N.

: DT2 1920 015

TECHNICAL DESCRIPTIONS
MP190E35W
( CURSOR )

The information in this literature is intended to be of a general nature only. Iveco reserve
the right to modify or change specification at any time.

1
MP190E35W N. : DT2 1920 015

Gearbox ZF 16S-151

Wheelbase Cab Drive Vcb

3800 MPC LEFT HAND DRIVE K0RB12A1

4200 MPC LEFT HAND DRIVE K0RB13A1

MPL LEFT HAND DRIVE K0RB13D1

4500 MPC LEFT HAND DRIVE K0RB14A1

MPL LEFT HAND DRIVE K0RB14D1

2 24/01/00
MP190E35W N. : DT2 1920 015

DIMENSIONS (mm) (AU 0608-D MPC)

A Wheelbase 3800 4200 4500

B Total length 6602 7007 7862

C Front overhang 1440 1440 1440

D Rear overhang 1195 1195 1780

E Max width 2500 2500 2500

F Front axle to back of cab 415 415 415

H Front of body to front axle distance 540 540 540

K Overall height to top of cab, unladen 3202 3202 3202

L Height of frame at frame end, unladen 1243 1241 1247

M Front track 1981 1981 1981

N Rear track 1827 1827 1827

P Minimum ground clearance ( Axle2 ) 316 316 316

Overall width (rear tyres) 2498 2498 2498

Approach angle 27° 27° 27°

Departure angle 18° 18° 12°

Ramp angle 24° 24° 21°

Back of cab to end of frame 4714 5119 5974

Steering radius wall to wall 8000 8550 8975

Steering radius kerb to kerb 7400 7950 8375

Frame top flange to ground (front axle unladen) 1170 1170 1170

Frame top flange to ground (rear axle unladen) 1225 1225 1225

3 24/01/00
MP190E35W N. : DT2 1920 015

DIMENSIONS (mm) (AU 0609-D MPL)

A Wheelbase 4200 4500

B Total length 7007 7862

C Front overhang 1440 1440

D Rear overhang 1195 1780

E Max width 2500 2500

F Front axle to back of cab 855 855

H Front of body to front axle distance 900 900

K Overall height to top of cab, unladen 3202 3202

L Height of frame at frame end, unladen 1241 1247

M Front track 1981 1981

N Rear track 1827 1827

P Minimum ground clearance ( Axle2 ) 316 316

Overall width (rear tyres) 2498 2498

Approach angle 26° 26°

Departure angle 18° 12°

Ramp angle 24° 21°

Back of cab to end of frame 4679 5534

Steering radius wall to wall 8550 8975

Steering radius kerb to kerb 7950 8375

Frame top flange to ground (front axle unladen) 1170 1170

Frame top flange to ground (rear axle unladen) 1225 1225

4 24/01/00
MP190E35W N. : DT2 1920 015

Weights (kg) (BU 0554-D MPC)

Wheelbase 3800 4200 4500

GVW EEC 18000 18000 18000

GVW Series 19000 19000 19000

GCW EEC 40000 40000 40000

GCW Series 44000 44000 44000

Permitted weight on axle 1 EEC 8000 8000 8000

Permitted weight on axle 1 Series 8000 8000 8000

Permitted weight on axle 2 EEC 11500 11500 11500

Permitted weight on axle 2 Series 13000 13000 13000

Body payload EEC 10830 10780 10700

Body payload Series 11830 11780 11700

Vehicle kerbweight 7170 7220 7300

Vehicle kerbweight 1 4740 4765 4775

Vehicle kerbweight 2 2430 2455 2525

Weights (kg) (BU 5554-D MPL)

Wheelbase 4200 4500

GVW EEC 18000 18000

GVW Series 19000 19000

GCW EEC 40000 40000

GCW Series 44000 44000

Permitted weight on axle 1 EEC 8000 8000

Permitted weight on axle 1 Series 8000 8000

Permitted weight on axle 2 EEC 11500 11500

Permitted weight on axle 2 Series 13000 13000

Body payload EEC 10670 10590

Body payload Series 11670 11590

Vehicle kerbweight 7330 7410

Vehicle kerbweight 1 4855 4865

Vehicle kerbweight 2 2475 2545

5 24/01/00
MP190E35W N. : DT2 1920 015

Engine F2B E0681A*A ( EU 0034-D)

Cycle DIESEL

Aspiration type TCA

Injection type UNIT INJECTOR

No. of cylinders 6 IN-LINE

Fuel type DIESEL OIL

4 Stroke / 2 Stroke cycle 4

Total displacement cm³ 7790

Bore / Stroke mm 115 / 125

Max power kW/Hp (1) 259kW 352 Hp 251 Rad / sec 2400 r.p.m.

Specific fuel consumption-max power 216 g/kWh

Max torque rpm Nm (2) 131 Kgm 1280 Nm 202 Rad / sec 1930 r.p.m.

Specific fuel consumption-max torque 194 g/kWh g/Hph

Power loss 0% up to 1500 m sea level

Dry weight Kg 678

Oil capacity kg 25

Crankshaft supported by 7 Bearings

Hydraulic steering pump

Emissions according regulations

Electronic engine management system controls following functions:

- Engine preheating - variable geometry turbocharger - injection control engine brake - speed control-
- cruise control - data exchange with ASR (anti-slip) control - indicators on instrument panel

6 24/01/00
MP190E35W N. : DT2 1920 015

Fuelling (ABU 0008-D)

No. of tanks 1

Total tank capacity l. 300

Fuel pump

Prefilter

Filter

Fuel separator

Air intake (AC 0001-D)

Filter type DRY

Snorkel position BEHIND THE CAB ON THE LEFT

Air intake WITH SNORKEL

Cooling (AD 0001-D)

Cooling system WATER

Fan type VISCOSTATIC

Clutch 16'' (FU 0001-D)

Type SINGLE DRY PLATE

GearboxZF - ZF 16S-151 (GU 0031-D)

Type SYNCRONIZED

Installation ENGINE FLANGED

Control MANUAL DOUBLE H

No. of gears (forward) 16+2 No. of synchro gears 16

Casing material ALUMINIUM

Dry weight Kg 295

Total ratio speed 16.47

Max. torque 163 Kgm/ 163 Nm

Possible P.T.O. installation

Gear ratios

1st 16.47

2nd 13.79

3rd 11.32

4th 9.48

5th 7.79

6th 6.52

7th 5.48

8th 4.58

9th 3.59

10th 3.01

11th 2.47

7 24/01/00
MP190E35W N. : DT2 1920 015

Gear ratios

12th 2.07

13th 1.70

14th 1.42

15th 1.20

16th 1.0

Rev. 1st 15.42

Rev. 2nd 12.91

Transfer box 32180 (HU 0001-D)

Type 2 REDUCTIONS

Installation SEPARATED ON THE FRAME

Shafts no. 3

Front driving axle (LU 0004-D )

Identification 5985

Type BANJO

Axle material CAST IRON

Reduction type HUBS REDUCTION

Rear drive axle (MU 0016-D )

Identification 451391/1

Type BANJO

Axle SINGLE

Wheel arrangement TWIN

Axle box material CAST IRON

Reduction type DOUBLE CENTRAL REDUCTION

Suspensions (NU 0007-D)

Front driving axle SINGLE RATE PARABOLIC SPRING

Rear drive axle VARIABLE FLEXIBILITY SPRING

Main features

Axle no. 1 2

Leaf width mm 90 100

Auxiliary leaf spring length (mm) 1360

Master leaf spring length (mm) 1900 1800

No. of auxiliary leaf springs 6

No. of master leaf springs 3 8

8 24/01/00
MP190E35W N. : DT2 1920 015

Shock absorbers (PU 0002-D)

Shock absorbers no. (front) 2

Shock absorbers no. (rear) 2

Shock absorbers type HYDRAULIC TELESCOPIC

Anti-roll bars (OU 0002-D)

Position FRONT AND REAR AXLE

Wheels (QU 0001-D)

Wheel type DISC

Rim dimensions 22,5" x 9.00"

Tyres (RU 0039-D)

Tyre dimensions 13 R 22.5

Load-index 156/150

Speed index K = 110 Km/h

Rolling radius mm 543

Rolling circumference mm 3410,04

Axle Mounting

1 SINGLE

2 TWIN

Steering 8098 (KU 0002-D)

Type HYDRAULIC

Adjustment type HEIGHT + STEERING WHEEL ANGLE

Max. steering wheel diameter (mm) 500

No. of parts steering column 2

Chassis (mm) (JU 0030-D)

Frame section DOUBLE BOTTLE NECK

Front crossmember fixing BOLTED

Middle crossmember fixing RIVETED - BOLTED

Rear crossmember fixing BOLTED

Wheelbase 3800 4200 4500

Side member material STEEL STEEL STEEL

Side member section "C" "C" "C"

Frame profile CONSTANT HEIGHT CONSTANT HEIGHT CONSTANT HEIGHT

Edge thickness 7.7 7.7 7.7

Web thickness 7.7 7.7 7.7

Upper edge width 80 80 80

Lower edge width 80 80 80

Side member max. height 304.4 304.4 304.4

9 24/01/00
MP190E35W N. : DT2 1920 015

Chassis (mm) (JU 0030-D)

Frame width at rear 771.4 771.4 771.4

10 24/01/00
MP190E35W N. : DT2 1920 015

Brakes (SU 0104-D)

Rear braking control

Air dryer

Air dryer

Auxiliary brake DECOMPRESSION TYPE BRAKE

Emergency brake SERVICE BRAKE

Parking brake SPRING BRAKE

Service brake AIR

Parking brake axles AXLE 2

Total tank capacity l. 65

Air compressor displacement cm³ 460

Air compressor TWO CYLINDER

Air tank material STEEL

Brake standards EEC

No. of circuits 2

Number of air tanks 4

Axle no. Axle 1 Axle 2

Brake type DRUM DRUM

No. of cylinders 2 2

Brake cylinder diameter (inches) 20 20

Drum diameter (mm) 410 410

Friction area cm² 2750 3085

Linings width (mm) 180 200

Electrics (VU 0022-D)

Voltage V 24

Alternator power V/A 24/90

No. of batteries 2

Battery voltage V 12

Battery capacity Ah 143

Starter motor power kW 4.5

Lighting (WU 0002-D)

No. of headlights 2

Type of lamps HALOGEN

Front parking lights

Tail lights

Front side marker lights

Backup lights

Hazard lights

11 24/01/00
MP190E35W N. : DT2 1920 015

Lighting (WU 0002-D)

Number plate lights

Rear fog lights

Side lights

Rear marker lights

Stop lights

Front direction indicators

Side direction indicators

Rear direction indicators

Rear cab lighting

Provision for front fog lights

Cab MPC (YU 0017-D)

Cab type FORWARD CONTROL

Version SHORT CAB

Material STEEL

Steps no. 3

Tilting device HYDRAULIC

Tilt angle 67°

Front doors type WINDOW SASH

Wind-up-window type (front) MANUAL ON RIGHT - MANUAL ON LEFT

Sun visors no. 2

Ceiling no. 1

Roof type LOW

Roof material PLASTIC

Windscreen type STRENGTHENED - LAMINATED

Windscreen ONE PIECE WOUND UP

Windscreen post type EEC/USA

No. of windscreen wipers 2

No. of windscreen wiper speeds 2

Side windows

Rear view mirrors no. 2

Mirror control MANUAL

Kerbside approach mirror

No. of places 2

No. of seats 2

Driver seat type SINGLE - FIXED

Driver seat adjustment IN HEIGHT LENGTH AND BACK INCLINATION

Passenger seat type SINGLE - FIXED

Passenger seat adjustment IN HEIGHT AND LENGTH

Fan speed no. 4

Provision for safety belts

12 24/01/00
MP190E35W N. : DT2 1920 015

Cab MPC (YU 0017-D)

Lighter

CB wiring

Radio wiring

Cab MPL (YU 5017-D)

Cab type FORWARD CONTROL

Version SLEEPER CAB

Material STEEL

Steps no. 3

Tilting device HYDRAULIC

Tilt angle 67°

Front doors type WINDOW SASH

Wind-up-window type (front) MANUAL ON RIGHT - MANUAL ON LEFT

Ceiling no. 1

Roof type LOW

Roof material PLASTIC

Windscreen type STRENGTHENED - LAMINATED

Windscreen ONE PIECE WOUND UP

Windscreen post type EEC/USA

No. of windscreen wipers 2

No. of windscreen wiper speeds 2

Side windows

Rear view mirrors no. 2

Mirror control MANUAL

Kerbside approach mirror

No. of places 2

No. of seats 2

Driver seat type SINGLE - FIXED

Driver seat adjustment IN HEIGHT LENGTH AND BACK INCLINATION

Passenger seat type SINGLE - FIXED

Passenger seat adjustment IN HEIGHT AND LENGTH

Fan speed no. 4

No. of bunks 1

Bunk position LOWER OVERTURNABLE

Provision for safety belts

Lighter

CB wiring

Radio wiring

13 24/01/00
MP190E35W N. : DT2 1920 015

In cab equipment (TU 0013-D)

Warning lights

High beam

Direction indicators (trailer)

Hazard lights

External lights

Low ranges

Longitudinal differential

Front transversal differential

Rear transversal differential

Hand brake on

ASR limiter

Brake failure

Engine preheating

Power take off

Water in fuel prefilter

Clogged air filter

Unhooked cab

Battery charge

Hydraulic steering power failure no. 1

Hydraulic steering power failure no. 2

ABS failure (tractor)

ABS failure (trailer)

EDC

Auxiliary brake

Auxiliary heating

Clogged engine oil filter

Engine brake

Warning lights prearrangement

Tipper in tipping position

Equipment prearrangement

IVECO Control

Switches

External lights

Hazard lights

Rear fog lights + warning light

Lamp tester

Rear cab light

Headlamp wipers

Fog lights

Additional lights

Engine diagnosis Blink Code

14 24/01/00
MP190E35W N. : DT2 1920 015

Switches

Engine brake

Instruments

Rpm counter

Air brakes pressure gauge

Engine oil pressure gauge + warning light

Tachograph (1driver)

MODUS diagnosis system

Water temperature indicator

Fuel level gauge

Socket

Oil gauge level

Multifunction stalk

Horn

High beam

Blinker

Indicator lights

Windscreen wiper with interval

Cruise control speed memory

Cruise control speed set

P.T.O./intersection line for body builders with regard to engine electronics in central electrics.
Central electric box with flap on passenger's side, usable as tabel and holder for a glass,
Tool box.

Miscellaneous (XU 0046-D)

Rear underride protection NO

Jack

Front towing hitch

Tools kit

Drawings (DU 0404-D)

Wheelbase 3800 4200 4500

Left hand drive vehicle 4180 5073 4180 5074 4180 5075
drawing
Sleeper cab frame drawing 4180 3773 4180 3774

Day cab frame drawing 4180 3770 4180 3773 4180 3774

15 24/01/00
MP190E35W N. : DT2 1920 015

Gearbox ZF 16S-151
Tyres 12.00 R 20 20PR
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
17 18 19 20 40 44

4.227 1 - 16.47 7.089 88 83 78 75 37 34

16 - 1 116.7 5.3 5 4.7 4.5 2.2 2
4.666 1 - 16.47 6.422 97 91 87 82 41 37
16 - 1 105.7 5.9 5.5 5.2 5 2.5 2.2
5.008 1 - 16.47 5.984 100 98 93 88 44 40
16 - 1 98.55 6.3 5.9 5.6 5.3 2.6 2.4
6.096 1 - 16.47 4.916 100 100 100 100 54 49
16 - 1 80.96 7.7 7.2 6.9 6.5 3.2 2.9

Gearbox ZF 16S-151
Tyres 13 R 22.5
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
17 18 19 20 40 44

4.227 1 - 16.47 7.063 88 83 79 75 37 34

16 - 1 116.3 5.3 5 4.8 4.5 2.2 2
4.666 1 - 16.47 6.399 97 92 87 83 41 37
16 - 1 105.3 5.9 5.6 5.3 5 2.5 2.2
5.008 1 - 16.47 5.962 100 99 93 89 44 40
16 - 1 98.19 6.3 6 5.7 5.4 2.7 2.4
6.096 1 - 16.47 4.898 100 100 100 100 54 49
16 - 1 80.67 7.7 7.3 6.9 6.5 3.2 2.9

Gearbox ZF 16S-151
Tyres 315/80 R 22.5
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
17 18 19 20 40 44

4.227 1 - 16.47 6.79 92 87 82 78 39 35

16 - 1 111.8 5.5 5.2 5 4.7 2.3 2.1
4.666 1 - 16.47 6.151 100 96 90 86 43 39
16 - 1 101.3 6.1 5.8 5.5 5.2 2.6 2.3
5.008 1 - 16.47 5.731 100 100 97 92 46 42
16 - 1 94.39 6.6 6.2 5.9 5.6 2.8 2.5
6.096 1 - 16.47 4.708 100 100 100 100 56 51
16 - 1 77.55 8 7.6 7.2 6.8 3.4 3.1

16 24/01/00
