 Main and sleeper units, 5 3⁄4” diameter, 3” width, CCW, pastic 1699947-C1 RD-5-5551-0P 73R6391
All models 1982-92 All units with 5 1⁄2” double entry wheel, 3 3⁄4” width 1691731-C1 RD-3-2557-2P 73R7151
All models 1982-92 All units with 4 1⁄2” double entry wheel, 3 3⁄8” width 1691727-C1, 1691728-C1 RD-5-10346-0P 73R7130
5000i, 9100i, 9200i, 9400i, 9900i 2000-04 Main unit & Bunk Booster Blower 1699947-C1 RD-5-5551-0P 73R6391
9200, 9300, 9400, 9600, 9700, 9800 1997-01 Main unit & Bunk Booster Blower 1699947-C1 RD-5-5551-0P 73R6391
9200, 9300, 9400, 9800, 9900 1999 Main unit and Bunk 1699947-C1 RD-5-5551-0P 73R6391
S Series models 1982-94 Motive Air units with4 1⁄2” double entry wheel, 3 3⁄8” width 1-4955Q RD-5-10346-0P 73R7130
CLUTCH ASSEMBLY
4700 Series IHC with T444E IHC
Poly 8 groove, , 5 3⁄8” diameter pulley, 1 5⁄8” gauge line, IHC
Engine, fits CCI/York ET210L-25224C 1818128-C1, C2 RD-5-9802-0P 75R0662
plug
compressors
4900 Series IHC with DT466E IHC Engine, Poly 6 groove, , 5 3⁄4” diameter pulley, 2” gauge line, 1687780-C92, 1687780-
RD-5-10364-0P 75R0512
fits CCI/York ET210L-25182C compressors weatherpak plug C92
9100 Series IHC with N14 Cummins
1 groove, 1⁄2” width, 6” diameter pulley, 2 3⁄4” gauge line,
Engine, fits CCI/York ET210L-25076C 481800-C91, ZGG19311 RD-5-4966-0P 75R0302
weatherpak plug
compressors
9300 Series IHC with 3406e Cat Engine, Poly 6 groove, , 5 3⁄4” diameter pulley, 2” gauge line, 1687780-C92, 1687780-
RD-5-10364-0P 75R0512
fits CCI/York ET210L-25182C compressors weatherpak plug C92
Fits IHC Models with CCI/York ET210L- Poly 8 groove, , 6 1⁄8” diameter pulley, 1 15⁄16” gauge line,
ZGG19310 RD-5-10365-0P 75R0682
25246C compressors metripak plug
Fits IHC Models with CCI/York ET210L- Poly 6 groove, , 5 3⁄4” diameter pulley, 2” gauge line,
ZGG704000 RD-5-10363-0P 75R0502
25240C compressors weatherpak plug
1 groove, 1⁄2” width, 6” diameter pulley, 2 3⁄4” gauge line, IHC 1653480-C91, 92,
plug ZGG14191
1 groove, 1⁄2” width, 6” diameter pulley, 2 3⁄4” gauge line, 14190, 481800-C91,
weatherpak plug ZGG19311,ZGG12141
1 groove, 1⁄2” width, 6 1⁄4” diameter pulley, 2 11⁄16” gauge line,
FitsCCI/York - R12/134A compressors 2016403-C1, C2, ZGG19845 RD-5-10397-0P 75R1342
IHC plug
PAGE 125
IHC - NAVISTAR
CLUTCH ASSEMBLY
1 groove, 1⁄2” width, 6 3⁄4” diameter pulley, 2 3⁄4” gauge line, 16766601-C91,395083C91
bullet plug 481802-C91
1 groove, 1⁄2” width, 6 3⁄4” diameter pulley, 2 3⁄4” gauge line,
FitsCCI/York - R12/134A compressors 395087-C91, ZGG11556 RD-5-4993-0P 75R4352
bullet plug
FitsCCI/York - R12/134A compressors 1 groove, 5⁄8” width, 6” diameter groove, 2 11⁄16” gauge line 393681-C91 RD-5-9657-0P 75R4732
2 groove, 1⁄2” width, 6” diameter pulley, 1 5⁄8” gauge line, 024-21590, 1647566-C91,
bullet plug 165338-C91, ZGG12135
2 groove, 1⁄2” width, 6” diameter pulley, 1 5⁄8” gauge line, 165129-C91, 1647566-C91,
weatherpak plug ZGG11566
2 groove, 1⁄2” width, 6 3⁄4” diameter pulley, 2 1⁄4” gauge line, 1669746-C91, 425450-C92,
IHC plug ZGG11565
2 groove, 1⁄2” width, 7” diameter pulley, 2” gauge line, bullet
FitsCCI/York - R12/134A compressors 1687801-C91, ZGG12136 RD-5-4994-0P 75R4502
plug
2 groove, 1⁄2” width, 7” diameter pulley, 2” gauge line, bullet
FitsCCI/York - R12/134A compressors 1140568-C91 RD-5-8382-0P 75R4534
plug, 24V
Poly 6 groove, 5 3⁄4” diameter groove, 2” gauge line, 2 wire
FitsCCI/York - R12/134A compressors ZGG704000 RD-5-10363-0P 75R0502
metripak plug
Poly 6 groove, 5 3⁄4” diameter groove, 1 5⁄8” gauge line, 2 wire
FitsCCI/York - R12/134A compressors ZGG19323, ZGG704000 RD-5-10366-0P 75R0522
Metripak
FitsCCI/York - R12/134A compressors Poly 6 groove, , 6 1⁄8” diameter pulley, IHC plug 1687780-C91, ZGG18414 RD-5-8009-0P 75R0612
Poly 8 groove, , 5 3⁄8” diameter pulley, 1 5⁄8” gauge line, IHC
FitsCCI/York - R12/134A compressors 1818128-C1, C2 RD-5-9802-0P 75R0662
plug
Poly 8 groove, , 6 1⁄8” diameter pulley, 1 15⁄16” gauge line,
FitsCCI/York - R12/134A compressors ZGG19310, ZGG19841 RD-5-10365-0P 75R0682
metripak plug
Fits Sanden SD508/510 R12/R134a 576625-C91, ZGG11207,
2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), 1 1⁄2” gauge line RD-5-5486-0P 75R0202
Fits Sanden SD508-514 R12/R134a 1 groove, 1⁄2” width, 4 3⁄4” diameter (122mm) overhang, bullet
8545-6011, 8545-6310 RD-5-10758-0P 75R1872
compressors plug
Fits Sanden SD508-514 R12/R134a
1 groove, 1⁄2” width, 6 1⁄4” diameter (158mm), bullet plug 653480-C91, 9313-6010 RD-5-5489-0P 75R1402
compressors
Poly 7 groove, 4.9” diameter (119mm), bullet plug ZGG704006, 6563-6010 RD-5-5574-0P 75R0042
compressors
Fits Sanden SD7H15HD R134a 4427-9931, 7730-9930,
Poly 8 groove, 4.9” diameter (125mm) RD-5-10361-0P 75R1432
Fits Sanden SD7H15HD R134a
Poly 8 groove, , 5 1⁄8” diameter (130mm), metripak plug 4700-9931, 4885-9931 RD-5-11374-0P 75R4802
compressors
Fits Seltec CH, Diesel Kiki, Zexel TM15 1 groove, overhang 1⁄2” width, 4.9” diameter (125mm), bullet
1691736-C1, ZGG16355 RD-5-6646-0P 75R0182
compressors plug
Fits Seltec CH, TM15 compressors 2 groove, 1⁄2” width, 5 21⁄64” diameter (135mm), male bullet 1691737-C1, ZGG13065 RD-5-6996-0P 75R0222
2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), weatherpak
Fits Seltec CH, TM15 compressors ZGG704005, 511946 RD-5-9655-0P 75R0232
plug
417888-C92, ER, R210L-
CCI / York Rotolock ER, R210L-series R-12 21237, 25062, 25149,
Rotolock Head, LH Suction without clutch, (universal - new) RD-5-8637-1P 75R7280
or 134a (ester oil) 1676831-C91, 1676832C91,
2502460-C91
ET210L-25061, 21160,
25150C,ZGG19254,
1676832-C91, C92,
CCI / York Tube-O ET, T210L-series R-12 1685127-C91, 2000820-
Tube O-Ring type head without clutch, (universal - new) RD-5-8638-1P 75R7290
or 134a (ester oil) C91, 2003413-C91,
2502459-C91, 2502460-
C91, 417888-C91, 468323-
C91, 417887-C93 .
PAGE 126
IHC - NAVISTAR
ET210L-25061, 21160,
25150-C, ZGG19254,
1676832-C91, C92,
CCI / York Tube-O ET, T210L-series R-12 1685127-C91, 2000820-
or 134a (ester oil) without charge ports C91, 2003413-C91,
2502459-C91, 2502460-
C91, 417888-C91, 468323-
C91, 417887-C93 .
CCI / York / Tecumseh R-12 or 134a
Rotolock Head, LH Suction without clutch, (universal - new) 417888-C91 RD-5-8637-1P 75R7280
(ester oil)
CCI / York / Tecumseh R-12 or 134a
Tube O-Ring type head without clutch, (universal - new) 1610046-C91 RD-5-8638-1P 75R7290
(ester oil)
CCI/Tecumseh Rotolock ER, R210L-series 417888-C91, ER, R210L-
R-12 or 134a (ester oil) 21237, 25062,
CCI/Tecumseh Tube-O ET, T210L-series 99244-5, ET210L-25061,
R-12 or 134a (ester oil) 21160, 25150C
COMPRESSOR - GM
Delco/GM A6 with Superheat switch
GM A6, 1 groove, 1⁄2” width, 4 7⁄8” diameter (124mm), generic 509170-C91 RD-5-5000-0P 75R8102
port, without oil
COMPRESSOR - SANDEN
IHC Models with Cummins 8.3L engine,
7H15, JDA Head, ear mt, 2 groove, 5 1⁄4” diameter (132mm), 2032287-C91 RD-5-11316-0P 75R81472
Sanden #4647
IHC Models with Detroit Series 60
7H15, JDA head, direct mt, poly 8, 4.7” (119mm) diameter 3551405-C1 RD-5-10738-0P 75R84622
Engine, Sanden #4822
IHC Model ISX 9800 Cab over, Sanden
7H15, #4492, 4761 R134a compressor 7H15, MDA head, direct mt, poly 6, 4.9” (125mm) diameter 3541235-C91, ZGG705017 RD-5-11254-0P 75R81352
with PAG oil
7H15 direct mount, poly 8 groove, (119mm) diameter 3582435-C1 75R84232
with PAG oil
Sanden 7H15, #4492, 4761 R134a
7H15, MDA head, direct mt, poly 6, 4.9” (125mm) diameter 3541235-C91, ZGG705017 RD-5-11254-0P 75R81352
Sanden 7H15, #4644, 4647, 4664, R134a
7H15, JD head, direct mt, 2 groove, 5 1⁄4” (132mm) diameter 2032287-C91 RD-5-10297-0P 75R84612
7H15, JDA head, ear mt, poly 7, 4.7” (119mm) diameter 2003413C91, ZGG705130 RD-5-11313-0P 75R81452
with PAG oil
Sanden 7H15, #4667, R134a compressor
7H15, KCA head, direct mt, poly 8, 4.7” (119mm) diameter 3579878-C1 RD-5-11326-0P 75R81502
with PAG oil
7H15 GWA head, direct mount, poly 6 groove, (125mm)
Sanden 7H15 #4815 3541235-C91, 3547916-C1 RD-5-13235-0P RD-5-13235-0P
diameter
7H15, JDA head, direct mt, poly 8, 4.7” (119mm) diameter RD-5-10738-0P 75R84622
with PAG oil
Sanden 510-HD, #9120 R-12 compressor SD510-HD, FG head, ear mount, 2 groove, 5 1⁄4” (132mm)
544929-C1 RD-5-5443-0P 75R8212
with charge ports, mineral oil diameter
74R89292
RD-5-11012-0P
Sanden 508, #9285 R-12 compressor with
FLX replacement, 2 groove, 5 1⁄4”(132mm) diameter 9285 with RD-5-10881-
with charge ports, mineral oil 75R89310
0P adapter
adapter
Sanden 508, #9514 R-12 compressor
TM15CH, F head, ear mount, 2 groove, 5 1⁄4” (135mm)
Compressor with mineral oil/ with 488-25011 RD-5-5876-1P 75R8512Q
diameter with ports
charge ports
ICE/Seltec TM15 # 488-45011 - R134a
TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) without
Compressor with PAG OIL, no charge 488-45011 RD-5-7145-1P 75R8612Q
ports
ports
PAGE 127
IHC - NAVISTAR
ICE/Seltec TM15 # 488-45063 - R134a TM15CH, D head, ear mount, 1 groove, 5” (125mm) diameter
488-45063 RD-5-8944-1P 75R8532Q
Compressor with PAG OIL without ports
ICE/Seltec TM15 # 488-45065 - R134a TM15CH, D head, ear mount, 1 groove, 6 1⁄4” (159mm)
488-45065 RD-5-7164-1P 75R8632Q
Compressor with PAG OIL diameter without ports
ICE/Seltec TM15 # 488-45077 - R134a
TM15BH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) without
ports
ports
ICE/Seltec TM16 # 2521494 - R134a
TM 16, GWA fittings, ear mount, Poly 8 groove, 4 3⁄4” (123mm)
Compressor with PAG OIL, no charge 3547916-C1 RD-5-10497-1P 75R8762Q
12v
ports
CONDENSER
2004801-C1, C2, C3, C4,
2000, 7000, 8000, 9000, 9200 Series 1992-2002 Radiator Mount, IHC and Red Dot unit, #R-10035-1, -2, -3, -4 RD-4-4713-0P 77R7000
690-2004801-C4
4000 Series 1989-94 Radiator Mount ZGG707002 RD-4-3724-0P 77R0650
Paystar, Transtar 1989-95 Radiator Mount ZGG707002 RD-4-3724-0P 77R0650
S Series 1977-92 Radiator Mount High Capacity RD-4-3945-0P 77R0700
S Series 1977-92 Grilldenser RD-4-3714-0P 77R5910
ELECTRICAL SWITCH
C400-900 with Kysor A/C units 1986-93 On-Off Switch 472253-C1 RD-5-3923-0P 71R0050
S Series with Kysor A/C units 1984-93 On-Off Switch 472253-C1 RD-5-3923-0P 71R0050
8300 Series 1989-93 Sleeper A/C Htr.Switch RD-5-0071-0 RD-5-0071-0P 71R0400
9300, 9400, 9600, 9700 Series 1982-99 Blower Switch (Fan) 501087-C3 RD-5-8256-0P 71R0480
All Series with OE # 431606-R1 Main unit 431606-R1 RD-5-6868-0P 71R8301
Fleetstar 2010 - 2050 1974-87 Main unit 1699955-C1 RD-5-8936-0P 71R8430
S Series 1995-01 Main unit with Red Dot A/C 1696846-C2 RD-5-10447-0P 71R8405
S Series 1984-95 Kysor A/C 404098, ZGG12467 RD-5-6868-0P 71R8301
S Series 1984-95 Red Dot A/C RD-5-6868-1, 1676649-C1 RD-5-6868-0P 71R8301
1696846-C2,-C3, 2503783-
2000, 4000, 8000 Series 1995-01 Main unit no nick type (O-ring) valve RD-5-10447-0P 71R8405
C91
2000, 4700, 4900, 8000, 8100, 8200,
1995-99 Main unit 12467Q RD-5-6868-0P 71R8301
8300
1696846-C1,-C2,-C3,
4700 Series 1994-98 Main unit no nick type (O-ring) valve RD-5-10447-0P 71R8405
2503783-C91
5000i, 9100i, 9200i, 9400i, 9900i 2000-10 Main unit No Nick Type Expansion Valve 1699955-C1, 2501794-C92 RD-5-10306-0P 71R8415
5000i, 9100i, 9200i, 9400i, 9900i 2000-02 Main unit No (HD2) Nick Type Expansion Valve 1699955-C1 RD-5-8936-0P 71R8430
8300 Sleeper series 1989-93 Sleeper units 1669337-C1 RD-5-6868-0P 71R8301
9000 - 9900 series 1997-06 Sleeper units 2501794-C92 RD-5-10306-0P 71R8415
9200, 9300, 9400, 9600, 9700, 9800 2000-02 Main unit no nick type (O-ring) valve 2503783C91 RD-5-10447-0P 71R8405
9200, 9300, 9400, 9600, 9700, 9800 1997-99 Main unit 1699955-C1 RD-5-8936-0P 71R8430
9200, 9400 series 1997-98 Pro Sleeper series with flange fittings 1699955-C2 RD-5-10306-0P 71R8415
9200i - 9900i series 2000-10 Sleeper units with flange fittings 2501794-C92 RD-5-10306-0P 71R8415
EXPANSION VALVE / EXTERNAL EQUALIZER
All Series with OE # 2684701-C1 Main unit, all models with flare fitting 2684701-C1 RD-4126-1P 71R8050
S Series (includes Motivair A/C) 1977-88 Main unit, with O-Ring style valve 469475-C1 RD-5-5862-0P 71R8080
Transtar 11 1974-84 Main unit, male flare type 1691711-C1 RD-4126-1P 71R8050
4000 Series 1983-00 Main unit, with O-Ring style valve 1691469-C2 RD-5-5862-0P 71R8080
4070A, 4070B 1974-82 Main unit, with O-Ring style valve 1691469-C2 RD-5-5862-0P 71R8080
4200, 4300 Series 1974-84 Main unit, male flare type 1691711-C1 RD-4126-1P 71R8050
4600 - 4900, 8000, 8100, 8200, 8300 1991-94 Main unit, with O-Ring style valve 1691469-C2 RD-5-5862-0P 71R8080
4600 - 4900, 8000, 8100, 8200, 8300 1991-92 Main unit 469475-C1 RD-5-5862-0P 71R8080
PAGE 128
IHC - NAVISTAR
5000 Series 1973-93 Main unit, male flare type 1691711-C1 RD-4126-1P 71R8050
5000, 7100, 8000, 9200, 9300, 9400,
1982-00 Main unit 1691469-C2 RD-5-5862-0P 71R8080
9600, 9700, 9800
5000, 9100, 9200, 9300, 9400(DAY CABS) 1997-99 Main unit with out Sleeper 1691469-C2 RD-5-5862-0P 71R8080
5000, 7100, 9200, 9300, 9400, 9600,
1991-92 Main unit 469475-C1 RD-5-5862-0P 71R8080
9700
7000 Series 1973-82 Main unit, with O-Ring style valve 1691469-C2 RD-5-5862-0P 71R8080
9000, 9100, 9400 series 1997-99 Day Cabs with O-Ring style valve 1691469-C2 RD-5-5862-0P 71R8080
1691469-C2, 469475-C1,
9000, 9300, 9400, 9600, 9700 Series 1982-96 Main unit RD-5-5862-0P 71R8080
ZGG12029
EA1385, 168903-C1,
2010 - 2050 Series 1974-87 Main unit, all models with flare fitting RD-5-6099-0P 71R8210
393352-C1
4000, 4200, 4300, 7500, 8000, 9000 3548044-C1,
2001-10 Main unit (NGV) - Behr Orifice Tube (purple) RD-5-10757-0P 71R8507
Series BOA8030500949
All models All 1676822-C91 RD-5-4919-0P 71R8500
Main unit
EXPANSION VALVE / SOLENOID VALVE
All models All Main unit 1669329-C1, 1669334-C1 RD-4188-0P 71R9002
FILTER
All Series with OE # 1699956-C1 1995-2010 A/C and heater intake, 13 5⁄8” x 10” x 3⁄4” 1699956-C1 RD-5-10775-0P 78R5308
All Series with mesh filter including bus
Mesh filter 9” x 9” x 5⁄8” ZGG720002 RD-5-10077-0P 78R5236
applications
Mesh filter 22 1⁄2” x 10 1⁄4” x 1⁄4” ZGG720005 RD-5-10081-0P 78R5257
applications
Mesh filter 28 1⁄2” x 7 1⁄8” x 5⁄16” ZGG720006 RD-5-10075-0P 78R5256
applications
Mesh filter 30” x 10 3⁄8” x 3⁄8” ZGG720008 RD-5-10082-0P 78R5255
applications
S Series 1977-93 A/C and heater filter, in cab, 10 1⁄2” x 9 3⁄4” x 3⁄4” 481813-C1, ZGG14513 RD-5-10774-0P 78R5302
498144-C1, ZGG14265,
4000, 7000, 8000 All A/C and heater filter, in cab, 13 1⁄2” x 13” x 3⁄4” RD-5-10773-0P 78R5306
ZGG720007
4070 A & B Series 1980-2000 A/C and heater filter, in cab, 15” x 11” x 3⁄4” 480836-C1 RD-5-10776-0P 78R5304
498144-C1, ZGG14265,
4600 - 4900 Series 1985-01 A/C and heater filter, in cab, 13 1⁄2” x 13” x 3⁄4” RD-5-10773-0P 78R5306
ZGG720007
5000, 8000 and 9000 Series 1995-07 A/C and heater intake, 13 5⁄8” x 10” x 3⁄4” 1699956-C1 RD-5-10775-0P 78R5308
498144-C1, ZGG14265,
5000 and 9000 Series 1991-97 A/C and heater filter, in cab, 13 1⁄2” x 13” x 3⁄4” RD-5-10773-0P 78R5306
ZGG720007
498144-C1, ZGG14265,
7100 - 9700 Series 1982-00 A/C and heater filter, in cab, 13 1⁄2” x 13” x 3⁄4” RD-5-10773-0P 78R5306
ZGG720007
PRESSURE SWITCH
Low pressure switch, normally closed with M12 Female
All with APAds Index #8040136 1998-03 1699310-C1, ‘8040136 RD-5-9991-0P 71R6405
Schrader
All with OE high pressure switch 1993-03 High pressure switch, normally open 210psi, closes 300psi 1514307-C1 RD-5-6430-0P 71R6110
All with OE trinary switch 1993-05 Trinary switch with 7⁄16”-20 female, normally open 1676658-C1 RD-5-4583-0P 71R7550
Trinary switch with 3⁄8”-24 male with bulkhead seal, normally
All with OE trinary switch 1993-05 1691699-C91 RD-5-4585-0P 71R7500
open
Low pressure switch, normally open, closes 42 psi, opens 32
C400-900 with Kysor AC 1986-93 544976-C1 RD-5-4833-0P 71R6030
psi
C400-900 with Kysor AC 1986-93 High pressure switch 544975-C1 RD-5-5873-0P 71R6070
S Series, 8000 Series 1977-93 544976-C1 RD-5-4833-0P 71R6030
psi
PAGE 129
IHC - NAVISTAR
PRESSURE SWITCH
Low pressure switch, normally open 11psi, close 42 psi, 1⁄4”
S Series, 8000 Series 1977-93 442183-C1 RD-5-5877-0P 71R6060
female flare
S, 9000 Series, normally closed high High pressure switch, normally closed 210psi, opens 340 psi,
1984-93 544975-C1 RD-5-5873-0P 71R6070
pressure R-12 switch 1⁄4” female flare
S Series, 9000 Series 1977-93 442183-C1, 544976-C1 RD-5-5877-0P 71R6060
female flare
S Series with Kysor Kombo 1984-93 544976-C1 RD-5-4833-0P 71R6030
psi
S Series with Kysor A/C - Heater 1984-93 High pressure switch 544975-C1 RD-5-5873-0P 71R6070
Transtar 4070A&B, 4200, 4300 Fleetstar Low pressure switch, normally open 11psi, close 39 psi, 1⁄4”
1974-91 442183-C1 RD-5-5877-0P 71R6060
2 female flare
Transtar 4070A&B, 4200, 4300 Fleetstar
1974-91 High pressure switch (normally closed) 544975-C1 RD-5-5873-0P 71R6070
2
Transtar 4070A&B, 4200, 4300 Fleetstar High pressure switch, normally open 250psi, close 375 psi,
1974-91 441821-C1 RD-5-8289-0P 71R6230
2 1⁄4” female flare
Transtar 4070B with Kysor KA 800/ Low pressure switch, normally open, closes 42 psi, opens 32
1977-82 544976-C1 RD-5-4833-0P 71R6030
SD510 10 COMP psi
Transtar 4070B with Kysor KA 800/ High pressure switch, normally closed 210psi, opens 340 psi,
1977-82 544975-C1 RD-5-5873-0P 71R6070
SD510 10 COMP 1⁄4” female flare
Low pressure switch, normally closed 7psi, open 30 psi, 1⁄4”
2000 Series 1989-96 587977-C1 RD-5-6397-0P 71R6020
female flare
High pressure switch, normally open 250psi, close 375 psi,
2000 Series 1983-96 441821-C1 RD-5-8289-0P 71R6230
1⁄4” female flare
2000, 4000 Series 1977-96 442183-C1, 544976-C1 RD-5-5877-0P 71R6060
female flare
High pressure switch, normally closed 210psi, opens 340 psi,
4000 Series 1977-92 480869-C1, 544975-C1 RD-5-5873-0P 71R6070
4070A & B, 4200, 4300 Series 1974-91 441821-C1 RD-5-8289-0P 71R6230
4600-4900, 5000, 8100-8300, High pressure switch, normally closed 205psi, opens 375 psi,
1991-00 1676787-C1, 318000 RD-5-10167-0P 71R6183
9200-9700Series 1⁄4” female flare
4600-4900, 5000, 8100-8300, Low pressure switch, normally closed 5psi, open 35 psi, M10
1991-00 1676786-C1, 318004 RD-5-10166-0P 71R6181
9200-9700Series female flare
5000 Series 1983-93 Low pressure switch (excluding CAT 3406) 544976-C1 RD-5-4833-0P 71R6030
5000 Series 1993-00 1676787-C1, 318000 RD-5-10166-0P 71R6181
Low pressure switch, normally closed 5psi, open 35 psi, M10
5000 Series 1993-00 1676786-C1, 318004 RD-5-10167-0P 71R6183
female flare
Low pressure switch, normally closed 7psi, open 30 psi, 1⁄4”
5000 Series 1989-96 587977-C1 RD-5-6397-0P 71R6020
female flare
5000 Series 1983-96 441821-C1 RD-5-8289-0P 71R6230
5000 Series with Caterpillar 3406 series Low pressure switch, normally open 11psi, close 39 psi, 1⁄4”
1983-93 442183-C1 RD-5-6397-0P 71R6020
engine female flare
5000 Series 1983-93 High pressure switch (with Shutters) 581686-C1 RD-5-6396-0P 71R6090
5000 Series 1983-96 441821-C1 RD-5-8289-0P 71R6230
5000 Series with air controlled engine High pressure switch, normally closed 210psi, opens 340 psi,
1983-93 480869-C1, 544975-C1 RD-5-5873-0P 71R6070
fan 1⁄4” female flare
5000 Series 1977-96 442183-C1, 544976-C1 RD-5-5877-0P 71R6060
female flare
7000, 7100, 8000 Series 1989-99 On -Off switch, A / C Compressor 1661427-C92 RD-5-8459-0P 71R0030
7000, 7100, 8000 Series 1989-94 Low pressure switch (normally closed) 1651985-C1 RD-5-6396-0P 71R6090
PAGE 130
IHC - NAVISTAR
PRESSURE SWITCH
7000, 7100, 8000 Series 1989-94 1651984-C1 RD-5-6833-0P 71R6120
8000 Series 1993-00 1676786-C1, 318004 RD-5-10167-0P 71R6183
female flare
8000 Series 1983-93 1618587-C1, 544975-C1 RD-5-5873-0P 71R6070
8000 Series 1977-93 442183-C1, C2, 587977-C1 RD-5-6397-0P 71R6020
female flare
8100 - 8300 Series 1993-00 1676787-C1, 318000 RD-5-10166-0P 71R6181
8300 Series 1989-93 88NT Engine High pressure switch 544975-C1 RD-5-5873-0P 71R6070
9000 Series, normally closed high High pressure switch, normally closed 210psi, opens 340 psi,
1989-95 544975-C1 RD-5-5873-0P 71R6070
pressure R-12 switch 1⁄4” female flare
9000, 9600 (Hi pressure - A6 GM High pressure switch, normally closed 210psi, opens 340 psi,
1982-95 1618587-C1 RD-5-5873-0P 71R6070
compressor) Series 1⁄4” female flare
9200, 9900 Series 1993-00 1676787-C1, 318000 RD-5-10166-0P 71R6181
9200, 9900 Series 1991-02 1676786-C1, 318004 RD-5-10167-0P 71R6183
female flare
9200, 9300, 9400, 9900 Series 1985-00 442183-C1, C2, 587977-C1 RD-5-6397-0P 71R6020
female flare
9300, 9400 Series 1985-93 442183-C1 RD-5-5877-0P 71R6060
female flare
9300, 9400 Series 1985-93 High pressure switch (with Shutters & Tecumseh COMP) 581686-C1 RD-5-6396-0P 71R6090
9300, 9400 Series 1983-96 441821-C1 RD-5-8289-0P 71R6230
9600, 9700 Series (all with Tecumseh Low pressure switch, normally open 11psi, close 39 psi, 1⁄4”
1982-93 442183-C1 RD-5-5877-0P 71R6060
Compressor) female flare
9600, 9700 Series (Exc. withTecumseh Low pressure switch, normally open 11psi, close 39 psi, 1⁄4”
1982-93 442183-C1 RD-5-5877-0P 71R6060
Compressor) female flare
RECEIVER DRIER
C400-900 1986-91 2 3⁄4”x10”, #6MOR in, #6 MOR out, PRV, Top Glass, Side Port 1676653-C1 RD-5-3593-0P 74R1756
CXT/MXT/RXT Truck, Military, Lonestar,
ALL Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
Cut Away Commercial Bus
Fleetstar 2010, Fleetstar 2050 - FL 1974-80 3”x6 1⁄4”, #6FOR in, #6 FOR out, PRV, Top Glass, Side Port 301319-C91, ZGG11816 RD-5-3843-0P 74R2526
Fleetstar 2010, Fleetstar 2050 - OR 1980-82 3”x6 1⁄4”, #6FOR in, #6 FOR out, PRV, Top Glass, Side Port 1691710-C91 RD-5-3843-0P 74R2526
2 3⁄4”x10”, #6MOR in, #6 MOR out, PRV, Fuse Port, Top Binary
Paystar, 6300 Series 1981-85 124552-C1 RD-5-9455-0P 74R1836
Switch
Paystar 6300 Series Conventianal w/
1984-92 2 3⁄4”x10”, #6 MOR in, #6 MOR out, PRV, 3⁄8-24 Top Switch Port 1676651-C1 RD-5-3593-1P 74R1706
Evans Combo A/C
Conventional Limited, ProStar ALL Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
S Series 1984-92 with 11⁄16” X 3⁄8” Female O-Ring, 3” X 10” 088048-02 RD-5-4959-0P 74R3450
S Series with Kysor Combo A/C 1984-92 3”x6 1⁄4”, #6FOR in, #6 FOR out, PRV, Top Glass, Side Port 1691710-C91 RD-5-7061-2P 74R2526
S Series 1984-92 3”x6 1⁄4”, #6FOR in, #6 FOR out, PRV, Top Glass, Side Port 088424-01, 402568 RD-5-7061-2P 74R2526
S Series (Exc. with Cummins 88NT
1977-91 3”x10”, 11⁄16” FOR in, #6 FOR out, PRV, Top Glass 454613-C1 RD-5-4959-0P 74R3450
engine)
Transtar 4070A, 4070B, Transtar II, 4200 1973-84 3”x10”, 11⁄16” FOR in, #6 FOR out, PRV, Top Glass 454613-C1 RD-5-4959-0P 74R3450
Transtar 4070B with Kysor KA800 A/C
1973-84 3”x8 1⁄4”, #6 MOR in, #6 MOR out, PRV, Side Glass, Top Port 1676663-C1 RD-5-4955-0P 74R2706
unit
2000, 4000, 5000, 8000, 9000 Series 1973-03 3”x10”, 11⁄16” FOR in, #6 FOR out, PRV, Top Glass 2000821-C1 RD-5-4959-0P 74R3450
2000, 4000, 8000, 9000 Series 1993-01 3”x10”, QD In, QD out, PRV, Top Glass, R134A Service Port 2004050C1 RD-5-10741-0P 74R3319
PAGE 131
IHC - NAVISTAR
RECEIVER DRIER
2000, 4600-4900, 5000, 8100-8300, 3”x10”, 11⁄16” FOR in, #6 FOR out, PRV, Top Glass, R134A Service
1993-00 1693117-C1 RD-5-12757-0P 74R3455
9200-9700 Port
3200 Commercial Bus Chassis ALL Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
4600-4900, 5000, 8100-8300, 1991-00 3”x8 1⁄4”, #6 MOR in, #6 MOR out, PRV, Side Glass, Top Port 1676663-C1 RD-5-4955-0P 74R2706
4000, 7100, 8100, 8300, 9300, 9400 (Exc
1977-1991 3”x10”, 11⁄16” FOR In, #6 FOR out, PRV, Top Glass RD-5-4959-0P 74R3450
with Cummins 88NT engine)
4100/4200/4300/4400 Medium Truck,
ALL Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
8500, 8600
4200, 4300, 4400, 7300, 7400, 7500, Accumulator, Aluminum, 3 1⁄2”x9 1⁄8”, Pad Fittings w/studs,
2001-07 3542577-C2 RD-5-12623-0P 74R5097
7600, 8500, 8600 Series M12 Switch Port, w/mounting bracket
Paystar F5000 1974-92 3”x10”, 11⁄16” FOR In, #6 FOR out, PRV, Top Glass 454613-C1 RD-5-4959-0P 74R3450
7300 Severe Service After 10/1/01 Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
7400/7500 Severe Service After 7/1/01 Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
7600 Severe Service After 4/1/02 Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
After
7700 Severe Service Receiver/Drier, Aluminum, Pad W/Stud x #6 Tube Insert 3670134-C1 RD-5-13206-0P 74R5401
12/15/03
9000 Series All 3”x10”, 11⁄16”, QD in, QD out, Moisture Ind, (2) M10 Switch Ports 1607149-C2 RD-5-10941-0P 74R3321
9000 Series All Quick disconnect, #6 male, #6 female outlet, 2 M10 ports RD-5-9793-0P 74R3318
3”x10”, 11⁄16” FOR in, #6 FOR out, PRV, Top Glass, R134A Service
9000i Series 2001-2007 1693117-C1 RD-5-12757-0P 74R3455
Port
3”X8 1⁄4”, #6 MOR in, #6FOR out, PRV, Top Glass, Moisture ind,
Transtar 4200, Transtar 4300 1974-80 426169-C1 RD-5-10735-0P 74R3156
1⁄4” Top Switch Port (2)
3200, 4100, 4200, 4300, 4400, 7700, Accumulator, Aluminum, Pad Fittings W/Studs, W Mounting
ALL 3542577-2 RD-5-12623-0P 74R5097
8500, 8600, CXT, MXT, RXT Bracket
After Accumulator, Aluminum, Pad Fittings W/Studs, W Mounting
7300 3542577-2 RD-5-12623-0P 74R5097
10/102001 Bracket
7400, 7500 3542577-2 RD-5-12623-0P 74R5097
7/1/2001 Bracket
7600 3542577-2 RD-5-12623-0P 74R5097
4/1/2002 Bracket
7700 3542577-2 RD-5-12623-0P 74R5097
12/15/2003 Bracket
Accumulator, Aluminum, Pad Fittings W/Studs, W Mounting
Cut Away Commercial Bus ALL 3542577-2 RD-5-12623-0P 74R5097
Bracket
Accumulator, Aluminum, Pad Fittings W/Studs, W Mounting
Conventional Limited, ProStar ALL 3542577-2 RD-5-12623-0P 74R5097
Bracket
RELAY
with Kysor A/C (mini relay), Bosch type (30 amp), SPST, 5
C400-900 1986-93 RD-5-6452-0 RD-5-4408-0P 71R1702
terminals
5000, 8000, 9300, 1982-94 EXC. 5000 Series Below, relay (30 amp), SPST, 5 terminals 447186C1 RD-5-10154-0P 71R1922
RESISTOR
S Series, 8000 Series 1977-93 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
Transtar 4070A & B, 4200/4300 Fleetstar 1974-91 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
2000, 4000, 8000 Series 1991-01 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
2000, 4600, 4700, 4900, 8100, 8200,
1991-99 Blower Resistor 1696836-C1 RD-5-10341-0P 71R1457
8300
5000 Series 1983-90 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
5000, 7100, 9200, 9300, 9400, 9600,
1991-96 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
9700, 9800
5000i, 9100i, 9200i, 9400i, 9900i 2000-04 Main unit Resistor 12V 3 speed 2500918-C1 RD-5-10341-0P 71R1457
PAGE 132
IHC - NAVISTAR
RESISTOR
9100, 9200, 9300, 9400(DAY CABS) 1997-99 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
9200, 9300, 9400, 9600, 9700, 9800 1997-99 Main unit Resistor 12V 3 speed 2500918-C1 RD-5-10341-0P 71R1457
9300, 9400, 9600, 9700 Series 1985-90 Blower Resistor 506552C1 RD-5-9916-0P 71R1460
SOLENOID VALVE - EXPANSION VALVE
All models Main unit 1669329-C1, 1669334-C1 RD-4188-0P 71R9002
THERMOSTATIC SWITCH
All Series with IHC-Navistar OE #
Fixed setting thermostat, 25” cap tube 1676655-C91, 1691722-C91 RD-5-4531-24P 71R3200
1676655-C91, 1691722-C91
All Series with IHC-Navistar OE # Fixed Setting thermostat with 24” capillary tube, flange
1691726-C91, 3093422 RD-4427-24P 71R3100
1691726-C91 mount
All Series with IHC-Navistar OE # Fixed Setting thermostat with 16” capillary tube, flange 1691729-C91, BOA-80-
RD-5-6429-0P 71R3150
1691729-C91 mount 946-00-079
Rotary thermostat, 36” capillary tube 175575-C1 RD-4125-36P 71R2250
175575-C1
All Series with IHC-Navistar OE # 301305-
Rotary thermostat with 48” capillary tube, 34 - 52°F 301305-C91 RD-4125-48P 71R2300
C91
Cable controlled thermostat, 30” cap tube 445444-C1 RD-4226-0P 71R2700
445444-C1
All Series with IHC-Navistar OE # A45-
All Models with factory air with rotary switch A45-1033, 13011-C2 RD-5-4909-0P 71R2100
1033, 13011-C2
Fleetstar, Transtar 4070A 1971-81 Rotary thermostat, 36” cap tube 446994-C1 RD-4125-36P 71R2250
Fleetstar, Transtar 4070B, 4200, 4300 1974-84 Cable controlled thermostat, 30” cap tube 436998-C91 RD-4226-0P 71R2700
RD-5-4531-24P,
S Series 1984-98 Red Dot Models, fixed setting thermostat, 24” cap tube RD-5-4531-24P 71R3200
ABP N83 323010
S Series 1984-98 Kysor Models, fixed setting thermostat, 24” cap tube ZGG716010 RD-5-4531-24P 71R3200
S Series 1984-91 Motovair Econo Models, rotary thermostat, 48” cap tube ZGG14812 RD-4125-48P 71R2300
S Series 1982-89 Motovair A/C Models, fixed setting thermostat, 25” cap tube 1676655-C1 RD-5-8257-0P 71R3300
2000 Series 1974-81 Rotary thermostat, 36” cap tube 446994-C1 RD-4125-36P 71R2250
2000, 4000, 4600, 4700, 4900, 5000,
7100, 7400, 8000, 9000, 9200 - 9800, 1989-01 Fixed setting thermostat, 25” cap tube 1664248-C1 RD-5-8257-0P 71R3300
9900
4000 Series, 4070, 4200, 4300 1973-85 Cable controlled thermostat, 43” cap tube 581691-C1 RD-5-4917-0P 71R2800
After Thermostat, Fixed, 25” Capillary, 34°-44°, W/Threaded
5000, 9200, 9900 1699953-C1 RD-5-8257-0P 71R3300
3/15/1996 Mountinf Holes
5000, 7100, 9000, 9100, 9200, 9300,
1973-01 Cable controlled thermostat, 43” cap tube 581691-C1 RD-5-4917-0P 71R2800
9400, 9600, 9700(Day Cab)
5500i, 5600i, 5900i, 9100, 9300, 9400, Thermostat, Fixed, 25” Capillary, 34°-44°, W/Threaded
ALL 1699953-C1 RD-5-8257-0P 71R3300
9800 Mountinf Holes
851691-C1,
9200, 9300, 9400, 9600, 9700, 9800 1977-1999 Cable operated 581691-C1,454347- RD-5-4917-0P 71R2800
C1,592231-C1,BSM323003
WATER VALVE
Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose 899996-R91 RD-5-4257-0P 72R5050
899996-R91
Manual valve for 5⁄8” hose to 5⁄8” hose ZGG14525 RD-5-5192-0P 72R5500
ZGG14525
S Series 1977-95 Red Dot A/C Units, cable operated RD-5-5300-0P RD-5-5300-0P 72R5200
8300 Series 1989-94 Sleeper Box with Heater Valve 1669333-C92 RD-5-8935-0P 72R6510
KENWORTH
BLOWER, FAN BLADE
All series with OE # HC1090, RD3133-9 Bergstrom, Kysor and Red Dot A/C, 6” diameter, CW HC1090, RD3133-9 RD-3133-9P 73R8050
PAGE 133
KENWORTH
BLOWER MOTOR
All series with Bergstrom A/C, OE #
Bergstrom A/C, single shaft, 4 3⁄4” length BSM203115 RD-5-5512-0P 73R0912
BSM203115
Bergstrom A/C, all with single shaft, 1 speed, 4” length 20322P, 20332P RD-5-10390-0P 73R0212
20322P, 20332P
Bergstrom A/C, double shaft, 1 speed, 4 3⁄4” length 20578P, 5577-22 RD-5-6801-0P 73R4182
20578P, 5577-22
All series with Bergstrom A/C, Kenworth
All with single shaft, 2 speed, CW, 4 1⁄4” length 20132P RD-3106-12P 73R0552
OE # 20132P
Bergstrom A/C, single shaft motor, 1 speed, 5” length 20152P1, 20302P RD-5-9100-0P 73R0462
OE # 20152P1, 20302P
Bergstrom A/C, 24V single shaft motor, 1 speed, 4 3⁄4” length 20193P1, 20303P RD-5-8073-24P 73R0474
OE # 20193P1, 20303P
All series with Bergstrom A/C, Kenworth Bergstrom A/C, 24V single shaft motor, 1 speed, CCW, 5”
20333P RD-5-4827-24P 73R0404
OE # 20333P length
All series with Kenworth OE # HA1520, HA1520, 20562P,
Bergstrom - Kysor A/C, single shaft, 1 speed, CW, 4 5⁄8” length RD-5-10905-0P 73R0442
BSM205620 BSM205620
All series with Kysor A/C, OE # 205840, 205840, BSM203085,
Kysor A/C, double shaft motor, 1 speed, 4 7⁄8” length RD-5-10068-0P 73R4322
BSM203085, 2809-551-007 2809-551-007
All series with Kysor A/C, OE # 273140,
273140, 274238, 2807-516-
274238, 2807-516-039, 2807-517-041, Kysor A/C, single shaft motor, 1 speed, 5” length RD-5-9100-0P 73R0462
039, 2807-517-041, 043
043
All series with Kysor A/C, OE # 2807-
Kysor A/C, single shaft motor, 1 speed, 5” length 2807-517-019 RD-5-6526-1P 73R0402
517-019
All series with OE # HA1520 1987-99 Sleeper Unit HA1520 RD-5-5230-0P 73R0522
All series with OE # 2807-508-043 1973-86 Sleeper Unit 2807-508-043 RD-3106-18P 73R0202
C500 Series 1997-07 Main unit, double shaft motor, 1 speed, 4 7⁄8” length 203134BSM, BSM203235 RD-5-10068-0P 73R4322
C500 Series 1980-09 Main unit, double shaft motor, 1 speed, 4 3⁄4” length BSM203080, K318-20-1 RD-5-6801-0P 73R4182
C500 Series 1995-03 Main unit, double shaft motor, 1 speed, 4 3⁄4” length HB1610 RD-5-6801-0P 73R4182
C500 Series 1979-00 All with single shaft, 1 speed, CCW, 5” length 2807-517-019, HA1120 RD-5-6526-1P 73R0402
HA1060, HA1605, 301072,
C500 Series 1978-00 Main unit, all with single shaft, 1 speed, CCW, 4 3⁄4” length RD-5-10746-0P 73R1012
301001
C500 Series 1995-99 Main unit, all with single shaft, 1 speed, CCW, 4 3⁄4” length HA1605 RD-5-10746-0P 73R1012
C500 Series 1995-97 Main unit (Red Dot) with single shaft, 4 3⁄4” length RD-5-6526-0P 73R0422
C500 Series 1976-79 Main unit, all with single shaft, 1 speed, CW, 5” length HA1180 RD-5-9100-0P 73R0462
274265, 2809-541-006,
C500 Series, Brute 1980-87 Main unit RD-5-6531-0P 73R0322
HA1700
C500 Series, Brute 1980-86 Main unit (Kysor) 274265 RD-5-5634-0P 73R0922
C500 Series, Brute 1980-85 Main unit (Kysor), single shaft, 1 speed, CW, 4 5⁄8” length 274341 RD-5-10905-0P 73R0442
Main unit (Red Dot) with single shaft, 2 speed, CW, 4 1⁄4”
C500 Series, Brute 1976-79 2030-12, RD-3106-12 RD-3106-12P 73R0552
length
C500, T-Series, W900 1980-09 Main unit, 12V, double shaft motor, 1 speed, 4 3⁄4” length HB1050, PF2646Q RD-5-6801-0P 73R4182
C500, T300, T600, T800, W900 1995-10 Bergstrom A/C, double shaft motor, 1 speed, 5 1⁄4” length 203080 RD-5-5049-1P 73R4422
C500, T400, T600, T800, W900 1986-94 Main unit, double shaft, 4 13⁄16” length 205780 RD-5-5121-0P 73R4252
C500, T400, T600, T800, W900 1995-10 Main unit, 12V, double shaft motor, 1 speed, 4 3⁄4” length HB1050, PF2646Q RD-5-6801-0P 73R4182
BSM201520, 203012P,
K100 Models 1974-85 Main unit, all with single shaft, 1 speed, CW, 5” length RD-5-9100-0P 73R0462
20302P, 2807-516-039
K100, K100E Series 1983-07 Bergstrom A/C, double shaft motor, 1 speed, 4 3⁄4” length BSM203085 RD-5-10068-0P 73R4322
BSM203080, BSM205840,
K100, K100E 1983-07 Main unit, 12V, double shaft motor, 1 speed, 4 3⁄4” length RD-5-6801-0P 73R4182
2809-541-009
K100, K100E Series all with OE# 203076,
1983-07 Double shaft motor, 1 speed, 4 3⁄4” length 203076, 2809-551-007 RD-5-10068-0P 73R4322
2809-551-007
20584P, 274271, HB1100,
K100C Models 1980-85 Double Shaft Motor, 1 speed, 5 1⁄4” length RD-5-5049-1P 73R4422
PF2865Q, PF28103Q
PAGE 134
KENWORTH
BLOWER MOTOR
K100C Models 1980-86 Double Shaft Motor, 1 speed, 5 3⁄8” length PF28193Q, 1099017 RD-5-10073-0P 73R4312
L700 1978-86 Main unit 2809-841-008 RD-5-5121-0P 73R4252
L700 1978-86 Main unit, double shaft with Red Dot A/C, (evaporator motor) HB1070, RD-5-5614-0 RD-5-5614-0P 73R4062
Main unit with Red Dot A/C (Condenser motor), 4 3⁄4” 301072, HA1060, RD-5-
L700 1978-86 RD-5-10746-0P 73R1012
diameter, CCW, single speed 10746-0
Sleeper series except T2000 1997-10 Sleeper Unit 203115 RD-5-8212-0P 73R0222
Sleeper series (modular) except T2000 1995-07 Sleeper Unit (Modular), single shaft, 4 3⁄4” length 203076 RD-5-5512-0P 73R0912
Sleeper series (integral) except T2000
1996-06 Sleeper Unit (integral), single shaft, 4 11⁄16” length 203115, 1014005 RD-5-10392-0P 73R0232
with Bergstrom A/C # 203115
Sleeper series with Bergstrom A/C #
1997-10 Sleeper Unit (Bergstrom), single shaft, 4 3⁄4” length BSM203115 RD-5-5512-0P 73R0912
BSM203115
Sleeper series with Kenworth OE #
1995-96 Sleeper unit, all with single shaft, 1 speed, CCW, 4 3⁄4” length HA1605 RD-5-5512-0P 73R0912
HA1605
1987-94 Sleeper unit, all with single shaft, 1 speed, CW, 4 5⁄8” length HA1520 RD-5-10905-0P 73R0442
HA1520
1973-86 Sleeper unit, all with single shaft, 1 speed, 4” length HA1040 RD-5-10390-0P 73R0212
HA1040
Sleeper series with Red Dot OE # RD-
1973-86 Sleeper unit, all with single shaft, 1 speed, 3 7⁄8” length RD-3106-18 RD-3106-18P 73R0202
3106-18
BSM203080, HB1035-50,
T300, T300 COMBO, T800 1995-10 Main unit (Bergstrom), double shaft, 4 3⁄4” length RD-5-6801-0P 73R4182
PF2646Q
T300 - T800, W900 1995-10 Main unit (Bergstrom), double shaft, 4 3⁄4” length HB1610 RD-5-6801-0P 73R4182
T300 - T800, W900 1996-01 Bergstrom A/C, double shaft motor, 1 speed, 4 3⁄4” length BSM203085 RD-5-10068-0P 73R4322
T300 - T800 1995-97 Bergstrom A/C, single shaft motor, 1 speed, 5” length 2807-517-019, HA1120 RD-5-6526-1P 73R0402
T400 - T800 1995-10 Main unit, double shaft, 4 3⁄4” length HB1050 RD-5-6801-0P 73R4182
T400, T600, T800, W900 1995-10 Main unit, all with single shaft, 1 speed, CCW, 4 3⁄4” length HA1605 RD-5-10746-0P 73R1012
T600 with Caterpillar NSX 31153 engine 1995-10 Bergstrom A/C, double shaft motor, 1 speed, 5 1⁄4” length 203080 RD-5-5049-1P 73R4422
T600 1995-97 Main unit (Red Dot) with single shaft, 4 3⁄4” length RD-5-6526-0P 73R0422
T2000 1996-09 Main unit (Bergstrom), single shaft with strap mounting BSM871218, 203142 RD-5-8922-0P 73R0612
T2000 1996-09 Main unit (Bergstrom), single shaft with strap mounting BSM203142 RD-5-10867-0P 73R0332
T2000 1996-09 Sleeper Unit (Bergstrom), single shaft with strap mounting BSM203139 RD-5-8922-0P 73R0612
T2000 1996-01 Sleeper Unit (Bergstrom), single shaft BSM203115 RD-5-5512-0P 73R0912
T2000 1999-05 Main unit (Bergstrom), double shaft, 4 3⁄4” length HB1035, HB1050, PF2646Q RD-5-6801-0P 73R4182
W900 1980-10 Main unit (Bergstrom), double shaft, 4 3⁄4” length BSM203080 RD-5-6801-0P 73R4182
W900 1995-97 Bergstrom A/C, single shaft motor, 1 speed, 5” length 2807-517-019, HA1120 RD-5-6526-1P 73R0402
W900 1974-83 Red Dot A/C, single shaft motor, 1 speed, 5” length RD-5-6526-1 RD-5-6526-1P 73R0402
274265, 2809-541-006,
W900 1978-81 All with single shaft motor, 1 speed, 4 1⁄2” length RD-5-6531-0P 73R0322
HA1700
13-210 Midranger 1987-93 Main unit, double shaft motor, 1 speed, 4” length RD-5-5614-0 RD-5-5614-0P 73R4062
BLOWER RELAY
All model series with OE # 221568,
1986-10 Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. 221568, 652420, CB1005 RD-5-4408-0P 71R1702
652420, CB1005
1986-10 Bosch style relay, 24V, SPDT, 5 terminals, 20⁄10 amp. 221711, 650690 RD-5-4417-0P 71R1704
650690
All model series with Red Dot A/C, OE #
1986-10 Twin temp relay, 12V, 8 terminal CB1015, RD-4370-0 RD-4370-0P 71R1652
CB1015, RD-4370-0
Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. RD-5-4408-0 RD-5-4408-0P 71R1702
RD-5-4408-0
Bosch style relay, 24V, SPDT, 5 terminals, 20⁄10 amp. RD-5-4417-0 RD-5-4417-0P 71R1704
RD-5-4417-0
All model series with Red Dot A/C, Bunk
1986-10 Bunk relay, 12V, 8 terminals, 15 amp. CB1010, RD-5-5027-1 RD-5-5027-1P 71R1802
relay, OE # RD-5-5027-1
PAGE 135
KENWORTH
BLOWER RESISTOR
T2000 1986-10 Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. CB1115 RD-5-4408-0P 71R1702
BLOWER RESISTOR
C500, K100E, W900B, W900T 1995-09 Bergstrom A/C units, 3 terminal, 3 speed 650179 RD-5-10341-0P 71R1457
C500, K100E, T400-800, W900B 1980-97 Bergstrom A/C units, 3 terminal, 3 speed 650790 RD-5-3647-0P 71R1450
C500, K100E, T400-800, W900B 1980-86 Red Dot speed control resistor, 3 terminal, 3 speed RD-5-3647-0 RD-5-3647-0P 71R1450
C500, T400-800, W900B 1980-85 Kysor A/C units, 3 terminal, 3 speed CA1010, 220990KB RD-5-10441-0P 71R1463
BLOWER SWITCH
All model series with Red Dot A/C, OE # Red Dot A/C units, rocker, 5 terminal, 15 amp, DPDT with
RD-4151-2 RD-4151-2P 70R0550
RD-4151-2 jumper
All model series with Red Dot A/C, OE # RD-4151-4, BA1040,
Red Dot A/C units, rocker, 6 terminal, 15 amp, DPDT RD-4151-4P 71R0600
RD-4151-4 K301-19
Red Dot A/C units, toggle, 5 terminal, ON-OFF-ON, DPDT BE1005, RD-4225-2 RD-4225-2P 71R0300
RD-4225-2
All model series with Red Dot A/C, OE # 223183, BA1030, RD-5-
Red Dot A/C units, toggle, 5 terminal, ON-OFF-ON, DPDT RD-5-3599-0P 71R0250
RD-5-3599-0 3599-0P
All model series with Red Dot A/C, OE # 650609, BA1065, BA1390,
Red Dot A/C units, rotary 5 terminal, 4 position, DP3T RD-5-3646-0P 71R1150
RD-5-3646-0 RD-5-3646-0
C500, K100, T400-800, W900B 1995-05 Fan Override Switch (grey) RD-5-8218-0 RD-5-8218-0P 71R6160
Bergstrom A/C units, toggle, 5 terminal, 4 position, SPST,
C500, K100E, W900B 1981-00 BA1005 RD-5-10056-0P 71R0453
bent lever
C500, K100, T400-800, W900B 1981-97 Circuit breaker, 15 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset CC1015, K1110-0548-15 RD-5-6602-0P 71R1310
C500, K100, T400-800, W900B 1981-97 Circuit breaker, 20 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset K1110-0548-20 RD-5-6714-0P 71R1315
C500, K100, T400-800, W900B 1981-97 Circuit breaker, 30 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset CC1020, K1110-0552-30 RD-5-5874-0P 71R1300
BE1025, K301-89, RD-
C500, K100, W900 series Red Dot A/C units, toggle, 3 terminal, ON-OFF-ON, SPDT RD-4225-1P 71R0150
4225-1
C500, W900B 1980-86 Kysor A/C units, toggle, 5 terminal, 4 position, SPST 221503KB, BA1000 RD-5-6804-0P 71R0460
C500, W900 model series with Red Dot
Red Dot A/C units, rocker, 3 terminal, 15 amp, SPDT BA1295, RD-4151-1 RD-4151-1P 71R0500
A/C, OE # RD-4151-1
K100 Series 1980-00 Red Dot A/C units, toggle, 5 terminal, 4 position, SPST BA1205, RD-5-4694-1 RD-5-4694-1P 71R0450
K100 Series 1980-86 Red Dot A/C units, toggle, 5 terminal, 4 position, SPST 1050, BA1205, RD-5-4694-1 RD-5-4694-1P 71R0450
T2000 series with Bergstrom A/C, OE#
1996-05 Bergstrom A/C units, micro switch 650471, 652100, BA1045 RD-5-8490-0P 71R1610
650471, 652100, BA1045
T2000 series with Signet A/C, OE#
1996-05 Fan Override Switch (grey), Signet A/C RD-5-8218-0 RD-5-8218-0P 71R6160
RD-5-8218-0
T2000 series, OE# CC1015, K1110-0548-
1996-05 Circuit breaker, 15 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset CC1015, K1110-0548-15 RD-5-6602-0P 71R1310
15
T2000 series, OE# CC1020, K1110-
1996-05 Circuit breaker, 30 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset CC1020, K1110-0552-30 RD-5-5874-0P 71R1300
0552-30
T2000 series, OE# K1110-0548-20 1996-05 Circuit breaker, 20 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset K1110-0548-20 RD-5-6714-0P 71R1315
W900 Series with Kysor A/C, OE#
1981-00 Kysor A/C units, toggle, 5 terminal, 4 position, SPST 221503KB, BA1000 RD-5-6804-0P 71R0460
221503KB, BA1000
W900 Series with Bergstrom A/C, OE#
1981-99 Bergstrom A/C units, toggle, 5 terminal, 4 position, SPST 322000 RD-5-6804-0P 71R0460
322000
BLOWER WHEEL
All model series with OE # 1-1033Q,
Bergstrom A/C with 5 1⁄4” single entry wheel, 2 1⁄2” width 1-1033Q, HC1025, HC1340 RD-3106-39P 73R6151
HC1025, HC1340
All model series with OE # 1-1034Q,
1-1034Q, 302081, 529800,
302081, 529800, 571040, HC1285, All with 5 1⁄4” single entry wheel, 3 7⁄16” width RD-5-3800-1P 73R6251
571040, HC1285, HF1060
HF1060
All model series with OE # 1-6307Q, 1-6307Q, HC1015, HC1020,
Bergstrom A/C with 5 1⁄4” double entry wheel, 3 3⁄4” width RD-3-2557-2P 73R7151
HC1020, HC1300 HC1300
All model series with OE # 260680, Kysor Class Six A/C, double entry, 3 3⁄16” diameter x 3 3⁄16”
1988-93 260680, HC1290 RD-5-5656-0P 73R7000
HC1290 width
PAGE 136
KENWORTH
BLOWER WHEEL
All model series with OE # 302042 Bergstrom A/C with 4 1⁄2” double entry wheel, 3 3⁄8” width 302042 RD-5-10346-0P 73R7130
1986-2008 All with 4 1⁄2” double entry wheel, 3 3⁄8” width 589540, 589540P RD-5-10346-0P 73R7130
589540P
All model series with OE # HC1015 Bergstrom A/C with 5 1⁄4” single entry wheel, 3 1⁄2” width HC1015 RD-5-8618-0P 73R6051
All model series with OE # HC1075 Bergstrom A/C with 3 3⁄4” double entry wheel, 3 7⁄8” width HC1075, 1199001 RD-5-3933-1P 73R7101
All model series with OE # HC1325, HC1325, HC1405, 260822,
Bergstrom A/C with 5 3⁄4” single entry wheel, 3” width RD-5-5601-0P 73R6370
HC1405, 260822, 260830 260830
All model series with OE # HC1350, RDH
1987-96 with Red Dot A/C, double entry, 3 3⁄16” diameter x 3 3⁄16” width HC1350, RDH RD5 5656 0 RD-5-5656-0P 73R7000
RD5 5656 0
All model series with OE # RD-3106-14,
Red Dot A/C with 5 1⁄4” single entry wheel, 2 1⁄2” width RD-3106-14, RD-3106-39 RD-3106-39P 73R6151
RD-3106-39
Red Dot A/C with 5 1⁄4” single entry wheel, 3 7⁄16” width RD-3106-15, RD-5-3800-1 RD-5-3800-1P 73R6251
RD-5-3800-1
Red Dot A/C with 5 1⁄4” single entry wheel, 3 1⁄2” width RD-3106-9, RD-5-8618-0 RD-5-8618-0P 73R6051
RD-5-8618-0
All model series with OE # RD-3-2557-0 Red Dot A/C with 5 1⁄4” double entry wheel, 3 3⁄4” width RD-3-2557-0 RD-3-2557-2P 73R7151
All model series with OE # RD-5-3933-1 Red Dot A/C with 3 3⁄4” double entry wheel, 3 7⁄8” width RD-5-3933-1 RD-5-3933-1P 73R7101
All model series with OE # RD-5-5601-0 Red Dot A/C with 5 3⁄4” single entry wheel, 3” width RD-5-5601-0 RD-5-5601-0P 73R6370
Main unit (Bergstrom) with 4 1⁄2” double entry wheel, 3 3⁄8”
C500 model series with OE # 589540 1986-06 589540 RD-5-10346-0P 73R7130
width
C500 model series with OE # HC1050 1986-94 Main unit with 4 1⁄2” double entry wheel, 3 3⁄8” width HC1050 RD-5-10346-0P 73R7130
K100, Mid-Ranger 1980-85 Main unit (Bergstrom A/C) HC1300 RD-3-2557-2P 73R7151
K100E 1980-85 Main unit (Red Dot A/C) RDH RD3 2557 2 RD-3-2557-2P 73R7151
Sleeper Units with Bergstrom A/C. OE# with Bergstrom A/C with 5 1⁄4” single entry wheel, 3 7⁄16”
1987-07 HC1285, 52480P RD-5-3800-1P 73R6251
HC1285, 52480P width
Sleeper Units with Bergstrom A/C. OE#
1987-99 with Bergstrom A/C 52980P RD-5-5263-0P 73R6230
52980P
Sleeper Units with Red Dot A/C OE#
1973-86 Red Dot A/C with 5 1⁄4” single entry wheel, 2 1⁄2” width HC1025, RDH RD3106 14 RD-3106-39P 73R6151
HC1025, RDH RD3106 14
T300 Combo 1995-03 Main unit with 4 1⁄2” double entry wheel, 3 3⁄8” width HC1050 RD-5-10346-0P 73R7130
T300, T400, T600, T800, W900 1986-10 589540 RD-5-10346-0P 73R7130
width
HC1000, HC1030, 1-4955Q,
T400, T600, T800, W900 1980-95 Main unit (Kysor) with 4 1⁄2” double entry wheel, 3 3⁄8” width RD-5-10346-0P 73R7130
360480
T400, T600, T800, W900 1986-94 Main unit with 4 1⁄2” double entry wheel, 3 3⁄8” width HC1050 RD-5-10346-0P 73R7130
T600 with Caterpillar NSX 31153 engine 1986-10 589540 RD-5-10346-0P 73R7130
width
T600, T800 1995-97 Main unit with 5 1⁄4” single entry wheel, 3 7⁄16” width HC1620, 52480P RD-5-3800-1P 73R6251
Main, Sleeper Unit (Bergstrom) with 4 1⁄2” double entry
T2000 Series 1995-06 563500, HC1050 RD-5-10346-0P 73R7130
wheel, 3 3⁄8” width
Main unit (Bergstrom A/C) with 4 1⁄2” double entry wheel, 3
W900 1986-10 589540 RD-5-10346-0P 73R7130
3⁄8” width
13-210 Mid-Ranger 1987-93 260680, HC1290 RD-5-5656-0P 73R7000
width
13-210 Mid-Ranger 1987-96 Red Dot A/C, double entry, 3 3⁄16” diameter x 3 3⁄16” width HC1350, RDH RD5 5656 0 RD-5-5656-0P 73R7000
CLUTCH ASSEMBLY
FitsCCI/York - R12/134A compressors 1 groove, 1⁄2” width, 6” diameter, weatherpak plug K332-62-2, KA1095 RD-5-4966-0P 75R0302
FitsCCI/York - R12/134A compressors 1 groove, 3⁄4” width, 6 3⁄4” diameter pulley, bullet plug K332-31, K332-62-1 RD-5-4993-0P 75R4352
K332-14, 19, 24, 27, 37, 44,
FitsCCI/York - R12/134A compressors 2 groove, 1⁄2” width, 6” diameter, weatherpak plug RD-5-4972-1P 75R1202
KA1040
FitsCCI/York - R12/134A compressors 2 groove, 1⁄2” width, 6” diameter, 1 wire plug K332-24 RD-5-4972-1P 75R1202
2 groove, 1⁄2” width, 6” diameter, 1 5⁄8” gauge line, metripak K332-59-5, KA1525, 024
plug 25238
PAGE 137
KENWORTH
CLUTCH ASSEMBLY
FitsCCI/York - R12/134A compressors 2 groove, 1⁄2” width, 6 3⁄4” diameter pulley, bullet plug K332-29/ KA1035 RD-5-4987-0P 75R3452
FitsCCI/York - R12/134A compressors 2 groove, 1⁄2” width, 7” diameter pulley, bullet plug 024-25078, 332334, MA-7A RD-5-4994-0P 75R4502
024 25247, 14444, MA N05,
FitsCCI/York - R12/134A compressors Poly 8 groove, 5 3⁄8” diameter, 1 5⁄8” gauge line, IHC plug RD-5-9802-0P 75R0662
KA1485
K332-59-3, KA1410, 024-
FitsCCI/York - R12/134A compressors Poly 6 groove, 5 3⁄4” diameter, weatherpak plug RD-5-10364-0P 75R0512
25144
Poly 6 groove, 5 3⁄4” diameter, 1 5⁄8” gauge line, metripak plug K332-59-7, KA1535, 024-
with diode 25241
FitsCCI/York - R12/134A compressors Poly 6 groove, 5 3⁄4” diameter, 2” gauge line, metripak plug KA1400, 024-25244 RD-5-10363-0P 75R0502
Poly 8 groove, 6 1⁄8” diameter, 1 15⁄16” gauge line, metripak K332-59-4, KA1405, 024-
plug 25247
FitsCCI/York - R12/134A compressors Poly 6 groove, 6 1⁄8” diameter, IHC plug KA1390, KA1400, KA1480 RD-5-8009-0P 75R0612
2 groove, 1⁄2” width, 4.9” diameter (125mm), bullet plug 6511-6110, 9353-6010 RD-5-7831-0P 75R0192
compressors, 12V
Fits Sanden 709, SD7H15 R134a
2 groove, 1⁄2” width, 4.9” diameter (125mm), metripak plug 4424-9931, 1399068 RD-5-10368-0P 75R1532
compressors
Fits Sanden SD5 (508/510/5H14) R12/ KA1345, KA1350, 6519-
2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), 1 wire plug RD-5-5486-0P 75R0202
R134a compressors, Sanden #4644 6010
Fits Sanden SD7H15HD R134a 2 groove, (24V), 1⁄2” width, 4.9” diameter (125mm), 280HD
K332-B25, 4611-9931 RD-5-7832-0P 75R0194
compressors, 24V plug
Fits Sanden SD7H15 R134a compressors,
Poly 7 groove, 4.7” diameter (119mm), weatherpak plug 4645-9931, 6512-6210 RD-5-10399-0P 75R0052
Sanden #4665
1 groove, overhang 1⁄2” width, 4.9” diameter (125mm), bullet ABP N83 303241, 303261,
Fits Seltec / Tama CH, TM15 compressors RD-5-6646-0P 75R0182
plug 511575
Fits Seltec /Tama CH, TM15 compressors 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), weatherpak
KA1160, 6511-6210, 511946 RD-5-9655-0P 75R0232
324-19427, 524-19726 plug
Fits Seltec/Diesel Kiki, CH Series
2 groove, 5 21⁄64” diameter (135mm), bullet plug 511051, 518199 RD-5-6996-0P 75R0222
compressors
CLUTCH SWITCH
C500, W900B, T-Series, K100E 1981-93 Clutch Switch BA1080 RD-5-8490-0P 71R1610
CCI/York Tecumseh Rotolock ER, R210L- ER, R210L- 25149, K318-48-
series R12 or 134a (ester oil) 4, 99239-5
CCI / York Tecumseh Tube-O ET, T210L-
Tube O-Ring type head without clutch, (universal - new) 99241-3 RD-5-8638-1P 75R7290
series R12 or 134a (ester oil)
CCI / York Tube-O ET, T210L-series, (OE new replacement) Tube “O” head, LH Suction, 2 groove,
ET210L-25237C RD-5-11218-0P 75R7322
Kenworth with Cat 3406B engine 1⁄2” width, 6” diameterclutch
CCI / York Tube-O ET, T210L-series, Tube “O” head, LH suction, 2 groove, 1⁄2” width, 6”
ET210L-25073C RD-5-11217-0P 75R7312
Kenworth with Cat 3406E engine diameterclutch (OE replacement - new)
CCI / York Tube-O ET, T210L-series, Tube “O” head, LH suction, 2 groove, 1⁄2” width, 6”
ET210L-25073C RD-5-11217-0P 75R7312
Kenworth with Cummins M11 engine diameterclutch (OE replacement - new)
CCI / York Tube-O ET, T210L-series,
Tube “O” head, LH Suction, poly 8, 6 1⁄8” diameterclutch ET210L-25246C RD-5-11219-0P 75R7332
Kenworth with Detroit 60 series engine
COMPRESSOR - SANDEN
Sanden 7H15, #4424 with Cummins ISM,
7H15, GQ head, ear mount, poly 6, 4.9” (125mm) diameter 4731, 4424 RD-5-10273-0P 75R84292
C10, C12 engine
Sanden 709, #4425 with Caterpillar MSX 4425, F69-6000, F69-
2000-06 709, GQ head, ear mount, poly 6, 4.9” (125mm) diameter RD-5-12332-0P 75R81632
70596 engine 6002-122
Sanden 7H15, #4426 R134a compressor 4426, F69-1000, F69-
7H15 Standard Duty 125mm 2 A groove, GQ head and fitting RD-5-12523-0P 75R8772
with PAG oil 6002-231
Sanden 7H15HD, #4432, 4759 Detroit 4432, 4759, F69-
7H15, GQ head, direct mount, poly 8, 4.7” diameter pulley RD-5-12334-0P 75R81662
S60 series 1003,F69-6002-111
Sanden 7H15HD, #4626, Detroit Series 7H15, JD head, direct mount, 2 groove, 5 1⁄4” (132mm) 4626, F69-1002, F69-6002-
RD-5-7522-0P 75R8432
S 60 diameter 133, LE1140
PAGE 138
KENWORTH
COMPRESSOR - SANDEN
7H15, JD head, ear mount, 2 groove, 4.9” (125mm) diameter LE1145 RD-5-7120-0P 75R8422
with PAG oil, Cummins ISC, ISB
Sanden 7H15, #4644, 4664 R134a
7H15, JD head, ear mount, 2 groove, 5 1⁄4” (132mm) diameter 4644, 4664, LE1035, LE1135 RD-5-10297-0P 75R84612
7H15, JDA head, ear mount, poly 7, 4.7” (119mm) diameter 4645, LE1150 RD-5-11313-0P 75R81452
with PAG oil
Sanden 7H15, #4647 R134a compressor 4647, F69-6001-253,
7H15, JDA head, ear mount, 2 groove, 5 1⁄4” (132mm) diameter RD-5-11316-0P 75R81472
with PAG oil LE1035, LE1135
7H15, JDA head, ear mount, poly 8, 4 3⁄4” (119mm) diameter 4660 RD-5-11322-0P 75R81482
with PAG oil
7H15, JD head, ear mount, 2 groove, 5 1⁄4” (132mm) diameter 4664 RD-5-10297-0P 75R84612
with PAG oil
Sanden 7H15, #4667 with Cummins 5.9L LE1085, K318-103, F69-
7H15, KC head, direct mount, poly 8, 4.7” (119mm) diameter RD-5-11326-0P 75R81502
engine 6002-114
7H15, MJA head, ear mount, poly 8, 4.7” (119mm) diameter F69-6001-215, 4672 RD-5-11328-0P 75R81512
with PAG oil, Cat 3116, 3126 engine
4695, F69-6001-153,
Sanden 7H15HD, #4695, Detroit Series 7H15, JD head, direct mount, 2 groove, 5 1⁄4” (132mm)
F69-1002, F69-6002-133, RD-5-7522-0P 75R8432
60, S 60 diameter
LE1140
4696, F69-1000, F69-
Sanden 7H15HD, #4696, Cat 3406E Standard Duty 125mm 2 A groove, GQ head and fitting RD-5-12523-0P 75R8772
6002-231
Sanden 7H15HD, #4696, Cummins M11, 4696, F69-1000, F69-
Standard Duty 125mm 2 A groove, GQ head and fitting RD-5-12523-0P 75R8772
N14, C10, C12, S60 6002-231
Sanden 7H15, #4713 R134a compressor 4713, 18-04088, F69-6001-
7H15, JDA head, ear mount, 2 groove, 5 1⁄4” (132mm) diameter RD-5-11316-0P 75R81472
with PAG oil 253, LE1620
7H15, GQ head, ear mount, poly 6, 4.9” (125mm) diameter 4731, 4424 RD-5-10273-0P 75R84292
C10, C12 engine
Sanden 7H15HD, #4739, Cat 3116, 3126 F69-6002-214, 18-04291,
7H15HD, KG head, ear mount, poly 8, 4.7” (119mm) diameter RD-5-11334-0P 75R81562
engine 4739
7H15, JDA head, ear mount, 2 groove, 4.9” (125mm) diameter 4740 RD-5-10274-0P 75R84312
Sanden 7H15HD, #4792, Cat 3406 engine 7H15, GQ head, direct mount, poly 6, 4.9” (125mm) diameter F69-6000 RD-5-10273-0P 75R84292
7H15, GQ head, ear mount, poly 6, 4.9” (125mm) diameter RD-5-12332-0P 75R81632
with PAG oil, Cat 3406 engine 6002-122
Sanden SD510HD, #5742, 9120 R12 with SD510HD, FG head, ear mount, 2A groove, 5 1⁄4” (132mm)
1980-94 5742, 9120 RD-5-5443-0P 75R8212
Mineral Oil and Charging Ports diameter
Sanden SD510HD, #9103 R12 with SD510HD, B head, ear mount, 2A groove, 5 1⁄4” (132mm)
1980-94 5742, 9103 RD-5-6164-0P 75R8262
Mineral Oil and Charging Ports diameter
RD-5-11012-0P 74R89292
Sanden 508, #9285 R-12 compressor with with
1980-94 FLX replacement, 2 groove, 5 1⁄4”(132mm) diameter 9285
with charge ports, mineral oil RD-5-10881-0P 75R89310
adapter adapter
Sanden 508, #9285, R12 with Mineral Oil
1980-94 SD508HD, FG head, 2A groove, 5 1⁄4”(132mm) diameter 9285, LE1015, LE1050 RD-5-5575-0P 75R8292
and Charging Ports
Sanden 508, #9514, R12 with Mineral Oil SD508, FG head, ear mount, 1A groove, 4 3⁄4” (122mm)
1980-94 9514 RD-5-5684-0P 75R8342
and Charging Ports diameter
252-1495, F69-1000,
Sanden Standard Duty# 4041 2A groove, 5” (125mm) diameter RD-5-12523-0P 75R8742Q
LF0231
ICE/Seltec TM 16 #252-1496 R134a with
TM16, ear mount, poly 8 groove, 4 3⁄4” (123mm) diameter 252-1496, 18-04178 RD-5-12535-0P 75R8752Q
PAG Oil & without ports
Seltec/ Diesel Kiki TM15, #488-25011 TM15 CH with 2A groove, 5 1⁄4” (135mm) diameter pulley with
K318-36-03/488-25011 RD-5-5876-1P 75R8512Q
R12 with mineral oil & charge ports O-Ring with ports
Seltec/ Diesel Kiki TM15, #488-25077 TM15 CH with 2A groove, 5 1⁄4” (135mm) diameter pulley with
488-25077 RD-5-7023-1P 75R8522Q
R12 with mineral oil & charge ports O-Ring fitting
PAGE 139
KENWORTH
ICE/Seltec TM15 # 488-45011 - R134a
TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) 488-45011 RD-5-7145-1P 75R8612Q
ICE/Seltec TM15 # 488-45063 - R134a
TM15CH, D head, ear mount, 1 groove, overhang, 5” (125mm) 488-45063 RD-5-8944-1P 75R8532Q
Compressor with PAG OIL, without ports
488-45065 RD-5-7164-1P 75R8632Q
Compressor with PAG OIL, without ports diameter without ports
Seltec/ Diesel Kiki TM15, #488-25077
R12 with mineral oil & charge ports
CONDENSER
C500, C500B Series 1999-02 Grilldenser - Radiator mount, Red Dot A/C K122-149 RD-4-5462-0P 77R0580
K100, K100E 1983-05 Grilldenser mount, Kenworth OE#K100 Series K-100 Series RD-4-3901-1P 77R6980
T300 1988-96 Non Functional Grill “Aluminum Finish” K137-300-1 RD-4-5226-4P 77R8301
T300 1988-96 Non Functional Grill “ Black Finish” K137-300-2 RD-4-5226-5P 77R8303
T300 1992-04 Grilldenser mount, Kenworth OE#K122-128 K122-128 RD-4-4613-1P 77R6955
T400 - T600 1990-00 Serpentine Condenser (Black), front mount K122-125 RD-5-12488-0P 77R6957
T400, T602, T603 1996-06 Non Functional Grill “Aluminum Finish” K137-299-1 RD-4-5190-0P 77R6970
T400, T602, T603 1996-06 Non Functional Grill “ Black Finish” K137-299-2 RD-4-5190-1P 77R6975
T600A 1981-91 Grilldenser K122-81 RD-4-3990-0P 77R6930
T602 Dual pass 1992-94 Grilldenser mount with angled bottom , (Black) K122-119, K122-123 RD-4-4550-1P 77R6940
T602 Dual pass, T800 series 1992-94 Grilldenser mount with angled bottom , (Chrome) K122-124 RD-4-4550-0P 77R6935
T800 1988-94 Grilldenser - Non Functional K137-230 RD-4-4219-0P 77R6990
T800 2008-10 Serpentine Condenser (Black), front mount N4778001 RD-4-7081-0P 77R6982
T800 Dual pass, T800H 1991-94 Grilldenser K122-118 RD-4-4360-0P 77R6947
T2000 2008-10 Serpentine Condenser (Black), front mount N4778001 RD-4-7081-0P 77R6982
T2000 2002-06 Serpentine Condenser (Black), front mount K122-125 RD-5-12488-0P 77R6957
W900, 900B 1981-92 Grilldenser K122-62 RD-4-3745-1P 77R6925
W900 1986-94 Radiator mount, Red Dot A/C, Kenworth OE#K122-84 K122-84, RD-4-3723-0 RD-4-3723-0P 77R8100
W900 1985-92 Roof mount, Red Dot A/C RD-4-3874-1 RD-4-3874-1P 77R0500
W900B, Dual pass 1994-98 Grilldenser - Radiator mount, Red Dot A/C K122-121, RD4 4403 1 RD-4-4403-1P 77R6960
W900L 1989-90 Grilldenser K122-98 RD-4-4276-0P 77R6965
13-210 MidRanger 1987-96 Radiator mount, Red Dot A/C RDH RD4 4161 0, PA1190 RD-4-4161-0P 77R0900
1400 Series 1979-89 Grilldenser K122-64 RD-4-3727-2P 77R6920
ELECTRICAL SWITCH
C500, W900B, T-Series 1980-85 Blower Switch (Kysor A/C) 221503/BA1005 RD-5-10056-0P 71R0453
C500, W900B, T-Series 1980-85 Blower Switch RD-5-6804-0P 71R0460
Blower Switch (Bergstrom A/C), fan rotary style, DP3T, 3
C500, W900B, T-Series, K100E 2001-04 BA1390 RD-5-3646-0P 71R1150
speed, long shaft thread
C500, W900B, T-Series, K100E 1986-00 Blower Switch (Bergstrom A/C) BA1005 RD-5-10056-0P 71R0453
K100 1980-85 Blower Switch (Red Dot A/C) 2199008 / BA1205 RD-5-4694-1P 71R0450
EVAPORATOR
All model series with Red Dot OE #
1973-86 Sleeper Unit (Red Dot) RDH RD2 1137 5, NA1055 RD-2-1137-5P 76R6110
RDHRD2 1137 5
C500 1996-03 Evaporator unit (Bergstrom) 151280 RD-2-2502-0P 76R6960
C500, Brute 1982-88 Sleeper Unit (Red Dot) RDH RD2 1137 5, NA1055 RD-2-1137-5P 76R6110
C500, Brute 1975-88 Main evaporator unit (Red Dot) RDH RD2 1121 0, NA1025 RD-2-1121-0P 76R6300
K100 1980-85 Main evaporator unit (Red Dot) RDH RD2 1170 0, NA1065 RD-2-1170-0P 76R7000
K100, K100E 1980-85 Main unit (Red Dot) RDH RD2 1364 0 RD-2-1364-0P 76R7050
PAGE 140
KENWORTH
EVAPORATOR
L700 1973-87 Sleeper Unit (Red Dot) RDH RD2 1137 5, NA1055 RD-2-1137-5P 76R6110
MidRanger 1987-95 with Red Dot A/C RDH RD2 1510 0, NA1145 RD-2-1510-0P 76R5000
T300, T400, T600, T800 1994-02 Main unit (Bergstrom) 307300 RD-2-2502-0P 76R6960
T300, T400, T600, T800, W900 1995-06 Main unit (Bergstrom) 151328 RD-2-2502-0P 76R6960
T400, T600, T800, W900 1986-03 Main unit 151280, NA1005 RD-2-2502-0P 76R6960
T600 with Caterpillar NSX 31153 engine 1999-07 Main unit (Bergstrom) 151328 RD-2-2502-0P 76R6960
T600A, T800 1973-86 Evaporator unit (Red Dot) RDH RD2 1275 0, NA1070 RD-2-1275-0P 76R6320
T600A, T800 1973-86 Evaporator unit (Red Dot) RDH RD2 1316 0, NA1230 RD-2-1316-0P 76R6350
T600A, T800 1973-86 Sleeper Unit (Red Dot) RDH RD2 1137 5, NA1055 RD-2-1137-5P 76R6110
W900 1975-88 Main evaporator unit (Red Dot) RDH RD2 1121 0, NA1025 RD-2-1121-0P 76R6300
W900 1973-87 Evaporator unit (Red Dot) RDH RD2 1137 5, NA1055 RD-2-1137-5P 76R6110
EXPANSION VALVE / AIR SWITCH
Cabovers, conventionals with air switch 1976-01 Air switch, momentary on, chrome push button RD 5 3827 4 RD-5-3827-4P 72R0240
All Series Conventionals with Red Dot
Red Dot A/C with female O-Ring fittings RD 4157 0, EA1065 RD-5-6868-0P 71R8301
Sleeper unit
All (except T-2000) 1986-03 Sleeper Unit 404098 / EA1065 RD-5-6868-0P 71R8301
13-210 MidRanger 1987-93 Red Dot A/C with female O-Ring fittings RD 4157 0, EA1065 RD-5-6868-0P 71R8301
13-210 MidRanger 1987-93 Kysor A/C with female O-Ring fittings 404098, EA1065 RD-5-6868-0P 71R8301
C500 1976-09 Main unit 404098 / EA1065 RD-5-6868-0P 71R8301
C500 1986-94 Main unit 404146 / EA1090 RD-5-7155-0P 71R8400
C500, Brute 1980-00 Kysor A/C with female O-Ring fittings RD 4157 0, EA1210, 540031 RD-5-6868-0P 71R8301
C500, Brute 1986-94 Bergstrom A/C with female O-Ring fittings EA1065 RD-5-6868-0P 71R8301
K100, K100E Models 1982-02 Block valve with female O-Ring fittings 404098, EA1065, RD4157-0 RD-5-6868-0P 71R8301
K100E 1982-02 Main unit 404098, 58590P, EA1065 RD-5-6868-0P 71R8301
Sleeper units with OE # 58590P Bergstrom A/C with female O-Ring fittings 58590P RD-5-6868-0P 71R8301
T300, T400, T600, T800, W900 1995-04 Main unit 404098 / EA1065 RD-5-6868-0P 71R8301
T300, T400, T600, T800 1986-02 Main unit 404098, 540031, EA1065 RD-5-6868-0P 71R8301
T400, T600, T800, W900 1982-00 Main unit 404146 / EA1090 RD-5-7155-0P 71R8400
T600 with Caterpillar NSX 31153 engine 1995-08 Main unit, Kysor A/C with female O-Ring fittings 540031 RD-5-6868-0P 71R8301
T800 with Caterpillar MSX 70596 engine 1995-08 Main unit, Kysor A/C with female O-Ring fittings 540031 RD-5-6868-0P 71R8301
T-2000 1996-08 Main unit No (HD2) Nick Type Expansion Valve 540057 RD-5-8936-0P 71R8430
T-2000 1996-08 Sleeper Unit, 1 1⁄2 T, flange expansion valve 540056 RD-5-10333-0P 71R8440
W900 1995-09 Main unit 404098, EA1065, EA1210 RD-5-6868-0P 71R8301
W900, Brute, C500 1969-80 with Block type expansion valve K251-306 RD-4126-1P 71R8050
404073, 56380, 576270,
C500 1981-95 Main unit with male O-Ring with 13” cap length RD-5-3824-1P 71R8100
EA1230
404073, 56380, 576270,
K100 1981-96 Main unit with male O-Ring with 13” cap length RD-5-3824-1P 71R8100
EA1230
W900, Brute 1969-82 Main unit with male flare with 18” cap length RD 4126 1 RD-4126-1P 71R8050
All series with Kysor A/C units, OE #
Kysor A/C with male O-Ring fittings, 13” cap length 404073 RD-5-3824-1P 71R8100
404073
All series with Red Dot A/C units, OE #
Red Dot A/C with male flare with 18” cap length RD 4126 1 RD-4126-1P 71R8050
RD 4126 1
All series with Red Dot A/C units, OE # 404073, 56380, 576270,
Red Dot A/C with male O-Ring with 13” cap length RD-5-3824-1P 71R8100
RD 5 3824 1 EA1230
PAGE 141
KENWORTH
EXPANSION VALVE / FAN CLUTCH SOLENOID
Cabovers, conventionals with fan clutch
1976-01 Fan clutch solenoid, 12VDC, .65 amps RD-5-0060-0P RD-5-0060-0P 72R1502
solenoid
EXPANSION VALVE / REFRIGERANT SOLENOID
Conventionals 1976-01 Sleeper units, 12VDC, #6 male O-Ring RD 4188 0, 410575, 560890 RD-4188-0P 71R9002
FILTER
T-2000 Series 2002-09 In-cab evaporator filter, 13 3⁄4” wide x 10 1⁄4” high x 3⁄4” thick BSM525507 RD-5-10745-0P 78R5420
HEATER CORE
All series with Red Dot heaters, OE # RD
1973-86 Sleeper Unit RDH RD1 0333 0 RD-1-0333-0P 76R2300
1 0333 0
All except T-2000 1995-00 Sleeper Unit 108263 RD-1-2383-0P 76R2150
C500 1995-10 Main unit (Bergstrom) MC1005 RD-1-2382-0P 76R2160
C500 1995-00 Main unit 108263 RD-1-2383-0P 76R2150
C500, Brute 1982-97 Main unit (Red Dot) RDH RD1 0297 0 RD-1-0297-0P 76R2700
C500, Brute 1976-82 Sleeper Unit (Red Dot) RDH RD1 0147 1 RD-1-0147-1P 76R2600
K100 1980-85 Main unit (Red Dot) RDH RD1 0388 0 RD-1-0388-0P 76R3400
L700 1973-86 Sleeper Unit (Red Dot) RDH RD1 0333 0 RD-1-0333-0P 76R2300
T400, T600, T800, W900 1995-10 Main unit (Bergstrom) MC1005 RD-1-2382-0P 76R2160
T400, T600, T800, W900 1994-00 Main unit 108263 RD-1-2383-0P 76R2150
PRESSURE SWITCH
All Series with 12V Red Dot CTC service
1973-89 12V CTC circuit blower speed control thermistor. RD-6-4797-0P RD-6-4797-0P 71R3502
kit, OE # RD-6-4797-0P
All Series with 24V Red Dot CTC service
1973-89 24V CTC circuit blower speed control thermistor. RD-6-4797-1P RD-6-4797-1P 71R3504
kit, OE # RD-6-4797-1P
All Series with Kenworth OE # 404171, 404171, BC1005, RD 5
1989-95 Trinary Switch, 3⁄8-24 female, normally open (drier mount) RD-5-4585-0P 71R7500
BC1005, RD 5 4585 0 4585 0
All Series with Kenworth OE # 8040135P All with APAds pressure switch 8040279P, 8040135 RD-5-9990-0P 71R6400
All Series with Kenworth OE # 8040136P All with APAds low pressure switch with M12 threads 8040136, 8040152 RD-5-9991-0P 71R6405
All Series with Kenworth OE # 8042103P All with APAds module 8042103 RD-5-10449-0P 71R6560
All Series with Kenworth OE # 8042105P All with APAds electronic control module 8042105 RD-5-10352-0P 71R6565
Trinary Switch, 7⁄16-20 female, normally open (exp valve
All Series with Kenworth OE # K301-355 K301-355, RD 5 4583 0 RD-5-4583-0P 71R7550
mount)
C500, K100, T400 - 800, W900B 1981-01 High pressure switch, NC 210 psi, opens 340 psi, M-10 female K301-370-1 RD-5-8220-0P 71R6180
Trinary Switch, 7⁄16-20 female, normally open (exp valve
C500, K100E, T400 - 800, W900B 1981-99 K301-239, RD 5 4583 0 RD-5-4583-0P 71R7550
mount)
C500, K100E, T-Series, W900B 1981-99 Male Trinary Switch, normally open RDH RD5 4585 0 RD-5-4585-0P 71R7500
C500, K100E, T-Series, W900B 1981-99 Male Trinary Switch, NC RDH RD5 4620 0 RD-5-4620-0P 71R7600
C500, K100E, T-Series, W900B 1981-99 Trinary Switch, NC (expansion valve mount) BA1240, RD-5-4625-0 RD-5-4625-0P 71R7650
C500, T400 - 800, W900B 1981-99 High pressure switch, NC 210 psi, opens 340 psi, M-10 female 867559, BB1025, BB1110 RD-5-5873-0P 71R6070
K100 Models, W900 1974-87 Safety Temp Switch K301-69 RD-4527-0P 71R6300
T2000 series 2002-08 318000 series RD-5-10166-0P 71R6181
T2000 series with OE# BSM650697 1998-07 High pressure switch, NC 210 psi, opens 340 psi, M-10 female BSM650697 RD-5-8220-0P 71R6180
Low pressure switch, black, NC 5 psi, opens 35 psi, M-10
T2000 series with OE# BSM650446 1998-00 BSM650446 RD-5-10167-0P 71R6183
female
RECEIVER DRIER
All Series with Kenworth OE # GD1135, GD1135, 319360, 088324-
1988-07 #6 Female, #6 male O-Ring, 3” X 10” with moisture indicator RD-5-11184-0P 74R3357
319360, 088324-00 00
All Series with Kenworth OE # JA1110 1988-94 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) JA1110 RD-5-4632-0P 74R1956
All Series with Kenworth OE # JA1895 1988-94 #6 male O-Ring, 2 3⁄4” X 10 5⁄8” JA1895 RD-5-3593-0P 74R1756
All Series with Kenworth OE # K251-306, K251-306, RD 4160 1,
1975-87 #6 male O-Ring, 2 3⁄4” X 10” with binary switch RD-5-9455-0P 74R1836
RD 4160 1, JA1120, JA1130 JA1120, JA1130
PAGE 142
KENWORTH
RECEIVER DRIER
K251-363, K251-486, RD
All Series with Kenworth OE # K251-363,
1975-87 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) 5 4632 1, JA1100, JA1105, RD-5-4632-1P 74R1906
K251-486, RD 5 4632 1, JA1100
1-1017Q
088079-00, 088133-01,
15099P, 1-6449Q, K251-
All Series with Kenworth OE #s as listed 1993-96 #6 male O-Ring, 3” X 10” with moisture indicator, side glass RD-5-6504-0P 74R2306
563, K251-566, JA1135,
JA2120, JA1300, JA1305
Brute, C500, Conventional 1975-87 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) K251-363, JA1105 RD-5-4632-1P 74R1906
Brute, C500, Conventional 1975-87 #6 male O-Ring, 2 3⁄4” X 9 5⁄8” with out Trinary Switch 402566, 1999010 RD-5-3593-1P 74R1706
K-100 models with OE# JA2035 1994-02 With Quick disconnect JA2035 RD-5-10729-0P 74R3313
K-100 models with OE# K251-571, RD
1994-99 3” x 10” with moisture indicator & side sight glass K251-571, RD 5 8254 0 RD-5-8254-0P 74R3356
5 8254 0
K-100 models with OE# K251-521 1988-07 with out Moisture Indicator K251-521 RD-5-4834-0P 74R3306
K-100 models with OE# K251-363,
1975-87 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) K251-363, JA1105 RD-5-4632-1P 74R1906
JA1105
402566, 1999010 1975-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8” with out Trinary Switch 402566, 1999010 RD-5-3593-1P 74R1706
T400, T450, T500, T600, T800, W900B 1988-96 with out Moisture Indicator K251-521 RD-5-4834-0P 74R3306
T400, T450, T600 1994-04 With Quick disconnect JA2035 RD-5-10729-0P 74R3313
T400, T450, T600, T800 1988-07 3” x 10” with moisture indicator & side sight glass K251-571, RD 5 8254 0 RD-5-8254-0P 74R3356
T600 with Caterpillar NSX 31153 engine 1988-07 3” x 10” with moisture indicator & side sight glass K251-571, RD 5 8254 0 RD-5-8254-0P 74R3356
T600, T800 1982-93 with Side Sight Glass (exc. 1988 and above) K251-459 RD-5-4834-0P 74R3306
T800A T800B 1993-96 #6 male O-Ring, 3” X 10” with Moisture Indicator, side glass K251-566 RD-5-6504-0P 74R2306
T2000 series with Cummins ISX 485
1996-10 Slimline manifold connection, 3” x 10 1⁄2” F37-6000, JA2225 RD-5-10434-0P 74R2001
DOHC ingine
T2000 series 1996-10 Slimline manifold connection, 3” x 10 1⁄2” F37-6000, JA2225 RD-5-10434-0P 74R2001
W900 1994-04 With Quick disconnect JA2035 RD-5-10729-0P 74R3313
W900A W900B 1993-96 #6 male O-Ring, 3” X 10” with Moisture Indicator, side glass K251-566 RD-5-6504-0P 74R2306
W900B models with OE# K251-571, RD
1998-07 3” x 10” with moisture indicator & side sight glass K251-571, RD 5 8254 0 RD-5-8254-0P 74R3356
5 8254 0
W900B models with OE# K251-459 1982-93 with Side Sight Glass (exc. 1988 and above) K251-459 RD-5-4834-0P 74R3306
W900 Conventional with OE# K251-363,
1975-87 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) K251-363, JA1105 RD-5-4632-1P 74R1906
JA1105
W900 Conventional with OE# 402566,
1975-87 #6 male O-Ring, 2 3⁄4” X 9 5⁄8” with out Trinary Switch 402566, 1999010 RD-5-3593-1P 74R1706
1999010
13-210 MidRanger 1987-93 with Kysor A/C RDH RD5 5583 0 RD-5-5583-0P 74R2606
13-210 MidRanger with Red Dot A/C 1987-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8” RDH RD5 5571 0 RD-5-5571-0P 74R1806
RELAY
1979-01 Blower-Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. 221568, 652420, CB1005 RD-5-4408-0P 71R1702
652420, CB1005
1986-10 Blower-Bosch style relay, 24V, SPDT, 5 terminals, 20⁄10 amp. 221711, 650690 RD-5-4417-0P 71R1704
650690
1986-10 Blower-Twin temp relay, 12V, 8 terminal CB1015, RD-4370-0 RD-4370-0P 71R1652
CB1015, RD-4370-0
Blower-Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. RD-5-4408-0 RD-5-4408-0P 71R1702
RD-5-4408-0
Blower-Bosch style relay, 24V, SPDT, 5 terminals, 20⁄10 amp. RD-5-4417-0 RD-5-4417-0P 71R1704
RD-5-4417-0
1986-10 Blower-Bunk relay, 12V, 8 terminals, 15 amp. CB1010, RD-5-5027-1 RD-5-5027-1P 71R1802
relay, OE # RD-5-5027-1
T2000 1986-10 Blower-Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. CB1115 RD-5-4408-0P 71R1702
RELAY (ACTUATOR)
All Series with electronic actuator
1996-03 Universal sealed actuator, PWM input, 12V or 24V BSM650341 RD-5-11862-0P 71R3577
(Bergstrom), Kenworth OE # 650341
PAGE 143
KENWORTH
EXPANSION VALVE / FAN CLUTCH SOLENOID
RESISTOR
C500, K100, K100E, T400-800, W900B 1980-86 Blower Resistor, Red Dot A/C units, 3 terminal, 3 speed RD-5-3647-0 RD-5-3647-0P 71R1450
C500, K100E, T400-800, W900B 1980-97 Blower Resistor, Bergstrom A/C units, 3 terminal, 3 speed 650790 RD-5-3647-0P 71R1450
C500, K100E, W900B 1995-04 Main unit and All Sleepers CA1035 RD-5-10341-0P 71R1457
C500, K100E, T-Series, W900B 1980-97 Blower Resistor (Bergstrom A/C) 650790
C500, K100E, W900B, W900T 1995-09 Blower Resistor, Bergstrom A/C units, 3 terminal, 3 speed 650179 RD-5-10341-0P 71R1457
C500, T400-800, W900B 1980-85 Blower Resistor, Kysor A/C units, 3 terminal, 3 speed CA1010, 220990KB RD-5-10441-0P 71R1463
Blower Resistor (Kysor A/C), speed control resistor, 3 terminal,
C500, W900B, T-Series 1980-97 KYS 220990 / CA1000 RD-5-3647-0P 71R1450
3 speed
T Series, T2000 1995-09 Main unit and All Sleepers CA1035 RD-5-10341-0P 71R1457
THERMOSTATIC SWITCH
All model series with Kysor A/C, OE # Kysor A/C, Rotary thermostat with 48” capillary tube, 34 -
BD1035, 404082 RD-4125-48P 71R2300
BD1035, 404082 52°F
C500 1991-04 650163 / BD1355 RD-5-8938-0P 71R3160
mount
C500 1991-08 RD 5 8938 0, 650163 RD-5-8938-0P 71R3160
mount
C500 1986-90 with Red Dot A/C, fixed setting with 24” capillary tube BD1105 RD-5-4531-24P 71R3200
Cable controlled thermostat with 30” capillary tube, flange 404019, A45-1040, BD1300,
C500 1969-79 RD-4226-0P 71R2700
mount RD 4226 0
C500, Brute 1980-00 with Red Dot A/C, fixed setting with 24” capillary tube 58949P RD-5-4531-24P 71R3200
A45-1054, BD1340, RD5
C500, Brute 1975-86 with Kysor A/C, fixed setting with 24” capillary tube RD-4427-24P 71R3100
4427 24
K100 Models 1969-82 RD-4226-0P 71R2700
mount RD 4226 0
K100 Models 1974-87 Safety temperature switch K301-69 RD-4527-0P 71R6300
BD1070, BD1075, RD5 4427
K100, K100E 1980-85 with Kysor A/C, fixed setting with 24” capillary tube RD-4427-24P 71R3100
17, RD5 4427 24
BD1105, RD 5 4531 24,
K100E 1986-02 with Red Dot A/C, fixed setting with 24” capillary tube RD-5-4531-24P 71R3200
RD-5-4427 17
Sleeper model series with Red Dot A/C,
Rotary switch with auxillary circuit BD1040, RD 4430 0 RD-4430-0P 71R2500
OE # BD1040, RD 4430 0
T300, T400, T600, T800 1991-07 650163 / BD1355 RD-5-8938-0P 71R3160
mount
323030, BD1105, RD RD5
T300, T400, T600, T800 1980-00 with Red Dot A/C, fixed setting with 24” capillary tube RD-5-4531-24P 71R3200
4531 24
T300, T400, T600, T800 1991-08 RD 5 8938 0, 650163 RD-5-8938-0P 71R3160
mount
323030, BD1105, RD RD5
T400, T450, T600, T800 1980-85 with Red Dot A/C, fixed setting with 24” capillary tube RD-5-4531-24P 71R3200
4531 24
T2000 Series 1998-08 RD 5 8938 0, 650163 RD-5-8938-0P 71R3160
mount
T2000 1996-04 650163 / BD1355 RD-5-8938-0P 71R3160
mount
W900 1991-07 650163 / BD1355 RD-5-8938-0P 71R3160
mount
W900 1986-90 with Red Dot A/C, fixed setting with 24” capillary tube BD1105 RD-5-4531-24P 71R3200
W900 1974-87 Safety temperature switch K301-69 RD-4527-0P 71R6300
A45-1054, BD1070, BD1075,
W900 1975-86 with Kysor A/C, fixed setting with 24” capillary tube RD-4427-24P 71R3100
RD5 4427 17, RD5 4427 24
323030, BD1105, RD RD5
W900 1986-90 with Red Dot A/C, fixed setting with 24” capillary tube RD-5-4531-24P 71R3200
4531 24
W900 1969-82 RD-4226-0P 71R2700
mount RD 4226 0
PAGE 144
KENWORTH
THERMOSTATIC SWITCH
13-210 MidRanger 1987-96 with Kysor A/C, fixed setting with 24” capillary tube RD RD5 4427 24, BD1105 RD-4427-24P 71R3100
13-210 MidRanger 1987-96 with Red Dot A/C, fixed setting with 24” capillary tube RD RD5 4531 24 RD-5-4531-24P 71R3200
13-210 MidRanger 1987-96 with Red Dot A/C, fixed setting with 24” capillary tube RD RD5 4531 24 RD-5-4531-24P 71R3200
WATER VALVE
All Series with air operated valve,
Air operated valve, straight, 5⁄8” to 5⁄8” hose K295-193 RD-5-8804-1P 72R6401
Kenworth OE # K295-193
1987-00 Air operated valve, 90° elbow MA1085 RD-5-8857-1P 72R6421
Kenworth OE # MA1085
All Series with cable controlled valve, OE
1983-02 Cable operated valve, pull to open, 5⁄8” to 3⁄4” hose RD 5 3877 0, MA1020 RD-5-8034-0P 72R5110
# RD 5 3877 0
All Series with Clima Tech valve,
Air operated valve, straight, 5⁄8” to 1⁄2” NPT female K295-164 RD-5-8856-0P 72R6430
Kenworth OE # K295-164
1982-02 Air operated valve, straight, 5⁄8” to 1⁄2” NPT female MA1030 RD-5-8856-0P 72R6430
1983-00 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose MA1065 RD-5-4257-0P 72R5050
All Series with Kysor valve, Kenworth OE
1983-00 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose 173096 RD-5-8935-0P 72R6510
# 173096
All Series with Motive Air valve,
Cable operated valve, straight, 5⁄8” to 5⁄8” hose 1-1574Q, MA1060 RD-5-5119-0P 72R5060
Kenworth OE # 1-1574Q
All Series with Red Dot valve, Kenworth
1982-02 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose RD 5 4257 0 RD-5-4257-0P 72R5050
OE # RD 5 4257 0
Air operated valve, straight, 3⁄4” to 5⁄8” hose RD 5 4797 0, RD 5 8859 0 RD-5-8859-0P 72R6410
OE # RD 5 4797 0
1987-02 Air operated valve, straight, 5⁄8” to 5⁄8” hose RD 5 4800 0, RD 5 8804 0 RD-5-8804-0P 72R6400
OE # RD 5 4800 0
1987-02 Air operated valve, straight, 5⁄8” to 5⁄8” hose RD 5 4800 1, RD 5 8804 1 RD-5-8804-1P 72R6401
OE # RD 5 4800 1
1982-02 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose RD 5 4923 0 RD-5-4923-0P 72R5040
OE # RD 5 4923 0
All Series with Red Dot valve, Kenworth RD 5 5036 0, RD 5 8856 0,
1982-02 Air operated valve, straight, 5⁄8” to 1⁄2” NPT female RD-5-8856-0P 72R6430
OE # RD 5 5036 0 MA1030
Cable operated valve, straight, 5⁄8” to 5⁄8” hose RD 5 5119 0, MA1060 RD-5-5119-0P 72R5060
OE # RD 5 5119 0
Air operated valve, 90° elbow RD 5 5138 0 RD-5-8857-1P 72R6421
OE # RD 5 5138 0
Cable operated valve (pull to close), 5⁄8” to 5⁄8” hose RD 5 5300 0, MA1100 RD-5-5300-0P 72R5200
OE # RD 5 5300 0
Cable operated valve (pull to open), 5⁄8” to 5⁄8” hose, 90° elbow RD 5 5495 1 RD-5-5495-1P 72R5260
OE # RD 5 5495 1
T300 1995-00 Cable Operated (Bergstrom), 5⁄8” hose to core mount MA1110 RD-5-10345-0P 72R6530
(Bergstrom), Kenworth OE # 650341
MACK
AIR VALVES, SWITCH
Air sensing switch Air switch, normally closed, opens 25psi, 1⁄8”-27 NPTF male 4379-RD544750 RD-5-4475-0P 72R0050
All with Red Dot A/C, air cylinder valve Double action air cylinder 3⁄4” diameter, 3 1⁄4” length 4379-RD554241 RD-5-5424-1P 72R1300
All with Red Dot A/C, air cylinder valve Single action air cylinder 3⁄4” diameter, 3 1⁄4” length 4379-RD32671 RD-3267-1P 72R1100
All with Red Dot A/C, air cylinder valve Single action air cylinder 5⁄8” diameter, 3 7⁄8” length 4379-RD557845 RD-5-5784-5P 72R1210
All with Red Dot A/C, air cylinder valve Single action air cylinder 5⁄8” diameter, 3 7⁄8” length 4379-RD554144 RD-5-5414-4P 72R1200
Cabovers, conventionals Air switch, momentary off, chrome push button 4379-RD538274 RD-5-3827-4P 72R0240
PAGE 145
MACK
AIR VALVES,
BLOWER, FANSWITCH
All Series with Mack OE # 96-14, Defrost Fan, universal, 8 5⁄8” height, black with chrome fan 96-14, 101RD35-P1,
RD-5-5796-0P 73R9062
101RD35-P1, 101RD41-P2 guard 101RD41-P2
BLOWER MOTOR
All C.O.E. Series with Bunk motor with
1986-96 Main unit (Red Dot) with single shaft, 4 1⁄2” length 4379-RD554350 RD-5-6531-0P 73R0322
Red Dot A/C
All C.O.E., Conventional Sleeper Series
1986-93 Sleeper Unit with single shaft, 4 1⁄2” length HA1175, 203174, 203178 RD-5-6531-0P 73R0322
with Bergstrom, Red Dot A/C
All Conventionals with Kysor Mini-Brute
1985-91 All with single shaft motor, 1 speed, 4 1⁄2” length HA1700 RD-5-6531-0P 73R0322
Combo A/C
All Series with Kysor Kombo heater
All with 3”diameter blower motor, 1 speed, CW direction 7979-274070 RD-5-9100-0P 73R0462
motor, OE# 7979-274070
All Series with Kysor roof mount
All with single shaft, 1 speed, CW, 4 5⁄8” length 7979-275130 RD-5-10905-0P 73R0442
condenser motor, OE# 7979-275130
All Series with Red Dot heater motor,
Heater blower motor, 1 speed, CW, 4” length 4379-RD556340 RD-5-5634-0P 73R0922
OE# 4379-RD556340
3230-51020, 4379-
CH Conventional with Signet A/C Heater 1986-95 Main unit with single shaft, CCW, 4 3⁄4” length RD-5-10746-0P 73R1012
RD5107460
CH with Red Dot Model R-4230/R-4240
1988-02 Red Dot A/C, single shaft, CCW, 4 13⁄32” length 4379-RD582030 RD-5-8203-0P 73R0962
(Combo & heater only -CTC)
CH, CL 1988-00 Sleeper Unit, heater blower motor, 1 speed, CW, 4” length 4379-RD591020 RD-5-5634-0P 73R0922
Main unit, All with 3”diameter blower motor, 1 speed, CW
CH, CL Conventional 1988-99 4379-RD591000 RD-5-9100-0P 73R0462
direction
CM 1988-97 Main unit with single shaft, 4 7⁄8” length HA1695, 4379-RD559070 RD-5-5120-0P 73R0512
with Kysor A/C (evaporator motor), double shaft motor, 1
CS Midliner 1986-96 7979-275102 RD-5-5614-0P 73R4062
speed, 4” length
CS Midliner (Conventional) with Red
1990-02 Main unit with double shaft, 4 13⁄16” length 4379-RD551210 RD-5-5121-0P 73R4252
Dot A/C
CS Midliner (Conventional) with Behr
1988-93 Main unit with single shaft, CCW, 4 3⁄4” length HA1060, 4379-RD582040 RD-5-8204-0P 73R0432
A/C
Main unit, All with 3”diameter blower motor, 1 speed, CW
CX / Vision 1999-00 4379-RD591000 RD-5-9100-0P 73R0462
direction
F MODEL 1975-81 with Kysor Combo 2790-275140 RD-5-5121-0P 73R4252
LE Series 1993-00 Main unit 4379-RD552692 RD-5-5269-2P 73R0622
MC (LCF) 1986-00 Main unit (LCF) with double shaft, 4 13⁄16” length 4379-RD551210 RD-5-5121-0P 73R4252
MH Ultra-Liner 1986-94 Main unit (Red Dot) 4379-RD555120 RD-5-5512-0P 73R0912
MR (Oscar) Series with Mack MP series 2RD570M Unit with Heater A/C, 12V double blower motor
2007-08 RD 5 12358 0 RD-5-12358-0P RD-5-12358-0P
engine only
MR (Oscar) Series with Mack MP series 2RD570M2, M3 Unit with heater only, 12V double blower
2007-08 RD 5 12358 0 RD-5-12358-0P RD-5-12358-0P
engine motor only
MR (Oscar) Series with Mack MP series
2007-08 2RD570M Unit with Heater A/C, 12V blower motor assy RD 5 8837 0 RD-5-8837-0P 73R5532
engine
2007-08 2RD570M2, M3 Unit with heater only, 12V blower motor assy RD 5 8837 0 RD-5-8837-0P 73R5532
engine
MR (LCF) 1986-02 Main unit (LCF) with double shaft, 4 13⁄16” length 4379-RD551210 RD-5-5121-0P 73R4252
MS Midliner (Conventional) with Behr
1988-93 Main unit with single shaft, CCW, 4 3⁄4” length HA1060, 4379-RD582040 RD-5-8204-0P 73R0432
A/C
with Kysor or Red Dot A/C (heater motor), double shaft motor,
MS Midliner 1979-01 275102-060 RD-5-5614-0P 73R4062
1 speed, 4” length
Main unit (fits all), heater blower motor, 1 speed, CW, 4”
R, RL, RS, RW, U, DM 1976-87 4379-RD556340 RD-5-5634-0P 73R0922
length
R, RL, RS, RW, U, DM 1982-86 Sleeper unit with Red Dot A/C, single shaft, 4 1⁄4” length 4379-RD310613 RD-3106-13P 73R0602
R, RL, RS, RW, U, DM with Kysor Mini- with Kysor Mini-Brute Combo A/C, heater blower motor, 1
1981-85 2790-275160 RD-5-5634-0P 73R0922
Brute Combo A/C speed, CW, 4” length
R, U, DM Conventional with Red Dot A/C 1987-01 Main unit (Red Dot) with single shaft, 4 1⁄2” length 4379-RD554350 RD-5-6531-0P 73R0322
PAGE 146
MACK
BLOWER MOTOR
4379-RD537530, 4379-
R, U, DM Conventional with Red Dot A/C 1987-93 Main unit (Red Dot) with single shaft, 4 3⁄4” length RD-5-6526-0P 73R0422
RD565260
R, U, DM Conventional with Evans A/C 1987-93 Main unit with single shaft, CCW, single speed, 4 3⁄4” length 2790-HV33109 RD-5-10746-0P 73R1012
R, U, DM Conventional 1975-93 Heater Only (Flanged Motor )(Evans) Black RD-5-10053-0P 73R2262
R, U, DM Conventional With Signet A/C 1979-87 Main unit (Red Dot) with single shaft, 4 7⁄8” length 4379-RD556340 RD-5-5634-0P 73R0922
RB, RD, DM, DMM with Red Dot A/C Unit 1988-02 Main unit (Red Dot) with single shaft, 4 7⁄8” length 4379-RD556340 RD-5-5634-0P 73R0922
RL, RS, RW 1987-03 Main unit, 10K HR Ball bearing motor 4379-RD591020 RD-5-9102-0P RD-5-9102-0P
RL, RS, RW 1987-93 Main unit, heater blower motor, 1 speed, CW, 4” length 4379-RD556340 RD-5-5634-0P 73R0922
Sleeper Series (COE’s) with Bunk Blower 1986-93 Sleeper unit, heater blower motor, 1 speed, CW, 4” length 4379-RD556341 RD-5-5634-1P 73R0922
Sleeper Series with Red Dot Model
1979-81 Sleeper 4379-RD310618 RD-3106-18P 73R0202
R-3911A
1979-86 Sleeper 4379-RD310618 RD-3106-18P 73R0202
R-3911H
1981-83 Sleeper unit with 2 speed, single shaft, CCW, 4 1⁄4” length 4379-RD310613 RD-3106-13P 73R0602
R-4020 COE
1981-86 Sleeper unit with 2 speed, single shaft, CCW, 4 1⁄4” length 4379-RD310613 RD-3106-13P 73R0602
R-4070 (Combo and heater only)
1987-94 Sleeper unit with single shaft, CCW, 4 1⁄4” length 4379-RD565261 RD-5-6526-1P 73R0402
R-4120 (Combo and heater only)
R-4230/R-4240 (Combo & heater only 1995-02 Sleeper 4379-RD582030 RD-5-8203-0P 73R0962
-CTC)
Sleeper Series with Red Dot Model, 2
Sleeper unit with 2 speed, single shaft, CCW, 4 1⁄4” length 4379-RD565261 RD-5-6526-1P 73R0402
speed motor
WL, WS 1981-86 Main unit (Red Dot) with single shaft, 4 3⁄4” length 4379-RD565260 RD-5-6526-0P 73R0422
BLOWER RELAY
All model series with mini relay, OE #
1983-97 Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. 2MR2014, 3917-65885-C2 RD-5-4408-0P 71R1702
2MR2014, 3917-65885-C2
All model series with Twin temp relay
1983-00 Red Dot twin temp relay, 12V, 8 terminal 4379-RD43700 RD-4370-0P 71R1652
with Red Dot A/C, OE # 4379-RD43700
CS, CS Midliner 1986-98 Bosch style relay with Behr Unit, 12V, SPST, 5 terminal 2MR1702 RD-5-4408-0P 71R1702
CS, CS Midliner 1983-97 Bosch style relay with Kysor Unit, 12V, SPST, 5 terminal 7979-221568, 7979-221655 RD-5-4408-0P 71R1702
MS, MS Midliner 1986-98 Bosch style relay with Behr Unit, 12V, SPST, 5 terminal 2MR1702 RD-5-4408-0P 71R1702
MS, MS Midliner 1983-97 Bosch style relay with Kysor Unit, 12V, SPST, 5 terminal 7979-221568, 7979-221655 RD-5-4408-0P 71R1702
BLOWER RESISTOR
All model series with Kysor A/C, OE #
1980-97 Resistor for Kysor A/C units, 3 terminal, 3 speed 7979-220990 RD-5-10441-0P 71R1463
7979-220990
All model series with Red Dot fan switch
1985-00 Resistor for Red Dot A/C units, 3 terminal, 3 speed 4379-RD536470 RD-5-3647-0P 71R1450
resistor, 4379-RD536470
CS, CS Midliner 1985-00 Resistor for Red Dot A/C units, 3 terminal, 3 speed 4379-RD536470 RD-5-3647-0P 71R1450
DM model series with Kysor A/C, OE #
7979-220990
MH Ultraliner 1981-95 Behr A/C units with 3 terminal, 4 speed resistor 3230-220276 RD-5-9916-0P 71R1460
MS, MS Midliner 1982-97 Resistor for Red Dot A/C units, 3 terminal, 3 speed 4379-RD536470 RD-5-3647-0P 71R1450
R model series with Kysor A/C, OE #
7979-220990
BLOWER SWITCH
All series with Kysor A/C, OE# 7979-
1979-04 with Kysor A/C toggle blower Switch, 12 volt, 6 terminal 7979-221189 RD-4123-2P 71R0200
221189
All series with Kysor, Red Dot A/C, OE # 220891, BA1260, 4379-
1977-86 A/C units with rocker blower fan switch, 5 terminal RD-4151-2P 71R0550
220891, BA1260, 4379-RD41512 RD41512
PAGE 147
MACK
BLOWER SWITCH
All series with Kysor, Red Dot A/C, OE #
1973-86 A/C units with toggle blower fan switch, 4 terminal 221030, 4379-RD500710 RD-5-0071-0P 71R0400
221030, 4379-RD500710
All series with micro switch, Red Dot 4379-RD54379, 4379-
1993-04 Red Dot A/C units, micro switch, 12 V, 8 amp, DPDT RD-5-10590-0P 71R1620
A/C, OE # 4379-RD584900 RD5105900
All series with Red Dot A/C, OE # 4379-
1986-94 Red Dot A/C units, rotary blower fan, thermostat control 4379-RD536460 RD-5-3646-0P 71R1150
RD536460
1978-94 A/C units with toggle blower fan switch, 5 terminal 4379-RD546941 RD-5-4694-1P 71R0450
RD546940
1985-93 A/C units with toggle blower fan switch, 10 terminal 4379-RD553021 RD-5-5302-1P 71R0470
RD553021
CH model series with Red Dot A/C, OE # 4379-RD54379, 4379-
4379-RD584900 RD5105900
CH model series 1988-00 Fan Switch - Lever 4379-RD546941 RD-5-4694-1P 71R0449
CH model series 1988-00 Fan Switch - Rotary 4379-RD587710 RD-5-8771-0P 71R1175
CH, CL, CM Conventional 1987-01 Red Dot A/C units, micro switch, 12 V, 15 amp, SPDT 4379-RD584900 RD-5-8490-0P 71R1610
CH, CL, CM, CS model series with Red Dot
1988-01 Red Dot A/C units, micro switch, 12 V, 15 amp, SPDT 4379-RD584900 RD-5-8490-0P 71R1610
A/C, OE # 4379-RD5105900
CS model series with Kysor A/C, OE # Kysor A/C units, rotary blower fan switch with resistor, 3 BA1145, 2175002, 2199002,
1978-94 RD-5-5194-0P 71R1210
BA1145 switch with resistor speed, DP3T 220268
CS model series with Kysor , Red Dot
1978-94 A/C units with toggle blower fan switch without resistor 4379-RD546941 RD-5-4694-1P 71R0450
A/C, OE # 4379-RD546941
CS model series with Red Dot A/C, OE #
4379-RD536460
CS Midliner/Magirus with Kysor A/C, OE# 3230-221-519, 7979-
1979-93 with Kysor A/C Blower Switch (12 volt non-resistor Type) RD-5-3646-0P 71R1150
3230-221-519, 7979-220635, 1MR2355 220635, 1MR2355
DM model series with Kysor, Red Dot
A/C, OE # 4379-RD546941
DM model series with Red Dot A/C, OE #
4379-RD536460
F Model C.O.E. 1975-81 Fan Switch (Bunk) 4379-RD537480 RD-5-3748-0P 71R0010
F Model C.O.E. 1975-81 Fan Switch (Main Evaporator) 4379-RD41232 RD-4123-2P 71R0200
Granite 2000-05 Rotary blower fan switch, 5 speed, DP3T 4379-RD5105870 RD-5-10587-0P 71R1170
MC with Kysor, Red Dot A/C, OE # 4379-
RD546941
Blower Switch, with factory A/C (Signet) rotary style, DP3T, 3
MH Ultraliner 1982-85 4379-RD536460 RD-5-3646-0P 71R1150
MR with Kysor, Red Dot A/C, OE # 4379-
RD546941
MS Midliner/Magirus with Kysor A/C,
1979-04 with Kysor A/C Blower Switch, 12 volt, 5 terminal 7979-220635 RD-5-9833-0P 71R1160
OE# 7979-220635
MS Midliner/Magirus with Kysor A/C,
1979-93 with Kysor A/C Blower Switch (12 volt non-resistor Type) 3230-221-519, 1MR2355 RD-5-3646-0P 71R1150
OE# 3230-221-519, 1MR2355
MS Midliner/Magirus with Kysor A/C, 7979-220300, 4379-
1979-93 with Kysor A/C,Blower Switch (12 volt resistor type) RD-5-5194-0P 71R1210
OE# 7979-220300 RD551940
MS model series with Red Dot A/C, OE #
4379-RD536460
R model series with Red Dot A/C, OE #
4379-RD536460
R model series with Kysor, Red Dot A/C,
OE # 4379-RD546941
Vision model series with Red Dot A/C 2000-04 Rotary blower fan switch, 5 speed, DP3T 4379-RD5105870 RD-5-10587-0P 71R1170
Vision model series with Red Dot A/C, OE 4379-RD54379, 4379-
# 4379-RD584900 RD5105900
PAGE 148
MACK
BLOWER WHEEL SWITCH
CH, CL Conventional with Red Dot A/C 1986-00 Main unit with 5 3⁄4” single entry wheel, 3 1⁄8” width 4379-RD566511 RD-5-6651-1P 73R6381
CM Series 1988-01 Main unit with 5 1⁄4” single entry wheel, 3 7⁄16” width 4379-RD538001 RD-5-3800-1P 73R6251
CM Series 1988-94 Main unit 4379-RD552630 RD-5-5263-0P 73R6230
CS, CS Midliner 1982-00 7979-260680 RD-5-5656-0P 73R7000
width
CS, CS Midliner (Conventional) with Red
1990-02 Red Dot A/C with 3 5⁄16” double entry wheel, 3 3⁄4” width 4379-RD348291 RD-3-4829-1P 73R7071
Dot A/C
CX 2000-01 Main unit 4379-RD566511 RD-5-6651-1P 73R6381
DM COE 1979-86 with Red Dot A/C (CCW Rotation)(2-1⁄2 Width) 4379-RD310614 RD-3106-39P 73R6151
DM, DM COE 1979-86 with Red Dot A/C (CCW Rotation)(3-1⁄2 Width) 4379-RD31069 RD-5-8618-0P 73R6051
DM, DM COE, DMM with Red Dot A/C 1979-99 Main unit with 5 1⁄4” double entry wheel, 3 1⁄2” width 4379-RD552630 RD-5-5263-0P 73R6230
DM, DMM with Climatech A/C 1986-00 Main unit with 5 1⁄4” double entry wheel, 3 7⁄16” width 4379-RD538001 RD-5-3800-1P 73R6251
F Model Evaporator Motor 1975-81 Main unit with 3 3⁄16” double entry wheel, 3 13⁄16” width 7979-260680 RD-5-5656-0P 73R7000
LE Series with Red Dot A/C 1993-00 Main unit with 5 1⁄4” double entry wheel, 3 3⁄4” width HC1300, 4379-RD325572 RD-3-2557-2P 73R7151
MC (L.C.F.) with Red Dot A/C 1986-99 Main unit with 3 3⁄4” double entry wheel, 3 7⁄8” width 4379-RD539330 RD-5-3933-1P 73R7101
MH, MH Ultraliner 1986-96 Main unit with 5 1⁄4” single entry wheel, 3 1⁄2” width 4379-RD31069 RD-5-8618-0P 73R6051
MR (L.C.F.) with Red Dot A/C 1986-99 Main unit with 3 3⁄4” double entry wheel, 3 7⁄8” width 4379-RD539330 RD-5-3933-1P 73R7101
MS, MS Midliner (includes tilt cab) 1982-00 7979-260680 RD-5-5656-0P 73R7000
width
MS, MS Midliner (includes tilt cab) 1990-99 Red Dot A/C, double entry, 3 3⁄16” diameter x 3 3⁄16” width 4379-RD556560 RD-5-5656-0P 73R7000
R, RB, RD, RL, RS, RW with Red Dot A/C 1987-99 Main unit with 5 1⁄4” double entry wheel, 3 1⁄2” width 4379-RD552630 RD-5-5263-0P 73R6230
R, RL, RS, RW with Red Dot A/C 1979-87 Main unit with 5 1⁄4” single entry wheel, 3 7⁄16” width 4379-RD538001 RD-5-3800-1P 73R6251
RB, RD with Climatech A/C 1986-00 Main unit with 5 1⁄4” double entry wheel, 3 7⁄16” width 4379-RD538001 RD-5-3800-1P 73R6251
R, RW, RL, RS COE 1979-86 CW Rotation 4379-RD552630 RD-5-5263-0P 73R6230
Main unit with 5 1⁄4” single entry wheel, 3 1⁄2” width, CCW
R, RW, RL, RS COE with Red Dot A/C 1979-86 4379-RD31069, HC1015 RD-5-8618-0P 73R6051
rotation
R, RW, RL, RS COE 1979-86 with Red Dot A/C (CCW Rotation)(2-1⁄2 Width) 4379-RD310614 RD-3106-39P 73R6151
R-3911A (Combo and heater only) 1979-86 Sleeper with 5 1⁄4” single entry wheel, 3 1⁄2” width, CW 4379-RD552630 RD-5-5263-0P 73R6230
R-3911A 1979-81 Sleeper with 5 1⁄4” single entry wheel, 2 1⁄2” width, CCW 4379-RD319639 RD-3106-39P 73R6151
R-3911H 1979-86 Sleeper with 5 1⁄4” single entry wheel, 2 1⁄2” width, CCW 4379-RD319639 RD-3106-39P 73R6151
R-4020 COE 1981-83 Sleeper with 5 1⁄4” single entry wheel, 3 1⁄2” width, CCW 4379-RD586180 RD-5-8618-0P 73R6051
R-4070(Combo and heater only) 1981-86 Sleeper with 5 1⁄4” single entry wheel, 2 1⁄2” width, CCW 4379-RD319639 RD-3106-39P 73R6151
R-4070 for Conventionals (Combo and
1981-87 Sleeper with 5 1⁄4” single entry wheel, 3 1⁄2” width, CCW 4379-RD586180 RD-5-8618-0P 73R6051
heater only)
R-4120, R-4230, R-4240 (Combo &
1987-04 Sleeper with 5 3⁄4” single entry wheel, 3” width, CCW 4379-RD556010 RD-5-5601-0P 73R6370
heater only)
R-4230/R-4240 (Combo & heater only
1995-02 Sleeper 4379-RD582030 RD-5-5601-0P 73R6370
-CTC)
Sleeper with Red Dot A/C 1986-94 Bunk Blower 4379-RD552630 RD-5-5263-0P 73R6230
Sleeper COE with Red Dot A/C 1986-94 COE bunk blower, 5 1⁄4” single entry wheel, 3 7⁄16” width 4379-RD538001 RD-5-3800-1P 73R6251
U 1987-95 with Red Dot A/C 4379-RD552630 RD-5-5263-0P 73R6230
U 1979-87 Main unit with 5 1⁄4” single entry wheel, 3 7⁄16” width 4379-RD538001 RD-5-3800-1P 73R6251
U, WL/WS COE with Red Dot A/C 1979-96 Sleeper with 5 1⁄4” single entry wheel, 3 1⁄2” width, CW 4379-RD552630 RD-5-5263-0P 73R6230
U, WL/WS COE with Red Dot A/C 1979-86 4379-RD31069, HC1015 RD-5-8618-0P 73R6051
rotation
U, WL/WS COE 1979-86 with Red Dot A/C (CCW Rotation)(2-1⁄2 Width) 4379-RD310614 RD-3106-39P 73R6151
Vision 1999-04 Main unit, 5 3⁄4” single entry wheel, 3 1⁄8” width, CCW 4379-RD566511 RD-5-6651-1P 73R6381
WL, WS with Red Dot A/C 1981-86 4379-RD31069 RD-5-8618-0P 73R6051
rotation
PAGE 149
MACK
BLOWERASSEMBLY
CLUTCH WHEEL
1 groove, 7 1⁄4” diameter pulley, 3⁄4” width, 2” gauge line, 1MXA1279, 1MXA3268,
bullet plug 10761
Fits CCI/York - R12/134A compressors 1MXA3217, 10582, 502731 RD-5-4975-0P 75R1652
bullet plug
FitsCCI/York - R12/134A compressors 502745, L50-2745 RD-5-4993-0P 75R4352
bullet plug
FitsCCI/York - R12/134A compressors 1MXA243, 10595, 502740 RD-5-4980-0P 75R2402
bullet plug
2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line,
Fits CCI/York - R12/134A compressors IMX240, 1MXA1280, 10884 RD-5-4972-1P 75R1202
weatherpak plug
Fits CCI/York - R12/134A compressors IMX242, 7531, 332639 RD-5-4967-0P 75R0452
bullet plug
2 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 2 1⁄4” gauge line, 1MXA1281, 11153, 10795,
IHC plug 502742
2 groove, 7” diameter pulley, 12V, 1⁄2” width, 2” gauge line,
FitsCCI/York - R12/134A compressors IMX246, 7534, 332334 RD-5-4994-0P 75R4502
bullet plug
Fits Sanden SD5 (508/510/5H14) R12/ 1 groove, 6 1⁄4” 158mm diameter pulley, variable width, bullet
6565-6210 RD-5-5489-0P 75R1402
R134a compressors, Sanden #9696 plug
Fits Sanden SD5 (508/510/5H14) R12/
R134a compressors, Sanden #5414, 2 groove, 5 1⁄4” diameter, 1⁄2” width, (132mm), 1 wire plug 6574-6210, 6514-6210 RD-5-5486-0P 75R0202
5429, 5728, 9694
Fits Seltec / DKS15CH, Tama CH, TM15 1 groove, 4.9” 125mm dia groove, overhang, 1⁄2” width, bullet
511869, 4379-RD566460 RD-5-6646-0P 75R0182
compressors plug
Fits Seltec / DKS15CH, Tama CH, TM15 2 groove, 5 21⁄64” 135mm diameter pulley, 1⁄2” width, bullet
2570151, 624-19724 RD-5-11025-0P 75R0172
compressors plug
CLUTCH SWITCH
CH, CL, CM Conventional with Red Dot
1988-00 Clutch Switch, micro switch, SPDT, 15 amp 4379-RD584900 RD-5-8490-0P 71R1610
A/C
CX / Vision with Red Dot A/C 2000-01 Clutch Switch, micro switch, SPDT, 15 amp 4379-RD584900 RD-5-8490-0P 71R1610
Rotolock Head, LH Suction without clutch, (universal - new) 99242-5, ER210L-25149 RD-5-8637-1P 75R7280
without clutch
Tube O-Ring type head without clutch, (universal - new) 99244-5, ET210L-25150 RD-5-8638-1P 75R7290
COMPRESSOR - SANDEN
7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter 206RD49AM, 4626 RD-5-7522-0P 75R8432
with PAG oil
7H15, JD head, ear mt, 2 groove, 4.9”(125mm) diameter 4379-RD571200, 4627 RD-5-7120-0P 75R8422
with PAG oil
7H15, JD head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 206RD413M, 4639 RD-5-10297-0P 75R84612
with PAG oil, fits Mack 206RD413M
Sanden 7H15, #4639 fits CH613 Models
7H15, JD head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 206RD413M, 4639 RD-5-10297-0P 75R84612
with E7 engine (330/350/427 hp)
7H15, JDA head, direct mt, poly 8, 4.7” (119mm) diameter 4822 RD-5-10738-0P 75R84622
with PAG oil
Sanden 7H15, #4883 R134a compressor 206RD51M, 20514024,
7H15 direct mt, poly 6 gr. (125mm) diameter, 2 wire RD-5-12330-0P 75R81622
with PAG oil, fits Mack 206RD51M 4883
Sanden SD510HD, #9103 R-12
206RD45A, 9103, 4379-
compressor with charge ports, mineral SD510HD, B head, ear mount, 2 gr, 5 1⁄4”(132mm) diameter RD-5-6164-0P 75R8262
RD561640
oil, fits Mack 206RD45A
compressor with charge ports, mineral SD510HD, FG head, ear mount, 2 gr, 5 1⁄4”(132mm) diameter 206RD48AM RD-5-5443-0P 75R8212
oil, fits Mack 206RD48AM
Sanden SD508, #9514 R-12 compressor
SD508, FG head, ear mount, 1 gr, 4 3⁄4”(122mm) diameter 4379-RD556840, 9514 RD-5-5684-0P 75R8342
PAGE 150
MACK
COMPRESSOR - SANDEN
with charge ports, mineral oil, fits Mack SD510HD, FG head, variable groove, 6 1⁄4”(158mm) diameter 206RD49AM, 9675 RD-5-5627-0P 75R8232
206RD49AM
TM15CH, F head, ear mount, 2 groove, 5 1⁄4” (135mm) 488-25011, 4379-
Compressor with mineral oil/ with RD-5-5876-1JP 75R8512Q
diameter with ports RD558760
charge ports
ICE/Seltec TM15 # 488-45011 - R134a
TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) without 488-45011, 4379-
ports RD571450
ports
ICE/Seltec TM15 # 488-45063 - R134a TM15CH, D head, ear mount, 1 groove, 5” (125mm) diameter 488-45063, 4379-
RD-5-8944-1P 75R8532Q
Compressor with PAG OIL without ports RD589440
ICE/Seltec TM15 # 488-45065 - R134a TM15CH, D head, ear mount, 1 groove, 6 1⁄4” (159mm) 488-45065, 4379-
RD-5-7164-1P 75R8632Q
Compressor with PAG OIL diameter without ports RD571640
488-25077, 4379-
Compressor with mineral oil/ with TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) RD-5-7023-1P 75R8522Q
RD570230
charge ports
ICE/Seltec TM15 # 488-45077 - R134a 488-45077, 4379-
TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) RD-5-9609-10P 75R8552Q
Compressor with PAG OIL, without ports RD596091
CONDENSER
All series with OE # 210RD421M, 4379- 210RD421M, 4379-
Main unit radiator mount, serpentine coil RD-4-5762-0P 77R1105
RD457620 RD457620
All series with Red Dot roof mount -
Main unit, R-6000 series roof mount, tube & fin coil 4379-RD438741 RD-4-3874-1P 77R0500
R-6000 Unit, OE # 4379-RD438741
210RD421M, 4379-
CH models with factory A/C 1994-98 Main unit radiator mount, serpentine coil RD-4-5762-0P 77R1105
RD457620
210RD411M, 4379-
CH models with factory A/C 1989-94 Main unit radiator mount, serpentine coil RD-4-5746-0P 77R7708
RD457460
CH (1994-98), CH600 Construction Truck 1986-03 Main unit radiator mount, serpentine coil 210RD54M RD-4-5769-0P 77R7704
CH600 Cross Country with sleeper 1985-03 Main unit Radiator Mount 210RD411M RD-4-5746-0P 77R7708
CL Mack Truck with supplier engine, i.e.
1986-05 All series with with factory A/C 210RD412M RD-4-5765-0P 77R7710
Cummins, Detroit, etc.
DH, DM 1991-93 All series with with factory A/C 210RD412M RD-4-5765-0P 77R7710
DM (1988-97), DM 600 Construction
1976-05 All series with with factory A/C 210RD410M RD-4-5763-0P 77R7706
Truck
210RD46AM, 4379-
DM Conventional 1980-89 with charge air fittings, serpentine coil RD-4-4232-0P 77R0560
RD442320
DM Conventional 1978-85 with Charge Air with Male O-Ring Fittings 210RD45A RD-4-4181-0P 77R0150
DM Conventional 1968-80 with Charge Air with Male O-Ring Fittings 4379-RD451461 RD-4-5146-1P 77R0570
Granite 2002-06 Condenser coil only for hood mount, backside 210RD428 RD-4-6415-0P 77R7717
MH Model 1972-84 Cab over 210RD46AM-R.H. RD-4-5770-0P 77R7702
MR (1987-93), MR600 Refuge/Waste
1982-05 All series with with factory A/C 210RD413 RD-4-5766-0P 77R7712
Truck
MS models 1978-86 Radiator mount with Kysor factory A/C, tube & fin coil 401043 RD-4-5811-0P 77R1150
210RD46AM, 4379-
R Conventional 1980-89 with charge air fittings, serpentine coil RD-4-4232-0P 77R0560
RD442320
R, U Conventional 1976-89 All series with with factory A/C, grilldenser coil 210RD277P2 RD-4-3714-0P 77R5910
R, U Conventional 1978-85 with Charge Air with Male O-Ring Fittings 210RD45A RD-4-4181-0P 77R0150
R, U Conventional 1968-80 with Charge Air with Male O-Ring Fittings 4379-RD451461 RD-4-5146-1P 77R0570
RB, RD 1988-97 All series with with factory A/C 210RD410M RD-4-5763-0P 77R7706
RD, RD688S 1995-97 All series with with factory A/C 210RD418 RD-4-5767-0P 77R7714
RD600 Construction Truck 1975-02 with with factory A/C 210RD412M RD-4-5765-0P 77R7710
RL, RS, RW 1984-95 Condenser coil only for hood mount, grilldenser coil 210RD48 RD-4-3434-1P 77R6900
PAGE 151
MACK
CONDENSER
RL, RS, RW 1984-95 Condenser coil only for hood mount, backside 210RD428 RD-4-6415-0P 77R7717
RW models 1990-91 with hood mount grilldenser coil 4379-RD435952 RD-4-3595-4P 77R8200
RW, RWL, RWS models 1976-84 with hood mount grilldenser coil 4379-RD435952 RD-4-3595-4P 77R8200
Vision 2002-03 Condenser coil only for hood mount, backside 210RD428 RD-4-6415-0P 77R7717
CONDENSER (POWER)
CS, MS Midliner models with Red Dot
1983-01 Main unit with 12V auxillary fan 4379-RD441442 RD-4-4144-2P 77R0250
A/C
CONTROL CABLE
Granite 2001-04 Main Cab 530243 RD-5-10588-0P 72R8180
2007-08 2RD570M, M2, M3 Unit, 60” length RD 5 6410 60 RD-5-6410-60P RD-5-6410-60P
engine
Vision 2000-04 Main Cab 530244 RD-5-10588-0P 72R8180
ELECTRICAL SWITCH
All 1985-93 Blower Switch 4379-RD553021 RD-5-5302-1P 71R0470
CH model series 1979-93 Fan Switch - Lever 4379-RD546941 RD-5-4694-1P 71R0449
CH model series 1988-00 Fan Switch - Rotary 4379-RD587710 RD-5-8771-0P 71R1175
Blower Switch(24 Volt), rotary style, DP3T, 3 speed, long shaft
CS, MS Midliner/Magirus 1979-93 7979-220268 RD-5-3646-0P 71R1150
thread
CS, MS Midliner/Magirus 1979-93 with Kysor A/C Blower Switch (12 Volt Non-Resistor Type) RD-5-3646-0P 71R1150
CS, MS Midliner/Magirus 1979-93 with Kysor A/C,Blower Switch (12 Volt Resistor Type) 4379-RD551940 RD-5-5194-0P 71R1210
F MODEL C.O.E. 1975-81 Fan Switch (Bunk) 4379-RD537480 RD-5-3748-0P 71R0010
F-MODEL C.O.E. 1975-81 Fan Switch (Main Evaporator) 4379-RD4123-2 RD-4123-2P 71R0200
Granite 2002-08 Fan Switch 4379-RD5105870 RD-5-10587-0P 71R1170
MC MR 1993-79 Fan Switch 4379-RD546941 RD-5-4694-1P 71R0450
Blower Switch, with Factory A/C (Signet), rotary style, DP3T, 3
MH Ultraliner 1982-85 4379-RD53646-0 RD-5-3646-0P 71R1150
MR (Oscar) Series with Mack MP series Actuator Assembly (with PWM input) for 2RD570M, M2, M3
2007-08 RD 5 11862 0 RD-5-11862-0P 71R3577
engine Unit
R, DM 1980-96 Fan Switch with Red Dot Unit 4379-RD546941 RD-5-4694-1P 71R0450
R, DM 1980-96 Fan Switch with Kysor Unit 4379-RD546941 RD-5-4694-1P 71R0450
Vision 2002-08 Fan Switch 4379-RD5105871 RD-5-10587-0P 71R1170
EVAPORATOR
All series with OE # 4379-RD218981 1995-02 Sleeper Unit 4379-RD218981 RD-2-1898-0P 76R6130
All Conventional series with Red Dot
1994-01 Sleeper Unit (Red Dot) 4379-RD218981 RD-2-1898-0P 76R6130
Model R-4230
CH, CL Conventional with Red Dot A/C 1988-01 Main unit (Red Dot) 4379-RD216550 RD-2-1655-0P 76R7510
CM Series with Red Dot A/C 1988-97 Main unit (Red Dot) 4379-RD215970 RD-2-1597-0P 76R6000
CS, CS Midliner with Red Dot A/C 1990-00 Port-of-Entry (Red Dot) 4379-RD216690 RD-2-1669-0P 76R5600
DM 1983-96 Sleeper and In Dash unit (Red Dot ) 4379-RD211375 RD-2-1137-5P 76R6110
DM, DMM with Red Dot A/C 1987-02 Main unit (with drain pan) 4379-RD214801 RD-2-1480-1P 76R6180
DM, DMM with Red Dot A/C 1984-02 Main unit (with out drain pan) 4379-RD214801 RD-2-1480-1P 76R6180
MC, MR Series 1986-04 Main unit 4379-RD213810 RD-2-1281-0P 76R6950
MH Ultraliner with Red Dot A/C 1986-97 Main unit (Red Dot) 4379-RD214700 RD-2-1470-0P 76R7700
2007-08 Evaporator for 2RD570M Unit with Heater A/C RD 2 1381 0 RD-2-1381-0P 76R6950
engine
MS Midliner with Red Dot A/C 1990-99 Port-of-Entry (Red Dot) 4379-RD215100 RD-2-1510-0P 76R5000
R, U with Red Dot A/C 1987-90 Main unit (with drain pan) 4379-RD214801 RD-2-1480-1P 76R6180
R, U with Red Dot A/C 1984-86 Main unit (with out drain pan) 4379-RD214801 RD-2-1480-1P 76R6180
R, U with Red Dot in dash unit 1975-84 Main (Red Dot in dash unit) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
PAGE 152
MACK
EVAPORATOR
R, RL, RS, RW, U (Red Dot model
1979-96 Sleeper (Red Dot) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
R-3911A)
R, RL, RS, RW, U (Red Dot model R-4070
1981-96 Sleeper (Red Dot) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
Combo and heater only)
R, RL, RS, RW (Red Dot model R-8810
1976-90 Main evaporator unit (Red Dot) 4379-RD211210, NA1025 RD-2-1121-0P 76R6300
Combo and heater only)
RB, RD, DM, DMM with Red Dot A/C 1988-02 Main unit (with drain pan) 4379-RD214801 RD-2-1480-1P 76R6180
RB, RD, DM, DMM with Red Dot A/C 1988-02 Main unit (with out drain pan) 4379-RD214801 RD-2-1480-1P 76R6180
R-3911A 1983-96 Sleeper (Red Dot) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
R-4020 COE 1981-83 Sleeper (Red Dot) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
R-4070 (Combo and heater only) 1983-96 Sleeper (Red Dot) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
R-4120 (Combo & heater only) 1987-94 Sleeper 4379-RD215900 RD-2-1590-0P 76R6140
R-4230 (Combo & heater only) 1994-01 Sleeper Unit (Red Dot) 4379-RD218981 RD-2-1898-0P 76R6130
R-8810 (Combo & heater only) 1976-90 Main evaporator unit (Red Dot) 4379-RD211210, NA1025 RD-2-1121-0P 76R6300
Vision models with Red Dot A/C 1999-04 Main unit (Red Dot) 4379-RD216550 RD-2-1655-0P 76R7510
WL, WS, Cruiseliner 1975-84 Sleeper (Red Dot) 4379-RD211375, NA1055 RD-2-1137-5P 76R6110
WL, WS, Cruiseliner 1975-84 Main unit (Red Dot) 4379-RD211560 RD-2-1156-0P 76R6700
All series with OE # 4300-57104, 4379- 4300-57104, 4379-
1979-93 with Sleeper Unit (Red Dot), Hi - capacity RD-5-6868-0P 71R8301
RD568680 RD568680
CH Conventional 1988-00 Main unit 4379-RD570150 RD-5-7015-0P 71R8321
CH, CHN 1999-06 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD570150 RD-5-7015-0P 71R8321
CH, CL 1988-00 Main unit, Hi - capacity 4379-RD568680 RD-5-6868-0P 71R8301
CH, CL, CL Conventional 1988-95 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD570150 RD-5-7015-0P 71R8321
CM, CM Conventional, CS, MS Midliner 1987-01 Main unit (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
CS, MS Midliner/Magirus 200/300
1979-93 Main unit with Kysor A/C 4379-RD568680 RD-5-6868-0P 71R8301
CS200-2
CX 2000-02 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD5105460 RD-5-10546-0P 71R8385
DM 1988-02 Main unit, Hi - capacity (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
DM with Kysor A/C 1976-93 Main unit, Hi - capacity (Kysor) 7979-404098 RD-5-6868-0P 71R8301
DM, DMM 1988-02 Main unit, Hi - capacity (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
Granite 2003-06 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD5105460 RD-5-10546-0P 71R8385
Granite 2002-07 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD570150 RD-5-7015-0P 71R8321
MC & MR Series 1986-02 Main unit 4379-RD568680 RD-5-6868-0P 71R8301
MH 1986-94 Main unit, Hi - capacity 4379-RD568680 RD-5-6868-0P 71R8301
MH 1986-94 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD570150 RD-5-7015-0P 71R8321
2007-08 2RD570M, M2, M3 Unit RD 5 6868 0 RD-5-6868-0P 71R8301
engine
R, RW, RS, RL 1978-95 Main unit, Hi - capacity (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
R, RW with Kysor A/C 1978-95 Main unit, Hi - capacity (Kysor) 7979-404098 RD-5-6868-0P 71R8301
RB, RD 1988-02 Main unit, Hi - capacity (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
R-3911A 1979-81 Sleeper 4379-RD568680 RD-5-6868-0P 71R8301
R-4020 COE 1981-83 Sleeper 4379-RD568680 RD-5-6868-0P 71R8301
R-4070 (Combo and heater only) 1981-86 Sleeper 4379-RD568680 RD-5-6868-0P 71R8301
1995-02 Sleeper 4379-RD568680 RD-5-6868-0P 71R8301
-CTC)
Vision 1999-05 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD570150 RD-5-7015-0P 71R8321
Vision 1999-04 Main unit, Hi - capacity (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
Vision 2000-02 Main unit, Hi - capacity (2 ton), (Red Dot) 4379-RD5105460 RD-5-10546-0P 71R8385
PAGE 153
MACK
WL, WS Cruiseliner, Superliner 1977-91 Main unit, Hi - capacity (Red Dot) 4379-RD568680 RD-5-6868-0P 71R8301
All series with OE # 4379-RD558620 1982-93 Main unit with Signet A/C 3230-218023 RD-5-5862-0P 71R8080
7979-404073, 4379-
DM, F Model C.O.E. (1975-81) 1975-94 Main unit, includes Evans RD-5-3824-1P 71R8100
RD538241
MH, MH Ultraliner 1983-93 Main unit with Signet A/C 3230-218023 RD-5-5862-0P 71R8080
7979-404073, 4379-
W models with Kysor A/C 1976-93 Roof mount Kysor KA 200 unit RD-5-3824-1P 71R8100
RD538241
7979-404073, 4379-
WL, WS Cruiseliner, Superliner 1975-83 1 1⁄2 ton with 13” capillary tube length RD-5-3824-1P 71R8100
RD538241
EXPANSION VALVE / SOLENOID VALVE
All models with OE#7979-404084,
Freon refrigerant Solenoid valve for Sleeper unit 207583, LA1225 RD-4188-0P 71R9002
4379-RD41880
FILTER
7787-525784, MA0201P,
CX, Granite, Vision 2002-09 Fresh air filter, main cab RD-5-10593-0P 78R5235
4379-RD5105930
HEATER CORE
All series with OE # 4379-RD105630 1987-00 Sleeper Unit (withCTC) 4379-RD105630 RD-1-0563-0P 76R2400
CH, CK, CL Conventional 1999-03 Main unit with Red Dot A/C 4379-RD107440 RD-1-0744-0P 76R3930
CH, CL Conventional 1988-93 Main unit with Red Dot A/C 4379-RD107440 RD-1-0744-0P 76R3930
CM Conventional 1989-01 Main unit with Red Dot A/C 4379-RD106990 RD-1-0699-0P 76R2100
DM, DMM 1988-02 Main unit (with out Drainpan) 4379-RD106151 RD-1-0615-1P 76R1900
DM, DMM 1981-01 Main unit with Red Dot A/C 4379-RD101471 RD-1-0147-1P 76R2600
Granite 2003-06 Main unit with Red Dot A/C 4379-RD107440 RD-1-0744-0P 76R3930
MC, MR 1986-02 Main unit with Red Dot A/C 4379-RD105500 RD-1-0550-0P 76R3300
MH Ultraliner 1986-93 Main unit 4379-RD106000 RD-1-0600-0P 76R4000
2007-08 2RD570M Unit with Heater A/C, standard heater core RD 1 0550 0 RD-1-0550-0P 76R3300
engine
2007-08 2RD570M2 Unit with heater only, standard heater core RD 1 0550 0 RD-1-0550-0P 76R3300
engine
2007-08 2RD570M3 Unit with heater only, HP heater core RD 1 0552 0 RD-1-0552-0P RD-1-0552-0P
engine
R-3911A 1979-81 Sleeper 4379-RD103330 RD-1-0333-0P 76R2300
R-3911H 1979-86 Sleeper 4379-RD103330 RD-1-0333-0P 76R2300
R, RW, RL, RS, U, DM 1979-88 Sleeper Unit 4379-RD103330 RD-1-0333-0P 76R2300
R-4020 COE 1981-83 Sleeper 4379-RD103710 RD-1-0371-1P 76R2210
R-4070 (Combo and heater only) 1981-86 Sleeper 4379-RD103710 RD-1-0371-1P 76R2210
1995-02 Sleeper 4379-RD108221 RD-1-0822-1P 76R2410
-CTC)
R, RB, RD, U 1984-02 Main unit (Plastic - with out Drainpan) 4379-RD106151 RD-1-0615-1P 76R1900
R, RL, RS, RW 1981-01 Main unit with Red Dot A/C RD-1-0147-1 RD-1-0147-1P 76R2600
Vision 1999-06 Main unit with Red Dot A/C 4379-RD107440 RD-1-0744-0P 76R3930
WL, WS Cruiseliner 1987-00 Sleeper Unit with Red Dot A/C 4379-RD105630 RD-1-0563-0P 76R2400
WL, WS Cruiseliner (Combo & heater
1975-84 Sleeper Unit with Red Dot A/C 4379-RD103710 RD-1-0371-1P 76R2210
only)
PRESSURE SWITCH
All series with OE # 4379-RD41910 Low pressure switch (normally open) 4379-RD41910 RD-4191-0P 71R6050
All Series with OE # 4379-RD5103520 1995-04 All with APAds electronic control module 4379-RD5103520 RD-5-10352-0P 71R6565
All series with OE # 4379-RD5121500 1980-01 with Red Dot A/C, Trinary Switch with harness 4379-RD5121500 RD-5-12150-0P 71R4501
PAGE 154
MACK
PRESSURE SWITCH
All series with OE # 4379-RD545830 1980-01 with Red Dot A/C, Trinary Switch with horizontal mount 4379-RD545830 RD-5-4583-0P 71R7550
All series with OE # 4379-RD545850 Drier mounted trinary switch, with 3⁄8”-24 male thread 4379-RD545850 RD-5-4585-0P 71R7500
All series with OE # 4379-RD545850 1980-01 Trinary Switch, with 3⁄8”-24 male thread 4379-RD545850 RD-5-4585-0P 71R7500
All series with OE # 4379-RD647970 1980-05 with Red Dot A/C, CTC circuit board, 12 volt 4379-RD647970 RD-6-4797-0P 71R3502
All series with OE # 4379-RD647971 1980-05 with Red Dot A/C, CTC circuit board, 24 volt 4379-RD647971 RD-6-4797-1P 71R3504
4379-RD558730, 7979-
All series with OE # 7979-404141 1980-01 High pressure switch with Kysor A/C RD-5-5873-0P 71R6070
404141
All Series with OE # 8040316P, 1MR2451 All with APAds electronic pressure switch 4379-RD5107690 RD-5-10769-0P 71R6416
CH, CHN, CL, CM, CS Conventional 1996-06 with Red Dot A/C, Binary Switch 4379-RD546400 RD-5-4640-0P 71R7050
CH, CL, CM, CS Conventional 1988-01 with Red Dot A/C, Binary Switch 4379-RD546400 RD-5-4640-0P 71R7050
CH, CL, CM Conventional 1988-93 with Signet Binary Switch 4379-RD545850 RD-5-4585-0P 71R7500
CH, CL, CM Conventional 1988-99 with Red Dot A/C, Trinary Switch with horizontal mount 4379-RD545830 RD-5-4583-0P 71R7550
4379-RD589460,
CH, CHN, CM, CS Conventional 1996-06 with Red Dot A/C, Binary Switch RD-5-8946-0P 71R6125
1MR3550M
CH, CHN, CM, CS Conventional 1990-05 with Red Dot A/C, Binary Switch (female fitting with harness) 4379-RD566292 RD-5-6629-2P 71R7750
4379-RD558730, 7979-
CS, MS Midliner, Magirus 1978-94 High pressure switch, normally closed 210psi, opens 340psi RD-5-5873-0P 71R6070
404141
R, RL, RS, RW, U, DM 1983-93 with Red Dot A/C, Trinary Switch 4379-RD563950 RD-5-6395-0P 71R6040
R, RL, RS, RW, U, DM 1983-00 with Red Dot A/C, Binary Switch 4379-RD546460 RD-5-4646-0P 71R7000
R, RL, RS, RW, U, DM 1983-00 with Red Dot A/C, Binary Switch 4379-RD546400 RD-5-4640-0P 71R7050
R, RL, RS, RW, U, DM 1983-93 with Signet Binary Switch 4379-RD545850 RD-5-4585-0P 71R7500
RECEIVER DRIER
All series with OE # 221RD331, 334, 335 1993-03 O-Ring type with metric ports and moisture indicator 221RD331, 334, 335 RD-5-11534-0P 74R3077
All series with OE # 221RD333 1986-97 O-Ring type with female switch port & moisture indicator 221RD333 RD-5-8240-0P 74R3346
All series with Red Dot OE # 4379-
1977-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) 402529 RD-5-4632-0P 74R1956
RD546320
1977-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) 4379-RD546321 RD-5-4632-1P 74R1906
RD546321
#6 male O-Ring, 2 3⁄4” X 10 5⁄8”, without trinary switch 4379-RD565672 RD-5-6567-2P 74R3466
RD565672
All Conventional series with OE # 7979- 7979-402492, 7979-
1983-94 O-Ring Type with Kysor MiniBrute A/C RD-5-4950-0P 74R0906
402492, 7979-402562 402562
CH, CHN Series 2006-07 O-Ring Type with Switch Port and HPRV 088214-00, 088214-03 RD-5-9789-0P 74R3106
CH, CHN Series 1999-06 O-Ring Type withMetric Ports and Moisture Indicator 221RD335 RD-5-11534-0P 74R3077
CH, CL Series 1994-02 O-Ring Type withMetric Ports and Moisture Indicator 221RD335 RD-5-11534-0P 74R3077
O-Ring type with standard ports, 3” x 10 1⁄4”, hi cap, pressure
CH, CL Series 1994-02 221RD334 RD-5-11535-0P 74R3324
relief, moisture indicator
221RD327P, 328P, 4379-
CH, CL, CM Series 1988-98 #6 male O-Ring, 2 3⁄4” X 10”, without binary switch RD-5-5572-0P 74R1856
RD555720
CS, MS Midliner 1989-00 O-Ring Type with Red Dot A/C 4379-RD570611 RD-5-7061-1P 74R2536
CS, MS Midliner 1989-00 O-Ring Type with Red Dot A/C 4379-RD570610 RD-5-7061-0P 74R2576
CS, MS Midliner 1983-94 O-Ring Type with Kysor A/C 7979-402562 RD-5-4950-0P 74R0906
CS, MS Midliner 1988-91 O-Ring Type with Behr A/C JA1045 RD-5-4950-0P 74R0906
CX 2005-07 O-Ring Type withMetric Ports and Moisture Indicator 221RD335 RD-5-11534-0P 74R3077
DM 1994-02 O-Ring Type withMetric Ports and Moisture Indicator 221RD335 RD-5-11534-0P 74R3077
DM 1994-02 O-Ring Type withStandard Ports and Moisture Indicator 221RD334 RD-5-11535-0P 74R3324
DM 1977-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) 4379-RD546321 RD-5-4632-1P 74R1906
DM 1977-93 O-Ring Type with side port, top glass, moisture indicator 221RD32 RD-5-7272-0P 74R2546
DM Series Conventional 1977-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) 402529 RD-5-4632-0P 74R1956
DM Series Conventional 1977-93 with out Switch 221RD32 RD-5-3843-0P 74R2556
PAGE 155
MACK
RECEIVER DRIER
F MODEL C.O.E. 1978-81 O-Ring Type with Kysor A/C 7979-402562 RD-5-4950-0P 74R0906
Granite Series 2006-07 O-Ring Type with Switch Port and HPRV 088214-00, 088214-03 RD-5-9789-0P 74R3106
Granite Series 2002-05 O-Ring Type withMetric Ports and Moisture Indicator 221RD335 RD-5-11534-0P 74R3077
MC, MR 1994-02 O-Ring Type withMetric Ports and Moisture Indicator 221RD335 RD-5-11534-0P 74R3077
MC, MR 1994-03 O-Ring Type withStandard Ports and Moisture Indicator 221RD334 RD-5-11535-0P 74R3324
MH, MH Ultraliner 1983-03 O-Ring type with female switch port & moisture indicator 221RD312, 333 RD-5-8240-0P 74R3346
High capacity O-Ring Type with trinary switch, side port, top
MS Midliner 1983-02 4379-RD547271 RD-5-4727-1P 74R2596
glass
MS Midliner 1985-89 O-Ring Type with Red Dot A/C 4379-RD570611 RD-5-7061-1P 74R2536
MS Midliner/Magirus 1979-87 O-Ring Type with female side mount switch port 402529, 4379-RD535930 RD-5-3593-0P 74R1756
R Series 1977-81 with Econodine Engine 402529 RD-5-3593-1P 74R1706
R, RL, RS, RW, U Series Conventional 1977-93 O-Ring Type with female side mount switch port 402529, 4379-RD535930 RD-5-3593-0P 74R1756
R, RL, RS, RW, U Series Conventional 1977-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) 4379-RD546321 RD-5-4632-1P 74R1906
R, RL, RS, RW, U Series Conventional 1977-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) 402529 RD-5-4632-0P 74R1956
R, RL, RS, RW, U Series Conventional 1994-96 O-Ring Type with side port, top glass, without switch 221RD32 RD-5-3843-0P 74R2556
R, RL, RS, RW, U Series Conventional 1994-96 O-Ring Type with side port, top glass, moisture indicator 221RD32 RD-5-7272-0P 74R2546
R, RL, RS, RW, U Series Conventional 1976-93 #6 male O-Ring, 2 3⁄4” X 10”, binary switch JA1120 RD-5-9455-0P 74R1836
RB, RD 1994-02 O-Ring Type with metric ports and moisture indicator 221RD335 RD-5-11534-0P 74R3077
RB, RD 1994-02 O-Ring Type withStandard Ports and Moisture Indicator 221RD334 RD-5-11535-0P 74R3324
WL, WS, WM, Cruiseliner C.O.E. 1979-87 O-Ring Type withSide Mount L.P. Switch 210RD39303 RD-5-3593-1P 74R1706
RELAY
with Kysor A/C, Blower Relay (except mini relay), Bosch type
CS, MS Midliner/Magirus 1983-97 2MR2014 RD-5-4408-0P 71R1702
(30 amp), SPST, 5 terminals
with Kysor A/C mini relay, Bosch type (30 amp), SPST, 5
CS, MS Midliner 1983-97 2MR2014 RD-5-4408-0P 71R1702
terminals
RELAY (ACTUATOR)
MR (Oscar) Series with Mack MP series Actuator Assembly (with PWM input) for 2RD570M, M2, M3
2007-08 RD 5 11862 0 RD-5-11862-0P 71R3577
engine Unit
RESISTOR
CS, MS Midliner 1982-97 Red Dot speed control resistor, 3 terminal, 3 speed 4379-RD536470 RD-5-3647-0P 71R1450
CS, MS Midliner 1987-93 with Factory A/C, Blower Resistor (4 TERM) 4103-5000819133 RD-5-10433-0P 71R1470
SOLENOID VALVE
All series with OE#7979-404084, 4379-
Freon refrigerant Solenoid valve for Sleeper unit 207583, LA1225 RD-4188-0P 71R9002
RD41880
Cabovers, conventionals Air Solenoid - Fan Clutch 4379-RD500600 RD-5-0060-0P 72R1502
Sleepers Freon refrigerant Solenoid valve for Sleeper units 4379-RD41880 RD-4188-0P 71R9002
THERMOSTATIC SWITCH
CH Conventional 1988-89 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
Fixed setting thermostat with 24” capillary tube, flange
CH, CHN, CL Conventional 1998-09 4379-RD442724 RD-4427-24P 71R3100
mount
CM Conventional 1989-00 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
CS, CS Midliner with Red Dot A/C 1989-01 4379-RD442724 RD-4427-24P 71R3100
mount
CS Midliner 1987-04 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
CS Midliner 1979-87 with Kysor A/C (Knob Type) with 48” capillary tube 4379-RD412548 RD-4125-48P 71R2300
with Kysor A/C (Preset Type), Main unit with fixed setting
CS 200-CS250 1983-89 4379-RD5453124 RD-5-4531-24P 71R3200
thermostat
Main unit Bergstrom, fixed setting thermostat with 24” 7787-650163, 4379-
CX 1999-09 RD-4427-24P 71R3100
capillary tube RD442724
DM, DMM 1976-00 4379-RD442724 RD-4427-24P 71R3100
mount
PAGE 156
MACK
THERMOSTATIC SWITCH
DM, DMM 1976-93 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
All models with Kysor Mini Brute A/C and factory air with 7979-404075, 4379-
DM, DMM 1976-89 RD-5-4909-0P 71R2100
rotary switch RD549090
F MODEL C.O.E. 1975-81 Heat sensing switch with clamp, opens 200°F 404008 RD-4527-0P 71R6300
F MODEL C.O.E. 1975-81 with Kysor A/C, Rotary thermostat, 36” capillary tube 7979-404028 RD-4125-36P 71R2250
7787-650163, 4379-
Granite 2002-09 Main unit Bergstrom RD-4427-24P 71R3100
RD442724
Fixed setting thermostat with Heater A/C, side and bottom
MC Series 1985-00 RD 5 4531 24 RD-5-4531-24P 71R3200
mtg
MH, MH Ultraliner 1986-89 4379-RD442724 RD-4427-24P 71R3100
mount
MH, MH Ultraliner 1982-88 Cable controlled thermostat, 30” capillary tube 4379-RD42260 RD-4226-0P 71R2700
3230-22533, 4379-
MH, MH Ultraliner 1982-87 Cable controlled thermostat, 43” capillary tube RD-5-4917-0P 71R2800
RD549170
MR & MC Series 1986-02 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
MR (Oscar) Series with Mack MP series Fixed setting for 2RD570M Unit with Heater A/C, side and
2007-08 RD 5 4531 24 RD-5-4531-24P 71R3200
engine bottom mtg
MS Midliner 1987-04 Red Dot A/C, Main unit with fixed setting thermostat A22-23640-000 RD-5-4531-24P 71R3200
MS Midliner with Red Dot A/C 1987-00 4379-RD442724 RD-4427-24P 71R3100
mount
with Kysor A/C (Preset Type), Main unit with fixed setting
MS Midliner 200, 250, 300 1983-89 4379-RD5453124 RD-5-4531-24P 71R3200
thermostat
MS Midliner 200-300, Magirus 1979-87 with Kysor A/C (Knob Type) with 48” capillary tube 4379-RD412548 RD-4125-48P 71R2300
R 1976-93 with Kysor A/C, Rotary thermostat, 36” capillary tube 7979-404028 RD-4125-36P 71R2250
R, U 1976-93 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
R-3911A 1979-81 Sleeper, Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
R-4020 COE 1981-83 Sleeper 4379-RD44300 RD-4430-0P 71R2500
R-4070 (Combo and heater only) 1981-86 Sleeper 4379-RD44300 RD-4430-0P 71R2500
R-4120 (Combo & heater only) non CTC 1987-94 Sleeper 4379-RD44300 RD-4430-0P 71R2500
RB, RD 1976-02 4379-RD442724 RD-4427-24P 71R3100
mount
RL, RS, RW 1975-95 Red Dot A/C, Main unit with fixed setting thermostat 4379-RD5453124 RD-5-4531-24P 71R3200
Sleeper Units with Bunk thermostat 1981-83 Sleeper units with rotary switch with auxillary circuit 4379-RD44300 RD-4430-0P 71R2500
WL, WS, Cruiseliner 1975-80 with Evans A/C, Rotary thermostat, 36” capillary tube 2790-HV27072 RD-4125-36P 71R2250
WL, WMI, WS, Cruiseliner 1980-83 4379-RD442724 RD-4427-24P 71R3100
mount
Fixed setting thermostat with 24” capillary tube, flange 7787-650163, 4379-
Vision 1999-09 RD-4427-24P 71R3100
mount RD442724
WATER VALVE
All series with Evans cable operated In line cable operated valve, straight (pull to open), 5⁄8” to
2790-HV22563 RD-5-4257-0P 72R5050
valve, OE # 2790-HV22563 5⁄8” hose
In line cable operated valve, straight (pull to open), 5⁄8” to
All series with OE # 2790-HV30644 2790-HV30644 RD-5-4923-0P 72R5040
5⁄8” hose
All series with OE # 29RD29301, 4379-
1983-00 Air Operated (Red Dot), 5⁄8” to 5⁄8” hose 29RD29301 RD-5-8857-1P 72R6421
RD588571
All series with OE # 4379-RD553001,
Cable Operated, Red Dot (5⁄8” to 5⁄8”), pull to open 4379-RD553001, 30RS326 RD-5-5300-1P 72R5210
30RS326
All series with OE # 4379-RD588041 Air Operated (Red Dot), 5⁄8” to 5⁄8” hose 4379-RD588041 RD-5-8804-1P 72R6401
2007-08 2RD570M, M2, M3 Unit 4379-RD552150 RD-5-5215-0P 72R5080
engine
R, DM 1980-96 Air Operated (Red Dot), 5⁄8” to 5⁄8” hose 29RD29300 RD-5-8857-0P 72R6420
R, DM 1980-96 Air Operated (Red Dot), 5⁄8” to 5⁄8” hose 29RD29301 RD-5-8857-1P 72R6421
PAGE 157
MACK
Water Valve
R, DM, Evans type cable operated valve 1977-86 In line cable controlled, 5⁄8” to 5⁄8” hose 2790-HV22563 RD-5-4257-0P 72R5050
WL, WS Conventional 1981-87 Air Operated Type (Red Dot), 5⁄8” to 1⁄2” NPT female 4379-RD588560 RD-5-8856-0P 72R6430
MH Ultraliner 1986-93 Air Operated (Red Dot), 5⁄8” to 5⁄8” hose 4379-RD588040 RD-5-8804-0P 72R6400
MH Ultraliner 1986-00 Air Operated (Red Dot), 5⁄8” to 5⁄8” hose 4379-RD588041 RD-5-8804-1P 72R6401
MARMON
BLOWER MOTOR
Conventional & COE 1981-95 Main unit (Red Dot) with single shaft, 4 3⁄4” length RD-5-6526-0 RD-5-6526-0P 73R0422
BLOWER WHEEL
Conventional & COE 1974-93 Main unit with Red Dot In-Dash Evaporator CCW 4369-RD-3106-9 RD-5-8618-0P 73R6051
Conventional & COE 1974-93 Main unit with Red Dot In-Dash Evaporator CW RD-5-5263-0P RD-5-5263-0P 73R6230
Conventional & COE 1974-93 Sleeper Unit RD-5-5601-0 RD-5-5601-0P 73R6370
EVAPORATOR
C.O.E. 1976-88 Main unit RD-2-1370-0 RD-2-1370-0P 76R7070
EXPANSION VALVE
Conventional & COE 1981-93 Main unit (BLOCK Type) RD-5-6868-1 RD-5-6868-0P 71R8301
HEATER CORE
Conventional 1981-91 Main unit RD-1-0147-1 RD-1-0147-1P 76R2600
THERMOSTATIC SWITCH
Conventional & COE 1981-83 Preset Type RD-5-4531-24 RD-5-4531-24P 71R3200
NAVISTAR see IHC - NAVISTAR

PETERBILT
AIR VALVES, SWITCH
All with Red Dot A/C, air switch
Air switch assembly RD-5-3827-6, MA1265 RD-5-3827-6P 72R0260
assembly, OE # RD-5-3827-6
All with Red Dot A/C, air switch Air switch assembly with quick disconnect 90° fitting, 1⁄4” in, RD-5-5721-0, 08-02445,
RD-5-5721-0P 72R0600
assembly, OE # RD-5-5721-0 1⁄8” out BA1210
All with Red Dot A/C, air switch Air switch assembly with quick disconnect 90° fitting, 1⁄4” in,
RD-5-5721-1 RD-5-5721-1P 72R0190
assembly, OE # RD-5-5721-1 1⁄4” out
All with Red Dot A/C, Cabovers,
Air switch-expansion valve, momentary on, chrome push
conventionals with air switch assembly 1976-01 RD-5-3827-4 RD-5-3827-4P 72R0240
button
for expansion valve
All with Red Dot A/C, double action air
Double action air cylinder .79” diameter, 5.34” length RD-5-5424-1 RD-5-5424-1P 72R1300
cylinder OE # RD-5-5424-1
All with Red Dot A/C, double action air
Double action air cylinder .79” diameter, 4 3⁄4” length RD-5-6028-1 RD-5-6028-1P 72R1310
All with Red Dot A/C, single action air
Single action air cylinder 5⁄8” diameter, 3 7⁄8” length RD-5-5414-4 RD-5-5414-4P 72R1200
All with Red Dot A/C, single action air
Single action air cylinder 5⁄8” diameter, 3 11⁄16” length RD-5-5784-5, DA1005 RD-5-5784-5P 72R1210
357, 375 - 379 Air sensing switch, OE #
1986-00 Air switch, normally closed, opens 25psi, 1⁄8”-27 NPTF male RD-5-4475-0 RD-5-4475-0P 72R0050
RD-5-4475-0
357, 375 - 379 Air sensing switch, OE #
1986-00 Air switch, normally open, 21 - 29psig, 1⁄8”-27 NPTF male RD-5-5538-0 RD-5-5538-0P 72R0070
RD-5-5538-0
BLOWER, FAN MOTOR
All series with OE# HG1040, PB2-14, Defrost Fan, universal 12 Volt, 2 speed, CW rotation, On-Off- HG1040, PB2-14, 2899-
RD-5-5796-0P 73R9062
2899-006-026, 038, 051 On 006-026, 038, 051
All series with OE# HD1025, 2899-006- Defrost Fan, universal 24 Volt, 2 speed, CW rotation, On-Off-
HD1025, 2899-006-056 RD-5-5796-24P 73R9064
056 On
BLOWER MOTOR
All Main and Sleeper series with OE#
1994-02 Kysor A/C, single shaft-vented, 1 speed, CW, 4 5⁄8” length P93CAA0300-01S RD-5-10905-0P 73R0442
P93CAA0300-01S
PAGE 158
PETERBILT
BLOWER MOTOR
All Sleeper series with Red Dot A/C, OE#
1988-94 Sleeper Unit (Red Dot) with single shaft, 4 3⁄4” length RD-5-6526-1 RD-5-6526-1P 73R0402
RD-5-6526-1
All Sleeper series, Conventional and Sleeper Unit (Red Dot) with single shaft, 1 speed, CCW, 4 3⁄4” 8268F, HA1060, RD-5-
1986-98 RD-5-10746-0P 73R1012
C.O.E. with Red Dot A/C length 3753-0
All Sleeper 362 C.O.E. series, Bunk motor 1982-87 Bunk unit, single shaft, 1 speed, CCW, 4 5⁄8” length 275140 RD-5-10389-0P 73R0372
C.O.E. 1976-86 with Kysor Rooftop 275130 RD-5-3690-0P 73R0502
C.O.E. 1973-81 Bunk Motor 275140 RD-5-5121-0P 73R4252
C.O.E. 282, 352 1974-80 Main unit (Kysor) 275140 RD-5-5121-0P 73R4252
Main unit (Kysor) , single shaft motor, 1 speed, CCW, 4 5⁄8”
C.O.E. 282, 352 1973-80 275140 RD-5-10389-0P 73R0372
length
C.O.E. 362 1988-04 with Red Dot A/C (Double Shaft) RD-5-5049-1P RD-5-5049-1P 73R4422
C.O.E. 362 1981-83 Main unit (Evans) HV33208 RD-5-3690-0P 73R0502
Main unit (Bergstrom), double shaft motor, 1 speed, 4 3⁄4”
C.O.E. 372 1991-94 205853, HB1625 RD-5-6801-0P 73R4182
length
13-200 MidRanger with Red Dot A/C 1995-91 Main unit with double shaft, 4 13⁄16” length RD-5-5121-0, HB1070 RD-5-5121-0P 73R4252
13-210 MidRanger with Kysor A/C 1988-95 Main unit, double shaft motor, 1 speed, 4” length 275102, HA1710 RD-5-5614-0P 73R4062
13-210 MidRanger with Red Dot A/C 1995-88 Main unit, double shaft motor, 1 speed, 4” length RD-5-5614-0, HA1710 RD-5-5614-0P 73R4062
282, 289, 352, 362, 372 with Kysor roof
1976-86 Kysor A/C, single shaft-vented, 1 speed, CW, 4 5⁄8” length 275130, HA1735 RD-5-10905-0P 73R0442
mount A/C
282, 289, 352, 362, 372 with Kysor roof
1976-86 Kysor A/C, single shaft-non-vented, 1 speed, CW, 4 7⁄8” length 275130 RD-5-7129-0P 73R0542
mount A/C
282, 352 1974-81 Main unit, single shaft, 1 speed, CCW, 4 5⁄8” length 275140, HA1135 RD-5-10389-0P 73R0372
282, 352 1973-80 Kysor Main unit, single shaft, 1 speed, CCW, 4 5⁄8” length 275140 RD-5-10389-0P 73R0372
273140, 2807-516-039,
282, 352 1969-75 Main unit, single shaft, 1 speed, CW, 5” length RD-5-9100-0P 73R0462
HA1120
289, 348, 349, 359, 362, includes Kysor Main and Bunk unit, single shaft, 1 speed, CCW, 4 5⁄8”
1982-86 275140, HA1155 RD-5-10389-0P 73R0372
Conventional length
310, 351, Series with Red Dot A/C 1979-86 Main unit with double shaft, 4 13⁄16” length RD-5-5121-0, HB1070 RD-5-5121-0P 73R4252
320 1997-04 Main unit, 1 speed, 3 1⁄4” diameter blower motor, CW or CCW 203080 RD-5-10390-0P 73R0212
BSM203080, 205780,
320 1996-10 Main unit heater only Dual Steer Bergstrom unit RD-5-6801-0P 73R4182
HB1050
Main unit with Red Dot A/C, double shaft motor, 1 speed, 4
320 1987-96 RD-5-6801-0, PF2646Q RD-5-6801-0P 73R4182
3⁄4” length
320 with Red Dot A/C 1995-10 Main unit, double shaft motor, 1 speed, 4 3⁄4” length HB1050 RD-5-6801-0P 73R4182
330,335,340,365,367 2005-10 Blower Motor HA0983 / 3X010983 RD-5-13069-0P 73R3142
352, 362, C.O.E. 1981-93 Main unit (Red Dot) AM86610 RD-5-5837-0P 73R4602
377,378,379,385,387,388,389 1998-2010 Main unit and Sleeper Unit (Signet) 3X010983 / HA0983 RD-5-13069-0P 73R3142
357, 377, 378, 379, 385 Conventional 1994-02 Main unit and Sleeper Unit (Signet) P93CAA0300-01S, HA1825 RD-5-10336-0P 73R0042
357, 359, 375, 377, 378, 379, 385
1994-00 Main unit P93CAA0300-01S, HA1825 RD-5-10336-0P 73R0042
Conventional
357, 359, 375, 377, 378, 379 Conventional 1987-94 Main unit (Red Dot) with single shaft, 4 3⁄4” length RD-5-6526-0 RD-5-6526-0P 73R0422
8268F, HA1060, RD-5-
357, 359, 375, 377, 378, 379 Conventional 1987-89 Main unit, all with single shaft, 1 speed, CCW, 4 3⁄4” length RD-5-10746-0P 73R1012
3753-0
357, 359, 375, 377, 378, 379, 385
1987-93 Sleeper Unit RD-5-6526-1 RD-5-6526-0P 73R0402
Conventional
359, 362 Conventional 1977-86 Main unit and Bunk RD-5-4927-0 RD-5-4927-0P 73R0702
RD-5-5049-1, PF28103Q,
362 Conventional with Red Dot A/C 1988-02 Main unit, double shaft motor, 1 speed, 5 1⁄4” length RD-5-5049-1P 73R4422
HB1100
372 1991-94 Main unit with Bergstrom A/C HB1625 RD-5-10073-0P 73R4312
379 Conventional with Signet A/C 1994-00 Signet A/C, single shaft-vented, 1 speed, CW, 4 5⁄8” length BSM301461 RD-5-10905-0P 73R0442
379 Conventional with Sleeper cab 1994-98 Bergstrom A/C, single shaft, 1 speed, 4 3⁄4” length BSM203076 RD-5-5512-0P 73R0912
PAGE 159
PETERBILT
BLOWER MOTOR
Main unit, strap mount, single shaft motor, 1 speed, 5 1⁄8”
379, 387 Conventional 1999-04 BSM203139, BSM203142 RD-5-8922-0P 73R0612
length
379, 387 Conventional 1999-02 Main unit (Bergstrom), single shaft with strap mounting BSM203142 RD-5-10867-0P 73R0332
379, 387 Conventional 1997-01 Main unit (Bergstrom), single shaft, 1 speed, 4 3⁄4” length BSM203133 RD-5-8204-0P 73R0432
387 2000-2010 Main unit (Bergstrom), single shaft, three ear bracket RD-5-8922-0P 73R0612
387 2000-10 Sleeper BSM203139 RD-5-10336-0P 73R0042
BLOWER RELAY
All 1986-10 Mini Relay 24 volt 650690 RD-5-4417-0P 71R1704
All model series with Blower relay, OE #
1986-10 Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. BSM652420 / CB1115 RD-5-4408-0P 71R1702
652420BSM
1985-95 Bunk relay, 12V, 8 terminals, 15 amp. CB1010, RD-5-5027-1 RD-5-5027-1P 71R1802
relay, OE # RD-5-5027-1
All model series with Twin temp relay
1986-94 Red Dot twin temp relay, 12V, 8 terminal CB1025 RD-4370-0P 71R1652
with Red Dot A/C, OE # CB1025
320LCF, 387 Conventional 1995-02 Bosch style relay, 12V, SPST, 5 terminals, 30⁄20 amp. BSM652420 RD-5-4408-0P 71R1702
All model series with Bunk control relay
1972-87 Red Dot bunk control relay, 12V, 8 terminal CB1025 RD-4370-0P 71R1652
with Kysor A/C, OE # 220996, CB1015
BLOWER RESISTOR
All model series with Kysor A/C, fan
1973-96 Resistor for Bergstrom A/C Main unit, 3 terminal, 3 speed CA1010, 220990 RD-5-10441-0P 71R1463
switch resistor, OE# CA1010, 220990
All C.O.E. and conventional model series
with Red Dot A/C, fan switch resistor, 1987-00 Resistor for Red Dot A/C units, 3 terminal, 3 speed CA1000, CA1005 RD-5-3647-0P 71R1450
OE# CA1000, CA1005
289-387 Conventional Series, with
Resistor (Circuit Breaker) for Red Dot A/C units, 3 terminal,
Red Dot A/C, fan switch resistor, OE# 1987-01 RD-5-3647-0 RD-5-3647-0P 71R1450
3 speed
RD-5-3647-0P
320 Series, all models with Bergstrom
1973-96 Resistor for Bergstrom A/C Main unit, 3 terminal, 3 speed CA1010 RD-5-10441-0P 71R1463
A/C, OE # CA1010
372 Series, all models with Bergstrom
1991-99 Bergstrom Main unit, 3 terminal, 3 speed CA1035 RD-5-10341-0P 71R1457
A/C, OE # CA1035
All model series with Red Dot A/C, CTC II
1987-95 CTC II Circuit board, 12 Volt CD1035, RD-6-4797-0P RD-6-4797-0P 71R3502
Circuit board
All model series with Red Dot A/C, CTC II
1987-95 CTC II Circuit board, 24 Volt CD1035, RD-6-4797-24P RD-6-4797-1P 71R3504
Circuit board
BLOWER SWITCH
All model series with Blower rotary BA1020, BA1190, BOA-80-
1993-00 Fan rotary switch, DP3T, 3 speed, short shaft thread RD-5-9833-0P 71R1160
switch, OE # BA1020, BA1190 926-00-059
All model series with Blower toggle BSM322005, BA1205, RD-
1987-94 Red Dot A/C units, toggle, 5 terminal, 4 position, SPST RD-5-4694-1P 71R0450
switch, OE # BSM322005 5-4694-1
Red Dot A/C Main units. Toggle switch, 12 V, 3 Position, DPDT,
282, 352 C.O.E. 1974-81 220758, BE1035 RD-4123-2P 71R0200
6 terminals
330 - 387 models, 15 amp circuit breaker 1993-05 Circuit breaker, 15 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset CC1015, K1110-0548-15 RD-5-6602-0P 71R1310
330 - 387 models, 20 amp circuit breaker 1993-05 Circuit breaker, 20 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset K1110-0548-20 RD-5-6714-0P 71R1315
330 - 387 models, fan cycling switch for Fan override (grey), Highside, normally open 200 psi, closes
1993-05 RD-5-8218-0 RD-5-8218-0P 71R6160
Red Dot and Signet A/C 270 psi
330 - 387 models, micro switch for BOA-80-908-00-
1993-05 Micro Switch with Bergstrom A/C, SPDT, 15 amp RD-5-8490-0P 71R1610
Bergstrom A/C 219,BSM650471
BLOWER WHEEL
All model series with OE # 260680, Kysor Class Six A/C, double entry, 3 3⁄16” diameter x 3 3⁄16”
1988-95 260680, HC1290 RD-5-5656-0P 73R7000
HC1290 width
All Conventional & C.O.E.model series Bergstrom A/C, Main unit with 4 1⁄2” double entry wheel, 3
1986-04 BSM302042 RD-5-10346-0P 73R7130
with Bergstrom A/C, OE # HC1050 3⁄8” width
PAGE 160
PETERBILT
BLOWER WHEEL
Conventional & C.O.E. 1987-99 with Red Dot A/C (sleeper ) RD-5-5601-0P RD-5-5601-0P 73R6370
13-210 MidRanger, Kysor and Red Dot
1986-96 Main unit with 3 3⁄16” double entry wheel, 3 13⁄16” width 260680, RD-5-5656-0 RD-5-5656-0P 73R7000
A/C
282, 289, 330, 349, 352, 353, 357, 359,
Red Dot Sleeper unit, single entry wheel(plastic), CCW, 5 3⁄4”
362, 372, 375 - 379, 387 C.O.E. and 1987-99 RD5 5601 0, HC1325 RD-5-5601-0P 73R6370
diameter
Conventional
BSM302081, HC1285, RD-
310, 357, 375, 377, 378, 379 Series 1987-97 Red Dot A/C with 5 1⁄4” single entry wheel, 3 7⁄16” width RD-5-3800-1P 73R6251
5-3800-1P
310 Series 1979-87 with Red Dot A/C RD-5-3933-1 RD-5-3933-1P 73R7101
310, 357, 375, 377, 378, 379 Conventional 1986-93 with Red Dot A/C RD-5-5263-0 RD-5-5263-0P 73R6230
320 1988-03 Red Dot A/C units with 5 1⁄2” double entry wheel, 3 3⁄4” width RD-3-2557-2 / HC1300 RD-3-2557-2P 73R7151
ALL 1996-03 Main unit with 4 1⁄2” double entry wheel, 3 3⁄8” width 589540 / HC1050 RD-5-10346-0P 73R7130
Bergstrom A/C, Main unit with 4 1⁄2” double entry wheel, 3
320 LCF 1986-04 BSM302042 RD-5-10346-0P 73R7130
3⁄8” width
330, 335, 340, 365, 367 2005-10 5.75” Dia CW P93CAB0400-01S/HC1625 RD-5-10435-0P 73R6383
330, 357, 359, 379, 385 Conventional 1995-02 Main and Sleeper units, 5 3⁄4” single entry wheel, 3 1⁄4” width PC93CAB0400-01S RD-5-8947-0P 73R6270
357, 377, 378, 379, 385 Conventional 1995-10 Main & Sleeper Unit P93CAB0400-01S/HC1625 RD-5-10435-0P 73R6383
387 2000-08 5.5” CW main unit and sleeper 563500, HC1050 RD-5-10346-0P 73R7130
362, 372 1988-01 Red Dot units with 5 1⁄2” double entry wheel, 3 3⁄4” width RD-3-2557-2 RD-3-2557-2P 73R7151
362 C.O.E. 1988-02 Red Dot units with 5 1⁄2” double entry wheel, 3 3⁄4” width RD-3-2557-2 RD-3-2557-2P 73R7151
Main unit (Bergstrom), dual rotation, 4 1⁄2” diameter, 3 3⁄8”
372 C.O.E. 1991-94 RD-5-10346-0P 73R7130
width
CIRCUIT BREAKER
Circuit breaker, Main unit (5 amp), speed control resistor, 3
372 C.O.E. 1991-94 RD-5-3647-0 RD-5-3647-0P 71R1450
terminal, 3 speed
CLUTCH ASSEMBLY
1 groove, 6 3⁄4” diameter pulley, 3⁄4” width, 2 3⁄4” gauge line, 18-1209, 18-02569,
bullet plug 502744, KA1015
1 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 3 1⁄8” gauge line, 18-2441, 10595, 502740,
bullet plug KA1020
1 groove, 6 3⁄4” diameter pulley, 11⁄16” width, 2” gauge line, 18-1208, 10584, 502732,
bullet plug KA1220
1 groove, 7 1⁄4” diameter pulley, 3⁄4” width, 2” gauge line,
Fits CCI/York - R12/134A compressors 18-1214, 502400, KA1010 RD-5-4995-0P 75R4652
bullet plug
2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line, 18-01210, 024 25190,
weatherpak plug 501939
Fits CCI/York - R12/134A compressors 18-02572, 332639 RD-5-4967-0P 75R0452
bullet plug
Fits CCI/York - R12/134A compressors 024 25238 RD-5-9456-0P 75R1302
metripak plug
2 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 2 1⁄4” gauge line, 18-1866, 11153, 502742,
IHC plug KA1035
Fits CCI/York - R12/134A compressors Poly 6 groove, 5 3⁄4” dia groove, far forward, metripak plug 024 25144, 14304 RD-5-10364-0P 75R0512
FitsCCI/York - R12/134A compressors Poly 6 groove, 5 7⁄8” diameter pulley, metripak plug 024 25241, 14565, KA1535 RD-5-10366-0P 75R0522
FitsCCI/York - R12/134A compressors Poly 6 groove, 5 7⁄8” dia groove, far forward, metripak plug 024 25244, 14432 RD-5-10363-0P 75R0502
Fits CCI/York - R12/134A compressors Poly 8 groove, 6 1⁄8” diameter pulley, metripak plug 024 25247, 14372, KA1405 RD-5-10365-0P 75R0682
2 groove, 4.9” 125mm diameter pulley, 1⁄2” width, metripak
Fits Sanden 7H15HD compressors 4740-9931, 6593-6010 RD-5-10368-0P 75R1532
plug
2 groove, 1⁄2” width, 4.9” diameter (125mm), bullet plug 6560-6010, 9353-6010 RD-5-7831-0P 75R0192
compressors, 12V
Fits Sanden SD508, 510, 514 R-12 2 groove, 12 Volt 5 1⁄4” (132mm) diameter pulley, 1⁄2” width, 6514-6210, 6519-6010,
RD-5-5486-0P 75R0202
compressors 1 wire 6574-6210
PAGE 161
PETERBILT
CLUTCH ASSEMBLY
Fits Sanden SD508, 510, 514 R-12 2 groove, 24 Volt 5 1⁄4” (132mm) diameter pulley, 1⁄2” width,
6519-6210, 6514-6210 RD-5-5487-0P 75R0204
compressors 1 wire
Fits Sanden SD7H15 R134a compressors,
Poly 7 groove, 4.7” diameter (119mm), weatherpak plug 4645-9931, 6512-6210 RD-5-10399-0P 75R0052
Sanden #4665
4606-6871, 4705-9930,
Fits Sanden SD7H15 R134a compressors Poly 8 groove, 4.7” diameter (119mm), metripak plug RD-5-10760-0P 75R1842
9931
Fits Seltec / DKS15CH, Tama CH, TM15, 1 groove, 4.9” (125mm) dia groove, overhang, 1⁄2” width, 511575, 511869, 524-19718,
RD-5-6646-0P 75R0182
TM16 compressors bullet plug KA1055
Fits Seltec / DKS15CH, Tama CH, TM15, 1 groove, 6 1⁄4” (159mm) dia groove, variable width, bullet
511587, 511870, 524-19719 RD-5-9799-0P 75R1422
TM16 compressors plug
Fits Seltec / DKS15CH, Tama CH, TM15, 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), weatherpak
511051 RD-5-9655-0P 75R0232
Fits Seltec / DKS15CH, Tama CH, TM15, 24V, 2 groove, 1⁄2” width, 5 21⁄64” diameter (135mm), bullet
511868, 524-19724, KA1025 RD-5-10232-0P 75R0274
CCI/York - Rotolock HD compressor
ER210L-25149, LC1000,
without clutch, replaces Rotolock Head, LH Suction without clutch, (universal - new) RD-5-8637-1P 75R7280
LC1005
OE#ER210L-25149, LC1000, LC1005
CCI/York - Tube O-Ring compressor with OE#ET210L-25073C,
clutch, replaces OE#ET210L-25073C, 488- 1995-02 488-25073C, K318-137-3, RD-5-11217-0P 75R7312
replacement - new)
25073C, K318-137-3, LC1080, LC1140 LC1080, LC1140
CCI/York - Tube O-Ring compressor
ET210L-25150, C, LC1010,
without clutch, replaces Tube O-Ring type head without clutch, (universal - new) RD-5-8638-1P 75R7290
LC1130, LC2120
OE#ET210L-25150, C
CCI/York - Tube O-Ring compressor with (OE new replacement) Tube O-Ring head with LH suction, 2
ET210L-25237C RD-5-11218-0P 75R7322
clutch, fits Cat 3406B engines groove, 2 wire clutch
CCI/York - Tube O-Ring compressor with
clutch, fits Cat 3406E and Cummin M11 1995-02 ET210L-25073C RD-5-11217-0P 75R7312
replacement - new)
engines
Tube O-Ring with LH suction, 8 groove, 6 1⁄8” diameter, 2 wire
with clutch, fits Detroit Diesel 60 series ET210L-25246C RD-5-11219-0P 75R7332
clutch
engines
CCI/York/Tecumseh - Rotolock HD
compressor without clutch, replaces Rotolock Head, LH Suction without clutch, (universal - new) LD1000 RD-5-8637-1P 75R7280
OE#LD1000
CCI/York/Tecumseh - Tube O-Ring
compressor without clutch, replaces Tube O-Ring type head without clutch, (universal - new) LD1005 RD-5-8638-1P 75R7290
OE#LD1005
COMPRESSOR - SANDEN
7H15, GQ head, ear mount, poly 6, 4.9” (125mm) diameter 4424, F69-6002-121 RD-5-10273-0P 75R84292
C10, C12, Sig 600 engine
with PAG oil, Cat 3406 engine 6002-122
4426, F69-1000, F69-
with PAG oil, fits 377, 379 models with Standard Duty 7H15 125mm 2 A groove, GQ head (4426) RD-5-12523-0P 75R8772
6002-231
Cat 3406E engine
Sanden 7H15HD, #4432 Detroit S60 4432, F69-1003, F69-
series engine 6002-111
7H15, JDA head, ear mount, 2 groove, 4.9” (125mm) diameter 4433, F69-6002-233 RD-5-10274-0P 75R84312
Sanden 7H15, #4429, fits Cat 3116, 3126
7H15, GH head, ear mount, 2 groove, 5 1⁄4”(132mm) diameter 4472, 18-04291 RD-5-11243-0P 75R81212
engine, Peterbilt OE#18-04291
Sanden 7H15, #4626 fits Series 60 4626, LE1140, F69-1002,
7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter RD-5-7522-0P 75R8432
Detroit, OE#LE1140 F69-6002-133
Sanden 7H15, #4644, fits 357 models
with Cat 3406 engine, Peterbilt OE#18- 7H15, JD head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4644, 18-03787 RD-5-10297-0P 75R84612
03787
PAGE 162
PETERBILT
COMPRESSOR - SANDEN
Sanden 7H15, #4645 ear mount with
4645, LE1150, F69-6002-
vert. O-Ring, fits Cat 3126 engine, 7H15, JDA head, ear mount, poly 7, 4.7” (119mm) diameter RD-5-11313-0P 75R81452
243
Peterbilt OE#LE1150
7H15, JDA head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4713, LE1135 RD-5-11316-0P 75R81472
with PAG oil, OE#LE1135
7H15, JDA head, ear mount, poly 8, 4 3⁄4” (119mm) diameter 4660 RD-5-11322-0P 75R81482
with PAG oil
7H15, JD head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4664, LE1620 RD-5-10297-0P 75R84612
with PAG oil, Peterbilt OE# LE1620
7H15, JD head, ear mt, poly 7, 4.7”(119mm) diameter 18-03788 RD-5-10295-0P 75R84572
with PAG oil
Sanden 7H15, #4667 with Cummins LE1085, K318-103, F69-
7H15, KC head, direct mount, poly 8, 4.7” (119mm) diameter RD-5-11326-0P 75R81502
5.9L, 8.3L engine 6002-114
7H15, MJA head, ear mount, poly 8, 4.7” (119mm) diameter 4672, F69-6001-215 RD-5-11328-0P 75R81512
with PAG oil, Cat 3116, 3126 engine
Sanden 7H15, #4687 fits S55 with R134a 7H15HD, CBA head, direct mt, poly 6, 4.9”(125mm) diameter,
4687, 22-44462-000 RD-5-10303-0P 75R84152
compressor with PAG oil S55.
Sanden 7H15, #4695 fits Detroit Series
4695, F69-1002, F69-
60, Cum ISC - R134a compressor with 7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter RD-5-7522-0P 75R8432
6002-133
PAG oil
Sanden 7H15, #4696 fits 357, 377, 379,
Sanden Standard Duty 125mm 2 A groove, GQ head 4696, F69-1000 RD-5-12523-0P 75R8772
385 models with Cat C12, 3406E engine
Sanden 7H15, #4696 fits 377, 379, 385
models with Cummins M11, N14 -525E Sanden Standard Duty 125mm 2 A groove, GQ head 4696, F69-1000 RD-5-12523-0P 75R8772
engine
Sanden 7H15, #4696 ear mount with
vert. O-Ring, fits Detroit S-60 engines, Sanden Standard Duty 125mm 2 A groove, GQ head 4696, 18-04154, F69-1000 RD-5-12523-0P 75R8772
Peterbilt OE#18-04154
Sanden 7H15, #4705, all models 134a
ICE-Seltec replacement, TM 16 123mm poly 8 groove, GQ head 4705/ 18-04178 RD-5-10496-0P 75R8752
with PAG oil “ICE” (will fit)
Sanden 7H15, #4713 R134a compressor,
fits Detroit 8.3 engines, Peterbilt 7H15, JDA head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 4713, 18-04088 RD-5-11316-0P 75R81472
OE#18-04088
7H15, GQ head, ear mount, poly 6, 4.9” (125mm) diameter 4731, 18-05000 RD-5-10273-0P 75R84292
C10, C12, Sig 600 engine
Sanden 7H15, #4734 fits Cat 3126 7H15, MJA head, ear mount, poly 8 groove, 4.7”(119mm)
4734, 22-47692-000 RD-5-10262-0P 75R84162
Engine, Mer 366. diameter
Sanden 7H15HD, #4739, Cat 3116, 3126 F69-6002-214, 18-04291,
7H15HD, KG head, ear mount, poly 8, 4.7” (119mm) diameter RD-5-11334-0P 75R81562
engine 4739
7H15, JDA head, ear mount, 2 groove, 4.9” (125mm) diameter 4740, 18-04373 RD-5-10274-0P 75R84312
Sanden 7H15HD, #4759 Detroit S60 4759, F69-1003, F69-
series engine 6002-111
Sanden 7H15, #4792 R134a compressor 4792, F69-6000, F69-6001-
with PAG oil, Cat 3406 engine 121, -122, F69-6002-122
Sanden SD510HD, #5742, 9120 R12
SD510HD, FG head, ear mount, 2A groove, 5 1⁄4” (132mm)
with mineral oil and charging ports, 1980-94 5742, 9120, 18-03536 RD-5-5443-0P 75R8212
diameter
OE#18-03536
Sanden 508, #9285, R12 with mineral oil
1980-95 SD508HD, FG head, 2A groove, 5 1⁄4”(132mm) diameter 9285, LE1015, LE1050 RD-5-5575-0P 75R8292
and charging ports
Sanden 508, #9514, R12 with mineral oil SD508, FG head, ear mount, 1A groove, 4 3⁄4” (122mm)
1980-95 9514 RD-5-5684-0P 75R8342
and charging ports diameter
Sanden R134a with PAG Oil & without
Standard Duty ear mount, 2A groove, 5” (125mm) diameter 252-1495, F69-1000 RD-5-12523-1P 75R8772Q
ports
PAGE 163
PETERBILT
ICE/Seltec TM 16 #252-1496 R134a with
TM16, ear mount, poly 8 groove, 4 3⁄4” (123mm) diameter 252-1496, 18-04178 RD-5-12535-1P 75R8752Q
PAG Oil & without ports
ICE/Seltec/ Diesel Kiki DKS15, TM15,
TM15 CH with 2A groove, 5 1⁄4” (135mm) diameter pulley with 18-3006, K318-36-03/488-
#488-25011 R12 with mineral oil, RD-5-5876-1 75R8512Q
O-Ring with ports 25011
OE#18-3006
ICE/Seltec TM15 # 488-45011 - R134a
ICE/Seltec TM15 # 488-45063 - R134a
488-45065 RD-5-7164-1P 75R8632Q
Compressor with PAG OIL, without ports diameter without ports
ICE/Seltec TM15 # 488-45077 - R134a
CONDENSER
335, 340 2006-07 25” X 31” X 5⁄8” W pad Fitting F31-6042 RD-4-6812-0P 77R1335
386, 387 2005-08 25” X 31” X 5⁄8” W pad Fitting F31-6042 RD-4-6812-0P 77R1335
All 2005-08 24” X 3⁄4” X 30 1⁄8” w pad fitting F31-6043 RD-4-6812-0P 77R1335
All 1999-00 Modine 1E4582 RD-4-7020-0P 77R0705
All 1987-00 With Detroit or Cat engines 18-03543 RD-4-5462-0P 77R0580
C.O.E., Conventional 1974-86 Radiator Mount (Grilldenser) RDG-7024-0P RDG-7024-0P 77R5350
Conventional 1974-86 Grilldenser (except hood mount) RD-4-3683-2P RD-4-3683-2P 77R7900
Conventional 1974-86 Grilldenser (except hood mount) RD-4-3683-2P RD-4-3683-2P 77R7900
Conventional models 289-387 1988-06 Serpentine Type 31 1⁄2” X 8 1⁄2” 23-12753 RD-4-5462-0P 77R0580
Conventional models 289-387 1974-86 Radiator Mount (Tube Fin), Red Dot O.E. 589540 RD-4-3724-0P 77R0650
13-210 MidRanger 1987-96 Radiator mount, Red Dot A/C RD-4-4161-0 / PA1190 RD-4-4161-0P 77R0900
310 LCF C.O.E., Conventional 1974-86 Radiator Mount (Grilldenser) RDG-7024-0P RDG-7024-0P 77R5350
320, 320LCF (Low Cab Forward) models 1994-01 Radiator mount, tube & fin coil type, Red Dot A/C RD-4-4931-0P RD-4-4931-0P 77R0665
357, 377, 378, 379, 385 Conventional 1994-02 Full Face with (Signet) A/C 18-0415 / 18-03809 RD-4-5658-0P 77R6950
357, 377, 378, 379, 385 C.O.E.,
1974-86 Radiator Mount (Grilldenser) RDG-7024-0P RDG-7024-0P 77R5350
Conventional
359 Conventional 1978-86 Grilldenser (except hood mount) RD-4-3683-2P RD-4-3683-2P 77R7900
ELECTRICAL SWITCH
ALL Conventional & C.O.E. 1987-93 Red Dot CTC II Circuit Board RD-6-4735-0 / CD1035 RD-6-4797-0P 71R3502
ALL Conventional & C.O.E. 1987-93 Red Dot CTC II Control Module RD-6-4680-0 RD-6-4680-0P 71R3550
All model series with Blower rotary BA1020, BA1190, BOA-80-
switch, OE # BA1020, BA1190 926-00-059
All model series with Blower toggle BSM322005, BA1205, RD-
1986-00 Red Dot A/C units, toggle, 5 terminal, 4 position, SPST RD-5-4694-1P 71R0450
switch, OE # BSM322005, 354375377379 5-4694-1
C.O.E. with Kysor A/C 1973-86 Bunk Switch (3-Prong) 220417 / BA1325 RD-5-3748-0P 71R0010
C.O.E. with Kysor A/C 1973-86 Bunk Switch (4-Prong) 221030 / BE1000 RD-5-0071-0P 71R0400
Conventional with Kysor A/C 1977-86 Fan Switch 221030 RD-5-0071-0P 71R0400
Conventional with Kysor A/C 1973-86 Rocker Switch 220891 / BA1260 RD-4151-2P 71R0550
Red Dot A/C Main units. Toggle switch, 12 V, 3 Position, DPDT,
282, 352 C.O.E. 1974-81 220758, 221289, BE1035 RD-4123-2P 71R0200
6 terminals
330 - 387 models, 20 amp circuit breaker 1993-05 Circuit breaker, 20 amp, 1 3⁄8” x 1 3⁄8” x 2⁄3” with reset K1110-0548-20 RD-5-6714-0P 71R1315
330 - 387 models, fan cycling switch for Fan override (grey), Highside, normally open 200 psi, closes
1993-05 RD-5-8218-0 RD-5-8218-0P 71R6160
Red Dot and Signet A/C 270 psi
330 - 387 models, micro switch for BOA-80-908-00-219,
1993-05 Micro Switch with Bergstrom A/C, SPDT, 15 amp RD-5-8490-0P 71R1610
Bergstrom A/C BSM650471
PAGE 164
PETERBILT
ELECTRICAL SWITCH
362 C.O.E. 1981-86 Blower Relay (30 amp), SPST, 5 terminals BA1010 RD-5-10154-0P 71R1922
EVAPORATOR
All Conv 1998-05 w Signet A/C 3X010018 RD-2-6299-0P 76R7730
All model series with Bergstrom A/C, OE
1986-93 Main unit (Bergstrom) 151280, NA1005 RD-2-1281-0P 76R6950
# 151280, NA1005
Conventional & C.O.E. 1987-98 Sleeper Unit (Red Dot) RD-2-1402-0, NA1145 RD-2-1402-0P 76R6150
13-210 MidRanger 1987-93 MidRanger Main unit (Red Dot A/C) RD-2-1510-0 RD-2-1510-0P 76R5000
320, 320LCF (Low Cab Forward) models 1995-02 Main unit (Bergstrom) 108291, NA1295 RD-2-2928-0P 76R6040
310, 357, 372, 375, 376, 377, 378, 389
1987-93 Main unit (Red Dot) RD-2-1485-0, NC1000 RD-2-1485-0P 76R6850
includes C.O.E.
362 C.O.E. 1980-03 Main unit (Red Dot) RD-2-1610-0 RD-2-1610-0P 76R7010
All 1997-07 W Bergstrom A/C EA1315 RD-5-7015-0P 71R8320
All Conventional and C.O.E. model series EA1065, RD-5-6868-1,
1975-97 Main unit (Red Dot) RD-5-6868-0P 71R8301
with OE # RD-4157-0, 308011, 18-04275 308011, 18-04275, 404098
289, 357, 375, 377, 379 1976-00 Main unit and Sleeper 18-04275, RD-5-6868-1 RD-5-6868-0P 71R8301
320 1996-01 Main unit, block valve, hi-capacity, 2 ton, female O-Ring 540035 RD-5-7015-0P 71R8321
320, 320LCF (Low Cab Forward) models 1987-97 Main unit (Red Dot) RD-5-6868-1 RD-5-6868-0P 71R8301
Main unit (Bergstrom), block valve, hi-capacity, 2 ton, female
320, 320LCF (Low Cab Forward) models 1986-00 EA1315 RD-5-7015-0P 71R8321
O-Ring
357, 375, 377, 379 with Red Dot A/C 1987-93 Sleeper Unit (Red Dot) RD-5-6868-1, EA1065 RD-5-6868-0P 71R8301
362, 372 C.O.E. 1987-04 Main unit 18-04275, RD-5-6868-1 RD-5-6868-0P 71R8301
387 with Bergstrom A/C 1997-07 Main unit, block valve with schrader port, 2 Ton BSM540057 RD-5-8936-0P 71R8430
387 with Bergstrom A/C 1999-07 Sleeper unit (Bergstrom) no nick type (O-ring) valve BSM540056 RD-5-10447-0P 71R8405
387 with Bergstrom A/C 1999-05 Sleeper unit (Bergstrom) BSM540044 RD-5-10447-0P 71R8405
387 with Bergstrom A/C 1997-00 Sleeper Unit, 1 1⁄2 T, flange expansion valve BSM540056 RD-5-10333-0P 71R8440
All Conventional and C.O.E. model series
Main unit, all models with flare fitting EA1005, 1899008 RD-4126-1P 71R8050
with OE # EA1005, 1899008
All Conventional and C.O.E. with Red Dot
Main unit (Red Dot) with O-Ring fitting RD-5-3824-1P RD-5-3824-1P 71R8100
A/C, OE # RD-5-3824-1P
282, 352 C.O.E. 1974-80 Main unit 404073, EA1020, EA1230 RD-5-3824-1P 71R8100
282, 352, 362, Conventional and C.O.E. 1969-87 Main unit with Evans A/C HV32668 RD-4126-1P 71R8050
359 Conventional and C.O.E. 1973-80 Main unit 404073, EA1020, EA1230 RD-5-3824-1P 71R8100
357, 377, 378, 379, 385 1994-01 Sleeper Unit (Signet) P93CAC3900-02S RD-5-10734-0P 71R8090
All model series with Signet A/C, OE #
1995-06 Main unit, Red orifice tube P93CAB2500-01S RD-5-9564-0P 71R8505
P93CAB2500-01S
357, 375, 378, 379, 385 1994-01 Main unit with GM CCOT (white)orifice tube for Signet A/C P93CAC3900-01S RD-5-4919-0P 71R8500
357, 377, 378, 379, 385 with Signet A/C 1997-05 Main unit, Orange tube, blue orifice with green HBNR 5X010061 RD-5-10011-0P 71R8504
EC1015, BSM308007,
357, 377, 378, 379, 385 with Signet A/C 1994-09 Main unit, Red orifice tube RD-5-9564-0P 71R8505
P93CAB2500-01S
EXPANSION VALVE / REFRIGERANT SOLENOID
Conventionals 1976-01 Sleeper units, 12VDC, #6 male O-Ring RD 4188 0, 410575, 560890 RD-4188-0P 71R9002
FILTER
All Conventional and C.O.E. model series
2008-10 In-cab foam air filter, 13 5⁄8” wide x 10” high x 3⁄4” thick BSM525838, 3199021 RD-5-10775-0P 78R5308
with In-Cab filter
387, All Conventional and C.O.E. model
1993-09 In-cab evaporator filter, 13 3⁄4” wide x 10 1⁄4” high x 3⁄4” thick BSM525507, KE0301P RD-5-10745-0P 78R5420
series with In-Cab filter
PAGE 165
PETERBILT
COMPRESSOR
HEATER CORE - SANDEN
Conventional & C.O.E. 1987-01 Sleeper Unit (Red Dot) RD-1-0574-0, MC1060 RD-1-0574-0P 76R2350
320, 362, 372 C.O.E. 1988-04 Main unit (Red Dot) RD-1-0715-0 RD-1-0715-0P 76R3460
357, 362, 375, 377, 378, 379 1987-95 Main unit (Red Dot) RD-1-0650-0 RD-1-0650-0P 76R3250
PRESSURE SWITCH
All Series with Red Dot A/C switch, OE #
Trinary Switch, normally closed (expansion valve mount) RD-5-4625-0, BA1240 RD-5-4625-0P 71R7650
RD-5-4625-0
All Series with Red Dot A/C, micro switch RD-5-8490-0, 650471,
1976-95 Red Dot A/C units, micro switch, SPDT, normally open RD-5-8490-0P 71R1610
OE # RD-5-8490-0 652100, BA1045
All Series with Red Dot A/C, OE # 18-
High pressure switch, normally open 190 psig, opens 250psi 18-03601, 20PS39-16 RD-5-4912-0P 71R6100
03600, 20PS40-11
All Series with Red Dot A/C, OE # RD-5- RD-5-6394-0, 18-03163,
1997-00 High Pressure Fan switch, normally open, 2 pin RD-5-6394-0P 71R6080
6394-0 BOA 80 941 00 063, BA1250
All Series with Red Dot trinary A/C Trinary Switch, 7⁄16-20 female, normally open (exp valve RD 5 4583 0, BC1000,
RD-5-4583-0P 71R7550
switch, OE # RD-5-4583-0 mount) BSM865700
All Series with Red Dot trinary A/C
Trinary Switch, 3⁄8-24 female, normally open (drier mount) BC1005, RD 5 4585 0 RD-5-4585-0P 71R7500
switch, OE # RD-5-4585-0, BC1005
All series with Signet A/C, low pressure P93CAA3606-1, RD-5-
Fan Override Switch (grey) RD-5-8218-0P 71R6160
switch 8218-0
330, 357, 358, 359, 379, 385 with low Low Pressure Cut-Out (beige), norm. open 23 psig, closes 47
1995-01 18-04331, P93CAA-3604-1 RD-5-8219-0P 71R6170
pressure switch psig
330, 357, 358, 359, 379, 385 with Signet High pressure switch, normally closed 210 psi, opens 340 psi,
1995-10 18-03825, P93CAA-3605-1 RD-5-8220-0P 71R6180
A/C, high pressure switch M-10 female (Purple)
330, 357, 358, 359, 379, 385 with Signet Low Pressure Cut-Out (beige), norm. open 23 psig, closes 47
1994-02 18-03824, P93CAA-3604-1 RD-5-8219-0P 71R6170
A/C, low pressure switch psig
BB1005, 20PS39-10,
357, 362, 372, 375, 376, 377, 378, 379 1988-01 Low pressure switch with Male Threads O-Ring(R134A) RD-5-6395-0P 71R6040
20PS39-40, 18-03285
18-03600, 20PS40-11, BOA
357, 375, 377, 378, 379 1988-95 High pressure fan switch, normally open 210psi, closes 300psi RD-5-6430-0P 71R6110
80-942-01-695
Low pressure cut out switch, 3⁄8”-24, norm. open, closes 27 BB1000, 085108-00,
357, 375, 377, 378, 379 RD-4191-0P 71R6050
psig 735203-1
387 series with Bergstrom A/C, low Low pressure switch, black, normally closed 5 psi, opens 35
1999-06 BSM650446 RD-5-10167-0P 71R6183
pressure switch, OE#BSM650446 psi, M-10 female
RECEIVER DRIER
All 2009-10 3” X 10 1⁄2” flange type, manifold block F37-6008 RD-5-10434-0P 74R2001
All Series with Kysor KA300 A/C,
1973-90 O-Ring Type with side port, top glass, without switch JA1900 RD-5-3843-0P 74R2556
Peterbilt OE # JA1900
All Series with Peterbilt OE # 18-03783 1993-96 Male & Female O-Ring with 2 Gage Ports, MI IN Cap, HPRV 18-03783 RD-5-10735-0P 74R3156
All Series with Peterbilt OE # 085200-00,
1987-94 Receiver Drier with quick disconnect & HPRV 085200-00, JA1780 RD-5-9791-0P 74R3314
JA1780
All Series with Peterbilt OE # K251-263, K251-306, RD 4160 1,
1975-89 #6 male O-Ring, 2 3⁄4” X 10” with binary switch RD-5-9455-0P 74R1836
RD 4160 1 JA1120, JA1130
Conventional & C.O.E. 1993-97 Male inlet, Female outlet with 2 M10 Ports 18-03783, 18-03076 RD-5-10735-0P 74R3156
Conventional & C.O.E. 1988-93 O-Ring Type with out Sight Glass 18-02346 RD-5-4834-0P 74R3306
Conventional & C.O.E. 1987-93 #6 male O-Ring, 3” X 10” with moisture indicator, side glass JA2120 RD-5-6504-0P 74R2306
Conventional and C.O.E with Peterbilt OE
1993-00 #6 male O-Ring, 3” X 8 1⁄4”, top port, schrader ports 18-03619, 23-14233 RD-5-10777-0P 74R2616
# 18-03619, 23-14233
13-210 MidRanger with Kysor A/C,
1987-93 #6 male O-Ring, 2 3⁄4” X 10 5⁄8” 402529, JA1895 RD-5-3593-0P 74R1756
Peterbilt OE # 402529, JA1895
13-210 MidRanger with Kysor A/C,
1987-93 #6 male O-Ring, 3” X 10” with moisture indicator, side glass JA2120 RD-5-6504-0P 74R2306
Peterbilt OE # JA2120
13-210 MidRanger with Peterbilt OE #
1987-93 #6 male O-Ring, 2 3⁄4” X 10 5⁄8”, without trinary switch JA1085 RD-5-6567-2P 74R3466
JA1085
13-210 MidRanger with Peterbilt OE #
1987-93 #6 male O-Ring, 2 3⁄4” X 10”, without binary switch JA1090 RD-5-5572-0P 74R1856
JA1090
PAGE 166
PETERBILT
RECEIVER DRIER
13-210 MidRanger with Red Dot A/C 1987-93 #6 male O-Ring, 2 3⁄4” X 9 5⁄8” RDH RD5 5571 0, JA1090 RD-5-5571-0P 74R1806
282 Series with Peterbilt OE # JA1110 1969-80 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) JA1110 RD-5-4632-0P 74R1956
282, 352 C.O.E. 1977-80 O-Ring type with female switch port and side sight glass 18-01800 RD-5-4955-0P 74R2706
282, 352, 357, 375, 377, 379 Conventional
1974-93 O-Ring type with female switch port and side sight glass 18-01800 / JA1240 RD-5-4955-0P 74R2706
with Kysor A/C
362 1981-93 Main unit (Red Dot) 18-02346 RD-5-4834-0P 74R3306
O-Ring Type with Female Side Mount Switch Port and top
362, 372, C.O.E. 1988-04 18-01800 / JA1240 RD-5-4955-0P 74R2706
Sight Glass
387 Conventional & C.O.E. 1999-10 3” X 10 1⁄2” flange type, manifold block F37-6000, JA2225 RD-5-10434-0P 74R2001
Conventional & C.O.E. 1994-02 Main unit with Accumulator, female O-Ring, 3 1⁄2” X 9 1⁄2” 18-03837 / JC1080 RD-5-10927-0P 74R5061
Conventional & C.O.E. with Signet A/C,
1998-10 Main unit with Accumulator (Signet) pad mount fittings 18-04171 / F31-6063 RD-5-9556-0P 74R5060
OE# 18-04171
357, 375, 378, 379, 385 1995-02 Main unit with Accumulator (Signet) 18-03837 RD-5-10927-0P 74R5061
RELAY
320 1997-04 Main unit Relay, Bosch type (30⁄20 amp), SPST, 5 terminals CB1005 RD-5-4408-0P 71R1702
RELAY (ACTUATOR)
(Bergstrom), Peterbilt OE # 650341
Conventional and C.O.E. series, Peterbilt
1995-01 Servo Actuator, 104° max. travel, D label (red) P93CAA0200-01S RD-5-6320-0P 71R3575
O.E. #P93CAA0200-01S
RESISTOR
ALL Conventional & C.O.E. 1995-09 Main unit & Sleeper (Bergstrom) 4 terminal 650475BSM / CA1070 RD-5-3647-0P 71R1450
ALL Conventional & C.O.E. 1991-96 Main unit (Bergstrom) 3 terminal 650179 / CA1035 RD-5-10341-0P 71R1457
C.O.E. with Kysor A/C 1973-86 Red Dot speed control resistor, 3 terminal, 3 speed 650790 RD-5-3647-0P 71R1450
Main unit (Bergstrom), speed control resistor, 3 terminal, 3
320 1987-96 650790 / CA1000 RD-5-3647-0P 71R1450
speed
320 1996-01 Resistor, 3 COIL, Thermosfused 12V CA1070 RD-5-10341-0P 71R1457
362 1988-04 Main unit, Red Dot speed control resistor, 3 terminal, 3 speed RD-5-3647-0 / CA1000 RD-5-3647-0P 71R1450
387 1999-01 Resistor, 3 COIL, Thermofused 12V CA1070 RD-5-10341-0P 71R1457
387 2000-04 Main and Sleeper Unit Blower Resistor (Bergstrom) CA1035 RD-5-10341-0P 71R1457
357, 375, 377, 379 Conventional 1987-93 Main unit (Red Dot) RD-6-4661-1 RD-6-4661-1P RD-6-4661-1P
THERMOSTATIC SWITCH
All Conventional Series with Signet A/C,
1995-99 Fixed setting with 24” capillary tube, 31 - 39°F P93CAA4230-02S RD-5-4531-24P 71R3200
OE# P93CAA4230-02S
All Series with Bergstrom-Kysor A/C,
1973-76 Rotary thermostat with 48” capillary tube, 34 - 52°F BD1035, 404082 RD-4125-48P 71R2300
rotary thermostat # 404082, BD1035
All Series with non-Red Dot A/C, RD-5-4531-24, 589490,
1977-86 Fixed setting with 24” capillary tube, 31 - 39°F RD-5-4531-24P 71R3200
thermostat # RD-5-4531-24 BD1075
All Series with Red Dot A/C, OE# RD-5- RD-5-4531-24, BSM323010,
4531-24 BD1095, BD1105
All Series with Red Dot Bunk unit, OE# RD-4430-0P, BD1040,
1987-01 Bunk thermostat rotary switch with auxillary circuit RD-4430-0P 71R2500
RD-4430-0 BD1285, 18-02329, 220497
282, 352 C.O.E. 1969-83 RD-4226-0P 71R2700
mount BD1420, RD 4226 0
282, 352 C.O.E. 1974-81 Cable controlled with 18” capillary tube, 26 - 66°F 404077 RD-5-4911-0P 71R2600
282, 352, 362 C.O.E. with bunk
1973-86 Bunk thermostat rotary switch with auxillary circuit 220497, BD1040, BD1285 RD-4430-0P 71R2500
thermostatic switch
Kysor A/C, Rotary thermostat with 48” capillary tube, 34 -
289, 359 1969-77 BD1035, 404082 RD-4125-48P 71R2300
52°F
RD-4427-24, BD1065,
310, 310 LCF Series 1979-86 Fixed setting with 24” capillary tube, 34 - 38°F RD-4427-24P 71R3100
BD1075
PAGE 167
PETERBILT
THERMOSTATIC SWITCH
320, 320 LCF Series 1986-08 Fixed setting with 24” capillary tube, 31 - 39°F 589490 / BD1075 RD-5-4531-24P 71R3200
357, 375, 377 Conventional with Kysor 404028, BA1015, BD1330,
1976-87 Main unit (Kysor), Rotary thermostat, 36” cap tube RD-4125-36P 71R2250
Main unit 1-1844Q
357, 375, 377, 379 Conventional 1987-93 Preset Type RD-5-4531-24 RD-5-4531-24P 71R3200
357, 375, 377, 379 Conventional with
1981-86 Fixed setting with 24” capillary tube, 31 - 39°F 404145 RD-5-4531-24P 71R3200
Kysor or Evans A/C (Preset Type)
362, 372 Series with Red Dot Main unit 1988-04 Fixed setting with 24” capillary tube, 31 - 39°F RD-5-4531-24 / BD1105 RD-5-4531-24P 71R3200
362, 372 C.O.E. with Bergstrom Main
1991-94 Main unit (Bergstrom), Rotary thermostat, 36” cap tube 404028, BA1345 RD-4125-36P 71R2250
unit
362, 375, 377, 379 Conventional Series 404157, BD1095, AM81019,
with Kysor, Evans A/C HV33061
All 2000-08 650163, BD1355 RD-5-8938-0P 71R3160
mount
WATER VALVE
All Conventional & C.O.E. Series with
1982-02 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose 173096 RD-5-8935-0P 72R6510
Kysor valve, Peterbilt OE # 173096
1987-00 Air operated valve, 90° elbow MA1085 RD-5-8857-1P 72R6421
Peterbilt OE # MA1085
357, 375, 377, 378, 379 1987-93 Cable Operated RD-5-5495-0 RD-5-5495-2P 72R5270
357, 375, 377, 378, 379 1987-93 Cable Operated, Red Dot (5⁄8” to 5⁄8”), pull to open, 90° RD-5-5495-0, MA1205 RD-5-5495-1P 72R5260
357, 375, 377, 378, 379 1987-93 Air operated valve, straight, 5⁄8” to 5⁄8” hose RD-5-8804-0 RD-5-8804-0P 72R6400
RD-5-4800-0, RD-5-8804-
357, 375, 377, 378, 379 1987-00 Air operated valve, straight, 5⁄8” to 5⁄8” hose RD-5-8804-1P 72R6401
1, MA1020
RD-5-8857-1, RD-5-5138-0,
357, 375, 377, 378, 379 1987-00 Air operated valve, 90° elbow, 5⁄8” to 5⁄8” hose RD-5-8857-1P 72R6421
MA1085
357, 375, 377, 378, 379 1987-93 Air Operated (with 90 degree elbow) RD-5-8857-0 RD-5-8857-0P 72R6420
362 Cable Operated RD-5-5300-0 RD-5-5300-0P 72R5200
387, All Series with electronic actuator
1999-01 Universal sealed actuator, PWM input, 12V or 24V MA1430, BSM650341 RD-5-11862-0P 71R3577
Conventional and C.O.E. series, Peterbilt
1995-01 Servo Actuator, 104° max. travel, D label (red) P93CAA0200-01S RD-5-6320-0P 71R3575
O.E. #P93CAA0200-01S
STERLING also see FORD and FREIGHTLINER

BLOWER MOTOR
F6UZ-19805BA, F8HH-
All series with Main unit, OE # F8HZ- A/C and heater flange mounted motor, CW, vented, shaft
1998-01 19805AA, F8HZ-19805AA, RD-5-10387-0P 73R2142
19805AA length 1 5⁄8”
BA, X4CZ-19805BA
All series with Main unit, OE # XC4H- A/C and heater 7 7⁄8” flange motor, CW, vented, shaft length
1998-10 XC4H-19805-AA RD-5-11579-0P 73R3072
19805-AA 1 1⁄2”
All main heater unit 1998-00 Flange motor F1HZ19805 RD-5-11843-0P 73R3092
All series with Main unit, rotary blower RD-5-
1998-10 Rotary switch, 4 terminal F4DZ-19986A RD-5-10194-0M
switch OE # F4DZ-19986A 10194-0M
All series with Main unit, blower switch F1HZ-19986A, D5AZ-
1998-10 Lever switch, 4 terminal, 4 position RD-5-10196-0P 71R0487
OE # F1HZ-19986A 19986A
CLUTCH ASSEMBLY
All series with Nippondenso Clutch, OE #
1986-92 All models with FS6 Nippondenso compressor, 2 groove E4HZ-2884-B RD-5-10354-0P 75R4712
E4HZ-2884-B
All series with Sanden 7H15 clutch, OE #
Poly 8 groove, 4.7” diameter (119mm), Ford plug 4427-9931, 7731-9930 RD-5-10361-0P 75R1432
4427-9931, 7731-9930
PAGE 168
STERLING
CLUTCH ASSEMBLY
F7HS-19D629AA,
without clutch, replaces 1998-02 Tube O-Ring type head without clutch, (universal - new) RD-5-8638-1P 75R7290
ET210L-25150, C
OE#ET210L-25150, C
COMPRESSOR - SANDEN
Sanden 7H15, #4305 R134a compressor 7H15, WJ head, ear mount, poly 8 groove, 4.7”(119mm)
1997-06 4305 RD-5-11239-0P 75R81172
with PAG oil diameter
Sanden 7H15, #4422 R134a compressor 7H15, WH head, direct mount, poly 8 groove, 4.7”(119mm)
4422 RD-5-11237-0P 75R81152
with PAG oil diameter
Sanden 7H15, #4423 fits Cummins C-12,
7H15, WJ head, direct mount, poly 6, 4.9”(125mm) diameter 4423 RD-5-11238-0P 75R81162
ISX engine
Sanden 7H15, #4427, 4718 fits Cat 3126 7H15, WJ head, ear mount, poly 8 groove, 4.7”(119mm)
1997-06 4427, 4718 RD-5-11259-0P 75R81392
engine, Mer 366. diameter
Sanden 7H15, #4469, 4603 Detroit 60, 7H15, WJ head, ear mount, 2A groove, 5 1⁄4” (132mm) 4469, 4603, F4HT-19D629-
RD-5-11241-0P 75R81192
ISC engine, OE# F4HT-19D629-CA diameter CA
Sanden 7H15, #4470, 4602 R134a 7H15, WH head, direct mount, 1A groove, 6 1⁄2” (169mm) 4470, 4602, F4HT-19D629-
1997-06 RD-5-11242-0P 75R81202
compressor with OE # F4HT-19D629-BA diameter BA
Sanden 7H15, #4482, 4885 R134a 7H15, GV head, ear mount, poly 8 groove, 4.7”(119mm)
1997-03 4482, 4885 RD-5-11249-0P 75R81282
compressor with PAG oil diameter
Sanden 7H15, #4486, 4767 R134a 7H15, WH head, direct mount, poly 8 groove, 4.7”(119mm) 4486, 4767, A22-48973-
1997-06 RD-5-11252-0P 75R81312
compressor with OE# A22-48973-000 diameter 000
Sanden 7H15, #4486, 4767, fits LT7500
7H15, WH head, direct mount, poly 8 groove, 4.7”(119mm)
- 9900 with Cat C12 engine, Detroit S60 1997-06 4486, 4767 RD-5-11252-0P 75R81312
diameter
series
Sanden 7H15, #4810, fits Cummins C12
1997-04 7H15, WJ head, direct mount, poly 6, 4.9”(125mm) diameter 4810 RD-5-10275-0P 75R84352
ISX engine
Sanden 7H15, #4817, fits Cat 3126 7H15, GV head, ear mount, poly 8 groove, 4.7”(119mm)
1997-03 4817 RD-5-11249-0P 75R81282
engine diameter
Sanden 7H15, # 7804, All Cargo series
7H15, WH head, direct mount, poly 8 groove, 4.7”(119mm)
with Cummins ISB engine, OE# F4HT- 1998-05 7804, F4HT-19D629-AA RD-5-11245-0P 75R81252
diameter
19D629-AA
CONDENSER
A-Line , A- Line Actera, L-Line 5500 -
1998-03 All models withFactory Air, Grilldenser Type 37” x 19” x 3⁄4” F6HZ-19712A RD-4-5696-0P 77R6807
8500, Silverstar
1995-98 All models withFactory Air, Grilldenser Type 37” x 19” x 3⁄4” F6HT-19710-BA RD-4-5696-0P 77R6807
8500, Silverstar
1994-97 All models withFactory Air, Grilldenser Type 27” x 21” x 1” F4HZ-19712A RD-4-5695-0P 77R6805
8500
All Series with Sterling OE# E59H- E59H-19860AA, E69Z-
1994-01 Main unit, Red orifice tube RD-5-9564-0P 71R8505
19860AA, E69Z-19D990A 19D990A
FILTER
All Series with Sterling OE# VCC36000006, N10G-
2003-06 Main unit, 8 1⁄4”x8 1⁄2”x3⁄4” pleated filter RD-5-11836-0P 78R5430
VCC36000006 36000006
PRESSURE SWITCH
All Series with Accumulator Cycling
1998-99 Accumulator Cycling Switch, closes 46 psi E35H-19E561AA RD-5-8026-0P 71R6095
Switch, OE # E35H-19E561AA
All Series with Pressure Cycling Switch,
Pressure Cycling Switch, closes 46 psi E35H-19E561A RD-5-8026-0P 71R6095
OE # E35H-19E561A
All Series with Red Dot A/C, OE # 18-
High pressure switch, normally open 190 psig, opens 250psi 18-03601, 20PS39-16 RD-5-4912-0P 71R6100
03600, 20PS40-11
All Series with Sterling OE # F3AH- F3AH-19E561AA, F3AZ-
1998-00 Accumulator Cycling R-134A Switch, normally opens 46psi RD-5-10442-0P 71R6093
19E561AA, F3AZ-19E561A 19E561A
Accumulator with 134A charge port and pressure switch port,
A-Line , A- Line Actera, 2000-10 4C4H19C808-AA RD-5-11546-0P 74R5095
inlet 5⁄8” (#10), outlet 3⁄4” (#12)
PAGE 169
Sterling
All Series with Sterling OE# F6HZ- Accumulator with 134A charge port and pressure switch port, F6HZ-19C836A, XC4H-
1997-06 RD-5-11546-0P 74R5095
19C836A, XC4H-19E647AA inlet 5⁄8” (#10), outlet 3⁄4” (#12) 19E647AA
All Series with Sterling OE# XL3Z- Accumulator, 3 1⁄2 diameter, 8 1⁄2” long, inlet Springlock,
1998-00 XL3Z-19C836AA, YF2586 RD-5-10463-0P 74R5083
19C836AA outlet Pad mount
All Series with Sterling OE# XL3Z- Accumulator, 3 1⁄2 diameter, 9 1⁄2” long, inlet #12 Springlock, XL3Z-19C836BA, F75Z-
1998-00 RD-5-10462-0P 74R5081
19C836BA outlet #10 male O-Ring 19C836BA
VOLVO/WHITE GMC
BLOWER, FAN BLADE
All series with OE # 60501-5002 Bergstrom, Kysor and Red Dot A/C, 10” diameter, 23° pitch 60501-5002 RD-5-7297-0P 73R8100
BLOWER, FAN MOTOR
All series with OE# 4060009-000, 4060009-000, 8911949,
Universal 12 Volt, 2 speed, CW rotation, On-Off-On RD-5-5796-0P 73R9062
8911949, 2899-006-026, 038, 051 2899-006-026, 038, 051
BLOWER MOTOR
Bergstrom A/C, single shaft motor, 1 speed, 5” length 1707646 RD-5-9100-0P 73R0462
1707646
All Series with Bergstrom A/C, OE # Main unit (Bergstrom), double shaft motor, 1 speed, 4 7⁄8”
1989-96 205853 RD-5-10068-0P 73R4322
205853 length
All Series with Evans, Red Dot heater,
1970-86 All with 3 1⁄4” diameter blower motor, 1 speed, Rev. direction 60009-5015, HV22714 RD-5-10390-0P 73R0212
OE# 60009-5015
All series with OE # 3918242, 2809-
Main unit, single shaft, 1 speed, 4 1⁄2” length, CCW 3918242, 2809-541-006 RD-5-6531-0P 73R0322
541-006
All series with OE # 3949261 Main unit with flange style motor, 1 speed, 4 3⁄4” length, CW 3949261 RD-5-4937-0P 73R2102
All series with OE # 3949262, 60009- 3949262, 60009-5009,
Main unit, single shaft, 1 speed, CW, 4 3⁄4” length RD-5-6526-0P 73R0422
5009 RD-5-6526-0
All series with OE # 3949266 Bergstrom A/C, double shaft, 4 3⁄4” length 3949266 RD-5-6801-0P 73R4182
All series with OE # 3949386 Heater/AC Motor (floor mt), 1 speed, 4 5⁄8” length, CCW 3949386 RD-5-10389-0P 73R0372
All series with OE # 3949388 Bergstrom A/C, single shaft motor, 1 speed, 5” length 3949388 RD-5-9100-0P 73R0462
All Series with OE # 60009-5005 1971-84 Kysor A/C, single shaft motor, 1 speed, 5” length 60009-5005, 2807-517-019 RD-5-6526-1P 73R0402
All Series with OE # 888384 Single shaft motor, 1 speed, 5” length, CCW 60009-5005, 2807-517-019 RD-5-6526-1P 73R0402
All Series with OE# V1112300 1986-94 Sleeper cab motor, single shaft with brackets (except Bosch) V1112300 RD-5-8255-0P 73R0982
All series with roof mounted A/C, OE #
Kysor A/C, single shaft-non-vented, 1 speed, CW, 4 7⁄8” length 60009-5014, 275130 RD-5-7129-0P 73R0542
60009-5014
All Series with sleeper unit blower, OE
Sleeper unit, single shaft-vented, 1 speed, CW, 4 5⁄8” length 892106 RD-5-10905-0P 73R0442
# 892106
ACL, WC, WCA, WG, WH, WI, WIA, WX,
1988-00 Main unit (Bergstrom), Double shaft blower motor kit only 3945237 RD-3-10538-0P 73R4532
WXLL, WXR with Bergstrom A/C
ACL, WG, WH, WX, WIA, WCA, WXLL 1988-98 Main unit (Bergstrom) motor kit 3945237 RD-3-10538-0P 73R4532
Autocar, RBII, RCII, RXII, WI Series 1977-87 Main unit, single shaft, 3 speed, CCW, 4 3⁄4” length 176571, 60009-5018 RD-5-4932-0P 73R1052
Autocar, WCS, WCL, WHE, WHL, WHS,
1988-02 Main unit (Bergstrom), plate mounted 6 3⁄4” diameter 1092319 RD-5-10395-0P 73R3032
WIL, WX
Autocar, WHE, WIA, WIM with OE# BOA
1989-94 Sleeper with Blower / wheel assembly, Bosch Type BOA 80-414-00-209 RD-5-10384-0p 73R5592
80 414 00 209
Autocar, WHE, WIA, WIM with Volvo OE#
1987-95 Sleeper with Blower / wheel assembly, Bosch Type 3947550 RD-5-8948-0P 73R5562
3947550
Autocar, WIA with Behr motor assembly, BOA 80-415-00-159, 279,
1988-00 Sleeper Unit, Double shaft blower motor kit only RD-3-10538-0P 73R4532
OE# BOA 80-415-00-159, 279, 3919288 3919288
Main unit with Kysor Class Six unit, double shaft motor, 1
FE Series 1988-02 275102 RD-5-5614-0P 73R4062
speed, 4” length
N Series with Red Dot OE# RD-5-3753-1,
1983-95 Main unit (Red Dot), single shaft, 1 speed, CCW, 4 1⁄2” length 3949263, RD-5-3753-1 RD-5-6531-0P 73R0322
Volvo OE# 3949263
N Series with Red Dot OE# RD-5-6526-0 1984-93 Main unit (Red Dot), single shaft, 1 speed, CW, 4 3⁄4” length RD-5-6526-0 RD-5-6526-0P 73R0422
N, RBII, RC, RCII, VN, WAH, WCA, WG,
1986-00 Main unit (Bergstrom), plate mounted 6 3⁄4” diameter 1092319 RD-5-10395-0P 73R3032
WH, WIA, WX
PAGE 170
VOLVO/WHITE GMC
BLOWER MOTOR
N, RBII, RC, RCII, VN, WAH, WCA, WG,
1989-94 Blower / wheel assembly, Bosch Type 1091070 RD-5-10384-0p 73R5592
WH, WIA, WX
N, RBII, RC, RCII, VN, WAH, WCA, WG, With Red Dot or Evans Heater, 1 speed, 3 1⁄4” diameter blower
1976-86 60009-5015 RD-5-10390-0P 73R0212
WH, WIA, WX motor, CW or CCW
N, RBII,, VN, WAH, WCA, WG, WIA 1986-96 Main unit (Bergstrom), plate mounted 6 3⁄4” diameter 1092319 RD-5-10395-0P 73R3032
RBII, RCII, RXII, WI Series 1977-87 Main unit, single shaft, 3 speed, CCW, 4 3⁄4” length 176571, 60009-5018 RD-5-4932-0P 73R1052
RC and with Series with Behr motor
1988-94 Double Shaft Motor only, 1 speed, 5 3⁄8” length 2809-820-020 RD-5-10073-0P 73R4312
assembly, OE # 2809-820-020
RC and with Series with Bosch motor
1988-94 Main unit, Double shaft blower motor kit only 3919288 RD-3-10538-0P 73R4532
assembly, OE # 3919288
VN 420, 610, 770 Series with Behr motor BOA-85-462-51-009,
1998-02 Sleeper Unit (Behr), plate mount, 7 3⁄16” diameter RD-5-10502-0P 73R3052
assembly 3949886
VN 420, 610, 770 Series with Bergstrom
1996-99 Sleeper Unit (Bergstrom) 3947416 RD-5-10905-0P 73R0442
motor assembly
VN 420, 610, 770 Series, VNL64T (97-98) Behr Sleeper Unit, plate mounted, 7” diameter, CW, 1 speed, 3949102, BOA-85-440-
1996-02 RD-5-11466-0P 73R3002
all with Behr motor unit 4 3⁄4” length 51-009
VN 770 Series with Behr motor unit 1997-03 Sleeper Unit, plate mounted 7” diameter, CCW 3949886 RD-5-10393-0P 73R3022
WAH, WCA, WIL Series with Bosch motor
1984-94 Main unit, Double shaft blower motor kit only 3919288 RD-3-10538-0P 73R4532
assembly, OE # 3919288
Main unit (Bergstrom), double shaft motor, 1 speed, 4 7⁄8”
WC, WCA, WG, WIA 1988-00 868541 RD-5-10068-0P 73R4322
length
WG, WX DUAL, WXLL DUAL 1988-01 Main unit (Bergstrom), plate mounted 6 3⁄4” diameter 1092319 RD-5-10395-0P 73R3032
WG, WXLL with Fasco motor assembly, BOA 80-415-00-159, 279,
1988-00 Main unit, Double shaft blower motor kit only RD-3-10538-0P 73R4532
OE# BOA 80-415-00-159, 279, 3919288 3919288
WG, WXLL, OE# V1118390, 3945237 1988-00 Double Shaft Motor, 1 speed, 5 3⁄8” length (except Bosch) V1118390, 3945237 RD-5-10073-0P 73R4312
WHL with Red Dot OE# RD3106-13, Volvo
1981-84 Main unit with 2 speed, single shaft, CCW, 4 1⁄4” length RD-3106-13, 60009-5005 RD-3106-13P 73R0602
OE# 60009-5005
WHL, WHS with Bosch motor 1984-87 Main unit (Bosch motor), plate mounted 6 3⁄4” diameter 868013 RD-5-10395-0P 73R3032
203038, 60009-5025,
WX Dual 1988-01 Main unit, Bosch motor, plate mounted 6 3⁄4” diameter RD-5-10395-0P 73R3032
V1092319, V1119217
WX Dual (Heater Only) 1988-01 Main unit (Bergstrom), Double shaft blower motor kit only 3945237 RD-3-10538-0P 73R4532
WXR 1994-99 Main unit (Bergstrom), Double shaft blower motor kit only 3945237 RD-3-10538-0P 73R4532
BLOWER RELAY
FE Series with Kysor Class 6 1974-00 Bosch type (30 amp), SPST, 5 terminals 176569, 651150 RD-5-4408-0P 71R1702
VN Series 420, 610, 770 1996-01 Main unit, Volvo White, 5 terminal, SPST, 40⁄30 amps BOA80-945-00-079 RD-5-9915-0P 71R1722
BLOWER RESISTOR
All model series with blower fan switch
Resistor for Bergstrom A/C Main unit, 3 terminal, 3 speed 60057-5005 RD-5-10441-0P 71R1463
resistor, OE# 60057-5005
All model series with blower fan switch Resistor (Circuit Breaker) for Volvo-White A/C units, 3
1987-05 V1697520, RD-5-3647-0 RD-5-3647-0P 71R1450
resistor, OE# V1697520 terminal, 3 speed
V1115284, V1118410,
ACL, WG, WH, WX, WIA, WCA, WX DUAL,
1984-00 Resistor only, Main unit, 12V, 3 terminal, 3 speed V212421, V313119, RD-5-10341-0P 71R1457
WXR, WXLL resistor kit (resistor only)
V3134241
VN Series 420, 610 1995-01 Resistor only, Main unit, 12V, 3 terminal, 3 speed 650179 RD-5-10341-0P 71R1457
BLOWER SWITCH
All model series with blower rotary BA1020, BA1190, BOA-80-
switch, OE # BA1020, BA1190 926-00-059
All model series with rocker switch, OE #
1988-00 Bergstrom A/C units, rocker, 2 terminal, 2 position, SPST 1118424, 650088 RD-5-8967-0P 71R0840
1118424, 650088
1984-94 Volvo White A/C units, rocker, 6 terminal, DPDT 60018-5003, RD-4151-4 RD-4151-4P 71R0600
60018-5003
RBII, RC, RCII, RX, WAH, WCA, WG, WH,
1986-93 Auxiliary fan rotary switch, DP3T, 3 speed, long shaft thread V11493 RD-5-3646-0P 71R1150
WIA,WX, VN
PAGE 171
VOLVO/WHITE GMC
BLOWER WHEEL SWITCH
All model series with Kysor Class Six A/C,
Kysor A/C, double entry, 3 3⁄16” diameter x 3 3⁄16” width 260680, BSM602005 RD-5-5656-0P 73R7000
OE # 260680, BSM602005
All model series with OE # 3918247 Red Dot A/C with 3 5⁄16” double entry wheel, 3 3⁄4” width 3918247 RD-3-4829-1P 73R7071
All model series with OE # 60010-5001 Main unit, Single entry wheel (steel), CCW, 5 1⁄4” diameter 60010-5001 RD-5-8618-0P 73R6051
All model series with OE # 60010-5002,
All with 5 1⁄4” single entry wheel, 3 7⁄16” width 60010-5002, 3949274 RD-5-3800-1P 73R6251
3949274
60010-5009, 1-1033Q,
All model series with OE # 60010-5009 Bergstrom A/C with 5 1⁄4” single entry wheel, 2 1⁄2” width RD-3106-39P 73R6151
HC1025, HC1340
All model series with OE # 60010-5014 Kysor A/C, double entry, 3 3⁄16” diameter x 3 3⁄16” width 60010-5014, HC1290 RD-5-5656-0P 73R7000
Main unit (Bergstrom), 4 1⁄2” diameter, 3 3⁄8” width, dual
ACL with Bergstrom A/C 1998-00 1118417 RD-5-10346-0P 73R7130
rotation
FE Series withKysor CLASS SIX 1983-91 260680, HC1290 RD-5-5656-0P 73R7000
width
Red Dot Backwall A/C with 5 1⁄4” double entry wheel, 3 3⁄4” RD-3-2557-2, 1697518,
N Series with Red Dot Backwall A/C 1984-91 RD-3-2557-2P 73R7151
width 3949392
VN Series 420, 610 Sleeper Unit 1996-03 Sleeper units, 5 5⁄8” single entry wheel, 3 7⁄16” width, CW 3947421, BSM302011 RD-5-10753-0P 73R6253
VX Dual (Heater Only) 1988-01 1118417 RD-5-10346-0P 73R7130
rotation
WC, WCA, WG, WH, WI, WIA, WX, WXLL,
WXLL DUAL (heater only), WXR all with 1988-01 1118417 RD-5-10346-0P 73R7130
rotation
Bergstrom A/C
Main unit (Red Dot), Single entry wheel (steel), CCW, 5 1⁄4”
WHL with Red Dot A/C 1982-83 60010-5001 RD-5-8618-0P 73R6051
diameter
CLUTCH ASSEMBLY
Fits CCI/York - R12/134A compressors, 1 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 1 3⁄4” gauge line, 02701-0496, 10582,
RD-5-4975-0P 75R1652
OE # 02701-0496 bullet plug 502731, 520533A
Fits CCI/York - R12/134A compressors, 2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line,
322639 RD-5-4967-0P 75R0452
OE # 322639 bullet plug
Fits CCI/York - R12/134A compressors, 1 groove, 6 3⁄4” diameter pulley, 11⁄16” width, 2” gauge line, 61103-0019, 541653,
RD-5-4983-0P 75R2852
OE # 61103-0019 bullet plug 10584, 502732
Fits CCI/York - R12/134A compressors, 2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line,
61103-0019 RD-5-10367-0P 75R0422
OE # 61103-0019 bullet plug
FitsCCI/York - R12/134A compressors, 1118116, 61103-0017, 024
2 groove, 6” diameter pulley, 1⁄2” width, weatherpak plug RD-5-4972-1P 75R1202
OE # 1118116 21590
FitsCCI/York - R12/134A compressors, OE
2 groove, 7” diameter pulley, 1⁄2” width, bullet plug 31160-7760, 332334 RD-5-4994-0P 75R4502
# 31160-7760, 332334
FitsCCI/York - R12/134A compressors, OE 2 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 2 1⁄4” gauge line,
61103-3606, 1411-41 RD-5-10370-0P 75R3502
# 61103-3606, 1411-41 IHC plug
Fits Sanden 709, SD7H15 R134a
4752-9931, 4777-9931,
compressor, clutch # 4752-9931, 4777- 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), metripak plug RD-5-10761-0P 75R1852
85100878
9931, 85100878
Fits Sanden 709, SD7H15 R134a 85105256, 4695-9931,
2 groove, 1⁄2” width, 4.9” diameter (125mm), metripak plug RD-5-10368-0P 75R1532
compressors, OE # 85105256 4896-9931
1 groove, 6 1⁄4” 158mm diameter pulley, variable width, bullet
R134a compressor #9116, 9680, 9696, 6521-6010 RD-5-5489-0P 75R1402
plug
clutch # 6521-6010
R134a compressor #9515, clutch # 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), 1 wire plug 6519-6010 RD-5-5486-0P 75R0202
6519-6010
R134a compressor #9548, 9669, clutch 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), 1 wire plug 6514-6210 RD-5-5486-0P 75R0202
# 6514-6210
R134a compressors #5423 thru 5434, 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), 1 wire plug 6514-6210 RD-5-5486-0P 75R0202
clutch # 6514-6210
PAGE 172
VOLVO/WHITE GMC
CLUTCH ASSEMBLY
compressor #4626, 4647, 4694, 4699 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), Ford OE plug 6504-6310, 6511-6210 RD-5-10379-0P 75R1542
clutch # 6504-6310, 6511-6210
compressor #4627, clutch # 6511-6110, 2 groove, 1⁄2” width, 4.9” diameter (125mm), bullet plug 6511-6110, 9353-6010 RD-5-7831-0P 75R0192
9353-6010
2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), metripak plug 3918124 RD-5-10759-0P 75R1832
compressor, clutch # 3918124
3099389, 3948140, 4606-
compressor, clutch # 4606-6871, 4705- Poly 8 groove, 4.7” diameter (119mm), metripak plug RD-5-10760-0P 75R1842
6871, 4705-9930, 9931
9930, 9931, 3099389, 3948140
Fits Seltec/Diesel Kiki, CH Series
2 groove, 5 21⁄64” diameter (135mm), bullet plug 511051, 518199 RD-5-6996-0P 75R0222
compressors, leaf spring
511575, 511869 RD-5-6646-0P 75R0182
compressors, clutch # 511575, 511869 plug
511587, 511870, 524-19719 RD-5-9799-0P 75R1422
TM16 compressors, clutch #511587 plug
without clutch, OE # ER210L-25149
R12/134A without clutch, OE # Tube O-Ring type head without clutch, (universal - new) ET210L-25150 RD-5-8638-1P 75R7290
ET210L-25150
CCI/York/Tecumseh - Rotolock Head,
compressors, R12/134A without clutch
COMPRESSOR - SANDEN
Sanden SD5H14, #4510 fits all series SD5H14 2 groove, 5 1⁄4” Diameter ear mount with verticle
8080060, 4510 RD-5-7088-0P 75R8382
with OE# 8080060 O-Ring fitting
Sanden 7H15, #4626 fits all series with 7H15HD, JD Head, direct mount, 2 groove, 5 1⁄4” diameter
8022507, 8177091 RD-5-7522-0P 75R8432
OE# 8022507, 8177091 (132mm) with verticle O-Ring fitting
Sanden 7H15, #4626 fits Detroit 60 7H15HD, JD Head, ear mount, 2 groove, 5 1⁄4” diameter
8022507, 4626 RD-5-7522-0P 75R8432
Series engine (132mm) with verticle O-Ring fitting
Sanden 7H15, #4627 fits all series with
7H15, JD head, ear mount, 2 groove, 4.9” (125mm) diameter 20370291, 8164872 RD-5-7120-0P 75R8422
OE# 20370291, 8164872
Sanden 7H15, #4627 fits Cummins M11,
7H15, JD head, ear mount, 2 groove, 4.9” (125mm) diameter 8164872, 4627 RD-5-7120-0P 75R8422
N14 engine
7H15, JDA head, ear mt, 2 groove, 5 1⁄4”(132mm) diameter 8177090, 4647 RD-5-11316-0P 75R81472
OE# 8177090
Sanden 7H15, #4659 fits all series with 7H15, KC head, ear mount, poly 8 groove, 5 1⁄8” (130 mm)
8142556, 4659 RD-5-10286-0P 75R84482
OE# 8142556 diameter
Sanden 7H15, #4659 fits Volvo 14.0L 7H15, KC head, ear mount, poly 8 groove, 5 1⁄8” (130 mm)
8142556 RD-5-10286-0P 75R84482
engine, OE# 8142556 diameter
Sanden 7H15, #4660 fits all series with 7H15, JDA head, ear mt, poly 8 groove, 4 3⁄4” (119mm)
8177089, 4660 RD-5-11322-0P 75R81482
OE # 8177089 diameter
Sanden 7H15, #4694 fits all series,
includes Caterpillar 3126 engine, 7H15, JD Head, ear mount, 2 groove, , 5 1⁄4” diameter (132mm) 8080060, 4694 RD-5-10276-0P 75R84362
Cummins M11 engine
Sanden 7H15, #4699 fits all series with 7H15, JD Head, direct mount, 2A groove, , 5 1⁄4” diameter
8080059, 85104467, 4699 RD-5-11330-0P 75R81532
OE# 8080059, 85104467 (132mm)
Sanden 7H15, #4699 fits Detroit 60 7H15, JD Head, direct mount, 2A groove, , 5 1⁄4” diameter
8080059, 4699 RD-5-11330-0P 75R81532
Series engine (132mm)
Sanden 7H15, #4700 fits Volvo 14.0L 8080058, 8142556,
7H15, KC head, ear mt, poly 8 groove, 5 1⁄8” (130 mm) diameter RD-5-10277-0P 75R84372
engine, OE # 8080058 8177089
PAGE 173
VOLVO/WHITE GMC
COMPRESSOR - SANDEN
Sanden 7H15, #4711, 8103 fits all series 7H15, JD head, ear mount, poly 8 groove, 4.7” (119 mm)
8142556, 4711, 8103 RD-5-9251-0P 75R8462
with OE# 8142556 diameter
Sanden 7H15, #4715 fits Detroit 60 7H15, WV Head, direct mount, 2A groove, , 5 1⁄4” diameter
8082269, 4715 RD-5-10278-0P 75R84382
Sanden 7H15, #4716 fits Volvo 14.0L 7H15, WV head, ear mount, poly 8 groove, 5 1⁄8” (130 mm)
8082268, 4716 RD-5-11356-0P 75R81762
engine, OE # 8082268 diameter
Sanden 7H15, #4717 fits Caterpillar 3126 7H15, WV Head, ear mount, 2A groove, , 5 1⁄4” diameter
8082270, 4717 RD-5-11343-0P 75R81652
engine, Cummins M11 engine (132mm)
Sanden 7H15, #4733 fits Volvo 7 & 12L, 7H15, WV head, direct mt, poly 8 groove, 5 1⁄8” (130 mm)
20388777, 4733 RD-5-11256-0P 75R81362
ISM11L, M11 diameter
Sanden 7H15, #4757, 4891 fits Cummins 7H15, WV Head, direct mount, poly 6 groove, , 4.9” diameter
8088112, 20501069 RD-5-11257-0P 75R81372
600 15L engine (125 mm)
Sanden 7H15, #4777, 4893 fits
7H15, WV Head, ear mount, 2A groove, , 5 1⁄4” diameter
Caterpillar 3126 engine, Cummins M11 20370289, 4777, 4893 RD-5-11343-0P 75R81652
(132mm)
engine
Sanden 7H15, #4777, 4893 fits
7H15, WV Head, ear mount, 2A groove, , 5 1⁄4” diameter
Caterpillar 3126 engine, Cummins M11 85104592 RD-5-11343-0P 75R81652
(132mm)
engine
20370290, 4778 RD-5-10281-0P 75R84432
Sanden 7H15, #4779 fits Caterpillar 3126
(125mm) Ear Mount JDA Head, 2A groove, clutch 20370291, 4779 RD-5-11336-0P 75R81572
engine, Cummins M11 engine
Sanden 7H15, #4780 fits Detroit 60 7H15, JD Head, direct mount, 2A groove, , 5 1⁄4” diameter
20370292, 4780 RD-5-11337-0P 75R81582
Sanden 7H15, #4781 fits Volvo 14.0L 7H15, KC head, ear mount, poly 8 groove, 4.9” (125mm)
20370293, 4781 RD-5-11338-0P 75R81592
Sanden 7H15, #4823 fits Volvo 14.0L 7H15, KC head, direct mt, poly 8 groove, 5 1⁄8” (130 mm)
20395054, 4823 RD-5-10282-0P 75R84452
85104593, 4890 RD-5-10278-0P 75R84382
Sanden 7H15, #4892 fits Volvo 7 & 12L, 7H15, WV head, direct mt, poly 8 groove, 5 1⁄8” (130 mm)
20501067, 4892 RD-5-11256-0P 75R81362
ISM11L, M11 diameter
7H15, JD Head, direct mount, 2A groove, , 5 1⁄4” diameter
OE# 8080059, 85104467 including S60 8080059, 85104467, 4894 RD-5-11345-0P 75R81672
(132mm)
series Detroit
Sanden 7H15, #4895 fits Volvo 14.0L 7H15, KC head, ear mount, poly 8 groove, 5 1⁄8” (130 mm)
85104531, 4895 RD-5-11346-0P 75R81682
Sanden 7H15, #4896 fits Caterpillar 3126 7H15, JD head , ear mount , 2A groove, 4.9” (125mm)
85104468, 4896 RD-5-11347-0P 75R81692
engine, Cummins M11 engine diameter
Sanden SD508, R-12, #5424 fits all series SD508, FG head, ear mount, 2A groove, 5 1⁄4” diameter
61104-0028, 5424 RD-5-11348-0P 75R81702
with Volvo OE # 61104-0028 (132mm) pulley with O-Ring fitting
Sanden SD5H14, #6664 fits all series SD5H14 2 groove, 5 1⁄4” Diameter ear mount with verticle
8177090, 6664 RD-5-7088-0P 75R8382
with OE# 8177090 O-Ring fitting
Sanden 510-HD, #9119, R12 with Mineral SD510, C head, ear mount, variable groove, 6 1⁄4” diameter
V1110148 RD-5-5200-0P 75R8222
oil, fits all R12 series with OE # V1110148 (158mm)
Sanden 508, 510-HD, #9120, R12 with
SD508⁄510, FG head, ear mount, 2 groove, 5 1⁄4” diameter
Mineral oil, fits all series with OE # 61104-0017, 28, 29 RD-5-5443-0P 75R8212
(132mm) pulley with O-Ring fitting
61104-0017, 28, 29
Sanden 7H15, #9680 fits all R134a series 7H15, C head, ear mount, variable groove, 6 1⁄4” diameter
V1110148 RD-5-11350-0P 75R81732
for OE # V1110148 (158mm)
ICE/Seltec TM16 # 2521475 - fits all TM16 2 groove, 5”(125mm) ear mount, will fit Sanden 4717
8082270, 4717 RD-5-10492-1P 75R8722Q
series with OE# 8082270 applications
ICE/Seltec TM16 # 2521493 - fits all TM16 2 groove, Poly 8 (123mm) ear mount, will fit Sanden
2521493, 8082268, 4716 RD-5-10494-1P 75R8732Q
series with OE# 8082268 4716 applications
PAGE 174
VOLVO/WHITE GMC
Compressor with mineral oil/ with 488-25011 RD-5-5876-1P 75R8512Q
diameter with ports
charge ports
ICE/Seltec / Diesel Kiki #488-25063 -
TM15CH, F head, ear mount, 1 groove, 5” (125mm) diameter
R12 Compressor with mineral oil/ with 488-25063 RD-5-5875-1P 75R8502Q
without ports
charging ports
ICE/Seltec TM15 # 488-45011 - R134a
ICE/Seltec TM15 # 488-45063 - R134a
488-45065 RD-5-7164-1P 75R8632Q
ICE/Seltec TM15 # 488-45077 - R134a
ports
ports
CONDENSER
All model series without aftercooler, OE
1983-87 Serpentine Type overall 29 3⁄4”, fin width 27 1⁄8” x 15 3⁄4” 61203-0012 RD-4-3916-0P 77R0950
# 61203-0012
Radiator Mount, Serpentine Type overall 43 13⁄32”, fin width
All model series with OE # 61203-0029 1988-96 61203-0029 RD-4-5809-0P 77R5270
36” x 17 3⁄4”
Radiator Mount, Tube-Fin Type overall 33”, fin width 29” x
18 1⁄2”
All model series with OE # 61203-3209 1987-91 Serpentine Type overall 29 3⁄4”, fin width 27 1⁄8” x 15 3⁄4” 61203-3209 RD-4-3916-0P 77R0950
All model series with R-12 originally
1992-95 Radiator Mount 61203-3211 RD-4-5812-0P 77R1175
installed, OE # 61203-3211
All model series with Red Dot A/C, OE # Radiator Mount, Tube-Fin Type overall 25”, fin width 23” x
RD-4-3724-0 RD-4-3724-0P 77R0650
RD-4-3724-0 12 1⁄4”
FE models with Kysor Class Six A/C 1983-93 Radiator mount with Kysor factory A/C, tube & fin coil 401043 RD-4-5811-0P 77R1150
RBII, RCII, RXII 1976-86 Serpentine Type overall 29 3⁄4”, fin width 27 1⁄8” x 15 3⁄4” 559371 RD-4-3916-0P 77R0950
RXII 1975-87 61203-0029 RD-4-5809-0P 77R5270
36” x 17 3⁄4”
RXII 1976-86 Serpentine Type overall 29 3⁄4”, fin width 27 1⁄8” x 15 3⁄4” 61203-3001 RD-4-3916-0P 77R0950
20461065, 21095290,
Radiator Mount, Tube-Fin Type overall 32 1⁄2”, fin width 30
VN series with pad mount 1996-03 3092918, 8084347, RD-4-6343-0P 77R0585
3⁄4” x 16 3⁄8”
8084348
WFL Models 1975-86 Serpentine Type overall 29 3⁄4”, fin width 27 1⁄8” x 15 3⁄4” 61203-3001 RD-4-3916-0P 77R0950
WFL Models 1975-85 Serpentine Type 15 x 27 (O-Ring Type) 3918297 RD-4-3917-0P 77R1100
ELECTRICAL SWITCH
All with toggle switch All Toggle switch, SPST, 2 terminal 60015-5015 RD-5-3748-0P 71R0010
All model series with blower rotary BA1020, BA1190, BOA-80-
switch, OE # BA1020, BA1190 926-00-059
1988-00 Bergstrom A/C units, rocker, 2 terminal, 2 position, SPST 1118424, 650088 RD-5-8967-0P 71R0840
1118424, 650088
1984-93 Volvo White A/C units, rocker, 6 terminal, DPDT 60018-5003, RD-4151-4 RD-4151-4P 71R0600
60018-5003
EVAPORATOR
60004-3201, NA1310,
Autocar, WHL, WHS, WIL, WX 1984-87 Main unit, 8” high x 12 11⁄16” long x 3 13⁄32” wide RD-2-1381-0P 76R6950
NB1100
N Series with Red Dot A/C 1984-95 Backwall Unit (Red Dot) 1697519, NA1230 RD-2-1316-0P 76R6350
60004-3201, NA1310,
WCL, WCS 1986-89 Main unit, 8” high x 12 11⁄16” long x 3 13⁄32” wide RD-2-1381-0P 76R6950
NB1100
60004-3201, NA1310,
WHE, WHL, WIM 1987-92 Main unit, 8” high x 12 11⁄16” long x 3 13⁄32” wide RD-2-1381-0P 76R6950
NB1100
WHL Conventional and C.O.E. Series with
1982-83 Main unit (Red Dot), 8” high x 5 5⁄8” long x 2 1⁄2” wide RD-2-1137-5, V1113965 RD-2-1137-5P 76R6110
Red Dot A/C
PAGE 175
VOLVO/WHITE GMC
EVAPORATOR
60004-3201, NA1310,
WX, WXLL DUAL 1994-00 Main unit (Bergstrom), 8” high x 12 11⁄16” long x 3 13⁄32” wide RD-2-1381-0P 76R6950
NB1100
ACL 1988-00 Main unit (Bergstrom) 3916657 RD-5-6868-0P 71R8301
BOA80-321-00-169,
Autocar 1993-99 Sleeper Unit (Behr) RD-5-7567-0P 71R8370
3949281
Autocar 1984-87 Main unit, block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
Autocar, Sleeper unit 1989-92 Sleeper Unit, block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
F6, F7, F86 Series 1981-94 Block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
BSM308011, 3916657,
FE Series 1983-95 Kysor Class Six with female O-Ring fittings RD-5-6868-0P 71R8301
540031, 040138-123
N Series 1984-93 Backwall Unit with Red Dot A/C 3916657, 540031 RD-5-6868-0P 71R8301
RC, RCII 1980-93 Main unit, block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
BSM308011, 3916657,
RXII, WXLL Series 1981-94 Block valve with female O-Ring fittings RD-5-6868-0P 71R8301
540031, 040138-123
3916182, 3949881, BOA80-
VHD Series 2000-02 Main unit, block valve, hi-capacity, 2 ton, female O-Ring RD-5-7015-0P 71R8321
321-00-249
3946673, BOA80-321-
VN Series 420, 610, 770 1996-02 Main unit RD-5-10333-0P 71R8440
00-209
3946673, BOA80-321-
VN Series 420, 610, 770 1996-01 Main unit (Behr), Block valve, 1 1⁄2 Ton, plate mounted RD-5-7179-0P 71R8420
00-209
3916657, 540031, 040138-
VN Series 420, 610 1996-99 Sleeper Unit (Bergstrom) RD-5-6868-0P 71R8301
123, BSM308011
3949281, BOA80-321-
VN Series 420, 610 1996-99 Sleeper Unit (Behr) RD-5-7567-0P 71R8370
00-169
Sleeper Unit (Behr), block valve, hi-capacity, 2 ton, female 3916182, 3949881, BOA80-
VN Series 420, 610, 770 1999-00 RD-5-7015-0P 71R8321
O-Ring 321-00-249
3916657, 60012-4401,
Volvo, GMC, Volvo White, with Series,
1981-92 Block valve with female O-Ring fittings 60012-5011, V1111909, RD-5-6868-0P 71R8301
Main and Sleeper Units
V1118406
WC, WI 1988-96 Main unit (Bergstrom) 3916657 RD-5-6868-0P 71R8301
BSM308011, 3916657,
WCA, WH, WG, WIA, WX 1988-01 Block valve with female O-Ring fittings 540031, 040138-123, RD-5-6868-0P 71R8301
EA1065
BSM308011, 3916657,
WCS, WCL 1986-90 Block valve with female O-Ring fittings 540031, 040138-123, RD-5-6868-0P 71R8301
EA1065
WG, WX 1999-00 Sleeper Unit (Bergstrom) 3916657 RD-5-6868-0P 71R8301
WIA, WX Dual 1988-01 Main unit, block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
BOA80-321-00-169,
WIA 1993-99 Sleeper Unit (Behr) RD-5-7567-0P 71R8370
3949281
WHL, WHS, WIL, WX 1981-87 Main unit, block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
WHE, WHL, WIM 1987-93 Main unit, block valve with female O-Ring fittings 3916657 RD-5-6868-0P 71R8301
WXLL Dual 1988-00 Main unit (Bergstrom) 3916657 RD-5-6868-0P 71R8301
WXR 1994-99 Main unit (Bergstrom) 3916657 RD-5-6868-0P 71R8301
All Series with OE# 60012-5002 Main unit with external equalizer, 1 1⁄2 Ton, male O-Ring 60012-5002 RD-5-3824-1P 71R8100
All Series Conventionals with Bunk
1990-93 External equalizer, 1 1⁄2 Ton, male O-Ring 60058-5002 RD-5-5862-0P 71R8080
Sleeper unit
RBII, RCII, RXII 1975-86 Main unit, all models with flare fitting 176190, 60012-0011 RD-4126-1P 71R8050
All Series with OE # A22-14420-1 Main unit with internal equalizer, 1 1⁄2 Ton, male O-Ring A22-14420-1 RD-5-10445-0P 71R8220
All Series with Bunk Sleeper unit 1990-94 Internal equalizer valve with male O-Ring fittings 60058-5002, 3916657 RD-5-11033-0P 71R8060
N, RBII, WAH, WCA 1990-96 Internal equalizer valve with male O-Ring fittings 60058-5002, 3916657 RD-5-11033-0P 71R8060
PAGE 176
VOLVO/WHITE GMC
WCL, WCS 1990-96 Internal equalizer valve with male O-Ring fittings 60058-3201, 3916657 RD-5-11033-0P 71R8060
WG, WIA, VN 1990-96 Internal equalizer valve with male O-Ring fittings 60058-3201, 3916657 RD-5-11033-0P 71R8060
FILTER
VN Series, conventional and C.O.E.
2003-10 Pleated air filter, 12 1⁄2” wide x 9 1⁄4” high x 1 1⁄8” thick 20435801 RD-5-12354-0P 78R5242
model series with underhood filter
HEATER CORE
WHL 1981-84 Main unit (Red Dot) RD-1-0371-1 RD-1-0371-1P 76R2210
PRESSURE SWITCH
All Conventional & C.O.E. Series with OE Trinary switch, with female 7⁄16”-20, 4 terminal, normally
61522-0006, 176225 RD-5-4625-0P 71R7650
# 61522-0006, 176225 closed
All Series with Red Dot A/C switch, OE # Trinary switch, with female 7⁄16”-20, 4 terminal, normally
RD-5-4625-0, BA1240 RD-5-4625-0P 71R7650
RD-5-4625-0 closed
All Series with Red Dot Trinary switch,
Trinary switch, with female 7⁄16”-20, 4 terminal, normally open RD-5-4583-0P RD-5-4583-0P 71R7550
OE #RD-5-4583-0P
All Series with Red Dot Trinary switch,
Trinary switch, with male 3⁄8”-24, normally closed fan switch RD-5-4620-0P RD-5-4620-0P 71R7600
OE #RD-5-4620-0P
Binary switch for Kysor A/C applications Binary 3⁄8”-24 UNF male with bulkhead seal RD 5 4646 0 RD-5-4646-0P 71R7000
Binary switch for Red Dot A/C
1983-94 Binary 7⁄16”-20 UNF female, Schrader type valve RD 5 4640 0, 61522-006 RD-5-4640-0P 71R7050
applications
Control module (APAds), used with
APAds electronic control module 8042105 RD-5-10352-0P 71R6565
Detroit Series 60 engines, OE# 8042105P
Fan control switch (APAds), used with
Cummins, Caterpillar engines, OE# APAds fan control switch 8042103 RD-5-10449-0P 71R6560
8042103P
3918220, 404140, 404141,
FE Series for Kysor Class Six A/C 1983-93 High pressure switch, normally closed 210 psi, opens 340 psi RD-5-5873-0P 71R6070
BB1075
FE Series with Kysor Class Six 1983-93 Low pressure switch, normally closed 42 psi, opens 32 psi 176227 RD-5-4833-0P 71R6030
Pressure switch fan trigger (APAds), all
APAds fan trigger control switch, M10 female fitting 8040242 RD-5-10789-0P 71R6450
series with OE# 8040242
Pressure switch, high (APAds), all series
APAds high pressure switch, M10 female fitting 8040135 RD-5-9990-0P 71R6400
with OE# 8040135
Pressure switch, low (APAds), all series
APAds low pressure switch, M10 female fitting 8040189 RD-5-10783-0P 71R6424
with OE# 8040189
Pressure switch, low (APAds), all series
APAds low pressure switch, 1⁄4” NPTF fitting 8040223, 3948742 RD-5-10853-0P 71R6442
with OE# 8040223, 3948742
Trinary switch harness assembly, OE
with Red Dot A/C, Trinary Switch with harness 61522-0007 RD-5-12150-0P 71R4501
#61522-0007
Trinary switch harness assembly, OE RDH RD5 4585 0, 61522-
Trinary switch, with male 3⁄8”-24, 4 terminal, normally closed RD-5-4585-0P 71R7500
#RDH RD5 4585 0, 61522-3801 3801
RECEIVER DRIER
All Volvo Series Models with OE#
#6 male O-Ring, 2 3⁄4” X 10 5⁄8” 3441124, 61510-5006 RD-5-3593-0P 74R1756
3441124, 61510-5006
with Quick disconnect & HPRV 61506-3601 RD-5-9791-0P 74R3314
61506-3601
All Volvo Series Models with OE# 61510- 61510-0001, 7077922,
Male & Male O-Ring with Fuse Plug, low pressure switch RD-4160-1P 74R2106
0001, 7077922, BSM319000 BSM319000
#6 male O-Ring, 2 3⁄4” X 10 5⁄8”, without trinary switch 61510-5005 RD-5-6567-2P 74R3466
61510-5005
1992-98 O-Ring Type with moisture indicator and HPRV 8025531, 61510-0008 RD-5-11533-0P 74R3107
8025531, 61510-0008
ACL, WCA, WG, WH, WIA, WX, WX DUAL,
1994-99 O-Ring Type with moisture indicator 3934718 / 20407203 RD-5-11533-0P 74R3107
WXR
ACL, WG, WX, WXLL, WXR 1999-01 O-Ring Type with moisture indicator 3934718 / 20407203 RD-5-11533-0P 74R3107
85107848 /61510-0008
ACL, WG, WH, WX, WIA, WCA, WX DUAL 1988-99 O-Ring Type with Switch Port and HPRV RD-5-11533-0P 74R3107
/20407203
PAGE 177
VOLVO/WHITE GMC
RECEIVER DRIER
ACL, WG, WH, WX, WIA, WCA, WXR,
1994-99 O-Ring Type with moisture indicator and HPRV 3934718 / 20407203 RD-5-11533-0P 74R3107
WX DUAL
ACL, WG, WH, WX, WIA, WCA, WXR,
1994-98 O-Ring Type with moisture indicator 3934718 / 20407203 RD-5-11533-0P 74R3107
WX DUAL
FE Series 1983-83 with Kysor Class Six A/C (EXC. 86-88 Turbo) 402562 RD-5-4950-0P 74R0906
N, RBII, WAH, WCA, WG, WIA
1976-83 #6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) 176246, JA1110 RD-5-4632-0P 74R1956
Conventional
RBII 1983-93 O-Ring Type with moisture indicator 3934718 / 20407203 RD-5-11533-0P 74R3107
RB, RBII, RC, RCII, RX, RXII 1984-92 O-Ring Type with Gage port & HPRV 61510-0006 RD-5-11533-0P 74R3107
RBII, RCII, RXII 1976-83 O-Ring Type with Female Side mount switch port 61510-0001,3,5007 RD-5-3593-0P 74R2256
VHD Series 1998-10 O-Ring Type with moisture indicator 20447319, 8086753 RD-5-11533-0P 74R3107
VHD Series 1998-10 O-Ring Type with 90° inlet and outlet 20447319, 8086753 RD-5-11531-0P 74R1427
VN 420, 610, 770 1997-02 O-Ring Type with 90° inlet and outlet 20447319, 8086753 RD-5-11531-0P 74R1427
VN 420, 610, 770 1998-10 O-Ring Type with 90° inlet and outlet 088485-01, 8086753 RD-5-11533-0P 74R3107
VN 420, 610, 770 1998-10 O-Ring Type with0 90° inlet and outlet 8086753 RD-5-10743-0P 74R1426
VN 420, 610, 770 1996-98 O-Ring Type with 90° inlet and outlet 8078261 RD-5-10742-0P 74R1406
O-Ring type with female switch port, moisture indicator and
VN 420, 610, 770 1996-00 20407203 RD-5-8240-0P 74R3346
straight fittings
O-Ring type with female switch port, moisture indicator and 20407205, 088492-01,
VN 420, 610, 770 1996-00 RD-5-10348-0P 74R3064
90° fittings 8078261
VN Models with OE# 088295-00,
1992-95 O-Ring Type with moisture indicator and HPRV 088295-00, 8025531 RD-5-11533-0P 74R3107
8025531
Volvo FE Series withTURBO 1986-93 with Kysor Class Six A/C 61510-0001,3,5007, 176232 RD-5-3593-0P 74R1756
Volvo White YF Conventional 1987-93 O-Ring Type with Kysor A/C 61510-0007 RD-5-5583-0P 74R2606
20407205, 3934718,
WG, WCA, WIA 1987-03 O-Ring Type with moisture indicator 8025531, 088491-01, RD-5-11533-0P 74R3107
61510-0008
WH, WX, WX DUAL, WXLL 1998-06 O-Ring Type with Switch Port and HPRV 8025531 RD-5-11533-0P 74R3107
White GMC Autocar ACL, ACM Series 1988-93 O-Ring Type with Female top mount switch port 61510-5005 RD-5-3593-1P 74R1706
RELAY
FE Series with Kysor Class Six 1988-93 Bosch type (30 amp), SPST, 5 terminals 176569, 3918212 RD-5-4408-0P 71R1702
BOA 80-945-00-079,
VHD (2000-01), VN Series 420, 610, 770 1996-01 Main unit, Volvo White, 5 terminal, SPST, 40⁄30 amps RD-5-9915-0P 71R1722
3949297
RESISTOR
1988-02 Blower Resistor (3 Speed) 3134241 RD-5-10341-0P 71R1457
WXLL, WXR
1984-00 Resistor (Kit) 1115284 RD-5-10341-0P 71R1457
WXLL, WXR
ACL, WG, WX, WXLL, WXR 1999-01 Blower Resistor (3 Speed) 3134241 RD-5-10341-0P 71R1457
Autocar, WCL, WCS, WHL, WHS, WIL, WX 1984-00 Resistor 1115284 RD-5-10341-0P 71R1457
1091071, BOA 80-926-
Autocar, WHE, WHL, WIA, WIM 1987-98 Resistor Sleeper Unit RD-5-6450-0P 71R1455
00-079
BOA 80-926-00-139,
VHD (2000-02), VN Series 420, 610, 770 1996-06 Main unit RD-5-10341-0P 71R1457
3946681
BOA 80-926-00-179,
VN Series 420, 610, 770 1997-04 Sleeper Unit (Behr) RD-5-10341-0P 71R1457
3949112
VN Series 420, 610, 770 1996-04 Sleeper Unit (Bergstrom) 3134241 RD-5-10341-0P 71R1457
WC, WI 1988-96 Blower Resistor (3 Speed) 3134241 RD-5-10341-0P 71R1457
WHE, WHL, WIM 1987-92 Resistor Main unit 1115284 RD-5-10341-0P 71R1457
WHL 1982-84 Blower speed control resistor, 3 terminal, 3 speed 3949290, V1697520 RD-5-3647-0P 71R1450
PAGE 178
VOLVO/WHITE GMC
RESISTOR
THERMOSTATIC SWITCH
All Conventional Volvo/White/GM Series
1973-93 Rotary (variable) thermostat, 36” capillary tube RD 5 4125 36, 9533N178 RD-4125-36P 71R2250
Models with OE# RD 5 4125 36
All Series with Eaton cable controlled
thermostat, OE# 60054-0001, 60054- 1983-93 Cable controlled with 18” capillary tube, 26 - 66°F 60054-0001, 60054-5002 RD-5-4911-0P 71R2600
5002
Preset (fixed) setting thermostat, 21” capillary tube, 31 -
ACL 1988-93 1118408 RD-5-10335-0P 71R3220
40°F
3915962, 525335,
ACL 1994-02 Preset (fixed) setting thermostat, 32” capillary tube RD-5-11031-0P 71R2200
BSM323020
Autocar, WHL, WHS, WIL, WX 1983-87 Cable controlled with 18” capillary tube, 26 - 66°F 60054-0001 RD-5-4911-0P 71R2600
FE Series 1983-91 Preset (fixed) setting thermostat, 24” capillary tube 3949291, 404145 RD-5-4531-24P 71R3200
N Series with Red Dot rotary thermostat,
1983-94 Rotary (variable) thermostat, 36” capillary tube RD 5 4125 36 RD-4125-36P 71R2250
OE# RD 5 4125 36
1117232, 02-7010174,
RBII, RCII, RXII 1976-86 Cable controlled thermostat, 30” capillary tube RD-4226-0P 71R2700
BSM621003
Preset (fixed) setting thermostat, 18” capillary tube, 28 - BOA80-946-00-129,
VHD Series 2000-02 RD-5-10736-0P 71R3155
35°F 3093431
Preset (fixed) setting thermostat, 18” capillary tube, 28 - BOA80-946-00-129,
VN Series 420, 610, 770 1996-02 RD-5-10736-0P 71R3155
35°F 3093431
3915962, 525335,
WCA, WG, WH, WIA, WX, WXR 1994-04 Preset (fixed) setting thermostat, 32” capillary tube RD-5-11031-0P 71R2200
BSM323020
WCA, WG, WH, WIA, WX 1988-00 1118408 RD-5-10335-0P 71R3220
40°F
WCL, WCS 1986-90 Cable controlled with 18” capillary tube, 26 - 66°F 60054-0001 RD-5-4911-0P 71R2600
WG Series 1983-93 Preset (fixed) setting thermostat, 25” capillary tube 404145 RD-5-4531-24P 71R3200
WG, AC (24V) 1994-96 1118408, 1110162 RD-5-10335-0P 71R3220
40°F
WG, WX Series with Volvo OE # Preset (fixed) thermostat with 24” capillary tube, flange
1993-97 V1118408, 1110162 RD-4427-24P 71R3100
V1118408, 1110162 mount
WHE, WHL, WIM 1986-93 Cable controlled with 18” capillary tube, 26 - 66°F 60054-0001 RD-5-4911-0P 71R2600
WI, WC 1988-96 Cable controlled thermostat, 32” capillary tube, 25 - 75°F 1118416 RD-5-10156-0P 71R2605
WX, WXLL DUAL 1988-99 Cable controlled thermostat, 32” capillary tube, 25 - 75°F 1118416 RD-5-10156-0P 71R2605
WATER VALVE
ACL, WCA, WG, WH, WIA 1994-99 Cable Operated (Bergstrom) Heater Only, pull to close 1118413 RD-5-10345-0P 72R6530
ACL, WCA, WG, WH, WIA, WX 1998-94 Cable Operated (Bergstrom), pull to close 1118413 RD-5-10345-0P 72R6530
ACL, WCA, WG, WH, WIA, WX, WXR 1998-94 Cable Operated (Bergstrom), pull to open 1118414 RD-5-11319-0P 72R6533
RBII, WAH, WCA, WG, WIA Conventional
1972-97 Cable Operated (Kysor), straight (pull to open), 5⁄8” to 5⁄8” hose 173096 RD-5-8935-0P 72R6510
with Kysor OE # 173096
1972-97 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose BOA 80-136-00-039 RD-5-4257-0P 72R5050
with OE # BOA 80-136-00-039
1972-97 Cable operated, (3⁄4” to 3⁄4”) V1117964, RDH RD5 5191 0 RD-5-5191-0P 72R5070
with Volvo OE # V1117964
RC, RCII, WH, WX C.O.E. with Kysor OE
1972-98 Cable Operated (Kysor), straight (pull to open), 5⁄8” to 5⁄8” hose 173096 RD-5-8935-0P 72R6510
# 173096
RC, RCII, WH, WX C.O.E. with OE # BOA
1972-98 Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose BOA 80-136-00-039 RD-5-4257-0P 72R5050
80-136-00-039
RC, RCII, WH, WX C.O.E. with Volvo OE
1972-98 Cable operated, (3⁄4” to 3⁄4”) V1117964, RDH RD5 5191 0 RD-5-5191-0P 72R5070
# V1117964
VN Series 420, 610 1996-99 Sleeper Unit Electronic Actuator for (Bergstrom) 3947439, BSM868580
WCA, WG, WIA 1994-98 Cable Operated (Bergstrom), pull to close 1118413 RD-5-10345-0P 72R6530
WG, WXLL DUAL 1998-02 Cable Operated (Bergstrom), pull to open BSM324146 RD-5-11319-0P 72R6533
WH, WX 1998-94 Cable Operated (Bergstrom), pull to open 1118414 RD-5-11319-0P 72R6533
WH, WX, WXR 1999-00 Cable Operated (Bergstrom), pull to open 1118414 RD-5-11319-0P 72R6533
PAGE 179
VOLVO/WHITE GMC
WATER VALVE
WI, WC 1988-96 Cable Operated (Bergstrom), pull to open 1118414 RD-5-11319-0P 72R6533
WXLL, WX DUAL 1988-01 Cable Operated (Bergstrom), pull to open 1118414 RD-5-11319-0P 72R6533
WESTERN STAR
BLOWER, FAN BLADE
All series with OE # 02-7075303, RD-
Bergstrom, Kysor and Red Dot A/C, 6” diameter, CW 02-7075303, RD-3133-9P RD-3133-9P 73R8050
3133-9P
BLOWER MOTOR
All model series with OE# 02-7008314,
1971-84 All with 3” diameter blower motor, 1 speed, CW, 5” length 02-7008314, 1707686 RD-5-9100-0P 73R0462
1707686
All model series with OE# 849601, 849601, 851402, 865236,
OE style blower motor (only), 3 3⁄4” length, non-vented RD-5-10391-0P 73R0092
851402, 865236 3093404
All model series with Red Dot A/C, OE# RD-5-10746-0, RD-5-
1985-95 Main unit, all with single shaft, 1 speed, CCW, 4 3⁄4” length RD-5-10746-0P 73R1012
RD-5-10746-0, RD-5-3753-1 3753-1
All model series with Red Dot OE# RD-3106-13, 02-7086612,
1971-84 Main unit with 2 speed, single shaft, CCW, 4 1⁄4” length RD-3106-13P 73R0602
RD3106-13 60009-5005
All sleeper model series with Red Dot
Blower motor, single speed, CCW, NV, Sleeper Unit RD-3106-18, 03-7075298 RD-3106-18P 73R0202
A/C, OE# RD3106-18
Constellation 4800, 4900, 5800, 5900 176132, RD-3-4058-0P,
1993-03 Sleeper Unit (Red Dot), motor blower assembly RD-3-4058-0P RD-3-4058-0P
with Red Dot units R-4230, R4240 RD-5-6315-0
Constellation 4800, 4900, 5800, 5900
1993-03 Sleeper unit, single shaft, CCW, 4 13⁄32” length 60009-3405 RD-5-8203-0P 73R0962
with Red Dot units R-4230, R4240
Constellation 4800, 4900, 5900, 6900
1996-01 Main unit (Red Dot) with single shaft, CW, 4 3⁄4” length RD-5-8663-0 RD-5-6526-0P 73R0422
with Red Dot A/C
Constellation 4800, 4900, 5900, 6900
1985-98 Sleeper unit with single shaft, CCW, 4 3⁄4” length 6009-5003 RD-5-8204-0P 73R0432
with Red Dot A/C, Sleeper unit
Constellation 4800, 4900, 5900, 6900
1996-04 Main cab (Red Dot), single shaft, 1 speed, CW, 4 3⁄8” length RD-3-8657-0 RD-3-8657-0P 73R1002
with Red Dot OE# RD-3-8657-0
Constellation with Red Dot OE# RD-3-
8657-0
Constellation, all series with Red Dot Sleeper unit with heater blower motor, 1 speed, CW, 4”
1996-99 RD-5-9102-0 RD-5-5634-0P 73R0922
heater motor, OE# RD-5-5634-0P length
Constellation, sleeper unit with Red Dot
1993-02 Sleeper unit, single shaft, CCW, 4 13⁄32” length 60009-3405 RD-5-8203-0P 73R0962
OE# 60009-3405
3949262, RD-5-6526-0,
Heritage 3800, 4800, 4900, 5900, 6900 1988-01 Main unit, single shaft, 1 speed, CW, 4 3⁄4” length RD-5-6526-0P 73R0422
RD-5-8202-0
Heritage 3800, 4800, 4900, 5900, 6900 1988-99 Main unit with heater blower motor, 1 speed, CW, 4” length RD-5-9102-0 RD-5-5634-0P 73R0922
Heritage 3800, 4800, 4900, 5900, 6900 1985-99 Sleeper Unit (Red Dot) with single shaft, CW, 4 3⁄4” length 60009-5009 RD-5-6526-0P 73R0422
Heritage 3800, 4800, 4900, 5900, 6900 1983-85 Sleeper Unit (Red Dot) with single shaft, CW, 4 3⁄4” length 60009-5009 RD-5-6526-0P 73R0422
Heritage 3800, 4800, 4900, 5900, 6900
1983-01 Sleeper unit, single shaft motor, 1 speed, 5” length 3949263, RD-5-6526-1 RD-5-6526-1P 73R0402
with Red Dot units R-4070, R-4170
Heritage 4800, 4900, 5800, 5900, 6900
1984-99 Main unit (Red Dot) with single shaft, CW, 4 3⁄4” length RD-5-6526-0, 6009-5003 RD-5-6526-0P 73R0422
with Red Dot A/C
Heritage 4800, 4900, 5900, 6900 with
Red Dot A/C
Heritage 4800, 4900, 5900, 6900 with
1994-99 Sleeper unit with single shaft, CCW, 4 3⁄4” length 6009-5003 RD-5-8204-0P 73R0432
Red Dot A/C, Sleeper unit
Heritage with OE# 6009-5003, 2807-
1985-98 Kysor A/C, single shaft motor, 1 speed, 5” length 6009-5003, 2807-517-019 RD-5-6526-1P 73R0402
517-019
Heritage with Red Dot OE# RD-3-8657-0 1996-04 Main cab, single shaft, 1 speed, CW, 4 3⁄8” length RD-3-8657-0 RD-3-8657-0P 73R1002
BLOWER RELAY
All series with 12V relay with 5 BOA80-945-00-079, VF4-
1996-04 Main unit, 5 terminal, SPST, 40/30 amps RD-5-9915-0P 71R1722
terminals, OE# BOA80-945-00-079 15F11-501
All series with 12V bosch style relay with
1988-95 Bosch type (30 amp), 12V, SPST, 5 terminals 0332-204-125, 150 RD-5-4408-0P 71R1702
5 terminals, OE# 0332-204-125, 150
PAGE 180
WESTERN STAR
BLOWER RELAY
All series with 24V bosch style relay with
1988-95 Bosch style relay, 24V, SPDT, 5 terminals, 20⁄10 amp 0332-204-203 RD-5-4417-0P 71R1704
5 terminals, OE# 0332-204-203
BLOWER SWITCH
All series with DP3T rotary switch, long
Auxiliary fan rotary switch, DP3T, 3 speed, long shaft thread BOA80-926-00-109 RD-5-3646-0P 71R1150
shaft, OE# BOA80-926-00-109
All series with DP3T rotary switch, short
1993-00 Rotary switch, DP3T, 3 speed, short shaft thread BOA-80-926-00-059 RD-5-9833-0P 71R1160
shaft, OE# BOA-80-926-00-059
All series with DP3T rotary switch, 3
All Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 176573 RD-5-5194-0P 71R1210
speed, OE# 176573
BLOWER WHEEL
All model series with OE# RD-5-8618-0P Sleeper, single entry wheel (steel), CCW, 5 1⁄4” diameter RD-5-8618-0P, RD-3106-9P RD-5-8618-0P 73R6051
Constellation 3800, 4800, 4900, 5900,
1984-96 Sleeper, single entry wheel (steel), CCW, 5 1⁄4” diameter 60010-5001, RD-5-8618-0P RD-5-8618-0P 73R6051
6900 with sleeper unit, Red Dot A/C
Constellation 4800, 4900, 5800, 5900
1983-00 Main unit, single entry wheel (plastic), CW, 5 1⁄4” diame RD-3106-38P, 02-7073625 RD3106-38P 73R6101
with Main unit, Red Dot A/C
Constellation 4800, 4900, 5800, 5900 Sleeper Unit (R-4230), single entry wheel(plastic), CCW, 5 3⁄4”
1995-01 60012-5001, RD-5-5601-0 RD-5-5601-0P 73R6370
with sleeper unit, Red Dot A/C diameter
Constellation 4800, 4900, 5800, 5900
1985-98 Sleeper unit with 5 1⁄4” single entry wheel, 3 7⁄16” width 60010-4401, RD-5-3800-1P RD-5-3800-1P 73R6251
with sleeper unit, Red Dot A/C
Heritage 3800, 4800, 4900, 5900, 6900
1985-98 Main unit with 5 1⁄4” double entry wheel, 3 1⁄2” width 60010-4401 RD-5-5263-0P 73R6230
with Main unit
Heritage 3800, 4800, 4900, 5900, 6900 Main unit with Red Dot A/C with 5 1⁄4” single entry wheel, 3 3949274, RD-3106-15,
1988-01 RD-5-3800-1P 73R6251
with Red Dot Main unit 7⁄16” width RD-5-3800-1
Heritage 4800, 4900, 5800, 5900, 6900
1983-01 Sleeper unit with 5 1⁄4” single entry wheel, 3 7⁄16” width 60010-4401, RD-5-3800-1P RD-5-3800-1P 73R6251
Heritage 4800, 4900, 5800, 5900, 6900
1982-01 Main unit, single entry wheel (plastic), CW, 5 1⁄4” diame RD-3106-38P, 02-7073625 RD3106-38P 73R6101
Heritage 4800, 4900, 5900, 6900 with Sleeper unit (R-4170), single entry wheel (steel), CCW, 5 1⁄4”
1985-00 60010-5001, RD-5-8618-0P RD-5-8618-0P 73R6051
sleeper unit, Red Dot A/C diameter
CLUTCH ASSEMBLY
Fits CCI/York - R12/134A compressors,
2 groove, 6” diameter pulley, 1⁄2” width, 1 5⁄8” gauge line, 024 25238, 30932420,
OE# 024 25238, 30932420, 520566, RD-5-9456-0P 75R1302
metripak plug 520566, 522582
522582
Fits CCI/York - R12/134A compressors, 1 groove, 6 3⁄4” diameter pulley, 1⁄2” width, 1 3⁄4” gauge line, 02-7010496, L50-2731,
RD-5-4975-0P 75R1652
OE# 02-7010496, 502731, L50-2731 bullet plug 502731
FitsCCI/York - R12/134A compressors, 2 groove, 7” diameter pulley, 12V, 1⁄2” width, 2” gauge line,
02-7074272, 332334, MA 7A RD-5-4994-0P 75R4502
OE# 02-7074272, 332334, MA 7A bullet plug
Fits CCI/York - R12/134A compressors,
2 groove, 1⁄2” width, 6 3⁄4” diameter pulley, bullet plug 502742, L50-2742, 176330 RD-5-4987-0P 75R3452
OE# 502742, L50-2742, 176330
Fits Sanden 7H15HD compressors, clutch
Poly 8 groove, 4.9” 125mm dia groove 6593-6010, 6522-6010 RD-5-10361-0P 75R1432
# 6593-6010, 6522-6010
Fits Sanden 7H15HD R134a compressor
#4626, 4647, 4694, 4699 clutch # 6504- 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), Ford OE plug 6504-6310, 6511-6210 RD-5-10379-0P 75R1542
6310, 6511-6210
Fits Sanden SD5 (510HD) R12/R134a
compressor #9548, 9669, clutch # 2 groove, 1⁄2” width, 5 1⁄4” diameter (132mm), 1 wire plug 509285, 6575-6310 RD-5-5486-0P 75R0202
509285, 6575-6310
Fits Sanden SD5 (5H14) R12/R134a
1 groove, 6 1⁄4” 158mm diameter pulley, variable width, bullet
compressor #9116, 9680, 9696, clutch # 6521-6010, V1110151 RD-5-5489-0P 75R1402
plug
6521-6010, V1110151
1 groove, 1⁄2” width, 4 3⁄4” diameter (122mm) overhang, bullet
compressors, clutch # 8545-6310, 8545-6310, 61190-4409 RD-5-10758-0P 75R1872
plug
61190-4409
511575, 511869 RD-5-6646-0P 75R0182
compressors, clutch # 511575, 511869 plug
PAGE 181
WESTERN STAR
CLUTCH ASSEMBLY
511051, 624-19749 RD-5-10723-0P 75R0262
TM16 compressors, clutch # 511051 plug
511587, 511870, 524-19719 RD-5-9799-0P 75R1422
TM16 compressors, clutch # 511587 plug
without clutch, OE # ER210L-25149
R12/134A without clutch, OE # Tube O-Ring type head without clutch, (universal - new) ET210L-25150 RD-5-8638-1P 75R7290
ET210L-25150
CCI/York/Tecumseh - Rotolock Head,
compressors, R12/134A without clutch
R12/134A without clutch, OE # ER210L- ET210L-25073C RD-5-11217-0P 75R7312
replacement - new)
25073C
CCI/York - Tube O-Ring compressors, ET, (OE new replacement) Tube “O” head, LH Suction, 2 groove,
ET210L-25237C RD-5-11218-0P 75R7322
T210L-series, OE # ET210L-25237C 1⁄2” width, 6” diameterclutch
CCI/York - Tube O-Ring compressors, ET, Tube “O” head, LH suction, 8 groove, 6 1⁄8” diameter, 2 wire
ET210L-25246C RD-5-11219-0P 75R7332
T210L-series, OE # ET210L-25246C clutch
COMPRESSOR - SANDEN
Sanden 7H15, #4626 R134a compressor Main unit, 7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) 61104-3420, 20370292,
1993-03 RD-5-7522-0P 75R8432
with PAG oil - fits Constellation models diameter 4626
61104-3420, 20370292,
with PAG oil - fits Detroit S-60, Cummins 7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) diameter RD-5-7522-0P 75R8432
4626
ISC engines
Sanden 7H15, #4626 R134a compressor Main unit, 7H15, JD head, direct mt, 2 groove, 5 1⁄4”(132mm) 61104-3420, 20370292,
1991-04 RD-5-7522-0P 75R8432
with PAG oil - fits Heritage models diameter 4626
with PAG oil, Cat C3126, Cummins M11 7H15, JD head, ear mount, 2 groove, 4.9” (125mm) diameter 4627, 8164872 RD-5-7120-0P 75R8422
engines
Sanden 7H15, #4645, 4665 R134a
4645, 4665, 61104-3423,
compressor with PAG oil, OE# 61104- 7H15, JDA head, ear mount, poly 7, 4.7” (119mm) diameter RD-5-11313-0P 75R81452
85100887
3423
Sanden 7H15, #4666, 4897 R134a
compressor with PAG oil - fits MBE4000 7H15, KCA head, direct mt, poly 8, 4.7” (119mm) diameter 61104-3430, 4666, 4897 RD-5-10285-0P 75R84472
engine
Sanden 7H15, #4667, 4897 R134a
7H15, KCA head, direct mt, poly 8, 4.7” (119mm) diameter 61104-3430, 4667, 4897 RD-5-11326-0P 75R81502
Sanden 7H15, #4780 R134a compressor 7H15, JD Head, direct mount, 2A groove, , 5 1⁄4” diameter
20370292, 4780 RD-5-11337-0P 75R81582
with PAG oil (132mm)
7H15, JD head, ear mount, 2 groove, 4.9” (125mm) diameter 61104-3411, 3916160 RD-5-7120-0P 75R8422
with PAG oil
61104-4001, 3918279,
compressor with charge ports, mineral SD510HD, B head, ear mount, 2 gr, 5 1⁄4”(132mm) diameter RD-5-6164-0P 75R8262
9103, RD561640
oil.
Sanden 510-HD, #9119, R12 with Mineral SD510, C head, ear mount, variable groove, 6 1⁄4” diameter
61104-0013 RD-5-5200-0P 75R8222
oil, fits R12 series with OE # 61104-0013 (158mm)
Sanden 510-HD, #9120 R12 with Mineral SD510HD, FG head, ear mount, 2A groove, 5 1⁄4” (132mm)
61104-3412, 3918270, 9120 RD-5-5443-0P 75R8212
Oil and Charging Ports diameter
Sanden 508HD, #9285, R12 with Mineral Main unit, SD508HD, FG head, 2A groove, 5 1⁄4”(132mm)
1991-95 9285, RD-5-5575-0 RD-5-5575-0P 75R8292
Oil , fits Heritage models diameter
Sanden 508, #9514, R12 with Mineral Oil 61104-3412, 61104-3418,
1991-95 Main unit, SD508, FG head, 1A groove, 4 3⁄4”(122mm) diameter RD-5-5684-0P 75R8342
, fits Heritage models 9514, RD-5-5684-0
PAGE 182
WESTERN STAR
COMPRESSOR - SANDEN
SD510HD, FG head, variable groove, 6 1⁄4”(158mm) diameter 9675 RD-5-5627-0P 75R8232
Compressor with mineral oil/ with 488-25011 RD-5-5876-0P 75R8512
diameter with ports
charge ports
ICE/Seltec TM15 # 488-45011 - R134a
TM15CH, D head, ear mount, 2 groove, 5 1⁄4” (135mm) 488-45011 RD-5-7145-0P 75R8612
ICE/Seltec TM15 # 488-45063 - R134a
TM15CH, D head, ear mount, 1 groove, overhang, 5” (125mm) 488-45063 RD-5-8944-0P 75R8532
488-45065 RD-5-7164-0P 75R8632
ICE/Seltec TM15 # 488-45077 - R134a
Compressor with PAG OIL, no charge 488-45077 RD-5-9609-1P 75R8552
ports
ports
CONDENSER
36” x 17 3⁄4”
Radiator Mount, Tube-Fin Type overall 33”, fin width 29” x
18 1⁄2”
All model series with OE # 61203-3209 1986-92 Serpentine Type overall 29 3⁄4”, fin width 27 1⁄8” x 15 3⁄4” 61203-3209 RD-4-3916-0P 77R0950
All model series with R-12 originally
1992-95 Radiator Mount 61203-3211 RD-4-5812-0P 77R1175
installed, OE # 61203-3211
EVAPORATOR
Constellation with Red Dot unit R-4230,
1993-09 Sleeper unit (Red Dot R-4230), 8 1⁄8” x 7 7⁄8” x 3 13⁄32” 60004-3402 RD-2-1898-0P 76R6130
OE# 60004-3402
Constellation with Red Dot unit R-5260,
1993-04 Main unit (Red Dot R-5260), 8” high x 5 5⁄8” long x 2 1⁄2” wide 60004-3401 RD-2-2423-0P 76R7530
OE# 60004-3401
Constellation with Red Dot unit R-5275 2004-08 Main unit (Red Dot R-5275) RD-2-4032-0P 76R7535
Heritage 3800, 4800, 4900, 5800, 5900, 176167, 6004-4403, RD-2-
1983-08 Sleeper unit (Red Dot R-4070,4170), 8” x 8” x 3 13⁄32” RD-2-1402-0P 76R6150
6900 1402-0
Heritage with Red Dot unit R-5275 2004-08 Main unit (Red Dot R-5275) RD-2-4032-0P 76R7535
Heritage 3800, 4800, 4900, 5900, 6900 1988-01 Main unit 176169, 6004-4401 RD-2-1272-0P 76R6310
Constellation 3800, 4800, 4900, 5800, Sleeper unit (R-4230), Hi - capacity (2 ton), Red Dot, female 3916657, 60012-4401,
1988-08 RD-5-6868-0P 71R8301
5900, 6900 with Red Dot block valve O-Ring 60012-5001
Constellation 4800, 4900, 5800, 5900,
1993-07 Main unit, Hi - capacity (2 ton), Red Dot, female O-Ring RD-5-7015-0 RD-5-7015-0P 71R8321
6900 with Red Dot block valve
Heritage 3800 (1988-98), 4800, 4900,
Sleeper unit (R-4070,4170), Hi - capacity (2 ton), Red Dot, 3916657, 60012-4401,
5800, 5900, 6900 with Red Dot block 1988-98 RD-5-6868-0P 71R8301
female O-Ring 60012-5001
valve
All model series with OE # 02-7010501, 02-7010501, 02-7086617,
Main unit, all models with male flare fitting, 18” capillary RD-4126-1P 71R8050
02-7086617, 2684701-C1 2684701-C1
All model series with OE # 02-7086505,
Main unit, all models with male O-Ring fitting, 13” capillary 02-7086505, RD-5-3824-1 RD-5-3824-1P 71R8100
RD-5-3824-1
All model series with OE # A22-14420-1 Main unit, all models with male O-Ring fitting, 12” capillary A22-14420-1 RD-5-10445-0P 71R8220
FILTER
All model series using Red Dot A/C
Framed mesh filter, 11 5⁄8” wide x 5” high x 7⁄8” thick 60015-3418, RD-3-8777-0P RD-3-8777-0P 78R5241
model R-5265, OE# 60015-3418
4900 Series, Constellation and Heritage
model series with inside cab under 1995-05 Unframed filter, 13 5⁄8” wide x 10” high x 3⁄4” thick WS101P RD-5-10775-0P 78R5308
dash filter
PAGE 183
WESTERN STAR
FILTER
HEATER CORE
Constellation 4800, 4900, 5800, 5900
1993-03 Main unit, Red Dot Heater A/C (R-2560) 60004-3403 RD-1-1201-0P 76R2420
with Red Dot unit (R-2560)
Constellation with Red Dot heater core,
2004-07 Main unit RD-1-1965-0 RD-1-1965-0P 76R4023
OE# RD-1-1965-0
Heritage 3800, 4800, 4900, 5800, 5900, RD-1-0460-1, 176280,
1988-01 Main unit, Red Dot Heater A/C RD-1-0460-1P 76R2500
6900 60003-4405
Heritage 3800, 4800, 4900, 5800, 5900, RD-1-0563-0, 3949252,
1983-99 Sleeper unit, Red Dot Heater A/C (R-4070,4170) RD-1-0563-0P 76R2400
6900 with Red Dot unit (R-4070, R-4170) 60003-4404
Heritage 4800, 4900, 5800, 5900 with
1985-03 Sleeper unit, Red Dot Heater A/C (R-2560) RD-1-0665-0 RD-1-0665-0P 76R2450
Red Dot unit (R-4120, R-4122, R-4160)
Heritage with Red Dot heater core, OE#
2004-07 Main unit RD-1-1965-0 RD-1-1965-0P 76R4023
RD-1-1965-0
3800, 4800, 4900, 5800, 5900, 6900 1983-99 Main unit, Red Dot Heater A/C (R-5060) 60003-4405 RD-1-0460-1P 76R2500
3800, 4800, 4900, 5800, 5900, 6900 RD-1-0563-0, 3949252,
1996-99 Sleeper unit, Red Dot Heater A/C RD-1-0563-0P 76R2400
with Red Dot unit 60003-4404
PRESSURE SWITCH
All model series with Red Dot Trinary High Pressure Trinary switch, with male 3⁄8”-24, 4 terminal,
1987-09 RD-5-4585-0, 02-2750417 RD-5-4585-0P 71R7500
Switch OE # RD-5-4585-0, 02-2750417 normally open
Constellation 4800, 4900, 5800, 5900 High Pressure Trinary switch (Main unit), with female 7⁄16”-20,
1987-09 176225, RD-5-4625-0 RD-5-4625-0P 71R7650
(Main unit) 4 terminal, normally closed
Constellation 4800, 4900, 5800, 5900 High Pressure Trinary switch (Sleeper Unit R-4230), with
1987-09 176225, RD-5-4625-0 RD-5-4625-0P 71R7650
(Sleeper Unit R-4230) female 7⁄16”-20, 4 terminal, normally closed
Heritage 3800, 4800, 4900, 5900, 6900 High Pressure Trinary switch (Sleeper Unit), with female 7⁄16”-
1987-09 176225, RD-5-4625-0 RD-5-4625-0P 71R7650
Sleeper Unit, Red Dot R-4170 20, 4 terminal, normally closed
High Pressure Trinary switch, with female 7⁄16”-20, 4 terminal,
3800, 4800, 4900, 5900, 6900 1987-09 176225, RD-5-4625-0 RD-5-4625-0P 71R7650
normally closed
3800, 4800, 4900, 5900, 6900 (Sleeper High Pressure Trinary switch (Sleeper Unit), with female 7⁄16”-
1987-09 176225, RD-5-4625-0 RD-5-4625-0P 71R7650
Unit) 20, 4 terminal, normally closed
RECEIVER DRIER
#6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) RD-5-4632-0 RD-5-4632-0P 74R1956
RD-5-4632-0
#6 male O-Ring, 2 3⁄4” X 10 5⁄8”, without trinary switch RD-5-6567-2 RD-5-6567-2P 74R3466
RD-5-6567-2
All model series with Western Star OE #
#6 male O-Ring, 2 3⁄4” X 10”, without binary switch 02-0707988 RD-5-5572-0P 74R1856
02-0707988
#6 male O-Ring, 2 3⁄4” X 10”, binary switch 02-7077922 RD-5-9455-0P 74R1836
02-7077922
#6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (top) 02-7077984 RD-5-4632-1P 74R1906
02-7077984
#6 male O-Ring, 2 3⁄4” X 9 5⁄8”, trinary switch (side) 04-9041020 RD-5-4632-0P 74R1956
04-9041020
61506-3406-000, 088343-
Constellation 4800, 4900, 5800, 5900 1993-06 Main unit, 3” X 10”, #6 male O-Ring, moisture indicator RD-5-7517-1P 74R3376
000
RD-5-7517-0, 176243,
Heritage 4800, 4900, 5800, 5900, 6900 1983-06 Main unit, 3” X 10”, #6 male O-Ring, moisture indicator RD-5-7517-0P 74R3136
61506-3402
3800, 4800, 4900, 5900, 6900 1988-93 O-Ring Type with Fuse Plug & Charge Port 176243, 61506-3402-000 RD-5-9515-0P 74R2676
Heritage 3800, 4800, 4900, 5900, 6900 1988-93 O-Ring Type with Fuse Plug & Charge Port 176243, 61506-3402-000 RD-5-9515-0P 74R2676
PAGE 184
WESTERN STAR
THERMOSTATIC SWITCH
All model series with OE# 02-7010174 1983-97 Cable controlled thermostat, 30” capillary tube 02-7010174, RD-4226-0 RD-4226-0P 71R2700
All model series with OE# 60054-4401 1985-09 Fixed setting thermostat, 25” capillary tube 60054-4401-000, 3949291 RD-5-4531-24P 71R3200
All model series with OE# A22-
1972-78 Rotary thermostat, 36” capillary tube A22-15817A-001 RD-4125-36P 71R2250
15817A-001
All model series with Red Dot OE#
1987-96 Rotary thermostat, 36” capillary tube RD-4125-36 RD-4125-36P 71R2250
RD-4125-36
Constellation 3800, 4800, 4900, 5900,
1988-07 Fixed setting thermostat, 25” capillary tube 60054-4401-000, 3949291 RD-5-4531-24P 71R3200
6900 Main unit
Constellation 3800, 4800, 4900, 5900, All models with bunk style thermostat, bimetal, 36” capillary
1983-99 02-7078047, RD 4430 0 RD-4430-0P 71R2500
6900 bunk thermostat switch tube
Heritage 3800, 4800, 4900, 5900, 6900 1983-96 Main unit, Fixed setting thermostat, 25” capillary tube 60054-4401-000, 3949291 RD-5-4531-24P 71R3200
All sleeper models with bunk style thermostat, bimetal, 36” G2028505, RD-4430-0,
Heritage 4800, 4900, 5800, 5900 1983-00 RD-4430-0P 71R2500
capillary tube 02-7078047
All sleeper models with bunk style thermostat, bimetal, 36” G2028505, RD-4430-0,
Heritage 4900, 5900, 6900 1983-00 RD-4430-0P 71R2500
All models with rotary style thermostat, bimetal, 36” G2028505, RD-4430-0,
3800, 4800, 4900, 5900, 6900 1983-00 RD-4430-0P 71R2500
Heritage 3800, 4800, 4900, 5900, 6900 All sleeper models with bunk style thermostat, bimetal, 36” G2028505, RD-4430-0,
1983-00 RD-4430-0P 71R2500
Sleeper unit capillary tube 02-7078047
Heritage 3800, 4800, 4900, 5900, 6900 Main unit with bunk style thermostat, bimetal, 36” capillary G2028505, RD-4430-0,
1983-00 RD-4430-0P 71R2500
Main unit tube 02-7078047
4800, 4900, 5800, 5900 1985-09 Fixed setting thermostat, 25” capillary tube 60054-4401-000, 3949291 RD-5-4531-24P 71R3200
WATER VALVE
All model series with Red Dot water
Cable operated valve, straight (pull to open), 5⁄8” to 5⁄8” hose RD 5 4923 0, 677413 RD-5-4923-0P 72R5040
valve, OE # RD 5 4923 0, 677413
All model series with Red Dot water
Cable Operated, Red Dot (5⁄8” to 5⁄8”), pull to open RDH RD5 5300 1 RD-5-5300-1P 72R5210
valve, OE # RD 5 5300 1
PAGE 185
Off-Road
OEM
Applications
OFF-ROAD APPLICATIONS
Model Description OEM Part No. Factory No. Part No.
AGCO, AGCO-ALLIS
BLOWER MOTOR
Single shaft motor, (2 reqd), 1 speed, 12V, CW, 4 3⁄4" length,
Air Planter, All series with OE#RD-5-6526-0 RD-5-6526-0 RD-5-6526-0P 73R0422
vented
Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW,
Gleaner F2, F3 - condenser blower 70257681-0, HV33208 RD-5-3690-0P 73R0502
4 7⁄8" length
Kysor A/C (evaporator blower), double shaft motor, 1 speed,
Gleaner F2, F3 - with Kysor A/C, evaporator blower 70257336-1 RD-5-10068-0P 73R4322
12V, 4 7⁄8" length
Gleaner G, GH - condenser blower 70257681-0, HV33208 RD-5-3690-0P 73R0502
4 7⁄8" length
Gleaner K2 - condenser blower 70257681-0, HV33208 RD-5-3690-0P 73R0502
4 7⁄8" length
Kysor A/C (evaporator blower), double shaft motor, 1 speed,
Gleaner K2 - with Kysor A/C, evaporator blower 70257336-1 RD-5-10068-0P 73R4322
12V, 4 7⁄8" length
Gleaner L, L2, L3 - condenser blower 70257681-0, HV33208 RD-5-3690-0P 73R0502
4 7⁄8" length
Gleaner M Hillside - with Kysor A/C Kysor A/C, double shaft motor, 1 speed, 12V, 4 7⁄8" length 70257336-1 RD-5-10068-0P 73R4322
Gleaner MH2, N2, N3, N5, N6, N7 - condenser blower 70257681-0, HV33208 RD-5-3690-0P 73R0502
4 7⁄8" length
Gleaner R4, R5 Single shaft motor, non vented, 12V, 1 speed, CW, 4 7⁄8" length 70257681-0, HV33208 RD-5-3690-0P 73R0502
Tractor 2 Series 200, from Serial No. 4001 Double shaft motor, vented, 12V, 1 speed, 4 13⁄16" length RD-5-5121-1 RD-5-5121-1P 73R4262
Tractor 8 Series 8030, 8050, 8070 with Kysor/Evans Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW,
70257681-0, HV33208 RD-5-3690-0P 73R0502
condenser blower 4 7⁄8" length
Tractor 35, 45, 55 Challenger Standard with
Blower Assembly, mixed flow for standard control units RD-3-8783-0P RD-3-8783-0P RD-3-8783-0P
Red Dot unit R-9787 (Standard)
Tractor 35, 45, 55 Challenger Advanced with
Blower Assembly, mixed flow for ATC applications RD-3-8783-0P RD-3-8783-0P RD-3-8783-0P
Red Dot unit R-9787 (ATC)
BLOWER SWITCH
Combines F (F, F2, F3), K, L (L, L3) M (M, M2, MH2), N
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 71195109 RD-5-10934-0P 71R1163
(N2, N3, N5, N6, N7) R (R42, R5, R52, R6, R7)
Combines L (L before serial no. 13000)
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 1175262-3 RD-5-5194-0P 71R1210
M (series M)
Tractors 2 (200 before serial no. 4001), 6 series (6060,
6080 type 1), 7 (7020, 7040, 7045, 7060, 7080, 7580), Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 1175262-3 RD-5-5194-0P 71R1210
8 series (8550)
Tractors 2 (200, 4W ), 6 (6060, 6080 Type 2), 7 (7020,
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 71195109 RD-5-10934-0P 71R1163
7040, 7045, 7060, 7080, 7580), 8 (8010, 8050, 8070)
BLOWER WHEEL
Gleaner F Model - evaporator blower Bergstrom A/C with 4 1⁄2" double entry wheel, 3 3⁄8" width BSM302042 RD-5-10346-0P 73R7130
Gleaner F2, K2, L2, M2, MH2 Model Bergstrom A/C with 4 1⁄2" double entry wheel, 3 3⁄8" width BSM302042 RD-5-10346-0P 73R7130
Gleaner N5, N6, N7 Model Bergstrom A/C with 4 1⁄2" double entry wheel, 3 3⁄8" width BSM302042 RD-5-10346-0P 73R7130
Gleaner N5, N6, N7 - evaporator blower Bergstrom A/C with 4 1⁄2" double entry wheel, 3 3⁄8" width BSM302042 RD-5-10346-0P 73R7130
CLUTCH ASSEMBLY
Combines F, K, L, L2, L3, M, N, R Series, CCI/York - R12 /
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 332334, MA 7A RD-5-4994-0P 75R4502
134A compressors
Tractor series 4, 4W, 440, with CCI/York R12 / 134A
compressors
Tractor series 4, 6, 7000, 8, 8000, 9000 with Sanden
2 groove 5 1⁄4" diameter, 1⁄2" width, (132mm), 1 wire plug 6574-6210, 6514-6210 RD-5-5486-0P 75R0202
SD5 (508 / 510 / 5H14) R12 / R134a compressors
ELECTRICAL SWITCH
All combine and tractor model series with OE#026476-
Rotary thermostat, 36" capillary tube, 34 - 52°F 026476-9 RD-4125-36P 71R2250
9
All combine and tractor model series with
Rotary thermostat with 48" capillary tube, 34 - 52°F 0272229-6 RD-4125-48P 71R2300
OE#0272229-6
All combine and tractor model series with OE#1162472 Rotary thermostat with 48" capillary tube, 34 - 52°F 1162472 RD-4125-48P 71R2300
PAGE 189
AGCO, AGCO-ALLIS
ELECTRICAL
EVAPORATOR SWITCH
Tractor 35, 45, 55 Challenger Standard with Red Dot
Evaporator for standard control units RD-2-3410-0P RD-2-3410-0P 76R7720
unit R-9787 (Standard)
Tractor 35, 45, 55 Challenger Advanced with Red Dot
Evaporator for ATC applications RD-2-3410-0P RD-2-3410-0P 76R7720
unit R-9787 (ATC)
Combines F, G, K, M, M2, M3, MH2, N, R Series Block valve with female O-Ring fittings 71307202-3 RD-5-6868-0P 71R8301
Tractor 6 Series 6260, 6680, 6690 Block valve with female O-Ring fittings 71307202-3 RD-5-6868-0P 71R8301
Tractor 7 Series 7110, 7120 Block valve with female O-Ring fittings 4322165-4 RD-5-6868-0P 71R8301
Tractor 8 Series 8630 Block valve with female O-Ring fittings 4322165-4 RD-5-6868-0P 71R8301
Tractor 9 Series 9130, 9150, 9170, 9190, 9435, 9445,
Block valve with female O-Ring fittings 4322165-4 RD-5-6868-0P 71R8301
9455, 9630, 9650, 9670, 9690
Tractor 9 Series 9800, 9815 Block valve with female O-Ring fittings 3901517M1 RD-5-7015-0P 71R8321
Male O-Ring with 13" capillary length, 13" equalizer tube
Tractor 3 Series 305 71504287-5 RD-5-3824-1P 71R8100
length
Tractor 7 Series 7000 - 7085 0268470-2 RD-5-3824-1P 71R8100
length
Tractor 7 Series 7580 before serial no. 2039 71504287-5 RD-5-3824-1P 71R8100
length
Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
Tractor 7 Series 7580 after serial no. 2039 3380223M1 RD-5-5862-0P 71R8080
length
Tractor 8 Series 8010, 8030, 8050, 8070, 8550 71504287-5 RD-5-3824-1P 71R8100
length
Main unit, Red orifice tube, length 3.46", OD .425", orifice .075" RD-5-9082-0 RD-5-9564-0P 71R8505
Main unit, Red orifice tube, length 3.46", OD .425", orifice .075" RD-5-9082-0 RD-5-9564-0P 71R8505
unit R-9787 (ATC)
HEATER CORE
Heater for standard control units RD-1-1975-0P RD-1-1975-0P 76R4305
Heater for ATC applications RD-1-1614-0P RD-1-1614-0P 76R4300
unit R-9787 (ATC)
PRESSURE SWITCH
Low pressure cut out switch, 3⁄8"-24, norm. open, 085108-00,
All series, low pressure cut-off, drier mounting RD-4191-0P 71R6050
closes 27 psig 72162165-4
RECEIVER DRIER
Combines F, F2, F3, K, K2, L, L2, L3, M, M2, M3, MH2, N,
with #6 Male Flare (top and side), 4" X 6 3⁄4" 1162927 RD-5-6077-0P 74R4016
N5, N6, N7, R5, R6, R7
Combines N, N5, N6, N7 with #6 Male Flare (top and side), 4" X 6 3⁄4" 1162927 RD-5-6077-0P 74R4016
Combines R5, R6, R9 with #6 Male Flare (top and side), 4" X 6 3⁄4" 71193543 RD-5-6077-0P 74R4016
Tractor AGRO-Star Series 8360, 8425 with #6 Male O-Ring, 2 3⁄4" X 9 5⁄8" RDH RD5 5571 0 RD-5-5571-0P 74R1806
Tractor DT225 Male & Male O-Ring HPRV, MI IN CAP A22-28796-000 RD-5-5583-0P 74R2606
Tractor 200 Series, 200, 220 with #6 Male O-Ring, pressure relief, 3" X 9" 0256818-6 RD-5-11183-0P 74R2802
Tractor 6 and 7 Series 6060, 6070, 6080, 7020, 7030,
In Line drier with #6 Female to Male O-Ring, 4" x 8" 0264644-6 RD-5-8862-0P 74R0400
7040, 7045, 7050, 7060, 7080, 7580
Tractor 8 Series 8010, 8030, 8050, 8070, 8550 In Line drier with #6 Female to Male O-Ring, 4" x 8" 70268464 RD-5-8862-0P 74R0400
Tractor 8 Series 8745, 8765, 8775, 8785 Male O-ring Type with Switch Port and HPRV 338332M2 RD-5-9789-0P 74R3106
Tractor 9 Series 9735, 9745, 9755, 9765, 9775, 9785 Male O-ring Type with Switch Port and HPRV 338332M2 RD-5-9789-0P 74R3106
Drier for standard control units RD-5-9440-0P RD-5-9440-0P 74R3070
PAGE 190
AGCO, AGCO-ALLIS
RECEIVER DRIER
Drier for ATC applications RD-5-9440-0P RD-5-9440-0P 74R3070
unit R-9787 (ATC)
RELAY
All F (F, F2, F3), K, L (L, L2, L3) M (M, M2, M3, MH2,
Bosch style relay, 24V, SPDT, 5 terminals, 20 / 10 amp. 221711, 650690 RD-5-4417-0P 71R1704
MH3) N (N5, N6, N7) series
RESISTOR, FAN
Fan speed resistor for standard control units RD-5-8923-0P RD-5-8923-0P 71R1465
THERMOSTATIC SWITCH
9
OE#0272229-6
Tractor 35, 45, 55 Challenger Standard with Red Dot Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
unit R-9787 (Standard) capillary tube, flange/side mt.
Thermostat sensor (evaporator) for advanced control units RD-5-9557-0P RD-5-9557-0P 71R3260
unit R-9787 (ATC)
WATER VALVE
Cable operated for standard control units RD-1-2246-0P RD-1-2246-0P 72R5355
Electronic water valve, 12V or 24V for advanced control units RD-5-8806-0P RD-5-8806-0P 72R7005
unit R-9787 (ATC)
ALLIS-CHALMERS
BLOWER MOTOR
All model series with Allis Chalmers OE#0578041, All with 3" diameter blower motor, 1 speed, NV, CCW, 3 5⁄8"
0578041, 0578041-6 RD-5-4550-0P 73R0102
0578041-6 length
All with 3 1⁄4" diameter blower motor, 1 speed, 4" length, 12V,
All model series with Allis Chalmers OE#1175326 1175326 RD-5-10390-0P 73R0212
Rev. direction
All model series with Allis Chalmers OE#1175327, OE style blower motor (only), 1 speed, 3 3⁄4" length, 12V non-
1175327, 1175327-4 RD-5-10391-0P 73R0092
1175327-4 vented
All model series with 1 1⁄8" shaft, Allis Chalmers Bergstrom - Kysor A/C, single shaft, 1 1⁄8" shaft length, NV, 12V,
1183560 RD-5-5230-0P 73R0522
OE#1183560 1 speed, CW, 4 5⁄8" length
OE style blower motor (only), 1 speed, 3 3⁄4" length, 12V non-
All model series with Allis Chalmers OE#1192657 1192657 RD-5-10391-0P 73R0092
vented
Combines, all series with 1 ⁄4" shaft, single shaft
3
Bergstrom - Kysor A/C, single shaft, 1 3⁄4" shaft length, 12V, 1 1183560, BSM205620,
RD-5-10905-0P 73R0442
motor, OE#1183560, 275130 speed, CW, 4 5⁄8" length 275130
Double shaft blower motor (only), 1 speed, 4 3⁄4" length, 12V
Combines, with double shaft style motor, OE#275152 275152 RD-5-6801-0P 73R4182
vented
Tractor 8000, 8500 with 1 3⁄4" shaft, Allis Chalmers Bergstrom - Kysor A/C, single shaft, 12V, 1 speed, CW, 4 5⁄8"
275130 RD-5-10905-0P 73R0442
OE#275130 length
CLUTCH ASSEMBLY
CCI/York - R12 / 134A compressors OE#024-25078,
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug 024-25078, MA6, MAE6AR RD-5-4967-0P 75R0452
MA6, MAE6AR
CCI/York - R12 / 134A compressors OE#024 25190, 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
03-1104973, 501939 plug 501939
CCI/York - R12 / 134A compressors OE#2084050-0 2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 2084050-0 RD-5-4994-0P 75R4502
CCI/York Tecumseh Rotolock ER, R210L-25149 R12 or
Rotolock Head, LH Suction without clutch, (universal - new) ER, R210L- 25149 RD-5-8637-1P 75R7280
134a (ester oil)
CCI/York Tecumseh Rotolock 99242-5, R12 or 134a
(ester oil)
CCI/York - Tube O-Ring compressor ET210L-25150, R12 Tube O-Ring type head, Super HD-universal, without charge
ET210L-25150 RD-5-8061-1P 75R7295
/ 134A without clutch ports with ester oil
PAGE 191
AGCO, AGCO-ALLIS
CCI/York - Tube O-Ring compressor ET210L-25150C,
Tube O-Ring type head without clutch, (universal - new) ET210L-25150C RD-5-8638-1P 75R7290
R12 / 134A without clutch
CCI/York - Tube O-Ring compressor, OE#99244-5, R12 /
134A without clutch
COMPRESSOR - GM
GM A6 compressor with Superheat switch port, 0259362-2, 1131243,
1 groove 1⁄2" width, 4 7⁄8" diameter (124mm), generic RD-5-5000-0P 75R8102
without oil 509170-C91
COMPRESSOR - SANDEN
All series with Sanden 5H14, #6664 R134a
5H14, FL head, ear mount, 2A groove, 5 1⁄4" (132mm) diameter 6664 RD-5-7088-0P 75R8382
compressors, 12V
Sanden 5H14, #6665 R134a compressors, 24V 5H14-HD, FL head, 2A groove, 5 1⁄4" (132mm) diameter 6665 RD-5-7089-0P 75R8384
Sanden 510-HD, #9103, R12 with Mineral Oil and
SD510HD, B head, 2A groove, 5 1⁄4"(132mm) diameter 9103 RD-5-6164-0P 75R8262
Charging Ports
Sanden 508-HD, #9285, R12 with Mineral Oil and
SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285 RD-5-5575-0P 75R8292
Charging Ports
Sanden 510-HD, #9674, 24V, R12 with Mineral Oil and
Charging Ports
Sanden SD510-HD, #9675 R-12 compressor with
SD510HD, FG head, variable groove, 6 1⁄4"(158mm) diameter 9675 RD-5-5627-0P 75R8232
charge ports, mineral oil
Block valve for female O-Ring fittings 04322165-4, RD 4157 0 RD-5-6868-0P 71R8301
OE#04322165-4
All combine and tractor model series with OE#329-413 Block valve, Hi - capacity (2 ton) 329-413 RD-5-7015-0P 71R8321
Block valve for female O-Ring fittings 72162195 RD-5-6868-0P 71R8301
OE#72162195
All combine and tractor model series with OE#826-003 External Equalizer with O-Ring style valve 826-003 RD-5-5862-0P 71R8080
All combine and tractor model series with OE#826-062 External Equalizer with male O-Ring with 13" cap length 826-062 RD-5-3824-1P 71R8100
External Equalizer unit with male flare with 18" capillary length 31134-300, RD 4126 1 RD-4126-1P 71R8050
300
All combine and tractor model series with OE#826-004 Internal equalizer valve with male O-Ring fittings 826-004 RD-5-11033-0P 71R8060
Internal equalizer, 1 1⁄2 Ton, Male O-Ring 1162473-1 RD-5-10445-0P 71R8220
OE#1162473-1
RECEIVER DRIER
Male O-Ring with fuse plug, side port, top glass 085098-00 RD-5-4950-0P 74R0906
OE#085098-00
Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" 088423-00 RD-5-7061-1P 74R2536
OE#088423-00
In Line drier with #6 Female to Male O-Ring, 4" x 8" 268464-02 RD-5-8862-0P 74R0400
OE#268464-02
Male & Male O-Ring with Fuse Plug, Low Pressure Switch 72161835-3 RD-4160-1P 74R2106
OE#72161835-3
with #6 Male Flare (top and side), 4" X 6 3⁄4" 1143539, 1162927 RD-5-6077-0P 74R4016
OE#1143539, 1162927
THERMOSTATIC SWITCH
All combine and tractor model series with OE#1162472 Rotary thermostat with 48" capillary tube, 34 - 52°F 1162472 RD-4125-48P 71R2300
OE#1162474-9
All combine and tractor model series with OE#404145 Fixed Setting thermostat with 24" capillary tube, flange mt. 404145 RD-4427-24P 71R3100
PAGE 192
CASE
BLOWER MOTOR
All model series with Case OE#A42567 Kysor A/C, double shaft motor, 1 speed, 4 7⁄8" length A42567 RD-5-10068-0P 73R4322
All with 3" diameter blower motor, 1 speed, NV, CCW, 3 5⁄8"
All model series with Case OE#A42599, F89388 A42599, F89388 RD-5-4550-0P 73R0102
length
Backhoe 480F Single speed, non vented, 12V, Reversable, 3 3⁄4" length 2807-508-043 RD-5-10391-0P 73R0092
Backhoe / Loader 580, 580L, 580M, 580 Super M,
Blower Assembly, 1 speed, 12V, 14 3⁄4" x 7 1⁄2" x 7" RD-5-11030-0 RD-5-11030-0P 73R5602
Turbo, 590, 590 Super M
Single shaft motor, 24V, CCW, NV, 1" slinger, 1 speed, 5" length 2G0409, 8P9982, 9G0393,
Backhoe / Loader / Tractors 777, 963LGP, 980B RD-5-6071-0P 73R0364
x 4" x 3" diameter 9G0397, 9G8693, 9G8697
Tractors 766, 1066, 1466, 1566 - condenser blower Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW,
539047-R2 RD-5-3690-0P 73R0502
motor 4 7⁄8" length
Tractors 1468, 1568 - condenser blower motor 117783-C1 RD-5-3690-0P 73R0502
4 7⁄8" length
Tractor 4166 - condenser blower motor 66390-C1 RD-5-3690-0P 73R0502
4 7⁄8" length
Tractors 8910, 8920, 8930, 8940, 8950 - blower motor Kysor A/C, double shaft motor, 1 speed, 4 7⁄8" length 80430411 RD-5-10068-0P 73R4322
Tractors 8910, 8920, 8930, 8940, 8950 - condenser Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW,
80417384 RD-5-3690-0P 73R0502
blower motor 4 7⁄8" length
Tractors Hydro 100 - condenser blower motor 539047-R2 RD-5-3690-0P 73R0502
4 7⁄8" length
BLOWER SWITCH
Combines 715, 815, 915, 1620, 1640, 1660, 1680, 1688 Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 168822C1, C2 RD-5-10934-0P 71R1163
Tractors 90 series, Super D, 580, 870, 970, 1070, 1175,
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 168822C1, C2 RD-5-10934-0P 71R1163
1270, 1370, 1570
Tractors 90 series with resistor Rotary switch, 3 speed, DP3T, 4 position, 5 terminal RD-5-5194-0P RD-5-5194-0P 71R1210
CLUTCH ASSEMBLY
CCI/York - R12 / 134A compressors,
2 groove 6" diameter pulley, 1⁄2" width, 2 1⁄4" ga 003-3938 RD-5-10367-0P 75R0422
OE#003-3938
CCI/York - R12 / 134A compressors,
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 003-4530 RD-5-4994-0P 75R4502
OE#003-4530
Fits Sanden SD7H15HD R134a compressor,
2 groove 1⁄2" width, 5 1⁄4" diameter (132mm) 6504-6310 RD-5-10379-0P 75R1542
OE #6504-6310
Fits Sanden SD508, 510, 514 R-12 compressors,
2 groove 5 1⁄4" (132mm) diameter pulley, 1⁄2" width, 1 wire 6514-6210 RD-5-5486-0P 75R0202
OE#6514-6210
All series with CCI / York Tecumseh Rotolock, LH ER210L-25149, -21237,
suction with OE#ER210L-25149 -25062, 99239-5
All series with CCI/York - Tube O-Ring compressors,
All series with CCI/York - Rotolock Head, R12 / 134A
without clutch
All series with CCI/York - Tube O-Ring compressors,
Combines with CCI / York Tecumseh Rotolock
All Models with Rotolock Type (universal) RH without clutch ER210R-16792, 25200 RD-5-10826-0P 75R7265
ER210R-16792, 25200
Combines with CCI / York Tecumseh Tube-O Tube O-Ring type head, Super HD-universal, without charge
ET210L-25428 RD-5-8061-1P 75R7295
ET210L-25428 ports with ester oil
Tractors 66, 86 series with York Rotolock
Rotolock Head (universal), RH Suction, without clutch ER210R-25200, -16792 RD-5-10826-0P 75R7265
ER210R-25200
Tractors 100 series, Hydro 100, 186 with Tecumseh ER210L- 25149, -21237,
Rotolock ER210L-25149 -25062, 99239-5
Tractors 100 series, Hydro 100, 186 with York Rotolock
ER210R-25200
Tractors 2090, 2390, 2590 with Tecumseh Rotolock ER210L- 25149, -21237,
ER210L-25149 -25062, 99239-5
PAGE 193
CASE
Tractors 2090, 2390, 2590 with York Rotolock
ER210R-25200
Tractor King 1470, 1570, 2470, 2670, 2870 with York
Rotolock ER210R-25200
COMPRESSOR - GM
Tractors AGRI-King 770, 870, 970, 1070, 1270, 1370 1131243, 12301930, 31,
with GM A6 with Superheat switch port, without oil 509170-C91
Tractors AGRI-King 770, 870, 970, 1070, 1270, 1370 1131243, 12301930, 31,
with GM A6 with Superheat switch port, without oil 509170-C91
Tractors 4490, 4690, 4890 with GM A6 with Superheat 1131243, 12301930, 31,
switch port, without oil 509170-C91
COMPRESSOR - SANDEN
All series with 12V Sanden 7H15HD, OE #4609. Case 4609, 1999755C3,
7H15, MD head, ear mount 2 groove, 6" (152mm) diameter RD-5-10259-0P 75R84112
OE#1999755C3, 86993462 86993462
All series with 24V Sanden 7H15HD, OE #4611. Case 4611, 1999760C2,
OE#1999760C2, 86983967 86993967
All series with 12V Sanden 7H15HD, OE #4768. Case
7H15, MD head, direct mount poly 8, 6" (152mm) diameter 4768, 317008A3, 86993463 RD-5-11311-0P 75R81412
OE#317008A3, 86993463
All series with 24V Sanden 7H15HD, OE #4795. Case
OE#352524A2, 86983968
compressors, 12V
5H14-HD, FL head, 2A groove, 5 1⁄4" (132mm) diameter 6665 RD-5-7089-0P 75R8384
compressors, 24V
All series with Sanden 510-HD, OE #8353, 9103 510-HD , B head, ear mount 2 groove, 5 1⁄4" (132mm) diameter 8353, 9103 RD-5-6164-0P 75R8262
All series with Sanden 508HD, OE #9285, 9515 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, 9515 RD-5-5575-0P 75R8292
All series with Sanden 510-HD, #9674, 24V, R12 with
Mineral Oil and Charging Ports
All series with Sanden SD510, #9675 R-12 compressor
Backhoe / Loader 580, 580K, L, M, 580 Super M, Turbo,
7H15, MD head, ear mount 2 groove, 6" (152mm) diameter 4609 RD-5-10259-0P 75R84112
590, 590 Super M
Combines 521, 525, 527 with Sanden 7H15, OE #4709,
7H15, KG head, ear mount, 2A groove, 4.9"(125mm) diameter 4709, 7862, 8023 RD-5-11331-0P 75R81552
7862, 8023
Combines 695, 795, 895, 995 with Sanden 5H14,
5H14, M head, ear mount, 2A groove, 5 1⁄4" (132mm) diameter 4513, 6631, 9264 RD-5-7548-0P 75R8312
OE#4513, 6631, 9264
Combines 2144, 2166, 2188 with Sanden 7H15HD, OE
#4609
Combines 2344, 2366, 2388 with Sanden 7H15HD, OE
#4609
Cotton Pickers 1822, 1844, 2555 with Sanden 7H15HD,
OE #4609
Tractors C, CX series with Sanden 7H15HD, OE #4609 7H15, MD head, ear mount 2 groove, 6" (152mm) diameter 4609 RD-5-10259-0P 75R84112
Tractors JX 55-95, MXM 120-190 with Sanden 7H15,
7H15, JDA head, ear mount, poly 8, 4 3⁄4" (119mm) diameter 4660 RD-5-11322-0P 75R81482
OE #4660
Tractors JX 55-95, MXM 120-190 with Sanden 7H15, OE 7H15, JD head, ear mount, poly 8 groove, 4.7" (119 mm)
4711, 8103 RD-5-9251-0P 75R8462
#4711, 8103 diameter
Tractors Magnum/MX 7100, 7200, 8900 series with
Sanden 7H15HD, OE #4609
Tractors Quad-Trac 9200, 9230, 9380 series with
Sanden 7H15HD, OE #4609
Tractors 90 series with Sanden 510-HD, OE #8353,
510-HD , B head, ear mount 2 groove, 5 1⁄4" (132mm) diameter 8353, 9103 RD-5-6164-0P 75R8262
9103
Tractors 90 series with Sanden 508HD, OE #9285, 9515 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, 9515 RD-5-5575-0P 75R8292
PAGE 194
CASE
COMPRESSOR - SANDEN
Tractors 91 Steiger series - with Sanden 510HD, OE SD510HD, C head, ear mount, variable groove 6 1⁄4" diameter
8478, 9119 RD-5-5200-0P 75R8222
#8478, 9119 (158mm)
Tractors 500, 600 Series with Sanden 5H14, OE#4513,
5H14, M head, ear mount, 2A groove, 5 1⁄4" (132mm) diameter 4513, 6631, 9264 RD-5-7548-0P 75R8312
6631, 9264
Tractors 8900 series with Sanden 7H15HD, OE #4609 7H15, MD head, ear mount 2 groove, 6" (152mm) diameter 4609 RD-5-10259-0P 75R84112
Wheel Loader 621DXT with 24V Sanden 7H15HD, OE 4611, 1999760C2,
#4611. Case OE#1999760C2, 86983967 86993967
Windrowers 6500, 8820, 8830, 8840, 8850, 8860, 8870
series with Sanden 7H15HD, OE #4609
All series with ICE/Seltec TM21HD # 488-47244 -
TM21HD, J head, direct mount, poly 8, 5 1⁄2" (141mm) diameter 488-47244 RD-5-12530-1P 75R86142Q
R134a Compressor with PAG OIL
ELECTRICAL SWITCH
Rotary thermostat, 27" capillary, 34°-52°F, clutch cycle range
All series using clutch cycling switch with OE#70500C2 70500C2 RD-4172-0P 71R2310
5°F
All series using clutch cycling switch with OE#L73646 Rotary thermostat with 36" capillary tube L73646 RD-4125-36P 71R2250
All Series using clutch cycling switch with
Rotary thermostat with 48" capillary tube, 34 - 52°F 301305-C91 RD-4125-48P 71R2300
OE#1259617-7
All Series using OE#118321C1 Block valve, 1 1⁄2 ton with female O-Ring fittings 118321C1 RD-5-6868-0P 71R8301
All Series using OE#60-5880T1 Block valve, 1 1⁄2 ton with female O-Ring fittings 60-5880T1 RD-5-6868-0P 71R8301
All Series using OE#1990756C1, C2 Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C1, C2 RD-5-7015-0P 71R8321
Block valve, Hi - capacity (2 ton), O-Ring fittings RD-5-9513-0 RD-5-9513-0P 71R8380
590, 590 Super M
Combines 1620, 1640, 1644, 1660, 1666, 1680, 1688
Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
series
Combines 2166, 2188, 2344 Axial, 2366 Axial, 2555
series
Sprayers SP2000, SP2500, SP3000 series Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
Tractors C, CX series Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
Tractors Magnum, MX series - 5100, 5200, 7100, 7200 Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
Tractors Quad-Trac series - 9380 Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
Tractors 3088, 3288, 3388, 3488, 3588, 3688, 3788
Block valve, 1 1⁄2 ton with female O-Ring fittings 118321C1 RD-5-6868-0P 71R8301
series
Tractors 5088, 5288, 5488 series Block valve, 1 1⁄2 ton with female O-Ring fittings 118321C1 RD-5-6868-0P 71R8301
Tractors 5120, 5130, 5140, 5220, 5230, 5240 series Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
Tractors 6388, 6588, 6788 series Block valve, 1 1⁄2 ton with female O-Ring fittings 118321C1 RD-5-6868-0P 71R8301
Tractors 7110, 7120, 7130, 7140, 7150, 7210, 7220,
7230, 7240, 7250 series
Tractors 7288, 7488 Series Block valve, 1 1⁄2 ton with female O-Ring fittings 118321C1 RD-5-6868-0P 71R8301
Tractors 8910, 8920, 8930, 8940, 8950 series Block valve, Hi - capacity (2 ton), O-Ring fittings 1990756C2 RD-5-7015-0P 71R8321
Tractors 9110, 9130, 9150, 9170, 9180, 9190 Series Block valve, 1 1⁄2 ton with female O-Ring fittings 118321C1 RD-5-6868-0P 71R8301
Tractors 9210, 9230, 9240, 9250, 9260, 9270, 9280,
9310, 9330, 9350, 9370, 9380 series
All Series using OE#A42625, RD-5-5862-0, 469475-C1, A42625, RD-5-5862-0,
External equalizer with male O-Ring with 10" capillary length RD-5-5862-0P 71R8080
826-081 469475-C1, 826-081
All Series using OE#1280333C1, C2 External equalizer with male O-Ring with 13" capillary length 1280333C2 RD-5-3824-1P 71R8100
Combines 1420, 1440, 1460, 1480 series External equalizer with male O-Ring with 13" capillary length 1280333C2 RD-5-3824-1P 71R8100
A42625, RD-5-5862-0,
Tractors 500, 600 Series External equalizer with male O-Ring with 10" capillary length RD-5-5862-0P 71R8080
469475-C1
Tractors 695, 795, 895, 995 series External equalizer with male O-Ring with 13" capillary length 1280333C2 RD-5-3824-1P 71R8100
PAGE 195
CASE
A42625, RD-5-5862-0,
Tractors 790, 1070, 1270, 1370, 1570 Series External equalizer with male O-Ring with 10" capillary length RD-5-5862-0P 71R8080
469475-C1
Windrowers 4000, 5000, 5500 series External equalizer with male O-Ring with 13" capillary length 1280333C2 RD-5-3824-1P 71R8100
Internal equalizer with male flare with 9" capillary length, flare
All Series using OE#168903C1, C91 168903C1, C91 RD-5-6099-0P 71R8210
fittings
All Series using OE#826-004 Internal equalizer valve with male O-Ring fittings 826-004 RD-5-10445-0P 71R8220
Combines 615, 715, 815, 915 series 168903C1 RD-5-6099-0P 71R8210
fittings
Tractors 766, 786, 886, 966, 986, 1066, 1086, 1466, Internal equalizer with male flare with 9" capillary length, flare
20179C1 RD-5-6099-0P 71R8210
1486, 1566, 1586 series fittings
Tractors 4166, 4186, 4366, 4386, 4586, 4786 series 20179C1 RD-5-6099-0P 71R8210
fittings
Windrowers 4000, 5000, 5500 series 168903C1 RD-5-6099-0P 71R8210
fittings
PRESSURE SWITCH
High Pressure Switch, normally closed 210psi, opens 340 psi, 1⁄4"
All series using high pressure switch, OE#111266C1 111266C1 RD-5-5873-0P 71R6070
female flare
High Pressure Switch, normally open 250psi, close 375 psi, 1⁄4"
female flare
All series using low pressure switch, receiver drier
Low pressure cut out switch, 3⁄8"-24, norm. open, closes 27 psig A47717 RD-4191-0P 71R6050
mounting (O-Ring seal) , OE#A47717
RECEIVER DRIER
All series with OE#085098-00 Male O-Ring with fuse plug, side port, top glass A22-14425-001 RD-5-4950-0P 74R0906
All series with OE#088423-00 Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 ⁄4" 088423-00
1
RD-5-7061-1P 74R2536
All series with OE#111218-C1 with #6 Male Flare (top and side), 4" X 6 3⁄4" 111218-C1 RD-5-6077-0P 74R4016
All Series with OE#118304-C1, 118418-C1 with #6 Male O-Ring (top and side), 4" X 6 3⁄4" 118304-C1, 118418-C1 RD-5-6075-0P 74R4006
All Series with OE#124552-C1 Male & Male O-Ring with Fuse Plug, Low Pressure Switch 124552-C1 RD-4160-1P 74R2106
All series with OE#143469-C2 with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 143469-C2 RD-5-11028-0P 74R4026
All series with OE#1990758-C2 with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
All series with OE#539049-R1, R91 with #6 Male Flare (top and side), 4" X 6 ⁄4"
3
539049-R1, R91 RD-5-6077-0P 74R4016
All series with OE#572832-R91 with #6 Male Flare (top and side), 4" X 6 3⁄4" 572832-R91 RD-5-6077-0P 74R4016
with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
590, 590 Super M
RD-5-4954-0, 088011-00,
Combines 521, 525, 527 series with #6 Male flare, 3" X 6 1⁄4" RD-5-4954-0P 74R2406
926384-C1
Combines 1460, 1480 series with #6 Male Flare (top and side), 4" X 6 3⁄4" 111218-C1, 539049-R1, R91 RD-5-6077-0P 74R4016
Combines 1620, 1640, 1644, 1660, 1666, 1680, 1688
series
Combines 2166, 2188, 2344, 2366, 2388, 2555 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
Cotton Pickers 1822, 1844, 2555 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 ⁄4"3
1990758-C2 RD-5-11028-0P 74R4026
Tractors AGRI-King 770, 870, 970, 1070, 1270, 1370
Male & Male O-Ring with Fuse Plug, Low Pressure Switch A61688, A76312 RD-4160-1P 74R2106
series
Tractors C, CX series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
Tractors Hydro 100, 186 series with #6 Male Flare (top and side), 4" X 6 3⁄4" 111218-C1, 539049-R1, R91 RD-5-6077-0P 74R4016
Tractors Magnum, MX 180, 200, 220, 240, 270, 5120,
5130, 5140, 7110, 7120, 7130, 7140, 7200, 8900 series
Tractors Quad-Trac 9380 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
Tractors Traction King 1470, 1570, 2470, 2670, 2870
Male & Male O-Ring with Fuse Plug, Low Pressure Switch A76312 RD-4160-1P 74R2106
series
Tractors 1466, 1468, 1566, 1568 series with #6 Male Flare (top and side), 4" X 6 3⁄4" 111218-C1, 539049-R1, R91 RD-5-6077-0P 74R4016
Tractors 1570, 1896 series Male & Male O-Ring with Fuse Plug, Low Pressure Switch A76312 RD-4160-1P 74R2106
PAGE 196
CASE
RECEIVER DRIER
Tractors 2090, 2096, 2290, 2294, 2390, 2394, 2470,
2590, 2594, 2670, 2870 series
Tractors 3088, 3288, 3294, 3388, 3394, 3488, 3588,
3594, 3688, 3788 series
Tractors 4166, 4366, 4386, 4586, 4786 series with #6 Male Flare (top and side), 4" X 6 3⁄4" 111218-C1, 539049-R1, R91 RD-5-6077-0P 74R4016
Tractors 4386, 4586, 4786 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 143464-C2, 143469-C2 RD-5-11028-0P 74R4026
Tractors 4490, 4494, 4690, 4694, 4890, 4894, 4994
series
Tractors 5088, 5120, 5130, 5140, 5220, 5230, 5240, 143464-C2, 143469-C2,
with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" RD-5-11028-0P 74R4026
5288, 5488 series 1990758-C2
Tractors 6388, 6588, 6788 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
Tractors 7110, 7120, 7130, 7140, 7150, 7288, 7488
series
Tractors 8910, 8920, 8930, 8940, 8950 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
Tractors 9110, 9130, 9150, 9170, 9180 series Male O-ring Type with Switch Port and HPRV 088214-00, 088214-03 RD-5-9789-0P 74R3106
Tractors 9210, 9230, 9240, 9250, 9260, 9270 series
Male O-ring Type with Switch Port and HPRV 088214-00, 088214-03 RD-5-9789-0P 74R3106
before serial no. JEE0031849
Tractors 9210, 9230, 9240, 9250, 9260, 9270 series
after no. serial JEE0031850
Tractors 9310, 9330, 9350, 9370, 9380 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 1990758-C2 RD-5-11028-0P 74R4026
Windrowers 4000, 5000, 8820, 8830, 8840, 8850
series
THERMOSTATIC SWITCH
All Series with OE#A42623 Rotary thermostat with 18" capillary tube, 28 - 62°F A42623 RD-5-4909-0P 71R2100
All Series with OE#109268-C2 Rotary thermostat with 48" capillary tube, 34 - 52°F 109268-C1, C2 RD-4125-48P 71R2300
All Series with OE#1162474-9 Rotary thermostat with 36" capillary tube, 34 - 52°F 1162474-9 RD-4125-36P 71R2250
All Series using clutch cycling switch with
OE#1259617-7
All Series with OE#175575C-1 Rotary thermostat with 48" capillary tube, 34 - 52°F 175575C-1 RD-4125-48P 71R2300
All Series with OE#301395-C91 Rotary thermostat with 48" capillary tube, 34 - 52°F 301395-C91 RD-4125-48P 71R2300
All Series with OE#404145 Fixed Setting thermostat with 24" capillary tube, flange mt. 404145 RD-4427-24P 71R3100
All Series with OE#70500-C2 Rotary thermostat with 18" capillary tube, 28 - 62°F 70500-C2 RD-5-4909-0P 71R2100
Rotary thermostat with 18" capillary tube, 35 - 44°F RD-5-11029-0 RD-5-11029-0P 71R2305
590, 590 Super M
CATERPILLAR
BLOWER - FAN
Telehandler TH26, 63, 82, 83, 103 Series with Red Dot
Pancake fan assembly, (puller) 12V RD-5-8641-0 RD-5-8641-0P RD-5-8641-0P
model R-10170-0, puller fan OE#RD-5-8641-0
Telehandler TH26, 63, 82, 83, 103 Series with Red Dot
model R-10170-1, puller fan OE#RD-5-8641-1
BLOWER - FAN RESISTOR
Skid Steer, A series Tier I & II, with Red Dot model
Blower Resistor, Red Dot A/C units, 3 terminal, 3 speed RD-5-3647-0 RD-5-3647-0P 71R1450
R-6500, R-6500-1
Skid Steer, B series Tier II, with Red Dot model R-295- Blower Resistor, Red Dot A/C units. Used on RD-5-8837-0P
RD-5-9447-0 RD-5-9447-0P 71R1403
0, R-9750 Blower Assembly
Ceramic tube style resistor, 4 terminal, 12V, 6 1⁄2" length x 1 3⁄16"
Large Haul Truck 793, 797 series for Red Dot models RD-5-8665-0 RD-5-8665-0P 71R1485
diam
Small Tract Type Tractor D3, D4, D5 with Red Dot unit
Ceramic style resistor RD-5-10028-0 RD-5-10028-0P RD-5-10028-0P
R-9789-0, -1
BLOWER MOTOR
D series models with 24V evaporator motor RD-5-6071-0P 73R0364
x 4" x 3" diameter RD-5-6071-0
PAGE 197
CATERPILLAR
BLOWER MOTOR
Large Haul Truck 777 series with Red Dot model Single shaft motor, 24V, CCW, NV, 1" slinger, 1 speed, 5" length 2G0409, 8P9982, 9G0397,
RD-5-6071-0P 73R0364
R-3800-5 with 24V evaporator motor x 4" x 3" diameter RD-5-6071-0
Large Haul Truck 793, 797 series with Red Dot model
Double shaft motor, 24V, NV, 1 speed, 5 3⁄4" length RD-5-10054-0P RD-5-10054-0P 73R4274
R-9785-0 with 24V evaporator motor
Loader 963LGP, 980B with 24V evaporator motor RD-5-6071-0P 73R0364
Motor Grader 24H with Red Dot model R-9790-0, Double shaft motor, 24V, NV, 1 speed, slinger, 5" length, 3 1⁄4"
3E-6392 RD-5-8375-0P RD-5-8375-0P
OE#3E-6392 shafts
Skid Steer with Red Dot R-10500, R-10500-1 model
Blower assembly with resistor, 12V, 13 3⁄4" x 5 3⁄8" x 5 1⁄8" RD-5-8583-0 RD-5-8583-0P 73R5552
evaporator
Skid Steer, A series Tier 1 & 2, with Red Dot model
Blower assembly, 12V, 12 1⁄4" x 3 1⁄8" x 4 1⁄2" RD-5-8837-1 RD-5-8837-1P 73R5642
R-6500, R-6500-1
Skid Steer, B series Tier 2, with Red Dot model R-6501 2RD570M Unit with Heater A/C, 12V blower motor assy RD 5 8837 0 RD-5-8837-0P 73R5532
Blower Assembly, mixed flow for standard control units RD-3-8783-0P RD-3-8783-0P RD-3-8783-0P
R-9789-0, -1
Telehandler TH26, 63, 82, 83, 103 Series with Red Dot RD-5-10068-0, 2809-
Double shaft motor, 1 speed, 4 3⁄4" length RD-5-10068-0P 73R4322
model R-10170-0, evaporator motor OE#2809-541-001 541-001
Track Type Tractor D6H, D6HLPG, D7H, D7HLPG, D8N, Single shaft motor, 24V, CCW, NV, 1" slinger, 1 speed, 5" length 2G0409, 8P9982, 9G0393,
RD-5-6071-0P 73R0364
D9L (early & late), D9N, D10, D11N x 4" x 3" diameter RD-5-6071-0
Wheel Tractor-Scraper 673E RD-5-6071-0P 73R0364
14G, 16G series models with 24V evaporator motor RD-5-6071-0P 73R0364
637E, 777, 963LGP series models with 24V evaporator Single shaft motor, 24V, CCW, NV, 1" slinger, 1 speed, 5" length 2G0409, 8P9982, 9G0393,
RD-5-6071-0P 73R0364
motor x 4" x 3" diameter RD-5-6071-0
906 series models with Red Dot model R-10160-0
Double shaft motor, 12V, 3 speed, 4" length RD-5-3780-0 RD-5-3780-0P 73R4102
evaporator motor
Single shaft motor, 24V, CCW, NV, 1" slinger, 1 speed, 5" length 8P9982, 9G0393, 9G8693,
980B series models with 24V evaporator motor RD-5-6071-0P 73R0364
x 4" x 3" diameter 9G8697, RD-5-6071-0
BLOWER SWITCH
325 Series using Red Dot A/C unit R-10004-0,
Toggle switch, SPST, 2 terminal RD-5-3748-0 RD-5-3748-0P 71R0010
OE#RD-5-3748-0
906 series models with Red Dot model R-10160-0
Sleeper A/C Htr. toggle switch, DPDT, ON-ON-ON RD-5-0071-0 RD-5-0071-0P 71R0400
evaporator motor
CLUTCH ASSEMBLY
CCI/York - R12 / 134A compressors, Caterpillar OE#003-
1 groove 1⁄2" width, 6" diameter pulley, 2 3⁄4" ga., IHC plug 003-3938 RD-5-9665-0P 75R0402
3938
CCI/York - R12 / 134A compressors, Caterpillar
OE#8517-6010
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 21590, 03-1104973,
CCI/York - R12 / 134A compressors, OE#024-21590 RD-5-4972-1P 75R1202
plug 501939
CCI/York - R12 / 134A compressors, OE#MA6, MAE6AR 2 groove 6" diameter pulley, 1⁄2" width, 2 1⁄4" ga MA6, MAE6AR RD-5-10367-0P 75R0422
CCI/York - R12 / 134A compressors, OE#MA7A 2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug MA7A RD-5-4994-0P 75R4502
All series with CCI/York - Rotolock Head without
clutch, OE#ER-210L-25149
All series with CCI/York - Tube O-Ring compressors
without clutch, OE#ET210L-25150
All series with CCI/York - Rotolock Head without
clutch, OE#99242-5
All series with CCI/York - Tube O-Ring compressors
without clutch, OE#99244-5
PAGE 198
CATERPILLAR
CLUTCH
COMPRESSOR ASSEMBLY - GM
All series with GM A6 with Superheat switch port, 1131243, 12301930, 31,
without oil 509170-C91
COMPRESSOR - SANDEN
Backhoe Loader 416D, 420D, 420D IT, 430D with
7H15SHD, GK head, ear mount, 1A groove, 6" (152mm) diameter 4608 RD-5-11311-0P 7581432
Sanden 7H15SHD, Sanden OE #4608
All series with Sanden 508HD 12V, R-12 , Sanden OE
#9285
All series with Sanden 508HD 12V, R-12 , Sanden OE
SD510HD, B head, ear mt., 2A groove, 5 1⁄4" (132mm)diameter 5742, 9103 RD-5-6164-0P 75R8262
#9103
All series with Sanden 510-HD, 24V, R-12, Sanden OE
#9674
All series with Sanden 510-HD, 12V, R-12, Sanden OE
SD510HD, FG head, variable groove, 6 1⁄4"(158mm) diameter 206RD49AM, 9675 RD-5-5627-0P 75R8232
#9675
SD5H14, FL head, ear mount, 2 groove 5 1⁄4" Diameter with
All series with Sanden SD5H14, Sanden OE #6664 8177090, 6664 RD-5-7088-0P 75R8382
verticle O-Ring fitting
All series with Sanden SD5H14, Caterpillar SD5H14, FL head, ear mount, 2 groove 5 1⁄4" Diameter with
72239450, 6664 RD-5-7088-0P 75R8382
OE#72239450 verticle O-Ring fitting
All series with Sanden 5H14, 24V, R134a compressor,
Sanden OE #6665
All series with Sanden 7H15SHD, 12V, R-12, Sanden OE 7H15SHD, KC head, ear mount, 2A groove, 5 1⁄2" (138mm)
4661, 114-9484 RD-5-11324-0P 75R81492
#4661, Cat OE#114-9484 diameter
All series with Sanden 7H15SHD, 24V, Sanden 4726, Cat OE#114-9676,
7H15SHD, GK head, ear mount, poly 8, 5 1⁄4"(132mm) diameter RD-5-10260-0P 75R84594
OE#4726, Cat OE#114-9676, 218-0234 218-0234
All series with Sanden 7H15, 24V, Sanden OE#4769, Cat
7H15, MD head, ear mount, poly 8, 5 1⁄4"(132mm) diameter 4769, Cat OE#163-0872 RD-5-11161-0P 75R81114
OE#163-0872
All series with Sanden 7H15, 12V, Sanden OE#4813, Cat 7H15SHD, KCA head, direct mount, poly 8, 5 1⁄4"(132mm)
4813, Cat OE#178-9570 RD-5-11260-0P 75R81402
OE#178-9570 diameter
All series with Sanden 7H15, 24V, Sanden OE#4840,
7H15SHD, GK head, direct mount, poly 8, 6" (152mm) diameter 4840, Cat OE#183-5106 RD-5-11236-0P 75R81134
Cat OE#183-5106
4604, 8107, Cat
All series with Sanden 7H15, 24V, Sanden OE#4604,
7H15SHD, GK head, ear, 1A groove, 5 1⁄2" (138mm) diameter OE#3E-1906, 101-1795, RD-5-11240-0P 75R81184
8107, Cat OE#3E-1906
134-3997
All series with Sanden 7H15, 12V, Sanden OE#4608, 4608, 8108, Cat
7H15SHD, GK head, ear mount, 1A groove, 6" (152mm) diameter RD-5-11311-0P 75R81432
8108, Cat OE#3E-1908 OE#3E-1907, 1908
All series with Sanden 7H15, 24V, Sanden OE#4640, 4640, 8109, Cat OE#106-
7H15SHD, GK head, ear mount, 1A groove, 6" (152mm) diameter RD-5-11248-0P 75R81274
8109, Cat OE#106-5122 5122
All series with ICE/Seltec TM21HD 12V, OE#488-47244
TM21HD, J head, direct mount, poly 8, 5 1⁄2" (141mm) diameter 488-47244, 435-67256 RD-5-12530-1P 75R86142Q
- R134a
All series with ICE/Seltec TM21HD 24V, OE#488-47246
TM21HD, J head, direct mount, poly 8, 5 1⁄2" (141mm) diameter 488-47246 RD-5-11866-1P 75R86144Q
- R134a
CONDENSER
IT14G, IT28G models with Red Dot A/C unit R-10046-0,
Radiator Mount, Tube & Fin type, 23" fin width x 12 1⁄4" x 1 3⁄4" RDH RD4 3724 0 RD-4-3724-0P 77R0650
R-10047-0
Large Haul Trucks with Red Dot A/C unit R-10235 Grilldenser type, 37" fin width x 32" x 3⁄4" RD-4-3683-2 RD-4-3683-2P 77R7900
Skid Steer A and B series with Red Dot R-10500,
Multi Flow type, 18 13⁄16" fin width x 14" x 3⁄4" RD-4-5378-0 RD-4-5378-0P 77R1290
R-10500-1 model evaporator
TH26, TH63, TH82, TH83, TH103 with Red Dot R-10170
Tube & Fin type, 26 7⁄16" fin width x 23 1⁄4" x 9 1⁄8" RD-4-4069-0 RD-4-4069-0P 77R0100
model evaporator
325 models with Red Dot A/C unit R-10004-0 Radiator Mount,Tube & Fin type, 21 1⁄2" fin width x 26 1⁄2" x 1 1⁄4" RD-4-4968-0 RD-4-4968-0P 77R7100
906 models with Red Dot A/C unit R-10160-0 Tube & Fin type, 20 7⁄8" fin width x 12" x 3 1⁄3" RD-4-4738-0 RD-4-4738-0P 77R0620
914G, 928G models with Red Dot A/C unit R-10046-0,
Tube & Fin type, Red Dot unit, 23" fin width x 12 1⁄4" x 1 3⁄4" RDH RD4 3724 0 RD-4-3724-0P 77R0650
R-10047-0
PAGE 199
CATERPILLAR
CONDENSER
950B - E, 966, 980A - C models with Red Dot A/C unit
Tube & Fin type, 23" fin width x 9 1⁄8" x 3" RD-4-4069-1 RD-4-4069-1P 77R0110
R-10044-3, R-10045-0
3V0251, 3V0258, RD-5-
All Series using OE#3V0251, 3V0258, RD-5-6868-0 Main Unit, 1 1⁄2 ton Hi - cap, Female O-Ring, 5°F, 80psi@40°F RD-5-6868-0P 71R8301
6868-0
All Series using OE#98370C3, RD-5-7015-0 Block valve, Hi - capacity (2 ton), O-Ring fittings 98370C3, RD-5-7015-0 RD-5-7015-0P 71R8321
All Series using Red Dot A/C unit R-10004-0,
Red Dot A/C unit R-10004-0, with female O-Ring RD-5-10447-0 RD-5-10447-0P 71R8405
OE#RD-5-10447-0
Challenger 1 35, 45, 55 Series with OE#362.761.0 Block valve, Hi - capacity (2 ton), O-Ring fittings 362.761.0, RD-5-7015-0 RD-5-7015-0P 71R8321
IT14G, IT28G Series using Red Dot A/C unit R-10046-0, Block valve with 1 1⁄2 ton Hi - cap, Female O-Ring, 5°F,
RD 4157 0, RD-5-6868-0 RD-5-6868-0P 71R8301
R-10047-0, OE#RD-5-6868-0 80psi@40°F
Large Haul Trucks with Red Dot A/C unit R-10235-3, -4 Block valve, Hi - capacity (2 ton), O-Ring fittings RD-5-7015-0 RD-5-7015-0P 71R8321
TH26, 63, 82, 83, 103 Series using Red Dot A/C unit Block valve with 1 1⁄2 ton Hi - cap, Female O-Ring, 5°F,
RD 4157 0, RD-5-6868-0 RD-5-6868-0P 71R8301
R-10170-0, OE#RD-5-6868-0 80psi@40°F
325 Series using Red Dot A/C unit R-10004-0,
Red Dot A/C unit R-10004-0, with female O-Ring RD-5-10447-0 RD-5-10447-0P 71R8405
OE#RD-5-10447-0
906 Series using Red Dot A/C unit R-10160-0, Block valve with 1 1⁄2 ton Hi - cap, Female O-Ring, 5°F,
RD 4157 0, RD-5-6868-0 RD-5-6868-0P 71R8301
OE#RD-5-6868-0 80psi@40°F
914G, 928G Series using Red Dot A/C unit R-10046-0, Block valve with 1 1⁄2 ton Hi - cap, Female O-Ring, 5°F,
RD 4157 0, RD-5-6868-0 RD-5-6868-0P 71R8301
R-10047-0, OE#RD-5-6868-0 80psi@40°F
950B - E, 966, 980A - C Series using Red Dot A/C unit Block valve with 1 1⁄2 ton Hi - cap, Female O-Ring, 5°F,
RD 4157 0, RD-5-6868-0 RD-5-6868-0P 71R8301
R-10044-3, OE#RD-5-6868-0 80psi@40°F
950F, 966F Series using Red Dot A/C unit R-10045-0, Red Dot A/C unit R-10045-0, 1 1⁄2 ton Hi - cap, Female O-Ring,
RD 4157 0, RD-5-6868-0 RD-5-6868-0P 71R8301
OE#RD-5-6868-0 5°F, 80psi@40°F
All Series with OE#1P6526 Main Unit, all models with #6, #8 male flare fitting, 18" tubes 1P6526 RD-4126-1P 71R8050
All Series with OE#2G0401 2G0401 RD-5-3824-1P 71R8100
length
Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube 2G0401, 3E9343, RD-5-
All Series with OE#2G0401, 3E9343, RD-5-5862-0 RD-5-5862-0P 71R8080
length 5862-0
Compactor 825B All models with #6, #8 male flare fitting, 18" tubes 1P6526 RD-4126-1P 71R8050
Loader 955L, 963LGP, 977L, 983B, 988 (late), 2G0401 RD-5-3824-1P 71R8100
length
Loader 980B, 988B (early), 992C All models with #6, #8 male flare fitting, 18" tubes 1P6526 RD-4126-1P 71R8050
Motor Grader 14G, 16G 2G0401 RD-5-3824-1P 71R8100
length
Skid Steer 225 (early) series All models with #6, #8 male flare fitting, 18" tubes 1P6526 RD-4126-1P 71R8050
Skid Steer 225 (late) series 2G0401 RD-5-3824-1P 71R8100
length
Track Type Tractor D6H, D6HLGP, D7G, D7H, D7HLGP, Male O-Ring with 13" capillary length, 13" equalizer tube
2G0401 RD-5-3824-1P 71R8100
D8K (late), D8N, D9N, D10, D11N length
Track Type Tractor D8K (early), D9H All models with #6, #8 male flare fitting, 18" tubes 1P6526 RD-4126-1P 71R8050
Wheel Dozer 824B All models with #6, #8 male flare fitting, 18" tubes 1P6526 RD-4126-1P 71R8050
Wheel Tractor Scraper 627B 2G0401 RD-5-3824-1P 71R8100
length
All Series with OE#RD-5-11033-0 Internal equalizer, 1 1⁄2 Ton, Male O-Ring RD-5-11033-0 RD-5-11033-0P 71R8060
All Series with OE#RD-5-10445-0 Internal equalizer, 1 1⁄2 Ton, Male O-Ring RD-5-10445-0 RD-5-10445-0P 71R8220
777 Series Large Haul Trucks, internal equalizer 168903C1, C91 RD-5-6099-0P 71R8210
fittings
PAGE 200
CATERPILLAR
EXPANSION
EXPANSION VALVE VALVE // EXTERNAL
ORIFICE TUBE EQUALIZER
Backhoe Loader 416D, 420D, 420 ID, 430D Aux. unit, Brown orifice tube RD-5-10013-0 RD-5-10013-0P 71R8506
Skid Steer A & B series Tier 2 using Red Dot A/C unit
Aux. unit, Brown orifice tube RD-5-10013-0 RD-5-10013-0P 71R8506
R-6500-1
Skid Steer A series Tier 2 using Red Dot A/C unit Aux. unit, Brown orifice tube with Assembly Housing RD-2-
RD-2-3901-0P RD-2-3901-0P 71R8600
R-6500-1 3856-0P
FILTER
Backhoe Loader 416D, 420D, 420D IT, 430D with OE Fresh air filter for Red Dot Unit R-3800-5,
1707272 RD-3-9805-0P 78R5243
#1707272 15 5⁄16" x 9 3⁄4" x 1⁄2"
Fresh air filter for Red Dot Unit R-9785-0,
Large Haul Truck 793, 797 RD-5-8668-0P 78R5318
15 3⁄4" x 7 7⁄8" x 2 1⁄4"
Skid Steer, A Series Tier 1 RD-5-10416-0P 78R5250
13 1⁄2" x 4 9⁄16" x 3⁄8"
Skid Steer, A Series Tier 2 RD-5-10416-0P 78R5250
13 1⁄2" x 4 9⁄16" x 3⁄8"
Skid Steer, B Series Tier II RD-3-10847-0P 78R5367
10 3⁄8" x 3 3⁄4" x 1"
Recirculating air filter, (filter foam) for Red Dot Unit R-6501-0,
Skid Steer, B Series Tier II RD-5-10687-0P 78R5313
10 3⁄8" x 3 1⁄4" x 3⁄8"
613C, 615C with panel filter, Cat OE#8P5142 Fresh air panel filter, 16 7⁄8" x 10" x 2 1⁄4" 8P5142 RD-5-6124-0P 78R5320
Fresh air panel filter for Red Dot Unit R-9785-0,
5130, 5230 with panel filter, Cat OE#8C4120 8C4120 RD-5-8668-0P 78R5318
15 3⁄4" x 7 7⁄8" x 2 1⁄4"
PRESSURE SWITCH
Large Haul Trucks with Red Dot A/C unit R-10235-3, -4 Binary 7⁄16"-20 UNF female, Schrader type valve RD 5 4640 0 RD-5-4640-0P 71R7050
Dual function switch (GM),
Open: low 20-33 psi, high 315-355 psi, RD-5-9577-0 RD-5-9577-0P 71R6150
Closed: low 23-37 psi, high 215-275 psi
TH26, 63, 82, 83, 103 Series using Red Dot A/C unit RD-5-8433-0, A22-36474-
Dual function switch (Fujikoki) with 7⁄16-20, 4 terminal RD-5-8433-0P 71R7075
R-10170-0, OE#RD-5-8433-0P 000
325 Series, Binary switch for models with Red Dot A/C
Binary 7⁄16"-20 UNF female, Schrader type valve RD 5 4640 0 RD-5-4640-0P 71R7050
unit R-10004-0
914G, 928G Series using Red Dot A/C unit R-10046-0,
R-10047-0, OE#RD 5 4640 0
950B - E, 966, 980A - C Series using Red Dot A/C unit RD-5-8433-0, A22-36474-
R-10044-3, OE#RD-5-8433-0P 000
950F, 966F Series using Red Dot A/C unit R-10045-0, RD-5-8433-0, A22-36474-
OE#RD-5-8433-0 000
RECEIVER DRIER
All Series with in-line drier with quick disconnect, Cat
In-line, quick disconnect, 2 1⁄2" x 13 7⁄8" 3E3535 RD-5-8605-0P 74R0470
OE#3E3535
All Series with drier, Cat OE#088209-02, 106-5534, #6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
RD-5-5955-0P 74R3516
5V5698 moisture indicator 5V5698
All Series with drier, Cat OE#106-5532, 106-5533, #6 Male O-Ring, 4" x 7 3⁄4", low pressure switch, moisture 106-5532, 106-5533,
RD-5-7564-0P 74R3526
8T8642, 9W0549 indicator 8T8642, 9W0549
All Series with 4" drier, Cat OE#6P1309 #6 Male Flare, 4" x 7 ⁄4", fuse
3
6P1309 RD-5-5954-0P 74R3506
#6 Male O-Ring in, #6 Female O-Ring out, pressure relief, metric
Challenger 1 35, 45, 55 Series with OE#362.761.0 362.761.0 RD-5-10586-0P 74R3330
ports
D10N, D16H Series with in-line drier with quick
disconnect, Cat OE#3E3535
IT14G, IT28G Series using Red Dot A/C unit R-10046-0,
#6 Male O-Ring, 2 1⁄2" x 7 11⁄16", 1⁄4" male side port 088273-00 RD-5-7559-0P 74R1106
R-10047-0, OE#088273-00
TH26, 63, 82, 83, 103 Series using Red Dot A/C unit
In-line, #6 Male O-Ring, 2 1⁄2" x 9 9⁄16" 088411-01 RD-5-7064-0P 74R0460
R-10170-0, OE#088411-01
Large Haul Trucks with Red Dot A/C unit R-10235-3, -4 #6 Male O-Ring, 2 3⁄4" x 9 5⁄8", hi capacity, pressure relief RD-5-7062-1 RD-5-7062-1P 74R1826
Large Haul Trucks 77 Series with Red Dot A/C #6 Male O-Ring, 3" x 6 ⁄4", hi capacity, pressure relief
1
RD-5-3843-0 RD-5-3843-0P 74R2556
PAGE 201
CATERPILLAR
RECEIVER DRIER
Loader 955L, 977L, 983B, 988B (early) series with 4"
#6 Male Flare, 4" x 7 3⁄4", fuse 6P1309 RD-5-5954-0P 74R3506
drier, Cat OE#6P1309
Loader 963LGP Series with Red Dot A/C #6 Male O-Ring, 3" x 6 1⁄4", hi capacity, pressure relief RD-5-3843-0 RD-5-3843-0P 74R2556
Loader 988B (late), 992C series with 4" drier, Cat #6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
RD-5-5955-0P 74R3516
OE#088209-02, 106-5534, 5V5698 moisture indicator 5V5698
Motor Grader 14G, 16G Series with Red Dot A/C #6 Male O-Ring, 3" x 6 1⁄4", hi capacity, pressure relief RD-5-3843-0 RD-5-3843-0P 74R2556
O-Ring Type with Fuse Plug & Charge Port 088193-03 RD-5-9515-0P 74R2676
Skid Steer 235 (early), 255 (early) series with 4" drier,
Cat OE#6P1309
Skid Steer 235 (late), 255 (late) series with drier, Cat #6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
RD-5-5955-0P 74R3516
Track Type Tractor D7G, D8N, D9L, D9L (early), D9N,
#6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
D11, D11N Series with drier, Cat OE#088209-02, 106- RD-5-5955-0P 74R3516
moisture indicator 406217, 5V5698
5534, 406217, 5V5698
Tract Type Tractor D8K, D9H Series with 4" drier, Cat
OE#6P1309
Track Type Tractor D9N Series, Cat OE#106-5532, 106- #6 Male O-Ring, 4" x 7 3⁄4", low pressure switch, moisture 106-5532, 106-5533,
RD-5-7564-0P 74R3526
5533, 8T8642, 9W0549 indicator 8T8642, 9W0549
Track Type Tractor D9N Series with Red Dot A/C #6 Male O-Ring, 4" x 7 1⁄2", fuse, side port, moisture indicator RD-5-7565-0 RD-5-7565-0P 74R3536
Track Type Tractor D10 Series with Red Dot A/C #6 Male O-Ring, 3" x 6 1⁄4", hi capacity, pressure relief RD-5-3843-0 RD-5-3843-0P 74R2556
Track Type Tractor 235, 255, 637D, 988B, 992, 994
#6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
Series with drier, Cat OE#088209-02, 106-5534, RD-5-5955-0P 74R3516
moisture indicator 406217, 5V5698
406217, 5V5698
Wheel Tractor Scraper 627B series with 4" drier, Cat
OE#6P1309
Wheel Tractor Scraper 637D series with drier, Cat #6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
RD-5-5955-0P 74R3516
Wheel Tractor Scraper 637E series with drier,
#6 Male O-Ring, 3" x 6 1⁄4", hi capacity, pressure relief RD-5-3843-0 RD-5-3843-0P 74R2556
OE#RD-5-3843-0
235, 255, 627D, 955L Series with 4" drier, Cat
OE#6P1309
235, 255, 637D, 988B, 992, 994 Series with drier, Cat #6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, 088209-02, 106-5534,
RD-5-5955-0P 74R3516
OE#088209-02, 106-5534, 406217, 5V5698 moisture indicator 406217, 5V5698
325 Series using Red Dot A/C unit R-10004-0, Cat
#6 Male O-Ring, 2 3⁄4" x 10", without binary switch 712-225, RD-5-5572-0 RD-5-5572-0P 74R1856
OE#712-225
906 Series using Red Dot A/C unit R-10160-0, Cat
Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" 088423-00, RD-5-7061-1 RD-5-7061-1P 74R2536
OE#088423-00
914G, 924G, 950F, 950G, 980F, 980G Series with in-line
drier with quick disconnect, Cat OE#3E3535
#6 Male O-Ring, 2 1⁄2" x 7 11⁄16", 1⁄4" male side port 088273-00 RD-5-7559-0P 74R1106
R-10047-0, OE#088273-00
950B - F, 966, 966F, 980A - C Series using Red Dot A/C
unit R-10044-3, OE#088411-01
992, 994 Series, Cat OE#106-5532, 106-5533, 8T8642, #6 Male O-Ring, 4" x 7 3⁄4", low pressure switch, moisture 106-5532, 106-5533,
RD-5-7564-0P 74R3526
9W0549 indicator 8T8642, 9W0549
3E0443, 106-1018, 101-
All Series with accumulator, Caterpillar OE#101-8789 Main Unit with Accumulator, female O-Ring, 3 1⁄2" x 9 1⁄2" RD-5-10927-0P 74R5061
8789, 151-5261
Challenger 1 35, 45, 55 Series with OE#RD-5-4961-0P Universal Accumulator (GM Style) 3 1⁄2" x 8" 15-1274, 849748, 3012944 RD-5-4961-0P 74R5050
D10N, D16H Series with accumulator, Cat OE#3E0443, 3E0443, 106-1018, 101-
Main Unit with Accumulator, female O-Ring, 3 1⁄2" x 9 1⁄2" RD-5-10927-0P 74R5061
106-1018, 101-8789, 151-5261 8789, 151-5261
914G, 924G, 950F, 950G, 980F, 980G Series
3E0443, 106-1018, 101-
accumulator, Cat OE#3E0443, 106-1018, 101-8789, Main Unit with Accumulator, female O-Ring, 3 1⁄2" x 9 1⁄2" RD-5-10927-0P 74R5061
8789, 151-5261
151-5261
PAGE 202
CATERPILLAR
RECEIVER
RESISTOR DRIER
Skid Steer, A series Tier I & II, with Red Dot model
R-6500, R-6500-1
Skid Steer, B series Tier II, with Red Dot model R-295- Blower Resistor, Red Dot A/C units. Used on RD-5-8837-0P
RD-5-9447-0 RD-5-9447-0P 71R1403
0, R-9750 Blower Assembly
Ceramic tube style resistor, 4 terminal, 12V, 6 1⁄2" length x 1 3⁄16"
Large Haul Truck 793, 797 series for Red Dot models RD-5-8665-0 RD-5-8665-0P 71R1485
diam
Ceramic style resistor RD-5-10028-0P RD-5-10028-0P
R-9789-0, -1
THERMOSTATIC SWITCH
All series with OE#2G0398 Rotary thermostat with 48" capillary tube, 34 - 52°F 2G398 RD-4125-48P 71R2300
2P4338, 6K9614, 6T9395,
All series with OE#2P4338, 6K9614, 6T9395, 8P5346,
Rotary thermostat, 36" capillary tube, 34 - 52°F 8P5346, 8P5349, 8P5350, RD-4125-36P 71R2250
8P5349, 8P5350, 9P3498
9P3498
Backhoe Loader 416D, 420D, 420D IT, 430D with Fixed Setting thermostat with 24" capillary tube, flange/side
RD-5-4531-24 RD-5-4531-24P 71R3200
OE#RD-5-4531-24 mt.
Rotary thermostat with 36" capillary tube, 34 - 52°F, clutch
Compactor 825B with Red Dot A/C, OE#RD-4125-36P RD-4125-36P RD-4125-36P 71R2250
cycle range 5°
IT14G, IT28G Series using Red Dot A/C unit R-10046-0,
Fixed Setting thermostat with 16" capillary tube, flange mt. RD-5-6429-0P RD-5-6429-0P 71R3150
R-10047-0, OE#RD-5-6429-0P
Large Haul Trucks with Red Dot A/C unit R-10235-3, -4,
OE#RD-5-6429-0
Large Haul Trucks 777 Series with Red Dot A/C,
Cable controlled thermostat, 30" capillary tube, 34 - 54°F RD-4226-0P RD-4226-0P 71R2700
OE#RD-4226-0P
Fixed Setting thermostat with 33" capillary tube, flange mt.,
Large Haul Trucks 793, 797 with OE#RD-5-8377-0 RD-5-8377-0 RD-5-8377-0P 71R3125
40 - 85°F
Loader 955L, 977L, 983B, 988B (early-late), 992C with Rotary thermostat with 36" capillary tube, 34 - 52°F, clutch
RD-4125-36P RD-4125-36P 71R2250
Red Dot A/C, OE#RD-4125-36P cycle range 5°
Motor Grader 14G, 16G Series with Red Dot A/C,
Cable controlled thermostat, 30" capillary tube, 34 - 54°F RD-4226-0P RD-4226-0P 71R2700
OE#RD-4226-0P
Fixed Setting thermostat with 33" capillary tube, flange mt.,
Motor Grader 24H, OE#RD-5-8377-0 RD-5-8377-0 RD-5-8377-0P 71R3125
40 - 85°F
Skid Steer A series Tier II with Red Dot A/C unit R-6500,
Thermistor, 12V fits Red Dot A/C unit R-6500 RD-5-10239-0 RD-5-10239-0P 71R3540
OE#RD-5-10239-0
Skid Steer A and B, B series II with Red Dot R-10050, Fixed Setting thermostat with 24" capillary tube, flange/side
RD-5-4531-24 RD-5-4531-24P 71R3200
R-10050-1 model evaporator, OE#RD-5-4531-24 mt.
Small Track Type Tractor D3, D4, D5 with Fixed Setting thermostat with 33" capillary tube, flange mt.,
RD-5-8377-0 RD-5-8377-0P 71R3125
OE#RD-5-8377-0 40 - 85°F
TH26, 63, 82, 83, 103 Series using Red Dot A/C unit
Fixed Setting thermostat with 24" capillary tube, flange mt. RD-4427-24 RD-4427-24P 71R3100
R-10170-0, OE#RD-4427-24
Tract Loader 963LGP with Red Dot A/C, OE#RD-4125- Rotary thermostat with 36" capillary tube, 34 - 52°F, clutch
RD-4125-36P RD-4125-36P 71R2250
36P cycle range 5°
Tract Type Tractor D6H, D6HLGP, D7G, D7H, D7HLGP,
Rotary thermostat with 36" capillary tube, 34 - 52°F, clutch
D8K, D8N, D9H, D9L (early) with Red Dot A/C, OE#RD- RD-4125-36P RD-4125-36P 71R2250
cycle range 5°
4125-36P
Wheel Tractor Scraper 627B, 637D with Red Dot A/C, Rotary thermostat with 36" capillary tube, 34 - 52°F, clutch
RD-4125-36P RD-4125-36P 71R2250
OE#RD-4125-36P cycle range 5°
325 Series with Red Dot A/C unit R-10004-0, Fixed Setting thermostat with 24" capillary tube, flange/side
RD-5-4531-24 RD-5-4531-24P 71R3200
OE#RD-5-4531-24 mt.
906 Series with Red Dot A/C unit R-10160-0, Fixed Setting thermostat with 24" capillary tube, flange/side
RD-5-4531-24 RD-5-4531-24P 71R3200
OE#RD-5-4531-24 mt.
R-10047-0, OE#RD-5-6429-0P
950B - F, 966, 966F, 980A - C Series using Red Dot A/C Rotary thermostat, 27" capillary, 34°-52°F, clutch cycle range
RD-4172-0 RD-4172-0P 71R2310
unit R-10044-3, OE#RD-4172-0 5°F
PAGE 203
CATERPILLAR
THERMOSTATIC SWITCH
950F, 966F Series using Red Dot A/C unit R-10045-0, Fixed setting thermostat with 24" capillary tube, flange/side
RD-5-4531-24P RD-5-4531-24P 71R3200
OE#RD-5-4531-24P mt.
WATER VALVE
All Series with OE#3P7994, 7G-8699 Cable operated valve, straight (pull to open), 5⁄8" to 5⁄8" hose 3P7994, 7G-8699 RD-5-4257-0P 72R5050
D4E, D5B, D5H, D6D, D7G, D8K, D9H Cable operated valve, straight (pull to open), 5⁄8" to 5⁄8" hose 7G-8699 RD-5-4257-0P 72R5050
Large Haul Trucks 793, 797 with OE#RD-5-8894-0 Cable operated valve, (pull to open), 5⁄8" to 5⁄8" hose RD-5-8894-0 RD-5-8894-0P 72R6535
Motor Grader 24H Series with OE#RD-5-8390-0 Cable operated valve RD-5-8390-0 RD-5-8390-0P 72R6525
Skid Steer A series Tier 1, II with Red Dot A/C unit, Cable operated with stem water control valve, (pull to close),
RD-5-10635-0P RD-5-10635-0P 72R5204
OE#RD-5-10635-0 5
⁄8" to 3⁄4" hose
Skid Steer B series Tier II with Red Dot A/C unit, Cable operated with stem water control valve, (pull to close),
RD-3-11046-0 RD-3-11046-0P 72R5203
OE#RD-3-11046-0 5
⁄8" to 3⁄4" hose
Small Track Type Tractor D3, D4, D5 with
Cable operated valve, straight (pull to open), 5⁄8" to 5⁄8" hose RD-5-10055-0 RD-5-10055-0P 72R6547
OE#RD-5-10055-0
215, 225, 235, 245, 615, 613B, 613C, 621, 621B, 623B,
627B, 631D, 633D, 637D, 639D, 943, 953, 955L, 963, Cable operated valve, straight (pull to open), 5⁄8" to 5⁄8" hose 7G-8699 RD-5-4257-0P 72R5050
977L, 983B973,
CRENLO/NEW HOLLAND
BLOWER MOTOR
Genesis Tractor 8670, 8770, 8870, 8970 Series with Red Blower assembly, single speed, 800 CFM, 12V, 18 7⁄16" x 3" x 6
RD-3-6770-0 RD-3-6770-0P 73R5502
Dot A/C units, OE#RD-3-6770-0P 21
⁄32"
COMPRESSOR - SANDEN
Genesis Tractor 8670, 8770, 8870, 8970 Series 24V
7H15FLX, GV head, ear mount, poly 8, 5 1⁄4"(133mm) diameter 4874 RD-5-11005-0P 75R89434
Sanden 7H15FLX, OE #4874.
EVAPORATOR
Genesis Tractor 8670, 8770, 8870, 8970 Series with Red
Dimensions: 6 7⁄64" height x 23 1⁄2" length x 3 13⁄32" width RD-2-3629-0 RD-2-3629-0P 76R7725
Dot A/C R-3960-2 unit
HEATER CORE
PRESSURE SWITCH
Genesis Tractor 8670, 8770, 8870, 8970 Series with
Low pressure switch, normally opens 15 psi, closes 35 psi RD-5-7038-0 RD-5-7038-0P 71R6135
Red Dot A/C
Binary 7⁄16"-20 UNF female, Schrader type valve RD 5 4640 0, 61522-006 RD-5-4640-0P 71R7050
Binary switch for Red Dot A/C
RECEIVER DRIER
O-Ring Type with side port, top glass, moisture indicator 221RD32 RD-5-7272-0P 74R2546
Red Dot A/C
THERMOSTATIC SWITCH
Red Dot Models, fixed setting thermostat, 24" cap tube RD-5-4531-24 RD-5-4531-24P 71R3200
DEUTZ-ALLIS
BLOWER MOTOR
275130, HA1520,
All series with Kysor A/C, OE#003-3938 Bergstrom - Kysor A/C, single shaft, 1 speed, CW, 4 5⁄8" length RD-5-10905-0P 73R0442
BSM205620
Air Planter 385 Series with Red Dot A/C, OE#431-7737 Main unit (Red Dot) with single shaft, 4 3⁄4" length 431-7737 RD-5-6526-0P 73R0422
Tractor D Series 5600, 6600 condenser blower, Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW,
70257681-0, HV33208 RD-5-3690-0P 73R0502
OE#70257681-0, HV33208 4 7⁄8" length
Tractor D Series 6200 evaporator blower, 205840, BSM203085,
Kysor A/C, double shaft motor, 1 speed, 4 7⁄8" length RD-5-10068-0P 73R4322
OE#70257681-0, HV33209 2809-551-007
PAGE 204
DEUTZ-ALLIS
RECEIVER DRIER
BLOWER SWITCH
Bergstrom - Kysor A/C, tandem blower switch, DP3T, 4 position,
All series with tandem blower switch, Kysor A/C RD-5-4908-0P 71R1200
5 terminal, 15 amps
All series with rotary blower switch with resistor,
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 586082, 1175262-3 RD-5-5194-0P 71R1210
OE#586082
All series with rotary blower switch without resistor Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 71195109 RD-5-10934-0P 71R1163
CLUTCH ASSEMBLY
All series with CCI/York - R12 / 134A compressors,
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug 003-3938 RD-5-4967-0P 75R0452
OE#003-3938
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 003-4530 RD-5-4994-0P 75R4502
OE#003-4530
All series with Sanden SD5 (5H14) R12/R134a
2 groove 5 1⁄4" diameter, 1⁄2" width, (132mm), 1 wire plug 6585-6010 RD-5-10379-0P 75R1542
compressors, OE#6585-6010
All series with Sanden SD5 (508) R12/R134a
compressors, OE#8517-6010
All series with CCI/York Tecumseh Rotolock ER, 79007020-5, 79007021-3,
R210L-25149, OE#79007020-5, 79007021-3 ER, R210L- 25149
All series with CCI/York - Tube O-Ring compressor
ET210L-25150
COMPRESSOR - GM
0256782, 70264637,
All series with GM A6 with Superheat switch port, 70272975-6, 70272976-5,
1 groove ⁄2" width, 4 ⁄8" diameter (124mm), generic
1 7
RD-5-5000-0P 75R8102
without oil, replaces OE#s shown 70272981,
79008037-8
COMPRESSOR - SANDEN
All series with Sanden 7H15, #4644 R134a compressor
7H15, JD head, ear mount 2 groove, 5 1⁄4"(132mm) diameter 72239750, 4644 RD-5-10297-0P 75R84612
with PAG oil, OE#72239750
compressors, 24V
SD508, B head, Ear mount, flare fittings, 2A groove, 5
All series with Sanden SD508 #8390 with flare fittings 1 8390 RD-5-5199-0P 75R8282
⁄4"(132mm) diameter
All series with Sanden 510-HD, #9103, R12 with
All series with Sanden 508, OE#9285 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, LE1015, LE1050 RD-5-5575-0P 75R8292
AGRO Star series 8360 with Sanden 508, OE##9285 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, LE1015, LE1050 RD-5-5575-0P 75R8292
D Series 5600, 8500 with Sanden 508, OE##9285 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, LE1015, LE1050 RD-5-5575-0P 75R8292
8600, 9800 series with Sanden 508, OE##9285 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, LE1015, LE1050 RD-5-5575-0P 75R8292
All combine and tractor model series with block valve,
Block valve with female O-Ring fittings 329-413 RD-5-7015-0P 71R8321
2 Ton, OE#329-413
Block valve with female O-Ring fittings 72162195 RD-5-6868-0P 71R8301
OE#72162195
All combine and tractor model series with Kysor A/C
block valve, OE#71307202
Tractors 7085, 7110, 7120, 7145 Series with
OE#04322165
Tractors 8600 Series with OE#04322165 Block valve with female O-Ring fittings 04322165 RD-5-6868-0P 71R8301
Tractors 9150, 9170, 9190, 9800 Series with
OE#04322165
PAGE 205
DEUTZ-ALLIS
COMPRESSOR
EXPANSION VALVE - SANDEN / EXTERNAL EQUALIZER
All combine and tractor model series with external
Male flare with 18" capillary length, 18" equalizer tube length 003-4238, RD 4126 1 RD-4126-1P 71R8050
equalizer, OE#003-4238
All combine and tractor model series with external Male O-Ring with 13" capillary length, 13" equalizer tube
003-4586 RD-5-3824-1P 71R8100
equalizer, OE#003-4586 length
All combine and tractor model series with external Male O-Ring with 13" capillary length, 13" equalizer tube
70259978 RD-5-3824-1P 71R8100
equalizer, OE#70259978 length
All combine and tractor model series with external Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
826-003 RD-5-5862-0P 71R8080
equalizer, OE#826-003 length
Tractors DX Series DX90, DX160 with male O-Ring Male O-Ring with 13" capillary length, 13" equalizer tube
RD-5-3824-1 RD-5-3824-1P 71R8100
fittings length
Tractors 6240, 6250, 6260, 6265, 6275 Series with Male O-Ring with 13" capillary length, 13" equalizer tube
RD-5-3824-1 RD-5-3824-1P 71R8100
male O-Ring fittings length
Tractors 8560 Series with male O-Ring fittings RD-5-3824-1 RD-5-3824-1P 71R8100
length
All combine and tractor model series with Internal equalizer with male flare with 9" capillary length, flare
1162473-1 RD-5-6099-0P 71R8210
OE#1162473-1 fittings
All combine and tractor model series with OE#826-004 Internal equalizer, 1 ⁄2 Ton, Male O-Ring
1
826-004 RD-5-10445-0P 71R8220
PRESSURE SWITCH
All series using high pressure switch, OE#432-2167, High Pressure Switch, normally closed 210psi, opens 340 psi, 1⁄4"
432-2167, 111266C1 RD-5-5873-0P 71R6070
111266C1 female flare
All series, low pressure cut-off, drier mounting Low pressure cut out switch, 3⁄8"-24, norm. open, closes 27 psig 085108-00, 72162165-4 RD-4191-0P 71R6050
RECEIVER DRIER
Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" 003-4228, 088423-00 RD-5-7061-1P 74R2536
4228, 088423-00
All combine and tractor model series with in line drier, 70268464, 70264644-6,
In Line drier with #6 Female to Male O-Ring, 4" x 8" RD-5-8862-0P 74R0400
OE#70268464, 70264644-6, 70275847 70275847
with #6 Male flare, 3" X 6 1⁄4" 70272317 RD-5-4954-0P 74R2406
OE#70272317
Male & Male O-Ring HPRV, MI IN CAP 70276903 RD-5-5583-0P 74R2606
OE#70276903
with #6 Male O-Ring, 3" X 8 1⁄4", top port, schrader ports 71355100 RD-5-10777-0P 74R2616
OE#71355100
Male & Male O-Ring with Fuse Plug, Low Pressure Switch 72161835-3 RD-4160-1P 74R2106
OE#72161835-3
Male inlet, Female outlet with 2 M10 Ports 72275275 RD-5-10735-0P 74R3156
OE#72275275
Male O-Ring with fuse plug, side port, top glass 72502208 RD-5-4950-0P 74R0906
OE#72502208
Tractor AGRO-Star Series 8360, 8425 with #6 Male O-Ring, 2 3⁄4" X 9 5⁄8" RDH RD5 5571 0 RD-5-5571-0P 74R1806
Tractor D series with in line drier, OE#70268464, 70268464, 70264644-6,
In Line drier with #6 Female to Male O-Ring, 4" x 8" RD-5-8862-0P 74R0400
70264644-6, 70275847 70275847
Tractor 8600, 9400, 9600, 9800 Series with #6 Male O-Ring, 2 3⁄4" X 9 5⁄8" RDH RD5 5571 0 RD-5-5571-0P 74R1806
Tractor 9700 Series with #6 Male O-Ring, 3" x 6 1⁄4" RD-5-7061-2 RD-5-7061-2P 74R2526
THERMOSTATIC SWITCH
4221
OE#70268476-9
PAGE 206
EUCLID
BLOWER MOTOR
Haul Truck series with Bergstrom A/C, Euclid
Bergstrom A/C, 24V single shaft motor, 1 speed, CCW, 5" length 20333P RD-5-4827-24P 73R0404
OE#20333P
ELECTRICAL SWITCH
9
Haul Truck series with block valve Block valve with female O-Ring fittings RD-5-6868-0P 71R8301
RECEIVER DRIER
Haul Truck series with receiver drier with #6 Male O-Ring, 3" X 9 1⁄4", side port, pressure relief RD-5-5588-0P 74R3056
FORD - NEW HOLLAND (FNH)

BLOWER MOTOR
All model series with FNH OE#271438 271438 RD-5-4550-0P 73R0102
length
CLUTCH ASSEMBLY
All series with CCI/York - R12 / 134A compressors, FNH
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug D5NN19D649A RD-5-4967-0P 75R0452
OE#D5NN19D649A
All series with CCI/York - R12 / 134A compressors, FNH
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug D2NN19D649AA RD-5-4994-0P 75R4502
OE#D2NN19D649AA
All series with Sanden SD508 R12/R134a compressor,
Sanden OE#6514-6210
All series with Sanden SD7H15HD R134a compressor,
OE #6504-6310
Combines TR70, TR75, TR76 with R210 series CCI/York 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
compressors plug 501939
Combines TR85, TR86, 87, 96, 97 with Sanden SD5 (508
/ 510 / 5H14) compressors
FW Series (except FW20) with Sanden SD510
1 groove 6 1⁄4" diameter pulley, 1⁄2 -3⁄4" width, bullet plug 6521-6010 RD-5-5489-0P 75R1402
compressor
FW Series including FW20 with Sanden SD508
compressor
Harvester / Balewagon 1038, 1078, 1079, 1085 with
R210 series CCI/York compressor
Harvester / Balewagon 1038, 1078, 1079, 1085 with 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
R210 series CCI/York compressor plug 501939
Harvester / Balewagon 1915, 2115 with Sanden SD5
(508 / 510 / 5H14) compressors
Harvester / Balewagon 1915, 2115 with CCI/York 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
Power Shift 8630, 8730, 8830 with R210L series CCI/ 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
York compressors plug 501939
Swathers / Windrowers 1118, 2450, 2550 with Sanden
SD5 (508 / 510 / 5H14) compressors
Swathers / Windrowers 1118, 2450, 2550 with CCI/ 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
Swathers / Windrowers 4750, 4850 with Sanden SD5
510 compressor, OE#9125
Tractor 230A, 233, 234, 333, 334, 355 with Sanden SD5
510 compressor
Tractor 1150, 1151, 1156 Versatile with Sanden SD5 510
compressor, OE#5733
Tractor 530A, 555A, 655A with T210 series CCI/York 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
PAGE 207

CLUTCH ASSEMBLY
Tractor 800-900 Series Versatile with Sanden SD5 510
compressor, OE#5733
Tractor 800-900 Series Versatile with T210 series CCI/ 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
Tractor 5000-8000 series with Sanden SD5 508
compressor
Tractor 5000-8000 series with R210 series CCI/York
compressor
Tractor 5610, 6610, 7610, 8210 series with Sanden SD5
510 compressor
Tractor 9000 series (except 9030) with R210 series CCI/
York compressor
Tractor 9030 series with Sanden SD7H15 compressor 2 groove 5 1⁄4" diameter, 1⁄2" width, (132mm), 1 wire plug 6574-6210, 6514-6210 RD-5-5486-0P 75R0202
TW series with R210 series CCI/York compressor 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug D5NN19D649A RD-5-4967-0P 75R0452
TW series with Sanden 5H14 compressor, OE#4536,
5708
All series with CCI/York Tecumseh Rotolock ER, EJPN19D623AA, ER, R210L-
R210L-25149, OE#EJPN19D623AA 25149
ET210L-25150
All series with CCI/York Tecumseh Rotolock OE#99242-
5, R12 or 134a (ester oil)
All series with CCI/York - Tube O-Ring compressor,
OE#99244-5, R12 / 134A
Combines TR70, TR75, TR76 with CCI/York Tecumseh ER, R210L- 25149,
Rotolock ER, R210L-25149, OE#EJPN19D623AA EJPN19D623AA,
Power Shift 8630, 8730, 8830 with CCI/York Tecumseh EJPN19D623AA, ER, R210L-
Rotolock ER, R210L-25149, OE#EJPN19D623A 25149
Tractors TW series with CCI/York Tecumseh Rotolock
ER, R210L-25149
COMPRESSOR - SANDEN
All series with Sanden 7H15HD, #4603. FNH
7H15, WJ head, ear mount 2 groove, 5 1⁄4"(132mm) diameter 9849085, 4603 RD-5-11241-0P 75R81192
OE#9849085
7H15, MD head, ear mount 2 groove, 6" (152mm) diameter 86993462, 4609 RD-5-10259-0P 75R84112
OE#86993462
All series with Sanden 7H15HD, #4617 R134a
Sanden 7H15SHD, MD head, ear mt., 2 goove, 5 1⁄4" (132mm) 86001191, 97005764, 4617 RD-5-10291-0P 75R84532
compressor, OE#86001191, 97005764
7H15HD, KC head, ear mount poly 8, 5 1⁄4"(133mm) diameter 9824775, 4637 RD-5-6919-0P 75R84522
compressor, OE#9824775
All series with Sanden 7H15, #4643 R134a compressor,
Sanden 7H15, CB head, ear mt., 2 goove, 5 1⁄4" (132mm) 9705764, 4643 RD-5-10292-0P 75R84552
OE#9705764
7H15, MD head, direct mount poly 8, 6" (152mm) diameter 86993463, 4768 RD-5-11311-0P 75R81412
OE#86993463
5H14HD, K head, ear mount 2 groove, 5 1⁄4"(132mm) diameter E8NN19D629AA, 5708 RD-5-9088-0P 75R8332
compressor, OE#E8NN19D629AA
All series with Sanden 5H14, #6665, 24V 5H14HD, 24V, FL head, 2A groove, 5 1⁄4" (132mm) diameter 6665 RD-5-7089-0P 75R8384
All series with Sanden 510HD, #9103, R-12 with
All series with Sanden 508HD, #9285, R-12 with
All series with Sanden 510-HD, #9674, 24V, R-12 with
PAGE 208

COMPRESSOR - SANDEN
with charge ports
All series with Sanden 7H15, R134a compressor with 86508521, 9822598,
7H15, JD head, ear mount 2 groove, 5 1⁄4"(132mm) diameter RD-5-10297-0P 75R84612
PAG oil, OE#86508521, 9822598, D6NN19D629A D6NN19D629A
Combines TR85, TR87, TR96, TR97 with Sanden 508HD,
#9285, R12 compressor
Combines TR88, TR89 with Sanden 5H14, #6629 R-12
5H14HD, FL head, ear mount poly 7, 4.7"(119mm) diameter 6629 RD-5-10293-0P 75R83172
compressor
Power Shift 8630, 8730, 8830 with Sanden 7H15, OE
7H15, KG head, ear mount, 2A groove, 4.9"(125mm) diameter 4709, 7862, 8023 RD-5-11331-0P 75R81552
#4709, 7862, 8023
Tractors Gemini 8160, 8260, 8360, 8560 with Sanden
7H15, JDA head, ear mount, poly 8, 4 3⁄4" (119mm) diameter 4660, 4711, 7890, 8028 RD-5-11322-0P 75R81482
7H15, OE#4660.
Tractors Gemini 8670, 8770, 8870, 8970 with Sanden
7H15HD, KC head, ear mount poly 8, 5 1⁄4"(133mm) diameter 9824775, 4637 RD-5-6919-0P 75R84522
7H15HD, #4637 R134a compressor, OE#9824775
Tractors TL70, TL80, TL90, TL100 with Sanden 5H14,
#4644 compressor, OE#72239750
Tractors TM115-190 with Sanden 7H15, OE #4660 7H15, JDA head, ear mount, poly 8, 4 3⁄4" (119mm) diameter 4660 RD-5-11322-0P 75R81482
Tractors TN55, TN65, TN70, TN75 with Sanden 5H14,
5H14, M head, ear mount, 2A groove, 5 1⁄4" (132mm) diameter 6631 RD-5-7548-0P 75R8312
OE#6631
Tractors TN90F with Sanden 7H15, #4644 R134a
compressor with PAG oil, OE#72239750
Tractors TS90, TS100, TS120, TV140 Bidirectional with
7H15, JDA head, ear mount, poly 8, 4 3⁄4" (119mm) diameter 4660 RD-5-11322-0P 75R81482
Sanden 7H15, OE #4660
Tractors TW with Sanden 5H14HD, #5708 compressor,
5H14HD, K head, ear mount 2 groove, 5 1⁄4"(132mm) diameter E8NN19D629AA, 5708 RD-5-9088-0P 75R8332
OE#E8NN19D629AA
Block valve with female O-Ring fittings 329-403, 329-413 RD-5-7015-0P 71R8321
2 Ton, OE#329-403, 329-413
Combine / Tractor P396 Series Block valve with female O-Ring fittings 3901517M1 RD-5-7015-0P 71R8321
Combine TR86, TR96, TR97, TR98 model series with
Block valve with female O-Ring fittings with 7⁄16" schrader port 404146 / EA1090 RD-5-7155-0P 71R8400
OE#847015
Combine TR89, TR99 model series with OE#847015 Block valve with female O-Ring fittings with 7⁄16" schrader port 404146 / EA1090 RD-5-7155-0P 71R8400
Harvesters / Balewagons 1915, 2115 model series with
OE#847015
Swathers / Windrowers 1118, 2450, 2550 model series
with OE#847015
Tractors D6 Series, OE#79840, E1NN-19849A Block valve with female O-Ring fittings 79840, E1NN-19849A RD-5-6868-0P 71R8301
Tractors 836, 846, 856, 876, 936, 946, 956, 976, 1156
Block valve with female O-Ring fittings 79840, E1NN-19849A RD-5-6868-0P 71R8301
Versatile Series, 2310 with OE#79840, E1NN-19849A
Tractors 2610, 2910 with OE#97005763 Block valve with female O-Ring fittings 97005763 RD-5-6868-0P 71R8301
All combine and tractor model series with OE#826-003 826-003 RD-5-5862-0P 71R8080
length
All combine and tractor model series with OE#826-081 External Equalizer, Male flare with 18" capillary length 826-081 RD-4126-1P 71R8050
All combine and tractor model series with External Equalizer, Male O-Ring with 13" capillary length, 13"
9966611 RD-5-3824-1P 71R8100
OE#9966611 equalizer tube length
Combine TR70, TR75, TR85 model series with
External Equalizer, Male flare with 18" capillary length 274571 RD-4126-1P 71R8050
OE#274571
Combine TR70, TR75, TR85, TR86, TR96, TR97, TR98 External Equalizer, Male O-Ring with 13" capillary length, 13"
80449624 RD-5-3824-1P 71R8100
model series with OE#80449624 equalizer tube length
Harvesters / Balewagons 1038, 1078, 1079, 1085
model series with OE#274571
Swathers / Windrowers 1118, 2450, 2550 model series
with OE#247571
PAGE 209

Swathers / Windrowers 4750, 4850 model series with
OE#247571
Tractors FQ 20, 30, 40, 60 model series with OE#D3AH-
External Equalizer, Male flare with 18" capillary length D3AH-18949AA RD-4126-1P 71R8050
18949AA
External Equalizer, Male O-Ring with 13" capillary length, 13"
Tractors FX 20, 30, 40, 60 model series RD-5-3824-1P 71R8100
equalizer tube length
External Equalizer, Male O-Ring, 1 1⁄2 Ton, 10" capillary length,
Tractors TW 10, 15, 20, 25, 30, 35 Series RD-5-5862-0P 71R8080
10" equalizer tube length
Tractors TW 10, 20, 30 model series with OE#D3AH-
18949AA
Tractors 2600, 3600, 4100, 4600, 5600, 6600 Series, External Equalizer, Male O-Ring with 13" capillary length, 13"
E7NN-19849A, 80449624 RD-5-3824-1P 71R8100
with OE#E7NN-19849A equalizer tube length
Tractors 5610, 6610, 7610, 7710, 8210 Series, with External Equalizer, Male O-Ring with 13" capillary length, 13"
E7NN-19849A, 80449624 RD-5-3824-1P 71R8100
OE#E7NN-19849A equalizer tube length
Tractors 7600, 7700, 7710 Series, with OE#D6AH- External Equalizer, Male O-Ring with 13" capillary length, 13"
D6AH-19849AA RD-5-3824-1P 71R8100
19849AA equalizer tube length
Tractors TW 8000, 9000 model series with OE#D3AH-
18949AA
All combine and tractor model series with OE#D3NN-
Internal equalizer, 1 1⁄2 Ton, Male O-Ring D3NN-19849A RD-5-10445-0P 71R8220
19849A
Internal equalizer valve with male O-Ring fittings SFDO17844, 826-004 RD-5-11033-0P 71R8060
OE#SFDO17844, 826-004
Tractors 230A, 233, 234, 333, 334, 355 with OE#D8NN- Internal equalizer with male flare with 9" capillary length, flare
D8NN-19849A RD-5-6099-0P 71R8210
19849A fittings
Tractors 530A, 555A, 655A with OE#D8NN-19849A D8NN-19849A RD-5-6099-0P 71R8210
fittings
RECEIVER DRIER
OE#085098-00
with #6 Male flare, 3" X 6 1⁄4", fuse, no port D6NN-19959A, 130217 RD-5-4954-0P 74R2406
19959A, 130217
All combine and tractor model series with OE#48510 Male & Male O-Ring HPRV, MI IN CAP 48510 RD-5-5583-0P 74R2606
All combine and tractor model series with OE#402565 Male & Male O-Ring with Fuse Plug, Low Pressure Switch 402565 RD-4160-1P 74R2106
All combine and tractor model series with OE#763787 Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" 763787 RD-5-7061-1P 74R2536
All combine and tractor model series with OE#620206 #6 Male Flare, 4" x 7 3⁄4", fuse 620206 RD-5-5954-0P 74R3506
Balewagon 1038, 1078, 1079, 1085 series, OE#D6NN-
with #6 Male flare, 3" X 6 1⁄4", fuse, no port D6NN-19959A RD-5-4954-0P 74R2406
19959A
Balewagon 1038, 1078, 1079, 1085 series, OE#9827053 with #6 Male O-Ring, 3" x 10", fuse, top port 9827053 RD-5-6504-0P 74R2306
Combines CR920, 940, 960, 970 with male O-Ring, 3" x
Male & Male O-Ring HPRV, MI IN CAP PH 088193-00 RD-5-11192-0P 74R2608
8 3⁄8", hi capacity
Combines TR70, TR75 series, OE#D6NN-19959A with #6 Male flare, 3" X 6 1⁄4", fuse, no port D6NN-19959A RD-5-4954-0P 74R2406
Combines TR76, TR85, TR86, TR98 series, OE#9827053 with #6 Male O-Ring, 3" x 10", fuse, top port 9827053 RD-5-6504-0P 74R2306
Combines TR87, TR89, TR97, TR99 series, OE#9827050 with #6 Male O-Ring, 3" x 10", fuse, top port, moisture indicator 9827050 RD-5-6768-1P 74R3322
Combines TX66 series, OE#696524 #6 Male O-Ring, 4" x 7 1⁄2", fuse, side port, moisture indicator 696524, RD-5-7565-0 RD-5-7565-0P 74R3536
Combines / Tractor 7600, 7700, 7710 series with
Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" 763787 RD-5-7061-1P 74R2536
OE#763787
Combines / Tractor 7600, 7700, 7710 series,
with #6 Male O-Ring, 3" x 10", fuse, top port 9827053 RD-5-6504-0P 74R2306
OE#9827053
Harvesters FX25, FX28, FX45, FX58 series,
#6 Male O-Ring, 4" x 7 1⁄2", fuse, side port, moisture indicator 89832539 RD-5-7565-0P 74R3536
OE#89832539
Harvesters 1915, 2115 series, OE#763787 Male & Male O-Ring HPRV, MI IN CAP 763787 RD-5-5583-0P 74R2606
PAGE 210

RECEIVER DRIER
with #6 Male to Female O-Ring, 3" x 10 1⁄8", pressure relief,
Combine / Tractor P396 Series RD-5-7292-0P 74R3336
moisture indicator
with #6 Male O-Ring, 3" x 10", pressure relief, top port,
Mower HW30 series, OE#9827050 9827050 RD-5-6768-1P 74R3322
moisture indicator
Swathers 4750, 4850 series, OE#763787 Male & Male O-Ring HPRV, MI IN CAP A22-28796-000 RD-5-5583-0P 74R2606
Tractors Gemini 8160, 8260, 8360, 8560 series,
with #6 Male O-Ring, 3" x 10", fuse, top port, moisture indicator 9827050 RD-5-6768-1P 74R3322
OE#9827050
Tractors Genesis 8670, 8770, 8870, 8970 series, with #6 Male to Female O-Ring, 3" x 8 3⁄4", pressure relief, top
86507374 RD-5-10583-0P 74R2667
OE#86507374 port
Tractors TG210 - TG285 series with #6 Male /Female O-Ring (top and bottom), 4" X 7 ⁄4" 3
143469-C2 RD-5-11028-0P 74R4026
Tractors 530A, 555A, 655A series, OE#D6NN-19959A with #6 Male flare, 3" X 6 1⁄4", fuse, no port D6NN-19959A RD-5-4954-0P 74R2406
Tractors 4835, 5635, 6635, 7635, OE#9705765 with #6 Male O-Ring, 3" x 10" 9705765 RD-5-10450-0P 74R3140
Tractors TL70, 80, 90, 100, TN / TND / TNS 55, 65, 70, 75
Male inlet, Female outlet with 2 M10 Ports 9705770 RD-5-10735-0P 74R3156
TN90F series with OE#9705770
Tractors TV140 Bidirectional, OE#80417372 O-Ring Type with #6 male inlet and outlet 80417372 RD-5-10743-0P 74R1426
Tractors Versatile 9282, 9482, 9682, 9882 series,
Male & Male O-Ring HPRV, MI IN CAP PH 088193-00 RD-5-11192-0P 74R2608
OE#402529
Windrowers 1118, 2450, 2550 series, OE#088423-00 Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" 088423-00 RD-5-7061-1P 74R2536
THERMOSTATIC SWITCH
Rotary thermostat with 18" capillary tube, 28 - 62°F D6NN-19N683B, C RD-5-4909-0P 71R2100
19N683B, C
OE#1162474-9
Rotary thermostat with 48" capillary tube, 34 - 52°F D3NN-19618A RD-4125-48P 71R2300
19618A
Rotary thermostat with 48" capillary tube, 34 - 52°F D5NN-19N633 RD-4125-48P 71R2300
19N633
All combine and tractor model series with OE#F0NN-
Rotary thermostat with 48" capillary tube, 34 - 52°F F0NN-19618AB RD-4125-48P 71R2300
19618AB
All combine and tractor model series Red Dot unit Thermostat for standard control units, fixed setting with 24"
8600262 RD-5-4531-24P 71R3200
R-9787 (Standard), OE#8600262 capillary tube, flange/side mt.
Combines / Tractor P396 series with Red Dot unit Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
R-9787 (Standard) capillary tube, flange/side mt.
IHC CASE
BLOWER MOTOR
All series with Bergstrom A/C, OE#117283-C91 Bergstrom A/C, 12V, single shaft, 1 speed, 4 3⁄4" length 117283-C91 RD-5-5512-0P 73R0912
All model series with Allis Chalmers OE#117284-C3 117284-C3 RD-5-4550-0P 73R0102
length
CLUTCH ASSEMBLY
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 111631C91 RD-5-4994-0P 75R4502
OE#111631C91
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug 165129C91 RD-5-4967-0P 75R0452
OE#165129C91
All series with Sanden 5H14 R134a compressor,
OE#6504-6310
All series with Sanden SD508 R12/R134a compressors,
OE#6514-6210
COMPRESSOR - GM
GM A6 with Superheat switch port, without oil,
1 groove 1⁄2" width, 4 7⁄8" diameter (124mm), generic 1131243 RD-5-5000-0P 75R8102
OE#1131243
PAGE 211
IHC CASE
THERMOSTATIC
COMPRESSOR - SANDEN SWITCH
All series with 12V Sanden 7H15HD, OE #4609. IHC- 4609, 1999755C3,
Case OE#1999755C3, 86993462 86993462
All series with 24V Sanden 7H15HD, OE #4611. IHC-Case 4611, 1999760C2,
OE#1999760C2, 86983967 86993967
All series with 12V Sanden 7H15HD, OE #4768. IHC-
Case OE#317008A3, 86993463
All series with 24V Sanden 7H15HD, OE #4795. IHC-
Case OE#4795, 352524A2, 86983968
compressors, 12V
compressors, 24V
All series with Sanden 510-HD, OE#9103 510-HD , B head, ear mount 2 groove, 5 1⁄4" (132mm) diameter 9103 RD-5-6164-0P 75R8262
All series with Sanden 508HD, OE #9285, 9515 SD508HD, FG head, 2A groove, 5 1⁄4"(132mm) diameter 9285, 9515 RD-5-5575-0P 75R8292
RECEIVER DRIER
OE#085098-00
OE#088423-00
All combine and tractor model series with 111218-C1, 539049-R91,
with #6 Male Flare (top and side), 4" X 6 3⁄4" RD-5-6077-0P 74R4016
OE#111218-C1, 539049-R91, 572832-R91 572832-R91
with #6 Male O-Ring (top and side), 4" X 6 3⁄4" 118304-C1, 118418-C1 RD-5-6075-0P 74R4006
OE#118304-C1, 118418-C1
with #6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 143469-C2, 1990758-C2 RD-5-11028-0P 74R4026
OE#143469-C2, 1990758-C2
All combine and tractor model series with OE#402565 Male & Male O-Ring with Fuse Plug, Low Pressure Switch 402565 RD-4160-1P 74R2106
THERMOSTATIC SWITCH
All combine and tractor model series using clutch
cycling switch with OE#1259617-7
Rotary thermostat with 48" capillary tube, 34 - 52°F 109268-C1, C2 RD-4125-48P 71R2300
OE#109268-C2
OE#1162474-9
Rotary thermostat with 48" capillary tube, 34 - 52°F 175575C-1 RD-4125-48P 71R2300
OE#175575C-1
Rotary thermostat with 36" capillary tube, 34 - 52°F 175575C91 RD-4125-36P 71R2250
OE#175575C91
Rotary thermostat with 48" capillary tube, 34 - 52°F 301395-C91 RD-4125-48P 71R2300
OE#301395-C91
All combine and tractor model series with OE#A42623,
Rotary thermostat with 18" capillary tube, 28 - 62°F A42623, 70500-C2 RD-5-4909-0P 71R2100
70500-C2
Rotary thermostat with 18" capillary tube, 35 - 44°F RD-5-11029-0 RD-5-11029-0P 71R2305
590, 590 Super M
PAGE 212
INTERNATIONAL (IHC) / NAVISTAR

BLOWER MOTOR
Combines 715, 815, 915 model series, heater only OE style blower motor (only), 1 speed, 3 3⁄4" length, 12V non-
936489-R91 RD-5-10391-0P 73R0092
OE#936489-R91 vented
Tractors 66 Series, 766 thru 4366, condenser motor, Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW
539047-R2 RD-5-3690-0P 73R0502
OE#539047-R2 or CCW, 4 7⁄8" length
Tractors 68 series, 1568 thru 4768, condenser motor, Single shaft motor, (2 reqd), 1 speed, 12V, CW, 4 3⁄4" length,
RD-5-6526-0 RD-5-6526-0P 73R0422
OE#RD-5-6526-0 vented
Tractors 86 Series, 786 thru 4786, condenser blower, Kysor/Evans (condenser blower), non vented, 12V, 1 speed, CW,
539047-R2 RD-5-3690-0P 73R0502
OE#539047-R2 4 7⁄8" length
All Combine / Loader / Tractor model series, blower
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 168822-C1 RD-5-10934-0P 71R1163
control, OE#168822-C1
CLUTCH ASSEMBLY
Combines 715, 815, 915 series, CCI/York R210 024-25078, MA6, MAE6AR,
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug RD-5-4967-0P 75R0452
compressors 165338C91
Combines 1400, 1600 series, CCI/York R210 332334, MA 7A, 111631-
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug RD-5-4994-0P 75R4502
compressors C91, 1687801C91
Combines 1400, 1600 series with Sanden SD510 R12/ 6574-6210, 6514-6210,
2 groove 5 1⁄4" diameter, 1⁄2" width, (132mm), 1 wire plug RD-5-5486-0P 75R0202
R134a compressors 576625C91
Combines 2144, 2166, 2188 series with Sanden SD510 6574-6210, 6514-6210,
2 groove 5 1⁄4" diameter, 1⁄2" width, (132mm), 1 wire plug RD-5-5486-0P 75R0202
R12/R134a compressors 576625C91
Tractors 66 series 766 thru 4366 series, CCI/York R210 024-25078, MA6, MAE6AR,
Tractor 68 series 1568 thru 5768, CCI/York R210 332334, MA 7A, 143405-
compressors C91, 1687801-C91
Tractors 86 series thru 4186 series, CCI/York R210 024-25078, MA6, MAE6AR,
Tractor 86 series 786 thru 4786 except 4186, CCI/York 332334, MA 7A, 143405-
R210 compressors C91, 1687801-C91
332334, MA 7A, 143405-
Tractor 88 series 3388 thru 4788, CCI/York R210
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug C91, RD-5-4994-0P 75R4502
compressors
1687801-C91
Windrowers 4000, 5000, 5500, 880 series, CCI/York - 024-25078, MA6, MAE6AR,
R210 compressors 165338C91
CLUTCH ASSEMBLY CYCLING SWITCH
5°F
Combine / Loader / Tractor series clutch cycling switch,
Rotary thermostat, 36" capillary tube, 34 - 52°F 175575C1 RD-4125-36P 71R2250
OE#175575C1
Combine / Loader / Tractor model series with
OE#109268C2
Combines 715, 815, 915 series with CCI/York Tecumseh
Rotolock ER, R210L-25149 compressor
Combines 1400, 1600 series with CCI/York Tecumseh
Rotolock ER, R210L-25149 compressor
Tractors 66 series 766 thru 4366 with CCI / York
Tecumseh Rotolock ER210R-16792, 25200
Tractors 68 series 1568 thru 5768 with CCI / York
Tecumseh Rotolock ER210R-16792, 25200
Tractor 86 series thru 4786 except 4186 series with CCI
/ York Tecumseh Rotolock ER210R-16792, 25200
Tractor 88 series 3388 thru 4788 except 4186 series
with CCI / York Tecumseh Rotolock ER210R-16792, All Models with Rotolock Type (universal) RH without clutch ER210R-16792, 25200 RD-5-10826-0P 75R7265
25200
Windrowers 4000, 5000, 5500, 880 series with CCI /
York Tecumseh Rotolock ER210R-16792, 25200
PAGE 213

RECEIVER DRIER
ELECTRICAL SWITCH
All series using clutch cycling switch, OE#70500C2 70500C2 RD-4172-0P 71R2310
5°F
Combine / Loader / Tractor model series, blower
OE#175575C1
OE#109268C2
Combines 1400, 1600 series with OE#1990756-C1 Block valve with female O-Ring fittings 1990756-C1 RD-5-7015-0P 71R8321
Combines 2100 series with OE#1990756-C2 Block valve with female O-Ring fittings 1990756-C2 RD-5-7015-0P 71R8321
Combines / Tractor 60C - 90C, 250C, 412B, 431B, 560,
580 series with OE#31134-300
Combines / Tractor 88 series 3388 thru 4788 with Male O-Ring with 13" capillary length, 13" equalizer tube
1280333-C1 RD-5-3824-1P 71R8100
OE#1280333-C1 length
Combines / Tractor 3305, 3307, 3309, 3311 series with Male O-Ring with 13" capillary length, 13" equalizer tube
71504287-5 RD-5-3824-1P 71R8100
OE#31134-301 length
Combines / Tractor 7211, 7231, 7241, 7251, 7261, Male O-Ring with 13" capillary length, 13" equalizer tube
71504287-5 RD-5-3824-1P 71R8100
7271AA series with OE#31134-301 length
Combines / Tractor D700, D750, D800 series with Male O-Ring with 13" capillary length, 13" equalizer tube
71504287-5 RD-5-3824-1P 71R8100
OE#31134-301 length
Combines / Tractor H90E, L175C, TD15C, TD25C, TD25E,
series with OE#31134-300
Combines / Tractor TD12, TD15E, TD20E, TD20G, TD25G, Male O-Ring with 13" capillary length, 13" equalizer tube
71504287-5 RD-5-3824-1P 71R8100
TD40, TS24A, B, C series with OE#31134-301 length
Windrowers 4000, 5000, 5500, 8800 series with Male O-Ring with 13" capillary length, 13" equalizer tube
1280333-C1 RD-5-3824-1P 71R8100
OE#1280333-C1 length
PRESSURE SWITCH
High Pressure Switch, normally closed 210psi, opens 340 psi, 1⁄4"
female flare
High Pressure Switch, normally open 250psi, close 375 psi, 1⁄4"
female flare
RECEIVER DRIER
Combines 715, 815, 915 series, OE#539049R-1 #6 Male Flare (top and side), 4" X 6 3⁄4" 539049R-1 RD-5-6077-0P 74R4016
Combines 1420, 1440, 1460, 1480 series,
#6 Male Flare (top and side), 4" X 6 ⁄4"
3
539049R-1 RD-5-6077-0P 74R4016
OE#539049R-1
Combines 1620, 1640, 1660, 1670, 1680, 1688 series,
#6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 143469C-2 RD-5-11028-0P 74R4026
OE#143469C-2
Combines 2144, 2166, 2188 series, OE#143469C-2 #6 Male /Female O-Ring (top and bottom), 4" X 7 ⁄4"
3
143469C-2 RD-5-11028-0P 74R4026
RD-5-4954-0, 088011-00,
Combines / Tractor 560, 580 series #6 Male flare, 3" X 6 1⁄4", fuse, no port RD-5-4954-0P 74R2406
926384-C1
Combines / Tractor D700, D750, D800 series with 4"
#6 Male Flare, 4" x 7 3⁄4", fuse, no port RD-5-5954-0 RD-5-5954-0P 74R3506
drier
Combines / Tractor TD12, TD15E, TD20E, TD20G, TD25G,
#6 Male Flare, 4" x 7 3⁄4", fuse, no port RD-5-5954-0 RD-5-5954-0P 74R3506
TD40 series with 4" drier
Tractors 66 Series except 4366 series, OE#539049C-1 #6 Male Flare (top and side), 4" X 6 3⁄4" 539049C-1 RD-5-6077-0P 74R4016
Tractors 68 Series except 4568 series, OE#539049C-1 #6 Male Flare (top and side), 4" X 6 ⁄4" 3
539049C-1 RD-5-6077-0P 74R4016
Tractors 86 Series except 4586, 4786 series,
#6 Male Flare (top and side), 4" X 6 3⁄4" 539049C-1 RD-5-6077-0P 74R4016
OE#539049C-1
Tractors 88 Series except 3388, 3788, 8588 series,
#6 Male Flare (top and side), 4" X 6 3⁄4" 539049C-1 RD-5-6077-0P 74R4016
OE#539049C-1
PAGE 214

RECEIVER DRIER
Windrowers 4000, 5000, 5500, 8800 series,
#6 Male /Female O-Ring (top and bottom), 4" X 7 3⁄4" 143469C-2 RD-5-11028-0P 74R4026
OE#143469C-2
THERMOSTATIC SWITCH
5°F
OE#109268C2
Combine / Loader / Tractor model series, blower
OE#175575C1
Combines / Tractor D700, D750, D800 series Rotary thermostat, 36" capillary tube, 34 - 52°F 026476-9 RD-4125-36P 71R2250
Combines / Tractor L175C series Rotary thermostat, 36" capillary tube, 34 - 52°F 026476-9 RD-4125-36P 71R2250
Combines / Tractor TD12, TD15C, TD15E, TD20E, TD20G,
TD25C, TD25E, TD25G series
Combines / Tractor TS24A, TS24B, TS24C series Rotary thermostat with 18" capillary tube, 28 - 62°F A42623 RD-5-4909-0P 71R2100
Combines / Tractor 60C, 70C, 80C, 90C, 250C series Rotary thermostat, 36" capillary tube, 34 - 52°F 026476-9 RD-4125-36P 71R2250
Combines / Tractor 560, 580 series Rotary thermostat with 48" capillary tube, 34 - 52°F RD-4125-48, 0272229-6 RD-4125-48P 71R2300
Combines / Tractor 3305, 3307, 3309, 3311 series with
Cable controlled thermostat, 30" capillary tube, 34 - 54°F RD-4226-0 RD-4226-0P 71R2700
Red Dot A/C, OE#RD-4226-0
Combines / Tractor 7221, 7231, 7241, 7251, 7261 series
Cable controlled thermostat, 30" capillary tube, 34 - 54°F RD-4226-0 RD-4226-0P 71R2700
with Red Dot A/C, OE#RD-4226-0
JOHN DEERE
BLOWER - FAN
All Loader / Tractor model series with remote mount
condenser, OE#RD-5-8641-0
All Loader / Tractor model series with remote mount
condenser, OE#RD-5-8641-1
Backhoe Loader 344G, 444G with Red Dot model
R-10036-0 (24V), puller fan OE#RD-5-8641-1
Backhoe Loader 344E, 444E with Red Dot A/C unit
Fan Blade - Red Dot A/C, 8" diameter, CW, aluminum RD-5-7123-0 RD-5-7123-0P 73R8080
R-10025-1, OE#RD-5-7123-0
Backhoe Loader 544E, 624E, 644E, 924E Series with
Red Dot model R-10150, puller fan OE#RD-5-8641-0
Fan Blade - Red Dot A/C, Bergstrom, Kysor, 6" diameter, CW,
Crawler Dozer 750C, 850C with OE#RD3133-9 RD3133-9 RD-3133-9P 73R8050
plastic
Wheel Loader 304H, 324H, 344H with Red Dot A/C unit
Fan / blower assembly, 12V, single speed, 13" x 3 3⁄4" RD-5-9076-2 RD-5-9076-2P 73R8642
R-9777 Condenser, OE#RD-5-9076-2
Wheel Loader 544H, 544G, 624G, 644G with Red Dot
Fan / blower assembly, 12V, CW, single speed, 10 5⁄8" x 2" RD-5-8703-2 RD-5-8703-2P 73R8562
A/C unit R-10151-0P Condenser, OE#RD-5-8703-2
Excavators 110, 120, 160LC with Red Dot A/C, OE#RD-
5-3647-0P
Backhoe Loader / Tractor 310E, 410E, 510E, 710E with
Red Dot A/C
Crawler Dozer 450H, 550H, 650H with Red Dot A/C unit Ceramic tube style resistor, (black), 4 terminal, 12V, 6 1⁄2" length
RD-5-8665-0 RD-5-8665-0P 71R1485
R-9475-0, OE#RD-5-8665-0 x 1 3⁄16" diam
Crawler Dozer 700H with Red Dot A/C, Ceramic tube style resistor, (white), 4 terminal, 12V, 7" length
RD-5-9062-0 RD-5-9062-0P 71R1480
OE#RD-5-9062-0 x 1 1⁄4" diam
Wheel Loaders 304H with Red Dot A/C models R-1400,
Blower assembly fan resistor, 3 speed, 4 terminal 20604004, RD-5-9437-0 RD-5-9437-0P 71R1402
R-1620, R-2550, R-2820, R-9777
PAGE 215
JOHN DEERE
THERMOSTATIC
BLOWER MOTORSWITCH
All with 3 1⁄4" diameter blower motor, 1 speed, 4" length, 12V,
All Loader / Tractor model series with OE#AR45856 AR45856 RD-5-10390-0P 73R0212
Rev. direction
All Loader / Tractor model series with OE#AR49962 12V, single shaft, 1 speed, 4 3⁄4" length AR49962 RD-5-5512-0P 73R0912
All Loader / Tractor model series, OE#RE37152 12V, single shaft, 1 speed, 4" x 3 1⁄2" x 3" RE37152 RD-5-10379-0P 73R0012
All Loader / Tractor model series, OE#RE46880 12V, single shaft, 1 speed, 4 11⁄16" x 4" x 3" RE46880 RD-5-10392-0P 73R0232
All Loader / Tractor model series, OE#275140 12V, single shaft, 1 speed, CCW, 4 5⁄8" length 275140 RD-5-10389-0P 73R0372
All Loader / Tractor model series remote mount
Single shaft motor (condenser motor), 12V, NV, 4 7⁄8" length RD-5-5120-0 RD-5-5120-0P 73R0512
condenser (12V), OE#RD-5-5120-0
All Loader / Tractor model series remote mount
Single shaft motor (condenser motor), 24V, 4 7⁄8" length RD-5-5120-24 RD-5-5120-24P 73R0514
condenser (24V), OE#RD-5-5120-24
Backhoe Loader 310E, 410E, 510E, 710E with Red Dot Double shaft motor, 12V, 1 speed, 5 5⁄16" length, shaft length 2
RD-5-8126-0 RD-5-8126-0P 73R4242
A/C unit R-9450-3, OE#RD-5-8126-0 7
⁄8"
Double shaft motor (evaporator motor), 12V, 4 13⁄16" length RD-5-5121-0 RD-5-5121-0P 73R4252
R-10025-0 (12V), OE#RD-5-5121-0
R-10025-1 (24V), OE#RD-5-5120-24
Backhoe Loader 344G, 444G with Red Dot A/C unit
Single shaft motor (evaporator motor), 24V, 5" x 4" x 3" length RD-5-4827-24 RD-5-4827-24P 73R0404
R-10036-0 (24V), OE#RD-5-4827-24
Backhoe Loader 490E, 690E, 790E, 892E with Red Dot
Double shaft motor, 3 speed, 24V, 4" x 3 13⁄32" x 3" length RD-5-3780-24 RD-5-3780-24P 73R4104
A/C unit R-10035, OE#RD-5-3780-24
Combines 3300, 4400, 4420, 4425, 4435, 4435 Hydro,
Kysor/Evans (condenser roof mount blower), single speed, NV,
6600, 6602, 6620, 6622, 7700, 7720, 7722, 8820, AR82005 RD-5-3690-0P 73R0502
12V, 1 speed, CW, 4 7⁄8" length
9400, 9500, 9600
Crawler Dozer 450H, 550H, 650H with Red Dot A/C unit
Blower assembly, 12V, single speed, 18 1⁄2" x 7 1⁄2" x 6 1⁄2" RD-3-9290-0 RD-3-9290-0P 73R5632
R-9475-0, OE#RD-3-9290-0
Crawler Dozer 700H with Red Dot A/C unit R-9475-0-
Blower assembly, 24V, single speed, 18 1⁄2" x 7 1⁄2" x 6 1⁄2" RD-3-9290-24 RD-3-9290-24P 73R5634
24, OE#RD-3-9290-24
Crawler Dozer 750C, 850C with Red Dot A/C unit Single shaft motor (evaporator motor), 2 speed, 24V, RD-3133-4-24, RD-5-
RD-5-10491-24P 73R0034
R-10003-0-24, OE#RD-3133-4-24 3 5⁄8" length 10491-24
Excavator 110, 120, 160LC, 200, 450LC with Red Dot
Double shaft motor, 24V, 1 speed, 5 1⁄4" length, shaft length 2 7⁄8" RD-5-5049-2 RD-5-5049-2P 73R4424
A/C unit R-10034-0P, OE#RD-5-5049-2
Loader / Tractor 792D, 992E with Red Dot A/C unit
Double shaft motor, 3 speed, 24V, 4" x 3 13⁄32" x 3" length RD-5-3780-24 RD-5-3780-24P 73R4104
R-10035, OE#RD-5-3780-24
Loader / Tractor 4000 thru 7040 series with 1 3⁄4" single Bergstrom - Kysor A/C, single shaft, 1 3⁄4" shaft length, 12V, 1 AR49962, 1183560,
RD-5-10905-0P 73R0442
shaft motor, OE#AR49962 speed, CW, 4 5⁄8" length BSM205620, 275130
Tractor 20 series (condenser blower) 4020, 4320, 4520, Kysor/Evans (condenser blower), single speed, NV, 12V, 1 speed,
AR82005 RD-5-3690-0P 73R0502
4620, 5020, 7020, 7520 CW, 4 7⁄8" length
Tractor 20 series (evaporator blower) 4020, 4320, Double shaft motor, single speed, 4 3⁄4" x 4" x 3", shaft 2 1⁄2"
AR62497 RD-5-5190-0P 73R4162
4520, 4620, 5020, 7020, 7521 length
Tractor 30 series without Sound Guard Cab 4020, 4320, Double shaft motor, single speed, 4 3⁄4" x 4" x 3", shaft 2 1⁄2"
AR62497 RD-5-5190-0P 73R4162
4520, 4620, 5020, 7020, 7521 length
Single shaft motor, 1 speed, 12V, CW/CCW 4 7⁄8" length, 1 1⁄2"
Tractor 70 series 8570, 8770, 8870, 8970 A22-29923-000 RD-5-8016-0P 73R0662
shaft length
Double shaft motor, single speed, 4 3⁄4" x 4" x 3", shaft 2 1⁄2"
Tractor 4000 series AR62497 RD-5-5190-0P 73R4162
length
Wheel Loader 304H, 324H, 344H with Red Dot A/C unit Evaporator motor / blower assembly with resistor, 12V, 13 3⁄4" x
RD-5-8583-0 RD-5-8583-0P 73R5552
R-9777 evaporator 5 3⁄8" x 5 1⁄8"
Wheel Loader 304H, 324H, 344H with Red Dot A/C unit Evaporator blower assembly with resistor, 12V, 13 3⁄4" x 5 3⁄8" x
RD-5-8583-0 RD-5-8583-0P 73R5552
R-10500 evaporator, OE#RD-5-8583-0 5 1⁄8"
BLOWER RELAY
All Loader / Tractor model series with Bosch relay,
Bosch type (30 amp), SPST, 5 terminals 0332-209-169 RD-5-4408-0P 71R1702
OE#0332-209-169
All Loader / Tractor model series with Hella relay,
Hella type, SPST, 5 terminals 960-388-25 RD-5-4408-0P 71R1702
OE#960-388-25
PAGE 216
JOHN DEERE
BLOWER
BLOWER MOTOR SWITCH
All Loader / Tractor model series with
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal RD-5-10934-0, 71195109 RD-5-10934-0P 71R1163
OE#RD-5-10934-0
BLOWER WHEEL
Backhoe Loader 344G, 444G with Red Dot A/C unit
Red Dot A/C, single entry, 3 13⁄16" diameter x 2 1⁄2" width, CCW RD-5-7312-0 RD-5-7312-0P 73R6300
R-10036-0, OE#RD-5-7312-0
Loader / Tractor 792D, 992E with Red Dot A/C unit
Red Dot A/C, double entry, 3 3⁄16" diameter x 3 3⁄16" width D2AZ-19834-A RD-5-5656-0P 73R7000
R-10035, OE#RD-5-5656-0
CLUTCH ASSEMBLY
All series with CCI/York - R12 / 134A compressors
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug AH79301 RD-5-4967-0P 75R0452
OE#AH79301
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug AH85847 RD-5-4994-0P 75R4502
OE#AH85847
All series with Sanden SD508 compressors, OE#6514-
6210
OE #6504-6310
Combines 4400, 4420, 4425, 4435, 4435 Hydro, 6600,
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug AH79301 RD-5-4967-0P 75R0452
6602, 6620, 6622, 7700 with CCI/York compressor
Combines 4400, 4420, 4425, 4435, 4435 Hydro, 6600, 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
6602, 6620, 6622, 7700 with CCI/York compressor plug 501939
Combines 4400, 4420, 4425, 4435, 4435 Hydro, 6600,
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug AH85847 RD-5-4994-0P 75R4502
6602, 6620, 6622, 7700 with CCI/York compressor
Excavator 110, 120, 160LC with Red Dot A/C unit
R-9500-0-24, R-10034-0P, Sanden SD5 R-12 2 groove, 24V, 5 1⁄4" (132mm) diameter pulley, 1⁄2" width, 1 wire 6519-6210, 6514-6210 RD-5-5487-0P 75R0204
compressors
Wheel Loader 304H with Red Dot A/C unit R-9777-1,
Single groove 6 1⁄4" (159mm), variable width, bullet plug 511051, RD-5-10723-0 RD-5-10723-0P 75R0262
Seltec TM15 compressors
Wheel Loader 324H, 344H with Red Dot A/C unit
Poly 8 groove 4 5⁄8" (123mm), bullet plug RD-5-10544-0 RD-5-10544-0P 75R0082
R-9777-1, Seltec TM15 compressors
2 groove, 24V, 5 1⁄4" (132mm) diameter pulley, 1⁄2" width, 1 wire 6519-6210, 6514-6210 RD-5-5487-0P 75R0204
R-10060-4P, Sanden SD5 R-12 compressors
Wheel Loader 544G, 624G, 644G with Red Dot A/C
drop-in evaporator kit R-10151-0P, Sanden SD5 R-12 2 groove 5 1⁄4" diameter, 1⁄2" width, (132mm), 1 wire plug 6574-6210, 6514-6210 RD-5-5486-0P 75R0202
compressors
All series with CCI/York Tecumseh Rotolock ER,
Rotolock Head, LH Suction without clutch, (universal - new) AH17626, ER, R210L- 25149 RD-5-8637-1P 75R7280
R210L-25149, OE#AH17626
ET210L-25150, R12 / 134A without clutch
Combines 4400, 4420, 4425, 4435, 4435 Hydro,
6600, 6602, 6620, 6622, 7700 with CCI/York Rotolock Rotolock Head, LH Suction without clutch, (universal - new) ER, R210L- 25149 RD-5-8637-1P 75R7280
compressor
COMPRESSOR - GM
All series with GM A6 with Superheat switch port, 1131243, 0259362-2,
without oil, OE#1131243 509170-C91
All series with ICE/Seltec TM21HD, OE#488-47244 TM21HD, J head, direct mount, poly 8, 5 1⁄2" (141mm) diameter 488-47244 RD-5-12530-1P 75R86142Q
TM21HD, 24V, J head, direct mount, poly 8, 5 1⁄2" (141mm)
All series with ICE/Seltec TM21HD 24V, OE#488-47246 488-47246 RD-5-11866-1P 75R86144Q
diameter
Wheel Loader 304H with Red Dot A/C unit R-9777-1,
ICE-Seltec TM15, C head, ear mount, 2 groove, 5"(125mm) 488-45075, 2521168 RD-5-9609-0P 75R85032
Seltec TM15, #488-45075, 2521168 R134a compressors
Wheel Loader 324H, 344H with Red Dot A/C unit
R-9777-1, Seltec TM15, #488-45122, 2521266 R134a ICE-Seltec TM15, A head, ear mount, poly 8, 4 3⁄4"(123mm) 488-45122, 2521266 RD-5-10429-0P 75R86132
compressors
PAGE 217
JOHN DEERE
COMPRESSOR -- NIPPONDENSO
COMPRESSOR NIPPONDENSO
Combines 9400, 9500, 9600, CTS with Nippondenso Nippondenso 10PA17C, poly 8, direct mount compressor RE46657, TY6765, 447-
RD-5-11048-0P 75R8922
10PA17C compressor, OE#RE46657, TY6765 without clutch 0442
Harvesters 4700, 4890, 4990 with Nippondenso FS6
Nippondenso FS6 ear mount compressor without clutch E7TZ-19703B RD-5-10371-0P 75R8906
compressor, OE#E7TZ-19703B
Sprayers 4700, 4890, 4990 with Nippondenso FS6
Tractors 20 series 4020, 4320, 4520, 4620, 5020, 7020,
7520 with Nippondenso FS6 compressor, OE#E7TZ- Nippondenso FS6 ear mount compressor without clutch E7TZ-19703B RD-5-10371-0P 75R8906
19703B
Tractors 40 series 4050, 4055, 4250, 4255, 4450, 4650,
4850 with Nippondenso FS6 compressor, OE#E7TZ- Nippondenso FS6 ear mount compressor without clutch E7TZ-19703B RD-5-10371-0P 75R8906
19703B
Tractors 7200, 7210, 7400, 7510, 7600, 7720, 7815,
Nippondenso 10PA17C, poly 8, direct mount compressor RE46609, TY6764, 447-
7820, 7920 with Nippondenso 10PA17C compressor, RD-5-11049-0P 75R8932
without clutch 0441
OE#RE46609, TY6764
Tractors 8100, 8100T, 8110, 8120, 8120T, 8130, 8200,
8200T, 8210, 8210T, 8220, 8220T, 8230, 8300, 8300T,
8310, 8310T, 8320, 8320T, 8330, 8400, 8400T, 8410, Nippondenso 10PA17C, poly 8, direct mount compressor RE46609, TY6764, 447-
RD-5-11049-0P 75R8932
8410T, 8420, 8420T, 8430, 8520, 8520T, 8530 with without clutch 0441
Nippondenso 10PA17C compressor, OE# RE46609,
TY6764
Tractors 8570, 8770, 8870, 8970 with Nippondenso Nippondenso 10PA17C, poly 8, direct mount compressor RE46657, TY6765, 447-
RD-5-11048-0P 75R8922
10PA17C compressor, OE#RE46657, TY6765 without clutch 0442
Utility Loaders 444J, 544J, 624J with Nippondenso Nippondenso 10PA17C, 24V, poly 8, direct mount compressor
AT226273, 471-0456 RD-5-11050-0P 75R8934
10PA17C compressor, OE#AT226273, 471-0456 without clutch
Wheel Loaders 444H, 544H, 624H, 644H, 644J, 724J
Nippondenso 10PA17C, 24V, poly 8, direct mount compressor
with JD drop-in evap kit, Nippondenso 10PA17C AT226273, 471-0456 RD-5-11050-0P 75R8934
without clutch
compressor, OE#AT226273, 471-0456
Wheel Loaders 544G, 624G, 644G with JD drop-in evap
Nippondenso 10PA17C, poly 8, direct mount compressor RE46657, TY6765, 447-
kit, Nippondenso 10PA17C compressor, OE#RE46657, RD-5-11048-0P 75R8922
without clutch 0442
TY6765
Wheel Loaders 824J with Nippondenso 10PA17C Nippondenso 10PA17C, 24V, poly 8, direct mount compressor
RD-5-11149-0P 75R8942
compressor without clutch
Windrowers 4700, 4890, 4990 with Nippondenso FS6
COMPRESSOR - SANDEN
Backhoe Loaders 444H with Sanden 5H14HD, #4537, 5H14-HD, K head, ear mount, 2A groove, 5 1⁄4" (132mm)
4537, 6634 RD-5-8680-0P 75R8354
6634 R134a compressors, 24V diameter
Excavators 110, 120, 160LC with Sanden 5H14HD, 5H14-HD, FL head, ear mount, 2A groove, 5 1⁄4" (132mm)
6665 RD-5-7089-0P 75R8384
#6665 R134a compressors, 24V diameter
Wheel Loaders 744E with Sanden 5H14HD, #6665 5H14-HD, FL head, ear mount, 2A groove, 5 1⁄4" (132mm)
6665 RD-5-7089-0P 75R8384
R134a compressors, 24V diameter
Wheel Loaders 444H, 544H, 624H with Red Dot
5H14-HD, K head, ear mount, 2A groove, 5 1⁄4" (132mm)
drop-in evap kit, Sanden 5H14HD, #4537, 6634 R134a 4537, 6634 RD-5-8680-0P 75R8354
diameter
compressors, 24V
Wheel Loader 544G, 624G, 644G with Red Dot drop-in
5H14-HD, FL head, ear mount, 2A groove, 5 1⁄4" (132mm)
evap kit, Sanden 5H14HD, #6664 R134a compressors, 6664 RD-5-7088-0P 75R8382
diameter
12V
COMPRESSOR MANIFOLD
Top discharge with oil bypass, #8 and #10 Male Insert O-Ring
Backhoe Loader 310G, 310SG, 410G RD-5-11151-0P 75R8920
fittings
Wheel Loader 304H Rear Port Adapter, head type A, Horizontal Male O-Ring, 3⁄4" x 7⁄8" RD-5-8010-0P 75R8505
Wheel Loader 324H, 344H Rear Port Adapter, head type B, Vertical Female O-Ring, 3⁄4" x 7⁄8" RD-5-9611-0P 75R8507
PAGE 218
JOHN DEERE
COMPRESSOR MANIFOLD
Wheel Loader 544G, 544H, 624G, 624H, 644G, 644H, Top discharge with oil bypass, #8 and #10 Male Insert O-Ring
RD-5-11152-0P 75R8921
772CH, 824J fittings
CONDENSER
Excavators 110, 120, 160LC Radiator Mount,Tube & Fin type, 21 1⁄2" fin width x 26 1⁄2" x 1 1⁄4" RD-4-4968-0 RD-4-4968-0P 77R7100
Wheel Loaders 444H, 544H, 624H with Red Dot A/C
Serpentine type, fin width 31 19⁄32" x 8 1⁄2" x 2" RD-4-5146-1 RD-4-5146-1P 77R0570
unit R-10060-4
Wheel Loader 544G, 624G, 644G with Red Dot A/C unit
Radiator Mount,Tube & Fin type, 21 5⁄8" fin width x 12 1⁄2" x 2 7⁄8" RD-4-4724-1 RD-4-4724-1P 77R7005
R-10150-0, -1
Wheel Loader 744E Radiator Mount,Tube & Fin type, 21 5⁄8" fin width x 12 1⁄2" x 2 7⁄8" RD-4-4724-1 RD-4-4724-1P 77R7005
ELECTRICAL SWITCH
All Loader / Tractor model series using clutch cycling
Rotary thermostat, 36" capillary tube, 34 - 52°F AR49960 RD-4125-36P 71R2250
switch with OE#AR49960
OE#RD-5-10934-0
All Loader / Tractor model series with OE#AH80197 Rotary thermostat with 48" capillary tube, 34 - 52°F AH80197 RD-4125-48P 71R2300
All Loader / Tractor model series with OE#AR59779 Rotary thermostat, 36" capillary tube, 34 - 52°F AR59779 RD-4125-36P 71R2250
Wheel Loader 544E, 624E, 644E series using clutch Rotary thermostat, 27" capillary, 34°-52°F, clutch cycle range
70500C2 RD-4172-0P 71R2310
cycling switch with OE#70500C2 5°F
EVAPORATOR
Backhoe Loader 310E, 310G, 310SG, 410E, 410G, 510E,
710E with Red Dot A/C unit Dimensions: 8 1⁄2" height x 13" length x 3 13⁄32" width RD-2-2780-0 RD-2-2780-0P 76R6655
R-9450-3
Crawler Dozer 450H, 550H, 650H with Red Dot A/C unit
R-9475-0
Crawler Dozer 700H with Red Dot A/C unit R-9475-
0-24
Excavators 110, 120, 160LC with Red Dot A/C unit
R-9500-0-24
R-9777-1
Dimensions: 10" height x 15 1⁄2" length x 3 3⁄4" width RD-2-3395-0 RD-2-3395-0P 76R7580
unit R-10060-4
Wheel Loader 544G, 624G, 644G with Red Dot A/C
Dimensions: 6 1⁄8" height x 22" length x 2 3⁄4" width RD-2-2495-0 RD-2-2495-0P 76R6550
drop-in unit R-10150-0, -1
ELECTRICAL SWITCH
All Loader / Tractor model series with OE#RE57575 Block valve with female O-Ring fittings RE57575 RD-5-6868-0P 71R8301
All Loader / Tractor model series with OE#AH122867 Block valve with female O-Ring fittings AH122867 RD-5-7015-0P 71R8321
All Loader / Tractor model series with Red Dot A/C unit
Block valve with female O-Ring fittings RE57575 RD-5-6868-0P 71R8301
R-10035-1thru 4, OE#RE57575
Backhoe Loader / Tractor 310D, 344E, 410D, 444E,
510D with Red Dot A/C unit R-10011-0, -1, R-10025-1
Backhoe Loader / Tractor 310E with Red Dot A/C unit
R-10011-0, -1, R-10025-1
Backhoe Loader / Tractor 310E, 410E, 410G, 510E, 710E
Block valve with female O-Ring fittings RD-5-8100-0 RD-5-8100-0P 71R8423
with Red Dot A/C unit R-9450-3
Combines 9400, 9500, 9600 series with OE#AH137702 Block valve with female O-Ring fittings AH122867, AH137702 RD-5-7015-0P 71R8321
Combines 9410, 9450, 9510, 9550, 9600, 9610, 9650,
9750 series with Red Dot A/C unit R-10011-0, -1, Block valve with female O-Ring fittings RE57575 RD-5-6868-0P 71R8301
R-10025-1
Combines 9410, 9450, 9510, 9550, 9600, 9610, 9650,
Block valve with female O-Ring fittings AH122867, AH137702 RD-5-7015-0P 71R8321
9750 series with OE#AH137702
Cotton Pickers 9900, 9910, 9920, 9930, 9940, 9950,
9960, 9965 series with OE#AH137702
PAGE 219
JOHN DEERE
ELECTRICAL SWITCH
Crawler Dozer 450H, 550H, 650H, 700H with Red Dot
A/C unit R-9475-0, R-9475-0-24
Excavators 110, 120, 160LC, 200, 450LC with Red Dot
A/C unit R-9500-0-24, R-10034-0
Harvesters 6650, 6750, 6850, 6950 series with
OE#RE57575
Sprayers 6000, 6100, 6500, 6600, 6700 series with
OE#AH137702
Tractors 10 Series, 6010, 6110, 6210, 6310, 6410
models with OE#RE57575
Tractors 10 Series, 7010, 7210, 7410, 7610, 7710, 7810
Tractors 10 Series, 8010, 8110, 8110T, 8210, 8210T,
8310, 8310T models with OE#RE57575
unit R-9777-1, OE#RD-5-9513-0
Wheel Loaders 444H, 544G, 544H, 624G, 624H, 644G
with Red Dot A/C unit R-10060-4, R-10151-0, -1
Windrowers / Sprayers 4700, 4710, 4890, 4990 series
with OE#RE57575
All Loader / Tractor model series with OE#AL28688, Male O-Ring with 13" capillary length, 13" equalizer tube AL28688, AR58482,
RD-5-3824-1P 71R8100
AR58482, RE13886 length RE13886
Male O-Ring, 1 ⁄2 Ton, 10" capillary length, 10" equalizer tube
1
All Loader / Tractor model series with OE#826-003 826-003 RD-5-5862-0P 71R8080
length
All Loader / Tractor model series with OE#AH80191 External Equalizer unit with male flare with 18" capillary length AH80191 RD-4126-1P 71R8050
Combines 7700, 7720, 8820 series with OE#AR58482 AR58482 RD-5-5862-0P 71R8080
length
Cotton Pickers 9900, 9910, 9920, 9930, 9940, 9950, Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AR58482 RD-5-5862-0P 71R8080
9960, 9965 series with OE#AR58482 length
Tractors 10 Series, 6010, 6110, 6210, 6310, 6410 Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AR58482 RD-5-5862-0P 71R8080
models with OE#AR58482 length
Tractors 10 Series, 7010, 7210, 7410, 7610, 7710, 7810 Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AR58482 RD-5-5862-0P 71R8080
Tractors 20 Series, 4020, 4320, 4520, 4620, 5020, 7020, Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AR58482 RD-5-5862-0P 71R8080
7520 models with OE#AR58482 length
AR58482 RD-5-5862-0P 71R8080
AR58482 RD-5-5862-0P 71R8080
Tractors 55 Series, 2955, 3055, 3155, 3255, 4055, 4255, Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AR58482 RD-5-5862-0P 71R8080
4455, 4755, 4955 models with OE#AR58482 length
Tractors 60 Series, 4560, 4760, 4960 models with Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AR58482 RD-5-5862-0P 71R8080
OE#AR58482 length
Tractors 80 Series, 8430, 8440, 8630, 8640 models Male O-Ring with 13" capillary length, 13" equalizer tube
AH140818 RD-5-3824-1P 71R8100
with OE#AH140818 length
Wheel Loader 344G, 444G with Red Dot A/C unit Male O-Ring with 13" capillary length, 13" equalizer tube AL28688, AR58482,
RD-5-3824-1P 71R8100
R-10036-0 length RE13886
Windrowers / Sprayers 4700, 4710, 4890, 4990 series Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
AH137702 RD-5-5862-0P 71R8080
with OE#AH137702 length
All Loader / Tractor model series with OE#826-004 Internal equalizer valve with male O-Ring fittings 826-004 RD-5-11033-0P 71R8060
All Loader / Tractor model series with OE#826-012 Internal equalizer, 1 1⁄2 Ton, Male O-Ring 826-012 RD-5-10445-0P 71R8220
PAGE 220
JOHN DEERE
Tractors 30 Series, 4030, 4230, 4430, 4630, 6030
Internal equalizer, 1 1⁄2 Ton, Male Flare AR49961 RD-5-6099-0P 71R8210
models with OE#AR49961
All Loader / Tractor model series with OE#RE24958 RE24958 RD-5-4919-0P 71R8500
main unit
Tractors 60 Series, 8560, 8760, 8960 models with Ford type, CCOT (Brown) Orifice Tube with accumulator system,
RE51969 RD-5-10013-0P 71R8506
OE#RE51969 main unit
Tractors 70 Series, 8570, 8770, 8870, 8970 models with Ford type, CCOT (Brown) Orifice Tube with accumulator system,
RE51969 RD-5-10013-0P 71R8506
OE#RE51969 main unit
Tractors 8000 Series, 8100, 8200, 8300, 8400 models Ford type, CCOT (Brown) Orifice Tube with accumulator system,
RE51969 RD-5-10013-0P 71R8506
with OE#RE51969 main unit
Tractors 9000 Series, 9100, 9200, 9300, 9400 models Ford type, CCOT (Brown) Orifice Tube with accumulator system,
RE51969 RD-5-10013-0P 71R8506
FILTER
Fresh air frame filter, 14 1⁄2" x 5" x 2 1⁄4" 873878 RD-5-8105-0P 78R5315
Red Dot A/C unit R-9450-3
Recirculating (unframed foam element), 14 3⁄4" x 3 1⁄2" x 1⁄2" RD-5-8106-0 RD-5-8106-0P 78R5375
Red Dot A/C unit R-9450
Fresh air frame filter, 17 1⁄2" x 5 1⁄2" x 3⁄8" 97026234 RD-5-8076-0P 78R5360
R-9500
HEATER
Backhoe Loader 310E, 410E, 510E, 710E with Red Dot
Core: 10 7⁄64" high x 13" long x 2 5⁄32" wide RD-1-1370-0 RD-1-1370-0P 76R3455
A/C unit R-9450-3
Core: 6 7⁄64" high x 23 29⁄64" long x 1 1⁄2" wide RD-1-1478-0 RD-1-1478-0P 76R4200
A/C unit R-9475
PRESSURE SWITCH
High Pressure Fan switch with M10 threads, opens 300 psi,
All Loader / Tractor model series with OE#AR45868 AR45868 RD-5-8287-0P 71R6210
closes 250psi
Backhoe Loader / Tractor 310D, 410D, 510D with Red
Dot A/C unit R-10011-0, -1
Backhoe Loaders 310E, 410E, 510E, 710E with Red Dot
Low pressure, normally open, metripak connector RD-5-8982-0 RD-5-8982-0P 71R6055
A/C, OE#RD-5-8982-0
R-10025-1
Backhoe Loader 344G, 444G with Red Dot model
R-10036-0
Backhoe Loader 490E, 690E, 790E, 792D, 892E, 992E,
with Red Dot A/C unit R-10035
Backhoe Loader / Tractor 544E, 624E, 644E with Red
All with Fujikoki binary sw with 7⁄16-20, 4 terminal A22-36474-000 RD-5-8433-0P 71R7075
Dot A/C unit R-10150
Low pressure, normally open, metripak connector RD-5-8982-0 RD-5-8982-0P 71R6055
A/C unit R-9475
Excavators 110, 120, 160LC, 200, 450LC with Red Dot
A/C unit R-10034-0
Wheel Loader 304H, 324H, 344H with Red Dot R-10050 Dual function switch (GM), Open: low 20-33, high 315-355,
RD-5-9577-0 RD-5-9577-0P 71R6150
model evaporator Closed: low 23-37, high 215-275
R-10060, OE#RD-5-4640-0
Wheel Loader 544G, 624G, 644G with Red Dot A/C,
OE#RD-5-4640-0
Wheel Loader 744E with Red Dot A/C unit R-10040-0 Binary 7⁄16"-20 UNF female, Schrader type valve RD 5 4640 0 RD-5-4640-0P 71R7050
PAGE 221
JOHN DEERE
RECEIVER DRIER
AH114865, AT125596,
All Loader / Tractor model series with OE#AH114865,
#6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator AT151981, AT162848, RD-5-9055-0P 74R4206
AT125596, AT151981, AT162848, AT63170
AT63170
All Loader / Tractor model series with OE#AR45867 with #6 Male flare, 3" X 6 ⁄4" 1
AR45867 RD-5-4954-0P 74R2406
AR59780, AR74486,
All Loader / Tractor model series with OE#AR59780,
In Line drier with #6 Female to Male O-Ring, 4" x 8" RE49169, AL77581, RD-5-8862-0P 74R0400
AR74486, RE49169, AL77581, AR79486
AR79486
with #6 Male /Female O-Ring (top and bottom), 4" X 7 ⁄4" 3
RD-5-11028-0 RD-5-11028-0P 74R4026
OE#RD-5-11028-0
All Loader / Tractor model series with OE#RE79486 with #6 Male Flare (top and side), 4" X 6 3⁄4" RE79486 RD-5-6077-0P 74R4016
All Wheel Loader series with Red Dot A/C,
with #6 Male O-Ring, 3" x 10", fuse, top port RD-5-6504-0 RD-5-6504-0P 74R2306
OE#RD-5-6504-0
Backhoe Loader / Tractor 310E, 310G, 310SG, 410E,
#6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator RD-5-9055-0 RD-5-9055-0P 74R4206
410G, 510E, 710E series with OE#RD-5-9055-0
Backhoe Loader / Tractor 544E, 624E, 644E with Red
Dot A/C unit R-10150
Combines 3300, 4400, 4420, 4425, 4435, 6600, 6620,
In Line drier with #6 Female to Male O-Ring, 4" x 8" RE49169 RD-5-8862-0P 74R0400
7700, 7720, 8820 with OE#RE49169
Combines 4445, 7440, 7445, 7721, 7772, 9400, 9410,
9450, 9500, 9510, 9550, 9600, 9610, 9650, 9750, 9930, #6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator AH114865, AT162848 RD-5-9055-0P 74R4206
9950
Construction Series #6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator RD-5-9055-0 RD-5-9055-0P 74R4206
Cotton Pickers 9900, 9910, 9920, 9930, 9940, 9950, Horizontal mount, in Line drier with #6 Female to Male O-Ring,
RE49169 RD-5-8862-0P 74R0400
9960, 9965 series with OE#RE49169 4" x 8"
Cotton Pickers 9900, 9910, 9920, 9930, 9940, 9950, Vertical mount, #6 Male O-Ring to #6 Female O-Ring, 4" x 8",
AH114865, AT162848 RD-5-9055-0P 74R4206
9960, 9965 series with OE#RE49169 moisture indicator
A/C unit R-9475
#6 Male O-Ring, 2 3⁄4" x 9 5⁄8", hi capacity, pressure relief RD-5-7062-1 RD-5-7062-1P 74R1826
R-9500
Sprayers 4700, 4710 series with OE#RE49169 In Line drier with #6 Female to Male O-Ring, 4" x 8" RE49169 RD-5-8862-0P 74R0400
Sprayers 6000, 6100, 6500, 6600, 6700, 6800, 6900
series with OE#RE49169
Tractors 10 series, 6010, 6110, 6210, 6310, 6410 with
OE#RE49169
Tractors 10 Series, 7010, 7210, 7410, 7610, 7710, 7810
Tractors 10 Series 8000, 8110, 8110T, 8210, 8210T,
#6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator AH114865, AT162848 RD-5-9055-0P 74R4206
8310, 8310T models
Tractors 20 Series, 4020, 4320, 4520, 4620, 5020, 7020,
with #6 Male flare, 3" x 6 1⁄4" AR45867 RD-5-4954-0P 74R2406
7520 models with OE#AR45867
Tractors 30 Series, 4030, 4230, 4430, 4630, 6030, 8430,
8630 models with OE#RE49169
Tractors 40 Series, 4040, 4240, 4440, 4640, 4840,
8440, 8640 models with OE#RE49169
Tractors 50 Series, 4050, 4250, 4450, 4650, 4850
Tractors 55 Series, 3055, 3255, 3355, 4055, 4255, 4455,
4555, 4755, 4955 models with OE#RE49169
Tractors 60 Series, 4560, 4760, 4960 models with
OE#RE49169
Tractors 80 Series #6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator RD-5-9055-0 RD-5-9055-0P 74R4206
OE#RE49169
PAGE 222
JOHN DEERE
RECEIVER DRIER
Tractors 6005, 7005 Series, 6405, 6605, 7405 models
In Line drier with #6 Female to Male O-Ring, 4" x 8" AL153705 RD-5-8862-0P 74R0400
with OE#AL153705
Tractors 6020 Series, 6120, 6220, 6320, 6420 models
with OE#AL153705
Tractors 7000 Series, 7200, 7400, 7600, 7700, 7800
with OE#AL153705
Tractors 8000 Series, 8100, 8200, 8300, 8400 models #6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator AH114865, AT162848 RD-5-9055-0P 74R4206
Tractors 8020, 8020T Series, 8020, 8120, 8220, 8320,
8420, 8520 models with OE#AL153705
with OE#RE49169
O-Ring Type, hi cap, pressure relief, moisture indicator, 3" x 6 1⁄4" RD-5-9419-0 RD-5-9419-0P 74R2590
unit R-9777-1, OE#RD-5-9419-0
Hi Cap #6 Male O-Ring with schrader, pressure relief, 3" x 6 1⁄4" RD-5-7061-1 RD-5-7061-1P 74R2536
unit R-10060, OE#RD-5-7061-1
Wheel Loaders 544G, 624G, 644G, 744E with Red Dot
O-Ring Type with side port, top glass, moisture indicator 221RD32 RD-5-7272-0P 74R2546
A/C unit R-10040
Wheel Loaders 544G, 544H, 624G, 624H, 644G, 644H,
724J, 744E, 744H, 824J with Red Dot A/C unit R-9475
Windrowers / Sprayers 4890, 4990, 4995 series with
OE#RE49169
Windrowers / Sprayers 5200, 5400, 5440, 5460, 5720,
#6 Male O-Ring to #6 Female O-Ring, 4" x 8", moisture indicator AH114865, AT162848 RD-5-9055-0P 74R4206
5730, 5820, 5830 series
Windrowers / Sprayers 5200, 5400, 5440, 5460, 5720,
5730, 5820, 5830 series with OE#RE49169
All Loader / Tractor model series with OE#A78583,
Main Unit with Accumulator, female O-Ring, 3 1⁄2" X 9 1⁄2" A78583, RE24620 RD-5-10927-0P 74R5061
RE24620
Universal Accumulator, female O-Ring, 3 1⁄2" X 8" RE24620 RD-5-4061-0P 74R5050
OE#RE24620
RELAY
All Loader / Tractor model series with Bosch relay,
Bosch type (30 amp), SPST, 5 terminals 0332-209-169 RD-5-4408-0P 71R1702
OE#0332-209-169
All Loader / Tractor model series with Hella relay,
Hella type, SPST, 5 terminals 960-388-25 RD-5-4408-0P 71R1702
OE#960-388-25
Resister
Red Dot A/C
Crawler Dozer 450H, 550H, 650H with Red Dot A/C unit Ceramic tube style fan resistor, 4 terminal, 12V, 6 1⁄2" length x 1
RD-5-8665-0 RD-5-8665-0P 71R1485
R-9475-0, OE#RD-5-8665-0 3
⁄16" diam
Crawler Dozer 700H with Red Dot A/C, Ceramic tube style fan resistor, (white), 4 terminal, 12V, 7"
RD-5-9062-0 RD-5-9062-0P 71R1480
OE#RD-5-9062-0 length x 1 1⁄4" diam
Excavators 110, 120, 160LC with Red Dot A/C, OE#RD-
5-3647-0P
Blower assembly fan resistor, 3 speed, 4 terminal 20604004, RD-5-9437-0 RD-5-9437-0P 71R1402
models R-1400, R-1620, R-2550, R-2820, R-9777
THERMOSTATIC SWITCH
All Loader / Tractor model series using clutch cycling
Rotary thermostat, 36" capillary tube, 34 - 52°F AR49960 RD-4125-36P 71R2250
switch with OE#AR49960
All Loader / Tractor model series with OE#AH80197 Rotary thermostat with 48" capillary tube, 34 - 52°F AH80197 RD-4125-48P 71R2300
All Loader / Tractor model series with OE#AR59779 Rotary thermostat, 36" capillary tube, 34 - 52°F AR59779 RD-4125-36P 71R2250
PAGE 223
JOHN DEERE
THERMOSTATIC SWITCH
Excavators 110, 120, 160LC, 200, 450LC with Red Dot Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
A/C unit R-10034-0 capillary tube, flange/side mt.
Backhoe Loader / Tractor 310D, 310E, 410D, 410E, 510D Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
with Red Dot A/C unit R-10011-0, -1 capillary tube, flange/side mt.
Backhoe Loader 344E, 444E with Red Dot A/C unit Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
R-10025-1 capillary tube, flange/side mt.
Backhoe Loader 344G, 444G with Red Dot model Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
Backhoe Loader 490E, 510E, 690E, 710E, 790E, 792D, Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
892E, 992E with Red Dot A/C unit R-10035 capillary tube, flange/side mt.
Crawler Dozer 450H, 550H, 650H, 700H with Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
OE#RD-5-4531-24 capillary tube, flange/side mt.
Wheel Loaders 304H, 324H, 344H OE#AR49960,
Rotary thermostat, 36" capillary tube, 34 - 52°F AR49960, AR59779 RD-4125-36P 71R2250
AR59779
Wheel Loaders 444H, 544H, 624H with Red Dot A/C Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
unit R-10060 capillary tube, flange/side mt.
Wheel Loaders 544G, 624G, 644G with Red Dot model Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
Thermostat for standard control units, fixed setting with 24"
Wheel Loader 744E with Red Dot A/C unit R-10040-0 RD-5-4531-24P RD-5-4531-24P 71R3200
capillary tube, flange/side mt.
WATER VALVE
All Loader / Tractor model series with Red Dot A/C
Cable operated valve (pull to open), 5⁄8" to 5⁄8" hose RD-5-8193-1 RD-5-8193-1P 72R5357
models R-9450, OE#RD-5-8193-1
Red Dot A/C model R-9450, OE#RD-5-8193-2
Crawler Dozer 450H, 550H, 650H with Red Dot A/C
Electronic water valve, 12V, 5⁄8" to 5⁄8" hose connections RD-1-1746-0 RD-1-1746-0P 72R6562
model R-9475-0, OE#RD-1-1746-0P
Loader / Tractor (Small Track Type) with
OE#RD-5-10055-0
Wheel Loaders 324H, 344H with Red Dot A/C model Cable operated valve with flow restrictor, (push to open), 5⁄8"
RD-5-9224-1 RD-5-9224-1P 72R5285
R-9777-1, OE#RD-5-9224-1 to 5⁄8" hose
KOBELCO
BLOWER MOTOR
Excavator SK100 with Red Dot A/C model #R-1550-1P Red Dot A/C, 24V single shaft motor, 1 speed, 4 3⁄4" length 20193P1, 20303P RD-5-8073-24P 73R0474
Excavator SK115 with Red Dot A/C model #R-1550-2P Red Dot A/C, 24V single shaft motor, 1 speed, 4 3⁄4" length 20193P1, 20303P RD-5-8073-24P 73R0474
Excavator SK120, 150, 200, 220, 270 (early serial
Red Dot A/C, 24V single shaft motor, 1 speed, 4 3⁄4" length 20193P1, 20303P RD-5-8073-24P 73R0474
numbers)with Red Dot A/C model R-1550-1P
Excavator SK120, 150, 200, 220, 270 (late serial
Excavator SK300, 400 (early & late serial numbers)
with Red Dot A/C model #R-1550-2P
Excavator SK100 with Red Dot A/C model #R-1550-1P Blower Resistor, Red Dot A/C units, 3 terminal, 3 speed RD-5-3647-0 RD-5-3647-0P 71R1450
CLUTCH ASSEMBLY
Excavator SK100 with Red Dot A/C model #R-1550-1P,
Sanden SD5 R-12 compressor
PAGE 224
KOBELCO
CLUTCH ASSEMBLY
Sanden SD5 R-12 compressor
numbers)with Red Dot A/C model R-1550-1P, Sanden 2 groove, 24V, 5 1⁄4" (132mm) diameter pulley, 1⁄2" width, 1 wire 6519-6210, 6514-6210 RD-5-5487-0P 75R0204
SD5 R-12 compressor
numbers)with Red Dot A/C model R-1550-2P, Sanden 2 groove, 24V, 5 1⁄4" (132mm) diameter pulley, 1⁄2" width, 1 wire 6519-6210, 6514-6210 RD-5-5487-0P 75R0204
SD5 R-12 compressor
with Red Dot A/C model #R-1550-2P, Sanden SD5 R-12 2 groove, 24V, 5 1⁄4" (132mm) diameter pulley, 1⁄2" width, 1 wire 6519-6210, 6514-6210 RD-5-5487-0P 75R0204
compressor
COMPRESSOR - SANDEN
5H14-HD, 24V, FL head, 2A groove, 5 1⁄4" (132mm) diameter 6665 RD-5-7089-0P 75R8384
Sanden 5H14, #6665
Excavator SK115 with Red Dot A/C model #R-1550-2P
with Red Dot A/C model R-1550-2P with Sanden 4537, 6634 RD-5-8680-0P 75R8354
diameter
5H14HD, #4537, 6634
numbers)with Red Dot A/C model R-1550-1P, Sanden 5H14-HD, 24V, FL head, 2A groove, 5 1⁄4" (132mm) diameter 6665 RD-5-7089-0P 75R8384
5H14, #6665
numbers) with Red Dot A/C model R-1550-2P with 4537, 6634 RD-5-8680-0P 75R8354
diameter
Sanden 5H14HD, #4537, 6634
with Red Dot A/C model #R-1550-2P, Sanden 5H14HD, 4537, 6634 RD-5-8680-0P 75R8354
diameter
#4537, 6634
CONDENSER
Excavator SK100 with Red Dot A/C model #R-1550-1P Tube & fin type, 20 1⁄2" x 18 1⁄4" x 1 13⁄16" RD-4-5154-0 RD-4-5154-0P 77R7010
Excavator SK115 with Red Dot A/C model #R-1550-2P Tube & fin type, 20 1⁄2" x 18 1⁄4" x 1 13⁄16" RD-4-5154-0 RD-4-5154-0P 77R7010
Tube & fin type, 20 1⁄2" x 18 1⁄4" x 1 13⁄16" RD-4-5154-0 RD-4-5154-0P 77R7010
Tube & fin type, 20 1⁄2" x 18 1⁄4" x 1 13⁄16" RD-4-5154-0 RD-4-5154-0P 77R7010
RD-4-5116-0 RD-4-5116-0P 77R7020
EVAPORATOR
Excavator SK100 with Red Dot A/C model #R-1550-1P Dimensions: 8" height x 11 1⁄2" length x 3 13⁄32" width RD-2-2762-0 RD-2-2762-0P 76R6430
Excavator SK100 with Red Dot A/C model #R-1550-1P Block valve with female O-Ring fittings RD-5-6868-0 RD-5-6868-0P 71R8301
Excavator SK115 with Red Dot A/C model #R-1550-2P Block valve with female O-Ring fittings RD-5-6868-0 RD-5-6868-0P 71R8301
PAGE 225
KOBELCO
FILTER ASSEMBLY
CLUTCH
Excavator SK100 with Red Dot A/C model #R-1550-1P Fresh air frame filter, 10 3⁄4" x 2 13⁄16" x 11⁄32" RD-5-8078-0 RD-5-8078-0P 78R5365
Excavator SK115 with Red Dot A/C model #R-1550-2P Fresh air frame filter, 10 3⁄4" x 2 13⁄16" x 11⁄32" RD-5-8078-0 RD-5-8078-0P 78R5365
Fresh air frame filter, 10 3⁄4" x 2 13⁄16" x 11⁄32" RD-5-8078-0 RD-5-8078-0P 78R5365
HEATER
PRESSURE SWITCH
Excavator SK100 with Red Dot A/C model #R-1550-1P Binary 7⁄16"-20 UNF female, Schrader type valve RD 5 4640 0 RD-5-4640-0P 71R7050
Excavator SK115 with Red Dot A/C model #R-1550-2P Binary 7⁄16"-20 UNF female, Schrader type valve RD 5 4640 0 RD-5-4640-0P 71R7050
numbers) with Red Dot A/C model R-1550-2P
RECEIVER DRIER
Excavator SK100 with Red Dot A/C model #R-1550-1P #6 Male O-Ring, 2 3⁄4" x 9 5⁄8", hi capacity, pressure relief RD-5-7062-1 RD-5-7062-1P 74R1826
Excavator SK115 with Red Dot A/C model #R-1550-2P #6 Male O-Ring, 2 3⁄4" x 9 5⁄8", hi capacity, pressure relief RD-5-7062-1 RD-5-7062-1P 74R1826
RESISTOR
THERMOSTATIC SWITCH
Excavator SK100 with Red Dot A/C model #R-1550-1P RD-5-4531-24P RD-5-4531-24P 71R3200
Excavator SK115 with Red Dot A/C model #R-1550-2P RD-5-4531-24P RD-5-4531-24P 71R3200
Excavator SK120, 150, 200, 220, 270 (early serial Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
numbers)with Red Dot A/C model R-1550-1P capillary tube, flange/side mt.
Excavator SK120, 150, 200, 220, 270 (late serial Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
numbers)with Red Dot A/C model R-1550-2P capillary tube, flange/side mt.
PAGE 226
KOBELCO
THERMOSTATIC SWITCH
Excavator SK300, 400 (early & late serial numbers) Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
with Red Dot A/C model #R-1550-2P capillary tube, flange/side mt.
WATER VALVE
for vehicles manuf. before 11/98
for vehicles manuf. before 11/98
Excavator SK120, 150, 200, 220, 270
(early serial numbers) with Red Dot A/C model R-1550- Cable operated valve (pull to open), 5⁄8" to 5⁄8" hose RD-5-8193-1 RD-5-8193-1P 72R5357
1P, for vehicles manuf. before 11/98
Excavator SK120, 150, 200, 220, 270
(late serial numbers) with Red Dot A/C model R-1550- Cable operated valve (pull to open), 5⁄8" to 5⁄8" hose RD-5-8193-1 RD-5-8193-1P 72R5357
2P, for vehicles manuf. before 11/98
with Red Dot A/C model #R-1550-2P, for vehicles Cable operated valve (pull to open), 5⁄8" to 5⁄8" hose RD-5-8193-1 RD-5-8193-1P 72R5357
manuf. before 11/98
Water valve replacement: For excavators manufactured before prior to 11/98, use water valve field installation kit RD-3-9191-0P
KOMATSU
BLOWER - FAN
Wheel Loader model series with remote mount
condenser, 12V fan
Wheel Loader model series with remote mount
condenser, 24V fan
Wheel Loader WA350 thru WA600 model series with
remote mount condenser, 24V fan
BLOWER MOTOR
All Loader / Tractor PC series models with remote
mount condenser (24V), OE#RD-5-5120-24
Bulldozer models D155A-1, D355A-3, OE#2807-405- Single shaft, 1 speed, 12V, CW / CCW, NV, 3 5⁄8" x 3" x 3", shaft
2807-405-046 RD-5-10394-0P 73R0002
046 length 1 3⁄4"
Excavator PC200-6, PC210-6, PC250-6 models,
Double shaft, 1 speed, 24V, vented, 4 13⁄16" x 4" x 3" 2809-530-013 RD-5-5121-2P 73R4264
OE#2809-530-013
Wheel Loader models, OE#404-825 Double shaft, 1 speed, 24V, vented, 4 13⁄16" x 4" x 3" 404-825 RD-5-5121-2P 73R4264
Wheel Loader / Tractor model series with remote
Single shaft motor (condenser motor), 12V, NV, 4 7⁄8" length RD-5-5120-0 RD-5-5120-0P 73R0512
Wheel Loader / Tractor model series with remote
Wheel Loader models 344G, 444G with Red Dot A/C
Red Dot A/C, 24V single shaft motor, 1 speed, CCW, 5" length RD-5-4827-24 RD-5-4827-24P 73R0404
model #R-10036-0P
BLOWER WHEEL
Excavator PC series with Red Dot A/C unit R-10015
series evaporator, OE#RD-5-7312-0
Excavator PC series with Red Dot A/C unit R-10015
series evaporator, OE#RD-5-7312-0
CLUTCH ASSEMBLY
All series with CCI/York - R12 / 134A compressors
OE#024-25078, MA6, MAE6AR
OE#332334, MA 7A
All series with CCI/York - R12 / 134A compressors 2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, weatherpak 024 25190, 03-1104973,
RD-5-4972-1P 75R1202
OE#024 25190, 03-1104973, 501939 plug 501939
All series with Sanden SD5 (508 / 510 / 5H14) R12/
R134a compressors
PAGE 227
KOMATSU
CLUTCH ASSEMBLY
OE #6504-6310
COMPRESSOR - SANDEN
All series with Sanden SD7H15 compressor #4652,
7H15, JD head, ear mount, 2A groove, 4.9"(125mm) diameter 1433064H91, Sanden 4652 RD-5-7124-0P 75R8424
Komatsu OE#1433064H91
Excavator PC series with Red Dot A/C unit R-10015-2,
-3 series evaporator, OE#RD-5-6868-0
Red Dot A/C unit R-10015-4 thru -7 series evaporator, Block valve with female O-Ring fittings RD-5-6868-0 RD-5-6868-0P 71R8301
OE#RD-5-6868-0
PRESSURE SWITCH
Excavator PC series with Red Dot A/C unit R-10015-2, RD-5-8433-0, A22-36474-
-3 series evaporator, OE#RD-5-8433-0 000
RD-5-8433-0, A22-36474-
Red Dot A/C unit R-10015-4 thru -7 series evaporator, Dual function switch (Fujikoki) with 7⁄16-20, 4 terminal RD-5-8433-0P 71R7075
000
OE#RD-5-8433-0
RECEIVER DRIER
In-line, #6 Male O-Ring, 2 1⁄2" x 9 9⁄16" RD-5-7064-0 RD-5-7064-0P 74R0460
-3 series evaporator, OE#RD-5-7064-0
Red Dot A/C unit R-10015-4 thru -7 series evaporator, RD-5-7064-0 RD-5-7064-0P 74R0460
OE#RD-5-7064-0
THERMOSTATIC SWITCH
Fixed Setting thermostat with 24" capillary tube, flange mt. 404145 RD-4427-24P 71R3100
-3 series evaporator, OE#RD-4424-24
Red Dot A/C unit R-10015-4 thru -7 series evaporator, 404145 RD-4427-24P 71R3100
OE#RD-4424-24
LINKBELT
BLOWER MOTOR
Excavator 4300, 5800, 6000 series with Red Dot A/C
Blower assembly, 3 speed, 24V, 13 3⁄4" x 5 3⁄8" x 5 1⁄8" RD-5-8583-1 RD-5-8583-1P 73R5554
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-8583-1
Resistor, 3 speed for blower assembly RD-5-9445-0 RD-5-9445-0P 71R1401
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-9445-0
CLUTCH ASSEMBLY
Excavator 4300, 5800, 6000 series with Tama CH,
24V, 2 groove 1⁄2" width, 5 21⁄64" diameter (135mm), bullet plug 511868, 524-19724, KA1025 RD-5-10232-0P 75R0274
TM15, TM16 compressors
Excavator 4300, 5800, 6000 series with Red Dot A/C,
ICE-Seltec TM15, D head, ear mount, 2 groove, 5 1⁄4"(135mm) 488-45015, 2521153 RD-5-7163-0P 75R8614
Seltec TM15 R134a compressors
CONDENSER
Multiflow type, 22 13⁄16" x 14" x 3⁄4" RD-4-5418-0 RD-4-5418-0P 77R1300
unit R-1620-1-24P, R-1625-0-24P, OE#RD-4-5418-0
EVAPORATOR
unit R-1620-1-24P, R-1625-0-24P, OE#RD-2-3070-0
Block valve, hi-capacity, 2 ton, female O-Ring RD-5-7015-0 RD-5-7015-0P 71R8321
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-7015-1
PAGE 228
LINKBELT
PRESSURE
FILTER SWITCH
Fresh air frame filter, 15" x 8" x 1" RD-5-8582-0 RD-5-8582-0P 78R5240
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-8582-0
HEATER CORE
unit R-1620-1-24P, R-1625-0-24P, OE#RD-1-1603-0
PRESSURE SWITCH
Trinary switch, with male 3⁄8 -24, 4 terminal, normally open RD-5-4585-0 RD-5-4585-0P 71R7500
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-4585-0
RECEIVER DRIER
#6 Male O-Ring, 2 3⁄4" X 9 5⁄8" with pressure relief switch RD-5-3593-1 RD-5-3593-1P 74R1706
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-3593-1
RESISTOR - BLOWER FAN
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-9445-0
THERMOSTATIC SWITCH
Excavator 4300, 5800, 6000 series with Red Dot A/C Fixed Setting thermostat with 24" capillary tube, flange/side
RD-5-4531-24P RD-5-4531-24P 71R3200
unit R-1620-1-24P, R-1625-0-24P, OE#RD-5-4531-24 mt.
WATER VALVE
Electronic water valve, 24V, 5⁄8" hose with actuator RD-1-1419-2 RD-1-1419-2P 72R6554
unit R-1620-1-24P, R-1625-0-24P, OE#RD-1-1419-2
MASSEY FERGUSON
BLOWER MOTOR
Combines 410, 510, 540, 550 series, Massey Ferguson
Single shaft, 2 speed, 12V, CCW, 4 1⁄4" length, vented 274939M1 RD-3106-13P 73R0602
OE#274939M1
Combines 750, 760, 850, 860, 865 series, condenser
Single shaft, 1 speed, 12V, CW, 4 3⁄4" length, vented RD-5-6526-0 RD-5-6526-0P 73R0422
motor, OE#RD-5-6526-0
Combines 8570, 8590 - with Kysor A/C, evaporator Kysor A/C (evaporator blower), double shaft motor, 1 speed,
107195M91 RD-5-10068-0P 73R4322
blower 12V, 4 7⁄8" length
Combines 8680, 8780 - with Kysor A/C, evaporator Kysor A/C (evaporator blower), double shaft motor, 1 speed,
70257336-1 RD-5-10068-0P 73R4322
blower 12V, 4 7⁄8" length
BLOWER SWITCH
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 271105M1 RD-5-10934-0P 71R1163
OE#271105M1
CLUTCH ASSEMBLY
2 groove 6" diameter pulley, 1⁄2" width, 1 5⁄8" ga, bullet plug 165129C1, 024-25078 RD-5-4967-0P 75R0452
OE#165129C1
1 groove, 6 3⁄4" diameter pulley, 3⁄4" width, 2 3⁄4" ga., bullet plug 250375M91, 03-1105003 RD-5-4993-0P 75R4352
OE#250375M91
All series with CCI/York - R12 / 134A compressors, 274363M91, A22-11669,
1 groove, 6 3⁄4" diameter pulley, 5⁄8" width, 3 1⁄8" ga., bullet plug RD-5-4981-0P 75R2552
OE#274363M91 502736
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 470039M91, 332334, MA 7A RD-5-4994-0P 75R4502
OE#470039M91
Combines 410, 510 series, fits CCI/York Rotolock
1 groove, 6 3⁄4" diameter pulley, 1⁄2" width, 2 3⁄4" ga., bullet plug L50-2393, 502393 RD-5-4984-0P 75R3002
compressors ER210 series
Combines 750, 760 series, fits CCI/York Rotolock
compressors F210 series
Combines 8450, 8460, 8590 series with CCI/York
2 groove 7" diameter pulley, 12V, 1⁄2" width, 2" ga, bullet plug 470039M91, 332334, MA 7A RD-5-4994-0P 75R4502
Rotolock compressor ER, R210L-25149
Tractors 300 series 362, 375, 383, 390, 393, 398, 399
with MF diesel, fits Rotolock compressors F210 series
Tractors 300 series 362, 375, 383, 390, 393, 398, 399
with Perkins diesel, fits Sanden SD510 compressors
PAGE 229
MASSEY FERGUSON
WATER
CLUTCHVALVE ASSEMBLY CYCLING SWITCH
Rotary thermostat with 48" capillary tube, 34 - 52°F D45093000 RD-4125-48P 71R2300
OE#D45093000
All series with CCI/York Tecumseh Rotolock
compressor # ER, R210L-25149. Massey Ferguson
OE#026088M91, 034589M1, 042405M91, 237412M91,
250951M91, 269925M91, 1042505M91
All series with CCI/York - Tube O-Ring compressor 1026088M91, ET210L-
ET210L-25150C, OE#1026088M91 25150C
All series with CCI/York Tecumseh Rotolock
compressor # 99242-5
All series with CCI/York - Tube O-Ring compressor #
Tube O-Ring type head without clutch, (generic, new) 99244-5 RD-5-8638-1P 75R7290
99244-5
Combines 410, 510 series with CCI/York Tecumseh
Rotolock compressor ER, R210L-25149
Combines 8450, 8460, 8590 series with CCI/York
Tecumseh Rotolock compressor ER, R210L-25149
COMPRESSOR - GM
All series with universal GM A6 with Superheat switch 1 groove 1⁄2" width, 4 7⁄8" diameter (124mm),
1131243 RD-5-5000-0P 75R8102
port, without oil, OE#1131243 generic, 12V
All series with new GM A6R without Superheat switch GM A6 24V, CW, 1 groove 1⁄2" width, 7" diameter,
1131243 RD-5-7566-0P 75R8184
port, without oil, OE#1131243 metric threads, new, 12V
Combines 540, 550, 750, 760 series with universal GM 1 groove 1⁄2" width, 4 7⁄8" diameter (124mm),
1131243 RD-5-5000-0P 75R8102
A6 with Superheat switch port, OE#1131243 generic, 12V
Combines 850, 860, 865 series with universal GM A6 1 groove 1⁄2" width, 4 7⁄8" diameter (124mm),
1131243 RD-5-5000-0P 75R8102
with Superheat switch port, OE#1131243 generic, 12V
Tractors 1085, 1105, 1135, 1155 series with universal 1 groove 1⁄2" width, 4 7⁄8" diameter (124mm),
1131243 RD-5-5000-0P 75R8102
GM A6 with Superheat switch port, OE#1131243 generic, 12V
Tractors 2640, 2675, 2705, 2745, 2775 series with
1 groove 1⁄2" width, 4 7⁄8" diameter (124mm),
universal GM A6 with Superheat switch port, 1131243 RD-5-5000-0P 75R8102
generic, 12V
OE#1131243
Tractors 4800, 4840, 4880 series with universal GM A6 1 groove 1⁄2" width, 4 7⁄8" diameter (124mm),
1131243 RD-5-5000-0P 75R8102
with Superheat switch port, OE#1131243 generic, 12V
COMPRESSOR - SANDEN
All series with Sanden 7H15, #4643 R134a compressor Sanden 7H15, CB head, ear mt., 2 goove, 5 1⁄4" (132mm) 4643 RD-5-10292-0P 75R84552
ELECTRICAL SWITCH
All combine and tractor model series with 1034565M91, 250698M1,
Rotary thermostat with 48" capillary tube, 34 - 52°F RD-4125-48P 71R2300
OE#1034565M91, 250698M1, 320059M2 320059M2
Rotary switch, 3 speed, DP3T, 4 position, 5 terminal 271105M1 RD-5-10934-0P 71R1163
OE#271105M1
Rotary thermostat with 48" capillary tube, 34 - 52°F D45093000 RD-4125-48P 71R2300
OE#D45093000
Combines 750, 760, 850, 860, 865, 885 series with
Block valve with female O-Ring fittings 284238M1 RD-5-6868-0P 71R8301
OE#284238M1
Combines 8775 thru 9745 series with OE#3902334M91 Block valve with female O-Ring fittings 3902334M91 RD-5-7015-0P 71R8321
Tractor 4200 Series 4220, 4225, 4245, 4255
Block valve with female O-Ring fittings 3901517M1 RD-5-7015-0P 71R8321
OE#3901517M1
EXPANSION VALVE / External Equalizer
All combine and tractor model series with Male O-Ring with 13" capillary length, 13" equalizer tube
3038918M91, 3321511M91 RD-5-3824-1P 71R8100
OE#3038918M91, 3321511M91 length
Tractor 3500 Series 3505, 3525, 3545 before serial Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
3380223M1 RD-5-5862-0P 71R8080
#C21009 with OE#3380223M1 length
PAGE 230
MASSEY FERGUSON
PRESSURE
EXPANSION SWITCH
VALVE / INTERNAL EQUALIZER
All combine and tractor model series with Internal equalizer with male flare with 9" capillary length, flare
1024984M92, 529876M91 RD-5-6099-0P 71R8210
OE#1024984M92, 529876M91 fittings
Internal equalizer, 1 1⁄2 Ton, Male O-Ring 3478520M91 RD-5-10445-0P 71R8220
OE#1034564M91, 237409M1
Combines 410, 450, 540, 550 series with Internal equalizer with male flare with 9" capillary length, flare
3038920M9, M91 RD-5-6099-0P 71R8210
OE#3038920M9, M91 fittings
Combines 750, 760, 850, 860, 865 series with Internal equalizer with male flare with 9" capillary length, flare
3038920M9, M91 RD-5-6099-0P 71R8210
Tractors 300 series 362, 375, 383, 390, 393, 398, 399
Internal equalizer, 1 1⁄2 Ton, Male O-Ring 3478520M91 RD-5-10445-0P 71R8220
with OE#3478520M91
Tractors 1000, 1085, 1100, 1105, 1130, 1135, 1155 Internal equalizer with male flare with 9" capillary length, flare
3038920M9, M91 RD-5-6099-0P 71R8210
series with OE#3038920M9, M91 fittings
Tractors 2600, 2640, 2675, 2700, 2705, 2745, 2775 Internal equalizer with male flare with 9" capillary length, flare
3038920M9, M91 RD-5-6099-0P 71R8210
series with OE#3038920M9, M91 fittings
Tractors 4800 series 4800, 4840, 4880 with Internal equalizer with male flare with 9" capillary length, flare
3038920M9, M91 RD-5-6099-0P 71R8210
PRESSURE SWITCH
All combine and tractor model series using high High Pressure Switch, normally closed 210psi, opens 340 psi, 1⁄4"
111266C1 RD-5-5873-0P 71R6070
pressure switch, OE#111266C1 female flare
All combine and tractor model series using normally
Trinary Switch, 3 speed, (on-off circuit closed) BA1240, RD-5-4625-0 RD-5-4625-0P 71R7650
closed trinary pressure switch
All combine and tractor model series using normally Trinary switch with female 7⁄16-20, 4 terminal (on-off circuit
A06-18015-000 RD-5-4583-0P 71R7550
open trinary pressure switch open)
RECEIVER DRIER
OE#088423-00
All combine and tractor model series with Male & Male O-Ring with Fuse Plug, Low Pressure Switch, use
3347710M1 RD-4160-1P 74R2106
OE#3347710M1 with flare adapters
with #6 Male O-Ring, 3" x 6 1⁄4" RD-5-7061-2P 74R2526
OE#284208M92, 3712495M1, 376335M1 376335M1
Combines 410, 450, 540, 550, 750, 760 series before
#6 Male flare, 3" X 6 1⁄4", fuse 250929M91 RD-5-4954-0P 74R2406
serial #17462474, OE#250929M91
Combines 760 series after serial #17462474,
with #6 Male O-Ring, 3" x 6 1⁄4" 237411M91 RD-5-7061-2P 74R2526
OE#237411M91
Combines 850, 860, 865 series with OE#284208M92 #6 Male O-Ring, 4" x 7 1⁄2", fuse, side port, moisture indicator 284208M92 RD-5-7565-0P 74R3536
Combines 2775 thru 2805 series with OE#1018462M91 Male O-Ring with fuse plug, side port, top glass 1018462M91 RD-5-4950-0P 74R0906
Combines 8450, 8460 series with OE#3347710W1 #6 Male O-Ring, 2 3⁄4" X 9 5⁄8", trinary switch (top) 3347710W1 RD-5-4632-1P 74R1906
Combines 8775, 8785, 9735, 9745 series with 284208M92, 3712495M1,
with #6 Male O-Ring, 3" x 6 1⁄4" RD-5-7061-2P 74R2526
OE#284208M92, 3712495M1, 376335M1 376335M1
Combines 8775, 8785, 9735, 9745 series with
OE#1034581M91
Combines 9690, 9790 with male O-Ring, 3" x 8 3⁄8", hi PH 088193-00, RD-5-
Male & Male O-Ring HPRV, MI IN CAP RD-5-11192-0P 74R2608
capacity 11192-0
Tractors 300 series 362, 375, 383, 390, 393, 398, 399
O-Ring Type with #6 male inlet and outlet 3383321M2 RD-5-10743-0P 74R1426
with R-12, OE#3383321M2
Tractors 300 series 362, 375, 383, 390, 393, 398, 399
with #6 Male O-Ring, 3" x 10", fuse, top port, moisture indicator 3763351M1 RD-5-6768-1P 74R3322
with R-134a, OE#3763351M1
Tractors 1000, 1085, 1100, 1105, 1130, 1135, 1155
series with OE#1034581M91
Tractors 2600, 2640, 2675, 2700, 2705, 2745, 2775
#6 Male O-Ring, 2 1⁄2" x 7 11⁄16", 1⁄4" male side port 3039149M91 RD-5-7559-0P 74R1106
series with OE#3039149M91
Tractors 3100 series 3120, 3140 with OE#3383321M2 O-Ring Type with #6 male inlet and outlet 3383321M2 RD-5-10743-0P 74R1426
Tractors 3500 series 3505, 3525, 3545 with
OE#338332M1
PAGE 231
MASSEY FERGUSON
RECEIVER DRIER
Tractors 3600 series 3660, 3670, 3680, 3690 with
OE#3383321M2
Tractors 4200 series 4220, 4225, 4245, 4255 with
Male O-ring Type with Switch Port and HPRV 3712495M1 RD-5-9789-0P 74R3106
OE#3712495M1
OE#1034581M91
OE#3712495M1
Tractors 6200 series 6245, 6250, 6255, 6260, 6265,
6270, 6280, 6290 with OE#3712495M1
OE#3712495M1
Tractors 8200 series 8210, 8220, 8240, 8245, 8250,
8260, 8270, 8280 with OE#3712495M1
THERMOSTATIC SWITCH
Rotary thermostat with 48" capillary tube, 34 - 52°F RD-4125-48P 71R2300
OE#1034565M91, 250698M1, 320059M2 320059M2
TAKEUCHI
BLOWER MOTOR
Backhoe BL70 with Red Dot A/C, OE#RD-5-8837-1 Blower Assembly, single speed, 12V, 12 1⁄4" x 3 1⁄8" x 4 1⁄2" RD-5-8837-1 RD-5-8837-1P 73R5642
Excavator TB1140 with Red Dot A/C unit R-2825-1-24,
Blower Assembly, three speed, 24V, 13 3⁄4" x 6 1⁄2" x 5" RD-5-9204-1 RD-5-9204-1P 73R5624
OE#R D-5-9204-1
Mini Excavator TB175 with Red Dot A/C unit R-20500, Blower Assembly (evaporator), three speed, 24V, 12 1⁄4" x 3 1⁄8"
RD-5-8838-0 RD-5-8838-0P 73R5534
OE#RD-5-8838-0 x 4 1⁄2"
BLOWER - FAN
Mini Excavator TB175 with Red Dot A/C unit R-20500,
Condenser pancake fan assembly, 24V, 1 speed, 13" x 13" x 3 3⁄4" RD-5-8747-5 RD-5-8747-5P 73R8654
condenser pancake fan OE#RD-5-8747-5
Backhoe BL70 with Red Dot A/C, OE#RD-5-6450-0 Fan speed blower resistor, 4 speed, 4 terminal RD-5-6450-0 RD-5-6450-0P 71R1455
OE#RD-5-9445-0
OE#RD-5-9448-0
COMPRESSOR - SANDEN
Excavator TB1140 with Sanden 7H15FLX #4870, Sanden 7H15FLX, GV head, ear mt., variable goove, 6 1⁄4"
4870, RD-5-10895-0 RD-5-10895-0P 75R89374
OE#RD-5-10895-0 (158mm)
Mini Excavator TB175 with Sanden 7H15, #4742,
Sanden 7H15-HD, KG head, ear mt., 2 goove, 4.9" (125mm) 4742, RD-5-9319-0 RD-5-9319-0P 75R84654
OE#RD-5-93190-0
Track Loader TL140, 150 with Sanden 5H09, #5077,
Sanden 5H09, K head, ear mt., 2 goove, 4.9" (125mm) 5077, RD-5-10493-0 RD-5-10493-0P 75R82142
OE#RD-5-10493-0P
CONDENSER
Multi Flow type, 16 1⁄4" fin width x 14" x 3⁄4" RD-4-5361-0 RD-4-5361-0P 77R1285
OE#RD-5-9204-1
Multi Flow type, 14" fin width x 14" X 7⁄8" RD-4-5722-0 RD-4-5722-0P 77R1275
OE#RD-4-5722-0
EVAPORATOR
Backhoe BL70 with Red Dot A/C, OE#RD-2-3741-0 Dimensions: 8" height x 11 1⁄2" length x 3 13⁄32" width RD-2-3741-0 RD-2-3741-0P 76R7730
Dimensions: 6 ⁄8" height x 16 ⁄2" length x 3 ⁄32" width
1 1 13
RD-2-3923-0 RD-2-3923-0P 76R7450
OE#RD-2-3923-0
OE#RD-2-3832-0
PAGE 232
TAKEUCHI
RECEIVER
EXPANSION DRIER
VALVE / BLOCK
Backhoe BL70 with Red Dot A/C, OE#RD-5-7015-0 Block valve with female O-Ring fittings RD-5-7015-0 RD-5-7015-0P 71R8321
OE#RD-5-6868-0
Main unit, orange tube, blue orifice with green HBNR RD-5-10011-0 RD-5-10011-0P 71R8504
OE#RD-5-10011-0
FILTER
Recirculating air foam filter, 16 5⁄16" x 5 3⁄4" x 1⁄2" RD-3-10331-0 RD-3-10331-0P 78R5301
OE#RD-3-10331-0
R-20500, OE#RD-3-10591-0
HEATER
OE#RD-1-2333-0
Dimensions: 6" height x 11" length x 2 3⁄16" width RD-1-2069-0 RD-1-2069-0P 76R2740
OE#RD-1-2069-0
PRESSURE SWITCH
Mini Excavator TB175 with Red Dot A/C unit R-1630, RD-5-8433-0, A22-36474-
R-20500, OE#RD-5-8433-0 000
RECEIVER DRIER
In-line Drier, 2 1⁄2" X 6 9⁄16" RD-5-4947-0 RD-5-4947-0P 74R0450
OE#RD-5-4947-0
In-line Drier, 2 1⁄2" X 6 9⁄16" RD-5-9389-0 RD-5-9389-0P 74R2800
OE#RD-5-9389-0
RESISTOR
Backhoe BL70 with Red Dot A/C, OE#RD-5-6450-0 Fan speed blower resistor, 4 speed, 4 terminal RD-5-6450-0 RD-5-6450-0P 71R1455
OE#RD-5-9445-0
OE#RD-5-9448-0
THERMOSTATIC SWITCH
Backhoe BL70 with Red Dot A/C, OE#RD-5-4531-24 RD-5-4531-24 RD-5-4531-24P 71R3200
Fixed Setting thermostat with 16" capillary tube, flange mt. RD-5-6429-0 RD-5-6429-0P 71R3150
OE#RD-5-6429-0
Mini Excavator TB175 with Red Dot A/C unit R-20500, Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24 RD-5-4531-24P 71R3200
OE#RD-5-4531-24 capillary tube, flange/side mt.
WATER VALVE
Cable operated for standard control units, 5⁄8" hose to 5⁄8" hose RD-4257-0 RD-4257-0P 72R5050
OE#RD-4257-0
Cable operated for standard control units, 5⁄8" hose to 5⁄8" hose RD-4257-0 RD-4257-0P 72R5050
OE#RD-4257-0
TEREX
CLUTCH ASSEMBLY
OE#024-25078, MA6, MAE6AR
OE#332334, MA 7A
All series with CCI/York Tecumseh Rotolock ER,
R210L-25149 compressor
PAGE 233
TEREX
Tube O-Ring type head without clutch, (universal - new) ET210L-25150C RD-5-8638-1P 75R7290
ET210L-25150C
COMPRESSOR - GM
All series with GM A6 compressor with Superheat 0259362-2, 1131243,
switch port, without oil 509170-C91
All series with new GM A6R without Superheat switch GM A6 24V, CW, 1 groove ⁄2" width, 7" diameter, metric threads,
1
1131274 RD-5-7566-0P 75R8184
port, without oil, OE#1131274 new
All model series with OE#9053997 9053997 RD-5-3824-1P 71R8100
length
RECEIVER DRIER
All model series with OE#RD-5-7559-0, Eagle A/C #6 Male O-Ring, 2 1⁄2" x 7 11⁄16", 1⁄4" male side port RD-5-7559-0 RD-5-7559-0P 74R1106
All model series using Red Dot A/C unit R-10046-0,
#6 Male O-Ring, 2 ⁄2" x 7 ⁄16", ⁄4" male side port
1 11 1
088273-00 RD-5-7559-0P 74R1106
R-10047-0, OE#088273-00
THERMOSTATIC SWITCH
All model series with OE#9038467 Rotary thermostat with 18" capillary tube, 28 - 62°F 9038467 RD-5-4909-0P 71R2100
All model series with Red Dot A/C, OE#RD-4226-0P Cable controlled thermostat, 30" capillary tube, 34 - 54°F RD-4226-0P RD-4226-0P 71R2700
TIMBERJACK
BLOWER MOTOR
Feller Buncher 608L, 608S, 850 with Red Dot A/C unit
Blower Assembly, three speed, 24V, 13 3⁄4" x 6 1⁄2" x 5" RD-5-9204-1 RD-5-9204-1P 73R5624
R-2825-0, OE#RD-5-9204-1
Skidder series models with Red Dot model R-9725-0,
Double shaft motor, 12V, 3 speed, 4" length RD-5-3780-0 RD-5-3780-0P 73R4102
R-9755-0, OE#RD-5-3780-0
Skidder series models, condenser motor,
Single shaft, 1 speed, 12V, CW, 4 3⁄4" length, vented RD-5-8709-0 RD-5-8709-0P 73R0562
OE#RD-5-8709-0
R-2825-0, OE#RD-5-9445-0
CONDENSER
Feller Buncher 608L, 608S with Red Dot A/C unit
Grilldenser type, fin width 37" x 33 5⁄8" x 1 1⁄2" thick RD-4-5655-0 RD-4-5655-0P 77R6255
R-2825-0, OE#RD-5-9204-1
Feller Buncher 850 with Red Dot A/C unit R-2825-0,
Grilldenser type, fin width 31 7⁄8" x 34 19⁄32" x 1 9⁄64" thick RD-4-5743-0 RD-4-5743-0P 77R6250
OE#RD-4-5743-0
Tube & Fin type, fin width 18 1⁄2" x 7 3⁄32" x 2 1⁄2" thick RD-4-4440-0 RD-4-4440-0P 77R0090
R-9755-0, OE#RD-4-4440-0
EVAPORATOR
R-2825-0, OE#RD-5-9204-1
R-9755-0, OE#RD-2-2047-0
Block valve, 1 1⁄2 ton, female O-Ring, 80 psig @ 40°F RD-5-6868-1, 1676649-C1 RD-5-6868-0P 71R8301
R-9755-0, OE#RD-2-2047-0
Main unit, orange tube, blue orifice with green HBNR RD-5-10011-0 RD-5-10011-0P 71R8504
R-2825-0, OE#RD-5-9204-1
FILTER
Recirculating air foam filter, 16 5⁄16" x 5 3⁄4" x 1⁄2" RD-3-10331-0 RD-3-10331-0P 78R5301
R-2825-0, OE#RD-3-10331-0
Fresh air frame filter, 18 7⁄8" x 4 13⁄16" x 5⁄16" RD-5-6867-0P RD-5-6867-0P 78R5350
R-9755-0, OE#RD-5-6867-0
PAGE 234
TIMBERJACK
RECEIVER
HEATER DRIER
R-2825-0, OE#RD-1-2333-0
RESISTOR
R-2825-0, OE#RD-5-9445-0
THERMOSTATIC SWITCH
Fixed Setting thermostat with 16" capillary tube, flange mt. RD-5-6429-0 RD-5-6429-0P 71R3150
R-2825-0, OE#RD-5-6429-0
Skidder series models with Red Dot model R-9725-0, Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24 RD-5-4531-24P 71R3200
R-9755-0, OE#RD-5-4531-24 capillary tube, flange/side mt.
WATER VALVE
Feller Buncher 608L, 608S, 850 with Red Dot A/C unit RD-5-5119-0, 1-1574Q,
Cable operated valve, straight, 5⁄8" to 5⁄8" hose RD-5-5119-0P 72R5060
R-2825-0, OE#RD-5-5119-0 MA1060
VERSATILE
BLOWER MOTOR
All Swathers and tractors with Kysor A/C evaporator, Kysor A/C (evaporator blower), double shaft motor, 1 speed,
70257336-1 RD-5-10068-0P 73R4322
OE#275158 12V, 4 7⁄8" length
All Swathers and tractors with Kysor A/C evaporator, Double shaft blower motor (only), 1 speed, 4 3⁄4" length, 12V
275152 RD-5-6801-0P 73R4182
OE#275152 vented
All Swathers and tractors with Kysor A/C condenser,
Kysor A/C, single shaft-non-vented, 1 speed, CW, 4 7⁄8" length 275130 RD-5-7129-0P 73R0542
OE#275130
BLOWER SWITCH
4K754, BOA-80-926-00-
All Swathers and tractors with OE#4K754 Rotary switch, DP3T, 3 speed, short shaft thread RD-5-9833-0P 71R1160
059
All Swathers and tractors with OE#RD-5-10934-0,
71195109
CLUTCH ASSEMBLY
All Swathers with Kysor A/C with Sanden SD508
compressors, OE#6574-6210, 6514-6210
All Swathers and tractors with CCI/York - R12 / 134A
compressors OE#024-25078, MA6, MAE6AR
All Swathers and tractors with CCI/York - R12 / 134A
compressors, OE#332334, MA 7A
All Swathers and tractors with Sanden SD5 (508 / 510 /
5H14) R12/R134a compressors
All Swathers and tractors with Sanden SD7H15HD
R134a compressor, OE #6504-6310
Tractors 256, 276, 550, 555 with Sanden SD510 R12/
R134a compressor, OE#6574-6210, 6514-6210
Tractors 700, 750 with 5⁄8" belt with Sanden SD510
1 groove 6 1⁄4" diameter pulley, 5⁄8" width, bullet plug 6521-6010 RD-5-5489-0P 75R1402
compressor
Tractors 700, 750 with 5⁄8" belt with York ER-210 series All with CCI, York Tecumseh compressor, 1 groove 6 3⁄4" diameter
502743, L50-2743 RD-5-4988-0P 75R3602
compressor pulley, 5⁄8" width, bullet plug
Tractors 800, 825, 835, 850 with ⁄8" belt with York
5
All with CCI, York Tecumseh compressor, 1 groove 6 ⁄4" diameter
3
502743, L50-2743 RD-5-4988-0P 75R3602
ER-210 series compressor pulley, 5⁄8" width, bullet plug
Tractors 855, 875, 876 with Sanden SD510 R12/R134a
compressor, OE#6574-6210, 6514-6210
Tractors 855, 875, 876 with York ER-210 series
compressor, OE#L50-2393, 502393
Tractors 900, 935, 950, 975 with Sanden SD510 R12/
R134a compressor, OE#6574-6210, 6514-6210
Tractors 900, 935, 950, 975 with York ER-210 series
compressor, OE#L50-2393, 502393
PAGE 235
VERSATILE
CLUTCH ASSEMBLY
Tractors 1150, 1153 with Sanden SD510 R12/R134a
compressor, OE#6574-6210, 6514-6210
All tractor series with CCI / York HD Rotolock ER-210
Rotolock Head, LH Suction without clutch, (universal - new) ER, R210L- 25149, 99242-5 RD-5-8637-1P 75R7280
series compressor
All tractor series with CCI/York/ Tecumseh - Tube
Tube O-Ring type head without clutch, (universal - new) ET210L-25150, -C, 99244-5 RD-5-8638-1P 75R7290
O-Ring ET210L-25150C compressor without clutch
Tractors 700, 750 with 5⁄8" belt with York ER-210 series
compressor
Tractors 800, 825, 835, 850, 855, 875, 876 with ⁄8" belt
5
with York ER-210 series compressor
Tractors 900, 935, 950, 975 with 5⁄8" belt with York
ER-210 series compressor
COMPRESSOR - SANDEN
All tractor series with Sanden 7H15, # 6664 R134a
7H15, JD head, ear mount 2 groove, 5 1⁄4" (132mm) diameter 6664, 72239750 RD-5-10297-0P 75R84612
compressor
All tractor series with Sanden 5H14, #6665 R134a
5H14-HD, FL head, 24V, 2A groove, 5 1⁄4" (132mm) diameter 6665 RD-5-7089-0P 75R8384
compressors, 24V
All tractor series with Sanden 510-HD, OE#9103 R-12
SD510HD, B head, 2A groove, 5⁄8" width, 5 1⁄4"(132mm) diameter 9103 RD-5-6164-0P 75R8262
compressor
All tractor series with Sanden 508, #9285, R12
compressor
All tractor series with Sanden 510-HD, #9674, 24V, R12
SD510HD, FG head, 24V, 2A groove, 5 1⁄4" (132mm) diameter 9674 RD-5-5626-0P 75R8214
compressor
All tractor series with Sanden SD510, #9675 R-12
SD510HD, FG head, variable groove, 6 1⁄4" (158mm) diameter 9675 RD-5-5627-0P 75R8232
compressor
Tractors 700, 750 with Sanden 5H14, OE#4511, 6671
SD5H14, C head, ear mount, 2A groove, 6 1⁄4" (132mm) diameter 4511, 6671 RD-5-8945-0P 75R8252
R-134a compressor
Tractors 855, 875, 876, 900, 935, 950, 975 with Sanden
510-HD, OE#9103 R-12 compressor
Tractors 1150, 1153 with Sanden 510-HD, OE#9103
R-12 compressor
ELECTRICAL SWITCH
All Swathers and tractors with OE#53620, 404028 Rotary thermostat, 36" capillary tube, 34 - 52°F 53620, 404028 RD-4125-36P 71R2250
4K754, BOA-80-926-00-
All Swathers and tractors with OE#4K754 Rotary switch, DP3T, 3 speed, short shaft thread RD-5-9833-0P 71R1160
059
All Swathers and tractors with OE#RD-5-10934-0,
71195109
All Swathers and tractors with block valve, OE#79840 Block valve with female O-Ring fittings 79840 RD-5-6868-0P 71R8301
Swathers and tractors with Kysor A/C with block valve,
Block valve with female O-Ring fittings 404087, 404098 RD-5-6868-0P 71R8301
OE#404087, 404098
Tractors 1150, 1153 with block valve, OE#79840 Block valve with female O-Ring fittings 79840 RD-5-6868-0P 71R8301
All Swathers and tractors with right angle valve, Male O-Ring with 13" capillary length, 13" equalizer tube
404073 RD-5-3824-1P 71R8100
OE#404073 length
Tractors 256, 276 with right angle valve, OE#70267 70267 RD-5-3824-1P 71R8100
length
Internal equalizer, 1 1⁄2 ton, with male flare with 9" capillary
All Swathers and tractors with flare fitting, OE#18384 18384 RD-5-6099-0P 71R8210
length, flare fittings
All Swathers and tractors with O-Ring fitting, OE#826-
Internal equalizer valve with male O-Ring fittings 826-004 RD-5-11033-0P 71R8060
004
Tractors 800, 825, 835, 850, 900, 935, 950, 975 with
Internal equalizer, 1 1⁄2 Ton, Male O-Ring 18384 RD-5-6099-0P 71R8210
OE#18384
PAGE 236
VERSATILE
PRESSURE
CLUTCH SWITCH
ASSEMBLY
High Pressure Fan switch with M10 threads, opens 300 psi,
All Swathers and tractors with OE#404081 404081, AR45868 RD-5-8287-0P 71R6210
closes 250psi
RECEIVER DRIER
All Swathers and tractors with OE#085098-00 Male O-Ring with fuse plug, side port, top glass 085098-00 RD-5-4950-0P 74R0906
All Swathers and tractors with OE#088011-00 with #6 Male flare, 3" X 6 1⁄4" 088011-00, 926384-C1 RD-5-4954-0P 74R2406
All Swathers and tractors with OE#088424-01 with #6 Male O-Ring, 3" x 6 1⁄4" 088424-01 RD-5-7061-2P 74R2526
All Swathers and tractors with OE#30080 with #6 Male Flare (top and side), 4" X 6 3⁄4" 30080, 1162927 RD-5-6077-0P 74R4016
All Swathers and tractors with OE#48510 with #6 Male O-Ring, 3" x 10", fuse, top port 48510, 9827053 RD-5-6504-0P 74R2306
All Swathers and tractors with OE#70966, 088411-01 In-line, #6 Male O-Ring, 2 1⁄2" x 9 9⁄16" 70966, 088411-01 RD-5-7064-0P 74R0460
Tractors 256, 276 with OE#48510 Male & Male O-Ring HPRV, MI IN CAP, 3" x 8 3⁄8", hi capacity 48510, PH 088193-00 RD-5-11192-0P 74R2608
THERMOSTATIC SWITCH
All Swathers and tractors with OE#18342 Rotary thermostat with 48" capillary tube, 34 - 52°F 18342, 0272229-6 RD-4125-48P 71R2300
All Swathers and tractors with OE#53620 Rotary thermostat, 36" capillary tube, 34 - 52°F 53620 RD-4125-36P 71R2250
All Swathers and tractors with Kysor A/C, OE#404028 Rotary thermostat, 36" capillary tube, 34 - 52°F 404028 RD-4125-36P 71R2250
VME
Tractor 175B, 175C series with OE#3380223M1, RD-5- Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
3380223M1 RD-5-5862-0P 71R8080
5862-0 length
Tractor 275B, 275C series with OE#3380223M1, RD-5- Male O-Ring, 1 1⁄2 Ton, 10" capillary length, 10" equalizer tube
3380223M1 RD-5-5862-0P 71R8080
5862-0 length
RECEIVER DRIER
Tractor 175C, 380 series with OE#RD-5-6075-0, RD-5-6075-0, 118304-C1,
with #6 Male O-Ring (top and side), 4" X 6 3⁄4" RD-5-6075-0P 74R4006
118304-C1, 118418-C1 118418-C1
#6 Male O-Ring, 4" x 7 3⁄4", side port, low pressure switch, RD-5-5955-0, 088209-02,
Tractor 175B, 275C series with drier, OE#RD-5-5955-0 RD-5-5955-0P 74R3516
moisture indicator 106-5534, 5V5698
THERMOSTATIC SWITCH
Tractor 380 series with OE#RD-5-4911-0, 404077 Cable controlled with 18" capillary tube, 26 - 66°F RD-5-4911-0, 404077 RD-5-4911-0P 71R2600
VOLVO OFF-ROAD
BLOWER MOTOR
Backhoe BL70 series used with Red Dot A/C unit
Blower assembly, 3 speed, 12V, 684 cfm, 13 3⁄4" x 6 1⁄2" x 5" RD-5-9204-0 RD-5-9204-0P 73R5622
R-9100-0, OE#RD-5-9204-0
Blower assembly, 1 speed, 12V, 12 1⁄4" x 3 1⁄8" x 4 1⁄2" RD-5-8837-1 RD-5-8837-1P 73R5642
R-9110-0, OE#RD-5-8837-1
Backhoe, Loader and Tractor L20B, L25B series 2RD570M Unit with Heater A/C, 12V blower motor assy RD 5 8837 0 RD-5-8837-0P 73R5532
Fan speed blower resistor, 4 speed, 4 terminal RD-5-6450-0 RD-5-6450-0P 71R1455
R-9110-0, OE#RD-5-6450-0
R-9110-0, OE#RD-5-3647-0
COMPRESSOR - SANDEN
Backhoe, Loader and Tractor L20B, L25B series with 7H15, JD head, ear mount, poly 8 groove, 4.7" (119 mm)
2811582, 8103 RD-5-9251-0P 75R8462
Sanden 7H15, #8103, OE #2811582 diameter
EVAPORATOR
R-9110-0, OE#RD-2-3741-0
R-9110-0, OE#RD-5-7015-0
PAGE 237
VOLVO OFF-ROAD
COMPRESSOR
EXPANSION VALVE - SANDEN/ ORIFICE TUBE
Backhoe, Loader and Tractor L20B, L25B model series GM type, CCOT (White) Orifice Tube with accumulator system,
RE24958 RD-5-4919-0P 71R8500
RECEIVER DRIER
Backhoe, Loader and Tractor L20B, L25B model series
In-line, quick disconnect, 2 1⁄2" x 13 7⁄8" RD-5-8605-0, 3E3535 RD-5-8605-0P 74R0470
with quick disconnect, Cat OE#3E3535
RESISTOR
Backhoe BL70 series used with Red Dot A/C,
Fan speed blower resistor, 4 speed, 4 terminal RD-5-6450-0 RD-5-6450-0P 71R1455
OE#RD-5-6450-0
R-9110-0, OE#RD-5-3647-0
THERMOSTATIC SWITCH
Backhoe BL70 series used with Red Dot A/C unit Thermostat for standard control units, fixed setting with 24"
RD-5-4531-24P RD-5-4531-24P 71R3200
R-9110-0, OE#RD-5-4531-24P capillary tube, flange/side mt.
Backhoe, Loader and Tractor L20B, L25B model series
Preset (fixed) setting thermostat, 21" capillary tube, 31 - 40°F 1118408 RD-5-10335-0P 71R3220
with OE#1118408
WATER VALVE
R-9100-0, OE#RD-5-10223-0
WABCO
60B, 85D Series with OE#2684701-C1 Main Unit, all models with flare fitting 2684701-C1 RD-4126-1P 71R8050
120CT, 120D Series with OE#2684701-C1 Main Unit, all models with flare fitting 2684701-C1 RD-4126-1P 71R8050
RECEIVER DRIER
60B, 85D, 120D Series with OE#72161835-3 Male & Male O-Ring with Fuse Plug, Low Pressure Switch 72161835-3 RD-4160-1P 74R2106
PAGE 238
OEM OFF-ROAD APPLICATIONS
Year Model Factory No. Part No. Year Model Factory No. Part No.
KOBELCO KOBELCO
BLOWER MOTOR HEATER CORE
Excavator-Late S/N** SK 120, 150, 200, 220, 270 RD-5-8073-24P 73R0474 Excavator-Late S/N** SK 120, 150, 200, 220, 270 RD-1-1351-0P 76R3010
Excavator SK100 RD-5-8073-24P 73R0474 Excavator SK100 RD-1-1351-0P 76R3010
Excavator-Early S/N* SK120, 150, 200, 220, 270 RD-5-8073-24P 73R0474 Excavator-Early S/N* SK120, 150, 200, 220, 270 RD-1-1351-0P 76R3010
Excavator SK300, SK400 RD-5-8073-24P 73R0474 Excavator SK300, SK400 RD-1-1351-0P 76R3010
CLUTCH HIGH PRESSURE SWITCH
COMPRESSOR LOW PRESSURE SWITCH
CONDENSER RECEIVER DRIER
EVAPORATOR THERMOSTAT
EXPANSION VALVE WATER VALVE
Excavator-Late S/N** SK 120, 150, 200, 220, 270 RD-5-6868-1P 71R8301 Excavator-Late S/N** SK 120, 150, 200, 220, 270 RD-5-8193-1P † 72R5357
Excavator SK100 RD-5-6868-1P 71R8301 Excavator SK100 RD-5-8193-1P † 72R5357
Excavator SK115 RD-5-6868-1P 71R8301 Excavator SK115 RD-5-8193-1P † 72R5357
Excavator-Early S/N* SK120, 150, 200, 220, 270 RD-5-6868-1P 71R8301 Excavator-Early S/N* SK120, 150, 200, 220, 270 RD-5-8193-1P † 72R5357
Excavator SK300, SK400 RD-5-6868-1P 71R8301 Excavator SK300, SK400 RD-5-8193-1P † 72R5357
FAN SPEED RESISTOR KOBELCO SK SERIES EXCAVATORS
Excavator-Late S/N** SK 120, 150, 200, 220, 270 RD-5-3647-0P 71R1450 * Early Machines are Units Prior to Serial No:
Excavator SK100 RD-5-3647-0P 71R1450 ** Late Machines are Units After Serial No.:
Excavator SK115 RD-5-3647-0P 71R1450 SK120LC YPU1500 SK120LC: YPU1500
Excavator-Early S/N* SK120, 150, 200, 220, 270 RD-5-3647-0P 71R1450 SK120 LPU0050 SK120: LPU0050
Excavator SK300, SK400 RD-5-3647-0P 71R1450 SK150LC YMU1450 SK150LC: YMU1450
FRESH AIR FILTER SK200LC YQU3000 SK200LC: YQU3000
Excavator-Late S/N** SK 120, 150, 200, 220, 270 RD-5-8078-0P 78R5365 SK200 YNU0400 SK200: YNU0400
Excavator SK100 RD-5-8078-0P 78R5365 SK220LC LLU1700 SK220LC: LLU1700
Excavator SK115 RD-5-8078-0P 78R5365 SK220NLC LLU5075 SK220NLC: LLU5075
Excavator-Early S/N* SK120, 150, 200, 220, 270 RD-5-8078-0P 78R5365 SK270LC LBU0175 SK270LC: LBU0175
Excavator SK300, SK400 RD-5-8078-0P 78R5365 † Water Valve-Replacement: For machines manufactured prior to 11/98 purchase
water valve ﬁeld install kit RD-3-9191-0P
PAGE 138
LINKBELT TAKEUCHI
BLOWER MOTOR BLOWER MOTOR
Excavator 4300, 5800, 6000 RD-5-8583-1P 73R5554 Backhoe BL70 RD-5-8837-1P 73R5642
CLUTCH Excavator TB1140 RD-5-9204-1P 73R5624
Excavator 4300, 5800, 6000 RD-5-10232-0P 75R0274 Mini Excavator TB175 RD-5-8838-0P 73R5534
COMPRESSOR COMPRESSOR
CONDENSER CONDENSER
Excavator 4300, 5800, 6000 RD-4-5418-0P 77R1300 Excavator TB1140 RD-4-5361-0P 77R1285
EVAPORATOR CONDENSER MOTOR
Excavator 4300, 5800, 6000 RD-2-3070-0P 76R6650 EVAPORATOR
EXPANSION VALVE Backhoe BL70 RD-2-3741-0P 76R7730
FAN SPEED RESISTOR EXPANSION VALVE
FRESH AIR FILTER Mini Excavator TB175 RD-5-6868-1P 71R8301
Excavator 4300, 5800, 6000 RD-5-8582-0P 78R5240 FAN SPEED RESISTOR
HEATER CORE Excavator TB1140 RD-5-9445-0P 71R1401
Excavator 4300, 5800, 6000 RD-1-2021-0P 76R3451 FRESH AIR FILTER
HIGH PRESSURE SWITCH Mini Excavator TB175 RD-3-10591-0P 78R5355
Excavator 4300, 5800, 6000 RD-5-4585-0P 71R7500 HEATER CORE
LOW PRESSURE SWITCH Mini Excavator TB175 RD-1-2069-0P 76R2740
Excavator 4300, 5800, 6000 RD-5-4585-0P 71R7500 HIGH PRESSURE SWITCH
RECEIVER DRIER RECEIVER DRIER
THERMOSTAT RECIRC AIR FILTER
Excavator 4300, 5800, 6000 RD-5-4531-24P 71R3200 THERMOSTAT
WATER VALVE Backhoe BL70 RD-5-4531-24P 71R3200
WATER VALVE
Excavator TB1140 RD-4257-0P 72R5050
Mini Excavator TB175 RD-4257-0P 72R5050
PAGE 139
TEREX VME
RECEIVER DRIER EXPANSION VALVE
All RD-5-7559-0P 74R1106 175B RD-5-5862-0P 71R8080
175C RD-5-5862-0P 71R8080
275B RD-5-5862-0P 71R8080
TIMBERJACK 275C RD-5-5862-0P 71R8080
BLOWER MOTOR RECEIVER DRIER
Feller Buncher 850 RD-5-9204-1P 73R5624 380 RD-5-6075-0P 74R4006
Skidder 1991-98 RD-5-3780-0P 73R4102 175B RD-5-5955-0P 74R3516
Feller Buncher 608 L & S RD-5-9204-1P 73R5624 175C RD-5-6075-0P 74R4006
CONDENSER 275C RD-5-5955-0P 74R3516
Feller Buncher 850 RD-4-5743-0P 77R6250 THERMOSTAT
Skidder 1991-98 RD-4-4440-0P 77R0090 380 RD-5-4911-0P 71R2600
Feller Buncher 608 L & S RD-4-5655-0P 77R6255
CONDENSER MOTOR
Skidder 1991-98 RD-5-8709-0P 73R0562 VOLVO
EVAPORATOR BLOWER MOTOR
Feller Buncher 850 RD-2-3923-0P 76R7450 Backhoe BL70 RD-5-9204-0P 73R5622
Skidder 1991-98 RD-2-2047-0P 76R4920 HEATER CORE
Feller Buncher 608 L & S RD-2-3923-0P 76R7450 Backhoe BL70 RD-1-2195-0P 76R3475
EXPANSION VALVE WATER VALVE
Feller Buncher 850 RD-5-10011-0P 71R8504 Backhoe BL70 RD-5-10223-0P 72R5055
Skidder 1991-98 RD-5-6868-1P 71R8301
FAN SPEED RESISTOR WABCO
Feller Buncher 850 RD-5-9445-0P 71R1401 EXPANSION VALVE
120CT RD-4126-1P 71R8050
HEATER CORE 120D RD-4126-1P 71R8050
Feller Buncher 850 RD-1-2333-0P 76R4100 60B RD-4126-1P 71R8050
Feller Buncher 608 L & S RD-1-2333-0P 76R4100 85D RD-4126-1P 71R8050

RECIRC AIR FILTER RECEIVER DRIER
Feller Buncher 850 RD-3-10331-0P 78R5301 120D RD-4160-1P 74R2106
Skidder 1991-98 RD-5-6867-0P 78R5350 60B RD-4160-1P 74R2106

Feller Buncher 608 L & S RD-3-10331-0P 78R5301 85D RD-4160-1P 74R2106
THERMOSTAT
Feller Buncher 850 RD-5-6429-0P 71R3150
Skidder 1991-98 RD-5-4531-24P 71R3200
WATER VALVE
Feller Buncher 850 RD-5-5119-0P 72R5060
PAGE 140
COMPRESSOR MOUNT KIT APPLICATIONS
Compressor
Mount Kits
PAGE 239
IMPORTANT - READ THIS
ENGINE MOUNT AND DRIVE ADAPTABILITY
NOTE: IMPORTANT - Minor modifications are occasionally necessary and are alignment be assured before final securement of mounting bolts are made. If
considered part of an installation. These kits are designed to fit vehicles with sufficient tolerance has not been allowed for that particular engine, further
standard equipment. Each model adapter kit is thoroughly checked by instal- modification, such as elongating a hole or reshaping a strap, may be necessary
lation of the bracket on a standard vehicle. The addition of special or optional to achieve proper alignment and fit. Some installations may require a slight
equipment may interfere with normal installation. Compressor mounts are modification or rearrangement of radiator mounting, gas or water lines for
an accessory, and are of no concern to the engine manufacturer. Casting proper clearance. Trucks are quite often custom built, and you may find differ-
dimensions and bosses utilized in the bracket mounting vary as they are of no ences in the supplier of power steering and other accessory equipment. It may
value to the engine manufacturer. Extra tolerances have been built into the be necessary to purchase a special accessory pulley, which is not furnished in
bracket to compensate for these differences. It is important that proper pulley the kit, from the truck distributor.
COMPRESSOR MOUNT KIT & CLUTCH APPLICATION

Mount kits contain all components and hardware required to mount compressor to engine.
Drive belt supplied with all kits except 75R9000 & 75R9895.
134A Compressor
134A Charge Mount Kit
Manufacturer Year Engine Clutch Compressor Fitting Number Belt No.†
Multi Use
Cat V-8 3208 (636 75R8382 75R9910 G9700
C.I.D) w/ Bracket 75R8384
Mounted Fan
Cat 3406B 6 Cyl 75R8382 75R9780 G9550
893 cu. in. 14.6 Liter 75R8384
Cummins 10 Liter 75R8382 75R9790
611 cu. in. 240 75R8384
300 H.P.
Cummins "N" Series 75R8382 75R9890 G9550
14 Liter (855 cu. in.) 75R8384
300 thru 444 H.P.
w/second groove from
engine open (accessary drive)
Cat 3176 75R8382 75R9545
75R8384
1990-95 Cummins L-10 75R8382 75R9625 G9530
75R8384
1994- Cummins M11 75R8382 75R9625 G9530
75R8384
Cummins 4BT & 6BT 75R8382 75R9895
without idler pulley 75R8384
1992-95 Cummins 6BT - 5.9 Ltr. 75R8382 75R9795
w/o air injection pump 75R8384
1991-95 Cummins 75R8382 75R9785
6C/6CT/6CTA 8.3L 75R8384
1991-95 Detroit Diesel 75R7280 75R5681**
Series 60 75R5688**
Autocar
Series A, DC, KK 1966-89 Cummins "N" Series 75R7280 75R5681** 75R9000
Conventional Full Flow Cooling Acc. 75R5688** or
Drive Pulley 208831 or 75R9220
190448. Except 20° tilt
or P/S on Acc. Drive
1966-89 Cummins "N" 75R8382 75R9670
1966-88 Cummins "N" Series 75R7280 75R5681** 75R9220
75R5688**
1970-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060 G9375
6V or 8V-92 75R5688**
Barko
450 HRT Cummins 6CT 8.3L 75R8422 75R9825
Log Loader 75R8424
PAGE 240
134A Compressor
Bucyrus
Erie 88B Cummins KT1150 75R8372 75R9835
Excavator 75R8374
Bomag
BW 851 Cummins 1150 75R8372 75R9835
Compactor 75R8374
K351 Cummins 855 75R8422 75R9870
Compactor 75R8424
Case
1550 Crawler Cummins 6-830 75R8422 75R9825
75R8424
888 Excavator Cummins 6-590 75R8422 75R9825
75R8424
W36 Wheel Loader Cummins 6CT 8.3L 75R8422 75R9825
75R8424
1550 Crawler Cummins 6-350 75R8422 75R9825
75R8424
580L, 480E, 480F Backhoe Cummins 4-390 75R8422 75R9840
75R8424
680L, 780D Backhoe Cummins 6-590 75R8422 75R9840
75R8424
580 Super E Backhoe Cummins 4-390 75R8422 75R9840
75R8424
680K Backhoe Cummins 4-390 75R8422 75R9840
75R8424
550G Crawler Cummins 4-390 75R8422 75R9840
75R8424
450C, 455 Crawler Cummins 4-390 75R8422 75R9840
75R8424
860 Trencher Cummins 4-390 75R8422 75R9840
75R8424
W11B Wheel Loader Cummins 4-390 75R8422 75R9840
75R8424
Caterpillar
216, 226, 228, 3034 75R8332 75R9960 D17250
236, 246, 248 3034T D17475
325, 322 3116, 3304, 3306, 75R8384 75R9970 G7380
920, 950E & 966C 3322, 3325 Excavator 75R9975
824C, 825C, 326C, 3406 75R8384 75R9535 G9600
245, 245B & 980C G9690
768C, 769C, 3408, 3412 75R8384 75R9615 G9480
772B & 773B
950F 3114,3116 75R8384 75R9635 G9710
215, 225, 229 Excavator 3304 75R8422 75R9973 D17501
75R8424
225, EL 240 Excavator 3304 75R8422 75R9815
75R8424
515, 518, 528, 3304 & 3306 75R8422 75R9815
530B Skid Steer 75R8424
615 Scraper 3306 75R8422 75R9815
75R8424
627B, 627E, with Low 3306 75R8422 75R9815
Crank Driven Alternator 75R8424
631D, 631E Scraper 3408 75R8422 75R9565
75R8424
633C Scraper D343 75R8422 75R9810
75R8424
** For R12 installations use 75R5611 and 75R5618 Service Valves

† G = Gates      D = Dayco      GY = Goodyear
PAGE 241
134A Compressor
Caterpillar
633E, 651E Scraper 3408 & 3412 75R8422 75R9565
75R8424
637A , 637D Scraper 3408 75R8422 75R9565
75R8424
769C Haul Truck 3408 75R8422 75R9565
75R8424
814, 815, 816 Compactor 3306 75R8422 75R9973 D17500
75R8424 GY17501
814B, 815B, 816B Compactor 3306 75R8422 75R9973 D17500
75R8424 GY17501
824C, 825C Compactor 3406 75R8422 75R9565
75R8424
920, 930, 950, 3304 & 3306 75R8422 75R9973 D17500
966C Wheel Loader 75R8424 GY17501
920, 930, 980B Wheel Loader 3304 & 3306 75R8422 75R9973 D17500
75R8424 GY17501
951C Crawler Loader 3304 75R8422 75R9973 D17500
75R8424 GY17501
955, 977L Crawler Loader 3304 & 3306 75R8422 75R9973 D17500
75R8424 GY17501
988B, 988C, 992C 3408 & 3412 75R8422 75R9565
Wheel Loader 75R8424
D22B, D25C, D250B, 3306 75R8422 75R9820
D35C, D300B, D330B, 75R8424
D350B, D350C
D4E, D6D, Crawler 3304 & 3306 75R8422 75R9973 D17500
75R8424
D5C Series III Crawler 3046 75R8422 75R9865
75R8424
D6C, D5B Crawler 3306 75R8422 75R9973 D17500
75R8424
D6D Crawler with Scroll injector 3306 75R8422 75R9815
75R8424
D6H Crawler 3306 75R8422 75R9815
75R8424
Champion
720A, 730A Motor Grader Cummins 6CT 8.3L 75R8422 75R9825
75R8424
740 Motor Grader Cummins 855 75R8422 75R9870
75R8424
Diamond Reo
Conventional or 1975-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060
C.O.E. Cab 6V or 8V-92 75R5688**
Dresser
A500E, A560E Motor Grader Cummins 6CT 8.3L 75R8422 75R9825
75R8424
850, 870 Motor Grader Cummins 6CT 8.3L 75R8422 75R9825
75R8424
412B Scraper Cummins 6CT 8.3L 75R8422 75R9825
75R8424
TD 20G, TD 25G, TD 40 Cummins 1150 75R8372 75R9835
75R8374
568, 560B Wheel Loader Cummins 1150 75R8372 75R9835
75R8374
558 Wheel Loader Cummins 855 75R8422 75R9870
75R8424

PAGE 242
134A Compressor
Euclid
R-25, R-35 Cummins 855 75R8422 75R9870
Haul Truck 75R8424
FMC
LS 4300 Excavator Cummins 6CT 8.3L 75R8422 75R9825
75R8424
LS 7400 Excavator Cummins 1150 75R8372 75R9835
75R8374
Ford
"F" & "L" Models 1977-89 V8 Caterpillar V-636 75R1202 75R7280 75R5681** 75R9180 G9630
With Water Pump Fan 75R5688** G9660
"L" Models 1997 - Cummins M-11 75R8382 75R9550
CL-9500
"L" Models 1997 - CAT C-10 75R8382 75R9560
CL-9500
"L" Models 1972-89 Cummins "N" Series 75R7280 75R5681** 75R9000
CL-9000 Full Flow Cooling. Acc 75R5688** or
Drive Pulley 210947 or 75R9220
210948. Except 20 tilt
1966-89 Cummins "N" 75R8382 75R9670
"L" Models 1970-92 Cat 3208 V636 75R8382 75R9900 G9360
With Bracket Mounted Fan
CL-9000 1967-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060 G9375
6V or 8V-71 75R5688**
Freightliner
1991-94 Detroit Series 60 75R1202 75R7280 75R5681**
75R5688**
Galion
Motor Grader Cummins 6CT 8.3L 75R8422 75R9825
75R8424
118C Motor Grader Cummins 855 75R8422 75R9870
75R8424
GMC/Chevrolet See WHITEGMC for information on Astro, Brigadier and General.
H, J, & M Series 1978-89 V-8 Caterpillar 3208 75R1202 75R7280 75R5681** 75R9180 G9630
With Bracket Mounted 75R5688** G9660
Fan
H, J, & M Series 1971-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060 G9375
6V or 8V-71 75R5688**
GMC COE 1969-93 Cummins "N" Series 75R7280 75R5681** 75R9220
H, J, & M Series 75R5688**
Titan Series 1969-93 Cummins "N" Series 75R7280 75R5681** 75R9220
COE H, J, & M 75R5688**
Series
Gradall
G660E Excavator Cummins 6CT 8.3L 75R8422 75R9825
75R8424
Hitachi
UH801 Excavator Cummins 1150 75R8372 75R9835
75R8374
"S" Series 1983-89 V/8 International 75R8382 75R9530 G9750
6.9 Liter, 421 cu. in.
“F”, "S" Series (All) 1979-87 6 Cyl. IHC DT-466 75R1202 75R7280 75R5681** 75R9100 G9550
75R5688**
2200-2500. 2600 1979-90 75R8382 75R9980 G9420
1994-00 DT-408/DT-466 75R8382 75R9985

PAGE 243
134A Compressor
"S" Series 1983-94 Cummins 6 Cyl. L-10 75R8382 75R9540 G9560
2200-2500
"F" Series
2200-2500
& 2600
Fleetstar "A" & 1972-89 Cummins "N" Series 75R7280 75R5681** 75R9000
Paystar Series Full Flow Cooling Acc 75R5688** or
Conventional Except 20° tilt 75R9220
4070A Transtar 1969-89 Cummins "N" Series 75R7280 75R5681** 75R9000
C.O.E. Full Flow Cooling Acc 75R5688** or
Drive Pulley 210926 75R9220
Except 20° tilt
4700 Series 1995 T44E Poly V Sanden 75R6000
Belt not Included
John Deere
110, 120, 160LC 4045-Powertech 75R8354 75R9720
200, 230, 270LC 6060T, 6068H 75R8354 75R9583
344G/444G 4045D, 4276T 75R8384 75R9695 G9480
444H 4045T 75R8354 75R9400 G9505
490E 4045T 75R8354 75R9715
544H 75R9405
544/624 6059T, 6-414 75R8384 75R9585 G9520
4039D, 4239D 75R8374 75R9645
4045D, 4045T 75R8374 75R9655 G9390
624H 75R9410
644E 6-466T 75R8384 75R9575 G9490
690E/790E 6068T 75R8384 75R9710 G9476
744E/992E,D 6101A/6101AT 75R8384 75R9805 G9440
892E 6076 75R8384 75R9575 G9415
Kenworth
CONV & COE 1966-89 Cummins Series, High 75R7280 75R5681** 75R9000
Fan. Full Flow Cooling 75R5688** or
Except 20° tilt 75R9220
1966-89 Cummins "N" 75R8382 75R9670
CONV & COE 1966-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060 G9375
6V or 8V-71 75R5688**
6V or 8V-92
Kobelco TLK
SK400 M.D. Cummins M11 75R8384 75R9630 G9412
1995-
Komatsu
WA350 to WA600 1986- 6D125, S6D125 75R8384 75R9950 G9560
PC60 to PC1000 and SA6125 6 cyl.
WA500 Wheel Loader SA6D140 75R8384 75R9595
G9335
WA 600 Wheel Loader SA6D170 75R8384 75R9605 G9380
PC300LC-5 Excavator Cummins 614T 75R8422 75R9825
75R8424
WS 23S-1 Scraper Cummins 1150 75R8372 75R9835
75R8374
PC 400LC5 Excavator S6D125-1 75R8422 75R9845
75R8424
WA470, WA450-1L S6D125 75R8422 75R9845

PAGE 244
134A Compressor
Komatsu
WA450-3 Wheel Loader SA6D125E-2 75R8422 75R9845
75R8424
PC180 Excavator S6D95L 75R8422 75R9850
75R8424
WA120, WA150 Wheel Loader S6D95L-1 75R8422 75R9850
75R8424
WA180 Wheel Loader S6D95L 75R8422 75R9850
75R8424
WA100, WA320-1 Wheel Loader S6D105 & 110 W/ VG 75R8372
75R8374
WA350, WA400 Wheel Loader SA6D110 WO/ VG 75R8372
75R8374
WA320 thru WA420 SA6D110 & S6D125 W/ VG 75R8372
D41P-6 Crawler S6D102E-1 75R8422 75R9860
75R8424
PC150-6 Excavator SA4D102E 75R8422 75R9860
75R8424
WA250-3 Wheel Loader S6D102E-1 75R8422 75R9860
75R8424
WA500 Wheel Loader Cummins 855 75R8422 75R9870
75R8424
PC400LC5 Excavator Cummins L-10 75R8422 75R9875
75R8424
WA 450-3 Wheel Loader Cummins LTA-10 75R8422 75R9875
75R8424
Koehring
6630 Excavator Cummins 6CT 8.3L 75R8422 75R9825
75R8424
Liebherr
962, 972, 974, 982 Excavator Cummins 855 75R8422 75R9870
75R8424
Mack
"R" Models 1972-89 6 Cyl. Mack 675, 676 75R1202 75R7280 75R5681** 75R9010 G9420
& 685 END-T, With 75R5688**
or Without
Turbocharger
"R" Models 1972-87 6 Cyl. Mack 675, 676 75R8382 75R9500 G9400
& 685 END-T, With or
Without Turbocharger
"R", "U" & "DM" 1972-89 6 Cyl. Mack 675, 676 75R8382 75R9500 G9400
Models & 685 END-T 2/ESI,
With or Without
Turbocharger, 2 or 4
Valve Head With United
Technology or Bosch 6000
Fuel Inj.System & Cast
Aluminum Timing Cover
"R" "U" & "CM" 1987-89 6 Cyl. Mack 675, 676 75R8382 75R9730 G9400
Models & 685 END-T, With or
Without Turbocharger
2 or 4 Valve Head With
United Technology or
Bosch 6000 Fuel Inject-
ion System & Cast
Aluminum Timing Cover

PAGE 245
134A Compressor
Mack
"R" "U" & "DM" 1966-89 Cummins "N" Series 75R2702 75R7280 75R5681** 75R9000
Models Except NTC-290 & 350 75R5688** or
Acc. Drive Pulley 75R9220
209669 or 190496
Except 20° tilt
1966-89 Cummins "N" 75R8382 75R9670
"F" Model COE 1965-89 Cummins NTC-290 & 75R7280 75R5681** 75R9000
350 75R5688** or
"F" Model COE 1966-89 Cyl. 335 Turbochd.
Except NTC-290 & 350. 75R7280 75R5681** 75R9220
Except 20° tilt 75R5688**
E6 Serial #T396BR192 75R8382 75R9515 G9495
and E7 All
MS 200, 250, 300 1989- California Eng 75R8382 75R9675 G9490
(060226)
MS 200, 250, 300 1983- Non California Engine 75R8382 75R9920 G7530
(060212) G7470
G9470
CS 200, 250, 300 1989- California Engine 75R8382 75R9675 G9490
(060226)
MC/MR 1983-90 EM-6-2256, 250L, 75R8382 75R9940 D17355
270L, 275L
Manitowoc
888 Crane Mobile Truck Crane Cummins L-10 75R8422 75R9830
75R8424
3900 Crane Mobile Truck Crane Cummins L-10 75R8422 75R9830
75R8424
M-250, 3900, 4100 Crane Cummins N14 75R8422 75R9870
75R8424
Marmon
"HDT" COE & 1967-89 Cummins "N" Series 75R7280 75R5681** 75R9000 or
"CHDT" CONV Except 20° tilt 75R5688**
75R9220
"HDT" & "CHDT" 1977-89 Detroit Diesel 8V-92 75R1202 75R7280 75R5681** 75R9060 G9375
75R5688**
Peterbilt
Conventional & 1973-89 Cummins "N" Series 75R7280 75R5681** 75R9000
COE Series Acc. Drive Pulley 75R5688** or
208831 Except 20° tilt. 75R9220
Conventional & 1963-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060 G9375
COE Cab 6V or 8V-71 75R5688**
Terex
TS14B Scraper Cummins 6CT 8.3L 75R8422 75R9825
75R8424
3308 Haul Truck Cummins KTTA19C 75R8372 75R9835
75R8374
S24C Scraper Cummins 1150 75R8372 75R9835
75R8374
Western Star
Conventional 1967-89 Cummins "N" Series 75R7280 75R5681** 75R9000
Full Flow Cooling 75R5688** or
1966-89 Cummins "N" 75R8382 75R9670

PAGE 246
134A Compressor
White GMC
Road 1966-89 Cummins "N" Series. 75R2702 75R7280 75R5681** 75R9000
Commander Full Flow Cooling, NH- 75R5688** or
COE 250 & NTC-335. Acc. 75R9220
Drive Pulley 211005 or
190546. Except 20° tilt
1966-89 Cummins "N" 75R8382 75R9670
4000 & 9000 1967-89 Cummins "N" Series 75R7280 75R5681** 75R9000
Road Boss Full Flow Cooling 75R5688** or
1966-89 Cummins "N" 75R8382 75R9670
6000 Series 1972-89 Cummins "N" Series 75R7280 75R5681** 75R9000
Expeditor COE Full Flow Cooling 75R5688** or
1966-89 Cummins "N" 75R8382 75R9670
Bruin or 1979-89 Detroit Dsl. 6V/8V-71 75R1202 75R7280 75R5681** 75R9060
Brigadier w/Hydraulic 75R5688**
Clutch Fan Only
H, J, & M Series 1969-89 Cummins "N" Series W/ 75R7280 75R5681** 75R9000
Titan Series & Standard or Full Flow 75R5688** or
Astro Series Cooling. Except 20° tilt 75R9220
1966-89 Cummins "N" 75R8382 75R9670
Titan & Bison 1977-89 Detroit Diesel 75R1202 75R7280 75R5681** 75R9060
Brigadier, Bruin 6V or 8V 75R5688**
without Hydraulic Fan

PAGE 247
Red Dot Model
Replacement
Parts
RED DOT MODEL REPLACEMENT PARTS
PSI Expansion Blower Fan/

Model Thermostat Switch Valve Motor Blower Drier
R-254-0 73R0032 73R8050
R-254-0-24 73R0034 73R8050
R-254-1 73R0062 73R8050
R-254-4 73R0032 73R8050
R-255-0 73R0032 73R8050
R-255-0-24 73R0034 73R8050
R-255-1 73R0062 73R8050
R-255-4 73R0032 73R8050
R-256-0 73R0022 73R8050
R-258 73R0072 73R8050
R-270-0
R-270-0-24
R-290-0 73R5522
R-290-24 73R5524
R-295-0 73R5532
R-295-0-24 73R5534
R-1550-0,-3 73R0474 73R6370
R-1550-1,-4 71R3200 71R7050 71R8301 73R0474 73R6370 74R1856
R-1550-5 71R3200 71R8301 73R0474 73R6370
R-1600 71R3200 71R8301 73R0474 73R6370

R-1620-0-24 71R3200 71R8321 73R5552
R-1620-1-24 71R3200 71R8321 73R5554
R-2000-1 71R2250 71R8301 73R4102 73R7000
R-2000-1-24 71R2250 71R8301 73R4104 73R7000
R-2000-6 71R2250 71R8301 73R5512
R-2000-6-24 71R2250 71R8301 73R5514
R-2000-5 71R3200 71R8301 73R5512
R-2000-7 71R3200 71R8301 73R5512
R-2020-0 73R0102 73R6251
R-2020-0-24 73R0104 73R6251
R-2100-0, -2 71R3150 71R8301 73R4062 73R7000
R-2100-3 71R3150 71R8301 73R4062 73R7000
R-2100-4 71R3150 71R8301 73R4062 73R7000
R-2100-0-24, -2-24 71R3150 71R8301 73R4064 73R7000
R-2110 Series 71R3100 71R8301 73R4062 73R7000
R-2120-0 71R3200 71R8301 73R4252 73R7071
R-2120-1 71R3200 71R8301 73R4254 73R7071
R-2150-0 71R3200 71R8410

R-2150-1 71R3200 71R8410 RD-5-9001-2P 74R2556
R-2170-6 71R3250 71R8100
PAGE 250
Heater
Core Evaporator Condenser Filter/Size
76R1100
76R1100
76R1110
76R1120
76R1400
76R1400
76R1410
76R1450
76R1100
76R1400
76R1100
76R1100
76R1100
76R1100
76R1400
76R1400
76R3010 Condenser Bracket Assembly 78R5365 RD-5-8078-0P 2 5 ⁄ 16 x10 3 ⁄4 (fresh air)
RD-4-5115-1P
Condenser Mounting Assembly
RD-4-5186-1P
76R3010 76R6430 Condenser Bracket Assembly 78R5365 RD-5-8078-0P 2 5 ⁄ 16 x10 3 ⁄4 (fresh air)
RD-4-5115-1P
RD-4-5186-1P
76R3010 76R6430 Condenser Bracket Assembly
RD-4-5115-1P
RD-4-5186-1P
76R3010 76R6430
76R3470 76R6650 78R5240 RD-5-8582-0P
76R3470 76R6650 78R5240 RD-5-8582-0P
76R5200
76R5200
76R5200
76R5200
76R5200
76R5200
76R0500
76R0500
RD-1-2023-0P 76R5320
76R5320
76R5320
76R5320
76R5000 77R0250
76R5600 Condenser Bracket Assembly (RH) RD-4-4956-1P (LH) RD-4-4957-1P
Condenser Mounting Kit RD-9-7170-0P
76R5600 Condenser Bracket Assembly (RH) RD-4-4956-1P (LH) RD-4-4957-1P
Condenser Mounting Kit RD-9-7170-0P
76R6460
76R6460
76R6460
PAGE 251

R-2190-4 71R3250 71R8100
R-2190-5 71R3250 74R2546
R-2500-4 71R3200 RD-5-8614-0P 71R8301 73R4122 73R7101
R-2500-7 71R3200 71R8301 73R4122 73R7101
R-2500-8 71R3200 71R8301 73R4122 73R7101
R-2500-9 71R3200 71R8301 73R4122 73R7101
R-2500-10 71R3200 71R8301 73R4122 73R7101
R-2500-12 71R3200 RD-5-8614-0P 71R8301 73R4122 73R7101
R-2505-0 71R8301 73R4122 73R7101
R-2510-0 71R3200 71R8301 RD-5-9001-0P RD-5-9000-0P
R-2510-1 RD-5-9001-0P RD-5-9000-0P
R-2510-8 71R3200 71R1610 71R8301 73R0462 RD-5-9000-0P
R-2510-9 71R3200 71R8301
R-2520-0 71R3200 71R0450 71R8321 73R0462 RD-5-9000-0P
R-2530-0 73R0462 73R7151
R-2550-0 71R8301 73R5622
R-2600-0 73R0462
R-2800-0 71R8301 73R5622
R-2810-0 71R3200 71R8301 73R5552
R-2815-0 RD-5-8747-6P
R-2820-0 71R3200 71R8301 73R5622
R-2820-1 71R3200 71R7075 71R8301 RD-5-10010-1P
R-2900-0 73R5532 Assy
R-3090-20 71R3200 71R8301 73R0422 73R6230
R-3130-4 71R3100 71R8301 73R0912 73R6051
R-3500-0 73R4122 73R7101
R-3500-0, -1 73R4122 73R7101
R-3500-2 71R1150 73R4122 73R7101
R-3510-0 RD-5-5269-1P 73R6051, 73R6230
R-3540-0 RD-5-8759-1P
R-3540-1 RD-5-8759-0P
R-3540-2 RD-5-8759-0P
R-3800-5 71R3200
R-3911H 73R0202 73R6151
R-3911H-24 73R0204 73R6151
R-3960 71R3200 71R8321 73R5502
R-4013H 73R0602 73R6051
R-4013H-24 73R0604 73R6051
R-4070-0 71R2500 71R8301 73R0602 73R6051
R-4070-1 71R2500 73R0602 73R6051
R-4120 71R2500 73R0962 73R6370
R-4122-0 71R8301 73R0962 73R6370
R-4122-1 73R0962 73R6370
R-4160-0 71R2500 71R8301 73R0962 73R6370
R-4160-1 CTC 71R8301 73R0962
R-4170-4 73R0402 73R6051
R-4180-0 71R8301 73R0402 73R6370
R-4180-1 73R0402 73R6051
PAGE 252
Heater
76R6460
76R6460 RD-4-5325-0P
76R6070
RD-2-3761-0P
RD-2-3761-0P
RD-2-3761-0P
RD-2-3761-0P
76R6070
76R3470 76R7020
76R3470
76R3470
76R3470 76R7030
RD-1-1570-0P
76R4020 76R7710
RD-1-1980-0P
RD-1-1932-0P
RD-1-1591-0P RD-2-3685-0P
RD-1-1823-0
76R2700 RD-2-1121-1P
RD-1-0740-0P 76R6440
76R3920
76R3920
76R3920
76R2550
RD-1-1545-0P
RD-1-1545-1P
RD-1-1545-0P
76R2300
76R2300
76R1710 RD-2-2854-0P
76R2600
76R2600
76R2210 76R6110
76R2210
76R2450 76R6140 Combo
76R2450 76R6140
76R2450
76R2450 76R6150
76R2400 76R6150
76R2400 76R6150
76R2400 76R6150
76R2400
PAGE 253

R-4190-5 73R0432 73R6370
R-4190-9 73R0432 73R6370
R-4190-39 73R0432 73R6370
R-4190-47 71R1165 73R0432 73R6370
R-4240-0 RD-3-5914-0P RD-5-9013-0P 73R0962 73R6370
R-4240-1 71R8301 73R0962 73R6370
R-4240-2 73R0962 73R6370
R-4240-7 71R8301 73R0962 73R6370
R-4240-8 73R0962 73R6370
R-4240-13 71R8301 73R0962 73R6370
R-4240-14 71R8301 73R0962 73R6370
R-4240-15 73R0962 73R6370
R-4240-16 71R8301 73R0962 73R6370
R-4240-3 71R8301 73R0962 73R6370
R-4240-4 71R8301 73R0962 73R6370
R-4290-21 73R0322 73R6151
R-4290-56 73R0322 73R6151
R-4450-0 71R3200 71R8321 73R4332
R-4500-2,-8 71R6130 RD-4-5370-0P 74R2576
R-4500-7 RD-5-9267-0P 73R8592 74R2590
R-4500-10 RD-5-9267-0P RD-5-8785-4P 74R2590
R-4500-11 RD-5-9267-0P 73R8592 74R2590
R-5040 73R0402 73R6101
R-5040 (12V) 71R3200 71R8301 73R0422 73R6101
R-5040 (24V) 71R8301 73R0454 73R6101
R-5045-0 71R2250 71R0200 73R4422
R-5045-2 71R2250 71R8301 73R4422 73R7151
R-5045-2-24 71R2250 71R8301 73R4424 73R7151
R-5045-3 71R2250 71R8301 73R4422 73R7151
R-5045-3-24 71R2250 71R8301 73R4424 73R7151
R-5050-2 73R0922 73R6230
R-5050-6 73R0922 73R6230
R-5050-7 71R3100 71R8301 73R0922 73R6230
R-5050-8 71R3100 71R8301 73R0922 73R6230
R-5060-12 73R0922 73R6230
R-5060-16 71R3200 71R8301 73R0922 73R6230
R-5060-19 71R3200 71R8301 RD-5-5435-24P 73R6230
R-5075-0 71R3100 71R8301 73R4422 73R7151
R-5075-0-24 71R3100 71R8301 73R4424 73R7151
R-5130 71R3200 72R0070 71R8301 73R0422 73R6230
R-5150-10 71R3100 73R0462 73R6381
R-5150-12 71R3100 71R8321 73R0462 73R6381
R-5150-14 71R3100 71R8321 73R0462 73R6381
R-5150-15 71R3100 71R8321 73R0462 73R6381
R-5150-16 71R3100 71R8321 73R0462 73R6381
R-5150-17 71R3100 71R8321 73R0462 73R6381
R-5150-2 71R3100 71R8321 73R0462 73R6381
R-5150-5 71R3100 71R8321 73R0462 73R6381
R-5150-6 71R3100 71R8321 73R0462 73R6381
PAGE 254
Heater
76R2330
76R2340 76R6150
76R2340 76R6150
RD-1-0822-1P RD-2-1898-1P
RD-1-0822-1P
RD-1-0822-1P RD-2-1898-1P
RD-1-0822-1P
RD-1-0822-1P RD-2-1898-1P
RD-1-0822-1P RD-2-1898-1P
RD-1-0822-1P
RD-1-0822-1P RD-2-1898-1P
RD-1-0822-1P RD-2-1898-1P
RD-1-0822-1P
76R2330
76R6120
77R0990
77R0990
77R0990
77R0990
76R3500
76R3500 76R7070
76R3500
76R3500 76R6070
76R3500 76R7070 78R5400
76R3500 76R7070
76R3500 76R7070
76R3500 76R7070
RD-1-0616-0P
RD-1-0959-0P
76R2010 76R6180
76R1900 76R6180
76R2500
76R2500 76R6310
76R2500 76R6310
76R3500 76R7070 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
76R3500 76R7070 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
76R3250 76R6850
76R3930
76R3930
76R3930
76R3930
76R3930
76R3930
76R3930
76R3930
76R3930
PAGE 255

R-5150-9 71R3100 71R8321 73R0462 73R6381
R-5155-3 71R3200 71R8321 RD-5-5269-1P 73R6051
R-5180-9 71R3200 71R0450 73R4422 73R7151
R-5200-0 71R3200 71R8301 73R5622
R-5260-0 71R3200 71R8321 73R6230
R-5260-4 71R3200 71R8380 73R6230
R-5260-10 71R3200 71R8380 73R1002 73R6230
R-5260-11 NONE 73R1002 73R6230
R-5260-12 71R8450 73R1002 73R6230
R-6000 (12V) 71R2250 71R7000 71R8301 73R0502 Cond 73R8110 Cond 74R2556
73R4262 Evap 73R6300 Evap CCW
R-6000 (24V) 71R2250 71R7000 71R8301 73R0504 Cond 73R8110 Cond 74R2556
73R4264 Evap 73R6300 Evap CCW
73R6350 Evap CW
R-6000-2 71R2250 71R7550 71R8301 73R4262 Evap 73R8110 Cond 74R2556
73R0512 Cond 73R6300 Evap CCW
73R6350 CW
R-6000-2-24 71R2250 71R7550 71R8301 73R4264 Evaporator 73R8110 Condenser 74R2556
73R0514 Condenser 73R6300 Evaporator CCW
73R6350 Evaporator CW
R-6060-0 71R7550 73R0512 73R8110 74R2556
R-6060-0-24 71R7550 73R0514 73R8110 74R2556
R-6100-0 71R2250 71R7550 71R8301 73R4262 Evaporator 73R8100 Condenser 74R2546
R-6100-0-24 71R2250 71R7550 71R8301 73R4264 Evaporator 73R8100 Condenser 74R2546
R-6105-0 71R3200 RD-5-9013-0P
R-6115-0 73R0034 73R8050
R-6120-0 RD-5-9245-24P RD-5-9000-0P
R-6120-1 RD-5-9245-24P RD-5-9000-0P
R-6120-6 RD-5-9245-24P RD-5-9000-0P
R-6125-0 73R4424 RD-5-7576-0P, -1P
R-6130-0,-1 73R0402 Evap 73R6051 (CCW)
73R0404
R-6135-0
R-6145-0 73R4424 RD-5-8101-0P, -1P
R-6160-0 73R0542 73R8100
R-6160-0-24 73R0544 73R8100
R-6160-1 73R0562
R-6160-1 73R0562 73R8100
R-6260 73R8612
R-6830 71R2250 71R8301 73R5572
R-6830-0-24 71R2250 71R8301 73R5584
R-6900
R-7002A 73R0502 73R8100
R-7050-0 73R0622 73R7151
R-7070-0 73R5532
R-7070-2 73R5532
* Solenoid Assembly ** Actuator

PAGE 256
Heater
76R3930
RD-1-0808-0P RD-2-1758-0P
76R3460 76R7010
RD-2-3425-0P
76R2420 76R7530
76R2420 76R7530
76R4023 76R7530
76R4023
76R4023 76R7530
76R5500 77R0500
76R5500 77R0500
76R5500 77R0500
76R5500 77R0500
77R0500
77R0500
76R5500 77R0620 78R5300 10 5 ⁄ 16” x 2 11 ⁄ 16” x 5 ⁄ 8”
76R5500 77R0620 78R5300 10 5 ⁄ 16” x 2 11 ⁄ 16” x 5 ⁄ 8”
RD-1-2235-0P
RD-1-1888-0P
RD-1-1888-0P
RD-1-1888-0P
RD-3-10194-0P
76R2300
78R5390
RD-1-2048-0P
77R0620
77R0620
77R0620
77R0620
77R0630
RD-2-5125-1P
RD-2-5125-1P
RD-1-1095-0P
76R3300
RD-1-0552-0P
PAGE 257

R-7070-4 71R3200 71R8301 73R5532
R-7165-0P RD-3-7844-7P * RD-5-7015-1P 73R5554
R-7170-0P,-0-24P 71R8301 73R5554
R-7211-5 73R0202 73R6151
R-7250-5 73R4422 73R7210
R-7350-1 RD-5-7575-3P
R-7350-5 RD-5-7575-3P
R-7550-0 - 73R8050
R-7550-1 73R0032 73R8050
R-7810-0 71R2250 71R8301 73R0602 73R6051
R-7810-0-24 71R2250 71R8301 73R0604 73R6051
R-7830-0 71R2250 71R8301 73R0402 73R7151
R-7830-0-24 71R2250 71R8301 73R0404 73R7151
R-7830-1 71R3200 71R8301 73R0402 73R7151
R-7830-1-24 71R3200 71R8301 73R0404 73R7151
R-8220-0, -1 71R3200 71R7500 71R8301 73R0422 73R7151 74R1956 w/Trinary™
74R1756 w/o Trinary™
R-8230-0 71R3200 71R7650 71R8301 73R0422 73R7151 74R1856
R-8235 71R3200 71R7650 71R8420 74R1856
R-8500-0 71R3200 71R8301 73R4102 73R7000
R-8500-0-24 71R3200 71R8301 73R4104 73R7000
R-8515-0 71R2300 71R8301 73R4202 73R6151/73R6101
R-8515-0-24 71R2300 71R8301 73R4204 73R6151/73R6101
R-8535-0 71R3100 71R8301 73R4202 73R6101 LH Blower
73R6151 RH Blower
R-8535-0-24 71R3100 71R8301 73R4204 73R6101 LH Blower
73R6151 RH Blower
R-8545-0 71R3100 71R8301 73R4262 73R6350 CW
73R6300 CCW
R-8545-0-24 71R3100 71R8301 73R4264 73R6350 CW
73R6300 CCW
R-8545-1 71R3100 71R8301 73R4262 73R6350 CW
73R6300 CCW
R-8545-1-24 71R3100 71R8301 73R4264 73R6350 CW
73R6300 CCW
R-8600-0 71R3200 71R7075 71R8301 73R5622 74R2536
R-8720-0 71R3200 71R7550 71R8301 73R0422 73R7151 74R1806
R-8720-3 71R3200 71R8301 73R0422 73R7151
R-8725-0 71R7550 74R5050
71R6095 74R5600
R-8730-0 71R7650 71R8505 74R5050
R-8810-MR0 71R3200 71R8301 73R0422 73R6230
R-8820-0, -1 71R3100 71R8301 73R0922 73R6230
R-8820-2 71R3100 71R8301 73R0922 73R6230
R-9450-2 RD-5-8126-0P
R-9450-3 71R3200 71R8423 RD-5-8126-0P
R-9475-0 71R3200 71R8423 73R5632 Assembly 74R4206
R-9475-0-24 71R3200 71R8423 73R5634 Assembly 74R4206
R-9485-0-24 73R7071
PAGE 258
Heater
76R3300 76R6950
RD-1-2635-0P RD-2-4291-0P RD-5-11581-0P RD-5-11470-1P **
RD-1-0333-4P
76R1550
76R1550
76R6400
76R6400
76R6350 78R5390 10 13 ⁄ 32” x 8 39 ⁄64” x 11 ⁄ 32”
76R6350 78R5390 10 13 ⁄ 32” x 8 39 ⁄64” x 11 ⁄ 32”
76R6350 78R5390 10 13 ⁄ 32” x 8 39 ⁄64” x 11 ⁄ 32”
76R6350 78R5390 10 13 ⁄ 32” x 8 39 ⁄64” x 11 ⁄ 32”
76R3910 76R7520 77R1100
76R3910 76R7520 77R1100

RD-2-2905-0P 77R1100
76R1030 76R5030 78R5330 17” x 3” x 1⁄4”
76R1030 76R5030 78R5330 17” x 3” x 1⁄4”
76R1510 76R5300 78R5340 15 13 ⁄ 16” x 4” x 5 ⁄ 16”
76R1510 76R5300 78R5340 15 13 ⁄ 16” x 4” x 5 ⁄ 16”
76R5300 78R5340 15 13 ⁄ 16” x 4” x 5 ⁄ 16”
76R5300 78R5340 15 13 ⁄ 16” x 4” x 5 ⁄ 16”
RD-2-3425-0P 77R1300 78R5245

76R3900 76R7500
76R3900 76R7500
76R7505 77R6800
RD-2-3320-0P 77R1300
76R2600 76R6300
76R1900 76R6180
76R2010 76R6180
RD-2-2780-0P
77R1504
RD-1-0860-0P 22 5 ⁄ 8” x 5 7 ⁄ 8” x 11 ⁄ 32”
PAGE 259

R-9500-0-24 71R3200 71R8321 73R4424 73R7200 CW
73R7210 CCW
R-9510-0-24 71R3200 71R8321 73R4424 73R7200 CW
73R7210 CCW
R-9520-0 71R3150 71R8321 RD-3-7383-0P
R-9520-0-24 71R3150 71R8321 RD-3-7383-1P
R-9715-0, -3 71R2250 71R8321 73R5502
R-9715-1 71R2250 71R8321 73R5502
R-9715-4 71R2250 71R1150 71R8321
R-9715-5 71R2250 71R1150 71R8321
R-9715-7 71R2250 71R8321 73R5502
R-9715-0-24, -3-24 71R2250 71R8321 73R5504
R-9720-0 73R0512 73R8110 74R0460
R-9720-0-24 73R0514 73R8110 74R0460
R-9720-1 73R0512 73R8110 74R0460
R-9720-1-24 73R0514 73R8110 74R0460
R-9720-2 73R0512 73R8110 74R0460
R-9720-2-24 73R0514 73R8110 74R0460
R-9720-3 71R7075 73R0512 73R8110 74R0460
R-9720-3-24 71R7075 73R0514 73R8110 74R0460
R-9720-4 RD-5-8641-0P Kit 74R0460
R-9720-4-24 RD-5-8641-3P Kit 74R0460
R-9720-5 71R7075 RD-5-8641-0P Kit 74R0460
R-9720-5-24 71R7075 RD-5-8641-3P Kit 74R0460
R-9720-7 71R7075 73R8582 74R0460
R-9725-0 RD-4-4450-0P 73R8080

R-9725-0, -1 73R0542 73R8080
R-9725-0-24,-1-24 73R0544 73R8080
R-9727-1 71R2250 71R7050 71R8301 73R0542 Cond 73R8110 74R2536
73R4202 Blower 73R6101 LH Blower
73R6151 RH Blower
R-9727-1-24 71R2250 71R7050 71R8301 73R0544 Cond 73R8110 74R2536
73R4204 Blower 73R6101 LH Blower
73R6151 RH Blower
R-9730-0 73R0512 73R8110 74R1866
R-9730-0-24 73R0514 73R8110 74R1866
R-9737-0, 71R3200 71R8301 73R4422 Evap 73R7200 CW 74R2546
-1, -2 RD-5-8705-0P Cond 73R7210 CCW
PAGE 260
Heater
76R7030 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
76R3420 76R6650 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
76R3465 76R6650 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”

76R3465 76R6650 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
76R6040 RD-1-0860-0P 22 5 ⁄ 8” x 5 7 ⁄ 8” x 11 ⁄ 32”
76R6040
76R6040 RD-1-0860-0P 22 5 ⁄ 8” x 5 7 ⁄ 8” x 11 ⁄ 32”
76R6040 RD-1-0860-0P 22 5 ⁄ 8” x 5 7 ⁄ 8” x 11 ⁄ 32”
76R6040
76R6040
77R0100 Hose Assembly for Inverted Condenser Mounting RD-2-2655-13P
Condenser Housing Assembly RD-4-4952-0P
77R0090
77R0090
77R0090
76R7100 77R0350 78R5300 10 3 ⁄ 8” x 2 3 ⁄4” x 5 ⁄ 8
76R7100 77R0350
77R0800
77R0800
76R1860 76R6015 77R0660 78R5370 24” x 4 5 ⁄ 8”
Condenser Housing Assembly
RD-4-4512-1P
PAGE 261

R-9737-0-24, 71R3200 71R8301 73R4424 Evap 73R7200 CW 74R2546
-1-24, -2-24 RD-5-8705-1 Cond 73R7210 CCW
R-9737-3 71R3200 71R8301 73R4422 Evap 73R7200 CW 74R2546

RD-5-8705-0P Cond 73R7210 CCW
R-9737-3-24 71R3200 71R8301 73R4424 Evap 73R7200 CW 74R2546

RD-5-8705-1P Cond 73R7210 CCW
R-9747-0 71R8301
R-9750-0, -1 71R2250 71R8301 73R4252 73R7071
R-9750-0-24, 71R2250 71R8301 73R4254 73R7071
-1-24
R-9750-3, -4, -5, -6 71R2250 71R8301 73R5532
R-9750-6 71R2250 71R8301 73R5534
R-9750-3-24, 71R2250 71R8301 73R5534
-4-24, -5-24, -6-24
R-9755-0 71R3200 71R8301 73R4102 73R7000
R-9755-0-24 71R3200 71R8301 73R4104 73R7000
R-9757-0 71R3200 71R6120 71R8301 73R4422 Evap 73R7200 CW 74R2546
RD-5-8747-4P Cond 73R7210 CCW
R-9757-0-24 71R3200 71R6120 71R8301 73R4424 Evap 73R7200 CW 74R2546
73R8654 73R7210 CCW
R-9775-0 71R3200 71R8301 73R4252 73R7110 CW
73R7120 CCW
R-9777-0,-1 71R3200 71R6150 71R8321 73R5552 74R2546
73R8642 Cond 74R2590
R-9777-0-24,-1-24 71R3200 71R6150 71R8321 73R5554 74R2546
R-9780-0 73R8644 Cond 74R2590
R-9787-0 71R3200
R-9800-0 71R3200 71R8310 73R4422 73R7200
R-9800-0-24 71R3200 71R8310 73R4424 73R7200
73R9202 73R0502 73R6101
Pressurizer
73R9204 73R0504 73R6101
Pressurizer
PAGE 262
Heater
76R1860 76R6015 77R0660 78R5370 24” x 4 5 ⁄ 8”
RD-4-4512-1P
76R1860 76R6015 77R0660 78R5370 24” x 4 5 ⁄ 8”
RD-4-4512-1P
76R1860 76R6015 77R0660 78R5370 24” x 4 5 ⁄ 8”
RD-4-4512-1P
76R6950
76R1000 76R4900 78R5310 20 3 ⁄4” x 4 1 ⁄4” x 2”
76R1000 76R4900 78R5310 20 3 ⁄4” x 4 1 ⁄4” x 2”
76R1000 76R4900 78R5310 20 3 ⁄4” x 4 1 ⁄4” x 2”

76R1000 76R4900
76R1000 76R4900 78R5310 20 3 ⁄4” x 4 1 ⁄4” x 2”
RD-1-1715-0P 76R4920 78R5350 18 7 ⁄ 8” x 4 13 ⁄ 16” x 5 ⁄ 16”

76R4920 78R5350 18 7 ⁄ 8” x 4 13 ⁄ 16” x 5 ⁄ 16”
76R1860 76R6015 77R0660 78R5370
76R1860 76R6015 77R0660 78R5370
76R1560 76R5820 77R1290 78R5410
76R1560 76R5820 77R1290 78R5410
76R1870 76R5700 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”

76R1870 76R5700 78R5360 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
PAGE 263
RED DOT OFF-ROAD KIT REPLACEMENT PARTS
PSI EXPANSION BLOWER BLOWER

Model APPLICATION THERMOSTAT SWITCH VALVE SWITCH MOTOR
R-10003-0-24 John Deere 750/850C Crawler 71R0100 73R0034
R-10004-0 Caterpillar 325 Excavator 71R3200 71R7050 71R8310 71R0010
R-10011-0, -1 John Deere 310D, 410D, 510D 71R3200 71R7050 71R8301
R-10012-4, -5 Komatsu PC 71R3100 71R7075 71R8301 71R0450 73R4254 Evap
R-10015-2, -3 Series Excavators
73R0514 Cond
R-10025-1 John Deere 71R3200 71R7050 71R8301 73R4252 Evap
344E, 444E
73R0542 Cond
R-10034 ALL John Deere 110, 120, 71R3200 71R7050 71R8321 71R0872 73R4424
-4 160, 200, 450 LC
R-10035-0 John Deere 490E 71R3200 71R7050 71R8301 71R0200 73R4104
R-10035-1, John Deere 690E, 790E 71R3200 71R7050 71R8301 71R0200 73R4104
-2, -3, -4, -5 892E, 992E, 792D
R-10036-0 John Deere 344G, 444G 71R3200 71R7050 71R8100 73R0404 Booster
RD-5-8705-1P Cond
R-10040-0 John Deere Upgrade Kit 71R3200 71R7050 71R8301
744E
R-10040-1 John Deere 744E 71R3200 71R7050 71R8301
R-10044-3 Caterpillar 950B - E 71R2310 71R7075 71R8301 RD-5-8641-1P Cond
-4, -5 966, 980 though “C” Kit
R-10045-0 Caterpillar 950F, 966F 71R3200 71R7075 71R8301 RD-5-8641-1P Cond Kit
R-10046-0 Caterpillar 914G/It14G 71R3150 71R7050 71R8301
R-10047-0 Caterpillar 928G/It28G 71R3150 71R7050 71R8301
R-10050-4, -5 Komatso WA350 to 71R3100 71R7075 71R8301 RD-5-8641-1P Cond
-6, -7 WA600 Kit
R-10051-0 Komatsu PC200-6 71R3200 71R8321 73R4424
R-10060-0 John Deere 444H 71R3200 71R7050 71R8321

R-10060-1 John Deere 544H 71R3200 71R7050 71R8321
R-10060-2, -4 John Deere 624H 71R3200 71R7050 71R8321
R-10150-3, John Deere 544E, 71R2310 71R7075 71R8301 RD-5-8641-0P
-4, -5 624E, 644E Cond Kit
R-10151-0, -1 John Deere 544G, 624G 71R3200 71R7050 71R8321 RD-5-8705-0P Cond Kit
R-10160-0, -1 Caterpillar 906 71R3200 71R8301 71R0400 73R4102
R-10170-0 Caterpillar TH26, 63, 82, 83, 103 71R3100 71R7075 71R8301 71R0872 73R4422
RD-5-8641-0P Cond Kit
R-10232 JCB 8052 EXCAVATOR 71R3150 71R7050 71R8321
R-10233 JCB 8060 EXCAVATOR
R-10235-3, -4 Caterpillar Haul Truck
R-10250-0 Kobelco TLK 760, 860, 965 71R3200 71R7050 71R8301 71R1150 73R4102
R-10500-0, -1 Caterpillar Skid Steer 71R3200 71R6150 71R8321 73R5552
PAGE 264
RED DOT OFF-ROAD KIT REPLACEMENT PARTS
R E D DOT HEATER
M OD EL R EPLAC EMENT PARTS
FAN/
BLOWER DRIER CORE EVAPORATOR CONDENSER FILTER/SIZE COMPRESSOR
73R8050 76R1400
74R1866 77R7100 75R8424
74R2586 RD-2-1855-0P 77R0670 75R8362
73R6350 CW 74R0460 76R5300 77R0110 78R5340 75R8614
73R6300 CCW 15 13⁄16” x 4” x 5⁄16”
73R8100 Cond
73R7110 CW 74R2576 77R0090 75R8612
73R7120 CCW
73R8080 Cond
73R7200 CW 74R1826 76R7030 77R7100 78R5360 75R8354
73R7210 CCW 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
73R7000 74R1826 76R1030 76R5030 RD-4-4705-0P 78R5330 75R8614
17” x 3” x 1 ⁄4”
73R7000 74R1826 76R1030 76R5030 77R7000 78R5330 (recirc) 75R8614
17” x 3” x 1 ⁄4”
78R5290 RD-5-7262-0P (fresh air filter)
4” x 6”
73R6300 74R2546 76R6460 77R7005 75R8384
74R2546 76R2010 76R6950
74R2546 76R2010 76R6950 75R8384

74R0460 76R6050 77R0110 75R8614
74R0460 76R7560 77R0110

74R1106 76R7570 77R0650 75R8384
74R1106 76R7570 77R0650 75R8384
74R0460 76R6400 77R0110 75R8614
73R7200 CW 76R3420 76R7030 78R5360 75R8614

73R7210 CCW 17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
74R2576 76R7580 77R0570 75R8354
74R2576 76R7580 77R0570 75R8354
74R2576 76R7580 77R0570 75R8354
74R0460 76R6030 77R0110 75R8612
74R2546 76R6550 77R0660 75R8382

73R7000 74R2536 76R5030 77R0620 78R5330 (Recirc) 75R8432
17 5 ⁄ 16” x 3” x 1 ⁄4”
73R7151 74R0460 76R3500 76R7070 77R0100 78R5360 75R8382
17 1 ⁄ 2” x 5 1 ⁄ 2” x 3 ⁄ 8”
74R1826 76R7550 RD-4-3683-3P 75R8614
76R7550
73R7000 76R4920 77R0670 78R5350 75R8612
18 7⁄ 8” x 4 13 ⁄ 16” x 5 ⁄ 16”
74R2590 76R1560 76R5820 77R1290 75R8332
PAGE 265
RED DOT OFF-ROAD KIT REPLACEMENT PARTS RED DOT OFF-ROAD KIT REPLACEMENT PARTS
PSI EXPANSION BLOWER BLOWER FAN/

R ED DO T MO D EL R EP L A C EM E N T P A RT S
HEATER
MODEL APPLICATION THERMOSTAT SWITCH VALVE SWITCH MOTOR BLOWER DRIER CORE EVAPORATOR CONDENSER FILTER/SIZE COMPRESSOR
R-10003-0-24 John Deere 750/850C Crawler 71R0100 73R0054 73R8050 76R1400
R-10004-0 Caterpillar 325 Excavator 71R3200 71R7050 71R8310 71R0010 74R1866 77R7100 75R8424
R-10011-0, -1 John Deere 310D, 410D, 510D 71R3200 71R7050 71R8301 74R2586 RD-2-1855-0P 77R0670 75R8362
R-10012-4, -5
R-10015-2, -3 Komatsu PC 71R3100 71R7075 71R8301 71R0450 73R4254 Evap 73R6350 CW 74R0460 76R5300 77R0110 78R5340 75R8614
Series Excavators 73R6300 CCW 15 13 ⁄ 16” x 4” x 5 ⁄ 16”
73R0514 Cond 73R8100 Cond
R-10025-1 John Deere 71R3200 71R7050 71R8301 73R4252 Evap 73R7110 CW 74R2576 77R0090 75R8612
344E, 444E 73R7120 CCW
73R0542 Cond 73R8080 Cond
R-10034 ALL John Deere 110, 120, 71R3200 71R7050 71R8321 71R0872 73R4424 73R7200 CW 74R1826 76R7030 77R7100 78R5360 75R8354
-4 160, 200, 450 LC 73R7210 CCW 17 1⁄ 2” x 5 1⁄ 2” x 3 ⁄ 8”
R-10035-0 John Deere 490E 71R3200 71R7050 71R8301 71R0200 73R4104 73R7000 74R1826 76R1030 76R5030 RD-4-4705-0P 78R5330 75R8614
17” x 3” x 1⁄4”
R-10035-1, John Deere 690E, 790E 71R3200 71R7050 71R8301 71R0200 73R4104 73R7000 74R1826 76R1030 76R5030 77R7000 78R5330 (recirc) 75R8614
-2, -3, -4, -5 892E, 992E, 792D 17” x 3” x 1⁄4”
78R5290 RD-5-7262-0P (fresh air ﬁlter)
4” x 6”
R-10036-0 John Deere 344G, 444G 71R3200 71R7050 71R8100 73R0404 Booster 73R6300 74R2546 76R6460 77R7005 75R8384
RD-5-8705-1P Cond
R-10040-0 John Deere Upgrade Kit 71R3200 71R7050 71R8301 74R2546 76R2010 76R6950
744E
R-10040-1 John Deere 744E 71R3200 71R7050 71R8301 74R2546 76R2010 76R6950 75R8384
R-10044-3 Caterpillar 950B - E 71R2310 71R7075 71R8301 RD-5-8641-1P Cond 74R0460 76R6050 77R0110 75R8614
-4, -5 966, 980 though “C” Kit
R-10045-0 Caterpillar 950F, 966F 71R3200 71R7075 71R8301 RD-5-8641-1P Cond Kit 74R0460 76R7560 77R0110
R-10046-0 Caterpillar 914G/It14G 71R3150 71R7050 71R8301 74R1106 76R7570 77R0650 75R8384
R-10047-0 Caterpillar 928G/It28G 71R3150 71R7050 71R8301 74R1106 76R7570 77R0650 75R8384
R-10050-4, -5 Komatso WA350 to 71R3100 71R7075 71R8301 RD-5-8641-1P Cond 74R0460 76R6400 77R0110 75R8614
-6, -7 WA600 Kit
R-10051-0 Komatsu PC200-6 71R3200 71R8321 73R4424 73R7200 CW 76R3420 76R7030 78R5360 75R8614
73R7210 CCW 17 1⁄ 2” x 5 1⁄ 2” x 3 ⁄ 8”
R-10060-0 John Deere 444H 71R3200 71R7050 71R8321 74R2576 76R7580 77R0570 75R8354
R-10060-1 John Deere 544H 71R3200 71R7050 71R8321 74R2576 76R7580 77R0570 75R8354
R-10060-2, -4 John Deere 624H 71R3200 71R7050 71R8321 74R2576 76R7580 77R0570 75R8354
R-10150-3, John Deere 544E, 71R2310 71R7075 71R8301 RD-5-8641-0P 74R0460 76R6030 77R0110 75R8612
-4, -5 624E, 644E Cond Kit
R-10151-0, -1 John Deere 544G, 624G 71R3200 71R7050 71R8321 RD-5-8705-0P Cond Kit 74R2546 76R6550 77R0660 75R8382
R-10160-0, -1 Caterpillar 906 71R3200 71R8301 71R0400 73R4102 73R7000 74R2536 76R5030 77R0620 78R5330 (Recirc) 75R8432
17 5 ⁄ 16” x 3” x 1⁄4”
R-10170-0 Caterpillar TH26, 63, 82, 83, 103 71R3100 71R7075 71R8301 71R0872 73R4422 73R7151 74R0460 76R3500 76R7070 77R0100 78R5360 75R8382
RD-5-8641-0P Cond Kit 17 1⁄ 2” x 5 1⁄ 2” x 3 ⁄ 8”
R-10232 JCB 8052 EXCAVATOR 71R3150 71R7050 71R8321 74R1826 76R7550 RD-4-3683-3P 75R8614
R-10233 JCB 8060 EXCAVATOR
R-10235-3, -4 Caterpillar Haul Truck
R-10250-0 Kobelco TLK 760, 860, 965 71R3200 71R7050 71R8301 71R1150 73R4102 73R7000 76R4920 77R0670 78R5350 75R8612
18 7⁄ 8” x 4 13 ⁄ 16” x 5 ⁄ 16”
R-10500-0, -1 Caterpillar Skid Steer 71R3200 71R6150 71R8321 73R5552 74R2590 76R1560 76R5820 77R1290 75R8332
PAGE 166 PAGE 167

Applications

Uploaded by

Copyright:

Available Formats

You might also like

Applications

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Applications

Uploaded by

Copyright:

Available Formats

On-Road

All Makes Products

All Makes Products

NAVISTAR see IHC - NAVISTAR

STERLING also see FORD and FREIGHTLINER

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

FORD - NEW HOLLAND (FNH)

Model Description OEM Part No. Factory No. Part No.

FORD - NEW HOLLAND (FNH)

Model Description OEM Part No. Factory No. Part No.

FORD - NEW HOLLAND (FNH)

Model Description OEM Part No. Factory No. Part No.

FORD - NEW HOLLAND (FNH)

Model Description OEM Part No. Factory No. Part No.

FORD - NEW HOLLAND (FNH)

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

INTERNATIONAL (IHC) / NAVISTAR

Model Description OEM Part No. Factory No. Part No.

INTERNATIONAL (IHC) / NAVISTAR

Model Description OEM Part No. Factory No. Part No.

INTERNATIONAL (IHC) / NAVISTAR

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.

Model Description OEM Part No. Factory No. Part No.
